Albatros2
The Albatros2 family is a comprehensive range of controls. It offers solutions for
basic to complex heating plant.
• Uniform and integral operating philosophy with clear-text display and menudriven operation
• Wireless or hard-wired peripheral devices (e.g. room unit, outside sensor)
• All-polar connections
• Extensive service and diagnostic functions
• remote supervision
Use
Types of buildings
• Residential and nonresidential buildings with own zone heating and DHW heating
facility
• Residential and non-residential buildings with a central heating plant
Types of heating systems
• Standard heating systems with:
Radiator, convector, floor, ceiling and radiation heating systems, DHW heating and
buffer storage tanks
• Types of heat sources:
Oil/gas boilers, heat pumps, solar plant, solid fuel boilers
