Always watching out for you l 2012
w w w . s e c u r i t y m a n i n c . c o m
INDEX
Wireless Home Alarm System
1
D.I.Y. Wireless Home Alarm System Kit (Air-AlarmII Series)
4
Quad-Band GSM Dialer (850/900/1800/1900MHz) with LED for Air-Alarm Series (SM-GSMdialer)
5
PIR Motion Sensor with Hidden Color Camera and SD Recorder with Remote Control (PIR-SD)
6
Indoor Motion Detection Alarm with Solar Panel (SolarPIR)
Wireless Cameras
7
Wi-Fi Interference Free Wireless Wall Clock Hidden Camera Kit (ClockCam)
8
Wi-Fi Interference Free Wireless Outdoor/Indoor Bullet Color Camera Kit with Night Vision and Audio (CUcam1)
9
Digital Wireless Mini Indoor Camera Kit with Audio (DigiminiAir)
10
Digital Wireless Outdoor/Indoor Color Camera Kit with Audio and Night Vision (DigioutAir)
11
Cordless Inspection Camera with Wireless Detachable Monitor (ToolCam)
12
Cordless Inspection 9.5mm Camera with Wireless Detachable Monitor (ToolCam II)
13
Outdoor/Indoor Wired Dome Camera with Night Vision (SM-400MC)
Wired Cameras
14
Weatherproof Bullet Color Camera with 100ft Cable (SM-302)
15
Outdoor/Indoor Wired Sony CCD Color Camera with 100ft Cable and Night Vision (SM-3032S)
Digital Video Recorders (DVRs)
16
Wall Clock Color Camera with Micro SD Recorder and Remote Control (ClockCamDVR)
17
Digital Outdoor Wireless Camera System Kit with PIR motion, 2-way Audio, Night Vision & SD Digital Video Recorder (DigiAir-SD)
17
4-Channel Wireless Digital Video Recorder, with 1 or 2 Wireless Camera(s), Night Vision, Audio, and SD Card Recorder
(DigiairWatch Series)
18
4-Channel Digital Wireless Security System – Includes 7” LCD/SD Recorder, 2 or 4 Digital Wireless Cameras with Night Vision
and Audio (DigiLCDDVR Series)
22
Mini Digital Video Recorder (HomeDVR)
23
One Outdoor Wireless Camera System Kit - Audio, Night Vision, and SD DVR (HomeDVR-KT1)
24
One Outdoor Wired Camera System Kit – Audio, Night Vision and SD Recorder (HomeDVR-KT1B)
25
USB Internet Camera and DVR Convertor Box (iCamDVR)
26
1 Wireless Camera System for Video Recording and Remote Monitoring From PC (iCamDVR1W)
Other Security Products and Accessories
27
Dummy Cameras (SM-3802, SM-320S, and SM-3601S)
28
Professional 15” LCD CCTV Monitor with Speaker (SM-1580)
29
Dummy Outdoor/Indoor Speed Dome Camera with LED (SM-2100)
30
Solar Power Outdoor/Indoor Dummy Camera with LED (SM-3803)
31
Remote Control Pan Base for camera (PanBase)
32
2 Surveillance Warning Signs-English/French (Sign2PK-EN/FR)
Air-Alarmll Series
MOTION
DOORBELL
WIRELESS
EASY TO USE
SIREN
D.I.Y. Wireless Home Alarm System Kit
SecurityMan Air-AlarmII series is a wireless LED touchpad security alarm system kit for home and business. It is user-friendly easy
to use protecting home/business at a minimum cost of investment. Do-It-Yourself installation and monitoring alarm system without
monthly fees is a key benefit for users. The system will alert by phone calls to owner through a series of enlisted phone numbers. The
owner can then dial into the host to arm or disarm using the phone’s numeric keypad. Air-AlarmII system can be upgraded by adding
up to 60 wireless sensors, sirens, and up to 10 remote controllers.
Features:
• Easy-to-use and cost-effective D.I.Y. (Do-It-Yourself) wireless intruder alarm system kit
• Supports up to 60 wireless sensors (15 wireless defense zones and 4 wireless sensors per zone)
• Transmit at 430-433MHz frequency band, wireless transmitting distance up to 300 feet (remote controller, smoke sensor,
Wireless home alarm system
doorbell), up to 450 feet (magnetic smart door/window sensor, PIR motion sensor), and up to 210 feet for wireless siren
1
• Supports up to 5 phone numbers for auto alarm call and 1 management center protocol (CID)
• Armed/disarmed by remote controller, phone call, or host’s keypad
• Easy “one-key” armed/disarmed operation
• Programmable silent alarm or audible alarm
• Recordable alarm voice message (up to 10 seconds record time)
• Telephone line disconnection alarm sounds every 5 seconds
• Smart 3 defense lines configuration (1st defense line is the perimeter, 2nd defense line for in-room, & 24-hour defense line)
• Internal rechargeable Li-ion backup battery in alarm host lasts up to 16 hours
• Doorbell rechargeable battery lasts up to 3 years (Air-AlarmII/B)
• Smart beeping and zone LED indication features to alert open status of any door/window sensor when attempting to arm
the system
• When in disarmed mode, the host beeps and zone LED light flashes 5 times to notify the door/window is open,
and 2 times to notify for close
• Alkaline batteries included for remote controllers, wireless door sensor, and wireless motion sensor last up to 2 years
• Programmable password
• Ademco CID compatible protocol
Air-Alarmll Series
Package Contents:
Air-AlarmII & Air-AlarmIIB (Standard Kits)
Air-AlarmIIDL (Deluxe Kit)
• Air-Alarm host with LED touch keypad and speaker
• Air-Alarm host with LED touch keypad and speaker
• 1 x Host Anchor Card for fixed position
• 1 x Host Anchor Card for fixed position
• 1 x 12VDC power adapter
• 1 x 12VDC power adapter
• 1 x Wireless doorbell button
• 2 x Wireless Wide-Angle PIR motion sensor with
• 1 x Wireless Wide-Angle PIR motion sensor with
mounting bracket (battery included)
mounting bracket (batteries included)
• 3 x Wireless magnetic smart door/window sensor
• 1 x Wireless magnetic smart door/window sensor
with mounting bracket (battery included)
with mounting bracket (batteries included)
• 1 x Wireless smoke alarm
• 1 x Wireless indoor siren
• 2 x Wireless remote control (batteries included)
• 2 x Wireless remote control (batteries included)
• 1 x Phone cable (3ft)
• 1 x Phone cable (3ft)
• 1 x USB cable (keep for future add-on Doorbell)
• 1 x USB cable (Air-AlarmIIE: keep for future add-on doorbell)
• 1 x Warning sign
• 1 x Warning sign
• 1 x User’s manual
• 1 x User’s manual
Air-AlarmIIE (Economy Kit)
Same as the Standard Kits package contents above only without:
• 1 x Wireless doorbell button
• 1 x Wireless indoor siren
Specifications:
Alarm Host (SM-8088T)
Wireless Doorbell Button (SM-82)
• Operating power: 9-15VDC
• Operating Power: Internal Rechargeable battery
• Static current: 50mA
• Wireless Transmitting distance: up to 300ft
• Alarm current: 500mA
• Operating environment: Temperature: -10º ~ 50º Humidity: < 80%
(in open area)
• Service life: up to 3 years
• Maximum available quantity of remote controllers: 10 PCS
• Maximum available quantity of wireless sensors: 60 PCS
Wireless Wide-Angle PIR Motion Sensor (SM-80)
• Dimensions: 150 x 107 x 26 (mm)
• Operating power: 9V battery
• Rechargeable battery: 3.7V 800mAh Li-ion
• Wireless Transmitting distance: 450ft (in open area)
• Service life: 2 years
• Speaker Siren 100dB (built-in)
• Detecting area: 100° 33x33ft
Wireless Smart Door/Window Sensor (SM-87L)
Wireless Remote Control (SM-88X)
• Operating power: 23A 12V alkaline battery
• Operating power: 27A 12V alkaline battery
• Wireless Transmitting distance: 450ft (in open area)
• Wireless Transmitting distance: 300ft (in open area)
• Service life: 2 years
• Service life: 2 years
• Alarm Distance: < 4cm
• Alarm host beeps and zone LED light flashes 5 times to notify
Wireless Indoor Siren (SM-103W)
the door/window is open (in disarm mode)
• Alarm host beeps and zone LED light flashes 2 times to notify
the door/window is close (in disarm mode)
• Smart beeping and zone LED indication features to alert the
opening status of any door/window sensor when attempting
to arm the system
• Operating Power: 100 to 240VAC
• Receiving Distance: 210ft (In open area)
• Siren Sound 105dB
Wireless home alarm system
(Standby: 16hrs, charge time: 12hrs)
2
Air-Alarmll Series
Optional add-on items:
Wireless Panic Button (SM-89)
• Operating power 23A 12V
(Alkaline Battery)
• Wireless transmitting distance >450ft
(in open area)
• Service life < 2 years
Wireless Outdoor Siren (SM-103)
• Operating power: 110~240VAC, 50Hz
• Siren Sound 120dB
• Size 202x112x65 (mm)
• Power Consumption ≤ 40mA
• Active Power Consumption ≤ 450mA
• Maximum Alarm Sound with flash: 3 minutes
• Wireless Transmitting Distance > 300ft
(in open area)
• Built-in 6VDC rechargeable backup battery (up to 100 hours)
Wireless Indoor Siren
(SM-103W)
Wireless Magnetic Smart Door/
Window Sensor (SM-87L)
Wireless home alarm system
Wireless Doorbell Button
(SM-82)
3
Wireless Wide-Angle
PIR Motion sensor (SM-80)
Wireless Remote Control
(SM-88X)
Wireless Smoke Sensor(SM-93)
• Operating power 9V Battery
• Wireless Transmitting distance > 300ft
(in open area)
• Service life < 2 years
• Monitoring range: 66ft 2
• Built-in alarm speaker (70dB)
• Function as a standalone smoke alarm
SM-GSMdialer
• Quad-band GSM frequecies, 850/900/1800/
1900MHz (for all GSM cell phones)
• Two Ni-MH 4.8v 600mAh rechargeable back up
batteries (up to 4 hours standby time for any
power outage)
• Four notification LEDs: GSM signal, call pick-up,
low power, and SIM problem.
