19-2224; Rev 3; 12/03

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

General Description

The MAX1901/MAX1902/MAX1904 are buck-topology, step-down, switch-mode, power-supply controllers that generate logic-supply voltages in battery-powered systems. These high-performance, dual/triple-output devices include on-board power-up sequencing, power-good signaling with delay, digital soft-start, secondary winding control, low dropout circuitry, internal frequency-compensation networks, and automatic bootstrapping.

Up to 97% efficiency is achieved through synchronous rectification and Maxim’s proprietary Idle Mode™ control scheme. Efficiency is greater than 80% over a 1000:1 load-current range, which extends battery life in system suspend or standby mode. Excellent dynamic response corrects output load transients within five clock cycles.

Strong 1A on-board gate drivers ensure fast external Nchannel MOSFET switching.

These devices feature a logic-controlled and synchronizable, fixed-frequency, pulse-width modulation (PWM) operating mode. This reduces noise and RF interference in sensitive mobile communications and pen-entry applications. Asserting the SKIP pin enables fixed-frequency mode, for lowest noise under all load conditions.

The MAX1901/MAX1902/MAX1904 include two PWM regulators, adjustable from 2.5V to 5.5V with fixed 5.0V and

3.3V modes. All these devices include secondary feedback regulation, and the MAX1902 contains a 12V/120mA linear regulator. The MAX1901/MAX1904 include a secondary feedback input (SECFB), plus a control pin

(STEER) that selects which PWM (3.3V or 5V) receives the secondary feedback signal. SECFB provides a method for adjusting the secondary winding voltage regulation point with an external resistor divider, and is intended to aid in creating auxiliary voltages other than fixed 12V.

The MAX1901/MAX1902 contain internal output overvoltage and undervoltage protection features.

________________________Applications

Notebook and Subnotebook Computers

PDAs and Mobile Communicators

Desktop CPU Local DC-DC Converters

Features

97% Efficiency

4.2V to 30V Input Range

2.5V to 5.5V Dual Adjustable Outputs

Selectable 3.3V and 5V Fixed or Adjustable

Outputs (Dual Mode™)

12V Linear Regulator

Adjustable Secondary Feedback

(MAX1901/MAX1904)

5V/50mA Linear Regulator Output

Precision 2.5V Reference Output

Programmable Power-Up Sequencing

Power-Good (RESET) Output

Output Overvoltage Protection

(MAX1901/MAX1902)

Output Undervoltage Shutdown

(MAX1901/MAX1902)

333kHz/500kHz Low-Noise, Fixed-Frequency

Operation

Low-Dropout, 98% Duty-Factor Operation

2.5mW Typical Quiescent Power (12V input, both

SMPSs on)

4µA Typical Shutdown Current

Ordering Information

PART

MAX1901EAI

MAX1901ETJ

MAX1902EAI

MAX1902ETJ

MAX1904EAI

MAX1904ETJ

TEMP RANGE PIN-PACKAGE

-40

°C to +85°C

28 SSOP

-40

°C to +85°C

32 Thin QFN 5m m x 5m m

-40

°C to +85°C

28 SSOP

-40

°C to +85°C

32 Thin QFN 5m m x 5m m

-40

°C to +85°C

28 SSOP

-40

°C to +85°C

32 Thin QFN 5m m x 5m m

Functional Diagram

INPUT

5V (RTC)

12V

5V

LINEAR

12V

LINEAR

3.3V

5V

3.3V

SMPS

5V

SMPS

Idle Mode is a trademark of Maxim Integrated Products, Inc.

Dual Mode is a trademark of Maxim Integrated Products, Inc.

Pin Configurations appear at end of data sheet.

ON/OFF POWER-UP

SEQUENCE

POWER-

GOOD

RESET

________________________________________________________________ Maxim Integrated Products 1

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at

1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

ABSOLUTE MAXIMUM RATINGS

V+ to GND ..............................................................-0.3V to +36V

PGND to GND.....................................................................±0.3V

V

L to GND ................................................................-0.3V to +6V

BST3, BST5 to GND ..............................................-0.3V to +36V

CSH3, CSH5 to GND................................................-0.3V to +6V

FB3 to GND ..............................................-0.3V to (CSL3 + 0.3V)

FB5 to GND ...............................................-0.3V to (CSL5 +0.3V)

LX3 to BST3..............................................................-6V to +0.3V

LX5 to BST5..............................................................-6V to +0.3V

REF, SYNC, SEQ, STEER, SKIP,

TIME/ON5, SECFB, RESET to GND ........-0.3V to (V

L

+ 0.3V)

V

DD to GND. ...........................................................-0.3V to +20V

RUN/ON3, SHDN to GND.............................-0.3V to (V+ + 0.3V)

12OUT to GND ..........................................-0.3V to (V

DD

+ 0.3V)

DL3, DL5 to PGND. .......................................-0.3V to (V

L

+ 0.3V)

DH3 to LX3 ..............................................-0.3V to (BST3 + 0.3V)

DH5 to LX5 ..............................................-0.3V to (BST5 + 0.3V)

V

L

, REF Short to GND ................................................Momentary

12OUT Short to GND..................................................Continuous

REF Current...........................................................+5mA to -1mA

V

L

Current. ........................................................................+50mA

12OUT Current . .............................................................+200mA

V

DD

Shunt Current. ...........................................................+15mA

Continuous Power Dissipation (T

A

= +70°C)

28-Pin SSOP (derate 9.52mW/°C above +70°C) ......762mW

32-Pin Thin QFN (derate 21.3mW/°C above +70°C) ..1702mW

Operating Temperature Range ...........................-40°C to +85°C

Storage Temperature Range ............................-65°C to +160°C

Lead Temperature (soldering, 10s) ................................+300°C

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.

ELECTRICAL CHARACTERISTICS

(V+ = 15V, both PWMs on, SYNC = V

L

, V

L load = 0, REF load = 0, SKIP = 0, T

A

= 0°C to +85°C, unless otherwise noted. Typical values are at T

A

= +25°C.)

CONDITIONS MIN TYP MAX UNITS PARAMETER

MAIN SMPS CONTROLLERS

Input Voltage Range 4.2

30.0

V

3V Output Voltage in Adjustable Mode

3V Output Voltage in Fixed Mode

5V Output Voltage in Adjustable Mode

5V Output Voltage in Fixed Mode

Output Voltage Adjust Range

Adjustable-Mode Threshold Voltage

Load Regulation

Line Regulation

Current-Limit Threshold

Idle Mode Threshold

Soft-Start Ramp Time

Oscillator Frequency

V+ = 4.2V to 30V, CSH3 - CSL3 = 0,

CSL3 tied to FB3

V+ = 4.2V to 30V, 0 < CSH3 - CSL3

< 80mV, FB3 = 0

V+ = 4.2V to 30V, CSH5 - CSL5 = 0,

CSL5 tied to FB5

V+ = 5.3V to 30V, 0 < CSH5 - CSL5

< 80mV, FB5 = 0

Either SMPS

Dual-mode comparator

Either SMPS, 0 < CSH_ - CSL_ < 80mV

Either SMPS, 5.2V < V+ < 30V

CSH3 - CSL3 or CSH5 - CSL5

SKIP = V

L

or V

DD

< 13V or SECFB < 2.44V

SKIP = 0, not tested

From enable to 95% full current limit with respect to f

OSC

(Note 1)

SYNC = V

L

SYNC = 0

2.42

3.20

2.42

4.85

REF

0.5

80

-50

10

450

283

2.5

3.39

2.5

5.13

-2

0.03

100

-100

25

512

500

333

2.58

3.47

2.58

5.25

5.5

1.1

120

-150

40

550

383

V

V

V

V

V

V

%

%/V mV mV clks kHz

2 _______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

ELECTRICAL CHARACTERISTICS (continued)

(V+ = 15V, both PWMs on, SYNC = V

L

, V

L load = 0, REF load = 0, SKIP = 0, T

A

= 0°C to +85°C, unless otherwise noted. Typical values are at T

A

= +25°C.)

MAX UNITS PARAMETER

Maximum Duty Factor

SYNC Input High-Pulse Width

SYNC Input Low-Pulse Width

SYNC Rise/Fall Time

SYNC Input Frequency Range

CONDITIONS

SYNC = V

L

SYNC = 0 (Note 2)

Not tested

Not tested

Not tested

Current-Sense Input Leakage Current

V+ = V

L

= 0,

CSL3 = CSH3 = CSL5 = CSH5 = 5.5V

FLYBACK CONTROLLER

V

DD

Regulation Threshold

SECFB Regulation Threshold

DL Pulse Width

V

DD

Shunt Threshold

V

DD

Shunt Sink Current

V

DD

Leakage Current

12V LINEAR REGULATOR (Note 3)

12OUT Output Voltage

12OUT Current Limit

Quiescent V

DD

Current

INTERNAL REGULATOR AND REFERENCE

Falling edge (Note 3)

Falling edge (MAX1901/MAX1904)

V

DD

< 13V or SECFB < 2.44V

Rising edge, hysteresis = 1% (Note 3)

V

DD

= 20V (Note 3)

V

DD

= 5V, off mode (Notes 3, 4)

13V < V

DD

< 18V, 0 < I

LOAD

< 120mA

12OUT forced to 11V, V

DD

= 13V

V

DD

= 18V, run mode, no 12OUT load

V

V

L

L

V

L

Output Voltage

Undervoltage Lockout-Fault Threshold

Switchover Threshold

REF Output Voltage

REF Load Regulation

SHDN = V+, RUN/ON3 = TIME/ON5 = 0,

5.4V < V+ < 30V, 0mA < I

LOAD

< 50mA

Falling edge, hysteresis = 1%

Rising edge of CSL5, hysteresis = 1%

No external load (Note 5)

0 < I

LOAD

< 50µA

0 < I

LOAD

< 5mA

REF Sink Current

REF Fault-Lockout Voltage

V+ Operating Supply Current

V+ Standby Supply Current

V+ Standby Supply Current in Dropout

V+ Shutdown Supply Current

Falling edge

V

L

switched over to CSL5, 5V SMPS on

V+ = 5.5V to 30V, both SMPSs off, includes current into

SHDN

V+ = 4.2V to 5.5V, both SMPSs off, includes current into

SHDN

V+ = 4.0V to 30V,

SHDN = 0

MIN

95

96.5

200

200

400

13

2.44

18

10

11.65

4.7

3.5

4.2

2.45

10

1.8

TYP

97

98

0.01

0.75

200

583

10

14

2.60

20

30

12.10

12.50

150

50 100

3.6

4.5

2.5

5

30

50

4

5.1

3.7

4.7

2.55

12.5

100.0

2.4

50

60

200

10

%

V

V

µs

V mA

µA ns ns ns kHz

µA

V mA

µA

V

µA

V

µA

V

V

V mV

µA

µA

µA

Quiescent Power Consumption

Both SMPSs enabled,

FB3 = FB5 = 0,

CSL3 = CSH3 = 3.5V,

CSL5 = CSH5 = 5.3V

(Note 3)

MAX1901/MAX1904

2.5

1.5

4

4 mW

_______________________________________________________________________________________ 3

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

ELECTRICAL CHARACTERISTICS (continued)

(V+ = 15V, both PWMs on, SYNC = V

L

, V

L load = 0, REF load = 0, SKIP = 0, T

A

= 0°C to +85°C, unless otherwise noted. Typical values are at T

A

= +25°C.)

