Introduction
ENGLISH
READ THIS BEFORE OPERATING YOUR UNIT
This symbol is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
CAUTION
: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
Caution regarding installation
Note : For heat dispersal, do not install this unit in a confined space
such as a bookcase or similar enclosure.
Do not block ventilation openings or stack other equipment on
the top.
FOR YOUR SAFETY
EUROPE
AUSTRALIA
220 V
240 V
Units shipped to Australia are designed for operation on 230 V AC only.
To ensure safe operation, the three-pin plug supplied must be inserted only into a standard threepin power point which is effectively earthed through the normal household wiring. Extension cords
used with the equipment must be three-core and be correctly wired to provide connection to earth.
Improper extension cords are a major cause of fatalities. The fact that the equipment operates
satisfactorily does not imply that the power point is earthed and that the installation is completely
safe. For your safety, if in any doubt about the effective earthing of the power point, consult a
qualified electrician.
PAN-EUROPEAN UNIFIED VOLTAGE
All units are suitable for use on supplies 220-240 V AC.
CAUTION
Information for Users on Collection and Disposal of
Old Equipment and used Batteries
• Leave a space around the unit for sufficient ventilation.
• Avoid installation in extremely hot or cold locations, or in an area
that is exposed to direct sunlight or heating equipment.
• Keep the unit free from moisture, water, and dust.
• Do not let foreign objects in the unit.
• The ventilation should not be impeded by covering the ventilation
openings with items, such as newspapers, table-cloths, curtains,
etc.
• No naked flame sources, such as lighted candles, should be
placed on the unit.
• Please be care the environmental aspects of battery disposal.
• The unit shall not be exposed to dripping or splashing for use.
• No objects filled with liquids, such as vases, shall be placed on
the unit.
• Do not let insecticides, benzene, and thinner come in contact
with the set.
• Never disassemble or modify the unit in any way.
■Notes on the AC power cord and the wall outlet.
• The unit is not disconnected from the AC power source(mains)
as long as it is connected to the wall outlet, even if the unit has
been turned off.
• To completely disconnect this product from the mains,
disconnect the plug from the wall socket outlet.
• When setting up this product, make sure that the AC outlet you
are using is easily acceptable.
• Disconnect the plug from the wall outlet when not using the unit
for long periods of time.
These symbols on the products, packaging, and/or
accompanying documents mean that used electrical
and electronic products and batteries should not be
mixed with general household waste. For proper
treatment, recovery and recycling of old products and
used batteries, please take them to applicable
collection points, in accordance with your national
legislation.
By disposing of these products and batteries correctly,
you will help to save valuable resources and prevent
any potential negative effects on human health and the
environment which could otherwise arise from
inappropriate waste handling.
For more information about collection and recycling of
old products and batteries, please contact your local
municipality, your waste diposal service or the point of
sale where you purchased the items.
[Information on Disposal in other Countries outside the
European Union]
These symbols are only valid in the European Union. If
you wish to discard these items, please contact your
local authorities or dealer and ask for the correct
method of diposal.
Note for the battery symbol (bottom two symbol
examples):
The sign Pb below the symbol for batteries indicates
that this batteries contains lead.
2
CONTENTS
Introduction
System Connections ........................................................................................................................................................ 4
Front Panel Controls ........................................................................................................................................................ 8
Universal Remote Controls ........................................................................................................................................... 10
• OPERATING COMPONENTS WITH REMOTE CONTROL ............................................................................................... 12
• REMOTE CONTROL OPERATION RANGE ...................................................................................................................... 12
• LOADING BATTERIES ....................................................................................................................................................... 12
• USING FUNCTIONS OF REMOTE CONTROL .................................................................................................................. 13
Operations
• LISTENING TO A PROGRAM SOURCE ............................................................................................................................ 16
• LISTENING TO RADIO BROADCASTS ............................................................................................................................. 19
• LISTENING TO RDS BROADCASTS(FM ONLY) .............................................................................................................. 21
(RDS Tuner (Regional Option for some countries in Europe, etc))
• RECORDING ...................................................................................................................................................................... 23
• OTHER FUNCTIONS .......................................................................................................................................................... 23
• ROOM2 PLAYBACK ........................................................................................................................................................... 24
Troubleshooting Guide ................................................................................................................................................... 26
Specifications ................................................................................................................................................................... 27
Setup Code Table ............................................................................................................................................................ 28
3
ENGLISH
• READ THIS BEFORE OPERATING YOUR UNIT ................................................................................................................ 2
System Connections
ENGLISH
• Please be certain that this unit is unplugged from the AC outlet before making any connections.
• Be sure to observe the color coding when connecting audio, video and speaker cords.
• Make connections firmly and correctly. If not, it can cause loss of sound, noise or damage to the receiver.
1
5
2
3
4
6
8
7
1. CONNECTING ANTENNAS
• Change the position of the FM indoor antenna until you
get the best reception of your favorite FM stations.
• A 75Ω outdoor FM antenna may be used to further
improve the reception. Disconnect the indoor
antenna before replacing it with the outdoor one.
• Place the AM loop antenna as far as possible from the receiver, TV set, speaker cords and the AC
input cord and set it to a direction for the best reception.
• If the reception is poor with the AM loop antenna, an AM outdoor antenna can be used in place of
the AM loop antenna.
4
• The AUX jacks may also be connected to an additional component.
• The DVD jacks may be connected to AUDIO OUT jacks of video components such as DVD player, TV, etc.
• The TAPE IN/OUT jacks can be connected to audio recording equipment such as a tape deck, an MD recorder, etc.
■Note : Do not connect the turntable with MC type cartridge directly. If so, use a separate head amplifier or step-up
transformer.
CD
Tape deck, MD recorder, etc.
CD player
3. CONNECTING LINE OUTs
• The LINE OUT jacks can be connected to the amplifier in another room to allow you to play the same program source that is
played in the main room
■Note : To minimize hum or noise, use high quality connection cord.
Main room
Another room
This receiver
AUDIO
IN
Amplifier
5
Speakers
ENGLISH
2. CONNECTING AUDIO COMPONENTS
ENGLISH
4. CONNECTING SPEAKERS
• You can connect up to four pairs of speakers to this receiver
and select the various combinations of speakers according to
your tastes.
• The speakers C and D can be installed in the main room as
the speakers A and B can or in the another room (ROOM2)
for ROOM2 playback. (For details, refer to "ROOM2
PLAYBACK" on page 24.)
• Be sure to connect speakers firmly and correctly according to
the channel (left and right) and the polarity (+ and -).
• If the connections are faulty, no sound will be heard from the
speakers, and if the polarity of the speaker connection is
incorrect, the sound will be unnatural and lack bass.
