19-3805; Rev 0; 8/06

EVALUATION KIT

AVAILABLE

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

General Description

The MAX7327, a 2-wire serial-interfaced peripheral, features 12 push-pull outputs and four configurable open-drain I/O ports with selectable internal pullups and transition detection. Ports are overvoltage protected to +6V, independent of supply voltage.

The four I/O ports configured as inputs are continuously monitored for state changes (transition detection). State changes are indicated by the open-drain, +6V-tolerant

INT output. The interrupt is latched, detecting transient changes. When the MAX7327 is subsequently accessed through the serial interface, any pending interrupt is cleared. The 12 push-pull and the four open-drain outputs are rated to sink 20mA, and are capable of driving

LEDs. The RST input clears the serial interface, terminating any I

2

C* communication to or from the MAX7327.

The MAX7327 uses two address inputs with four-level logic to allow 16 I

2

C slave addresses. The slave address also determines the power-up logic state for the I/O ports, and enables or disables internal 40k

Ω pullups in groups of two ports.

The MAX7327 is one device in a family of pin-compatible port expanders with a choice of input ports, open-drain

I/O ports, and push-pull output ports (see Table 1).

The MAX7327 is available in the 24-pin QSOP and

TQFN packages, and is specified over the -40°C to

+125°C automotive temperature range.

Cell Phones

SAN/NAS

Servers

Applications

Notebooks

Satellite Radio

Automotive

Features

400kHz I

2

C Serial Interface

+1.71V to +5.5V Operating Voltage

12 Push-Pull Output Ports, Rated at 20mA Sink

Current

4 Open-Drain I/O Ports, Rated at 20mA Sink Current

I/O Ports are Overvoltage Protected to +6V

Selectable I/O Port Power-Up Default Logic States

Transient Changes are Latched, Allowing Detection

Between Read Operations

♦ INT Output Alerts Changes on Inputs

AD0 and AD2 Inputs Select from 16 Slave

Addresses

Low 0.6µA (typ) Standby Current

-40°C to +125°C Temperature Range

Ordering Information

PART TEMP RANGE PIN-PACKAGE

PKG

CODE

E24-1 MAX7327AEG+ -40°C to +125°C 24 QSOP

MAX7327ATG+ -40°C to +125°C

24 TQFN - E P **

( 4m m x 4m m )

T2444-3

MAX7327AATG+ -40°C to +125°C

24 TQFN - E P **

( 3.5m m x 3.5m m )

T243A3-1

+Denotes lead-free package.

**EP = Exposed pad.

Selector Guide

Pin Configurations

TOP VIEW

SCL 19

SDA 20

V+ 21

INT

22

RST

23

AD2

24

18 17 16 15 14 13

MAX7327

EXPOSED PADDLE

1 2 3 4 5 6

12 O10

11 O9

10 O8

9

GND

8

O7

7

O6

TQFN (4mm x 4mm)

Pin Configurations continued at end of data sheet.

PART INPUTS

INTERRUPT

MASK

OPEN-

DRAIN

OUTPUTS

PUSH-PULL

OUTPUTS

MAX7324 8

MAX7325 Up to 8

MAX7326 4

MAX7327 Up to 4

Yes

Yes

Up to 8

Up to 4

8

8

12

12

Typical Application Circuit and Functional Diagram appear at end of data sheet.

*Purchase of I

2

C components from Maxim Integrated Products,

Inc., or one of its sublicensed Associated Companies, conveys a license under the Philips I

2

C Patent Rights to use these components in an I

2

C system, provided that the system conforms to the I

2

C Standard Specification as defined by Philips.

________________________________________________________________ Maxim Integrated Products 1

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at

1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

ABSOLUTE MAXIMUM RATINGS

(All voltages referenced to GND.)

Supply Voltage V+....................................................-0.3V to +6V

SCL, SDA, AD0, AD2, RST, INT, P2–P5 ..................-0.3V to +6V

O0, O1, O6–O15 .............................................-0.3V to V

+

+ 0.3V

O0, O1, O6–O15 Output Current .....................................±25mA

P2–P5 Sink Current ............................................................25mA

SDA Sink Current ...............................................................10mA

INT Sink Current .................................................................10mA

Total V+ Current .................................................................50mA

Total GND Current ...........................................................100mA

Continuous Power Dissipation (T

A

= +70°C)

24-Pin QSOP (derate 9.5mW/°C over +70°C)...........761.9mW

24-Pin TQFN (derate 20.8mW/°C over +70°C) .......1666.7mW

Operating Temperature Range .........................-40°C to +125°C

Junction Temperature ......................................................+150°C

Storage Temperature Range .............................-65°C to +150°C

Lead Temperature (soldering, 10s) .................................+300°C

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.

DC ELECTRICAL CHARACTERISTICS

(V+ = +1.71V to +5.5V, T

A

= -40°C to +125°C, unless otherwise noted. Typical values are at V+ = +3.3V, T

A

= +25°C.) (Note 1)

PARAMETER

Operating Supply Voltage

Power-On Reset Voltage

Standby Current

(Interface Idle)

Supply Current

(Interface Running)

Input High-Voltage

SDA, SCL, AD0, AD2,

RST, P2–P5

Input Low-Voltage

SDA, SCL, AD0, AD2,

RST, P2–P5

Input Leakage Current

SDA, SCL, AD0, AD2,

RST, P2–P5

Input Capacitance

SDA, SCL, AD0, AD2,

RST, P2–P5

SYMBOL

V+

V

POR

I

I

STB

V

V

IH

I+

IH

IL

, I

IL

CONDITIONS

T

A

= -40°C to +125°C

V+ falling

SCL and SDA and other digital inputs at V+

T

A

= -40°C to

+125°C f

SCL

= 400kHz; other digital inputs at V+

V+ < 1.8V

V+

≥ 1.8 V

T

A

= -40°C to

+125°C

V+ < 1.8V

V+

≥ 1.8 V

SDA, SCL, AD0, AD2,

RST, P0–P7 at V+ or GND, internal pullup disabled

MIN

1.71

0.8 x V+

0.7 x V+

-0.2

TYP

0.6

23

10

MAX UNITS

5.50

V

1.6

V

1.9

55

0.2 x V+

0.3 x V+

+0.2

µA

µA

V

V

µA pF

Output Low Voltage

O8–O15, P0, P7

Output High Voltage

O0, O1, O6–O15, P2–P5

Output Low-Voltage SDA

Output Low-Voltage

INT

Port Input Pullup Resistor

VOL

V+ = 1.71V, I

SINK

= 5mA (QSOP)