CONDITIONS MIN TYP MAX UNITS PARAMETER

FAULT DETECTION (MAX1901/MAX1902)

Overvoltage Trip Threshold 4 7 10 %

Overvoltage Fault Propagation Delay

Output Undervoltage Threshold

Output Undervoltage Lockout Time

Thermal-Shutdown Threshold

RESET

With respect to unloaded output voltage

CSL_ driven 2% above overvoltage trip threshold

With respect to unloaded output voltage

From each SMPS enabled, with respect to f

OSC

Typical hysteresis = 10°C

60

1.5

70

5,000 6,144 7,000

150

80

µs

% clks

°C

RESET Trip Threshold

RESET Propagation Delay

With respect to unloaded output voltage, falling edge; typical hysteresis = 1%

Falling edge, CSL_ driven 2% below

RESET trip threshold

With respect to f

OSC

-7 -5.5

1.5

-4

27,000 32,000 37,000

%

µs clks

RESET Delay Time

INPUTS AND OUTPUTS

Feedback-Input Leakage Current 1 50 nA

Logic Input-Low Voltage

Logic Input-High Voltage

Input Leakage Current

Logic Output-Low Voltage

Logic Output-High Current

TIME/ON5 Input Trip Level

TIME/ON5 Source Current

TIME/ON5 On-Resistance

Gate-Driver Sink/Source Current

Gate-Driver On-Resistance

FB3, FB5; SECFB = 2.6V

RUN/ON3,

SKIP, TIME/ON5 (SEQ = REF),

SHDN, STEER, SYNC

RUN/ON3,

SKIP, TIME/ON5 (SEQ = REF),

SHDN, STEER, SYNC

RUN/ON3,

SKIP, TIME/ON5 (SEQ = REF),

SHDN, STEER, SYNC, SEQ; V

PIN

= 0V or 3.3V

RESET, I

SINK

= 4mA

RESET = 3.5V

SEQ = 0 or V

L

TIME/ON5 = 0, SEQ = 0 or V

L

TIME/ON5; RUN/ON3 = 0, SEQ = 0 or V

L

DL3, DH3, DL5, DH5; forced to 2V

SSOP package

High or low (Note 6)

QFN package

2.4

1

2.4

2.5

3

15

1

1.5

1.5

0.6

±1

0.4

2.6

3.5

80

7

8

V

V

µA

V mA

V

µA

A

4 _______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

ELECTRICAL CHARACTERISTICS

(V+ = 15V, both PWMs on, SYNC = V

L

, V

L load = 0, REF load = 0, SKIP = 0, T

A

= -40°C to +85°C, unless otherwise noted.) (Note 7)

MIN TYP MAX UNITS PARAMETER

MAIN SMPS CONTROLLERS

Input Voltage Range

CONDITIONS

3V Output Voltage in Adjustable Mode

3V Output Voltage in Fixed Mode

5V Output Voltage in Adjustable Mode

5V Output Voltage in Fixed Mode

Output Voltage Adjust Range

Adjustable-Mode Threshold Voltage

Current-Limit Threshold

Oscillator Frequency

Maximum Duty Factor

V

V

V

L

L

L

Output Voltage

Undervoltage Lockout-Fault Threshold

Switchover Threshold

REF Output Voltage

REF Load Regulation

V+ = 4.2V to 30V, CSH3 - CSL3 = 0,

CSL3 tied to FB3

V+ = 4.2V to 30V, 0 < CSH3 - CSL3

< 80mV, FB3 = 0

V+ = 4.2V to 30V, CSH5 - CSL5 = 0,

CSL5 tied to FB5

V+ = 5.3V to 30V, 0 < CSH5 - CSL5

< 80mV, FB5 = 0

Either SMPS

Dual-mode comparator

CSH3 - CSL3 or CSH5 - CSL5

SKIP = V

L

or V

DD

< 13V or SECFB < 2.44V

SYNC = V

L

SYNC = 0

SYNC = V

L

SYNC = 0 (Note 2)

SYNC Input Frequency Range

FLYBACK CONTROLLER

V

DD

Regulation Threshold

SECFB Regulation Threshold

V

DD

Shunt Threshold

V

DD

Shunt Sink Current

12V LINEAR REGULATOR (Note 3)

12OUT Output Voltage

Quiescent V

DD

Current

INTERNAL REGULATOR AND REFERENCE

Falling edge (Note 3)

Falling edge (MAX1901/MAX1904)

Rising edge, hysteresis = 1% (Note 3)

V

DD

= 20V (Note 3)

13V < V

DD

< 18V, 0mA < I

LOAD

< 100mA

V

DD

= 18V, run mode, no 12OUT load

SHDN = V+, RUN/ON3 = TIME/ON5 = 0,

5.4V < V+ < 30V, 0 < I

LOAD

< 50mA

Falling edge, hysteresis = 1%

Rising edge of CSL5, hysteresis = 1%

No external load (Note 5)

0 < I

LOAD

< 50µA

0 < I

LOAD

< 5mA

REF Sink Current

REF Fault Lockout Voltage

V+ Operating Supply Current

Falling edge

V

L

switched over to CSL5, 5V SMPS on

4.2

2.42

3.20

2.42

4.85

REF

0.5

80

-50

450

283

95

97

400

13

2.44

18

10

11.65

4.7

3.5

4.2

2.45

10

1.8

30.0

2.58

3.47

2.58

5.1

3.7

4.7

2.55

12.5

100.0

5.25

5.5

1.1

120

-150

550

383

583

14

2.60

20

12.50

100

2.4

50

V

V

V

V kHz

% kHz

V

V

V mA

V

µA

V

V

V mV

V

V

V

V mV

µA

V

µA

_______________________________________________________________________________________ 5

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

ELECTRICAL CHARACTERISTICS (continued)

(V+ = 15V, both PWMs on, SYNC = V

L

, V

L load = 0, REF load = 0, SKIP = 0, T

A

= -40°C to +85°C, unless otherwise noted.) (Note 7)

PARAMETER

V+ Standby Supply Current

V+ Standby Supply Current in Dropout

V+ Shutdown Supply Current

Quiescent Power Consumption

CONDITIONS

V+ = 5.5V to 30V, both SMPSs off, includes current into

SHDN

V+ = 4.2V to 5.5V, both SMPSs off, includes current into

SHDN

V+ = 4.0V to 30V,

SHDN = 0

Both SMPSs enabled,

FB3 = FB5 = 0,

CSL3 = CSH3 = 3.5V,

CSL5 = CSH5 = 5.3V

(Note 3)

MAX1901/MAX1904

MIN TYP MAX

60

200

10

4

4

UNITS

µA

µA

µA mW

FAULT DETECTION (MAX1901/MAX1902)

Overvoltage Trip Threshold

Output Undervoltage Threshold

With respect to unloaded output voltage

With respect to unloaded output voltage

4

60

10

80

%

%

Output Undervoltage Lockout Time

From each SMPS enabled, with respect to f

OSC

5,000 7,000 clks

RESET

RESET Trip Threshold

With respect to unloaded output voltage, falling edge; typical hysteresis = 1%

-7 -4

% clks

RESET Delay Time

INPUTS AND OUTPUTS

Feedback-Input Leakage Current

With respect to f

OSC

27,000 37,000

Logic Input-Low Voltage

FB3, FB5; SECFB = 2.6V

RUN/ON3,

SKIP, TIME/ON5 (SEQ = REF),

SHDN, STEER, SYNC

50

0.6

nA

V

Logic Input-High Voltage

Logic Output-Low Voltage

Logic Output-High Current

RUN/ON3,

SKIP, TIME/ON5 (SEQ = REF),

SHDN, STEER, SYNC

RESET, I

SINK

= 4mA

RESET = 3.5V

2.4

1

0.4

V

V mA

TIME/ON5 Input Trip Level

TIME/ON5 Source Current

TIME/ON5 On-Resistance

Gate-Driver On-Resistance

SEQ = 0 or V

L

TIME/ON5 = 0, SEQ = 0 or V

L

TIME/ON5; RUN/ON3 = 0, SEQ = 0 or V

L

SSOP package

High or low (Note 6)

QFN package

2.4

2.5

2.6

3.5

80

7

V

µA

8

Note 1: Each of the four digital soft-start levels is tested for functionality; the steps are typically in 20mV increments.

Note 2: High duty-factor operation supports low input-to-output differential voltages, and is achieved at a lowered operating frequency

(see the Dropout Operation section).

Note 3: MAX1902 only.

Note 4: Off mode for the 12V linear regulator occurs when the SMPS that has flyback feedback (V

DD

) steered to it is disabled. In situations where the main outputs are being held up by external keep-alive supplies, turning off the 12OUT regulator prevents a leakage path from the output-referred flyback winding, through the rectifier, and into V

DD

.

Note 5: Since the reference uses V

L as its supply, the reference’s V+ line-regulation error is insignificant.

Note 6: Production testing limitations due to package handing require relaxed maximum on-resistance specifications for the thin

QFN package. The SSOP and thin QFN package contain the same die, and the thin QFN package imposes no additional resistance incircuit.

Note 7: Specifications from to 0°C to -40°C are guaranteed by design, not production tested.

6 _______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Typical Operating Characteristics

(Circuit of Figure 1, Table 1, 6A/500kHz components, T

A

= +25°C, unless otherwise noted.)

EFFICIENCY vs. 5V OUTPUT CURRENT

100

95

90

85

80

75

70

65

60

55

50

0.001

V+ = 6V

V+ = 15V

ON5 = 5V

ON3 = 0V f = 500kHz

MAX1901/MAX1904

0.01

0.1

1

5V OUTPUT CURRENT (A)

10

NO LOAD INPUT CURRENT vs. INPUT VOLTAGE

100

SKIP = V

L

EFFICIENCY vs. 3.3V OUTPUT CURRENT

100

95

90

85

80

75

70

65

60

55

50

0.001

V+ = 6V

V+ = 15V

ON5 = ON3 = 5V f = 500kHz

MAX1901/MAX1904

0.01

0.1

1

3.3V OUTPUT CURRENT (A)

10

V+ STANDBY INPUT CURRENT vs. INPUT VOLTAGE

10,000

800

600

400

200

MAXIMUM V

DD

OUTPUT CURRENT vs. INPUT VOLTAGE

5V LOAD = 0

5V LOAD = 3A

0

0 5 10

INPUT VOLTAGE (V)

15

SHUTDOWN INPUT CURRENT vs. INPUT VOLTAGE

10

SHDN = 0V

8

20

10 1000

6

1

SKIP = 0V

0.1

0.01

0 5 10 15

ON5 = ON3 = 5V

NO LOAD

20

INPUT VOLTAGE (V)

25 30

1000

MINIMUM V

IN

TO V

OUT

DIFFERENTIAL vs. 5V OUTPUT CURRENT

MAX1901 toc07

100

10

0.001

100

10

1

0

1000

5 10 15

ON5 = ON3 = 0V

NO LOAD

20

INPUT VOLTAGE (V)

25 30

SWITCHING FREQUENCY vs. LOAD CURRENT

3.3V, V

IN

= 15V

4

2

0

0 5 10 15 20

INPUT VOLTAGE (V)

25

V

L

REGULATOR OUTPUT VOLTAGE vs. OUTPUT CURRENT

30

5.00

V

IN

= 15V

ON3 = ON5 = 0V

4.98

100 f = 500kHz f = 333kHz

5V, V

IN

= 15V

4.96

10

3.3V, V

IN

= 6.5V

5V, V

IN

= 6.5V

4.94

V

OUT

> 4.8V

0.01

0.1

1

5V OUTPUT CURRENT (A)

10

1

0.1

0.001

0.01

0.1

LOAD CURRENT (A)

1 10

4.92

4.90

0 10 20 30

OUTPUT CURRENT (mA)

40 50

_______________________________________________________________________________________

7

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Typical Operating Characteristics (continued)

(Circuit of Figure 1, Table 1, 6A/500kHz components, T

A

= +25°C, unless otherwise noted.)

