4-464-273-11 (1)
Operation is subject to the following two
conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference,
including interference that may cause undesired
operation of this device.
Location of Controls
Unit (Front)
Playing a CD-DA/MP3 disc
1 Press CD FUNCTION  on the remote or press
This equipment complies with IC radiation
exposure limits set forth for an uncontrolled
environment and meets RSS-102 of the IC radio
frequency (RF) Exposure rules. This equipment
has very low levels of RF energy that it deemed to
comply without maximum permissive exposure
evaluation (MPE). But it is desirable that it should
be installed and operated keeping the radiator
at least 20cm or more away from person’s body
(excluding extremities:hands, wrists, feet and
ankles).
Home Audio System
GB Operating Instructions
ˎCompatibility
ˎ
with all MP3 encoding/writing software,
CD-R/RW drive and recording device, and recording media
cannot be guaranteed. Incompatible MP3 discs may
produce noise or interrupted audio or may not play at all.
Operations
FUNCTION  on the unit repeatedly until “CD”
appears in the display .
2 Press the  (open/close) button  to open
the disc tray .
3 Load a disc with the label side facing up.
Label side
(printed side)
©2013 Sony Corporation
Printed in China
WARNING
To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
To reduce the risk of fire, do not cover the
ventilation opening of the appliance with
newspapers, tablecloths, curtains, etc.
Do not expose the appliance to naked flame
sources (for example, lighted candles).
To reduce the risk of fire or electric shock, do not
expose this appliance to dripping or splashing,
and do not place objects filled with liquids, such
as vases, on the appliance.
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.
As the main plug is used to disconnect the unit
from the mains, connect the unit to an easily
accessible AC outlet. Should you notice an
abnormality in the unit, disconnect the main plug
from the AC outlet immediately.
This symbol is intended to alert
the user to the presence of
uninsulated“dangerous voltage”
within the product’s enclosure that
may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
This symbol is intended to alert the
user to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
Do not expose batteries or appliances with
battery-installed to excessive heat, such as
sunshine and fire.
The unit is not disconnected from the mains as
long as it is connected to the AC outlet, even if the
unit itself has been turned off.
CAUTION
The use of optical instruments with this product
will increase eye hazard.
Owner’s Record
The model and serial numbers are located
on the rear exterior of the unit. Record these
numbers in the space provided below. Refer to
them whenever you call upon your Sony dealer
regarding this product.
Model No.
Serial No.
Important Safety Instructions
1)
2)
3)
4)
5)
6)
7)
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8) Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9) Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong.
The wide blade or the third prong are provided
for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10)Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11) Only use attachments/accessories specified by
the manufacturer.
12)Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus.
When a cart is used, use caution whenmoving
the cart/apparatus combination to avoid injury
from tip-over.
13)Unplug this apparatus during lightning storms
or when unused for long periods of time.
14)Refer all servicing to qualified service
personnel.
Servicing is required when the apparatus has
been damaged in any way, such as powersupply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
The following FCC statement applies only
to the version of this model manufactured
for sale in the U.S.A. Other versions may
not comply with FCC technical regulations.
NOTE:
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuantto Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more of
the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the
equipment and receiver.
 Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
 Consult the dealer or an experienced radio/TV
technician for help.
CAUTION
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
This equipment must not be co-located or
operated in conjunction with any other antenna
or transmitter.
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency
(RF) Exposure Guidelines in Supplement C to
OET65. This equipment has very low levels of
RF energy that it deemed to comply without
maximum permissive exposure evaluation (MPE).
But it is desirable that it should be installed and
operated keeping the radiator at least 20cm
or more away from person’s body (excluding
extremities: hands, wrists, feet and ankles).
preset number.
If another station is already assigned to the
selected preset number, the station is replaced
by the new station.
4 Press
1 Press CD FUNCTION  on the remote or press
FUNCTION  on the unit repeatedly until “CD”
appears in the display .
3 Select a folder (MP3 disc only).
+/   repeatedly to select the
Press
desired folder.
If you want to program all files in the folder,
.
press
Tip
When you use headphones, connect to  (headphone) jack .
Remote
This manual mainly explains operations using
the remote, but the same operations can also be
performed using the buttons on the unit having
the same or similar names.
To use the remote
This product is designed to playback discs that
conform to the Compact Disc (CD) standard.
Recently, various music discs encoded with
copyright protection technologies are marketed
by some record companies. Please be aware
that among those discs, there are some that do
not conform to the CD standard and may not be
playable by this product.
Slide and remove the battery compartment lid,
and insert the two supplied R6 (size AA) batteries,
 side first, matching the polarities shown below.
 (open/close) 
4 Press the  (open/close) button  to close
Press /  repeatedly until the desired
track or file number appears.
the disc tray .
5 Press  (play/pause) button .
Selected track
or file number
Playback starts.
Notes on using the remote
ˎWith
ˎ
normal use, the batteries should last for about 6
months.
ˎDo
ˎ not mix an old battery with a new one or mix different
types of batteries.
ˎIf
ˎ you do not use the remote for a long period of time,
remove the batteries to avoid damage from battery leakage
and corrosion.
Getting Started
Rear of the speaker
ˎIf
ˎ you cannot remove the disc and “LOCKED” appears in the
display , contact your nearest Sony dealer.
ˎDo
ˎ not load a disc with non-standard shapes (e.g., heart,
square, star). Doing this may cause irreparable damage to
the system.
ˎDo
ˎ not use a disc with tape, stickers or paste on it as this
may cause malfunction.
ˎWhen
ˎ
you remove a disc, do not touch the surface of the
disc.
Other operations
To
Do the following:
Pause playback
Press  . To resume play,
press the button again.
Stop playback
Press  .
Select a track
or file
Find a point in a
track or file
Press / .
Select Repeat
Play
Hold down /  (or
/  on the unit)
during playback, and release
the button at the desired point.
Press REPEAT  repeatedly
until “ ” (all tracks of files)
or “ 1” (single track or file)
appears.
Select a folder on Press
+/  repeatedly.
an MP3 disc
Remove a disc
Press   on the unit.
red 
To change the play mode
Press PLAY MODE  repeatedly while the player
is stopped. You can select Normal Play mode (no
indication or “FLDR”* appears), Shuffle Play mode
(“SHUF” or “FLDR SHUF”* appears), or Program
Play mode (“PGM” appears).
Play mode
 Power input (AC IN)
After all equipments are connected, connect the
power cord  to the wall outlet.
Setting the clock
1 Press   to turn on the system.
2 Press TIMER MENU  to select the clock set
mode.
 Speakers (left/right) connectors
Firmly connect the right speaker cord  to R, and
the left speaker cord  to L.
 AUDIO IN (external input) jack
Connect optional external equipment with an
audio connecting cable (not supplied).
 Antennas
FM lead antenna (supplied)
AM loop antenna (supplied)
Find a location and an orientation that provide
good reception, and then fix the antennas to a
stable surface (window, wall, etc.).
