Welcome to
HD-CCTV
Philosophy,
Vision,
& Mission
Enjoy the Genuine HD Security
with WEBGATE HD-CCTV Solution.
Established in 1997, Daemyung Enterprise Co., Ltd. WEBGATE division, has been continuously tried to keep the promise of
providing the best and the most innovative products in the world of security. With a world-class technology and highly reliable
products, WEBGATE is currently leading the world of security market.
We will always keep the promise to meet the changes in the market and provide you the best.
WEBGATE Philosophy : We value the manifestation of future trends.
Based on this, Webgate is the leading company in the world of HD Video
surveillance market and continuing to serve the most convenient and secure
product line humanity has ever known.
Welcome to a new... World of Webgate
History of
2012. 5
HD1600M
2012. 12
WEBGATE
HDC400M
2013. 3
OPT-TX/RX
2013. 10
VCU
1999. 5
WebEye-E10
2000. 1
i-Rec C104
2001. 1
M360, DVrS
2002. 2
WebEye-MC10
2003. 5
DS412
Development of Image processing system of
UAV (Unmanned Aerial Vehicle) for the Korean Army
Development of WebEye series,
The world’s first Wavelet base multi streaming IP Camera
Development of i-Rec C104,
The world’s first DVR integrating camera
Development of DVrS,
The world’s first 108ch NVR solution
The world’s first 3GPP real-time
MPEG-4 streaming camera
2007. 9
MD1600H
2007.10
MD3200M
NVS04S
2010.11
C720B
2010.11
RP102
The world’s first Hybrid DVR(Analog 4ch + IP 12ch)
using WEBGATE’s own differential Wavelet image process
2011. 2
C1080B
2003. 10
DS1600Q
2005. 5
Control Center
2007. 3
B101M
Development of DS1600Q
16ch Wavelet DVR using WEBGATE own differential
Wavelet image processing
Development of Control Center
CMS(Central Management Software) supporting
1024 unit registration, 6 monitors and virtual matrix etc.
Development of MPEG-4 IP products supporting
8 different multi streams
Development of MD1600H
The world’s first 16ch D1 real-time standalone DVR
2013. 10
C1080P Series
Development of MD3200M
The world’s first 32ch 2CIF real-time standalone DVR
2011. 3
HD400H
2011. 7
HD800H
2012. 5
SDI2HDMI
Leadership Award
4ch Compact size Full-HD DVR
Certified by HDcctv Alliance
2013. 11
HD1600F-PDR
Fiber-Optic Converter 4 models
The world’s first certified product by HDcctv Alliance
Development of NVS04S
The world’s first 16ch Mega-Pixel Standalone type NVR
720p HD-SDI camera,
The world’s first certified product by HDcctv Alliance.
HD-SDI repeater,
The world’s first certified product by HDcctv Alliance
1080p HD-SDI camera,
The world’s first certified product by HDcctv Alliance
1080p HD-SDI camera 11 models
Certified by HDcctv Alliance
1080p PoC HD-SDI camera 12 models
Certified by HDcctv Alliance
The world’s first certified product by HDcctv Alliance
HDC400F-PD
2013. 12
HDC801F-PD
Won “Compliance Leadership Award”
from HDcctv Alliance
3 consecutive years in 2011, 2012, 2013
The world’s first PoC/CoC 16ch Full-HD DVR
Full-Frame recording, Built-in PoC/CoC,
DoubleReachTM, RAID function.
The world’s first certified product by HDcctv Alliance
PoC/CoC 4ch Full-HD DVR
Full-Frame recording, Built-in PoC/CoC function
Certified by HDcctv Alliance
PoC/CoC 8ch Full-HD DVR
Full-Frame recording, Built-in PoC/CoC function
Certified by HDcctv Alliance
Patents
1999.10
2008.10
2013. 11
2013. 12
C1080 Series
1998. 3
16ch Full-HD DVR,
The world’s first certified product by HDcctv Alliance
Method of image processing for monitoring camera
2010. 6
Method of hard disk driver mount
2000. 3
Method and network expression system of embedded device
2010. 6
IR LED control and IR LED camera
2003. 3
Method and multi channels support device of
digital Image system
2012. 7
Using SDI Compressed video transferring system
and the way
2003. 8
2D Wavelet conversion device
2007.12
Internet Protocol-based surveillance system and the method
to assign internet protocol address.
Management method of network camera
2013. 12
2013. 4
SNS Relay Service for Embedded device
Design of camera front case
Patents Pending
Effective management method for memory allocation and cancellation
4ch Full-HD DVR,
The world’s first certified product by HDcctv Alliance
8ch Full-HD DVR,
The world’s first certified product by HDcctv Alliance
HD-SDI to HDMI convertor,
The world’s first certified product by HDcctv Alliance
WEBGATE won the “Compliance Leadership Award”
for 3 consecutive years by 2013
PRODUCT LINEUP
Premium to your security
09p
HD-CCTV One Cable Solution
75p
HD-CCTV Camera
Seonsor
Model
OS /
Codec
Model
Channel
HD1600F-PDR
16ch
HD1600M-PDR
HD800F-PDR
HD400F-PDR
16ch
Linux /
H.264 High
Profile, JPEG
C1080B
17p
HD-CCTV Ultimate Performance PoC DVR
Display /
Resolution
Recording /
Resolution
480/[email protected]
120/[email protected]
C1080PBM
-
DC12V
89p
-
-
-
PoC / DC12V
91p
93p
Double
Reach
Page
-
-
-
PoC
AC24V / DC12V
4/1
HDMI
5
Max. 128TB (NS04R)
Max. 32TB (eSATA)
C1080PD
C1080D
2
O
O
O
41p
C1080PD-IR
C1080D-IR
24
-
-
PoC
AC24V / DC12V
95p
5
Max. 128TB (NS04R)
Max. 32TB (eSATA)
2
O
O
O
43p
C1080PD-AF
C1080D-AF
-
O
-
PoC
AC24V / DC12V
97p
-
PoC
AC24V / DC12V
99p
-
O
PoC
AC24V / DC12V
93p
-
O
PoC
AC24V / DC12V
95p
O
PoC
AC24V / DC12V
97p
O
PoC
AC24V / DC12V
99p
O
PoC
AC24V / DC12V
101p
101p
HDMI
4/1
HDMI
5
Max. 32TB (eSATA)
2
O
O
O
45p
C1080PD-IR-AF
C1080D-IR-AF
4ch
120/[email protected]
4/1
HDMI
5
Max. 32TB (eSATA)
2
O
O
O
47p
C1080PVD
C1080VD
HDMI
2
Max. 32TB (eSATA)
2
-
O
O
49p
C1080PVD-IR
C1080VD-IR
HDC400F-PD
4ch
120/[email protected]
4/1
HDMI
1
Max. 32TB (eSATA)
2
-
O
O
51p
C1080PVD-AF
C1080VD-AF
All models acquired HDcctv certificate
24
1/3” 2.1MP
CMOS
30/[email protected]
60/[email protected]
2.8~11mm
F1.4
DC Iris Lens
Monitor
Output
HDD
External Storage
USB
RAID
PoC/CoC
Double
Reach
Page
HD1600F-R
16ch
480/[email protected]
4/1
HDMI
5
Max. 128TB (NS04R)
Max. 32TB (eSATA)
2
O
-
-
53p
HD1600F
16ch
480/[email protected]
4/1
HDMI
5
Max. 128TB (NS04R)
Max. 32TB (eSATA)
2
-
-
-
55p
HDC1601M
16ch
120/[email protected]
4/1
HDMI
2
Max. 32TB (eSATA)
2
-
-
-
57p
8ch
240/[email protected]
4/1
HDMI
5
Max. 32TB (eSATA)
2
O
-
-
59p
HDC801F
8ch
240/[email protected]
4/1
HDMI
2
Max. 32TB (eSATA)
2
-
-
-
61p
HDC801H
8ch
120/[email protected]
4/1
HDMI
2
Max. 32TB (eSATA)
2
-
-
-
63p
HDC400F
4ch
120/100f[email protected]
4/1
HDMI
2
-
2
-
-
-
65p
67p
O
O
18
-
18
O
O
PoC
AC24V / DC12V
C1080PBL-IR48-AF
C1080BL-IR48-AF
48
O
O
PoC
AC24V / DC12V
101p
O
O
AC24V
103p
O
-
AC24V / DC12V
103p
C1080PT-Z20F*
HD-CCTV Storage
Common :
3DNR / WDR / BLC / TDN
OSD / Anti-Motion Blur /
Anti-Flicker / De-Fog /
AGC / Privacy Masking
O
C1080PBL-IR18-AF
C1080BL-IR18-AF
C1080PT-Z20*
All models acquired HDcctv certificate
Suffix P models :
PoC (Power over Coax)
CoC (Control over Coax)
24
C1080PBL-IR18
C1080BL-IR18
Audio
In/Out
24
-
C1080PVD-IR-AF
C1080VD-IR-AF
HD-CCTV High Performance DVR
1/2.8” 2.1MP
CMOS
30/[email protected]
60/[email protected]
20x Optical Zoom
Lens
-
3DNR / WDR / BLC / OSD(RS485)
Preset / Scan / Pattern / Group
All models acquired HDcctv certificate (except * marked models)
105p
HD-CCTV Converter & Etc
Model
RP101P
Feature
Page
1ch PoC Repeater for HD-SDI
113p
Model
Feature
Page
HD2SD
1ch HD-SDI to 1ch CVBS Converter
119p
115p
PS101P
1ch Power Supply for PoC Devices
113p
OPT-TX4-RS485P
4ch HD-SDI to Optic Converter
supporting PoC function
DR101P-TX
1ch DoubleReach Transmitter for HD-SDI
113p
OPT-TX1-RS485U(C)
1ch HD-SDI to Optic Converter
119p
115p
OPT-RX1-RS485U(C)
1ch Optic to HD-SDI Converter
119p
DR101P-RX
1ch DoubleReach Receiver for HD-SDI
Max Capacity
HDD Bay
RAID
Host I/F
Power Supply
Page
RP102
1ch HD-SDI to 2ch HD-SDI Repeater
115p
OPT-TX4-RS485U(C)
4ch HD-SDI to Optic Converter
121p
NS04R
128TB
4
1, 5, 10
Giga Ethernet
220W Power w/PFC
69p
SDI2HDMI
1ch HD-SDI to 1ch HDMI Converter
117p
OPT-RX16-RS485U(C)
16ch Optic to HD-SDI Converter
121p
ES0104
16TB
4
0, 1, 3, 5, 10, LARGE
eSATA
220W power w/PFC
71p
HDMI2SDI*
1ch HDMI to 1ch HD-SDI Converter
117p
WKC-100*
Remote Control Keyboard
121p
Model
ES0212
5
-
PoC/CoC
4/1
Linux /
H.264 High
Profile, JPEG
-
RAID
4/1
Recording /
Resolution
Page
USB
240/[email protected]
Display /
Resolution
Power
External Storage
16ch
Channel
IP66
Function
HDD
240/[email protected]
HD800F-R
C/CS
Mount
Auto
Focus
LEDs
Monitor
Output
8ch
OS /
Codec
Lens
Audio
In/Out
HDC801F-PD
Model
Resolution
16TB
12
0, 1, 10(1E), 3, 5, 6 and JBOB
eSATA
400Wx2 redundant power w/PFC
73p
SD2HD*
6ch CVBS to 1ch HD-SDI Converter
117p
All models acquired HDcctv certificate (except * marked models)
6
PRODUCT LINEUP
Premium to your security
123p
HD IP / NVR
Model
B101M
Feature
Page
1ch video server with MPEG-4
125p
D101M
1ch video decoder with MPEG-4
127p
HDC730C
1/3” 1.3M CMOS, 1280x720(720p 30fps),
PoE, MPEG 4
129p
Model
Feature
Page
SPD360M
1/4” Optical 36x CCD, D1 x30(25)fps, MPEG 4
131p
NVS04S
16ch Network Video Recorder
with 4 hot-swap SATA HDD
133p
135p
H.264 Standalone DVR
OS /
Codec
Model
Channel
Recording /
Resolution
Display
Audio
In/Out
Monitor Out
HDD /
ODD
External Storage
Max. 8TB(eSATA)
Max. 32TB(NVS04R)
Max. 8TB(eSATA)
Max. 32TB(NVS04R)
Max. 8TB(eSATA)
Max. 32TB(NVS04R)
Page
2
137p
2
139p
MH3200M
32ch
960/800fps
960/[email protected]
16 / 1
4 BNC + 2 DVI
4/1
MH1600H
16ch
480/400fps
480/[email protected]
16 / 1
4 BNC + 2 DVI
4/1
MH1600M
16ch
480/400fps
480/[email protected]
16 / 1
2 BNC + 1 DVI
4/1
2
141p
EH1600L
16ch
480/400fps
480/[email protected]
4/1
2 BNC + 1 DVI
2/1
Max. 8TB(eSATA)
2
143p
8ch
240/200fps
240/[email protected]
4/1
2 BNC + 1 DVI
2/1
Max. 8TB(eSATA)
2
145p
EH400H
4ch
120/100fps
120/[email protected]
4/1
2 BNC + 1 DVI
2/1
Max. 8TB(eSATA)
2
147p
LH1600C
16ch
480/400fps
480/[email protected]
4/1
2 BNC + 1 VGA
2/0
-
2
149p
LH800L
8ch
240/200fps
240/[email protected]
4/1
2 BNC + 1 VGA
2/0
-
2
151p
EH800M
Linux /
H.264,
JPEG
153p
Software Solution
e-Map
Rule-based
auto-action
Action
Log
External Controller
Page
Model
Units
Decoding
Performance
Control Center Standard
1024
8 HD
2
128
No
Yes
No
No
USB joystick, Jog / Shuttle
169p
Control Center Pro
1024
12 HD
6
256
No
Sub-map
Yes
Yes
USB joystick, Jog / Shuttle, WKC-100
169p
Control Center Enterprise
1024
12 HD
4 + 50
3456
Yes
Sub-map
Yes
Yes
USB joystick, Jog / Shuttle, WKC-100
169p
Monitor
Simultaneous
Monitoring Channels
Virtual
matrix
WinRDS
Video Streaming Re-Distribution Solution, 512Channel Input, 512Channel Output, Up to 100 User registration
171p
WebEye
Mobile App for iOS and Android, 16Units Registration, 4Split-Screen Live Monitoring & PTZ Control,
HD Resolution, Alarm and System Event Log, WinRDS can be registered
173p
Solution Guides
HD-CCTV Tech Note
7
USB
175p
203p
Installation Case
Ordering Information
185p
229p
8
One Cable
Solution
Easy Installation
True Plug & Play
PoC / CoC
DoubleReachTM
HD-CCTV
One Cable
Solution
The World’s First HD-CCTV One Cable Solution including DVR, Camera, Converter models
One Cable Solution for Full-HD video transmission, Camera power supply & control via Coaxial cable
One Cable Solution
Premium to your security
About One Cable Solution - Camera Power supply & Control through coax cable
CoC(Control over Coax)
Not only PoC function but also camera control can be executed through coaxial cable. Cameras do not need additional RS-485
cable to control camera, so PoC camera’s OSD menu control, Zoom/Focus control and firmware upgrade can be executed by
coaxial cable. In case of PTZ dome which requires somewhat higher power consumption, only CoC function can be utilized
interfaced with RP101P.
One Cable Solution provides camera power through coaxial cable, so installation of camera
power supply is not necessary. Also, DVR can transmit camera control data through same coaxial cable, so camera’s all OSD menu control is possible. For AF camera models, Zoom/Focus,
One-push auto focus control can be additionally supported. One Cable Solution provides
easy installation at actual installation sites. And besides, because DVR or CMS can control
camera, it supports efficient management of video surveillance system at the same time.
DVR transmits camera control signal through coaxial cable
Supports OSD menu, Zoom/Focus control and camera firmware upgrade
PoC Camera
PoC DVR
HD-SDI Video + Power (PoC) + RS485 (CoC)
PoC Camera
PoC DVR
Power (PoC) + RS485 (CoC)
Max. 200m with 5C-HFBT Coax Cable
No Power
Supply
[ Camera power supply and control through coaxial cable ]
HD1080p HD-SDI Video
PoC Camera
Max. 200m
with 5C-HFBT
Easy Installation and Maintenance using PoC/CoC function
No Power
Supply
DVR provides power to camera through coaxial cable
Cameras do not require additional installation for power supply
11
No Power Supply
Max. 200m
with 5C-HFBT
[ Extension of transmission distance using PoC Repeater, RP101P ]
PoC(Power over Coax)
The Ultimate performance PoC DVR series supply power to cameras through coaxial cables, so cameras don’t need additional
installation for power supply. Besides, DVR provides auto-detection of PoC/Non-PoC camera, supports over-current alarm and
its protection, status of PoC operation. By using WEBGATE’s recommended 5C-HFBT coaxial cable, PoC cameras can transmit
HD-SDI video up to 200m. Moreover, PoC repeater RP101P can be used to extend the transmission distance. RP101P is a
repeater which supports PoC function and because its power is supplied from DVR, it can be located anywhere without any
restriction of installation.
PoC DVR
PoC Repeater
RP101P
C1080PT-Z20
PoC Repeater
RP101P
PoC DVR
RS485
No Power Supply
[ Example of using CoC function ]
12
One Cable Solution
Premium to your security
HD-SDI Transmission distance extension using DoubleReachTM function
PoC, DoubleReachTM Converters : RP101P, PS101P, DR101P-TX, DR101P-RX, OPT-TX4-RS485P
The Ultimate performance PoC DVR’s DoubleReachTM is a new technology for HD-SDI video transmission. This technology
converts Full-HD video to the undistinguishable video level by naked eye, and extends HD-SDI transmission distance by two
times (up to 400m) when it compared with conventional HD-SDI.
HD DVR models which support DoubleReach can receive DoubleReach video for odd channels without additional equipment,
and users can easily relocate channels which are displayed on multi-screen. To use this function, camera needs DoubleReach
transmitter DR101P-TX, and it can work together with PoC repeater RP101P.
PoC Repeater
This technology is especially useful when it comes to upgrading existing system. Because DoubleReachTM technology changes
the HD-SDI’s video data from 1.5Gb/s to 270Mb/s, old existing cable can be effectively used to transmit HD-SDI signal and,
making the users to configure HD video surveillance system with ease.
To use this function, camera side needs DoubleReachTM transmitter of DR101P-TX, and PoC repeater of RP101P can be worked
together to extend video transmission distance.
PoC(Power over Coax) repeater, RP101P extends the HD-SDI video transmission distance between PoC camera and PoC DVR.
Because RP101P also supports CoC(Control over Coax) function, operator can control camera’s all functions (such as OSD
menu, Zoom/Focus control and Firmware upgrade) through DVR.
DoubleReachTM Transmitter & Receiver
DoubleReach Transmitter, DR101P-TX can be directly connected to a DVR which support the function, or can be connected
to DoubleReach Receiver, DR101P-RX. DoubleReach function extends the HD-SDI video transmission distance by two times.
Besides, DoubleReach converters support PoC & CoC functions at the same time.
Supports up to 400m HD-SDI video transmission using 5C-HFBT(RG-6) cable
It is effective when the existing cable’s performance is low or its length is over 200m
PoC Camera
Can be interfaced with PoC repeater RP101P
DoubleReach Receiver
DR101P-RX
DR101P-TX
Non-PoC DVR
RS485
Max. 200m
with 5C-HFBT
No Power
Supply
PoC Camera
Max. 200m
with 5C-HFBT
No Power
Supply
PoC DVR with built-in
DoubleReach
DoubleReach Transmitter
DR101P-TX
Max. 400m
with 5C-HFBT
Max. 400m
with 5C-HFBT
No Power
Supply
Power
[ Non-DoubleReach DVR needs DR101P-RX ]
PoC DVR supplies necessary power to PoC Repeater and DoubleReach Transmitter, so they do not require additional power
installation basically.
No Power
Supply
[ DoubleReach doubles HD-SDI transmission distance ]
13
14
One Cable Solution
Premium to your security
How to use One Cable Solution using Non-PoC DVR
Fiber-Optic Transmitter supporting power to PoC cameras
PS101P is power supply that supply power to PoC devices. If using PS101P, existing Non-PoC DVR can use One Cable Solution
with ease.
If Fiber-optic transmitter of OPT-TX4-RS485P which can supply necessary power to PoC cameras were used for large-scale
surveillance sites, you can easily design and configure the system.
OPT-TX4-RS485P supplies power to up to 4 PoC cameras using its input power, and it uses fiber-optic cable for long-distance
HD-SDI video transmission.
PoC Camera
Power Supply for PoC
PS101P
Non-PoC DVR
RS485
Max. 200m
with 5C-HFBT
PoC Camera
No Power
Supply
OPT-TX4-RS485P
Power
n FL
HD-SDI Video + PoC + CoC
[ One cable solution using PS101P ]
PS101P can be interfaced with PoC Repeater and you can use DoubleReach function using DR101P-RX.
2 FL
PoC Camera
RP101P
Power Supply for PoC
PS101P
Non-PoC DVR
RS485
1 FL
Max. 200m
with 5C-HFBT
No Power
Supply
Max. 200m
with 5C-HFBT
No Power
Supply
Power
Fiber-Optic Cable
(Max. 20Km)
[ Example of using PS101P and PoC repeater ]
PoC Camera
DR101P-TX
DoubleReach Receiver
DR101P-RX
RS485
Max. 200m
with 5C-HFBT
No Power
Supply
Max. 400m
with 5C-HFBT
No Power
Supply
OPT-RX16-RS485U
Non-PoC DVR
Power
Coax
Cable
RS485
Twist Pair
16ch HD DVR
[ Example of using DR101P-RX to have DoubleReach capability ]
15
16
HD-CCTV
DVR
Full-HD Video Recorder
H.264 / Multi-Streaming
Broadcast quality
PoC/CoC
RAID / DoubleReachTM
Full-frame recording/playback, broadcasting class video quality using H.264 High-profile Codec,
and network multi-streaming provide the best way to build High definition surveillance system.
HD-CCTV
DVR
HD-CCTV DVR Features
PoC/CoC, DoubleReachTM Support for One Cable Solution
PoC(Power over Coax) Support
Auto Detection of PoC Camera / Power supply to Camera
PoC DVR can supply camera power through coaxial cable. DVR
can provide maximum 16W per channel, and DVR can supply
power to PoC repeater within the power specifications.
If PoC camera or PoC repeater is connected to DVR through coaxial cable, DVR automatically detect the devices, and start to
supply power to PoC devices. DVR has over-current protection
function per each channel and also shows the working condition of PoC operating.
CoC(Control over Coax) Support
Automatic setting of communication / Camera Control
PoC DVR can transmit control commands to PoC camera
through coaxial cable.
In case of Non-PoC DVR, RS485 cable installation, protocol, address, baud rate, data bit, parity bit, stop bit settings are necessary. But, in case of PoC camera, these settings are unnecessary.
By merely assigning CoC at PTZ menu, DVR can control all camera functions with 57,600bps baud rate.
Premium to your security
As you can see from below Figure, if PoC cameras are connected to a PoC DVR by coaxial cable, PoC DVR supplies necessary
power to cameras and additional power installation is not necessary. Also, you can control whole camera menu through DVR
or CMS without additional RS485 cable installation and it makes simple design and to build efficient video surveillance system.
PoC Camera
PoC DVR
HD-SDI Video + Power (PoC) + RS485 (CoC)
Max. 200m with 5C-HFBT Coax Cable
No Power
Supply
DoubleReachTM Support – Built-in DoubleReach Receiver
DoubleReachTM is the latest HD-SDI technology which converts Full-HD video to the undistinguishable video quality level by
naked eye and transmit the video up to 400m through 5C-HFBT coaxial cable. DoubleReach supporting HD DVR models can
receive DoubleReach video for odd channels without additional equipment and users can easily relocate channels which are
displayed on multi-screen. Also, DoubleReach technology includes PoC/CoC function, so DoubleReach transmitter’s power
can be supplied from DVR.
PoC Camera
DoubleReach Transmitter
DR101P-TX
Max. 200m
with 5C-HFBT
No Power
Supply
19
PoC DVR with built-in
DoubleReach
Max. 400m
with 5C-HFBT
No Power
Supply
20
HD-CCTV DVR Features
Broadcasting class video quality using H.264 High-profile Codec
New DVR
1dB
2dB
Competitor
30dB
21dB
4dB
17dB
4dB
Previous
DVR
2Mbps
4Mbps
Webgate’s video image
6Mbps
8Mbps
10Mbps
12Mbps
Bitrate
Full-Frame Recording
The Ultimate performance PoC DVR series support 30fps recording of 1080p Full-HD video per each channel, and customers
can configure the recording condition from 1fps to 30fps per each channel. Places such as casino, racetrack and bank requires
all frame recording, and we can provide full-frame video recording without any frame missing.
Video Quality
30dB
Premium to your security
HD DVR series adopted H.264 High-profile Codec, and it shows
better video compression performance through overall rage of
bitrate when it compared with competitor’s H.264 Main-profile or H.264 Base-profile. Especially, at lower bitrate(Less than
4Mbps) section, our HD DVR needs only half of bitrate in order
to show similar video quality level.
Moreover, because HD DVR allows video quality setting up to
12Mbps, customers can get the best quality recording under
an environment of complicated or a lot of movement.
Competitor’s video image
Full-Frame Recording
Non Full-Frame Recording
Full-Frame Playback Using AMD
(Advanced Multi-channel Decoding)
Full-frame recorded video can be played by full-frame
at every playback mode. WEBGATE’s AMD(Advanced
Multi-channel Decoding) technology controls video
decoder performance according to the split-screen
modes, so DVR can provide full-frame playback not
only at single screen but at 16 split-screen mode.
Recorded video:
1920 x 1080
Single screen playback:
30fps decoding with 1920 x 1080 size
21
16 split screen Playback
480fps decoding with 480 x 270 size
22
HD-CCTV DVR Features
Premium to your security
Convenient and versatile Search features
Intuitive and simple User Interface
HD DVR series provide Calendar/Timeline search feature which had been only supported by PC software. Through this integrated search method, customers can intuitionally find the recorded video data they want.
Besides, all HD DVR models support up to 64 times fast playback and step playback for forward/reverse direction to help easy
search.
HD DVR series have intuitive and simple user interfaces. Because DVR adopted PC’s user interface components like mouse
right click and scroll-wheel, everyone easily operates DVR. Moreover, CMS setting page’s GUI(Graphic User Interface) have
exactly same interface with DVR’s, so customers who are not familiar with DVR can easily perform the whole DVR settings.
Drop-down menu by mouse right button click
Setting all channels at one page
28 frame
Stop
Step
Reverse
Fast
Reverse
Play
Fast
Forward
Step
Forward
29 frame
Pause
User friendly setting menu
30 frame
23
24
HD-CCTV DVR Features
Premium to your security
Improvement on reliability of recording data by RAID technology
Multi-Streaming Technology
RAID(Redundant Array Independent Disk) technology raise the reliability of recorded data by duplicated data storing or/and
by processing of pre-assigned parity bits. HD400/800/1600F-PDR, HD800/1600F-R and HD1600M-PDR allows a maximum of
5HDDs inside and they support RAID function by using these HDDs. RAID level 1,5,10 are supported and they can restore the
HDD’s data even if the data on a hard disk was damaged.
All of WEBGATE’s products support multi-streaming, which satisfy various network requests such as high-quality monitoring,
low bandwidth network and mobile monitoring.
HD DVR series always provide 3 video streams of H.264 high quality HD stream, H.264 SD class (640x360, nHD) stream and JPEG
SD class stream.
The users can obtain high-quality HD video images, monitor several channels at the same time, or check the video images
through mobile phone, FTP, E-mail and so on.
All these actions are automatically performed during the communication between DVR and CMS. So, users do not need to
worry about what type of stream they use, and there is no need to turn off any other functions to use multiple streams.
Supports RAID level 1,5,10 according to the quantity of installed HDDs
Hardware RAID system increased reliability than others’ software RAID
Even if one HDD is damaged, the DVR can keep recording
DVR provides Auto-Rebuilding function when the damaged HDD is replaced to a new one.
DVR keeps recording during auto-rebuilding process.
RAID 1
HDD1
HDD2
DATA
RAID
D5
HDD1
HDD1
HDD2
H.264
HD
H.264
nHD
JPEG 1fps
nHD
Mobile
stream
HDD3
HDD2
DATA
DATA
HDD3
HDD4
HDD5
RAID 10
DATA
HDD1
HDD2
HDD3
HDD4
Note. When 16ch Full-Frame DVR is using RAID5, the recording performance is reduced from 480fps to 320fps.
But, 4ch and 8ch DVR models do not show such performance reduction.
25
26
HD-CCTV DVR Features
Premium to your security
Upgraded Network Performance
Rapid network response using SLL(Super Low Latency) technology
The Ultimate performance PoC DVR series support 480fps network monitoring as well as 480fps recording and 480fps playback. Newly adopted high-performance network module can provide Full-HD video monitoring up to 12 channels, and nHD
video monitoring up to 48 channels. It means that DVR can provide Full-Frame monitoring service up to 72Mbps.
The HD DVR’s video codec starts its compression even before images fully fill up the memory and finishes its compression by
the time images have filled up the memory. Because this SLL technology is also optimized to the network transmission, video
monitoring within local network only shows approximately 270ms delay.
Such a fast network response is very useful when real time monitoring over the network is necessary.
User1
HD Single screen
30fps
User2
HD Single screen
30fps
72Mbps full frame service
User3
HD Single screen
30fps
Network
0ms
Full HD12 channels
or
nHD 48 channels
Good
User4
HD Single screen
30fps
WEBGATE
270ms
Eqorgvkvqtʋu
1100ms
User5
16 Split screen
480fps
User6
16 Split screen
480fps
27
No Good
Network Monitoring Latency
28
HD-CCTV DVR Features
Premium to your security
True Full-HD Display
High Performance, High Reliability Video File System (VFS)
HD DVR series provide clear and natural video image at single/ 4-split/ 9-split/
16-split display screen. Because DVR was designed to be optimized to Full-HD
1080p video, it shows industry’s best resolution of 1200TV lines.
WEBGATE’s VFS is specialized DVR file system that minimizes the hard disk drive header’s movement, and it allows data to
be saved consecutively by sectors By using VFS, the DVR can maximize HDD’s performance and improve reliability as well as
life-cycle of HDD.
IPFR(Intelligent Power Failure Recovery) Technology
The SMPS is specially designed to protect circuit control so data on the HDD will not be destroyed during a sudden power
failure. In some cases where data is lost, the IPFR minimizes its loss within the last single frame instead of the entire block.
Diverse bad block management
If any trouble occurs inside HDD, the HDD will mark the relevant block to prevent further access. If there are too many defects
to record, DVR will hand over recording to the next HDD automatically. Bad blocks found by both DVR and S.M.A.R.T function
are shown all together, so the users can make data backups before the HDD completely fails. If any trouble occurs, the DVR
will make notification by e-mail, relay, popup windows, and other methods.
Digital Zoom of WEBGATE’s product
29
Digital Zoom of Competitor’s Digital Zoom
30
HD-CCTV DVR Features
Premium to your security
Mass storage
At-the-PC Playback
Aside from the default communication network port, some HD DVR models provide additional Gigabit Ethernet port for storage interface. WEBGATE’s storage NS04R can expand HD DVR’s HDD capacity up to 128TB using this storage port. The NS04R
has two network ports that can be cascaded up to 8 units without additional hub devices and it can improve the reliability of
recorded data by supporting RAID function including Mirroring.
Additionally, external eSATA storage which have RAID technology can be connected to HD DVR’s eSATA port, and this can
expand the DVR storage capacity up to 32TB.
HD DVR series are using the dedicated Video File System(VFS) which is optimized to DVR. But this VFS is based on Linux based
file system, so it does not have compatibility with FAT, NTFS file systems which are supported by Microsoft Windows. It means
that the HDD which was used in DVR can not be recognized by Microsoft Windows based PC.
Gigabit Connect
eSATA
NS04R can expand DVR’s recording capacity up to 128TB by connecting with HD1600F-PDR, HD1600M-PDR, HD1600F-R,
HD1600F
In case of WEBGATE’s HD DVR series, if the HDD which was used in DVR is connected to a PC through USB or eSATA, users can
do all the necessary works such as Playback, Search, Backup even though Microsoft Windows originally does not support users
to read/write from the HDD. So, when the DVR is broken, the user can play recorded data and create backups using CMS. Since
all these processes only require reading process of the HDD, the HDD will not have any affects when re-installed to the DVR.
When full backup is necessary, user can connect same or bigger HDD and use CMS software to easily make a duplicate.
(1)
Take Out
HD DVR
Removed
Harddisk
Removed
Harddisk
Control Center
Interface to PC
(2)
Control Conter
Playback
Harddisk
Reader
Backup
New
Harddisk
1TB External Hard disk back-up
HD DVR series support data backup up to 1TB using NTFS file system. 32GB USB flash memory using FAT32, 1TB external USB
hard drive or external eSATA hard drive can be used for data backup. Also, customers can make backup data as AVI video
format as well as WEBGATE dedicated video file format.
31
Search & Play
(3)
32
HD-CCTV DVR Features
Premium to your security
Easy network installation by Plug & Play
WNS (WEBGATE Naming Service)
To remotely access to a DVR through internet which has dynamic IP address, you do not need to configure complicated router
setting. By merely activating UPnP protocol and WRS service at DVR menu, you can easily access to the DVR.
DVR
CMS
DHCP activated
Choose WRS server
UPnP activated
Enter Group ID
Enter Gruoup ID
Connecting successful
Choose DVR
Auto Port Forward using UPnP
WRS(WEBGATE Registration Service)
If a DVR shares the port number to the router by UPnP protocol, the router can deliver the connection request from
an external source to the DVR automatically. Users don’t
need to configure the router.
WRS is a network service that manages the DVR which has
both a public and dynamic IP. If the operator inputs a group
ID at DVR menu, the group ID is registered to WEBGATE’s
WRS server. Since the CMS shows the DVR list under the
same group ID by communication between CMS and WRS,
user can easily connect to the desired DVR. There is no
need to sign up for a membership, remember MAC address
or serial number.
33
WNS is a DDNS service which was developed
and managed by WEBGATE. If used WNS servers, users can easily connect to the DVR by
assigned domain name.
Because WNS is served from a server located
in IDC(Internet Data Center) where can always
provide stable connection state, prompt action is possible even if any trouble occurs. The
user can directly configure the WNS service
through WNS webpage(www.mycam.to) or
DVR menu. Of course, user can use free DDNS
services such as www.dyndns.org or www.
no-ip.org.
Frame by Frame step reverse
Due to high performance codec the latest
video processing technology, the DVR can
provide forward and reverse step-by-step
playback by frame. When the user wants to
find any single frame, it will be very effective. It is very useful in places like racetrack
and casino where all frames are valuable.
34
HD-CCTV DVR Features
Premium to your security
Advanced Lightning Arrestor
NTP server
WEBGATE’s advanced lightning arresters can cope with 6KV test condition. And it meets more than the requirement of the
international surge standard IEC61000-4-5’s highest level, class5(2KV). All of WEBGATE’s HD-SDI DVRs have built in advanced
arrestors to help minimize damage from potential lightning strikes. The HD-SDI product line of high-frequency signals, RS-485
communication lines have the advanced surge protection circuit. This also includes protection for the sensor / relay as well.
Manage DVR time equally
Time server
NTP client
NTP client
Interface with POS/ATM
WEBGATE DVR can interface with VSI product lines that contain 300 types of POS/ATM protocols within. Through he family of
VSI products, the DVR can record text data, provide search and playback. By connecting multiple VSI products, the DVR can
receive text data from several POS devices and DVR can connect the text data to the desired video channel. DVR records video
and text data separately, and can overlay text data on video when it is necessary. CMS also supports text search.
ATM
camera
Time Synchronized DVR Network
The DVR can synchronize time information directly from NTP server. Moreover, a DVR can work as a time server and distribute
the time information to other DVRs on the local network at the same time. This way, there is not time differences between
each DVR.
Also, when DVR is not connected to a network, DVR’s temperature compensated real-time clock guarantees less than 0.1
second error in one day.
