We Make It Easy for You
EverFocus Electronics Corp. is a professional IP solution provider. We offer you a total solution including megapixel network
cameras, NVRs, peripherals and among these all, the EverFocus user-friendly CMS. Aiming at creating an easy IP-based
environment for you, our esteemed customer, we keep on trying to look for better solutions to fulfill your needs.
EverFocus has offices located around the world including the U.S.A, U.K, Germany, China, India, Japan and Taiwan.
EverFocus offers quality products, superior technical support, project design consultation, certified dealer programs,
educational trainings and many more to meet the demands of our customers worldwide. We believe the key component to
success lies in the development and quality of our products and excellent customer service.
Focused on You.
“Focused on You.” is a true description of EverFocus and our employees. We are constantly trying to redefine our role
in the marketplace and the World. Our goal is for every product that we manufacture to be easily installed with minimal
maintenance. Our extensive warranty is a testimony to the quality that we achieve on all of our products. Here at EverFocus
we take one word to heart when describing our company as a whole: Focused. We are focused on your needs, on providing
the industry with great products, and on innovation. When it comes to security equipment, go with the name you trust; go
with the name that is Focused on your company.
Thank you for your continued support. We look forward to serving all of your security needs for many years to come.
EverFocus Software Partners:
Notice:
© 2012 EverFocus Electronics Corp. The EverFocus trademark is registered by EverFocus Corp.All rights reserved. Product features and
specifications are subject to change without notice. No parts or contents of this datasheet may be reproduced or transmitted in any form
or by any means without permission from EverFocus.
•  Not all models featured are available in all countries. For accessories and other products information, please visit www.everfocus.com.tw
•  Safety precaution: carefully read the operating instructions and installation manual before using EverFocus product
•  EverFocus can not be responsible for network performance and/or other manufacturer products that resident on the network
•  These products may be subject to export control regulations
•  The above all photographs were taken for the purpose of explanation; actual images may differ
•  Models vary in different countries, please visit EverFocus regional websites for detailed ordering information.
* All product specifications are subject to change without notice
Table of Contents
IP Surveillance
3 Megapixel HD IP Camera
EAN2350................................................................................................................................................ 3
2 Megapixel HD IP Cameras In Order of Pixels
EDN3240................................................................................................................................................ 4
EDN2245................................................................................................................................................ 5
EHN3200................................................................................................................................................ 6
EZN3240................................................................................................................................................ 7
EAN3200................................................................................................................................................ 8
EAN2218................................................................................................................................................ 9
EPN2218/EPN2218i Speed Dome.............................................................................................................10
EQN2200/2201......................................................................................................................................11
1.3 Megapixel HD IP Cameras In Order of Pixels
EAN2150...............................................................................................................................................12
EAN900.................................................................................................................................................13
Super HAD CCD IP Cameras In Order of TV Lines
EDN850H...............................................................................................................................................14
EZN850.................................................................................................................................................15
EAN850A...............................................................................................................................................16
EDN800.................................................................................................................................................17
EAN800A/EAN800AW..............................................................................................................................18
EPN IP Speed Dome Series.....................................................................................................................19
Softwares
PowerFocus CMS....................................................................................................................................20
NVR Software........................................................................................................................................22
Accessories
EVS410..................................................................................................................................................23
EVS200A/EVS200AW..............................................................................................................................24
NVR PLUS..............................................................................................................................................25
NVR-202/NVR-204..................................................................................................................................26
EKB200.................................................................................................................................................27
2
* All product specifications are subject to change without notice
IP Surveillance
3 Megapixel HD IP Box Camera
EAN2350
3 Megapixel, H.264, WDR, PoE,
Network Box Camera
NEW
Compliant
3 Megapixel HD IP Camera
*Lens sold separately
Features
Specifications
•  Progressive Scan CMOS Sensor
•  Dual Streams, Full HD real-time + D1 real-time
•  H.264 and M-JPEG Compression
•  Motion Detection
•  Privacy Masks
•  WDR
•  Smart Picture Quality/3DNR
•  True Day/Night (ICR)
•  Auto Iris Lens support
•  Micro SD support
•  BNC Analog output
•  PoE support
•  ONVIF Support
Model Name
EAN2350
Image Sensor
Picture Elements
1~ 1/10,000sec.
White Balance
Manual / AWB / ATW
C/CS mount Lens
Video Compression
Resolution
H.264
M-JPEG
Manual
Sharpness
Manual
Contrast
White Balance
Manual
Auto/Manual
Saturation
Manual
Backlight Comepnsation
On/Off
Hue
Manual
Digital Zoom
Support
WDR
On/Off
3D Noise
On/Off
Motion detection
On/Off
Privacy Mask
On/Off
Two-way Audio
Alarm Input
Alarm Output
Event Notification
Multiple Languages
Interface
Password Levels
User Account
Lens Mounting
Operating Temperature
Power Source
52mm/2”
Full HD 1080p/SXGA/HD 720p/XGA/SVGA/D1/VGA/CIF
Auto/Manual
Audio Compression
Power Consumption
Dimensions (L x W x H)
Weight
Certificates
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
H.264 / M-JPEG
3M(2048x1536)/Full HD 1080p/SXGA/HD 720p/XGA/SVGA/D1/VGA/CIF
Exposure
Tampering Alarm
76mm/3”
C/CS mount Lens (Lens sold separately)
Brightness
ICR
125mm/4.9”
2048(H) x 1536(V)
Shutter Speed
Privacy Mask Type
Dimensions
1/2.7" Progressive CMOS
Color
Auto/On/Off
On/Off
Line out, Line in/Mic in
G.711 / G.726
5V 10kΩ pull up
Photo Relay Output 300VDC/AC
HTTP, FTP, SMTP
English, French, German, Italian, Korean, Simplified Chinese, Russian
10/100Mbps Ethernet (RJ-45)
User and Administrator
20
C / CS mount
-10°C ~ 50°C / 14°F ~ 122°F (10% to 90% Humidity), No Condensation
12VDC/24VAC/PoE
4W
125 x 76 x 52mm / 4.9” x 3” x 2” (w/o lens)
330g/0.73lbs
CE, FCC
* All product specifications are subject to change without notice
3
IP Surveillance 2 Megapixel HD IP Indoor IR Dome Cameras
EDN3240
2 Megapixel, H.264, Full HD, IR Network Dome Camera
Series
2 Megapixel HD IP Cameras
Features
Specifications
•  1/2.7” 1080p/720p HD color CMOS image sensor delivers
HDTV video quality in 16:9 aspect ratio
•  Supports both H.264 and Motion JPEG in full 30fps frame
rate
•  High Performance Noise Filter improves image quality
•  Provides NTSC/PAL TV Signal ‘test mode’ output for local aim
and focus or display on an analog monitor
•  Dual Codec for H.264 and M-JPEG allows choice of stream
formats to fit the application
•  Built-in slot for an SDHC card enables local event or backup
recording in the event of network interruptions
•  Provides true Day/Night functionality with automatic IR filter
operation
•  Up to 4X ‘sens-up’ low light enhancement
•  Two Way Audio transport (line level input/output)
•  ONVIF/PSIA compliance interoperates with a broad range of
systems
•  Dual power capability PoE or 12VDC for flexible installation
•  Local alarm inputs and outputs
•  May be attached to wall or ceiling; flush or surface mounted
•  3-Axis adjustment for almost any viewing angle
•  Equipped with 34 IR LEDs for day and night environments
•  IR distance up to 66 feet (20m; depending on surface
reflectivity)
•  High Output IR LEDs, with a lifespan exceeding 20,000 hours
Pickup Device
Lens Type
Sensitivity
Day/Night
Electronic Shutter Speed
SENSE-UP
Auto Gain Control
White Balance mode
Noise Filter
Dimensions
Other settings
Video Test Output
IR Emitters
IR Distance
IR Wavelength
IR LED Lifespan
Video Compression
Video Resolution
Video Quality
Frame Rate
Audio Compression
Audio Input
Audio Output
Operation Mode
Interface
Supported Protocols
Alarm Input/Output
Event Trigger
Notifications
1/2.7" Full HD progressive scan CMOS sensor
Vari-focal lens, Auto Iris, f=3.3~10mm
0.5 Lux/F=1.2 (0 Lux / IR On)
True Day/Night with IR cut filter
1/10000 s to 1/7.5 s (1/60 second nominal)
OFF/x2/x4
OFF/Low/Middle/High selectable
Auto, Custom
Auto/Low/High
Brightness, Contrast, Saturation, Sharpness, Hue, Auto Exposure, Backlight
Compensation, Mirror, Flip, Day/Night, Anti-Flicker
BNC socket, composite 1 V p-p / 75Ω in local test mode only
34 long life LEDs
Up to 20M (66ft.)
850nm
20,000 hours
H.264 / M-JPEG
1920x1080 to 160x120; depends on overall configuration of stream(s)
VBR: 5 level adjustable, CBR: 256Kbps~6Mbps
25/30fps @ all resolutions
G.711 PCM 8 KHz
1 Vrms ; 3.5mm phone jack; Mono, Line in
1 Vrms ; 3.5mm phone jack; Mono, Line out
Two-way audio
10Base-T/100Base-TX auto-negotiation, RJ-45 socket
TCP/IP,UDP,ICMP,DHCP,NTP,DNS,DDNS,SMTP,SNMP,FTP,HTTP,PPPoE,UPnP,B
onjour,RTP,RTSP,RTCP,IGMP,ICMP,ARP,ONVIF,PSIA
1/1
Alarm Input, Manual Trigger, Motion Detection, Fan Failure, Schedule
Recording
Trigger alarm output, Send mail notification, Upload video to FTP, Record
video to PC, Record to SD card and Network alarm
Pre- and Post - alarm
buffer
SD Card Slot
128mm/5.1”
Power Supply
Power over Ethernet
Power Consumption
Weight
140mm/5.5”
Dimensions
4
* All product specifications are subject to change without notice
Operating Temperature
Humidity
Certificates
40MB
Secure Disk physical layer specification version 2.0
Supports SDHC Host Specification
12 VDC & PoE
Yes (PoE 802.3af)
9W max. (IR LED On)
550g/1.102lbs.
