**D**

**E V E L O P M E**

**N**

**T O F**

**I**

**I**

**M A G E**

**C**

**O M P R E S S**

**I**

**I**

**L**

**O**

**O**

**N**

**W**

**P**

**O W**

**E R**

**T**

**E C H N**

**I**

**I Q U E**

**S**

**S u n i i l l**

**K u m a r r P a t t t t a n a i i k**

**D e p a r t t m e n t t o f f E l l e c t t r o n i i c s s & C o m m u n i i c a t t i i o n E n g i i n e e r i i n g**

**N a t t i i o n a l l I**

**I n s s t t i i t t u t t e o f f T e c c h n o l l o g y R o u r r k e l l a**

** **

** **

**D**

**E V E L O P M E**

**N**

**T **

** **

**O F **

** **

**L**

**O W **

** **

**P**

**O W E R **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

** **

**I**

**I**

**M A G E **

** **

**C**

**O M P R E S S**

**I**

**I**

**O**

**N **

** **

**T**

**E C H N**

**I**

**I Q**

**U**

**E**

**S**

** **

** **

*A thesis submitted in partial fulfillment of the requirements for the degree of *

**Master of Technology (Research) in **

**Electronics & Communication Engineering **

*By *

*Sunil Kumar Pattanaik *

**Roll No: 60407004**

*Under the supervision of *

**Dr. Kamala Kanta Mahapatra **

**Professor **

## Department of Electronics & Communication Engineering

## National Institute of Technology Rourkela

**May, 2006**

Department of Electronics & Communication Engineering

NATIONAL INSTITUTE OF TECHNOLOGY, ROURKELA

ORISSA, INDIA – 769 008

C

## ERTIFICATE

T his is to certify that the thesis titled “**Development of Low Power Image **

* Compression techniques*”, submitted to the National Institute of Technology,

Rourkela by **Mr.** **Sunil Kumar Pattanaik**, Roll No. **60407004 **for the award of the degree of Master of Technology (Research) in Electronics & Communication

Engineering, is a bona fide record of research work carried out by him under my supervision and guidance.

The candidate has fulfilled all the prescribed requirements.

The thesis, which is based on candidate’s own work, has not been submitted elsewhere for a degree/diploma.

In my opinion, the thesis is of standard required for the award of a Master of

Technology (Research) degree in Electronics & Communication Engineering.

To the best of my knowledge, he bears a good moral character and decent behavior.

**Prof. K. K. Mahapatra **

*Department of Electronics & Communication Engineering *

National Institute of Technology

Rourkela‐769 008 (INDIA)

Email: [email protected]** **

**Dedicated to my Grand Parents **

## B

IO

## -D

ATA OF THE

## C

ANDIDATE

**Name of the Candidate **

: Sunil Kumar Pattanaik

**Father’s Name **

**Permanent Address **

: Purna Chandra Pattanaik

Gajapati Marga

:

At/po: Hinjilicut

Dist: Ganjam

Orissa

761102

:

## [email protected]

**Email ID **

**ACADEMIC **

**QUALIFICATION**

• Continuing **M. Tech. (Research) **in Electronics & Communication

Engineering, National Institute of Technology Rourkela, Orissa

(INDIA).** **

• **M.Sc. **in Electronics, *Berhampur University*, Orissa (INDIA).

• **P.G.D.C.A, ***Pondicherry University,* (INDIA)** **

• **B. Sc. **Science College Hinjilicut, *Berhampur University*, Orissa

(INDIA).

**PUBLICATION**

Published/Accepted 05 papers in National and International

Conferences;

Communicated 02 papers to International Journals.

A

## CKNOWLEDGEMENT

I would like to take this opportunity to extend my deepest gratitude to my teacher and supervisor, Prof. K. K. Mahapatra, for his continuous encouragement and active guidance. I am indebted to him for the valuable time he has spared for me during this work. He is always there to meet and talk about my ideas, to proofread and mark up my research papers and chapters, and to ask me good questions to help me think through my problems.

I am very much thankful to Prof. G. Panda, for his continuous encouragement. Also, I am indebted to him who provided me all official and laboratory facilities.

I am grateful to Dr. S. Meher and Prof. T.K. Dan for his valuable suggestions and comments during this research period.

My sincere thanks go to Prof. G.S. Rath, Dr. S.K. Patra, Prof. S. Pramanik, Dr. B.

Majhi, and Prof. B.D. Sahoo whose valuable suggestions helped me a lot in completing this thesis.

I would like to thank Dr. Debi Prasad Das, Scientist, CEERI, Pilani for his kind support during the on period of my thesis work. In addition, let me thank all my friends Saroj, Pankaj, Rana babu, Sushant, Manas, Vamsi, Alekhika, Babita Madam,

Sabuj, Debi, Nilamani sir, Jitendra sir and Peter for their great support and encouragement during the research period. Also, I am thankful to all the non-teaching staffs of ECE Department for their kind cooperation.

During the course of this work, I am supported by a project VLSI-SMDP sponsored by

DIT, Govt. of India. I am really thankful to them.

Last but not the least, I take this opportunity to express my regards and obligation to my parents and family members for educating me in all expects. I can never forget for their unconditional support and encouragement to pursue my interests.

ii

*Sunil Kumar Pattanaik*

FPGA

JPEG

MEQ

MPEG

MSE

PSNR

RBEQ

RBF

SNR

VLC

VLSI

ANN

DCT

DHT

DPCM

DWT

L

## IST OF

A

## BBREVIATIONS

Artificial Neural Network

Discrete Cosine Transform

Discrete Hartley Transform differential pulse code modulation

Discrete Wavelet Transform

Field Programmable Gate Array

Join Picture Expert Group

Modified Energy Quantisation

Moving Pictures Experts Group

Mean Square Error

Peak Signal to Noise Ratio

Rule Based Energy Quantisation

Radial Basis Function

Signal to Noise Ratio

Variable Length Code

Very Large Scale Integration

L

## IST OF

F

## IGURES

3.5

3.6

3.7

3.8

3.9

3.10

Figure

Number

1.1

1.2

1.3

1.4

1.5

1.6

1.7

2.1

2.2

Title Page

Image Compression System

Image Decompression System

Block Diagram of Transform Loop

Limits of an Arithmetic Coder

Diagram Illustrating the Run Length Coder

Digital Image Processing steps in a Digital Camera

Functional block-diagram specification of a digital camera

Leakage current types: (a) reverse biased diode current, (b) subthreshold leakage current.

Low-power design methodology at different abstraction levels

3

4

6

10

11

14

17

2.4

2.5

2.6

2.9

2.10

Asynchronous design with dynamic voltage scaling.

(a) Original signal flow graph. (b) Unrolled signal flow graph.

Original Data Path

A precomputaiton structure for low power

A two input NAND gate

Original Signal ( )

*f t*

2

Energy Quantisation based Image Compression Encoder

Energy Quantisation Decoding and Encoding example

Energy Quantisation based Image Compression Decode

Modified Energy Quantisation based Image Compression Decoder

Standard (512x512) test images used for testing the proposed algorithms

23

42

43

44

45

45

25

26

26

27

28

29

29

30

33

36

37

40

41

48

5.5

5.6

5.7

6.1

6.2

6.3

3.11 Reconstructed image and error images of JPEG quantisation technique 50

3.12 Reconstructed image and error images of EQ technique 51

3.13

3.14 Reconstructed image and error images of RBEQ technique

4.1

4.2

Schematic block diagram of the conventional JPEG scheme of data compression

Scanning order of DHT coefficient

4.3

4.4

4.5

Reconstructed image and error images of MEQ technique

Energy Quantisation based Image Compression Encoder

Energy Quantisation based Image Compression Decoder

Modified Energy Quantisation based Image Compression Decoder

52

53

55

57

61

61

62

4.6

4.7

4.8

5.1

Reconstructed image and error images of EQ technique

Reconstructed image and error images of MEQ technique

Reconstructed image and error images of RBEQ technique

Schematic Diagram of Arithmetic Compression (AC) System

5.3

5.4

Arithmetic Compression Simulation Results of LENA Image

Arithmetic Compression Simulation Results of Babbon Image

66

67

68

71

72

74

75

Arithmetic Compression Simulation Results of Peppers Image

Arithmetic Compression Simulation Results of Gold Hill Image

Arithmetic Compression Simulation Results of Airport Image

Steps involved in VLSI designing

Internal Structure of an FPGA

Building block in basic cell design

6.5 AccelChip DSP Synthesis Flow

76

77

78

84

85

86

87

90

A

## BSTRACT

Digital camera is the main medium for digital photography. The basic operation performed by a simple digital camera is, to convert the light energy to electrical energy, then the energy is converted to digital format and a compression algorithm is used to reduce memory requirement for storing the image. This compression algorithm is frequently called for capturing and storing the images. This leads us to develop an efficient compression algorithm which will give the same result as that of the existing algorithms with low power consumption. As a result the new algorithm implemented camera can be used for capturing more images then the previous one.

1) Discrete Cosine Transform (DCT) based JPEG is an accepted standard for lossy compression of still image. Quantisation is mainly responsible for the amount loss in the image quality in the process of lossy compression. A new Energy Quantisation (EQ) method proposed for speeding up the coding and decoding procedure while preserving image quality. Some of the high frequency components of the transformed sub image are preserved in accordance to the quantisation value. There is no need of a dequantiser at the decoder side. This would enable reduction of hardware and would make the implementation much simpler. The proposed EQ method is modified and two new quatisation techniques Modified Energy Quantisation (MEQ) and Rule Based Energy

Quantisation (RBEQ) proposed to further reduce the hardware requirement.

2) DCT and IDCT are used for the coding and decoding of the image. Calculations of both are independent to each other, so there is a need of two different hardware. Where as in case of DHT transform the forward and inverse transforms are same except a scale factor in the inverse transform. As a result the hardware requirement to compute both the forward and inverse DHT is approximately reduced by 50% as those of the DCT and

IDCT.

3) All the Energy Quantisation techniques proposed are applied to further reduce the complexity of DHT based JPEG compression technique.

4) A new simple arithmetic compression technique is proposed for lossless compression.

The computational complexity is very less compare to previous techniques.

5) All the image compression techniques proposed are synthesised for Virtex XCV1000 device for the testing and verification of low complexity and hence low power. DHT based JPEG with rule based energy quantisation is an ideal solution for lossy image compression technique as the hardware requirement is less and power consumption is very low compare to other techniques.

## Contents

Certificate

Bio-data of the Candidate

Acknowledgement

List of Abbreviations

List of Figures

**CHAPTER 1: Introduction **

Preamble

1.1 Image Compression and Reconstruction

1.1.1 Transformations

1.1.2 Quantisation

1.1.3 Lossless coding

1.2 Performance measures of Image Compression

1.3 Digital Camera Fundamentals

1.4 Motivation

1.6 Chapter-wise Organization

**CHAPTER 2: Low Power VLSI Design Techniques **

Preamble

2.1 Power Dissipation Sources

2.1.1 Short-Circuit Power

8

12

13

16

4

7

1

3

16

17

18

18

19

21

22

22

23

24

2.3 Summary

**CHAPTER-3: Image Compression Using Discrete Cosine Transform **

Preamble

3.1.1 Discrete Cosine Transform (DCT)

3.3.1 Technique-1: Energy Quantisation (EQ)

3.3.2 Technique-II : Modified Energy Quantisation (MEQ)

3.3.3 Rule Based Energy Quantisation (RBEQ)

3.5 Summary

**CHAPTER-4: Hartley Transform Based JPEG **

Preamble

4.1 JPEG Baseline Algorithm

4.1.2 Quantisation of the DCT coefficients

4.1.3 Coding of the quantised coefficients

4.1.4 Reconstruction of the original image

4.2 Motivation

30

32

34

24

25

26

27

41

42

42

42

35

36

37

39

45

46

47

54

56

56

57

55

55

55

56

4.3 Discrete Hartley Transform (DHT)

4.4.1 Technique-1: Energy Quantisation (EQ)

4.4.2 Technique-II : Modified Energy Quantisation (MEQ)

4.4.3 Rule Based Energy Quantisation (RBEQ)

4.6 Summary

**CHAPTER-5: Arithmetic Lossless Compression Technique **

Preamble

5.1 Arithmetic Compression (AC)

5.1.1 Forward Arithmetic Compression Algorithm

5.1.2 Forward Arithmetic Compression Algorithm

5.3 Summary

**CHAPTER-6: FPGA Implementation of the compression techiques **

Preamble

6.1 VLSI Overview and Reconfigurable Computing

6.1.1 Advantages of Using ASIC

6.1.2 Major Risks of Using ASIC

6.2 VLSI Design Methodologies

6.3.1 Selection of FPGA deice

6.4 Introduction to AccelChip

6.4.1 AccelChip DSP Synthesis Flow

6.6 Summary

60

62

63

64

69

58

58

59

60

70

71

72

73

73

79

82

85

86

88

80

80

81

82

88

90

92

**CHAPTER-7: Conclusion **

Preamble

7.1 Achievements and Limitations of the work

**Bibliography**

93

93

95

LOW POWER

Image Compression Techniques

Chapter

1

# Introduction

*Introduction*

Data compression is the process of converting data files into smaller files for efficiency of storage and transmission. As one of the enabling technologies of the multimedia revolution, data compression is a key to rapid progress being made in information technology. The digital data have become an important source of information in the present world of communication systems. In this Internet age the power of the digital images to convey information as compared to the text data is obvious to all. This power of the images can be accessible and possible through the digital technology that enhances through its ability to process, transmit and reproduce with unparalleled faithfulness to the original images. It would not be practical to put images, audio, and video alone on websites without compression.

What is data compression? And why do we need it? Many people may have heard of JPEG (Joint Photographic Experts Group) and MPEG (Moving Pictures

Experts Group), which are standards for representing images and video. Data compression algorithms are used in those standards to reduce the number of bits required to represent an image or a video sequence. Compression is the process of representing information in a compact form. Data compression treats information in digital form, which is, as binary numbers represented by bytes of data with very large data sets. Fox example, a single small 4" x 4" size color picture, scanned at 300 dots per inch (dpi) with 24 bits/pixel of true color, will produce a file containing more than 4 megabytes of data. At least three floppy disks are required to store such a picture. This picture requires more than one minute for transmission by a typical transmission line (64k bit/second ISDN). That is why large image files remain a major bottleneck in a distributed environment. Although increasing the bandwidth is a possible solution, the relatively high cost makes this less attractive. Therefore, compression is a necessary and essential method for creating image files with manageable and transmittable sizes.

Data and information are not the same thing rather the data are the means by which the information is conveyed. Thus while conveying the same information by different formats of the data, there is every possibility that some data are common between the ways of representing the information and can be removed as redundant.

The basic motive behind the data compression is to search for such redundancy and then to remove them faithfully without compromising with the quality of the

1

*Introduction*

reconstructed data. Mathematically the concept of redundancy may be expressed as follows:

If

*n*

1 and

*n*

2 denote the number of information–carrying units in two data sets which represents the same information, the relative data redundancy

*R*

*D*

of the first data set (the one characterized by

*n*

1

) can be defined as

*R*

*D*

=

1

−

1

*C*

*R*

(1.1) where

*C*

*R*

, commonly called the compression ratio, is

*C*

*R*

=

*n*

1

*n*

2

(1.2)

For the case of

*n*

=

1

*n*

2

*C*

*R*

=

*R*

*D*

=

0

, indicating that the first representation of the information contains no redundant data. When

*n*

2

<<

*n*

1

,

*C*

*R*

→ ∞ and

*R*

*D*

→

1 , signifies that highly redundant data. When

*n*

2

>>

*n*

1

,

*C*

*R*

→

0

and

*R*

*D*

→ −∞

, indicates that the second data set contains much more data than the original representation. Generally a

*C*

*R*

=

10 (or 10:1) defines that the first data set has

10 information carrying units for every 1 unit in the second or compressed data set.

Thus corresponding redundancy of 0.9 means 90 percent of the data in the first data set is redundant with respect to the second one.

In order to be useful, a compression algorithm has a corresponding decompression algorithm that reproduces the original file once the compressed file is given. There have been many types of compression algorithms developed. These algorithms fall into two broad types, lossless algorithms and lossy algorithms. A lossless algorithm reproduces the data exactly same as the original one. A lossy algorithm, as its name implies, loses some data. Data loss may be unacceptable in many applications. For example, text compression must be lossless because a very small difference can result in statements with totally different meanings. There are also many situations where loss may be either unnoticeable or acceptable. In image compression, for example, the exact reconstructed value of each sample of the image

2

*Introduction*

is not necessary. Depending on the quality required of the reconstructed image, varying amounts of loss of information can be accepted.

**1.1 Image Compression and Reconstruction **

Three basic data redundancies can be categorized in the image compression standard.

1. Spatial redundancy due to the correlation between neighboring pixels.

The spatial and spectral redundancies are present because certain spatial and spectral patterns between the pixels and the color components are common to each other, whereas the psycho-visual redundancy originates from the fact that the human eye is insensitive to certain spatial frequencies. The principle of image compression algorithms are (i) reducing the redundancy in the image data and (or) (ii) producing a reconstructed image from the original image with the introduction of error that is insignificant to the intended applications. The aim here is to obtain an acceptable representation of digital image while preserving the essential information contained in that particular data set.

Original


Figure 1.1: Image Compression System

The problem faced by image compression is very easy to define, as demonstrated in figure 1.1. First the original digital image is usually transformed into another domain, where it is highly de-correlated by using some transform. This de-correlation concentrates the important image information into a more compact form. The compressor then removes the redundancy in the transformed image and stores it into a compressed file or data stream. In the second stage, the quantisation block reduces the accuracy of the transformed output in accordance with some pre-

3

*Introduction*

established fidelity criterion. Also this stage reduces the psycho-visual redundancy of the input image. Quantisation operation is a reversible process and thus may be omitted when there is a need of error free or lossless compression. In the final stage of the data compression model the symbol coder creates a fixed or variable-length code to represent the quantiser output and maps the output in accordance with the code. Generally a variable-length code is used to represent the mapped and quantised data set. It assigns the shortest code words to the most frequently occurring output values and thus reduces coding redundancy. The operation in fact is a reversible one.

The decompression reverses the compression process to produce the recovered image as shown in figure 1.2. The recovered image may have lost some information due to the compression, and may have an error or distortion compared to the original image.

Figure 1.2: Image Decompression System

**1.1.1 Transforms **

The first stage in an image compressor is the transform. Transformation of the image data is required to convert the image into a domain where it is easier to compress. A transform operates on an image's pixel intensities and converts them into a set of transform coefficients. Natural images (which are the most common images to be compressed) have a lot of spatial correlation between pixel intensities, and these correlations can be exploited by the transform. This is achieved by mapping similar large scale changes in the data onto single transform coefficients.

This type of mapping causes the transformed image to become highly decorrelated and standard compression techniques can then be used to further compress the transform coefficients.

The general form of a spatial intensity transform used on the image data is shown by equation (1.3):

4

*Introduction*

=

∑∑

*i j*

(1.3) where is the transform coefficient, is the image pixel intensity array,

is the transform function. This equation shows that the transform coefficients are the sum of the effects of the transform on the pixel intensities, over the whole section of the image to be transformed.

The transform is rarely applied to the whole of the image. As the area of the image to which the transform has to be applied increases, the number of calculations also increases proportionally. This suggests that to keep the number of calculations small (and manageable), the area that the transform is applied to should be as small as possible. However, the decorrelation effects on the transform improve, when a larger area of the image is considered, and this in turn improves the compression performance.

In a real system a compromise is established between the compression and the speed of the transform. The effects of decorrelation are not linearly proportional to the area used so it is not possible to theoretically determine the best area to apply the transform to; it has to be done using practical results.

The image is broken into a sub-blocks and the transform is applied to each block separately. Each block then has a set of transform coefficients, which describe it. Although it has been stated that images are highly correlated, this is only true over local areas of the image. There may be little or no correlation between distant sections (100 pixels) of the image. Applying the transform to image blocks exploits the local similarity of the image without losing the benefits of decorrelation in the transform coefficients.

