This Guide Covers the Most Recommended Products for an On-Site Paging System
For More Products, visit Our Website
Paging Systems
Pagers
WaveWare Technologies, Inc.
2630 National Dr. Garland, TX. 75041
Phone: 1.800.373.1466 Fax: 972.479.1735
Website: www.WirelessMessaging.com
Email Sales: [email protected]
“We Deliver Information at the Speed of Light”
Software
On-Site Paging Systems
Highly Recommended for Most Single Com Port Applications
SPS-5 v9S at 5 Watts UHF
The WaveWare SPS-5 v9S Single Com Port
Paging System Allows you to Automatically
Transmit Messages to Industry Standard
On-Site POCSAG Pagers.
The Superior Features of the WaveWare
SPS-5 v9S Paging System Includes:
o
o
o
o
o
o
o
o
Rauland Borg Responder Nurse Call.
Emergin Wireless.
WaveWare Alert Utility.
WaveWare Enterprise Messaging.
Bosch Security Systems.
Alarm/Fire Panels.
MedHost Systems (WaveWare Protocol).
And Many other Host Systems.
o
For More Details: See v9S Brochure at…
http://www.wirelessmessaging.com/brochures.html
o
1 RS-232 Serial Com Port (DB-9 Female)
TAP, COMP1, COMP2, Scope, SNPP and
WaveWare Interface Protocols.
Compatible with Industry Standard POCSAG
Pagers.
Supports POCSAG Alphanumeric, Numeric
and Tone/Vibe Messaging at RF Pager Data
Rates of 512, 1200 and 2400 bps.
Available as UHF (400-430MHz and 440470MHz) or VHF (148-174MHz).
Supports TAP Protocol v1.8 with
Enhancements Including Control Character
Embedding, Extended Pager ID Processing
and Function Code Control.
RF Carrier Detect Feature.
o
Available in 2 or 5 watts, UHF or VHF *.
o
o
The SPS-5 v9S Paging System is Compatible with
Host Systems using the “TAP Direct” Connect
Interface, Including:
o
o
o
o
SPS-5 v9S
Includes: v9S System, Rubber Duck
Antenna, Power Supply, 10Ft. Serial
Cable, Mounting Hardware and
Installation CD.
* VHF Special Order
P/N= 0100-2701
The FCC Site Licenses Information.
o
o
o
FCC Requires that All Paging Systems have a
“Site” License.
We Offer the use of our “Shared Use” Frequency
Site Licenses.
Or we can help obtain a License for your site.
FCC
Site Licenses
WaveWare “Shared Use” Licenses & Cost:
o
o
o
You may Choose from our List of
Shared Use Frequencies
For 2 Watts: P/N= 0512-2250
For 5 watts: P/N= 0512-2253
For 25 watts: P/N= 0512-2255
o For Help Obtaining an “FCC Site License” for
Systems needing more than 25 watts: P/N= 0512-2251
On-Site Paging Systems
Highly Recommended for Most Ethernet Port Applications
SPS-5 v9E at 5 Watts UHF
The WaveWare SPS-5 v9E Ethernet Port
Paging System Allows you to Automatically
Transmit Messages to Industry Standard
On-Site POCSAG Pagers.
The Superior Features of the WaveWare
SPS-5 v9E Paging System Includes:
o
o
o
o
o
o
o
o
Rauland Borg Responder Nurse Call.
Emergin Wireless.
WaveWare Alert Utility.
WaveWare Enterprise Messaging.
Bosch Security Systems.
Alarm/Fire Panels.
MedHost Systems (WaveWare Protocol).
And Many other Host Systems.
o
For More Details: See v9E Brochure at…
http://www.wirelessmessaging.com/brochures.html
o
o
o
FCC Requires that All Paging Systems have a
“Site” License.
We Offer the use of our “Shared Use” Frequency
Site Licenses.
Or we can help obtain a License for your site.
o
Available in 2 or 5 watts, UHF or VHF *.
o
o
o
o
o
SPS-5 v9E
Includes: v9E System, Rubber Duck
Antenna, Power Supply, (1) 10Ft. Serial
Cable, (1) Ethernet Cable, Mounting
Hardware and Installation CD.
P/N= 0100-2901
The FCC Site Licenses Information.
o
1 Ethernet Port (Supports 1 IP Address with
2 Socket Connections)
1 RS-232 Serial Com Port (DB-9 Female)
TAP, COMP1, COMP2, Scope, SNPP and
WaveWare Interface Protocols on Both Ports.