Surface Type: 140 x 128mm / 5.5” x 5.1”
Ceiling Type:140 x 68mm / 5.5” x 2.77”
0°C ~ 40°C / 32°F ~ 104°F
< 90% not condensing
CE, FCC
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance 2 Megapixel HD IP Outdoor IR Dome Cameras
EDN2245
2 Megapixel, H.264, Vari-Focal Lens,
Network Outdoor IR Dome
NEW
Compliant
2 Megapixel HD IP Cameras
Features
Specifications
•  Progressive Scan CMOS Sensor
•  Full HD 1080p / HD 720p real-time at dual
streaming
•  H.264 and M-JPEG compression
•  Remote Zoom & Focus
•  Motion Detection
•  Privacy Masks
•  True Day/Night (ICR)
•  Micro SD support
•  BNC analog output
•  Weatherproof (IP66 international)
•  Vandal proof dome cover
•  ONVIF Support
Model Name
Image Sensor
Picture Elements
Shutter Speed
Minimum Illumination
White Balance Lens
Lens Type Varifocal lens/
Motorized lens
Field of View
Video Compression
71°~21°
H.264/ M-JPEG
1080p 25/30fps, 720p 25/30fps
Brightness
Manual
Backlight Compensation
On/Off
Exposure
Auto/Manual
Sharpness
Manual
Manual
Auto/Manual
Manual
Hue
Manual
Digital Zoom
Support
Motion detection
On/Off
Privacy Mask
Support
ICR
Tampering Alarm
Two-way Audio
Audio Compression
Alarm Input
Alarm Output
Event Notification
Multiple Languages
Password Levels
Security
130mm / 5.12”
Manual/AWB/ATW F=1.4/F=3~9 mm
Full HD 1080p/HD 720p/SXGA/D1/VGA/QVGA/CIF
Saturation
User Account
Built-in IR
Illuminator Wavelength
Number of LEDs
Operating Temperature
Power Source
Power Consumption
Weatherproof Standard
Dimensions ( Ø x H )
Weight
Certificates
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
1~1/10000sec.
Color: 0.2 Lux @ F=1.4 , B/W:0.02 Lux / F=1.4
Frame Rate
White Balance
151mm / 5.94”
1920(H) x 1080(V)
Resolution
Contrast
Dimensions
EDN2245
1/2.7” Progressive CMOS
Auto/On/Off
On/Off
Line out, Line in/Mic in
G.711 / G.726
5V 10kΩ pull up
Photo Relay Output 300VDC/AC
HTTP, FTP, SMTP
English, French, German, Italian, Korean, Simplified Chinese, Russian
User and Administrator
HTTPS, IP Filter, IEEE 802.1X
20
Working distance up to 30m
850nm
23
-10°C~50°C / 14°F ~ 122°F
(10% to 90% Humidity), no condensation
12VDC/24VAC/PoE
System: 5.5W (Heater: +15W, Fan: +1W, Built-in IR Illuminator: +3.4W,
Motorized Lens: +3.6W)
IP66
130 x 151mm / 5.12” x 5.94”
1.3kg/2.9lbs
CE, FCC
* All product specifications are subject to change without notice
5
IP Surveillance 2 Megapixel HD IP Outdoor Dome Cameras
EHN3200
2 Megapixel, H.264, Full HD, Outdoor Network Dome Camera
Series
2 Megapixel HD IP Cameras
Features
Specifications
•  1/2.7" 1080p/720p HD color CMOS image sensor
delivers HDTV video quality in 16:9 aspect ratio
•  Supports both H.264 and Motion JPEG in full 30 fps
frame rate
•  High Performance Noise Filter improves image quality
•  Provides NTSC/PAL TV Signal ‘test mode’ output for
local aim and focus or display on an analog monitor
•  Dual Codec for H.264 and M-JPEG allows choice of
stream formats to fit the application
•  Built-in slot for an SDHC card enables local event
or backup recording in the event of network
interruptions
•  Provides true Day/Night functionality with automatic
IR filter operation
•  Up to 4X ‘sens-up’ low light enhancement
•  Two Way Audio transport (line level input/output)
•  ONVIF/PSIA compliance interoperates with a broad
range of systems
•  Dual power capability PoE or 12VDC for flexible
installation
•  Local alarm inputs and outputs
•  Vandal Proof & Weatherproof IP66 rated
Pickup Device
Dimensions
Lens Type
Vari-focal lens, Auto Iris, f=3.3~12mm
Sensitivity
0.5 Lux/F=1.2
Day/Night
True Day/Night with IR cut filter
Electronic Shutter Speed
SENSE-UP
1/10000 s to 1/7.5 s (1/60 second nominal)
OFF/x2/x4
Auto Gain Control
White Balance mode
Noise Filter
OFF/Low/Middle/High selectable
Auto, Custom
Auto/Low/High
Other settings
Video Test Output
Video Compression
Video Resolution
Video Quality
Brightness, Contrast, Saturation, Sharpness, Hue, Auto Exposure, Backlight
Compensation, Mirror, Flip, Day/Night, Anti-Flicker
BNC socket, composite 1 V p-p, 75Ω in local test mode only
H.264 / M-JPEG
1920x1080 to 160x120; depends on overall configuration of stream(s)
VBR: 5 level adjustable, CBR: 256Kbps~6Mbps
Frame Rate
25/30fps @ all resolutions
Audio Compression
Audio Input
G.711 PCM 8 kHz
1 Vrms ; 3.5mm phone jack; Mono, Line in
Audio Output
1 Vrms ; 3.5mm phone jack; Mono, Line out
Operation Mode
Interface
Two-way audio
10Base-T/100Base-TX auto-negotiation, RJ-45 socket
Supported Protocols
Alarm Input/Output
TCP/IP,UDP,ICMP,DHCP,NTP,DNS,DDNS,SMTP,SNMP,FTP,HTTP,PPPoE,UPnP,
Bonjour,RTP,RTSP,RTCP,IGMP,ICMP,ARP,ONVIF,PSIA
1/1
Event Trigger
Alarm Input, Manual Trigger, Motion Detection, Schedule Recording
Notifications
Trigger alarm output, Send mail notification, Upload video to FTP, Record
video to PC, Record to SD card and Network alarm
Pre- and Post - alarm
buffer
Power Supply
Power over Ethernet
Power Consumption
Weight
Yes (PoE 802.3af)
4W max.
0.74 kg/1.6lbs
Dimension (O.D. x H)
Operating Temperature
Humidity
40MB
Secure Disk physical layer specification version 2.0
Supports SDHC Host Specification
12 VDC & PoE
SD Card
127mm /5.0”
1/2.7" Full HD progressive scan CMOS sensor
123mm x 107.8mm; 4.8” x 4.2”
-10°C ~50°C / 14°F~122°F
< 90% not condensing
Certificates
CE, FCC
112.8mm/4.44”
6
* All product specifications are subject to change without notice
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance 2 Megapixel HD IP Outdoor IR Bullet Cameras
EZN3240
2 Megapixel, H.264, Full HD, Outdoor, IR Network Bullet Camera
Series
2 Megapixel HD IP Cameras
Features
Specifications
•  1/2.7” 1080p/720p HD color CMOS image sensor delivers
HDTV video quality in 16:9 aspect ratio
•  Supports both H.264 and Motion JPEG in full 30 fps frame
rate
•  High Performance Noise Filter improves image quality
•  Provides NTSC/PAL TV Signal ‘test mode’ output for local
aim and focus or display on an analog monitor
•  Dual Codec for H.264 and M-JPEG allows choice of stream
formats to fit the application
•  Provides true Day/Night functionality with automatic IR
filter operation
•  Up to 4X ‘sens-up’ low light enhancement
•  Two Way Audio transport (line level input/output)
•  ONVIF/PSIA compliance interoperates with a broad range
of systems
•  Multiple power capability PoE or 12VDC or 24VAC for
flexible installation
•  Local alarm inputs and outputs
•  Extended IR range of up to 40M (131ft.) with 35 LEDs
and variable output IR control to manage illumination and
conserve energy
•  Split glad to prevent internal IR reflections
•  Flexible mounting and positioning – speed – mount ring
fits 4” round electrical box; or remove base to mate with 1”
conduit
•  E-Z lock ring at the base is designed with easy to grip
tabs for firmly clamp the camera in place, plus a set screw
for added security
Dimensions
”
m/3
75m
Pickup Device
Lens Type
Sensitivity
Day/Night
Electronic Shutter Speed
SENSE-UP
Auto Gain Control
White Balance mode
Noise Filter
Other settings
Video Test Output
IR Emitters
IR Configuration
IR Output
IR Distance
IR Wavelength
IR LED Lifespan
Video Compression
Video Resolution
Video Quality
Frame Rate
Audio Compression
Audio Input
Audio Output
Operation Mode
Interface
Supported Protocols
Alarm Input/Output
Event Trigger
Notifications
Pre- and Post - alarm
buffer
Built-in SDHC Card
(optional)
Power Supply
Power over Ethernet
Power Consumption
Weight
Dimension (L x H x W)
Operating Temperature
Humidity
Weatherproof
Vandal Resistant
316.2mm/12.5”
Mounting Pattern
Certificates
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
40MB
8GB, 16GB, 32GB
12 VDC & 24VAC & PoE
Yes (PoE 802.3af)
12VDC: 11W max./24VAC: 11W max. (IR LED On)
1250g/2.275lbs.