35
Mart
POS
VSI Pro
Hydra
POS
VSI Pro
RS-485
Ehternet
Search text contents
RS-232
36
HD-CCTV DVR Features
Premium to your security
Multi platform support by Java viewer
Flexible and powerful WESP SDK
WEBGATE’s DVR are embedded with Java Viewer which
support connection from different operating systems such
as Mac and Linux. User can access PTZ control, event/alarm
through such as MS Windows’ internet explorer, Chrome
and Firefox.
Due to the flexibility and interoperability of the WESP (WEBGATE Embedded Standard Protocol) SDK, it supports all functions
of equipment so that a user can easily develop their own applications.
This SDK supports a broad range of equipment from low to high levels such as video data receiving and playback with caption
display. The user can develop programs based on their coding capabilities.
The WESP SDK was developed based on Microsoft COM technology, and it supports various programming languages (VB,
VC++, VB Script, Java Script, .NET). Web developers who are familiar Java Script can create their own customized applications
to fit their needs.
Since all of WEBGATE’s products conform to WESP protocol, if a user create a program, that same application can be used with
other WEBGATE products.
Chrome
Safari
FireFox
Centralized Password Management
WEBGATE’s DVRs contain Radius protocol with which a server can change every DVRs’ password at once. This function is instrumental and handy for the places where the administrator needs to change the password periodically.
Monitor
Powerful User
Application
Simple User
Application
Web
Application
File Converter
(2) Validation Request
Playback
Bank #2
(4
)L
og
in
OK
&
or
Pa
NG
ss
w
or
d
(3) Validation Result
Bank #1
Bank #3
High Level Functions
WESP SDK
(1
)I
D
RADUIS
Server
WESP SDK
Config
Serial Port
Low Level Functions
RADUIS
Server
Network
WESP Protocol
Event
Control Center
PTZ
Bank #4
HD DVR
Bank #5
SD DVR
Video Server IP Camera
NVR
WinRDS
WRS/WNS
Discovery
Control Center
37
38
HD-CCTV DVR Features
Premium to your security
Powerful CMS : Control Center Standard/ Pro/ Enterprise
Mobile Viewer : WebEye
Control Center Standard is provided as a bundle software for the DVR. It can provide users with a maximum of 1024 DVRs, dual-monitors, View Set, user-specific authority settings, e-Map, real-time status and other necessary functions found in high-end
models. It also provides real time event status, and all the other necessary functions. Diverse search methods are also included
such as Time, Calendar, Event, Thumbnail, and text based search to help the operator playback recorded video data with ease.
The Control Center Pro includes all functions of the Standard version, but also provides functions which are necessary for a
large scale central control system. It supports a maximum 6 monitors, provides Rule-based Auto Action which the operator
can define a series of DVR actions. The DVR can also record the operator’s CMS control history.
The Enterprise version provides Virtual Matrix system, One server PC can control a maximum of 50 client PC’s CMS. This allows
large scale of systems to be constructed without using expensive HD-SDI matrix device.
WebEye is a mobile application that supports iOS and Android.
Users can register DVRs, monitor video and control PTZ. Also,
WebEye supports full-frame monitoring and digital zoom to
observe the details of HD video.
WebEye provides system log to check DVR’s operating condition such as power failure, hard disk trouble, also provides
event log to check alarm history.
Pinch to Zoom
[ HD video check using D-Zoom in iPhone viewer ]
Product Family : HD DVR
Full-frame recording/playback, PoC/CoC, DoubleReach, RAID supporing Ultimate performance PoC DVR series and High performance DVR series are available.
Ultimate performance PoC DVR
full screen
e-map view
playback
Hwnn/htcog"Tgeqtfkpi"("Rnc{dcem"hqt"cnn"ejcppgnu
Dwknv/kp"RqE1EqE."FqwdngTgcejVO."TCKF"hwpevkqp
JF3822H/RFT
JF:22H/RFT
main display
39
smart search
JF3822O/RFT
JF622H/RFT
High performance DVR
Jkij"rgthqtocpeg"6"1":"1"38ej"FXT
JF3822H/T
JF:22H/T
JF3822H
JFE:23H/RF
JFE3823O
JFE:23J
JFE:23H
JFE622H/RF
JFE622H
schedule backup
40
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
NETWORK
Video input standard
SMPTE 292M (HD-SDI)
Odd channels support DoubleReach (Total 8 channels)
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Resolution / framerate
SMPTE 274M (1080p, 1920x1080) : 25, 30, 29.97 fps
DDNS
WNS, DynDNS, NoIP, WRS
Input format auto detection
Bandwidth limit
Supported
Connectors
16ch, 75Ω BNC connector
NTP
Server / Client / Both
PoC
16ch, Power over Coax, Max. 16 W/ch, Total 180W
Users
10 monitoring, 2 playback
CoC
16ch, Control over Coax, Max. 57,600bps
Streaming
1 HD, H.264 stream, Same as recording setting
1 additional H.264 stream, nHD(640 x 360)
VIDEO OUTPUT
Video Output
HDMI
1, 4, 9, 10, 13, 16 split-screen
User defined sequence / Alarm pop-up
1920 x 1080p via HDMI port
HD1600F-PDR
RECORDING
Full-HD & Full-Frame DVR supporting PoC/CoC, DoubleReachTM, RAID
Key Features
Front
- 16ch HD-SDI Standalone DVR
- The World’s First HDcctv Certified PoC/CoC 16ch HD-SDI DVR
- Control all 16 cameras by CoC (Control over Coax) function
- Doubles the video transmission distance by DoubleReachTM technology
- Adjustable recording quality and framerate per each channel
H.264 / JPEG
1920 x 1080
Rate
480/400 fps at 1080p
Quality
Mode
Schedule
24hrs / 7days
Back
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
IP filtering
Supported
STORAGE & BACKUP
5 internal SATA HDDs, 1 external eSATA Interface,
1 Gigabit network for storage(NS04R)
1080p, 10 levels up to 12Mbps
RAID Level
1/5/10 Supported
Manual & Event / Schedule & Event / Continuous & Event
File system
Proprietary file system, Data-loss protection against
Capacity
Max. 32TB with eSATA, Max. 128TB with cascaded NS04R
power-failure
Mode
Speed
Instant playback / search
Max. 480/400 fps at 1080p
Backup type
Multi-channel or Single channel avi file
Backup device
USB drive (2 ports)
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
S.M.A.R.T.
Temperature and Health checking
Block playback
24hours ~ 99days
SERIAL & I/O
EVENT & ALARM
- Supports High-resolutions over 1200TV lines at Live/Playback
User level
User privilege
Storage devices
PLAYBACK
- Self-power supply to all 16 cameras by PoC (Power over Cable) function
- Max. 480/400fps Recording & Playback at Full-HD 1080p resolution
Compression
Resolution
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
SECURITY
Serial port
Sensor input
1 RS-232C, 2 RS-485
16 Dry-contacts
Relay output
4 Relays
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
Event source
Event check schedule
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
- Full-HD 1920x1080 resolution output via HDMI port
Event action
Buzzer, Relay, E-mail, FTP, Alarm pop-up
CONTROLLER
- Various Live and Playback display (1/4/9/10/13/16 Split-screen)
MD area
15 x 10
Device
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
Sensor input
Dry contact (N.O. or N.C. selectable)
SOFTWARE
Text input
POS/ATM support, AVE VSI Pro/Hydra support
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
Mobile viewer
Monitoring / PTZ / LogView with iPhone & Android
CMS
Control Center Standard, Max. 1024 DVRs
SDK
ActiveX(COM) SDK
- Max. 5 Internal SATA Type HDDs
- Hardwired RAID system supporting RAID level 1/5/10
Dimension (unit:mm)
SYSTEM ALARM
- Supports Max. 128TB(NS0104R connection via Gigabit ethernet) and
Alarm source
Alarm action
Max. 32TB(e-SATA) external storage interface
AUDIO
- At-the-PC Playback of removed DVR HDD
Input/output
Compression
Input 4ch RCA / output HDMI, RCA
16KHz, 16bit sampling ADPCM
Direction
Both
418
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
- Lightning arrester on HD-SDI, RS-485, DIO ports
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
PTZ
ways such as E-map, Viewset
Protocols
- Java Viewer for Chrome, Firefox, Safari
- Provides Full SDK for easy and powerful customization
41
445
88
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
Front panel, IR remote, Joystick Keyboard, Mouse
ENVIRONMENTAL & PHYSICAL
Dimension
Weight
445(W) x 418(D) x 88(H) mm
10 Kg (No HDD)
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
AC free volt (100 ~ 240VAC), 50/60Hz
PoC Power
DC 24V/7.5A (Option)
Power Consumption
Max. 100W Typical 70W(1 HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
42
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
NETWORK
Video input standard
SMPTE 292M (HD-SDI)
Odd channels support DoubleReach (Total 8 channels)
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Resolution / framerate
SMPTE 274M (1080p, 1920x1080) : 25, 30, 29.97 fps
DDNS
WNS, DynDNS, NoIP, WRS
Input format auto detection
Bandwidth limit
Supported
Connectors
16ch, 75Ω BNC connector
NTP
Server / Client / Both
PoC
16ch, Power over Coax, Max. 16 W/ch, Total 180W
Users
10 monitoring, 2 playback
CoC
16ch, Control over Coax, Max. 57,600bps
Streaming
1 HD, H.264 stream, Same as recording setting
1 additional H.264 stream, nHD(640 x 360)
VIDEO OUTPUT
Video Output
HDMI
1, 4, 9, 10, 13, 16 split-screen
User defined sequence / Alarm pop-up
1920 x 1080p via HDMI port
HD1600M-PDR
RECORDING
Full-HD DVR supporting PoC/CoC, DoubleReachTM, RAID
Key Features
Front
- 16ch HD-SDI Standalone DVR
- Certified by HDcctv Alliance
- Control all 16 cameras by CoC (Control over Coax) function
- Doubles the video transmission distance by DoubleReachTM technology
- Adjustable recording quality and framerate per each channel
H.264 / JPEG
1920 x 1080
Rate
120/100 fps at 1080p
Quality
Mode
Schedule
24hrs / 7days
Back
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
IP filtering
Supported
STORAGE & BACKUP
5 internal SATA HDDs, 1 external eSATA Interface,
1 Gigabit network for storage(NS04R)
1080p, 10 levels up to 12Mbps
RAID Level
1/5/10 Supported
Manual & Event / Schedule & Event / Continuous & Event
File system
Proprietary file system, Data-loss protection against
Capacity
Max. 32TB with eSATA, Max. 128TB with cascaded NS04R
power-failure
Mode
Speed
Instant playback / search
Max. 120/100 fps at 1080p
Backup type
Multi-channel or Single channel avi file
Backup device
USB drive (2 ports)
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
S.M.A.R.T.
Temperature and Health checking
Block playback
24hours ~ 99days
SERIAL & I/O
EVENT & ALARM
- Supports High-resolutions over 1200TV lines at Live/Playback
User level
User privilege
Storage devices
PLAYBACK
- Self-power supply to all 16 cameras by PoC (Power over Cable) function
- Max. 120/100fps Recording & Playback at Full-HD 1080p resolution
Compression
Resolution
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
SECURITY
Serial port
Sensor input
1 RS-232C, 2 RS-485
16 Dry-contacts
Relay output
4 Relays
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
Event source
Event check schedule
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
- Full-HD 1920x1080 resolution output via HDMI port
Event action
Buzzer, Relay, E-mail, FTP, Alarm pop-up
CONTROLLER
- Various Live and Playback display (1/4/9/10/13/16 Split-screen)
MD area
15 x 10
Device
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
Sensor input
Dry contact (N.O. or N.C. selectable)
SOFTWARE
Text input
POS/ATM support, AVE VSI Pro/Hydra support
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
Mobile viewer
Monitoring / PTZ / LogView with iPhone & Android
CMS
Control Center Standard, Max. 1024 DVRs
SDK
ActiveX(COM) SDK
- Max. 5 Internal SATA Type HDDs
- Hardwired RAID system supporting RAID level 1/5/10
Dimension (unit:mm)
SYSTEM ALARM
- Supports Max. 128TB(NS04R connection via Gigabit ethernet) and
Alarm source
Alarm action
Max. 32TB(e-SATA) external storage interface
AUDIO
- At-the-PC Playback of removed DVR HDD
Input/output
Compression
Input 4ch RCA / output HDMI, RCA
16KHz, 16bit sampling ADPCM
Direction
Both
418
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
- Lightning arrester on HD-SDI, RS-485, DIO ports
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
PTZ
ways such as E-map, Viewset
Protocols
- Java Viewer for Chrome, Firefox, Safari
- Provides Full SDK for easy and powerful customization
43
445
88
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
Front panel, IR remote, Joystick Keyboard, Mouse
ENVIRONMENTAL & PHYSICAL
Dimension
Weight
445(W) x 418(D) x 88(H) mm
10 Kg (No HDD)
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
AC free volt (100 ~ 240VAC), 50/60Hz
PoC Power
DC 24V/7.5A (Option)
Power Consumption
Max. 100W Typical 70W(1 HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
44
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
NETWORK
Video input standard
SMPTE 292M (HD-SDI)
Odd channels support DoubleReach (Total 4 channels)
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Resolution / framerate
SMPTE 274M (1080p, 1920x1080) : 25, 30, 29.97 fps
DDNS
WNS, DynDNS, NoIP, WRS
Input format auto detection
Bandwidth limit
Supported
Connectors
8ch, 75Ω BNC connector
NTP
Server / Client / Both
PoC
8ch, Power over Coax, Max. 16 W/ch, Total 120W
Users
10 monitoring, 2 playback
CoC
8ch, Control over Coax, Max. 57,600bps
Streaming
1 HD, H.264 stream, Same as recording setting
1 additional H.264 stream, nHD(640 x 360)
VIDEO OUTPUT
Video Output
HDMI
1, 4, 8 split-screen
User defined sequence / Alarm pop-up
HD800F-PDR
1920 x 1080p via HDMI port
Full-HD & Full-Frame DVR supporting PoC/CoC, DoubleReachTM, RAID
RECORDING
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
SECURITY
User level
User privilege
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
IP filtering
Supported
STORAGE & BACKUP
Compression
Resolution
H.264 / JPEG
1920 x 1080
Rate
240/200 fps at 1080p
Storage devices
RAID Level
5 internal SATA HDDs, 1 external eSATA Interface
1/5/10 Supported
- 8ch HD-SDI Standalone DVR
Quality
1080p, 10 levels up to 12Mbps
File system
Proprietary file system, Data-loss protection against
- Certified by HDcctv Alliance
Mode
Manual & Event / Schedule & Event / Continuous & Event
- Self-power supply to all 8 cameras by PoC (Power over Cable) function
Schedule
24hrs / 7days
- Control all 8 cameras by CoC (Control over Coax) function
PLAYBACK
Key Features
Front
TM
- Doubles the video transmission distance by DoubleReach technology
- Max. 240/200fps Recording & Playback at Full-HD 1080p resolution
- Adjustable recording quality and framerate per each channel
Back
- Supports High-resolutions over 1200TV lines at Live/Playback
- Full-HD 1920x1080 resolution output via HDMI port
- Various Live and Playback display (1/4/8 Split-screen)
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
- Max. 5 Internal SATA Type HDDs
Dimension (unit:mm)
- Hardwired RAID system supporting RAID level 1/5/10
- Supports Max. 128TB(NS0104R connection via Gigabit ethernet) and
418
- At-the-PC Playback of removed DVR HDD
- Lightning arrester on HD-SDI, RS-485, DIO ports
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
ways such as E-map, Viewset
- Java Viewer for Chrome, Firefox, Safari
- Provides Full SDK for easy and powerful customization
45
USB drive (2 ports)
S.M.A.R.T.
Temperature and Health checking
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
SERIAL & I/O
Block playback
24hours ~ 99days
Serial port
Sensor input
1 RS-232C, 2 RS-485
8 Dry-contacts
Event source
Event check schedule
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
Relay output
4 Relays
Event action
Buzzer, Relay, E-mail, FTP, Alarm pop-up
Device
MD area
15 x 10
SOFTWARE
Sensor input
Dry contact (N.O. or N.C. selectable)
Text input
POS/ATM support, AVE VSI Pro/Hydra support
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
Mobile viewer
Monitoring / PTZ / LogView with iPhone & Android
CMS
Control Center Standard, Max. 1024 DVRs
SDK
ActiveX(COM) SDK
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
445
CONTROLLER
Front panel, IR remote, Joystick Keyboard, Mouse
ENVIRONMENTAL & PHYSICAL
AUDIO
Input/output
Compression
Input 4ch RCA / output HDMI, RCA
16KHz, 16bit sampling ADPCM
Dimension
Weight
Direction
Both
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
AC free volt (100 ~ 240VAC), 50/60Hz
PoC Power
DC 24V/5A (Option)
PTZ
Protocols
88
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
Backup device
Alarm source
Alarm action
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
Multi-channel or Single channel avi file
Instant playback / search
Max. 240/200 fps at 1080p
SYSTEM ALARM
Max. 32TB(e-SATA) external storage interface
Max. 32TB with eSATA
Backup type
Mode
Speed
EVENT & ALARM
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
power-failure
Capacity
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
445(W) x 418(D) x 88(H) mm
10 Kg (No HDD)
Power Consumption
Max. 100W Typical 70W(1 HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
46
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
NETWORK
Video input standard
SMPTE 292M (HD-SDI)
Odd channels support DoubleReach (Total 2 channels)
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Resolution / framerate
SMPTE 274M (1080p, 1920x1080) : 25, 30, 29.97 fps
DDNS
WNS, DynDNS, NoIP, WRS
Input format auto detection
Bandwidth limit
Supported
Connectors
4ch, 75Ω BNC connector
NTP
Server / Client / Both
PoC
4ch, Power over Coax, Max. 16 W/ch, Total 64W
Users
10 monitoring, 2 playback
CoC
4ch, Control over Coax, Max. 57,600bps
Streaming
1 HD, H.264 stream, Same as recording setting
1 additional H.264 stream, nHD(640 x 360)
VIDEO OUTPUT
Video Output
HDMI
1, 4 split-screen
User defined sequence / Alarm pop-up
HD400F-PDR
1920 x 1080p via HDMI port
Full-HD & Full-Frame DVR supporting PoC/CoC, DoubleReachTM, RAID
RECORDING
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
SECURITY
User level
User privilege
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
IP filtering
Supported
STORAGE & BACKUP
Compression
Resolution
H.264 / JPEG
1920 x 1080
Rate
120/100 fps at 1080p
Storage devices
RAID Level
5 internal SATA HDDs, 1 external eSATA Interface
1/5/10 Supported
- 4ch HD-SDI Standalone DVR
Quality
1080p, 10 levels up to 12Mbps
File system
Proprietary file system, Data-loss protection against
- Certified by HDcctv Alliance
Mode
Manual & Event / Schedule & Event / Continuous & Event
- Self-power supply to all 4 cameras by PoC (Power over Cable) function
Schedule
24hrs / 7days
- Control all 4 cameras by CoC (Control over Coax) function
PLAYBACK
Key Features
Front
TM
- Doubles the video transmission distance by DoubleReach technology
- Max. 120/100fps Recording & Playback at Full-HD 1080p resolution
- Adjustable recording quality and framerate per each channel
Back
- Supports High-resolutions over 1200TV lines at Live/Playback
- Full-HD 1920x1080 resolution output via HDMI port
- Various Live and Playback display (1/4 Split-screen)
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
- Max. 5 Internal SATA Type HDDs
Dimension (unit:mm)
- Hardwired RAID system supporting RAID level 1/5/10
- Supports Max. 128TB(NS0104R connection via Gigabit ethernet) and
418
- At-the-PC Playback of removed DVR HDD
- Lightning arrester on HD-SDI, RS-485, DIO ports
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
ways such as E-map, Viewset
- Java Viewer for Chrome, Firefox, Safari
- Provides Full SDK for easy and powerful customization
47
USB drive (2 ports)
S.M.A.R.T.
Temperature and Health checking
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
SERIAL & I/O
Block playback
24hours ~ 99days
Serial port
Sensor input
1 RS-232C, 2 RS-485
4 Dry-contacts
Event source
Event check schedule
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
Relay output
4 Relays
Event action
Buzzer, Relay, E-mail, FTP, Alarm pop-up
Device
MD area
15 x 10
SOFTWARE
Sensor input
Dry contact (N.O. or N.C. selectable)
Text input
POS/ATM support, AVE VSI Pro/Hydra support
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
Mobile viewer
Monitoring / PTZ / LogView with iPhone & Android
CMS
Control Center Standard, Max. 1024 DVRs
SDK
ActiveX(COM) SDK
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
445
CONTROLLER
Front panel, IR remote, Joystick Keyboard, Mouse
ENVIRONMENTAL & PHYSICAL
AUDIO
Input/output
Compression
Input 4ch RCA / output HDMI, RCA
16KHz, 16bit sampling ADPCM
Dimension
Weight
Direction
Both
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
AC free volt (100 ~ 240VAC), 50/60Hz
PoC Power
DC 24V/5A (Option)
PTZ
Protocols
88
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
Backup device
Alarm source
Alarm action
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
Multi-channel or Single channel avi file
Instant playback / search
Max. 120/100 fps at 1080p
SYSTEM ALARM
Max. 32TB(e-SATA) external storage interface
Max. 32TB with eSATA
Backup type
Mode
Speed
EVENT & ALARM
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
power-failure
Capacity
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
445(W) x 418(D) x 88(H) mm
10 Kg (No HDD)
Power Consumption
Max. 100W Typical 70W(1 HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
48
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
NETWORK
Video input standard
SMPTE 292M (HD-SDI)
Odd channels support DoubleReach (Total 4 channels)
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Resolution / framerate
SMPTE 274M(1080p, 1920x1080) : 25, 30, 29.97 fps
DDNS
WNS, DynDNS, NoIP, WRS
Input format auto detection
Bandwidth limit
Supported
Connectors
8ch, 75Ω BNC connector
NTP
Server / Client / Both
PoC
8ch, Power over Coax, Max. 16 W/ch, Total 120W
Users
10 monitoring, 2 playback
CoC
8ch, Control over Coax, Max. 57,600bps
Streaming
1 HD, H.264 stream, Same as recording setting
1 additional H.264 stream, nHD(640 x 360)
VIDEO OUTPUT
Video Output
HDMI
1, 4, 8 split-screen
User defined sequence / Alarm pop-up
HDC801F-PD
1920 x 1080p via HDMI port
Full-HD & Full-Frame DVR supporting PoC/CoC, DoubleReachTM
RECORDING
Compression
Resolution
H.264 / JPEG
1920 x 1080
Rate
240/200 fps at 1080p
- 8ch HD-SDI Standalone DVR
Quality
1080p, 10 levels up to 12Mbps
- The World’s First HDcctv Certified PoC/CoC 8ch HD-SDI DVR
Mode
- Self-power supply to all 8 cameras by PoC (Power over Cable) function
Schedule
- Control all 8 cameras by CoC (Control over Coax) function
PLAYBACK
Key Features
Front
TM
- Doubles the video transmission distance by DoubleReach technology
- Max. 240/200fps Recording & Playback at Full-HD 1080p resolution
- Adjustable recording quality and framerate per each channel
Back
- Supports High-resolutions over 1200TV lines at Live/Playback
- Full-HD 1920x1080 resolution output via HDMI port
- Various Live and Playback display (1/4/8 Split-screen)
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
- Max. 2 Internal SATA Type HDDs
- Supports Max. 32TB(e-SATA) external storage interface
Dimension (unit:mm)
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
393
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
ways such as E-map, Viewset
Supported
STORAGE & BACKUP
Manual & Event / Schedule & Event / Continuous & Event
Capacity
Max. 32TB with eSATA
24hrs / 7days
Backup type
Multi-channel or Single channel avi file
Backup device
USB drive (2 ports)
Temperature and Health checking
power-failure
Instant playback / search
Max. 240/200 fps at 1080p
S.M.A.R.T.
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
Block playback
24hours ~ 99days
Serial port
Sensor input
1 RS-232C, 2 RS-485
8 Dry-contacts
Relay output
2 Relays
SERIAL & I/O
Event source
Event check schedule
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
CONTROLLER
Event action
Buzzer, Relay, E-mail, FTP, Alarm pop-up
SOFTWARE
MD area
15 x 10
Sensor input
Dry contact (N.O. or N.C. selectable)
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
Text input
POS/ATM support, AVE VSI Pro/Hydra support
Mobile viewer
Monitoring / PTZ / LogView with iPhone & Android
CMS
Control Center Standard, Max. 1024 DVRs
SDK
ActiveX(COM) SDK
HDD fail, HDD almost full, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
AUDIO
- Java Viewer for Chrome, Firefox, Safari
Input/output
Compression
Input 4ch RCA / output HDMI, RCA
16KHz, 16bit sampling ADPCM
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
Direction
Both
- Provides Full SDK for easy and powerful customization
PTZ
Protocols
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
Device
Front panel, IR remote, Joystick Keyboard, Mouse
ENVIRONMENTAL & PHYSICAL
Dimension
Weight
350(W) x 393(D) x 88(H) mm
8 Kg (No HDD)
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
AC free volt (100 ~ 240VAC), 50/60Hz
PoC Power
DC 24V/5A (Option)
Power Consumption
Max. 75W Typical 50W (1HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
88
350
IP filtering
Mode
Speed
Alarm source
Alarm action
- Lightning arrester on HD-SDI, RS-485, DIO ports
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
2 internal SATA HDDs, 1 external eSATA Interface
Proprietary file system, Data-loss protection against
SYSTEM ALARM
- At-the-PC Playback of removed DVR HDD
User level
User privilege
Storage devices
File system
EVENT & ALARM
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
SECURITY
49
50
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
NETWORK
Video input standard
SMPTE 292M (HD-SDI)
Odd channels support DoubleReach (Total 2 channels)
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Resolution / framerate
SMPTE 274M(1080p, 1920x1080) : 25, 30, 29.97 fps
DDNS
WNS, DynDNS, NoIP, WRS
Input format auto detection
Bandwidth limit
Supported
Connectors
4ch, 75Ω BNC connector
NTP
Server / Client / Both
PoC
4ch, Power over Coax, Max. 16 W/ch, Total 64W
Users
10 monitoring, 2 playback
CoC
4ch, Control over Coax, Max. 57,600bps
Streaming
1 HD, H.264 stream, Same as recording setting
1 additional H.264 stream, nHD(640 x 360)
VIDEO OUTPUT
Video Output
HDMI
1, 4 split-screen
User defined sequence / Alarm pop-up
HDC400F-PD
1920 x 1080p via HDMI port
Full-HD & Full-Frame DVR supporting PoC/CoC, DoubleReachTM
RECORDING
Compression
Resolution
H.264 / JPEG
1920 x 1080
Rate
120/100 fps at 1080p
- 4ch HD-SDI Standalone DVR
Quality
1080p, 10 levels up to 12Mbps
- The World’s First HDcctv Certified PoC/CoC 4ch HD-SDI DVR
Mode
- Self-power supply to all 4 cameras by PoC (Power over Cable) function
Schedule
- Control all 4 cameras by CoC (Control over Coax) function
PLAYBACK
Key Features
Front
TM
- Doubles the video transmission distance by DoubleReach technology
- Max. 120/100fps Recording & Playback at Full-HD 1080p resolution
- Adjustable recording quality and framerate per each channel
Back
- Supports High-resolutions over 1200TV lines at Live/Playback
- Full-HD 1920x1080 resolution output via HDMI port
- Various Live and Playback display (1/4 Split-screen)
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
- Max. 1 Internal SATA Type HDDs
- Supports Max. 32TB(e-SATA) external storage interface
Dimension (unit:mm)
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
232
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
ways such as E-map, Viewset
Capacity
Max. 32TB with eSATA
24hrs / 7days
Backup type
Multi-channel or Single channel avi file
Backup device
USB drive (2 ports)
Temperature and Health checking
S.M.A.R.T.
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
Block playback
24hours ~ 99days
Serial port
Sensor input
1 RS-232C, 2 RS-485
4 Dry-contacts
Relay output
2 Relays
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
CONTROLLER
Event action
Buzzer, Relay, E-mail, FTP, Alarm pop-up
SOFTWARE
MD area
15 x 10
Sensor input
Dry contact (N.O. or N.C. selectable)
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
Text input
POS/ATM support, AVE VSI Pro/Hydra support
Mobile viewer
Monitoring with PTZ, iPhone & Android supported
CMS
Control Center Standard, Max. 1024 DVRs
SDK
ActiveX(COM) SDK
HDD fail, HDD almost full, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
AUDIO
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
Direction
Both
PTZ
Protocols
65
SERIAL & I/O
Event source
Event check schedule
- Java Viewer for Chrome, Firefox, Safari
51
power-failure
Instant playback / search
Max. 120/100 fps at 1080p
Input 4ch RCA / output HDMI
16KHz, 16bit sampling ADPCM
290
Supported
STORAGE & BACKUP
Manual & Event / Schedule & Event / Continuous & Event
Input/output
Compression
- Provides Full SDK for easy and powerful customization
IP filtering
Mode
Speed
Alarm source
Alarm action
- Lightning arrester on HD-SDI, RS-485, DIO ports
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
1 internal SATA HDDs, 1 external eSATA Interface
Proprietary file system, Data-loss protection against
SYSTEM ALARM
- At-the-PC Playback of removed DVR HDD
User level
User privilege
Storage devices
File system
EVENT & ALARM
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
SECURITY
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
Device
Front panel, IR remote, Joystick Keyboard, Mouse
ENVIRONMENTAL & PHYSICAL
Dimension
Weight
290(W) x 232(D) x 65(H) mm
2.5 Kg (No HDD)
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
DC24V, 5A
Power Consumption
Max. 30W Typical 20W (1HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
52
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
Video input standard
Resolution / framerate
Connectors
NETWORK
SMPTE 292M (HD-SDI)
SMPTE 274M (1080p, 1920x1080) : 25, 30, 29.97 fps
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Input format auto detection
DDNS
WNS, DynDNS, NoIP, WRS
16ch, 75Ω BNC connector
Bandwidth limit
Supported
NTP
Server / Client / Both
Users
10 monitoring, 2 playback
Streaming
1 HD, H.264 stream, Same as recording setting
VIDEO OUTPUT
Video Output
HDMI
1, 4, 9, 10, 13, 16 split-screen
1 additional H.264 stream, nHD(640 x 360)
User defined sequence / Alarm pop-up
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
1920 x 1080p via HDMI port
SECURITY
RECORDING
HD1600F-R
Full-HD & Full-Frame DVR supporting RAID
Key Features
Front
Compression
Resolution
H.264 / JPEG
1920 x 1080
User level
User privilege
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
Rate
480/400 fps at 1080p
IP filtering
Supported
Quality
1080p, 10 levels up to 12Mbps
STORAGE & BACKUP
Mode
Manual & Event / Schedule & Event / Continuous & Event
Storage devices
Schedule
24hrs / 7days
5 internal SATA HDDs, 1 external eSATA Interface,
1 Gigabit network for storage(NS04R)
- 16ch HD-SDI Standalone DVR
PLAYBACK
RAID Level
1/5/10 Supported
- Certified by HDcctv Alliance
Instant playback / search
Max. 480/400 fps at 1080p
File system
Proprietary file system, Data-loss protection against
- Max. 480/400fps Recording & Playback at Full-HD 1080p resolution
Mode
Speed
- Adjustable recording quality and framerate per each channel
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
Capacity
Max. 32TB with eSATA, Max. 128TB with cascaded NS04R
- Supports High-resolutions over 1200TV lines at Live/Playback
Block playback
24hours ~ 99days
Backup type
Multi-channel or Single channel avi file
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
EVENT & ALARM
Backup device
USB drive (2 ports)
Temperature and Health checking
- Full-HD 1920x1080 resolution output via HDMI port
Back
- Various Live and Playback display (1/4/9/10/13/16 Split-screen)
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
- Max. 5 Internal SATA Type HDDs
- Hardwired RAID system supporting RAID level 1/5/10
- Supports Max. 128TB(NS0104R connection via Gigabit ethernet) and
Max. 32TB(e-SATA) external storage interface
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
S.M.A.R.T.
Event action
Buzzer, Relay, E-mail, FTP, Alarm pop-up
MD area
15 x 10
Serial port
Sensor input
1 RS-232C, 2 RS-485
16 Dry-contacts
Sensor input
Dry contact (N.O. or N.C. selectable)
Relay output
4 Relays
Text input
POS/ATM support, AVE VSI Pro/Hydra support
CONTROLLER
- At-the-PC Playback of removed DVR HDD
Device
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
418
ways such as E-map, Viewset
- Java Viewer for Chrome, Firefox, Safari
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
Input/output
Compression
Input 4ch RCA / output HDMI, RCA
16KHz, 16bit sampling ADPCM
Mobile viewer
Monitoring / PTZ / LogView with iPhone & Android
CMS
Control Center Standard, Max. 1024 DVRs
Direction
Both
SDK
ActiveX(COM) SDK
ENVIRONMENTAL & PHYSICAL
PTZ
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
Protocols
- Provides Full SDK for easy and powerful customization
88
445
Front panel, IR remote, Joystick Keyboard, Mouse
SOFTWARE
AUDIO
- Lightning arrester on HD-SDI, RS-485, DIO ports
SERIAL & I/O
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
Alarm source
Alarm action
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
53
Event source
Event check schedule
SYSTEM ALARM
Dimension (unit:mm)
power-failure
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
Dimension
Weight
445(W) x 418(D) x 88(H) mm
10 Kg (No HDD)
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
AC free volt (100 ~ 240VAC), 50/60Hz
Power Consumption
Max. 100W Typical 70W(1 HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
54
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
Video input standard
Resolution / framerate
Connectors
NETWORK
SMPTE 292M (HD-SDI)
SMPTE 274M (1080p, 1920x1080) : 25, 30, 29.97 fps
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Input format auto detection
DDNS
WNS, DynDNS, NoIP, WRS
16ch, 75Ω BNC connector
Bandwidth limit
Supported
NTP
Server / Client / Both
Users
10 monitoring, 2 playback
Streaming
1 HD, H.264 stream, Same as recording setting
VIDEO OUTPUT
Video Output
HDMI
1, 4, 9, 10, 13, 16 split-screen
1 additional H.264 stream, nHD(640 x 360)
User defined sequence / Alarm pop-up
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
1920 x 1080p via HDMI port
SECURITY
RECORDING
HD1600F
Full-HD & Full-Frame Digital Video Recorder
Key Features
Front
Compression
Resolution
H.264 / JPEG
1920 x 1080
User level
User privilege
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
Rate
480/400 fps at 1080p
IP filtering
Supported
Quality
1080p, 10 levels up to 12Mbps
STORAGE & BACKUP
Mode
Manual & Event / Schedule & Event / Continuous & Event
Storage devices
Schedule
24hrs / 7days
5 internal SATA HDDs, 1 external eSATA Interface,
1 Gigabit network for storage(NS04R)
- 16ch HD-SDI Standalone DVR
PLAYBACK
File system
Proprietary file system, Data-loss protection against
- Certified by HDcctv Alliance
- Max. 480/400fps Recording & Playback at Full-HD 1080p resolution
Mode
Speed
Instant playback / search
Max. 480/400 fps at 1080p
Capacity
Max. 32TB with eSATA, Max. 128TB with cascaded NS04R
- Adjustable recording quality and framerate per each channel
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
Backup type
Multi-channel or Single channel avi file
- Supports High-resolutions over 1200TV lines at Live/Playback
Block playback
24hours ~ 99days
Backup device
USB drive (2 ports)
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
EVENT & ALARM
S.M.A.R.T.
