HP Deskjet 1510 series
Table of contents
1 HP Deskjet 1510 series Help ............................................................................................................................ 1
2 Get to know the HP Deskjet 1510 series .......................................................................................................... 3
Printer parts .......................................................................................................................................... 4
Control panel features .......................................................................................................................... 5
Status light ............................................................................................................................................ 6
Auto-Off ................................................................................................................................................ 9
3 Print ................................................................................................................................................................. 11
Print documents ................................................................................................................................. 12
Print photos ........................................................................................................................................ 14
Print envelopes ................................................................................................................................... 15
Print using the maximum dpi .............................................................................................................. 16
Tips for print success ......................................................................................................................... 17
4 Paper basics ................................................................................................................................................... 19
Recommended papers for printing ..................................................................................................... 20
Load media ......................................................................................................................................... 22
5 Copy and scan ................................................................................................................................................ 27
Copy documents ................................................................................................................................ 28
Scan to a computer ............................................................................................................................ 30
Tips for copy success ......................................................................................................................... 32
Tips for scan success ......................................................................................................................... 33
6 Work with ink cartridges .................................................................................................................................. 35
Check estimated ink levels ................................................................................................................. 36
Order ink supplies .............................................................................................................................. 37
Choose right ink cartridges ................................................................................................................. 38
Replace ink cartridges ........................................................................................................................ 39
Use single-cartridge mode ................................................................................................................. 41
ENWW
iii
Cartridge warranty information ........................................................................................................... 42
Tips for working with ink cartridges .................................................................................................... 43
7 Connectivity .................................................................................................................................................... 45
Connect a new printer ........................................................................................................................ 46
USB connection .................................................................................................................................. 47
8 Solve a problem .............................................................................................................................................. 49
Improve print quality ........................................................................................................................... 50
Clear paper jam .................................................................................................................................. 54
Unable to print .................................................................................................................................... 57
Clear print carriage ............................................................................................................................. 60
Identify a defective cartridge .............................................................................................................. 61
Prepare trays ...................................................................................................................................... 62
Resolve copy and scan issues ........................................................................................................... 63
Printer failure ...................................................................................................................................... 64
Ink cartridge problem .......................................................................................................................... 65
Older generation cartridges ................................................................................................................ 67
HP support ......................................................................................................................................... 68
Appendix A Technical information ..................................................................................................................... 71
Hewlett-Packard Company notices .................................................................................................... 72
Specifications ..................................................................................................................................... 73
Environmental product stewardship program ..................................................................................... 76
Regulatory notices .............................................................................................................................. 80
Index ................................................................................................................................................................... 85
iv
ENWW
1
HP Deskjet 1510 series Help
Learn how to use your HP Deskjet 1510 series
ENWW
●
Printer parts on page 4
●
Control panel features on page 5
●
Load media on page 22
●
Copy documents on page 28
●
Scan to a computer on page 30
●
Replace ink cartridges on page 39
●
Clear paper jam on page 54
1
2
Chapter 1 HP Deskjet 1510 series Help
ENWW
2
ENWW
Get to know the HP Deskjet 1510 series
●
Printer parts
●
Control panel features
●
Status light
●
Auto-Off
3
Printer parts
●
●
4
Front view
1
Input tray
2
Input tray guard
3
Ink cartridges
4
Lid
5
Lid-backing
6
Paper-width guide for the input tray
7
Control panel
8
Cartridge access door
9
Output tray
10
Output tray extender (also referred to as the tray extender)
11
Scanner glass
Rear view
12
USB port
13
Power connection
Chapter 2 Get to know the HP Deskjet 1510 series
ENWW
Control panel features
Figure 2-1 Control panel features
ENWW
Feature
Description
1
On button: Turns the printer on or off.
2
Cancel button: Stops the current operation.
3
Start Copy Black button: Starts a black-and-white copy job. Acts as a resume button after
resolving print problems.
4
Start Copy Color button: Starts a color copy job. Acts as a resume button after resolving print
problems.
5
Attention light: Indicates that there is a paper jam, the printer is out of paper, or some event
that requires your attention.
6
Cartridge lights: Indicates low ink or an ink cartridge problem.
Control panel features
5
Status light
●
When the printer is turned on, the On button light is lit.
●
When the printer is turned off, the On button light is off.
●
When the printer is in Sleep mode, the On button light is dimmed. The printer automatically
enters Sleep mode after 5 minutes of inactivity.
●
When the printer is processing a job, the On button light is blinking.
Additional blinking lights signal errors that you can resolve. See below to learn about light behavior
and what to do.
Light behavior
Cause and Solution
The Attention light is blinking.
The output tray is closed when printing is attempted, there is
no paper, there is a paper jam, or the scanner is not working.
●
If the output tray is closed, open it.
●
If there is no paper, load paper, and then press any
button, except the Cancel button, to resume printing.
●
If one of ink cartridges is missing, the printer enters to
the single-cartridge mode automatically. To exit the
single-cartridge mode, insert the corresponding ink
cartridge. For more information, see Use singlecartridge mode on page 41.
●
If there is a paper jam, clear the paper jam, and then
press any button, except the Cancel button, to resume
printing. For more information, see Clear paper jam
on page 54.
If the problem persists, contact HP. The printer can still print
even if the scanner is not working.
Both Cartridge lights and the Attention light are blinking.
6
Chapter 2 Get to know the HP Deskjet 1510 series
The cartridge access door is open, or the carriage inside the
printer is stalled.
●
If the cartridge access door is open, close it. See
Prepare trays on page 62 for more information.
●
If the carriage is stalled, open the cartridge access door,
move the carriage to the right to clear the obstruction,
and then close the cartridge access door. Press any
button, except the Cancel button, to resume printing.
See Clear print carriage on page 60 for more
information.
ENWW
Light behavior
Cause and Solution
One Cartridge light is on (not blinking).
An “on” Cartridge light indicates that the corresponding ink
cartridge still has the tape on, is low on ink, is missing, or is
counterfeit.
Both Cartridge lights are on (not blinking).
●
If the pink tape is still on the ink cartridge, remove it.
●
If the ink cartridge is low on ink, replace the ink
cartridge when print quality is no longer acceptable. For
more information, see Replace ink cartridges
on page 39.
●
If one of ink cartridges is missing, the printer enters to
the single-cartridge mode automatically. To exit the
single-cartridge mode, insert the corresponding ink
cartridge. For more information, see Use singlecartridge mode on page 41.
●
If the ink cartridge is counterfeit, replace the
corresponding ink cartridge with an original HP ink
cartridge, or press any button, except the Cancel
button, to resume printing.
Both ink cartridges are low on ink.
●
One Cartridge light is blinking.
ENWW
Replace both ink cartridges when print quality is no
longer acceptable. For more information, see Replace
ink cartridges on page 39.
A “blinking” Cartridge light indicates that the corresponding
ink cartridge is not installed correctly, is incompatible, or is
very low on ink.
●
If the ink cartridge is not installed correctly, reinsert the
ink cartridge.
●
If the ink cartridge is incompatible, replace it with a
compatible ink cartridge.
●
If the ink cartridge is very low on ink, press any button,
except the Cancel button, to resume printing, and
replace the corresponding ink cartridge when print
quality is no longer acceptable.
Status light
7
Light behavior
Cause and Solution
Both Cartridge lights are blinking.
Both ink cartridges may still have the tape on, are missing,
are defective, or are very low on ink.
The On button light, both Cartridge lights, and the Attention
light are blinking.
●
If the pink tape is still on the ink cartridges, remove it.
●
If the ink cartridges are missing, install the missing ink
cartridges.
●
If the ink cartridges are defective, replace the ink
cartridges. See Identify a defective cartridge
on page 61 to identify if only one ink cartridge is a
defective.
