F
ounded in 1940 by Clayton Long and Art Moss, Valley Pipe & Supply Co. started as a
supplier of industrial pipe, valves, fittings and plumbing fixtures and supplies. With its
office in the center of the agricultural rich San Joaquin Valley, Fresno became a hub for
many food processing facilities, chemical plants, wineries, and OEM manufacturers. By the
mid 1960's the company became involved with several manufacturers of waterworks underground pipe, valves, fittings, and fire hydrants and established itself by supplying these items
to municipalities and contractors from Modesto to Bakersfield.
In 1966, one of the founders, Art Moss passed away leaving Clayton Long as the remaining
officer in the company. Mr. Long, needing help in day to day operations of the business that
had grown to 15 employees, brought his son Donald Long and Richard Ermoian into the
business as partners. In 1967 the company incorporated with Don and Dick becoming
corporate officers.
During the 1970's and 80's Valley Pipe & Supply continued to grow and expand and in 1989
negotiated to purchase the prints and patterns of winery pumps, 3-way must valves, PCT
fittings and machinery from long time Fresno business - Valley Foundry & Machine Works.
Shortly thereafter, a fabrication shop was added to continue the long tradition of supplying
quality products throughout North America.
In the early 1990's Don Long and Dick Ermoian retired and the third generation of the Long
family took over management of the company. Mitchell and Charles, both sons of Don Long,
have grown up in the business and assumed leadership roles as President & Treasurer.
By the mid 1990's Valley Pipe & Supply was looking to expand and moved into the Mexico
market opening a sales office in the state of Sonora. In 1999, a new branch location was
added in Napa, California to service its many customers throughout the wine industry in
Northern California and in 2001, a sales office was established in Niagara on the Lake,
Ontario, Canada.
Third Edition
VALLEY PIPE
&SUPPLY, INC.
WINERY and INDUSTRIAL SUPPLIES
Headquarters
1801 Santa Clara, Fresno, California 93721
Phone 559-233-0321 • Fax 559-233-1713 • Email: [email protected]
www.valleypipe.com
Napa
Phone 707-226-6427
International Sales’ Office
Mexico – Carborca, Sonora • Phone/Fax 6373727382
TABLE OF CONTENTS
Presses
Membrane presses ............................................................ 3
Basket presses .................................................................... 5
Tanks & Fermenters
Standard tanks.................................................................. 6
Automatic fermenters ....................................................... 7
Rotary fermenters ............................................................. 9
Crushers / Destemmers ................................................ 10
Filters
Filter cartridge housing .................................................. 11
Plate and frame ............................................................... 12
Combination ................................................................... 12
Horizontal screen DE...................................................... 13
Rotary drum.................................................................... 14
Crossflow.......................................................................... 14
Pumps
Flexible Impeller.............................................................. 15
Solid capacity centrifugal................................................ 15
Centrifugal transfer......................................................... 16
Air
................................................................................... 16
Must Pumps..................................................................... 17
Rotary lobe ...................................................................... 17
Progressive cavity ............................................................ 18
Piston................................................................................ 19
Dump Bins, Sorting Tables & Conveyors ............... 20
Tank Mixers ........................................................................ 22
Cooling plates.................................................................... 22
Custom Fabrication & Machining ............................ 23
Barrel Systems ................................................................... 24
Miscellaneous Equipment ........................................... 25
Instrumentation ............................................................... 26
Valves
Winery.............................................................................. 27
Industrial ......................................................................... 28
Hose......................................................................29
Fittings
Weld.................................................................................. 30
Tri-Clamp......................................................................... 31
I-Line ............................................................................... 32
Bevel................................................................................. 32
DIN................................................................................... 33
Garolla ............................................................................. 33
Miscellaneous................................................................... 33
Cam and Groove.............................................................. 34
PCT Hose Fitting............................................................. 35
Pipe & Tubing .................................................................... 36
Information .............................................. Inside Back Cover
TABLE OF CONTENTS
MEMBRANE PRESSES
Defranceschi
State of the art presses offer high quality components & workmanship with
reliability and optimum performance.
Main features include:
• Complete stainless steel frame construction.
• Domed ends allow gentler action on membrane during inflation and
vacuum process.
• Mirror polished inside with welds grinded flush and polished. This allows a
sanitary environment and ease of cleaning.
• Vertical slots to outside prevent sharp edges from damaging grapes
(open cage style).
• Closed cage presses can be used for maceration.
• PLC control board with keypad and display.
• Cremant cycle (Champagne program).
JP Series
MO Series
SLOTTED CAGE (OPEN) STYLE
18
22.5
30
40
JP
50
60
80
120
150
MO
200
300
Whole-Door
.9 - 1.3
1.1 - 1.7
1.5 - 2.2
1.9 - 2.9
2.2 - 3.2
2.6 - 3.9
3.5 - 5.2
5.1 - 7.5
7.5 - 11.2
10 - 15
15 - 22.5
Crushed-Door/Ax
3.6 - 4.5
4.5 - 5.6
6 - 7.5
7.8 - 9.7
6.7 - 13.5
8.1 - 16.2
10.8 - 21.6
15.5 - 31
30 - 37.5
40 - 50
60 - 75
Ferment-Door/Ax
5.7 - 7.2
7.2 - 9
9.6 - 12
12.5 - 15.6
15 - 22.5
18 - 27
24 - 36
34.5 - 51.7
48 - 60
64 - 80
96 - 120
Metric
Tons
Hectoliter
Vacuum pump (Hp)
1.4
1.4
1.4
1.4
2.9
4
4
5.3
5.3
5.3
2x 5.3
Rotation Motor (Hp)
1
1
1.4
1.4
2.9
2.9
4
5.3
7.3
7.3
12.3
Air Compressor (Hp)
2.9
4
5.3
5.3
10.4
10.4
12.3
Opt.
Opt.
Opt.
Opt.
Axial Valve*
4" M
4" M
4" M
4" M
5" M
5" M
5" P
5" P
5" P
5" P
5" P
Loading Door (in)
19.7x29.5
19.7x37.8
19.7x37.8
19.7x37.8
19.7x37.8
19.7x37.8
24.8x26.4
24.8x26.4
24.8x28.3
24.8x28.3
24.8x28.3
Juice Vat (gal)
121
153
153
185
79
79
132
132
132
150
225
Cage Spray Pipe
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Empty Wieght (lbs)
1807
1984
2469
2711
3960
4224
6160
8140
9479
11023
17636
*M=Manual, P=Pneumatic
3
PRESSES
MEMBRANE PRESSES
Defranceschi
JPc Series
CD Series
CLOSED CAGE STYLE
22.5
Whole-Door
1.1 - 1.7
1.5 - 2.2
Crushed-Door/Ax
4.5 - 5.6
6 - 7.5
7.8 - 9.7
6.2 - 12.4
8.1 - 16.2
9.9 - 19.9
14.4 - 28.8
30 - 37.5
46.7 - 63.5
55.5 - 81
Ferment-Door/Ax
7.2 - 9
9.6 - 12
12.5 - 15.6
13.8 - 20.7
18 - 27
22.1 - 33.1
32 - 48
48 - 60
79 - 102.5
98.5 - 131.7
Vacuum pump (Hp)
1.4
1.4
1.4
2.9
4
4
5.3
5.3
7.3
10
Rotation Motor (Hp)
1
1.4
1.4
2.9
2.9
4
5.3
7.3
10
14.7
Metric
Ton
Hectoliter
JP/CD
30
40
50
60
1.9 - 2.9
2-3
2.6 - 3.9
80
CD
120
150
250
320
3.2 - 4.8
4.7 - 6.9
7.5 - 11.2
12.2 - 18.2
15.1 - 22.5
Air Compressor (Hp)
4
5.3
5.3
10.4
10.4
12.3
Opt.