V+ = 1.71V, I

SINK

= 5mA (TQFN)

V+ = 2.5V, I

SINK

= 10mA (QSOP)

V+ = 2.5V, I

SINK

= 10mA (TQFN)

V+ = 3.3V, I

SINK

= 15mA (QSOP)

V+ = 3.3V, I

SINK

= 15mA (TQFN)

V+ = 5V, I

SINK

= 20mA (QSOP)

V+ = 5V, I

SINK

= 20mA (TQFN)

V+ = +1.71V, I

SOURCE

= 2mA

VOH

V+ = +2.5V, I

SOURCE

= 5mA

V+ = +3.3V, I

SOURCE

= 5mA

V+ = +5V, I

SOURCE

= 10mA

V

OLSDA

I

SINK

= 6mA

V

OLINT

I

SINK

= 5mA

R

PU

90

90

110

110

130

130

140

140

V+ - 250 V+ - 30

V+ - 360 V+ - 70

V+ - 260 V+ - 100

V+ - 360 V+ - 120

25

130

40

230

280

250

300

180

230

210

260

250

250

55 mV mV mV mV k

Ω

2 _______________________________________________________________________________________

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

PORT AND INTERRUPT INT TIMING CHARACTERISTICS

(V+ = +1.71V to +5.5V, T

A

= -40°C to +125°C, unless otherwise noted. Typical values are at V+ = +3.3V, T

A

= +25°C.) (Note 1)

PARAMETER

Port Output Data Valid

Port Input Setup Time

Port Input Hold Time

INT Input Data Valid Time

INT Reset Delay Time from STOP

INT Reset Delay Time from

Acknowledge

SYMBOL

t

PPV t

PSU t

PH t

IV t

IP t

IR

C

L

≤ 100pF

C

L

≤ 100pF

C

L

≤ 100pF

C

L

≤ 100pF

C

L

≤ 100pF

C

L

≤ 100pF

CONDITIONS MIN

0

4

TYP MAX

4

4

4

4

UNITS

µs

µs

µs

µs

µs

µs

TIMING CHARACTERISTICS

(V+ = +1.71V to +5.5V, T

A

= -40°C to +125°C, unless otherwise noted. Typical values are at V+ = +3.3V, T

A

= +25°C.) (Note 1)

PARAMETER

Serial-Clock Frequency

Bus Free Time Between a STOP and a START Condition

Hold Time (Repeated) START

Condition

SYMBOL

t f t

SCL

BUF

HD, STA

CONDITIONS MIN

1.3

0.6

TYP MAX

400

UNITS

kHz

µs

µs

Repeated START Condition

Setup Time

STOP Condition Setup Time

Data Hold Time

Data Setup Time

SCL Clock Low Period

SCL Clock High Period

Rise Time of Both SDA and SCL

Signals, Receiving t t t

SU, STA

SU, STO

HD, DAT t

SU, DAT t t

LOW

HIGH

(Note 2)

0.6

0.6

100

1.3

0.7

0.9

µs

Fall Time of Both SDA and SCL

Signals, Receiving

Fall Time of SDA Transmitting t t t

R

F

F,TX

(Notes 3, 4)

(Notes 3, 4)

(Notes 3, 4)

20 +

0.1C

b

20 +

0.1C

b

20 +

0.1C

b

50

300

300

250 ns ns ns

Pulse Width of Spike Suppressed

Capacitive Load for Each Bus

Line

RST Pulse Width

RST Rising to START Condition

Setup Time t t t

SP

C b

W

RST

(Note 5)

(Note 3)

500

1

400 ns pF ns

µs

Note 1: All parameters tested at T

A

= +25°C. Specifications over temperature are guaranteed by design.

Note 2: A master device must provide a hold time of at least 300ns for the SDA signal (referred to V

IL of the SCL signal) in order to bridge the undefined region of SCL’s falling edge.

Note 3: Guaranteed by design.

Note 4: C b

= total capacitance of one bus line in pF. t

R and t

F measured between 0.3 x V+ and 0.7 x V+ with I

SINK

≤ 6mA.

Note 5: Input filters on the SDA and SCL inputs suppress noise spikes less than 50ns.

µs

µs ns

µs

µs

_______________________________________________________________________________________ 3

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

Typical Operating Characteristics

(T

A

= +25°C, unless otherwise noted.)

STANDBY CURRENT vs. TEMPERATURE

2.0

1.8

1.6

1.4

f

SCL

= 0kHz

1.2

1.0

0.8

0.6

V+ = +2.5V

V+ = +3.3V

V+ = +5.0V

0.4

0.2

V+ = +1.71V

0

-40 -25 -10 5 20 35 50 65 80 95 110 125

TEMPERATURE (

°C)

OUTPUT VOLTAGE LOW vs. TEMPERATURE

0.25

0.20

V+ = +5.0V

I

SINK

= 20mA

V+ = +3.3V

I

SINK

= 15mA

0.15

60

50

40

30

20

10

SUPPLY CURRENT vs. TEMPERATURE

f

SCL

= 400kHz

V+ = +5.0V

V+ = +3.3V

V+ = +2.5V

V+ = +1.71V

6

0

-40 -25 -10 5 20 35 50 65 80 95 110 125

TEMPERATURE (

°C)

