SUPPRESSION OF BLOCKING ARTIFACT IN COMPRESSED IMAGE Master of Technology

SUPPRESSION OF BLOCKING ARTIFACT IN COMPRESSED IMAGE Master of Technology
SUPPRESSION OF BLOCKING ARTIFACT IN
COMPRESSED IMAGE
A thesis submitted in partial fulfilment
of the requirements for the award of the degree of
Master of Technology
in
Electronics and Communication Engineering
(Specialization: Signal & Image Processing)
by
JYOTI MISHRA
Roll No: 212EC6440
Department of Electronics & Communication Engineering
National Institute of Technology
Rourkela - 769008, Odisha, INDIA
May 2014
SUPPRESSION OF BLOCKING ARTIFACT IN
COMPRESSED IMAGE
A thesis submitted in partial fulfilment
of the requirements for the award of the degree of
Master of Technology
in
Electronics and Communication Engineering
(Specialization: Signal & Image Processing)
by
JYOTI MISHRA
Roll No: 212EC6440
Under the Supervision of
Prof. SUKADEV MEHER
Department of Electronics & Communication Engineering
National Institute of Technology
Rourkela - 769008, Odisha, INDIA
May 2014
Department of Electronics & Communication Engineering
National Institute of Technology
Rourkela - 769008, Odisha, INDIA
CERTIFICATE
This is to certify that the Thesis Report entitled “Suppression Of Blocking Artifact In
Compressed Image” submitted by Ms. JYOTI MISHRA bearing roll no. 212EC6440 in
partial fulfilment of the requirements for the award of Master of Technology in Electronics and
Communication Engineering with specialization in “Signal & Image Processing” during
session 2012-2014 at National Institute of Technology, Rourkela is an credible work carried
out by her under my supervision and direction.
Dr. Sukadev Meher
Place:
Professor
Date:
Dept. of Electronics and Comm. Engineering
National Institute of Technology
Rourkela-769008
v
Acknowledgement
The actual spirit of achieving a goal is through the way of caliber and abstemious
discipline. I would have never succeeded in completing my target without the collaboration,
inspiration and lessen provided to me by variegated personalities.
I am grateful to countless parochial and worldwide squint who have contributed
towards framing this thesis. At the outset, I would like to express my heartfelt thanks to Dr.
Sukadev Meher for his enlightenment during my thesis work. As my supervisor, he has
constantly encouraged me to remain focused on achieving my target. His observations and
comments helped me to establish the overall orientation of the research and to move forward
with investigation in depth. He has helped me profoundly and been a source of knowledge.
I am also thankful to all the professors of the department for their brace and uplifting. I
must acknowledge the academic resources that I have got from NIT Rourkela. I would like to
thank administrative and technical staff members of the Department who have been kind
enough to advise and help in their respective roles.
I am really thankful to my all respectable laboratory representatives. My sincere thanks
to everyone who has provided me with kind words, a welcome ear, new ideas, useful criticism,
or their invaluable time, I am truly indebted.
My deep-rooted regard goes to my family for their unflagging love and support
throughout my life, this disquisition is simply impossible without them. I am indebted to my
father and Mother Mr. Uday Narayan Mishra and Nirmala Mishra, who allow me to attain such
a higher study and also provided me all supports during my study. My full enthusiasm to the
work would have not been possible without their blessings and moral support. This thesis is
dedicated to them who did not forget to keep me in their hearts when I could not be beside
them.
Last but not least, heartful thanks be to BABAJI for my life through all tests in the past
years. You have made my life more plentiful. May your name be dignified, honored, and
glorified.
Date:
Place:
Roll No: 212EC6440
Dept. of ECE
NIT, Rourkela
vi
ABSTRACT
Image compression is actually major content for certain perspectives in the area of
interactive media communication. Image processing is the mechanism for handling different
kinds of images, processed images can be stored routinely and conveyance of such kind of
images from one place to another place becomes simple to the user.
By using image
compression technique we are able to represent the image with lesser number of data bits.
image compression execution can cut down the bandwidth and the volume of the data to
be transmitted. (BDCT) block-based discrete cosine transform is long establish used transform
for the two static and uninterrupted images. While we compress any kind of image by lossy
type of image compression technique then there will be loss of data bits, we have to
confrontation unwanted artifacts ringing and blocking artifacts and when we want to restore
such kind of image then we face problem of blurring of images, which is sometimes called as
the annoying artifacts problem near the block of the image. The recovered images from jpeg
compression create blocking artifact near block boundaries of the image in high compression.
Artifacts take on several forms in images. We are going to focus on blocking artifacts
at medium and high level compression. Various types of images can be processed and we can
diminish blocking artifacts up to tolerable level. Some standard techniques MPEG and JPEG
are used in video and image processing field respectively for the compression. Lossy image
compression technique is used in photographic images because loss of bits is tolerable, Since
last few decades, image compression in real time applications has been a provocative field for
image processing professionals. To recover original image decompression succeed by the
different post processing techniques. High quality image communication with low-bit rate is
securing exclusive attention in the nearly created utilizations such as video conferencing, video
phone and interactive TV and latest utilizations such as telemedicine, picture archiving, and
communications scheme(PACS).
The reduction in blocking artifact is classified by three parameters, PSNR (Peak Signal
to Noise Ratio), MSSIM (Mean structure similarity index based on human visual perception)
and block boundary measure (BBM).
Keywords- DCT, JPEG, Blocking Artifacts, PSNR, BBM, MSSIM, HVS