2.505

REF OUTPUT VOLTAGE vs. OUTPUT CURRENT

V

IN

= 15V

ON3 = ON5 = 0

STARTUP WAVEFORMS

MAX1901 toc11

2.500

2.495

2.490

0

0

0

0

RUN

5V/div

3.3V OUTPUT

2V/div

TIME

2V/div

5V OUTPUT

5V/div

2.485

0 1 2 3 4

OUTPUT CURRENT (mA)

5 6

SEQ = V

L

2ms/div

, O.O1

µF CAPACITOR ON TIME

5V LOAD TRANSIENT RESPONSE

MAX1901 toc12

3.3V LOAD TRANSIENT RESPONSE

MAX1901 toc13

10V

0

5A

0

V

IN

= 8V, I

OUT

20

µs/div

= 1A TO 5A

5V OUTPUT

5OmV/div

AC-COUPLED

V

LX5

10V/div

I

LX5

5A/div

10V

0

5A

0

V

IN

= 8V, I

20

µs/div

OUT

= 1A TO 5A

3.3V OUTPUT

5OmV/div

AC-COUPLED

V

LX3

10V/div

I

LX3

5A/div

8 _______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

SSOP

1

2

PIN

QFN

29

30

3

4

5

6

7

8

9

10

11

12

13

14

31

1

2

3

4

5

7

8

9

10

11

12

Pin Description

NAME

CSH3

CSL3

FB3

12OUT

(MAX1902)

STEER

(MAX1901/

MAX1904)

V

DD

(MAX1902)

SECFB

(MAX1901/

MAX1904)

SYNC

TIME/ON5

GND

REF

SKIP

RESET

FB5

CSL5

CSH5

FUNCTION

Current-Sense Input for the 3.3V SMPS. Current-limit level is 100mV referred to CSL3.

Current-Sense Input. Also serves as the feedback input in fixed-output mode.

Feedback Input for the 3.3V SMPS. Regulates at FB3 = REF (approx. 2.5V) in adjustable mode. FB3 is a dual-mode input that also selects the 3.3V fixed output voltage setting when connected to GND. Connect FB3 to a resistor-divider for adjustable-output mode.

12V/120mA Linear-Regulator Output. Input supply comes from V

DD

. Bypass 12OUT to

GND with 1µF (min).

Logic-Control Input for Secondary Feedback. Selects the PWM that uses a transformer and secondary feedback signal (SECFB):

STEER = GND: 3.3V SMPS uses transformer

STEER = V

L

: 5V SMPS uses transformer

Supply Voltage Input for the 12OUT Linear Regulator. Also connects to an internal resistor-divider for secondary winding feedback and to an 18V overvoltage shunt regulator clamp.

Secondary Winding Feedback Input. Normally connected to a resistor-divider from an auxiliary output. SECFB regulates at V

SECFB

= 2.5V (see the Secondary Feedback

Regulation Loop section). Connect to V

L

if not used.

Oscillator Synchronization and Frequency Select. Connect to V

L

for 500kHz operation; connect to GND for 333kHz operation. Can be driven at 400kHz to 583kHz for external synchronization.

Dual-Purpose Timing Capacitor Pin and ON/

OFF Control Input. See the Power-Up

Sequencing and ON/

OFF Controls section.

Low-Noise Analog Ground and Feedback Reference Point

2.5V Reference Voltage Output. Bypass to GND with 1µF (min).

Log i c- contr ol i np ut that d i sab l es i d l e m od e w hen hi g h. C onnect to GN D for nor m al use.

Active-Low Timed Reset Output.

RESET swings GND to V

L

. Goes high after a fixed

32,000 clock-cycle delay following power-up.

Feedback Input for the 5V SMPS. Regulates at FB5 = REF (approx. 2.5V) in adjustable mode. FB5 is a dual-mode input that also selects the 5V fixed output voltage setting when connected to GND. Connect FB5 to a resistor-divider for adjustable-output mode.

C ur r ent- S ense Inp ut for the 5V S M P S . Al so ser ves as the feed b ack i np ut i n fi xed - outp ut m od e, and as the b ootstr ap sup p l y i np ut w hen the vol tag e on C S L5/V

L

i s > 4.5V .

Current-Sense Input for the 5V SMPS. Current-limit level is 100mV referred to CSL5.

_______________________________________________________________________________________ 9

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Pin Description (continued)

QSOP

PIN

QFN

NAME

15

16

17

18

19

20

21

22

23

24

25

26

27

28

13

14

15

17

18

19

20

21

22

23

24

26

27

28

6, 16, 25, 32

SEQ

DH5

LX5

BST5

DL5

PGND

VL

V+

SHDN

DL3

BST3

LX3

DH3

RUN/ON3

N.C.

FUNCTION

Pin-strap input that selects the SMPS power-up sequence:

SEQ = GND: 5V before 3.3V,

RESET output determined by both outputs

SEQ = REF: Separate ON3/ON5 controls,

RESET output determined by 3.3V output

SEQ = V

L

: 3.3V before 5V,

RESET output determined by both outputs

Gate-Drive Output for the 5V, High-Side N-Channel Switch. DH5 is a floating driver output that swings from LX5 to BST5, riding on the LX5 switching node voltage.

Switching-Node (Inductor) Connection. Can swing 2V below ground without hazard.

Boost Capacitor Connection for High-Side Gate Drive (0.1µF)

Gate-Drive Output for the Low-Side Synchronous-Rectifier MOSFET. Swings 0 to V

L

.

Power Ground

5V Internal Linear-Regulator Output. V

L

is also the supply-voltage rail for the chip.

After the 5V SMPS output has reached 4.5V (typ), V

L

automatically switches to the output voltage through CSL5 for bootstrapping. Bypass to GND with 4.7µF. V

L supplies up to 25mA for external loads.

Battery Voltage Input, 4.2V to 30V. Bypass V+ to PGND close to the IC with a 0.22µF capacitor. Connects to a linear regulator that powers V

L

.

Shutdown Control Input, Active Low. Logic threshold is set at approximately 1V. For automatic startup, connect

SHDN to V+ through a 220k

Ω resistor and bypass SHDN to

GND with a 0.01µF capacitor.

Gate-Drive Output for the Low-Side Synchronous-Rectifier MOSFET. Swings 0 to VL.

Boost Capacitor Connection for High-Side Gate Drive (0.1µF)

Switching-Node (Inductor) Connection. Can swing 2V below ground without hazard.

Gate-Drive Output for the 3.3V, High-Side N-Channel Switch. DH3 is a floating driver output that swings from LX3 to BST3, riding on the LX3 switching-node voltage.

ON/

OFF Control Input. See the Power-Up Sequencing and ON/ OFF Controls section.

No Connection

10 ______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

5V OUTPUT

C1

*

R1

5V ON/OFF

3.3V ON/OFF

ON/OFF

INPUT

7V TO 24V

C3

C4

0.1

µF

L1

Q1

Q2

10

4.7

µF

0.1

µF

0.1

µF

V+ SHDN SECFB V

L

BST5

DH5

SYNC

BST3

DH3

LX5

LX3

DL5

PGND

MAX1901

MAX1904

DL3

GND

CSH5

CSL5

CSH3

CSL3

FB3

FB5

RESET

TIME/ON5

RUN/ON3

SKIP

STEER

REF

SEQ

0.1

µF

5V ALWAYS ON

4.7

µF

0.1

µF

Q3

C5

0.1

µF

L2

Q4

R2

3.3V OUTPUT

* C2

RESET OUTPUT

1

µF

2.5V ALWAYS ON

*1A SCHOTTKY DIODE REQUIRED

FOR THE MAX1901 (SEE THE OUTPUT

OVERVOLTAGE PROTECTION SECTION).

Figure 1. Standard 3.3V/5V Application Circuit (MAX1901/MAX1904)

______________________________________________________________________________________ 11

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Standard Application Circuit

The basic MAX1901/MAX1904 dual-output 3.3V/5V buck converter (Figure 1) is easily adapted to meet a wide range of applications with inputs up to 28V by substituting components from Table 1. These circuits represent a good set of tradeoffs between cost, size, and efficiency, while staying within the worst-case specification limits for stress-related parameters, such as capacitor ripple current. Don’t change the frequency of these circuits without first recalculating component values (particularly inductance value at maximum battery voltage). Adding a Schottky rectifier across each synchronous rectifier improves the efficiency of these circuits by approximately 1%, but this rectifier is otherwise not needed because the MOSFETs required for these circuits typically incorporate a high-speed silicon diode from drain to source. Use a Schottky rectifier rated at a DC current equal to at least one-third of the load current.

Detailed Description

The MAX1901/MAX1902/MAX1904 are dual, BiCMOS, switch-mode power-supply controllers designed primarily for buck-topology regulators in battery-powered applications where high-efficiency and low-quiescent supply current are critical. Light-load efficiency is enhanced by automatic Idle-Mode operation, a variable-frequency pulse-skipping mode that reduces transition and gate-charge losses. Each step-down, power-switching circuit consists of two N-channel

MOSFETs, a rectifier, and an LC output filter. The output voltage is the average AC voltage at the switching node, which is regulated by changing the duty cycle of the MOSFET switches. The gate-drive signal to the

N-channel high-side MOSFET must exceed the battery voltage, and is provided by a flying-capacitor boost circuit that uses a 100nF capacitor connected to BST_.

Table 1. Component Selection for Standard 3.3V/5V Application

COMPONENT

Input Range

Frequency

Q1, Q3 High-Side

MOSFETs

7V to 24V

333kHz

4A/333kHz

1/2 Fairchild FDS6982S or

1/2 International Rectifier

IRF7901D1

LOAD CURRENT

4A/500kHz

7V to 24V

500kHz

1/2 Fairchild FDS6982S or

1/2 International Rectifier

IRF7901D1

Q2, Q4 Low-Side

MOSFETs with Integrated

Schottky Diodes

C3 Input Capacitor

C1 Output Capacitor

C2 Output Capacitor

R1, R2 Resistors

L1 Inductor

L2 Inductor

1/2 Fairchild FDS6982S or

1/2 International Rectifier

IRF7901D1

3 ✕ 10µF, 25V ceramic

Taiyo Yuden TMK432BJ106KM

150µF, 6V POSCAP

Sanyo 6TPC150M

2 ✕ 150µF, 4V POSCAP

Sanyo 4TPC150M

0.018

Dale WSL2512-R018-F

10µH, 4.5A Ferrite

Sumida CDRH124-100

7.0µH, 5.2A Ferrite

Sumida CEI122-H-7R0

1/2 Fairchild FDS6982S or

1/2 International Rectifier

IRF7901D1

3 ✕ 10µF, 25V ceramic

Taiyo Yuden TMK432BJ106KM

150µF, 6V POSCAP

Sanyo 6TPC150M

2 ✕ 150µF, 4V POSCAP

Sanyo 4TPC150M

0.018

Dale WSL2512-R018-F

7.0µH, 5.2A Ferrite

Sumida CEI122-H-7R0

5.6µH, 5.2A Ferrite

Sumida CEI122-H-5R6

7V to 24V

500kHz

6A/500kHz

Fairchild FDS6612A or

International Rectifier

IRF7807V

Fairchild FDS6670S or

International Rectifier

IRF7807DV1

4 ✕ 10µF, 25V ceramic

Taiyo Yuden TMK432BJ106KM

2 ✕ 150µF, 6V POSCAP

Sanyo 6TPC150M

2 ✕ 220µF, 4V POSCAP

Sanyo 4TPC220M

0.012

Dale WSL2512-R012-F

4.2µH, 6.9A Ferrite

Sumida CEI122-H-4R2

4.2µH, 6.9A Ferrite

Sumida CEI122-H-4R2

12 ______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Table 2. Component Suppliers

MANUFACTURER

Dale-Vishay

Fairchild

Semiconductor

International

Rectifier

Sanyo

Sumida

Taiyo Yuden

USA PHONE

402-564-3131

408-721-2181

310-322-3331

619-661-6835

847-956-0666

408-573-4150

FACTORY FAX

402-563-6418

408-721-1635

310-322-3332

619-661-1055

847-956-0702

408-573-4159

The MAX1901/MAX1902/MAX1904 contain ten major circuit blocks (Figure 2).

