2008 Clarion Application Guide
1
Contents
Category
Page
Technologies
3
Multimedia
30
Navigation
44
Source Units
50
Satellite Radio
59
Amplifiers
62
Subwoofers
75
Subwoofer Enclosures
106
Bass Book
110
Speakers
114
Marine Audio
133
Ungo ProSecurity
149
Car Audio Reference Guide
178
Guide Overview
WELCOME TO CLARION!
CLARION CORPORATION OF
AMERICA DEALER TECH
HOTLINE
800-733-3336
CLARION CANADA INC.
DEALER TECH HOTLINE
905-829-4600
800-668-5612
ONLINE WIRING, OWNERS
AND INSTALLATION
MANUALS AND PRODUCT
INFORMATION
WWW.TEAMCLARION.COM
This Sales and Application Guide provides you with all the information necessary to sell and install the entire Clarion product line.
Clarion has been a driving force in the mobile electronics industry for over 50 years. At Clarion, research and development has
always played a key role decade after decade. Our worldwide
engineering team is responsible for many technological innovations
that have influenced the entire car audio industry. Clarion products
are designed to satisfy not only the casual listener, but the discerning audiophile as well.
As part of the Clarion dealer network, you are able to offer your
customers car audio components unparalleled in quality and value.
We not only provide the right products, but also the necessary
support services.
The Dealer Technical Hotline is available to all authorized Clarion
dealers for installation and technical questions. It is manned by
Clarion experts from 8:30 AM to 5:00 PM EST, Monday through
Friday. A voice mail system is available to leave a message during
non-business hours and weekends.
Wiring diagrams are available 24 hours a day, seven days a week
from the www.teamclarion.com web site. Also available online are
owner's manuals, FAQs, product images, display board tags, and
online order entry.
CONTENT AND ACCURACY
Clarion makes every effort to ensure the accuracy and detail of the
information contained within this Product Application Guide.
However, due to continuous improvements and availability of information, the content of this document may need to be updated
throughout the year. The most recent and accurate version of the
binder can always be found online at www.teamclarion.com.
1
Corporate Overview
QUALITY CONTROL
Clarion products have long been recognized as being extremely
reliable. Quality control is an essential ingredient for reliability. During
manufacturing, products are tested at every stage – from first prototype,
through various stages of production, to the finished product. They are
subjected to a battery of tests ranging from vibration, shock, temperature
fluctuation, moisture, and other elements. Clarion’s attention to quality
control has earned an ISO 9002 Certification, the highest in the industry.
RESEARCH AND
DEVELOPMENT
Clarion has maintained a strong research and development program ever
since the company’s founding in 1947. By keeping ahead of the industry
with new innovations, Clarion has been able to offer “leading edge”
products for discerning audiophiles the world over. Clarion maintains
research facilities around the world. Three main laboratories in Japan
include product development, product engineering, and semi-conductor
research. In the United States, Clarion has a Technical Support Service
Center, as well as the North American Product Planning Department,
based at the Cypress (California) Corporate Office Complex. The staff of
engineers in Cypress work closely with engineers in Japan for product
development in both OEM and aftermarket products.
CLARION FIRSTS
IN THE INDUSTRY
• First car radio in Japan (Model A-214 – 1948)
• First audio equipment supplier to Japanese auto maker (Renault Motor
Co. - 1953)
• First fully-transistorized car radio in the world (1959)
• First car stereo set in Japan (CA-802 – 1963)
• First cassette car stereo set in Japan (PE-801 – 1968)
• First auto-reverse car cassette player in the world (PE-666 – 1971)
• First car radio FM impulse noise suppressor in Japan (CZ1 – 1978)
• First car graphic equalizer booster in the world (EQB – 1978)
• First AM noise-suppressing IC in the world (CZ2 – 1979)
• First motorcycle radio set in the world (Honda Motor – 1980)
• First DAT player for the car in the world (DAC2000 – 1984)
• First combination AM/FM, CD changer-controller, and cellular telephone
to operate by voice recognition (CAL-1000 – 1992)
• First active digital control system (ADCS-1 – 1993)
• First car multimedia system (TTX7101/VMA9181 – 1995)
• First in-car computer/audio system (Clarion Auto-PC – 1998)
• First in-dash integrated multi-zone DVD/MP3/CD/Tuner/Navigation
system (Clarion Joyride – 2002)
• First half-DIN in-dash powered center-channel speaker (SRK5 – 2003)
• First static memory, in-dash digital recorder (DXZ845MC Music Catcher
System – 2003)
• First Fully transportable Navigation and Entertainment system (NICE 2005)
2
Audio
Technologies
Audio Technologies
iPod Connectivity
In 2005, Clarion established a new benchmark
in Apple iPod connectivity with the release of
the VRX755VD and CCA649 (iPod audio control interface cable). This revolutionary multimedia source unit provided seamless operation
and control of the iPod with GUI (graphical
user interface) controls similar to those found
on the iPod. Not only did it control iPod while
connected, but it also recharged the internal
battery of the iPod. For those with a conventional CeNET source unit, Clarion offered the
EA1251B (CeNET black box interface). This
black box iPod interface allowed iPod users
to connect their iPod to CeNET source units
manufactured as far back to 2001. It essentially converted the iPod into an electronic CD
changer, as it required the creation of “Clarion”
playlists. Unlike a typical CD with an average
of 14 songs, each “Clarion” playlist was capable of storing up to 99 songs. Thus eliminating
scratched discs and trying to find the appropriate jewel case.
In 2006, Clarion introduced the VRX765VD
and MAX675VD multimedia command stations to the market place. Coincidentally, it
corresponded to the release of the Apple iPod
capable of video playback. Like it predecessor
the CCA649, the newly released CCA673 (iPod
audio control / video playback interface cable)
not only provided iPod audio control, but video
playback as well.
Multimedia stations weren’t the only category
to receive an iPod connectivity makeover.
CeNET source units, including CeNET marine
source units, took advantage of the new iPod
interface that didn’t require special playlists
and offered song selection sorted by song
title, album, artist, composer, genre, or playlist.
The EA1276B (CeNET iPod black box interface) provided the iPod integration people had
longed for.
In 2007, the continued growth of the multimedia category brought forth the release of
two additional multimedia control stations and
the introduction of two additional iPod interfaces. New for 2007 were the VRX775VD and
VRX575USB with the MAX675VD carrying over
from the previous model year. The VRX775VD
and MAX675VD utilized the CCA673, while
the VRX575USB uses the CCA691 (iPod audio
control / video playback interface cable).
These combinations of products provided
audio iPod control and video playback without
compromising sound quality and ease of use.
Since technology never stands still, the
EA1276B was replaced with the CCAIPOD
(CeNET iPod interface). Although they both
offered the same iPod audio playback and
song selection, the differences were evident in
their size and ease of installation. No longer
was it necessary to find a place for a bulky
black box.
A major turning point in iPod connectivity
came about in 2008. With a complete new
line-up of multimedia and CD source units.
With Clarion’s dominating presence in the multimedia category, six new multimedia stations
were introduced two of which are iPod direct
connect. But the innovations didn’t stop there;
as four new CD source units were introduced
offering USB iPod direct connect as well.
USB iPod direct connect allows iPod owners to connect their iPod with a standard USB
to iPod connector cable. The cable typically
included with the purchase of an iPod.
For the extremist, the VRX785BT and
MAX685BT offer both USB iPod direct connect
for audio control or audio control and video
playback with the CCA723 (iPod audio control
/ video playback interface cable). With their
advanced features and navigation capabilities, it is understandable why these units are
desired amongst the extremists.
The VRX585USB and VRX385USB offer audio
control and video playback when interfaced
with CCA691 cable. Whether scrolling through
thousand of songs or video files, nothing else
4
Audio Technologies
is required other than a fingertip.
Rounding up the new 2008 multimedia category are the VRX485VD and MAX385VD.
These multimedia control stations offer iPod
audio control and video playback when interfaced with the CCUIPOD1 (iPod audio control
/ video playback interface cable). An evident
sign of Clarion quality can be observed by the
exceptional audio/video playback and ease of
operation.
USB iPod direct connect also took center
stage when it came to CD source units with
four of them with USB iPod direct connectivity.
No black box or interface cable required!
Virtually from the beginning of the Apple iPod
reign, Clarion was at the forefront of iPod connectivity. By offering consumers GUI’s mimicking those commonly found on their iPod on
multimedia command stations with high speed
song and playlist search capabilities. And the
ability to utilize their existing Clarion CD source
units dating back as far as 2001 with their
iPod.
5
Apple iPod Interfaces
EA1251B (CeNET Black Box iPod Interface)
• Compatible with 2001-2006 CeNET Source Units
• Simulates the iPod as a 6-Disc CeNET CD
changer
• Requires “Clarion” playlists to be created.
• Some source units with CD-Text function have
the capability to show ID3 TAG information.
• Charges the iPod battery.
EA1276B (CeNET Black Box iPod Interface)
• Compatible with 2007-up CeNET Source Unit
• Compatible with Marine source units: M455A,
M475, CMD4A, CMD5
• Category direct access: Playlist, Artist, Album,
Song, Genre, Composer
• Some source units with CD-Text function have
the capability to show ID3 TAG information.
• Charges the iPod battery.
• Replaced by the CCAIPOD
CCAIPOD (Advanced CeNET iPod Interface)
• Compatible with 2007-up CeNET Source Unit
• Compatible with Marine source units: M455A,
M475, CMD4A, CMD5
• Category direct access: Playlist, Artist, Album,
Song, Genre, Composer
• Some source units with CD-Text function have
the capability to show ID3 TAG information.
• Charges the iPod battery.
Audio Technologies
CCA673 (iPod Audio Control / Video Playback
Interface Cable)
• Audio control and video playback with:
VRX765VD, VRX775VD, MAX675VD,
MAX675VDII
• Audio control only with: VRX755VD
• iPod GUI (graphical user interface) on-screen
display
• On-screen display of: Podcast titles, Artist
names, Album titles, Song titles, Genre names,
Playlist titles, Composer names
• Touch-screen direct category access to:
Playlist, Artist, Album, Song, Genre, Composer
• Video playback with compatible Apple iPods
• Charges the iPod battery.
CCA691 (iPod Audio Control / Video Playback
Interface Cable)
• Audio control and video playback with:
VRX385VD, VRX575USB, VRX585USB
• On-screen display of: Podcast titles, Artist
names, Album titles, Song titles, Genre names,
Playlist titles, Composer names
• Touch-screen direct category access to:
Playlist, Artist, Album, Song, Genre, Composer
• Video playback with compatible Apple iPods
• Charges the iPod battery.
CCA723 (iPod Audio Control / Video Playback
Interface Cable)
• Audio control and video playback with:
VRX785BT, MAX685BT
• iPod GUI (graphical user interface) on-screen
display
• On-screen display of: Podcast titles, Artist
names, Album titles, Song titles, Genre names,
Playlist titles, Composer names
• Touch-screen direct category access to:
Playlist, Artist, Album, Song, Genre, Composer
• Video playback with compatible Apple iPods
• Charges the iPod battery.
CCUIPOD1 (iPod Audio Control / Video
Playback Interface Cable)
• Audio control and video playback with:
VRX485VD, MAX385VD
• On-screen display of: Podcast titles, Artist
names, Album titles, Song titles, Genre names,
Playlist titles, Composer names
• Touch-screen direct category access to:
Playlist, Artist, Album, Song, Genre, Composer
• Video playback with compatible Apple iPods
• Charges the iPod battery.
6
Audio Technologies - iPod Compatability Chart
iPod
1Gen
2Gen
3Gen
4Gen
4GenPhoto
5Gen Video
6Gen Classic
- iPod Cable
Double Din
Multimedia
MAX685BT
(21)
(21)
(21)
(21)
(21)
- CCA723
(5,8,9,10,13)
(5,8,9,10,13,20)
iPod Cable
- CCUIPOD1
MAX385VD
(21)
(21)
(21)
(21)
(21)
- CCUIPOD1
(13)
(13, 20)
CCUIPOD1
- iPod Cable
VRX785BT
(21)
(21)
(21)
(21)
(21)
- CCA723
(5,8,9,10,13)
(5,8,9,10,13,20)
iPod Cable
Single Din Multimedia
- CCA691
VRX585USB
(21)
(21)
(21)
(21)
(21)
- CCA691
(9, 13, 17)
(2,9,13,17,20)
CCA691
- CCUIPOD1
VRX485VD
(21)
(21)
(21)
(21)
(21)
- CCUIPOD1
(13)
(13, 20)
CCUIPOD1
- CCA691
VRX385USB
(21)
(21)
(21)
(21)
- CCA691
(9, 13, 17)
(2,9,13,17,20)
CCA691
Mechless
FB275BT/
FB275BTB
(21)
(21)
(21)
(21)
(21)
(21)
(21)
Double Din Source Units
DUZ385SAT
(22)
(22)
(22)
(22)
(22)
(2)
iPod Cable
(1,2)
iPod Cable
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(1,2)
CCAIPOD
(21)
(21)
(21)
EA1251B
EA1251B
EA1251B
EA1251B
DXZ785USB
(21)
(21)
(21)
EA1251B
EA1251B
(2)
iPod Cable
(1,2)
iPod Cable
DXZ585USB
(21)
(21)
(21)
EA1251B
EA1251B
(2)
iPod Cable
(1,2)
iPod Cable
DXZ385USB
(22)
(22)
(22)
EA1251B
EA1251B
(2)
iPod Cable
(1,2)
iPod Cable
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
CMD5
(21)
(21)
(21)
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
M475
(22)
(22)
(22)
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(22)
(22)
(22)
(22)
(22)
(22)
(22)
UDB275MP
DFZ675MC
DRZ9255
Single Din Source Units
DB285USB
DB185MP
Marine
Source Units
M275
Note
1 “ERROR 3” message will be shown during FF/FB mode at the end / top of the track position
2 The image and video cannot be displayed.
3 Please connect iPod again if “ERROR 5” message is displayed by missing connect. If it
cannot recover the connection, please reset iPod software.
4 The playlist selection of a Chinese font may be PAUSE status.
5 Cannot play the les in “On-the-Go”.
6 During connection the “Accessary Connected” display is shown on the iPod
7
(21)
7
8
9
10
11
12
13
14
The playlist cannot be reproduced. It returns by reconnecting iPod.
When you connect iPod, please connect iPod after stopping playback.
“Smart Playlist” not supported.
There are some cases when trick play is not effective.
Can’t display “VIDEO” Key
Can’t display video les
The video contents cannot be controlled by touch panel through the main unit
CCA723 is required for playback video contents and the video contents can be
Audio Technologies - iPod Compatability Chart
iPod Mini
1Gen
iPod Shufe
2Gen
1Gen
iPod Nano
2Gen
1Gen
2Gen
iTouch
iPhone
3Gen
1Gen
1Gen
IPOD CABLE
CCA723
(6,7,8,9,10,13,20)
IPOD CABLE
CCA723
(6,7,8,9,10,13,20)
IPOD CABLE
CCA723
(5,6,7,8,9,10,13,15
16,20)
(13, 20)
CCUIPOD1
(13, 20)
CCUIPOD1
(13, 20)
CCUIPOD1
IPOD CABLE
CCA723
(6,7,8,9,10,13,20)
IPOD CABLE
CCA723
(6,7,8,9,10,13,20)
IPOD CABLE
CCA723
(6,7,8,9,10,13,20)
(21)
(21)
(21)
(21)
(2, 9)
iPod Cable
(2, 9)
iPod Cable
(21)
(21)
(21)
(21)
(2)
CCUIPOD1
(2)
CCUIPOD1
(21)
(21)
(21)
(21)
(2, 9)
iPod Cable
(2, 9)
iPod Cable
(21)
(21)
(21)
(21)
(2, 9, 17)
CCA691
(2, 9, 17)
CCA691
(2, 9, 13, 17, 20)
CCA691
(2, 6, 9,13,17, 20)
CCA691
(2,6,9,10,13,17, 20)
CCA691
(21)
(21)
(21)
(21)
(2)
CCUIPOD1
(2)
CCUIPOD1
(13, 20)
CCUIPOD1
(13, 20)
CCUIPOD1
(13,20)
CCUIPOD1
(21)
(21)
(21)
(21)
(2, 9, 17)
CCA691
(2, 9, 17)
CCA691
(2, 9, 13, 20)
CCA691
(2, 6, 9,13, 20)
CCA691
(2, 6,9,10,13,17,20)
CCA691
(21)
(21)
(21)
(21)
(21)
(21)
(21)
(24)
(24)
(22)
(22)
(22)
(22)
(2)
iPod Cable
(2)
iPod Cable
(2)
iPod Cable
(3, 4, 6)
iPod Cable
(3, 4)
iPod Cable
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(23)
(23)
CCAIPOD
CCAIPOD
(21)
(21)
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(3, 4, 6)
CCAIPOD
(3, 4)
CCAIPOD
EA1251B
EA1251B
(21)
(21)
EA1251B
EA1251B
EA1251B
EA1251B
EA1251B
(21)
(21)
(21)
(21)
(2)
iPod Cable
(2)
iPod Cable
(2)
iPod Cable
(3, 4, 6)
iPod Cable
(3, 4)
iPod Cable
(21)
(21)
(21)
(21)
(2)
iPod Cable
(2)
iPod Cable
(2)
iPod Cable
(3, 4, 6)
iPod Cable
(3, 4)
iPod Cable
(22)
(22)
(22)
(22)
(2)
iPod Cable
(2)
iPod Cable
(2)
iPod Cable
(3, 4, 6)
iPod Cable
(3, 4)
iPod Cable
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(23)
(23)
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(23)
(23)
(2)
CCAIPOD
(2)
CCAIPOD
(21)
(21)
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(22)
(22)
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(2)
CCAIPOD
(22)
(22)
(22)
(22)
(22)
(22)
(22)
(23)
(23)
15
16
17
18
19
controlled by touch panel through the VRX / MAX
Please connect “Airplane” mode
Can’t support Bluetooth connection.
There are some limitation when displaying characters other than alphabet and numeric. In
this case “*” will be displayed instead.
In case iPod is not charged, please turn OFF and ON the POWER of Source unit.
There are some cases “clarion” LOGO on the iPod will not disappear when disconnecting
the iPod. In that case reconnect iPod to Source unit and disconnect again, or Reset iPod.
20 Apple no longer allows 3rd party video connections to these units. Use Apple
Composite AV Cable (p/n: MB129LL/A) and connect to Visual Input.
21 No control over iPod by Source. Use CCAAUX + CCUAUXEX1.
22 No control over iPod by Source. Use CCUAUXEX1.
23 No control over iPod by Source. Use compatible iPhone/iTouch 3.5mm to 3.5mm
adapter
24 No control over iPod by Source. Use compatible iPhone/iTouch 3.5mm to 3.5mm
adapter + CCAAUX.
8
Audio Technologies
Bluetooth Connectivity
In efforts to promote driver safety and the safety
of others, Clarion is offering several source units
featuring a built-in Bluetooth interface and a universal Bluetooth transceiver. Aside from handsfree phone operation, they’re also capable of
Bluetooth audio streaming (A2DP) and audio/
video remote control profiles (AVRCP).
Highlighting the product line up is the EZD580,
a 4.3” portable navigation system. This portable navigation system allows Bluetooth operation anywhere life takes you. Whether in the car,
home, office, or wandering the streets Bluetooth
connectivity is right at your fingertips.
amplified speaker. When paired with a cell phone,
the BLT370 has a dedicated wire to give commands toa a "Bluetooth Ready" Clarion source
unit to automatically swithch to an auxiliary input
when placing or receiving a call. Additionally, it
has a 2.5mm input for an optional microphone
(mono).
There is no compromise for safety and that’s why
Clarion offers products with integrated Bluetooth
connectivity and a universal Bluetooth transceiver
compatible with any source unit.
NOTE:
For a detailed description of Bluetooth and
Bluetooth profiles, please to refer to Bluetooth
Technology section of the Clarion Application
Guide.
Bluetooth Accessories
For the mobile entertainment enthusiast, Clarion
offer two multimedia control stations with an integrated Bluetooth interface. The VRX785BT (single
DIN chassis) and MAX685BT (double DIN chassis)
have the ability to transfer the phone book of the
paired cell phone for easy dialing and caller identification.
Termed the “metal shark design,” the FB275BT
and FB275BTB have a built-in Bluetooth interface.
The uniqueness of these units is the ability to use
the radio preset buttons as direct access to frequently called phone numbers with the paired cell
phone.
Rounding off Clarion’s Bluetooth connectivity
products is the BLT370, universal Bluetooth transceiver. The BLT370 can be interfaced with any
source unit that features an auxiliary input or to an
9
BLT370: Bluetooth Audio/Mobile Phone
Transceiver
• Can be interfaced with any source unit with an
auxiliary input.
• Bluetooth Audio Streaming (A2DP)
• Circut for Bluetooth ready Source Units
• 2.5mm Microphone Input
RCB199: External Microphone for VRX785BT
and MAX685BT
• External uni-directional microphone cuts down
much of the background noise.
• Integrated Visor Mount
• 3.5mm Mini-Jack
• BLT370 requires 3.5mm to 2.5mm male adaptor
Audio Technologies
Bluetooth Basics
Bluetooth wireless technology is a short-range
communications technology intended to replace
the cables connecting portable and/or fixed
devices while maintaining high levels of security.
The Bluetooth specification defines a uniform
structure for a wide range of devices to connect
and communicate with each other.
Bluetooth technology has achieved global
acceptance such that any Bluetooth enabled
device, almost everywhere in the world, can connect to other Bluetooth enabled devices in proximity.
Bluetooth enabled electronic devices connect
and communicate wirelessly through shortrange, ad hoc networks known as piconets. Each
device can simultaneously communicate with up
to seven other devices within a single piconet.
Each device can also belong to several piconets
simultaneously. Piconets are established dynamically and automatically as Bluetooth enabled
devices enter and leave radio proximity.
A fundamental Bluetooth wireless technology
strength is the ability to simultaneously handle
both data and voice transmissions. This enables
users to enjoy variety of innovative solutions
such as a hands-free headset for voice calls,
printing and fax capabilities, and synchronizing
PDA, laptop, and mobile phone applications to
name a few.
Bluetooth Profiles
Advanced Audio Distribution Profile
(A2DP)
A2DP describes how stereo quality audio
can be streamed from a media source to a
sink. A2DP defines the protocols and procedures that realize distribution of audio content of high quality in mono or stereo on ACL
channels. The term “advanced audio”, therefore, should be distinguished from “Bluetooth
audio”, which indicates distribution of narrow
band voice on SCO channels as defined in
the baseband specification.
Audio/Video Remote Control Profile
(AVRCP)
AVRCP is designed to provide a standard
interface to control TVs, hi-fi equipment, or
other to allow a single remote control (or
other device) to control all the A/V equipment
that a user has access to. It may be used in
concert with A2DP.
AVRCP defines how to control characteristics
of streaming media. This includes pausing,
stopping and starting playback and volume
control as well as other types of remote control operations.
Hands-Free Profile (HFP)
HFP describes how a gateway device can
be used to place and receive calls for a
hand-free device. A typical configuration
is an automobile using a mobile phone for
a gateway device. In the car, the stereo is
used for the phone audio and a microphone
is installed in the car for sending outgoing
audio. HFP is also used for a personal computer to act as a speakerphone for a mobile
phone in a home or office environment.
Headset Profile (HSP)
The HSP describes how a Bluetooth enabled headset should communicate with a
computer or other Bluetooth enabled device
such as a mobile phone. When connected
and configured, the headset can act as the
remote device’s audio input and output interface.
10
Audio Technologies
Object Exchange (OBEX)
OBEX is a transfer protocol that defines data
objects and a communication protocol two
devices can use to exchange those objects.
OBEX is designed to enable devices supporting infrared communication to exchange
a wide variety of data and commands in a
resource-sensitive standardized fashion. The
OBEX protocol also defines a folder-listing
object, which is used to browse the contents
of folders on remote device. OBEX enables
applications to work over the Bluetooth technology protocol stack as well as the IrDA
stack. For Bluetooth enabled devices, only
connection-oriented OBEX is supported.
Three application profiles have been developed using OBEX that include SYNC, FTP
and OPP.
Object Push Profile (OPP)
OPP defines the roles of push server and
push client. It is called push because the
transfers are always instigated by the sender
(client), not the receiver (server). OPP focuses on a narrow range of object formats to
maximize interoperability. The most common
acceptable format is the vCard. OPP may
also be used for sending objects such as
pictures or appointment details.
11
Audio Technologies
USB Connectivity
For 2008, USB connectivity was the focal point
in the development of eleven multimedia and CD
source units. USB connectivity provides easy
music transporting from your computer via USB
Mass Storage Device (a.k.a. jump drives) or compatible music player to your Clarion source unit.
In selected source units, it also provides USB
iPod Direct Connect connectivity. Allowing iPod
owners to connect their iPod using an USB cable
with direct access to playlist, albums, artists,
composers, or songs.
An additional advantage of Clarion USB ports is
they’re all powered. What does this mean? This
means it can be
used to recharge the
battery of commonly
used devices such
as cellular phones,
portable navigation
units, iPods, and
more through the
USB port.
Multimedia Source Units:
MAX685BT (rear USB port, USB iPod Direct Connect)
VRX785BT (rear USB port, USB iPod Direct Connect)
VRX585USB (rear USB port, USB iPod Direct Connect)
VRX385USB (rear USB port, USB iPod Direct Connect)
CD Source Units:
DXZ785USB (rear USB port, USB iPod Direct Connect)
DXZ585USB (front USB port, USB iPod Direct Connect)
DXZ385USB (front USB port, USB iPod Direct Connect)
DB285USB (front USB port)
DUZ385SAT (rear USB port, USB iPod Direct Connect)
UDB275MP (front USB port)
USB Accessories:
CCAUSB: USB 2.0 Extension with Integrated Cover
• 1 Meter Cable with gold plated copper contacts providing maximum conductivity with
minimal data loss.
• Requires ¾” hole for mounting
NOTE:
USB Mass Storage Class devices (a.k.a. jump
drives) that require special software or contain
software drivers may not be detected when connected to USB equipped source units. Check
the manufacturer’s specification before proceeding.
SD Card Connectivity
Storage devices come in all shapes and sizes,
but one of the most commonly used is the SD
(Secure Digital) Memory Card. Smaller than a
pack of matches, these media storage devices
can store thousands of songs. Clarion offers
three source units capable of SD memory card
playback: FB275BT, FB275BTB, and DFZ675MC
12
Audio Technologies
All three source units allow users to scroll
through files and folders with same features usually associated with CD playback. Features like,
fast forward, fast rewind, scan play, folder scan,
repeat play, folder repeat play, and random play.
In addition, the ability to display folder name, file
name, album name, or artist name for easy identification of what’s playing
Clarion philosophy on SD memory cards is simple, “load ‘em, play ‘em!”
NOTE:
It is recommended not to use SD memory cards
exceeding 1GB.
Auxiliary Inputs
For 2008, Clarion’s multimedia, CD source units,
and Marine source units all feature an adjustable
sensitivity auxiliary input. Thus eliminating the
crude and inferior FM modulation of an external
audio source. Whether connecting a Bluetooth
interface, portable music player, satellite radio
receiver, video game station, video player, or computer is simple. Merely connect a standard audio
cable for the audio source into the auxiliary input
on the source unit.
To ensure excellent sound quality and matching
the audio levels through the various sources on
head unit, Clarion incorporated an auxiliary level
sensitivity adjustment. This eliminates variations
in volume while switching from the internal audio
sources to an external audio source. In addition,
it minimizes the audio clipping which can generate
distortion and other unwanted noise.
No matter the source, Clarion has you connected.
13
Auxiliary Input Accessories:
CCAAUX: Female 3.5mm Stereo Mini-Jack to
Male RCA Extension Cable with Integrated Cover
• 3.5mm Gold Plated Stereo Mini-Jack
• 1 Meter OFC RCA Cable with Gold Plated RCA
Connectors
• Integrated Protective
Cover
• Requires ¾” Hole for
Mounting
CCUAUXEX1: 6' Male 3.5mm
to 3.5mm Audio Cable
• 3.5mm Gold Plated Stereo
Audio Cable
• Used to connect portable
audio players to CCAAUX
or Front panel Auxilliary
input
Multimedia Source Units
MAX685BT (rear RCA input)
MAX385VD (rear RCA input)
VRX785BT (rear RCA input)
VRX585USB (rear RCA input)
VRX485VD (rear RCA input)
VRX385USB (rear RCA input)
CD Source Units
DRZ9255 (‘2’ rear RCA inputs)
DXZ785USB (rear RCA input)
DXZ585USB (rear RCA input)
DXZ385USB (front panel 3.5mm input)
DXZ285USB (front panel 3.5mm input)
DB185MP (front panel 3.5mm input)
DUZ385SAT (front panel 3.5mm input)
UDB275MP (front panel 3.5mm input)
DFZ675MC (front panel 3.5mm input)
Marine Source Units
CMD5 (rear RCA inputs)
M475 (front panel 3.5mm input)
M275 (front panel 3.5mm input)
Audio Technologies
OEM Remote Ready
With more and more vehicles featuring radio controls integrated in the steering wheel, it is more
important than ever to offer aftermarket source
units capable of interfacing with them. That’s
why Clarion offers a host of multimedia control
stations and CD source units with the capability of adding a third party OEM steering wheel
remote interface.
Load your favourite CD, hit record, and in 1/4 the
time it takes to listen to the song, Music Catcher II
has stored it in its flash memory IC.
By using the Music Catcher System, no longer is
there a need to carry around fragile CD storage
cases, or risk damage to your favourite CD.
These third party interfaces utilize the key functions found on the steering wheel, such as
volume, mute, seek, track, band, and source
controls. By allowing the driver to control the primary functions of the source unit from the steering wheel, it minimizes distractions and removal
of the hand from the steering wheel to adjust the
source unit.
For additional information regarding OEM steering wheel interfaces, please visit: www.pacaudio.com, keyword: SWI-JACK & SWI-CAN
OEM Steering Wheel Remote Ready Multimedia
Control Stations:
VRX785BT
MAX685BT
VRX585USB
VRX385USB
OEM Steering Wheel Remote Ready CD Source
Units:
DXZ785USB DB285USB
UDB275MP
DXZ585USB DB185MP
DXZ385USB DUZ385SAT
Music Catcher II
Clarions evolved Music Catcher System II can be
found on the DFZ675MC. Music Catcher II, which
utilizes an on-board flash memory module, allows
one to record, play and erase up to 13 CDs worth
of music (Music Catcher will not record MP3/WMA
files). Music Catcher offers four recording modes
to choose from, so you can choose between storage capacity and fidelity.
Music Catcher II is also capable of recording
audio at up to 4x normal playback speed, letting
you record your favourite songs faster than ever.
Phone Mute Input
Clarion source units feature a Cell Phone mute
input wire. As discussed previously, this wire
also functions as the Bluetooth Control wire on
Bluetooth Ready source unit models.
In its normal function, when a (-) ground signal is
applied to the brown wire in the radio harness,
the radio will mute the audio output until the (-)
ground signal is removed. This is designed to be
used with Cellular phone car kits.
2008 Bluetooth Ready source units feature a
programming option that will, when enabled,
switch the source unit to the auxiliary input when
(-) ground is applied to the brown wire. This is for
use with the BLT370 Bluetooth Interface.
Navigation Ready
Clarion is a world leader in the development of
GPS Navigation systems, manufacturing OEM
systems for the top car manufacturers in the world,
including Porsche, Nissan, Infiniti, Volkswagen,
Ford and more.
14
Audio Technologies
For 2008, Clarion offers two source units that are
Navigation Ready - the 1-DIN VRX785BT and the
2-DIN MAX685BT. These source units feature an
RGB connection on the back of the radio that
accepts a high resolution video signal from our
NAX980HD Navigation System, as well as programming to provide full touch screen control
over all navigation functions. These source units
will also mute the audio signal to allow navigation
commands to come through loud and clear while
you are driving.
2-Zone Entertainment
Clarion offers four source units that offer 2-Zone
Entertainment. This function allows front seat
passengers to listen to one audio source while
rear seat passengers can enjoy another through
and overhead or headrest monitor with headphones.
The rear seat passengers can enjoy a DVD movie
with the front seat passengers can listen to the
Radio Tuner, iPod or Visual Input. Volume control
over the 2-Zone output is performed by the headphones as the 2-Zone output is line-level.
Please review your source unit owner's manual
for limitations pertaining to 2-Zone functionality
with respect to specific accessories.
CCD Camera Input
The Clarion VRX785BT, MAX685BT, VRX585USB
and VRX385USB feature a dedicated CCD camera input jack on the rear of the source unit. When
connected to the CK625E camera kit, the camera
input will be triggered automatically when the
vehicle is put in reverse. This makes backing up
safe and secure.
15
A/V Inputs
This additional A/V input allows you to connect
and external A/V source such as a video game
system or TV Tuner (TTX005) to your multimedia
source unit. This allows for system expansion
and when combined with the MSS430 Source
Commander A/V Switcher, can be at the heart of
a massive multimedia system.
A/V Outputs
This allows you to connect the output of the
internal DVD player, or Visual input to an external monitor. The A/V output features a line-level
audio signal. The connected device must have
it's own volume control. Compatible devices
include overhead or headrest monitors with wireless headphones.
Video Distribution
Any time a video signal is to be split and connected to multiple vide sources, the use of a proper
electronic video distribution amplifier is required.
The Clarion VA700 provides seven buffered video
outputs from a single composite video input connection.
Using the VA700 will ensure that picture quality remains clear and sharp and the brightness
and contrast levels are not altered. The use of
Y-cables is not an option for splitting a composite
video signal as the signal voltage determines the
black level of the image, and will be altered when
split.
Audio Technologies
Compressed Media Formats
Transmitting audio and data via satellite spawned
the need to various formats of media compression. These formats allow multiple signals to
occupy the same bandwidth as an uncompressed signal. This increased efficiency, reduces
cost and allows more data to be transmitted at
higher speeds.
Clarion is at the forefront of compressed media
file playback. For 2008, Clarion offers support for
AAC, DiVX and MPEG compressed media files to
our already extensive list.
WAVE Format
Wave (.wav) files are considered to be uncompressed. This is file format is used for the storage of 2-channel audio in digital form. The file
is stored in PCM (Pulse Code Modulation) form
and uses the standard 44,100 samples per second, 16 bits per sample times two channels. The
resulting data rate is 1,411.2 kbps.
Microsoft originally claimed that WMA files had
better sound quality than MP3 files recorded at
the same bitrate. Subsequent double-blind testing have repeatedly confirmed that the file formats are very similar.
AAC Format
AAC (Advanced Audio Coding) is another lossy
compression and encoding format for digital
audio. The AAC format has been made popular
as it is the standard format for the Apple iPod.
AAC offers more sample and bitrate options as
compared to MP3 files. Sampling rates from 8
kHz to 96kHz are available) and up to 48 channels
can be encoded.
AAC happens to the default audio codec used on
the PlayStation 3, PSP, the Apple iTunes website
and iPod products.
DivX
MP3 Format
MP3 files gained popularity due to their reduced
file size. MP3 stands for MPEG-1 Audio Layer 3.
MP3 files use perceptual encoding to reduce files
sizes while limiting the effect on sound quality.
The MP3 standard allows for bitrates between
32 kbps and 320 kbps with sampling rates of 32,
44.1 and 48 kHz. A higher bitrate represents less
compression and better (relative to the original)
sound quality.
ID3 Tag Display
ID3 tags were created and inserted at the end
of an MP3 file allow for the storage of metadata
information such as song title, artist, album name,
genre and year.
WMA Format
WMA (Windows Media Audio) is a compressed
audio file format created by Microsoft. It is very
similar in concept to MP3 files, but includes provisions for DRM (Digital Rights Management).
At the forefront of compressed video technology is the DivX codec. The latest version of this
codec, called DivX 6 (or DivX Media Format)
reduces the file size of digital movies while retaining support for multiple audio tracks, interactive
menus, chapter points, multiple video streams
and subtitles.
For 2008, the Clarion VRX785BT, MAX685BT,
VRX385USB and VRX585USB support the DivX
Media Format in its native form. Offering high
quality, fully interactive movie playback. These
units are fully DivX Certified.
CD Text
CD Text is an extension of the standard audio
CD format and allows Album Name, Song Name
and Artist information to be stored on a standard
audio CD. Source units bearing the CD Text logo
are capable of displaying this information from
compatible discs. Not all store-bought CD's are
encoded with CD Text information. Look for the
16
Audio Technologies
CD Text logo on the packaging or disc to confirm
proper encoding.
MPEG 1, 2 and 4
The Motion Picture Experts Group (MPEG) is a
group that oversees the development of video
and audio encoding standards. The various
MPEG standards outline the capabilities of each
compression format.
MPEG-1
This was the initial audio and video compression
standard and later became the standard for the
Video CD. It utilizes MP3 for the audio track.
MPEG-2
The is the standard format for audio and video
broadcast for standard television. It is used for
over-the-air broadcast, as well as Dish Network,
digital cable and with some slight variations, on
DVDs.
MPEG-4
This is an expansion of the MPEG-1 format and
adds the ability to support audio/video objects,
low bitrate encoding, 3D content and support for
Digital Rights Management (DRM)
Video CD
Video CD (VCD) is the standard digital format for
storing video on a compact disc. The VCD format offers a resolution of 352x240 pixels with an
aspect ratio of 107:80 (within 0.3% of 4:3) and a
framerate of 29.97 or 23.976 frames per second
and a bitrate of 1.150 kbps
MP3 on DVD
Storing MP3 files on a DVD provides you with the
ability to have days and days of music on hand,
on a single convenient disc.
Please review the directory structure guidlines in
the owner's manual of each product.
17
Performance Technologies and Features
Signal Processing
Clarion products remain at the forefront of sound
quality and performance. Our source units have
features that allows your mobile audio system
to recreate sound that is closer to the original
recording than ever before. These features include
advanced signal restoration for compressed audio,
digital equalization, advanced D/A converters and
digital storage systems.
Clarion calls the concept of remaining true to the
original audio recording Sound Genesis. This is at
the heart of everything Clarion does.
Sound Restorer
Compressed audio files allow a large amount of
information to be stored in a small space. The
drawback is that some of the audio information,
particularly in the high frequency range is lost.
The result of Sound Restorer processing is music
that sounds more like the original recording. The
subtle nuances and harmonics are recreated and
your music won't sound like compressed music
any more.
Digital Z-Enhancer
High performance system equalization to compensate for factory speaker performance or vehicle acoustics has never been easier, thanks to
Digital Z-Enhancer.
Clarion's Digital Z-Enhancer features three preset
equalization curves, each with 7 'effect' levels.
The result is 21 different easily accessible curves
to make altering the performance of your audio
system quick, easy and satisfying.
Clarion introduces Sound Restorer - a digital
technology that analyzes a musical waveform for
high frequency content, then recreates harmonics
to restore those lost during compression.
Original Recording
Compressed Recording
Sound Restorer Processed Recording
Digital Z-Enhancer can be found on the
DFZ675MC, DXZ785USB and DXZ585USB.
18
Performance Technologies and Features
Z-Enhancer
Making system tuning as easy as possible is one
of the primary concepts behind HMI. Z-Enhancer
makes tuning as easy as pushing a button.
Z-Enhancer offers bass and treble equalization
via three preset EQ curves, each curve is adjustable in effect level in seven steps from -3 to +3.
Excite - Emphasizes Bass and Treble while
dempahsizing midrange
Here are the parameters for each of the frequency
bands:
Bass: Boost: -12 to +12dB
Q-Factor: 1, 1.25, 1.5 or 2
Frequency: 50, 80 or 120 Hz
Mid:
Boost: -12 to +12dB
Q-Factor: 1.5 or 2
Frequency: 700Hz, 1kHz or 2kHz
Bass: Boost: -12 to +12dB
Frequency: 8kHz or 12kHz
5-Band Parametric Equalizer
Impact - Emphasizes Bass and Treble
B-Boost - Emphasizes Bass
3-Band Parametric Equalizer
This advanced equalization system is found on
the MAX685BT and VRX785BT. A parametric
equalizer allows for advanced and detailed system frequency response adjustment.
The 3-Band Parametric Equalizer allows you to
adjust the bass and midrange for Q-factor (bandwidth), Boost and Center Frequency. Treble is
adjustable only for Boost and Center Frequency.
19
The DRZ9255 features a 5-Band parametric
equalizer. This evolves its flexibility and tuning
features to allow for perfect frequency response
adjustment. The 5-Band parametric equalizer
allows allows for independent left and right channel adjustment. The copy command allows you
to quickly duplicate settings from one channel to
the other. Here are the parameters for the different bands:
Band 1, 2 and 3
Boost: -12dB to +12dB
Q-Factor: 0.5 to 12.0
Frequency: 50Hz to 20kHz
Band 4 and 5
Boost: -12dB to +12dB
Q-Factor: 0.5 to 12.0
Frequency: 630Hz to 20kHz
Q-Factor
The following graphs show the relationship
between center frequency, gain and Q-curve.
When a large Q-Factor number is selected, the Qcurve becomes sharper. When a small Q-Factor
number is chosen, the Q-Curve becomes wide.
The shape of the Q-Curve determines the range
of frequencies the boost or cut will affect.
The calculation that determines the Q-Factor is
based on the center frequency of the equalization, and the bandwidth at the -3dB point.
Performance Technologies and Features
To make adjusting time alignment easy, Clarion
calibrates our two time alingment systems (found
on the DRZ9255 and DXZ785USB) in units of
measure, rather than in units of time. This means
you can simply take out a tape measure and
record the distance from the listener to each
speaker. Fine tuning by a trained ear will result
in an excellent soundstage and realistic audio
performance.
DRZ9255
Magna Bass EX
Conventional loudness circuits boost bass frequencies around 100Hz. This results in a muddy
over-boosted sound which is un-natural. MagnaBass EX focuses the bass boost at 50Hz, adding
warmth and richness to the sound. This 50Hz
boost efffectively extends the frequency response
of smaller speakers, making you system sound
larger and more capable. The result is dynamic
bass performance that sounds real.
