ZS-BT1
ZS-BT1
Boombox with Bluetooth® Technology
Bluetooth® Capability (A2DP)2
Audio-in for Digital Music Player or PC
Stylish, Slim Body with Front Loading CD
High Power 4.5 Watts per Channel Output
MEGA BASS® Sound System
Digital AM/FM Stereo Tuner
30 Station Memory Presets (10AM/20FM)
2 Line Dot-Matrix LCD with Back Light
CD-R/RW Playback1
Remote Control for Tuner and CD Operation
ZS-BT1
Features
Bluetooth® Capability (A2DP)1 allows you to wirelessly
stream and listen to music on your boombox from a Bluetooth
capable2 cell phone or from a digital music player with a
Bluetooth adaptor(sold separately).
Audio-in for Digital Music Player or PC allows for simple plugand-play integration with a digital music player or PC making it
easy to listen to your favorite music no matter where you're at.
Stylish, Slim Body with Front Loading CD Design provides easy
access to your CD for playback functionality.
High Power 4.6 Total Watts for dynamic sound quality.
MEGA BASS® Sound System produces rich, deep, bass tones
for more powerful overall sound.
Boombox with Bluetooth® Technology
Equalizer: 5 presets (Rock, Pop, Jazz, Vocal, Custom)
Tuner Type: Digital
Backlit Color: Blue
Hardware
Remote Control: Yes
Power
Power Requirements: 4.6W Total (1.8W + 1.8W (at 3.2 ohms, 10%
harmonic distortion)
Battery Type: Unit: “D” x 6 (optional); Remote: “AAA” x 2
Power Consumption (in Operation): 16W
Power Handling Capacity: With 3.2-ohm loads, both channels
driven from 150-6300Hz; rated 1.8 W per channel minimum RMS
power, with no more than 10% total harmonic distortion in AC
operation
Speaker
Digital AM/FM Stereo Tuner provides the most accurate driftfree tuning of AM and FM radio stations and lets you choose
from a wide variety of radio, talk and music programs with the
added enjoyment of stereo sound.
Speaker System: Built-In Stereo
Speaker Dimensions: 4" (10cm) x 2
Speaker Type: Bass Reflex Speaker system
30 Station Memory Presets lets you quickly and easily tune in
to your choice of up to 10 AM or 20 FM radio stations.
Headphone Input(s): 1
DC-In: 1
PC Audio Input(s): Yes
2 Line Dot-Matrix LCD Display with Back Light provides ID3 tag
information for fast and easy identification and location of your
ATRAC® or MP3 selections and makes it easy to search all
music files even in another folder layer.
CD-R/RW Playback1 plays back CD-R/RW discs burned either
in a PC or a home recording deck. Create custom mixes from
your existing personal music collection.
Remote Control for Tuner and CD Operation includes keys to
directly access tracks on a CD as well as pre-set stations
programmed into tuner memory.
CD Play Modes (Program/Shuffle/Repeat) lets you hear
tracks in sequence as recorded, in program(RMS)order, a
single track over and over or all tracks in random (shuffle)
order.
Specifications
Inputs and Outputs
Dimensions
Weight: 4.3 with battery, 3.7 without battery
Measurements: 480 x 156 x 250mm
Supplied Accessories
AC Power Cord
Remote Control
Color: Silver
UPC Code: 027242698260
1. CD-R/RW media/formats are not universally compatible.
2. Not all Bluetooth enabled devices may communicate with each other.
©2005 Sony Electronics Inc.
Sony, like no other, Remote Commander, and S-Master are trademarks of Sony. All other trademarks are
property of their respective owners.
Bluetooth is a trademark of the Bluetooth SIG.
Features and specifications are subject to change without notice. Non-metric weights and measures are
approximate.
General
Type of Use: Portable Boombox
Tray Type: Front Loading Single CD
Disc Capacity: 1
Audio
Digital-to-Analog Converter: 1 Bit
Frequency Response: CD: 20-20000Hz (+1/-2dB)
Format(s) Supported: CD-R/RW Playback Compatibility1
Tuning: Auto Scan Radio
Antenna System: AM: Built-in Ferrite Bar Antenna; FM: Telescopic
Antenna
Frequency Range: AM: 530-1710kHz; FM: 87.5-108.0MHz
CD Play Mode(s): Program, Shuffle, Repeat, 20 Track RMS
Programming
Station Preset(s): 30(10 AM, 20 FM)
Sound Enhancer: Mega Bass®
Please visit the Dealer Network for current information at
www.sony.com/dn
Sony Electronics Inc. •16530 Via Esprillo •San Diego, CA 92127 •1.800.222.7669 •www.sony.com
Last Updated: 10/08/2007