Compatible with Industry Standard POCSAG
Pagers.
Supports POCSAG Alphanumeric, Numeric
and Tone/Vibe Messaging at RF Pager Data
Rates of 512, 1200 and 2400 bps.
Available as UHF (400-430MHz and 440470MHz) or VHF (148-174MHz).
Supports TAP Protocol v1.8 with
Enhancements Including Control Character
Embedding, Extended Pager ID Processing
and Function Code Control.
RF Carrier Detect Feature.
o
The SPS-5 v9E Paging System is Compatible with
Host Systems using an Ethernet Connection or using
a “TAP Direct” Connect Interface, Including:
FCC
Site Licenses
o
* VHF Special Order
WaveWare “Shared Use” Licenses & Cost:
o
o
o
You may Choose from our List of
Shared Use Frequencies
For 2 Watts: P/N= 0512-2250
For 5 watts: P/N= 0512-2253
For 25 watts: P/N= 0512-2255
o For Help Obtaining an “FCC Site License” for
Systems needing more than 25 watts: P/N= 0512-2251
On-Site Paging Systems
Recommended for Most 2-Serial Com Port Applications
SPS-5 v9 at 5 Watts UHF
The WaveWare SPS-5 v9 Dual Com Port
Paging System Allows you to Automatically
Transmit Messages to Industry Standard
On-Site POCSAG Pagers.
The Superior Features of the WaveWare
SPS-5 v9 Dual Com Port Paging System
Includes:
The SPS-5 v9 Paging System is Compatible with Host
Systems using the “TAP Direct” Connect Interface,
Including:
o
o
o
o
o
o
o
o
o
o
Rauland Borg Responder Nurse Call.
Emergin Wireless.
WaveWare Alert Utility.
WaveWare Enterprise Messaging.
Bosch Security Systems.
Alarm/Fire Panels.
MedHost Systems (WaveWare Protocol).
And Many other Host Systems.
o
For More Details: See v9 Brochure at…
http://www.wirelessmessaging.com/brochures.html
o
2 RS-232 Serial Com Ports (DB-9 Female)
TAP, COMP1, COMP2, Scope, SNPP and
WaveWare Interface Protocols.
Compatible with Industry Standard POCSAG
Pagers.
Supports POCSAG Alphanumeric, Numeric
and Tone/Vibe Messaging at RF Pager Data
Rates of 512, 1200 and 2400 bps.
Available as UHF (400-430MHz and 440470MHz) or VHF (148-174MHz).
Supports TAP Protocol v1.8 with
Enhancements Including Control Character
Embedding, Extended Pager ID Processing
and Function Code Control.
RF Carrier Detect Feature.
o
Available in 2 or 5 watts, UHF or VHF *.
o
o
o
WaveWare SPS-5 v9
(Dual Com Port)
Includes: v9 System, Rubber Duck
Antenna, Power Supply, 10Ft. Serial
Cable (1), Mounting Hardware and
Installation CD.
o
* VHF Special Order
P/N= 0100-2601
The FCC Site Licenses Information.
o
o
o
FCC Requires that All Paging Systems have a
“Site” License.
We Offer the use of our “Shared Use” Frequency
Site Licenses.
Or we can help obtain a License for your site.
FCC
Site Licenses
WaveWare “Shared Use” Licenses & Cost:
o
o
o
You may Choose from our List of
Shared Use Frequencies
For 2 Watts: P/N= 0512-2250
For 5 watts: P/N= 0512-2253
For 25 watts: P/N= 0512-2255
o For Help Obtaining an “FCC Site License” for
Systems needing more than 25 watts: P/N= 0512-2251
On-Site Alphanumeric Pagers
Models Recommended for Most Applications
Apollo Gold or 924 UHF
P/N= 929-460MHz
The Apollo Gold Alphanumeric Pager.
o
o
o
o
o
o
o
o
o
The Apollo Gold Specifications:
Synthesized (Default) or Crystal Types.
True Pocket Size.
4-Line with ZOOM.
Large LCD Display.
Blue Back-Lit Display.
User Friendly Interface.
One-Button-Delete Feature.
Selective PC or Hand Programmable.
Supported Languages: English, Spanish,
Portuguese, Russian, German and French.
o
o
o
o
o
o
o
Frequency Bands: UHF 408-473MHz,
VHF 138-174MHz and 929-932MHz.
Pager Baud Rates: 512, 1200 and 2400 bps.