■Notes :
• For safe amplifier operation, use the speakers with
impedance of over 8Ω when you connect a pair terminals of
SPEAKER A and B terminals or/and a pair terminals of
SPEAKER C and D terminals and use the speakers with
impedance of over 16Ω when you connect both SPEAKER A
and B terminals or/and both SPEAKER C and D terminals.
• Do not let the bare speaker wires touch each other or any
metal part of this receiver. This could damage this receiver
and/or the speakers.
Speaker A
(Main room)
Right
Speaker C
(Main room/ROOM2)
Left
Right
Right
Left
Speaker B
(Main room)
Left
Right
Left
Speaker D
(Main room/ROOM2)
5. CONNECTING PC FOR UPGRADES
• This receiver incorporates RS-232C terminal that may be
used in the future to update the operating software so that it
will be able to support new digital audio formats, external
control by using an external device and the like.
■Notes:
• Programming for upgrades and external control requires
specialized programming knowledge and for that reason we
recommend that it only be done by qualified installers. For
more information on future upgrades and external control,
visit the Sherwood web site at www.sherwoodamerica.com or
contact your dealer.
• Do not disconnect the connection cable while updating the
operating software, etc.
Should this happen, it may be result in malfunction or cause
damage to the unit.
PC with RS-232C port
6
• The multi-room system kit(sold separately ) is essential for operation from a remote location .
For information on the multi-room system kit, contact the Xantech corporation at 1-800-843-5465 or www.xantech.com.
• IR IN jack allows you to control this receiver from another room with the remote control unit.
• To control this receiver from another room with the remote control unit, connect the IR IN jack to the output of the connecting
block.
• If this receiver is located inside a cabinet or other enclosure where the infrared beams from the remote control unit cannot
enter, then operation with the remote control unit will not be possible. In such a case, connect the IR IN jack to the output of
the connecting block.
• To control other compatible component from another room with the universal remote control unit, connect the IR OUT jack to
the IR emitter.
■Note: Remote operation may become unreliable if the IR receiver is exposed to strong light such as direct sunlight or inverted
fluorescent.
7. SWITCHED AC OUTLET
• This outlet is switched on (power-on mode) and off (standby
mode) according to power control as follows (Maximum total
capacity is 100 W (0.43A)).
Standby mode - Switched AC outlet off
Power - on mode - Switched AC outlet on
8. AC INPUT CORD
• Plug the cord into an wall AC outlet.
7
ENGLISH
6. CONNECTING MULTI-ROOM SYSTEM KIT
Front Panel Controls
1
21 16
24
22 11 9
10
5
ENGLISH
3
6
7
8
17
12
13
1. POWER switch
2. POWER ON/STANDBY button/indicator
3. INPUT SELECTOR knob
4. BAND button
5. MASTER VOLUME knob
6. HEADPHONE jack
7. MUTE button/indicator
8. SPEAKER A/B, C/D SELECTOR buttons
9. TUNING UP/DOWN(▲/▼) buttons
10. PRESET UP/DOWN(▲/▼) buttons
11. MEMORY button
12. BASS UP/DOWN (▶/◀) buttons
14
15 18
19
20
13. TREBLE UP/DOWN (▶/◀) buttons
14. BALANCE UP/DOWN (▶/◀) buttons
15. TONE DIRECT button
16. TONE DIRECT indicator
17. DISPLAY button
18. ROOM 2 button
19. AUX 1, 2 IN jacks
For details, see next page.
20. Bluetooth IN connector
For details, see next page.
21. REMOTE SENSOR
22. FLUORESCENT display
For details, see below.
■FLUORESCENT DISPLAY
1. Input, frequency, volume level, operating information, etc.
2. STEREO indicator
3. TUNED indicator
4. ROOM2 indicator
5. SLEEP indicator
8
6. MEMORY indicator
7. Preset number, sleep time display
8. TONE DIRECT indicator
9. RDS indicators
(Regional option for Europe, etc.)
• The AUX 1, 2 IN jacks can be connected to additional audio
components such as an MP3 player, etc.
■ Note :
• When connecting these jacks to an MP3 player, etc., you
should use the stereo mini cord, not a mono mini cord.
■Bluetooth IN CONNECTOR
• If the Bluetooth IN connector is connected to Sherwood Audio Receiver BTR7(sold separately) with Bluetooth wireless technology, you can enjoy music
wirelessly with a music player featuring Bluetooth wireless technology such
as MP3 player, mobile phone, etc..
(For information on Sherwood Audio Receiver BT-R7, contact your dealer.)
• The Bluetooth word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Sherwood is under
license. Other trademarks and trade names are those of their respective
owners.
■ Note :
• For safe operation, turn the power off before connecting or disconnecting the
Audio Receiver BT-R7.
9
ENGLISH
■AUX 1, 2 IN JACKS
ENGLISH
Universal Remote Controls
This universal remote control can operate not only this receiver but also most popular brands of audio and video components
such as CD players, tape decks, TVs, cable boxes, VCRs, DVD players, satellite receivers, etc.
• To operate 7 components other than this receiver , you should enter the setup code for each component.
(For details, refer to “USING FUNCTIONS OF REMOTE CONTROL” on page 13.)
• The numbered buttons on the remote control have different functions in different device modes. For details, refer to
"FUNCTION TABLE of the NUMBERED BUTTONS" on the next page.
■Note : In such a case that some components do not have the REMOTE SENSOR which receives the remote signals, this
remote control cannot operate them.
10
ENGLISH
■FUNCTION TABLE of the NUMBERED BUTTONS.
■Notes :
• Some functions for each component may not be available or may work differently.
• Depending on other kinds of components that are available for each DEVICE button, some functions may not be
available or may work differently, too.
• For details about functions, refer to the operating instructions of each component.
11
ENGLISH
OPERATING COMPONENTS WITH REMOTE CONTROL
REMOTE CONTROL OPERATION RANGE
1. Enter the setup code for each component other than
• Use the remote control within a range of about 7 meters
(23 feet) and angles of up to 30 degrees aiming at the
remote sensor.
this receiver. For details, refer to “Entering a setup
code” on page 13.
2. Turn on the component you want to operate.
3. Press the DEVICE button on the remote control
corresponding to the component you wish to operate.
4. Aim the remote control at the REMOTE SENSOR of
the component you wish to control and press the
button corresponding to the operation you want.
LOADING BATTERIES
• When the remote control does not operate, the old batteries should be replaced. In this case, load new batteries within several
minutes after removing old batteries.
• If the batteries are removed or have been exhausted for a longer period of time, memorized contents will be cleared.
