Security Cameras Surveillance Systems Closed Circuit Television Video
Professional Reliable Vandal Proof Security Camera Day & Night Dome
Infrared LED Bullet Weatherproof Auto-Tracking Pan Tilt Zoom Digital
Video Recorder Dual Power Central Monitoring Software High Resolution
Zero Defect Eclipse Function Security Camera Motion Detection Backlight
Compensation Digital Image Stabilization Wide Dynamic Range The Art of
Surveillance Security Cameras Surveillance Systems Closed Circuit Television Video Professional CCTV Reliable Vandal Proof Day & Night Dome
Infrared LED Bullet Weatherproof Auto-Tracking Pan Tilt Zoom Digital
Video Recorder Dual Power Central Monitoring Software High Resolution
Zero Defect Eclipse Function Motion Detection Backlight Compensation
Digital Image Stabilization Wide Dynamic Range The Art of Surveillance
Security Cameras Surveillance Systems Closed Circuit Television Video Professional CCTV Reliable Vandal Proof Day & Night Dome Infrared LED Bullet Weatherproof Auto-Tracking Pan Tilt Zoom Digital Video
Recorder Dual Power Central Monitoring Software High Resolution Zero
Defect Eclipse Function Motion Detection Backlight Compensation Digital
Image Stabilization Wide Dynamic Range CCTV The Art of Surveillance
Security Cameras Surveillance Systems Closed Circuit Television Video
Professional Reliable Vandal Proof Day & Night Dome Infrared LED Bullet
Weatherproof Auto-Tracking Pan Tilt Zoom Digital Video Recorder Dual
Power Central Monitoring Software High Resolution Zero Defect Eclipse
Function Surveillance Security Camera Motion Detection Security Camera
Backlight Compensation Digital Image Stabilization Wide Dynamic Range
The Art of Surveillance
Security Cameras Surveillance Systems
Closed Circuit Television Video Professional Reliable Vandal Proof Day &
Night Dome CCTV Infrared LED Bullet Weatherproof Auto-Tracking Pan
Tilt Zoom Digital Video Recorder Dual Power Central Monitoring Software
Manufacturing
Solutions
Product Catalog
2011
Table of Content
Dome Cameras............................................................................................12-17
Box Camera ......................................................................................................18
Bullet Cameras ............................................................................................19-22
Pan / Tilt / Zoom Cameras ...........................................................................23-24
P/T/Z Accessories .............................................................................................25
High Speed Pan / Tilt / Zoom Camera ..............................................................26
License Plate Camera .......................................................................................27
IP Cameras ..................................................................................................29-37
NVR-Pro .......................................................................................................38-39
Digital Video Recorder .................................................................................41-43
Rack Mount Hybrid Server ...........................................................................44-45
Central Monitoring Station ................................................................................46
Matrix Switcher.............................................................................................47-48
Keyboard ...........................................................................................................49
Monitors ............................................................................................................50
Lens...................................................................................................................51
Housing / Bracket .............................................................................................52
Beginning with just a few simple products, Veilux has grown to offer lots of products in the
video security industry.
Veilux is decidedly focused on capturing the rapidly growing international video security
market. Veilux’s growing number of international locations also includes numerous sales
and training offices, distribution centers, and service center locations around the world;
London UK, Cairo Egypt, Amman Jordan, Seoul S.Korea, Shangzou China.
As Veilux’s Product Development Director says, “We supply solutions which are specially
geared to meet the user’s needs. This applies in the security market just as it does in the IT
area. And this is precisely where our strength lies - we are a flexible research, development,
and manufacturing company which specializes in security products.”
Engineering
Utilizing CAD Systems, Digital 3D Modeling and Stress Analysis, Veilux’s engineers
comprise the most capable development team in the industry.
Quality Assurance
In-house product and design testing capabilities include, Compliance Test Labs, ESD and
Environmental Testing.
From Start to Finish
Powerful capabilities allow Veilux to control the production process from start to finish.
Achieving Excellence
Veilux employees work within clean, safe, friendly environments, featuring state-of-the-art
systems, tools, and technologies.
Service 100% Customer Satisfaction
Guaranteed Ship Dates, In-Stock Availability, Technical Assistance with 100% Customer
Satisfaction.
VS-IP36X
UNDERWATER PROOF IR LED PTZ CAMERA
VS-IP36X has been designed unique and strong with high
quality for security applications that demand the very high
performance both day and at night time.
Rated to an industry leading IP68, the vandal resistant
aluminum camera housing is suitable for installation in the
harshest of environments.
Surveillance with optimum picture is possible owing to filter
changeable Day & Night function and DSS function.
Auto-IR cut filter removable function is the auto-controlling
operation such as color picture plus infrared cut filter during the
day and black and white picture plus filter elimination at night.
FEATURES
•The World’s First 360° Endless Pan / Tilt Motion
•Auto LED Brightness Control by Distance Range
•Auto LED Pulse Control by Shutter Speed (2 Times Better LED
Brightness)
•Pan / Tilt Torque Compensation (Step-Out Prevention)
•Tilt Glass Protecting From Reflection
•Internal Ciruit Protection
•High-Quality LED Adopted
•Tempered Glass Adopted (Dew Condensation Prevention)
•Reliable Durability
•Easy Maintenance
•IP-68 Perfect Waterproof
?? mm
INTRODUCING OUR BRAND NEW CAMERA
The range offers numerous benefits over the use of traditional
dome and PTZ cameras, and comes with a variety of options in
order to offer a best fit solution for virtually any application.
530
TV LINES
??? mm
Auto White
AWB Balance
VOLTAGE
OPTICAL/
DIGITAL
ZOOM
IR LED
VANDAL
RESISTANT
4
Toll Free: (800) 510-6528
www.veilux.net
Back Light
0.05
LUX
BLC Compensation
OFF
24AC
ON
PAN/TILT/ZOOM
D&N
NIGHT
DAY
ITEM
VS-IP36X
Video System
PAL / NTSC
Video Output
Composite Video
Image Sensor
1/4" SONY SuperHAD CCD
Image Pixel
410K (NTSC), 470K(PAL)
Horizontal Resolution
530 TVL
Minimum Illumination
0.05 Lux at 1/4 Sec & ICR-ON Mode
Zoom
36x Optical / 12x Digital
Lens
f-3.4mm(wide) to 122.4mm(tele), F1.6 to F4.5
S/N Ratio
>50dB
Sync System
Internal
Gamma Characteristic
0.45
White Balance
Auto
Backlight Compensation
On / Off
Housing
Die-Cast Aluminum & "O"-Ring Sealed
(All Internal Parts - Anticorrosive Coating)
Operating Temperature
-40°C ~ +55°C, 30%~90% Humidity
Operating Voltage
AC 24V (AC15~30V) 50/60Hz, 1.5A
Power Consumption Max
Max 40W
PAN
Angle
0°~360° (Endless)
Manual Speed
1~100° /Sec
Preset Speed
10~200° /Sec
TILT
Angle
0°~360° (Endless)
Manual Speed
1~100° /Sec
IP Rating
IP-68
Preset Positions
165
Preset Tours
8 Programmable Group Tours (1 Group / 60 Steps)
Pattern
8 Programmable Patterns
Scan
8 Programmable Scans
Camera ID
0~255 Address
Privacy Zones
24 Privacy Masking
On Screen Display
Camera ID, Name, Area Name, Preset Name, Tour
Name, Angle
Heater
Optional
Special Function
External Temperature Display
Protocols
Pelco D/P
Controller Interface
RS-485, Baud Rate:2400~9600bps
Alarm
4 Alarms
Aux Out
2 Aux Out
IR Mode
IR Light Reaching Distance:100M
Visual Distance:100M
(IR LED Type:850nm) Zoom
Available to Control LED Level
Toll Free: (800) 510-6528
www.veilux.net
INTRODUCING OUR BRAND NEW CAMERA
VS-IP36X
UNDERWATER PROOF IR LED PTZ CAMERA
5
6
1/3” CCD, 580 TV Lines
3.6mm Board Lens, 48 IR LEDs
SVB-70IR48
1/3” CCD, 700 TV Lines
3.6mm Board Lens, 48 IR LEDs
SVB-60IRC28L3516D
1/3” SuperHAD II CCD
High Resolution 600 TV Lines
Sens-Up (x512), Zero Defects, 28 IR LEDs
SVB-60IRC66L3516D
1/3” SuperHAD II CCD
High Resolution 600 TV Lines
Sens-Up (x512), Zero Defects, 66 IR LEDs
SVB-60IRC80L650D
1/3” SuperHAD CCD
High Resolution 600 TV Lines
80 IR LEDs, 6~50mm
VP-ATDN18X
1/4” Color CCD
540 TV Lines, 18x Optical Zoom, 12x
Digital Zoom
VP-ATDN36X
1/4” Color CCD
540 TV Lines, 36x Optical Zoom, 12x
Digital Zoom
VP-ATDNC23X
1/4” Veilux SuperHAD CCD
520 TV Lines, 23x Optical Power Zoom,
10x Digital Zoom
VP-ATDNC27X
Object Auto-Tracking Day & Night Camera
1/4” Veilux SuperHAD CCD
520 TV Lines, 27x Optical Power Zoom,
10x Digital Zoom
VP-54CDN10X
1/4” Inter Line Transfer CCD
540 TV Lines, 10x Optical Zoom
Car License Plate Camera (D/N, Low Light, High
Speed Capture)
Day & Night IR Bullet Camera
Dual Power True Day & Night WDR 3D DNR IR
Bullet Camera
Dual Power True Day & Night WDR 3D DNR IR
Bullet Camera
Dual Power True Day & Night WDR IR Bullet
Super DNR Camera
Object Auto-Tracking Day & Night Camera
Object Auto-Tracking Day & Night Camera
Object Auto-Tracking Day & Night Camera
Mini High Speed PTZ Camera
Toll Free: (800) 510-6528
www.veilux.net
Pg 51
VSSC-54CDNR-90
Pg 51
1/3” SuperHAD II CCD
High Resolution 600 TV Lines
Sens-Up (x512), Zero Defects, Lens Options
Dual Power True Day & Night WDR 3D DNR
Color Camera
Pg 51
SVS-60CDNRD
Pg 52
1/3” SONY CCD
High Resolution 600 TV Lines
IP-68 - Underwater Proof
Dual Power True Day & Night Underwater Proof
WDR 3D DNR Vandal Proof IR Dome Camera
Pg 25
SVV-60IRC40L2812D
Pg 25
1/3” SuperHAD II CCD
High Resolution 600 TV Lines
Sens-Up, Zero Defects, 2.8~12mm
Dual Power True Day & Night WDR 3D DNR
Vandal Proof Dome Camera
Pg 25
SVV-60CDNL2812D
Pg 25
1/3” SuperHAD II CCD
High Resolution 600 TV Lines
Sens-Up (x512), Zero Defects, 30 IR LEDs
Dual Power Day & Night WDR 3D DNR IR Dome
Camera
Pg 25
SVD-60IR30L2812D
Pg 25
1/3” SuperHAD II CCD
High Resolution 600 TV Lines
Sens-Up (x512), Zero Defects, 2.8~12mm
Dual Power Day & Night WDR 3D DNR Dome
Camera
Pg 25
SVD-60DNL2812D
DOME CAMERA
1/3” SuperHAD CCD
700 TV Lines - 2.8~10mm
3-Axis Dome Camera
LICENSE PLATE STANDARD CAMERA
SVD-70L2810
BULLET CAMERA
1/3” SuperHAD CCD
650 TV Lines - 3.6mm
3-Axis Dome Camera
PAN / TILT / ZOOM CAMERA
SVD-65MINI
Pg 49
Pg 26
Pg 24
Pg 24
Pg 23
Pg 23
Pg 22
Pg 21
Pg 20
Pg 19
Pg 25
Pg 18
Pg 17
Pg 16
Pg 15
Pg 14
Pg 13
Pg 12
PRODUCT LINE UP
Security Cameras and Accessories
VL-0358A
Vari-Focal Manual Iris
Lens (DC Drive)
VL-02812A
Vari-Focal Auto Iris
Lens (DC Drive)
VL-05100A
Auto Iris Lens
(DC Drive)
VCH-619
Outdoor / Indoor
Camera Housing
I-6
In-Ceiling Mount
S6
Surface Mount
W6
W6 - Wall Mount
P6
Pendant Mount
VM-CORNER
Pan / Tilt / Zoom
Corner Mount
WM-POLE
Pan / Tilt / Zoom Pole
Mount
VP-PS
Outdoor Wall Power
Supply
VK-64
Controller
Pg 34
Pg 32
REC & PB Speed: CIF 120ips / 100ips
HD1 120ips / 100ips
D1 120ips / 100ips
SVR-824DVD
REC & PB Speed: CIF 240ips / 200ips
HD1 240ips / 200ips
D1 120ips / 100ips
SVR-1648DVD
REC & PB Speed: CIF 480ips / 400ips
HD1 240ips / 200ips
D1 120ips / 100ips
VRMS-1648
Frame rate for monitoring: live display 480
fps (NTSC) / 400 fps (PAL)
Recording: 480 fps (N) / 400 fps (P)
VRMS-3296
Industrial Rack Mount AVA DVR
Frame rate for monitoring: live display 480
fps (NTSC) / 400 fps (PAL)
Recording: 960 fps (N) / 800 fps (P)
VMS-2000 Series
Video Output: Modular 4~16 Channels
Video Input: Modular 16~64 Channels
VVIP-WM
VMS-3000 Series
Video Output: Modular 4~16 Channels
Video Input: Modular 32~144 Channels
VVIP-CM
VMS-4000 Series
Video Output: Modular 16~32 Channels
Video Input: Modular 48~294 Channels
VMS-9000 Series
Video Output: Modular 48~64 Channels
Video Input: Modular 112~256 Channels
VL-02812A
Monitor
Monitor Size Available:
17”, 19”, 22”, 32”, 42”
Metal Case and Tempered Glass
VL-05100A
VX-WLCDM
2.5” TFT LCD Screen
480 x 234 pixel
5VDC power
VDIP-D1L312 / VDIP-2L316
1/3" 520 TV Line, SONY SuperHAD II CCD
1/3 2" CMOS 2.0M Pixels Progressive
Scan - Dome Camera
VPIP-ICM
VVIP-D1L312 / VVIP-2L316
1/3" 520 TV Line, SONY SuperHAD II CCD
1/3 2" CMOS 2.0M Pixels Progressive
Scan - Weather Proof & Vandal Proof
VPIP-JB
VSIP-D1 / VSIP-2
1/3" 520 TV Line, SONY SuperHAD II CCD
1/3 2" CMOS 2.0M Pixels Progressive
Scan - Bullet Camera
VPIP-D127X / VPIP-D133X / VPIP-D137X
1/4" SONY ExView HAD CCD
27x Optical Zoom, 33x Optical Zoom,
37x Optical Zoom
Industrial Rack Mount AVA DVR
Matrix Switcher
Matrix Switcher
Matrix Switcher
Matrix Switcher
Monitor
TFT LCD Monitor
Dual Codec IP Camera / 2 Megapixel IP Camera
Dual Codec IP Camera / 2 Megapixel IP Camera
Dual Codec IP Camera / 2 Megapixel IP Camera
Speed Dome Dual Codec IP Camera
INDUSTRIAL RACk MOUNT AVA DVR
Digital Video Recorder PRO DVR Series 16
Channel
VCB-480-16EX
16 Channel Capture
Card
VCB-960-32EX
32 Channel Capture
Card
Wall Mount Bracket
MATRIX SWITCHER
Digital Video Recorder PRO DVR Series 8
Channel
Ceiling Mount
Bracket
VL-0358A
Vari-Focal Manual Iris
Lens (DC Drive)
Vari-Focal Auto Iris
Lens (DC Drive)
MONITOR
Digital Video Recorder ECO DVR Series 4
Channel
DIGITAL VIDEO RECORDER
SVR-412DVD
Auto Iris Lens
(DC Drive)
VPIP-VM
Wall Bracket
Ceiling Bracket
Junction Box
IP CAMERA
Pg 30
Pg 28
Pg 50
Pg 50
Pg 48
Pg 48
Pg 47
Pg 47
Pg 45
Pg 45
Pg 43
Pg 43
Pg 42
PRODUCT LINE UP
Video Recording Systems and Accessories
VPIP-CA
Corner Mount
VPIP-PA
Pole Mount
Toll Free: (800) 510-6528
www.veilux.net
7
C A M E R A
CAMERA SELECTION
CCD Format
Resolution
Lens
IR LED
Min.
Illumination
Auto Gain
Control
Wide Dynamic
Range
Back Light
Compensation
Auto White
Balance
Digital
Zoom
Sens-Up
(x512)
3D
DNR
3Axis
Power
SVD-65MINI
1/3”
SuperHAD
CCD
650 TV
Lines
3.6mm
-
0.000001
Lux
Auto
-
-
-
-
-
-
Yes
12VDC
SVD-70L2810
1/3”
SuperHAD
CCD
700 TV
Lines
2.8m ~
10mm
-
0.1 Lux
Auto
-
-
-
-
-
-
Yes
12VDC
SVD-60DNL2812D
1/3”
SuperHAD II
CCD
600 TV
Lines
2.8 ~
12mm
-
0.0002
Lux
Auto
Auto
Auto
Auto
x1 ~
x10
off ~
x512
On /
Off
Yes
12VDC /
24VAC
SVD-60IR30L2812D
1/3”
SuperHAD II
CCD
600 TV
Lines
2.8 ~
12mm
30 Units
0 Lux
Auto
Auto
Auto
Auto
x1 ~
x10
Off ~
x512
On /
Off
Yes
12VDC /
24VAC
SVV-60DNL2812D
1/3”
SuperHAD II
CCD
600 TV
Lines
2.8 ~
12mm
-
0.0002
Lux
Auto
Auto
Auto
Auto
x1 ~
x10
Off ~
x512
On /
Off
Yes
12VDC /
24VAC
SVV-60IR40L2812D
1/3” SONY
CCD
600 TV
Lines
2.8 ~
11mm,
3.5 ~
16mm
40 Units
0.003
Lux
Auto
Auto
-
Auto
-
Off ~
x512
On /
Off
Yes
12VDC /
24VAC
SVS-60DNRD
1/3”
SuperHAD II
CCD
600 TV
Lines
C/CS
Mount
-
0.0002
Lux
Auto
Auto
Auto
Auto
x1 ~
x10
Off ~
x512
On /
Off
-
12VDC /
24VAC
VSSC-54CDNR-90
1/3”
SuperHAD II
CCD
540 TV
Lines
C/CS
Mount
-
0.08 Lux
Auto
Auto
Auto
Auto
-
Auto
-
-
24VAC
VP-ATDN18X
1/4” Color
CCD
540 TV
Lines
4~
72mm
-
0.01 Lux
Auto
-
Auto
Auto
12x
-
-
Yes
24VAC
VP-ATDN36X
1/4” Color
CCD
540 TV
Lines
4~
144mm
-
0.01 Lux
Auto
-
Auto
Auto
12x
-
-
Yes
24VAC
VP-ATDNC23X
1/4” Veilux
SuperHAD
CCD
520 TV
Lines
3.6 ~
82.8mm
-
0.001
Lux
Auto
-
Auto
Auto
10x
-
-
Yes
24VAC
VP-ATDNC27X
1/4” Veilux
SuperHAD
CCD
520 TV
Lines
3.6 ~
97.2mm
-
0.001
Lux
Auto
-
Auto
Auto
10x
-
-
Yes
24VAC
VP-54CDN10X
1/4”
Inter Line
Transfer
CCD
540 TV
Lines
3.8 ~
38mm
-
0.02 Lux
Auto
-
Auto
Auto
-
-
-
Yes
12VDC
SVB-70IR48
1/3” CCD
700 TV
Lines
3.6mm
48 Units
-
-
-
Auto
Auto
-
-
-
-
12VDC
SVB-60IR28L3516D
1/3”
SuperHAD II
CCD
600 TV
Lines
3.5 ~
16mm
28 Units
0 Lux
Auto
Auto
Auto
Auto
x1 ~
x10
Off ~
x512
On /
Off
-
12VDC /
24VAC
SVB-60IR66L3516D
1/3”
SuperHAD II
CCD
600 TV
Lines
3.5 ~
16mm
66 Units
0 Lux
Auto
Auto
Auto
Auto
x1 ~
x10
Off ~
x512
On /
Off
-
12VDC /
24VAC
SVB-60IR80L650D
1/3”
SuperHAD
CCD
600 TV
Lines
6~
50mm
80 Units
0.00001
Lux
-
Auto
Auto
Auto
-
x32
-
-
12VDC /
24VAC
Model
Toll Free: (800) 510-6528
www.veilux.net
9
CAMERA TERMS & FEATURES
Technical Glossary
3D DNR (Digital Noise Reduction)
D-Zoom (x1 ~ x10)
VX7-DSP technology achieves a 3D DNR (3 Dimensional Digital Noise Reduction)
function very excellently by using upgraded 3D filtering and enables to keep this function
automatically while operating the camera to provide the clear and superior images in very
low light luminance. Normally video noise is increased at low light condition while the
gain level of amplifier expends. VX7-DSP compensates the dynamic noise by using the
information of formal frame in no activity part.
