ML-2510 Series / ML-2570 Series
Monochrome Laser Printer
User’s Guide
Downloaded From ManualsPrinter.com Manuals
This manual is provided for information purposes only. All information included herein is subject to change without notice. Samsung Electronics is not
responsible for any direct or indirect damages, arising from or related to the use of this manual.
© 2006 Samsung Electronics Co., Ltd. All rights reserved.
• ML-2510, ML-2570, and ML-2571N are model names of Samsung Electronics Co., Ltd.
• Samsung and Samsung logo are trademarks of Samsung Electronics Co., Ltd.
• Centronics is a trademark of Centronics Data Computer Corporation.
• IBM and IBM PC are trademarks of International Business Machines Corporation.
• PCL and PCL 6 are trademarks of Hewlett-Packard company.
• Microsoft, Windows, Windows 98, Windows Me, Windows 2000, Windows NT 4.0, Windows XP(32/64 bit) and Windows 2003 are registered trademarks
of Microsoft Corporation.
• PostScript 3 is a trademark of Adobe System, Inc.
• UFST® and MicroType™ are registered trademarks of Monotype Imaging Inc.
• TrueType, LaserWriter, and Macintosh are trademarks of Apple Computer, Inc.
• All other brand or product names are trademarks of their respective companies or organizations.
Downloaded From ManualsPrinter.com Manuals
contact SAMSUNG worldwide
If you have any comments or questions regarding Samsung products, contact the Samsung customer care center.
COUNTRY
CUSTOMER CARE CENTER
WEB SITE
COUNTRY
CUSTOMER CARE CENTER
WEB SITE
INDIA
3030 8282
1800 110011
1-800-3000-8282
www.samsung.com/in
INDONESIA
0800-112-8888
www.samsung.com/id
ITALIA
800-SAMSUNG(726-7864)
www.samsung.com/it
JAMAICA
1-800-234-7267
www.samsung.com/
latin
JAPAN
0120-327-527
www.samsung.com/jp
LATVIA
8000-7267
www.samsung.com/lv
LITHUANIA
8-800-77777
www.samsung.com/lt
LUXEMBURG
02 261 03 710
www.samsung.com/lu
MALAYSIA
1800-88-9999
www.samsung.com/my
MEXICO
01-800-SAMSUNG (7267864)
www.samsung.com/mx
www.samsung.com/
latin
NETHERLAND
S
0900 SAMSUNG(726-7864
€ 0,10/min)
www.samsung.com/nl
www.samsung.com/cz
NEW
ZEALAND
0800 SAMSUNG (0800 726
786)
www.samsung.com/nz
Samsung Zrt., česká organizační složka, Oasis
Florenc, Sokolovská394/17, 180 00, Praha 8
NICARAGUA
00-1800-5077267
www.samsung.com/
latin
DENMARK
70 70 19 70
www.samsung.com/dk
NORWAY
815-56 480
www.samsung.com/no
ECUADOR
1-800-10-7267
www.samsung.com/
latin
PANAMA
800-7267
www.samsung.com/
latin
EL
SALVADOR
800-6225
www.samsung.com/
latin
PHILIPPINES
1800-10-SAMSUNG (7267864)
www.samsung.com/ph
ESTONIA
800-7267
www.samsung.ee
POLAND
www.samsung.com/pl
KAZAKHSTAN
8-10-800-500-55-500
www.samsung.com/
kz_ru
0 801 801 881
022-607-93-33
PORTUGAL
80820-SAMSUNG (7267864)
www.samsung.com/pt
PUERTO RICO
1-800-682-3180
www.samsung.com/
latin
REP.
DOMINICA
1-800-751-2676
www.samsung.com/
latin
EIRE
0818 717 100
www.samsung.com/ie
RUSSIA
8-800-555-55-55
www.samsung.ru
SINGAPORE
1800-SAMSUNG (7267864)
www.samsung.com/sg
SLOVAKIA
0800-SAMSUNG (7267864)
www.samsung.com/sk
SOUTH
AFRICA
0860 SAMSUNG (7247864)
www.samsung.com/za
ARGENTINE
0800-333-3733
www.samsung.com/ar
AUSTRALIA
1300 362 603
www.samsung.com/au
AUSTRIA
0800-SAMSUNG (7267864)
www.samsung.com/at
BELGIUM
02 201 2418
www.samsung.com/be
BRAZIL
0800-124-421
4004-0000
www.samsung.com/br
CANADA
1-800-SAMSUNG (7267864)
www.samsung.com/ca
CHILE
800-SAMSUNG (726-7864)
www.samsung.com/cl
CHINA
800-810-5858
400-810-5858
010-6475 1880
www.samsung.com/cn
COLOMBIA
01-8000112112
www.samsung.com.co
COSTA RICA
0-800-507-7267
CZECH
REPUBLIC
800-726-786 (800 SAMSUNG)
KYRGYZSTAN
00-800-500-55-500
FINLAND
030-6227 515
www.samsung.com/fi
FRANCE
3260 SAMSUNG
08 25 08 65 65 (€ 0,15/min)
www.samsung.com/fr
GERMANY
01805 - SAMSUNG (7267864 € 0,14/min)
www.samsung.de
GUATEMALA
1-800-299-0013
www.samsung.com/
latin
HONDURAS
800-7919267
www.samsung.com/
latin
HONG KONG
3698 4698
www.samsung.com/hk
HUNGARY
06-80-SAMSUNG (7267864)
www.samsung.com/hu
Downloaded From ManualsPrinter.com Manuals
COUNTRY
CUSTOMER CARE CENTER
WEB SITE
SPAIN
902-1-SAMSU(72678)
www.samsung.com/es
SWEDEN
0771-400 200
www.samsung.com/se
SWITZERLAN
D
0800-SAMSUNG (7267864)
www.samsung.com/ch
TADJIKISTAN
8-10-800-500-55-500
TAIWAN
0800-329-999
www.samsung.com/tw
THAILAND
1800-29-3232
02-689-3232
www.samsung.com/th
TRINIDAD &
TOBAGO
1-800-SAMSUNG (7267864)
www.samsung.com/
latin
TURKEY
444 77 11
www.samsung.com/tr
U.A.E
800-SAMSUNG (726-7864)
8000-4726
www.samsung.com/ae
U.K
0845 SAMSUNG (7267864)
www.samsung.com/uk
U.S.A
1-800-SAMSUNG (7267864)
www.samsung.com/us
UKRAINE
8-800-502-0000
www.samsung.ua
UZBEKISTAN
8-10-800-500-55-500
www.samsung.com/
kz_ru
VENEZUELA
0-800-100-5303
www.samsung.com/
latin
VIETNAM
1 800 588 889
www.samsung.com/vn
Downloaded From ManualsPrinter.com Manuals
CONTENTS
1. Introduction
Special features ......................................................................................................................................................
Printer overview ......................................................................................................................................................
Control panel overview ............................................................................................................................................
Finding more information ........................................................................................................................................
Selecting a location .................................................................................................................................................
1.1
1.2
1.3
1.3
1.4
2. Basic setup
Printing a demo page .............................................................................................................................................. 2.1
Using toner save mode ........................................................................................................................................... 2.1
3. Software overview
Supplied software .................................................................................................................................................... 3.1
Printer driver features .............................................................................................................................................. 3.2
System requirements .............................................................................................................................................. 3.2
4. Network setup
Introduction ............................................................................................................................................................. 4.1
Supported operating systems ................................................................................................................................. 4.1
Installing an external wired network interface server .............................................................................................. 4.2
5. Loading print media
Selecting print media ............................................................................................................................................... 5.1
Loading paper ......................................................................................................................................................... 5.4
Knowing an output location ..................................................................................................................................... 5.6
6. Basic printing
Printing a document ................................................................................................................................................ 6.1
Canceling a print job ............................................................................................................................................... 6.1
7. Ordering supplies and accessories
Toner cartridge ........................................................................................................................................................ 7.1
Accessory ................................................................................................................................................................ 7.1
How to purchase ..................................................................................................................................................... 7.1
8. Maintenance
Cleaning the printer .................................................................................................................................................
Maintaining the toner cartridge ................................................................................................................................
Printing a configuration page ..................................................................................................................................
Maintenance parts ...................................................................................................................................................
Downloaded From ManualsPrinter.com Manuals
8.1
8.3
8.5
8.5
9. Troubleshooting
Clearing paper jams ................................................................................................................................................ 9.1
Troubleshooting checklist ........................................................................................................................................ 9.4
Understanding the LEDs ......................................................................................................................................... 9.4
Solving general printing problems ........................................................................................................................... 9.5
Solving print quality problems ................................................................................................................................. 9.7
Common Windows problems .................................................................................................................................. 9.9
Common PostScript problems ................................................................................................................................ 9.9
Common Linux problems ...................................................................................................................................... 9.10
Common Macintosh problems .............................................................................................................................. 9.10
10. Specifications
Printer specifications ............................................................................................................................................. 10.1
Downloaded From ManualsPrinter.com Manuals
Important Precautions and Safety Information
17 The Power cord supplied with your machine should be used for safe operation. If
you are using a cord which is longer than 2 m with 110 V machine, then it should
be 16 AWG* or bigger.
When using this machine, these basic safety precautions should always be followed to
reduce risk of fire, electric shock, and injury to people:
18 SAVE THESE INSTRUCTIONS.
1
Read and understand all instructions.
2
Use common sense whenever operating electrical appliances.
3
Follow all warnings and instructions marked on the machine and in the literature
accompanying the machine.
4
If an operating instruction appears to conflict with safety information, heed the
safety information. You may have misunderstood the operating instruction. If you
cannot resolve the conflict, contact your sales or service representative for
assistance.
5
Unplug the machine from the AC wall socket before cleaning. Do not use liquid or
aerosol cleaners. Use only a damp cloth for cleaning.
Class I laser products are not considered to be hazardous. The laser system and printer
are designed so there is never any human access to laser radiation above a Class I level
during normal operation, user maintenance, or prescribed service condition.
6
Do not place the machine on an unstable cart, stand or table. It may fall, causing
serious damage.
WARNING
7
Your machine should never be placed on, near or over a radiator, heater, air
conditioner or ventilation duct.
8
Do not allow anything to rest on the power cable. Do not locate your machine
where the cords will be abused by persons walking on them.
9
Do not overload wall outlets and extension cords. This can diminish performance,
and may result in the risk of fire or electric shock.
Environmental and Safety Consideration
Laser Safety Statement
The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR,
chapter 1 Subchapter J for Class I(1) laser products, and elsewhere, is certified as a
Class I laser product conforming to the requirements of IEC 825.
Never operate or service the printer with the protective cover removed from Laser/
Scanner assembly. The reflected beam, although invisible, can damage your eyes.
When using this product, these basic safety precautions should always be followed to
reduce risk of fire, electric shock, and injury to persons:
10 Do not allow pets to chew on the AC power or PC interface cords.
11 Never push objects of any kind into the machine through case or cabinet
openings. They may touch dangerous voltage points, creating a risk of fire or
shock. Never spill liquid of any kind onto or into the machine.
12 To reduce the risk of electric shock, do not disassemble the machine. Take it to a
qualified service technician when repair work is required. Opening or removing
covers may expose you to dangerous voltages or other risks. Incorrect reassembly
could cause electric shock when the unit is subsequently used.
13 Unplug the machine from the PC and AC wall outlet, and refer servicing to
qualified service personnel under the following conditions:
• When any part of the power cord, plug, or connecting cable is damaged or
frayed.
• If liquid has been spilled into the machine.
• If the machine has been exposed to rain or water.
• If the machine does not operate properly after instructions have been followed.
• If the machine has been dropped, or the cabinet appears damaged.
• If the machine exhibits a sudden and distinct change in performance.
Ozone Safety
14 Adjust only those controls covered by the operating instructions. Improper
adjustment of other controls may result in damage, and may require extensive
work by a qualified service technician to restore the machine to normal operation.
During normal operation, this machine produces ozone. The ozone
produced does not present a hazard to the operator. However, it is
advisable that the machine be operated in a well ventilated area.
15 Avoid using this machine during a lightning storm. There may be a remote risk of
electric shock from lightning. If possible, unplug the AC power for the duration of
the lightning storm.
If you need additional information about ozone, please contact your
nearest Samsung dealer.
16 If you continuously print multiple pages, the surface of the output tray may become
hot. Be careful not to touch the surface, and keep children away from the surface.
* AWG: American Wire Gauge
i
Downloaded From ManualsPrinter.com Manuals
Power Saver
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This printer contains advanced energy conservation technology that reduces power
consumption when it is not in active use.
When the printer does not receive data for an extended period of time, power
consumption is automatically lowered.
CAUTION: Changes or modifications not expressly approved by the manufacturer
Recycling
Canadian Radio Interference Regulations
responsible for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus as set out in the interference-causing equipment standard entitled
“Digital Apparatus”, ICES-003 of the Industry and Science Canada.
Please recycle or dispose of packaging materials for this product in
an environmentally responsible manner.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux
appareils numériques de Classe B prescrites dans la norme sur le matériel brouilleur:
“Appareils Numériques”, ICES-003 édictée par l’Industrie et Sciences Canada.
Correct Disposal of This Product (Waste Electrical &
Electronic Equipment)
Declaration of Conformity (European Countries)
Approvals and Certifications
(Applicable in the European Union and other European countries with
separate collection systems)
The CE marking applied to this product symbolises Samsung
Electronics Co., Ltd. Declaration of Conformity with the following
applicable 93/68/EEC Directives of the European Union as of the
dates indicated:
This marking shown on the product or its literature, indicates that it
should not be disposed with other household wastes at the end of its
working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
January 1, 1995: Council Directive 73/23/EEC Approximation of the
laws of the member states related to low voltage equipment.
January 1, 1996: Council Directive 89/336/EEC (92/31/EEC), approximation of the laws
of the Member States related to electromagnetic compatibility.
Household users should contact either the retailer where they purchased this product,
or their local government office, for details of where and how they can take this item for
environmentally safe recycling.
March 9, 1999: Council Directive 1999/5/EC on radio equipment and
telecommunications terminal equipment and the mutual recognition of their conformity.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other commercial wastes for
disposal.
A full declaration, defining the relevant Directives and referenced standards can be
obtained from your Samsung Electronics Co., Ltd. representative.
Replacing the Fitted Plug (for UK Only)
Radio Frequency Emissions
Important
FCC Regulations
The mains lead for this machine is fitted with a standard (BS 1363) 13 amp plug and has
a 13 amp fuse. When you change or examine the fuse, you must re-fit the correct 13
amp fuse. You then need to replace the fuse cover. If you have lost the fuse cover, do
not use the plug until you have another fuse cover.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
• This device may not cause harmful interference, and
Please contact the people from you purchased the machine.
• This device must accept any interference received, including interference that
may cause undesired operation.
The 13 amp plug is the most widely used type in the UK and should be suitable.
However, some buildings (mainly old ones) do not have normal 13 amp plug sockets.
You need to buy a suitable plug adaptor. Do not remove the moulded plug.
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
Warning
If you cut off the moulded plug, get rid of it straight away.
You cannot rewire the plug and you may receive an electric shock if you plug it
into a socket.
IMPORTANT
The wires in the mains lead have the following color code:
• Green and Yellow:
ii
Downloaded From ManualsPrinter.com Manuals
WARNING: You must earth this machine.
Earth
• Blue:
Neutral
• Brown:
Live
If the wires in the mains lead do not match the colors marked in your plug, do the
following:
You must connect the green and yellow wire to the pin marked by the letter “E” or by the
safety ‘Earth symbol’ or colored green and yellow or green.
G
G
Declaration of Conformity
You must connect the blue wire to the pin which is marked with the letter “N” or colored
black.
For the following product:
Mono Laser Printer model " ML-2571N, ML-2570, ML-2510 ”
You must connect the brown wire to the pin which is marked with the letter “L” or colored
red.
Manufactured at:
of Samsung Electronics Co., Ltd.
#259, Gongdan-Dong, Gumi-City, Gyeongsangbuk-Do, 730-030 Korea
of Samsung Electronics (Shandong) Digital Printing Co., Ltd.
264209, Samsung Road, Weihai Hi-Tech. IDZ, Shandong Province, P.R.China
of Weihai Shin Heung Digital Electronics Co., Ltd.
98, Samsung Road, Weihai Hi-Tech. IDZ, Shandong Province, P.R.China.
of Weihat Intops Electronics Co. Ltd.
Keji Road-268-1, Weihai Hi-tech, IDZ, Shandong Province, P.R.China
You must have a 13 amp fuse in the plug, adaptor, or at the distribution board.
(Factory name, address)
We hereby declare, that the product above is in compliance with the essential requirements of the
Low Voltage Directive (2006/95/EC) and EMC Directive (2004/108/EC) by application of:
EN 60950-1:2001+A11:2004
EN 55022:1998 + A1:2000 + A2:2003
EN 55024:1998 + A1:2001 + A2:2003
EN 61000-3-2:2000 + A2 : 2005
EN 61000-3-3:1995 + A1:2001
The Technical documentation is kept at the below Manufacturer’s address.
Manufacturer
G
Samsung Electronics Co., Ltd.
#259, Gongdan-Dong, Gumi-City
Gyungbuk, Korea 730-030
G
G
G
January 08, 2008G
Whan-Soon Yim / S. Manager
Representative in the EU:
G
Samsung Electronics Euro QA Lab.