Should this happen, you should memorize them again.
1. Remove the cover.
2. Load two batteries ("AAA" size, 1.5V) matching the
polarity.
• Remove the batteries when they are not used for a long
time.
• Do not use the rechargeable batteries (Ni-Cd type).
• Be sure to use alkaline batteries.
12
• This remote control can control up to 8 different components.
• Before operating audio and video components other than this receiver with using this remote control, the setup code for each
component should be entered.
• For system remote control operation, "000" was stored previously in the memory of the device button "CD" for Sherwood CD
player, "DVD" for Sherwood DVD player, "AUX" for Sherwood tape deck and "TV" for Sherwood TV respectively as its factory
setup code. So, you don’t need to enter its code for each Sherwood component except in such a case that its code does not
work.
Entering a setup code
1. Turn on the component you want to operate.
4. Enter a 3 digit code, aiming the remote control at the
remote sensor on the component.
Example) When entering "001".
2. Find the setup codes according to the type and the
brand name of your component, referring to "Setup
Code Table" on page 28.
3. Press and hold down both the “ENTER/MEMORY”
button and the desired one of the DEVICE buttons for
more than 1 seconds.
• If entering is performed successfully, the LED will flicker
twice.
• To be sure that the setup code is correct, press the POWER
ON(or STANDBY) button.
If your component is tuned off, the setup code is correct.
• When your component is not turned off, repeat the above
steps 2 to 4, trying each code for your component until you
find one that works.
■Notes:
• If the LED did not flicker twice, then repeat the above
steps 3 to 4 and try entering the same code again.
• Manufacturers may use different setup codes for the same
product category. For that reason, it is important that you
check to see if the code you have entered operates as
many controls as possible. If only a few functions operate,
check to see if another code will work with more buttons.
• The LED will flicker once.
■Note : The “AUD” button is unavailable for the audio
components other than this receiver.
5. Repeat the above steps 1 to 4 for each of your
components.
13
ENGLISH
USING FUNCTIONS OF REMOTE CONTROL
ENGLISH
Using a punch-through function
This remote control may be programmed to operate either the AUDIO volume punch-through or the TV volume and/or TV
channel punch-through in conjunction with any of the eight components controlled by this remote control.
For example, since this receiver will likely be used as the sound system while watching TV, you may want to adjust this
receiver’s volume although this remote control is set to control the TV.
• When programming this remote control for the AUDIO volume punch-through, press and hold down both "AUD" button and
"VOLUME ▲" button for more than 1 second.
• If programming is performed successfully, the LED will
flicker twice.
• When you want either TV volume or TV channel punchthrough, press and hold down both "TV" button and either
"VOLUME ▲" or "CHANNEL ▲" button for more than 1
second.
■Note: If you use one of AUDIO and TV volume punchthrough functions, you cannot use the other.
■Removing a punch-through function
• When removing the AUDIO volume punch-through, press and hold down both "AUD" button and "VOLUME ▼" button for
more than 1 second.
• If removing is performed successfully, the LED will flicker twice.
• When you want to remove either TV volume or TV channel punch-through, press and hold down both "TV" button and either
"VOLUME ▼" or "CHANNEL ▼" button for more than 1 second.
14
Programming a macro function
1. Press and hold down both "ENTER/MEMORY" button
2. Press the operation buttons you want to program in
and one of three NUMERIC buttons ("1"~"3")
corresponding to "M1"~"M3" buttons for more than 1
second.
order.
■Note: You should press the corresponding DEVICE
buttons before pressing each operation button.
Example) When programming a series of button operations
into "M1" button.
Example) When playing a CD on the CD player connected
to CD jacks of this receiver.
①. Press "AUD" button to control this receiver.
②. Press "POWER ON" button to turn this receiver on.
③. Press "AUD" button to control this receiver.
④. Press "CD (2)" button to select the desired input
source.
⑤. Press "CD" button to control the CD player.
⑥. Press "POWER ON" button to turn the CD player on.
⑦. Press "CD" button to control the CD player.
⑧. Press "▶" button to start playback.
• If the macro mode is entered, the LED will flicker once.
3. Press "ENTER/MEMORY" button.
• If the programming is performed successfully, the LED will flicker twice.
■To remove a macro program
• When removing a macro program, perform the above steps 1 and 3, but
ignore the step 2.
■To change a macro program
• When a new macro program is stored into a MACRO button with
performing the above steps 1 to 3, the previous macro program is cleared
from the memory of the MACRO button.
Operating a macro function
• Aim the remote control at the REMOTE SENSORs of the
components to be controlled and press the MACRO
button you want.
Example) When pressing “M1” button.
■Notes:
• The codes programmed into a MACRO button will be
transmitted at an interval of 0.5 seconds. However, some
components may not be able to complete one operation in
0.5 seconds and may miss the next code.
In this case, the macro function cannot control the
corresponding components correctly.
• Be sure to use the remote control within the remote
control operation range of the components.
• Depending on the operation status of the components,
etc., the macro function cannot control the corresponding
components correctly.
15
ENGLISH
• The macro function enables you to program a series of button operations(up to 10) on this remote control into a single button.
• You can store up to three separate macro command sequences into “M1”, “M2” and “M3” buttons.
Operations
ENGLISH
LISTENING TO A PROGRAM SOURCE
Before operation
• Push the POWER switch.
• This unit enters the standby mode and the POWER
ON/STANDBY button lights up amber.
This means that the receiver is not disconnected from the
AC mains and a small amount of current is retained to
support the operation readiness.
• To switch the power off, push the POWER switch again.
Then the power is cut off and the POWER ON/STANDBY
button goes off.
1. In the standby mode, turn the power on.
• Each time the POWER ON/STANDBY button on the front
panel is pressed, the receiver is turned on to enter the
operating mode(the POWER ON/STANDBY button lights
up blue) or off to enter the standby mode(the POWER
ON/STANDBY button lights up amber).
• On the remote control, press the POWER ON button to
enter the operating mode or press the STANDBY button
to enter the standby mode.
or
2. Switch the desired speakers on.
• You can select the various combinations of speakers
depending on where the speakers C or/and D are
installed.
• Each time the SPEAKER A/B SELECTOR button on the
front panel is pressed, the speakers are switched on or off
as follows:
→ A/B ~ → - /- ~ → A/ - ~ → - /B ~
or
or (MAIN A/B)
or (MAIN -/-) or (MAIN A/-)
or (MAIN-/B)
( ): When the ROOM2 mode is set to on.