OUTPUT VOLTAGE HIGH vs. TEMPERATURE

V+ = +5.0V

I

SOURCE

= 10mA

5

4

V+ = +3.3V

I

SOURCE

= 5mA

3

V+ = +2.5V I

SOURCE

= 5mA

V+ = +1.71V I

SOURCE

= 2mA

0.10

0.05

V+ = +2.5V

I

SINK

= 10mA

V+ = +1.71V

I

SINK

= 5mA

V+ = +1.62V

I

SINK

= 4mA

0

-40 -25 -10 5 20 35 50 65 80 95 110 125

TEMPERATURE (

°C)

2

1

0

-40 -25 -10 5 20 35 50 65 80 95 110 125

TEMPERATURE (

°C)

Pin Description

QSOP

1

2

3, 21

4, 5, 10,

11, 13–20

6–9

12

22

23

24

PIN

TQFN

22

23

24, 18

1, 2, 7, 8,

10–17

3–6

9

19

20

21

EP

NAME

INT

RST

AD2, AD0

O0, O1,

O6–O15

P2–P5

GND

SCL

SDA

V+

EP

FUNCTION

Active-Low Interrupt Output.

INT is an open-drain output.

Active-Low Reset Input. Drive

RST low to clear the 2-wire interface.

Address Inputs. Select device slave address with AD0 and AD2. Connect AD0 and AD2 to either GND, V+, SCL, or SDA to give four logic combinations (see Tables 2 and 3).

Output Ports. O0, O1, O6–O15 are push-pull outputs rated at 20mA.

P2–P5 Open-Drain I/Os

Ground

I

2

C-Compatible Serial Clock Input

I

2

C-Compatible Serial Data I/O

Positive Supply Voltage. Bypass V+ to GND with a 0.047µF ceramic capacitor.

Exposed Pad. Connect exposed pad to GND.

4 _______________________________________________________________________________________

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

Detailed Description

MAX7319–MAX7329 Family Comparison

The MAX7324–MAX7327 family consists of four pincompatible, 16-port expanders that integrate the functions of the MAX7320 and one of either the MAX7319,

MAX7321, MAX7322, or MAX7323.

Functional Overview

The MAX7327 is a general-purpose port expander operating from a +1.71V to +5.5V supply that provides

12 push-pull output ports with a 20mA sink, 10mA source drive capability, and four open-drain I/O ports with a 20mA sink capability. The four open-drain outputs are overvoltage protected to +6V.

The MAX7327 is set to two of 32 I

2

C slave addresses

(see Tables 2 and 3) using address inputs AD2 and

AD0, and is accessed over an I

2

C serial interface up to

400kHz. Eight push-pull outputs use a different slave address from the other four push-pull outputs and the open-drain I/Os. The eight push-pull outputs, O8–O15, use the 101xxxx addresses while the four outputs O0,

O1, O6, and O7 and the open-drain I/Os P2–P5 use addresses with 110xxxx. The RST input clears the serial interface in case of a bus lockup, terminating any serial transaction to or from the MAX7327.

Any of the four open-drain ports can be configured as a logic input by setting the port output logic-high (logichigh for an open-drain output is high impedance).

When the MAX7327 is read through the serial interface, the actual logic levels at the ports are read back.

Table 1. MAX7319–MAX7329 Family Comparison

PART

I

2

C

SLAVE

ADDRESS

16-PORT EXPANDERS

INPUTS

INPUT

INTERRUPT

MASK

OPEN-

DRAIN

OUTPUTS

PUSH-

PULL

OUTPUTS

CONFIGURATION

8 inputs and 8 push-pull outputs version:

8 input ports with programmable latching transition detection interrupt and selectable pullups.

MAX7324

MAX7325

101xxxx and

110xxxx

8

Up to 8

Yes

Up to 8

8

8

8 push-pull outputs with selectable default logic levels.

Offers maximum versatility for automatic input monitoring. An interrupt mask selects which inputs cause an interrupt on transitions, and transition flags identify which inputs have changed (even if only for a transient) since the ports were last read.

8 I/O and 8 push-pull outputs version:

8 open-drain I/O ports with latching transition detection interrupt and selectable pullups.

8 push-pull outputs with selectable default logic levels.

Open-drain outputs can level shift the logic-high state to a higher or lower voltage than V+ using external pullup resistors, but pullups draw current when output is low. Any open-drain port can be used as an input by setting the open-drain output to logichigh. Transition flags identify which open-drain port inputs have changed (even if only for a transient) since the ports were last read.

_______________________________________________________________________________________ 5

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

Table 1. MAX7319–MAX7329 Family Comparison (continued)

PART

I

2

C

SLAVE

ADDRESS

INPUTS

INPUT

INTERRUPT

MASK

OPEN-

DRAIN

OUTPUTS

PUSH-

PULL

OUTPUTS

CONFIGURATION

4 input-only, 12 push-pull output versions:

4 input ports with programmable latching transition detection interrupt and selectable pullups.

MAX7326

MAX7327

101xxxx and

110xxxx

4

Up to 4

Yes

Up to 4

12

12

12 push-pull outputs with selectable default logic levels.

Offers maximum versatility for automatic input monitoring. An interrupt mask selects which inputs cause an interrupt on transitions, and transition flags identify which inputs have changed (even if only for a transient) since the ports were last read.

4 I/O, 12 push-pull output versions:

4 open-drain I/O ports with latching transition detection interrupt and selectable pullups.

12 push-pull outputs with selectable default logic levels.

Open-drain outputs can level shift the logic-high state to a higher or lower voltage than V+ using external pullup resistors, but pullups draw current when output is low. Any open-drain port can be used as an input by setting the open-drain output to logichigh. Transition flags identify which open-drain port inputs have changed (even if only for a transient) since the ports were last read.

