Rehab Shower Commode
Wheelchair Accessories
The versatile E&J Folding Rehab Shower
Commode chair has earned the reputation of being the premier self-propelled
chair for personal hygiene care. This
chair features an overall narrow width
and a corrosion-resistant stainless steel
frame. The chair can be positioned over
a standard toilet or be used as a portable,
self-contained commode.
Standard Features
• Recessed seat and frame side contours allow easy access
for toileting activities while seated
• Durable 24" one piece composite wheels with integral
handrims and solid rubber tires
• Cushioned vinyl seat is sealed against moisture
penetration and vented for optimal foam compression
• Chair comes standard with oval opening seat
(C-shaped and solid seat are optional)
• Completely removable full length arms for ease of transfer
• Swingaway, detachable footrests permit close approaches
to beds, toilets and wheelchairs
• Removable, hygienic plastic pail and lid are included
• Non-corrosive composite footplates
• Maximum weight capacity 250 lb
• Meets Medicare Code E1399
Wa rranty
Two year limited warranty on side frames and crossbraces.
Rehab Commode – 1202 series
Seat Width
Seat
Depth
Seat
Height
Overall Width
Overall Depth
Product
Weight
Advantage - 3H01 series
18" or 20"
16"
19 1/2"
26" or 28 1/2"
32"
40 lbs
Traveler SE - 3E01 series
16", 18" or
20"
16"
18" or 24 1/2", 26 1/2" or 28
20"
1/2"
31 1/2"
40 lbs
Traveler L3 - 3F01 series
16", 18" or
20"
Wheelchair Model
18" or 24 1/2", 26 1/2" or 28
20"
1/2"
29"
34 lbs
18" or
20"
23", 25" or 27"
31 1/2"
32 lbs
18" or
20"
28 1/2" , 30 1/2" or 32
1/2"
34"
57 lbs
20 1/2"
35 1/2" or 39 1/2"
33 3/4"
90 lbs
Transport Chairs (Aluminum) EJ78 series
17" or 19" 15 3/4"
19"
22 3/4" or 24 3/4"
37"
20 lbs
Transport Chairs (Steel)
19"
22 3/4" or 24 3/4"
37"
24 lbs
Traveler L4 - 3F02 series
16"
16", 18" or 16" or
20"
18"
Traveler HD - 3G01 series
20", 22" or
24"
Paramount XD - 5PX1 series
26" or 30" 19 1/2"
18"
17" or 19" 15 3/4"
Transport Chairs - Bariatric
EJ777-1
24"
15 3/4"
20"
29 1/2"
40"
33 lbs
Traveler Recliner - 5101 series
16", 18" or
20"
17"
19 3/4"
24 1/4", 26 1/4" or 28
1/4"
36"
55 lbs
17"
18"
23 1/2"
25"
40"
45 lbs
Rehab Shower Commode -
NOTE: Everest & Jennings maintains the policy of continual product improvement,
therefore, we reserve the right to make changes without notice. All dimensions are ±1/4".
*Without Front Rigging.
Graham-Field offers a range of complementary products for
its wheelchair products.
Skin Protection and Positioning Cushion
Provides long-term skin protection and positioning
for high-risk patients. A specialized gel center surrounded by comfortable foam layers reduces tissue
interface pressures at critical points. Soft stretchable cover
is moisture resistant and reduces shear/friction. 350 lb
weight capacity.
Two year limited warranty 8920 series
Skin Protection Cushion
Reduces surface pressure through the use of a proprietary non-aqueous gel placed in three pressure
zones. The cushion uses high-density base foam in
combination with a visco-elastic topper for added comfort
and also positions the user with a moderate slope from
front to back. 250 lb weight capacity. Available in standard
and bariatric sizes. 18 month warranty 8930 series
Basic Wedge Cushion
Features a specialized gel layer with a convoluted
foam topper that reduces tissue interface pressures
at critical points. Moderate wedge design slopes from 4” in
front to 3 1/4” in the rear. Soft stretchable cover is moisture
resistant and reduces shear/friction. 350 lb weight capacity.
