LM124

LM124
 SLOS066S − SEPTEMBER 1975 − REVISED JULY 2008
D
D
D
D
D
D
description/ordering information
These devices consist of four independent
high-gain frequency-compensated operational
amplifiers that are designed specifically to operate
from a single supply over a wide range of voltages.
Operation from split supplies also is possible if the
difference between the two supplies is 3 V to 32 V
(3 V to 26 V for the LM2902), and VCC is at least
1.5 V more positive than the input common-mode
voltage. The low supply-current drain is
independent of the magnitude of the supply
voltage.
1OUT
1IN−
1IN+
VCC
2IN+
2IN−
2OUT
1
14
2
13
3
12
4
11
5
10
6
9
7
8
4OUT
4IN−
4IN+
GND
3IN+
3IN−
3OUT
LM124, LM124A . . . FK PACKAGE
(TOP VIEW)
1IN−
1OUT
NC
4OUT
4IN−
D
− LM224K, LM224KA
− LM324K, LM324KA
− LM2902K, LM2902KV, LM2902KAV
Wide Supply Ranges
− Single Supply . . . 3 V to 32 V
(26 V for LM2902)
− Dual Supplies . . . +1.5 V to +16 V
(+13 V for LM2902)
Low Supply-Current Drain Independent of
Supply Voltage . . . 0.8 mA Typ
Common-Mode Input Voltage Range
Includes Ground, Allowing Direct Sensing
Near Ground
Low Input Bias and Offset Parameters
− Input Offset Voltage . . . 3 mV Typ
A Versions . . . 2 mV Typ
− Input Offset Current . . . 2 nA Typ
− Input Bias Current . . . 20 nA Typ
A Versions . . . 15 nA Typ
Differential Input Voltage Range Equal to
Maximum-Rated Supply Voltage . . . 32 V
(26 V for LM2902)
Open-Loop Differential Voltage
Amplification . . . 100 V/mV Typ
Internal Frequency Compensation
LM124 . . . D, J, OR W PACKAGE
LM124A . . . J OR W PACKAGE
LM224, LM224A, LM224K, LM224KA . . . D OR N PACKAGE
LM324, LM324K . . . D, N, NS, OR PW PACKAGE
LM324A . . . D, DB, N, NS, OR PW PACKAGE
LM324KA . . . D, N, NS, OR PW PACKAGE
LM2902 . . . D, N, NS, OR PW PACKAGE
LM2902K . . . D, DB, N, NS, OR PW PACKAGE
LM2902KV, LM2902KAV . . . D OR PW PACKAGE
(TOP VIEW)
1IN+
NC
VCC
NC
2IN+
4
3 2 1 20 19
18
5
17
6
16
7
15
8
14
9 10 11 12 13
4IN+
NC
GND
NC
3IN+
2IN−
2OUT
NC
3OUT
3IN−
D 2-kV ESD Protection for:
NC − No internal connection
Applications include transducer amplifiers, dc amplification blocks, and all the conventional
operational-amplifier circuits that now can be more easily implemented in single-supply-voltage systems. For
example, the LM124 can be operated directly from the standard 5-V supply that is used in digital systems and
provides the required interface electronics, without requiring additional ±15-V supplies.