The two pulse-width-modulation (PWM) controllers each consist of a Dual Mode feedback network and multiplexer, a multi-input PWM comparator, high-side and low-side gate drivers, and logic. MAX1901/

MAX1902 contain fault-protection circuits that monitor the main PWM outputs for undervoltage and overvoltage. A power-on sequence block controls the powerup timing of the main PWMs and determines whether one or both of the outputs are monitored for undervoltage faults. The MAX1902 includes a secondary feedback network and 12V linear regulator to generate a 12V output from a coupled-inductor flyback winding. The

MAX1901/MAX1904 have a secondary feedback input

(SECFB) instead, which allows a quasi-regulated, adjustable output, coupled-inductor flyback winding to be attached to either the 3.3V or the 5V main inductor. Bias generator blocks include the 5V IC internal rail (V

L

) linear regulator, 2.5V precision reference, and automatic bootstrap switchover circuit. The PWMs share a common

333kHz/500kHz synchronizable oscillator.

These internal IC blocks aren’t powered directly from the battery. Instead, the 5V V

L linear regulator steps down the battery voltage to supply both V

L and the gate drivers. The synchronous-switch gate drivers are directly powered from V

L

, while the high-side switch gate drivers are indirectly powered from V

L via an external diode-capacitor boost circuit. An automatic bootstrap circuit turns off the 5V linear regulator and powers the IC from the 5V PWM output voltage if the output is above 4.5V.

PWM Controller Block

The two PWM controllers are nearly identical. The only differences are fixed output settings (3.3V vs. 5V), the

VL/CSL5 bootstrap switch connected to the 5V PWM, and SECFB. The heart of each current-mode PWM controller is a multi-input, open-loop comparator that sums three signals: the output-voltage error signal with respect to the reference voltage, the current-sense signal, and the slope-compensation ramp (Figure 3). The

PWM controller is a direct-summing type, lacking a traditional error amplifier and the phase shift associated with it. This direct-summing configuration approaches ideal cycle-by-cycle control over the output voltage.

When SKIP = low, Idle Mode circuitry automatically optimizes efficiency throughout the load current range.

Idle Mode dramatically improves light-load efficiency by reducing the effective frequency, which reduces switching losses. It keeps the peak inductor current above 25% of the full current limit in an active cycle, allowing subsequent cycles to be skipped. Idle Mode transitions seamlessly to fixed-frequency PWM operation as load current increases.

With SKIP = high, the controller always operates in fixedfrequency PWM mode for lowest noise. Each pulse from the oscillator sets the main PWM latch that turns on the high-side switch for a period determined by the duty factor (approximately V

OUT

/ V

IN

). As the high-side switch turns off, the synchronous rectifier latch sets; 60ns later, the low-side switch turns on. The low-side switch stays on until the beginning of the next clock cycle.

In PWM mode, the controller operates as a fixed-frequency current-mode controller where the duty ratio is set by the input/output voltage ratio. The current-mode feedback system regulates the peak inductor current value as a function of the output-voltage error signal. In continuous-conduction mode, the average inductor current is nearly the same as the peak current, so the circuit acts as a switch-mode transconductance amplifier. This pushes the second output LC filter pole, normally found in a duty-factor-controlled (voltage-mode)

PWM, to a higher frequency. To preserve inner-loop stability and eliminate regenerative inductor current

“staircasing”, a slope-compensation ramp is summed into the main PWM comparator to make the apparent duty factor less than 50%.

The MAX1901/MAX1902/MAX1904 use a relatively low loop gain, allowing the use of lower-cost output capacitors. The relative gains of the voltage-sense and current-sense inputs are weighted by the values of current sources that bias three differential input stages in the main PWM comparator (Figure 4). The relative gain of the voltage comparator to the current comparator is internally fixed at K = 2:1. The low loop gain results in the 2% typical load-regulation error. The low value of loop gain helps reduce output filter capacitor size and cost by shifting the unity-gain crossover frequency to a lower level.

______________________________________________________________________________________ 13

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

INPUT

7V to 24V

3.3V

R1

R2

5V ALWAYS ON

SHDN V+ SYNC

-

+

4.5V

CSL5

MAX1902

V

REF

BST3

DH3

LX3

DL3

L

V

L

ON/OFF

5V

LINEAR

REG

2.5V

REF

3.3V

PWM

LOGIC

333kHz

TO

500kHz

OSC

12V

LINEAR

REG

IN

SECFB

+

-

13V

12OUT

V

DD

BST5

5V

PWM

LOGIC

V

L

DH5

LX5

DL5

PGND

CSH3

CSL3

+

-

FB3

+

-

0.6V

TIME/ON5

V

L

REF -

+

REF

LPF

50kHz

OV/UV

FAULT

1.75V

2.68V

REF

LPF

50kHz

-

+

CSH5

CSL5

POWER-ON

SEQUENCE

LOGIC

-

2.388V

-

OUTPUTS

UP

RUN/ON3

-

+

+

-

GND

TIMER

+

-

0.6V

FB5

RESET

2.6V

SEQ

1V

Figure 2. MAX1902 Functional Diagram

14 ______________________________________________________________________________________

12V

RAW 15V

5V

R3

R4

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

REF

MAIN PWM

COMPARATOR

1X

R

S

Q

OSC

LEVEL

SHIFT

BST_

DH_

LX_

CSH_

CSL_

FROM

FEEDBACK

DIVIDER

SLOPE COMP

30mV

SKIP

SHDN

DAC

COUNTER

SOFT-START

CK

CURRENT

LIMIT

SHOOT-

THROUGH

CONTROL

-100mV

SYNCHRONOUS

RECTIFIER CONTROL

R

Q

S

LEVEL

SHIFT

VL

DL_

PGND

REF

0.75

µs

SINGLE-SHOT

SECFB

Figure 3. PWM Controller Functional Block Diagram

______________________________________________________________________________________ 15

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Table 3. SKIP PWM Table

SKIP

Low

Low

High

High

LOAD CURRENT

Light

Heavy

Light

Heavy

MODE

Idle

PWM

PWM

PWM

DESCRIPTION

Pulse-skipping, supply current = 250µA at V

IN

=12V, discontinuous inductor

Constant-frequency PWM continuous-inductor current

Constant-frequency PWM continuous-inductor current

Constant-frequency PWM continuous-inductor current

V

L

R1 R2

TO PWM

LOGIC

FB_

I1 I2 I3

UNCOMPENSATED

HIGH-SPEED

LEVEL TRANSLATOR

AND BUFFER

OUTPUT DRIVER

V

BIAS

REF

CSH_

CSL_

SLOPE COMPENSATION

Figure 4. Main PWM Comparator Block Diagram

The output filter capacitors (Figure1, C1 and C2) set a dominant pole in the feedback loop that must roll off the loop gain to unity before encountering the zero introduced by the output capacitor’s parasitic resistance

(ESR) (see the Design Procedure section). A 50kHz pole-zero cancellation filter provides additional rolloff above the unity-gain crossover. This internal 50kHz low-pass compensation filter cancels the zero due to filter capacitor ESR. The 50kHz filter is included in the loop in both fixed-output and adjustable-output modes.

Synchronous Rectifier Driver (DL)

Synchronous rectification reduces conduction losses in the rectifier by shunting the normal Schottky catch diode with a low-resistance MOSFET switch. Also, the synchronous rectifier ensures proper startup of the boost gate-driver circuit.

If the circuit is operating in continuous-conduction mode, the DL drive waveform is simply the complement of the DH high-side drive waveform (with controlled dead time to prevent cross-conduction or “shoot through”). In discontinuous (light-load) mode, the synchronous switch is turned off as the inductor current falls through zero. The synchronous rectifier works under all operating conditions, including Idle Mode.

The SECFB signal further controls the synchronous switch timing in order to improve multiple-output cross-regulation

(see the Secondary Feedback Regulation Loop section).

Internal VL and REF Supplies

An internal regulator produces the 5V supply (V

L

) that powers the PWM controller, logic, reference, and other blocks within the IC. This 5V low-dropout linear regulator supplies up to 25mA for external loads, with a reserve of 25mA for supplying gate-drive power.

Bypass V

L to GND with 4.7µF.

Important: Ensure that V

L does not exceed 6V.

Measure V

L with the main output fully loaded. If it is pumped above 5.5V, either excessive boost-diode capacitance or excessive ripple at V+ is the probable cause. Use only small-signal diodes for the boost circuit (10mA to 100mA Schottky or 1N4148 are preferred), and bypass V+ to PGND with 4.7µF directly at the package pins.

16 ______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

The 2.5V reference (REF) is accurate to ±2% over temperature, making REF useful as a precision system reference. Bypass REF to GND with 1µF minimum. REF can supply up to 5mA for external loads. (Bypass REF with a minimum 1µF/mA reference load current.)

However, if extremely accurate specifications for both the main output voltages and REF are essential, avoid loading REF more than 100µA. Loading REF reduces the main output voltage slightly, because of the reference load-regulation error.

When the 5V main output voltage is above 4.5V, an internal P-channel MOSFET switch connects CSL5 to

VL, while simultaneously shutting down the VL linear regulator. This action bootstraps the IC, powering the internal circuitry from the output voltage, rather than through a linear regulator from the battery.

Bootstrapping reduces power dissipation due to gate charge and quiescent losses by providing that power from a 90%-efficient switch-mode source, rather than from a much less efficient linear regulator.

Boost High-Side Gate-Drive Supply

(BST3 and BST5)

Gate-drive voltage for the high-side N-channel switches is generated by a flying-capacitor boost circuit (Figure 2).

The capacitor between BST_ and LX_ is alternately charged from the VL supply and placed parallel to the high-side MOSFET’s gate-source terminals. On startup, the synchronous rectifier (low-side MOSFET) forces LX_ to 0V and charges the boost capacitors to 5V. On the second half-cycle, the SMPS turns on the high-side MOS-

FET by closing an internal switch between BST_ and

DH_. This provides the necessary enhancement voltage to turn on the high-side switch, an action that “boosts” the

5V gate-drive signal above the battery voltage.

Ringing at the high-side MOSFET gate (DH3 and DH5) in discontinuous-conduction mode (light loads) is a natural operating condition. It is caused by residual energy in the tank circuit, formed by the inductor and stray capacitance at the switching node, LX. The gate-drive negative rail is referred to LX, so any ringing there is directly coupled to the gate-drive output.

