HP Rack & Power
Solutions
Notebook
Edition 6
Businesses across the world rely on
HP Qualified Options to complete
their data centres. Boost the power,
performance and reliability of
your data centre with Rack &
Power solutions.
HP Rack & Power Solutions
Notebook
Edition 6
Table of contents:
HP Qualified Options.............................................. 4
HP Rack & Power Solutions....................................... 5
Racks..................................................................... 6
Rack options........................................................... 7
Cooling................................................................. 8
Management – KVM solutions.................................. 9
KVM Interface Adapter........................................... 11
Rack Consoles.......................................................12
UPS solutions – Single-phase – Tower.......................13
UPS solutions – Single-phase – Rack.........................14
3-phase UPS solutions.............................................15
PDU solutions.........................................................17
HP Intelligent PDU (iPDU).........................................18
HP Monitored PDU.................................................19
HP Modular PDU...................................................20
Power cords..........................................................21
Power supplies.......................................................22
HP Factory Express Services....................................23
Name:
Company:
Address 1:
Address 2:
Phone/Fax:
E-mail:
3
HP Qualified Options
Completing your data centre and removing data centre boundaries
HP Qualified Options strengthen the foundation of your data centre with high-calibre
products that are easy to maintain and tailored for ProLiant, Integrity and StorageWorks,
giving you confidence in your whole infrastructure.
HP Qualified Options have passed our rigorous qualification processes. Experience
dependable quality you can count on, and when you need it, use outstanding HP support
services for your whole environment. When you purchase HP hardware, don’t compromise
on the quality of your options. With HP Qualified Options, you can be confident of your
whole infrastructure.
Dependable quality
Deliver greater business performance with fewer interruptions when you complete your infrastructure
with HP options.
Simplified support
Free up your valuable time when you have HP’s high-calibre technical expertise, keeping your whole
business in business.
Tailored for ProLiant/Integrity/StorageWorks
Focus on growing your business and not maintaining IT when you optimise your infrastructure with HP
options designed for servers and storage.
Energy maximisation
Get more out of IT as you stretch the limits of your data centre’s power and cooling capabilities.
Data centre adaptability
Effortlessly manage changing energy demands as you grow IT to accelerate business performance.
Environmental transformation
Gain IT flexibility and overcome tomorrow’s data centre limitations today with innovative solutions built
for your business’s success.
www.hp.com/go/qualifiedoptions
HP Rack & Power Solutions are part of the HP Qualified Options portfolio –
read more on the next page.
4
HP Rack & Power Solutions
Completing your data centre and removing data centre boundaries
HP Rack & Power Solutions are the foundation for your IT.
HP takes a holistic approach to power and cooling issues, from end to end (from chip
to chiller). HP Rack & Power Solutions are part of HP’s end-to-end solution, and are important
if you want to increase energy-efficiency of your IT infrastructure.
HP has designed these solutions to ensure current and future integration with HP ProLiant,
BladeSystem and Integrity servers, HP StorageWorks and HP Systems Insight Manager.
HP offers a one-stop shop for your ongoing physical infrastructure needs – from solutions to services.
HP Qualified Options and HP Rack & Power Solutions simplify product and vendor qualifications,
procurement and customer support, and guarantee product compatibility as well.
This all secures long-term scalability, energy efficiency and investment protection.
Over 20 million servers sold worldwide – so turn to the one stop you’ve trusted so far.
HP Rack & Power Solutions are built on:
•Rack and rack options – to provide the base for a flexible, adaptive IT infrastructure
•Power solutions – to protect, distribute and monitor power
•Access and monitoring solutions – to harmonise the management of heterogeneous
servers, storage and IT infrastructure
•Cooling solutions – to handle increased heat and increase cooling efficiency at rack and
data centre level
Synergy and integration is the difference
HP servers
HP storage
Rack & Power infrastructure (Rack, UPS,
PDU, KVM etc.) seamlessly integrated and
qualified with HP servers and HP storage
HP software
Infrastructure
management
(Power & Cooling)
integration with HP
SIM
HP services
Integrated Care
Pack – HP Server &
Storage Care Pack
supports Rack &
Power products at no
additional cost
HP Factory Express Services enable pre-integration and customisation of your complete solution:
Server + Storage + Software + Rack & Power
HP Rack & Power Solutions
The base for a flexible and adaptive IT infrastructure
5
Racks
HP racks
•Industry standard – outstanding quality and load capacity to protect your IT investment
•Universal – qualified with HP server and storage, EIA compliant to secure compatibility with
HP server, storage and power solutions as well as third party equipment
•Cool – fully perforated doors and excellent cable management to maximise airflow
•Flexible, with wide range of racks and rack options – to meet your
individual needs
•Easy installation – to deploy your IT easier and faster, and reduce costs
•Fast IT deployment – possible to ship racks preconfigured (ready to deploy) with
shipping option “shock pallet” and HP Factory Express Rack Integration Service
•Integrated Care Pack Support – HP Server & Storage Care Pack support at
no additional cost
HP Universal Rack – HP Rack 10000 G2 Series
Model
Height
Dimensions (HxWxD)
Dynamic
load
Static load
Part
number
Shipped with
Shipping option
10622 G2
22U
1092 x 609.6 x 1008 mm
(43 x 24 x 39.691 in)
474 kg
(1045 lbs)
908 kg
(2000 lbs)
AF021A
perforated front & rear door;
side panel, stabiliser kit
Standard pallet
10636 G2
36U
1742.4 x 609.6 x 1008 mm
(68.6 x 24 x 39.691 in)
690 kg
(1520 lbs)
908 kg
(2000 lbs)
AF011A
1742.4 x 609.6 x 1008 mm
(68.6 x 24 x 39.691 in)
690 kg
(1520 lbs)
908 kg
(2000 lbs)
AF014A
perforated front & rear door;
rear extension (155 mm)
1999.8 x 609.6 x 1008 mm
(78.7 x 24 x 39.69 in)
908 kg
(2000 lbs)
1360 kg
(3000 lbs)
AF001A
perforated front & rear door
908 kg
(2000 lbs)
1360 kg
(3000 lbs)
AF030A
front & rear door, pre
configured modified 42U
rack2
Shock pallet1
1133 kg
(2500 lbs)
1360 kg
(3000 lbs)
AF091A
perforated front & rear door
Standard pallet
1133 kg
(2500 lbs)
1360 kg
(3000 lbs)
AF092A
AF022A
10642 G2
10647 G2
10642 G2
10842 G2
10636 G2
42U
Shock pallet1
perforated front & rear door
AF012A
Standard pallet
Shock pallet1
AF002A
Shock pallet1
Standard pallet
Shock pallet1
10642 G2
1200 mm
deep
42U
10842 G2
42U
wide
1999.8 x 800.1 x 1008 mm
(78.7 x 31.5 x 39.69 in)
908 kg
(2000 lbs)
908 kg
(2000 lbs)
AF041A
AF042A
Shock pallet1
10647 G2
47U
2285 x 609.6 x 1008 mm
(89.96 x 24 x 39.69 in)
908 kg
(2000 lbs)
1360 kg
(3000 lbs)
AF031A
Standard pallet
10647 G2
1200 mm
deep
47U
2285 x 609.6 x 1200 mm
(89.96 x 24 x 47.2 in)
1133 kg
(2500 lbs)
1360 kg
(3000 lbs)
AF097A
1133 kg
(2500 lbs)
1360 kg
(3000 lbs)
AF094A
1999.8 x 609.6 x 1200 mm
(78.7 x 24 x 47.2 in)
Shock pallet1
perforated front & rear door
perforated front & rear door
Standard pallet
Standard pallet
Shock pallet1
1
It is mandatory to use a shock pallet when shipping racks with equipment installed.
2
Modified and pre configured 10642 G2 rack for air duct solution (AF028A) which will be mounted at customer. Shipped including: special bottom
and top panel, solid rear doors, air dams, side panels and rack rear extension.
HP Rack 10000 Series G1
10622 G2
S10614
Model
Height
Dimensions (HxWxD)
Dynamic
load
Static load
Part
number
Shipped with
Shipping option
S10614
14U
724 x 600 x 1000 mm
(23.62 x 23.62 x 39.37 in)
227 kg
(500 lbs)
270 kg
(600 lbs)
292302B22
perforated front & rear
door; side panel
Shock pallet*
*
It is mandatory to use a shock pallet when shipping racks with equipment installed.
