ClearCom DIR-TSO-2693
2014 May Price List
Please note that items with no pricing require configuring and will be quoted as a configured system.
Issue 1: April 7 2014
Part
Index
Short Description
Description
DIR Price
1000
ANALOG PARTY LINE INTERCOM AND AUDIO PRODUCTS
1001
ENCORE MAIN STATIONS / POWER SUPPLIES
1002
CS-702
2 Ch. portable headset main station
2 Ch. portable headset main station:
Encore two-channel portable headset main station. Built-in 1-amp (2-amp peak) power
supply. Three XLR-3 Male connectors for each partyline A and B, one XLR-3 female for
Program Audio in and one XLR-3 Male for Stage Announce out on the rear panel.
1003
MS-702
2 Ch. headset/speaker main station
2 Ch. headset/speaker main station:
Encore two-channel headset/speaker main station. Built-in 1-amp (2-amp peak) power
supply, 1RU rack mount. Three XLR-3 Male connectors for each partyline A and B, one XLR-3
female for Program Audio in and one XLR-3 Male for Stage Announce out on the rear panel.
Jack for hot mic out.
$1,141.98
1004
MS-704
4 Ch. headset/speaker main station
4 Ch. headset/speaker main station:
Encore four-channel headset/speaker main station. Built-in 1-amp (2-amp peak) power
supply, 2RU rack mount. Four pairs of XLR-3 Male connectors for partylines A-D, one XLR-3
female for Program Audio in and one XLR-3 Male for Stage Announce out on the rear panel.
Jack for hot mic out.
$1,694.98
$2,189.54
984.62
1005
SB-704
4 Ch. switchboard main station
4 Ch. switchboard main station:
Encore four-channel switchboard main station. 5 positions X 10 outputs assignment matrix,
no speaker. Built-in 1-amp (2-amp peak) power supply, 2RU rack mount. One XLR-3 Male
connectors for each partyline A-D; one XLR-3 Male per Partyline output 1-10; one XLR-3
female for Program Audio in and one XLR-3 Male for Stage Announce out on the rear panel.
Jacks for hot mic out and external loudspeaker.
1006
PS-702
2 Ch. rack mount power supply
2 Ch. rack mount power supply:
Encore two-channel one-amp, (two-amp peak), 1RU rack mount, universal power supply.
Two channels X three intercom jacks. One A/B selectable jack and one program input. Three
XLR-3 Male connectors for each partyline A and B, and one XLR-3 female for Program Audio
in on the rear panel.
$768.81
1007
PS-704
4 Ch. rack mount power supply
4 Ch. rack mount power supply:
Encore four-channel one-amp, two-amp peak, 1RU rack mount system power supply. Four
channels X two intercom jacks. One program input, universal power supply. Two XLR-3 Male
connectors for each partyline A -D, and one XLR-3 female for Program Audio in on the rear
panel.
$984.62
1008
PK-7
Single-Channel 0.4-amp portable power supply
Single-Channel 0.4-amp portable power supply:
Encore single-channel 0.4-amp portable power supply module. Includes universal power
supply. Three XLR-3 Male connectors for partylines on the rear panel.
$296.73
1017
ENCORE BELTPACKS AND HEADSET STATIONS
1018.1
RS-701
Single-Channel standard beltpack
Single-Channel standard beltpack:
Encore single-channel standard beltpack. Four-pin male headset connector and three-pin
female/male loop through intercom line connectors.
$283.25
1019
RS-602
2 Ch. dual listen monaural beltpack
2 Ch. dual listen monaural beltpack:
Encore two-channel standard dual listen monaural beltpack four-pin male headset
connector. Six-pin female/male loop through intercom line connectors. Requires YC-36
adapter to connect with standard three-pin cabling.
$382.16
1019.1
RS-702
2 Ch. dual listen monaural beltpack
2 Ch. dual listen monaural beltpack:
Encore two-channel standard dual listen monaural beltpack four-pin male headset
connector. Six-pin female/male loop through intercom line connectors. Requires YC-36
adapter to connect with standard three-pin cabling.
$382.16
1020
RS-603
2 Ch. TW dual listen monaural beltpack
2 Ch. TW dual listen monaural beltpack:
Encore two-channel/three-pin dual listen monaural beltpack four-pin male headset
connector. Three-pin female/male loop through intercom line connectors. Requires a TWC701.
$418.13
1020.1
RS-703
2 Ch. TW dual listen monaural beltpack
2 Ch. TW dual listen monaural beltpack:
Encore two-channel/three-pin dual listen monaural beltpack four-pin male headset
connector. Three-pin female/male loop through intercom line connectors. Requires a TWC701.
$418.13
1025
VPC-1
V-Pack programming software for 600 series beltpack
V-Pack programming software for 600 series beltpack:
Encore V-Pack configuration software for 600-series beltpack (Windows-based). Includes a
DB-9 female to 3.5 mm/1/8" jack cable to connect beltpack to a PC serial port.
Documentation included.
$60.25
1026
HB-702
2 Ch. flush-mount headset station
2 Ch. flush-mount headset station:
Encore two-channel selectable flush-mount headset station. Mounts in console or standard
two-gang electrical box. Includes a Four-pin male headset connector.
$323.71
1027
HB-704
4 Ch. flush-mount headset station
4 Ch. flush-mount headset station:
Encore four-channel selectable flush-mount headset station. Mounts in console or standard
two-gang electrical box. Includes a Four-pin male headset connector.
$386.65
ClearCom DIR
1 of 33
Part
Index
Short Description
Description
DIR Price
1028
RM-702
2 Ch. remote station rack mount
2 Ch. remote station rack mount:
Encore two-channel 1RU remote station rack mount with internal speaker and ports for
gooseneck microphone and/or headset. Must be used in conjunction with a power supply
such as a PS-702 or MS-702.
$980.12
1029
RM-704
4 Ch. remote station rack mount
4 Ch. remote station rack mount:
Encore four-channel 2RU remote station rack mount with internal speaker and ports for
gooseneck microphone and/or headset. Must be used in conjunction with a power supply
such as a PS-704 or MS-704.
$1,191.43
1030
KB-702
2 Ch. flush-mount headset/speaker station
2 Ch. flush-mount headset/speaker station:
Encore two-channel selectable flush-mount headset/speaker station. Mounts in four-gang
box, console, or V-Box accessory enclosure 21.6cm/8.25" X 11.4cm/4.5". Includes a Four-pin
male headset connector.
$359.68
1031
KB-702GM
2 Ch. flush-mount headset/speaker GN mic
2 Ch. flush-mount headset/speaker GN mic:
Encore two-channel selectable flush-mount headset/speaker station, gooseneck
microphone jack and VOX. Mounts in four-gang box, console, or V-Box accessory enclosure
21.6cm/8.25" X 11.4cm/4.5". Includes a Four-pin male headset connector.
$517.04
1032
KB-701
Single-Channel flush-mount PTT speaker station
Single-Channel flush-mount PTT speaker station:
Encore single-channel half-duplex flush-mount push-to-talk speaker/microphone station
mounts In four-gang box, console, or accessory enclosure 21.6cm/8.25" x 11.4cm/4.5".
$359.68
1033
V-BOX
Wedge shaped enclosure for KB stations
Wedge shaped enclosure for KB stations:
Encore portable wedge-shaped enclosure for angled or vertical mounting. Desktop/wallmount enclosure for KB-701, KB-702GM and KB-702 stations.
$242.78
1034
ENCORE SYSTEM INTERFACES
1035
EB7-4W
4-wire adapter board for KB/HB
4-wire adapter board for KB/HB:
Encore plug-in 4-wire adapter board for KB-701/702 and HB-702/704 stations.
$256.27
1041
EF-701M
4-wire interface with call signal
4-wire interface with call signal:
Encore four-wire interface with call signal. Interfaces matrix to a single channel of standard
or TW party-line.
$687.88
1042
IF4W4
4 Ch., 4-wire interface
4 Ch., 4-wire interface:
Encore four-channel 3/4-wire camera interface. 1RU rack mount provides four discrete ClearCom to 3-wire or 4-wire interface circuits. Can be used to connect to four different two-wire
partyline channels or a single partyline channel with four 4-wire connections.
1043
TW-12C
CC/RTS system interface
CC/RTS system interface:
Clear-Com/RTS system interface - 1RU rack mount. Interface a single intercom channel.
Clear-Com to Clear-Com or Clear-Com to RTS systems.
$989.11
1044
TW-47
2-way radio interface
2-way radio interface:
Clear-Com/RTS two-way radio interface connects Clear-Com or RTS to most two-way radios.
A custom interface cable will be required and is not provided.
$467.58
1044.1
$1,016.09
ENCORE IFB SYSTEM INTERFACES
1045
PIC-4704
IFB central controller
IFB central controller:
Encore IFB main station 1RU rack mount. Requires MA-704/AX-704 controllers and IC-25-6
cable or similar and power supply such as the PS-702.
1046
MA-704
IFB control panel mic jack
IFB control panel mic jack:
Encore IFB control panel with 6.35mm/1/4" microphone jack, four individual talent buttons
and "All" talk button. For use with the PIC-4704. See the optional CEP-RK console for rack
mounting.
$818.27
1047
AX-704
IFB expansion control panel
IFB expansion control panel:
Encore IFB expansion control panel with four individual talent buttons. For use with the PIC4704 and MA-704. See the optional CEP-RK console for rack mounting.
$656.41
1048
TR-50
Monaural IFB talent receiver
Monaural IFB talent receiver:
Wired monaural IFB talent receiver 3.5mm/1/8" mini jack includes TS-1. Requires a ClearCom PSU. See also CC-010A earpiece.
$168.15
1049
CEP-RK
Rack kit for MA-704 and AX-704
Rack kit for MA-704 and AX-704:
1RU rack mount kit for MA-704 and AX-704 control panels. Holds up to three IFB control
panels.
$133.08
1050
TS-1
Monaural talent earphone
Monaural talent earphone:
Monaural talent earphone. Monaural IFB talent earphone. Plugs into TR-50 and wireless IFB
receivers.
$41.36
1051
YC-66
Y adapter for IFB systems
Y adapter for IFB systems:
Six-pin Y adapter for IFB systems. Two six-pin female connectors wired to one six-pin male.
$115.10
1052
QUE-COM INTERCOM COMPONENTS
1053
SMQ-1
Que-Com single-ear headset/beltpack
Que-Com single-ear headset/beltpack:
Que-Com single-ear headset/beltpack combination.
$247.28
ClearCom DIR
$1,002.60
2 of 33
Part
Index
Short Description
Description
DIR Price
3-way intercom line splitter
3-way intercom line splitter:
Three-way intercom line splitter. One three-pin female and three three-pin male XLR-type
connectors.
Commentator/translation console
Commentator/translation console:
On-air announcer box, no 4-wire interface, no 48V phantom power.
$1,204.92
8x24 Ch. program station assignment panel
8x24 Ch. program station assignment panel:
Eight 24-channel programmable station-assignment panel. Stores 14 presets and
expandable up to 15 sources and 72 destinations. Assigns 24 stations or groups to one of
eight party-line channels. 2RU rack mount. See also RCS-WIN software (free of charge) for
assigning PLs.
$2,346.90
RCS-2700 programming software
RCS-2700 programming software:
RCS-2700 programming software for Windows. Now free of charge (and available on our
website).
$0.00
Intercom cable 25 feet
Intercom cable 25 feet:
7.5m/25ft intercom cable - three-pin XLR-type.
$45.86
IC-50
Intercom cable 50 feet
Intercom cable 50 feet:
15.2m/50ft intercom cable - three-pin XLR-type.
$64.74
1068
IC-100
Intercom cable 100 feet
Intercom cable 100 feet:
30.4m/100ft intercom cable - three-pin XLR-type.
$97.11
1069
IC-25-2P
2 pairs superflex intercom cable 25 feet
2 pairs superflex intercom cable 25 feet:
Two pairs 7.6m/25ft intercom cable - six-pin XLR-type for use with RS-602 beltpacks.
$119.59
1070
IC-50-2P
2 pairs superflex intercom cable 50 feet
2 pairs superflex intercom cable 50 feet:
Two pairs 15.2m/50ft intercom cable - six-pin XLR-type for use with RS-602 beltpacks.
$156.46
1071
IC-100-2P
2 pairs superflex intercom cable 100 feet
2 pairs superflex intercom cable 100 feet:
Two pairs 30.4m/100ft intercom cable - six-pin XLR-type for use with RS-602 beltpacks.
$224.80
1072
IC-25-6
4 pairs superflex intercom cable 25 feet
4 pairs superflex intercom cable 25 feet:
Four pairs 7.6m/25ft intercom cable - six-pin XLR-type required to connect PIC-4704 to MA704 and AX-704.
$164.55
1073
IC-50-6
4 pairs superflex intercom cable 50 feet
4 pairs superflex intercom cable 50 feet:
Four pairs 15.2m/50ft intercom cable - six-pin XLR-type required to connect PIC-4704 to MA704 and AX-704.
$215.81
1074
IC-100-6
4 pairs superflex intercom cable 100 feet
4 pairs superflex intercom cable 100 feet:
Four pairs 30.4m/100ft intercom cable - six-pin XLR-type required to connect PIC-4704 to MA704 and AX-704.
$319.21
1075
ENCORE SYSTEM ACCESSORIES
1076
FL-7
Call signal flasher
Call signal flasher:
Encore call signal flasher provides adjustable visual and/or audible indication of a call
signal.
$341.69
1077
WP-2
2 Ch. selectable intercom outlet
2 Ch. selectable intercom outlet:
Encore channel selectable intercom outlet wall plate. Three-pin male connector and
channel select switch on a single-gang wall plate.
$59.35
1078
WP-6
2 Ch. 6-pin intercom outlet
2 Ch. 6-pin intercom outlet:
Two-channel six-pin intercom outlet wall plate six-pin male connector on a single-gang wall
plate for RS-602.
$82.73
1080
YC-36
2 Ch. beltpack adapter
2 Ch. beltpack adapter:
Three-pin to six-pin adapter combines two single-channel three-pin cables into a single twochannel six-pin connector for use with RS-602 beltpacks.
$87.22
1081
TWC-701
TW adaptor module
TW adaptor module:
Two-channel/three-pin XLR adapter module. Combines two intercom channels onto a single
three-pin cable for use with RS-603 beltpacks. Connect up to fifteen RS-603 beltpacks to
TWC-701 output.
$332.70
1083
MT-1
Isolator PCB for PL interface
Isolator PCB for PL interface:
Isolator circuit card for party-line intercom systems. Electrically isolates ground, power and
signaling between two systems.
$188.83
1085
GM-9
9 inch plug-in GN mic
9 inch plug-in GN mic:
22.9cm/9" plug-in gooseneck microphone for party-line stations, i-series and ICS panels.
$169.95
1055
SP-3
1056
BROADCAST AUDIO PRODUCTS
1060
AB-120
1061
PROGRAMMABLE SOURCE-ASSIGNMENT PANEL
1062
RCS-2700
1064
RCS-WIN
1065
ENCORE INTERCONNECT CABLES AND CONNECTORS
1066
IC-25
1067
ClearCom DIR
$69.24
3 of 33
Part
Index
Short Description
Description
DIR Price
18 inch plug-in GN mic
18 inch plug-in GN mic:
45.8cm/18" plug-in gooseneck microphone for party-line stations, i-series and ICS panels.
HMS-4X
HelixNet digital 4 Ch. headset/speaker main station
HelixNet digital 4 Ch. headset/speaker main station:
HelixNet digital four-channel headset/speaker main station - supports up to 20 HBP-2X
beltpacks. Three rear panel expansion bays accept up to three (optional) interface
modules. Uses optional 110/340 series gooseneck microphones. High-contrast OLED display
per channel.
2002
HBP-2X
HelixNet digital 2 Ch. dual listen monaural beltpack
HelixNet digital 2 Ch. dual listen monaural beltpack:
HelixNet digital two-channel standard dual listen monaural beltpack with display and fourpin male headset connector. Three-pin female/male loop through intercom line connectors.
High-contrast OLED display.
$845.24
2002.5
HBP-2XS
HelixNet digital 2 Ch. dual listen beltpack
HelixNet digital 2 Ch. dual listen beltpack:
HelixNet digital two-channel standard dual listen beltpack with display and five-pin female
headset connector. Three-pin female/male loop through intercom line connectors. Highcontrast OLED display.
$845.24
2003
HLI-4W2
HelixNet 4-wire module
HelixNet 4-wire module:
4-wire interface module. Dual channel 4-wire interface with transformer balancing.
$804.78
2004
HLI-2W2
HelixNet 2-wire module
HelixNet 2-wire module:
2-wire Clear-Com/RTS dual party-line interface module. Does not power the party-lines
attached to HLI-2W2 modules. These require Encore master station PSUs such as the PS-702 or
MS-702 or RTS equivalent power supply.
$921.67
2005
HLI-ET2
HelixNet Ethernet module
HelixNet Ethernet module:
Ethernet interface module. Dual channel Ethernet for LAN connectivity.
$494.56
HLI-FBS
HelixNet Fiber module
HelixNet Fiber module:
Fiber interface module. The HLI-FBS Fiber Linking Module provides a daisy-chain fiber
interface to connect to other HelixNet Main Stations.
With the Fiber Modules, Main stations share partyline channels and program audio, and
make them available to any station and beltpack
on the linked system. Fiber Modules can be mixed with Ethernet Modules in the same
network.
The HLI-FBS comes with one SFP LC duplex Single Mode transceiver, (see sales options for HLIMMFO and HLI-SMFO).
$494.56
2006.5
HLI-MMFO
HelixNet Fiber MM TxVr
HelixNet Fiber MM TxVr:
One Multi-Mode transceiver for the HelixNet HLI-FBS fiber module. The HLI-FBS fiber module
accepts two SFP transceivers and comes with one with SM transceiver already fitted. The HLIFBS module can mix the fitted default Single Mode transceiver with one of these Multi-Mode
transceivers for two different fiber links.
$85.42
2006.6
HLI-SMFO
HelixNet Fiber SM TxVr
HelixNet Fiber SM TxVr:
One Single-Mode transceiver for the HelixNet HLI-FBS fiber module. The HLI-FBS fiber module
takes two SFP transceivers and comes with one SM transceiver already fitted. The HLI-FBS
module can house two fiber transceivers when the module is in the middle of chained fiber
link with other HLI-FBS modules either side.
2007
HRM-4X
HelixNet Remote Station
HelixNet Remote Station:
HelixNet digital four-channel headset/speaker remote station. Powered though single
screened twisted pair PL cable, PoE or external wall AC adapter. Uses optional 110/340
series gooseneck microphones. High-contrast OLED display per channel.
$2,158.07
2008
HKB-2X
HelixNet Speaker Station
HelixNet Speaker Station:
HelixNet digital two-channel headset/speaker wall station. Powered though single screened
twisted pair PL cable, PoE or external wall AC adapter. Uses optional 110/340 series
gooseneck microphones. High-contrast OLED display per channel. Can be fitted into a 4
gang US standard wall plate or mounted in the S-Mount wall and desktop mount.
$1,303.83
2009
S-MOUNT
HelixNet Wall/Desk Mount
HelixNet Wall/Desk Mount:
HelixNet desktop or wall mounting kit for the HKB-2X.
1086
GM-18
2000
HELIXNET DIGITAL NETWORKED PARTYLINE
2001
2006
ClearCom DIR
$178.94
$3,682.20
$107.90
$359.68
4 of 33
Part
Index
Short Description
Description
DIR Price
Single-Channel wireless UHF base station, band A2
Single-Channel wireless UHF base station, band A2:
Single-channel frequency-agile UHF wireless intercom base station band A2. Tx: 518-536 MHz
Rx: 632-650 MHz.
$4,131.80
WBS-670/B4
Single-Channel wireless UHF base station, band B4
Single-Channel wireless UHF base station, band B4:
Single-channel frequency-agile UHF wireless intercom base station band B4. Tx: 536-554 MHz
Rx: 668-686 MHz.
$4,131.80
3008
WBS-680/A2
2 Ch. wireless UHF base station, band A2
2 Ch. wireless UHF base station, band A2:
Two-channel frequency-agile UHF wireless intercom base station band A2. Tx: 518-536 MHz
Rx: 632-650 MHz.
$5,368.19
3009
WBS-680/B4
2 Ch. wireless UHF base station, band B4
2 Ch. wireless UHF base station, band B4:
Two-channel frequency-agile UHF wireless intercom base station band B4. Tx: 536-554 MHz
Rx: 668-686 MHz.
$5,368.19
3012
WBS-680/E88
2 Ch. wireless UHF base station, band E88
2 Ch. wireless UHF base station, band E88:
Two-channel frequency-agile UHF wireless intercom base station band E88. Tx: 590-608 MHz
Rx: 470-488 MHz.
$5,368.19
3013
WBS TRANSCEIVER BELTPACKS
3014
WTR-670/A2
Single-Channel wireless UHF transceiver, band A2
Single-Channel wireless UHF transceiver, band A2:
Single-channel frequency-agile UHF wireless intercom beltpack. Tx: 632-650 MHz Rx: 518-536
MHz.
$1,344.29
3015
WTR-670/B4
Single-Channel wireless UHF transceiver, band B4
Single-Channel wireless UHF transceiver, band B4:
Single-channel frequency-agile UHF wireless intercom beltpack. Tx: 668-686 MHz Rx: 536-554
MHz.
$1,344.29
3019
WTR-680/A2
2 Ch. wireless UHF transceiver, band A2
2 Ch. wireless UHF transceiver, band A2:
Two-channel frequency-agile UHF wireless intercom beltpack. Tx: 632-650 MHz Rx: 518-536
MHz.
$1,703.97
3020
WTR-680/B4
2 Ch. wireless UHF transceiver, band B4
2 Ch. wireless UHF transceiver, band B4:
Two-channel frequency-agile UHF wireless intercom beltpack. Tx: 536-554 MHz Rx: 668-686
MHz.
$1,703.97
3023
WTR-680/E88
2 Ch. wireless UHF transceiver, band E88
2 Ch. wireless UHF transceiver, band E88:
Two-channel frequency-agile UHF wireless intercom beltpack. Tx: 470-488 MHz Rx: 590-608
MHz.