The DRZ9255 offers the industries finest time
alignment adjustment steps. You can adjust each
channels delay in 0.7cm (roughly 1/4-inch) steps
to perfectly align the output of each channel.
The DRZ9255 feautres 8 channels of output
(Subwoofer, Low, Mid and High) and both left
and right outputs are adjustable independantly.
The maximum distance is 512.4cm (roughly 201
inches). This is perfect for a three-way front stage
and subwoofer system.
DXZ785USB
This is the little brother to the flagship DRZ9255,
but is still incredibly potent. The time alignment
on this unit is adjustable in 2.3cm (roughly 1 inch)
steps. There are six channels of output on the
DXZ785USB (Low, Mid and High) and of course,
each of the six is adjustable independantly. This
is perfect to a bi-amped (2-way) front stage
plus subwoofer system. The maximum delay is
501.4cm (just under 200 inches).
Electronic Crossovers
Time Alignment
Advanced Digital Signal Processing (DSP) allows
for intricate and complex mathematical functions
to be performed on an audio signal. One of these
advanced functions is Time Alignment.
Time Alignment refers to the ability to adjust the
relative arrival time of one signal as compared to
another.
Electronic crossovers are designed to pass only
a certain range of frequencies through a circuit.
There are two types of eletronic crossovers: HighPass and Low-Pass.
A High-Pass crossover will allow only those frequencies above (higher than) the crossover point
to pass through. This type of crossover is used on
tweeters to protect them from low and midrange
frequencies and on midrange drivers to protect
them from low frequencies.
A Low-Pass crossover will only allow those
20
Performance Technologies and Features
frequencies below (lower than) the crossover
point to pass through. This type of crossover is
used on subwoofers to keep midrange and high
frequencies from being reproduced.
unit to run your speakers, while an amplifier and
subwoofer can handle low frequency output.
Clarion electronic crossovers are all adjustable for
frequency and are easy to implement.
A combination of High- and Low-Pass crossovers
may be used to fliter both and low frequencies
passed to a device such as a midrange or midbass driver. This is called a Band-Pass crossover.
The following chart outlines the crossover functionality in each unit.
There are two important numbers to consider
when considering a crossover - the cutoff frequency - fc and the crossover slope.
The crossover frequency determines the point at
which the filter will start to work. For example, a
High-Pass crossover set to 100Hz will attenuate
the frequencies below 100Hz and pass frequencies above 100Hz.
Crossover slope describes the rate at which the
crossover attenuates those frequencies.
Speakers are designed to operate within a specific range of frequencies. Sending frequencies
to a speaker that it was not designed to handle
reduces its performance and could result in poor
sound quality. For 2008, Clarion includes electronic Low-Pass and High-Pass crossovers on
the DXZ385USB through DXZ785USB source
units.
The electronic crossovers found in Clarion source
units not only affects the pre-amp outputs, but the
signal being sent to the internal amplifier as well.
This means you can use a high-power source
21
Source
DB185MP
DB285USB
DXZ385USB
DXZ585USB
DXZ785USB
MAX685BT
VRX785BT
VRX585USB
VRX485VD
MAX385VD
VRX385USB
HPF Frequency
HPF Slope
120Hz
50/80/120Hz
50/80/120Hz
50/80/120Hz
50/80/120Hz
120Hz
N/A
N/A
120Hz
6dB
12dB
12dB
12dB
12dB
6dB
N/A
N/A
6dB
Source
DB185MP
DB285USB
DXZ385USB
DXZ585USB
DXZ785USB
MAX685BT
VRX785BT
VRX585USB
VRX485VD
MAX385VD
VRX385USB
LPF Frequency
Level Control
Level Control
50/80/120Hz
50/80/120Hz
50/80/120Hz
50/80/120Hz
50/80/120Hz
50/80/120Hz
60/120/180Hz
60/120/180Hz
50/80/120Hz
LPF Slope
12dB
12dB
12dB
12dB
12dB
12dB
12dB
12dB
12dB
Performance Technologies and Features
DXZ785USB Crossovers
DRZ9255 Crossovers
The DXZ785USB features three different operating modes - 2-Way, 3-Way and Normal.
The DRZ9255 features three different operating
modes - Standard, Multi and Direct.
The following chart outlines the output functions
in each mode:
The following chart outlines the output functions
in each mode:
Mode
Normal
3-Way
2-Way
Mode
Direct
Multi
Standard
Front
Front
High
High
Rear
Rear
Mid
Mid
Subwoofer
Subwoofer
Subwoofer
Rear
The internal amplifier receives the same signal
as the front and rear RCA channels to allow a
2-Way or 3-Way system to be built using only an
amp for the subwoofer or rear speakers.
The crossover settings associated with these
modes are outlined as follows:
High
Items
Filter (HPF)
Slope
Phase
Range
25Hz-20kHz & Thru
6, 12 or 18dB
normal / reverse
Initial value
2 kHz
12dB
Normal
Mid
Items
Filter (LPF)
Slope (LPF)
Filter (HPF)
Slope (HPF)
Phase
Range
630Hz-10kHz & Thru
6, 12 or 18dB
25Hz-10kHz & Thru
6, 12 or 18dB
normal / reverse
Initial value
2 kHz
12dB
Through
12dB
Normal
SUB (3-Way) / (Rear 2-Way)
Items
Range
Filter (LPF)
25Hz-10kHz & Thru
Slope (LPF)
6, 12 or 18dB
Filter (HPF)
16Hz-250Hz & Thru
Slope (HPF) 6, 12 or 18dB
Phase
normal / reverse
Normal
Items
Front/Rear(HPF)
Sub (LPF)
Initial value
80Hz
12dB
Through
12dB
Normal
Front, Rear & Non-Fader
High, Mid, Low & Subwoofer
Front High, Front Low, Rear &
Subwoofer
The crossover settings associated with these
modes are outlined as follows:
Direct Mode
No crossovers active in this mode
Standard (Front 2-Way) Mode
Items
Range
High (HPF)
315Hz to 20kHz
Front (LPF)
250Hz to 20Khz & Through
Rear (HPF)
25Hz to 250Hz & Through
Sub (LPF)
25Hz to 250Hz & Through
Sub (HPF)
16Hz to 80Hz & through
Slope (ALL)
6, 12 or 18dB / Octave
Gain (ALL)
0 to -24dB
Multi Mode
Items
High (HPF)
MID (LPF)
MID (HPF)
LOW (LPF)
LOW (HPF)
Sub (LPF)
Sub (HPF)
Slope (ALL)
Gain (ALL)
Range
315Hz to 20kHz
250Hz to 20Khz & Through
200Hz to 20Khz & Through
250Hz to 10kHz & Through
25Hz to 250Hz & Through
25Hz to 250Hz & Through
16Hz to 80Hz & through
6, 12 or 18dB / Octave
0 to -24dB
Range
50/80/120Hz
50/80/120Hz
22
Performance Technologies and Features
D/A Converters
24-Bit 96kHz
Converting digitally stored information (such as
that found on a Compact Disc or DVD) back into
an analog signal is the job of the D/A Converter.
At its price point - there is nothing like the
DRZ9255 in the industry. It's not just the incredible time alignment, equalization and state of the
art hardware - its got technology too.
The D/A converter reads each 16-bit word from
the disc and assigns it an analog voltage. A conventional D/A Converter repeats this task 44,100
times a second.
The accuracy of the D/A Converter in terms of
voltage and timing are a key component to determining the sound quality capabilities and noise
output of the source unit.
1-Bit
A 1-Bit D/A converter works by comparing one bit
of information to the one previous to it. If the new
bit is higher than the previous one, it increases
the output voltage. If the new bit is lower than the
previous, then it decreases the output voltage. A
filter on the output of the D/A Converter smoothes
out the signal and the result a reproduction of the
original audio waveform.
24-Bit
Clarion source units featuring our 24-Bit D/A converter bring new realism and detail to your music.
24-Bit D/A converters offer several benefits as
compared to a conventional 1-Bit D/A converter.
Primarily, a 24-Bit D/A converter significantly increases dynamic range capability, reduces
quantization error and improves jitter. The result
is music that sounds more realistic, especially
in the high frequency range. Cymbals become
clearer and more detailed. Ambience and room
effects become more accurate. The entire listening experience takes a step forward in fidelity and
authenticity.
This effect can be clearly heard on even the most
basic of audio systems. Comparing one source
unit to another, even when using four factory
speakers will reveal a very significant improvement in performance.
23
The DRZ9255 features a 96kHz 24-Bit D/A converter. Why is this important?
The sampling rate (or how often the D/A converter
converts a digital signal back to analog) defines
the highest frequency that can be reproduced. A
conventional D/A converter operates at 44.1kHz
and as defined by the Nyquest Frequency (the
highest frequency that can be reproduced is half
of the sampling frequency). The highest frequency
that can be reproduced is 22.05kHz.
The 96kHz D/A converter in the DRZ9255 operates at twice this frequency, moving the maximum
reproducible frequency up to 48kHz.
Any time a filter is implemented in a circuit, it not
only affects frequency response, but also phase
response (the relative arrival time of different frequencies). What does this mean for the end-user?
Moving the high frequency roll-off up one octave
higher means that the DRZ9255 can reproduce
high frequencies with coherence, detail and clarity. Clarion was the first company to implement a
96kHz DAC in the car audio industry.
Frequency response of the DRZ9255 as compared
to a conventional 44.1kHz D/A Converter.
Performance Technologies and Features
High Voltage Preamp Outputs
CD Operational Safeguards
Noise is bad. From the noise of the wind whistling
past your windows to the hum of your tires on the
road, noise makes it harder for us to enjoy our
music. When it comes to music, having noise in
your system is no fun at all. Clarion offers three
step-up preamp output systems for 2008.
Clarion’s CD operational safeguards allow the CD
mechanism to detect disc size, prior disc-in-drive
detection, foreign object detection, and allow for
auto reload.
6 Volt preamp output provides a 4.5dB reduction in
noise. The DRZ9255 can provide 8Vrms of output
on it's 8 channels. This equates to 6dB less noise
from your amplifiers / system.
Clarion’s CD mechanism uses photosensors and
LEDs to identify 3" or 5" compact discs. Clarion’s
CD mechanism uses a tapered roller to precisely
center the CD onto the drive spindle.
Low Impedance Preamp Output
All Clarion preamp outputs feature low output
impedance drive circuitry. Output impedance is
most commonly looked at in terms of a resistance
measurement, in the case of Clarion preamp outputs, this specification is ~330 Ohms.
This has several effects in terms of sound quality
as compared to products that have high output
impedances (1,000+ Ohms). More of the audio
signal voltage is passed to the load device. The
preamp is capable of driving lower impedance
loads (necessary should RCA Y-cables be used).
The audio signal is less succeptable to frequency
response degradation caused by reactances in the
RCA cables or the input stage of the amplifier or
processor.
Many processors and amplifiers use DC blocking
capacitors on their inputs. When a high-impedance
source unit is connected to these loads, the bass
and treble performance can suffer. Low impedance outputs result in flatter frequency response
and more output from your amplifiers.
A tapered loading-roller precisely centers the CD
onto the drive spindle. Since the roller mechanism
is tapered, only the edges of the CD are touched,
thereby eliminating the possibility of scratches.
Tapered Roller
Touches CD Edges
CD Mechanism
These operational safeguards allow safer CD disc
handling, prevent jams from accidental loading of
two CDs, and help to reduce service problems
by detecting foreign objects in the drive mechanism.
24
Performance Technologies and Features
Zero-Bit Detector Mute
Clarion CD Players feature a zero-bit detection
mute circuit. This circuit turns off (mutes) both the
line-level and speaker-level outputs when it does
not see a digital signal for 750 milliseconds. Since
a digital signal consists of “one” and “zero” bits,
the zero-bit detector will turn off the analog audio
input signal to the preamp section when it sees a
series of zero bits. The purpose of this circuit is to
eliminate tracking noise or background noise that
is typically associated with the decoding of the
digital signal to its final analog form.
TRIGGER
ON
750 ms
ANALOG TRIGGER
OFF
OFF
57 μs
R Channel Preamp
Just as with the power ratings, Signal to Noise
(S/N Ratio) measurements will follow similar
guidelines. The S/N Ratio measurement will be
taken at a power level of 1W into a 4 Ohm load.
This means that all device measurements will
be comparable, no matter how much power the
product produces.
MOSFET Power IC
The MOSFET Power IC is smaller and more efficient than previous amplifier designs. MOSFET
amplifiers are capable of producing more power
because the output voltage can be switched
closer to the rail voltage. In a head unit, with only
12V of power being supplied from the cars electrical system, this is critically important to maximizing amplification capabilities.
The solid horizontal lines denote the positive and
negative amplifier power supply rail voltage.
Digital Data Stream 011011011011010000000000000000000000001010101001
The zero-bit detector mutes the preamplifier analog outputs after a series of zero bits exceeds
750-ms. Audio is restored after a period of one
and zero bits is longer than 57 μs.
CEA-2006 Ratings
All new Clarion amplified products have been
rated using the CEA-2006 specification. This
specification was created to allow power production numbers to be compared between one brand
and another without concern for measurement
type.
The CEA-2006 specification states that power
measured using this format will be constant
through the entire specified audio bandwidth
range. The power measurement will be taken with
14.4V being supplied and the distortion from the
output signal can't exceed 1%.
25
The smaller sine wave shows the maximum
undistorted output from a standard bipolar output
transistor.
The larger sine wave shows the maximum undistorted output from a MOSFET output device.The
net result - more voltage means more power.
Multimedia Technologies
Center Channel
Making the installation and integration of a center
channel easier than ever is the SRK604 1-DIN
center channel.
The SRK604 features a pair of 30mm dome midrange drivers and a 20mm dome tweeter. The
SRK604 also includes a 40W amplifier.
The front panel of the SRK604 offers a center
channel level control, as well as a subwoofer level
control for a pass-through RCA signal.
To help explain the concept of the center channel
operating and configuration, we have included a
basic wiring diagram.
You also have the option of running the subwoofer signal in stereo should your source unit provide
a stereo subwoofer signal. The SRK604 does not
include an electronic crossover, only a subwoofer
level control.
High Resolution LCD Displays
All Clarion LCD display screens use the latest in
active matrix technology to give you the brightest, most detailed image available. Thin Film
Transistors (TFT) are attached to each RGB, (red/
green/blue) pixel to provide more control over
the color being reproduced. This method helps
reduce display “white-wash” associated with a
conventional passive-matrix screen, and helps to
ensure optimal picture quality.
By employing a “striped pixel configuration” to
align RGB pixels into columns, we can use more
pixels to enhance details and provide better color
definition. Having the controls for brightness on
the front panel allows easy adjustment of picture
quality.
LCD Display Resolution
Clarions in-dash 7" LCD displays feature a screen
resolution of 1440 x 234 pixels for a total of
336,960 pixels. Some companies try and confuse
you by describing the number of picture elements - each of the red, green and blue picture
elements. By their standards, these units would
have 1,010,880 picture elements. When comparing video displays, make sure the specifications
you are comparing are using the same format.
26
Design & Interface Technologies
HMI Concept
Metal Shark Interface
Clarion has long been considered the industry
leader in the development and implementation of
advanced Human Machine Interface designs and
concepts. Back in 2006, Clarion took the HMI
concept to the next level and made it the focus
of the companies products. HMI refers to the
interaction, interconnection and interdependance
of man, music and machine - all while being easy
to use.
Clarion isn't satisfied to sit idly by and watch the
world go by. We are industry leaders in the development of new HMI interfaces. One of the most
distinctive interfaces to come to the mobile electronics industry is the Metal Shark Interface.
Slidetrak
Back for 2008 is the Slidetrak interface. Slidetrak
ushered in a new era in source unit operation and
control, making it easier and safer to use than
ever before.
Found on the FB275BT and FB275BTB, the
Metal Shark interface takes its look from the gills
of the great white shark. These units feature edge
lit buttons and metallic center section with a
vacuum fluorescent display and centrally located
volume control.
The FB275BT and FB275BTB break all stereotypes and define the next evolution of source unit
design.
The large acrylic panel that covers the LCD display on the DXZ585USB and DXZ785USB now
serves as your Seek Up and Seek Down (and
tracking function) control. This panel (known as
the Seek Panel) slides to the left and right to perform these functions. The days of searching for
tiny little tracking and seek buttons is gone.
A significant benefit to the end user of Slidetrak is
ease of use. With the source unit installed in their
vehicle, no longer do they need to take their eyes
off the road to change tracks or radio stations.
Simply 'poke' at the center of the radio, and your
are on to new musical experience.
728 Color Illumination
Intergration with your car means more than simply connecting to your speaker wires - it includes
control and cosmetics. Clarions 728 color illumination allows you to match the radio illumination
to the factory illumination in your car. Not only
does this mean your radio sounds better than the
one that came from the factory, but now it looks
better too!
728 Color illumination can be found on the
DXZ785USB, FB275BT, FB275BTB, UDB275MP
and DFZ675MC source units.
27
Design & Interface Technologies
Touch Panel Operation
Ease of use and intuitive operation are behind
our LCD touch panel operation - found on
the VRX785BT, VRX585USB, VRX485USB,
MAX685BT and MAX385VD. Source selection
and control, setup menus and more are accessible by a simple touch of your finger.
Add to that the ability to navigate through DVD
on-screen menus by simply touching the menu
item, and using your multimedia source unit is as
easy as can be.
Clarion 1-DIN source units are capable of being
isntalled in ISO Mount Fashion. This means, no
trim ring is required to install the radio or to have
its detachable control panel function properly and
be removeable.
ISO mounting typically means that factory style
brackets are to be used. Clarion source units feature industry standard mounting holes on the side
of the radio that align perfectly with these brackets. This reduces installation time and improves
the look of the final product.
Many new install kits make use of this ISO mounting technique, allowing radios to be installed so
they look like they belong.
An example of ISO Mounting taken to the next
level.
Dimmer Input
Safety comes in many forms - but being able
to concentrate on your driving is a fundamental
part of the HMI concept. Driving at night adds an
additional level of complexity. To make it as easy
as possible, Clarion includes a dimmer input wire
on many of our source units. When connected to
the factory dash illumination circuit, a signal on
this wire causes the deck to reduce the brightness of the radio display, preventing it from being
a distraction. Safety in the form of simplicity.
ISO Mount Capability
A product designed for easy installation makes
sense, not only for the staff performing the installation, but for the end user as well. When a radio
looks like it belongs in the dash, all the experiences surrounding its operation just seem better.
28
Design & Interface Technologies
Message Info
Amp Canceller
Personalization is always on our minds - we want
the right clothes, the right car and the right music
to match our personal style. Clarion knows this,
and has included the Message Info option as one
of the screen savers on our source units. Users
can enter a message, up to 30 characters in
length, and have it scroll across the screen.
Taking your audio system to the next level often
involves the installation of one or more external
amplifiers. If your entire system is being powered by external amplifiers, simply enable the
Amp Canceller feature on your head unit. When
Amp Canceller is engaged, power to the internal
amplifier IC is turned off. This reduces the current
draw of the source unit and improves its sonic
performance.
Instant Station Recall (ISR)
Getting to where you want to go should always
be as easy as simply pressing a button. When it
comes to your favorite radio station, ISR has you
covered. Tune in your favorite radio station, then
press and hold the ISR button. You can choose
AM or FM - it doesn't care. Now, any time you
want, no matter what source you are listening to,
a simple tap of the ISR will return you the programmed radio station.
This is a great feature to use on all-news radio
stations when you want up-to-the-minute traffic
reports.
Key Off Eject
Have you ever forgotten to bring your favorite
CD into the house after arriving home from a trip.
With Clarion's Key Off Eject feature - the disc
eject function works, even when the ignition isn't
turned on. Press eject and the disc pops out.
Last Position Memory
As CD players started to become popular, many
people started to experience inherent drawbacks of this random access storage media. With
a cassette tape - it stays where you left it when
you shut off the power. Then, when you turn it
back on, playback resumes from that same point.
With Clarion's Last Position Memory - the same
is true for your CD player. Turn the car off, do your
shopping, then get back in. Your music picks up
where you left off.
29
Multimedia
Multimedia
MAX685BT
2-DIN DVD MULTIMEDIA STATION WITH TOUCH
PANEL CONTROL
• Motorized sloping control panel with 7-inch QVGA Colour
LCD touch sensitive display
• DVD-Video, DVD, DVD±R/W, CD, CD-R/RW ready
• MP3/WMA/AAC Compatible with ID3-TAG display
• Official DivX® Certified product
• Plays all versions of DivX® video (including DivX® 6) with
standard playback of DivX® media files
• Rear USB connector
• USB WMDRM10 compatible
• Built-in Bluetooth® Hands-free (HFP & OPP) and Audio
Streaming (A2DP & AVRCP)
• Direct USB iPod Audio
• iPod Video Ready (CCA723 Required)
• XM® Mini-Tuner Direct Connection Ready
• CeNET Control of HDD Navigation (NAX980HD/
NAX970HD)
• RGB input for navigation
• 2-Zone entertainment: Front and Rear independent source
control
• Built-in LPF/HPF
• Subwoofer level control
• 24-Bit D/A converter
• 3-band parametric equalizer
• MAGNA BASS EX
• 6 ch RCA output and 2 ch RCA output for 2-Zone
• 1 AUX AV input (2 ch Audio + Video)
• Rear-view Camera input
• 50 W × 4 MOS-FET Amplifier
• DSP AM/FM Tuner w/ 18 FM/6AM presets
• Optional 3rd party OEM Steering Wheel Remote Ready
• Built-in IR Eye (RCB198 Remote Control Included)
31
General Specifications
Power Requirement:
Current Consumption:
Weight:
Dimensions (w x h x d):
10.8 - 15.6 V
4.0A
2.6kg
7" x 3-15/16" x 6-5/16"
DVD Specifications
Frequency Response:
S/N Ratio:
Dynamic Range:
Distortion:
20Hz - 20kHz
100 dB (1kHz)
100 dB (1 kHz)
0.006%
Audio Input/Output Specifications
Audio Input Voltage:
Audio Input Voltage:
Audio Input Voltage:
Audio Output Voltage:
Audio Output Impedance:
Video Input Voltage:
Video Output Voltage:
130 mVrms (Low)
600 mVrms (Med)
840 mVrms (High)
2.0V
330 Ohms
1.0 Vp-p @ 75 Ohms
1.0 Vp-p at 75 Ohms
LCD Screen Specifications:
Screen Size:
Pixels:
Resolution:
7" Wide Type
336,960
1440 x 234
Audio Amplifier Specifications
Rated Power Output:
Maximum Power Output:
Minimum Speaker Impedance:
20W x 4 CEA-2006
50W x 4
4 Ohms
FM Tuner Specifications:
Frequency Range:
Usable Sensitivity:
50dB Quieting:
Alternate Channel Selectivity:
Stereo Separation:
Frequency Response:
87.9 MHz - 107.9 MHz
9 dBf
15 dBf
70 dB
32 dB (1kHz)
30Hz to 15kHz
AM Tuner Specifications:
Frequency Range:
Useable Sensitivity:
530 kHz to 1710 kHz
28dBuV
iPod Interface Cables:
Audio only:
Video and Audio:
Direct USB
CCA723
Multimedia
MAX385VD
2-DIN DVD MULTIMEDIA STATION WITH TOUCH
PANEL CONTROL
• 6.5-inch QVGA Colour LCD Monitor
• Touch Panel Control
• DVD-Video, DVD, DVD±R/W, CD, CD-R/RW Ready
• MP3/WMA Compatible with ID3-TAG Display
• 18 FM / 6 AM Station Presets
• Phone Mute
• iPod® Direct Connection and Control (Optional
CCUIPOD1 Cable required)
• Sirius®SSP Direct Connection Ready
• 24-Bit D/A Converter
• 6 ch RCA Output (Front + Rear +Subwoofer)
• 40 W × 4 Built-in Amplifier
• Rotary Volume Control
• Built-in IR Eye and Remote Control Included
• Rear Audio and Visual Input
• Rear AV Output
• Low-Pass Filter & Sub Level Control
General Specifications
Power Requirement:
Current Consumption:
Weight:
Dimensions (w x h x d):
10.8 - 15.6 V
4.0A
2.6kg
7" x 3-15/16" x 6-5/16"
DVD Specifications
Frequency Response:
S/N Ratio:
Dynamic Range:
Distortion:
20Hz - 20kHz
100 dB (1kHz)
100 dB (1 kHz)
0.006%
Audio Input/Output Specifications
Audio Input Voltage:
Audio Input Voltage:
Audio Input Voltage:
Audio Output Voltage:
Audio Output Impedance:
Video Input Voltage:
Video Output Voltage:
130 mVrms (Low)
600 mVrms (Med)
840 mVrms (High)
2.0V
330 Ohms
1.0 Vp-p @ 75 Ohms
1.0 Vp-p at 75 Ohms
LCD Screen Specifications:
Screen Size:
Pixels:
Resolution:
7" Wide Type
336,960
1440 x 234
Audio Amplifier Specifications
Rated Power Output:
Maximum Power Output:
Minimum Speaker Impedance:
19W x 4 CEA-2006
50W x 4
4 Ohms
FM Tuner Specifications:
Frequency Range:
Usable Sensitivity:
50dB Quieting:
Alternate Channel Selectivity:
Stereo Separation:
Frequency Response:
87.9 MHz - 107.9 MHz
9 dBf
15 dBf
70 dB
32 dB (1kHz)
30Hz to 15kHz
AM Tuner Specifications:
Frequency Range:
Useable Sensitivity:
530 kHz to 1710 kHz
28dBuV
iPod Interface Cables:
iPod Video cable (Audio and Video)
CCA691
32
Multimedia
VRX785BT
1-DIN DVD MULTIMEDIA STATION WITH TOUCH
PANEL CONTROL
• Motorized Flip-out control panel with 7-inch QVGA Colour
LCD touch sensitive display
• DVD-Video, DVD, DVD±R/W, CD, CD-R/RW ready
• MP3/WMA/AAC Compatible with ID3-TAG display
• Official DivX® Certified product
• Plays all versions of DivX® video (including DivX® 6) with
standard playback of DivX® media files
• Rear USB connector
• USB WMDRM10 compatible
• Built-in Bluetooth® Hands-free (HFP & OPP) and Audio
Streaming(A2DP & AVRCP)
• Direct USB iPod Audio
• iPod Video Ready (CCA723 Required)
• XM® Mini-Tuner Direct Connection Ready
• CeNET Control of HDD Navigation (NAX980HD/
NAX970HD) • RGB input for navigation
• 2-Zone entertainment: Front and Rear independent
source control
• Built-in LPF/HPF
• Subwoofer level control
• 24-Bit D/A converter
• 3-band parametric equalizer
• MAGNA BASS EX
• 6 ch RCA output and 2 ch RCA output for 2-Zone
• 1 AUX AV input (2 ch Audio + Video)
• Rear-view Camera input
• 50 W × 4 MOS-FET Amplifier
• DSP AM/FM Tuner w/ 18 FM/6AM presets
• Optional 3rd party OEM Steering Wheel Remote Ready
• Built-in IR Eye (RCB198 Remote Control Included)
33
General Specifications
Power Requirement:
Current Consumption:
Weight:
Dimensions (w x h x d):
10.8 - 15.6 V
4.0A
2.4kg
7" x 1-15/16" x 6-1/2"
DVD Specifications
Frequency Response:
S/N Ratio:
Dynamic Range:
Distortion:
20Hz - 20kHz
75 dbA (1 Watt Ref)
100 dB (1 kHz)
0.01%
Audio Input/Output Specifications
Audio Input Voltage:
Audio Input Voltage:
Audio Input Voltage:
Audio Output Voltage:
Audio Output Impedance:
Video Input Voltage:
Video Output Voltage:
130 mVrms (Low)
600 mVrms (Med)
840 mVrms (High)
2.0V
330 Ohms
1.0 Vp-p @ 75 Ohms
1.0 Vp-p at 75 Ohms
LCD Screen Specifications:
Screen Size:
Pixels:
Resolution:
7" Wide Type
336,960
1440 x 234
Audio Amplifier Specifications
Rated Power Output:
Maximum Power Output:
Minimum Speaker Impedance:
19W x 4 CEA-2006
50W x 4
4 Ohms
FM Tuner Specifications:
Frequency Range:
Usable Sensitivity:
50dB Quieting:
Alternate Channel Selectivity:
Stereo Separation:
Frequency Response:
87.9 MHz - 107.9 MHz
9 dBf
15 dBf
70 dB
35 dB (1kHz)
30Hz to 15kHz)
AM Tuner Specifications:
Frequency Range:
Useable Sensitivity:
530 kHz to 1710 kHz
28dBuV
iPod Interface Cables:
Audio only:
Video and Audio:
Direct USB
CCA723
Multimedia
VRX585USB
1-DIN DVD MULTIMEDIA STATION WITH 7-INCH
TOUCH PANEL CONTROL
• Fully Motorized 7-inch TFT Colour LCD Monitor
• Touch Panel Control
• DVD, DVD±R/W, CD, CD-R/RW ready
• MP3 and WMA and iTunes® AAC (only USB) Compatible
with ID3-TAG display
• Official DivX® Certified product
• Plays All Versions of DivX® Video (including DivX® 6)
with Standard Playback of DivX® Media Files
• Rear USB Connector
• iPod Direct Connection and Control (Optional CCA691
Cable Required)
• Shock Proof Memory
• 24-Bit D/A Converter
• Subwoofer Level Control
• 2-Zone Entertainment: Front and Rear Independent
Source Control
• Z-Enhancer Plus sound customization
• 2-band Parametric Equalizer
• MAGNA BASS EX
• Built-in LPF/HPF
• Built-in Amplifier Canceller
• 18 FM/12 AM Presets
• 50W×4 MOS-FET Amplifier
• Adjustable Display Brightness
• A/V Input with Level Control
• 6ch RCA Output
• Optional 3rd party OEM Steering Wheel Remote Ready
• Bluetooth® Interface Ready (Optional BLT370)
• Detachable Control Panel
General Specifications
Power Requirement:
Current Consumption:
Weight:
Dimensions (w x h x d):
10.8 - 15.6 V
4.0A
2.4kg
7" x 1-15/16" x 6-1/2"
DVD Specifications
Frequency Response:
S/N Ratio:
Dynamic Range:
Distortion:
20Hz - 20kHz
75 dbA (1 Watt Ref)
100 dB (1 kHz)
0.01%
Audio Input/Output Specifications
Audio Input Voltage:
Audio Input Voltage:
Audio Input Voltage:
Audio Output Voltage:
Audio Output Impedance:
Video Input Voltage:
Video Output Voltage:
130 mVrms (Low)
600 mVrms (Med)
840 mVrms (High)
2.0V
330 Ohms
1.0 Vp-p @ 75 Ohms
1.0 Vp-p at 75 Ohms
LCD Screen Specifications:
Screen Size:
Pixels:
Resolution:
7" Wide Type
336,960
1440 x 234
Audio Amplifier Specifications
Rated Power Output:
Maximum Power Output:
Minimum Speaker Impedance:
19W x 4 CEA-2006
50W x 4
4 Ohms
FM Tuner Specifications:
Frequency Range:
Usable Sensitivity:
50dB Quieting:
Alternate Channel Selectivity:
Stereo Separation:
Frequency Response:
87.9 MHz - 107.9 MHz
9 dBf
15 dBf
70 dB
35 dB (1kHz)
30Hz to 15kHz)
AM Tuner Specifications:
Frequency Range:
Useable Sensitivity:
530 kHz to 1710 kHz
28dBuV
iPod Interface Cable:
iPod Video cable (Audio and Video)
CCA691
34
Multimedia
VRX485VD
1-DIN DVD MULTIMEDIA STATION WITH 7-INCH
TOUCH PANEL CONTROL
• Fully Motorized 7-inch QVGA Colour LCD Monitor
• Touch Panel Control
• DVD-Video, DVD, DVD±R/W, CD, CD-R/RW ready
• MP3/WMA Compatible with ID3-TAG Display
• 18 FM / 6 AM Station Presets
• iPod® Direct Connection and Control (Optional CCUIPOD1
Cable Required )
• Seek Manual Up/Down
• Adjustable Display Brightness
• Display Tilt Angle: 5 Positions
• Sirius® SSP Direct Connection Ready
• 24-Bit D/A Converter
• RCA Visual Input
• 6ch RCA Output
• 40 W × 4 Amplifier
• Built-in IR Eye and Remote Control Included
• Low-Pass Filter & Sub Level Control
35
General Specifications
Power Requirement:
Current Consumption:
Weight:
Dimensions (w x h x d):
10.8 - 15.6 V
4.0A
2.4kg
7" x 1-15/16" x 6-1/2"
DVD Specifications
Frequency Response:
S/N Ratio:
Dynamic Range:
Distortion:
20Hz - 20kHz
75 dbA (1 Watt Ref)
100 dB (1 kHz)
0.01%
Audio Input/Output Specifications
Audio Input Voltage:
Audio Input Voltage:
Audio Input Voltage:
Audio Output Voltage:
Audio Output Impedance:
Video Input Voltage:
Video Output Voltage:
130 mVrms (Low)
600 mVrms (Med)
840 mVrms (High)
2.0V
330 Ohms
1.0 Vp-p @ 75 Ohms
1.0 Vp-p at 75 Ohms
LCD Screen Specifications:
Screen Size:
Pixels:
Resolution:
7" Wide Type
336,960
1440 x 234
Audio Amplifier Specifications
Rated Power Output:
Maximum Power Output:
Minimum Speaker Impedance:
19W x 4 CEA-2006
50W x 4
4 Ohms
FM Tuner Specifications:
Frequency Range:
Usable Sensitivity:
50dB Quieting:
Alternate Channel Selectivity:
Stereo Separation:
Frequency Response:
87.9 MHz - 107.9 MHz
9 dBf
15 dBf
70 dB
35 dB (1kHz)
30Hz to 15kHz)
AM Tuner Specifications:
Frequency Range:
Useable Sensitivity:
530 kHz to 1710 kHz
28dBuV
iPod Interface Cable:
iPod Video cable (Audio and Video)
CCA691
Multimedia
VRX385USB
1-DIN DVD MULTIMEDIA STATION WITH 3.5-INCH
DISPLAY
• Motorized Sloping Control Panel with 3.5-inch TFT Colour
LCD Monitor
• DVD, DVD±R/W, CD, CD-R/RW Ready
• MP3, WMA and iTunes® AAC (via USB) Compatible with
ID3-TAG Display
• Official DivX® Certified Product
• Plays All Versions of DivX® Video (Including DivX® 6)
with Standard Playback of DivX® Media Files
• Rear USB Connector
• 50 W x 4 MOS-FET Amplifier
• iPod® Direct Connection and Control (Optional CCA691
Cable required)
• Shock Proof Memory
• 24-Bit D/A Converter
• Subwoofer Level Control
• 2-Zone Entertainment: Front and Rear Independent
Source Control
• Z-Enhancer Plus sound customization
• 2-band Parametric Equalizer
• MAGNA BASS EX
• Built-in LPF/HPF
• Amplifier Canceler
• Adjustable Display Brightness
• Detachable Control Panel
• A/VInput with Level Control
• 6 ch / 2V RCA Output
• 18 FM/12 AM Presets
• CCD Camera RCA Input
• Optional 3rd party OEM Steering Wheel Remote Ready
• Bluetooth® Interface Ready (Optional BLT370)
General Specifications
Power Requirement:
Current Consumption:
Weight:
Dimensions (w x h x d):
10.8 - 15.6 V
4.0A
2.4kg
7" x 1-15/16" x 6-1/2"
DVD Specifications
Frequency Response:
S/N Ratio:
Dynamic Range:
Distortion:
20Hz - 20kHz
75 dbA (1 Watt Ref)
100 dB (1 kHz)
0.01%
Audio Input/Output Specifications
Audio Input Voltage:
Audio Input Voltage:
Audio Input Voltage:
Audio Output Voltage:
Audio Output Impedance:
Video Input Voltage:
Video Output Voltage:
130 mVrms (Low)
600 mVrms (Med)
840 mVrms (High)
2.0V
330 Ohms
1.0 Vp-p @ 75 Ohms
1.0 Vp-p at 75 Ohms
LCD Screen Specifications:
Screen Size:
Pixels:
Resolution:
3.5" Wide Type
336,960
1440 x 234
Audio Amplifier Specifications
Rated Power Output:
Maximum Power Output:
Minimum Speaker Impedance:
19W x 4 CEA-2006
50W x 4
4 Ohms
FM Tuner Specifications:
Frequency Range:
Usable Sensitivity:
50dB Quieting:
Alternate Channel Selectivity:
Stereo Separation:
Frequency Response:
87.9 MHz - 107.9 MHz
9 dBf
15 dBf
70 dB
35 dB (1kHz)
30Hz to 15kHz)
AM Tuner Specifications:
Frequency Range:
Useable Sensitivity:
530 kHz to 1710 kHz
28dBuV
iPod Interface Cable:
iPod Video cable (Audio and Video)
CCA691
36
Multimedia
VB475
VS755
AM/FM DVD RECEIVER
1-DIN IN-DASH DVD/CD/MP3 PLAYER
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
DVD-R/RW. DVD+R/RW, CD-R/RW Ready
MP3/WMA Compatible
18FM / 12AM presets
24-Bit D/A Converter
12-Character Dot Matrix LCD Display
6 Channel preamp output
Subwoofer Level Control
45W x 4 Amplifier
2 Composite Video outputs
IR Remote Control
Detachable Control Panel
General Specifications
Power Requirement:
10.5-15V
Power Supply:
DC, negative ground
Operating Current Consumption (MAX): 10A
General Specifications
Power Requirement:
Current Consumption:
Weight:
Dimensions (w x h x d):
DVD Specifications
Format:
Audio Specifications
S/N Ratio
Dynamic Range:
Output Power:
Load Impedance
THD
Input Level (max):
Output Level (max):
Video Input Level
80 dB
80 dB
25W x 4
4 Ohms
<1%
2V
2V
1Vp-p at 75 Ohms
Tuner Specifications
Useable FM Sensitivity:
FM Frequency response:
FM S/N Ratio
AM Useable Sensitivity
AM S/N Ratio
20 dBu
60 Hz - 14kHz
55 dB
36dBu
43dB
DVD Specifications
Region Number:
S/N Ratio
Dynamic Range:
Distortion:
1
90 dB
90 dB
0.05%
37
One-DIN In-Dash DVD Player
Plays DVD Video, CD Audio, and MP3 Encoded CD-R/RW
CD-R/CD-RW Playback
Adjustable Audio Gain Controller
2 A/V inputs (including front panel)
1 A/V Output
24-Bit D/A Converter
IR Remote Control
ID3 Tag for MP3 Titles
Video System:
Audio System:
Mounting Angle:
Video Specifications
Output Level:
Video System:
11-16V
Less than 3.0 A
3.5 lb
7" x 2" x 6-5/8"
DVD-Video Disc
(Two Layer, Two Side)
Standard NTSC
MP3 I, MP3 II
0 to +/- 30 degrees
Video Input Terminal:
1.0 V, 75 ohms
16:9 Letter Box,
4:3 Pan Scan
0.5 - 2.0 V, 75 ohms
Audio Specifications
Maximum Output:
Frequency Response:
S/N Ratio (A-wtd):
Separation:
1.0 V
20 Hz to 20 kHz
85 dB
>70 dB
Multimedia
VMA770
VMA5096
7" WIDE-SCREEN HEADREST COLOR LCD
MONITOR
5" WIDE-SCREEN HEADREST COLOR LCD
MONITOR
•
•
•
•
•
Slim, Easy-Fit Universal Mounting Bracket (Included)
TFT Active Matrix Display With 16:9/4:3 Format
On-Screen Display (OSD)
Two A/V Inputs
Built-In Dual IR Audio Transmitter for (Optional) WH204
Headphones
• Built-In IR Receiver for pass-through
• Front Panel Controls for Power, Source, and Picture
• Auto Turn-On/Off with Ignition
•
•
•
•
•
Specifications
Power Requirement:
Current Consumption:
Pixels:
Resolution:
Video input level (RCA)
Video Format
LCD Type:
Screen Size:
Weight:
Dimensions (w x h x d):
Mounting Dimensions:
Specifications
Power Requirement:
Current Consumption:
Pixels:
Resolution:
Video input level (RCA)
Video Format
LCD Type:
Screen Size:
Weight:
Dimensions (w x h x d):
Mounting Dimensions:
11-16V
0.6 A
336,960
1,440 x 234
1.0V p-p
NTSC / PAL
Colour TFT, Active Matrix
7"
350g
7-1/8 x 5-3/16" x 1-1/16"
8" x 6" x 1"
Slim, Easy-Fit Universal Mounting Bracket (Included)
TFT Active Matrix Display With 16:9/4:3 Format
On-Screen Display (OSD)
Two A/V Inputs
Built-In Dual IR Audio Transmitter for (Optional) WH204
Headphones
• Built-In IR Receiver for pass-through
• Front Panel Controls for Power, Source, and Picture
• Auto Turn-On/Off with Ignition
11-16V
0.6 A
211,200
960 x 234
1.0V p-p NTSC
NTSC / PAL
Colour TFT, Active Matrix
5"
300g
5-3/8" x 4-1/8" x 1-1/16"
7-1/8" x 5-3/8" x 1"
38
Multimedia
OHM1575VD
OHM1075VD
15.4" OVERHEAD ENTERTAINMENT CENTER
10.2" OVERHEAD ENTERTAINMENT CENTER
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
15.4" Active Matrix TFT LCD Display
Integrated DVD / CD Mechanism
Front Panel Controls
Infrared Remote Control
Infrared Audio Transmitter
Slim Mounting Profile
MPEG 1, 2 & 4 Compatible
MP3 and WMA Playback
2 A/V Inputs
1 A/V Output
Built-In LED Dome Light
On Screen Menu Display
Adjustable Display Modes: Wide / Normal
2 Sets IR Wireless headphones
10.2" Active Matrix TFT LCD Display
Integrated DVD / CD Mechanism
Front Panel Controls
Infrared Remote Control
Infrared Audio Transmitter
Slim Mounting Profile
MPEG 1, 2 & 4 Compatible
MP3 and WMA Playback
2 A/V Inputs
1 A/V Output
Built-In LED Dome Light
On Screen Menu Display
Adjustable Display Modes: Wide / Normal
2 Sets IR Wireless headphones
General Specifications
Power Requirement:
Power Supply:
Operating Current Consumption:
Maximum Current Consumption:
Video System:
Video Signal:
Resolution:
Viewing Angle (up/down/left/right):
Display Swivel Angle:
Operating Temperature:
Storage Temperature:
Dome Light Power:
10-16V
DC, negative ground
<1.5A
<2.0A
NTSC and PAL
1.0Vp-p, 75-Ohm Load
1024 x 768
10/30/40/40
0-180 degrees
-5 - 55 degree C
-20 - 70 degrees C
2 Watts
General Specifications
Power Requirement:
Power Supply:
Operating Current Consumption:
Maximum Current Consumption:
Video System:
Video Signal:
Resolution:
Viewing Angle (up/down/left/right):
Display Swivel Angle:
Operating Temperature:
Storage Temperature:
Dome Light Power:
10-16V
DC, negative ground
<1.5A
<2.0A
NTSC and PAL
1.0Vp-p, 75-Ohm Load
800 x 480
45/65/65/65
0-180 degrees
-5 - 55 degree C
-20 - 70 degrees C
2 Watts
Physical Specifications
Dimensions (closed):
Dimensions (open):
Weight:
15.25" x 13.75" x 2.5"
15.25" x 13.75" x 13"
6.1 Lbs
Physical Specifications
Dimensions (closed):
Dimensions (open):
Weight:
11.1" x 9.625" x 2"
11.1" x 9.625" x 8.75"
5.0 Lbs
Replacement Headphones:
WH114H
Replacement Headphones:
WH114H
39
Multimedia
OHM875VD
SRK604
8.0" OVERHEAD ENTERTAINMENT CENTER
1-DIN CENTER CHANNEL SPEAKER WITH AMPLIFIER
•
•
•
•
•
•
•
•
•
•
•
•
•
•
8" Active Matrix TFT LCD Display
Integrated DVD / CD Mechanism
Front Panel Controls
Infrared Remote Control
Infrared Audio Transmitter
Slim Mounting Profile
MPEG 1, 2 & 4 Compatible
MP3 and WMA Playback
2 A/V Inputs
1 A/V Output
Built-In LED Dome Light
On Screen Menu Display
Adjustable Display Modes: Wide / Normal
IR Wireless headphone
General Specifications
Power Requirement:
Power Supply:
Operating Current Consumption:
Maximum Current Consumption:
Video System:
Video Signal:
Resolution:
Viewing Angle (up/down/left/right):
Display Swivel Angle:
Operating Temperature:
Storage Temperature:
Dome Light Power:
10-16V
DC, negative ground
<1.5A
<2.0A
NTSC and PAL
1.0Vp-p, 75-Ohm Load
800 x 480
45/65/65/65
0-180 degrees
-5 - 55 degree C
-20 - 70 degrees C
2 Watts
Physical Specifications
Dimensions (closed):
Dimensions (open):
Weight:
10.375" x 8.875" x 1.75"
10.375" x 8.875" x 7.75"
4.4 Lbs
Replacement Headphones:
WH114H
• Compact speaker for 1-Din in-dash or Surface Mount
Applications
• Two 30mm PEI parabolic dome midrange drivers
• One 20mm PEI parabolic dome tweeter
• 40W Amplifier
• Front panel level control
• Front panel pass-through subwoofer level control
General Specifications
Power Requirement:
Current Consumption:
DC14.4V
2.5A
Amplifier Specifications
Frequency Response:
Signal to Noise Ratio:
Distortion:
Power Output (JEITA):
Power Output (1kHz, 1%):
Input Sensitivity:
Dimensions (mm):
Weight:
20 Hz to 50 kHz
85 dB
0.05%
40W
20W
300mV - 7.5V
152 x 25 x 68
330g
Speaker Specifications
Max Power Handling:
Continuous Power Handling:
Efficiency:
Frequency response:
Dimensions (mm):
Weight:
50W
20W
92dB
200Hz - 35kHz
171 x 47 x 29
190g
40
Multimedia
VA700
MSS430
VIDEO DISTRIBUTION AMPLIFIER
SOURCE COMMANDER A/V SWITCHER
• 1 Composite Video input
• 7 Composite Video outputs
•
•
•
•
General Specifications
Power Requirement:
Power Supply:
Maximum Current Consumption:
Max Power Consumption:
Video Signal:
Bandwidth:
Physical Specifications
Dimensions:
41
10.8 - 15.6V
DC, negative ground
240 mA
3.3W
1.0Vp-p, 75-Ohm Load
5Hz - 10 MHz
3 A/V inputs
4 A/V outputs
3 Wired Control Stations
Rear Camera reverse trigger input
General Specifications
Power Requirement:
Power Supply:
Maximum Current Consumption:
11 - 16V
DC, negative ground
1.6 A
Audio Specifications
Frequency Response:
S/N Ratio:
30Hz - 25kHz
60dB
Video Specifications
Output Level:
Frequency Response:
Video Gain:
Input Impedance:
1.0Vp-p
39Hz - 5.5 MHz
0dB (+/- 2dB)
75 Ohm
Physical Specifications
Dimensions (main unit):
Dimensions (Control Station)
Control station mounting hole:
9.84" x 1.06" x 5.24"
2.6" x 1.7" x 0.60"
1.9" x 2.8"
5/6" x 5-1/8" x 3-1/4"
Multimedia
TTX005
CK625E
STAND ALONE TV TUNER
REAR VISION COLOR CAMERA KIT
•
•
•
•
•
•
Kit Inlcudes:
• Reverse Image Color Camera (CC2011E)
• Camera Power Supply With Reverse Trigger Input (CAA185)
• 23’ Weather Resistant Camera Cable (MF23RM)
IR Remote Control
Plug-In IR Remote Receiver
Stereo Audio Output
Composite Video Output
4-Channel Diversity Antenna Input
Requires External Antenna(e)
Specifications
Power Requirement:
Current Consumption:
Operational Temperature:
Storage Temperature:
11-16V
Less than 250 mA
41 to 104 degrees F
-4 to 140 degrees F
General Specifications
Video Output Level:
Audio Output Level:
Channels Reception:
Antenna Input:
Video System:
1.2 V
140 mV
2 to 65
75 ohms (3.5 mm plugs)
NTSC
Antenna is Required
ZCB-003:
Thru-Glass Mono-Pole Car TV Antenna
ZCB-301:
On-Glass Mono-Pole Car TV Antenna
ZCB-303:
On-Glass Mono-Pole Car TV Antenna
CC1030E (Rear Vision Color Camera)
• Reverse Image Color Camera
• Wide-Angle Lens (115° Wide X 88° Vertical)
• Weather Resistant Aluminum Case
• Low Light Sensitivity (3 Lux)
• High Resolution 1/4” CCD Element
• 250,000 Pixel Count
• Waterproof Mini-Din Connection System
• Operating Temperature: -4°F - 140°
• Dimensions: 1 7/8” (W) X 1 3/8” (H) X 1 3/4” (D)
CAA-185 (Rear Vision Camera Power Supply)
• Selectable Full-Time Camera Operation
• Composite Video Output
• Dimensions: 3 5/8” (W) X 1 3/8” (H) X 2 (D)
MF23RM (23’ Weather Resistant Camera Cable)
• 23’ Weather Resistant Insulated Cable
• Waterproof Mini-DIN Connection System
42
Multimedia
Wireless Headphones
WH104
IR Wireless Headphone System (Two Headphones and
Transmitter)
WH114H
Replacement Headphone for Overhead Monitors and as
WH104 Additional Headphones
WH204
2-Source Wireless IR headphone System
FM200
FM MODULATOR
WH204H
Replacement headphone for the WH204 - including
OHMD74 and OHMD102
• 2-Channel RCA Audio Input
• On/Off Switch
• Input Level Control
• 2 Modulating Frequencies (88.7MHz & 89.1MHz)
• Motorola-Style Antenna input and output connectors
WH105
RF Wireless headphone system
WH105H
Replacement headphone for WH105
FM700W
WIRELESS FM MODULATOR
• 2-Channel RCA Audio Input
• On/Off Switch
• Input Level Control
• 8 Modulating Frequencies (see chart below)
43
1
2
3
4
A
107.9
107.7
107.5
107.3
B
88.9
88.7
88.5
88.3
Navigation
Navigation – EZD580
Specifications
Operating System:
Processor:
EZD580
TRANSPORTABLE NAVIGATION SYSTEM
Features
• 4.3” Color Monitor Touch Panel Control
• Built-in Bluetooth Hands-free (HFP) and Audio Streaming
(A2DP & AVRCP)
• Coverage of Entire USA and Canada
• Easy to Use New Navigation Engine
• 12 Million Points of Interest with Icons
• FM RDS-TMC Traffic Service Ready (Optional NAVRDS
and Subscription Required)
• TTS (Text to Speech) Announces Street Names
• 2GB Flash Memory (Map Data Pre-Loaded)
• SiRF GPS III Module with 20-channel GPS Receiver
• Built-in Loudspeaker
• USB 2.0 Connection for Updating and Charging
• Rechargeable Battery Lasts up to 4 Hours
• 2D and 3D Map Views
• Lane and Signpost Info
• Automatic Route Recalculation
• Simple Destination Input
Entertainment
• SD/MMC-Card Slot for MP3/WMA Playback and
Supports SDHC (Up To 4GB Memory Card)
• JPEG Picture Viewer / Slideshow
• 3.5mm External Headphone Connector
Mobility
• Windshield / Dash Mount and Stylus Pen Included
• USB Cable and Car Charger Included
45
Windows CE 5.0
Samsung 2443 400MHz
Built-in 64 MB RAM
2GB Flash Memory
Storage Temperature:
-20~60ºC
SD/MMC Slot:
4GB SD Card max
Display Type:
4.3" TFT Touch screen
Display Resolution:
480 x 272 Color Transflective LCD
with Touch Panel (Samsung)
Weight:
0.45 lbs
Dimensions:
No Cradle:
5-1/8" (W) x 3-1/2" (H) x 3/4" (D)
Accessories:
• NAVDC DC Power Adapter
• NAVMOUNT3 Suction Cup & Mounting Bracket
• NAVRDS Traffic Message Channel Module
http://www.realtimetraffic.net
Navigation – NAX980HD
Specifications:
GPS Antenna Mode:
Antenna Impedance:
GPS receiving frequency:
Sensitivity:
NAX980HD
CENET HDD NAVIGATION SYSTEM
• 40GB Built-in High Speed Hard Disk Drive
• Built-in Gyro Sensor
• Touch-screen Operation
• Navteq and Info USA Mapping Coverage of USA and
Canada
• Comprehensive 10M Points of Interest Database
• Audible Voice Commands in 3 Different Languages
(English / French / Spanish)
• Turn-by-Turn Voice Prompts
• Personalized 3D Frequent and Favorites menu
• 3D Menu and Junction View
• High Speed and Accurate Search
• Adaptive Route Learning
• Dedicated Central and Graphic Processing Unit
• Quick Route Calculation and Recalculation
• Quick Access to Shortcut menu
• Front Panel USB Port
• External GPS Antenna Included
Voice synthesis:
Sampling frequency;
Power Supply voltage:
Ground:
Current Consumption:
Dimensions:
Main unit:
Antenna:
Microstrip Flat
50 ohm
1575.42 MHz, C/A Code
-130 dBm or better
15 GPS Channels
ADPCM
11.025 kHz
DC 14V
Negative
Less than 3.0 A
205 (W) x 29.5 (H) x 169 (D) mm
30.4 (W) x 11.7 (H) x 35.5 (D) mm
Required Connections:
Power and Ground
GPS Antenna (supplied)
CeNET
Vehicle Speed Sensor (VSS)
Parking Brake
Reverse Light
Compatible with: MAX675VD, MAX675VDII, MAX685BT,
VRX775VD, and VRX785BT
(Sold Separately)
46
Navigation
Clarion Navigation
Clarion has long been considered a world leader
in the development of mobile navigation systems.