HP Rack 100 Series
Model
Height
Dimensions (HxWxD)
Dynamic
load
Static load
Part
number
Shipped with
Shipping option
v142
42U
2000 x 600 x 1070 mm
See note*
907 kg
(2000 lbs)
AF046A
perforated front and
rear door
Standard pallet
*
This rack is not certified to be shipped and moved within a data centre with equipment installed. This rack is not delivered on castors.
v142
6
For more information, visit www.hp.com/products/racks
and www.hp.com/products/rackoptions
Rack options
HP rack options
•Industry standard – to secure compatibility and your investment protection
•Thermal and cable management options – to ensure correct airflow and cooling: filler/blanking panel, side panel kits,
cable management kit, airflow optimisation kit and rack rear extension kit
•Stabiliser and ballast kits – increase rack stability and safety
•Grounding kits – optimise electrical grounding (mandatory)
•Shelving, mounting and rail kits – for maximum density and easy access
•Rack options which complete the solution – HP rack light kit, 2U universal locking drawer, etc.
•Integrated Care Pack Support – HP Server & Storage Care Pack support at no additional cost
HP Rack Options
Part number
HP Rack Option – description
Compatible with HP rack series
10000 G1
10000 G2
MCS
other 19-inch racks
Cable and thermal management
168233-B21
Cable-management D-rings Kit, 10 pack
•
•
•
• (incl. HP v142, 5642)
379820-B21
HP Rack Cable velcro (hoop and loop) strips/clips, 50 pack
•
•
•
• (incl. HP v142, 5642)
383982-B21
Rack Top Cable Tray 600 mm, 8 pack, for 600 mm wide 10000 series racks
•
•
•
HP v142
383983-B21
Rack Top Cable Tray 800 mm, for 10842 rack
383984-B21
Rack-to-Rack Adjustable Aisle Transfer, cable bridge, for 10000 series racks
•
•
AF099A
Rack Cable Management Kit – one 1U and one 2U cable management bracket,
10 D-rings, 1 cross-over bracket, 20 Rack cable velcro staps/clips
•
•
•
• (incl. HP v142, 5642)
AF060A
36U Rack Rear Extension Kit (155 mm) – for HP rack 10636
AF036A
42U (600 mm wide) Rack Rear Extension Kit (200 mm) – for HP rack 10642 G2 and
HP MCS G1 & G2
AF043A
47U (600 mm wide) Rack Rear Extension Kit (200 mm) – for HP rack 10647 G2
257414-B21
Fan Kit 220V, 6 fans, mounted on top of the rack
10842
HP v142
36 U
36 U
•
42U/10642
•
•
•
47U/10647
All, beside 14U (not)
•
AF070A
HP 10 pk, carbonite black, 1U Universal Filler Panel
•
•
• (incl. HP v142, 5642)
AF071A
HP 100 pk, carbonite black, 1U Universal Filler Panel
•
•
•
• (incl. HP v142, 5642)
AF090A
HP 10K G2 Series Rack Airflow Optimisation Kit
•
•
AF028A
HP 10642 G2 Top Exhaust Extension Kit
•
•
AF029A
HP 10642 G2 Top Exhaust Field Retrofit Kit
•
•
AF030A
HP Modified 10642G2 Rack
Shelving, mounting, side panel & grounding kits
234672-B21
100 kg Sliding Shelf – Graphite, has to be combined with the suitable Rack
Stabiliser Kit
•
•
•
• (incl. HP v142, 5642)
253449-B21
Monitor/Utility Shelf – Graphite 1U fixed shelf that can be mounted at any height
within 19"/HP Racks to place a monitor or another component.
Width: 19"/482.6 mm, depth: 739.9 mm, load capacity: 68kg
•
•
•
• (incl. HP v142, 5642)
361591-B21
HP 2U Universal Locking Drawer – Graphite
•
•
•
• (incl. HP v142, 5642)
332558-B21
Depth Adjustable Fixed Rail Kit; max. 136 kg
•
•
248929-B21
10000 Rack Series Baying Kit
•
•
248931-B21
42U 9000 to 10000 Rack Series Offset Baying Kit
•
•
AF048A
HP v142 Rack Baying Kit
AF056A
10636 G2 (36U) Side Panels (set of two) (Graphite Metallic)
36 U
AF054A
10642 G2 (42U) Side Panels (set of two) (Graphite Metallic)
42 U
AF050A
Side Panel (47U) 10000 G2 series
47 U
AF093A
10642 G2 (42U) 1200 deep Side Panels (set of two) (Graphite Metallic)
42U
1200 mm deep
AF095A
10647 G2 (47U) 1200 deep Side Panels (set of two) (Graphite Metallic)
47U
1200 mm deep
AF047A
Side Panel (42U) kit for HP v142 rack
AF019A
HP 10636 G2 Front Door ALL
36 U
36 U
AF009A
HP 10642 G2 Front Door ALL
42U/10642
42U/10642
AF074A
HP 10000 G2 Rack Grounding Kit
•
•
AF040A
HP v142 Rack Grounding Kit
• (incl. HP v142, 5642)
HP v142
v142 rack
•
v142 rack
Stabilisation & Lighting
120672-B21
Ballast Kit
AF062A
HP 10K G2 Stabiliser* Kit 600 mm, for 600 mm wide HP 10K G2 racks
AF065A
HP 10K G2 Stabiliser* Kit 600 mm Heavy Duty V2, for 600 mm wide HP 10K G2 racks
AF066A
Stabiliser* Kit 800 mm 10K G2 ALL
AF076A
HP Rack Tie Down Kit for 1000 mm deep 10K G2 racks
•
AF075A
HP Rack Tie Down Kit for 1200 mm deep 10K G2 racks
•
AF049A
HP v142 Rack Stabiliser* Kit
361589-B21
Rack Light Kit
*
•
•
• (incl. HP v142, 5642)
•
•
10842
v142 rack
•
•
An anti-tip stabiliser provides stability and support when equipment is installed, removed or accessed within the rack. Heavy-duty stabilr kits should
be used when a single racked component exceeds 90 kg
•
v142 rack
7
Cooling
HP Modular Cooling System (MCS) G2
•Highly efficient closed coupled cooling system – for high-density deployments
•Cooling capacity: up to 35 kW
•in single-rack configuration/35 kW
•in two-rack configuration (two HP MCS G2 42U racks at a time)/up to 17.5 kW per rack
•Safe general design – separation of cooling unit and IT rack – to prevent water contact with servers
•Server/blade/storage deployments and access – unaffected by design
•Automatic door release – for additional safety
•Integrated remote management – integration with HP SIM
•Fast IT deployment – possible to ship HP MCS and expansion rack preconfigured (ready to deploy) –
shock pallet included
+
HP MCS G2
HP MCS G2
Expansion rack
=
HP MCS G2
HP MCS G2 with
Expansion rack
HP Modular Cooling System (MCS) G2
Model
Product description
HP Modular Cooling
System (MCS) G2
HP Modular Cooling System (MCS) G2, includes 10642 G2 rack, support for a 2nd rack (MCS
AF025A
G2 Expansion Rack), up to 35 kW cooling capacity (one rack config) or two times up to 17,5 kW
(two rack config), 2750 CFM (~1800 m3/h) of chilled air, dimensions (H x W x D): 1999.8 x 909
x 1270 mm, delivered on shock pallet (CTO capable/ready for factory integration);
Shipping info (shipped with): cooling rack + HP 10642 rack (42U) + sealed front and rear doors,
rack front extension, side panel, automatic door opening release; shipped on shock pallet;
Part number
HP Modular Cooling
System (MCS) G2 10642
Expansion Rack
Expansion rack for HP Modular Cooling System (MCS) G2; includes special 42U HP 10642 G2
rack (sealed: front door, rear door, rack bottom plate), dimensions (H x W x D): 1999.8 x 609.6
x 1270 mm, delivered on shock pallet (CTO capable/ready for factory integration);
Shipping info (shipped with): IT rack (42U, 10642) + sealed front and rear door, sealed bottom,
rack front extension, side panel; shipped on shock pallet
AF026A
MCS G2 Flex Hose and
Coupling Kit
The kit contains set of 1.0 inch diameter, Couplings and Parallel-to-Tapered adapter included to
address regional differences.
The Modular Cooling System Water Hook-up kit can be ordered ahead of the MCS G2 for site
preparation purposes.