Temperature and Health checking
- Full-HD 1920x1080 resolution output via HDMI port
Back
- Various Live and Playback display (1/4/9/10/13/16 Split-screen)
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
- Max. 5 Internal SATA Type HDDs
- Supports Max. 128TB(NS04R connection via Gigabit ethernet) and
Max. 32TB(e-SATA) external storage interface
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
Dimension (unit:mm)
Event action
Buzzer, Relay, E-mail, FTP, Alarm pop-up
Serial port
Sensor input
1 RS-232C, 2 RS-485
16 Dry-contacts
MD area
15 x 10
Relay output
4 Relays
Sensor input
Dry contact (N.O. or N.C. selectable)
CONTROLLER
Text input
POS/ATM support, AVE VSI Pro/Hydra support
Device
ways such as E-map, Viewset
418
- Java Viewer for Chrome, Firefox, Safari
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
88
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
Mobile viewer
Monitoring / PTZ / LogView with iPhone & Android
Input 4ch RCA / output HDMI, RCA
16KHz, 16bit sampling ADPCM
CMS
Control Center Standard, Max. 1024 DVRs
SDK
ActiveX(COM) SDK
Direction
Both
ENVIRONMENTAL & PHYSICAL
Protocols
445
Web viewer
Java viewer
Input/output
Compression
PTZ
- Provides Full SDK for easy and powerful customization
Front panel, IR remote, Joystick Keyboard, Mouse
SOFTWARE
AUDIO
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
55
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
Alarm source
Alarm action
- Lightning arrester on HD-SDI, RS-485, DIO ports
SERIAL & I/O
Event source
Event check schedule
SYSTEM ALARM
- At-the-PC Playback of removed DVR HDD
power-failure
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
Dimension
Weight
445(W) x 418(D) x 88(H) mm
10 Kg (No HDD)
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
AC free volt (100 ~ 240VAC), 50/60Hz
Power Consumption
Max. 100W Typical 70W(1 HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
56
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
Video input standard
Resolution / framerate
Connectors
NETWORK
SMPTE 292M (HD-SDI)
SMPTE 274M(1080p, 1920x1080) : 25, 30, 29.97 fps
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Input format auto detection
DDNS
WNS, DynDNS, NoIP, WRS
16ch, 75Ω BNC connector
Bandwidth limit
Supported
NTP
Server / Client / Both
Users
10 monitoring, 2 playback
Streaming
1 HD, H.264 stream, Same as recording setting
VIDEO OUTPUT
Video Output
HDMI
1, 4, 9, 10, 13, 16 split-screen
1 additional H.264 stream, nHD(640 x 360)
User defined sequence / Alarm pop-up
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
1920 x 1080p via HDMI port
SECURITY
RECORDING
HDC1601M
Full-HD Digital Video Recorder
Key Features
Front
Compression
Resolution
H.264 / JPEG
1920 x 1080
User level
User privilege
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
Rate
120/100 fps at 1080p
IP filtering
Supported
Quality
1080p, 10 levels up to 12Mbps
STORAGE & BACKUP
Mode
Manual & Event / Schedule & Event / Continuous & Event
Schedule
24hrs / 7days
Storage devices
File system
2 internal SATA HDDs, 1 external eSATA Interface
Proprietary file system, Data-loss protection against
power-failure
- 16ch HD-SDI Standalone DVR
PLAYBACK
- Certified by HDcctv Alliance
Instant playback / search
Max. 120/100 fps at 1080p
Capacity
Max. 32TB with eSATA
- Max. 120/100fps Recording & Playback at Full-HD 1080p resolution
Mode
Speed
Backup type
Multi-channel or Single channel avi file
- Adjustable recording quality and framerate per each channel
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
Backup device
USB drive (2 ports)
- Supports High-resolutions over 1200TV lines at Live/Playback
Block playback
24hours ~ 99days
S.M.A.R.T.
Temperature and Health checking
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
EVENT & ALARM
Back
- Full-HD 1920x1080 resolution output via HDMI port
- Various Live and Playback display (1/4/9/10/13/16 Split-screen)
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
- Max. 2 Internal SATA Type HDDs
- Supports Max. 32TB(e-SATA) external storage interface
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
- At-the-PC Playback of removed DVR HDD
- Lightning arrester on HD-SDI, RS-485, DIO ports
SERIAL & I/O
Event source
Event check schedule
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
Serial port
Sensor input
1 RS-232C, 2 RS-485
16 Dry-contacts
Event action
Buzzer, Relay, E-mail, FTP, Alarm pop-up
Relay output
2 Relays
MD area
15 x 10
CONTROLLER
Sensor input
Dry contact (N.O. or N.C. selectable)
Device
Text input
POS/ATM support, AVE VSI Pro/Hydra support
SOFTWARE
SYSTEM ALARM
Dimension (unit:mm)
Alarm source
Alarm action
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
HDD fail, HDD almost full, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
AUDIO
ways such as E-map, Viewset
- Java Viewer for Chrome, Firefox, Safari
393
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
- Provides Full SDK for easy and powerful customization
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
Mobile viewer
Monitoring / PTZ / LogView with iPhone & Android
CMS
Control Center Standard, Max. 1024 DVRs
ActiveX(COM) SDK
Input/output
Compression
Input 4ch RCA / output HDMI, RCA
16KHz, 16bit sampling ADPCM
SDK
Direction
Both
Dimension
Weight
350(W) x 393(D) x 88(H) mm
8 Kg (No HDD)
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
AC free volt (100 ~ 240VAC), 50/60Hz
PTZ
Protocols
ENVIRONMENTAL & PHYSICAL
Power Consumption
Max. 75W Typical 50W (1HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
88
350
Front panel, IR remote, Joystick Keyboard, Mouse
57
58
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
Video input standard
Resolution / framerate
Connectors
NETWORK
SMPTE 292M (HD-SDI)
SMPTE 274M (1080p, 1920x1080) : 25, 30, 29.97 fps
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Input format auto detection
DDNS
WNS, DynDNS, NoIP, WRS
8ch, 75Ω BNC connector
Bandwidth limit
Supported
NTP
Server / Client / Both
Users
10 monitoring, 2 playback
Streaming
1 HD, H.264 stream, Same as recording setting
VIDEO OUTPUT
Video Output
HDMI
1, 4, 8 split-screen
1 additional H.264 stream, nHD(640 x 360)
User defined sequence / Alarm pop-up
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
1920 x 1080p via HDMI port
SECURITY
RECORDING
HD800F-R
Full-HD & Full-Frame DVR supporting RAID
Key Features
Front
Compression
Resolution
H.264 / JPEG
1920 x 1080
User level
User privilege
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
Rate
240/200 fps at 1080p
IP filtering
Supported
Quality
1080p, 10 levels up to 12Mbps
STORAGE & BACKUP
Mode
Manual & Event / Schedule & Event / Continuous & Event
Schedule
24hrs / 7days
Storage devices
RAID Level
5 internal SATA HDDs, 1 external eSATA Interface
1/5/10 Supported
File system
Proprietary file system, Data-loss protection against
- 8ch HD-SDI Standalone DVR
PLAYBACK
- Certified by HDcctv Alliance
- Max. 240/200fps Recording & Playback at Full-HD 1080p resolution
Mode
Speed
Instant playback / search
Max. 240/200 fps at 1080p
Capacity
Max. 32TB with eSATA
- Adjustable recording quality and framerate per each channel
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
Backup type
Multi-channel or Single channel avi file
- Supports High-resolutions over 1200TV lines at Live/Playback
Block playback
24hours ~ 99days
Backup device
USB drive (2 ports)
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
EVENT & ALARM
S.M.A.R.T.
Temperature and Health checking
- Full-HD 1920x1080 resolution output via HDMI port
Back
- Various Live and Playback display (1/4/8 Split-screen)
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
- Max. 5 Internal SATA Type HDDs
- Hardwired RAID system supporting RAID level 1/5/10
- Supports Max. 32TB(e-SATA) external storage interface
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
Dimension (unit:mm)
Event action
Buzzer, Relay, E-mail, FTP, Alarm pop-up
Serial port
Sensor input
1 RS-232C, 2 RS-485
8 Dry-contacts
MD area
15 x 10
Relay output
4 Relays
Sensor input
Dry contact (N.O. or N.C. selectable)
CONTROLLER
Text input
POS/ATM support, AVE VSI Pro/Hydra support
Device
ways such as E-map, Viewset
418
- Java Viewer for Chrome, Firefox, Safari
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
88
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
Mobile viewer
Monitoring / PTZ / LogView with iPhone & Android
Input 4ch RCA / output HDMI, RCA
16KHz, 16bit sampling ADPCM
CMS
Control Center Standard, Max. 1024 DVRs
SDK
ActiveX(COM) SDK
Direction
Both
ENVIRONMENTAL & PHYSICAL
Protocols
445
Web viewer
Java viewer
Input/output
Compression
PTZ
- Provides Full SDK for easy and powerful customization
Front panel, IR remote, Joystick Keyboard, Mouse
SOFTWARE
AUDIO
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
59
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
Alarm source
Alarm action
- Lightning arrester on HD-SDI, RS-485, DIO ports
SERIAL & I/O
Event source
Event check schedule
SYSTEM ALARM
- At-the-PC Playback of removed DVR HDD
power-failure
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
Dimension
Weight
445(W) x 418(D) x 88(H) mm
10 Kg (No HDD)
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
AC free volt (100 ~ 240VAC), 50/60HzZ
Power Consumption
Max. 100W Typical 70W(1 HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
60
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
Video input standard
Resolution / framerate
Connectors
NETWORK
SMPTE 292M (HD-SDI)
SMPTE 274M(1080p, 1920x1080) : 25, 30, 29.97 fps
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Input format auto detection
DDNS
WNS, DynDNS, NoIP, WRS
8ch, 75Ω BNC connector
Bandwidth limit
Supported
NTP
Server / Client / Both
Users
10 monitoring, 2 playback
Streaming
1 HD, H.264 stream, Same as recording setting
VIDEO OUTPUT
Video Output
HDMI
1, 4, 8 split-screen
1 additional H.264 stream, nHD(640 x 360)
User defined sequence / Alarm pop-up
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
1920 x 1080p via HDMI port
SECURITY
RECORDING
HDC801F
Full-HD & Full-Frame Digital Video Recorder
Key Features
Front
Compression
Resolution
H.264 / JPEG
1920 x 1080
User level
User privilege
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
Rate
240/200 fps at 1080p
IP filtering
Supported
Quality
1080p, 10 levels up to 12Mbps
STORAGE & BACKUP
Mode
Manual & Event / Schedule & Event / Continuous & Event
Schedule
24hrs / 7days
Storage devices
File system
2 internal SATA HDDs, 1 external eSATA Interface
Proprietary file system, Data-loss protection against
power-failure
- 8ch HD-SDI Standalone DVR
PLAYBACK
- Certified by HDcctv Alliance
Instant playback / search
Max. 240/200 fps at 1080p
Capacity
Max. 32TB with eSATA
- Max. 240/200fps Recording & Playback at Full-HD 1080p resolution
Mode
Speed
Backup type
Multi-channel or Single channel avi file
- Adjustable recording quality and framerate per each channel
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
Backup device
USB drive (2 ports)
- Supports High-resolutions over 1200TV lines at Live/Playback
Block playback
24hours ~ 99days
S.M.A.R.T.
Temperature and Health checking
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
EVENT & ALARM
Back
- Full-HD 1920x1080 resolution output via HDMI port
- Various Live and Playback display (1/4/8 Split-screen)
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
- Max. 2 Internal SATA Type HDDs
- Supports Max. 32TB(e-SATA) external storage interface
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
- At-the-PC Playback of removed DVR HDD
- Lightning arrester on HD-SDI, RS-485, DIO ports
SERIAL & I/O
Event source
Event check schedule
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
Serial port
Sensor input
1 RS-232C, 2 RS-485
8 Dry-contacts
Event action
Buzzer, Relay, E-mail, FTP, Alarm pop-up
Relay output
2 Relays
MD area
15 x 10
CONTROLLER
Sensor input
Dry contact (N.O. or N.C. selectable)
Device
Text input
POS/ATM support, AVE VSI Pro/Hydra support
SOFTWARE
SYSTEM ALARM
Dimension (unit:mm)
Alarm source
Alarm action
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
HDD fail, HDD almost full, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
AUDIO
ways such as E-map, Viewset
- Java Viewer for Chrome, Firefox, Safari
393
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
- Provides Full SDK for easy and powerful customization
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
Mobile viewer
Monitoring / PTZ / LogView with iPhone & Android
CMS
Control Center Standard, Max. 1024 DVRs
ActiveX(COM) SDK
Input/output
Compression
Input 4ch RCA / output HDMI, RCA
16KHz, 16bit sampling ADPCM
SDK
Direction
Both
Dimension
Weight
350(W) x 393(D) x 88(H) mm
8 Kg (No HDD)
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
AC free volt (100 ~ 240VAC), 50/60Hz
PTZ
Protocols
ENVIRONMENTAL & PHYSICAL
Power Consumption
Max. 75W Typical 50W (1HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
88
350
Front panel, IR remote, Joystick Keyboard, Mouse
61
62
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
Video input standard
Resolution / framerate
Connectors
NETWORK
SMPTE 292M (HD-SDI)
SMPTE 274M(1080p, 1920x1080) : 25, 30, 29.97 fps
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Input format auto detection
DDNS
WNS, DynDNS, NoIP, WRS
8ch, 75Ω BNC connector
Bandwidth limit
Supported
NTP
Server / Client / Both
Users
10 monitoring, 2 playback
Streaming
1 HD, H.264 stream, Same as recording setting
VIDEO OUTPUT
Video Output
HDMI
1, 4, 8 split-screen
1 additional H.264 stream, nHD(640 x 360)
User defined sequence / Alarm pop-up
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
1920 x 1080p via HDMI port
SECURITY
RECORDING
HDC801H
Full-HD Digital Video Recorder
Key Features
Front
Compression
Resolution
H.264 / JPEG
1920 x 1080
User level
User privilege
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
Rate
120/100 fps at 1080p
IP filtering
Supported
Quality
1080p, 10 levels up to 12Mbps
STORAGE & BACKUP
Mode
Manual & Event / Schedule & Event / Continuous & Event
Schedule
24hrs / 7days
Storage devices
File system
2 internal SATA HDDs, 1 external eSATA Interface
Proprietary file system, Data-loss protection against
power-failure
- 8ch HD-SDI Standalone DVR
PLAYBACK
- Certified by HDcctv Alliance
Instant playback / search
Max. 120/100 fps at 1080p
Capacity
Max. 32TB with eSATA
- Max. 100/120fps Recording & Playback at Full-HD 1080p resolution
Mode
Speed
Backup type
Multi-channel or Single channel avi file
- Adjustable recording quality and framerate per each channel
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
Backup device
USB drive (2 ports)
- Supports High-resolutions over 1200TV lines at Live/Playback
Block playback
24hours ~ 99days
S.M.A.R.T.
Temperature and Health checking
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
EVENT & ALARM
Back
- Full-HD 1920x1080 resolution output via HDMI port
- Various Live and Playback display (1/4/8 Split-screen)
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
- Max. 2 Internal SATA Type HDDs
- Supports Max. 32TB(e-SATA) external storage interface
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
- At-the-PC Playback of removed DVR HDD
- Lightning arrester on HD-SDI, RS-485, DIO ports
SERIAL & I/O
Event source
Event check schedule
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
Serial port
Sensor input
1 RS-232C, 2 RS-485
8 Dry-contacts
Event action
Buzzer, Relay, E-mail, FTP, Alarm pop-up
Relay output
2 Relays
MD area
15 x 10
CONTROLLER
Sensor input
Dry contact (N.O. or N.C. selectable)
Device
Text input
POS/ATM support, AVE VSI Pro/Hydra support
SOFTWARE
SYSTEM ALARM
Dimension (unit:mm)
Alarm source
Alarm action
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
HDD fail, HDD almost full, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
AUDIO
ways such as E-map, Viewset
- Java Viewer for Chrome, Firefox, Safari
393
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
- Provides Full SDK for easy and powerful customization
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
Mobile viewer
Monitoring / PTZ / LogView with iPhone & Android
CMS
Control Center Standard, Max. 1024 DVRs
ActiveX(COM) SDK
Input/output
Compression
Input 4ch RCA / output HDMI, RCA
16KHz, 16bit sampling ADPCM
SDK
Direction
Both
Dimension
Weight
350(W) x 393(D) x 88(H) mm
8 Kg (No HDD)
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
AC free volt (100 ~ 240VAC), 50/60Hz
PTZ
Protocols
ENVIRONMENTAL & PHYSICAL
Power Consumption
Max. 75W Typical 50W (1HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
88
350
Front panel, IR remote, Joystick Keyboard, Mouse
63
64
HD-CCTV DVR
Premium to your security
Specifications
VIDEO INPUT
Video input standard
Resolution / framerate
Connectors
NETWORK
SMPTE 292M (HD-SDI)
SMPTE 274M(1080p, 1920x1080) : 25, 30, 29.97 fps
Interface
Type
1 Gigabit Ethernet (10/100/1000Mbps)
Static IP, Dynamic IP, xDSL
Input format auto detection
DDNS
WNS, DynDNS, NoIP, WRS
4ch, 75Ω BNC connector
Bandwidth limit
Supported
NTP
Server / Client / Both
Users
10 monitoring, 2 playback
Streaming
1 HD, H.264 stream, Same as recording setting
VIDEO OUTPUT
Video Output
HDMI
1, 4 split-screen
1 additional H.264 stream, nHD(640 x 360)
User defined sequence / Alarm pop-up
1 JPEG stream, nHD(640 x 360) for e-mail or mobile
1920 x 1080p via HDMI port
SECURITY
RECORDING
HDC400F
Full-HD & Full-Frame Digital Video Recorder
Key Features
Front
Compression
Resolution
H.264 / JPEG
1920 x 1080
User level
User privilege
1 admin, 10 users
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC
Rate
120/100 fps at 1080p
IP filtering
Supported
Quality
1080p, 10 levels up to 12Mbps
STORAGE & BACKUP
Mode
Manual & Event / Schedule & Event / Continuous & Event
Schedule
24hrs / 7days
Storage devices
File system
2 internal SATA HDDs
Proprietary file system, Data-loss protection against
power-failure
- 4ch HD-SDI Standalone DVR
PLAYBACK
- Certified by HDcctv Alliance
Instant playback / search
Max. 120/100 fps at 1080p
Backup type
Multi-channel or Single channel avi file
- Max. 120/100fps Recording & Playback at Full-HD 1080p resolution
Mode
Speed
Backup device
USB drive (2 ports)
- Adjustable recording quality and framerate per each channel
Search type
Time, Calendar, Timeline, Event, Thumbnail, Smart, Text
S.M.A.R.T.
Temperature and Health checking
- Supports High-resolutions over 1200TV lines at Live/Playback
Block playback
24hours ~ 99days
SERIAL & I/O
- Supports Dual Codec(H.264,JPEG) & Multi Stream (HD, nHD(640x360))
- Full-HD 1920x1080 resolution output via HDMI port
EVENT & ALARM
Back
- Various Live and Playback display (1/4 Split-screen)
- Robust IPFR (Intelligent Power Failure Recovery) DVR File System
- Max. 2 Internal SATA Type HDDs
- Date/Time, Calendar, Event, Thumbnail, Smart, Text Search available
- At-the-PC Playback of removed DVR HDD
- Lightning arrester on HD-SDI, RS-485, DIO ports
- Provides bundle CMS program, managing Max. 1,024 DVRs in various
- Supports various mobile platform (iPhone/Android Viewer, Mobile page)
232
- Provides Full SDK for easy and powerful customization
CONTROLLER
MD area
15 x 10
Device
Sensor input
Dry contact (N.O. or N.C. selectable)
SOFTWARE
Text input
POS/ATM support, AVE VSI Pro/Hydra support
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event / PTZ with IE, Chrome, Safari
HDD fail, HDD almost full, Password fail, WRS fail
Warning message, Buzzer, E-mail, Relay
Mobile viewer
Monitoring / PTZ / LogView with iPhone & Android
CMS
Control Center Standard, Max. 1024 DVRs
SDK
ActiveX(COM) SDK
Input/output
Compression
Input 4ch RCA / output HDMI
16KHz, 16bit sampling ADPCM
Direction
Both
PTZ
Protocols
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, Panasonic and others
Front panel, IR remote, Joystick Keyboard, Mouse
ENVIRONMENTAL & PHYSICAL
Dimension
Weight
290(W) x 232(D) x 65(H) mm
2.5 Kg (No HDD)
Operating temperature
5°C~45°C (41°F ~ 113°F)
Power
DC12V, 5A
Power Consumption
Max. 30W Typical 20W (1HDD)
Approval
KC, FCC, CE, RoHS, HDcctv
65
290
2 Relays
Buzzer, Relay, E-mail, FTP, Alarm pop-up
AUDIO
- Java Viewer for Chrome, Firefox, Safari
Relay output
Event action
Alarm source
Alarm action
ways such as E-map, Viewset
1 RS-232C, 2 RS-485
4 Dry-contacts
MD(Motion Detection), Sensor, Text, Video Loss
24hrs / 7days
SYSTEM ALARM
Dimension (unit:mm)
Serial port
Sensor input
Event source
Event check schedule
65
66
HD-CCTV
Storage
HD-CCTV Storage
Premium to your security
Front
Back
Specifications
SYSTEM
NS04R
HD-CCTV External Storage Equipment
Key Features
OS
Storage device
Embedded linux
4 SATA interface with hot-swap function
Intelligent file system
Data-loss protection against power failure
Capacity / Unit
Max 32TB
Capacity Expansion
Max 128TB by cascaded NS04R
Max 8 NS04R can be cascaded
Dimension (unit:mm)
RECORDING
- Dedicated storage equipment for DVR
Performance
RAID
- Supports WEBGATE’s HD DVR series
- Max. 128TB storage expansion
383
- RAID Level 1/5/10 and support Auto-Rebuiding
- IPFR (Intelligent Power Failure Recovery) file system
NETWORK
Connection 1
Connection 2
- At-the-PC Playback of removed DVR HDD
- 4 Hot-Swap, SATA type HDD bays
96Mbps
RAID level 1/5/10 with Auto Rebuild
Gigabit ethernet for DVR connection
Gigabit ethernet for cascaded connection of NS04R
- Built-in 1 network port for DVR connection
ENVIRONMENTAL & PHYSICAL
445
44
- Built-in 1 network port for NS04R cascade connection
69
Dimension
Weight
445(W) x 383(D) x 44(H) mm
Approx. 5.5 Kg (with one HDD)
Operating Temperature
5°C ~ 45°C (41°F ~ 113°F)
Power
AC free voltage (100 ~ 240V), 50/60Hz
Power consumption
Max. 85W Typical 60W
Approval
FCC, CE, MIC, RoHS
70
HD-CCTV Storage
Premium to your security
Front
Back
Specifications
ELECTRICAL
ES0104
e-SATA RAID Subsystem
Key Features
- 1U/4Bays, eSATA - SATA II RAID sub-system
Dimension (unit:mm)
Form-factor
RAID processor
1U 19-inch rackmount chassis
Integrated Micro Processor
RAID level
0, 1, 3, 5, 10, Large
No. of channels (host+drive)
1+4
Host bus interface
eSATA x 1, USB 3.0 x 1, 1394b x 2
Drive bus interface
SATA II (Up to 3.0Gbps)
Data transfer rate
Up to 3Gbps (eSATA)
Up to 5Gbps (USB 3.0)
446.4
Up to 800Mbps (1394b)
Hot-swap drive trays
Four(4) 3.5-inch Disk trays
- SATAII (up to 3Gbps) host bus interface
Cooling fan
1
- Supports hot spare and automatic rebuild
Management Interface
Locally RAID Level Switch / In-Band GUI
- Local event notification
Failed drive indicators
Yes
- Real time drive activity and system status indicators
Failed drive auto rebuild
Yes
- Easy RAID level maintenance
Environment monitor
Yes
- Max. 8TB support interfaced with LH/EH/MH DVR series
Auto spare support
Yes
- Max 32TB support interfaced with HD DVR series
Power supply
220W with PFC
500
- RAID : 0,1, 3, 5, 10, Large
AC 90V ~ 264V Full Range
3A~5A, 50~60Hz
44
486.4
71
ENVIRONMENTAL
Relative Humidity
Operating Temperature
10% ~ 85% Non-condensing
10°C ~ 40°C (50°F ~ 104°F)
Physical Dimensions
486.4(W) x 500(D) x 44(H) mm
Weight
6.8kg (without HDD)
72
HD-CCTV Storage
Premium to your security
Specifications
ELECTRICAL
Form-factor
RAID processor
2U 19-inch rackmount chassis
400MHz storage I/O processor
RAID level
0 , 1 , 10 (1E) , 3 , 5 , 6 and JBOD
Cache memory
256MB
No. of channels (host+drive)
4+12
Host bus interface
USB 2.0 / eSATA x 2 / iSCSI
*Only eSATA is suitable for DVR connection
Drive bus interface
SATA II (Up to 3.0 Gbps)
Data transfer rate
Support up to 480 Mbps (USB 2.0)
Support up to 3.0 Gbps (SATA II)
Support 10 / 100 / 1000 Mbps Ethernet
Hot-swap drive trays
Twelve (12) 1-inch trays
Cooling fan
2
Password protection
Yes
Audible alarm
Yes
Failed drive indicators
Yes
Failed drive auto rebuild
Yes
Online consistency check
Yes
Online expansion
No
Array Roaming
Yes
Online RAID level/ stripe size migration
Yes
- RAID 0,1,10(1E),3,5,6 and JBOD
Instant availability and background initialization
Yes
- Redundant power supplier
Environment monitor
Yes
- eSATA (3Gbps) host interface
Auto spare support
Yes
- Max. 8TB support interfaced with LH/EH/MH DVR series
Bad block auto-remapping
Yes
- Max 32TB support interfaced with HD DVR series
Remote management
Yes
- Hot-spare and auto rebuild
MAID support
Yes
- Inside buzzer alarm
Over 2TB support
Yes
- Password protection
Power supplies
400W x2 redundant power supplies w/PFC
- Serial port for external event notification
Power requirements
AC 100V ~ 240V +/-10% Full range, 6A ~ 3A, 50Hz ~ 60Hz
e-SATA RAID Subsystem
Key Features
- 2U/12Bays, eSATA - SATA II RAID sub-system
Dimension (unit:mm)
446
500
ES0212
- Smart LCD panel
- Real-time drive and status notification
482
ENVIRONMENTAL
88
- Web base GUI management utility
73
Relative Humidity
Operating Temperature
10% ~ 85% Non-condensing
10°C ~ 40°C (50°F ~ 104°F)
Physical Dimensions
482(W) x 500(D) x 88(H) mm
Weight
14.4kg (without HDD)
74
HD-CCTV
CAMERA
HD-CCTV
CAMERA
1080p Full HD
Anti-Motion blur
SMART IR-LED Control
Digital Slow Shutter
Auto Focus
PoC/CoC
HD-CCTV Camera Features
Premium to your security
True Plug & Play Support
DVR interface : Remote camera control by DVR
PoC camera’s operating power is supplied from PoC DVR through coaxial cable. That is, cameras do not need additional installation of power supply, and just connecting coaxial cable, you can get Full-HD 1080p high-resolution video.
Also, PoC camera’s control commands can receive through same coaxial cable. Because it helps easy control of Zoom/Focus
and OSD menu, it increases the operational efficiency.
If PoC cameras are connected to a PoC DVR directly or if Non-PoC cameras are connected to a DVR by serial communication,
DVR can control all the OSD menu of camera, and allow user to upgrade camera firmware. By this function, user can even
manage the camera through network. In case of -AF models, users can control camera’s zoom and Focus.
PoC Camera
PoC DVR
Power (PoC) + RS485 (CoC)
PoC Cameras
PoC DVR
HD1080p HD-SDI Video
OSD Control/Firmware Upgrade
& Zoom/Focus Control
Easy Installation and maintenance of PoC camera
Once a PoC camera is connected to a PoC DVR, DVR can control
all camera functions including OSD menu without additional cable
installation. Also, a wired remote controller is provided with a PoC
camera to support easier installation.
Ethernet
Non-PoC Cameras
RS485
OSD Control/Firmware Upgrade
& Zoom/Focus Control
Non-PoC DVR
RS485
77
78
HD-CCTV Camera Features
Premium to your security
High-Resolution : Provides 1,200TV Line
Auto Focus : Auto Focus by one-push
All HD-CCTV camera products provide high-quality Full-HD(1920 x 1080) video image.
They uses state-of-the-art signal processing technology to show excellent video.
AF series cameras support auto focus function. To adjust focus of HD camera is very difficult working at actual installation site.
Auto focus solution can help users to get the best HD video image without complicated adjustments. And also, if PoC cameras
are connected a PoC DVR, user can control camera OSD menu, Zoom/Focus through coaxial cable without additional cable
installation. In case of Non-PoC cameras, if serial cable is connected between camera and DVR, user can control camera.
WGI HD-SDI Camera (C1080B)
Over
1,200
TV Line
Before Auto Focus
After Auto Focus
Excellent Sensitivity : Clear image at 0.0005 lux
High-performance signal processing makes camera to have high sensitivity at dark environment where even human eyes
cannot identify target object.
(BW: 0.0005Lux / Color: [email protected], F1.2, 3100K, DSS off)
WGI C1080B (2M, CMOS, 0.2Lux)
“S” Camera (2M, CMOS, 1.0Lux)
Test Environment: 0.08 Lux Color Mode - F1.2, Fluorescent
79
WGI C1080B (2M, CMOS, 0.0005Lux)
“S” Camera (2M, CMOS, 0.1Lux)
Test Environment: 0.005 Lux B/W Mode - F1.2, Fluorescent
80
HD-CCTV Camera Features
Premium to your security
Anti-Motion blur : Delivers more clear image for a moving object
[Outdoor Mode]
Clear images, without motion blurring, are provided using highly performed new video signal processing.
This mode minimizes the motion blurring at outdoor environment, and it is especially useful for the license plate recognition
on the road. This function also minimizes the image blurring caused by camera vibration, and provides clear video image.
[Indoor Mode]
This mode minimizes the motion blurring in indoor environment like entrance or corridor.
Motion Blur
Motion Blur
81
Anti-Motion Blur
Anti-Motion Blur
Normal
Anti-Motion Blur
82
HD-CCTV Camera Features
Premium to your security
CVBS output : Auxiliary analog video output
Test Pattern : Color Bar, Stress Pattern
All camera models provide CVBS(NTSC/PAL) video signal output to support easy installation.
If use this CVBS output, installer can easily adjust focus and angle of view without using HD video.
To help checking the quality of HD-SDI transmission cable,
cameras support color bar and stress pattern. This is a request from HDcctv Alliance and it also helps to check product’s well-working condition. Especially, Stress pattern is the
most sensitive video image to cable quality.
WDR : Smart Backlight Compensation
Color Bar
WDR function helps cameras to show clear video images even with very bright and dark scene are mixed in the same image.
Users may select BLC or HLC function according to the installed environment.
Stress Pattern
SMART IR-LED : Intelligent brightness control
WDR OFF
WDR ON
SMART IR-LED function automatically controls the intensity of IR-LED according to the distance with the target. Cameras can
show clear video image without saturation of light at dark environment.
White Balance : Nature color as it is…
Camera delivers natural color images by excellent color reproduction performance against various light conditions.
C1080B(2M, CMOS)
83
“L” company (2M IP, CMOS)
“G” company (2M HD-SDI, CMOS)
Normal IR-LED
Smart IR-LED
84
HD-CCTV Camera Features
Premium to your security
DSS : Digital Slow Shutter (Sense-up)
3DNR : Powerful 3-Dimensional Digital Noise Reduction
At very dark environment, DSS function accumulates the light into the sensor pixels, and provides visible video image as a
result.
3DNR function removes video noise at dark environment, and it provides clear video image as a result. We adopted 3DNR and
it provides better performance than 2DNR.
3DNR function removes video noise at dark environment, providing clear video during low light environment. HD-CCTV cameras adopted 3NDR technology because it surpasses the performance shown in 2DNR.
Light Off, DSS Off
Light Off, DSS ON = 5x
Light Off, DSS ON = 10x
C1080B 3DNR OFF
C1080B 3DNR ON (high)
TDN : True Day & Night
TDN function always provides clear video image by distinguishing daytime and nighttime. In case of night time, TDN mechanism removes IR-CUT filter to gather more light including IR light source.
Dual Voltage : DC12V / AC24V
Regarding Non-PoC camera products, users may select either
DC12V or AC24V according to the install environment. Both
power inputs use same terminal, and camera contains a protection circuit for reverse DC polarity input.
Light On, Day Mode (228 Lux)
85
Light Off, Day Mode (0 Lux)
DC12V
AC24V
Light Off, Night Mode (0 Lux)
86
HD-CCTV Camera Features
Premium to your security
Low power consumption
Product Family : HD Camera
HD-CCTV cameras show lower power consumption compared
to competitors’ products. They show lower heating result and
because cameras are very sensitive to their installation environment, we significantly increased the reliability of products.
There are diverse PoC and Non-PoC camera models composed of box, indoor/outdoor dome, bullet and PTZ. Especially, dome
and bullet camera models support IR-LED and Auto focus function and help easy installation and maintenance.
LOW
Electric Power
Excellent mechanical design
Dome type camera’s 3-axis gimbal provides easy installation.
Box type camera’s front case keeps lens exactly perpendicular to sensor, and it provides homogeneous focus over the whole
video image.
Bullet type camera requires only one screw to fix its position, which is also convenient when it comes to installation.
type
Appearance
PoC Model
Non-PoC Model
C1080PBM
BOX
C1080B
Box Camera (Patent pending: 10-2011-0014790)
Title: Design of camera front case
Substance: Mechanical design which keeps the center of image sensor
and lens for fine focusing. The design minimized the mechanical error.
Bullet Camera (Patent No. : 10-1018881)
Title: CCTV Bracket
Substance: Mechanical design fixing 3-axis with ease which is used for adjusting of angle of view.
