Development of a demonstration device for vibrations

Jonathan Gengenbach

Bachelor’s thesis

May 2015

Degree Programme in Mechanical and Production Engineering

1

Table of contents

1 Introduction and objectives ..................................................... 6

2 Theoretical part ....................................................................... 7

2.1

Introduction and motivation.................................................................. 7

2.2

Laval Rotor ............................................................................................. 7

2.2.1

Modelling ......................................................................................... 7

2.2.2

Simulation ..................................................................................... 12

2.2.3

System behaviour .......................................................................... 13

2.2.4

Supporting ..................................................................................... 15

2.2.5

Weaknesses of the model .............................................................. 16

2.3

System with two and more degrees of freedom ................................... 18

2.3.1

Introduction ................................................................................... 18

2.3.2

Natural frequencies and natural modes of a continuous shaft ..... 18

2.3.3

Rotor with two attached disks ....................................................... 19

2.4

Torsional vibrations ............................................................................ 24

3 Development of the demonstration device .............................. 26

3.1

Introduction ........................................................................................ 26

3.2

Features of the device ........................................................................... 27

3.3

Concept ................................................................................................. 27

3.4

Drafting ............................................................................................... 28

3.4.1

Functional groups ......................................................................... 28

3.4.2

Dimensioning rotor ...................................................................... 29

3.4.3

Supporting .................................................................................... 32

3.4.4

Shaft hub joint ............................................................................... 37

3.4.5

Housing ......................................................................................... 40

3.4.6

Safety concept ............................................................................... 42

2

3.4.7

Safety bearing ................................................................................ 45

3.5

Elaboration .......................................................................................... 46

3.5.1

Introduction .................................................................................. 46

3.5.2

Bearing choosing ........................................................................... 47

3.5.3

Supporting design .......................................................................... 51

3.5.4

Rotor design ................................................................................... 55

3.5.5

Safety bearing design ..................................................................... 59

3.5.6

Shaft design .................................................................................. 60

3.5.7

Housing design .............................................................................. 67

3.5.8

Safety-cap design .......................................................................... 68

3.6

Summary and prospects ...................................................................... 69

4 Summary ............................................................................... 71

5 Discussion .............................................................................. 72

6 References ............................................................................. 73

7 Attachment ............................................................................ 75

3

Figures

Figure 1: Laval Rotor with blocked translatory motion ..................................... 8

Figure 2: Laval Rotor with equivalent Springs and damping ............................ 8

Figure 3: Laval Rotor with forces ....................................................................... 8

Figure 4: Bearing's influence of the equivalent stiffness .................................. 11

Figure 5: Unbalance ........................................................................................... 11

Figure 6: Simulink model equation (2.4) .......................................................... 12

Figure 7: Simulink model equation (2.2) .......................................................... 13

Figure 8: Simulink model .................................................................................. 13

Figure 9: Simulink model constant angular speed............................................ 13

Figure 10: Transfer function Laval Rotor .......................................................... 14

Figure 11: Orbits centre of shaft and mass ........................................................ 14

Figure 12: Laval Rotor with non-rigid bearings ................................................ 15

Figure 13: Comparison stiffness ratio of shaft to supporting............................ 16

Figure 14: Beam's three lowest mode shapes .................................................... 19

Figure 15: Rotor with two disks ........................................................................ 20

Figure 16: Bending line w(F,x) .......................................................................... 21

Figure 17: Force diagram at position I and II .................................................... 21

Figure 18: Rotatory motion of the disk ............................................................. 23

Figure 19: Torsional system .............................................................................. 24

Figure 20: Diagram of moments ...................................................................... 24

Figure 21: Unbalanced caused force .................................................................. 25

Figure 22: arrangement with a) one rotor b) two rotor c) cantilevered rotor . 28

Figure 23: Curves of constant masses and frequency ...................................... 30

Figure 24: max. rotor displacement according unbalanced mass and damping ratio .................................................................................................................... 31

Figure 25: Bearing arrangement ...................................................................... 34

Figure 26: Design proposals bearing shifting ................................................... 35

Figure 27: Design proposals shaft hub connection .......................................... 38

Figure 28: Ringspann Trontorque Mini (Ringspann GmbH, 2014) ................ 39

Figure 29: Design proposals housing ............................................................... 40

Figure 30: Safety bearing concept .................................................................... 46

4

Figure 31: non-rigid bearing axis ....................................................................... 47

Figure 32: self-aligning ball bearing ................................................................. 48

Figure 33: Force diagram disk .......................................................................... 48

Figure 34: Supporting ........................................................................................ 51

Figure 35: Bearing loading ................................................................................ 52

Figure 36: Fittings bearing ................................................................................ 52

Figure 37: Stress due to shrinkage fit ................................................................ 55

Figure 38: Stress due to dynamic loading ......................................................... 55

Figure 39: Inner rotor ........................................................................................ 56

Figure 40: Outer rotor ....................................................................................... 56

Figure 41: Safety bearing .................................................................................. 60

Figure 42: ROTEX coupling (KTR Kupplungstechnik GmbH , 2015) .............. 61

Figure 43: Bending line .................................................................................... 62

Figure 44: Shaft connection .............................................................................. 63

Figure 45: FE calculation strain caused by bending ......................................... 65

Figure 46: FE calculation combined stress ....................................................... 65

Figure 47: Stress cycle ........................................................................................ 65

Figure 48: fatigue strength diagram .................................................................. 67

Figure 49: Housing ........................................................................................... 68

Figure 50: Safety cap with several plates ......................................................... 69

Figure 51: Safety cap with bended plate ........................................................... 69

Figure 52: Complete device .............................................................................. 70

5

Tables

Table 1: Rotor dimensions ................................................................................. 31

Table 2: Decision matrix supporting .................................................................33

Table 3: Decision matrix bearing adjusting ..................................................... 36

Table 4: Decision matrix shaft hub joint .......................................................... 39

Table 5: Decision matrix housing ...................................................................... 41

Table 6: Harm evaluation categories (Mattilainen, 2015) ............................... 43

Table 7: Levels of risk (Mattilainen, 2015) ....................................................... 44

Table 8: Risks of the identified hazards ........................................................... 44

Table 9: Parameter bearing calculation............................................................ 49

Table 10: Bearing load ratings .......................................................................... 50

Table 11: Properties PA6 and POM-C ................................................................ 53

Table 12: Parameter for fit selection .................................................................. 57

Table 13: Main properties ROTEX coupling ..................................................... 61

Table 14: Properties Loctite 638 ....................................................................... 63

Table 15: Properties S355 ................................................................................. 66

6

1

Introduction and objectives

I got the possibility to finish my Automotive Engineering studies in the double degree program which is provided in cooperation of my home institution, the

Hochschule Esslingen University of Applied Sciences and the JAMK University of Applied Sciences. Therefore I have spent the autumn semester 2014 and the spring semester 2015 at the JAMK in Jyväskylä, Finland. Part of the double degree program is creating the bachelor’s thesis abroad. In the end of the autumn semester 2014, Jorma Matilainen who is principal lecturer in the

School of Technology, proposed me to make the, in this document introduced, development project within my thesis work. At this point I want to thank

Jorma for the opportunity to do the thesis work at the JAMK and for his supervision as his role as representative of the host organisation. Furthermore I want to thank Matti Kurki who accompanies the thesis work as the supervisor.

The objective of this thesis work is to develop a laboratory device which demonstrates imbalance excited bending vibrations of a shaft. The device’s purpose is to illustrate the in the lecture taught theory about critical shaft revolution speeds and to sensitise the students for the thereby arising risks.

The thesis is separated into two main parts, the theoretical part (chapter 2)

and the actual development project (chapter 3). The theoretical part deals with

the modelling and mathematically description of the oscillating rotor and

serves as fundament for the designing of the device. Chapter 3 includes all

steps which are passed while developing the demonstration device.

7

2

Theoretical part

2.1

Introduction and motivation

Bending vibrations of a shaft which are caused by an unbalanced mass distribution have a big influence of the runnability and the stability of machines. On bearings transmitted vibrations stress the bearings and reduce their life expectancy. The vibrations also can generate noises and rattling which are disturbing the machine users and the environment. The oscillating bending of the shaft increase the strain in the shaft which can cause an earlier destruction.

High displacements of the shaft bring the risk of a collision between the shaft and the housing. Because of the named hazards it is necessary to consider imbalances while designing and operating a machine with a turning shaft.

In the theoretical part the effect of this vibrations are illustrated. It basically examines two different types of vibrations, the imbalanced excited bending vi-

brations (2.2, 2.3) and the imbalanced excited torsional vibrations which are

studied in brief in chapter 2.4. In chapter 2.2 the bending vibrations are de-

duced in the simplified one degree of freedom model. Based on the in chapter

2.2 gained knowledge the chapter 2.3 introduces shortly bending vibrations in

systems with two and more degrees of freedom.

2.2

Laval Rotor

2.2.1

Modelling

The simplest model to understand and calculate the effect of an imbalanced rotor is the so called Laval Rotor which is in English-written literature often introduced as Jeffcott-Rotor. The Laval Rotor was first described and patented by the Swedish engineer Gustav de Laval (Gasch, Nordmann, & Pfützner,

2006, 15). The Laval Rotor consists of a bending flexible and massless shaft

with a disk attached on its half-length (Figure 1). The most elementary bearing

model are two bearings which are infinite stiff in vertical directions to the shaft and torque-free for bending. In the technical mechanics this bearings are called pinned-supporting.

8

Figure 1: Laval Rotor with blocked translatory motion

Because of the symmetric structure of the system the disk is only free to shift vertically to the shaft (y- and z- direction) as well as to rotate around the shafts axis (x-direction) and does not tilt around the y- and z- axis. Due the simplification of the shaft as massless and the fact that in this particular system the disk is just moving in a plane the shaft is substitutable for a spring with an

equivalent stiffness k (Figure 2). Another simplification of the system is the

negligence of the gravity so that there is no static bending caused by the gravity force. In an imbalanced rotor the centre of the disk

’s mass C is not the same then its geometrical centre M. If the disk is not displaced its geometrical centre is on the bearings centres’ connection line. To simplify the calculations it is functional to place the origin of co-ordinates into the connection line of the bearings.

Figure 2: Laval Rotor with equivalent Springs and damping

Figure 3: Laval Rotor with forces

9

Figure 3 shows the force-diagram of the in y- and z-direction displaced Laval

Rotor. z m and y m

are the displacement of the rotor. z c and y c are the positions of the disk’s centre of mass. e is the constant value of the disks eccentricity. The determination of the mathematically determination of the eccentricity e is de-

scribed in the equation (2.7).

� is the current rotation angle of the disk. � is for calculation reasons determined as counter clockwise (mathematical positive) and begins on the z-axis. The active forces in this model of the Laval Rotor are the inert forces

∙ / ∙ , the spring forces ∙

/

and the forces which are caused by the damping

/

. The damping in this model is implemented as a viscose damping which is the mathematically simplest way to describe damping. The accurateness and weakness of this damping model will be discussed later. According to the

Newton’s Law of Motion the rotor has

to be in balance of forces (2.1).