VX7-DSP technology enables a various magnification and helps to get the enlarging video
image very conveniently. VX7-DSP has a remote control technology for a camera without
physical control by a built-in fan & tilt function on the chip.
Digital Zoom Off
Conventional DNR Camera
VX7-DSP Camera
Zero Defect
VX7-DSP with Perfect Adaptive Defect Correction delivers more clear pictures to be
captured in very low light illuminance by using two methods of algorithm for the defect
pixel compensation and performs the zero defect thoroughly.
Digital Zoom On
DIS (Digital Image Stabilization)
VX7-DSP delivers the digital image stabilization and the picture accuracy for anti-shaking
compensation against the exterior influence such as wind and vibration after installing
camera and permits more stable images in video output. VX7-DSP enables to get the
moving direction information of the objects per field as the chip has a built-in image
tracking module.
DIS Off
CCD Defects
Polygonal Privacy Masking (Polygonal, 8 Colors)
Sens-Up (x512, DSS)
VX7-DSP permits high quality pictures by supporting a long time of the exposure more
than 1/60sec. [NTSC] and enables to recognize the shape and color of suspended object
under the no light condition in case of the exposure of more than 8sec. (x512).
DSS Off
DIS On
Zero Defects
DSS On
VX7-DSP ensures to protect the privacy for the private and specific areas onto the video
signal output by polygonal masking function very conveniently and exactly. VX7-DSP
allows the size and position of masking area to be controlled very easily and conveniently
and 8 areas masking setting which is user programmable in color, brightness ad mosaic.
Privacy Off
Privacy On
Eclipse
VX7-DSP technology enables to recognize a visible car license plate clearly by
blocking unnecessary lights.
Signal-to-Noise Ratio
The SNR (signal-to-noise ratio) refers to the analog-to-digital conversion; this is the error
signal caused by the constant conversion of the signal. In other words when a camera is
viewing an animated object it is constantly recapturing the image and converting it, the
higher the SNR the smoother the capture.
Eclipse Off
10
Toll Free: (800) 510-6528
www.veilux.net
Eclipse On
CAMERA TERMS & FEATURES
Technical Glossary
600 TV Lines Ultra High Resolution
SuperHAD CCD
The horizontal resolution of 600 TV Lines at Color mode and 700 TV Lines at Black /
White mode by using a high density CCD in our VX7-DSP. VX7-DSP technology performs
vivid and obvious image output with ultra high horizontal resolution by using a own
De-mosaic interpolation algorithm and also the specialized and built-in sharpness filter.
HAD (hole accumulation diode) is a special chipset designed by SONY that uses
microscopic lenses right on the CCD. Allowing the camera to gather light more efficiently
even in the dark that results in better picture quality in low light situations.
Without
Conventional Camera
With
VX7-DSP Camera
Automatic White Balance
WDR (Wide Dynamic Range)
VX7-DSP delivers a powerful Wide Dynamic Range to the camera to provide the best
pictures in interior and exterior conditions under extreme high contrasts between
lightness and darkness and automatically compensates a necessary light level to get
detailed information in the dark park without saturation from the bright part. Our VX7-DSP
technology enables the WDR function to be very efficient in normal CCD by using Dual
Shutter (Long & Short shutter) algorithm and the specialized AE (Auto Exposure) and
intelligent image processing.
The automatic white balance feature is a function in which the camera calculates the
overall color in the current view and color corrects it. The camera uses a reference point
that closest represents white and re-balances the other colors to match giving a crisp
view unhindered by temperature tint. The temperature tint is the blue tint caused by the
cold temperature in the early morning and orange and yellow tint in the afternoon when
it is hottest.
Afternoon
WDR Off
Morning
WDR On
White Balance
High Sensitivity True Day & Night
VX7-DSP loaded with Day & Night function delivers the high quality of the color image
and performs while converting the color into monochrome automatically as under less
than the specific level of the sensitivity. VX7-DSP is more superior in the Sense-Up
function with x512 and 3D DNR very effectively to ensure a clear image in the darkness.
Conventional Camera
VX7-DSP Camera
Lux
Lux is the unit measuring the intensity of light. The light of a full moon is about 0.1Lux
and the higher the number the less visible objects and scene will be.
0.3Lux
0.1Lux
Automatic Gain Control
The automatic gain control is a control circuit that systematically increase the intensity
of a signal if it is weak and decrease the intensity of a signal if it is to strong so that the
desired output signal remains constant.
Toll Free: (800) 510-6528
www.veilux.net
11
SVD-65MINI
3-Axis Dome Camera
DOME
CAMERAS
ITEM
SVD-65MINI
UNDERWATER
CAMERAS
Pick Up Element
1/3” SuperHAD CCD
Horizontal Resolution
650 TV Lines
Effective Picture
Elements (H * V)
PAL: 752 (H) x 582 (V)
NTSC: 768 (H) x 494 (V)
BOX
CAMERAS
BULLET
CAMERAS
S/N Ratio
More than 48dB
Clock Frequency (MHZ)
NTSC: 28.636, PAL: 28.375
Scanning System
2:1 Interlace
Minimum illumination
0.000001 Lux (f1.2 20IRE)
Synchronous System
Internal, Negative Sync.
Auto Electronic Shutter
NTSC: 1/60s ~ 1/100,000s
PAL: 1/50s ~ 1/100,000s
Gamma Characteristic
0.45
Video Output
1.0 Vp-p, 75Ω
Auto Gain Control
Auto
Power / Current
9VDC ~ 15VDC (Recommendation 12VDC)
Lens
3.6mm
Dimension (mm)
93mm(ø) x 64mm(H)
Weight (g)
~250
Storage Temperature
-30°C ~ +60°C
Operation Temperature
-10°C ~ +45°C
FEATURES
PAN / TILT /
ZOOM CAMERAS
•Sensor (CCD) - Adopt 1/3” High Resolution Color CCD Sensor
•Auto Gain Control (AGC) - Built-in Auto Gain Control (AGC)
Circuit. The Color Camera Can Get High Definition Picture in
Low Lux Condition
•Auto Electronic Shutter (AES) - Built-in Auto Electronic
Shutter Function. The Color Camera’s AES Speed Can Reach
1/100,000s
•Gamma Characteristic - Camera Gamma Characteristic is 0.45
•Scanning Mode - NTSC or PAL Mode
93 mm
LICENSE
PLATE CAMERA
Gain
AGC Auto
Control
OFF
650
TV LINES
33 mm
64 mm
12
Toll Free: (800) 510-6528
www.veilux.net
3-AXIS
ON
0.000001(f1.2)
LUX
VOLTAGE
12DC
SVD-70L2810
3-Axis Dome Camera
DOME
CAMERAS
ITEM
SVD-58L2810
UNDERWATER
CAMERAS
Pick Up Element
1/3” SuperHAD CCD
Horizontal Resolution
700 TV Lines
Effective Picture
Elements (H * V)
PAL: 752 (H) x 582 (V)
NTSC: 768 (H) x 494 (V)
S/N Ratio
More than 48dB
BOX
CAMERAS
BULLET
CAMERAS
Clock Frequency (MHZ)
NTSC: 28.636, PAL: 28.375
Scanning System
2:1 Interlace
Minimum illumination
0.1 Lux
Synchronous System
Internal, Negative Sync.
Auto Electronic Shutter
NTSC: 1/60s ~ 1/100,000s
PAL: 1/50s ~ 1/100,000s
Gamma Characteristic
0.45
Video Output
1.0 Vp-p, 75Ω
Auto Gain Control
Auto
Power / Current
12VDC (+/- 10%) / 120mA
Lens
2.8~10mm
Dimension (mm)
118 x 102
Weight (g)
300
Storage Temperature
-30°C ~ +60°C
Operation Temperature
-10°C ~ +45°C
FEATURES
PAN / TILT /
ZOOM CAMERAS
•Sensor (CCD) - Adopt 1/3” High Resolution Color CCD Sensor
•Auto Gain Control (AGC) - Built-in Auto Gain Control (AGC)
Circuit. The Color Camera Can Get High Definition Picture in
Low Lux Condition
•Auto Electronic Shutter (AES) - Built-in Auto Electronic
Shutter Function. The Color Camera’s AES Speed Can Reach
1/100,000s
•Gamma Characteristic - Camera Gamma Characteristic is 0.45
•Scanning Mode - NTSC or PAL Mode
118 mm
LICENSE
PLATE CAMERA
Gain
AGC Auto
Control
OFF
13
102 mm
52 mm
700
TV LINES
Toll Free: (800) 510-6528
www.veilux.net
3-AXIS
ON
0.1
LUX
VOLTAGE
12DC
•1/3˝ SuperHAD II CCD
•High Resolution 600TV Lines
•Day & Night Function
•WDR (Wide Dynamic Range)
•3D DNR (Digital Noise Reduction)
•Sens-Up Function (x512)
•Internal / Line Lock Function
•LSC (Lens Shading Compensation)
•Privacy Mask (Polygonal Mosaic)
•DIS (Digital Image Stabilization
•Eclipse Function
•Zero Defect
•O.S.D. Menu Function
•3-Axis Gimbal
•Plastic Dome Case
•Motion Detection
•Digital Zoom (x1 ~ x10)
•Backlight Compensation
H/V 15.734 / 59.94 Hz
H/V 15.625 / 50 Hz
Sync Line Lock
H/V 15.750 / 60 Hz
H/V 15.625 / 50 Hz
Scanning System
2: 1 Interlace
Horizontal Res.
600TV Lines (Max.) / 700TV Lines (B/W)
Min. Illumination
Sense-Up Off
0.12 Lux (15 IRE), 0.2 Lux (30 IRE),
0.4 Lux (50 IRE) F1.2
Min. Illumination
Sense-Up On
0.0002 Lux (15 IRE), 0.0005 Lux (30 IRE),
0.0008 Lux (50 IRE) F1.2
Video Output
1.0 Vp-p / 75ohm Video 0.714 Vp-p
Y Correction
0.45
S/N
More than 52dB (AGC OFF)
O.S.D.
Lens, E-Shutter, Backlight, WDR, AGC, Sens-Up, White
Balance, Day & Night, Motion, Mirror, Sharpness, Gamma,
Freeze, NEGA, DNR, D-Zoom, LSC, Eclipse, DIS, Privacy,
Communication, Sync, Camera-ID, Title
Electronic Shutter
1/60~1/120,000 sec.
Privacy Masking
8 Windows (Polygonal, 8 Colors)
Day & Night
Color / BW / Auto / EXT
Motion Detection
On / Off
Digital Zoom
x1.0 ~ x10
Sens-Up (Low Shutter)
Off ~ x512
Sync
Auto / Internal / Digital Line Lock
White Balance
ATW / AWC / Manual / Push
WDR
On / Off (Step 1, Step 2, Step 3)
3D-DNR / AGC
On / Off (Off, Low, Mid, High)
LSC / DIS / Eclipse
On / Off
Lens
Aspherical 2.8~12mm DC Auto Iris Lens
Oper Temp’ / Hum’
-20°C ~ 60°C / 30% ~ 80%
1/50~1/120,000 sec
Storage Temp’ / Hum’
-30°C ~ 60°C / 20% ~ 90%
Power (Max.)
12VDC, 260mA / 24VAC, 170mA
Dimension / Weight
144(Ø) x 103mm(H) / About 600g
144 mm
OFF
ON
Auto White
AWB Balance
Back Light
BLC Compensation
OFF
ON
VOLTAGE
12DC
24AC
0.0002
LUX
600
TV LINES
DC AUTO IRIS
3-AXIS
MIRROR
FUNCTION
10x ZOOM
103 mm
55 mm
Gain
AGC Auto
Control
UNDERWATER
CAMERAS
1/3” SuperHAD II CCD
Sync Internal
BOX
CAMERAS
Image Sensor
BULLET
CAMERAS
PAL
PAN / TILT /
ZOOM CAMERAS
FEATURES
SVD-60DNL2812D
NTSC
LICENSE
PLATE CAMERA
ITEM
Signal System
DOME
CAMERAS
SVD-60DNL2812D
Dual Power Day & Night WDR 3D DNR Dome Camera
Toll Free: (800) 510-6528
www.veilux.net
14
SVD-60IR30L2812D
Dual Power Day & Night WDR 3D DNR IR Dome Camera
DOME
CAMERAS
ITEM
SVD-60IR30L2812D
UNDERWATER
CAMERAS
BOX
CAMERAS
BULLET
CAMERAS
PAN / TILT /
ZOOM CAMERAS
TV System
NTSC
Image Sensor
1/3” SuperHAD II CCD
PAL
Sync Internal
H/V 15.734 / 59.94 Hz
H/V 15.625 / 50 Hz
Sync Line Lock
H/V 15.750 / 60 Hz
H/V 15.625 / 50 Hz
Scanning System
2 : 1 Interlace
Horizontal Res.
600TV Lines (Max.) / 700TV Lines (B/W)
Min. Illumination
Sense-Up Off
0.12 Lux (15 IRE), 0.2 Lux (30 IRE), 0.4 Lux (50 IRE) F1.2
Min. Illumination
Sense-Up On
0 Lux (15 IRE), 0 Lux (30 IRE),
0 Lux (50 IRE) F1.2
Video Output
1.0Vp-p / 75ohm Video 0.714Vp-p
Y Correction
0.45
S/N
More Than 52dB (AGC off)
O.S.D.
Lens, E-Shutter, Backlight, WDR, AGC, Sens-Up, White
Balance, Day & Night, Motion, Mirror, Sharpness, Gamma,
Freeze, NEGA, DNR, D-Zoom, LSC, Eclipse, DIS, Privacy,
Communication, Sync, Camera-ID, Title
Electrical Shutter
1/60 ~ 1/120,000
Privacy Masking
8 Windows (Polygonal, 8 Colors)
Day & Night
Color / BW / Auto / EXT
Motion Detection
On / Off
Digital Zoom
x1.0 ~ x10
Sens-Up (Low Shutter)
Off ~ x512
Sync
Auto / Internal / Digital Line Lock
1/50 ~ 1/120,000
FEATURES
LICENSE
PLATE CAMERA
White Balance
ATW / AWC / Manual / Push
WDR
On / Off (Step 1, Step 2, Step 3)
3D-DNR / AGC
On / Off (Off, Low, Mid, High)
LSC / DIS / Eclipse
On / Off
Lens
Aspherical 2.8~12mm DC Auto Iris Lens
IR LED
30 Units 850nm Infrared LED, 20,000 Hrs
Beam Spread
36° + 56°
Night View Distance
Indoor 45m / Outdoor 25m
Oper Temp’ / Hum’
-20ºC~60ºC / 30%~80%
Stor Temp’ / Hum’
-30ºC~60ºC / 20%~90%
Power Supply
12VDC, 510mA / 24VAC, 340mA
Dimension / Weight
144(ø) x 103(H) / About 640g
144 mm
•1/3˝ SuperHAD II CCD
•High Resolution 600TV Lines
•IR LED (Main): 30 Units 850nm Infrared LED, 20,000 Hrs
•Night View Distance: Indoor 45m / Outdoor 25m
•External Control: Tele / Wide, Near / Far, O.S.D., Service Video
•WDR (Wide Dynamic Range)
•3D DNR (Digital Noise Reduction)
•LSC (Lens Shading Compensation)
•3-Axis Gimbal
•Privacy Mask (Polygonal Mosaic)
•Zero Defect
•Internal / Line Lock Function
•Eclipse Function
•DIS (Digital Image Stabilization)
•Motion Detection
•Sens-Up Function (x512)
•Plastic Dome Case
•Digital Zoom (x1 ~ x10)
•Backlight Compensation
MIRROR
FUNCTION
15
103 mm
55 mm
VOLTAGE
Toll Free: (800) 510-6528
www.veilux.net
12DC
24AC
600
TV LINES
DAY
OFF
Auto White
ON
AWB Balance
DC AUTO IRIS
Gain
AGC Auto
Control
0
LUX
OFF
D&N
NIGHT
Back Light
BLC Compensation
IR LED
10x ZOOM
ON
3-AXIS
SVV-60CDNL2812D
•1/3˝ SuperHAD II CCD
•High Resolution 600TV Lines
•WDR (Wide Dynamic Range)
•3D-DNR (Digital Noise Reduction)
•Digital Zoom (x1 ~ x10)
•LSC (Lens Shading Compensation)
•Privacy Mask (Polygonal Mosaic)
•Sens-Up Function (x512)
•Internal / Line Lock Function
•DIS (Digital Image Stabilization)
OFF
ON
Auto White
0.0002
LUX
NIGHT
12DC
600TV Lines (Max.) / 700TV Lines (B/W)
Min. Illumination
Sense-Up Off
0.12 Lux (15 IRE), 0.2 Lux (30 IRE), 0.4 Lux (50 IRE) F1.2
Min. Illumination
Sense-Up On
0.0002 Lux (15 IRE), 0.2 Lux (30 IRE), 0.4 Lux (50 IRE) F1.2
Video Output
1.0Vp-p / 75ohm Video 0.714Vp-p
Y Correction
0.45
S/N
More than 52dB (AGC OFF)
O.S.D.
Lens, E-Shutter, Backlight, WDR, AGC, Sens-Up, White
Balance, Day & Night, Motion, Mirror, Sharpness, Gamma,
Freeze, NEGA, DNR, D-Zoom, LSC, Eclipse, DIS, Privacy,
Communication, Sync, Camera-ID, Title
Electrical Shutter
1/60~1/120,000
Privacy Masking
8 Windows (Polygonal, 8 Colors)
Day & Night
Color / BW / Auto / EXT
Motion Detection
Low, Middle, High, Off (Selectable)
Digital Zoom
x1.0 ~ x10
Sens-Up (Low Shutter)
Off ~ x512
Sync
Auto / Internal / Digital Line Lock
White Balance
ATW / AWC / Manual / Push
WDR
On / Off (Step 1, Step 2, Step 3)
3D-DNR / AGC
On / Off (Off, Low, Mid, High)
LSC / DIS / Eclipse
On / Off
Lens
Aspherical 2.8~12mm DC Auto Iris Lens
Oper Temp’ / Hum’
-20°C ~ 60°C / 30% ~ 80%
Storage Temp’ / Hum’
-30°C ~ 60°C / 20% ~ 90%
Power (Max.)
12VDC, 260mA / 24VAC, 170mA
Dimension / Weight
145(Ø) x 106mm(H) / About 1,040g
3-AXIS
10x ZOOM
106 mm
MIRROR
FUNCTION
24AC
1/50~1/120,000
UNDERWATER
CAMERAS
Horizontal Resolution
BOX
CAMERAS
2:1 Interlace
BULLET
CAMERAS
H/V 15.625 / 50 Hz
Scanning System
VANDALPROOF
600
TV LINES
DC AUTO IRIS
H/V 15.625 / 50 Hz
H/V 15.750 / 60 Hz
145 mm
Back Light
ON
H/V 15.734 / 59.94 Hz
Sync Line Lock
DAY
VOLTAGE
OFF
1/3” SuperHAD II CCD
Sync Internal
D&N
AWB Balance
BLC Compensation
Image Sensor
56 mm
Gain
AGC Auto
Control
•Day & Night
•Zero Defect
•Eclipse Function
•Motion Detection
•O.S.D. Menu Function
•3-Axis Gimbal
•Backlight Compensation
•IR Cut Filter Removable
PAL
PAN / TILT /
ZOOM CAMERAS
FEATURES
SVV-60DNL2812D
NTSC
LICENSE
PLATE CAMERA
ITEM
Signal System
DOME
CAMERAS
Dual Power True Day & Night WDR 3D DNR Vandal Proof Dome Camera
Toll Free: (800) 510-6528
www.veilux.net
16
SVV-60IRC40L2812D
Dual Power True Day & Night Underwater Proof WDR 3D DNR
Vandal Proof IR Dome Camera
DOME
CAMERAS
ITEM
SVV-60IRC40L2812D
UNDERWATER
CAMERAS
Image Sensor
1/3" SONY CCD (ICX 638 / ICX 639)
Effective Pixels
768(H) x 494(V) - NTSC
768(H) x 494(V) - PAL
Scanning Frequency
15.734Khz / 59.95Hz - NTSC
15.625Khz / 50Hz - PAL
Scanning System
2:1 Interlace
Shutter Speed
1/60 ~ 1/120,000 Sec.