AF089A
HP Care Packs for HP Modular Cooling System (MCS)
8
Model
Product description
Part number
Next Busines Day On-Site Service, 5-Day x 9-Hour
Coverage, 3 Years, Electronic
HP Care Pack for HP Modular Cooling System (MCS); standard
warranty: 1 year
UE001E
4-Hour On-Site Service, 5-Day x 13-Hour Coverage,
3 Years, Electronic
UE002E
4-Hour On-Site Service, 7-Day x 24-Hour Coverage,
3 Years, Electronic
UE003E
6-Hour On-Site Service, 7-Day x 24-Hour Coverage,
3 Years, Electronic
UE004E
Hardware Installation for HP Modular Cooling
System (MCS)
HP Care Pack for installation of servers and storage into the MCS
(fixed price)
UE005E
Hardware Installation for HP Modular Cooling
System (MCS) 10642 Expansion Rack
HP Care Pack for installation of servers and storage into the MCS
expansion rack (fixed price)
U2871E
Model
Product description
Part number
Site Data Center Thermal Quick Assessment Service
Entry level Data Center Cooling assesment
HB691AE
For more information, visit www.hp.com/go/powerandcooling and
www.hp.com/go/mcs
Management – KVM solutions
Server management with HP KVMs
HP KVM Switches
•Improved management and efficiency – to allow
centralised management, convenient access and
reduced costs
Four different model families by need
•Multi-platform management from one console – to
fit perfectly into heterogeneous environments
KVM for desktop and small server room
•Entry level 4 port Desktop KVM switch with
conventional KVM cabling (AF611A)
•Redundant access path for HP iLO
and seamless integration with HP iLO –
to provide secure and redundant access
KVM for Server Management
•Lower costs – through integrated Care Pack
Support for HP KVM Switches with a ProLiant
Server Care Pack
•Analogue KVM switch with local consoles and
Virtual Media (AF618A/AF619A)
•Integrated Care Pack Support – HP Server &
Storage Server Care Pack support at no additional
cost
•Analogue KVM switch with local consoles
(AF616A/AF617A)
•Digital KVM switch with local and remote access
(KVM over IP) and Virtual Media (AF62xA)
See more details below and on next page.
Model comparison: HP KVM with CAT5 cabling
Features
HP KVM Server Console Switch
(AF616A, AF617A)
HP KVM Server Console Switch
with Virtual Media (AF618A,
AF619A)
HP KVM IP Console
Switch with Virtual Media
(AF620A, AF621A, AF622A)
Number of server ports/devices
(with one unit)
8 or 16
16 or 32
8 or 16 or 32
Max. supported servers/devices
256 (cascaded)
up to 1024 (cascaded)
up to 1024 (cascaded)
LAN/WAN access
No
No
Yes (1 or 2 or 4 users)
Number of simultaneous users
(local + remote via network)
2 (local)
2 (local)
2 (1l+1r) or 3 (1l+2r) or 5 (1l+4r)
Video resolution
up to 1280 x 1024
up to 1280 x 1024
up to 1280 x 1024
Improved cable management
Yes (CAT5e, up to 30 m)
Yes (CAT5e, up to 30 m)
Yes (CAT5e, up to 30 m)
SNMP – manageable through HP
Systems Insight Manager (SIM)
No
No
Yes (1 IP address)
Multiple language support*
Yes
Yes
Yes
Multi-brand and multi-OS support
Yes
Yes
Yes
Supports different connections
(PS/2, USB, Serial) for KVM
Yes – with PS/2, USB, Serial and BladeSystem Interface Adapters
Supports Virtual Media (local)
No
Yes**
Yes**
Supports Virtual Media (remote)
No
No
Yes**
Built-in tiering (cascading) port
Yes
Yes
No
Seamless integration with iLO
Yes
Yes
Yes
*
Supports English, French, Italian, German, Spanish, Dutch and Japanese.
**
Yes – with PS/2 Interface Adapter with VM (via USB) support; USB Interface Adapter with VM support.
Virtual Media
HP KVM Switches with Virtual Media support feature local virtual media for connecting USB media
devices. With virtual media, you can transfer data that is stored on CDs, USB drives, USB external hard
drives or any other media source between targets. This will make it possible to do software installations or
updates from a remote location.
(An Interface adapter with virtual media support is required for this functionality)
For more rack options, visit www.hp.com/go/kvm
9
Management – KVM solutions
KVM for Server Management
Analogue KVM (local access)
Model
Description
Part number
HP 0x2x8 KVM SVR CNSL
G2 SW
2 local user/8 ports; CAT5 cabling
AF616A
HP 0x2x16 KVM SVR CNSL
G2 SW
2 local user/16 ports; CAT5 cabling
AF617A
Analogue HP KVM server console switches G2 (CAT5 based)
Analogue HP KVM server console switches G2 (CAT5 based) – with USB Virtual Media* support
HP 0x2x16 KVM Server
Console Switch G2 with
Virtual Media CAC Software
HP KVM Server Console Switch G2 with Virtual Media,
CAC, 2 local users, 16 ports, local USB Virtual Media*
support, CAT5 cabling
AF618A
HP 0x2x32 KVM Server
Console Switch G2 with
Virtual Media CAC Software
HP KVM Server Console Switch G2 with Virtual Media,
CAC, 2 local users, 32 ports, local USB Virtual Media*
support, CAT5 cabling
AF619A
Description
Part number
Digital KVM (remote and local access)
Model
Digital (over IP) HP KVM server console switches G2 (CAT5 based) – with USB Virtual Media* support
*
HP 1x1Ex8 KVM IP Console
Switch G2 with Virtual Media
CAC Software
HP KVM IP Console Switch G2, with Virtual Media*,
CAC, 1 remote user, 1 local user, 8 ports, local USB
Virtual Media* and remote Virtual Media* support,
integrated Active Directroy support (LDAP), CAT5 cabling
AF620A
HP 2x1Ex16 KVM IP Console
Switch G2 with Virtual Media
CAC Software
HP KVM IP Console Switch G2, with Virtual Media*,
CAC, 2 remote users, 1 local user, 16 ports, local USB
Virtual Media* and remote Virtual Media* support,
integrated Active Directroy support (LDAP), CAT5 cabling
AF621A
HP 4x1Ex32 KVM IP Console
Switch G2 with Virtual Media
CAC Software
HP KVM IP Console Switch G2, with Virtual Media*,
CAC, 4 remote users, 1 local user, 16 ports, local USB
Virtual Media* and remote Virtual Media* support,
integrated Active Directroy support (LDAP), CAT5 cabling
AF622A
Virtual media support requires the use of Virtual Media Interface Adapters.
HP KVM Console Switches with
Virtual Media are supporting
up to two level tiering (cascading)
and remote access (IP models)
Tiering/cascading with new
HP console switches
10
For more information, visit www.hp.com/go/kvm
KVM Interface Adapter
HP KVM Interface Adapter and Cables
Model
Description
Part number
Universal components for CAT5 based HP KVM switches G2 with Virtual Media* and CAC support
HP KVM Console USB Virtual
Media CAC Interface Adapter
USB KVM IF adapter with Virtual Media support via USB
and CAC support
AF623A
HP KVM Console PS2/USB
Virtual Media CAC Interface
Adapter
USB KVM IF adapter with Virtual Media support via USB
and CAC support**
AF624A
HP KVM Console Serial/
Power G2 Interface Adapter
Serial (Terminal)-RJ45/CAT5 G2, 1 pack, incl. Pwr
supply
AF625A
Universal components for CAT5 based HP KVM switches with Virtual Media* support
PS/2 Virtual Media Interface
Adapter, 1 pack
PS/2 KVM IF adapter with Virtual Media support via
USB**
AF604A
USB Virtual Media Interface
Adapter, 1 pack
USB KVM IF adapter with Virtual Media support via USB
AF603A
Universal components for CAT5 based HP KVM switches (no Virtual Media support; supports KVM only)
HP KVM Interface Adapter
PS/2-CAT5 Qty 8 WW
PS/2-RJ45/CAT5; 8 pack, Note: no Virtual Media
support
262587-B21
HP KVM Interface Adapter
PS/2-CAT5 Qty 1 WW
PS/2-RJ45/CAT5; 1 pack, Note: no Virtual Media
support
262588-B21
HP KVM Interface Adapter
USB-CAT5 Qty 1 WW
USB-RJ45/CAT5; 1 pack, Note: no Virtual Media
support
336047-B21
HP KVM Interface Adapter
Serial-CAT5 Qty 1 WW
Serial (Terminal)-RJ45/CAT5, 1 pack, incl. Pwr supply,
Note: VT100 terminal emulation
373035-B21
HP BladeSystem CAT5 KVM
Interface Adapter Qty 1 WW
HP BladeSystem p-Class, SUVI/CAT5 + 1USB, 1 pack,
Note: supports HP BladeSystems p-Class products only,
Note: no Virtual Media support
AF100A
HP BLc KVM Interface Adapter HP BladeSystem c-class, SUVI/CAT5 + 1USB, 1 pack,
Note: supports HP BladeSystems c-Class products only
AF605A
CAT5 UTP Cables for HP KVM Switches (CAT5 based) with & without VM and for HP Serial Console Server
CAT5e Cable 3ft, 4 pack
CAT5e Cable 0.9 metre, 4 pack
263474-B21
CAT5e Cable 6ft, 8 pack
CAT5e Cable 1.8 metre, 8 pack
263474-B22
CAT5e Cable 12ft, 8 pack
CAT5e Cable 3.7 metre, 8 pack
263474-B23
CAT5e Cable 20ft, 4 pack
CAT5e Cable 6.1 metre, 4 pack
263474-B24
CAT5e Cable 40ft, 1 pack
CAT5e Cable 12.2 metre, 1 pack
263474-B25
*
Virtual media support requires the use of Virtual Media Interface Adapters
**
Note: Requires PS/2 mouse and keyboard connections and one USB port on server.