$1,703.97
3029
WBS WIRELESS ACCESSORIES
3045
WTR-BAT
Rechargeable battery pack WTR-670/680
Rechargeable battery pack WTR-670/680:
Rechargeable battery pack for WTR-670 or WTR-680 beltpack.
3048
WTR4C
4-bay charger for WTR-BAT US
4-bay charger for WTR-BAT US:
50/60Hz power supply including US AC connector battery charger for four WTR-BAT
rechargeable batteries, 110V and four WTR-BAT rechargeable batteries.
3050
IFB WIRELESS SYSTEM
3051
PRC-2/D
UHF IFB receiver beltpack, frequency block 24
UHF IFB receiver beltpack, frequency block 24:
UHF wireless IFB receiver beltpack. Coordinated with the receive frequencies of the PTX-2/D.
614.4 - 639.9 MHz.
$719.36
3052
PRC-2/E
UHF IFB receiver beltpack, frequency block 25
UHF IFB receiver beltpack, frequency block 25:
UHF wireless IFB receiver beltpack. Coordinated with the receive frequencies of the PTX-2/E.
640.0 - 665.5 MHz.
$719.36
3053
PRC-2/F
UHF IFB receiver beltpack, frequency block 26
UHF IFB receiver beltpack, frequency block 26:
UHF wireless IFB receiver beltpack. Coordinated with the receive frequencies of the PTX-2/F.
665.6 - 691.1 MHz.
$719.36
3054
PTX-3/D
UHF IFB transmitter base station, frequency block 24
UHF IFB transmitter base station, frequency block 24:
UHF wireless IFB transmitter base station with 256 selectable frequencies at 100 kHz
increments. Supplied with TP12E power supply. Stand-alone or rack mountable with the PRK2 kit. 614.4 - 639.9 MHz.
$1,258.87
3055
PTX-3/E
UHF IFB transmitter base station, frequency block 25
UHF IFB transmitter base station, frequency block 25:
UHF wireless IFB transmitter base station with 256 selectable frequencies at 100 kHz
increments. Stand-alone or rack mountable with the PRK-2 kit. 640.0 - 665.5 MHz.
$1,258.87
3056
PTX-3/F
UHF IFB transmitter base station, frequency block 26
UHF IFB transmitter base station, frequency block 26:
UHF wireless IFB transmitter base station with 256 selectable frequencies at 100 kHz
increments. Supplied with TP12E power supply. Stand-alone or rack mountable with the PRK2 kit. 665.6 - 691.1 MHz.
$1,258.87
3057
PRK-2
Rack mount kit PTX-3 transmitter
Rack mount kit PTX-3 transmitter:
1RU rack mount kit for the PTX-3 transmitter. Up to four transmitters can be rack mounted
using the kit.
3300
HME PRO850 COMPLETE WIRELESS SYSTEMS
3000
3001
3002
ANALOG WIRELESS
WBS-670 & WBS-680 FREQUENCY AGILE UHF WIRELESS INTERCOM SYSTEMS
WBS BASE STATIONS
3003
WBS-670/A2
3004
ClearCom DIR
$124.99
$1,429.72
$238.29
5 of 33
Part
Index
3301
3302
3303
CZ11323-1
CZ11323-2
CZ11323-4
Short Description
Description
DIR Price
4-Up PRO850 2 Ch. system, band 1
4-Up PRO850 2 Ch. system, band 1:
BS850 Two-Channel base station with 2 transmitters & 4 receiver modules; 2 antennas.
115/230 VAC power supply. 1 each 115 VAC & 230 VAC power cord, 4 single channel BP850
Beltpacks each with alkaline battery sled & 2 antennas, PRO850 software, beltpack
configuration cable and manual. base TX Band 1: 488-506MHz. Beltpack TX Band 9: 632650MHz. For beltpack dual band operation you must order Dual Receiver Module
$10,695.91
4-Up PRO850 2 Ch. system, band 2
4-Up PRO850 2 Ch. system, band 2:
BS850 Two-Channel base station with 2 transmitters & 4 receiver modules, 2
antennas,115/230 VAC power supply, 1 each 115 VAC & 230 VAC power cords, 4 single
channel BP850 Beltpacks each with alkaline battery sled & 2 antennas, PRO850 software,
beltpack configuration cable and manual. base TX Band 2: 506-524MHz. Beltpack TX Band A:
650-668MHz. For beltpack dual band operation you must order Dual Receiver Module
$10,695.91
4-Up PRO850 2 Ch. system, band 4
4-Up PRO850 2 Ch. system, band 4:
BS850 Two-Channel base station with 2 transmitters & 4 receiver modules, 2 antennas;
115/230 VAC power supply, 1 each 115 VAC & 230 VAC power cords, 4 single channel BP850
Beltpacks each with alkaline battery sled & 2 antennas, PRO850 software, beltpack
configuration cable and manual. base TX Band 4: 542-560MHz. Beltpack TX Band C: 686704MHz. For beltpack dual band operation you must order Dual Receiver Module
$10,695.91
$9,239.22
3304
CZ11386-1
4-Up PRO850-1 Single-Channel system, band 1
4-Up PRO850-1 Single-Channel system, band 1:
BS850 Single-Channel base station with 1 transmitter & 4 receiver modules, 2 antennas,
115/230 VAC power supply, 1 each 115 VAC & 230 VAC power cords, 4 single channel BP850
Beltpacks each with alkaline battery sled & 2 antennas, PRO850 software, beltpack
configuration cable and manual. base TX Band 1: 488-506MHz. Beltpack TX Band 9: 632650MHz. For beltpack dual band operation you must order Dual Receiver Module.
3305
CZ11386-2
4-Up PRO850-1 Single-Channel system, band 2
4-Up PRO850-1 Single-Channel system, band 2:
BS850 Single-Channel base station with 1 transmitter & 4 receiver modules, 2 antennas,
115/230 VAC power supply, 1 each 115 VAC & 230 VAC power cords, 4 BP850 Beltpacks
each with alkaline battery sled & 2 antennas, PRO850 software, beltpack configuration
cable and manual. base TX Band 2: 506-524MHz. Beltpack TX Band A: 650-668MHz
$9,239.22
4-Up PRO850-1 Single-Channel system, band 4
4-Up PRO850-1 Single-Channel system, band 4:
BS850 Single-Channel base station with 1 transmitter & 4 receiver modules, 2 antennas;
115/230 VAC power supply, 1 each 115 VAC & 230 VAC power cords, 4 single channel BP850
Beltpacks each with alkaline battery sled & 2 antennas, PRO850 software, beltpack
configuration cable and manual. base TX Band 4: 542-560MHz. Beltpack TX Band C: 686704MHz
$9,239.22
3306
CZ11386-4
3307
HME PRO850 WIRELESS BELTPACKS
3308
CZ11427-91
BP850 2 Ch. beltpack, band 9/1
BP850 2 Ch. beltpack, band 9/1:
BP850 Single or dual channel beltpack with battery sled and antennas, TX Band 9: 632650MHz. For use with the BS850 base station, Band 1. For dual band operation you must order
Dual Receiver Module
$1,290.34
3309
CZ11427-A1
BP850 2 Ch. beltpack, band A/2
BP850 2 Ch. beltpack, band A/2:
BP850 Single or dual channel beltpack with battery sled and antennas, TX Band A: 650668MHz. For use with the BS850 base station, Band 2. For dual band operation you must order
Dual Receiver Module
$1,290.34
3310
CZ11427-C1
BP850 2 Ch. beltpack, band C/4
BP850 2 Ch. beltpack, band C/4:
BP850 Single or dual channel beltpack with battery sled and antennas, TX Band C: 686704MHz. For use with the BS850 base station, Band 4. For dual band operation you must order
Dual Receiver Module
$1,290.34
3311
CZ11427-92
BP850 2 Ch. beltpack, dual talk/listen, band 9/1
BP850 2 Ch. beltpack, dual talk/listen, band 9/1:
BP850 Two-Channel dual band beltpack with battery sled and antennas, TX Band 9: 632650MHz. For use with the BS850 base station, Band 1. Dual band receiver module installed.
$1,685.99
3312
CZ11427-A2
BP850 2 Ch. beltpack, dual talk/listen, band A/2
BP850 2 Ch. beltpack, dual talk/listen, band A/2:
BP850 Two-Channel dual band beltpack with battery sled and antennas, TX Band A: 650668MHz. For use with the BS850 base station, Band 2. Dual band receiver module installed.
$1,685.99
3313
CZ11427-C2
BP850 2 Ch. beltpack, dual talk/listen, band C/4
BP850 2 Ch. beltpack, dual talk/listen, band C/4:
BP850 Two-Channel dual band beltpack with battery sled and antennas, TX Band C: 686704MHz. For use with the BS850 base station, Band 4. Dual band receiver module installed.
$1,685.99
3314
HME PRO850 WIRELESS BASESTATIONS
3315
CZ11424-5124
BS850 base station w/ 2 transmitters, band 1
BS850 base station w/ 2 transmitters, band 1:
BS850 Two-Channel base station with 2 Transmitter 4 Receiver power supply, power cord,
antennas, Transmit Band: 1 (488-506MHz)
$5,534.54
3315.1
CZ11424-5224
BS850 base station w/ 2 transmitters, band 2
BS850 base station w/ 2 transmitters, band 2:
BS850 Two-Channel base station with 2 Transmitter 4 Receiver power supply, power cord,
antennas, Transmit Band: 2 (506-524MHz)
$5,534.54
3315.2
CZ11424-5424
BS850 base station w / 2 transmitters, band 4
BS850 base station w / 2 transmitters, band 4:
BS850 Two-Channel base station with 2 Transmitter 4 Receiver power supply, power cord,
antennas, Transmit Band: 4 (542-560MHz)
$5,534.54
ClearCom DIR
6 of 33
Part
Index
Short Description
Description
DIR Price
3316
CZ11424-5114
BS850 base station w/ 1 transmitter, band 1
BS850 base station w/ 1 transmitter, band 1:
BS850 Single-Channel base station with 1 Transmitter 4 Receiver power supply, power cord,
antennas, Transmit Band: 1 (488-506MHz)
$4,077.84
3316.1
CZ11424-5214
BS850 base station w/ 1 transmitter, band 2
BS850 base station w/ 1 transmitter, band 2:
BS850 Single-Channel base station with 1 Transmitter 4 Receiver power supply, power cord,
antennas, Transmit Band: 2 (506-524MHz)
$4,077.84
3316.2
CZ11424-5414
BS850 base station w/ 1 transmitter, band 4
BS850 base station w/ 1 transmitter, band 4:
BS850 Single-Channel base station with 1 Transmitter 4 Receiver power supply, power cord,
antennas, Transmit Band: 4 (542-560MHz)
$4,077.84
3500
3501
DIGITAL WIRELESS
FREESPEAK / CELLCOM (1.9GHz)
3503
CELLCOM-BASE
CellCom 1.92 GHz digital wireless base station
CellCom 1.92 GHz digital wireless base station:
Cell-Com Digital license-free wireless base station. Supports up to 20 Beltpacks and 10
antennas. (Two antennas can connect to the base station directly or up to 10 antennas can
be connected by using two x PD2203 splitters) The base station has connections for two
party-lines and 4 4-wires plus a dedicated SA output and dedicated program audio input.
$9,877.64
3505
CEL-BP
CellCom digital wireless beltpack
CellCom digital wireless beltpack:
Digital wireless beltpack including two talk and listen keys with integral crosspoint level
rotary controls and answerback/menu key. LED level and call signalization and LCD menu.
Including XLR-4M headset connector, PC set-up and DC charging connections, protective
case, belt clips, shoulder strap, rechargeable batteries, battery sled and single AC charger.
$1,398.25
3507
CEL-TA
CellCom active antenna
CellCom active antenna:
Active antenna, one supports up to five beltpacks. More antennas needed if roaming or
more beltpack support is required. Including PSU.
$1,312.82
3508
PD2203
FreeSpeak/CellCom antenna splitter
FreeSpeak/CellCom antenna splitter:
Antenna splitter box. Provides five antenna feeds from one antenna port on the
FreeSpeak/CellCom-base station or FreeSpeak/CellCom Integra rear card. Including PSU.
$2,005.20
3509
FREESPEAK/CELLCOM ACCESSORIES
3511
740112+BAT
CellCom/FreeSpeak beltpack battery pack
CellCom/FreeSpeak beltpack battery pack:
Spare battery pack including 4 AA rechargeable batteries.
3514
CEL-FS-CHRGR
5-way battery clip charger
5-way battery clip charger:
FreeSpeak/CellCom battery clip charger. The units houses and charges five battery clips.
3600
HME DX100 COMPLETE DIGITAL WIRELESS SYSTEMS (2.4GHz)
$44.96
$512.54
3601
CZ11383
4-Up DX100 system without headsets
4-Up DX100 system without headsets:
MB100 Single-Channel stand-alone license-free mobile base station w/2 antennas; 115/230
VAC power supply, 115VAC power cord, AA battery sled for base; 4 BP200 Beltpacks with; 8
BAT41 batteries and 4 pouches; AC40A Battery Charger; 115/230 VAC power supply, 115VAC
power cord, manual *No headsets are included with this system*
3602
CZ11396
4-Up DX100 system w/ WH200 headsets
4-Up DX100 system w/ WH200 headsets:
MB100 Single-Channel stand-alone license-free mobile base station w/2 antennas; 115/230
VAC power supply, 115VAC power cord, AA battery sled for base; 4 WH200 All-In-OneWireless Headsets with; 8 BAT41 batteries; AC40A Battery Charger; 115/230 VAC power
supply, 115VAC power cord, manual
$4,783.71
3603
CZ11433
4-Up DX100 system w/ HS15 headsets
4-Up DX100 system w/ HS15 headsets:
MB100 Single-Channel stand-alone license-free mobile base station w/2 antennas; 115/230
VAC power supply, 115VAC power cord, AA battery sled for base; 4 BP200 Beltpacks with; 8
BAT41 batteries and 4 pouches; 4 HS15 Single Muff Noise canceling Headsets, AC40A Battery
Charger,115/230 VAC power supply, 115VAC power cord, manual
$5,350.20
3605
HME DX121 COMPLETE SYSTEMS (2.4GHz)
3606
CZ11465
DX121 system without headsets
DX121 system without headsets:
BS121 license-free base station with HS-XLR4F Interface cable, 2 antennas, 115/230 VAC
power supply, 115VAC power cord, 1 BP200 Beltpack with 2 BAT41 batteries and pouch,
manual *No headset is included with this system*
$2,409.84
3607
CZ11464
DX121 system w/ WH200 headset
DX121 system w/ WH200 headset:
BS121 license-free base station with HS-XLR4F Interface cable, 2 antennas, 115/230 VAC
power supply, 115VAC power cord, WH200 All-In-One-Wireless Headset with 2 BAT41
batteries, manual
$2,432.32
3608
CZ11462
DX121 system w/ HS15 headset
DX121 system w/ HS15 headset:
BS121 license-free base station with HS-XLR4F Interface cable, 2 antennas, 115/230 VAC
power supply, 115 VAC power cord, BP200 Beltpack with 2 BAT41 batteries and pouch; 1
HS15 Single Muff Noise canceling Headset, manual
$2,571.69
3611
HME DX200 COMPLETE SYSTEMS (2.4GHz)
4-Up DX200 system without headsets
4-Up DX200 system without headsets:
BS200 license-free base station w/2 antennas; 115/230 VAC power supply; 115VAC power
cord, 4 BP200 Beltpacks with; 8 BAT41 batteries and 4 pouches; AC40A Battery Charger;
115/230 VAC power supply, 115VAC power cord, manual *No headsets are included with
this system*
$6,681.01
3612
CZ11375
ClearCom DIR
$4,689.30
7 of 33
Part
Index
Short Description
Description
DIR Price
3613
CZ11447
4-Up DX200 system w/ WH200 headsets
4-Up DX200 system w/ WH200 headsets:
BS200 license-free base station w/2 antennas; 115/230 VAC power supply; 115 VAC power
cord, 4 WH200All-In-One-Wireless Headsets with 8 BAT41 batteries; 1 HS15 Single Muff Noise
canceling Headset; AC40A Battery Charger; 115/230 VAC power supply, 115VAC power
cord, manual
$6,937.28
3614
CZ11432
4-Up DX200 system w/ HS15 headsets
4-Up DX200 system w/ HS15 headsets:
BS200 license-free base station w/2 antennas; 115/230 VAC power supply; 115 VAC power
cord, 4 BP200 Beltpacks with; 8 BAT41 batteries and 4 pouches; 5 HS15 Single Muff Noise
canceling Headsets; AC40A Battery Charger; 115/230 VAC power supply, 115VAC power
cord , manual
$7,503.77
3615.1
HME DX210 COMPLETE SYSTEMS (2.4GHz)
3615.2
CZ11513
4-Up DX210 system w/ HS15 headsets
4-Up DX210 system w/ HS15 headsets:
BS210 license-free base station w/2 antennas; 115/230 VAC power supply; 115 VAC power
cord, 4 BP210 Beltpacks with; 8 BAT41 batteries and 4 pouches; 5 HS15 Single Muff Noise
Canceling Headsets; AC40A Battery Charger; 115/230 VAC power supply, 115VAC power
cord, manual.
$8,920.00
3615.3
CZ11514
4-Up DX210 system w/ WH210 headset
4-Up DX210 system w/ WH210 headset:
BS210 license-free base station w/2 antennas; 115/230 VAC power supply; 115 VAC power
cord, 4 WH210 All-in-one-Wireless Headsets with 8 batteries; 1 HS15 Single Muff Noise
canceling Headset, AC40A Battery Charger; 115/230 VAC power supply, 115VAC power
cord, manual.
$8,245.61
3615.4
CZ11515
4-Up DX210 system without Headsets
4-Up DX210 system without Headsets:
BS210 license-free base station w/2 antennas; 115/230 VAC power supply; 115 VAC power
cord, 4 BP210 Beltpacks with; 8 BAT41 batteries and 4 pouches; AC40A Battery Charger;
115/230 VAC power supply, 115VAC power cord, manual.
$8,097.24
3620
HME DX100, DX121, DX200 AND DX210 COMMUNICATORS
3621
CZ11434
BP200 beltpack w/HS15 headset
BP200 beltpack w/HS15 headset:
Beltpack with 2 BAT41 batteries, pouch, HS15 Single Muff Noise canceling Headset
$863.23
3622
CZ11435
BP200 beltpack w/HS15D headset
BP200 beltpack w/HS15D headset:
Beltpack with 2 BAT41 batteries, pouch, HS15D Dual Muff Noise canceling Headset
$971.13
3623
CZ11442
BP200 beltpack w/HS16 headset
BP200 beltpack w/HS16 headset:
Beltpack with 2 BAT41 batteries, pouch, HS16 Single Muff Lightweight Headset
$831.75
3624
CZ11381
BP200 beltpack w/HS4-3 earpiece and lapel mic
BP200 beltpack w/HS4-3 earpiece and lapel mic:
Beltpack with 2 BAT41 batteries, pouch, HS4-3 Earpiece Lapel Mic Kit
$777.80
3625
CZ11360
BP200 beltpack without headset
BP200 beltpack without headset:
Beltpack with 2 BAT41 batteries, pouch
$701.37
3626
CZ11392
WH200 wireless headset
WH200 wireless headset:
All-In-One Wireless Headset with 2 BAT41 batteries, headstrap
$723.85
3628.1
CZ11517
BP210 beltpack without headset
BP210 beltpack without headset:
Two-Channel Belt pack with 2 BAT41 batteries and pouch. For use with the DX210 base
station.
$894.70
3628.2
CZ11518
WH210 wireless headset
WH210 wireless headset:
All-In-One Wireless Headset with 2 BAT41 batteries, headstrap. For use with the DX210 base
station.
$890.20
3629
HME DX300ES COMMUNICATORS (2.4GHz)
3630
CZ11439
BP300 beltpack w/HS15 headset, MB300ES base station only
3631
CZ11440
BP300 beltpack w/HS15D headset, MB300ES base station only
BP300 beltpack w/HS15D headset, MB300ES base station only:
Beltpack with 1 BAT41 battery, pouch, and HS15D Dual Muff Noise canceling Headset
$615.95
3632
CZ11408
BP300 beltpack without headset, MB300ES base station only
BP300 beltpack without headset, MB300ES base station only:
Beltpack with 1 BAT41 battery, and pouch
$341.69
3633
CZ11407
WH300 all-in-one wireless headset, MB300ES base station only
WH300 all-in-one wireless headset, MB300ES base station only:
All-In-One Wireless Headset with 1 BAT41 battery, and headstrap
$503.55
3634
HME DX SERIES BASESTATIONS (2.4GHz)
3635
CZ11400
MB100 base station
MB100 base station:
Base station with 115/230VAC power supply, 115VAC power cord, base battery sled, 2
antennas, and manual
$1,335.30
3636
CZ11461
BS121 base station
BS121 base station:
Base station with HS-XLR4F Interface cable, 115/230VAC power supply, 115VAC power cord,
2 antennas, and manual
$1,708.47
ClearCom DIR
BP300 beltpack w/HS15 headset, MB300ES base station only:
Beltpack with 1 BAT41 battery, pouch, and HS15 Single Muff Noise canceling Headset
$508.04
8 of 33
Part
Index
Short Description
Description
DIR Price
3637
CZ11398
BS200 base station without headset
BS200 base station without headset:
License-free base station with 115/230VAC power supply, 115VAC power cord, 2 antennas,
and manual
$3,322.52
3639.1
CZ11516
BS210 base station without headset
BS210 base station without headset:
DX210 license-free base station w/2 antennas. 115/230 VAC power supply. Includes 115 VAC
power cord and manual.
$3,951.96
3640
CZ11467
MB300ES base station
MB300ES base station:
License-free base station with 115/230VAC power supply, 115VAC power cord, two AA
battery sleds, two antennas, interconnect cable, and manual
$2,733.55
3800
TEMPEST2400 DIGITAL WIRELESS (2.4 GHz)
3801
CM-244
Tempest2400 2.4 GHz 4 Ch. Basestation
Tempest2400 2.4 GHz 4 Ch. Basestation:
Tempest 2.4 GHz four-channel, full feature license-free Basestation. Including AC power
cord, USB cable, 6ft programming cable with ⅛" (3.5mm) straight mini-jack connector, two
whip antennas and T-desk software. Supports up to five wireless BeltStations in normal mode
and unlimited BeltStations in shared and split modes. Seamless roaming capable.