87
Plastic Dome
C1080PD, C1080PD-AF
C1080PD-IR, C1080PD-IR-AF
C1080D, C1080D-AF
C1080D-IR, C1080D-IR-AF
Vandal Dome
C1080PVD, C1080PVD-AF
C1080PVD-IP, C1080PVD-IP
C1080VD, C1080VD-AF
C1080VD-IR, C1080VD-IR-AF
C1080PBL-IR18
C1080PBL-IR18-AF
C1080PBL-IR48-AF
C1080BL-IR18
C1080BL-IR18-AF
C1080BL-IR48-AF
Bullet
PTZ
C1080PT-Z20*
C1080PT-Z20F*
All models acquired HDcctv 1.0 certificate (Except * marked 2 models)
88
HD-CCTV CAMERA
Premium to your security
Specifications
VIDEO
Sensor Type
Total Pixels
1/3” 2.1Megapixel CMOS
1920(H) x 1080(V) = 2.1M pixels
Scanning System
Min illumination
Progressive Scan
B/W
[email protected], F1.2, 3100K, DSS(OFF), AGC(10)
Color
[email protected], F1.2, 3100K, DSS(OFF), AGC(10)
Mount
CS/ C(Ring Adaptor)
Filter
True Day & Night (ICR)
type
DC Auto Iris, Manual
Output
1(BNC 1.0 Vp-p, 75Ω)
Resolution
1080p 30/25fps, 720p 30/25fps (Clipping)
HD-SDI
SMPTE 292M compatible
Distance
Approx. 200m(650 ft.) via RG6, 150m(490 ft.) via RG59
Control Method
OSD(5 Push Buttons), DVR, CMS(Control Center)
AGC
1 ~ 10 steps
Mirror
Horizontal / Vertical
WDR
OFF, 0 ~ 4 step
BLC
ACE
DNR
OFF, LOW, MIDDLE, HIGH
OFF, ON
OFF, LOW, MIDDLE, HIGH
DSS
OFF, x2 ~ x10
White Balance
AUTO, PRESET, MANUAL
Electric shutter
INDOOR, OUTDOOR, INDOOR-ANTI BLUR, OUTDOOR-ANTI BLUR, MANUAL(12steps)
D-ZOOM
0 ~ 16 steps
ANTI-FLICKER
OFF, ON
Lens Shading
OFF, ON
- Certified by HDcctv Alliance
HLC
0 ~ 10 steps
- 1/3” 2.1M CMOS progressive image sensor
Privacy
OFF, ON (28 Zones )
Lens
Video Output
Video Control
C1080B
High-Definition Box Camera
Key Features
Dimension (unit:mm)
CONTROL INTERFACE
63
- HD-SDI 1080p30/25 & 720p30/25 video output
- Horizontal/Vertical resolution over 1200TV lines
- High-performance under low light environment
(BW : 0.0005Lux/ Color : [email protected], F.1.4, 3100K, DSS off )
- 3DNR (Noise Reduction)
- Backlight compensation of WDR/BLC/HLC
- Privacy zone function (Color selectable)
- True Day&Night with IR cut filter removable
- Anti-Motion Blur function
- Remote OSD control & camera upgrade through RS485 from DVR
- DC Iris & C/CS mountable (C-Adaptor Ring)
- Supports Test Patterns (Color bar, Stress Pattern)
89
68
150
RS232
RS485
Debug
Upgrade Firmware / OSD Control
Strobe for external light
TTL level
ELECTRICITY
Power Consumption
DC 12V ± 10%, 4W
MECHANICAL
Dimension
Weight
ENVIRONMENTS
Operation Temp. / Humidity
CERTIFICATIONS
Certifications
68(W) x 150(D) x 63(H) mm
350g (Lens not included)
-10 ºC ~ 50 ºC / 0%RH ~ 80%RH
KC, FCC, CE, RoHS, HDcctv
90
HD-CCTV CAMERA
Premium to your security
Specifications
VIDEO
Camera Models
PoC
Non-PoC
C1080PBM
Sensor Type
1/3” 2.1Megapixel CMOS
Total Pixels
1920(H) x 1080(V) = 2.1M pixels
Scanning System
Min illumination
Lens
Video Output
Video Control
C1080PBM
High-Definition Box Camera (PoC & DC12V Support)
Key Features
Dimension (unit:mm)
Progressive Scan
B/W
[email protected], F1.2, 3100K, DSS(OFF), AGC(10)
Color
[email protected], F1.2, 3100K, DSS(OFF), AGC(10)
Mount
CS/ C(Ring Adaptor)
Filter
True Day & Night (ICR)
type
DC Auto Iris, Manual
Output
1(BNC 1.0 Vp-p, 75Ω)
Resolution
1080p 30/25fps, 720p 30/25fps
HD-SDI
SMPTE 292M compatible
Distance
Max. 200m(650ft) video transmission through 5C-HFBT cable
Control Method
OSD Menu, DVR (Supporting remote control via CoC), CMS (Control Center)
AGC
1 ~ 10 steps
Mirror
Horizontal / Vertical
WDR
OFF, 0 ~ 4 step
BLC
ACE
DNR
OFF, LOW, MIDDLE, HIGH
OFF, ON
OFF, LOW, MIDDLE, HIGH
OFF, Auto, x2 ~ x10 steps
White Balance
AUTO, PRESET, MANUAL
- Camera power supply through Coax (PoC) or DC12V input
Electric shutter
INDOOR, OUTDOOR, INDOOR-ANTI BLUR, OUTDOOR-ANTI BLUR, MANUAL(12 steps)
- OSD control, Firmware upgrade through Coax (CoC) & supports additional RS485 port
D-ZOOM
0 ~ 16 steps
- 1/3“, 2.1M CMOS progressive image sensor
ANTI-FLICKER
OFF, ON
- HD-SDI 1080p30/25 & 720p30/25 video output
Lens Shading
OFF, ON
- Horizontal/Vertical resolution over 1200TV lines
HLC
0 ~ 10 steps
DE-FOG
OFF, ON (Auto / Manual)
Privacy
OFF, ON (15 Zones )
- Superior Sensitivity (BW: 0.0005Lux/Color: [email protected], F1.2, 3100K, DSS Off )
56
DSS
- Certified by HDcctv Alliance
68
80.2
- 3DNR (Noise Reduction)
- Backlight compensation of WDR/ BLC/ HLC
CONTROL INTERFACE
- Privacy zone masking (Color selectable)
Control
- True Day&Night with IR cut filter removable
ELECTRICITY
- Anti-Motion Blur function for fast moving object
Power Consumption
- De-Fog function
MECHANICAL
- Test Pattern output (Color bar, Stress Pattern)
Dimension
Weight
- Provides wired remote controller for OSD control and CVBS output
- DC Iris & C/CS mount Lens applicable (C-Adaptor Ring)
91
ENVIRONMENTS
Operation Temp. / Humidity
CERTIFICATIONS
Certifications
CoC (Control over Coax) / RS485
PoC(DC24V ± 10%), 3W / DC 12V ± 10%, 2W
68(W) x 80.2(D) x 56(H) mm
320g (Lens not included)
-10 ºC ~ 50 ºC / 0%RH ~ 80%RH
KC, FCC, CE, RoHS, HDcctv
92
HD-CCTV CAMERA
Premium to your security
Specifications
VIDEO
Camera Models
PoC
C1080PD / C1080PVD
Sensor Type
1/3”, 2.1Megapixel CMOS
Total Pixels
1920(H) x 1080(V) = 2.1M pixels
Scanning System
Min illumination
Non-PoC
C1080D / C1080VD
Progressive Scan
B/W
[email protected], F1.4, 3100K, DSS(OFF), AGC(10)
Color
[email protected], F1.4, 3100K, DSS(OFF), AGC(10)
Mount
D-Mount
Filter
True Day & Night (ICR)
type
DC Iris, 2.8~11mm, F1.4, IR Corrective Megapixel Lens
Output
1 (BNC 1.0 Vp-p, 75Ω)
Resolution
1080p 30/25fps, 720p 30/25fps
HD-SDI
SMPTE 292M compatible
Distance
Max. 200m(650ft) video transmission through 5C-HFBT cable
Control Method
OSD Menu, DVR (Supporting remote control via CoC), CMS(Control Center)
AGC
1 ~ 10 steps
Mirror
Horizontal / Vertical
WDR
OFF, 0 ~ 4 step
BLC
ACE
DNR
OFF, LOW, MIDDLE, HIGH
OFF, ON
OFF, LOW, MIDDLE, HIGH
- OSD control, Firmware upgrade through coax (CoC)
DSS
OFF, Auto, x2 ~ x10 steps
- Provides wired remote controller for OSD control and CVBS output
White Balance
AUTO, PRESET, MANUAL
Electric shutter
INDOOR, OUTDOOR, INDOOR-ANTI BLUR, OUTDOOR-ANTI BLUR, MANUAL(12 steps)
- Certified by HDcctv Alliance
D-ZOOM
0 ~ 16 steps
- 1/3“, 2.1M CMOS progressive image sensor
ANTI-FLICKER
OFF, ON
- HD-SDI 1080p30/25&720p30/25 video output
Lens Shading
OFF, ON
- DC Iris, 2.8mm~11mm, F1.4, IR Corrective Megapixel Lens
HLC
0 ~ 10 steps
- Horizontal/Vertical resolution over 1200TV lines
DE-FOG
OFF, ON (Auto / Manual)
Privacy
OFF, ON (15 Zones )
Lens
C1080PVD / C1080VD
C1080PD / C1080D
C1080PVD / C1080VD
Key Features
Video Output
C1080PD / C1080D
Video Control
High-Definition Dome Camera
Dimension (unit:mm)
[PoC Cameras : C1080PD, C1080PVD]
C1080D
[Common Features]
- Superior Sensitivity (BW: 0.0005 Lux/Color: [email protected], F1.4, 3100K, DSS off )
130
C1080PD
104
- Camera power supply through coax (PoC)
C1080PVD
C1080VD
CONTROL INTERFACE
- 3DNR (Noise Reduction)
- Anti-Motion Blur function for fast moving object
- De-Fog function
- Test Pattern output (Color bar, Stress Pattern)
- Dustproof, Waterproof of IP66 (C1080PVD/C1080VD)
136
- True Day&Night with IR cut filter removable
60
- Privacy zone masking (Color selectable)
Control
111
- Backlight compensation of WDR/BLC/HLC
Power Consumption
RS485
PoC(DC24V ± 10%), 3W
DC 12V ± 10%, 3W / AC 24V ± 10%, 4W
MECHANICAL
Dimension
Weight
C1080PD/D
C1080PVD/VD
130(ø) x 104(H)mm
136(ø) x 111(H)mm
C1080PD/D
360g
C1080PVD/VD
760g
ENVIRONMENTS
Operation Temp. / Humidity
CERTIFICATIONS
Certifications
93
CoC (Control over Coax)
ELECTRICITY
-10 ºC ~ 50 ºC / 0%RH ~ 80%RH
KC, FCC, CE, RoHS, HDcctv
94
HD-CCTV CAMERA
Premium to your security
Specifications
VIDEO
Camera Models
C1080PD-IR / C1080D-IR
PoC
C1080PD-IR, C1080PVD-IR
Sensor Type
1/3” 2.1Megapixel CMOS
Total Pixels
1920(H) x 1080(V) = 2.1M pixels
Scanning System
Min illumination
Non-PoC
C1080D-IR, C1080VD-IR
Progressive Scan
B/W
[email protected], F1.4, 3100K, DSS(OFF), AGC(10)
Color
[email protected], F1.4, 3100K, DSS(OFF), AGC(10)
Mount
D-Mount
Filter
True Day & Night (ICR)
type
DC Iris, 2.8~11mm, F1.4, IR Corrective Megapixel Lens
Output
1 (BNC 1.0 Vp-p, 75Ω)
Resolution
1080p 30/25fps, 720p 30/25fps
HD-SDI
SMPTE 292M compatible
Distance
Max. 200m(650ft) video transmission through 5C-HFBT cable
Control Method
OSD Menu, DVR (Supporting remote control via CoC), CMS(Control Center)
AGC
1 ~ 10 steps
Mirror
Horizontal / Vertical
WDR
OFF, 0 ~ 4 step
BLC
ACE
DNR
OFF, LOW, MIDDLE, HIGH
OFF, ON
OFF, LOW, MIDDLE, HIGH
DSS
OFF, Auto, x2 ~ x10 steps
White Balance
AUTO, PRESET, MANUAL
- OSD control, Firmware upgrade through coax (CoC)
Electric shutter
INDOOR, OUTDOOR, INDOOR-ANTI BLUR, OUTDOOR-ANTI BLUR, MANUAL(12 steps)
- Provides wired remote controller for OSD control and CVBS output
D-ZOOM
0 ~ 16 steps
ANTI-FLICKER
OFF, ON
- Certified by HDcctv Alliance
Lens Shading
OFF, ON
- 1/3” 2.1M CMOS progressive image sensor
HLC
0 ~ 10 steps
DE-FOG
OFF, ON (Auto / Manual)
Privacy
OFF, ON (15 Zones )
Lens
Video Output
C1080PVD-IR / C1080VD-IR
C1080PD-IR / C1080D-IR
C1080PVD-IR / C1080VD-IR
Key Features
Video Control
IR-LED High-Definition Dome Camera
Dimension (unit:mm)
[PoC Camera : C1080PD-IR, C1080PVD-IR]
C1080D-IR
130
C1080PD-IR
104
- Camera power supply through coax (PoC)
[Common Features]
- HD-SDI 1080p25/30 & 720p25/30 Video Output
- DC Iris, 2.8mm~11mm, F1.4, IR Corrective Megapixel Lens
LIGHT
- Horizontal/Vertical resolution over 1200TV line
- Superior Sensitivity (BW : 0.0005 Lux/ Color : [email protected], F.1.4, 3100K, DSS off )
C1080PVD-IR
IR Light Source
C1080VD-IR
- 3DNR (Noise Reduction)
- True Day&Night with IR cut filter removable
- Anti-Motion Blur function for fast moving object
- De-Fog function
- Smart IR function (No Saturation)
- Test Pattern output (Color bar, Stress Pattern)
- Dust-proof/Water-proof of IP66 (C1080PVD-IR/C1080VD-IR)
- 3-axis gimbal structure for easy installation
- Built-in IR LED : 24pcs, Visible length : up to 30m
95
60
136
- Privacy zone masking (Color selectable)
Control
111
- Backlight compensation of WDR/BLC/HLC
24pcs, 850nm, 60º, control by visible light sensor, max. 30m
CONTROL INTERFACE
CoC (Control over Coax)
RS485
PoC(DC24V ± 10%), 4W
DC 12V ± 10%, 4W / AC 24V ± 10%, 5W
ELECTRICITY
Power Consumption
MECHANICAL
Dimension
Weight
C1080PD/D
C1080PVD/VD
130(ø) x 104(H)mm
136(ø) x 111(H)mm
C1080PD/D
370g
C1080PVD/VD
770g
ENVIRONMENTS
Operation Temp. / Humidity
CERTIFICATIONS
Certifications
-10 ºC ~ 50 ºC / 0%RH ~ 80%RH
KC, FCC, CE, RoHS, HDcctv
96
HD-CCTV CAMERA
Premium to your security
Specifications
VIDEO
Camera Models
PoC
C1080PD-AF, C1080PVD-AF
Sensor Type
1/3” 2.1Megapixel CMOS
Total Pixels
1920(H) x 1080(V) = 2.1M pixels
Scanning System
Min illumination
Non-PoC
C1080D-AF, C1080VD-AF
Progressive Scan
B/W
[email protected], F1.4, 3100K, DSS(OFF), AGC(10)
Color
[email protected], F1.4, 3100K, DSS(OFF), AGC(10)
Mount
D-Mount
Filter
True Day & Night (ICR)
type
DC Iris, 2.8~11mm, F1.4, IR Corrective Megapixel Lens
Output
1 (BNC 1.0 Vp-p, 75Ω)
Resolution
1080p 30/25fps, 720p 30/25fps
HD-SDI
SMPTE 292M compatible
Distance
Max. 200m(650ft) video transmission through 5C-HFBT cable
Control Method
OSD Menu, DVR (Supporting remote control via CoC), CMS(Control Center)
AGC
1 ~ 10 steps
Mirror
Horizontal / Vertical
WDR
OFF, 0 ~ 4 step
BLC
ACE
DNR
OFF, LOW, MIDDLE, HIGH
OFF, ON
OFF, LOW, MIDDLE, HIGH
- Zoom/Focus, OSD control, Firmware upgrade through coax (CoC)
DSS
OFF, Auto, x2 ~ x10 steps
- Provides wired remote controller for OSD control and CVBS output
White Balance
AUTO, PRESET, MANUAL
Electric shutter
INDOOR, OUTDOOR, INDOOR-ANTI BLUR, OUTDOOR-ANTI BLUR, MANUAL(12 steps)
- Certified by HDcctv Alliance
D-ZOOM
0 ~ 16 steps
- 1/3” 2.1M CMOS progressive image sensor
ANTI-FLICKER
OFF, ON
- HD-SDI 1080p30/25 & 720p30/25 Video Output
Lens Shading
OFF, ON
- DC Iris, 2.8mm~11mm, F1.4, IR Corrective Megapixel Lens
HLC
0 ~ 10 steps
- One-Push Auto Focus, Zoom/Focus Control
DE-FOG
OFF, ON (Auto / Manual)
Privacy
OFF, ON (15 Zones )
Lens
C1080PD-AF / C1080D-AF
C1080PD-AF / C1080D-AF
C1080PVD-AF / C1080VD-AF
Key Features
C1080PVD-AF / C1080VD-AF
Video Output
Video Control
Auto Focus High-Definition Dome Camera
Dimension (unit:mm)
[PoC Cameras : C1080PD-AF, C1080PVD-AF]
[Common Features]
- Horizontal/Vertical resolution over 1200TV lines
C1080D-AF
130
C1080PD-AF
104
- Camera power supply through coax (PoC)
C1080PVD-AF
C1080VD-AF
CONTROL INTERFACE
- Superior Sensitivity (BW : 0.0005 Lux/ Color : [email protected], F.1.2, 3100K, DSS off )
- True Day&Night with IR cut filter removable
- Anti-Motion Blur function for fast moving object
- De-Fog Function
- Test Pattern output (Color bar, Stress Pattern)
- Dust-proof, Water-proof of IP66 (C1080PVD-AF/C1080VD-AF)
97
136
- Privacy zone masking (Color selectable)
60
- Backlight compensation of WDR/BLC/HLC
Control
111
- 3DNR (Noise Reduction)
CoC (Control over Coax)
RS485
PoC(DC24V ± 10%), 3W
DC 12V ± 10%, 3W / AC 24V ± 10%, 4W
ELECTRICITY
Power Consumption
MECHANICAL
Dimension
Weight
C1080PD/D
C1080PVD/VD
130(ø) x 104(H)mm
136(ø) x 111(H)mm
C1080PD/D
370g
C1080PVD/VD
770g
ENVIRONMENTS
Operation Temp. / Humidity
CERTIFICATIONS
Certifications
-10 ºC ~ 50 ºC / 0%RH ~ 80%RH
KC, FCC, CE, RoHS, HDcctv
98
HD-CCTV CAMERA
Premium to your security
Specifications
VIDEO
Camera Models
C1080PD-IR-AF
C1080D-IR-AF
PoC
C1080PD-IR-AF, C1080PVD-IR-AF
Sensor Type
1/3” 2.1Megapixel CMOS
Total Pixels
1920(H) x 1080(V) = 2.1M pixels
Scanning System
Min illumination
Lens
Video Output
C1080PVD-IR-AF
C1080VD-IR-AF
C1080PD-IR-AF / C1080D-IR-AF
C1080PVD-IR-AF / C1080VD-IR-AF IR-LED, Auto Focus High-Definition Dome Camera
99
130
C1080D-IR-AF
104
C1080PD-IR-AF
Progressive Scan
B/W
[email protected], F1.4, 3100K, DSS(OFF), AGC(10)
Color
[email protected], F1.4, 3100K, DSS(OFF), AGC(10)
Mount
D-Mount
Filter
True Day & Night (ICR)
type
DC Iris, 2.8~11mm, F1.4, IR Corrective Megapixel Lens
Output
1 (BNC 1.0 Vp-p, 75Ω)
Resolution
1080p 30/25fps, 720p 30/25fps
HD-SDI
SMPTE 292M compatible
Distance
Max. 200m(650ft) video transmission through 5C-HFBT cable
Control Method
OSD Menu, DVR (Supporting remote control via CoC), CMS(Control Center)
AGC
1 ~ 10 steps
Mirror
Horizontal / Vertical
WDR
OFF, 0 ~ 4 step
BLC
ACE
DNR
OFF, LOW, MIDDLE, HIGH
OFF, ON
OFF, LOW, MIDDLE, HIGH
DSS
OFF, Auto, x2 ~ x10 steps
White Balance
AUTO, PRESET, MANUAL
Electric shutter
INDOOR, OUTDOOR, INDOOR-ANTI BLUR, OUTDOOR-ANTI BLUR, MANUAL(12 steps)
D-ZOOM
0 ~ 16 steps
ANTI-FLICKER
OFF, ON
Lens Shading
OFF, ON
HLC
0 ~ 10 steps
DE-FOG
OFF, ON (Auto / Manual)
Privacy
OFF, ON (15 Zones )
LIGHT
IR Light Source
C1080VD-IR-AF
24pcs, 850nm, 60º, control by visible light sensor, max. 30m
CONTROL INTERFACE
Control
136
C1080PVD-IR-AF
60
[PoC Camera : C1080PD-IR-AF, C1080PVD-IR-AF]
- Camera power supply through coax (PoC)
- Zoom/Focus, OSD control, Firmware upgrade through coax (CoC)
- Provides wired remote controller for OSD control and CVBS output
[Common Features]
- Certified by HDcctv Alliance
- 1/3” 2.1M CMOS progressive image sensor
- HD-SDI 1080p30/25 & 720p30/25 Video Output
- DC Iris, 2.8mm~11mm, F1.4, IR Corrective Megapixel Lens
- One-Push Auto Focus, Zoom/Focus Control
- Horizontal/Vertical resolution over 1200TV lines
- Superior Sensitivity (BW : 0.0005 Lux/ Color : [email protected], F.1.4, 3100K, DSS off )
- 3DNR (Noise Reduction)
- Backlight compensation of WDR/BLC/HLC
- Privacy zone masking (Color selectable)
- True Day&Night with IR cut filter removable
- Anti-Motion Blur for fast moving object
- De-Fog function
- Smart IR function (No Saturation)
- Test Pattern output (Color bar, Stress Pattern)
- Dust-proof, Water-proof of IP66 (C1080PVD-AF/C1080VD-AF)
- Built-in IR LED : 24pcs, Visible length : up to 30m
Dimension (unit:mm)
111
Key Features
Video Control
Non-PoC
C1080D-IR-AF, C1080VD-IR-AF
CoC (Control over Coax)
RS485
PoC(DC24V ± 10%), 4W
DC 12V ± 10%, 4W / AC 24V ± 10%, 6W
ELECTRICITY
Power Consumption
MECHANICAL
Dimension
Weight
C1080PD/D
C1080PVD/VD
130(ø) x 104(H)mm
136(ø) x 111(H)mm
C1080PD/D
380g
C1080PVD/VD
780g
ENVIRONMENTS
Operation Temp. / Humidity
CERTIFICATIONS
Certifications
-10 ºC ~ 50 ºC / 0%RH ~ 80%RH
KC, FCC, CE, RoHS, HDcctv
100
HD-CCTV CAMERA
Premium to your security
Specifications
VIDEO
Camera Models
C1080PBL-IR48-AFF
C1080BL-IR48-AF
PoC
C1080PBL-IR18, C1080PBL-IR18-AF, C1080PBL-IR48-AF
Sensor Type
1/3” 2.1Megapixel CMOS
Total Pixels
1920(H) x 1080(V) = 2.1M pixels
Scanning System
Min illumination
Lens
Video Output
Video Control
C1080PBL-IR18 / C1080BL-IR18
C1080PBL-IR18/C1080BL-IR18
C1080PBL-IR18-AF/ C1080BL-IR18-AF
C1080PBL-IR18-AF / C1080BL-IR18-AF
C1080PBL-IR48-AF / C1080BL-IR48-AF IR-LED, Auto Focus High-Definition Bullet Camera
101
C1080PBL-IR18 / C1080PBL-IR18-AF
C1080BL-IR18 / C1080BL-IR18-AF
88
70
79
118
[PoC Camera : C1080PBL-IR18(-AF), C1080PBL-IR48-AF]
- Camera power supply through Coax (PoC)
- Zoom/Focus, OSD control, Firmware upgrade through Coax (CoC)
- Provides wired remote controller for OSD control and CVBS output
[Common Featrues]
- Certified by HDcctv Alliance
- 1/3“, 2.1M CMOS progressive image sensor
- HD-SDI 1080p30/25 & 720p30/25 Video Output
- DC Iris, 2.8mm~11mm, F1.4, IR Corrective Megapixel Lens
- One-Push Auto Focus, Zoom/Focus Control (-AF Series)
- Horizontal/Vertical resolution over 1200TV lines
- Superior Sensitivity (BW: 0.0005 Lux/ Color: [email protected], F1.4, 3100K, DSS off )
- 3DNR (Noise Reduction)
- Backlight compensation of WDR/BLC/HLC
- Privacy zone masking (Color selectable)
- True Day&Night with IR cut filter removable
- Anti-Motion Blur function for fast moving object
- De-Fog function
- Smart IR function (No Saturation)
- Test Pattern output (Color bar, Stress Pattern)
- All-in-one Bracket & Housing structure supporting IP66
- Built-in IR LED
C1080PBL-IR18-AF/C1080BL-IR18-AF(18pcs), Visibility : up to 25m
C1080PBL-IR-48-AF/C1080BL-IR-48-AF(48pcs), Visibility : up to 48m
Dimension (unit:mm)
Progressive Scan
B/W
[email protected], F1.4, 3100K, DSS(OFF), AGC(10)
Color
[email protected], F1.4, 3100K, DSS(OFF), AGC(10)
Filter
True Day & Night (ICR)
Type
DC Iris, 2.8~11mm, F1.4, IR Corrective Megapixel Lens
Output
1 (BNC 1.0 Vp-p, 75Ω)
Resolution
1080p 30/25fps, 720p 30/25fps
HD-SDI
SMPTE 292M compatible
Distance
Max. 200m(650ft) video transmission through 5C-HFBT cable
Control Method
OSD Menu, DVR (Supporting remote control via CoC), CMS(Control Center)
AGC
1 ~ 10 steps
Mirror
Horizontal / Vertical
WDR
OFF, 0 ~ 4 steps
BLC
OFF, LOW, MIDDLE, HIGH
ACE
DNR
DSS
OFF, ON
OFF, LOW, MIDDLE, HIGH
OFF, Auto, x2 ~ x10 steps
White Balance
AUTO, PRESET, MANUAL
Electric shutter
INDOOR, OUTDOOR, INDOOR-ANTI BLUR, OUTDOOR-ANTI BLUR, MANUAL(12 steps)
D-ZOOM
0 ~ 16 steps
ANTI-FLICKER
OFF, ON
Lens Shading
OFF, ON
HLC
0 ~ 10 steps
DE-FOG
OFF, ON (Auto / Manual)
Privacy
OFF, ON (15 Zones )
CONTROL INTERFACE
Control
CoC (Control over Coax)
RS485
LIGHT
IR Light Source
120
198
C1080PBL/BL-IR18 Ser.
C1080PBL/BL-IR48 Ser.
18pcs, 850nm, 60°, control by visible light sensor, max. 25m
48pcs, 850nm, 60°, control by visible light sensor, max. 48m
C1080PBL/BL-IR18 Ser.
C1080PBL/BL-IR48 Ser.
PoC (DC24V ± 10%), 4W
PoC (DC24V ± 10%), 6W
C1080PBL/BL-IR18 Ser.
C1080PBL/BL-IR48 Ser.
88(W) x 118(H) x 198(D) mm
120(W) x 140(H) x 254(D) mm
C1080PBL/BL-IR18 Ser.
C1080PBL/BL-IR18 : 710g, C1080PBL/BL-IR18-AF : 720g
C1080PBL/BL-IR48 Ser.
1600g
ELECTRICITY
C1080PBL-IR48-AF
C1080BL-IR48-AF
Power Consumption
120
DC12V ± 10%, 4W / AC 24V ± 10%, 6W
DC12V ± 10%, 5W / AC 24V ± 10%, 8W
MECHANICAL
Dimension
87
95
140
Key Features
Non-PoC
C1080BL-IR18, C1080BL-IR18-AF, C1080BL-IR48-AF
133
254
Weight
ENVIRONMENTS
Operation Temp. / Humidity
CERTIFICATIONS
Certifications
-10 ºC ~ 50 ºC / 0%RH ~ 80%RH
KC, FCC, CE, RoHS, HDcctv
102
HD-CCTV CAMERA
Premium to your security
Key Features
- HD-SDI Speed Dome Camera
- 20x Optical Zoom (4.7~94mm) and 12x Digital Zoom
- 1/2.8, 2Megapixel CMOS progressive image sensor
- HD-SDI 1080p or 720p Video Output
- Automatic Pan/Tilt speed control according to zoom magnification
- Pan Speed : Max. 360°/sec
- Manual Speed : Min. 0.05°/sec
- Endless 360° Pan Rotation
- WDR function
- 3D Noise Reduction
- Privacy zone Masking (Up to 8 Area)
- True Day&Night with IR cut filter removable
- 255 Preset, 4 Patterns, 8 Scans and 8 Group functions
- Power-up Action
Specifications
VIDEO
Camera Models
Sensor type
C1080PT-Z20
1/2.8” 2Megapixel CMOS
Total Pixels
1920(H) x 1080(V) = 2.1M pixels
Scanning System
Min illumination
Lens
Video Output
C1080PT-Z20
C10
080PT-Z
Z20
Dimension (unit:mm)
Full-HD PTZ Dome Camera
Video Control
- Outdoor PTZ Dome Camera
Wall Mount Bracket
- Weather-Proof (IP66)
132
182.5
383
71
- Supports Wall-Mount, Ceiling-Mount
142
78.7
187
102
Pan/Tilt
ø146
ø259
C1080PT-Z20F
Progressive Scan
B/W
[email protected], F1.6, DSS(OFF), High Sensitivity Mode [email protected] 50IRE
Color
[email protected], F1.6, DSS(OFF), High Sensitivity Mode [email protected] 50IRE
Zoom
20x Optical zoom & 12x Digital zoom
Angle of View
H:55.4˚(W) ~ 2.9˚(T)
Facal Length
F1.6 ~ 3.5, f=4.7 ~ 94mm
CVBS Output
1 (BNC 1.0 Vp-p, 75Ω)
HD-SDI Resolution
1080p 30/25fps, 720p 60/50fps, 1080i 60/50fps
HD-SDI Standard
SMPTE 292M compatible
Transmission Distance
Approx. 200m(650 ft.) via RG6, 150m(490 ft.) via RG59
Day&Night
Auto/Day/Night(ICR)
Focus
Auto/Manual
Exposure Mode
Full Auto/ Shutter/ Iris/ Bright/ Manual
White Balance
Auto WB/ Indoor/ Outdoor/ One Push WB/ Manual WB
AGC
WDR
Range
Auto, Manual (-3~28dB, 16Steps)
Auto/Off
Pan:360˚(Endless), Tilt:180˚
Pan/Tilt Speed
Preset 400˚/sec, Manual:0.05˚~200˚/sec (Zoom proportional), Scan:1˚~180˚/sec
Preset
255 presets with labels/ Independent camera setup
Pattern
4 Patterns(Approx. 5 Minutes for each pattern)
Scan
8 Scans
Group
8 Groups (max. 20 functions for each group)
Other functions
Power-up Action & etc.
CONTROL INTERFACE
Ceiling Mount Bracket
Communication
RS-485 Protocol
Flush Mount
RS-485
Auto(Pelco-D, Pelco-P, Samsung-E can be supported automatically)
ELECTRICITY
Power Consumption
102
286
101.8
90.9
187
142
182.5
Full-HD PTZ Dome Camera
51.5
117.7
C1080PT-Z20F
- Supports Flush-Mount
78.7
- Indoor PTZ Dome Camera
ø149
AC 24V, Max. 55W (Heater 30W)
DC12V / AC24V, Max. 20W
Dome(ø) : 146mm, Housing(øxH) : 259x266mm
Net : 6Kg, Package : 10.9Kg
Dome(ø) : 146mm, Net (øxH): 211.8x244.2mm
Net: 1.75Kg, Package: 2.4Kg
-40 ºC ~ 50 ºC / 10%RH ~ 80%RH
-10 ºC ~ 50 ºC / 10%RH ~ 80%RH
MECHANICAL
Dimension
Weight
ENVIRONMENTS
Operation Temp.
CERTIFICATIONS
Certifications
FCC, CE, IP66
ø72.7
ø211.8
ø259
404.5
103
104
HD-CCTV Converters & etc
HD-CCTV
Converter&etc
Premium
Pre
emiu
m m to
to your
your
ourr security
secur
se
currity
cu
ittyy
HD-CCTV
Converters & etc.
PoC/CoC Repeater
DoubleReach Converter
2CH Distributor
HD-SDI Repeater
HDMI Converter
CVBS Converter
Optic Converter
105
106
HD-CCTV Converter Features
Premium to your security
Converters for One Cable Solution
PoC Camera
DR101P-TX
HD-SDI
PoC/CoC
P C/C
TM
PoC/CoC and DoubleReach converters help to configure diverse One Cable Solutions
Max. 200m
When using a PoC DVR, up to 2 RP101P (PoC/CoC repeater) can be placed to extend the HD-SDI transmission distance.
DoubleReach
PoC / CoC
Even if using a Non-PoC DVR, you can use a PS101P to configure One Cable Solution. PS101P can be used to provide power to PoC/CoC
devices. Also, if you use a DR101P-RX (DoubleReach receiver), you can use DoubleReach transmission technology through Non-PoC DVR.
Max. 800m
Non-PoC DVR
Max. 400m
HD-SDI
Max. 200m
When long distance video transmission is needed, you can use OPT-TX4-RS485P (4ch Fiber-Optic transmitter) which can supply power
to PoC cameras. You can configure One Cable Solution between Fiber-Optic transmitter and cameras.
DR101P-RX
RP101P
PoC Camera
HD-SDI
P
PoC/CoC
C/C
OPT-TX4-RS485P
Max. 200m
HD-SDI
P
PoC/CoC
C/C
Max. 600m
PoC DVR
Max. 200m
HD-SDI
P
PoC/CoC
C/C
RP101P
HD-SDI
PoC/CoC
P C/C
HD-SDI
PoC/CoC
P C/C
Max. 200m
Fiber-Optic
4
PoC / CoC
OPTIC & RS485
Max. 20 Km
HD-SDI
PoC/CoC
P C/C
RP101P
PoC Camera
4
HD-SDI
P
PoC/CoC
C/C
HD-SDI
PoC/CoC
P C/C
Max. 200m
HD-SDI
P
PoC/CoC
C/C
Max. 200m
HD-SDI
Max. 200m
Max. 600m
OPT-TX16-RS485UC
Non-PoC DVR
HD-SDI
Max. 200m
PS101P
107
108
HD-CCTV Converter Features
Premium to your security
Diverse HD-SDI Converters : RP101P, SDI2HDMI, HDMI2SDI, SD2HD, HD2SD
Fiber Optic Converters : OPT-TX/RX Series
Building a HD-CCTV system requires various devices.
For this, WEBGATE is prepared diverse devices such as repeaters for extending transmission distance, converters between HDSDI and HDMI and converters between HD and SD.
Each device insures the best video quality of HD-SDI signal to configure the most optimized system.
Fiber-optic cable can be used for long distance HD-SDI transmission (up to 20Km).
If HD-SDI video signal is transmitted using fiber-optic cable, it provides noiseless clear video and can support RS485 for camera
control at the same time.
1ch, 4ch Fiber-optic transmitters and 1ch, 16ch Fiber-optic receivers are applied to a number of large- scale installation sites
and utilized.
HD-SDI
HD
SDI
HD-SDI Camara
OPT-TX1-RS485U(C)
RP102
HD-SDI
HD-SDI
HD
SDI
[HD-SDI Monitor]
OPTIC & RS485
1 Km
Max. 20 Km
HD-SDI
HD
SDI
HD-SDI
OPT-RX1-RS485U(C)
HD-SDI Camera
SDI2HDMI
HDMI
HD-SDI
Divx Player
(HD Source)
OPT-TX4-RS485U(C)
[HDMI Monitor]
HDMI2SDI
HD-SDI
HD-SDI
HDMI
4
HD-SDI
SD Camera
SD2HD
ANALOG
OPTIC & RS485
HD-SDI
Max. 20 Km
HD-SDI
4
HD-SDI Camera
HD2SD
HD-SDI
HD-SDI
HD-SDI
ANALOG
OPT-RX16-RS485U(C)
[Analog CCTV Monitor]
109
110
HD-CCTV Converter Features
Premium to your security
Product Family : HD Converters
PoC & DoubleReachTM Converters
Model
Appearance
Non-PoC Converters
Description
Model
RP101P
PoC Repeater
RP102
HD-SDI Repeater
PS101P
PoC Power Supply
SDI2HDMI
SDI to HDMI
Converter
DR101P-TX
DoubleReachTM
1ch Transmitter
HDMI2SDI
HDMI to SDI
Converter
DR101P-RX
DoubleReachTM
1ch Receiver
SD2HD
SD to HD
Converter
OPT-TX4-RS485P
PoC Fiber-Optic
4ch Transmitter
HD2SD
HD to SD
Converter
OPT-TX1-RS485U(C)
Fiber-Optic
1ch Transmitter
OPT-TX4-RS485U(C)
Fiber-Optic
4ch Transmitter
OPT-RX1-RS485U(C)
Fiber-Optic
1ch Receiver
OPT-RX16-RS485U(C)
Fiber-Optic
16ch Receiver
* DoubleReach Transmitter & Receiver supports PoC/CoC together
Appearance
Description
* Fiber-Optic converter’s suffix C models have HDcctv certification.