316.2mm x 82.5mm x 105.5mm Diameter /
12.49“ x 3.24“ x 4.15“ Diameter
-40°C ~ 50°C / -40°F ~ 122°F (built-in heater)
< 90% not condensing
IP66, built-in heater
Yes
Speedy-Mounting Ring mates with 4” round electrical box; base swivel is
1”NPT – remove base plate for coupling to standard conduit fittings.
CE, FCC
81.5mm/3.2”
106.5mm/4.2”
184.2mm/7.3”
1/2.7" Full HD progressive scan CMOS sensor
Vari-focal lens, Auto Iris, f=3.3~10mm with stepping motor
0.5 Lux/F=1.2 (0 Lux / IR On)
True Day/Night with IR cut filter
1/10000 s to 1/7.5 s (1/60 second nominal)
OFF/x2/x4
OFF/Low/Middle/High selectable
Auto, Custom
Auto/Low/High
Brightness, Contrast, Saturation, Sharpness, Hue, Auto Exposure, Backlight
Compensation, Mirror, Flip, Day/Night, Anti-Flicker
BNC socket, composite 1 V p-p / 75Ω in local test mode only
35 long life LEDs
Split glass isolation prevents internal reflections
Intelligent variable intensity illumination/Energy management
Up to 40M (131ft)
850nm
20,000 hours
H.264 / M-JPEG
1920x1080 to 160x120; depends on overall configuration of stream(s)
VBR: 5 level adjustable, CBR: 256Kbps~6Mbps
25/30fps @ all resolutions
G.711 PCM 8KHz
1 Vrms ; 3.5mm phone jack; Mono, Line in
1 Vrms ; 3.5mm phone jack; Mono, Line out
Two-way audio
10Base-T/100Base-TX auto-negotiation, RJ-45 socket
TCP/IP,UDP,ICMP,DHCP,NTP,DNS,DDNS,SMTP,SNMP,FTP,HTTP,PPPoE,UPnP,B
onjour,RTP,RTSP,RTCP,IGMP,ICMP,ARP,ONVIF,PSIA
1/1
Alarm Input, Manual Trigger, Motion Detection, Schedule Recording
Trigger alarm output, Send mail notification, Upload video to FTP, Record
video to PC, Record to SD card and Network alarm
* All product specifications are subject to change without notice
7
IP Surveillance 2 Megapixel HD IP Box Cameras
EAN3200
2 Megapixel, H.264, Full HD Network Box Camera
Series
2 Megapixel HD IP Cameras
*Lens sold separately
Features
Specifications
•  1/3” 1080p/720p HD color CMOS image sensor
delivers HDTV video quality in 16:9 aspect ratio
•  Supports both H.264 and M-JPEG in full 30fps frame
rate
•  High Performance Noise Filter improves image
quality and conserves disk storage
•  Provides NTSC/PAL TV signal output for local aim
and focus or display on an analog monitor
•  Dual Codec for H.264 and M-JPEG allows choice of
stream formats to fit the application
•  Built-in slot for an SDHC card enables local event
or backup recording in the event of network
interruptions
•  Provides true Day/Night functionality with automatic
IR filter operation
•  Two Way Audio transport (line level input/output)
•  ONVIF/PSIA compliance interoperates with a broad
range of systems
•  Dual power capability PoE or 12VDC for flexible
installation
•  Local alarm inputs and outputs
Camera Type
Pickup Device
Lens Type
Sensitivity
Day/Night
Electronic Shutter Speed
SENSE-UP
Auto Gain Control
White Balance mode
Noise Filter
Dimensions
136mm/5.4”
13mm/0.5”
10mm/0.4”
8
57mm/2.2”
Megapixel Network Camera
68mm/2.7”
Indoor, traditional style Megapixel network camera
1/3" Full HD progressive scan CMOS sensor
Optional C/CS mount, manual / DD control support
0.5 Lux/F=1.2
True Day/Night with IR cut filter
1/10000 s to 1/7.5 s
OFF/x2/x4
OFF/Low/Middle/High selectable
Auto, Custom
Auto/Low/High
Brightness, Contrast, Saturation, Sharpness, Hue, Auto Exposure,
Other settings
Backlight Compensation, Mirror, Flip, Day/Night, Anti-Flicker
Video Output
BNC socket, composite 1 Vp-p, 75Ω in local test mode only
Video Compression
H.264 / M-JPEG
Video Resolution
1920x1080 to 160x120
Video Quality
VBR: 5 level adjustable, CBR: 30Kbps~6Mbps
Frame Rate
All resolutions @ 25/30fps
Audio Compression
G.726 ADPCM 8 kHz
Audio Input
1 Vrms ; 3.5mm phone jack; Mono
Audio Output
1 Vrms ; 3.5mm phone jack; Mono
Operation Mode
Two-way audio
10Base-T/100Base-TX auto-negotiation, RJ-45 socket,
Interface
Support MDI/MDI-X auto
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP, uPnP,
Supported Protocols
ONVIF/PSIA
Alarm Input / Output
1/1
RS485
Yes (function reserved)
Event Trigger
Alarm Input, Manual Trigger, Motion Detection, Schedule Recording
Trigger alarm output, Send mail notification, Upload video to FTP, Record
Notifications
video to PC, Record to SD card and Network alarm
Pre-and Post-alarm buffer
Up to 120 sec.
Secure Disk physical layer specification version 2.0
SD Card
Supports SDHC Host Specification
Power Supply
12 VDC & PoE
Power over Ethernet
Yes (PoE 802.3af)
Power Consumption
4 W max. (12VDC)
Weight
550g/1.102lbs
Dimension (W x H x D)
68 x 57 x 135mm / 2.72” x 2.28” x 5.4”
Operating Temperature
0°C ~ 40°C / 32°F ~ 104°F
Humidity
< 90% not condensing
Certificates
CE, FCC
49mm/1.9”
* All product specifications are subject to change without notice
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance 2 Megapixel HD IP Box Cameras
EAN2218
2 Megapixel, H.264, WDR,
18x Optical Zoom Lens,
Network Box Camera
NEW
Compliant
2 Megapixel HD IP Cameras
Features
Specifications
•  Sony Progressive CMOS Sensor
•  Built-in 18x Optical Zoom with
AF f= 4.7~84.6mm (18x)
•  Full HD 1080p real-time
•  H.264 and M-JPEG Compression
•  Wide Dynamic Range (WDR)
•  Smart Picture Quality/3D Noise Reduction
•  Motion Detection
•  Privacy Masks
•  True Day/Night (ICR)
•  Micro SD support
•  BNC analog output
•  PoE support
•  ONVIF Support
Model Name
18x Zoom AF IP Camera
Image Sensor
1/2.8” Sony Progressive CMOS
Picture Elements
Minimum Illumination
1~1/10000sec.
White Balance
Manual/ATM/Auto
Focal Length
F number
Compression Format
Resolution
Manual
Sharpness
Manual
Contrast
Manual
Auto/Manual
Saturation
Manual
Hue
Manual
Backlight Compensation
On/Off
Digital Zoom
Support
WDR
On/Off
3D Noise Reduction
On/Off
Motion Detection
On/Off
Privacy Mask
On/Off
Tampering Alarm
Two-way Audio
Audio Compression
Alarm Input
52mm/2.05”
H.264/M-JPEG
Full HD 1080p/HD 720p/XGA/SVGA/D1/VGA/CIF
Auto/Manual
ICR
Alarm Output
Event Notification
Multiple Languages
Interface
Password Levels
Security
Max. Client
Operating Temperature
Power Source
Power Consumption
Dimensions (L x W x H)
Weight
Certificates
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
4.7~84.6mm
F=1.6(Wide); F=2.8(Tele)
Exposure
Privacy Mask Type
75.2mm/2.96”
18x Optical Zoom, Auto Focus
Brightness
White Balance
183mm/17.22”
1920(H) x 1080(V)
Color: 0.2 Lux; B/W: 0.02 Lux
Shutter Speed
Lens
Dimensions
EAN2218
Camera Model
Color
Auto/On/Off
On/Off
Line out, Line in/Mic in
G.711/G.726
5V 10kΩ pull up
Photo Relay Output 300VDC/AC
HTTP, FTP, SMTP
English, French, German, Italian, Korean, Simplified Chinese, Russian
10/100Mbps Ethernet (RJ-45)
User and Administrator
HTTPS, IP Filter, IEEE 802.1X
20
0°C~40°C/32°F~104°F (10%~90% Humidity), No Condensation
12VDC/24VAC/PoE
6W (500mA)
183 x 75.2 x 52mm / 17.22” x 2.96” x 2.05”
450g/1lbs
CE, FCC
* All product specifications are subject to change without notice
9
IP Surveillance 2 Megapixel HD IP Speed Dome Cameras
EPN2218/EPN2218i
2 Megapixel, H.264, 18x
Outdoor/Indoor IP Speed Dome Camera
NEW
Compliant
2 Megapixel HD IP Cameras
Outdoor
Features
Indoor
Specifications
•  18x Optical Zoom
•  8x Digital Zoom
•  Simultaneous dual streams: H.264 and M-JPEG
•  Full HD real-time Resolution
•  Two-way audio support
•  Removable IR Cut Filter
•  Motion Detection
•  Wide Dynamic Range (WDR)
•  Digital Noise Reduction
Model Name
EPN2218
EPN2218i
Environment
Outdoor
Indoor
Image Sensor
1/2.8” Sony Progressive Scan CMOS Sensor
Optical Zoom
18X
Digital Zoom
1~8x variable
Focal Length
4.7~84.6mm
Focus Mode
Auto/Manual
White Balance
Auto/Indoor/Outdoor/ATW
Iris Control
Auto/Manual
Electronic Shutter
1/30~1/10k sec.