Current-Limiting and Current-Sense

Inputs (CSH and CSL)

The current-limit circuit resets the main PWM latch and turns off the high-side MOSFET switch whenever the voltage difference between CSH and CSL exceeds

100mV. This limiting is effective for both current flow directions, putting the threshold limit at ±100mV. The tolerance on the positive current limit is ±20%, so the external low-value sense resistor (R1) must be sized for

80mV/ I

PEAK

, where I

PEAK is the required peak-inductor current to support the full load current, while components must be designed to withstand continuouscurrent stresses of 120mV/R1.

For breadboarding or for very-high-current applications, it may be useful to wire the current-sense inputs with a twisted pair, rather than PC traces. (This twisted pair need not be special; two pieces of wire-wrap wire twisted together is sufficient.) This reduces the possible noise picked up at CSH_ and CSL_, which can cause unstable switching and reduced output current. The

CSL5 input also serves as the IC’s bootstrap supply input. Whenever V

CSL5

> 4.5V, an internal switch connects CSL5 to V

L

.

Oscillator Frequency and

Synchronization (SYNC)

The SYNC input controls the oscillator frequency. Low selects 333kHz; high selects 500kHz. SYNC can also be used to synchronize with an external 5V CMOS or

TTL clock generator. SYNC has a guaranteed 400kHz to 583kHz capture range. A high-to-low transition on

SYNC initiates a new cycle.

500kHz operation optimizes the application circuit for component size and cost. 333kHz operation provides increased efficiency, lower dropout, and improved load-transient response at low input-output voltage differences (see the Low-Voltage Operation section).

Shutdown Mode

Holding SHDN low puts the IC into its 4µA shutdown mode. SHDN is logic input with a threshold of about 1V

(the V

TH of an internal N-channel MOSFET). For automatic startup, bypass SHDN to GND with a 0.01µF capacitor and connect it to V+ through a 220k

Ω resistor.

Power-Up Sequencing and

ON/

OFF Controls

Startup is controlled by RUN/ON3 and TIME/ON5 in conjunction with SEQ. With SEQ tied to REF, the two control inputs act as separate ON/OFF controls for each supply. With SEQ tied to VL or GND, RUN/ON3 becomes the master ON/OFF control input and

TIME/ON5 becomes a timing pin, with the delay between the two supplies determined by an external capacitor. The delay is approximately 800µs/nF. The

3.3V supply powers up first if SEQ is tied to VL, and the

5V supply is first if SEQ is tied to GND. When driving

TIME/ON5 as a control input with external logic, always place a resistor (>1k

Ω) in series with the input. This prevents possible crowbar current due to the internal discharge pulldown transistor, which turns on in standby mode and momentarily at the first power-up or in shutdown mode.

______________________________________________________________________________________ 17

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

RESET Power-Good Voltage Monitor

The power-good monitor generates a system RESET signal. At first power-up, RESET is held low until both the 3.3V and 5V SMPS outputs are in regulation. At this point, an internal timer begins counting oscillator pulses, and RESET continues to be held low until 32,000 cycles have elapsed. After this timeout period (64ms at

500kHz or 96ms at 333kHz), RESET is actively pulled up to V

L

. If SEQ is tied to REF (for separate ON3/ON5 controls), only the 3.3V SMPS is monitored—the 5V

SMPS is ignored.

Output Undervoltage Shutdown

Protection (MAX1901/MAX1902)

The output undervoltage lockout circuit is similar to foldback current limiting, but employs a timer rather than a variable current limit. Each SMPS has an undervoltage protection circuit that is activated 6144 clock cycles after the SMPS is enabled. If either SMPS output is under 70% of the nominal value, both SMPSs are latched off and their outputs are clamped to ground by the synchronous rectifier MOSFETs (see the Output

Overvoltage Protection section). They won’t restart until

SHDN or RUN/ON3 is toggled, or until V+ power is cycled below 1V. Note that undervoltage protection can make prototype troubleshooting difficult, since you have only 12ms or 18ms to figure out what might be wrong with the circuit before both SMPSs are latched off. In extreme cases, it may be useful to substitute the

MAX1904 into the prototype breadboard until the prototype is working properly.

Output Overvoltage Protection

(MAX1901/MAX1902)

Both SMPS outputs are monitored for overvoltage. If either output is more than 7% above the nominal regulation point, both low-side gate drivers (DL_) are latched high until SHDN or RUN/ON3 is toggled, or until V+ power is cycled below 1V. This action turns on the synchronous rectifiers with 100% duty, in turn rapidly discharging the output capacitors and forcing both

SMPS outputs to ground. The DL outputs are also kept high whenever the corresponding SMPS is disabled, and in shutdown if V

L is sustained.

Discharging the output capacitor through the main inductor causes the output to momentarily go below

GND. Clamp this negative pulse with a back-biased 1A

Schottky diode across the output capacitor (Figure 1).

To ensure overvoltage protection on initial power-up, connect signal diodes from both output voltages to V

L

(cathodes to V

L

) to eliminate the V

L power-up delay.

This circuitry protects the load from accidental overvoltage caused by a short circuit across the high-side power MOSFETs. This scheme relies on the presence of a fuse, in series with the battery, which is blown by the resulting crowbar current. Note that the overvoltage circuitry will interfere with external keep-alive supplies that hold up the outputs (such as lithium backup or hotswap power supplies); in such cases, the MAX1904 should be used.

Low-Noise Operation (PWM Mode)

PWM mode (SKIP = high) minimizes RF and audio interference in noise-sensitive applications (such as hi-fi multimedia-equipped systems), cellular phones, RF communicating computers, and electromagnetic pen entry systems. See the summary of operating modes in

Table 2. SKIP can be driven from an external logic signal.

Table 4. Operating Modes

SHDN

SEQ RUN/ON3

Low

High

High

High

High

High

High

High

High

X

REF

REF

REF

REF

GND

GND

VL

VL

X

Low

High

Low

High

Low

High

Low

High

TIME/ON5

X

Low

Low

High

High

Timing Capacitor

Timing Capacitor

Timing Capacitor

Timing Capacitor

MODE

Shutdown

Standby

Run

Run

Run

Standby

Run

Standby

Run

DESCRIPTION

All circuit blocks turned off.

Supply current = 4µA.

Both SMPSs off. Supply current = 30µA.

3.3V SMPS enabled/5V off.

5V SMPS enabled/3.3V off.

Both SMPSs enabled.

Both SMPSs off. Supply current = 30µA.

Both SMPSs enabled. 5V enabled before 3.3V.

Both SMPSs off. Supply current = 30µA.

Both SMPSs enabled. 3.3V enabled Before 5V.

18 ______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Interference due to switching noise is reduced in PWM mode by ensuring a constant switching frequency, thus concentrating the emissions at a known frequency outside the system audio or IF bands. Choose an oscillator frequency for which switching frequency harmonics don’t overlap a sensitive frequency band. If necessary, synchronize the oscillator to a tight-tolerance external clock generator. To extend the output-voltage regulation range, constant operating frequency is not maintained under overload or dropout conditions (see the

Dropout Operation section).

PWM mode (SKIP = high) forces two changes upon the

PWM controllers. First, it disables the minimum-current comparator, ensuring fixed-frequency operation.

Second, it changes the detection threshold for reverse current limit from 0 to -100mV, allowing the inductor current to reverse at light loads. This results in fixed-frequency operation and continuous inductor-current flow.

This eliminates discontinuous-mode inductor ringing and improves cross regulation of transformer-coupled multiple-output supplies, particularly in circuits that don’t use additional secondary regulation via SECFB or V

DD

.

In most applications, tie SKIP to GND to minimize quiescent supply current. VL supply current with SKIP high is typically 30mA, depending on external MOSFET gate capacitance and switching losses.

Internal Digital Soft-Start Circuit

Soft-start allows a gradual increase of the internal current-limit level at startup to reduce input surge currents.

Both SMPSs contain internal digital soft-start circuits, each controlled by a counter, a digital-to-analog converter (DAC), and a current-limit comparator. In shutdown or standby mode, the soft-start counter is reset to zero. When an SMPS is enabled, its counter starts counting oscillator pulses, and the DAC begins incrementing the comparison voltage applied to the currentlimit comparator. The DAC output increases from 0 to

100mV in five equal steps as the count increases to

512 clocks. As a result, the main output capacitor charges up relatively slowly. The exact time of the output rise depends on output capacitance and load current, and is typically 600µs with a 500kHz oscillator.

Dropout Operation

Dropout (low input-output differential operation) is enhanced by stretching the clock pulse width to increase the maximum duty factor. The algorithm follows: If the output voltage (V

OUT

) drops out of regulation without the current limit having been reached, the

SMPS skips an off-time period (extending the on-time).

At the end of the cycle, if the output is still out of regulation, the SMPS skips another off-time period. This action can continue until three off-time periods are skipped, effectively dividing the clock frequency by as much as four.

The typical PWM minimum off-time is 300ns, regardless of the operating frequency. Lowering the operating frequency raises the maximum duty factor above 97%.

Adjustable-Output Feedback

(Dual Mode FB)

Fixed, preset output voltages are selected when FB_ is connected to ground. Adjusting the main output voltage with external resistors is simple for any of the

MAX1901/MAX1902/MAX1904, through resistor dividers connected to FB3 and FB5 (Figure 2). Calculate the output voltage with the following formula:

V

OUT

= V

REF

(1 + R1 / R2) where V

REF

= 2.5V nominal.

The nominal output should be set approximately 1% or

2% high to make up for the MAX1901/MAX1902/

MAX1904 -2% typical load-regulation error. For example, if designing for a 3.0V output, use a resistor ratio that results in a nominal output voltage of 3.05V. This slight offsetting gives the best possible accuracy.

Recommended normal values for R2 range from 5k

Ω to

100k

Ω. To achieve a 2.5V nominal output, simply connect FB_ directly to CSL_.

Remote output-voltage sensing, while not possible in fixed-output mode due to the combined nature of the voltage-sense and current-sense inputs (CSL3 and

CSL5), is easy to do in adjustable mode by using the top of the external resistor-divider as the remote sense point.

When using adjustable mode, it is a good idea to always set the “3.3V output” to a lower voltage than the

“5V output.” The 3.3V output must always be less than

VL, so that the voltage on CSH3 and CSL3 is within the common-mode range of the current-sense inputs. While

VL is nominally 5V, it can be as low as 4.7V when linearly regulating, and as low as 4.2V when automatically bootstrapped to CSH5.

Secondary Feedback Regulation Loop

(SECFB or V

DD

)

A flyback-winding control loop regulates a secondary winding output, improving cross-regulation when the primary output is lightly loaded or when there is a low input-output differential voltage. If V

DD or SECFB falls below its regulation threshold, the low-side switch is turned on for an extra 0.75µs. This reverses the induc-

______________________________________________________________________________________ 19

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

tor (primary) current, pulling current from the output filter capacitor and causing the flyback transformer to operate in forward mode. The low impedance presented by the transformer secondary in forward mode dumps current into the secondary output, charging up the secondary capacitor and bringing V

DD or SECFB back into regulation. The secondary feedback loop does not improve secondary output accuracy in normal flyback mode, where the main (primary) output is heavily loaded. In this condition, secondary output accuracy is determined by the secondary rectifier drop, transformer turns ratio, and accuracy of the main output voltage. A linear post-regulator may still be needed to meet strict output-accuracy specifications.

MAX1902 has a V

DD pin that regulates at a fixed 13.5V, set by an internal resistor-divider. The MAX1901/

MAX1904 have an adjustable secondary-output voltage set by an external resistor-divider on SECFB (Figure 5).