Transforming image blocks also introduces a blocking artifact effect, which can be a major problem. Since the coefficients that describe one block are not related to those describing the surrounding blocks, it is possible for discontinuities to occur along the block edge of compressed images. Blocking artifact is only visible at higher compression rates, in most systems, but can severely reduce the visual quality of a compressor, even if the rate distortion performance is still acceptable. The

5

*Introduction*

blocks that the image is broken into do not have to be a fixed size or shape, but they are generally non-overlapping.

Transforms are generally formed in pairs so that the image can be reconstructed by applying the inverse transform. If the transforms are applied to an image without compression, then there are two possibilities, as shown in figure 1.3:

1. The transform is perfectly reconstructing and there is no error in the recovered image. This type of transform is often quite complex, since no data is lost and it can take a long time to compute.

2. The transform is "lossy" and information is lost on either the forward or inverse transform stage. These transforms can be useful, since they are very easy to calculate and often represent the image using a low number of transform coefficients.

They produce a moderate compression without any further processing.

Figure 1.3: Block Diagram of Transform Loop

If the image is passed through the transform loop (figure 1.3) multiple times, then theoretically either lossless or lossy transforms should produce the same recovered error each time. However since lossy transforms often favour a variable block size method, it is not always the case that reapplying a codec to a recovered image (coded with the same codec) will produce the same result i.e. an image is coded many times it may never converge to a fixed result. This problem is cause for great concern in broadcast compression as images can be compressed many times after they are originally captured.

6

*Introduction*

**1.1.2 Quantisation **

The transform stage spatially decorrelates the spatial property of the image, but does not always produce compression. Quantisation relevant to image coding is discussed in this section and simplified to allow a general rule for the quantisation of transform image coefficients to be developed. Quantisation is the main stage in case of lossy image compression, where most of the image compression is achieved.

Before quantisation a transform coefficient may take an infinite range of values, limited only by the accuracy of the medium it is stored in. After quantisation the transform coefficient will be represented by a number of discrete values. This could be represented as:

*c q*

= D

(1.4) where q is the quantisation function, c is the transform coefficients and

*c q*

=

*c c c*

0 1 2

,....... }

*n*

.

Linear quantisation is the most basic form of quantisation. The transform coefficients are divided by a quantisation step and the result is converted to an integer, by truncation of the decimal point equation (1.5).

*c q*

=

*Integer c*

(

*i*

)

*q i*

(1.5) where

*q i*

is the quantisation step,

*c i*

is the transform coefficient, and

*c q*

is the integer quantised coefficients.

The transform data is limited based on the 8 bit pixel intensities of standard images. This allows a quantisation step to be chosen, which limits the number of quantised states available, hence compressing the coefficient to a desired number of bits. However, it is not possible to control compression in this way, since a real system losslessly codes the quantised coefficients and this operation is not well defined.

The choice of q can vary since some transform coefficients are more important than others and, as a result, a quantisation table is usually formed, providing different *q* values for each transform coefficient. How to choose *q* is quite

7

*Introduction*

difficult since there is no simple relationship between the compression and the value

*q* takes.

**1.1.3 Lossless Coding **

Lossless coding aims at reducing the redundant data, by exploiting its statistics. Theoretically this coding method should compress a data source without introducing any new errors into the data. It is possible to reduce the information required to store data to a theoretical minimum, by exploiting the 'blind' statistics of the data, without considering the order in which it is received. This is usually achieved with a Huffman coding [1 - 2], but arithmetic coding [1 - 2]** **can also be useful.

In lossless coding it is useful to refer the inputs as data symbols to be compressed and the output from the lossless coder as compressed symbols. The data symbols are usually quantised transform coefficients in image compression, but they can be anything, provided the coder has knowledge of their statistics.

**1.1.3.1 Entropy Coding **

This is the most effective method of lossless coding and is nearly always present in image compression. Entropy is the average minimum number of bits that a data symbol stream can be compressed into, when each symbol is considered in isolation, based on its statistics. It can be calculated directly using equation (1.6), but it is sometimes not possible to reach the theoretical minimum entropy due to the implementation of the entropy coder.

*Entropy*

=

∑

*PDD x*

2

(1.6) where *PDD(x) *is the probability density distribution of symbol x.

There are two different approaches to entropy coding, Huffman coding [1 - 2] and arithmetic coding [1 - 2]. Huffman compression is a more common and robust method, however cannot compress data to less than one bit/symbol. Arithmetic coding is less controllable and does not compress well at higher bits/symbol, however it can reduce its entropy below one bit/symbol. For this reason arithmetic

8

*Introduction*

coders are not often used, unless the average entropy of the source is expected to drop below one bit / symbol.

**1.1.3.2 Huffman Coding **

Huffman compression [1 - 2]** **is designed to reduce the entropy of a data source close to the theoretical minimum entropy described in equation (1.6). The

Huffman coder does this by representing common data symbols with short compressed symbols and rare data symbols with long compressed symbols. The average effect of this method is to reduce the redundancy of each compressed symbol to a minimum.

A Huffman coder determines the compressed symbols by forming a data tree from the original data symbols and their associated probabilities. The tree is formed by applying the following rules until it is complete.

1. Link the two unlinked data symbols with the lowest probability to form a new data symbol with probability equal to the sum of the previous two symbols.

2. Continue to link the active data symbols with the smallest probability until a complete data tree is formed.

Table 1.1 showing four symbols compressed using Hoffman Coding

Binary Compressed Symbol

A 0.06 00

B 0.04 01

111

110

C 0.2 10 10

D 0.7 11 0

Consider the example shown in Table 1.1. There are four symbols, which can be described by the binary data symbols shown, and have an average bits/symbol coding rate of 2. If the four symbols are Huffman coded, then we obtain the compressed binary symbols shown in Table 1.1. The average bits/symbol for the compressed binary symbols is 1.3, which is a lossless compression of 1.5:1. The

9

*Introduction*

example shown in Table 1.1 shows the major failing of the Huffman coder. The entropy of the source given is 1.0, but the Huffman coder is only able to reduce the bit/symbol coding rate to 1.3. If the entropy of the data source is often close to or below 1 bit/symbol, then the Huffman coder does not perform optimally, and needs to be improved.

**1.1.3.3 Arithmetic Coding **

Arithmetic coding [1-2]** **works by treating a stream of data symbols as a whole and does not replace individual data symbols with compressed versions. The coder is always implemented in binary and to avoid confusion it will be explained by reference to binary numbers.

An arithmetic coder takes an upper and lower limit, and defines a range between these upper and lower limits to be equivalent to a symbol with the probability of 1.0. Symbols are encoded by modifying the range of the arithmetic coder and sending symbols to reconstruct this range information at the decoder. The operation of an arithmetic coder can be demonstrated by using the data previously used in Table 1.1. The data can be represented as probabilities in the arithmetic coder as shown in figure 1.4.(b). It can be seen that the symbol probabilities stack to form a continuous range of probabilities between 0.0 and 1.0. This gives a range of probabilities that represent each symbol.

Figure 1.4: Limits of an Arithmetic Coder

10

*Introduction*

The upper limit of the arithmetic coder is initially set to a value which corresponds to a probability of 1.0 but with infinite precision. This can be represented in binary as an infinite number of bits set to 1, since there is no fixed position for the decimal point. The lower limit is set to zero with infinite precision, again using an infinite number of binary bits set to 0. The only problem with this assumption is that computers work with fixed length numbers, commonly 4 to 8 bytes long, so it is impossible to represent the infinite precision. To over come this the limits are set as large as possible and their infinite length is simulated, by the coding algorithm.

The operation of encoding a symbol by the coder requires the range to be reduced in the following way:

*Range = Upper Limit - Lower Limit *

*New Upper Limit = Lower Limit + Range x P*

*HIGH*

* (Symbol) *

*New Lower Limit = Lower Limit + Range x P*

*LOW(*

*(Symbol)* where *P*

*HIGH*

* (Symbol)* is the higher probability range of the symbol, and

*P*

*LOW*

*(Symbol)* is the lower probability range of the symbol.

**1.1.3.4 Run Length Coding **

Run length coding is effective on data sources that have linear runs of the same symbol inside a data stream. The run length coder works by counting the number of occurrences of the same symbol and then forming a new symbol which describes the run length and the run symbol type. This is demonstrated in figure 1.5.

0

0 0 0 0

1 1 1

1 0

0 0 0

2 2

2

2 2

Data set

Data set

Figure 1.5: Diagram Illustrating the Run Length Coder

11

*Introduction*

The entropy of the new symbol stream, which contains the run length codes is less than the original, providing there are sufficient runs to make the method viable.

Run length coding has a similar effect to arithmetic coding without the complication of the arithmetic coder.

**1.2 Performance Measures of Image Compression **

Normally the performance of a data compression scheme can be measured in terms of three parameters. These are: ii. complexities iii. Distortion measurement for lossy compression

Compression efficiency is measured through compression ratio (CR). The CR can be defined as the ratio of the data size (number of bits) of the original data to the size of the corresponding compressed data. The complexities of a digital data compression algorithms are measured by a number of data operations required performing both the encoding and decoding process. The data operations include additions, subtractions, and multiplication, divisions and shift operations. Generally there are two parameters: efficiency and complexities, which are mutually conflicting. One can not be benefited from both sides that are the efficiency of a compression algorithm varies proportionally with the complexity. More complex algorithm yields better compression performance with a greater data reduction and takes a longer time to execute. In the lossy compression algorithms, distortion measurement is used to measure the amount of information lost on the reconstruction of the original signal or image data that has been recovered from the compressed data through encoding and decoding operations. The mean square error (MSE) is one of the distortion measurements in the reconstructed data. The performance measurement parameter; signal to noise ratio (SNR) is also used to measure the performance of the lossy compression algorithms. These measurement criteria are often used for 1D data. For image data (2D) compression, the SNR is replaced by a parameter known as peak signal to noise ratio (PSNR). Another way of distortion measurement is the

12

*Introduction*

percentage of energy retained in the compressed data. The above distortion measurements can be mathematically expressed as:

For One Dimensional data Mean Square Error calculated as

*MSE*

=

1

*N*

*N n*

∑

−

1

=

0

( )

−

'( )

2

(1.7) where N is the number of pixels in the image,

( ) is the original data and

is the compressed data.

PSNR(Peak Signal to Noise Ratio) for two dimensional image data is

*PSNR*

=

10 log (

10

255

2

*MSE*

1

) (1.8)

Where

*MSE*

1

=

1

*MN*

*M m*

−

1

*N*

−

1

∑ ∑

*n*

=

0

( , )

−

'( , )

2

(1.9)

Percentage of energy retain is given by

(

*Vector norm of data after compression*

)

2

(

*Vector norm of data before compression*

)

2

×

100

(1.10)

None of the main methods for measuring image distortion takes into account, how good the recovered image looks to the human visual system. This is an area called psycho-visual image analysis, and it is an area of research which has a large scope. Unfortunately little progress has been made into an automated method for calculating a psycho-visual distortion measure.

**1.3 Digital Camera **

A digital camera is a popular consumer electronic device that can capture images, or "take pictures," and store them in digital format. A digital still camera does not contain film, but rather then it contains one or more ICs, possessing processors and memories [7]. The key advantage of digital photography systems is their ability to provide noise-free storage, duplication, editing, and transmission of the

13

*Introduction*

digital images. The increased processing, storage, and communications capabilities of desktop PCs, coupled with their decreasing cost, have sparked the growth of digital photography.

From a designer's point of view, a simple digital camera performs two key tasks. The first task is that of processing images and storing them in internal memory.

The second task is that of uploading the images serially to an attached PC. The task of processing and storing images is initiated when the user presses the shutter button. At this point, the image is captured and converted to digital form by a charge-coupled device (CCD) or CMOS. Then, the image is processed and stored in internal memory.

Figure 1.6: Digital Image Processing Steps in a Digital Camera

Figure 1.6, shows the key image processing steps implemented in digital cameras [4, 6, 7], or in host computers that process the raw image files provided by digital cameras. The sensor data may be processed to conceal defective or noisy pixels, and to correct for sensitivity variations caused by the lens or sensor.

CFA - Most digital cameras use this approach. A mosaic *color filter array*

(CFA) is fabricated on top of the individual sensor photosites. Many different arrangements of colors are possible [4, 6], but each photosite is sensitive to only one spectral band. An optical anti-aliasing filter is normally used to reduce false color artifacts.

Color sequential - The color image is created with a monochrome sensor using three successive exposures taken with different optical red, green, and blue

(RGB) filters, or a tunable LCD, in the optical path. These cameras are used for studio photography of inanimate scenes, but cannot be used for portraits, because subject motion causes colored edge artifacts. The CFA data from the sensor is interpolated to

14

*Introduction*

reconstruct the "missing" color pixel values. Adaptive FIR filters are used for better results.

White balance corrects for the scene illuminant, since daylight has a greater proportion of blue energy than tungsten lamps. The R and B signals are multiplied by

R and B gain values intended to provide equal RGB pixel values for neutral (e.g., white or gray) objects. Color correction may use a 3 x 3 matrix to correct the camera spectral sensitivities, and tone correction uses a set of lookup tables. Image sharpening, achieved by simple or adaptive spatial filters, compensates lens blur and provides a subjectively sharper image.

To store images on memory cards, standard JPEG compression [2, 3, 32] is typically used to reduce the file size to less than 2 bits per pixel, in order to increase the number of images that can be stored. Exif format JPEG-compressed files produced by digital cameras, and by film scanners to picture CD discs, include metadata that provides information about the image capture device and the picture taking conditions. This metadata can be used to simplify image retrieval and provide higher quality prints from the digital files. The metadata often includes a "thumbnail" size image at the beginning of the PEG file, to allow groups of images to be rapidly viewed so that appropriate images can be quickly selected for viewing, copying, or printing.

Some of the new compression standard features are:

• Improved compression efficiency

•

•

Multiple resolution representation

Embedded bit stream (progressive decoding from lossless to lossy)

Many of these features are invaluable for digital cameras. For example, improved compression efficiency allows for either more images to be stored on the same memory card or for the same number of images to be stored with a higher image quality. The multi-resolution feature allows the various segments of the bit stream to be decoded to provide multiple resolutions of the image as needed. For example, the

15

*Introduction*

low-resolution image can be used as a thumbnail display on the camera LCD, while the medium resolution image is shared through e-mail, and the higher resolution images are used to create high-quality prints.

**1.3.1 Requirements Specification **

Specification describes what a particular 'system should do, namely the system's requirements [6]. Specifications include both functional and nonfunctional requirements. Functional requirements describe the system's behavior, meaning the system's outputs as a function of inputs (e.g., "output X should equal input y times

2"). Nonfunctional requirements describe constraints on design metrics (e.g., "the system should use 0.001 watt or less"), battery life should be as long as possible. The initial functional specification of a system may be very general and may come from the company's marketing department.

**1.3.2 Nonfunctional Requirements **

Given our initial requirements specification, we might want to pay attention to several design metrics in particular: performance, size, power, and energy.

Performance is the time required to process an image [6]. Size is the number of elementary logic gates (such as a two input NAND gate) in our IC. Power is a measure of the average electrical energy consumed by the IC while processing an image. Energy is power times time, which directly relates to battery lifetime. Some of these metrics will be constrained metrics-those metrics must have values below (or in some cases above) a certain threshold. Some metrics may be optimization metrics - those metrics should be improved as much as possible, since this optimization improves the product. A metric can be both a constrained and optimization metric.

Regarding size, our design must use an IC that fits in a reasonably sized camera. Suppose that, based on current technology, we determine that our IC has a size constraint of 200,000 gates. In addition to being a constrained metric, size is also an optimization metric, since smaller ICs are generally cheaper. They are cheaper because we can either get higher yield from a current technology or use an older and hence cheaper technology.

16

*Introduction*

**1.3.3 Functional Requirements **

Figure 1.7: Functional block-diagram specification of a digital camera

The high-level functionality of the digital camera can be described by using the flowchart in figure 1.7 [6]. The major functions involved in image capture, namely zero-bias adjust, Image compression (DCT, quantisation and archive in memory). The compressed image data transmitted serially. Note that figure 1.4 does not dictate that each of the blocks be mapped onto a distinct processor. Instead, the description only aids in capturing the functionality of the digital camera by breaking that functionality down into simpler functions. The functions could be implemented on any combination of single-purpose and general-purpose processors.

Finally, power is a constrained metric because the IC must operate below a certain temperature. Note that the digital camera cannot use a fan to cool the IC, so low power operation is crucial. Let's assume we determine the power constraint to be

200 mill watt. Energy will be an optimization metric because we want the battery to last as long as possible. Notice that reducing power or time each reduces energy.

17

*Introduction*

**1.4 Motivation **

Image compression is an important issue in digital image processing and finds extensive applications in many fields. This is the basic operation performed frequently by any digital photography technique to capture an image. For longer use of the portable photography device it should consume less power so that battery life will be more. To improve the Conventional techniques of image compressions using the DCT have already been reported and sufficient literatures are available on this.

The JPEG is a lossy compression scheme, which employs the DCT as a tool and used mainly in digital cameras for compression of images. In the recent past the demand for low power image compression is growing. As a result various research workers are actively engaged to evolve efficient methods of image compression using latest digital signal processing techniques. The objective is to achieve a reasonable compression ratio as well as better quality of reproduction of image with a low power consumption. Keeping these objectives in mind the research work in the present thesis has been undertaken. In sequel the following problems have been investigated.

For solving for low power image compression we have modified the existing

JPEG architecture which is the basic technique used for image compression and proposed some new low complexity method of compression technique. The performances of the proposed compression techniques have been evaluated and have been compared with that of the standard technique. Finally the proposed algorithms implemented in hardware and the power consumption is estimated. It is in general, observed that the proposed techniques are efficient than the conventional one. The results of the investigation have been outlined and discussed in subsequent Chapters.

**1.5 Literature Survey **

Interest in portable devices [6] has enhanced the requirement of developing low-power signal processors and algorithms, as well as the development of low-power general purpose processors. Designers have been able to reduce the energy requirements of particular functions, such as video compression, by several orders of magnitude [15, 63]. Low power techniques [11 - 23] can be discussed at various levels of abstractions: system level, algorithm and architecture level, logic level,

18

*Introduction*

circuit level, and technology level [12 - 14]. One important technique for low power is at algorithmic level by using algorithmic transformations [12 - 14]. This technique exploits the complexity, concurrency, regularity, and locality of an algorithm.

Reducing the complexity of an algorithm reduces the number of operations and hence the power consumption. This technique is used for reduction of power consumption by reducing the complexity.

The JPEG [24, 32, 41, 50] is one of the standard digital image compression for multilevel still images including both grayscale and colour images. Among the different models the JPEG baseline is the most widely used. It is based on the

Transform coding using the DCT. Due to the lossy transformation, the JPEG output at high CR (at 15-20:1) becomes effected by the blocking artifacts and ridges separated in the image that are found to merge during compression. Normally the DCT has been used in the JPEG compression scheme. However, in the DSP literature many other efficient transforms such as Discrete Hartley Transform (DHT) [56 – 60]** **can be used in place of DCT, which may enhances the performance of the JPEG.

Vector quantisation, (VQ) mainly used for lossy image compression to reduce the image data [42]. Many VQ techniques applied for image compression has been reported [41 - 45]. The main problem with existing VQs is preparation of the code book [44, 52]. In VQ techniques creating the code book is a complicated process which has to be designed mainly to preserve the low frequency coefficients, and most of the high frequency coefficients are discarded.

Many lossless image compression techniques [66 -73] are exists. The main aim behind these compression techniques to get good quality image reconstruction and low compression. These techniques are mainly used for those images like medical images [66, 68, 69], satellite images etc.