AGC control
Auto/Manual
Back Light
On/Off
Pan Travel
360° endless
Tilt Travel
-10°~190°
Manual Speed
0.5°~90°/s
Presets
256
Preset Accuracy
0.225°
Preset Speed
5°~400°/s
Sequence
8
Auto Pan
4
Cruise
8
Privacy Mask
16
Proportional Pan & Tilt
* Accessories Option: T-Bar Ceiling Mount: EPTZ-ICMBD;
Indoor Mount Kit: EPTZ-CMBD;
Pendant: EPTZ-WMBD
Dimensions
On/Off (Pan and tilt speed proportional to zoom ratio)
Resume after Power loss
Yes
Zone Title
16
Home Function
Preset/Sequence/Auto pan/Cruise
Auto Flip
Digital/Mechanical/Off
Digital Slow Shutter
On/Off
Motion Detection
On/Off
Wide Dynamic Range
On/Off
Day/Night: IR Cut Filter
Outdoor Model
Auto/Manual
Image Inverse
On/Off
Image Freeze
On/Off
Indoor Model
2D/3D Noise Reduction
172mm/6.8”
Compression Format
Video Streaming
On/Off
H.264 Main Profile/M-JPEG
Multiple Streams, H.264 + M-JPEG/H.264 + H.264
Video Resolution
Frame Rate
229mm/9”
282mm/11.1”
Audio Compression
10/100Mb Ethernet (RJ-45)
Digital Alarm Input
4
Digital Alarm Output
2
Preset, Sequence, Auto pan, Cruise
User Account and Password Protection
Operating Temperature
-45°C~50°C / -49°F~122°F
0°C~40°C / 32°F~104°F
Dimensions ( Ø x H )
192 x 282mm / 7.6” x 11.1”
172 x 229mm / 6.8” x 9”
Weight
2.32kg/5.11lbs w/sunshield
1.62kg/3.57lbs
AC24V ± 10%
PoE+/AC24V ± 10%
Power Source
Power Consumption
Certificates
* All product specifications are subject to change without notice
Two-way
Interface
Security
192mm/7.6”
G711/G.726 ADPCM/AAC
Audio Streaming
Alarm Reaction
10
1080P/720P/VGA/D1
30/25fps @ 1080P, 60/50fps @ 720P
65W (with Heater)
20W
CE, FCC, IP66 (EPN2218)
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance 2 Megapixel HD IP Cameras
EQN2200/2201
2 Megapixel, H.264, HD Network Camera
(Q-Cam Network Camera)
Series
2 Megapixel HD IP Cameras
Features
Specifications
•  2 Megapixel image capture (Max. Resolution: 1600
x 1200)
•  Built in H.264 and M-JPEG dual stream output at
720p image size with up to 30fps
•  Integrated fix focus wide angle lens (4.3mm),
adjustable focus
•  Full screen monitoring
•  Two-way audio capability
•  Built-in microphone & speaker
•  Image transfer by motion detection, digital I/O
•  Smart wizard event management
•  Plug-and-play installation
•  Image date and time stamp
•  Built-in 802.11g/b wireless (EQN2201)
Model Name
Pickup Device
1/3" progressive scan CMOS sensor, 2 Megapixel
Lens
4.3mm/F=1.8
Sensitivity
0.5 Lux/F=1.8
Video Compression
Video Resolution
Frame Rate
Microphone & Speaker
Operation Mode
H.264 / M-JPEG
1600 x 1200~160 x 120
1600 x [email protected], 1280 x [email protected], 720p [email protected] 30fps
Built-in
Two-way audio
10Base-T/100Base-TX auto-negotiation, RJ-45 socket
Interface
Support MDI / MDI-X auto crossover function
Built-in IEEE 802.11b/g WLAN (for EQN2201)
Supported Protocols
Alarm Input/Output
Event Trigger
Notification
Power Supply
Power Consumption
Weight
Dimensions
EQN2200: wired interface
EQN2201: wired and wireless interface
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP,
ONVIF, PSIA
1/1
Alarm Input, Manual Trigger, Motion Detection
Trigger alarm output, Send mail notification,
Upload video to FTP and Network alarm
5VDC
EQN2200: 3.5W max.
EQN2201: 4.0W max.
140g/0.31lbs
Dimension (H x W x D)
97 x 66 x 55mm / 3.8” x 2.6” x 2.2”
Operating Temperature
0°C~40°C / 32°F~104°F
Humidity
Certificates
< 90% not condensing
CE, FCC
54.5mm / 2.1”
66mm / 2.6”
96.5mm / 3.8”
62mm / 2.4”
118mm / 4.6”
41mm / 1.6”
103mm / 4”
75.5mm / 3”
78mm / 3”
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
11
IP Surveillance 1.3 Megapixel HD IP Box Cameras
EAN2150
1.3 Megapixels CCD, H.264, WDR,
True Day/Night, Network Box Camera
NEW
Compliant
1.3 Megapixel HD IP Cameras
*Lens sold separately
Features
Specifications
•  Sony Progressive Scan CCD sensor
•  HD 720p real-time at dual streaming
•  H.264, M-JPEG and MPEG-4 compression
•  Integrated real-time WDR
•  2D/3D Noise Reduction
•  Motion Detection
•  Privacy Masks
•  True Day/Night (ICR)
•  Micro SD support
•  BNC analog output
•  ONVIF Support
Model Name
EAN2150
Image Sensor
Picture Elements
Minimum Illumination
Shutter Speed
White Balance
Lens Mount
1/3" Sony Progressive CCD
1280(H) x 960 (V)
Color:0.03 Lux @ F=1.2 ; B/W: 0.001 Lux / F=1.2
1~ 1/10000sec.
Manual/AWB
C/CS mount Lens (Lens sold separately)
Compression Format
H.264 Baseline/M-JPEG/MPEG-4
Resolution
1280 x 960/HD 720p/D1/VGA/QVGA/CIF/QCIF
Frame Rate
1280 x 960 @ 12.5/15fps, 720p @ 25/30fps
Brightness
Manual
Exposure
Auto/Manual/Fixed Shutter/Auto Iris Mode
Backlight
On/Off
Sharpness
Manual
Contrast
Manual
White Balance
Auto/Manual/Indoor/Outdoor
Digital Zoom
1x ~ 16x
Motion Detection
Image Rotation
WDR
On/Off
Flip, Mirror, and 180°Rotate
Off/4 Level Adjustment
3D Noise Reduction
On/Off
Privacy Mask
5
Privacy Mask Type
ICR
Auto/On/Off
Audio Two-way Audio
Dimensions
Transparent, Color
Audio Compression
Alarm Input
Line out/Line in/Mic in
G.711/G.726
5V 10kΩ pull up
Alarm Output
Multiple Languages
Event Notification
Interface
Photo relay output 300VAC
English, French, German, Italian, Simplified Chinese, Russian
HTTP, FTP, SMTP
10/100 Mb Ethernet (RJ-45)
Password Levels
User and Administrator
Max. Client
125mm/4.9”
20
Operating Temperature
76mm/3”
Power Source
0°C ~ 50°C / 32°F ~ 122°F (10% - 90% humidity),No Condensation
DC12VAC/24V/PoE
52mm/2”
Power Consumption
12
* All product specifications are subject to change without notice
Dimensions (L x W x H)
Weight
6W
125 x 76 x 52mm / 4.9” x 3” x 2”(w/o lens)
330g/0.73lbs
Certificates
CE, FCC
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance 1.3 Megapixel IP Box Cameras
EAN900
1.3 Megapixel, H.264, Box Network Camera
Series
Features
1.3 Megapixel IP Cameras
Software Partners:
Specifications
•  1.3 Megapixel, 1/3” progressive scan CMOS sensor
with high sensitivity
•  Built-in H.264, MPEG-4 and M-JPEG digital signal
output at 1280x1024 image size with up to 15fps
•  H.264 / MPEG-4 / M-JPEG multi stream output for
simultaneous live monitoring and high resolution
recording
•  Power over Ethernet (PoE) IEEE 802.3af
•  True Day/Night function with removable IR cut
filter User-friendly Smart Event Wizard for Event/
Schedule/Alarm recording to PC or SD Card
•  Triggered Alarm when motion is detected
•  Email notification or FTP video upload upon motion
detection and alarm
•  Built-in SD memory card slot for local storage and
support SDHC
Pickup Device
Picture Elements
Sensitivity
Day & Night
Lens Type
Video Output
Compression Format
Max. Video Resolution
Video Quality
Frame Rate
Microphone
Operation Mode
Interface
Supported Protocols
RS-485
Power Source
Built-in *
Two-way audio
10Base-T/100Base-TX auto-negotiation, RJ-45 socket
Support MDI / MDI-X auto crossover function HTTP, TCP/IP, UDP, RTP,
RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
1/1
RS-485 interface half-duplex
Alarm input, Manual trigger, Motion detection and Schedule recording
Trigger alarm output, Send mail notification, Upload video to FTP,
Record video to SD card, Record video to PC and Network alarm
48MB RAM reserved for pre-alarm record up to 120 sec.
