Abstract
Vibration in metal cutting is a common problem in the manufacturing industry, especially when long and slender tool holders or boring bars are involved
in the manufacturing process. Vibration has a detrimental effect on machining.
In particular the surface finish is likely to suffer, but tool life is also most likely
to be reduced. Tool vibration also results in loud noise that may disturb the
working environment.
The first part of this thesis describes the development of a robust and manually adjustable analog controller capable of actively controlling boring bar vibrations related to internal turning. This controller is compared with an adaptive
digital feedback filtered-x LMS controller and it displays similar performance
with a vibration attenuation of up to 50 dB.
A thorough experimental investigation of the influence of the clamping properties on the dynamic properties of clamped boring bars is also carried out in
second part of the thesis. In relation to this, it is demonstrated that the number of clamping screws, the clamping screw diameter size, the screw tightening
torque and the order the screws are tightened, have a significant influence on
a clamped boring bar’s eigenfrequencies as well as on its mode shape orientation in the cutting speed - cutting depth plane. Also, an initial investigation of
nonlinear dynamic properties of clamped boring bars was carried out.
Furthermore, vibration in milling has also been studied in relation to milling
tool holders with a long overhang. A basic investigation concerning the spatial
dynamic properties of the tool holders of milling machines, both when not cutting and during cutting, has been carried out. Also, active control of milling
tool holder vibration has been investigated and a first prototype of an active
milling tool holder was implemented and tested. The challenge of transferring
electrical power while maintaining good signal quality to and from a rotating
object is addressed and a solution to this is proposed.
Finally, vibration is also a problem for the hydroelectric power industry.
In Sweden, hydroelectric power plants stand for approximately half of Sweden’s
electrical power production and are also considered to be a so-called green source
of energy. When renovating water turbines in small-scale hydroelectric power
plants and modifying them to optimize efficiency, it is not uncommon that disturbing vibrations occur in the power plant. These vibrations have a negative
influence on the production capacity and will wear various components quickly.
Occasionally, these vibrations may cause severe damage to the power plant.
To identify this vibration problem, experimental modal analysis and operating
deflection shape analysis were utilized. To reduce the vibration problem, active control using inertial mass actuators was investigated. Preliminary results
indicate a significant attenuation of the vibrations.