Blackbushe Business Park
Saxony Way, Yateley, Hampshire
GU46 6GG, UK
January 08, 2008
(Place and date of issue)
iii
Downloaded From ManualsPrinter.com Manuals
G
Yong Sang Park / S. Manager
1 Introduction
Special features
Your new printer is equipped with several special features that improve
the print quality. You can:
Congratulations on the purchase of your printer!
This chapter includes:
•
Special features
•
Printer overview
•
Control panel overview
•
Finding more information
•
Selecting a location
Print with excellent quality and high speed
• You can print up to 1200 x 1200 dpi effective
output (ML-2570, ML-2571N) or 1200 x 600 dpi
effective output (ML-2510). See the Software
Section.
• Your printer prints A4-sized paper at up to 24 ppma
and letter-sized paper at up to 25 ppm.
Handle paper flexibly
• Manual tray supports one sheet of envelopes,
labels, transparencies, custom-sized materials,
postcards and heavy paper.
• Standard 250-sheet tray supports plain paper.
• 100-sheet output tray supports convenient access.
Create professional documents
• Print Watermarks. You can customize your
documents with words, such as “Confidential.” See
the Software Section.
• Print Posters. The text and pictures of each page
of your document are magnified and printed across
the sheet of paper and can then be taped together
to form a poster. See the Software Section.
Save time and money
1
2
• Your printer allows you to use toner save mode to
save toner. See the Software Section.
• You can print on both sides of the paper manually
to save paper [Double-side Printing (Manual)].
3
4
• You can print multiple pages on a single sheet of
paper to save paper (N-Up printing). See the
Software Section.
• You can use preprinted forms and letterhead with
plain paper. See the Software Section.
• Your printer automatically conserves electricity
by substantially reducing power consumption when
not in use.
Expand the printer capacity
• A Network interface enables network printing. You
can buy and add an external wired network
interface server to the ML-2510 and ML-2570. The
ML-2571N comes with a built-in network interface,
10/100 Base TX.
a. pages per minute
1.1
Downloaded From ManualsPrinter.com Manuals
<Introduction>
Print in various environments
Printer overview
• A PostScript 3 Emulation* (PS) enables PS printing in the ML-2570
and ML-2571N.
Front view
* Zoran IPS Emulation compatible with PostScript 3
• © Copyright 1995-2005, Zoran Corporation.
All rights reserved. Zoran, the Zoran logo,
IPS/PS3 and OneImage are trademarks of
Zoran Corporation.
* 136 PS3 fonts
• Contains UFST and MicroType from Monotype Imaging Inc.
• You can print in Windows 98/Me/NT 4.0/2000/XP(32/64 bit)/2003.
• Your printer is compatible with Linux and Macintosh.
• Your printer comes with both Parallel and USB interfaces.
• You can also use a Network interface. The ML-2571N comes with
a built-in network interface, 10/100 Base TX. However, you need to
buy and install the external wired network interface server to the
ML-2510 and ML-2570.
Printer features
The table below lists a general overview of features supported by your
printer.
(I: Installed, O: Option, NA: Not Available)
Features
IEEE 1284 Parallel
USB 2.0
Network Interface
(Ethernet 10/100
Base TX)
ML-2510
ML-2570
ML-2571N
I
I
I
I
(USB 1.1:
Compatible with
USB 2.0)
O
(External)
I
I
(USB 2.0: Hi(USB 2.0: HiSpeed USB 2.0) Speed USB 2.0)
O
(External)
I
* The figure above shows an ML-2571N.
1
output tray
6
manual tray
PCL Emulation
NA
I
I
2
top cover
7
standard tray
PostScript
Emulation
NA
I
I
3
control panel
8
paper length guide
4
front cover
9
paper width guide
5
output tray extension
1.2
Downloaded From ManualsPrinter.com Manuals
<Introduction>
Rear view
Finding more information
You can find information for setting up and using your printer from the
following resources, either printed or onscreen.
Quick Install
Guide
Provides information on setting up your
printer, therefore, be sure to follow the
instructions in the guide to get the printer
ready.
Online User’s
Guide
Provides you with step-by-step instructions for
using your printer’s full features, and contains
information for maintaining your printer,
troubleshooting, and installing accessories.
This user’s guide also contains a Software
Section providing you with information on how
to print documents with your printer on various
operating systems, and how to use the
supplied software utilities.
* The figure above shows an ML-2571N.
1
parallel port
4
power receptacle
2
USB port
5
power switch
3
network port
Note
• You can access the user’s guides in
other languages from the Manual
folder on the printer driver CD.
Network Printer
User’s Guide
Contained on the network utilities CD,
provides you with information on setting up
and connecting your printer to a network.
Printer Driver
Help
Provides you with help information on printer
driver properties and instructions for setting up
the properties for printing. To access a printer
driver help screen, click Help from the printer
properties dialog box.
Samsung
Website
If you have Internet access, you can get help,
support, printer drivers, manuals, and order
information from the Samsung website,
www.samsungprinter.com.
Control panel overview
1
Error: Indicates the status of your printer. See page 9.4.
2
Online: Indicates the status of your printer. See page 9.4.
3
Cancel: Prints a demo page or configuration page.
Cancels the print job.
Makes the printer pick up the print media.
1.3
Downloaded From ManualsPrinter.com Manuals
<Introduction>
Selecting a location
Select a level, stable place with adequate space for air circulation. Allow
extra space for opening covers and trays.
The area should be well-ventilated and away from direct sunlight or
sources of heat, cold, and humidity. Do not set the printer close to the
edge of your desk or table.
Clearance space
Front: 482.6 mm
(enough space so that
tray can be opened)
Back: 100 mm (enough
space for ventilation)
Right: 100 mm (enough
space for ventilation)
Left: 100 mm (enough
space for ventilation)
1.4
Downloaded From ManualsPrinter.com Manuals
<Introduction>
2 Basic setup
Printing a demo page
After setting up your printer, print a demo page to make sure that the
printer is operating correctly.
This chapter includes:
•
Printing a demo page
•
Using toner save mode
Press and hold the Cancel button for about 2 seconds.
A demo page prints out.
Using toner save mode
Toner save mode allows the printer to use less toner on each page.
Activating this mode extends the life of your toner cartridge and reduces
your cost per page beyond what one would experience in the normal
mode, but it reduces print quality. This setting is not available with the
1200dpi (Best) setting.
You can set the toner save mode from the printer properties window on
your printer driver. See the Software Section.
2.1
Downloaded From ManualsPrinter.com Manuals
<Basic setup>
3 Software overview
Supplied software
You must install the printer software using the supplied CDs after you
have set up your printer and connected it to your computer.
This chapter gives you an overview of the software that comes with your
printer. Further details about installing and using the software are
explained in the Software Section.
Each CD provides you with the following software:
This chapter includes:
•
Supplied software
•
Printer driver features
•
System requirements
CD
printer
software
CD
network
utilities
CD
(ML-2571N
only)
3.1
Downloaded From ManualsPrinter.com Manuals
<Software overview>
Contents
Windows
• Printer driver: Use this driver to take
full advantage of your printer’s
features.
• Smart Panel: This program allows
you to monitor the printer’s status and
alerts you when an error occurs during
printing.
• Printer Settings Utility: This program
is automatically installed when you
install the Smart Panel. (ML-2570, ML2571N only)
• PCL6 driver: Use this driver to print
documents in the PCL6, PCL5e
language. (ML-2570, ML-2571N only)
• Postscript Printer Description
(PPD) file: Use the PostScript driver to
print documents with complex fonts
and graphics in the PostScript
language. (ML-2570, ML-2571N only)
• User’s Guide in PDF
Linux
• Printer driver: Use this driver to run
your printer from a Linux computer
and print documents.
• Smart Panel: This program allows
you to monitor the printer’s status and
alerts you when an error occurs during
printing.
Macintosh
• Postscript Printer Description
(PPD) file: Use this file to run your
printer from a Macintosh computer
and print documents. (ML-2570, ML2571N only)
• Smart Panel: This program allows
you to monitor the printer’s status and
alerts you when an error occurs during
printing.
Windows
• SyncThru™ Web Admin Service:
Use this web-based program to
remotely manage, monitor, and
troubleshoot network printers.
• Set IP: Use this program to set your
printer’s TCP/IP addresses.
• Network Printer User’s Guide in
PDF
Printer driver features
System requirements
Your printer drivers support the following standard features:
• Paper source selection
Before you begin, ensure that your system meets the following
requirements:
• Paper size, orientation and type
Windows
• Number of copies
Item
In addition, you can use various special printing features. The following
table shows a general overview of features supported by your printer
drivers:
Windows
Linux
SPLa
PCL 6
PostScript
SPL
CUPS
PostScript
Toner save
O
O
O
O
X
X
Print quality
option
O
O
O
O
O
O
Poster
printing
O
O
X
X
X
X
Multiple
pages per
sheet
(N-up)
O
O
O
O
(2, 4)
O
O
Fit to page
printing
O
Scale
printing
O
O
O
X
O
O
Watermark
O
O
X
X
X
X
Overlay
O
O
X
X
X
X
Feature
O
O
Macintosh
X
X
Windows 98/Me/NT 4.0/2000/XP(32/64 bit)/2003
CPU
Windows 98/
Me/NT 4.0/2000
Pentium II
400 MHz or
higher
Pentium III
933 MHz
Windows
XP(32/64 bit)/
2003
Pentium III
933 MHz or
higher
Pentium IV
1 GHz
Windows 98/
Me/NT 4.0/2000
64 MB or more
128 MB
Windows
XP(32/64 bit)/
2003
128 MB or more
256 MB
Windows 98/
Me/NT 4.0/2000
300 MB or more
1 GB
Windows
XP(32/64 bit)/
2003
1 GB or more
5 GB
Free disk
space
Internet
Explorer
5.0 or higher
Note
a Samsung Printer Language
• For Windows NT 4.0/2000/XP(32/64 bit)/2003, users who
have an administrator right can install the software.
Note
• Overlay is not supported in Windows NT 4.0.
3.2
Downloaded From ManualsPrinter.com Manuals
Recommended
Operating
system
RAM
O
Requirements
<Software overview>
Linux
Item
Requirements
Operating system
Various Linux OS including
• Red Hat 8 ~ 9
• Fedora Core 1 ~ 3
• Mandrake 9.2 ~ 10.1
• SuSE 8.2 ~ 9.2
Processor
Pentium IV 1 GHz or higher
RAM
256 MB or higher
Free disk page
1 GB or higher
Software
•
•
•
•
Linux Kernel 2.4 or higher
Glibc 2.2 or higher
CUPS
SANE
Macintosh
Item
Requirements
Operating system
Macintosh 10.3 (ML-2510), 8.6 ~ 9.2 and
10.1 ~ 10.4 (ML-2570, ML-2571N)
RAM
128 MB
Free disk space
200 MB
Connection
USB interface, Network interface
3.3
Downloaded From ManualsPrinter.com Manuals
<Software overview>
4 Network setup
Introduction
Once you have connected your printer to a network with an RJ-45
Ethernet cable, you can share the printer with other network users.
This chapter gives you basic information for setting up your printer for
network connections.
You need to set up the network protocols on the printer to use it as your
network printer. Protocols can be set up by the following programs that
came with your printer:
This chapter includes:
•
Introduction
•
Supported operating systems
•
Installing an external wired network interface server
• SyncThru™ Web Admin Service: A web-based printer
management solution for network administrators. SyncThru™ Web
Admin Service provides you with an efficient way of managing
network devices and lets you remotely monitor and troubleshoot
network printers from any site with corporate intranet access.
• SyncThru™ Web Service: A web server embedded to your network
print server, which allows you to configure the network parameters
necessary for the printer to connect to various network environments.
• SetIP: A utility program allowing you to select a network interface and
manually configure the addresses for use with the TCP/IP protocol.
For further details, refer to the user’s guide on the network utilities CD
that came with your printer.
Supported operating systems
The following table shows the network environments supported by the
printer:
Item
Requirements
Network interface
• 10/100 Base-TX
Network operating
system
• Windows 98/Me/NT 4.0/2000/XP(32/64 bit)/
2003
• Linux OS including Red Hat 8 ~ 9,
Fedora Core 1 ~ 3, Mandrake 9.2 ~ 10.1,
SuSE 8.2 ~ 9.2
• Mac OS 8.6 ~ 9.2, 10.1 ~ 10.4
• Unix HP-UX, Solaris, SunOS, SCO UNIX
Network protocols
•
•
•
•
Dynamic
addressing server
• DHCP, BOOTP
TCP/IP
EtherTalk
HTTP 1.1
SNMPv2
• TCP/IP: Transmission Control Protocol/Internet Protocol
• DHCP: Dynamic Host Configuration Protocol
• BOOTP: Bootstrap Protocol
4.1
Downloaded From ManualsPrinter.com Manuals
<Network setup>
Installing an external wired network interface
server
The ML-2571N is equipped with wired network interface, allowing you to
use your printer on a network.
To use the ML-2510 and ML-2570 in network environments, you need to
buy an optional external wired network interface server. For order
information, see page 7.1.
4.2
Downloaded From ManualsPrinter.com Manuals
<Network setup>
5 Loading print media
Selecting print media
This chapter includes:
You can print on a variety of print media, such as plain paper, envelopes,
labels, and transparencies. Always use print media that meet the
guidelines for use with your printer. Print media that does not meet the
guidelines outlined in this user’s guide may cause the following
problems:
•
Selecting print media
• Poor print quality
•
Loading paper
• Increased paper jams
•
Knowing an output location
• Premature wear on the printer
This chapter will help you understand the types of paper you can use
with your printer and how to properly load paper in the different paper
trays for the best print quality.
Properties, such as weight, composition, grain, and moisture content,
are important factors that affect the printer’s performance and the output
quality. When you choose print media, consider the following:
• Desired outcome: The print media you choose should be appropriate
for your project.
• Size: You can use any size print media that fits easily within the paper
adjusters of the paper tray.
• Weight: Your printer supports print media weights as follows:
- 16 to 43 lb (60 to 163 g/m2) for the standard tray and manual tray
- 20 to 24 lb (75 to 90 g/m2) for the manual duplex printing
• Brightness: Some print media are whiter than others and produce
sharper, more vibrant images.
• Surface smoothness: The smoothness of the print media affects how
crisp the printing looks on the paper.
Notes
• Some print media may meet all of the guidelines in this section
and still not produce satisfactory results. This may be the
result of improper handling, unacceptable temperature and
humidity levels, or other variables over which Samsung has no
control.
• Before purchasing large quantities of print media, ensure that
it meets the requirements specified in this user’s guide.
Caution
• Using print media that does not meet these specifications may
cause problems, requiring repairs. Such repairs are not
covered by Samsung’s warranty or service agreements.
5.1
Downloaded From ManualsPrinter.com Manuals
<Loading print media>
Supported sizes of paper
Type
Plain paper
Size
Dimensions
Weight
• 16 to 24 lb (60 to 90 g/m2)
for the tray with multi-pages
feeding
• 16 to 43 lb (60 to 163 g/m2)
for the tray with single page
feeding and the manual
tray
• 250 sheets of 75 g/m2
(20 lb) paper for the
standard tray
• 1 sheet of paper for the
manual tray
20 to 24 lb (75 to 90 g/m2)
1 sheet of paper for the
manual tray
Letter
216 x 279 mm (8.5 x 11 inches)
Legal
216 x 356 mm (8.5 x 14 inches)
Folio
216 x 330.2 mm (8.5 x 13 inches)
Oficio
216 x 343 mm (8.5 x 13.5 inches)
A4
210 x 297 mm (8.27 x 11.69 inches)
JIS B5
182 x 257 mm (7.18 x 10.12 inches)
ISO B5
176 x 250 mm (6.93 x 9.84 inches)
Executive
184.2 x 266.7 mm (7.25 x 10.5 inches)
A5
148.5 x 210 mm (5.85 x 8.27 inches)
A6
105 x 148.5 mm (4.13 x 5.85 inches)
Envelope Monarch
98.4 x 190.5 mm (3.88 x 7.5 inches)
Envelope No.10
105 x 241 mm (4.12 x 9.5 inches)
Envelope DL
110 x 220 mm (4.33 x 8.66 inches)
Envelope C5
162 x 229 mm (6.38 x 9.02 inches)
Envelope C6
114 x 162 mm (4.49 x 6.38 inches)
Transparency
Letter, A4
Refer to the Plain paper section
37 to 39 lb (138 to 146 g/m2)
Labels
Letter, A4
Refer to the Plain paper section
32 to 40 lb (120 to 150 g/m2)
Card stock
Letter, A4
Refer to the Plain paper section
24 to 43 lb (90 to 163 g/m2)
Minimum size (custom)
76 x 127 mm (3 x 5 inches)
16 to 43 lb (60 to 163 g/m2)
Maximum size (custom)
216 x 356 mm (8.5 x 14 inches)
Envelope
a. Maximum capacity may differ depending on print media weight, thickness and environmental conditions.
Print media for manual duplex printing
Type
Plain paper
Size
Weight
20 to 24 lb (75 to 90 g/m2)
A4, Letter, Oficio, Legal, and Folio
5.2
Downloaded From ManualsPrinter.com Manuals
Capacitya
<Loading print media>
Refer to the above Capacity
sections
Guidelines for selecting and storing print media
Guidelines for special print media
When selecting or loading paper, envelopes, or other print media, keep
these guidelines in mind:
Type
• Always use print media that conform with the specifications listed on
the next column.