From the revolutionary Auto PC and Joyride to
the EZD580 and NAX - Clarion's navigation products have always stood out in the crowd, offering
features and performance second to none.
EZDrive is the epitome of our HMI slogan, integrating Man, Music and Machine into a friendly,
easy to use package.
Portable Navigation - EZD580
Interface
A 4.3-inch TFT LCD display combined with a
touch screen overlay makes viewing and working with your EZD580 is easier than ever. We've
even include a stylus to make entering data entry
quicker and easier. The EZD580 even has a place
to store the stylus when not in use. Day and Night
modes make viewing the EZD580 bright and
clear during the day, but not distracting at night.
Turn by Turn voice prompts provide all the information you need - and it works in English, French
and Spanish.
Portability
The EZD580 sets a new standard for portable
navigation. The EZD580 is fully portable with a
built-in Lithium Ion battery cell and integrated
20-channel SiRF III GPS receiver. You can use it
in your car, on your bike or even in your hands as
you walk down the street.
Configurable
The EZD580 does what you want, the way you
want it. You can tilt the map to view it in 3D mode,
tell it to avoid toll roads or plot a route with multiple way points. The ability to make the EZD580
look and behave the way you want is nearly endless.
Bluetooth
The EZD580 features a Bluetooth 2.0 interface to
make hands-free cell phone operation easy. You
can even dial your phone from the EZD580 and
communicate through it's built-in microphone.
Speed
The EZD580 features a 400 MHz RISC CPU, the
Microsoft Windows CE NET 5.0 Core operating
system and 2GB of on-board flash memory . This
means that entering your destination and making route calculations is blazingly fast. Even map
scrolling and zooming is taken to a new level of
speed and accuracy.
Quick Setup
The EZD580 ships with a windshield mounting
bracket, a suction cup mounting plate and a car
charger. Put the EZD580 in place and power it
up - that's all it takes get you out on the road and
headed to your destination.
47
Navigation
Audio Player
The Suction Cup Mounting Solution
The EZD580 includes an advanced audio player,
ready to bring your MP3 files to life. The player
includes a built-in equalizer and athe provided
headphone jack means that your EZD580 can
also be your portable media player. Simply copy
your MP3 files to an SD or MMC card, pop it in
and enjoy.
All your customer needs to do is pick a location
on the windshield. Stick the suction cup to the
desired location, press the air-release button, and
then pull back the small lever to lock the mount
into place. This mount also offers two adjustment
points, allowing users to easily dial in the correct
angle.
You can move EZD580 from one car to another
and be on the road in less time than it takes to fill
your cars gas tank.
Built-In Speaker
Picture Viewer
Do you have a digital camera? Want to show your
friends the pictures from your last vacation or the
car show you went to on the weekend? Pop the
SD card out of your camera and slide it into the
EZD580 and let the slideshow do the rest for you.
The high resolution LCD will bring your pictures
to life.
EZD580 is built-in speaker certainly is a convenient feature, especially when you’re on the road.
The built-in speaker can also be used to entertain
the driver and passenger while back seat passengers enjoy a video entertainment system. The
speaker can also be used to hear voice prompts
during navigation when the vehicle’s existing stereo system is in use.
Built-In GPS Antenna
EZD580 is truly ready to go right out of the box.
The EZD580 offers an internal antenna. No need
to fumble with wires, just plug it in, mount it to
your windshield and go.
Open Architecture
The EZD580 and its operating system were built
on a fully upgradeable platform. As new maps or
software updates become available, you can load
them via the SD card slot or via the USB 1.1 port
on the bottom.
Convenience
The EZD580 includes a mini-USB car charger or
can be charged by plugging it into the USB port
of your computer.
48
Navigation
Clarion In-Dash Navigation
The face of in-dash navigation has changed forever with the introduction of the NAX980HD Hard
Disk Drive Navigation System. This system is
based on our revolutionary 3D mapping system
that has won several awards in the Asia.
Raw Power
The NAX980HD was designed from the ground
up for only one task - to provide the best possible navigation accuracy, speed and detail of any
navigation system at any price.
Part of the secret behind the speed of the
NAX980HD is its on-board 3D Graphics processor. Unlike conventional all-in-one navgiation
systems, the NAX980HD doesn't generate the
graphics on the main CPU. This leaves the main
CPU free to do route updates and calculations,
while detailed and smooth graphics are generated by an on-board 3D Graphics Processing
Unit and transmitted to either the Many of our
Multimedia Source Units via a dedicated RGB
video connection.
Information is stored on the NAX980HD on a
40GB mobile hard disk drive. This isn't the same
drive in your laptop. It was designed to withstand
the toughest challenges the mobile environment
can throw at it.
Personalization
From the ability to upload new wallpaper themes
to the NAX980HD (downloadable from www.
clarion.com) to all the different route calculation
options. The NAX980HD will get you were you
want to go. Want to avoid toll roads or highways
alltogether - just select the route planning options
that suit your needs and go to town.
Ease of Use
From the predictive text entry to more than 10
Million Points of Interest - the NAX980HD does
everyting it can to help you get to your destination. Should you stray from the planned route,
instant route recalculations get you back on track
49
- sometimes before you even know you made a
wrong turn.
It Learns
The NAX980HD has the ability to learn your
route preferences. If you have 'taken your way'
instead of following the directions the NAX980HD
provides several times, it will include your preferences in the route planning. Avoid those areas of
traffic congestion or construction without lifting a
finger.
The "favorites menu" lets you access all your
common destinations in an uncommon way. This
fully rendered 3D menu provides animated icons
to make your selection even easier.
Looks Good
The high resolution 2D and 3D graphics displayed
on your compatible MAX or VRX Multimedia
Source Units are fully configurable to provide
as much, or as little information as you desire.
Upcoming turns, distance until next turn, ETA,
Compass and more are just some of the options.
The NAX980HD will even overlay audio information.
No Surprises
Thanks to turn-by-turn voice prompts, an event
distance count-down meter and distance to next
event displays, no turn, exit or lane change is
going to sneak up on you. With the NAX980HD
at your side, you can drive safely and confidently.
Voice prompts are available in English, French
and Spanish, as are the navigation menus.
True Integration
The NAX980HD is based on a navigation system designed for OEM use. This is part of what
makes it so accurate, detailed and easy to use.
The NAX980HD features an on-board Gyro sensor and inputs for VSS, parking brake and reverse
light inputs. The combination of these features
an a high-sensitivity GPS antenna ensure that
the NAX980HD always knows where you are and
which way you are pointed.
Source Units
50
Source Units - DB185MP/DB285USB
DB185MP
DB285USB
CD/MP3/WMA RECEIVER
CD/MP3/WMA RECEIVER WITH CENET
• MP3/WMA Plaback with ID3 Tag Display
• Front Auxiliary Input with Level Control
• Bluetooth Ready (BLT370 Required)
• Sound Adjustment (Z-Enhancer / Magna Bass EX)
• 13 x 8 Digit High Visibility Dot Matrix Display
• CD-R/RW Compatible
• Screen Savers
• Rotary Volume Control
• 4-Channel / 2V RCA Preout
• 50 Watts x 4 Built-In amplifier
• Detachable Control Panel
• OEM Steering Wheel Remote Ready
• MP3/WMA Plaback with ID3 Tag Display
• CeNET Control of DVD Changer, CD Changer, Satellite Radio and
Advanced iPod Interface
• Front Auxiliary Input with Level Control
• Bluetooth Ready (BLT370 Required)
• Sound Adjustment (Z-Enhancer / Magna Bass EX)
• 13 x 8 Digit High Visibility Dot Matrix Display
• CD-R/RW Compatible
• Screen Savers
• Rotary Volume Control
• 4-Channel / 2V RCA Preout
• 50 Watts x 4 Built-In amplifier
• Detachable Control Panel
• OEM Steering Wheel Remote Ready
• Built-In IR Remote Eye (remote optional)
Wire Harness
Replacement DCP
854-634-959
DCP606
Specifications
Power Supply Voltage
Allowable Voltage:
Current Consumption (Max)
Antenna output rated current
Maximum Power Output
CEA-2006 Power Output
Line Level Output Voltage
CD Signal to Noise Ratio
CD Frequency Response
CD Dynamic Range
Harmonic Distortion
FM Frequency Range
FM Frequency Response
FM Usable Sensitivity
FM 50 dB Quieting Sensitivity
FM Stereo Separation
AM Frequency Range
FM Usable Sensitivity
14.4VDC Negative Ground
10.8V to 15.6V
15 Amps
500mA
50 Wrms x 4
21 Wrms x 4
1.8 Vrms
87dBA 1W into 4 Ohms
10Hz to 20KHz (±1dB)
87dB (1kHz)
0.01%
87.9 MHz to 107.9 MHz
30Hz to 15kHz
11 dBf
17 dBf
35 dB
530 kHz to 1710 kHz
25 uV
51
Wire Harness
Replacement DCP
854-634-959
DCP614
Specifications
Power Supply Voltage
Allowable Voltage:
Current Consumption (Max)
Antenna output rated current
Maximum Power Output
CEA-2006 Power Output
Line Level Output Voltage
CD Signal to Noise Ratio
CD Frequency Response
CD Dynamic Range
Harmonic Distortion
FM Frequency Range
FM Frequency Response
FM Usable Sensitivity
FM 50 dB Quieting Sensitivity
FM Stereo Separation
AM Frequency Range
FM Usable Sensitivity
14.4VDC Negative Ground
10.8V to 15.6V
15 Amps
500mA
50 Wrms x 4
19 Wrms x 4
1.8 Vrms
80dBA 1W into 4 Ohms
5Hz to 20KHz (±1dB)
95dB (1kHz)
0.01%
87.9 MHz to 107.9 MHz
30Hz to 15kHz
9 dBf
15 dBf
35 dB
530 kHz to 1710 kHz
25 uV
Source Units - DXZ385USB/DXZ585USB
DXZ385USB
DXZ585USB
CD/MP3/WMA RECEIVER WITH CENET
CD/MP3/WMA/AAC RECEIVER WITH CENET
• MP3/WMA Playback with ID3 Tag Display
• CeNET Control of DVD Changer, CD Changer, Satellite Radio and
Advanced iPod Interface
• Front Auxiliary Input with Level Control
• Bluetooth Ready (BLT370 Required)
• Built-In Electronic HPF/LPF Crossovers
• Sound Adjustment (Z-Enhancer / Magna Bass EX)
• 13 x 8 Digit High Visibility Dot Matrix Display
• CD-R/RW Compatible
• Screen Savers
• Rotary Volume Control
• 6-Channel / 2V RCA Preout
• 50 Watts x 4 Built-In amplifier
• Detachable Control Panel
• OEM Steering Wheel Remote Ready
• Built-In IR Remote Eye (remote optional)
• "SLIDETRAK" HMI Interface
• MP3/WMA/AAC Playback with ID3 Tag Display
• Front Panel USB Port (support for up to 15,000 songs)
• CeNET Control of CD Changer, Satellite Radio
• Direct USB iPod Control
• 24-Bit D/A Converter
• Rear 2-CH RCA Auxiliary Input with Level Control
• Flip Down Detachable Control Panel
• Bluetooth Ready (BLT370 Required)
• Built-In Electronic HPF/LPF Crossovers
• Sound Adjustment (Digital Z-Enhancer / Magna Bass EX)
• Sound Restorer
• 2-Band Parametric Equalizer
• Digital AM/FM Tuner
• 13 x 8 Digit 2-Line High Visibility LCD Display
• CD-R/RW Compatible
• 6-Channel / 6V RCA Preout (with Subwoofer Control)
• 53 Watts x 4 Built-In amplifier
• OEM Steering Wheel Remote Ready
• Built-In IR Remote Eye - Remote Included
• 2 Year Waranty (If installed by an authorized Clarion dealer)
Wire Harness
Replacement DCP
854-634-959
DCP615
Specifications
Power Supply Voltage
Allowable Voltage:
Current Consumption (Max)
Antenna output rated current
Maximum Power Output
CEA-2006 Power Output
Line Level Output Voltage
CD Signal to Noise Ratio
CD Frequency Response
CD Dynamic Range
Harmonic Distortion
FM Frequency Range
FM Frequency Response
FM Usable Sensitivity
FM 50 dB Quieting Sensitivity
FM Stereo Separation
AM Frequency Range
FM Usable Sensitivity
14.4VDC Negative Ground
10.8V to 15.6V
15 Amps
500mA
50 Wrms x 4
19 Wrms x 4
3.6 Vrms
80dBA 1W into 4 Ohms
5Hz to 20KHz (±1dB)
95dB (1kHz)
0.01%
87.9 MHz to 107.9 MHz
30Hz to 15kHz
9 dBf
15 dBf
35 dB
530 kHz to 1710 kHz
25 uV
Wire Harness
Replacement DCP
854-634-959
DCP608
Specifications
Power Supply Voltage
Allowable Voltage:
Current Consumption (Max)
Antenna output rated current
Maximum Power Output
CEA-2006 Power Output
Line Level Output Voltage
CD Signal to Noise Ratio
CD Frequency Response
CD Dynamic Range
Harmonic Distortion
FM Frequency Range
FM Frequency Response
FM Usable Sensitivity
FM 50 dB Quieting Sensitivity
FM Stereo Separation
AM Frequency Range
FM Usable Sensitivity
14.4VDC Negative Ground
10.8V to 15.6V
15 Amps
500mA
53 Wrms x 4
19 Wrms x 4
5.7 Vrms
83dBA 1W into 4 Ohms
5Hz to 20KHz (±1dB)
95dB (1kHz)
0.01%
87.9 MHz to 107.9 MHz
30Hz to 15kHz
9 dBf
15 dBf
35 dB
530 kHz to 1710 kHz
25 uV
52
Source Units - DXZ785USB/DRZ9255
DXZ785USB
DRZ9255
CD/MP3/WMA/AAC RECEIVER WITH CENET
AM/FM CD PLAYER WITH CENET, TIME
ALIGNMENT, PARAMETRIC EQ AND 4-WAY
CROSSOVER
• "SLIDETRAK" HMI Interface
• MP3/WMA/AAC Playback with ID3 Tag Display
• Rear USB Port (support for up to 15,000 songs)
• CeNET Control of CD Changer, Satellite Radio
• Direct USB iPod Control
• 24-Bit D/A Converter
• Rear 2-CH RCA Auxiliary Input with Level Control
• Motorized Flip Down Detachable Control Panel
• 728 Color Display and Button Illumination
• Bluetooth Ready (BLT370 Required)
• Advanced Electronic 2-way/3-way Crossovers
• 6-Channel Time Alignment Control with 23mm steps
• Sound Adjustment (Digital Z-Enhancer / Magna Bass EX)
• Sound Restorer
• 3-Band Parametric Equalizer
• Digital AM/FM Tuner
• High visibility Dot Matrix LCD Display
• CD-R/RW Compatible
• 6-Channel / 6V RCA Preout (with Subwoofer Control)
• 53 Watts x 4 Built-In amplifier
• OEM Steering Wheel Remote Ready
• Built-In IR Remote Eye - Remote Included
• 2 Year Waranty (If installed by an authorized Clarion dealer)
Wire Harness
Replacement DCP
Specifications
Power Supply Voltage
Allowable Voltage:
Current Consumption (Max)
Antenna output rated current
Maximum Power Output
CEA-2006 Power Output
Line Level Output Voltage
CD Signal to Noise Ratio
CD Frequency Response
CD Dynamic Range
Harmonic Distortion
FM Frequency Range
FM Frequency Response
FM Usable Sensitivity
FM 50 dB Quieting Sensitivity
FM Stereo Separation
AM Frequency Range
FM Usable Sensitivity
53
854-634-959
DCP607
14.4VDC Negative Ground
10.8V to 15.6V
15 Amps
500mA
53 Wrms x 4
20 Wrms x 4
5.7 Vrms
84dBA 1W into 4 Ohms
5Hz to 20KHz (±1dB)
95dB (1kHz)
0.01%
87.9 MHz to 107.9 MHz
30Hz to 15kHz
9 dBf
15 dBf
35 dB
530 kHz to 1710 kHz
25 uV
• Dual 24-Bit Burr Brown 96kHz 64x oversampling D/A converters
• Digital Time Alignment for each channel with 0.7cm (1/4") steps
• 4-Way electronic crossovers - 6, 12 or 18dB Slopes, bandpass on
Sub, Low and Midrange outputs
• 5-Band Parametric Equalizer with presets
• 0.5dB/Step Burr Brown Zero-Crossing volume control
• CeNET Control of CD Changer, DVD Changer, TV Tuner and iPod
Interface
• Copper Plated chassis for EFI Noise rejection
• 8-Volt, 8-channel Gold Plated preamp outputs with OFC cables
• Two Auxiliary inputs
• External 30V DC/DC converter power supply
• Fiber Optic input for CD/DVD changer
• Vacuum Fluorescent Display
• IR Remote Control
• MagiTune+ AM/FM Tuner
• Zinc Die-Cast Faceplate
Specifications
Power Supply Voltage
Allowable Voltage:
Current Consumption (Max)
Line Level Output Voltage
CD Frequency Response
Signal to Noise Ratio
CD Dynamic Range
Harmonic Distortion
FM Frequency Range
FM Frequency Response
FM Usable Sensitivity
FM 50 dB Quieting Sensitivity
FM Stereo Separation
AM Frequency Range
FM Usable Sensitivity
14.4VDC Negative Ground
10.8V to 15.6V
<5 Amps
8.0 Vrms
5Hz to 20KHz (±1dB)
112dB
100 dB
0.003% (20Hz to 20kHz)
87.9 MHz to 107.9 MHz
30Hz to 15kHz
9 dBf
15 dBf
35 dB
530 kHz to 1710 kHz
25 uV
Source Units - FB275BTB/FB275BT/XA311
FB275BTB
XA311
AM/FM CASSETTE PLAYER WITH
CD CHANGER CONTROLLER AND DIN CHASSIS
•
•
•
•
•
•
•
FB275BT
Magi-Tune Tuner with 20 FM/5 AM Presets
Rotary Volume Control
Z-Enhancer EQ Selector
Green LCD Display
C-Bus Changer Control
160 W Amplifier (40 W x 4)
Auto Reverse
BLUETOOTH SD/MP3 RECEIVER
• Built-in Bluetooth Interface (HSP, A2DP & AVRCP Profiles)
• SD Card Slot
• MP3 Playback via SD Card
• Detachable Flip Down Control Panel
• FM Receiver
• 2 Channel RCA Auxiliary Input with Level Control
• 2 Channel / 2V RCA Preout
• 200 Watts (50 Watts x 4)
• 3.5mm External Micro phone Connector
Wire Harness
854-634-959
Specifications (preliminary)
Power Supply Voltage
Allowable Voltage:
Current Consumption (Max)
Antenna output rated current
Maximum Power Output
CEA-2006 Power Output
Line Level Output Voltage
FM Frequency Range
FM Frequency Response
FM Usable Sensitivity
FM 50 dB Quieting Sensitivity
FM Stereo Separation
AM Frequency Range
FM Usable Sensitivity
14.4VDC Negative Ground
10.8V to 15.6V
15 Amps
500mA
50 Wrms x 4
17 Wrms x 4
2.0 Vrms
87.9 MHz to 107.9 MHz
30Hz to 15kHz
11 dBf
17 dBf
35 dB
530 kHz to 1710 kHz
25 uV
Wire Harness
Specifications
FM Useable Sensitivity
FM 50 dB Quieting Sensitivity
FM Alternate Channel Selectivity
FM Stereo Separation
FM Stereo Frequency Response
Tape Wow and Flutter
Tape Channel Separation
Tape Signal-to-Noise Ratio, Metal Tape,
No Noise Reduction
Tape Frequency Response, Metal Tape
Maximum Power Output
Continuous Power Output
854-634-950
11 dB
17 dB
75 dB
35 dB
30 Hz to 15 kHz
0.08 %
45 dB
58 dB
30 Hz to 20 kHz
40 W x 4
14 W x 4
Optional Changer
DC625
54
Source Units - DFZ675MC/DUZ385SAT
DFZ675MC
DUZ385SAT
CD/MP3/WMA 2-DIN RECEIVER WITH CENET
CONTROL AND MUSIC CATCHER II
CD/USB/MP3/WMA/AAC RECEIVER
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Vacuum Fluorescent Display
Plays CD, CD-R & CD-RW
MP3 and WMA decoding with ID3 tag display
CeNET control for DVD Changer (Easy), TV Tuner, 6-Disc CD
Changer, Satellite radio tuner and iPod Interface.
728 Colour Display and Button Illumination
4-Channel 2-Volt RCA Output
Front Panel 3.5mm Auxiliary Input
Front Panel SD Card Slot
Music Catcher II digital recorder with 4x record speed
200W MOSFET Amplifier (50W x 4)
Digital Z-Enhancer
Magna Bass EX
Random Play, Intro Scan, Track Repeat
Rotary Volume Control
18 FM/6 AM Presets
Adjustable Display Contrast
Built-In Amp Canceller
IR Remote Control
Specifications
Maximum Power Output
CEA-2006 Power Output
Line Level Output Voltage
CD Signal to Noise Ratio
CD Frequency Response
CD Dynamic Range
Harmonic Distortion
FM Frequency Range
FM Frequency Response
FM Usable Sensitivity
FM 50 dB Quieting Sensitivity
FM Stereo Separation
MP3 Formats
55
50 Wrms x 4
19 Wrms x 4
2.0Vrms
81dB 1W into 4 Ohms
10Hz to 20KHz (±1dB)
95 dB
0.01%
87.9 MHz to 107.9 MHz
30Hz to 15kHz
9 dBf
15 dBf
35 dB
MPEG 1, 2 and 2.5-Layer 3
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
MP3 and WMA decoding with ID3 tag display
Plays CD, CD-R & CD-RW
USB Digital Media Streaming Capability
Rear USB Connector
Direct USB iPod Audio
Front Panel 3.5mm Auxiliary Input
Rotary Volume Control with Source Indicator
13 x 10 Digital 2-Line High Visibility LCD
White Colour Display and Illuminated Keys
Magna Bass EX, Z-Enhancer
Z-Enhancer Plus Sound Customization
200W MOSFET Amplifier (50W x 4)
2-Channel 2-Volt RCA Output
18 FM/6 AM Presets
OEM Steering Wheel Remote Ready
Bluetooth Ready (BLT370 Required)
Sirius Satellite Ready (K-SIRIUS Sold Separetly)
XM Mini-Tuner Direct (Receiver Sold Separetly)
IR Remote Control (Optional)
Specifications (preliminary)
Maximum Power Output
CEA-2006 Power Output
Line Level Output Voltage
CD Signal to Noise Ratio
CD Frequency Response
CD Dynamic Range
Harmonic Distortion
FM Frequency Range
FM Frequency Response
FM Usable Sensitivity
FM 50 dB Quieting Sensitivity
FM Stereo Separation
MP3 Formats
50 Wrms x 4
20 Wrms x 4
2.0Vrms
79dB 1W into 4 Ohms
10Hz to 20KHz (±1dB)
95 dB
0.01%
87.9 MHz to 107.9 MHz
30Hz to 15kHz
9 dBf
15 dBf
35 dB
MPEG 1, 2 and 2.5-Layer 3
Source Units – UDB275MP/ADB340MP
UDB275MP
ADB340MP
CD/USB/MP3/WMA RECEIVER
CD/MP3 CASSETTE PLAYER RECEIVER 2-DIN
CHASSIS
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
MP3 and WMA decoding with ID3 tag display
Plays CD, CD-R & CD-RW
Front USB Slot
Front Panel 3.5mm Auxiliary Input
Rotary Volume Control with Source Indicator
High Visibilty Display with Screen Savers
728 Colour Display and Button Illumination
Magna Bass EX, Z-Enhancer
Z-Enhancer Sound Customization
200W MOSFET Amplifier (50W x 4)
2-Channel 2-Volt RCA Output
18 FM/6 AM Presets
OEM Steering Wheel Remote Ready
Bluetooth Ready (BLT370 Required)
IR Remote Control
Specifications (preliminary)
Maximum Power Output
CEA-2006 Power Output
Line Level Output Voltage
CD Signal to Noise Ratio
CD Frequency Response
CD Dynamic Range
Harmonic Distortion
FM Frequency Range
FM Frequency Response
FM Usable Sensitivity
FM 50 dB Quieting Sensitivity
FM Stereo Separation
MP3 Formats
50 Wrms x 4
19 Wrms x 4
2.0Vrms
79dB 1W into 4 Ohms
10Hz to 20KHz (±1dB)
95 dB
0.01%
87.9 MHz to 107.9 MHz
30Hz to 15kHz
9 dBf
15 dBf
35 dB
MPEG 1, 2 and 2.5-Layer 3
•
•
•
•
•
•
•
•
•
•
•
Flip-Down Faceplate
Plays CD-R and RWs
Plays MP3-Encoded CDs
Full-Logic Cassette Player with Auto Reverse
3-Band Graphic EQ
LCD With Spectrum Analyzer
2-Channel RCA Line-Level Output
2-Channel Auxiliary Input
200 W Amplifier (50 W x 4)
Radio Tuner with 18 FM/6 AM Presets
CD Text and CD Titling
Wire Harness
Specifications
FM Useable Sensitivity
FM 50 dB Quieting Sensitivity
FM Alternate Channel Selectivity
FM Stereo Separation
FM Stereo Frequency Response
CD Signal-to-Noise Ratio
CD Frequency Response
CD Dynamic Range
Tape Wow and Flutter
Tape Channel Separation
Tape Signal-to-Noise Ratio, Metal Tape,
Dolby B Noise Reduction
Tape Frequency Response, Metal Tape
Maximum Power Output
Continuous Power Output
Line-Level Output Voltage
854-634-950
11 dB
17 dB
70 dB
35 dB
30 Hz to 15 kHz
100 dB
10 Hz to 20 kHz
95 dB
0.06 %
45 dB
67 dB
30 Hz to 20 kHz
50 W x 4
17 W x 4
1.8 V
56
Source Units – DCZ625/DC625 CD Changers
DCZ625
DC625
CeNET 6-DISC CD CHANGER
C-BUS 6 DISC CD CHANGER
Features
Features
•
•
•
•
•
•
•
•
•
•
•
•
•
•
6-Disc Magazine
Plays CD-R/RW Discs
CeNET Control
Zero-Bit Detector Mute Circuit
Horizontal or Vertical Mounting Capability
Fiber-Optic Digital Output
CD Text and CD Titling
Magazine: CAA397
Specifications
CD Channel Separation . . . . . . . . . . . . . . . . . . . . . . . 85 dB
CD Signal-to-Noise . . . . . . . . . . . . . . . . . . . . . . . . . . 100 dB
CD Frequency Response . . . . . . . . . . . . . . . .5 Hz to 20 kHz
CD Dynamic Range . . . . . . . . . . . . . . . . . . . . . . . . . . . 94 dB
Dimensions (h x l x d) . . . . . . . . . . . . . . 2-1/2" x 9" x 6-5/8"
57
6 Disc Magazine
Plays CD-R/RW Discs
C-Bus Control
Zero-Bit Detector Mute Circuit
Horizontal or Vertical Mounting Capability
Magazine: CAA397
Specifications
CD Channel Separation . . . . . . . . . . . . . . . . . . . . . . . . 85 dB
CD Signal-to-Noise . . . . . . . . . . . . . . . . . . . . . . . . . . 100 dB
CD Frequency Response . . . . . . . . . . . . . . . .5 Hz to 20 kHz
CD Dynamic Range . . . . . . . . . . . . . . . . . . . . . . . . . . . 94 dB
Dimensions (h x l x d) . . . . . . . . . . . . . . 2-1/2" x 9" x 6-5/8"
Source Units – FMC250/Accessory Information
C-Bus Cables
CCA273
5' C-Bus Changer Cable, Male-to-Male
FMC250
FM MODULATOR/CD CHANGER CONTROL
FEATURES
•
•
•
•
12 FM Frequencies (switchable)
C-Bus Control and communication
Output Level Control
IR Remote Control RCB131
Works with C-Bus changers only
CCA306
20" C-Bus Changer Cable, Angle Male-to-Straight
Female
CCA308
16’ C-Bus CD Changer (Extension) Cable,
Male-to-Female
CCA329
16' C-Bus CD Changer (Replacement) Cable, Male-toMale
CCA350
5' C-Bus CD Changer Cable, Angle Male-to-Angle Male
CD Changer Magazines
CAA397
6-Disc Magazine for DCZ625, DC625, VCZ625
CAA355
6 Disc Magazine for CDC655TZ, CDC635, and
XM655-RET
CAA134
3-Pack/One Each Red, White, and Blue
6-Disc Magazine for CDC1255Z and CDC1235
CAA122
One Black 6-Disc Magazine for CDC1255Z and
CDC1235
CeNET Cables
CCA519
CeNet Y-Adapter for Multi-Changer Connection and
iPod interface installation.
CCA520
8' CeNET CD Changer (Extension) Cable,
Male-to-Female
CCA521
20.5" CeNET CD Changer (Extension) Cable,
Male-to-Female
CAA561
16' CeNET CD Changer (Replacement) Cable,
Male-to-Male
58
Satellite Radio
Satellite Radio - Technologies
Sat Ready for 2008
Sirius Marine Solutions
New 2008 Clarion CeNET compatible source
units are now SAT Radio ready. This means that
you can choose from Sirius or XM Radio - giving
you more than 200 different channels of entertainment to choose from.
As the world leader in marine audio product
design and production, Clarion takes enjoying
satellite radio on the water to the next level with
out marine specific Sirius Satellite Radio package.
How does Satellite Radio work?
K-SIRIUSM - SIRIUS Satellite Radio Receiver
Though the exact mechanism and placement
of satellites varies between XM and Sirius, the
concept is essentially the same. Both companies
operate their own studios and program their own
music. The broadcast is transmitted to a satellite
(or satellites) orbiting above North America. The
tuner in your car receives this digitally transmitted signal and provides you with more than 100
different choices of stations - many of which are
commercial free. Both Sirius and XM are pay-foruse services.