Secure Disk physical layer specification version 2.0
Support SDHC Host Specification
12VDC & PoE
Power Consumption
4.5W max. (12VDC)
Operating Temperature
Humidity
550g/1.102lbs
68 x 57 x 136mm / 2.7" x 2.2" x 5.4"
with BNC socket: 68 x 57 x 146mm / 2.7" x 2.2" x 5.7"
0°C~40°C / 32°F~104°F
< 90% no condensing
CE, FCC, UL
57mm/2.2”
Certificates
49mm/1.9”
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Up to 15fps in 1280x1024
Yes (PoE 802.3af 48VDC)
Dimensions (W x H x D)
10mm/0.4”
1280 x 1024
8 levels adjustable
Power over Ethernet
Weight
Megapixel Network Camera
H.264 / MPEG-4 / M-JPEG
32 simultaneous clients
Alarm Input/Output
SD Card
68mm/2.7”
BNC socket, composite 1Vp-p, 75Ω
Min. 64 kbps adjustable
Pre-and Post-alarm Buffer
13mm/0.5”
True Day/Night with ICR module
Optional C / CS mount, manual / DD control supported
Max. Client Limit
Notification
136mm/5.4”
1280 x 1024
0.5 Lux/F=1.2
Bandwidth Control
Event Trigger
Dimensions
1/3” Progressive scan CMOS 1.3 Megapixel
* All product specifications are subject to change without notice
13
IP Surveillance Nevio Series IP Outdoor Dome Cameras
EDN850H
560 TVL, IP66, True Day/Night,
Outdoor Network Dome Camera
Series
Nevio Series IP Cameras
Software Partners:
Features
Specifications
•  Multi stream output at 4CIF resolution @ 30fps
•  H.264 / MPEG-4 / M-JPEG multi stream output for
simultaneous live monitoringand high resolution
recording
•  True Day/Night function with ICR module
•  Built-in DNR (Dynamic Noise Reduction) for noise
reduction and a 70% saving of Disk storage
•  The starlight Super-high sensitivity of 0.002 Lux/
F=1.2 is achieved by setting
•  SENS-UP Slow Shutter 128x max
•  Built-in Vari-Focal lens
•  Power over Ethernet (PoE) IEEE 802.3af
•  Support MDI/MDI-X auto crossover
•  Smart Wizard settings for varied Event and schedule
recording
•  Built-in SD memory card slot for local storage and
support SDHC
•  Two-way Audio
•  Easy wall or ceiling installation
•  Vandal Resistant & Weatherproof IP66 rating
Pickup Device
Picture Elements
NTSC: 768 x 494 ; PAL: 752 x 582
0.002 Lux (SENS-UP 128x) ; 0.25 Lux/F=1.2
Sensitivity
Yes (with IR cut filter)
Day & Night
Vari-Focal Lens with Auto Iris (2.8~10mm)
Lens Type
BNC socket, composite 1Vp-p, 75Ω
Video Output
560 TVL
Video Output Resolution
Compression Format
Max. Video Resolution
H.264 / MPEG-4 / M-JPEG
4CIF, VGA,CIF, QVGA, QCIF
8 levels adjustable
Video Quality
Frame Rate
Up to 30fps
Audio Input
3.5mm stereo socket, sensitivity 1 Vrms
Audio Output
3.5mm stereo socket, sensitivity 1 Vrms
Compression
Method IMA ADPCM (Pulse Code Modulation)
Operation
Mode Two-way audio
Interface
10Base-T/100Base-TX auto-negotiation, RJ-45 socket
MDI / MDI-X auto crossover function
Support
Supported Protocols
Bandwidth Control
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
Min. 64 kbps adjustable
Max. Client
Limit 32 simultaneous clients
Alarm Input
1 x input for dry contacts, Normal Open / Normal Closed adjustable
Alarm Output
Event Trigger by
1 x dry relay contact, Normal Open / Normal Closed adjustable,
70 VDC/200 mA max
Alarm input, Manual trigger, Motion detection and Schedule recording
Trigger alarm output, Send mail notification, Upload video to FTP,
Notification
Dimensions
1/3” Sony Super HAD Interlaced CCD
Record video to SD card, Record video to PC and Network alarm
Pre-and Post-alarm Buffer
Secure Disk physical layer specification version 2.0
SD Card
Supports SDHC Host Specification
Power Source
127mm /5.0”
48MB RAM reserved for pre-alarm record up to 120 sec.
12VDC & PoE
PoE
Yes (PoE 802.3af)
Power Consumption
5W max. (12VDC)
Weatherproof Ratings
IP66
Dimensions (O.D. x H)
127 x 112.8mm/5.0" x 4.44"
CE, FCC
Certificates
112.8mm/4.44”
14
* All product specifications are subject to change without notice
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance Nevio Series IP Outdoor IR Bullet Cameras
EZN850
560 TVL, True Day/Night, Weatherproof,
IR Network Bullet Camera
Series
Features
Nevio Series IP Cameras
Software Partners:
Specifications
•  Built-in H.264, MPEG-4 and M-JPEG multi stream
outputs at 4CIF image size with up to 30 fps
•  SENS-UP shutter technology 128x
•  Support 4 independent video streams that can
provide different compression formats and
resolutions for simultaneous live monitoring and
high resolution recording
•  Built-in external adjuster control for 6~50mm auto
iris lens (zoom and focus). Lens control is available
through web browser
•  True Day/Night function with removable IR cut filter
•  IR distance up to 50 meters (about 164ft.) with
Vari-Frequency IR control
•  Smart Wizard settings for various event
management and schedule recording
•  Built-in SD memory card slot for local storage and
support SD High Capacity
•  Motion detection and privacy area function
•  Vandal proof and IP66 weatherproof
Pickup Device
Picture Elements
Sensitivity
True Day/Night with removable IR cut filter
Lens Type
Vari-focal 6~50mm lens (9x optical zoom)
Video Output
Video Output Resolution
IR Distance
560 TVL
50m/164 feet
850nm
IR LED Lifespan
20,000 hours
Video Compression
Video Resolution
Video Quality
Frame Rate
Interface
Supported Protocols
Bandwidth Control
Max. Client
RS-485
Alarm Input/Output
H.264 / MPEG-4 / M-JPEG
4CIF, VGA, QVGA, QCIF
8 level adjustable
Up to 30fps
10Base-T/100Base-TX auto-negotiation, RJ-45 socket Support MDI /
MDI-X auto crossover function
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, FHCP, DNS, DDNS, NTP
Min. 64 kbps adjustable
32 simultaneous clients
RS-485 interface half-duplex
1x1
Power Output
DC12V for external IR illuminator
Event Trigger
Alarm input, Manual trigger, Motion detection and Schedule recording
Power
Consumption
Weatherproof Ratings
Vandal Resistant
Operating Temperature
Humidity
Secure Disk physical layer specification version 2.0
Supports SDHC Host Specification
2 types: 24VAC ; 100~240VCA
24VAC: 28W max. (Heater/ON & IR LED/ON);
100VAC~240VAC: 8W max. (Heater/ON & IR LED/ON)
IP66
Yes
-40°C~50°C / -40°F~122°F
<90%, not condensing
Heater
Yes
Weight
2.5kg/5.5lbs (3.0kg/6.6lbs with bracket)
Dimensions (W x H)
115 mm / 4.5”
Certificates
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
BNC socket, composite 1Vp-p, 75Ω
IR Wavelength
Power Source
295 mm / 11.8”
0.002 Lux/F=1.2 (IR Off, SENS-UP 128x) ; 0 Lux (IR On)
Day & Night
SD Card
Dimensions
1/3” Sony Super HAD CCD
NTSC: 768 x 494 ; PAL: 752 x 582
295 x 115 mm / 11.8" x 4.5"
CE, FCC, UL
* All product specifications are subject to change without notice
15
IP Surveillance Nevio Series IP Box Cameras
EAN850A
560 TVL, Super Low Lux Network Camera
Series
Nevio Series IP Cameras
Software Partners:
*Lens sold separately
Features
Specifications
•  Built-in H.264, MPEG-4 and M-JPEG digital signal
output at 4CIF image size with up to 30fps
•  H.264 / MPEG-4 / M-JPEG multi stream output for
simultaneous live monitoring and high resolution
recording
•  Support 4 independent video streams that can
provide different compression formats and
resolutions
•  Power over Ethernet (PoE) IEEE 802.3af
•  Built-in DNR (Dynamic Noise Reduction) for noise
reduction and a 70% saving of Disk storage
•  The starlight Super-high sensitivity of 0.002 Lux/
F=1.2 is achieved by setting SENS-UP Shutter X128
•  Bandwidth control:64k/128k/256k/1M/2M/4M/8M
bps and unlimited
•  Built-in network interface (10Base-T/100Base-TX)
for remote monitoring by PC
•  Support MDI/MDI-X auto crossover function
•  Smart Wizard settings for varied Event and schedule
recording conditions
•  Built-in SD memory card slot for local storage and
support SD High Capacity
•  Two way audio
Pickup Device
Picture Elements
Sensitivity
Day & Night
True Day/Night with ICR module
Lens Type
Optional C / CS mount, manual / DD control supported
Video Output
Compression Format
Max. Video Resolution
Video Quality
Frame Rate
Event Trigger
16
Two-way audio
Alarm input, Manual trigger, Motion detection and Schedule recording
Trigger alarm output, Send mail notification, Upload video to FTP,
Notification
Record video to SD card, Record video to PC and Network alarm
Pre-and Post-alarm Buffer
Interface
48MB RAM reserved for pre-alarm to 120 sec.
