altEa
Multimedia
enJoYneerInG
INDEX
3.
notes
4.USB CONSOLE
Archos
Blusens
Corsair
Cowon
Creative
Dane - Elec
Emtec
Energy Sistem
Freecom
HP
Imation
Integral
Iomega
Kingston
LaCie
Lexar
LG
Memup
Philips
PNY
Samsung
SanDisk
Seagate
Sony
SPC Internet
Sungoo
Sunstech
Sweex
TakeMS
Toshiba
Transcend
Trekstor
Verbatim
Western Digital
Zipy
32.IPOD® CONSOLE
Apple
36.
SD Card slot
Emtec
Kingston
Lexar
PNY
SanDisk
Sony
Transcend
Verbatim
Last modification: May 2013
Notes
USB ConsolE
/ Only external storage media or USB mass storage media
(Mass Storage Device) 2.0 compliant USB specification.
/ The partition of an external data medium must conform to the FAT16
file system (<2 GB) or FAT32 (> 2 GB) (FAT: File Allocation Table).
/ Some multimedia devices may take longer to load due to multiple
files, folders and subfolders or due to non-reproducible content.
/ Do not use adapters for memory cards, their use may cause errors
during operation.
/ To manage external storage device, see the manufacturer’s
instruction manual.
/ Medium / high volume level of the external device is recommended
for clear sound via the MEDIA IN (CUP / USB Port).
The playback start time is influenced by the connected device.
If it exceeds a certain time during the initialization process
(read content) it may be necessary to select the audio source via
/
F ind information on audio formats and playlists for your
MEDIA IN (CUP / USB port) in the user manual.
MEDIA menu to play the device.
/ The folder structure on the external storage medium should not
exceed a depth of eight levels of folders. A folder should contain
no more than 1,000 files.
iPOD ConsolE
/
F ind information on audio formats and playlists for your
/ M EDIA IN (CUP / USB Port) offers a standard USB voltage of
MEDIA IN (CUP / USB port) in the user manual.
5 volts. The maximum intensity is limited to 1000 mA.
/ The use of USB extension cables and USB Hub (USB hub)
can cause malfunctions.
SD Card slot
/ If an external storage medium is divided into multiple partitions,
only the first partition with compatible audio files will be played.
3. multimedia devices ALTEA Notes
/ Consult user manual for usage information, media and audio
formats for your SEAT Media System 2.1 browser.
Multimedia
devices
Usb console
archos
Capacity
FIRMWARE
1 4 Vision
4 GB
V1.10
1 8 Vision
4 GB
V05.00.0001
2 Vision
8 GB
V1.32
2 0d Vision
4 GB
V1.22
2 4c Vision
8 GB
V1.53
2 8 Vision
4 GB
V1.0
3 Vision
8 GB
V1.09
4 3 Vision
8 GB
V1.18
7 0 Home Tablet
8 GB
Android 1.5 (V1.0.15)
Activate data USB mode
2 8 Internet Tablet
8 GB
Android 2.1 Update 1
(V1.0.84)
Activate data USB mode
4. multimedia devices ALTEA USB CONSOLE
Notes
archos
Capacity
FIRMWARE
Notes
3 2 Internet Tablet
8 GB
Android 2.1 Update 1
(V1.0.41)
USB Mode: UMS
4 3 Internet Tablet
16 GB
Android 2.2.1 (V2.0.54)
Activate data USB mode
4 8 Internet Tablet
HD 500 GB
Android 1.6 (V2.0.45)
Activate data USB mode
Internal Hard Drive (FAT 32)
5 Internet Tablet
32 GB
Android 1.6 (V1.7.77)
USB Mode: MSC