This package includes Clarion’s SC-C1 receiver,
but does not include the automotive antenna.
You must purchase a marine satellite radio antenna for the K-SIRIUSM to work.
K-SIRIUS - SIRIUS Satellite Radio Receiver
This package includes Clarion’s K-SIRIUS receiver and Sirius Antenna and a CeNET cable. The
receiver can be controlled using any CeNETequipped source unit.
SRA25 - SIRIUS Marine Antenna
Features:
• CeNET interface for direct operation by all
SIRIUS-Ready Clarion source units
• CeNET Pass-Through for Connection of CD
Changers and any other Clarion CeNET products.
60
Satellite Radio - Marine Solutions
SRA40 - SIRIUS Marine Antenna
These are marine specific antennae for use with
the K-SIRIUSM. These antennae are manufactured by Shakespeare and are part of their Galaxy
series of marine antenna products.
The antenna do not require any additional power
connections. The antenna can be mounted to
surfaces up to 1 inch thick .
These antennae includes a 25 foot long low loss
cable with quick disconnect and a gold plated
TMC antenna connector.
SRC50 - 50-Foot Replacement Cable
The SR50 is a foot long replacement cable for the
SRA40/SRA25 antenna. This is not an extension.
61
Amplifiers
62
Amplifiers
2008 Amplifier Line Overview
With a heritage of power, performance and quality that spans many decades, Clarion proudly
introduces our most sophisticated amplifier line
ever. The entire line offers the kind of power and
performance that todays customers demand.
Clarion does not ignore the need for an amplifier to look cool, but we put sound quality and
performance at the top of our list. We will not
forego musical transparency and control for size
or a cosmetic feature, instead we embrace the
latest in power supply technologies to make our
amplifiers simulatenously musical, efficient and
compact.
Clarion amplifiers are developed to compliment
one-another in terms of features, performance
and design. These features exist to help installers
complete the integration of these amplifiers into
a vehicle faster and more accurately. Likewise,
these features also help to improve the performance of the amplifier.
The new 'c Series" amplifiers offer impressive
power offerings from a very compact package.
Furthermore, these amplifiers feature a Class D
design that allows them to produce this power
without putting a significant load on your battery
or requiring a large heat sink to stay cool.
APX Series
Model
APX2121
APX4241
APX1301
Description
2-Channel
4-Channel
Mono
Power (4:)
2 x 60W
4 x 60W
1 x 300W
APX Plus Series
Model
Class Description
APX2181
AB
2-Channel
APX4361
AB
4-Channel
Power (4:)
2 x 90W
4 x 90W
c Series
Model
c220.4
C250.1
Power (4:)
4 x 55W
1 x 400W
63
Class
AB
AB
AB
Class Description
D
4-Channel
D
Mono
DPX Series
Model
DPX2251
DPX1851
DPX11551
Class
GH
GH
GH
Description
2-Channel
Mono
Mono
Power
2 x 200W
1 x 850W
1 x 1550W
2008 Amplifier Technologies
Precise Frequency Selector
Electronic Crossover
The inclusion of an electronic crossover in an
amplifier allows the speaker to receive on the
musical information that it can produce properly.
This means that sound quality from the speaker is
improved and power handling in smaller speakers
is increased dramatically.
One drawback of an electronic crossover which
allows the crossover frequency to be adjusted
through the use of a potentiometer is that it can be
difficult to precisely set the crossover frequency .
This is because the potentiometer is nearly infinitely adjustable. Many crossover controls are only
labelled at the top and bottom of their frequency
range, making selecting a frequency in the middle
of the adjustment range nearly impossible..
Clarion provides a simple and elegant solution
for accurately setting crossover points with our
PFS (Precise Frequency Selector) crossover.
The potentiometer on the APX2181, APX4361,
DPX2251, DPX1851, DPX11551, APX290M and
APX490M amplifiers has 41 detented positions.
Using the supplied charts, you can select a specific crossover frequency, then to set it, turn the
adjustment potentiometer the according number
of clicks, and you are done.
One of the many benefits of this feature surfaces
when you are building a multi-amp system. With
conventional (Non PFS) crossover controls, you
could end up setting a subwoofer amp set to
70Hz when you were aiming for 85Hz and end up
at 100Hz on the mids and highs amp. The result
would be a system that lacks mid-bass dynamics
and makes the bass frequencies sound disconnected from the mids and highs. PFS makes
under/over-lapping of crossovers history.
Amplifiers – Technologies
Input Voltage Selector Gain
Control
Conventional amplifier gain (or sensitivity) adjustment systems have inherent limitations. These
controls utilise ganged or stacked potentiometers
to allow you to match the power production capabilities of the amplifier to the signal strength of the
source unit that is feeding it. To allow an amplifier
to be used with as many different sources as possible, the sensitivity range should be as wide as
possible.
Because the gain control uses several potentiometers that are connected together (ganged), the
exact resistance of each of these devices may not
match the next one. The result is one channel of
the amplifier will be louder than the other. This is
called channel imbalance.
To combat channel imbalance, Clarion has impleted IVS (Input Voltage Selector) technolgoy on the
APX2181, APX4361, DPX2251, DPX1851 and
DPX11551 amplifiers.
IVS dramatically reduces channel imbalance by
implementing a switch that controls the gain
range: 0-0.6v, 0.6-2v, 2-8v. This switch is used in
conjunction with a narrow-range adjustable potentiometer for fine tuning. The result is a reduction in
maximum potential channel imbalance, improved
imaging and a more accurate soundstage.
The graph above shows the amount of channel imbalance from two identical amplifiers, one
with IVS and one without, The curve with the
large bump (red) is the amplifier without IVS and
reaches a maximum channel imbalance of 0.75dB
at 0.25% of maximum gain. The two overlapping
curves (Blue and Green) show the channel imbal-
ance of an IVS-equipped amp at the 0.6-2V and
2V-8V settings. The maximum imbalance is only
0.45dB - nearly half of the non-IVS amplifier.
You might be asking yourself: Why not individual
gain controls? While individual gain controls can
offer very accurate sensitivity settings, an installer
MUST use an oscilloscope or voltmeter to properly set these controls for accurate channel to
channel output. At the very least, the installer
could tune the system by ear, but this will require
many trips from the listening position back to the
amplifier. The decision to implement IVS offers the
same result but saves the installer time when setting gains because fewer tools are required.
Hybrid Class GH Power Supplies
Amplifier efficiency has never been more important
than it is in today's modern vehicles. Alternators,
batteries and factory wiring are smaller than ever
to produce the lightest and most fuel efficient
vehicles possible at the lowest cost.
Clarion's DPX amplifiers feature Hybrid Class GH
power supplies. This technology is the result of
years of design and testing to offer the optimum
balance of sound quality and efficiency - exactly
what a Clarion customer demands.
The operation of a Hybrid Class GH amplifier is
very simple. Traditional amplifiers use a Class
AB output device topology. Essentially, there
are a set of switching devices (transistors) for
the positive half of the waveform and another
set for the negative half of the waveform. These
devices operate linearly, passing more current
through them as more signal is sent to them.
The drawback with Class AB topology is that the
output devices operate in their resistive region,
rarely fully on or off. This results in a great deal
of heat being generated and energy wasted.
Around a decade ago, the introduction of Class
D amplifiers to the car audio market offered a
significant improvement in amplifier efficiency at
the expense of sound quality and control. Class D
amplifiers operate by cycling the output devices
fully on and off very quickly. Adjusting the on ver-
64
Amplifiers – Technologies
sus off time effects a change in output level. One
of the many drawbacks of Class D amplifiers is
that they require large filtering networks after the
output stage to clean up the signal and remove
high frequency switching noise. Class D amplifiers can cause significant electrical interference
that can affect radio reception.
Clarion's Hybrid Class GH technology is truly the
best of both worlds. Clarion’s DPX amplifiers use
a fully analog Class AB audio path. This meanss
tight, controlled, dynamic power output.
How does Hybrid Class GH work to improve
efficiency if the audio path is all analog? Think
of the new Dodge Hemi or Cadillac Northstar
engines. These engines have the ability to shut
down a number of cylinders to reduce fuel comsumption and heat generation when under light
loads. The power supply of a Hybird Class GH
amplifier works in the same way. A microcontroller (computer) inside the amplifier controls the
output voltage of the power supply. It keeps the
voltage just above the output level necessary
to reproduce the audio signal. This means that
although the output devices are operated linearly,
they are almost fully on - it's the power supply
voltage that changes. The result is a significant
improvement in efficiency without any effect on
amplifier sound quality.
The graph below compares the efficiency of a conventional Class AB 1500W amp to our DPX11551
1500W amplifier. You can see that around 350W
DPX11551 is ~65% efficient, whereas the conventional Class AB is merely 25% efficient. This
means, that the DPX11551 is drawing only 37A
of current, where the Class AB amp would be
drawing closer to 97A of current.
65
Strappable Power
The DPX1851 and DPX11551 amplifiers are both
strappable. This means, a pair of amplifiers can
be used on a single voice coil to provide additional power production for extreme SPL levels.
A pair of DPX1851 amplifiers would produce
1,600W into a 2 or 4 Ohm load, and a pair of
DPX11551 would produce 3,000W into a 2 or 4
Ohm load.
Remote Bass Control
The Clarion DPX2251, DPX1851
and DPX11551 amplifiers offer the ability to connect a an optional Remote Bass Control module called the BC2. This allows you to control
the amplifiers output level from the front of the
vehicle. Unlike some competitors products, this
is not a bass boost control. This was done for
optimum sound quality and performance across
the entire frequency range, rather than making
the bass sound boomy.
Adjustable Subsonic Filter
Clarion’s DPX1851 and
DPX11551 amplifiers feature an adjustable subsonic filter. This filter is adjustable from 10Hz to
80Hz using a potentiometer on the end panel of
the amplifier.
When using subwoofers in vented cabinets with
high tuning frequencies (above 35Hz), in or large
vented enclosures, physical power handling of
the subwoofer may easily be exceeded. The
proper use of a subsonic filter will limit the
amount of ultra-low frequency information being
passed through to the speaker, as well as reduce
the amount of power the amplifier consumes in
amplifying those low frequencies.
Forced Induction Cooling
Clarion's APX Plus and DPX amplifiers feature
forced induction cooling. This is a two-part
technology. First, the heatsink design of the
amplifier maximizes air flow across the switching devices to hit them with a blast of cool air.
Air is then injested into the core of the amplifier
and expelled through the ends of the amp. The
second part of Forced Induction Cooling is the
Amplifiers – Technologies
computer controlled cooling fan. A thermal sensor connected to the heat sink of the amp combined with programming logic in the amplifiers
core decides the appropriate speed for the fan
to maximize cooling while minimizing noise.
Clarion recommends the use of twisted-pair RCA
interconnects with our amplifiers.
High Impedance Inputs
Clarion amplifiers feature high impedance RCA
input stages. This allows source unit with low
quality high impedance preamp outputs to
provide the best possible frequency and phase
response while limiting the effect of interconnect reactances on the amplifiers frequency
response.
High impedance inputs also allow you drive
multiple amplifiers from a single set of preamp
outputs using Y-Cables without as dramatic an
effect on signal quality
Mixed-Mode Operation
Clarion 2- and 4-channel amplifiers use an
inverting circuit that allows a pair of channels to
simultaneously drive multiple satellite speakers
in stereo and a subwoofer in a bridged-mono
configuration. When used in conjunction with
passive crossover components, a Clarion amplifier is capable of mixed mode operation that can
power an entire audio system.
Differential Inputs
High-impedance differential input stages separate the input signal ground from the common
chassis ground. This creates a very effective
ground-loop isolation circuit that reduces the
possibility of charging system noise entering
the signal path. The circuit also compares the
signal information on the shield to that of the
center conductor and eliminates any common
signal (noise), leaving only clear and detailed
music.
Amplifier Circuit Components
Any product is only as good as its weakest link.
When Clarion decided to reduce the physical
size of our DPX and APX Plus amplifiers, we
knew that this could not be done at the expense
of sound quality, performance or reliability.
The decision was made to design these amplifiers
for the use of surface mount technology (SMT)
devices. SMT devices offer improved tolerances
as compared to through-hole devices, and better
resist electrical interference from RF or EMI noise.
The result is an amplifier that costs a little more to
produce, but sounds better.
This advanced circuit topology ensures that
Clarion amplifiers will accurately reproduce all the
dynamics and subtleties found in today’s digital
recordings. At the same time, noise suppression
circuits work to effectively to eliminate induced
electrical system noise, contributing to maximum
dynamic range.
66
Amplifiers – Technologies
Illuminated Heat Sink
Clarion's APX Plus and DPX amplifiers feature
an illuminated Carbon Fiber badge in the center
of the amplifer. This badge can be removed and
rotated to maintain the readability in custom
installations.
Multi-Channel Amplifiers
Clarion’s multi-channel amplifiers provide four
channels of amplification from one chassis/ Each
amplifier is equipped with front and rear gain
controls and high-/low-pass electronic crossovers. This configuration provides maximum system flexibility.
A four-channel amplifieris the perfect starting
point in terms of an amplifier upgrade. This amplifier is the most flexible in terms of system expansion. It can be used to drive four full-range speakers, four full-range speakers and a subwoofer, a
mid and tweeter set or more. A four channel amp
rarely needs to be replaced as a customers system expands over the years, adding value to the
purchase.
CEA-2006 Compliant
The Consumer Electronics Associated developed the CEA-2006 standard to provide a level
playing field in which amplifier power and S/N
Ratio specificiations can be compared equally.
All Clarion power amplifer specifications adhere
to the guidelines of the CEA-2006 specification.
The CEA-2006 specification outlines the following test criteria for amplifier power output
testing. Rated power shall be measured with all
channels driven into a specified load impedance
with a distortion level that does not exceed 1%.
The amplifier shall produce this power across a
67
specified frequency range (commonly 20Hz to
20kHz) and be powered by a DC power supply
of 14.4V. The S/N Ratio specification is measured with respect to an output equal to 1W,
commonly 2V in a mobile audio application.
Product Specifications
Clarion has invested a significant amount of time
and expense ensuring that our amplifiers provide
the best possible sonic performance and excellent value. A look at the specifications associated with any of our amplifiers quickly demonstrates this dedication to purist performance.
From the extended frequency response to the low
S/N Ratios and distortion specifications, Clarion
amplifiers provide class leading performance.
Clarion takes great pride in the fact that our
amplifiers offer frequency response well beyond
the audible spectrum. This ensures perfectly
linear output with no emphasis in any region. It
also moves the phase shift commonly associated with high frequency roll-off out of the audible range. The APX4361and APX2181 feature
greater than 10Hz-50kHz frequency response
within 1dB - not the usual 3dB rating other products use.
2 Year Warranty
Clarion offers a 2-year warranty against defects
in materials and workmanship on the APX2181,
APX4361, DPX2251, DPX1851 and DPX11551
amplifiers if the product is purchased from, and
installed by an authorized Clarion dealer.
PFS Crossover Charts
Please use the following charts to set the crossover frequency on the APX2181, APX4361 and
DPX2251 amplifiers.
Please use the following charts to set the crossover frequency on the DPX1851 and DPX11551
amplifiers.
Position
Position
Crossover Frequency
1....................................49
2....................................49
3....................................50
4....................................50
5....................................51
6....................................52
7....................................52
8....................................55
9....................................60
10..................................65
11..................................80
12..................................85
13..................................90
14..................................100
15..................................125
16..................................140
17..................................155
18..................................165
19..................................175
20..................................178
21..................................180
22..................................200
23..................................210
24..................................220
25..................................230
26..................................250
27..................................280
28..................................300
29..................................325
30..................................369
31..................................410
32..................................420
33..................................455
34..................................475
35..................................495
36..................................500
37..................................510
38..................................520
39..................................530
40..................................540
41..................................550
Crossover Frequency
1..................................24
2..................................24
3..................................24
4..................................24
5..................................24
6..................................25
7..................................27
8..................................30
9..................................33
10................................35
11................................40
12................................43
13................................50
14................................55
15................................60
16................................65
17................................70
18................................75
19................................77
20................................82
21................................86
22................................90
23................................95
24................................100
25................................110
26................................120
27................................125
28................................130
29................................150
30................................155
31................................160
32................................165
33................................175
34................................175
35................................180
36................................180
37................................185
38................................190
39................................195
40................................200
41................................200
68
DPX Amplifier Error Codes
The APX2181, APX4361, DPX2251, DPX1851 and DPX11551 amplifiers feature computer controlled
on-board diagnostics. The chart below outlines the error message and the cause of the message.
Amp Illumination
Red End Panel LED Blue End Panel LED Cause
ON
OFF
ON
FLASHING
SLOW FLASH
FLASH OUT OF SYNC
FAST FLASH
FLASH IN SYNC
OFF
Short Circuit Detection
3 FLASHES
THREE FLASHES
OFF
Repeated Short Circuit
OFF
Amplifier Operating Normally
FLASHING
OFF
Thermal Protection
Input Voltage Overload
Problem:
Amp is in thermal protection mode
Solution:
- Shut off system and let amp cool down.
- Check speaker load on amp, make sure it does not exceed specification
- Ensure adequate air space around the amplifier
- Ensure end panels (DPX amps) are not obstructed and limiting air flow
Problem:
Input Voltage Overload
Solution:
- Service vehicle electrical system (alternator and voltage regulator)
Problem:
Short Circuit Detection
Solution:
- Check speaker load on amp, make sure it does not exceed specification
- Check all speaker wires for short circuits
- Check all speaker wires for shorts to ground
- Replace speakers with known good units
Problem:
Repeated Short Circuit
Solution:
Resolve Short Circuit problem, disconnect amp for 15 minutes to reset.
69
Amplifiers - Specifications
DPX11551
DPX1851
1 CHANNEL HYBRID CLASS GH AMPLIFIER
1 CHANNEL HYBRID CLASS GH AMPLIFIER
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Hybrid Class GH Power Supply
Class AB Audio Path
IVS (Input Voltage Selector) Gain Control
PFS (Precise Frequency Selector) Electronic Low-Pass Crossover
(30Hz to 250Hz, 12 dB/octave)
Adjustable Subsonic Filter (10Hz to 50Hz)
Variable Bass Boost Control (0 to 15dB, 30-125Hz)
Strappable
Comlimentary Sanken Triple Darlington Output Transistors
MOSFET Power Supply Devices
Speaker Level Inputs
Double Sided FR4PC Board
On-Board Diagnostics
Gold-Plated RCA/Speaker/Power Connectors
Illuminated Amplifier Shroud
Remote Bass Control Ready (BC2 Sold Separetly)
Specifications
Number of Channels
Frequency Response (±1.0dB)
Signal-to-Noise Ratio (CEA-2006)
Noise Floor
input Impedance
Input Sensitivity
High Level Input Sensitivity
Bass Boost
Power Output @ 2 Ohms (CEA-2006)
Power Output @ 4 Ohm (CEA-2006)
Dimensions (l x w x h)
1
10 Hz to 230Hz
>63 dB
< 1mV
22 kOhms
0.2 to 0.6 V
0.6 to 2.0V
2 to 8V
0.4v to 1.2V
1.2 to 4V
4 to 16V
0 -15dB @ 45Hz
1550W
850W
16-3/4"x10-1/8"x2-3/8"
•
•
•
•
•
•
•
•
•
•
•
Hybrid Class GH Power Supply
Class AB Audio Path
IVS (Input Voltage Selector) Gain Control
PFS (Precise Frequency Selector) Electronic Low-Pass Crossover
(30Hz to 250Hz, 12 dB/octave)
Adjustable Subsonic Filter (10Hz to 50Hz)
Variable Bass Boost Control (0 to 15dB, 30-125Hz)
Strappable
Comlimentary Sanken Triple Darlington Output Transistors
MOSFET Power Supply Devices
Speaker Level Inputs
Double Sided FR4PC Board
On-Board Diagnostics
Gold-Plated RCA/Speaker/Power Connectors
Illuminated Amplifier Shroud
Remote Bass Control Ready (BC2 Sold Separetly)
Specifications
Number of Channels
Frequency Response (±1.0dB)
Signal-to-Noise Ratio (CEA-2006)
Noise Floor
Input Impedance
Input Sensitivity
High Level Input Sensitivity
Bass Boost
Power Output @ 2 Ohms (CEA-2006)
Power Output @ 4 Ohm (CEA-2006)
Dimensions (l x w x h)
1
16 Hz to 150Hz
>68 dB
< 1 mV
22 kOhms
0.2 to 0.6 V
0.6 to 2.0V
2 to 8V
0.4v to 1.2V
1.2 to 4V
4 to 16V
0 -15dB @ 45Hz
850W
460W
13-5/8"x10-1/8"x2-3/8"
70
Amplifiers - Specifications
DPX2251
APX4361
2/1 CHANNEL HYBRID CLASS GH AMPLIFIER
4/3/2 CHANNEL CLASS AB AMPLIFIER
•
•
•
•
• Class AB Audio Path
• IVS (Input Voltage Selector) Gain Control
• PFS (Precise Frequency Selector) Electronic High/Low-Pass
Crossover (50Hz to 550Hz/550Hz to 5.5kHz, 12 dB/octave)
• Variable Bass Boost Control (0 to 15dB @ 50Hz)
• Bridgeable and Mixed Mode operation
• Comlimentary Sanken Triple Darlington Output Transistors
• MOSFET Power Supply Devices
• F/R source select switch
• Speaker Level Inputs
• Double Sided FR4PC Board
• On-Board Diagnostics
• Gold-Plated RCA/Speaker/Power Connectors
• Illuminated Amplifier Shroud
•
•
•
•
•
•
•
•
•
Hybrid Class GH Power Supply
Class AB Audio Path
IVS (Input Voltage Selector) Gain Control
PFS (Precise Frequency Selector) Electronic High/Low-Pass
Crossover (50Hz to 550Hz/550Hz to 5.5kHz, 12 dB/octave)
Variable Bass Boost Control (0 to 15dB @ 50Hz)
Bridgeable and Mixed Mode operation
Comlimentary Sanken Triple Darlington Output Transistors
MOSFET Power Supply Devices
Speaker Level Inputs
Double Sided FR4PC Board
On-Board Diagnostics
Gold-Plated RCA/Speaker/Power Connectors
Illuminated Amplifier Shroud
Specifications
Number of Channels
Frequency Response (±1.0dB)
Signal-to-Noise Ratio (CEA-2006)
Noise Floor
Channel Separation
Input Impedance
Input Sensitivity
2
18 Hz to 30kHz
> 86 dB
< 1.5mV
> 70dB
22 kOhms
0.2 to 0.6 V
0.6 to 2.0V
2 to 8V
High Level Input Sensitivity
0.4v to 1.2V
1.2 to 4V
4 to 16V
Bass Boost
0 -15dB @ 45Hz
Power Output @ 4 Ohm Stereo (CEA-2006)
180W x 2
Power Output @ 2 Ohms Stereo (CEA-2006)
300W x 2
Power Output @ 4 Ohm Mono (CEA-2006)
600W x 1
Dimensions (l x w x h)
12-3/4"x10-1/8"x2-3/8"
71
Specifications
Number of Channels
Frequency Response (±1.0dB)
Signal-to-Noise Ratio (CEA-2006)
Noise Floor
Channel Separation
[email protected] Rated Output
Input Impedance
Input Sensitivity
4
10 Hz to 50kHz
> 86 dB
< 2mV
>70dB
0.05 %
33 kOhms
0.2 to 0.6 V
0.6 to 2.0V
2 to 8V
High Level Input Sensitivity
0.4v to 1.2V
1.2 to 4V
4 to 16V
Bass Boost
0 -15dB @ 50Hz
Power Output @ 4 Ohm Stereo (CEA-2006)
90W x 4
Power Output @ 2 Ohms Stereo (CEA-2006)
160W x 4
Power Output @ 4 Ohm Mono (CEA-2006)
320W x 2
Dimensions (l x w x h)
12-1/4"x10-1/8"x2-3/8"
Amplifiers -Specifications
APX2181
APX1301
2/1 CHANNEL CLASS AB AMPLIFIER
1 CHANNEL CLASS AB AMPLIFIER
• Class AB Audio Path
• IVS (Input Voltage Selector) Gain Control
• PFS (Precise Frequency Selector) Electronic High/Low-Pass
Crossover (50Hz to 550Hz/550Hz to 5.5kHz, 12 dB/octave)
• Variable Bass Boost Control (0 to 15dB @ 50Hz)
• Bridgeable and Mixed Mode operation
• Comlimentary Sanken Triple Darlington Output Transistors
• MOSFET Power Supply Devices
• Speaker Level Inputs
• Double Sided FR4PC Board
• On-Board Diagnostics
• Gold-Plated RCA/Speaker/Power Connectors
• Illuminated Amplifier Shroud
• Class AB Audio Path
• Adjustable Low-Pass Crossover
(30Hz to 300Hz, 12 dB/octave)
• Selectable Bass Boost (0dB, 6dB, 12dB)
• MOSFET Power Supply Devices
• Speaker Level Inputs
• Double Sided FR4PC Board
• Gold-Plated RCA/Speaker Connectors
Specifications
Number of Channels
Frequency Response (±1.0dB)
Signal-to-Noise Ratio (CEA-2006)
Noise Floor
Channel Separation
[email protected] Rated Output
Input Impedance
Input Sensitivity
2
10 Hz to 50kHz
> 86 dB
< 2mV
>70dB
0.05 %
33 kOhms
0.2 to 0.6 V
0.6 to 2.0V
2 to 8V
High Level Input Sensitivity
0.4v to 1.2V
1.2 to 4V
4 to 16V
Bass Boost
0 -15dB @ 50Hz
Power Output @ 4 Ohm Stereo (CEA-2006)
90W x 2
Power Output @ 2 Ohms Stereo (CEA-2006)
160W x 2
Power Output @ 4 Ohm Mono (CEA-2006)
320W x 1
Dimensions (l x w x h)
10"x10-1/8"x2-3/8"
Specifications
Number of Channels
Frequency Response (±1.0dB)
Signal-to-Noise Ratio (CEA-2006)
[email protected] Rated Output
Input Impedance
Input Sensitivity
Bass Boost
Power Output @ 2 Ohm (CEA-2006)
Power Output @ 4 Ohms (CEA-2006)
Dimensions (l x w x h)
1
10 Hz to 300Hz
> 70 dB
<0.1 %
22 kOhms
0.2V to 5.5V
0, 6dB, 12dB
400W x 1
300W x 1
11-7/8"x11"x2-1/4"
72
Amplifiers - Specifications
APX4241
APX2121
4/3/2 CHANNEL CLASS AB AMPLIFIER
2/1 CHANNEL CLASS AB AMPLIFIER
• Class AB Audio Path
• Independantly Adjustable Front and Rear High/Low-Pass
Crossovers (30Hz to 300Hz, 12 dB/octave)
• Selectable Bass Boost (0dB, 6dB, 12dB)
• MOSFET Power Supply Devices
• Speaker Level Inputs
• Double Sided FR4PC Board
• Gold-Plated RCA/Speaker Connectors
• Class AB Audio Path
• Adjustable High/Low-Pass Crossovers (30Hz to 300Hz, 12 dB/
octave)
• Selectable Bass Boost (0dB, 6dB, 12dB)
• MOSFET Power Supply Devices
• Speaker Level Inputs
• Double Sided FR4PC Board
• Gold-Plated RCA/Speaker Connectors
Specifications
Number of Channels
4
Frequency Response (±1.0dB)
20 Hz to 30kHz
Signal-to-Noise Ratio (CEA-2006)
> 75 dB
[email protected] Rated Output
<0.1 %
Input Impedance
22 kOhms
Input Sensitivity
0.2V to 5.5V
Bass Boost
0, 6dB or 12dB
Power Output @ 4 Ohms Stereo (CEA-2006)
60W x 4
Power Output @ 2 Ohms Stereo (CEA-2006)
80W x 4
Power Output @ 4 Ohms Mono (CEA-2006)
180W x 2
Dimensions (l x w x h)
11-7/8"x11"x2-1/4"
Specifications
Number of Channels
2
Frequency Response (±1.0dB)
20 Hz to 30kHz
Signal-to-Noise Ratio (CEA-2006)
> 85 dB
[email protected] Rated Output
<0.1 %
Input Impedance
22 kOhms
Input Sensitivity
0.2V to 5.5V
Bass Boost
0, 6dB or 12dB
Power Output @ 4 Ohms Stereo (CEA-2006)
60W x 2
Power Output @ 2 Ohms Stereo (CEA-2006)
80W x 2
Power Output @ 4 Ohms Mono (CEA-2006)
180W x 1
Dimensions (l x w x h)
7-1/8" x 11"x2-1/4"
73
Processors - EQS746 / MCD360
EQS746
MCD360
1/2-DIN GRAPHIC EQUALIZER/CROSSOVER
3-WAY ELECTRONIC CROSSOVER
• 7-Band Graphic Equalizer
• Front panel selectable Main/Auxiliary Inputs
• Front/Rear output with fader and subwoofer output with
subwoofer level control
• Selectable Subwoofer Low-Pass Frequency at 60 or 90 Hz
• 6-Channel/7-Volt RCA Line-Level Output
• Auxiliary input sensitivity
• Blue Illumination
•
•
•
•
•
•
•
•
Specifications
Power Source:
Frequency Response
Signal-to-Noise Ratio
Output Voltage
Center Frequencies
Specifications
Power Source:
Frequency Response
Signal-to-Noise Ratio
Separation
High-Pass Frequency Range
Dimensions (w x h x d)
14.4V DC Negative Ground
10 Hz to 50 kHz
100 dB
7.0 Vrms
50Hz, 125Hz, 125Hz,
315Hz, 750Hz, 2.2kHz,
6kHz, 16kHz
7" x 1-1/8" x 4-1/16"
18 dB/Octave Slope-Variable Crossovers
Front, Rear and Subwoofer Outputs with Level Controls
Built-in Bass EQ
Super-Flexible Design
Remote Subwoofer Level Control
Crossover-Frequency Multiplier Switch
2/4/6 Channels of Input
Separate Front and Rear Crossover Points
14.4V DC Negative Ground
10 Hz to 50 kHz
>100 dB
60dB
32 Hz to 8 kHz, Front
32 to 400 Hz, Rear
Subwoofer Equalizer Center Frequency 25 to 100 Hz
Subwoofer Equalizer Boost
0 to 18 dB
Output Voltage
5.0 Vrms
Ouput Impedance
100 Ohms
Input Impedance
20k Ohms
Crossover Slope Rate
18dB/Octave
Crossover Characteristics
Butterworth
Ouput Gain
1:2 (+6dB)
Distortion
0.01% THD at 1V
Dimensions (w x h x d)
5-1/2" x 1-3/4" x 5 -1/2"
74
Subwoofers
Subwoofers – Technologies
Signature Series Woofers
Canada Only Model
Powder coated damped aluminum basket
Providing a stable platform for the speaker to
work from is critical. The cast and powder coated aluminum baskets used in Signature Series
speakers feature a low resonance design and
incredible strength.
Spring Loaded Terminals
Clarion’s dedication to Sound Genesis - reproducing music as it was originally played - is
taken to a new level with the re-introduction of
the Signature Series line of component speakers
and subwoofers. These products use the latest
technologies to produce music that is dynamic,
accurate and easy to listen to.
Composite Cone Design
The cone of any speaker must balance three
important criteria to recreate music accurately
- mass, damping and rigidity. The Composite
Cone Design used on the Signature Series speakers is the secret to their incredible performance.
The cone is a sandwich of glass fibre and PMI
(Polymethacrylimide) foam. This cone is extremely low in mass, while being rigid and well damped
at the same time.
The speaker terminals are spring loaded pushtypes with minimal contact resistance and high
transmission efficiency. These connections allow
for a quick connection that is reliable.
3-Inch Aluminum Voice Coil Former
At the heart of Signature Series subwoofers is
a 3-inch diameter aluminum voice coil former.
This former helps wick heat away from the voice
coil winding for improved power handling. The
Aluminum former doesn’t add significant mass to
the cone , resulting in excellent response.
4-layer CCAW Voice Coil winding
The Signature Series subwoofers employ a
four-layer Copper Clad Aluminum Wire winding design. The dual voice coil design is low in
mass, but helps create an intense magnetic field,
further improving transient response. The voice
coil winding length is 60mm. Thise ensures linear
operation at high excursion levels.
Dual Spider Design
Rubber Surround
Signature Series speakers feature a rubber surround for enhanced flexibility, low distortion and
reliability.
Because of the massive amounts of power that
the Signature Series subwoofer can handle, the
design requires two Conex spiders to ensure
linear motion throughout the drivers range. The
bottom spider is inverted to cancel out any nonlinearities present.
76
Subwoofers – Technologies
Spider Exhaust Technology
PXW Subwoofers
If you look at the base of the basket of a Signature
Series subwoofer, you will see many mesh-protected vents. These vents serve two purposes.
First and foremost, they allow hot air to escape
from the voice coil, helping to improve power
handling. These vents also relieve pressure from
underneath the spider, reducing distortion and
improving linearity at high excursion levels.
Clarion PXW subwoofers have been designed to
offer the best possible performance, while featuring design characteristics found in speakers costing two to three times as much.
High Excursion Design
Reproducing low frequencies at high levels
requires a significant amount of air to be moved.
Signature Series subwoofers have an Xmax
specification of 25mm (1-inch) for extreme low
frequency output.
Bumped and Vented Pole Piece
The vent in the pole piece of the Signature Series
subwoofers allows for the release of air pressure
beneath the dust cap which allows for more linear cone motion. It also allows hot air to escape
from the inside of the voice coil assembly - further
improving the speakers ability to handle high levels of power. The bump provides additional space
for the 3-inch aluminum voice coil to move up
and down, providing linear speaker operation and
incredible excursion capabilities.
Custom Designed Die-Cast Aluminum
Basket
The foundation of any subwoofer is its basket.
This is what holds all the components in alignment, ensuring reliable and linear operation. The
new Clarion PXW subwoofers feature a massive
die-cast aluminum basket structure that not only
looks formidable, but offers a rock-steady foundation for the motor and cone assembly.
Spider Exhaust Technology
Keeping the voice coil assembly of a subwoofer
cool is paramount to making sure the driver lasts
and sounds good. As the motor assembly (voice
coil, magnet, top and bottom plates) heat up, they
become less efficient - this is known as power
compression.
A speaker that can better dissipate heat will
sound better and last longer. Clarion PXW subwoofers feature SET (Spider Exhaust Technology)
cooling to allow heat generated from the voice
coil assembly to escape from the area beneath
the spider.
SET also allows pressurized air to escape from
beneath the spider. This improves overall speaker
77
Subwoofers – Technologies
linearity, especially at high excursion levels.
The PXW subwoofer allows hot air to escape
through the spokes of the basket. If you look
inside the basket, you can see that each spoke is
hollow. This extends to below the spider mounting plateau, providing ventilation and cooling.
Gold Plated Terminal Blocks
A solid electrical connection is mandatory to
ensuring reliable speaker operation. The new
PXW subwoofers feature custom-tooled
terminal blocks that will secure up to an 8 AWG
conductor.
Sewn Tinsel Leads
The connection between the voice coil and the
terminal block is critical, since all the power sent
to the speaker gets transferred through these
connections. PXW subwoofers feature massively
oversized braided tinsel leads for excellent power
transfer.
Dual Strontium Ferrite Magnets
There are many ways to alter the efficiency of a
speaker. The most common method is to adjust
the magnetic field strength by altering the gap
between the voice coil and top plate. Clarion has
implemented dual high-quality Strontium Ferrite
magnets in all PXW subwoofers. This provides an
intense magnetic field for excellent efficiency, as
well as controlled, dynamic performance.
To ensure silent and reliable operation, the tinsel
leads have been sewn to the spider at the bottom
of each roll. This allows the tinsel lead to flex
independently of the spider, preventing changes
in driver compliance at different excursion levels.
This feature also allows the tinsel leads to operate
completely silently.
An additional benefit of this large motor structure
is its thermal mass. This helps dissipate heat from
the voice coil to further improve performance.
Hyper Extended Vented Pole Piece
The T-Yoke (Bottom plate) on all PXW subwoofers
features a large cooling vent that is protected by
a mesh screen. This vent serves two purposes. It
allows heated air to escape from the inside of the
voice coil and allows pressurized air to escape
from beneath the dust cap. The mesh screen
keeps debris out of the narrow-gap voice coil
gap area.
The bottom of the pole piece has been extended
to allow increased excursion capabilities from the
PXW subwoofers. Conventional designs result in
the voice coil bumping into the bottom plate.
Linear Roll Poly-Cotton Spiders
Linear spiders offer extremely linear cone motion
control. This means that the new Clarion PXW
subwoofers will sound good while operating at
low levels and remain controlled and dynamic
when being pushed to high excursions.
Dual Heat Resistant Voice Coils
All PXW subwoofers feature Dual Voice Coil
designs. You have your choice of dual 2 Ohm or
dual 4 Ohm for 1, 2, 4 or 8 Ohm Impedances.
This ensures that Clarion PXW subwoofers will
work perfectly to achieve the maximum power
potential when connected to any amp on the
market.
78
Subwoofers – Technologies
You can tell which driver you are ordering by the
last number in the model. The PXW1x51 are dual
2 Ohm drivers and PXW1x52 are dual 4 Ohm
driver. If you parallel the voice coils, you get the
number at the end of the model number.
PXW1051
PXW1052
PXW1251
PXW1252
PXW1552
Dual 2 Ohm
Dual 4 Ohm
Dual 2 Ohm
Dual 4 Ohm
Dual 4 Ohm
1 or 4 Ohms
2 or 8 Ohms
1 or 4 Ohms
2 or 8 Ohms
2 or 8 Ohms
Kevlar / Paper Composite Cone Design
The balance between strength and mass in a
woofer cone is of the utmost importance. The
cone of the PXW subwoofers is a composite of
pulp paper and Kelvar Fibers.
Polypropylene Electrolytic Spun
Aluminum Coated Dust Cap
The dust cap on PXW subwoofers contains more
engineering than meets the eye. The shape of the
dust cap, with this five reinforcing spokes, adds
significant strength to the design. Each spoke
triangulates the center of the cone, ensuring it
does not flex during motion.
The dust cap covers the entire face of the
subwoofer to add strength to the Kevlar/
Paper reinforced cone beneath. The dust cap
triangulates the outer edge of the cone below,
further strengthening the assembly.
The dust cap features an electrolytically applied
spun aluminum finish.
Paper cones have excellent strength to mass
properties, but can soften slightly in high humidity
environments. To rectify this, Clarion mixes Kevlar
fibers into the pulp paper mixture. These fibers
produce a much stronger cone that offers better
resistance to changing environmental conditions.
Hidden Screw Mounting Gasket
CoPolymer Composite High Excursion
Surround
The surround at the outer edge of the cone serves
three important duties - it provides compliance to
the cone assembly, it damps the cone assembly,
and it allows the speaker cone to travel through
its range of motion while maintaining an airtight
seal.
Clarion PXW subwoofers feature a synthetic
rubber surround that provides the flexibility of
foam while offering the reliability and longevity of
rubber. The shape of the surround allows the cone
to travel through its range of motion unimpaired
for increased linearity.
79
The new PXW subwoofers feature a custom tooled
rubber mounting gasket. This gasket ensures
a perfectly airtight seal against the face of an
enclosure, and conceals the mounting hardware
for a clean, attractive installation. The gasket can
be removed and reversed for installations that will
show the rear of the subwoofer.
Subwoofers – Technologies
PFW subwoofer
important. The new PFW subwoofer sounds
excellent in a vented enclosure. The optimum
volume being 0.5 cubic feet with a 2" dia vent, 9.5
inches long for excellent low frequency extension
and power handling.
SRW subwoofers
The evolution of the shallow-mount subwoofer the PFW1051.
This subwoofer was designed to offer the best
possible performance from a driver that requires
only three inches of mounting depth.
Clarion chose not to add additional expense
to the PFW subwoofer by implementing
overly exotic material applications or complex
suspension designs - instead we simply took
everything that makes the PXW subwoofers great,
and compressed it into a shallower package.
Reliable, easy to install and great sounding - the
PFW1051.
Learning from our success with the PXW
subwoofers, Clarion introduces the third
generation SRW line of subwoofers. Many of
the technologies and features found on the PXW
subwoofers have made their way to the SRW
series.
Paper / Glass Fiber Composite Cone
Design
The balance between strength and mass in a
woofer cone is of the utmost importance. The
cone of the SRW subwoofers is a composite of
pulp paper and glass fibers.
Single Voice Coil
Unlike the PXW subwoofers, the PFW1051 is
available only in a single 4 Ohm voice coil
configuration with a 300W continuous, 600W
Maximum thermal power handling rating.
Paper cones have excellent strength to mass
properties, but can soften slightly in high humidity
environments. To rectify this, Clarion mixes glass
fibers into the pulp paper mixture. These fibers
produce a much stronger cone that offers better
resistance to changing environmental conditions.
Small Enclosure Requirements
Building a subwoofer that looks impressive is one
thing, but ensuring it will perform in the kind of
applications people want is equally, if not more
Powder Coated Steel Basket
Building a woofer that sounds good is one thing,
but todays demanding autosound enthusiasts
80
Subwoofers – Technologies
want their woofers to look good at the same
time. The new SRW subwoofers were designed
with this in mind. The powder coated stamped
steel basket emulates the design of the PXW
subwoofer, providing a stable, solid foundation.
is higher than conventional ferrite magnets.
Combining this magnet with our heat-resistant
voice coil and the result is a line of subwoofers
that are able to deliver high SPLs with excellent
sound quality
Rear-Vented Pole Piece
Nitrile Butadiene Rubber Surround
To prevent pressure from building up under the
dust cap and causing distortion and nonlinearities,
a vent is provided on the rear of the pole piece.
This allows for smooth cone movement, which
contributes to smooth, powerful bass response.
Ensuring a reliable and flexible connection
between the cone assembly and the basket is an
NBR rubber surround
SFW Subwoofers
This vent also allows hot air to exit from the inside
of the voice coil and motor assembly. Heat is the
enemy of every speaker. Improved cooling means
that your subwoofer will play louder, longer.