8-PORT EXPANDERS

MAX7319

110xxxx

MAX7320

101xxxx

MAX7321

110xxxx Up to 8

MAX7322

110xxxx

8

4

Yes

Yes

Up to 8

8

4

Input-only versions:

8 input ports with programmable latching transition detection interrupt and selectable pullups.

Output-only versions:

8 push-pull outputs with selectable power-up default levels.

I/O versions:

8 open-drain I/O ports with latching transition detection interrupt and selectable pullups.

4 input-only, 4 output-only versions:

4 input ports with programmable latching transition detection interrupt and selectable pullups.

4 push-pull outputs with selectable power-up default levels.

6 _______________________________________________________________________________________

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

Table 1. MAX7319–MAX7329 Family Comparison (continued)

PART

I

2

C

SLAVE

ADDRESS

INPUTS

INPUT

INTERRUPT

MASK

OPEN-

DRAIN

OUTPUTS

PUSH-

PULL

OUTPUTS

MAX7323

110xxxx Up to 4 — Up to 4 4

CONFIGURATION

4 I/O, 4 output-only versions:

4 open-drain I/O ports with latching transition detection interrupt and selectable pullups.

4 push-pull outputs with selectable power-up default levels.

MAX7328

MAX7329

0100xxx

0111xxx

Up to 8 — Up to 8 —

PCF8574-, PCF8574A-compatible versions:

8 open-drain I/O ports with nonlatching transition detection interrupt and pullups on all ports.

The four open-drain ports offer latching transition detection functionality when used as inputs. All input ports are continuously monitored for changes. An input change sets 1 of 4 flag bits that identify the changed input(s). All flags are cleared upon a subsequent read or write transaction to the MAX7327.

A latching interrupt output INT automatically flags data changes on any of the I/O ports used as inputs through an interrupt mask register. Data changes on any input port forces INT to a logic-low. The interrupt output INT is deasserted when the MAX7327 is next accessed through the serial interface.

Internal pullup resistors to V+ are selected by the address select inputs, AD0 and AD2. Pullups are enabled on the input ports in groups of two (see Table 2). Use the slave address selection to ensure that I/O ports used as inputs are logic-high on power-up. I/O ports with internal pullups enabled default to a logic-high output state. I/O ports with internal pullups disabled default to a logic-low output state.

Output port power-up logic levels are selected by the address select inputs AD0 and AD2. Ports default to logic-high or logic-low on power-up in groups of two

(see Tables 2 and 3).

Initial Power-Up

On power-up, the default states of the 12 push-pull output ports and the four open-drain I/O ports are set according to the I

2

C slave address selection inputs,

AD0 and AD2 (see Tables 2 and 3). For I/O ports used as inputs, ensure that the default states are logic-high; therefore, the I/O ports power up in the high-impedance state. All I/O ports configured with pullups enabled also have a logic-high default state. On powerup, the transition detection logic is reset, and INT is deasserted. The transition flags are cleared, indicating no data changes.

Power-On Reset (POR)

The MAX7327 contains an integral POR circuit that ensures all registers are reset to a known state on power-up. When V+ rises above V

POR

(1.6V max), the

POR circuit releases the registers and 2-wire interface for normal operation. When V+ drops to less than V

POR

, the MAX7327 resets all register contents to the POR defaults (Tables 2 and 3).

RST Input

The active-low RST input operates as a hardware reset that voids any I

2

C transaction involving the MAX7327, forcing the MAX7327 into the I

2

C STOP condition. A reset does not affect the interrupt output (INT).

Standby Mode

When the serial interface is idle, the MAX7327 automatically enters standby mode drawing minimal supply current.

Slave Address, Power-Up Default Logic

Levels, and Input Pullup Selection

Address inputs AD0 and AD2 determine the MAX7327 slave address and select which inputs have pullup resistors. Pullups are enabled on the input ports in groups of two (see Table 2).

The MAX7327 slave address is determined on each I

2

C transmission, regardless of whether the transmission is actually addressing the MAX7327. The MAX7327 distinguishes whether address inputs AD0 and AD2 are connected to SDA or SCL instead of fixed-logic levels V+ or GND during the transmission. The MAX7327 slave

_______________________________________________________________________________________ 7

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

address can be configured dynamically in the application without cycling the device supply.

On initial power-up, the MAX7327 cannot decode the address inputs AD0 and AD2 fully until the first I

2

C transmission. AD0 and AD2 initially appear to be connected to V+ or GND. This is important because the address selection is used to determine the power-up default states of the output ports, I/O port initial logic state, and whether pullups are enabled. At power-up, the I

2

C SDA and SCL bus interface lines are high impedance at the I/O pins of every device (master or slave) connected to the bus, including the MAX7327.

This is guaranteed as part of the I

2

C specification.

Therefore, when address inputs AD0 and AD2 are connected to SDA or SCL during power-up, they appear to be connected to V+. The pullup selection logic uses

AD0 to select whether pullups are enabled for ports P2 and P3, and uses AD2 to select whether pullups are enabled for ports P4 and P5. The rule is that a logichigh, SDA, or SCL connection selects the pullups and sets the logic state to high. A logic-low deselects the pullups and sets the default logic state to low. The pullup configuration is correct on power-up for a standard I

2

C configuration, where SDA or SCL are pulled up to V+ by the external I

2

C pullup resistors.

There are circumstances where the assumption that

SDA = SCL = V+ on power-up is not true; for example, in applications in which there is legitimate bus activity during power-up. If SDA and SCL are terminated with pullup resistors to a different supply voltage to the

MAX7327’s supply voltage, and if that pullup supply rises later than the MAX7327’s supply, then SDA or

SCL may appear at power-up to be connected to GND.

In such applications, use the four address combinations that are selected by connecting address inputs

AD0 and AD2 to V+ or GND (shown in bold in Tables 2 and 3). These selections are guaranteed to be correct at power-up, independent of SDA and SCL behavior. If one of the other 12 address combinations is used, an unexpected combination of pullups might be asserted until the first I

2

C transmission (to any device, not necessarily the MAX7327) is put on the bus.