111
112
HD-CCTV Converters & etc
RP101P
Premium to your security
Specifications
HD-SDI Repeater for PoC/CoC/DoubleReach
VIDEO INPUT
Key Features
Video input standard
Resolution
TM
VIDEO OUTPUT
Video output standard
Resolution
65
- HD-SDI Repeater supporting PoC/CoC/DoubeReachTM
PoC(Power over Coax), CoC(Control over Coax)
- Power supply to PoC/DoubleReach devices via coaxial cable(PoC)
- Camera control data transmission via coaxial cable(CoC)
- Further transmission distance extension using multiple repeaters
(Max. 2 devices between PoC Camera and PoC DVR)
- LED indicators for Power, Video input, PoC output, RS485 output
- Additional terminal blocks for power input and RS485 ouput
Dimension (unit:mm)
95
134
26
Equalizing, Reclocking, Cable driving
Power over Coax, Max.16W (DC24V)
CoC
Camera control data transmission, Max. 57600bps
VIDEO INPUT
Video input standard
Resolution
Dimension (unit:mm)
Power(Red), Video In(Green),
PoC Out(Red), RS485 Out(Green)
RS485 out
Terminal block
Power input
Terminal block (Additional Power Input DC24V)
ENVIRONMENTAL & PHYSICAL
Dimension
Weight
134(W) x 65(D) x 26(H) mm
Approx. 140g(0.3 lbs)
Operating temperature
0°C to +50°C / 20%RH to 80%RH
Power consumption
Max 2W
Approval
KC, FCC, CE, RoHS, HDcctv
INTERFACE
1CH(HD-SDI SMPTE 292M, DoubleReachTM)
SMPTE 274M(1080p30/25)
VIDEO OUTPUT
Video output standard
Resolution
- Power supply for PoC/CoC/DoubleReachTM devices
PoC(Power over Coax), CoC(Control over Coax)
- Power supply to PoC/DoubleReach devices via coaxial cable(PoC)
- Camera control data transmission via coaxial cable(CoC)
- LED indicators for Power, Video input, PoC output,
RS485 input status
- Terminal blocks for power and RS485 input
1CH(HD-SDI SMPTE 292M, DoubleReachTM)
SMPTE 274M(1080p30/25)
65
PERFORMANCE
Function
PoC
Equalizing, Reclocking, Cable driving
Power over Coax, Max.16W (DC24V)
CoC
Camera control data transmission, Max. 57600bps
95
134
26
DR101P-TX
Indication LED
Power(Red), Video In(Green),
PoC Out(Red), RS485 In(Green)
RS485 input
Terminal block
Power input
Terminal block (Additional Power Input DC24V)
ENVIRONMENTAL & PHYSICAL
Dimension
Weight
134(W) x 65(D) x 26(H) mm
Approx. 140g(0.3 lbs)
Operating temperature
0°C to +50°C / 20%RH to 80%RH
Power consumption
Max 2W
Approval
KC, FCC, CE, RoHS, HDcctv
Specifications
VIDEO INPUT
DoubleReachTM Transmitter supporting PoC / CoC function
Video input standard
Resolution
Dimension (unit:mm)
INTERFACE
1CH(HD-SDI SMPTE 292M)
SMPTE 274M(1080p30/25)
VIDEO OUTPUT
- DoubeReachTM Transmitter supporting PoC/CoC function
PoC(Power over Coax), CoC(Control over Coax)
- Camera power supply via coaxial cable (PoC)
- Camera remote control via coaxial cable (CoC)
- HD-SDI video transmission up to 400m based on 5C-HFBT cable
- LED indicators for Power, Video input, PoC output, RS485 output
- Additional terminal blocks for power input and RS485 ouput
Video output standard
Resolution
1CH(DoubleReachTM)
SMPTE 274M(1080p30/25)
PERFORMANCE
65
26
113
Function
PoC
Indication LED
Specifications
Power supply for PoC / CoC / DoubleReachTM
Key Features
1CH(HD-SDI SMPTE 292M, DoubleReachTM)
SMPTE 274M(1080p30/25)
PERFORMANCE
PS101P
Key Features
INTERFACE
1CH(HD-SDI SMPTE 292M, DoubleReachTM)
SMPTE 274M(1080p30/25)
95
134
Function
PoC
DoubleReachTM Converting
Power over Coax, Max.16W (DC24V)
CoC
Camera control data transmission, Max. 57600bps
Indication LED
Power(Red), Video In(Green),
PoC Out(Red), RS485 Out(Green)
RS485 out
Terminal block
Power input
Terminal block (Additional Power Input DC24V)
ENVIRONMENTAL & PHYSICAL
Dimension
Weight
134(W) x 65(D) x 26(H) mm
Approx. 170g(0.3 lbs)
Operating temperature
0°C to +50°C / 20%RH to 80%RH
Power consumption
Max 3W
Approval
KC, FCC, CE, RoHS, HDcctv
114
HD-CCTV Converters & etc
Premium to your security
DR101P-RX
Specifications
VIDEO INPUT
TM
DoubleReach Receiver supporting PoC/CoC function
- DoubeReachTM Receiver supporting PoC/CoC function
PoC(Power over Coax), CoC(Control over Coax)
- Power supply via coaxial cable (PoC)
- Camera remote control via coaxial cable (CoC)
- HD-SDI video transmission up to 400m based
on 5C-HFBT cable
- LED indicators for Power, Video input, PoC output, RS485 input
- Terminal blocks for power input and RS485 input
Dimension (unit:mm)
INTERFACE
1CH(DoubleReachTM)
SMPTE 274M(1080p30/25)
VIDEO OUTPUT
Video output standard
Resolution
1CH(HD-SDI SMPTE 292M)
SMPTE 274M(1080p30/25)
PERFORMANCE
65
Key Features
Video input standard
Resolution
95
134
26
OPT-TX4-RS485P
Function
PoC
DoubleReachTM Converting
Power over Coax, Max.16W (DC24V)
CoC
Camera control data transmission, Max. 57600bps
Indication LED
Power(Red), Video In(Green),
PoC Out(Red), RS485 In(Green)
RS485 input
Terminal block
Power input
Terminal block (Additional Power Input DC24V)
ENVIRONMENTAL & PHYSICAL
Dimension
Weight
134(W) x 65(D) x 26(H) mm
Approx. 170g(0.3 lbs)
Operating temperature
0°C to +50°C / 20%RH to 80%RH
Power consumption
Max 3W
Approval
KC, FCC, CE, RoHS, HDcctv
Specifications
Fiber-Optic Transmitter Supporting PoC/CoC
VIDEO INPUT
Key Features
Video input standard
Resolution
Dimension (unit:mm)
- 4ch HD-SDI to Optic converter Supporting PoC/CoC
PoC(Power over Coax), CoC(Control over Coax)
- Camera power supply via coaxial cable (PoC)
- Camera remote control via coaxial cable (CoC)
- BNC 4ch input, LC type 4ch Fiber-optic output
- Up to 20Km video/data(RS485) transmission
via single-mode cable
- LED indicators for Power, HD-SDI Input, PoC Output,
RS485 data and Optic status
INTERFACE
1CH(HD-SDI SMPTE 292M, DoubleReachTM)
SMPTE 274M(1080p30/25)
Indication LED
1310/1550 nm (Tx / Rx)
Single mode / Max. 20Km
RS485 out
Terminal block
Power input
4pin DC-JACK (DC24V)
RS485(Green), Optic(Green)
VIDEO OUTPUT
PERFORMANCE
ENVIRONMENTAL & PHYSICAL
Function
PoC
Equalizing, Reclocking, Cable driving
Power over Coax, Max.16W (DC24V) /ch
Dimension
Weight
239(W) x 140(D) x 44(H) mm
Approx. 1Kg (2.20 lbs)
CoC
Camera control data transmission, Max. 57600bps
Operating temperature
0°C to +50°C / 20%RH to 80%RH
44
140
Video output standard
Resolution
Power(Red),
HD-SDI(Green), PoC(Red),
Power consumption
Max 9W
Approval
KC, FCC, CE, RoHS, HDcctv
239
Specifications
RP102
- The World’s first HDcctv Certified repeater
- HD-SDI repeater & distributer
- BNC 1ch input / 2ch outputs
- Auto-detection of HD-SDI video format
- Transmission distance extendable using multiple repeaters
- HD-SDI transmission distance :
Approx. 200m(650ft.) via RG6 or 150m(490ft.) via RG59
- Power, Link LED indicator
115
Video input standard
Resolution
Dimension (unit:mm)
INTERFACE
1CH(HD-SDI SMPTE 292M)
SMPTE 274M(1080i60/50, 1080p30/25)
Indication LED
SMPTE 296M(720p25/30/50/60)
Dimension
Weight
92(W) x 65(D) x 26(H) mm
Approx. 120g(0.2 lbs)
2CH (HD-SDI SMPTE 292M)
SMPTE 274M(1080i60/50, 1080p30/25)
Operating temperature
0°C to +50°C / 20%RH to 80%RH
Input Voltage
DC12V
SMPTE 296M(720p25/30/50/60)
Power consumption
Max 3W
Approval
KC, FCC, CE, RoHS, HDcctv
VIDEO OUTPUT
Video output standard
Resolution
65
Key Features
VIDEO INPUT
26
60
92
PERFORMANCE
Function
Power LED(Red), Link LED(Green)
ENVIRONMENTAL & PHYSICAL
Include equalizing, Reclocking, Driver
116
HD-CCTV Converters & etc
Premium to your security
Specifications
SDI2HDMI
- The world’s first HDcctv certified converter
- HD-SDI to HDMI converter
- BNC input / HDMI output
- Supports HD-SDI 1080p & 720p video format
- Supports HDMI embedded audio
- OSD for video status display
- Compatible with 50/60Hz system
- Power, Link LED indicator
Video input standard
Resolution
Dimension (unit:mm)
Video output standard
Resolution
21
26
SMPTE 296M(720p25/30/50/60)
ENVIRONMENTAL & PHYSICAL
1CH(HDMI)
1080p60RB, 1080p60, 1080i60, 720p60
Audio output
92
115
2CH(Left, Right)
Power LED(Red), Link LED(Green)
4 Dip switches for operation mode setting
Dimension
Weight
115(W) x 65(D) x 26(H) mm
Approx. 140g(0.3 lbs)
Operating temperature
0°C to +50°C / 20%RH to 80%RH
Input Voltage
DC12V
Power consumption
Max 4W
Approval
KC, FCC, CE, RoHS, HDcctv
Specifications
VIDEO INPUT
Video input standard
Resolution
Dimension (unit:mm)
- HDMI to HD-SDI converter
- Selectable one HDMI among two HDMI input
- Auto detection on input image
- Mode selection switch for video output format
selection
- HD-SDI embedded audio & RCA audio output
- Power LED indicator
INTERFACE
2CH (HDMI, selectable)
SMPTE 274M(1080i60/50, 1080p30/25)
Indication LED
Input channel indication LED (Green, Red),
Power LED (Red)
SMPTE 296M(720p25/30/50/60)
Mode selection switch
4 Dip switches for operation mode setting
VIDEO OUTPUT
122
Video output standard
Resolution
ENVIRONMENTAL & PHYSICAL
2CH (HD-SDI SMPTE 292M)
SMPTE 274M(1080i60/50, 1080p30/25)
Dimension
Weight
126(W) x 122(D) x 33(H) mm
Approx. 310g(0.7 lbs)
SMPTE 296M(720p25/30/50/60)
Operating temperature
0°C to +50°C / 20%RH to 80%RH
AUDIO
Audio output
112
126
33
2CH (Left, Right), RCA connector
PERFORMANCE
Function
Input Voltage
DV12V
Power consumption
Max 4W
Approval
KC, FCC, CE, RoHS
Include equalizing, Reclocking, Driver
Specifications
SD2HD
ENVIRONMENTAL & PHYSICAL
VIDEO INPUT
Video input standard
Key Features
Indication LED
Mode selection switch
AUDIO
HDMI2SDI
Key Features
INTERFACE
1CH(HD-SDI SMPTE 292M)
SMPTE 274M(1080i60/50, 1080p30/25)
VIDEO OUTPUT
65
Key Features
VIDEO INPUT
Dimension (unit:mm)
Dimension
Weight
143(W) x 121(D) x 33(H) mm
Approx. 320g(0.7 lbs)
1CH (HD-SDI SMPTE 292M)
SMPTE274M(1080p30/25)
Operating temperature
0°C to +50°C / 20%RH to 80%RH
VIDEO OUTPUT
Video output standard
Resolution
- CVBS to HD-SDI converter
- Max 6ch CVBS signal input
- NTSC/PAL switch selectable
- 1/4/6 split-screen output selectable
- 16:9 or 4:3 video ratio selectable
- Power LED indicator
6CH (NTSC/PAL CVBS)
INTERFACE
121
Indication LED
Mode select switch
Include equalizing, Reclocking, Driver
SW1 : NTSC/PAL select
Input Voltage
DC12V
Power consumption
Max 5W
Approval
KC, FCC, CE, RoHS
SW2 : Split-Screen select
SW3 : Split-Screen select
33
117
143
SW4 : 16:9/4:3 Mode select
118
HD-CCTV Converters & etc
Premium to your security
Specifications
HD2SD
- The world’s first HDcctv certified converter
- HD-SDI to CVBS converter
(HD-SDI Loop-through output)
- BNC 1ch Input / 2ch outputs
- HD-SDI 1080p & 720p Video Format
- NTSC/PAL Auto-Output by detecting input video
- Standby mode for power saving
- 50/60Hz system compatible
- Power, Link LED indicator
Video input standard
Resolution
Dimension (unit:mm)
Video output standard
Indication LED
26
119
Operating temperature
0°C to +50°C / 20%RH to 80%RH
1CH CVBS(NTSC/PAL-auto change according to 25/30Hz)
1CH (HD-SDI SMPTE 292M)
Input Voltage
DC 12V
Power consumption
Max 2.2W
Approval
KC, FCC, CE, RoHS, HDcctv
Power LED : Red, Link LED : Green
HD-SDI PORT
Video standard
Resolution
Dimension ((unit:mm))
ENVIRONMENTAL & PHYSICAL
SMPTE292M
SMPTE 274M(1080p30/25)
Dimension
Weight
117W) x 65(D) x 26(H) mm
Approx. 150g(0.33 lbs)
SMPTE 296M(720p25/30/50/60)
Operating temperature
0°C to +50°C / 20%RH to 80%RH
OPTICAL PORT
26
Fiber Type
Connector
Single-mode
LC
Distance
20Km(12.4mi) at 1.5Gbps
DC 12V
Power consumption
Max. 2.0W
Approval
KC, FCC, CE, RoHS, HDcctv
Specifications
ENVIRONMENTAL & PHYSICAL
HD-SDI PORT
Video standard
Resolution
Dimension (unit:mm)
SMPTE292M
SMPTE 274M(1080p30/25)
Dimension
Weight
117W) x 65(D) x 26(H) mm
Approx. 160g(0.35 lbs)
SMPTE 296M(720p25/30/50/60)
Operating temperature
0°C ~ 50°C / 5% ~ 95%RH
OPTICAL PORT
26
Input Voltage
95.5
117
65
- 1ch Optic to HD-SDI converter
- LC type 1ch Fiber-optic input, BNC 1ch output
- Supports SMPTE-292M(HD-SDI) video standard
- Supports 1080p25/30, 1080i50/60,
720p25/30/50/60 resolution
- Up to 20Km video/data(RS485) transmission
via single-mode cable
- Power, Video, Data, Optic status LED indicators
- ‘UC’ model has HDcctv certificate
SMPTE 296M(720p25/30/50/60)
Specifications
OPT-RX1-RS485U(C)
Key Features
97(W) x 65(D) x 26(H) mm
Approx. 120g
60
97
65
- 1ch HD-SDI to Optic converter
- BNC 1ch input, LC type 1ch Fiber-optic output
- Supports SMPTE-292M(HD-SDI) video standard
- Supports 1080p25/30, 1080i50/60,
720p25/30/50/60 resolution
- Up to 20Km video/data(RS485) transmission
via single-mode cable
- Power, Video, Data, Optic status LED indicators
- ‘UC’ model has HDcctv certificate
Dimension
Weight
INTERFACE
OPT-TX1-RS485U(C)
Key Features
ENVIRONMENTAL & PHYSICAL
1CH (HD-SDI SMPTE 292M)
SMPTE 274M(1080i60/50, 1080p30/25)
VIDEO OUTPUT
65
Key Features
VIDEO INPUT
Fiber Type
Connector
Single-mode
LC
Distance
20Km(12.4mi) at 1.5Gbps
Input Voltage
DC12V
Power consumption
Max. 2.0W
Approval
KC, FCC, CE, RoHS, HDcctv
95.5
117
120
HD-CCTV Converters & etc
Premium to your security
Specifications
OPT-TX4-RS485U(C)
Key Features
HD-SDI PORT
Video standard
Resolution
Dimension (unit:mm)
- 4ch HD-SDI to Optic converter
- BNC 4ch input, LC type 4ch Fiber-optic output
- Supports SMPTE-292M(HD-SDI) video standard
- Supports 1080p25/30, 1080i50/60,
720p25/30/50/60 resolution
- Up to 20Km video/data(RS485) transmission
via single-mode cable
- Power, Video, Data, Optic status LED indicators
- ‘UC’ model has HDcctv certificate
ENVIRONMENTAL & PHYSICAL
SMPTE292M
SMPTE 274M(1080p30/25)
Dimension
Weight
239(W) x 120(D) x 44(H) mm
Approx. 1Kg(2.2lbs)
SMPTE 296M(720p25/30/50/60)
Operating temperature
0°C ~ 50°C / 5% ~ 95%RH
Fiber Type
Connector
Single-mode
LC
Distance
20Km(12.4mi) at 1.5Gbps
Input Voltage
DC 12V
Power consumption
Max. 6.0W
Approval
KC, FCC, CE, RoHS, HDcctv
44
120
OPTICAL PORT
239
Specifications
OPT-RX16-RS485U(C)
Dimension (unit:mm)
462
483
121
483(W) x 342(D) x 44(H) mm
Approx. 4.5Kg(9.92lbs)
SMPTE 296M(720p25/30/50/60)
Operating temperature
0°C ~ 50°C / 5% ~ 95%RH
Fiber Type
Connector
Single-mode
LC
Distance
20Km(12.4mi) at 1.5Gbps
Input Voltage
DC 12V
Power consumption
Max. 30W
Approval
KC, FCC, CE, RoHS, HDcctv
Specifications
INTERFACE
DEVICE CONNECTION
Support Devices
Dimension (unit:mm)
HD/MH/EH/LH series DVR
Pelco-D/Pelco-P protocol supported camera
Joy Stick
LCD
Control Center Software
ENVIRONMENTAL & PHYSICAL
OPTICAL PORT
190
- Supports 255 DVRs, 255 Speed dome camera
- PTZ dome camera control via DVR or CMS
- Unit and channel control which are connected
to Control Center
- Supports Preset, Tour, Pattern, Group and
other major functions
- Supports RS485/422/232
- Supports various protocols
(Pelco-D, Pelco-P and so on)
Dimension
Weight
44
WKC-100
Key Features
ENVIRONMENTAL & PHYSICAL
SMPTE292M
SMPTE 274M(1080p30/25)
OPTICAL PORT
342
- 16ch Optic to HD-SDI converter
- LC type 16ch Fiber-optic input, BNC 16ch output
- Supports SMPTE-292M(HD-SDI) video standard
- Supports 1080p25/30, 1080i50/60,
720p25/30/50/60 resolution
- Up to 20Km video/data(RS485) transmission
via single-mode cable
- Power, Video, Data, Optic status LED indicators
- 19” Rack-mount type
- ‘UC’ model has HDcctv certificate
Video standard
Resolution
361
Key Features
HD-SDI PORT
390
3 Axis Joy Stick
30 x 8 Character LCD
Dimension
Weight
390(W) x 190(D) x 97(H) mm
Approx. 1.2kg
Operating temperature
0°C to +50°C / 0%RH to 90%RH
Method
Cascade
RS485/RS422/RS232
Up to 255 keyboards with Master/Slave
Protocol
EZ,HWL,S2,S2e,Pelco-D, Pelco-P
Input Voltage
DC12V / 0.5A
Password
Master,User Login
Power Consumption
Max 6W
97
122
HD IP &
NVR
HD IP
&
NVR
Versatile WESP
(Webgate Embedded Standard Protocol) SDK
Provides Max.8 Streams
Dual Video Compression
Reliable Standalone NVR
Supports Mirroring and IPFR
(Intelligent Power Failure Recovery)
HD IP/NVR
Premium to your security
Specifications
IMAGE COMPRESSION
MPEG-4 Resolution
JPEG Resolution
Up to 720x480, 30 frames per second Support D1(4CIF)/HALF(2CIF)/CIF/QCIF
Support D1(4CIF)/HALF(2CIF)/CIF/QCIF
Performance
Up to 8 streams simultaneously MPEG-4 D1(4CIF) 60fps
NETWORK
Program
Protocol
Control Center, Web Browser
TCP/IP, HTTP, ARP, ICMP, UDP, FTP, SMTP, DNS, DHCP, PPPoE, SNTP
Connection
10/100Mbps Ethernet (RJ-45)
F/W Upgrade
Firmware upgrade via Network
Number of clients
10 users
Security
Encrypted password, IP filtering
INPUT / OUTPUT
Video
Audio
1 Input : CVBS(BNC) / 1 Output : CVBS(BNC)
1 input : Line-in, 1Vpp / 1 output : Line-out, 1Vpp
Sensor Input
Software-controlled 2 sensor inputs (Dry contact)
Digital Output Schedule
Daily : Day / Night / Four-segment time frame
Weekly : Weekdays / Weekends
Conditions : MD, Sensor
Digital Output
Software-controlled 2 digital outputs (TTL level)
PTZ CONTROL
B101M
Network Server Solution
Key Features
Dimension (unit:mm)
Serial Port
Control Method (Remote)
RS232, RS422/485
PTZ control at the screen (control center, web)
Preset Mode
64 preset positions per channel
ADDITIONAL FUNCTION
Password Protection
Video Motion Detection
Yes
Yes
- Supports Multi Streaming (Max.8) under D1/60fps performance
FTP/E-mail Sending
Yes
- Supports Dual-Codec (MPEG-4 & JPEG)
OS
- Supports D1 / Half D1 / CIF / QCIF Resolutions
Operation System
- 2 Sensor Inputs (Dry Contact) / 2 Digital Outputs (TTL level)
ENVIRONMENTS
- Live monitoring and Server setup via IE Browser
Operation Temperature
Storage Temperature
5ºC~40ºC
-10ºC~55ºC
Operation Humidity
30%~80%, free of condensation
Storage Humidity
93% below, free of condensation
121
- 1ch MPEG-4 Video server
Front
Embedded Linux
ELECTRICITY
DC Adaptor (optional)
Power Consumption
Input : AC 110~220V / Output : DC 12V 5A
Max. 5W (DC12V)
MECHANICAL
Back
113
33
125
124
Dimension (mm)
Weight
121.0(W) x 124.0(D) x 33.0(H)
Approx. 300g
Approval
KC, FCC, CE, RoHS
126
HD IP/NVR
Premium to your security
Specifications
IMAGE COMPRESSION
MPEG-4 Resolution
JPEG Resolution
Up to 720x480, 30 frames per second Support D1(4CIF)/HALF(2CIF)/CIF/QCIF
Support D1(4CIF)/HALF(2CIF)/CIF/QCIF
NETWORK
Program
Protocol
Control Center
TCP/IP, HTTP, ARP, ICMP, UDP, FTP, SMTP, DNS, DHCP, PPPoE, SNTP
Connection
10/100Mbps Ethernet (RJ-45)
F/W Upgrade
Firmware upgrade via Network
Security
Encrypted password, IP filtering
INPUT / OUTPUT
Video
Audio
1 ch output for analog monitor
1 input : Line-in, 1Vpp / 1 output : Line-out, 1Vpp
ADDITIONAL FUNCTION
D101M
Key Input for OSD control
Sequence Monitoring
Yes
Yes
Keyboard for remote PTZ control
Yes
Caption on Screen
Yes
Network Server Solution
Key Features
OS
Dimension (unit:mm)
Operation System
Embedded Linux
- 1ch MPEG-4 video decoder
- Supports various resolution D1(4CIF), HALF D1(2CIF), CIF, QCIF
ENVIRONMENTS
- MPEG-4 & JPEG decoding
- Sequential monitoring up to 16 video servers
Operation Temperature
Storage Temperature
5ºC~40ºC
-10ºC~55ºC
- OSD menu control of video server at non-PC environment
Operation Humidity
30%~80%, free of condensation
- Supports bi-directional audio (1ch RCA input & output)
Storage Humidity
93% below, free of condensation
ELECTRICITY
121
Front
DC Adaptor (optional)
Power Consumption
Input : AC 110~220V / Output : DC 12V, 5A
Max. 5W (DC12V)
MECHANICAL
113
Back
33
127
124
Dimension (mm)
Weight
121.0(W) x 124.0(D) x 33.0(H)
Approx. 300g
Approval
KC, FCC, CE, RoHS
128
HD IP/NVR
Premium to your security
Specifications
LENS
Lens Mount
Lens Type
PTZ CONTROL
CS / C(Ring Adaptor)
Manual Iris, DC Iris, Video Iris
Serial Port
Control Method (Remote)
RS232, RS422/485
PTZ control at the screen (control center, web)
Preset Mode
64 preset positions per channel
CAMERA
ADDITIONAL FUNCTION
Image Sensor
Resolution
Progressive Scan, 1/3”, CMOS image sensor
1280 x 720(720p)
Effective Pixels
1.25M-Effective Pixels
Password Protection
Video Motion Detection
Yes
Yes
Min. Lux Level
0.001 Lux @ 50IRE, F1.4, 3100K, 0.5Lux @ 50IRE, F1.4, 3100K
FTP/E-mail Sending
Yes
Sensitivity(F5.6)
3200K, 706 cd/m2, Y signal, 1/30 s accumulation
White Balance
ATW/AWC/PUSH
AGC
Yes
Back-light compensation
Yes
DSS
Yes
OS
Operation System
Embedded Linux
ENVIRONMENTS
IMAGE COMPRESSION
HDC730C
MPEG-4 Resolution
Up to 1280x720, 30 frames per second
Supports 720p/D1(4CIF)/HALF(2CIF)/CIF/QCIF
JPEG Resolution
Supports 720p/D1(4CIF)/HALF(2CIF)/CIF/QCIF
Performance
Up to 2 streams simultaneously
MPEG-4 720p 30fps performance
HD Box Camera
Key Features
Program
Protocol
- 1ch MPEG-4 High-Definition network camera
5ºC~40ºC
-10ºC~55ºC
Operation Humidity
30%~80%, free of condensation
Storage Humidity
93% below, free of condensation
ELECTRICITY
DC Adaptor (optional)
Power Consumption
NETWORK
Dimension (unit:mm)
Operation Temperature
Storage Temperature
Control Center, Web Browser
TCP/IP, HTTP, ARP, ICMP, UDP, FTP, SMTP,
DNS, DHCP, PPPoE, SNTP
Input : AC 110~220V / Output : DC 12V 5A
Max. 7W (DC12V), 8W(PoE)
MECHANICAL
- [email protected] or [email protected] performance
Connection
10/100Mbps Ethernet (RJ-45)
Dimension (mm)
Weight
68(W) x 149.2(D) x 63(H)
Approx. 460g
- Supports 1280x720, (x1/4), (x1/16) resolutions
F/W Upgrade
Firmware upgrade via Network
Approval
KC, FCC, CE, RoHS
Number of clients
5 users
Security
Encrypted password, IP filtering
63
- 1/3”, 1.3M CMOS Sensor
- Superior sensitivity, 0.001lux @B&W, 0.5lux @Color
- PoE (Power over Ethernet) Option
- Bi-Directional Audio (1ch Input/Output)
- 2 sensor Inputs (Dry Contact) / 2 digital Outputs (TTL level)
- RS232 and RS422/485 port for PTZ Control
68
149.2
INPUT / OUTPUT
- Supports static or dynamic IP for xDSL and cable-modem User
Video
Audio
1 ch output
1 input : Line-in, 1Vpp / 1 output : Line-out, 1Vpp
- Live monitoring and camera setup via IE Browser
Sensor input
Software-controlled 2 sensor inputs (Dry contact)
- Supports WESP (Webgate Embedded Standard Protocol)
Digital Output Schedule
Daily : Day / Night / Four-segment time frame
- SDK is available for customization
Weekly : Weekdays / Weekends
Conditions : MD, Sensor
Digital Output
129
Software-controlled 2 digital outputs (TTL level)
130
HD IP/NVR
Premium to your security
SPD360M
Specifications
IP Speed Dome Camera
LENS
Lens Optical
Key Features
PTZ CONTROL
36x (f=3.4 ~ 122.4mm), F1.6(Wide) ~ F4.5(Tele)
Optical zoom 36x & Digital zoom 16x (Total 576x)
Serial Port
Control Method (Remote)
RS232, RS485
PTZ control at the screen (control center, web)
Preset Mode
64 preset positions per channel
COD CAMERA
- 1ch MPEG-4 Network speed dome camera
ADDITIONAL FUNCTION
- Supports multi-streaming(Max.8) with D1/60fps performance
COD Format
Video Type
Progressive Scan, 1/3”, CMOS image sensor
NTSC
- Supports D1/ Half D1/ CIF /QCIF resolution
Max. Resolution
720 x 480
Password Protection
Video Motion Detection
Yes
Yes
- Day/Night function of IR Cut-filter removing method
Image Transfer Rate
MAX. 30fps (NTSC) / 25fps (PAL)
FTP/E-mail Sending
Yes
- 360° endless panning
Minimum illumination
0.5 lx (50 IRE)
- 36x Optical zoom (Max. 576x including 12x digital zoom)
0.05 lx (50 IRE, IR Filter OFF)
- MPEG-4 & JPEG Dual Codec
0.001 lx (50 IRE, IR Filter ON, 512 Fields)
OS
- Noise Reduction / Optional PoE
0.0001 lx (50 IRE, IR Filter OFF, 512 Fields)
Operation System
- Bi-directional audio
AGC
High / Medium / Low
- 4 Sensor inputs (Dry contact) / 2 Digital outputs (TTL Level)
Auto white balance
ATW / AWC / Indoor / Outdoor / Manual
Back-light compensation
BLC / BMB / WDR
- Supports RS232, RS485 and CVBS output for Local operation
- Supports Fixed/Dynamic IP address for xDSL, Cable modem users
- Live monitoring and configuration through web browser
IMAGE COMPRESSION
- WESP (WEBGATE Embedded Standard Protocol) SDK compatible
Dimension (unit:mm)
Embedded Linux
ENVIRONMENTS
Operation Temperature
Storage Temperature
5ºC~40ºC
-10ºC~55ºC
Operation Humidity
30%~80%, free of condensation
Storage Humidity
93% below, free of condensation
MPEG-4 Resolution
Up to 1280x720 @ 30 frames per second
Support D1(4CIF)/ HALF(2CIF)/ CIF/ QCIF
JPEG Resolution
Support D1(4CIF)/ HALF(2CIF)/ CIF/ QCIF
Performance
MPEG-4 D1(4CIF) 60fps performance
ELECTRICITY
Up to 8 video streams simultaneously
DC Adaptor (optional)
Power Consumption
Control Center, Web Browser
TCP/IP, HTTP, ARP, ICMP, UDP, FTP, SMTP,
MECHANICAL
Input : AC 110~220V / Output : DC 12V, 5A
Max. 7W (DC12V)
126
NETWORK
191
67
Program
Protocol
DNS, DHCP, PPPoE, SNTP
Dimension (mm)
Weight
126.0(Φ) x 191.0(mm)
Approx. 1.2kg
Connection
10/100Mbps Ethernet (RJ-45)
Approval
KC, FCC, CE, RoHS
F/W Upgrade
Firmware upgrade via Network
Number of clients
10 users
Security
Encrypted password, IP filtering
INPUT / OUTPUT
131
Video output
Audio
VBS, 1Vp-p / 75Ω, Composite signal
1 input : Line-in, 1Vpp / 1 output : Line-out, 1Vpp
Sensor input
Software-controlled 4 sensor inputs (Dry contact)
Digital output
Software-controlled 2 digital outputs (TTL level)
132
HD IP/NVR
Premium to your security
Specifications
SYSTEM
OS
Network
Embedded linux
1 Gigabit Ethernet port for network
1 Gigabit Ethernet for future use
VIDEO
Recording channels
Supported camera
Up to 16 HD video streams
B101M, E30M, SPD260M, SPD350M, SPD360M, VD101M, HDC730
* Axis, Arecont, Truen, Acti, STW, Brickcom
* Please contact local sales for the details
Codec
MPEG-4, H.264
Recording Rate
up to 480fps
STORAGE
NVS04S
HD Network Video Recorder
Key Features
Capacity
Performance
8TB
Up to 80Mbps
Storage device
4 SATA interface with hot-swap function
Intelligent file system
Data-loss protection against power failure
EVENT
Dimension (unit:mm)
Capacity
Storage device
8TB
4 SATA interface with hot-swap function
Intelligent file system
Data-loss protection against power failure
- Network Video Recorder (Standalone type NVR)
- Up to 16 HD video streams can be recorded
- 4 Hot-Swap, SATA type HDD bays
ENVIRONMENTS
- Remote playback and configuration via CMS (Control Center)
Operation Temperature
Storage Temperature
+5ºC~+40ºC (+41F ~ +113F)
-25ºC~+70ºC (-13F ~ +158F)
Operation Humidity
30%~80%, free of condensation
Storage Humidity
93% below, free of condensation
- IPFR Support (Intelligent Power Failure Recovery)
383
Front
ELECTRICITY
Power
Power Consumption with 4HDD
AC 100~240V, 50/60Hz
TBD
ENVIRONMENTAL & PHYSICAL
Back
Dimension (mm)
Weight
445(W) x 383(D) x 44(H)
Approx. 5.5 Kg (with one HDD)
44
445
133
134
H.264
DVR
H.264
DVR
H.264 and JPEG dual codec
Adjustable resolution
PTZ control
Built-in Mirroring support
H.264 Standalone DVR
Premium to your security
Specifications
VIDEO INPUT
Video input analog ch
Connectors
NETWORK
32 BNC connectors (NTSC/PAL, auto detect)
32ch, 75Ω BNC connector
VIDEO OUTPUT
Video Output
Loop Output
4 BNC (Each monitor supports16 split-screen), 2 DVI
1, 4, 9, 16 mode
H.264 Standalone Digital Video Recorder
Front
- 32ch Standalone DVR
Server / Client / Both
Users
10 monitoring, 2 playback
Menu, PTZ, relay, playback, power On/Off, copy,Network MIC
IP filtering
Supported
Resolution
Rate
D1(4CIF), HALF(2CIF), CIF
960/800fps (NTSC/PAL) at Half D1(2CIF)
Quality
5 levels of compression rate /
Mode
Manual & Event / Schedule & Event / Continuous & Event
Schedule
24hrs / 7days
PLAYBACK
- 4 Individual monitor output via built-in 4 BNC and 2 DVI port
Mode
Search type
Instant playback / search
Time, Calendar, Event, Thumbnail, Smart
Block playback
24hours ~ 99days
Back
Supported
NTP
User level
User privilege
- Adjustable recording quality and framerate per each channel
- Supports Dual Codec(H.264, JPEG) / Multi stream
Supported
Bandwidth limit
SECURITY
- Full-frame monitoring/recording(960/[email protected]) for all channels
(Each monitor can support playback / split-screen / menu display)
WRS
Not supported
Record frame rate adjustment
Key Features
10/100 Ethernet
Fixed IP, Floating IP, xDSL
User defined sequence / alarm pop-up
RECORDING
MH3200M
Interface
Type
STORAGE & BACKUP
Storage devices
4 internal SATA HDDs, 1 external eSATA I/F,
1 ethernet for storage
Mirroring
Supported
File system
Proprietary file system, data-loss protection
Capacity
Max 8TB with SATA, Max 32TB with cascaded NVS04R
Backup type
Multi-channel own file format or single channel avi file
Backup device
Internal CD/DVD or USB drive(2 port)
S.M.A.R.T.