NTSC
1/50 ~ 1/120,000 Sec.
PAL
BOX
CAMERAS
BULLET
CAMERAS
PAN / TILT /
ZOOM CAMERAS
Resolution
600 TVL (Color) / 700 TVL (B/W)
S/N Ratio
More Than 50dB (AGC Off)
Wide Dynamic Range
52dB (x128)
Min. Illumination
0.003 Lux (F1.2 / 50 IRE (LED Off)) Sens-Up x512
Gamma
r=0.45
Lens
IR Filter Change Type DC Auto Iris Lens
(2.8 ~ 11mm, 3.5 ~ 16mm)
Sync System
Internal
Auto Gain Control
High / Middle / Low / Off Selectable
Sens Up
Auto / Fixed / Off (Selectable x2 ~ x512)
Motion Detection
On / Off (8 Zone / Output OSD)
DNR
On / Off (1 ~ 32 Level Adjustable)
Privacy
On / Off (12 Zone / Output OSD)
Mirror
On / Off (H-Rev, V-Rev)
D & N Selection
Color / Auto / Extern / BW Selectable
Freeze
N/A
Sharpness
Level Adjustable
White Balance
ATW / AWC / Manual / Outdoor (1,800K ~ 10,500K)
On Screen Display
Support
Video Out
VBS 1.0 Vp-p / 75Ω
Power
DC 12V / 430mA, (6.0W) / AC 24V / 400mA, (10.0W)
FEATURES
Regulated DC 12V 1.0A or AC 24V 1.0A Power Supply
Operating Temps
-10°C ~ +50°C
IR LED
Wave 850mm / 40 Ea.
Outside Control
Focus (Far - Near) / Zoom (Wide - Tele)
Gain
AGC Auto
Control
?? mm
?? mm
LICENSE
PLATE CAMERA
Power Supply
•Hi Resolution - 600 TV Lines
•WDR - Wide Dynamic Range
•Advanced 3D Filtering DNR (Digital Noise Reduction) Saving Up to
70% DVR Storage
•True Day & Night Function
•DIS (Digital Image Stabilizer) Stabilises Images by Reducing Flickering
•HLC (High Light Compensation) Distinct Recognition of a License Plate
•Sense-Up (x256), 6 Points Privacy Masking Areas
•ICON OSD (On-Screen Display) Control
•Motion Detection, Second Video Output
•IP-68 - Perfect Waterproof
OFF
ON
Auto White
AWB Balance
VOLTAGE
D&N
600
TV LINES
NIGHT
DAY
DC AUTO IRIS
17
Toll Free: (800) 510-6528
www.veilux.net
MIRROR
FUNCTION
0
LUX
3-AXIS
12DC
24AC
VANDALPROOF
IR LED
SVS-60CDNRD
Dual Power True Day & Night WDR 3D DNR Color Camera
1/3” SuperHAD II CCD
Sync Internal
H/V 15.734 / 59.94 Hz
H/V 15.625 / 50 Hz
Sync Line Lock
H/V 15.750 / 60 Hz
H/V 15.625 / 50 Hz
Scanning System
2 : 1 Interlace
Horizontal Res.
600TV Lines (Max), 700TV Lines (B/W)
Min. Illumination
Sense-Up Off
0.12 Lux (15 IRE), 0.2 Lux (30 IRE), 0.4 Lux (50 IRE) F1.2
Min. Illumination
Sense-Up On
0.0002 Lux (15 IRE), 0.0005 Lux (30 IRE),
0.0008 Lux (50 IRE) F1.2
Video Output
1.0Vp-p / 75ohm Video 0.714Vp-p
Y Correction
0.45
S/N
More than 52dB (AGC off)
O.S.D.
Lens, E-Shutter, Backlight, WDR, AGC, Sens-Up, White-Balance,
Day & Night, Motion, Mirror, Sharpness, Gamma, Freeze, Nega,
DNR, D-Zoom, LSC, Eclipse, DIS, Privacy, Communication, Sync,
Camera-ID, Title
Electrical Shutter
1/60 ~ 1/120,000
Privacy Masking
8 Windows (Polygonal, 8 Colors)
OFF
ON
D&N
NIGHT
MIRROR
FUNCTION
DAY
Color / BW / Auto / EXT
Motion Detection
On / Off
Digital Zoom
x1.0 ~ x10
Sens-Up (Low Shutter)
Off ~ x512
Sync
Auto / Internal / Digital Line Lock
White Balance
ATW / AWC / Manual / Push
WDR
On / Off (Step 1, Step 2, Step 3)
PAN / TILT /
ZOOM CAMERAS
Day & Night
3D-DNR
On / Off (Off, Low, Mid, High)
LSC / DIS / Eclipse
On / Off
12DC
AGC
Low / Middle / High / Off
24AC
Lens
C/CS Mount
Oper Temp’/Hum’
-20°C ~ 60°C / 30% ~ 80%
Store Temp’/Hum’
-30°C ~ 60°C / 20% ~ 90%
Power (Max.)
12VDC / 24VAC (Free Voltage Optional)
Gain
AGC Auto
Control
Dimension
61mm(V) x 55mm(H) x 106mm(L)
OFF
Weight
About 460g
VOLTAGE
600
TV LINES
ON
0.0002
LUX
LICENSE
PLATE CAMERA
Back Light
BLC Compensation
1/50 ~ 1/120,000
UNDERWATER
CAMERAS
Image Sensor
106 mm
WDR 3D DNR
Optional Lens
SUPER HIGH RESOLUTION DIGITAL COLOR CAMERA
VL-0358A - 3.5mm ~ 8.0mm
VL-02812A - 2.8mm ~ 12mm
VL-05100A - 5mm ~ 100mm
UP
L
55 mm
Auto White
AWB Balance
•Digital Zoom (x1 ~ x10)
•Day & Night Function
•Motion Detection
•O.S.D. Menu Function
•Sens-Up Function (x512)
•Internal / Line Lock Function
•Backlight Compensation
•Free Voltage Optional
PAL
BOX
CAMERAS
NTSC
FEATURES
•1/3˝ SuperHAD II CCD
•High Resolution 600TV Lines
•WDR (Wide Dynamic Range)
•3D DNR (Digital Noise Reduction)
•LSC (Lens Shading Compensation)
•Privacy Mask (Polygonal Mosaic)
•Zero Defect
•Eclipse Function
•IR Cut Filter Removable
SVS-60DNRD
TV System
BULLET
CAMERAS
ITEM
DOME
CAMERAS
(box camera does not come with shown lens)
VIDEO
R
DOWN
POWER
DC IRIS
DC 12V
AC 24V
Toll Free: (800) 510-6528
www.veilux.net
18
SVB-70IR48
Day & Night IR Bullet Camera
DOME
CAMERAS
ITEM
SVB-58IR48
UNDERWATER
CAMERAS
Signal System
NTSC
Image Sensor
1/3” CCD
PAL
Horizontal Resolution
700 TV Lines
TV System
NTSC
Sync System
Internal Synchronization
Lens
3.6mm Board Lens
LED
48pcs x Diameter 5 LED, 40m IR Range
Minimum Illumination
0.1 Lux / F1.2
BOX
CAMERAS
BULLET
CAMERAS
PAN / TILT /
ZOOM CAMERAS
Synchronous System
Internal, Negative Sync
S/N Ratio
48 dB (AGC Off)
Scanning System
NTSC: 525 Lines 60 Field / sec
Electronic Shutter Times
NTSC 1/60 - 1/100,000 sec
Gamma Characteristic
0.45
Video Output
1.0 Vp-p, 75 Ohms
White Balance
Auto
Voltage
12VDC (+/-10%)
Current
700mA
Dimension
128mm(L) x 82mm(W) x 70mm(H)
Weight
500g
Operation Temperature
-10˚C - +45˚C (RH95% Max)
Color
Silver
128 mm
FEATURES
•1/3˝ CCD
•700 TV Lines
•High Resolution: Vivid Sharp Picture
•Day & Night Function
•3.6mm Board Lens
•48 Units Infrared LED
•Back Light Compensation
LICENSE
PLATE CAMERA
Auto White
AWB Balance
0.1
LUX
Back Light
BLC Compensation
OFF
173 mm
IR LED
ON
VOLTAGE
12DC
700
TV LINES
82 mm
D&N
NIGHT
70 mm
19
Toll Free: (800) 510-6528
www.veilux.net
DAY
Gain
AGC Auto
Control
OFF
ON
Auto White
AWB Balance
VOLTAGE
Back Light
600
TV LINES
BLC Compensation
OFF
IR LED
ON
MIRROR
FUNCTION
0
LUX
12DC
24AC
DC AUTO IRIS
10x ZOOM
H/V 15.734 / 59.94 Hz
H/V 15.625 / 50 Hz
Sync Line Lock
H/V 15.750 / 60 Hz
H/V 15.625 / 50 Hz
Scanning System
2 : 1 Interlace
Horizontal Res.
600TV Lines (Max) / 700TV Lines (B/W)
Min. Illumination
Sense-Up Off
0.12 Lux (15 IRE), 0.2 Lux (30 IRE), 0.4 Lux (50 IRE) F1.2
Min. Illumination
Sense-Up On
0 Lux (15 IRE), 0 Lux (30 IRE), 0 Lux (50 IRE) F1.2
Video Output
1.0Vp-p / 75ohm Video 0.714Vp-p
Y Correction
0.45
S/N
More than 52dB (AGC off)
O.S.D.
Lens, E-Shutter, Backlight, WDR, AGC, Sens-Up, White-Balance, Day &
Night, Motion, Mirror, Sharpness, Gamma, Freeze, Nega, DNR, D-Zoom,
LSC, Eclipse, DIS, Privacy, Communication, Sync, Camera-ID, Title
Electrical Shutter
1/60 ~ 1/120,000
Privacy Masking
8 Windows (Polygonal, 8 Colors)
Day & Night
Color / BW / Auto / EXT
Motion Detection
On / Off
Digital Zoom
x1.0 ~ x10
Sens-Up (Low Shutter)
Off ~ x512
Sync
Auto / Internal / Digital Line Lock
White Balance
ATW / AWC / Manual / Push
WDR
On / Off (Step 1, Step 2, Step 3)
3D-DNR
On / Off (Off, Low, Mid, High)
LSC / DIS / Eclipse
On / Off
AGC
Low / Middle / High / Off
1/50 ~ 1/120,000
Lens
Aspherical 3.5~16mm DC Auto Iris Lens
IR LED
28 Units 850nm Infrared LED,
20,000 Hrs
Beam Spread
36° + 56°
Night View Distance
Indoor 35m / Outdoor 25m
Operate Temp’ / Hum’
-20°C ~ 60°C / 30% ~ 80%
66 Units 850nm Infrared LED,
20,000 Hrs
Indoor 50m / Outdoor 30m
Storage Temp’ / Hum’
-30°C ~ 60°C / 20% ~ 90%
Power (Max.)
12VDC, 510mA / 24VAC, 340mA
12VDC, 940mA / 24VAC, 620mA
Dimension
74.5(ø) x 151(L)
94(ø) x 166(L)
Weight
About 1,350g
About 2,350g
UNDERWATER
CAMERAS
1/3” SuperHAD II CCD
Sync Internal
BOX
CAMERAS
Image Sensor
BULLET
CAMERAS
•1/3˝ SuperHAD II CCD
•High Resolution 600TV Lines
•External Control: Tele / Wide, Near / Far, O.S.D., Service Video
•Zero Defect
•WDR (Wide Dynamic Range)
•Eclipse Function
•3D DNR (Digital Noise Reduction)
•Day & Night Function
•LSC (Lens Shading Compensation)
•Motion Detection
•Privacy Mask (Polygonal Mosaic)
•O.S.D Menu Function
•Built-in Concealed Cable Bracket
•Backlight Compensation
•Sens-Up Function (x512)
•Digital Zoom (x1 ~ x10)
•Internal / Line Lock Function
•IR Cut Filter Removable
•DIS (Digital Image Stabilization)
PAL
PAN / TILT /
ZOOM CAMERAS
FEATURES
SVB-60IRC28L3516D
NTSC
LICENSE
PLATE CAMERA
ITEM
TV System
DOME
CAMERAS
SVB-60IRC28L3516D
Dual Power True Day & Night WDR 3D DNR IR Bullet Camera
88 mm
D&N
NIGHT
DAY
Toll Free: (800) 510-6528
www.veilux.net
20
Gain
AGC Auto
Control
OFF
ON
Auto White
AWB Balance
VOLTAGE
Back Light
600
TV LINES
BLC Compensation
OFF
IR LED
ON
MIRROR
FUNCTION
0
LUX
12DC
24AC
DC AUTO IRIS
10x ZOOM
H/V 15.734 / 59.94 Hz
H/V 15.625 / 50 Hz
Sync Line Lock
H/V 15.750 / 60 Hz
H/V 15.625 / 50 Hz
Scanning System
2 : 1 Interlace
Horizontal Res.
600TV Lines (Max) / 700TV Lines (B/W)
Min. Illumination
Sense-Up Off
0.12 Lux (15 IRE), 0.2 Lux (30 IRE), 0.4 Lux (50 IRE) F1.2
Min. Illumination
Sense-Up On
0 Lux (15 IRE), 0 Lux (30 IRE), 0 Lux (50 IRE) F1.2
Video Output
1.0Vp-p / 75ohm Video 0.714Vp-p
Y Correction
0.45
S/N
More than 52dB (AGC off)
O.S.D.
Lens, E-Shutter, Backlight, WDR, AGC, Sens-Up, White-Balance, Day &
Night, Motion, Mirror, Sharpness, Gamma, Freeze, Nega, DNR, D-Zoom,
LSC, Eclipse, DIS, Privacy, Communication, Sync, Camera-ID, Title
Electrical Shutter
1/60 ~ 1/120,000
Privacy Masking
8 Windows (Polygonal, 8 Colors)
Day & Night
Color / BW / Auto / EXT
Motion Detection
On / Off
Digital Zoom
x1.0 ~ x10
Sens-Up (Low Shutter)
Off ~ x512
1/50 ~ 1/120,000
Sync
Auto / Internal / Digital Line Lock
White Balance
ATW / AWC / Manual / Push
WDR
On / Off (Step 1, Step 2, Step 3)
3D-DNR
On / Off (Off, Low, Mid, High)
LSC / DIS / Eclipse
On / Off
AGC
Low / Middle / High / Off
Lens
Aspherical 3.5~16mm DC Auto Iris Lens
IR LED
28 Units 850nm Infrared LED,
20,000 Hrs
Beam Spread
36° + 56°
Night View Distance
Indoor 35m / Outdoor 25m
Operate Temp’ / Hum’
-20°C ~ 60°C / 30% ~ 80%
66 Units 850nm Infrared LED,
20,000 Hrs
Indoor 50m / Outdoor 30m
Storage Temp’ / Hum’
-30°C ~ 60°C / 20% ~ 90%
Power (Max.)
12VDC, 510mA / 24VAC, 340mA
12VDC, 940mA / 24VAC, 620mA
Dimension
74.5(ø) x 151(L)
94(ø) x 166(L)
Weight
About 1,350g
About 2,350g
UNDERWATER
CAMERAS
1/3” SuperHAD II CCD
Sync Internal
BOX
CAMERAS
Image Sensor
BULLET
CAMERAS
•1/3˝ SuperHAD II CCD
•High Resolution 600TV Lines
•External Control: Tele / Wide, Near / Far, O.S.D., Service Video
•Zero Defect
•WDR (Wide Dynamic Range)
•Eclipse Function
•3D DNR (Digital Noise Reduction)
•Day & Night Function
•LSC (Lens Shading Compensation)
•Motion Detection
•Privacy Mask (Polygonal Mosaic)
•O.S.D Menu Function
•Built-in Concealed Cable Bracket
•Backlight Compensation
•Sens-Up Function (x512)
•Digital Zoom (x1 ~ x10)
•Internal / Line Lock Function
•IR Cut Filter Removable
•DIS (Digital Image Stabilization)
PAL
PAN / TILT /
ZOOM CAMERAS
FEATURES
SVB-60IRC66L3516D
NTSC
LICENSE
PLATE CAMERA
ITEM
TV System
DOME
CAMERAS
SVB-60IRC66L3516D
Dual Power True Day & Night WDR 3D DNR IR Bullet Camera
112 mm
D&N
NIGHT
DAY
Toll Free: (800) 510-6528
www.veilux.net
21
SVB-60IRC80L650D
Dual Power True Day & Night WDR IR Bullet Super DNR Camera
DOME
CAMERAS
(this camera is for special order only)
ITEM
SVB-60IRC80L650D
UNDERWATER
CAMERAS
Signal System
NTSC
Image Sensor
1/3” Super HAD CCD
PAL
Effective Pixels
768(H) x 494(V)
Resolution
600 TV Lines
Synchronization
Internal
Frequency
15.734 KHz(H)
59.94 Hz(V)
752(H) x 582(V)
15.625 KHz (H)
50.00 Hz(V)
BOX
CAMERAS
Video Output
1.0 Vp-p Composite Video at 75 ohm
Burst Level
0.286 Vp-p
S/N Ratio
More than 50db (y, Aperture, AGC OFF)
Min. Illumination
0 Lux (F1.2 20IRE, Sense-up X32)
Sense Up
Max. 32 Times, 0.00001 Lux
Gamma Correction
=0.45
AGC
+18dB Max.
IRIS Control
Electrical IRIS / Lens IRIS (DC Lens)
BULLET
CAMERAS
PAN / TILT /
ZOOM CAMERAS
Electronic Shutter
1/60~1/120,000 sec.
O.S.D
Lens, Brightness, Backlight, Shutter, AGC, Sense Up,
White Balance, Day / Night, Motion, Privacy, Title, Nega /
Posi, Sharpness, Mirror
1/50~1/120,000 sec
Lens
6~50mm DC Auto Iris Lens
IR LED (Main)
40 Units 850nm Infrared LED, 20,000 Hrs / 36° + 56°
SRLED
(Single Reflection LED)
20+20 Units 850nm Infrared LED, 20,000 Hrs / +-9°
Night View Distance
Outdoor 120m
Oper. Temp/Hum
-10°C ~ 50°C / 30%~80%
Stor. Temp/Hum
-20°C ~ 60°C / 20%~90%
Power Supply
12VDC / 24VAC
Dimensions
90(V) x 93(H) x 235(L)mm
LICENSE
PLATE CAMERA
323 mm
FEATURES
•1/3˝ Super HAD CCD
•High Resolution Over 600 TV Lines
•Day & Night
•IR LEDs (Main) 40 Units Infrared LEDs 20,000 Hrs 850nm
•SRLED (Single Reflection LED) 20+20 Units SRLED
20,000 Hrs 850nm
•Night View Distance: Outdoor 120m
•External Control: Tele/Wide, Near/Far, OSD, Service Video
•Privacy Function / Electronic IRIS
•DNR (Digital Noise Reduction)
•Controlled By OSD Menu
•Built-in Concealed Cable Bracket
•Stabilized Images by reducing flickering
•IR Cut Filter Removable
Gain
AGC Auto
Control
OFF
ON
Auto White
AWB Balance
VOLTAGE
Back Light
600
TV LINES
BLC Compensation
OFF
Toll Free: (800) 510-6528
www.veilux.net
IR LED
95 mm
200 mm
22
92 mm
ON
MIRROR
FUNCTION
0
LUX
12DC
24AC
FLICKERLESS
D&N
NIGHT
DC AUTO IRIS
DAY
Auto White
AWB Balance
OFF
ON
OPTICAL/
DIGITAL
ZOOM
ON
D&N
NIGHT
Image Sensor
1/4” Color CCD
Resolution
540 TV Lines (Day) / 680 TV Lines (Night)
Pan / Tilt Speed
Pan: 0.05°~400°/sec; Tilt: 0.03°~240°/sec
S/N Ratio
More than 50db (AGC OFF)
Min. illumination
0.1 Lux - Day / 0.01 Lux - Night
Gain Control
Auto / Manual
Back Light Comp’
Auto / Manual
36x
Lens
F1.6-F3.8 f=4-72mm
Panning Range
Pan: 0°~360° Continuous ; Tilt: 0°~90°
VOLTAGE
F1.6-F3.8 f=4-144mm
Preset Position No.