Opt.
Opt.
Opt.
Axial Valve*
4" M
4" M
4" M
5" M
5" M
5" P
5" P
5" P
5" P
5" P
Loading Door (in)
19.7x37.8
19.7x37.8
19.7x37.8
24.8x28.3
24.8x28.3
24.8x28.3
24.8x28.3
24.8x28.3
24.8x28.3
24.8x28.3
Juice Vat (gal)
153
153
185
85
85
106
106
198
225
225
Cage Spray Pipe
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Opt.
Empty Wieght (lbs)
2094
2645
2866
4409
4956
6393
8377
10582
14935
17637
*M=Manual, P=Pneumatic
JP/CD model door seals optional
CD model door seals
Options include:
• Normal/Reverse rotation of cage.
• Level probes and control for must pump.
• Leg extension kits
• Cold maceration system (CD models)
• Extra doors for faster loading/unloading. (CD models)
• Pneumatic axial feed valve for smaller models. (CD models)
• CO2 maceration kit. (CD models)
PRESSES
4
BASKET PRESSES
CEP
Vertical electric-hydraulic basket press mounted on wheels.Electrical
motor and control panel mounted on press.
Models:
Sirio – Traditional model with zinc-plated trolley and wooden basket
with coated iron bands.
Sirio C – Zinc-plated trolley and wood basket with stainless steel bands.
Sirio X – Zinc-plated trolley and basket made entirely of stainless steel
(Models 70 &80).
Options include:
• Extra trolley and basket.
• Pressing plate and trolley centering plates coated in stainless steel.
• Double hydraulic pumps.
• Nylon drainage disks and fabric filter bags.
MODEL
BASKET
CAPACITY
BASKET SIZE LENGTH X WIDTH X HEIGHT
Sirio 60
60 Gal.
2' x 2' 6"
Sirio 70
81 Gal.
2' 4" x 2' 6"
Sirio 80
126 Gal.
2' 8" x 3' 2"
Sirio 100
238 Gal.
3' 4" x 3' 7"
More sizes available up to 1296 gallons
4' x 2' 9" x 7'
5' 2" x 3' 9" x 7' 7"
5' 9" x 4' 1" x 8' 5"
6' 11" x 4' 5" x 9' 6"
BASKET PRESSES
Milani
Vertical automated hydraulic basket press.
• Large hydraulic ram creates an even pressure on the pressing plate that will
allow the liquid to filter through the grape pulp and prevents the liquid
from splashing outwards.
• Slotted stainless steel basket is protected on the outside with a transparent,
movable, accident prevention cylinder.
• Cage and safety cylinder are lifted simultaneously by two hydraulic rams to
remove the grape pulp.
• Pressing phases are controlled with a PLC containing 10 programs to control
and optimize each and every phase of the processing cycle.
MODEL
BASKET CAPACITY
LENGTH X WIDTH X HEIGHT
Hercules 10
211 Gal
6' 7" x 4' 3" x 11' 6"
Hercules 15
475 Gal
8' 2" x 5' 11" x 11' 6"
5
PRESSES
STANDARD TANKS
Defranceschi
Please ask about our custom tank manufacturing.
Pressure tanks and square tanks also available in different sizes.
CAPACITY
CONICAL BOTTOM
FLAT BOTTOM
HL
Gal
Diameter
Height*
Diameter
Height*
10
265
3' 3"
6' 11"
3' 3"
9' 1"
20
530
4' 1"
8'
4' 2"
10'
25
650
4' 2"
9' 3"
4' 4"
10' 11"
30
785
4' 5"
9' 9"
4' 9"
10' 11"
35
920
4' 7"
10' 2"
5' 1"
11'
40
1050
4' 9"
10' 8"
5' 1"
11' 9"
45
1150
4' 10"
11' 6"
5' 5"
11' 10"
50
1300
5' 3"
11' 7"
5' 9"
11' 11"
55
1450
5' 4"
11' 7"
5' 10"
12' 4"
60
1550
5' 6"
11' 8"
6' 1"
12' 4"
65
1700
5' 9"
11' 9"
6' 4"
12' 4"
70
1830
5' 11"
11' 9"
6' 7"
12' 5"
75
1950
6' 2"
11' 10"
6' 7"
12' 10"
80
2100
6' 4"
11' 11"
6' 10"
12' 10"
100
2625
6' 9"
13' 8"
6' 11"
14' 6"
125
3250
6' 11"
15' 3"
6' 11"
17'
150
3950
7' 3"
16' 2"
7' 2"
18' 8"
200
5250
7' 3"
20' 4"
7' 3"
22' 4"
Options include:
• Conical top, truncated top or variable lid.
• Conical bottom or flat sloping bottom.
• Stainless steel legs, galvanized steel, or painted steel base.
• Rectangular, oval or round doors.
• Stainless Steel Butterfly or Ball valves.
• Temperature gauge, sample valve, level gauge board.
• Pump over piping.
• Cooling jackets.
• Ladder bracket, walkway bracket and grab handle.
• Red/white combination tanks.
• Mirror-polished inside for easy cleaning and less tartrate accumulation
around cooling jackets.
TANKS • FERMENTERS
6
AUTOMATIC FERMENTERS
Defranceschi
CE – Pump-over system
Automatic fermenters with pumping-over cap sparger, fermentation temperature
controller and power-operated pomace discharger. Range between 2,900 and 26,400 gal.
Includes:
• Valves (sample, racking, discharge and cooling).
• Adjustable feet.
• Electrical control panel with temperature control and pump-over cycles.
• Cooling/heating jackets on side of tank.
• Low speed pump over pump with sparger (motorized on bigger models).
• Gear motor driven discharge blade for pomace removal.
MODEL
GAL
DIAMETER
HEIGHT
110 CE
2900
7' 5"
13' 9"
150 CE
4000
7' 5"
17' 1"
200 CE
5300
7' 5"
21' 2"
More sizes available on request.
fermentamatic – Pump-over system
Automatic fermenters with central filter column for pump-over with filtered must. This
feature allows more skin contact and assist CO2 extraction. Fermentation temperature
control and power-operated pomace discharge system. Range between 2,900 and
26,400 gal.
Includes:
• Valves (sample, racking, discharge, cooling and pneumatic).
• Adjustable feet.
• Electrical control panel with temperature control, pump-over cycles.
• Cooling/ heating jackets on side of tank.
• Low speed pump over pump with motorized (bigger models) sparger.
• Central filter screen.
• Gear motor driven discharge blade for pomace removal.
MODEL
GAL
DIAMETER
HEIGHT
110 FE
2900
7' 5"
13' 9"
150 FE
4000
7' 5"
17' 1"
200 FE
5300
7' 5"
21' 2"
KT3
KT2
KT1
KT2
KT3
0,6
0,8
1,0
1,2
0,4
min
KT2
START
STOP
0,6
0,2
0
KT3
0,8
1,0
1,2
0,4
min
0,2
0
KT2
RESET
0
T
U
O
N
U
m
R
T
/P
K
TG
S
h h
IGR
m m
ER
VS
V
P
2
IN
E
E
N
D
E
G
D
W
O
N
O
O
A
M
D
M
R
/T
.P
T
3
U
U
O
T
E
S
E
R
sh
s
m
sh
1
Y
LA
P
IS
D
TIM
4
KT1
START
STOP
0
set
More sizes available on request.