$5,750.34
3802
CM-222
Tempest2400 2.4 GHz 2 Ch. Basestation
Tempest2400 2.4 GHz 2 Ch. Basestation:
Tempest 2.4 GHz two-channel, full feature license-free Basestation. Including AC power
cord, USB cable, 6ft programming cable with ⅛" (3.5mm) straight mini-jack connector, one
whip antenna and T-desk software. Supports up to five wireless BeltStations in normal mode
and unlimited BeltStations in shared and split modes. Seamless roaming capable.
$4,491.47
$2,378.37
3802.1
CB-222
Tempest2400 2.4 GHz 2 Ch. MasterBelt
Tempest2400 2.4 GHz 2 Ch. MasterBelt:
Tempest 2.4 GHz 2 channel, dual-listen wireless Master Beltstation as a mobile Basestation.
Allows up to five Normal Mode (CP-222) BeltStations and unlimited Shared Mode
BeltStations, to connect to a single BeltStation which acts as Basestation, 4-PIN male XLR,
program port and USB connector. Comes with USB cable, 1/8" stereo mini programming
cable, 2000mAh Li-Poly rechargeable battery and multi-blade international wall charger.
Does not require a Basestation to function and will not pair with a Basestation.
3803
CP-242
Tempest2400 2.4 GHz 4 Ch. BeltStation
Tempest2400 2.4 GHz 4 Ch. BeltStation:
Tempest 2.4 GHz four-channel, dual listen wireless BeltStation, four-pin male XLR, program
port and USB connector. Including Li-poly rechargeable battery and AC USB wall charger.
Seamless roaming capable.
$1,919.78
3804
CP-222
Tempest2400 2.4 GHz 2 Ch. BeltStation
Tempest2400 2.4 GHz 2 Ch. BeltStation:
Tempest 2.4 GHz two-channel, dual listen wireless BeltStation, four-pin male XLR, program
port and USB connector. Including Li-poly rechargeable battery and AC USB wall charger.
Seamless roaming capable.
$1,524.13
3805
CCT-RT
Tempest2400 2.4 GHz remote transceiver
Tempest2400 2.4 GHz remote transceiver:
Tempest 2.4 GHz Remote Antenna Transceiver. Power provided by Tempest 2400 Basestation
via CAT-5 cable up to 457m/1500ft. Including 4.5m/15ft CAT-5 cable and two whip antennas.
Utilizing the remote transceiver disables the antennas at the base.
$1,883.81
3805
CCT-RT-EX
Tempest 2400/900 Remote Antenna Line Extender
Tempest 2400/900 Remote Antenna Line Extender :
Extends distance of CCT-RT, and CCT-9RT, up to 3000 feet, can use 3 in parallel for a
maximum distance of 5000 ft, includes AC adapter.
$885.71
Tempest2400 ZSync dongle
Tempest2400 ZSync dongle:
Tempest ZSync dongle. For use with Basestations with Radio version 1.18 or later. Allows a
zero synchronization reference to enable Nomad Seamless Roaming and to improve
performance of multi-Base systems in non-roaming applications. Includes integrated 5VDC
wall power supply.
$355.18
$2,243.49
3805.1
SG-100
3805.2
SG-120
Tempest2400 Parallel ZSync generator
Tempest2400 Parallel ZSync generator:
Tempest parallel ZSync generator. For use with Basestations with Radio version 1.18 or later.
Allows a zero synchronization reference to enable Tempest2400 Seamless Roaming and to
improve performance of multi-Base systems in non-roaming applications. Provides 12
parallel ZSync feeds. Multiple Parallel ZSync generators may be linked for larger system
configuration. 1RU rack mount, Includes AC power cord.
3806
T-BC5A
Tempest 5-bay battery charger
Tempest 5-bay battery charger:
Tempest five-bay battery charger for charging lithium-polymer batteries outside of the
BeltStation.
3807
T-LP1
Tempest Li-Poly battery
Tempest Li-Poly battery:
Lithium polymer battery for Tempest BeltStations.
3808
CCT-DAKIT1
Tempest2400 2.4 GHz 9dBi directional antenna kit
Tempest2400 2.4 GHz 9dBi directional antenna kit:
9dBi directional antenna kit including two x 9dBi directional antennas, mounting brackets,
one x L-bracket, two x 15.9 mm/5/8" diameter mounting posts, two x 4.5m/10ft coax cables
and one Bogen "C" clamp.
$926.17
3810
CCT-WAKIT2
Tempest2400 2.4 GHz 2 Ch. 2dBi antenna extension kit
Tempest2400 2.4 GHz 2 Ch. 2dBi antenna extension kit:
Tempest 2.4 GHz 2 dBi whip antenna expansion cable kit for the 2 CH Tempest base.
Includes one 25ft (7.7m) RP-TNC jack to RP-TNC plug cable, one mounting clamp, and one
standard rack screw
$161.85
ClearCom DIR
$669.90
$89.02
9 of 33
Part
Index
Short Description
Description
DIR Price
3811
CCT-WAKIT4
Tempest2400 2.4 GHz 4 Ch. 2dBi antenna extension kit
Tempest2400 2.4 GHz 4 Ch. 2dBi antenna extension kit:
Tempest 2.4 GHz 2dBi whip antenna expansion cable kit for the 4 CH Tempest base or CCTRT. Includes two 25ft (7.7m) RP-TNC jack to RP-TNC plug cables, two mounting clamps, and
two standard rack screws.
$265.26
3812
BOG-C1575B
Tempest Bogen 'C' clamp
Tempest Bogen 'C' clamp:
Bogen "C" clamp C1575B. Including mounting bracket for CCT-RT or spare part for clamp in
CCT-DAKIT1.
$53.05
3814
CCT-DA
Tempest2400 2.4 GHz 9dBi directional antenna spare
Tempest2400 2.4 GHz 9dBi directional antenna spare:
9dBi directional antenna including mounting bracket for 15.9mm/5/8" stud mount. Spare
part for CCT-DAKIT1 kit.
3815
400102Z
Tempest BeltStation multi-blade USB wall charger spare
Tempest BeltStation multi-blade USB wall charger spare:
Tempest BeltStation USB multi-blade wall charger (US, UK, EU, AUS blades) - Spare.
3817
CCT-BSUG
Tempest2400 2.4 GHz radio upgrade service
Tempest2400 2.4 GHz radio upgrade service:
Tempest2400 radio upgrade service price per radio to upgrade BeltStations, Basestations,
and CCT-RT radio modules from 1.14 /1.15 versions to 1.18 (Roaming Capable)
3818
TEMPEST900 DIGITAL WIRELESS (900 MHz) Not availble to CE countries
3819
CM-944
Tempest900, 900 MHz 4 Ch. Basestation
Tempest900, 900 MHz 4 Ch. Basestation:
Tempest 900 MHz four-channel, full feature Basestation. Including AC power cord, USB cable,
6ft programming cable with ⅛" (3.5mm) straight mini-jack connector, two whip antennas
and T-desk software. Supports up to five wireless BeltStations in normal mode and unlimited
BeltStations in shared and split modes.
$6,199.94
3820
CM-922
Tempest900, 900 MHz 2 Ch. Basestation
Tempest900, 900 MHz 2 Ch. Basestation:
Tempest 900 MHz two-channel, full feature Basestation. Including AC power cord, USB cable,
6ftprogramming cable with ⅛" (3.5mm) straight mini-jack connector, one whip antenna and
T-desk software. Supports up to five wireless BeltStation in normal mode and unlimited
BeltStations in shared and split modes.
$4,941.07
3821
CP-942A
Tempest900, 900 MHz 4 Ch. BeltStation
Tempest900, 900 MHz 4 Ch. BeltStation:
Tempest 900 MHz four-channel, dual listen wireless BeltStation, four-pin male XLR, program
port and USB connector. Including Li-poly rechargeable battery and AC USB wall charger.
Extended range antenna.
$2,108.61
3822
CP-922A
Tempest900, 900 MHz 2 Ch. BeltStation
Tempest900, 900 MHz 2 Ch. BeltStation:
Tempest 900 MHz two-channel, dual listen wireless BeltStation, four-pin male XLR, program
port and USB connector. Including Li-poly rechargeable battery and AC USB wall charger.
Extended range antenna.
$1,659.01
3823
CCT-9RT
Tempest900, 900 MHz remote transceiver
Tempest900, 900 MHz remote transceiver:
Tempest 900 MHz Remote Antenna Transceiver. Power provided by Tempest900 Basestation
via CAT-5 cable up to 457m/1500ft. Including 4.5m/15ft CAT-5 cable and two whip antennas.
Utilizing the remote transceiver disables the antennas at the base.
$2,063.65
4000
HEADSETS AND ACCESSORIES
4001
CC-300-X4
Single-ear standard HS XLR-4F
Single-ear standard HS XLR-4F:
Single enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom, includes HS-ES ear sock and headset bag - field removable four-pin
female XLR for standard Clear-Com connection.
$260.77
4002
CC-400-X4
Double-ear standard HS XLR-4F
Double-ear standard HS XLR-4F:
Double enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom includes HS-ES ear socks and headset bag- field removable four-pin
female XLR for standard Clear-Com connection.
$310.22
4003
CC-300-Y4
Single-ear standard HS XLR-4M
Single-ear standard HS XLR-4M:
Single enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom, includes HS-ES ear sock and headset bag - field removable four-pin
male XLR for RTS compatible connection.
$287.74
4004
CC-400-Y4
Double-ear standard HS XLR-4M
Double-ear standard HS XLR-4M:
Double enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom includes HS-ES ear socks and headset bag- field removable four-pin
male XLR for RTS compatible connection.
$337.20
4005
CC-300-X5
Single-ear standard HS XLR-5M
Single-ear standard HS XLR-5M:
Single enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom includes HS-ES ear sock and headset bag - field removable five-pin male
XLR.
$287.74
4006
CC-400-X5
Double-ear standard HS XLR-5M
Double-ear standard HS XLR-5M:
Double enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom includes HS-ES ear socks and headset bag - field removable five-pin
male XLR.
$337.20
4007
CC-300-X6
Single-ear standard HS XLR-6M
Single-ear standard HS XLR-6M:
Single enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom includes HS-ES ear sock and headset bag - field removable six pin male
XLR.
$287.74
ClearCom DIR
$310.22
$35.07
$314.72
10 of 33
Part
Index
Short Description
Description
DIR Price
4008
CC-400-X6
Double-ear standard HS XLR-6M
Double-ear standard HS XLR-6M:
Double enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom includes HS-ES ear socks and headset bag - field removable six-pin male
XLR.
$337.20
4009
CC-300-X7
Single-ear standard HS XLR-7F
Single-ear standard HS XLR-7F:
Single enclosed ear headset with superior audio quality and on/ off switch in goose neck
microphone boom includes HS-ES ear sock and headset bag - seven-pin female XLR.
$292.24
4010
CC-400-X7
Double-ear standard HS XLR-7F
Double-ear standard HS XLR-7F:
Double enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom includes HS-ES ear socks and headset bag - field removable seven-pin
female XLR.
$341.69
4011
CC-300-Y5
Single-ear standard HS XLR-5F
Single-ear standard HS XLR-5F:
Single enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom includes HS-ES ear sock and headset bag - field removable five-pin
female XLR.
$292.24
4012
CC-400-Y5
Double-ear standard HS XLR-5F
Double-ear standard HS XLR-5F:
Double enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom includes HS-ES ear socks and headset bag field removable five-pin
female XLR.
$341.69
4013
CC-300-B6
Single-ear standard HS non-terminated
Single-ear standard HS non-terminated:
Single enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom includes HS-ES ear sock and headset bag - non-terminated (bare wires).
$278.75
4014
CC-400-B6
Double-ear standard HS non-terminated
Double-ear standard HS non-terminated:
Double enclosed ear headset with superior audio quality and on/ off switch in gooseneck
microphone boom includes HS-ES ear socks and headset bag- non-terminated (bare wires).
$328.21
CC-010A
IFB Ear Set (mini-jack)
IFB Ear Set (mini-jack):
IFB Ear Set Includes Audio Driver, Coiled Acoustic Ear tube with Clothing Clip, 5 Ft (1.5m)
cable with ⅛" (3.5mm) Straight Mini-jack Connector. Replaces CC-010.
4016
CC-25
Single-ear light headset (mini-jack)
Single-ear light headset (mini-jack):
Single open ear lightweight around-the-ear mounted headset. Including 2.5mm/0.1" minijack for use with RS-600-Series Beltpacks only.
$137.58
4017
CC-26K-X5
Single-ear light headset XLR-5M
Single-ear light headset XLR-5M:
Single open ear lightweight headset - five-pin male XLR.
$178.94
4018
CC-26K-X4
Single-ear light headset XLR-4F
Single-ear light headset XLR-4F:
Single open ear lightweight headset - four-pin female XLR for standard Clear-Com
connection.
$178.94
4027
CC-27
Wrap-around light headset XLR-4F
Wrap-around light headset XLR-4F:
Single ear bud, wrap around rear worn headset - four-pin female XLR for standard ClearCom connection.
$133.08
4028
CC-40
Single-ear economy headset XLR-4F
Single-ear economy headset XLR-4F:
Single enclosed ear economy headset - four-pin female XLR for standard Clear-Com
connection. Optional ear sock covers (ES-1) are recommended.
$142.97
4029
CC-60
Double-ear economy headset XLR-4F
Double-ear economy headset XLR-4F:
Double enclosed ear economy headset - four-pin female XLR for standard Clear-Com
connection. Optional ear sock covers (ES-1) are recommended.
$169.95
4030
PT-7
Push-to-talk handheld mic XLR-4F
Push-to-talk handheld mic XLR-4F:
Push-to-talk handheld microphone - four-pin female XLR for standard Clear-Com
connection.
$110.60
4031
HS-6
Telephone-style handset XLR-4F
Telephone-style handset XLR-4F:
Telephone-style handset with coiled cord and push to talk button on telephone handsetfour-pin female XLR for standard Clear-Com connection.
$128.58
4032
ES-1
1 pair ear sock covers for headsets
1 pair ear sock covers for headsets:
Ear Sock cover for CC-40, CC-60, and discontinued CC-95 and CC-260 enclosed ear
headsets, 1 pair.
$14.39
4033
HS-ES
1 pair ear sock covers for 300/400 headsets
1 pair ear sock covers for 300/400 headsets:
Ear Sock cover for all CC-300 and CC-400 headsets, 1 pair.
$4.50
4034
HME DX SERIES HEADSETS
4035
CZ11450
HS15 headset
HS15 headset:
Single muff noise-canceling headset, Electret mic, with Mini DIN connector.
$164.55
4036
CZ11451
HS15D headset
HS15D headset:
Double muff noise-canceling headset Electret mic, with Mini DIN connector.
$274.25
4015.5
ClearCom DIR
$67.44
11 of 33
Part
Index
Short Description
Description
DIR Price
4037
CZ11452
HS16 headset
HS16 headset:
Single muff lightweight headset with directional Electret mic. Mini DIN connector.
4038
CZ11453
HSI6000 headset adapter
HSI6000 headset adapter:
2.5mm Headset Adapter for BP200 Beltpack and BP300 Beltpack
$74.63
4039
CZ11454
HS4-3 earpiece and lapel mic
HS4-3 earpiece and lapel mic:
Earpiece & lapel (clip-on) Electret mic
$76.43
4040
G27245-1
Clear-Com 4-pin MD-XLR4M adapter
Clear-Com 4-pin MD-XLR4M adapter:
Adapter Cable for use with Clear-Com 4-pin XLR4F terminated dynamic headset with DX
Mini DIN headset connector.
$74.63
4041
G27256-1
MD-XLR4F adapter
MD-XLR4F adapter:
Adapter Cable for using XLR4M terminated dynamic headset with DX Mini DIN headset
connector.
$74.63
4042
G27267-1
MD-XLR5F adapter
MD-XLR5F adapter:
Adapter Cable for using XLR5M terminated dynamic headset with DX Mini DIN headset
connector
$74.63
4042
115G394
Headset extension cable
Headset extension cable:
Single 6' headset extension cable for HS15/15D, HS16 headsets
$9.89
4043
HME DX SERIES ACCESSORIES
4044
101G048
DX base antenna
DX base antenna:
5.9” Reverse TNC base antenna
$51.25
4045
647G006
DX antenna splitter/combiner
DX antenna splitter/combiner:
2-Way Antenna Splitter/Combiner
$106.10
4046
G28066-1
RMK200 mounting kit
RMK200 mounting kit:
1RU Mounting Panel for base antennas, includes two 2' cables
$127.69
4047
G27009-1
DX 6' remote antenna kit
DX 6' remote antenna kit:
Single 6 foot (1.8m) RP-TNC jack to RP-TNC plug cable with right angle bracket for remote
base antenna on DX base stations, two kits are required to remote both antennas
$78.23
4048
G26671-1
DX 30' remote antenna kit
DX 30' remote antenna kit:
Single 30 foot (7.7m) RP-TNC jack to RP-TNC plug cable with right angle bracket for remote
base antenna on DX base stations, two kits are required to remote both antennas
$112.40
4049
104034
BAT41 rechargeable battery
BAT41 rechargeable battery:
Battery, Li-ion rechargeable, for BP200/210/300 beltpacks and WH200/210/300.
4050
CZ11378
AC40A battery charger
AC40A battery charger:
Battery charger, 4-port quick charger w/adapter, 115/230 VAC, power cord for BAT41
batteries.
4052
G28820-1Z1
AC850A charger
AC850A charger:
4 Port charger for BAT850 battery, power supply, cord and manual
4053
G28572-1
HS-XLR4F interface cable
HS-XLR4F interface cable:
48" Interface cable. Bare leads to XLR4F headset connector
$49.46
4054
G28572-2
HS-XLR4M interface cable
HS-XLR4M interface cable:
48" Interface cable. Bare leads to XLR4M headset connector
$49.46
4056
G27942-1
Base station monitor speaker
Base station monitor speaker:
Compact Speaker with enclosure. Plugs into rear of BS200 base station or WS200 Speaker
Station
4058
115G362
4 ft. DX headset cable w/ connector
4 ft. DX headset cable w/ connector:
48" headset bare leads cable with molded mini-DIN connector
$21.58
4059
115G372
CAT-5 cable
CAT-5 cable:
Base station Interconnect Cable - 7' with RJ45 connectors
$8.09
4060
176G018
Travel case for DX300ES
Travel case for DX300ES:
Travel Case for DX300 Systems. Includes foam inserts, holds MB300 base station, 4 belt packs,
with storage for cables and headsets.
$332.70
4063
HME PRO850 HEADSETS
4064
CZ11458
HS15 Single-muff headset, 4F
HS15 Single-muff headset, 4F:
Single Muff Electret Microphone Noise canceling Headset with 4-pin female connector for
use with HME PRO850 or Clear-Com V-series, FreeSpeak/ CellCom, Tempest, RS-700 &
HelixNet
$211.31
ClearCom DIR
$130.38
$43.16
$566.49
$1,029.58
$165.45
12 of 33
Part
Index
Short Description
Description
DIR Price
HS15D Dual-muff Headset, 4F
HS15D Dual-muff Headset, 4F:
Double Muff Electret Microphone Noise canceling Headset with 4-pin female connector for
use with HME PRO850 or traditional Clear-Com V-series, FreeSpeak/ CellCom, Tempest, RS700 & HelixNet
$296.73
4065
CZ11459
4066
HME PRO850 WIRELESS ACCESSORIES
4067
G24589-1
RAK850 remote kit
RAK850 remote kit:
Ground Plane Adapter for one BS850 base station antenna with 30' of cable
$129.48
4068
G28077-1
RMK850 mounting kit
RMK850 mounting kit:
1RU panel for mounting BS850 base station antennas, with 2' of cable
$119.59
4069
G27021-1
BAT850 NiMH battery
BAT850 NiMH battery:
7.2V 2100mAH NiMH rechargeable battery for BP850 beltpack, MB100 base station, MB300ES
base station and WS200 Speaker Station
4070
CZ11484
AC850A charger
AC850A charger:
4 Port charger for BAT850 batteries, power supply, cord and manual
4071
105G073
Battery sled, 6 AA
Battery sled, 6 AA:
Battery sled for BP850 Beltpack, WS200 Station, and MB100/MB300ES bases. Holds 6 “AA”
cells.
$4.50
4072
172G658
BP850 battery sled door
BP850 battery sled door:
Battery sled door for BP850 Beltpack
$2.70
4073
115G342
BP850 Config cable
BP850 Config cable:
BP850 Beltpack configuration cable
$9.89
4074
196G018
Power supply cable
Power supply cable:
115 VAC cable for use with VAC power supply
$16.19
4075
CZ11421
12VDC power supply with cord
12VDC power supply with cord:
115/230 VAC universal power supply and cord for HME Wireless base stations, WS200 Speaker
Station, or AC40A battery charger
5000
ECLIPSE-HX
NOTE: Your order may include a "configured part name" such as
C-ECLIPSE-HX-MEDIAN-64P under which will be shown the cards
and power cord choice.
NOTE: Your order may include a "configured part name" such as C-ECLIPSE-HX-MEDIAN-64P
under which will be shown the cards and power cord choice.
ECLIPSE-HX-PICO
Eclipse HX-Pico, 36-port 1RU digital matrix
Eclipse HX-Pico, 36-port 1RU digital matrix:
1RU HX-PiCo 36-port matrix frame. 1RU frame with user menu and 32 RJ-45 programmable
panel/4-wire ports and four 4-wire in/out ports. Matrix has dual-redundant PSUs. Requires EHX
configuration software.