256
Auto Cruise
Auto Switch from 0 to 54 Preset Pos’ Sequentially
Pattern Scan
P/T/Z Scan from 55 to 63 Preset Pos’ Automatically
Comm. Port
RS-485
Baud Rate
1200bps, 2400bps, 4800bps, 9600bps, 19200bps
Spectra Address
0~255
Power Supply
24VAC
Track Speed
0°~100°/sec
Operating Temp
-25ºC ~ +70ºC (w/o Heater) /
-50ºC ~ +70ºC (with Heater)
optional mounts
S-6
W-6
I-6 - In-Ceiling Mount
W-6 - Wall Mount
S-6 - Surface Mount
P-6 - Pendant Mount
I-6
24AC
DAY
BOX
CAMERAS
18x
12x
BULLET
CAMERAS
Optical Zoom
Digital Zoom
PAL
P-6
540
TV LINES
Gain
AGC Auto
Control
OFF
Surface, In-Ceiling, Wall, Pole
NTSC
0.1
LUX
Back Light
BLC Compensation
Mounting Type
Signal System
PAN / TILT /
ZOOM CAMERAS
•Stabilized Images by Reducing Flickering
•Motion Auto Tracking, Intelligent Surveillance with Alarm Function
•Preset, Auto Cruise & Pattern Scan Function
•Multi Communication Protocol Supported, Baud Rate Programmable
•360° Continuous Pan
•0º to 9º Tilt From Horizontal Plane Auto Flip 180º
•Iris & Focus, Auto/ Manual
•White Balance, Auto/ Manual
•Back Light Compensation, Auto/ Manual
•Heater & Blower Included (Outdoor Only)
•Weatherproof (IP-66) - (Outdoor Only)
VP-ATDN36X
LICENSE
PLATE CAMERA
FEATURES
VP-ATDN18X
UNDERWATER
CAMERAS
ITEM
DOME
CAMERAS
VP-ATDN18X / VP-ATDN36X
Object Auto-Tracking Day & Night Camera
accesories
VP-PS - Power Supply
VM-POLE - Pole Mount
VM-CORNER - Corner Mount
PAN/TILT/ZOOM
FLICKERLESS
VM-CORNER
VP-PS
VM-POLE
Toll Free: (800) 510-6528
www.veilux.net
23
VP-ATDNC23X / VP-ATDNC27X
Object Auto-Tracking Day & Night Camera
optional model
DOME
CAMERAS
VP-FDNC23X / VP-FDNC27X | High-Speed Dome Camera
ITEM
VP-ATDNC23X
VP-ATDNC27X
UNDERWATER
CAMERAS
BOX
CAMERAS
BULLET
CAMERAS
PAN / TILT /
ZOOM CAMERAS
Mounting Type
Surface, In-Ceiling, Wall, Pole
Signal System
NTSC
Scanning System
2:1 Interface
Scanning Freq(H)
15.734 KHz
Scanning Freq(V)
59.94 Hz
Image Sensor
1/4” VEILUX SuperHAD CCD
Sync. Sensor
Internal
Total Pixels No.
811 (H) x 508 (V) 410K
Effective Pixels
768 (H) x 494 (V) 380K
Hor. Resolution
520 TV Lines
Video Output Level
1.0 Vp-p (75Ω, Composite)
Pan / Tilt Speed
Pan: 0.05°~400°/sec; Tilt: 0.03°~240°/sec
S/N Ratio
More than 48dB (AGC Off)
Digital Zoom
10x
Lens
23x Zoom Video AF
(F1.6 (W), F3.2 (T)
f=3.6~82.8mm)
Panning Range
Pan: 0°~360° Continuous; Tilt: 0°~90°
Track Speed
0°~100°/sec
Min. Illumination
Day Mode 1Lux (30IRE), Night Mode 0.5Lux (30IRE),
DSS 0.001Lux (128FLD, 30IRE)
Day & Night
Digital Slow Shutter
Power Supply
24VAC
PAL
27x Zoom Video AF
(F1.6 (W), F3.2 (T)
f=3.6~97.2mm)
FEATURES
optional mounts
LICENSE
PLATE CAMERA
S-6
W-6
I-6 - In-Ceiling Mount
W-6 - Wall Mount
S-6 - Surface Mount
P-6 - Pendant Mount
I-6
P-6
Auto White
accesories
VP-PS - Power Supply
VM-POLE - Pole Mount
VM-CORNER - Corner Mount
VM-CORNER
VP-PS
AWB Balance
Toll Free: (800) 510-6528
www.veilux.net
0.001
LUX
Back Light
BLC Compensation
OFF
ON
OPTICAL/
DIGITAL
ZOOM
VOLTAGE
520
TV LINES
D&N
NIGHT
VM-POLE
24
•1/4” VEILUX SuperHAD CCD / High Resolution: 520 TV Line
•Stabilized Images by Reducing Flickering
•Motion Auto Tracking, Intelligent Surveillance with Alarm Function
•Preset, Auto Cruise & Pattern Scan Function
•Multi Communication Protocol Supported, Baud Rate Programmable
•360° Continuous Pan
•0° to 9° Tilt From Horizontal Plane Auto Flip 180°
•Iris & Focus, White Balance, Backlight Compensation - Auto / Manual
•Weatherproof (IP-66) - (Outdoor Only)
•Built-in Auto Focus / Auto Iris
•TDN (ICR) / On-Screen Menu Control (OSD)
•Nine Backlight Compensation (BLC) Zones
•Video Transmission Distance Adjustable (3 Step)
•RS-232C TTL Interface / Electronic Sensitivity-up (DSS)
•24VAC
DAY
AUTO IRIS
24AC
FLICKERLESS
PAN/TILT/ZOOM
PAN / TILT / ZOOM ACCCESSORIES
I6 - IN-CEILING MOUNT
S6 - SURFACE MOUNT
•Pan / Tilt / Zoom Mount
•Indoor / Outdoor Use
•Aluminum in Black - Ring Color in White
•121mm (H) - Base
•229mm (H) - Total Height
•216mm (Diameter)
UNDERWATER
CAMERAS
PAN / TILT /
ZOOM CAMERAS
•Pan / Tilt / Zoom Mount
•Indoor Use
•Plastic in Black
BOX
CAMERAS
•Pan / Tilt / Zoom Mount
•Indoor / Outdoor Use
•Weatherproof IP-66
•Stainless Steel in Beige
•Built-in Heater & Blower
•Distance From Wall - 318mm
•305mm (H) x 241mm (Diameter)
•Pan / Tilt / Zoom Mount
•Stainless Steel in Beige
•241mm (H) - Pendant Shaft
•305mm (H) x 241mm (Diameter)
BULLET
CAMERAS
W6 - Wall Mount
P6 - Pendant Mount
DOME
CAMERAS
Housing, Mounts, & Power Supply
VP-PS - OUTDOOR WALL POWER SUPPLY
LICENSE
PLATE CAMERA
•Stainless Steel in Beige
•For Auto Tracking Pan / Tilt / Zoom Cameras
•Mounts Behind W6 Exterior Wall Mount
VM-CORNER - PAN / TILT / ZOOM CORNER MOUNT
•Stainless Steel in Beige
•203mm (W) x 165mm (D) x 248mm (H)
•For Use With W6 Outdoor PTZ Wall Mount
PAN / TILT / ZOOM POLE MOUNT - VM-POLE
•Stainless Steel in Beige
•203mm (W) x 216mm (D) x 254mm (H)
•For Use With W6 Outdoor PTZ Wall Mount
Toll Free: (800) 510-6528
www.veilux.net
25
VP-54CDN10X
Mini High Speed PTZ Camera
VP-54CDN10X
NTSC
Signal Format
1/4” Inter Line Transfer CCD
S/N Ratio
50DB (AGC Off, Weight On)
Resolution
540 TV Lines
Illumination
Color: 0.7 Lux; Black & White: 0.02 Lux
Day & Night
Yes
Optical Zoom
10x
Lens
f=3.8 ~ 38mm, F 1.8 ~ 3.2
BLC
AWC / Auto / Manual
BOX
CAMERAS
AGC
Auto / Manual
Pan / Tilt Speed
Pan: 0.05 ~ 400˚/sec; Tilt: 0.03 ~ 240˚/sec
Pan / Tilt Range
Pan: 0 ~ 360˚ Continuous;
Tilt: 0 ~ 90˚, Auto Flip
Presets
256
Auto Cruise
Auto Switch From 1 to 30 Preset Positions Sequentially
Pattern Scan
4 Routes Of Pattern Scan
Comm. Port
RS-485
Baud Rate
2400bps, 4800bps, 9600bps
Protocols
Pelco D, Pelco P
Operation Temp
-250˚C ~ +70˚C (w/o Heater)
Power
12VDC
BULLET
CAMERAS
Signal System
UNDERWATER
CAMERAS
DOME
CAMERAS
ITEM
PAL
FEATURES
PAN / TILT /
ZOOM CAMERAS
• Equipped With Samsung 10X Optical Zoom
• Built-in English OSD Menu
• Auto Actions (Such as Preset, Cruise, Pattern Scan Etc.)
On Power Up and Park
• Hi-Precision Motor Providing Stable and Precise
Performance
• Pan / Tilt Speed Adaptive to Zoom Times
• Integrated Design with Compact Construction and
High Reliability
LICENSE
PLATE CAMERA
Gain
AGC Auto
Control
OFF
ON
Back Light
BLC Compensation
OFF
wall mount included
Toll Free: (800) 510-6528
www.veilux.net
ON
PAN/TILT/ZOOM
10x ZOOM
26
0.02
LUX
VOLTAGE
12DC
540
TV LINES
D&N
NIGHT
DAY
VSSC-54CDNR-90
Car License Plate Camera (D/N, Low Light, High Speed Capture)
OFF
ON
Auto White
VOLTAGE
Back Light
540
TV LINES
OFF
ON
Number of Total Pixels
795(H) x 596(V)
Resolution; DSP
NTSC
540TVL; SONY HQ1
1.0Vp-p Composite, 75Ω; BNC
Signal to Noise Ratio
More than 50dB (Super AGC Off)
Gamma Correction
0.45
Mechanical IR Cut Filter
(ICR)
External Controlled by D/N IO; Color (In: 0V or Normal
Open) / Day & Night (In: 5~12VDC or Normal Close)
IR LED; Working Distance
Available with Infrared Illuminator
Synchronizing System
Internal / Line Lock (AC Version Only)
Electronic Shutter
AES: 1/50 (60) sec. ~ 1/100,000 sec.
Manual Shutter: 0:1/100(120)sec. 1:1/190sec.
2:1/350sec. 3:1/610sec. 4:1/1120sec. 5:1/2000sec.
6:1/3240sec. 7:1/4000sec.
Intelligent Shutter Speed
Capturing Car License Plate for Vehicle Speed Up to 150
km / hr (90 mile / hr) in the Daytime and 150 km / hr (90
mile / hr) at Night with External IR LEDs
Automatic Gain Control
AGC / SUPER AGC
Auto White Balance
Automatic
Back Light Compensation
On / Off
DNR; Sense Up
Automatic Dynamic Digital Noise Reduction (DNR);
Digital Day & Night Mode
NA
Automatic IRIS;
Connector
Video / DC; D4 IRIS Jack
Adjustment VR
DC Level, L.L V-Phase
Lens Mount
C/CS Mount (with Adaptor)
Power Supply;
Consumption
10.8 ~ 39VDC / 24VAC : 3.0W
Operation; Storage Temp.
-10˚C ~ 50˚C; -20˚C ~ 60˚C
Operation; Storage Hum’
Maximum: RH80%; RH90%
Dimensions / Weight
62mm(W) x 56mm(H) x 120mm(D) / 300g
120 mm
VIDEO
CAR
DC
BLC
BOX
CAMERAS
0.08 Lux @ F1.0
Video Output; Connector
UNDERWATER
CAMERAS
811(H) x 508(V)
Minimum illumination
0.08
LUX
AWB Balance
BLC Compensation
1/3” SuperHAD II CCD
FLC S.AGC
L.L.
V.P.
24AC
ME SHUTTER
OFF NORM AGC INT
Y/C OUT
56 mm
Gain
AGC Auto
Control
PAL
BULLET
CAMERAS
•1/3” SuperHAD CCD II
•HQ1 / 540TV / 0.08 Lux @ F1.0
•Capable of Capturing Car License Plate Numbers at High Speed
(Day: Up to 150 km / hr (90 mile / hr); Night: 150 km / hr
(90 mile / hr) with External IR LEDs)
•AGC / BLC (On / Off)
•Line Lock / 8 Steps Manual Shutter
•D/N Input Controlled by External IR illuminators
•Mechanical IR Cut Filter (ICR)
•Built-in DNR & Sense Up
•For Highway Surveillance
TV System
Image Sensor
LICENSE
PLATE CAMERA
FEATURES
VSSC-54CDNR-90
PAN / TILT /
ZOOM CAMERAS
ITEM
DOME
CAMERAS
(license plate camera does not come with shown lens)
IN
N.C
D/N I 0
GND
GND
AC24V
DC+12V
VIDEO OUT
Toll Free: (800) 510-6528
www.veilux.net
27
IP CAMERA
CAMERA SELECTION
Model
CCD Format
Horizontal
Resolution
Lens
IR LED
Min.
Illumination
Resolutions
Dimensions
(W X H x D)
Weight
Operating
Temperature
Power
VDIP-D1L312
1/3”
SONY
SuperHAD II
CCD
520 TV
Lines
3.3 ~
12mm
Yes
0.1 Lux
720 x 480 (Full D1), 640 x 480 (VGA),
720 x 240 (Half D1), 352 x 240 (CIF),
176 x 112 (QCIF)
162mm (6.4") x
113mm (4.4")
0.58Kg
(1lbs)
0 ~ 45°C
(32 ~ 113°F)
12VDC,
1A /
SMPS
VDIP-2L316
1/3 2"
CMOS
2.0M Pixels
Progressive
Scan
1,600 x
1,200
Pixels
(UXGA)
3.6 ~
16mm
Yes
0.2 Lux
-15fps @ 1600 x 1200 / 1280 x 1024
-30fps @ 1280 x 720 / 800 x 600 /
640 x 480 / 704 x 480 / 704 x 240 /
352 x 240 / 176 x 112
162mm (6.4") x
113mm (4.4")
0.58Kg
(1lbs)
0 ~ 45°C
(32 ~ 113°F)
12VDC,
1A /
SMPS
VVIP-D1L312
1/3”
SONY
SuperHAD II
CCD
520 TV
Lines
3.3 ~
12mm
Yes
0.1 Lux
720 x 480 (Full D1), 640 x 480 (VGA),
720 x 240 (Half D1), 352 x 240 (CIF),
176 x 112 (QCIF)
148mm (5.8") x
122mm (4.8")
1Kg
(2lbs)
-10°C ~ 50°C
(14°F ~ 122°C)
-40°C ~ 50°C
(-40°F ~ 122°F)
12VDC,
2A /
24W
VVIP-2L316
1/3 2"
CMOS
2.0M Pixels
Progressive
Scan
1,600 x
1,200
Pixels
(UXGA)
3.6 ~
16mm
Yes
0.2 Lux
-15fps @ 1600 x 1200 / 1280 x 1024
-30fps @ 1280 x 720 / 800 x 600 /
640 x 480 / 704 x 480 / 704 x 240 /
352 x 240 / 176 x 112
148mm (5.8") x
122mm (4.8")
1Kg
(2lbs)
-10°C ~ 50°C
(14°F ~ 122°C)
-40°C ~ 50°C
(-40°F ~ 122°F)
12VDC,
2A /
24W
VSIP-D1
1/3”
SONY
SuperHAD II
CCD
520 TV
Lines
3.5 ~
8.0mm
No
0.1 Lux
720 x 480 (Full D1), 640 x 480 (VGA),
720 x 240 (Half D1), 352 x 240 (CIF),
176 x 112 (QCIF)
Body:
66mm (2.6") x
58mm (2.3") x
119mm (4.7")
0.51Kg
(1lbs)
0 ~ 45°C
(32 ~ 113°F)
12VDC,
1A /
SMPS
VSIP-2
1/3 2"
CMOS
2.0M Pixels
Progressive
Scan
1,600 x
1,200
Pixels
(UXGA)
4.5 ~
10mm
No
0.2 Lux
-15fps @ 1600 x 1200 / 1280 x 1024
-30fps @ 1280 x 720 / 800 x 600 /
640 x 480 / 704 x 480 / 704 x 240 /
352 x 240 / 176 x 112
Body:
66mm (2.6") x
58mm (2.3") x
119mm (4.7")
0.51Kg
(1lbs)
0 ~ 45°C
(32 ~ 113°F)
12VDC,
1A /
SMPS
VPIP-D127X
1/4" SONY
ExView
HAD CCD
550 TV
Line
F=1.6
~ 2.9,
f=3.5 ~
94.5mm
No
0.4 Lux
720 x 480 (Full D1), 640 x 480 (VGA),
720 x 240 (Half D1), 352 x 240 (CIF),
176 x 112 (QCIF)
253mm (10") x
463mm (18.2")
5.3Kg
(11.7lbs)
-10°C ~ 50°C
(14°F ~ 122°F)
-40°C ~ 50°C
(-40°F ~ 122°F)
24VAC,
1.75A /
42W
VPIP-D133X
1/4" SONY
ExView
HAD CCD
550 TV
Line
F=1.6 ~
3.6,
f=3.5 ~
115.5mm
No
0.4 Lux
720 x 480 (Full D1), 640 x 480 (VGA),
720 x 240 (Half D1), 352 x 240 (CIF),
176 x 112 (QCIF)
253mm (10") x
463mm (18.2")
5.3Kg
(11.7lbs)
-10°C ~ 50°C
(14°F ~ 122°F)
-40°C ~ 50°C
(-40°F ~ 122°F)
24VAC,
1.75A /
42W
VPIP-D137X
1/4" SONY
ExView
HAD CCD
550 TV
Line
F=1.6 ~
3.9,
f=3.5 ~
129.5mm
No
0.4 Lux
720 x 480 (Full D1), 640 x 480 (VGA),
720 x 240 (Half D1), 352 x 240 (CIF),
176 x 112 (QCIF)
253mm (10") x
463mm (18.2")
5.3Kg
(11.7lbs)
-10°C ~ 50°C
(14°F ~ 122°F)
-40°C ~ 50°C
(-40°F ~ 122°F)
24VAC,
1.75A /
42W
Toll Free: (800) 510-6528
www.veilux.net
29
VDIP-D1L312
Dual Codec IP Camera
DOME IP
CAMERAS
ITEM
VDIP-D1L312
VANDAL PROOF
IP CAMERAS
Image Sensor
1/3” 410K, 520 TV Line, SONY SuperHAD II CCD
Effective Pixels (H x V)
NTSC: 811 x 508, PAL: 795 x 596
Min. Illumination
(30 IRE) - Color: 0.1 Lux, B/W: 0.001 Lux
Horizontal Resolution
Color: 520 TV Line, B/W: 580 TV Line
Lens
3.3 ~ 12mm, F1.5, Vari-focal, Viewing Angle (H: 80.2°)
Video Part
Compression Method
Resolution
Simultaneous Dual Codec (H.264 / MJPEG)
BOX IP
CAMERAS
NTSC
PAL / SECAM
720 x 480 (Full D1),
640 x 480 (VGA),
720 x 240 (Half D1),
352 x 240 (CIF),
176 x 112 (QCIF)
720 x 576 (Full D1),
640 x 480 (VGA),
720 x 288 (Half D1),
352 x 288 (CIF),
176 x 112 (QCIF)
PAN / TILT / ZOOM
IP CAMERAS
Intelligent Bit-Rate Control
CBR, VBR, HBR
PTZ
Digital PTZ & Video Crop
Image Setting
Text Overlay, Privacy Mask, De-Interlace Filter
Motion Detection
3 Regions
Audio Part
Mono Upstream
32 Kbps G.726 ADPCM ~ Line-In / MIC-In
Mono Downstream
128 Kbps 16-bit Linear PCM ~ Line-Out (1Vpk)
Network
NVR-PRO
Network Protocol
-IPv4/v6, TCP, UDP, IGMP, ICMP, ICMPv6, ARP, RARP,
PPPoE, RTCP
-RTP, RTSP, SDP, HTTP, HTTPS, SMTP, FTP, DHCP,
UPnP, SNMP
-NTP, DNS, DynDNS, SOCKS, QoS Layer 3 DiffServ,
Bonjour
Dynamic IP
Supported
Security
-User ID & Password Protection, IP Address Filtering
-HTTPS Encryption, Digest Authentication, User
Access Log
External Terminals
LAN
10 / 100 BaseT LAN (Auto MDIX)
Analog Output
1 Channel D1 CVBS Output of the Encoding Video
Alarm Input / Output
Alarm 1/0 (1 Sensor Input & 1 Relay Output)
FEATURES
• Dual-Codec (H.264 & MJPEG)
• Multi Profile Streaming (Up to 3 Streams of Different Resolutions,
Frame Rates and Codec Selections)
• Digital PTZ, Video Crop
• Analog Video Output (CVBS)
• Built-in Standard PoE
• Two-Way Audio Communication
• 3G Mobile A/V Surveillance (Through 3G Server)
• 3-Axis Lens Mount
• Robust Design & Convenient Installation
• Optional Items - Local Storage, D/N (TDN), IR LED
System Integration
Alarm Triggers
Intelligent Video + Sensor Input
Alarm Events
Video File Upload (FTP), Still Image (Email), PTZ
Presets, Relay Output
3G Mobile
3G Mobile Phone Support
520
TV LINES
0.1
LUX
3-AXIS
VOLTAGE
Client Software
NVR-Pro
64 CH
Operating Environment, Power, Dimension
30
Operating Temperature
0 ~ 45°C (32 ~ 113°F)
Operating Humidity
8 ~ 80% RH
Power
12VDC, 1A / SMPS
Dimensions (W x D)
162mm (6”) x 113mm (4”)
Weight
0.58Kg (1lbs)
Approvals
FCC, CE, MIC, RoHS
Toll Free: (800) 510-6528
www.veilux.net
IR LED
12DC
VDIP-2L316
1,600 x 1,200 Pixels (UXGA)
Min. Illumination (50IRE)
0.2 Lux / F1.2 (IR On = 0 Lux)
Lens
Varifocal f=3.6 ~ 16mm, F1.2
Day & Night
Supported (TDN, IR LED)