• GSM wireless antenna with magnetic base and
6.5 ft cable (for accurate positioning)
• Two telephone-out ports (one for alarm host and
one for phone hand-set for regular call usage)
• Require a prepaid & valid SIM card (not included)
to be inserted
• Anchor guidance on the back side for easy
mounting on wall
• Power switch (on/off)
• Dimensions (main unit): 5.5” x 4” x 1”
• Gross/Net weights: 1.5 lbs
SM-GSMdialer
New Product for Nov. 2012
The SM-GSMdialer is simply designed for Air-Alarm (SecurityMan
wireless alarm system) users who do not have a land line and still
want to have alarm calling notification using GSM SIM dialer. This
GSM dialer features Quad-band frequencies, internal rechargeable
batteries, and the ability to connect a regular telephone hand-set
for incoming and outgoing calls over a GSM network. To use the
GSM dialer, simply insert a prepaid or contract GSM SIM card (not
included) into the GSM SIM slot, plug in the power adapter, connect
the dialer to the Air-Alarm host unit and it is ready to go.
Quad-Band GSM Dialer (850/900/1800/1900MHz)
with LED for Air-Alarm Series
Package Contents:
• SM-GSMdialer
• 1 x phone cable (connect to Air-Alarm host)
• Antenna with magnetic base and bracket
• GSM anchor guidance card (for easy mounting)
• 1 x 12V DC power adapter
• User’s manual
Specifications:
• Supports quad-band GSM frequecies, 850/900/1800/1900MHz (for most GSM SIM card)
• Two Ni-MH 4.8v 600mAh rechargeable back up batteries (up to 4 hours standby time for power outage)
• Four notification LED lights: GSM Signal, Call Pick Up, Low Power, and SIM Problem.
• GSM wireless antenna with magnetic base and 9.5 ft cable (for accurate positioning)
• Requires a prepaid or a valid SIM card (not included) to be inserted
• Cable management slots and GSM anchor guidance card for easy wall mount
• Backup battery power ON/OFF switch
• Dimensions (main unit): 5.5” x 4” x 1”
• Gross weight: 1.5 lbs (in package)
Air-Alarm Back Panel
SM-GSMdialer Back Panel
Cable Management Slots
Mounting Holes
SIM Card Slot
SIM
TEL OUT
Backup Battery ON/OFF
Power
TEL OUT
TEL OUT
TEL IN
TEL IN
TEL OUT
Wireless home alarm system
• Two telephone-out ports (one for alarm host and one for phone hand-set for regular call usage)
4
PIR-SD
New Product for Oct. 2012
Camera
MOTION
RECORD TO SD
REMOTE
DO IT YOURSELF
COLOR
WIRELESS
SD slot
PIR Motion Sensor with Hidden Color Camera
and SD Recorder with Remote Control
The PIR-SD is a color camera w/SD recorder (SD card not included) hidden inside a motion detector. This covert motion detector
camera blends perfectly into almost any home or business environment where an alarm system might be present and can also be
integrated with any of our SecurityMan DIY Wireless Home Alarm Systems, providing you with both security and discreet monitoring
capabilities. So whether you’re looking to expand your SecurityMan wireless security system or just looking for a covert hidden
camera, the PIR-SD will fit your needs.
Features:
Package Contents:
• PIR motion sensor with color camera and SD recorder (SD card not included)
• Integrates with any SecurityMan DIY Wireless Alarm Systems (Air-Alarm series)
• Up to 300ft (clear line of sight) wireless transmitting distance between the PIR-SD
and alarm host (100ft indoors)
• 1 minute video clip per motion detection event
• Records up to 12 hours of video footage on a 32GB SD card
• Memory full notifi cation
• Audible and visual new fi le alert notifi cation
• Can easily be armed/disarmed via remote control, alarm host keypad, or phone call
(when integrated with a SecurityMan Air-Alarm system)
• One touch (remote control) manual record for emergency situations
• Easy PC playback using a PC card reader or direct connect via mini USB port
• 1 x PIR-SD with mounting bracket
(SD card not included)
• 1 x USB cable (power and PC data transfer)
• 2 x Security signs (warning stickers)
• 1 x Remote control
• 1 x USB power adapter
• 1 x User’s manual
Wireless home alarm system
Key Specifications:
5
Image Sensor
Resolution
Recording Speed
Camera Lens
Camera Viewing Angle
Recording Video Format
Recording Time and size
LED Indicator
PIR sensor/camera
Remote Controller
Wireless (General)
USB Port
Video Storage (SD slot)
PIR Detecting Area
Pet Immunity
Power Consumption
Power Supply
Dimensions (LxWxH)
Gross Weight
Operating Power
Remote Control Distance
Battery Life Time
Buttons
Frequency
Transmission Distance
Operating Temperature
Operating Humidity
1/6.5” CMOS color
640x480
30 fps
8mm
H:60 degree, V:35 degree
AVI
One minute per motion detection event. 40MB/minute
2 LED lights (Red: power, record and alarm/
Blue: SD full or new REC file)
2.0 (data transfer to PC or USB power adapter)
SD card (up to 32GB, SD Class 4 or higher, SD not included)
110 degree; 26ft (8M)
22 lbs (10 Kgs) or less
≤ 60mA (standby mode); 110mA (active mode)
110~240VAC, 5VDC 1.0A (USB)
4.3” x 2.4” x 1.7”
0.5 lbs
27A 12V battery (alkaline)
Up to 300ft (in open area); Up to 100ft (indoors)
Up to 2 years
Arm, Disarm, and Emergency
433MHz
Up to 300ft (in open area); Up to 100ft (indoors)
-10°C~50°C/14ºF~122ºF
≤ 85% RH
SolarPIR
TM
SIREN
MOTION DETECTION
SOLAR
RECYCLE
GREEN ENERGY
Indoor Motion Detection Alarm with Solar Panel
Go green with SecurityMan affordable SolarPIRTM, an alarm driven by motion detection device. Use SolarPIRTM to help protect your
home and business featuring energy saving designed solar panel with backup batteries (3xAA not included). In the armed mode, the
alarm will sound for 30 seconds if it is triggered by the built-in PIR motion sensor. Simple designed to be easily mounted to walls in
seconds or simply stand on desktops. The technology of solar panel used to recycle indoor lighting (100+ Lux) as a source of power
to conserve and extend the battery life where general AA batteries alone can last up to three years.
Features:
Package Contents:
• D.I.Y. (do-it-yourself) installation in seconds for wall mount or desktop
• SolarPIR™
• PIR motion detection coverage: up to 8m (26 ft)/40° horizontal; 6m (20ft)/75° horizontal
• User’s Manual
• Pet immunity weight: 5 Kg (11 lbs) to reduce false alarm
• Screws
• Ultra alarm sound 130dB for average home coverage
• Delay time to exit is 30 seconds and 5 seconds entry delay
• Programmable 4 digits security code via front four keys
• Battery low light indicator
• Low power consumption design with stand by current 20 μA
• Minimum lighting level for solar panel: 100 Lux
• Dimensions: 70 (W) x 116 (H) x 33mm (D) (2.75” x 45.67” x 1.30”)
Wireless home alarm system
• Energy efficient with solar panel and backup batteries (3xAA, not included)
6
ClockCam
WIRELESS
RANGE
COLOR
DO IT YOURSELF
UP TO 150FT
Camera
Wi-Fi Interference Free Wireless Wall Clock Hidden Camera Kit
The ClockCam is designed for users who want to discreetly monitor their visitors, strangers, babysitters, and business activities.
It includes a wireless receiver and a wireless camera hidden in a functional wall clock. It can be installed in seconds, hassle free of
running long video cable. Simply mount the clock at a desired location, connect the power of the clock-camera, to receiver, and then
connect the receiver to a monitor for live view, or connect to a recorder for recording. It is a perfect security product for homes and
small businesses.