10Base-T/100Base-TX auto-negotiation, Rj-45 socket Support MDI /
MEI-X auto crossover function
Supported Protocols
Bandwidth Control
Max. Client Limit
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
Min. 64 k Byte / sec. adjustable
32 simultaneous clients
Alarm Input/Output
RS-485
Secure Disk physical layer specification version 2.0
Supports SDHC Host Specification
5W max. (12VDC)
500g/1.102lbs
68 x 57 x 136mm / 2.7" x 2.2" x 5.4"
with BNC socket: 68 x 57 x 146mm / 2.7" x 2.2" x 5.7"
0°C~40°C / 32~°F~104°F
< 90% not condensing
CE, FCC, UL
57mm/2.2”
Certificates
12 VDC & PoE
Yes (PoE 802.3af 48VDC)
Operating Temperature
Humidity
1/1
RS-485 interface half-duplex
Dimensions (W x H x D)
10mm/0.4”
8 level adjustable
Built-in
Operation Mode
Weight
Megapixel Network Camera
4CIF, VGA,CIF, QVGA, QCIF
Up to 30fps
Power Consumption
68mm/2.7”
560 TVL
H.264 / MPEG-4 / M-JPEG
Microphone
PoE
13mm/0.5”
BNC socket, composite 1 Vp-p, 75Ω
Video Output Resolution
Power Source
136mm/5.4”
NTSC: 768 x 494/PAL: 752 x 582
0.002 Lux (SENS-UP X128) ; 0.25 Lux/F=1.2
SD Card
Dimensions
1/3” Sony Super HAD Interlaced CCD
49mm/1.9”
* All product specifications are subject to change without notice
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance Nevio Series IP Indoor Dome Cameras
EDN800
520 TVL, True Day/Night, Vandalproof,
Network Dome Camera
Series
Features
Nevio Series IP Cameras
Software Partners:
Specifications
•  Built-in H.264, MPEG-4 and M-JPEG digital signal
output at 4CIF image size with up to 30fps
•  H.264 / MPEG-4 / M-JPEG multi stream output for
simultaneous live monitoring and high resolution
recording
•  Support 4 independent video streams that can
provide different compression formats and
resolutions
•  The high sensitivity of 0.4 Lux/F=1.2 is achieved by
using the advanced 1/3" Sony Super HAD CCD
•  Built-in Vari=focal Lens
•  Power over Ethernet (PoE) IEEE 802.3af
•  Support MDI/MDI-X auto crossover function
•  Bandwidth control:64k/128k/256k/1m/2m/4m/8m
bps and unlimited
•  Built-in network interface (10Base-T/100Base-TX)
for remote monitoring by PC
•  Smart Wizard settings for various event and
schedule recording conditions
•  Built-in SD memory card slot for local storage and
support SD High Capacity (SDHC)
•  Built-in digital motion detection
Pickup Device
Picture Elements
Sensitivity
Day & Night
Lens Type
Video Output
Video Output Resolution
Compression Format
Max. Video Resolution
Video Quality
Frame Rate
Interface
Supported Protocols
Yes
Vari-Focal Lens (3.7~12mm)
BNC socket, composite 1 Vp-p, 75Ω
520 TVL
H.264 / MPEG-4 / M-JPEG
4CIF, VGAL,CIF, QVGA, QCIF
8 levels adjustable
Up to 30fps
10Base-T100Base-TX auto-negotiation, RJ-45 socket Support MDI /
MDI-X auto crossover function
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
Min. 64 kbps adjustable
Max. Client
32 simultaneous clients
Alarm Input/Output
Event Trigger
Notification
Pre-and Post-alarm Buffer
SD Card
1x1
Alarm input, manual trigger,
Motion detection and Schedule recording
Trigger alarm output, Send mail notification, Upload, Video to FTP,
Record video to SD card, Record video to PC and Network alarm
48MB RAM reserved for pre-alarm record up to 120 sec.
Secure Disk physical layer specification version 2.0
Supports SDHC Host Specification
12 VDC & PoE
Power over Ethernet
Yes (PoE 802.3af)
Power Consumption
5W max. (12VDC)
Weight
Dimensions (O.D x H)
127mm /5.0”
0.4 Lux/F=1.2
Bandwidth Control
Power Source
Dimensions
1/3” Sony Super HAD CCD
NTSC: 768 x 494 ; PAL: 752 x 582
550g/1.213lbs
127 x 113mm / 5.0" x 4.5"
Operating Temperature
0°C~40°C / 32°F~104°
Humidity
<90%, not condensing
Vandal Resistant
Certificates
Yes
CE, FCC, UL
113mm/4.5”
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
17
IP Surveillance Nevio Series IP Box Cameras
EAN800A/EAN800AW
520 TVL, H.264, True Day/Night Advanced Network Camera
Series
Nevio Series IP Cameras
Software Partners:
*Lens sold separately
Features
Specifications
•  Built-in H.264, MPEG-4 and M-JPEG digital signal
output with up to 30 EPS at 4CIF (704 x 480)
•  Support H.264 / MPEG-4 / M-JPEG triple stream for
simultaneous live, monitoring and high resolution
recording
•  Power over Ethernet (PoE) IEEE 802.3af
•  Support MDI/MDI-X auto crossover function
•  Equipped with Smart Event Wizard for Motion
Detection, Schedule, and Alarm recording to PC or
SD Card
•  Email notification or FTP video upload upon motion
detection and alarm
•  Built-in SD memory card slot for local storage and
support SD High Capacity
•  Manage AGC, BLC, FL, ES, H-Mirror, IRIS Level and
Day/Night via web browser
•  Two way audio
•  Built-in IEEE 802.11b/g for wireless module
(EAN800AW)
Pickup Device
Picture Elements
Sensitivity
NTSC: 768 x 494/PAL: 752 x 582
0.4 Lux/F=1.2
Day & Night
Yes
Lens Type
Optional C / CS mount, manual / DD control supported
Video Output
BNC socket, composite 1Vp-p, 75Ω
Video Output Resolution
Compression Format
Max. Video Resolution
Video Quality
Frame Rate
520 TVL
H.264 / MPEG-4 / M-JPEG
4CIF, VGA,CIF, QVGA, QCIF
8 levels (adjustable)
Up to 30fps
Microphone
Built-in*
Operation Mode
Two-way audio
10Base-TX auto-negotiation, RJ-45 socket Support MDI/MDI-X auto
Interface
crossover function
Supported Protocols
Bandwidth Control
Max. Client Limit
Built-in IEEE 802.11b/g WLAN (EAN800AW) HTTP, TCP/IP, UDP, RTP,
RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
Min. 64 kbps adjustable
32 clients simultaneously (max).
Alarm Input/Output
RS-485
1/1
Rs-485 interface half-duplex
Event Trigger
Alarm Input, Manual Trigger,
Motion Detection and Schedule Recording
Trigger alarm output, Send mail notification, Upload video to FTP,
Notification
Record video to SD card, Record video to PC and Network alarm
Pre-and Post-alarm Buffer
Dimensions
1/3” Sony Super HAD Interlaced CCD
48MB RAM reserved for pre-alarm record up to 120 sec.
Secure Disk physical layer specification version 2.0
SD Card
Supports SDHC Host Specification
Power Source
PoE
12VDC & PoE
Yes (PoE 802.3af 48 VDC)
Power Consumption
Weight
EAN800A: 5W max. (12VDC) EAN800AW: 6.5W max. (12VDC)
550g/1.102lbs
68 x 57 x 136mm 2.7" x 2.2" x 5.4"
Dimensions (W x H x D)
136mm/5.4”
with Antenna: 68 x 125 x 167mm / 2.7" x 4.9" x 6.6"
13mm/0.5”
Operating Temperature
Humidity
0°C~40°C / 32°F~104°F
< 90% not condensing
CE, FCC, UL
7mm/0.3”
57mm/2.2”
Certificates
1.3 Megapixel Network Camera
with BNC socket: 68 x 57 x 146mm / 2.7" x 2.2" x 5.7"
18
* All product specifications are subject to change without notice
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance EPN Series IP Speed Dome Cameras
EPN IP Speed Dome Series
520 TVL/530 TVL, 33x/36x Optical Zoom,
Auto Tracking, High Speed Pan & Tilt,
Network Speed Dome Camera
Series
Features
Nevio Series IP PTZ Cameras
Outdoor
Indoor
Specifications
•  Support smart auto tracking functions
•  Built-in H.264 / MPEG-4 / M-JPEG digital signal
output at 4CIF image size with up to 30fps
•  H.264 / MPEG-4 / M-JPEG multi stream output for
simultaneous live monitoring and high resolution
recording
•  Support 3 independent video streams that can
provide different compression formats and
resolutions
•  Support MDI/MDI-X auto crossover function
•  Bandwidth control: 64k/128k/256k/1M/2M/4M/8M
bps and unlimited
•  Built-in network interface (10Base-T/100Base-TX)
for remote monitoring by PC
•  Smart Wizard settings for various event and
schedule recording conditions
•  One-click easy installation
•  Built-in 33x/36x optical AF zoom camera
•  True Day/Night function with removable IR cut filter
•  Low luminance for better image quality at night
•  Smart alarm reaction & resume after alarm
•  Enhanced auto-resume & power-up function
•  Digital Flip function
Model Name
EPN3100
EPN3100i
EPN3600
EPN3600i
(Outdoor)
(Indoor)
(Outdoor)
(Indoor)
1/4" Sony CCD
Pickup Device
1/4" Sony Ex-View HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525 TVL, 60 fields/sec.; PAL: 625 TVL, 50 fields/sec.
Picture Elements
NTSC: 768 x 494; PAL: 752 x 582
520 TVL
530 TVL
Normal: 0.4 Lux/F1.6
Normal: 1.4 Lux/1/60(1/50)seс.
Horizontal Resolution
Min. Illumination
Night Mode: 0.08 Lux/F1.6
Night Mode: 0.01 Lux/1/4 (1/3)seс.