Keep the antennas away from the unit, power
cord and other AV components to avoid picking
noise.
Secure the end of the FM lead antenna with
adhesive tape.
To prepare the AM loop antenna
Rewind an
antenna cord
wound around the
antenna and raise
the antenna stand.
Stand the
antenna and
secure it to the
slit until it clicks.
3
If “PLAY SET” flashes, press /  repeatedly
(enter) .
to select “CLOCK,” and then press
Press /  repeatedly to set the hour, then
(enter) .
press
4 Use the same procedure to set the minutes.
Note
The clock settings are reset when you disconnect the power
cord or if a power failure occurs.
To display the clock when the system is off
Press DISPLAY  repeatedly to display the clock.
The clock is displayed for about 8 seconds.
If the system is in BLUETOOTH Standby mode, the
clock does not appear by pressing DISPLAY .
Attaching speaker pads
Attach the supplied speaker pads to the bottom
of the speakers to prevent slipping.
* When “FLDR” or “FLDR SHUF” appears, all the files in the
selected folder on the MP3 disc will be played. When
playing a CD-DA disc, the system performs the same
operation as Normal Play (no indication) or Shuffle Play
“SHUF.”
When “PUSH STOP” appears
You cannot change the play mode during
playback. Stop playback then change the play
mode.
Note on the play mode
If the power cord is disconnected when the
system is on, the play mode returns to Normal
Play.
Notes on Repeat Play
ˎ“ˎ ” indicates that all tracks or files will be repeated until
you stop playback.
ˎ“ˎ
1” indicates that a single track or file will be repeated
until you stop playback.
ˎIf
ˎ the power cord is disconnected when the system is on,
Repeat Play is cancelled.
Notes on Shuffle Play mode
ˎWhen
ˎ
Shuffle Play mode is set to “SHUF,” the system
shuffle-plays all tracks or files on the disc. When Shuffle
Play mode is set to “FLDR SHUF,” the system shuffle-plays all
tracks or files in selected folder.
ˎWhen
ˎ
you turn off the system, the selected Shuffle Play
mode (“SHUF” or “FLDR SHUF”) is cleared and the play
mode returns to Normal or FLDR Play mode.
Notes on playing MP3 discs
ˎDo
ˎ not save unnecessary folders or files on a disc that has
MP3 files.
ˎFolders
ˎ
that have no MP3 files are not recognized on the
system.
ˎThe
ˎ
system can only play MP3 files that have a file
extension of “.mp3.”
when file name has the “.mp3” file extension, if it is
ˎEven
ˎ
not an audio MP3 file, playing this file may generate a loud
noise, which could cause damage of the system.
ˎThe
ˎ
maximum number of MP3 folders and files compatible
with this system is:
999* folders (including the root folder)
999 files
250 files in a single folder
8 folder levels (in the tree structure of files)
 to register the station.
“COMPLETE” appears in the display .
5 Repeat steps 1 through 4 to register other
stations.
You can preset up to 20 FM, 10 AM stations.
To tune in to a preset radio station
Press TUNING MODE  repeatedly until “PRESET”
appears in the display , and then press TUNE
+/  to select the preset number to which the
desired station is registered.
ˎWith
ˎ
some connected USB devices, it may take a long time
to transmit signals from the system or to finish reading the
USB device.
ˎCompatibility
ˎ
with all encoding/writing software cannot be
guaranteed. If audio files on the USB device were originally
encoded with incompatible software, those files may
produce noise or ,may malfunction.
ˎThe
ˎ
maximum number of folders and files on the USB
device compatible with this system is:
1,000* folders (including the root folder)
3,000 files
250 files in a single folder
8 folder levels (in the tree structure of files)
* This includes folders that have no playable audio file and
empty folders. The number of folders that the system
can recognize may be less than actual number of folders,
depending on the folder structure.
Notes
ˎIf
ˎ you initiate setup during BLUETOOTH connection, the
connection is cut.
ˎWhen
ˎ
using an Apple product, update it to the latest
software version. For details on updating, refer to the
operation manual supplied with your Apple product.
ˎIf
ˎ sound is interrupted during reception in AAC codec
format, set the BT AAC menu to “OFF.”
Pairing the system with a BLUETOOTH
device
Connection example
ˎThe
ˎ
system does not necessarily support all the functions
provided in a connected USB device.
that have no audio files are not recognized.
ˎFolders
ˎ
ˎThe
ˎ
audio formats that you can listen to with this system
are as follows:
MP3: file extension “.mp3”
WMA: file extension “.wma”
AAC: file extension “.m4a,” “mp4” or “.3gp”
Note that even when file name has the correct file
extension, if the actual file differs, the system may produce
noise or may malfunction.
BLUETOOTH device
such as a “WALKMAN”
4 Select the desired track or file number.
Notes
License and Trademark Notice
ˎWindows
ˎ
Media is either a registered trademark
or trademark of Microsoft Corporation in the
United States and/or other countries.
ˎMPEG
ˎ
Layer-3 audio coding technology and
patents licensed from Fraunhofer IIS and
Thomson.
ˎThe
ˎ
BLUETOOTH® word mark and logos are
registered trademarks owned by BLUETOOTH
SIG, Inc. and any use of such marks by Sony
Corporation is under license. Other trademarks
and trade names are those of their respective
owners.
ˎThe
ˎ
N Mark is a trademark or registered
trademark of NFC Forum, Inc. in the United
States and in other countries.
is a trademark of Google Inc.
ˎAndroid
ˎ
ˎThis
ˎ
product is protected by certain intellectual
property rights of Microsoft Corporation. Use or
distribution of such technology outside of this
product is prohibited without a license from
Microsoft or an authorized Microsoft subsidiary.
ˎThe
ˎ
system names and product names indicated
in this manual are generally the trademarks or
registered trademarks of the manufacturer. ™
and ® marks are omitted in this manual.
3 Press TUNE +/  repeatedly to select a
appears while the player is stopped.
Music discs encoded with copyright
protection technologies
CMT-SBT100
Creating your own program
(Program Play)
Preset number
2 Press PLAY MODE  repeatedly until “PGM”
Note on DualDiscs
A DualDisc is a two sided disc product which
mates DVD recorded material on one side with
digital audio material on the other side. However,
since the audio material side does not conform to
the Compact Disc (CD) standard, playback on this
product is not guaranteed.
* This include folders that have no MP3 or other files. The
number of folders that the system can recognize may
be less than actual number of folders, depending on the
folder structure.
2 Press TUNER MEMORY .
5 Press
Total playing time
of the selected
track or file
.
“--.--” appears when the total playing time
exceeds 100 minutes for an CD-DA or when you
program an MP3 files.
6 Repeat steps 3 through 5 to program
additional tracks or files, up to a total of 25
tracks or files.
7 Press  .
Your program of tracks or files starts playback.
The programmed files or tracks remain
available until you remove the disc from the
disc tray  or unplug the power cord.
To play the same program again, press  .