●
If the ink cartridges are very low on ink, press any
button, except the Cancel button, to resume printing,
and replace both ink cartridges when print quality is no
longer acceptable. For more information, see Replace
ink cartridges on page 39.
The printer is in an error state. To exit the error state, reset
the printer.
1.
Turn off the printer.
2.
Unplug the power cord.
3.
Wait a minute, and then plug the power cord back in.
4.
Turn on the printer.
If the problem persists, contact HP.
8
Chapter 2 Get to know the HP Deskjet 1510 series
ENWW
Auto-Off
Auto-Off is automatically enabled by default when you turn on the printer. When Auto-Off is enabled,
the printer will automatically turn off after 2 hours of inactivity to help reduce energy use. Auto-Off
turns the printer off completely, so you must use the On button to turn the printer back on. For printer
models with wireless or Ethernet network capability, Auto-Off is automatically disabled when the
printer establishes a wireless or Ethernet network connection. Even when Auto-Off is disabled, the
printer enters Sleep mode after 5 minutes of inactivity to help reduce energy use.
To change the Auto-Off setting from the printer software
1.
Depending on your operating system, do one of the following to open the printer software:
●
Windows 8: On the Start screen, right-click an empty area on the screen, click All Apps on
the app bar, and then click the icon with the printer's name.
●
Windows 7, Windows Vista, and Windows XP: From the computer desktop, click Start,
select All Programs, click HP, click HP Deskjet 1510 series, and then click HP Deskjet 1510
series.
2.
In the printer software, select Print & Scan, and then click Maintain Your Printer to access the
printer toolbox.
3.
The printer toolbox appears.
4.
Click Advanced Settings, and then follow the on-screen instructions.
Once you change the setting, the printer maintains the setting that you choose.
ENWW
Auto-Off
9
10
Chapter 2 Get to know the HP Deskjet 1510 series
ENWW
3
Print
This section contains the following topics:
ENWW
●
Print documents
●
Print photos
●
Print envelopes
●
Print using the maximum dpi
●
Tips for print success
11
Print documents
Load paper
1.
Make sure the output tray is open.
2.
Make sure you have paper loaded in the input tray.
To print a document
1.
From your software, click the Print button.
2.
Make sure your printer is selected.
3.
Click the button that opens the Properties dialog box.
Depending on your software application, this button might be called Properties, Options, Printer
Setup, Printer Properties, Printer, or Preferences.
4.
Select the appropriate options.
●
On the Layout tab, select Portrait or Landscape orientation.
●
On the Paper/Quality tab, select the appropriate paper type and print quality from the Media
drop-down list.
●
Click Advanced to select the appropriate paper size from the Paper Size drop-down list.
5.
Click OK to close the Properties dialog box.
6.
Click Print or OK to begin printing.
To print on both sides of the page
1.
From your software, click the Print button.
2.
Make sure your printer is selected.
3.
Click the button that opens the Properties dialog box.
Depending on your software application, this button might be called Properties, Options, Printer
Setup, Printer Properties, Printer, or Preferences.
4.
12
Select the appropriate options.
Chapter 3 Print
ENWW
ENWW
●
On the Layout tab, select Portrait or Landscape orientation.
●
On the Paper/Quality tab, select the appropriate paper type and print quality from the Media
drop-down list.
●
Click Advanced to select the appropriate paper size from the Paper Size drop-down list.
5.
On the Layout tab, select an appropriate option from the Print on Both Sides Manually dropdown list.
6.
Click OK to print.
7.
After the even numbered pages of the document have been printed, remove the document from
the output tray.
8.
Follow the on-screen instructions, reload the paper in the input tray with the blank side up and
top of page down, and then click Continue.
Print documents
13
Print photos
Load photo paper
1.
Make sure the output tray is open.
2.
Remove all paper from the input tray, and then load the photo paper with side to be printed on
facing up.
To print a photo on photo paper
1.
On the File menu in your software, click Print.
2.
Make sure your printer is selected.
3.
Click the button that opens the Properties dialog box.
Depending on your software application, this button might be called Properties, Options, Printer
Setup, Printer Properties, Printer, or Preferences.
4.
Select the appropriate options.
●
On the Layout tab, select Portrait or Landscape orientation.
●
On the Paper/Quality tab, select the appropriate paper type and print quality from the Media
drop-down list.
●
Click Advanced to select the appropriate paper size from the Paper Size drop-down list.
NOTE: For maximum dpi resolution, go to the Paper/Quality tab and select Photo Paper, Best
Quality from the Media drop-down list. Then go to the Advanced tab and select Yes from the
Print in Max DPI drop-down list. If you want to print Max DPI in grayscale, select High Quality
Grayscale from the Print in Grayscale drop-down list.
5.
Click OK to return to the Properties dialog box.
6.
Click OK, and then click Print or OK in the Print dialog box.
NOTE: After the printing is finished, remove unused photo paper from the input tray. Store the photo
paper so it does not start to curl, which could reduce the quality of your printout.
14
Chapter 3 Print
ENWW
Print envelopes
You can load one or more envelopes into the input tray of the HP Deskjet 1510 series. Do not use
shiny or embossed envelopes or envelopes that have clasps or windows.
NOTE: For details on how to format text on envelopes, see the help files in your word processing
software.
Load envelopes
1.
Make sure the output tray is open.
2.
Slide the paper-width guide all the way to the left.
3.
Place the envelopes in the right side of the input tray. The side to be printed on should face up.
4.
Push the envelopes into the printer until they stop.
5.
Slide the paper-width guide firmly against the edge of the envelopes.
To print an envelope
1.
On the File menu in your software, click Print.
2.
Make sure your printer is selected.
3.
Click the button that opens the Properties dialog box.
Depending on your software application, this button might be called Properties, Options, Printer
Setup, Printer Properties, Printer, or Preferences.
4.
5.
ENWW
Select the appropriate options.
●
On the Layout tab, select Portrait or Landscape orientation.
●
On the Paper/Quality tab, select the appropriate paper type and print quality from the Media
drop-down list.
●
Click Advanced to select the appropriate paper size from the Paper Size drop-down list.
Click OK, and then click Print or OK in the Print dialog box.
Print envelopes
15
Print using the maximum dpi
Use maximum dots per inch (dpi) to print high-quality, sharp images on photo paper.
Printing in maximum dpi takes longer than printing with other settings and requires a large amount of
memory.
To print in Maximum dpi mode
1.
On the File menu in your software, click Print.
2.
Make sure your printer is selected.
3.
Click the button that opens the Properties dialog box.
Depending on your software application, this button might be called Properties, Options, Printer
Setup, Printer Properties, Printer, or Preferences.
4.
Click the Paper/Quality tab.
5.
From the Media drop-down list, must select Photo Paper, Best Quality to enable printing in
maximum dpi.
6.
Click the Advanced button.
7.
In the Printer Features area, select Yes from the Print in Max DPI drop-down list.
8.
Select the appropriate paper size from the Paper Size drop-down list.
9.
Click OK to close the advanced options.
10. Confirm Orientation on the Layout tab, and then click OK to print.
16
Chapter 3 Print
ENWW
Tips for print success
To print successfully, the HP ink cartridges should be functioning properly with sufficient ink, the
paper should be loaded correctly, and the product should have the appropriate settings. Print settings
do not apply to copying or scanning.
Ink tips
●
Use original HP ink cartridges.
●
Install both the black and tri-color cartridges correctly.
For more information, see Replace ink cartridges on page 39.
●
Check the estimated ink levels in the ink cartridges to make sure there is sufficient ink.
For more information, see Check estimated ink levels on page 36.
●
If the print quality is not acceptable, see Improve print quality on page 50 for more information.
Paper loading tips
●
Load a stack of paper (not just one page). All of the paper in the stack should be the same size
and type to avoid a paper jam.