Temperature and health
against power-failure
SERIAL & I/O
- Supports IPFR (Intelligent Power Failure Recovery) file system
Serial port
Sensor input
1 RS-232C, 2 RS-485
16 dry-contact
Relay output
4 relay
- 4 Internal SATA type HDDs
EVENT & ALARM
- Supports external storage via gigabit ethernet (NVS04R)
- Supports external storage via eSATA port
Event source
Event check schedule
- Date/Time, Calendar, Event, Thumbnail, Smart, Text search available
Event action
Buzzer, Relay, E-mail, Twitter, FTP, Alarm Pop-Up
CONTROLLER
- Provides bundle CMS program that manages 1,024 DVRs in various
MD area
22x15(NTSC) or 22x18(PAL) grid
Device
Sensor input
Dry contact (N.O. or N.C. selectable)
Text input
POS/ATM support, AVE VSI Pro/Hydra support
ways such as E-map, Viewset
Dimension (unit:mm)
- Java Viewer for Chrome, Firefox, Safari
MD(Motion Detection), sensor, video loss, text
24hrs / 7days
- Various mobile platform support (iPhone/Android Viewer, Mobile page)
SYSTEM ALARM
418
- Provides full SDK for easy and powerful customization
Alarm source
Alarm action
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, buzzer, e-mail, relay, twitter
Input/output
16ch input / 1ch output
88
445
PTZ
Protocols
Front panel, IR remote, Joystick KBD, Mouse
SOFTWARE
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event/ PTZ with Chrome, Firefox and Safari
Mobile viewer
Monitoring with PTZ, iPhone & Android supported
CMS
Control Center standard, max 1024 DVRs
SDK
ActiveX(COM) SDK
ENVIRONMENTAL & PHYSICAL
AUDIO
137
1 admin, 10 users
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, and Panasonic
Dimension
Weight
445(W) x 418(D) x 88(H) mm
Approx. 9.5 Kg (No HDD)
Operating temperature
5°C ~ 45°C (41°F ~ 113°F)
Power
AC free voltage (100 ~ 240V), 50/60Hz
Power consumption
Approval
Max. 75W Typical 50W
FCC, CE, MIC, RoHS
138
H.264 Standalone DVR
Premium to your security
Specifications
VIDEO INPUT
Video input analog ch
Connectors
NETWORK
16 BNC connectors (NTSC/PAL, auto detect)
16ch, 75Ω BNC connector
VIDEO OUTPUT
Video Output
Loop Output
4 BNC (Each monitor supports16 split-screen), 2 DVI
1, 4, 9, 16 mode
H.264 Standalone Digital Video Recorder
Front
- 16ch Standalone DVR
Server / Client / Both
Users
10 monitoring, 2 playback
Menu, PTZ, relay, playback, power On/Off, copy, Network MIC
IP filtering
Supported
Resolution
Rate
D1(4CIF), HALF(2CIF), CIF
480/400fps (NTSC/PAL) at D1(4CIF)
Quality
5 levels of compression rate /
Mode
Manual & Event / Schedule & Event / Continuous & Event
Schedule
24hrs / 7days
PLAYBACK
- 4 Individual monitor output via built-in 4 BNC and 2 DVI port
Mode
Search type
Instant playback / search
Time, Calendar, Event, Thumbnail, Smart
Block playback
24hours ~ 99days
Back
Supported
NTP
User level
User privilege
- Adjustable recording quality and framerate per each channel
- Supports Dual Codec(H.264, JPEG) / Multi stream
Supported
Bandwidth limit
SECURITY
- Full-frame monitoring/recording(480/[email protected]) for all channels
(Each monitor can support playback /split screen / menu display)
WRS
16 with auto-termination
Record frame rate adjustment
Key Features
10/100 Ethernet
Fixed IP, Floating IP, xDSL
User defined sequence / alarm pop-up
RECORDING
MH1600H
Interface
Type
STORAGE & BACKUP
Storage devices
4 internal SATA HDDs, 1 external eSATA I/F,
1 ethernet for storage
Mirroring
Supported
File system
Proprietary file system, data-loss protection
Capacity
Max 8TB with SATA, Max 32TB with cascaded NVS04R
Backup type
Multi-channel own file format or single channel avi file
Backup device
Internal CD/DVD or USB drive(2 port)
S.M.A.R.T.
Temperature and health
against power-failure
SERIAL & I/O
- Supports IPFR (Intelligent Power Failure Recovery) File System
Serial port
Sensor input
1 RS-232C, 2 RS-485
16 dry-contact
Relay output
4 relay
- 4 Internal SATA type HDDs
EVENT & ALARM
- Supports external Storage via gigabit ethernet (NVS04R)
- Supports external storage via eSATA port
Event source
Event check schedule
- Date/Time, Calendar, Event, Thumbnail, Smart, Text search available
Event action
Buzzer, Relay, E-mail, Twitter, FTP, Alarm Pop-Up
CONTROLLER
- Provides bundle CMS program that manages 1,024 DVRs in various
MD area
22x15(NTSC) or 22x18(PAL) grid
Device
Sensor input
Dry contact (N.O. or N.C. selectable)
Text input
POS/ATM support, AVE VSI Pro/Hydra support
ways such as E-map, Viewset
Dimension (unit:mm)
- Java Viewer for Chrome, Firefox, Safari
MD(Motion Detection), sensor, video loss, text
24hrs / 7days
- Various mobile platform support (iPhone/Android Viewer, Mobile page)
SYSTEM ALARM
418
- Provides Full SDK for easy and powerful customization
Alarm source
Alarm action
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, buzzer, e-mail, relay, twitter
Input/output
16ch input / 1ch output
88
445
PTZ
Protocols
Front panel, IR remote, Joystick KBD, Mouse
SOFTWARE
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event/ PTZ with Chrome, Firefox and Safari
Mobile viewer
Monitoring with PTZ, iPhone & Android supported
CMS
Control Center standard, max 1024 DVRs
SDK
ActiveX(COM) SDK
ENVIRONMENTAL & PHYSICAL
AUDIO
139
1 admin, 10 users
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, and Panasonic
Dimension
Weight
445(W) x 418(D) x 88(H) mm
Approx. 9.5 Kg (No HDD)
Operating temperature
5°C ~ 45°C (41°F ~ 113°F)
Power
AC free voltage (100 ~ 240V), 50/60Hz
Power consumption
Approval
Max. 75W Typical 50W
FCC, CE, MIC, RoHS
140
H.264 Standalone DVR
Premium to your security
Specifications
VIDEO INPUT
Video input analog ch
Connectors
NETWORK
16 BNC connectors (NTSC/PAL, auto detect)
16ch, 75Ω BNC connector
VIDEO OUTPUT
Video Output
Loop Output
2 BNC (Each monitor supports 16 split-screen), 1 DVI
1, 4, 9, 16 mode
H.264 Standalone Digital Video Recorder
Front
- 16ch Standalone DVR
Server / Client / Both
Users
10 monitoring, 2 playback
Menu, PTZ, relay, playback, power On/Off, copy, Network MIC
IP filtering
Supported
Resolution
Rate
D1(4CIF), HALF(2CIF), CIF
480/400fps (NTSC/PAL) at Half D1(2CIF)
Quality
5 levels of compression rate /
Mode
Manual & Event / Schedule & Event / Continuous & Event
Schedule
24hrs / 7days
PLAYBACK
- 4 Individual monitor output via built-in 4 BNC and 2 DVI port
Mode
Search type
Instant playback / search
Time, Calendar, Event, Thumbnail, Smart
Block playback
24hours ~ 99days
Back
Supported
NTP
User level
User privilege
- Adjustable recording quality and framerate per each channel
- Supports Dual Codec(H.264, JPEG) / Multi stream
Supported
Bandwidth limit
SECURITY
- Full-frame monitoring/recording(480/[email protected]) for all channels
(Each monitor can support playback / split-screen/menu display)
WRS
16 with auto-termination
Record frame rate adjustment
Key Features
10/100 Ethernet
Fixed IP, Floating IP, xDSL
User defined sequence / alarm pop-up
RECORDING
MH1600M
Interface
Type
STORAGE & BACKUP
Storage devices
4 internal SATA HDDs, 1 external eSATA I/F,
1 ethernet for storage
Mirroring
Supported
File system
Proprietary file system, data-loss protection
Capacity
Max 8TB with SATA, Max 32TB with cascaded NVS04R
Backup type
Multi-channel own file format or single channel avi file
Backup device
Internal CD/DVD or USB drive(2 port)
S.M.A.R.T.
Temperature and health
against power-failure
SERIAL & I/O
- Supports IPFR (Intelligent Power Failure Recovery) File System
Serial port
Sensor input
1 RS-232C, 2 RS-485
16 dry-contact
Relay output
4 relay
- 4 Internal SATA type HDDs
EVENT & ALARM
- Supports external storage via gigabit ethernet (NVS04R)
- Supports external storage via eSATA port
Event source
Event check schedule
- Date/Time, Calendar, Event, Thumbnail, Smart, Text search available
Event action
Buzzer, Relay, E-mail, Twitter, FTP, Alarm Pop-Up
CONTROLLER
- Provides bundle CMS program that manages 1,024 DVRs in various
MD area
22x15(NTSC) or 22x18(PAL) grid
Device
Sensor input
Dry contact (N.O. or N.C. selectable)
Text input
POS/ATM support, AVE VSI Pro/Hydra support
ways such as E-map, Viewset
Dimension (unit:mm)
- Java Viewer for Chrome, Firefox, Safari
MD(Motion Detection), sensor, video loss, text
24hrs / 7days
- Various mobile platform support (iPhone/Android Viewer, Mobile page)
SYSTEM ALARM
418
- Provides Full SDK for easy and powerful customization
Alarm source
Alarm action
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, buzzer, e-mail, relay, twitter
Input/output
16ch input / 1ch output
88
445
PTZ
Protocols
Front panel, IR remote, Joystick KBD, Mouse
SOFTWARE
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event/ PTZ with Chrome, Firefox and Safari
Mobile viewer
Monitoring with PTZ, iPhone & Android supported
CMS
Control Center standard, max 1024 DVRs
SDK
ActiveX(COM) SDK
ENVIRONMENTAL & PHYSICAL
AUDIO
141
1 admin, 10 users
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, and Panasonic
Dimension
Weight
445(W) x 418(D) x 88(H) mm
Approx. 9.5 Kg (No HDD)
Operating temperature
5°C ~ 45°C (41°F ~ 113°F)
Power
AC free voltage (100 ~ 240V), 50/60Hz
Power consumption
Approval
Max. 75W Typical 50W
FCC, CE, MIC, RoHS
142
H.264 Standalone DVR
Premium to your security
Specifications
VIDEO INPUT
Video input analog ch
Connectors
NETWORK
16 BNC connectors (NTSC/PAL, auto detect)
16ch, 75Ω BNC connector
VIDEO OUTPUT
Video Output
2 BNC (1 Main Monitor, 1 Spot Monitor), 1 DVI
1, 4, 9, 16 mode
User defined sequence / alarm pop-up
Loop Output
16 with auto-termination
RECORDING
EH1600L
H.264 Standalone Digital Video Recorder
Key Features
Front
- 16ch Standalone DVR
Resolution
Rate
D1(4CIF), HALF(2CIF), CIF
480/400fps (NTSC/PAL) at Half D1(2CIF)
Quality
5 levels of compression rate /
Supported
NTP
Server / Client / Both
Users
10 monitoring, 2 playback
SECURITY
User level
User privilege
Menu, PTZ, relay, playback, power On/Off, copy, Network MIC
IP filtering
Supported
STORAGE & BACKUP
Manual & Event / Schedule & Event / Continuous & Event
File system
Proprietary file system, data-loss protection
Schedule
24hrs / 7days
Mode
Search type
Instant playback / search
Time, Calendar, Event, Thumbnail, Smart
Block playback
24hours ~ 99days
- Date/Time, Calendar, Event, Thumbnail, Smart, Text search available
EVENT & ALARM
- Provides bundle CMS program that manages 1,024 DVRs in various
Event source
Event check schedule
against power-failure
Capacity
Max 8TB with SATA
Backup type
Multi-channel own file format or single channel avi file
Backup device
Internal CD/DVD or USB drive(2 port)
S.M.A.R.T.
Temperature and health
SERIAL & I/O
Serial port
Sensor input
1 RS-232C, 2 RS-485
16 dry-contact
MD(Motion Detection), sensor, video loss, text
24hrs / 7days
Relay output
2 relay
- Supports external storage via eSATA port
- Java Viewer for Chrome, Firefox, Safari
Event action
Buzzer, Relay, E-mail, Twitter, FTP, Alarm Pop-Up
CONTROLLER
- Various mobile platform support (iPhone/Android Viewer, Mobile page)
MD area
22x15(NTSC) or 22x18(PAL) grid
Device
Sensor input
Dry contact (N.O. or N.C. selectable)
Text input
POS/ATM support, AVE VSI Pro/Hydra support
- Provide Full SDK for easy and powerful customization
Dimension (unit:mm)
413
SYSTEM ALARM
Alarm source
Alarm action
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, buzzer, e-mail, relay, twitter
Input/output
88
143
4ch input / 1ch output
PTZ
Protocols
Front panel, IR remote, Joystick KBD, Mouse
SOFTWARE
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event/ PTZ with Chrome, Firefox and Safari
Mobile viewer
Monitoring with PTZ, iPhone & Android supported
CMS
Control Center standard, max 1024 DVRs
SDK
ActiveX(COM) SDK
ENVIRONMENTAL & PHYSICAL
AUDIO
350
1 admin, 10 users
Mode
- Main and Spot monitor output via built-in 2 BNC and 1 DVI port
ways such as E-map, Viewset
Supported
Bandwidth limit
2 internal SATA HDDs, 1 external eSATA I/F
Not Supported
PLAYBACK
Back
WRS
Storage devices
Mirroring
- Adjustable recording quality and framerate per each channel
- 2 Internal SATA type HDDs
10/100 Ethernet
Fixed IP, Floating IP, xDSL
Record frame rate adjustment
- Full-frame monitoring/recording(480/[email protected]) for all channels
- Supports Dual Codec(H.264, JPEG) / Multi stream
Interface
Type
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, and Panasonic
Dimension
Weight
350(W) x 413(D) x 88(H) mm
Approx. 8.0 Kg (No HDD)
Operating temperature
5°C ~ 45°C (41°F ~ 113°F)
Power
AC free voltage (100 ~ 240V), 50/60Hz
Power consumption
Approval
Max. 75W Typical 50W
FCC, CE, MIC, RoHS
144
H.264 Standalone DVR
Premium to your security
Specifications
VIDEO INPUT
Video input analog ch
Connectors
NETWORK
8 BNC connectors (NTSC/PAL, auto detect)
8ch, 75Ω BNC connector
VIDEO OUTPUT
Video Output
2 BNC (1 Main Monitor, 1 Spot Monitor), 1 DVI
1, 4, 9 mode
User defined sequence / alarm pop-up
Loop Output
8 with auto-termination
RECORDING
EH800M
H.264 Standalone Digital Video Recorder
Key Features
Front
- 8ch Standalone DVR
Resolution
Rate
D1(4CIF), HALF(2CIF), CIF
240/200fps (NTSC/PAL) at HALF D1(2CIF)
Quality
5 levels of compression rate /
Supported
NTP
Server / Client / Both
Users
10 monitoring, 2 playback
SECURITY
User level
User privilege
Menu, PTZ, relay, playback, power On/Off, copy, Network MIC
IP filtering
Supported
STORAGE & BACKUP
Manual & Event / Schedule & Event / Continuous & Event
File system
Proprietary file system, data-loss protection
Schedule
24hrs / 7days
Mode
Search type
Instant playback / search
Time, Calendar, Event, Thumbnail, Smart
Block playback
24hours ~ 99days
- Date/Time, Calendar, Event, Thumbnail, Smart, Text search available
EVENT & ALARM
- Provides bundle CMS program that manages 1,024 DVRs in various
Event source
Event check schedule
against power-failure
Capacity
Max 8TB with SATA
Backup type
Multi-channel own file format or single channel avi file
Backup device
Internal CD/DVD or USB drive(2 port)
S.M.A.R.T.
Temperature and health
SERIAL & I/O
Serial port
Sensor input
1 RS-232C, 2 RS-485
8 dry-contact
MD(Motion Detection), sensor, video loss, text
24hrs / 7days
Relay output
2 relay
- Supports external storage via eSATA port
- Java Viewer for Chrome, Firefox, Safari
Event action
Buzzer, Relay, E-mail, Twitter, FTP, Alarm Pop-Up
CONTROLLER
- Various mobile platform support (iPhone/Android Viewer, Mobile page)
MD area
22x15(NTSC) or 22x18(PAL) grid
Device
Sensor input
Dry contact (N.O. or N.C. selectable)
Text input
POS/ATM support, AVE VSI Pro/Hydra support
- Provides full SDK for easy and powerful customization
Dimension (unit:mm)
413
SYSTEM ALARM
Alarm source
Alarm action
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, buzzer, e-mail, relay, twitter
Input/output
88
145
4ch input / 1ch output
PTZ
Protocols
Front panel, IR remote, Joystick KBD, Mouse
SOFTWARE
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event/ PTZ with Chrome, Firefox and Safari
Mobile viewer
Monitoring with PTZ, iPhone & Android supported
CMS
Control Center standard, max 1024 DVRs
SDK
ActiveX(COM) SDK
ENVIRONMENTAL & PHYSICAL
AUDIO
350
1 admin, 10 users
Mode
- Main and Spot monitor output via built-in 2 BNC and 1 DVI Port
ways such as E-map, Viewset
Supported
Bandwidth limit
2 internal SATA HDDs, 1 external eSATA I/F
Not Supported
PLAYBACK
Back
WRS
Storage devices
Mirroring
- Adjustable recording quality and framerate per each channel
- 2 Internal SATA type HDDs
10/100 Ethernet
Fixed IP, Floating IP, xDSL
Record frame rate adjustment
- Full-frame monitoring/recording(240/[email protected]) for all channels
- Supports Dual Codec(H.264, JPEG) / Multi stream
Interface
Type
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, and Panasonic
Dimension
Weight
350(W) x 413(D) x 88(H) mm
Approx. 8.0 Kg (No HDD)
Operating temperature
5°C ~ 45°C (41°F ~ 113°F)
Power
AC free voltage (100 ~ 240V), 50/60Hz
Power consumption
Approval
Max. 75W Typical 50W
FCC, CE, MIC, RoHS
146
H.264 Standalone DVR
Premium to your security
Specifications
VIDEO INPUT
Video input analog ch
Connectors
NETWORK
4 BNC connectors (NTSC/PAL, auto detect)
4ch, 75Ω BNC connector
VIDEO OUTPUT
Video Output
2 BNC (1 Main Monitor, 1 Spot Monitor), 1 DVI
1, 4 mode
User defined sequence / alarm pop-up
Loop Output
4 with auto-termination
RECORDING
EH400H
H.264 Standalone Digital Video Recorder
Key Features
Front
- 4ch Standalone DVR
Resolution
Rate
D1(4CIF), HALF(2CIF), CIF
120/100fps (NTSC/PAL) at D1 (4CIF)
Quality
5 levels of compression rate /
1 admin, 10 users
IP filtering
Supported
STORAGE & BACKUP
against power-failure
Capacity
Max 8TB with SATA
Backup type
Multi-channel own file format or single channel avi file
Backup device
Internal CD/DVD or USB drive(2 port)
S.M.A.R.T.
Temperature and health
SERIAL & I/O
Serial port
Sensor input
1 RS-232C, 2 RS-485
4 dry-contact
MD(Motion Detection), sensor, video loss, text
24hrs / 7days
Relay output
2 relay
Event action
Buzzer, Relay, E-mail, Twitter, FTP, Alarm Pop-Up
CONTROLLER
MD area
22x15(NTSC) or 22x18(PAL) grid
Device
Sensor input
Dry contact (N.O. or N.C. selectable)
Text input
POS/ATM support, AVE VSI Pro/Hydra support
- Date/Time, Calendar, Event, Thumbnail, Smart, Text search available
EVENT & ALARM
- Provides bundle CMS program that manages 1,024 DVRs in various
Event source
Event check schedule
- Java Viewer for Chrome, Firefox, Safari
- Various mobile platform support (iPhone/Android Viewer, Mobile page)
SYSTEM ALARM
413
Menu, PTZ, relay, playback, power On/Off, copy, Network MIC
Proprietary file system, data-loss protection
- Supports external storage via eSATA port
Alarm source
Alarm action
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, buzzer, e-mail, relay, twitter
Input/output
4ch input / 1ch output
PTZ
Protocols
Front panel, IR remote, Joystick KBD, Mouse
SOFTWARE
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event/ PTZ with Chrome, Firefox and Safari
Mobile viewer
Monitoring with PTZ, iPhone & Android supported
CMS
Control Center standard, max 1024 DVRs
SDK
ActiveX(COM) SDK
ENVIRONMENTAL & PHYSICAL
AUDIO
88
User level
User privilege
File system
24hours ~ 99days
147
SECURITY
24hrs / 7days
Block playback
350
10 monitoring, 2 playback
Manual & Event / Schedule & Event / Continuous & Event
Instant playback / search
Time, Calendar, Event, Thumbnail, Smart
Dimension (unit:mm)
Server / Client / Both
Users
Schedule
Mode
Search type
- Provides full SDK for easy and powerful customization
Supported
NTP
Mode
- Main and Spot monitor output via built-in 2 BNC and 1 DVI Port
ways such as E-map, Viewset
Supported
Bandwidth limit
2 internal SATA HDDs, 1 external eSATA I/F
Not Supported
PLAYBACK
Back
WRS
Storage devices
Mirroring
- Adjustable recording quality and framerate per each channel
- 2 Internal SATA Type HDDs
10/100 Ethernet
Fixed IP, Floating IP, xDSL
Record frame rate adjustment
- Full-frame monitoring/recording(120/[email protected]) for all channels
- Supports Dual Codec(H.264, JPEG) / Multi stream
Interface
Type
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, and Panasonic
Dimension
Weight
350(W) x 413(D) x 88(H) mm
Approx. 8.0 Kg (No HDD)
Operating temperature
5°C ~ 45°C (41°F ~ 113°F)
Power
AC free voltage (100 ~ 240V), 50/60Hz
Power consumption
Approval
Max. 75W Typical 50W
FCC, CE, MIC, RoHS
148
H.264 Standalone DVR
Premium to your security
Specifications
VIDEO INPUT
Video input analog ch
Connectors
NETWORK
16 BNC connectors (NTSC/PAL, auto detect)
16ch, 75Ω BNC connector
VIDEO OUTPUT
Video Output
2 BNC (1 Main Monitor, 1 Spot Monitor), 1 VGA
1, 4, 9, 16 mode
User defined sequence / alarm pop-up
Loop Output
Not Supported
RECORDING
LH1600C
H.264 Standalone Digital Video Recorder
Key Features
Front
- 16ch Standalone DVR
Resolution
Rate
D1(4CIF), HALF(2CIF), CIF
480/400fps (NTSC/PAL) at CIF
Quality
5 levels of compression rate /
Supported
NTP
Server / Client / Both
Users
10 monitoring, 2 playback
SECURITY
User level
User privilege
Menu, PTZ, relay, playback, power On/Off, copy, Network MIC
IP filtering
Supported
STORAGE & BACKUP
Manual & Event / Schedule & Event / Continuous & Event
File system
Proprietary file system, data-loss protection
Schedule
24hrs / 7days
Mode
Search type
Instant playback / search
Time, Calendar, Event, Thumbnail, Smart
Block playback
24hours ~ 99days
- Date/Time, Calendar, Event, Thumbnail, Smart, Text search available
EVENT & ALARM
against power-failure
Capacity
Max 8TB with SATA
Backup type
Multi-channel own file format or single channel avi file
Backup device
Internal CD/DVD or USB drive(2 port)
S.M.A.R.T.
Temperature and health
SERIAL & I/O
Serial port
Sensor input
1 RS-232C, 2 RS-485
16 dry-contact
2 relay
Event source
Event check schedule
MD(Motion Detection), sensor, video loss, text
24hrs / 7days
Relay output
- Java Viewer for Chrome, Firefox, Safari
- Various mobile platform support (iPhone/Android Viewer, Mobile page)
Event action
Buzzer, Relay, E-mail, Twitter, FTP, Alarm Pop-Up
CONTROLLER
MD area
22x15(NTSC) or 22x18(PAL) grid
Device
Sensor input
Dry contact (N.O. or N.C. selectable)
Text input
POS/ATM support, AVE VSI Pro/Hydra support
ways such as E-map, Viewset
Dimension (unit:mm)
413
SYSTEM ALARM
Alarm source
Alarm action
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, buzzer, e-mail, relay, twitter
Input/output
88
149
4ch input / 1ch output
PTZ
Protocols
Front panel, IR remote, Joystick KBD, Mouse
SOFTWARE
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event/ PTZ with Chrome, Firefox and Safari
Mobile viewer
Monitoring with PTZ, iPhone & Android supported
CMS
Control Center standard, max 1024 DVRs
SDK
ActiveX(COM) SDK
ENVIRONMENTAL & PHYSICAL
AUDIO
350
1 admin, 10 users
Mode
- Main and Spot monitor output via built-in 2 BNC and 1 DVI port
- Provides bundle CMS program that manages 1,024 DVRs in various
Supported
Bandwidth limit
2 internal SATA HDD
Not Supported
PLAYBACK
Back
WRS
Storage devices
Mirroring
- Adjustable recording quality and framerate per each channel
- Supports external storage via eSATA
10/100 Ethernet
Fixed IP, Floating IP, xDSL
Record frame rate adjustment
- Full-frame monitoring/recording(480/[email protected]) for all channels
- Supports Dual Codec(H.264, JPEG) / Multi stream
Interface
Type
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, and Panasonic
Dimension
Weight
350(W) x 413(D) x 88(H) mm
Approx. 8.0 Kg (No HDD)
Operating temperature
5°C ~ 45°C (41°F ~ 113°F)
Power
AC free voltage (100 ~ 240V), 50/60Hz
Power consumption
Approval
Max. 75W Typical 50W
FCC, CE, MIC, RoHS
150
H.264 Standalone DVR
Premium to your security
Specifications
VIDEO INPUT
Video input analog ch
Connectors
NETWORK
8 BNC connectors (NTSC/PAL, auto detect)
8ch, 75Ω BNC connector
VIDEO OUTPUT
Video Output
2 BNC (1 Main Monitor, 1 Spot Monitor), 1 VGA
1, 4, 9 mode
User defined sequence / alarm pop-up
Loop Output
Not Supported
RECORDING
LH800L
H.264 Standalone Digital Video Recorder
Key Features
Front
- 8ch Standalone DVR
Resolution
Rate
D1(4CIF), HALF(2CIF), CIF
240/200fps (NTSC/PAL) at CIF
Quality
5 levels of compression rate /
Supported
NTP
Server / Client / Both
Users
10 monitoring, 2 playback
SECURITY
User level
User privilege
Menu, PTZ, relay, playback, power On/Off, copy, Network MIC
IP filtering
Supported
STORAGE & BACKUP
Manual & Event / Schedule & Event / Continuous & Event
File system
Proprietary file system, data-loss protection
Schedule
24hrs / 7days
Mode
Search type
Instant playback / search
Time, Calendar, Event, Thumbnail, Smart
Block playback
24hours ~ 99days
- Date/Time, Calendar, Event, Thumbnail, Smart, Text search available
EVENT & ALARM
against power-failure
Capacity
Max 8TB with SATA
Backup type
Multi-channel own file format or single channel avi file
Backup device
Internal CD/DVD or USB drive(2 port)
S.M.A.R.T.
Temperature and health
SERIAL & I/O
Serial port
Sensor input
1 RS-232C, 2 RS-485
8 dry-contact
2 relay
Event source
Event check schedule
MD(Motion Detection), sensor, video loss, text
24hrs / 7days
Relay output
- Java Viewer for Chrome, Firefox, Safari
- Various Mobile Platform Support (iPhone/Android Viewer, Mobile page)
Event action
Buzzer, Relay, E-mail, Twitter, FTP, Alarm Pop-Up
CONTROLLER
MD area
22x15(NTSC) or 22x18(PAL) grid
Device
Sensor input
Dry contact (N.O. or N.C. selectable)
Text input
POS/ATM support, AVE VSI Pro/Hydra support
ways such as E-map, Viewset
Dimension (unit:mm)
413
SYSTEM ALARM
Alarm source
Alarm action
HDD fail, HDD almost full, fan fail, Password fail, WRS fail
Warning message, buzzer, e-mail, relay, twitter
Input/output
88
151
4ch input / 1ch output
PTZ
Protocols
Front panel, IR remote, Joystick KBD, Mouse
SOFTWARE
Web viewer
Java viewer
Monitoring / Event / PTZ / Playback with IE
Monitoring / Event/ PTZ with Chrome, Firefox and Safari
Mobile viewer
Monitoring with PTZ, iPhone & Android supported
CMS
Control Center standard, max 1024 DVRs
SDK
ActiveX(COM) SDK
ENVIRONMENTAL & PHYSICAL
AUDIO
350
1 admin, 10 users
Mode
- Main and Spot Monitor output via built-in 2 BNC and 1 DVI Port
- Provides bundle CMS program that manages 1,024 DVRs in various
Supported
Bandwidth limit
2 internal SATA HDDs
Not Supported
PLAYBACK
Back
WRS
Storage devices
Mirroring
- Adjustable recording quality and framerate per each channel
- 2 Internal SATA type HDDs (Optional DVD-R/W)
10/100 Ethernet
Fixed IP, Floating IP, xDSL
Record frame rate adjustment
- full-frame monitoring/recording(240/[email protected]) for all channels
- Supports Dual Codec(H.264, JPEG) / Multi stream
Interface
Type
35 models including C1080, C1080PT-Z20, Pelco-D,
Pelco-P, Samsung, and Panasonic
Dimension
Weight
350(W) x 413(D) x 88(H) mm
Approx. 8.0 Kg (No HDD)
Operating temperature
5°C ~ 45°C (41°F ~ 113°F)
Power
AC free voltage (100 ~ 240V), 50/60Hz
Power consumption
Approval
Max. 75W Typical 50W
FCC, CE, MIC, RoHS
152
Software
SOLUTION
WebEye - WEBGATE mobile application - allows the authorized users to monitor and control all WEBGATE products
under mobile environment anywhere and anytime.
Convenient and Feature-rich CMS
WebEye for iPhone, Android Phone
Easy DVR access by Mobile page
Live Monitoring Anytime Anywhere
Centralized Management Solution
Premium to your security
Integrated Control Software Solution : Control Center
Control Center is an integrated Central Managing Software of WEBGATE. Standard version is supplied for with products, and
more powerful features are included in the Pro version. Enterprise version is equipped with Virtual Matrix feature.
Network
Max. 512
channels
Integrated Control Solution
WinRDS
Max. 512
Channels
Integrated Control
Software
Streaming
solution
Customizing
solution
Mobile solution
Dynamic IP solution
Control Center
Standard
Win RDS
WESP SDK
WebEye for
iOS
WRS
WebEye for
Android
WNS
Web
Server
[ Max. 512 video stream inputs from DVR, provides maximum. 512 video stream outputs to clients ]
Control Center
Pro
Operator
Building #1
Building #1
Building #2
Operator
Building #2
Control Center
Enterprise
WinRDS
Streaming Solution : WinRDS
WinRDS(Windows Re-Distribution Server) is streaming server providing video/audio stream and alarm/status information to
multi users. It is very helpful when distributing video stream via public website without DVR’s recording performance reduction, or multiple Control Center operating is required.
There are some differences according to resolutions, but, WinRDS allows max. 512 video streaming inputs(channels) from
DVR and can provide max. 512 stable video streams to Control Center(CMS), WebViewer(Mobile monitoring App) and web
browsers.
155
Building #3
Building #4
Admin
Building #1~#4
Network
Operator
Building #3
Operator
Building #4
156
Centralized Management Solution
Premium to your security
In case of large-scale video surveillance system, the administrator might have to assign several users’ authority to individual
DVR differently. This will be difficult and time consuming for administrator to assign each DVR with different authorities per
user.
WinRDS allows max. 100 user registration, and the administrator can easily
allocate individual user’s authority. WinRDS helps the administrator to easily
assign/modify user’s authority through simple user interface.
If 2 Network Interface cards are used in a PC which runs WinRDS, user can
separate network as DVR side and client side. So, security could be improved and lessen the network burden.
Dynamic IP Solution : WRS and WNS
WRS and WNS are solutions which enable remote users to access to units having dynamic
IP address.
WRS(WEBGATE Registration Service) is different from competitors’ DDNS service where
complicated procedures such as member
register, unit register are required. Instead, using Control Center, users can easily find their
units and register it.
Users’ authority setting trough WinRDS
Customizing Solution : WESP SDK
The powerful, abundant WESP(WEBGATE Embedded Standard Protocol) SDK has full function of Control Center with which
any special application preferred by user can be developed with ease. From low level functions which have all functions of the
products, to high level functions, showing images and controlling PTZ achieved in a single code, users can develop various
programs to meet their needs.
In addition, It can be programmed with various languages (VB, VC++, VB Script, Java Script, .NET) since it is made based on
Microsoft COM® Technology. Webpage programmer using Java Script can make featured application too.
All WEBGATE’s products use single protocol called WESP so one single program can be adopted to all range of WEBGATE’s
products.
Powerful
Application
Simple
Application
Web
Application
High Level Functions
WESP SDK
Low Level Functions
WESP Protocol
HD DVR
157
SD DVR
Video Server
IP Camera
NVR
WinRDS
WRS/WNS
WNS(WEBGATE Naming Service) is DDNS
service which changes IP address managed
by WRS server into domain name address. It
is required when a user wants to access the
unit from web browser instead of Control
Center.
All the WRS and WNS services are free to use
and both were developed and managed inhouse. This is why users do not need to worry
about sudden service discontinues or malfunctions. Moreover, these services are being
managed without a break in IDC (Internet
Data Center) to protect from power failure.
The administrator can confirm DVR’s DDNS
operating condition by accessing WNS server
as following figure.
158
Centralized Management Solution
Premium to your security
Mobile Solution : WebEye for iPhone, Android phone
DVRs
WebEye is customized App working on iOS and Android which can manage multi devices under mobile environment. DVR
or WinRDS can be registered and monitored or user can control PTZ too. System log to check system for power failure, HDD
failure and Event log to check alarm status are supported.
Supporting full frame image monitoring and if connected to HD DVR, user can check details of image from received HD level
high quality image through Digital Zoom function.
WESP SDK
Control Center
WinRDS / WinDVRs
IP Cameras
[ HD video’s digital zoom ]
1024 Units Management
Provides Simplified Integrated Solution through Unified Protocol Policy
This all solutions are provided in unified single protocol called WESP(WEBGATE Embedded Standard Protocol). WEBGATE had
been aware of how important it is to unify Protocol when WEBGATE started as IP camera expert and developed WESP which
is in-house unified protocol in early of 2000. All products from IP camera, NVR, SD DVR to HD DVR developed using WESP protocol can be managed under single software(Control Center). Newly developing products also will be unified using the same
software.
159
Control Center can manage Max. 1024 units
in one PC. By using “Distributed Connection
Management”, usage of CPU and network
bandwidth are minimized. Therefore allowing one PC to effectively control many units
in real time.
Network
Control
C
Contro
ontro
troll Center
Cent
Center
ter
160
Control Center Features
Control Center – Strong Central Management Software
Control Center is a strong central management software which can manage up to 1024 DVRs, and operator can
monitor up to 256 channels at the same time through up to 6 monitors. Control center is classified as Standard/
Pro/Enterprise version according to its function and performance. Also, each version has diverse functions for DVR
management, video monitoring, playback and alarm events.
Premium to your security
Supports Multi Monitor
Standard version supports maximum of 2 monitors and Pro version supports maximum 6 monitors to manage multi units
effectively in one PC. Quick and easy setup on each multi monitor can be done through Layout manager.
Also to maintain screen configuration preferred by user, it can memorize user’s configured screen configuration when power
off then restore it when starts.
Flexible High Performance Video Engine
Over 12 channels at 1080p 30fps stream can smoothly run with new high performance display engine. If PC suddenly lacks
resources because of other programs, software will automatically reduce frame rate of minimum channels for system stability.
And once PC gets stable, it will automatically recover its original frame rate.
Specialized functions for the large-scale monitoring system
DVR’s setting values and configuration information can be imported or exported. When using these functions, you can easily
configure a lot of DVRs. Control Center supports automatic restart after PC booting or abnormal close, and you can use Action
Log function which record DVR operating history. Also, it supports efficient system operation using dedicated Joystick controller, USB Joystick and others.