To cancel Program Play
Playing a file on a USB device
You can play audio files stored on a USB device by
connecting a USB memory or USB device to the
system. The playable audio format is MP3/WMA*/
AAC*.
Check the websites below for the information
about compatible USB devices.
For customers in the United States:
http://esupport.sony.com/
For customers in Canada:
http://esupport.sony.com/CA/
* Files with DRM (Digital Rights Management) copyright
protection or files downloaded from an online music store
cannot be played on this system. If you try to play one of
these files, the system plays the next unprotected audio
file.
1 Press USB FUNCTION  on the remote or
press FUNCTION  on the unit repeatedly
until “USB” appears in the display .
2 Connect the USB device directly or via the USB
cable supplied with the USB device to the USB
port  on the unit.
3 Press   to start playback.
Press PLAY MODE  repeatedly until “PGM”
disappears while the player is stopped.
Other operations
To
Do the following:
To delete the last track or file of the
program
Pause playback
Press  . To resume play,
press the button again.
Stop playback
Press  . To resume play,
press   *1. To cancel
resume play, press  
again*2.
Select a folder
Press
Select a file
Press / .
Find a point in
a file
Hold down / 
(/  on the unit)
during playback, and release
the button at the desired point.
Select Repeat
Play
Press REPEAT  repeatedly
until “ ” (all audio files) or
“ 1” (single audio file)
appears.
Press CLEAR  while the player is stopped.
Notes
ˎIf
ˎ the disc is ejected after programming, all the
programmed tracks or files are deleted.
ˎIf
ˎ the power cord is disconnected when the system is on,
the programmed tracks or files are deleted.
Listening to the radio
Tuning in a radio station
1 Press TUNER FUNCTION  on the remote or
press FUNCTION  on the unit repeatedly
until “TUNER FM” or “TUNER AM” appears in
the display.
2 Perform tuning.
For automatic scanning
Press TUNING MODE  repeatedly until “AUTO”
appears, and then press TUNE +/ . Scanning
stops automatically when a station is tuned in,
and “STEREO” (for stereo programs only) appears
in the display .
+/   repeatedly.
When playing a VBR MP3/WMA file, the system may
resume playback from a different point.
*2
When resume play is canceled, the display returns to the
number of folders.
*1
To change the play mode
Press PLAY MODE  repeatedly while the player
is stopped. You can select Normal Play mode (no
indication or “FLDR” appears*1), or Shuffle Play
mode (“SHUF” or “FLDR SHUF” appears*2).
Charging a USB device or iPod/
iPhone/iPad
If you connect a USB device or iPod/iPhone/iPad
to the USB port  when the system is turned on,
charging begins automatically.
To stop charging the USB device
Press /  to turn off the system, and then
disconnect the USB cable.
Notes
ˎYou
ˎ
cannot charge the USB device or iPod/iPhone/iPad
when the system is off. Some USB devices and iPod/iPhone
may not be charged owing to their characteristics.
ˎIf
ˎ the system enters Standby mode during charging of a
USB device or iPod/iPhone/iPad, the charging stops in
progress. Before charging, turn off the Automatic Standby
function. For details, see “Setting the Automatic Standby
function.”
Using the BLUETOOTH function
You can listen to music from your iPod/iPhone/
iPad or BLUETOOTH device over a wireless
connection.
Before using the BLUETOOTH function, perform
pairing to register your BLUETOOTH device.
The system supports registration and connection
of the BLUETOOTH device and NFC, which enables
data communication by just touching a specified
location. For details on NFC, see “Connecting by
one-touch action (NFC).”
What is pairing?
The BLUETOOTH devices to be connected must be
registered with each other beforehand. Pairing is
an operation of registering two devices.
Once a pairing operation is performed, it does
not have to be performed again. In the following
cases, however, a pairing operation must be
performed again:
ˎˎPairing information was erased when the
BLUETOOTH device was repaired.
ˎˎYou attempt to pair the system with more than
10 BLUETOOTH devices.
This system can pair with up to 9 BLUETOOTH
devices. If you pair another BLUETOOTH device
after pairing with 9 devices was performed,
pairing information of the device that was
connected with the system first is overwritten
with that of the new device.
ˎˎPairing registration information of this system is
erased from the connected device.
ˎˎIf you initialize the system or erase the
pairing history with the system, all the pairing
information will be erased.
When no indication is selected, the system plays all files on
the USB device. When “FLDR” is selected, the system plays
all files in the selected folder on the USB device.
*2
When “SHUF” is selected, the system shuffle-plays all audio
files on the USB device. When “FLDR SHUF” is selected, the
system shuffle-plays all audio files in the selected folder.
The BLUETOOTH indicator in the center of the
BLUETOOTH button  allows checking of the
BLUETOOTH status.
Note on the play mode
System status
*1
If the scanning does not stop, press   to stop
scanning, then perform manual tuning (below).
When you tune in a station that provides RDS
services, information such as the service name or
station name is provided by broadcasts.
For manual tuning
Press TUNING MODE  repeatedly until
“MANUAL” appears, and then press TUNE +/ 
repeatedly to tune in the desired station.
Tip
To reduce static noise on a weak FM stereo station, press FM
MODE  repeatedly until “MONO” appears to turn off stereo
reception.
To change the AM tuning interval
The default setting for AM tuning interval is 9 kHz
(or 10 kHz for some areas). Use the buttons on the
unit to perform this operation.
1 Press FUNCTION  on the unit repeatedly to
select the AM station.
2 Press /  to turn off the system.
3 Press and hold FUNCTION  and press / 
on the unit.
“STEP 9K” or “STEP 10K” appears in the display
. When you change the interval, all the AM
preset stations are erased.
Presetting radio stations
1 Tune in the desired station.
If the power cord is disconnected when the
system is on, the play mode returns to Normal
Play.
Notes on Repeat Play
ˎ“ˎ ” indicates that all files will be repeated until you stop
playback.
ˎ“ˎ
1” indicates that a single file will be repeated until you
stop playback.
ˎIf
ˎ the power cord is disconnected when the system is on,
Repeat Play is cancelled.
Note on Shuffle Play mode
When you turn off the system, the selected Shuffle Play
mode (“SHUF” or “FLDR SHUF”) is cleared and the play mode
returns to Normal Play mode (no indication or “FLDR”).
Notes
ˎThe
ˎ
playback order for the system may differ from the
playback order of the connected digital music player.
ˎBe
ˎ sure to turn off the system before removing the USB
device. Removing the USB device while the system is turned
on may corrupt the data on the USB device.
ˎWhen
ˎ
USB cable connection is necessary, connect the USB
cable supplied with the USB device to be connected. For
details on connection, refer to the operation manual of the
USB device.
ˎIt
ˎ may take time before “READING” appears after
connecting, depending on the type of USB device
connected.
ˎDo
ˎ not connect the USB device through a USB hub.
ˎWhen
ˎ
the USB device is connected, the system reads all the
files on the USB device. If there are many folders or files on
the USB device, it may take a long time to finish reading the
USB device.