Workstation KVM switches
The HP Workstation KVM Switches provide the
flexibility and performance for small environment
to connect up to four computers and share USB
peripherals like DVD-ROM burners, printers, and
scanners. You can connect multiple workstations to
a single keyboard, mouse, and monitor. Support
for both USB and PS/2 devices. Flexible mounting
allows the switch to work in table top or rack
mount applications.
Model
The HP Workstation KVM switch can
be used for:
•Managing up to 4 desktop or rack mount
computers
•Sharing USB devices between up to 4 computers
•Front-end switch to other KVM switches (connect
local user ports to the switch)
•Desktop migration projects
Description
Part number
HP KVM switches with conventional KVM cabling
HP PS2 Server Console Cable, KVM Cable for HP 1x4 USB/PS2 KVM Switch, 6 foot,
2 metre, 2-Pack
2-Pack
AF612A
HP USB Server Console
Cable, 2 metre, 2-Pack
KVM Cable for HP 1x4 USB KVM Switch, 6 foot, 2-Pack
AF613A
HP 1x4 Server Console Switch
1 user/4 ports; USB and PS2; 3 USB ports for additional AF611A
devices; conventional KVM cabling; included: rack
mount (rails), 2 x HP PS2 Server Console Cable (2 metre)
11
Rack Consoles
Rack Console – TFT Monitors and keyboards
Model
Description
Part number
HP 1U Rackmount Keyboard
with USB, with touch pad and
USB pass through
1U rack keyboard with touch pad and front USB
• full size keyboard with Windows shortcut keys, different country specific keyboard layouts available
• integrated touch pad
• USB pass through (also on front available)
• Tool-less universal rail kit included
AG0xxA*
HP TFT7600 G2 Rackmount
Keyboard and Monitor
(17" TFT), with touch pad,
USB pass through, 1U
1U all-in-one rack console (monitor, keyboard, touch
pad), new design
• 17,3" TFT display (WXGA+)
• full size keyboard with Windows shortcut keys,
different country specific keyboard layouts available
• integrated touch pad
• USB pass through (also on front available)
• Tool-less universal rail kit included
AZ8xxA*
Compatible with HP Racks and 19" racks
Part number
HP Rack Option – description
10000 G1
10000 G2
MCS
other 19"
racks
•
•
•
•
Rack TFT Monitors and Keyboards
AZ8xxA*
*
12
HP TFT7600 Rackmount Keyboard and Monitor, new design
• 1U all-in-one rack console (monitor, keyboard, touch pad)
• 17,3" TFT display (WXGA+)
• full s keyboard with Windows short cut keys, different country
specific keyboard layouts available
• integrated touch pad
• USB pass through (also on front available)
AZ871A
HP TFT7600 KVM Console UK Kit
•
•
•
•
AZ872A
HP TFT7600 KVM Console GR Kit
•
•
•
•
•
AZ873A
HP TFT7600 KVM Console FR Kit
•
•
•
AZ874A
HP TFT7600 KVM Console Itl Kit
•
•
•
•
AZ875A
HP TFT7600 KVM Console SP Kit
•
•
•
•
AZ876A
HP TFT7600 KVM Console Den Kit
•
•
•
•
AZ877A
HP TFT7600 KVM Console Nw Kit
•
•
•
•
AZ878A
HP TFT7600 KVM Console SE-FI Kit
•
•
•
•
AZ879A
HP TFT7600 KVM Console Swi Kit
•
•
•
•
AZ880A
HP TFT7600 KVM Console Port Kit
•
•
•
•
AZ881A
HP TFT7600 KVM Console Bel Kit
•
•
•
•
AZ883A
HP TFT7600 KVM Console Rus Kit
•
•
•
•
AZ884A
HP TFT7600 KVM Console Intl Kit
•
•
•
•
AG0xxA*
HP 1U Rackmount Keyboard with touch pad and USB
•
•
•
•
AG072A
1U Rackmount Keyboard with USB US
•
•
•
•
AG073A
1U Rackmount Keyboard with USB UK
•
•
•
•
AG074A
1U Rackmount Keyboard with USB GR
•
•
•
•
AG075A
1U Rackmount Keyboard with USB FR
•
•
•
•
AG076A
1U Rackmount Keyboard with USB IT
•
•
•
•
AG077A
1U Rackmount Keyboard with USB SP
•
•
•
•
AG078A
1U Rackmount Keyboard with USB DEN
•
•
•
•
AG079A
1U Rackmount Keyboard with USB NOR
•
•
•
•
AG080A
1U Rackmount Keyboard with USB SE/FI
•
•
•
•
AG081A
1U Rackmount Keyboard with USB SWI
•
•
•
•
AG082A
1U Rackmount Keyboard with USB PORT
•
•
•
•
AG083A
1U Rackmount Keyboard with USB BEL
•
•
•
•
AG084A
1U Rackmount Keyboard with USB JPN2
•
•
•
•
AG085A
1U Rackmount Keyboard with USB RUS
•
•
•
•
AG086A
1U Rackmount Keyboard with USB Intl
•
•
•
•
Refers to country-specific keyboard.
For more information, visit www.hp.com/go/kvm
For more information, visit www.hp.com/products/rackoptions
UPS solutions – Single-phase – Tower
HP Tower UPS
•UPS capacity – from 500 W to 3000 W (real power)
•Enhanced Battery Management (EBM) – significantly extend battery service life
•60-day battery – pre-failure warning and 3-year backup warranty
•Extended Runtime Modules (ERMs) – increase UPS backup time by need (optional)
•Hot-swap battery modules – provide highest availability
•Integrated Care Pack Support – HP Server & Storage Care Pack support of HP UPSs up to 12 kVA
at no additional cost
HP Tower UPS
Model
T750 G2 Intl
T1000 G3, Intl
T1500 G3, Intl
R/T3000 G2, Intl
Part number
AF447A
AF449A
AF451A
AF468A
Replacement for/old model
T750 Intl/
378439-B31
T1000 G2, Intl/
AF405A
T1500 G2, Intl/
AF408A
R3000 Intl/AF414A
R/T2200 G2 Intl/AF411A
Form factor
Tower
Tower
Tower
Tower/Rack/2U
Tower to Rack conversion kit
included
Power output
750 VA
500 W
1000 VA
670 W
1500 VA
950 W
3300 VA
3000 W
Backup time at 80% load1
6 mins
6 mins
6 mins
7 mins2
Load segments
1
1
1
2
Output connections (Intl model)
4 x IEC 320 C13
6 x IEC 320 C13 (10A)
Input Power Cord
Input connection: IEC 320 C13
Input power cord is not included; optional (country specific) power cord
see “power cords”
Country specific power cord
included
Hot-swap batteries
Yes
Yes
Yes
Yes
Weight (kg)
12.7
12.7
25
37
Optional ERM/
ERM part number
N/A
N/A
N/A
up to 2 ERM/AF455A
Communication
USB/serial; includes HP power-management software HP Power Protector
Communication option
N/A
Warranty
3-year HP warranty (3-1-1), HP battery pre-faillure warranty and integrated Care Pack Support with no
additional costs3
2x IEC 320 C19 (16A)
6x IEC 320 C13 (10A)
+ one extension bar (7 x C13)
HP UPS Network Module
(AF465A)
1
ackup times are estimated for typical applications at recommended load level of 80%. Actual performance will depend on environment conditions,
B
ambient temperature, battery age and other factors.
2
Increased system uptime possible with optional Extended Runtime Modules (ERMs).
3
HP Server and Storage Care Pack also supports HP UPSs up to 12 kVA at no additional cost.