●
Load paper with side to be printed on facing up.
●
Ensure that paper loaded in the input tray lays flat and the edges are not bent or torn.
●
Adjust the paper-width guide in the input tray to fit snugly against all paper. Make sure the
paper-width guide does not bend the paper in the input tray.
For more information, see Load media on page 22.
Printer settings tips
●
On the Paper/Quality tab, select the appropriate paper type and print quality from the Media
drop-down list.
●
Select the appropriate paper size from the Paper Size drop-down list in the Advanced Options
dialog box. Access the Advanced Options dialog box by clicking the Advanced button on the
Layout or Paper/Quality tab.
●
To change default print settings, click Print & Scan, and then click Set Preferences in the printer
software.
Depending on your operating system, do one of the following to open the printer software:
●
ENWW
◦
Windows 8: On the Start screen, right-click an empty area on the screen, click All Apps on
the app bar, and then click the icon with the printer's name.
◦
Windows 7, Windows Vista, and Windows XP: From the computer desktop, click Start,
select All Programs, click HP, click HP Deskjet 1510 series, and then click HP Deskjet 1510
series.
If you want to print a black and white document using black ink only, click the Advanced button.
From the Print in Grayscale drop-down menu, select Black Ink Only, then click the OK button.
Tips for print success
17
Notes
●
Original HP ink cartridges are designed and tested with HP printers and papers to help you
easily produce great results, time after time.
NOTE: HP cannot guarantee the quality or reliability of non-HP supplies. Product service or
repairs required as a result of using a non-HP supply will not be covered under warranty.
If you believe you purchased original HP ink cartridges, go to:
www.hp.com/go/anticounterfeit
●
Ink level warnings and indicators provide estimates for planning purposes only.
NOTE: When you receive a low-ink warning message, consider having a replacement ink
cartridge available to avoid possible printing delays. You do not need to replace the ink
cartridges until print quality becomes unacceptable.
18
●
Software settings selected in the print driver only apply to printing, they do not apply to copying
or scanning.
●
You can print your document on both sides of the paper.
Chapter 3 Print
ENWW
4
Paper basics
You can load many different types and sizes of paper in the HP Printer, including letter or A4 paper,
photo paper, and envelopes.
This section contains the following topics:
ENWW
●
Recommended papers for printing
●
Load media
19
Recommended papers for printing
If you want the best print quality, HP recommends using HP papers that are specifically designed for
the type of project you are printing.
Depending on your country/region, some of these papers might not be available.
ColorLok
●
HP recommends plain papers with the ColorLok logo for printing and copying of everyday
documents. All papers with the ColorLok logo are independently tested to meet high standards
of reliability and print quality, and produce documents with crisp, vivid color, bolder blacks, and
dry faster than ordinary plain papers. Look for papers with the ColorLok logo in a variety of
weights and sizes from major paper manufacturers.
Photo printing
●
HP Premium Plus Photo Paper
HP Premium Plus Photo Paper is HP’s highest-quality photo paper for your best photos. With
HP Premium Plus Photo Paper, you can print beautiful photos that are instant-dry so you can
share them right off the printer. It is available in several sizes, including A4, 8.5 x 11 inch, 4 x 6
inch (10 x 15 cm), 5 x 7 inch (13 x 18 cm), and 11 x 17 inch (A3), and in two finishes - glossy or
soft gloss (semi-gloss). Ideal for framing, displaying, or gifting your best photos and special
photo projects. HP Premium Plus Photo Paper delivers exceptional results with professional
quality and durability.
●
HP Advanced Photo Paper
This thick photo paper features an instant-dry finish for easy handling without smudging. It
resists water, smears, fingerprints, and humidity. Your prints have a look and feel comparable to
a store-processed photo. It is available in several sizes, including A4, 8.5 x 11 inch, 10 x 15 cm
(4 x 6 inch), 13 x 18 cm (5 x 7 inch). It is acid-free for longer lasting documents.
●
HP Everyday Photo Paper
Print colorful, everyday snapshots at a low cost, using paper designed for casual photo printing.
This affordable photo paper dries quickly for easy handling. Get sharp, crisp images when you
use this paper with any inkjet printer. It is available in glossy finish in several sizes, including A4,
8.5 x 11 inch, and 10 x 15 cm (4 x 6 inch). For longer-lasting photos, it is acid-free.
Business documents
●
HP Premium Presentation Paper or HP Professional Paper 120
These papers are heavy two-sided matte papers perfect for presentation, proposals, reports,
and newsletters. They are heavyweight for an impressive look and feel.
●
20
HP Brochure Paper or HP Professional Paper 180
Chapter 4 Paper basics
ENWW
These papers are glossy-coated or matte-coated on both sides for two-sided use. They are the
perfect choice for near-photographic reproductions and business graphics for report covers,
special presentations, brochures, mailers, and calendars.
Everyday printing
●
HP Bright White Inkjet Paper
HP Bright White Inkjet Paper delivers high-contrast colors and sharp text. It is opaque enough
for two-sided color usage with no show-through, which makes it ideal for newsletters, reports,
and flyers. It features ColorLok Technology for less smearing, bolder blacks, and vivid colors.
●
HP Printing Paper
HP Printing Paper is a high-quality multifunction paper. It produces documents that look and feel
more substantial than documents printed on standard multipurpose or copy paper. It features
ColorLok Technology for less smearing, bolder blacks, and vivid colors. It is acid-free for longer
lasting documents.
●
HP Office Paper
HP Office Paper is a high-quality multifunction paper. It is suitable for copies, drafts, memos, and
other everyday documents. It features ColorLok Technology for less smearing, bolder blacks,
and vivid colors. It is acid-free for longer lasting documents.
●
HP Office Recycled Paper
HP Office Recycled Paper is a high-quality multifunction paper made with 30% recycled fiber. It
features ColorLok Technology for less smearing, bolder blacks and vivid colors.
Special projects
●
HP Iron-On Transfers
HP Iron-on Transfers (for light or white fabrics) are the ideal solution for creating custom T-shirts
from your digital photos.
ENWW
Recommended papers for printing
21
Load media
Select a paper size to continue.
Load full-size paper
22
1.
Raise the input tray.
2.
Lower the output tray and pull out the output tray extender.
3.
Slide the paper-width guide to the left.
4.
Insert a stack of paper into the input tray with the short edge down and the print side up, and
slide the stack of paper down until it stops.
Chapter 4 Paper basics
ENWW
5.
Slide the paper-width guide to the right until it stops at the edge of paper.
Load small-size paper
ENWW
1.
Raise the input tray.
2.
Lower the output tray and pull out the output tray extender.
3.
Slide the paper-width guide to the left.
Load media
23
4.
Insert a stack of photo paper with the short edge down and the print side up, and slide the stack
of paper forward until it stops.
5.
Slide the paper-width guide to the right until it stops at the edge of paper.
Load envelopes
24
1.
Raise the input tray.
2.
Lower the output tray and pull out the output tray extender.
3.
Slide the paper-width guide to the left and remove all paper from the input tray.
Chapter 4 Paper basics
ENWW
4.
Insert one or more envelopes into far-right side of the input tray and slide the stack of envelopes
down until it stops.
The side to be printed on should face up. The flap should be on the left side and facing down.
5.
ENWW
Slide the paper-width guide to the right against the stack of envelopes until it stops.
Load media
25
26
Chapter 4 Paper basics
ENWW
5
ENWW
Copy and scan
●
Copy documents
●
Scan to a computer
●
Tips for copy success
●
Tips for scan success
27
Copy documents
NOTE: All documents are copied in normal quality print mode. You cannot change the print mode
quality when copying.
1-sided original to 1-sided copy
28
1.
Load paper in the input tray.
2.
Load the original.
a.
Lift the lid of the printer.
b.