Two year limited warranty 8220 series
Wheelchair IV/O2 Holder Combo
Combination IV holder and O2 cylinder holder
(cylinder not included) B10320F
Wheelchair Side Pouch
Convenient black side pouch attaches to
manual wheelchair arm for
extra storage
EJSIDE07
Wheelchair O2 Holder Bag
Adjustable black bag holds D
or E cylinders (cylinder not
included) EJ02BAG07
Wheelchair Anti-Fold Bar
Used on 16" - 24" wide wheelchairs to prevent
folding of wheelchair and deter theft 92523850
GF Health Products, Inc. Atlanta, Georgia 30360
770.368.4700 www.grahamfield.com
© 2011, GF Health Products, Inc.
GF1100003 RevB11
The
brand has set the standard for
manual wheelchairs for over 76 years. As the inventor of
the first folding wheelchair that revolutionized the
market, Everest & Jennings continues in its tradition of
providing the innovation and the quality that you have
come to expect. Graham-Field is committed to meeting
both the needs of our customers and users with our
wheelchair offering that includes:
r Designs that are durable, built to last and
meet RESNA standards for wheelchairs
r An extensive line of ready-to-ship wheelchairs to meet all your consumer needs
r Product offerings that provide value and
are efficient for inventory management
such as interchangeability in parts
Graham-Field is focused on delivering the utmost quality,
value and providing continuous improvements of our
wheelchair line.
Advantage®
The Advantage wheelchair
provides comfort and durability at
an affordable price. Designed as a
low maintenance wheelchair, it
offers a silver vein durable
hammertone steel finish that is
both attractive and long lasting.
Standard Features
• Black, padded nylon upholstery, Vinyl Upholstery option
available
• Industry compatible “tool-free” adjustable front rigging
with heel loops standard on swing away footrests
• Sleek, hammertone silver vein finish
• Comfortable padded armrests
• Chart pocket on back
• Push to lock brakes
• 250 lb. weight capacity
• Meets Medicare code K0001
Wa rranty
Limited one year on side frames and crossbraces
Advantage wheelchairs – 3H01series
Traveler® SE
The Traveler SE is the standard
wheelchair of choice. Designed
with dual rear axles and adjustable
casters, this wheelchair can convert from a K0001 Medicare code
to a K0002 Medicare code.
The Traveler SE has industry
compatible front rigging and has
vinyl upholstery constructed with a strong inner lining for
added support.
Standard Features
• Black vinyl upholstery
• Chart pocket on back
• Industry compatible “tool-free” adjustable front rigging
with heel loops standard on swing away footrests
• Hammertone paint provides a long lasting and
durable finish
• Two position axle and caster fork provides 2" seat
height adjustment
• 250 lb. weight capacity
• Meets Medicare code K0001 and K0002
Wa rranty
Limited one year on side frames and crossbraces
Traveler SE wheelchairs – 3E01series
Traveler® L3
The Traveler L3 lightweight frame
weighs less than 36 pounds
making it the ideal K0003 Medicare
coded wheelchair built for short
and long term use as well as rental
needs. Designed with dual axles
and multi-position caster forks, this
wheelchair provides an adjustable
seat height of 18 or 20 inches.
Standard Features
• Weighs less than 36 lbs. without front rigging
• Durable, long lasting carbon steel frame
• Black, padded nylon upholstery
• Chart pocket on back
• Industry compatible “tool-free” adjustable front rigging
with heel loops standard on swing away footrests
• Non-marking polyurethane rear tires
• Detachable Desk and Full Length Armrest options
• 250 lb. weight capacity
• Meets Medicare code K0003
Wa rranty
Limited Lifetime Warranty on side frame and crossbraces
Traveler L3 wheelchairs – 3F01series
Traveler® L4
The new Traveler L4 is a high
strength; lightweight Medicare
approved K0004 wheelchair
designed for both the home and
rehab markets. Weighing less than
34 lbs, it features a dual position
axle, multi-position caster forks for
18 or 20 inch seat height adjustment and offers flip back desk and
full length arm options for easy lateral movement. Precision
bearings and non-marking polyurethane rear tires also
expand the longevity of the wheelchair.