Video Part
Compression Method
Simultaneous Dual Codec (H.264 / MJPEG)
Resolution
-15fps @ 1600 x 1200 / 1280 x 1024
-30fps @ 1280 x 720 / 800 x 600 / 640 x 480 /
704 x 480 / 704 x 240 / 352 x 240 / 176 x 112
Intelligent Bit-Rate Control
CBR, VBR, HBR
PTZ
Digital PTZ & Video Crop
Image Setting
Text Overlay, Privacy Mask, De-Interlace Filter
Motion Detection
3 Regions
Audio Part
FEATURES
0.2
LUX
PAN/TILT/ZOOM
VOLTAGE
D&N
2 MP
TV LINES
Auto White
NIGHT
DAY
32Kbps G.726 ADPCM ~ Line-In / MIC-In
Mono Downstream
128Kbps 16-Bit Linear PCM ~ Line-Out (1Vpk)
Network
• Dual-Codec (H.264 & MJPEG)
• Progressive Scan Megapixel (2.0M CMOS)
• Multi Profile Streaming (Up to 3 Streams of Different
Resolutions, Frame Rates and Codec Selections)
• Digital PTZ, Video Crop
• Analog Video Output (CVBS)
• Built-in Standard PoE
• Two-Way Audio Communication
• 3G Mobile A/V Surveillance (Through 3G Server)
• Built-in D/N (TDN), IR LED
• 3-Axis Lens Mount
• Robust Design & Convenient Installation
• Optional Items - Local Storage, Bracket
AWB Balance
Mono Upstream
Network Protocol
-IPv4/v6, TCP, UDP, IGMP, ICMP, ICMPv6, ARP, RARP,
PPPoE, RTCP
-RTP, RTSP, SDP, HTTP, HTTPS, SMTP, FTP, DHCP, UPnP,
SNMP
-NTP, DNS, DynDNS, SOCKS, QoS Layer 3 DiffServ,
Bonjour
Dynamic IP
Supported
Security
-User ID & Password Protection, IP Address Filtering
-HTTPS Encryption, Digest Authentication, User Access
Log
External Terminals
LAN
10 / 100 BaseT LAN (Auto MDIX)
Analog Output
1 Channel D1 CVBS Output of the Encoding
Alarm Input / Output
Alarm 1/0 (1 Sensor Input & 1 Relay Output)
VANDAL PROOF
IP CAMERAS
Progressive Scan 1/3 2” CMOS 2.0M Pixels
Full Resolution
BOX IP
CAMERAS
Image Sensor
PAN / TILT / ZOOM
IP CAMERAS
VDIP-2L316
NVR-PRO
ITEM
DOME IP
CAMERAS
2 Megapixel IP Camera
System Integration
Alarm Triggers
Intelligent Video + Sensor Input
Alarm Events
Video File Upload (FTP), Still Image (Email), PTZ Presets,
Relay Output
3G Mobile
3G Mobile Phone Support
Client Software
12DC
NVR-Pro
64 CH
Operating Environment, Power, Dimensions
Operating Temperature
0 ~ 45°C (32 ~ 113°F)
Operating Humidity
8 ~ 80% RH
Power
12VDC, 1A / SMPS
Dimensions (W x H x D)
162mm (6”) x 113mm (4”)
Weight
0.58Kg (1lbs)
Approvals
FCC, CE, MIC, RoHS
Toll Free: (800) 510-6528
www.veilux.net
31
VVIP-D1L312
Dual Codec IP Camera
DOME IP
CAMERAS
ITEM
VVIP-D1L312
VANDAL PROOF
IP CAMERAS
Image Sensor
1/3” 410K, 520 TV Line, SONY SuperHAD II CCD
Effective Pixels (H x V)
NTSC: 811 x 508, PAL: 795 x 596
Min. Illumination (30IRE)
Color: 0.1 Lux, B/W: 0.001 Lux
Horizontal Resolution
Color: 520 TV Line, B/W: 580 TV Line
Lens
3.3 ~ 12mm, F1.5, Vari-focal, Viewing Angle (H: 80.2°)
Video Part
Compression Method
Resolution
Simultaneous Dual Codec (H.264 / MJPEG)
BOX IP
CAMERAS
NTSC
PAL / SECAM
720 x 480 (Full D1),
640 x 480 (VGA),
720 x 240 (Half D1),
352 x 240 (CIF),
176 x 112 (QCIF)
720 x 576 (Full D1),
640 x 480 (VGA),
720 x 288 (Half D1),
352 x 288 (CIF),
176 x 112 (QCIF)
PAN / TILT / ZOOM
IP CAMERAS
Intelligent Bit-Rate Control
CBR, VBR, HBR
PTZ
Digital PTZ & Video Crop
Image Setting
Text Overlay, Privacy Mask, De-Interlace Filter
Motion Detection
3 Regions
Mono Upstream
32 Kbps G.726 ADPCM ~ Line-In / MIC-In
Mono Downstream
128 Kbps 16-bit Linear PCM ~ Line-Out (1Vpk)
Network
NVR-PRO
Network Protocol
-IPv4/v6, TCP, UDP, IGMP, ICMP, ICMPv6, ARP, RARP,
PPPoE, RTCP
-RTP, RTSP, SDP, HTTP, HTTPS, SMTP, FTP, DHCP,
UPnP, SNMP
-NTP, DNS, DynDNS, SOCKS, QoS Layer 3 DiffServ,
Bonjour
Dynamic IP
Supported
Security
-User ID & Password Protection, IP Address Filtering
-HTTPS Encryption, Digest Authentication, User
Access Log
External Terminals
LAN
10 / 100 BaseT LAN (Auto MDIX)
Analog Output
1 Channel D1 CVBS Output of the Encoding Video
Alarm Input / Output
Alarm 1/0 (1 Sensor Input & 1 Relay Output)
System Integration
Alarm Triggers
Intelligent Video + Sensor Input
Alarm Events
Video File Upload (FTP), Still Image (Email), PTZ
Presets, Relay Output
3G Mobile
3G Mobile Phone Support
NVR-Pro
• Dual-Codec (H.264 & MJPEG)
• Multi Profile Streaming (Up to 3 Streams of Different Resolutions,
Frame Rates and Codec Selections)
• Digital PTZ, Video Crop, Analog Video Output (CVBS)
• Built-in Standard PoE, Two-Way Audio Communication
• 3G Mobile A/V Surveillance (Through 3G Server)
• 3-Axis Lens Mount
• Robust Design & Convenient Installation
• Vandal Proof, Weather Proof (IP-66)
• Optional Items - Local Storage, D/N (TDN), IR LED, Bracket
520
TV LINES
0.1
LUX
3-AXIS
VOLTAGE
VANDALPROOF
12DC
WEATHER
PROOF
IP66
IR LED
Optional Mounts
Client Software
64 CH
Operating Environment, Power, Dimension
32
FEATURES
Audio Part
Operating Temperature
- PoE Power: -10°C ~ 50°C (14°F ~ 122°C)
- DC Power: -40°C ~ 50°C (-40°F ~ 122°F)
Operating Humidity
8 ~ 80% RH
Power
12VDC, 2A with Heater and IR LED, 24W
Dimensions (W x D)
148mm (6”) x 122mm (5”)
Weight
1Kg (2lbs)
Approvals
FCC, CE, MIC, RoHS
Toll Free: (800) 510-6528
www.veilux.net
Wall Mount Bracket
VVIP-WM
VVIP-CM
Ceiling Mount Bracket
VVIP-2L316
1,600 x 1,200 Pixels (UXGA)
Min. Illumination (50IRE)
0.2 Lux / F1.2 (IR On = 0 Lux)
Lens
Varifocal f=3.6 ~ 16mm, F1.2
Day & Night
Supported (TDN, IR LED)
Video Part
Compression Method
Simultaneous Dual Codec (H.264 / MJPEG)
Resolution
-15fps @ 1600 x 1200 / 1280 x 1024
-30fps @ 1280 x 720 / 800 x 600 / 640 x 480 /
704 x 480 / 704 x 240 / 352 x 240 / 176 x 112
Intelligent Bit-Rate Control
CBR, VBR, HBR
PTZ
Digital PTZ & Video Crop
Image Setting
Text Overlay, Privacy Mask, De-Interlace Filter
Motion Detection
3 Regions
Audio Part
FEATURES
0.2
LUX
3-AXIS
VOLTAGE
Auto White
WEATHER
PROOF
12DC
2 MP
TV LINES
IR LED
32Kbps G.726 ADPCM ~ Line-In / MIC-In
Mono Downstream
128Kbps 16-Bit Linear PCM ~ Line-Out (1Vpk)
Network
• Dual-Codec (H.264 & MJPEG)
• Progressive Scan Megapixel (2.0M CMOS)
• Multi Profile Streaming (Up to 3 Streams of Different
Resolutions, Frame Rates and Codec Selections)
• Digital PTZ, Video Crop, Analog Video Output
• Built-in Standard PoE, Two-Way Audio Communication
• 3G Mobile A/V Surveillance (Through 3G Server)
• Built-in D/N (TDN), IR LED, 3-Axis Lens Mount
• Robust Design & Convenient Installation
• Vandal Proof, Weather Proof (IP-66)
• Optional Items - Local Storage, Bracket
AWB Balance
Mono Upstream
Network Protocol
Dynamic IP
Supported
Security
-User ID & Password Protection, IP Address Filtering
-HTTPS Encryption, Digest Authentication, User Access
Log
External Terminals
IP66
D&N
NIGHT
-IPv4/v6, TCP, UDP, IGMP, ICMP, ICMPv6, ARP, RARP,
PPPoE, RTCP
-RTP, RTSP, SDP, HTTP, HTTPS, SMTP, FTP, DHCP, UPnP,
SNMP
-NTP, DNS, DynDNS, SOCKS, QoS Layer 3 DiffServ,
Bonjour
DAY
VANDALPROOF
LAN
10 / 100 BaseT LAN (Auto MDIX)
Analog Output
1 Channel D1 CVBS Output of the Encoding
Alarm Input / Output
Alarm 1/0 (1 Sensor Input & 1 Relay Output)
VANDAL PROOF
IP CAMERAS
Progressive Scan 1/3 2” CMOS 2.0M Pixels
Full Resolution
BOX IP
CAMERAS
Image Sensor
PAN / TILT / ZOOM
IP CAMERAS
VVIP-2L316
NVR-PRO
ITEM
DOME IP
CAMERAS
2 Megapixel IP Camera
System Integration
Alarm Triggers
Intelligent Video + Sensor Input
Alarm Events
Video File Upload (FTP), Still Image (Email), PTZ Presets,
Relay Output
3G Mobile
3G Mobile Phone Support
Client Software
Optional Mounts
Wall Mount Bracket
VVIP-WM
NVR-Pro
VVIP-CM
Ceiling Mount Bracket
64 CH
Operating Environment, Power, Dimensions
Operating Temperature
- PoE Power: -10°C ~ 50°C (14°F ~ 122°C)
- DC Power: -40°C ~ 50°C (-40°F ~ 122°F)
Operating Humidity
8 ~ 80% RH
Power
12VDC, 2A with Heater and IR LED, 24W
Dimensions (W x H x D)
148mm (6”) x 122mm (4”)
Weight
1Kg (2lbs)
Approvals
FCC, CE, MIC, RoHS
Toll Free: (800) 510-6528
www.veilux.net
33
VSIP-D1
Dual Codec IP Camera
DOME IP
CAMERAS
(box camera does not come with shown lens)
ITEM
VSIP-D1
VANDAL PROOF
IP CAMERAS
Image Sensor
1/3” 410K, 520 TV Line, SONY SuperHAD II CCD
Effective Pixels (H x V)
NTSC: 811 x 508, PAL: 795 x 596
Min. Illumination (30IRE)
Color: 0.1 Lux, B/W: 0.001 Lux
Horizontal Resolution
Color: 520 TV Line, B/W: 580 TV Line
Lens
Recommended Lens: Vari-Focal 3.5 ~ 8.0mm, F1.4,
Viewing Angle (H: 80.7°)
Video Part
Compression Method
Resolution
Simultaneous Dual Codec (H.264 / MJPEG)
BOX IP
CAMERAS
NTSC
PAL / SECAM
720 x 480 (Full D1),
640 x 480 (VGA),
720 x 240 (Half D1),
352 x 240 (CIF),
176 x 112 (QCIF)
720 x 576 (Full D1),
640 x 480 (VGA),
720 x 288 (Half D1),
352 x 288 (CIF),
176 x 112 (QCIF)
PAN / TILT / ZOOM
IP CAMERAS
Intelligent Bit-Rate Control
CBR, VBR, HBR
PTZ
Digital PTZ & Video Crop
Image Setting
Text Overlay, Privacy Mask, De-Interlace Filter
Motion Detection
3 Regions
Audio Part
Mono Upstream
32 Kbps G.726 ADPCM ~ Line-In / MIC-In
Mono Downstream
128 Kbps 16-bit Linear PCM ~ Line-Out (1Vpk)
Network
Network Protocol
-IPv4/v6, TCP, UDP, IGMP, ICMP, ICMPv6, ARP, RARP,
PPPoE, RTCP
-RTP, RTSP, SDP, HTTP, HTTPS, SMTP, FTP, DHCP,
UPnP, SNMP
-NTP, DNS, DynDNS, SOCKS, QoS Layer 3 DiffServ,
Bonjour
NVR-PRO
Dynamic IP
Supported
Security
-User ID & Password Protection, IP Address Filtering
-HTTPS Encryption, Digest Authentication, User
Access Log
External Terminals
FEATURES
• Dual-Codec (H.264 & MJPEG)
• Multi Profile Streaming (Up to 3 Streams of Different Resolutions,
Frame Rates and Codec Selections)
• Digital PTZ, Video Crop
• Analog Video Output (CVBS)
• Built-in Standard PoE
• Two-Way Audio Communication
• 3G Mobile A/V Surveillance (Through 3G Server)
• Robust Design & Convenient Installation
• Optional Items - Local Storage, D/N (TDN), Lens
520
TV LINES
0.2
LUX
LAN
10 / 100 BaseT LAN (Auto MDIX)
Analog Output
1 Channel D1 CVBS Output of the Encoding Video
Alarm Input / Output
Alarm 1/0 (1 Sensor Input & 1 Relay Output)
AWB Balance
Alarm Triggers
Intelligent Video + Sensor Input
D&N
Alarm Events
Video File Upload (FTP), Still Image (Email), PTZ
Presets, Relay Output
NIGHT
3G Mobile
3G Mobile Phone Support
Auto White
VOLTAGE
12DC
System Integration
DAY
Client Software
NVR-Pro
64 CH
Operating Environment, Power, Dimension
34
Operating Temperature
0 ~ 45°C (32 ~ 113°F)
Operating Humidity
8 ~ 80% RH
Power
12VDC, 1A / SMPS
Dimensions (W x D)
Body: 66mm (2.6”) x 58mm (2.3”) x 119mm (4.7”)
Weight
0.51Kg (1lbs)
Approvals
FCC, CE, MIC, RoHS
Toll Free: (800) 510-6528
www.veilux.net
Optional Lens
VL-0358A - 3.5mm ~ 8.0mm
VL-02812A - 2.8mm ~ 12mm
VL-05100A - 5mm ~ 100mm
VSIP-2
Progressive Scan 1/3 2” CMOS 2.0M Pixels
Full Resolution
1,600 x 1,200 Pixels (UXGA)
Min. Illumination (50IRE)
0.2 Lux / F1.2
Lens
Recommended Lens: Varifocal 4.5 ~ 10mm, F1.6
Day & Night
Supported
Video Part
FEATURES
0.2
LUX
Auto White
AWB Balance
VOLTAGE
12DC
D&N
NIGHT
Simultaneous Dual Codec (H.264 / MJPEG)
Resolution
-15fps @ 1600 x 1200 / 1280 x 1024
-30fps @ 1280 x 720 / 800 x 600 / 640 x 480 /
704 x 480 / 704 x 240 / 352 x 240 / 176 x 112
Intelligent Bit-Rate Control
CBR, VBR, HBR
PTZ
Digital PTZ & Video Crop
Image Setting
Text Overlay, Privacy Mask, De-Interlace Filter
Motion Detection
3 Regions
Audio Part
• Dual-Codec (H.264 & MJPEG)
• Progressive Scan Megapixel (2.0M CMOS)
• Multi Profile Streaming (Up to 3 Streams of Different
Resolutions, Frame Rates and Codec Selections)
• Digital PTZ, Video Crop
• Analog Video Output (CVBS)
• Built-in Standard PoE, Built-in D/N (TDN)
• Two-Way Audio Communication
• 3G Mobile A/V Surveillance (Through 3G Server)
• Robust Design & Convenient Installation
• Optional Items - Local Storage, Lens
2 MP
TV LINES
Compression Method
DAY
Mono Upstream
32Kbps G.726 ADPCM ~ Line-In / MIC-In
Mono Downstream
128Kbps 16-Bit Linear PCM ~ Line-Out (1Vpk)
Network
Network Protocol
-IPv4/v6, TCP, UDP, IGMP, ICMP, ICMPv6, ARP, RARP,
PPPoE, RTCP
-RTP, RTSP, SDP, HTTP, HTTPS, SMTP, FTP, DHCP, UPnP,
SNMP
-NTP, DNS, DynDNS, SOCKS, QoS Layer 3 DiffServ,
Bonjour
Dynamic IP
Supported
Security
-User ID & Password Protection, IP Address Filtering
-HTTPS Encryption, Digest Authentication, User Access
Log
External Terminals
LAN
10 / 100 BaseT LAN (Auto MDIX)
Analog Output
1 Channel D1 CVBS Output of the Encoding
Alarm Input / Output
Alarm 1/0 (1 Sensor Input & 1 Relay Output)
VANDAL PROOF
IP CAMERAS
Image Sensor
BOX IP
CAMERAS
VSIP-2
PAN / TILT / ZOOM
IP CAMERAS
ITEM
NVR-PRO
(box camera does not come with shown lens)
DOME IP
CAMERAS
2 Megapixel IP Camera
System Integration
Alarm Triggers
Intelligent Video + Sensor Input
Alarm Events
Video File Upload (FTP), Still Image (Email), PTZ Presets,
Relay Output
3G Mobile
3G Mobile Phone Support
Client Software
NVR-Pro
Optional Lens
VL-0358A - 3.5mm ~ 8.0mm
VL-02812A - 2.8mm ~ 12mm
VL-05100A - 5mm ~ 100mm
64 CH
Operating Environment, Power, Dimensions
Operating Temperature
0 ~ 45°C (32 ~ 113°F)
Operating Humidity
8 ~ 80% RH
Power
12VDC, 1A / SMPS
Dimensions (W x H x D)
Body: 66mm (2.6”) x 58mm (2.3”) x 119mm (4.7”)
Weight
0.51Kg (1lbs)
Approvals
FCC, CE, MIC, RoHS
Toll Free: (800) 510-6528
www.veilux.net
35
VPIP-D127X
Speed Dome Dual Codec IP Camera
DOME IP
CAMERAS
optional model:
VPIP-D133X
VANDAL PROOF
IP CAMERAS
•33x Optical Zoom (F=1.6 ~ 3.6, f=3.5 ~ 115.5mm)
•12x Digital Zoom (396x Total Zoom with Optical)
•Min. Illumination: 0.4Lux (Normal), 0.02Lux (Night),
0.00007Lux (Sense-Up: 256x)
VPIP-D137X
BOX IP
CAMERAS
•37x Optical Zoom (F=1.6 ~ 3.9, f=3.5 ~ 129.5mm)
•12x Digital Zoom (444x Total Zoom with Optical)
•Min. Illumination: 0.7Lux (Normal), 0.061Lux (Night),
0.00007Lux (Sense-Up: 256x)
PAN / TILT / ZOOM
IP CAMERAS
FEATURES
optional mount:
Wall Bracket
Ceiling Bracket
NVR-PRO
VPIP-VM
VPIP-ICM
Junction Box
• Dual-Codec (H.264 & MJPEG)
• Multi Profile Streaming (Up to 3 Streams of Different Resolutions,
Frame Rates and Codec Selections)
• Digital PTZ, Video Crop
• Bi-Directional Audio Communication
• 3G Mobile A/V Surveillance (Through 3G Server)
• Ultra Quiet Mechanism
• IP + (Hybrid) Feature
- Simultaneous Control Through RS-485 and IP Network
• IP66 Compliant Housing
• Fan & Heater
• Optional Items - Local Storage, Mounting Bracket,
Keyboard Controller, AC Power Adaptor
550
TV LINES
VPIP-JB
Auto White
AWB Balance
Pole & Corner Mount
VPIP-CA
36
Toll Free: (800) 510-6528
www.veilux.net
WEATHER
PROOF
VPIP-PA
IP66
Back Light
0.00007
LUX
BLC Compensation
VOLTAGE
MIRROR
FUNCTION
3-AXIS
OFF
24AC
OPTICAL
ZOOM
ON
Simultaneous Dual Codec (H.264 / MJPEG)
360° Endless / -2° ~ 90°
NTSC