256 Channels Display via Auto Stream Selection
Control Center supports Max. 64 split-screen monitoring per monitor, Standard
version supports 128 channels monitoring via 2 monitors, Pro version support 256
channels monitoring via 4 monitors out of 6 monitors.
Auto Stream Selection function supports the most optimized full frame monitoring
during multi monitoring. This function, with the help of advantages of WEBGATE’s
products supporting multi streaming, selects stream automatically fitting screen division to avoid unnecessary network bandwidth or CPU consumption. For example,
when HD DVR is connected, HD video for single channel mode, small sized SD video
(D1, Half, CIF, etc.) for 16 split screen or smaller screen. This function works automatically, so user doesn’t need to select stream or wait for it.
161
Virtual Matrix Function
Enterprise version of Control Center has a feature to mange 51 PCs as 1 server and 50 clients. Server Control Center can control
screen of Client Control Center so user can monitor 3,000 channels and manage them throughout virtual matrix of 1024 x 51.
Server and Client Control Center share information so either connecting to any PC among 51ea PCs, user can work under same
screen configuration and unit information.
162
Control Center Features
Premium to your security
ViewSet : Virtualizing units by channel grouping
Status & Action Panel showing status of connected units in real time graphically
Viewset function is grouping function where user can select
preferring channels from multi units and it works as one of
unit virtualized with new name.
Control Center provides various features such as user’s own
editable screen configuration, Alarm popup together with
other channels included in viewset, sequence among viewset and so on.
This viewset features will be very useful for intensive monitoring on important spots selected by user.
Status & Action panel is managing tool to show multi unit’s status in real time. It can graphically show each unit’s status for
video connection, motion detection and alarm sensor. And also turn on relay, send voice warning message to make proper
response to the occurred events.
[ The way to 2ea ‘FLOOR’viewset by mixing 3ea DVR channels ]
Authority setup function per user
Control Center has user management function to limit feature on each user. Executing Control Center can be blocked by
password or specific program such as ‘setup’, ‘playback’ can be blocked per user.
Pro version has more detailed function such as saving layout per user or block specific unit access.
MD/No Video
Shows camera status of DVR as no-video or Motion Detection
Sensor Input
Show current status of sensor.
Relay Output
Shows status of relay or control it.
Talk
Audio transfer to selected or all units through PC mike.
Recording
Shows status if recording is going or if any problem in HDD.
Alarm Notify
Select not to receive alarm of units
Classified Map Function
Units can be managed in a unit of map by locating camera, sensor, mike and relay on the map. Monitoring video, controlling
relay or displaying all set of videos registered in the map can be supported. Icon will be flickering to inform user of event such
as MD, Sensor on, Relay on.
Moreover, Pro version supports sub-map or map link to support effective navigation feature among maps.
163
Diverse Event Management
If an event such as sensor alarm, motion detection was occurred, Control Center can provide diverse event actions like alarm
popup, buzzer, latch window, image save and recording. And also, if used Rule-Based Auto Action, you can program the series
of actions for a specific event and it helps efficient event management.
164
Control Center Features
Premium to your security
Integrated event management via Rule-based Auto Action
Keyboard shortcut and joystick keyboard support
When an event is triggered, user can set Control Center to make various actions such as image popup, warning sound (wav file
format) output, E-mail sending, warning window’s popup, move preset, quick record, save JPEG image and so on. Also, these
actions can be scheduled to be performed only during the specific time period. Pro version further allows these actions to
perform under definite rule or a scenario.
The most of functions can be set into keyboard shortcut for easy and fast control. Based on this method, using the customized
keyboard WKC-100 or USB joystick users will more directly select channels as well as control PTZ. With USB Jog/Shuttle, users
can even control playback speed if they desire.
ͮ"Ugngev"cevkqp"vq"rgthqto
yjgp"cncto"vtkiigtu0
Ͳ"Cevkqp"twng"ku"eqorngvgf0
[ Example for control PTZ from joystick ]
[Example for monitoring playback frame by frame using jog & shuttle]
Event Log Save/Search Function
ͱ"Ugv"rgthqtokpi"vkog"hqt"vjg"cevkqp0
ͯ"Ugngev"yjkej"cncto"ku"vq"dg"vtkiigt0
While Control Center is running, all the incoming event logs will be saved and managed in database. Users can search event
logs after selecting preferable condition and the result can be exported as a file, or related video can be played by directly
connecting the unit.
Ͱ"Ugv"vjg"fguetkrvkqp"qh"cncto"cevkqp0
[This picture is about how to make rule-based auto action for one of example that warning message of “Do not open the door”
output from DVR(DVR0) with speaker if there is someone opening the back door of office (Sensor No.1 of Full-HD DVR) at lunch time
(12 ~ 2 o’clock)]
This function is available with Control Center Pro version.
165
User Action Log Save/Search Function (Pro version)
Pro version not only saves events logs, but it also saves user’s Control Center usage. Allowing users to see who performed such
acts as playback/backup/close warning message to check if the operator followed the procedure.
166
Control Center Features
Premium to your security
Calendar/Timeline/Smart/Thumbnail/Text Search
Quick Recording
Control Center’s playback program provides various search features.
Through timeline search, users can see graphically what kind of events happened during certain time period and can move
to the desired time with ease.
Smart search enables user to see images only with motion in designated area set by user.
Thumbnail search allows users to check long video files with glance of an eye.
Users can also search for text data of POS/ATM and other facilities stored in DVR and bring back the videos of when the text
files were recorded.
User can make instant recording while monitoring through Control Center by clicking the right button of mouse.
Schedule Backup
Schedule backup runs through pre-set schedule which makes data of DVR, connected to Control Center, to be saved in PC’s
hard disks. It is possible to select unit, time to backup, channel individually, so users can effectively prepare a backup program.
Playback At-the-PC
HDD used in DVR can be connected to a PC through USB or eSATA port and user can achieve playback, search, backup from
the HDD through Control Center, whereas reading/writing on the HDD is impossible through Windows OS.
The feature will come in handy if DVR is damaged by intruder, and user needs to check the recorded video image. Simply install
the HDD from damaged DVR to a PC, then through Control Center, user can see video images and make backups if necessary.
This procedure only requires reading for HDD, so HDD will not have any affects when re-installed to the DVR.
In addition, if a full HDD backup is necessary, user can simply connect same or bigger HDD to a PC and use Control Center for
backup.
Select start/end
time of backup
data
Select DVR
Select file lacation,
storage period
and etc
167
Select channel
Select time to
achieve backup
168
Control Center Software
Premium to your security
MONITOR
Performance
Realtime Audio
Remote PTZ Control
Remote I/O Control
Save snapshot image
Quick Recording
Alarm Log Viewer, Save/Search Event List
Control Center (4.x)
Key Features
- Central Monitoring Software (CMS) supporting Max. 1024 units
- Consists of Monitoring, Playback, Setup Program and Utilities
- Max. 64 split-screen per monitor
- Management of multi monitors at a PC
(Std: 2, Pro:6, Ent: 4+50 Extended Monitor)
- Layered Map function
- Status & Action panel displaying statuses of connected units
- Rule based Auto Action (Pro, Ent)
- User’s Action Log Save/Search function (Pro, Ent)
- Auto backup of DVR via Schedule Backup function
- Remote login to other Control Center to share unit information (Ent)
- Supports all WEBGATE products including IP camera, NVR, DVR, Software
- High-performance video engine displaying 12 Full-HD video streams in realtime
- Calendar, Timeline, Event, Text, Smart, Thumbnail search support
- Composition of user-defined split-screen via Viewset
- Alarm Pop-up / Sequence switching function
- User-specific permission settings
- Event Log Save / Search Function
- USB or dedicated Joystick Keyboard (WKC-100) support (Pro, Ent)
- Playback/Search/Backup/Copy from a HDD that was removed from DVR
Specifications
Control Center Standard
Control Center Professional
Control Center Enterprise
1024
2
1024
6
1024
4+50 External Monitor
GENERAL
Maximum # of Units
Maximum # of Monitors (Views)
Maximum # of Supported Split-Screen
1/4/9/13/26/25/36/49/64
1/4/9/13/26/25/36/49/64
1/4/9/13/26/25/36/49/64
H/W Support
WebEye
i-Rec
HD DVR series
LH/EH/MH DVR series
MD DVR Series
DS DVR series
MPEG-4 WebEye Series
NVS04S
WinDVrS
WinRDS
WebEye
i-Rec
HD DVR series
LH/EH/MH DVR series
MD DVR Series
DS DVR series
MPEG-4 WebEye Series
NVS04S
WinDVrS
WinRDS
Video Format
Audio Format
H.264/MPEG4/JPEG
ADPCM/Truespeech/G.723
User Management
Yes
H.264/MPEG4/JPEG
ADPCM/Truespeech/G.723
Yes
Unit allocation to manage
Monitor allocation to manage
2
WebEye
i-Rec
HD DVR series
LH/EH/MH DVR series
MD DVR Series
DS DVR series
MPEG-4 WebEye Series
NVS04S
WinDVrS
WinRDS
H.264/MPEG4/JPEG
ADPCM/Truespeech/G.723
Yes
Unit allocation to manage
Monitor allocation to manage
2
Account level
2
Max account
100
100
100
WNS (DDNS)
Yes
Yes
Yes
WRS (Dynamic IP Registration Service)
Yes
Yes
Yes
169
Control Center Standard
Control Center Professional
Control Center Enterprise
8 HD 1080p30
Yes
Yes
Yes
Yes
Yes
Yes
12 HD 1080p30
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Alarm Popup, Buzzer, Latch Window, Relay,
e-Mail, Preset, Recording, Save Image
Yes
Yes
Items of errors to be managed are
selectable freely
12 HD 1080p30 / PC
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Alarm Popup, Buzzer, Latch Window, Relay,
e-Mail, Preset, Recording, Save Image
Yes
Yes
Items of errors to be managed are
selectable freely
Yes
User action, auto action
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Section, Sub Map, Map Link
Yes
Auto Action
Yes
Alarm Popup, Buzzer
Rule based auto action
No
Error Management
(Latch function)
No
Action Log
No
Log Save
Status Viewer
Auto Connection (Lost & Recovery)
Watermark
Keyboard Shortcuts
Joystick Interface (WKC-100)
Viewset (group)
Yes
Yes
Yes
Yes
No
No
Yes
Map
Yes
Remote Login
PLAYBACK
Playback
Backup (re4, avi)
Log Viewer
Timeline display (log)Timeline index search
Go to a certain timeCalendar search
Playback event image
Speed playback(0.5 ~ 64x)
Smart Search
Thumbnail Search
Text Search
Snapshot / print
Zoom in/out image, Brightness/Contrast
Audio play
Fix Layout
UTILITIES
Web Viewer
Schedule Backup
System Requirement
No
Yes
User action, auto action
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Section, Sub Map, Map Link
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Intel Core i5 3GHz
4GB of RAM
500GB HDD
1024MB PCI-E Graphic Card
Support AGP Accelate
100/1000 Ethernet NIC
Sound Card
WinXP/Win7/Win8
Intel Core i7 3.4GHz
8GB of RAM
500GB HDD
Radeon 1024MB PCI-E Graphic Cards
Support AGP Accelate
Support PCI-E 2.0 16x or higher
100/1000 Ethernet NIC
Sound Card
WinXP/Win7/Win8
Recommended
Intel Core i7 3.4GHz
8GB of RAM
500GB HDD
Radeon 1024MB PCI-E Graphic Cards
Support AGP Accelate
Support PCI-E 2.0 16x or higher
100/1000 Ethernet NIC
Sound Card
WinXP/Win7/Win8
170
Video Streaming Software
Premium to your security
Specifications
WinRDS (Windows ReDistribution Server)
- Max. 512 video stream distribution to users (up to 500Mbps)
RE-DISTRIBUTE
Maximum number of input stream
(Channels)
Supported Device
Max. number of input streams per video
resolution (Unit : Stream)
Max. number of output streams per
video resolution (Unit : Stream)
Multi-Streams per Channel
- Authority Management of DVR access and channel control based on user account
Network
More than 1Gbit
Unit/Channel name transmission
Support
Remote Software
Control Center Standard / Pro / Enterprise
Key Features
- Streaming Server to Re-Distribute DVR video stream to multi Users
- Max. 100 Users registration
- Max. 512 video stream input from DVRs (up to 500Mbps)
Scenario 1.
512 Channels
DVR
512(CIF 7fps) / 250(CIF 30fps) / 170(D1 15fps) / 140(720p 15fps) / 80(1080p 15fps)
Up to 500Mbps
512(CIF 7fps) / 250(CIF 30fps) / 170(D1 15fps) / 140(720p 15fps) / 80(1080p 15fps)
Up to 500Mbps
Support
Android : WebEye 2.0 or higher
Multiple users want to get full-frame video image from DVR
iPhone : WebEye 2.4 or higher
DVR
CMS
CMS
DVR
CMS
WinRDS
DVR
MANAGEMENT
Management Program
Max. number of user registration
Control Center Configuration Tool
100 Users
DVR Auto-detection in Local network
Supported
Batch registration of auto-detected DVRs Supported
Authority management of DVR
Monitoring / Search / PTZ / Relay / Mic / Backup
Authority management of each Channel Monitoirng / Search / Backup
Authority’s batch registration of multi users
Support
PLAYBACK
Playback
Backup
Support
Issue of serial number to the individual users
ETC.
Watch-Dog
License
Support
Issue of serial number to the individual users
PC SPEC. RECOMMENDATION
CPU
Memory
Intel i7-870 CPU @2.93GHz or higher
4GB RAM
HDD Capacity
1TB or more
Network Interface Card
PCI-E Gigabit Ethernet NIC card x 2EA
CMS
DVR
CMS
PC User
PC User
DVR
Mobile User
WinRDS
Mobile User
Mobile User
171
Scenario 2."
Users want to distribute DVR video image to unspecified individuals
through public website
172
Mobile Application Software
Premium to your security
Specifications
iOS
Android
iPhone 3GS/4G, iPhone 5G, iPod Touch 3G/4G, iPad, iPad2
iOS 4.2 or higher
HD DVR series
MH/EH/LH DVR series
MD DVR series
WinRDS
All Android Phones
Android 2.3 or higher
HD DVR series
MH/EH/LH DVR series
MD DVR series
WinRDS
List Manager
Address
Add, Remove, Modify, Rearrange
IP, URL(DNS/DDNS), WRS
Add, Remove, Modify, Rearrange
IP, URL (DNS/DDNS), WRS
Port
Support
Support
ID/Password
Support
Support
Discovery
VIDEO INPUT
TCP, WRS (up to 16)
TCP, WRS (up to 20)
- Single/Quad screen monitoring
Protocol
Standard
WESP
NTSC, PAL, HD
WESP
NTSC, PAL, HD
- Video streaming up to 30fps
Resolution
QCIF, CIF, HALF, D1, 720p, 1080p
QCIF, CIF, HALF, D1, 720p, 1080p
- Supports PTZ control
Compression
JPEG, H.264
JPEG, H.264
- Supports D-Zoom of HD video
VIDEO DISPLAY
- Unit status by searching system log
Division
Single or Quad
Single or Quad
- Unit status check by searching System log
Frame rate
MAX CIF 30, Half 20, D1 7, 720P 4, 1080P 1, JPEG 1 fps (It depends on network)
- Alarm history check by searching Event log
DIGITAL ZOOM
SUPPORT
H/W
OS
WebEye
Device
SERVER
Key Features
- Mobile Viewer for iPhone / Android phone
- Supports HD/MH/EH/LH DVR series
- Max. 16 DVR Support
- Capable to connect a unit that has dynamic IP
- Supports QCIF/CIF/Half/D1/720p/1080p resolutions
Support
Thumbnail View
4X
-
4X
Support
CGI call
Zoom In/Out, Tilt Up/Down, Pan Left/Right
WESP
Zoom In/Out, Tilt Up/Down, Pan Left/Right
Type
Protocol
System Log, Event Log
WESP
System Log, Event Log
WESP
Search
Date (Event Log - Date + Time)
Date
System log filter
Nothing
Status&Action
”CH Pre Alarm Start“, “CH Post Alarm Stop”,
“CH Recording Start”, “CH Recording Stop”,
“Manual Recording Start”, “Manual Recording Stop”,
“Unknown Code”
Nothing
Status&Action
”CH Pre Alarm Start“, “CH Post Alarm Stop”,
“CH Recording Start”, “CH Recording Stop”,
“Manual Recording Start”, “Manual Recording Stop”,
“Unknown Code”
Text
”Text Input”
Text
”Text Input”
Motion
”Motion Detected”, “MD Off”
Motion
”Motion Detected”, “MD Off”
Alarm
”Sensor On”, “Sensor Off”, “CH Network Event On”,
”CH Network Event Off”, “CH Site Connected”,
”CH Site Disconnected”, “CH Site Disconnected(Cont.)”,
”CH No Video”, “CH Video Detected”, “Bookmark”
Up to 1000
Alarm
”Sensor On”, “Sensor Off”, “CH Network Event On”,
”CH Network Event Off”, “CH Site Connected”,
”CH Site Disconnected”, “CH Site Disconnected(Cont.)”,
”CH No Video”, “CH Video Detected”, “Bookmark”
Up to 1000
PTZ
Screen Shots
Protocol
Command
LOG
Event log filter
Limitied
173
174
Solution
Guides
Hotel & Leisure
Game & Casino
Bank
Transportation
Industry
Public & Education
Retail
WEBGATE Solution Guides
Premium to your security
Hotel & Leisure
Game & Casino
Prevents any negligent accidents of customers and employees as well as protect the important equipment in hotel or its facility.
With real-time monitoring and HDTV level video recording without delay, customers are provided with a comfortable environogpv"yjgtg"vjg{"ecp"hggn"uchg0
Reliable management of entrance histories through
differentiated high-definition recording
Prevention of cheating through differentiated
high-definition and real-time recording
Safe custody of recording data through
high-capacity storage and mirroring function
- Video recording of maximum 30 frames/second at 1920 x 1080 image size
without delay time
- Monitoring of cheating by customers and dealers, and provision of optimal
corroborative facts in case of an accident
- Minimizes unnecessary frictions with customers
- Provision of an external storage interface of maximum 128TB per a HD-SDI DVR
- Safe custody of data via mirroring recording method
- Provision of perfect measures against troubles in the storage media
- Provides high resolution records of HD video image data to identify visitors
- Simple entrance search using date/time, thumbnail or smart search
Minimization of factors for a friction with customers
- High-definition parking lot monitoring
- Recognition of leaving/entering car number plates and conditions
- High-density recording of lobby situation and customer receptions
Prevention of negligent accidents through
the efficient monitoring of dangerous areas
- 6 times better video resolution than conventional analog video system with
HD1080p camera
- 3 times wider viewing angle than conventional analog video system with
HD1080p camera
- Effectively monitor elevator, indoor/outdoor swimming pools and restrict areas
177
High-density Internet P.R. of the views around the
hotel and resort, weather, etc.
- Real-time high-definition video P.R. of hotels and resorts via the Internet homepage
- Securing video clips for tourism and P.R. sites
Establishment of a large-scale system using HD-SDI
matrix and CMS
- Decentralized video record processing by HD-SDI DVRs
- Provides integrated solution by HD-SDI matrix and/or provides network
integration by CMS
178
WEBGATE Solution Guides
Premium to your security
Bank
Transportation
Protects your precious financial assets from various crimes through wide monitoring and HDTV class video recording.
Monitoring road traffic and protect the safety of passengers and crew at airport, harbor and railway.
Thorough recording of visitors through differentiated
high-definition video
Reliable prevention of robbery, cheating and
provides the corroborative facts
- 3 times wider viewing angle than conventional analog camera with HD1080p
- Reliable recording of customer movement, and provision of high-definition
- Recording of maximum 30 frames per second at 1920 x 1080 resolution
- Prevention of a dispute with customers and employees
Clear recording of customer face through applying a
HD camera to the ATM
Integration of DVRs using a CMS
- 6 times better resolution than conventional analog camera with HD1080p camera
- Provision of a perfect solution compared to the existing CCTV recorded image
in which face recognition was unclear
- Provides the perfect solution against unclear face recording result of SD system
Safe custody of recording data through high-capacity
storage and its mirroring function
- Saves recorded data over 6 months worth
- Provides perfect measure against a trouble of storage media through dispersed
storage, mirroring, backup, etc.
179
- Integrated control and real-time remote monitoring of dispersed DVRs at each
branch
- Prior prevention of unjust data operation by using a Radius function
Monitoring the waiting room and facility of airport,
harbor and railway, using more wider view and clear
- Search for suspicious people and monitor their actions
- Automatic recognition of persons on the blacklist through interlocking with
face recognition system
- Monitoring of robbery case and damage of important facilities such as roads,
airports, harbor, etc.
Monitoring of a real-time traffic situation
/"Nqpi/fkuvcpeg"vtcpuokuukqp"qh"jkij/fghkpkvkqp"xkfgq"vq"eqpvtqn"egpvgt"
vjtqwij"hkdgt/qrvke"ecdng
/"Fgvckngf"eqphktocvkqp"qh"ceekfgpv"eqpvgpvu"d{"wukpi"cp"cwvq/hqewu"RV\"
ecogtc
Perfect identification of unjust passengers and
provision of corroborative facts
- Ticket gate at railway station and subway station
- Monitors any violence in a bus and provides the best recorded video image
Excellent recognition rate of car license plate by high
definition image
- Monitors any illegal parking
- Checks entering/leaving vehicles in parking lot
180
WEBGATE Solution Guides
Premium to your security
Industry
Retail
Through high-definition and real-time monitoring methods, prevents future hazards in dangerous facilities.
With the same design and installation method as the existing ones, you can still get HDTV class monitoring and its recorded
video images with simple DVR operation.
Provides optimal monitoring solution for important
facilities
- Regulates intruders from hydro, thermal or nuclear power plants
- Protects power plant, factory, warehouse or building’s facilities
Monitoring of a civil or architectural construction site
- Theft prevention of raw and subsidiary materials and the damage to facilities
- Monitoring in all directions of 360° by using wide angle and auto-focus PTZ
camera
- Remote monitoring of the construction progress situation at a site
Monitoring the operation condition of important
equipment
Process control of a factory or plant
- Remote monitoring of operation condition, and real-time checking through
iPhone or Android Phone
- Can provide corroborative facts about control responsibility by using a reliable
high-definition recorded image
- Process monitoring by using high-definition and real-time transmission
- Real-time monitoring and alarming of dangerous equipment in petroleum and
chemical plant, etc.
- Detects possible accident risks to prevent workers and equipment
181
Provision of the same design and installation method
as the existing analog CCTV design
Efficient store management through interface with
POS system
/"Pq"pggf"qh"eqornkecvgf"pgvyqtm"eqphkiwtcvkqp"cpf"ugvwr
/"Rtqxkfgu"c"oqpkvqtkpi"ogvjqf"{qw"ctg"cntgcf{"hcoknkct"ykvj
/"Okpkok|g"wppgeguuct{"htkevkqpu"ykvj"ewuvqogtu
/"Rquukdknkv{"qh"rtqxkfkpi"eqttqdqtcvkxg"hcevu"cdqwv"gzcev"oqpg{"tgegkrv"
cpf"fkudwtugogpvu
Configuration of a full-embedded system
guaranteeing reliability
/"Pqv"pgeguuct{"qh"uqhvyctg"kpuvcnncvkqp"qt"eqornkecvgf"qrgtcvkqp
/"Vtqwdng/htgg"godgffgf"rtqfwevu
Simple monitoring, recording and playback method
without needing a PC
Improvement of store service
/"Tgcn/vkog"oqpkvqtkpi"qh"uvqtg"vjtqwij"kRjqpg"qt"Cpftqkf"Rjqpg
/"Ejgemkpi"vjg"fkurnc{"eqpfkvkqpu"qh"ogtejcpfkug."cpf"uwurkekqwu"
ewuvqogtu"vq"rtgxgpv"tqddgt{
/"Fq"pqv"pggf"eqornkecvgf"ugvwru"hqt"qrgtcvkqp
/"Ukorng"FXT"qrgtcvkqp"ykvj"htqpv"dwvvqpu"qt"oqwug"enkem
182
WEBGATE Solution Guides
Public & Education
With wide viewing angle and high-definition video images, we provide optimal solution to manage public facilities and juvenile
crimes that may occur at school.
Premium to your security
Provision of a perfect urban crime prevention
solution
- Monitors vehicle movement by number plate recognition and particular
region using high-definition video
- Interlocking with an emergency bell system
- Integration of a wide area crime prevention system using the CMS
Monitoring of a downtown park
- Monitoring of illegal activities in a park
School zone monitoring
- Searches for suspicious people around elementary schools and report them
to a police station
- Provides countermeasures against illegal intruder into a school
- Provision of the optimal solution to prevent juvenile crimes in school through
wide-angle surveillance and high quality video
Real-time monitoring of cultural assets and
advertisement of tourism through Internet
- Real-time and high-definition monitoring of major national cultural assets
- Prevention of damage to cultural assets by suspicious persons, and provides
reliable evidence
- Prevents damages to cultural assets from suspicious people and provides
reliable evidence
183
184
INSTALLATION
CASE
HD-CCTV
Installation Cases
Resort
Hotel
Racecourse Park
Power Station
City Surveillance
Remodeling of Department Store
Recognition of License Plate
HD-CCTV Installation Cases
Resort
Premium to your security
Purpose
· To incorporate optimal video surveillance system to increase the efficiency in work and prevent accidents
· Protection of customers and facilities by installing high quality CCTV camera
· By using storage system and NMS(Network Management System) program, each department can monitor necessary scene
using GUI(Graphic User Interface) client program. The system provides real-time monitoring through VPN network when an
accident occurred
Results
· Provided the best Full-HD video surveillance system to prevent crime and protect facilities
· Stable and high quality video can provide obvious evidences for any conflicts between customers
· Provided real-time monitoring surveillance capabilities to security personnel throughout the resort
Installed Product List
Installation Place
· Installation case of large scale resort composed of 32 floor building (4 below, 28 above)
· Resort facilities have 516 rooms, water park, 8 convention halls, wedding center and restaurants
187
1SPEVDUT
2UZ
$%"')%%PNF$BNFSB
$#.)%#PY$BNFSB
$15;)%94QFFEEPNF$BNFSB
0154%*593464%*5P0QUJD
0154%*394%*5P0QUJD
)%)DI)%%73
5#Y&"
.))DI%%73
5#Y&"
ⲳ-&%'VMM)%.POJUPS
ⲳ-&%'VMM)%.POJUPS
$POUSPM$FOUFS1SP
$POUSPM$FOUFS4UBOEBSE
8JO3%4
188
HD-CCTV Installation Cases
Configuration
Premium to your security
HD-SDI video’s long distance transmission using optical cable
Because cameras were scattered all around the resort, the most of HD-SDI video transmission was done with optic cables.
· Camera’s HD-SDI video signal has been transferred to optic transmitter via coaxial cable, and the transmitter converts the HDSDI signal to optic and delivered the signal to the monitoring room.
· Also, optic receiver converts the incoming optic signals to HD-SDI and delivered to the DVR.
1
2
1
1
OPT-TX4-RS485U
1
Camera
Wall-Mount FDF
Location : 10 floors in the building
4
Location : Monitoring room in the 1st floor of building
DVR
1
1
1
1
3
OPT-TX16-RS485U
Rack-Mount FDF
2
189
190
HD-CCTV Installation Cases
/P
%FTDSJQUJPO
ⴗ
)%4%*$PBYJBM$BCMF
ⴘ
$PSF4JOHMF.PEF'JCFS0QUJD$BCMF
ⴙ
1JHUBJMDBCMFGPSDPOOFDUJOHXJUIPVUEPPS'JCFS0QUJD$BCMF
ⴚ
0VUEPPS$PSF'JCFS0QUJD$BCMF
Premium to your security
3FNBSLT
DVR #n
LAN
LAN
Network
LAN
Network
WinRDS
Control Center Pro
LAN
Client #3
LAN
Integrated video surveillance system using Control Center Pro
Control Center Pro was used to the video surveillance system design. Control Center Pro has additional functions compared
to Control Center Standard such as (1) up to 6 monitors support (2) Joystick controller interface (3) diverse actions for events
and etc.
· System was designed for a WKC-100(Joystick Controller) to control DVR and PTZ via Control Center Pro.
· Control Center Pro accommodates maximum of 6 monitors. In this case, 4 large LED monitors(42”) are connected to Control
Center Pro and supports simultaneous 256 video channel monitoring.
· In order to efficiently monitor more than 300 cameras, Control Center’s grouping function, ViewSet, has been used. Security
personnel can easily place the grouped cameras’ display to a monitor’s split screen.
· Also, alarm pop-up has been incorporated with map function for direct and intuitive monitoring.
Client #2
LAN
Client #4
LAN
Client #1
RS232
Client #5
Video distribution solution using WinRDS
To preserve the recording performance of DVR, WinRDS was incorporated to support multi-monitoring from different locations simultaneously.
· In WinRDS installed PC, two network cards are inserted to separate the DVR network from client network and to reduce the
network overload.
· There are total of 5 fixed Control Center clients. Different monitoring channel access authorities were given to security
personnel to perform remote monitoring via Control Center and mobile phone.
191
192
HD-CCTV Installation Cases
Hotel
Installation place
· Installation case of Luxury 5 star hotel composed of 20 floors
· 377 rooms including 34 suite rooms, grand ballroom accommodating 450 people, banquet hall of diverse size, fitness club,
swimming pool, sauna, business center and wedding halls
Premium to your security
Installed Product List
1SPEVDUT
2UZ
$%"')%%PNF$BNFSB
$#.)%#PY$BNFSB
$15;)%94QFFEEPNF$BNFSB
0154%*59394%*UP0QUJD
0154%*5943944%*345P0QUJD
015&954%*UP0QUJD$)&95&/%&3
)%)DI)%%73
5#Y&"
.))DI%%73
5#Y&"
$POUSPM$FOUFS1SP
$POUSPM$FOUFS4UBOEBSE
8JO3%4
Configuration
Purpose and results
· Because the conventional SD-class analog camera provided very unclear video image which can not identify even the face
of visitors. The hotel requested a solution to provide higher resolution and wider angle of view even using a single camera
· Full-HD high resolution and seamless video monitoring without frame drop
· Stable 30FPS monitoring and recording for important places like hotel lobby, entrance of parking lot
· Facility management department and security department are provided with the necessary video at their desk and mobile
phone
193
194
HD-CCTV Installation Cases
Resort
Premium to your security
Installed Product List
1SPEVDUT
$%"')%%PNF$BNFSB
$#.)%#PY$BNFSB
$15;)%94QFFEEPNF$BNFSB
0154%*59394%*UP0QUJD
0154%*5943944%*345P0QUJD
015&954%*UP0QUJD$)&95&/%&3
)%)DI)%%73
5#Y&"
$POUSPM$FOUFS1SP
$POUSPM$FOUFS4UBOEBSE
8JO3%4
2UZ
Configuration
(A condominium building)
Installation place
· Large scale resort complex. It has 4 condominium buildings composed of 683 rooms, luxury village buildings, hotel, golf
courses and etc.
· Additional facilities such as diverse restaurants, Teddy bear museum, recreational facilities and Aqua world
Result
· Full-HD video’s optical transmission to get reliability of video data
· High definition video and wider monitoring angle which could not be supported by analog cameras
· Efficient video surveillance by real-time PTZ control without delay
· Full-frame monitoring of important areas and high quality video distribution to security guards
195
196
HD-CCTV Installation Cases
Racecourse Park
Premium to your security
Power Station
Installation place and purpose
Installation place and purpose
· A racecourse park opening total 782 races throughout 94 days in a year with about 980 horses
· Because much prize money is provided through a horse race, securing the clear full-frame video data was crucial
· 5 power stations, and their construction sites
· Main key facilities which supply energy to nation. so, These sites required strict surveillance for the security
Results
Results
· Provided the best quality and lossless full-frame video monitoring and recording
· Provided the perfect still image owing to camera’s Anti-motion blur function, and this is used to check the race ranking
· In order to discriminate the horse that passed the finish line first, system used WEBGATE DVR’s step forward/reverse playback
function
· In order to support user’s easy operating, USB jog shuttle was interfaced with WEBGATE’s CMS, Control Center Pro.
Installed products
· Box camera, C1080B which supports Anti-Motion Blur function
· 8ch Full-HD HD-SDI DVR, HD800H
· Jog Shuttle interface to Control Center Pro
197
· Monitors operating condition of major equipment
· 360° all-around video surveillance using 20x outdoor speed dome camera
· Working together with video analytics system to detect intruder on fence and smoke detection
· Clear and seamless high definition video provided monitoring of materials theft at power plant’s construction site, and
monitoring of construction progress
Installed products
· 20x outdoor speed dome camera, C1080PT-Z20
· 8ch Full-HD HD-SDI DVR, HD800H
· HD DVR dedicated external storage to keep 6 months recording data, NVS04R
· Control Center Pro and Joystick controller WKC-100
198
HD-CCTV Installation Cases
Premium to your security
City Surveillance
Remodeling of department store
Traffic Monitoring
Installation place and purpose
School zone
· Total 90 places for city surveillance
· School zones and crime concern
places
· Provided high-definition video
monitoring and still image.
Considered about integration with
existing CCTV system, easy operation
and management
Installation place and purpose
· A department store opened in 2006
· Video from more than 100 analog cameras are transmitted to central monitoring room through coaxial cables, and video
monitoring/recording was executed by PC-based DVR
· Because the existing CCTV system was superannuated, system replacement was necessary
Results
Results
· Improved the monitoring efficiency by wide monitoring angle (Security function and license plate recognition were
performed by same camera)
· Monitoring and recording of all vehicle’s city entry and exit. Quick identification when an accident occurred
· Crackdown of lawless vehicle inside school zone
· Reuse of existing coaxial cables
· Provided lossless Full-HD video with real-time without video latency
· Department store’s CCTV operators who do not have enough knowledge about network was able to manage the new HDCCTV system by same operation and management method with existing system
· As a result of system upgrade, enhanced the video monitoring quality for parking lot monitoring, theft prevention and
frictions with customers
Installed products
Installed products
· Box cameras of C1080B, C1080BM which support Anti-motion blur function
· 8ch Full-HD HD-SDI DVR, HD800H
· Network system integration based on Control Center software
· Existing camera’s alternate product, Box camera C1080BM and Dome camera C1080D
· 16ch Full-HD HD-SDI DVR, HD1600M
· Network video monitoring through Control Center
199
200
HD-CCTV Installation Cases
Premium to your security
Recognition of license plate
Installation place and purpose
· A Pay Tunnel’s management agency wanted to record the vehicle license plate for those who passed the tollgate in high
speed without paying and make them pay fines
· They requested camera, illuminator and recorder solution which can provide clear number plate image of high-speed
vehicle’s number plate even at night
· They needed solution for 10 tollbooth and each recorder should keep the recorded video data more than one year
Results
· WEBGATE successfully passed the readability test with IR illuminator integrated HD-SDI camera. (DIRC-1080BL)
· The test was executed at night time for diverse cars which are moving at speeds higher than 80Km
· By interfacing external storages(NVS04R) with 8-channel HD DVR(HD800H), WEBGATE was able to provide 1 year recording
solution to the tunnel management agency
Installed products
· IR illuminator integrated HD-SDI camera (DIRC-1080BL)
· 8ch Full-HD HD-SDI DVR, HD800H
· HD DVR dedicated external storage, NVS04R
201
202
01 JF/EEVX"u{uvgo"cpf"JF/UFK"vtcpuokuukqp"ogvjqf
02 JF/EEVXʋu"Hgcvwtgu"cpf"Cfxcpvcigu
03 Cdqwv"JF/UFK"Ecdng
04 Ngikdknkv{"qh"JF/UFK"\qqo"Ecogtc
05 Kpvtqfwevkqp"qh"vjg"JFeevx"Cnnkcpeg
HD-CCTV SYSTEM
01
)%$$57TZTUFNBOE)%4%*USBOTNJTTJPONFUIPE
Premium to your security
HD class video quality as the biggest issue in the CCTV market
HD-SDI transmission method used in HD-CCTV system
Recently the biggest issue in CCTV market can be said to be the high resolution application of HD or Megapixel class more
than anything else. Not simply enhancing the camera’s video quality, but the change of resolution from the existing SD(720x480:NTSC) class to HD(1920x1080:HD1080p) class requires a change in the whole system. In the HDTV era, high definition and
high visibility were required in the market, but the SD class(NTSC/PAL) image was not enough to meet the requirement due to
its limitation in resolution. The market requirement for high definition started to be applied to the CCTV market in a Megapixel
IP camera type along with the development of a HD class image sensor at a reasonable price, and recently HD-SDI transmission technology was grafted on the CCTV market, starting to be introduced as a product group of HD-CCTV.
