USERS MANUAL
Version: 1.9
Date: 06/05/2014
CellXtract™ User Manual
I
Limitation of Liability and Warranty Information
IMPORTANT NOTICE: PLEASE READ CAREFULLY
Use of the CellXtract device to gain unauthorized access to a computer, telephone or PDA may
violate various United States federal and state criminal statutes including, without limitation, the
Computer Fraud and Abuse Act, Pub L. No. 98-473, 98 Stat. 2190, 18 U.S.C. §§1030, et seq.,
and other similar laws, regulations and other governmental requirements in effect in the country in
which Customer resides.
By opening of the attached package, Customer represents and warrants that the CellXtract
device will only be used in a lawful manner in accordance with all applicable laws. Customer will
indemnify, defend and hold harmless Seller from all fees, costs, expenses, losses, liabilities and
damages of every nature and character including, without limitation, legal fees resulting from a
breach or violation of the representation and warranty contained in the preceding sentence.
Warranty
DISCLAIMER
IMPORTANT - PLEASE READ THE TERMS OF THIS AGREEMENT CAREFULLY. BY
INSTALLING OR USING LOGICUBE PRODUCTS, YOU AGREE TO BE BOUND BY THIS
AGREEMENT.
IN NO EVENT WILL LOGICUBE BE LIABLE (WHETHER UNDER THIS AGREEMENT,
RESULTING FROM THE PERFORMANCE OR USE OF LOGICUBE PRODUCTS, OR
OTHERWISE) FOR ANY AMOUNTS REPRESENTING LOSS OF PROFITS, LOSS OR
INACCURACY OF DATA, LOSS OR DELAYS OF BUSINESS, LOSS OF TIME, COSTS OF
PROCUREMENT OF SUBSTITUTE GOODS, SERVICES, OR TECHNOLOGY, PROPERTY
DAMAGE, OR INDIRECT, CONSEQUENTIAL, OR PUNITIVE DAMAGES OF A PURCHASER
OR USER OF LOGICUBE PRODUCTS OR ANY THIRD PARTY. LOGICUBE’S AGGREGATE
LIABILITY IN CONTRACT, TORT, OR OTHERWISE (WHETHER UNDER THIS AGREEMENT,
RESULTING FROM THE PERFORMANCE OR USE OF LOGICUBE PRODUCTS, OR
OTHERWISE) TO A PURCHASER OR USER OF LOGICUBE PRODUCTS SHALL BE LIMITED
TO THE AMOUNT PAID BY THE PURCHASER FOR THE LOGICUBE PRODUCT. THIS
LIMITATION OF LIABILITY WILL BE EFFECTIVE EVEN IF LOGICUBE HAS BEEN ADVISED
OF THE POSSIBILITY OF ANY SUCH DAMAGES.
LOGICUBE MAKES EVERY EFFORT TO ENSURE PROPER OPERATION OF ITS
PRODUCTS. HOWEVER, THE PURCHASER IS RESPONSIBLE FOR VERIFYING THAT THE
OUTPUT OF A LOGICUBE PRODUCT MEETS THE PURCHASER’S REQUIREMENTS. THE
CellXtract™ User Manual
I
TABLE OF CONTENTS
PURCHASER FURTHER ACKNOWLEDGES THAT IMPROPER OPERATION OF LOGICUBE
PRODUCTS CAN CAUSE LOSS OF DATA, DEFECTIVE FORMATTING, OR DEFECTIVE
DATA LOADING. LOGICUBE WILL MAKE EFFORTS TO SOLVE OR REPAIR ANY PROBLEMS
IDENTIFIED BY PURCHASER, EITHER UNDER THE WARRANTY SET FORTH BELOW OR
ON A TIME AND MATERIALS BASIS.
LIMITED WARRANTY
FOR ONE YEAR FROM THE DATE OF SALE (THE “WARRANTY PERIOD”) LOGICUBE
WARRANTS THAT THE PRODUCT (EXCLUDING CABLES, ADAPTERS, AND OTHER
“CONSUMABLE” ITEMS) IS FREE FROM MANUFACTURING DEFECTS IN MATERIAL AND
WORKMANSHIP. THIS LIMITED WARRANTY COVERS DEFECTS ENCOUNTERED IN THE
NORMAL USE OF THE PRODUCT DURING THE WARRANTY PERIOD AND DOES NOT
APPLY TO: PRODUCTS DAMAGED DUE TO PHYSICAL ABUSE, MISHANDLING, ACCIDENT,
NEGLIGENCE, OR FAILURE TO FOLLOW ALL OPERATING INSTRUCTIONS CONTAINED IN
THE OPERATING MANUAL; PRODUCTS WHICH ARE MODIFIED; PRODUCTS WHICH ARE
USED IN ANY MANNER OTHER THAN THE MANNER FOR WHICH THEY WERE INTENDED,
AS SET FORTH IN THE OPERATING MANUAL; PRODUCTS WHICH ARE DAMAGED OR
DEFECTS CAUSED BY THE USE OF UNAUTHORIZED PARTS OR BY UNAUTHORIZED
SERVICE; PRODUCTS DAMAGED DUE TO UNSUITABLE OPERATING OR PHYSICAL
CONDITIONS DIFFERING FROM THOSE RECOMMENDED IN THE OPERATING MANUAL OR
PRODUCT SPECIFICATIONS PROVIDED BY LOGICUBE; ANY PRODUCT WHICH HAS HAD
ANY OF ITS SERIAL NUMBERS ALTERED OR REMOVED; OR ANY PRODUCT DAMAGED
DUE TO IMPROPER PACKAGING OF THE WARRANTY RETURN TO LOGICUBE. AT
LOGICUBE’S OPTION, ANY PRODUCT PROVEN TO BE DEFECTIVE WITHIN THE
WARRANTY PERIOD WILL EITHER BE REPAIRED OR REPLACED USING NEW OR
REFURBISHED COMPONENTS AT NO COST. THIS WARRANTY IS THE SOLE AND
EXCLUSIVE REMEDY FOR DEFECTIVE PRODUCTS. IF A PRODUCT IS HAS BECOME
OBSOLETE OR IS NO LONGER SUPPORTED BY LOGICUBE THE PRODUCT MAY BE
REPLACED WITH AN EQUIVALENT OR SUCCESSOR PRODUCT AT LOGICUBE’S
DISCRETION. THIS WARRANTY EXTENDS ONLY TO THE END PURCHASER OF LOGICUBE
PRODUCTS. THIS WARRANTY DOES NOT APPLY TO, AND IS NOT FOR THE BENEFIT OF,
RESELLERS OR DISTRIBUTORS OF LOGICUBE PRODUCTS. UNLESS OTHERWISE
AGREED IN WRITING BY LOGICUBE, NO WARRANTY IS PROVIDED TO RESELLERS OR
DISTRIBUTORS OF LOGICUBE PRODUCTS.
IN ORDER TO RECEIVE WARRANTY SERVICES CONTACT LOGICUBE’S TECHNICAL
SUPPORT DEPARTMENT VIA PHONE OR E-MAIL. PRODUCTS RETURNED TO LOGICUBE
FOR REPAIR UNDER WARRANTY MUST REFERENCE A LOGICUBE RETURN MATERIAL
AUTHORIZATION NUMBER (“RMA”). ANY PRODUCT RECEIVED BY LOGICUBE WITHOUT
AN RMA# WILL BE REFUSED AND RETURNED TO PURCHASER. THE PURCHASER MUST
CONTACT LOGICUBE’S TECHNICAL SUPPORT DEPARTMENT VIA E-MAIL
([email protected]) OR VIA PHONE AT +1-818-700-8488 OPT. 3 TO OBTAIN A
VALID RMA#. THE PURCHASER MAY BE REQUIRED TO PERFORM CERTAIN DIAGNOSTIC
TESTS ON A PRODUCT PRIOR TO LOGICUBE ISSUING AN RMA#. THE PURCHASER MUST
PROVIDE THE PRODUCT MODEL, SERIAL NUMBER, PURCHASER NAME AND ADDRESS,
EMAIL ADDRESS AND A DESCRIPTION OF THE PROBLEM WITH AS MUCH DETAIL AS
POSSIBLE. REASONABLE TELEPHONE AND EMAIL SUPPORT ARE ALSO AVAILABLE FOR
THE LIFE OF THE PRODUCT AS DEFINED BY LOGICUBE.
EXCEPT AS OTHERWISE SPECIFICALLY PROVIDED IN THIS AGREEMENT, LOGICUBE
PRODUCTS ARE PROVIDED AS-IS AND AS-AVAILABLE, AND LOGICUBE DISCLAIMS ANY
AND ALL OTHER WARRANTIES (WHETHER EXPRESS, IMPLIED, OR STATUTORY)
INCLUDING, WITHOUT LIMITATION, ANY WARRANTIES OF MERCHANTABILITY, FITNESS
FOR A PARTICULAR PURPOSE, OR NONINFRINGEMENT OF THIRD PARTY RIGHTS.
CellXtract™ User Manual
II
TABLE OF CONTENTS
SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO
YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY HAVE
OTHER RIGHTS WHICH VARY FROM JURISDICTION TO JURISDICTION.
For further assistance please contact Logicube Technical Support at: +1-818-700-8488, or by
email to [email protected] Phone support is available 7AM-5PM weekdays (excluding
US national holidays)
Logicube RoHS Compliance Statement
LOGICUBE PRODUCTS COMPLY WITH THE EUROPEAN UNION RESTRICTION OF THE
USE OF CERTAIN HAZARDOUS SUBSTANCES IN ELECTRONIC EQUIPMENT, ROHS
DIRECTIVE (2002/95/EC).
THE ROHS DIRECTIVE PROHIBITS THE SALE OF CERTAIN ELECTRONIC EQUIPMENT
CONTAINING SOME HAZARDOUS SUBSTANCES SUCH AS MERCURY, LEAD, CADMIUM,
HEXAVALENT CHROMIUM AND CERTAIN FLAME-RETARDANTS IN THE EUROPEAN
UNION. THIS DIRECTIVE APPLIES TO ELECTRONIC PRODUCTS PLACED ON THE EU
MARKET AFTER JULY 1, 2006.
End User License Agreement (EULA)
LOGICUBE, INC. OWNS THE CELLXTRACT SOFTWARE AND HEREBY GRANTS THE
LICENSEE A LIMITED, PERPETUAL, NON-EXCLUSIVE AND NON-TRANSFERABLE LICENSE
TO USE THE SOFTWARE SOLELY IN THE COURSE OF LAWFULLY OPERATING THE
DEVICE WITH WHICH THE SOFTWARE IS INTEGRATED, AND FOR NO OTHER PURPOSE.
A COPY OF THE LICENSE MAY BE VIEWED FROM WITHIN THE CELLXTRACT
APPLICATION AND THE END USER WILL BE PROMPTED TO ACCEPT THE TERMS OF THE
LICENSE PRIOR TO INITIAL USE OF THE DEVICE. A COPY OF THE LICENSE IS INCLUDED
IN THE USERS MANUAL OR YOU MAY CONTACT LOGICUBE, INC. FOR A COPY.
THE DEVICE ALSO CONTAINS AN EMBEDDED PC. THE END USER SOFTWARE LICENSE
AGREEMENT FOR SOFTWARE CONTAINED WITHIN THE EMBEDDED PC IS PROVIDED AS
A PAPER LICENSE ALONG WITH THE CELLXTRACT DEVICE IN THE ATTACHED
PACKAGE. BY USING THE SOFTWARE YOU AGREE TO BE BOUND BY THE TERMS OF
THE APPLICABLE LICENSE AGREEMENT. THIS LICENCE COVERS THE OPERATING
SYSTEM THAT SUPPORTS THE CELLXTRACT DEVICE SOFTWARE AND ANY OTHER
SOFTWARE CONTAINED ON THE EMBEDDED LAPTOP. PLEASE NOTE THE WARRANTY
RESTRICTIONS ON ACCESSING THE EMBEDDED PC. A COPY OF THIS LICENSE IS ALSO
AVAILABLE FROM LOGICUBE, INC.
NOTE: Opening the CellXtract faceplate to access the embedded PC will void the warranty.
NOTE: “Hacking” the CellXtract application to access the embedded PC’s Operating System will
also void the warranty. Logicube can reload the CellXtract application for a substantial fee.
CellXtract™ User Manual
III
TABLE OF CONTENTS
Table of Contents
LIMITATION OF LIABILITY AND WARRANTY INFORMATION .................................................. I
IMPORTANT NOTICE: PLEASE READ CAREFULLY ........................................................................ I
W ARRANTY .................................................................................................................................................. I
LOGICUBE ROHS COMPLIANCE STATEMENT ...........................................................................................III
END USER LICENSE AGREEMENT (EULA) ...............................................................................................III
TABLE OF CONTENTS ............................................................................................................................... IV
1. INTRODUCTION TO CELLXTRACT AND CELLXTRACT-TNT ................................................. 8
INTRODUCTION ........................................................................................................................................... 8
Recommended use of CellXtract/CellXtract-TNT ................................................................................... 9
Current Software Version of CellXtract and CellXtract-TNT ................................................................ 9
CellXtract/CellXtract-TNT Extraction Notes.......................................................................................... 9
Features .................................................................................................................................................10
Using this guide .....................................................................................................................................12
System description .................................................................................................................................12
2. GETTING STARTED .............................................................................................................................14
OVERVIEW OF THE CELLXTRACT ..............................................................................................................14
DIFFERENCES BETWEEN CELLXTRACT AND CELLXTRACT-TNT .............................................................16
SETTING UP CELLXTRACT ........................................................................................................................16
Battery Status and Temp Level ..............................................................................................................16
Charging CellXtract ..............................................................................................................................17
Powering Up CellXtract ........................................................................................................................17
External Storage Location .....................................................................................................................18
STEP BY STEP – DEVICE EXTRACTION .....................................................................................................20
Attaching an external storage location..................................................................................................21
Selecting a handset ................................................................................................................................21
Selecting a connection type ...................................................................................................................21
Connecting the handset .........................................................................................................................21
Case Details screen ...............................................................................................................................22
Extracting Standard data.......................................................................................................................22
Extracting Extended data ......................................................................................................................22
Report Preview ......................................................................................................................................22
ATTACHING AND IDENTIFYING DEVICES ....................................................................................................22
Attaching a Cellular Phone ...................................................................................................................23
List Models ........................................................................................................................................................ 23
View Models...................................................................................................................................................... 24
Refine List ......................................................................................................................................................... 24
Generic Extraction Module ................................................................................................................................ 26
SIM Card Extraction .............................................................................................................................27
SIM PIN and PUK Codes .................................................................................................................................. 28
Dual SIM Extracted Data ................................................................................................................................... 28
Attaching a Memory Flash Card ...........................................................................................................29
Imaging Flash Media ......................................................................................................................................... 30
Attaching a GPS Device ........................................................................................................................31
SIM Card ID Cloning Step-by-step (Create NIC) .................................................................................32
Create from Existing SIM .................................................................................................................................. 32
Manually enter NIC data.................................................................................................................................... 35
Create a test NIC................................................................................................................................................ 38
CONNECTION OPTIONS .............................................................................................................................40
Helper Icons....................................................................................................................................................... 40
Cable Connection ..................................................................................................................................41
Infrared (IR) Connection .......................................................................................................................41
Bluetooth Connection ............................................................................................................................42
CellXtract™ User Manual
IV
TABLE OF CONTENTS
Custom Extraction .................................................................................................................................43
SIM Cards and Flash Memory Card Connection ..................................................................................44
MAIN CONNECTIVITY ICONS ......................................................................................................................44
OTHER CONNECTIVITY ICONS ...................................................................................................................45
NETWORK ISOLATION (NIC) CARDS .........................................................................................................45
EXTRACTION WITHOUT A SIM CARD .........................................................................................................46
3. CAPTURING DATA ...............................................................................................................................48
CASE DETAILS ...........................................................................................................................................48
Other Notes............................................................................................................................................49
DATA EXTRACTION ....................................................................................................................................49
Searching for Drivers ............................................................................................................................49
Standard Data Extraction ......................................................................................................................49
SMS Attached Content ...........................................................................................................................50
Cancel Capture ......................................................................................................................................51
Extended Data Extraction .....................................................................................................................51
Support for Non-Latin Languages .........................................................................................................52
4. ANALYZING CAPTURED DATA .......................................................................................................53
DISPLAYING EXTRACTED DATA.................................................................................................................53
Keyword Search.....................................................................................................................................55
Viewing Extracted Data.........................................................................................................................57
Displaying Previous Extractions ...........................................................................................................58
THE AUDIT TRAIL .......................................................................................................................................58
THE EXAMINATION REPORT ......................................................................................................................58
5. OTHER FEATURES ..............................................................................................................................59
MAIN APPLICATION SCREEN .....................................................................................................................59
SOFTWARE UPDATE INSTRUCTIONS .........................................................................................................59
CellXtract & CellXtract-TNT Software Update Instructions.................................................................60
iTunes Update Instructions ....................................................................................................................61
SYSTEM SETUP .........................................................................................................................................61
Logical Extraction .................................................................................................................................61
Physical Extraction ...............................................................................................................................62
Display...................................................................................................................................................63
Information ............................................................................................................................................63
Report ....................................................................................................................................................64
On Screen Report Settings ................................................................................................................................. 64
Output Report Settings ...................................................................................................................................... 65
Advanced Button ....................................................................................................................................65
SHUTTING DOWN CELLXTRACT ................................................................................................................65
6. REFERENCE ..........................................................................................................................................66
EXTRACTION NOTES ...................................................................................................................................66
SQLite Viewer ........................................................................................................................................66
Android Devices ....................................................................................................................................67
Samsung Galaxy S3 ........................................................................................................................................... 68
Android Ad-hoc device rooting ......................................................................................................................... 69
Android Email ................................................................................................................................................... 70
Android App Data.............................................................................................................................................. 70
Android Location Information ........................................................................................................................... 71
Android files of Interest ..................................................................................................................................... 71
Apple iPhone Devices ............................................................................................................................72
iPhone Passcode Bypass .................................................................................................................................... 73
iPhone App Data ................................................................................................................................................ 74
iPhone files of Interest ....................................................................................................................................... 75
Apple Location Information .............................................................................................................................. 75
CellXtract™ User Manual
V
TABLE OF CONTENTS
iPhone Support – User Application Notes ......................................................................................................... 75
BlackBerry Devices ...............................................................................................................................76
Unlocking a BlackBerry Device ........................................................................................................................ 76
BlackBerry Personal ID Numbers (PINs) .......................................................................................................... 77
Windows Mobile Devices.......................................................................................................................77
Various Windows Mobile Devices .................................................................................................................... 77
Symbian Devices ....................................................................................................................................77
Capture from Symbian UIQ 2nd & 3rd Edition OS ............................................................................................. 78
Symbian Event Logs .......................................................................................................................................... 79
Palm OS Devices ...................................................................................................................................80
Motorola Devices ..................................................................................................................................80
Time/Date Stamps from Motorola Phones ......................................................................................................... 80
Sony Ericsson Devices ...........................................................................................................................80
Data Capture from Sony Ericsson Phones ......................................................................................................... 81
Unlocking Sony Ericsson Handsets ................................................................................................................... 81
Siemens Devices ....................................................................................................................................82
Other Extraction Notes ..........................................................................................................................82
GPS Extraction Notes ............................................................................................................................82
Tom Tom Devices ............................................................................................................................................. 82
Garmin Devices ................................................................................................................................................. 83
HP Satellite Navigation Devices ........................................................................................................................ 83
Generic GPS Extraction ..................................................................................................................................... 83
GPS Track Logs ................................................................................................................................................. 85
Opening GPSData.gpx Output Files in Google Earth ........................................................................................ 85
Geo-Tag Data from Images ...................................................................................................................88
7. PHYSICAL EXTRACTION ..................................................................................................................89
INTRODUCTION ...........................................................................................................................................89
STEP BY STEP – PHYSICAL EXTRACTION .................................................................................................89
Attaching an external storage location..................................................................................................90
Selecting Physical Extraction and the handset ......................................................................................90
Connecting the Handset.........................................................................................................................90
Case Details Screen ...............................................................................................................................91
Performing the Extraction .....................................................................................................................91
Report Preview ......................................................................................................................................92
Android Disk Partition Settings .............................................................................................................93
8. CELLXTRACT-TNT ..............................................................................................................................94
INTRODUCTION ...........................................................................................................................................94
STEP BY STEP – DEVICE EXTRACTION FOR CELLXTRACT-TNT ..............................................................95
Attaching an external storage location..................................................................................................95
Selecting a chipset .................................................................................................................................95
Connecting the power clamps to the phone power terminals ................................................................97
Identifying the data port on the phone and the correct Cable Tip .........................................................97
Connecting the data and power cables to the CellXtract-TNT ..............................................................98
Case Details screen ...............................................................................................................................98
Selecting the bootloader ........................................................................................................................99
Performing the extraction ......................................................................................................................99
Report Preview ....................................................................................................................................100
9. GLOSSARY AND TROUBLESHOOTING GUIDE .........................................................................101
GLOSSARY ...............................................................................................................................................101
TROUBLESHOOTING GUIDE .....................................................................................................................102
HELP MESSAGES.....................................................................................................................................105
8. SUPPORTED HANDSETS ..................................................................................................................107
SUPPORT AND VALIDATION .....................................................................................................................107
CellXtract™ User Manual
VI
TABLE OF CONTENTS
HANDSETS – EXPECTED SUPPORT.........................................................................................................134
HANDSETS – OTHER ...............................................................................................................................143
GPS DEVICE – VERIFIED CELLXTRACT SUPPORT.................................................................................144
9. INDEX ....................................................................................................................................................146
10. CELLXTRACT SOFTWARE LICENSE .........................................................................................148
CELLXTRACT SOFTWARE LICENSE - EU ................................................................................................148
CELLXTRACT SOFTWARE LICENSE - US ................................................................................................156
GNU GENERAL PUBLIC LICENSE............................................................................................................161
TECHNICAL SUPPORT INFORMATION ......................................................................................................166
CellXtract™ User Manual
VII
1. Introduction to CellXtract and CellXtract-TNT
Introduction
Congratulations on your purchase of CellXtract or CellXtract-TNT. This manual
covers the features and operation of both models. Information on the specific
capabilities and operation of CellXtract-TNT for Chinese-chip mobile devices can
be found in chapter 7.
CellXtract
CellXtract is a self-contained, rugged device that has been designed specifically for
harsh field environments. The CellXtract is a comprehensive data extraction tool
and is a standalone device with no external computer required to immediately view
data extracted from mobile devices. CellXtract provides data extractions from cell
phones, smartphones, Satellite Navigation Devices, PDAs, SIM cards and flash
based media. Data can be extracted from devices using three connection methods;
data cables, infrared ports or Bluetooth radio frequency communications. The
target devices may connect to CellXtract by one, two or all three of these methods.
The CellXtract software also helps with easy identification of the target device and
informs the user of available connection methods. The user can select the
preferred connection method.
CellXtract-TNT
The CellXtract-TNT model delivers all of the features of CellXtract plus the ability to
extract data from thousands of Chinese “knock-off” and legitimate brand mobile
devices. The CellXtract-TNT provides a full physical extraction of the memory chips
on Chinese-chip cell phones, a full physical image (binary file) of the memory chip
CellXtract® User Manual
8
INTRODUCTION
is extracted. The binary file is decoded to show user information including
passwords, SMS, contacts, call logs and deleted data. The CellXtract-TNT supports
data extraction from the major chipset manufacturers including MediaTEK, Infineon,
Spreadtrum, MSTAR, and Cool Sand.
Recommended use of CellXtract/CellXtract-TNT
CellXtract/CellXtract-TNT is a forensically sound mobile device
data extraction tool, able to obtain real time intelligence from a
mobile device at a scene. It is designed to extract as much
information as possible in a forensic manner and disclose any
other information which might be present but has not been
extracted. It is aimed at getting information immediately from the
mobile device to help move forward an investigation. CellXtract and
CellXtract-TNT have been designed with a full audit trail allowing
users to demonstrate when actions were taken. The examination is
write-protected to ensure that information cannot be written to the
handset or media card.
CellXtract and CellXtract-TNT have been tested on a large range of
devices and its capabilities are displayed during the data extraction
process. The tests have verified that CellXtract and CellXtract-TNT
extracts data reliably. The User should consult this information to
ensure that the captured data meets their needs
Users should consider using CellXtract and CellXtract-TNT in an
appropriate environment to prevent any messages or calls being
received which will change the data on the handset. This can also
be considered as interception. The user should consult with their
local authorities for recommendations on legal implication of
intercepting data in the context of their examinations.
Current Software Version of CellXtract and CellXtract-TNT
Software updates are available by subscription only. Software
updates ensure that your CellXtract/CellXtract-TNT provides
compatibility with the latest mobile devices on the market. Please
contact Logicube Technical Support to verify if you have a valid
subscription.
New software features are listed in the CellXtract/CellXtract-TNT
activity log every time it is started.
CellXtract/CellXtract-TNT Extraction Notes
There are several changes to handsets that will result from
examination by CellXtract or CellXtract-TNT.
If an unread SMS is opened during the examination process, the
unread SMS status will change to “read” on the phone or SIM card.
However CellXtract and CellXtract-TNT will report the original
status of the message.
CellXtract and CellXtract-TNT operation will remove the missed call
message or symbol from the handset.
Bluetooth acquisitions will leave the extracting device name in the
“trusted devices” list in the handset Bluetooth menu.
CellXtract™ User Manual
9
INTRODUCTION
The extraction of SMS messages can be skipped thus preventing
these changes to the data on the handset.
Features
Data extraction from mobile devices with no external computer
required – view data in real-time, on scene
Portable and light-weight with a rugged chassis specifically
designed for the harshest field environments
Intuitive and easy to use even for non-technical personnel
Supports over 2,000 mobile devices including Apple iPhone,
Android, BlackBerry, Smart Phones, Palm, Symbian, Windows
Mobile and GPS devices. Apple and Android Tablets will be
supported in an upcoming release.
Comprehensive data extraction includes the acquisition of missed
calls, dialed calls, received calls, phonebook, SMS messages,
deleted SMS messages from SIM, Multimedia (MMS) messages,
calendar, memos, to-do lists, photos, video, audio and other files
Designed specifically for military organizations. The batterypowered CellXtract and CellXtract-TNT are light weight at 4 lbs,
provide a ruggedized chassis, and small footprint (8”x8.5”x3”)
making it ideal for harsh field environments. Meets IP54
(international Protection Code) specification for dust and splashing
water and a subset of MIL-STD-810F specification for
Altitude/Temperature/Humidity/Rain/Sand/Dust/Shock/Vibration
A user-friendly color touch screen and interface make
CellXtract/CellXtract-TNT easy to navigate for novice users. Easy
to read reports are available on demand. Report structure is
specifically designed for forensic investigators. Provides reports in
SQLite3 and converted to HTML for easy viewing.
Search capture reports by entering an individual keyword using the
touchscreen keyboard on the CellXtract/CellXtract-TNT or pre-load
a list of search keywords.
Extracted data is unaltered using write protection, MD5 hash for
data verification, and time-stamped audit trail
Bluetooth and IrDA capability
Built-in SIM Card/SD Card reader
SIM ID Cloning feature that allows you to extract phone data when
the SIM Card is PIN locked or when the SIM is not available
Memory Card Reader is included to support extraction from other
types of flash memory cards
NIC (Network Isolation Card) isolates the suspect phone from the
cellular network making it impossible to receive SMS messages or
calls
Physical Acquisition currently available for the CellXtract-TNT for
phones with the Chinese chipsets (Infineon, Mediatek and
Spreadtrum, MSTAR, and Cool Sand.
An internal rechargeable battery is easily recharged using an AC
power source or DC power (12v and optional 24v) connectivity.
These power options ensure that the CellXtract/CellXtract-TNT is
CellXtract™ User Manual
10
INTRODUCTION
available for use anytime, anywhere, including in military vehicles
such as Humvees
Supports all major network technologies including CDMA, GSM,
iDEN, TDMA
Customized data downloads. Users can specify which parts of a
phone’s memory are extracted
Phone cables included for all supported phones in a convenient
carrying case
CellXtract/CellXtract-TNT will display Geo-Tag data for images that
have been captured using a device with a GPS receiver
Device selection software allows users to quickly identify by brand,
model, photo, and/or dimensions
Capture Skype call logs and contacts
Frequent software updates (subscription required) ensures
compatibility with new phones as they are introduced
Optional physical extraction on Android based phones (Android 1.6
– 2.3.4) extracting, dumping, and decoding data from contacts, call
logs, SMS, emails, and user files.
CellXtract-TNT only: Full physical extraction of the memory chips
on Chinese-chip cell phones. A full physical image (binary file) of
the memory chip is extracted
CellXtract-TNT only: Support for thousands of mobile devices that
use Chinese-manufactured chipsets. The four supported chipsets,
Infineon, Spreadtrum, Mediatek and MSTAR, and Cool Sand
represent over 97% of Chinese-chip phones on the market.
CellXtract-TNT only: Auto pin definition identifies data and power
configurations
CellXtract-TNT only: Extracts, decodes and reports deleted data
CellXtract-TNT only: User Password extraction supported for all
Chinese chipsets
CellXtract-TNT only: Data decoding on Chinese chipset phones.
After acquisition of the memory chip’s physical image, the binary
file is decoded to show user information including passwords,
SMS, contacts and call logs. Supports decoding various languages
and character sets including Arabic and Chinese and Southeast
Asian languages and data storage formats
CellXtract-TNT only: Binary file export. Binary file can be saved to
an external storage device and then imported to third-party tools for
further manual or automatic decoding.
CellXtract-TNT only: Password extracted immediately and provided
to examiner during extraction process.
CellXtract-TNT only: Extracts from MTK, SPD, INF features phones
and MTK Android.
CellXtract-TNT only: Decodes file system, SMS, contacts call logs,
pin codes and IMEIs.
CellXtract-TNT only: Decodes deleted data.
CellXtract-TNT only: File download support for MTK chipset.
CellXtract™ User Manual
11
INTRODUCTION
Using this guide
This user guide is made up of 10 sections:
Introduction
Getting Started
Capturing Data
Analyzing Captured Data
Other Features
CellXtract-TNT
Glossary and Troubleshooting Guide
Supported Handsets
Index
CellXtract Software License
System description
The CellXtract system is packed in a carrying case. Inside, you will
find the following components:
AC Adapter
A complete set of adapters for all phones supported
Cable storage carrying bag
Memory card reader
A USB thumb drive
3 NICs (Network Isolation Cards) to be used for network
isolation and SIM ID cloning
Two Micro SIM card adapters
One micro SD card with SD card adapter
One USB hub
One Velcro tie
A radio frequency foil shielding (Faraday) bag
12V car charger
CD with CellXtract software and user’s manual
NOTE: Opening the CellXtract to access the embedded PC will void the warranty.
“Hacking” the CellXtract application to access the embedded PC’s Operating
System will also void the warranty. Logicube can reload the CellXtract application
for a substantial fee.
The CellXtract-TNT system is packed in a carrying case. Inside,
you will find the following components:
Two cable storage bags with complete set of
adapters for all phones supported as well as cables
and “tips” for extraction from Chinese phones
Memory card reader
A USB thumb drive
3 NICs (Network Isolation Cards) to be used for
network isolation and SIM ID Cloning
CellXtract™ User Manual
12
INTRODUCTION
12V car charger
CD with CellXtract™ software and a users’ manual
NOTE: Opening the CellXtract-TNT to access the embedded PC will void the
warranty. “Hacking” the CellXtract-TNT application to access the embedded PC’s
Operating System will also void the warranty. Logicube can reload the CellXtractTNT application for a substantial fee.
CellXtract™ User Manual
13
2. Getting Started
Overview of the CellXtract
CellXtract Overview
CellXtract-TNT Left Panel Overview
CellXtract® User Manual
14
GETTING STARTED
1. TOUCH SCREEN INTERFACE – All of the CellXtract/CellXtract-TNT
software and user input is controlled from here
2. LEFT PANEL – The left panel contains the following ports:
Two USB Ports (For handset device cables, memory card reader
and Bluetooth adapter)
SIM card reader with LED
SD card reader with LED
RJ-45 handset port with LED
Infrared panel
Data port (CellXtract-TNT only)
Power Port (CellXtract-TNT only)
3. RIGHT PANEL – The right panel contains the following ports:
Two USB ports for external storage devices and input devices
Power socket
15-pin VGA port
PS/2 port for a keyboard
RS-232 (9-pin serial) port
RJ-45 network (LAN) port
4. USB Ports – The left side USB ports are designed to have the phone
cable and Bluetooth adapter attached. The right side USB ports are
designed for USB an external storage location such as a USB flash drive
(or external USB drive where reports can be saved to) along with an
input device (if desired) such as a mouse or keyboard.
5. SIM Card Reader – Attach a SIM card, Micro SIM adapter, or a NIC/SIM
ID card into this slot to extract a SIM card, Micro SIM card, or create a
NIC or SIM ID card.
6. SIM Card Reader LED – This LED blinks when reading a SIM card or
creating a NIC/SIM ID card.
7. RJ-45 Handset Port – This port used for the non-USB cables provided
with CellXtract/CellXtract-TNT for extraction of various devices
8. RJ-45 Handset Port LED – This LED is for the RJ-45 Handset Port.
9. INFRARED (IR) PANEL – During an infrared capture, the wireless
device’s IR port is pointed toward this panel.
10. POWER SOCKET – Attach the included AC adapter to this power socket
to charge the CellXtract/CellXtract-TNT battery and to operate the
CellXtract using external power.
11. 15-pin VGA Port – This port can be used to attach an external monitor
that has a VGA input.
12. PS/2 Port – This port can be used to attach a keyboard.
13. RS-232 Port – This port is used for some handsets with off-the-shelf
cables not included with CellXtract/CellXtract-TNT.
14. RJ-45 Network (LAN) Port – 10/100 Ethernet port currently reserved for
future use.
15. 16-pin Data Port – CellXtract-TNT only. Data port for the data cable
included with CellXtract-TNT.
CellXtract™ User Manual
15
GETTING STARTED
16. 3.5mm Power Port – CellXtract-TNT only. Power port for the power
cables included with CellXtract-TNT.
NOTE: Other flash-based media cards (i.e. CompactFlash, Memory Stick, etc.)
can be read in the memory card reader included with CellXtract. The memory
card reader should be connected to one of the USB ports on the left panel.
Differences between CellXtract and CellXtract-TNT
The CellXtract-TNT has all the capabilities of the CellXtract plus the ability to
extract data from major Chinese-manufactured chipsets: MediaTEK (MTK),
Infineon, and Spreadtrum, MSTAR, and Cool Sand.
Chapter 1 through 6 covers the set-up and operation of CellXtract. These
instructions also apply to CellXtract-TNT when you are performing extractions
from non-Chinese chipset handsets.
Specific instructions for using CellXtract-TNT to perform extractions from
Chinese-chip mobile devices can be found in Chapter 8.
Setting Up CellXtract
Battery Status and Temp Level
Before CellXtract is powered up for the very first time, it needs to
have the battery charged. Attach the AC cable into the AC
adapter and connect the other end to a wall outlet or power strip.
Allow CellXtract to charge for at least 2 ½ hours.
The CellXtract main application screen displays the battery life of
the unit. When the battery has depleted to around 5%, CellXtract
will alert the user to recharge the CellXtract. When the battery
level drops below this state, CellXtract will shut down and will not
restart correctly until the unit is charged. The temperature level is
displayed in degrees Fahrenheit and shows the system
temperature.
Temperature Notes:
CellXtract will warn the user when the system
temperature exceeds 122 degrees Fahrenheit.
CellXtract will shut down if the temperature level
reaches 131 degrees Fahrenheit.
Battery Recharge State
CellXtract™ User Manual
16
GETTING STARTED
Charging CellXtract
CellXtract may be charged with the included AC adapter. The AC
adapter can be plugged into 110V or 220V AC power.
Normal charge time = 2 ½ Hours – A full charge will give about 5
hours of usage.
CellXtract also comes with a 12V car charger which can be used
to charge the CellXtract using an in-vehicle 12V power supply.
An optional 12V/24V cable that can be plugged into a military
BA-5590 battery is also available.
Powering Up CellXtract
To power up CellXtract follow this step-by-step procedure:
1. The power button is located in front of the CellXtract.
Locate the button with the following power symbol:
Power symbol
2. Press and release the power button. CellXtract will
initialize and boot-up to the End User License
Agreement (EULA).
End User License Agreement
3. Tap the Accept button to continue. CellXtract will boot to
the Main Application Menu.
CellXtract™ User Manual
17
GETTING STARTED
CellXtract Main Application Screen
.
External Storage Location
CellXtract saves all extraction reports and files to an external
location. This is typically a USB flash drive or a USB external
drive. The external storage location should always be placed on
a USB port on the right side.
It is recommended that the USB flash drive used when extracting
a device is larger in capacity than the total memory of the device
(including any removable memory cards).
If a storage location is unavailable or has not been set during an
extraction of a device, the following message will appear:
External storage unavailable prompt
Attach an external storage device to one of the available USB
ports on the right panel of the CellXtract then tap the Yes button.
CellXtract will display a list of attached drives.
CellXtract™ User Manual
18
GETTING STARTED
Drive selection screen
Tap the desired drive to highlight it then tap the Select button.
CellXtract will then ask if you would like to save this storage
setting. The two choices are:
No this time only – Select this if you do not want to save the
storage setting.
Yes save setting – Select this if you would like CellXtract to
remember this storage setting.
Save storage confirmation screen
NOTE: If a previously used external storage device is attached,
CellXtract will display the following screen. The drive letter may
be different from what is displayed on your screen.
CellXtract™ User Manual
19
GETTING STARTED
Existing external storage prompt
Select YES to capture to the selected external storage device.
Select Cancel to cancel the operation.
Select New location to select a different external storage
device.
Step by Step – Device Extraction
Logical handset extraction is composed of 8 sections:
Attaching an external storage location
Selecting a handset
Selecting a connection type (cable, Bluetooth, or infrared)
Connecting the handset
Case Details screen
Extracting Standard data (SMS, contacts, etc.)
Extracting Extended data (images, audio, video, etc.)
Report Preview
These sections are described in more detail in this manual.
NOTE: For physical extraction, please refer to Chapter 7 – Physical extraction.
The following instructions are an example of how to perform a handset
extraction.
NOTE: The recommended direction for extraction is left to right. The phone
cables and USB adapter should be connected to the USB ports on the left
side while the external storage location should be connected to the USB
ports on the right side.
CellXtract™ User Manual
20
GETTING STARTED
Attaching an external storage location
Attach an external storage location such as a USB flash drive or
USB external drive to one of the available USB ports on the right
panel. This will allow CellXtract to save extracted files and the
report to the selected external storage location.
It is recommended that the USB flash drive used when extracting
a device is larger in capacity than the total memory of the device
(including any removable memory cards).
Selecting a handset
1. From the main screen, tap Read New Device.
2. Select the device type (For example, Cell Phone. If Cell
Phone is selected, choose Logical Extraction).
3. Select the manufacturer or Operating System of the
device (For example, Sony Ericsson).
4. Next, select the model either by List Models, View
Models or Refine List (For example, List Models).
5. A list of handsets will appear by model number. Scroll up
or down to locate the model of the handset (For
example, T610).
Selecting a connection type
When the handset is selected, the handset screen will appear
which will show a picture of the handset (if available) along with
the types of data that can be extracted. It will also show all the
supported connection types (Cable, Infrared, and Bluetooth) for
this handset.
1. Select the desired connection type. Depending on the
model, you can choose between Cable, Infrared or
Bluetooth. Some handsets do not support all
connection types.
NOTE: If a cable connection is available, it will be
selected by default.
2. Tap Run Extraction.
Connecting the handset
CellXtract will now show instructions on how to connect the
handset.
If cable was selected, CellXtract will let the user know
what cable to attach, and when to attach the handset.
Some cables need to be connected to an available USB
port while others will need to be connected to the RJ-45
Handset Port.
CellXtract™ User Manual
21
GETTING STARTED
NOTE: Some Nokia phones will require the back
cover and battery to be removed. The cable will
connect to the Nokia phone through the battery
compartment (for example, cable 32).
If infrared was selected, CellXtract will give instructions
on how to enable infrared on the handset.
If Bluetooth was selected, CellXtract will scan for visible
Bluetooth devices within range then give instructions on
how to connect to the device.
Case Details screen
Once connected to the handset, CellXtract will show the Case
Details screen. The user can fill this screen at this time, or have
the option to fill it out later, after the extraction has completed.
Extracting Standard data
CellXtract will then begin extracting Standard data. This includes
handset information, contacts, SMS, call registers and organizer
files.
Extracting Extended data
After Standard data has been extracted, CellXtract will begin
extracting Extended data. This includes images, audio files,
videos, and other files.
NOTE: If at any point the CellXtract hangs or freezes during an
extraction, connect the included USB hub between the USB port (on the
left panel) and the phone cable and perform the extraction again. If your
CellXtract did not come with a USB hub, please contact Logicube
Technical Support. Contact information can be found at the end of this
document.
Report Preview
Once the Extended data extraction has completed, CellXtract will
show the report preview on the screen. Users can view the
report on the spot and see what data was extracted. From the
Report Preview screen, users can perform many different tasks
such as searching for keywords. Printing the report, viewing the
report, or disconnect the external storage location which will
contain the report to be previewed on another computer.
Attaching and Identifying Devices