PAL / SECAM
Pan / Tilt Speed Manual
0.5° ~ 200°/sec (64 Step) / 0.5 ~ 45°/sec (64 Step)
Pan / Tilt Speed Preset
Max 300°/sec, Min 10°/sec /
Max 250°/sec, Min 200°/sec
System Accuracy
0.024°
720 x 480 (Full D1),
640 x 480 (VGA),
720 x 240 (Half D1),
352 x 240 (CIF),
176 x 112 (QCIF)
720 x 576 (Full D1),
640 x 480 (VGA),
720 x 288 (Half D1),
352 x 288 (CIF),
176 x 112 (QCIF)
Pan / Tilt Rotation Angle
Functions
Presets
165 Positions with 16 Character Labels Available for
Each Position with Different Speed Steps
Auto Pan
Programmable Auto Scan
Pattern
8 Programmable Patterns (Total 480 Seconds)
Sector
8 Selectable Sectors with 16 Characters
Privacy Zone
8
Alarm Input
4 Alarms (with Various Programmable States)
Alarm Actions
Activate Preset, Group Scanning or Output Per Alarm
Input
Resolution
Multi-Profile Streaming
- 3 Simultaneous Video Profiles
- Select the Codec Type, Resolution and Frame Rates for
Each Profile
Intelligent Bit-Rate Control
CBR, VBR, HBR
PTZ
Digital PTZ & Video Crop
Image Setting
Text Overlay, Privacy Mask, De-Interlace Filter
Motion Detection
3 Regions
Audio Part
Mono Upstream
32Kbps G.726 ADPCM ~ Line-In / MIC-In
Mono Downstream
128Kbps 16-Bit Linear PCM ~ Line-Out (1 Vpk)
Auto Flip
On / Off
External Terminals
OSD Menu / Password Protection
Yes
LAN
10 / 100 BaseT LAN (Audo MDIX)
Communication
RS-485
Analog Output
1 Channel D1 CVBS Output of Then Encoding Video
Pelco-D, Pelco-P
RS-485
RS-485 for External PTZ Device
Alarm Input / Output
Alarm 1/0 (4 Sensor Input & 2 Relay Output)
PTZ Protocol
Camera Module
Image Sensor
1/4” SONY ExView HAD CCD
Client Software
Total Image Pixels
811(H) * 508(V) 410K - NTSC
795(H) * 596(V) 470K - PAL
NVR-Pro
Number of Effective Pixels
768(H) x 494(V) 380K - NTSC
752(H) * 582(V) 440K - PAL
Alarm Triggers
Intelligent Video + Sensor Input
Horizontal Resolution
550 TV Line (Color) - NTSC / 680 TV Line (B/W) - PAL
Alarm Events
Video File Upload (FTP), Still Image (Email), PTZ
Presets, Relay Output
Lens - Optical
27x Optical Zoom (F=1.6 ~ 2.9, f=3.5 ~ 94.5mm)
PTZ Control
00 Presets, Guard Tour, PTZ Control Queue
Lens - Digital
12x (324x with Optical)
3G Mobile
3G Mobile Phone Support
Day & Night (ICR)
Auto / Day / Night
Operating Environment, Power, Dimension
Min. Illumination
0.4 Lux (Normal) / 0.02 Lux (Night) /
0.00007 Lux (Sense-Up: 256x)
Operating Temperature
-Without Heater: -10°C ~ 50°C (14°F ~ 122°F)
-With Heater: -40°C ~ 50°C (-40°F ~ 122°F)
Luminance S/N Ratio
More than 50dB
Operating Humidity
8 ~ 80% RH
Video Output
Composite Video Output 75 Ohm Terminated
Power
24VAC, 1.75A / 42W
BLC / Flickerless / DSS
On / Off
Dimensions (W x D)
253mm (10") x 462.7mm (18")
Network
64CH
System Integration
Weight
5.3Kg (11.7lbs) / Net
-IPv4/v6, TCP, UDP, IGMP, ICMP, ICMPv6, ARP, RARP,
PPPoE, RTCP
-RTP, RTSP, SDP, HTTP, HTTPS, SMTP, FTP, DHCP,
UPnP, SNMP
-NTP, DNS, DynDNS, SOCKS, QoS Layer 3 DiffServ,
Bonjour
Approvals
FCC, CE, MIC, RoHS
Local Storage
SD Card or Flash Memory
Keyboard Controller
SVK-64
Bracket
VPIP-JB, VPIP-VM, VPIP-ICM, VPIP-CA, VPIP-PA
Dynamic IP
Support
Power Adaptor
24VAC, 2.5A
Security
-User ID & Password Protection, IP Address Filtering
-HTTPS Encryption, Digest Authentication, User
Access Log
Network Protocol
Toll Free: (800) 510-6528
www.veilux.net
VANDAL PROOF
IP CAMERAS
Compression Method
Pan / Tilt
BOX IP
CAMERAS
Video Part
PAN / TILT / ZOOM
IP CAMERAS
VPIP-D127X
NVR-PRO
ITEM
DOME IP
CAMERAS
VPIP-D127X
Speed Dome Dual Codec IP Camera
37
NVR-PRO
CMS Software
DOME IP
CAMERAS
VANDAL PROOF
IP CAMERAS
BOX IP
CAMERAS
PAN / TILT / ZOOM
IP CAMERAS
Intuitive Connection to IP Cameras:
Bit Rate (Kbps) / CH
Number of
Channels
Video
Audio
•Simple and Cost-Effective to Add Additional IP Camera Licenses
16
300
32
57.3696
•Supports IP D1 & Megapixel IP Camera
32
300
32
114.7392
•Each Server is Expandable to Up to 64 IP Cameras
•Supports Latest IP Camera Technology Including Megapixel Cameras, H.264 and Analytics
NVR-PRO
•Digital PTZ Functionality on All Cameras in Live and Recorded Mode
64
Enter
Number of
Channels
300
64
Enter
Video Rate
(Kbps)
32
500
229.4784
Enter
Audio Rate
(Kbps)
32
HDD Space
Consumption
GByte / Day
367.7184
Intuitive User Interface:
•Intuitive User Interface Requires Minimal or No Training
•Servers to Create Scalable Networks
•Easy-to-Use, Powerful Video and Audio Export Features
•Multi-Monitor Client Display. Drag and Drop Cameras and Maps Between Monitors
•Graphical Search Display for All Cameras and Recorded Audio
•Easy to Use Multi-Camera Search, Playback and Export
S/W
Name
# of Max
Channels
Recommended
CPU Type
NVR-Pro 16
16 CH
Pentium-4 3G (1
Core or Above)
NVR-Pro 32
32 CH
Pentium-Dual 3G
(2 Core or Above)
or Above
•Smart Search Function
•Powerful Mapping Feature Integrates Seamlessly with Video Streams. Add Any Number
of Maps From Any Image Source, Place Cameras and Alarms On Map, Watch Interactive
NVR-Pro 48
48 CH
Pentium-Dual 3G
2CPU (4 Core or
Above)
NVR-Pro 64
64 CH
Pentium-Dual 3G
2CPU (4 Core or
Above)
Activity On Map
38
HDD Space / Day
(Giga Byte)
Toll Free: (800) 510-6528
www.veilux.net
Main Memory
(RAM)
NIC
100Mbps
1 GByte or
Above
1Gbps
- Up to 64CH (16 x 4 Windows)
- Each Window Independently Reconfigurable
Recording
- ICF Data Format
- Up to 4 Recording Folders, Overwrite Control
- Recording by Manual, Schedule, Alarm (Sensor, Motion)
•Compressions Supported H.264, MJPEG, MPEG4
•View Live and Playback Simultaneously
•Two-Way Audio
Local Playback
- Independent Playback Window
- Search by Calendar and Search Filter
•Bandwidth-Optimized Multi-Streaming
•Advanced Access Clients
Remote Playback
- Remote Search & Playback From Other PC (To Be
Developed)
•Intelligent PTZ Control
•PTZ Patrolling and Scanning
Alarm Event
- Sensor & Motion Detection
•Archive to Network Drive
Audio / PTZ
•Export Evidence with Viewer
•Max 64CH Viewing and Recording (4 Windows, 16CH / Windows)
Audio
- Bi-Directional Audio Communication Between NVR-PRO
and IP Camera
- Audio Mixing
PTZ
- Remote PTZ Control (Manual)
- Centering
- Preset / Focus / Speed Control
Digital PTZ
- Remote Control
- Video Crop
•Digital PTZ for Megapixel IP Camera
•Remote Control to Local Flash Memory and HDD (RVS, DVR Controller)
•Alarm Status Display (64CH)
•Tiling & Resizing of Windows
•Remote P/T/Z Control
•Bi-Directional Audio Communication
•Save & Load of Configuration Information
•Easy Record & Search (Manual, Schedule, Alarm, Motion Detection)
•Support Up to 4 Monitors
•Daemon, Channel Grouping, Software Protection etc.
•Program Lock
•Dependable, Robust and Stable
•High Performance Achieved on Standard Computer Equipment by Using Powerful MultiThreaded Technology
Relay Control
Remote Relay Control
Remote Relay On / Off Control
Remote Control of
Recording Video Server
- Remote Recording Control
- Remote Playback
- Download From Recording Video Server
- Web Hard Disk
Audio Input / Output
1CH (From Microphone or Audio Device) / 1CH (to
Speaker)
Hardware Platform (PC / Server)
•Maximize Disk Use Store Only the Images You Need by Saving to Archive By Motion
System (Test PC Spec)
- Model: Dell Precision T3400 525W
- Processor: Intel® CoreTM 2 Duo E8400 (3.00GHz /
1333MHz FSB / 6MB L2 Cache)
- OS: Factory Install Genuine Windows® XP Professional
SP2 Edition (Korean)
- Resource CD for Windows XP 32 Bit 1
- Memory: 2GB (2 x 1GB) NECC Dual Channel DDR2
667MHz SDRAM Memory
- Video Card: 256MB PCIe x 16 ATI Fire GL v3600, Dual
DVI or VGA Support
- HDD: Seagate S-ATA 750GB * 3
Memory
2G RAM
HDD
OS Set Up Space / Data Recording HDD
Graphic Card
ATI Card / AGP (AGP, PCI-E) / Memory 128M
NIC
100 BaseT or Above, Gigabit LAN Recommended
OS
Windows XP
Detection, Events or Self-Defined Recording Schedules
•Fast Easy to Export Video Evidence
Toll Free: (800) 510-6528
www.veilux.net
VANDAL PROOF
IP CAMERAS
Live Viewing
BOX IP
CAMERAS
Live Viewing / Recording / Local Playback
•Up to 64 IP Cameras, Supports Megapixel and D1
•E-Map Electronic Icon Map Display Support
NVR-PRO
PAN / TILT / ZOOM
IP CAMERAS
•Single-Server System
ITEM
NVR-PRO
FEATURES
DOME IP
CAMERAS
NVR-PRO
CMS Software
39
ACCESSORIES
VIDEO RECORDING SYSTEMS SELECTIONS
Model
Video Input
Video Output
Compression
Resolution
Display
Speed
REC
Speed
Internal
HDD
Internal
DVD
External
Backup
Sensor
Input
Relay
Out
Audio
Input
Audio
Output
Power
Supply
Weight
SVR-824DVD
8 Channel
Input (BNC) /
NTSC / PAL
1V 75 Ohm
8 Outputs
(Composite BNC,
VGA, S-Video, Loop
Through, Spot)
Enhanced
MPEG-4,
M-JPEG
NTSC 704 x 480 /
PAL 704 x 576
Real
Time
Display
CIF 240ips / 200ips
HD1 120ips / 100ips
D1 60ips / 50ips
2
1
USB
8 Port
4
Port
4
Channel
Input
1
Channel
Out
12VA,
6A
7.50 Kg
(without
HDD)
SVR-1648DVD
16 Channel
Input (BNC) /
NTSC / PAL
1V 75 Ohm
16 Outputs
(Composite BNC,
VGA, S-Video, Loop
Through, Spot)
Enhanced
MPEG-4,
M-JPEG
NTSC 704 x 480 /
PAL 704 x 576
Real
Time
Display
CIF 480ips / 400ips
HD1 240ips / 200ips
D1 120ips / 100ips
2
1
USB
16
Port
4
Port
4
Channel
Input
1
Channel
Out
12VA,
6A
7.50 Kg
(without
HDD)
Model
Video Board
Camera
Inputs
Frame Rate for
Monitoring
Frame Rate
for Recording
System
CPU
P/T/Z Camera
Control
Remote Control
Time Date
Stamp
Audio
Record
Data
Back Up
Operation
System
Slot Type
(Interface)
5VDC
Input
To Use
2-Cards
VRMS-1648
VCB-480-16EX
16
Channel
Live Display
480 FPS
(NTSC) /
400 FPS (PAL)
Max. 480 FPS
(NTSC) /
400 FPS
(PAL)
P4 3.2GHz
Yes
Setting, Display
Control, Relay
Output, P/T/Z
Camera
Yes
16
Channel
DVD,
DAT,
HDD,
CD-RW
Windows
2000, XP,
2003, Vista,
Windows 7
PCI
Express
Yes
Yes
VRMS-3296
VCB-960-32EX
32
Channel
Live Display
480 FPS
(NTSC) /
400 FPS (PAL)
Max. 960 FPS
(NTSC) /
400 FPS
(PAL)
P4 3.2GHz
Yes
Setting, Display
Control, Relay
Output, P/T/Z
Camera
Yes
16
Channel
DVD,
DAT,
HDD,
CD-RW
Windows
2000, XP,
2003, Vista,
Windows 7
PCI
Express
Yes
Yes
Model
Video Output
Video Input
Switch Attribute
Video / Audio
Switch
Switch
Mode
Switch Speed
Video
Alarm
Data
Backup
Screen Display
Image Input
Mode
IP Mode
Dimension
VMS-2000 Series
Modular 4 ~
16 Channels
Modular 4 ~
16 Channels
Manual / Auto
Cross Point
Switch and
Salvos
Synchronous
Switch
Power
Synchronous
Switch
PAL: 20ms,
NTSC: 16.7ms
Video Loss
Detection
Alarm
Computer
Backup
Date / Time,
Camera Title,
Alarm Info, etc
Computer
Input (Veilux
Software)
Ethernet
Mode or
One Channel
Video Server
430mm (W) x
88mm (H) x
300mm (D)
VMS-3000 Series
Modular 4 ~
16 Channels
Modular 32 ~
144 Channels
Manual / Auto
Cross Point
Switch and
Salvos
Synchronous
Switch
Power
Synchronous
Switch
PAL: 20ms,
NTSC: 16.7ms
Video Loss
Detection
Alarm
Computer
Backup
Date / Time,
Camera Title,
Alarm Info, etc
Computer
Input (Veilux
Software)
Ethernet
Mode or
One Channel
Video Server
430mm (W) x
132mm (H) x
240mm (D)
VMS-4000 Series
Modular 16 ~
32 Channels
Modular 48 ~
294 Channels
Manual / Auto
Cross Point
Switch and
Salvos
Synchronous
Switch
Power
Synchronous
Switch
PAL: 20ms,
NTSC: 16.7ms
Video Loss
Detection
Alarm
Computer
Backup
Date / Time,
Camera Title,
Alarm Info, etc
Computer
Input (Veilux
Software)
Ethernet
Mode or
One Channel
Video Server
430mm (W) x
132mm (H) x
240mm (D)
VMS-9000 Series
Modular 48 ~
64 Channels
Modular 112 ~
256 Channels
Manual / Auto
Cross Point
Switch and
Salvos
Synchronous
Switch
Power
Synchronous
Switch
PAL: 20ms,
NTSC: 16.7ms
Video Loss
Detection
Alarm
Computer
Backup
Date / Time,
Camera Title,
Alarm Info, etc
Computer
Input (Veilux
Software)
Ethernet
Mode or
One Channel
Video Server
430mm (W) x
396mm (H) x
300mm (D)
Toll Free: (800) 510-6528
www.veilux.net
41
DIGITAL VIDEO RECORDER DVR SERIES
8 Channel, 16 Channel
STANDALONE
DVR
RACK
MOUNT DVR
CMS
FEATURES
MATRIX
SWITCHER
KEYBOARD
•Backup
- Powerful Backup (AVI, Native DB) and Support Various Device
(USB, CD, DVD, FTP)
- Scheduled FTP Backup
•Network
- Easy Network Configuration (STATIC, DHCP, DDNS)
- Live View & Search Via Web Viewer
- Mobile Phone View Support
- Support CMS (Central Monitoring System) via 128 Channel
- UPnP NAT Traverse
- Support Time Sync Via NTP
•Interface
- 2 x SATA HDDs + 1 x ODD
- Support 4 Channel Audio
- Support Loop Output
- Support Various Input Device (Mouse, Remocon, Front Button)
•ETC
- Support S.M.A.R.T. (Self Monitoring Analysis and Reporting Technology)
- Easy Multilingual Interactive GUI
- Multi Language (More Than 8 Languages)
- Support Various Input Device (Mouse, Remocon, Front Button)
•Record
- Realtime Recording Speed Up to 480/400fps @ CIF
- Highly Effective H.264 Codec
- Independent Resolution, FPS, Quality and Audio Setting Per Channel
- Record by Duration (30 Days, 90 Days, ..., User Define), Write Mode
(Overwrite, Suspend)
- Support Daylight Saving
•Event
- Support Event Record (Motion, Alarm, Panic)
- Independent Realtime Event Schedule & Resolution Setting Per Channel
- Event (Motion, Alarm, S.M.A.R.T.) Notification Via Beep, Email, CMS
•PTZ
- Support Various PTZ, Keypad (80 Models at PTZ, 4 Models at Keypad)
- Related Event with PTZ Preset
•Search
- Various Search Mode (Calendar, Timeline, Event, POS
- Quick Playback by Right Click Mouse Button on Live
MONITOR
DIAGRAMS
4
5
Front Panel View - 8, 16
IR
POWER
SEARCH
Q.MENU
DIGITAL VIDEO RECORDER
POWER
REC
ALARM
NET
INFO
DISPLAY
PTZ
BACKUP
LEN
REW
PLAY/PAUSE FAST
STOP
REC
USB 2.0
HOUSING
1
1. DVR Writer
2. USB Port
3. Play Back Record Menu
2
4. PTZ Control Menu Control Buttons
5. Menu Control Joystick
3
14
13
Back Panel View - 16 CH
12
M A IN
OU T
VID EO
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
SPO T
OU T
LOO P
OU T
ALARM IN
AUD IO
IN 1
AUD IO
IN 2
AUD IO
IN 3
1
42
Toll Free: (800) 510-6528
www.veilux.net
AUD IO
IN 4
AUD IO
OUT
M OU SE
PS2
S-VH S
2
3
4
VGA
5
ETHERN ET
6
E-SATA
RS-485
+ -
D C 12V
7
8
9
ALARM IN
10
1. Audio In (CH 1~4)
5. VGA Out
9. DC (12V / 5A)
13. Video In (CH 1 ~ 16)
2. Audio Out
3. Mouse (PS/2)
4. S-Video Out
6. Ethernet
7. E-SATA
8. RS-485
10. Alarm In (#1 ~ 16)
11. Alarm Out (#1 ~ 4)
12. Loop Out (CH 1 ~ 16)
14. Main TV Out
15. Spot TV Out
ALARM OU T
11
15
16CH BNC, 1Vp-p
1 x Dsub 15 Pin (1024 x 768)
Main Output, Spot Output
1 x BNC (Composite)
AUDIO
Audio Input / Audio Output
4CH RCA / 1Ch RCA
LIVE VIEW
Resolution
Live FPS
16 Channel
Multi Screen
704 x 480(NTSC), 704 x 576(PAL)
240fps
480fps
1, 4, 9 Screen
1, 4, 9, 16 Screen
Sequence Time
1 ~ 60 Sec.