7
TANKS • FERMENTERS
AUTOMATIC FERMENTERS
Defranceschi
3000CP- Punch down system
Automatic fermenters with pneumatic cap plunging pistons, fermentation temperature
control and optional power-operated pomace discharge system. Range between 900 and
13,200 gal.
Includes:
• Valves (sample, racking, discharge, cooling and pneumatic).
• Adjustable feet.
• Electrical control panel with temperature control and plunging cycles.
• Cooling jackets for heating or cooling the tank.
• Pump over tube and splash plate standard on 110Cp and bigger models.
Options:
• Gear motor driven discharge blade for pomace removal (models 90Cp and up).
MODEL
GAL
DIAMETER
HEIGHT
34 CP
900
5' 4"
11' 3"
50 CP
1300
5' 10"
13' 11"
75 CP
2000
6' 10"
13' 11"
90 CP
2380
7' 5"
14' 7"
110 CP
2900
7' 5"
16' 11"
130 CP
3400
7' 5"
18' 6"
150 CP
4000
7' 5"
20' 10"
200 CP
5300
7' 5"
24' 6"
0
B
2
START
0,6
0,8
1,0
0,4
1
1,2
0,2
min
0
D
2
0,8
0,6
1,0
A
1
0,4
STOP
1,2
0,2
0,6
min
0
0,8
2
1,0
0,4
1,2
0,2
min
0
0,8
0,6
1,0
C
1
110
2900
7' 5"
17' 7"
130
3400
7' 5"
19' 2"
150
4000
7' 5"
21' 6"
200
5300
7' 5"
25' 2"
0
CP
set
More sizes available on request.
TANKS • FERMENTERS
D
0
>
<
=
sv
• Valves (sample, racking, discharge, seed extraction, cooling and pneumatic).
• Adjustable feet.
• Electrical control panel with temperature control, pump over and plunging cycles.
• Cooling jackets on side of tank and heating jacket on bottom of the tank.
• Low speed pump-over pump with motorized(bigger models) sparger.
• Filter screen in bottom for pump over.
• Gear motor driven discharge blade for pomace and seed removal.
HEIGHT
C
B
A
Automatic fermenters with pneumatic cap plunging pistons, automatic pump-over,
possibility of removing the seeds during fermentation, fermentation temperature
control and power-operated pomace discharge system. Range between 2,900 and
13,200 gal.
Includes:
DIAMETER
1
2
1
prg
puntarossa - Punch down system
GAL
2
1,2
min
0
More sizes available on request.
MODEL
0,4
0,2
8
3000
ROTOCAP FERMENTERS
Defranceschi
Automatic fermenter with quasi-horizontal cap-plunging rotating system, cap remounting and macro-oxygenation
device (for cap. >=100hl), possibility of removing the seeds during fermentation and cooling/ heating jackets.
• Central upper hatch with air vent valve for cap.<65hl
•Central upper hatch with juice sparger sprayer for cap. >100hl
•Upper off-center hatch with air vent valve for cap. >100hl
•Lower rectangular manhole with tunnel for total outlet and device for expulsion of seeds
•Stainless steel ball valves, projectile well for temperature probe and sample cock
•Remounting piping at work height connected to the sparger for cap. >100 hl
•Gearmotor, fitted to a removable, low-speed rotor with staggered blades (1/16 rpm).
•Cooling/heating jackets
•Electrical control board for controlling the rotor and the temperature
CAPACITY
HL
Gal
40
65
100
160
ROTARY FERMENTERS
1055
1720
2640
4225
Milani
Revolving self-emptying horizontal fermenter supplied complete with the following items:
• Removable discharge door on conical end.
• Rectangular discharge door for total discharge.
• Complete detachable internal drainage channels for quick and efficient draining without loss of the pomace.
• A helical screw set inside the tank shell into the conical end, which facilitates the quick and complete emptying.
• Three safety valves for fermentation gasses.
• Cooling pocket located on the external housing.
• Self-braking motor reducer with speed variator.
• Electrical control board for rotation control and fermentation temperature control.
• Tank manufactured from grade 304 stainless steel, and support frame from carbon steel, painted.
Custom design and dimensions available on request.
MODEL
GALLON
LENGTH
WIDTH
HEIGHT
POWER
100HL
2642
14' 11"
7' 3"
8' 1"
4 HP
150HL
3963
17' 1"
7' 10"
8' 8"
5.5 HP
180HL
4755
17' 9"
7' 7"
9' 10"
7.38HP
200HL
5283
17' 9"
8' 2"
10' 8"
5.5 HP
250HL
6604
18' 8"
9' 2"
11' 8"
5.5 HP
300HL
7925
20'
9' 10"
12' 4"
10HP
350HL
9246
23' 7"
9' 2"
12'
10HP
400HL
10567
25' 3"
9' 2"
12'
10HP
More sizes available on request.
9
TANKS • FERMENTERS
DESTEMER CRUSHER
AMOS-AM & AKS
Advantages:
• Easily disassembled and cleaned
•Adjustable speed control
•Complete with hopper
Destemer crusher chart.pdf
1
1/7/11
7:21 AM
•Sturdy stainless steel
structure
•Basket available in stainless steel or superior grade plastic
•Berries gently handled
•Optional crusher available
•Rollers crush adjustment range from 3 to 10 mm
•No crush gap between rollers is 90 mm
•Dejuicing at inlet.
Model
Ton/Hr
Beater/Drum
Rotation
Control
Dual
Direction Feed Screw
Drum
Regulation
Rotation
AMD 621
2-15
I*
Yes
Fixed
AMT 631
15-30
I*
Yes
Adjustable
AKS 741
25-45
F*
No
Fixed
AKS 761
40-60
F*
No
Fixed
AMD 206
2-6
I*
Yes
AMT 212
2-12
I*
Yes
N/A
Adjustable
I=Independent/non-fixed ratio of beater and Drum
F=Fixed ratio relationship
*Note: Stand-alone crusher on frame with hopper available
CRUSHERS & DESTEMMERS
NEW MODELS 2011
VPS
VPS Sample grape crusher
• Stainless steel hopper with S/S frame.
• Aluminium serrated spring-loaded adjustable rollers that accommodate all
sizes of grapes.
• Non-lubricated bearings.
• Safety switch
• 3/4HP, 120V motor,
• 58RPM chain driven
• 30”L x 21”W x 45”H
VPS crusher/stemmer
• 80 – 100tons per hour
• All S/S contact parts
• Sealed roller bearings
• 20” x 24” feed hopper
• Right and left screw feed
• 40 – 60HP motor, 280RPM
• 177”L x 56”W x 82”H
CRUSHERS • DESTEMMERS
10
CRUSHERS & DESTEMMERS
Milani
Milani - Antares
This machine is made for a softer and more delicate destemming operation with ease of
maintenance in mind. Constructed from stainless steel.
Includes:
• Cage covers flip open for ease of cleaning.
• Input hopper can be opened for ease of cleaning.
• In-feed auger in hopper.