10 1 Internet Tablet
16 GB
Android 2.2.1 (V2.1.6)
Activate data USB mode
Clipper
2 GB
–
G12
1 GB
V044.002.280
M17
4 GB
V00.51.02
M21
8 GB
CF207k39xB_V1.7
P70
8 GB
V1.1
P71
8 GB
V1.0
P81
4 GB
DVB_TO_TM_D2.9.11
Blusens
5. multimedia devices ALTEA USB CONSOLE
Corsair
Capacity
FIRMWARE
Notes
Flash Voyager GT USB 3.0
32 GB
–
USB 3.0
Flash Voyager Mini
16 GB
–
Flash Voyager USB 2.0
16 GB
–
D3 Plenue
16 GB
Android 2.3.3
(V2.55 Class B)
Activate data USB mode
Internal Memory (FAT 32)
iAudio 9
8 GB
V1.11
MTP Player
iAudio 10
16 GB
V1.07
MTP Player. Activate CHARGE+SYNC
iAudio E2
2 GB
–
J3
16 GB
V2.22
MTP Player
S9
8 GB
V2.41
MTP Player
Zen Mozaic EZ 300
8 GB
V1.04.02
Zen MX
8 GB
V1.21.01e
Cowon
Creative
6. multimedia devices ALTEA USB CONSOLE
MTP Player
Creative
Capacity
FIRMWARE
Zen Style 100
8 GB
V1.02.02
Zen Style 300
8 GB
V1.01.07
Zen Style M300
8 GB
V1.00.22e
ZEN Touch 2
8 GB
Android 2.1 Update 1
(V1.00.38e)
Activate data transfer mode
Zen X-FI
16 GB
V1.04.08
MTP Player
Zen X-FI Style
16 GB
V1.03.04
Zen X-FI2
16 GB
V1.11.01
ZiiO 7"
8 GB
Android 2.1 Update2
(V1.00.27)
Aero
32 GB
–
Micro Mate
8 GB
–
Music
2 GB
–
zLight
1 GB
–
Dane-Elec
7. multimedia devices ALTEA USB CONSOLE
Notes
Activate data USB mode
DanE-ElEC
CaPaCity
FirmWarE
zLight
4 GB
–
zLight
16 GB
–
zMatePen
1 GB
–
zMatePen
32 GB
–
C300
16 GB
–
C400
32 GB
–
C650
32 GB
–
M400 em-Desk
16 GB
–
s360
4 GB
–
s400 em-Desk
8 GB
–
s520 ready Boost
1 GB
–
notES
EmtEC
8.
mUltimEDia DEviCES altEa
UsB ConsoLe
UsB 3.0
not recommended. Poor contact
Energy Sistem
Capacity
FIRMWARE
Notes
Energy Tablet i504
4 GB
Android 2.1
Activate data USB mode
Inngenio 5000 HDP M-EX
2 GB
V01.03.0023
Serie 15 Sport (1502)
2 GB
V1.04
Serie 16 Sport (1608)
8 GB
V1.7
Serie 22 Ultralight (2208)
8 GB
V1.06
Serie 25 MP4 Sport (2508)
8 GB
V1.21
Serie 32 DUO FM-T (3202)
2 GB
V00.00.0001
Serie 40 Touch (4020)
4 GB
V00.000.0000
Serie 41 Compact (4108)
8 GB
V2.0
Serie 42 Touch (4208)
8 GB
V1.1.3
Serie 50 TV-OUT (5030)
8 GB
V20.08.2009
Serie 52 Touch TV-OUT (5204)
4 GB
V1.1.1
9. multimedia devices ALTEA USB CONSOLE
Key must be pressed again after removal
Energy Sistem
Capacity
FIRMWARE
Notes
Serie 60 Widescreen (6030)
8 GB
V22.10.2008
Serie 70 TDT TV (7008)
8 GB
V4.0
Serie 75 TDT TV Widescreen (7516)
16 GB
V1.17
DataBar
32 GB
–
DataBar XXS
2 GB
–
Mobile Drive Sq
1024 GB
–
Hard Drive 2,5” (FAT 32). USB 3.0
ToughDrive
320 GB
–
Hard Drive 2,5” (FAT 32)
USBCard
8 GB
–
USBMemory
250 GB
–
v165w
32 GB
–
v195b
32 GB
–
Not supported
Freecom
Hard Drive 1,8” (FAT 32)
HP
10. multimedia devices ALTEA USB CONSOLE
Not recommended. Poor contact
hP
CaPaCity
FirmWarE
notES
v245o
16 GB
–
Atom
16 GB
–
nano Pro
32 GB
–
Pivot
16 GB
–
swivel
16 GB
–
Mini UsB Flash Drive
8 GB
–
splash UsB Flash Drive
32 GB
–
eGo Portable
500 GB
–
Hard Drive 2,5” (FAt 32)
eGo Portable (superspeed 3.0)
500 GB
–
Hard Drive 2,5” (FAt 32). UsB 3.0
external ssD Flash Drive
128 GB
–
ssD Flash Drive 1,8” (FAt 32). UsB 3.0
Datatraveler 100
2 GB
–
imation
intEgral
iomEga
KingSton
11.