Envelopes
• Attempting to print on damp, curled, wrinkled, or torn paper can cause
paper jams and poor print quality.
• For the best print quality, use only high quality copier grade paper
specifically recommended for use in laser printers.
• Avoid using the following print media types:
- Paper with embossed lettering, perforations, or a texture that is too
smooth or too rough
- Erasable bond paper
- Multi-paged paper
- Synthetic paper and thermally reactive paper
- Carbonless paper and Tracing paper.
• Use of these types of paper could result in paper jams, chemical
smells, and damage to your printer.
• Store print media in its ream wrapper until you are ready to use it.
Place cartons on pallets or shelves, not on the floor. Do not place
heavy objects on top of the paper, whether it is packaged or
unpackaged. Keep it away from moisture or other conditions that can
cause it to wrinkle or curl.
• Store unused print media at temperatures between 15o C and 30o C
(59o F to 86o F). The relative humidity should be between 10% and
70%.
• Store unused print media in a moisture-proof wrap, such as a plastic
container or bag, to prevent dust and moisture from contaminating
your paper.
• Load special print media types one sheet at a time through the
manual tray to avoid paper jams.
Guidelines
• Successful printing on envelopes depends
upon the quality of the envelopes. When
selecting envelopes, consider the following
factors:
- Weight: The weight of the envelope paper
should not exceed 90 g/m2 (24 lb) or jamming
may occur.
- Construction: Prior to printing, envelopes
should lie flat with less than 6 mm
(0.25 inches) curl, and should not contain air.
- Condition: Envelopes should not be wrinkled,
nicked, or otherwise damaged.
- Temperature: You should use envelopes that
are compatible with the heat and pressure of
the printer during operation.
• Use only well-constructed envelopes with sharp
and well creased folds.
• Do not use stamped envelopes.
• Do not use envelopes with clasps, snaps,
windows, coated lining, self-adhesive seals, or
other synthetic materials.
• Do not use damaged or poorly made
envelopes.
• Be sure the seam at both ends of the envelope
extends all the way to the corner of the
envelope.
Acceptable
• To prevent print media, such as transparencies and label sheets, from
sticking together, remove them as they print out.
Unacceptable
CAUTION: If you print 20 envelopes in succession, the surface
of the top cover may become hot. Please exercise caution.
• Envelopes with a peel-off adhesive strip or with
more than one flap that folds over to seal must
use adhesives compatible with the printer’s
fusing temperature of 180° C (356° F) for
0.1 second. The extra flaps and strips might
cause wrinkling, creasing, or jams, and may
even damage the fuser.
• For the best print quality, position margins no
closer than 15 mm (0.6 inches) from the edges
of the envelope.
• Avoid printing over the area where the
envelope’s seams meet.
5.3
Downloaded From ManualsPrinter.com Manuals
<Loading print media>
Type
Guidelines
Transparencies
• To avoid damaging the printer, use only
transparencies designed for use in laser
printers.
• Transparencies used in the printer must be able
to withstand 180° C (356° F), the printer’s
fusing temperature.
• Place them on a flat surface after removing
them from the printer.
• Do not leave them in the paper tray for long
periods of time. Dust and dirt may accumulate
on them, resulting in spotty printing.
• To avoid smudging caused by fingerprints,
handle them carefully.
• To avoid fading, do not expose printed
transparencies to prolonged sunlight.
• Ensure that transparencies are not wrinkled,
curled, or have any torn edges.
Labels
• To avoid damaging the printer, use only labels
designed for use in laser printers.
• When selecting labels, consider the following
factors:
- Adhesives: The adhesive material should be
stable at 180° C (356° F), the printer’s fusing
temperature.
- Arrangement: Only use labels with no
exposed backing between them. Labels can
peel off sheets that have spaces between the
labels, causing serious jams.
- Curl: Prior to printing, labels must lie flat with
no more than 13 mm (5 inches) of curl in any
direction.
- Condition: Do not use labels with wrinkles,
bubbles, or other indications of separation.
• Make sure that there is no exposed adhesive
material between labels. Exposed areas can
cause labels to peel off during printing, which
can cause paper jams. Exposed adhesive can
also cause damage to printer components.
• Do not run a sheet of labels through the printer
more than once. The adhesive backing is
designed for only a single pass through the
printer.
• Do not use labels that are separating from the
backing sheet or are wrinkled, bubbled, or
otherwise damaged.
Card stock or
custom-sized
materials
Type
Preprinted
paper
• Letterhead must be printed with heat-resistant
ink that will not melt, vaporize, or release
hazardous emissions when subjected to the
printer’s fusing temperature of 180° C (356° F)
for 0.1 second.
• Letterhead ink must be non-flammable and
should not adversely affect printer rollers.
• Forms and letterhead should be sealed in a
moisture-proof wrapping to prevent changes
during storage.
• Before you load preprinted paper, such as
forms and letterhead, verify that the ink on the
paper is dry. During the fusing process, wet ink
can come off preprinted paper, reducing print
quality.
Loading paper
Load the print media you use for the majority of your print jobs in the tray.
The tray can hold a maximum of 250 sheets of 75 g/m2 (20 lb) plain
paper.
Using the standard tray
To load paper, open the tray and load paper with the side to be printed
on facing up.
You can load letterhead paper with the design side face up. The top edge
of the sheet with the logo should be entered into the printer first.
Notes
• If you experience problems with paper feed, place one sheet at
a time in the manual tray.
• You can load previously printed paper. The printed side should
be facing down with an uncurled edge enter the printer first. If
you experience problems with paper feed, turn the paper
around. Note that the print quality is not guaranteed.
• Do not print on print media smaller than 76 mm
(3 inches) wide or 127 mm (5 inches) long.
• In the software application, set margins at least
6.4 mm (0.25 inches) away from the edges of
the material.
5.4
Downloaded From ManualsPrinter.com Manuals
Guidelines
<Loading print media>
Using the manual tray
2
Adjust the manual tray paper width guides to the width of the paper.
Do not force too much, or the paper will bend, which could result in
a paper jam or skew.
3
When you print a document, set the paper source and type in the
software application. See the Software Section.
The manual tray can hold special sizes and types of print media, such as
transparency, postcard, note card, and envelope. It is useful for single
page printing on special print media.
To load paper in the manual tray:
1
Load one sheet of paper with the side to be printed on facing up.
Tips on using the manual tray
• Load only one sheet of print media at a time in the manual tray.
Depending on the print media type you are using, keep the
following loading guidelines:
• To prevent paper jams, do not add paper when there is still paper in
the manual tray. This also applies to the standard tray.
• Envelopes: Flap side down and with the stamp area on the top left
side.
• Print media should be loaded face up with the top edge going into the
manual tray first and be placed in the center of the tray.
• Transparencies: Print side up and the top with the adhesive strip
entering the printer first.
• Always load only the print media specified in page 5.2 to avoid paper
jams and print quality problems.
• Labels: Print side up and the top short edge entering the printer
first.
Using manual feed mode
• Preprinted paper: Design side up and the top edge entering the
printer first.
You can manually load a sheet of print media in the manual tray if you
select Manual Feeder in the Source option from the Paper tab when
you change print settings to print a document. See the Software
Section. Manually loading paper can be helpful when you want to check
the print quality after each page is printed.
• Card stock: Print side up and the short edge entering the printer
first.
• Previously printed paper: Previously printed side down and an
uncurled edge entering the printer first.
Load paper sheet-by-sheet in the manual tray, send print data to print the
first page, and press the Cancel button on the control panel to print each
following page.
Note
• For transparency, hold it by the edges and avoid touching the
print side. Oils from your fingers can cause print quality
problems.
5.5
Downloaded From ManualsPrinter.com Manuals
<Loading print media>
1
Load the paper in the manual tray with the side to be printed on
facing up.
Knowing an output location
1
1
2
Adjust the manual tray paper width guides to the width of the paper.
Do not force too much, or the paper will bend, which could result in
a paper jam or skew.
output tray
The output tray collects paper face down, in the order in which the sheets
were printed.
Note
• If you continuously print many pages, the surface of the output
tray may become hot. Be careful not to touch the surface, and
especially keep children away from the surface.
• The output tray can hold up to 100 sheets of 75 g/m2 (20 lb)
plain paper. Remove the pages so that the tray is not
overloaded.
3
When you print a document, set the paper source to Manual
Feeder and select the appropriate paper size and type in the
software application. See the Software Section.
4
Print a document.
5
Press the Cancel button.
The printer picks up the print media and prints.
Note
• If you do not press the Cancel button, after a pause the printer
will automatically pick the print media.
6
Insert the next sheet into the manual tray and press the Cancel
button.
Repeat this step for every page to be printed.
5.6
Downloaded From ManualsPrinter.com Manuals
<Loading print media>
6 Basic printing
Printing a document
This chapter includes:
This printer allows you to print from various Windows, Macintosh, or
Linux applications. The exact steps for printing a document may vary
depending on the application you use.
•
Printing a document
For details about printing, see the Software Section.
•
Canceling a print job
This chapter explains common printing tasks.
Canceling a print job
If the print job is waiting in a print queue or print spooler, such as the
printer group in Windows, delete the job as follows:
1
Click the Windows Start button.
2
For Windows 98/Me/NT 4.0/2000, select Settings and then
Printers.
For Windows XP(32/64 bit)/2003, select Printers and Faxes.
3
Double-click the Samsung ML-2510 Series, Samsung ML-2570
Series, Samsung ML-2570 Series PCL 6 or Samsung ML-2570
Series PS icon.
4
From the Document menu, select Cancel Printing (Windows 98/
Me) or Cancel (Windows NT 4.0/2000/XP(32/64 bit)/2003).
Note
• You can access this window simply by double-clicking the
printer icon at the bottom right corner of the Windows desktop.
You can also cancel the current job by pressing the Cancel button on the
control panel of your printer.
6.1
Downloaded From ManualsPrinter.com Manuals
<Basic printing>
7 Ordering supplies and
Toner cartridge
accessories
When the toner runs out, you can order the following type of toner
cartridge for your printer:
This chapter provides information on the toner cartridge and accessory
that are available for your printer.
This chapter includes:
•
Toner cartridge
•
Accessory
•
How to purchase
Yielda
Type
High yield
Approx. 3,000 pages
Part number
ML-2010D3
a. ISO 19752 5% coverage
Accessory
You can purchase and install the following accessory to your ML-2510
and ML-2570 printer:
Accessory
Description
Ethernet 10/100
Base TX
external wired
network
interface server
Allows you to connect
your printer to a network
environment using the
external wired network
server.
Part number
ML-00ND
How to purchase
To order Samsung-authorized supplies or accessories, contact your
local Samsung dealer or the retailer where you purchased your printer,
or visit www.samsungprinter.com and select your country/region for
information on calling for technical support.
7.1
Downloaded From ManualsPrinter.com Manuals
<Ordering supplies and accessories>
8 Maintenance
Cleaning the printer
During the printing process, paper, toner, and dust particles can
accumulate inside the printer. This buildup can cause print quality
problems, such as toner specks or smearing.
This chapter provides information for maintaining your printer and the
toner cartridge.
This chapter includes:
•
Cleaning the printer
•
Maintaining the toner cartridge
•
Printing a configuration page
•
Maintenance parts
Caution
• Cleaning the cabinet of the printer with cleaning materials
containing large amounts of alcohol, solvents, or other strong
substances can discolor or crack the cabinet.
Cleaning the outside of the printer
Clean the cabinet of the printer with a soft, lint-free cloth. You can
dampen the cloth slightly with water, but be careful not to let any water
drip onto or into the printer.
Cleaning the inside of the printer
1
Turn the printer off and unplug the power cord. Wait for the printer
to cool down.
2
Open the front cover and pull the toner cartridge out. Set it on a
clean flat surface.
Caution
• To prevent damage to the toner cartridge, do not expose it to
light for more than a few minutes. Cover it with a piece of
paper, if necessary.
• Do not touch the green surface underside of the toner
cartridge. Use the handle on the cartridge to avoid touching
this area.
8.1
Downloaded From ManualsPrinter.com Manuals
<Maintenance>
3
Pull the manual tray out.
4
With a dry lint-free cloth, wipe away any dust and spilled toner from
the toner cartridge area and the toner cartridge cavity.
6
Reinsert the manual tray.
7
Hold the toner cartridge by the handle and slowly insert the
cartridge into the opening in the printer.
Tabs on the sides of the cartridge and corresponding grooves
within the printer will guide the cartridge into the correct position
until it locks into place completely.
Caution
• While cleaning the inside of the printer, be careful not to reach
too far into the printer. The fuser area may be hot.
5
Gently swab the long strip of glass (LSU) inside the top of the
cartridge and check for dirt or dust.
8
Close the front cover. Make sure that the cover is securely closed.
9
Plug in the power cord and turn the printer on.
Note
• The long strip of glass is hard to locate.
8.2
Downloaded From ManualsPrinter.com Manuals
<Maintenance>
Caution
Maintaining the toner cartridge
• Avoid reaching too far into the printer. The fuser area may be
hot.
• To prevent damage to the toner cartridge, do not expose it to
light for more than a few minutes. Cover it with a piece of
paper, if necessary.
• Do not touch the green surface underside of the toner
cartridge. Use the handle on the cartridge to avoid touching
this area.
Toner cartridge storage
To get the most from the toner cartridge, keep the following guidelines in
mind:
• Do not remove the toner cartridge from its package until ready for
use.
• Do not refill the toner cartridge. The printer warranty does not cover
damage caused by using a refilled cartridge.
3
• Store toner cartridge in the same environment as the printer.
Thoroughly shake the cartridge 5 or 6 times to distribute the toner
evenly inside the cartridge.
• To prevent damage to the toner cartridge, do not expose it to light for
more than a few minutes.
Expected cartridge life
The life of the toner cartridge depends on the amount of toner that print
jobs require. When printing text at ISO 19752 5% coverage, a new toner
cartridge lasts an average of 3,000 pages. (The original toner cartridge
supplied with the printer lasts an average of 1,000 pages.) The actual
number may also be different depending on the print density of the
pages you print on, and the number of pages may be affected by
operating environment, printing interval, print media type, and print
media size. If you print a lot of graphics, you may need to change the
cartridge more often.
Caution
• If toner gets on your clothing, wipe it off with a dry cloth and
wash clothing in cold water. Hot water sets toner into fabric.
4
Redistributing toner cartridge
Hold the toner cartridge by the handle and slowly insert the
cartridge into the opening in the printer.
Tabs on the sides of the cartridge and corresponding grooves
within the printer will guide the cartridge into the correct position
until it locks into place completely.
When the toner cartridge is near the end of its life span:
• White streaks and light printing occur.
• The Smart Panel program window appears on the computer.
• The Error LED blinks red.
If this happens, you can temporarily reestablish print quality by
redistributing the remaining toner in the cartridge. In some cases, white
streaks or light printing will still occur even after you have redistributed
the toner.
1
Open the front cover.
2
Pull the toner cartridge out.
5
Close the front cover. Make sure that the cover is securely closed.
Note
• At this stage, if you need to replace the toner cartridge, see
page 8.4.
8.3
Downloaded From ManualsPrinter.com Manuals
<Maintenance>
Replacing the toner cartridge
5
When the toner is completely empty or the toner cartridge reachde the
end of its life span:
Remove the paper protecting the toner cartridge by pulling the
packing tape.
• The Smart Panel program window appears on the computer.
• The Error LED blinks red.
At this stage, the toner cartridge needs to be replaced. For toner
cartridge ordering information, see page 7.1.
1
Open the front cover.
2
Pull the old toner cartridge out.
Note
• Refer to the helpful pictures on the cartridge wrapping paper.
Caution
3
• If toner gets on your clothing, wipe it off with a dry cloth and
wash clothing in cold water. Hot water sets toner into fabric.
• To prevent damage to the toner cartridge, do not expose it to
light for more than a few minutes. Cover it with a piece of
paper, if necessary.
• Do not touch the green surface underside of the toner
cartridge. Use the handle on the cartridge to avoid touching
this area.
Remove the new toner cartridge from its bag.
6
Hold the toner cartridge by the handle and slowly insert the
cartridge into the opening in the printer.
Tabs on the sides of the cartridge and corresponding grooves
within the printer will guide the cartridge into the correct position
until it locks into place completely.
Caution
• Do not use sharp objects, such as a knife or scissors, to open
the toner cartridge package. They might scratch the drum of
the cartridge.
4
Thoroughly shake the cartridge 5 or 6 times to distribute the toner
evenly inside the cartridge.
7
Close the front cover. Make sure that the cover is securely closed.
Thoroughly shake the cartridge to assure maximum copies per
cartridge.
8.4
Downloaded From ManualsPrinter.com Manuals
<Maintenance>
Printing a configuration page
You can print a configuration page to view current printer settings, or to
help troubleshoot printer problems.
Press and hold the Cancel button for about 5 seconds.
A configuration page prints out.
Maintenance parts
To avoid print quality and paper feed problems resulting from worn parts
and to maintain your printer in top working condition, the following items
will need to be replaced when the specified number of pages have been
printed or when the life span of each item has expired.
Items
Yield (Average)
Transfer roller
Approx. 50,000 pages
Fuser unit
Approx. 50,000 pages
Pick-up roller
Approx. 50,000 pages
Samsung highly recommends that an authorized service provider, dealer
or the retailer where you bought the printer replaces the items.