HD-SDI is a standard specification to transmit video between HD class broadcasting systems. HD-SDI is the abbreviation of
High Definition Serial Digital Interface, which means the method to convert video signal into serial video data and transmit
it through a coaxial cable without compressing it. HD-SDI was standardized by SMPTE, which describes all the contents of
electric interfaces, data formats, auxiliary data and video formats. The feature of HD-SDI transmission method is that because it
transmits video as digital signal, it does not make degradation of video quality within a distance where data are not lost. It can
transmit audio and control signals as well as images, and it seems that it will be able to supply power in the future.
The HD-SDI transmission method is basically different from SD class transmission method. As shown in the table below. Although they use the same coaxial cable, but there is big difference that SD class video is using the analog transmission method
and HD-SDI is using the digital transmission method. In addition, the HD-SDI transmission method is one of the SDI transmission methods, which can transmit video up to 1080p30. This is defined in SMPTE 292M, which uses 1.485 Gb/s transmission
data quantity and 750MHz transmission frequency.
Introduction of HD-SDI transmission technology
In order to adopt HD class video into CCTV system, HD-SDI transmission technology and dedicated chip solutions were introduced in the security market. Because HD-SDI is easy to understand and easy to use, it provided easy way to build the HD
surveillance system. Moreover, because this technology was already verified in the broadcasting market, it can be said that
HD-SDI surveillance systems already have the reliability.
HD-CCTV as a HD system?
In here, we want to define a CCTV to transmit the SD class
video through a coaxial cable as the SD-CCTV, and a CCTV
to transmit the HD class video through a coaxial cable using HD-SDI transmission method as the HD-CCTV. This is
because the HD-SDI transmission method was developed as
the most suitable transmission method to transmit the HD
class video without degradation of video quality, being used
as the standard transmission method between broadcasting systems for HDTV system. Now, the high definition video security market is expected to develop into a new shape
through competition and fusion between the HD-CCTV market and the IP market.
205
4%$$57
4%*USBOTNJTTJPONFUIPE
4%)%*
)%4%*
(4%*
4JHOBMUZQF
"OBMPHVF
%JHJUBM
%JHJUBM
%JHJUBM
4UBOEBSE
/54$1"-4&$".
4.15&.
4.15&.
4.15&.
%BUBUSBOTNJTTJPOWPMVNF
9
.CT
(CT
(CT
5SBOTNJTTJPOGSFRVFODZ
9
.)[
"CPVU.)[
"CPVU()[
.BYSFTPMVUJPO
YJPSYJ
Y!J
JQ
Q
HD-SDI : A technology to transmit HD video digitally through a coaxial cable without compressing it.
HD-CCTV, HDcctv, HD-SDI terminology
HD-SDI : Technology to transmit HD video digitally through a coaxial cable without compression
HD-CCTV : HD class video CCTV system realized by using HD-SDI transmission method
HDcctv : HD-CCTV assured its specifications and performance by HDcctv Alliance
206
HD-CCTV SYSTEM
01
)%$$57TZTUFNBOE)%4%*USBOTNJTTJPONFUIPE
Example of HD-CCTV system configuration
Premium to your security
What is the weak point of the HD-CCTV system?
The figure below is an example of using a HD-SDI transmission method, showing that various types of cameras are connected
with a HD-SDI DVR using the HD-SDI transmission technology to realize the system. In here, HD-SDI cameras, repeaters, DVRs,
etc. were used. A repeater can be used in the middle of a line to extend the transmission distance of the HD-SDI signal, and the
existing SD camera’s video signal can be changed to the HD-SDI signal through a converter.
Short transmission distance?
The transmission distance of existing SD-CCTV is 300m or more when using a coaxial cable. The transmission distance of HD-SDI is about
150m~200m when using a coaxial cable exclusive for the HD-SDI. Of course, there may be a little difference depending on quality of coaxial
cables. Even using the existing coaxial cable can transmit video at least 100m. For your reference, the transmission distance of the UTP cable(CAT5,6) for network communication is about 100m, and accordingly, the transmission distance may not be a weak point. In addition, using a
commercialized HD-SDI repeater or optical transmission converter can extend the transmission distance as much as one likes.
Remote monitoring(network) is impossible?
HD-SDI camera can be networked through a DVR or video server, so there is no problem in integration through a network. Users can also
monitor the HD video with their smart phones with the service provided through DVR. In security market, connection of camera to a storage
device(DVR) is essential, and this is why network monitoring is possible without any additional equipment.
Full-HD 1080p resolution is enough?
Full-HD video has 6 times better resolution than SD, but considering the aspect that SD camera’s video quality is deteriorated through analog
signal transmission and the degradation of still image due to interlace scanning at image sensor (composed of a field of image frame taken at
two different times), the video quality difference between SD class and HD class exceeds the 6 times difference by far. In addition, realistically
most of the monitoring equipment(HDTV, LCD monitor, etc.) has the 1920x1080 resolution. The HDTV broadcasting also uses the 1920x1080
screen size, so you can do monitoring HD resolution at the most competitive price. Now, considering the reality that HDTVs are supplied in
a full scale just worldwide, the Full-HD 1080p resolution is expected to become the most competitive resolution for a considerable period.
Feature comparison of HD-CCTV system
The following table summarizes the differences between HD-CCTV, SD-CCTV and IP based system. In example, HD-CCTV
shows that the camera image can be recorded without being affected by network errors because the the most important part
of video transmission is using coaxial cable. This is just one of the key factors in the security system.
1BUIXBZUP*1/FUXPSL
3FDPSEJOH*NNVOFUP*1-"/'BJMVSF
8PSLTXJUI&YJTUJOH$PBY
-PDBM4JUF-JWF7JFX*NNVOFUP*1-"/'BJMVSF
/FBS;FSP-BUFODZ
$PNQSFIFOTJWF(MPCBM*OUFSGBDF4UBOEBSE
(VBSBOUFFE1MVHBOE1MBZ
%JHJUBM
%FMJWFSTPS7JEFP
%FMJWFSTGVMMGSBNFSBUF)%57
$PNNJTTJPOFE$PTUQFS7JEFP$IBOOFM
%FMJWFST.17JEFP
207
)%$$57)%4%*
5SBOTNJTTJPONFUIPE
$$57
.1*1$BNFSB
%73PS4USFBNFS
%73PS4USFBNFS
/73PS3PVUFS
:FT
:FT
6TVBMMZ/PU
:FT
:FT
/FFET"EBQUPS
:FT
:FT
/P
:FT
:FT
/P
:FT
:FT
/P
:FT
:FT
/P
6ODPNQSFTTFE
/P
$PNQSFTTFE
6ODPNQSFTTFE
/P
$PNQSFTTFE
6ODPNQSFTTFE
/P
/P
.FEJVN
-PX
)JHI
1MBOOFE
/P
$PNQSFTTFE
Prospect of HD-CCTV system
The request for HD-CCTV by the users already accustomed to high video quality of HDTV are considered very natural and
expected. Price can be a burden but it is expected to approach the customer required level in near future.
The HD-CCTV system introduced for the first time in 2009, started to be released in a full scale from 2012. According to IMS
research published in 2013, HD-CCTV will have full-scale growth from 2013 and will have average 64% growth rate to 2017,
and expected to have 1.4 billion market share. It seems that a number of sites requiring the high resolution such as important
facilities, banking sectors, etc. will be changed into the HD-CCTV during this period. With previous experiences of SD-CCTV
system design, installation, management, we are able to easily maneuver HD-CCTV products. We can operate small system
to large scale system with no problem. As an example, its installation at a place requiring high video quality such as highway
control system, casino, bank, etc. is being discussed in a full scale. If someone buys a new TV, it is expected to be HDTV. So, it is
only natural to expect that getting a new CCTV means the installation of HD-CCTV system in near future.
208
HD-CCTV SYSTEM
02
)%$$57ⲱT'FBUVSFTBOE"EWBOUBHFT
Premium to your security
6 times bigger resolution size
Face Identification
HD-SDI standard allows 1080p resolution image together with
720p. In case of 1080p resolution, it has 6 times bigger image size
than SD level resolution. Therefore, it will be able to be used in the
special market such as car license plate recognition or face identification of criminal requiring High Resolution.
Below pictures show the difference between 1080p image and SD image. These pictures were taken under the same environment and you can clearly see the big difference in parts of face and text identification.
SD Resolution
Full HD Resolution
Full HD
High Definition
1080p shows over 1200TV lines in both horizontal and vertical resolution. It is decidedly superior to the SD resolution which
can only show less than 700TV lines
SD
Digital transmission without video quality degradation
In case of SD-CCTV, transmitted analog video signal’s quality is decreased by external noise and during the digital converting
at DVR, but HD-SDI cameras execute image processing, get digital video and transmit the digital video to DVR without any
converting process. So, there is no video degradation during the transmission and DVR processing, and user can monitor clear
video images.
Fully Digital Signal
Coax cable
209
HDMI cable
210
HD-CCTV SYSTEM
02
)%$$57ⲱT'FBUVSFTBOE"EWBOUBHFT
Premium to your security
Uncompressed video for monitoring
The effect of raising legibility
Below pictures show resolution chart image taken from diverse 2 Mega-Pixel cameras. Since HD-SDI cameras do not compress
video, it shows more clear image, and superior horizontal and vertical resolution.
We compared 35x speed dome camera used in conventional CCTV to 20x HD-CCTV camera.
The picture of 20x Full-HD camera is more clear than
35x SD camera in same distance. This can be surely recognized if you look at the number plate. 20x Full-HD
camera has the resolution of 49x SD camera and please
refer to “Readability of Full HD & SD camera” for detailed
information.
“L”2M IP Camera
“S”2M IP Camera
WEBGATE C1080 HD Camera
35x SD camera image
20x Full HD camera image
650 TV Line
750 TV Line
over 1,200 TV Line
Progressive Screen
Since HD-SDI camera captures the images by progressive scan method, user can see the very clear image without video noise
occurred by interlace scan method of SD camera. Like below pictures, HD-SDI camera’s progressive scan method enables to
get clear image even for moving object.
Progressive scan
211
Interace scan
212
HD-CCTV SYSTEM
02
)%$$57ⲱT'FBUVSFTBOE"EWBOUBHFT
Premium to your security
Plug & Play using Coaxial Cable
Trustworthy Channel (Video-only Channel)
Improved Camera reliability by low heat
In case of HD-CCTV, the coaxial cable used
in conventional CCTV can be reusable. The
management of camera and DVR is very similar to that of SD products, so it can contribute
to minimize the technical burden of conventional installer and manager of monitoring
center. This is because HD-CCTV is relatively
easier when it is compared with IP system
which has product compatibility issue and
difficult network configuration.
It is possible to transmit and record video with no interference of network error because HD-CCTV is transmitting
video through coaxial cable. The trustworthy of transmitting
channel is one of the most core elements to secure trustworthy of security system.
Surveillance cameras can be installed indoor or outdoor.
Sometimes HD-SDI cameras are installed under the environment where temperature is very high. HD-SDI cameras do
not need H.264 compression or IP network feature, so the
power consumption is relatively minimized than IP cameras,
resulting minimization of performance degradation of camera, insuring the reliability.
Easy Integrated Monitoring
Securing Compatibility among Equipment
The system using both HD-SDI camera and HD-SDI DVR
can be easily integrated and installed into the conventional
SD-CCTV. It is easy to use some channels as SD and some
channels as HD together in the same monitoring system.
This could be achieved more easily with the help of HD-SDI
Hybrid DVR or SD-to-HD converter.
In addition, it is possible to integrate with IP network system
and remotely access the system because HD-SDI DVR has
the network feature.
The system using various HD-SDI camera and HD-SDI DVR
can be easily integrated and installed like conventional SDCCTV system. Various converters will offer easy connection
among different type of devices if HD class video is converted into HD-SDI transmission method. This is superior to
the IP camera system which makes compatibility problem
among devices due to the different high-level protocol.
Therefore, user can configure HD-CCTV system based on
installation environment requirement by selecting various
cameras and accessories regardless of manufacturers.
HD real time monitoring (Full Frame, No latency, No compression)
Because HD-SDI transmits video as digital data without compression, you can get the best video image without any quality
degradation, and furthermore because there is no latency, you can control PTZ with real-time from control center. It means
HD-SDI had overcome some restrictions of HD video introduction due to picture degradation and delay of IP solution.
The below picture shows the component of network system. IP camera includes delay caused by video compression and network transmission. Besides, NVR includes delay caused by network and video recovery. This will make the overall delay of total
system, and this will decrease the completeness of the system such as you can see from PTZ control.
HD Encoder
Ethernet
HD Decoder
CMS center
HD Box Cam
IP Camera
SDI to OPTIC
FIBER OPTIC
OPTIC to SDI
HD PTZ
Sensor
Compression
TCP/IP
ISP
HD Box Cam
Ethernet
Repeater
Repeater
Monitor
HD-SDI
Ethernet
NVR or PC
HD Dome
HD-SDI
Monitor
Decompression
TCP/IP
HDMI
HD Camcorder
213
HDMI to SDI
HDMI
HD DVR
214
HD-CCTV SYSTEM
03
"CPVU)%4%*$BCMF
Premium to your security
The main coaxial cable types and specifications
Features of HD-SDI signal
The transmission method of HD-SDI uses Bitrate 1.485Gbit/s of SDI(Serial Digital Interface) method as a standard of SMPTE
292M defined by SMPTE(Society of Motion Picture and Television Engineer). The transmission of HD-SDI uses high frequency
of 750MHz due to large amount of data transferred per second. Compared to Analog video signal which uses less than 10MHz,
it is over 75 times differences. The higher frequency means short wavelength of signal, and signal attenuation by distance will
be increased. So, the most important part in HD-SDI transmission is to minimize decrease of signal. To minimize decrease of
signal , user needs to select suitable coaxial cable for HD-SDI transmission.
RG-type coaxial cable
RG-type coaxial cables include RG-59, RG-6, RG-58, RG-8, etc. following the American coaxial cable standard. RG-58, RG-8 is 50ohm coaxial
cable and RG-59, RG-6 is 75ohm video coaxial cable. RG-59 means 4C high-foamed coaxial cable, and RG-6 means 5C high-foamed coaxial
cable. /U means normal cable and /T means triple shielded cable.
ECX-type coaxial cable
Coaxial Cable
ECX-type coaxial cables include 3C-2V, 5C-2V, 7C-2V,
The coaxial cable consists of signal line with insulator surrounding signal line and shield(outer conductor). The signal
line, metal, has resistance value and this resistance value can
be separated as resistance, capacitance and reactance. From
these 3 values characteristic impedance is decided, and
there are 50ohm and 75ohm impedance in Coaxial cable.
Video cable has minimum attenuation at 75ohm characteristic impedance and can transfer signal farthest at that time.
External diameter of signal line, permittivity of insulator and external diameter of insulator are the elements to maintain 75ohm
impedance.
Even though conventional Analog CCTV system consists of coaxial cable, user needs to check impedance of coaxial cable, quality
of insulator, shielding method and impedance of cable connector to apply HD-CCTV system using HD-SDI.
10C-2V etc., and they are defined in Korean domestic
Vjg"kpvgtpcn"uvtwevwtg"qh"GEZ"v{rg"eqczkcn"ecdng
standard KSC 3610. They are solid polyethylene insulation type coaxial cable, and it is different from foamed
insulation type ones. 3, 5, 7, and 10 means the outer diameter, C means 75ohm impedance, 2 means PE (polyethylene), and V means braided-shielding.
FB (T)-type coaxial cable
FB(T)-type coaxial cables include 3C-(H) FB (T), 4C-(H) FB
(T), 7C-(H) FB (T), 10C-(H) FB (T) etc., and they are de-
Vjg"kpvgtpcn"uvtwevwtg"qh"HD*V+"v{rg"eqczkcn"ecdng
fined as foamed/high-foamed polyethylene insulation
coaxial cable in Korean domestic standard KSC 3617. 3,
75ohm Impedance
5, 7, and 10 means the outer diameter, C means 75ohm
The picture shows Attenuation according to Characteristic Impedance, Power and Volt-
impedance, F means foamed PE insulation, B means
age. HD-SDI transmission signal is very low voltage and the most important part in the
braided-shielding, and T means triple shield. Especially, HF means high-foamed, but the expression is a little different according to manufac-
coaxial cable is signal decrease. If signal decrease is big, that means transmission distance
turers. In case of HD-SDI transmission, high-foamed insulation type is better than ECX type, and HFBT/FBT type’s triple shielding shows better
becomes short. So, 75ohm characteristic impedance cable which shows minimum atten-
signal attenuation performance.
uation should be used.
For reference, FB(T) type coaxial cable shows the most cost effective performance in HD-SDI transmission because it has high-foamed insula-
In contrast to HD-SDI signal, 50ohm characteristic impedance coaxial cable is used in area
tion and shielding as default suitable for high frequency. But, if the distance is short, every cable does not make problem. You may refer to the
standard signal attenuation vs. frequency band table provided from cable manufacturers. You may think that HD-SDI signal eqwnf"tgcej"vq"vjg"
of RF such as communication, measurement, antenna to deliver signal of higher voltage
and current even though signal decrease is bit fallen behind.
215
Impedance in Ohms
fkuvcpeg"yjgtg"vjg"uvcpfctf"cvvgpwcvkqp"dgeqog"42fD"cv"972OJ|"*314"qh"307IJ|+"htgswgpe{"dcpf0
216
HD-CCTV SYSTEM
03
"CPVU)%4%*$BCMF
5C-HFBT cable performance
Selecting a Coaxial cable for HD-SDI (5C-HFBT)
To get stable HD-SDI video signal, selecting a cable is very important. WEBGATE is providing most suitable Coaxial cable, BNC
connector and Cabling tools for our valuable customers.
Selecting a HD-SDI coaxial cable
.BOVGBDUVSFS
4QFD
%JTUBODF
$FOUFSDPOEVDUPS
#SBJEFETIJFME
Ⲳ"ⲳ
$)'#5)%4%*
N
PINN
PINN
Ⲳ#ⲳ
$)'#5
N
PINN
PINN
Ⲳ$ⲳ
$)'#5
N
PINN
PINN
· If 50ohm BNC connector is used, transmission distance is decreased 10~20m
· Superiority of “A” company product
- Center Conductor : “A” company uses annealed copper, but the other companies use copper covered steel
- Braided shield : “A” company uses 0.13mm, but the other company use 0.09mm
[ BNC cable termination ]
Crimp Barrel
Premium to your security
Braided shield
5C-HFBT product type
Foil shield
BNC connector
Center conductor
Center pin
.BOVGBDUVSFS
4QFD
$FOUFSDPOEVDUPS
Ⲳ"ⲳ
$)'#5
5IFSFBSFLJOETPGDBCMFCZCSBJETIJFME
Ⲳ#ⲳ
$)'#5
0OF$)'#5QSPEVDU
Ⲳ$ⲳ
$)'#5
0OF$)'#5QSPEVDU
- WEBGATE is supplying “A” company’s 5C-HFBT coaxial cable.
Transmission distance of several cables
- When selecting 5C-HFBT coaxial cable, its center conductor must be composed of annealed copper.
$BCMF
%JTUBODF
$)'#5
"QQSPYN
There are 2 kinds of center conductor. The first one is made of copper, and the other one is copper covered steel.
- Signal transmission distance of 5C-HFBT cable can be judged by resistance of center conductor.
(Refer to below 5C-HFBT cable performance table)
$)'#5
"QQSPYN
- BNC connector must have 75ohm impedance. (if used 50ohm’s one, transmission distance will be decreased around 10~20m)
$7
"QQSPYN
- Crimping type center conductor can be easily used for assembly.
$7
"QQSPYN
50ohm impedance
BNC connector body
$FOUFSDPOEVDUPSNBEFCZBOOFBMFEDPQQFSTIPXTCFUUFSQFSGPSNBODFUIBODPQQFSDPWFSFETUFF
#SBJEFETIJFMEBGGFDUTUPUSBOTNJTTJPOEJTUBODF
Introduction of cabling tools
Comparison of 50ohm and 75ohm BNC Connector
Kpuwncvqt"ku
rtqvtwfgf"vq"qwvukfg
3FNBSL
Kpuwncvqt"ku
Rncegf"kpukfg
75ohm impedance
BNC connector body
]Ecdng"Uvtkrrgt"JV/554_
]"DPE"Etkorkpi"Vqqn"_
]"7E"DPE"RNWI"_
]"7E/JHDV"㰴㒨⭈"_
ⲻ Regarding purchase of Coaxial cable, BNC connector, Cabling tools, WEBGATE is waiting for your inquiry.
217
218
HD-CCTV SYSTEM
03
"CPVU)%4%*$BCMF
Premium to your security
HD-SDI signal extension
Fiber Optic converter
(HD-SDI fiber optic transmission)
Maximum HD-SDI transmission distance is almost decided according to the type of coaxial cable as shown in the table below.
If you want to lengthen the distance, you may use higher rating cable which has lower signal attenuation or use HD-SDI repeater or adopt fiber-optic converter for long distance.
In order to make up for the weakness and to reduce transmission
HD-SDI Speed Dome
OPT-TX1-RS485UC
loss and to extend transmission distance to dozens of Km, fib20 Km
er-optic transmitter is in use. The advantages are as follows. installation is easy due to thin cable, and although HD-SDI video can
be transmitted around 100~300m using normal coaxial cable,
but it can be transmitted up to dozen of Km by fiber-optic cable.
OPT-TX1-RS485UC
Moreover, normal coaxial cable is easy to be affected by EMI, RFI
noise, but fiber-optic cable is not affected by these electromagnetic noises, and if used multiplex transmission, several data can
be transmitted through one fiber-optic cable.
Repeater / PoC Repeater
HD-SDI repeater has equalizer function to compensate and recover video signals attenuated. HD-SDI repeater is used for extend the transmission distance. PoC(Power over Coax) is a repeater which supplies power via coaxial cable. If used PoC repeater, it does not need to supply power into the repeaters which are connected in the middle of line. According to the cable type, maximum number of PoC repeater is different.
Guide for Fiber-Optic Converter (OPT-TX/RX Series)
Installation configuration
Camera
RP102
RP102
RP102
RP102
Camera
OPT-TX1-RS485UC
OPT-RX1-RS485UC
HD-SDI
DVR
HD-SDI
RS485
RS485
Fiber Optic Cable
Max. 20Km
[ Repeater ]
Camera
PoC
Repeater
PoC
Repeater
PoC
Repeater
PoC
Repeater
Optical Cable and Connector
[ PoC Repeater ]
]"Qrvkecn"Ecdng"_
219
]"Qrvkecn"Eqppgevqt"_
]"Qrvkecn"ecdng"eqppgevkqp"_
220
HD-CCTV SYSTEM
03
"CPVU)%4%*$BCMF
Premium to your security
Transmission distance of HD-SDI signal
*UFN
$BCMFUZQF
%JTUBODF
5SBOTNJTTJPOTJHOBM
4JOHMFNPEFPQUJDBMDBCMF
.BY,N
)%4%*Q34
.VMUJNPEFPQUJDBMDBCMF
.BY,N
)%4%*Q34
"QQMZJOH
'JFME
# OPT-TX/RX Series support only LC type connector
4JOHMFNPEFGJCFSPQUJDDBCMF
.VMUJNPEFGJCFSPQUJDDBCMF
6TFGPS⽃XBWFMFOHUITJHOBM
6TFGPS⽃XBWFMFOHUITJHOBM
-POHEJTUBODFSFQFBUFSMFTTUSBOTNJTTJPO
4IPSUEJTUBODFUSBOTNJTTJPO
%BUBUSBOTNJTTJPODBCMF
0QUJDBMDBCMFGPS-"/
-POHEJTUBODFUSBOTNJTTJPO
0QUJDBMDBCMFGPSEBUB
$"57DBCMF
0QUJDBMDBCMFGPSEJTUSJCVUJPO
# Single-mode or Multi-mode cable can be used depending on transmission distance
*OUFSOBMDPSFEJBNFUFSJT⽄
'FBUVSFT
6OJGPSNPQUJDBMDIBSBDUFSJTUJDTBOEMPXMPTT
*OUFSOBMDPSFEJBNFUFSJT⽄⽄
4USPOHGPSNJDSPCBOEJOH
%PVCMFDPBUJOHUZQF
4VQFSJPSDPNQBUJCJMJUZXJUIFYUFSOBMEFWJDFT
Optical cable and Connector type
2) Connector types of optic cable
1) Optical cable types and specifications
Optic cable or Optic jumper code can be divided into 2 types.
ͮ Single mode cable : Core diameter is about 9‫ۯ‬, which is being used for wideband, long distance and it can make repeaterless
QRV/VZ1TZ"Ugtkgu"uwrrqtv
NE"v{rg"Eqppgevqt
transmission up to 50km. In case of small-size core diameter single-mode cable, the cable path is narrow so it is hard to deliver large
SC
ST
MTRJ
FDDI(MIC)
BIOCONIC
FC
MU
FJ45
amount information, but is possible to deliver information far away. The cable jacket color normally uses Yellow color.
ͯ Multi mode cable : Core diameter is 50~100‫ۯ‬, which is being used for short distance. In case of big-size core diameter multi-mode cable,
the cable path is wide so it can deliver large amount information. The cable jacket color normally uses Orange color.
]"Uvtwevwtg"qh"Ukping/oqfg"hkdgt/qrvke"ecdng"_
Eqtg"/"fkcogvgt"ku";‫ۯ‬
Encf"/"fkcogvgt"ku"34707‫ۯ‬
Rncuvke"eqcvkpi"nc{gt"/"fkcogvgt"ku"472‫ۯ‬
221
LC
VF45
]"Uvtwevwtg"qh"Ownvk/oqfg"hkdgt/qrvke"ecdng"_
Eqtg"/"fkcogvgt"ku"7218407‫ۯ‬
Encf"/"fkcogvgt"ku"34707‫ۯ‬
Rncuvke"eqcvkpi"nc{gt"/"fkcogvgt"ku"472‫ۯ‬
222
HD-CCTV SYSTEM
04
-FHJCJMJUZPG)%4%*;PPN$BNFSB
Premium to your security
Legibility of HD-SDI zoom camera (vs. analog camera)
Zoom performance comparison using actual cameras
To get the optical performance of lens, we may simply compare the focal-length of lenses. But, it is somewhat risky to judge
the zoom performance only based on the zoom magnification which is calculated by the focal-length ratio of Tele-end and
Wide-end. Several factors like resolution of lens itself and light transmittance affect the actual legibility of zoom camera.
In the following case, zoom performance of two 35x and 37x camera is almost same, but actually 35x zoom camera will show
better zoom performance. In other words, the higher zoom magnification does not mean the better legibility.
If we compare the legibility among cameras through the formula of “Focal-length at Tele-end x Resolution Factor = Virtual
focal-length at tele-end”
· Camera A : 35x optical zoom (f=3.4 ~ 119mm)
· Camera B : 37x optical zoom (f=3.2 ~ 118.4mm)
Many conventional zoom camera and speed dome customers had been judged zoom performance based on focal-length
at Tele-End, and zoom magnification. But, if we compare the HD-CCTV camera with conventional analog camera, we need
more deep study. Because HD-CCTV camera has much higher resolution than analog camera, it is not suitable only to use lens
magnification to compare the legibility between the videos.
Camera1
Analog 35x zoom camera (410K pixels, 720 x 480)
Focal length : 3.4mm ~ 119mm
119mm x 1 = 119mm
Camera2
HD-CCTV 18x zoom camera (720p, 1,280 x 720)
Focal length : 4.7mm ~ 84.6mm
84.6mm x 1.63 = 137.9mm
Camera3
HD-CCTV 20x zoom camera (1080p, 1920 x 1080)
Focal length : 4.7mm ~ 94mm
94mm x 2.45 = 230.3mm
Legibility comparison between analog and HD-CCTV camera based on resolution
You may consider 20x HD-CCTV camera may have lower legibility if it compared with 35x analog camera because it has lower
zoom magnification, but it it not true. Because HD-CCTV camera is using 2 megapixel image sensor, it provides much greater
information than analog camera which uses 410Kpixel image sensor. Moreover, HD-CCTV is using digital video transmission
method so, it prevents the drop of video quality during transmission, and it keeps relatively higher legibility.
More technically, let’s compare the pixel quantity between HD-CCTV camera and analog camera. NTSC video can be converted to digital video, and its maximum size is as follows.
· Resolution of HD-CCTV camera
· Resolution of Analog camera
From the above results, camera 2 shows similar legibility to 29x (137.9mm/4.7mm), analog zoom camera, and camera 3 shows similar legibility
to 49x (230.3mm/4.7mm) analog zoom camera. In other words, judging the zoom performance of HD-SDI and analog camera by simply their
zoom magnification may bring wrong result.
That is, even through camera’s “Focal length at Tele-End” is same, the actual legibility shows difference according to camera’s resolution.
: 1920 x 1080 = 2,073,600 pixels (HD1080p)
: 720 x 480 = 345,600 pixels (NTSC)
Therefore, HD-CCTV’s total pixel is exactly 6 times bigger than analog’s one. Because √6=2.45, it means HD-CCTV camera has
same effect as using a zoom lens which has 2.45 times better performance compared to an analog camera.
223
224
HD-CCTV SYSTEM
05
*OUSPEVDUJPOPGUIF)%$$57"MMJBODF
Premium to your security
Status of HDcctv alliance
Guarantee of product compatibility and transmission performance
Founded in 2009, HDcctv Alliance(www.highdefcctv.org) is developing the HD-SDI standard based on SMPTE standard. Their
purpose is functional and performance standardization for speedy HD-SDI market expansion, so it adds new items to ensure
the performance or restricts items suitable for surveillance market. Approx. 50 companies all over the world is joining this
alliance and closely working with the alliance. Below picture shows the company logos that joined and working with HDcctv
Alliance at present. It includes diverse companies like chipset provider, DVR and camera manufacturers from various countries
of the world.
HDcctv Alliance is developing the HD-SDI standard, and this standard includes video, physical layer, meta data, etc. which are
using between HD-SDI Tx/Rx equipment. Especially, they are standardizing the performance, compatibility requirements that
are necessary for surveillance camera, DVR, monitor, and repeater, and its purpose is fast market expansion of HD-SDI products
in surveillance market. For example, because still image is as very important as video in surveillance market, they do not allow
interlace scan method that makes quality degradation of still image and only allow progressive scanning method.
HDcctv Alliance is clearly providing the HD-SDI’s minimum requirements for performance, standardizing the compatibility
between equipment, ensuring product performance for the expansion and settlement of the HD-CCTV market.
Standardization (differences from SMPTE)
HDcctv Alliance and SMPTE made a license agreement in year 2009, and the HDcctv standard was derived from SMPTE-292M.
Because HD-SDI is already proven technology in broadcasting market, it did not need a separate standard. However, in contrast to the relatively small and high cost of broadcasting equipment market, large and price-sensitive surveillance market
needs further standardization of electrical function, performance and the compatibility between diverse equipment. HDcctv
standard requests the plug and play regardless of device’s features, nation, price and it provides their test methods in certification process.
Below table shows the differences between SMPTE and HDcctv standard. HD-CCTV adopted 1.485Gbps, 1080p30 HD-SDI
transmission method due to the compatibility between equipment and importance of still image. Additionally, the transmission distance is one of the main issues, it requests strict signal quality of equipment. HDcctv is still working for improvement of
transmission distance, communication between equipment and adding PoC function for easy installation.
7JEFP'PSNBU
4.15&
)%DDUW7
1IZTJDBM-BZFS
4%4%*)%4%*(4%*
)%4%*
.BYCJUSBUF
VQUPQ
VQUPQ
4DBOOJOH
QSPHSFTTJWFJOUFSMBDF
QSPHSFTTJWF
4JHOBM-PTTE#
UZQJDBMMZE#
E#!-$'#
#JUFSSPS
/PUEFGJOFE
/PFSSPSXIFON!3(
F9UFOE3FBDI
/PUEFGJOFE
XJMMCFSFMFBTFEBU)%DDUW93
#JEJSFDUJPOBMDPOUSPM
/PUEFGJOFE
XJMMCFSFMFBTFEBU)%DDUW7
1PXFSPWFS$PBY
/PUEFGJOFE
XJMMCFSFMFBTFEMBUFS
$FSUJGJDBUJPO1SPDFTT
/PUEFGJOFE
0
4JHOBM1FSGPSNBODF
'VUVSF4QFD
&UD
225
226
WEBGATE, the leading company in HD-CCTV market
Premium to your security
Leadership Award for 3 years in a row
WEBGATE won
on the HDcctv Leadership Award for 3 consecutive years from 2011 to 2013.
This award means that HD-CCTV market has recognized WEBGATE’s tireless new product development, the effort
effo to spread
significant system
ystem installation cases, holding customer seminars.
Also, this proves
ves that WEBGATE is the leading manufacturer driving the HD-CCTV market in the world.
2011
2012
2013
WEBGATE’s HDcctv certificates
WEBGATE’s Vision
Since receiving the world’s first HDcctv camera certificate in 2010, WEBGATE has acquired total of 45 certificates for DVR, camera and converter products.
Especially, WEBGATE acquired HDcctv certifications for PoC cameras on October in 2013, and acquired the world’s first certifications for PoC DVR models also. It is truly a defining moment for HD-CCTV industry. Because it directs the future of “One Cable
Solution” using HD-SDI products.
WEBGATE is holding total 45 HDcctv certificates and it is top among HDcctv members (Based January 2014). Also, keep designing high quality products satisfying fussy HDcctv Alliance standard.
ⰑDVR Products – Total 13 certificates
ⰑCamera Products – Total 25 certificates
ⰑConverter Products – Total 7 certificates
Established in 1997, Daemyung Enterprise Co., Ltd. WEBGATE division, has been continuously tried to keep the promise of providing the best and the most innovative products in the world of security. With a world-class technology and highly reliable
products, WEBGATE is currently leading the world of security market.
We will always keep the promise to meet the changes in the market and provide you the best.
227
228
Ordering Information
Premium to your security
HD-SDI DVR
HD1600F-PDR-20T5
Number of HDD
10T : 1TB HDD
20T : 2TB HDD
30T : 3TB HDD
40T : 4TB HDD
P : PoC/CoC support
D : DoubleReach support
R : RAID support
Large case
Medium case
F : HD1080p 30fps/ch
H : HD1080p 15fps/ch
M : HD1080p 7.5fps/ch
Small case
In case of HDC,
00 : Small case
01 : Medium case
4 : 4ch
8 : 8ch
16 : 16ch
HD : Large case
HDC : Medium or Small Case
HD-SDI Box & Bullet Camera
Singapore Sole Distributor:
Jia Ying Trading Pte Ltd
HD-SDI Dome Camera
C1080PBL-IR48-AF
C1080PVD-IR-AF
AF : Auto Focus
Blank : Manual Focus
IR18 : Built-in 18 IR-LED
IR48 : Built-in 48 IR-LED
Blank : No IR-LED
B : Box Camera (Long Body)
BM : Box Camera (Short Body)
BL : Bullet Camera
P : Built-in PoC/CoC
Blank : Non-PoC
HD1080P Camera
229
AF : Auto Focus
Blank : Manual Focus
IR : Built-in 24 IR-LED
Blank : No IR-LED
D : Plastic Dome
VD : Vandal Dome
P : Built-in PoC/CoC
Blank : Non-PoC/CoC
HD1080P Camera
1 Rochor Canal Road, #02-67/69/34-37
Sim Lim Square Singapore 188504
T. +65. 6336.0404 F. +65. 6338.0404
www.jiaying.com
[email protected] | [email protected]
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
