AccuPro 1-Button Dispenser (model #39331) Instruction Guide

AccuPro 1-Button Dispenser (model #39331) Instruction Guide
Troubleshooting Chart:
Problem
Cause
Solution
1. No discharge
a. No water
b. Magnetic valve not functioning
d. Eductor clogged
e. Clogged water inlet strainer
a.
b.
d.
e.
a. Clogged foot valve
b. Metering tip or eductor has
scale build-up
c. Low water pressure
a. Clean or replace
b. Clean (descale)* or replace
2. No concentrate draw
d. Discharge tube and/or flooding
ring not in place
e. Concentrate container empty
f. Inlet hose barb not screwed
into eductor tightly
g. Clogged water inlet strainer
h. Air leak in chemical pick-up tube
3. Excess concentrate draw
a. Metering tip not in place
b. Chemical above eductor
4. Failure of unit to turn off
5. Excess foaming in discharge
a. Water valve parts dirty or
defective
b. Magnet doesn't fully return
c. Push button stuck
a. Air leak in pick-up tube
Open water supply
Install valve parts kit
Clean* or replace
Disconnect inlet water line and clean
strainer
c. Minimum 25 PSI (with water running)
required to operate unit properly
d. Push tube firmly onto eductor discharge
hose barb, or replace tube if it doesn't
have a flooding ring.
e. Replace with full container
f. Tighten, but do not overtighten
g. Disconnect inlet water line and clean
strainer
h. Put clamp on tube or replace tube if brittle
a. Press correct tip firmly into barb on
eductor
b. Place concentrate below the eductor
Proportioner
with E-Gap Eductor
Package Should Contain:
1. P roportioner unit.
2. Supply tubing.
3. Foot valve assembly & weight for each eductor.
1,2,
4. D ischarge tube for each eductor.
5. Metering tip kit(s).
6. Mounting bracket & anchor kit.
7. Hook(s) for discharge tube(s) -- Models with high ow eductors only.
8. I nstruction sheet.
THANK YOU FOR YOUR INTEREST IN OUR PRODUCTS
Hydro Systems manufactures quality chemical proportioning equiment. Please use this equipment
carefully and observe all warnings and cautions.
********************************************************* NOTE*********************************************
WEAR
protective clothing and eyewear when dispensing chemicals or other materials.
ALWAYS
observe safety and handling instructions of the chemical manufacturers.
ALWAYS
direct discharge away from you or other persons or into approved containers.
ALWAYS
dispense cleaners and chemicals in accordance with manufacturer's instructions. Exercise
CAUTION when maintaining your equipment.
KEEP
WEAR
equipment clean to maintain proper operation.
ALWAYS
re-assemble equipment according to instruction procedures. Be sure all components are
rmly screwed or latched into position.
ATTACH
only to tap water outlets (85 PSI maximum).
NOTE
If the unit is used to ll a sink or the discharge hose can be placed into a sink, the unit must
be mounted so that the bottom of the cabinet is above the over ow rim of the sink.
a. Clean* or replace with valve parts kit
b. Make sure magnet moves freely.
c. Remove button and clean cabinet/button
to remove any dirt lodged in slide recess
a. Put clamp on tube or replace tube if brittle
* In hard water areas, scale may form inside the discharge end of the eductor, as well as in other areas of the unit that
are exposed to water. This scale may be removed by soaking the eductor in a descaling solution (deliming solution).
To remove an eductor located in the cabinet, firmly grasp water valve and unthread eductor. Replace in same manner.
Alternatively, a scaled eductor can be cleaned (or kept from scaling) by drawing the descaling solution through the unit.
Operate the unit with the suction tube in the descaling solution. Operate the unit until solution is drawn consistently, then
flush the unit by drawing clear water through it for a minute. Replace concentrate container and put suction tube into
concentrate.
3798 Round Bottom Road, Cincinnati, OH 45244 U.S.A. • Phone: (513) 271-8800 • Fax: (513) 271-0160 • www.hydrosystemsco.com
10093951
4/09
& 3 Button Units
protective clothing and eyewear when working in the vicinity of all chemicals, lling or emptying equipment or changing metering tips.
Installation and Operation:
1. Find suitable place close to water source for unit. Mounting bracket should be installed approx. 5' from oor. Level bracket
& mark holes. Drill 9/32" holes & install mounting anchors and screws in bracket. Drill holes for the three wall anchors with
a 5/16" drill bit, using the cabinet back as a template for proper spacing of the mounting screws. Install mounting anchors,
and then screws in top two anchors. Slide key holes in cabinet back over screw heads, tighten screws, then install bottom
screw. Do not mount more than 6 feet (1.8 meters) above the bottom of the concentrate container, nor below the highest
concentrate level (never mount your concentrate higher than the proportioner).
2. Hang cabinet on bracket. Mark hole for lower cabinet screw. Remove cabinet & drill 9/32" hole. Install anchor and
screw to lower unit hole. When mounting unit do not mount any higher than 5 feet from the oor. Also, never mount your
concentrate container higher than the unit.
3. Select a metering tip, and insert into hose barb on eductor body. (Repeat for all eductors.)
4. Cut supply tubing provided into separate supply tubes for each product to be dispensed. Supply tubes should reach from
hose barb on eductor to bottom of the concentrate container. Slide a ceramic weight over one end of tube and slide a foot
valve into the same end of the tube. (Prepare a tube for each eductor.)
5. Slip other end of supply tube through an opening in either side of the cabinet and push over the hose barb/metering tip
on the eductor. (Repeat for all eductors.)