• Picking fingers either in stainless with rubber tips or UHMW.
• Food grade rollers for crushing action.
• Adjustable crushing rollers.
• A bypass system on crusher rollers to eliminate all crushing and receive whole
berries.
• Variable speed drive on the destemming shaft for easy speed adjustment.
• Multi-sized holes in basket starting from large to small. This allows for throughput
of different sized berries and less broken stems in the finished product.
Options include:
• Rapid-Drum-Approach(RDA) system to adjust distance between fingers and drum cage.
• Assist in leaf removal (models 150 and larger).
• Optional discharge pumps and hoppers.
MODEL
PRODUCTION / HOUR
SIZE (LENGTH X WIDTH X HEIGHT)
70
5 – 6 Ton
7'2" x 2'4" x 4'8"
150
12 Ton
8'7" x 2'9" x 5'9"
200
20 Ton
8'11" x 3'3" x 6'7"
300
30 Ton
9'6" x 3'9" x 7'5"
500
50 Ton
10'8" x 4'3" x 7'11"
600
60 Ton
12'1" x 4'11" x 8'8"
FILTERS
Cartridge filter housings and stations
• Entirely built in polished stainless steel 304 or 316, sanitary
construction.
• Housing are complete with pressure gauge, sampling valve, breathing
valve and total drainage valve.
• Suitable to work with any style of cartridge (specify brand when
ordering).
• Several models are available: 1-3-5-8-12-16-18 and 24 cartridge (30”
cartridge)
DESTEMER CRUSHER/FILTERS
11
FILTERS
Spadoni
Kappa – 40 x 40cm Plate and frame
• The 40x 40cm plate filter can be utilized as a straight plate filter with cellulose filter sheets or as a plate & frame
filter for D.E. filtration.
• S/S unit mounted on wheels.
• Noril plates are steam sterilizable.
• All plates, gauges, sight glasses and drip tray included.
• Diversion chamber for double filtration and extension piece
included.
Options include:
• Centrifugal pump on trolley or mounted on filter frame
• Manual hydraulic closure
• Plates in Stainless Steel.
• Heavy duty version for Sparkling wine
• Frames for D.E. filtration
MODEL
PLATES
FILTER AREA
Kappa 3
12
1,8 m^2
Kappa 4
20
3 m^2
Kappa 5
30
4,6 m^2
Kappa 6
40
6,2 m^2
Kappa 7
50
7,8 m^2
Kappa 8
60
9,5 m^2
Kappa 9
80
12,6 m^2
Kappa 10
100
16 m^2
Magnum - 60 x 60cm Platefilter
Larger version of the Kappa series with hydraulic closure.
Alfa Magic – Combination wine/Lees filter (40 x 40cm)
• Combination plate and frame filter for filtration of lees or
wine. Replacing the lees plates with “wine plate” allows the
operator to utilize this filter also for polishing and sterilizing
filtration.
• Stainless steel construction.
• Plates made from noryl.
• S/S piston pump and buffer tank.
• Removable S/S driptray.
• Closing unit with large screw or manual hydraulic system on
request.
• S/S pressure gauges and sample valves.
• Models range from 10 to 40 plates with increments of 10.
12
FILTERS
FILTERS
Spadoni
Dcbl – Horizontal screen D.E. filter
• Horizontal screen filter equipped with manual D.E. discharge system.
• S/S Compact mobile unit mounted on four wheels.
• Dosing of D.E. by means of adjustable output pump.
• Flow meter with lighted sight glasses.
• Patented tilting system for filtering screens assures easy cleaning.
Options include:
• Special model for beer filtration.
MODEL
FILTER
SURFACE
Dcbl 50
2 m^2
50 Hl/h
22 GPM
2.35 HP
Dcbl 80
3 m^2
80 Hl/h
35 GPM
3.35 HP
Dcbl 100
4 m^2
100 Hl/h
44 GPM
3.35 HP
Dcbl 125
5 m^2
125 Hl/h
55 GPM
5.7 HP
Dcbl 150
6 m^2
150 Hl/h
66 GPM
5.7 HP
OUTPUT
POWER
Mac – Horizontal D.E. filter
• Filters mounted on wheels up to 30m2
• S/S units with variable flow dosing pump.
• Use of last filter screen as scavenger filter.
• Centrifugal cake discharge system.
• In place cleaning by means of internal spray nozzles.
• Easy maintenance through top cover with centrifugal motor
mounted in bottom.
Options include:
• Models for oil filtration.
MODEL
FILTER
SURFACE
Mac 5
5 m^2
120 Hl/h
Mac 8
8 m^2
Mac 10
POWER
PRESSURE
53 GPM
8.49 HP
87 psi
200 Hl/h
88 GPM
11.17 HP
87 psi
10 m^2
250 Hl/h
110 GPM
18.1 HP
87 psi
Mac 12
12 m^2
300 Hl/h
132 GPM
23.63 HP
87 psi
Mac15
15 m^2
350 Hl/h
154 GPM
23.63 HP
87 psi
Mac 18
18 m^2
480 Hl/h
211 GPM
30.51 HP
87 psi
Mac 20
20 m^2
500 Hl/h
220 GPM
36.88 HP
87 psi
Mac 25
25 m^2
630 Hl/h
277 GPM
47.27 HP
102 psi
Mac 30
30 m^2
750 Hl/h
330 GPM
61.02 HP
102 psi
Mac 40
40 m^2
1000 Hl/h
440 GPM
73.76 HP
102 psi
FILTERS
OUTPUT
13
FILTERS
Spadoni
Asso – RotAry drum vacuum filter
• Mechanical vacuum filters for filtration of must, lees and juices with a high solid content.
• 304SS unit with 316SS screen.
• Centralized control panel.
• D.E. tank equipped with mixer.
• Vacuum pump cooling system equipped with buffer tank to control water consumption.
• Filtered liquid manifold separated from Air manifold.
Options include:
• Cake discharge conveyors.
• Automatic drum washing system.
• SS vacuum pump.
MODEL
FILTER SURFACE
OUTPUT
3
3 m^2
159 gal
5
5 m^2
264 gal
8
8 m^2
264 gal
10
10 m^2
396 gal
15
15 m^2
674 gal
20
20 m^2
845 gal
25
25 m^2
1004 gal
30
30 m^2
1136 gal
FTs – crossflow filters
• Stainless steel crossflow filters equipped with a special tubular
capillary membranes made in polypropylene.
• Fully automatic operating system.
• Real suitable for filtering beer and sparkling wine.
• Excellent filtered product stabilization.
• Easy membrane washing and sanitization.
MODEL
FILTER
SURFACE
MODULES
POWER
FTS 10
10 m^2
1
4.02 HP
FTS 20
20 m^2
2
5.36 HP
FTS 30
30 m^2
3
8.05 HP
FTS 40
40 m^2
4
13.41 HP
FTS 60
60 m^2
6
16.09 HP
FTS 80
80 m^2
8
22.8 HP
FTS 120
120 m^2
12
29.5 HP
FTS 160
160 m^2
16
37.55 HP
14
FILTERS
PUMPS
FLEXIBLE IMPELLER PUMPS - BCM
• Pump body and cart made from stainless steel.
• Neoprene food grade flexible impeller.
• Overload protection.
• Reversible.
• Ceramic sleeve with o-ring seals are less expensive than standard
mechanical seals.
Options include:
• Hydraulic, mechanical or electronic speed variator.