**1.6 Chapter-wise Organization of the thesis: **

The thesis is organised as follows:

**(1) **

**Chapter-1 **outlines the basic principle of image compression and deals with the performance measurement of digital image compression. It gives a brief idea of digital camera architecture. It also reviews the relevant

19

*Introduction*

literature on digital image compression and formulates the problems to be investigated in sequel. The motivation behind choosing various problems is also outlined.

**(2) **

**Chapter-2 **presents an overall idea about low power VLSI design, such as what are the sources of power loss in a circuit and how to control these losses. Describes all the low power techniques such as system level, algorithm level, architecture level, logic level and circuit level. Lastly it describes the basic steps to be followed for low power design.

**(3) **

**Chapter-3 **introduces DCT and its application in JPEG image compression technique briefly. The work reported in the literature on

JPEG based compression is clearly reviewed. Three new quantisation techniques are proposed to reduce the computational complexity. The proposed techniques are compared with the standard JPEG technique through computer simulation on standard images.

**(4) **

In **Chapter-4 **the standard DCT is replaced by DHT to reduce the computational complexity, ringing effect and blocking effect. The three quantisation techniques proposed in chapter-1 is used with DHT to further reduce the complexity of compression technique. The performance of these new techniques is compared with the standard conventional JPEG.

**(5) **

In **Chapter-5 **a new method of lossless image compression technique is proposed. The computational complexity of this technique is very less compared to other image compression technique. The performance of these new techniques is compared with the standard conventional lossless

JPEG compression technique.

**(6) **

**Chapter-6 **briefly introduces VLSI design and AccelChip synthesis process. Also lists the FPGA implementation results of all the proposed techniques and compared with the standard JPEG technique. ** **

**(7) **

In** Chapter-7, **conclusion has been made and some further research scopes are suggested.** **

20

LOW POWER

Image Compression Techniques

Chapter

2

# Low Power VLSI

# Design Techniques

* Low Power VLSI Design Techniques*

In the past few years there has been an explosive growth in the demand for portable computing and communication devices, from mobile telephones to sophisticated multimedia gadgets [11]. This interest in these devices has enhanced the requirement of developing low-power signal processors and algorithms, as well as the development of low-power general purpose processors. In the digital signal processing area, the results of this attention to power are quite remarkable. Designers have been able to reduce the energy requirements of particular functions, such as video compression, by several orders of magnitude [14]. This reduction has come as a result of focusing on the power dissipation at all levels of the design process, from algorithm design to the detailed implementation. In the general purpose processor area, however, there has been little work done to understand how to design energy efficient processors.

Performance of processors has been growing at an exponential rate, doubling every 18 to 24 months. However, at the same time the power dissipated by these processors has also been growing considerably. Although the rate of growth of power dissipation is perhaps not quite proportional to performance and size (the number of transistors) it still has led to processors which dissipated more than 50W. For such processors cooling becomes an absolute necessity and at high power dissipation level this is even difficult and expensive. If this trend continues processors will soon dissipate hundreds of watts, which would be unacceptable in most systems. Thus there is great interest in understanding how to continue increasing performance without increasing the power dissipation.

For portable applications the problem is even more severe since battery life depends on the power dissipation. Lithium-ion batteries have an energy density of approximately 100Wh/kg, the highest available today. To operate a 50 W processor for 4 hours requires a 2 kg battery; hence it can hardly be termed as a portable device.

In order to compare processor designs that have different performance and power one needs a measure of "goodness". If two processors have the same performance or the same power, then it is trivial to choose which is better—users prefer higher performance for the same power level or the lower power one if they have the same performance. But processor designs rarely have the same performance. Designers have to determine whether to add a particular feature will make a processor more

21

* Low Power VLSI Design Techniques*

desirable or not. However micro-architectural designing changes the amount of parallelism of the processor, affects the efficiency of the processor. Since both the performance and energy dissipation of modern processors depend heavily on the design of the memory hierarchy, one must look not only at the processor itself, but also have to look at the design of the memory. Since memories and clocking circuits are critical components of every digital system, much work already has been done to reduce the energy requirements. A different approach to reduce the energy dissipation of clocks and memories is to change the technology by scaling the supply voltage and the threshold voltage of transistors.

**2.1 Power Dissipation Sources **

In CMOS circuits, the main contributions to the power consumption are from short-circuiting current, leakage current, and switching currents [18], [21]. In the following subsections, we introduce them separately.

**2.1.1 Short-Circuit Power **

In a static CMOS circuit, there are two complementary networks: p-network

(pull-up network) and n-network (pull-down network). The logic functions for the two networks are complementary to each other. Normally when the input and output state are stable, only one network is turned on and conducts the output either to power supply node or to ground node and the other network is turned off and blocks the current from flowing. Short-circuit current exists during the transitions as one network is turned on and the other network is still active. For example, the input signal to an inverter is switching from 0 to

*V dd*

. During this transaction, there exists a short time interval where the input voltage is larger than

*V tn*

but less than

*V*

−

*dd*

*V tp*

.

During this time interval, both PMOS-transistor (p-network) and NMOS-transistor

(n-network) are turned on and the short-circuit current flows through both kinds of transistors from power supply line to the ground.

The exact analysis of the short-circuit current in a simple inverter [18] is complex, this is analyzed by SPICE simulation. It is observed that the short-circuit current is proportional to the slope of input signals, the output loads and the

22

* Low Power VLSI Design Techniques*

transistor sizes [19]. The short-circuit current consumes typically less than 10% of the total power in a "well-designed" circuit [19].

**2.1.2 Leakage Power **

Leakage currents are due to two sources: one from the currents that flow through the reverse biased diodes (reverse biased PN-Junction current), the other from the currents that flow through transistors that are non-conducting (subthreshold channel conduction current). p + n + p n + p + n + n +

(a) (b)

Figure 2.1: Leakage current types: (a) reverse biased diode current, (b) subthreshold leakage current.

The leakage currents are proportional to the leakage area and exponential of the threshold voltage. The leakage currents are due to manufacturing technology and cannot be modified by the designers except in some logic styles. Subthreshold leakage and reverse-biased junction leakage, both increases dramatically with temperature and are independent of the operating voltage for a given fabrication process.

The leakage current is in the order of pico-Ampere, but it increases as the threshold voltage is reduced. In some cases, like large RAMs, the leakage current is one of the main concerns. The leakage current is currently not a severe problem in most digital designs. However, the power consumed by leakage current can be as large as the power consumed by the switching current for

0 .

06

μ

*m*

technology. The usage of multiple threshold voltages can reduce the leakage current in deepsubmicron technology. Leakage current is difficult to predict, measure or optimized.

23

* Low Power VLSI Design Techniques*

Generally, leakage current serves no useful purposes, but some circuits do exploit it for intended operations, such as power-on reset signal generation. The leakage power problem mainly appears in very low frequency circuits or ones with “sleep modes” where dynamic activities are suppressed.

**2.1.3 Switching Power **

The switching currents are due to the charging and discharging of node capacitances. The node capacitances mainly include gate, overlapping, and interconnection capacitances. The power consumed by switching current [18] can be expressed as

*P*

=

α

*C*

*L fV dd*

2

/ 2

(2.1) where

α

a is the switching activity factor, *C*

*L*

* *is the load capacitance, *f* is the clock frequency, and *V*

*dd *

* *is the supply voltage.

The above equation (2.1) shows that the switching power depends on a few quantities that are readily observable and measurable in CMOS circuits. It is applicable to almost every digital circuit and hence provides guidelines for the low power design.

The power consumed by switching current is the dominant part of the power consumption. Reducing the switching current is the focus of most low power design techniques. For large capacitance circuits, reduction of the frequency is the best way to reduce the switching power. The use of different coding methods, number representation systems, continuing sequences and data representations can directly alter the switching frequency of the design, which alters the switching power. The best method of reducing switching frequency is to eliminate logic switching that is not necessary for computation.

**2.2 Low Power Techniques **

Low power techniques can be discussed at various levels of abstractions: system level, algorithm and architecture level, logic level, circuit level, and technology level [18], [21]. Figure 2.2 shows some examples of techniques at the different levels.

24

* Low Power VLSI Design Techniques*

Figure 2.2: Low-power design methodology at different abstraction levels.

In the following sections, an overview for different low power techniques has been described in detail. This is organized on the basis of abstraction level.

**2.2.1 System Level**

A system typically consists of both hardware and software components, which affect the power consumption. The system design includes the hardware/software partitioning, hardware platform selection (application-specific or general-purpose processors), resource sharing (scheduling) strategy, etc. The system design usually has the largest impact on the power consumption and hence the low power techniques applied at this level have the most potential for power reduction.

At the system level, it is hard to find the best solution for low power in the large design space and there is a shortage of accurate power analysis tools at this level.

However, if, for example, the instruction-level power models for a given processor are available, software power optimization can be performed [23]. It is observed that faster code and frequently usage of cache are most likely to reduce the power consumption.

25

* Low Power VLSI Design Techniques*

The order of instructions also have an impact on the internal switching within processors and hence on the power consumption.

The power-down and clock gating are two of the most used low power techniques at system level. The non-active hardware units are shut down to save the power. The clock drivers, which often consume 30-40% of the total power consumption, can be gated to reduce switching activities as illustrated in figure 2.3.

Figure 2.3: Clock gating.

The power-down can be extended to the whole system. This is called sleep mode and widely used in low power processors. The system is designed for the peak performance. However, the computation requirement is time varying. Adapting clocking frequency and/or dynamic voltage scaling to match the performance constraints is another low power technique. The lower requirement for performance at certain time interval can be used to reduce the power supply voltage. This requires either feedback mechanism (load monitoring and voltage control) or predetermined timing to activate the voltage down-scaling.

Figure 2.4: Asynchronous design with dynamic voltage scaling.

Asynchronous design of the circuit can also be used as another low power designing technique. The asynchronous designs have many attractive features, like non-global clocking, automatic power-down, no spurious transitions, and low peak

26

* Low Power VLSI Design Techniques*

current, etc. It is easy to reduce the power consumption further by combining the asynchronous design technique with other low power techniques, for instance, dynamic voltage scaling technique [20], as shown in the following figure 2.4.

**2.2.2 Algorithm Level **

The algorithm selection has large impact on the power consumption. The task of algorithm design is to select the most energy-efficient algorithm that just satisfies the constraints. The cost of an algorithm includes the computation part and the communication/storage part. The complexity measurement for an algorithm includes the number of operations and the cost of communication and storage. Reduction of the number of operations, cost per operation, and long distance communications are key issues to algorithm selection.

One important technique for low power of the algorithmic level is algorithmic transformations [21]. This technique exploits the complexity, concurrency, regularity, and locality of an algorithm. Reducing the complexity of an algorithm reduces the number of operations and hence the power consumption. The possibility of increasing concurrency in an algorithm allows the use of other techniques, e.g., voltage scaling, to reduce the power consumption. The regularity and locality of an algorithm affects the controls and communications in the hardware.

Figure 2.5: (a) Original signal flow graph. (b) Unrolled signal flow graph.

The loop unrolling technique [18], [12 - 13] is a transformation that aims to enhance the speed. This technique can be used for reducing the power consumption.

With loop unrolling, the critical path can be reduced and hence voltage scaling can be applied to reduce the power consumption.

27

* Low Power VLSI Design Techniques*

In figure 2.5, the unrolling reduces the critical path and gives a voltage reduction of 26% [18 – 23]. This reduces the power consumption with 20% even the capacitance load is increases with 50% [13]. Furthermore, this technique can be combined with other techniques at architectural level, for instance, pipeline and interleaving, to save more power. In some cases, like digital filters, the faster algorithms, combined with voltage-scaling, can be used for energy-efficient applications [18].

**2.2.3 Architecture Level**

According to the selection of the algorithm, the architecture can be determined for the given algorithm. From equation (2.1) we can say that, an efficient way to reduce the dynamic power consumption is the voltage scaling. When supply voltage is reduced, the power consumption is reduced. However, this increases the gate delay. To compensate the delay, low power techniques like parallelism and pipelining [14] architectures were used.

The use of two parallel datapath is equivalent to interleaving of two computational tasks. A datapath to determine the largest number of C and (A + B) is shown in figure 2.6. It requires an adder and a comparator. The original clock frequency is 40 MHz [14].

A

Figure 2.6: Original data path.

In order to maintain the throughput while reducing the power supply voltage, we use a parallel architecture. The parallel architecture with twice the amount of resources is shown in figure 2.7. The clock frequency can be reduced to half, from 40

MHz to 20 MHz since two tasks are executed concurrently. This allows the supply

28

* Low Power VLSI Design Techniques*

voltage to be scaled down from 5 V to 2.9 V [14]. Since the extra routing is required to distribute computations to two parallel units, the capacitance load is increased by a factor of 2.15 [14]. The power is calculated by using equation (2.2).

Figure 2.7: Parallel implementation.

*P par*

=

*C*

2

*par*

*V par f par*

=

( 2 .

15

*C actual*

)( 0 .

58

*V actual*

)

2

(

*f actual*

2

)

=

0 .

36

*P actual*

B

Figure 2.8: Pipelining implementation.

*P pipe*

=

*C pipe*

*V*

2

*pipe f pipe*

=

( 1 .

15

*C actual*

)( 0 .

58

*V actual*

)

2

(

*f actual*

)

=

0 .

39

*P actual*

(2.2)

(2.3)

Pipelining is another method for increasing the throughput. By adding a pipelining buffer / register after the adder in figure 2.8., the throughput can the

29

* Low Power VLSI Design Techniques*

increased from 1 /(

*T*

+

*add*

*T comp*

) to 1 / max(

*T add*

,

*T comp*

) . If *T*

*add*

* *is equal *T*

*comp*

,* *this increases the throughput by a factor of 2. As a result the supply voltage also scaled down to 2.9 V (the gate delay doubles) [14]. The effective capacitance increases to a factor of 1.15 because of the insertions of latches [14]. The power consumption for pipelining [14] is calculated using equation (2.3).

Main advantage of pipelining is the low area overhead in comparison with using parallel data paths. Another benefit is that the amount of glitches can be reduced.

However, since the delay increases significantly as the voltage approaches the threshold voltage and the capacitance load for routing and/or pipeline registers increases, there exists an optimal power supply voltage. Reduction of supply voltage lower than the optimal voltage increases the power consumption.

**2.2.4 Logic Level **

The power consumption depends on the switching activity factor, which in turn depends on the statistical characteristics of data. The low power techniques at the logic level, however, focus mainly on the reduction of switching activity factor by using the signal correlation and the node capacitances. In case of the gated clocking, the clock input to non-active functional block does not change by gating, and, hence, reduces the switching of clock network.

Figure 2.9: A precomputation structure for low power.

Precomputation [18] uses the same concept to reduce the switching activity factor: a selective precomputing of the output of a circuit is done before the outputs are required, and this reduces the switching activity by gating those inputs to the circuit.

As shown in figure 2.9, the input data is partitioned into two parts, corresponding to

30

* Low Power VLSI Design Techniques*

registers *R*

*1*

and *R*

*2*

. One part, *R*

*1*

, is computed in precomputation block g, one clock cycle before the computation of A. The result from g decides gating of *R*

*2*

. The power can then be saved by reducing the switching activity factor in A.

Lets consider a comparator as an example of precomputation for low-power.

The comparator takes the MSB of the two numbers to register *R*

*1*

and the others to *R*

*2*

.

The comparison of MSB is performed in g. If two MSBs are not equal, the output from g gated the remaining inputs. In this way, only a small portion of inputs to the comparator's main block A (subtracter) is changed. Therefore the switching activity is reduced.

Gate reorganization [18] is another technique used to restructure the circuit.

This can be decomposition a complex gate to simple gates, or combines simple gates to a complex gate, duplication of a gate, deleting/addition of wires. The decomposition of a complex gate and duplication of a gate help to separate the critical and non-critical path. Which reduce the size of gates in the non-critical path, as a result reduces the power consumption. In some cases, the decomposition of a complex gate increases the circuit speed and gives more space for power supply voltage scaling. The composition of simple gates can reduce the power consumption. The complex gate can reduce the charge/discharge of high-frequently switching node. The deleting of wires reduces the circuit size as a result, reduces the load capacitance. The addition of wires helps to provide an additional interconnection for better results.

Logic encoding defines the way data bits are represented on the circuits. The encoding is usually optimized for reduction of delay or area. In low power design, the encoding is optimized for reduction of switching activities since various encoding schemes have different switching properties.

In a counter design, counters with binary and Gray code have the same functionality. For N-bit counter with binary code, a full counting cycle requires

2(2 n

- 1) transitions [18] A full counting cycle for a Gray coded N-bit counter requires only 2 n

transitions. For instance, the full counting cycle for a 2-bit binary coded counter is from 00, 01, 10, 11, and back to 00, which requires 6 transitions. The full counting cycle for 2-bit Gray coded counter is from 00, 01, 11, 10, and back to 00, which requires 4 transitions. The binary coded counter has twice transitions as the

31

* Low Power VLSI Design Techniques*

Gray coded counter when the n is large. Using binary coded counter therefore requires more power consumption than using Gray coded counter under the same conditions.

Traditionally, the logic coding style is used for enhancement of speed performance. Careful choice of coding style is important to meet the speed requirement and minimize the power consumption. This can be applied to the finite state machine, where states can be coded with different schemes.

A bus is the main on-chip communication channel that has large capacitance.

As the on-chip transfer rate, increases, the use of buses contributes with a significant portion of the total power. Bus encoding is a technique to exploit the property of transmitted signal to reduce the power consumption.

**2.2.5 Circuit Level **

At the circuit level, the power saving techniques is quite limited if compared with the other techniques at higher abstract levels. However, this cannot be ignored.

The power savings can be significant as the basic cells are frequently used. A few percents improvement for D flip-flop can significantly reduce the power consumption in deep pipelined memory systems.

In CMOS circuits, the dynamic power consumption is caused by the transitions. Spurious transitions typically consume between 10% and 40% of the switching activity power in the typical combinational logic. In some cases, like array multipliers, the amount of spurious transitions is large. To reduce the spurious transitions, the delays of signals from registers that converge at a gate should be roughly equal. This can be done by insertions of buffers and device sizing [18]. The insertions of buffer increase the total load capacitance but can still reduce the spurious transitions. This technique is called path balancing.

Many logic gates have inputs that are logically equivalent, i.e., the swapping of inputs does not modify the logic function of the gate. Some examples of gates are

NAND, NOR, XOR, etc. However, from the power consumption point of view, the order of inputs does effect the power consumption. Lets consider the figure 1.10, the

A-input, which is near the output in a two-input NAND gate, consumes less power than the B-input closed to the ground with the same switching activity factor. Pin

32

* Low Power VLSI Design Techniques*

ordering is to assign more frequently switching input pins near to the output node, which will consume less power. In this way, the power consumption will be reduced without cost. However, the statistics of switching activity factors for different pins must be known in advanced and this limits the use of pin ordering [18].

C i i

Figure 2.10: A two input NAND gate.

Different logic styles have different electrical characteristics. The selection of logic style affects the speed and power consumption. In most cases, the standard

CMOS logic is used for speed and power trade-off. In some cases other logic styles, like complementary pass-transistor logic (CPL) is efficient.

Transistor sizing affects both delay and power consumption. Generally, a gate with smaller size has smaller capacitance and consumes less power. To minimize the transistor sizes and meet the speed requirement is a trade-off. Typically, the transistor sizing uses static timing analysis to find out those gates (whose slack time is larger than 0) to be reduced. The transistor sizing is generally applicable for different technologies.

33

* Low Power VLSI Design Techniques*

**2.3 Summary **

Several approaches to reduce the power consumption have been briefly discussed. Below we summarize some of the most commonly used low power techniques.

• Reduce the number of operations. The selection of algorithm and/or architecture has significant impact on the power consumption.

•

•

Power supply voltage scaling. The voltage scaling is an efficient way to reduce the power consumption. Since the throughput is reduced as the voltage is reduced, this may need to be compensated by using parallel and/or pipelining techniques.

I/Os between chips can consume large power due to the large capacitive loads.