About the BLUETOOTH indicator
Indicator status
The system is in
Flashes slowly in blue.
BLUETOOTH Standby
(when the system is on).
During BLUETOOTH
Flashes quickly in blue.
pairing
The system is
Flashes in blue.
attempting to connect
with a BLUETOOTH
device.
The system has
Lit in blue.
established in
connection with a
BLUETOOTH device.
Enabling reception of AAC codec
You can receive data in AAC codec format from a
BLUETOOTH device. To enable reception, set up
using the option menu.
1 Press OPTIONS  to display the setting menu.
2 Press /  repeatedly to select “BT AAC,”
then press
.
3 Press /  repeatedly to select “ON” or
“OFF,” then press .
ON: to receive in AAC codec format
OFF: to receive in SBC codec format
1 Place the BLUETOOTH device to be connected
within 1 meter from the system.
2 Press BLUETOOTH FUNCTION  or press
FUNCTION  on the unit repeatedly until “BT
AUDIO” appears in the display .
ˎˎThe BLUETOOTH indicator  flashes slowly
in blue.
ˎˎIf the system has been automatically
connected with the BLUETOOTH device in
the past, press BLUETOOTH  on the unit
to cancel the connection so that “BT AUDIO”
appears in the display .
3 Press and hold BLUETOOTH  on the unit for
2 seconds or longer.
The BLUETOOTH indicator  flashes quickly in
blue and “PAIRING” flashes in the display .
The system is in Pairing mode.
4 Perform the pairing operation on the
BLUETOOTH device and search for this system
with the BLUETOOTH device.
When searching has finished, a list of the
devices found may appear on the BLUETOOTH
device display.
ˎˎThis system appears as “SONY:CMT-SBT100.”
If it does not appear, perform the procedure
from step 1 again.
ˎˎWhen establishing connection with this
system, select the audio profile (A2DP, AVRCP)
on the BLUETOOTH device.
ˎˎIf the BLUETOOTH device does not support
AVRCP (Audio Video Remote Control Profile),
you cannot perform playback or stop
playback with the system.
ˎˎFor details on operations of the BLUETOOTH
device to be connected, refer to the operation
manual supplied with your BLUETOOTH
device.
5 Select “SONY:CMT-SBT100” in the display of
the BLUETOOTH device.
If prompted to enter a passkey on the
BLUETOOTH device, enter “0000.”
6 Operate the BLUETOOTH device and perform
BLUETOOTH connection.
When pairing is completed and connection
with the BLUETOOTH device is established
correctly, the display  changes to “BT AUDIO”
from “PAIRING” and the BLUETOOTH indicator
 flashes slowly in blue.
ˎˎDepending on the type of BLUETOOTH device,
connection may start automatically after
pairing is completed.
Notes
ˎ“Passkey”
ˎ
may be called “Passcode,” “PIN code,” “PIN
number” or “Password,” etc., depending on the device.
ˎThe
ˎ
pairing standby status of the system is cancelled after
about 5 minutes. If pairing is not successful, perform the
procedure from step 1.
ˎIf
ˎ you want to pair with several BLUETOOTH devices,
perform the procedure from step 1 to 6 individually for each
BLUETOOTH device.
Tip
You can perform a pairing operation or attempt to make a
BLUETOOTH connection with another BLUETOOTH device
while the BLUETOOTH connection is established with one
BLUETOOTH device. The currently established BLUETOOTH
connection is cancelled when BLUETOOTH connection with
another device is successfully established.
To erase the pairing registration
information
1 Press BLUETOOTH FUNCTION  on the remote
or press FUNCTION  on the unit repeatedly
until “BT AUDIO” appears in the display .
When the system is connected with a
BLUETOOTH device, the device name set for the
connected BLUETOOTH device appears in the
display  of the system. Press BLUETOOTH 
on the unit to cancel the connection with that
BLUETOOTH device then display “BT AUDIO.”
2 Press OPTIONS  to display the setting menu.
3 Press /  repeatedly to select “DEL LINK,”
then press
.
4 Press /  repeatedly to select “OK,” then
press .
“COMPLETE” appears and all the pairing
information is erased.
Note
If you have erased the pairing information, you cannot make
a BLUETOOTH connection unless pairing is performed again.
To connect with a BLUETOOTH device again, you must enter
the passkey on the BLUETOOTH device.
Connecting by one-touch action (NFC)
NFC enables data communication by just touching
your device to a specified location.
Compatible smartphones are those equipped
with the NFC function (compatible operating
system: Android version 2.3.3 or later with the
exception of Android 3.x).
Check the website below for information on
compatible devices.
For customers in the United States:
http://esupport.sony.com/
For customers in Canada:
http://esupport.sony.com/CA/
Preparation on your smartphone (Android)
An NFC-compliant application must be installed
on your smartphone. If not installed, you can
download “NFC Easy Connect” from Google Play.
ˎˎIn some countries and regions, NFC-compliant
application may not be downloaded.
ˎˎFor some smartphones, this function may
be available without downloading “NFC Easy
Connect.” In this case, the operation and
specifications of the smartphone may be
different from the description in this manual.
1 Install the application.
If you access using 2D Code
Read the following 2D Code to access.
3 Press   to start playback.
Depending on the BLUETOOTH device, you may
have to press   twice.
Depending on the BLUETOOTH device, you
may have to start up the AV software of the
BLUETOOTH device beforehand.
function.
For details, refer to the user’s guide supplied
with your smartphone.
About the “NFC Easy Connect” application
This is a free application especially used for
Android. Search the internet for detailed
information on “NFC Easy Connect” and download
the application.
ˎˎIn some countries and regions, NFC-compliant
application may not be downloaded.
Making a connection with your
smartphone by one-touch action
Just touch your smartphone to the system. The
system is turned on automatically, and pairing
and BLUETOOTH connection are established.
1 Start the “NFC Easy Connect” application on
your smartphone.
Check that the application display appears.
2 Touch your smartphone to the unit.
Touch the smartphone to the N-Mark  on the
unit and maintain contact until the smartphone
vibrates.
Other operations
To
Do the following:
Pause playback
Press  *.
Stop playback
Press  .
Select a folder
Press
Select a file
Press / .
Find a point in
a file
Hold down /  (or
/  on the unit)
during playback and release
the button at the desired point.
+/ .
* Depending on the BLUETOOTH device, you may have to
press   twice.
Note
These operations may not be available for certain
BLUETOOTH devices. In addition, the actual operations may
differ depending on the connected BLUETOOTH device.
Press DISPLAY  while the BLUETOOTH device
name set on the connected BLUETOOTH device is
shown in the display . The BLUETOOTH device
address appears in two installments on the
system display for 8 seconds.
To cancel the connection with a
BLUETOOTH device
Press BLUETOOTH  on the unit. “DISCONNECT”
appears in the display .
Depending on the BLUETOOTH device, the
connection may be cancelled automatically when
you stop playback.