8.5
Downloaded From ManualsPrinter.com Manuals
<Maintenance>
9 Troubleshooting
Clearing paper jams
Note
This chapter provides helpful information for what to do if you encounter
an error while using your printer.
• When removing paper that is jammed in the printer, if possible
always pull the paper in the direction that it normally moves so
as not to damage internal components. Always pull firmly and
evenly; do not jerk the paper. If the paper tears, ensure that all
fragments of paper are removed; otherwise a jam will occur
again.
This chapter includes:
•
Clearing paper jams
•
Troubleshooting checklist
•
Understanding the LEDs
•
Solving general printing problems
•
Solving print quality problems
•
Common Windows problems
•
Common PostScript problems
•
Common Linux problems
In the standard tray
•
Common Macintosh problems
1
When a paper jam occurs, the Error LED lights red. Open and close the
front cover. The jammed paper automatically exits the printer.
In the paper feed area
Remove the jammed paper by gently pulling it straight out. Make
sure that all of the paper is properly aligned in the standard tray.
If the paper does not move when you pull, or if you do not see the
paper in this area, check the fuser area around the toner cartridge.
See page 9.2.
2
9.1
Downloaded From ManualsPrinter.com Manuals
Open and close the front cover to resume printing the document
from failed pages.
<Troubleshooting>
In the manual tray
Caution
1
• To prevent damage to the toner cartridge, do not expose it to
light for more than a few minutes. Cover it with a piece of
paper, if necessary.
• Do not touch the green surface underside of the toner
cartridge. Use the handle on the cartridge to avoid touching
this area.
Remove the jammed paper in the manual tray by gently pulling it
straight out.
2
If necessary, pull the manual tray out.
3
Remove the jammed paper by gently pulling it out.
If the paper does not move when you pull, or if you do not see the
paper in this area, check the fuser area around the toner cartridge.
See page 9.2.
2
Open and close the front cover to resume printing the document
from failed pages.
If you do not see the jammed paper or if there is any resistance
removing the paper, stop pulling and go to the paper exit area. See
page 9.3.
Around the toner cartridge
Note
• The fuser area is hot. Be careful when removing paper from
the printer.
1
Open the front cover and pull the toner cartridge out.
9.2
Downloaded From ManualsPrinter.com Manuals
4
If necessary, reinsert the manual tray.
5
Replace the toner cartridge and close the front cover. Printing
automatically resumes.
<Troubleshooting>
In the paper exit area
1
Open and close the front cover. The jammed paper is automatically
ejected from the printer.
2
Gently pull the jammed paper out of the output tray.
If you do not see the jammed paper or if there is any resistance
when you pull, stop pulling and go to the next step.
3
Open the top cover and inner cover.
4
Loosen the jammed paper if it is caught in the heat roller. Then
gently pull the jammed paper out.
5
Close the inner cover and top cover. Printing automatically
resumes.
Tips for avoiding paper jams
By selecting the correct print media types, most paper jams can be
avoided. When a paper jam occurs, follow the steps outlined on page
9.1.
• Follow the procedures on page 5.4. Ensure that the adjustable guides
are positioned correctly.
• Do not overload the tray.
• Do not remove paper from the tray while your printer is printing.
• Flex, fan, and straighten paper before loading.
• Do not use creased, damp, or highly curled paper.
• Do not mix paper types in the tray.
• Use only recommended print media. See page 5.1.
Caution
• Ensure that the recommended print side of print media is facing up in
the tray.
• When removing the jammed paper, be careful not to touch the
heat roller (located underneath the inner cover). It is hot and
could cause burns!
• The top and inner cover themselves may also be hot due to
the heat roller. Allows the printer to cool before opening the
covers.
9.3
Downloaded From ManualsPrinter.com Manuals
<Troubleshooting>
Troubleshooting checklist
Understanding the LEDs
If the printer is not working properly, consult the following checklist. If the
printer does not pass a step, follow the corresponding suggested
solutions.
Condition
Suggested solutions
Make sure that the
Online LED on the
control panel lights
green.
• If the Online LED is off, check the power
cord connection. Check the power switch.
Check the power source by plugging the
power cord into another outlet.
Print a demo page
to verify that the
printer is feeding
paper correctly. See
page 2.1.
• If a demo page does not print, check the
paper supply in the tray.
• If the paper jams in the printer, see page
9.1.
Check the demo
page to see if it
printed correctly.
If there is a print quality problem, see page
9.7.
Print a short
document from a
software application
to verify that the
computer and
printer are
connected and are
communicating
correctly.
• If the page does not print, check the cable
connection between the printer and the
computer.
• Check the print queue or print spooler to
see if the printer has been paused.
• Check the software application to ensure
that you are using the proper printer driver
and communication port. If the page is
interrupted during printing, see page 9.5.
If completing the
checklist does not
resolve the printer
problem, check the
following
troubleshooting
sections.
• “Understanding the LEDs” on page 9.4.
• “Solving general printing problems” on
page 9.5.
• “Common Windows problems” on page
9.9.
• “Common PostScript problems” on page
9.9.
• “Common Linux problems” on page 9.10.
• “Common Macintosh problems” on page
9.10.
LED
Error
Online
Status
Red
Green
On
• A paper jam has occurred. To
solve the problem, see page 9.1.
• The cover is open. Close the
cover.
• There is no paper in the tray.
Load paper in the tray.
• The printer has stopped printing
due to a major error.
• The toner cartridge is not
installed. Install the toner
cartridge.
• Your system has some
problems. If this problem occurs,
contact your service
representative.
Blinking
• A minor error is occurring and
the printer is waiting for the error
to be cleared. When the problem
is cleared, the printer resumes
printing.
• The toner cartridge is low. Order
a new toner cartridge. You can
temporarily improve print quality
by redistributing the toner. See
page 8.3.
• The toner is totally exhausted.
Remove the old toner cartridge
and install a new one. See page
8.4.
• The toner cartridge reached the
end of its life.
On
• The printer is in power save
mode.
• The printer is on-line and can
receive data from the computer.
Blinking
9.4
Downloaded From ManualsPrinter.com Manuals
Description
<Troubleshooting>
• Blinks slowly indicates that the
printer is receiving data from the
computer.
• Blinks quickly indicates that the
printer is printing data.
Solving general printing problems
Condition
Condition
The printer
does not
print.
Possible cause
Suggested solutions
The printer is not
receiving power.
Check the power cord
connections. Check the power
switch and the power source.
The printer is not
selected as the
default printer.
Select Samsung ML-2510
Series, Samsung ML-2570
Series, Samsung ML-2570
Series PCL 6 or Samsung ML2570 Series PS as your default
printer.
The printer cover
is not closed.
Close the printer cover.
Paper is jammed.
Clear the paper jam. See page
9.1.
No paper is
loaded.
Load paper. See page 5.4.
The toner
cartridge is not
installed.
Install the toner cartridge.
The printer may
be in manual feed
mode and out of
paper.
Add paper to the manual tray,
and press the Cancel button
on the control panel.
The connection
cable between
the computer and
the printer is not
connected
properly.
Disconnect the printer cable
and reconnect it.
The connection
cable between
the computer and
the printer is
defective.
If possible, attach the cable to
another computer that is
working properly and try to print
a document. You can also try
using a different printer cable.
The port setting is
incorrect.
Check the Windows printer
setting to make sure that the
print job is sent to the correct
port. If the computer has more
than one port, make sure that
the printer is attached to the
correct one.
Check the printer properties to
ensure that all of the print
settings are correct.
The printer driver
may be
incorrectly
installed.
Reinstall the printer driver; See
the Software Section. Try
printing a test page.
The printer is
malfunctioning.
Check the LEDs on the control
panel to determine if the printer
is indicating a system error.
Printer
selects print
media from
the wrong
paper
source.
The paper source
selection in the
printer properties
may be incorrect.
For many software
applications, the paper source
selection is found under the
Paper tab within the printer
properties. Select the correct
paper source. See the
Software Section.
Paper does
not feed into
the printer.
Paper has not
been loaded
correctly.
Remove paper from the tray
and reload it correctly.
There is too much
paper in the tray.
Remove excess paper from the
tray.
The paper is too
thick.
Use only paper that meets
printer specifications.
The job may be
very complex.
Reduce the complexity of the
page(s) or try adjusting the
print quality settings.
Print job is
extremely
slow.
Check that the adjustable
guides are set correctly.
To adjust the print quality
settings, reduce the resolution.
If you have set the resolution to
1200 dpi (Best), change it to
600 dpi (Normal). See the
Software Section.
Change the port setting to the
USB or network port to improve
print speed.
Your printer prints A4-sized
paper at 24 ppm and lettersized paper at 25 ppm.
9.5
Downloaded From ManualsPrinter.com Manuals
Suggested solutions
The printer may
be configured
incorrectly.
The printer
does not
print.
(Continued)
For problems with the operation of your printer, refer to the table for
suggested solutions.
Possible cause
<Troubleshooting>
Condition
Possible cause
Suggested solutions
Print job is
extremely
slow.
(Continued)
If using Windows
98/Me, the
Spooling Setting
may be set
incorrectly.
From the Start menu, choose
Settings and Printers. Rightclick the Samsung ML-2510
Series, Samsung ML-2570
Series, Samsung ML-2570
Series PCL 6, or Samsung ML2570 Series PS printer icon,
choose Properties, click the
Details tab, and then choose
the Spool Settings button.
Select the desired spool
setting.
Half the page
is blank.
The paper
keeps
jamming.
The computer
may have
insufficient
random-access
memory (RAM).
Simplify the page layout and
remove any unnecessary
graphics from the document.
The page layout
is too complex.
Simplify the page layout and
remove any unnecessary
graphics from the document.
The page
orientation setting
may be incorrect.
Change the page orientation in
your application. See the
Software Section.
The paper size
and the paper
size settings do
not match.
Ensure that the paper size in
the printer driver settings
matches the paper in the tray.
Or, ensure that the paper size
in the printer driver settings
matches the paper selection in
the software application
settings you use.
There is too much
paper in the tray.
Condition
Possible cause
Suggested solutions
The printer
prints, but
the text is
wrong,
garbled, or
incomplete.
The printer cable
is loose or
defective.
Disconnect and reconnect the
printer cable. Try a print job that
you have already printed
successfully. If possible, attach
the cable and printer to another
computer and try a print job
that you know works. Finally,
try a new printer cable.
The wrong printer
driver was
selected.
Check the application’s printer
selection menu to ensure that
your printer is selected.
The software
application is
malfunctioning.
Try printing a job from another
application.
The operating
system is
malfunctioning.
If printing from Windows (any
version), exit to a DOS prompt
and verify functionality with the
following command: At a C:\
prompt, type Dir LPT1, and
press Enter. (This assumes
you are connected to LPT1.)
Exit Windows and reboot the
computer. Turn the printer off
and then back on again.
Pages print,
but are
blank.
Remove excess paper from the
tray.
If printing on special print
media, use the manual tray.
An incorrect type
of paper is being
used.
Use only paper that meets
printer specifications.
If printing on special print
media, use the manual tray.
There may be
debris inside the
printer.
Open the front cover and
remove the debris.
The
illustrations
print
incorrectly in
Adobe
Illustrator.
9.6
Downloaded From ManualsPrinter.com Manuals
<Troubleshooting>
The toner
cartridge is
defective or out of
toner.
Redistribute the toner
cartridge. See page 8.3.
If necessary, replace the toner
cartridge. See page 8.4.
The file may have
blank pages.
Check the file to ensure that it
does not contain blank pages.
Some parts, such
as the controller
or the board, may
be defective.
Contact a service
representative.
The setting in the
software
application is
wrong.
Select Download as Bitmap in
the Advanced Options window
of the graphic properties. Print
the document again.
Solving print quality problems
Condition
Vertical lines
Dirt inside of the printer or improper paper loading may reduce print
quality. See the table below to troubleshoot problems.
Condition
Light or faded
print
Toner spots
Dropouts
Suggested solutions
If a vertical white streak or faded area appears
on the page:
• The toner supply is low. You may be able to
temporarily extend the toner cartridge life. See
page 8.3. If this does not improve print quality,
install a new toner cartridge.
• The paper may not meet paper specifications
(for example, the paper is too moist or too
rough). See page 5.3.
• If the entire page is light, the print resolution
setting is too light or toner save mode is on.
Adjust the print resolution and toner save
mode in the printer properties. See the
Software Section.
• A combination of faded or smeared defects
may indicate that the printer needs cleaning.
See page 8.1.
• The surface of LSU may be dirty. Clean the
LSU. See page 8.2.
If black vertical streaks appear on the page:
• The drum inside the toner cartridge has
probably been scratched. Install a new toner
cartridge. See page 8.4.
If white vertical streaks appear on the page:
• The surface of the LSU part inside the printer
may be dirty. Clean the LSU. See page 8.2.
Gray
background
If the amount of background shading becomes
unacceptable, the procedures below may fix the
problem.
• Change to lighter weight pages. See page 5.3.
• Check the printer’s environment; low humidity
(lower than 20% RH) or high humidity (higher
than 80% RH) conditions can increase the
amount of background shading.
• Remove the old toner cartridge and install a
new one. See page 8.4.
• The paper may not meet specifications (for
example, the paper is too moist or too rough).
See page 5.3.
• The transfer roller or paper path may be dirty.
See page 8.1.
Toner smear
• Clean the inside of the printer. See page 8.1.
• Check the paper type and quality. See page
5.2.
• Remove the toner cartridge and install a new
one. See page 8.4.
Vertical
repetitive
defects
If marks repeatedly appear on the printed side of
the page at even intervals:
• The toner cartridge may be damaged. If a
repetitive mark occurs on the page, install a
new toner cartridge. See page 8.4.
• Parts of the printer may have toner on them. If
the defects occur on the back of the page, the
problem will likely correct itself after a few
more pages.
• The fusing assembly may be damaged.
Contact a service representative.
If generally rounded, faded areas occur
randomly on the page:
• A single sheet of paper may be defective. Try
reprinting the job.
• The moisture content of the paper is uneven
or the paper has moist spots on its surface.
Try a different brand of paper. See page 5.3.
• The paper lot is bad. The manufacturing
processes can cause some areas to reject
toner. Try a different kind or brand of paper.
• The toner cartridge may be defective. See
“Vertical repetitive defects” on the next
column.
• If these steps do not correct the problems,
contact a service representative.
9.7
Downloaded From ManualsPrinter.com Manuals
Suggested solutions
<Troubleshooting>
Condition
Background
scatter
Suggested solutions
Condition
Background scatter results from bits of toner
distributed on the printed page.
Wrinkles or
creases
• Ensure that the paper is loaded properly.
• Check the paper type and quality. See page
5.2.
• Turn over the stack of paper in the tray. Also
try rotating the paper 180° in the tray.
Back of
printouts are
dirty
• The transfer roller may be dirty. See page 8.1.
• Check for leaking toner. Clean the inside of
the printer.
Solid black
pages
• Ensure that the paper is loaded properly.
• Check the paper type and quality. See page
5.2.
• Ensure that the paper is loaded correctly and
the adjustable guides are not too tight or too
loose against the paper stack.
• The toner cartridge may not be installed
properly. Remove the cartridge and reinsert.
• The toner cartridge may be defective and
need replacing. Install a new toner cartridge.
• The printer may require repair. Contact a
service representative.
Loose toner
• Ensure that the paper is loaded properly.
• Check the paper type and quality. Both high
temperature and humidity can cause paper
curl. See page 5.2.
• Turn over the stack of paper in the tray. Also
try rotating the paper 180° in the tray.
• Clean the inside of the printer.
• Check the paper type and quality. See page
5.2.
• Install a new toner cartridge. See page 8.4.
• If the problem persists, the printer may require
repair. Contact a service representative.
Character voids
Character voids are white areas within
characters that should be solid black:
• The paper may be too damp. Try printing with
a different batch of paper. Do not open
packages of paper until necessary so that the
paper does not absorb too much moisture.
• If background scatter occurs on an envelope,
change the printing layout to avoid printing
over areas that have overlapping seams on
the reverse side. Printing on seams can cause
problems.
• If background scatter covers the entire
surface area of a printed page, adjust the print
resolution through your software application or
via the printer properties window.
Misformed
characters
Page skew
Curl or wave
Suggested solutions
• If characters are improperly formed and
producing hollowed images, the paper stock
may be too slick. Try a different paper. See
page 5.3.
• If you are using transparencies, try another
type of transparency. Because of the
composition of the transparency, some
character voids may be normal.
• You may be printing on the wrong surface on
the paper. Turn over the paper in the tray.
• The paper may not meet paper specifications.
See page 5.3.
9.8
Downloaded From ManualsPrinter.com Manuals
<Troubleshooting>
Condition
Horizontal
stripes
Suggested solutions
If horizontally aligned black streaks or smears
appear:
• The toner cartridge may be installed
improperly. Remove the cartridge and
reinsert.
• The toner cartridge may be defective. Install a
new toner cartridge. See page 8.4.
• If the problem persists, the printer may require
repair. Contact a service representative.
Curl
Condition
Suggested solutions
“Fail To Print,” “A
printer timeout error
occurred,”
messages appear.
These messages may appear during printing.
Just keep waiting until the printer finishes
printing. If the message appears in standby
mode or after printing has been completed,
check the connection and/or whether an error
has occurred.
Note
• Refer to Microsoft Windows 98/Me/NT 4.0/2000/XP(32/64 bit)/
2003 User’s Guide that came with your PC for further
information on Windows error messages.