mUltimEDia DEviCES altEa
UsB ConsoLe
Kingston
Capacity
FIRMWARE
DataTraveler 100
32 GB
–
DataTraveler 100 G2
32 GB
–
DataTraveler 101
16 GB
–
DataTraveler 101 G2
32 GB
–
DataTraveler 102
32 GB
–
DataTraveler 108
16 GB
–
DataTraveler 109
16 GB
–
DataTraveler 160
32 GB
–
DataTraveler 200
32 GB
–
DataTraveler 410
16 GB
–
DataTraveler DTI
8 GB
–
DataTraveler G2
4 GB
–
12. multimedia devices ALTEA USB CONSOLE
Notes
Not supported
Kingston
Capacity
FIRMWARE
Notes
DataTraveler G2
32 GB
–
Not supported
DataTraveler G3
32 GB
–
DataTraveler HyperX 3.0
256 GB
–
DataTraveler Locker
16 GB
–
DataTraveler Micro
32 GB
–
DataTraveler Mini Fun G2
8 GB
–
DataTraveler R3.0
64 GB
–
DataTraveler R500
64 GB
–
DataTraveler SE9
8 GB
–
DataTraveler Ultimate 3.0
32 GB
–
USB 3.0
DataTraveler Ultimate 3.0 G2
64 GB
–
USB 3.0
DataTraveler Workspace
64 GB
–
USB 3.0
13. multimedia devices ALTEA USB CONSOLE
USB 3.0
USB 3.0
laCiE
CaPaCity
FirmWarE
CooKey
32 GB
–
CurrenKey
8 GB
–
FastKey
30 GB
–
IamaKey
8 GB
–
ItsaKey
8 GB
–
MosKeyto
8 GB
–
rikiki
500 GB
–
Hard Drive 2,5” (FAt 32)
rugged Mini
500 GB
–
Hard Drive 2,5” (FAt 32). UsB 3.0
starck Mobile Hard Drive
500 GB
–
Hard Drive 2,5” (FAt 32)
WhizKey
8 GB
–
XtremKey
64 GB
–
echo se
16 GB
–
lExar
14.