∙ + ∙ + ∙ =

∙ + ∙ + ∙ =

(2.1)

Beside the forces the torques also have to be in balance. The moments which act around C are the rotor’s moment of inertia � ∙ , the inertia of the rotor’s mass multiplied by the effective eccentricity

∙ cos � ∙ / ∙ cos � ∙ and the external driving torque .

∙ sin � ∙ ∙ + ∙ − ∙ cos � ∙ ∙ + ∙

+� ∙ − =

(2.2)

With help of the trigonometric functions and the two-times derivation and

are expressible as a function of / and �.

10

= + ∙ sin �

= + ∙ � ∙ cos �

= − ∙ � ∙ sin � + ∙ � ∙ cos �

(2.3)

= + ∙ cos �

= − ∙ � ∙ sin �

= − ∙ � ∙ cos � − ∙ � ∙ sin �

Equation (2.3) inserted in (2.1) makes a differential equations with the geo-

metrical centre (

/ ) of the rotor and its first and second derivation

(

/ , / ). For a better comprehension of the differential equation the terms with

/ , / and / are brought on the left side of the equality sign and the equation is transposed so that the highest derivation (

/ is an own term.

+ ∙ + ∙ = − ∙ � ∙ cos � + ∙ � ∙ sin �

(2.4)

+ ∙ + ∙ = ∙ � ∙ sin � + ∙ � ∙ cos �

Equations (2.4) are inhomogeneous differential equations of second order.

The left side of the equality sign is the homogeneous part. The homogeneous part is the differential equation of a free, damped oscillation. The undamped natural frequency of those systems is

� (2.5).

� = √

(2.5)

The differential equation’s right side is the perturbation function which describes the excitement of the system caused by the imbalance. To predict the behaviour of a Laval Rotor the equivalent spring stiffness ( ) is needed. It depends on the geometry and material of the shaft and the kind of its bearing.

11

The equivalent spring stiffness is for small bending nearly constant and can be

approximated with equations (2.6). The influence of the kind of bearing ( ) is listed in Figure 4. describes

the Young’s modulus, the second moment of area and and are the radius and length of the shaft.

=

∙ ∙ with:

=

(2.6)

Pin-joints

=48

Fixed-joint

=192

Figure 4: Bearing's influence of the equivalent stiffness

The eccentricity ( ) can be calculated by the unbalanced mass ( ) and its position (

) according equation (2.7). Both parameters are known in the

case of the demonstration device, in which the imbalance is constructed.

Figure 5: Unbalance

12

= ∙

(2.7)

Due the appearance of

� and its second derivation in non-linear terms like

sine, cosine and quadratic functions in the equation (2.4) and (2.2) the solu-

tions of the differential equations are not trivial. Therefore the system is solved

in a numerical way, which is described in chapter 2.2.2.

2.2.2

Simulation

To solve the differential equations (2.2) and (2.4) the system is built in

Matlab/Simulink. Figure 6 shows the implementation of the equation (2.4). It

has the angle

� and its derivations as input signals. The eccentricity ( ), the damping coefficient ( ), the spring stiffness ( ) and the mass are constant values which are calculated outside the simulation. The model’s structure of the

part of equation (2.4) which contains

is similar to the described one.

Figure 6: Simulink model equation (2.4)

The torsional moment’s Simulink model is shown in Figure 7. There is the

torque ( ) the external control variable. The eccentricity ( ) and the inertia ( ) are constant values.

13

Figure 7: Simulink model equation (2.2)

Figure 8: Simulink model

Figure 8 contains the Simulink model which executes the correlations between

equations (2.4) and (2.2).

To analyse the system’s behaviour by constant rotations speeds and to deduce the transfer function it is viable to replace the mo-

ment’s equation (2.2) with a constant angular speed

� (Figure 9). The mo-

ment’s equation calculates out of the system’s state and the external torque the momentary angle (

�) respectively the angular speed (�) and its acceleration

(

�).

Figure 9: Simulink model constant angular speed

2.2.3

System behaviour

The transfer function (Figure 10) illustrates the vectorial sum of the

rotor’s displacement (

√ +

) plotted against the rotation speed by several damping ratios. The revolution speed (

�) is normalised to the system’s natural frequency (

� ) and the displacement to the eccentricity ( ). The transfer function shows that there is almost no displacement low angular speeds. Next to the natural frequency the displacement ascends depending, on the damping

14 ratio to very high values. An undamped system reaches at its natural frequency infinite deflexion. Because of the hazard of shaft fractures this angular speed is called the critical speed. At higher angular speed the displacement stabilised to the value of the eccentricity.

Figure 10: Transfer function Laval Rotor

The observation of the paths which the centre of the mass respectively the geo-

metrical centre of the shaft describe are shown in Figure 11. This paths are

called also called orbits. At lower rotation speed the radius of the mass centre orbit is bigger than the geometrical centre ones. By increasing the rotation speed this ratio turns. At higher speeds, the centre of mass approaches to a stable non-moving state and the centre of the shaft describes an orbit with the radius of the eccentricity.

Figure 11: Orbits centre of shaft and mass

15

2.2.4

Supporting

The kind of the bearing has basically two factors of influence on the bending vibration of the shaft. As opposed to the assumption made in the first model of the Laval Rotor the bearings are not totally rigid in the radial direction and also not totally non-rigid for bending. The stiffness of the supporting in the radial directions (y/z) can be seen as springs in a row to the equivalent springs of

the shaft (Figure 12).

Figure 12: Laval Rotor with non-rigid bearings

For an undamped system the result stiffness can be calculated with

equation (2.8). It is

assumed that the supporting’s stiffness is different in the y- and z- direction but symmetrically on both sides. This assumption reproduce very well the reality like it is in the demonstration device, where the same bearing supporting is used on both sides.

,

,

=

= ℎ ℎ ℎ ℎ

+

+

,

,

,

,

(2.8)

Due the different stiffness in the z- and y- direction the orbits of the shaft

’s geometrically centre and its centre of mass are an elliptical instead of circular.

Additionally to the position of the centre of mass and the geometrically centre of the shaft it is interesting to examine the displacement of the bearing. According the

Hooke’s law the deflexion is inversely proportional to the spring

16 stiffness. Referred to that the share of the displacement in the shaft and the

supporting depends on the ratio of the stiffness between those. Figure 13

shows exemplarily the bending of the shaft and the deflexion of its supporting.

In both cases are the totally stiffness the same so that the totally displacement of the rotor is also the same. In the upper case the equivalent stiffness of the shaft is much lower than the stiffness of the bearing. In the lower case both are similarly stiff.

Figure 13: Comparison stiffness ratio of shaft to supporting

Since the total system stiffness is lower with a less stiff supporting, the natural

frequency decreases (2.5). The influence of the stiffness in bending directions

is more difficult to determine. It is contained in the constant number ( ) in

equation (2.6). The totally rigid bending support (Fixed-joints) leads to a four-

time higher equivalent spring than the totally non-rigid bending support

(Pinned-joints). Depending on the actual bearings the stiffness is somewhere between. Self-aligning ball bearing for instance are nearly non-rigid in bending direction as against plain bearings are rather rigid.

2.2.5

Weaknesses of the model

The described model of the Laval-Rotor is just an approximation to an actual system. Depending on the actual system characteristics, the model has different weaknesses with different impact to the system’s accurateness. In this

17 chapter are the negligence of the gravity, the influence of the damping, the negligence of the shaft’s mass and the determination of the shaft’s stiffness discussed.

The negligence of the gravity is just in case of a completely balanced shaft exact. In this case the bending vibrations are added to the static, of the gravitation force caused bending of the shaft. Imbalanced, horizontal mounted shafts have according to Stodola (1918, 1-3) an additional critical speed. Is the rotor central on the shaft this critical speed is the half of the shafts first critical speed. The derivation of this new critical speed is with following concept possible (Stodola, 1918, 1-3). The view on the system should be from a with the shaft speed (

�) rotating co-ordinate system. Due the elastic vibration the shafts centre follows a circle with the velocity of the critical speed (

� ). The motion seen by the rotating system has the relative speed

� − �. The gravity impacts the centre of mass with the rotating force

∙ ∙ sin � respectively

∙ ∙ cos � which generate vibrations with the angular frequency (�). The gravity caused vibration and the natural vibration are in resonance if

� − � =

�. In this case is � = � / and the amplitudes of both vibrations can be added.

Another aspect which brings inexactness into the model is the assumption that the damping is a totally viscose. This assumption simplifies the mathematical model but reflects the reality not completely accurate. Furthermore even if the system is precisely described with a viscose damping the determination of the damping ratio is not easy. The most practical procedure to determinate the damping ratio is to measure the decay time of the actual system which is obviously not feasible when the system is still in development.

The most-reaching simplification of the system is probably the consideration of the shaft as massless. The accurateness of this simplification depends on the ratio between the rotor mass and the shaft mass. A continuous shafts has its own vibration behaviour. The determination of the influence of this vibrations should not be done here because it requires a highly more complex model than

18 the model of the Laval-Rotor is. For more exactly outcomes with consideration of the shafts mass and geometry it is recommendable to calculate the system with the finite element method.

As earlier discussed the kind of the supporting has a big influence of the stiffness of the shaft. And even if the correct equation for the equivalent stiffness is found it is valid for small bending magnitudes. For higher bending magnitudes the shaft gets stiffer. Moreover the model assumes a linear-elastic material behaviour which is just valid in certain limits.

2.3

System with two and more degrees of freedom

2.3.1

Introduction

Each multi-degree of freedom system with n degree of freedoms has n natural frequencies with the belonging n natural modes (Rao, 2010, 461). Due the continuous distribution of mass and rigidity on the shaft, the in the previous chapter introduced Laval-Rotor actually has an infinite number of natural frequencies. Basically this applies for all actual systems, but the influence of the higher natural frequencies is different in different systems. In this chapter a system similar to the Laval-Rotor but with two disks as well as a shaft without attached disks are discussed. Due the disks

’ slim shape orthogonal to the shaftaxis, they have a high mass at a marginal length on the shaft. The shaft is contrary to the disks relative lightweight by its comparatively high length. Therefore the disk mass’ influence on the rotor’s vibration behaviour is much higher than the shaft mass’. This is why systems with attached disks are more accurately describable with a lower number degrees of freedom then it is the case of a rotor without attached disks.

2.3.2

Natural frequencies and natural modes of a continuous shaft

According to Rao (2010, 527) the shape of a continuous beam’s respectively a

shaft’s nth natural mode is described with the formula (2.9). is the length of

the beam and the particular maximal deflexion. The determination of which is depending on the beam’s material, dimensions and damping is not

19 described in this thesis. The natural frequencies of continuous beams which

are pinned-supported are computed in equation (2.10) (Rao, 2010, 526). Figure 14 shows the three lowest mode shapes according formula (2.9).