Code Format: POCSAG and Flex.
Alert Tone Loudness: [email protected] (12”).
Channel Spacing: 25 KHz and 12.5 KHz.
Cap Codes: 6 Cap Codes POCSAG, 16 Flex.
Dimension: 80 (L) x 53(W) x 20 (H) mm
o
For More Details: See Gold Brochure at…
o
Apollo Gold (ALA-25)
Recommended For use: With Our SPS-5 v9S or
the SPS-5 v9 or v9E Paging Systems.
Includes: Holster, Chain, Battery and
User Guide.
http://www.wirelessmessaging.com/brochures.html
P/N= 924ES460
The Apollo 924 Alphanumeric Pager.
o
o
o
o
o
o
o
The Apollo 924 Specifications:
Portuguese, Russian, German and French.
o
o
o
o
o
o
o
Frequency Bands: UHF 408-473MHz,
VHF 138-174MHz and 929-932MHz.
Pager Baud Rates: 512, 1200 and 2400 bps.
Code Format: POCSAG and Flex.
Alert Tone Loudness: [email protected] (12”).
Channel Spacing: 25 KHz and 12.5 KHz.
Cap Codes: 6 Cap Codes POCSAG, 16 Flex.
Dimension: 64 (L) x 43(W) x 20 (H) mm
o
For More Details: See 924 Brochure at…
o
Synthesized (Default) or Crystal Types.
True Mini - Pocket Size.
4-Line with ZOOM.
Large LCD Display.
User Friendly Interface.
Selective PC or Hand Programmable.
Supported Languages: English, Spanish,
Recommended For use: With Our SPS-5 v9S or
the SPS-5 v9 or v9E Paging Systems.
Apollo 924 (AL-924)
Includes: Holster, Chain, Battery and
User Guide.
http://www.wirelessmessaging.com/brochures.html
Or ask us about our other Pager Models
WaveWare Wallpager LED Displays
Models Recommended for Most Applications
AS-112, AS-112R and AS-122, AS-122R
The AS-112 Wallpager.
o
o
o
o
o
o
o
o
1 or 2 Line Display (4” or 2” Fonts).
Red Display Color (10 or 24 Characters).
Built-in Paging Data Receiver.
Works like a Pager.
Displays up to 24 Messages.
Synthesized Receiver.
PC Programmable for Freq., CC and BR.
Use the Message Time Out Feature or use
the “Reset” Message Delete Command.
o
Recommended For use: With Our SPS-5 v9
or the SPS-5 v9S or v9E Paging Systems.
The AS-112R Wallpager.
o
o
o
o
o
o
o
o
o
1 or 2 Line Display (4” or 2” Fonts).
Red Display Color (10 or 24 Characters).
Built-in Paging Data Receiver.
Works like a Pager.
Displays up to 24 Messages.
Synthesized Receiver.
PC Programmable for Freq., CC and BR.
Built-in Relay for Annunciation Devices.
Use the Message Time Out Feature or use
the “Reset” Message Delete Command.
o
Recommended For use: With Our SPS-5 v9
or the SPS-5 v9S or v9E Paging Systems.
P/N= AS112
The AS-112 Specifications:
o
o
o
o
o
o
o
Frequency Bands: UHF 408-473MHz,
VHF 138-174MHz and 929-932MHz.
Pager Baud Rates: 512, 1200 and 2400 bps.
Code Format: POCSAG and Flex.
LED Array: 320 x 16
Channel Spacing: 12.5 KHz.
Cap Codes: 6 Cap Codes POCSAG, 16 Flex.
Dimension: 28 (L) x 3 (D) x 6 (H) inches.
Also Avail: in 20 or 52 Characters (AS-122).
o
For More Details: See AS-112 Brochure at…
o
Wallpager (2 Line Mode)
Includes: Programming Software and
OTA Commands on CD.
http://www.wirelessmessaging.com/Product_Brochures.html
P/N= AS112R
The Apollo AS-112R Specifications:
o
o
o
o
o
o
o
o
Frequency Bands: UHF 408-473MHz,
VHF 138-174MHz and 929-932MHz.
Pager Baud Rates: 512, 1200 and 2400 bps.
Code Format: POCSAG and Flex.
LED Array: 320 x 16
Channel Spacing: 12.5 KHz.
Cap Codes: 6 Cap Codes POCSAG, 16 Flex.
Relay Activated when Page is Received.