Load the original print side down on the right front corner of the scanner glass.
Chapter 5 Copy and scan
ENWW
c.
3.
Close the lid.
Press either Start Copy Black or Start Copy Color to start the copy.
You can increase the number of copies (up to 9) by pressing the button multiple times.
ENWW
Copy documents
29
Scan to a computer
To scan to a computer, the HP Deskjet 1510 series and computer must be connected and turned on.
Single page scan
1.
2.
Load the original.
a.
Lift the lid of the printer.
b.
Load the original print side down on the right front corner of the scanner glass.
c.
Close the lid.
Start the scan.
a.
30
Start the scan job using the printer software. Depending on your operating system, do one
of the following to open the printer software:
Chapter 5 Copy and scan
ENWW
b.
ENWW
●
Windows 8: On the Start screen, right-click an empty area on the screen, click All Apps
on the app bar, and then click the icon with the printer's name.
●
Windows 7, Windows Vista, and Windows XP: From the computer desktop, click Start,
select All Programs, click HP, click HP Deskjet 1510 series, and then click HP Deskjet
1510 series.
In the printer software, select the Print & Scan tab, and then select Scan a Document or
Photo under Scan. You will see scan options that you can select on the computer screen.
Scan to a computer
31
Tips for copy success
●
Load your original print side down on the right front corner of the scanner glass.
●
To resize the copy, scan the original to the computer, resize it using an application on the
computer, and then print the resized document.
●
Clean the scanner glass and make sure that there are no foreign materials adhering to it.
Click here to go online for more information.
32
Chapter 5 Copy and scan
ENWW
Tips for scan success
●
Load your original print side down on the right front corner of the scanner glass.
●
Clean the scanner glass and make sure that there are no foreign materials adhering to it.
Click here to go online for more information.
ENWW
Tips for scan success
33
34
Chapter 5 Copy and scan
ENWW
6
Work with ink cartridges
This section contains the following topics:
ENWW
●
Check estimated ink levels
●
Order ink supplies
●
Choose right ink cartridges
●
Replace ink cartridges
●
Use single-cartridge mode
●
Cartridge warranty information
●
Tips for working with ink cartridges
35
Check estimated ink levels
You can easily check the ink supply level to determine how soon you might need to replace an ink
cartridge. The ink supply level shows an estimate of the amount of ink remaining in the ink cartridges.
To check the ink levels
1.
2.
Depending on your operating system, do one of the following to open the printer software:
●
Windows 8: On the Start screen, right-click an empty area on the screen, click All Apps on
the app bar, and then click the icon with the printer's name.
●
Windows 7, Windows Vista, and Windows XP: From the computer desktop, click Start,
select All Programs, click HP, click HP Deskjet 1510 series, and then click HP Deskjet 1510
series.
In the printer software, click Estimated Ink Levels.
NOTE: If you have installed a refilled or remanufactured ink cartridge, or an ink cartridge that has
been used in another printer, the ink level indicator might be inaccurate or unavailable.
NOTE: Ink level warnings and indicators provide estimates for planning purposes only. When you
receive a low-ink warning message, consider having a replacement ink cartridge available to avoid
possible printing delays. You do not have to replace the ink cartridges until the print quality is
unacceptable.
NOTE: Ink from the ink cartridges is used in the printing process in a number of different ways,
including in the initialization process, which prepares the printer and cartridges for printing, and in
printhead servicing, which keeps print nozzles clear and ink flowing smoothly. In addition, some
residual ink is left in the ink cartridge after it is used. For more information, see www.hp.com/go/
inkusage.
36
Chapter 6 Work with ink cartridges
ENWW
Order ink supplies
Before ordering cartridges, locate the correct cartridge number.
Locate the cartridge number on the printer
●
The cartridge number is located inside the cartridge access door.
Locate the cartridge number in the printer software
1.
2.
Depending on your operating system, do one of the following to open the printer software:
●
Windows 8: On the Start screen, right-click an empty area on the screen, click All Apps on
the app bar, and then click the icon with the printer's name.
●
Windows 7, Windows Vista, and Windows XP: From the computer desktop, click Start,
select All Programs, click HP, click HP Deskjet 1510 series, and then click HP Deskjet 1510
series.
In the printer software, click Shop, and then click Shop For Supplies Online.
The correct cartridge number appears when you use this link.
To order original HP supplies for the HP Deskjet 1510 series, go to www.hp.com/buy/supplies. If
prompted, choose your country/region, follow the prompts to select your product, and then click one
of the shopping links on the page.
NOTE: Ordering ink cartridges online is not supported in all countries/regions. If it is not available in
your country/region, you may still view supplies information and print a list for reference when
shopping at a local HP reseller.
ENWW
Order ink supplies
37
Choose right ink cartridges
HP recommends that you use original HP cartridges. Original HP cartridges are designed and tested
with HP printers to help you easily produce great results, time after time.
38
Chapter 6 Work with ink cartridges
ENWW
Replace ink cartridges
To replace the ink cartridges
1.
Check that power is on.
2.
Load paper.
3.
Remove the ink cartridge.
4.
a.
Open the cartridge access door and wait for the print carriage to move to the center of the
pinter.
b.
Press down to release the ink cartridge, and then remove it from the slot.
Insert new ink cartridge.
a.
ENWW
Remove the ink cartridge from the packaging.
Replace ink cartridges
39
b.
Remove the plastic tape using the pink pull tab.
c.
Slide the ink cartridge into slot until it clicks into place.
d.
Close the cartridge access door.
NOTE: The HP printer software prompts you to align the ink cartridges when you print a
document after installing a new ink cartridge.
40
Chapter 6 Work with ink cartridges
ENWW
Use single-cartridge mode
Use the single-cartridge mode to operate the HP Deskjet 1510 series with only one ink cartridge. The
single-cartridge mode is initiated when an ink cartridge is removed from the ink cartridge carriage.
During the single-cartridge mode, the printer can copy documents and print jobs from the computer.
NOTE: When the HP Deskjet 1510 series operates in single-cartridge mode, a message is
displayed on screen. If the message is displayed and two ink cartridges are installed in the printer,
verify that the protective piece of plastic tape has been removed from each ink cartridge. When
plastic tape covers the ink cartridge contacts, the printer cannot detect that the ink cartridge is
installed.
Exit single-cartridge mode
●
ENWW
Install both the black and tri-color cartridges in the HP Deskjet 1510 series to exit singlecartridge mode.
Use single-cartridge mode
41
Cartridge warranty information
The HP cartridge warranty is applicable when the cartridge is used in its designated HP printing
device. This warranty does not cover HP ink cartridges that have been refilled, remanufactured,
refurbished, misused, or tampered with.
During the warranty period the cartridge is covered as long as the HP ink is not depleted and the end
of warranty date has not been reached. The end of warranty date, in YYYY/MM/DD format, may be
found on the cartridge as indicated:
For a copy of the HP Limited Warranty Statement, see the printed documentation that came with the
printer.
42
Chapter 6 Work with ink cartridges
ENWW
Tips for working with ink cartridges
Use the following tips to work with ink cartridges:
ENWW
●
To protect the ink cartridges from drying out, always turn the printer off using the On button, and
wait until the On button light goes out.
●
Do not open or untape ink cartridges until you are ready to install them. Leaving tape on the ink
cartridges reduces ink evaporation.
●
Insert the ink cartridges into the correct slots. Match the color and icon of each ink cartridge to
the color and icon for each slot. Make sure the ink cartridges snap into place.
●
After you insert new ink cartridges, align the printer for best print quality. See Improve print
quality on page 50 for more information.
●
When the Estimated Ink Levels in the printer software shows one or both ink cartridges in a low
state, consider getting replacement cartridges to avoid possible printing delays. You do not need
to replace the ink cartridges until print quality becomes unacceptable. See Replace ink
cartridges on page 39 for more information.