Features:
• Do-it-yourself, easy to setup and use
Package Contents: (G.W. 3.2lbs)
• Hidden wireless color camera built-in functional wall-clock
• 1 x Wall Clock Camera (ClockCam-T)
• No interference from crowded 2.4GHz & 5.8GHz frequencies including
• 1 x Receiver W/ Antenna (ClockCam-R)
• 1 x AV Cable (for receiver)
Wi-Fi (wireless network) device
• Video transmission goes up to 330ft clear line of sight or 100ft indoor
• 2 x Warning Stickers
• Add more wireless receivers (one channel, 900MHz) for multi rooms
• 2 x Power Adapters
• 1 x User Manual
monitoring (no multi cameras)
Applications:
• Discreetly monitor with fully functional design
• Monitor childcare, know your children are safe for peace of mind
• Monitor your valuables, home, business, office
Wireless Cameras
Specifications:
7
Wall-Clock Camera (ClockCam-T)
Image Sensor
1/4 Inch CMOS, Color
Effective Pixels
510(H) x 492 (V)
Signal System
NTSC
Viewing Angle
Vertical 35 Degree/Horizontal 46 Degree
Transmission Frequency
FM, 900MHz (one channel, 906MHz)
Clock type
Quartz Wall-Clock (Durable plastic glass)
Dimensions/Shaft Length 14.3 (W) x 1.75 (D) / 12mm
Clock: 1.5VDC(AA Battery, not included)
Power
Camera: AC 100~240V 6DVC 800mA
Operating Temperature
-10 ~ +50(Degree C) / +14 ~ +122(DegreeF)
Receiver (ClockCam-R)
Audio/Video Output
Antenna Type
Wireless Receiving Frequency
Dimensions(WxDxH)
Operating Temperature
Power
1 RCA/ 1RCA
SMA (87dBm sensitivity)
ISM, 900MHz (one channel, 906MHz)
4 x3 x1
-10 ~ +50 (Degree C)
+14 ~ +122 (Degree F)
AC 100~240V 6VDC 800mA
CUcam1
AUDIO
NIGHT VISION
COLOR
WIRELESS
RANGE
DO IT YOURSELF
WEATHER
RESISTANT
UP TO 330FT
Wi-Fi Interference Free Wireless Outdoor/Indoor Bullet
Color Camera Kit with Night Vision and Audio
Features:
Package Contents:
•
•
•
•
•
•
•
•
•
• 1 x 900 MHz wireless outdoor/indoor color
camera (SM-302TX) and wall-mount bracket
• 1 x 900 MHz wireless receiver (SM-302RX)
and antenna
• 2 x 8VDC Power Adapters
• 1 x AV cable
• 1 x manual
• Plectrum & Dry Wall Screws
Do-it-yourself(D.I.Y.), easy to setup and use
Perfect for monitoring around your home or business
Wireless video direct to your TV or recorder
High quality picture and sound transmitting and receiving
No interference from crowded 2.4GHz devices
Built-in IR LEDs for night vision (up to 23ft, B/W)
Stronger wall penetration than 2.4GHz/5.8GHz wireless transmission
Video transmission goes up to 330ft clear line of sight or 100ft indoor
Weatherproof camera design for outdoor usage
SM-302TX Camera
SM-302RX Receiver
Image Sensor
Total Pixels
Video Format
Minimum Illumination
Night Vision Range
Lens
Transmission Frequency
Modulation Type
S/N
Transmission Power
Audio Frequency Band
Microphone
Voice Monitoring Distance
Power Consumption
Antenna
Transmission Distance
Power
Transmission Frequency
Channel Indication
Frequency Stability
Local Oscillator Leakage
Receiving Sensitivity
Differential Phase
S/N
Video Output Impedance/Video Output Voltage
Audio Carrier
Audio Frequency Band
Audio Output Impedance/Audio Output Voltage
Audio S/N
Antenna Type
RF Input Impedance
Power Consumption
Power
Power Switch
1/4_CMOS
510(H)_492(V)
NTSC
0 lux (IR on)
Up to 23ft
Internal, f=3.6mm fish eye lens
900MHz
FM
40dB(AGCOff)
2~30mW
4.5MHz
Built-in
up to 20ft
200mA(IR ON)/80mA(IR OFF)
SMA
up to 330ft
8V 300mA(Positive inside) IP54
900MHz
1 Green LED
±100KHz
≤-55dBm
≤-85dBm
10Deg.
38dB
75ohm/1.0±0.2Vp-p (Standard value:1Vp-p)
4.5MHz
100_20KHz
10Kohm/1.2±0.4Vp-p (Standard value:1Vp-p)
50dB
SMA
50ohm
180mA(MAX.)
8V 300mA(Positive inside)
Touch Button
Wireless Cameras
Specification:
8
DigiminiAir
DO IT YOURSELF
COLOR
DIGITAL
WIRELESS
AUDIO
Digital Wireless Mini Indoor Camera Kit with Audio
Go digital with your wireless security needs; the simplest way to secure your home and business. DigiminiAir is a do-it-yourself
mini size digital wireless security camera kit; designed for easy to operate and easy to install. In comparison to the traditional
analog wireless technology running on 900MHz, 2.4GHz, and 5.8GHz, the 2.4GHz digital wireless technology provides three
key advantages; stronger signal strength which provides longer transmission distance (indoor/clear-line-of-site: 200ft/350ft
v.s.100ft/300ft), digital signal which is interference free from crowded wireless analog devices (Wi-Fi routers, Bluetooth devices,
cordless/cell phones, and other digital wireless band), and privacy which is worry free of signal interceptions from neighborhood.
Package Contents:
• 1 x Digital wireless mini indoor camera with antenna and mounting bracket
• 1 x Digital wireless receiver with antenna and docking stand
• 2 x Power adapters (for camera and receiver)
• 1 x AV cable
• User’s manual and screws
Features:
•
•
•
•
•
•
•
•
•
•
Do-it-yourself (D.I.Y) easy to setup and use digital wireless camera kit
Mini size camera design
Wireless transmission up to 200ft between walls and up to 350ft in clear line of sight
No Wi-Fi interference; no interference from crowded analog 900MHz/2.4GHz/5.8GHz/6.0GHz devices
Built-in microphone for audible recording up to 20ft away
AV output RCA interface from receiver to monitor for live display or to a recorder
Digital wireless pairing between camera and receiver, worry free of signal interception by neighbors
Supports up to 4 sets of digital wireless camera/receiver (CH1~CH4) to a location
One receiver supports up to four digital wireless cameras (switching one camera at a time)
Video signal loss alert notification
Key Specifications:
Wireless Cameras
SM-211DT (Camera)
9
SM-451DR (Receiver)
Wireless
Image Sensor
1/4” CMOS Color
Resolution
510 x 492 pixels (NTSC)
Viewing Angle
60 degree
Audio
Microphone built-in (audio monitoring up to 20ft)
Minimum Illumination
3 Lux/F1.2
Pairing Button
1
Power Supply
DC 5V / 1.5A
Dimensions (LxWxH)
1.45” x 1.45” x 0.8”
Pairing Button
1
Channel Button
1 CH button (Manually Select CH1~CH4)
AV Output
1 x Video out (RCA); 1 x Audio out (RCA)
Power Supply
DC 5V / 1.5A
Dimensions
4.2” x 2.7” x 0.9”
Stand
1 x docking stand
Frequency
ISM 2400 – 2480 MHz (CH1/CH2/CH3/CH4)
Transmission power
17 dBm
Receiver Sensitivity
≤ -85dBm
Modulation
GFSK
Antenna
Omni 3dBi
Transmission Distance
Up to 350 ft clear line of sight; up to 200ft (indoor)
Operating Temperature
-20°C ~ 60°C/-4°F ~ 140°F
Operating Humidity
20% -80% RH
DigioutAir
DO IT YOURSELF
DIGITAL
WIRELESS
WEATHER
RESISTANT
COLOR
NIGHT VISION
AUDIO
Digital Wireless Outdoor/Indoor Color Camera Kit with
Audio and Night Vision
Go digital with your wireless security needs; the simplest way to secure your home and business. DigioutAir is a do-it-yourself
digital security camera kit designed for easy installation and operation. In comparison to the traditional analog wireless
technology running on 900MHz, 2.4GHz, and 5.8GHz, the 2.4GHz digital wireless technology provides three key advantages;
stronger signal strength which provides longer transmission distance (indoor/clear-line-of-site: 200ft/490ft v.s.100ft/300ft),
digital signal which is interference free from crowded wireless analog devices (Wi-Fi routers, Bluetooth devices, cordless/cell
phones, and other digital wireless band), and privacy which is worry free of signal interceptions from neighborhood.
Package Contents:
• 1 x Digital wireless outdoor/indoor camera with antenna and sun visor
• 1 x Digital wireless receiver with antenna and docking stand
• 2 x Power adapter (for camera and receiver)
• 1 x AV cable
• 1 x Camera mounting bracket
• User’s manual and screws
Features:
•
•
•
•
•
•
•
•
•
•
•
Do-it-yourself (D.I.Y) easy to setup and use digital wireless camera kit
Weatherproof camera housing for outdoor and indoor applications
Wireless transmission up to 200ft between walls and up to 490ft in clear line of site
No Wi-Fi interference; no interference from crowded analog 900MHz/2.4GHz/5.8GHz/6.0GHz devices
Camera with built-in infrared LEDs for night vision up to 50ft (B/W)
Built-in microphone for audible recording up to 20ft away
AV output RCA interface from receiver to monitor for live display or to a recorder
Digital wireless pairing camera and receiver, worry-free of signal interception
Supports up to 4 sets of digital wireless camera/receiver (CH1~CH4) to a location
One receiver supports up to four digital wireless cameras (switching one camera at a time)
Video signal loss alert notification
SM-703DT (Camera)
SM-451DR (Receiver)
Wireless
Image Sensor
Resolution
Viewing Angle
Weatherproof Rating
Night Vision Range
Audio
Minimum Illumination
Pairing Button
IR LEDs
Power Supply
Dimensions (LxWxH)
Pairing Button
Channel Button
AV Output
Power Supply
Dimensions
Stand
Frequency
Transmission power
Receiver Sensitivity
Modulation
Antenna
Transmission Distance
Operating Temperature
Operating Humidity
1/4” CMOS Color
510 x 492 pixels (NTSC)
35 degree
IP65
Up to 50ft / 15m (B/W)
Microphone built-in (audio monitoring up to 20ft)
3 Lux/F1.2 (IR off); 0 Lux (IR on)
1
24 LEDs
DC 5V / 1.5A
3.5” x 2.4” x 2.4”
1
1 CH button (Select CH1~CH4)
1 x Video out (RCA); 1 x Audio out (RCA)
DC 5V / 800mA
4.2” x 2.7” x 0.9”
1 x docking stand
ISM 2400 – 2480 MHz (CH1/CH2/CH3/CH4)
17 dBm
≤ -85dBm
GFSK
Omni 3dBi
Up to 490 ft (150m) clear line of site; up to 150ft (indoor)
-20°C ~ 60°C/-4°F ~ 140°F
20% -80% RH
Wireless Cameras
Key Specifications:
10
ToolCam
Waterproof
3ft
10m
COLOR
DO IT YOURSELF
NIGHT VISION
SUBMERGIBLE
3FT
WIRELESS
RANGE
UP TO 150FT
Cordless Inspection Camera with Wireless Detachable Monitor
Features:
•Cost-effective visual aid for hard-to-reach areas
•Allows inspecting, examining, or finding things via camera and attachments
•Waterproof (IP67) 2.4GHz mini wireless color camera with 2 LEDs and semi-flexible 3’ cable
•Detachable and comfort handgrip with adjustable LED tuner and detachable 2.4” LCD color monitor
•Camera LED night vision up to 2ft
•2.4GHz wireless receiver built-in LCD monitor for portability (up to 150 ft clear line of sight)
•Rechargeable Li-battery built-in the monitor last up to 5 hours
•One video input for optional wired camera and one video output for larger monitor display
•Camera uses 4 AA batteries (not included), good up to 3 hrs of continuous run-time
•Ideal for homeowners, mechanics, contractors, electricians, and security guards
Package Contents:
•1
•1
•1
•1
•1
•1
x
x
x
x
x
x
2.4” TFT-LCD color monitor with built-in rechargeable battery
Handgrip gun
Waterproof camera with LEDs and 3ft flexible cable
Mirror, Hook, Magnet tip attachments
8VDC power adapter and adapter cable (for monitor)
User manual
Camera Specifications:
Image Sensor Total Pixels Signal System Horizontal View Angle Transmission Frequency Minimum Illumination Modulation Type Bandwidth Power Supply Handgrip Dimensions Camera Head Diameter CMOS, Color
712 (H) x 485 (V)
NTSC
50 Degree
2468 MHz
0 Lux (WITH LED ON)
FM
25 MHz
4 x AA (Not Included)
186 (W) x 145 (D) x 41 (H) (mm)
17 mm
Wireless Cameras
Monitor Specifications:
11
LCD Screen Type Effective Pixels Video System Wireless Receiving Frequency Exterior Power Supply Voltage Consumption Current Video Output Level Dimensions(WxDxH) Operating Temperature Operating Humidity
Weight (Whole Kit) 2.4” TFT-LCD
480 x 240
NTSC
2468 MHz
8VDC
450mA (Max.)