mUltimEDia DEviCES altEa
UsB ConsoLe
notES
ssD Flash Drive (FAt 32). UsB 3.0
Lexar
Capacity
FIRMWARE
Echo ZE
32 GB
–
Echo ZX
32 GB
–
JumpDrive FireFly
8 GB
–
JumpDrive Retrax
32 GB
–
JumpDrive TwistTurn
64 GB
–
JumpDrive VE
16 GB
–
Flash Drive Xtick
2 GB
–
XD5
500 GB
–
K-Star
8 GB
V1.07
M24HD
8 GB
V1.1.00.100520
Pop Key
2 GB
–
Notes
LG
Hard Drive 2,5” (FAT 32)
memup
15. multimedia devices ALTEA USB CONSOLE
Not supported
mEmUP
CaPaCity
FirmWarE
notES
Quickee
16 GB
–
UsB 3.0
twist'n Key
32 GB
–
GoGear Ariaz
8 GB
V6.25
not supported
GoGear Ariaz new (/ 02)
16 GB
V2.59
MtP Player
GoGear Muse
16 GB
V1.30.0
UsB Mode: MsC
GoGear raga (/ 02)
4 GB
V1.11
GoGear Vibe
4 GB
V2.21
UsB Flash Drive
8 GB
–
Attaché
32 GB
–
Attaché Compact
4 GB
–
Attaché Micro sleek
32 GB
–
PhiliPS
Pny
16. mUltimEDia DEviCES altEa
UsB ConsoLe
MtP Player
PNY
Capacity
FIRMWARE
Notes
Attaché Original
8 GB
–
Attaché Original
16 GB
–
Attaché Original
32 GB
–
Attaché Premium
32 GB
–
Attaché Storage Label
16 GB
–
Micro Attaché City Series
4 GB
–
Poor contact
GT-P1000 GALAXY Tab
16 GB
P1000XXJID Android 2.2
Activate data USB mode
S2
500 GB
–
Hard Drive 2,5” (FAT 32)
YP-CP3
4 GB
V2.08 EU
YP-G50 GALAXY Player 50
8 GB
Android 2.1 Update 1
Activate mass storage mode
YP-M1
8 GB
V.1.23 FR-00-JA1
USB Mode: MSC
YP-P3
8 GB
V2.18 FR
Activate data USB mode
Samsung
17. multimedia devices ALTEA USB CONSOLE
Samsung
Capacity
FIRMWARE
Notes
YP-Q2
16 GB
V1.19 EU
USB Mode: MSC
YP-Q3
8 GB
V1.20 FR-00-JJ6
YP-R0
8 GB
V1.19 EU-00-JD2
YP-R1
8 GB
V1.09 EU-00-II3
Not supported
YP-R1
16 GB
V1.09 EU-00-II3
Not supported
YP-S1 TicToc
2 GB
V1.15
YP-U5
4 GB
V1.33 FR
MTP Player
YP-U6
4 GB
V1.09 FR-00-JK3
MTP Player
Cruzer
8 GB
–
Cruzer
16 GB
–
Cruzer
32 GB
–
Cruzer Blade
8 GB
–
SanDisk
18. multimedia devices ALTEA USB CONSOLE
Not supported
SanDiSK
CaPaCity
FirmWarE
Cruzer edge
16 GB
–
Cruzer Micro skin
8 GB
–
Cruzer Pattern
8 GB
–
Password protection software
Cruzer slice
32 GB
–
not supported
extreme Cruzer Contour
8 GB
–
sansa Clip
4 GB
–
MtP Player
sansa Clip+
8 GB
V01.01.05F
not supported
sansa e280
8 GB
V01.02.18F
MtP Player
sansa Fuze
2 GB
V01.01.11F
not supported
sansa Fuze+
8 GB
V02.37.01F
MtP Player
sansa View
8 GB
V01.02.09F
MtP Player
Ultra Backup
16 GB
–
19. mUltimEDia DEviCES altEa
UsB ConsoLe
notES
SanDisk
Capacity
FIRMWARE
Notes
Ultra Cruzer Titanium
16 GB
–
Password protection software
GoFlex Slim
320 GB
–
Hard Drive 2,5” (FAT 32). USB 3.0
FreeAgent Go
1024 GB
–
Hard Drive 2,5” (FAT 32)
Micro Vault Classic
4 GB
–
(USM4GJ)
Micro Vault Click Serie U
16 GB
–