= ∙ � ∙ ∙

� = ∙ √

(2.9)

(2.10)

Figure 14: Beam's three lowest mode shapes

2.3.3

Rotor with two attached disks

Basically the in the previous chapter 2.2 about the Laval- Rotor got findings

are also valid for the rotor with two masses (Figure 15). The mechanism of un-

balanced gained vibrations are the same in the system with two rotors. So it is also dangerous to run the rotor at rotation speeds which are nearby its natural frequencies. Compared to the Laval- Rotor, a Rotor with two disks has two natural frequencies which have to be considered. Both natural frequencies are important for the dimensioning of the demonstration device.

20

Figure 15: Rotor with two disks

To identify the natural frequencies the equation of motion has to be deter-

mined (2.11). The introduced system is undamped. Equation (2.11) is a differ-

ential equation written in matrix form with as mass matrix and as stiff-

ness matrix. Solving equation (2.12) gives the natural frequencies.

̅ ∙ + ̅ ∙ =

(2.11) det[̅ − � ̅] =

With:

(2.12)

̅ = [

] , ̅ = [ ]

− are so called factors of influence and are measuring units of the system’s stiffness relating to the disk’s positions. Technically they are the shaft’s deflexion on position w caused by a force (

F = N) applied on position v. To determine the factors of influence, the bending line

(Figure 16) caused by the

force

F is calculated. The correlation between the bending line and

is

=

=

and

= =

. Since the symmetrical structure of the rotor, the equations

=

and

=

are valid.

21

Figure 16: Bending line w(F,x)

The approach to calculate the bending is the Bernoulli beam theory (2.13).

∙ ∙ = − (2.13)

To determine

the beam is cut twice (Figure 17). At their cross section the equations of the moments (2.14) is formulated.

Figure 17: Force diagram at position I and II

��

� =

= ∙

= − ∙

(2.14)

22

The moment’s equations (2.14) inserted into the Bernoulli beam theory (2.13)

and two times integrated gives the equation of the bending line (2.15) with the

integration constants

, , and .

∙ ∙

∙ ∙

∙ ∙

= − ∙

= − ∙ ∙ +

= − ∙ ∙ + ∙ +

(2.15)

∙ ∙

∙ ∙

= ∙

= ∙ ∙

− ∙ ∙ ∙ +

∙ ∙ = ∙ ∙ − ∙ ∙ ∙ + ∙ +

There are four boundary conditions needed to determine the four integrations constants. Boundary conditions and result from the supporting at both ends of the shaft which do not allow displacements. Boundary conditions and

� are formed out of the fact that = / and = are the same point and therefore their displacement and their sloping are the same.

=

= / =

= / = =

= / = =

(2.16)

The four boundary conditions are an equations system with four unknowns.

Its solution is not shown here. The determined integrations constants inserted

in equation (2.15) gives the equation of the bending line (2.17).

23

∙ ∙ = − ∙ ∙ + ∙ ∙ ∙

(2.17)

∙ ∙ = ∙ − ∙ + ∙ +

Out of the bending line

’s equation (2.17) the factors of influence

, , and are determined with the above described conditions.

= = ( = , = ) = ∙ ∙ ∙

(2.18)

= = ( = , = ) = ∙ ∙ ∙

The in chapter 2.2.5 described weaknesses of the Laval-Rotor which are the

negligence of the gravity, the inadequacy of the damping model, the negligence of the shafts’ mass and the inexactness in the determination of the system’s stiffness are also valid for the rotor with two attached disks. Beside those there is a further influence factor. Due the bending of the shaft the rotors do not only move translational and rotatory around the x-axis but also in small angles

rotatory around the z-axis (Figure 18).

Figure 18: Rotatory motion of the disk

According the law of conservation of angular momentum or colloquially called the gyro effect the rotating disk pursues because of its inertia to stay in its actual state. For the described system, that means that depending on the inertia around the shaft axis and the rotating speed there arises a moment which is opposite directed to the slope of the shaft (

�). This moment acts against the

24 shafts deflexion and stabilize the system against the vibration. A numeral determination of this moment is not part of this thesis but should be considered by fast running systems with heavy hubs.

2.4

Torsional vibrations

Beside the in the previous chapters described motions and vibrations in translational directions a shaft also has a rotatory behaviour which should not be neglected. This chapter deals with the determination of the torsional vibrations of a shaft with two rotors.

Figure 19: Torsional system

Figure 20: Diagram of moments

The system shown in Figure 19 is a shaft with two attached masses and a ne-

glected inertia. Since both disks have generally different rotation angles, they

are cut free (Figure 20). On both disks act their respective moment of inertia

as well as the moment emerging by their torsion against each other. The oscil-

lating differential equations (2.19) are derived out of the principle of the mo-

ment equilibrium.

� +

� +

� − � =

� − � =

(2.19)

The oscillating differential equations (2.19) written in matrix-form makes the

equation (2.20). The natural frequencies are determined by solving the equation (2.21).

25

With:

̅ ∙ [�� ] + ̅ ∙ [

� ] = [ ]

̅ = [

] ; ̅ = [

] det[̅ − � ̅] =

(2.20)

(2.21)

The torsional rotating system responses analogue to the in chapter 2.2.3 de-

scribed behaviour of the Laval-Rotor on external oscillating excitations. If the excitation frequency is nearby a natural frequency of the rotating system, its torsional vibrations gets high amplitudes. A kind of excitement are like in the case of the Laval-Rotor, imbalanced caused forces.

Figure 21: Unbalanced caused force

Figure 21 shows the, by the off-centred mass caused force (

∙ ). This force causes with the on the rotors angular position (

�) depending lever arm a moment (

∙ ∙ ∙ cos �). Since generally both rotors are imbalanced, the oscil-

lating differential equations (2.19) changes to the non-linear differential equa-

tion (2.22).

̅ ∙ [�� ] + ̅ ∙ [

� ] = [ cos � cos � ]

With:

(2.22)

̅ = [

] ; ̅ = [

]

26

3

Development of the demonstration device

3.1

Introduction

Based on the in the previous chapters generated knowledge about bending vibrations a demonstration device is developed. The demonstration device should be used in the context of lectures and laboratory-works to visualize the imbalanced-caused bending vibrations and the possibilities to influence them by changing the system properties. This work contains all steps of the product development from the request to the finished designed and documented product. The process is split in four main stages: the planning-, the concept-, the drafting- and the elaboration-stage. The planning-stage contains mainly the elaboration of the list of requirements in agreement with the customer. The list of requirements consists all features which are required of the finished product. The scheduling is also part of the planning. It determines periods of time for the different development stages and also consists milestones to set specific project-events. Based on the list of requirement the concept is described. During the concept-phase an abstract working principle is developed.

It describes the particular functions of the system without specifying its technical realization. The technical realization is developed in the drafting-stage.

The overall design is executed and the system is divided in functional groups.

Additionally main attributes like functional-dominating dimensions or the speed-range are defined during the drafting-stage. The elaboration-stage is mainly the construction respectively designing of the particular parts and the producing of the technical drawings for manufacturing. A complete product documentation which contains an operational manual as well as an assembly guidance is done in the developing process. The manufacturing of the parts will be done in the JAMK’s mechanical workshop and is not part of this thesis work.

27

3.2

Features of the device

The list of requirements is elaborated together with Jorma Mattilainen and

Matti Kurki. The requirements are derived from the demand of the device as a lecture and laboratory-work supporting apparatus. It should be able to show unbalanced excited bending vibrations with amplitudes which are high enough to see with the naked eye. The systems arrangement should be changeable in the position and amount of the masses. It also should be able to influence the bending stiffness of the shaft. Since of the purpose of the device, it should be easily moveable and the operating should be fast, safety and easy.

3.3

Concept

The working concepts for the different rotor arrangements are directly derived out of the list of requirements. There are basically three different kinds of ar-

rangement which are shown in Figure 22. All of those modes are controlled by

a by the user predetermined revolution speed. The shaft with the rotor respectively rotors should be as good as possible uncoupled from the environment so

that the bending vibrations are as free and unaffected as possible. Figure 22 a)

shows the working mode with one imbalanced rotor between the two bearings.

The magnitude of the imbalance, the position of the rotor as well as the effec-

tive length of the shaft are adjustable. The second working mode (Figure 22

b)) has a second rotor with adjustable position and imbalance. The last mode

as shown in Figure 22 c) has a cantilevered adjustable rotor.

a) b)

28 c)

Figure 22: arrangement with a) one rotor b) two rotor c) cantilevered rotor

3.4

Drafting

The objective of the drafting is to gather, on the basic of the overall concept, the functionalities of the different parts and their main attributes. Therefore

the concept is separated into different functional groups (chapter 3.4.1). By

analysing the functional groups, the overall design of the different components is made.

The first step is the specification of the rotor’s dimensions (chapter

3.4.2) because they determine the dimensions of every other component. An

important part of the drafting is the development of the safety concept which

is made in chapter 3.4.6.

3.4.1

Functional groups

The device is divided into different functional groups which are under certain limitations independently designable. The first functional group is the oscillating system. It contains all parts which are directly involved in the bending vibration. The second functional group, the supporting includes all parts that are necessary to support the shaft and adjust the shaft’s effective length. In the functional group driveline are all parts integrated which are necessary to provide the torque for operating the system by a certain speed. The housing contains all the equipment needed to keep the systems parts in position, hold up the forces and torques and also the mechanism to avoid accidents by touching rotating parts.

29

Functional group: Oscillating system

 Shaft

 Rotor

 Unbalanced mass

 Mechanism for adjusting rotor’s position

Functional group: Supporting

 Bearings

 Bearing supporting

 Mechanism for adjusting bearing’s position

Functional group: Driveline

 Motor

 Controlling

 coupling – motor to shaft

Functional group: Housing

 Carrier, ground plate

 Vibration absorber system

 Safety equipment

3.4.2

Dimensioning rotor

Important attributes to get the desired natural frequencies of the rotor, are beside the shaft’s length, diameter and its modulus of elasticity the disk’s mass and the bearing type. The calculations are based on the in the theoretical part gathered formulas. The dimensioning process is described below.

1.

Determine maximal rotating speed depending on the maximal motor speed and safety issues.

� = /min

30

2.

Determine second natural frequency lower then maximal rotating speed.

� ≪ � → � = /min

3.

Determine material (young’s modulus) and bearing type.

Young’s modulus: 200 GPa (Steel)

Bearing types: self-aligning ball bearings (non-rigid bending support)

4.

Choose shaft length, diameter and disk mass. Therefore curves with a constant second natural frequency and modulus of elasticity are plotted

(Figure 23).

Figure 23: Curves of constant masses and frequency

In Table 1 the in agreement with the thesis supervisor chosen attributes and

the expected natural frequencies are listed.

31

Mass Length Diameter f

1

1 kg 0,6 m 9,982 mm

-> 10 mm

1030 1/min f

2

2007 1/min f

Laval

1410 1/min

Table 1: Rotor dimensions

Determination unbalanced mass

The unbalanced mass and its lever arm causes the excitement of the vibrations. For the above given shaft dimensions, the maximum displacement at its

first natural frequency of a Laval-Rotor is shown in Figure 24. The displace-

ment is plotted against the unbalanced mass by a constant lever arm of 0,1 m.

The displacement depends also on the damping ratio. Since the damping ratio is not accurately definable, it is practicable to choose the unbalanced mass experimentally on the finished demonstration device.