Using optional audio
components
1 Press VOLUME   on the remote or turn the
VOLUME dial  on the unit left to turn down
the volume.
2 Connect additional audio component to the
AUDIO IN jack  using an audio connecting
cable (not supplied).
3 Press AUDIO IN FUNCTION  on the remote
or press FUNCTION  on the unit repeatedly
until “AUDIO IN” appears in the display .
4 Start playback of the connected component.
Adjust the volume on the connected
component during playback.
Note
The system may enter Standby mode automatically if the
volume level of the connected component is too low. Adjust
the component’s volume accordingly.
Listening to music through a
BLUETOOTH connection
You can operate a BLUETOOTH device by
connecting the system and a BLUETOOTH device
using AVRCP.
Check the following before playing music:
ˎˎThe BLUETOOTH function of the BLUETOOTH
device is enabled.
ˎˎPairing has been completed.
1 Press BLUETOOTH FUNCTION  on the
remote or press FUNCTION  on the unit
repeatedly until “BT AUDIO” appears in the
display .
2 Establish BLUETOOTH connection with the
BLUETOOTH device.
Once the connection is established, “CONNECT”
appears in the display  then the BLUETOOTH
device name set with the BLUETOOTH device
appears.
If the BLUETOOTH device has been
connected with this system in the past, it
may be connected automatically with no user
operation required.
“OFF,” then press
Setting the Automatic Standby
function
With the Automatic Standby function, the
system enters Standby mode automatically in
about 15 minutes when there is no operation
or audio signal output. “AUTO STBY” appears in
the display  for 2 minutes before the system
enters Standby mode. By default, the Automatic
Standby function is turned on. You can turn off
the function using the option menu.
1
2 Press /  repeatedly to select “AUTO
Press OPTIONS  to display the setting menu.
STBY,” then press
.
3 Press /  repeatedly to select “ON” or
“OFF,” then press
.
Notes
ˎThe
ˎ
Automatic Standby function is invalid for the tuner
function (FM/AM), even when you have enabled it.
ˎThe
ˎ
system may not enter Standby mode automatically in
the following cases:
while an audio signal is being detected
during playback of audio tracks or files
while the preset Sleep Timer or Play Timer is in process
ˎThe
ˎ
system counts down the time (15 minutes) again until
it enters Standby mode, even when Automatic Standby
function is enabled when a USB device is connected or
when a button on the remote or unit is pressed.
Setting the BLUETOOTH Standby
mode
You can enable/disable BLUETOOTH Standby
mode.
When BLUETOOTH Standby mode is enabled,
the system enters Wait mode for BLUETOOTH
connection even when the system is turned off.
If the system receives a playback command from
the connected BLUETOOTH device, it turns on and
music is played back. The BLUETOOTH Standby
mode is disabled by default.
1 Press OPTIONS  to display the setting
menu.
.
4 Press / (power)  to turn off the system.
When “BT STBY” is set to “ON,” the system turns
on and you can listen to music by activating
BLUETOOTH on the connected component.
Note
the VOLUME dial  on the unit left or right to
adjust the volume.
ˎˎTo disconnect the established connection, touch
your smartphone to the N-Mark  on the unit.
ˎˎWhen you touch an NFC-compliant smartphone
to the unit while another BLUETOOTH device
is connected with this system, the BLUETOOTH
device is disconnected and the system is
connected with the smartphone.
ˎˎIf you touch the smartphone connected with this
system to another NFC-compliant BLUETOOTH
headset or speaker, the smartphone is
disconnected from the system and connected
with the touched BLUETOOTH device.
.
3 Press /  repeatedly to select “ON” or
the VOLUME dial  on the unit left or right to
adjust the volume.
5 Press VOLUME +/  on the remote or turn
Complete the connection with your
smartphone, following the instructions on the
screen.
Refer to the user’s guide of your smartphone
for the part of your smartphone used as touch
contact.
then press
4 Press VOLUME +/  on the remote or turn
To check the address of a connected
BLUETOOTH device
2 Set your smartphone to enable the NFC
2 Press /  repeatedly to select “BT STBY,”
“BT STBY” does not appear in the setting menu, if the
BLUETOOTH device is not registered on this system.
Adjusting the sound
Setting the bass boost
Press BASS BOOST  repeatedly to select “ON”
or “OFF.”
Adjusting the bass and treble
Press BASS +/  to adjust bass or TREBLE +/
 to adjust treble.
Or, press EQ  on the unit repeatedly to select
“BASS” or “TREBLE,” and adjust the selected item
using TUNE +/ .
Tip
This system is equipped with the DSEE function to reproduce
clear treble despite degradation caused by compression.
The DSEE function is usually activated automatically by
recognizing the sound source, but it may not be activated
depending on the function in use.
Changing the display
To
Do the following:
View
Press DISPLAY  repeatedly
information on when the system is on.
the display  *1
Display clock
Press DISPLAY  repeatedly
when the system is off. *2 The
clock appears for about 8
seconds.
You can view the information described below during
playback of a CD-DA/MP3 disc.
*2
The information does not appear in BLUETOOTH mode.
*1
CD-DA disc
remaining playing time of a track during
playback
total remaining playing time
MP3 disc
track or file name
artist name
album name
Notes on the display information
ˎCharacters
ˎ
that cannot be displayed appear as “_”.
ˎThe
ˎ
following are not displayed:
remaining playing time or total playing time for an MP3
disc
remaining playing time for an MP3 file
ˎThe
ˎ
following are not displayed correctly:
elapsed playing time of an MP3 file encoded using VBR
(Variable Bit Rate).
folder and file names that do not follow either the
ISO9660 Level 1/Level 2 or Joliet in the expansion format.
ˎThe
ˎ
following are displayed:
total playing time for a CD-DA disc (except when PGM
mode is selected and the player is stopped)
remaining playing time for a track of CD-DA disc
remaining playing time for a CD-DA disc (only when
Normal Play mode is selected during playback)
ID3 tag information for MP3 files. ID3 version 2 tag
information display has priority when both ID3 version 1
and version 2 tags are used for a single MP3 file.
up to 64 characters for an ID3 tag, where characters
allowed are uppercase letters (A to Z), numbers (0 to 9),
and symbols (˝ $ % ’ ( ) * + , – . / < = > @ [ \ ] _ ` { | } ! ? ^ ~)
Using the timers
The system offers Sleep Timer and Play Timer. The
Sleep Timer has priority over the Play Timer.
Setting the Sleep Timer
The system is turned off automatically after the
time set for the Sleep Timer is elapsed.
The Sleep Timer works even if the clock is not set.
1 Press SLEEP  repeatedly to specify the time.
ˎˎSelect “30MIN” to turn off the system after 30
minutes.
ˎˎTo cancel the Sleep Timer, select “OFF.”
Setting the Play Timer
You can listen to a CD-DA or MP3 disc or radio
every day at a preset time.
Make sure you have set the clock before setting
the timer.