Handset devices can be difficult to identify. Many show the manufacturer or
carrier’s name or logo, but not the model name or number. This information is
usually displayed behind the battery of the target device. To view the label,
power down the target device then remove the battery.
CellXtract™ User Manual
22
GETTING STARTED
On power-up a PIN or PUK number may be required to unlock the target device.
This number can be obtained from the device’s network service provider by
authorized law enforcement personnel.
Identification of the target device is required to determine which connection
methods are available (e.g. cable, infrared or Bluetooth) and for data cables, the
specific cable connector.
Attaching a Cellular Phone
1. Attach an external storage device to one of the available
USB ports on the right panel.
2. Tap the Read New Device button on the Main Application
Screen. The Device Type Selection screen will appear.
3. Tap the Cell Phone button. The next screen prompts the
user to choose Logical or Physical extraction.
4. Select Logical Extraction. The next screen prompts the
user to choose the manufacturer.
5. Once the manufacturer is chosen, the Cell Phone Selection
Screen will appear. For a given manufacturer, CellXtract
helps to identify the target cellular phone as follows:
Selection from a model list (List models)
Selection from model images (View Models)
Selection from a “short list” of model images based on
entered dimensions (Refine List)
List Models
If the user knows the model of the cell phone,
then the List Models option should be selected.
A list will come up of all known models. Scroll
down the list and select the model number of the
cell phone.
Cell Phone Model List
CellXtract™ User Manual
23
GETTING STARTED
View Models
If the model is unknown, images of all models
for the chosen manufacturer are obtained by
selecting View Models. Scroll down the list and
choose the image that looks like the target cell
phone.
Cell Phone Models
NOTE: Fully verified and supported handsets are indicated by
green “check marks”. Handsets that are not supported but are
expected to work are indicated by amber check marks.
Unverified handsets have no check mark. Treat extractions from
these handsets as a minimum data extraction.
NOTE: Some handsets can use a Network Isolation card (NIC)
during capture. This feature is further explained in the Network
Isolation (NIC) Cards and SIM Card ID Cloning section later in
this chapter.
You may be faced with a large list of cell phones. To narrow
down the search, tap the Back button and select Refine List.
Refine List
Refine List gives the user the option to apply
two filters. The user can choose to apply either
or both of these filters.
The first will narrow down the images shown
using physical features of the phone (e.g. Does
the phone have an antenna or camera and what
type of phone is it?).
The second or Input Dimensions filter is used to
enter the physical dimensions of the target
device (length, width, depth) using mm or
inches. CellXtract will display the models
matching those dimensions or features.
Tap the Up and Down Arrows to change each
filter. If the handset does not have one of the
CellXtract™ User Manual
24
GETTING STARTED
features, such as a camera, set the filter to
“Ignore”.
When finished, tap the Display Phones button.
CellXtract will display models matching those
features.
Tap the model number or image to highlight it,
and then tap the Select button.
Refine list screen with features
Refine list screen with dimensions
NOTE: This screen will allow the user to enter the dimensions in
mm, 1/8 inch or 1/16 inch increments.
6. The handset screen will appear which will show a picture of
the handset (if available) along with the types of data that
can be extracted. It will also show all the supported
connection types (Cable, Infrared, Bluetooth) for this
handset.
7. Select the desired connection type. Depending on the
model, you can choose between Cable, Infrared or
Bluetooth. Some handsets do not support all connection
types.
NOTE: If a cable connection is available, it will be
selected by default.
8. Tap Run Extraction and follow the on-screen instructions to
begin the extraction process. CellXtract will prompt you to
CellXtract™ User Manual
25
GETTING STARTED
insert a cable, letting you know what cable number to
connect and when to connect the handset.
9. The Case Details screen will appear. You can fill out the
case details at this time then tap the OK icon or tap the
LATER button if you want to fill out the information later.
10. CellXtract will begin the extraction. When the process
finishes, the Extraction Complete screen will appear.
NOTE: If Automatically extract ALL files from the
Extraction Settings screen is not checked, CellXtract will
show a list of extended data (images, audio, video, etc.)
that can be extracted. You may select all, some, or none
of the files displayed.
11. Tap the OK icon to complete the process and preview the
report.
Generic Extraction Module
If the Other Button is chosen on the Cell Phone
extraction screen, the Generic Extraction
Module appears. This is used to extract from
handsets that have not been identified or verified
with CellXtract. This includes handsets where
data could not be obtained from the known
manufacturers as well as from unknown
manufacturers.
The time taken for data extraction can take up to
30 minutes, depending on the amount of data.
The Generic Extraction Module only supports
Bluetooth and Infrared connections.
Generic extraction screen
NOTE: Users should be aware that data extracted with
the Generic Extraction Module is NOT validated. It is
recommended that any data extracted using this method
is visually verified by the User to ensure that no data is
missed or misrepresented.
CellXtract™ User Manual
26
GETTING STARTED
SIM Card Extraction
NOTE: CellXtract supports the ability to clone an existing
SIM card ID. This and other features using the Network
Isolation Card (NIC) are described in detail in the Network
Isolation (NIC) Cards section on p. 56.
SIM Card extraction supports SIM, Micro SIM and USIM cards.
1. Remove the SIM Card from the target cell phone. It is
usually located underneath the battery. Follow the cell
phone manufacturer’s instructions on how to remove the
SIM card.
2. Attach an external storage device to one of the available
USB ports on the right panel.
3. Tap the Read New Device button on the Main
Application Screen. The Device Type Selection screen
will appear.
4. Tap the SIM Card button. At this point CellXtract will
prompt you to insert an external storage location or
verify where you want to capture the data to. Select the
external storage location desired.
5. A screen will appear prompting you to insert the SIM
card into the reader. Place the SIM card, gold connector
side facing down, in the SIM card slot then tap the OK
icon. If the target phone uses a Micro SIM card (such as
the iPhone 4 and 4S), place the Micro SIM card on the
Micro SIM adapter and place the adapter, gold
connector facing down, in the SIM card slot then tap the
OK icon. The SIM card slot is located on the left side of
the CellXtract.
6. As the card is read, the green LED to the left of the SIM
card slot will blink for about 15-30 seconds. The Case
Details screen will appear. You can fill out the case
details at this time then tap the OK icon or tap the
LATER button if you want to fill out the information later.
7. The CellXtract will read the SIM card and begin the
extraction. When the process finishes, the Extraction
Complete screen will appear.
8. Tap the OK icon to complete the process and preview
the report.
Network Isolation Card Note: If “Create Network Isolation
Card after SIM extraction” is selected (checked) in the
‘Extraction’ settings screen, CellXtract will prompt the user to
insert a NIC. CellXtract will then create a Network Isolation
Card that can be used in place of the SIM card to isolate the
handset from the network.
NOTE: Refer to Chapter 4. Analyzing Captured Data for
more information regarding the extracted data.
CellXtract™ User Manual
27
GETTING STARTED
SIM PIN and PUK Codes
CellXtract enables an investigator to unlock SIM
cards via the PIN code and the PUK code, if
they are known.
When CellXtract is used to unlock a SIM card
via the PIN code it does not relock the card
afterwards.
When unlocking the SIM card via the PUK code
CellXtract will reset the PIN number to “0000”.
To enable the feature to enter the PUK code, the
PIN code needs to be entered incorrectly
several times. The PIN-input screen displays the
number of attempts remaining before the PUK
code is required.
Dual SIM Extracted Data
Dual SIM handsets can contain two SIM cards;
however the handsets are fully operational with
only one SIM. Dual SIM handsets will have the
following data:
These handsets make use of two SIM card
slots and are referred to as Slot 1 and Slot
2. Either slot can be used if only one SIM
card is present.
There are a number of ways the user can
switch between SIM cards including a
software menu option or a hardware button.
The handsets also have the functionality to
set which SIM card is initially used on startup irrespective of the Slot it is in. Therefore
the SIM card in Slot 2 can be set to be used
before that in Slot 1.
The SIM cards will be referred to as Primary
SIM and Secondary SIM, where the Primary
SIM is the one set to be used first.
The following data has been tested and can be
extracted from these handsets:
IMEI – Each Dual SIM handset has two IMEI
numbers, one for each SIM card Slot. The IMEI
numbers are associated to the SIM card slots on
the handset NOT the SIM Cards. CellXtract will
only extract the IMEI number of Slot 1
regardless of how many SIM cards are present
or which card is set as the Primary SIM.
IMSI – Each Dual SIM handset can have up to
two IMSI numbers, one for each SIM card
inserted. CellXtract will only extract the IMSI of
CellXtract™ User Manual
28
GETTING STARTED
the Primary SIM card, regardless of which slot it
is inserted into.
SIM Contacts – Dual SIM handsets can store
contacts to either SIM card. CellXtract can
retrieve contacts from both SIM cards and
identify which card they were stored on.
Contacts stored on the Primary SIM will be
labeled “[Primary SIM]”. Contacts stored on the
Secondary SIM will be labeled “[Secondary
SIM]”.
SMS Messages – Dual SIM handsets can store
SMS messages on either SIM card. CellXtract
will only extract messages stored on the Primary
SIM card, regardless of which slot it is inserted
into. CellXtract will extract all handset SMS
messages but cannot determine which SIM card
they were sent to/from, this can be determined
by viewing the SMS on the handset.
Call Logs – Dual SIM handsets store all call
logs on the handset and can be dialled or
received from either SIM card. CellXtract will
extract all call log entries but cannot determine
which SIM card was used to dial or receive the
call, this can be determined by viewing the call
logs on the handset. Any LDN’s stored on the
SIM cards will not be extracted, a separate SIM
card extraction will obtain this data.
NIC Functionality – Where NIC (Network
Isolation Card) support is verified, a NIC will
need to be created for each SIM card used in a
Dual SIM handset. The NIC will need to be
returned to the same Slot from which the SIM
card taken from. Placing a NIC in the wrong slot
will result in a loss of data.
NOTE: A separate extraction should always be
performed on all SIM cards.
Attaching a Memory Flash Card
A memory card reader is included with CellXtract. The memory
card reader supports several different formats:
CompactFlash (CF)
Secure Digital (SD, SDXC)
MultiMediaCard (MMC)
Memory Stick (MS)
Memory Stick Micro (M2)
CellXtract™ User Manual
29
GETTING STARTED
Micro SD
X-Card
The CellXtract software application does not allow data to be
written to the Memory Card Reader slots.
NOTE: Do not insert the flash memory card (target card) at
this time. CellXtract will prompt when to insert the target card.
1. Attach an external storage device to one of the available
USB ports on the right panel.
2. Tap the Read New Device button on the Main
Application Screen. The Device Type Selection screen
will appear.
3. Tap the Flash Memory button.
NOTE: If prompted for an external storage location,
please refer to External Storage Location in the
CellXtract Operation section of this manual.
4. A screen will appear with the message: “Please ensure
that the target card/drive is NOT inserted at this moment.
Tap the OK icon to continue.
5. A screen will appear with the message: “Insert target
card now”. Attach the included memory card reader to
one of the USB ports then attach the memory flash card
you want to extract. Tap the OK icon when the white
and blue LEDs on the memory card reader lights up.
6. The Case Details screen will appear. You can fill out the
case details at this time then tap the OK icon or tap the
LATER button if you want to fill out the information later.
7. The CellXtract will read the flash memory card and begin
the extraction. When the process finishes, the
Extraction Complete screen will appear.
8. Tap the OK icon to complete the process and preview
the report.
NOTE: Refer to Chapter 4. Analyzing Captured Data for
more information regarding the extracted data.
Imaging Flash Media
After capturing data, CellXtract will ask the user
if it should perform a complete image capture of
the flash memory card. If the user chooses to do
this, CellXtract will run the following procedure:
1. CellXtract will make a sector-by-sector
copy of the entire flash media drive.
CellXtract™ User Manual
30
GETTING STARTED
2. The copy will be stored as an image file
in the “_resource” folder of the
extraction directory.
3. CellXtract will then scan the image file
for the following types of JPEG files:
-
Extant JPEG: Normal, readable
JPEG files.
Deleted JPEG
Embedded JPEG: JPEG files
embedded in emails or other
files.
4. Any found JPEG files will be displayed
by CellXtract in the Extended Data
screen.
5. The image file can be copied to a thumb
drive and investigated further with hexediting or forensic software.
NOTE: CellXtract cannot distinguish between
Extant, deleted or embedded JPEG files. The
image file should be further investigated to
determine the status of any found files, and
whether similar files exist in other formats.
Attaching a GPS Device
CellXtract can extract data from a number of GPS devices.
NOTE: For device specific extraction notes, please see
Chapter 6: Reference.
1. Attach an external storage device to one of the available
USB ports on the right panel.
2. Tap the Read New Device button on the Main
Application Screen. The Device Type Selection screen
will appear.
3. Tap the GPS Device button.
4. The next screen prompts the user to choose the type of
GPS. Select the GPS to be extracted and tap the OK
icon.
NOTE: If prompted for an external storage location,
please refer to External Storage Location in the
CellXtract Operation section of this manual.
5. Follow the on screen instructions to connect the GPS
device. Once connected, the Case Details screen will
appear. You can fill out the case details at this time then
tap the OK icon or tap the LATER button if you want to
fill out the information later.
6. The CellXtract will read the GPS device and begin the
extraction. When the process finishes, the Extraction
Complete screen will appear.
CellXtract™ User Manual
31
GETTING STARTED
7. Tap the OK icon to complete the process and preview
the report.
NOTE: Refer to Chapter 4. Analyzing Captured Data
for more information regarding the extracted data.
SIM Card ID Cloning Step-by-step (Create NIC)
SIM Card ID cloning is available with CellXtract. You have three
choices allowing different types of SIM Card ID cloning
depending on the situation at hand.
Create from Existing SIM
Manually enter NIC data
Create Test NIC
An explanation and summary for each method is included in the
step-by-step instructions below.
Create from Existing SIM
CellXtract will clone the original SIM card ID. It
will copy the ICCID and IMSI from original SIM
card onto a NIC (SIM ID Card). The ICCID and
IMSI on NIC must be identical to original SIM.
NIC (SIM ID Card) ICCID and IMSI values can
be checked by performing a SIM Card Extraction
of NIC.
This method is useful when the original SIM card
is available.
1. Tap Read New Device from the main
menu. The device type selection screen
will appear
Device Type screen
2. From the NIC Operation screen, tap
Create from Existing SIM.
CellXtract™ User Manual
32
GETTING STARTED
NIC/SIM ID Operation screen
3. Place the SIM card into the SIM card
adapter then insert the adapter into the
reader. Tap OK.
Insert SIM card screen
4. CellXtract will read the inserted SIM
card. After this process, the following
screen will appear:
Remove master SIM
5. Remove the SIM card from the adapter
and place the NIC (SIM ID Card) into
the same adapter. Insert the adapter
into the reader then tap OK. CellXtract
will create the NIC (SIMID Card). When
this process finishes, the screen below
will appear. Tap OK.
CellXtract™ User Manual
33
GETTING STARTED
Successful NIC creation
6. CellXtract will prompt whether a phone
is compatible with Network Isolation
Cards. Selecting No will finish the
process and bring the user back to the
CellXtract main screen. Selecting YES
to the screen below will prompt the user
to identify the phone to be used with the
NIC (SIM ID Card).
NIC compatibility screen
7. After selecting the phone, one of the
following two screens will appear. Tap
OK to finish he process and go back to
the CellXtract main screen.
Supported NIC
CellXtract™ User Manual
34
GETTING STARTED
Phone untested with NIC
Manually enter NIC data
CellXtract will create a NIC (SIM ID Card) by
writing valid ICCID and IMSI values entered by
the user.
This method is useful when the original SIM card
is not available. To find out the correct ICCID or
IMSI numbers, please contact the handset’s
network provider.
Valid ICCID numbers are 19 or 20 digits long
and include the following:
The first 2 digits represent the Major
Industry Identifier (89 for
telecommunications)
1-3 digit Country Code
1-4 digit Issuer ID
Variable length individual Account ID
Valid IMSI numbers are 15 digits long and
include the following:
The first 3 digits represent the Mobile
Country Code (MCC)
The next 2 or 3 digits represent the
Mobile Network Code (MNC).
The next digits represent the mobile
station identification number. Normally
there will be 10 digits but would be
fewer in the case of a 3-digit MNC or if
national regulations indicate that the
total length of the IMSI should be less
than 15 digits.
NIC (SIM ID Card) ICCID and IMSI values can
be checked by performing a SIM Card Extraction
of NIC.
CellXtract™ User Manual
35
GETTING STARTED
1. Tap Read New Device from the main
menu. The device type selection screen
will appear
Device type screen
2. From the NIC Operation screen, tap
Manually enter NIC data.
NIC/SIM ID Operation screen
3. The following screen will appear. Use
the virtual keyboard (or an attached
keyboard) and enter the ICCID and IMSI
values. When finished, tap OK.
NIC/SIM ID data entry screen
4. Place the NIC (SIM ID Card) into the
adapter and insert the adapter into the
reader. Tap OK.
CellXtract™ User Manual
36
GETTING STARTED
Insert NIC/SIM ID
5. CellXtract will create the NIC (SIM ID
Card). When this process finishes, the
screen below will appear. Tap OK.
Successful NIC creation
6. CellXtract will prompt whether a phone
is compatible with Network Isolation
Cards. Selecting No will finish the
process and bring the user back to the
CellXtract main screen. Selecting YES
to the screen below will prompt the user
to identify the phone to be used with the
NIC (SIM ID Card).
NIC compatibility screen
CellXtract™ User Manual
37
GETTING STARTED
7. After selecting the phone, one of the
following two screens will appear. Tap
OK to finish he process and go back to
the CellXtract main screen.
Supported NIC
Phone untested with NIC
Create a test NIC
CellXtract will attempt to write default ICCID and
IMSI onto a NIC (SIM ID Card). The default
values are:
ICCID = 894900050701001429
IMSI = 001010123456789
A warning will appear after creating a test NIC:
“A Test NIC can be used to access handset data
but should only be used as a last resort.
Inserting into a handset may cause data to be
lost or changed”
NIC ICCID and IMSI values can be checked by
performing a SIM Card Extraction of NIC.
This method should be used as a last resort if
none of the previous methods work. It is
important to understand that incorrect ICCID or
CellXtract™ User Manual
38
GETTING STARTED
IMSI data may cause data on the handset to be
lost or changed.
1. Tap Read New Device from the main
menu. The device type selection screen
will appear
Device type screen
2. From the NIC Operation screen, tap
Create Test NIC.
NIC/SIM ID Operation screen
3. Place the NIC into the adapter and
insert the adapter into the reader. Tap
OK
Insert NIC/SIM ID
4. CellXtract will create the NIC (SIM ID
Card). When this process finishes, the
CellXtract™ User Manual
39
GETTING STARTED
screen below will appear. Tap OK to
finish the process.
Successful Test NIC creation
Connection Options
Once the correct target device has been chosen, the next screen will show the
different connection options that are available. The three different methods of
connection are Cable, Infrared or Bluetooth.
The Connectivity Option screen also shows the type of data that can be extracted
from the target device. This information is shown as a series of icons that are
listed at the end of this chapter. Any data types that cannot be extracted have a
red “X” through the icon.
The Connectivity option Screen will also alert the user if the target device
supports memory cards.
NOTE: The Connectivity Option screen will show items that can be downloaded
from the SIM card if the chosen handset is a GSM phone.
Connectivity Option Screen
Helper Icons
The Connectivity Option Screen also has three
“Helper Icons” that indicate the location of the
CellXtract™ User Manual
40
GETTING STARTED
handset’s On/Off switch, Cable Port and IR Port
(if available).
Cable Connection
1. Select Cable from the Connectivity Option Screen.
2. Tap the “Run Extraction” button.
3. Attach the appropriate cable to one of the USB ports on
the left panel.
NOTE: DO NOT attach the cell phone until prompted by
CellXtract.
Infrared (IR) Connection
Some cell phones and PDAs have a built-in infrared (IR) port,
which can be used to transfer data from the target device.
1. Select Infrared from the Connectivity Option Screen and
tap the “Run Extraction” button.
2. A prompt will appear on the screen asking the user to
set the target device to infrared. If the device is a
recognized cell phone, CellXtract will display instructions
to set it to infrared mode.
Instructions for Infrared Mode
3. Once the device is in infrared mode, place it across the
Infrared emitter on the left side of the CellXtract. Make
sure that the device’s IR port is facing the CellXtract’s
emitter located on the left panel.
4. When an infrared connection is made, the Case Details
screen will appear.
CellXtract™ User Manual
41
GETTING STARTED
Bluetooth Connection
Many Cell Phones have Bluetooth capability, which can be used
to transfer data from the target device. CellXtract has a range of
60 feet for Bluetooth connectivity.
Bluetooth extraction is a wireless communication link. On
initiation, CellXtract will produce a list of all Bluetooth enabled
devices. Caution is therefore required when selecting the correct
device name list, particularly if two devices in the area have the
same name. Any connection will require confirmation/acceptance
on the handset in question before the extraction process can
commence. This prevents accidental connection to other
devices.
Bluetooth capability can only extract data once the handset has
been 'paired' with the CellXtract unit. Pairing is when you enter a
4-digit code into the phone/handset to accept the connection. If
the 4-digit code is incorrectly entered you cannot access any
data from the device. Data can only be extracted over Bluetooth
if the device is PAIRED FIRST.
1. Attach the included Bluetooth Adapter to any one of the
available USB ports on the left panel.
NOTE: Do not attach the Bluetooth adapter to the
USB ports on the right side of the CellXtract.
Only the Bluetooth Adapter supplied by
Logicube is supported.
2. Select Bluetooth from the Connectivity Option Screen
and tap the “Run Extraction” button. If the device is a
recognized cell phone, CellXtract will display instructions
to set it to Bluetooth mode.
3. A prompt will appear asking the User to select “Discover
devices” to begin.
Discover Device List Screen
4. Once the target device has Bluetooth enabled and is
discoverable, tap the “Discover devices” button.
CellXtract™ User Manual
42
GETTING STARTED
5. A Bluetooth Activity screen will appear as CellXtract
searches for Bluetooth devices.
6. After 20-30 seconds, CellXtract will display a list of found
devices. Select the name of the target device and tap
the Select button.
NOTE: If the target device does not appear in the list,
tap the “Discover devices” button again. It may take
more than one attempt to access the device.
7. Once connected, the Target device will prompt the user
to allow connection. When requested, enter the 4-digit
code as 1234 on the target device. Once the pairing
process is complete, data extraction will begin
automatically.
NOTE: The target device screen must be monitored
during this stage of the process. Some target
devices require confirmation at various stages to
continue extracting.
After data extraction, a reminder will appear for the
user to remove the CellXtract from the Device’s
Bluetooth History list.
Custom Extraction
Pressing the “Custom Extraction” instead of the “Run Extraction”
button allows the user to decide what data is downloaded from a
handset. This is handy when the user only needs the call log
from a handset, for example.
Custom Extraction Screen
Tap the radio buttons to download or skip different data types.
Press OK when finished.
Any data not read will appear in the capture report as “User
chose not to extract ___________”.
NOTE: “Extract Files” refers to all image, movie, sound and other
files found in the Extended Data portion of a capture.
CellXtract™ User Manual
43
GETTING STARTED
SIM Cards and Flash Memory Card Connection
SIM Cards and Flash Memory Cards require no special
Connection procedures. Once the card is connected, data will
begin to extract as outlined in Chapter 3 – Capturing Data.
Main Connectivity Icons
The Connectivity Option Screen uses distinct icons to show what data can be
pulled from supported phones with different connection options.
ICON
DESCRIPTION
ICON
DESCRIPTION
IMEI Number
Sent SMS Message
Time
Saved SMS Message
Date
Calendar Entries
Contact List (ADN)
Tasks
Dialed Calls
Audio Files
Received Calls
Image Files
Missed Calls
Video Files
Read SMS Message
Other Files
Unread SMS Message
NOTE: Presence of this symbol
next to the icon denotes that the
data is extracted with relevant
timestamps.
CellXtract™ User Manual
44
GETTING STARTED
Multimedia Message – SMS
messages that can include
attachments.
Other Files
Connectivity Icon Table
Other connectivity Icons
The Connectivity Option Screen also tells whether a handset supports extraction through
a NIC or if the handset can be accessed without its SIM card.
Network Isolation (NIC) Cards
Some handsets require a SIM card to turn on and allow access to the handset and its
data. The Network Isolation Card (NIC) allows the user to have access to the handset
and its data without having to connect to the handset’s mobile network. CellXtract has the
ability to isolate many handsets from the mobile network by using a NIC. NICs are placed
in the SIM card slot of the handset.
There are three categories of support for this feature.
Handsets that support this feature are displayed with a blue NIC icon.
Handsets that do not support this feature are displayed with a blue NIC icon crossed
with a red line.
Handsets that are untested for this feature are displayed with no NIC icon.
Phone Model Selection Screen
CellXtract™ User Manual
45
GETTING STARTED
Connectivity Option Screen
To set the CellXtract to create a NIC after a SIM card extraction, follow these steps:
1. From the main menu, tap the System Setup button.
2. Tap the Extraction button.
3. Place a check mark on the Create Network Isolation Card after SIM
extraction.
4. Tap the Apply button.
5. Tap the OK icon.
6. CellXtract will prompt and ask if you want to make these settings permanent or
use them this time only. The changes will remain until CellXtract is restarted.
Select one of the following choices:
a. No this time only
b. Yes save settings
7. At this time you may perform a SIM card extraction. After the SIM card extraction,
CellXtract will prompt you to insert the NIC in the reader slot and proceed to
create the Network Isolation Card.
Extraction without a SIM Card
CellXtract can extract data from many handsets with the SIM card removed. If a
handset’s SIM is PIN locked this feature allows an extraction of the handset with the SIM
removed. If supported, this feature is displayed in the Connectivity Screen.
CellXtract™ User Manual
46
GETTING STARTED
SIMless extraction
CellXtract™ User Manual
47
3. Capturing Data
Case Details
Once the target device has been successfully connected, the Case Details input form
appears:
Case details screen
If the report will be filled out later, tap the Later button to continue on to data
extraction.
If the report is to be filled out now, tap the first line that needs to be filled out. Use
the virtual keyboard (or an attached keyboard) to fill out the case details.
NOTE: The keyboard is also accessible from any screen that displays the button to the left.
The virtual keyboard below will appear.
Virtual Keyboard
NOTE: Alternatively, a PS2 or USB Keyboard can be attached to the CellXtract through the
PS2 port or one of the available USB ports on the right panel.
CellXtract® User Manual
48
CAPTURING DATA
Tap the OK icon once all of the information is filled out. The fields entered will be built into
the final report, which is generated on completion of the extraction.
Other Notes
Certain fields will show users a list of previous entries. These entries can
be dropped into the field without retyping them. The Case Details form will
remember the last 20 entries for the following fields:
Case Reference Number
CellXtract Operator
Investigating Officer
Exhibit ID
Service Provider
The Case Details Form can be opened and edited for previous extractions.
Data Extraction
Searching for Drivers
Sometimes, CellXtract may need to load new drivers for a handset that has
never been attached before. A progress bar will appear briefly that
indicates drivers are being loaded. The capture session will continue once
the drivers are loaded.
Note: Allow sufficient time for the driver to load.
Standard Data Extraction
Once a target device has been identified and connected, the CellXtract
software will prompt the user to continue. Doing so starts the extraction
process for “standard data”.
Standard data includes such information as Contacts, Call Logs, SMS Text
Messages and Organizer data.
As the data is being extracted, CellXtract will show the progress in the
Activity Log on the screen:
Activity Log
CellXtract™ User Manual
49
CAPTURING DATA
SMS Attached Content
SMS Messages can contain extra content other than standard text.
CellXtract notifies the user when any extra content appears within an SMS
Message.
NOTE: This feature is currently only supported for SMS extracted through
handsets supporting AT commands. Reporting of attached content
functionality is not supported for BlackBerry, Symbian or Windows Mobile
handsets.
Notifications appear within the body part of the message and describe the
type of attached content.
Notifications appear in the following form:
[CONTAINS CLIPART REFER TO HANDSET]
SMS Messages may contain more than one type of attached content.
CellXtract will display a notification for each piece of attached content
within the message.
VCard and VCalendar Content
VCards and VCalendars are used to exchange information between
application.
VCards store address book entries while VCalendars store organiser
entries.
VCards and VCalendars can be attached to SMS Messages. CellXtract will
display the raw data of attached VCards and VCalendars within the body of
the SMS Message.
VCard and VCalendar data will appear between the tags
[ATTACHEMENT: CONTACT DATA]
Or
[ATTACHMENT: CALENDAR DATA]
And will end with
[END ATTACHMENT]
As SMS Messages have a limited size VCards and VCalendars may span
several messages.
In this case each part of the VCard or VCalendar will start with the tag to
indicate the content follows from a previous message.
[ATTACHMENT CONT..]
Each message part will also end with the tag below to indicate that more
content will follow in the next message:
[…]
CellXtract™ User Manual
50
CAPTURING DATA
NOTE: VCard and VCalendar content is displayed in its raw format. Where
VCards and VCalendars span more than one SMS Message, each part will
need to be manually put together to form a valid VCard or VCalendar entry.
More information on VCards and VCalendars can be found at
www.imc.org/pdi/
Cancel Capture
The capture process can always be aborted by tapping the Cancel button
during the capture operation. This button is located towards the top right of
the main screen.
This will allow the user to skip the current capture operation (i.e.
downloading contacts) or abandon the whole capture session. Pressing the
Cancel button will go back to the main screen.
Extended Data Extraction
“Extended Data” refers to such items as Image files, Video files, Audio files
and any other files such as themes, screensavers, etc.
When the standard data has been extracted, the user is given the option to
select and download other files from the target device.
1. Tap the Images Button at the bottom of the screen, CellXtract will
display all supported Image files that were found in the target
device’s memory.
2. Select an Image file for download by tapping once on it. Tap a
second time to deselect the file. Scroll through the list and tap any
other files that are desired.
3. Repeat Steps 1 – 2 for the “Video”, “Audio” and “Other” buttons.
NOTE: Select all files of a particular type by tapping the “Select all
<.ext> files” bar.
4. As files are selected, CellXtract shows the number and size of total
files at the top of the screen.
5. Once all needed files have been selected, tap the Download
button. The Download Manager will show progress as the files are
downloaded to CellXtract.
6. At any time, press the Change Selection button to stop
downloading and re-select the files to download.
7. As the files download, the Activity Log will indicate downloaded
files in green, selected files not downloaded in gray and unselected
files in white.
On completion of the download, a summary of all files, including listings for
files not selected for download, will be displayed. The data received from
the target device is written into an SQLite3 file, then stored in the case
unique folder.
CellXtract™ User Manual
51
CAPTURING DATA
Support for Non-Latin Languages
All handsets supported by CellXtract have had full validation of each
feature carried out for the full range of Latin character sets (ASCII
programming language).
CellXtract has also been further developed to extract information from
Unicode languages that provide non-Latin character sets such as Greek
and Arabic characters.
These extractions have not been verified although tests indicate the
following:
SIM cards (supported natively)
Windows (supported natively)
Nokia (supported natively)
Sony Ericsson (full support, Unicode development implemented: an
option has been implemented to allow the user to extract in ASCII if
required)
Samsung (partial validated Unicode support - for messages only)
Motorola (partial support, Unicode development implemented: an
option has been implemented to allow the user to extract in ASCII if
required)
Siemens (partial i.e. validated Unicode support for handsets
contacts and notes)
If CellXtract does not extract a character; it will appear as a square on the
screen.
CellXtract™ User Manual
52
4. Analyzing Captured Data
Displaying Extracted Data
Once the extraction for standard and extended data is complete, the data is displayed
onscreen and will also generate the CellXtract report in HTML format. All data is individually
hashed using the MD5 algorithm to ensure that the data can be verified as unchanged.
As of CellXtract software 1.5.x.x, the extracted data is viewable in a new on-screen report:
Preview screen
The on-screen report can have different icons showing depending on the type of device
extracted. Each button will have a number showing how much data was extracted. Here is
a list of all available icons:
--- Device information – Shows information about the device including the
Manufacturer, Model, IMEI/ESN, SIM Card information (if a SIM card is included), etc.
--- Contacts – This contains extracted contacts from the device.
--- Call Logs – This contains extracted call logs from the device.
--- Messages – This contains extracted messages from the device.
--- Calendars – This contains extracted calendar entries from the device.
--- Tasks – This contains extracted tasks from the device.
CellXtract® User Manual
53
ANALYZING CAPTURED DATA
--- Notes – This contains extracted notes from the device.
--- URLs – This contains extracted URLs from the device.
--- Dictionaries – This contains extracted dictionaries from the device.
--- IM Contacts – This contains extracted contacts from Instant Messengers.
--- IM Call Logs – This contains extracted call logs from Instant Messengers.
--- IM Chat – This contains extracted chat entries from Instant Messengers.
--- Event Logs – This contains extracted event logs from the device.
--- Locations – This contains extracted locations from the device.
--- GPS Data – This contains extracted GPS data from GPS devices.
--- Image Files – This contains extracted image files from the device.
--- Video Files – This contains extracted video files from the device.
--- Audio Files – This contains extracted audio files from the device.
--- Other Files – This contains any other extracted files from the device.
NOTE: Depending on the device, you may only see some of the icons above. For
example:
SIM Cards will only show the following buttons: Device Information, Contacts,
Call Logs and Message.
Memory Cards will only show the following buttons: Image Files, Audio Files,
Video Files, and Other Files.
Phones will show all buttons (except GPS)
GPS will show all buttons.
There are also three icons located at the bottom of the screen:
--- Case Details – This button opens the Case Details Input Form. Data can be
edited or added to the form. Please refer back to Chapter 3 – Capturing Data for more
information about this form.
--- Preview Extraction – This button allows you to view the Examination Report
in. Please see the section ‘The Examination Report’ later in this chapter for more
information on the Examination Report.
CellXtract™ User Manual
54
ANALYZING CAPTURED DATA
--- Keyword Search – Search for data from an imported keyword list stored on a
USB thumb drive in the following folder: E:\CellXtract\Report Search.txt, where “E:” is a
USB drive. Keywords can also be added to a custom list.
--- Finished – This button closes the data View Screen and goes back to the
Main Application Menu.
Keyword Search
To perform a keyword search from the on-screen report, tap the Keyword
Search button. A keyword search window will appear.
Tap the Edit button to edit the keyword search. Using the on-screen
keyboard or an attached keyboard, add keywords to the custom list. As you
tap the Add button, the keyword entered should appear on the right side.
Tap the Done button when finished.
CellXtract™ User Manual
55
ANALYZING CAPTURED DATA
To use an imported keyword list, a keyword list file must first be created
then saved on an external USB location (USB flash drive, USB external
drive, etc.). Place a check mark on the Use Imported Keyword List box
then tap the Done button.
To create the keyword list, on a computer, open Notepad or a similar text
editor.
Type a simple list of words as shown in the next screen shot below. Words
are not case sensitive so type in all lower-case.
Save the file as “Report Search.txt” (case sensitive) and copy it to a USB
storage device in a folder called CellXtract (for example,
X:\CellXtract\Report Search.txt). Place this file on the same USB storage
device that has your previous extractions or a USB storage device which
will be used with CellXtract for future extractions.
After entering the keywords or selecting the imported keyword list, tap the
Search button. CellXtract will now search all extracted records for the
chosen keywords and display the results. To view the each individual
record, highlight the record then tap the Select button.
CellXtract™ User Manual
56
ANALYZING CAPTURED DATA
Viewing Extracted Data
To view the extracted data, tap one of the icons on the report screen.
CellXtract will display all the extracted data based on your selection.
Five buttons are available on each section viewed:
--- Tapping this icon scrolls up one page/entry.
--- Tapping this icon scrolls down one page/entry.
--- Tapping this icon scrolls up within the current page/entry.
--- Tapping this icon scrolls down within the current page/entry.
--- Brings you back to the previous screen to preview another
section.
CellXtract™ User Manual
57
ANALYZING CAPTURED DATA
Displaying Previous Extractions
Previously extracted data files can be viewed by selecting “View Previous
Extractions” from the main CellXtract window. Previous extractions are
organized by date. Additionally, the user can search for a particular
extraction by one of these choices:
Case Reference Number
Exhibit ID
ICCID Number
IMEI Number
1. From the Main Application Screen, tap the View Device History
button. A list of all previous capture sessions will appear.
2. Choose the desired search criteria from the View Detail list on the
side of the screen.
3. Scroll to the desired capture session and tap it once to select.
4. Tap the Select button. The Standard and Extended Data Screens
for that capture session will appear.
The Audit Trail
The audit trail is a set of two files that are generated along with the capture
session.
Log.dat records all commands sent to and received from the target device.
This includes AT commands.
Audittrail.txt records all data received from the target device.
All three files are stored and moved with the extracted data. They can be
accessed once the capture session has been backed up to a USB storage
device. They cannot be accessed from within CellXtract
NOTE: Logicube Technical Support may ask the user to send a copy of
log.dat for troubleshooting purposes.
The Examination Report
The Examination Report is generated as an SQLite3 file. This SQLite3 file
is then translated and converted to an HTML file for easy viewing.
NOTE: XML format is available and can be selected in the CellXtract setup
screen. See the section ‘System Setup’ in Chapter 5: Other Features.
CellXtract™ User Manual
58
5. Other Features
Main Application Screen
This chapter discusses those features of the CellXtract Application that were not covered in
previous chapters.
Main Application Screen
Software Update Instructions
Logicube will provide software updates that will provide compatibility with new mobile
devices. Optional software subscriptions are tied to the serial number of your CellXtract
device. The software will automatically verify that your subscription is active and valid.
Users will be notified when new software updates are available for download.
Requirements:
A computer with Internet access and a working USB port
A USB flash drive (the recommended format for the USB flash drive is the exFAT
filesystem).
The CellXtract/CellXtract-TNT with the AC adapter.
CellXtract® User Manual
59
OTHER FEATURES
CellXtract & CellXtract-TNT Software Update Instructions
The instructions below describe how to update the software on the CellXtract
and CellXtract-TNT:
1. Customers with an active software subscription will be notified via
email when there is a new software update.
2. Enter the following URL into your browser:
http://www.logicube.com/knowledge/cellxtract
3. You will find links to the following:
a. CellXtract Software (for both CellXtract and CellXtract-TNT)
b. CellXtract Release Notes
c. Software Update Instructions
d. Handset Compatibility List
e. CellXtract/CellXtract-TNT User’s Manual (in the Product
Documentation section)
4. Download CellXtract software and extract/unzip the files to the root of a
USB flash drive. When the files are extracted/unzipped, a folder called
“CellXtract Update” (case sensitive, without the quotes) should be
found on the root of the USB storage device. This folder will contain the
following files (not in any order):
a. Update.exe
b. CXTFiles.exe
c. BuildDate.txt
d. CellXtract_users_manual.pdf
e. License.lic
5. Connect the AC adapter to the CellXtract and turn the CellXtract on.
Accept the End User License Agreement when it appears on the
screen.
6. From the CellXtract Main Application Screen, tap the Upgrade
Software button.
7. You will be prompted to insert the USB storage device. Attach the USB
storage device used in step 4 to an available USB port on the right
panel. Wait 5 to 10 seconds then tap the OK button.
8. The software update files will automatically download from the USB
storage device and the CellXtract will restart.
9. The software update will begin. When completed, the CellXtract will
commit/save the changes then restart again.
NOTE: The USB flash drive must be connected during the entire
upgrade process.
10. Validate the Software version by going to System Setup then
Information.
CellXtract™ User Manual
60
OTHER FEATURES
iTunes Update Instructions
Starting with software 1.5.x.x, iTunes will be automatically updated (if needed)
during the CellXtract software update.
NOTE: If iTunes needs to be updated, the CellXtract software update can take
up to 50 minutes to complete
System Setup
Tapping the System Setup button from the main screen brings up the CellXtract Setup
Menu:
CellXtract Setup menu
Logical Extraction
Tapping this button brings up the Logical Extraction Settings screen.
Logical Extraction Settings
CellXtract™ User Manual
61
OTHER FEATURES
Extract Files – Checking this box will cause CellXtract to extract the target
device’s files
Automatically Extract All Files – Checking this box will automatically
download all Extended Data files without prompting the user. This includes
all image, video, audio and other files.
Skip Messages During Extraction – Checking this box gives the option to
skip unread SMS messages during extraction. During a capture session, a
window will appear allowing you to choose whether to skip message
extraction or not. The prompt gives the user 15 seconds to skip or
download unread SMS messages. If none of the buttons are pressed, then
the messages are skipped.
Do extended SIM file acquisition – This setting will pull all available data
off of the SIM card and generate a SIMDAT file.
Create Network Isolation Card after SIM Capture – Checking this box
will allow some SIM data to be copied post SIM extraction to a target
Network Isolation Card (NIC). The newly created NIC installed in the
handset and contains enough information to appear to be the original SIM
card, but it will not have the necessary information to allow the handset to
connect to the network. This effectively provides Network Isolation for the
phone.
Extract ALL Android files – This setting, when checked, will extract all
Android files in a logical extraction.
Export data as XML (as well as SQLite3) – When checked, this will
export the data to an XML file. The SQlite3 file will still be generated.
Physical Extraction
Tapping this will allow you to change settings involving the physical
extraction of devices.
Logical Extraction Settings
Extract all Android partitions – With this setting checked, all disk
partitions on the Android handset will be extracted. Each partition will be
extracted and can be seen on the external storage location in the User
Files folder.
CellXtract™ User Manual
62
OTHER FEATURES
Recover files from whole partition - This option attempts to recover files
from the different partitions.
Export data as XML (as well as SQLite3) – When checked, this will
export the data to an XML file. The SQlite3 file will still be generated.
Display
Accessing this screen will allow you to increase or decrease the brightness
of the screen.
Display Settings
Information
Tapping this button will bring up a screen that shows Logicube Technical
Support contact information. The top of the screen will contain the
CellXtract’s serial number (CellXtract Number), software subscription
expiration date (license expiry), days remaining on the software
subscription (Days Remaining), software and firmware versions. To ensure
that you continue to receive software updates (for compatibility with new
phones and new feature releases) contact Logicube sales or Technical
Support to renew your subscription prior to the expiration date. Software
subscription expiration does not affect the operation of CellXtract.
Information screen
CellXtract™ User Manual
63
OTHER FEATURES
It also allows the user to insert his or her company logo into the printed
reports.
1. On the user’s PC, rename the logo to LOGO.jpg. Make sure that it
is less than 1MB in size.
NOTE: The logo’s name is case sensitive, so it needs to be saved
exactly as LOGO.jpg.
2. Copy the logo to the root directory of a USB storage device.
3. In the screen above, tap the “Change Logo” button.
4. Insert the USB storage device to an available USB port on the right
panel.
5. Tap the OK icon.
6. The logo will be automatically copied to CellXtract and overwrite
any existing logo.
Report
Tapping this button brings up the Report Settings screen. Checked items
are represented by a blue box.
Report Settings menu
On Screen Report Settings
Show Unread Messages – Un-checking this box prevents
CellXtract from showing any unread SMS messages on
screen. This setting can be used for any phones that
change extracted unread messages to read status.
Show Hashes – Checking this box will display the MD5
Hash Value for all extracted data files.
Show Error Descriptions – Checking this box will show
detailed error descriptions for any failure to extract data. If
unchecked, failure messages will read: ”An error occurred
during the extraction of this section of data”.
Show Image Metadata – Checking this box will include
metadata information with any downloaded images.
NOTE: All metadata may not be retrieved from
every image extraction.
CellXtract™ User Manual
64
OTHER FEATURES
Show Non-downloaded Files – Un-checking this box
replaces the list of non-downloaded files on the screen with
a statement that the user has chosen not to show nondownloaded data.
Output Report Settings
Show Unread Messages – Un-checking this box prevents
CellXtract from showing any unread SMS messages on the
report.
Show Hashes – Checking this box will display the MD5
Hash Value for all extracted data files.
Show Error Descriptions – Checking this box will show
detailed error descriptions for any failure to extract data. If
unchecked, failure messages will read: ”An error occurred
during the extraction of this section of data”.
Show Image Metadata – Checking this box will include
metadata information with any downloaded images on the
report.
Show Image Thumb Nails – Checking this box will show
thumb nail images of any downloaded image files on the
report.
Show Non-downloaded Files – Un-checking this box
replaces the list of non-downloaded files on the report with
a statement that the user has chosen not to show nondownloaded data.
Advanced Button
This button is reserved for troubleshooting purposes only when directed by
Logicube Technical Support.
Shutting Down CellXtract
The system can be shut down directly from the Main Application Screen. Tap the “Shut
Down” button and confirm the action. CellXtract will automatically power itself down.
Shut Down screen
CellXtract™ User Manual
65
6. Reference
Extraction notes
This section contains extraction information and notes regarding specific handsets, phone
Operating Systems, or devices.
SQLite Viewer
CellXtract now includes an SQLite Viewer which allows SQLite databases
to be explored – SQLite databases can be found in Apple, Android OS
devices, BlackBerry and Symbian OS Series 60 smartphones. Apps such
as Apple Safari and Opera store data in SQLite databases.
An SQLite database looks like the following screen when viewing extracted
data.
Tap the link in the extracted data entry (in this example, tap “view file
content as HEX/ASCII”. The following screen will appear:
Tap the SQLite Viewer button to open the SQLite Viewer.
CellXtract® User Manual
66
REFERENCE
Android Devices
CellXtract has the capacity to extract information from mobile
devices that use Google’s Android operating system. Extracted
data includes: Contact details, Call Logs, SMS messages,
Calendar/Tasks and Files. CellXtract supports extraction of
contacts database on handsets running on Android 2.2 operating
system.
For physical extraction of Android devices, please refer to Chapter 7 –
Physical extraction.
Before an extraction can be performed, users must:
1. Select “Unknown Sources” and “USB debugging” in the target
devices application settings.
2. Ensure the target device has a formatted SD Card inserted.
The Android extraction process requires the use of an application (Agent)
which is automatically installed onto the target device and executed. The
Agent extracts data from the device and stores in a temporary file called
ANDDAT on the devices SD Card. (\sdcard\ANDDAT). At the end of the
extraction, the ANDDAT file is deleted from the card and the Agent is
automatically uninstalled.
Supports physical extraction and decoding of Android phones
Supports Android O/S 1.6 through 2.3.4
Supports Android file systems EXT3, EXT4 and RFS, and provides
limited support for YAFFS2. YAFFS2 is expected to be fully supported
in a future release
Supports dumping and decoding of contacts, call logs, SMS, emails
and user files
Can extract deleted file items such as databases, images, video, audio
and documents
CellXtract™ User Manual
67
REFERENCE
It is expected that most Android phones using the above mentioned
Android O/S and/or file systems will be supported.
Samsung Galaxy S3
The following Samsung Galaxy S3 devices can be rooted.
Not all Samsung Galaxy S3 models have been
validated, if your handset model is missing from
the Android model list, please select Android
Generic.
NOTE: Rooting Samsung Galaxy S3 requires permanently
flashing a new insecure bootloader image onto the device.
The device will remain permanently rooted.
NOTE: 100% successful rooting is not guaranteed. In rare instances
rooting can render the handset inoperable. Proceed with caution.





