5001.1
ECLIPSE-HX-DELTA-0P
Spare HX-Delta frame, without port cards
5001.2
ECLIPSE-HX-DELTA-16P
Eclipse HX-Delta, with 16 ports
Eclipse HX-Delta, with 16 ports:
Eclipse HX-Delta 4 slot 16-port matrix frame. Including 3RU card frame with back-plane
circuit boards and three interface module slots, dual-redundant CPU's (CPU-HX-SPARE), dualredundant power supplies and 1 x MVX-A16-HX port card. Requires EHX configuration
software.
Eclipse HX-Delta, with 32 ports
Eclipse HX-Delta, with 32 ports:
Eclipse HX-Delta 4 slot 32-port matrix frame. Including 3RU card frame with back-plane
circuit boards and three interface module slots, dual-redundant CPU's (CPU-HX-SPARE), dualredundant power supplies and 2 x MVX-A16-HX port card. Requires EHX configuration
software.
Eclipse HX-Delta, with 48 ports
Eclipse HX-Delta, with 48 ports:
Eclipse HX-Delta 4 slot 48-port matrix frame. Including 3RU card frame with back-plane
circuit boards and three interface module slots, dual-redundant CPU's (CPU-HX-SPARE), dualredundant power supplies and 3x MVX-A16-HX port card. Requires EHX configuration
software.
5000.2
5001
5001.3
5001.4
$75.53
$1,029.58
$144.77
ECLIPSE-HX MAIN FRAMES
ECLIPSE-HX-DELTA-32P
ECLIPSE-HX-DELTA-48P
Spare HX-Delta frame, without port cards:
Spare Eclipse HX-Delta 4 slot matrix frame. Including 3RU card frame with three interface
module slots, dual-redundant CPU's (CPU-HX-SPARE) and dual-redundant power supplies.
5001.5
ECLIPSE-HX-DELTA-64P
Eclipse HX-Delta, with 64 ports
Eclipse HX-Delta, with 64 ports:
Eclipse HX-Delta 4 slot 64-port matrix frame. Including 3RU card frame with back-plane
circuit boards and three interface module slots, dual-redundant CPU's (CPU-HX-SPARE), dualredundant power supplies and 4 x MVX-A16-HX port card. Requires EHX configuration
software.
5002.1
ECLIPSE-HX-MEDIAN-0P
Spare HX-Median frame, without port cards
Spare HX-Median frame, without port cards:
Spare Eclipse HX-Median 7 slot matrix frame. Including 6RU card frame with eight interface
module slots, dual-redundant CPU's (CPU-HX-SPARE) and dual-redundant power supplies.
5003
ECLIPSE-HX-MEDIAN-16P
Eclipse HX-Median, with 16 ports
Eclipse HX-Median, with 16 ports:
Eclipse HX-Median 7 slot 16-port matrix frame. Including 6RU card frame with back-plane
circuit boards and eight interface module slots, dual-redundant CPU's (CPU-HX-SPARE), dualredundant power supplies and 1 x MVX-A16-HX port card. Requires EHX configuration
software.
ClearCom DIR
13 of 33
Part
Index
Short Description
Description
5004
ECLIPSE-HX-MEDIAN-32P
Eclipse HX-Median, with 32 ports
Eclipse HX-Median, with 32 ports:
Eclipse HX-Median 7 slot 32-port matrix frame. Including 6RU card frame with back-plane
circuit boards and eight interface module slots, dual-redundant CPU's (CPU-HX-SPARE), dualredundant power supplies and 2 x MVX-A16-HX port cards. Requires EHX configuration
software.
5005
ECLIPSE-HX-MEDIAN-48P
Eclipse HX-Median, with 48 ports
Eclipse HX-Median, with 48 ports:
Eclipse HX-Median 7 slot 48-port matrix frame. Including 6RU card frame with back-plane
circuit boards and eight interface module slots, dual-redundant CPU's (CPU-HX-SPARE), dualredundant power supplies and 3 x MVX-A16-HX port cards. Requires EHX configuration
software.
5006
ECLIPSE-HX-MEDIAN-64P
Eclipse HX-Median, with 64 ports
Eclipse HX-Median, with 64 ports:
Eclipse HX-Median 7 slot 64-port matrix frame. Including 6RU card frame with back-plane
circuit boards and eight interface module slots, dual-redundant CPU's (CPU-HX-SPARE), dualredundant power supplies and 4 x MVX-A16-HX port cards. Requires EHX configuration
software.
5007
ECLIPSE-HX-MEDIAN-80P
Eclipse HX-Median, with 80 ports
Eclipse HX-Median, with 80 ports:
Eclipse HX-Median 7 slot 80-port matrix frame. Including 6RU card frame with back-plane
circuit boards and eight interface module slots, dual-redundant CPU's (CPU-HX-SPARE), dualredundant power supplies and 5 x MVX-A16-HX port cards. Requires EHX configuration
software.
5008
ECLIPSE-HX-MEDIAN-96P
Eclipse HX-Median, with 96 ports
Eclipse HX-Median, with 96 ports:
Eclipse HX-Median 7 slot 96-port matrix frame. Including 6RU card frame with back-plane
circuit boards and eight interface module slots, dual-redundant CPU's (CPU-HX-SPARE), dualredundant power supplies and 6 x MVX-A16-HX port cards. Requires EHX configuration
software.
5009
ECLIPSE-HX-MEDIAN-112P
Eclipse HX-Median, with 112 ports
Eclipse HX-Median, with 112 ports:
Eclipse HX-Median 7 slot 112-port matrix frame. Including 6RU card frame with back-plane
circuit boards and eight interface module slots, dual-redundant CPU's (CPU-HX-SPARE), dualredundant power supplies and 7 x MVX-A16-HX port cards. Requires EHX configuration
software.
5010
ECLIPSE-HX-OMEGA-0P
Spare Eclipse HX-Omega frame, without port cards
Spare Eclipse HX-Omega frame, without port cards:
Spare Eclipse HX-Omega 15 slot matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE) and dual-redundant power supplies.
5011
ECLIPSE-HX-OMEGA-16P
Eclipse HX-Omega, with 16 ports
Eclipse HX-Omega, with 16 ports:
Eclipse HX-Omega 15 slot 16-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 1 x MVX-A16-HX port
card. Requires EHX configuration software.
5012
ECLIPSE-HX-OMEGA-32P
Eclipse HX-Omega, with 32 ports
Eclipse HX-Omega, with 32 ports:
Eclipse HX-Omega 15 slot 32-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 2 x MVX-A16-HX port
cards. Requires EHX configuration software.
5013
ECLIPSE-HX-OMEGA-48P
Eclipse HX-Omega, with 48 ports
Eclipse HX-Omega, with 48 ports:
Eclipse HX-Omega 15 slot 48-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 3 x MVX-A16-HX port
cards. Requires EHX configuration software.
5014
ECLIPSE-HX-OMEGA-64P
Eclipse HX-Omega, with 64 ports
Eclipse HX-Omega, with 64 ports:
Eclipse HX-Omega 15 slot 64-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 4 x MVX-A16-HX port
cards. Requires EHX configuration software.
5015
ECLIPSE-HX-OMEGA-80P
Eclipse HX-Omega, with 80 ports
Eclipse HX-Omega, with 80 ports:
Eclipse HX-Omega 15 slot 80-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 5 x MVX-A16-HX port
cards. Requires EHX configuration software.
5016
ECLIPSE-HX-OMEGA-96P
Eclipse HX-Omega, with 96 ports
Eclipse HX-Omega, with 96 ports:
Eclipse HX-Omega 15 slot 96-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 6 x MVX-A16-HX port
cards. Requires EHX configuration software.
5017
ECLIPSE-HX-OMEGA-112P
Eclipse HX-Omega, with 112 ports
Eclipse HX-Omega, with 112 ports:
Eclipse HX-Omega 15 slot 112-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 7 x MVX-A16-HX port
cards. Requires EHX configuration software.
5018
ECLIPSE-HX-OMEGA-128P
Eclipse HX-Omega, with 128 ports
Eclipse HX-Omega, with 128 ports:
Eclipse HX-Omega 15 slot 128-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 8 x MVX-A16-HX port
cards. Requires EHX configuration software.
5019
ECLIPSE-HX-OMEGA-144P
Eclipse HX-Omega, with 144 ports
Eclipse HX-Omega, with 144 ports:
Eclipse HX-Omega 15 slot 144-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 9 x MVX-A16-HX port
cards. Requires EHX configuration software.
ClearCom DIR
DIR Price
14 of 33
Part
Index
Short Description
Description
5020
ECLIPSE-HX-OMEGA-160P
Eclipse HX-Omega, with 160 ports
Eclipse HX-Omega, with 160 ports:
Eclipse HX-Omega 15 slot 160-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 10 x MVX-A16-HX port
cards. Requires EHX configuration software.
5021
ECLIPSE-HX-OMEGA-176P
Eclipse HX-Omega, with 176 ports
Eclipse HX-Omega, with 176 ports:
Eclipse HX-Omega 15 slot 176-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 11 x MVX-A16-HX port
cards. Requires EHX configuration software.
5022
ECLIPSE-HX-OMEGA-192P
Eclipse HX-Omega, with 192 ports
Eclipse HX-Omega, with 192 ports:
Eclipse HX-Omega 15 slot 192-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 12 x MVX-A16-HX port
cards. Requires EHX configuration software.
5023
ECLIPSE-HX-OMEGA-208P
Eclipse HX-Omega, with 208 ports
Eclipse HX-Omega, with 208 ports:
Eclipse HX-Omega 15 slot 208-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 13 x MVX-A16-HX port
cards. Requires EHX configuration software.
5024
ECLIPSE-HX-OMEGA-224P
Eclipse HX-Omega, with 224 ports
5025
ECLIPSE-HX-OMEGA-240P
Eclipse HX-Omega, with 240 ports
Eclipse HX-Omega, with 240 ports:
Eclipse HX-Omega 15 slot 240-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 15 x MVX-A16-HX port
cards. Requires EHX configuration software.
5025.5
Eclipse HX-Omega, with 224 ports:
Eclipse HX-Omega 15 slot 224-port matrix frame. Including 6RU card frame with dualredundant CPU's (CPU-HX-SPARE), dual-redundant power supplies and 14 x MVX-A16-HX port
cards. Requires EHX configuration software.
ECLIPSE-HX MATRIX CARDS
5026
MVX-A16-HX
Spare 16 port card for Eclipse-HX
Spare 16 port card for Eclipse-HX:
Spare Eclipse HX-Median, HX-Delta or HX-Omega 16 port analog panel/direct/interface
front and rear card set. Takes one slot in the matrix frame.
5027
CPU-HX-SPARE
Spare Eclipse-HX CPU card
Spare Eclipse-HX CPU card:
Spare Eclipse HX-Median or HX-Omega system processor front card. This stores and executes
system configurations.
5028
E-QUE-HX
Eclipse-HX Integra Wireless or E1/T1 Trunking card
Eclipse-HX Integra Wireless or E1/T1 Trunking card:
Eclipse HX-Median or HX-Omega Integra digital wireless card set to support up to 10 active
antennas. The rear card has eight ports for directly connecting antennas (without power)
and up to 10 antennas using the optional PD2203 splitters. Can also be used for E1 (30
Channel) or T1 (24 Channel) trunking. Maximum four cards per Eclipse frame as standard.
Takes one slot in the 6RU matrix frame.
5029
IVC-32-HX
Eclipse-HX IP card
Eclipse-HX IP card:
IVC-32-HX IP matrix card set uses "Instant Voice" technology for 32 audio channels of low
latency, high performance IP audio connections to V-Series panels and Concert clients. The
Ethernet port connection is available for use on the customers LAN, WAN or Internet
connection. Maximum four cards per Eclipse frame as standard. Takes one slot in the 6RU
matrix frame.
5030
E-MADI64-HX
Eclipse-HX MADI 64 Ch. Card
Eclipse-HX MADI 64 Ch. Card:
Eclipse-MADI-HX 64 port card set. Configurable via ECS for 16, 32, 48, 56 or 64 channels and
sample rates of 44.1 KHz, 48.0 KHz or 96 KHz (32 Ch. only) in this mode. All ports include VOX.
Duplex LC connections using Multi-mode fiber, 1km/0.6 mile distance continuous glass. BNC
Coax connections for Input, Output and Video/ world clock Input. Requires EHX v7.0 or
newer. Takes one slot in the 6RU matrix frame.
5031
LMC-64-HX
Eclipse-HX level meter card
Eclipse-HX level meter card:
LMC-64-HX level meter card set for the Eclipse HX-Median 7 slot or Eclipse HX-Omega 15 slot
matrices. Provides Clear-Vu meters on Production Maestro Pro giving up to 64 channels of
matrix input or output port metering. Takes one slot in the 6RU matrix frame.
5032
E-FIB-HX
Eclipse-HX Fiber interface card
Eclipse-HX Fiber interface card:
Fiber-Net interface card set for the 7 slot HX-Median or 15 slot HX-Omega matrices. A Single
E-FIB-HX provides connections for both a main and a backup Fiber ring. Provides Duplex LC
single mode fiber connections, supporting up to 10km(6.6mile) of continuous glass.
Maximum two card sets per Eclipse HX frame. Takes one slot in the 6RU matrix frame.
EHX.7.5.0
EHX Eclipse-HX Configuration Software DVD v7.5
EHX Eclipse-HX Configuration Software DVD v7.5:
EHX - Eclipse HX configuration system programming software DVD v7.5 with manuals. New
Configuration application for HX systems based on V-series and I-series panels only. (ECS
5.2.x is available for Legacy compatible systems). License includes use of EHX client software
on multiple PC's on a single Eclipse HX networked matrix system. If you wish to use the
software on more than one matrix network, you must contact Clear-Com, and if required,
purchase further licenses. Please see "Upgrade-Kits" for Eclipse to Eclipse-HX upgrades.
LOGIC-MAESTRO-HX
EHX graphical logic module
EHX graphical logic module:
Logic Maestro programming module for EHX.
A graphical logic-programming tool, enabling design and programming of complex logical
crosspoint functions and controls.
Provided free of charge with EHX.
5032.1
5033.2
5034
DIR Price
ECLIPSE HX MATRIX SOFTWARE
ClearCom DIR
15 of 33
Part
Index
5035
5036
EHX-SERVER
HCI-E-HX
Short Description
Description
EHX Client and Server facility
EHX Client and Server facility:
Client and separate server module for EHX.
Required for Eclipse network systems or when client PC’s are required to access to the
Eclipse matrix. One copy is required per Eclipse network.
Provided Free of charge with EHX.
Eclipse-HX host control interface License
Eclipse-HX host control interface License:
Host control interface (HCI) License, allows control and/or monitoring on an Eclipse-HX
matrix via the Eclipse HCI Protocol. Each Eclipse matrix requires a separate license. HCI
Licenses are not transferable. Clear-Com will support to the nominated application
developer in using the HCI interface. For further information please contact your Clear-Com
sales representative.
5037
PM-PRO-1-HX
Eclipse-HX PM-Pro user license and DVD
Eclipse-HX PM-Pro user license and DVD:
Production Maestro Pro is a PC based Assignment tool for the Eclipse system providing fast
and reliable assignment of 4-wires, Conferences and IFB resources. Every matrix requires one
license for each Production Maestro Pro Client that connects to it. Requires EHX v7.0 or
newer. See LMC-64 Matrix card for Clear-Vu metering. Clear-Vu requires ECS 5.2 or higher.
DVD includes Manuals.
5038
PM-PRO-SITE-HX
Eclipse-HX PM-PRO site license and DVD
Eclipse-HX PM-PRO site license and DVD:
Production Maestro Pro is a PC based Assignment tool for the Eclipse system providing fast
and reliable assignment of 4-wires, Conferences and IFB resources. This site license provides
a fixed price for 10 Production Maestro Pro licenses per matrix in the EHX linked network. See
LMC-64-HX Matrix card for Clear-Vu metering. DVD includes Manuals.
Eclipse PiCo to HX-PiCo upgrade package
Eclipse PiCo to HX-PiCo upgrade package:
Upgrade of an Eclipse-PiCo matrix to Eclipse-HX PiCo (with the latest software release). The
associated hardware upgrade of the PiCo matrix must be performed by Clear-Com factory
service in the US or by the European service center in Germany. The customer is responsible
for all shipping, customs, duties and taxes. Any agreed repairs to the original PiCo, if
required, will incur extra charges.
5039
UPGRADE-PKG-PICO-HX
5040
UPGRADE-KIT-MED-HX
Eclipse Median to HX-Median upgrade Kit
Eclipse Median to HX-Median upgrade Kit:
Kit of parts to convert an Eclipse Median matrix into its HX-Median counterpart.
Implementation of the HX-Median upgrade requires on-site Clear-Com Application
Engineering support.
Please see Factory Configuration & Services below and contact your Clear-Com Sales
Representative for pricing.
5041
UPGRADE-KIT-OME-HX
Eclipse Omega to HX-Omega upgrade Kit
Eclipse Omega to HX-Omega upgrade Kit:
Kit of parts to convert an Eclipse Omega matrix into its HX-Omega counterpart.
Implementation of the HX-PiCO upgrade requires on-site Clear-Com Application
Engineering support.
Please see Factory Configuration & Services below and contact your Clear-Com Sales
Representative for pricing.
5100
5100.1
5100.2
ECLIPSE DIGITAL MATRIX
ECLIPSE MAIN FRAMES
(Provides Legacy Panel Support. For latest features please use Eclipse-HX)
ECLIPSE-PICO
Eclipse 36-port 1RU digital matrix
Eclipse 36-port 1RU digital matrix:
1RU PiCo 36-port matrix frame. 1RU frame with user menu and 32 RJ-45 programmable
panel/4-wire ports and four 4-wire in/out ports. Has dual-redundant PSUs. Requires ECS
configuration software.
5102.1
ECLIPSE-MEDIAN/0
Spare Median frame with CPU & CPU
Spare Median frame with CPU & CPU:
Spare Eclipse-Median 7 slot matrix frame. Including 6RU card frame with eight interface
module slots, dual-redundant 710746Z CPU processors and dual-redundant power supplies.
5103
ECLIPSE-MEDIAN/16
Eclipse-Median 16
Eclipse-Median 16:
Eclipse-Median 7 slot 16-port matrix frame. Including 6RU card frame with back-plane circuit
boards and eight interface module slots, dual-redundant 710746Z CPU processors, dualredundant power supplies and 1 x MVX-A16 port card. Requires ECS configuration software.
5104
ECLIPSE-MEDIAN/32
Eclipse-Median 32
Eclipse-Median 32:
Eclipse-Median 7 slot 32-port matrix frame. Including 6RU card frame with back-plane circuit
boards and eight interface module slots, dual-redundant 710746Z CPU processors, dualredundant power supplies and 2 x MVX-A16 port cards. Requires ECS configuration software.
5105
ECLIPSE-MEDIAN/48
Eclipse-Median 48
Eclipse-Median 48:
Eclipse-Median 7 slot 48-port matrix frame. Including 6RU card frame with back-plane circuit
boards and eight interface module slots, dual-redundant 710746Z CPU processors, dualredundant power supplies and 3 x MVX-A16 port cards. Requires ECS configuration software.
5106
ECLIPSE-MEDIAN/64
Eclipse-Median 64
Eclipse-Median 64:
Eclipse-Median 7 slot 64-port matrix frame. Including 6RU card frame with back-plane circuit
boards and eight interface module slots, dual-redundant 710746Z CPU processors, dualredundant power supplies and 4 x MVX-A16 port cards. Requires ECS configuration software.
5107
ECLIPSE-MEDIAN/80
Eclipse-Median 80
Eclipse-Median 80:
Eclipse-Median 7 slot 80-port matrix frame. Including 6RU card frame with back-plane circuit
boards and eight interface module slots, dual-redundant 710746Z CPU processors, dualredundant power supplies and 5 x MVX-A16 port cards. Requires ECS configuration software.
5101
DIR Price
ClearCom DIR
16 of 33
Part
Index
Short Description
Description
5108
ECLIPSE-MEDIAN/96
Eclipse-Median 96
Eclipse-Median 96:
Eclipse-Median 7 slot 96-port matrix frame. Including 6RU card frame with back-plane circuit
boards and eight interface module slots, dual-redundant 710746Z CPU processors, dualredundant power supplies and 6 x MVX-A16 port cards. Requires ECS configuration software.
5109
ECLIPSE-MEDIAN/112
Eclipse-Median 112
Eclipse-Median 112:
Eclipse-Median 7 slot 112-port matrix frame. Including 6RU card frame with back-plane
circuit boards and eight interface module slots, dual-redundant 710746Z CPU processors,
dual-redundant power supplies and 7 x MVX-A16 port cards. Requires ECS configuration
software.
5110.1
ECLIPSE-OMEGA/0
Spare Omega frame
Spare Omega frame:
Spare Eclipse-Omega 15 slot matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors and dual-redundant power supplies.
5111
ECLIPSE-OMEGA/16
Eclipse-Omega 16
Eclipse-Omega 16:
Eclipse-Omega 15 slot 16-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 1 x MVX-A16 port card.
Requires ECS configuration software.
5112
ECLIPSE-OMEGA/32
Eclipse-Omega 32
Eclipse-Omega 32:
Eclipse-Omega 15 slot 32-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 2 x MVX-A16 port cards.
Requires ECS configuration software.
5113
ECLIPSE-OMEGA/48
Eclipse-Omega 48
Eclipse-Omega 48:
Eclipse-Omega 15 slot 48-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 3 x MVX-A16 port cards.
Requires ECS configuration software.
5114
ECLIPSE-OMEGA/64
Eclipse-Omega 64
Eclipse-Omega 64:
Eclipse-Omega 15 slot 64-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 4 x MVX-A16 port cards.
Requires ECS configuration software.
5115
ECLIPSE-OMEGA/80
Eclipse-Omega 80
Eclipse-Omega 80:
Eclipse-Omega 15 slot 80-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 5 x MVX-A16 port cards.
Requires ECS configuration software.
5116
ECLIPSE-OMEGA/96
Eclipse-Omega 96
Eclipse-Omega 96:
Eclipse-Omega 15 slot 96-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 6 x MVX-A16 port cards.
Requires ECS configuration software.
5117
ECLIPSE-OMEGA/112
Eclipse-Omega 112
Eclipse-Omega 112:
Eclipse-Omega 15 slot 112-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 7 x MVX-A16 port cards.