• Bypass valve.
• Single-phase and three-phase models.
• Viton flexible impeller.
MODEL
PORT SIZE
FLOW (GPM) @ RPM
HP
30
1"
32
1080
1.2 Hp
40
1-1/2"
54
1080
1.2 Hp
50I
2"
0 – 89
0 – 1020
2.5 Hp
50M
2"
16 –95
228 – 1200
2.5 Hp
60I
2-1/2"
6 – 143
60 – 1020
7.5 Hp
60M
2-1/2"
25 – 152
228 – 1200
3 Hp
70I
3"
6 – 143
60 – 1020
7.5 Hp
70M
3"
25 - 152
228 – 1200
3 Hp
Solid capacity Centrifugal pumps - Tecnicapompe
The screw-shaped impeller conveys the product into the pump casing. This enables the pump to be widely used in
the wine industry for the wine recirculation process where the suspended products form and integrity need to be
preserved. Special screw-shaped impeller, together with the progressively increasing volute-shaped casing prevent
pump obstruction and damage to solid particles in suspension.
Permits the wine must and part of the rising fermentation to remount together. It’s microcast screw-shape impeller
produces a volute shape pump casing. It will not break down contents in the grape, so it enables maximum output,
producing a high quality wine with enhanced color.
Options include:
• Special inlet/outlet connections.
• Stainless steel trolley and motor cover.
MODEL
PORT SIZE
FLOW @ 15’ HEAD
POWER
TCD 15/E
2"
12 000 Gal/h
2.3HP
TCD 40/E
3"
28 000 Gal/h
6.4HP
TCD 55/E
4"
35 000 Gal/h
8.8HP
15
PUMPS
PUMPS
centrifugal transfer pumps - VPS
Transfer pumps for wine and other liquids. Close-couple pump design and stainless steel shaft wear sleeves with
adjustable suction cover plates to compensate for wear on covers and impellers.
Options include:
• Mounted on sub base or portable cart.
• Packing glands or mechanical shaft seals.
• Electronic variator.
MODEL
PORT
SIZE
110 – 1-1/2
FLOW (GPM) @ TOTAL HEAD
HP – RPM
30'
50'
80'
1"
40
-
-
1.5 – 1800
110 – 1-1/2
1"
65
55
10
1.5 – 3600
110 – 2
1"
85
70
45
2 – 3600
110 – 3
1"
95
95
85
3 – 3600
122 – 3
2"
160
130
20
3 – 1800
121 – 5
2"
190
170
20
5 – 1800
CH 141 – 7-1/2
2"
195
195
170
7.5 – 1800
CH 144 – 10
2"
235
230
220
10 – 1800
CH 153 – 15
3"
540
540
440
15 – 1800
CH 153 – 20
3"
700
650
520
20 – 1800
CH 154 – 15
4"
700
650
400
15 – 1800
CH 154 – 20
4"
1000
900
550
20 - 1800
Airpumps
• Self priming.
• Handles fluids with high solid capacity.
• Ability to run dry.
• Variable flow rate & discharge pressure.
• Dead head.
• Shear sensitive.
• Pumping efficiency remain constant.
Options include:
• Body material: Aluminum, 316 Stainless Steel, Polypropylene, Kynar, etc.
• Valve types: ball or flat style with different materials.
• Carts with pneumatic tires.
• Surge chamber.
• Regulator
PUMPS
16
PUMPS
MUST PUMPS AMOS – AMP
Advantages:
• Gentle handling of grapes and pomace thanks to slow rotation, large impeller and two-speed motor.
• Easy-to-clean thanks to simple design and construction.
• Suitable for whole grapes, crushed grapes, fermented masses and other viscous composites
• Large load surface, reduced height
• All parts in contact with products (except for stator) are in AISI304 stainless steel.
• Cable rotor notably reduces vibrations
• Two-speed motor (standard) allows rpm to be cut 50%
• Choice of manual or optional automatic control
• Optional dry operation protection
• Optional sensor controls min/max levels and automatic change over to 2nd speed.
• Optional casters can be installed on standard static structure (models 1050 and larger)
• Pump can be installed under AMOS AKS destemers
AMP
T/h
rpm
T/h
rpm
Port
out
DN
820
10
110
20
220
80
1030
20
70
40
140
100
220
120
Model
1st speed
830
1050
1280
1580
15
145
25
120
50
85
40
110
2nd speed
30
290
50
240
80
100
170
80
100
150
RotAry Lobe pumps
• Omac positive displacement pumphead.
• Wash down duty electrical motor.
• Mounted on stainless steel cart with pneumatic tires.
• Electronic variable speed drive in enclosure with 50’ remote control cord.
• Forward/reverse and start/stop operation
• Includes 30’ electrical power cord
• High-pressure capabilities.
• Available in 1”to 8” port sizes.
Options include:
• Rotor styles: Bi lobe, tri lobe, batwing, etc.
• Dry run protection.
• Pressure control.
• Anti seize rotor material.
• Foam filled or solid tires.
MODEL
PORT SIZE
FLOW @ RPM
PRESSURE
HP
Yebo 50
2"
0 - 48 GPM @ 530 RPM
100 PSI
3 HP
Yebo 100
3"
0 – 98 GPM @ 530 RPM
100 PSI
5 HP
Yebo 160
3"
0 – 162 GPM @ 530 RPM
145 PSI
7.5 HP
Yebo 220
4"
0 – 217 GPM @ 530 RPM
100 PSI
10 HP
Yebo 350
4"
0 – 347 GPM @ 548 RPM
145 PSI
15 HP
17
PUMPS
PUMPS
Progressive cavity pumps
• Stainless steel screw with food grade stator.
• Compact direct drive assembly eliminate
synchronization ratio between separate hopper feed and
pump flow.
• Replaceable wearing parts on coupling yoke and rod.
Bushes eliminate replacing complete coupling head.
• Customize sizing for specific application – low
revolution with big solid capacity.
Options include:
• Mechanical or electronic variator for speed control.
• Stop, start, forward and reverse switch gear.
• Customize port sizes and hoppers (EW-models: extra
wide option for machine harvest grapes).
• Fix mounting or mobile units.
• Bypass valve.
• Dry run protection with liquid sensor.
• Electronic or mechanical pressure valve fitted for filtering or bottling.
• Ozone friendly material.
MODEL
PORT SIZE
FLOW (GPM) @ RPM
P 8/1
2" / 2"
22
550
2
P 16/1
2" / 2"
40
550
4
P 55/1
3" / 3"
132
600
7
P 90/1
3" / 3"
198
600
10
P 160/1
4" / 4"
330
500
15
EW 95/1
4"
119
300
10
EW 160/1
6"
165
250
15
EW 225/1
8"
242
250
15
EW 450/1
8"
396
250
25
EW Series
POWER
P Series
PUMPS
18
PUMPS
Piston pumps
• Two speed 3phase motor with electrical protected control panel.
• Flow reverse lever.
• Pressure switch for safety or shut off.
• Stainless Steel pump casing.
Options include:
• Various port sizes.
• Variable speed drive.