●
If you remove an ink cartridge from the printer for any reason, try to replace it again as soon as
possible. Outside of the printer, if unprotected, ink cartridges begin to dry out.
Tips for working with ink cartridges
43
44
Chapter 6 Work with ink cartridges
ENWW
7
Connectivity
This section contains the following topics:
ENWW
●
Connect a new printer
●
USB connection
45
Connect a new printer
If you have not connected the printer to your computer, or you want to connect another new printer of
the same model to your computer, you can use the Connect a new printer function to set up the
connection.
NOTE:
1.
46
Use this method if you have already installed the printer software.
Depending on your operating system, do one of the following:
●
Windows 8: On the Start screen, right-click an empty area on the screen, and then click All
Apps on the app bar.
●
Windows 7, Windows Vista, and Windows XP: From the computer desktop, click Start,
select All Programs, click HP, and then click HP Deskjet 1510 series.
2.
Select Printer Setup & Software.
3.
Select Connect a new printer. Follow the on-screen instructions.
Chapter 7 Connectivity
ENWW
USB connection
The HP Deskjet 1510 series supports a rear USB 2.0 High Speed port for connection to a computer.
To connect the printer with the USB cable
1.
Insert the printer software CD in the computer CD-ROM drive.
NOTE: Do not connect the USB cable to the printer until you are prompted to do so.
2.
Follow the on-screen instructions. When you are prompted, connect the printer to the computer
by selecting USB on the Connection Options screen.
3.
Follow the on-screen instructions.
If the printer software has been installed, the printer will operate as a plug-and-play device. If the
software has not been installed, insert the CD that came with the printer and follow the on-screen
instructions.
ENWW
USB connection
47
48
Chapter 7 Connectivity
ENWW
8
Solve a problem
This section contains the following topics:
ENWW
●
Improve print quality
●
Clear paper jam
●
Unable to print
●
Clear print carriage
●
Identify a defective cartridge
●
Prepare trays
●
Resolve copy and scan issues
●
Printer failure
●
Ink cartridge problem
●
Older generation cartridges
●
HP support
49
Improve print quality
NOTE: To protect the ink cartridges from drying out, always turn the printer off using the On button,
and wait until the On button light goes out.
To improve print quality
1.
Make sure you are using original HP ink cartridges.
2.
Check the printer software to make sure you have selected the appropriate paper type and print
quality from the Media drop-down list.
In the printer software, click Print & Scan and then click Set Preferences to access the print
properties.
3.
Check the estimated ink levels to determine if the ink cartridges are low on ink.
For more information, see Check estimated ink levels on page 36. If the ink cartridges are low on
ink consider replacing them.
4.
Align the ink cartridges.
To align the ink cartridges
a.
Load letter or A4 unused plain white paper into the input tray.
b.
Depending on your operating system, do one of the following to open the printer software:
c.
●
Windows 8: On the Start screen, right-click an empty area on the screen, click All Apps
on the app bar, and then click the icon with the printer's name.
●
Windows 7, Windows Vista, and Windows XP: From the computer desktop, click Start,
select All Programs, click HP, click HP Deskjet 1510 series, and then click HP Deskjet
1510 series.
In the printer software, click Print & Scan and then click Maintain Your Printer to access the
printer toolbox.
The printer toolbox appears.
d.
Click Align Ink Cartridges on the Device Services tab.
The printer prints an alignment sheet.
50
Chapter 8 Solve a problem
ENWW
5.
e.
Load the cartridge alignment sheet print side down on the right front corner of the scanner
glass.
f.
Press the Start Copy Black button. The printer aligns the ink cartridges. Recycle or discard
the cartridge alignment sheet.
Print a diagnostics page if the ink cartridges are not low on ink.
To print a diagnostics page
ENWW
a.
Load letter or A4 unused plain white paper into the input tray.
b.
Depending on your operating system, do one of the following to open the printer software:
●
Windows 8: On the Start screen, right-click an empty area on the screen, click All Apps
on the app bar, and then click the icon with the printer's name.
●
Windows 7, Windows Vista, and Windows XP: From the computer desktop, click Start,
select All Programs, click HP, click HP Deskjet 1510 series, and then click HP Deskjet
1510 series.
c.
In the printer software, click Print & Scan and then click Maintain Your Printer to access the
printer toolbox.
d.
Click Print Diagnostic Information on the Device Reports tab to print a diagnostics page.
Improve print quality
51
e.
6.
Review the blue, magenta, yellow, and black boxes on the diagnostics page.
Clean the ink cartridges automatically, if the diagnostic page shows steaks or missing portions of
the color and black boxes.
To clean the ink cartridges automatically
52
a.
Load letter or A4 unused plain white paper into the input tray.
b.
Depending on your operating system, do one of the following to open the printer software:
●
Windows 8: On the Start screen, right-click an empty area on the screen, click All Apps
on the app bar, and then click the icon with the printer's name.
●
Windows 7, Windows Vista, and Windows XP: From the computer desktop, click Start,
select All Programs, click HP, click HP Deskjet 1510 series, and then click HP Deskjet
1510 series.
c.
In the printer software, click Print & Scan and then click Maintain Your Printer to access the
printer toolbox.
d.
Click Clean Ink Cartridges on the Device Services tab. Follow the on-screen instructions.
Chapter 8 Solve a problem
ENWW
If the above solutions do not resolve the problem, click here for more online troubleshooting.
ENWW
Improve print quality
53
Clear paper jam
Use the following steps to clear a paper jam.
Clear a paper jam from the input tray
1.
Press the Cancel button to try to clear the jam automatically. If this does not work, the paper jam
will need to be cleared manually.
2.
Pull the paper gently out of the input tray.
3.
Press the Start Copy Black or Start Copy Color button on the control panel to continue the
current job.
Clear a paper jam from the output tray
1.
Press the Cancel button to try to clear the jam automatically. If this does not work, the paper jam
will need to be cleared manually.
2.
pull the paper gently out of the output tray.
3.
Press the Start Copy Black or Start Copy Color button on the control panel to continue the
current job.
Clear a paper jam from the cartridge access area
1.
54
Press the Cancel button to try to clear the jam automatically. If this does not work, the paper jam
will need to be cleared manually.
Chapter 8 Solve a problem
ENWW
2.
Open the cartridge access door and slide the print carriage to the right to access the paper jam.
3.
Press the Start Copy Black or Start Copy Color button on the control panel to continue the
current job.
Clear a paper jam inside of the printer
ENWW
1.
Press the Cancel button to try to clear the jam automatically. If this does not work, the paper jam
will need to be cleared manually.
2.
Open the cleanout door located on the bottom of the printer. Press tabs on both sides of the
cleanout door.
3.
Remove the jammed paper.
Clear paper jam
55
4.
Close the cleanout door. Gently push the door towards the printer until both latches snap into
place.
5.
Press the Start Copy Black or Start Copy Color button on the control panel to continue the
current job.
If the above solutions do not resolve the problem, click here for more online troubleshooting.
Prevent paper jams
●
Do not overfill the input tray.
●
Remove printed papers from the output tray frequently.
●
Ensure that paper loaded in the input tray lays flat and the edges are not bent or torn.
●
Do not combine different paper types and paper sizes in the input tray; the entire stack of paper
in the input tray must be the same size and type.
●
Adjust the paper-width guide in the input tray to fit snugly against all paper. Make sure the
paper-width guide does not bend the paper in the input tray.
●
Do not force paper too far forward in the input tray.
●
Do not add paper while the printer is printing. If the printer is about to run out of paper, wait until
the out of paper message appears before adding paper.
If the above solutions do not resolve the problem, click here for more online troubleshooting.