1 Prepare the sound source, and turn the
VOLUME dial  on the unit left or right or
press VOLUME +/  on the remote to adjust
the volume.
The available sound sources are: CD, USB, and
TUNER (FM or AM) FUNCTION.
To start from a specific CD track, audio file or
radio station, create your own program.
2 Press TIMER MENU .
3 Press /  repeatedly to select “PLAY SET,”
then press .
The start time flashes in the display.
4 Set the time to start operation.
Press /  repeatedly to set the hour, then
press .
The minute indication flashes. Use the
procedure above to set the minutes.
When the start time is set, the system goes to
the stop time setting.
5 Use the same procedure as in step 4 to set the
time to stop the operation.
If “TIME NG” flashes in the display
The start time and the stop time are set to the
same time. Change the stop time.
6 Select the sound source.
Press /  repeatedly until the desired
sound source appears, then press .
For the available sound sources, see step 1.
After the sound source selection is finished,
the confirmation display for the Play Timer
appears.
7 Press / (power)  to turn off the system.
ˎˎWhen the Play Timer is set, the system
automatically turns on about 15 seconds (for
FM or AM) or about 90 seconds (for a CD-DA
disc or USB device) before the preset time.
ˎˎThe Play Timer does not work if the system
is on at the preset time. Be careful not to
operate the system until it is turned on and
starts play with the timer.
To check the setting
1 Press TIMER MENU .
2 Press /  repeatedly to select “TIMER SEL,”
and then press
.
3 Press /  repeatedly to select “PLAY SEL,”
and then press .
The timer setting appears in the display.
To cancel the timer
Repeat the same procedure as “To check the
setting” until “OFF” appears in step 3, and then
press .
ˎˎThe balance of left and right sound is false.
Check the left and right speakers are connected
correctly.
ˎˎPut the speakers symmetrically.
ˎˎConnect the supplied speakers.
Severe hum or noise occurs.
ˎˎMove the system away from sources of noise.
ˎˎConnect the system to a different wall outlet.
ˎˎUse of an AC power tap with a noise filter (not
supplied) is recommended.
The USB device cannot be charged.
CD-DA/MP3 disc
“LOCKED” appears in the display  and
the disc cannot be removed from the disc
tray.
ˎˎConsult your nearest Sony dealer or local
authorized Sony service facility.
The disc or file will not play.
ˎˎThe disc that has not been finalized (a CD-R or
CD-RW disc to which data can be added).
The sound skips, or the disc will not play.
ˎˎWipe the disc clean, and replace it.
ˎˎMove the system to a location away from
vibration (for example, on top of a stable stand).
ˎˎOscillation of the speakers may be the cause
of sound skips, depending on the volume
level. Move the speakers away from the unit or
change the location of the speakers.
Play does not start from the first track or
file.
ˎˎReturn to normal play by pressing PLAY MODE
 repeatedly in stop mode until both “PGM”
and “SHUF” in the display  disappear.
ˎˎThe following discs can increase the time it takes
to start playback:
a disc recorded with a complicated tree
structure.
a disc recorded in multi-session format.
a disc that has many folders.
The Play Timer setting remains as long as the setting is not
cancelled manually.
Troubleshooting
1 Make sure the power cord is firmly connected.
2 Find your problem in the checklist below, and
take the indicated corrective action.
If the issue persists, contact your nearest Sony
dealer.
If the STANDBY indicator  flashes
Immediately unplug the power cord, and check
the following item.
ˎˎIs the speaker cord shorted out?
After the STANDBY indicator  stops flashing,
reconnect the power cord, and turn on the
system. If the issue persists, contact your
nearest Sony dealer.
General
The system does not turn on.
ˎˎIs the power cord plugged in correctly?
The system has entered Standby mode
unexpectedly.
ˎˎThis is not a malfunction. The system enters
Standby mode automatically in about 15
minutes when there is no operation or audio
signal output. See “Setting the Automatic
Standby function.”
The clock setting or the Play Timer
operation has been cancelled
unexpectedly.
ˎˎIf about a minute elapses with no operation, the
clock setting or Play Timer setting is cancelled
automatically. Perform the operation again from
the beginning.
There is no sound.
ˎˎMake sure the speaker cords are connected
correctly.
ˎˎCheck the supplied speakers are used.
ˎˎTurn the VOLUME dial  on the unit clockwise
or press VOLUME +  on the remote to turn up
the volume.
ˎˎMake sure the headphones are disconnected
from the headphone jack.
ˎˎMake sure an external component is connected
correctly to the AUDIO IN jack  and set the
function to AUDIO IN.
ˎˎThe specified station may have temporarily
stopped broadcast.
Play does not start from the first track.
ˎˎSet the play mode to Normal Play mode.
Notes
Tip
ˎˎTurn off the system and reconnect the USB
device, then turn on the system.
ˎˎCheck the information on the websites about
compatible USB devices with URLs listed under
“Playing a file on a USB device.”
ˎˎRemove any obstacles between the remote and
the remote sensor  on the unit, and position
the unit away from fluorescent lights.
ˎˎPoint the remote at the remote sensor on the
unit.
ˎˎMove the remote closer to the system.
Starting playback takes more time than
usual.
ˎWhen
ˎ
the sound source for a Play Timer is set to a radio
station that you set using Automatic Scanning (AUTO)
or Manual Tuning (MANUAL) and you change the radio
frequency or band after setting the timer, the radio station
setting for the timer will also be changed.
ˎWhen
ˎ
the sound source for a Play Timer is set to a radio
station tuned from a preset radio station (preset number 1
to 20), and if you change the frequency of the radio station
or band after setting the timer, the radio station setting for
the timer will not change. The radio station tuning for the
timer is fixed at what you set for it.
Play does not start.
The remote does not function.
To change the setting
Start over from step 1.
ˎˎThe USB device does not work properly. Refer
to the operating manual supplied with the USB
device for how to deal with this problem.
USB device
An unsupported USB device is connected.
ˎˎIf you connect an unsupported USB device,
the following problems may occur. Check the
information on the websites about compatible
USB devices with URLs listed under “Playing a
file on a USB device.”
The USB device is not recognized.
File or folder names are not displayed on this
system.
Playback is not possible.
The sound skips.
There is noise.
A distorted sound is output.
There is no sound.
ˎˎThe USB device is not connected correctly. Turn
off the system, and then reconnect the USB
device.
There is noise, skipping, or distorted
sound.
ˎˎAn unsupported USB device is connected.
Connect a supported USB device.
ˎˎTurn off the system, then reconnect the USB
device and turn on the system.
ˎˎThe music data itself contains noise, or the
sound is distorted. Noise may have been
entered when creating music data due to the
conditions of the computer. In this case, delete
the file and send the music data again.
ˎˎThe bit rate used when encoding the files was
low. Send files encoded with higher bit rates to
the USB device.
“READING” is displayed for an extended
time, or it takes a long time before
playback starts.
ˎˎThe reading process may take a long time in the
following cases.
There are many folders or files on the USB
device.