• Each time the SPEAKER C/D SELECTOR button on the front panel is pressed, the speakers are switched on or off as
follows:
→ ~C/D → ~ - / - → ~ C/ - → ~ - / D
or (R2 C/D)
or (R2 -/-)
or (R2 C/-)
or (R2 -/D)
( ): When the ROOM2 mode is set to on.
• When using the headphones for private listening, switch off all the speakers installed in the main room.
■Note: To use ROOM2 function, you should install speakers C or/and D in another room (ROOM2) and set the ROOM2
mode to on.(For details, refer to “CONNECTING SPEAKERS” on page 6 and “ROOM2 PLAYBACK” on page 24.)
16
6. To mute the sound.
or
or
• Each time the INPUT SELECTOR knob is rotated, the
input source is changed as follows:
TUNER
PHONO
AUX 2
AUX 1
• “MUTE” flickers.
• To resume the previous sound level, press this button
again.
• When adjusting the volume, the mutting effect is turned off.
(Frequency display)
BT-IN
CD
TAPE
DVD
AUX
7. To listen with the headphones.
4. Operate the selected component for playback.
5. Adjust the volume to a comfortable listening level.
or
• Be sure to switch off all the speakers installed in the main
room.
■Note : Be careful not to set the volume too high when
using headphones.
17
ENGLISH
3. Select the desired input source.
Adjusting the tone (bass and treble)
ENGLISH
8. Adjust the tone as desired.
9. To listen to a program source without the tone effect.
■When adjusting the bass
or
or
• “TON DIR” is displayed, “DIRECT” lights up and the sound
that bypasses the tone circuitry will be heard.
• To cancel the tone direct function, press this button again
to display “TON CTRL”, and then “DIRECT” goes off.
■When adjusting the treble
or
• Each time the buttons are pressed, the tone (BASS and
TRBL) can be adjusted within the range of -10~+10 dB.
■Notes :
• When the tone direct function is activated, the tone mode
cannot be entered and “TON DIR” flickers for 3 seconds.
• Extreme settings at high volume may damage your
speakers.
• In general, the bass and treble levels are adjusted to 0.
Adjusting the sound volume balance
10. Adjust the sound volume balance between the left and right speakers.
• Each time the buttons are pressed, the balance level can
be adjusted within the range of L 10~R 10.
■Note : In general, the balance level is adjusted to 0.
or
18
LISTENING TO RADIO BROADCASTS
1. Select the tuner and then the desired band.
2. Press the TUNING UP(▲, +)/ DOWN(▼, -) buttons for
more than 0.5 second.
or
or
• The tuner will now search until a station of sufficient
strength has been found. The display shows the tuned
frequency and "TUNED".
• If the station found is not the desired one, simply repeat
this operation.
• Weak stations are skipped during auto tuning.
• Each time this button is pressed, the tuner is automatically
selected and the band is changed as follows ;
→ FM STereo → FM MONO → AM
("ST" lights up)
("ST" goes off)
• When FM stereo broadcasts are poor because of weak
broadcast signals, select the FM mono mode to reduce the
noise, then FM broadcasts are reproduced in monaural
sound.
Auto presetting
Manual tuning
• Manual tuning is useful when you already know the
frequency of the desired station.
• After selecting the desired band, press the TUNING UP(▲,
+)/ DOWN(▼, -) buttons repeatedly until the right frequency
has been reached.
• Auto presetting function automatically searches for FM
stations only and store them in the memory.
• While listening to radio broadcasts, press and hold down the
(ENTER/)MEMORY button for more than 2 seconds.
or
or
• Then "AUTO MEM" flickers and this receiver starts auto
presetting.
• Up to 30 FM stations can be stored.
■Notes:
• FM stations of weak strength cannot be memorized.
• To memorize AM stations or weak stations, preform "Manual
presetting" procedure with using "Manual tuning" operation.
19
ENGLISH
Auto tuning
Manual presetting
• You can store up to 30 preferred stations in the memory.
2. Press the (ENTER/)MEMORY button.
ENGLISH
1. Tune in the desired station with auto or manual tuning.
or
• "MEM" is flickering for 5 seconds.
3. Select the desired preset number (1~30) and press the (ENTER/)MEMORY button.
or
• The station has now been stored in the memory.
• A stored frequency is erased from the memory by storing another frequency in its place.
• If “MEM” goes off, start again from the above step 2.
4. Repeat the above steps1 to 3 to memorize other stations.
■MEMORY BACKUP FUNCTION
The following items, set before the receiver is turned off, are memorized.
• INPUT SELECTOR settings
• Preset stations,etc.
• The ROOM2 settings
Tuning to preset stations
• After selecting the tuner as an input source, select the desired preset number.
or
20
RDS Tuner(Regional Option for some countries in Europe, etc.)
RDS(Radio Data System) is a method for sending information signals together with the transmitter signals. Your tuner is
capable of translating these signals and putting the information on the display. These codes contain the following informations.
Program Service name(PS), A list of Program Types(PTY), Traffic Announcement(TA), Clock Time(CT), Radio Text(RT).
■Note : In the other countries, RDS tuner function cannot be available.
RDS search
• Use this function to automatically search and receive the stations offering RDS services.
1. In the FM mode, select the RDS search mode.
2. While displaying "RDS SRCH".
or
• Each time this button is pressed, the search mode
changes as follows :
→ RDS SRCH → TP SRCH → PTY SRCH → OFF
• The tuner automatically searches stations offering RDS
services and the station name is displayed.
• If no other RDS station is found, "NO RDS" is displayed.
• When "RDS SRCH" is not displayed, repeat again from
the above step 1.
TP search
• Use this function to automatically search and receive the stations broadcasting the traffic program.
1. In the FM mode, select the TP search mode.
2. While displaying "TP SRCH".
or
• The tuner automatically searches stations broadcasting
the traffic program.
• "NO TRAFF"is displayed if the signal is too weak or there
are no stations broadcasting the traffic program.
• When "TP SRCH" is not displayed, repeat again from the
above step 1.
• "TP SRCH" is displayed.
21
ENGLISH
LISTENING TO RDS BROADCASTS (FM ONLY)
PTY search
• Use this function to automatically search and receive the stations broadcasting the desired program type.
In the FM mode, select the PTY search mode..
ENGLISH
1.
• "PTY SRCH" is displayed.
3. While displaying the desired program type.
2. While displaying "PTY SRCH", select the desired
program type.
or
• Each time these buttons are pressed, one of 29 different
types of programs is selected.
(NEWS, AFFAIRS, INFO, SPORT, EDUCATE, DRAMA,
CULTURE, SCIENCE, VARIED, POP M, ROCK M, EASY
M, LIGHT M, CLASSICS, OTHER M, WEATHER,
FINANCE, CHILDREN, SOCIAL, RELIGION, PHONE IN,
TRAVEL, LEISURE, JAZZ, COUNTRY, NATION M,
OLDIES, FOLK M, DOCUMENT)
• The tuner automatically searches a station offering PTY
services.
