INTELLIGENT DIAGNOSIS AND SMART DETECTION OF CRACK IN A STRUCTURE

INTELLIGENT DIAGNOSIS AND SMART DETECTION OF CRACK IN A STRUCTURE
INTELLIGENT DIAGNOSIS AND SMART
DETECTION OF CRACK IN A STRUCTURE
FROM ITS VIBRATION SIGNATURES
Harish Chandra Das
Intelligent Diagnosis and Smart Detection of Crack
in a Structure from its Vibration Signatures
Thesis Submitted to the
Department of Mechanical Engineering
National Institute of Technology, Rourkela
for award of the degree
of
Doctor of Philosophy
by
Harish Chandra Das
under the guidance of
Prof. Dayal R. Parhi
&
Prof. R.C.Kar
Department of Mechanical Engineering
National Institute of Technology Rourkela
Orissa (India)-769008
December 2009
Declaration
I hereby declare that this submission is my own work and that, to the best of my
knowledge and belief, it contains no material previously published or written by another
person nor material which to a substantial extent has been accepted for the award of any
other degree or diploma of the university or other institute of higher learning, except where
due acknowledgement has been made in the text.
(Harish Chandra Das)
Date:
Certificate
This is to certify that the thesis entitled, “Intelligent Diagnosis and Smart Detection of
Crack in a Structure from its Vibration Signatures”, being submitted by Mr. Harish
Chandra Das to the Department of Mechanical Engineering, National Institute of
Technology, Rourkela, for the partial fulfillment of award of the degree Doctor of
Philosophy, is a record of bona fide research work carried out by him under our supervision
and guidance.
This thesis in our opinion, is worthy of consideration for award of the degree of Doctor of
Philosophy in accordance with the regulation of the institute. To the best of our knowledge,
the results embodied in this thesis have not been submitted to any other University or
Institute for the award of any degree or diploma.
Prof. D.R. Parhi
(Supervisor)
Prof. R.C. Kar
(Co-Supervisor)
iv
Acknowledgements
I would like to express my gratitude to all those people who made this research possible and
those who have made my experience in the Institute one that I will always remember fondly.
First and foremost I wish to thank my supervisor, Prof. Dayal R. Parhi, Professor of
Mechanical Engineering, N.I.T, Rourkela, for kindly providing me an opportunity to work
under his supervision and guidance. His patience, stimulating suggestions and
encouragement helped me in all the time of research for and writing of this thesis.
I wish to thank my second supervisor, Dr. R.C. Kar for his priceless suggestions and for
directing the PhD on to the right track. He has been supportive since the days I began
working on this research.
I am thankful to Prof. Sunil Kumar Sarangi, Director of National Institute of Technology, for
giving me an opportunity to work under the supervision of Prof. Dayal R. Parhi. I am
thankful to Prof. R.K. Sahoo, Head of the Department, Department of Mechanical
Engineering, for his moral support and valuable suggestions regarding the research work.
I express my deepest gratitude to Prof. Manojranjan Nayak, President, Siksha O Anusandhan
University, Bhubaneswar, Orissa, who gave me the opportunity of pursuing this research
work .His constant inspiration, encouragement and valuable advice have profoundly
contributed to the completion of the present thesis.
I am thankful to Mr. Amiya kumar Dash, research scholar, who has helped me a lot in
compilation of this thesis.
Finally I would like to thank my wife, Mrs. Lipika Das, for all her support and
encouragement. I thank my daughter, Ms. Barsha Das and son Mr. Adarsh Das, for giving me
so much joy now and so much to look forward to.
v
Synopsis
In recent years, there has been a growing interest in the development of structural health
monitoring for vibrating structures, especially crack detection methodologies and on-line
diagnostic techniques. In the current research, methodologies have been developed for
damage detection of a cracked cantilever beam using analytical, fuzzy logic, neural network
and fuzzy neuro techniques. The presence of a crack in a structural member introduces a
local flexibility that affects its dynamic response. For finding out the deviation in the
vibrating signatures of the cracked cantilever beam the local stiffness matrices are taken into
account. Theoretical analyses have been carried out to calculate the natural frequencies and
mode shapes of the cracked cantilever beam using local stiffness matrices. Strain energy
release rate has been used for calculating the local stiffness of the beam. The fuzzy inference
system has been designed using the first three relative natural frequencies and mode shapes
as input parameters. The output from the fuzzy controller is relative crack location and
relative crack depth. Several fuzzy rules have been developed using the vibration signatures
of the cantilever beam. A Neural Network technique using multi layered back propagation
algorithm has been developed for damage assessment using the first three relative natural
frequencies and mode shapes as input parameters and relative crack location and relative
crack depth as output parameters. Several training patterns are derived for designing the
Neural Network. A hybrid fuzzy-neuro intelligent system has been formulated for fault
identification.
The fuzzy controller is designed with six input parameters and two output parameters. The
input parameters to the fuzzy system are relative deviation of first three natural frequencies
and first three mode shapes. The output parameters of the fuzzy system are initial relative
crack depth and initial relative crack location. The input parameters to the neural controller
are relative deviation of first three natural frequencies and first three mode shapes along with
the interim outputs of fuzzy controller. The output parameters of the fuzzy-neuro system are
final relative crack depth and final relative crack location. A series of fuzzy rules and
training patterns are derived for the fuzzy and neural system respectively to predict the final
crack location and final crack depth.To diagnose the crack in the vibrating structure multiple
vi
adaptive neuro-fuzzy inference system (MANFIS) methodology has been applied. The final
outputs of the MANFIS are relative crack depth and relative crack location. Several hundred
fuzzy rules and neural network training patterns are derived using natural frequencies, mode
shapes, crack depths and crack locations.
The proposed research work aims to broaden the development in the area of fault detection of
dynamically vibrating structures. This research also addresses the accuracy for detection of
crack location and depth with considerably low computational time. The objective of the
research is related to design of an intelligent controller for prediction of damage location and
severity in a uniform cracked cantilever beam using AI techniques (i.e. Fuzzy, neural,
adaptive neuro-fuzzy and Manfis).
vii