0.9 - 1.3V @ 75 ohm
100 x 70 x 30 (mm)
-10°C ~ 50°C /14°F ~ 12 2 °F
15 ~ 85%RH
2.30 lbs
ToolCam II
Waterproof
3ft
10m
COLOR
DO IT YOURSELF
NIGHT VISION
SUBMERGIBLE
3FT
WIRELESS
RANGE
UP TO 150FT
Cordless Inspection 9.5mm Camera with Wireless
Detachable Monitor
Features:
•Cost-effective visual aid for hard-to-reach areas
•Allows inspecting, examining, or finding things via 9.5mm camera and attachments
•Waterproof (IP67) 2.4GHz mini wireless color camera with 2 LEDs and semi-flexible 3’ cable
•Detachable and comfort handgrip with adjustable LED tuner and detachable 2.4” LCD color monitor
•Camera LED night vision up to 2ft
•2.4GHz wireless receiver built-in LCD monitor for portability (up to 150 ft clear line of sight)
•Rechargeable Li-battery built-in the monitor last up to 5 hours
•One video input for optional wired camera and one video output for larger monitor display
•Camera uses 4 AA batteries (not included), good up to 3 hrs of continuous run-time
•Ideal for homeowners, mechanics, contractors, electricians, and security guards
Package Contents:
•1
•1
•1
•1
•1
•1
x
x
x
x
x
x
2.4” TFT-LCD color monitor with built-in rechargeable battery
Handgrip gun
Waterproof 9.5mm camera with LEDs and 3ft flexible cable
Mirror, Hook, Magnet tip attachments
8VDC power adapter and adapter cable (for monitor)
User manual
Camera Specifications:
Image Sensor Total Pixels Signal System Horizontal View Angle Transmission Frequency Minimum Illumination Modulation Type Bandwidth Power Supply Handgrip Dimensions Camera Head Diameter CMOS, Color
712 (H) x 485 (V)
NTSC
50 Degree
2468 MHz
0 Lux (WITH LED ON)
FM
25 MHz
4 x AA (Not Included)
186 (W) x 145 (D) x 41 (H) (mm)
9.5 mm
LCD Screen Type Effective Pixels Video System Wireless Receiving Frequency Exterior Power Supply Voltage Consumption Current Video Output Level Dimensions(WxDxH) Operating Temperature Operating Humidity
Weight (Whole Kit) 2.4” TFT-LCD
480 x 240
NTSC
2468 MHz
8VDC
450mA (Max.)
0.9 - 1.3V @ 75 ohm
100 x 70 x 30 (mm)
-10°C ~ 50°C /14°F ~ 122°F
15 ~ 85%RH
2.30 lbs
Wireless Cameras
Monitor Specifications:
12
SM-400MC
New Product for Oct./Nov. 2012
DO IT YOURSELF
WEATHER
RESISTANT
COLOR
NIGHT VISION
Outdoor/Indoor Wired Dome Camera with Night Vision
The SecurityMan SM-400MC is a professionally designed security camera to help deter unwanted intruders and activities. Its
robust stylistic design along with 35ft of night vision makes the SM-400MC ideal for both indoor and outdoor applications
providing your home or business with the ultimate protection. Best of all, its design makes the SM-400MC a perfect companion
to our SecurityMan SM-2100 dummy dome camera to help increase security presence anywhere with just a fraction of the cost.
Features:
• Robust, weather-proof color camera, good for both outdoor and indoor
• Do-it-yourself (D.I.Y) easy to setup wired camera kit
• Conveys strong security presence due to its stylistic dome design
• Night vision up to 35ft
• Ceiling or wall mountable
• Adjustable camera body
Package Includes:
• 1 x Dome color CMOS camera with wall/ceiling mount base
• 1 x AC adapter (DC 12V/1.0A)
• 1 x 100ft BNC VP (video/power) cable
• 2 x Warning stickers
• 3 x Dry wall screws
• User’s manual
Wireless Cameras
Specifications:
13
Image sensor
1/4” CMOS Color
Min. illumination
0 .5lux IR off, 0lux IR on
Horizontal resolution
400 Horizontal TV lines
Video output
1.0Vp-p/75 Ω (composite)
Effective pixels
640(H)*480(V) NTSC
Microphone
No
Weather-proof
IP45
Signal/Noise ratio
>48dB
Backlight compensation
Yes
Operating temperature
-10º C ~ 50º C /14ºF ~ 122ºF
Focal length
6mm
Operating humidity
98%, RH≤95
Viewing angle
35 Degree
Power Consumption
DC 12V/ 300mA
Number of IR LEDs
14 LEDs
Dimensions (LxWxH)
9”x6”x6”
IR range
Up to 35ft
Weight (G.W)
4.6lb
SM-302
AUDIO
NIGHT VISION
COLOR
DO IT YOURSELF
WEATHER
RESISTANT
Weatherproof Bullet Color Camera with 100ft Cable
Features:
• D.I.Y. (Do-it-yourself) pack - crystal clear color camera and mounting bracket
• Built-in IR LEDs for night vision (up to 23ft, B/W)
• Built-in microphone for audio monitoring
• Weatherproof camera; applications for outdoor and indoor, wall-mount or ceiling mount
• Compact bullet type camera design
• Ideal for homes and small businesses surveillance
Package Contents:
• 1 x SM-302 camera with bracket
• 1 x 100ft AVP cable (Avoid using other AVP cable for best picture quality)
• 1 x Power adapter
• 1 x Manual
Image Sensor
1/4” Color CMOS
Video Resolution
510x492 (NTSC)
Horizontal Resolution
420 TV Lines
Audio
Microphone built-in
Lens
3.6mm
Waterproof
IP54
Viewing Angle
45°
Connector Interface
Audio/Video(RCA)
Power Consumption
200mA(IR ON)/80mA(IR OFF)
Operating Temperature
-10°C to 50°C /14°F~122°F
Operating Humidity
85%RH
Dimensions (WxDXH)
2.4”x1.4”x1.4” (camera body)
Weight (Gross)
1.5 lbs
Wired Cameras
Specifications:
14
SM-3032S
COLOR
NIGHT VISION
1/3” CCD
DO IT YOURSELF
WEATHER
RESISTANT
Outdoor/Indoor Wired Sony CCD Color Camera with 100ft
Cable and Night Vision
Features:
•
•
•
•
Crystal clear 420TVL, 1/3” Weatherproof Sony CCD color camera
Streamline weatherproof (IP65) camera body
Built-in 30 IR LED for night vision (B/W) up to 100ft
Convenient all-in-one D.I.Y. (do-it-yourself) kit which includes camera with lens, bracket, cable, and power adapter.
Package Contents:
•
•
•
•
Weatherproof color camera with mounting bracket (metal)
100ft VP (video/power) cable
12VDC power adapter (UL)
Mounting Accessories
Wired Cameras
Specification:
15
Image Pick-up Device
SONY II Super HAD 1/3 Color CCD
Effective Picture Elements
NTSC: 512(H) x 492(V)
Horizontal Resolution
420 horizontal TV lines
Minimum Illumination
0 Lux with IR on (night time)
S/N Ratio
> 48 dB
Auto Electronic Shutter
NTSC:1/50s~1/100,000s, PAL:1/60s~1/110,000s
Back Light Compensation
Auto
Gain Control
Auto
White Balance
Auto
Gamma Correction
R>0.45
Lens Furnished
3.6mm
Electronic Shutter
1/60, 1/100000sec
Viewing Angle
75 /55 (horizontal/vertical)
Synchronous System
Internal
Video Output
1 Vp-p Composite Video / 75 Ohms.
Weatherproof
IP65
Power Supply
12V DC / 1.0A (AC 110v~220v), UL
Operating Temp.