(USM16GL)
Micro Vault Click Excellence
16 GB
–
(USM16GLX)
Micro Vault Serie R
32 GB
–
(USM32GR)
Micro Vault Style
16 GB
–
(USM16GM)
Micro Vault Tiny
8 GB
–
(USM8GH)
Walkman NWZ-A826
4 GB
V1.01
MTP Player
Walkman NWZ-A845
16 GB
V1.00
MTP Player
Seagate
sony
20. multimedia devices ALTEA USB CONSOLE
sony
Capacity
FIRMWARE
Notes
Walkman NWZ-A867
64 GB
V2.00
MTP Player
Walkman NWZ-B143F
4 GB
V1.00
MTP Player
Walkman NWZ-B153F
4 GB
V1.00
MTP Player
Walkman NWZ-E436F
4 GB
V1.02
MTP Player
Walkman NWZ-E443
4 GB
V1.00
MTP Player
Walkman NWZ-E453
4 GB
V1.00
MTP Player
Walkman NWZ-E464
8 GB
V2.00
MTP Player
Walkman NWZ-S544
8 GB
V1.00
MTP Player
Walkman NWZ-S754
8 GB
V1.00
MTP Player
Walkman NWZ-X1050
16 GB
V1.02
MTP Player
Serie 071 (0718)
8 GB
V4.0.4
Serie 072 (0728)
8 GB
V3.30
SPC Internet
21. multimedia devices ALTEA USB CONSOLE
SPC Internet
Capacity
FIRMWARE
Serie 073 (0738)
8 GB
V1.6
Serie 074 (0748)
8 GB
V2.0.6
Serie 075 (0754)
4 GB
V1.20
Serie 501 (5014)
4 GB
V1.1.15
Serie 506 (5064N)
4 GB
Android 2.3.4 (V2.0.5)
Serie 801 (8014)
4 GB
V1.03
Serie 804 (8044)
4 GB
V1.0.3
Serie 807 (8078)
8 GB
V01.07.0004
Serie 809 (8098)
8 GB
V01.01.0001
Serie 814 (8144R)
4 GB
V9.6.56.1017
Serie 816 (8166T)
16 GB
V03.00.0006
Serie 817 (8178)
8 GB
V10.01.08
22. multimedia devices ALTEA USB CONSOLE
Notes
Activate data USB mode
Key must be pressed again after removal
SPC intErnEt
CaPaCity
FirmWarE
serie 818 (8188)
8 GB
V03.00.0005
serie 819 (8194)
4 GB
V1.02
serie 821 (8214r)
4 GB
V1.0.14.0929
serie 822 (8228)
8 GB
V1.05
serie 823 (8238)
8 GB
V00.51.02
serie 824 (8244s)
4 GB
–
serie 827 (8274n)
4 GB
V0.1.02
serie 828 (8284r)
4 GB
V1.0.02
UsB stick
2 GB
–
Atlantis
8 GB
e500V2_4001_1125
Dedalo
4 GB
V9.6.55.1018
notES
SUngoo
SUnStECh
23.
mUltimEDia DEviCES altEa
UsB ConsoLe
not supported
SUnStECh
CaPaCity
FirmWarE
Fang
8 GB
V02.00.0003
Gea
8 GB
V1.1
Helios
8 GB
V01.110503
Icaro
8 GB
V02.00.0002
sport
8 GB
C11_K42I_V2.6
troya
4 GB
–
troya
8 GB
–
Clipz MP3 Player
2 GB
–
optimuo MP4 Player
4 GB
–
Veni MP3 Player
2 GB
V1.0.15.1101
Vidi MP4 Player
4 GB
10068v2.0
SWEEx
24.
mUltimEDia DEviCES altEa
UsB ConsoLe
notES
taKEmS
CaPaCity
FirmWarE
notES
MeM-Drive Colorline
16 GB
–
MeM-Drive easy II
16 GB
–
MeM-Drive Fashionline
8 GB
–
MeM-Drive Mini Metal
4 GB
–
MeM-Drive Mini Metal
8 GB
–
stor.e steel
250 GB
–
Hard Drive 1,8” (FAt 32)
Folio 100
16 GB
Android 2.2
Activate data UsB mode
JetFlash 220
8 GB
–
Fingerprint reader
reproduces only public partition
JetFlash 300
8 GB
–
JetFlash 330
16 GB
–
JetFlash 360
32 GB
–
toShiBa
tranSCEnD
25.