Requires ECS configuration software
5118
ECLIPSE-OMEGA/128
Eclipse-Omega 128
Eclipse-Omega 128:
Eclipse-Omega 15 slot 128-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 8 x MVX-A16 port cards.
Requires ECS configuration software.
5119
ECLIPSE-OMEGA/144
Eclipse-Omega 144
Eclipse-Omega 144:
Eclipse-Omega 15 slot 144-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 9 x MVX-A16 port cards.
Requires ECS configuration software.
5120
ECLIPSE-OMEGA/160
Eclipse-Omega 160
Eclipse-Omega 160:
Eclipse-Omega 15 slot 160-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 10 x MVX-A16 port cards.
Requires ECS configuration software.
5121
ECLIPSE-OMEGA/176
Eclipse-Omega 176
Eclipse-Omega 176:
Eclipse-Omega 15 slot 176-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 11 x MVX-A16 port cards.
Requires ECS configuration software.
5122
ECLIPSE-OMEGA/192
Eclipse-Omega 192
Eclipse-Omega 192:
Eclipse-Omega 15 slot 192-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 12 x MVX-A16 port cards.
Requires ECS configuration software.
5123
ECLIPSE-OMEGA/208
Eclipse-Omega 208
Eclipse-Omega 208:
Eclipse-Omega 15 slot 208-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 13 x MVX-A16 port cards.
Requires ECS configuration software.
5124
ECLIPSE-OMEGA/224
Eclipse-Omega 224
Eclipse-Omega 224:
Eclipse-Omega 15 slot 224-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 14 x MVX-A16 port cards.
Requires ECS configuration software.
ClearCom DIR
DIR Price
17 of 33
Part
Index
5125
5125.1
ECLIPSE-OMEGA/240
Short Description
Description
Eclipse-Omega 240
Eclipse-Omega 240:
Eclipse-Omega 15 slot 240-port matrix frame. Including 6RU card frame with dual-redundant
710746Z CPU processors, dual-redundant power supplies and 15 x MVX-A16 port cards.
Requires ECS configuration software.
ECLIPSE MATRIX CARDS
5130
MVX-A16
Spare 16 port card
Spare 16 port card:
Spare Eclipse Median or Omega 16 port analog panel/direct/interface front and rear card
set. Takes one slot in the 6RU matrix frame.
5131
710746Z
Spare CPU card
Spare CPU card:
Spare Eclipse Median or Omega system processor configuration front card.
Integra Wireless or E1/T1 Trunking card
Integra Wireless or E1/T1 Trunking card:
Eclipse Median or Omega Integra digital wireless card set to support up to 10 active
antennas. The rear card has eight ports for directly connecting antennas (without power)
and up to 10 antennas using the optional PD2203 splitters. Can also be used for E1 (30
Channel) or T1 (24 Channel) trunking. Maximum four cards per Eclipse frame. Requires
ECS.5.0 or newer. Takes one slot in the 6RU matrix frame.
Eclipse IP card
Eclipse IP card:
IVC-32 IP matrix card set for the Eclipse-Median 7 slot or Eclipse-Omega 15 slot matrices with
"Instant Voice" technology for 32 audio channels of low latency, high performance IP audio
connections to V-Series panels and Concert 2.0 clients. The Ethernet port connection is
available for use on the customers LAN, WAN or Internet connection. Maximum four cards
per Eclipse frame. Requires ECS.5.1 or newer. Takes one slot in the 6RU matrix frame.
5133
5134
DIR Price
E-QUE
IVC-32
5135
E-MADI64
Eclipse MADI 64 Ch. card
Eclipse MADI 64 Ch. card:
Eclipse-MADI 64 port card set. Configurable via ECS for 16, 32, 48, 56 or 64 channels and
sample rates of 44.1 KHz, 48.0 KHz or 96 KHz (32 Ch. only) in this mode. All ports include VOX.
Duplex LC connections using Multi-mode fiber, 1km/0.6 mile distance continuous glass. BNC
Coax connections for Input, Output and Video/ world clock Input. Requires Eclipse 5.2.4 or
newer. Takes one slot in the 6RU matrix frame.
5136
LMC-64
Eclipse level meter card
Eclipse level meter card:
LMC-64 level meter card and rear card set for the Eclipse-Median 7 slot or Eclipse-Omega
15 slot matrices to provide the Clear-Vu meters on Production Maestro Pro giving up to 64
channels of matrix input or output port metering. Takes one slot in the 6RU matrix frame.
Requires ECS 5.2 or higher.
5137
E-FIB
Fiber interface card
Fiber interface card:
Fiber-Net interface card set for the Eclipse-Omega 15 slot and Median frames. A Single E-FIB
provides connections for both a Main and a Backup Fiber ring. Duplex LC connections using
single mode fiber, 10km/6.6mile distance continuous glass. Maximum two card sets per
Eclipse frame. Requires Eclipse v4.2 or newer. Takes one slot in the 6RU matrix frame.
5138
720379Z
Spare Eclipse-Median & Omega PSU
Spare Eclipse-Median & Omega PSU:
Spare Eclipse-Median 7 slot and Omega PSU Module (new type 2009).
5139
400101Z
Spare Eclipse-PiCo PSU
Spare Eclipse-PiCo PSU:
Spare Eclipse PiCo PSU Module. We recommend purchasing in pairs to balance voltages.
5200
ECLIPSE MATRIX SOFTWARE
5203
ECS.5.2
Eclipse Configuration Software DVD v5.2
Eclipse Configuration Software DVD v5.2:
Eclipse configuration system programming software DVD v5.2 with manuals. Provides IP
manager, panel key, PL, IFB, ISO Fixed Group and GPI control configuration and assignment.
You may use the ECS client software on any PC within a single networked matrix system. If
you wish to use the software on more than one matrix network, you must contact ClearCom and if required purchase further licenses.
5204
ECS-OLD-SW-CHARGE
Charge for older system software
Charge for older system software:
Additional charge for non-default factory fit Eclipse system software. ECS compliant version
choice limited to ECS.4.2, ECS.5.0.4, ECS.5.1.1 and ECS.5.1.3. Please specify the ECS
compliant version with your order.
5205
LOGIC MAESTRO
EHX graphical logic module
EHX graphical logic module:
Logic Maestro programming module for ECS.
A graphical logic-programming tool, enabling design and programming of complex logical
crosspoint functions and controls.
Provided free of charge with ECS.
5206
ECS/SERVER
EHX Client and Server facility
EHX Client and Server facility:
Client and separate server module for ECS.
Required for Eclipse network systems or when client PC’s are required to access to the
Eclipse matrix. Provided Free of charge with ECS.
5208
HCI/E
Eclipse host control interface License
Eclipse host control interface License:
Host control interface (HCI) License, allows control and/or monitoring on an Eclipse matrix
via the Eclipses HCI Protocol. Each Eclipse matrix requires a separate license. HCI Licenses
are not transferable. Clear-Com will support to the nominated application developer in
using the HCI interface. For further information please contact your Clear-Com sales
representative.
ClearCom DIR
18 of 33
Part
Index
5211
PRODUCTION-MAESTRO-PRO-1
Short Description
Description
Production Maestro Pro user license & DVD
Production Maestro Pro user license & DVD:
Production Maestro Pro is a PC based Assignment tool for the Eclipse system providing fast
and reliable assignment of 4-wires, Conferences and IFB resources. Every matrix requires one
license for each Production Maestro Pro Client that connects to it. Requires ECS.5.1.3 or
newer. See LMC-64 Matrix card for Clear-Vu metering. Clear-Vu requires ECS.5.2 or higher.
DVD includes Manuals.
5212
PRODUCTION-MAESTRO-PRO-SITE
Production Maestro Pro site license & DVD
Production Maestro Pro site license & DVD:
Production Maestro Pro is a PC based Assignment tool for the Eclipse system providing fast
and reliable assignment of 4-wires, Conferences and IFB resources. This site license provides
a fixed price for 10 Production Maestro Pro licenses per matrix in the ECS linked network.
Requires ECS.5.1.3 or newer. See LMC-64 Matrix card for Clear-Vu metering. Clear-Vu
requires ECS.5.2 or higher. DVD includes Manuals.
5213
SOFTWARE-UG-PICO
PiCo system upgrade charge
PiCo system upgrade charge:
Charge for the upgrade of one Eclipse-PiCo system software to the latest Eclipse version.
Please supply Sales with all supporting information to enable the correct sets of EPROMs and
DVDs to be dispatched. If in doubt please contact your distributor or technical support
center. Please see "Upgrade-Kits" for Eclipse to Eclipse-HX upgrades.
Median/Omega upgrade charge
Median/Omega upgrade charge:
Charge for the upgrade of one Eclipse-Omega 15 slot or Median system software to the
latest Eclipse version. Please supply Sales with all supporting information to enable the
correct sets of EPROMs and DVDs to be dispatched. If in doubt please contact your
distributor or technical support center. Please see "Upgrade-Kits" for Eclipse to Eclipse-HX
upgrades.
5214
SOFTWARE-UG-MED&OME
5220
ECLIPSE-HX POWER SUPPLIES (also suitable for ECLIPSE)
5221
720379Z
Spare PSU for Eclipse and Eclipse-HX(Median & Omega)
Spare PSU for Eclipse and Eclipse-HX(Median & Omega):
Spare PSU Module. Suitable for Eclipse HX-Median, Eclipse HX-Omega, Eclipse Median and
Eclipse Omega.
5222
400101Z
Spare PSU for Eclipse HX-PiCo and Eclipse PiCo
Spare PSU for Eclipse HX-PiCo and Eclipse PiCo:
Spare Eclipse PiCo and HX-PiCo PSU Module.
We recommend purchasing in pairs to balance voltages.
5300
ECLIPSE-HX V-SERIES IP PANELS (YELLOW DISPLAY) (also suitable for ECLIPSE)
5301
V12LDX4Y-IP
V-Series panel 1RU 12 lever XLR4
V-Series panel 1RU 12 lever XLR4:
IP enabled V-Series 1RU 12 lever key yellow ten-character display panel with XLR-4 male
headset connector and user menu. The panel has 12 keys including one reply/answer-back
key and eight shift pages. Each key has individual up/down crosspoint level buttons.
5302
V12LDX5Y-IP
V-Series panel 1RU 12 lever XLR5
V-Series panel 1RU 12 lever XLR5:
IP enabled V-Series 1RU 12 lever key yellow ten-character display panel with XLR-5 female
binaural headset connector and user menu. The panel has 12 keys including one
reply/answer-back key and eight shift pages. Each key has individual up/down crosspoint
level buttons.
5303
V12LDX7Y-IP
V-Series panel 1RU 12 lever XLR7
V-Series panel 1RU 12 lever XLR7 :
IP enabled V-Series 1RU 12 lever key yellow ten-character display panel with XLR-7 male
headset connector and user menu. The panel has 12 keys including one reply/answer-back
key and eight shift pages. Each key has individual up/down crosspoint level buttons.
5304
V24LDX4Y-IP
V-Series panel 2RU 24 lever XLR4
V-Series panel 2RU 24 lever XLR4:
IP enabled V-Series 2RU 24 lever key yellow ten-character display panel with XLR-4 male
headset connector and user menu. The panel has 24 keys including one reply/answer-back
key, dial keypad and eight shift pages. Each key has individual up/down crosspoint level
buttons.
5305
V24LDX5Y-IP
V-Series panel 2RU 24 lever XLR5
V-Series panel 2RU 24 lever XLR5:
IP enabled V-Series 2RU 24 lever key yellow ten-character display panel with XLR-5 female
binaural headset connector and user menu. The panel has 24 keys including one
reply/answer-back key, dial keypad and eight shift pages. Each key has individual up/down
crosspoint level buttons.
5306
V24LDX7Y-IP
V-Series panel 2RU 24 lever XLR7
V-Series panel 2RU 24 lever XLR7 :
IP enabled V-Series 2RU 24 lever key yellow ten-character display panel with XLR-7 male
headset connector and user menu. The panel has 24 keys including one reply/answer-back
key, dial keypad and eight shift pages. Each key has individual up/down crosspoint level
buttons.
5307
V12RDX4
V-Series panel 1RU 12 rotary XLR4
V-Series panel 1RU 12 rotary XLR4:
IP enabled V-Series 1RU 12 Rotary and pushbutton key yellow ten-character display panel
with XLR-4 male headset connector and user menu. The panel has 12 rotary buttons for listen
and crosspoint control and 12 pushbuttons as talk keys including one reply/answer-back key
and eight shift pages. Requires version ECS.5.2 or EHX.7.0 and higher .
5307.2
V12RDX7
V-Series panel 1RU 12 rotary XLR7
V-Series panel 1RU 12 rotary XLR7:
IP enabled V-Series 1RU 12 Rotary and pushbutton key yellow ten-character display panel
with XLR-7 male headset connector and user menu. The panel has 12 rotary buttons for listen
and crosspoint control and 12 pushbuttons as talk keys including one reply/answer-back key
and eight shift pages. Requires version ECS.5.2 or EHX.7.0 and higher .
ClearCom DIR
DIR Price
19 of 33
Part
Index
Short Description
Description
5308
V12RDX5
V-Series panel 1RU 12 rotary XLR5
V-Series panel 1RU 12 rotary XLR5:
IP enabled V-Series 1RU 12 Rotary and pushbutton key yellow ten-character display panel
with XLR-5 female binaural headset connector and user menu. The panel has 12 rotary
buttons for listen and crosspoint control and 12 pushbuttons as talk keys including one
reply/answer-back key and eight shift pages. Requires version ECS.5.2 or EHX.7.0 and higher .
5309
V24RDX4
V-Series panel 2RU 24 rotary XLR4
V-Series panel 2RU 24 rotary XLR4:
IP enabled V-Series 2RU 24 Rotary and pushbutton key yellow ten-character display panel
with XLR-4 male headset connector and user menu. The panel has 24 rotary buttons for listen
and crosspoint control and 24 pushbuttons as talk keys including one reply/answer-back key,
dial keypad and eight shift pages. Requires version ECS.5.2 or EHX.7.0 and higher .
5310
V24RDX5
V-Series panel 2RU 24 rotary XLR5
V-Series panel 2RU 24 rotary XLR5:
IP enabled V-Series 2RU 24 Rotary and pushbutton key yellow ten-character display panel
with XLR-5 female binaural headset connector and user menu. The panel has 24 rotary
buttons for listen and crosspoint control and 24 pushbuttons as talk keys including one
reply/answer-back key, dial keypad and eight shift pages. Requires version ECS.5.2 or
EHX.7.0 and higher .
5311
V12PDX4Y-IP
V-Series panel 1RU 12 pushbutton XLR4
V-Series panel 1RU 12 pushbutton XLR4:
IP enabled V-Series 1RU 12 pushbutton yellow ten-character display panel with XLR-4 male
headset and user menu. The panel has 12 pushbuttons including one reply/answer-back key
and eight shift pages. Each key has individual up/down crosspoint level buttons.
5312
V12PDX7Y-IP
V-Series panel 1RU 12 pushbutton XLR7
V-Series panel 1RU 12 pushbutton XLR7:
IP enabled V-Series 1RU 12 pushbutton yellow ten-character display panel with XLR-7 male
headset and user menu. The panel has 12 pushbuttons including one reply/answer-back key
and eight shift pages. Each key has individual up/down crosspoint level buttons.
5313
V12PDX5Y-IP
V-Series panel 1RU 12 pushbutton XLR5
V-Series panel 1RU 12 pushbutton XLR5:
IP enabled V-Series 1RU 12 pushbutton yellow ten-character display panel with XLR-5 female
binaural headset and user menu. The panel has 12 pushbuttons including one reply/answerback key and eight shift pages. Each key has individual up/down crosspoint level buttons.
5314
V24PDX4Y-IP
V-Series panel 2RU 24 pushbutton XLR4
V-Series panel 2RU 24 pushbutton XLR4:
IP enabled V-Series 2RU 24 pushbutton yellow ten-character display panel with XLR-4 male
headset and user menu. The panel has 24 pushbuttons including one reply/answer-back key,
dial keypad and eight shift pages. Each key has individual up/down crosspoint level buttons.
5315
V24PDX5Y-IP
V-Series panel 2RU 24 pushbutton XLR5
V-Series panel 2RU 24 pushbutton XLR5:
IP enabled V-Series 2RU 24 pushbutton yellow ten-character display panel with XLR-5 female
binaural headset and user menu. The panel has 24 pushbuttons including one reply/answerback key, dial keypad and eight shift pages. Each key has individual up/down crosspoint
level buttons.
5316
V12LDDX4Y-IP
V-Series desktop 12 lever XLR4
V-Series desktop 12 lever XLR4:
IP enabled V-Series 12 lever key yellow ten-character display desktop panel with XLR-4 male
headset connector and user menu. The desktop has 12 keys including one reply/answerback key, dial keypad and eight shift pages. Each key has individual up/down crosspoint
level buttons.
5317
V12LDDX5Y-IP
V-Series desktop 12 lever XLR5
V-Series desktop 12 lever XLR5:
IP enabled V-Series 12 lever key yellow ten-character display desktop panel with XLR-5
female binaural headset connector and user menu. The desktop has 12 keys including one
reply/answer-back key, dial keypad and eight shift pages. Each key has individual up/down
crosspoint level buttons.
5318
V12LDDX7Y-IP
V-Series desktop 12 lever XLR7
V-Series desktop 12 lever XLR7:
IP enabled V-Series 12 lever key yellow ten-character display desktop panel with XLR-7 male
headset connector and user menu. The desktop has 12 keys including one reply/answerback key, dial keypad and eight shift pages. Each key has individual up/down crosspoint
level buttons.
5319
V12RDDX4
V-Series desktop 12 rotary XLR4
V-Series desktop 12 rotary XLR4:
IP enabled V-Series 12 Rotary key yellow ten-character display desktop panel with XLR-4
male headset connector and user menu. The desktop has 12 rotary buttons for listen and
crosspoint control and 12 pushbuttons as talk keys including one reply/answer-back key. dial
keypad and eight shift pages. Requires version ECS.5.2 or EHX.7.0 and higher .
5320
V12RDDX5
V-Series desktop 12 rotary XLR5
V-Series desktop 12 rotary XLR5:
IP enabled V-Series 12 Rotary key yellow ten-character display desktop panel with XLR-5
female binaural headset connector and user menu. The desktop has 12 rotary buttons for
listen and crosspoint control and 12 pushbuttons as talk keys including one reply/answerback key. dial keypad and eight shift pages. Requires version ECS.5.2 or EHX.7.0 and higher .
5321
V12PDDX4Y-IP
V-Series desktop 12 pushbutton XLR4
V-Series desktop 12 pushbutton XLR4:
IP enabled V-Series 12 pushbutton yellow ten-character display desktop panel with XLR-4
male headset connector and user menu. The desktop has 12 buttons including one for
reply/answer-back, dial keypad and eight shift pages. Each button has individual up/down
crosspoint level buttons.
ClearCom DIR
DIR Price
20 of 33
Part
Index
Short Description
Description
5322
V12PDDX5Y-IP
V-Series desktop 12 pushbutton XLR5
V-Series desktop 12 pushbutton XLR5:
IP enabled V-Series 12 pushbutton yellow ten-character display desktop panel with XLR-5
female binaural headset connector and user menu. The desktop has 12 buttons including
one for reply/answer-back, dial keypad and eight shift pages. Each button has individual
up/down crosspoint level buttons.
5323
V12LDEY
V-Series panel 1RU 12 lever expansion
V-Series panel 1RU 12 lever expansion:
V-Series 1RU 12 lever key yellow ten-character display expansion key panel. Connects to the
host V-Series panel over CAT5 up to 7m/25ft. Up to eight lever key expansion panels can be
connected to the V-Series host Lever panel.
5324
V12RDE
V-Series panel 1RU 12 rotary expansion
V-Series panel 1RU 12 rotary expansion:
V-Series 1RU 12 Rotary key yellow ten-character display expansion key panel. Connects to
the V-Series host panel over CAT5 up to 7m/25ft. Up to eight Rotary expansion panels can be
connected to the host V-series Rotary panel. Requires version ECS.5.2 or EHX.7.0 and higher .
5325
V12PDEY
V-Series panel 1RU 12 pushbutton expansion
V-Series panel 1RU 12 pushbutton expansion:
V-Series 1RU 12 pushbutton yellow ten-character display expansion key panel. Connects to
the V-Series host panel over CAT5 up to 7m/25ft. Up to eight pushbutton expansion panels
can be connected to the V-Series host pushbutton panel.
5340
ECLIPSE-HX V-SERIES PANELS with AES & IP ( Also suitable for ECLIPSE)
5342
5343
5344
5345
V12LDX5Y-AES-IP
V24LDX4Y-AES-IP
V24LDX5Y-AES-IP
V12RDX4-AES
V-Series panel 1RU 12 lever XLR5 AES
V-Series panel 1RU 12 lever XLR5 AES:
IP enabled V-Series 1RU 12 lever key yellow ten-character display panel with XLR-5 female
binaural headset connector and user menu. The panel has 12 keys including one
reply/answer-back key and eight shift pages. Each key has individual up/down crosspoint
level buttons. Including factory fitted AES adapter card for coax cable connection or AES3
digital audio over CAT5.
V-Series panel 2RU 24 lever XLR4 AES
V-Series panel 2RU 24 lever XLR4 AES:
IP enabled V-Series 2RU 24 lever key yellow ten-character display panel with XLR-4 male
headset connector and user menu. The panel has 24 keys including one reply/answer-back
key. dial keypad and eight shift pages. Each key has individual up/down crosspoint level
buttons. Including factory fitted AES adapter card for coax cable connection or AES3 digital
audio over CAT5.
V-Series panel 2RU 24 lever XLR5 AES
V-Series panel 2RU 24 lever XLR5 AES:
IP enabled V-Series 2RU 24 lever key yellow ten-character display panel with XLR-5 female
binaural headset connector and user menu. The panel has 24 keys including one
reply/answer-back key. dial keypad and eight shift pages. Each key has individual up/down
crosspoint level buttons. Including factory fitted AES adapter card for coax cable
connection or AES3 digital audio over CAT5.