Figure 24: max. rotor displacement according unbalanced mass and damping ratio

32

3.4.3

Supporting

Derived from the concept, the supporting has to execute different tasks respectively it has to meet different properties. First it has to support the bearings forces properly.

Part of this is to isolate the shaft’s vibrations from the device’s housing. This isolation is on the one hand necessary to avoid an oscillating of the device’s housing and on the other hand to keep the shaft’s vibration as free from external influences as possible. The supporting also has to provide the possibility to change the effective shaft length by varying the bearing distance.

Summarized, the supporting has three different main tasks: supporting the bearing, isolating the vibrations and adjusting the length. Since this three tasks demand quite different properties of the supporting, they are designed separately.

Bearings supporting

The supporting has to hold the static load of the rotor which is caused by the gravitation and the forces which are caused by the oscillating of the rotor. It also has to determine the shaft’s axial position. Basically there are two different main solutions to support the bearing. Either to use standardized bearing housings or to design and manufacture custom housings. This decision is

made with the following decision matrix (Table 2) and in dialog with the pro-

jects supervisors. The criteria which are used for the decision are:

-

Overall dimensions:

Since the standardized housings for bearings are designed for about the maximum bearing load, they have presumably way bigger overall dimensions than special for the demonstration devices designed ones.

-

Weight:

Because of the same reason as for the overall dimensions, the weight of a custom housing will be presumably way lower than a standardized housing.

33

-

Costs:

Compared to the purchase price of standardized housings, the manufacturing which includes material costs, machining costs and working times is most probably more expensive.

Dimensions

Weight

Costs

Sum

Factor Standardized housing

5 rating

2

1) weighted

10

2

4

2

5

4

20

34

Custom housing rating

5

5

1 weighted

25

10

4

39

1)

1 - very poor; 5

–very good

Table 2: Decision matrix supporting

According the decision matrix a custom manufactured housing is the more matching solution.

Adjusting of the effective length

To adjust the shaft’s effective length at least one of both bearings has to be moveable. Since the shaft’s axial positions has also to be fixed by the supporting and it is difficult feasible to have an adjustable bearing which also should fix the shaft’s axial position, it is practicable to separate those two tasks onto both bearings. This is realized by setting the motor-sided bearing as static and the other one as shiftable. The static, motor-sided b earing has to fix the shaft’s axial position. This layout of the supporting is a so called locating and non-lo-

cating bearing arrangement (Figure 25).

34

Figure 25: Bearing arrangement

There are several different possibilities to realize the shifting and fixing of the

adjustable bearing. There are three basically different solutions gathered. Figure 26 a) shows the first solution. It is based on the mechanism like it is used

to move the slide of a milling-machine or a bench vice. It has a turnable-supported threaded bar which is as long as the adjusting range of the bearing should be. The threaded bar is on one side axially fixed and has on the other side a handle. The bearing supporting is located on a slide which is routed on two guide rails. The slide-supporting unit has an inside thread in which is the threaded bar stuck. Thereby the slide moves by turning the threaded bar. On

Figure 26 b) and c) are the second solution for shifting and fixing the bearing

shown. They consist out of four different main units. A slide-supporting unit, guide rails, a clamping plate and clamping screws. The slide is axially free supported on the guide rails and clamped with the clamping plate and screws against them. The slide-supporting unit is manually shiftable into the desired

position after loosening the clamping screws. The third solution (Figure 26 d))

acts similarly to the previous one. The clamping is performed by screws which push against the upper face of the rail. The slide and the rail are shaped in a way that they are clamped to each other by tightening the screws.

35 a) c) b) d)

Figure 26: Design proposals bearing shifting

The selecting of the adjusting and fixing principle is executed by using a decision matrix. Therefore the solutions are evaluated by the following criteria:

-

Usability

Since the solution a) just requires a turning of the threaded bar to adjust the bearing’s positions, it is quite easy to use. Especially the finetuning is comfortable but a larger changing takes a quite long time. The usage of the solution b)/c) and d) are similar. They require a loosening and tightening of the screws for the positioning of the bearing. A larger changing of the positioning is compared to solution a) much faster.

-

Costs

The manufacturing of solution a) is pretty extensive. Especially the threaded bar and its supporting is expensive. Since the rails of solution d) have a complex shape, they are not realizable with standard profiles but have to be manufactured out of solid profiles which leads to higher

36 costs. For the rails of solution b)/c) can be standardized profiles used.

The solution b)/c) has, compared to solution d) an additional part.

-

Dimensions and weight

The solutions b)/c) and d) have comparable dimensions and weights.

Since of the threaded bar and its supporting, the solution a) is heavier and needs additional space.

-

Clamping capability

Since of the threaded bar’s self-locking, it has a good clamping capability. The solution d) has a between the screws and the rails just a small contact surface a therefore a lower axial fixation.

The solution’s a) and d) fixation in the plane vertically to the shaft is because of the rail

’s shape very strong. The clamping of solution b)/c) has to be supplied by its screws initial tension and has therefor a lower clamping capability.

Usability

Costs

Dimensions and weight

Clamping capability

Sum

Factor

4

5

3

2 r 1)

3

2

2

5 a) w 2)

12

10

6

10

Solution r

4

5

5

3 b)/c) w

16

25

15

6 r

4

4

5

4 d) w

16

20

15

8

38 62 59

1)

rating: 1 - very poor; 5

–very good;

2)

weighted rating

Table 3: Decision matrix bearing adjusting

37

According the decision matrix the solutions b) and c) are the concepts with the highest potential. Since the solution b) has because of its triangular rail a selfaligning while clamping, it is used as concept for the further elaboration.

Vibration isolation

Since the bearing housing has to be stiff enough to support the bearings outer ring, it has nearly no damping capability. To provide the necessary damping capability the supporting’s clamping unit should be quite solid and out of a material with a high internal damping.

3.4.4

Shaft hub joint

According the concept the disks have to be shift- and removable attached onto the shaft. Since there appears between the disk and the shaft only the torque which results of the disk’s inertness, the holding force does not affect the choosing of the shaft hub joint much. Beside the fulfilment of its main tasks, the shaft hub joint has to satisfy different demands. It should be fast to strain and loose, around the shaft axis balanced and as low priced as possible. Since the connection has to be re-adjustable, it should to be friction-locked. There

are several different principles for the shaft hub connection. Proposal a) (Figure 27 a)) is to separate the disk into two part which are clamped with stretch-

ing screws and an interference fit onto the shaft. The manufacturing of this solution is complicated because the accurateness of the fit is difficult to achieve on the open hole. Since the point symmetrical shape, the solution a) is bal-

anced. Its loosing and straining is quite fast. Figure 27 b) shows the second

proposal for the shaft hub connection. It is a screw-strained cone clamping connection. It has on one or both sides of the hub a loose element with a conical plane which clamps due tightening against a further conical plane on the inner-side of the hub. This kind of shaft hub joint is as standardized part available and has therefore low manufacturing costs. Since this shaft hub joint has several screws to strain, it is more time-intensive to adjust the position of the

disks than by systems with fewer screws. The last (Figure 27 b)) solution which

is taken into account is also a cone clamping connection and has basically the

38 same working principle like the previous one. Instead of multiple screws which strains the conical faces against each other it has just a single nut. This brings the advantage of a fast adjusting of the disk by just loosing and straining one nut. This kind of element is also available as standard purchasing part and also needs no additional machining. a) b) c)

(Ringspann GmbH, 2014)

Figure 27: Design proposals shaft hub connection

The selection of the used system is made with a decision matrix. Evaluated are the properties:

-

Costs

Considered are the purchasing costs as well as the manufacturing costs.

39

-

Ease of use

The ease of use is mostly depending on the time which is needed for adjusting the time. Solution a) has compared to the other solutions the advantage that the rotor is completely attach- and removable at any position of the shaft. The other solutions has to be putted on the end of the shaft.

Costs

Ease of use

Sum

1

1

Factor r 1)

2

3 a) w 2)

2

3

Solution b) r

4

2 w

4

2 r

4

4 d) w

4

4

5 6 4

1) rating: 1 - very poor; 5

–very good;

2) weighted rating

Table 4: Decision matrix shaft hub joint

According the decision matrix the cone clamping element which is strained with a single nut is the best solution. The in the device used clamping element is the Ringpspann Trantorque Mini. It is available for shaft dimension between 3 mm and 16 mm and supports a maximum transmissible torque of 68

Nm which is way more than needed. Its outer diameter of the clamping element is 23 mm and the seat length for the hub is 13 mm. This dimensions has to be considered by designing the disk.

Figure 28: Ringspann Trontorque Mini (Ringspann GmbH, 2014)

40

3.4.5

Housing

The housing’s main function is to keep all the different parts like the motor, the bearing supporting and the safety-cap in position and provide them a sufficient supporting as well as the needed space to execute their functions. The housing has to be stiff enough to keep in shape while carrying but also resistant against stimulation of the shaft’s vibration. It should be easy to transport and therefore lightweight. Since an usage of standard parts is mostly more cost-effective than the manufacturing of custom-parts, they are preferred. The ease of assembling should also be considered. The first developed

concept (Figure 29 a)) for the housing consists of a base frame assembled out

of standard aluminium profiles and a plastic cover plate where the different

units are mounted on. At Matti Kurkis suggestion a concept (Figure 29 b))

with a massive base plate out of plastic is considered, too. The different parts are mounted directly onto the base plate. a) b)

Figure 29: Design proposals housing

The choosing of the housing concept is executed by using a decision matrix.

Therefore the solutions are evaluated by the following criteria:

41

-

Costs

The costs of proposal a) are mostly determined by the material costs of the standard profiles and their connecting elements. A roughly estimated price by using parts of the company Item is about 270 € (item

Industrietechnik GmbH, 2015). A massive 50 mm PA6 plate is for comparable dimensions about 320

€. Additionally to the higher material costs the machining of proposal b) is more extensive.

-

Weight

The estimated weight of the aluminium frame and the cover plate (proposal a)) is about 14 kg. The weight of a comparable PA6 plate is about

22 kg (B & T Metall- und Kunststoffhandel GmbH, 2015).

-

Stiffness and damping capability

The damping capability of proposal a) is probably for the same stiffness, compared to all in proposal b) applicable plastics much lower.

Costs

Weight

Stiffness and damping

Sum

Factor

3

2

4 a) Al-Profiles r 1) w 2)

4 16

4

3

12

6

Solution b) Solid plate r w

3

3

5

12

9

10

34 31

1) rating: 1 - very poor; 5

–very good;

2) weighted rating

Table 5: Decision matrix housing

According the decision matrix the aluminium-frame solution is the better concept for the requirements and serves as draft for the further development.

42

3.4.6

Safety concept

The elaborated safety concept is based on the approach of risk assessment like it is described in ISO- Norm 12100 (Mattilainen, 2015). Therefore, the possible hazards are identified. For this purpose, all tasks which are proceed by using the device have to be considered. After the identification, the risks of the hazards are evaluated. Depending on the risks their countermeasures are elaborated.

