19-1257; Rev 1; 3/98
Low-Dropout, 120mA Linear Regulators
For dual versions, refer to the MAX8865/MAX8866 data
sheet. For low-noise versions with 30µVRMS output
noise, refer to the MAX8877/MAX8878.
________________________Applications
Cordless Telephones
____________________________Features
♦ LP2980 Pin-Compatible SOT23 Package
♦ Low, 55mV Dropout Voltage at 50mA IOUT
(130mV at 120mA)
♦ Low, 73µA No-Load Supply Current
Low, 82µA Operating Supply Current (even in
dropout)
♦ Miniature External Components
♦ Thermal Overload Protection
♦ Output Current Limit
♦ Reverse Battery Protection
♦ Dual Mode Operation: Fixed or Adjustable
(1.25V to 6.5V) Output
♦ Low-Power Shutdown
______________Ordering Information
TEMP. RANGE
PINPACKAGE
SOT TOP
MARK
MAX8873TEUK-T -40°C to +85°C
5 SOT23-5
ABZH
-40°C to +85°C
5 SOT23-5
ABZI
MAX8873REUK-T -40°C to +85°C
5 SOT23-5
ABZL
PART
MAX8873SEUK-T
Modems
PCS Telephones
Hand-Held Instruments
MAX8874TEUK-T -40°C to +85°C
5 SOT23-5
ABZJ
Cellular Telephones
Palmtop Computers
MAX8874SEUK-T
-40°C to +85°C
5 SOT23-5
ABZK
PCMCIA Cards
Electronic Planners
MAX8874REUK-T -40°C to +85°C
5 SOT23-5
ABZM
__________Typical Operating Circuit
__________________Pin Configuration
TOP VIEW
IN 1
OUT
IN
BATTERY
CIN
1µF
MAX8873
MAX8874
SHDN
GND
5 OUT
OUTPUT
VOLTAGE
COUT
1µF
SET
GND 2
MAX8873
MAX8874
SHDN 3
4 SET
SOT23-5
Dual Mode is a trademark of Maxim Integrated Products.
________________________________________________________________ Maxim Integrated Products
1
For free samples & the latest literature: http://www.maxim-ic.com, or phone 1-800-998-8800.
For small orders, phone 408-737-7600 ext. 3468.
MAX8873T/S/R, MAX8874T/S/R
_______________General Description
The MAX8873T/S/R and MAX8874T/S/R low-dropout linear regulators operate from a +2.5V to +6.5V input
range and deliver up to 120mA. A PMOS pass transistor allows the low, 82µA supply current to remain independent of load, making these devices ideal for
battery-operated portable equipment such as cellular
phones and cordless phones.
The devices feature Dual Mode™ operation: their output voltage is preset (at 3.15V for the T versions, 2.84V
for the S versions, or 2.80V for the R versions) or can be
adjusted with an external resistor divider. Total error on
the output is ±3.5%. Output voltages are set on the low
side of popular ranges so that power drain is minimized
for longer battery life. Other features include low-power
shutdown, short-circuit protection, thermal shutdown
protection, and reverse battery protection. The
MAX8874 also includes an auto-discharge function,
which actively discharges the output voltage to ground
when the device is placed in shutdown mode. Both
devices come in a miniature 5-pin SOT23 package.
MAX8873T/S/R, MAX8874T/S/R
Low-Dropout, 120mA Linear Regulators
ABSOLUTE MAXIMUM RATINGS
VIN to GND ..................................................................-7V to +7V
Output Short-Circuit Duration ............................................Infinite
SET to GND ..............................................................-0.3V to +7V
SHDN to GND..............................................................-7V to +7V
SHDN to IN .................................................................-7V to 0.3V
OUT to GND ................................................-0.3V to (VIN + 0.3V)
Continuous Power Dissipation (TA = +70°C)
SOT23-5 (derate 7.1mW/°C above +70°C) .................571mW
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
θJA ..................................................................................140°C/W
Storage Temperature Range .............................-65°C to +160°C
Lead Temperature (soldering, 10sec) .............................+300°C
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
ELECTRICAL CHARACTERISTICS
(VIN = +3.6V, TA = TMIN to TMAX, unless otherwise noted. Typical values are at TA = +25°C.) (Note 1)
PARAMETER
Input Voltage (Note 2)
Output Voltage
Adjustable Output Voltage
Range (Note 3)
SYMBOL
CONDITIONS
MIN
VIN
VOUT
0mA ≤ IOUT ≤ 50mA,
SET = GND
Ground Pin Current
MAX
UNITS
6.5
V
MAX887_T
3.05
3.15
3.25
MAX887_S
2.75
2.84
2.93
MAX887_R
2.70
2.80
2.88
VOUT
VSET
Maximum Output Current
Current Limit (Note 4)
TYP
2.5
6.5
120
ILIM
IQ
Dropout Voltage (Note 5)
IOUT = 0mA
73
IOUT = 50mA
82
150
1.1
IOUT = 50mA
55
120
0
0.15
SET = GND
0.011
0.030
SET tied to OUT
0.006
∆VLNR
VIN = 2.5V to 6.5V, SET tied to OUT,
IOUT = 1mA
Load Regulation
∆VLDR
IOUT = 0mA to 50mA
Output Voltage Noise
mA
IOUT = 1mA
Line Regulation
10Hz to 1MHz
-0.15
V
mA
280
SET = GND
V
COUT = 1µF
350
COUT = 100µF
220
µA
mV
%/V
%/mA
µVRMS
SHUTDOWN
SHDN Input Threshold
VIH
SHDN Input Bias Current
ISHDN
Shutdown Supply Current
IQSHDN
Shutdown Discharge
Resistance (MAX8874)
2
2.0
VIL
0.4
V SHDN = VIN
VOUT = 0V
TA = +25°C
0
TA = TMAX
0.05
TA = +25°C
0.0001
TA = TMAX
0.02
300