Table 2. MAX7327 Address Map for Outputs O0, O1, O6, O7, and Ports P2–P5

PIN

CONNECTION

AD2

DEVICE ADDRESS PORTS POWER-UP DEFAULT 40k

Ω INPUT PULLUPS ENABLED

AD0 A6 A5 A4 A3 A2 A1 A0 O7 O6 P5 P4 P3 P2 O1 O0 O7 O6 P5 P4 P3 P2 O1 O0

SCL

SCL

SCL

SCL

SDA

SDA

SDA

SDA

SCL

SDA

GND GND

GND

V+

GND

GND

SCL

SDA

GND

V+

SCL

SDA

GND

V+

V+

V+

V+

V+

GND

V+

SCL

SDA

1

1 1 0 0 0 0 1 1 1 1 1 1 1 1 1

1 1 0 0 0 1 0 1 1 1 1 1 1 1 1

1 1 0 0 0 1 1 1 1 1 1 1 1 1 1

1 1 0 0 1 0 0 1 1 1 1 0 0 0 0

1 1 0 0 1 0 1 1 1 1 1 1 1 1 1

1 1 0 0 1 1 0 1 1 1 1 1 1 1 1

1 1 0 0 1 1 1 1 1 1 1 1 1 1 1

1 1 0 1 0 0 0 0 0 0 0 0 0 0 0

1 1 0 1 0 0 1 0 0 0 0 1 1 1 1

1 1 0 1 0 1 0 0 0 0 0 1 1 1 1

1 1 0 1 0 1 1 0 0 0 0 1 1 1 1

1

1

1

1

1

1

1

1

1

0

0

0

0

0

0

1

1

1

1

0

1

1

1

1

0

0

0

1

1

0

0

1

0

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

0

0

1

1

1

0

0

1

1

1

0

0

1

1

1

0

0

1

1

1

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y Y Y Y

Y Y Y Y

Y Y Y Y

Y Y — —

Y Y Y Y

Y Y Y Y

Y Y Y Y

— — — —

— — Y Y

— — Y Y

— — Y Y

Y Y — —

Y

Y

Y

8 _______________________________________________________________________________________

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

Table 3. MAX7327 Address Map for Outputs O8–O15

PIN

C O NN EC TIO N

AD2 AD0

SCL GND

SCL V+

SCL SCL

SCL SDA

SDA GND

SDA V+

SDA SCL

SDA SDA

GND GND

GND V+

GND SCL

GND SDA

V+

V+

V+

V+

GND

V+

SCL

SDA

1

1

1

A6

1

1

1

1

1

1

1

1

1

1

1

1

1

0

0

0

A5

0

0

0

0

0

0

0

0

0

0

0

0

0

DEVICE ADDRESS

1

1

1

A4

1

1

1

1

1

1

1

1

1

1

1

1

1

0

0

0

A3

0

0

0

0

0

1

1

1

1

1

1

1

1

0

1

1

A2

0

0

0

1

1

1

1

1

1

0

0

0

0

1

0

1

A0

0

1

0

0

1

0

1

0

1

0

1

0

1

1

0

0

A1

0

0

1

1

1

1

1

0

0

1

1

0

0

OUTPUTS POWER-UP DEFAULT

1

1

1

1

0

0

0

0

1

1

1

O15 O14 O13 O12 O11 O10

1 1 1 1 0 0

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

0

1

1

0

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

0

0

0

0

1

1

1

1

0

0

0

0

1

1

1

1

0

0

0

0

1

1

0

1

1

1

0

1

1

1

0

1

1

1

0

1

1

0

1

O9

0

1

1

1

1

1

1

0

1

1

1

0

1

1

0

1

O8

0

1

1

1

1

1

1

0

1

1

1

0

1

I/O Port Inputs

I/O port inputs switch at CMOS logic levels as determined by the expander’s supply voltage, and are overvoltage tolerant to +6V, independent of the expander’s supply voltage.

I/O Port Input Transition Detection

All I/O ports configured as inputs are monitored for changes since the expander was last accessed through the serial interface. The state of the ports is stored in an internal “snapshot” register for transition monitoring. The snapshot is continuously compared with the actual input conditions, and if a change is detected for any port input, INT is asserted to signal a state change. The input ports are sampled (internally latched into the snapshot register) and the old transition flags cleared during the I

2

C acknowledge of every

MAX7327 read and write access. The previous port transition flags are read through the serial interface as the second byte of a 2-byte read sequence.

A long read sequence (more than 2 bytes) can be used to poll the expander continuously without the overhead of resending the slave address. If more than 2 bytes are read from the expander, the expander repeatedly returns the 2 bytes of input port data followed by the transition flags. The inputs are repeatedly resampled and the transition flags repeatedly reset for each pair of bytes read. All changes that occur during a long read sequence are detected and reported.

The INT output is not reasserted during a read sequence to avoid recursive reentry into an interrupt service routine. Instead, if a data change occurs that would normally cause the INT output to be set, the INT assertion is delayed until the STOP condition. INT is not reasserted upon a STOP condition if the changed input data is read before the STOP occurs. The INT logic ensures that unnecessary interrupts are not asserted, yet data changes are detected and reported no matter when the change occurs.

_______________________________________________________________________________________ 9

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

Serial Interface

Serial Addressing

The MAX7327 operates as a slave that sends and receives data through an I

2

C interface. The interface uses a serial-data line (SDA) and a serial-clock line (SCL) to achieve bidirectional communication between master(s) and slave(s). The master initiates all data transfers to and from the MAX7327 and generates the SCL clock that synchronizes the data transfer (Figure 1).

SDA operates as both an input and an open-drain output. A pullup resistor, typically 4.7k

Ω, is required on

SDA. SCL operates only as an input. A pullup resistor, typically 4.7k

Ω, is required on SCL if there are multiple masters on the 2-wire interface, or if the master in a single-master system has an open-drain SCL output.