CellXtract™ User Manual
SAMSUNG I9300 4.0.4 build IMM76D
SAMSUNG I9300 4.0.4 build IMM76D
SAMSUNG I9300 4.0.4 build IMM76D
SAMSUNG I9300 4.1.1 build JRO03C
SAMSUNG I9300 4.1.1 build JRO03C
SAMSUNG I9300 4.1.2 build JZO54K
SAMSUNG I9300T 4.1.2
SAMSUNG I9305 4.1.1 build JRO03C
SAMSUNG I9305 4.1.1 build JRO03C
SAMSUNG I9305 4.1.1 build JRO03C
SAMSUNG I9305 4.1.1 build JRO03C
SAMSUNG I9305 4.1.2 build JZO54K
SAMSUNG I9305 4.1.2 build JZO54K
SAMSUNG I9305N 4.1.1 build JRO03C
SAMSUNG I9305N 4.1.2
SAMSUNG I9305T 4.1.2
SAMSUNG SCH-I535 4.0.4 build IMM76D
SAMSUNG SCH-I535 4.1.1 build JRO03C
SAMSUNG SCH-I535 4.1.2
SAMSUNG SCH-I939 4.1.2
SAMSUNG SCH-R530 4.0.4 build IMM76D
SAMSUNG SCH-R530 4.1.1 build JRO03C
SAMSUNG SCH-R530 4.1.2
SAMSUNG SCH-R530M 4.0.4 build IMM76D
SAMSUNG SGH-I747 4.0.4 build IMM76D
SAMSUNG SGH-I747 4.1.1 build JRO03C
SAMSUNG SGH-I747 4.1.1 build JRO03L
SAMSUNG SGH-I747M 4.0.4 build IMM76D
SAMSUNG SGH-I747M 4.0.4 build IMM76D
68
REFERENCE