V-Series panel 1RU 12 rotary XLR4 AES
V-Series panel 1RU 12 rotary XLR4 AES:
IP enabled V-Series 1RU 12 Rotary and pushbutton key yellow ten-character display panel
with XLR-4 male headset connector and user menu. The panel has 12 rotary buttons for listen
and crosspoint control and 12 pushbuttons as talk keys including one reply/answer-back key
and eight shift pages. Including factory fitted AES adapter card for coax cable connection
or AES3 digital audio over CAT5. Requires version ECS.5.2 or higher.
5346
V12RDX5-AES
V-Series panel 1RU 12 rotary XLR5 AES
V-Series panel 1RU 12 rotary XLR5 AES:
IP enabled V-Series 1RU 12 Rotary and pushbutton key yellow ten-character display panel
with XLR-5 female binaural headset connector and user menu. The panel has 12 rotary
buttons for listen and crosspoint control and 12 pushbuttons as talk keys including one
reply/answer-back key and eight shift pages. Including factory fitted AES adapter card for
coax cable connection or AES3 digital audio over CAT5. Requires version ECS.5.2 or higher.
5347
V24RDX4-AES
V-Series panel 2RU 24 rotary XLR4 AES
V-Series panel 2RU 24 rotary XLR4 AES:
IP enabled V-Series 2RU 24 Rotary and pushbutton key yellow ten-character display panel
with XLR-4 male headset connector and user menu. The panel has 24 rotary buttons for listen
and crosspoint control and 24 pushbuttons as talk keys including one reply/answer-back key,
dial keypad and eight shift pages. Including factory fitted AES adapter card for coax cable
connection or AES3 digital audio over CAT5. Requires version ECS.5.2 or higher.
5348
V24RDX5-AES
V-Series panel 2RU 24 rotary XLR5 AES
V-Series panel 2RU 24 rotary XLR5 AES:
IP enabled V-Series 2RU 24 Rotary and pushbutton key yellow ten-character display panel
with XLR-5 female binaural headset connector and user menu. The panel has 24 rotary
buttons for listen and crosspoint control and 24 pushbuttons as talk keys including one
reply/answer-back key, dial keypad and eight shift pages. Including factory fitted AES
adapter card for coax cable connection or AES3 digital audio over CAT5. Requires version
ECS.5.2 or higher.
5349
V12PDX4Y-AES-IP
V-Series panel 1RU 12 pushbutton XLR4 AES
V-Series panel 1RU 12 pushbutton XLR4 AES:
IP enabled V-Series 1RU 12 pushbutton yellow ten-character display panel with XLR-4 male
headset and user menu. The panel has 12 pushbuttons including one reply/answer-back key
and eight shift pages. Each key has individual up/down crosspoint level buttons. Including
factory fitted AES adapter card for coax cable connection or AES3 digital audio over CAT5.
5350
V12PDX5Y-AES-IP
V-Series panel 1RU 12 pushbutton XLR5 AES
V-Series panel 1RU 12 pushbutton XLR5 AES:
IP enabled V-Series 1RU 12 pushbutton yellow ten-character display panel with XLR-5 female
binaural headset and user menu. The panel has 12 pushbuttons including one reply/answerback key and eight shift pages. Each key has individual up/down crosspoint level buttons.
Including factory fitted AES adapter card for coax cable connection or AES3 digital audio
over CAT5.
ClearCom DIR
DIR Price
21 of 33
Part
Index
5351
5352
5353
5354
V24PDX4Y-AES-IP
V24PDX5Y-AES-IP
V12LDDX4Y-AES-IP
V12LDDX5Y-AES-IP
Short Description
Description
V-Series panel 2RU 24 pushbutton XLR4 AES
V-Series panel 2RU 24 pushbutton XLR4 AES:
IP enabled V-Series 2RU 24 pushbutton yellow ten-character display panel with XLR-4 male
headset and user menu. The panel has 24 pushbuttons including one reply/answer-back key,
dial keypad and eight shift pages. Each key has individual up/down crosspoint level buttons.
Including factory fitted AES adapter card for coax cable connection or AES3 digital audio
over CAT5.
V-Series panel 2RU 24 pushbutton XLR5 AES
V-Series panel 2RU 24 pushbutton XLR5 AES:
IP enabled V-Series 2RU 24 pushbutton yellow ten-character display panel with XLR-5 female
binaural headset and user menu. The panel has 24 pushbuttons including one reply/answerback key, dial keypad and eight shift pages. Each key has individual up/down crosspoint
level buttons. Including factory fitted AES adapter card for coax cable connection or AES3
digital audio over CAT5.
V-Series desktop 12 lever XLR4 AES
V-Series desktop 12 lever XLR4 AES:
IP enabled V-Series 12 lever key yellow ten-character display desktop panel with XLR-4 male
headset connector and user menu. The desktop has 12 keys including one reply/answerback key, dial keypad and eight shift pages. Each key has individual up/down crosspoint
level buttons. Including factory fitted AES adapter card for coax cable connection or AES3
digital audio over CAT5.
V-Series desktop 12 lever XLR5 AES
V-Series desktop 12 lever XLR5 AES:
IP enabled V-Series 12 lever key yellow ten-character display desktop panel with XLR-5
female binaural headset connector and user menu. The desktop has 12 keys including one
reply/answer-back key, dial keypad and eight shift pages. Each key has individual up/down
crosspoint level buttons. Including factory fitted AES adapter card for coax cable
connection or AES3 digital audio over CAT5.
5355
V12PDDX4Y-AES-IP
V-Series desktop 12 pushbutton XLR4 AES
V-Series desktop 12 pushbutton XLR4 AES:
IP enabled V-Series 12 pushbutton yellow ten-character display desktop panel with XLR-4
male headset connector and user menu. The desktop has 12 buttons including one for
reply/answer-back, dial keypad and eight shift pages. Each button has individual up/down
crosspoint level buttons. Including factory fitted AES adapter card for coax cable
connection or AES3 digital audio over CAT5.
5356
V12PDDX5Y-AES-IP
V-Series desktop 12 pushbutton XLR5 AES
V-Series desktop 12 pushbutton XLR5 AES:
IP enabled V-Series 12 pushbutton yellow ten-character display desktop panel with XLR-5
female binaural headset connector and user menu. The desktop has 12 buttons including
one for reply/answer-back, dial keypad and eight shift pages. Each button has individual
up/down crosspoint level buttons. Including factory fitted AES adapter card for coax cable
connection or AES3 digital audio over CAT5.
V-Series desktop 12 rotary XLR4 AES
V-Series desktop 12 rotary XLR4 AES:
IP enabled V-Series 12 Rotary key yellow ten-character display desktop panel with XLR-4
male headset connector and user menu. The desktop has 12 rotary buttons for listen and
crosspoint control and 12 pushbuttons as talk keys including one reply/answer-back key, dial
keypad and eight shift pages. Including factory fitted AES adapter card for coax cable
connection or AES3 digital audio over CAT5. Requires version ECS.5.2 or higher.
V-Series desktop 12 rotary XLR5 AES
V-Series desktop 12 rotary XLR5 AES:
IP enabled V-Series 12 Rotary key yellow ten-character display desktop panel with XLR-5
female binaural headset connector and user menu. The desktop has 12 rotary buttons for
listen and crosspoint control and 12 pushbuttons as talk keys including one reply/answerback key, dial keypad and eight shift pages. Including factory fitted AES adapter card for
coax cable connection or AES3 digital audio over CAT5. Requires version ECS.5.2 or higher.
V-Series 24 Lever XLR7 AES
V-Series 24 Lever XLR7 AES:
IP enabled V-Series 2RU 24 lever key yellow ten-character display panel with XLR-7 male
headset connector and user menu. The panel has 24 keys including one reply/answer-back
key. dial keypad and eight shift pages. Each key has individual up/down crosspoint level
buttons. Including factory fitted AES adapter card for coax cable connection or AES3 digital
audio over CAT5.
5357
5358
V12RDDX4-AES
V12RDDX5-AES
DIR Price
5359
V24LDX7Y-AES-IP
5380
V-SERIES MICROPHONES (also used on Helix Net & 4000 panels)
5381
110/340
340mm standard length GN mic
340mm standard length GN mic:
Standard length microphone - gooseneck 34cm/12", for use with 4000, V-Series and HelixNet
panels.
$229.29
5382
110/100
100mm short GN mic
100mm short GN mic:
Short microphone - gooseneck 10cm/4", for use with 4000, V-Series and HelixNet panels.
$265.26
5383
110/490
490mm long GN mic
490mm long GN mic:
Long microphone - extended gooseneck 49cm/19", for use with 4000, V-Series and HelixNet
panels.
$292.24
5390
V-SERIES SPARES AND OPTIONS
5391
V-AES-OPTN
V-Series panel AES adapter card
V-Series panel AES adapter card:
V-Series panel AES3/RJ-45 and AES/BNC adapter card. This card allows the V-Series panels to
operate over coax cable to the AES-6-CX module or over CAT5 to the AES-6-RJ module. This
adapter card only fits latest issue V-Series panels (built after Oct 2008).
5391
V-DISP-YEL-P
V-Series pushbutton display change yellow
V-Series pushbutton display change yellow:
Factory charge to replace one 6-way blue display pushbutton module with a 6-way yellow
display lever key module. 1RU panels require two 6-way modules and 2RU panels require
four. This service is available to match existing V-series blue display panels with yellow
display ones.
ClearCom DIR
22 of 33
Part
Index
Short Description
Description
5391
V-IP-OPTN
V-Series panel IP license
V-Series panel IP license:
V-Series IP software upgrade for existing V-Series panels. It enables any V-Series host (main)
panel with IP access to connect to any IVC-32 card in the remote Eclipse-Median 7 slot or
Eclipse-Omega 15 slot matrices. The price does not include the V-Series panel. Requires
Eclipse v5.1 software or newer.
5391
V-PNL-SW
V-Series software downgrade
V-Series software downgrade:
V-Series Panel older software version. No charge for versions 5.1.3 or 5.2. Downgrade charge
for earlier versions. Default version is v5.2 or HX 7.1.
Specify panels like this: V12LDX5-IP-[4.2]
5391.1
453G023
Universal PSU for V-Series & 4000 Panels
Universal PSU for V-Series & 4000 Panels:
Spare 110/220V AC PSU for V-Series, 4000 panels, ICS-22, AP-22, XP-22, XPL-22 and
FreeSpeak/CellCom PD2201 / CEL-TA antennas and PD2203 splitters. For ICS-22 wall wart PSU
see T11046-1. For V-series panels only the relevant new bracket is 251800Z (on the spares list).
5392
PNL-DESKTOP-KIT
Desktop ears for rack panels
Desktop ears for rack panels:
Panel desktop rack kit. Pair of metal panel ears with soft feet to allow rack mounting panels
to sit on a desktop surface. Suitable for both 1RU and 2RU panels.
5392
V-DISP-YEL-L
V-Series lever display change yellow
V-Series lever display change yellow:
Factory charge to replace one 6-way blue display lever key module with a 6-way yellow
display lever key module. 1RU panels require two 6-way modules and 2RU panels require
four. This service is available to match existing V-series blue display panels with yellow
display ones.
5500
I-SERIES PANELS (AVAILABLE FOR ECLIPSE-HX and ECLIPSE VERSIONS)
5501
i-1200E
I-Series 1RU 16 key non-display panel
I-Series 1RU 16 key non-display panel:
I-Series 1RU with 2 non-display key modules providing 16 pushbuttons, gooseneck and
headset connections, loudspeaker with level control. See AUX101 module for panel audio
and GPI options. Uses GN-250/450 or GM-9/18 series of microphones.
5502
i-1400E
I-Series 1RU 32 key non-display panel
I-Series 1RU 32 key non-display panel:
I-Series 1RU with 4 non-display key modules providing 32 pushbuttons, gooseneck and
headset connections, loudspeaker with level control. See AUX101 module for panel audio
and GPI options. Uses GN-250/450 or GM-9/18 series of microphones.
5503
i-1430E
i-Series 1RU 32 key display & keypad
i-Series 1RU 32 key display & keypad:
I-Series 1RU with four display key modules and keypad providing 32 pushbuttons and four
displays, keypad for local assignments, gooseneck and headset connections and
loudspeaker with level control. See I-1470E or AUX101 module for panel audio and GPI
options. Uses GN-250/450 or GM-9/18 series of microphones.
5505
i-1470E
i-Series 1RU 32 key display, keypad & AUX-101
i-Series 1RU 32 key display, keypad & AUX-101:
I-Series 1RU with four display key modules and a keypad providing 32 pushbuttons and four
displays, gooseneck and headset connections and loudspeaker with level control. Includes
AUX101 module for panel audio and GPI options. Uses GN-250/450 or GM-9/18 series of
microphones.
5506
i-1210E
I-Series 1RU 16 key display panel
I-Series 1RU 16 key display panel:
I-Series 1RU with two display key module providing 16 pushbuttons and display, gooseneck
and headset connections and loudspeaker with level control. See AUX101 module for panel
audio and GPI options. Uses GN-250/450 or GM-9/18 series of microphones. This panel does
not have a keypad. See I-1430E or I-1470E.
5507
i-1110E
I-Series 1RU 8 key display panel
I-Series 1RU 8 key display panel:
I-Series 1RU with one display key module providing eight pushbuttons and display,
gooseneck and headset connections and loudspeaker with level control. See AUX101
module for panel audio and GPI options. Uses GN-250/450 or GM-9/18 series of
microphones.
5508
e-1410E
i-Series 32 key expansion panel & display
i-Series 32 key expansion panel & display:
I-Series expansion panel with four display key modules providing an extra 32 pushbuttons.
5509
AUX-101
i-Series relay/GPI & audio option
i-Series relay/GPI & audio option:
I-Series relay-GPI and audio I/O option card. Customer fit option. See i-1470E for factory
fitted option.
5509.1
DIR Price
I-SERIES MICROPHONES (also used ICS panels)
5510
GN-250
250mm standard length plug-in GN mic
250mm standard length plug-in GN mic:
I-Series gooseneck microphone 25cm/10". Also available for ICS-1008E and ICS-1016E panels
and party-line stations.
$193.33
5511
GN-450
450mm long plug-in GN mic
450mm long plug-in GN mic:
I-Series gooseneck microphone 45cm/18". Also available for ICS-1008E and ICS-1016E panels
and party-line stations.
$202.32
5520
ICS PANEL SUPPORT (NOT AVAILABLE FOR ECLIPSE HX VERSION)
5524
ICS-1008E
ClearCom DIR
16 pushbutton panel (no display)
16 pushbutton panel (no display):
16-key pushbutton panel (paper label, no display) 1RU. Uses GM-9, GM-18, GN-250 or GN-450
microphones. Uses an external universal PSU-24 supplied. Not compatible with Eclipse-HX
23 of 33
Part
Index
Short Description
Description
5525
ICS-1016E
32 pushbutton panel (no display)
32 pushbutton panel (no display):
32-key pushbutton panel (paper label, no display) 1RU. Uses GM-9, GM-18, GN-250 or GN-450
microphones. Uses an external universal PSU-24 supplied. Not compatible with Eclipse-HX
5526
ICS-22
Flush 2 label selector speaker station
Flush 2 label selector speaker station:
Flush-mount two port selectable speaker station. Mounts in a four-gang US wall box. This item
requires external 16-28V DC power, (AC wall wart included). For installation please see the
Product Manual. Not compatible with Eclipse-HX.
5528
DT-BOX
Desktop box
Desktop box:
Desktop box for ICS-21 or ICS-22.
5529
ICS-52/92PNL-UG
ICS-52 or 92 panel upgrade charge
ICS-52 or 92 panel upgrade charge:
Kit to allow ICS-52 and ICS-92 panels to be connected to Eclipse matrix systems. Includes
single panel 710630 EPROM and RJ-45 rear panel. Not compatible with Eclipse-HX
5530
ICS-62/102PNL-UG
ICS-62 or 102 panel upgrade charge
ICS-62 or 102 panel upgrade charge:
Kit to allow ICS-62 and ICS-102 panels to be connected to Eclipse matrix systems. Includes
single panel 710631 EPROM and RJ-45 rear panel. Not compatible with Eclipse-HX
5531
ICS-2003PNL-UG
ICS-2003 panel upgrade charge
ICS-2003 panel upgrade charge:
Kit to allow ICS-2003 panels to be connected to Eclipse matrix systems. Includes single panel
710648Z AND 710649Z EPROMS. Not compatible with Eclipse-HX
5532
ICS-1008/16PNL-UG
ICS-1008 or 1016 panel upgrade charge
ICS-1008 or 1016 panel upgrade charge:
Kit to allow ICS-1008 and ICS-1016 panels to be connected to Eclipse matrix systems.
Includes single panel 710632Z EPROMS. Not compatible with Eclipse-HX
5540.1
DIR Price
4000 SERIES 2 PANEL SUPPORT (NOT AVAILABLE FOR ECLIPSE HX VERSION)
5545
710684Z
Eclipse 4200 panel isolator card
Eclipse 4200 panel isolator card:
Spare panel RJ-45 Isolator card required when the 42xxE rack mounted panels are
connected to Eclipse matrix systems. Not compatible with Eclipse-HX
5546
710685Z
Eclipse 4294 desktop panel isolator card
Eclipse 4294 desktop panel isolator card:
Spare panel RJ-45 Isolator card required for 4294 desktop panels are connected to Eclipse
matrix systems. Not compatible with Eclipse-HX
5547
4224/15/26PNL-UG
Eclipse 4200 pushbutton upgrade panel kit
Eclipse 4200 pushbutton upgrade panel kit:
Kit to allow 4224/15/26 panels to be connected to Eclipse matrix systems. Including 710684Z
isolator card, boot EPROM and Clear-Com badge. Not compatible with Eclipse-HX
5548
4212/22PNL-UG
Eclipse 4200 LCD panel upgrade kit
Eclipse 4200 LCD panel upgrade kit:
Kit to allow 4212/4222 panels to be connected to Eclipse matrix systems. Including 710685Z
isolator card, boot EPROM and Clear-Com badge. Not compatible with Eclipse-HX
5549
4294PNL-UG
Eclipse 4200 desktop panel upgrade kit
Eclipse 4200 desktop panel upgrade kit:
Kit to allow 4294 desktop panels to be connected to Eclipse matrix systems. Including
710685Z isolator card, boot EPROM and Clear-Com badge. Not compatible with Eclipse-HX
5560
ECLIPSE-HX INTERFACE MODULES (also suitable for ECLIPSE)
5561
CCI-22
2 Ch. Partyline Module
2 Ch. Partyline Module:
2-wire Clear-Com/RTS dual party-line interface. Does not power the party-lines attached to
CCI-22 modules, these require Encore master station PSUs such as the PS-702 or MS-702.
Includes DB-9 mating connectors.
5563
FOR-22
2 Ch. 4wire/2 way transmitter Balanced module
2 Ch. 4wire/2 way transmitter Balanced module:
4-wire/two-way radio dual interface module. Dual channel 4-wire interface with transformer
balancing and level control. Including a software controlled relay changeover per channel.
Includes DB-9 mating connectors. May require custom cable for radio connections, (not
supplied).
5565
TEL-14
2 Ch. Telephone Hybrid module
2 Ch. Telephone Hybrid module:
Two-line auto-nulling dual digital telephone interface module. Provides telephone line
balancing for two separate POTS lines. Intercom panels can dial out and the lines dial into
ports under software control. See 710755Z new CPU.
5568
RLY-6
6 SPDT Relay Control Module
6 SPDT Relay Control Module:
Relay control interface module (six SPDT relays).
5570
GPI-6
6 Opto Input Control Module
6 Opto Input Control Module:
Input control interface module (six universal inputs).
5572
AES-6-RJ
6 Ch. AES3 digital audio module
6 Ch. AES3 digital audio module:
AES-6 AES3 digital audio interface module for use with IMF-3, IMF-102 and Eclipse-Median,
Eclipse HX-Median and Eclipse HX-Delta frames. Uses RJ-45 connectors. Provides for six
monaural or three stereo AES3 digital audio channels to ports on the Eclipse or Eclipse-HX
matrices.
ClearCom DIR
24 of 33
Part
Index
Short Description
Description
5573
AES-6-CX
6 way coax digital panel module
6 way coax digital panel module:
AES-6 coax interface module for use with IMF-3, IMF-102, Eclipse-Median, Eclipse HX-Median
and Eclipse HX-Delta frames. Provides V-Series-AES coax panels (or 4000 panels with the
PDE4536 option card) two channel coax connection for use with Eclipse and Eclipse-HX
matrices.
5574
IMF-102
1RU interface module frame including PSU
1RU interface module frame including PSU:
1RU interface module frame with internal PSU, holds one or two horizontal interface
modules. Note: Does not power the party-lines attached to CCI-22 modules.
5575
IMF-3
3RU interface module frame excluding PSU
3RU interface module frame excluding PSU:
IMF-3 interface module frame 3RU, holds 11 interface modules. Includes cable and blanking
plates are supplied as required Requires a 1RU external power supply, PSU-101, if using an
interface besides the CCI-22. Limit of 8 TEL-14 modules.
5576
PSU-101
1RU PSU for IMF-3 interface frame
1RU PSU for IMF-3 interface frame:
PSU-101 power supply for the IMF-3. Includes cable, Note: Does not power the party-lines
attached to CCI-22 modules.
5577
820079Z
IMF-3 or 102 blank cover kit
IMF-3 or 102 blank cover kit:
Blank cover kit includes front and rear blanking plates and fixing screws.
5580
BAL-8
1RU 8 port transformer isolation
1RU 8 port transformer isolation:
1RU eight port transformer isolation. Interface contains eight four-pair, transformer-isolated
ports. Each port handles two audio signals and two RS-422 data lines. The unit isolates the
connection between Eclipse ports and peripheral devices such as cameras or monitoring
systems.
5583
TW-60
1RU 4 Ch. radio comms interface
1RU 4 Ch. radio comms interface:
Four channel two-way radio interface connecting Clear-Com or other radios to any twoway radio. Has a variable audio delay for offsetting key up times.