RECORDING
Compression
H.264 / G.726
Rate (NTSC)
Max. 240fps for HD1
Rate (PAL)
Max. 200fps for HD1
Quality
Schedule
Pre-Alarm / Post-Alarm
Max. 400fps for CIF
5 Levels
Normal / Normal + Motion / Normal + Motion + Alarm
5 Sec. (Fixed) / 10 Sec. ~ 30 Min.
Holiday
Storage / E-SATA
Max. 480fps for CIF
Support Holiday Schedule
SATA HDD 2 HDD + 1 ODD / E-SATA Data Recording
SEARCH
Mode
Calendar / Event / POS
Fwd. Playback, Rev. Playback
x1 / x4 / x8 / x16 / x32 / x64
Quick Playback
Multi Screen
Go To 10 Minutes Ago
1, 4, 9 Screen
1, 4, 9, 16 Screen
ALARM
Sensor Input
4CH, NO / NC
Relay Output
1CH, NO / NC
EVENT
Source
Notification
Alarm In / Power Up / Motion / Video Loss / HDD Failure
Alarm Out / Buzzer / E-Mail
BACKUP
Format
Native Database / AVI
Media
USB2.0 Flash Disk / USB-CD / USB-DVD / FTP
CONTROL
PTZ Port, Keyboard
Function
KBD Protocol
RACK
MOUNT DVR
8CH BNC, 1Vp-p
VGA Output
KEYBOARD
Video Input, Video Output
NTSC / PAL
CMS
VIDEO
Standard
MATRIX
SWITCHER
Quadplex (Live / Recording / Network / Backup or Playback)
MONITOR
Multiplex Operation
SVR-1648DVD
LEN
8 Channel
SVR-824DVD
HOUSING
ITEM
STANDALONE
DVR
DIGITAL VIDEO RECORDER DVR SERIES
8 Channel, 16 Channel
1 x RS-485 / Up to 19.2kbps
PTZ, Focus, 128 Preset, Preset Tour
Up to 4 Protocols
Toll Free: (800) 510-6528
www.veilux.net
43
INDUSTRIAL RACK MOUNT AVA DVR
VRMS-1648, VRMS-3296
STANDALONE
DVR
BENEFITS
RACK
MOUNT DVR
•Easy to Use Very Intuitive
•Easy to Install
•Efficient Storage Management
•Easy to Control and Manage with Multi Level User Management
•Fully Backed and Supported By Veilux Customer Service
•Affordably Priced
CMS
MODEL
MATRIX
SWITCHER
KEYBOARD
Hard Drive Space
Video Board
Camera Inputs
Frame Rate for Recording
Empty Hard Disk for Recording
VCB-480-16EX
16 Channel
Max. 480 FPS (NTSC) / 400 FPS (PAL)
VRMS-1648-2TB
2 Terabyte Hard Disk for Recording
VCB-480-16EX
16 Channel
Max. 480 FPS (NTSC) / 400 FPS (PAL)
VRMS-1648-4TB
4 Terabyte Hard Disk for Recording
VCB-480-16EX
16 Channel
Max. 480 FPS (NTSC) / 400 FPS (PAL)
VRMS-1648-6TB
6 Terabyte Hard Disk for Recording
VCB-480-16EX
16 Channel
Max. 480 FPS (NTSC) / 400 FPS (PAL)
VRMS-1648-8TB
8 Terabyte Hard Disk for Recording
VCB-480-16EX
16 Channel
Max. 480 FPS (NTSC) / 400 FPS (PAL)
Empty Hard Disk for Recording
VCB-960-32EX
32 Channel
Max. 960 FPS (NTSC) / 400 FPS (PAL)
VRMS-3296-2TB
2 Terabyte Hard Disk for Recording
VCB-960-32EX
32 Channel
Max. 960 FPS (NTSC) / 400 FPS (PAL)
VRMS-3296-4TB
4 Terabyte Hard Disk for Recording
VCB-960-32EX
32 Channel
Max. 960 FPS (NTSC) / 400 FPS (PAL)
VRMS-3296-6TB
6 Terabyte Hard Disk for Recording
VCB-960-32EX
32 Channel
Max. 960 FPS (NTSC) / 400 FPS (PAL)
VRMS-3296-8TB
8 Terabyte Hard Disk for Recording
VCB-960-32EX
32 Channel
Max. 960 FPS (NTSC) / 400 FPS (PAL)
VRMS-1648
VRMS-3296
the DVR come with
500 GB Hard Disk
for operating system
and without monitor
MONITOR
The Veilux pc based digital video recorder (DVR) is the next generation of an affordable professional level DVR. The unit is designed for the entry to professional level market that requires one to
thirty two camera inputs, powerful video storage management with efficient H.264 compression, multi-event recording, quick and easy to use graphical user interface (GUI), internal storage capacity up to 16 TB, and remote client connectivity to as many as 50 veilux dvr servers with the use of CMS Central Monitoring Station replaces matrix switcher display up to 4 monitors. The veilux
pc based system not only replaces the traditional VCR and multiplexer combination, it provides a solution that scales from stand-alone to network video streaming.
Veilux pc based digital video recorder support advanced video analytics that is capable of tracking up to 100 simultaneously moving objects. Systems settings allow the drawing of virtual barriers
with intrusion detection which detects if object is within or crossing a virtually defined zone or line allowing alarm triggers through the DVR server with a few settings.
LEN
Veilux DVR’s are simple to playback with a graphical time/date interface, operations such as easy search, fast-forward, and backward, slow motion, and pause, frame by frame or even panoramic
view. It offers zoom in functionality on playback to pick up extra detail, with the capability of adjusting contrast and clarity. Video files can be backed up in their native video format with its built-in
player making it easy to give to authorities to playback.
HOUSING
Each camera is separately configured for frame rate, motion areas, resolutions, compression recording method and more. Now you can give that important camera additional frames, and leave
the back room to record just when needed. Then, set cameras for remote notification-just in case. This DVR has multi level access for all the DVR users blocking and allowing certain features and
DVR functions from being accessed remotely or locally.
All Veilux DVR server supports major Point of Sale cash registers in the market by embedding text overlay on the camera to view money transactions live over video. Video files can be search by
and video transaction event by querying a certain product name, dollar amount, transaction type etc. This advanced feature provides flexibility and saves time on video playback and video search.
With Multi-Event recording and HD Storage Management customers can set recording schedules and allocate storage space to best match their retention requirements. Add the improvements of
H.264 compression and the the available advanced video analytics with the cost offered veilux dvr becomes an extremely cost-effective system for any small business to enterprise level surveillance solution.
44
Toll Free: (800) 510-6528
www.veilux.net
INDUSTRIAL RACK MOUNT AVA DVR
Audio Decoding
Audio Input / Audio Output
Sampling Ratio
Encoding Output Bit Rate
G.722
16 Channels / 16 Channels
8 Khz
16 Kbps
Interfaces
Video Connectors:
Optional Loop Thru
Network Port: / Serial Port:
Optional Alarm:
Monitor Ports: / Interface Ports:
Recording Optional Audio:
System Audio:
4, 8, 16, 32 Female BNC 75 Ohms Inputs
4, 8, 16 or 32 Female BNC 75 Ohms Output Loop Through
Ethernet Port 10M / 100M, RJ45 / RS-232 Port
16 Alarm Inputs, 4 Relay Outputs
VGA, RCA Spot Monitor Output 75 Ohm / USB 2.0
Input 16 x 3.5mm Monaural Jacks
Ouput 16 x 3.5mm Monaural Jacks
Microphone in, and audio output
D1, 4CIF (704 x 576) / 2CIF (704 x 288) / CIF (352 x 288)
30 Frames Per Second
1, 4, 6, 9, 10, 13, 16, 25, 36
Frame Rate
NTSC: 1/16 ~ 30 FPS / PAL: 1/16 ~ 25 FPS
Network Capabilities
Protocols:
Panel Operation
IP, TCP, UDP, PPoE, DHCP, PPP
Operating System
Operation:
Buttons
Microsoft Windows
Front Panel, Keyboard, Mouse, CD / DVD+-RW
Power, Reboot, DVD Eject Button, Front USB 2.0 x 2 Connector
Electrical
Input Voltage:
Power Consumption
Power of Protection
Cable Type
USA Standard
European Standard
UK Standard
Internal Storage
Recording Modes
Up to 8 SATA Hard Disks, 500 GB Included
Manually, Scheduled, Alarm, Motion Detection
Image Encryption
Image Authentication
Watermark Technology
Software Included
Selectable Switch AC 100-240V 50/60 Hz
400W
Power On Self Recovery
117 VAC, 3 Prongs, 6FT or 1.8 Meters
220 VAC, 3 Prongs, Molded Connector 6FT or 1.8 Meters
250 VAC, 3 Prongs, Molded Connector 6FT or 1.8 Meters
Physical
Dimensions
Color of Chassis
Front Panel
Material of Main
Chassis
Material of Front Panel
Front Panel Filter
Indicators
Security Lock
Approximate Weights
19 x 7 x 20.8 Inches / 482.6 x 177.8 x 528.4mm
Black
Blue
1.2mm SECC Zinc-Coated Steel
Aluminum
Removable and Washable
LEDs for On / Off, HDD, Fan & Alarm
Front Panel
35 LBS (15.9 KGS) Without Hard Disks
Every Additional Hard Disks Weighs Approximately
1.5 LBS (0.7 KGS)
Client Applications
Remote Client
Storage
Channel Sequential
Web Client
CMS Optional
RACK
MOUNT DVR
PAL:
Video Display Rate:
Video Display Modes:
(Main Monitor)
Video Display Modes:
(Spot Monitor)
CMS
Recording Resolution
NTSC:
D1, 4CIF (704 x 480) / 2CIF (704 x 240) / CIF (352 x 240)
MATRIX
SWITCHER
Spot Monitor
Video Encoding
Video Inputs
NTSC / PAL Composite
NTSC / PAL VGA (1024 x 768)
60 Hz Capacities for NTSC / 50 Hz Capacities for PAL
RCA Composite
H.264 MPEG4 / Part 10, MPEG4, MJPEG Per Channel
16 / 32 Analog Inputs
KEYBOARD
Input
Output
MONITOR
Optional Audio Available Models
Video
LEN
•H.264 Compression MPEG4 Selected Per Channel
•Up to 16,000 Gigabyte of Storage
•Optional DVD Video Recorder
•Up to 704 x 480 / 704 x 576 NTSC / PAL Resolution
•Multi-Event Recording Mode
•Channel Independent Resolution, Quality, and Frame Rate Settings
•HDD Storage Manager for Disk Optimization
•Continuous, Motion, Alarm, Instant, and Scheduled Recording
•Full-Function Remote Agent with Administration Functions
•Real-Time Display and Recording
•Remote Desktop VIA IE Browser or Client Software
•Supports Up to 32 Video Inputs
•16 Audio Inputs Option Available
•TCP/IP Based Network, LAN, PSTN, ISDN
•Remote Desktop Setting, Display Control, Relay Output, P/T/Z Camera
•Remote Screen 1, 4, 9, 16, 32 Channel Split Screens
•Remote Control the P/T/Z Camera, Just as if you Were at the Local DVR
•Selectable Recording Option Per Camera
•Selectable Frame Rate Recording Per Camera
•Selectable Video Compression Recording Per Camera
•Watchdog for Auto Reboot Hardware in Case of Power Failure
•Integrated with ATM / Point of Sale System for Image Text Overlay
•Date Timestamp Overlay Camera
•Central Monitoring Software Option Available to Monitor Up to 50 DVR Systems
•Supports PDA Microsoft Windows Mobile 2003 Second Edition
•Microsoft Windows Mobile 5.0
•Supports Dynamic DNS Services
•Supports Audio, Sensors and Relays Built Into the Network Video Servers
•Optional Supports Up to 4 License Plate Recognition Cameras, Storing License Plates Which
Can Be Triggered By Motion Sensor Option
TECHNICAL SPECIFICATIONS
HOUSING
FEATURES
STANDALONE
DVR
VRMS-1648, VRMS-3296
Remote Access Via Client Software, Live View,
Full DVR Configuration, Remote Playback, E-Map
Remote Access Via Browser, Screen Partitions,
Remote Playback
Manage, View, Playback, E-MAP, Alarm Monitoring,
Up to 50 DVR
Certifications - CE and FCC | UL Listed
Toll Free: (800) 510-6528
www.veilux.net
45
VCMS-10, VCMS-30, VCMS-50
Central Monitoring Station For Rackmount DVR
STANDALONE
DVR
FEATURES
•Manage 1000’s of Cameras from One Location
- You Can Manage Hundreds of Cameras From One System
- Monitor Up to 10, 30, or 50 DVR Servers at the Same Time (by License)
- View Up to 64 Channels On Each Monitor (Multiple Monitors Supported)
RACK
MOUNT DVR
•View Up to 4 Monitors from One Server
- One Central Monitoring Server Can be Connected to Multiple Monitors
- Each Monitor Can Display Separate Information
(i.e., E-Map, Alarms, Custom Video Recalls, etc)
•Roll Over Management of Alarm Functions
- One Major Function of the CMS is Alarm Monitoring
- Each System Can Monitor Various and Multiple Alarm Conditions from Multiple DVRs
CMS
- Can Set Various and Separate Actions (Beep, Display Video, Alert, Email, Save, etc.)
- If One Alarm is Being Monitored, Subsequent Alarms
Can be “Rolled Over” to the Next Station
•Global E-Mapping and DVR Mapping
MATRIX
SWITCHER
- Provides Global Area E-Mapping and DVR Server E-Mapping
CMS (Central Monitoring Station is a
centralized DVR Management System)
CMS has many useful features to help
center users.
KEYBOARD
- NVR
- Video Analytics
- When Alarms Occur, the Alarmed Camera or DVR Shows Up on the E-Map, and in Video
•Remote Control of the DVR Server
- The CMS is Capable of Controlling the DVRs in Their Remote Location
- Supports and Expands the RMS functions (Including Search, Setup and PTZ)
•Multi User Management Support
- Supports Multiple Users
- Each User Has Different Levels and Permissions
•Scalable Software is Easy to Use
- Easy to Use Windows Based Interface
- Developed By Windows MDI
- Simultaneously Display Multiple Windows
- Supports Drag & Drop Operations
MONITOR
LEN
HOUSING
46
Toll Free: (800) 510-6528
www.veilux.net
VMS-2000 Series & VMS-3000 Series
ITEM
VMS-2000 Series
Video Output
VMS-3000 Series
Modular 4~16 Channels
Video Input
Modular 16~64 Channels
Modular 32~144 Channels
Video Input Signal: 1Vp-p (75Ω)
Video Output Signal: 1Vp-p (75Ω)
RACK
MOUNT DVR
Audio Input Signal: 0.5Vp-p~5Vp-p (600Ω)
Audio Output Signal: Input Follower
Video S/N: >70.5 dB
Audio S/N: >58 dB
Video / Audio Index
The Video Input Isolates: >55 dB
The Video Output Isolates: >50 dB
The Audio Frequency Output Isolates: >55 dB
FEATURES
Audio Channel Bandwidth: 50Hz~30KHz
Switch Attribute
MATRIX
SWITCHER
Video Channel Bandwidth: 12MHz
Manual / Auto Cross Point Switch and Salvos
Video / Audio Switch
Synchronous Switch
Power Synchronous Switch
Switch Speed
PAL: 20ms, NTSC: 16.7ms
Video Alarm
Video Loss Detection Alarm
Data Storage
Built-in Memorizer, Non-Volatile Memory:
For a Minimum of 10 Years
Data Backup
KEYBOARD
Switch Mode
Computer Backup
Screen Display
Date / Time, Camera Title, Alarm Info, etc
Image Input Mode
Computer Input (Veilux Software)
Ethernet Mode or One Channel Video Server
430mm(W) x 88mm(H) x
300mm(D)
Dimension
430mm(W) x 132mm(H) x
240mm(D)
VMS-2U1604 (16 x 4)
VMS-2U3204 (32 x 4)
VMS-2U3208 (32 x 8)
VMS-2U6408 (64 x 8)
VMS-2U3212 (32 x 12)
VMS-2U6412 (64 x 12)
VMS-2U3216 (32 x 16)
VMS-2U4816 (48 x 16)
VMS-2U6416 (64 x 16)
VMS-3U3204 (32 x 4)
VMS-3U6404 (64 x 4)
VMS-3U9604 (96 x 4)
VMS-3U11204 (112 x 4)
VMS-3U15204 (152 x 4)
VMS-3U3208 (32 x 8)
VMS-3U5608 (56 x 8)
VMS-3U9608 (96 x 8)
VMS-3U11208 (112 x 8)
VMS-3U12808 (128 x 8)
VMS-3U14408 (144 x 8)
VMS-3U4812 (48 x 12)
VMS-3U6412 (64 x 12)
VMS-3U9612 (96 x 12)
VMS-3U11212 (112 x 12)
VMS-3U12812 (128 x 12)
VMS-3U4816 (48 x 16)
VMS-3U6416 (64 x 16)
VMS-3U9616 (96 x 16)
VMS-3U11216 (112 x 16)
VMS-3000 Series
VMS-3000 Series
VMS-2000 Series
MODEL NO. - VIDEO INPUT x VIDEO OUTPUT
Toll Free: (800) 510-6528
www.veilux.net
MONITOR
IP Mode
LEN
•Camera Title Input Through PC, Built-in IP Port (optional)
•Adopt Built-in IP Control Mode and Video Server, the Operation of Mainframe and Video
Switch are Controlled via IP; Support IE (optional)
•Modular Structure for Easy Expansion, 2U Standard Aluminium Alloy Case
•Password Protection to Prevent Unauthorized Operating; System Partitioning with Different
Keyboard Priorities
•Video / Audio Port and Communications Port with Surge Protection and Thunder proof
•Video / Audio Switch Card, Alarm Input Card, Follow Control Card Integrated as
Surveillance Mainframe (optional)
•Connect 16 Branch Keyboards; More Than 3 Level Ethernet Connections is Available for
Remote Programming and Controlling
•All Functions of Matrix Can Be Set by Menu, Input and Output with Loop Design (optional)
•Auto Turn on Pick-up Sensor and Light, Auto Switch Image and Start Recording After
Alarming (optional)
•Alarm Mode: Timed, Manual, Normally Alarm Arming / Alarm Disarming and Alarm
Recording (optional)
•Matrix Control P/T, PELCO-D, PELCO-P, KALATEL (Phillips), Veilux Protocol, Baud Rate
•Computer Backup for System Set, Hot Backup Mainframe Option Design (optional)
•Plug-in Scalable High Density Architecture for Easy Expansion, 3U Standard Aluminium
Alloy Case (VMS-3000 Series)
CMS
The Audio Frequency Input Isolates: >58 dB
HOUSING
VMS-2000 Series
STANDALONE
DVR
Matrix Switcher
47
VMS-4000 Series & VMS-9000 Series
Matrix Switcher
STANDALONE
DVR
VMS-4000 Series
VMS-9000 Series
Video Output
ITEM
Modular 16~32 Channels
Modular 48~64 Channels
Video Input
Modular 48~294 Channels
Modular 112~256 Channels
Video Input Signal: 1Vp-p (75Ω)
Video Output Signal: 1Vp-p (75Ω)
RACK
MOUNT DVR
Audio Input Signal: 0.5Vp-p~5Vp-p (600Ω)
Audio Output Signal: Input Follow
Video S/N: >70.5 dB
Audio S/N: >58 dB
Audio / Video Index
The Video Input Isolates: >55 dB
The Video Output Isolates: >50 dB
CMS
The Audio Frequency Input Isolates: >58 dB
The Audio Frequency Output Isolates: >55 dB
Audio Channel Bandwidth: 50Hz~30KHz
MATRIX
SWITCHER
Video Channel Bandwidth: 12MHz
Switch Attribute
Manual / Auto Cross Point Switch and Salvos
KEYBOARD
Video / Audio
Synchronous Switch
Switch Method
Power Synchronous Switch
Switch Speed
PAL: 20ms, NTSC: 16.7ms
Video Alarm
Video Loss Detection Alarm
Data Storage
Built-in Memorizer, Non-Volatile Memory: for a Minimum of 10
Years
Data Backup
Computer Backup
Screen Display
Date / Time, Camera Title, Alarm Info, etc
Image Input Mode
Computer Input (Veilux Software)
IP Mode
Environment
Dimension
Ethernet Control Mode or One Channel Video Server
Temperature: -10°C~+50°C,
Humidity: 90%
(Non-Condensing)
--
430mm(W) x 132mm(H) x
240mm(D)
430mm(W) x 396mm(H) x
300mm(D)
LEN
HOUSING
VMS-4U11416 (144 x 16)
VMS-4U16016 (160 x 16)
VMS-4U22416 (224 x 16)
VMS-4U25616 (256 x 16)
VMS-4U29416 (294 x 16)
VMS-4U12832 (128 x 32)
VMS-4U19232 (192 x 32)
VMS-4U25632 (256 x 32)
VMS-9U11248 (112 x 48)
VMS-9U19248 (192 x 48)
VMS-9U25648 (256 x 48)
VMS-9U26248 (262 x 48)
VMS-9U9664 (96 x 64)
VMS-9U12864 (128 x 64)
VMS-9U19264 (192 x 64)
VMS-9U25664 (256 x 64)
Toll Free: (800) 510-6528
www.veilux.net
VMS-9000 Series
VMS-4U4820 (48 x 20)
VMS-4U6420 (64 x 20)
VMS-4U9620 (96 x 20)
VMS-4U11220 (112 x 20)
VMS-4U4824 (48 x 24)
VMS-4U6424 (64 x 24)
VMS-4U9624 (96 x 24)
VMS-4U11224 (112 x 24)
VMS-4U5628 (56 x 28)
VMS-4U6428 (64 x 28)
VMS-4U9628 (96 x 28)
VMS-4U10428 (104 x 28)
VMS-4U3232 (32 x 32)
VMS-4U5632 (56 x 32)
VMS-4U6432 (64 x 32)
VMS-4U9632 (96 x 32)
FEATURES
•Camera Title Input Through PC, Built-in IP Port (optional)
•Adopt Built-in IP Control Mode and Video Server, the Operation of Mainframe and Video
Switch are Controlled via IP; Support IE (optional)
•Plug-in Scalable High Density Architecture for Easy Expansion, 4U (VMS-4000 Series),
9U (VMS-9000 Series) Standard Aluminium Alloy Case
•Password Protection to Prevent Unauthorized Operating; System Partitioning with Different
Keyboard Priorities
•Video / Audio Port and Communications Port with Surge Protection and Lightning Proof
•Computer Backup for System Set, Hot Backup Mainframe Option Design
•Video / Audio Switch Card, Follow Control Card Integrated as Surveillance Mainframe
•Connect 16 (VMS-4000 Series), 64 (VMS-9000 Series) Branch Keyboards, More Than
3 Level Ethernet Connections is Available for Remote Programming and Controlling
•All Functions of Matrix Can Be Set Through Menu, Input and Output with Loop Design
•Expand to 512 Channel Video Outputs and 9999 Channel Video Inputs, Input and
Output with Loop Design (VMS-9000 Series)
VMS-9000 Series
MODEL NO. - VIDEO INPUT x VIDEO OUTPUT
VMS-4000 Series
MONITOR
48
VMS-4000 Series
VK-64
CCTV Receiver (DRX-502/500), PTZ Dome Cameras
Communication Method
RS-485 (422)
Communication Speed
RS-485 - 9600bps, N, 8, 1
Connector
Modular Cable Connection with Junction Box
Power Supplied Via Junction Box
Package
Junction Box, 5M Cable (Modular Jacks Both Ends)
Operating Distance
Max 1.2Km (When Using Shielded Twisted Pair Cable)
Power
12W
Operating Condition
0ºC~+40ºC
Weight
Approx. 3.5Kg
Dimensions
337.5(W) x 50(H) x 153(D)mm
MATRIX
SWITCHER
Connecting Unit
RACK
MOUNT DVR
VK-64
Pan / Tilt, Zoom, Power, Auto Pan, AUX Control x 2, Preset
CMS
ITEM
Control
STANDALONE
DVR
Controller (3-Axis Joystick Keyboard)
FEATURES
HOUSING
LEN
MONITOR
KEYBOARD
•Controller For The Remote Control of CCTV Devices:
Power, Pan / Tilt / Zoom Lens, AUX
•Controls Up To Maximum 255 CCTV Receivers
•Preset Control: 64 Positions Memory Set For Each Camera
•Built-In Requital Ability For Electricity Failure: Power, Auto, Pan, Preset Position
•Built-In Back Light For LCD Window
•3-Axis Joystick Control To Pan / Tilt / Zoom Movement
•Can Be Connected With Up to 8 Sub-Keyboards
•Controller to the PTZs, Matrix Switchers, and Standalone DVR
Toll Free: (800) 510-6528
www.veilux.net
49
LCD CCTV MONITOR
STANDALONE
DVR
ITEM
RACK
MOUNT DVR
Metal Case and Tempered Glass
Resolution
1280(H) x 1024(V)
Colors
16.7 Million Colors
Contrast Ratio
500:1 (Typical) Brightness: 300 Cd/m2
Response Time
12 ms
TV Lines
NTSC 600 Lines, PAL 800 Lines
NTSC / PAL Automated Switch
Connector
1*VGA, 1*BNC (In + Out), 1*Audio, 1*S-Video
Wall Mount
Optional
Packing
395*510*140mm
CMS
MATRIX
SWITCHER
KEYBOARD
MONITOR
LEN
HOUSING
50
VLCD-17
MODEL NO.