Reducing the number of chips is a promising approach to reduce the power consumption.

•

•

•

Power management. In many systems, the most power consuming parts are often idle. For example, in a lap-top computer, the portion of display and hard disk could consume more than 50% of the total power consumption. Using power management strategies to shut down these components when they are idle for a long time can achieve good power saving.

Reducing the effective capacitance. The effective capacitance can be reduced by several approaches, for example, compact layout and efficient logic style.

Reduce the number of transitions. To minimize the number of transitions, especially the glitches, is important

34

LOW POWER

Image Compression Techniques

Chapter

3

# DCT Based Image

# Compression

*Image compression using Discrete Cosine Transform *

Discrete cosine transform (DCT) [39, 44] is widely used in image processing, especially for compression. Some of the applications of two-dimensional DCT involve still image compression and compression of individual video frames, while multidimensional DCT is mostly used for compression of video streams. DCT is also useful for transferring multidimensional data to frequency domain, where different operations, like spread-spectrum, data compression, data watermarking, can be performed in easier and more efficient manner. A number of papers discussing DCT algorithms is available in the literature that signifies its importance and application.

Hardware implementation of parallel DCT transform is possible, that would give higher throughput than software solutions. Special purpose DCT hardware decreases the computational load from the processor and therefore improves the performance of complete multimedia system. The throughput is directly influencing the quality of experience of multimedia content. Another important factor that influences the quality is the finite register length effect that affects the accuracy of the forward-inverse transformation process.

Hence, the motivation for investigating hardware specific DCT algorithms is clear. As 2-D DCT algorithms are the most typical for image compression, the main focus of this chapter will be on the efficient hardware implementations of 2-D DCT based compression by decreasing the number of computations, increasing the accuracy of reconstruction, and reducing the chip area. This in return reduces the power consumption of the compression technique. As the number of applications that require higher-dimensional DCT algorithms are growing, a special attention will be paid to the algorithms that are easily extensible to higher dimensional cases.

The JPEG standard has been around since the late 1980's and has been an effective first solution to the standardisation of image compression. Although JPEG has some very useful strategies for DCT quantisation and compression, it was only developed for low compressions. The 8

×8 DCT block size was chosen for speed

(which is less of an issue now, with the advent of faster processors) not for performance. The JPEG standard will be briefly explained in this chapter to provide a basis to understand the new DCT related work.

35

*Image compression using Discrete Cosine Transform *

This chapter contains three new and different approaches for using the DCT.

The first uses a ‘Energy Quantisation’ method for compression. The aim of this energy quantisation and then modified energy quantisation techniques is to reduce the quantisation complexity in terms of hardware implementation. Finally, a ‘Rule-based

Energy Quantisation’ method is presented that automatically sets the threshold value for the quantization of the transformed DCT coefficients. The main aim behind these two proposed schemes is to reduce the hardware requirement for quantisation and dequantisation, and to reduce the use of memory, to reduce the power consumption.

**3.1 JPEG Compression **

The JPEG (Joint Photographic Experts Group) standard [32,50] has been around for some time and is the only standard for lossy still image compression.

There are quite a lot of interesting techniques used in the JPEG standard and it is important to give an overview of how JPEG works. There are several variations of

JPEG, but only the 'baseline' method is discussed here.

8 x 8 blocks DCT – Based Encoder

FDCT Quantizer Huffman

Encoder

Source Image

Data

Table

Specifications

Figure 3.1: JPEG Encoder

Table

Specifications

As shown in the figure 3.1, the image is first partitioned into non-overlapping

8

× 8 blocks. A Forward Discrete Cosine Transform (FDCT) is applied to each block to convert the spatial domain gray levels of pixels into coefficients in frequency domain. To improve the precision of the DCT the image is 'zero shifted', before the

DCT is applied. This converts a 0

→

255 image intensity range to a -128

→

127 range, which works more efficiently with the DCT. One of these transformed values is referred to as the DC coefficient and the other 63 as the AC coefficients.

After the computation of DCT coefficients, they are normalized with different scales according to a quantization table provided by the JPEG standard conducted by psychovisual evidence. The quantized coefficients are rearranged in a

36

*Image compression using Discrete Cosine Transform *

zigzag scan order for further compressed by an efficient lossless coding algorithm such as runlength coding, arithmetic coding, Huffman coding. The decoding process is simply the inverse process of encoding as shown in figure 3.2.

DCT – Based Decode r

Huffman

Decoder

Dequantizer IDCT

Compressed

Image Data

Table

Specifications

Table

Specifications

Figure 3.2: JPEG Decoder

**3.1.1 DISCRETE COSINE TRANSFORM (DCT) **

Reconstructed

Image Data

The DCT is a widely used transformation in transformation for data compression. It is an orthogonal transform, which has a fixed set of (image independent) basis functions, an efficient algorithm for computation, and good energy compaction and correlation reduction properties. Ahmed et al [39] found that the

Karhunen Lòeve Transform (KLT) basis function of a first order Markov image closely resemble those of the DCT. They become identical as the correlation between the adjacent pixel approaches to one.

The DCT belongs to the family of discrete trigonometric transform, which has

16 members [44]. The 1D DCT of a 1

×

*N*

vector

*x*

( )

is defined as

*Y k C k*

*N*

−

1

[ ] [ ] [ ]

*n*

## ∑

=

0 cos

⎡

⎢⎣

(

2

*n*

+

2

1

*N*

) k

π

⎤

⎥⎦

(3.1) where

*k*

=

0 , 1 , 2 ,...,

*N*

−

1 and

*C*

=

⎡

⎢

⎢

⎢

⎣

1

N for k

1

N for k

=

0

=

1,2,..., N 1

⎦

⎤

⎥

⎥

⎥

⎥

The original signal vector

*x*

can be reconstructed back from the DCT coefficients

*Y*

[ ]

using the Inverse DCT (IDCT) operation and can be defined as

*x*

[ ]

=

*k*

*N*

∑

−

1

=

0

*C*

cos

⎡

⎢⎣

(

2

*n*

+

2

1

*N*

) k

π

⎤

⎥⎦ (3.2)

37

*Image compression using Discrete Cosine Transform *

The DCT can be extended to the transformation of 2D signals or images. This can be achieved in two steps: by computing the 1D DCT of each of the individual rows of the two-dimensional image and then computing the 1D DCT of each column of the image. If

*x*

(

*n*

1

, *n*

2

)

represents a 2D image of size

*N N*

an image is given by:

*Y*

[ ] [ ] [ ]

−

1

*m*

=

0

*N N*

∑∑

*n*

−

1

=

0

*x*

[ ] cos

⎜

(

2

*m*

2

+

*N*

1

)

*j*

π cos

⎜

(

2

*n*

2

+

1

*N*

)

*k*

π

and

[ ] [ ]

=

⎢

⎢

⎡

⎢

1

N

1

N

for j,k

=

0

for j,k

=

1,2,...,N-1

⎥

⎥

⎤

⎥

(3.3)

*x*

Similarly the 2D IDCT can be defined as

[ ]

=

*j*

−

1

=

0

*N N*

∑∑

*k*

−

1

=

0

*C C Y j*

, cos

(

2

*m*

+

1

)

*j*

π

2

*N*

⎠ cos

⎜

(

2

*n*

2

+

1

*N*

)

*k*

π

(3.4)

The DCT is a real valued transform and is closely related to the DFT. In particular, a

*N N x*

(

*n*

1

, *n*

2

)

can be expressed in terms of 2

*N*

×

2

*N*

DFT of its even-symmetric extension, which leads to a fast computational algorithm. Because of the even-symmetric extension process, no artificial discontinuities are introduced at the block boundaries. Additionally the computation of the DCT requires only real arithmetic. Because of the above properties the DCT is popular and widely used for data compression operation.

The DCT presented in equations (3.1) and (3.4) is orthonormal and perfectly reconstructing provided the coefficients are represented to an infinite precision. This means that when the coefficients are compressed it is possible to obtain a full range of compressions and image qualities. The coefficients of the DCT are always quantised for high compression, but DCT is very resistant to quantisation errors due to the statistics of the coefficients it produces. The coefficients of a DCT are usually linearly quantised by dividing by a predetermined quantisation step.

38

*Image compression using Discrete Cosine Transform *

The DCT is applied to image blocks N x N pixels in size (where N is usually multiple of 2) over the entire image. The size of the blocks used is an important factor since they determine the effectiveness of the transform over the whole image. If the blocks are too small then the images is not effectively decorrelated but if the blocks are too big then local features are no longer exploited.

The tiling of any transform across the image leads to artifacts at the block boundaries. The DCT is associated with blocking artifact since the JPEG standard suffers heavily from this at higher compressions. However the DCT is protected against blocking artifact as effectively as possible, without interconnecting blocks, since the DCT basis functions all have a zero gradient at the edges of their blocks.

This means that only the DC level significantly affects the blocking artifact and this can then be targeted.

Ringing is a major problem in DCT operation. When edges occur in an image

DCT relies on the high frequency components to make the image shaper. However these high frequency components persist across the whole block and although they are effective at improving the edge quality they tend to 'ring' in the flat areas of the block.

This ringing effect increases, when larger blocks are used, but larger blocks are better in compression terms, so a trade off is usually established.

**3.1.2 QUANTISATION **

In lossy image compression the transformation decompose the image into uncorrelated parts projected on orthogonal basis of the transformation. These basis are represented by eigenvectors which are independent and orthogonal in nature.

Taking inverse of the transformed values will result in the retrieval of the actual image data. For compression of the image, the independent characteristic of the transformed coefficients are considered, truncating some of these coefficients will not affect the others. This truncation of the transformed coefficients is actually the lossy process involved in compression and known as quantization [43]. So we can say that

DCT is perfectly reconstructing, when all the coefficients are calculated and stored to their full resolution. For high compression, the DCT coefficients are normalized by different scales, according to the quantization matrix as shown in the Table-3.1 provided by JPEG standard, which is designed by conducting some psycho visual

39

*Image compression using Discrete Cosine Transform *

evidence. The JPEG quantizer is a bank of 64 linear (uniform) quantizers, one for each DCT coefficients as shown in figure 3.3. The i'th quantizer is evaluated as

*Y i*

=

*Round*

⎛

⎜

*X*

*Q i i*

⎞

⎟

(3.5) where

*Q i*

is the i’th quantization step size, *X * is the input where as

*Y i*

is the scaled and quantized version of *X *. The JPEG decoder dequantizes

*i*

*Y i*

to obtain a quantized version of *X * using

*i*

*X*

'

=

*Q i*

∗ .

X

0

X

1

X

2

X

3 q

2 q

3 q

0 q

1

Y

0

Y

1

Y

2

Y

3

X i

Y i q i

X

63

Y

63 q

63

Figure 3.3: JPEG Quantiser

Table 3.1: JPEG Quantisation matrix

18 22 37 56 68 109 103 77 90 110 185 255 255 255 255 255

24 35 55 64 81 104 113 92 120 175 255 255 255 255 255 255

49 64 78 87 103 121 120 101 245 255 255 255 255 255 255 255

72 92 95 98 112 100 103 99 255 255 255 255 255 255 255 255

MAT1 MAT2

Vector quantization, (VQ) mainly used for reducing or compressing the image data [42]. Application VQ on images for compression started from early 1975 by Hilbert mainly for the coding of multispectral Landsat imaginary. Many VQ techniques applied for image compression has been reported [41 - 45]. The main problem with existing VQs is preparation of the code book [43, 45]. In VQ

40

*Image compression using Discrete Cosine Transform *

techniques creating the code book is a complicated process which has to be designed mainly to preserve the low frequency coefficients, and most of the high frequency coefficients are discarded, which results in the loss of edges of the image. The encoder search the whole code book to identify the nearest matching vector template to an input vector, which also takes a lot of time.

**3.1.3 CODING **

After the DCT coefficients have been quantised, the DC coefficients are

DPCM coded and then they are entropy coded along with the AC coefficients. The quantised AC and DC coefficient values are entropy coded in the same way, but because of the long runs in the AC coefficient, an additional run length process is applied to them to reduce their redundancy.

Figure 3.4: Zigzag Scanning

The quantised coefficients are all rearranged in a zigzag order as shown in figure 3.4. The run length in this zigzag order is described by a RUN-SIZE symbol.

The RUN is a count of how many zeros occurred before the quantised coefficient and the SIZE symbol is used in the same way as it was for the DC coefficients, but on their AC counter parts. The two symbols are combined to form a RUN-SIZE symbol and this symbol is then entropy coded. Additional bits are also transmitted to specify the exact value of the quantised coefficient. A size of zero in the AC coefficient is used to indicate that the rest of the 8

× 8 block is zeros (End of Block or EOB).

41

*Image compression using Discrete Cosine Transform *

**3.2 SIGNAL ENERGY **

The idea of the "size" of a signal is crucial to many applications. It is also nice to know if the signal driving a set of headphones is enough to create a sound. The given example deals with electric signals, which generally vary with different signals with very different tolerances. For this reason, it is convenient to quantify this idea of

"size". This leads to the ideas of signal energy and signal power.

Since we often think of signal as a function of varying amplitude through time, it seems to reason that a good measurement of the strength of a signal would be the area under the curve. However, this area may have a negative part. This negative part does not have less strength than a positive signal of the same size. This suggests squaring the signal or taking its absolute value, then finding the area under that curve.

It turns out that what we call the energy of a signal is the area under the squared signal. The original signal and the energy of the signal is shown in figure 3.5, and equation 3.6 shows the formula for the calculation of energy of a continuous signal.

*E t*

=

∞

∫

− ∞

(|

*f*

(

*t*

) |

2

)

*dt*

(3.6)

**3.3 ENERGY QUANTISATION (EQ) **

( )

2

*f t*

**3.3.1 Technique-1: Energy Quantisation (EQ) **

The technique of energy calculation discussed in the previous section has been applied to calculate the energy of the transformed coefficients of the image block, where each transformed pixel values are considered as the amplitude of the image

42

*Image compression using Discrete Cosine Transform *

signal. Taking the square of each transformed coefficients and taking the sum gives rise to the energy content in that block. It means that each signal has some contribution to the total energy. Than a threshold value considered for elimination of the transformed coefficients i.e. if the energy of the transformed coefficient is less than the threshold value than make that zero, otherwise keep the coefficient as it is.

The threshold value is considered according to the user requirement, i.e. how much energy of the image user want to save. For higher compression and low quality, less transformed coefficients has to be stored i.e. maximum amount of the energy has to be discarded. For low compression and high quality, maximum amount energy has to be saved.

8 x 8 blocks DCT – Based Encoder

FDCT

Energy calculation

&

Thresholding

Huffman

Encoder

Source Image

Data

Table

Specifications

Compressed

Image Data

Figure 3.6: Energy Quantisation based Image Compression Encoder

Energy Quantisation based image compression (EQ-IC) technique encoder and is shown in figure 3.6. Figure 3.7, illustrates the proposed energy quantization technique briefly by taking a sample 8

× 8 block. Figure 3.7 (a), is an 8 × 8 block of

8-bit samples taken arbitrarily from a real image. The sample to sample variation is very high, which indicates the existence of high spatial frequency. The actual samples level sifted by subtracting 128 from each sample, as DCT is designed to work on sample values ranging form -127 to 128. The samples are than passed through the

FDCT block, for converting the samples to frequency domain. Figure 3.7 (b), shows the resulting DCT coefficients, where it’s very clear that most of the coefficients are very small. Figure 3.7 (c), shows the quantized DCT coefficients, normalized by the quantization table (Table -1). Figure 3.7 (d) shows the DCT coefficients quantized by using the proposed algorithm. First the normalized energy of the transformed coefficients is calculated using the following equation,

43

*Image compression using Discrete Cosine Transform *

*E n*

=

1

*MN*

*M N*

∑∑

*m*

=

0

*n*

=

0

*x*

(

*m*

,

*n*

)

2

.

(3.7)

Where

*M*

and

*N*

are the width and length of the sample block and transformed samples. Than according to the threshold value, i.e. a measure to know the contribution of the transformed sample to the normalized energy is considered.

154 123 123 123 123 123 123 136

192 180 136 154 154 154 136 110

254 198 154 154 180 154 123 123

239 180 136 180 180 166 123 123

180 154 136 167 166 149 136 136

128 136 123 136 154 180 198 154

123 105 110 149 136 136 180 166

110 136 123 123 123 136 154 136

(a) Source Image Sample

162.3 40.6 20.0 72.3 30.3 12.5 -19.7 -11.5

30.5 108.4 10.5 32.3 27.7 -15.5 18.4 -2.0

-94.2 -60.1 12.3 -43.4 -31.3 6.1 -3.3 7.2

-38.6 -83.6 -5.4 -22.2 -13.5 15.5 -1.3 3.5

-0.9 -11.8 12.8 0.2 28.1 12.6 8.4 2.9

-9.9 11.2 7.8 -16.3 21.5 0.1 5.9 10.7

(b) Forward DCT coefficients

10 4 2 5 1 0 0 0

3 9 1 2 1 0 0 0

-7 -5 1 -2 -1 0 0 0

-3 -5 0 -1 0 0 0 0

-2 1 0 0 0 0 0 0

0 0 0 0 0 0 0 0

0 0 0 0 0 0 0 0

0 0 0 0 0 0 0 0

(c) JPEG Quantized Coefficients

149 134 119 116 121 126 127 128

204 168 140 144 155 150 135 125

253 195 155 166 183 165 131 111

245 185 148 166 184 160 124 107

188 149 132 155 172 159 141 136

132 123 125 143 160 166 168 171

109 119 126 128 139 158 168 166

111 127 127 114 118 141 147 135

(e) Reconstructed image of JPEG Dequantized

Coefficients

10 3 1 5 2 0 -1 0

2 7 0 2 2 0 0 0

-6 -4 0 -3 -2 0 0 0

-2 -5 0 -1 0 0 0 0

-2 0 0 0 0 0 0 0

0 0 0 0 2 0 0 0

0 0 0 0 0 0 0 0

0 0 0 0 1 0 0 0

(d) Energy Quantized Coefficients

30% of Normalized Discarded

149 127 113 132 139 122 123 128

195 177 148 146 153 148 134 109

253 194 152 173 184 150 122 110

241 183 142 166 183 154 128 115

188 154 128 149 171 163 152 139

139 135 125 138 158 168 173 162

123 118 116 136 148 148 160 168

101 128 126 113 118 142 156 137

(f) Reconstructed image of energy Dequantized

Coefficients

Figure 3.7: Energy Quantisation Decoding and Encoding example

For this example the threshold value is taken as 30% of the normalized energy. For higher compression this threshold value has to be increased. The DCT coefficient can be saved as it is, but the transformed coefficients/samples have been normalized to decrease the amplitudes. At the decoder the compressed data is dequantized and passed through the IDCT operation to reconstruct the image. Figure

3.7 (e) shows the reconstructed samples, after dequantizing the compressed samples using the quantization table.

The decoding technique is shown in figure 3.8. The reconstructed pixel using the energy dequantisation is shown in Figure 3.7 (f). From the reconstructed image

44

*Image compression using Discrete Cosine Transform *

pixel values it is clear that some of the high frequency components are preserved.

This indicates that the edge property of the image is preserved.

DCT – Based Decode r

Huffman

Decoder

IDCT

Compressed

Image Data

Reconstructed

Image Data

Table

Specifications

Figure 3.8: Energy Quantisation based Image Compression Decoder

**3.3.2 Technique-II : Modified Energy Quantisation (MEQ) **

In case of the second method i.e. Modified energy quantisation the energy is calculated by taking the absolute value of the transformed coefficients as shown in figure 3.9. By performing the absolute operation all the transformed coefficients are converted into some positive amplitude. The area under this positive coefficients will give the energy of the signal. It means that each signal amplitude represents the energy of that signal. A threshold value has to be considered for elimination of the transformed coefficients i.e. if the energy of the transformed coefficient is less than the threshold value than make that zero, otherwise keep the coefficient as it is. Mean of the signal is used to set the threshold value for truncation of the transformed coefficients as shown in equation (3.8).