For more information, visit www.hp.com/products/ups
13
UPS Solutions – Single-phase – Rack
HP Rack UPS – Single-phase
•UPS capacity – from 1000 W to 6500 W (real power)
•Patented Enhanced Battery Management (EBM) – doubles battery life time up to 6 years
•60-day battery – pre-failure warning and 3-year backup warranty
•Extended Runtime Modules (ERMs) – increase UPS backup time by need (optional)
•Hot-swap battery modules – provide highest availability
•Integrated Care Pack Support – HP Server & Storage Care Pack support of
HP UPSs up to 12 kVA at no additional cost
Model
R1500 G3, Intl
R/T3000 G2, Intl
R5000 Intl
R7000 Intl
Part number
AF471A
AF468A
AF461A
AF463A
Form factor
Rack/1U
Tower/Rack/2U; Tower
to Rack conversion kit
included;
Rack/3U
Rack/4U
Power output (Watt)
1000 W
3000 W
4500 W
6500 W
Backup time at 80% load1
8 mins
7 mins
7 mins
7 mins
Load segments
2
2
2
2
Output connections
(Intl model)
4x IEC 320 C13
2x IEC 320 C19 (16A)
6x IEC 320 C13 (10A)
+ one extension bar
(7 x C13)
4x IEC320 C19 (16A);
4x IEC320 C13 (10A);
1x IEC309 (32A)
6x IEC320 C19 (16A);
2x IEC309 (32A);
via included PDU sticks:
14x IEC320 C13 (10A);
see footer3
Input Power Cord
not included; optional
(country specific) power
cord see “power cords”
country specific power
cord included3
detached power cord
with IEC320 309 (32A,
one phase)
detached power cord
with IEC320 309 (32A,
one phase)
Hot-swap batteries
Yes
Yes
Yes
Yes
Unit weight (kg)
22.9
37
57
68
Optional ERM/ERM part
number
N/A
up to 2 ERM/AF455A
up to 4 ERM/AF464A
up to 4 ERM/AF464A
Communication
Serial (RS-232/DB9),
optional available:
UPS Network Module
(AF465A)
USB/serial; optional
available: UPS Network
Module (AF465A)
USB/serial/Ethernet;
Note: UPS Network Module (AF465A) is included
Communication Software
Includes Power Management software HP Power Protector
Warranty
3-year HP warranty (3-1-1), HP battery pre-faillure warranty and integrated Care Pack Support with no
additional costs2
1
Backup times are estimated for typical applications at recommended load level of 80%. Actual performance will depend on environment conditions,
ambient temperature, battery age and other factors. Increased system uptime possible with optional Extended Runtime Modules (ERMs).
2
ProLiant server care pack supports connected HP UPS also – with no additional costs.
3
P R7000 UPS delivery includes: 2 Extension Bars (7 x C13 outlets each), these could be connected to the C19s on the UPS unit and provide up
H
to 14 IEC320 C13 outputs. In addition: Two 10 Amp IEC to IEC jumper cords
UPS Options
For which HP UPS
Part number
UPS ERM Module UPS Expansion Runtime Module (extended battery) – extends
backup time
Model
Description
availability depends on UPS
model, see UPS table above
availability depends
on UPS model, see
UPS product tables
HP UPS
Management
Module
UPS management card with one ethernet port and five
serial ports (RJ45); embedded management software with
communication and management functions:
• allows direct communication to ethernet and up to
five servers via serial connection
• remote access
HP UPS R1500 G2, R3000,
AF401A
R/T3000, R5500 and former
“HP UPS XR models”;
The HP UPS management module
is included with R8000/3,
R12000/3 and RP36000/3;
further info see quick specks
HP UPS Network
Module
The HP UPS Management Module enables you to monitor and
manage power environments through comprehensive control
of HP UPSs. The HP UPS Management Module can support
either a single UPS configuration or provides additional power
protection with support for dual redundant UPS configuration for
no-single-point-of-failure. The additional serial ports will provide
greater power management control and flexible monitoring.
HP UPS R1500 G3, R/T3000
AF465A
G2, R5000 and R7000 models.
The HP UPS network module is
included with R7000 UPS; further
info see quick specks
If you need help sizing your HP Rack and Power infrastructure solution (Rack, Rack
options, UPS, PDU, KVM), please go to www.hprackandpowersizer.com
14
Or contact our experts at: [email protected] (for technical questions)
or [email protected] (for solution design)
3-phase UPS solutions
HP 3-phase UPS solutions – 3-phase UPS modules and Parallel UPS
(preconfigured UPS Rack)
•UPS modules with 8 kVA and 12 kVA capacity
•Parallel UPS with 36 kVA capacity – scalable up to 60 kVA in a single 19-inch rack
•High-density design, lightweight, hot-swappable battery and electronics modules
•Intelligent automated maintenance bypass in each UPS module/chassis
•Integrated Care Pack Support for the single Rack UPS modules (R8000/3 and R12000/3) –
HP Server & Storage Care Pack supports HP UPSs up to 12 kVA at no additional cost
HP 3-phase UPS Modules (Rackmount)
Model
R8000/3 Intl
R12000/3 Intl
Part number
AF432A
AF430A
Form factor
Rack module/6U
Rack module/6U
INput power
INput connections
(Intl model)
400 V 3-phase
1 x IEC 309 16A (3-phase power)
400 V 3-phase
1 x IEC 309 32A (3-phase power)
OUTput power rating/capacity
8 kVA/8 kW; 400 V 3-phase
12 kVA/12 kW; 400 V 3-phase
OUTput connections
(Intl model)
1 x IEC 309 16A (3-phase power)
2 x IEC 309 16A (3-phase power) = UPS output
module (AF434A)
Backup time at 80% load
12 mins
6 mins
Hot-swap electronic modules &
batteries
Yes
Yes
Weight (kg)
140
140
Optional ERM/
part number
max. 4/AF434A
max. 4/AF434A
Communication
HP UPS Management module (AF401A) included; module with one ethernet port and five serial ports (RJ45)
Communication software
Embedded HP Power Management software on HP UPS Management module (AF401A)
Warranty
3-Year HP warranty (3-1-1), HP battery pre-failure warranty and integrated Care Pack Support at no
additional cost
HP 3-phase Parallel UPS (preconfigured Rack & module)
Model
RP36000/3 Intl
RP12000/3 Intl
Description
Preconfigured parallel rack UPS
Rack 42U with three UPS modules and power bar
Additional 12 kVA UPS module for RP36000/3 (to
be added into the parallel rack UPS (RP36000/3))
Part number
AF439A
AF437A
Form factor
Rack 42U (HP 10000 Series G2, 10642)
Rack module/6U
INput power
INput connections
(Intl model)
400 V 3-phase
Hard wire terminal
400 V 3-phase
to power bus bar (on RP36000/3)
OUTput power rating/capacity
non-redundant: 36 kVA/36 kW
n+1 redundant: 24 kVA/24 kW – expandable up to
60 kVA (n+1)
12 kVA/12 kW; 400 V 3-phase
OUTput connections
(Intl model)
Hard wire terminal; Optional (add on): HP R12000/3
Intl UPS Output Module (AF441A)
Connector to power bus bar (on RP36000/3) or
optional: UPS output module (AF441A)
Backup time at 80% load
12 mins
6 mins
Hot-swap electronic modules &
batteries
Yes
Yes
Weight (kg)
578
140
Optional ERM/
part number
AF434A
max. 4/AF434A
Communication
HP UPS Management module (AF401A) included; module with one ethernet port and five serial ports (RJ45)
Communication software
Embedded HP Power Management software on HP UPS Management module (AF401A)
Warranty
3-Year HP warranty (3-1-1), HP battery pre-failure warranty
For more information, visit www.hp.com/products/rackoptions
15
3-phase UPS solutions (cont.)
Options – for HP 3-phase Rack and Parallel UPS
Model
Description
For which HP UPS
Part number
HP R12000/3 Intl UPS
Output Module
Rackmount UPS Output Module, with 2 x IEC309 16A
connectors (3-phase)
RP12000/3 (this module is included
with R12000/3)
AF441A
HP 3-phase UPS ERM
Module
UPS Expansion Runtime Module (extended battery)
3U extends backup time up to four (4) ERMs per UPS
R8000/3
R12000/3
RP36000/3
RP12000/3
AF434A
HP 3-phase 16A Intl Mod
PDU, Core unit
Core unit only, input: 3-phase, IEC309 16A 4Pin,
attached input cord, connects into 3-phase facility
input or to a 3-phase UPS; Output: 6 x IEC320 C19
(single phase)
R8000/3
R12000/3
AF513A
HP 11 kVA S1316
Monitored PDU (Intl)
Single input, 3-phase, 16A, Intl
Input: 1 x IEC309, 5Pin 16A
Output: 39/36 C13 (10A) plus 3 C19 (16A)
R8000/3
R12000/3
AF508A
HP 22 kVA S2316
Monitored PDU (Intl)
Dual input, 3-phase, 16A, Intl
Input: 2 x IEC309, 5Pin 16A
Output: 78/72 (2 x 36) C13 (10A) plus 6 (2 x 3) C19
R12000/3
RP12000/3 and 36000/3 – with
additional UPS output module (option)
AF507A
Power cords/jumper cables
Model
Description
Part number
HP 5’ IEC309 516P
Intl Jumper Cable
Power cord – jumper cable IEC309 16A, 5Pin 1.65 m
460153-005
HP 10’ IEC309 516P
Intl Jumper Cable
Power cord – jumper cable IEC309 16A, 5Pin 3.3 m
460153-010
HP 15’ IEC309 516P
Intl Jumper Cable
Power cord – jumper cable IEC309 16A, 5Pin 4.95 m
460153-015
If you need help sizing your HP Rack and Power infrastructure solution (Rack, Rack
options, UPS, PDU, KVM), please go to www.hprackandpowersizer.com
16
For more UPS options, information on HP power products and software downloads,
please visit www.hp.com/products/ups
PDU solutions
HP is offering three different PDU families to meet different
customer needs
HP Intelligent PDU (iPDU) – New introduced End of 2010
•Key component of HPs Intelligent Power Discovery (IPD) solution – eliminate costly downtime
caused by human errors in power wiring and PDU configurations
•Mountable in 1U or zero U locations to save valuable space in the rack and to offer
proper cable management
•Monitor and control power outlets individually
•Measure and display the power consumption for every component in the rack with 99% accuracy
•Enable to manage and monitor power distribution from anywhere to prevent problems and speed
response times
•Various models with different power inputs and capacities – see key features in comparison table
below and on following pages
HP Monitored PDU
See key features in comparison table below and on following pages
HP Modular PDU
See key features in comparison table below and on following pages
HP IPD Solution and PDU comparison
The PDU comparison (table below) helps to identify the best PDU solution and point out the
difference to other PDUs on the market which stop at the power outlet control level. Key
differentiators for HPs iPDU are all functions which are related to HPs Intelligent Power Discovery
(IPD) solution.