Dimension: 28 (L) x 3 (D) x 6 (H) inches.
Also Avail: in 20 or 52 Characters (AS-122R).
o
For More Details: See AS-112R Brochure at…
o
Wallpager (1 or 2 Line with Relay)
Includes: Programming Software and
OTA Commands on CD.
http://www.wirelessmessaging.com/Product_Brochures.html
Ask us about our Horn/Strobe Combo Annunciation Devices for Our Wallpager Displays
WaveWare Software
Software Recommended for Sending Custom Text Messages and for Port Monitoring, Routing, Escalations and Translations of Paging Messages
WaveWare Enterprise Messaging and Alert Utility Software Packages
Enterprise Messaging Features:
P/N= 0212-0003
Our Enterprise Messaging Allows you to Enhance
Operational Productivity by Delivering Messages
from your Windows Desktop to:
o
o
o
o
o
On-site Pagers
Internet Email
Wide Area (City Wide) Pagers
o
o
o
o
o
Other Features Include:
o
o
o
User Friendly Interface
The Software Requires a Registration Key
And Many more Basic Features
New Features Include: (For the Unlimited Clients Only)
o
o
Web Client to Send Email via your Web Browser
Web Browser Messaging Interface
* Our Enterprise Lite (3 Client Version) is Also Available
Alert Utility Features:
Enterprise Messaging
Includes: Unlimited Clients and
Web Client Browser Feature and
Much more.
Desktop Computer Minimum Requirements:
o
o
Plain Text / COMP1, COMP2, TAP and Inovonics
Common Applications of Alert Utility Include:
o Nurse Call / Emergency Call, Building Management
Systems, Machinery Equipment, Fire Interface Panels,
Industrial Alarms and Security Systems
http://www.wirelessmessaging.com/Product_Brochures.html
P/N= 0212-0007
A Variety of Alarm and Messaging Conditions, with Key
String Matching, Translations, Repeats and Escalation
for up to 1,200 Alarm Points
Output Protocols Supported Include:
o Direct Serial TAP, SMTP (Internet E-Mail) and SNPP
(Internet Paging Carrier), LED Message Boards,
WaveWare Enterprise Software, Spectralink Wireless
Telephones and Text-to-Speech
For More Details: See Enterprise Brochure at:
NOTE: IIS Must be Turned OFF
Input Protocols Supported Include:
o
Only Desktops are Supported, NO Servers
Only Windows XP Pro and Windows 7 Pro SP1
Operating Systems are Supported
1 GHz Processor or Higher Speed
10 GB Hard Drive or Larger
2 GB Memory Minimum
1 RS-232 Serial DB-9 Com Port
1 Ethernet Port
Recommended For use:
With any of Our SPS-5 v9Series
Paging Systems.
Our Alert Utility Software Allows you to Monitor
up to 4 Serial Com Ports for:
o
Desktop Computer Minimum Requirements:
Alert Utility
Includes: Qty. 3 I/O Ports Activated.
Additional I/O Ports are Available for
Purchase, if needed.
o
o
o
o
o
o
Only Desktops are Supported, NO Servers
Only Windows XP Pro and Windows 7 Pro SP1
Operating Systems are Supported
1 GHz Processor or Higher Speed
10 GB Hard Drive or Larger
2 GB Memory Minimum
3 Minimum RS-232 Serial Com Ports
Additional I/O Ports are Available for Purchase
1 Ethernet Port
For More Details: See Alert Utility Brochure at:
http://www.wirelessmessaging.com/Product_Brochures.html
Recommended For use:
With any of Our SPS-5 v9Series
Paging Systems.
WaveWare Software - Continued
This Software Package and Products are Recommended for the Assisted Living Environment
WaveWare Call Manager Software can be used with Inovonics EchoStream Products and our SPS-5 v9 Series Paging Systems
Call Manager Features:
P/N= 0212-0022
Our Call Manager Software is Designed to Monitor Service
Requests from Both Inovonics Wireless Transmitters and
From Wired Call Systems while Notifying Call Activation and
De-Activation Events via Pager and LED Message Boards
while Logging the Event History.
o
o
o
o
o
o
Works with:
o On-Site Pagers and LED Wallpager Signs
o LED Message Boards (LED Signs)
Other Options Include:
o
o
o
o
o
o
o
o
Configure up to 2 Input Com Ports
Configure On-Site Paging Output
Station and Room Assignments
Wired and Wireless Devices
Register Receivers and Call Devices
Configure Message Boards
Assign Pagers
General Settings
Report Generation Utility Includes:
o
o
o
Report Types – Includes Sort by and Filters, Frequent
Calls and Receiver Activity and much more
Report Dates – A Particular Date or a Range of Dates
Report Dates Report Templates to be Emailed to
Recipients
Desktop Computer Minimum Requirements:
Call Manager
Monitor and Manage Events
Includes: Report Generation Utility
o
Only Desktops are Supported, NO Servers.