S.E.T. - Spider Exhaust Technology
Adding to the arsenal of 'cool technolgies' is Spider
Exhaust Technology. Cooling vents incorporated
into the spider mounting frame provide a path for
hot air to escape from the voice coil. These vents
also release pressure from behind the spider,
helping to improve performance and reduce
distortion.
Gold Plated Terminal Blocks
Terminal blocks allow for secure and solid
electrical connections to be made to the woofer.
The terminal blocks will easily accept 8 AWG
cables for efficient current transfer.
Just as the PFW is a shallow version of the PXW
subwoofer, so is the SFW subwoofer a shallow
version of the SRW sub. We took everything
that made the SRW great and compressed it in
a package that requires less than 3 inches of
mounting depth.
The SFW1051 features a single 4 Ohm voice coil
winding with a rated continuous thermal power
handling of 300W. A single strontium ferrite
magnet enclosed by a stamped steel basket
provides a serious kick.
Kapton Voice Coil Former
Helping to dissipate heat and increase speaker
longevity is a Kapton voice coil former. Kapton is
a Polymide Film developed by DuPont. Kapton
offers an excellent balance of thermal resistance
and low mass. This helps to reduce the overall
moving mass of the driver and provides quicker
transient response and improved dynamics.
Powerful Strontium Magnet
high conductivity double-stacked Strontium
magnets are used in the SRW subwoofers to
obtain an air-gap magnetic flux density that
81
Building a shallow subwoofer is one thing, but
providing one that performs is another. The
SFW1051 was designed to offer 'big sub' bass in
a small space. A vented enclosure with an internal
volume of 0.5 cubic feet, tuned to 35Hz sounds
fantastic and the combination works great when
powered by the APX1301 amplifier.
Subwoofers – Technologies
SW Subwoofers
contributes to linear, powerful bass response.
Providing performance at an unbeatable price
are the SW1051 and SW1251 subwoofers
from Clarion. These subwoofers feature many
of the same technologies as the SRW and
PXW subwoofers, including a vented pole
piece, Polypropylene dust cap, Strontium Ferrite
Magnets, and high temperature voice coil
formers.
This vent also allows hot air to exit from the inside
of the voice coil and motor assembly. Heat is the
enemy of every speaker. Improved cooling means
that your subwoofer will play louder, longer.
Small Enclosure Requirements
Clarion SW series subwoofers will produce tight,
musical bass from very small enclosures. Not
having to waste valuable trunk space means you
can fit more woofers in the same space, or have
room for your personal belongings.
Powerful Strontium Magnet Assembly
High Temperature Voice Coil Assembly
SW subwoofers are designed with a single high
temperature 4 Ohm voice coil. The voice coil is
wrapped around a 2-inch Kapton former for solid
and reliable performance.
Spider Exhaust Technology (SET)
Additional cooling is provided thanks to a series
of cooling vents that are incorporated into the top
of the voice coil former. These vents allow hot air
to escape from underneath the spider, as well as
preventing this air from becoming pressurized
during high excursion levels.
A high conductivity double-stacked magnet is
used in the SW subwoofers to obtain an airgap magnetic flux density that is higher than
conventional ferrite magnets. Combining this
magnet with a heat-resistant voice coil results
in a subwoofer that is able to deliver high output
levels while sounding great.
Rubber Coated Tinsel Leads
SW subwoofers feature gold plated electrical
terminals for a reliable connection. The tinsel
leads that run from the terminals to the voice coil
are encased in rubber to ensure they will never
short against anything. This rubber casing also
helps damp their movement, ensuring the driver
operates without mechanical noise that would
interfere with music reproduction.
Powder Coated Steel Basket
SW subwoofers are based on a stamped steel
basket that has been treated to a textured black
powder coat finish. The basket features spokes
that have their edges rolled over for additional
strength.
Rear-Vented Pole Piece
To prevent pressure from building up under the
dust cap and causing distortion and nonlinearities,
a vent is provided on the rear of the pole piece.
This allows for smooth cone motion, which
82
Subwoofers – SSW1001 Information
SSW1001 (Canadian Model)
10" DUAL VOICE COIL SIGNATURE SERIES
SUBWOOFER
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Composite Cone Design
Powder Coated Damped Aluminum Basket
Butyl Rubber Surround
Dual High-Performance Conex Spiders
4-Layer CCAW Voice Coil
3” aluminum voice coil bobbin
Dual 4-Ohm Voice Coils
Dual Strontium Ferrite Magnets (85.5 Oz each)
Oversized tinsel leads
Gold-Plated Push Type Terminals
S.E.T. (Spider Exhaust Technology) cooling
Chrome Plated, Bumped and Vented T-Yoke
Injection-moulded rubber mounting gasket
Custom Tooled Magnet Boot
Subwoofer Class
10"
Mounting Hole
231 mm
Mounting Depth
175 mm
Outside Diameter
275 mm
Max. Peak Music
2000 W
Continuous Power
1000 W
Fs (Hz)
33.5
Qms
4.27
Vas (Liters)
15.1
Mms (grams)
190.7
Xmax (mm)
24.0
Qes
0.753
Re (Ohms)
1.6
Le (mH)
n/a
Z (ohms)
1.92
Qts
0.64
no (%)
0.0727
1-W SPL (dB)
80.76
2.8 V SPL (dB)
87.75
83
1
2
3
4
5
6
7
8
9
Rubber Surround
Composite Cone Design
Dual Linear Conex Spiders
Spring Loaded Terminals
3-inch 4-Layer Voice Coil on Aluminum former
Spider Exhaust Technology
Dual Magnet Assembly
Extended Bottom Plate
Cast Aluminum Chassis
Subwoofers – SSW1201 Information
SSW1201 (Canadian Model)
12" DUAL VOICE COIL SIGNATURE SERIES
SUBWOOFER
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Composite Cone Design
Powder Coated Damped Aluminum Basket
Butyl Rubber Surround
Dual High-Performance Conex Spiders
4-Layer CCAW Voice Coil
3” Black Anodized aluminum voice coil bobbin
Dual 4-Ohm Voice Coils
Dual Strontium Ferrite Magnets (85.5 Oz each)
Oversized tinsel leads
Gold-Plated Push Type Terminals
S.E.T. (Spider Exhaust Technology) cooling
Chrome Plated, Bumped and Vented T-Yoke
Injection-moulded rubber mounting gasket
Custom Tooled Magnet Boot
Subwoofer Class
12"
Mounting Hole
231 mm
Mounting Depth
175 mm
Outside Diameter
275 mm
Max. Peak Music
2000 W
Continuous Power
1000 W
Fs (Hz)
26.82
Qms
4.681
Vas (Liters)
41.84
Mms (grams)
270
Xmax (mm)
24
Qes
0.578
Re (Ohms)
1.468
Le (mH)
1.517
Z (ohms)
7.0704
Qts
0.514
no (%)
0.135
1-W SPL (dB)
87.57
2.8 V SPL (dB)
88.89
1
2
3
4
5
6
7
8
9
Rubber Surround
Composite Cone Design
Dual Linear Conex Spiders
Spring Loaded Terminals
3-inch 4-Layer Voice Coil on Aluminum former
Spider Exhaust Technology
Dual Magnet Assembly
Extended Bottom Plate
Cast Aluminum Chassis
84
Subwoofers – PXW1051/1052 Information
PXW1051 T-S Parameters
PXW1051 / PXW1052 Features
•
•
•
•
•
•
•
•
•
•
•
•
•
Black Powder Coat Die Cast Aluminum Basket
Polypropylene Electrolytic Spun Aluminum Coated Dust Cap
Kevlar / Paper Composite Cone
Co-Polymer Composite high-excursion surround
Dual Strontium Ferrite Magnets
Hyper Extended Pole Piece Assembly
Dual Voice Coils
Custom Tooled Gold Plated terminal blocks
S.E.T. (Spider Exhaust Technology) cooling / venting
Mesh Covered Vented Pole Piece
Reversable hidden screw mounting gasket
1,000-Watt Maximum Music Power
500-Watt Continuous Power Handling
Dimensions
85
Fs (Hz)
Qms
VAS (Litres)
VAS (Cubic Feet)
MMs (Grams)
Xmax (mm)
Xmax (inches)
Sd (m2)
Qes (Series / Parallel)
Re (Serial / Parallel)
Le (Series / Parallel)
Z (Series / Parallel)
Bl (Series / Parallel)
Qts (Series / Parallel)
dB SPL (1W/1M)
Power (RMS / MAX)
Vd (Cubic Feet)
Outside Diameter
Mounting Hole
Mounting Depth
Total Height
Total Weight
30.86
6.474
32.95
1.164
126.9
12
0.472
0.0333
0.509 / 0.556
6.474 / 3.865
4.93 / 1.225
7.768 / 4.638
13.68 / 16.93
0.472 / 0.512
84.8
500 / 1000
0.12
10-9/16"
9-1/8"
5-5/16"
6-3/16"
14.8 lbs
PXW1052 T-S Parameters
Fs (Hz)
Qms
VAS (Litres)
VAS (Cubic Feet)
MMS (Grams)
Xmax (mm)
Xmax (inches)
Sd (m2)
Qes (Series / Parallel)
Re (Serial / Parallel)
Le (Series / Parallel)
Z (Series / Parallel)
Bl (Series / Parallel)
Qts (Series / Parallel)
dB SPL (1W/1M)
Power (RMS / MAX)
Vd (Cubic Feet)
Outside Diameter
Mounting Hole
Mounting Depth
Total Height
Total Weight
33.56
6.206
30.17
1.065
117.2
12
0.472
0.0333
0.55 / 0.612
6.926 / 1.909
7.872 / 1.961
7.311 / 2.291
17.64 / 8.778
0.505 / 0.557
85.16
500 / 1000
0.12
10-9/16"
9-1/8"
5-5/16"
6-3/16"
14.8 lbs
Subwoofers – PXW1251/1252 Information
PXW1251 T-S Parameters
PXW1251 / PXW1252 Features
•
•
•
•
•
•
•
•
•
•
•
•
•
Black Powder Coat Die Cast Aluminum Basket
Polypropylene Electrolytic Spun Aluminum Coated Dust Cap
Kevlar / Paper Composite Cone
Co-Polymer Composite high-excursion surround
Dual Strontium Ferrite Magnets
Hyper Extended Pole Piece Assembly
Dual Voice Coils
Custom Tooled Gold Plated terminal blocks
S.E.T. (Spider Exhaust Technology) cooling / venting
Mesh Covered Vented Pole Piece
Reversable hidden Screw mounting gasket
1,000-Watt Maximum Music Power
500-Watt Continuous Power Handling
Dimensions
Fs (Hz)
Qms
VAS (Litres)
VAS (Cubic Feet)
MMs (Grams)
Xmax (mm)
Xmax (inches)
Sd (m2)
Qes (Series / Parallel)
Re (Serial / Parallel)
Le (Series / Parallel)
Z (Series / Parallel)
Bl (Series / Parallel)
Qts (Series / Parallel)
dB SPL (1W/1M)
Power (RMS / MAX)
Vd (Cubic Feet)
Outside Diameter
Mounting Hole
Mounting Depth
Total Height
Total Weight
30.76
6.759
67.73
2.392
142.6
12
0.472
0.0333
0.593 / 0.692
3.832 / 1.116
4.843 / 1.2
4.598 / 1.339
13.34 / 6.666
0.545 / 0.628
87.2
500 / 1000
0.15
12-7/16"
11-0"
6-1/8"
7-0"
16.5 lbs
PXW1252 T-S Parameters
Fs (Hz)
Qms
VAS (Litres)
VAS (Cubic Feet)
MMs (Grams)
Xmax (mm)
Xmax (inches)
Sd (m2)
Qes (Series / Parallel)
Re (Serial / Parallel)
Le (Series / Parallel)
Z (Series / Parallel)
Bl (Series / Parallel)
Qts (Series / Parallel)
dB SPL (1W/1M)
Power (RMS / MAX)
Vd (Cubic Feet)
Outside Diameter
Mounting Hole
Mounting Depth
Total Height
Total Weight
34.27
7.15
62.76
2.216
117.2
12
0.472
0.0504
0.62 / 0.726
7.192 / 1.978
7.206 / 1.786
8.63 / 2.374
17.59 / 8.53
0.571 / 0.659
88.08
500 / 1000
0.15
12-7/16"
11-0"
6-1/8"
7-0"
16.5 lbs
86
Subwoofers – PXW1552 Information
PXW1552 T-S Parameters
PXW1552 Features
•
•
•
•
•
•
•
•
•
•
•
•
•
Black Powder Coat Die Cast Aluminum Basket
Polypropylene Electrolytic Spun Aluminum Coated Dust Cap
Kevlar / Paper Composite Cone
Co-Polymer Composite high-excursion surround
Dual Strontium Ferrite Magnets
Hyper Extended Pole Piece Assembly
Dual 4-Ohm Voice Coils
Custom Tooled Gold Plated terminal blocks
S.E.T. (Spider Exhaust Technology) cooling / venting
Mesh Covered Vented Pole Piece
Reversable hidden screw mounting gasket
1,500-Watt Maximum Music Power
750-Watt Continuous Power Handling
Dimensions
87
Fs (Hz)
Qms
VAS (Litres)
VAS (Cubic Feet)
MMs (Grams)
Xmax (mm)
Xmax (inches)
Sd (m2)
Qes (Series / Parallel)
Re (Serial / Parallel)
Le (Series / Parallel)
Z (Series / Parallel)
Bl (Series / Parallel)
Qts (Series / Parallel)
dB SPL (1W/1M)
Power (RMS / MAX)
Vd (Cubic Feet)
Outside Diameter
Mounting Hole
Mounting Depth
Total Height
Total Weight
23.28
5.927
193.1
6.818
269.2
12.5
0.492
0.885
0.532 / 0.602
7.092 / 1.954
9.216 / 2.267
8.51 / 2.345
22.9 / 11.31
0.488 / 0.546
88.6
750 / 1,500
0.21
15-15/16"
14-1/4"
7"
7-13/16"
23.55 lbs
Subwoofers – PFW1051 Information
PFW1051 T-S Parameters
PFW1051 Features
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Black Powder Coat Die Cast Aluminum Basket
Less than 3" mounting depth
Polypropylene Electrolytic Spun Aluminum Coated Dust Cap
Kevlar / Paper Composite Cone
Co-Polymer Composite high-excursion surround
Strontium Ferrite Magnets
Extended Pole Piece Assembly
Singlel 4-Ohm Voice Coils
Custom Tooled Gold Plated terminal blocks
S.E.T. (Spider Exhaust Technology) cooling / venting
Mesh Covered Vented Pole Piece
Reversable hidden screw mounting gasket
600-Watt Maximum Music Power
300-Watt Continuous Power Handling
Fs (Hz)
Qms
VAS (Litres)
VAS (Cubic Feet)
MMs (Grams)
Xmax (mm)
Xmax (inches)
Sd (m2)
Qes
Re
Le
Z
Bl
Qts
dB SPL (1W/1M)
Power (RMS / MAX)
Vd (Cubic Feet)
Outside Diameter
Mounting Hole
Mounting Depth
Total Height
Total Weight
41.29
6.569
27.21
0.961
84.76
5.5
0.217
0.0331
0.541
3.302
2.921
3.962
11.59
0.5
87.48
300 / 600
0.045
10-9/16"
9-1/8"
2-3/4"
3-5/8"
9.8 lbs
Dimensions
88
Subwoofers – SRW1051 Information
SRW1051
10" SINGLE VOICE COIL SUBWOOFER
•
•
•
•
•
•
•
•
•
•
Polypropylene Electrolytic Spun Aluminum Dust Cap
Paper / Glass Fiber Cone Design
Nitrile Butadiene Rubber High Excursion Surround
Dual Strontium Ferrite Magnets
Hyper Extended Pole Piece
Linear Cotton Spider with Integrated Tinsel Leads
Gold Plated Terminal Blocks
Custom Stamped Steel Powder Coated Chassis
Spider Exhaust Technology voice coil cooling
Vented Pole Piece
Subwoofer Class
10"
Mounting Hole
9-1/32"
Mounting Depth
4-9/16"
Outside Diameter
10-17/32"
Max. Peak Music
750
Continuous Power
375
Fs (Hz)
31.75
Qms
9.02
Vas (Liters)
29.01
Mms (grams)
121.5
Xmax (mm)
12
Qes
0.499
Re (Ohms)
3.67
Le (mH)
1.41
Z (ohms)
4.404
Qts
0.473
no (%)
0.179
1-W SPL (dB)
84.68
2.8 V SPL (dB)
88.07
89
Subwoofers – SRW1052 Information
SRW1052
10" DUAL VOICE COIL SUBWOOFER
•
•
•
•
•
•
•
•
•
•
Polypropylene Electrolytic Spun Aluminum Dust Cap
Paper / Glass Fiber Cone Design
Nitrile Butadiene Rubber High Excursion Surround
Dual Strontium Ferrite Magnets
Hyper Extended Pole Piece
Linear Cotton Spider with Integrated Tinsel Leads
Gold Plated Terminal Blocks
Custom Stamped Steel Powder Coated Chassis
Spider Exhaust Technology voice coil cooling
Vented Pole Piece
Subwoofer Class
10"
Mounting Hole
9-1/32"
Mounting Depth
4-9/16"
Outside Diameter
10-17/32"
Max. Peak Music
750
Continuous Power
375
Fs (Hz)
32.49
Qms
7.243
Vas (Liters)
30.6
Mms (grams)
109.9
Xmax (mm)
12
Qes
0.499
Re (Ohms)
7.36
Le (mH)
2.465
Z (ohms)
8.832
Qts
0.467
no (%)
0.203
1-W SPL (dB)
85.22
2.8 V SPL (dB)
85.58
90
Subwoofers – SRW1251 Information
SRW1251
12" SINGLE VOICE COIL SUBWOOFER
•
•
•
•
•
•
•
•
•
•
Polypropylene Electrolytic Spun Aluminum Dust Cap
Paper / Glass Fiber Cone Design
Nitrile Butadiene Rubber High Excursion Surround
Dual Strontium Ferrite Magnets
Hyper Extended Pole Piece
Linear Cotton Spider with Integrated Tinsel Leads
Gold Plated Terminal Blocks
Custom Stamped Steel Powder Coated Chassis
Spider Exhaust Technology voice coil cooling
Vented Pole Piece
Subwoofer Class
Mounting Hole
12"
10-29/32"
Mounting Depth
4-3/4"
Outside Diameter
12-15/32"
Max. Peak Music
800
Continuous Power
400
Fs (Hz)
31.75
Qms
7.227
Vas (Liters)
59.01
Mms (grams)
145.7
Xmax (mm)
12
Qes
0.592
Re (Ohms)
3.72
Le (mH)
1.505
Z (ohms)
4.464
Qts
0.547
no (%)
0.307
1-W SPL (dB)
87.02
2.8 V SPL (dB)
90.35
91
Subwoofers – SRW1252 Information
SRW1252
12" DUAL VOICE COIL SUBWOOFER
•
•
•
•
•
•
•
•
•
•
Polypropylene Electrolytic Spun Aluminum Dust Cap
Paper / Glass Fiber Cone Design
Nitrile Butadiene Rubber High Excursion Surround
Dual Strontium Ferrite Magnets
Hyper Extended Pole Piece
Linear Cotton Spider with Integrated Tinsel Leads
Gold Plated Terminal Blocks
Custom Stamped Steel Powder Coated Chassis
Spider Exhaust Technology voice coil cooling
Vented Pole Piece
Subwoofer Class
Mounting Hole
10"
10-29/32"
Mounting Depth
4-3/4"
Outside Diameter
12-15/32
Max. Peak Music
800
Continuous Power
400
Fs (Hz)
Qms
31.03
7.2
Vas (Liters)
68.69
Mms (grams)
131.9
Xmax (mm)
12
Qes
0.641
Re (Ohms)
7.21
Le (mH)
2.721
Z (ohms)
8.652
Qts
0.589
no (%)
0.309
1-W SPL (dB)
87.04
2.8 V SPL (dB)
87.5
92
Subwoofers – SFW1051 Information
SFW1051
10" SHALLOW MOUNT SINGLE VOICE COIL
SUBWOOFER
•
•
•
•
•
•
•
•
•
•
Polypropylene Electrolytic Spun Aluminum Dust Cap
Paper / Glass Fiber Cone Design
Nitrile Butadiene Rubber High Excursion Surround
Strontium Ferrite Magnet
Extended Pole Piece
Linear Cotton Spider with Integrated Tinsel Leads
Gold Plated Terminal Blocks
Custom Stamped Steel Powder Coated Chassis
Spider Exhaust Technology voice coil cooling
Vented Pole Piece
Subwoofer Class
10"
Mounting Hole
9-1/32"
Mounting Depth
2-25/32"
Outside Diameter
10-17/32"
Max. Peak Music
600
Continuous Power
300
Fs (Hz)
37.32
Qms
8.635
Vas (Liters)
19.08
Mms (grams)
133.6
Xmax (mm)
5.5
Qes
0.619
Re (Ohms)
3.75
Le (mH)
1.104
Z (ohms)
4.5
Qts
0.578
no (%)
0.154
1-W SPL (dB)
84.03
2.8 V SPL (dB)
87.33
93
Subwoofers – SW1251 Information
SW1251
12" SINGLE VOICE COIL SUBWOOFER
•
•
•
•
•
•
•
Polypropylene Electrolytic Spun Aluminum Dust Cap
Nitrile Butadiene Rubber High Excursion Surround
Dual Strontium Ferrite Magnets
Hyper Extended Pole Piece
Linear Cotton Spider
Custom Stamped Steel Powder Coated Chassis
Vented Pole Piece
Subwoofer Class
Mounting Hole
12"
12-9/32"
Mounting Depth
6-7/16"
Outside Diameter
11-1/32"
Max. Peak Music
700
Continuous Power
350
Fs (Hz)
29.89
Qms
6.573
Vas (Liters)
67.92
Mms (grams)
172.3
Xmax (mm)
12
Qes
0.685
Re (Ohms)
3.66
Le (mH)
1.845
Z (ohms)
4.392
Qts
0.62
no (%)
0.255
1-W SPL (dB)
86.22
2.8 V SPL (dB)
89.61
94
Subwoofers – SW1051 Information
SW1051
10" SINGLE VOICE COIL SUBWOOFER
•
•
•
•
•
•
•
Polypropylene Electrolytic Spun Aluminum Dust Cap
Nitrile Butadiene Rubber High Excursion Surround
Dual Strontium Ferrite Magnets
Hyper Extended Pole Piece
Linear Cotton Spider
Custom Stamped Steel Powder Coated Chassis
Vented Pole Piece
Subwoofer Class
10"
Mounting Hole
9-1/8"
Mounting Depth
5-3/4"
Outside Diameter
10-5/16"
Max. Peak Music
600
Continuous Power
300
Fs (Hz)
35.632
Qms
5.722
Vas (Liters)
25.761
Mms (grams)
131.93
Xmax (mm)
12
Qes
0.646
Re (Ohms)
3.64
Le (mH)
0.721
Z (ohms)
4.368
Qts
0.58
no (%)
0.174
1-W SPL (dB)
84.55
2.8 V SPL (dB)
87.97
95
SSW1201 Enclosures (Canadian Model)
Sealed Enclosure - Sound Quality
Net Internal Air Volume:
0.7ft3
F3 Frequency:
65.84 Hz
Total System Q:
0.671
Vented Enclosure - Street
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
Sealed Enclosure - Compact
Net Internal Air Volume:
0.5 ft3
F3 Frequency:
63.32 Hz
Total System Q:
0.772
Vented Enclosure - Dual Driver High Output (common chamber)
Net Internal Air Volume:
2.5 ft3
Vent Dimension:
4" ID x 4.8" long
F3 Frequency:
37.75 Hz
1.5
3" ID x 7.75" long
34.52 Hz
Vented Enclosure - High Output
Net Internal Air Volume:
1.4 ft3
Vent Dimension:
4" ID x 11.75" long
F3 Frequency:
36.51 Hz
96
SSW1001 Enclosures (Candian Model)
Sealed Enclosure - Sound Quality
Net Internal Air Volume:
0.5ft3
F3 Frequency:
48.4
Total System Q:
0.675
Vented Enclosure - Sound Quality
Net Internal Air Volume:
1.0
Vent Dimension:
3" ID x 19" long
F3 Frequency:
25.09 Hz
Vented Enclosure - High Output
Net Internal Air Volume:
0.5ft3
Vent Dimension:
3" ID x 24.675" long
F3 Frequency:
33.64Hz
Vented Enclosure - Dual Driver High Output (common chamber)
Net Internal Air Volume:
1.5 ft3
Vent Dimension:
4" ID x 15.125" long
F3 Frequency:
28.91 Hz
97
PXW1051/1052 Enclosures
PXW1051/1052 Enclosure Designs
Sealed Enclosure - Street
Net Internal Air Volume:
F3 Frequency:
Total System Q:
Vented Enclosure - Sound Quality
Net Internal Air Volume:
1.0
Vent Dimension:
2.5" ID x 11-1.8" long
F3 Frequency:
29.29 Hz
0.5ft3
52.12Hz
0.719
Dual Sealed Enclosure - 2 x PXW1051/1052
Net Internal Air Volume:
0.9ft3
F3 Frequency:
52.64Hz
Total System Q:
0.741
Vented Enclosure - Street
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
Bandpass Enclosure - SPL
Sealed Chamber Net Air Volume:
Vented Chamber Net Air Volume:
Vent Dimension:
F3 Frequency:
Dual Vented Enclosure - 2 x PXW1051/1052 Vented Street
Net Internal Air Volume:
2.0 ft3
Vent Dimension:
4" ID x 10-3/8" long
F3 Frequency:
30.5 Hz
0.75 ft3
0.8 ft3
4" ID x 10-1/2" long
39.67 Hz
1.0 ft3
3" ID x 9-3/8" long
34.18 Hz
98
PXW1251/1252 Enclosures
PXW1251/1252 Enclosure Designs
Sealed Enclosure - Sound Quality
Net Internal Air Volume:
0.83ft3
F3 Frequency:
49.15Hz
Total System Q:
0.899
Vented Enclosure - SPL
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
Dual Sealed Enclosure - 2 x PXW1251/1252
Net Internal Air Volume:
1.6ft3
F3 Frequency:
549.61Hz
Total System Q:
0.904
Dual Vented Enclosure - 2 x PXW1251/1252 - Street
Net Internal Air Volume:
3.5 ft3
Vent Dimension:
4" ID x 6-1/2" long
F3 Frequency:
38.34 Hz
Vented Enclosure - Street
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
99
1.8ft3
3" x 6-0"
32.48Hz
2.0 ft3
4" ID x 6-0" long
33.84 Hz
PXW1552 / PFW1051 Enclosures
PXW1552 Enclosure Designs
PFW1051 Enclosure Designs
Sealed Enclosure - Sound Quality
Net Internal Air Volume:
1.5ft3
F3 Frequency:
43.84Hz
Total System Q:
0.906
Vented Enclosure
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
Vented Enclosure - Street
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
Vented Enclosure - SPL
Sealed Enclosures are not recommended for this driver.
3.5 ft3
4" ID x 6-3/4" long
29.73 Hz
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
3.5 ft3
2 x 4" ID x 6-5/8" long
33.93 Hz
0.5 ft3
2" ID x 9"" long
53.2 Hz
100
SRW1051 / SRW1052 Enclosures
Sealed Enclosure - Sound Quality
Net Internal Air Volume:
0.5 ft3
F3 Frequency:
61.94 Hz
Total System Q:
0.61
Vented Enclosure - Sound Quality
Net Internal Air Volume:
1.0 ft3
Vent Dimension:
3/4" x 12" x 26"
F3 Frequency:
30.68 Hz
Dual Driver Vented Enclosure - Street
Net Internal Air Volume:
1.75 ft3
Vent Dimension:
4" ID x 15" long
F3 Frequency:
27.93 Hz
Dual Driver Vented Enclosure - Street
Net Internal Air Volume:
2.5 ft3
Vent Dimension:
4" ID x 7" long
F3 Frequency:
30.59 Hz
Vented Enclosure - Compact
Net Internal Air Volume:
0.8 ft3
Vent Dimension:
2.54" ID x 11.5" long
F3 Frequency:
44.31 Hz
101
SRW1251 / SRW1252 Enclosures
Sealed Enclosure - Sound Quality
Net Internal Air Volume:
0.8 ft3
F3 Frequency:
49.52 Hz
Total System Q:
0.866
Vented Enclosure - Sound Quality
Net Internal Air Volume:
1.5 ft3
Vent Dimension:
3" ID x 12" long
F3 Frequency:
33.81 Hz
Vented Enclosure - SPL
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
Dual Driver Vented Enclosure
Net Internal Air Volume:
3.5 ft3
Vent Dimension:
4" ID x 4.25" long
F3 Frequency:
33.08 Hz
2.0 ft3
4" ID x 7" long
33.08 Hz
Vented Enclosure - Compact
Net Internal Air Volume:
1.0 ft3
Vent Dimension:
3" ID x 13" long
F3 Frequency:
33.08 Hz
102
SFW1051 Enclosure
Vented Enclosure
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
0.5 ft3
2" ID x 9" long
39.47 Hz
Sealed Enclosures are not recommended for this driver.
103
SW1051 Enclosures
Sealed Enclosure - Sound Quality
Net Internal Air Volume:
0.5 ft3
F3 Frequency:
53.66 Hz
Total System Q:
0.743
Vented Enclosure - Street
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
Vented Enclosure - Street
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
Dual Driver Vented Enclosure
Net Internal Air Volume:
1.6 ft3
Vent Dimension:
4" ID x 13" long
F3 Frequency:
40.73 Hz
1.1 ft3
3" ID x 13.5" long
30.61 Hz
0.65 ft3
3" ID x 16" long
38.56 Hz
104
SW1251 Enclosures
Sealed Enclosure - Sound Quality
Net Internal Air Volume:
0.9 ft3
F3 Frequency:
45.4 Hz
Total System Q:
0.87
Vented Enclosure - Street
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
Vented Enclosure - SPL
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
Dual Driver Vented Enclosure
Net Internal Air Volume:
3.0 ft3
Vent Dimension:
4" ID x 4" long
F3 Frequency:
35.45 Hz
105
2.25 ft3
4" ID x 8.75" long
32.87 Hz
1.5 ft3
3" ID x 7.8" long
32.87 Hz
Subwoofer
Enclosures
Subwoofer Enclosures
Clarion Pre-loaded subwoofer
enclosures
Today's Car Audio specialist doesn’t always
have the time to design and construct the perfect subwoofer system, yet his or her customers
demand the best possible performance for their
dollar. Clarion comes to your rescue with a complete line of pre-loaded subwoofer enclosures
- designed and manufactured in Canada to offer
the best possible performance from your Clarion
subwoofers.
Cosmetics
Clarion Subwoofer enclosures don’t just look
good, they are designed to last. The enclosures
are wrapped in tough carpet for a clean look.
The front panels of the enclosures feature polyethylene vinyl wrapping. This vinyl wrap not only
adds style to the enclosure, but its tough surface
resists scuffs and scratches commonly associated with painted enclosures. Clarion subwoofer
enclosures also feature a silver Clarion gel badge
and engraving to complete the package.
Flexibility
Construction
Clarion Subwoofer enclosures are constructed
from 3/4-inch hardwood MDF. This wood offers
much higher density throughout the material as
compared to most off-shore sourced products.
The result is in an enclosure that is well damped
for tight, accurate, uncolored music reproduction.
Conventional
Joint
Rabbet
Joint
Where two panels meet at right angles, Clarion
subwoofer enclosures use Rabbet construction.
This increases the surface area of the connection
to offer more strength, and an improved seal.
Design
Each Clarion Subwoofer enclosure is designed
specifically for the driver that is included with it.
No compromises were made during the design
- offering the best possible balance of output,
extension and dynamic response. Generic subwoofer enclosures don’t always offer this balance, reducing your customers enjoyment and
satisfaction.
In many instances, generic subwoofer enclosures
are not acceptable for use with some drivers. This
may void the warranty on your subwoofer.
107
Clarion Subwoofer enclosures are offered in
many combinations to maximize the performance
of your audio system. Our single 10” and single
12” PXW series enclosures are offered in 4 Ohm
or 2 Ohm designs. Match these enclosures to
your amp for maximum output.
Ease of installation
Clarion subwoofer enclosures feature recessed
five-way binding post terminals. This provides
a protected electrical connection while allowing
easy access should the enclosure need to be
removed for any reason.
Subwoofer Enclosures
PX1125P4
PX1125P2
PX1105P4
PX1105P2
SINGLE 12” PORTED SUB
ENCLOSURE - 4 OHMS
SINGLE 12” PORTED SUB
ENCLOSURE - 2 OHMS
SINGLE 10” PORTED SUB
ENCLOSURE - 4 OHMS
SINGLE 10” PORTED SUB
ENCLOSURE - 2 OHMS
• Includes PXW1251 Subwoofer
• Includes PXW1252 Subwoofer
• Includes PXW1051 Subwoofer
• Includes PXW1052 Subwoofer
Measurements:
Width
Height
Depth(top)
Depth(bottom)
Measurements:
Width
Height
Depth(top)
Depth(bottom)
Measurements:
Width
Height
Depth(top)
Depth(bottom)
Measurements:
Width
Height
Depth(top)
Depth(bottom)
24.25
13.625
13.25
15.75
PX1105PTR4
24.25
13.625
13.25
15.75
19.375
11.375
12.5
13.75
19.375
11.375
12.5
13.75
PX2125P
PX2105P
SINGLE 10” PORTED SUB
ENCLOSURE FOR PICK-UP TRUCK
DUAL 12” PORTED SUB
ENCLOSURE - 4 OHMS
DUAL 10” PORTED SUB
ENCLOSURE - 4 OHMS
DUAL 10” PORTED SUB
ENCLOSURE FOR PICK-UP TRUCK
• Includes PFW1051 Subwoofer - 4 Ohm Net Load
• Includes 2 PXW1252 Subwoofers
• Includes 2 PXW1052 Subwoofers
• Includes 2 PFW1051 Subwoofers - 2 Ohm Net Load
Measurements:
Width
Height
Depth(top)
Depth(bottom)
Measurements:
Width
Height
Depth(top)
Depth(bottom)
Measurements:
Width
Height
Depth(top)
Depth(bottom)
Measurements:
Width
Height
Depth(top)
Depth(bottom)
23
15.25
5
6.75
32.125
14.875
15.5
18.25
PX2105PTR2
30.25
12.625
13.75
17
45.125
15.25
15
6.75
Wired remote
control
SW1125P
SW1105P
SRV314
SINGLE 12” PORTED SUB
ENCLOSURE - 4-OHMS
SINGLE 10” PORTED SUB
ENCLOSURE - 4-OHMS
SLIM DESIGN 6-3/4” POWERED
SUBWOOFER
• Includes SW1251 Subwoofer
* May not be exactly as shown
• Includes SW1051 Subwoofer
* May not be exactly as shown
Measurements:
Width
Height
Depth(top)
Depth(bottom)
Measurements:
Width
Height
Depth(top)
Depth(bottom)
• Maxx Bass circut for virtual bass enhancer • Dual Voice Coil • 120 W
High Powered amplifier • Remote control for gain control/Low-Pass
Filter (selectable 50/75/100/120Hz)/phase select
24.25
13.75
11.25
15.625
19.25
11.25
9.25
11.5
Measurements:
Width
Height
Depth(top)
Depth(bottom)
24.25
13.625
13.25
15.75
108
Subwoofer Enclosures
SR2125P
SR2105P
DUAL 12” PORTED SUB
ENCLOSURE - 4 OHMS
DUAL 10” PORTED SUB
ENCLOSURE - 4 OHMS
SINGLE 12” PORTED SUB
ENCLOSURE - 4-OHMS
SINGLE 10” PORTED SUB
ENCLOSURE - 4-OHMS
• Includes 2 SRW1252 Subwoofers
• Includes 2 SRW1052 Subwoofers
• Includes SRW1251 Subwoofer
• Includes SRW1051 Subwoofer
Measurements:
Width
Height
Depth(top)
Depth(bottom)
Measurements:
Width
Height
Depth(top)
Depth(bottom)
Measurements:
Width
Height
Depth(top)
Depth(bottom)
Measurements:
Width
Height
Depth(top)
Depth(bottom)
32.25
14.875
13
15.75
SR1125S
SR1125P
30.25
13.25
12.5
14.75
SR1105P
24.25
13.75
11.25
14.625
19.25
13.75
12.25
10.375
SR1105PTR4
SR1105S
SINGLE 12” SEALED SUB
ENCLOSURE - 4-OHMS
SINGLE 10” SEALED SUB
ENCLOSURE - 4-OHMS
SINGLE 10” PORTED SUB
ENCLOSURE FOR PICK-UP TRUCK
• Includes SRW1251 Subwoofer
• Includes SRW1051 Subwoofer
• Includes SFW1051 Subwoofer - 4 Ohm Net Load
Measurements:
Width
Height
Depth(top)
Depth(bottom)
Measurements:
Width
Height
Depth(top)
Depth(bottom)
Measurements:
Width
Height
Depth(top)
Depth(bottom)
18.5
13.75
12.25
7.875
15.75
12.25
6.625
8.75
23
15.25
5
6.75
Enclosure Part Number Decoder:
PX1105STR4
Model
SW
SRW
PXW
109
Quantity
1
2
Size
10
12
15
Series
5
Design
Ported or
Sealed
Custom
A - Amplified
TR - Truck Box
Box - no sub incl.
Net Load
2 Ohms
4 Ohms
THE CLARION BASS BOOK
WOOFER WIRING DIAGRAMS
2 SVC Parallel
3 SVC Parallel
1 DVC Series 2 DVC Series/Parallel
1 DVC Parallel
4 SVC Series/Parallel
8 SVC Series/Parallel
3 DVC Series/Parallel
2 DVC Parallel
4 SVC Parallel
4 DVC Series/Parallel
3 DVC Parallel
4 DVC Parallel/Series
Subwoofer to Amplifier Chart
SW Subwoofers
SRW Subwoofers
SW1051 SW1251 SFW1051 SRW1051
VC Wiring
Impedance
APX2121
SRW1052
Series
8
PXW
SRW1251
Parallel
2
4
4
4
4
4
1
1
1
1
1
1
1
1
1
1
SRW1252
Series
8
Parallel
2
PFW1051
4
PXW1051
Series
4
Parallel
1
PXW1052
Series
8
Parallel
2
2
1
1
APX4241
APX1301
1/2 1/2 1/2 1/2 2/3/4 1
APX2181
Ampliers
APX4361
DPX2251
1/2 2/3/4 1
1/2 1/2
1
1
1
1
1
2
1
2
1
1
2
1
1
1
1
2
1
2
1
1
2
43
43
43
43
2
43
2
43
1
4
4
3/4 2/3
4
2/3
4
3/4 2/3
4
85
85
85
4
4
2/3
4
2
1
44
2
DPX1851
DPX11551
85
How to use this Chart:
Notes:
1- Select the amplifier you want to use.
1 - 2 Channel amplifiers are to be Bridged.
2- Look across the row to see which subwoofers
are compatible, and in what configuration
2 - 4 Channel amplifiers, rear channels used for subwoofers.
Front Channels run High-Pass with Full range speakers
4- Install, Tune and Enjoy.
3 - See 4 SVC Series/Parallel Diagram
4 - See 4 DVC Parallel/Series Diagram
5 - See 8 SVC Series/Parallel Diagram
111
1
Subwoofer to Amplifier Chart
PXW Subwoofers
PFW1051
4
PXW1051
Series
4
Parallel
1
1/2 1/2
PXW1052
PXW1251
Series
8
Parallel
2
Series
4
2
1
Parallel
1
Signature Series
PXW1252
Series
8
Parallel
2
1/2
2
1
1
1
2
1
2
1
1
2
1
2
43
1
2
1
44
3/4 2/3
4
2/3
4
1
44
2
2/3
4
2/3
4
PXW1552
Series
8
Parallel
2
SSW1001
Series
8
Parallel
2
SSW1201
Series
8
Parallel
2
1
2
1
4
1
4
2
1
3/4
2
1
3/4
2
Important Information
All multiple woofer configurations have woofers
connected to each other in Parallel unless noted.
DVC woofer voice coils are to be wired as noted
in VC WIRING row, to show impedance as noted
in the inpedance row.
112
Enclosure to Amplifier Chart
DPX11551
DPX1851
DPX2251
SW1105P
SW1125P
SR1105PTR4
SR1105S
SR1125S
SR1105P
SR1125P
SR2105P
SR2125P
APX4361
APX2181
APX2121
320w
300w
160w
160w
320w
320w
300w
160w
160w
320w
320w
300w
160w
160w
320w
320w
300w
160w
160w
320w
320w
300w
160w
160w
320w
320w
300w
160w
160w
320w
320w
300w
160w
160w
650w
320w
320w
300w
460w
650w
320w
320w
300w
320w
320w
300w
PX2105PTR2
400w
PX1105P2
400w
PX1105P4
460w
PX1125P2
650w
320w
320w
850w
PX1125P4
PX2125P
APX4241
320w
460w
PX1105PTR4
PX2105P
APX1301
300w
400w
460w
650w
320w
320w
300w
850w
460w
650w
320w
320w
300w
850w
460w
650w
320w
320w
300w
How to use this Chart:
1- Select the enclosure that will t in the vehicle.
2- Look across the row and select an amplier based on the desired power output level.
3- Install, Tune and Enjoy.