Intelligent Power Discovery is the name for a solution which combines HP’s highly efficient server
power supplies, HP’s intelligent power distribution units and HP’s power management software. The
HP IPD solution is designed to make it easy to add new servers to a data center and automatically
adjust power allotment and includes remote power outlet control and power redundancy check.
Using HP’s software you can manage power allocation and find overheating servers and define
policies to save energy and to increase availability. You can use HP’s remote server management
console iLO to manage practically all of your power requirements.
For more information, see next page and please visit www.hp.com/go/IPD
Model comparison: HP PDU
Feature
HP Intelligent PDU (iPDU)
HP Monitored PDU
HP Modular PDU
Rack Mount
1U or zero U locations
Vertical zero U in the back of
the rack
1U or zero U locations
Power Input
Single and Three phase
dependent on model
Single and Three phase
dependent on model; dual power
input models available
Single and Three phase dependent
on model
Multiple circuit brakers
Yes
Yes
Yes
Power Monitoring
(at the rack)
Yes, Monitoring display,
99% accuracy
Yes, Monitoring display
No
Power Monitoring (remote)
Yes (embedded SW and
integration within HP SIM/Insight
Control)
Yes, with optional Module
(embedded SW and integration
within HP SIM/Insight Control)
No
Remote power outlet control
(on/off switching)
Yes
No
No
Automatic power redundancy
check
Yes, as part of HP IPD solution
No
No
Automatic power capping
Yes, as part of HP IPD solution
No
No
Automatic power re-deployment
Yes, as part of HP IPD solution
No
No
For more information about HP PDUs, see next pages
17
HP Intelligent PDU (iPDU)
HP iPDU is a key component of HPs Intelligent Power Discovery (IPD) – which includes automatic power redundancy control
and integration with HP System Insight Manager and HP Insight Control. Key features:
•Modular architecture – based on PDU core unit with multiple circuit breaker, network connection and extension bars
•Density optimised 1U/0U rackmount design – including mounting brackets
•Local and remote power monitoring – local power monitoring display and remote power reporting
•Remote power outlet control – which could be set up automatically (based on events or/and thresholds)
•Integrated Care Pack support – HP Server & Storage Care Pack supports HP PDUs at no additional cost
Model
Description
Outlets (Output)
HP Intelligent
Mod PDU 32a
Intl Core
iPDU core unit, input: IEC 309 32A/IEC332P6, connects into facility input or HP UPS R5500; output: 6 x C19 (16A);
6 x IEC 320 C19 (16A)
includes the rack rear mount LED display unit. Note: iPDU core units could be combined with extension bars (AF528A,
AF529A) by need;
Part
number
AF525A
HP Intelignt Mod iPDU core unit, input: 3-phase, IEC 309 16A 4 pin/IEC516P6, attached input cord, connects into 3-phase facility
PDU 3ph 16a Intl input or to a 3-phase UPS;
Core
output: 6 x C19 (16A); includes the rack rear mount LED display unit.
Note: iPDU core units could be combined with extension bars (AF528A, AF529A) by need;
6 x IEC 320 C19 (16A)
AF526A
HP Intelignt Mod iPDU core unit, input: 3-phase, IEC 309 16A 4 pin/IEC532P6, attached input cord, connects into 3-phase facility
PDU 3ph 32a Intl input or to a 3-phase UPS;
Core
output: 6 x C19 (16A); includes the rack rear mount LED display unit.
Note: iPDU core units could be combined with extension bars (AF528A, AF529A) by need;
6 x IEC 320 C19 (16A)
AF527A
HP 5xc13 PDU
Extension Bars
Kit
Two (kit) Standard Extension Bar, 5 x C13 outlets, power and UID LEDs;
Note: Standard (non-intelligent) Extension Bars are monitored as a single load segment by the iPDU core unit and
do not support Intelligent Power Discovery. Note: Extension Bars can be mixed on a PDU core to create custom
configurations. Up to 6 extension bars may be added to each Intelligent PDU Core unit.
10 (2x5) IEC 320 C13 (10A) AF528A
HP 5xc13
Intelligent PDU
Ext Bars Kit
Two (kit) Intelligent Extension Bars, 5 x C13 outlets, individual monitoring and control; Note: Intelligent Extensions
Bars have individually monitored outlets that are also individually switchable for power cycling attached equipment.
Each individual C13 outlet has Power Line Communications to support Intelligent Power Discovery when connected
to PLC enabled common slot power supplies. Note: Extension Bars can be mixed on a PDU core to create custom
configurations. Up to 6 extension bars may be added to each Intelligent PDU Core unit.
10 (2x5) IEC 320 C13 (10A) AF529A
HP Intelligent
Mod PDU 32a
Intl Kit
iPDU kit with core unit and four (4) intelligent extension bars, input: IEC 309 32A/IEC332P6, connects into facility input 20 (4x5) IEC 320 C13 (10A) AF534A
or HP UPS R5500;
2 x IEC 320 C19 (16A)
output on iPDU core: 6 x C19 (16A); output on extension bars:
20 (4 x 5) C13 (10A); includes the rack rear mount LED display unit.
For more information, please visit www.hp.com/go/IPD
18
HP Monitored PDU (with power monitoring)
•Power input – single and dual input models with 3-phase or single-phase power
•Density-optimised 0U rackmount design (vertical in the back of the rack) –
including mounting brackets
•Local power – monitoring display and optional remote power reporting
•Unique colour-coded load identification and circuit breaker per load segment
•Mounting and cord retention brackets – for rackmounting included
•Integrated Care Pack support – HP Server & Storage Care Pack supports HP PDUs
at no additional cost
Model
Description
Outlets (Output)
HP 22 kVA S2316 Monitored
PDU (Intl)
Dual input, 3-phase, 16A, Intl
Input: 2xIEC 309, 5 pin 16A
Height: 1524mm/~35U
78/72 (2x36) C13 (10A)
plus 6 (2x3) C19
AF507A
HP 11 kVA S1316 Monitored
PDU (Intl)
Single input, 3-phase, 16A, Intl
Input: 1 x IEC 309, 5 pin 16A
Height: 1524mm/~35U
39/36 C13 (10A) plus 3
C19 (16A)
AF508A
HP 14.7 kVA S2132
Monitored PDU (Intl)
Dual input, single-phase, 32A, Intl
Input: 2 x IEC 309, 3 pin 32A
Height: 1524mm/~35U
78/72 (2x36) C13 (10A)
plus 6 (2x3) C19 (16A)
AF509A
HP 7.4 kVA S1132 Monitored
PDU (Intl)
Single input, single-phase, 32A, Intl
Input: 2 x IEC 309, 3 pin 32A
Height: 1524mm/~35U
39/36 C13 (10A) plus 3
C19 (16A)
AF510A
HP 7.3 kVA S132 Monitored
PDU (Intl)
Single input, single-phase, 32A, Intl
Input: 1 x IEC 309, 3 pin 32A, flat enclosure
Height: 733mm/~17U
27/24 C13 (10A) plus 3
C19 (16A)
AF915A
HP 22 kVA S1332 Monitored
PDU (Intl)
Single input, 3-phase, 32A, Intl
Input: 1 x IEC 309, 5 pin, 32A
Height: 733mm/~17U
12 C19 (16A)
AF917A
HP PDU management module
Hot plug retofit option for all HP monitored PDUs. Embedded
software, remote power monitoring and PDU management via
Ethernet.