Ordinarily, the secondary regulation point is set 5% to

10% below the voltage normally produced by the flyback effect. For example, if the output voltage as determined by turns ratio is 15V, set the feedback resistor ratio to produce 13.5V. Otherwise, the SECFB one-shot might be triggered unintentionally, unnecessarily increasing supply current and output noise.

12V Linear Regulator Output (MAX1902)

The MAX1902 includes a 12V linear regulator output capable of delivering 120mA of output current.

Typically, greater current is available at the expense of output accuracy. If an accurate output of more than

120mA is needed, an external pass transistor can be added. The circuit in Figure 6 delivers more than

200mA. Total output current is constrained by the V+ input voltage and the transformer primary load (see

Maximum V

DD

Output Current vs. Input Voltage graphs in the Typical Operating Characteristics).

Design Procedure

The three predesigned 3V/5V standard application circuits (Figure 1 and Table 1) contain ready-to-use solutions for common application needs. Also, one standard flyback transformer circuit supports the

12OUT linear regulator in the Applications Information section. Use the following design procedure to optimize these basic schematics for different voltage or current requirements. But before beginning a design, firmly establish the following:

Maximum Input (Battery) Voltage, V

IN(MAX)

. This value should include the worst-case conditions, such as noload operation when a battery charger or AC adapter is

R2

1-SHOT

TRIG

SECFB

2.5V REF

V+

DH_

R1

POSITIVE

SECONDARY

OUTPUT

MAX1901

MAX1904

DL_

+V

TRIP

= V

REF

(

R1

1 + –––

)

R2

WHERE V

REF

(NOMINAL) = 2.5V

MAIN

OUTPUT

MAX1902

12OUT

V

DD

DH_

V+

0.1

µF

0.1

µF

10

2N3906

12V OUTPUT

200mA

10

µF

0.1

µF

V

DD

OUTPUT

2.2

µF

MAIN

OUTPUT

DL_

Figure 5. Adjusting the Secondary Output Voltage with SECFB Figure 6. Increased 12V Linear Regulator Output Current

20 ______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

connected but no battery is installed. V

IN(MAX) must not exceed 30V.

Minimum Input (Battery) Voltage, V

IN(MIN)

.This should be taken at full load under the lowest battery conditions. If V

IN(MIN) is less than 4.2V, use an external circuit to externally hold V

L above the V

L undervoltage lockout threshold. If the minimum input-output difference is less than 1.5V, the filter capacitance required to maintain good AC load regulation increases (see the

Low-Voltage Operation section).

Inductor Value

The exact inductor value isn’t critical and can be freely adjusted to make trade-offs between size, cost, and efficiency. Lower inductor values minimize size and cost, but reduce efficiency due to higher peak-current levels. The smallest inductor is achieved by lowering the inductance until the circuit operates at the border between continuous and discontinuous mode. Further reducing the inductor value below this crossover point results in discontinuous-conduction operation even at full load. This helps lower output-filter capacitance requirements, but efficiency suffers due to high I

2

R losses. On the other hand, higher inductor values mean greater efficiency, but resistive losses due to extra wire turns will eventually exceed the benefit gained from lower peak-current levels. Also, high inductor values can affect load-transient response (see the V

SAG equation in the Low-Voltage Operation section). The equations that follow are for continuous-conduction operation, since the MAX1901/MAX1902/MAX1904 are intended mainly for high-efficiency, battery-powered applications. Discontinuous conduction doesn’t affect normal idle-mode operation.

Three key inductor parameters must be specified: inductance value (L), peak current (I

PEAK

), and DC resistance (R

DC

). The following equation includes a constant (LIR) which is the ratio of inductor peak-topeak AC current to DC load current. A higher LIR value allows smaller inductance, but results in higher losses and higher ripple. A good compromise between size and losses is found at a 30% ripple-current to load-current ratio (LIR = 0.3), which corresponds to a peakinductor current 1.15 times higher than the DC load current.

L

=

V

OUT

(

V

IN MAX

V

IN MAX )

)

V

OUT

× ×

I

OUT

×

)

LIR where: f = switching frequency, normally 333kHz or

500kHz

I

OUT

= maximum DC load current

LIR = ratio of AC to DC inductor current, typically 0.3; should be >0.15

The nominal peak-inductor current at full load is 1.15

I

OUT if the above equation is used; otherwise, the peak current can be calculated by:

I

PEAK

=

I

LOAD

+

(

V

OUT

( V

IN MAX )

2 f L V

V

OUT

)

)

The inductor’s DC resistance should be low enough that

R

DC

I

PEAK

< 100mV, as it is a key parameter for efficiency performance. If a standard off-the-shelf inductor is not available, choose a core with an LI

2 rating greater than L

I

PEAK

2 and wind it with the largest-diameter wire that fits the winding area. Ferrite core material is strongly preferred. Shielded-core geometries help keep noise,

EMI, and switching-waveform jitter low.

Current-Sense Resistor Value

The current-sense resistor value is calculated according to the worst-case low current-limit threshold voltage

(from the Electrical Characteristics) and the peak inductor current:

R

SENSE

=

80 mV

I

PEAK

Use I

PEAK from the second equation in the Inductor

Value section.

Use the calculated value of R

SENSE to size the MOS-

FET switches and specify inductor saturation-current ratings according to the worst-case high current-limit threshold voltage:

I

PEAK MAX )

=

120 mV

R

SENSE

Low-inductance resistors, such as surface-mount metal-film, are recommended.

Input-Capacitor Value

The input filter capacitor is usually selected according to input ripple current requirements and voltage rating, rather than capacitor value. Ceramic capacitors or

Sanyo OS-CON capacitors are typically used to handle the power-up surge-currents, especially when connecting to robust AC adapters or low-impedance batteries.

RMS input ripple current (I

RMS

) is determined by the input voltage and load current, with the worst case occurring at V

IN

= 2

V

OUT

:

______________________________________________________________________________________ 21

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

I

RMS

=

I

LOAD

×

V

OUT

( V

IN

V

OUT

)

V

IN

Therefore, when V

IN is 2 x V

OUT

:

I

RMS

=

I

LOAD

2

Bypassing V+

Bypass the V+ input with a 4.7µF tantalum capacitor paralleled with a 0.1µF ceramic capacitor, close to the

IC. A 10

Ω series resistor to V

IN is also recommended.

Bypassing VL

Bypass the VL output with a 4.7µF tantalum capacitor paralleled with a 0.1µF ceramic capacitor, close to the device.

Output-Filter Capacitor Value

The output-filter capacitor values are generally determined by the ESR and voltage-rating requirements, rather than actual capacitance requirements for loop stability. In other words, the low-ESR electrolytic capacitor that meets the ESR requirement usually has more output capacitance than is required for AC stability. Use only specialized low-ESR capacitors intended for switchingregulator applications, such as AVX TPS, Sanyo

POSCAP, or Kemet T510. To ensure stability, the capacitor must meet both minimum capacitance and maximum

ESR values as given in the following equations:

C

OUT

>

V

REF

( 1

+

V

OUT

/ V

IN MIN )

)

V

OUT

×

R

SENSE

× f scope won’t quite sync up. Technically speaking, this jitter (usually harmless) is unstable operation, since the duty factor varies slightly. As capacitors with higher

ESRs are used, the jitter becomes more pronounced, and the load-transient output-voltage waveform starts looking ragged at the edges. Eventually, the load-transient waveform has enough ringing on it that the peak noise levels exceed the allowable output-voltage tolerance. Note that even with zero phase margin and gross instability present, the output-voltage noise never gets much worse than I

PEAK

R

ESR

(under constant loads).

The output-voltage ripple is usually dominated by the filter capacitor’s ESR, and can be approximated as

I

RIPPLE

R

ESR

. There is also a capacitive term, so the full equation for ripple in continuous-conduction mode is V

NOISE (p-p)

= I

RIPPLE

[R

ESR

+ 1/(2

π

✕ f

C

OUT

)]. In idle mode, the inductor current becomes discontinuous, with high peaks and widely spaced pulses, so the noise can actually be higher at light load

(compared to full load). In idle mode, calculate the output ripple as follows:

V

)

=

×

R

ESR

+

V

R

SENSE

OUT

+

1 /( V

IN

V

OUT

R

SENSE

2

×

C

OUT

)]

R

ESR

<

R

SENSE

×

V

OUT

V

REF

These equations are worst case, with 45° of phase margin to ensure jitter-free, fixed-frequency operation and provide a nicely damped output response for zero to full-load step changes. Some cost-conscious designers may wish to bend these rules with less-expensive capacitors, particularly if the load lacks large step changes. This practice is tolerable if some bench testing over temperature is done to verify acceptable noise and transient response.

No well-defined boundary exists between stable and unstable operation. As phase margin is reduced, the first symptom is a bit of timing jitter, which shows up as blurred edges in the switching waveforms where the

Transformer Design

(for Auxiliary Outputs Only)

Buck-plus-flyback applications, sometimes called “coupled-inductor” topologies, need a transformer to generate multiple output voltages. Performing the basic electrical design is a simple task of calculating turns ratios and adding the power delivered to the secondary to calculate the current-sense resistor and primary inductance. However, extremes of low input-output differentials, widely different output loading levels, and high turns ratios can complicate the design due to parasitic transformer parameters such as interwinding capacitance, secondary resistance, and leakage inductance. For examples of what is possible with real world transformers, see the Maximum V

DD

Output

Current vs. Input Voltage graph in the Typical

Operating Characteristics.

Power from the main and secondary outputs is combined to get an equivalent current referred to the main output voltage (see the Inductor Value section for parameter definitions). Set the current-sense resistor value at 80mV

/ I

TOTAL

.

22 ______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

P

TOTAL

= The sum of the output power from all outputs

I

TOTAL

= P

TOTAL

/ V

OUT

= The equivalent output current referred to V

OUT

L

PRIMARY

=

V

V

OUT

( V

IN MAX )

IN MAX )

V

OUT

× ×

I

TOTAL

×

)

LIR

Turns Ratio N

=

V

V

SEC

OUT MIN )

+

+

V

FWD

V

RECT

+

V

SENSE where: V

SEC

= the minimum required rectified sec ondary output voltage

V

FWD

= the forward drop across the secondary rectifier

V

OUT(MIN)

= the minimum value of the main out put voltage (from the Electrical

Characteristics tables)

V

RECT

= the on-state voltage drop across the synchronous rectifier MOSFET

V

SENSE

= the voltage drop across the sense resistor

In positive-output applications, the transformer secondary return is often referred to the main output voltage, rather than to ground, to reduce the needed turns ratio. In this case, the main output voltage must first be subtracted from the secondary voltage to obtain V

SEC

.

Selecting Other Components

MOSFET Switches

The high-current N-channel MOSFETs must be logiclevel types with guaranteed on-resistance specifications at V

GS

= 4.5V. Lower gate threshold specifications are better (i.e., 2V max rather than 3V max). Drain-source breakdown voltage ratings must at least equal the maximum input voltage, preferably with a 20% derating factor. The best MOSFETs will have the lowest on-resistance per nanocoulomb of gate charge.

Multiplying R

DS(ON)

Q

G provides a good figure for comparing various MOSFETs. Newer MOSFET process technologies with dense cell structures generally perform best. The internal gate drivers tolerate >100nC total gate charge, but 70nC is a more practical upper limit to maintain best switching times.

In high-current applications, MOSFET package power dissipation often becomes a dominant design factor.