*A m*

=

1

*MN*

*M N*

∑ ∑

*m*

=

0

*n*

=

0

(3.8) where

*M*

and

*N*

are the width and length of the sample block and transformed samples.

*A m*

is the default threshold value. To sift the level of threshold value

*A m*

is multiplied by some constant i.e. for higher compression and low quality of reconstruction

*A m*

should be multiplied by some integer greater then 1, for low compression and high quality

*A m*

should be divided by some integer.

*Image compression using Discrete Cosine Transform *

The threshold value is considered according to the user requirement, i.e. how much energy of the image user want to save. For higher compression and low quality, less transformed coefficients has to be stored i.e. maximum amount of the energy has to be discarded. For low compression and high quality, maximum amount energy has to be saved. The decoding procedure is same as the previous technique as shown in figure 3.8.

**3.3.3 Rule Based Energy Quantisation (RBEQ) **

Instead of representing knowledge in a relatively declarative, static way, rulebased system represent knowledge in terms of a bunch of rules that tell what should be done or what could be concluded in different situations. A rule-based system consists of a bunch of IF-THEN rules, and some interpreter controlling the application of the rules, given the facts.

Rules in the system represent possible actions to take when specified conditions hold on items in the working memory - they are sometimes called condition-action rules. The conditions are usually patterns that must match items in the working memory, while the actions usually involve adding or deleting items from the working memory. The rule based designing broadly divided into two types: forward chaining design, and backward chaining design. In a forward chaining designer have to start with some initial facts, and keep using the rules to draw new conclusions (or take certain actions) given those facts. In a backward chaining designer have to start with some hypothesis (or goal) to prove, and keep looking for rules that would allow to conclude that hypothesis, perhaps setting new subgoals to prove. Forward chaining design are primarily data-driven, while backward chaining design are goal-driven.

Forward chaining design process is used here for compression of the image.

Normalized energy

*E n*

is used as the primary data to set the rules for the quantization of the blocks. Calculation of

*E n*

is already explained by the equation 3.7 in section

3.4.1. As the blocks which have edges contributes in large energy and the blocks

46

*Image compression using Discrete Cosine Transform *

which has no edges contributes to less energy. So this property of the image blocks taken in to account and some rules are formed using this energy values. Here two rules are proposed, one for high compression low quality of reconstruction and other one for low compression high quality of reconstruction, compared to the fixed energy quantization method.

Rule-1 (*RBEQ-1*):

If

*n*

1000, quantisation value is 10% of

*E n*

Else if

*E*

≥

*n*

700, quantisation value is 30% of

*E n*

Else if

*E*

≥

*n*

500, quantisation value is 50% of

*E n*

Else if

*E*

≥

*n*

300, quantisation value is 60% of

*E n*

Else quantisation value is 70% of

*E n*

Rule-2 (*RBEQ-2*):

If

*n*

1000, quantisation value is 10% of

*E n*

Else if

*E*

≥

*n*

500, quantisation value is 50% of

*E n*

Else quantisation value is 90% of

*E n*

**3.4 SIMULATION RESULTS **

Five different standard test images shown in figure 3.10 are used in the simulation of the image compression task using the DCT based JPEG, Energy

Quantisation technique (EQ), Modified Energy Quantisation (MEQ) and Rule Based

Energy Quantisation (RBEQ-1 & RBEQ-2) respectively. At first the image blocks are passed through the FDCT blocks for conversion into frequency domain. Then the transformed coefficients are allowed to compress using the quantisation operation.

After the quantisation the quantized coefficients are coded using some lossless coding algorithm. This completes the compression of the original data and the coded data represent the compressed version of the original sample images.

47

*Image compression using Discrete Cosine Transform *

The performance comparison has been carried out using all the performance indices given in equations (1.2-1.4). These are; PSNR peak signal to noise ratio, energy retained and bits per pixel obtained in the process of compression and reconstruction of signals or images. The same parameters are computed for all the images using the DCT based compression and proposed techniques. Table 3.2 lists the

PSNR in dB obtained for JPEG technique and proposed techniques, Table 3.3 lists the bpp (bits per pixel) required for representing one pixel in case of the compressed image. The reconstructed image and the error images for different techniques are shown in figures 3.11 - 3.14.

(a) Lena Image (b) Bobbon Image

(c) Peppers Image (d) GoldHill Image

48

*Image compression using Discrete Cosine Transform *

Figure 3.10: Standard (512x512) test images used for testing the proposed algorithms

49

*Image compression using Discrete Cosine Transform *

Table 3.2: Comparative results in PSNR (dB) of different Quantisation techniques for five different images

LENA PEPPERS AIRPORT

JPEG

EQ

MAT-1 36.80 28.22 34.74 33.58 28.68

MAT-2 30.62 23.42 30.09 28.65 24.58

100% 31.23 25.92 30.53 29.88 25.63

80% 31.71 26.58 30.97 30.33 26.11

60% 32.39 27.45 31.55 30.88 26.79

40% 33.37 28.72 32.34 31.70 27.81

20% 35.06 30.87 33.63 33.06 29.71

10% 36.65 32.92 34.75 34.37 31.63

5% 37.99 34.39 35.61 35.43 33.43

MEQ

RBEQ

JPEG

EQ

100% 37.35 29.82 34.80 34.30 29.79

80% 38.36 31.37 35.45 35.23 31.35

60% 39.31 33.21 36.10 36.00 33.25

40% 39.84 34.80 36.49 36.26 34.71

20% 39.88 35.09 36.54 36.27 34.99

RBEQ1 36.23 37.94 34.37 34.82 31.29

RBEQ2 36.07 2.001 34.24 34.24 31.11

Table 3.3: Comparative results in bpp (bits per pixcel) of different Quantisation techniques for five different images:

LENA PEPPERS AIRPORT

MAT-1 0.691 1.538 0.700 0.876 1.234

MAT-2 0.193 0.381 0.197 0.205 0.208

100% 0.403 1.228 0.395 0.497 0.721

80% 0.428 1.358 0.424 0.542 0.808

60% 0.461 1.516 0.461 0.597 0.939

40% 0.531 1.724 0.520 0.680 1.133

20% 0.602 2.004 0.632 0.821 1.453

10% 0.691 2.232 0.750 0.959 1.700

5% 0.761 2.419 0.874 1.090 1.916

MEQ

RBEQ

100% 0.752 1.946 0.804 0.949 1.533

80% 0.816 2.149 0.898 1.064 1.788

60% 0.873 2.339 0.992 1.194 2.080

40% 0.898 2.508 1.063 1.260 2.269

20% 0.900 2.565 1.076 1.263 2.317

RBEQ1 0.621 2.001 0.627 0.832 1.602

RBEQ2 0.611 2.062 0.608 0.805 1.576

50

*Image compression using Discrete Cosine Transform *

(a) Reconstructed image using MAT-1 (b) Error image using MAT-1

(c) Reconstructed image using MAT-2 (d) Error image using MAT-2

(e) Reconstructed image using MAT-1 (f) Error image using MAT-1

(g) Reconstructed image using MAT-2 (h) Error image using MAT-2

Figure 3.11: Reconstructed image and error images of JPEG quantisation technique

51

*Image compression using Discrete Cosine Transform *

(a) Threshold=100% of E n

(b) Threshold=80% of E n

(c) Threshold=60% of E n

(d) Threshold=100% of E n

(e) Threshold=80% of E n

(f) Threshold=60% of E n

(g) Threshold=40% of E n

(h) Threshold=20% of E n

(i) Threshold=10% of E n

(j) Threshold=40% of E n

(k) Threshold=20% of E n

(l) Threshold=10% of E n

Figure 3.12: Reconstructed image and error images of EQ technique

52

*Image compression using Discrete Cosine Transform *

(a) Threshold=5 of E n

(b) Threshold=3 of E n

(c) Threshold= E n

(d) Threshold=5 of E n

(e) Threshold=3 of E n

(f) Threshold= E n

(h) Threshold=60% of E n

(i) Threshold=40% of E n

(g) Threshold=80% of E n

(j) Threshold=80% of E n

(k) Threshold=60% of E n

(l) Threshold=40% of E

Figure 3.13: Reconstructed image and error images of MEQ technique n

53

*Image compression using Discrete Cosine Transform *

(a) Using RBEQ-1 (b) Using RBEQ-1 (c) Using RBEQ-1

(d) Using RBEQ-1 (e) Using RBEQ-1 (f) Using RBEQ-1

(g) Using RBEQ-2 (h) Using RBEQ-2 (i) Using RBEQ-2

(j) Using RBEQ-2 (k) Using RBEQ-2 (l) Using RBEQ-2

Figure 3.14: Reconstructed image and error images of RBEQ technique

54

*Image compression using Discrete Cosine Transform *

**3.5 Summary and Discussion **

In this Chapter we have employed the DCT based JPEG image compression technique. Three new quantisation techniques are proposed that can replace the existing vector quantisation technique. Simulation results indicate that the proposed techniques achieve nearly same PSNR value as that of the existing JPEG technique.

The third rule based energy quantisation (RBEQ) technique improves the performance of image compression by making it intelligent to select the threshold value for each block separately according to the amount of energy content of that block.

55

LOW POWER

Image Compression Techniques

Chapter

4

# DHT Based Image

# Compression

*Hartley transform based JPEG *

JPEG [32, 50] has been created out of the collaboration between the consultative Committee on International Telephone and Telegraph (CCITT) and the

International Standard Organization (ISO) to establish an International standard for image compression. It is based on the transform coding using DCT. The JPEG standard describes a family of image compression techniques for continuous tone

(gray-scale) still images. Because of the amount of data involved and the psychovisual redundancy present in the images, JPEG employs a lossy compression scheme based on the transform coding. The JPEG defines four operation modes: sequential DCT based mode, sequential lossless mode, progressive DCT based mode, and hierarchical mode. The simplest sequential algorithm among the DCT based

JPEG referred to as JPEG baseline, is widely used compression algorithm in the JPEG family.

Baseline algorithm is also called the sequential algorithm. The JPEG baseline data compression scheme can be summarized in the following three steps. The block diagram of the conventional JPEG framework has been shown in figure 4.1.

Input block

DCT

Quantization

Zigzag scanning

DPCM of DC coefficients

VLC

Compressed data

Output block

DCT

Inv.

Quantization

Inv. zigzag scanning

Inv. DPCM of DC coeff.

VLD

Figure 4.1: Schematic block diagram of the conventional

JPEG scheme of data compression

**4.1.1 DCT computation*** *

Initially the whole image is subdivided into 8 8

*n*

−

1

2

*n*

pixel is then level shifted by subtracting 2 , where is the maximum number of

55

*Hartley transform based JPEG *

given levels. That is for 8-bit images we subtract 128 from each pixel in an attempt to remove the DC level of each block. The 2D DCT of each block is then computed.

**4.1.2 Quantisation of the DCT coefficients**

The DCT coefficients thus obtained are then thresholded using a Quantisation

Matrix (QM) of size (

8

×

8

) [4.2, 4.3] and reordered using zigzag scanning to form a

1D sequence of 64 quantised coefficients. The first one is the DC coefficient and the rest 63 coefficients are the AC coefficients. The effect of dividing by such a QM would be to favour the low frequencies. The QM can be scaled to provide a variety of compression levels. The entries of the QM are usually determined according to the psychovisual considerations. A typical QM might be an integer multiple of a matrix such as in [9]. The multiplier might be any positive integer. The larger the multiplier, the better is the compression and accordingly a degradation in the reconstructed image is noticed. Also to reduce the psychovisual redundancy in image, JPEG incorporates the characteristic of the human visual system into the compression process through the specification of QM. It is known that the frequency response of the human visual system drops off with increasing spatial frequency. Further this drop off is faster in the two chrominance channels. As a result, the JPEG allows specification of two QM, one for the luminance and another for the two chrominance channels to allocate more bits for the representation of coefficients, which are visually more significant [54] Thus the choice of the QM and multiplier greatly influences the performance of the method.

**4.1.3 Coding of the quantised coefficients**

The nonzero AC coefficients are Huffman coded using the Variable length code (VLC) that defines the value of the coefficients and the number of preceding zeros. The DC coefficient of each block is coded using the differential pulse code modulation (DPCM) relative to the DCT coefficients of the previous block.

**4.1.4 Reconstruction of the original image**

The reconstruction process of this scheme can be obtained by reversing all the forward processes, like Variable Length Decoding, Inverse DPCM, Inverse quantization and the inverse DCT algorithm.

56

*Hartley transform based JPEG *

**4.2 Motivation **

The JPEG conventionally employs the DCT as the transform block in its framework for image compression. The performance of the JPEG is quite satisfactory.

In the DSP literature many other efficient transforms such as Good Winograd

Transform (GWT) [34, 46] and DHT are being used. Similarly the DHT is a real valued transform whose forward and inverse transforms are same except for an inclusion of a scale factor in the inverse transform. Besides, the DHT can compute both convolution and the DFT efficiently [46]. The memory requirement to compute both the forward and inverse DHT is about 50% as those of the DCT. In the present work we have attempted the use of the DHT in JPEG to find out whether the new version of the JPEG can provide equivalent performance as that of the conventional one. The choice of QM and the multiplier greatly influence the performance of the

JPEG scheme of image compression and reconstruction. While replacing the DHT in the JPEG framework, care should be taken in choosing proper QM. The same QM shown in Table-3.1 is used for testing the results. But these QM were unable to give proper results as they are designed to preserve data which follows the zigzag scan order as shown in figure 3.4. DHT transformed coefficients do not follows the zigzag scanning; instead they follow a special scanning order as shown in figure 4.2. So the designing of the QM matrix is quite difficult in this case. To eliminate these difficulties the quantisation techniques proposed in chapter one used and tested for different images to examine whether the newer version has any advantage over the conventional compression scheme or not.

3 16 17 19 21 23 25 27

5 18 29 30 32 34 36 38

7 20 31 40 41 43 45 47

9 22 33 42 49 50 52 54

11 24 35 44 51 56 57 59

13 26 37 46 53 58 61 62

15 28 39 48 55 60 63 64

Figure 4.2: Scanning order of DHT coefficient

57

*Hartley transform based JPEG *

**4.3 Discrete Hartley Transform (DHT) **

**4.3.1 1D DHT **

In 1942, R. V. L. Hartley [61] proposed a real integral transform for the analysis of transmission problem. Based on that integral transform, Bracewell [59] proposed a real valued discrete transform called the DHT. The DHT is a real valued alternative to the DFT as the even and odd parts of the DHT of a real valued sequence are same as the real and negative imaginary parts of the corresponding DFT components. The DHT of an N-point real valued sequence

*x*

( )

is defined as [60]

*X*

=

1

*N*

*N n*

∑

=

0

−

1

*x*

( ) cas

(

2

π kn N

)

(4.1) and the inverse transform is

*x*

( )

=

*N k*

−

1

∑

=

0

*X*

( ) cas

(

2

π kn N

) where, cas

(

2

π

*kn N*

)

= cos

(

2

π

*kn N*

)

+ sin

(

2

π

*kn N*

) for

*k*

,

*n*

=

0 , 1 , 2 ,...,

*N*

−

1

(4.2)

Equations (4.1) and (4.2) may respectively be expressed in the matrix product form as:

*X*

=

( )

*C*

*N x*

, and

*x*

=

*C*

*N*

*X*

(4.3) where *x * is the

*N*

×

1 input vector and

*X*

is the

*N*

×

1 DHT vector.

*C*

*N*

is the

*N N*

Hartley matrix whose elements are given by

*C*

*N*

( )

= cos

(

2

π

*kn N*

)

+ sin

(

2

π

*kn N*

) for

*k*

,

*n*

=

0 , 1 , 2 ,...,

*N*

−

1

from (4.4) it can be seen that

*C*

*N*

( )

=

*C*

*N*

( ) and

(4.4)

(4.5)

*N n*

∑

−

1

=

0

*C*

*N*

( ) (

*N n*

,

*k*

′

)

=

*N*

δ

*k k*

′ where Kronecker delta

δ is given by

(4.6)

58

*Hartley transform based JPEG *

δ

*k k*

′

=

⎡

⎢

1 for k

0 for k

=

≠ k

′ k

′ from (4.5) and (4.6) it can be found that the Hartley matrix is a nonsingular Harmitian matrix of eigen value

±

*N*

. An important feature of this transform that makes it more advantageous compared to the DFT and DCT is that the inverse transform defines by (4.2) is identical to the forward transform given by (4.1), except a scale

1 factor of

*N*

. Therefore, only one routine may be coded and stored for the forward as well as inverse transform.

**4.3.2 2D DHT **

Just like 1D, the 2D DHT computation can be developed and has a potential application in the field of image processing [57]. Development of efficient schemes for its fast computation is, therefore, a subject of interest. Many researches have been carried out to solve this problem. Bracewell et al [60] have proposed an efficient algorithm to compute the multidimensional DHT by adding certain number of intermediate arrays where each of the arrays is computed using 1-dimensional fast

DHT algorithm. Another scheme of computation of the DHT has been proposed [58], where the computation is based on the prime-factor decomposition. According to this scheme, multidimensional DHT can be computed using a 1D fast DFT algorithm and an 1D fast DHT algorithm. This scheme has been reported to be less compulsive as well as structurally less complex over the earlier scheme. In the JPEG scheme we have incorporated the DHT that has been computed using the prime factor. A brief overview of this algorithm is follows.

The 2D DHT of an array

[

*x*

(

*m*

,

*n*

)

]

of size

*M N*

*X k l*

=

*n*

−

1

*M N*

∑ ∑

=

0

−

1

*m*

=

0

*x*

(

*m*

,

*n*

)

⎡

⎢ cos 2

π

*km*

+

*M*

ln

*N*

⎤

⎥

+

⎡

⎢ sin 2

π

*km*

+

*M*

ln

*N*

⎤

⎥

(4.7)

By splitting the arguments of sine and cosine function of (4.7), we get

*X*

where

=

*n*

−

1

*N*

∑

=

0

*u*

( )

⎡

⎢⎣ cos

2

π

*N*

ln

+ sin

2

π

*N*

ln

⎤

⎥⎦

+

*n*

−

1

*N*

∑

=

0

*v k n*

⎡

⎢⎣ cos

2

π

*N*

ln

− sin

2

π

*N*

ln

⎤

⎥⎦

(4.8)

59

*Hartley transform based JPEG u*

=

*M*

∑

−

1

*m*

=

0

*x*

(

*m*

,

*n*

) cos

2

π

*km*

*M v k n*

=

*m*

*M*

∑

−

1

=

0

*x*

(

*m*

,

*n*

) cos

2

π

*km*

*M*

(4.9)

(4.10)

It may be noted that

( )

and

( )

, for

*k*

=

0 , 1 ,...,

*M*

−

1 , represent the real parts and the negative imaginary parts of M-point DFT of nth column of

[

*x*

(

*m*

,

*n*

)

]

, respectively.

Substituting

*n*

=

*N*

−

*n*

on the second sum of (4.8), we can get

*X*

=

*n*

*N*

∑

−

1

=

0

*w*

( )

⎡

⎢⎣ cos

2

π

*N*

ln

+ sin

2

π

*N*

ln

⎤

⎥⎦ where,

*w*

( ) ( )

+

*v*

(

*k*

,

(

*N*

−

*n*

)

*N*

)

The symbol

( )

*N*

denotes the modulo N operation

(4.11)

(4.12)

Equations (4.9) - (4.12) indicate that a 2D DHT of an array of size

*M N*

may be computed in the following sequences: i. The M-point DFT of each column of

[

*x*

(

*m*

,

*n*

)

]

be computed. ii. The real parts of the DFT of the nth column be added with the –ve of corresponding imaginary parts of the DFT of the (N-n)th column, for n=1,2,…,N-1. The real part of the DFT of zeroth column, however, be added with the -ve imaginary part of the DFT of the same column. The results thus obtained, be stored in the corresponding position of

[

*x*

(

*m*

,

*n*

)

]

under its new variable name

[

*w*

(

*m*

,

*n*

)

]

. iii. Finally, the N-point DHT of each row of

[

*w*

(

*m*

,

*n*

) ]

be computed to obtained the desired 2D DHT.