5584
IFB-104
1RU 4 port IFB breakout interface
1RU 4 port IFB breakout interface:
1RU four-port XLR-3 IFB intercom/audio cue break out matrix interface. Each IFB output and
program audio/cue audio uses XLR-3 I/O and is transformer balanced. Connections to the
matrix use RJ-45. If directly connecting TR-50s, a power supply such as the PK-7 or PS-702 is
required.
5585
FIM-202D
Dual port fiber matrix to 2 remote panels
Dual port fiber matrix to 2 remote panels:
Two-port matrix frame to/from panel or module fiber interface (dual fiber run required). Can
be used for one or two audio connections over fiber. Price quoted is for one unit and two
units are required per two 4-wire audio channels or two panel to matrix links.
15000
15001
15002
ICON INTERFACING SOLUTIONS
THESE PRODUCTS CAN BE USED TO EXTEND CLEAR-COM INTO OTHER INTERCOM OR AUDIO SYSTEMS
ProGrid Digital
All devices include dual PSU
15003
PG32-AES-FXM
ProGrid 4x8 AES3 Iface MM
ProGrid 4x8 AES3 Iface MM:
1RU, 4x 8 AES3 channels ports, allowing any I/O combination of 32 AES3 (64 mono channels),
Dual PSU, Multi Mode Fiber & SANE Twisted Pair CAT5.
15004
PG32-AES- FXS
ProGrid 4x8 AES3 Iface SM
ProGrid 4x8 AES3 Iface SM:
1RU, 4x 8 AES3 channels ports, allowing any I/O combination of 32 AES3 (64 mono channels),
Dual PSU, Single Mode Fiber & SANE Twisted Pair CAT5.
15005
PG2-MADI -F-FXM
ProGrid 2xMADI Iface MM
ProGrid 2xMADI Iface MM:
1RU, 2x 64 MADI In + 2x 64 MADI Out via SC optical port, Dual PSU, Multi Mode Fiber & SANE
Twisted Pair CAT5.
15006
PG2-MADI-F-FXS
ProGrid 2xMADI Iface SM
ProGrid 2xMADI Iface SM:
1RU, 2x 64 MADI In + 2x 64 MADI Out via SC optical port, Dual PSU, Single Mode Fiber & SANE
Twisted Pair CAT5.
15007
PG2-MADI-C-FXM
ProGrid 2xMADI If BNC MM
ProGrid 2xMADI If BNC MM:
1RU, 2x 64 MADI In + 2x 64 MADI Out via BNC port, Dual PSU, Multi Mode Fiber & SANE
Twisted Pair CAT5.
15008
PG2-MADI-C-FXS
ProGrid 2xMADI If BNC SM
ProGrid 2xMADI If BNC SM:
1RU, 2x 64 MADI In + 2x 64 MADI Out via BNC port, Dual PSU, Single Mode Fiber & SANE
Twisted Pair CAT5.
15009
ProGrid Audio Products
15010
PG16-16MI-FXM
ProGrid 16 Mic ip Ifce MM
ProGrid 16 Mic ip Ifce MM:
1RU, 16 Microphone Inputs, Dual PSU, Multi Mode Fiber & SANE Twisted Pair CAT5. inc 17 x 3pole Euroblock screw connectors
15011
PG16-16MI-FXS
ProGrid 16 Mic ip Ifce SM
ProGrid 16 Mic ip Ifce SM:
1RU, 16 Microphone Inputs, Dual PSU, Single Mode Fiber & SANE Twisted Pair CAT5. inc 17 x 3pole Euroblock screw connectors
15012
PG16-16MI-TP
ProGrid 16 Mic ip Ifce TP
ProGrid 16 Mic ip Ifce TP:
1RU, 16 Microphone Inputs, Dual PSU, SANE Twisted Pair CAT5 Only. inc 17 x 3-pole Euroblock
screw connectors
ClearCom DIR
DIR Price
25 of 33
Part
Index
Short Description
Description
15013
PG16-16LI-FXM
ProGrid 2x8 lne ip If MM
ProGrid 2x8 lne ip If MM:
1RU, 2 x 8 channel Line Inputs, Dual PSU, Multi Mode Fiber & SANE Twisted Pair CAT5. inc 17 x
3-pole Euroblock screw connectors
15014
PG16-16LI-FXS
ProGrid 2x8 lne ip If SM
ProGrid 2x8 lne ip If SM:
1RU, 2 x 8 channel Line Inputs, Dual PSU, Single Mode Fiber & SANE Twisted Pair CAT5. inc 17 x
3-pole Euroblock screw connectors
15015
PG16-16LI-TP
ProGrid 2x8 lne ip If TP
ProGrid 2x8 lne ip If TP:
1RU, 2 x 8 channel Line Inputs, Dual PSU, SANE Twisted Pair CAT5 Only. inc 17 x 3-pole
Euroblock screw connectors
15016
PG16-16LO-FXM
ProGrid 2x8 lne op If MM
ProGrid 2x8 lne op If MM:
1RU, 2 x 8 channel Line Outputs, Dual PSU, Multi Mode Fiber & SANE Twisted Pair CAT5. inc 17
x 3-pole Euroblock screw connectors
15017
PG16-16LO-FXS
ProGrid 2x8 lne op If SM
ProGrid 2x8 lne op If SM:
1RU, 2 x 8 channel Line Outputs, Dual PSU, Single Mode Fiber & SANE Twisted Pair CAT5. inc
17 x 3-pole Euroblock screw connectors
15018
PG16-16LO-TP
ProGrid 2x8 lne op If TP
ProGrid 2x8 lne op If TP:
1RU, 2 x 8 channel Line Outputs, Dual PSU, SANE Twisted Pair CAT5 Only. inc 17 x 3-pole
Euroblock screw connectors
15019
PG16-8MI-8LI-FXM
ProGrid 8 Mic 8 ip If MM
ProGrid 8 Mic 8 ip If MM:
1RU, 1 x 8 channel Microphone Inputs, 1 x 8 channel Line Inputs, Dual PSU, Multi Mode Fiber
& SANE Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15020
PG16-8MI-8LI-FXS
ProGrid 8 Mic 8 ip If SM
ProGrid 8 Mic 8 ip If SM:
1RU, 1 x 8 channel Microphone Inputs, 1 x 8 channel Line Inputs, Dual PSU, Single Mode Fiber
& SANE Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15021
PG16-8MI-8LI-TP
ProGrid 8 Mic 8 ip If TP
ProGrid 8 Mic 8 ip If TP:
1RU, 1 x 8 channel Microphone Inputs, 1 x 8 channel Line Inputs, Dual PSU, SANE Twisted Pair
CAT5 Only. inc 17 x 3-pole Euroblock screw connectors
15022
PG16-8MI-8LO-FXM
ProGrid 8 Mic 8 op If MM
ProGrid 8 Mic 8 op If MM:
1RU, 1 x 8 channel Microphone Inputs, 1 x 8 channel Line Outputs, Dual PSU, Multi Mode
Fiber & SANE Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15023
PG16-8MI-8LO-FXS
ProGrid 8 Mic 8 op If SM
ProGrid 8 Mic 8 op If SM:
1RU, 1 x 8 channel Microphone Inputs, 1 x 8 channel Line Outputs, Dual PSU, Single Mode
Fiber & SANE Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15024
PG16-8MI-8LO-TP
ProGrid 8 Mic 8 op If TP
ProGrid 8 Mic 8 op If TP:
1RU, 1 x 8 channel Microphone Inputs, 1 x 8 channel Line Outputs, Dual PSU, SANE Twisted
Pair CAT5 Only. inc 17 x 3-pole Euroblock screw connectors
15025
PG16-8LI-8LO-FXM
ProGrid 8 ip 8 op If MM
ProGrid 8 ip 8 op If MM:
1RU, 1 x 8 channel Line Inputs, 1 x 8 channel Line Outputs, Dual PSU, Multi Mode Fiber & SANE
Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15026
PG16-8LI-8LO-FXS
ProGrid 8 ip 8 op If SM
ProGrid 8 ip 8 op If SM:
1RU, 1 x 8 channel Line Inputs, 1 x 8 channel Line Outputs, Dual PSU, Single Mode Fiber &
SANE Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15027
PG16-8LI-8LO-TP
ProGrid 8 ip 8 op If TP
ProGrid 8 ip 8 op If TP:
1RU, 1 x 8 channel Line Inputs, 1 x 8 channel Line Outputs, Dual PSU, SANE Twisted Pair CAT5
Only. inc 17 x 3-pole Euroblock screw connectors
15028
PG16-8DMPRE-FXM
ProGrid 8 dual Mic If MM
ProGrid 8 dual Mic If MM:
1RU, 1 x 8 channel Microphone Inputs with dual preamps and converters, Dual PSU, Multi
Mode Fiber & SANE Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15029
PG16-8DMPRE-FXS
ProGrid 8 dual Mic If SM
ProGrid 8 dual Mic If SM:
1RU, 1 x 8 channel Microphone Inputs with dual preamps and converters, Dual PSU, Single
Mode Fiber & SANE Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15030
PG16-8DMPRE-TP
ProGrid 8 dual Mic If TP
ProGrid 8 dual Mic If TP:
1RU, 1 x 8 channel Microphone Inputs with dual preamps and converters, Dual PSU, SANE
Twisted Pair CAT5 Only. inc 17 x 3-pole Euroblock screw connectors
15031
PG16-8AE-FXM
ProGrid 8 AES3 If MM
ProGrid 8 AES3 If MM:
1RU, 1 x 8 channel AES3 I-O, Dual PSU, Multi Mode fiber & SANE Twisted Pair CAT5. inc 17 x 3pole Euroblock screw connectors
15032
PG16-8AE-FXS
ProGrid 8 AES3 If SM
ProGrid 8 AES3 If SM:
1RU, 1 x 8 channel AES3 I-O, Dual PSU, Single Mode fiber & SANE Twisted Pair CAT5. inc 17 x 3pole Euroblock screw connectors
ClearCom DIR
DIR Price
26 of 33
Part
Index
Short Description
Description
15033
PG16-8AE-TP
ProGrid 8 AES3 If TP
ProGrid 8 AES3 If TP:
1RU, 1 x 8 channel AES3 I-O, Dual PSU, SANE Twisted Pair CAT5 Only. inc 17 x 3-pole Euroblock
screw connectors
15034
PG16-8AE-SRC-FXM
ProGrid 8 AES3 SRC If MM
ProGrid 8 AES3 SRC If MM:
1RU, 1 x 8 channel AES3 I-O with internal sample rate convertor, Dual PSU, Multi Mode fiber &
SANE Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15035
PG16-8AE-SRC-FXS
ProGrid 8 AES3 SRC If SM
ProGrid 8 AES3 SRC If SM:
1RU, 1 x 8 channel AES3 I-O with internal sample rate convertor, Dual PSU, Single Mode fiber
& SANE Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15036
PG16-8AE-SRC-TP
ProGrid 8 AES3 SCR If TP
ProGrid 8 AES3 SCR If TP:
1RU, 1 x 8 channel AES3 I-O with internal sample rate convertor, Dual PSU, SANE Twisted Pair
CAT5 Only. inc 17 x 3-pole Euroblock screw connectors
15037
PG16-4AE-8MI-FXM
ProGrid 4 AES3 8mic If MM
ProGrid 4 AES3 8mic If MM:
1RU, 1 x 4 channel AES3 I-O, 1 x 8 channel Microphone Inputs, Dual PSU, Multi Mode fiber &
SANE Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15038
PG16-4AE-8MI-FXS
ProGrid 4 AES3 8mic If SM
ProGrid 4 AES3 8mic If SM:
1RU, 1 x 4 channel AES3 I-O, 1 x 8 channel Microphone Inputs, Dual PSU, Single Mode fiber &
SANE Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15039
PG16-4AE-8MI-TP
ProGrid 4 AES3 8mic If TP
ProGrid 4 AES3 8mic If TP:
1RU, 1 x 4 channel AES3 I-O, 1 x 8 channel Microphone Inputs, Dual PSU, SANE Twisted Pair
CAT5 Only. inc 17 x 3-pole Euroblock screw connectors
15040
PG16-4AE-8LI-FXM
ProGrid 4 AES3 8 li If MM
ProGrid 4 AES3 8 li If MM:
1RU, 1 x 4 channel AES3 I-O, 1 x 8 channel Line Inputs, Dual PSU, Multi Mode fiber & SANE
Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15041
PG16-4AE-8LI-FXS
ProGrid 4 AES3 8 li If SM
ProGrid 4 AES3 8 li If SM:
1RU, 1 x 4 channel AES3 I-O, 1 x 8 channel Line Inputs, Dual PSU, Single Mode Fiber & SANE
Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors
15042
PG16-4AE-8LI-TP
ProGrid 4 AES3 8 li If TP
ProGrid 4 AES3 8 li If TP:
1RU, 1 x 4 channel AES3 I-O, 1 x 8 channel Line Inputs, Dual PSU, SANE Twisted Pair CAT5. inc
17 x 3-pole Euroblock screw connectors
15043
PG16-4AE-8LO-FXM
ProGrid 4 AES3 8 lo If MM
ProGrid 4 AES3 8 lo If MM:
1RU, 1 x 4 channel AES3 I-O, 1 x 8 channel Line Outputs, Dual PSU, Multi Mode fiber & SANE
Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors.
15044
PG16-4AE-8LO-FXS
ProGrid 4 AES3 8 lo If SM
ProGrid 4 AES3 8 lo If SM:
1RU, 1 x 4 channel AES3 I-O, 1 x 8 channel Line Outputs, Dual PSU, Single Mode Fiber & SANE
Twisted Pair CAT5. inc 17 x 3-pole Euroblock screw connectors.
15045
PG16-4AE-8LO-TP
ProGrid 4 AES3 8 lo If TP
ProGrid 4 AES3 8 lo If TP:
1RU, 1 x 4 channel AES3 I-O, 1 x 8 channel Line Outputs, Dual PSU, SANE Twisted Pair CAT5. inc
17 x 3-pole Euroblock screw connectors.
15046
PG8-8MI-FXM
ProGrid 8 Mic ip Ifce MM
ProGrid 8 Mic ip Ifce MM:
1RU, 1 x 8 channel Microphone Inputs, Dual PSU, Multi Mode Fiber & SANE Twisted Pair CAT5.
inc 9 x 3-pole Euroblock screw connectors.
15047
PG8-8MI-FXS
ProGrid 8 Mic ip Ifce SM
ProGrid 8 Mic ip Ifce SM:
1RU, 1 x 8 channel Microphone Inputs, Dual PSU, Single Mode Fiber & SANE Twisted Pair CAT5.
inc 9 x 3-pole Euroblock screw connectors.
15048
PG8-8MI-TP
ProGrid 8 Mic ip Ifce TP
ProGrid 8 Mic ip Ifce TP:
1RU, 1 x 8 channel Microphone Inputs, Dual PSU, SANE Twisted Pair CAT5 Only. inc 9 x 3-pole
Euroblock screw connectors.
15049
PG8-8LI-FXM
ProGrid 1x8 lne ip If MM
ProGrid 1x8 lne ip If MM:
1RU, 1 x 8 channel Line Inputs, Dual PSU, Multi Mode Fiber & SANE Twisted Pair CAT5. inc 9 x 3pole Euroblock screw connectors.
15050
PG8-8LI-FXS
ProGrid 1x8 lne ip If SM
ProGrid 1x8 lne ip If SM:
1RU, 1 x 8 channel Line Inputs, Dual PSU, Single Mode Fiber & SANE Twisted Pair CAT5. inc 9 x
3-pole Euroblock screw connectors.
15051
PG8-8LI-TP
ProGrid 1x8 lne ip If TP
ProGrid 1x8 lne ip If TP:
1RU, 1 x 8 channel Line Inputs, Dual PSU, SANE Twisted Pair CAT5 Only. inc 9 x 3-pole
Euroblock screw connectors.
15052
PG8-8LO-FXM
ProGrid 1x8 lne op If MM
ProGrid 1x8 lne op If MM:
1RU, 1 x 8 channel Line Outputs, Dual PSU, Multi Mode Fiber & SANE Twisted Pair CAT5. inc 9 x
3-pole Euroblock screw connectors.
15053
PG8-8LO-FXS
ProGrid 1x8 lne op If SM
ProGrid 1x8 lne op If SM:
1RU, 1 x 8 channel Line Outputs, Dual PSU, Single Mode Fiber & SANE Twisted Pair CAT5. inc 9
x 3-pole Euroblock screw connectors.
ClearCom DIR
DIR Price
27 of 33
Part
Index
Short Description
Description
ProGrid 1x8 lne op If TP
ProGrid 1x8 lne op If TP:
1RU, 1 x 8 channel Line Outputs, Dual PSU, SANE Twisted Pair CAT5 Only. inc 9 x 3-pole
Euroblock screw connectors.
PG8-INTERCOM-CC-FXM
ProGrid 8 422C Icom If MM
ProGrid 8 422C Icom If MM:
1RU, 8 x 4-channel Intercom Inputs + 8 x 4-channel Intercom Outputs, Dual PSU, Multi Mode
fiber & SANE Twisted Pair CAT5, Clear-Com Intercom.
15057
PG8-INTERCOM-CC-FXS
ProGrid 8 422C Icom If SM
ProGrid 8 422C Icom If SM:
1RU, 8 x 4-channel Intercom Inputs + 8 x 4-channel Intercom Outputs, Dual PSU, Single Mode
Fiber & SANE Twisted Pair CAT5, Clear-Com Intercom.
15059
PG8-INTERCOM-485-FXM
ProGrid 8 485R Icom If MM
ProGrid 8 485R Icom If MM:
1RU, 8 x 4-channel Intercom Inputs + 8 x 4-channel Intercom Outputs, Dual PSU, Multi Mode
Fiber & SANE Twisted Pair CAT5, Intercom with RS485 data.
15060
PG8-INTERCOM-485-FXS
ProGrid 8 485R Icom If SM
ProGrid 8 485R Icom If SM:
1RU, 8 x 4-channel Intercom Inputs + 8 x 4-channel Intercom Outputs, Dual PSU, Single Mode
Fiber & SANE Twisted Pair CAT5, Intercom with RS485 data.
15062
PG8-INTERCOM-444-FXM
ProGrid 8 444 Icom If MM
ProGrid 8 444 Icom If MM:
1RU, 8 x 4-channel Intercom Inputs + 8 x 4-channel Intercom Outputs, Dual PSU, Multi Mode
Fiber & SANE Twisted Pair CAT5, Intercom with optically isolated GPIO.
15063
PG8-INTERCOM-444-FXS
ProGrid 8 444 Icom If SM
ProGrid 8 444 Icom If SM:
1RU, 8 x 4-channel Intercom Inputs + 8 x 4-channel Intercom Outputs, Dual PSU, Single Mode
Fiber & SANE Twisted Pair CAT5, Intercom with optically isolated GPIO.
15065
PG4-INTERCOM-CC-FXM
ProGrid 4 422C Icom If MM
ProGrid 4 422C Icom If MM:
1RU, 4 x 4-channel Intercom Inputs + 4 x 4-channel Intercom Outputs, Dual PSU, Multi Mode
fiber & SANE Twisted Pair CAT5, Clear-Com intercom.
15066
PG4-INTERCOM-CC-FXS
ProGrid 4 422C Icom If SM
ProGrid 4 422C Icom If SM:
1RU, 4 x 4-channel Intercom Inputs + 4 x 4-channel Intercom Outputs, Dual PSU, Single Mode
Fiber & SANE Twisted Pair CAT5, Clear-Com intercom.
15068
PG4-INTERCOM-485-FXM
ProGrid 4 485R Icom If MM
ProGrid 4 485R Icom If MM:
1RU, 4 x 4-channel Intercom Inputs + 4 x 4-channel Intercom Outputs, Dual PSU, Multi Mode
Fiber & SANE Twisted Pair CAT5.
15069
PG4-INTERCOM-485-FXS
ProGrid 4 485R Icom If SM
ProGrid 4 485R Icom If SM:
1RU, 4 x 4-channel Intercom Inputs + 4 x 4-channel Intercom Outputs, Dual PSU, Single Mode
Fiber & SANE Twisted Pair CAT5.
15070
PG4-INTERCOM-485-TP
ProGrid 4 485R Icom If TP
ProGrid 4 485R Icom If TP:
1RU, 4 x 4-channel Intercom Inputs + 4 x 4-channel Intercom Outputs, Dual PSU, SANE Twisted
Pair CAT5 Only.
15071
PG4-INTERCOM-444-FXM
ProGrid 4 444 Icom If MM
ProGrid 4 444 Icom If MM:
1RU, 4 x 4-channel Intercom Inputs + 4 x 4-channel Intercom Outputs, Dual PSU, Multi Mode
Fiber & SANE Twisted Pair CAT5.
15072
PG4-INTERCOM-444-FXS
ProGrid 4 444 Icom If SM
ProGrid 4 444 Icom If SM:
1RU, 4 x 4-channel Intercom Inputs + 4 x 4-channel Intercom Outputs, Dual PSU, Single Mode
Fiber & SANE Twisted Pair CAT5.
15076
ProGrid Yamaha Products
15077
PG-YG2
Master module with 8 or 16 audio I-O, HA Remote transport, 10100Mb Fast Ethernet port
Master module with 8 or 16 audio I-O, HA Remote transport, 10-100Mb Fast Ethernet port:
Master module with 8 or 16 audio I/O, HA Remote transport, 10/100Mb Fast Ethernet port.
15078
PG-YS2
Slave module with 8 or 16 audio I-O. Up to 3x YS2 in 16 channel
mode or up to 7x PG-YS2 in 8 channel mode when used in
conjunction with 1x YG2 module.
Slave module with 8 or 16 audio I-O. Up to 3x YS2 in 16 channel mode or up to 7x PG-YS2 in 8
channel mode when used in conjunction with 1x YG2 module.:
Slave module with 8 or 16 audio I/O. Up to 3x YS2 in 16 channel mode or up to 7x PG-YS2 in 8
channel mode when used in conjunction with 1x YG2 module.