Identified hazards

-

Turning parts

The fast turning shaft during the operation involves the risk of injuries if a part of the body comes into contact with it. Also clothes or other fabrics can be dangerous if they winding up on the turning shaft.

-

Unintentional restart

An unintentional start of the device during the adjusting, cleaning and maintaining can lead to a physically contact with fast turning parts.

-

High shaft deflexions

If the device is operated next to the shaft’s critical speed, the deflexion of it can be improper high. This can cause a fracture of the shaft or other components.

-

Loosening of imbalance-screw

If a screw which are attached onto the rotating disk for apply an imbalance get loose while operating, it can become a dangerously projectile.

43

Risk evaluation

The evaluation of the risk is done by rating the severity of the harm and the probability of its occurrence. The severity of the harm is grouped into the categories slight (normal reversible) injury or health hazards, serious (normal irreversible) injury o r health hazards and death. The probability of the harm’s occurrence is evaluated by the user’s expose to the hazard, the probability of occurrence of a hazardous event and the possibility to avoid or limit the harm

(Mattilainen, 2015).

Severity of harm

PROBABIL-

ITY OF OC-

CURRENCE

OF HARM

A

B

C

Person’s exposure to hazard

Probability of occurrence of a hazardous event

1) slight injury or health hazards

2) serious injury or health hazards

3) death

1) seldom … quite often

2) regularly … constantly

1) low

2) average

3) high

D

Possibility to limit the harm

1) possible under certain conditions

2) seldom possible

Table 6: Harm evaluation categories (Mattilainen, 2015)

After evaluating each hazard according Table 6 the Level of risk can be read

out of Table 7. The higher the number the more dangerous is the rated hazard.

The result of the risk level affects the priority of the countermeasure.

44

A B

1) 1)

1)

2)

2)

1)

3)

2)

1*

3

5

7

9

1)

1)

D

2

4

6

8

10

2)

3

5

7

9

11

1)

C

2) 3)

4

6

8

10

5

7

9

11

6

8

10

12

12

2)

13

1)

14

2)

D D

*1… very safe – 14… highly unsafe

Table 7: Levels of risk (Mattilainen, 2015)

Table 8 shows the evaluated criteria and the out of Table 7 derived risk level of

the identified hazards. According this the hazard of turning parts and the loosening of an imbalance-screw involve the highest danger. But every other single hazard is also not to neglect and it also has to be a countermeasure developed against them.

Hazards

A) Severity of harm

B)

Person’s exposure to hazard

Turning parts

Unintentional restart

2

2

2

1

High shaft deflexions

2 1

Loosening of screw

3 2

Table 8: Risks of the identified hazards

C) Probability of occurrence

3

D) Possibility to limit the harm

1

Level of risk

9

2

2

1

1

1

1

5

5

9

45

Countermeasures

To avoid the danger of an accidently grabbing into turning parts or other contact with it, a safety-cap is practicable. The safety-cap has to be transparent to not restrict the purpose of the device. It also has to be removable or has to be able to open to adjust the arrangement of the system. This safety-cap also serves as a barrier for loosening part of the rotor.

To prevent an unintentional restart while working on the device a safety circuit, which cuts of the current if the safety-cap is open, is needed. Therefore a switch is required which cannot be accidently pressed. Since the electrical work is not part of this thesis, this countermeasure has to be considered by the person which does the wiring of the motor.

To ensure that there are no improper high shaft deflexions the maximum deflexion of the shaft has to be limited. Therefore a safety bearing is used. It restricts the shaft deflexion as a mechanical barrier.

3.4.7

Safety bearing

In chapter 3.4.6, the safety bearing as a countermeasure against too high shaft

deflexions is introduced. It restricts the deflexion to a maximal amplitude of 5

mm (Figure 30 a)). If the shaft deflexion reaches 5 mm the rotor collides with

the safety bearing and stops the swinging up. The safety bearing has to be out of a plastic material which does not damage the rotor while touching. The safety bearing has beside the restriction of the shaft deflexion a second purpose. It serves as an additional supporting if the shiftable bearing is removed.

Therefore the rotor has an additional shoulder with the same diameter as the inner diameter of the safety bearing. The shaft can be supported due sliding

the safety bearing onto the rotors shoulder (Figure 30 b)). The adjustment of

the safety bearing position is similar to the of the supporting.

46 a) b)

Figure 30: Safety bearing concept

3.5

Elaboration

3.5.1

Introduction

Chapter 3.5 deals with the elaboration of the in the drafting specified concepts.

In the elaboration are the custom components designed and standard parts selected. Part of the elaboration are also the material selection of the custom parts and, if required, their strength calculation. The order of the subchapters are in accord with the order the elaboration process is made. Basically the elaboration is made “from inside to outside”. This means that firstly the bearing is selected. The dimensions of the bearing sets the dimension of the support which affects the housing and the safety-cap. Obviously, this process cannot be made completely sequential since sometimes loops are necessary. Part of the results of the elaboration process are the manufacturing and assembly drawings which can be found in the attachment.

47

3.5.2

Bearing choosing

Since the dimension of the bearings determines the design of the complete supporting, it is chosen at the beginning of the elaboration process. The bearings has to fulfil different requirements in its application at the demonstration device. The most apparently requirements are to hold the forces which are transferred from the shaft and enable the shafts almost torque free rotation.

Beside these, the bearing should be as non-rigid as possible against angular-

displacements in the shafts direction (Figure 31). This allows the shaft a nearly

free bending without high restraints caused by the supporting. The bearings should also be almost maintenance-free and should have a life-cycle which is at least as long as the demonstration device is in business.

Figure 31: non-rigid bearing axis

Because of the requirement of the bearing as mostly non-rigid against turning in the shaft direction, the selection of possible bearing-types is limited. Every type of plain bearing restricts this angular movement too much. The for this angular displacement most non-rigid rolling-element bearings are the so

called self-aligning ball bearings (Figure 32). Self-aligning ball bearings are

bearings with two ball rows, which are running in two grooves on the inner ring. The contact surface on the outer ring is spherically shaped and allows the

balls to move some degrees around the bearing centre (Figure 32b)). Typically,

self-aligning ball bearings allow an angular displacement of about 4 to 7 degrees (NSK Ltd., 2015).

48

Figure 32: self-aligning ball bearing

The maximal load is the decisive parameter for choosing a suitable bearing.

The radial load is a combination of the static gravity force and the rotary force.

During a proper operating of the demonstration device there does not occur noteworthy axial forces. The rotary forces are centrifugal forces which results from the rotation of the disks with a particular displacement at a particular an-

gular speed. Figure 33 shows the force diagram with the gravity force and the

centrifugal force marked.

Figure 33: Force diagram disk

The maximal centrifugal forces occur at the second natural frequency of the system, with both disks attached and their maximal allowable displacement of

5 mm (3.1).

49 with:

,

,

,

= ~ ∙

� = ≈

=

=

= ∙

= �

≈ ∙ ∙ ∙

,

,

≈ ≈

≈ ∙ , ≈ N

, �

≈ =

(3.1)

The determination of the required dynamic ( ) and static ( ) basic load ratings are done according the Roloff/Matek guideline (Wittel, Muhs, Jannasch,

& Voßiek, 2013, 506) in (3.2). The used parameters are listed in Table 9. All

parameters are selected either out of Roloff/Matek or, if not named, calculated in this thesis.

Symbol Parameter

P p n

L

1oh

P

0

S

0

Dynamic load

Life-time exponent 3

Rotating speed

Desired life-time

Static load

Static safety factor

Value

0,22 kN

2000 min

2ooo h

0,01 kN

1,5

Table 9: Parameter bearing calculation

-1

Source

-

Roloff/Matek 14.2.6

-

Roloff/Matek TB 14-7

-

Roloff/Matek 14.2.6

50

≥ √

6 ℎ

≥ , √

,

,

6 / i

6

= , kN

≥ P ∙ S

≥ , ∙ , = , kN

(3.2)

The, by the leading ball bearing manufacturers SKF and NSK offered selfaligning ball bearings with the lowest load ratings and an inner diameter of 10

mm are listed in Table 10.

Manufacturer

SKF

NSK

Type

1200 ETN9

1200

Table 10: Bearing load ratings

C

5,53 kN

5,55 kN

C

0

1,18 kN

1,19 kN

The actual dynamic ( ) and static ( ) basic load ratings of the bearings are way higher than the required basic load rating ( ,

,

) and are therefore not in danger to be destroyed by the load. The bearing life-time and the minimum load of the bearing is also calculated with the SKF Bearing Calculator which is available on www.skf.com. The SKF Bearing Calculator attests a lifetime (L

1oh

) of 132400 hours which exceeds the desired life-time multiple. To ensure an operation without slippage a minimum radial load is needed. Especially at high angular accelerations and at high revolution speeds ball bearings tent to slip what could cause damages of the bearings. The risk of slipping increases with the viscosity of the lubricant. To keep the risk of slipping down the demonstration device should not be operated at high revolution speeds if there is no disk attached. A fast raise of the motor should also be avoid.

51

3.5.3

Supporting design

The supporting is separated into two main units: the bearing housing and the clamping unit. The bearing housing is a milled aluminium part. It has to support the bearing with an appropriate fit. The clamping unit consists of two plastic plates which are strained by four screws and nuts on a guidance. The upper plate has a milled pocket where the housing is bolted into. The guidance are two triangular Item aluminium profiles and two aluminium L-profiles which are mounted onto the baseplate.

Figure 34: Supporting

Selection of fit

Since of the imbalanced excited force, the load on the bearing rotating inner

ring is a point loading (Figure 35). The stationary outer ring has a circumfer-

ential load. The bearing manufacturer recommend for this type of load a transition fit at the outer ring and clearance fit at the inner ring (Haberhauer & Bodenstein, 2014, 134). The specific load is low (P / C = 0,22 kN / 5,53 kN=

0,04) and therefore the more loose recommended fits allowed. The used bore

tolerance is K7 and the shaft tolerance is g6 (Figure 36).

52

Figure 35: Bearing loading Figure 36: Fittings bearing

For a forceless joining of the bearing housing and the bearing, the housing has to be heated. Since of the thermal expansion the inner diameter of the housing increases depending on its temperature. The required joining temperature

( ℎ �

) of the housing is calculated in formula (3.3) (Haberhauer & Boden-

stein 2014, 134). with: ℎ � ℎ � ℎ �

= +

= ° +

+ Δ

, + ,

,

−6 −

·

= , °

DΔ = , (join clearance)

= ° (ambient temperature)

= ,

mm (maximum clearance)

� = ,

−6 −

(thermal expansion)

=

(nominal Diameter)

(3.3)

Material selection of the plastic parts

The material for the clamping unit has to fulfil different requirements. Firstly, it has to be good to machine. It also has to have a sufficient mechanical

53 strength and good damping properties. In the group of the established structure plastics Polyamide 6 (PA6) and Polyacetal (POM) meets this properties best. PA6 has a slightly higher mechanical strength and also a higher ductility as well as better damping characteristics and suits therefore better for the application.