-10°C~50°C /+14°F~122 °F
IR LED
30pcs of Φ5 IR LED
IR Night Vision Range
100ft (30m) max
Camera Dimensions
6 x 3.75 x 2 (not include bracket)
Camera Weight (Net)
1.14 lbs (camera only, no adapter, cable, and package)
ClockCamDVR
IR hole for the remote control
Camera
DO IT YOURSELF
COLOR
CAMERA
MICRO SD
MEDIA BACKUP
REMOTE
Wall Clock Color Camera with Micro SD Recorder
and Remote Control
Features:
Package Contents:
• Do-it-yourself, easy to setup and use
• 1 x Wall Clock Camera
• Hidden wireless color camera built-in functional wall-clock
• 1 x Remote Controller
• Crystal clear video quality recording with VGA, D1or HD in AVI format
• 2 x Warning Stickers
• Motion and pre-alarm (3 sec.) recording
• 1 x Power Adapters
• Record to micro SD card (not included, up to 32GB/36hrs)
• 1 x Video-out Cable
• Overwrite function when SD is full
• 1 x USB cables
• Date/Time stamp video recording
• 1 x Manual
• Easy playback or download on a PC via micro SD or direct PC connection through USB
**Micro SD not included
Applications:
• Discreetly monitor with fully functional design
• Monitor childcare, know your children are safe for peace of mind
• Monitor your valuables, home, business, office
Specifications:
Home
Store
Office
Image Sensor
1/4-inch CMOS, color
Recording Format
AVI (video), JPEG (Picture)
Effective Pixels
1280x720(NTSC)
Recording Resolution
HD (1280x720)/D1 (800x592)/VGA (640x480)
Viewing Angle
Vertical 35°; Horizontal 45°
Recording Speed (data size)
30fps , approx 35MB/min (Default HD quality)
Recording Mode
Motion detection;
Pre-Alarm Recording Time
3 seconds
Manual by Remote Controller
PC Connection Interface
USB (for backup/download)
Outputs
1 x AV output
Memory
Micro SD (up to 32GB, not included)
Clock Type
Quartz wall-clock (durable plastic glass)
Operation
Remote Controller (up to 10 m indoor)
Dimensions/Shaft Length
14.3” (Ø) x 1.75” (D)/ 12mm
Operating Humidity
20% -80% RH
Operating Temperature
-10°C to 50°C (14°F~122°F)
Power
Camera: AC 100~240V 6VDC 800mA
Power
Clock: 1.5VDC (AA battery, not included)
Digital Video Recorders (DVRs)
The ClockCamDVR is designed for users who want to discreetly monitor their visitors, strangers, and business activities.
It includes a hidden camera in a functional wall clock and record to micro SD– an economical total solution. It can be installed in
seconds, hassle free of running long video cable. Simply mount the clock at a desired location, connect the power of the clock-camera,
and ready to record. It is a perfect security product for homes and small business.
16
DigiAir-SD
WIRELESS
RANGE
DO IT YOURSELF
COLOR
UP TO 100FT
VOICE
CONFERENCE
RECORD TO SD
NIGHT VISION
Digital Outdoor Wireless Camera System Kit with PIR motion,
2-way Audio, Night Vision and SD Digital Video Recorder
Features:
•
•
•
•
•
•
•
•
•
•
•
•
•
Do-it-yourself (D.I.Y), easy to setup and use security system
Weatherproof camera with PIR motion sensor
2-way audio communication between camera and receiver
Wireless transmission up to 130ft with walls in between
No Wi-Fi interference and interference from crowded analog 900MHz/2.4GHz/5.8GHz/6.0GHz devices
Digital signal, worry free of interception by neighbor with wireless device(s)
Future upgradable by adding 3 more digital wireless cameras (only one active channel for recording) or integrate up to 3 more
DigiAir-SD kits (ch2/ch3/ch4)
Camera built-in infrared LEDs for night vision up to 50ft (B/W)
Schedule, manual, or motion detection recording
Records video clips or photos to SD card (up to 32GB) with time stamp
Approximately 62 hours of video or 1.157 million photos for a 32GB (not included) of storage
Overwrites when SD is full
Toggle between quad live view display, single full, or sequential single full screen display
Digital Video Recorders (DVRs)
Package Contents:
17
• 1 x Digital wireless outdoor/indoor Camera (SM-60DT) with antenna
• 1 x Digital wireless receiver/recorder (SM-60DR) with antenna
• 2 x Power adapter (for camera and receiver)
• 1 x AV cable
• 1 x Camera mounting bracket
• 3 screws and user’s manual
SM-60DT (Camera)
SM-60DR (Receiver/Recorder)
1/4” CMOS Color
640 x 480 pixels
60 degree
IP33
Up to 50ft / 15m (B/W)
Microphone built-in (audio monitoring up to 20ft)
Built-in (92 ±3 db)
Detection up to 20 ft
Detection angles: 45 degree (horizontal) 35 degree (vertical)
Power Supply/Consumption AC100v-240v DC 12V 500mA/270 mA (Max)
4.33” x 2.95” x 3.23”
Dimensions
Video Resolution
Video Mode
Recording Frame Rate
Recording Modes
Storage
AV Output
Power Supply/Consumption
Dimensions
Image Sensor
Resolution
View Angle
Weatherproof Rating
Night Vision Range
Audio
Speaker
PIR Motion Sensor
Wireless
Frequency
Receiver Sensitivity
Modulation
Antenna
Transmission Distance
Operating Temperature
Operating Humidity
ISM 2400 – 2483.5 MHz (CH1/CH2/CH3/CH4/Loop)
-81 dBm (Typical)
GFSK
Omni 3dBi
Up to 330 ft (100m) clear line of sight; up to 130ft (indoor)
-10°C to 60°C (14°F~140°F)
20% -80% RH
640x480(VGA), 320x240(QVGA)
M-JPEG AVI (video) / JPEG (photo)
11 (VGA) – 30 fps (QVGA) (for NTSC)
Schedule, Manual, or Motion Detection
SD card (up to 32GB, not included)
One (connect to monitor/speaker)
AC100v-240v DC 12V 500mA / 160mA Max.
4.72” x 3.3” x 0.9”
DigiairWatch Series
New Product for Nov. 2012
DigiairWatch
DO IT YOURSELF
DIGITAL
WIRELESS
MOTION
DETECTION
WEATHER
RESISTANT
DigiairWatch2
RECORD TO SD
COLOR
AUDIO
NIGHT VISION
4-Channel Wireless Digital Video Recorder, with One or Two
Wireless Camera(s), Night Vision, Audio, and SD Card Recorder
Go digital with your wireless security needs; the simplest and secure way to protect your home and business. The DigiairWatch and
DigiairWatch2 are D.I.Y. (do-it-yourself) economy digital wireless security systems. Our DigiairWatch Series includes One (DigiairWatch) or
Two (DigiairWatch2) weatherproof digital wireless camera(s) and a wireless receiver/recorder that records to a SD card. Compared to full
version digital video recording (DVR) systems, the DigiairWatch series are much less complicated to operate, much more affordable and can
be installed in minutes. Simply insert a SD card into the receiver, position and mount the camera(s), plug all the power adapters into an electrical
power outlet and you are ready to record. In comparison to the traditional wireless technology (analog), digital wireless provides three key
features which include: Increased range of transmission, secure signal and unlike analog, the digital signals are virtually interference-free from
crowded wireless analog devices such as: Wi-Fi routers, Bluetooth devices, cordless phones, microwaves and cell phones.