STAINLESS
MODEL
PORT SIZE
FLOW - GPM
# PISTON
POWER - HP
85 MXT
2"
20 / 37
1
0.8 / 1
130 MXT
2"
31 / 57
1
2/3
220 MXT
3"
51 / 97
1
4 / 5.5
250 MXT
3"
57 / 110
1
5/6
260 BXT
2-1/2"
60 / 115
2
5/6
360 BXT
3"
80 / 155
2
5/6
460 BXT
3"
101 / 203
2
8 / 10
560 BXT
4"
123 / 247
2
11 / 13
700 BXT
4"
159 / 308
2
12 / 15
19
PUMPS
INCLINED BELT CONVEYOR
AMOS – AE
The AMOS belt conveyors are designed and engineered to fit into any
new or existing grape reception layout. The structure is completely
constructed in stainless steel AISI 304.
Standard Equipment:
• Electric motor installed on lower pulley
•Electrical control with ON/OFF and emergency switch
•Easy to clean and sanitize
•Food grade belt with V profiles every 10”
•Variable unloading height, adjustable with hydraulic jack, equipped
with hand pump
•Frame on four pivot casters with brakes
•Choice between 3 standard hoppers
Options:
•Custom made loading hopper
•Open grape chute (4 different mounting options)
•Special grape chute for the use of flexible hoses
•Flexible hose (1 meter)
•Variable mechanical adjusted speed motor < 0.75 kW
•Variable electronic adjusted speed inverter < 1.1 kW
Model
AE30250F
AE30350F
AE30500F
AE30700F
AE50250F
AE50350F
AE50500F
AE50700F
Axis Belt
Length
8' 2"
11' 6"
16' 5"
23'
8' 2"
11' 6"
16' 5"
23'
Belt
Width
1'
1'
1'
1'
1' 8"
1' 8"
1' 8"
1' 8"
Unloading Height
Min.
3' 2"
4' 6"
6' 9"
9' 6"
3' 2"
4' 6"
6' 9"
9' 6"
Unlodaing Height
Max
6' 2"
8' 9"
12' 2"
17'
6' 2"
8' 9"
12' 2"
17'
VIBRATING SORTING TABLE
AMOS – AV
The AMOS vibrating sorting tables are designed and engineered to
fit into any new or existing grape reception layout. The structure
is completely constructed in stainless steel AISI 304, on height
adjustable legs.
Standard Equipment:
• Body entirely made in stainless steel AISI 304
•Working width 27.6”
•Working height 33.5” ± 2”
•Variable speed control with electronic inverter
•Perforated surface on first part of the table
•Juice pan with 2” outlet
•Installed on legs with pivot casters complete with breaks
•Control panel with speed control and emergency switch
Model
Options:
•Loading hopper
•Filter inlet for juice pan
•2nd draining surface with juice pan (only for 18’ table)
•Filter inlet for 2nd juice pan (only for 18’ table)
AV70200V
AV70320V
AV70500V
BINS • TABLES • CONVEYORS
20
Length
6' 6"
10' 6"
16' 5"
Width
2' 4"
2' 4"
2' 4"
Total Width
2' 9"
2' 9"
2' 9"
BELT SORTING TABLE
AMOS – AN
The AMOS belt sorting tables are designed and engineered to fit
into any new or existing grape reception layout. The structure
is completely constructed in stainless steel AISI 304, on height
adjustable legs.
Standard Equipment:
• Mechanical variable speed motor
•Easy to clean and sanitize
•The belt is slightly higher towards the sides
•Electrical control with ON/OFF and emergency switch
•Food grade belt
•Scraping device for the belt
•Fast belt tensioning system
•Frame on four pivot casters with brake
Options:
•Higher side walls on 3 sides for easier dumping
•Juice recovery pan
•Separation wall
Model
Axis Belt Length
Total Length
Belt
Width
Total
Width
AN80265V
AN80365V
AN80515V
8' 8"
12'
16' 11"
9' 7"
12' 10"
17' 9"
2' 8"
2' 8"
2' 8"
3' 8"
3' 8"
3' 8"
VIBRATING HOPPER
AMOS – ADV 2
The ADV 2 assures an optimal feeding of the machine for a better
destemming result. Used on the beginning of a sorting line, the ADV
2 distributes the grapes uniformly on the sorting table.
Model
ADV 2-50
ADV 2-100
Hopper
Capacity
500 lit.
1000 lit.
*Note: Optional frame not included
BINS • TABLES • CONVEYORS
21
TANK MIXERS
TANK MIXERS
• Mobile or fixed units.
• Stainless steel constuction.
• Electrical protection and safety switch.
Options include:
• Mounting connections: flanged or different clamp
solutions.
• Slow speed (800RPM).
• Timers.
• Single or three-phase motors.
• Variable speed (200-1800RPM).
• Mobile stand.
MODEL
STD PORT SIZE
CAPACITY
POWER
CL 35E
2"
9 246 gal
1 HP
CL 70E
2-1/2"
18 492 gal
2 HP
CL100E
2-1/2"
26 417 gal
4 HP
CL150E
2-1/2"
52 834 gal
5 HP
COOLING PLATES
Complete Stainless Steel construction.
Mirror polished material.
Variety of sizes available.
TANK MIXERS
22
CUSTOM FABRICATION & MACHINING
Custom fabrication & repair
• Repairs on miscellaneous equipment.
• Dump hoppers.
• Screw feeders.
• Tube in tube
chillers/heat
exchangers.
• Pump-over
sumps with
screen.
• Pump carts.
• Special
fittings.
• Check with us for all
your fabrication and
machining needs.
CUSTOM FABRICATION & MACHINING
23
BARREL SYSTEMS
barrel topping
Air diaphragm pumps
s/s Topping guns
Barrel Fillers
barrel wands
Sight Glasses
Spinners
Other accesories including bungs,
stoppers, barrel racks,
washing systems, etc.,
available on request.
BARREL SYSTEMS
24
MISCELLANEOUS
3-WAY BRONZE MUST VALVES
GAS SPARGING DEVICES
PUMP-OVER IRRIGATORS
RACKING ARMS
AERATORS
SPRAY BALLS
TANK WASHERS
FITTINGS AND PARTS
WASHDOWN STATIONS
GASKETS AND PARTS FOR MANWAYS AND HANDHOLES
FOOD GRADE BUCKETS, SHOVELS AND CLEANING BRUSHES
25
MISCELLANEOUS
INSTRUMENTATION
Thermometers:
Call for information and availibility. Specify:
• Range: -80° F to 1000° F
• Dial size: 3” & 4” STD.
• Stem Lengths: 2 ˚” through 24”
• Mounting connections: ˚” NPT
• Options: Special stemlenghts, field calibrations, adjustable angle
Pressure gauges:
Call for price & availability - many in stock.
Specify: Style, dial size, material, connection size, range and application.
Automation control devices
Batch meters, Flowmeters, liquid sensors, float switches, pressure sensors, level
switches and temperature control systems. We also can custom build a variety of
electrical control panels.
INSTRUMENTATION
26
WINERY VALVES
Ball Valves
Tassalini, Capriani, VA, Sharpe, Inoxpa and several other brands
stocked & available.
Sizes: 1”, 1-1/2”, 2”, 2-1/2”, 3”, 4”, 6”.
Connections: TC, weld end, I-line, bevel seat, DIN.
Butterfly Valves
Stainless Steel body: Tassalini, Definox, Capriani, Inoxpa and
several other brands stocked & available.
Sizes: 1”, 1-1/2”, 2”, 2-1/2”, 3”, 4”, 6”.
Connections: TC, weld end, I-line, bevel seat, DIN.