The file structure is extremely complex.
Not enough free space in the memory.
The internal memory is fragmented.
The file or folder name (album name) is
not displayed correctly.
ˎˎSend the music data to the USB device again,
as the data stored in the USB device may have
been corrupted.
ˎˎThe character code that can be displayed by this
system are as follows:
Upper cases (A to Z).
Numbers (0 to 9).
Symbols (< > * +, [ ] @ \ _).
Other characters appear as “_.”
The USB device is not recognized.
ˎˎTurn off the system and reconnect the USB
device, then turn on the system.
ˎˎCheck the information on the websites about
compatible USB devices with URLs listed under
“Playing a file on a USB device.”
ˎˎMake sure the USB device is connected securely.
ˎˎCharging cannot be made when the power of
the system is off.
ˎˎThe USB device may not be supported by this
system. Check the information on the websites
about compatible USB devices.
Tuner
Severe hum or noise occurs (“STEREO”
flashes in the display window ), or
broadcasts cannot be received.
ˎˎConnect the antenna properly.
ˎˎFind a location and an orientation that provide
good reception, and then set up the antenna
again.
ˎˎKeep the antennas away from the unit, speaker
cord or other AV components to avoid picking
up noise.
ˎˎTurn off nearby electrical equipment.
Several radio stations can be heard at the
same time.
ˎˎFind a location and an orientation that provide
good reception, and then set up the antenna
again.
ˎˎBundle the antenna cables using commercially
available cord clips, for example, and adjust the
cable lengths.
To reset the system to factory settings
If the system still does not operate properly, reset
the system to factory settings.
Use buttons on the unit to reset the system to its
factory default settings.
1 Disconnect the power cord and confirm that
the STANDBY indicator  is not lit. Then
reconnect the power cord and turn on the
system.
2 Press and hold   and /  on the unit
until “RESET” appears in the display.
All user-configured settings, such as preset
radio stations, timer, and the clock, are deleted.
If the problem persists after doing all of the
above, consult your nearest Sony dealer.
Messages
CANNOT PLAY: The system cannot play audio
files due to an unsupported file format or
playback restriction.
CAN’T PLAY: You have set a disc that cannot be
played back on this system, such as CD-ROM
and DVD disc.
COMPLETE: The station preset operation ended
normally.
DATA ERROR: You tried to play an unplayable file.
ERROR: You operated the system during
initialization. Wait for a while until the
initialization is completed.
LOCKED: The disc tray  is locked and you
cannot remove the disc. Contact your nearest
Sony dealer.
NO DEVICE: No USB device is connected or the
connected USB device has been removed.
NO DISC: There is no disc in the player, or you
have loaded a disc that cannot be played.
NO MEMORY: The memory media is not inserted
in the USB device, or the system does not
identify the memory media.
NO STEP: All of the programmed tracks have
been erased.
NO SUPPORT: The system does not support the
connected USB device.
NO TRACK: There are not playable files on the
USB device or disc.
NOT IN USE: You pressed an unplayable button.
OVER CURRENT: Remove the USB device from
the port and turn off the system then turn on
the system.
PUSH STOP: You pressed PLAY MODE  during
playback in the CD or USB function.
READING: The system is reading the information
on the disc or USB device. Some buttons do not
work during reading.
STEP FULL: You tried to program more than 25
tracks or files.
TIME NG: The Play Timer start and end times are
set to the same time.
Precautions
Discs that this system CAN play
ˎˎAudio CD-DA discs
ˎˎCD-R/CD-RW (audio data of CD-DA tracks and
MP3 files)
Do not use a CD-R/CD-RW disc with no data
stored. Doing so may damage the disc.
Discs that this system CANNOT play
ˎˎCD-ROM
ˎˎCD-R/CD-RW other than those recorded in
music CD format or MP3 format conforming to
ISO9660 Level 1/Level 2, Joliet
ˎˎCD-R/CD-RW recorded in multi-session format
and not closed the session
ˎˎCD-R/CD-RW of poor recording quality,
CD-R/CD‑RW that have scratches or are dirty,
or CD‑R/CD-RW recorded with an incompatible
recording device
ˎˎCD-R/CD-RW which is finalized incorrectly
ˎˎDiscs containing files other than MPEG 1 Audio
Layer-3 (MP3) files
ˎˎDiscs of non-standard shape (for example, heart,
square, star)
ˎˎDiscs that have adhesive tape, paper, or sticker
attached to them
ˎˎRental or used discs with attached seals where
the glue extends beyond the seal
ˎˎDiscs that have labels printed using ink that feels
tacky when touched
ˎBecause
ˎ
of the properties of BLUETOOTH wireless
technology, playback on this system is slightly delayed
compared with audio playback on the transmitting device.
Effective communication range
BLUETOOTH devices should be used within
approximately 10 meters (unobstructed distance)
of each other. The effective communication
range may become shorter under the following
conditions.
When a person, metal object, wall or other
obstruction is between the devices with a
BLUETOOTH connection
Locations where a wireless LAN is installed
Around microwave ovens that are in use
Locations where other electromagnetic waves
occur
Effects of other devices
ˎˎBefore playing, wipe the disc with a cleaning
cloth from the center out to the edge.
ˎˎDo not clean discs with solvents, such as
benzine, thinner, or commercially available
cleaners or anti-static spray intended for vinyl
LPs.
ˎˎDo not expose discs to direct sunlight or heat
sources such as hot air ducts, nor leave it in a car
parked in direct sunlight.
BLUETOOTH devices and wireless LAN (IEEE
802.11b/g) use the same frequency band (2.4
GHz). When using your BLUETOOTH device
near a device with wireless LAN capability,
electromagnetic interference may occur. This
could result in lower data transfer rates, noise,
or inability to connect. If this happens, try the
following remedies:
Try connecting this system and BLUETOOTH
mobile phone or BLUETOOTH device when you
are at least 10 meters away from the wireless
LAN equipment.
Turn off the power to the wireless LAN
equipment when using your BLUETOOTH
device within 10 meters.
On safety
Effects on other devices
Notes on CD-DA discs
ˎˎCompletely disconnect the power cord (mains
lead) from the wall outlet (mains) if it is not
going to be used for an extended period of time.
When unplugging the system, always grip the
plug. Never pull the cord itself.
ˎˎShould any solid object or liquid get into the
system, unplug the system, and have it checked
by qualified personnel before operating it again.
ˎˎThe AC power cord can be changed only by a
qualified service facility.
On placement
ˎˎDo not place the system in an inclined position
or in locations that are extremely hot, cold, dusty,
dirty, or humid or lacking adequate ventilation,
or subject to vibration, direct sunlight or a bright
light.
ˎˎBe careful when placing the system on surfaces
that have been specially treated (for example,
with wax, oil, polish) as staining or discoloration
of the surface may result.
ˎˎIf the system is brought directly from a cold to a
warm location or is placed in a very damp room,
moisture may condense on the lens inside the
CD player, and cause the system to malfunction.