DigiairWatch
DigiairWatch2
• 1 x Digital wireless camera with antenna and bracket
• 2 x Digital wireless cameras with antenna and bracket
• 1 x Digital wireless receiver with antenna and SD slot
• 1 x Digital wireless receiver with antenna and SD slot
• 2 x Power adapters (for camera and receiver)
• 3 x Power adapters (for cameras and receiver)
• 1 x AV output cable (for receiver)
• 1 x AV output cable (for receiver)
• 1 x User’s manual
• 1 x User’s manual
*SD memory card not included
*SD memory card not included
Features:
• Do-it-yourself (D.I.Y) easy to use and simple installation
• Includes one/two digital wireless camera(s) and a wireless receiver with SD slot
• Integrated digital video recorder, SD memory card not included
• 2.4GHz digital wireless recording system. No video cables required
• Weatherproof (IP54) CMOS color camera for outdoor and indoor applications
• Increased range of transmission up to 200ft between walls and up to 490ft clear line of sight
• No Wi-Fi interference; no interference from crowded analog 900MHz/2.4GHz/5.8GHz/6.0GHz devices
• Secure signal: neighbors cannot pick up the signal or listen in
• Camera with built-in infrared LEDs for night vision up to 30ft (B/W)
• Built-in microphone for audible recording up to 30ft away
• Motion detection and manual recording with optional video or picture selection
Digital Video Recorders (DVRs)
Package Contents:
18
• Auto overwrite function when SD card is full
• Records 15-second video clip per motion detection in MP4 format and list file names by date, time, and CH number
• With a 32GB SD, DigiairWatch records up to 65 hours in single full screen or 260 hours in Quad mode
• With a 32GB SD, DigiairWatch2 records up to 65 hours in single full screen of an active camera or
130 hours for both active cameras in Quad mode
• Audio and video output RCA interfaces from receiver to monitor for display
• Upgradable by adding up to 4 total digital wireless cameras
• Records 1 channel or all 4 channels at the same time (in Quad mode)
• Single channel full screen, auto sequential rotation or Quad view display
• Playback directly from the receiver or PC via SD card reader with any MP4 player software
• Infrared filtered camera for best vibrant color picture
Key Specifications:
SM-816DT (camera)
Image Sensor
CMOS Color
Resolution
640 x 480 pixels (NTSC/PAL selectable)
Viewing Angle
45 degree
Audio
Microphone built-in (audio monitoring up to 30ft)
Minimum Illumination
2 Lux (IR off); 0 Lux (IR on)
IR LED Night Vision Range
Up to 30ft (B/W)
Weatherproof Rating
IP54
Antenna
1 x Angle adjustable antenna
Consumption Current
500mA
Mounting Bracket
Angle adjustable
Power LED Indicator
1
Power Supply
DC 5V/1.0A
Dimensions (LxWxH)
6.0” x 2.3” x 1.8” (camera body only)
Pairing Button
1
Display Modes
Single (auto switchable for multi cameras) or Quad (no audio)
CH Switch Intervals
Selectable from Never/5/10/15/20 seconds (for single mode)
Frame Rate
30fps in single mode or 15fps/camera in Quad mode
Recording Resolutions
512x384 for single mode
320x240 for Quad mode
Recording Modes
Motion detection/Manual
Recording Format
MPEG4 (video)
JPEG (photo)
Motion Detect Video Clip/Size
15 seconds per clip; 2MB/clip in single; 500K/clip in quad
Digital Video Recorders (DVRs)
mode for an active camera
19
SM-804DR (receiver)
SD Slot
1 SD slot, supports up to 32GB (not included)
Control Buttons
Snap Shot, Record, Camera, Quad Screen, Menu, Exit, OK,
and Up/Down/Left/Right Keys
Wireless (general)
LED Indicators
Power and Motion Detection
Power On/Off
1 x Power switch
AV Out
1 x Video/Audio output (RCA)
Antenna
1 x Angle adjustable antenna
Power In
1 x DC in power jack
Power Supply
DC 12V/1.0A
Consumption Current
400mA
Dimensions (LxWxH)
5.5” x 3.8” x 1.0”
Frequency
ISM 2400 – 2483.5 MHz (CH1/CH2/CH3/CH4)
Transmission Distance
Up to 490 ft (150m) clear line of sight; up to 200ft (indoor)
Operating Temperature
-10ºC ~ 50ºC /14ºF ~ 122ºF
Operating Humidity
≤ 85% RH
DigiLCDDVR Series
New Product for Nov. 2012
DigiLCDDVR2
DO IT
YOURSELF
DIGITAL
WIRELESS
MOTION
DETECTION
DigiLCDDVR4
WEATHER
RESISTANT
RECORD TO SD
COLOR
AUDIO
NIGHT VISION
4-Channel Digital Wireless Security System – Includes 7”
LCD/SD Recorder, 2 or 4 Digital Wireless Cameras with Night
Vision and Audio
Go digital with your wireless security needs; the simplest and secure way to protect your home and business. The DigiLCDDVR2
and DigiLCDDVR4 are D.I.Y. (do-it-yourself) complete digital wireless security systems. The DigiLCDDVR2/DigiLCDDVR4 includes
two/four weatherproof digital wireless cameras and a 7” LCD/SD DVR combo. Compared to full version digital video recording
(DVR) systems, the DigiLCDDVR series are much less complicated to operate, much more affordable and can be installed in minutes.
Simply insert a SD card (not included) into the LCD monitor, position and mount the cameras, plug in all the power adapters and
you are ready to record. In comparison to the traditional wireless technology (analog), digital wireless provides three key features
which include: Increased range of transmission, secure signal and unlike analog, the digital signals are virtually interference-free from
crowded wireless analog devices such as: Wi-Fi routers, Bluetooth devices, cordless phones, microwaves and cell phones.
DigiLCDDVR2
DigiLCDDVR4
• 2 x Digital wireless cameras with antenna and bracket
• 4 x Digital wireless cameras with antenna and bracket
• 1 x 7” LCD monitor with antenna and SD slot
• 1 x 7” LCD monitor with antenna and SD slot
• 2 x Power adapters (DC 5V/1.0A for cameras)
• 4 x Power adapters (DC 5V/1.0A for cameras)
• 1 x Power adapter (DC 12V/1.0A for LCD monitor)
• 1 x Power adapter (DC 12V/1.0A for LCD monitor)
• 1 x User’s manual
• 1 x User’s manual
*SD memory card not included
*SD memory card not included
Features:
• Do-it-yourself (D.I.Y) easy to setup and use 2.4GHz digital wireless recording system
• Space saving 7” LCD monitor with an Integrated SD digital video recorder (SD card not included)
• Simple installation. No video cables required.
• DigiLCDDVR series Includes two or four digital wireless cameras with IR LEDs for night vision (30ft B/W)
• Weatherproof (IP54) CMOS color camera for indoor and outdoor applications
• Increased range of transmission up to 200ft between walls and up to 490ft in clear line of sight
• No Wi-Fi interference; no interference from crowded analog 900MHz/2.4GHz/5.8GHz/6.0GHz devices
• Secure signal: neighbors cannot pick up the signal or listen in
• Built-in microphone for audible recording up to 30ft away
• Motion detection and manual recording with optional video or picture selection
• Auto overwrite function when SD is full
• Records 15-second video clips per motion detect in MP4 format with time and date stamp
Digital Video Recorders (DVRs)
Package Contents:
20
• DigiLCDDVR2 records up to 65 hours in single full screen of an active camera or 130 hours for both active
cameras in Quad mode using a 32GB SD card.
• DigiLCDDVR4 records up to 65 hours in single full screen of an active camera or 260 hours for all four active cameras in
Quad mode using a 32GB SD card.
• RCA audio/video output interfaces from receiver to monitor for display
• Upgradable by adding up to 4 total digital wireless cameras
• Records 1 channel or all 4 channels at the same time (in Quad mode)
• Single channel full screen, auto sequential rotation or Quad view display
• Playback directly from the receiver or PC via SD card reader with any MP4 player software
• Infrared filtered camera for best vibrant color picture
Key Specifications:
SM-816DT (camera)
Image Sensor
CMOS Color
Resolution
640 x 480 pixels (NTSC/PAL selectable)
Viewing Angle
45 degree
Audio
Microphone built-in (audio monitoring up to 30ft)
Minimum Illumination
2 Lux (IR off); 0 Lux (IR on)
IR LED Night Vision Range
Up to 30ft (B/W)
Weatherproof Rating
IP54
Antenna
1 x Angle adjustable antenna
Consumption Current
500mA
Mounting Bracket
Angle adjustable
Power LED Indicator
1
Power Supply
DC 5V/1.0A
Dimensions (LxWxH)
6.0” x 2.3” x 1.8” (camera body only)
Pairing Button
1
Display Modes
Single (auto switchable for multi cameras) or Quad (no audio)
CH Switch Intervals
Selectable from Never/5/10/15/20 seconds (for single mode)
Frame Rate
30fps in single mode or 15fps/camera in quad mode
Recording Resolutions
512x384 for single mode
320x240 for Quad mode
Recording Modes
Motion detection/Manual
Recording Format
MPEG4 (video)
JPEG (photo)
Digital Video Recorders (DVRs)
Motion Detect Video Clip/Size
21
15 seconds per clip; 2MB/clip in single; 500K/clip in quad mode for an
active camera
SM-371DR (LCD
SD Slot
1 SD slot, supports up to 32GB (not included)
monitor/receiver)
Control Buttons
Snap Shot, Record, Camera, Quad Screen, Quad, Menu, Exit, OK, and
Up/Down/Left/Right Keys
Wireless (general)
LED Indicators
Power and Motion Detection
Power On/Off
1 x Power switch
AV Out
1 x AV output
Antenna
1 (push up for better reception)
Power In
1 x DC in power jack
Power Supply
DC 12V/1.0A
Consumption Current
500mA
Dimensions (LxWxH)
7.0” x 6.0” x 1.0”
Frequency
ISM 2400 – 2483.5 MHz (CH1/CH2/CH3/CH4)
Transmission Distance
Up to 490 ft (150m) clear line of sight; up to 200ft (indoor)
Operating Temperature
-10°C ~ 50°C /14ºF ~ 122°F
Operating Humidity
≤ 85% RH
HomeDVR
EASY TO USE
USB
MPEG4
MOTION
DETECTION
RECORD TO SD
REMOTE
Mini Digital Video Recorder
Features:
•Easy-to-use basic digital video recorder
•Schedule, manual, or motion recording
•24 - 404 hours recording time for a 32GB SD (not included) upon various setting
•Date and time stamp footages
•Two video and audio inputs (one active channel for recording) and one video and audio output
•Alarm integration with one alarm input and one alarm output
•USB port for backup, download, and playback
•Easy operation by remote controller and front panel
•Overwrite function when SD is full
Package Contents:
•HomeDVR unit
•Power adapter
•2 x Alarm cable
•3 x AV cable
•USB cable
•Remote control
•1 x User’s Manual
Video Format
Video Resolution
Image Resolution
Recording Frame Rate
Storage Media
Storage Capacity
USB Interface
Video Display
Video Compression Format
Video Record Quality
Video Input
Video output
Alarm Input
Alarm Output
Audio Input
Audio Output
Audio Compression
Record Type
Record Format
Record Mode
Playback Function
Automatic Overwrite
Power Supply
Power Consumption
Operating Temperature
Operating Humidity
Dimensions
Weight (net)
NTSC/PAL(selectable)
D1 720x480(NTSC) and 720x576(PAL), CIF
CIF 350 x 240 (NTSC)/352 x 288(PAL)
30fps, 25fps, 20fps, 15fps, 10fps, 5fps
SD card
32GB (max)
USB 2.0 Mini
Full Screen (Live and Playback)
MPEG4
High/Medium/Low
2 Channels RCA (1.0VP- P ,75Ω)
1 Channel RCA (1.0VP- P ,75Ω)
1Channel
1 Channel
2 Channels RCA (200~1000mv 10K Ω)
1 Channel RCA (200~3000mv 5K Ω)
PCM
Photo/Video
JPEG(Photo)/AVI(Video)
Manual, Motion Detection and Schedule Recording
Pause, Normal, FF, REW
Yes
AC 100~240V, 6VDC 800mA
25W (max)
-10°C ~ 60°C/14°F ~ 140°F
20%~80%
130mm (L) x 95mm(W) x 25mm (H)
0.2Kg (0.44lbs)
Digital Video Recorders (DVRs)
Specifications:
22
HomeDVR-KT1
WIRELESS
RANGE
UP TO 100FT
AUDIO
RECORD TO SD
COLOR
DO IT YOURSELF
NIGHT VISION
One Outdoor Wireless Camera System Kit - Audio, Night
Vision, and SD DVR
Features:
Package Contents:
• Do-it-yourself (D.I.Y), easy to setup and use
• 1 x HomeDVR unit and remote control
• Small scale security system for home and business
• 1 x Wireless outdoor/indoor camera
• Compact size outdoor/indoor wireless camera (SM-302TX) with audio
• Wireless transmission up to 100ft without Wi-Fi interference or interference
from 2.4Hz/5.8GHz devices.