Iron body: Demco, Watts, Stockham and several other brands
stocked and available.
Sizes: 2” through 24”.
Connections: wafer or lug.
Knifegate Valves
Foodgrade S/S body with several seat options available.
Sizes: 2” through 24”.
Operators: handwheel, lever or air.
check Valves
Stainless Steel body: Tassalini, Definox. Capriani and several
other brands stocked & available.
Sizes: 1”, 1-1/2”, 2” , 2-1/2”, 3”, 4”, 6”.
Connections: TC, weld end, I-line, bevel seat, DIN.
Sample valves
Stainless Steel VPS and other brands available.
MNPT- 1/4”, 3/8”, 1/2”.
TC - 1-1/2”, 2”.
Pressure & vacuum tank vents
PVC, stainless steel and other options available.
Sizes: 2” , 2-1/2” , 3” , 4” , 6”.
27
VALVES
INDUSTRIAL VALVES
valves, THreaded
BALL
1/4"
3/8"
1/2"
3/4"
1"
1-1/4"
1-1/2"
2"
2-1/2"
3"
4"
Stainless Steel
*
*
*
*
*
*
*
*
*
*
*
Carbon
*
*
*
*
*
*
*
*
Bronze
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
PVC
GATE
Stainless Steel
*
*
*
*
*
*
*
*
Carbon
*
*
*
*
*
*
*
*
Bronze
*
*
*
*
*
*
*
*
Stainless Steel
*
*
*
*
*
*
*
*
Bronze
*
*
*
*
*
*
*
*
Stainless Steel
*
*
*
*
*
*
*
*
Bronze
*
*
*
*
*
*
*
*
*
*
*
PVC (Ball)
*
*
*
*
*
*
*
*
*
*
GLOBE
SWING CHECK
Miscellaneous valves
Pressure reducing, safety relief,
ammonia, electric and pneumatic
actuators.
Soleniod valves
Type:
Operation:
Media:
Size:
Pressure:
Voltage:
VALVES
2way, 3way, 4way.
NO, NC.
Air, water, light oil, steam, other.
1/8” through 2”
0 – 1500psi.
DC: 12, 24, 125.
AC: 24, 120, 240, 480.
Special voltages available.
28
FOOD GRADE RUBBER HOSE
vps cuvÉe
General-purpose suction and discharge hose for food and beverage
processing.
White Chlorobutyl (FDA, 3-A, USDA compliant) tube with
reinforcement from spiral plied synthetic fabric with Polyester
Monofilament Helix. Cover is gray (wrapped) / white & green
branding tape.
Gates Cellar master
Also available.
FOOD GRADE PVC HOSE
Nutriflo
General-purpose suction and discharge hose for food processing.
Clear Pliovic (FDA, 3-A, USDA compliant) tube with reinforcement from high
density Pliovic helix.
Kanaline FW
Heavy duty food grade suction and discharge hose.
Flexible PVC, rigid PVC helix, synthetic braiding, smooth bore, corrugated OD
(FDA & 3-A compliant). Lightweight and flexible with clear sidewall permits
visual check of material flow. External helix provides easy drag.
BRAND
ID SIZE (in)
MAX. WP
VACUUM
TEMPERATURE
VPS Cuvee
1, 1-1/2, 2, 2-1/2, 3
250psi
27 in/HG
-30° F to 220° F
1
1-1/2
2
3
4
6
1-1/2, 2, 3
4
106 psi
89 psi
79 psi
65 psi
55 psi
47 psi
125 psi
100 psi
29 in/HG
15° F to 150° F
28 in/HG
-13° F to 158° F
1/2, 1
300 psi
---
-20° F to 190° F
Nutriflo
Kanaline FW
Washdown
WASHDOWN RUBBER HOSE
Economical air & water hose
Red or white synthetic rubber tube with spiral synthetic
yarn reinforcement.
A wide variety of shanks available,
designed to prevent slippage and blow off.
29
HOSE
WELD FITTINGS
Stainless steel tube weld fittings.
Standard non-polished; also available in 3A polished.
Standard sizes:
3/4" 1", 1-1/2", 2", 2-1/2", 3", 4", 6" (Call for availablility).
45 degree
90 degree
cap
tee
adapter
cross
stub ends
backing flanges
Standard reducer configurations:
1x3/4, 1x1-1/2, 2x1-1/2, 2x1, 2-1/2x1
2-1/2x1-1/2, 2-1/2x2, 3x1, 3x1-1/2, 3x2
3x2-1/2, 4x2, 4x2-1/2, 4x3,5x3
5x4, 6x4, 6x5
concentric reducer
FITTINGS
Y
30
ecccentric reducer
TRI-CLAMP FITTINGS
Stainless steel triclamp fittings.
Standard sizes:
1", 1-1/2", 2", 2-1/2", 3", 4", 6" (Call for availablility).
45 degree
90 degree
tee
Y
long ferrule
short ferrule
wingnut clamp
bolted clamp
gasket
cross
end cap
Buna, EPDM, Viton,
Teflon, Silicone
Standard reducer configurations:
2x1-1/2, 2x1, 2-1/2x1
2-1/2x1-1/2, 2-1/2x2, 3x1
3x1-1/2 3x2, 3x2-1/2
4x2, 4x2-1/2, 4x3
concentric reducer
eccentric reducer
31
FITTINGS
I-LINE FITTINGS
Male and Female ends available: 1", 1-1/2", 2", 2-1/2", 3", 4" (Call for availablility).
Male Ferrule
FEMale Ferrule
Male cap
wingnut clamp
FEMale cap
bolted clamp
BEVEL SEAT FITTINGS
Male and Female ends available: 1", 1-1/2", 2", 2-1/2", 3", 4" (Call for availablility).
thread weld
ferrule
FITTINGS
plain weld
ferrule
32
HEX NUT
DIN FITTINGS
Standard sizes: 20, 25, 40, 50, 65, 80, 100 (Call for availablility).
Male weld
adapter
FEMale weld
adapter
nut
seal
GAROLLA FITTINGS
Standard sizes: 50, 60, 80, 100 (Call for availablility).
clamp • cap • gasket
half ferrule
MISCELLANEOUS FITTINGS
• 150 Lb. threaded stainless steel, 304 and 316.
• 150 Lb. threaded black and galvanized malleable iron.
• Schedule 40 and 80 PVC, slip and thread.
• Copper sweat.
• 125 Lb. brass threaded.
• Others available.
33
FITTINGS
CAM AND GROOVE FITTINGS
Cam and groove fittings available in aluminum, brass, polypropylene, nylon, stainless steel.
Standard sizes:
1/2", 3/4" 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4", 6", 8" (Call for availablility).
male adapter
female npt
female coupler
male npt
female coupler
nose shank
female coupler
female npt
male adapter
hose shank
male adapter
male npt
dust cap
male weld
adapter
male weld
coupler
dust cap
FITTINGS
34
PCT HOSE FITTINGS
The "original" domestic manufactured
No. 137
No. 138
No. 140
No. 142
No. 198
No. 311
No. 197N
No. 141
No. 197FE
(Shank only)
w/197N
No. 197MA
No. 197F
No. 175
No. 149N
PART NO.