In this situation, remove the disc, and leave the
system turned on for about an hour until the
moisture evaporates.
On heat buildup
ˎˎHeat buildup on the unit during operation is
normal and is not cause for alarm.
ˎˎDo not touch the cabinet if it has been used
continuously at a high volume because the
cabinet may have become hot.
ˎˎDo not obstruct the ventilation holes.
On the speaker system
This speaker system is not magnetically shielded,
and the picture on nearby TV sets may become
magnetically distorted. In this situation, turn off
the TV, wait 15 to 30 minutes, and turn it back on.
Cleaning the cabinet
Clean this system with a soft cloth slightly
moistened with a mild detergent solution. Do not
use any type of abrasive pads, scouring powder,
or solvents, such as thinner, benzine, or alcohol.
BLUETOOTH wireless
technology
BLUETOOTH wireless technology is a short-range
wireless technology linking digital devices, such
as personal computers and digital still cameras.
Using the BLUETOOTH wireless technology, you
can operate the units involved within a range of
about 10 meters.
The BLUETOOTH wireless technology is commonly
used between two devices, but a single device
can be connected to multiple devices.
You do not need wires to get connected as you
do with a USB connection, and you do not need
to place the devices face to face as you do with
wireless infrared technology. You can use the
technology with one BLUETOOTH device in your
bag or pocket.
BLUETOOTH wireless technology is a global
standard supported by thousands of companies.
These companies produce products that meet the
global standard.
Supported BLUETOOTH version and
profiles
Profile refers to a standard set of capabilities for
various BLUETOOTH product capabilities. See
“Specifications” for details on the supported
BLUETOOTH version and profiles.
Notes
ˎTo
ˎ use a BLUETOOTH device connected to this system,
the device must support the same profile as this system.
Note that the functions of the BLUETOOTH device may be
different depending on the specifications of the device,
even if it has the same profile as this system.
The radio waves broadcast by this system may
interfere with the operation of some medical
devices. Since this interference may result in
malfunction, always turn off the power on
this system, BLUETOOTH mobile phone and
BLUETOOTH device in the following locations:
In hospitals, on trains, and in airplanes
Near automatic doors or fire alarms
Notes
ˎThis
ˎ
system supports security functions that comply with
the BLUETOOTH specification as a means of ensuring
security during communication using BLUETOOTH
technology. However, this security may be insufficient
depending on the setting contents and other factors, so
always be careful when performing communication using
BLUETOOTH technology.
ˎSony
ˎ
cannot be held liable in any way for damages or other
loss resulting from information leaks during communication
using BLUETOOTH technology.
ˎBLUETOOTH
ˎ
communication is not necessarily guaranteed
with all BLUETOOTH devices that have the same profile as
this system.
ˎBLUETOOTH
ˎ
devices connected with this system must
comply with the BLUETOOTH specification prescribed
by the BLUETOOTH SIG, Inc., and must be certified to
comply. However, even when a device complies with the
BLUETOOTH specification, there may be cases where the
characteristics or specifications of the BLUETOOTH device
make it impossible to connect, or may result in different
control methods, display or operation.
ˎNoise
ˎ
may occur or the audio may cut off depending on
the BLUETOOTH device connected with this system, the
communications environment, or surrounding conditions.
Specifications
Amplifier section
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
(The United States model only)
With 6 ohm loads, both channels driven, from
120 - 10,000 Hz; rated 20 watts per channel
minimum RMS power, with no more than 0.7%
total harmonic distortion from 250 milliwatts to
rated output.
Power output (rated): 20 watts + 20 watts
(at 6 ohms, 1 kHz, 1% THD)
RMS power output (reference): 25 watts + 25 watts
(per channel at 6 ohms, 1 kHz)
Inputs/Outputs
AUDIO IN (external input) jack:
Stereo mini jack, sensitivity 700 mV, impedance
47 kilohms
 (headphone) jack:
Stereo mini jack, 8 ohms or more
USB:
Supported bit rate: MP3 (MPEG 1 Audio Layer-3):
32 kbps – 320 kbps, VBR
WMA: 48 kbps - 192 kbps, VBR
AAC: 48 kbps - 320 kbps
Sampling frequencies: MP3 (MPEG 1 Audio
Layer-3): 32/44.1/48 kHz
WMA: 44.1 kHz
AAC: 44.1 kHz
USB port: Type A, 5 V DC 2.1 A
CD-DA/MP3 player section
System: Compact disc and digital audio system
Laser Diode Properties
Emission Duration: Continuous
Laser Output*: Less than 44.6 µW
*This output is the value measurement at a
distance of 200mm from the objective lens
surface on the Optical Pick-up Block with 7mm
aperture.
Frequency response: 50 Hz – 20 kHz
Signal-to-noise ratio: More than 90 dB
Dynamic range: More than 90 dB
Tuner section
AM tuner section:
Tuning range:
530 kHz – 1,710 kHz (with 10 kHz tuning
interval)
531 kHz – 1,710 kHz (with 9 kHz tuning interval)
Antenna: AM loop antenna
Intermediate frequency: 400 kHz
FM tuner section:
FM stereo, FM superheterodyne tuner
Antenna: FM lead antenna
Tuning range: 87.5 MHz – 108.0 MHz (100 kHz
step)
BLUETOOTH section
Communication system:
BLUETOOTH Standard version 3.0
Output:
BLUETOOTH Standard Power Class 2
Maximum communication range:
Line of sight approx. 10 m*1
Frequency band:
2.4 GHz band (2.4000 GHz - 2.4835 GHz)
Modulation method:
FHSS
Compatible BLUETOOTH profiles*2:
A2DP (Advanced Audio Distribution Profile)
AVRCP (Audio Video Remote Control Profile)
Supported content protection method:
SCMS-T method
Transmission bandwidth:
20 Hz – 20,000 Hz (with 44.1 kHz sampling)
The actual range will vary depending on
factors such as obstacles between devices,
magnetic fields around a microwave oven,
static electricity, reception sensitivity, antenna’s
performance, operating system, software
application, etc.
*2
BLUETOOTH standard profiles indicate the
purpose of BLUETOOTH communication
between devices.
*1
Speaker section
2-way speaker system, Bass Reflex
Woofer: 100 mm, cone type
Tweeter: 40 mm, cone type
Dimensions (W/H/D):
Approx. 150 mm × 240 mm × 220 mm
Mass: Approx. 2.0 kg (per unit)
General
Power requirements:
AC 120 V, 60 Hz
Power consumption: 35 watts
Dimensions (W/H/D):
Approx. 290 mm × 106 mm × 221 mm (incl.
projecting parts)
Mass: Approx. 2.7 kg
Supplied accessories: Remote (RM-AMU171) (1), R6
(Size AA) batteries (2), Speaker cords (2), Speaker
pads (8), FM lead/AM loop antenna (1), Operating
Instructions (this manual) (1)
Design and specifications are subject to change
without notice.
Standby power consumption: 0.5 W
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