Ethernet (RJ45), Serial (DB9)
AF400A
2 C13 PDU Extention bars
2 PDU extention bars with 7 receptacles (C13)
Input: C20
14/ 2x7 C13 (10A)
AF500A
Fixed-cord extension bar kit
2 PDU extension bars with 7 fixed and short cables (33 cm)
Input: C20
2 x 7 IEC320 C13
For more information, please visit www.hp.com/products/ups
Part number
351655-B21
19
HP Modular PDU
•Modular architecture – based on PDU core unit with multiple circuit breaker and extension bars
•Density optimised 1U/0U rackmount design – including mounting brackets
•Power Input and capacity on demand – various models with single phase and 3-phase power input
•Integrated Care Pack support – HP Server & Storage Care Pack supports HP PDUs at
no additional cost
20
Model
Description
Outlets (Output/single
phase)
16A mPDU
(worldwide)
Core unit and 2 extension bars, input: IEC 309 C20, connects into
facility input or high-voltage UPS R3000, R5500
14 (2x7) IEC 320 C13 (10A) 252663-B24
32A mPDU (Intl)
Core unit and 4 extension bars, input: IEC 309 32A, connects into
facility input or HP UPS R5500
28 (4x7) IEC 320 C13 (10A) 252663-B31
40A mPDU
(worldwide)
Core unit and 4 extension bars; can be hard wired directly into facility 28 (4x7) IEC 320 C13 (10A) 252663-B21
input or to a high-voltage UPS
40A mPDU (Intl)
Core unit and 4 extension bars, input: IEC 309 63A, can be
connected directly into facility input or to a high-voltage UPS
28 (4x7) IEC 320 C13 (10A) 252663-B32
Core only 32A (Intl)
Core unit only, input: IEC 309 32A, connects into facility input
or R5500
4 x IEC 320 C19
252663-B33
Core only 40A (Intl)
Core unit only, input: IEC 309 63A 3 pin, attached input cord,
connects into facility input or to a high-voltage UPS
4 x IEC 320 C19
252663-B34
Core only, HP 3 Phase
16A Intl Mod PDU
Modular PDU Core unit only, input: 3-phase, IEC 309 16A 4 pin,
attached input cord, connects into 3-phase facility input or to a
3-phase UPS
6 x IEC 320 C19
AF513A
Core only, HP 3 Phase
32A Intl Mod PDUs
Modular PDU Core unit only, input: 3-phase, IEC 309 32A 4 pin,
attached input cord, connects into 3-phase facility input or to a
3-phase UPS (hard wired output)
6 x IEC 320 C19
AF518A
Fixed-cord extension
bar kit
2 PDU extension bars with 7 fixed and short cables (33cm)
Input: C20
2 x 7 IEC320 C13
351655-B21
2 C13 PDU extension
bars
2 PDU extention bars with 7 receptacles (C13)
Input: C20
14; 2x7 C13 (10A)
AF500A
3rd-party mPDU
mounting kit
3rd-party mPDU mounting kit (worldwide)
For more information, please visit www.hp.com/products/ups
Part number
310777-B21
Power cords
Jumper cords (PDU to server, or UPS to server)
Model
Part number
Qtty
Colour
County
Length (m)
Input
Output
CBL1xIECC13-C14 0.5 m WW ALL
142257-B28
1
black
WW
0,5
IEC C13
IEC C14
CBL1xIECC13-C14 1.37 m
142257-006
1
black
WW
1,37
IEC C13
IEC C14
CBL15xIECC13-C14 1.37 m
142257-007
15
black
WW
1,37
IEC C13
IEC C14
CBL1xIECC13-C14 2.5 m
142257-002
1
black
WW
2,5
IEC C13
IEC C14
CBL1xIECC13-C14 3.0 m
142257-003
1
black
WW
3
IEC C13
IEC C14
CBL1xIECC13-C14 3.6 m – right angled power cord
142257-003
1
black
WW
3,6
IEC C13
IEC C14
IEC320-C19 to IEC320-C14 Jumper
(10A, IEC, 10ft/3.0 m)
313228-B21
1
black
WW
3
IEC C19
IEC C14
HP Rdnt 2 m,10A,C13-C14 Jumper Cord
AF573A
1
grey
WW
2
IEC C13
IEC C14
HP Rdnt 1.2 m 16A C19-C20 Jumper Cord
AF575A
1
grey
WW
1,2
IEC C19
IEC C20
HP Rdnt 2 m,16A,C19-C20 Jumper Cord
AF574A
1
grey
WW
2
IEC C19
IEC C20
HP Rdnt 2.5 m,16A,C19-C20 Jumper Cord
AF574A
1
grey
WW
2
IEC C19
IEC C20
HP Rdnt 4.5 m,16A,C19-C20 Jumper Cord
295633-B22
1
black
WW
2,5
IEC C19
IEC C20
CBL1xIECC19-C20 2.5 m
E7798A
1
black
WW
2,5
IEC C19
IEC C20
CBL1xIECC19-C20 4 m
E7804A
1
black
WW
4
IEC C19
IEC C20
CBL1xIECC19-Field Wired, 4.5 m
E7806A
1
black
WW
4,5
IEC C19
Field Wired
Power cords for HP IPD solution
Model
Part number
Qtty
Colour
County
Length
(m)
Input
Output
82 cm PLC power cable with data lines, single
SG506A
1
black
WW
1
IEC C13 & PLC
IEC C14 & PLC
82 cm PLC power cable with data lines, 5 Pack
SG507A
5
black
WW
5
IEC C13 & PLC
IEC C14 & PLC
148 cm PLC power cable with data lines, single
SG508A
1
black
WW
1
IEC C13 & PLC
IEC C14 & PLC
148 cm PLC power cable with data lines, 5 pack
SG509A
5
black
WW
5
IEC C13 & PLC
IEC C14 & PLC
198 cm PLC power cable with data lines, single
SG510A
1
black
WW
1
IEC C13 & PLC
IEC C14 & PLC
198 cm PLC power cable with data lines, 5 pack
SG511A
5
black
WW
5
IEC C13 & PLC
IEC C14 & PLC
330 cm PLC power cable with data lines, single
SG512A
1
black
WW
1
IEC C13 & PLC
IEC C14 & PLC
Note: All PLC Power cables are IEC C13 to IEC C14 “jumper cables“ and designated by bright blue IEC connectors. PLC power cables enable
Intelligent Power Discovery communications between HP Common Slot Platinum Power Supplies and the HP Intelligent Extension Bars when used
with the HP Intelligent PDU cores.
Country specific power cords
Model
Part number
Qtty
County
Power Cord Kit, 1.83 m, 10A, C13-EURO
AF568A
1
Mainland Europe
(Germany, France, …)
Power Cord Kit, 1.83 m, 10A, C13-UK/HK/
SINGAPORE
AF570A
1
UK
Length
(m)
Input
recept.