SAMSUNG SGH-I747M 4.1.1 build JRO03C
SAMSUNG SGH-I747M 4.1.2
SAMSUNG SGH-T999 4.0.4 build IMM76D
SAMSUNG SGH-T999 4.1.1 build JRO03C
SAMSUNG SGH-T999 4.1.2
SAMSUNG SGH-T999V 4.0.4 build IMM76D
SAMSUNG SGH-T999V 4.1.1 build JRO03C
SAMSUNG SPH-L710 4.0.4 build IMM76D
SAMSUNG SPH-L710 4.1.1 build JRO03C
SAMSUNG SPH-L710 4.1.2
Android Ad-hoc device rooting
CellXtract can attempt ad-hoc rooting of Android Devices.
This allows CellXtract to extract the complete file structure
of the device. Ad-hoc rooting does not work with all
Android devices. Rooting is removed after the device is
restarted. Please check with local laws governing rooting
prior to using.
Android OS versions 1.6-2.3 are supported
Gives access to the whole file system. After
rooting/data/data and/data/misc folders of Android
device internal memory are available for analysis.
Without root permissions these folders are
inaccessible.
100% successful rooting is not guaranteed
NOTE: 100% successful rooting is not guaranteed. In rare instances
rooting can render the handset inoperable. Proceed with caution.
Ad-hoc rooting will provide the following features:
-
Allows user to access the whole device file system
Deleted data in database tables (deleted contacts,
messages, etc.)
Pre-installed and custom applications with user data
Yahoo! Mail and Google Mail application data
Google Maps, Google Talk and Google Calendar
application data
Dropbox application data
Ad-hoc device rooting is not required for the data
extraction of Call Logs, Phonebook and Messages.
When performing an Android extraction, CellXtract will ask
if you want to temporarily “Root” the Android device. If
successful, the device will remain rooted until turned off.
CellXtract™ User Manual
69
REFERENCE
If the device is not rooted, only the following file locations
will be extracted:
/sdcard/
If the device is rooted and the checkbox for ‘Extract ALL
Android files’ is not checked, only the following file
locations will be extracted:
/sdcard/
/data/data/
/data/misc/
Android Email
CellXtract can extract data from the default email and Gmail
databases.
Device must be temporarily rooted
Email attachments not supported
Email body preview only
Android App Data
The Android extraction can extract data from the following
apps:
Dolphin Browser
eBuddy Messenger
Facebook Messenger
Firefox Browser
Google Maps, Google Calendar, Google Hangouts,
Google Mail, and Google Talk application data
Line
Skype
Skyfire Browser
Tumblr
Viber
WhatsApp Messenger
Yahoo Messenger
NOTE: The Android device must be rooted for the above
data to be extracted.
eBuddy Messenger, Facebook Messenger, Google
Hangouts, Google Talk, Line, Skype, Viber, WhatsApp
Messenger, Tumblr, and Yahoo Messenger are
categorized as IM Data and can be found in the following
report sections: IM Contacts, IM Calls and IM Chat.
Dolphin Browser, Firefox Browser, and Skyfire Browser
data can be found in the URLs report section.
Google Maps data can be found in the Locations report
section.
CellXtract™ User Manual
70
REFERENCE
Android Location Information
The Android extraction can extract Cell and WIFI connection
location information which includes GPS coordinates and
timestamps. This information is shown in the Location
Information section of the report. CellXtract also generates a
Google Earth .KML file called GPSData.kml which is created
in the extracted data files folder. This file can be imported
into Google Earth. Note: The device must be rooted to
acquire location information.
Android files of Interest
The Android extraction can extract system files *. Some of
these files may contain useful information. These files are
described below: C:\data\data\com.google.android.location\files\cache.wifi
Contains cached WIFI connection details.
C:\data\data\com.google.android.location\files\cache.cell
Contains cached Cell connection details.
C:\data\data\com.android.providers.userdictionary\datab
ases\user_dict.db
Containing cached user entered text
C:\data\data\com.google.android.gm\databases\gmail.db
C:\data\data\com.google.android.gm\databases\mailstor
e.*.db
Contains Google email account and mailstore databases
C:\data\data\com.google.android.talk\shared_prefs\Budd
yList.xml
Contains Google Talk contact details
C:\data\data\com.android.providers.calendar\databases\
calendar.db
Contains Google calendar details
C:\data\data\com.yahoo.mobile.client.android.mail\datab
ases\mail.db
Contains Yahoo email details
NOTE: Device must be rooted to acquire some of these files.
CellXtract™ User Manual
71
REFERENCE
Apple iPhone Devices
Apple iOS 7 is supported with CellXtract software 1.7.x.x. iTunes will
automatically be updated during the CellXtract 1.7.x.x software installation.
PList Viewer
CellXtract now includes a PList Viewer which allows Apple
Property List binary XML files to be viewed. Plist files may
contain a lot of valuable forensic information such as
browser history, Wi-Fi access points, speed dials,
Bluetooth settings, global applications settings, Apple
Store settings etc.
A PList database looks like the following screen when
viewing extracted data.
Tap the link in the extracted data entry (in this example,
tap “view file content as HEX/ASCII”. The following screen
will appear:
Tap the PList Viewer button to open the PList Viewer.
CellXtract™ User Manual
72
REFERENCE
iPhone Passcode Bypass
CellXtract can extract data from a passcode locked iPhone
if specific iTunes .plist files from a PC or Mac are available.
The iPhone’s passcode must have been enabled then
synced with the PC or Mac after the passcode was
enabled. The PList files will need to be copied from the PC
or Mac to a specific folder/directory on a USB drive.
1. Locate iTunes .plist files from synced PC or Mac.
These can be found in the following locations:
Windows 98/ME/2000/XP iTunes Users:
C:\Documents and Settings\All Users\Application Data\Apple\Lockdown\
Windows Vista iTunes Users:
C:\Users\<User Name>\AppData\Roaming\Apple Computer\Lockdown\
Windows 7 iTunes Users:
C:\ProgramData\Apple\Lockdown\
NOTE: Windows file locations are hidden by the Operating
System by default. There are different ways of showing
CellXtract™ User Manual
73
REFERENCE
hidden files depending on the Operating System. Please
search the Internet or contact Microsoft support for
instructions on how to show hidden files.
Mac OS X iTunes Users:
VolumeName\Users\<User
Name>\Library\Lockdown\
Or
/var/db/lockdown
2. Copy all iTunes .plist files to the following directory
on a USB drive (It is recommended that the USB
drive is formatted before creating
\CellXtract\Lockdown directory and copying .plist
files):
:\CellXtract\Lockdown\
3. Insert USB drive into CellXtract unit and perform a
regular iPhone extraction. CellXtract will then search
the USB drives for any .plist files and import them if
found.
iPhone App Data
The iPhone extraction can extract data from the following
apps:
 Apple Maps (iOS 6 and above only)
 eBuddy Messenger
 FaceTime
 Line
 Skype
 Tumblr
 Viber
 WhatsApp Messenger
 Yahoo Messenger
Apple maps report will contain GPS coordinates and Google
Maps hyperlinks (added to the “Locations” section of the
report). Data is exported in KML format, which can be opened
using Google Earth, Google Maps, and Google Maps for
mobile.
eBuddy Messenger, Line, Skype, Yahoo Messenger, Viber,
WhatsApp Messenger and Tumblr data is categorized as IM
Data and can be found in the following report sections: IM
Contacts, IM Calls and IM Chat.
FaceTime data can be found in the Calls report section.
CellXtract™ User Manual
74
REFERENCE
iPhone files of Interest
During the iPhone extraction process a number of ‘other’
files can be extracted. Some of these files may contain
useful information.
A selection of these files is shown below:
/library/cookies/cookies.plist
Contains web site cookies saved by the Safari browser.
/library/mail/accounts.plist
Contains details of the email server accounts that are
configured on the device. Emails cannot be obtained by
CellXtract.
/media/webclips
Contains a list of web page shortcuts assigned to the
device's main screen. Each webpage is stored in a
separate directory that contains a property list called
Info.plist. This property list has details of the title and
URL of each page.
/library/maps/history.plist
Contains a ‘Google Maps’ history file which includes
addresses, route directions and other useful data.
/library/safari/history.plist
Contains the Safari web browser history from when it
was last cleared.
/library/keyboard/dynamic-text.dat
A keyboard cache containing text entered by the user.
/Library/preferences/com.apple.maps.plist
Contains the last longitude/latitude coordinates viewed
in the ‘Google maps’ application.
/library/preferences/com.apple.mobilesafari.plist
Contains a list of recent searches performed using the
Safari browser
Note: The content of these files has not been verified.
Apple Location Information
The file GPSData.kml is created when extracting an
iPhone. This file can be opened using Google Earth.
iPhone Support – User Application Notes
iTunes
CellXtract™ User Manual
75
REFERENCE
Do not install versions of iTunes that is not supported by
the CellXtract software release. The CellXtract software
will automatically update iTunes if necessary.
iPhone 5
The iPhone 5 is expected to work, but at this time has not
been fully validated by Logicube.
Skype
CellXtract supports extraction of Skype data from Apple
iPhones. Extracted data includes
Voice/Video calls
In the extraction report, Skype voice/video calls are shown
under the Call Register section
Chat messages
In the extraction report, Skype chat messages are shown
in the Messages section
User profiles
In the extraction report, Skype user profiles are shown in
the Contacts section
BlackBerry Devices
BlackBerry devices can only connect via Cable. BlackBerry devices that
are password-protected will need to be unlocked before data can be
extracted.
Unlocking a BlackBerry Device
The CellXtract allows the user to input the PIN lock for a
BlackBerry device directly through the CellXtract interface
rather than the device itself. The CellXtract will
automatically detect if a PIN lock is enabled and bring up
the Enter Password Prompt.
Enter Password Prompt
TIP: Tap “Hide Password” to turn it on or off. If Hide
Password is on, the password will appear.
CellXtract™ User Manual
76
REFERENCE
Hide Password Turned On
NOTE: The password or the PIN of the BlackBerry device
will need to be entered. CellXtract cannot unlock the
device without it.
BlackBerry Personal ID Numbers (PINs)
Each BlackBerry device is assigned a unique personal
identification number (PIN), which allows identification of
each device.
The PIN number of other BlackBerry users is stored in the
devices phonebook with their contact information and
allows direct PIN-to-PIN emailing and messaging.
CellXtract extracts each contact PIN number from the
phonebook as well as the PIN numbers associated with
messages sent from other BlackBerry users.
Windows Mobile Devices
Windows Mobile devices need to have Active Sync enabled before they
can be set to Infrared mode. Please refer to the “Connection Options”
section in Chapter 2.
Windows mobile 7 phones will be supported in a future release.
Various Windows Mobile Devices
The following mobile GPS software has been verified and
can be extracted from supported devices using CellXtract:

Google Maps Mobile on Various Windows Mobile
devices
Symbian Devices
CellXtract will extract information from mobile handsets that use the
Symbian operating system (Series 60 / Nokia Symbian OS V 8.1).
CellXtract™ User Manual
77
REFERENCE
Extracted data includes Contact Details, Call Logs, SMS messages,
Calendar, Tasks and Files.
This data capture is possible with the following caveats:
No SIM data is extracted from Symbian handsets.
“Nicknames” are not extracted.
Cannot extract any SMS messages stored in 'My Folders' directory or other
user created folders.
To extract data, it is necessary for CellXtract to write temporary .dat files to
the target phone. These files are removed at the end of capture.
nd
Capture from Symbian UIQ 2
rd
& 3 Edition OS
CellXtract will extract information from mobile handsets
nd
rd
that use the Symbian UIQ 2 and 3 Edition OS. Extracted
data includes Contact Details, Messages, Calendar, Tasks
and Files.
Data capture requires a handset Agent and the use of a
CellXtract UIQ memory card. This is a specially prepared
card by CellXtract to temporarily store and transfer data.
WARNING: Do not create the UIQ memory card from the
card used inside the handset. Always use a separate
blank, formatted card that is not write-protected.
Follow these steps to capture data:
1. User inserts spare memory card into the memory card
reader.
2. CellXtract generates and formats a UIQ card and installs
the Agent.
3. User then inserts the UIQ card into handset.
4. User locates the Agent installer on the UIQ card using the
file browser application and then installs the agent onto the
device.
5. User locates and runs the Agent application, then waits for
the data extraction to complete. Extracted data is now
stored on the UIQ card.
6. User removes the UIQ card from the handset and inserts it
back into the memory card reader.
7. CellXtract automatically copies and decodes all data from
the UIQ card.
8. CellXtract formats the UIQ card.
9. CellXtract instructs the user to uninstall the agent from the
handset.
10. CellXtract presents the results to the user.
This data capture is possible with the following caveats:
CellXtract™ User Manual
78
REFERENCE
Extraction of Call Logs is not supported.
Extraction of SMS messages stored in user created folders
is not supported.
Extraction of MMS / Email messages is not supported.
Memory cards within these phones need to be captured
separately. (Please refer to “Attaching a Flash Memory
Card” section in Chapter 2).
Symbian Event Logs
nd
rd
Symbian S60 2 Edition and 3 Edition handsets have the
ability to record events which CellXtract will extract.
The following information can be extracted:
Voice Call events – ID, Number, Date, Time,
Direction and Duration
SMS events – ID, Number, Date, Time, Direction,
Message Fragment and Status
MMS events – ID, Name, Date, Time, Direction
and Duration
These events are normally accessed by the handset’s Log
Viewer application. These events have a validity period set
in the Log Viewer settings. Once this duration period has
expired, events will no longer be accessible.
Points of Interest
Timestamps extracted by CellXtract are always
reported in Greenwich Mean Time (GMT) whereas
the timestamps shown in the handset’s Log Viewer
application are set to the handset’s current time
zone.
CellXtract is able to extract message fragments for
SMS events. These are not displayed by the Log
Viewer application. Only the first 64 characters of a
message are reported any messages greater than
64 characters are truncated in the event log,
including multipart messages where only the first
64 characters of the first message part are
reported.
Incoming MMS messages are shown as 2
separate events, 1 incoming SMS event and 1
outgoing MMS event. CellXtract extracts both of
these events. The SMS event has a body fragment
of Data Message
The following Symbian S60 handsets are verified on
CellXtract:
CellXtract™ User Manual
79
REFERENCE
NOKIA: 3230, 3250 5320XpressMusic, 5500 Sport, 5700,
6120, 6220 Classic, 6260, 6290, 6620, 6630, 7610, E50,
E51, E61, E63, E65, E66, E70, E71, N70, N71, N72, N73,
N76, N77, N79, N80, N81, N82, N85, N90, N91, N93,
N93i, N95, N95 8GB
SAMSUNG: I8510, SGH-D720, SGH-G810
Palm OS Devices
Palm OS devices are supported with the following caveats:
Extraction of SMS messages is currently not supported.
Extraction of user files is currently not supported.
CellXtract is able to collect the following information from Palm
devices: Contact Details, Call Logs (if available), Calendars,
Tasks, Notes and Palm Database (PDB) files. PDB files are where
Palm OS keeps data stored in RAM. The data is kept in database
format. These files can contain user data.
Motorola Devices
The extraction of Unicode characters for all data sets has not been verified
for Motorola devices.
Before an extraction begins with one of these devices the CellXtract will
offer the user a choice:
1. Extract validated data set only. This means that some Unicode
data will not be extracted.
2. Attempt to extract all Unicode data. Software will try to extract
Unicode characters for all data sets on the device. At this time the
output in this case is not guaranteed by validation testing.
Time/Date Stamps from Motorola Phones
Users should note that Motorola timestamps / date stamps
are not reported due to current limitations in how file
“modified” and file “created” timestamps are reported in the
Motorola OS.
Sony Ericsson Devices
The extraction of Unicode characters for all data sets has not been verified
for Motorola devices.
Before an extraction begins with one of these devices the CellXtract will
offer the user a choice:
1. Extract validated data set only. This means that some Unicode
data will not be extracted.
2. Attempt to extract all Unicode data. Software will try to extract
Unicode characters for all data sets on the device. At this time the
output in this case is not guaranteed by validation testing.
CellXtract™ User Manual
80
REFERENCE
Data Capture from Sony Ericsson Phones
If the User runs into trouble capturing data from a Sony
Ericsson phone users should make sure that the “Default
Contacts” setting on the target handset is set to “Phone
Contact” before an extraction is performed.
This is done by navigating manually on the phone’s menus
as follows:
Menu > Contacts > Options > Advanced > Default
Contact > Select “Phone Contact”.
Once this setting is enabled, users should have no trouble
extracting data from the handset.
Unlocking Sony Ericsson Handsets
CellXtract is able to deactivate Sony Ericsson handset lock
codes of up to 8 digits.
Some handsets may not be able to establish a USB
connection whilst the handset lock is active. In this case
CellXtract will first attempt to locate device drivers then ask
the user to confirm the handset is locked.
If yes the user is instructed to restart the handset and reconnect it before the unlock code screen appears.
Tap OK to unlock the handset.
NOTE: Depending on the code that has been set
CellXtract may take some time to unlock the handset.
Below is a guide as to how long unlocking may take. To
attempt to unlock:
All 4 digit codes up to 4 mins
All 5 digit codes up to 40 mins
All 6 digit codes up to 7 hours
All 7 digit codes up to 3 days
All 8 digit codes up to 30 days
The Activity log will show the progress of the unlocking
process.
NOTE: The unlocking process can be cancelled at any
time. However data extraction cannot be performed on a
locked handset. If the process is cancelled without finding
the unlock code, it will need to be started again to unlock
the handset.
Once the handset has been unlocked data extraction will
be performed automatically. The unlock code is displayed
in the Device Information section of the report.
CellXtract™ User Manual
81
REFERENCE
NOTE: CellXtract only unlocks the handset; it DOES NOT
remove the handset lock. If the handset is restarted after
the extraction the code will need to be re-entered.
NOTE: CellXtract cannot unlock handsets that do NOT
contain a SIM card.
Siemens Devices
Occasionally, Siemens handsets have been known to return a NULL
response when asked for data of a particular type (i.e. SMS messages). If
this happens, the following error message will appear under the relevant
data type:
Handset has been known to occasionally return a null response.
Please refer to handset and retry extraction.
Users should check the affected field(s) on the handset and retry the
extraction.
Other Extraction Notes
CellXtract can playback W4A files that have been extracted from devices.
W4A files are audio files that can be created on some mobile handsets.
GPS Extraction Notes
The following describe some extraction notes for specific GPS devices:
Tom Tom Devices
If a TomTom GO 720 is to be selected, choose “TomTom
GO 720”. After capture, you will get an opportunity to
capture the memory card separately. If present, remove
the memory card from the GPS device. This will be
captured later.
WARNING: ALWAYS remove the Memory Card from a
TomTom device prior to capture.
NOTE: TomTom can store the same information in the
device and on the Memory Card. For that reason, the
device and card may contain different sets of the same
type of data (i.e. application info, favorite destinations,
etc.)
The following information can be extracted from the
supported TomTom Devices:
Device information - Manufacturer, Model, Serial Number
Owner information - Owner’s Name, Owner’s Street,
Owner’s Town, Owner’s City
CellXtract™ User Manual
82
REFERENCE
GPS location information - ‘Home’ address with GPS
coordinate, ‘Favorite’ addresses with GPS coordinates,
‘Destination’ addresses with GPS coordinates, ‘Recent’
addresses with GPS coordinate, ‘Miscellaneous’
addresses with GPS coordinates
Telecommunication information (only on supported
devices) - Telephone contact information stored on
TomTom, Telephone numbers called via the TomTom,
Telephone numbers of calls received via the TomTom,
SMS messages received via the TomTom, SMS messages
sent via the TomTom
Files (only on supported devices) - MP3 files, JPEG files
Garmin Devices
The following information can be extracted from Garmin
devices: manufacturer, model, serial number, “favorite”
addresses with GPS coordinates.
After the GPS Device is extracted, press “Memory Card”
on the screen that appears. Follow the directions for
Connecting a Memory Flash Card earlier in this chapter.
HP Satellite Navigation Devices
The following information can be extracted from HP
satellite navigation devices:
GPS location information – ‘Favorite’ addresses with
GPS coordinates, Route ‘Waypoint’ addresses with GPS
coordinates, ‘Search History’ addresses with GPS
coordinates.
Telecommunication information - Contact information,
call registers.
Files - User files can also be retrieved from the device by
performing a separate Flash Media extraction.
Generic GPS Extraction
CellXtract can search certain devices for GPS data
generated by any of the following GPS Software:
CoPilot 6
Garmin
Navman Smart ST
NavNGo
NDrive
TomTom
The data files generated by this software can be stored on
devices without any GPS software installed. This data can
still be extracted using CellXtract.
CellXtract™ User Manual
83
REFERENCE
Devices which GPS Data can be extracted from are:
Sat-Nav GPS Devices
Windows Mobile Devices
Flash Media Cards
Mass Storage Devices
NOTE: GPS Devices can be used to store data generated
from other devices. Therefore, care must be taken when
linking data to a specific device.
The following GPS Data can be extracted:
‘Favorite Locations’ - These are a list of addresses
and/or coordinates which a user has chosen to
store on the device. They can contain Home and
Work locations.
‘Recent Destinations’ – These are a list of previous
destinations the owner has selected to navigate to.
‘Route Waypoint Data’ – These are a list of
addresses and/or coordinates which form set
locations along a route that the user has created.
‘History’ - This is a list of addresses and/or
coordinates that the owner has previously
searched for or viewed. This list may also contain
Favourite and Route Waypoint Locations. This list
differs from Recent Destinations in that the owner
may not have selected to navigate to the location.
NOTE: The presence of any of the above data on a device
does not indicate that the owner has been to that location.
Only that the owner chose to view and/or save that location
on the device.
CellXtract will also extract Telecommunications data from
some Sat-Nav GPS Devices.
The following Telecommunications data can be extracted:
Contact information
Telephone numbers called via the GPS Device
Telephone numbers of calls received via the GPS
Device
SMS sent and received via the GPS device
This information is extracted from the data files created by
the above software only. Mobile communication devices
may have a separate store for this information.
NOTE: It is recommended that a separate PDA extraction
be performed on all WinMobile devices to obtain
Telecommunication Data
CellXtract™ User Manual
84
REFERENCE
GPS Track Logs
CellXtract can extract GPS track logs from devices
manufactured by:
Garmin
Navman
HP
Track logs record the GPS coordinates of the device every
1-2 seconds giving an accurate description of where the
device has been and when.
The CellXtract report shows only the start point of each
stored track log, as each track can potentially store
thousands of points.
Track log data is best viewed by importing the
GPSData.gpx into Google Earth.
NOTE: Some devices start logging as soon as they
are turned on, however other devices require the
user to initiate logging to record track log data.
Opening GPSData.gpx Output Files in Google Earth
CellXtract generates an additional data file when extracting
GPS Data. This file contains GPS data and can be
imported into Google Earth to display the data.
The data file GPSData.gpx is created within the extraction
folder automatically when a GPS extraction is performed.
The data file stores all waypoints, routes and track log data
in a format which can be used by Google Earth to display
all of the GPS data in the report.
NOTE: Google Earth 5.0 will need to be installed on a PC
to view the GPSData.gpx file. This can be downloaded
from: http://earth.google.com
Open Google Earth and tap the File menu.
Google Earth (part 1)
CellXtract™ User Manual
85
REFERENCE
Then select Open
Google Earth (part 2)
Navigate to the location where the extracted data files are
stored.
Opening GPSData files
In the Files of type drop down box select Gps (*.gpx *.loc
*.mps) and then select the GPSData file and tap open.
Alternatively you can drag the GPSData.gpx file into
Google Earth.
The GPS Data Import window appears allowing you to
choose what types of data you want to import.
CellXtract™ User Manual
86
REFERENCE
Google Earth data types
To display all GPS fixes along a saved track log make sure
you check the Create clickable image for track and route
points.
Google Earth import options
The data is then displayed on the map and can be selected
using the Places navigation panel.
CellXtract™ User Manual
87
REFERENCE
Google Earth view
A full Google Earth User Guide can be viewed at:
http://earth.google.com/intl/en/userguide/v5/
NOTE: Google Earth imports GPS coordinates, Time and
Date, Altitude and waypoint name data only. Any other
information displayed in Google Earth has been inferred by
the Google Earth software.
Geo-Tag Data from Images
CellXtract will display Geo-Tag data for images that have been captured
using a device with a GPS receiver.
A Geo-Tag consists of latitude and longitude coordinates and adds
geographical identification to an image.
Geo-Tag information is automatically extracted and appears in the
metadata section associated with an image.
Geo-Tag
NOTE: Geo-Tagging is only displayed if the image has been captured
using a device that supports geo-tagging.
CellXtract™ User Manual
88
7. Physical Extraction
Introduction
Physical extraction is available on both CellXtract and CellXtract-TNT. This feature performs a
physical extraction of Android phones. Android OS 1.6 through 2.3.4 are currently supported. The
version of Android OS can be found on the handset by navigating to Settings, then About Phone.
Android physical extraction requires root access. If the phone is not already rooted, CellXtract will
attempt to temporarily root the phone. This is not a permanent root and the device can be un-rooted
by either turning the phone off then back on or by removing the phone battery.
CellXtract extracts a physical memory dump from each selected memory partition. For each
memory dump CellXtract will:
a. Attempt to reconstruct the file system and then search for contacts, call logs, SMS, emails
and user files (audio, images, etc.) and
b. Scan the dump for deleted and embedded data.
As well as the regular CellXtract report, the results from each extraction will include one or more
memory dumps, one or more reconstructed file systems (stored in the User Files folder ) and
deleted and embedded data (stored in the Recovered Files folder).
Step by Step – Physical Extraction
The Physical Extraction process on the CellXtract or CellXtract-TNT is composed of the following
steps:
Attaching an external storage location
Selecting Physical Extraction and the handset
Connecting the handset
Case Details screen
Performing the extraction
Report Preview
NOTES:
-
Make sure the AC adapter is connected to the CellXtract when performing a
physical extraction. The physical extraction process may take several hours.
-
The storage capacity of the external storage location must be larger than the
amount of memory on the phone itself (internal memory). This is not the
capacity of the micro SD card. To find out the amount of memory on the phone,
refer to the manufacturer’s website.
CellXtract® User Manual
89
PHYSICAL EXTRACTION
Attaching an external storage location
1. Attach an external storage location such as a USB flash
drive or USB external drive to one of the available USB
ports on the right panel. This will allow CellXtract to save
extracted files and the report to the selected external
storage location.
NOTE: Some handsets may contain flash images that
exceed 4GB. If the external storage (USB flash drive or
USB external drive) is formatted to FAT32 the file size
limitations (4GB) of the FAT32 format can cause
unsuccessful extraction results. In these cases, the
external storage media (USB flash drive or USB external
drive) must be formatted to a file system which supports
file sizes greater than 4GB such as NTFS.
Selecting Physical Extraction and the handset
2. From the main screen, tap Read New Device.
3. Select Cell Phone.
4. Select Physical Extraction.
5. Select By O/S.
6. Select either Android OS or Nokia 1100 then tap the
Select icon.
Connecting the Handset
7. For Android devices, follow the on-screen instructions to
enable Unknown Sources and USB Debugging.
CellXtract™ User Manual
90
PHYSICAL EXTRACTION
8. Follow the on-screen instructions to connect the correct
cable.
9. Follow any other on-screen instructions that may appear.
Case Details Screen
10. The Case details screen will appear. You can fill out the
case details at this time then tap the OK icon or tap the
Later button if you want to fill out the information later.
Performing the Extraction
11. The extraction process will begin. This process may take
several hours to finish.
12. When the extraction is finished, a window will appear
stating the extraction is complete. At this point, you can
CellXtract™ User Manual
91
PHYSICAL EXTRACTION
disconnect the phone and cables. Tap the OK icon to
continue.
Report Preview
13. The report preview will appear. From this screen you can
view the extracted data.
NOTE: The following data can be extracted from
the phone and shown on the report:
Device Info
Contacts
Call Registers
Messages
Other (Calendar, Tasks and Notes)
Extended Data (Images, Audio, Video, and
other files)
Recovered Data (Deleted, Embedded &
Extant files)
14. The external storage location will contain a copy of each of
the phone’s partitions and is located in the User Files
folder.
15. The external storage location will contain a copy of the
deleted, embedded and extant files recovered from each of
the phone’s partitions and is located in the Recovered Files
folder.
CellXtract™ User Manual
92
PHYSICAL EXTRACTION
Android Disk Partition Settings
By default CellXtract will only extract the handsets data
partition. To extract all partitions you must tick the “ALL
Android disk partitions (physical)” in the Physical
Extraction Settings. Please note this may take a long time
to complete the extraction.
CellXtract™ User Manual
93
8. CellXtract-TNT
Introduction
The CellXtract-TNT has all the capabilities of CellXtract plus the ability to extract data from
major Chinese-manufactured chipsets: MediaTEK (MTK), Infineon, Spreadtrum, MSTAR,
and Cool Sand chipsets. It performs a physical extraction of the handset’s memory, which is
saved in a binary file and provides a report that is simple and easy to read and review. The
report can be viewed directly on the CellXtract-TNT or be taken to another computer to be
viewed. In addition, for MTK chipset, there is a logical extraction option. If logical is
selected, CellXtract-TNT will attempt to extract data by physical and logical methods and
report all the data recovered in one report.
There are several different bootloaders available for each chipset type. If the Auto
bootloader option in CellXtract-TNT fails, then you will need to try each of the bootloaders
available for each chipset (listed below) until successful.
MediaTek
Boot 0 – Auto
Boot 1 – Boot A (6223/25/26)
Boot 2 – MTK_AllInOne_DA_V3.1004 (62xx)
Boot 3 – Boot D (Dedicated to the MT6235 invalid IMEI)
Boot 4 - MTK_AllInOne_DA_V3.1032 (62xx)
Boot 5 - MTK_AllInOne_DA_V3.1108 (62xx)
Boot 6 - MTK_AllInOne_DA_V2.1131(65xx Android)
Boot 7 - MTK_AllInOne_DA_V5.1148 (62xx)
Boot 8 - MTK_AllInOne_DA_V5.1205 (62xx)
Boot 9 - MTK_AllInOne_DA_V7.1216 (65xx Android)
Boot 10 - MTK_AllInOne_DA_V5.1232 (625A/62xx)
Boot 11 - MTK_AllInOne_DA_V7.1304 (65xx Android)
Boot 12 – MTK_6223 (Moto, Alcatel, TCL series)
Spreadtrum
Boot 0 - Auto
Boot 1 – Boot H (6600L/L2/L6/L7/USB/COM)
Boot 2 – Boot J (6610/20)
Boot 3 – Boot K (6800H)
Boot 4 – Boot A (6600M/E/D Normal Speed)
Boot 5 – Boot B (6600M/E/D High Speed)
Boot 6 – Boot C (6600R)
Boot 7 – Boot D (6600H/R2)
Boot 8 – Boot E (6800)
Boot 9 – Boot F (6600D – NOR)
Boot 10 – Boot G (6600M/I/E-HOR)
Boot 11 – Boot I (8800S/H/880xG)
Boot 12 – Boot L (6530)
Boot 13 – Boot M (6820/8810)
CellXtract® User Manual
94
CELLXTRACT-TNT
Infineon
Boot 0 – Boot A
Boot 1 – Boot B
MSTAR
Boot 0 – Boot A (8535/8538/8533 NOR_FLASH)
Boot 1 – Boot B (8528 NOR_FLASH)
Boot 2 – Boot C (8535/8538 NAND_FLASH)
Boot 3 – Boot D (8533C NOR_FLASH)
Boot 4 – Boot E (8533x_family NOR_FLASH)
Boot 5 – Boot F (8535N NAND_FLASH)
Boot 6 – Boot G (8533x_family NAND_FLASH)
Boot 7 – Boot H (Auto)
Cool Sand
Boot 0 – Boot A
Boot 1 – Boot B
Step by Step – Device Extraction for CellXtract-TNT
The Chinese-manufactured chipset extraction process is more complex than for other types
of device. The process is shown below:
Attaching an external storage location
Selecting a chipset type
Connecting the power clamps to the phone power terminals
Identifying the data port on the phone and the correct cable tip.
Connecting the data and power cables to the CellXtract-TNT
Case Details screen
Selecting the bootloader
Performing the extraction
Report Preview
Attaching an external storage location
1. Attach an external storage location such as a USB flash
drive or USB external drive to one of the available USB
ports on the right panel. This will allow CellXtract-TNT to
save extracted files and the report to the selected external
storage location.
Selecting a chipset
2. From the main screen, tap Read New Device.
3. Select Cell Phone
CellXtract™ User Manual
95
CELLXTRACT-TNT
4. Select Physical Extraction.
5. Select By Chipset.
6. A list of supported chipsets will appear. If you know the
chipset on the phone, tap the proper chipset from the list
then tap the Select icon. If you are unsure what the chipset
is, tap Auto then tap the Select icon to let the CellXtractTNT attempt to identify the correct chipset.
7. A window will appear asking if you want to capture to the
attached external storage location. Select Yes to continue.
If no external storage location is attached, you will be
prompted to attach one.
CellXtract™ User Manual
96
CELLXTRACT-TNT
Connecting the power clamps to the phone power terminals
8. The screen above will appear. Remove the battery from
the handset. From the battery, note which power pins are
positive (+) and negative (-). Connect the power clamps to
the phone power terminals. It is not necessary to match
polarity (the red and black clamps can connect to either
positive or negative terminals).
NOTE: If you do not have the battery, try
connecting to the outer power terminals first.
9. Tap the OK icon to continue.
Identifying the data port on the phone and the correct Cable Tip
10. The screen above will appear. Identify the data port on the
phone. This should be on the top, bottom, or sides of the
phone. Try to recognize the shape and the number of pins
in the port.
11. Find the correct cable tip in the case i.e. locate the cable
tip that matches the phone data port.
NOTES:
It may be difficult to match the correct cable tip
with the phone's data port. Some cable tips
may appear to fit the same data port, so care
CellXtract™ User Manual
97
CELLXTRACT-TNT
must be taken. Comparing the pin
configuration in the phone's data port with the
cable tip can help with the selection.
Each Cable Tip is marked to with the number
of pins on the Cable Tip. For example, P-5B is
a micro-USB sized Cable Tip with 5 pins while
P-7A is a micro-USB sized Cable Tip with 7
pins.
12. Plug in the appropriate cable tip into the phone’s data port
and connect the main data cable to the cable tip.
13. Tap the OK icon to continue.
Connecting the data and power cables to the CellXtract-TNT
14. Connect the data and power cables to CellXtract-TNT.
15. Tap the OK icon to continue.
Case Details screen
16. The Case details screen will appear. You can fill out the
case details at this time then tap the OK icon or tap the
Later button if you want to fill out the information later.
CellXtract™ User Manual
98
CELLXTRACT-TNT
Selecting the bootloader
17. The Tarantula popup dialog will appear. The left drop-down
selection will show the previously selected chipset (or Auto
if it was selected). Choose a bootloader from the right
drop-down selection or leave as Automatic (0) if you are
unsure. Tap the Connect icon to continue.
NOTES:
You can change the selected chipset on this
screen.
For MTK chipset, tap Include logical if you
want to perform a logical extraction as well as
physical extraction. The CellXtract-TNT will
perform a logical extraction immediately after
the physical extraction. Results from both
physical and logical extractions will be shown
in the final report. Note: there may be duplicate
data contained in the final report.
Performing the extraction
18. CellXtract-TNT will perform the extraction. Watch the
screen carefully as some extractions will require you to
press and hold the power button on the phone. The yellow
section above shows any messages and instructions for
the user.
CellXtract™ User Manual
99
CELLXTRACT-TNT
NOTES:
If asked to press the handset power button,
you may need to do this multiple times.
If the screen shows “Scan failed” or
“Connection failed”, check both the power and
data connections between the CellXtract-TNT
and the phone or try a different cable tip and
then press Retry.
If the screen shows “Physical extraction
failed”, try selecting a different chipset /
bootloader combination and then press Retry.
Report Preview
19. When the extraction is finished, a window will appear
stating the extraction is complete. At this point, you can
disconnect the phone and cables. Tap the OK icon to
continue.
20. The report preview will appear. From this screen you can
view the extracted data.
NOTE: See Chapter 4 for more information on viewing
extracted data.
CellXtract™ User Manual
100
9. Glossary and Troubleshooting Guide
Glossary
SIM (Subscriber Identity Module) - Essentially a small computer on a card that sits within the
mobile phone and controls various functions of call making. It also has enough memory to hold
information such as ADN and SMS.
ADN (Abbreviated Dialing Numbers) - more commonly known as the phonebook or contacts.
SMS (Short Message Service) – SMS is a form of textual conversation permitted by a network
carrier. The service allows a user to send and receive textual messages direct to their handsets.
The storage capacity depends on the handset and SIM. The date and time of received messages is
generated by the network, all other date and time stamps are generated from the handset time. The
maximum character length is 160 per SMS. Some handsets allow longer messages to be compiled
and therefore are split into relevant parts when sent, these messages are known as concatenated.
Deleted SMS (Short Message Service) - These are text messages that have been deleted from
the SIM card by the cellphone user. However, most mobile phones do not remove the message, but
mark the message to be overwritten by incoming messages from the network.
MMS (Multimedia Messaging Service) – A service which allows Multimedia messages to be sent
from one mobile to another via one or more call centers or network providers. A Multimedia
message is stored on the handset and can contain a combination of text, video clips, images and
sound clips.
ICCID (Integrated Circuit Card Identifier) - The serial number of the SIM card stored electronically
within the SIM. A similar number or shortened version is often found printed on the SIM card.
IMEI (International Mobile Equipment Identifier) - This is a unique number given to each
handset. This is usually printed somewhere on the handset, (typically in the battery compartment)
and stored electronically in the phone handset memory. It can be viewed typing *#06# on the
keypad.
PIN (Personal Identification Number) - The SIM card has been locked against unauthorized
access using the PIN number. When PIN security is activated, the correct PIN number must be
entered in order to use any of the features of the handset (make calls, access ADN etc.) The only
calls that can be made without a PIN are calls to the emergency services.
PUK (Personnel Unblocking Key) - If the PIN is unknown the PUK is used to unblock the SIM
card and enable a new PIN code to be entered.
MSISDN (Mobile Station ISDN Number) - This number is the standard international number used
to identify a given subscriber. However, the number stored in the MSISDN location on a SIM Card
can be changed without affecting the actual telephone number. Therefore, the MSISDN number
downloaded from the SIM card can only be used as an indicator.
IMSI (International Mobile Subscriber Identity) – This is a unique number allocated to each
mobile phone subscriber, stored electronically within the SIM Card. It is used by the network to look
up the telephone number associated to the SIM Card.
CellXtract® User Manual
101
GLOSSARY AND TROUBLESHOOTING GUIDE
GSM (Global System for Mobile Communications) - a digital mobile telephone system that is
widely used in Europe and other parts of the world. GSM uses a variation of time division multiple
access (TDMA) and is the most widely used of the three digital wireless telephone technologies
(TDMA, GSM, and CDMA).
CDMA (Code Division Multiple Access) - refers to any of several protocols used in so-called
second-generation (2G) and third-generation (3G) wireless communications. As the term implies,
CDMA is a form of multiplexing, which allows numerous signals to occupy a single transmission
channel, optimizing the use of available bandwidth. The technology is used in ultra-high-frequency
(UHF) cellular telephone systems in the 800-MHz and 1.9-GHz bands.
TDMA (Time Division Multiple Access) - is a technology used in digital cellular telephone
communication that divides each cellular channel into three time slots in order to increase the
amount of data that can be carried.
Cluster The smallest block of memory in a drive that can be written to individually by the file
system.
Allocation table Table that keeps track of the contents of each cluster on the drive. The allocation
table is used to combine clusters in the correct order to construct the files in the file system.
Allocated space Any cluster that is being used to store a file and has a written entry in the
allocation table
Unallocated Space Any clusters that have an empty entry in the allocation table (i.e. are not
assigned to any file) and are marked as being available for over writing by the file system.
Extant File A files that is still active in the file system and has appropriate entries in the allocation
table to be reconstructed.
Contiguous File A file stored using clusters that are located next to each other in the drive’s
memory.
Troubleshooting Guide
CellXtract fails to power up
CellXtract hangs or freezes during an
extraction
Dimensions entered do not display
correct phone
Mobile device not listed or no image
can be found.
CellXtract™ User Manual
The CellXtract battery may be discharged.
Try connecting the AC adapter.
Connect the included USB hub between the USB
port (on the left panel) and the phone cable and
perform the extraction again. If your CellXtract did
not come with a USB hub, please contact
Logicube Technical Support. Contact information
can be found at the end of this document.
Re-measure and re-enter dimensions by adjusting
them slightly.
NOTE: The phone may not yet be included in the
identification module
Mobile device may not yet be supported by the
identification module. Select a similar device from
the listing and use IR or Bluetooth ONLY. Damage
to the handset can occur by selecting the wrong
cable for a device and is not recommended.
102
GLOSSARY AND TROUBLESHOOTING GUIDE
Infrared discovery failed
Bluetooth extraction failed
NOTE: The device make and model reported is
obtained from the phone not based on the device
selected from the identification module.
Ensure infrared is active on target device and IR
window is aligned with the CellXtract’s pickup
sensor.
Ensure Bluetooth adapter is inserted in one of the
USB ports on the left panel. On the target device,
ensure Bluetooth is active and is in discoverable
mode. Also, target device may be asking for a 4digit code number or file acceptance on screen
during the extraction.
Connector not recognized or detected
Ensure cable is replaced correctly and retry then
reboot the CellXtract if problem persists.
No cable connection method offered
A small number of handsets only offer Bluetooth or
Infrared connectivity.
Battery is not charging
Discharge the battery completely then attach the
AC adapter and charge the battery for 2.5 hours.
CellXtract application freezes
continuously
Reboot the CellXtract and try a different phone to
test along with a different external storage
location.
SIM card read fail
Ensure SIM is correctly inserted and in the correct
orientation.
‘SIM PIN required’ message
Enter PIN code. If entered incorrectly 3 times PUK
will be required.
‘SIM PUK required’ message
Contact carrier/provider to obtain PUK code.
CellXtract fails to read memory card
Ensure card is inserted correctly. Reboot
CellXtract. Try a different USB port.
SIM Card LED goes out
Try a different SIM card for testing purposes. If
problems persist, press and hold the power button
for 7 seconds to force the CellXtract to shut down.
CellXtract unit freezes or crashes
Press and hold the power button for 7 seconds to
force the CellXtract to shut down
Validated phones: Testing and QA.
When a new software update for CellXtract is created the current market phones are added to the
device listing in the software to enable the CellXtract operator to attempt an extraction on 'new
market release' phones. These phones are added on the CellXtract's identification module as soon
as we are aware of them and sometimes before we have been able to purchase and validate them
on the software. This gives the CellXtract operator the added advantage of being able to read
phones new to the market, as soon as they are released. Many of which will work in the same way
as devices already validated and can then be used as intelligence in an investigation.
Validated phones, on the other hand, have been tested following Logicube quality assurance
procedures and any phones that are identified by the operator that have a green tick next to the
picture on CellXtract or show the extractable data icons to the right of the large image, show that
the extraction is reliable and is repeatable.
CellXtract™ User Manual
103
GLOSSARY AND TROUBLESHOOTING GUIDE
CellXtract Start-up Problems
Logon details
The default username is ‘CellXtract’ and the password is not set. Note: the username and
password are case sensitive.
Connected peripherals
Ensure all external peripherals are disconnected from the CellXtract on start-up particularly external
screens or monitors.
Screen Freeze or System ‘Crash’ (Blank Screen)
System hardware reset
Press the power switch to perform a full system reset. The CellXtract should be rebooted normally
following a full system reset.
The 'cannot find drivers' message
There are a few possible reasons for this message being displayed:
Untested handset
The device is not validated and does not use one of the standard device drivers. We have been
unable to ensure that the correct driver is used because, at the time of this writing, we do not own a
test phone of this type.
Connection error
The cable is not connected to the phone properly. Check the phone connection port and connector
terminals for debris. If possible, confirm that there is no damage to the cable by running a test
phone.
USB hub fault on pc
Windows cannot communicate with any USB devices due to a system fault within the PC - the
system should be reset by shutting down and restarting CellXtract.
Mass storage mode
The phone is set as a mass storage device on connection. For the extraction to be successful it
must appear as a data modem on connection. The setting will need to be changed in the
connection settings menu on the phone.
Phone battery low
If the phone battery is very low then some of the circuitry inside the phone fails to switch on, even
though the phone has powered up. Ensure that the phone has adequate charge before attempting
an extraction on CellXtract.
Android USB Connection
Some Android handsets automatically connect to an unsupported USB mode. In this case, you
must change the default USB connection mode to “Charge Only” or “Modem Mode”. To do this,
connect the phone to CellXtract via the USB cable, then pull down the Android notification bar
(press the very top of the screen and pull down) and select USB Connection, then select “Charge
Only” or “Modem Mode”, and press OK.
Bluetooth Pairing problems
Discoverable mode
CellXtract™ User Manual
104
GLOSSARY AND TROUBLESHOOTING GUIDE
If the device is not present in the device list following a Bluetooth discovery check that the phone
has Bluetooth switched on and it is in discoverable mode. Some devices can be in a hidden state
even though the Bluetooth is switched on.
NOTE: Be sure that you know the correct identification name for a device before selecting it
for pairing.
Pairing failure
Ensure that the correct pass code (‘1234’) was entered during the pairing process.
Win Mobile devices are not supported over a Bluetooth connection. This is because the connection
has to be initiated by the handset only. The CellXtract cannot be discovered on Bluetooth by other
devices.
Report Logo or Search file Upload problems
Fails to Upload Report Logo
The report logo has to be named ‘LOGO.jpg’ (in capital letters only) and stored on the root directory
of a USB pen.
NOTE: .jpeg extensions are not supported.
USB hub fault on PC
If windows cannot communicate with any USB devices due to a system fault within the PC- the
system should be reset by shutting down and restarting CellXtract.
Setting the System Time/Date
The system time and date must be set in the system BIOS.
Network Isolation Card problems
Missing SIM information
The NIC has been designed for network isolation purposes only. It is not an exact copy of the
original SIM and only stores a subset of SIM data, including just the first 34 Abbreviated Dialed
Numbers (ADNs) and 25 SMS messages. As a result not all SIM data will be visible, or reported
after performing a Cell phone extraction, on a handset with a NIC inserted.
Failed to create NIC
There was a problem with the NIC creation process. CellXtract was unable to read or copy
mandatory SIM data onto the NIC. If this message appears, then the NIC should not be inserted
into the target handset as data including call registers may be lost.
Help Messages
Help messages can be seen by tapping the Help Icon (a question mark on the
upper-left of the screen) on some windows. This will bring up a description of the
error and possible solutions.
CellXtract™ User Manual
105
GLOSSARY AND TROUBLESHOOTING GUIDE
Help Icon Location
CellXtract™ User Manual
106
8. Supported Handsets
Support and Validation
Physical Extraction from Chinese Chipset Phones
CellXtract-TNT
A full physical image (binary file) of the memory chip is extracted
Extracts, decodes and reports deleted data on Chinese chipset phones
(Coolsand decoding is currently not supported)
User password extraction is supported on Chinese chipset phones
Supports data extraction from the following Chinese-manufactured chipsets:
MediaTEK (MTK)
Spreadtrum
Infineon
MSTAR
Cool Sand
It is expected that most phones built with the above chipsets will be supported.
Physical Extraction from Android Phones
CellXtract* and CellXtract-TNT
A physical extraction from Android Operating Systems 1.6 through 2.3.4, and file systems EXT3,
EXT4 and RFS is supported. Limited support of the YAFFS2 file system is available at this time, but
is expected to be fully supported in a future release. It is expected that most Android phones using
the above O/S and/or file systems will be supported.
Supports dumping and decoding of contacts, call logs, MS, emails and user files
Will extract deleted file items such as databases, images, video, audio and documents
*You must have the Physical Extraction feature activated on your CellXtract. All units shipped after 6/11/12
included Physical Extraction. If you are not sure whether your CellXtract has this feature please contact our
technical support team at [email protected] to verify.
CellXtract® User Manual
107
SUPPORTED HANDSETS
CellXtract and CellXtract-TNT
Logical Extraction – Supported Handsets
The following handsets have been tested and the results verified on CellXtract and CellXtract-TNT
using the standard validation procedures of Logicube. The results below display the data sets that
can be extracted from CellXtract and CellXtract-TNT for the specific handset. There may be
additional data sets available from handsets and these will require further examination. These
handsets are assigned a green tick next to their image on CellXtract and CellXtract-TNT.
Key:
Phone ID
Phone ID w timestamp
Contacts
Call Logs
Call Logs w timestamp
SMS