113
Speakers
Speakers
2008 Clarion Speakers
New Speaker Series
The 2008 speaker line offers better value
and performance through advanced material
application and new designs. The differentiation
between each of our five speaker series means
that it's easy to allow a custom to 'step up' the
performance of their system. Here's a breakdown
of the general features of each series:
Good Series
OEM Replacement speakers
MIPP (Mica Injected Polypropylene woofer cones)
PEI (Poly Ether Imide) Tweeter
Stamped Steel Chassis
Strontium Ferrite Magnet
Stylized Spoked Grill
High Efficiency Design Motor
Quality Series
OEM Upgrade Speakers
TM - MIPP (Titanium Metalized MIPP woofer cones)
Silk Soft Dome Midrange and Tweeters
Rubber Woofer Surround
Stamped Steel Chassis
Stylized Grill with Mesh Insert
In-line crossover on SRQ1320S/SRQ1620S
Signature Series
Audiophile Speakers
Glass Fiber/PMI Foam Composite Cone Woofer
Inverted Titanium Tweeter with phase plug
Ferrofluid damping and cooling in tweeter
Rubber Woofer Surround
Cast Aluminum Chassis
2-Way Passive Crossover Network with Amplifier
Protection Circuit
New Speaker Model Numbers
During the design phase of the new 2008 Clarion
speakers, a conscious effort was made to better
differentiate each of the speaker series from
oneanother in terms of features, performance
and their part numbers. For 2008, we offer five
different series of speakers.
To simplify the differentiation between the speaker
lines, Clarion has redeveloped the speaker naming
convention to provide more information about the
product itself.
The options for each category are as follows:
Series:
G - Good
Q - Quality
P - Platinum
U - Ultra
S - Signature
Size:
2 - 3/4"
3 - 1"
9 - 3-1/2"
10 - 4"
13 - 5-1/4"
16 - 6-1/2"
17 - 6-3/4"
4x6"
6x9"
Designs:
2 - 2-Way
3 - 3-Way
Desciptors:
R - Regular
C - Custom - no grills included
S - Separates
H - High Frequency Only
M - MultiFit
Platinum Series
High End Aftermarket Speakers
Glass Fiber woofer cones
Silk Soft Dome Tweeter
Rubber Woofer Surround
Cast Aluminum Chassis
Stylized Grill with Mesh insert
2-Way external Passive Crossover Networks
Removable Phase Plug
MultiFit Design
Ultra Series
Competition Level Speakers
Titanium Impregnated Glass Fiber Woofer Cone
Silk Soft Dome Tweeter
Rubber Woofer Surround
2-Piece Cast Aluminum chassis with SET
Stylized Grill with Mesh Insert
Upgrade 2-Way Passive Crossover Networks
Removable Phase Plug
MultiFit Design
115
Speakers
Using this information, you know the series, size,
design and application of each speaker in the
line, making it easier to understand our extensive
product offerings.
Of course, you can mix and match, so you can
use the woofer on the 6x8" adapter plate and
mount the tweeter either coaxially or as a separate to potentially improve the soundstage.
Let's look at a the SRQ1630R as an example.
Each letter and number of the product part has
a meaning.
The MultiFit concept has been applied to six
speaker models across the Ultra and Platinum
series of the speakers.
SR
Q
16
3
0
R
- Retail Speaker
- Series - Quality
- Size - 160mm (6.5")
- Design - 3-Way
- Generation - First year
- Descriptor - Regular
MultiFit
Clarion introduces a simple and elegant solution
to a problem that most car audio retailers didn't
know they had - MultiFit. The MultiFit concept
is not new to Clarion, but it's breadth has been
expanded to serve you even better.
The MultiFit concept is quite simple - a speaker
system that fits multiple applications without the
need for additional hardware.
The reasoning behind the concept is to allow
car audio retailer to stock fewer different SKUs,
while still being able to offer a solution for each
application.
Here's an example of how MultiFit works. The
SRP1620M kit includes a pair of 6.5" woofers,
a pair of 3/4" tweeters, plastic grills, mesh grill
inserts, a pair of passive crossover networks,
6x8" adapter plates and GM Chrysler adapters.
The tweeter includes surface and flush mounting hardware. You can mount the tweeter as a
component, anywhere you want with respect
to the midrange. Or you can remove the phase
plug from the center of the midrange driver and
install the tweeter in its place to create a coaxial driver.
With all these parts included, the SRP1620M
is a 6-1/2" Component Set, 6-1/2" Coaxial Set
and 6x8" plate Speaker Set
CEA-2031 Compliance
Just as the Consumer Electronics Association
revolutionized amplifier power specifications
with CEA-2006, so to have they begun to make
an impact on speaker specifications. All new
2008 Clarion speakers are compliant with the
newly introduce CEA-2031 Mobile Speaker
standard. This CEA-2031 logo assures that the
speaker has been testing using methods that
are in accordance with the standards. These
specifications include: Power Handling in Watts.
Maximum power handling, Cut-out Diameter,
mounting depth, diameter and impedance.
Environmentally Friendly
Clarion is commited to maintaining our ISO14001
environmental standards certification. This is
acheived by ensuring that our products are produced in a manner that reduces or eliminates a
detrimental impact on the environment. One of
the simplest changes we have made is to implement the use of lead-free solder in the manufacturing of all of our loudspeakers.
Designed and Tested to Last
To remain a world leader in the car audio industry, Clarion has established a set of in-house
116
Speaker Technologies
quality control criteria to ensure our products
meet our customers expectations for performance and longevity.
All of Clarion's 2008 speakers went through a
fine-tuning process at our head office in Tokyo
Japan. These listening sessions were not
only attended by the speaker enigneers that
designed the products, but also by staff from
our offices in the USA and Canada.
Although listening is a critical part of the design
process, so to are our efforts to ensure the
speakers will last. Each Clarion speaker is tested to ensure it will be able to perform without
failure for 100 hours when being driven at it's
Continuous Rated power rating. This ensures
the speakers meet their specifications, and that
you know when you sell a set of speakers to a
customer, he is going to enjoy them for years
and years.
Signature Series - Audiophile
design and performance
Signature Series component sets were designed
to offer discerning listeners the best in mobile
sound reproduction. The materials used in these
component sets represent the state-of-the-art in
terms of speaker design.
Powder coated dampened aluminum basket
Providing a stable platform for the speaker to
work from is critical. The cast and powder coated
aluminum baskets used in the Signature Series
speakers feature a low resonance design and
incredible strength.
Rubber Surround
Signature Series speakers feature a rubber surround for enhanced flexibility, low distortion and
reliability. This surround also provides damping to
the cone to reduce resonance and colouration.
4-layer CCAW Voice Coil winding
The Signature Series components employ a
four-layer Copper Clad Aluminum Wire voice coil
winding design. This design is low in mass, but
helps create an intense magnetic field, further
improving transient response.
Fixed Phase Plug
Instead of a conventional dust cap, the Signature
Series component speakers employ a fixed phase
plug. This reduces moving mass for better transient performance due to the elimination of the
dust cap. It also helps direct sound laterally,
improving off-axis response.
Composite Cone Design
The cone of any speaker must combine three
important criteria to achieve accurate music
production - mass, damping and rigidity. The
Composite Cone Design used on the Signature
Series speakers is essential to their incredible
performance. The cone is a sandwich of glass
fibre and a PMI (Polymethacrylimide) foam cone.
This cone is extremely low in mass, while being
rigid and well dampened at the same time.
117
Woven Tinsel Leads
To ensure the complete absence of mechanical
noise, Clarion has chosen to implement tinsel
leads that are woven into the spider.
Speaker Technologies
Passive Crossover Network
At the heart of the Signature Series component
is their passive crossover networks. These networks were designed to offer excellent frequency
response, as well as good system power handling. The tweeter features an elaborate protection circuit that will prevent damage to the speaker while not upsetting the amplifier driving it.
1” Inverted Dome Titanium tweeter
Detail and accuracy in high frequencies is
achieved using a 1-inch titanium dome tweeter
and Neodynium magnet. The inverted dome
tweeter features an integrated phase plug to
excellent off-axis performance.
Balancing the charactertistics of weight, rigidity
and damping are the key to producing a cone
that allows for excellent dynamics and smooth
frequency response.
The use of Glass Fiber in the Utra and Platinum
series speakers was chosen based on it's excellent strength to mass ratio and good damping
characteristics.
The cones of these drivers feature a parabolic
shape that further strengthens the cone and
helps reduce resonance.
The result is clear and detailing midrange
performance with solid and authorative bass
response.
Ferrofluid Cooling
By injecting Ferrofluid (a non-cunductive magnetic liquid) into the voice coil gap area of
the Inverted Dome Titanium Tweeter, efficiency
and power handling capabilities are increased.
Ferrofluid also helps to dampen resonances
and reduce impedance rise at the resonant frequency.
Ultra and Platinum Series
Both the Ultra and Platinum series speakers
feature many similar product features and design
concepts. We will review how these different
components contribute to the performance of
these speakers.
Glass Fiber Woofer Cones
The purpose of the speaker cone is to act as a
linear piston that compresses and rarifies the
air in front of it as the motor assembly moves it
back and forth.
Silk Dome Tweeters
The silk dome tweeters found in the Ultra and
Platinum series speakers offer smooth frequency
response and good transient performance.
These tweeters are powered by a Neodymium
magnet for improved efficiency and clarity.
The result is a tweeter that is easy to listen to
while still offering excellent detail and accuracy.
These speakers were designed to offer extended
frequeuncy response all the way out to 50kHz.
This reduces the phase shift commonly associated with tweeters that attenuate abruptly above
20kHz.
We also include Flush Mount and Surface Mount
hardware with all our tweeters, so no matter what vehicle you are working on, there are
mounting options to make your life easy.
118
Speaker Technologies
Cast Aluminum Chassis
At the heart of each and every speaker is it's
chassis (basket). The Ultra and Platinum series
speakers feature custom tooled cast aluminum chassis' that integrate Spider Exhaust
Technology cooling.
These chassis' are very rigid, preventing chassi
distortion due to installation on surfaces that are
not flat.
These chassis are designed to be non-resonant.
A chassis that is flimsy can cause colouration
and distortion in the music.
Finally, the inclusion of Spider Exhaust
Technology cooling in both the Ultra and
Platinum series speakers not only helps to
improve power handling, but to increase driver
linearity thanks to the ability to vent air pressure
from beneath the spider mounting plateau.
Another factor that directly effects driver efficiency and power handling is the air gap between
the top plate and the voice coil former. Clarion
specifies a very narrow gap to further improve
driver efficiency. This narrow gap helps to dissipate heat from the voice coil assembly for
improved power handling and reduced power
compression.
Passive Crossover Network
Although the passive crossover networks found
in the Platinum Series speakers look similar to
their 2007 counterparts, many new features have
been implemented.
The most noticeable change is the move to
an incandescent lamp for tweeter protection.
This provides a gradual clamping of power to
the speaker instead of the old PTC switch that
would disconnect the tweeter from the circuit to
prevent damage dur to being overdriven.
These networks feature a third order (18dB/
Octave) filter on the tweeter to allow for extended low frequency performance while maintaing
good physical power handling.
A first order filter (6dB/octave) on the woofer
provides a phase correct transition and allows
for flexible speaker placement.
The networks include both 0dB and -3dB settings for the tweeter. This means you do your
system tuning without the need to equalizers or
tone controls.
Powerful Motor
Each Ultra and Platinum series driver is based
around a Strontium Ferrite Magnet in the motor.
The use of Strontium ferrite as opposed to less
expensive magnet materials such as Barium
Ferrite allows for a more intense magnetic
field around the voice coil. This means that the
speaker will respond faster to music and be
more efficient.
119
Speaker Technologies
Advanced Suspension System
Locating the cone and voice coil in the exact
center of the magnet assembly while allowing
it to move linearly is accomplished thanks to a
synthetic rubber surround and Conex progressive spider.
Conex is a synthetic fiber that offers excellent
thermal stability as well as abrasion resistance.
This means that it can handle the high temperatures associated with high power speaker
applications and not fatigue during normal use.
Conex is known as meta-aramid fiber and is
very similar to Nomex which was first produced
by DuPont.
The rubber surround remains flexible over a
wide temperature range and resists failure due
to UV exposure or thermal cycling. The rubber
surround also acts as a damper, helping to eliminate cone resonances.
Environmentally Friendly
Clarion is commited to maintaining our
ISO14001 environmental standards certification.
This is acheived by ensuring that our products
are produced in a manner that reduces or eliminates a detrimental impact on the environment.
One of the simplest changes we have made is
to implement the use of lead-free solder in the
manufacturing of all of our loudspeakers.
On the Quality series speakers, these MIPP
cones are treated with a Titanium Metallized
coating. This coating helps to stabilize the polypropylene and protect it from the effects of UV
Exposure.
Tweeter Technology
The tweeters used on the Good series of speakers are moulded from PEI (Polyether Imide). PEI
is a high performance polymer plastic that offers
excellent chemical and temperature stability
characteristics. In fact, PEI is so dimensionally
stable, parts are oftem machined from PEI as
replacements for metal components in military
weapon applications. PEI is a product of GE
Plastics
The Quality series speakers feature a Silk Dome
tweeter that is powered by a Neodymium magnet. This tweeter offers a sound that is described
as 'smooth' because the silk material itself acts
as a vibration damping material.
Quality and Good Series
Advanced Cone Materials
The woofer cones found on all Quality and Good
series speakers are made from Mica Injected
Polypropylene. Unlike many speakers that are
made from 'pure' polypropylene, the addition of
Mica flake to the polypropylene increases the
resulting materials thermal stability (resistance to
deformation due to heat) and increased rigidity
(known as Modulus). Many other company only
offer this kind of technology on their higher end
speakers.
Powerful Motor
Each Ultra and Platinum series driver is based
around a Strontium Ferrite Magnet in the motor.
The use of Strontium ferrite as opposed to less
expensive magnet materials such as Barium
Ferrite allows for a more intense magnetic
field around the voice coil. This means that the
speaker will respond faster to music and be
more efficient.
120
Speaker Technologies
Another factor that directly effects driver efficiency and power handling is the air gap between
the top plate and the voice coil former. Clarion
specifies a very narrow gap to further improve
driver efficiency. This narrow gap helps to dissipate heat from the voice coil assembly for
improved power handling and reduced power
compression.
Application Specific Sizing
The Quality and Good series of speakers
includes every common speaker size from
3-1/2" up to 6x9" and everything in between.
This means that you can offer your customer a
solution for any new vehicle application.
The design of many of the speaker chassis
includes elongated or multiple mounting holes to
make installation even easier.
121
Signature Series Speakers (Canadian Model)
SSS501
SSS601
SIGNATURE SERIES 5.25” COMPONENT SET
SIGNATURE SERIES 6.5” COMPONENT SET
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
5.25" Composite Cone Design woofer
Rubber Surround
Solid Aluminum Fixed Phase Plug
Powder coated cast aluminum basket
Chrome Back Plate
Woven Tinsel Lead
Spring Loaded electrical connections
1" Inverted Titanium Dome Tweeter
Ferrofluid cooled and damped Tweeter
Passive Crossover with tweeter attenuation
Specifications
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .100 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . . .200 W
Frequency Response . . . . . . . . . . . . . 55 Hz to 25kHz
Mounting Depth . . . . . . . . . . . . . . . . . . . . . . . . 2-7/16"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . . . 4-9/16"
6.5" Composite Cone Design woofer
Rubber Surround
Solid Aluminum Fixed Phase Plug
Powder coated cast aluminum basket
Chrome Back Plate
Woven Tinsel Lead
Spring Loaded electrical connections
1" Inverted Titanium Dome Tweeter
Ferrofluid cooled and damped Tweeter
Passive Crossover with tweeter attenuation
Specifications
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .100 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . . .200 W
Frequency Response . . . . . . . . . . . . . 40 Hz to 25kHz
Mounting Depth . . . . . . . . . . . . . . . . . . . . . . . 2-13/16"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . . 5-11/16"
122
Speakers – Features/Specifications
SRU1720M
SRU1320M
6-3/4" / 6"×8" MULTIFIT
SPEAKER SYSTEM
5-1/4" / 5"×7" MULTIFIT
SPEAKER SYSTEM
Features
• 350 Watts Maximum Music Power
• MultiFit Speaker System Design
• 6-3/4" TP-GF Cone Woofer with Rubber Surround
• 1" TP-Silk Dome Tweeter with Neodymium Magnet
• 2-Way Mounting Tweeter (Flush Mounting/Surface
Mounting)
• High Grade -12dB/oct 2way Crossover Network
with Level Attenuator (0,-3dB)
• Extremely High Frequency Reproduction/80kHz
• Aluminum Die-Cast Frame for Higher Power
Handling and Reduced Distortion
• S.E.T.(Spider Exhaust Technology) Cooling
• Grille & Mesh Included
• Powerful Strontium Magnet for Dynamic Bass
Response
• GM Fit Basket Design/6"x8" FORD Adaptor
Included
Features
• 250 Watts Maximum Music Power
• MultiFit Speaker System Design
• 5-1/4" TP-GF Cone Woofer with Rubber Surround
• 1" TP-Silk Dome Tweeter with Neodymium Magnet
• 2-Way Mounting Tweeter (Flush Mounting/Surface
Mounting)
• High Grade -12dB/oct 2way Crossover Network
with Level Attenuator (0,-3dB)
• Extremely High Frequency Reproduction/80kHz
• Aluminum Die-Cast Frame for Higher Power
Handling and Reduced Distortion
• S.E.T.(Spider Exhaust Technology) Cooling
• Grille & Mesh Included
• Powerful Strontium Magnet for Dynamic Bass
Response
• 5"x7" FORD/CHRYSLER/TOYOTA Adaptor Included
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .80 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . ...350 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . .2-13/16"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . .140mm
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .80 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . ...250 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . . 2-5/16""
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . . 114mm
123
Speakers – Features/Specifications
SRU310H
SRP1620M
1" DOME TWEETER
6-1/2" / 6"×8" MULTIFIT
SPEAKER SYSTEM
Features
• 300 Watts Maximum Music Power
• 1" TP-Silk Dome Tweeter with Neodymium Magnet
• 2-Way Mounting Tweeter (Flush Mounting/Surface
Mounting)
• High Grade -12dB/oct Crossover Network with
Level Attenuator (0,-3dB,-6dB)
• Extremely High Frequency Reproduction/80kHz
• Powerful Neodymium Magnet
Features
• 250 Watts Maximum Music Power
• MultiFit Speaker System Design
• 6-1/2" Glass-Fiber Cone Woofer with Rubber
Surround
• 3/4" Pure Silk Dome Tweeter with Neodymium Magnet
• 2-Way Mounting Tweeter (Flush Mounting/Surface
Mounting)
• High Grade -12dB/oct 2way Crossover Network with
Level Attenuator (0,-3dB)
• Extremely High Frequency Reproduction/50kHz
• Aluminum Die-Cast Frame for Higher Power Handling
and Reduced Distortion
• S.E.T.(Spider Exhaust Technology) Cooling
• Grille & Mesh Included
• Powerful Strontium Magnet for Dynamic Bass
Response
• GM Fit Basket Design/ CHRYSLER Adaptor Included
• 6"x8" FORD Adaptor Included
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .90 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .300 W
Frequency Response . . . . . . . . . . . . . . . 2,000 Hz to 80 kHz
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .70 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .250 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . . . .2-1/2"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . .123mm
124
Speakers – Features/Specifications
SRP1320M
SRP6920M
5-1/4" / 5"×7" MULTIFIT
SPEAKER SYSTEM
6"×9" MULTIFIT
SPEAKER SYSTEM
Features
• 220 Watts Maximum Music Power
• MultiFit Speaker System Design
• 5-1/4" Glass-Fiber Cone Woofer with Rubber
Surround
• 3/4" Pure Silk Dome Tweeter with Neodymium
Magnet
• 2-Way Mounting Tweeter (Flush Mounting/Surface
Mounting)
• High Grade -12dB/oct 2way Crossover Network
with Level Attenuator (0,-3dB)
• Extremely High Frequency Reproduction/50kHz
• Aluminum Die-Cast Frame for Higher Power
Handling and Reduced Distortion
• S.E.T. (Spider Exhaust Technology) Cooling
• Grille & Mesh Included
• Powerful Strontium Magnet for Dynamic Bass
Response
• 5"x7" FORD/CHRYSLER/TOYOTA Adaptor Included
Features
• 450 Watts Maximum Music Power
• MultiFit Speaker System Design
• 6"x9" Glass-Fiber Cone Woofer with Rubber
Surround
• 1" Pure Silk Dome Tweeter with Neodymium Magnet
• 2-Way Mounting Tweeter (Flush Mounting/Surface
Mounting)
• High Grade -12dB/oct 2way Crossover Network
with Level Attenuator (0,-3dB)
• Extremely High Frequency Reproduction/50kHz
• Aluminum Die-Cast Frame for Higher Power
Handling and Reduced Distortion
• S.E.T.(Spider Exhaust Technology) Cooling
• Grille & Mesh Included
• Powerful Strontium Magnet for Dynamic Bass
Response
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . . . 60 W
Maximum Power. . . . . . . . . . . . . . . . . . . . . . . . .220 W
Mounting Depth . . . . . . . . . . . . . . . . . . . . . . . . . 2-1/8"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . . . 114mm
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92db
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .90 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .450 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . . 3-7/16""
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . . . . . .222mm
125
Speakers – Features/Specifications
SRP4620M
SRP310H
4" / 4"×6" MULTIFIT
SPEAKER SYSTEM
1" DOME TWEETER
Features
• 150 Watts Maximum Music Power
• MultiFit Speaker System Design
• 4 Glass-Fiber Cone Woofer with Rubber Surround
• 3/4 Pure Silk Dome Tweeter with Neodymium
Magnet
• 2-Way Mounting Tweeter (Flush Mounting/Surface
Mounting)
• High Grade -12dB/oct 2way Crossover Network
with Level Attenuator (0,-3dB)
• Extremely High Frequency Reproduction/50kHz
• Aluminum Die-Cast Frame for Higher Power
Handling and Reduced Distortion
• S.E.T.(Spider Exhaust Technology) Cooling
• Grille & Mesh Included
• Powerful Strontium Magnet for Dynamic Bass
Response
• 4 x6 OEM Replacement Adaptor Included
• Grille & Mesh NOT Included
Features
• 250 Watts Maximum Music Power
• 1" Pure Silk Dome Tweeter with Neodymium Magnet
• 2-Way Mounting Tweeter (Flush Mounting/Surface
Mounting)
• High Grade -12dB/oct Crossover Network with
Level Attenuator (0,-3dB,-6dB)
• Extremely High Frequency Reproduction/50kHz
• Powerful Neodymium Magnet
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88db
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .60 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .150 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . 1-13/16""
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . . . . . . .92mm
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .70 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .250 W
Frequency Response . . . . . . . . 2,000 Hz to 50 kHz
126
Speakers – Features/Specifications
SRQ1620S
SRQ1320S
6-1/2" 2-WAY COMPONENT SPEAKER
5-1/4" 2-WAY COMPONENT SPEAKER
Features
• 250 Watts Maximum Music Power
• 6-1/2" TM-MIPP Cone Woofer
• 3/4" Pure Silk Dome Tweeter with Neodymium
Magnet
• 2-Way Mounting Tweeter (Variable Angle Flush
Mounting/Surface Mounting)
• Grille & Mesh Included
• Powerful Strontium Magnet for Dynamic Bass
Response
• In-Line -6dB/oct Crossover Network
• GM Fit Basket Design/CHRYSLER Adaptor Included
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91db
Continuous Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50 W
Maximum Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .250 W
Mounting Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5/16"
Cut-Out Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125mm
127
Features
• 200 Watts Maximum Music Power
• 5-1/4" TM-MIPP Cone Woofer
• 3/4" Pure Silk Dome Tweeter with Neodymium
Magnet
• 2-Way Mounting Tweeter (Variable Angle Flush
Mounting/Surface Mounting)
• Custom-Fit Tweeter Bracket Included
• Powerful Strontium Magnet for Dynamic Bass
Response
• Grille & Mesh Included
• In-Line -6dB/oct Crossover Network
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91db
Continuos Power . . . . . . . . . . . . . . . . . . . . . . . .45 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .200 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . .1-13/16"
Cut-Out Size . . . . . . . . . . . . . . . . . . . . . . . 112.5mm
Speakers – Features/Specifications
SRQ6930R
SRQ1630R
6"X9" MULTIAXIAL 3-WAY SPEAKER
6-1/2" MULTIAXIAL 3-WAY SPEAKER
Features
• 400 Watts Maximum Music Power
• 6"x 9" TM-MIPP Cone Woofer
• 1" Pure Silk Dome Mid-Range & 5/16" Dome
Tweeter
• Powerful Strontium Magnet for Dynamic Bass
Response
• Grille & Mesh Included
Features
• 280 Watts Maximum Music Power
• 6-1/2" TM-MIPP Cone Woofer
• 3/4" Pure Silk Dome Mid-Range & 5/16" Dome
Tweeter
• Powerful Strontium Magnet for Dynamic Bass
Response
• Grille & Mesh Included
• GM Fit Basket Design/CHRYSLER Adaptor Included
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93db
Continuos Power . . . . . . . . . . . . . . . . . . . . . . . .80 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .400 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . . . .3-1/8"
Cut-Out Size . . . . . . . . . . . . . . . . . . . . . . . . .222mm
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91db
Continuous Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55 W
Maximum Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .280 W
Mounting Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3/16"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . . . . . . . .123mm
128
Speakers – Features/Specifications
SRQ6830C
SRQ5730C
6"X8" CUSTOM FIT MULTIAXIAL 3-WAY SPEAKER
5"X7" CUSTOM FIT MULTIAXIAL 3-WAY SPEAKER
Features
• 300 Watts Maximum Music Power
• 6" x 8" TM-MIPP Cone Woofer
• 3/4" Pure Silk Dome Mid-Range & 5/16" Dome
Tweeter
• Powerful Strontium Magnet for Dynamic Bass
Response
• Designed for Direct OEM Replacement
Features
• 250 Watts Maximum Music Power
• 5" x 7" TM-MIPP Cone Woofer
• 3/4" Pure Silk Dome Mid-Range & 5/16" Dome
Tweeter
• Powerful Strontium Magnet for Dynamic Bass
Response
• Designed for Direct OEM Replacement
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92db
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .60 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .300 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . . . .2-3/8"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . .186mm
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92db
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .55 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .250 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . . . .2-1/8"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . 178.5mm
129
Speakers – Features/Specifications
SRQ210H
SRV314
3/4" DOME TWEETER
AMPLIFIED SUBWOOFER
Features
• 200 Watts Maximum Music Power
• 3/4" Pure Silk Dome Tweeter with Neodymium
Magnet
• 2-Way Mounting Tweeter (Variable Angle Flush
Mounting/Surface Mounting)
• Powerful Neodymium Magnet
• In-Line -6dB/oct Crossover Network
Features
• Dual-Voice coil
• 120 W high power amplifier with low pass filter
• Maxx Bass circuit for virtual bass enhancer
• 6-3/4" counter drive woofer with dual-neodymium
magnet
• Air compression structure with aluminum die-cast
enclosure
• Remote control for gain control /low-pass filter
(selectable 50/75/100/120 Hz)/phase select
• Blue LED power indicator
• RCA line level input/Speaker level input
*“Maxx Bass” is a patent of KS-Waves.“Maxx Bass” is
a registered trademark of KS-Waves.
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90db
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .45 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .200 W
Frequency Response . . . . . . . . 2,500 Hz to 35 kHz
Specifications
• Speaker type: 6-3/4" counter drive powered
subwoofer
• Unit used: 6-3/4" MIPP cone woofer (Dual Voice
coil)
• Rated output: 60W (30W+30W)
• Max power output:120W (60W+60W)
• Playback frequency range: 30 to 200Hz
• Cut-off frequency: 50Hz/75Hz/100Hz/120Hz
• Input sensitivity: RCA input 20mV to 2V, Speaker
input 0.2V to 20V
• Power source voltage: DC14.4V
• Ground: Negative
• Current consumption: 7.0A
• External dimensions:
Main unit:
12-1/4" (W) x 2-5/8" (H) x 8-1/4" (D)
Remote control Unit:
3-15/16" (W) x 1-1/8" (H) x 1" (D)
• Weight: [Body] 2.0Kg [Remote control] 220g
130
Speakers – Features/Specifications
SRG6920R
SRG1620R
6" X 9" COAXIAL 2-WAY SPEAKER
6-1/2" COAXIAL 2-WAY SPEAKER
Features
• 350 Watts Maximum Music Power
• 6" x 9" MIPP Cone Woofer
• 2-5/8" Metallized PEI Cone Tweeter
• Powerful Strontium Magnet for Dynamic Bass
Response
Features
• 180 Watts Maximum Music Power
• 6-1/2" MIPP Cone Woofer
• 1" Metallized PEI Balanced-Drive Tweeter
• Powerful Strontium Magnet for Dynamic Bass
Response
• GM Fit Basket Design/CHRYSLER Adaptor Included
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70 W
Maximum Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .350 W
Mounting Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15/16"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . .222mm
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .35 W
Maximum Power.. . . . . . . . . . . . . . . . . . . . . . .180 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . . . .1-7/8"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . .123mm
SRG1320R
SRG1020R
5-1/4" COAXIAL 2-WAY SPEAKER
4" COAXIAL 2-WAY SPEAKER
Features
• 150 Watts Maximum Music Power
• 5-1/4" MIPP Cone Woofer
• 1" Metallized PEI Balanced-Drive Tweeter
• Powerful Strontium Magnet for Dynamic Bass
Response
Features
• 140 Watts Maximum Music Power
• 4" MIPP Cone Woofer
• 1" Metallized PEI Balanced-Drive Tweeter
• Powerful Strontium Magnet for Dynamic Bass
Response
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 W
Maximum Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150W
Mounting Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13/16"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . 113.5mm
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .30 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .140 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . .1-11/16"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . .102mm
131
Speakers – Features/Specifications
SRG5720C
SRG4620C
5" X 7" CUSTOM FIT COAXIAL 2-WAY SPEAKER
4" X 6" CUSTOM FIT COZXIAL 2-WAY SPEAKER
Features
• 200 Watts Maximum Music Power
• 5" x 7" MIPP Cone Woofer
• 1" Metallized PEI Balanced-Drive Tweeter
• Powerful Strontium Magnet for Dynamic Bass
Response
• Designed for Direct OEM Replacement
Features
• 140 Watts Maximum Music Power
• 4" x 6" MIPP Cone Woofer
• 1" Metallized PEI Balanced-Drive Tweeter
• Powerful Strontium Magnet for Dynamic Bass
Response
• Designed for Direct OEM Replacement
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .45 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .200 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . . . .2-1/6"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . 178.5mm
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .30 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . .140 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . .1-13/16"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . 138.5mm
SRG920C
3-1/2" CUSTOM FIT COAXIAL 2-WAY SPEAKER
Features
• 60 Watts Maximum Music Power
• 3-1/2" MIPP Cone Woofer
• 1" Metallized PEI Balanced-Drive Tweeter
• Powerful Strontium Magnet for Dynamic Bass
Response
• Designed for Direct OEM Replacement
Specifications
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89dB
Continuous Power . . . . . . . . . . . . . . . . . . . . . . .20 W
Maximum Power . . . . . . . . . . . . . . . . . . . . . . . .60 W
Mounting Depth. . . . . . . . . . . . . . . . . . . . . . .1-5/16"
Cut-Out Size Width . . . . . . . . . . . . . . . . . . . . .78mm
132
Marine Audio
Marine Audio – Technologies
Land or Sea – Clarion Will Take You
There
Digital Media Compatible
The CMD5, M475 and M275 are compatible with
MP3 and WMA files. Burn your favorite music
onto a CD-R or CD-R/W and enjoy hours of
entertainment without changing discs.
Stainless Steel Chassis
The CMD5 and M475 feature a stainless steel
chassis to help prevent water from entering the
the radio and damaging the circuitry inside. We
have also included a drip shield over the wire
harness connection to further reduce the risk of
water being able to infiltrate the radio.
Bluetooth Ready
The CMD5, M475 and M275 are Bluetooth ready.
Simply connect the BLT370 and enjoy high quality streaming audio from your portable music
player or MP3-equipped cellular phone. You can
even answer the phone.
Quick Release Door with Watertight Seal
The design of this door with its unique rubber
gasket and door assembly, gives you maximum
protection of the CMD5’s internal components.
This design gives the user one-touch easy loading of CDs. You can rest assured of long lasting
moisture protection with at least 10,000 duty
cycles for durability.
CMD5’s Water-Resistant Face Plate Meets
IPX5 Watertight Standard
The water-resistant face plate on the CMD5 can
withstand a 65 gallon stream of water from a
1-inch diameter hose at 10 feet for 5 minutes.
This standard eliminates concerns of water damage caused by rain, splashes, and wash downs.
Silicone Oil Damped Suspension System
Our tried-and-true mobile audio CD mechanisms
are fine-tuned for the marine environment to minimize mistracking. This is accomplished without
resorting to buffer circuits, which can add distortion and degrade sound quality.
Conformally Coated PC Boards
All Clarion Marine head units have had their
circuit boards coated with Humiseal. This is a
product developed to protect electronic components being used in harsh environments. This
coating is one of the many reasons why Clarion
Marine head units meet the ASTM B117 Salt/Fog
Exposure specification.
134
Marine Audio – Technologies
Front Panel Auxiliary Inputs
Marine Power Amplifiers
The M475 and M275 feature from panel Auxiliary
input connections. Simply connect your portable music player, DVD player or even a laptop
and enjoy high quality, interference free music.
Clarion Auxiliary inputs feature three sensitivity
ranges to ensure perfect level matching.
Power amplifiers are essential in marine applications where high ambient noise competes with
the sound system. The fact is that without an
amplifier, increasing the volume control often
means increasing distortion.
Clarion also offers the CCUAUXEX1 Aux input
cable to make bringing your music to life even
easier. This is a 3-foot cable with 1/8-inch stereo
mini-jacks on each end. Perfect for connecting
your portable audio player to either the M275 or
M475.
Wired Remote Controls
The CMD5 and M475 are ready for Clarion's
wired remote control system. Choose our 3-inch
LCD equipped remotes (CMRC1-SB or CMRC1BSS) for full command over all functions and
a display to let you know whats going on. Our
2-inch remotes (CMRC2-SB or CMRC2-BSS)
have all the same functionality, but without the
display. Both remotes are available in black or
stainless steel finishes and up to four remotes
can be used with one source unit with optional
(M101RYC) Y-Cables.
Infrared Remote Controls
The CMD5 and M475 are IR remote
control ready. Enjoy full control over
your audio system system control
from almost anywhere on the boat.
Advanced iPod Interface Ready
Combine the CMD5 or M475 with the CCAIPOD
for advanced control over your Apple iPod.
Sort your music by Album, Artists, Song Title,
Composer, Genre or Playlist to make listening to
what you want easier than ever. You can see the
title of what you are listening to on the display of
your radio.
135
Just like increasing the size of the engine adds to
the performance of a boat, increasing power of
the audio system adds to its performance. People
who know audio understand that amplifiers add
more than just volume to music. They reduce distortion at high volumes and ensure that the music
that you hear is crisp, clear and powerful.
Clarion marine audio amplifiers include sound
quality features such as electronic crossovers
and differential inputs. Our amplifiers are also
bridgeable, so you can make even more power
when driving a subwoofer or two.
Advanced Marine Design
Nobody understands the marine audio environment like Clarion - we invented the category
and remain the industry leader. Clarion marine
product are designed to not only look and sound
great, but to withstand the harshest tests Mother
Nature can through their way.
ASTM B117 Salt Fog Exposure Standard
This test was created to evaluate a products
corrosion resistance over extended exposure to
salt water. The test involves subjecting a device
(speaker for example) to a spray in a closed
chamber of a solution of NaCl ranging in concentration from 3.5 to 20%. The second part of the
test involves bubbling compressed air through
a humidifying tower containing hot de-ionized
water. This recreates a condition of 100% humidity. Clarion products subjected to these tests must
pass without corrosion, damage or failure.
Marine Audio – Technologies
ASTM D4329 - UV Exposure Testing
This testing standard describes an evaluation of
the damaging effects of long term outdoor UV
exposure. The test subjects must withstand alternating cycles of 8 hours of ultraviolet light exposure at 70 degrees Celsius, followed by 4 hours
of condensation at 50 degrees Celsuis, then
repeated for extended periods of time in multiples
of 500 hours per test (up to 2000 Hours). The
devices under test must pass without discoloring,
fading, chalking or cracking.
Centrex 814 Chassis and Grills
All Clarion marine speaker chassis' and grills are
injection moulded from a polymer plastic called
Centrex 814. This plastic has physical properties
similar to ABS plastic, but adds the ability to resist
chalking, fading and yellowing due to prolonged
UV exposure.
Triple Gasket Design
All Clarion marine speakers include a synthetic
rubber mounting gasket to ensure water does not
infiltrate behind the speaker. This not only protects
the speaker itself from damage, but the hull of
the boat. All marine speakers feature Santoprene
rubber surround at the outer edge of the woofers
for durability and flexibility in all weather conditions. Coaxial marine speakers feature a custom
tooled Santoprene rubber gasket at the base of
the woofer cone that seals the cone to the tweeter
mounting post. These three gaskets ensure there
is no way water can penetrate the speaker, causing it to fail or your boat to be damaged.
7-inch speakers
Clarion's line of 7-inch diameter speakers set new
standards for marine audio entertainment. These
speakers were designed to the same strict tolerances as our 6.5-inch speakers, but offer improved
efficiency, as well as improved bass output thanks
to a 35% increase in cone area.
Sport Series Speakers
The Sport Series of speakers were introduced
to add options to your purchase. If you are looking for aggressive styling with the same proven
marine performance you’ve come to expect from
Clarion, then the Sport Series CMCX7.1s 7-inch
coaxial speaker set and CMSW10.1s 10” subwoofer are the perfect choice.
Wakeboard Tower Speaker Systems
New for 2008, Clarion introduces a full line of
wakeboard tower speaker enclosures. These
enclosures are constructed from high quality,
hand-laid fiberglass and feature and automotive quality clear finish. Each pair of enclosures
includes stainless steel mounting hardware that
will accomodate tower bar diameters from 1-7/8"
through 2.5".
The enclosures were designed specifically for use
with Clarion's 7-inch coaxial speakers for excellent efficiency and sound quality.
You can purchase the enclosures in your choice
of silver, black or white with either the CMCX7.1
or CMCX7.1S coaxial speaker set.
Dare to compare: The Clarion CMR1720T enclosures offer more than twice the efficiency of other
6.5" wakeboard tower speaker enclosures. This
means that your music will be louder, your hear
and feel more bass, your boat battery will last
longer and you get more bang for your buck.
The results of our efforts is a speaker that is 3dB
more efficient with dramatically improved low
frequency extension and smooth band to band
performance.
136
Marine Audio – CMD5
Specifications
CMD5
MARINE AM/FM CD/MP3/WMA PLAYER WITH
CENET CONTROL AND WATERTIGHT
FACEPLATE
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
ASTM B117 Salt/Fog Exposure Certified
ASTM D4329 UV Exposure Certified
IPX 5 Water Intrusion Rated
Exclusive flip-down Marinized Front Panel
MP3/WMA Compressed audio file playback
CD-R / CD-RW compatible
Bluetooth Ready for Streaming Audio and Hands-Free phone
operation (Optional BLT370 required)
White Positive 2-Line LCD display
CeNET Control of Optional TV Tuner, 6-Disc CD Changer,
Advanced iPod Interface and Satellite Radio Receiver
Humiseal Conformally Coated circuit board
Input for Marine Wired Remote Control (remote not included)
IR Remote Control (included)
Bass/Treble controls
Subwoofer Level Control
6-Channel RCA Line Level Output
2-Channel RCA Line Level Aux Input
212-Watt Amplifier (53 W x 4)
DSP Radio Tuner with 18 FM/6 AM Presets
Magna Bass EX
Screen Saver
Stainless Steel Chassis
Drip Shield over wire harness connections
Advanced iPod Interface Ready (requires CCA-IPOD)
137
FM Useable Sensitivity
FM 50 dB Quieting Sensitivity
FM Alternate Channel Selectivity
FM Stereo Separation
FM Stereo Frequency Response
AM Useable Sensitivity
CD Signal-to-Noise Ratio
CD Frequency Response
CD Dynamic Range
Maximum Power Output
Continuous Power Output
Harmonic Distortion
Line-Level Output Voltage
Dimensions, Escutcheon (h x w x d)
Dimensions, Chassis (h x w x d)
9 dB
15 dB
70 dB
35 dB
30 Hz to 15 kHz
25 uV
100 dB
10 Hz to 20 kHz
95 dB
53 W x 4
21 W x 4
0.02%
2.0 V
3-5/8 x 7-7/8 x 1-7/8
2 x 7-1/8 x 7-7/10
Marine Audio – M475/M275
M475
M275
MARINE MP3/WMA RECEIVER WITH CENET
MARINE MP3/WMA RECEIVER
• MP3/WMA Compressed audio file playback
• CD-R / CD-RW compatible
• Bluetooth Ready for Streaming Audio and Hands-Free phone
operation (Optional BLT370 required)
• White Positive LCD display
• CeNET Control of Optional TV Tuner, 6-Disc CD Changer, Ipod
Interface and Satellite Radio Receiver
• Humiseal Conformally Coated circuit board
• Input for Marine Wired Remote Control (remote not included)
• IR Remote Control (included)
• Subwoofer Level Control
• Z-Enhancer and Magna Bass EX
• 6-Channel RCA Line Level Output
• Front Panel Aux Input
• 200-Watt Amplifier (50 W x 4)
• DSP Radio Tuner with 18 FM/6 AM Presets
• Magna Bass EX
• Screen Saver
• Detachable Control Panel
• Stainless Steel Chassis
• Drip Shield over wire harness connections
• Advanced iPod Interface Ready (requires CCA-IPOD)
• MP3/WMA Compressed audio file playback
• CD-R / CD-RW compatible
• Bluetooth Ready for Streaming Audio and Hands-Free phone
operation (Optional BLT370 required)
• White Positive LCD display
• Pelgan Z Conformally Coated circuit board
• Z-Enhancer and Magna Bass EX
• 2-Channel RCA Line Level Output
• Front Panel Aux Input
• 200-Watt Amplifier (50 W x 4)
• DSP Radio Tuner with 18 FM/6 AM Presets
• Magna Bass EX
• Detachable Control Panel
Specifications (preliminary)
FM Useable Sensitivity
FM 50 dB Quieting Sensitivity
FM Alternate Channel Selectivity
FM Stereo Separation
FM Stereo Frequency Response
CD Signal-to-Noise Ratio
CD Frequency Response
CD Dynamic Range
Maximum Power Output
Continuous Power Output
Line-Level Output Voltage
Dimensions, Chassis (h x w x d)
9 dB
15 dB
70 dB
35 dB
30 Hz to 15 kHz
100 dB
10 Hz to 20 kHz
95 dB
50 W x 4
19 W x 4
2.0 V
2" x 7" x 6"
Specifications (preliminary)
FM Useable Sensitivity
FM 50 dB Quieting Sensitivity
FM Alternate Channel Selectivity
FM Stereo Separation
FM Stereo Frequency Response
CD Signal-to-Noise Ratio
CD Frequency Response
CD Dynamic Range
Maximum Power Output
Continuous Power Output
Line-Level Output Voltage
Dimensions, Chassis (h x w x d)
9 dB
15 dB
70 dB
35 dB
30 Hz to 15 kHz
100 dB
10 Hz to 20 kHz
95 dB
50 W x 4
19 W x 4
2.0 V
2" x 7" x 6"
138
Marine Wired Remote Controls
CMRC1-SB
CMRC2-SB
WATERPROOF WIRED LCD REMOTE CONTROL
WATERPROOF WIRED REMOTE CONTROL
CMRC1-BSS
CMRC2-BSS
WATERPROOF WIRED LCD REMOTE CONTROL
WATERPROOF WIRED REMOTE CONTROL
Same as above with Stainless Steel trim ring.