Each transmission consists of a START condition sent by a master, followed by the MAX7327’s 7-bit slave addresses plus R/W bits, one or more data bytes, and finally a STOP condition (Figure 2).

START and STOP Conditions

Both SCL and SDA remain high when the interface is not busy. A master signals the beginning of a transmission with a START (S) condition by transitioning SDA from high to low while SCL is high. When the master has finished communicating with the slave, the master issues a STOP (P) condition by transitioning SDA from low to high while SCL is high. The bus is then free for another transmission (Figure 2).

Bit Transfer

One data bit is transferred during each clock pulse.

The data on SDA must remain stable while SCL is high

(Figure 3).

SDA

SCL t

HD,STA

START CONDITION t

LOW t

SU,DAT t

HIGH t

R t

F t

HD,DAT

Figure 1. 2-Wire Serial Interface Timing Details

t

SU,STA t

HD,STA

REPEATED START CONDITION t

SU,STO t

BUF

STOP

CONDITION

START

CONDITION

SDA

SCL

S

START

CONDITION

Figure 2. START and STOP Conditions

P

STOP

CONDITION

SDA

SCL

DATA LINE STABLE;

DATA VALID

CHANGE OF DATA

ALLOWED

Figure 3. Bit Transfer

10 ______________________________________________________________________________________

Acknowledge

The acknowledge bit is a clocked 9th bit the recipient uses to acknowledge receipt of each byte of data ( Figure 4).

Each byte transferred effectively requires 9 bits. The master generates the 9th clock pulse, and the recipient pulls down SDA during the acknowledge clock pulse, such that the SDA line is stable low during the high period of the clock pulse. When the master is transmitting to the MAX7327, the MAX7327 generates the acknowledge bit because the device is the recipient.

When the MAX7327 is transmitting to the master, the master generates the acknowledge bit because the master is the recipient.

Slave Address

The MAX7327 has two different 7-bit slave addresses

(Figure 5). The addresses are different to communicate to the eight push-pull outputs, O8-O15, or the other eight I/Os. The eighth bit following the 7-bit slave address is the R/W bit. It is low for a write command, and high for a read command.

The first (A6), second (A5), and third (A4) bits of the

MAX7327 slave address are always 1, 1, and 0 (O0,

O1, P2–P5, O6, O7) or 1, 0, and 1 (O8–O15). Connect

AD0 and AD2 to GND, V+

,

SDA, or SCL to select slave address bits A3, A2, A1, and A0. The MAX7327 has 16 possible slave addresses (Tables 2 and 3), allowing up to 16 MAX7327 devices on an I

2

C bus.

SCL

START

CONDITION

SDA BY

TRANSMITTER

SDA BY

RECEIVER S

1

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

2

CLOCK PULSE

FOR ACKNOWLEDGEMENT

8 9

Accessing the MAX7327

The MAX7327 is a combination of MAX7320 and

MAX7323. The group A of eight ports (O0, O1, P2–P5,

O6, and O7) corresponding to those of the MAX7323 and the group B of eight ports (O8–O15) corresponding to those of the MAX7320 are read/write separately through their own addresses as shown by Tables 2 and 3, respectively.

A single-byte read from the group A ports of the

MAX7327 returns the status of the four I/O ports and the four output ports (read back as inputs), and clear both the internal transition flags and the INT output when the master acknowledges the slave address byte.

A 2-byte read from the group A ports of the MAX7327 returns the status of the four I/O ports and the four output ports (as for a single byte read), followed by the four transition flags for the four I/O ports. The internal transition flags and the INT output are cleared automatically when the master acknowledges the slave address byte (but the previous transition flag data is sent as the second byte).

A multibyte read (more than 2 bytes before the I

2

C

STOP bit) from the group A ports of the MAX7327 repeatedly returns the port data, alternating with the transition flags. As the port data is resampled for each transmission, and the transition flags are reset each time, a multibyte read continuously returns the current data and identifies any changing I/O ports.

If a port input data change occurs during the read sequence, then INT is reasserted during the I

2

C STOP bit. The MAX7327 does not generate another interrupt during a single-byte or multibyte MAX7327 read routine.

Input port data is sampled during the preceding I

2

C acknowledge bit (the acknowledge bit for the I

2

C slave address in the case of a single-byte or 2-byte read).

Figure 4. Acknowledge

A4 A3 A2 SDA

SCL

1

MSB

Figure 5. Slave Address

A5 A1 A0

LSB

R/W ACK

______________________________________________________________________________________ 11

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

A single-byte read from the group B ports of the

MAX7327 returns the status of the eight output ports, read back as inputs.

A 2-byte read from the group B ports of the MAX7327 repeatedly returns the status of the eight output ports, read back as inputs.

A multibyte read (more than 2 bytes before the I

2

C

STOP bit) from the group B ports of the MAX7327 repeatedly returns the status of the eight output ports, read back as inputs.

A single-byte write to the group A or B ports of the

MAX7327 sets the logic state of all eight ports.

A multibyte write to the group A or B ports of the

MAX7327 repeatedly sets the logic state of all eight ports.

Reading the MAX7327

A read from the group A ports of the MAX7327 starts with the master transmitting the port group’s slave address with the R/W bit set to high. The MAX7327 acknowledges the slave address, and samples the status of the ports during the acknowledge bit. INT goes high during the slave address acknowledge. The master can then issue a STOP condition after the acknowledge. The snapshot is taken, and the INT status remains unchanged, if the master terminates the serial transition with a no-acknowledge.