If the printed paper is curled or paper does not
feed into the printer:
• Turn over the stack of paper in the tray. Also
try rotating the paper 180° in the tray.
Common PostScript problems
The following situations are PostScript language specific and may occur
when several printer languages are being used.
An unknown
image repetitively
appears on a
next few sheets
or loose toner,
light print or
contamination
occurs.
Note
Your printer is probably being used at an altitude
of 2,500 m (8,200 ft) or above.
The high altitude may affect the print quality
such as loose toner or light imaging. You can set
this option through Printer Settings Utility or
Printer Tab in printer driver’s properties. Refer
to the Software Section for details.
• To receive a printed or screen displayed message when
PostScript errors occur, open the Print Options window and
click the desired selection next to the PostScript errors section.
Condition
Possible cause
Suggested solutions
PostScript file
can not be
printed.
The PostScript
driver may not
be installed
correctly.
• Print a configuration page
and verify that the PostScript
version is available for
printing.
• Install the PostScript driver;
to installing the PS printer
driver, see the Software
Section.
• If problem consists, contact a
service representative.
“Limit Check
Error” message
appears.
The print job
was too
complex.
You might need to reduce the
complexity of the page.
A PostScript
error page
prints.
Print job may
not be
PostScript.
Make sure that the print job is a
PostScript job. Check to see
whether the software
application expected a setup or
PostScript header file to be sent
to the printer.
When print a
document in
Macintosh with
Acrobat Reader
6.0 or higher,
colors print
incorrectly.
The resolution
setting in the
printer driver
may not be
matched with
that in Acrobat
Reader.
Make sure that the resolution
setting in your printer driver
matches that in Acrobat
Reader.
Common Windows problems
Condition
Suggested solutions
“File in Use”
message appears
during installation.
Exit all software applications. Remove all
software from the StartUp Group, then restart
Windows. Reinstall the printer driver.
“Error Writing to
LPTx” message
appears.
• Ensure that the cables are connected
correctly and the printer is on.
• If bi-directional communication is not turned
on in the driver, it will also cause this
message.
“General Protection
Fault”, “Exception
OE”, “Spool32”, or
“Illegal Operation”
messages appear.
Close all other applications, reboot Windows,
and try printing again.
9.9
Downloaded From ManualsPrinter.com Manuals
<Troubleshooting>
Common Linux problems
Condition
The printer doesn’t
print.
I encounter error
“Unable to open
mfp port device
file!” when printing
a document.
Common Macintosh problems
Suggested solutions
Condition
• Check if the printer driver is installed in your
system. Open Unified Driver Configurator
and switch to the Printers tab in Printers
configuration window to look at the list of
available printers. Make sure that your
machine is displayed on the list. If not,
please, invoke Add new printer wizard to set
up your device.
• Check if the printer is started. Open Printers
configuration and select your machine on
the printers list. Look at the description in
the Selected printer pane. If its status
contains “(stopped)” string, please, press
the Start button. After that normal operation
of the printer should be restored. The
"stopped" status might be activated when
some problems in printing occurred.
The printer does not
print a document from
Acrobat Reader.
Change the Print Method option to Print
as Image when you print from Acrobat
Reader.
The document has
printed, but the print job
has not disappeared
from the spooler in Mac
OS 10.3.2.
Update your Mac OS to OS 10.3.3 or
higher.
The printer does not
print a document from
Illustrator on IPP
printing.
Change the Data type option in the
Adobe Illustrator print menu to Binary.
Please avoid changing print job parameters
(via LPR GUI, for example) while a print job is
in progress. Known versions of CUPS server
break the print job whenever print options are
changed and then try to restart the job from
the beginning. Since Unified Linux Driver
locks mfp port while printing, the abrupt
termination of the driver keeps the port locked
and therefore unavailable for subsequent print
jobs. If this situation occurred, please, try to
release the mfp port.
9.10
Downloaded From ManualsPrinter.com Manuals
Suggested solutions
<Troubleshooting>
Or, you can use Appletalk printing.
10 Specifications
Printer specifications
Item
Specifications and description
Printing speeda
Up to 24 ppm in A4 (25 ppm in Letter)
Resolution
ML-2510
Up to 1200 x 600 dpi effective
output
ML-2570,
Up to 1200 x 1200 dpi
effective output
ML-2571N
Warm-up time
Less than 15 seconds
First print out
time
9 seconds (From Ready)
Sleep mode: 25 seconds
Power rating
110 ~ 127 VAC, 50 / 60 Hz, 5.5 A
220 ~ 240 VAC, 50 / 60 Hz, 3 A
Power
consumption
Average: 390 W (ML-2510), 400 W (ML-2570,
ML-2571N)
Power save mode: Less than 6.5 W (ML-2510),
8.5 W (ML-2570, ML-2571N)
Noise levelb
Standby mode: Less than 35 dBA
Printing mode: Less than 53 dBA
Toner cartridge
lifec
3,000 pages at ISO 19752 5% coverage
(ships with 1,000 pages starter toner cartridge)
Duty cycle
Monthly: Up to 10,000 pages
Weight
8.9 Kg (including consumables)
Package weight
Paper: 1.6 Kg, Plastic: 0.3 Kg
External
dimensions
(W x D x H)
13.9 X 11.7 X 9.7 inches (354 X 297 X 246 mm)
Operating
environment
Temperature: 50° F to 90° F (10° C to 32° C)
Humidity: 20% to 80% RH
Printer language
ML-2510
SPL
ML-2570,
ML-2571N
SPL, PostScript 3, PCL6d
ML-2510
8 MB (non expandable)
ML-2570,
32 MB (non expandable)
Memory
ML-2571N
Fonts
10.1
Downloaded From ManualsPrinter.com Manuals
<Specifications>
Windows fonts
Item
Interface
Specifications and description
• IEEE 1284 Bidirectional Parallel Standard
- Modes supported: Compatible, Nibble, Byte,
ECP
• USB Interface Standard
- USB 1.1: Compatible with USB 2.0 (ML-2510
only)
- USB 2.0: Hi-Speed USB 2.0: (ML-2570, ML2571N only)
- 480 Mbps 1 port
• Network Interface
- Ethernet 10/100 Base TX wired LAN (optional
item in the ML-2510, ML-2570)
OS compatibility
• Windows 98/Me/NT 4.0/2000/XP(32/64 bit)/2003
• Various Linux OS
• Mac 10.3 (ML-2510) or 8.6 ~ 9.2/10.1 ~ 10.4
(ML-2570, ML-2571N)
Printer driverse
• SPL: Windows, Linux
• CUPS: Macintosh OS 10.3 (ML-2510)
• PCL6 driver (ML-2570, ML-2571N only):
Windows 98/Me/NT 4.0/2000/XP(32/64 bit)/2003
• PostScript driver (ML-2570, ML-2571N only):
Windows 98/Me/NT 4.0/2000/XP(32/64 bit)/2003,
Macintosh OS 8.6 ~ 9.2/10.1 ~ 10.4
Options
Ethernet 10/100 Base TX wired network
interface server
(ML-2510, ML-2570 only)
a. Print speed will be affected by operating system used, computing performance, application software, connection method, print media type, print media
size, and job complexity.
b. Sound pressure Level, ISO7779
c. The number of pages may be affected by operating environment, printing interval, print media type, and print media size.
d. Compatible with PCL6 version 2.1
e. Please visit www.samsungprinter.com to download the latest software version.
10.2
Downloaded From ManualsPrinter.com Manuals
<Specifications>
INDEX
A
O
S
accessories, order information 7.1
output location 5.6
C
P
cleaning
inside 8.1
outside 8.1
component location 1.2
configuration page, print 8.5
control panel
LED 9.4
overview 1.3
paper guidelines 5.3
paper jam, clear
around the toner cartridge 9.2
manual tray 9.2
paper exit area 9.3
standard tray 9.1
paper load
manual tray 5.5
standard tray 5.4
paper size, specifications 5.2
paper type, specifications 5.2
PostScript problems 9.9
print quality problems, solve 9.7
printing
configuration page 8.5
demo page 2.1
problems 9.5
problem, solve
checklist 9.4
Linux 9.10
Macintosh 9.10
paper jams 9.1
printing 9.5
printing quality 9.7
PS errors 9.9
Windows 9.9
special print media, guidelines 5.3
specification, printer 10.1
supplies, order information 7.1
system requirements
Linux 3.3
Macintosh 3.3
Windows 3.2
D
demo page, print 2.1
J
jam, clear 9.1
L
LED, meaning 9.4
Linux problems 9.10
loading paper
manual tray 5.5
standard tray 5.4
M
Macintosh problems 9.10
maintenance parts 8.5
manual feed mode, use 5.5
manual tray, use 5.5
N
Q
quality problems 9.7
R
redistributing, toner cartridge 8.3
replacing, toner cartridge 8.4
network interface server, install 4.2
network operating systems 4.1
1
Downloaded From ManualsPrinter.com Manuals
T
toner cartridge
maintaining 8.3
redistributing 8.3
replacing 8.4
toner save mode, use 2.1
troubleshooting 9.1
W
Windows problems 9.9
Samsung Printer
Software section
Downloaded From ManualsPrinter.com Manuals
SOFTWARE
SECTION
CONTENTS
Chapter 1:
INSTALLING PRINTER SOFTWARE
IN
WINDOWS
Installing Printer Software ........................................................................................................ 4
Installing Software for Local Printing ................................................................................. 4
Installing Software for Network Printing ............................................................................. 7
Reinstalling Printer Software ................................................................................................... 10
Removing Printer Software ..................................................................................................... 11
Chapter 2:
BASIC PRINTING
Printing a Document .............................................................................................................. 12
Printer Settings ..................................................................................................................... 13
Layout Tab .................................................................................................................. 13
Paper Tab .................................................................................................................... 14
Graphics Tab ............................................................................................................... 15
Extras Tab ................................................................................................................... 16
About Tab ................................................................................................................... 16
Printer Tab .................................................................................................................. 16
Using a Favorite Setting ................................................................................................ 17
Using Help ................................................................................................................... 17
1
Downloaded From ManualsPrinter.com Manuals
Chapter 3:
ADVANCED PRINTING
Printing Multiple Pages on One Sheet of Paper (N-Up Printing) ..................................................... 18
Printing Posters ..................................................................................................................... 19
Printing Booklets .................................................................................................................. 19
Printing on Both Sides of Paper ............................................................................................... 20
Printing a Reduced or Enlarged Document ................................................................................ 20
Fitting Your Document to a Selected Paper Size ......................................................................... 20
Using Watermarks ................................................................................................................. 21
Using an Existing Watermark ......................................................................................... 21
Creating a Watermark ................................................................................................... 21
Editing a Watermark ..................................................................................................... 21
Deleting a Watermark ................................................................................................... 21
Using Overlays ...................................................................................................................... 22
What is an Overlay? ...................................................................................................... 22
Creating a New Page Overlay ......................................................................................... 22
Using a Page Overlay .................................................................................................... 22
Deleting a Page Overlay ................................................................................................ 22
Chapter 4:
USING WINDOWS POSTSCRIPT DRIVER
(ML-2570/2571N ONLY)
Printer Settings ..................................................................................................................... 23
Advanced .................................................................................................................. 23
Using Help ................................................................................................................... 23
Chapter 5:
SHARING
THE
PRINTER LOCALLY
Setting Up a Host Computer ................................................................................................... 24
Setting Up a Client Computer .................................................................................................. 24
Chapter 6:
USING SMART PANEL
Understanding Smart Panel .................................................................................................... 25
Opening the Troubleshooting Guide ......................................................................................... 26
Using Printer Settings Utility ................................................................................................... 26
Using Onscreen Help File ............................................................................................... 26
Changing the Smart Panel Program Settings ............................................................................. 26
2
Downloaded From ManualsPrinter.com Manuals
Chapter 7:
USING YOUR PRINTER
IN
LINUX
Getting Started ..................................................................................................................... 27
Installing the Unified Linux Driver ............................................................................................ 27
Installing the Unified Linux Driver ................................................................................... 27
Uninstalling the Unified Linux Driver ............................................................................... 28
Using the Unified Driver Configurator ....................................................................................... 29
Opening the Unified Driver Configurator .......................................................................... 29
Printers Configuration ................................................................................................... 29
Ports Configuration ....................................................................................................... 30
Configuring Printer Properties ................................................................................................. 30
Printing a Document .............................................................................................................. 31
Printing from Applications .............................................................................................. 31
Printing Files ................................................................................................................ 31
Chapter 8:
USING YOUR PRINTER
WITH A
MACINTOSH
Installing printer driver for Macintosh ....................................................................................... 32
ML-2510 only ............................................................................................................... 32
ML-2570/ML-2571N only ............................................................................................... 33
Setting Up the Printer ............................................................................................................ 33
ML-2510 only ............................................................................................................... 33
ML-2570/ML-2571N only ............................................................................................... 34
Printing ................................................................................................................................ 34
Printing a Document ..................................................................................................... 34
Changing Printer Settings .............................................................................................. 35
Printing Multiple Pages on One Sheet of Paper .................................................................. 36
3
Downloaded From ManualsPrinter.com Manuals
1
Installing Printer
Software in Windows
This chapter includes:
• Installing Printer Software
Typical Installation
This is recommended for most users. All components necessary
for printer operations will be installed.
1
Make sure that the printer is connected to your computer
and powered on.
2
Insert the supplied CD-ROM into your CD-ROM drive.
The CD-ROM should automatically run, and an installation
window appears.
• Reinstalling Printer Software
• Removing Printer Software
If the installation window does not appear, click Start and
then Run. Type X:\Setup.exe, replacing “X” with the
letter which represents your drive and click OK.
Installing Printer Software
You can install the printer software for local printing or network
printing. To install the printer software on the computer,
perform the appropriate installation procedure depending on
the printer in use.
A printer driver is software that lets your computer
communicate with your printer. The procedure to install drivers
may differ depending on the operating system you are using.
All applications should be closed on your PC before beginning
installation.
Installing Software for Local Printing
3
A local printer is a printer directly attached to your computer
using the printer cable supplied with your printer, such as a USB
or parallel cable. If your printer is attached to a network, skip
this step and go to “Installing Software for Network Printing” on
page 7.
You can install the printer software using the typical or custom
method.
Click Next.
• If necessary, select a language from the drop-down list.
• View User’s Guide: Allows you to view the User’s
Guide. If your computer doesn’t have Adobe Acrobat,
click on this option and it will automatically install Adobe
Acrobat Reader for you.
4
Select Typical installation for a local printer. Click
Next.
NOTE: If the “New Hardware Wizard” window appears during
the installation procedure, click
in the upper right corner of
the box to close the window, or click Cancel.
Downloaded From ManualsPrinter.com Manuals
4
Installing Printer Software in Windows
7
NOTE: If your printer is not already connected to the
computer, the following window will appear.
To register yourself as a user of Samsung Printers in order
to receive information from Samsung, select the checkbox
and click Finish. You are now sent to the Samsung web
site.
Otherwise, just click Finish.
• After connecting the printer, click Next.
• If you don’t want to connect the printer at this time, click
Next, and No on the following screen. Then the installation
will start and a test page will not be printed at the end of the
installation.
• The installation window that appears in this User’s
Guide may differ depending on the printer and
interface in use.
5
NOTE: After setup is complete, if your printer driver doesn’t
work properly, reinstall the printer driver. See “Reinstalling
Printer Software” on page 10.
Custom Installation
After the installation is finished, a window asking you to
print a test page appears. If you choose to print a test
page, select the checkbox and click Next.
You can choose individual components to install.
Otherwise, just click Next and skip to step 7.
6
If the test page prints out correctly, click Yes.
1
Make sure that the printer is connected to your computer
and powered on.
2
Insert the supplied CD-ROM into your CD-ROM drive.
The CD-ROM should automatically run, and an installation
window appears.
If not, click No to reprint it.
If the installation window does not appear, click Start and
then Run. Type X:\Setup.exe, replacing “X” with the
letter which represents your drive and click OK.
5
Downloaded From ManualsPrinter.com Manuals
Installing Printer Software in Windows
3
Click Next.
• If necessary, select a language from the drop-down list.
NOTE: If your printer is not already connected to the
computer, the following window will appear.
• View User’s Guide: Allows you to view the User’s
Guide. If your computer doesn’t have Adobe Acrobat,
click on this option and it will automatically install Adobe
Acrobat Reader for you.
4
5
Select Custom installation. Click Next.
• After connecting the printer, click Next.
• If you don’t want to connect the printer at this time, click
Next, and No on the following screen. Then the installation
will start and a test page will not be printed at the end of the
installation.
• The installation window that appears in this User’s
Guide may differ depending on the printer and
interface in use.
Select your printer and click Next.
6
Select the components to be installed and click Next.
NOTE: You can change the desired installation folder by
clicking [Browse].
7
After the installation is finished, a window asking you to
print a test page appears. If you choose to print a test
page, select the checkbox and click Next.
Otherwise, just click Next and skip to step 9.
8
If the test page prints out correctly, click Yes.
If not, click No to reprint it.
6
Downloaded From ManualsPrinter.com Manuals
Installing Printer Software in Windows
9
To register yourself as a user of Samsung Printers in order
to receive information from Samsung, select the checkbox
and click Finish. You are now sent to the Samsung web
site.
If the installation window does not appear, click Start and
then Run. Type X:\Setup.exe, replacing “X” with the
letter which represents your drive and click OK.
Otherwise, just click Finish.
3
Click Next.