I

2

R power losses are the greatest heat contributor for both high-side and low-side MOSFETs. I

2

R losses are distributed between Q1 and Q2 according to duty factor (see the following equations). Generally, switching losses affect only the upper MOSFET, since the

Schottky rectifier clamps the switching node in most cases before the synchronous rectifier turns on. Gate charge losses are dissipated by the driver and don’t heat the MOSFET. Calculate the temperature rise according to package thermal-resistance specifications to ensure that both MOSFETs are within their maximum junction temperature at high ambient temperature. The worst-case dissipation for the high-side MOSFET occurs at both extremes of input voltage, and the worst-case dissipation for the low-side MOSFET occurs at maximum input voltage:

PD upperFET

=

I

LOAD

2

×

R

DS ON )

×



+

V

IN

×

I

LOAD

V

IN

×

C

RSS

I

GATE

+

20 ns



DUTY

PD upperFET

=

I

LOAD

2

(

×

R

DS ON )

DUTY

=

V

OUT

+

V

Q 2

) (

×

( 1 DUTY

V

IN

V

Q 1

)

) where: On-state voltage drop V

Q_

= I

LOAD

R

DS(ON)

C

RSS

= MOSFET reverse transfer capacitance

I

GATE

= DH driver peak output current capability

(1A typ)

20ns = DH driver inherent rise/fall time

Under output short-circuit, the MAX1904 synchronous rectifier MOSFET suffers extra stress because its duty factor can increase to greater than 0.9. It may need to be oversized to tolerate a continuous DC short circuit.

During short circuit, the MAX1901/MAX1902’s output undervoltage shutdown protects the synchronous rectifier under output short-circuit conditions.

To reduce EMI, add a 0.1µF ceramic capacitor from the high-side switch drain to the low-side switch source.

Rectifier Clamp Diode

The rectifier diode is a clamp across the low-side MOS-

FET that catches the negative inductor swing during the 60ns dead time between turning one MOSFET off and each low-side MOSFET on. The latest generations of MOSFETs incorporate a high-speed Schottky diode, which serves as an adequate clamp diode. For

MOSFETs without integrated Schottky diodes, place a

Schottky diode in parallel with the low-side MOSFET.

______________________________________________________________________________________ 23

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Use a Schottky diode with a DC current rating equal to one third of the load current. The Schottky diode’s rated reverse breakdown voltage must be at least equal to the maximum input voltage, preferably with a 20% derating factor.

Boost-Supply Diode

A signal diode such as a 1N4148 works well in most applications. If the input voltage can go below +6V, use a small (20mA) Schottky diode for slightly improved efficiency and dropout characteristics. Don’t use large power diodes, such as 1N5817 or 1N4001, since high junction capacitance can pump up V

L to excessive voltages.

Rectifier Diode (Transformer Secondary Diode)

The secondary diode in coupled-inductor applications must withstand flyback voltages greater than 60V, which usually rules out most Schottky rectifiers.

Common silicon rectifiers, such as the 1N4001, are also prohibited because they are too slow. This often makes fast silicon rectifiers such as the MURS120 the only choice. The flyback voltage across the rectifier is related to the V

IN

- V

OUT difference, according to the transformer turns ratio:

V

FLYBACK

= V

SEC

+ (V

IN

- V

OUT

)

N

Electrical Characteristics parameter, 97% guaranteed over temperature at f = 333kHz), as follows:

V

SAG

=

2

×

C

OUT

×

I

STEP

2

( V

IN MIN )

×

L

×

D

MAX

V

OUT

)

The cure for low-voltage sag is to increase the output capacitor’s value. Take a 333kHz/6A application circuit as an example, at V

IN

= +5.5V, V

OUT

= +5V, L = 6.7µH, f = 333kHz, I

STEP

= 3A (half-load step), a total capacitance of 470µF keeps the sag less than 200mV. The capacitance is higher than that shown in the Typical

Application Circuit because of the lower input voltage.

Note that only the capacitance requirement increases, and the ESR requirements don’t change. Therefore, the added capacitance can be supplied by a low-cost bulk capacitor in parallel with the normal low-ESR capacitor.

Applications Information

Heavy-Load Efficiency Considerations

The major efficiency-loss mechanisms under loads are, in the usual order of importance:

• P(I

2

R) = I

2

R losses

• P(tran) = transition losses

• P(gate) = gate-charge losses

• P(diode) = diode-conduction losses

• P(cap) = input capacitor ESR losses

• P(IC) = losses due to the IC’s operating supply current

Inductor core losses are fairly low at heavy loads because the inductor’s AC current component is small.

Therefore, they aren’t accounted for in this analysis.

Ferrite cores are preferred, especially at 300kHz, but powdered cores, such as Kool-Mu, can work well: where: N = the transformer turns ratio SEC/PRI

V

SEC

= the maximum secondary DC output voltage

V

OUT

= the primary (main) output voltage

Subtract the main output voltage (V

OUT

) from V

FLY-

BACK in this equation if the secondary winding is returned to V

OUT and not to ground. The diode reversebreakdown rating must also accommodate any ringing due to leakage inductance. The rectifier diode’s current rating should be at least twice the DC load current on the secondary output.

Low-Voltage Operation

Low input voltages and low input-output differential voltages each require extra care in their design. Low absolute input voltages can cause the V

L linear regulator to enter dropout and eventually shut itself off. Low input voltages relative to the output (low V

IN

- V

OUT differential) can cause bad load regulation in multi-output flyback applications (see the design equations in the Transformer

Design section). Also, low V

IN

- V

OUT differentials can also cause the output voltage to sag when the load current changes abruptly. The amplitude of the sag is a function of inductor value and maximum duty factor (an

Efficiency = P

OUT

/P

IN

100%

= P

OUT

/(P

OUT

+ P

TOTAL

)

100%

P

TOTAL

= P(I

2

R) + P(tran) + P(gate) + P(diode) +

P (I

P(cap) + P(IC)

2

R) = I

LOAD

2 x (R

DC

+ R

DS(ON)

+ R where RDC is the DC resistance of the coil, R

DS(ON) is the MOSFET on-resistance, and R

SENSE is the currentsense resistor value. The R

DS(ON) term assumes identical MOSFETs for the high-side and low-side switches: because they time-share the inductor current. If the

MOSFETs aren’t identical, their losses can be estimated by averaging the losses according to duty factor.

24 ______________________________________________________________________________________

SENSE

)

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Table 5. Low-Voltage Troubleshooting Chart

SYMPTOM CONDITION ROOT CAUSE

Sag or droop in V

OUT under step-load change

Low V

IN

- V

OUT differential, <1.5V

Limited inductor-current slew rate per cycle.

SOLUTION

Increase bulk output capacitance per formula (see the Low-Voltage Operation section). Reduce inductor value.

Dropout voltage is too high (V

OUT

follows V

IN

as

V

IN

decreases)

Unstable—jitters between different duty factors and frequencies

Low V

IN

- V

OUT differential, <1V

Low V

IN

- V

OUT differential, <0.5V

Maximum duty-cycle limits exceeded.

Reduce operation to 333kHz. Reduce

MOSFET on-resistance and coil DCR.

Increase the minimum input voltage or ignore.

Secondary output won’t support a load

Poor efficiency

Low V

IN

- V

OUT differential,

V

IN

< 1.3 ✕

V

OUT(MAIN)

Low input voltage,

<5V

Normal function of internal lowdropout circuitry.

Not enough duty cycle left to initiate forward-mode operation.

Small AC current in primary can’t store energy for flyback operation.

V

L

linear regulator is going into dropout and isn’t providing good gate-drive levels.

Reduce operation to 333kHz. Reduce secondary impedances; use a Schottky diode, if possible. Stack secondary winding on the main output.

Use a small 20mA Schottky diode for boost diode. Supply V

L

from an external source.

Won’t start under load or quits before battery is completely dead

Low input voltage,

<4.5V

V

L

output is so low that it hits the

V

L

UVLO threshold.

Supply V

L

from an external source other than V

IN

, such as the system 5V supply.

f

( )

=

V

IN

×

I

LOAD

×

[

(

V

IN

×

C

RSS

/ I

GATE

)

20 ns

] where C

RSS is the reverse transfer capacitance of the high-side MOSFET (a data sheet parameter), I

GATE is the DH gate-driver peak output current (1.5A typical), and 20ns is the rise/fall time of the DH driver (20ns typ).

P(gate) = Q

G

✕ f

V

L where V

L is the internal-logic-supply voltage (5V), and

Q

G is the sum of the gate-charge values for low-side and high-side switches. For matched MOSFETs, Q

G is twice the data sheet value of an individual MOSFET. If

V

OUT is set to less than 4.5V, replace V

L in this equation with V

BATT

. In this case, efficiency can be improved by connecting V

L to an efficient 5V source, such as the system 5V supply:

P(diode) = I

LOAD

V

FWD

✕ t

D

✕ f where t

D is the diode-conduction time (120ns typ) and

V

FWD is the forward voltage of the diode.

This power is dissipated in the MOSFET body diode if no external Schottky diode is used:

P(cap) = (I

RMS

)

2 x R

ESR where I

RMS is the input ripple current as calculated in the

Design Procedure and Input-Capacitor Value sections.

Light-Load Efficiency Considerations

Under light loads, the PWM operates in discontinuous mode, where the inductor current discharges to zero at some point during the switching cycle. This makes the inductor current’s AC component high compared to the load current, which increases core losses and I

2

R losses in the output filter capacitors. For best light-load efficiency, use MOSFETs with moderate gate-charge levels, and use ferrite, MPP, or other low-loss core material.

______________________________________________________________________________________ 25

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Lossless-Inductor Current-Sensing

The DC resistance (DCR) of the inductor can be used to sense inductor current to improve the efficiency and to reduce the cost by eliminating the sense resistor.

Figure 7 shows the sense circuit, where L is the inductance, R

L is the inductor DCR, R

S

, and C

S form an RC low-pass sense network. If the time constant of the inductor is equal to that of the sense network, i.e.:

L

R

L

= then the voltage across C

S becomes

V

S

=

R

L

×

I

L where I

L is the inductor current.

Determine the required sense-resistor value using the equation given in the Current-Sense Resistor Value section. Choose an inductor with DCR equal or greater than the sense resistor value. If the DCR is greater than the sense-resistor value, use a divider to scale down the voltage. Use the maximum inductance and minimum DCR to get the maximum possible inductor time constant. Select R

S and C

S so that the maximum sense network time constant is equal or greater than the maximum inductor time constant.

Reduced Output Capacitance Application

In applications where higher output ripple is acceptable, lower output capacitance or higher ESR output capacitors can be used. In such cases, cycle-by-cycle stability is maintained by adding feedforward compensation to offset for the increased output ESR. Figure 8 shows the addition of the feedforward compensation circuit. C

FB provides noise filtering, R

FF is the feedforward resistor and C

LX provides DC blocking. Use

100pF for C

FB and C

LX

. Select R

FF according to the equation below:

R

FF

4

×

R 3 L f

ESR

Set the value for R

FF close to the calculation. Do not make R

FF too small as that will introduce too much feedforward, possibly causing an overvoltage to be seen at the feedback pin, and changing the mode of operation to a voltage mode.

PC Board Layout Considerations

Good PC board layout is required in order to achieve specified noise, efficiency, and stability performance.