DESCRIPTION
SIZES
No. 197-N
Hose Nut
1” • 11/2” • 2” • 3”
No. 197-Fe
Hose Shanks
1” • 11/2” • 2” • 3”
No. 197-Ma
Hose Shanks
1” • 11/2” • 2” • 3”
No. 137
PCT-Hose Caps
1” • 11/2” • 2” • 3”
No. 198
Dbl-female Connector
S.S. Sleeve
1” • 11/2” • 2” • 3”
No. 140
PCT x IPS male Hose Nipple
1” • 11/2” • 2” • 3”
No. 141
Pin-Lug PCT Dbl-Male Hose
Connector
1” • 11/2” • 2” • 3”
No. 142
PCT Hose Reducers
1”x 3/4” thru 4” x 3”
No. 138
PCT Hose Bushings
1”x 3/4” thru 4” x 3”
No. 149N
Wash-Down Nozzles
with Shut Off
1”
No. 311
PCT x Tube Adapter
1” • 11/2” • 2” • 3”
No. 197-F
Female Ferrules
1” • 11/2” • 2” • 3”
No. 175
Manganese-Bronze
Spanner Wrench
35
BRONZE
STAINLESS
STEEL
FITTINGS
PIPE & TUBING
WELDED STAINLESS TUBING
O.D./IN.
WALL/IN
I.D./IN.
.250
.065
.120
.128
.375
.065
.245
.215
STEEL: BLACK & GALVANIZED
WT./FT.
SCHEDULE 40
NOM
WALL
TKS.
NOM
SIZE
21 FEET
SCHEDULE 40
SCHEDULE 80
WT.
PER
FT.
NOM
WALL
TKS.
WT.
PER
FT.
PCS.
PER
LIFT
WT. LBS.
PER
LIFT
FEET
PER
LIFT
.500
.065
.370
.302
.625
.065
.495
.389
1/8
.068
.2447
.095
.3145
-
-
-
.750
.065
.620
.476
1/4
.088
.4248
.119
.5351
240
5040
2141
3/8
.091
.5676
.126
.7388
180
3780
2146
1/2
.109
.8510
.147
1.088
120
2540
2162
3/4
.113
1.131
.154
1.474
84
1764
1995
1
.133
1.679
.179
2.172
60
1260
2116
1-1/4
.140
2.273
.191
2.997
42
882
2005
1-1/2
.145
2.718
.200
3.631
36
756
2055
.875
.065
.745
.562
1.000
.065
.870
.649
1.035
.065
.905
.673
1.125
.065
.995
.736
1.250
.065
1.120
.823
1.500
.065
1.370
.996
1.750
.065
1.620
1.170
1.875
.065
1.745
1.257
2
.154
3.653
.218
5.022
26
546
1995
2.000
.065
1.870
1.343
2-1/2
.203
5.793
.276
7.661
18
378
2190
2.125
.065
1.995
1.435
3
.216
7.576
.300
10.25
14
294
2227
2.250
.065
2.120
1.517
3-1/2
.226
9.109
.318
12.51
12
252
2295
2.500
.065
2.370
1.690
4
.237
10.79
.337
14.98
10
210
2266
3.000
.065
2.870
2.037
5
.258
14.62
.375
20.78
8
168
2456
3.500
.065
3.370
2.385
6
.280
18.97
.432
28.57
7
147
2789
4.000
.065
3.870
2.732
5.000
.065
4.870
3.426
8
.322
28.55
.500
43.39
5
105
2996
6.000
.065
5.870
4.120
8.000
.120
7.760
10.100
10.000
.065
9.870
6.897
SCHEDULE 40
MIN.
WALL
SCHEDULE 80
WT.
PER 100'
MIN.
WALL
WT.
PER 100'
copper tube
SIZE
TYPE K
TYPE L/ACR
1/2
.840
.109
16.18
.840
.147
20.62
HARD
COILS
3/4
1.050
.113
21.58
1.050
.154
28.01
20'
Lengths
60' thru 1-1/2
100' thru 1-1/4
40' & 60' -2"
only
1
1.315
.133
32.00
1.315
.179
41.22
1-1/4
1.660
.140
43.40
1.660
.191
57.06
WALL WGT/FT
1-1/2
1.900
.145
51.83
1.900
.200
69.18
2
2.375
.154
69.72
2.375
.218
95.86
2-1/2
2.875
.203
110.57
2.875
.276
146.21
3
3.500
.216
144.83
3.500
.300
195.84
4.500
.337
286.24
SIZE
NOM
PVC Pressure Pipe
pvc1120, astm, d-1785, nsf-pw
O.D.
Standard Lengths
HARD
COILS
20'
Lengths
60' thru 1-1/2
100' thru 1-1/4
40' & 60' -2"
only
WALL WGT/FT
O.D.
NOM
O.D.
1/4
3/8
.035
.145
.030
.126
3/8
1/2
.049
.269
.035
.198
1/2
5/8
.049
.344
.040
.285
5/8
3/4
.049
.418
.042
.362
3/4
7/8
.065
.641
.045
.455
4
4.500
.237
206.21
O.D.
1
1-1/8
.065
.839
.050
.655
5
5.563
.258
278.90
-
1-1/4
1-3/8
.065
1.04
.055
.884
6
6.625
.280
363.38
6.625
.432
546.52
1-1/2
1-5/8
.072
1.36
.060
1.14
8
8.625
.322
546.95
8.625
.500
830.11
2
2-1/8
.083
2.06
.070
1.75
2-1/2
2-5/8
.095
2.93
.080
2.48
3
3-1/8
.109
4.00
.090
3.33
3-1/2
3-5/8
.120
5.12
.100
4.29
4
4-1/8
.134
6.51
.110
5.38
5
5-1/8
.160
9.67
.125
6
8
6-1/8
8-1/8
.192
.271
13.90
25.90
.140
.200
PIPE & TUBING
-
-
REFRIGERATION SERVICE TUBE
O.D. SIZE
1/8"
3/16"
1/4"
5/16"
3/8"
1/2"
5/8"
3/4"
7.61
WALL THICKNESS
.030
.030
.030
.032
.032
.032
.035
.035
10.20
19.30
WT. PER FOOT
.0347
.0575
.0804
.109
.134
.182
.251
.305
WT. PER COIL
1.74
2.88
4.02
5.45
6.70
9.10
12.55
15.25
36
INFORMATION
This data is not binding. Valley Pipe & Supply, Inc. reserves the right to make any alterations it
deems necessary without prior warning.
Valley Pipe & Supply Inc.
Headquarters
1801 Santa Clara St., Fresno, CA 93721
Phone - 559-233 0321
Fax - 559-233 1713
Email - [email protected]
Web - www.valleypipe.com
Napa - 707-226 6427
Sales Office
Mexico - Caborca, Sonora
Phone/Fax - 6373727382
Valley Pipe & Supply Inc. is a distributor/representative and custom manufacturer of winery
equipment and related items for the beverage industry. This catalog does not show or mention all of
the products available to its customers. The data contained in this catalog is for reference purpose
only, in no way binding, and subject to change without prior notice.
Please call the office or sales representative in your area for assistance regarding:
• Prices
• Payment terms
• Delivery times and shipping information
• Technical information
• Warranties
Valley Pipe & Supply Inc. thanks you for your interest in our products and for your business.
&
Headquarters
1801 Santa Clara, Fresno, California 93721
Phone 559-233-0321 • Fax 559-233-1713 • Email: [email protected]
www.valleypipe.com
Napa
Phone 707-226-6427
International Sales Office
Mexico – Carborca, Sonora • Phone/Fax 6373727382
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