6. Place foot valve ends of supply tubes into concentrate containers. REMEMBER TO CHECK FOOT VALVE STRAINERS
PERIODICALLY FOR CLOGGING: CLEAN IF NECESSARY.
7. A short discharge tube is used with the 1GPM eductor; minumum tube length is 8 inches (20cm) for proper operation.
Longer tubes (4 feet) are used with a 3.5 GPM eductor. Do not remove the ooding rings from inside the tubes. Slide
end of tube with ooding ring over eductor discharge outlet. (Repeat for all eductors.) Hooks may be installed on longer
tubes to allow discharge tube to conveniently hang from dispenser when not in use.
8. Replace cabinet cover. Hook two bottom catches, and swing up to snap onto latch. A
Clip or bend
screw provided may be installed in the hole on top to prevent easy removal of cover.
these tabs
9. Connect water supply hose of at least 3/8" ID to water inlet swivel. (Minimum 25 PSI
to depress
pressure, with water running, is required for proper operation.) Connect opposite end of button into
hose to water supply. Turn water supply on.
locked
10. Push button to start ow of desired water/concentrate solution, and hold until supply
position.
tube is primed ( lled). Then push the button whenever dispensing is desired, and
release button to stop ow of solution. If you wish to be able to lock the button in the
"on" position: clip or bend the two tabs behind the lower front portion of the button (see
diagram). This allows the button to be fully depressed and allows it to latch in the "on"
position. To unlock, pull the button out.
Metering Tip Selection:
The final concentration of the dispensed
solution is related to both the size of the
metering tip opening and the viscosity of
the liquid being siphoned. For water-thin
products, the chart at right can be used
as a guideline. If product is noticeably
thicker than water, consult the Measurement of Concentration Procedure below
to achieve your desired water-to-product
ratio. Because dilution can vary with water
temperature and pressure, actual dilution
achieved can only be ascertained by using
the Measurement of Concentration Procedure. The clear, undrilled tip is provided
to permit drilling to size not listed should
you need a dilution ratio that falls between
standard tip sizes.
Tip
Color
APPROXIMATE DILUTIONS
AT 40 PSI FOR WATER-THIN PRODUCTS (1.0 CP)
Orifice
Std. Drill
Ratio (per Eductor Flow)
Size
Number 1 GPM
3.5 GPM
5.0 GPM
No Tip
Grey
Black
Beige
Red
White
Blue
Tan
Green
Orange
Brown
Yellow
Aqua
Purple
Pink
.187
.128
.098
.070
.052
.043
.040
.035
.028
.025
.023
.020
.018
.014
.010
(3/16)
(30)
(40)
(50)
(55)
(57)
(60)
(65)
(70)
(72)
(74)
(76)
(77)
(79)
(87)
2.6:1
2.6:1
2.5:1
3:1
5:1
7:1
9:1
11:1
17:1
19:1
22:1
32:1
39:1
64:1
128:1
4:1
4:1
5:1
8:1
13:1
22:1
26:1
34:1
52:1
64:1
71:1
102:1
128:1
213:1
447:1
7:1
7:1
8:1
12:1
19:1
30:1
35:1
44:1
70:1
86:1
99:1
128:1
158:1
271:1
523:1
NOTE: A 1 GPM eductor is grey; a 3.5
GPM eductor is yellow. Refer to parts
diagram if unfamiliar with names of system
components.
Measurement of Concentration:
You can determine the dispensed waterto-product ratio for any metering tip size
and product viscosity. All that is required
is to operate the primed dispenser for a minute or so and note two things: the amount of dispensed solution, and the amount of
concentrate used in preparation of the solution dispensed. The water-to-product ratio is then calculated as follows:
Dilution Ratio (X:1) where X = Amount of Mixed Solution — Amount of Concentrate Drawn
Amount of Concentrate Drawn
Dilution Ratio, then, equals X parts water to one part concentrate (X:1). If the test does not yield the desired ratio, choose a different
tip and repeat the test. Alternative methods to this test are 1) pH (using litmus paper), and 2) titration. Contact your concentrate
supplier for further information on these alternative methods and the materials required to perform them.
AccuPro Parts Diagram/List:
9
a
b
c
d
10
12a,b,c
Key
13
15
16
1
2
3
4
6
6
7
8
9
17
3
2
1
18
5
4
19
Part No. Description
238100
10082830
10082801
10082821
10082840
10091035
10093710
10093991
10093992
10093993
10075980
14a,b
AccuPro Parts Diagram:
11
10
11
12a
b
c
13
14 a
b
15
16
17
18
6
19*
Valve parts kit
a. diaphragm
b. armature
c. spring
d. valve bonnet
10079010 Spring
10079000 Magnet
290
1 GPM eductor assembly
291
3.5 GPM eductor assembly
296
5.0 GPM eductor assembly
3401-R
Hose barb assembly*
Included in eductor assembly's
10088822 1 GPM discharge tube
with flooding ring (8")
90048495 3.5 GPM discharge tube
with flooding ring (4')
690014
Metering tip, kit
500870
Tubing 1/4" x 7'
509900
Weight
10089410 Footvalve --Vtion (EPDM also
available. Order 10076302.)
10080730 Hose hook, dark grey (standard)
10080731 Hose hook, sky blue
10080732 Hose hook, red
10080733 Hose hook, green
10080734 Hose hook, light grey
10080735 Hose hook, yellow
* Hose hooks are for high flow discharge tubes
NOT SHOWN:
641751
7
8
Strainer washer
Swivel collar (molded)
Swivel stem (molded)
Connector fitting
Connector fitting cap
Wall bracket
Button, dark grey
Cabinet set, 1-button unit
Cabinet set, 2-button unit
Security screw (for cabinet top)