15079
PG-Y3R-TP
SANE module with 8 or 16 audio I-O, HA Remote transport, 10-100Mb Fast Ethernet port. Each
SANE module with 8 or 16 audio I-O, HA Remote transport, 10card is independent and multiple cards can be used in one Yamaha console.:
100Mb Fast Ethernet port. Each card is independent and multiple
SANE module with 8 or 16 audio I/O, HA Remote transport, 10/100Mb Fast Ethernet port. Each
cards can be used in one Yamaha console.
card is independent and multiple cards can be used in one Yamaha console.
15091
ProGrid 3rd Party Accessories
15054
PG8-8LO-TP
15055
ProGrid Intercom Products
15056
15121
MUX-22-CC
ClearCom DIR
2 x 4 Ch CC I-com + 4 video i/o fiber i/f
DIR Price
2 x Opt 4 Ch CC I-com + 4 video i/o fiber i/f:
Two point to point Broaman Intercom and Video interfaces each with two SANE CAT5
network ports and Optocore Multi-Mode LC Fiber interface. Includes 4 Clear-Com RS422
intercom channels, 4 3G-SDI video inputs and 4 3G-SDI video outputs. A separate sync
output is available. GPIO Option card. Redundant PSU included. Both Broaman MUX
interfaces required for end to end link.
28 of 33
Part
Index
Short Description
Description
DIR Price
15129
VOICE2
1RU 4 Ch. IP communications interface
1RU 4 Ch. IP communications interface:
Four channel IP communications interface, 1RU, for extending intercom audio
communications to remote sites over IP networks (LAN, WAN, Internet). Supports: Up to 4
remote user panels intelligently linked backed to the Eclipse Digital Matrix; Up to 4 intelligent
trunk lines between remote matrix systems; Up to 4 four-wire Audio pairs and 4 Asynchronous
RS-422 data links. Rev. B.
15130
Concert-Server-4W
Pre-Loaded 4/W Concert Server Assembly
Pre-Loaded 4/W Concert Server Assembly:
Server Hardware equipped with 8 duplex 4-Wire audio ports and pre-loaded with Concert
Server software. Includes breakout to 16 XLRs (8 Inputs and 8 Outputs). Utilizes an ASI5640
sound card.
15131
FIM-202D
Dual port fiber matrix to 2 remote panels
Dual port fiber matrix to 2 remote panels:
Two-port matrix frame to/from panel or module fiber interface (dual fiber run required). Can
be used for one or two audio connections over fiber. Price quoted is for one unit and two
units are required per two 4-wire audio channels or two panel to matrix links.
5700
ECLIPSE-HX SYSTEM MANUALS
5701
MAN-ECLIPSE-HX-PICO
Eclipse HX-PiCo paper manual set
Eclipse HX-PiCo paper manual set:
Eclipse HX-PiCo paper manual set. This is a bound set of paper manuals in addition to the
CD-ROM already supplied with the equipment. It includes all Eclipse interfaces and panels.
5702
MAN-ECLIPSE-HX-MEDIAN
Eclipse HX-Median paper manual set
Eclipse HX-Median paper manual set:
Eclipse HX-Median 7 slot paper manual set. This is a bound set of paper manuals in addition
to the CD-ROM already supplied with the equipment. Including all Eclipse interfaces and
panels.
5703
MAN-ECLIPSE-HX-OMEGA
Eclipse HX-Omega paper manual set
Eclipse HX-Omega paper manual set:
Eclipse HX-Omega 15 slot paper manual set. This is a bound set of paper manuals in addition
to the CD-ROM already supplied with the equipment. Including all Eclipse interfaces and
panels.
5704
ECLIPSE SYSTEM MANUALS
5705
MAN-ECLIPSE-PICO
Eclipse-PiCo paper manual set
Eclipse-PiCo paper manual set:
Eclipse-PiCo paper manual set. This is a bound set of paper manuals in addition to the CDROM already supplied with the equipment. It includes all Eclipse interfaces and panels.
5706
MAN-ECLIPSE-MEDIAN
Eclipse-Median paper manual set
Eclipse-Median paper manual set:
Eclipse-Median 7 slot paper manual set. This is a bound set of paper manuals in addition to
the CD-ROM already supplied with the equipment. Including all Eclipse interfaces and
panels.
5707
MAN-ECLIPSE-OMEGA
Eclipse-Omega 15 slot paper manual set
Eclipse-Omega 15 slot paper manual set:
Eclipse-Omega 15 slot paper manual set. This is a bound set of paper manuals in addition to
the CD-ROM already supplied with the equipment. Including all Eclipse interfaces and
panels.
6000
6001
IP INTERCOM
ECLIPSE IP INTERFACE AND IP PANELS
1RU 4 Ch. IP communications interface
1RU 4 Ch. IP communications interface:
Four channel IP communications interface, 1RU, for extending intercom audio
communications to remote sites over IP networks (LAN, WAN, Internet). Supports: Up to 4
remote user panels intelligently linked backed to the Eclipse Digital Matrix; Up to 4 intelligent
trunk lines between remote matrix systems; Up to 4 four-wire Audio pairs and 4 Asynchronous
RS-422 data links. Rev. B.
$3,731.65
Concert 10 client perpetual access licenses
Concert 10 client perpetual access licenses:
Concert PC based Intercom system software for 10 clients. Includes Server software with
licenses for 10 Clients and 8 Server Channels. Requires a physical server. Each remote client
can integrate audio sources into the system via USB and external interface. Concert can
function as a stand-alone system or when integrated into the matrix with an IVC-32 card,
each client can function as a virtual matrix panel with access like a physical matrix panel.
Clients are supported on Windows 7, XP, MAC and ENPS (via Active X). Please contact your
Clear-Com representative to expand an existing installation.
$3,147.18
Concert 15 client perpetual access licenses
Concert 15 client perpetual access licenses:
Concert PC based Intercom system software for 15 clients. Includes Server software with
licenses for 15 Clients and 8 Server Channels. Requires a physical server. Each remote client
can integrate audio sources into the system via USB and external interface. Concert can
function as a stand-alone system or when integrated into the matrix with an IVC-32 card,
each client can function as a virtual matrix panel with access like a physical matrix panel.
Clients are supported on Windows 7, XP, MAC and ENPS (via Active X). Please contact your
Clear-Com representative to expand an existing installation.
$5,844.76
Concert 25 client perpetual access licenses
Concert 25 client perpetual access licenses:
Concert PC based Intercom system software for 25 clients. Includes Server software with
licenses for 25 Clients and 8 Server Channels. Requires a physical server. Each remote client
can integrate audio sources into the system via USB and external interface. Concert can
function as a stand-alone system or when integrated into the matrix with an IVC-32 card,
each client can function as a virtual matrix panel with access like a physical matrix panel.
Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).Please contact your
Clear-Com representative to expand an existing installation.
$10,790.33
6002
VOICE2
6004
CONCERT IP INTERCOM SYSTEM
6101
6102
6103
CL-10-P
CL-15-P
CL-25-P
ClearCom DIR
29 of 33
Part
Index
6104
6105
6106
6107
6108
6109
6110
6111
CL-50-P
CL-100-P
CL-10-A
CL-15-A
CL-25-A
CL-50-A
CL-100-A
CL-05-C
ClearCom DIR
Short Description
Description
DIR Price
Concert 50 client perpetual access licenses
Concert 50 client perpetual access licenses:
Concert PC based Intercom system software for 50 clients. Includes Server software with
licenses for 50 Clients and 8 Server Channels. Requires a physical server. Each remote client
can integrate audio sources into the system via USB and external interface. Concert can
function as a stand-alone system or when integrated into the matrix with an IVC-32 card,
each client can function as a virtual matrix panel with access like a physical matrix panel.
Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).Please contact your
Clear-Com representative to expand an existing installation.
$20,231.86
Concert 100 client perpetual access licenses
Concert 100 client perpetual access licenses:
Concert PC based Intercom system software for 100 clients. Includes Server software with
licenses for 100 Clients and 8 Server Channels. Requires a physical server. Each remote client
can integrate audio sources into the system via USB and external interface. Concert can
function as a stand-alone system or when integrated into the matrix with an IVC-32 card,
each client can function as a virtual matrix panel with access like a physical matrix panel.
Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).Please contact your
Clear-Com representative to expand an existing installation.
$31,471.78
Concert 10 client annual access licenses
Concert 10 client annual access licenses:
Concert PC based Intercom system software for 10 clients, annual subscription. Includes
Server software with licenses for 10 Clients and 8 Server Channels. Requires a physical server.
Each remote client can integrate audio sources into the system via USB and an external
interface. Concert can function as a stand-alone system or, when integrated into the matrix
with an IVC-32 card, each client can function as a virtual matrix panel with access like a
physical matrix panel. Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).
Please contact your Clear-Com representative to expand an existing installation.
The Annual Subscription Fee is valid for one year. Must be renewed at the end of the year.
$1,618.55
Concert 15 client annual access licenses
Concert 15 client annual access licenses:
Concert PC based Intercom system software for 15 clients, annual subscription. Includes
Server software with licenses for 15 Clients and 8 Server Channels. Requires a physical server.
Each remote client can integrate audio sources into the system via USB and an external
interface. Concert can function as a stand-alone system or, when integrated into the matrix
with an IVC-32 card, each client can function as a virtual matrix panel with access like a
physical matrix panel. Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).
Please contact your Clear-Com representative to expand an existing installation.
The Annual Subscription Fee is valid for one year. Must be renewed at the end of the year.
$2,967.34
Concert 25 client annual access licenses
Concert 25 client annual access licenses:
Concert PC based Intercom system software for 25 clients, annual subscription. Includes
Server software with licenses for 25 Clients and 8 Server Channels. Requires a physical server.
Each remote client can integrate audio sources into the system via USB and an external
interface. Concert can function as a stand-alone system or, when integrated into the matrix
with an IVC-32 card, each client can function as a virtual matrix panel with access like a
physical matrix panel. Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).
Please contact your Clear-Com representative to expand an existing installation.
The Annual Subscription Fee is valid for one year. Must be renewed at the end of the year.
$3,596.78
Concert 50 client annual access licenses
Concert 50 client annual access licenses:
Concert PC based Intercom system software for 50 clients, annual subscription. Includes
Server software with licenses for 50 Clients and 8 Server Channels. Requires a physical server.
Each remote client can integrate audio sources into the system via USB and an external
interface. Concert can function as a stand-alone system or, when integrated into the matrix
with an IVC-32 card, each client can function as a virtual matrix panel with access like a
physical matrix panel. Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).
Please contact your Clear-Com representative to expand an existing installation.
The Annual Subscription Fee is valid for one year. Must be renewed at the end of the year.
$10,250.81
Concert 100 client annual access licenses
Concert 100 client annual access licenses:
Concert PC based Intercom system software for 100 clients, annual subscription. Includes
Server software with licenses for 100 Clients and 8 Server Channels. Requires a physical
server. Each remote client can integrate audio sources into the system via USB and an
external interface. Concert can function as a stand-alone system or, when integrated into
the matrix with an IVC-32 card, each client can function as a virtual matrix panel with
access like a physical matrix panel. Clients are supported on Windows 7, XP, MAC and ENPS
(via Active X). Please contact your Clear-Com representative to expand an existing
installation.
The Annual Subscription Fee is valid for one year. Must be renewed at the end of the year.
$15,915.73
Concert 5 client cloud access licenses
Concert 5 client cloud access licenses:
Concert PC Intercom system software running on Clear-Com managed Cloud Server.
Customer MUST have Internet Access.
Up to 5 client annual subscription access licenses. Each remote client can integrate audio
sources into the system via USB and external interface. Function as a stand-alone system.
Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).
The Annual Cloud Subscription Fee is valid for one year. Must be renewed at the end of the
year.
$1,942.26
30 of 33
Part
Index
6112
6113
6114
6115
CL-10-C
CL-15-C
CL-25-C
CL-50-C
Short Description
Description
DIR Price
Concert 10 client cloud access licenses
Concert 10 client cloud access licenses:
Concert PC Intercom system software running on Clear-Com managed Cloud Server.
Customer MUST have Internet Access.
Up to 10 client annual subscription access licenses. Each remote client can integrate audio
sources into the system via USB and external interface. Function as a stand-alone system.
Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).
The Annual Cloud Subscription Fee is valid for one year. Must be renewed at the end of the
year.
$3,452.90
Concert 15 client cloud access licenses
Concert 15 client cloud access licenses:
Concert PC Intercom system software running on Clear-Com managed Cloud Server.
Customer MUST have Internet Access.
Up to 15 client annual subscription access licenses. Each remote client can integrate audio
sources into the system via USB and external interface. Function as a stand-alone system.
Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).
The Annual Cloud Subscription Fee is valid for one year. Must be renewed at the end of the
year.
$4,585.89
Concert 25 client cloud access licenses
Concert 25 client cloud access licenses:
Concert PC Intercom system software running on Clear-Com managed Cloud Server.
Customer MUST have Internet Access.
Up to 25 client annual subscription access licenses. Each remote client can integrate audio
sources into the system via USB and external interface. Function as a stand-alone system.
Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).
The Annual Cloud Subscription Fee is valid for one year. Must be renewed at the end of the
year.
$6,851.86
Concert 50 client cloud access licenses
Concert 50 client cloud access licenses:
Concert PC Intercom system software running on Clear-Com managed Cloud Server.
Customer MUST have Internet Access.
Up to 50 client annual subscription access licenses. Each remote client can integrate audio
sources into the system via USB and external interface. Function as a stand-alone system.
Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).
The Annual Cloud Subscription Fee is valid for one year. Must be renewed at the end of the
year.
$11,221.94
$17,911.94
6116
CL-100-C
Concert 100 client cloud access licenses
Concert 100 client cloud access licenses:
Concert PC Intercom system software running on Clear-Com managed Cloud Server.
Customer MUST have Internet Access.
Up to 100 client annual subscription access licenses. Each remote client can integrate audio
sources into the system via USB and external interface. Function as a stand-alone system.
Clients are supported on Windows 7, XP, MAC and ENPS (via Active X).
The Annual Cloud Subscription Fee is valid for one year. Must be renewed at the end of the
year.
6119
CH-04-P
Concert 4 server channel perpetual licenses
Concert 4 server channel perpetual licenses:
Additional perpetual server channel licenses. Up to 4 additional perpetual server channel
access licenses for audio connection at the server.
$719.36
6120
CH-08-P
Concert 8 server channel perpetual licenses
Concert 8 server channel perpetual licenses:
Additional perpetual server channel licenses. Up to 8 additional perpetual server channel
access licenses for audio connection at the server.
$1,079.03
6121
CH-16-P
Concert 16 server channel perpetual licenses
Concert 16 server channel perpetual licenses:
Additional perpetual server channel licenses. Up to 16 additional perpetual server channel
access licenses for audio connection at the server.
$1,726.45
6122
CH-32-P
Concert 32 server channel perpetual licenses
Concert 32 server channel perpetual licenses:
Additional perpetual server channel licenses. Up to 32 additional perpetual server channel
access licenses for audio connection at the server.
$2,877.42
6123
CH-64-P
Concert 64 server channel perpetual licenses
Concert 64 server channel perpetual licenses:
Additional perpetual server channel licenses. Up to 64 additional perpetual server channel
access licenses for audio connection at the server.
$4,603.87
6124
CH-04-A
Concert 4 server channel annual licenses
Concert 4 server channel annual licenses:
Additional annual server channel licenses. Up to 4 additional annual subscription server
channel access licenses for audio connection at the server. The annual channel subscription
license is valid for one year. Must be renewed at the end of the year.
$404.64
6125
CH-08-A
Concert 8 server channel annual licenses
Concert 8 server channel annual licenses:
Additional annual server channel licenses. Up to 8 additional annual subscription server
channel access licenses for audio connection at the server. The annual channel subscription
license is valid for one year. Must be renewed at the end of the year.
$548.51
6126
CH-16-A
Concert 16 server channel annual licenses
Concert 16 server channel annual licenses:
Additional annual server channel licenses. Up to 16 additional annual subscription server
channel access licenses for audio connection at the server. The annual channel subscription
license is valid for one year. Must be renewed at the end of the year.
$863.23
ClearCom DIR
31 of 33
Part
Index
Short Description
Description
DIR Price
6127
CH-32-A
Concert 32 server channel annual licenses
Concert 32 server channel annual licenses:
Additional annual server channel licenses. Up to 32 additional annual subscription server
channel access licenses for audio connection at the server. The annual channel subscription
license is valid for one year. Must be renewed at the end of the year.
$1,483.67
6128
CH-64-A
Concert 64 server channel annual licenses
Concert 64 server channel annual licenses:
Additional annual server channel licenses. Up to 64 additional annual subscription server
channel access licenses for audio connection at the server. The annual channel subscription
license is valid for one year. Must be renewed at the end of the year.
$2,337.90
6140
Concert-Server
Pre-Loaded Concert Server Assembly
Pre-Loaded Concert Server Assembly:
Server Hardware pre-loaded with Concert Server software.
$2,108.61
6141
Concert-Server-4W
Pre-Loaded 4/W Concert Server Assembly
Pre-Loaded 4/W Concert Server Assembly:
Server Hardware equipped with 8 duplex 4-Wire audio ports and pre-loaded with Concert
Server software. Includes breakout to 16 XLRs (8 Inputs and 8 Outputs). Utilizes an ASI5640
sound card.
$3,871.03
6142
CONCERT-RJ45-CBL-DONGLE
RJ45 Adaptor Cable for Concert Server
RJ45 Adaptor Cable for Concert Server :
RJ45 adaptor cable for Concert servers which fitted with an Audio Science ASI5640 sound
card. Supports up to 8 bi-directional voice channels to Eclipse matrix systems.
$404.64
9000
FACTORY CONFIGURATION AND SERVICES -No Discounts apply
9001
SVC-FAT
Factory acceptance daily charge
Factory acceptance daily charge:
Daily charge for factory based acceptance testing and evaluation reports (Net price). Price
includes system set-up and configuration to customer's requirements. Allow one day plus an
extra day for every 64 matrix ports. Please see SVC-FTRN-xx to add any agreed training days.
$1,284.56
9002
SVC-COMM-US
Daily commissioning & service charge (from US)
Daily commissioning & service charge (from US):
Daily charge for commissioning or on-site training serviced from the US office (Net price).
Price includes round trip air flight, reasonable travel and daily expenses. Note: A two-day
minimum and travel surcharge may apply for commissioning in Central and South America.
Please see SVC-COMM-SURCH.
$1,813.50
9003
SVC-COMM-GOV
Commissioning & service charge (MAG)
Commissioning & service charge (MAG):
Charge for commissioning and/or on-site training serviced from the US office on Continental
US only, (Net price). Price includes three (3) days onsite and two (2) days travel and normal
daily expenses. US Government, Military, and MAG Contractors only.
$6,347.25
9004
SVC-COMM-SURCH
Travel Surcharge
Travel Surcharge:
For site visits to countries in Central and South America (not including Mexico), a travel
surcharge applies for any trip in excess of 16 hours round-trip, as calculated on travel
originating from and returning to SFO.
$2,015.00
9005
SVC-COMM-UK
Daily commissioning & service charge (from UK)
Daily commissioning & service charge (from UK):
Daily charge for commissioning or on-site training serviced from the UK office (Net price).
Price includes round trip air flight, reasonable travel and daily expenses. Note: An additional
1-day commissioning charge will be added for travel to and from the commissioning site in
excess of 8 hours each way, based on departure from LHR.
$2,271.91
9006
SVC-COMM-APAC
Daily commissioning & service charge (from Asia)
Daily commissioning & service charge (from Asia):
Daily charge for commissioning or on-site training serviced from the Singapore office (Net
price). Price includes round trip air flight, reasonable travel and daily expenses. Note: An
additional 1-day commissioning charge will be added for travel to and from the
commissioning site in excess of 8 hours each way, based on departure from Changi Airport.
$1,773.20
9007
SVC-FTRN-US
Daily Factory Training charge (in US)
Daily Factory Training charge (in US):
Daily charge for training in the US at the Clear-Com Office (Net price). Price includes set-up
charges and materials for up to 10 students.
$1,249.30
9008
SVC-FTRN-UK
Daily Factory Training charge (in UK)
Daily Factory Training charge (in UK):
Daily charge for training in the UK at the Clear-Com Office (Net price). Price includes set-up
charges and materials for up to 10 students.
$1,249.30
9009
SVC-HOUR-AE
Hourly charge for AE on-site work
Hourly charge for AE on-site work:
Hourly charge for any on-site work such as commissioning or training by an Application
Engineer (Net price).
NOTE: Travel not included. Additional fees may apply.
$236.76
9010
SVC-HOUR-REPAIR
Hourly charge for repair work
Hourly charge for repair work:
Hourly charge for bench repair work (Net price). Repair work performed at Clear-Com’s
Alameda facility.
$100.75
ClearCom DIR
32 of 33
Part
Index
9010
Short Description
Description
DIR Price
$901.71
MISC. SERVICES - No Discounts apply
9011
SVC-REM6-AE
Remote Configuration Charge
Remote Configuration Charge:
Three two-hour sessions of remote PC-based assistance by an Applications Engineer. Can be
used for commissioning assistance, training, or other services for currently supported
products offered through Applications Engineering. Requires advance scheduling.
Valid for up to one year after purchase. On-site remote access equipment and Internet
access required (not included). (Net Price).
9012
CERTORIG
Stamped Certificate of Origin
Stamped Certificate of Origin:
To supply a certificate of manufactured origin stamped COC from Chamber of Commerce.
$206.54
9013
CERTORIG-CC
Certificate of Origin from Clear-Com only
Certificate of Origin from Clear-Com only:
To supply a certificate of manufactured origin. Not stamped by the US Chamber of
Commerce.
$105.79
9014
SVC-XWARR
Warranty Extension
Warranty Extension:
One or Two-year extension of the product’s warranty, including free parts and labor
(shipping not included), continuous phone and e-mail tech support and software updates
while under warranty. Available on new and customer-owned products (limitations apply).
0.75
9015
SVC-AWR
Advance Replacement Extension
Advance Replacement Extension:
21-month extension of the product’s Advance Replacement Warranty. Report a failure, get
a replacement (shipping not included and limitations apply), continuous phone and e-mail
tech support, and software updates while under warranty.
0.75
ClearCom DIR
33 of 33
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