• If necessary, select a language from the drop-down list.
• View User’s Guide: Allows you to view the User’s
Guide. If your computer doesn’t have Adobe Acrobat,
click on this option and it will automatically install Adobe
Acrobat Reader for you.
Installing Software for Network
Printing
When you connect your printer to a network, you must first
configure the TCP/IP settings for the printer. After you have
assigned and verified the TCP/IP settings, you are ready to
install the software on each computer on the network.
4
Select Typical installation for a network printer. Click
Next.
You can install the printer software using the typical or custom
method.
Typical Installation
This is recommended for most users. All components necessary
for printer operations will be installed.
1
Make sure that the printer is connected to your network
and powered on. For details about connecting to the
network, see the supplied printer’s User’s Guide.
2
Insert the supplied CD-ROM into your CD-ROM drive.
The CD-ROM should automatically run, and an installation
window appears.
7
Downloaded From ManualsPrinter.com Manuals
Installing Printer Software in Windows
5
Custom Installation
The list of printers available on the network appears.
Select the printer you want to install from the list and then
click Next.
You can choose individual components to install and set a
specific IP address.
1
Make sure that the printer is connected to your network
and powered on. For details about connecting to the
network, see the supplied printer’s User’s Guide.
2
Insert the supplied CD-ROM into your CD-ROM drive.
The CD-ROM should automatically run, and an installation
window appears.
If the installation window does not appear, click Start and
then Run. Type X:\Setup.exe, replacing “X” with the
letter which represents your drive and click OK.
• If you do not see your printer on the list, click Update to
refresh the list, or select Add TCP/IP Port to add your
printer to the network. To add the printer to the
network, enter the port name and the IP address for the
printer.
• To find a shared network printer (UNC Path), select
Shared Printer [UNC] and enter the shared name
manually or find a shared printer by clicking the Browse
button.
6
After the installation is finished, a window appears asking
you to print a test page and to register yourself as a user
of Samsung Printers in order to receive information from
Samsung. If you so desire, select the corresponding
checkbox(es) and click Finish.
3
Click Next.
• If necessary, select a language from the drop-down list.
• View User’s Guide: Allows you to view the User’s
Guide. If your computer doesn’t have Adobe Acrobat,
click on this option and it will automatically install Adobe
Acrobat Reader for you.
Otherwise, just click Finish.
4
Select Custom installation. Click Next.
NOTE: After setup is complete, if your printer driver doesn’t
work properly, reinstall the printer driver. See “Reinstalling
Printer Software” on page 10.
8
Downloaded From ManualsPrinter.com Manuals
Installing Printer Software in Windows
5
6
The list of printers available on the network appears.
Select the printer you want to install from the list and then
click Next.
• If you do not see your printer on the list, click Update to
refresh the list, or select Add TCP/IP Port to add your
printer to the network. To add the printer to the
network, enter the port name and the IP address for the
printer.
Select the components to be installed. After selecting the
components, the following window appears. You can also
change the printer name, set the printer to be shared on
the network, set the printer as the default printer, and
change the port name of each printer. Click Next.
To install this software on a server, select the Setting up
this printer on a server checkbox.
7
• To find a shared network printer (UNC Path), select
Shared Printer [UNC] and enter the shared name
manually or find a shared printer by clicking the Browse
button.
After the installation is finished, a window appears asking
you to print a test page and to register yourself as a user
of Samsung Printers in order to receive information from
Samsung. If you so desire, select the corresponding
checkbox(es) and click Finish.
Otherwise, just click Finish.
TIP: If you want to set a specific IP address on a specific
network printer, click the Set IP Address button. The Set IP
Address window appears. Do as follows:
NOTE: After setup is complete, if your printer driver doesn’t
work properly, reinstall the printer driver. See “Reinstalling
Printer Software” on page 10.
a. Select a printer to be set with a specific IP address from the
list. To verify your printer’s IP address or MAC address,
print a Network Configuration page.
b. Configure an IP address, subnet mask, and gateway for the
printer manually and click Configure to set the specific IP
address for the network printer.
c. Click Next.
9
Downloaded From ManualsPrinter.com Manuals
Installing Printer Software in Windows
Reinstalling Printer Software
NOTE: If your printer is not already connected to the
computer, the following window will appear.
You can reinstall the software if installation fails.
1 Start Windows.
2
3
4
From the Start menu select Programs or All Programs
→ your printer driver name → Maintenance.
Select Repair and click Next.
The list of printers available on the network appears.
Select the printer you want to install from the list and then
click Next.
• After connecting the printer, click Next.
• If you don’t want to connect the printer at this time, click
Next, and No on the following screen. Then the installation
will start and a test page will not be printed at the end of the
installation.
• The reinstallation window that appears in this User’s
Guide may differ depending on the printer and
interface in use.
• If you do not see your printer on the list, click Update to
refresh the list, or select Add TCP/IP Port to add your
printer to the network. To add the printer to the
network, enter the port name and the IP address for the
printer.
5
If you installed the printer software for local printing
and you select your printer driver name, the window
asking you to print a test page appears. Do as follows:
a. To print a test page, select the check box and click
Next.
• To find a shared network printer (UNC Path), select
Shared Printer [UNC] and enter the shared name
manually or find a shared printer by clicking the Browse
button.
You will see a component list so that you can reinstall any
item individually.
Downloaded From ManualsPrinter.com Manuals
Select the components you want to reinstall and click
Next.
b. If the test page prints out correctly, click Yes.
6
If it doesn’t, click No to reprint it.
When the reinstallation is done, click Finish.
10
Installing Printer Software in Windows
Removing Printer Software
1
2
3
4
5
6
Start Windows.
From the Start menu select Programs or All Programs
→ your printer driver name → Maintenance.
Select Remove and click Next.
You will see a component list so that you can remove any
item individually.
Select the components you want to remove and then click
Next.
When your computer asks you to confirm your selection,
click Yes.
The selected driver and all of its components are removed
from your computer.
After the software is removed, click Finish.
11
Downloaded From ManualsPrinter.com Manuals
Installing Printer Software in Windows
2
1
2
Basic Printing
This chapter explains the printing options and common printing
tasks in Windows.
Open the document you want to print.
Select Print from the File menu. The Print window is
displayed. It may look slightly different depending on your
application.
The basic print settings are selected within the Print
window. These settings include the number of copies and
print range.
This chapter includes:
• Printing a Document
• Printer Settings
- Layout Tab
- Paper Tab
Make sure that your
printer is selected.
- Graphics Tab
- Extras Tab
- About Tab
- Printer Tab
- Using a Favorite Setting
- Using Help
3
Printing a Document
4
NOTES:
• Your printer driver Properties window that appears in this
User’s Guide may differ depending on the printer in use.
However the composition of the printer properties window is
similar.
• Check the Operating System(s) that are compatible
with your printer. Please refer to the OS Compatibility
section of Printer Specifications in your Printer User’s
Guide.
• If you need to know the exact name of your printer, you can
check the supplied CD-ROM.
5
6
The following procedure describes the general steps required
for printing from various Windows applications. The exact steps
for printing a document may vary depending on the application
program you are using. Refer to the User’s Guide of your
software application for the exact printing procedure.
12
Downloaded From ManualsPrinter.com Manuals
Basic Printing
Select your printer driver from the Name drop-down
list.
To take advantage of the printer features provided by your
printer driver, click Properties or Preferences in the
application’s Print window. For details, see “Printer
Settings” on page 13.
If you see Setup, Printer, or Options in your Print
window, click it instead. Then click Properties on the next
screen.
Click OK to close the printer properties window.
To start the print job, click OK or Print in the Print
window.
Layout Tab
Printer Settings
The Layout tab provides options to adjust how the document
appears on the printed page. The Layout Options includes
Multiple Pages per Side, Poster Printing and Booklet
Printing. See “Printing a Document” on page 12 for more
information on accessing printer properties.
You can use the printer properties window, which allows you to
access all of the printer options you need when using your
printer. When the printer properties are displayed, you can
review and change the settings needed for your print job.
Your printer properties window may differ, depending on your
operating system. This Software User’s Guide shows the
Properties window for Windows XP.
1
Your printer driver Properties window that appears in this
User’s Guide may differ depending on the printer in use.
2
If you access printer properties through the Printers folder, you
can view additional Windows-based tabs (refer to your
Windows User’s Guide) and the Printer tab (see “Printer Tab” on
page 16).
NOTES:
• Most Windows applications will override settings you specify
in the printer driver. Change all print settings available in the
software application first, and change any remaining settings
using the printer driver.
• The settings you change remain in effect only while you are
using the current program. To make your changes
permanent, make them in the Printers folder.
• The following procedure is for Windows XP. For other
Windows OS, refer to the corresponding Windows User's
Guide or online help.
1. Click the Windows Start button.
2. Select Printers and Faxes.
3. Select your printer driver icon.
4. Right-click on the printer driver icon and select
Printing Preferences.
5. Change the settings on each tab, click OK.
Paper Orientation
Paper Orientation allows you to select the direction in which
information is printed on a page.
• Portrait prints across the width of the page, letter style.
• Landscape prints across the length of the page, spreadsheet
style.
• Rotate allows you to rotate the page the selected degrees.
Portrait
Landscape
Layout Options
Layout Options allows you to select advanced printing options.
You can choose Multiple Pages per Side and Poster Printing.
• For details, see “Printing Multiple Pages on One Sheet of Paper
(N-Up Printing)” on page 18.
• For details, see “Printing Posters” on page 19
Double-sided Printing
Double-sided Printing allows you to print on both sides of
paper. If this option does not appear, your printer does
not have this feature.
• For details, see “Printing on Both Sides of Paper” on page 20.
13
Downloaded From ManualsPrinter.com Manuals
Basic Printing
Paper Tab
3 Source
Make sure that Source is set to the corresponding paper tray.
Use Manual Feeder when printing on special materials like
envelopes and transparencies. You have to load one sheet at a
time into the Manual Tray or Multi-Purpose Tray.
If the paper source is set to Auto Selection, the printer
automatically picks up print material in the following tray order:
Manual Tray or Multi-Purpose Tray, Tray1.
Use the following options to set the basic paper handling
specifications when you access the printer properties. See
“Printing a Document” on page 12 for more information on
accessing printer properties.
Click the Paper tab to access various paper properties.
1
4 Type
Set Type to correspond to the paper loaded in the tray from
which you want to print. This will let you get the best quality
printout. If not, print quality may not be acheived as you want.
Cotton: 20 lb to 24 lb (75~90 g/m2) cotton paper such as Gilbert
25 % and Gilbert 100 %.
Plain Paper: Normal plain paper. Select this type if your printer is
monochrome and printing on the 16 lb (60 g/m2) cotton paper.
Recycled: 20 lb to 24 lb (75~90 g/m2) recycled paper.
Color Paper: 20 lb to 24 lb (75~90 g/m2) color-backgrounded
paper.
2
3
4
5
5 Scaling Printing
Scaling Printing allows you to automatically or manually scale
your print job on a page. You can choose from None, Reduce/
Enlarge, and Fit to Page.
• For details, see “Printing a Reduced or Enlarged Document” on
page 20.
• For details, see “Fitting Your Document to a Selected Paper
Size” on page 20.
1 Copies
Copies allows you to choose the number of copies to be printed.
You can select 1 to 999 copies.
2 Size
Size allows you to set the size of paper you loaded in the tray.
If the required size is not listed in the Size box, click Custom.
When the Custom Paper Setting window appears, set the paper
size and click OK. The setting appears in the list so that you can
select it.
14
Downloaded From ManualsPrinter.com Manuals
Basic Printing
Graphics Tab
Darkness
Use this option to lighten or darken your print job. Some
printers do not support this feature.
• Normal: This setting is for normal documents.
• Light: This setting is for bolder line widths or darker gray-scale
images.
• Dark: This setting is for finer line width, higher definition in
graphics, and lighter gray-scale images.
Use the following Graphic options to adjust the print quality for
your specific printing needs. See “Printing a Document” on
page 12 for more information on accessing printer properties.
Click the Graphic tab to display the properties shown below..
Toner Save Mode
Selecting this option extends the life of your toner cartridge and
reduces your cost per page without a significant reduction in print
quality. Some printers do not support this feature.
• Printer Setting: If you select this option, this feature is
determined by the setting you’ve made on the control panel of
the printer.
• On: Select this option to allow the printer to use less toner on
each page.
• Off: If you don’t need to save toner when printing a document,
select this option.
Advanced Options
You can set advanced settings by clicking the Advanced
Options button.
• TrueType Options: This option determines what the driver
tells the printer about how to image the text in your document.
Select the appropriate setting according to the status of your
document. This option may be available only in
Windows 9x/Me, depending on your particular printer
model.
- Download as Outline: When this option is selected, the
driver will download any TrueType fonts that are used in your
document not already stored (resident) on your printer. If,
after printing a document, you find that the fonts did not print
correctly, choose Download as bit image and resubmit your
print job. The Download as bit image setting is often useful
when printing Adobe. This feature is available only
when you use the PCL printer driver.
- Download as Bitmap: When this option is selected, the
driver will download the font data as bitmap images.
Documents with complicated fonts, such as Korean or
Chinese, or various other fonts, will print faster in this setting.
- Print as Graphics: When this option is selected, the driver
will download any fonts as graphics. When printing documents
with high graphic content and relatively few TrueType fonts,
printing performance (speed) may be enhanced in this
setting.
• Print All Text To Black: When the Print All Text To Black
option is checked, all text in your document prints solid black,
regardless of the color it appears on the screen.
• Print All Text To Darken: When the Print All Text To Darken
option is checked, all text in your document is allowed to print
darker than on a normal document. Some printers do not
support this feature.
Resolution
The Resolution options you can select may vary
depending on your printer model. The higher the setting,
the sharper the clarity of printed characters and graphics. The
higher setting also may increase the time it takes to print a
document.
Image Mode
The available options are Normal and Text Enhance. Some
printers do not support this feature.
• Printer Setting: If you select this option, this feature is
determined by the setting you’ve made on the control panel of
the printer.
• Normal: This setting is for normal documents.
• Text Enhance: Image Mode allows the user to enhance
printouts.
15
Downloaded From ManualsPrinter.com Manuals
Basic Printing
Extras Tab
About Tab
You can select output options for your document. See “Printing
a Document” on page 12 for more information about accessing
the printer properties.
Use the About tab to display the copyright notice and the
version number of the driver. If you have an Internet browser,
you can connect to the Internet by clicking on the web site icon.
See “Printing a Document” on page 12 for more information
about accessing printer properties.
Click the Extras tab to access the following feature:
1
Printer Tab
2
If you access printer properties through the Printers folder,
you can view the Printer tab. You can set the printer
configuration.
3
The following procedure is for Windows XP. For other Windows
OS, refer to the corresponding Windows User's Guide or online
help.
1 Click the Windows Start menu.
2
3
4
5
1 Watermark
You can create a background text image to be printed on each
page of your document. For details, see “Using Watermarks” on
page 21.
2 Overlay
Overlays are often used to take the place of preprinted forms and
letterhead paper. For details, see “Using Overlays” on page 22.
3 Output Options
• Print Subset: You can set the sequence in which the pages
print. Select the print order from the drop-down list.
- Normal(1,2,3): Your printer prints all pages from the first
page to the last page.
- Reverse All Pages(3,2,1): Your printer prints all pages from
the last page to the first page.
- Print Odd Pages: Your printer prints only the odd numbered
pages of the document.
- Print Even Pages: Your printer prints only the even
numbered pages of the document.
• Use Printer Fonts: When Use Printer Fonts is checked, the
printer uses the fonts that are stored in its memory (resident
fonts) to print your document, rather than downloading the
fonts used in your document. Because downloading fonts takes
time, selecting this option can speed up your printing time.
When using Printer fonts, the printer will try to match the fonts
used in your document to those stored in its memory. If,
however, you use fonts in your document that are very different
from those resident in the printer, your printed output will
appear very different from what it looks like on the screen.
This feature is available only when you use the PCL
printer driver.
16
Downloaded From ManualsPrinter.com Manuals
Basic Printing
Select Printers and Faxes.
Select your printer driver icon.
Right-click on the printer driver icon and select
Properties.
Click the Printer tab and set the options.
Using a Favorite Setting
The Favorites option, which is visible on each properties tab,
allows you to save the current properties settings for future
use.
To save a Favorites item:
1
2
Change the settings as needed on each tab.
3
Click Save.
Enter a name for the item in the Favorites input box.
When you save Favorites, all current driver settings are
saved.
To use a saved setting, select the item from the Favorites drop
down list. The printer is now set to print according to the
Favorites setting you selected.
To delete a Favorites item, select it from the list and click
Delete.
You can also restore the printer driver’s default settings by
selecting Printer Default from the list.
Using Help
Your printer has a help screen that can be activated by clicking
the Help button in the printer properties window. These help
screens give detailed information about the printer features
provided by the printer driver.
You can also click
from the upper right corner of the window,
and then click on any setting.
17
Downloaded From ManualsPrinter.com Manuals
Basic Printing
3
Advanced Printing
Printing Multiple Pages on One
Sheet of Paper (N-Up Printing)
This chapter explains printing options and advanced printing
tasks.
1
2
3
4
NOTE:
• Your printer driver Properties window that appears in this
User’s Guide may differ depending on the printer in use.
However the composition of the printer properties window is
similar.
• If you need to know the exact name of your printer, you can
check the supplied CD-ROM.