• If no station is found, "NO PROG" is displayed.
• When "PTY SRCH" is not displayed, repeat again from the
above step 1.
DISPLAY
• In the FM mode,
• Each time the DISPLAY button is pressed, the display
mode changes as follows:
Program
→ Frequency → Service name →
(PS)
Program
Clock
Radio
Type
→ Time → Text
(PTY)
(CT)
(RT)
• If the signals are too weak or no RDS service is available,
"NO NAME", "NO PTY", "NO TIME" or "NO TEXT" will be
displayed.
22
RECORDING
ENGLISH
• The volume, tone(bass, treble) and balance settings have no effect on the recording signals.
• When you select tuner, BT-IN, CD, DVD, AUX, AUX 1, AUX 2 or PHONO as a recording source, recording can be made on
the TAPE.
• The ROOM2 input source cannot be recorded onto the TAPE.
Recording with TAPE
1. Select the desired input as a recording source except
2. Start recording on the TAPE.
for TAPE.
or
3. Start play on the desired input.
OTHER FUNCTIONS
Operating the sleep timer
Adjusting the brightness of the fluorescent
display
• The sleep timer allows the system to continue to operate
for a specified period of time before automatically shutting
off.
• Each time this button is pressed, the brightness of the
fluorescent display changes as follows:
→ ON → dimmer → OFF
• Each time this button is pressed, the sleep time changes
as follows:
→ 10 → 20 → 30 → • • • → 90 → OFF
Unit : minutes
• In the display OFF mode, pressing any button will restore
the display ON mode.
• While operating the sleep timer, "
" lights up.
• When the sleep time is selected, the fluorescent display is
dimly lit.
• When the ROOM2 function is operating, it will not be
turned off by the sleep timer.
23
ENGLISH
ROOM2 PLAYBACK
• This function allows enjoying one source in the main room and playing another in a different room at the same time.
• Even when this receiver enters the standby mode, in such a case that "R2" is dimly lit, meaning only the ROOM2 circuitry
operates, the ROOM2 source can be played independently. Therefore, when you do not use the ROOM2 function, turn off the
ROOM2 function to save electricity.
• To enjoy ROOM2 source, turn on the ROOM2 function and adjust the ROOM2 settings as below.
1. Enter the ROOM2 mode.
3. Select the desired ROOM2 speakers.
or
or
• "R2 > ~ " is displayed for several seconds.
• Each time this button is pressed, the mode is changed to
the ROOM2 mode ("R2 > ~") or the main mode (main
input display).
• When "R2 > ~" is not displayed, press this button again.
■Note : Only while displaying the ROOM2 mode, you can
set the ROOM2 mode.
• Each time the SPEAKER C/D SELECTOR button is
pressed, the speakers are switched on or off as
follows:
R2 C/D
R2 - / R2 C/ R2 - /D
2. Turn on the ROOM2 mode.
4. Select the desired ROOM2 input.
■Note : Only when the ROOM2 mode is set to on, the
speakers C or/and D can be used as ROOM2
speakers.
or
or
• Each time the POWER ON/STANDBY button on the front
panel is pressed, the ROOM2 mode changes as follows :
• Each time the INPUT SELECTOR knob is rotated, the
ROOM2 input source is changed as follows :
R2 > OFF : ROOM2 off mode("R2" turns off)
TUNER
BT-IN
R2 > input display : ROOM2 on mode("R2" lights up)
• On the remote control, press the POWER ON button to
turn on the ROOM2 mode or press the STANDBY button
to turn it off.
■Note : Only while displaying the ROOM2 on mode, you
can adjust the ROOM2 settings.
24
PHONO
AUX 2
CD
TAPE
DVD
AUX 1
AUX
5. Start play on the component related to the ROOM2
7. To mute the sound.
or
6. Adjust the ROOM2 volume to a comfortable listening
level.
• While the mute function for ROOM2 is operating, "R2" is
flickering.
• To resume the previous sound level, press this button
again.
or
25
ENGLISH
source.
Troubleshooting Guide
ENGLISH
If a fault occurs, run through the table below before taking your receiver for repair.
If the fault persists, attempt to solve it by switching the receiver off and on again. If this fails to resolve the situation, consult with
your dealer. Under no circumstances should you repair the receiver yourself as this could invalidate the warranty.
PROBLEM
POSSIBLE CAUSE
REMEDY
No power
• The AC input cord is disconnected.
• Poor connection at AC wall outlet or the
outlet is inactive.
• Connect the cord securely.
• Check the outlet using a lamp or another
appliance.
No sound
• The speaker cords are disconnected.
• The volume is adjusted too low.
• The MUTE button on the remote control is
pressed to ON.
• Speakers are not switched on.
• Incorrect selection of the input source.
• Incorrect connections between the
components.
• Check the speaker connections.
• Adjust the volume.
• Press the MUTE button to cancel the
muting effect.
• Switch on the desired speakers.
• Select the desired input source correctly.
• Make connections correctly.
Stations cannot be
received
• No antenna is connected.
• The desired station frequency is not tuned
in.
• The antenna is in wrong position.
• Connect an antenna.
• Tune in the desired station frequency.
• An incorrect station frequency has been
memorized.
• The memorized stations are cleared.
• Memorize the correct station frequency.
Poor FM reception
• No antenna is connected.
• The antenna is not positioned for the best
reception.
• Connect an antenna.
• Change the position of the antenna.
Continuous hissing noise
during FM reception,
especially when a stereo
broadcast is received.
• Weak signals.
• Change the position of the antenna.
• Install an outdoor antenna.
Continuous or intermittent
hissing noise during AM
reception, especially at
night.
• Noise is caused by motors, fluorescent
lamps or lightning, etc.
• Keep the receiver away from noise
sources.
• Install an outdoor AM antenna.
No recording
• Incorrect selection between the
components.
• Incorrect operation of each component for
playback and recording.
• Make connections correctly.
• Batteries are not loaded or exhausted.
• The remote sensor is obstructed.
• Replace the batteries.
• Remove the obstacle.
Preset stations cannot be
received
Remote control unit does
not operate.
26
• Move the antenna and retry tuning.
• Memorize the stations again.
• Operate each component correctly.