SMS w timestamp 
MMS
MMS

Files


Organizer


F900
3
ACER
n50
4
ACER
X960
5
ALCATEL
OT-C707
6
AMOI
WP-S1
7
ANDROID
G1
8
APPLE
iPhone
9
APPLE
iPhone 3G
10
APPLE
11
Date Added
ACER
Cable No.
2

     
 
 
     
GSM
2
10-Jan
GSM
2
10-Jan
    
GSM
Organiser
beTouch E101
Files
ACER
Messages
1
Call Logs
Model
Contacts
Manufacturer
Phone ID
No.
Mobile Standard
Handsets that appear with no cable number assigned are supported via Infrared or
Bluetooth methods.
    

     
     
     
 
 
GSM
GSM
6-Jul
2
9-Oct
8-Apr
GSM
2
9-Apr
GSM
2
8-Jul
GSM
3
8-Oct
GSM
3
9-Oct
iPhone 4
      GSM
3
11-May
APPLE
iPhone 5
      GSM
Mfg
Apr-13
12
APPLE
iPad
3
Sep-12
13
BENQ
E72
2
9-Jan
CellXtract™ User Manual
 
    
108

N/A
 GSM
SUPPORTED HANDSETS
    
14
BENQ
P50
15
BENQ SIEMENS
EF81
16
BENQ SIEMENS
S68
17
BENQ SIEMENS
S88
   
18
BLACKBERRY
7230
  
19
BLACKBERRY
7250
  
20
BLACKBERRY
7290
   
21
BLACKBERRY
8100
   
22
BLACKBERRY
8120
    
23
BLACKBERRY
8300
    
24
BLACKBERRY
8310
   
25
BLACKBERRY
8320
   
26
BLACKBERRY
8330
    
27
BLACKBERRY
8520
    
28
BLACKBERRY
8800
   
29
BLACKBERRY
8800
    
30
BLACKBERRY
8820
   
31
BLACKBERRY
8830
   
32
BLACKBERRY
8900
    
33
BLACKBERRY
9000
    
34
BLACKBERRY
9500
    
35
BLACKBERRY
9530
    
36
BLACKBERRY
9700
   
37
BLACKBERRY
7100t
 
38
BLACKBERRY
7100v
  
39
BLACKBERRY
7100x
  
40
BLACKBERRY
8700f
  
41
BLACKBERRY
8700g
  
42
BLACKBERRY
8700v
  
43
BLACKBERRY
8707g
   
44
BLACKBERRY
8707v
   
45
BLACKBERRY
9780
46
BLACKBERRY
47

 GSM
 
  
 
2
6-Jul
GSM
7-Apr
 GSM
6-Jul
GSM
7-Jul
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 CDMA
 GSM
 GSM
 GSM
 GSM
 CDMA
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
2
8-Apr
2
7-Jul
2
7-Jan
2
7-Jul
2
9-Jan
2
9-Jan
2
8-Jul
2
8-Apr
2
9-Jan
1
10-Jan
2
10-Jan
2
8-Oct
2
8-Apr
2
8-Oct
1
9-Jul
2
9-Jan
1
9-Jul
1
9-Jul
1
10-Sep
2
6-Apr
2
6-Apr
2
6-Apr
2
7-Jan
2
7-Jan
2
7-Oct
2
9-Oct
2
7-Jul
     GSM
1
11-Dec
9800
     GSM
1
11-Dec
BLACKBERRY
9650
  
1
11-Dec
48
DELL
AXIM X51v
49
E-TEN
P300B
50
GLOFIISH
M810
51
GLOFIISH
X600
CellXtract™ User Manual

 GSM

    
     
     
 
109

GSM
6-Oct
GSM
7-Oct
GSM
2
9-Oct
GSM
2
8-Oct
SUPPORTED HANDSETS
   





52
HP
iPAQ 514
53
HP
iPAQ H5550
54
HP
iPAQ HW6915
55
HP
iPAQ rx1950
 

56
HP
iPAQ rz1710
 

57
HTC
Desire
    
GSM
1
11-May
58
HTC
EVO 4G
    
CDMA
1
11-May
59
HTC
Hero
2
9-Oct
60
HTC
Incredible
1
11-May
61
HTC
Kaizer
   
 GSM
2
8-Jan
62
HTC
Magic
   
GSM
2
9-Oct
63
HTC
NEXUS ONE
   
GSM
1
10-Dec
64
HTC
P3300
   
GSM
2
7-Oct
65
HTC
P3450
   
GSM
2
9-Jul
66
HTC
P3470
   
GSM
2
8-Oct
67
HTC
P5500
    
GSM
2
8-Oct
68
HTC
S310
    
GSM
2
7-Jul
69
HTC
S620
    
GSM
2
8-Oct
70
HTC
S710
    
GSM
2
8-Jul
71
HTC
S740
    
GSM
2
9-Jul
72
HTC
S743
      GSM
8
10-Dec
73
HTC
Shadow
2
8-Oct
74
HTC
SMT5800
2
10-Sep
75
HTC
Snap
 GSM
      CDMA
      GSM
2
9-Oct
76
HTC
Tattoo
GSM
2
10-Jan
77
HTC
Tornado
GSM
2
8-Jan
78
HTC
Touch
GSM
2
7-Oct
79
HTC
TOUCH CRUISE
GSM
2
9-Apr
80
HTC
TOUCH DIMOND
GSM
2
9-Jul
81
HTC
Inspire
GSM
1
11-Dec
82
HTC
ThunderBolt
    
CDMA
1
11-Dec
83
HTC
Sensation
    
GSM
1
Apr-12
84
HTC
Amaze 4G
    
GSM
1
Apr-12
85
HTC
Status
    
GSM
1
Apr-12
86
HUAWEI
U8150
    
GSM
1
11-Dec
87
HUAWEI
M735
1
11-Dec
88
HUAWEI
U8800
89
HUAWEI
M860
CellXtract™ User Manual
 

    
   
GSM
6-Jul
GSM
6-Oct
GSM
7-Jul
GSM
6-Jul
      CDMA
    
   

    
     
     
   
   
   
7-Oct
GSM
 GSM








2
 CDMA
    
GSM
1
Apr-12
  
CDMA
1
Sep-12
110

SUPPORTED HANDSETS








90
IMATE
JAM
   
91
IMATE
JAMin
   
92
IMATE
JASJAR
93
IMATE
K-JAM
   
94
IMATE
PDA2K
    
95
IMATE
SP3i
    
96
IMATE
SP5
    
97
IMATE
SPL
    
98
KYOCERA
K323
 
 
CDMA
9-Jan
99
KYOCERA
K342
 
 
CDMA
9-Jan
100
KYOCERA
K404
   
CDMA
22
6-Jul
101
KYOCERA
K9
 
 
CDMA
22
9-Jan
102
KYOCERA
KX1
 
 
CDMA
22
9-Jan
103
KYOCERA
KX160
 
 
CDMA
22
9-Jan
104
KYOCERA
KX5
 
 
CDMA
105
KYOCERA
KX9a
 
 
CDMA
22
9-Jan
106
KYOCERA
S1300
 
 
1
10-Sep
107
KYOCERA
S4000
 
 CDMA
   CDMA
1
10-Sep
108
KYOCERA
SE47
   
CDMA
21
6-Jul
109
KYOCERA
M1400
 CDMA
1
Dec-11
110
LG
A7110
 GSM
12
6-Jul
111
LG
AX380
    
5
9-Jul
112
LG
C1300i
 

21
7-Jan
113
LG
C1500
 

21
7-Jan
114
LG
C2000
 

 GSM
 GSM
 GSM
21
7-Jan
115
LG
C2500

 
GSM
2
10-Jul
116
LG
CE500
  
GSM
12
6-Jul
117
LG
CG225
 
GSM
21
7-Jan
118
LG
CG300
 
GSM
21
7-Jan
119
LG
F2500
 
120
LG
F9100
 
121
LG
F9200
 
122
LG
G4020
 
123
LG
G4050
 
124
LG
GD900
 



  








  
125
LG
GS170
 
126
LG
GT365
127
LG
GT950 (Arena)
CellXtract™ User Manual
    
 

  

GSM
2
6-Jul
GSM
2
6-Jul
GSM
2
6-Oct
GSM
2
6-Jul
GSM
8-Jul
GSM
2
6-Jul
GSM
2
6-Jul
GSM
2
7-Jul
CDMA
9-Jan
GSM
8-Apr
GSM
21
7-Jan
GSM
21
7-Jan
GSM
21
8-Apr
GSM
21
7-Jan
GSM
1
10-Jan

GSM
1
10-Dec
 

 GSM
5
10-Sep

 
GSM
1
11-May
111
SUPPORTED HANDSETS
 GSM
   GSM
1
10-Jan
1
10-Jan
      GSM
1
11-May
GSM
5
8-Oct
GSM
5
9-Oct
GSM
5
9-Apr
GSM
5
8-Oct
GSM
5
8-Apr
GSM
5
8-Apr
GSM
5
8-Apr
GSM
5
8-Apr
GSM
5
8-Apr
GSM
5
9-Jan
GSM
5
9-Jan
  
GSM
2
10-Sep
  
GSM
2
10-Sep
5
7-Jul
5
6-Oct
5
8-Apr
12
6-Oct
5
8-Oct
128
LG
GW300
 
129
LG
GW520
 
130
LG
GW820 (Expo)
131
LG
KC550
 
 
132
LG
KC780
 
 
133
LG
KC910
 
 
134
LG
KE500
 
 
135
LG
KE770
 
 
136
LG
KE800
 
 
137
LG
KE820
 
 
138
LG
KE850
 
 
139
LG
KE970
 
 
140
LG
KF510
 
 
141
LG
KF600
 
 
142
LG
KG200

143
LG
KG300

144
LG
KG320
 
 
145
LG
KG800
 
 
146
LG
KG810
 
147
LG
KG920
 
148
LG
KM710
 

149
LG
KM900
 
 
150
LG
KP170
 
 
151
LG
KP500
 
 
152
LG
KU990
 
 
153
LG
L1150
 

154
LG
L1200
 

155
LG
L1400i
 

156
LG
LG6190
    
157
LG
LX150
   
158
LG
LX160
   
159
LG
LX550
    
160
LG
LX5550
    
161
LG
MM535
    
162
LG
MN240 (Imprint)
163
LG
MT310
164
LG
P7200
165
LG
PM225
CellXtract™ User Manual
 

 











 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
10-Jan
5
10-Jan
5
9-Apr
5
9-Apr
21
8-Apr
21
7-Jan
21
7-Jan
19
10-Sep
5
8-Apr
5
8-Apr
19
8-Apr
12
7-Oct
19
6-Apr
      CDMA
1
11-May
      CDMA
1
10-Dec
 GSM
      CDMA
12
6-Apr
19
6-Apr
  
112

SUPPORTED HANDSETS
 CDMA
  
  GSM
 

 GSM
 
   GSM
 

 GSM
 

 GSM
 
   GSM
 

 GSM
    
166
LG
PM325
19
6-Apr
167
LG
S5200
12
6-Apr
168
LG
U8110
12
9-Apr
169
LG
U8120
12
9-Apr
170
LG
U8130
12
9-Apr
171
LG
U8138
12
9-Apr
172
LG
U8360
12
9-Apr
173
LG
U8380
12
9-Apr
174
LG
UN430
 
 
CDMA
1
10-Dec
175
LG
UX260
    
 CDMA
5
9-Oct
176
LG
UX300
      CDMA
1
10-Dec
177
LG
UX355
    
19
7-Jul
178
LG
UX390
    
19
7-Jul
179
LG
UX4750
    
19
8-Jan
180
LG
UX5000
    
19
8-Jan
181
LG
VI125
    
19
6-Apr
182
LG
VX10000
    
5
9-Jan
183
LG
VX4500
    
21
6-Jul
184
LG
VX4600
    
21
6-Jul
185
LG
VX4700
    
19
6-Apr
186
LG
VX5200
    
19
6-Apr
187
LG
VX5300
    
20
6-Oct
188
LG
VX5400
    
5
9-Jan
189
LG
VX5500
    
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 GSM
 CDMA
 CDMA
1
10-Sep
190
LG
VX5600
      CDMA
1
10-Dec
191
LG
VX6000
    
12
6-Jul
192
LG
VX6100
    
19
6-Apr
193
LG
VX6190
    
19
10-Sep
194
LG
VX7000
    
19
6-Jul
195
LG
VX8000
    
19
6-Jul
196
LG
VX8100
    
19
6-Apr
197
LG
VX8300
    
20
6-Oct
198
LG
VX8350
    
5
8-Apr
199
LG
VX8500
    
5
8-Oct
200
LG
VX8575
    
1
10-Sep
201
LG
VX8610
    
1
9-Oct
202
LG
VX8700
    
5
9-Jan
203
LG
VX8800
    
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
5
9-Jan
CellXtract™ User Manual
113
SUPPORTED HANDSETS
204
LG
VX9100
    
 CDMA
1
9-Jan
205
LG
VX9200
      CDMA
1
10-Dec
206
LG
VX9400
    
 CDMA
5
8-Apr
207
LG
VX9700
      CDMA
1
10-Dec
208
LG
VX9800
    
19
7-Jan
209
LG
VX9900
 CDMA
      CDMA
5
8-Oct
210
LG
P509
    
GSM
1
11-Dec
211
LG
KS20
      GSM
5
11-Dec
212
LG
VS750
      CDMA
1
11-Dec
213
LG
UX310
   
 CDMA
1
11-Dec
214
LG
MT375
      CDMA
1
11-Dec
215
LG
VN530
  
1
11-Dec
216
LG
P505
    
GSM
1
Apr-12
217
LG
C729
    
GSM
1
Apr-12
218
LG
LG670
    
CDMA
1
Apr-12
219
LG
AX145
 CDMA
21
Apr-12
220
LG
P925
    
GSM
1
Apr-12
221
LG
P930
    
GSM
1
Apr-12
222
LOBSTER
700TV
2
8-Jan
223
MIO
A501
2
9-Jul
224
MIO
A701
 GSM
      GSM
      GSM
2
7-Apr
225
MOTOROLA
MB810 (DROID X)
    
CDMA
1
11-May
226
MOTOROLA
A555 (Devour)
    
CDMA
1
11-May
227
MOTOROLA
A835
    
9
5-Dec
228
MOTOROLA
A855
   
1
10-Sep
229
MOTOROLA
C332
   
2
7-Jul
230
MOTOROLA
C343
   
9
6-Apr
231
MOTOROLA
C350
   
2
6-Apr
232
MOTOROLA
C385
   
2
5-Dec
233
MOTOROLA
C390
    
2
5-Dec
234
MOTOROLA
C550
   
2
5-Dec
235
MOTOROLA
C650
    
2
5-Dec
236
MOTOROLA
C975
    
9
5-Dec
237
MOTOROLA
E1
    
9
6-Apr
238
MOTOROLA
E1000
    
9
6-Oct
239
MOTOROLA
E1070
    
2
7-Jan
240
MOTOROLA
E398
    
 GSM
 CDMA
 GSM
 CDMA
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 CDMA
 GSM
 GSM
9
5-Dec
241
MOTOROLA
E8
CellXtract™ User Manual
  CDMA
 
   
 
114
 
GSM
10-Jan
SUPPORTED HANDSETS
   
 CDMA
 GSM
 CDMA
 GSM
 GSM
 GSM
 GSM
 CDMA
 GSM
 GSM
 GSM
 GSM
242
MOTOROLA
E815
243
MOTOROLA
K1
    
244
MOTOROLA
K1m
    
245
MOTOROLA
K3
 
246
MOTOROLA
L2
   
247
MOTOROLA
L6
    
248
MOTOROLA
L7
    
249
MOTOROLA
maxx Ve
   
250
MOTOROLA
MPX200
    
251
MOTOROLA
MPX220
    
252
MOTOROLA
Q
   
253
MOTOROLA
Q9h
   
254
MOTOROLA
QA1
    
255
MOTOROLA
T280i
   
256
MOTOROLA
T300p
257
MOTOROLA
U6
258
MOTOROLA
V1050
 GSM
   
 CDMA
      GSM
      GSM
259
MOTOROLA
V120c
   
260
MOTOROLA
V180
    
261
MOTOROLA
V188
262
MOTOROLA
V190
263
MOTOROLA
V195
264
MOTOROLA
265
 
GSM
6-Oct
2
7-Oct
7-Apr
2
7-Jul
2
6-Oct
2
6-Apr
2
6-Apr
10-Jan
2
6-Jul
9
6-Jul
2
8-Jan
1
8-Apr
1
10-Sep
6-Oct
9
5-Dec
2
6-Apr
9
6-Oct
CDMA
9
6-Apr
GSM
2
5-Dec
GSM
2
6-Apr
GSM
2
7-Jul
GSM
2
6-Oct
V220

     
   

   

     
GSM
2
6-Apr
MOTOROLA
V235
    
GSM
2
7-Jan
266
MOTOROLA
V260
9
8-Jan
267
MOTOROLA
V265
 
9
8-Apr
268
MOTOROLA
V3
 
2
5-Dec
269
MOTOROLA
V300
 
9
5-Dec
270
MOTOROLA
V360
 
 CDMA
 
 CDMA
    GSM
    GSM
    GSM
2
6-Apr
271
MOTOROLA
V3a
      CDMA
2
11-May
272
MOTOROLA
V3c
    
273
MOTOROLA
V3i
    
274
MOTOROLA
V3m
   
275
MOTOROLA
V3x
    
276
MOTOROLA
V3xx
    
277
MOTOROLA
V400
   
278
MOTOROLA
V500
   
279
MOTOROLA
V525
    
CellXtract™ User Manual
   
115
 CDMA
 GSM
 CDMA
 GSM
 GSM
 GSM
 GSM
 GSM
10-Jan
2
6-Apr
8-Apr
2
6-Jul
2
9-Oct
9
8-Jan
9
8-Jul
9
5-Dec
SUPPORTED HANDSETS
 GSM
 GSM
 GSM
 GSM
 GSM
 CDMA
 CDMA
 GSM
 GSM
 CDMA
 GSM
 GSM
 CDMA
280
MOTOROLA
V540
   