Same as above with Stainless Steel trim ring
Features
Features
•
•
•
•
•
•
•
•
•
•
•
•
•
•
LCD Readout
Uses Standard-Gauge 3" Hole-Cutout Size
Round Mounting Hole for Easy Installation
Water-Resistant Design
Rubber-Gasket Rear Seal
UV-Resistant Front Panel and Rubber Buttons
Controls all Major Radio, CD, CD Changer, iPod and Satellite
Radio Functions
Uses Standard-Gauge 2-1/16"Hole-Cutout Size
Round Mounting Hole for Easy Installation
Water-Resistant Design
Rubber-Gasket Rear Seal
UV-Resistant Front Panel and Rubber Buttons
Controls all Major Radio, iPod and CD Functions
2-1/16" round mounting hole
M101RXC
REMOTE KITS
• 23' Extention Cable for Both Wired Remote Controls
K-CMRC1-SB includes CMRC1-SB remote and M101RXC
23-foot extension cable
M101RYC
• “Y” Cable to Connect Two Wired Remote Controls to a single
Wired Remote Ready marine source unit
K-CMRC1-BSS includes CMRC1-BSS remote and M101RXC
23-foot extension cable
K-CMRC2-SB includes CMRC2-SB remote and M101RXC
23-foot extension cable
K-CMRC2-BSS includes CMRC2-BSS remote and M101RXC
23-foot extension cable
139
Marine Audio – APX290M/APX490M
APX290M
APX490M
2/1-CHANNEL POWER AMPLIFIER
4/3/2-CHANNEL POWER AMPLIFIER
• 90 Watts x 2 @ 4 Ohm
• 150 Watts x 2 @ 2 Ohm
• 360 Watts x 1 @ 2 Ohm
• Class AB Output Stage
• High or Low Pass Electronic Crossover (50Hz to 5.5kHz)
at 12dB/Octave
• Conformal Coated Double Sided FR4PC Board
• Corrosion Resistant Aluminum Heat Sink
• Variable Bass Boost Control
• Soft Turn-On and Turn-Off Circuitry
• Ground Loop Isolation Circuit
• Gold Plated RCA, Power, and Speaker Connections
• Speaker Level Inputs
• 90 Watts x 4 @ 4 Ohm
• 165 Watts x 4 @ 2 Ohm
• 360 Watts x 2 @ 2 Ohm
• Class AB Output Stage
• Independant High or Low Pass Electronic Crossovers
(50Hz to 5.5kHz) at 12dB/Octave
• Conformal Coated Double Sided FR4PC Board
• Corrosion Resistant Aluminum Heat Sink
• Variable Bass Boost Control
• Soft Turn-On and Turn-Off Circuitry
• Ground Loop Isolation Circuit
• Gold Plated RCA, Power, and Speaker Connections
• Speaker Level Inputs
Specifications
Number of Channels
2
Frequency Response (±.3dB)
20 Hz to 20kHz
Signal-to-Noise Ratio (CEA-2006)
> 95 dB
[email protected] Rated Output
0.10 %
Input Sensitivity
0.2 to 6 V
High Level Input Sensitivity
0.5v to 13V
Power Output @ 4 Ohm Stereo (CEA-2006)
90W x 2
Power Output @ 2 Ohms Stereo (CEA-2006)
150W x 4
Power Output @ 4 Ohm Mono (CEA-2006)
250W x 2
Dimensions (l x w x h)
10-1/2" x 9-1/8" x 2-1/4"
Specifications
Number of Channels
2
Frequency Response (±.3dB)
20 Hz to 20kHz
Signal-to-Noise Ratio (CEA-2006)
> 97 dB
[email protected] Rated Output
0.10 %
Input Sensitivity
0.2 to 6 V
High Level Input Sensitivity
0.5v to 13V
Power Output @ 4 Ohm Stereo (CEA-2006)
90W x 2
Power Output @ 2 Ohms Stereo (CEA-2006)
165W x 4
Power Output @ 4 Ohm Mono (CEA-2006)
330W x 2
Dimensions (l x w x h)
16-1/8" x 9-1/8" x 2-1/4"
140
Marine Audio – Speakers Information
CM1605
CM1625
6-1/2" MARINE DUAL CONE SPEAKER SET
6-1/2" MARINE COAXIAL SPEAKER SET
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Maximum Power Handling: 100 Watts
Continuous Power Handling: 25 Watts
Cone Material: Polypropylene Woofer Cone
Santoprene Rubber Surround
Rubber Mounting Gasket
Meets or Exceeds ASTM B117 (Salt/Fog Exposure)
Meets or Exceeds ASTM D4329 (UV Exposure)
Frequency Response: 60Hz – 18kHz
Efficiency: 87dB @ 1 meter, 1 watt
Cut Out Size: 5”
Mounting Depth: 2 3/8”
Maximum Power Handling: 100 Watts
Continuous Power Handling: 25 Watts
Polypropylene Woofer Cone
Santoprene Rubber Surround
Triple Gasket Design
3/4” Titanium-Coated Dome Tweeter
Meets or Exceeds ASTM B117 (Salt/Fog Exposure)
Meets or Exceeds ASTM D4329 (UV Exposure)
Frequency Response: 60Hz – 20kHz
Efficiency: 87dB @ 1 meter, 1 watt
Cut Out Size: 5”
Mounting Depth: 2 3/8”
CM1635
CMSW10.1
6-1/2" MARINE COMPONENT SPEAKER SET
10" MARINE SUBWOOFER
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Maximum Power Handling: 130 Watts
Continuous Power Handling: 35 Watts
Polypropylene Woofer Cone
Santoprene Rubber Surround
1” Titanium-Coated Dome Tweeter
Meets or Exceeds ASTM B117 (Salt/Fog Exposure)
Meets or Exceeds ASTM D4329 (UV Exposure)
Frequency Response: 60Hz – 20kHz
Efficiency: 87dB @ 1 meter, 1 watt
Cut Out Size (Woofer): 5”
Cut Out Size (Tweeter): 2”
Mounting Depth (Woofer): 5”
Mounting Depth (Tweeter): 7/8”
Tweeter Mounting Configurations: Flush or Surface
141
Maximum Power Handling: 350 Watts
Continuous Power Handling: 100 Watts
Polypropylene Cone
Santoprene Rubber Surround
Meets or Exceeds ASTM B117 (Salt/Fog Exposure)
Meets or Exceeds ASTM D4329 (UV Exposure)
Frequency Response: 60Hz – 2.5kHz
Efficiency: 88dB @ 1meter, 1watt
Wire Terminals: Gold-Plated Spade Terminals
Rubber Mounting Gasket
Protected Magnet and Rear Cone Design
Cut Out Size: 9 1/16”
Mounting Depth: 4 1/4”
Impedance: 4 Ohm
Marine Audio – Speakers Information
CMCS7.1
CMCX7.1
7" MARINE COMPONENT SPEAKER SET
7" MARINE COAXIAL SPEAKER SET
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Maximum Power Handling: 160 Watts
Continuous Power Handling: 50Watts
Polypropylene Woofer Cone
Santoprene Rubber Surround
Rubber Mounting Gasket
1.25” Titanium-Coated Dome Tweeter
Meets or Exceeds ASTM B117 (Salt/Fog Exposure)
Meets or Exceeds ASTM D4329 (UV Exposure)
Frequency Response: 60Hz – 20kHz
Efficiency: 93dB
Cut Out Size (Woofer): 6 1/4”
Mounting Depth (Woofer): 5”
Tweeter Mounting Configurations: Flush or Surface
Maximum Power Handling: 160 Watts
Continuous Power Handling: 50 Watts
Polypropylene Woofer Cone
Santoprene Rubber Surround
Triple Gasket Design
1.25” Titanium-Coated Dome Tweeter
Meets or Exceeds ASTM B117 (Salt/Fog Exposure)
Meets or Exceeds ASTM D4329 (UV Exposure)
Frequency Response: 50Hz – 22kHz
Efficiency: 93dB @ 1 meter, 1 watt
Cut Out Size: 6 1/4”
Mounting Depth: 2 3/8”
CMDC7.1
7" MARINE DUAL CONE SPEAKER SET
•
•
•
•
•
•
•
•
•
•
•
Maximum Power Handling: 120 Watts
Continuous Power Handling: 40 Watts
Polypropylene Woofer Cone
Santoprene Rubber Surround
Rubber Mounting Gasket
Meets or Exceeds ASTM B117 (Salt/Fog Exposure)
Meets or Exceeds ASTM D4329 (UV Exposure)
Frequency Response: 50Hz – 18kHz
Efficiency: 93dB @ 1 meter, 1 watt
Cut Out Size: 6 1/4”
Mounting Depth: 2 3/8”
142
Marine Audio - Sport Series Information
CMCS7.1s
CMSW10.1s
7" SPORT SERIES MARINE SPEAKER SET
10" SPORT SERIES MARINE
SUBWOOFER
•
•
•
•
•
•
•
•
•
•
•
Meets or exceeds ASTM B117 (Salt/Fog Exposure)
Meets or exceeds ASTM D4329 (UV Exposure)
7" Polypropylene Woofer
1.25" Titanium-Dome Tweeter
Santoprene Rubber Surround
Triple Gasket Design
UV-Resistant High-Impact Centrex 814 Plastic Grill and frame
Gold-Plated Speaker Terminals
Rubber-Insulated Tinsel Leads
Stainless Steel Mounting Hardware
160W Power Handling
143
•
•
•
•
•
•
•
•
•
•
•
•
•
Maximum Power Handling: 350 Watts
Continuous Power Handling: 100 Watts
Polypropylene Woofer Cone
Santoprene Rubber Surround
Rubber Mounting Gasket
Meets or Exceeds ASTM B117 (Salt/Fog Exposure)
Meets or Exceeds ASTM D4329 (UV Exposure)
Frequency Response: 60Hz – 2.5kHz
Efficiency: 88dB @ 1meter, 1watt
Wire Terminals: Gold-Plated Spade Terminals
Cut Out Size: 9 1/16”
Mounting Depth: 4 1/4”
Impedance: 4-Ohm
Wakeboard Tower Speaker System
MARINE WAKEBOARD TOWER SPEAKER
SYSTEMS
•
•
•
•
•
•
•
•
•
•
•
Meets or exceeds ASTM B117 (Salt/Fog Exposure)
Meets or exceeds ASTM D4329 (UV Exposure)
Hand Laid Fiberglass enclosure construction
7" Polypropylene Woofer
1.25" Titanium-Dome Tweeter
Santoprene Rubber Surround
Rubber Mounting Gasket
UV-Resistant High-Impact Centrex 814 Plastic Grill and frame
Spring Loaded Speaker Terminals
Stainless Steel Mounting Hardware (1-7/8" - 2-1/2")
160W Power Handling
Available Colour/Speaker Combinations
Model
K-CMR1720TS
K-CMR1720TW
K-CMR1720TB
K-CMR1720TS-S
K-CMR1720TW-S
K-CMR1720TB-S
Enclosure Colour
Silver
White
Black
Silver
White
Black
Speakers
CMCX7.1
CMCX7.1
CMCX7,1
CMCX7.1S
CMCX7.1S
CMCX7,1S
144
Marine Audio – Accessories
RTR600B/RTR600W
SEAGIM
MANUAL OPERATION MARINE COVER
MARINE ENCLOSURE WITH HYDRAULIC COVER
•
•
•
•
•
•
•
•
•
•
•
One-Piece design with removable screw covers
Rubber gasket behind main housing
Manual opening function
Easy push-button release
Protects DIN-sized radio from water splash damage
BNC5200B/BNC5200W
HYDRAULIC MARINE COVER
•
•
•
•
•
Two-piece front panel design - Main housing and trim ring
Rubber gasket behind main housing
Damped opening function
Easy push-button release
Protects DIN-sized radio from water splash damage
145
Protects 1-DIN radio from damage due to splashes
Two-piece front panel design - Main housing and trim ring
Rubber gasket behind main housing
Two wire/vent openings in removable rear panel
Damped opening function
Reversible mounting hardware - surface or suspended mounting.
Marine Audio – Subwoofer Specifications
CMSW10.1 T-S Parameters
CMSW10.1s T-S Parameters
Fs (Hz)
Qms
VAS (Litres)
VAS (Cubic Feet)
MMs (Grams)
Xmax (mm)
Xmax (inches)
Sd (m2)
Qes
Re
Le
Z
Bl
Qts
dB SPL (1W/1M)
Power (RMS)
Vd (Cubic Feet)
Outside Diameter
Mounting Hole
Mounting Depth
Total Weight
Grill Color
Fs (Hz)
Qms
VAS (Litres)
VAS (Cubic Feet)
MMs (Grams)
Xmax (mm)
Xmax (inches)
Sd (m2)
Qes
Re
Le
Z
Bl
Qts
dB SPL (1W/1M)
Power (RMS / MAX)
Vd (Cubic Feet)
Outside Diameter
Mounting Hole
Mounting Depth
Total Weight
Grill Color
49.7
9.243
21.57
0.761
63.46
10
0.394
0.0306
1.003
3.857
1.977
4.629
8.729
0.905
86.2
350
0.045
10-9/16"
8.875
4.5"
9.8 lbs
White
50.09
8.256
18.6
0.657
72.51
12
0.472
0.03067
1.084
4.152
2.064
4.983
9.351
0.958
85.33
350
0.045
10-9/16"
8.875
4.5"
9.8 lbs
Silver/Grey
Enclosure Designs
Enclosure Designs
Sealed Enclosure
Net Internal Air Volume:
F3 Frequency:
Total System Q:
0.9 ft3
52.5 Hz
1.1
Sealed Enclosure
Net Internal Air Volume:
F3 Frequency:
Total System Q:
0.6 ft3
56.24 Hz
1.0
Vented Enclosure
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
1.5 ft3
3" ID x 5.6" Long
32.19 Hz
Vented Enclosure
Net Internal Air Volume:
Vent Dimension:
F3 Frequency:
1.4 ft3
3" ID x 5.875" long
31.48 Hz
146
Marine Remote Compatibility Chart
DECK
BUS
Infra Red
M101RCB
M101RCC
M101RCW
M102RCB
M102RCW
XMA1
C-Bus
N/A
Yes
Yes
Yes
Yes
Yes
XMA2
N/A
N/A
N/A
N/A
N/A
N/A
N/A
XMD1
C-Bus
N/A
Yes
Yes
Yes
Yes/No Mute
Yes/No Mute
XMD2
N/A
N/A
Yes
Yes
Yes
Yes/No Mute
Yes/No Mute
XMD3
CeNET
N/A
Yes
Yes
Yes
Yes
Yes
CMD4
CeNET
N/A
Yes
Yes
Yes
Yes
Yes
CMD4A
CeNET
Yes
Yes
Yes
Yes
Yes
Yes
CMD5
CeNET
Yes
Yes
Yes
Yes
Yes
Yes
M475
CeNET
Yes
Yes
Yes
Yes
Yes
Yes
M455A
CeNET
N/A
Yes
Yes
Yes
Yes
Yes
M455
CeNET
N/A
Yes
Yes
Yes
Yes
Yes
M335
N/A
N/A
Yes
Yes
Yes
Yes
Yes
M275
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M255
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M0350
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M1000R
C-Bus
N/A
Inc
Inc
Inc
Inc
Inc
M2455
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M3170
C-Bus
N/A
Yes
Yes
Yes
Yes/No Mute
Yes/No Mute
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M3580
M4275
N/A
N/A
M5170
C-Bus
N/A
M5275
C-Bus
N/A
M5355
C-Bus
N/A
M5470
C-Bus
N/A
Yes
Yes
Yes
Yes/No Mute
Yes/No Mute
M5475
C-Bus
N/A
Yes
Yes
Yes
Yes
Yes
M5675
C-Bus
N/A
Yes
Yes
Yes
Yes
Yes
M5680
N/A
N/A
N/A
N/A
N/A
N/A
M8430
N/A
N/A
N/A
N/A
N/A
N/A
M9480
N/A
N/A
N/A
N/A
N/A
N/A
147
Marine Remote Compatibility Chart
DECK
M102RCS
M201RCS
M202RC
M301RC
XMA1
Yes
Yes
XMA2
N/A
N/A
XMD1
Yes/No Mute
Yes
XMD2
Yes/No Mute
Yes
XMD3
Yes
Yes/ No Display Yes/ No Display
Yes
CMD4
Yes
Yes/No Display Yes/ No Display
CMD4A
Yes
CMD5
CMRC1SB CMRC1BSS CMRC2SB CMRC2BSS
Yes/ No Display Yes/ No Display Yes/No Display
Yes/No Display
Yes
Yes
N/A
N/A
N/A
Yes/No Display Yes/ No Display Yes/No Display
Yes/No Display
Yes
Yes
Yes/ No Display Yes/ No Display Yes/No Display
Yes/No Display
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes/No Display Yes/ No Display
Yes
Yes
Yes
Yes
Yes
Yes
Yes/No Display Yes/ No Display
Yes
Yes
Yes
Yes
Yes
M475
Yes
Yes/No Display
Yes/No Display
Yes
Yes
Yes
Yes
Yes
M455A
Yes
Yes/No Display
Yes/No Display
Yes
Yes
Yes
Yes
Yes
M455
Yes
Yes/No Display
Yes/No Display
Yes
Yes
Yes
Yes
Yes
M335
Yes
Yes/ No Display
Yes
Yes/No Display
Yes
Yes
M275
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M255
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M0350
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M1000R
Inc
Inc
Inc
Inc
Inc
Inc
Inc
Inc
M2455
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Yes/No Mute
Yes/No Mute
N/A
N/A
N/A
Yes/ No Display Yes/No Display
Yes/No Display No Yes/No Display No
Yes/No Display
Mute
Mute
M3170
Yes/No Mute
Yes/No Display
Yes/No Display
M3580
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M4275
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M5470
Yes/No Mute
Yes/No Display
Yes/No Display
Yes/No Mute
Yes/No Mute
M5475
Yes
Yes/No Display
Yes/No Display
Yes/No Mute
Yes/No Mute
M5675
Yes
Yes/No Display Yes/ No Display Yes/ No Display Yes/No Display
Yes/No Display
Yes
Yes
M5680
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M8430
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M9480
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
M5170
M5275
M5355
Yes/No Display No Yes/No Display No
Mute
Mute
Yes/No Display No Yes/No Display No
Yes/No Display
Mute
Mute
Yes/No Display
148
UNGO
ProSecurity
Ungo – Information
K20
RS10
KEYLESS ENTRY SYSTEM
REMOTE ENGINE START WITH KEYLESS ENTRY
Features
Features
• (2) 4-Button Remote Transmitters (SAA474U)
• 2 Auxiliary Outputs
• On-Board Relays for Door Locks and Dome Light
Supervision
• Horn Honk Output
• Driver’s Door Unlock Priority Compatible
• Comfort Closure
• (+/-) Parking Light Output
• Common Features
•
•
•
•
•
•
S100
S670
SECURITY SYSTEM
TWO-WAY SECURITY SYSTEM
Features
Features
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
(2) 4-Button Remote Transmitters (SAA474U)
2 Auxiliary Outputs
(+/-) Parking Light Output
ProSecurity Programmer Compatible
Common Features
Common Security Features
(1) 4-Button Remote Transmitter (SAA474U)
1 Auxiliary Output
(-) Door Lock Outputs
Short Run / Turbo Timer Mode
(+/-) Parking Light Output
Comfort Closure
(1) 2-Way LCD Remote Transmitter (SAA477U)
(1) 4-Button Remote Transmitter (SAA474U)
3 Auxiliary Outputs
On-Board Relays for Door Locks and Dome Light Supervision
Horn Honk Output
(+/-) Parking Light Output
Comfort Closure
Common Features
Common Security Features
150
Ungo – Information
SR6000
SR9000
TWO-WAY SECURITY SYSTEM WITH REMOTE
ENGINE START
1-MILE RANGE TWO-WAY SECURITY SYSTEM
WITH REMOTE ENGINE START
Features
Features
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
(1) 2-Way LCD Remote Transmitter (SAA477U)
(1) 4-Button Remote Transmitter (SAA474U)
3 Auxiliary Outputs
Short Run / Turbo Timer Mode
Compact Satellite Relay Pack
Driver’s Door Unlock Priority Compatible
(+/-) Parking Light Output
ProSecurity Programmer Compatible
Common Features
Common Remote Start and Security Features
151
2-Way LCD Remote Transmitter (SAA7701U)
SDC (Secure Digital Communication) capable of 1-Mile Range
4 Auxiliary Outputs
Short Run / Turbo Timer Mode
Compact Satellite Relay Pack
Driver’s Door Unlock Priority Compatible
Built-In Wait to Start Diesel Timer
Driver's Door Priority
Defroster Output
Comfort Closure
Dedicated Horn Honk Output
ProSecurity Programmer Compatible
Common Features
Common Remote Start and Security Features
UNGO – Features and Technologies
Common UNGO Features
Anti-Code Grabbing Technology
Individual Remote Recognition
Keyless Entry*
Remote Enabled Valet
Hyper Blue Status LED
Remote Panic
Selectable Ignition Controlled Door Locks
ProSecurity Starter Disable*
ProSecurity Power Up
Progressive Door Unlock*
Dome Light Supervision Output*
Trunk/Hatch Release Output*
* May Require Additional Parts & Labor
Common Security Features
Extended Range Antenna
Dual Stage Impact Sensor
Programmable Override Sequence
Remote Silent Arm/Disarm Capability
Event History Diagnostics
Selectable Siren Duration and Tones
False Alarm Prevention Circuitry
Common Remote Start Features
Extended Range Antenna
Anti-Grind Circuitry
Tachometer or Voltage Sensing
Gasoline or Diesel Vehicle Compatible
Over and Under Rev Protection
Built-in Wait-to-Start Timer
Selectable Run Timer
Short Run Timer / Turbo Timer Mode
Rear Defroster Activation
UNGO Feature Descriptions
Secure Digital Communications
In order to achieve a reliable 1-Mile of range
from the SR9000, Clarion has implemented
Spread Spectrum Technology Secure Digital
Communication. Spread Spectrum Technology
takes a signal (in the case of the SR9000, a rolling code that tells the system what do to) and
spreads the code over a wide range of frequencies. The advantage of this is that because the
signal is so spread out, it becomes more resistant to interference, and helps to guarantee the
signal is received and decoded.
Ungo Spread Spectrum Technology operates
at 900Mhz, further improving its resistance to
interference
Anti-Carjacking
The optional anti-carjacking system feature is
designed to ensure that any unauthorized user
of the vehicle (even using the keys and remote
control) will not be able to permanently separate
the owner from their vehicle.
This system cannot prevent a carjacking attempt;
however, it does ensure that if an unauthorized
user takes the vehicle, it will be disabled (after
several progressive warnings) as a safely as
possible.
Anti-Code Grabbing Technology (a.k.a.
Code Hopping):
The receiver and remotes use a mathematical
formula called an algorithm to change their code
each time the remote is used. This technology
has been developed to increase the security of
the unit. The control unit knows what the next
codes should be. This helps to keep the remote
“in sync” with the control unit even if you use
the remote control out of range of the vehicle.
152
UNGO – Features and Technologies
Anti-Grind Circuitry
Whenever the vehicle is remote started,
advanced anti-grind circuitry prevents the starter from engaging, even if the key is turned to
the start position. This prevents damage to the
starter motor if the key is turned to the start
position during remote start operation.
Built-in Wait-to-Start Timer
Diesel vehicles need adequate time to warm
up the glow plugs prior to starting. When the
remote start is activated, the wait-to-start timer
will allow the glow plugs to properly warm up
before engaging the starter circuit. This feature
prevents damage to the motor and glow plugs
during remote start operation.
Comfort Closure
If programmed ON the door lock output will
activate the Comfort Closure output for 20 seconds. This output will begin 200mS after the
final door lock output has completed regardless
of the door lock programming. This feature is
designed to integrate with vehicle that can close
the power windows and sunroof by holding the
key in the driver door lock position, and will
operate on both single input systems and two
pulse dead bolt systems.
Dome Light Supervision Output
The dome light will illuminate for 30 seconds
each time the system is disarmed using the
remote control. This is useful for seeing inside
the vehicle at night prior to entering it.
Dual Stage Impact Sensor
A sensor mounted in the vehicle that is designed
to pick up impacts to the vehicle or glass.
Depending on the strength of the impact, the
sensor can determine whether it’s an accidental
contact or actual violation attempt.
Event History Diagnostic
ProSecurity systems can provide notification
that the alarm was previously triggered. The sta-
153
tus LED will indicate which zone was involved.
The system will retain this information in its
memory, until the next time the ignition key is
turned ON.
Extended Range Antenna
An optional external receiver/antenna used to
upgrade the remote/receiver performance in
areas of high radio interference such as military
bases, airports, and hospitals.
False Alarm Prevention
It prevents annoying repetitive sequences due
to faulty door pins switches or environmental
conditions such as thunder, jackhammers, airport noise, etc.
Gasoline or Diesel Vehicle Compatible
ProSecurity remote start systems can be
installed into either gasoline or diesel vehicles.
Hyper Blue LED
A blue LED (Light Emmiting Diode) mounted at
a discretionary location inside the vehicle. It is
used to indicate the status of your system.
Individual Remote Recognition
Individual Remote Recognition makes it possible to program different settings for each remote
that is used with the system. Then, whenever
a specific remote is used, the system will recall
the setting assigned to that remote. IDR lets up
to four users of the system have different settings that meet their specific needs. It is almost
like having four separate alarms in your vehicle,
one for each user.
Keyless Entry
Allows for easy entry or exiting of the vehicle
without having fumbling around for keys. May
require additional parts and labor.
UNGO – Features and Technologies
Over and Under Rev Protection
Remote Enabled Valet (REV)
The system monitors the engine speed and will
automatically shut the engine off if the RPMs
rise above or fall below the programmed levels.
This feature prevents damage to the motor due
to fuel delivery system failures or other problems, which may cause the engine to race.
The security system will not arm, even with the
remote, but all convenience functions (door
locks, trunk release, etc.) will still continue to
work normally. REV allows access to Valet
Mode without having to disclose the location of
the Valet/Override switch.
Programmable Override Sequence
Remote Panic
ProSecurity systems can be programmed to
respond to one to five pulses of the Valet/
Override Switch for the disarm function.
If you are threatened in or near your vehicle,
you can attract attention by triggering the system with your remote control. Just press the
“PANIC” or “LOCK” button for two seconds,
and you will enter Panic Mode. The siren will
sound and the parking lights will flash for the
programmed siren duration. To stop Panic
Mode at any time, press the “LOCK” button on
the remote.
Progressive Door Unlock
For added security, the ProSecurity system
can be configured to unlock the driver’s door
only, leaving the passenger doors locked.
Pressing the UNLOCK button an additional time
will unlock the passenger doors. This option
requires additional parts and labor.
ProSecurity Power Up
The ProSecurity system will store its current
state of non-volatile memory. If the power is
lost and then reconnected the system will recall
the stored state from memory. This means if
the unit is in Valet Mode and the battery is disconnected for any reason, when the battery is
reconnected the unit will still be in Valet Mode.
ProSecurity Starter Disable
An automatic switch controlled by your system
that prevents the vehicle’s starter from cranking
whenever the system is armed. The vehicle is
never prevented from cranking when the system
is disarmed, in Valet Mode, or if the starter interrupt switch itself fails.
Rear Defroster Activation
During remote start operation, the rear defroster
can be activated. This option requires additional parts and labor.
Remote Silent Arm/Disarm Capability
The siren chirps upon arm or disarm can be
temporarily eliminated for that one operation
only. The siren arm/disarm chirps can be turned
off permanently, if desired. The siren chirps will
also be eliminated during the warn-away trigger
of the Dual Stage Impact Sensor.
Selectable Ignition Controlled Door
Locks
When the ignition is turned ON, the doors will
lock within 3 seconds and unlock when the
ignition is turned OFF. Ignition controlled lock
and unlock are independent features are can be
programmed separately.
Selectable Siren Duration and Tones
The duration of the siren can be programmed
to either 30 or 60 seconds. Some states have
laws regulating how long a security system can
sound. The multi-tone sirens included with
ProSecurity systems can be easily modified to
select desired tones or single tone.
154
UNGO – Features and Technologies
Short Run Timer / Turbo Timer Mode
Short run turbo mode keeps the engine running
after arriving at your destination for a programmable period of time.
Tachometer or Voltage Sensing
ProSecurity remote start systems either use a
tachometer signal or sense the voltage of the
vehicle during remote start activation. These
signals inform the remote start system that the
vehicle has successfully started and is running.
The system’s auxiliary output can be programmed to operate a factory power release
for the vehicle’s trunk or hatch. If the factory
release is not power activated, an optional trunk
release solenoid can often be added.
Trunk/Hatch Release Output
The system’s auxiliary output can be programmed to operate a factory power release for
the vehicle’s trunk or hatch. If the factory release
is not power activated, an optional trunk release
solenoid can often be added. This output will
then disable / ignore the two-stage shock sensor as you load and unload the vehicle.
155
UNGO – Application Notes
Obtaining Optimal Range
It is recommended that all security components
be grounded at the same location.
Mounting the Extended Range Antenna:
Turning Off the Anti-Code Grabbing
Technology (a.k.a. Code Hopping):
1. Clean the mounting area with a quality glass
cleaner or alcohol to remove any dirt or residue.
2. Plug the receiver/antenna cable into the receiver/antenna.
3. Mount the receiver/antenna vertically using the
supplied double-sided tape.
4. Route the receiver/antenna cable to the control
module and plug it into the four-pin antenna connector.
Important:
• To achieve the best possible range, DO NOT
leave the antenna cable bundled up tightly
underneath the dash. Try to extend the cable the
full length during installation.
• DO NOT mount the control module to close the
vehicle’s Body Control Module and/or Electronic
Control Modules.
Mounting the Standard Antenna:
1. Route the antenna as high up as possible,
extending it to its full length.
2. Secure it in place using a cable tie.
Important:
• DO NOT cut or extend the antenna, as it’s tuned
precisely to the control unit.
• Route the antenna away from moving parts under
the dash and from the vehicle’s Body Control
Module and/or Electronic Control Modules.
Mounting the Control Unit:
• Do not mount or secure the control unit to close
to the vehicle’s Body Control Module and/or
Electronic Control Modules.
• Do not mount or secure the control unit to close
sources of heat, such as the heater core and/or
air ducts.
• Ground the control unit to a clean, paint-free
sheet metal location using a factory bolt that
DOES NOT have any vehicle component grounds
attached to it. A screw should only be used when
in conjunction with a two-sided lock washer.
Under dash brackets and door sheet metal are
not acceptable ground points.
Although this is a feature designed to prevent
the remote transmitters from being cloned and
retransmitted to the control unit, it is virtual
impossible to do. “Code Grabbers” have a very
limited range, usually required to within 5 feet of
the remote transmitter while the button is being
depressed. By turning the off the Anti-Code
Grabbing feature, it can increase the receiving/
transmitting range by 30-35%.
Refer to the “System Features Menu” for the
Feature Number and programming instructions.
Double Stacking (2) CR2016 Batteries:
The CR2032 3-volt micro lithium coin cell battery
inside of the SAA474U (4-button) remote transmitter can be substituted with (2) CR2016 3-volt
batteries. This can increase the range between
65-75%, depending on the surroundings.
Procedure:
1. Insert a small flat head screwdriver into the
notch on the bottom of the remote transmitter.
2. Gently twist the screwdriver to spreading apart
the two halves of the remote transmitter.
3. Open up the remote transmitter exposing the
CR2032 battery and slide it out.
4. Slide (2) CR2016 batteries into the battery
holder with the “+” facing upwards. (It may be
easier to slide one battery in at a time. With the
first battery in place, slide the second battery
between the PC board and battery.)
5. Prior to closing the two halves of the remote
transmitter, verify the batteries are installed
correctly by pressing any of the buttons. The
green LED indicator should illuminate when a
button is pressed. If the LED does not illuminate,
double-check the direction of the batteries. The
“+” should be facing upwards matching the “+”
on the battery retaining clip.
6. Snap together the two halves of the remote
transmitter.
156
UNGO – Application Notes
Obtaining a Tachometer Reference
Signal
The tachometer reference signal is an essential
signal for the safe operation of a remote start
system. This signal informs the remote start
module that the vehicle has successfully started
and is running. It can also determine whether the
vehicle is idling at a safe RPM level. In the event
the vehicles idle is racing or below safer operating
level, the remote start module will shut down.
To test for a tachometer wire, a multi-meter
capable of test AC voltage must be used. The
tachometer wire will show between 1V and
6V AC. In multi-coil systems, the system can
learn individual coil wires. Individual coil wires
in a multi-coil ignition system will register lower
amounts of AC voltage. Also, if necessary, the
system can use a fuel injector control wire for
engine speed sensing. Common locations for
a tachometer wire are at the ignition coil, back
of the gauge cluster, engine computers, and
automatic transmission computers.
How to Find a Tachometer Wire with a MultiMeter:
remote start module.
It is highly recommended to solder this connection, due to the heat generated inside the engine
bay. Using t-taps or scotch-locks are likely to fail
due to the heat.
Fuel Injector Wire:
1. Examine the individual fuel injectors and determine which wire(s) are common on each fuel
injector.
2. The “different” colored wire can be used for
the tachometer reference signal for the remote
start module. (Only one fuel injector wire is
necessary.)
3. Teach tachometer reference signal to the
remote start module.
It is highly recommended to solder this connection, due to the heat generated inside the engine
bay. Using t-taps or scotch-locks are likely to fail
due to the heat.
Tachometer Reference Options
Tachless
1. Set the multi-meter to ACV or AC voltage (12V
or 20V is fine)
2. Attach the (-) probe of the meter to chassis
ground.
3. Start the vehicle and allow it to reach its normal
idle speed.
4. Probe the wire you suspect of being the
tachometer wire with the red probe of the meter.
5. If it’s the correct wire the meter will read
between 1V and 6V.
If programmed to the voltage sense setting, the
unit will crank the starter for a preset time during.
Once the starter has been engaged, the system
will check the voltage level to verify the engine is
running.
Multi-Coil Systems:
Some vehicles have many accessories, which are
turned on during remote start activation. In these
vehicles, the variation of voltage between the
engine off and the vehicle running is very slight
and the remote start module may “think” the vehicle has not started. This can cause the remote
start module to shut down after the vehicle has
been started. If this is the case, the Voltage
Check Level must be set to the LOW position.
1. Examine the individual coils and determine
which wires are common on each coil. (Example:
2002 Chevy Pick-up: Each coil has 4 wires, three
common wires on each coil and the 4th wire
changes.)
2. The “different” colored wire can be used for the
tachometer reference signal for the remote start
module. (Only one coil wire is necessary.)
3. Teach tachometer reference signal to the
157
When using tachless operation, it is essential to
determine the correct crank time to prevent damage to the starter. It may take several remote start
activations to determine the crank time.
UNGO – Application Notes / Terms
Voltage sensing is not recommended in areas
that experience extreme cold temperatures. The
resistance in the vehicles wiring increases which
can cause intermittent remote start reliability.
454T: Alternator RPM Monitor
The 454T Alternator RPM Monitor is for use with
remote engine starts as an alternative to direct
connection to the vehicle’s tachometer or fuel
injector wire. It detects electrical spikes in the
vehicles electrical system and converts them into
an output that simulates a tachometer.
Passlock 2
The Passlock 2 system must see the correct
resistance code at the correct time. When the
ignition switch is turned to the crank position, the
“Bulb Check” wire is switched to ground. This
starts a time window during which the instrument
cluster panel (IPC) analyzes the resistance code
(R-Code). If the R-Code is valid and is received
in the proper window of time, the IPC sends a
code via data bus to the PCM to enable the fuel
injection system. If the key cylinder itself is pulled
out or damaged, it will not generate the resistance
code and the vehicle will not run.
Passkey 3
Remote Start Terms and Definitions
Immobilizer (a.k.a.: Transponder)
The Immobilizer uses an antenna ring around the
ignition cylinder to energize a small transponder
chip hidden in the ignition key. When the ignition is turned on, the chip is energized and the
antenna rings sends the code to the Immobilizer
control unit. The vehicle will only start if the code
matches the one programmed into the vehicle.
Passkey/VATS
The Passkey/VATS system consists of four parts:
the Passkey cylinder, the ignition switch, the
instrument cluster panel (IPC), and the power
train control module (PCM). The system requires
that the key cylinder be mechanically turned using
a key. When the key cylinder is properly turned,
it generates a resistance code (R-Code), which is
sent to the IPC. The vehicle will only start if the
R-Codes match the key and key cylinder.
The Immobilizer uses an antenna ring around the
ignition cylinder to energize a small transponder
chip hidden in the ignition key. When the ignition is turned on, the chip is energized and the
antenna rings sends the code to the Immobilizer
control unit. If the code is incorrect the vehicle
will not start.
PATS
Passive Anti-Theft System (PATS) uses a specially
programmed key to start the vehicle, similar to
the Immobilizer. It uses an antenna ring around
the ignition cylinder to energize a small transponder chip hidden in the ignition key. When the
ignition is turned on, the chip is energized and the
antenna ring sends the code to the PATS control
unit. If the code is incorrect the vehicle will not
start.
Resistor
One of the components necessary in interface
with VATS factory anti-theft systems. A resistor(s)
are used in conjunction to reproduce the resistance code (R-Code) embedded in the vehicle’s
key
158
Replacement Remote Controls
Model Number
Remote Description
5000-1
1 BUTTON TRANSMITTER FOR 5000 SERIES
SAA3651
5000-2
2 BUTTON TRANSMITTER FOR 5000-2 SERIES
SAA3652
6200
2 BUTTON TRANSMITTER (RED LED)
SAA3623
6200V
2 BUTTON VARICODE TRANSMITTER
SAA3624
6400
2 BUTTON TRANSMITTER (RED LED)
SAA3623
6400V
2 BUTTON VARICODE TRANSMITTER
SAA3624
6500
4 BUTTON TRANSMITTER (RED LED)
SAA3649
6500V
4 BUTTON VARICODE TRANSMITTER
SAA3650
CS100
2 BUTTON VARICODE TRANSMITTER
SAA3624
CS105
2 BUTTON REMOTE TRANSMITTER FOR CS105
SAA200T
CS150
3 BUTTON REMOTE TRANSMITTER
SAA150T
CS200
2 BUTTON REMOTE TRANSMITTER FOR CS200
SAA200T
G1100
3 BUTTON REMOTE TRANSMITTER
SAA003T
G1100
4 BUTTON REMOTE TRANSMITTER
SAA004T
GUARDSMAN
2 BUTTON GUARDSMAN TRANSMITTER
SAA3601
GUARDSMAN
VARICODE TRANSMITTER - 1000V SERIES
SAA3100
K10
4 BUTTON REMOTE TRANSMITTER
SAA474U
KE106
3 BUTTON REMOTE TRANSMITTER
SAA003T
KE106
4 BUTTON REMOTE TRANSMITTER
SAA004T
MC500
2 BUTTON VARICODE TRANSMITTER
SMA3255
MS1000
2 BUTTON VARICODE TRANSMITTER
SAA3624
MS1001
2 BUTTON VARICODE 2 TRANSMITTER
SAA3704
MS2000
3 BUTTON REMOTE TRANSMITTER
SAA003T
MS2000
4 BUTTON REMOTE TRANSMITTER
SAA004T
MC2000V
2 BUTTON VARICODE TRANSMITTER
SMA3255
MS2002
3 BUTTON REMOTE TRANSMITTER W/PURPLE BUTTONS
SAA3715
MS2004
4 BUTTON REMOTE TRANSMITTER
SAA004T
MS2005
4 BUTTON REMOTE TRANSMITTER
SAA004T
MS2006
5 BUTTON REMOTE TRANSMITTER
SAA005T
MS2007
5 BUTTON FM 2-WAY LCD TRANSMITTER
MS2100
5 BUTTON REMOTE TRANSMITTER
SAA205T
MS2105
5 BUTTON REMOTE TRANSMITTER
SAA205T
MS2106
5 BUTTON REMOTE TRANSMITTER
SAA205T
MS2107
5 BUTTON REMOTE TRANSMITTER
SAA205T
MS2107
5 BUTTON FM 2-WAY LCD TRANSMITTER
SAA217T
MS3001
3 BUTTON VARICODE 2 TRANSMITTER
SAA3705
159
Remote Part Number
SAA217T Generic
Replacement Remote Controls
MS3200
3 BUTTON VARICODE 2 TRANSMITTER
SAA3705
MS3200
3 BUTTON VARICODE 2 TRANSMITTER
SAA3706
MS3200
3 BUTTON REMOTE TRANSMITTER W/PURPLE BUTTONS
SAA3715
MS5000
3 BUTTON VARICODE 2 TRANSMITTER
SAA3703
MS5500
3 BUTTON REMOTE TRANSMITTER W/ BLUE BUTTONS
SAA3716
MS5505
3 BUTTON VARICODE 2 TRANSMITTER
SAA3716
MS7000
3 BUTTON VARICODE 2 TRANSMITTER
SAA3703
MS8200
3 BUTTON VARICODE 2 TRANSMITTER
SAA3706
MS8200
3 BUTTON REMOTE TRANSMITTER W/ BLUE BUTTONS
SAA3716
MS8300
3 BUTTON VARICODE 2 TRANSMITTER
SAA3706
MS8300
3 BUTTON REMOTE TRANSMITTER W/ BLUE BUTTONS
SAA3716
MS850
2 BUTTON REMOTE TRANSMITTER W/PURPLE BUTTONS
SAA3714
MS9000
3 BUTTON VARICODE 2 TRANSMITTER
SAA3703
RK1
4 BUTTON REMOTE TRANSMITTER
SAA474U
RS151
4 BUTTON REMOTE TRANSMITTER
SAA004T
RS251
4 BUTTON REMOTE TRANSMITTER
SAA251T
RS300
5 BUTTON REMOTE TRANSMITTER
SAA205T
S100
4 BUTTON REMOTE TRANSMITTER
SAA474U
S400
4 BUTTON REMOTE TRANSMITTER
SAA474U
S660
2-WAY REMOTE TRANSMITTER
SAA477U
S670
2-WAY REMOTE TRANSMITTER
SAA477U
RS10
4 BUTTON REMOTE TRANSMITTER (Number Pads SAA874)
SAA474U
K10
4 BUTTON REMOTE TRANSMITTER
SAA474U
K20
4 BUTTON REMOTE TRANSMITTER
SAA474U
SAS6200
2 BUTTON VARICODE TRANSMITTER
SAA3624
SAS6400
2 BUTTON VARICODE TRANSMITTER
SAA3624
SAS6500
4 BUTTON VARICODE TRANSMITTER
SAA3650
SMS0500
2 BUTTON VARICODE TRANSMITTER
SAA3624
SMS2000
2 BUTTON VARICODE TRANSMITTER
SAA3624
SR1000
4 BUTTON REMOTE TRANSMITTER
SAA474U
SR5000
2-WAY LCD TRANSMITTER
SAA477U
SR5000
4 BUTTON REMOTE TRANSMITTER
SAA474U
SR6000
2-WAY LCD TRANSMITTER
SAA477U
SR6000
4 BUTTON REMOTE TRANSMITTER
SAA474U
SR9000
2-WAY SST REMOTE TRANSMITTER
SAA7701U
TECHNE
1 BUTTON TRANSMITTER - JUMPER PROGRAMMING
SAA3621
TECHNE
2 BUTTON TRANSMITTER - JUMPER PROGRAMMING
SAA3622
160
UNGO – Application Notes
161
UNGO – Application Notes
162
UNGO – Application Notes
163
UNGO – Application Notes
Interfacing with Passkey 3 systems with Relays and Key
164
UNGO – Remote Start Diagnostics
Remote Start Diagnostics
The starter continues to crank even though
the engine has started.