56
Chapter 8 Solve a problem
ENWW
Unable to print
If you are having trouble printing, you can download the HP Print and Scan Doctor, which can
troubleshoot this issue for you automatically. To get the utility, click the appropriate link:
Take me to the HP Print and Scan Doctor download page.
NOTE:
The HP Print and Scan Doctor may not be available in all languages.
Resolve print issues
Make sure that the printer is turned on and that there is paper in the input tray. If you are still unable
to print, try the following in order:
1.
Check for error messages from the printer software and resolve them by following the on-screen
instructions.
2.
Disconnect and reconnect the USB cable.
3.
Verify that the printer is not paused or offline.
To verify that the printer is not paused or offline
a.
4.
Depending on your operating system, do one of the following:
●
Windows 8: Point to or tap the upper-right corner of the screen to open the Charms
bar, click the Settings icon, click or tap Control Panel, and then click or tap View
devices and printers.
●
Windows 7: From the Windows Start menu, click Devices and Printers.
●
Windows Vista: From the Windows Start menu, click Control Panel, and then click
Printers.
●
Windows XP: From the Windows Start menu, click Control Panel, and then click
Printers and Faxes.
b.
Either double-click the icon for your printer, or right-click the icon for your printer and select
See what’s printing to open the print queue.
c.
On the Printer menu, make sure there are no check marks next to Pause Printing or Use
Printer Offline.
d.
If you make any changes, try to print again.
Verify that the printer is set as the default printer.
To verify that the printer is set as the default printer
a.
ENWW
Depending on your operating system, do one of the following:
●
Windows 8: Point to or tap the upper-right corner of the screen to open the Charms
bar, click the Settings icon, click or tap Control Panel, and then click or tap View
devices and printers.
●
Windows 7: From the Windows Start menu, click Devices and Printers.
Unable to print
57
b.
●
Windows Vista: From the Windows Start menu, click Control Panel, and then click
Printers.
●
Windows XP: From the Windows Start menu, click Control Panel, and then click
Printers and Faxes.
Make sure the correct printer is set as the default printer.
The default printer has a check mark in a black or green circle next to it.
5.
c.
If the wrong printer is set as the default printer, right-click the correct printer and select Set
as Default Printer.
d.
Try using your printer again.
Restart the print spooler.
To restart the print spooler
a.
Depending on your operating system, do one of the following:
Windows 8
i.
Point to or tap the upper-right corner of the screen to open the Charms bar, and then
click the Settings icon.
ii.
Click or tap Control Panel, and then click or tap System and Security.
iii.
Click or tap Administrative Tools, and then double-click or double-tap Services.
iv.
Right-click or touch and hold Print Spooler, and then click Properties.
v.
On the General tab, next to Startup type, make sure that Automatic is selected.
vi.
If the service is not already running, under Service status, click or tap Start, and then
click or tap OK.
Windows 7
i.
From the Windows Start menu, click Control Panel, System and Security, and then
Administrative Tools.
ii.
Double-click Services.
iii.
Right-click the Print Spooler, and then click Properties.
iv.
On the General tab, next to Startup type, make sure that Automatic is selected.
v.
If the service is not already running, under Service status, click Start, and then click
OK.
Windows Vista
58
i.
From the Windows Start menu, click Control Panel, System and Maintenance,
Administrative Tools.
ii.
Double-click Services.
iii.
Right-click the Print Spooler service, and then click Properties.
Chapter 8 Solve a problem
ENWW
iv.
On the General tab, next to Startup type, make sure that Automatic is selected.
v.
If the service is not already running, under Service status, click Start, and then click
OK.
Windows XP
b.
i.
From the Windows Start menu, right click My Computer.
ii.
Click Manage, and then click Services and Applications.
iii.
Double-click Services, and then select Print Spooler.
iv.
Right-click Print Spooler, and click Restart to restart the service.
Make sure the correct printer is set as the default printer.
The default printer has a check mark in a black or green circle next to it.
c.
If the wrong printer is set as the default printer, right-click the correct printer and select Set
as Default Printer.
d.
Try using your printer again.
6.
Restart the computer.
7.
Clear the print queue.
To clear the print queue
a.
Depending on your operating system, do one of the following:
●
Windows 8: Point to or tap the upper-right corner of the screen to open the Charms
bar, click the Settings icon, click or tap Control Panel, and then click or tap View
devices and printers.
●
Windows 7: From the Windows Start menu, click Devices and Printers.
●
Windows Vista: From the Windows Start menu, click Control Panel, and then click
Printers.
●
Windows XP: From the Windows Start menu, click Control Panel, and then click
Printers and Faxes.
b.
Double-click the icon for your printer to open the print queue.
c.
On the Printer menu, click Cancel all documents or Purge Print Document, and then click
Yes to confirm.
d.
If there are still documents in the queue, restart the computer and try printing again after
the computer has restarted.
e.
Check the print queue again to make sure it is clear, and then try to print again.
If the above solutions do not resolve the problem, click here for more online troubleshooting.
ENWW
Unable to print
59
Clear print carriage
Remove any objects, such as paper, that are blocking the print carriage.
See Clear paper jam on page 54 for more information.
NOTE: Do not use any tools or other devices to remove jammed paper. Always use caution when
removing jammed paper from inside the printer.
Click here to go online for more information.
60
Chapter 8 Solve a problem
ENWW
Identify a defective cartridge
If both the tri-color and black ink cartridge lights are blinking, and the On button light is on, both
cartridges may still have tape on, be very low on ink, or are missing. First make sure that the pink
tape has been removed from both cartridges, and that both ink cartridges are installed. If both ink
cartridge lights are still blinking, then one or both cartridges may be defective. To determine if one
cartridge is defective, do the following:
ENWW
1.
Remove the black ink cartridge.
2.
Close the cartridge access door.
3.
If the On button light blinks quickly, replace the tri-color cartridge. If the On button light does not
blink, replace the black cartridge.
Identify a defective cartridge
61
Prepare trays
Open output tray
▲
Output tray must be open to begin printing.
Close cartridge access door
▲
Cartridge door must be closed to begin printing.
Click here to go online for more information.
62
Chapter 8 Solve a problem
ENWW
Resolve copy and scan issues
HP provides an HP Print and Scan Doctor (Windows only) that can help solve many common “Unable
to scan” issues.
NOTE:
The HP Print and Scan Doctor may not be available in all languages.
Take me to the HP Print and Scan Doctor download page.
Learn more about how to solve scan issues. Click here to go online for more information.
Learn how to solve copy issues. Click here to go online for more information.
ENWW
Resolve copy and scan issues
63
Printer failure
Resolve printer failure.
▲
Turn the printer off, then on. If that does not resolve the problem, contact HP.
Please contact HP support for help .
64
Chapter 8 Solve a problem
ENWW
Ink cartridge problem
First try removing and reinserting the ink cartridges. If this does not work, clean the cartridge
contacts. If your problem is still not resolved, replace the ink cartridges. For more information, see
Replace ink cartridges on page 39.
Clean the ink cartridge contacts
CAUTION: The cleaning procedure should take only a few minutes. Make sure that the ink
cartridges are reinstalled in the printer as soon as possible. It is not recommended to leave the ink
cartridges outside of the printer longer than 30 minutes. This could result in damage to the printhead
or the ink cartridges.
1.
Check that power is on.
2.
Open the cartridge access door and wait for the print carriage to move to the center of the
printer.
3.
Remove the ink cartridge indicated by the flashing cartridge light on the control panel.
4.
Hold the ink cartridge by its sides with the bottom pointing up and locate the electrical contacts
on the ink cartridge.
The electrical contacts are the small gold-colored dots on the ink cartridge.
5.
Wipe only the contacts with a dry swab or lint-free cloth.
CAUTION: Be careful to wipe only the contacts, and do not smear any of the ink or other
debris elsewhere on the ink cartridge.