Only Windows XP Pro and Windows 7 Pro SP1
Operating Systems are Supported
1 GHz Processor or Higher Speed
10 GB Hard Drive or Larger
2 GB Memory Minimum
2 to 3 RS-232 Serial DB-9 Com Ports
Number or Com Ports Depends on Configuration
1 Ethernet Port
For More Details: See Enterprise Brochure at:
http://www.wirelessmessaging.com/Product_Brochures.html
Recommended For use:
With any of Our SPS-5 v9Series
Paging Systems.
Paging System RF Amplification Equipment
Recommended for Most 25 to 50 watt Applications
UHF RF Amplification (Signal Booster) Kits
The RF Mobile Amplifier Kit Allows you to
Transmit at a Higher Power Level (watts).
Additional Information of RF TPL Amp Kits
we sell Includes:
The RF Mobile Amplifier Kit is Compatible with most
Low Powered Paging Systems, Including:
Please Note:
25-watt Amp Kit P/N= 0007-1002
o
o
Requires a 2-watt or a 5-watt Input.
25 watts Requires approx 1.72 watt Input
from Transmitter.
50 watts Requires approx 4 watt Input from
Transmitter.
Available as UHF (440-470MHz) or by
Special Order VHF (148-174MHz).
25 or 50 watt Output Combo Amp, meaning
that One Amp can do either Output, depends
on the Input watts.
Power Supply Harness Included.
Wall Mountable.
The Paging System and the RF Amp Must be Tuned
together, as a Package. Will Not be Sold Separate.
50-watt Amp Kit P/N= 0007-1003
o
For the Antenna Supplied, see Below.
o
o
o
o
SPS-5 v9S UHF 2 or 5 watt Paging System.
SPS-5 v9E UHF 2 or 5 watt Paging System.
SPS-5 v9 UHF 2 or 5 watt Paging System.
And Many other Paging Systems.
o
For More Details: See Amp Brochure at…
http://www.wirelessmessaging.com/Product_Brochures.html
o
o
25 or 50 watt Amp Kit
o
Includes: The TPL RF Mobile Amplifier,
a 15 Amp Power Supply, 20” UHF
Fiberglass Antenna, 5 Ft. Jumper Coax
and a 25 or 50 Ft. RG-8 Coax Cable and
Ant. Mounting Hardware.
o
Antenna Kit Specifications:
The Amp Kit Antenna Information.
o
Used with the 25 and 50 watt Amp Kits.
Can be used almost anywhere Inside or
Outside the Building.
Recommend Installing in a Centralized
Location within the Coverage area.
Recommend Installing in Upright Position,
but can be used Installed Slightly Slanted.
Comes with All Mounting Hardware.
o
Recommend using RG-8 or RG-8U Coax.
o
o
o
o
o
o
o
o
o
o
o
Unity Gain Antenna, no Ground Plane.
(No DB-Gain with this Model)
18” to 20” Tall Fiberglass.
50 ohms Impedance.
1.5:1 VSWR.
Connector Type is N-Series Female.
Frequency Range is UHF 450-470MHz.
200-watt Maximum Power Input.
o
Weighs 1 lb. - without Hardware.
o
Antenna (Part of the Amp Kit)
Includes: Antenna and Mounting
Hardware.
Ask us about Our High Power Paging “Terminals” w/ Power from 25 to 100 watts UHF, Complete and with a 19” Rack Mount Enclosure.
On-Site Paging System Diagram with Peripherals
Highly Recommended for Most Paging System Applications
SPS-5 v9S, v9E or v9 at 5 Watts UHF
The SPS-5 v9S, v9E or v9 Paging System works well with everything you see above and more, including most Nurse Call Products.
Including: Pagers, Paging Data Receivers, LED Wallpager Displays, Alarm Contact Systems and Messaging Software
Please Contact us for Pricing.
Phone Sales: 1.800.373.1466 or Email: [email protected]
WaveWare Technologies, Inc.
2630 National Dr.
Garland, TX. 75041
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