When the master reads one byte from the group A ports of the MAX7327 and subsequently issues a STOP condition (Figure 6), the MAX7327 transmits the current port data, clears the change flags, and resets the tran-

S

O7 O6 P5 P4 P3 P2 O1 O0

NO ACKNOWLEDGE

FROM MASTER

ACKNOWLEDGE FROM MAX7327

MAX7327 SLAVE ADDRESS 1

R/W

A D7 D6 D5 D4 D3 D2 D1 D0 N

PORT SNAPSHOT PORT SNAPSHOT

P

SCL

PORTS t

IV

INT OUTPUT

Figure 6. Reading Group A Ports of the MAX7327 (1 Data Byte)

t

PH t

IR t

PS

INT REMAINS HIGH UNTIL STOP CONDITION t

IP

12 ______________________________________________________________________________________

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

sition detection. INT deasserts during the slave acknowledge. The new snapshot data is the current port data transmitted to the master, and therefore, port changes occuring during the transmission are detected. INT remains high until the STOP condition.

When the master reads 2 bytes from the group A ports of the MAX7327 and subsequently issues a STOP condition (Figure 7), the MAX7327 transmits the current port data, followed by the change flags. The change flags are then cleared, and transition detection is reset.

INT goes high (high impedance if an external pullup resistor is not fitted) during the slave acknowledge. The new snapshot data is the current port data transmitted to the master, and therefore, port changes occuring during the transmission are detected. INT remains high until the STOP condition.

A read from the group B ports of the MAX7327 starts with the master transmitting the group’s slave address with the R/W bit set high. The MAX7327 acknowledges the slave address, and samples the logic state of the output ports during the acknowledge bit. The master can read one or more bytes from the group B ports of the

MAX7327 and then issues a STOP condition (Figure 8).

The MAX7327 transmits the current port data, read back from the actual port outputs (not the port output latches) during the acknowledge. If a port is forced to a logic state other than its programmed state, the readback reflects this. If driving a capacitive load, the readback port level verification algorithms may need to take the RC rise/fall time into account.

Typically, the master reads one byte from the group B ports of the MAX7327, then issues a STOP condition

(Figure 8). However, the master can read two or more

S

SCL

PORTS t

IV

INT OUTPUT

FLAG

O7 O6 P5 P4 P3 P2 O1 O0

F7 F6 F5 F4 F3 F2 F1 F0

NO ACKNOWLEDGE

FROM MASTER

ACKNOWLEDGE FROM MAX7327

MAX7327 SLAVE ADDRESS 1 A D7 D6 D5 D4 D3 D2 D1 D0 A D7 D6 D5 D4 D3 D2 D1 D0 N P

R/W

PORT SNAPSHOT

PORT SNAPSHOT PORT SNAPSHOT t

IR t

PH t

PS

INT REMAINS HIGH UNTIL STOP CONDITION t

IP

Figure 7. Reading Group A Ports of the MAX7327 (2 Data Bytes)

S

PORT SNAPSHOT DATA

ACKNOWLEDGE FROM MAX7327

MAX7327 SLAVE ADDRESS

1

R/W

P7 P6 P5 P4 P3

DATA 1

P2 P1 P0

A D7 D6 D5 D4 D3 D2 D1 D0 A

PORT SNAPSHOT TAKEN

PORT SNAPSHOT TAKEN

P

ACKNOWLEDGE

FROM MASTER

SCL

Figure 8. Reading Group B Ports of MAX7327

______________________________________________________________________________________ 13

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

bytes from the group B ports of the MAX7327, then issues a STOP condition. In this case, the MAX7327 resamples the port outputs during each acknowledge and transmits the new data each time.

Writing to the MAX7327

A write to the group A or B ports of the MAX7327 starts with the master transmitting the group’s slave address with the R/W bit set low. The MAX7327 acknowledges the slave address, and samples the ports during the acknowledge bit. INT goes high (high impedance if an external pullup resistor is not fitted) during the slave acknowledge only when it writes to the group A ports.

The master can now transmit one or more bytes of data. The MAX7327 acknowledges these subsequent bytes of data and updates the corresponding group’s ports with each new byte until the master issues a

STOP condition (Figure 9).

Applications Information

Port Input and I

2

C Interface Level

Translation from Higher or Lower Logic Voltages

The MAX7327’s SDA, SCL, AD0, AD2, RST, INT, and the four I/O ports P2–P5 are overvoltage protected to

+6V, independent of V+. This allows the MAX7327 to operate from a lower supply voltage, such as +3.3V, while the I

2

C interface and/or some of the four I/O ports are driven from a higher logic level, such as +5V.

The MAX7327 can operate from a higher supply voltage, such as +3V, while the I

2

C interface and/or some of the four I/O ports P2–P5 are driven from a lower logic level, such as +2.5V. For V+ < 1.8V, apply a minimum voltage of 0.8 x V+ to assert a logic-high on any input.

For a V+

≥ 1.8V, apply a voltage of 0.7 x V+ to assert a logic-high. For example, a MAX7327 operating from a

+5V supply may not recognize a +3.3V nominal logichigh. One solution for input-level translation is to drive

MAX7327 inputs from open-drain outputs. Use a pullup resistor to V+ or a higher supply to ensure a high logic voltage greater than 0.7 x V+.

Port Output Signal Level Translation

The open-drain output architecture allows for level translation to higher or lower voltages than the

MAX7327’s supply. Use an external pullup resistor on any output to convert the high-impedance logic-high condition to a positive voltage level. The resistor can be connected to any voltage up to +6V, and the resistor value chosen to ensure no more than 20mA to be sunk in logic-low condition. For interfacing CMOS inputs, a pullup resistor value of 220k

Ω is a good starting point.

Use a lower resistance to improve noise immunity, in applications where power consumption is less critical, or where a faster rise time is needed for a given capacitive load.