mUltimEDia DEviCES altEa
UsB ConsoLe
Transcend
Capacity
FIRMWARE
JetFlash 500
32 GB
–
JetFlash 530
32 GB
–
JetFlash 600
32 GB
–
JetFlash 620
64 GB
–
JetFlash T3
8 GB
–
JetFlash T5
8 GB
–
JetFlash V10
8 GB
–
JetFlash V10
16 GB
–
JetFlash V15
8 GB
–
JetFlash V20
4 GB
–
JetFlash V20
64 GB
–
JetFlash V30
4 GB
–
26. multimedia devices ALTEA USB CONSOLE
Notes
Transcend
Capacity
FIRMWARE
JetFlash V33
16 GB
–
JetFlash V35
8 GB
–
JetFlash V60
16 GB
–
JetFlash V70
16 GB
–
JetFlash V85
16 GB
–
JetFlash V95 C
16 GB
–
MP 870
8 GB
V1.01.00
Not supported
SSD18C3
128 GB
–
SSD Flash Drive 1,8” (FAT 32). USB 3.0
StoreJet 25H3P
1024 GB
–
Not supported. Hard Drive 2,5” (FAT 32)
USB 3.0.
StoreJet 25M
320 GB
–
Hard Drive 2,5” (FAT 32)
StoreJet 25M3
640 GB
–
Not supported. Hard Drive 2,5” (FAT 32)
USB 3.0.
i.Beat cebrax 2.0 FM
4 GB
V1.2
Trekstor
27. multimedia devices ALTEA USB CONSOLE
Notes
Trekstor
Capacity
FIRMWARE
Notes
i.Beat move S 2.0
4 GB
V01.00.0008
i.Beat sense
4 GB
V0.1.08
i.Beat veo
8 GB
V1.5.15
Pocket
250 GB
–
Store 'n' Go Clip-It
4 GB
–
Store 'n' Go Flash USB
4 GB
–
Password protection software
Store 'n' Go Hard Disk
500 GB
–
Hard Drive 2,5” (FAT 32)
Store 'n' Go Micro
4 GB
–
Store 'n' Go Netbook
8 GB
–
Store 'n' Go PinStripe
4 GB
–
Store 'n' Go V3
16 GB
–
Verbatim
28. multimedia devices ALTEA USB CONSOLE
Hard Drive 1,8” (FAT 32)
USB 3.0
Western Digital
Capacity
FIRMWARE
Notes
My Passport
2048 GB
–
Hard Drive 2,5” (FAT 32). USB 3.0
My Passport Essential
640 GB
–
Hard Drive 2,5” (FAT 32)
Albatros
4 GB
V SY20110217
Biking (Go by Zipy)
2 GB
–
Bird
4 GB
V1.5
Condor
4 GB
AID_20100719_V1.0
Crocodile
4 GB
V A2.00.0001
Diving (Go by Zipy)
2 GB
–
Duck
8 GB
V17.93.16
Flamingo
4 GB
SY227PO715-20111031
USB Mode: MSC
Fly
2 GB
–
Key must be pressed again after removal
Flying (Go by Zipy)
2 GB
–
Zipy
29. multimedia devices ALTEA USB CONSOLE
ZiPy
30.