You can select the number of pages to print on a single sheet
of paper. To print more than one page per sheet, the pages will
be reduced in size and arranged in the order you specify. You
can print up to 16 pages on one sheet.
1
2
3
This chapter includes:
• Printing Multiple Pages on One Sheet of Paper (N-Up
Printing)
4
• Printing Posters
• Printing Booklets
• Printing on Both Sides of Paper
5
• Printing a Reduced or Enlarged Document
6
• Fitting Your Document to a Selected Paper Size
• Using Watermarks
• Using Overlays
18
Downloaded From ManualsPrinter.com Manuals
Advanced Printing
To change the print settings from your software
application, access printer properties. See “Printing a
Document” on page 12.
From the Layout tab, choose Multiple Pages per Side in
the Layout Type drop-down list.
Select the number of pages you want to print per sheet
(1, 2, 4, 6, 9, or 16) in the Pages per Side drop-down
list.
Select the page order from the Page Order drop-down
list, if necessary.
Check Print Page Border to print a border around each
page on the sheet.
Click the Paper tab, select the paper source, size, and
type.
Click OK and print the document.
Printing Posters
Printing Booklets
This feature allows you to print a single-page document onto 4,
9, or 16 sheets of paper, for the purpose of pasting the sheets
together to form one poster-size document.
1
2
3
8
To change the print settings from your software
application, access printer properties. See “Printing a
Document” on page 12.
Click the Layout tab, select Poster Printing in the
Layout Type drop-down list.
Configure the poster option:
9
8
9
This printer feature allows you to print your document on both
sides of the paper and arranges the pages so that the paper can
be folded in half after printing to produce a booklet.
1 To change the print settings from your software
application, access the printer properties. See “Printing a
Document” on page 12.
2 From the Layout tab, choose Booklet Printing from the
Type drop-down list.
You can select the page layout from Poster<2x2>,
Poster<3x3>, or Poster<4x4>. If you select
Poster<2x2>, the output will be automatically stretched
to cover 4 physical pages.
NOTE: The booklet printing option is available when A4,
Letter, Legal, or Folio size is selected in the Size option on the
Paper tab.
3
4
5
Specify an overlap in millimeters or inches to make it
easier to pasting the sheets together.
0.15 inches
0.15 inches
4
5
Click the Paper tab, select the paper source, size, and
type.
Click OK and print the document. You can complete the
poster by pasting the sheets together.
19
Downloaded From ManualsPrinter.com Manuals
Advanced Printing
Click the Paper tab, and select the paper source, size, and
type.
Click OK and print the document.
After printing, fold and staple the pages.
Printing on Both Sides of Paper
Printing a Reduced or Enlarged
Document
You can print on both sides of a sheet of paper. Before printing,
decide how you want your document oriented.
You can change the size of a page’s content to appear larger or
smaller on the printed page.
The options are:
• Printer Setting, if you select this option, this feature is
determined by the setting you’ve made on the control
panel of the printer. If this option does not appear,
1
your printer does not have this feature.
2
• None
• Long Edge, which is the conventional layout used in
book binding.
• Short Edge, which is the type often used with calendars.
3
4
5
2
2
To change the print settings from your software
application, access printer properties. See “Printing a
Document” on page 12.
From the Paper tab, select Reduce/Enlarge in the
Printing Type drop-down list.
Enter the scaling rate in the Percentage input box.
You can also click the
or
button.
Select the paper source, size, and type in Paper Options.
Click OK and print the document.
3
3
2
5
5
2
3
5
3
Fitting Your Document to a
Selected Paper Size
5
▲ Long Edge
▲ Short Edge
• Reverse Duplex, allows you to select general print
order compare to duplex print order. If this option does
not appear, your printer does not have this feature.
A
NOTE:
This printer feature allows you to scale your print job to any
selected paper size regardless of the digital document size. This
can be useful when you want to check fine details on a small
document.
• Do not print on both sides of labels, transparencies,
envelopes, or thick paper. Paper jamming and damage to the
printer may result.
• To use double-sided printing, you can use only the following
paper sizes: A4, Letter, Legal, and Folio, with a weight of
20~24 lbs (75~90 g/m²).
1
1
4
5
2
3
4
5
2
3
To change the print settings from your software
application, access printer properties. “Printing a
Document” on page 12.
From the Layout tab, select the paper orientation.
From the Double-sided Printing(Manual) section,
select the binding option you want.
Click the Paper tab and select the paper source, size, and
type.
Click OK and print the document.
NOTE: If your printer does not have a duplex unit, you should
complete the printing job manually. The printer prints every
other page of the document first. After printing the first side of
your job, the Printing Tip window appears. Follow the onscreen instructions to complete the printing job.
20
Downloaded From ManualsPrinter.com Manuals
Advanced Printing
To change the print settings from your software
application, access printer properties. See “Printing a
Document” on page 12.
From the Paper tab, select Fit to Page in the Printing
Type drop-down list.
Select the correct size from the Target Page drop-down
list.
Select the paper source, size, and type in Paper Options.
Click OK and print the document.
Editing a Watermark
Using Watermarks
1
The Watermark option allows you to print text over an existing
document. For example, you may want to have large gray
letters reading “DRAFT” or “CONFIDENTIAL” printed diagonally
across the first page or all pages of a document.
2
There are several predefined watermarks that come with the
printer, and they can be modified, or you can add new ones to
the list.
3
4
5
Using an Existing Watermark
1
2
3
To change the print settings from your software
application, access printer properties. See “Printing a
Document” on page 12.
Click the Extras tab, and select the desired watermark
from the Watermark drop-down list. You will see the
selected watermark in the preview image.
Click OK and start printing.
1
2
3
it is printed.
4
Creating a Watermark
2
3
4
5
6
To change the print settings from your software
application, access printer properties. See “Printing a
Document” on page 12.
Click the Extras tab, and click the Edit button in the
Watermark section. The Edit Watermark window
appears.
Enter a text message in the Watermark Message box.
You can enter up to 40 characters. The message displays
in the preview window.
When the First Page Only box is checked, the watermark
prints on the first page only.
Select watermark options.
You can select the font name, style, size, or grayscale level
from the Font Attributes section and set the angle of the
watermark from the Message Angle section.
Click Add to add a new watermark to the list.
When you have finished editing, click OK and start
printing.
To stop printing the watermark, select <No Watermark> from
the Watermark drop-down list.
21
Downloaded From ManualsPrinter.com Manuals
Click OK until you exit the Print window.
Deleting a Watermark
NOTE: The preview image shows how the page will look when
1
To change the print settings from your software
application, access printer properties. See “Printing a
Document” on page 12.
Click the Extras tab and click the Edit button in the
Watermark section. The Edit Watermark window
appears.
Select the watermark you want to edit from the Current
Watermarks list and change the watermark message and
options.
Click Update to save the changes.
Advanced Printing
To change the print settings from your software
application, access printer properties. See “Printing a
Document” on page 12.
From the Extras tab, click the Edit button in the
Watermark section. The Edit Watermark window
appears.
Select the watermark you want to delete from the Current
Watermarks list and click Delete.
Click OK until you exit the Print window.
Using a Page Overlay
Using Overlays
After an overlay has been created, it is ready to be printed with
your document. To print an overlay with a document:
1
2
What is an Overlay?
Dear ABC
Regards
WORLD BEST
An overlay is text and/or images stored in the computer hard
disk drive (HDD) as a special file format that can be printed on
any document. Overlays are often used to take the place of
preprinted forms and letterhead paper. Rather than using
preprinted letterhead, you can create an overlay containing the
exact same information that is currently on your letterhead. To
print a letter with your company’s letterhead, you do not need
to load preprinted letterhead paper in the printer. You need only
tell the printer to print the letterhead overlay on your
document.
3
4
5
To use a page overlay, you must create a new page overlay
containing your logo or image.
WORLD BEST
2
3
4
5
6
7
To change the print settings from your software
application, access printer properties. See “Printing a
Document” on page 12.
Click the Extras tab.
Select the desired overlay from the Overlay drop-down
list box.
If the overlay file you want does not appear in the
Overlay list, click Edit button and Load Overlay, and
select the overlay file.
If you have stored the overlay file you want to use in an
external source, you can also load the file when you access
the Load Overlay window.
Creating a New Page Overlay
1
Create or open the document you want to print.
6
Create or open a document containing text or an image for
use in a new page overlay. Position the items exactly as
you wish them to appear when printed as an overlay.
To save the document as an overlay, access printer
properties. See “Printing a Document” on page 12.
Click the Extras tab, and click Edit button in the Overlay
section.
In the Edit Overlay window, click Create Overlay.
7
After you select the file, click Open. The file appears in the
Overlay List box and is available for printing. Select the
overlay from the Overlay List box.
If necessary, click Confirm Page Overlay When
Printing. If this box is checked, a message window
appears each time you submit a document for printing,
asking you to confirm your wish to print an overlay on your
document.
If this box is not checked and an overlay has been
selected, the overlay automatically prints with your
document.
Click OK or Yes until printing begins.
In the Create Overlay window, type a name of up to eight
characters in the File name box. Select the destination
path, if necessary. (The default is C:\Formover).
Click Save. The name appears on the Overlay List box.
NOTE: The resolution of the overlay document must be the
Click OK or Yes to finish creating.
same as that of the document you will print with the overlay.
The selected overlay downloads with your print job and
prints on your document.
The file is not printed. Instead it is stored on your
computer hard disk drive.
Deleting a Page Overlay
NOTE: The overlay document size must be the same as the
documents you print with the overlay. Do not create an overlay
with a watermark.
You can delete page overlays that you no longer use.
1
2
3
4
5
6
22
Downloaded From ManualsPrinter.com Manuals
Advanced Printing
In the printer properties window, click the Extras tab.
Click the Edit button in the Overlay section.
Select the overlay you want to delete from the Overlay
List box.
Click Delete Overlay.
When a confirming message window appears, click Yes.
Click OK until you exit the Print window.
4
Advanced
Using Windows
PostScript Driver
You can use advanced settings by clicking the Advanced
button.
(ML-2570/2571N only)
If you want to use the PostScript driver provided with your
system CD-ROM to print a document.
PPDs, in combination with the PostScript driver, access printer
features and allow the computer to communicate with the
printer. An installation program for the PPDs is provided on the
supplied software CD-ROM.
This chapter includes:
Printer Settings
You can use the printer properties window, which allows you to
access all of the printer options you need when using your
printer. When the printer properties are displayed, you can
review and change the settings needed for your print job.
• Paper/Output this option allows you to select the size of the
paper loaded in the tray.
• Graphic this option allows you to adjust the print quality for
your specific printing needs.
• Document Options this options allow you to set the PostScript
options or printer features.
Your printer properties window may differ, depending on your
operating system. This Software User’s Guide shows the
Properties window for Windows XP.
Your printer driver Properties window that appears in this
User’s Guide may differ depending on the printer in use.
NOTES:
• Most Windows applications will override settings you specify
in the printer driver. Change all print settings available in the
software application first, and change any remaining settings
using the printer driver.
• The settings you change remain in effect only while you are
using the current program. To make your changes
permanent, make them in the Printers folder.
• The following procedure is for Windows XP. For other
Windows OS, refer to the corresponding Windows User's
Guide or online help.
1. Click the Windows Start button.
2. Select Printers and Faxes.
3. Select your printer driver icon.
4. Right-click on the printer driver icon and select
Printing Preferences.
5. Change the settings on each tab, click OK.
Using Help
You can click
from the upper right corner of the window, and
then click on any setting.
23
Downloaded From ManualsPrinter.com Manuals
Using Windows PostScript Driver (ML-2570/2571N only)
5
Sharing the Printer
Locally
Setting Up a Host Computer
1
2
3
4
5
6
You can connect the printer directly to a selected computer,
which is called “host computer,” on the network.
The following procedure is for Windows XP. For other Windows
OS, refer to the corresponding Windows User's Guide or online
help.
NOTES:
• Check the Operating System(s) that are compatible with
your printer. Please refer to the OS Compatibility section of
Printer Specifications in your Printer User’s Guide.
• If you need to know the exact name of your printer, you can
check the supplied CD-ROM.
From the Start menu select Printers and Faxes.
Double-click your printer driver icon.
From the Printer menu, select Sharing.
Check the Share this printer box.
Fill in the Shared Name field, and then click OK.
Setting Up a Client Computer
1 Right-click the Windows Start button and select Explorer.
2 Open your network folder in the left column.
3 Click the shared name.
4 From the Start menu select Printers and Faxes.
5 Double-click your printer driver icon.
6 From the Printer menu, select Properties.
7 From the Ports tab, click Add Port.
8 Select Local Port and click New Port.
9 Fill in the Enter a port name field with the shared name.
10 Click OK and click Close.
11 Click Apply and click OK.
24
Downloaded From ManualsPrinter.com Manuals
Start Windows.
Sharing the Printer Locally
6
If you are a Windows user, from the Start menu, select
Programs or All Programs → your printer driver name →
Smart Panel.
Using Smart Panel
Smart Panel is a program that monitors and informs you of the
status of the printer, and allows you to customize the printer’s
settings. Smart Panel is installed automatically when you
install the printer software.
NOTES:
• If you have already installed more than one Samsung
printer, first select the printer model you want in order to
use the corresponding Smart Panel. Right-click (in Windows
or Linux) or click (in Mac OS X) the Smart Panel icon and
select your printer name.
• The Smart Panel window and its contents shown in this
Software User’s Guide may differ depending on the printer or
Operating System in use.
NOTES:
• To use this program, you need:
- Windows 98 or higher (Windows NT 4.0 can be used only
for network-supported printers.) To check for Operating
System(s) that are compatible with your printer, refer to
Printer Specifications in your Printer User’s Guide.
- Mac OS X 10.3 or higher
- Linux. To check for Linux systems that are compatible with
your printer, refer to Printer Specifications in your Printer
User’s Guide.
- Internet Explorer version 5.0 or higher for flash animation
in HTML Help.
• If you need to know the exact name of your printer, you can
check the supplied CD-ROM.
The Smart Panel program displays the current status of the
printer, the toner cartridge and various other information. You
can also change settings.
1
2
3
4
Understanding Smart Panel
1 Buy Now
You can order replacement toner cartridge(s) online.
If an error occurs while printing, Smart Panel appears
automatically, showing the error.
You can also launch Smart Panel manually. Double-click the
Smart Panel icon on the Windows task bar (in Windows), or
Notification Area (in Linux). You can also click it on the status
bar (in Mac OS X).
2 Troubleshooting Guide
You can view Help to solve problems.
3 Printer Setting (ML-2570, 2571N olnly)
You can configure various printer settings in the Printer Settings
Utility window. Any printers do not have this feature.
Double-click this icon in Windows.
NOTE: If your printer is connected to a network and you are a
Windows user, the SyncThru Web Service window appears
instead of the Printer Settings Utility window. Mac OS X and
Linux do not support network environments.
Click this icon in Mac OS X.
4 Driver Setting (Only for Windows)
You can use the printer properties window, which allows you to
access all of the printer options you need for using your
printer. For details, See “Printer Settings” on page 13.
Click this icon in Linux.
25
Downloaded From ManualsPrinter.com Manuals
Using Smart Panel
Opening the Troubleshooting
Guide
Changing the Smart Panel
Program Settings
Using the troubleshooting guide, you can view solutions for
error status problems.
Right-click (in Windows or Linux) or click (in Mac OS X) the
Smart Panel icon and select Options.
Right-click (in Windows or Linux) or click (in Mac OS X) the
Smart Panel icon and select Troubleshooting Guide.
Select the settings you want from the Options window.
Using Printer Settings Utility
Using the Printer Settings Utility, you can configure and check
print settings.
1
2
3
Right-click (in Windows or Linux) or click (in Mac OS X) the
Smart Panel icon and select Printer Setting.
Change the settings.
To send the changes to the printer, click the Apply button.
NOTES: If your printer is connected to a network, the
SyncThru Web Service window appears instead of the
Printer Settings Utility window.
Using Onscreen Help File
For more information about Printer Settings Utility, click
Downloaded From ManualsPrinter.com Manuals
.
26
Using Smart Panel
7
Using Your Printer in
Linux
Installing the Unified Linux
Driver
You can use your machine in a Linux environment.
Installing the Unified Linux Driver
1
This chapter includes:
• Getting Started
2
• Installing the Unified Linux Driver
Make sure that you connect your machine to your
computer. Turn both the computer and the machine on.
When the Administrator Login window appears, type in
root in the Login field and enter the system password.
• Using the Unified Driver Configurator
NOTE: You must log in as a super user (root) to install the
• Configuring Printer Properties
printer software. If you are not a super user, ask your system
administrator.
• Printing a Document
3
Getting Started
If the CD-ROM does not automatically run, click the
icon at the bottom of the desktop. When the Terminal
screen appears, type in:
The supplied CD-ROM provides you with Samsung’s Unified
Linux Driver package for using your machine with a Linux
computer.
If the CD-ROM is secondary master and the location to
mount is /mnt/cdrom,
After the driver is installed on your Linux system, the driver
package allows you to monitor a number of machine devices via
fast ECP parallel ports and USB simultaneously.
[[email protected] root]#mount -t iso9660 /dev/hdc /mnt/
cdrom
The Unified Linux Driver package is supplied with a smart and
flexible installation program. You don't need to search for
additional components that might be necessary for the Unified
Linux Driver software: all required packages will be carried onto
your system and installed automatically; this is possible on a
wide set of the most popular Linux clones.