Each of the 12 push-pull output ports has protection diodes to V+ and GND. When a port output is driven to a voltage higher than V+ or lower than GND, the appropriate protection diode clamps the output to a diode drop above V+ or below GND. When the MAX7327 is powered down (V+ = 0V), every output port’s protection

WRITE

TO PORT

DATA OUT

FROM PORT

SCL

SDA

S

1 2 3 4 5 6 7 8

SLAVE ADDRESS

0 A

START CONDITION R/W ACKNOWLEDGE

FROM SLAVE

DATA TO PORT

DATA 1 t

PV

A

ACKNOWLEDGE

FROM SLAVE

DATA TO PORT

DATA 2

DATA 1 VALID t

PV

A

ACKNOWLEDGE

FROM SLAVE

DATA 2 VALID

Figure 9. Writing the MAX7327

14 ______________________________________________________________________________________

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

diodes to V+ and GND continue to appear as a diode clamp from each output to GND (Figure 10).

Each of the four I/O ports P2–P5 has a protection diode to GND (Figure 11). When a port output is driven to a voltage lower than GND, the protection diode clamps the output to a diode drop below GND.

Each of the four I/O ports P2–P5 also has a 40k

Ω (typ) pullup resistor that can be enabled or disabled. When a port input is driven to a voltage higher than V+, the body diode of the pullup enable switch conducts and the 40k

Ω pullup resistor is enabled. When the

MAX7327 is powered down (V+ = 0V), each I/O port appears as a 40k

Ω resistor in series with a diode connected to 0V. Input ports are protected to +6V under any of these circumstances (Figure 11).

Driving LED Loads

When driving LEDs from one of the 12 push-pull outputs, a resistor must be fitted in series with the LED to limit the LED current to no more than 20mA. Connect the LED cathode to the MAX7327 port, and the LED anode to V+ through the series current-limiting resistor,

R

LED

. Set the port output low to light the LED. Choose the resistor value according to the following formula:

R

LED

= (V

SUPPLY

- V

LED

- V

OL

) / I

LED where:

R

LED is the resistance of the resistor in series with the

LED (

Ω).

V

SUPPLY is the supply voltage used to drive the LED (V).

V

LED is the forward voltage of the LED (V).

V

OL is the output low voltage of the MAX7327 when sinking I

LED

(V).

I

LED is the desired operating current of the LED (A).

For example, to operate a 2.2V red LED at 10mA from a

+5V supply:

R

LED

= (5 - 2.2 - 0.1) / 0.01 = 270

Ω

Driving Load Currents Higher than 20mA

The MAX7327 can be used to drive loads such as relays that draw more than 20mA by paralleling outputs. Use at least one output per 20mA of load current; for example, a 5V 330mW relay draws 66mA, and therefore, requires four paralleled outputs. Any combination of outputs can be used as part of a load-sharing design because any combination of ports can be set or cleared at the same time by writing to the MAX7327. Do not exceed a total sink current of 100mA for the device.

The MAX7327 must be protected from the negative voltage transient generated when switching off inductive loads (such as relays), by connecting a reversebiased diode across the inductive load. Choose the peak current for the diode to be greater than the inductive load’s operating current.

Power-Supply Considerations

The MAX7327 operates with a supply voltage of +1.71V

to +5.5V. Bypass the supply to GND with a ceramic capacitor of at least 0.047µF as close as possible to the device. For the TQFN version, additionally connect the exposed pad to GND.

MAX7327

OUTPUT

V+ V+

O0–O2

O6–O15

PULLUP

ENABLE

V+ V+

40k

Ω

MAX7327

INPUT

OUTPUT

P2–P5

Figure 10. MAX7327 Push-Pull Output Port Structure Figure 11. MAX7327 Open-Drain I/O Port Structure

______________________________________________________________________________________ 15

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

Functional Diagram Typical Application Circuit

3.3V

AD0

AD2

SCL

SDA

RST

INPUT

FILTER

POWER-ON

RESET

I

2

C

CONTROL

MAX7327

I/O

PORTS

O15

O14

O13

O12

O11

O10

O9

O8

O7

O6

P5

P4

P3

P2

O1

O0

INT

μC

SCL

SDA

RST

INT

V+

SCL

SDA

RST

INT

AD0

AD2

MAX7327

O15

O14

013

012

O11

O10

O9

O8

O7

O6

P5

P4

P3

P2

O2

O1

GND

OUTPUT

OUTPUT

OUTPUT

OUTPUT

OUTPUT

OUTPUT

INPUT/OUTPUT

INPUT/OUTPUT

INPUT/OUTPUT

INPUT/OUTPUT

OUTPUT

OUTPUT

Pin Configurations (continued)

TOP VIEW

INT

1

RST 2

AD2 3

O0 4

O1 5

P2 6

P3 7

P4

8

P5 9

O6 10

O7 11

GND 12

MAX7327

QSOP

24 V+

23 SDA

22 SCL

21 AD0

20 O15

19 O14

18 O13

17

O12

16 O11

15 O10

14 O9

13 O8

PROCESS: BiCMOS

Chip Information

16 ______________________________________________________________________________________

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

Package Information

(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information, go to www.maxim-ic.com/packages.)

PACKAGE OUTLINE,

12, 16, 20, 24, 28L THIN QFN, 4x4x0.8mm

21-0139 E

1

2

______________________________________________________________________________________ 17

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

Package Information (continued)

(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information, go to www.maxim-ic.com/packages.)

PACKAGE OUTLINE,

12, 16, 20, 24, 28L THIN QFN, 4x4x0.8mm

21-0139

E

2

2

18 ______________________________________________________________________________________

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

Package Information (continued)

(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information, go to www.maxim-ic.com/packages.)

PACKAGE OUTLINE, QSOP .150", .025" LEAD PITCH

21-0055 F

1

1

______________________________________________________________________________________ 19

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

Package Information (continued)

(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information, go to www.maxim-ic.com/packages.)

20 ______________________________________________________________________________________

I

2

C Port Expander with 12 Push-Pull

Outputs and 4 Open-Drain I/Os

Package Information (continued)

(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information, go to www.maxim-ic.com/packages.)

Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.

Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 ____________________ 21

© 2006 Maxim Integrated Products is a registered trademark of Maxim Integrated Products, Inc.

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