The PC board layout artist must be given explicit instructions, preferably a pencil sketch showing the placement of power-switching components and highcurrent routing. A ground plane is essential for optimum

DH_

LX_

MAX1901

MAX1902

MAX1904

CSH_

CSL_

DL_

V

IN

R

S

C

IN

L

INDUCTOR

R

L

C

S

V

OUT

C

OUT

MAX1901

MAX1902

MAX1904

FB_

DL_

DH_

CSL_

CSH_

LX_

V

IN

C

IN

L

C

LX

R

FF

R

SENSE

C

FB

V

OUT

R3

C

OUT

R4

Figure 7. Lossless Inductor Current Sensing Figure 8. Adding Feedforward Compensation

26 ______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

performance. In most applications, the circuit will be located on a multilayer board, and full use of the four or more copper layers is recommended. Use the top layer for high-current connections, the bottom layer for quiet connections (REF, SS, GND), and the inner layers for an uninterrupted ground plane. Use the following stepby-step guide:

1) Place the high-power components (Figure 1, C1, C3,

C4, Q1, Q2, L1, and R1) first, with their grounds adjacent.

• Priority 1: Minimize current-sense resistor trace lengths and ensure accurate current sensing with

Kelvin connections (Figure 9).

• Priority 2: Minimize ground trace lengths in the high-current paths (discussed below).

• Priority 3: Minimize other trace lengths in the high current paths.

Use >5mm-wide traces

CIN to high-side MOSFET drain: 10mm max length

Rectifier diode cathode to low-side MOSFET:

5mm max length

LX node (MOSFETs, rectifier cathode, inductor):

15mm max length

Ideally, surface-mount power components are butted up to one another with their ground terminals almost touching. These high-current grounds are then connected to each other with a wide filled zone of top-layer copper so they don’t go through vias. The resulting top layer “subground-plane” is connected to the normal inner-layer ground plane at the output ground terminals, which ensures that the IC’s analog ground is sensing at the supply’s output terminals without interference from IR drops

HIGH-CURRENT PATH

SENSE RESISTOR

MAX1901/MAX1902/MAX1904

Figure 9. Kelvin Connections for the Current-Sense Resistors

and ground noise. Other high-current paths should also be minimized, but focusing primarily on short ground and current-sense connections eliminates about 90% of all PC board layout problems.

2) Place the IC and signal components. Keep the main switching nodes (LX nodes) away from sensitive analog components (current-sense traces and REF capacitor). Place the IC and analog components on the opposite side of the board from the powerswitching node. Important: the IC must be no more than 10mm from the current-sense resistors. Keep the gate-drive traces (DH_, DL_, and BST_) shorter than 20mm and route them away from CSH_, CSL_, and REF.

3) Use a single-point star ground where the input ground trace, power ground (sub-ground-plane), and normal ground plane meet at the supply’s output ground terminal. Connect both IC ground pins and all

IC bypass capacitors to the normal ground plane.

______________________________________________________________________________________ 27

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

ON/OFF

INPUT

6.5V TO 28V

3.3V OUTPUT (3A)

C1

*

R1

C3

TO 3.3V OUTPUT

* *

TO 5V OUTPUT

C4

10

4.7

µF 0.1

µF

5V ALWAYS ON

L1

0.1

µF

1N5819

3V ON/OFF

5V ON/OFF

23

SHDN

D1

25

BST3

Q1

27

DH3

0.1

µF

26

LX3

Q2

24

DL3

V+

22 6

SYNC

V

L

21

12OUT

4

V

DD

5

D2

BST5

18

DH5

16 Q3

MAX1902

LX5

17

DL5

PGND

19

20

Q4

0.1

µF

1

CSH3

2

CSL3

3

FB3

28

RUN/ON3

7

TIME/ON5

CSH5

14

CSL5

13

FB5

12

SEQ

REF

15

9

1

µF

1N5819

0.1

µF

D5

0.1

µF

T2

1:2.2

RESET

11

4.7

µF

2.2

µF

R2

2.5V REF

12V AT 120mA

2.2

µF

POWER-GOOD

5V OUTPUT

C2

*

SKIP

10

GND

8

*V

L

DIODES AND OUTPUT SCHOTTKY DIODES REQUIRED

FOR THE MAX1902 ONLY (SEE THE OUTPUT OVERVOLTAGE PROTECTION

AND OUTPUT UNDERVOLTAGE SHUTDOWN PROTECTION SECTIONS).

Figure 10. Triple Output Application for MAX1902

28 ______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

5V OUTPUT

*

C1

ON/OFF

* *

INPUT

6V TO 24V

R1

C3

0.1

µF

L1

Q1

10

4.7

µF

0.1

µF

0.1

µF

V+ SHDN SECFB V

L

BST5

DH5

BST3

DH3

1N5819

Q2

LX5 LX3

DL5

MAX1901

MAX1904

DL3

PGND

CSH5

CSL5

CSH3

CSL3

OPEN

0

ON/OFF

ON/OFF

FB5

FB3

RESET

TIME/ON5

RUN/ON3

SKIP

STEER

GND

REF SYNC SEQ

5V ALWAYS ON

4.7

µF

0.1

µF

Q3

0.1

µF

L2

Q4

1N5819

RESET OUTPUT

R2

OPEN

0

3.3V OUTPUT

C2

*

1

µF

*V

L

DIODES AND OUTPUT SCHOTTKY DIODES REQUIRED

FOR THE MAX1901 ONLY (SEE THE OUTPUT OVERVOLTAGE PROTECTION

AND OUTPUT UNDERVOLTAGE SHUTDOWN PROTECTION SECTIONS).

Figure 11. Dual 6A Notebook Computer Power Supply

______________________________________________________________________________________ 29

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

DEVICE

MAX1901

MAX1902

MAX1904

AUXILLARY OUTPUT

None (SECFB input)

12V Linear Regulator

None (SECFB input)

SECONDARY FEEDBACK

Selectable (STEER pin)

Feeds into the 5V SMPS

Selectable (STEER pin)

Selector Guide

OVER/UNDERVOLTAGE

PROTECTION

Yes

Yes

No

Pin Configurations

TOP VIEW

CSH3

1

CSL3

2

FB3 3

12OUT 4

V

DD

5

SYNC 6

TIME/ON5 7

GND 8

REF

9

SKIP

10

RESET 11

FB5 12

CSL5

13

CSH5

14

MAX1902

28

RUN/ON3

27 DH3

26

LX3

25 BST3

24 DL3

23 SHDN

22 V+

21 V

L

20

PGND

19

DL5

18

BST5

17

LX5

16 DH5

15

SEQ

SSOP

CSH3

1

CSL3

2

FB3 3

STEER 4

SECFB 5

SYNC

6

TIME/ON5 7

GND 8

REF 9

SKIP

10

RESET 11

FB5 12

CSL5

13

CSH5 14

MAX1901

MAX1904

28

27

RUN/ON3

DH3

26

LX3

25

BST3

24

DL3

23 SHDN

22

V+

21 V

L

20

PGND

19

DL5

18

BST5

17

LX5

16 DH5

15

SEQ

SSOP

12OUT

V

DD

SYNC

TIME/ON5

GND

N.C.

REF

SKIP

5

6

7

8

1

2

3

4

MAX1902

20

19

18

17

24 BST3

23 DL3

22

21

SHDN

V+

V

L

PGND

DL5

BST5

STEER

SECFB

SYNC

TIME/ON5

1

2

3

4

GND

N.C.

REF

SKIP

5

6

7

8

MAX1901

MAX1904

32 THIN QFN 5mm

× 5mm

32 THIN QFN 5mm

× 5mm

30 ______________________________________________________________________________________

20

19

18

17

24 BST3

23 DL3

22

21

SHDN

V+

V

L

PGND

DL5

BST5

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Package Information

(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information go to www.maxim-ic.com/packages.)

2 1

E H

DIM

A

A1

D

E

B

C e

H

L

INCHES MILLIMETERS

MIN

0.068

MAX

0.078

MIN

1.73

0.002

0.010

0.008

0.015

0.05

0.25

0.004

0.008

0.09

SEE VARIATIONS

MAX

1.99

0.21

0.38

0.20

0.205

0.212

0.0256 BSC

0.301

0.025

0∞

0.311

0.037

8∞

5.20

5.38

0.65 BSC

7.65

0.63

0∞

7.90

0.95

8∞

D

D

D

D

D

INCHES

MIN MAX

0.239

0.239

0.278

0.317

0.397

0.249

0.249

0.289

0.328

0.407

MILLIMETERS

MIN

6.07

6.07

7.07

8.07

10.07

MAX

6.33

6.33

7.33

8.33

10.33

N

14L

16L

20L

24L

28L

N

A

B e

A1

L

D

NOTES:

1. D&E DO NOT INCLUDE MOLD FLASH.

2. MOLD FLASH OR PROTRUSIONS NOT TO EXCEED .15 MM (.006").

3. CONTROLLING DIMENSION: MILLIMETERS.

4. MEETS JEDEC MO150.

5. LEADS TO BE COPLANAR WITHIN 0.10 MM.

C

PROPRIETARY INFORMATION

TITLE:

PACKAGE OUTLINE, SSOP, 5.3 MM

APPROVAL DOCUMENT CONTROL NO.

21-0056

REV.

C

1

1

______________________________________________________________________________________ 31

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Package Information (continued)

(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information go to www.maxim-ic.com/packages.)

PIN # 1

I.D.

D

D/2

0.15 C A

0.15 C B

E/2

E

(NE-1) X e

DETAIL A k

D2

D2/2 b

0.10 M C A B

PIN # 1 I.D.

0.35x45∞

E2/2

C

L E2

L k e

(ND-1) X e

C

A1 A3

A

0.10 C

0.08 C

L

CL e

L e

PROPRIETARY INFORMATION

TITLE:

PACKAGE OUTLINE

16, 20, 28, 32L, QFN THIN, 5x5x0.8 mm

APPROVAL DOCUMENT CONTROL NO.

REV.

21-0140 C

1

2

32 ______________________________________________________________________________________

500kHz Multi-Output, Low-Noise Power-Supply

Controllers for Notebook Computers

Package Information (continued)

(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information go to www.maxim-ic.com/packages.)

COMMON DIMENSIONS

EXPOSED PAD VARIATIONS

NOTES:

1. DIMENSIONING & TOLERANCING CONFORM TO ASME Y14.5M-1994.

2. ALL DIMENSIONS ARE IN MILLIMETERS. ANGLES ARE IN DEGREES.

3. N IS THE TOTAL NUMBER OF TERMINALS.

4. THE TERMINAL #1 IDENTIFIER AND TERMINAL NUMBERING CONVENTION SHALL CONFORM TO JESD 95-1

SPP-012. DETAILS OF TERMINAL #1 IDENTIFIER ARE OPTIONAL, BUT MUST BE LOCATED WITHIN THE

ZONE INDICATED. THE TERMINAL #1 IDENTIFIER MAY BE EITHER A MOLD OR MARKED FEATURE.

5. DIMENSION b APPLIES TO METALLIZED TERMINAL AND IS MEASURED BETWEEN 0.25 mm AND 0.30 mm

FROM TERMINAL TIP.

6. ND AND NE REFER TO THE NUMBER OF TERMINALS ON EACH D AND E SIDE RESPECTIVELY.

7. DEPOPULATION IS POSSIBLE IN A SYMMETRICAL FASHION.

8. COPLANARITY APPLIES TO THE EXPOSED HEAT SINK SLUG AS WELL AS THE TERMINALS.

9. DRAWING CONFORMS TO JEDEC MO220.

10. WARPAGE SHALL NOT EXCEED 0.10 mm.

PROPRIETARY INFORMATION

TITLE:

PACKAGE OUTLINE

16, 20, 28, 32L, QFN THIN, 5x5x0.8 mm

APPROVAL DOCUMENT CONTROL NO.

REV.

21-0140 C

2

2

Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.

Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 ____________________ 33

© 2003 Maxim Integrated Products Printed USA is a registered trademark of Maxim Integrated Products.

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