• 3 x Power adapter
• Built-in IR LEDs camera for night vision up to 23 (B/W)
(for camera, receiver, and HomeDVR)
• Future upgradable by adding 1 more wired camera
• 3 x AV cable
(select one active channel for recording)
• 2 x Alarm cable
• Records audio and video to SD card (up to 32GB)
• Camera mounting screws and plectrum
• Up to 24-404 hours recording time for a 32GB (not included)
• Overwrites when SD is full
• Schedule, manual, or motion detection recording
(SM-302TX) with bracket
• 1 x Wireless receiver (SM-302RX) with antenna
(focus adjustment tool)
• Quick Start Guide and manuals
(HomeDVR and SM-302RX/TX)
Digital Video Recorders (DVRs)
• USB port for backup, download, and playback
23
Specifications:
SM-302TX Camera
SM-302RXceiver
HomeDVR
Image Sensor
Total Pixels
Video Format
Transmission Frequency
Night Vision Range
Audio
Wireless Transmission Distance
Weatherproof
Channel Support
Channel Indication
Video Output/ Audio Output
Antenna Type
Power Button
Video Compression
Video/Audio Inputs
Video/Audio Output
Video Resolution (NTSC/PAL)
USB Mini
Operation
1/4¨ CMOS Color
510(H) x 492(V)
NTSC
900MHz wireless
Up to 23ft (B/W)
Microphone built-in (audio monitoring up to 20ft)
Up to 330ft clear line of sight; up to 100ft indoor
IP54
1 channel 900MHz
CH1 Green LED
1/1 RCA
SMA
1
MPEG4
2/2 (3.5mm interface, NTSC/PAL) (Choose one for recording)
1/1 (3.5mm interface)
350x240/352x288 (Recording); 704x480/704x576 (Preview/Playback image)
USB 2.0
Front panel and remote control (IR)
HomeDVR-KT1B
COLOR
DO IT YOURSELF
NIGHT VISION
WIRELESS
RANGE
UP TO 100FT
AUDIO
RECORD TO SD
One Outdoor Wired Camera System Kit – Audio, Night
Vision and SD Recorder
The HomeDVR-KT1B is a simple one camera recorder security system for home and small business. It includes one compact size wired
outdoor/indoor color camera with night vision and a palm size digital video recorder. The digital video recorder can records 24-404
total hours of audio and video using MPEG-4 compression into a SD card featuring time/date stamp, automatic overwrites when SD
card is full, and more.
Features:
Package Contents:
•
•
•
•
•
•
• 1 x HomeDVR recorder and remote control
• 1 x Wired outdoor/indoor camera (SM-302)
with mounting bracket
• 2 x Power adapters (camera and recorder)
• 3 x AV cable
• 2 x Alarm cable
• 1 x USB cable
• Camera mounting screws
• Quick Start Guide and manuals (HomeDVR and SM-302)
• 1 x 100ft VP(video power) cable
•
•
•
•
•
Do-it-yourself (D.I.Y), easy to setup and use
Small scale security system for home and business
One compact size outdoor/indoor color camera (SM-302) with audio
Best picture quality from wired camera; wireless interference free
Built-in IR LEDs for night vision up to 23 (B/W)
Future upgradeable by adding 1 more wireless or wired camera
(select one active channel for recording)
Records audio and video to SD card (up to 32GB, SD card not included)
Up to 24-404 video hours of recording time for a 32GB
Overwrites when SD card is full
Schedule, manual, or motion detection recording
USB port for backup, download, and playback
SM-302 Camera
HomeDVR
Image Sensor
Total Pixels
Video Format
Horizontal Resolution
Night Vision Range
Audio
Viewing Angle
Weatherproof
Connector Interface
Power Consumption
Operating Temperature
Operating Humidity
Dimensions (WxDXH)
Video Compression
Video/Audio Inputs
Video/Audio Output
Video Resolution (NTSC/PAL)
USB Mini
Operation
1/4” CMOS Color
510(H) x 492(V)
NTSC
420 TV Lines
Up to 23ft (B/W)
Microphone built-in (audio monitoring up to 20ft)
45 degree
IP54
Audio/Video (RCA)
200 mA (IR ON) / 80 mA (IR OFF)
-10°C ~ 50°C / 14°F ~ 122°F
85%RH
2.4”x1.4”x1.4” (camera body)
MPEG4
2/2 (3.5mm interface, NTSC/PAL) (Choose one for recording)
1/1 (3.5mm interface)
350x240/352x288 (Recording)
704x480/704x576 (Preview/Playback image)
USB 1.1
Front panel and remote control (IR)
Digital Video Recorders (DVRs)
Key Specifications:
24
iCamDVR
see feature #1
for more detail
7
WINDOWS
AUDIO
HI-SPEED
INTERNET
DO IT YOURSELF
MPEG4
NIGHT VISION
SUPPORT
USB Internet Camera and DVR Convertor Box
•Cost-effective solution for video recording and remote monitoring over the internet
•Converts wired/wireless camera(s) into internet camera(s)
•Turns your PC into a DVR (Digital Video Recorder)
•Includes PC software for recording, playback and remote monitoring
4 CHANNEL DISPLAY
Features:
•Supports smart phones with Win Mobile, Symbian, WinCE, iPhone, and Android OS
•Easily turn a camera into an Internet camera.
•Easily turn a PC into a DVR (digital video recorder) the most cost-effective way.
•MPEG4 video compression for higher quality picture and streaming video.
•Supports up to 4 cameras for recording and monitoring on PC.
•USB 2.0; good for faster/smoother video transmission.
•Real time recording rate at total 30fps(NTSC) / 25fps(PAL).
•Web Based IE remote monitoring and PTZ control. (require PTZ camera with supported protocol plus RS-485 port on the PC).
•Supports static IP or dynamic domain name.
•Auto-email, buzzer sound, pre-alarm record, and alert notification by motion detection.
•User Management (User Name and Password) security control.
Digital Video Recorders (DVRs)
Specifications:
25
Input Type
Video Input
Audio Input
Video Output
Live & Recording Frame Rate
Compression format
Video Resolution
Recorder Media
Record Mode
Network Protocol
PTZ Protocol
Remote Access
RCA x 4
4 CH
2 CH (select one)
USB 2.0 (to PC)
Total 30 fps(NTSC) for 4 Channels; 7.5fps each channel
(option) Total 25fps(PAL) for 4 channels; 6.25 fps each channel
MPEG4
320x240 or 640x480 (NTSC); 352x288 or 704x576 (PAL)
HDD, USB Disk, CD-RW via computer
Motion/Schedule/Manual
TCP/IP
Null, Lilin, Minking, Neon, PelcoD, PelcoP, Star, Video, and VISCA
Web Based IE for live view and playback
System Requirements:
OS Supported
DirectX
CPU
MOTHERBOARD
RAM
HDD
VGA
USB
Windows 2000, XP, Vista, and Windows 7 (32-bit/64-bit)
9.0 or Higher
Intel Pentium 4 or Celeron 1.7 GHz minimum
Intel 845/865/915 series
256M (minimum)
80GB (recommended)
GeForce2 / GeForce4 / FX5200 / ATI Rage128 (AGP)
USB 2.0 port
iCamDVR1W
see feature #1
for more detail
1 Wireless Camera System for Video Recording
and Remote Monitoring From PC
Features:
•Supports smart phone with Win Mobile, Symbian, WinCE, iPhone, and Android OS
•Easily turn wired/wireless camera(s) to Internet camera(s)
•Easily turn a PC into a DVR (digital video recorder) for recording
•Includes 1 D.I.Y. small wireless indoor/outdoor color camera (SM-302TX) with audio and night vision
•SM-302TX camera can transmit up to 100ft indoor without any Wi-Fi interference or any interference from 2.4Hz/5.8GHz devices
•Upgradable in the future by adding up to three more cameras.