CaPaCity
FirmWarE
notES
Fox
8 GB
V9.5.55.0100
UsB Mode: MsC
Frog
4 GB
V10.82.97
Fun
8 GB
Android 2.1 Update 1
Guppy
2 GB
sY190Po633-20110824
Ibis
4 GB
sY169Po631-20110920
Iguana
4 GB
V0929
Jumping (Go by Zipy)
4 GB
sY20110627
Parrot
4 GB
sY20100604
Peacock
4 GB
V 17.90.16
Pelican
4 GB
V1.3.1705
rabbit
2 GB
sY20110523
rolling (Go by Zipy)
2 GB
–
mUltimEDia DEviCES altEa
UsB ConsoLe
Zipy
Capacity
FIRMWARE
Notes
Running (Go by Zipy)
2 GB
V5.000.004
MTP Player
SmartFun 4.3
4 GB
Android 2.3.1
Activate data USB mode
31. multimedia devices ALTEA USB CONSOLE
MultIMEDIa
DEvIcEs
iPod® console
aPPlE
32.
CaPaCity
FirmWarE
notES
iPad 2
64 GB
V4.3.3
Model MC775tY
iPad Mini
32 GB
V6.1
Model MD532tY/A.
Apple Lightning-to-30-pin connector
adapter (MD823ZM/A).
new iPad (iPad 3)
64 GB
V5.1.1
Model MD371tY
iPhone 3G
16 GB
V2.2.1 / V3.1.3 / V4.1
Model MB496CZ
iPhone 3Gs
32 GB
V3.1.2 / V4.0.2 / V4.2.1
Model MC134t
iPhone 4
16 GB
V4.1 / V4.3.3
Model MC603Y
iPhone 4s
32 GB
V5.0.1
Model MD242Y
iPhone 5
32 GB
V6.0.1
Model MD299Y.
Apple Lightning-to-30-pin connector
adapter (MD823ZM/A).
iPod Classic 5G
80 GB
V1.0.2
iPod Classic 6G
160 GB
V1.1.2
mUltimEDia DEviCES altEa
IPoD® ConsoLe
aPPlE
33.
CaPaCity
FirmWarE
iPod Classic 6.5G
120 GB
V2.0.1
iPod Classic 6.5G (2009)
160 GB
V2.0.3
iPod nano 2G
2 GB
V1.2
iPod nano 3G
8 GB
V1.0
iPod nano 4G
8 GB
V1.0.3
iPod nano 4G
16 GB
V1.0.3
iPod nano 5G
8 GB
V1.0.1
iPod nano 5G
16 GB
V1.0.1
iPod nano 6G
8 GB
V1.0 / V1.1 / V1.2
iPod nano 6G
16 GB
V1.0 / V1.1 / V1.2
iPod nano 7G
16 GB
V1.0.1
iPod shuffle 2G
1 GB
V1.0.2
mUltimEDia DEviCES altEa
IPoD® ConsoLe
notES
Apple Lightning-to-30-pin connector
adapter (MD823ZM/A).
aPPlE
34.
CaPaCity
FirmWarE
iPod shuffle 3G
2 GB
V1.1
iPod shuffle 3G
4 GB
V1.1
iPod shuffle 4G
2 GB
V1.0 / V1.0.1
iPod touch 1G
16 GB
V1.1.5
iPod touch 2G
8 GB
V2.1.1
iPod touch 2G
16 GB
V2.2.1
iPod touch 3G
8 GB
V3.1.1
iPod touch 3G
32 GB
V3.1.2
iPod touch 3G
64 GB
V3.1.2
iPod touch 4G
8 GB
4.1 / V4.3.3 / V5.0.1
iPod touch 4G
32 GB
V4.1 / V4.2.1 / V5.0.1
iPod touch 4G
64 GB
V4.1 / / V5.0.1
mUltimEDia DEviCES altEa
IPoD® ConsoLe
notES
apple
Capacity
FIRMWARE
Notes
iPod Touch 5G
64 GB
V6.0
Apple Lightning-to-30-pin connector
adapte (MD823ZM/A)
iPod Video 5G
60 GB
V1.1.2
35. multimedia devices ALTEA iPod® CONSOLE
multimedia
devices
SD Card slot (only for SEAT Media System 2.1)
EMTEC
Capacity
FIRMWARE
Notes
MicroSD Standard
2 GB