Properties

Density

Modulus of elasticity

Tensile strength

Elongation at break

PA6

1.14 g/cm

3300 MPa

79 MPa

130 %

3

Damping characteristics Very good

Table 11: Properties PA6 and POM-C

POM-C

1,41 g/cm 3

2800 MPa

67 MPa

32 % good

(Ensinger GmbH, 2015)

Stress analyses bearing housing

The stress which acts in the bearing housing is a combination of the static stress resulting of the shrink fit between the bearing and the housing and the dynamic, rotating load. The stress analyses is made with the finite element tool of CATIA V5. The following calculations have the purpose to get a rough scale of the stress in the housing. If the stress is in a critical range the analyses has to be done more precisely. To calculate the stress, the load of the fit and the dynamic load are needed. As dynamic load the number which is calculated

for the bearing dimensioning is used (3.1). For a rough calculation of the pres-

sure in the shrink fit, the bearing is assumed as a solid part. This assumption reduces the shrinkage of the bearing and increases the result of the calculation and is therefore uncritical. The bearing housing is assumed as a hub with an outer diameter appropriate the upper part of the housing ( ). The maximal possible pressure results of the highest interference ( ℎ

), the bearing’s and housing’s elasticity (

; ), Poisson’s ratio (�

; � ) and the housing’s geometry.

54

� =

� =

� = ℎ

, ∙ /

∙ ,

, ∙ /

∙ ,

� = , /

(3.4) with:

= − �

=

=

/

/

=

+

+

+ �

− , +

= ,

+ ,

− , + ,

= ,

The fixation which are simulated in the finite element analyses are not like in the actual case made with bolts and surface contacts. The bolts are neglected and the fixation is realised with three so called surface slider on the bearing

housings base (Figure 38). Surface slider lock the displacement vertically to

the restrict surface. This simplification does affect the result of the finite element result just insignificantly, as the critical locations are in the upper part of the housing. The load of the shrinkage fit is simulated as a surface pressure on the contact face to the bearing. This loading type conforms to the actual loading precisely. The equivalent stress (Von Mises stress) resulting from the shrinkage fit has a local maximum of about 50 MPa at the flange of the bearing contact surface. This enhancement of the stress evolves from the notching effect on this position. This maximum stress is uncritical because it is far lower than the tensile strength of every aluminium alloy. If commercially available pure aluminium (tensile strength: ~90 MPa, yield strength: ~35 MPa) is used, local non-critically plasticity can occur. The stress caused by the dynamic load is computed statically in different directions. In that way the maximal stress of the rotating load can be found. The maximum Von Mises stress is about 4 MPa

55 and therefore negligible. Since of the low dynamic stress, a fatigue strength calculation is not made.

Figure 37: Stress due to shrinkage fit Figure 38: Stress due to dynamic loading

3.5.4

Rotor design

The rotor’s purpose is to be the “mass” in the mass-spring system. Beside this it has to provide the possibility to attach the imbalance. The major property of

the rotor is its weight which is determined in chapter 3.4.2. It is clamped with

the in chapter 3.4.4 selected shaft hub joint on the shaft. Therefore it needs a

suitable fit. Additionally the rotor has a shoulder that limits together with the safety bearing the maximal shaft deflexion. This function is described in chap-

ter 3.5.5. The rotor is divided into two parts. The outer rotor (Figure 39) which is a disk with a constant thickness and the inner rotor (Figure 40) that has the

shoulder for the safety bearing, the fit for the shaft hub joint and a fit for the outer rotor. The separation into two parts saves a lot of material and machining cost as the outer part can be made out of a sheet with a way lower thickness than the inner part needs. The outer rotor has threaded holes where bolts can be mounted, to apply the desired imbalance. The holes are on four different diameter, so that is it possible to adjust four different magnitudes of imbalance with one bolt. A combination of several bolts increases the possible

56 steps of the im balance’s magnitude. Since the rotors are in touch with skin while adjusting their position, they are exposed to sweat. To avoid rusting, the rotors material is stainless steel. Since there are no highly requirements on the material strength, the used stainless steel can be chosen by its cost and availability. Because of its cheap price, the well-established stainless steel V2A steel

(x5CrNi18-10) is selected.

Figure 39: Inner rotor

Figure 40: Outer rotor

Fit calculation

The connection between the outer and the inner rotor is made with an interference fit. The calculation are made according Roloff / Matek (Wittel, Muhs,

Jannasch, & Voßiek, 2013, 389

– 395). The maximum requried transferable torque is the torque which is needed to tight the shaft hub joint (

=

).

Symbol Parameter

� coefficient of adhesion

Adhesion safety factor

Value

0,19

1,5

Yielding safety factor 1,2

Roughness inner rotor

25

Source

Roloff/Matek TB 12-6 (steel

– steel)

Roloff/Matek 12.3.1 (static loading)

Roloff/Matek 12.3.1 (ductile material)

Roloff/Matek TB 2-12 (milled surface)

57

,

Roughness outer rotor

Yield strength inner rotor

25

Roloff/Matek TB 2-12 (milled surface)

190 MPa V2A

(x5CrNi18-10)

Modulus of elasticity 200 GPa V2A

Diameter of fit

Outer diameter outer

�� rotor

Inner diameter inner

� rotor

Length of fit

Table 12: Parameter for fit selection

35 mm

114 mm

23 mm

11 mm

(x5CrNi18-10)

Drawing 2

Drawing 2

Drawing 3

Drawing 2

First the lowest required joint compression is calculated (

� ) (3.5). It results of

the fit’s surface ( �

) and diameter (

), the coefficient of adhesion (

�) and the required transferable torque ( ).

� =

∙ � =

∙ ,

∙ ,

With:

=

/ =

= ∙

, ∙

=

= ∙ ∙

= , /

=

(3.5)

With the lowest required joint compression, the lowest required allowance of

interference can ( ) be calculated (3.6). The grading ( ) of the fit surface

caused by the compression is also considered.

58

=

� ∙

∙ + =

, ∙

∙ , + � = �

With:

=

=

=

= , ∙

+

��

=

+

=

+

+

=

= ,

+ ,

− ,

= ,

= , ∙

+

+ ,

− ,

� + � =

= ,

(3.6)

The highest allowed joint compression (

� ℎ

) is determined by the strength of

the used material of the inner and outer rotor and is calculated in (3.7). The

highest allowed joint compression sets the highest allowed interference ( ℎ

)

(3.8).

� ℎ ℎ�

=

=

,

,

� ℎ�

< � ℎ

=

,

− ,

=

,

− ,

⇒ � ℎ

= � ℎ�

= /

=

=

/

/

(3.7) ℎ

=

� ℎ

∙ + =

∙ , + � = �

(3.8)

The difference of the highest and lowest allowed allowance of interference determines the possible dimension variation ( ) of the fit. The dimension variation is separated into the tolerance of the inner and outer diameter (

, ). The tolerances are chosen according the ISO- tolerance table (ISO 286). Because of machining reasons a hole basic fit is chosen.

59

= ℎ

− = � − � = �

⇒inner dimension:

H6 (EI=0 µm; ES=16 µm)

⇒outer dimension:

� = + = µm + µm = µm

= + ℎ

= + µm = µm u6 (ei=60 µm; eo=76 µm)

(3.9)

To join the parts forceless, the inner rotor has to be cooled down or the outer rotor heated up. The calculation of the required temperature difference is mad

in (3.10) (Haberhauer & Bodenstein, 2014).

Δ

=

Δ

=

+ Δ

, + ,

, ∙ −6 − · =

°

(3.10) with:

DΔ = ,

mm (join clearance)

= ,

mm (maximum clearance)

� = , ∙

−6 −

thermal expansion)

=

(nominal Diameter)

3.5.5

Safety bearing design

The safety bearing consists out of the bearing itself, a strain plate, two metal plates and a countersunk bolt. Since the safety bearing does not have to support high loads it is strained with just one bolt. To hold the strain plate while straining the bolt, it has two shoulders which are in contact to the ground plate. The metal part which is inserted into the strain plate is threaded and transmits the bolts stress into the strain plate. The material requirements for the bearing and the strain plate are similar to them for the supporting’s plastic

60

parts. Therefore the in chapter 3.5.3 selected material is also used for the

safety bearing.

Figure 41: Safety bearing

3.5.6

Shaft design

The main properties of the shaft are determined in chapter 3.4.2. Its diameter

is 10 mm and the maximal effective length which means the distance between the bearings is about 600 mm.

The shaft’s material is in drafting defined as a steel material. To adjust or remove the supporting, safety bearing and the rotor, the shaft has to have a constant diameter on his complete length. This is also necessary to meet the theoretical assumptions which are made for trans-

forming the shaft into an equivalent spring (chapter 2.2.1). The axial fixation

of the shaft is done in the motor-sided supporting. Therefore the bearing is fixed with a retaining ring on the shaft.

Coupling

The shaft is driven by the electric motor. The electric motor is already at hand and therefore the shaft has to be adapted to the given dimensions. The connection between the shaft and the motor should be as non-rigid against bending

61 as possible to get a free bending of the shaft. Beside this, the connection should isolate vibrations and rotation oscillating. A shaft coupling with a rubber element is practicable and common to satisfy this requirements. Since the required transferable torque is quite low, it plays just a minor role for the selecting of the coupling. There are lot of different supplier which offer very similar solutions. The chosen coupling are the ROTEX torsionally flexible cou-

pling of the company KTR (Figure 42, Table 13).

Figure 42: ROTEX coupling (KTR Kupplungstechnik GmbH , 2015)

Property

Maximal angular displacement

Maximal radial displacement

Nominal torque

Value

0,9°

0,85 mm

10 Nm

Shaft hub joint Key connection

(KTR Kupplungstechnik GmbH , 2015)

Table 13: Main properties ROTEX coupling

The coupling is non-rigid against bending until an angle of 0,9 °. To check if the coupling is non-rigid for the complete displacement of the rotor the bending line of the shaft is as parabolic approximated. For an exemplary calcula-

tion (3.11), the distance between the bearings is 600 mm and the maximal allowed rotor displacement is centric of the shaft (Figure 43).

62

Figure 43: Bending line

The shaft bending angles which are at the bearing’s position are about the same like at the coupling. For a free bending the bending angle at the bearing is 1,9 °. According this the stiffness of the system will increase for higher shaft deflexion than 0,9 °.

=

=

= ∙ +

= ∙ −

α = arctan(

= /

) = arctan ( ) = , °

(3.11)

With:

= −

=

⇒ = −

⇒ = /

63

Figure 44: Shaft connection

Since the diameters of the shaft and the motor’s output shaft are different, an

adapter needed (Figure 44). This adapter is connected with a key to the RO-

TEX coupling. The connection between the adapter and the shaft is made with a glued joint. A glue joint is the favourable connection because it does not require an additional machining of the shaft. An interference fit is not used because it would either require a second diameter of the shaft or the hole of the adapter cannot made according the hole basic system (H). Usual industrial metal glues can hold high shear forces up to 25 N/mm². A suitable glue is the

Loctite 638. For this glue connection the maximal transferable torque is about

100 Nm. The used fit between the adapter and the shaft is a H7/g6. This fit is a clearance fit with a clearance of 5 to 29 µm which features an optimal bonded joint and a force-less mounting.