[[email protected] root]#cd /mnt/cdrom/Linux
[[email protected] root]#./install.sh
NOTE: The installation program runs automatically if you
have an autorun software package installed and configured.
4
27
Downloaded From ManualsPrinter.com Manuals
Insert the printer software CD-ROM. The CD-ROM will
automatically run.
Using Your Printer in Linux
When the welcome screen appears, click Next.
5
Uninstalling the Unified Linux Driver
When the installation is complete, click Finish.
1
When the Administrator Login window appears, type in
root in the Login field and enter the system password.
NOTE: You must log in as a super user (root) to install the
printer software. If you are not a super user, ask your system
administrator.
2
Insert the printer software CD-ROM. The CD-ROM will
automatically run.
If the CD-ROM does not automatically run, click the
icon at the bottom of the desktop. When the Terminal
screen appears, type in:
If the CD-ROM is secondary master and the location to
mount is /mnt/cdrom,
The installation program has added the Unified Driver
Configurator desktop icon and Samsung Unified Driver
group to the system menu for your convenience. If you
have any difficulties, consult the onscreen help that is
available through your system menu or can otherwise be
called from the driver package windows applications,
such as Unified Driver Configurator.
[[email protected] root]#mount -t iso9660 /dev/hdc /mnt/
cdrom
[[email protected] root]#cd /mnt/cdrom/Linux
[[email protected] root]#./uninstall.sh
NOTE: The installation program runs automatically if you
have an autorun software package installed and configured.
28
Downloaded From ManualsPrinter.com Manuals
Using Your Printer in Linux
3
4
Click Uninstall.
5
Click Finish.
Click Next.
Printers Configuration
Using the Unified Driver
Configurator
Printers configuration has the two tabs: Printers and Classes.
Printers Tab
You can see the current system’s printer configuration by
clicking on the printer icon button on the left side of the Unified
Driver Configurator window.
Unified Linux Driver Configurator is a tool primarily intended for
configuring Printer.
After installing the Unified Linux driver, the Unified Linux Driver
Configurator icon will automatically be created on your desktop.
Switches to Printer
configuration.
Opening the Unified Driver
Configurator
1
2
Shows all of the
installed printer.
Double-click Unified Driver Configurator on the
desktop.
You can also click the Startup Menu icon and select
Samsung Unified Driver and then Unified Driver
Configurator.
Press each button on the Modules pane to switch to the
corresponding configuration window.
Shows the status,
model name and
URI of your printer.
You can use the following printer control buttons:
Printers Configuration button
• Refresh: renews the available printers list.
Scanners Configuration button
(for MFP device only)
• Add Printer: allows you to add a new printer.
• Remove Printer: removes the selected printer.
Ports Configuration button
• Set as Default: sets the current printer as a default
printer.
• Stop/Start: stops/starts the printer.
• Test: allows you to print a test page to check if the
machine is working properly.
• Properties: allows you to view and change the printer
properties. For details, see page 30.
3
You can use the onscreen help by clicking Help.
After changing the configurations, click Exit to close the
Unified Driver Configurator.
29
Downloaded From ManualsPrinter.com Manuals
Using Your Printer in Linux
Classes Tab
Configuring Printer Properties
The Classes tab shows a list of available printer classes.
Using the properties window provided by the Printers
configuration, you can change the various properties for your
machine as a printer.
1 Open the Unified Driver Configurator.
Shows all of the
printer classes.
2
3
If necessary, switch to Printers configuration.
Select your machine on the available printers list and click
Properties.
The Printer Properties window opens.
Shows the status of the
class and the number of
printers in the class.
• Refresh : Renews the classes list.
• Add Class... : Allows you to add a new printer class.
• Remove Class : Removes the selected printer class.
Ports Configuration
In this window, you can view the list of available ports, check
the status of each port and release a port that is stalled in busy
state when its owner is terminated for any reason.
Switches to
ports
configuration.
Shows all of the
available ports.
Shows the port type,
device connected to
the port and status
4
• Refresh : Renews the available ports list.
• Release port : Releases the selected port.
30
Downloaded From ManualsPrinter.com Manuals
Using Your Printer in Linux
The following five tabs display at the top of the window:
•General: allows you to change the printer location and
name. The name entered in this tab displays on the
printer list in Printers configuration.
•Connection: allows you to view or select another port. If
you change the printer port from USB to parallel or vice
versa while in use, you must re-configure the printer port
in this tab.
•Driver: allows you to view or select another printer
driver. By clicking Options, you can set the default
device options.
•Jobs: shows the list of print jobs. Click Cancel job to
cancel the selected job and select the Show completed
jobs check box to see previous jobs on the job list.
•Classes: shows the class that your printer is in. Click
Add to Class to add your printer to a specific class or
click Remove from Class to remove the printer from the
selected class.
Click OK to apply the changes and close the Printer
Properties Window.
Printing a Document
Printing from Applications
There are a lot of Linux applications that you are allowed to
print from using Common UNIX Printing System (CUPS). You
can print on your machine from any such application.
1 From the application you are using, select Print from the
File menu.
2 Select Print directly using lpr.
3
5
In the LPR GUI window, select the model name of your
machine from the Printer list and click Properties.
6
7
Click.
The following four tabs display at the top of the window.
•General - allows you to change the paper size, the paper
type, and the orientation of the documents, enables the
duplex feature, adds start and end banners, and changes
the number of pages per sheet.
•Text - allows you to specify the page margins and set the
text options, such as spacing or columns.
•Graphics - allows you to set image options that are used
when printing images/files, such as color options, image
size, or image position.
•Device: allows you to set the print resolution, paper
source, and destination.
Click Apply to apply the changes and close the Properties
window.
Click OK in the LPR GUI window to start printing.
The Printing window appears, allowing you to monitor the
status of your print job.
To abort the current job, click Cancel.
Printing Files
You can print many different types of files on the Samsung
machine device using the standard CUPS way - directly from
the command line interface. The CUPS lpr utility allows you do
that. But the drivers package replaces the standard lpr tool by
a much more user-friendly LPR GUI program.
To print any document file:
1 Type lpr <file_name> from the Linux shell command
line and press Enter. The LPR GUI window appears.
4
Change the printer and print job properties.
2
3
31
Downloaded From ManualsPrinter.com Manuals
Using Your Printer in Linux
When you type only lpr and press Enter, the Select
file(s) to print window appears first. Just select any files
you want to print and click Open.
In the LPR GUI window, select your printer from the list,
and change the printer and print job properties.
For details about the properties window, see page 31.
Click OK to start printing.
8
Using Your Printer with
a Macintosh
Installing printer driver for
Macintosh
Your printer supports Macintosh systems with a built-in USB
interface or 10/100 Base-TX network interface card. When you
print a file from a Macintosh computer, you can use the driver by
installing the PPD file.
ML-2510 only
The CD-ROM that came with your printer provides you with the
PPD file that allows you to use the CUPS driver or Apple
LaserWriter driver (only available when you use a printer
which supports the PostScript driver), for printing on a
Macintosh computer.
NOTE: Some printers do not support a network
interface. Make sure that your printer supports a
network interface by referring to Printer Specifications
in your Printer User’s Guide.
Install the Printer driver
1
This chapter includes:
• Installing printer driver for Macintosh
2
• Setting Up the Printer
3
• Printing
4
5
6
7
8
Make sure that you connect your printer to the computer.
Turn on your computer and printer.
Insert the CD-ROM which came with your printer into the
CD-ROM drive.
Double-click CD-ROM icon that appears on your
Macintosh desktop.
Double-click the MAC_Installer folder.
Double-click the MAC_Printer folder.
Double-click the Samsung SPL2 Installer icon.
Enter the password and click OK.
The Samsung SPL Installer window opens. Click Continue
and then click Continue.
Select Easy Install and click Install.
9
10 After the installation is finished, click Quit.
Uninstalling the Printer driver
Uninstall is required if you are upgrading the software, or if
installation fails.
1
2
3
4
5
6
7
8
9
32
Downloaded From ManualsPrinter.com Manuals
Using Your Printer with a Macintosh
Insert the CD-ROM which came with your printer into the
CD-ROM drive.
Double-click CD-ROM icon that appears on your
Macintosh desktop.
Double-click the MAC_Installer folder.
Double-click the MAC_Printer folder.
Double-click the Samsung SPL2 Installer icon.
Enter the password and click OK.
The Samsung SPL Installer window opens. Click Continue
and then click Continue.
Select Uninstall and then click Uninstall.
When the uninstallation is done, click Quit.
ML-2570/ML-2571N only
The PostScript driver CD-ROM that came with your machine
provides you with the PPD file to use the PS driver, Apple
LaserWriter driver, for printing on a Macintosh computer.
Also, it provides you with the Twain driver for scanning on a
Macintosh computer.
1
2
3
4
5
6
7
Connect your machine to the computer using the USB
cable or the Ethernet cable.
Turn on your computer and the machine.
Insert the PostScript driver CD-ROM which came with your
machine into the CD-ROM drive.
Double-click CD-ROM icon that appears on your
Macintosh desktop.
Double-click the MAC_Installer folder.
Double-click the MAC_Printer folder.
For Mac OS 8.6~9.2, double-click the Samsung LBP
Installer Classic icon.
For Mac OS 10.1~10.4, double-click the Samsung LBP
Installer OSX icon.
Click Continue.
8
9 Click Install.
10 After the installation is finished, click Quit.
Setting Up the Printer
Set up for your printer will be different depending on which
cable you use to connect the printer to your computer—the
network cable or the USB cable.
ML-2510 only
For a Network-connected Macintosh
NOTE: Some printers do not support a network
interface. Before connecting your printer, make sure
that your printer supports a network interface by
referring to Printer Specifications in your Printer User’s
Guide.
1
2
3
4
5
6
7
8
Follow the instructions on “Installing printer driver for
Macintosh” on page 32 to install the PPD and Filter files on
your computer.
Open Print Setup Utility from the Utilities folder.
Click Add on the Printer List.
Select the IP Printing tab.
Select Socket/HP Jet Direct in Printer Type.
WHEN PRINTING A DOCUMENT CONTAINING
MANY PAGES, PRINTING PERFORMANCE MAY BE
ENHANCED BY CHOOSING SOCKET FOR PRINTER
TYPE OPTION.
Enter the printer’s IP address in the Printer Address
field.
Enter the queue name in the Queue Name field. If you
cannot determine the queue name for your printer server,
try using the default queue first.
Select Samsung in Printer Model and your printer in
Model Name.
Click Add.
9
10 Your printer’s IP address appears on the Printer List, and
is set as the default printer.
For a USB-connected Macintosh
1
2
3
4
5
6
Follow the instructions on “Installing printer driver for
Macintosh” on page 32 to install the PPD and Filter files on
your computer.
Open Print Setup Utility from the Utilities folder.
Click Add on the Printer List.
Select the USB tab.
Select Samsung in Printer Model and your printer in
Model Name.
Click Add.
Your printer appears on the Printer List, and is set as the
default printer.
Downloaded From ManualsPrinter.com Manuals
33
Using Your Printer with a Macintosh
ML-2570/ML-2571N only
Printing
For a Network-connected Macintosh
NOTE: Some printers do not support a network
interface. Before connecting your printer, make sure
that your printer supports a network interface by
referring to Printer Specifications in your Printer User’s
Guide.
1
2
3
4
5
6
NOTES:
• The Macintosh printer’s properties window that appears in
this User’s Guide may differ depending on the printer in use.
However the composition of the printer properties window is
similar.
• You can check your printer name in the supplied CDROM.
Follow the instructions on “Installing printer driver for
Macintosh” on page 32 to install the PPD file on your
computer.
Open Print Center or Printer Setup Utility from the
Utilities folder.
Click Add on the Printer List.
Printing a Document
When you print with a Macintosh, you need to check the printer
software setting in each application you use. Follow these steps
to print from a Macintosh.
Select the AppleTalk tab.
The name of your machine appears on the list. Select
SEC000xxxxxxxxx from the printer box, where the
xxxxxxxxx varies depending on your machine.
Click Add.
1
If Auto Select does not work properly, select Samsung in
Printer Model and your printer name in Model Name.
3
Open a Macintosh application and select the file you want
to print.
Open the File menu and click Page Setup (Document
Setup in some applications).
Choose your paper size, orientation, scaling, and other
options and click OK.
2
Your machine appears on the Printer List and is set as the
default printer.
For a USB-connected Macintosh
1
2
3
4
5
6
Follow the instructions on “Installing printer driver for
Macintosh” on page 32 to install the PPD file on your
computer.
Open Print Center or Printer Setup Utility from the
Utilities folder.
Click Add on the Printer List.
Make sure that your
printer is selected.
Select the USB tab.
Select your printer name and click Add.
If Auto Select does not work properly, select Samsung in
Printer Model and your printer name in Model Name.
▲ Mac OS 10.3
Your machine appears on the Printer List and is set as the
default printer.
4
5
6
34
Downloaded From ManualsPrinter.com Manuals
Using Your Printer with a Macintosh
Open the File menu and click Print.
Choose the number of copies you want and indicate which
pages you want to print.
Click Print when you finish setting the options.
Changing Printer Settings
Printer Features Setting
You can use advanced printing features when using your
printer.
The Printer Features tab provides options for selecting the
paper type and adjusting print quality.
Select Printer Features from the Presets drop-down list to
access the following features:
From your Macintosh application, select Print from the File
menu. The printer name which appears in the printer properties
window may differ depending on the printer in use. Except for
the name, the composition of the printer properties window is
similar.
Layout Setting
The Layout tab provides options to adjust how the document
appears on the printed page. You can print multiple pages on
one sheet of paper.
▲ Mac OS 10.3
Select Layout from the Presets drop-down list to access the
following features. For details, see “Printing Multiple Pages on
One Sheet of Paper” on the next column.
Image Mode (ML-2570/2571N)
Image Mode allows the user to enhance printouts. The available
options are Normal and Text Enhance.
Fit to Page (ML-2570/ML-2571N)
This printer feature allows you to scale your print job to any
selected paper size regardless of the digital document size. This
can be useful when you want to check fine details on a small
document.
Paper Type
Set Type to correspond to the paper loaded in the tray from
which you want to print. This will let you get the best quality
printout. If you load a different type of print material, select the
corresponding paper type.
Resolution(Quality)
The Resolution options you can select may vary
depending on your printer model. You can select the
printing resolution. The higher the setting, the sharper the clarity
of printed characters and graphics. The higher setting also may
increase the time it takes to print a document.
▲ Mac OS 10.3
35
Downloaded From ManualsPrinter.com Manuals
Using Your Printer with a Macintosh
Printing Multiple Pages on One Sheet
of Paper
You can print more than one page on a single sheet of paper.
This feature provides a cost-effective way to print draft pages.
1
2
From your Macintosh application, select Print from the
File menu.
Select Layout.
▲ Mac OS 10.3
3
4
Select the number of pages you want to print on one sheet
of paper on the Pages per Sheet drop-down list.
Select the page order from the Layout Direction option.
5
To print a border around each page on the sheet, select
the option you want from the Border drop-down list.
Click Print, and the printer prints the selected number of
pages on one side of each page.
36
Downloaded From ManualsPrinter.com Manuals
Using Your Printer with a Macintosh
SOFTWARE
SECTION
INDEX
A
advanced printing, use 18
B
booklet printing 19
D
document, print
Macintosh 34
Windows 12
double-sided printing 20
E
Extras properties, set 16
F
favorites settings, use 17
G
Graphics properties, set 15
H
help, use 17, 23
I
install
printer driver
Macintosh 32
Windows 4
installing
Linux software 27
L
Layout properties, set
Macintosh 35
Windows 13
Linux
driver, install 27
printer properties 30
printing 31
M
Macintosh
driver
install 32
uninstall 32
printing 34
setting up the printer 33
MFP driver, install
Linux 27
N
n-up printing
Macintosh 36
Windows 18
O
orientation, print 31
Windows 13
overlay
create 22
delete 22
print 22
P
Paper properties, set 14
paper size, set 14
print 31
paper source, set 31
Windows 14
paper type, set
Macintosh 35
print 31
poster, print 19
37
Downloaded From ManualsPrinter.com Manuals
PostScript driver
installing 23
print
document 12
fit to page 20
from Macintosh 34
from Windows 12
N-up
Macintosh 36
Windows 18
overlay 22
poster 21
scaling 20
watermark 21
print resolution 31
printer driver
install
Macintosh 32
printer driver, install
Linux 27
printer properties
Linux 31
printer properties, set
Macintosh 35
Windows 13, 23
printer resolution, set
Macintosh 35
Windows 15
printer software
install
Windows 4
uninstall
Macintosh 32
Windows 11
printing
booklets 19
double-sided 20
from Linux 31
R
resolution
printing 31
S
setting
darkness 15
favorites 17
image mode 15
resolution
Macintosh 35
Windows 15
toner save 15
true-type option 15
software
install
Macintosh 32
Windows 4
reinstall
Windows 10
system requirements
Macintosh 32
uninstall
Macintosh 32
Windows 11
status monitor, use 25
T
toner save, set 15
U
uninstall, software
Macintosh 32
Windows 11
uninstalling
MFP driver
Linux 28
W
watermark
create 21
delete 21
edit 21
print 21
38
Downloaded From ManualsPrinter.com Manuals
www.samsungprinter.com
Downloaded From ManualsPrinter.com Manuals
GGGGGGGGGGGGGRev. 5.00