281
MOTOROLA
V550
    
282
MOTOROLA
V551
    
283
MOTOROLA
V6
284
MOTOROLA
V600
    
285
MOTOROLA
V60p
   
286
MOTOROLA
V60v
   
287
MOTOROLA
V620
    
288
MOTOROLA
V635
    
289
MOTOROLA
V65p
   
290
MOTOROLA
V66i
   
291
MOTOROLA
V70
   
292
MOTOROLA
V710
  
293
MOTOROLA
V8
 
 
GSM
294
MOTOROLA
V80
    
 GSM
295
MOTOROLA
V860 (Barrage)
296
MOTOROLA
V9
297
MOTOROLA
V950
 
298
MOTOROLA
V975
 
299
MOTOROLA
V980
 
300
MOTOROLA
V9m
 
301
MOTOROLA
302
 
 
9
7-Jul
9
6-Apr
9
6-Apr
2
7-Jul
5-Dec
9
5-Dec
9
7-Jul
9
6-Apr
9
5-Dec
9
8-Apr
9
5-Dec
9
5-Dec
9
6-Apr
10-Jan
9
5-Dec
      CDMA
1
11-May
 GSM
 
 CDMA
    GSM
    GSM
    CDMA
1
8-Apr
VE240
      CDMA
2
MOTOROLA
W385
    
8-Apr
303
MOTOROLA
W450
  
9-Oct
304
MOTOROLA
W510
    
GSM
305
MOTOROLA
W755
    
CDMA
306
MOTOROLA
W840 (Quantico)
307
MOTOROLA
Z3
    
308
MOTOROLA
Z6
 
 
309
MOTOROLA
Z6m
 
 
 CDMA
310
MOTOROLA
Z6tv
    
CDMA
311
MOTOROLA
Z8
 
312
MOTOROLA
Z9
    
GSM
313
MOTOROLA
ZN4
    
CDMA
314
MOTOROLA
MB860
    
GSM
1
Dec-11
315
MOTOROLA
XT610
  
CDMA
1
Dec-11
316
MOTOROLA
MB865
    
GSM
1
Sep-12
317
NDRIVE
S300
    
 GSM
2
9-Apr
CellXtract™ User Manual
    
9
8-Jul
9
5-Dec
8-Apr
 CDMA
  GSM
      CDMA
116
10-Jan

 
 GSM
2
11-May
8-Jan
10-Jan
1
11-May
2
7-Apr
GSM
10-Jan
8-Apr
10-Sep
 GSM
8-Jul
1
9-Apr
10-Jan
SUPPORTED HANDSETS
318
NEO
808i
   
319
NOKIA
1100
   
320
NOKIA
1101
   
321
NOKIA
1110
   
322
NOKIA
1112
   
323
NOKIA
1200
   
324
NOKIA
1208
   
325
NOKIA
1209
   
326
NOKIA
1600
   
327
NOKIA
2100
  
328
NOKIA
2285
329
NOKIA
2300
   
330
NOKIA
2310
   
331
NOKIA
2600
    
GSM
332
NOKIA
2610
  
GSM
25
7-Oct
333
NOKIA
2626
  
GSM
25
7-Oct
334
NOKIA
2630
    
GSM
335
NOKIA
2650
    
336
NOKIA
2652
 GSM
      GSM
337
NOKIA
2680
    
GSM
9-Jan
338
NOKIA
2760
    
GSM
8-Jan
339
NOKIA
3100
    
GSM
24
6-Oct
340
NOKIA
3109
    
GSM
2
7-Oct
341
NOKIA
3110
    
GSM
2
7-Jul
342
NOKIA
3120
    
24
8-Jul
343
NOKIA
3200
 GSM
     GSM
24
6-Apr
344
NOKIA
3210
  
GSM
34
7-Oct
345
NOKIA
3220
    
GSM
24
7-Apr
346
NOKIA
3230
    
 GSM
7
7-Apr
347
NOKIA
3250
    
GSM
7
7-Apr
348
NOKIA
3310
  
GSM
32
7-Oct
349
NOKIA
3330
 
GSM
32
8-Jan
350
NOKIA
3410
  
GSM
32
7-Oct
351
NOKIA
3510
   
 GSM
30
8-Jan
352
NOKIA
3555
    
CDMA
1
8-Oct
353
NOKIA
5000
    
GSM
354
NOKIA
5070
    
GSM
CellXtract™ User Manual
  
117
GSM








9-Jan
GSM
28
7-Oct
GSM
28
7-Oct
GSM
25
7-Oct
GSM
25
7-Oct
GSM
28
8-Jan
GSM
28
8-Jan
GSM
28
9-Apr
GSM
25
7-Oct
GSM
29
7-Oct
24
6-Oct
28
7-Oct
25
7-Oct
 CDMA
 GSM
 GSM
8-Jul
8-Apr
31
7-Oct
31
7-Oct
8-Oct
24
7-Jul
SUPPORTED HANDSETS
 GSM
24
5-Dec
GSM
33
7-Oct
    
GSM
24
8-Jul
5200
    
GSM
2
7-Apr
NOKIA
5210
   
GSM
360
NOKIA
5220
    
GSM
1
8-Oct
361
NOKIA
5230
    
 GSM
1
10-Sep
362
NOKIA
5300
    
GSM
2
7-Apr
363
NOKIA
5310
    
GSM
1
8-Jan
364
NOKIA
5320
    
1
9-Jan
365
NOKIA
5500
 GSM
      GSM
7
7-Apr
366
NOKIA
5610
    
GSM
1
8-Apr
367
NOKIA
5700
    
GSM
2
7-Jul
368
NOKIA
5800
    
1
9-Jul
369
NOKIA
6010
 GSM
 GSM
30
7-Oct
370
NOKIA
6020
    
GSM
24
5-Dec
371
NOKIA
6021
    
GSM
24
6-Apr
372
NOKIA
6030
   
25
7-Oct
373
NOKIA
6060
   
 GSM
 GSM
25
7-Oct
374
NOKIA
6061
   
GSM
25
8-Apr
375
NOKIA
6070
   
 GSM
24
6-Oct
376
NOKIA
6080
   
GSM
24
7-Jan
377
NOKIA
6085
    
GSM
7
7-Jul
378
NOKIA
6086
    
GSM
7
8-Apr
379
NOKIA
6100
    
 GSM
24
5-Dec
380
NOKIA
6101
    
GSM
24
5-Dec
381
NOKIA
6103
24
6-Oct
382
NOKIA
6108
 GSM
      GSM
24
7-Oct
383
NOKIA
6111
    
GSM
7
6-Apr
384
NOKIA
6120
    
2
8-Jan
385
NOKIA
6125
 GSM
      GSM
7
6-Oct
386
NOKIA
6130
   
GSM
33
7-Oct
387
NOKIA
6131
    
GSM
7
6-Jul
388
NOKIA
6136
    
GSM
7
7-Jan
389
NOKIA
6150
   
GSM
33
7-Oct
390
NOKIA
6151
    
GSM
7
6-Oct
391
NOKIA
6170
    
GSM
7
5-Dec
355
NOKIA
5100
356
NOKIA
5110
357
NOKIA
5140
358
NOKIA
359
CellXtract™ User Manual
    
   
   
    
118
7-Apr
SUPPORTED HANDSETS
24
7-Jul
1
9-Jul
6210
 GSM
      GSM
   
 GSM
33
7-Oct
NOKIA
6220
    
24
5-Dec
396
NOKIA
6225
    
24
7-Jul
397
NOKIA
6230
    
GSM
7
6-Apr
398
NOKIA
6233
    
 GSM
7
6-Oct
399
NOKIA
6234
    
GSM
7
7-Jul
400
NOKIA
6260
    
 GSM
7
7-Jan
401
NOKIA
6263
    
CDMA
2
8-Oct
402
NOKIA
6267
    
GSM
2
8-Jan
403
NOKIA
6270
    
GSM
7
6-Jul
404
NOKIA
6280
    
GSM
7
6-Apr
405
NOKIA
6282
    
GSM
7
7-Jul
406
NOKIA
6288
    
GSM
7
7-Jul
407
NOKIA
6290
    
GSM
2
7-Oct
408
NOKIA
6300
    
GSM
2
7-Jul
409
NOKIA
6301
    
GSM
2
9-Jan
410
NOKIA
6310
   
411
NOKIA
6360
  
412
NOKIA
6510
   
413
NOKIA
6555
    
414
NOKIA
6610
   
415
NOKIA
6620
    
416
NOKIA
6630
    
417
NOKIA
6650
    
418
NOKIA
6670
    
419
NOKIA
6680
    
420
NOKIA
6790
    
421
NOKIA
6800
422
NOKIA
423
392
NOKIA
6200
393
NOKIA
6210
394
NOKIA
395
    
GSM
 CDMA
 GSM
 CDMA
 GSM







6-Apr
33
7-Oct
7-Apr
GSM
1
8-Jan
GSM
24
6-Apr
GSM
7
7-Apr
GSM
8-Jan
GSM
1
9-Jul
GSM
7
7-Jan
GSM
7
7-Jan
GSM
1
10-Sep
    
GSM
24
7-Oct
6810
    
GSM
24
7-Jul
NOKIA
6820
    
GSM
24
6-Apr
424
NOKIA
6822
    
GSM
24
5-Dec
425
NOKIA
7020
    
GSM
1
10-Dec
426
NOKIA
7110
   
 GSM
33
7-Oct
427
NOKIA
7200
    
GSM
24
6-Oct
428
NOKIA
7210
    
GSM
1
9-Jan
CellXtract™ User Manual
119
SUPPORTED HANDSETS
429
NOKIA
7210
    
 GSM
24
5-Dec
430
NOKIA
7260
    
GSM
24
6-Apr
431
NOKIA
7270
    
GSM
7
5-Dec
432
NOKIA
7280
    
GSM
433
NOKIA
7360
    
GSM
24
6-Apr
434
NOKIA
7370
    
GSM
7
6-Apr
435
NOKIA
7373
    
GSM
7
7-Apr
436
NOKIA
7380
    
GSM
437
NOKIA
7390
    
GSM
2
7-Apr
438
NOKIA
7500
    
GSM
2
8-Jan
439
NOKIA
7510
    
GSM
1
9-Jul
440
NOKIA
7600
    
7
5-Dec
441
NOKIA
7610
 GSM
      GSM
7
7-Jan
442
NOKIA
7900
    
GSM
1
8-Apr
443
NOKIA
8210
   
GSM
29
7-Apr
444
NOKIA
8310
   
 GSM
7-Apr
445
NOKIA
8800
    
GSM
5-Dec
446
NOKIA
8850
   
GSM
7-Apr
447
NOKIA
8910
   
5-Dec
448
NOKIA
1110i
   
 GSM
 GSM
449
NOKIA
2323 Classic
    
GSM
9-Oct
450
NOKIA
2330 Classic
    
GSM
9-Oct
451
NOKIA
2700 Classic
    
GSM
452
NOKIA
2720 Fold
    
GSM
453
NOKIA
2730 Classic
    
GSM
1
10-Jan
454
NOKIA
2865i
    
CDMA
7
8-Jan
455
NOKIA
3120 Classic
    
GSM
1
9-Apr
456
NOKIA
3155i
    
CDMA
7
8-Apr
457
NOKIA
3500 classic
    
GSM
2
8-Jan
458
NOKIA
3510i
 GSM
30
7-Oct
459
NOKIA
3600 Slide
    
GSM
1
8-Oct
460
NOKIA
3720 Classic
    
GSM
1
10-Jan
461
NOKIA
5130 Xpress Music
    
GSM
1
9-Oct
462
NOKIA
5140i
   
GSM
24
5-Dec
463
NOKIA
5530 Xpress Music
1
9-Oct
464
NOKIA
5630 Xpress Music
1
9-Oct
465
NOKIA
5730 Xpress Music
 GSM
      GSM
      GSM
1
9-Oct
CellXtract™ User Manual
   
    
120
5-Dec
6-Apr
25
1
7-Oct
9-Oct
10-Jan
SUPPORTED HANDSETS
466
NOKIA
6015i
    
467
NOKIA
6030b
   
468
NOKIA
6110 Navigator
469
NOKIA
470
 CDMA
24
6-Oct
GSM
25
10-Jan
    
GSM
2
7-Oct
6124c
    
 GSM
2
9-Jan
NOKIA
6155i
    
CDMA
7
8-Apr
471
NOKIA
6165i
    
CDMA
7
7-Jan
472
NOKIA
6208 Classic
    
GSM
1
9-Oct
473
NOKIA
6212 Classic
    
GSM
1
9-Oct
474
NOKIA
6220 Classic
    
 GSM
1
9-Apr
475
NOKIA
6230i
   
GSM
7
6-Apr
476
NOKIA
6235i
  

CDMA
7
6-Apr
477
NOKIA
6255i
  

CDMA
7
6-Apr
478
NOKIA
6260 Slide
    
GSM
1
9-Oct
479
NOKIA
6265i
    
CDMA
7
8-Jan
480
NOKIA
6275i
    
GSM
7
8-Apr
481
NOKIA
6303 Classic
    
GSM
1
9-Oct
482
NOKIA
6310i
483
NOKIA
6500 classic
    
GSM
1
8-Jan
484
NOKIA
6500 Slide
    
GSM
1
8-Apr
485
NOKIA
6600 fold
    
GSM
1
9-Jan
486
NOKIA
6600 slide
    
GSM
1
9-Jan
487
NOKIA
6600i Slide
    
GSM
1
10-Jan
488
NOKIA
6610i
    
 GSM
24
5-Dec
489
NOKIA
6700 Classic
    
GSM
1
10-Jan
490
NOKIA
6720 Classic
    
1
9-Oct
491
NOKIA
6730 Classic
1
9-Oct
492
NOKIA
6760 Slide
 GSM
      GSM
      GSM
1
10-Jan
493
NOKIA
7100 Supernova
    
GSM
494
NOKIA
7250i
    
 GSM
24
5-Dec
495
NOKIA
7310 Supernova
    
GSM
1
8-Oct
496
NOKIA
7610 Supernova
    
GSM
1
8-Oct
497
NOKIA
8600 Luna
    
GSM
1
8-Oct
498
NOKIA
8910i
499
NOKIA
E50
    
GSM
7
7-Apr
500
NOKIA
E51
    
GSM
2
8-Apr
501
NOKIA
E55
    
1
10-Jan
502
NOKIA
E60
 GSM
      GSM
7
7-Apr
CellXtract™ User Manual
   
   
121
 GSM
7-Apr
9-Apr
 GSM
5-Dec
SUPPORTED HANDSETS
503
NOKIA
E61
    
504
NOKIA
E63
    
505
NOKIA
506
GSM
7
7-Apr
1
9-Apr
E65
 GSM
      GSM
7
7-Apr
NOKIA
E66
    
GSM
1
8-Oct
507
NOKIA
E70
    
GSM
7
7-Apr
508
NOKIA
E71
    
1
8-Oct
509
NOKIA
E75
1
9-Jul
510
NOKIA
N70
 GSM
      GSM
      GSM
7
7-Jan
511
NOKIA
N71
    
GSM
7
7-Jul
512
NOKIA
N72
    
GSM
7
7-Jan
513
NOKIA
N73
    
GSM
7
7-Apr
514
NOKIA
N76
    
GSM
2
7-Jul
515
NOKIA
N77
    
GSM
7
8-Oct
516
NOKIA
N79
    
GSM
1
9-Jan
517
NOKIA
N80
    
GSM
7
7-Apr
518
NOKIA
N81 8GB
    
GSM
1
8-Apr
519
NOKIA
N82
    
GSM
1
8-Jul
520
NOKIA
N85
    
GSM
1
9-Apr
521
NOKIA
N90
    
GSM
7
7-Jan
522
NOKIA
N91
    
GSM
2
7-Apr
523
NOKIA
N93
    
GSM
7
8-Apr
524
NOKIA
N93i
    
GSM
7
7-Jul
525
NOKIA
N95
    
GSM
2
8-Jan
526
NOKIA
N95 8GB
    
GSM
2
8-Jul
527
NOKIA
N96
    
GSM
1
8-Oct
528
NOKIA
N97
    
GSM
1
9-Oct
529
NOKIA
N97 mini
    
GSM
1
10-Sep
530
NOKIA
X3
    
GSM
1
10-Dec
531
NOKIA
X6
      GSM
1
11-May
532
NOKIA
6350
    
GSM
1
Dec-11
533
NOKIA
X2-01
    
GSM
1
Dec-11
534
O2
ICE
12
7-Oct
535
O2
XDA
   
536
O2
XDA IIi
   
537
ORANGE
SPV C500
   
538
ORANGE
SPV C550
   
539
ORANGE
SPV C600
    
540
PALM
700P
CellXtract™ User Manual
 
 
  
122

















 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 CDMA
6-Jul
6-Jul
2
6-Jul
2
6-Jul
2
6-Jul
23
10-Jan
SUPPORTED HANDSETS

     
 

  
 
     
GSM
23
9-Jan
GSM
2
9-Jan
GSM
23
8-Apr
GSM
2
9-Jan
P8000
    
GSM
1
Apr-12
SAGEM
my302X
    
548
SAGEM
my401C
    
549
SAGEM
my401V
    
550
SAGEM
my401X
    
551
SAGEM
my411C
   
552
SAGEM
my411Cv
   
553
SAGEM
my411X
    
554
SAGEM
my501C
   
555
SAGEM
my511X
   
556
SAGEM
my600v
   
557
SAGEM
my700X
    
558
SAGEM
myV-55
   
559
SAGEM
myV-65
   
560
SAGEM
myX5-2
   
561
SAGEM
myX-6
    
562
SAMSUNG
B2100
    
563
SAMSUNG
B2700
 
 
564
SAMSUNG
B3310
 
 
565
SAMSUNG
B5702
    
566
SAMSUNG
B7300
    
567
SAMSUNG
C3050
 
568
SAMSUNG
C6625
    
569
SAMSUNG
E1360
    
570
SAMSUNG
E2210
    
571
SAMSUNG
I8000
    
572
SAMSUNG
i8510
    
573
SAMSUNG
M3200
    
574
SAMSUNG
M7500
 
 
575
SAMSUNG
M7600
 
 
576
SAMSUNG
M8800
 
 
577
SAMSUNG
S3030
 
 
578
SAMSUNG
S3100
    
541
PALM
Centro
542
PALM
Treo 500
543
PALM
Treo 680
544
PALM
Treo 750
545
PALM
Treo Pro
546
PANTECH
547
CellXtract™ User Manual
 
123
 
































GSM
7-Jul
GSM
7-Apr
GSM
8-Jan
GSM
7-Apr
GSM
7-Apr
GSM
8-Jan
GSM
8-Jan
GSM
8-Jan
GSM
7-Apr
GSM
8-Jan
GSM
7-Jul
GSM
7-Apr
GSM
8-Jan
GSM
8-Jan
GSM
8-Jan
GSM
8-Jan
GSM
4
9-Jul
GSM
4
9-Apr
GSM
1
9-Oct
GSM
4
9-Oct
GSM
1
10-Jan
GSM
4
9-Jul
GSM
4
9-Oct
GSM
9-Oct
GSM
9-Oct
GSM
1
GSM
10-Jan
9-Apr
GSM
4
10-Jan
GSM
1
9-Jul
GSM
1
9-Jul
GSM
4
9-Apr
GSM
4
9-Oct
GSM
4
10-Jan
SUPPORTED HANDSETS
579
SAMSUNG
S3500
 
580
SAMSUNG
S3600
    
581
SAMSUNG
S3650
 
582
SAMSUNG
S5050
    
583
SAMSUNG
S5230
 
 
584
SAMSUNG
S5600
 
 
585
SAMSUNG
S7220
 
 
586
SAMSUNG
S7330
 
 
587
SAMSUNG
S8000
 
 
588
SAMSUNG
S8300
 
 
589
SAMSUNG
SCH-A310
 

590
SAMSUNG
SCH-A530
 

591
SAMSUNG
SCH-A570
 

592
SAMSUNG
SCH-A630
 

593
SAMSUNG
SCH-A650
 

 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
594
SAMSUNG
SCH-A670
 

595
SAMSUNG
SCH-A795
   
596
SAMSUNG
SCH-A850
    
597
SAMSUNG
SCH-A870
   
598
SAMSUNG
SCH-A930
    
599
SAMSUNG
SCH-A950
    
600
SAMSUNG
SCH-A990
    
601
SAMSUNG
602
 
 
4
9-Apr
10-Jan
4
10-Jan
4
9-Oct
4
9-Oct
1
9-Oct
1
9-Jul
4
9-Apr
1
9-Oct
1
9-Jul
11
6-Apr
11
6-Apr
11
6-Oct
10
6-Oct
11
6-Apr
CDMA
11
6-Apr
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
10
8-Apr
10
8-Apr
10
8-Apr
10
8-Apr
10
8-Apr
10
8-Apr
SCH-i220
      CDMA
1
11-May
SAMSUNG
SCH-i600
603
SAMSUNG
SCH-i730
604
SAMSUNG
SCH-i760
 GSM
      CDMA
      GSM
18
8-Jul
605
SAMSUNG
SCH-i920
      CDMA
1
10-Dec
606
SAMSUNG
SCH-R450
4
9-Jul
607
SAMSUNG
SCH-U340
 CDMA
      CDMA
10
9-Jul
608
SAMSUNG
SCH-U350
      CDMA
4
10-Dec
609
SAMSUNG
SCH-U410
    
10
8-Apr
610
SAMSUNG
SCH-U650
4
9-Jul
611
SAMSUNG
SCH-U740
 CDMA
   
 CDMA
      CDMA
6
10-Jan
612
SAMSUNG
SCH-U820
    
CDMA
1
10-Dec
613
SAMSUNG
SCH-U940
4
9-Jul
614
SAMSUNG
SGH-A177
4
10-Jan
615
SAMSUNG
SGH-A300
16
5-Dec
616
SAMSUNG
SGH-A517
 CDMA
      GSM
  
 GSM
      GSM
4
8-Apr
CellXtract™ User Manual

 
   
   
124
6-Jul
6-Jul
SUPPORTED HANDSETS
617
SAMSUNG
SGH-A687
 
   GSM
618
SAMSUNG
SGH-A707
 

619
SAMSUNG
SGH-A717
  

620
SAMSUNG
SGH-A727
  

621
SAMSUNG
SGH-A737
 
 
622
SAMSUNG
SGH-A747
 
 
623
SAMSUNG
SGH-A767
 
 
624
SAMSUNG
SGH-A777
625
SAMSUNG
626
4
10-Dec
GSM
6
8-Jan
GSM
6
8-Jan
GSM
6
8-Jan
GSM
4
8-Oct
GSM
4
8-Oct
GSM
4
9-Jul
 
   GSM
4
10-Dec
SGH-A827
 
 
4
8-Oct
SAMSUNG
SGH-A837
 
 GSM
   GSM
4
9-Jul
627
SAMSUNG
SGH-A877
 
   GSM
4
10-Dec
628
SAMSUNG
SGH-A887
 
   GSM
4
10-Dec
629
SAMSUNG
SGH-C100
   
GSM
16
5-Dec
630
SAMSUNG
SGH-C207
   
GSM
16
6-Jul
631
SAMSUNG
SGH-C225
   
GSM
16
5-Dec
632
SAMSUNG
SGH-C300
   
GSM
16
8-Jan
633
SAMSUNG
SGH-D307
   
GSM
11
6-Jul
634
SAMSUNG
SGH-D357
    
GSM
11
7-Jul
635
SAMSUNG
SGH-D407
    
636
SAMSUNG
SGH-D410
   
637
SAMSUNG
SGH-D500
    
638
SAMSUNG
SGH-D520
    
639
SAMSUNG
SGH-D600
    
640
SAMSUNG
SGH-D720
    
641
SAMSUNG
SGH-D780
    
642
SAMSUNG
SGH-D800
    
643
SAMSUNG
SGH-D807
    
644
SAMSUNG
SGH-D820
    
645
SAMSUNG
SGH-D830
    
646
SAMSUNG
SGH-D840
    
647
SAMSUNG
SGH-D880
    
648
SAMSUNG
SGH-D900
    
649
SAMSUNG
SGH-D900i
    
650
SAMSUNG
SGH-D980
   
651
SAMSUNG
SGH-E105
   
652
SAMSUNG
SGH-E210
 
653
SAMSUNG
SGH-E250
    
654
SAMSUNG
SGH-E330
    
CellXtract™ User Manual
125
 
































GSM
7-Oct
GSM
16
5-Dec
GSM
11
5-Dec
GSM
6
7-Apr
GSM
11
6-Apr
GSM
12
7-Jul
GSM
4
9-Jan
GSM
6
6-Oct
GSM
6
8-Apr
GSM
6
6-Oct
GSM
6
7-Apr
GSM
6
7-Jul
GSM
4
8-Jul
GSM
6
7-Apr
GSM
6
7-Oct
GSM
4
9-Apr
GSM
16
6-Apr
GSM
8-Jan
GSM
6
7-Apr
GSM
17
6-Oct
SUPPORTED HANDSETS
GSM
17
6-Oct
GSM
11
5-Dec
GSM
11
7-Jan
SGH-E390

     
     