Standard Features
• Black, padded nylon upholstery
• Chart pocket on back
• Anti-tippers come standard
• Non-marking polyurethane tires,
Quick Release option available
• Industry compatible “tool-free” adjustable front rigging
with heel loops standard on swing away footrests
• Flip back desk and full arm options for lateral transfers,
(Height adjustable desk arms available)
• Height adjustable back
• 250 lb. weight capacity, 300 lb. on 18" seat depth models
• Meets Medicare code K0004
Wa rranty
Limited lifetime warranty on sideframe and crossbraces
Traveler L4 wheelchairs – 3F02 series
(3F03 for 18" seat depth models)
Traveler® H D
Built to support up to 500 lb; this
heavy duty wheelchair was
designed with precise engineering
and key reinforcements throughout
its structure. Double cross braces,
precision bearings and reinforced
gussets add strength to this wheelchair. The vinyl upholstery with
double inner lining prevents sagging. The Traveler HD,
available in 20", 22" and 24" wide options offers 24"
polyurethane tires along with durable aluminum footplates
to withstand everyday use.
Standard Features
• Embossed black upholstery with double
inner lining for durability
• Hammertone silver vein style provides a long lasting
and durable finish
• Reinforced frame at all critical load-bearing points
• Industry compatible “tool-free” adjustable front rigging
with heel loops standard on swing away footrests
• Chart pocket standard
• 24" x 1" black plastic wheels with black handrims and
non-marking polyurethane tires
• Durable aluminum black footplates
• Available in Detachable Desk and Full Length Armrests
• Two position axle and caster fork provides 2" seat
height adjustment
• 500 lb. weight capacity
• Meets Medicare code K0007
Wa rranty
5 year warranty on side frame and crossbraces
Traveler HD wheelchairs – 3G01 series
Paramount® XD
The Paramount XD is ideal for the
bariatric user that requires a larger
seat. With 26" and 30" seat width
options and 19 1/2" seat depth,
this wheelchair is designed to provide additional comfort and support up to a 650 lb weight capacity.
Standard Features
• Black reinforced, padded nylon
upholstery
• Reinforced welds and gussets on frame
• Desk arm with optional Swingaway footrest and
Elevating legrest front rigging
• Maximum weight capacity of 650 lb.
• 8"x 2" Solid casters
• 24" Solid rear wheels
Wa rranty
Limited lifetime warranty on side frame and crossbraces
Paramount HD wheelchairs – 5PX1 series
Transport Chairs
The Everest & Jennings Transport Chair is an
affordable alternative for those individuals
with limited mobility. Its compact size and
lighter weight allow a companion to lift and
store the chair with ease.
Standard Features:
• Stylish painted finishes (Red, Blue and
Silver, Pink and Aqua options for Aluminum models)
• 250 lb weight capacity
• Black, padded, nylon upholstery
• Full length arms are padded for comfort
• Fold down back makes transport and storage easy
• Comes standard with seat positioning belt
• Available in both Steel and Aluminum
• 17" and 19" seat width options
• Industry compatible swingaway footrests
• Bariatric model supporting 400 lb also available
• Meets Medicare code E1038 and E1039 (Bariatric model)
Wa rranty
One year (three year on bariatric) warranty on side
frames and crossbraces
Aluminum Transport Chair – EJ78 series
Steel Transport Chair – EJ795-1 (17") & EJ796-1 (19")
Bariatric Transport Chair –EJ777-2
Traveler® Recliner
The same built-in quality as the standard
Traveler wheelchair with the addition of a
full reclining back. The back features
unlimited adjustments using easy,
finger-trigger hinge and cable mechanisms.
The Traveler Recliner comes with a higher
back and removable full support headrest.
The Traveler Recliner offers a 250 lb weight capacity in 16", 18"
and 20" seat width options.
Standard Features
• Durable, low maintenance chrome-plated steel frame
• Rear axles are mounted further back than on standard
Traveler for added stability
• Deep Blue upholstery with inner lining (Burgundy and Black
upholstery available as options. Please see Price List/Order
Form for available options)
• Detachable desk and full length arm options with padding
for comfort
• Anti-tippers come standard
• Meets Medicare K0001 / E1226 (Recliner Back) / E0966 (Head
Rest Extension) specifications for wheelchairs.
Wa rranty
Two year limited warranty on frames and crossbraces
Traveler Recliner 5101 series
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