ENWW
Ink cartridge problem
65
6.
On the inside of the printer, locate the contacts for the cartridge.
The printer contacts are the set of gold-colored bumps positioned to meet the contacts on the ink
cartridge.
7.
Use a dry swab or lint-free cloth to wipe the contacts.
8.
Reinstall the ink cartridge.
9.
Close the cartridge access door, and check if the error message has gone away.
10. If you still receive the error message, turn the printer off, and then on again.
NOTE: If one ink cartridge is causing problems, you can remove it and use the single-cartridge
mode to operate the HP Deskjet 1510 series with only one ink cartridge.
Click here to go online for more information.
66
Chapter 8 Solve a problem
ENWW
Older generation cartridges
You will need to use a newer version of this cartridge. In most cases you can identify a newer version
of the cartridge by looking at the exterior of the cartridge package and finding the Warranty Ends
date.
If it says ‘v1’ several spaces to the right of the date, then the cartridge is the updated newer version. If
it is an older generation cartridge, contact HP support for help or replacement.
Click here to go online for more information.
ENWW
Older generation cartridges
67
HP support
●
Register printer
●
Support process
●
HP support by phone
●
Additional warranty options
Register printer
By taking just a few quick minutes to register, you can enjoy quicker service, more efficient support,
and product support alerts. If you did not register your printer while installing the software, you can
register now at http://www.register.hp.com.
Support process
If you have a problem, follow these steps:
1.
Check the documentation that came with the printer.
2.
Visit the HP online support website at www.hp.com/support.
HP online support is available to all HP customers. It is the fastest source for up-to-date product
information and expert assistance, and includes the following features:
3.
●
Fast access to qualified online support specialists
●
Software and driver updates for the printer
●
Valuable troubleshooting information for common problems
●
Proactive printer updates, support alerts, and HP newsgrams that are available when you
register the printer
Call HP support.
Support options and availability vary by printer, country/region, and language.
HP support by phone
Phone support options and availability vary by printer, country/region, and language.
This section contains the following topics:
68
●
Phone support period
●
Placing a call
●
Support phone numbers
●
After the phone support period
Chapter 8 Solve a problem
ENWW
Phone support period
One year of phone support is available in North America, Asia Pacific, and Latin America (including
Mexico). To determine the duration of phone support in Europe, the Middle East, and Africa, go to
www.hp.com/support. Standard phone company charges apply.
Placing a call
Call HP support while you are in front of the computer and the printer. Be prepared to provide the
following information:
●
Product name (Located on the printer, such as HP Deskjet 1510, HP Deskjet Ink Advantage
1515)
●
Product number (located inside the cartridge access door)
●
Serial number (located on the back or bottom of the printer)
●
Messages that appear when the situation occurs
●
Answers to these questions:
◦
Has this situation happened before?
◦
Can you recreate it?
◦
Did you add any new hardware or software to your computer at about the time that this
situation began?
◦
Did anything else occur prior to this situation (such as a thunderstorm, the printer was
moved, etc.)?
Support phone numbers
For the most current HP list of telephone support numbers and call costs information, see
www.hp.com/support.
After the phone support period
After the phone support period, help is available from HP at an additional cost. Help may also be
available at the HP online support website: www.hp.com/support. Contact your HP dealer or call the
support phone number for your country/region to learn more about support options.
Additional warranty options
Extended service plans are available for the HP Deskjet 1510 series at additional costs. Go to
www.hp.com/support, select your country/region and language, then explore the services and
warranty area for information about the extended service plans.
ENWW
HP support
69
70
Chapter 8 Solve a problem
ENWW
A
Technical information
The technical specifications and international regulatory information for the HP Deskjet 1510 series
are provided in this section.
For additional specifications, see the printed documentation that came with the HP Deskjet 1510
series.
This section contains the following topics:
ENWW
●
Hewlett-Packard Company notices
●
Specifications
●
Environmental product stewardship program
●
Regulatory notices
71
Hewlett-Packard Company notices
The information contained herein is subject to change without notice.
All rights reserved. Reproduction, adaptation, or translation of this material is prohibited without prior
written permission of Hewlett-Packard, except as allowed under the copyright laws. The only
warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial errors or omissions contained
herein.
© 2012 Hewlett-Packard Development Company, L.P.
Microsoft®, Windows ®, Windows® XP, Windows Vista®, Windows® 7 and Windows® 8 are U.S.
registered trademarks of Microsoft Corporation.
72
Appendix A Technical information
ENWW
Specifications
Technical specifications for the HP Deskjet 1510 series are provided in this section. For more product
specifications, see the Product Data Sheet at www.hp.com/support.
●
System requirements
●
Environmental specifications
●
Input tray capacity
●
Output tray capacity
●
Paper size
●
Paper weights
●
Print specifications
●
Copy specifications
●
Scan specifications
●
Print resolution
●
Power specifications
●
Cartridge yield
●
Acoustic information
System requirements
Software and system requirements are located in the Readme file.
For information about future operating system releases and support, visit the HP online support
website at www.hp.com/support.
Environmental specifications
●
Recommended operating temperature range: 15 ºC to 32 ºC (59 ºF to 90 ºF)
●
Allowable operating temperature range: 5 ºC to 40 ºC (41 ºF to 104 ºF)
●
Humidity: 15% to 80% RH non-condensing; 28 ºC maximum dewpoint
●
Nonoperating (Storage) temperature range: –40 ºC to 60 ºC (–40 ºF to 140 ºF)
●
In the presence of high electromagnetic fields, it is possible the output from the HP Deskjet 1510
series may be slightly distorted
●
HP recommends using a USB cable less than or equal to 3 m (10 feet) in length to minimize
injected noise due to potential high electromagnetic fields
Input tray capacity
Plain paper sheets (80 g/m2 [20lb]): Up to 50
Envelopes: Up to 5
ENWW
Specifications
73
Index cards: Up to 20
Photo paper sheets: Up to 20
Output tray capacity
Plain paper sheets (80 g/m2 [20lb]): Up to 30
Envelopes: Up to 5
Index cards: Up to 10
Photo paper sheets: Up to 10
Paper size
For a complete list of supported media sizes, see the printer software.
Paper weights
Plain Paper: 64 to 90 g/m² (16 to 24 lb)
Envelopes: 75 to 90 g/m² (20 to 24 lb)
Cards: Up to 200 g/m² (110-lb index maximum)
Photo Paper: Up to 280 g/m² (75 lb)
Print specifications
●
Print speeds vary according to the complexity of the document
●
Method: drop-on-demand thermal inkjet
●
Language: PCL3 GUI
Copy specifications
●
Digital image processing
●
Copy speeds vary according to the complexity of the document and model
Scan specifications
●
Resolution: up to 1200 x 1200 ppi optical
For more information about ppi resolution, see the scanner software.
74
●
Color: 24-bit color, 8-bit grayscale (256 levels of gray)
●
Maximum scan size from glass: 21.6 x 29.7 cm (8.5 x 11.7 inches)
Appendix A Technical information
ENWW
Print resolution
Draft mode
●
Color Input/Black Render: 300x300dpi
●
Output (Black/Color): Automatic
Normal mode
●
Color Input/Black Render: 600x300dpi
●
Output (Black/Color): Automatic
Plain-Best mode
●
Color Input/Black Render: 600x600dpi
●
Output (Black/Color): Automatic
Photo-Best mode
●
Color Input/Black Render: 600x600dpi
●
Output (Black/Color): Automatic
Max DPI mode
●
Color Input/Black Render: 1200x1200dpi
●
Output: Automatic (Black), 4800x1200 optimized dpi (Color)
Power specifications
0957-2385
●
Input voltage: 100-240Vac (+/- 10%)
●
Input frequency: 50/60 Hz (+/- 3Hz)
0957-2403
●
Input voltage: 200-240Vac (+/- 10%)
●
Input frequency: 50/60 Hz (+/- 3Hz)
NOTE:
Use only with the power adapter supplied by HP.