     
GSM
6
7-Apr
SAMSUNG
SGH-E530
    
GSM
660
SAMSUNG
SGH-E570
    
GSM
6
7-Apr
661
SAMSUNG
SGH-E590
    
GSM
6
7-Oct
662
SAMSUNG
SGH-E600
   
GSM
16
7-Jul
663
SAMSUNG
SGH-E630
    
GSM
17
6-Apr
664
SAMSUNG
SGH-E700
    
GSM
17
5-Dec
665
SAMSUNG
SGH-E715
   
GSM
16
6-Oct
666
SAMSUNG
SGH-E720
    
GSM
12
5-Dec
667
SAMSUNG
SGH-E730
    
GSM
11
5-Dec
668
SAMSUNG
SGH-E740
    
GSM
6
8-Jan
669
SAMSUNG
SGH-E760
    
GSM
11
5-Dec
670
SAMSUNG
SGH-E770
    
GSM
11
6-Apr
671
SAMSUNG
SGH-E800
    
GSM
17
5-Dec
672
SAMSUNG
SGH-E830
    
GSM
6
8-Apr
673
SAMSUNG
SGH-E840
    
GSM
6
7-Oct
674
SAMSUNG
SGH-E870
    
GSM
6
6-Oct
675
SAMSUNG
SGH-E880
    
676
SAMSUNG
SGH-E900
    
677
SAMSUNG
SGH-E950
    
678
SAMSUNG
SGH-F110
   
679
SAMSUNG
SGH-F210
    
680
SAMSUNG
SGH-F250
    
681
SAMSUNG
SGH-F300
    
682
SAMSUNG
SGH-F330
    
683
SAMSUNG
SGH-F400
    
684
SAMSUNG
SGH-F480
 
685
SAMSUNG
SGH-F490
    
686
SAMSUNG
SGH-F500
    
687
SAMSUNG
SGH-F700
 
 
688
SAMSUNG
SGH-G400
 
 
689
SAMSUNG
SGH-G600
    
690
SAMSUNG
SGH-G800
    
691
SAMSUNG
SGH-G810
    
692
SAMSUNG
SGH-i200
    
655
SAMSUNG
SGH-E335
656
SAMSUNG
SGH-E350
657
SAMSUNG
SGH-E370
658
SAMSUNG
659
CellXtract™ User Manual
    
126
 














5-Dec
GSM

















7-Jul
GSM
6
7-Jan
GSM
6
8-Jan
GSM
4
8-Oct
GSM
8-Jan
GSM
4
9-Jan
GSM
6
7-Jul
GSM
4
8-Jul
GSM
4
8-Jul
GSM
4
9-Jan
GSM
4
8-Jul
GSM
6
7-Oct
GSM
4
9-Apr
GSM
4
9-Apr
GSM
8-Jan
GSM
4
8-Jul
GSM
1
9-Apr
GSM
4
9-Jan
SUPPORTED HANDSETS
693
SAMSUNG
SGH-i300
    
694
SAMSUNG
SGH-i320
    
695
SAMSUNG
SGH-i325
    
696
SAMSUNG
SGH-i600
    
697
SAMSUNG
SGH-i607
    
698
SAMSUNG
SGH-i617
    
699
SAMSUNG
SGH-i620
    
700
SAMSUNG
SGH-i710
    
701
SAMSUNG
SGH-i780
    
702
SAMSUNG
SGH-i900
    
703
SAMSUNG
SGH-J600
 
 
704
SAMSUNG
SGH-J610
 
 
705
SAMSUNG
SGH-J700
    
706
SAMSUNG
SGH-L700
 
707
SAMSUNG
SGH-L760
708
SAMSUNG
SGH-L770
709
SAMSUNG
SGH-M150
710
SAMSUNG
SGH-M610
711
SAMSUNG
712
 GSM
 GSM
 GSM
 CDMA
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
12
7-Oct
7-Jan
4
9-Jan
2
7-Oct
6
7-Jul
4
8-Oct
6
9-Jan
6
7-Oct
4
9-Jul
4
9-Jan
6
8-Jan
4
8-Oct
4
8-Jul
GSM
4
10-Jan
GSM
4
8-Oct
SGH-P207

 
  
     
   

   

SAMSUNG
SGH-P300
 
713
SAMSUNG
SGH-P310
    
714
SAMSUNG
SGH-P400
715
SAMSUNG
SGH-P510
716
SAMSUNG
SGH-P520
717
SAMSUNG
SGH-P735
718
SAMSUNG
SGH-P777
719
SAMSUNG
SGH-P850
720
SAMSUNG
SGH-S300M
721
SAMSUNG
722
 
 
 
GSM
9-Jan
GSM
4
8-Oct
GSM
4
8-Oct
GSM
11
6-Oct
GSM
6
6-Apr
GSM
6
7-Apr
GSM
16
5-Dec
SGH-S307

   

   

     
     
   

     
   

   

SAMSUNG
SGH-S400i
723
SAMSUNG
724

GSM
5-Dec
GSM
4
8-Apr
GSM
12
5-Dec
GSM
6-Jul
GSM
11
6-Oct
GSM
16
6-Oct
GSM
16
5-Dec
    
GSM
11
7-Apr
SGH-S401i
    
GSM
11
7-Apr
SAMSUNG
SGH-T301
    
4
10-Jan
725
SAMSUNG
SGH-T309
11
6-Jul
726
SAMSUNG
SGH-T349
 GSM
      GSM
      GSM
727
SAMSUNG
SGH-T369
      GSM
1
11-May
728
SAMSUNG
SGH-T429
    
4
8-Jul
729
SAMSUNG
SGH-T439
4
8-Oct
730
SAMSUNG
SGH-T469
 GSM
      GSM
 
   GSM
CellXtract™ User Manual
127
10-Jan
10-Sep
SUPPORTED HANDSETS
731
SAMSUNG
SGH-T509
    
732
SAMSUNG
SGH-T539
    
733
SAMSUNG
SGH-T609
    
734
SAMSUNG
SGH-T639
735
SAMSUNG
SGH-T719
    
736
SAMSUNG
SGH-T729
    
737
SAMSUNG
SGH-T739
    
738
SAMSUNG
SGH-T749
 
739
SAMSUNG
SGH-T809
    
740
SAMSUNG
SGH-T819
 
 
741
SAMSUNG
SGH-T919
 
 
742
SAMSUNG
SGH-U100
    
743
SAMSUNG
SGH-U600
    
744
SAMSUNG
SGH-U700
    
745
SAMSUNG
SGH-U800
 
746
SAMSUNG
SGH-U900
    
747
SAMSUNG
SGH-X100
    
748
SAMSUNG
SGH-X427m
   
749
SAMSUNG
SGH-X450
   
750
SAMSUNG
SGH-X460
    
751
SAMSUNG
SGH-X475
   
752
SAMSUNG
SGH-X495
    
753
SAMSUNG
SGH-X497
    
754
SAMSUNG
SGH-X500
755
SAMSUNG
SGH-X507
    
756
SAMSUNG
SGH-X530
757
SAMSUNG
SGH-X600
758
SAMSUNG
SGH-X640
759
SAMSUNG
760
 







GSM
6
7-Jan
GSM
4
8-Apr
GSM
11
7-Jan
GSM
4
8-Oct
GSM
11
7-Jan
GSM
4
8-Apr
GSM
4
8-Oct
   GSM
4
10-Dec
GSM
6
6-Jul
GSM
4
8-Oct
GSM
4
9-Jul
 















GSM
7-Jul
GSM
6
7-Jul
GSM
6
8-Jan
GSM
4
9-Jan
GSM
4
8-Jul
GSM
17
7-Oct
GSM
16
6-Apr
GSM
16
5-Dec
GSM
17
7-Apr
GSM
17
6-Oct
GSM
17
8-Jul
GSM
17
8-Jul
    
GSM
11
8-Apr
GSM
11
7-Apr
GSM
16
7-Apr
GSM
17
6-Oct
GSM
17
6-Oct
SGH-X650

   

     
     
     
GSM
17
7-Jul
SAMSUNG
SGH-X660
    
GSM
11
7-Apr
761
SAMSUNG
SGH-X680
    
GSM
11
8-Jul
762
SAMSUNG
SGH-X700
    
763
SAMSUNG
SGH-X820
    
764
SAMSUNG
SGH-X830
    
765
SAMSUNG
SGH-Z240
 
766
SAMSUNG
SGH-Z320i
    
767
SAMSUNG
SGH-Z510
   
768
SAMSUNG
SGH-Z720
 
CellXtract™ User Manual
128
 
 








GSM
7-Oct
GSM
6
6-Oct
GSM
6
7-Apr
GSM
6
8-Jul
GSM
18
9-Apr
GSM
6
6-Jul
GSM
6
8-Jul
SUPPORTED HANDSETS
 CDMA
 CDMA
 CDMA
4
9-Jul
11
7-Jan
11
7-Jul
CDMA
11
6-Oct

 CDMA
11
7-Jul
 

CDMA
11
6-Apr
SPH-A680
 

 CDMA
11
7-Jul
SAMSUNG
SPH-A740
 

CDMA
11
6-Apr
777
SAMSUNG
SPH-A760
 

CDMA
11
6-Apr
778
SAMSUNG
SPH-A820
 

11
7-Apr
779
SAMSUNG
SPH-A840
 

11
6-Apr
780
SAMSUNG
SPH-A900
   
11
8-Jul
781
SAMSUNG
SPH-A920
   
11
8-Jul
782
SAMSUNG
SPH-A960
   
11
8-Jul
783
SAMSUNG
SPH-M500
   
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
 CDMA
11
8-Jul
784
SAMSUNG
SPH-M540
   
CDMA
1
9-Jul
785
SAMSUNG
SPH-M610
      CDMA
6
10-Dec
786
SAMSUNG
SGH-T959V
GSM
1
Dec-11
787
SAMSUNG
SGH-T249
      GSM
1
Dec-11
788
SAMSUNG
SCH-i400
    
CDMA
1
Apr-12
789
SAMSUNG
SPH-D700
    
CDMA
1
Apr-12
790
SAMSUNG
SGH-T589
    
GSM
1
Apr-12
791
SAMSUNG
SPH-M910
    
CDMA
1
Apr-12
792
SAMSUNG
SCH-R350
 CDMA
1
Apr-12
793
SAMSUNG
SGH-i727
    
GSM
1
Apr-12
794
SAMSUNG
SGH-i897
    
GSM
1
Apr-12
795
SAMSUNG
SGH-i997
    
GSM
1
Apr-12
796
SAMSUNG
SGH-T499
    
GSM
1
Apr-12
797
SAMSUNG
SCH-i515
    
CDMA
1
Sep-12
798
SAMSUNG
GT-I9100
    
GSM
1
Sep-12
799
SHARP
FX PLUS
    
GSM
1
Apr-12
800
SIEMENS
A60
    
GSM
13
8-Jul
801
SIEMENS
A65
  

GSM
13
5-Dec
802
SIEMENS
A75
  
 
GSM
13
6-Apr
803
SIEMENS
C35
   
 GSM
14
5-Dec
804
SIEMENS
C35i
   
GSM
14
6-Oct
805
SIEMENS
C55

 
GSM
13
6-Apr
806
SIEMENS
C60

  
GSM
13
6-Apr
769
SAMSUNG
SPH-A513
   
770
SAMSUNG
SPH-A580
 

771
SAMSUNG
SPH-A600
 

772
SAMSUNG
SPH-A620
 
773
SAMSUNG
SPH-A640
 
774
SAMSUNG
SPH-A660
775
SAMSUNG
776
CellXtract™ User Manual
    
   
129
SUPPORTED HANDSETS
807
SIEMENS
C61
  
808
SIEMENS
C62
809
SIEMENS
C65
  
810
SIEMENS
C72
811
SIEMENS
CF110
812
SIEMENS
813
 
GSM
13
6-Apr
   
GSM
13
5-Dec
GSM
13
5-Dec
GSM
13
6-Jul
GSM
13
6-Apr
CF75

     
     
     
GSM
13
6-Apr
SIEMENS
CL75
  
GSM
13
6-Apr
814
SIEMENS
CT66
    
GSM
13
6-Apr
815
SIEMENS
CX65
  
 
GSM
13
5-Dec
816
SIEMENS
M55
  
 
GSM
13
6-Jul
817
SIEMENS
M65
  
 
GSM
13
5-Dec
818
SIEMENS
M75
    
GSM
13
6-Apr
819
SIEMENS
MC60
  
GSM
13
5-Dec
820
SIEMENS
ME45
   
GSM
14
8-Jul
821
SIEMENS
ME75
  
 
GSM
13
6-Apr
822
SIEMENS
S55
  
 
GSM
13
6-Apr
823
SIEMENS
S65
  
 
GSM
13
5-Dec
824
SIEMENS
S75
    
GSM
13
6-Apr
825
SIEMENS
SF65
    
826
SIEMENS
SK65
  
 
827
SIEMENS
SL55
  
 
828
SIEMENS
SL65
  
 
829
SIEMENS
SP65
  

830
SONIM
XP3
    
831
SONY ERICSSON
C510
    
832
SONY ERICSSON
C702
    
833
SONY ERICSSON
C901
    
834
SONY ERICSSON
C902
    
835
SONY ERICSSON
C903
    
836
SONY ERICSSON
C905
    
837
SONY ERICSSON
D750i
    
838
SONY ERICSSON
F305
    
839
SONY ERICSSON
F500i
    
840
SONY ERICSSON
841
 


























GSM
6-Jul
GSM
13
5-Dec
GSM
13
5-Dec
GSM
13
5-Dec
GSM
9-Jul
GSM
9-Oct
GSM
8
GSM
GSM
9-Apr
8-Oct
8
GSM
9-Oct
8-Oct
GSM
8
9-Oct
GSM
8
9-Apr
GSM
8
6-Apr
GSM
9-Oct
15
5-Dec
G502
 GSM
      GSM
8
8-Oct
SONY ERICSSON
G700
   
GSM
8
9-Jan
842
SONY ERICSSON
G705
    
 GSM
8
9-Apr
843
SONY ERICSSON
G900
   
GSM
8
9-Jan
844
SONY ERICSSON
J105i
    
 GSM
8
10-Sep
CellXtract™ User Manual
130
SUPPORTED HANDSETS




















845
SONY ERICSSON
J300i
    
846
SONY ERICSSON
K300i
    
847
SONY ERICSSON
K310i
    
848
SONY ERICSSON
K320i
    
849
SONY ERICSSON
K500i
    
850
SONY ERICSSON
K510i
    
851
SONY ERICSSON
K530i
    
852
SONY ERICSSON
K550i
    
853
SONY ERICSSON
K550im
    
854
SONY ERICSSON
K600i
    
855
SONY ERICSSON
K608i
    
856
SONY ERICSSON
K610i
    
857
SONY ERICSSON
K630i
    
858
SONY ERICSSON
K660i
    
859
SONY ERICSSON
K700i
    
860
SONY ERICSSON
K750i
    
861
SONY ERICSSON
K770i
    
862
SONY ERICSSON
K800i
    
863
SONY ERICSSON
K810i
    
864
SONY ERICSSON
K850i
    
865
SONY ERICSSON
M600
866
SONY ERICSSON
P1i
867
SONY ERICSSON
P800
 

868
SONY ERICSSON
P900i
 

 GSM
 GSM
869
SONY ERICSSON
P990i
   
GSM
870
SONY ERICSSON
S302
    
GSM
9-Oct
871
SONY ERICSSON
S312
    
GSM
10-Jan
872
SONY ERICSSON
S500i
    
873
SONY ERICSSON
S700i
874
SONY ERICSSON
S710a
875
SONY ERICSSON
876
GSM
15
5-Dec
GSM
15
5-Dec
GSM
8
6-Oct
GSM
8
9-Jan
GSM
15
5-Dec
GSM
8
7-Jan
GSM
8
8-Jan
GSM
8
7-Jul
GSM
8
7-Jul
GSM
15
5-Dec
GSM
15
6-Oct
GSM
8
6-Oct
GSM
8
8-Jul
GSM
8
8-Jul
GSM
15
5-Dec
GSM
8
5-Dec
GSM
8
8-Jan
GSM
8
6-Jul
GSM
8
7-Jul
GSM
8
8-Jan
   
GSM
8
9-Jan
   
GSM
8
9-Jan
8-Apr
8-Jul
8
9-Jan
 GSM
      GSM
      GSM
8
7-Oct
15
5-Dec
15
6-Apr
T230
   
GSM
15
7-Jul
SONY ERICSSON
T290i
   
GSM
15
5-Dec
877
SONY ERICSSON
T300
   
GSM
15
5-Dec
878
SONY ERICSSON
T310
   
GSM
15
5-Dec
879
SONY ERICSSON
T610
    
15
5-Dec
880
SONY ERICSSON
T630
15
5-Dec
881
SONY ERICSSON
T650i
 GSM
      GSM
      GSM
8
8-Jan
882
SONY ERICSSON
T68
   
15
5-Dec
CellXtract™ User Manual
131
GSM
SUPPORTED HANDSETS
15
6-Oct
8
9-Jan
T707
 GSM
      GSM
      GSM
8
9-Oct
SONY ERICSSON
T715
    
GSM
8
10-Jan
887
SONY ERICSSON
TM506
      GSM
8
10-Dec
888
SONY ERICSSON
U100i Yari
    
GSM
8
10-Jan
889
SONY ERICSSON
U10i Aino
    
GSM
8
10-Jan
890
SONY ERICSSON
U1i Satio

  
GSM
891
SONY ERICSSON
U5i (Vivaz)
    
GSM
1
11-May
892
SONY ERICSSON
V600i
    
GSM
15
6-Apr
893
SONY ERICSSON
V630i
    
GSM
8
7-Jul
894
SONY ERICSSON
V640i
    
GSM
8
8-Jul
895
SONY ERICSSON
V800
    
GSM
15
5-Dec
896
SONY ERICSSON
W200i
    
GSM
8
7-Jul
897
SONY ERICSSON
W300i
    
898
SONY ERICSSON
W302
    
899
SONY ERICSSON
W350
    
900
SONY ERICSSON
W380i
 GSM
      GSM
901
SONY ERICSSON
W395
    
GSM
902
SONY ERICSSON
W508
    
 GSM
8
9-Oct
903
SONY ERICSSON
W518A
      GSM
8
10-Dec
904
SONY ERICSSON
W550i
    
GSM
8
5-Dec
905
SONY ERICSSON
W580i
    
GSM
8
7-Oct
906
SONY ERICSSON
W595
    
GSM
8
9-Jan
907
SONY ERICSSON
W610i
    
GSM
8
7-Jul
908
SONY ERICSSON
W660i
    
GSM
8
8-Jan
909
SONY ERICSSON
W705
    
GSM
8
9-Apr
910
SONY ERICSSON
W710i
    
GSM
8
6-Oct
911
SONY ERICSSON
W760
    
912
SONY ERICSSON
W800i
    
913
SONY ERICSSON
W810i
    
914
SONY ERICSSON
W850i
    
915
SONY ERICSSON
W880i
    
916
SONY ERICSSON
W890i
    
917
SONY ERICSSON
W900i
    
918
SONY ERICSSON
W902
    
919
SONY ERICSSON
W910i
    
920
SONY ERICSSON
W950i
   
883
SONY ERICSSON
T68i
884
SONY ERICSSON
T700
885
SONY ERICSSON
886
CellXtract™ User Manual
   
132






















10-Jan
GSM
6-Jul
GSM
9-Oct
8
8-Oct
8
8-Jul
9-Oct
GSM
8-Oct
GSM
8
5-Dec
GSM
8
6-Jul
GSM
8
6-Oct
GSM
8
7-Apr
GSM
8
8-Jul
GSM
8
6-Apr
GSM
8
9-Apr
GSM
8
8-Jan
GSM
8
9-Jan
SUPPORTED HANDSETS
921
SONY ERICSSON
W960
   
922
SONY ERICSSON
W980
    
923
SONY ERICSSON
W995
924
SONY ERICSSON
925
GSM
8
9-Jan
8
9-Jan
8
9-Oct
X1
 GSM
      GSM
      GSM
2
9-Jan
SONY ERICSSON
X10
    
GSM
1
11-May
926
SONY ERICSSON
Z1010
    
GSM
15
7-Jul
927
SONY ERICSSON
Z310i
    
GSM
8
7-Jul
928
SONY ERICSSON
Z500a
    
GSM
15
6-Apr
929
SONY ERICSSON
Z520a
    
GSM
8
6-Oct
930
SONY ERICSSON
Z520i
    
GSM
8
5-Dec
931
SONY ERICSSON
Z530i
    
GSM
8
6-Jul
932
SONY ERICSSON
Z550i
    
GSM
8
6-Oct
933
SONY ERICSSON
Z555i
    
GSM
8
8-Jul
934
SONY ERICSSON
Z600
    
GSM
15
5-Dec
935
SONY ERICSSON
Z610i
    
GSM
8
7-Apr
936
SONY ERICSSON
Z710i
    
GSM
8
7-Apr
937
SONY ERICSSON
Z770
    
938
SONY ERICSSON
Z800i
    
939
T-MOBILE
MDA Vario II
940
TOSHIBA
G810
    
941
TOSHIBA
G910
    
942
TOSHIBA
Portege G500
    
943
TOSHIBA
Portege G710
    
944
UBiQUiO
401
    
945
UBiQUiO
501
    
946
VERIZON
XV6700
947
VISOA
Spiderphone
948
VODAFONE
527
   
949
VODAFONE
533
   
950
VODAFONE
710
 
 
951
VODAFONE
725
 
 
952
VODAFONE
810
 
 
953
VODAFONE
830
 
 
954
ZTE
C78
 
 
CellXtract™ User Manual
   
   

133
  





















GSM
8-Oct
GSM
15
5-Dec
GSM
2
8-Jul
GSM
2
9-Jul
GSM
2
9-Jul
GSM
2
7-Jul
GSM
2
9-Apr
GSM
2
7-Jul
GSM
2
7-Jul
GSM
2
7-Oct
GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 GSM
 CDMA
10-Jan
9-Jul
9-Jul
7-Oct
9-Jul
8-Jul
9-Jul
10-Sep
SUPPORTED HANDSETS
Handsets – Expected Support
The following handsets have not been verified on CellXtract however their appearance or
technology indicates that data extraction will be possible as shown by the icons on CellXtract.
These handsets are assigned an amber tick. It is recommended that all data is treated as a
minimum extraction as there may be additional data sets available that require further examination.
Data can be extracted from these handsets as normal by selecting the device from the
Manufacturers list and extracting over Bluetooth, Infrared or Cable as required.
All Windows Mobile devices can be extracted using the PDA option and selecting Windows. All
Windows Mobile devices are supported by Infrared and/or Cable.
MFG
MFG
MODEL
MFG
MODEL
ASUS
H502
AT&T
2125
ACER
ACER
ACER
ACER
ACER
ACER
ACER
ACER
ACER
ACER
ACER
ACER
MODEL
beTouch
E100
beTouch
E200
c510
c530
c531
DX650
DX900
Liquid
M900
n10
n30
n35
n300
ASUS
ASUS
ASUS
ASUS
ASUS
ASUS
ASUS
ASUS
ASUS
ASUS
ASUS
ASUS
M530W
M356
M930
Mars II
Mypal A626
MyPal A632
MyPal A636
MyPal A636N
MyPal A639
MyPal A686
P305
P320
3125
5700
8125
8500
8525
SX56
SX66
5050
5600
6601
XV6600
XV6700
ACER
n310
ASUS
P505
ACER
n311
ASUS
P525
ACER
n320
ASUS
P526
ACER
n321
ASUS
P527
ACER
neoTouch
ASUS
P535
AIRIS
T610
ASUS
P550
AIRIS
T620
ASUS
P552
AIRO
AMOI
A25
E72
ASUS
ASUS
P560
P565
AT&T
AT&T
AT&T
AT&T
AT&T
AT&T
AT&T
AUDIOVOX
AUDIOVOX
AUDIOVOX
AUDIOVOX
AUDIOVOX
BENQSIEMENS
BLACKBERR
Y
BLACKBERR
Y
BLACKBERR
Y
BLACKBERR
Y
BLACKBERR
Y
BLACKBERR
Y
BLACKBERR
Y
BLACKBERR
ACER
CellXtract™ User Manual
134
P51
8110
8130 (Pearl)
8220
8230 (Pearl)
Pearl 3G
9100
9105 (Pearl
3G)
Curve 3G
9300
9520
SUPPORTED HANDSETS
AMOI
E75
ASUS
P735
AMOI
E76
ASUS
P750
AMOI
E78
ASUS
P835
AMOI
E850
ASUS
V88i
AMOI
E860
moboDA
3160
moboDA
3360
moboDA
3380
SP310
iPod Touch
iPhone 4S
iPhone 5S
ASUS
Z801
ASUS
Z810
Y
BLACKBERR
Y
BLACKBERR
Y
BLACKBERR
Y
BLACKBERR
Y
BLACKBERR
Y
BLACKBERR
Y
ASUS
ZX1
CINGULAR
2125
AT Mobile
AT Mobile
AT Mobile
AT Bear
AT Cobra
AT Eagle
CINGULAR
CINGULAR
CINGULAR
3125
8100
8125
AT Mobile
AT Falcon
SX66
A696
J501
AT Mobile
AT Pelican
CINGULAR
CINGULAR
iPAQ
h6325
DOPOD
CHT 9100
FUJITSU
SIEMENS
3800
DOPOD
D600
3830
DOPOD
D802
3835
DOPOD
D8110
3850
DOPOD
M700
3870
DOPOD
P100
3875
DOPOD
P800W
3900
DOPOD
S300
3950
DOPOD
U1000
3955
E-PLUS
PDA III
3970
E-PLUS
PDA IV
3975
ETEN
600
DAXIAN
CU928
ETEN
600e
DELL
AXIM
Pocket DJ
20GB
ETEN
DX900
ETEN
E500
AnexTEK
AnexTEK
AnexTEK
AnexTEK
Apple
Apple
Apple
ASUS
ASUS
CINGULA
R iPAQ
COMPAQ
iPAQ
COMPAQ
iPAQ
COMPAQ
iPAQ
COMPAQ
iPAQ
COMPAQ
iPAQ
COMPAQ
iPAQ
COMPAQ
iPAQ
COMPAQ
iPAQ
COMPAQ
iPAQ
COMPAQ
iPAQ
COMPAQ
iPAQ
DELL
CellXtract™ User Manual
135
FUJITSU
SIEMENS
FUJITSU
SIEMENS
FUJITSU
SIEMENS
FUJITSU
SIEMENS
FUJITSU
SIEMENS
FUJITSU
SIEMENS
FUJITSU
SIEMENS
FUJITSU
SIEMENS
FUJITSU
SIEMENS
FUJITSU
SIEMENS
FUJITSU
SIEMENS
FUJITSU
SIEMENS
FUJITSU
SIEMENS
GARMINASUS
9550
9630
9650 (Bold)
9670 (Style)
Torch 9800
9900
h6320
C550
N100
N110
N500
N520
N520c
N520e
N520p
N560
N560c
N560e
T810
T830
V70
Garminfone
SUPPORTED HANDSETS
DELL
DELL
DELL
Pocket DJ
30GB
X3
X3i
ETEN
ETEN
ETEN
E900
G500
G500+
GIGABYTE
GIGABYTE
GIGABYTE
DELL
X30
ETEN
M500
GIGABYTE
DELL
X5
ETEN
M550