Specifications
■ AMPLIFIER SECTION
| 2 X 100 W
■ FM TUNER SECTION
• Tuning frequency range
| 87.5~108 MHz
• Usable sensitivity, THD 3%, S/N 26 dB
| 15 dBf
• 46 dB quieting sensitivity, mono/stereo
| 25.2/45.2 dBf
• Signal to noise ratio, 65 dBf, mono/stereo
| 68/65 dB
• Total harmonic distortion, 65 dBf, 1 kHz, mono/stereo
| 0.5/0.8%
• Frequency response, 20 Hz~14 kHz
| ±3 dB
• Stereo separation, 1 kHz
| 30 dB
• Capture ratio
| 4 dB
• IF rejection ratio
| 75 dB
■ AM TUNER SECTION
• Tuning frequency range
| 522~1611 kHz
• Usable sensitivity , S/N 20 dB | 55 dBµ/m
• Signal to noise ratio
| 50 dB
• Selectivity
| 30 dB
■ GENERAL
• Power supply
| 230 V~ 50 Hz
• Power consumption
| 330 W
• Switched AC outlet
| TOTAL 100 W (0.43 A)
• Dimensions (W×H×D, including protruding parts)
• Weight (Net)
| 8.6 kg(19 lbs)
|
440X141X370mm(17-3/8X5-1/2X14-1/2 inches)
Note: Design and specifications are subject to change without notice for improvements.
27
ENGLISH
• Power output, 8Ω, THD 0.7 %, 20 Hz~20 kHz, only a pair of speakers driven
• Total harmonic distortion, 8Ω, @ -3dB, 20 Hz~20 kHz
| 0.05 %
• Intermodulation distortion
60 Hz : 7 kHz= 4 : 1 SMPTE, 8Ω, 100 W
| 0.03 %
• Input sensitivity, 47 kΩ
Phono(MM)
| 2.5 mV
Line(CD,DVD,TAPE,AUX)
| 220 mV
• Signal to noise ratio, IHF "A" weighted
Phono(MM)
| 75 dB
Line(CD,DVD,TAPE,AUX)
| 98 dB
• Frequency response
Phono(MM), RIAA, 20 Hz~20 kHz
| ±0.3 dB
Line(CD,DVD,TAPE,AUX), 10 Hz~100 kHz
| ±3 dB
• Output level
TAPE OUT, 2.2 kΩ
| 200 mV
• Bass/Treble control, 100 Hz/10 kHz
| ±10 dB
Setup Code Table
ENGLISH
TV
ADMIRAL
AKAI
ALBA
ALBIRAL
ALCATEL
AMSTRAD
ANAM
ARC EN CIEL
ARISTONA
ARTHUR MARTIN
ASA
ATLANTIC
AUDIOSONIC
AUSIND
AUTOVOX
BAIRD
BASICLINE
BAUR
BEKO
BLAUPUNKT
BRANDT
BRION VEGA
BRUNS
BSR
BUSH
CENTURY
CGE
CIHAN
CLARIVOX
CONDOR
CONTEC
CONTINENTAL
EDITION
CROSLEY
CROWN
CTC CLATRONIC
DAEWOO
DECCA
DEGRAAF
DIXI
DRYNATRON
DUAL
DUAL-TEC
DUMONT
ELBE
ELBIT
050
093
068
116
022
000
155
028
099
078
053
125
050
099
054
053
099
083
006
011
023
094
028
050
048
059
033
098
016
065
048
099
087
028
101
147
046
089
099
036
049
049
099
096
046
016
065
134
049
021
156
039
049
ELCIT
123
ELMAN
ELTA
EMERSON
ERRES
EUROPHON
157
043
050
145
019
081
142
149
FERGUSON
139
128
055
111
117
120
122
123
FIDELITY
FINLUX
057
113
134
144
055
019
057
049
100
039
102
040
111
043
114
145
050
110
068
101
101
132
124
050
124
074
079
079
136
132
FISHER
FORGESTONE
FORMENTI
FORTRESS
FRABA
FRONTECH
FUJITSU
FUNAI
GBC
GEC
GELOSO
GOLDSTAR
069
081
GOODMANS
GORENJE
GREATZ
136
116
111
GRANADA
GRUNDIG
039
050
060
040
109
063
043
115
145
081
HANSEATIC
HANTAREX
HEMMERMANN
HIFIVOX
HINARI
HITACHI
118
090
141
099
050
116
132
057
HYPER
IMPERIAL
INGELEN
073
28
046
132
046
090
158
049
098
132
146
116
099
034
113
015
149
099
137
075
054
025
054
109
099
103
092
076
033
066
001
129
033
115
094
114
033
111
097
127
028
158
014
056
132
093
016
001
130
097
103
050
109
127
097
099
051
115
040
149
149
046
073
048
041
150
057
061
053
074
050
055
079
052
057
109
109
136
053
109
111
125
109
132
017
090
060
115
134
099
152
077
134
090
049
075
109
134
049
134
057
122
123
128
058
060
142
058
108
112
099
049
109
139
043
045
034
139
084
145
143
036
110
091
081
090
099
067
081
145
117
088
124
109
079
122
132
128
133
129
132
098
142
046
059
132
060
109
003
077
049
136
058
130
099
125
100
082
047
039
033
033
109
134
099
101
058
134
050
088
INTERFUNK
IRRADIO
ITT
JVC
KTV
KAISUI
KARCHER
KENDO
KENNEDY
KORTING
KRIESLER
LENOIR
LOEWE OPTA
LOGIK
LUMA
LUXOR
MAGNADYNE
MAGNAFON
MARANTZ
MATSUI
McMICHAEL
MEMOREX
METZ
MINERVA
MISTRAL
MITSUBISHI
MIVAR
MULTITECH
MURPHY
MAONIS
NATIONAL
NEC
NECKERMANN
NEI
NIKKAI
NOBLEX
NOBLIKO
NOGAMATIC
NOKIA
093
090
047
142
093
001
123
135
033
099
006
006
098
144
050
099
078
099
008
072
118
049
058
135
046
127
046
049
158
134
088
090
094
094
149
033
118
097
046
134
096
042
033
099
049
060
015
098
028
001
123
135
098
097
099
143
077
NORDMENDE
049
123
143
140
128
083
154
050
128
053
058
148
089
145
129
077
105
129
058
091
090
109
130
109
OCEANIC
ONCEAS
OPTONICA
ORION
OSAKI
OSIO
OSUME
OTTO VERSAND
P.T ACTTRON
PAEL
PANASONIC
019
059
049
097
149
120
139
083
097
132
097
099
090
109
111
050
019
142
PATHE CINEMA
PERDIO
PHILCO
149
047
049
050
115
PHILIPS
134
117
120
123
129
PHOENIX
PHONOLA
103
050
109
115
099