Cartridge yield
Visit www.hp.com/go/learnaboutsupplies for more information on estimated cartridge yields.
Acoustic information
If you have Internet access, you can get acoustic information from the HP website. Go to:
www.hp.com/support.
ENWW
Specifications
75
Environmental product stewardship program
Hewlett-Packard is committed to providing quality products in an environmentally sound manner.
Design for recycling has been incorporated into this product. The number of materials has been kept
to a minimum while ensuring proper functionality and reliability. Dissimilar materials have been
designed to separate easily. Fasteners and other connections are easy to locate, access, and remove
using common tools. High priority parts have been designed to access quickly for efficient
disassembly and repair.
For more information, visit HP’s Commitment to the Environment website at:
www.hp.com/hpinfo/globalcitizenship/environment/index.html
●
Eco-Tips
●
Paper use
●
Plastics
●
Material safety data sheets
●
Recycling program
●
HP inkjet supplies recycling program
●
Power consumption
●
Sleep mode
●
Disposal of waste equipment by users
●
Chemical substances
●
Toxic and hazardous substance table (China)
●
Restriction of hazardous substance (Ukraine)
●
Restriction of hazardous substance (India)
Eco-Tips
HP is committed to helping customers reduce their environmental footprint. Please visit the HP
Environmental Programs and Initiatives website for more information on HP’s environmental
initiatives.
www.hp.com/hpinfo/globalcitizenship/environment/
Paper use
This product is suited for the use of recycled paper according to DIN 19309 and EN 12281:2002.
Plastics
Plastic parts over 25 grams are marked according to international standards that enhance the ability
to identify plastics for recycling purposes at the end of product life.
76
Appendix A Technical information
ENWW
Material safety data sheets
Material safety data sheets (MSDS) can be obtained from the HP website at:
www.hp.com/go/msds
Recycling program
HP offers an increasing number of product return and recycling programs in many countries/regions,
and partners with some of the largest electronic recycling centers throughout the world. HP conserves
resources by reselling some of its most popular products. For more information regarding recycling of
HP products, please visit:
www.hp.com/hpinfo/globalcitizenship/environment/recycle/
HP inkjet supplies recycling program
HP is committed to protecting the environment. The HP Inkjet Supplies Recycling Program is
available in many countries/regions, and lets you recycle used print cartridges and ink cartridges free
of charge. For more information, go to the following website:
www.hp.com/hpinfo/globalcitizenship/environment/recycle/
Power consumption
Hewlett-Packard printing and imaging equipment marked with the ENERGY STAR® logo is qualified
to the U.S. Environmental Protection Agency’s ENERGY STAR specifications for imaging equipment.
The following mark will appear on ENERGY STAR qualified imaging products:
Additional ENERGY STAR qualified imaging product model information is listed at: www.hp.com/go/
energystar
Sleep mode
ENWW
●
Power usage is reduced while in Sleep mode.
●
After initial setup of printer, the printer will enter Sleep mode after 5 minutes of inactivity.
●
The time to Sleep mode cannot be changed.
Environmental product stewardship program
77
Disposal of waste equipment by users
This symbol means do not dispose of your product with your other household waste.
Instead, you should protect human health and the environment by handing over your
waste equipment to a designated collection point for the recycling of waste electrical
and electronic equipment. For more information, please contact your household waste
disposal service, or go to http://www.hp.com/recycle.
Chemical substances
HP is committed to providing our customers with information about the chemical substances in our
products as needed to comply with legal requirements such as REACH (Regulation EC No
1907/2006 of the European Parliament and the Council). A chemical information report for this
product can be found at: www.hp.com/go/reach.
Toxic and hazardous substance table (China)
Restriction of hazardous substance (Ukraine)
78
Appendix A Technical information
ENWW
Restriction of hazardous substance (India)
ENWW
Environmental product stewardship program
79
Regulatory notices
The HP Deskjet 1510 series meets product requirements from regulatory agencies in your country/
region.
This section contains the following topics:
●
Regulatory model identification number
●
FCC statement
●
Notice to users in Korea
●
VCCI (Class B) compliance statement for users in Japan
●
Notice to users in Japan about the power cord
●
European Union Regulatory Notice
●
Declaration of conformity
Regulatory model identification number
For regulatory identification purposes, your product is assigned a Regulatory Model Number. The
Regulatory Model Number for your product is SNPRB-1204-01. This regulatory number should not be
confused with the marketing name (HP Deskjet 1510 All-in-One Printer, HP Deskjet Ink Advantage
1515 All-in-One Printer, etc.) or product numbers (B2L56 to B2L60, C5X22 to C5X27, etc.).
80
Appendix A Technical information
ENWW
FCC statement
Notice to users in Korea
VCCI (Class B) compliance statement for users in Japan
Notice to users in Japan about the power cord
ENWW
Regulatory notices
81
European Union Regulatory Notice
Products bearing the CE marking comply with the following EU Directives:
●
Low Voltage Directive 2006/95/EC
●
EMC Directive 2004/108/EC
●
Ecodesign Directive 2009/125/EC, where applicable
CE compliance of this product is valid only if powered with the correct CE-marked AC adapter
provided by HP.
If this product has telecommunications functionality, it also complies with the essential requirements
of the following EU Directive:
●
R&TTE Directive 1999/5/EC
Compliance with these directives implies conformity to applicable harmonized European standards
(European Norms) that are listed in the EU Declaration of Conformity issued by HP for this product or
product family and available (in English only) either within the product documentation or at the
following website: www.hp.com/go/certificates (type the product number in the search field).
The compliance is indicated by one of the following conformity markings placed on the product:
For non-telecommunications products and for EU harmonized
telecommunications products, such as Bluetooth® within power class below
10mW.
For EU non-harmonized telecommunications products (If applicable, a 4-digit
notified body number is inserted between CE and !).
Please refer to the regulatory label provided on the product.
The telecommunications functionality of this product may be used in the following EU and EFTA
countries: Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,
Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg,
Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovak Republic, Slovenia, Spain, Sweden,
Switzerland, and United Kingdom.
The telephone connector (not available for all products) is intended for connection to analogue
telephone networks.
82
Appendix A Technical information
ENWW
Products with wireless LAN devices
●
Some countries may have specific obligations or special requirements about the operation of
Wireless LAN networks such as indoor use only or restrictions of the channels available. Please
make sure that the country settings of the wireless network are correct.
●
For 2.4-GHz Wireless LAN operation of this product, certain restrictions apply: This product may
be used indoors for the entire 2400-MHz to 2483.5-MHz frequency band (channels 1 to 13). For
outdoor use, only the 2400-MHz to 2454-MHz frequency band (channels 1 to 7) may be used.
For the latest requirements, see www.arcep.fr.
France
The point of contact for regulatory matters is:
Hewlett-Packard GmbH, Dept./MS: HQ-TRE, Herrenberger Strasse 140, 71034 Boeblingen,
GERMANY
ENWW
Regulatory notices
83
Declaration of conformity
84
Appendix A Technical information
ENWW
Index
A
after the support period
B
buttons, control panel
69
5
C
control panel
buttons 5
features 5
copy
specifications 74
customer support
warranty 69
E
environment
Environmental product
stewardship program 76
environmental specifications
73
P
paper
recommended types 20
phone support 68
phone support period
period for support 69
print
specifications 74
R
recycle
ink cartridges 77
regulatory notices 80
regulatory model identification
number 80
S
scan
scan specifications 74
support process 68
system requirements 73
T
technical information
copy specifications 74
environmental specifications
73
print specifications 74
scan specifications 74
system requirements 73
W
warranty 69
Download PDF