In the event that a remote start system fails to
start, or stops running after a short period of time,
you can retrieve the source of the shutdown from
the UNGO ProSecurity system
1. Has the tach wire been learned? See Tach
Learning section of the installation guide.
2. Is the tach wire receiving the correct information? Either the wrong tach wire has been used,
or a bad connection exists.
1. Turn the Ignition off
2. Press and hold the Override switch
3. Turn the ignition on then off
4. Release the Override switch
5. Press and release the Override switch.
The LED will now report the last system shutdown by flashing one of the following patterns for
a period of one minute.
LED Flashes
One
Two
Three
Four
Six
Seven
Eight
Shutdown Cause
System Timed Out
Over-Rev Shutdown
Low or no RPM
Remote Shutdown or optional
button
+/- Shutdown
(-) Neutral safety shutdown
Wait-to-start timed out.
Remote Start Troubleshooting
The ignition comes on, but the starter will
not crank
1. Does it start with the key in the ignition? If so,
does the vehicle have a VATS Pass-Key system?
2. Will it start with the brake pedal depressed?
(Make sure to disconnect the brake shutdown
when performing this test.) If so, it may have a
brake/starter interlock.
3. Is the correct starter wire being energized?
Check by energizing it yourself with a fused test
lead.
The starter cranks for six seconds but does
not start.
1. Either the wrong ignition wire is being energized, the unit’s ignition and accessory wires have
been connected backwards, or the vehicle has
two ignition circuits. Try activating the unit with
the ignition key in the “run” position. If the vehicle
then runs normally, retest your ignition system.
165
The climate control system does not work
while the unit is operating the vehicle.
Either the wrong accessory wire is being energized or more than one ignition or accessory wire
must be energized in order to operate the climate
control system.
The remote start will not activate.
1. Check harnesses and connections. Make sure
the harnesses are fully plugged into the remote
start module. Make sure there are good connections to the vehicle wiring.
2. Check voltage and fuses. Use a meter and
check for voltage between the red wire in the 5
pin ribbon harness and the black ground wire. If
you have less than battery voltage, check both
30A fuses on the relay satellite. Also make sure
that the ground wire is going to a chassis ground
and not to something under the dash.
3. Check diagnostics. The diagnostics will tell you
which shutdown is active or not connected.
The remote start will activate but the starter
never engages.
1. Check for voltage on the purple starter wire two
seconds after the remote start becomes active. If
there is voltage present, skip to Step 4. If there is
not voltage present, advance to Step 2.
2. Check the 30A fuses.
3. Check diagnostics. If the gray/black wire is
detecting ground upon activation, the starter will
not crank.
4. Make sure the purple starter wire is connected
to the correct starter wire.
5. Does the vehicle have an immobilizer? Some
immobilizer systems will not allow the vehicle to
crank if active.
6. Check connections. The two red heavy gauge
input wires on the relay satellite should have solid
connections. “T-taps”, or “scotch locks” are not
UNGO – Remote Start Diagnostics
recommended for any high current heavy gauge
wiring. Also, if the vehicle has more than one
12-volt input wire, then connect one red wire to
each.
The vehicle starts, but immediately dies
1. Does the vehicle have an immobilizer? The
vehicles immobilizer will cut the fuel and/or spark
during unauthorized starting attempts.
2. Is the remote start programmed for voltage
sense? If so, the start time may not be set high
enough, or you may have to adjust the voltage
threshold in programming. Voltage sense will not
work on some vehicles.
3. Check diagnostics. Sometimes a shutdown
will become active during cranking or just after
cranking.
The vehicle starts, but the starter keeps running
1. Is the system programmed for engine checking off or voltage sense? When programmed for
either of these features, the engine cranks for the
preprogrammed crank time regardless of how
long it takes to start the vehicle to actually start.
Adjust to a lower cranking time.
2. Was the Tach Learn successful? The LED must
light solidly and brightly to indicate a successful
learn.
3. Make sure that there is a tach signal right at the
purple/white tach input wire of the remote start.
If not, recheck the connection to the vehicle’s
tach wire and make sure the wire is not broken or
shorted to ground leading to the remote start.
The vehicle will start and run only for about
10 seconds
1. Is the remote start programmed for voltage
sense? Try programming the unit for low voltage reference. If this does not work, a tach wire
should be used.
2. Check diagnostics.
166
UNGO – Multiple Vehicle Operation
Technical Information: Multiple Vehicle Operation
Ungo ProSecurity remote transmitters are capable of operating multiple vehicles equipped with ProSecurity
systems. This is beneficial for individuals with multiple vehicles and/or reducing the clutter on a keychain.
1. Follow the remote programming procedure for the particular ProSecurity system and delete all the
remote transmitters for both vehicles.
2. Follow the remote programming procedure for the particular ProSecurity system and program the
desired function to the assigned button. Continue this process until all the button assignments have
been complete on both vehicles.
EXAMPLE: S100 Multiple Vehicle Operation
Programming Vehicle 1.
1. Open the door of the Vehicle 1.
2. Turn the ignition ON
3. Press the Valet/Override button 9 times and then press it one more time and hold it in. The LED
will flash 9 times indicating that selection.
4. Release the Valet/Override button and turn the ignition OFF and then back ON.
5. Press the Valet/Override button 4 times and then press it one more time and hold it in.
6. Press the LOCK button on each remote transmitter. The LED will flash 4 times indicating that
selection.
7. Release the Valet/Override button and press it 1 time and then hold it in. The LED will flash 5
times indicating that selection.
8. Press the UNLOCK button on each remote transmitter. The LED will flash 5 times indicating that
selection.
9. Release the Valet/Override button and turn the ignition OFF and then back ON.
10. Turn the ignition ON.
11. Press the Valet/Override button 2 times and then press it one more time and hold it in.
12. Press both the LOCK and UNLOCK buttons together on each remote transmitter. The LED will
flash 2 times indicating that selection.
13. Release the Valet/Override button and turn the ignition OFF.
167
UNGO – Multiple Vehicle Operation
Vehicle 1:
LOCK: Arm (Lock)
UNLOCK: Disarm (Unlock)
LOCK & UNLOCK: Channel 2 (Auxiliary 1)
Programming Vehicle 2
1. Open the door of the Vehicle 2.
2. Turn the ignition ON
3. Press the Valet/Override button 9 times and then press it one more time and hold it in.
The LED will flash 9 times indicating that selection.
4. Release the Valet/Override button and turn the ignition OFF and then back ON.
5. Press the Valet/Override button 4 times and then press it one more time and hold it in.
6. Press the AUX button on each remote transmitter. The LED will flash 4 times indicating
that selection.
7. Release the Valet/Override button and press it 1 time and then hold it in. The LED will
flash 5 times indicating that selection.
8. Press the “*” button on each remote transmitter. The LED will flash 5 times indicating that
selection.
9. Release the Valet/Override button and turn the ignition OFF and then back ON.
10. Turn the ignition ON.
11. Press the Valet/Override button 2 times and then press it one more time and hold it in.
12. Press both the AUX and “*” buttons together on each remote transmitter. The LED will
flash 2 times indicating that selection.
13. Release the Valet/Override button and turn the ignition OFF.
Vehicle 2:
AUX: Arm (Lock)
“*”: Disarm (Unlock)
AUX and “*”: Channel 2 (Auxiliary 1)
168
UNGO – Door Lock Application Guide
Reverse Polarity Door Lock Systems
Aftermarket Door Lock Actuators
169
UNGO – Door Lock Application Guide
Vacuum Door Lock Systems
The lock pulse duration my be programmed to 3.5 seconds
One-Wire Door Lock System
This door lock system requires a negative pulse to unlock the foors , and cutting the wire to lock the
doors.
170
UNGO – Door Lock Application Guide
Multiplexed Door Lock Systems
Multiplexed door lock systems have more than one function on the same wire and require the use of
different resistor values. It is necessary to use external relays any time a resistor is used.
Positive Trigger Multiplexed Door Lock System
Test Procedure for Multiplexed Door Lock Systems:
1.
Locate the Lock/Unlock wire in the vehicle.
2.
Cut the wire in half and determine the polarity of the wire.
3.
Using a digital multimeter, measure the resistance for Lock and Unlock. (See Diagram)
Test Configuration for Positive Door Lock Systems
171
UNGO – Door Lock Application Guide
Multiplexed Door Lock Systems
Multiplexed door lock systems have more than one function on the same wire and require the use of
different resistor values. It is necessary to use external relays any time a resistor is used.
Negative Trigger Multiplexed Door Lock System
Test Procedure for Multiplexed Door Lock Systems:
1.
Locate the Lock/Unlock wire in the vehicle.
2.
Cut the wire in half and determine the polarity of the wire.
3.
Using a digital multimeter, measure the resistance for Lock and Unlock. (See Diagram)
Test Configuration for Positive Door Lock Systems
172
UNGO – Door Lock Application Guide
Multiplexed Door Lock Systems with On-Board Relays
Reverse Polarity Door Lock Systems with On-Board Relays:
173
UNGO – Door Lock Application Guide
Progressive Door Lock Using Positive Door Lock Trigger
174
UNGO – Door Lock Application Guide
Progressive Door Lock Using Negative Door Lock Trigger
175
UNGO – Programming Guide
Technical Information Module Programming: Models: K10, K20, S670, RS10
System features can also be changed by using the ProSecurity Programmer
176
UNGO – Programming Guide
Technical Information Module Programming: Models: S100, S400, S660, SR1000, SR5000, SR6000
System features can also be changed by using the ProSecurity Programmer
177
Car Audio
Reference Guide
Special Thanks to the Mobile Dynamics
Toronto Campus for their assistance in
the creation of this portion of the Clarion
Application Guide
Car Audio Reference Guide
Car Audio Reference Guide
This section of the 2008 Clarion Application
Guide provides some basic guidelines, tips and
tricks related to the installation and design of
a car audio system. This section in no way
replaces proper training, certification, mentorship
and experience.
Tools
Clarion recommends
that high quality tools
be used at all times.
The use of quality tools
helps to ensure proper
engagement
with
fasteners, a reduced
chance of stripping, rounding over or damage
to the vehicle. This applies to socket sets,
screwdrivers, crimpers, pliers, wrenches, wire
strippers and so forth.
Clarion recommends that only a high
quality Digital Multimeter be used for
testing ALL electrical circuits. Test
lights can cause damage to automotive
computer systems, resulting in
expensive repairs.
When
you
are
installing
a mobile
security, convenience
or remote start system,
you commonly have to
probe many wires. A
tool that makes this very
easy is the Power Probe II. It will indicate both
12V or Ground both with an LED and an audible
tone - meaning you don't need to 'read' a display.
It will also provide power and ground at the test
probe tip - ideal for testing door locks and other
electrical components.
Clarion strongly recommends that all electrical
connections be soldered. A properly performed
solder connection will start with a good solid
mechanical connection - ie: The wires should
already have a strong mechanical connections typically twisted together. Once the mechanical
179
connection has been established, then the
connection can be heated thoroughly with
the soldering iron and solder flowed into the
connection. Soldering provides an airtight
connection that helps to prevent corrosion.
Once the solder connection is complete and has
cooled, wrap the connection tightly with good
quality electrical tape. Clarion recommends 3M
vinyl tape.
An alternative, though less reliable than soldering
is the use of high quality, properly sized butt
connectors and a good quality crimping tool.
Clarion recommends the Klein 1005 or equivalent
crimping tool.
Clarion does not recommend the 'twist and tape'
method of making electrical connections.
With the increasing use of data connections in
the car, an the need to interface with Vehicle
Speed Sensor (VSS) wires for Navigation System
installations, Clarion recommends that all
installation facilities have at least one portable
oscilloscope available. An oscilloscope will
dispplay voltage waveforms on its screen relative
to a fixed time base. The oscilloscope can also be
used to set amplifier gains to prevent clipping and
distortion through the audio signal path.
Car Audio Reference Guide
Vehicle preparation and precaution
Before beginning work on a vehicle, inspect
it thoroughly for pre-existing damage or nonfunctioning circuitry. Show the customer any
problems BEFORE you begin work on the vehicle.
Clarion recommends the use of a work order form
for each vehicle that has a vehicle diagram on the
rear of the form. The installer can indicate any
pre-installation conditions and have the customer
initial/sign the form.
If you will be required to disconnect the battery,
ensure that you have the security code for the
source unit - if applicable.
When working under the hood, use fender covers at all times to prevent damage. Use magnetic
screw trays to hold nuts, bolts and screws, and
store all tools on a cart next to the vehicle. Do
not rest tools on the engine, cowl or fenders of
the car.
The image above shows an electrical representation of a spoken conversation. The high points
represent high sound levels and low areas represent little or no sound.
Frequency
If you look at sound using an oscilloscope, you
can see the voltage moving up and down relative
to time. If you are listening to a pure tone - like the
'test tone' on your TV in the middle of the night,
then waveform will look something like the graph
below.
When working inside the car use carpet and seat
protectors. If you will be making electrical connections, protect the area below where you are
working with a drop cloth capable of handling
drops of solder.
When working with the door open installing a
remote start (or similar), especially on expensive
cars, protect the door sill with masking tape. This
will help prevent scratches from occurring.
Period
Car Audio Physics
Understanding some of the basic fundamentals
of physics is required to comfortably sell and
install car audio products.
Sound
Sound is essentially changes in air pressure.
These compressions and rarefactions cause
minute bones inside our ears to vibrate, which
our brains translate into perceived sound.
The period is the amount of time between two
identical points on a repeating waveform. We
measure this in seconds or milliseconds. If you
take the reciprocal of this number, you get frequency. For example - If you measure a period
using a scope of 0.025 seconds, then take the
reciprocal (1/0.025) you will see the frequency is
40Hz.
Amplitude
The Amplitude of a sound describes its intensity,
loudness or strength. Later on we will explain the
Decibel scale and how it relates to sound pressure measurement and observation.
180
Car Audio Reference Guide
Frequency Response
If you look at the sound coming from a speaker,
you want all the different frequencies to be reproduced at the same level. This is known as the
frequency response of a speaker. A frequency
response graph, shows the output level (of a
speaker, amplifier, source unit, etc). The X-axis
represents the different frequencies measure and
the Y-axis represents how strong the output is.
Ideally, a speaker would produce all frequencies
at exactly the same level, but due to the physical
limitations of every speaker, this is not possible.
The graph below shows the frequency response
of a typical high-quality full-range speaker.
The goal of a high quality car audio system is
to accurately reproduce a musical performance.
When sound is recorded in stereo (two channels),
it is of the utmost importance that the sound
coming from each channel arrives at the listeners
ear simultaneously. This can be achieved through
proper speaker placement, or compensated for
by using time alignment or digital delays.
Octave
An Octave is a way of describing a doubling or
halving of a frequency. If a 1,000Hz (1kHz) tone is
being played, a tone one octave higher will be at
2.0 kHz. If the second tone were an octave lower,
it would be at 500Hz (0.5 kHz).
Decibel
This is one of the most misunderstood terms in
modern audio discussions. The BEL is the unit of
measure used to describe sound intensity. It was
first defined by Alexander Graham Bell. The Bel is
an extremely large unit of measure, so the Decibel
unit is more commonly used. 1 Decibel (dB) is
equal to 0.1 Bel.
Phase
Phase refers to the relative arrival time of two
signals or waveforms. Imagine two speakers
playing the exactly same sound, set up in your
living room. If you were to take one speaker and
move it further away from you, the time it takes for
the sound to arrive at your ears changes. This is
known as a delay or phase shift. The graph below
shows a phase shift between two sine waves.
The Decibel was created in response to numerous
tests on human hearing to describe sound
intensities (volume).
1dB = The smallest perceivable change in intensity
within the most sensitive range of human hearing
(between 3 and 4 kHz)
3dB = The smallest perceivable difference in
intensity at all frequencies.
10dB = A perceived doubling or halving of sound
intensity
In terms of electrical signals, decibels can still
be used to describe the difference between two
voltages or amplitudes. This is quite convenient
when talking about power coming from an
amplifier, since each time we want to increase
the perceived output from a speaker system by
3dB, we need to double the power coming from
an amp.
181
Car Audio Reference Guide
Example: A speaker has an efficiency rating of
88dB 1W/1M. This means that when this speaker
is installed in an infinite baffle (the wall of a very
large room for example) and powered with 1
Watt of power, it will produce 88dB of sound. If
we want to increase the output of this speaker
to 91dB, we need 2 Watts of power from the
amplifier. The following chart outlines the power
required for this speaker to reproduce different
sound levels:
Reference - 88dB 1W/1M
Output Level
118
115
112
109
106
103
100
97
94
91
88
85
82
79
76
73
70
67
64
61
58
Power (Watts)
1024
512
256
128
64
32
16
8
4
2
1
0.5
0.25
0.125
0.0625
0.03125
0.015625
0.0078125
0.00390625
0.001953125
0.000976563
Relative difference
+30dB
+27dB
+24dB
+21dB
+18dB
+15dB
+12dB
+9dB
+6dB
+3dB
0dB
-3dB
-6dB
-9dB
-12dB
-15dB
-18dB
-21dB
-24dB
-27dB
-30dB
You can see that the power being produced by an
amplifier needs to vary over an enormous range to
reproduce music at different listening levels. You
can also see that significant amounts of power
are required to reproduce realistic listening levels,
which is why high quality car audio amplifiers are
very important.
Limits of Sound
How loud a speaker can play depends on two
important criteria.
1 - How much power a speaker can handle.
2 - How far the speaker cone can move.
Thermal power handling is determined primarily
by the physical size of the voice coil assembly,
and by the materials used to construct the voice
coil. An inexpensive speaker may use a cardboard
voice coil former with very thin copper wire with
only one winding layer. if a great deal of power
is sent to the speaker, the voice coil will heat up
quickly and become damaged. Conversely, a
large diameter voice coil, wound on an aluminum
former (for example) with four layers of copper
can clearly withstand more heat.
Thermal power handling can also be affected
by the design of the components surrounding
the voice coil. SET (Spider Exhaust Technology)
allows air flow in and around the voice coil
assembly to help remove heat. A tighter gap
between the voice coil and the top plate also
helps to transfer heat away from the voice coil
and reduce termperatures. And finally, a vented
pole piece allows airflow around the inside of the
voice coil for cooling from the inside.
Physical power handling is determined by the
physical dimensions and capabilities of the
components used to construct a loudspeaker. The
spider and surround (suspension components)
control cone motion (and center the cone in the
voice coil gap). These are often chosen carefully
to be the limiting factor in excursion capability so
that physical damage doesn't occur due to overexcursion. Most often, if the suspension is not
stiff enough, the voice coil former will run into the
bottom plate as the speaker moves rearward.
Physical power handling is controlled through
proper enclosure design and by sending the
proper signals to the speaker.
Small speakers should not be sent large amounts
of low frequency information - you wouldn't
expect a subwoofer to try and reproduct bass in
182
Car Audio Reference Guide
your car. A crossover (active of passive) should
be used to limit low frequencies sent to small
drivers.
In the case of a subwoofer enclosure, there are
two factors that will determine power handling.
In both sealed and vented enclosures, the size of
the enclosure has a great effect on the physical
power handling. A larger enclosure offers a 'softer'
air spring to resist the motion of the cone.
In a vented enclosure, the driver "see's" the
enclosure as being nearly infinitely large below the
tuning frequency. It is of the utmost importance
that the tuning frequency be low enough to
control cone motion. Clarion recommends the
use of a subsonic filter when a vented enclosure
is used with a high (>35Hz) tuning frequency to
prevent speaker damage.
183
Car Audio Reference Guide
Relays
Relay Circuits
The ability to switch high current electrical circuits using
low current control systems
has made the use of relays
extremely popular. Relays
can also be used to perform
relatively elaborate processes - including conversion
from positive to negative
pulsing, negative to positive
pulsing, momentary to constant pulsing, retained
accessory circuits and so forth. This section will
look at the basic connections on a relay and
some of the most basic circuits. A few minutes of
searching on the Internet will reveal some of the
more complex circuits available.
This circuit allows multiple loads to be switched
from a single relay. This is convenient for using a
single remote turn on wire from a source unit to
turn on multiple amplifiers.
Relay Connections
The following circuit will take a positive input
(front a door trigger for example) and convert it to
a negative output.
The most popular (and recommended) relays are
available from Bosch and Potter and Brumfeld.
These SPDT (Single Pole Double Throw) relays
can handle in excess of 20A of current while only
requiring 200mA (0.2 A) to energize the circuit.
This diagram shows the pin locations and labels
on the bottom of a relay.
Pin
Function
30
87
87a
85
86
Common Connection
Normally Open Connection
Normally Closed Connection
Coil
Coil
The following circuit will take a negative trigger
(output from an alarm) and convert it to a positive
output (to drive a light or fan for example).
184
Car Audio Reference Guide
Common Car Audio Math
The following section provides a simple and easy
to use reference for some of the more commonly
utilized mathematical formulas in the car audio
industry.
Ohm's Law
Ohm's Law was named after Georg Ohm, a
mathematician and physicist, born in 1789 and
lived to be 65 while living in Bavaria. Mr. Ohm
created the foundation for the basic units of
electricity which are now accepted as a standard
worldwide. Ohm's Law describes the relationship
between Power, Voltage, Current and Resistant in
AC, DC and RF (Radio Frequency) circuits and is
the foundation for all electronic circuit design.
Voltage (measured in Volts) is a measurement of
electrical potential between two points. One Volt
is the potential difference required to move one
Coulomb of charge between two points in a circuit while using one Joule of energy.
Current (measured in Amps) describes the rate of
electron flow in a circuit. One amp is equivalent
to the flow of one Coulomb (6.25x108 electrons)
per second.
Resistance (measured in Ohms) is the unit of
resistance to current flow. One Ohm of resistance will allow one Amp of current to pass when
a potential of one Volt is applied to a circuit.
The Greek letter Omega is universally used to
describe Ohms.
Power (measured in Watts) is a measurement of
electrical work being done. One Watt is equivalent to one Joule of energy being transferred or
dissipated in one second.
Joules is the Metric unit of energy (replaces
Calorie) and is equivalent to the amount of work
needed to apply a force of one Newton over a
distance of 1 Meter. 1 Calorie = 4.184 Joules
The above chart provides all the common formulas related to Ohm's Law.
185
These units are used to describe the function of
any electrical circuit. Using the Ohm's Law wheel
on the left side of this page, you can calculate any
third unit when you know two of them.
Car Audio Reference Guide
Resistance Formula Calculations
Current Formula Calculations
How to read the Ohm's Law wheel
Resistance = Voltage / Current
Resistance = Voltage2 / Power
Resistance = Power / Current2
Example:
If you know a circuit has a voltage potential of 12
Volts and 6 Amps of current is passing through
it, then you can calculate the resistance in that
circuit: 12 ÷ 6 = 2. The circuit has a resistance of
2 Ohms.
Example:
If you know a device is dissipating 100W of
energy and has a resistance of 4 Ohms, you can
calculate the current being passed through the
device: —(100 ÷ 4) = 5 Amps
Power Formula Calculations
Example:
If you know a device is dissipating 100W of power
and 12V is being applied to the device, you can
calculate the current passing through the device:
100 ÷ 12 = 8.33A
Voltage Formula Calculations
Example:
If you know a device (a resistor for example) has
2A of current being passed through it and has
a resistance of 10 Ohms, then the voltage drop
across the resistor will be: 2 x 10 = 20V
186
Car Audio Reference Guide
Resistance Circuit Calculations
Parallel
There are two ways of connecting devices (or
loads) together - series and parallel.
Series Circuits
When multiple devices are wired in Series then
use the following formula:
Rtotal = R1 + R2 + R3 + R...
The total resistance is the sum of each resistance.
Example:
A circuit with four 2-Ohm loads wired in Series
has a total resistance of: 2 + 2 + 2 + 2 = 8 Ohms
Parallel Circuits
When multiple resistive devices are wired in parallel, the formula is slightly more complex:
1/Rtotal = 1/R1 + 1/R2 + 1/R3 + 1/R...
This is know as calculating the sum of reciprocal
resistances.
Example:
A circuit with four 8-Ohm loads wired in parallel
has a total resistance of:
1 / ((1/8)+(1/8)+(1/8)+(1/8) = 2 Ohms
Circuit wiring Descriptions
So how do you wire a device (most commonly
a speaker) in series or parallel? The drawings
below described each method.
The example above shows a Dual Voice Coil
subwoofer with both voice coils wired in parallel. The two positive connections are both connected to the positive terminal of the amplifier
and both negative connections are connected to
the negative terminal of the amplifier. If this were
a PXW1051 with dual 2 Ohm voice coils, the load
would be 1 Ohm, if this was a PXW1052 with
duial 4 Ohm voice coils the net load would be 2
Ohms.
Series Parallel Circuits
This example is more complex. When multiple
drivers are in use, you can wire each driver using
series or parallel, then wire the set of drivers in
either series or parallel. When multiple drivers
are being used, Clarion recommends wiring each
speaker in series with the other. In the unlikely
event of a speaker failure, this provides the most
protection against further damage.
Series
The example above shows a Dual Voice Coil
subwoofer with both voice coils wired in series.
If this were a PXW1051 with dual 2 Ohm voice
coils, the net load would be 4 Ohms. If this was
a PXW1051, with dual 4 Ohm voice coils, the net
load would be 8 Ohms.
187
In this example, if we are using two PXW1051
subwoofers, the net load would be 2 Ohms. If
these were PXW1052 subwoofer, the load would
be 4 Ohms.
Car Audio Reference Guide
Passive Crossovers
When connecting multiple speakers to an amplifier, passive crossover components are often
required to filter the signal going to each speaker.
For example, if you connect a midrange and a
tweeter, you don't want bass to go to the tweeter
and you don't want highs to go to the midrange.
Similarly, if you bridge a woofer to a two channel
amp and a set of full-range speakers, you only
want bass to be heard from the woofer and only
mids and highs from the full-range speakers. This
section will describe how to calculate the appropriate component (capacitor or inductor) values
to build these systems.
Nomenclature
Capacitors have two ratings - a capacitance value
and a voltage. The amount of energy storage in a
capacitor is measured in Farads. Since the Farad
is a very large unit, most capacitors, especially
those used in filter circuits are measured in 1 millionth of a farad, or a microfarad. The greek letter
mu (μ) is used to describe micro:
1μF = 1/1,000,000 of a Farad and is pronounced
1 microFarad.
Common values for filter capacitors range
between 1μF and 250μF.
1mH = 1/1000 of a Henry and is pronounced 1
milliHenry.
Inductors are rated in Henries. Again, this is a very
large unit of measurement, and in filter networks,
we use 1 thousanth of a Henry or a milliHenry.
High-Pass filters
A high-pass filter allows only frequencies higher
than the selected crossover point to pass through
the circuit. We use non-polarized capacitors
wired in series with the load to create these filter
networks. The equation above outlines how to
calculate the correct component value. The chart
below outlines common capacitor values for
common speakers sizes in a 4 Ohm impednace.
Load impedance is ciritcally important to passive
crossover component value. If you change the
impedance, you need to recalculate the component value.
Speaker Size
Capacitor
6x9, 6x8
6.5, 5x7
5.25
4, 4x6
3.5
Tweeter
250-300 μF
200 μF
150 μF
100 μF
47μF
2.7-3.3μF
188
Car Audio Reference Guide
Low-Pass filter
Passive Crossover Wiring - Mixed mode
Combinations of high- and low-pass filters can
be combined amongst different speakers. This
is commonly used when wiring mixed-mode
systems. The illustration below shows the wiring drawing for a pair of 6x9 speakers and a
subwoofer on a single two channel amplifier. The
subwoofer would be connected to the bridged
terminals and the 6x9s would be wired in stereo.
Using the crossover information provided previously, we would use a 250uF capacitor on each
6x9 and a 6.6mH inductor on the subwoofer.
Not surprisingly, a low-pass filter allows only
those frequencies below the selected crossover
point to pass un-attenuated. Low-Pass filters are
typically used with subwoofers, as you don't want
mids and highs to be reproduced.
In car audio, we use an inductor (also called a
choke) as a low-pass filter. The formula above
allows you to calculate the appropriate inductor
value. For most single 4 Ohm subwoofers, a 6.0
or 6.6mH inductor works well.
189
In application, wether the passive component is
installed on the positive wire or the negative, it will
have no effect on the performance of the circuit.
However, it is common to wire all speakers in the
same fashion for simplicity and to make troubleshooting and adjustments later on.
Car Audio Reference Guide
Subwoofer Enclosure Guide
Even the most expensive, complex subwoofer on
the planet won’t sound good unless it is installed
in a properly designed and constructed enclosure. The following section outlines subwoofer
enclosure design and construction guidelines.
Construction Notes
All enclosure should be constructed of 3/4” thickness North American-produced MDF or highquality plywood with one finished side (installed
facing the inside of the enclosure). The use of
particle board will result in substandard performance and could potentially lead to premature
speaker failure.
• All enclosure joints must be secured with
• When calculating enclosure volumes, please
remember to include the volume of the subwoofer,
the vent(s) and/or brace(s) in your calculations.
• For optimal performance from your subwoofer
enclosure, the ideal ratio of Width to Height to
Depth should ideally match the Greek Golden
Rectangle ratio of W=1.0, D=0.618 and H=1.618.
This ratio of dimensions results in a reduction of
standing waves inside the enclosure and the best
possible sonic performance.
• Where applicable, the inside and outside edge
of all vents should be rounded over (radiussed)
to smooth airflow over the edge of the vent. This
can be done with a router and a round-over bit.
The use of Aeroports (or equivalent) also works
very well.
screws or nails.
Subwoofer Enclosure Application Chart
• Wood glue (or equivalent) must be used along
the edges of all joints.
• All panel joints should be sealed with appropri-
ate caulking material - latex or rope caulk. Do not
use Silicone sealant - the gases that are released
during the curing process may be harmful to the
adhesives used to assemble a subwoofer.
• Large panels should be reinforced with an
internal brace to reduce panel flexing due to the
pressures created inside the speaker cabinet.
Likewise, around the mounting face of the subwoofer, braces should run from the front panel
to the rear panel of the enclosure to further
strengthen it.
There are many different styles of subwoofer
enclosures - sealed, vented, bandpass, transmission line, aperiodic, isobaric and multi-chamber
vented - just to name a few.
Each enclosure has different strengths,
characteristics and weaknesses. The chart below
provides a generalised overview of the differences
between some of the most common enclosures.
Clarion recommends the use of Sealed (Acoustic
Suspension) or Vented (Bass Reflex) enclosure
for our subwoofers. These enclosures are the
easiest to design, offers the best dynamic and
transient response characteristics and is the
most tolerance of design and construction errors
- bottom line, they always sound great!
• Clarion does not recommend the use of passive
crossover components with our subwoofers
(Inductors or Chokes). We recommend that a
dedicated subwoofer amplifier with an integrated
electronic crossover be used to achieve maximum
performance from the sub-bass system.
• Where applicable, Clarion recommends the use
of a subsonic filter in ported enclosure applications.
190
Car Audio Reference Guide
Subwoofer Enclosure Calculations
Clarion offers an extensive line of high quality,
product specific subwoofer enclosures. Clarion
dealers will, on occasion, be called upon to custom build a subwoofer enclosure from scratch
to better maximise the space inside a vehicle,
provide room for additional speakers, integrate
an elaborate amp rack or to perform a completely
custom installed. The following instructions outline the steps required to design a custom-sized
subwoofer enclosure.
Step 1: Measurements
The first step is to take careful measurements of
the vehicle in which you want to build the enclosure. You must measure the maximum width,
height and depth, taking into consideration the
ability to install the enclosure into the vehicle
through the trunk/hatch opening. Also consider
bracketry, seatbelt enclosure and other obstacles
in the trunk.
Example:
Trunk Width: 35.0 inches
Trunk Height: 14 Inches
Desired Max Depth: 11 Inches
The Maximum desired depth and/or the trunk
opening will determine just how big the enclosure
can be. You can always make it smaller.
Step 2: Rough Calculation
Now that you have some basic numbers, you
can calculate the maximum possible enclosure
volume. Clarion strongly suggests that 3/4" or
thicker MDF or good quality 'one side good' plywood be used for all enclosures. In our example
we will use 3/4" material.
Example:
Take each dimension and subtract the wood
thickness:
Internal Width: 35.0 - (2 x 0.75) = 33.5
Internal Height: 14 - (2 x 0.75) = 12.5
Internal Depth: 11.0 - (2 x 0.75) = 9.5
191
Multiply these numbers together to come up
with an internal volume:
33.5 x 12.5 x 9.5 = 3978.125 cubic inches
Divide by 1728 to convert this measurement into
cubic feet:
3978.125 ÷ 1728 = 2.30 ft3
This is the largest air volume (not including woofer, port or brace displacement you can use. You
can now select the subwoofers you want based
on this information.
Step 3: Subwoofer Selection
Clarion subwoofer spec sheets include several
popular and highly effective enclosure designs.
Using the volume calculated above, you can
choose any driver or combination of drivers you
want to occupy this space.
Example:
In our example, we have a maximum gross
volume of 2.30 cubic feet. Looking through the
Application Guide - we see that a few of our
options are:
The PXW1252 requires a net volume of 1.7
cubic feet in a ported enclosure.
Two PXW1252 woofers require a net volume of
1.6 cubic feet in a sealed enclosure
Two PXW1052 require a net volume of 2.0 cubic
feet in a ported enclosure.
Three PXW1052 subwoofers require a net volume of 1.5 cubic feet in a sealed enclosure.
One PXW1552 requires a net volume of 1.5
cubic feet in a sealed enclosure
We'll go with a pair of PXW1052 drivers in a
vented enclosure.
Step 4: Final Volume Calculations
Knowing the maximum width and height of
the enclosure, so we can modify the depth of
the enclosure to create the perfect net internal
volume.
Car Audio Reference Guide
Example - Vent Volume
The vent volume calculation goes as follows:
The spec sheet outlines the need for two vents,
each with an internal diameter of 2.5 inches
each with a length of 8.25 inches. To calculate
the volume of each vent, we need to determine
how much space those vents will occupy in the
enclosure:
Area of a circle formula: Pi x R2 = 3.1416 x R x R
Where R is the radius of the outside of the vent.
Most round vents are made of ABS plastic drainage pipe with a wall thickness of 0.125 - 0.25
inches. For a 2.5" pipe, the outside diameter
would be approximately 2.75 inches.
Part of the vent extends through the face of the
enclosure, so we can subtract the thickness of
the front panel of the enclosure from the volume
calculation.
3.1416 x 1.375 x 1.375 x (8.25 - 0.75) = 44.546
cubic inches.
sion calculation would go as follows:
Convert cubic feet to cubic inches:
1.5 x 1728 = 2592 cubic inches.
Divide by internal height:
2592 ÷ 12.5 = 207.36
Divide by internal width:
207.36 ÷ 33.5 = 6.189
6.189 is the internal depth of the enclosure. Add
the thickness of the front and rear panels and you
have the outside depth of the enclosure:
6.189 + 0.75 + 0.75 = 7.689
You may need to massage the width or height
dimensions of the enclosure to provide adequate
mounting depth and port clearance for your
design. You can alter any dimension necessary
to achieve the desired result.
We have two vents, so we double that volume:
44.546 x 2 = 89.09 cubic inches
Then convert back to cubic feet:
88.03 ÷ 1728 = 0.05 cubic feet.
Example - Total Volume
We need to add the air volume required to the
displacement of any objects inside the enclosure.
Here are the items we need to consider:
Net Air volume: 2.0 cubic feet
Driver displacement: 0.12 cubic feet each
Vent Displacement: 0.05 cubic feet total
Total air volume = 2.0 + 0.12 + 0.12 + 0.05 =
2.29 cubic feet.
For this example, the dimensions are within 1%
of the target volume, and we can use the 35 x 14
x 11 dimensions.
Step 4a: Alternate Volume Calculations
If we needed a smaller volume, let's say 1.5 cubic
feet gross air space, then the enclosure dimen-
192
Car Audio Reference Guide
Amplifier Installation
Power Cable Sizing
When installing an amplifier in a modern vehicle,
careful consideration needs to be paid to power
wire connections. High power amplifiers can
easily consume significant amounts of current easily exceeding 100A+ of current.
Proper power wire sizing is paramount in allowing
an amplifier to make its rated power. The chart
below outlines the power cable requirements to a
single amplifier.
Ground Connections
Wiring Protection
It is paramount that any power wire run through
the car, be it a large gauge cable to power and
amplifier or a small wire to power an accessory
such as an overhead monitor, be fused.
Imagine the following scenario - a large audio
system is installed in a vehicle - a 1/0 AWG power
cable is run from the battery to a distribution
block at the rear of the car. The car gets into an
accident - it is T-Boned on the side of the car the
power wire runs down. The impact pinches the
power, shorting it directly to ground. This could
result in the battery exploding or at least, wires
melting and catching fire.
Clarion recommends the use of an ANL or AGU
fuse holder on all power wires. When connecting
any cable to the battery, a fuse must be installed
within 8 inches of the battery terminal. Clarion
does not recommend the use of circuit breakers. Their failure mode (what happens when the
device does not operate as intended) does not
guarantee that the circuit will be protected in the
event of a short circuit.
193
When installing an amplifier, it is paramount that
the ground connection and path back to the
battery and alternator be capable of handling
even more current than the audio system will
utilize. The reason is that the factory electrical
system (lights, fans, computers, sensors, ignition
system, etc) is already using these connections
to operate the vehicle. Any cable you add to
the positive circuitry, will need to be added to
the ground path at the same time. The most
important of which is the cable running from the
negative terminal of the battery to the chassis.
On many new vehicles, the body and chassis
panels are not welded together, but instead glued
using high strength epoxies. These connections
will not pass current - making the chassis of the
car unsuitable for grounding an amplifier. Clarion
strongly recommends running a cable of equal
size to that of the power wire to the negative
terminal of the amplifier. This ground wire must
also be grounded at the rear of the vehicle.
If you run a 4 AWG power cable to an amplifier,
run a 4 AWG ground cable at the same time.
This will allow for significantly increased current
carrying capacity, result in less voltage drop and
allow your amplifiers to produce more power.
Cable size by Power and Distance
RMS Watts 4 Feet
8 Feet
12 feet
16 Feet
20 Feet
100
200
400
600
800
1000
1500
8 AWG
8 AWG
4 AWG
4 AWG
4 AWG
2 AWG
2 AWG
8 AWG
4 AWG
4 AWG
4 AWG
2 AWG
2 AWG
1/0 AWG
4 AWG
4 AWG
4 AWG
4 AWG
2 AWG
2 AWG
1/0 AWG
10 AWG
10 AWG
8 AWG
8 AWG
4 AWG
4 AWG
4 AWG
10 AWG
8 AWG
8 AWG
4 AWG
4 AWG
4 AWG
2 AWG
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