051
053
115
106
060
118
068
050
100
114
057
133
058
035
119
099
099
047
148
115
115
049
080
077
136
050
138
144
104
085
050
019
109
110
134
139
120
136
046
039
140
128
083
122
134
099
043
058
148
089
053
145
105
129
PIONEER
PRANDONIPRINCE
PREMIER
PRINCE
PROTECH
PYE
QUASAR
QUELLE
114
062
RADIOLA
RADIOMARELLI
057
081
109
130
RANK
RBM
REDIFFUSION
REX
ROBOTRON
RTF
SABA
122
134
SAISHO
SALORA
29
028
091
109
099
137
000
060
077
087
033
065
099
030
121
099
060
016
079
009
049
078
099
099
078
020
098
124
098
049
099
149
046
047
057
118
099
078
046
127
074
074
062
096
134
048
048
028
043
086
158
053
125
032
081
064
039
043
145
131
059
118
068
127
090
047
049
109
139
095
104
107
109
116
132
030
132
010
050
088
053
049
101
136
013
019
050
109
124
018
142
024
148
099
149
109
050
111
019
125
142
149
049
145
091
097
053
115
097
054
049
078
097
099
058
123
049
053
134
050
019
142
051
100
111
073
050
053
049
112
074
019
077
053
113
128
142
097
132
103
050
109
062
123
144
134
019
141
110
069
050
050
031
097
091
099
139
128
032
050
081
118
117
135
037
145
039
115
040
120
119
120
083
068
122
090
123
053
042
126
111
123
134
148
055
114
149
ENGLISH
INNO HIT
SAMBERS
SAMPO
SAMSUNG
ENGLISH
SANYO
SBR
SCHAUB LORENZ
SCHNEIDER
SEG
SEI
SELECO
SHARP
Sherwood
SIAREM
SICATEL
SIEMENS
SIERA
SILVER
SINGER
SINUDYNE
SONOKO
SONY
STERN
TANDBERG
TANDY
TASHIKO
TATUNG
TEC
TELEAVIA
TELEFUNKEN
TELETECH
TELEVIDEON
TENSAI
THOMSON
THORNFERGUSON
TOCOM
TOSHIBA
TRANS
CONTINENTS
TRIUMPH
UHER
ULTRA VOX
046
121
015
090
001
060
049
001
129
096
141
132
046
158
016
069
033
000
046
116
005
087
099
078
054
016
158
049
146
096
133
099
002
099
096
028
081
028
090
099
049
012
145
097
051
053
115
077
026
151
002
113
142
058
130
099
109
099
153
005
118
148
109
134
049
142
054
077
136
033
071
149
122
044
054
088
123
048
136
128
050
125
052
149
019
078
019
141
110
059
096
134
087
144
UNIVERSUM
UNIVOX
VEGAVOX
VOXSON
WATSON
WATT RADIO
WEGA
WHITE
WESTINGHOUSE
YOKO
ZANUSSI
ZOPPAS
050
109
115
094
036
100
111
114
049
050
019
142
149
046
046
090
007
144
050
050
109
059
109
127
027
019
033
110
038
069
118
134
060
033
060
099
039
137
063
132
040
065
115
118
043
145
091
041
145
150
086
091
053
109
111
125
028
091
032
081
039
040
014
061
029
004
040
116
041
149
054
086
150
016
033
070
074
098
158
052
098
097
053
134
111
046
125
099
050
109
034
054
077
051
109
116
127
099
099
096
096
111
144
144
019
019
110
110
069
134
134
042
008
011
009
042
045
018
011
042
014
014
022
020
052
032
033
056
031
052
031
054
045
018
025
034
134
099
VCR
137
097
092
116
079
050
111
046
033
AKAI
ALBA
AMSTRAD
ANITSCH
ARC EN CIEL
ARISTONA
ASA
AWIA
BAIRD
BAUER. BOSCH
BLAUPUNKT
BRANDT
ELECTRONIQUE
BRIONVEGA
BUSH
C.EDISON
CANON
CAPEHART
CGE
CONTINENTAL
EDISON
CRAIG
CURTIS MATHES
DAEWOO
DAYTRON
DECCA
DEGRAAF
DUAL
DUMONT
DYNATECH
EMERSON
FERGUSON
FIDELITY
FINLANDIA
FINLUX
FISHER
043
057
120
30
042
041
008
041
014
020
011
042
000
019
001
020
011
003
042
003
011
002
042
011
003
003
000
042
033
043
043
055
056
052
040
020
042
052
056
013
052
020
021
042
006
052
011
018
010
059
011
030
019
052
018
006
003
011
005
018
011
036
HANSEATIC
HARMANKARDON
HIFIVOX
HINARI
HITACHI
IMPERIAL
INGELEN
INGERSOL
ITT
JENSEN
JVC
KENWOOD
KRIESLER
KUBA
LLOYD
LOEWE OPTA
LOGIK
LUXOR
MAGNADYNE
MAGNASONIC
MAGNAVOX
MARANTZ
MATUI
MEMOREX
METZ
MGA
MINERVA
MINOLTA
MITSUBISHI
MTC
MULTITECH
MURPHY
NAONIS
NATIONAL
NEC
NECKERMANN
NOGAMATIC
NOKIA
NORDMENDE
OPTONICA
ORION
011
019
014
004
008
041
003
014
054
043
004
042
002
006
011
042
027
005
033
042
042
005
045
043
011
014
008
033
041
038
019
004
010
000
014
017
055
006
060
011
008
011
042
040
004
002
042
003
052
039
045
002
062
011
042
005
043
046
056
018
018
050
052
038
055
031
053
056
008
007
052
024
011
027
042
056
052
038
041
038
042
056
050
052
056
042
031
060
060
030
052
063
018
027
038
029
014
025
003
043
046
027
005
031
OSAKI
OTTO VERAND
P. CINEMA
PALLADIUM
PANASONIC
PATHE MARCONI
PENTAX
PERDIO
PHILIPS
PHONOLA
PIONEER
PORTLAND
PROLINE
PYE
QUARTZ
QUELLE
RADIOLA
RADIOMARELLI
RCA
REALISTIC
057
REX
SABA
SAISHO
SALORA
SAMSUNG
SANSUI
SANYO
SBR
SCHAUB LORENZ
SCHNEIDER
SEI-SINUDYNE
SELECO
SENTRA
SHARP
SHINTOM
SIEMENS
SIERA
SINUDYNE
SONY
STERN
STS
SUNKAI
SYLVANIA
SYMPHONIC
TASHIKO
TATUNG
TEAC
TEKNIKA
TELEAVIA
TELEFUNKEN
TENOSAL
031
018
031
011
054
045
037
054