(ICR ON)
(ICR ON)
50dB
S/N Ratio (AGC OFF)
Electronic Shutter
1~ 1/10,000 (s)
1/120,000 (s) (NTSC)
128x
Digital Slow Shutter
Shutter Selection
50dB
128x~1/60 (1/50)~
60x (50x for PAL)
AUTO; A.FLK; Manual
AUTO; A.FLK;
128x~1/60 (1/50)~1/120,000
Manual 1~1/10,000 selectable
selectable
Lens Type
Zoom Ratio
33x optical zoom, f=3.3mm
36x optical zoom, f=3.4mm
(wide)~99mm (tele), F1.6~F3.2
(wide)~122.4mm (tele), F1.6~F4.5
264x max
432x max
(33x Optical and 8x Digital zoom)
(36x Optical and 12x Digital zoom)
Picture Compression
H.264 / MPEG-4 / M-JPEG
4CIF, VGA,CIF, QVGA, QCIF
Picture Resolution
NTSC: 720 x 480, 640 x 480, 352 x 40, 320 x 240, 176 x 144;
PAL: 720 x 576, 640 x 480, 352 x 288, 352 x 288, 176 x 144
Dimensions
Streaming Frame Rate
Focus Control
Iris Control
True Day & Night
Indoor Model
Outdoor Model
Certificates
1~30 IPS (NTSC), 1~25 IPS (PAL) adjustable
One Push/Auto/Manual
Auto/Manual
Yes (Auto/Day/Night)
CE, FCC, UL
159mm/6.3”
230mm/9.1”
280mm/11”
Software Partners:
180mm/7.1”
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
19
PowerFocus CMS Central Management Software for Network Video Recording
PowerFocus CMS
Central Management Software
for Network Video Recording
NEW
PowerFocus CMS
for Network Video Recording
Features
•  Compatible with all of EverFocus IP cameras
•  Support remote configuration of EverFocus Nevio /
Nevio HD series IP cameras, Video Encoders
•  Multiple monitor display with up to 64 IP cameras
•  Bit rate display for overall usage and per camera
stream helps manage bandwidth utilization
•  Customized layout tool, easily add and merge your
own style layout of management
•  Intelligent playback search engine, up to 128x or
1/64 forward searching speed, find your desired
section immediately and precisely
•  Built-in internal converter tool, directly output to
Windows Media Video (WMV) format, save your
second converting time
•  Support EverFocus EKB200 joystick control
•  Smart Camera Network Loss Alarm
•  Easy PTZ control and configure your EverFocus
speed dome
•  E-map for all devices visualized management
•  Real-time Digital Zoom, quickly catch your desired
area
•  Easily image switch and duplicate
•  Support advanced water mark, protect your
converted video copy
•  Energy saving function reduces your computer
loading
•  Motion detection with alarm pop up
•  SMTP mail notice support Gmail, Yahoo and Hotmail
•  Support multiple camera groups
•  Advance event and action settings
System Requirements
Specifications
System
CPU
RAM
Recommend
Minimum
Intel Core i5-2400
Intel Core 2 Duo E6300
4GB
2GB
8GB recommended for larger systems
Display
Graphics card with DirectX 9.0c; video memory of 512MB or above
Ethernet
Gigabit Ethernet
Hard Disk
80GB or above (2.1G Free space required)
Windows XP, Windows Vista, Windows 7 (32,64 bit support)
Microsoft.Net runtime environment (included in installation package)
OS
*Performance varies depending on equipments used and subject to actual test result.
20
* All product specifications are subject to change without notice
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
PowerFocus CMS Central Management Software for Network Video Recording
PowerFocus CMS
Central Management Software
for Network Video Recording
PowerFocus CMS
Presentative User Interface
Intuitive Icon
No more menu trees, intuitive button instead.
Smart Zoom
Digital Zoom your desired area by scrolling your mouse wheel.
Zoom In
E-map
E-map for all devices visualized management.
Zoom Out
Customized layout tool
Customized layout tool, easily add and merge your own style layout of
management.
Practical Technology
Energy Saving Mode
Save up to 80% display image computing for adding more camera
image source.
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Video Wall
Support multiple monitors to build up video wall with 64 cameras.
* All product specifications are subject to change without notice
21
NVR Software Network Management Software
NVR Software
NVR Surveillance Management Software
NVR Software
Features
•  Support EverFocus NeVio series IP cameras, megapixel
cameras, 3rd party video encoders/IP cameras and more
•  Accepts MPEG-4 / M-JPEG / H.264 video formats
•  Remote PTZ operation and supports PTZ reaction presets
•  Multiple monitor display with up to 64 cameras in Live View
and up to 16 cameras in Playback View
•  Local view with 1 or (optional) 2 monitors for Live View plus
(optional) 1 monitor dedicated for simultaneous Playback
View
•  Remote Live View with 1 or (optional) 2 monitors (or 1
monitor for Playback View only)
•  Smart detection of many types of camera, input, POS and
system events, with 10 potential instant alarm responses
(example, email alert and E-map popup)
•  Complete I/O device integration
•  Intelligent playback system with 5 video analytic searches
•  Remote client live viewer, playback, backup, I/O control and
remote desktop operation
•  Joystick support on PTZ cameras and software enabled
digital PTZ function are both available
•  Preset points and patrol functions are also available on
many camera models
•  User friendly graphical user interface (GUI) with camera
drag and drop for setup and recording, familiar to all users
with basic PC knowledge
•  Audio and video recording synchronization
•  Watermark capability
•  Resource Management tool can monitor system resources
and trigger instant alarm notifications
•  DDNS functionality
•  3 GPP / PDA / Mobile Handy Viewer support
•  Remote I/O control
•  Video enhancement tools t fine tune the image’s visibility,
sharpness, brightness, contrast or even grey scale
•  Export to AVI or ASF file format
•  Take a snapshot of the recording in BMP or JPEG format to
print or file
•  Back up video images to USB drives, CD/DVD or hard disk
drives
•  Schedule recording can be set by day, week or repeating
interval
•  Intelligent Search recognizes 5 different special events
(general motion, missing object, foreign object, camera
occlusion and signal lost) in recorded files, in addition to
searches by date, time and log file
•  Counting application with direction for certain objects or
areas
•  Bit rate display for overall usage and per camera stream
helps manage bandwidth utilization
•  Unusual events are recorded to the system log, and
counting application results can be exported to an Excel or
text for analysis
Specifications
IP Camera Inputs*
IP Cameras Supported
Digital PTZ
Up to 64 (depending on licenses purchased)
*Models vary. Contact EverFocus for exact list of supported models
EverFocus NeVio and other IP cameras in addition to 3rd party video
encoders and IP cameras
Supported in live view and playback
Multiple View
Triple Monitor
Audio Recording
Screen Layout
Compression Format
Recording Type
Playback Channels
Playback Control
Auto Overwrite
Additional I/O Functions
POP Input
Zoom function preserves live view by duplicating the same video feed
onto multiple channels in different areas
Up to 64 love camera views each on two monitors in addition to
displaying playback video on a separate monitor
Synchronized with video on each channel
Single, 6,10 &13 plus NxN up to 64 cameras (16 on playback)
H.264 / MPEG-4 / M-JPEG SUPPORTED
Continuous, digital input trigger, on motion detection, on event manual
and per schedule
Up to 16 channels max. displayed
Forward / reverse step and play fast (to 16x) and slow (to 1/16x)
Oldest recordings recycled when disk is full
Optional expansion module
Optional POS interface serial data to Ethernet
Chinese (Simplified & Traditional), Czech, Danish, English, Farsi,
Supported Language
Finnish, French, German, Greek, Hebrew, Hungarian, Italian, Japanese,
Korean, Portuguese (Brazil), Portuguese (Portugal), Russian, Slovak,
Spanish
*Performance varies depending on equipments used and subject to actual test result.
22
* All product specifications are subject to change without notice
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
IP Accessories H.264 Video Encoder
EVS410
4 Channels H.264 Video Encoder
NEW
Series
IP Accessories
Features
Specifications
•  Dual Codec for H.264 and M-JPEG in 30fps frame
rate in all resolutions
•  H.264 / M-JPEG dual stream output and
independent video stream configuration from each
channel for simultaneous live monitoring and high
resolution recording
•  Built-in high performance 3D de-noise and deinterlacer engines to reduce noise artifacts, increase
S/N ratio, and covert videos from interlace to
progressive
•  Smart Wizard settings for varied event and schedule
recording
•  Support PTZ camera control via RS485
•  Built-in slot for an SDHC card enables local event
or backup recording in the event of network
interruptions
•  Two-way Audio
Video Compression
Video Resolution
Video Quality
Frame Rate
Video Source
Compression Method
VBR: 5 level adjustable, CBR: 256Kbps~3Mbps
Up to 30fps
4 BNC composite, 1 V p-p, 75Ω
NTSC/PAL auto-sense
G.711 PCM 8 kHz
Audio Input
1 Vrms ; 3.5mm phone jack; Mono
Audio Output
1 Vrms ; 3.5mm phone jack; Mono
Operation Mode
Interface
Supported Protocols
Two-way audio
10Base-T/100Base-TX auto-negotiation, RJ-45 socket
Support MDI/MDI-X auto crossover function
TCP/IP,UDP,ICMP,DHCP,NTP,DNS,DDNS,SMTP,SNMP,FTP,HTTP,HTTPs,PP
PoE, UPnP,Bonjour,RTP,RTSP,RTCP,UDP,IGMP,ICMP,ARP,ONVIF,PSIA
Alarm Input/Output
4/1
RS485
Yes
Event Trigger
Notifications
Pre- and Post- alarm buffer
SD Card
Power Supply
Power Consumption
Weight
Dimensions (W x H x D)
Dimensions
H.264 / M-JPEG
704*480(576)/640x480/352*240(288)/320x240/176*112(144)
Operating Temperature
Humidity
Certificates
Alarm input, Manual trigger, Motion detection, Video loss, Tampering
detection and Schedule recording
Trigger alarm output, Send mail notification, Upload video to FTP,
Record video to SD card, Record video to PC and Network alarm
40MB
Secure Disk physical layer specification version 2.0
Supports SDHC Host Specification
12 VDC
36W max.