**4.4 Energy Quantisation (EQ) **

**4.4.1 Technique-1: Energy Quantisation (EQ) **

This same technique of energy calculation discussed in the previous chapter has been applied to calculate the energy of the transformed coefficients of the image block, where each transformed pixel values are considered as the amplitude of the image signal. Taking the square of each transformed coefficients and taking the sum

60

*Hartley transform based JPEG *

gives rise to the energy content in that block. It means that each signal has some contribution to the total energy. Than a threshold value considered for elimination of the transformed coefficients i.e. if the energy of the transformed coefficient is less than the threshold value than make that zero, otherwise keep the coefficient as it is.

The threshold value is considered according to the user requirement, i.e. how much energy of the image user want to save. For higher compression and low quality, less transformed coefficients has to be stored i.e. maximum amount of the energy has to be discarded. For low compression and high quality, maximum amount energy has to be saved.

8 x 8 blocks

Energy calculation

&

Thresholding

Huffman

Encoder

Source Image

Data

Table

Specifications

Compressed

Image Data

Figure 4.3: Energy Quantisation based Image Compression Encoder

First the normalized energy of the transformed coefficients is calculated using the following equation,

*E n*

=

1

*MN*

*M N*

∑∑

*m*

=

0

*n*

=

0

*x*

(

*m*

,

*n*

)

2

.

(4.13)

Where

*M*

and

*N*

are the width and length of the sample block and is the transformed samples. Than according to the threshold value, i.e. a measure to know the contribution of the transformed sample to the normalized energy is considered.

DHT –

Based Decoder

Huffman

Decoder

IDHT

Compressed

Image Data

Reconstructed

Image Data

Table

Specifications

Figure 4.4: Energy Quantisation based Image Compression Decoder

61

*Hartley transform based JPEG *

The decoding technique is shown in figure 4.4. From the reconstructed image pixel values it is clear that some of the high frequency components are preserved.

This indicates that the edge property of the image is preserved.

**4.4.2 Technique-II : Modified Energy Quantisation (MEQ) **

In case of the second method i.e. Modified energy quantisation the energy is calculated by taking the absolute value of the transformed coefficients as shown in figure 4.5. By performing the absolute operation all the transformed coefficients are converted into some positive amplitude. The area under these positive coefficients will give the energy of the signal and the amplitude represents the energy of that signal.

DHT – Based Encoder

DHT

Figure 4.5: Modified Energy Quantisation based Image Compression Decoder

A threshold value has to be considered for elimination of the transformed coefficients i.e. if the energy of the transformed coefficient is less than the threshold value than make that zero, otherwise keep the coefficient as it is. Mean of the signal is used to set the threshold value for truncation of the transformed coefficients as shown in equation (4.15).

*A m*

=

1

*MN*

*M N*

∑ ∑

*m*

=

0

*n*

=

0

(4.15) where

*M*

and

*N*

are the width and length of the sample block and is the transformed samples.

*A m*

is the default threshold value. To shift the level of threshold value

*A m*

is multiplied by some constant i.e. for higher compression and low quality of reconstruction

*A m*

should be multiplied by some integer greater then 1, for low compression and high quality

*A m*

should be divided by some integer.

The threshold value is considered according to the user requirement, i.e. how much energy of the image user want to save. For higher compression and low

62

*Hartley transform based JPEG *

quality, less transformed coefficients has to be stored i.e. maximum amount of the energy has to be discarded. For low compression and high quality, maximum amount energy has to be saved. The decoding procedure is same as the previous technique as shown in figure 4.4.

**4.4.3 RULE BASED ENERGY QUANTISATION (RBEQ) **

Instead of representing knowledge in a relatively declarative, static way, rulebased system represent knowledge in terms of a bunch of rules that tell what should be done or what could be concluded in different situations. A rule-based system consists of a set of IF-THEN rules, and some interpreter controlling the application of the rules, given the facts.

Rules in the system represent possible actions to take when specified conditions hold on items in the working memory - they are sometimes called condition-action rules. The conditions are usually patterns that must match items in the working memory, while the actions usually involve adding or deleting items from the working memory. The rule based designing broadly divided into two types: forward chaining design, and backward chaining design. In a forward chaining designer have to start with some initial facts, and keep using the rules to draw new conclusions (or take certain actions) given those facts. In a backward chaining designer have to start with some hypothesis (or goal) to prove, and keep looking for rules that would allow concluding that hypothesis, perhaps setting new subgoals to prove. Forward chaining design is primarily data-driven, while backward chaining design are goal-driven.

The energy quantisation rules proposed in chapter 3 is used to threshold the transformed coefficients. Form the simulation result it is very much clear that the performance of the proposed DHT based JPEG technique out performs the existing technique of quantisation. Both the rules are unchanged for testing the proposed technique. These rules can be modified for both better compression and better quality.

The two rules are specified

63

*Hartley transform based JPEG *

Rule-1 (*RBEQ-1*):

If

*n*

1000, quantisation value is 10% of

*E n*

Else if

*E*

≥

*n*

700, quantisation value is 30% of

*E n*

Else if

*E*

≥

*n*

500, quantisation value is 50% of

*E n*

Else if

*E*

≥

*n*

300, quantisation value is 60% of

*E n*

Else quantisation value is 70% of

*E n*

Rule-2 (*RBEQ-2*):

If

*n*

1000, quantisation value is 10% of

*E n*

Else if

*E*

≥

*n*

500, quantisation value is 50% of

*E n*

Else quantisation value is 90% of

*E n*

In this section we provide simulation results both for the conventional and newer version of the JPEG. Because of the obvious advantage of DHT over DCT, we have replaced the DCT block in the encoder side with the DHT and IDCT block in the decoder side with the DHT having a scale factor of

1

*N*

⎟

.

The performance comparison has been carried out using all the performance indices given by (1.2-1.4). These are; PSNR peak signal to noise ratio, energy retained and bits per pixel obtained in the process of compression and reconstruction of signals or images. The same parameters are computed for all the images using the

DCT based compression and proposed techniques. Table 4.1 lists the PSNR in dB obtained for JPEG technique and proposed techniques, Table 4.2 lists the bpp (bits per pixel) required for representing one pixel in case of the compressed image. The reconstructed image and the error images for different techniques are shown in figures

4.6 - 4.8.

64

*Hartley transform based JPEG *

Table 4.1: Comparative results in PSNR (dB) of different Quantisation techniques for five different images

EQ

100% 29.83 25.55 29.13 29.22 25.32

80% 30.35 26.09 29.60 29.68 25.80

60% 31.03 27.05 30.18 30.24 26.53

40% 31.92 28.40 31.02 31.11 27.48

20% 33.59 30.01 32.55 32.69 29.56

10% 34.98 32.98 33.85 34.00 30.80

MEQ

RBEQ

100% 34.98 29.82 33.64 34.06 29.64

90% 35.41 30.13 34.11 34.71 30.32

70% 36.66 31.34 34.96 35.76 32.04

50% 37.68 34.69 35.95 36.06 34.38

30% 37.91 35.09 36.21 36.07 35.04

RBEQ1 30.04 25.81 29.35 29.45 25.56

RBEQ2 30.67 26.48 29.86 29.95 26.71

Table 4.2 Comparative results in bpp (bits per pixcel) of different Quantisation techniques for five different images:

EQ

100% 0.501 0.502 0.502 0.635 0.749

80% 0.546 0.547 0.547 0.701 0.856

60% 0.607 0.609 0.609 0.784 1.030

40% 0.688 0.710 0.710 0.911 1.251

20% 0.844 0.901 0.901 1.107 1.624

10% 0.958 1.077 1.077 1.293 1.826

5 0.317 0.295 0.284 0.317 0.220

MEQ

RBEQ

100% 1.057 2.321 1.152 1.408 1.013

90% 1.086 2.385 1.197 1.464 2.047

70% 1.114 2.536 1.266 1.526 2.225

50% 1.175 2.728 1.319 1.537 2.386

30% 1.181 2.741 1.328 1.539 2.407

RBEQ1 0.521 1.427 0.522 0.667 0.806

RBEQ2 0.576 1.588 0.576 0.740 0.950

65

*Hartley transform based JPEG *

(a) Threshold=100% of E n

(b) Threshold=80% of E n

(c) Threshold=60% of E n

(d) Threshold=100% of E n

(e) Threshold=80% of E n

(f) Threshold=60% of E n

(g) Threshold=40% of E n

(h) Threshold=20% of E n

(i) Threshold=10% of E n

(j) Threshold=40% of E n

(k) Threshold=20% of E n

(l) Threshold=10% of E n

Figure 4.6: Reconstructed image and error images of EQ technique

66

*Hartley transform based JPEG *

(a) Threshold=5 of E n

(b) Threshold=3 of E n

(c) Threshold= E n

(d) Threshold=5 of E n

(e) Threshold=3 of E n

(f) Threshold= E n

(g) Threshold=90% of E n

(h) Threshold=70% of E n

(i) Threshold=50% of E n

(j) Threshold=90% of E n

(k) Threshold=70% of E n

(l) Threshold=50% of E n

Figure 4.7: Reconstructed image and error images of MEQ technique

67

*Hartley transform based JPEG *

(a) Using RBEQ-1 (b) Using RBEQ-1 (c) Using RBEQ-1

(d) Using RBEQ-1 (e) Using RBEQ-1 (f) Using RBEQ-1

(g) Using RBEQ-2 (h) Using RBEQ-2 (i) Using RBEQ-2

(j) Using RBEQ-2 (k) Using RBEQ-2 (l) Using RBEQ-2

Figure 4.8: Reconstructed image and error images of RBEQ technique

68

*Hartley transform based JPEG *

**4.6 SUMMARY **

Exhaustive computer simulation results indicate that the DHT based JPEG is a useful alternative to that of a DCT based JPEG because of less storage requirement and improved compression and reconstruction performance. Qualitatively it is found to offer superior performance compared to the conventional JPEG. It is evident from the plots computed from the saving energy and PSNR in dB in the reconstructed images. Besides, there is saving in memory space in employing the DHT rather than the DCT and IDCT.

69

LOW POWER

Image Compression Technique

Chapter

5

# Arithmetic Image

# Compression

*Arithmetic Lossless Compression Technique *

With the increasing use of multimedia technologies, image compression requires higher performance. To address needs and requirements of multimedia and internet applications, many efficient image compression techniques, with considerably different features, have been developed. An image compression technique exploits a common characteristic of most images that is the neighboring picture elements or pixels are highly correlated [9]. It means a typical still image contains a large amount of spatial redundancy in plain areas where adjacent pixels have almost the same values. In addition a still image contains subjective redundancy, which is determined by the properties of Human Visual System (HVS).

HVS presents some tolerance to distortion depending upon the image and viewing conditions. Consequently, pixels must not always be reproduced exactly same as the original one but still HVS will not detect the difference between original image and reproduced image [65].

All compression techniques can be basically classified into two main categories: called as lossy compression and lossless compression. Lossy schemes offer compression by a factor of 20 or more, but do not allow exact recovery of original images. In lossless schemes on the other hand compression ratio is limited to a factor of 2, but it allows exact reconstruction of images from the compressed imaged. This method is considered to be useful when finer details of the images are required to be retained for certain reasons as in case of medical and space images, remote sensing images and fine arts etc. Exact lossless recovery is, however, not an essential requirement in many situations because different applications may tolerate different limits of deviation from the original value. A third category of compression technique called as near lossless compression [62 - 79] is, therefore, evolving in the recent years. Near lossless compression method guarantees that difference between a pixel value of the reconstructed image and the value of corresponding pixel in the original image cannot exceed a specified upper limit [66, 69].

Transform domain approach using the discrete cosine transform (DCT) or the discrete wavelet transform (DWT) along with an entropy coding is usually deployed for lossy compression. For lossless and near lossless compression using differential pulse code modulation (DPCM) based on different predictors and error-modeling schemes are popularly used due to their simplicity as well as its efficiency although

70

*Arithmetic Lossless Compression Technique *

wavelet-based filter bank coding and some hybrid schemes are also suggested [36],

But, all these methods for near lossless coding cannot be directly extended to lossy region to have a unified approach for compression that can be suitable for variable compression requirement. Recently, a unified coding algorithm is suggested for lossy, lossless as well as the near lossless compression using lossless-DCT (L-DCT) [77].

Since L-DCT maps an integer vector to a vector mat is also expressed by integer it does not introduce reconstruction error when no quantization is performed. L-DCT can therefore be used for lossless compression, and the compression performance of the L-DCT is found to be comparable to that of conventional DCT for lossy as well as near lossless compression.

Based on some simple arithmetic calculation, an efficient Lossless Image

Compression technique is proposed. This technique is designed for high quality still image compression, especially PSNR value above 34. This algorithm is most applicable for those images where lossy compression is avoided such as medical and scientific images. The encoding and decoding procedure is very fast.

**5.1 Arithmetic Compression (AC) **

For the gray level image, the pixel value is usually represented in integer format. The LOG-EXP image compression [74 - 75] is based on the logarithmic number system (LNS) properties, and brings the pixel values to 8 as a result the neighboring difference between the pixels also reduced. Using the proposed different transforms we concentrate the statistical property of the image to a particular range and discard some of the transformed values depending upon the requirement.

Original


Level

Shifting

Forward

*AC*

Shift Right

Base

Difference

Snake

Scanning

Variable

Length

Coding

Compressed

Data

Inverse

*AC*

Reconstructed


Level

Shifting

Shift Left

Base

Difference

Addition

Variable

Length

Decoding

71

*Arithmetic Lossless Compression Technique *

The compression and decompression flow of the new arithmetic compression algorithm is shown in figure 5.1. Where for reducing the distribution of the pixel value to locate in a small and continuous range, the pixels are divided by a base number and only the division value is stored and the reminder is truncated. As a result it removes the redundancy of the data, at the same time the large neighboring distance between two pixels reduced to a small value. The neighbor pixels usually represent the same object so the values of the pixels are similar. The neighboring differences will be very small and there may be many similar differences. When the pixels are processed in sequential scan at the time of changes form one line to next line occurs, there will be one large neighboring difference. To avoid such kind of large neighboring difference, the snake scan is used as shown in figure 5.2.

Neighbouring Difference

## Figure 4.2: Snake Scanning

**5.1.1 Forward Arithmetic Compression Algorithm **

Step 1: The input image is level shifted by 2P-1 that is, 2P-1 is subtracted from each pixel value, where P is the number of bits used to represent each pixel.

Thus 128 is subtracted form each pixel if the image is 8-bit.

Step 2: Divide the level shifted pixel values by the base, where base is any value in between 4 to 16 and take the integer part only, similar as modulo operation.

For high quality the base should be small and for high compression the base should be high.

Step 3: Perform snake scan and calculate the difference of the adjacent pixel values as shown in figure 5.2.

72

*Arithmetic Lossless Compression Technique *

Step 4: Perform Variable Run length coding for lossless coding of the decorrelated coefficients.

**5.1.2 Inverse Arithmetic Compression Algorithm **

Step 1: Perform Run length decoding to get back the pixel values form the lossless coded data.

Step 2: Perform snake scan and calculate the original pixel values by adding the differences.

Step 3: Multiply the pixel values by the base to get back the original pixel values. In this case the maximum loss will be equal to base -1.

Step 4: Level shifted by 2P-1 that is, 2P-1 is added to each pixel value, where

P is the number of bits used to represent each pixel. Thus 128 is added to each pixel if the image is 8-bit.

**5.2 Simulation Results **

The programs are implemented using Matlab 7.1. Performance of the proposed scheme is evaluated on a set of test images namely, Lena, Baboon, Pepper,

Gold Hill and Airport images seen in figure 3.10 of second chapter. In Table 5.1 and

Table 5.2, the performance of the proposed technique is compared with the JPEG compression. Two different quantization matrixes Mat1 & Mat2 as shown in

Table 3.1 of second chapter has been considered for JPEG compression.

Table 5.1 lists the PSNR in dB obtained for JPEG technique and proposed techniques for modulo values 4, 8, 16, 32 i.e. 2 n

where n= 1, 2, 3… etc. Table 5.2 lists the bpp (bits per pixel) required for representing one pixel in case of the compressed image. The reconstructed image and the error images for different techniques are shown in figures 5.3 – 5.7.

73

*Arithmetic Lossless Compression Technique *

(a) JPEG : Mat1 (b) JPEG : Mat2 (c) Base 4

(d) JPEG : Mat1 (e) JPEG : Mat2 (f) Base 4

(g) Base 8 (h) Base 16 (i) Base 32

(j) Base 8 (k) Base 16 (l) Base 32

Figure 5.3: (a, b) Decoded Lena images using JPEG quantization matrix Mat1 & Mat2

(d, e) Error images of JPEG quantization matrix Mat1 & Mat2

(c, g, h, i)Decoded images using proposed Tech for modulo 4, 8, 16, 32

(f, j, k, l) Error images using proposed Tech for modulo 4, 8, 16, 32

74

*Arithmetic Lossless Compression Technique *

(a) JPEG : Mat1 (b) JPEG : Mat2 (c) Base 4

(d) JPEG : Mat1 (e) JPEG : Mat2 (f) Base 4

(g) Base 8 (h) Base 16 (i) Base 32

(j) Base 8 (k) Base 16 (l) Base 32

Figure 5.4: (a, b) Decoded Babbon image using JPEG quantization matrix Mat1 & Mat2

(d, e) Error images of JPEG quantization matrix Mat1 & Mat2

(c, g, h, i)Decoded images using proposed Tech for modulo 4, 8, 16, 32

(f, j, k, l) Error images using proposed Tech for modulo 4, 8, 16, 32

75

*Arithmetic Lossless Compression Technique *

(a) JPEG : Mat1 (b) JPEG : Mat2 (c) Base 4

(d) JPEG : Mat1 (e) JPEG : Mat2 (f) Base 4

(g) Base 8 (h) Base 16 (i) Base 32

(j) Base 8 (k) Base 16 (l) Base 32

Figure 5.5: (a, b) Decoded Peppers image using JPEG quantization matrix Mat1 & Mat2

(d, e) Error images of JPEG quantization matrix Mat1 & Mat2

(c, g, h, i)Decoded images using proposed Tech for modulo 4, 8, 16, 32

(f, j, k, l) Error images using proposed Tech for modulo 4, 8, 16, 32

76

*Arithmetic Lossless Compression Technique *

(a) JPEG : Mat1 (b) JPEG : Mat2 (c) Base 4

(d) JPEG : Mat1 (e) JPEG : Mat2 (f) Base 4

(g) Base 8 (h) Base 16 (i) Base 32

(j) Base 8 (k) Base 16 (l) Base 32

Figure 5.6: (a, b) Decoded Gold Hill image using JPEG quantization matrix Mat1 & Mat2

(d, e) Error images of JPEG quantization matrix Mat1 & Mat2

(c, g, h, i)Decoded images using proposed Tech for modulo 4, 8, 16, 32

(f, j, k, l) Error images using proposed Tech for modulo 4, 8, 16, 32

77

*Arithmetic Lossless Compression Technique *

(a) JPEG : Mat1 (b) JPEG : Mat2 (c) Base 4

(d) JPEG : Mat1 (e) JPEG : Mat2 (f) Base 4

(g) Base 8 (h) Base 16 (i) Base 32

(j) Base 8 (k) Base 16 (l) Base 32

Figure 5.7: (a, b) Decoded Airport image using JPEG quantization matrix Mat1 & Mat2

(d, e) Error images of JPEG quantization matrix Mat1 & Mat2

(c, g, h, i)Decoded images using proposed Tech for modulo 4, 8, 16, 32

(f, j, k, l) Error images using proposed Tech for modulo 4, 8, 16, 32

Table 5.1: Comparative results in PSNR (dB) for JPEG compression and Aritmatic

78

*Arithmetic Lossless Compression Technique *

compression techniques for five different images

LENA PEPPERS AIRPORT

JPEG

MAT-1 36.80 28.22 34.74 33.58 28.68

MAT-2 30.62 23.42 30.09 28.65 24.58

Arithmetic

Compression 16 34.93 34.78 34.87 34.75 34.90

32 28.66 28.80 28.87 28.87 28.79

Arithmetic

Compression

+

Snake scan

16 34.93 34.78 34.87 34.75 34.90

32 28.67 28.80 28.86 28.87 28.34

Table 5.2: Comparative results in bpp (bits per pixcel) for JPEG compression and

Aritmatic compression techniques for five different images:

JPEG

LENA PEPPERS AIRPORT

MAT-1 36.80 28.22 34.74 33.58 28.68

MAT-2 30.62 23.42 30.09 28.65 24.58

Arithmetic

Compression 16 4.707 4.550 4.988 4.779 5.189

32 3.887 3.768 4.180 3.956 4.344

Arithmetic

Compression

+

Snake scan

16 2.648 3.451 2.722 2.817 3.335

32 2.380 2.870 2.393 2.439 2.861

**5.3 Summary and Discussion **

A new method of lossless image compression technique is proposed to speedup the encoding and decoding procedure to fulfill the present-day requirement of multimedia technology. This is very much useful for those images where the information content is very large i.e. redundant data is very less. From the simulation results it’s clear that the edges of the images are lost in case of the JPEG compression, where as in case of the proposed technique the edges are preserved. The coding and decoding procedure is very faster then the existing algorithms as only few addition/ subtraction and sift operation are performed to obtain the compression. The hardware requirement for the implementation of the proposed technique will be less then that of the existing technique

.