Property

Maximal shear forces

Maximal gap

Curing time (hand-tight)

Table 14: Properties Loctite 638

Value

> 25 N/mm²

250 µm

4 min

(Henkel AG, 2015)

64

Strength calculation

The strain in the shaft is caused by two different effects. The bending of the shaft and the contact pressure of the Ringspann shaft hub joint. The tension caused by the bending is oscillating and the contact pressure static. Since there is an oscillating load, the shaft is verified on fatigue strength. The calculations are made by hand with supporting by finite elements methods. For the calculation the rotor is centric assumed. In this case the highest shaft deflexion is on the same length as the contact pressure of the shaft hub joint. The strain caused by the bending (

� is calculated in (3.12).

� =

∙ =

With:

=

=

∙ ∙ ∙

=

=

∙ ∙

=

∙ =

=

(3.12)

Its solution is evaluated with a finite elements calculation (Figure 45). The re-

straints in the finite elements calculation are blocked translator deflexions of the shaft ends. The load is a forced deflexion at the centre of the shaft. This constraints causes a parabolic bending of the shaft. The solution of the maximal equivalent stress is 169 MPa and therefor about the same than the maximal stress calculated by hand (176 MPa).

65

Figure 45: FE calculation strain caused by bending

The static stress caused by the clamping force of the hub joint connection is for the lowest recommended tightening torque of the damping nut 197 MPa

(Ringspann GmbH, 2014). According the finite element solution, the combined stress is on the stretched side of the shaft (

� ℎ

) 358 MPa and on the compressed side (

� ) 22 MPa (Figure 46).

Figure 46: FE calculation combined stress

Figure 47: Stress cycle

The fatigue strength calculation is made according the strength of materials 2 script (Apel, 2012) which is based on the FKM- guidelines (research curatorship mechanical engineering). The fatigue strength of the material depends on

66 the nature of the load. A mean stress (

� ) reduces the fatigue strength (� ).

The fatigue strength for a pure alternating load (R=-1) can be estimated with its tensile strength ( ) and its ductility. The FKM-guidelines gives experimental determined ratios between the alternating fatigue strength and the tensile strength of certain material sorts ( ). The influence of the stress ratio (R)

can be read in the fatigue strength diagram (Figure 48). The rate of the stress

ratio’s influence depends on the materials tensile strength and is specified in mean stress sensitivity (

less steel S355 (Table 15).

). The calculation is made for the proposed stain-

Tensile strength Mean stress sensitivity

490..630 MPa

, ∙

∙ − ,

Table 15: Properties S355

Alternating strength factor

0,45

(Apel, 2012)

=

� ℎ

� =

� ℎ

=

− �

=

= , ≈

=

(3.13)

� = ∙ = , ∙

= , ∙

[ ] − , = , ∙

∙ − , = ,

The fatigue strength for the given stress ratio

tigue strength diagram (Figure 48). It is

�=

�=

can be read out the fa-

=

. The safety factor for a fatigue fracture is

= , (3.14). This result is just a roughly expectation

and is shows just a tendency of the actual fatigue strength. Since the calculations are made with the lowest specified tensile strength the actual fatigue strength is probably higher. The fatigue strength is defined as the stress which destroys the material after 10 6 stress cycles. 10 6 stress cycles are at a mean revolution speed of 1500 1/min a run-time of about 700 minutes. The run-time by maximum shaft deflexion will be just several seconds or at least few minutes.

Therefore the probability of a collapse is even less.

67

Figure 48: fatigue strength diagram

=

�=

= = ,

(3.14)

3.5.7

Housing design

The housing (Figure 49) consist mainly out of an aluminium profile frame on

which are two plastic plates mounted. The plates serve as basis for the motor and the supporting rails. The aluminium frame has in combination with supporting rails the needed stiffness for carrying the device and for supporting the motor and the rotor. The plates provide an additional damping between the rotor supporting and the frame as well as between the motor and the frame.

This reduces a vibrating of the housing. A low vibration of the complete device is necessary to ensure an undisturbed oscillating of the rotor. The requirements of the plate material is alike those of the supporting’s plastic parts.

Therefore the in chapter 3.5.3 selected material can also be used for the plates.

68

Figure 49: Housing

3.5.8

Safety-cap design

One of the in chapter 3.4.6 defined safety measures is the safety-cap. It has to

avoid a harmful contact between the rotating parts of the device and the user.

Additionally, it provides a barrier if rotating parts get loose or the shaft collapses. To not limit the view onto the rotor, the safety-cap is made out of Plexiglas (acrylic glass). An established glass thickness for applications like this is 8 mm. This thickness is adopted by commercial safety-caps for machine tools.

For a good torsion stiffness and to close the cap on both ends, there are endcaps out of plastics (PA6 or POM). The cap is fixed with two quick clamps on each end to fastening plates. The Plexiglas cover can be either bended to shape

or pieced out of several plates. The bended cover (Figure 51) needs threaded

holes on its faces to join it to the cap ends. This threaded holes are critical to produce because of the occurring notch effect. There is a high risk that the

Plexiglas cover cracks while cutting the tread or straining the bolts. The bending of Plexiglas is with a sufficient heating possible. If the cap will be made with a bended Plexiglas cover the processing instructions of the material has be followed. Since of the manufacturing difficulties, a cap is elaborated which

does not requires threads in the Plexiglas (Figure 50). It has instead of one

bended plate five several plates with milled chamfers on their long sides. The cap ends have milled slots in which the Plexiglas plates are bonded. To achieve an additionally stiffness, the cap ends are connected with two bars.

69

Figure 50: Safety cap with several plates

Figure 51: Safety cap with bended plate

3.6

Summary and prospects

The complete demonstration device is shown in Figure 52. The natural fre-

quencies of the rotor can be varied by adjusting the free supporting’s position as well as by adjusting the position of the disks. To remove or attach a disk the free supporting has to be slide of the shaft so that the disk and its safety bearing can be pulled out the shaft. To keep the shaft horizontally while the free bearing is taken-off, the second safety bearing is supposed to be put onto its corresponding disk. The disks can also be mounted on the cantilevered side of the shaft if desired. The combination of the thin shaft, the comparatively heavy disks and the, to a certain extend non-rigid supporting should demonstrate the critical speeds and their characteristic oscillating modes well. A sufficient operational safety is given by the safety-cap and the safety bearings. A detailed

70 operation manual and the assembly instructions for the device can be found in the attachment.

Figure 52: Complete device

Since in this work is just the mechanical design of the device made, the controlling of the motor has to be elaborated in a further work. Unfortunately the manufacturing of the custom parts is not done during my stay in Jyväskylä, so the assembling and putting into service has to be made later.

71

4

Summary

The introduced Laval Rotor is a simple model of a shaft-disk combination. The negligence of the shaft’s mass and the assumption of a symmetrically system permits to transfer the model into a plane mass-spring system which can be simply descript with a usual linear oscillating differential equation. An imbalance combined with a turning of the rotor excites the oscillating. This excitement makes the differential equation inhomogeneous and is described in the perturbation function. Since of the imbalance the differential equation got non-linear. The solving of the model is made numerical in the software

Matlab. Analysing the transfer function shows that the system

’s maximum deflexion is on its natural frequency. This deflexion depends on the damping and reaches in an undamped system infinite. Because of the risk of destruction, the natural frequency of a shaft is called critical speed. The Laval Rotor has because of its simplification as a one-mass system just a single degree of freedom and so just a single natural frequency. A distributed of the mass raises the number of degrees of freedom and also the number of natural frequencies.

Therefore a shaft with several disks has several critical speeds. A rotor oscillates beside translational also rotational which also should be taken in account while constructing a shaft.

The development project is separated in the planning phase, the conception phase, the drafting and the elaboration. In the conception are the device’s rough functions gathered. The concept describes that shaft length as well as the disks amount and positions should be adjustable. The drafting improves this concepts and specifies sub-functions and their operation methods. In the elaboration the designing process is completed and provides every documents which are necessary to manufacture and operate the device.

72

5

Discussion

A main objective of this thesis-work was on the one hand the gathering of the theoretical basis which is necessary to understand the effect of imbalanced excited bending vibrations of rotors and to determine the concept of the demonstration device. Furthermore, the development of an executable demonstration device was the actual objective of this work.

The theoretical basis is compiled in the theoretical part of this thesis. It provides an extensive overview and a comprehensively mathematical description of the phenomenon of imbalanced excited vibrations. The theoretical basis exceeds the, for the development demanded knowledge and deepened the author’s skills in the theory of oscillations and simulation.

The development of the demonstration device for imbalanced excited bending vibrations has be done during the thesis-work. The demands on the device are mainly fulfilled.

Since the designing of the motor’s control circuit is not made in this thesis-work, the demonstration device is not ready for use yet. Unfortunately, the manufacturing of the custom designed parts is not made during the author’s stay in Jyväskylä, so the assembling as well as the bringing into service cannot be done by the author. The development process demands capabilities in different subjects but primarily in the field of mechanical engineering design. The major challenge of the project was to meet the timetable.

The creating of the thesis was interesting, challenging and not least, because of the results satisfactory. Once more, I want to thank Matti and Jorma for supervising the thesis and the frequent, fruitful meetings.

73

6

References

Gasch, R., Nordmann, R., & Pfützner, H. 2006. Rotordynamik [Rotor

dynamic]. Berlin: Springer-Verlag.

Rao, S. 2010. Mechanical Vibrations. New Jersey: Prentice Hall.

Wittel, H., Muhs, D., Jannasch, D., & Voßiek, J. 2013. Roloff/Matek

Maschinenelemente [Roloff/Matek machine elements]. Wiesbaden: Springer

Vieweg.

Haberhauer, H., & Bodenstein, F. 2014. Maschinenelemente [Machine

elements]. Berlin: Springer Verlag.

Stodola, A. 1918. Eine neue kritische Wellengeschwindigkeit [A new critical

shaft speed]. Dinglers Polytechnisches Journal, 12. January 1918.

Apel, N. 2012. Festigkeitslehre 2 [Strength of materials 2]. Hochschule Esslingen.

Mattilainen, J. 2015. Machine Safety & Ergonomics. JAMK University of

Applied Sciences.

B & T Metall- und Kunststoffhandel GmbH. 2o April 2015. Prices of PA6 and

POM-C. Retrieved from http://www.metallkunststoffhandel.de/shop/

Henkel AG. 12 May 2015. Loctite 638 Data sheet. Retrieved from http://tds.henkel.com/tds5/docs/638-EN.PDF item Industrietechnik GmbH. 20 April 2015. Prices of item products.

Retrieved from http://www.item24.com/

KTR Kupplungstechnik GmbH. 10 April 2015. ROTEX catalogue. Retrieved from http://ktrinternational.com/root/img/pool/pdf/produktkataloge/en/ en_gesamt/001_rotex_en.pdf

74

NSK Ltd. 15 April 2015. Information about self-aligning ball bearings.

