FEATURES

Charge Balancing ADC

24 Bits No Missing Codes

0.0015% Nonlinearity

Five-Channel Programmable Gain Front End

Gains from 1 to 128

Can Be Configured as Three Fully Differential

Inputs or Five Pseudo-Differential Inputs

Three-Wire Serial Interface

SPI™, QSPI™, MICROWIRE™ and DSP Compatible

3 V (AD7714-3) or 5 V (AD7714-5) Operation

Low Noise (<150 nV rms)

Low Current (350␣

A typ) with Power-Down (5 A typ)

AD7714Y Grade:

+2.7 V to 3.3 V or +4.75 V to +5.25 V Operation

0.0010% Linearity Error

–40

C to +105C Temperature Range

Schmitt Trigger on SCLK and DIN

Low Current (226␣

A typ) with Power-Down (4 A typ)

Lower Power Dissipation than Standard AD7714

Available in 24-Lead TSSOP Package

Low-Pass Filter with Programmable Filter Cutoffs

Ability to Read/Write Calibration Coefficients

APPLICATIONS

Portable Industrial Instruments

Portable Weigh Scales

Loop-Powered Systems

Pressure Transducers

GENERAL DESCRIPTION†

The AD7714 is a complete analog front end for low-frequency measurement applications. The device accepts low level signals directly from a transducer and outputs a serial digital word. It employs a sigma-delta conversion technique to realize up to 24 bits of no missing codes performance. The input signal is applied to a proprietary programmable gain front end based around an analog modulator. The modulator output is processed by an onchip digital filter. The first notch of this digital filter can be programmed via the on-chip control register allowing adjustment of the filter cutoff and settling time.

The part features three differential analog inputs (which can also be configured as five pseudo-differential analog inputs) as well as a differential reference input. It operates from a single supply (+3␣ V or +5␣ V). The AD7714 thus performs all signal conditioning and conversion for a system consisting of up to five channels.

The AD7714 is ideal for use in smart, microcontroller- or DSPbased systems. It features a serial interface that can be configured

†See page 39 for data sheet index.

SPI and QSPI are trademarks of Motorola, Inc.

MICROWIRE is a trademark of National Semiconductor Corporation.

REV. C

Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices.

3 V/5 V, CMOS, 500

A

Signal Conditioning ADC

AD7714

AIN1

AIN2

AIN3

AIN4

AIN5

AIN6

FUNCTIONAL BLOCK DIAGRAM

AV

DD

DV

DD

REF IN(–) REF IN(+)

AV

DD

1

m

A

AGND

1

m

A

BUFFER PGA

CHARGE

BALANCING

A/D CONVERTER

Σ

-

MODULATOR

DIGITAL FILTER

A = 1–128

SERIAL INTERFACE

REGISTER BANK

STANDBY

SYNC

BUFFER

MCLK IN

MCLK OUT

CLOCK

GENERATION

AD7714

SCLK

CS

DIN

DOUT

AGND

DGND POL

DRDY RESET

for three-wire operation. Gain settings, signal polarity and channel selection can be configured in software using the serial port. The

AD7714 provides self-calibration, system calibration and background calibration options and also allows the user to read and write the on-chip calibration registers.

CMOS construction ensures very low power dissipation, and the power-down mode reduces the standby power consumption to

15␣

µ

W typ. The part is available in a 24-pin, 0.3 inch-wide, plastic dual-in-line package (DIP); a 24-lead small outline (SOIC) package, a 28-lead shrink small outline package (SSOP) and a

24-lead thin shrink small outline package (TSSOP).

PRODUCT HIGHLIGHTS

1. The AD7714Y offers the following features in addition to the standard AD7714: wider temperature range, Schmitt trigger on SCLK and DIN, operation down to 2.7 V, lower power consumption, better linearity, and availability in 24-lead

TSSOP package.

2. The AD7714 consumes less than 500

µ

A (f

CLK IN

= 1␣ MHz) or 1 mA (f

CLK IN

= 2.5␣ MHz) in total supply current, making it ideal for use in loop-powered systems.

3. The programmable gain channels allow the AD7714 to accept input signals directly from a strain gage or transducer removing a considerable amount of signal conditioning.

4. The AD7714 is ideal for microcontroller or DSP processor applications with a three-wire serial interface reducing the number of interconnect lines and reducing the number of optocouplers required in isolated systems. The part contains on-chip registers that allow control over filter cutoff, input gain, channel selection, signal polarity and calibration modes.

5. The part features excellent static performance specifications with 24-bit no missing codes,

±

0.0015% accuracy and low rms noise (140 nV). Endpoint errors and the effects of temperature drift are eliminated by on-chip self-calibration, which removes zero-scale and full-scale errors.