79

LOW POWER

Image Compression Technique

Chapter

6

# FPGA

# Implementation Results

*FPGA Implementation of the compression techniques *

Electronics design automation must cope with technological trend in silicon integration. Nowadays, the possibility of integrating millions of transistors onto a single silicon chip is demanding for new CAD tools, to bridge the gap between technology and design. As integration technology enables the development of deep submicron CMOS circuits for digital signal processing (DSP) in an ever and ever increasing variety of applications, designers have to face new problems which require new design methodologies and tools.

The increasing gap between technology capability and designer productivity is demanding for new design methodologies and innovative CAD tools, as in previous stages of the “design crisis”. Following the introduction of electronics design automation tools for physical design (partitioning, placement and routing) and, more recently, for digital circuit synthesis from behavioral description (hardware description languages), now a remarkable effort is being spent, aiming at the automatic synthesis starting from functional specifications rather than from behavioral representation.

The image compression techniques discussed in the previous chapters are implemented in hardware for the testing and verification of low complexity and hence low power. In this chapter a brief overview of VLSI design is given. In the second section a overview of AccelChip software is given, which is used for implementation of all the algorithms. And finally the implementation results are tabulated and compared to draw definite conclusions.

**6.1 VLSI Overview and Reconfigurable Computing **

The semiconductor industry has evolved the first integrated circuits (ICs) that matured rapidly since then. Early small-scale integration (SSI) ICs contain a few

(1 to 10) logic gates NAND gates, NOR gates and few tens of transistors. The era of medium-scale integration (MSI) increased the range of integrated logic available to some counters and some larger functions. The era of large-scale integration (LSI) packed even larger logic functions, such as the first microprocessors, into a single chip. Then the evolution of very large scale integration (VLSI) has developed when millions of transistors can be integrated into a single chip. By using VLSI, the design of 64-bit microprocessors, complete with cache memory and floating point arithmetic

80

*FPGA Implementation of the compression techniques *

units has become possible. Based on all the new technologies which have been grown from several years, the digital integrated circuit (IC) is one of the most phenomenal growths in terms of circuit complexity, switching speed and the power dissipation.

The design of digital system from specification to final product involves a lot of effort. Among the possible design methodologies of full-custom, mask programmable and field programmable logic devices, field programmable gate array (FPGAs) [80] with different architecture and programming capacity are recently used overwhelmingly in different Application Specific Integrated Circuit (ASIC) development. Various types of sophisticated Computed Aided Design (CAD) tools are now available which really made the whole process feasible economically and timely.

6.1.1 Advantages of Using ASIC

The major advantages of using an ASIC are as follows;

(a) **Miniaturization **

The usage of custom ICs will reduce the size of the end product. An ASIC may replace the functions of a number of PCBs in the system, resulting in size reduction.

(b) **Lesser inventory **

The reduced number of components per system reduces the inventory. This in turn reduces the overall cost.

(c) **Reduced maintenance cost **

Lesser components lead to fewer failures and lesser system down time.

Maintenance will be easy. All it may need would be the replacement of a single PCB.

(d) **Lower power consumption **

Lesser number of components in a system reduces the power consumption.

Most of the ASICs are based on the low power CMOS technology.

81

*FPGA Implementation of the compression techniques *

(e) **Performance **

More number of functions can be integrated to the ASIC, without increasing the size, cost or power consumption of the product

6.1.2 Major Risks of Using ASIC

(a) **Higher Cost **

ASIC will be always expensive than the standard components. We have to invest more time and money for the design and development phase. The selection of the ASIC technology is very important.

(b) **Time to market **

The product lead time will be more for an ASIC based system. The market research team should define the requirement of the end product well in advance. Last minute changes in the specification will result in delayed market entry and revenue loss. The right product should be introduced in to the market at the right time.

(c) **First time success **

The ASIC design should be properly simulated and thoroughly tested to insure the first time success. Any failure will affect the time to market and resulting huge loss in revenue.

6.2 VLSI Design Methodologies

The basic steps involved in designing an ASIC can well be understood from the figure 6.1 [80]. This is an iterative process of development and testing.

ASIC can broadly be classified into following categories. ** **

(A) **Full Custom ASIC **

Possibly all logic cells and mask layers are customized in a full custom ASIC.

So, full custom ICs are more costly. Manufacturing time (not including design time) requires 8 to 10 weeks. Designers go for full custom if there is no suitable existing cell library which is fast enough or the logic cells are small enough or consume too much power.

82

*FPGA Implementation of the compression techniques *

This ASIC technology is chosen, based on many reasons like

1) Power consumption

2) Functional requirement

3) Speed of the ASIC

4) Non availability of suitable library

5) Product life, etc.

Microprocessor and Microcontroller are examples of full custom IC. Full custom technology is widely used in the mixed analog digital ASICs.** **

(B) **Semi-Custom ASIC **

In the semi custom ASIC, the designer will be using the pre-characterized and sometimes prefabricated logic cells. This approach reduces the design time and increases the turn around time of the ASIC.

Again the semi-custom ASIC can be subcategorized into,

1) Standard Cell based

2) Gate Array base

(C) **Programmable ASIC **

The programmable ASIC is the latest invention of the IC family. A programmable ASIC can be reprogrammed according to a change in the specification.

Just it needs to reconfigure itself by the new configuration file, unlike the case of other ASIC where one has to go through all the steps starting from specification to fabrication. It reduces the development time and cost. The programmable ASIC can be sub grouped into two types according to their architecture and function.

1) Programmable Logic Device (PLD)

2) Field Programmable Gate Array (FPGA)

83

*FPGA Implementation of the compression techniques *

3)

Figure 6.1: Steps involved in VLSI designing

84

*FPGA Implementation of the compression techniques *

6.3 FPGA Devices

FPGA is a high capacity programmable logic device [82]. An FPGA consists of an array of programmable basic logic cells surrounded by programmable interconnect. It can be configured by end user (field programmable) to have specific circuitry with in it. Any combinational or sequential circuit can be designed using

FPGA. The programmable logic array was introduced in the late 1970s and was followed by the introduction of the first FPGA, XC2000 series, by Xilinx in 1985.

The advantage of FPGAs is that they combine the performance that can be achieved by ASICs with the flexibility of programmable microprocessors. With these merits,

FPGAs destroyed the balance of gate array market and have taken a significant proportion of the standard cell market. Conceptually a programmable FPGA has three key elements as illustrated in figure 6.2.

**Programmable logic cells: **It provides the functional elements for constructing the user’s logic.

**Programmable Input/Output (I/O) blocks: **It provide the interface between the package pins and the logic cell.

**Programmable interconnects:*** *It provides routing paths to connect the inputs and outputs of the logic cell and I/O blocks.

Programmable

Function Unit

Programmable IO blocks

Programmable

Interconnect

Path

Figure 6.2: Internal Structure of an FPGA

85

*FPGA Implementation of the compression techniques *

Programmable

Memory element

Programmable

Memory element

0

1

1

1

0

0

1

0

S1 S1 S0

**MUX **

Clk

>

D-FF

M

U

X

Figure 6.3: Building block in basic cell design

Cout

For any programmable device the control information is stored in the memory which can be programmed as shown in figure 6.3. According to the select input from the programmable memory the accurate data are selected by the MUX and thus the switches are connected accordingly.

**6.3.1 Selection of FPGA device **

The performance and cost of the final FPGA based product, depends on the target FPGA. Therefore before making a prototype, it is very much essential to choose the target FPGA device. Large variations of FPGA devices are available, by different vendors. In this present research work the target FPGA **Virtex****, XCV1000**

**is selected and is a product from the vendor Xilinx [83]. The resources offered by this family of FPGA are summarized in Table 6.1 and Table 6.2. The Virtex FPGA family delivers high-performance, high-capacity programmable logic solutions. Dramatic increases in silicon efficiency result from optimizing the new architecture for placeand-route efficiency and exploiting an aggressive 5-layer-metal 0.22 µm CMOS process. These advances make Virtex FPGAs powerful and flexible alternatives to mask-programmed gate arrays.**

Table – 6.1 : FPGA Resources

Device System Gates CLB Array Logic Cells Available I/O Block RAM

XCV1000 1,124,022 64 X 96 27,648 512 131,072

86

*FPGA Implementation of the compression techniques *

Table – 6.2 : FPGA Resources

Device Slices Flip Flops 4 Input LUTs Available I/O Block RAM

XCV1000 12,288 24,576 24,576 512 131,072

Virtex devices feature a flexible, regular architecture as shown in figure 6.4, comprises an array of configurable logic blocks (CLBs) surrounded by programmable input/output blocks (IOBs), all interconnected by a rich hierarchy of fast, versatile routing resources. The abundance of routing resources permits the Virtex family to accommodate even the largest and most complex designs.

Virtex FPGAs are SRAM-based, and are customized by loading configuration data into internal memory cells. In some modes, the FPGA reads its own configuration data from an external PROM (master serial mode). Otherwise, the configuration data is written into the FPGA (Select- MAP™, slave serial, and JTAG modes). The standard Xilinx Foundation™ and Alliance Series™ Development systems deliver complete design support for Virtex, covering every aspect from behavioral and schematic entry, through simulation, automatic design translation and implementation, to the creation, downloading, and read-back of a configuration bit stream. Virtex devices provide better performance than previous generations of

FPGA. Designs can achieve synchronous system clock rates up to 200 MHz including

I/O. Virtex inputs and outputs comply fully with PCI specifications, and interfaces can be implemented that operate at 33 MHz or 66 MHz.

Figure 6.4: Virtex Architecture

87

*FPGA Implementation of the compression techniques *

**6.4 Introduction to AccelChip **

AccelChip DSP Synthesis, is a DSP (Digital Signal Processing) synthesis tool that allows to transform a MATLAB floating-point design into a synthesized hardware module that can be implemented in silicon (FPGA or ASIC). AccelChip

DSP Synthesis features an easy-to-use Graphical User Interface, called AccelView, that controls an integrated environment with other design tools such as MATLAB,

HDL simulators, logic synthesizers, and some vendor tools.

AccelChip® DSP Synthesis provides the following capability:

• Reads and analyzes a MATLAB floating-point design

• Automatically creates an equivalent MATLAB fixed-point design

• Invokes a MATLAB simulation to verify the fixed-point design

• Provides you with the power to quickly explore design tradeoffs of algorithms that are optimized for target FPGA and ASIC architectures

• Creates a synthesizable RTL HDL model and a Testbench to ensure bit-true, cycleaccurate design verification

• Provides scripts that invoke and control downstream tools such as HDL simulators,

RTL logic synthesizers, and vendor implementation tools.

**6.4.1 AccelChip DSP Synthesis Flow **

A MATLAB floating-point model is synthesized into a hardware module using the following basic steps in the AccelChip DSP Synthesis Flow shown in figure 6.5.

1. Examine the Coding Style of the Floating-Point Model. We should first verify that the MATLAB design conforms to minimum AccelChip style guidelines that are explained in the manual provided.

2. Create an AccelChip Project. We invoke AccelChip DSP Synthesis, then click

Project and specify the name of a new Project file. The Project file is placed in the

Project Directory where all future AccelChip-generated files are saved.

88

*FPGA Implementation of the compression techniques *

3. Verify the Floating-Point Model. We should have verification constructs in the

MATLAB script file to apply stimulus and plot results. This output plot is the

"golden" reference for comparing future results. If we have verified the floatingpoint model outside of AccelChip DSP Synthesis, we may skip this step.

4. Analyze the Floating-Point Model. This step creates an in-memory model of the design. In a later pass through this flow, one can add design directives that guide

AccelChip toward finding the best hardware architecture for the design.

5. Generate a Fixed-Point Model. This step generates a fixed-point model of the design, and then places the design files in a newly generated project sub-folder named MATLAB.

6. Verify the Fixed-Point Model. When we select Verify Fixed Point, AccelChip automatically runs a MATLAB fixed-point simulation. Then after the simulation visually compare the Fixed-Point Plot with the Floating-Point Plot to verify a match.

7. Generate an RTL Model. This step generates an RTL Model from the in- memory design data base. The RTL model can be generated in VHDL or Verilog format.

8. Verify the RTL Model with the HDL Simulator. When Verify RTL option is selected, HDL simulator will test the generated RTL code by using the generated

Testbench. Finally PASSED or FAILED will be indicated in a simulation report.

9. Synthesize the RTL Design into a Gate-Level Netlist. This step invokes a pre- specified RTL synthesis tool for the design. The generated gate-level netlist is ready for place and route using the Vendor's implementation tools.

10. Implement the Gate-Level Netlist. When Implement is selected it invoke the vendor's implementation tools to place and route the design. The generated files of interest are a gate-level HDL simulation file and a configuration file containing the bitstream for configuring the FPGA hardware.

11. Verify the Gate Level Design. This step uses the AccelChip Testbench to run a bit-true simulation check on the gate-level HDL simulation model. A PASSED indication means that the implemented design is bit-true with the original fixedpoint MATLAB design.

89

*FPGA Implementation of the compression techniques *

Figure 5.5: AccelChip DSP Synthesis Flow

**6.5 Simulation Results **

All the compression techniques discussed in the previous chapters are synthesized by using the AccelChip DSP Synthesis tools. FPGA **Virtex****, XCV1000**

**device is used for synthesize all the algorithms to get an approximate hardware requirements for their calculation. The comparative study is performed in terms of number of slices, number of Flip Flops, number of LUTs used, Table 6.3 presents lists for calculation of DCT, IDCT, JPEG quantisation, energy quantisation (EQ), modified energy quantisation (MEQ), rule based energy quantisaton (RBEQ), DHT and IDHT, Arithmetic compression technique respectively. Table 6.4 presents a comparative study for different image compression techniques in terms of size and**

90

*FPGA Implementation of the compression techniques *

power consumption in mW calculated using the Xilinx websites power calculation tool [81]. For calculation of the power consumption we have assumed that all the devices are operated at 10MHz frequency.

Table 6.3: Synthesize reports of different techniques

Number of

Slices Used

Number of Flip

Flops used

Number of 4

Input LUTs used

DCT Calculation

IDCT Calculation

JPEG Quantisation

JPEG Dequantisation

Energy Quantisation

(EQ)

Modified Energy

Quantisation (MEQ)

Rule Based Energy

Quantisation (RBEQ)

DHT and IDHT

Arithmetic difference

Encoding

Arithmetic difference

Decoding

Arithmetic Encoding with snake scan

Arithmetic Encoding with snake scan

4836

6295

15338

14146

6561

8346

22827

11250

8538

11188

27529

25811

17927 25816 33099

15602 23163 27951

11867 14741 9990

5939 4420 10844

950 149 1381

22 37 35

1897 236 2766

52 64 94

91

*FPGA Implementation of the compression techniques *

Table 6.4: Comparison between different image compression technique in terms of size and power consumption

Compression

Techniques

Number of

Slices Used

Number of

Flip Flops used

Number of 4

Input LUTs used

Power consumed in mW

DCT + IDCT + JPEG

Quantisation

DCT + IDCT + EQ

DCT + IDCT + MEQ

40615 48984 73066

29058

26733

40723

38070

52825

47677

2011

1637

1501

DCT + IDCT + RBEQ 22998

DHT + IDHT + JPEG

Quantisation

DHT + IDHT + EQ

29648 29716

35423 38497 64184

23866 30236 43943

1056

1811

1301

DHT + IDHT + MEQ 21541

DHT + IDHT + RBEQ 17806

27583

19161

38795

20834

1165

720

Arithmetic difference coding and decoding

Arithmetic Snake scan coding and decoding

972 186 1416

1949 300 2860

11

22

It is clear form the implementation that the hard ware requirement gradually decreases form vector quantisation to rule based energy quantisation. DHT based

JPEG with rule based energy quantisation is an ideal solution for lossy image compression technique as the hardware requirement is less and power consumption is very low compare to other techniques. If we want to go for good quality, low compression and high speed then the arithmetic compression with snake scanning is the best choice, which also consumes very less power compare to the rest compression techniques. The schematic generated after implementation of the last technique is shown in Appendix-1.

92

LOW POWER

Image Compression Techniques

Chapter

7

# Conclusion

*Conclusion *

The work in this thesis, primarily focuses on image compression with less computation and low power. Novel schemes for quantisation of transformed coefficients have also been devised. The work reported in this thesis is summarized in this chapter. Section 7.1 lists the pros and cons of the work. Section 7.2 provides some scope for further development.

**7.1 Achievements and Limitations of the work **

A brief study on low power VLSI design is discussed in Chapter II. The main sources of power losses in the transistors are explained and the necessary action has to be taken to reduce this losses were specified. All the low power techniques such as system level, algorithm level, architecture level, logic level and circuit level are explained elaborately also explains how these techniques are used for power reduction. Lastly it describes the basic steps to be followed for low power design.

It is observed from the investigations made in Chapter III that the proposed three quantisation techniques: energy quantisation, modified energy quantisation and rule based energy quantisation are better candidate for signal and image compression compared to the standard scalar and vector quantisation techniques. Further the rule based energy quantisation technique makes the quantisation process intelligent by setting different threshold value for different image blocks and yields superior compression performance as compared to other techniques. The computational complexity of the proposed techniques is also less compare to the standard JPEG technique.

In Chapter IV we have discussed an alternative scheme of JPEG by substituting the DHT in place of the conventional DCT. Such a substitution has resulted improved compression and reconstruction performance. It is shown that qualitatively the new JPEG offers superior performance. Further there is a saving in hardware if DHT is employed in place of the DCT. We have also used the quantisation techniques proposed in chapter-III with this DHT based JPEG compression technique. Which further reduces the computational complexity and also facilitates easier implementation.

As digital storage is becoming so cheap and so wide spread and the available transmission channel bandwidth is increasing due to the deployment of cable, fiber optics and ADSL modems, why is there a need to provide more powerful compression scheme? The answer is, with no doubt mobile video transmission

93

*Conclusion *

channels and Internet streaming, which mainly requires high quality and high speed.

Chapter V we provide a novel lossless image compression technique. The main aim behind this technique is to reduce the complexity and secondly to make the compression technique fast with a reasonable image compression. With this new technique the compression and decompression technique becomes very faster and also hardware requirement is very less compare to other techniques re out signal compression the transmission time as well as the storage requirement will be large but inclusion of compression and reconstruction scheme reduces the storage requirement and data transmission time.