Output plug
1,83
IEC C13
IEC 83 C4
(CEE7-VII)/Schuko
1,83
IEC C13
BS 1363/A
Power Cord Kit, 1.83 m, 10A, C13-SWISS
AF565A
1
Switzerland/Denmark
1,83
IEC C13
SEV 1011
Power Cord Kit, 1.83 m, 10A, C13-ITALY/CHILE
AF571A
1
Italy
1,83
IEC C13
CEI 23-50
Power Cord Kit, 1.83 m, 10A, C13-ISRAEL
AF564A
1
Israel
1,83
IEC C13
SI 32
Power Cord Kit, 1.83 m, 10A, C13-DANISH
AF566A
1
Denmark
1,83
IEC C13
DK 2-5A
Power Cord Kit, 2.5 m, 10A, C13-ISRAEL
AF583A
1
Israel
2,5
IEC C13
SI 32
Power Cord Kit, 2.5 m, 10A, C13-S.AFRICAN
AF567A
1
South Africa
2,5
IEC C13
SABS 164
2,5
IEC C13
2
IEC C13
Power Cord Kit, 2.5 m, 10A, C13-AUSTRALIAN
AF569A
1
Australia
Power Cord Kit, 2.0 m, 10A, C13-JAPAN
AF572A
1
Japan
Power Cord Kit, 3.6 m, 16A, C19-EURO
AF576A
1
Mainland Europe
(Germany, France, …)
3,6
IEC C19
IEC 83 C4
(CEE7-VII)/Schuko
Power Cord Kit, 3.6 m, 16A, C19-EURO
305340-021
25
Mainland Europe
(Germany, France, …)
3,6
IEC C19
IEC 83 C4
(CEE7-VII)/Schuko
Power Cord Kit, 3.6 m, 16A, IEC309
AF581A
1
Intl
3,6
IEC C19
IEC 306 16A
single-phase
Power Cord Kit, 3.6 m, 16A, C19-UK/HK/
SINGAPORE
305340-031
25
UK
3,6
IEC C19
BS 1363/A
Power Cord Kit, 3.6 m, 16A, C19-UK/HK/
SINGAPORE
359615-031
1
UK
3,6
IEC C19
BS 1363/A
Power Cord Kit, 3.6 m, 16A, C19-SWISS
305340-081
25
Power Cord Kit, 3.6 m, 16A, C19-ITALY/CHILE
AF580A
1
Switzerland
3,6
IEC C19
SEV 1011
Italy
3,6
IEC C19
CEI 23-50
Power Cord Kit, 3.6 m, 16A, C19-ITALY/CHILE
305340-061
25
Italy
3,6
IEC C19
CEI 23-50
Power Cord Kit, 2.5 m, 16A, C19-ISRAEL
TBD
25
Israel
2,5
IEC C19
SI 32
25
Power Cord Kit, 3.6 m, 16A, C19-DANISH
305340-081
Power Cord Kit, 3.6 m, 16A, C19-S.AFRICAN
AF579A
Power Cord Kit, 3.6 m, 16A, C19-S.AFRICAN
305340-AR1
Denmark
3,6
IEC C19
DK 2-5A
1
South Africa
3,6
IEC C19
SABS 164
25
South Africa
3,6
IEC C19
SABS 164
For more information about power cords, please visit:
http://h18004.www1.hp.com/products/servers/proliantstorage/power-protection/index.html
http://powercords.hp.com
21
FCC Classification
Hot-Plug Power Supply
Supports Dynamic
Power Capping
Supports HE Mode/
Load Balancing
Redundancy Supported
Supports Intelligent
Power Discovery
Max Power
Efficiency
Power Efficiency
Certification (80Plus, CSCI)
Output
Part number
Power Supplies
HP 350W Factory Integrated Power Supply Kit
646146-B21
350W
80%
HP 400W Factory Integrated Power Supply Kit
515739-B21
400W
82%
HP 500W Factory Integrated Power Supply Kit
515915-B21
500W
90%
Gold
HP 500W Factory Integrated Power Supply Kit with Backplane
537150-B21
500W
90%
Gold
A
HP 500W Power Supply Kit
583437-B21
500W
90%
Gold
A
HP 365W Redundant Power Supply Kit with Backplane
532092-B21
365W
89%
A
HP 1100W Hot Plug Power Supply Kit
348114-B21
1100W
85%
B
HP 750W Factory Integrated Power Supply Kit
515997-B21
750W
85%
Non Common Slot Power Supplies
HP 300W Power Supply Kit
445067-001
300W
80%
HP 460W Factory Integrated Power Supply Kit
500447-B21
460W
82%
HP 430W Factory Integrated Power Supply Kit
431652-B21
430W
A
HP 700W Hot Plug Power Supply Kit
411076-001
700W
85%
B
HP 1000W Hot Plug Power Supply Kit
399771-001
1000W
85%
B
HP 1200W Common Slot Silver Hot Plug Power Supply Kit
437572-B21
1200W
90%
Silver
B
HP 1200W Common Slot Silver Hot Plug Power Supply Kit
500172-B21
1200W
90%
Silver
B
HP 460W Common Slot Gold Hot Plug Power Supply Kit
503296-B21
460W
92%
Gold
B
HP 460W Common Slot Gold Hot Plug Power Supply Kit
with Backplane
535684-B21
460W
92%
Gold
B
HP 750W Common Slot Gold Hot Plug Power Supply Kit
512327-B21
750W
92%
Gold
B
HP 750W Common Slot Gold Hot Plug Power Supply Kit
with Backplane
535683-B21
750W
92%
Gold
B
HP 460W Common Slot Platinum Hot Plug Power Supply Kit
593188-B21
460W
94%
Platinum
A
HP 460W Common Slot Platinum Hot Plug Power Supply Kit
with Backplane
605923-B21
460W
94%
Platinum
A
Common Slot Power Supplies
HP 750W Common Slot Platinum Hot Plug Power Supply Kit
593831-B21
750W
94%
Platinum
A
HP 1200W Common Slot Platinum Hot Plug Power Supply Kit
578322-B21
1200W
94%
Platinum
A
HP 1200W Common Slot -48VDC Hot Plug Power Supply Kit
437573-B21
1200W
90%
HP 2400W Gold Hot Plug Power Supply Kit
499243-B21
2400W
92%
Gold

A
HP 6X 2400W Gold Hot Plug Power Supply Kit
517521-B21
2400W
92%
Gold

A
HP 2400W Platinum Hot Plug Power Supply Kit
588603-B21
2400W
94%
Platinum

A
HP 6X 2400W Platinum Hot Plug Power Supply Kit
517521-B22
2400W
94%
Platinum

A
AH332A
2250W
90%
Blade Power Supplies
HP 2250W -48VDC Hot Plug Power Supply Kit
For more information about power supplies, please visit:
http://h18004.www1.hp.com/products/servers/rackandpower/powersupplies/index.html
22

HP Factory Express Services
Customisation, integration and deployment services from the HP Factory
to the data centre that save you time, money and resources
With HP Factory Express Services, you can:
•Collaborate with HP experts thereby freeing up your IT resources to deliver
other strategic value for your business
•Choose how your solution is built, tested, integrated, shipped and deployed
•Receive ready-to-deploy solutions delivered consistently worldwide
HP Factory Express Services are a perfect fit for your Rack & Power solution
since they enable pre-delivery customisation and integration, ensuring you
receive a total solution that is ready to go.
HP Factory Express System Customisation Services
Tell us how you want your system built, racked, labelled and cabled.
HP offers:
•Custom system settings
•Hardware and rack integration
•Asset & RFID tagging and labelling
•Special packaging – and more!
HP Factory Express Logistic Services
HP can create a custom delivery experience to accommodate your site
constraints and project needs. HP offers:
•Delivery at your site directly to the data centre
•Special equipment to transport heavy racked items
•Unpacking and waste removal
•Non-working day/time delivery
•Consolidation of your orders ensuring one delivery
HP Factory Express Software Image Management Services
By leveraging HP engineering to load and manage your software image at
our factory, we can help reduce your installation time. HP offers:
•Image development and qualification
•Image loading
•Image recovery
HP Factory Express Solution Services
For complex project rollout and end-to-end support for ease of
implementation, HP offers additional value-added services:
•Project management
•Onsite setup and turn-on
•Engineering consultation, support and training
Top to bottom:
•Complete system
documentation
•Rack integration up to
cluster solutions across
multiple racks
•Best-in-class cable
management
and airflow
•Almost ready to
go, awaiting final
packaging
For more information, visit www.hp.com/go/factoryexpress
23
HP Rack & Power Solutions
Subject:
Date:
www.hp.com/go/rackandpower
HP Rack & Power Solutions
Subject:
Date:
www.hp.com/go/rackandpower
HP Rack & Power Solutions
Subject:
Date:
www.hp.com/go/rackandpower
HP Rack & Power Solutions
Subject:
Date:
www.hp.com/go/rackandpower
Synergy and integration is the difference
HP servers
HP storage
Rack & Power infrastructure (Rack, UPS,
PDU, KVM etc.) seamlessly integrated and
qualified with HP servers and HP storage
HP software
Infrastructure
management
(Power & Cooling)
integration with HP
SIM
HP services
Integrated Care
Pack – HP Server &
Storage Care Pack
supports Rack &
Power products at no
additional cost
HP Factory Express Services enable pre-integration and customisation of your complete solution:
Server + Storage + Software + Rack & Power
HP Rack & Power Solutions
The base for a flexible and adaptive IT infrastructure
Energy-efficient computing in the next-generation
data centre
HP: Taking a holistic approach to power and cooling
issues, from end to end – from Chip to Chiller.
HP Rack & Power Solutions are part of HP’s
end-to-end solution, and important if you want to
create an energyefficient data centre.
Made for HP, by HP
We give you a one-stop shop for your entire
solution – simplifying product and vendor
qualifications, procurement and customer support,
and guaranteeing product compatibility.
HP Rack & Power Solutions
•Racks and rack options – to provide the base
for a flexible, adaptive IT infrastructure
•Power – to protect, distribute and monitor
the power
HP Rack & Power Solutions are qualified for seamless
•Access and monitoring – to harmonise the
integration with HP ProLiant and Integrity servers, HPmanagement of heterogeneous servers, storage
UX based servers and HP storage offerings, as well
and IT infrastructure
as standards-based third-party solutions.
•Cooling – to handle the increased heat on the
rack and data centre level
You can find out more by referring to the HP Rack & Power Solutions toolkit, or by
visiting us online at: www.hp.com/go/rackandpower
www.hp.com/eur/rackandpower
For specific queries, please contact your local HP representative
Get connected
Share with colleagues
www.hp.com/go/getconnected
Get the insider view on tech trends, alerts, and
HP solutions for better business outcomes
© Copyright 2011 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only
warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing
herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained
herein.
4AA2-5078EEE, Created October 2011
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