MONITOR SIZE
VLCD-19
19” TFT LCD Monitor
VLCD-22
22” TFT LCD Monitor
VLCD-32
32” TFT LCD Monitor
VLVD-42
42” TFT LCD Monitor
VX-WLCDM
TFT LCD Monitor
ITEM
FEATURES
VX-WLCDM
Screen
2.5” TFT LCD
Pixel
480 x 234
Power
5VDC
Battery
3.7V (Nokia N73 Battery is Replaceable)
Power Consumption
1.2W
Operation Temp’
0°C~50°C
Storage Temp’
-30°C~80°C
Weight
100g
Size
85 x 64 x 209 (mm)
Accessories
AV Cable, Instruction Manual, Charger, Battery, Wrist Strap
Toll Free: (800) 510-6528
www.veilux.net
•2.5 inch TFT LCD Monitor
•Manual Operation
•Video System Input:
PAL / NTSC
•Specially Used in CCTV
Testing and Monitoring
•Available For Navigation
•No Radiation
•Battery is Rechargeable
5 to 100mm
Aperture (f-stop)
1.4~360
f1.4 - C
1.8
Lens Format
1/3”
1/3”
1/3”
Mount
CS
CS
CS
View Angle Hor.
95.6°~22.1°
77.6° to 35.4°
44 - 2.7
View Angle Vertical
--
57.6° to 26.6°
--
Minimum Object Dis.
--
0.40 m (1.31 ft)
--
Back Focal Length
7.7mm
--
--
0.1mm
--
--
--
--
--
--
Yes
DC
M.O.D.
Effective Aperture
AI
VL-0358A
Vari-Focal Manual Iris Lens (DC Drive)
•1/3” Format
•CS Mounts
•Color Corrected Optics
•High Quality, Compact Design
•Fixed and Variable Focal Lengths
•Slip Clutch on Lens Mount for
Easy Positioning
Front
Ø28mm
Rear
Ø10.2mm
AI Control
--
--
Screw Thread
1” x 1/32” - 6G
--
--
Weight:
160G
38g (1.34 oz)
0.8
Size
44 x 67.6 x 51.6mm
34.0 x 43.5 mm
(1.34 x 1.71 in)
--
Housing
Aluminium Alloy
#6061
--
--
Screw
Copper
--
--
Lens
Glass Lenses
--
--
Lide
Plastic
--
--
Color
Black
--
--
Surface Finish
Sand Oxidation
--
--
MATERIAL
RACK
MOUNT DVR
VL-05100A
3.5 to 8.0mm
CMS
VL-0358A
2.8~12mm
MATRIX
SWITCHER
VL-02812A
KEYBOARD
•Focal Length: 2.8~12mm
•Aperture: 1.4~360
•Mount: CS
•Image Format: 1/3”
•Angle of View: 95.6°~22.1°
•M.O.D.: 0.1m
•Weight: 160g
•Size: Dia. 44 x 67.6 x 51.6mm
ITEM
Focal Length
MONITOR
VL-02812A
Vari-Focal Auto Iris Lens (DC Drive)
STANDALONE
DVR
LENS
VL-05100A
Auto Iris Lens (DC Drive)
HOUSING
LEN
The varifocal range from 5 to 100
mm is extremely large. This range
allow fast and easy selection
of desirable field of view. For
instance, the angle of view of a
camera with 1/3” sensor can be
set from 55 to 2.7.
Toll Free: (800) 510-6528
www.veilux.net
51
VCH-619
Outdoor / Indoor Camera Housing
STANDALONE
DVR
RACK
MOUNT DVR
CMS
ITEM
151mm (W) x 145mm (H) x 390mm (L)
Suitable Camera
95mm (W) x 80mm (H) x 250mm (L)
Package
8pcs / ctn / 630mm x 405mm x 340mm
VCH-619 (Camera Housing)
VCH-619HB (Camera Housing with Heater & Blower)
Outdoor / Indoor Camera Housing
KEYBOARD
Nylon + Fiber Glass in Beige
390 mm
Certificate: CE + IP-66 Rating
Features
Optional Accessories: Heater, Blower
12VDC / 24VAC / 110VAC / 220VAC
Cable Thru Wall Mount
MONITOR
LEN
VHM-208
Housing Bracket
HOUSING
ITEM
VHM-208
Dimensions
75mm (W) x 280mm (L) x 115mm (H)
Package
20pcs / ctn / 465mm x 270mm x 465mm
Housing Bracket with Cable Managed
Features
Aluminum in Beige
Max. Load: 10kg
360° Swivel 120° Tilt
Toll Free: (800) 510-6528
www.veilux.net
145 mm
MATRIX
SWITCHER
Dimensions
Work with VHM-208 + VHM-209
52
OPTIONAL MODELS
VCH-619
LEGAL | Warranty / Terms & Conditions
WARRANTY: VEILUX warrants all of products to be free from defect in material or workmanship, and will remedy any such defect according to the terms of this Limited Warranty. All VEILUX CCTV products are warranted for a period of TWO YEARS.
VEILUX, at its discretion, will replace or credit any defective component(s) of VEILUX products at no charge for a period of 120 days from date of invoice.
Beyond 120 days VEILUX will repair at no charge, any defective component(s) for the initial twenty-four (24) months from the date of invoice.
The following requirements must be followed in full or warranty service and/or shipment will not be honored.
To make request for credit, replacement or claim for service under this Limited Warranty the original purchaser must obtain a Return Authorization Number (RA#) from VEILUX and return the VEILUX product, shipping prepaid, in the original shipping
container (or equivalent) assuming the risk of loss or damage in transit. The assigned RA# must be clearly marked on the outside of shipping container, and all original power cords, software, manuals, etc. must be included. A written receipt/invoice for
the VEILUX product, showing the date of purchase, dealers’s name and both the model and serial numbers of the product must accompany any request for credit, replacement, or claim for work to be performed under this Limited Warranty. VEILUX RA#
will be honored domestically for 30 days and internationally for 45 days from date of issue.
This Limited Warranty shall not apply if the product has damage due to abuse, misuse, misapplication, accident, or as a result of service or modification by any other than the authorized
VEILUX Service Center. If a product is returned to VEILUX for replacement or repair and no problem is found the purchaser will be billed a $50.00 fee for inspection as well as all associated freight charges. Any product that is returned to VEILUX for
replacement or credit without all original power cords, software CDs, manuals, etc. will be charged a 25% restocking fee and only receive partial credit.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE ON THE FACE HERE OF AND DESCRIBED ABOVE. NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL EXTEND BEYOND THE RESPECTIVE WARRANTY.
PERIOD DESCRIBED ABOVE. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
VEILUX SHALL NOT BE RESPONSIBLE OF LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSS ARISING FROM THE USE OF THIS PRODUCT. Some states do not allow the exclusion or limitation or incidental or c
onsequential damages, so the above exclusion may not apply to you. Additional information on obtaining service under Limited Warranty is available by contacting the VEILUX dealer from whom the product was purchased of by contacting VEILUX directly
at 877-801-8811 or 972-602-7846.
The Limited Warranty applies to al VEILUX products. However, the procedure for obtaining service may vary outside the continental United States. Contact your VEILUX dealer for such warranty service information. This warranty gives you specific legal
rights, and you may also have other rights which vary from state to state.
TERMS & CONDITIONS
Governing Terms & Conditions: Sales of the security video surveillance products by VEILUX are made only to the company’s authorized dealers/distribution on the company’s standard terms & conditions of sales, which are set forth herein (“The terms
and conditions”). These terms and conditions may be modified or supplemented only by written documents separately signed by the company’s authorized personnel at its headquarters in Grand Prairie, Texas. Any terms and conditions contained in any
purchase order of other form used by dealer/distributor to order a CCTV product which are different from, in addition to, or in any way inconsistent with these terms and conditions shall be of no force or effect whatsoever.
Products: The company reserves the right from time to time, to add or discontinue any product from those offered for sale by the company or to modify the specifications of any product without notice to the dealer/distributor
Acceptance of Order: Salespersons or any other representatives of the company are only authorized to solicit orders from dealers/distributors and have no authority to accept orders on behalf of the company. All orders become effective only if, and
when approved and accepted in writing by the issuance of its order acknowledgement. The company reserves the right to refuse any order.
Change or Cancellation of Accepted Order: Dealer/distributor may not change or cancel an accepted order without the prior written consent of the company. Cancellations accepted by the company will be conditioned on the payment by the dealer/
distributor if the company’s cancellation charges in accordance with the company’s cancellation policy is in effect at the time of cancellation.
Price: Unless otherwise specified in the company’s order acknowledgement or a written quotation from the company to the dealer/distributor each order is accepted subject to the following: All prices, quotations, shipments and deliveries by the
company are F.O.B. Grand Prairie, Texas / All prices are subject to change without notice / Price in effect at the time of the order is placed / All transportation and other delivery costs are for the account of the dealer/distributor.
Taxes: The purchase price for a product does not include any taxes, which may be applicable to the purchase, sale, value, use and transportation of the product. The dealer/distributor agrees to pay such taxes or alternatively to reimburse the company
upon demand for any such taxes which the company is liable for the collection of payment. Dealer/distributor may, in lieu, of such payment provide to the company, evidence of the issue of tax exemption certificate acceptable to the appropriate taxing
authority.
Delivery Title and Risk: Unless otherwise specified in the company’s acknowledgement, the company reserves the right to ship all or any part of the product specified in any accepted order. Title to the products shall pass to the dealer/distributor and
the dealer/distributor shall assume all risk and liability for loss, damage or destruction to such products after delivery to the carrier. If dealer/distributor should receive delivery of any product in damaged condition or should a shortage occur, dealer/
distributor shall report such damage or shortage to the delivery carrier and to the company within 48 business hours of receipt of goods by dealer/distributor. Any loss or shortage occasioned by damage occurring in transit will be for the account of
dealer/distributor. Unless otherwise mutually agreed upon in writing, shipping dates are approximate and the company shall not incur any obligation or liability to the dealer/distributor for failure to ship by the shipping date or any other date. The company
reserves the right to ship the products in a single or multiple shipments.
Force Majeure: If the company’s performance of its obligations under any accepted order is delayed or made impossible or commercially impractical due to any cause beyond the company’s reasonable control (including, without limitation, acts of
God, labor disputes, compliance with government regulations, equipment failure, shortages in transportation, inability to obtain necessary materials/products, defects or delays in performance by company’s suppliers or requirements of testing or product
approval authorities) the company shall have such reasonable additional time within which to perform the accepted order as may be res on ably necessary under the circumstances. In the event that the company is unable to obtain sufficient products to
meet all demands from customers, the company shall have the right to allocate deliveries to its customers in any manner which the company may, in its sole discretion, determine to be equitable.
Payment: The dealer/distributor shall make payment of the purchase price for the products in full to the company within the payment and credit terms granted by the company. The company reserves the right at any time to require the dealer/distributor
to provide satisfactory security for the due payment of the purchase price for the products in addition to the security interest reserved pursuant to the “Security” section. Failure to provide such security will entitle the company to hold further shipment
until such security is provided or to cancel the accepted order or so much of it as remains unfilled.
Security: The company reserves, until payment in full for the products is received, a purchase money security interest in all products sold to the dealer/distributor under each accepted order. A copy of the dealer/distributor contract with the company
may be filed as a financing statement with the appropriate state authorities to protect the company’s security interest in the products
Default: If the dealer/distributor fails to make payment in full for the products within the time period set forth above or within the time period expressly agreed upon in writing by the parties, such failure to pay on time constitutes a material breach of
contract by the dealer/distributor permitting the company to suspend delivery under any accepted order or other contact between the dealer/distributor and the company. The dealer/ distributor shall pay to the company an added service charge of 1½%
per month (or the legal maximum allowed in the deal/distributor’s state) on all delinquent invoices or portion thereof until paid. In the event that the company is required to take legal action, dealer/distributor shall pay all collection fees and/or attorney’s
fees plus any court costs.
Guarantor: The company may from time to time require a third party guarantor to guarantee payment of the company’s invoices submitted to the dealer/distributor under the terms of an accepted order. The guarantor shall agree to pay outstanding
invoices within the agreed payment terms for the accepted order and in addition a service charge of 1½% per month (or the legal maximum allowed in the dealer/distributor’s state) on all delinquent invoices or portion thereof until paid. In the event that
the company’ is required to take legal action, including the use of a collection agency to collect past due amounts, the guarantor shall pay all collection fees and/or attorney’s fees plus any court costs.
Returns: Authorizations and instructions for the return of any product must be obtained by dealer/distributor before returning any product for any reason. The product must be returned with complete identification, freight prepaid and in accordance with
the company’s most current return policies and procedures or it will not be accepted. For a copy of the most current returns policies call VEILUX service department at 877-801-5511 ext000. All items returned for credit are subject to inspection upon
receipt and a restocking charge. In no event will the company be responsible for any product returned without proper authorization or identification.
Installation and Service: Advice, Assistance, or Training: The company assumes no obligation or liability for any advice, technical assistance or training provided by the company to the dealer/distributor with respect to products, or for any results
occurring as a result of the application of such advice, technical assistance, or training and the dealer/distributor shall have sole responsibility for selection and supplications of the products appropriate for the end use of such products and for the proper
installation and servicing of such products.
Waiver: Waiver by the company of any breach of any of the terms and conditions shall not be construed as a waiver of any other breach, and the failure by the company to exercise any right arising from any default of dealer/distributor hereunder shall
not be deemed to be a waiver of such right, which may be exercised at any subsequent time.
Patents: The company shall indemnify and save dealer/distributor harmless from any judgement for damages and/or costs which may be rendered against dealer/distributor in any suite brought against dealer/distributor on account of the infringement
of any U.S. patent by any product supplied by the company providing that the dealer/distributor promptly notifies the company of the commencement of any suit and authorizes the company to settle or defend such suit at the company may see fit and
provide further that dealer/distributor renders every reasonable assistance which the company may require in defending such suit.
Assignment: Dealer/distributor shall not assign its rights or delegate its duties, responsibilities or obligations arising under any accepted order, in whole or in part without the prior written consent of the company. Any actual or attempted assignment
without the company’s prior written consent shall entitle the company to cancel such accepted order upon written notice to dealer/distributor.
Termination: Company may terminate any accepted order or part thereof for any reason at the company’s convenience upon written notice to dealer/distributor. Dealer/distributor hereby waives a claims for consequential damages resulting from or
relating to such termination, including, without limitation, any lost products or loss of anticipated profits and to accept as its sole remedy for termination the reasonable additional costs of obtaining substitute goods of the same quantity and quality as the
products provided that in no event shall such costs exceed the price of the accepted order or part thereof so terminated as stated on the company’s acknowledgement. Any claim for adjustment not submitted within sixty (60) days from the date of such
termination shall be deemed to have been waived by dealer/distributor.
Governing Law: These terms and conditions and each accepted order shall be governed by the law of the State of Texas without regard to Texas principles or rules of conflicts of laws that might require the applicant of the law of another jurisdiction.
Design and specifications are subject to change without notice
Veilux U.S.A
3015 Eagle Dr. 100
Grand Prairie, TX 75052
Veilux Middle East Branch Jordan
Telaa Al Aley, Hay Al Salaheen
Amman, Jordan
Office: 1 (800) 510-6528
Fax: (214) 988 - 2858
Office: (00962) 6556 - 1768
Tel: (962) 795 - 4430 - 46
www.veilux.net
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