•MPEG4 video compression for higher quality picture and streaming video
•USB2.0 good for faster/smoother video transmission
•Real time video recording rate at total 30fps(NTSC) / 25fps(PAL)
•PTZ control. (require PTZ camera with supported protocol plus RS-485 port on the PC)
•Schedule or video motion detection recording
•Supports one channel audio recording
•Web Based remote monitoring and remote playback from web browser
•Supports static IP or dynamic domain name
•Auto-email, buzzer sound, pre-alarm record, and alert notification by motion detection
•User Management (User Name and Password) security control
Package Contents:
Receiver
AC Adaptor
Récepteur
Recibidor
Adaptateur CA
Adaptador de corriente AC
Wireless Camera
Camera
Caméra sans fil
Cámara inalámbrica
•2 x 8VDC power AC adapters
•1 x AV cable
•1 x User’s manual and Quick Start Guide
to Desktop or Notebook PC
Vers un ordinateur de bureau ou un portable
a Desktop o portable PC
Video
Vidéo
Video
Caméra
Cámara
iCamDVR
Camera
Caméra
Cámara
Audio
Wireless Camera
Receiver
Récepteur
Recibidor
Caméra sans fil
Cámara inalámbrica
Acoustique
Audio
to Internet
AC Adaptor
Adaptateur CA
Adaptador de corriente AC
Vers l’internet
a Internet
Digital Video Recorders (DVRs)
•1 x iCamDVR (USB Internet camera and DVR converter box with software and manual CD)
•1 x Wireless night vision indoor/outdoor color cameras ( Model No: SM-302TX)
•1 x Wi-Fi interference free wireless receivers ( Model No: SM-302RX)
26
Dummy Cameras
SecurityMan dummy cameras are designed as professional security cameras for deterring unwanted intruders by just a fraction of
the cost of a real camera. They all come with flashing red LED light which enhances the presence of the cameras. Dummy cameras
can be used to mix in with real cameras or individually to increase security presence anywhere.
DUMMY
DO IT YOURSELF
FLASHING LED
Dummy Outdoor/Indoor Camera w/ LED (SM-3802)
• Dummy camera with flashing LED
• Weather resistant and anodized aluminum casing
• Metal mounting bracketLooks like real security camera
• Powered by 2 x AA batteries (not included)
• Adjustable mounting bracket
• Dimension: 280X120X90mm
DUMMY
DO IT YOURSELF
FLASHING LED
Dummy Indoor Dome Camera w/ LED (SM-320S)
• Imitation IR LEDs and one flashing LED
• Indoor dome camera type
• Plastic material
Other Security Products and Accessories
• Powered by 2 x AAA batteries (not included)
27
• Dimension: ¢95X95mm
DUMMY
DO IT YOURSELF
FLASHING LED
Dummy Indoor Camera w/ LED (SM-3601S)
• Imitation IR LEDs and one flashing LED
• Plastic material
• Metal mounting bracket
• Powered by 2 x AA batteries (not included)
• Dimension: ¢80X260mm
Package contents(for all above): Dummy camera, bracket and screws, and two security signs (stickers)
SM-1580
170°
150°
SPEAKER
MONITOR VIEWING
ANGLE
SVGA
720 TV LINE
COLOR
REMOTE
Professional 15" LCD CCTV Monitor with Speaker
SecurityMan SM-1580 is a professional 15-inch LCD CCTV monitor. It is the most economical and popular size of LCD CCTV monitor. It is
mostly used in home, business, medical care and industrial for monitoring and replacing the traditional bulky CRT monitor. In comparison
to a LCD TV or a computer LCD monitor, it is more reliable, stable, and last longer due to the nature of CCTV monitor. LCD CCTV
monitor features higher definition, better color revivification, wider viewing angle, higher brightness and contrast ratio, better than a
standard LCD display monitor. SM-1580 monitor is designed with convenient CCTV connection interfaces for your security needs.
Features:
•
•
•
•
•
•
High quality A-grade 15-inch TFT/LCD color monitor
High definition 720 TV lines and 1024x768 60Hz resolution
High resistance to pressure, electric current, humidity and temperature
Wide viewing angle 170°/150° (horizontal/vertical)
Easy operation by front panel buttons and remote control
Convenient CCTV interfaces; S-Video, BNC Video, RCA Audio, and VGA
• 1 x 15” LCD monitor with desktop base
• 1 x Power adapter
• 1 x Remote control (battery included)
• 1 x User’s manual
(Optional item: SM-BK1580 Wall-mount bracket)
Specification:
System
VGA
Video Input/Output
Audio
Menu
Dimension
Weight (Net/Gross)
Power Supply
Operating Temperature
Operating Humidity
Display Panel
Resolution/TVL
Brightness
Contrast
Response Time
Viewing Angle (horizontal/vertical)
Composite Video
S-Video
VGA
Voltage
Power Consumption
NTSC, PAL
15” 4:3 Color TFT/LCD
1024x768 60Hz/720TV Lines
300cd/m2
450:1
16ms
170°/150°
2 BNC inputs and 2 BNC outputs, 1.0Vpp, 75Ω,
1 input and 1 output
1 input
3 RCA inputs, 3 RCA outputs, and Speaker 2W
OSD (On-Screen Digital)
14.02”x11.73”x2.64”
9.92 lbs (4.5 Kg) / 13.23 lbs (6 Kg)
AC100-230V 50-60 Hz
32W Max.
0°C - 40°C/32°F - 104°F
10% - 85%
Other Security Products and Accessories
Package Contents:
28
SM-2100
Home
Store
DUMMY
EASY TO USE
Office
WEATHER
RESISTANT
FLASHING LED
Dummy Outdoor/Indoor Speed Dome Camera with LED
SecurityMan dummy camera SM-2100 is designed as a professional security camera for deterring unwanted intruders by just
a fraction of the cost of a real camera. It comes with a flashing red LED light which enhances the presence of the camera.
Multiple dummy cameras can be used to mix in with real cameras or individually to increase security presence anywhere.
Specifications:
Other Security Products and Accessories
• Dummy speed dome camera type with flashing LED
29
• Weather resistant
• Plastic material
• Wall mount/ceiling mount bracket
• Powered by 2*AA batteries (not included)
• Dimension: 24(H) x 12.8 (W) cm (9.5 x 5 inches)
• Weight (net/gross): 0.6 lbs / 0.86 lbs
Package Contents:
• Dummy camera, bracket and screws, two security signs (stickers), and manual
SecurityMan¨
SecurityMan¨
VIDEO/AUDIO
VIDEO/AUDIO
MONITORING AND
MONITORING AND
RECORDING DEVICES
RECORDING DEVICES
IN USE ON THESE IN USE ON THESE
PREMISES
PREMISES
www.securitymaninc.com
www.securitymaninc.com
SM-3803
Solar Panel
LED Light
DUMMY
EASY TO USE
WEATHER
RESISTANT
FLASHING LED
RECYCLE
GREEN ENERGY
Solar Power Outdoor/Indoor Dummy Camera with LED
Package Contents:
• Dummy camera with solar and LED
• Mounting bracket and sun visor
• 2pcs of security sign stickers
• Screws and accessories
Key Features and Specifications:
• Weather resistant dummy camera with one flashing red LED
• Energy efficient built-in solar panel or 2xAAA backup standard/rechargeable batteries (not included) when it is darker
• Adjustable wall-mount bracket
• Looks like real security camera
• Solar charges/conserves rechargeable/standard AAA batteries
• Low power consumption of 0.04W
• Camera dimensions: 160 (L) x 80 (W) x 74mm (H) (6.30” x 3.15” x 2.91”)
• N.W. 301g; G.W. 389g
Other Security Products and Accessories
Go green with SecurityMan (SM-3803) inexpensive solar dummy camera. Solar dummy camera can be use to protect your home and
business. It features energy saving designed solar panel capable of charging rechargeable batteries and conserve/extend the battery
life of standard batteries (2 x AAA requires, battery not included). The built-in solar panel will recycle indoor lights of 100+ Lux as power
source or it will use batteries power instead. Generally, two AAA batteries could last up to three years instead of one year. Equipped
with a flashing red LED light which enhances the presence of camera and security. Professional designed to purposely deter unwanted
intruders and solicitors with just a fraction of a cost of a real security camera. Mix in with real cameras for more dynamic presence or
use individually to increase security anywhere.
30
PanBase
Remote Control Pan Base for camera
Other Security Products and Accessories
The SecurityMan PANBASE is a remote control pan base for wired/wireless camera. PANBASE allows you to rotate your wired/wireless
video camera left and right with 370˚ viewing range and remotely position a camera to any desired angle with a remote control.
31
Features:
Package Contents:
•
•
•
•
•
•
•
•
•
•
•
•
•
Works great with wired/wireless security cameras
370˚ rotation range
Convenient 12V DC output for security camera
2 button remote for power and rotation direction with red L.E.D. indicator
433MHz wireless remote
Up to 150 ft remote distance
Sleek compact design
Easy installation
Pan base body
Remote controller
Power adaptor
Mounting bracket and accessories
User manual
Specification:
Pan Base
Remote Control
RF Receiver Sensible
RF Receiver frequency
Auto/Remote scanning angle
Manual adjust angle
Speed of Scanning
Max load
Noise (away 30cm unload)
Power Supply
Out Power
Dimension
Weight
Operation temperature range
Remote control range
RF Output Power
RF Transmitter Frequency
Battery
Transmitter Current
Maintain Current
Dimension
Weight
-80dBm(excel)
433.92MHz
370˚
75˚Max
50 seconds/change
500g
Less Than 40dB
12VDC 200mA
15VAC 400mA
3.9” x 3.9” x 3.9”
320 g
-10°C ~ 50°C/14°F ~ 122 °F
Up to 150ft (line of sight)
0dBm
433.92MHz
12V DC GP23A battery
20mA
40nA
3.7” x 1.9” x 1.1”
40g
Sign2PK-EN/FR
2 Surveillance Warning Signs-English/French
Features:
• Cost effective security to deter unwanted intruders
• D.I.Y. (Do-it-yourself) install in seconds
• Flexible mount to entrance door, window, wall, or yard on a stake (not included)
• Weatherproof plastic material sign
Package Contents:
• 2 x Plastic warning signs
Key Specifications:
• Material: Plastic
• Size: 8.48” (L) x 8.45” (W)
Other Security Products and Accessories
• 2 x Suction cups with hook (for window-mount)
32
w w w. s e c u r i t y m a n i n c .co m
SecurityMan 4601 E. Airport Dr. Ontario, CA 91761 ©Copyright 2012. All rights reserved.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