–
EMTEC SD adapter
SDHC Class 4 (60X)
32 GB
–
SDHC Class 10
32 GB
–
MicroSD Standard
2 GB
–
Kingston SD adapter
MicroSDHC Class 4
16 GB
–
Kingston SD adapter
MicroSDHC Class 10
16 GB
–
Kingston SD adapter
SD Standard
2 GB
–
SDHC Class 4
16 GB
–
SDHC Class 10
16 GB
–
SDHC Ultimate Class 6
16 GB
–
Kingston
36. multimedia devices ALTEA SD Card slot
Kingston
Capacity
FIRMWARE
Notes
SDHC Ultimate X 100X Class 10
8 GB
–
SDHC Ultimate XX 233X UHS-I
16 GB
–
SDXC UHS-I Class 10
64 GB
–
FAT32
SDXC Professional 133x Class 10
128 GB
–
FAT32
MicroSD Premium Standard
2 GB
–
PNY SD adapter
MicroSDHC Premium Class 4
8 GB
–
PNY SD adapter
SDHC Optima Class 4
16 GB
–
SDHC Premium
16 GB
–
SDHC Storage Class 4
16 GB
–
MicroSD Standard
1 GB
–
SanDisk SD adapter
MicroSDHC Class 2
4 GB
–
SanDisk SD adapter
lexar
PNY
SanDisk
37. multimedia devices ALTEA SD Card slot
SanDiSK
CaPaCity
FirmWarE
notES
MicrosDHC Mobile Ultra UHs-I Class 10
32 GB
–
sanDisk sD adapter
MicrosDXC Mobile Ultra UHs-I Class 10
64 GB
–
sanDisk sD adapter. FAt32
sDHC extreme Class 10
8 GB
–
30MB/s
sDHC extreme Pro UHs-I Class 10
32 GB
–
45MB/s
sDHC standard Class 2
4 GB
–
sDHC Ultra Class 4
16 GB
–
15MB/s
MicrosD standard
2 GB
–
sony srAC-A1 sD adapter.
(sr-2C1)
MicrosDHC Class 4
4 GB
–
sony srAC-A1 sD adapter.
(sr-4C4)
sDHC Class 4
8 GB
–
(sF-32C4)
sDHCessential Class 4
8 GB
–
(sF-8B4)
sDHC experiencie UHs-I Class 10
32 GB
–
40MB/s. (sF32UY)
sDHC expert UHs-I Class 10
32 GB
–
94MB/s. (sF32UX)
Sony
38.
mUltimEDia DEviCES altEa
sD CArD sLot
Sony
CaPaCity
FirmWarE
notES
sDHC expert Class 10
16 GB
–
(sF-16nX)
MicrosD standard
2 GB
–
transcend sD adapter
MicrosDHC Class 2
16 GB
–
transcend sD adapter
MicrosDHC Class 6
16 GB
–
transcend sD adapter
MicrosDHC Class 10
32 GB
–
transcend sD adapter
sD standard
2 GB
–
sD 80X
1 GB
–
sD 133X
2 GB
–
sD 150X
2 GB
–
sDHC Class 2
32 GB
–
sDHC Class 4
32 GB
–
sDHC Class 6
32 GB
–
tranSCEnD
39.
mUltimEDia DEviCES altEa
sD CArD sLot
Transcend
Capacity
FIRMWARE
Notes
SDHC Ultimate UHS-I Class 10
16 GB
-
SDHC Ultimate Class 10
32 GB
–
SDXC Ultimate Class 10
64 GB
–
FAT32
MicroSD Standard
2 GB
–
Standard SD adapter
MicroSDHC Class 4
8 GB
–
Standard SD adapter
MicroSDHC Class 6
8 GB
–
Standard SD adapter
MicroSDHC Class 10
32 GB
–
Standard SD adapter
SD Standard
2 GB
–
Verbatim
40. multimedia devices ALTEA SD Card slot
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