007
017
013
011
049
056
052
042
041
056
005
033
042
046
010
060
014
052
041
038
056
052
042
052
042
056
050
052
053
035
025
027
31
011
043
014
041
023
042
006
011
012
031
014
060
020
011
014
005
002
045
041
019
000
046
042
039
002
005
013
042
000
018
041
008
027
042
020
045
008
014
045
027
044
042
006
025
011
011
011
011
011
011
042
042
008
014
051
056
007
040
052
014
045
046
018
045
018
029
031
045
018
029
031
044
031
054
003
005
011
013
056
042
010
017
019
060
003
029
042
011
052
056
025
052
027
035
032
061
005
025
038
056
045
050
031
052
038
056
052
046
105
048
043
031
055
031
054
038
015
056
016
052
026
028
017
017
042
042
056
056
052
052
029
045
ENGLISH
FUNAI
GE
GENERAL
GOLDSTAR
GOODMANS
GRAETZ
GRANADA
GRUNDIG
ENGLISH
THOMSON
THORNFERGUSON
TOSHIBA
TOTELEVISION
UHER
ULTRA VOX
UNITECH
UNIVERSUM
URANYA
VECTOR
VICTOR
VIDITAL
WESTING HOUSE
WARDS
YAMAHA
ZANUSSI
ZENDER
ZOPPAS
042
056
052
039
036
001
013
042
041
013
041
041
004
042
041
041
019
004
042
052
042
042
059
030
052
034
042
056
017
058
052
CBL
ABC
014
Allegro
Archer
Bell&Howell
Century
Citizen
Comtronics
Contec
Easten
Emerson
Everquest
Focus
Garrard
Gemini
General Instrument
GoldStar
Goodmind
Hamlin
Hitachi
Hytex
Jasco
Jerrold
043
060
042
056
052
056
DVD
DENON
GE
JVC
LG
MAGNAVOX
MITSUBISHI
ONKYO
PANASONIC
PHILIPS
PIONEER
PROSCAN
RCA
SAMSUNG
SHERWOOD
SONY
THOMSON
TOSHIBA
VIETA
YAMAHA
ZENITH
017
003
007
011
019
001
009
015
019
002
003
003
016
000
022
005
003
006
014
019
011
004
Memolex
Movie Time
NSC
Oak
Optimus
Panasonic
Paragon
Philips
Pioneer
Popular Mechanics
Pulsar
Quasar
RCA
Radio Shack
Recoton
Regal
Regency
Rembrandt
Runco
SL Marx
Smasung
Scientific Atlanta
Signal
Signature
Sprucer
Starcom
010
023
004
004
008
010
020
011
021
012
013
014
004
010
32
002
007
018
018
009
018
018
014
011
001
026
010
022
018
010
033
017
026
012
006
007
010
002
006
000
015
015
011
031
000
000
018
017
022
000
000
031
010
022
012
001
006
000
014
017
003
010
006
031
002
003
006
021
026
009
008
030
276
040
006
034
020
004
013
018
007
034
021
033
032
016
031
021
014
025
021
026
028
030
027
020
014
023
014
010
009
010
010
010
015
014
007
000
010
018
007
153
015
000
022
014
026
MAGAI
MARANTZ
MASPRO
MATSUSHITA
METZ
MINERVA
MULTISTAR
MURATO
NEC
NEIRU
NOKIA
NORSAT
PACE
PANASONIC
PHILIPS
PHONOLA
PROSAT
PYE
QUADRAL
QUELLE
RADIOLA
REDIFFUSION
SABA
SALORA
SAMSUNG
SAT PARTNER
SATPORTNER
SCHAUB LORENZ
SCHNEIDER
SIEMENS
SIERA
SILVA
SKY
STARCOM
STARSAT
TECHNISAT
TELEFUNKEN
TELESYSTEM
THORNFERGUSON
008
019
024
SAT
ALBA
AMSTRAD
ARCON
ARISTONA
ASTRA
BLAUPUNKT
BUSH
CH.MASTER
CITY COM
DDC
DYNASAT
ECHOSTAR
EMME ESSE
FAIT
FERGUSON
FINLUX
FRACARRO
FTE
GOLDSTAR
GRAETZ
GROTHUSEN
GRUNDIG
HINARI
HIRSCHMANN
HITACHI
INGELEN
ITT
ITT-NOKIA
JERROLD
KATHREIN
KOSMOS
KRIESLER
LENCO
LUXOR
030
008
021
016
028
033
016
030
005
030
005
002
005
005
014
006
005
022
004
026
004
033
030
003
013
026
034
032
038
005
004
016
004
026
019
027
009
032
020
041
007
016
013
017
018
036
018
021
037
016
006
TRIAD
UNIDEN
UNITED CABLE
V TECHNOLOGY
VORTEC
ZENDER
037
018
014
022
026
037
023
021
037
33
022
012
016
000
036
036
022
004
040
021
026
015
001
032
003
016
030
016
030
036
016
015
035
026
003
004
021
026
005
033
016
004
039
038
022
003
025
005
010
043
004
022
038
004
003
022
ENGLISH
Stargate
Starquest
TV86
Teleview
Tocom
Toshiba
Tusa
Unika
United Artists
Universal
Viewstar
Zenith
Zentek
037
042
016
017
011
012
029
014
041
016
024
025
018
044
017
018
022
037
016
036
021
ENGLISH
CD
ADCOM
AIWA
AKAI
AUDIO
ARC EN CIEL
DENON
FISHER
H/K
JVC
KENWOOD
MARANTZ
MONDIAL
AND
NAKAMICHI
NIKKO
ONKYI
PANASONIC
PHILPS
PIONEER
RCA
REALISTIC
SANSUI
SHARP
SHERWOOD
SONY
TEAC
TECHNICS
VICTOR
YAMAHA
AUX-TAPE/MD
021
045
046
016
036
230
054
006
017
028
003
015
033
048
049
016
013
051
014
005
007
045
040
019
000
058
050
055
051
001
044
SHERWOOD
039
022
014
027
012
034
020
014
047
001
010
002
042
037
052
011
008
009
041
053
035
030
029
021
019
025
026
052
043
016
AUX-LD
018
DAEWOO
DENON
GOLDSTAR
KENWOOD
MAGNAVOX
OPTIMUS
PANASONIC
PHILIPS
POINNEER
RCA
REALISTIC
SAMSUNG
SHARP
TECHINCS
TOSHIBA
YAMAHA
016
023
024
032
004
031
006
038
056
000(for tape deck)
015 016(for MD recorder)
057
34
002
012
004
003
010
007
013
010
000
006
007
001
003
013
003
008
009
005
011
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