VLSI designing procedure is discussed briefly in chapter-VI. All the advantages and disadvantage of using FPGA over ASIC design is discussed. How to select the FPGA device for different requirements were discussed. AccelChip DSP

Synthesis, is a DSP (Digital Signal Processing) synthesis tool that allows to transform a MATLAB floating-point design into a synthesized hardware module that can be implemented in silicon (FPGA or ASIC), all the step involved for the implementation of different algorithms were discussed. Finally some conclusions were made on the basis of the implementation results. It is clear form the implementation that the hard ware requirement gradually decreases form vector quantisation to rule based energy quantisation. DHT based JPEG with rule based energy quantisation is an ideal solution for lossy image compression technique as the hardware requirement is less and power consumption is very low compare to other techniques. If we want to go for good quality, low compression and high speed then the arithmetic compression with snake scanning is the best choice, which also consumes very less power compare to the rest compression techniques.

In general, it is concluded that the investigation made in the present thesis pertains to the development of some alternative compression-reconstruction schemes, which offer superior performance compared to the conventional works. The proposed quantisation techniques for image compression proposed in the thesis has aimed to enhance the CR required for some multimedia applications while reducing the computational complexity for coding and decoding. Simulation study has been carried out to support this idea. Further all the compression techniques proposed were implanted to get the size required in terms of number of slices, LUTs, Flip-Flops used which is used to calculate the power consumption by different techniques. Which

94

*Conclusion *

exploits the use of efficient image compression and reconstruction schemes with low power consumption.

To conclude this thesis, following are some points that may lead to some better and interesting results.

The different image compression techniques developed in the thesis can suitably be applied for 3D video signals. Some hybrid image compression scheme or algorithms can be developed by using some soft computing techniques like multilayer

Artificial Neural Network (ANN), Radial Basis Function (RBF), Multi-Layer

Perceptron (MLP) with the proposed techniques. This investigation may lead to intelligent and adaptive efficient compression scheme. The proposed quantisation techniques can be used in other image compression techniques such as Discrete

Wavelet Transform (DWT) and Slantlet transform to threshold the transformed coefficients.

95

**Bibliography **

[1] David Salomon, Data Compression, The Complete Reference, 2nd Edition

Springer-Verlag 1998.

[2] Digital Compression and coding of Continuous-tone still images, part 1, requirements and Guidelines. ISO/IEC JTC1 Draft International Standard

10918-1, Nov. 1991.

[3] Digital Compression and coding of Continuous-tone still images, part 2, compliance Testing. ISO/IEC JTC1 Committee Draft 10918-1, Dec. 1991.

[4] E. Fossum, "CMOS Image Sensors: Electronic Camera on a Chip", IEEE Int.

Electron. Devices Meeting Tech. Digest, Dec. 1995, pp. 1-9.

[5] Eyadat, M.; Muhi, I.; “Compression standards roles in image processing: case study”, International Conference on Information Technology: Coding and

Computing, 2005. ITCC 2005. Volume 2, 4-6 April 2005 Page(s):135 - 140

Vol. 2.

[6] Frank Vahid, Tony Givargis, “Embedded System Design: A Unified

Hardware/Software Introduction”, John Wiley & Sons, 2002.

[7] K. A. Parulski, "Color Filters and Processing Alternatives for One-chip

Cameras," IEEE Trans. Electron Devices, Vol. ED-32, NO. 8, pp. 1381-1389,

Aug. 1985.

[8] N. Kihara, et al., "The Electronic Still Camera: A New Concept in

Photography," IEEE Trans. Cons. Electron., Vol. CE-28, NO. 3, pp. 325-

335, Aug. 1982.

[9] R. C. Gonzalez and R. E. Woods, “Digital Image Processing”, Reading. MA:

Addison Wesley, 2004.

[10] Ranjan Bose, Information theory coding and Cryptography, Tata McGraw-

Hill

2003.

[11] S. Narayanaswamy, S. Seshan, E. Amir, et al., “A low-power, lightweight unit to provide ubiquitous information access application and network support for

InfoPad”, IEEE Personal Communications, pp. 4–17, Apr. 1996.

[12] A. Chadrakasan and R. W. Brodersen, Low Power Digital CMOS Design,

Kluwer, 1995.

[13] A. Chadrakasan, M. P. Potkonjak, R. Mehra, J. Rabey, and R. W. Brodersen,

“Optimizing power using transformations,” IEEE Trans. on Computer-Aided

Design, Vol. 14, No. 1, pp. 12–31, Jan., 1995.

[14] A. P. Chandrakasan, S. Sheng, and R. W. Brodersen, “Low-power CMOS digital design”, IEEE Journal of Solid-State Circuits, vol. 27, no. 4, pp. 473–

483, Apr. 1992.

[15] Bright, M.S.; Arslan, T.; “Synthesis of low-power DSP systems using a genetic algorithm”, IEEE Transactions on Evolutionary Computation, Volume

5, Issue 1, Feb 2001 Page(s):27 – 40.

[16] Chunyan Wang; “Low-power VLSI design and implementation, from another point of view”, Proceedings of 2005 IEEE International Workshop on VLSI

Design and Video Technology, 2005. 28-30 May 2005 Page(s): xix – xix.

[17] Elassal, M.; Baker, A.; Bayoumi, M.; “A low power VLSI design paradigm for iterative decoders”, IEEE Workshop on Signal Processing Systems

Design and Implementation, 2005. 2-4 Nov. 2005 Page(s):272 – 277.

[18] G. K Yeap, “Practical Low Power Digital VLSI Design”, Kluwer Academic

Publishers, Norwell, Mass., 1998.

[19] H. J. M. Veendrick, “Short-circuit dissipation of static CMOS circuitry and its impact on the design of buffer circuits,” IEEE Journal of Solid-State Circuit,

Vol. 19, pp. 468–473, Aug., 1984.

[20] L. Nielsen, C. Nielsen, J. Spars, and K. van Berkel, “Lowpower operation using self-timed circuits and adaptive scaling of the supply voltage,” IEEE

Trans. on VLSI Systems, Vol. 2, No. 4, pp. 391–397, Dec., 1994.

[21] Rabaey JM and Pedram M, “Low Power Design Methodologies”, Kluwer

Publishers, 1996.

[22] Sakurai, T.; “Low-power and high-speed VLSI design with low supply voltage through cooperation between levels”, International Symposium on

Quality Electronic Design, 2002. Proceedings. 18-21 March 2002 Page(s):445

– 450.

[23] V. Tiwari, S. Malik, and P. Ashar, “Compilation techniques for low energy: an overview,” In Proc. of 1994 IEEE Symp. On Low Power Electronics, San

Diego, California, USA, Oct., 1994, pp. 38–39.

[24] Agostini, L.V.; Silva, I.S.; Bampi, S.; “Pipelined entropy coders for JPEG compression”, Proceedings. 15th Symposium on Integrated Circuits and

Systems Design, 2002. 9-14 Sept. 2002 Page(s):203 – 208.

[25] Agostini, L.V.; Silva, I.S.; Bampi, S.; “Pipelined fast 2D DCT architecture for

JPEG image compression”, 14th Symposium onIntegrated Circuits and

Systems Design, 2001, 10-15 Sept. 2001 Page(s):226 – 231

[26] Arcangelo, B.; Massimo, M.; “JPEG compression factor control: a new algorithm”, International Conference on Consumer Electronics, 2001. ICCE.

19-21 June 2001 Page(s):206 – 207

[27] Battiato, S.; Mancuso, M.; Bosco, A.; Guarnera, M.; “Psychovisual and statistical optimization of quantization tables for DCT compression engines”,

Proceedings. 11th International Conference on Image Analysis and

Processing, 2001. 26-28 Sept. 2001 Page(s):602 – 606.

[28] Bruna, A.; Capra, A.; Battiato, S.; La Rosa, S.; “Advanced DCT rate control by single step analysis”, International Conference on Consumer Electronics,

2005. ICCE. 2005 Digest of Technical Papers. 8-12 Jan. 2005 Page(s):453 –

454.

[29] Campbell, D.; Maeder, A.; Tapia-Vergara, F., “Mammogram JPEG quantisation matrix optimisation for PACS”, The Seventh Australian and New

Zealand 2001 Intelligent Information Systems Conference, 18-21 Nov. 2001

Page(s):1 – 6.

[30] Chun-Hsien Chou; Kuo-Cheng Liu, “Color Image Compression using

Adaptive Color Quantization”, Image Processing, 2004. ICIP '04. 2004

International Conference on Vol. 4, 24-27, pp. 2331 – 2334, Oct. 2004

[31] D.L. Tull, Robert J. Safranek, “Variable dimension quantization in the transform domain”, ICIP 1995, pp. 302-305, 1995

[32] G. K. Wallace, “The JPEG Still Picture Compression Standard”, IEEE Trans.

On Consumer Electronics, vol.38, No.1, pp. xviii – xxxiv, Feb 1992.

[33] Golner, M.A.; Mikhael, W.B.; Krishnan, V.; Ramaswamy, A, “Region Based

Variable Quantization for JPEG Image Compression”, Circuits and Systems,

2000. Proceedings of the 43rd IEEE Midwest Symposium on Vol. 2, pp 604 –

607, Aug. 2000.

[34] H. F. Silverman, “An introduction to programming the Winograd Fourier transform algorithm (WFTA)”, IEEE Trans. Acoust., Speech, Signal

Processing, vol. ASSP-25, pp. 152-165, Apr. 1977.

[35] John G. Proakis and D. G. Manolakis, “Digital Signal Processing”, Prentice

Hall, 3 rd

Edition, May’ 1994.

[36] L. Karray, P. Duhatnel, and O. Rioul, " Image coding with an if norm and confidence interval criteria", IEEE Trans. Imaging Processing, Vol.7, no. 5, pp.621-631, Sep 1994.

[37] M. Goldberg, P. R. Boucher, and S. Shlien, “image Compression Using

Adaptive Vector Quantization”, IEEE Trans. Commun., Vol. COM-34, No. 2,

Feb. 1986.

[38] Melnikov, G.; Katsaggelos, A.K.; “A jointly optimal fractal/DCT compression scheme”, IEEE Transactions on Multimedia, Volume 4, Issue 4, Dec. 2002

Page(s):413 – 422.

[39] N. Ahmed, T. Natrajan, and K. R. Rao, “Discrete Cosine Transform”, IEEE

Transactions on Computers, vol. 23, pp. 90-93, July 1989.

[40] Neelamani, R.; deQueiroz, R.; Fan, Z.; Dash, S.; Baraniuk, R.G.; “JPEG

Compression History Estimation for Color Images”, International Conference on Image Processing, 2003. ICIP 2003. Volume 3, 14-17 Sept. 2003

Page(s):III - 245-8 vol.2

[41] R. L. de Queiroz, P. Fleckenstein, “Very Fast JPEG Compression Using

Hierarchical Vector Quantization”, IEEE Signal Processing Letters, Vol. 7,

No. 5, pp. 97-99, May 2000

[42] R. M. Gray, “Vector Quantization”, IEEE ASSP Mag., PP 4-29, Apr. 1984.

[43] R. M. Gray, D. L. Neuhoff, “Quantization”, IEEE Trans. Inform. Theory, Vol.

44, No. 6, 1998.

[44] S. Martucea, “Symmetric convolution and the discrete sine and cosine transform”, IEEE Transaction on Signal Processing, vol. 42, pp. 1038-1051,

May’ 1994.

[45] S. P. Lioyd, “Least-Squares Quantization in PCM”, IEEE Trans. Inform.

Theory, Vol. IT-25, pp. 373-380, July 1979.

[46] S. Winograd, “On computing the discrete Fourier transform”, Math. Comput., vol. 32, pp. 175-199, Jan. 1978.

[47] Samadani, R.; Sundararajan, A.; Said, A.; “Deringing and deblocking DCT compression artifacts with efficient shifted transforms”, 2004 International

Conference on Image Processing, 2004. ICIP '04. Volume 3, 24-27 Oct. 2004

Page(s):1799 - 1802 Vol. 3.

[48] Shneier and M. Abdel-Mottaleb., “Exploiting the JPEG compress scheme for image retrieval.” IEEE Trans. Pattern Anal. Machine Intel, vol. 18, pp. 849-

853, Aug. 1996.

[49] Soo-Chang Pei; Jian-Jiun Ding; “Generalized eigenvectors and fractionalization of offset DFTs and DCTs”, IEEE Transactions on Signal

Processing, Volume 52, Issue 7, July 2004 Page(s):2032 – 2046.

[50] W. B. Pennebaker and J. L. Mitchell., JPEG Still Image Data Compression

Standard, Van Nostrand Reinhold, New York, 1993.

[51] Wu, Y.-G.; “GA-based DCT quantisation table design procedure for medical images”, IEE Proceedings-Vision, Image and Signal Processing, Volume 151,

Issue 5, 30 Oct. 2004 Page(s):353 – 359.

[52] Y. Linde, A. Buzo, and R. M. Gray, “An algorithm for vector quantizer design”, IEEE Trans. Commun., Vol. COM-28, pp. 84-95, Jan. 1980.

[53] Ying Luo; Ward, R.K.; “Removing the blocking artifacts of block-based DCT compressed images”, IEEE Transactions on Image Processing, Volume 12,

Issue 7, July 2003 Page(s):838 – 842.

[54] A. Murat Tekalp, “Digital Video Processing”, Prentice Hall Publication, NJ,

1995.

[55] Jiebo Luo; Qing Yu; Miller, M.E.; “A triage method of determining the extent of JPEG compression artifacts”, Proceedings. 2002 International Conference on Image Processing. 2002. Volume 1, 22-25 Sept. 2002 Page(s):I-473 - I-

476 vol.1.

[56] Meher, P.K.; Srikanthan, T.; Gupta, J.; Agarwal, H.K.; “Near lossless image compression using lossless Hartley like transform”, Fourth Pacific Rim

Conference on Multimedia, Information, Communications and Signal

Processing, 2003 and the Volume 1, 15-18 Dec. 2003 Page(s):213 - 217

Vol.1.

[57] O, Buneman, et al: “Multidimensional Hartley transform”, Proc. Of IEEE, vol.

75, no. 2, pp. 267, Feb. 1987

[58] P. K. Meher, J. K. Satapathy, and G. Panda, “Fast computation of multidimensional discrete Hartley Transform”, Electronics letter, vol. 28, no.

12, pp. 1077-1078, June 1992.

[59] R. N. Bracewell, et al: “Discrete Hartley Transform”, J. Opt. Soc. Amer., vol.

73, no. 12, pp. 1832-1835, Dec. 1983.

[60] R. N. Bracewell, O. Buneman, et al: “Fast two-dimensional Hartley transform”, Proc. IEEE, vol. 74, no. 9, pp. 1282-1283, Sept. 1986

[61] R. V. L. Hartley, et al: “A more symmetrical Fourier analysis applied to transmission problem””, Proc. IRE, vol. 30, pp. 144-150, Mar. 1942.

[62] Avcibas, I.; Memon, N.; Sankur, B.; Sayood, K.; “A successively refinable lossless image-coding algorithm”, Communications, IEEE Transactions on

Volume 53, Issue 3, March 2005 Page(s):445 – 452

[63] Boulgouris, N.V.; Tzovaras, D.; Strintzis, M.G.; ”Lossless image compression based on optimal prediction, adaptive lifting, and conditional arithmetic coding”, IEEE Transactions on Image Processing, Volume 10, Issue 1, Jan.

2001 Page(s):1 – 14.

[64] Chin-Chen Chang; Chih-Ping Hsieh; Ju-Yuan Hsiao; “A new approach to lossless image compression”, International Conference on Communication

Technology Proceedings, 2003. ICCT 2003. Volume 2, 9-11 April 2003

Page(s):1734 - 1738 vol.2.

[65] Jayant, N-Johnston, J. Safranek, “Signal Compression Based in Models of

Human Perception”, Proc. of IEEE 81(1993), 1385-1422.

[66] K. Chen and T.V. Ramabadran, “Near-lossless compression of medical images through entropy-coded DPCM", IEEE Trans. Med. Imaging, Vol.13, no. 3, pp.538-548, Sep 1994.

[67] Krivoulets, A.; “A method for progressive near-lossless image compression”,

2003 International Conference on Image Processing, 2003. ICIP 2003.

Proceedings. Volume 2, 14-17 Sept. 2003 Page(s):II - 185-8 vol.3.

[68] Krivoulets, A.; “Progressive near-lossless coding of medical images”,

Proceedings of the 3rd International Symposium on Image and Signal

Processing and Analysis, 2003. ISPA 2003. Volume 1, 18-20 Sept. 2003

Page(s):202 - 207 Vol.1.

[69] M. Das, D.L. Neuhoff and C.L. Lin, "Near-lossless compression of medical images", Proc. International Conference on Acoustics, Speech, and Signal

Processing, 1995. ICASSP-95, Vol.4, pp. 2347 -2350, 1995.

[70] Mielikainen, J.; Toivanen, P.; “Clustered DPCM for the lossless compression of hyperspectral images”, IEEE Transactions on Geoscience and Remote

Sensing, Volume 41, Issue 12, Part 2, Dec. 2003 Page(s):2943 – 2946.

[71] Rane, S.D.; Sapiro, G.; “Evaluation of JPEG-LS, the new lossless and controlled-lossy still image compression standard, for compression of highresolution elevation data”, IEEE Transactions on Geoscience and Remote

Sensing, Volume 39, Issue 10, Oct. 2001 Page(s):2298 – 2306.

[72] Ratakonda, K.; Ahuja, N.; “Lossless image compression with multiscale segmentation”, IEEE Transactions on Image Processing, Volume 11, Issue 11,

Nov. 2002 Page(s):1228 – 1237.

[73] Redondo, R.; Cristobal, G.; “Lossless chain coder for gray edge images”,

Proceedings. 2003 International Conference on Image Processing, 2003. ICIP

2003. Volume 2, 14-17 Sept. 2003 Page(s): II - 201-4 vol.3.

[74] S. C. Huang, L. G. Chen, “LOG-EXP Compression System Design and

Implementation”, IEEE International Sym. On Consumer Electronics, 1998.

[75] S. C. Huang, L. G. Chen, “LOG-EXP Still Image Compression Chip Design”,

IEEE Trans. On Consumer Electronics, vol.45, No.3, pp. 812 – 818, Aug

1999.

[76] S. C. Huang, L. G. Chen, H. C. Chan,“A Novel Image Compression

Algorithm by Using LOG-EXP Transform”, IEEE Sym. On Circuits and

System, 1999.

[77] S. Chokchaitam and M. Iwahashi, "Lossless, near-lossless and lossy adaptive coding based on the lossless DCT," Proc. IEEE International Symposium on Circuits and Systems, 2002. ISCAS 2002. Voi.l, pp. I-781 -1-784, 2002.

[78] Van der Vleuten, R.J.; “Low-complexity lossless and fine-granularity scalable near-lossless compression of color images”, Proceedings. DCC 2002Data

Compression Conference, 2002. 2-4 April 2002 Page(s):477.

[79] Xin Chen; Ju-fu Feng; Kwong, S.; “Lossy and lossless compression for colorquantized images”, Proceedings. 2001 International Conference on Image

Processing, 2001. Volume 1, 7-10 Oct. 2001 Page(s):870 - 873 vol.1.

[80] M.J.S. Smith, Application Specific Integrated Circuits, Pearson Education,

2003.

[81] Power calculation site: http://www.xilinx.com/cgi-bin/powerweb.pl

[82] Stephen Trimberger, Field Programmable Gate Array Technology, Kluwer

Academic Publishers, 1994.

[83] The Xilinx Home page: www.xilinx.com

Block - 1

Block -2 and Block -3

(Implementation Block Diagram of Arithmetic Compression Technique )

*Appendix - I *

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

### Related manuals

advertisement