665g/1.47lbs
13 x 38.4 x 164.4mm / 5.2” x 1.5” x 6.5”
0°C ~50°C / 32°F~122°F
(20%~80% Humidity)
CE, FCC
164.4mm/6.5”
121mm/4.8”
153mm/6”
131mm/5.2”
38.4mm/1.5”
111mm/4.4”
102mm/4”
25.5mm/1”
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
23
IP Accessories H.264 Video Encoder
EVS200A/EVS200AW
2 Channels H.264 Video Encoder
Series
IP Accessories
Software Partners:
Features
Specifications
•  High quality H.264, MPEG-4 and M-JPEG multi
stream output at 4CIF resolution @60fps
•  H.264 / MPEG-4 / M-JPEG dual stream output per
channel for simultaneous live monitoring and high
resolution recording
•  Smart wizard settings for varied event and schedule
recording
•  Support PTZ control
•  Built-in SD memory card slot for local storage and
support SDHC
•  Two-way audio
•  Power over Ethernet (PoE) IEEE 802.3af
•  Ultra-compact size for space-saving applications
Video Compression
Video Reslolution
Video Quality
8 levels adjustable
Frame Rate
Up to 30fps
Video Source
2 BNC composite, 1Vp-p/75Ω NTSC/PAL auto-sense
Compression Method
Operation Mode
IMA ADPCM (Pulse Code Modulation)
2 way audio
10Base-T/100Base-TX auto-negotiation,
Interface
Supported Protocols
RJ-45 socket Support MDI / MDI-X auto crossover function
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
Bandwidth Control
Min. 64 kbps adjustable,
Max. Client Limit
32 simultaneous clients
Standard
IEEE 802.11b/g
Antenna Gain
2 dBi
Alarm I/O
2/2
Serial Connector
RS485
Event Triggered
Alarm input, Manual trigger, Motion detection and Schedule recording
Trigger alarm output, Send mail notification, Upload video to FTP,
Notification
Pre-and Post-Alarm Butter
Record video to SD card, Record video to PC and Network alarm
48MB RAM reserved for pre-alarm record up to 120 sec
Secure Disk physical layer specification version 2.0
SD Card
Supports SDHC Host Specification
12 VDC
Power Supply
Dimensions
H.264 / MPEG-4 / M-JPEG
4CIF, VGA,CIF, QVGA, QCIF
Power over Ethernet
Yes (PoE 802.3af)
Power Consumption
4.5w max. (12VDC)
Certificates
CE, FCC
38.2mm/1.5”
117mm/4.6”
24
* All product specifications are subject to change without notice
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Accessories Network Video Recorder Server
NVR PLUS
NEW
High Performance
Network Video Recorder Server
Specifications
•  Built-in Intel i7-860 High Performance Processor
with Hyper-Threading Technology
•  Up to 16GB DDR3-1333 (8GB Installed)
•  Industrial Grade NVR Designed
•  Dual Gigabit LAN supports 10/100/1000Mbps
•  Independent 1G DDR3 Graphic Card support Dualmonitor with one DVI-I, one D-SUB and one HDMI
port
•  HDD capacity: 4 x 3.5” SATA HDD with RAID 0, 1, 5,
10
•  2U Height Rack Mount Chassis
•  Windows Embedded Std 7
•  Full Win32® API and .NET application compatibility
•  2-year Warranty
Video Compression
Maximum Supported Number
of Channels
H.264 / MPEG-4 / M-JPEG
Ethernet
64 channels
(subject to image setting & quality)
10/100/1000Mbps
Display
1x DVI-I / 1x D-SUB / 1x HDMI port
USB
Serial port (RS-32)
Audio
Storage
Power Input
Chassis Construction
OS
Operating Temperature
Storage Temperature
Dimensions (W x H x D)
Color
Mouting
Certificates
IP Accessories
Features
6* USB2.0
2* RS-232
2 (Mic-in, Line-out)
Up to 4 Disks
100~240VAC (Full Range)
Heavy Duty Metal
Windows Embedded Std 7
0~40°C / 32~104°F
10~85% @ 40°C, non-condensing
-20~60°C / -4~140°F
10~95% @ 40°C, non-condensing
482 x 88 x 480mm/18.98" x 3.46" x 18.9"
Black
Rack Mount
CE, FCC
Dimensions
Left View
87.2mm/3.43”
523.9mm/20.63”
426.4 mm/16.79”
479.4mm/18.87”
Front out-side View
88.0mm/3.46”
44.4 mm/1.75”
Rear out-side View
Front in-side View
465.1mm/18.31”
482.0mm/18.98”
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
25
IP Accessories Network Video Recorder Server
NVR-202/NVR-204
NEW
2CH / 4CH embedded NVR with 2 HDD Bay
IP Accessories
Features
Specifications
•  Linux embedded – free from PC crash and virus
attack
•  Support 30+ brands of IP cameras and 900+ models
•  Support panomorph PTZ (360°)
•  Support mobile client - iPhone, iPad, Android
•  Alarm source of Central Management System
•  Support megapixel camera recording and H.264
compression format
•  Server-client architecture
•  Web-based management (IE7 and later versions)
•  Online GUI schedule recording
•  Multiple camera streams for low bandwidth remote
viewer
•  Support E-map with device indicator
•  Playback system with 5 intelligent search
•  Remote I/O solution and camera I/O integration
•  Built in RAID 0,1 function
Model Name
NVR-202
Number of Channels
Compression Format
Ethernet
NVR-204
2
4
MPEG-4, M-JPEG, H.264, MxPEG (depends on IP camera)
10/100/1000Mbps
USB
2 USB 2.0 (on Back Panel)
Recording Rate
Mobile View Support
Audio Recording
Storage
Max. 40Mbps, 60fps @ 1.3M
Max. 40Mbps, 120fps @ 1.3M
Support apps for iPhone, iPad, Android
Synchronized Audio and Video recording
2 SATA II HDD bay
Supported Language
Recording Modes
Remote Live View Control
Playback Search
OS
English, Japanese, Traditional Chinese, Spanish, Deutsch, Finnish,
French, Hungarian, Italian, Russian, Czech, Korean, Polish, Dutch,
Serbian, Swedish, Portuguese (Brazil)
Continuous record, record by schedule, event trigger record,
digital input trigger record
Live view, preset/go, PTZ, remote I/O, snapshot, multi-view,
digital PTZ, advanced E-Map, bandwidth monitoring
General motion, missing object, foreign object, lose focus,
camera occlusion
Embedded Linux
Operating Temperature
0°C~40°C / 32°F~104°F (20~80% humidity)
Dimensions (H x W x D)
140 x 109 x 219mm / 5.51” x 4.29” x 8.62”
Power Source
100~240VAC ,40W max
Certificates
CE, FCC
Dimensions
109mm / 4.29"
PWR
SYS
DISK 2
LAN 1
26
* All product specifications are subject to change without notice
140mm / 5.51"
USB
DISK 1
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Accessories Control Keyboard
EKB200
USB Control Keyboard with 3-Axis
Specifications
•  “Plug and play” USB interface
•  3-Axis joystick for PTZ control function
•  Support standard HID class device with high
compatibility
•  Industrial ID design
•  Long working life of industrial grade 3-axis joystick
•  4 pre-defined PTZ function keys: Iris+/-, Focus+/•  12 free assignable function keys
•  Panel mount kit available
•  No external power supply required
•  Suitable for right or left-handed users
•  Dedicated EverFocus JoyMap keymapper software
for standard Windows operation
•  Support standard HID class device, easy for 3rd
party integration
•  Supported by EverFocus PowerCon central
management software for easy PTZ operation
Interface
USB 1.1
PTZ Function Key
4 keys, Iris+, Iris-, Focus+, Focus-
Assignable key
12 keys
Default Protocol
USB HID class
Keymapper Support
EverFocus JoyMap
USB Cable (Length)
1.8m/6ft.
USB Cable (Color)
Black
Dimension (W × D × H)
200.5 × 200.5 × 111.3mm / 7.9” ×7.9” x 4.4” (with Joystick)
Weight
800g/1.94lbs
Operating Temperature
0˚C~50˚C / 32˚F~122˚F
Mounting Method
Desktop, Panel
Power Source
USB Bus Power
Power Consumption
80mA max.
Certificates
CE, FCC class A
System Examples
111.3mm/4.4”
58mm/2.3”
3mm/0.1”
Dimensions
7.9mm/0.3”
Accessories
Features
PowerFocus
NVR Software
130.6mm/5.2”
135.9mm/5.4”
200.5mm/7.9”
EKB200
200.5mm/7.9”
200.5mm/7.9”
EverFocus EPN IP Speed Dome Series
*Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
27
Index
Model Number
EAN800A/EAN800AW
EAN850A
EAN900
EAN2150
EAN3200
EAN2350
EAN2218
EDN800
EDN850H
EDN2245
EDN3240
EHN3200
EKB200
EPN2218/EPN2218i Speed Dome
EPN IP Speed Dome Series
EQN2200/2201
EVS200A/EVS200AW
EVS410
EZN3240
EZN850
NVR-202/NVR-204
NVR PLUS
NVR Software
PowerFocus CMS
28
* All product specifications are subject to change without notice
Page Number
18
16
13
12
8
3
9
17
14
5
4
6
27
10
19
11
24
23
7
15
26
25
22
20
MEMO
* All product specifications are subject to change without notice
29
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