Retrieved from http://www.nsk.com/products/ballbearing/selfaligning/

Ringspann GmbH. 15 December 2015. Installation and Operating

Instructions for Cone Clamping Elements. Retrieved from http://www.ringspann.com/files_db/1417603013_46__14.pdf

75

7

Attachment

1.

Part list

Manufacturing drawings:

2.

Supporting (DWR001)

3.

Outer rotor (DWR002)

4.

Inner rotor (DWR003)

5.

Shaft (DWR004)

6.

Hull (DWR005)

7.

Supporting plate (DWR006)

8.

Support strainplate (DWR007)

9.

Safety-bearing (DWR008)

10.

Safety-bearing strainplate (DWR009)

11.

Safety-bearing mountingplate (DWR010)

12.

Mountingplate strainplate (DWR011)

13.

Groundplate (DWR012)

14.

Corner 1 (DWR013)

15.

Corner 2 (DWR014)

16.

Cap plexiglass corner (DWR015)

17.

Cap plexiglass side (DWR016)

18.

Cap face (DWR017)

19.

Cap face motor side (DWR018)

20.

Cap rail (DWR019)

21.

Cap shoulder (DWR020)

22.

L-profile (DWR029)

Assembly drawings:

23.

Safety-cap (DWR021)

24.

Rotor (DWR022)

25.

Supporting (DWR023)

26.

Frame (DWR024)

27.

Housing (DWR025)

28.

Safety-bearing (DWR026)

29.

Complete device top-view (DWR027)

30.

Complete device side-view (DWR028)

Manuals:

31.

Assembly instructions

32.

Operation manual

PART LIST

Custom parts

Part Nr.

PART001

PART002

PART003

PART004

PART005

PART006

PART007

PART008

PART009

PART010

PART011

PART012

PART013

PART014

PART015

PART016

PART017

PART018

PART019

PART020

Drawing Nr. Name

DWR001

DWR002

Bearing housing

Rotor outer

DWR003

DWR004

DWR005

DWR006

Rotor inner

Shaft

Hull

Supporting plate

DWR007

DWR008

DWR009

DWR010

DWR011

DWR012

DWR013

Supporting strainplate

Safetybearing

Safetybearing strainplate

Mountingplate Safetybearing

Mountingplate Strainplate

Groundplate

Corner 1

DWR014

DWR015

DWR016

DWR017

DWR018

DWR019

DWR020

Corner 2

Cap plexiglass corner

Cap plexiglass side

Cap face

Cap face motorside

Cap rail

CAP shoulder

Purchasing parts

PART101

PART102

PART103

DWR029 PART104

PART105

PART106

PART107

PART108

PART109

PART110

PART111

PART112

Item profile 40x40 45° x820mm

Item profile 40x40 x180mm

Item profile 40x40 x1400mm

Item L-profile 40x40x4 x820mm

Ringspann shaft-hub-coupling

Rotex coupling

Self-alligning ball bearing

Item T-Slot Nut 8 St M4

Item T-Slot Nut 8 St M6

ItemAutomatic-Fastening Set 8 quick fastener

Motor

Standard pts.

Norm

PART201 ISO 10642

Name

Countersunk Screw M4x22

PART202

PART203

ISO 10642 Countersunk Screw M6x25

ISO 10642 Countersunk Screw M8x80

PART204

PART205

PART206

PART207

ISO 4762

ISO 4032

ISO 4017

ISO 4032

Cylinder Screw M8x25

Hex nut M8

Hex Screw M10x40

Hex nut M10

PART208

PART209

PART210

ISO 4762

ISO 4032

Cylinder Screw M6x14

Hex Nut M5

ISO 10642 Countersunk Screw M5x25

2

2

1

2

2

3

2

44

12

12

4

1

4

4

8

16

40

12

10

4

4

4

1

1

2

2

2

3

2

2

2

2

2

2

2

2

2

1

1

2

Amount Material

2

2

Aluminium

Stainless Steel (V2A)

Stainless Steel (V2A)

Structural Steel (S355)

Structural Steel (S355)

Plastics (POM-C/PA6)

Plastics (POM-C/PA6)

Plastics (POM-C/PA6)

Plastics (POM-C/PA6)

Structural Steel (S235)

Structural Steel (S235)

Plastics (POM-C/PA6)

Plastics (POM-C/PA6)

Plastics (POM-C/PA6)

Acryl glass (Plexiglass)

Acryl glass (Plexiglass)

Plastics (POM-C/PA6)

Plastics (POM-C/PA6)

Plastics (POM-C/PA6)

Plastics (POM-C/PA6)

Order Number

See Item offer

See Item offer

See Item offer

See Item offer

4202-010100-000000 see Rotex drawing

SKF 1200 ETN9

See Item offer

See Item offer

See Item offer

Position

Groundplate, Corners

L-Profile/45°-Profile

Supporting/Safetybearing

Supporting

Supporting

Motor

Motor

Rotor

Cap

Cap

Weight [kg]

0,16

0,93

0,12

0,42

0,08

0,27

0,17

0,16

0,05

0,1

0,11

2,26

0,08

0,08

0,81

0,85

0,49

0,44

0,5

0,16

0,002

0,005

0,034

0,014

0,004

0,032

0,01

0,005

0,003

0,002

1,62

0,44

3,46

0,66

0,05

0,35

0,034

0,011

0,01

0,035

13,2

PART213

PART214

PART211

PART212

ISO 4762

DIN 125A

Cylinder Screw M4x40

Washer M10

DIN 6885 Feather key - Form A 8x7x18

DIN 471 Retaining ring - A 10x1

2

1

4

8

Cap shoulder

Motor

Device weight:

GROUP LIST

GROUP Nr.

GROUP001

GROUP002

GROUP003

GROUP004

GROUP005

GROUP006

GROUP007

Drawing Nr. Name

DWR021 Safety cap

DWR022

DWR023

DWR024

DWR025

Rotor

Supporting

Frame

Housing

DWR026

DWR027

DWR028

Safetybearing unit

Complete device

44 kg

0,003

The ITEM proiles , are o e ted o ea h li k ith t o

ITEM faste i g sets  a ordi g the ITEM i stru io s.

The grou dplates  are ou ted o the fra e  ith M

ou tersu k s re s a d ITEM M T-Slot uts  . Therefor the ITEM uts ha e to e posiio ed i to fra e eforeha d.

The L-proiles  ha e to e alig ed ith the la k of the grou dplates a d pla ed up to o ta t ith the ross proile.

Ne t, the posiio s for the oreholes i the grou dplates should e arked a d drilled ith , dia eter.

No , the tria gular ITEM proiles  a e ou ted ith

M ou tersu k s re s a d ITEM M T-Slot uts as ell as the or er parts  ith M ou tersu k s re s IM slot uts. The safet - ap shoulder  ha e to e i ed ith M li der s re s a d M slot uts.

The asse l of the shat has to e do e i a ertai order. Firstl , the feather ke  has to e i serted i to the adapter  a d the retai i g ke  ´put o to the shat  . Ne t, the eari g  a e put o to the shat ith o ta t to the retai i g ri g. Ater ards, the adapter has to e glued o to the shat. Therefor Lo ite

8 or a si ilar glue has to e used. The adapter should e put ith o ta t to the eari g so that the eari g does ot ha e a a ial pla . The glue ust e used a ordi g the i stru io s.

No , the eari gs a d housi gs a e joi ed. To joi the eari gs  a d their housi gs  for eless the housi gs ha e to e heated o a out 8 °C. The heai g a e either do e ith a hot air gu or ith a o e .

The eari g housi gs

should o e ou ted o the ou i g plates  .

Therefor M8 li der s re s a d M8 uts are used.

8

The se o d eari g a o also e put o to the shat. Ne t, the shat-suppori g u it has to e pla ed o the tria gular proiles.

 

The suppori g plates are i ed together ith their strai plates  . Therefor

M8 8 ou tersu k s re a d M8 uts are used.

To joi the i er rotor  a d the outer rotor  for eless, the eed a te perature difere e of a out °C. The shoulder’s fa e of the i er rotor a d the outer rotor should e i o ta t ater joi i g.

Asse li g i stru io /

No , the rotors  a d safet - eari gs  a e ou ted. Therefor the free suppori g has to e slide of the shat. The shat ust e keep horizo tall . The rotors are la ped ith the Ri gspa oupli g o to the shat.

The re uired tor ue is N a d should ot e e eed. The safet - eari gs are ou ted ith their etal plates a d a M8 8 ou tersu k s re ea h.

The se o d feather ke has to e put o to the otor’s shat. Ne t, the Rote oupli g  a e put o to the rotor’s shat. The otor ith the Rote oupli g ust e put ge tl o the shat. The otor’s eri all posiio should e set ith thi spa er dis s. If the otor’s i al posiio is fou d, the holes for the la pi g olts a e arked a d holes drilled.

The otor is i ed ith four M uts.

olts a d

The Ple iglas plates of the ap ha e to e glued i to o e of the ap-e ds. If the plates do ot it i to the slot, the slot should e ide ith sa dpaper. The applied glue should e a suita le glue for plasi aterials.

The ui k faste ers  should e ou ted i that a that there is a slight te sio et ee the ap a d the ap shoulders.

No , the ap-rails  should e ou ted o the ap-e d

ith a M ou tersu k s re s a d M ut ea h.

Ater ards, the se o d ape d a e glued o Ple iglas plates a d strai ed ith the ap-rails.

Asse li g i stru io /

Operation manual:

Read operation manual before using the device!

While shaft rotating, the safety-cap must not be removed!

While shaft rotating, the safety-bearings must always be at the disks!

To change the rotor

’s layout, open the quick fasteners and remove the safety-cap.

The oscillating system consists of the shaft (1), the free supporting (2), the fixed supporting (3), two disks (4), two safety-bearings (5) and imbalance-screws (6). The free support, the disks with their safety-bearings and the imbalance-screws can be adjusted.

To adjust the position of the free supporting, loose the four straining bolts

(internal hexagon 5 mm). The fixed supporting must not be shifted.

To shift the disk, the nut of the shaft hub connection has to be loosen.

Therefore, one person holds the disk and another person carefully loose the nut with an open-ended wrench (19 mm). The tightening torque must not exceed

31 Nm.

Operation manual 1/2

Before starting the device, the safety-bearing always have to be shifted on the disk

’s rim (1). The safety-bearing restricts the maximal deflexion of the shaft. The safetybearing should be in position, that it barely not clamps the disk

’s shoulder (2). The safety-bearing is strained with 5 mm internal hexagon 5 wrench.

Before removing the free supporting from the shaft, the safety-bearing must be put onto the disk

’s shoulder. Now, the safety-bearing serves as an additional supporting of the shaft and keeps the shaft horizontally if the free supporting is removed.

To remove or attach a disk and safety-bearing, the free supporting has to be shifted to the end of the rails.

To remove the safety-bearing its strainplate has to be 90° rotated. Therefor its bolt has to be loosen as far as required to turn the strainplate. Now, the safety-bearing can be taken.

The layout can be put in every desired way.

Before starting the device make sure that each screw and the disks are nuts are tightened. Check if the safety-bearings are properly positioned to the disks.

Operation manual 2/2

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
