MUSICIANS DRIVE ALL OUR INNOVATIONS. At Samson, we strive to simplify the lives
of all musicians through high-performance audio gear that delivers tremendous value. This year, our design
team has created an array of amazing new products that will free your creativity.
From our USB microphones, micro wireless technology and portable PA systems, to our comprehensive
mixers, studio monitors and accessory packages, 2011 is the year to push your musical imagination to the
edge just like the world-class artists that you’ll find throughout these pages.
Thanks to our driving obsession to innovate, Samson brings the future to you, today.
5
10
30
49
PA Cabinets
Auro
4-13
5
LIVE!
6-7
Resound HD
8-9
Expedition Portable PA
Mixers
XML / TXM Series
10-13
14-19
15
L Series
16-17
MDR / S Series
18-19
Amplifiers
20-23
Servo Series
21
SX Series
22
Processors
S Class Mini
24-29
25
S Class
26-27
C Class
28
Powerbrite
29
Recording
Studio Monitors
30-41
31
USB Mics
32-33
XLR Mics
34-37
Drum Mics
38
Headworn Mics
39
Contractor Mics
40-41
Headphones
42-43
Accessories
44-47
Mic Accessories
45
Stands / Racks
46
Cables
47
Wireless
48-55
AirLine Micro
49
AirLine Synth
50
AirLine 77
51
Concert 77 / 277
UM1 77
Stage 5 / 55
AirLine Guitar
52-53
53
54-55
55
PA Cabinets
Auro • Live! • dB • Resound HD • Portable PA
AURO SERIES
LOUDSPEAKERS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
AURO 2-Way Active Speakers
Combining superior components and meticulous engineering, Auro 2-way
active speaker systems are designed to integrate the key elements of power,
portability and exceptional sound into any PA setup.
•Compact, lightweight speaker systems
with 400 watts of output power
•Built-in Optimax compressor/limiter with
2-stage speaker protection
•34mm compression driver with 1-inch exit
•1-3/8-inch pole mount receptacle
•XLR and 1/4-inch mic/line inputs and
XLR line output
•Two oversized ergonomic carry handles
•Dual-angle floor monitor positioning
•2-band equalizer
SPECIFICATIONS
AURO D412
AURO D415
•12-inch extended range low frequency driver
•15-inch extended range low frequency driver
Use as Near-Field
Perfect for Stand Mounting
AURO SERIES
Speaker Size12-inch 15-inch
Power Handling
400 watts
400 watts
Impedance
8 Ω
8Ω
Weight
35.80 lbs
49 lbs
Use as Far-Field
D412
D415
5
LIVE! SERIES
6
PA CABINETS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
LIVE! Active PA Cabinets
The highest quality components and exceptional engineering make Live! Active
PA Cabinets a great choice for a small to medium loudspeaker system.
•Dual limiter speaker processing
•XLR extension output with Mix/Thru switch
•XLR mic/line inputs with 2-band EQ and
level control
•All-wood cabinets
LIVE! 612 2-Way PA Cabinet
LIVE! 615 PA Cabinet
LIVE! 612M Active 2-Way Monitor
•2-way bi-amped active loudspeaker system
•2-way bi-amped active loudspeaker system
•2-way bi-amped active stage monitor
•300 watts RMS total power
(LF 250 watts + HF 50 watts)
•300 watts RMS total power
(LF 250 watts + HF 50 watts)
•300 watts RMS total power (LF 250 watts + HF 50 watts)
•Custom designed, heavy-duty, 12-inch low
frequency driver with 3-inch voice coil
•Custom designed, heavy-duty, 15-inch low
frequency driver with 3-inch voice coil
•34mm titanium compression driver with 1-inch exit
•34mm titanium compression driver with 1-inch exit
•Custom designed, heavy-duty, 12-inch low frequency
driver with 3-inch voice coil
•34mm titanium compression driver with 1-inch exit
SPECIFICATIONS
LIVE! SERIES
LIVE! 615
LIVE! 612M
LIVE! 1212
LIVE! 1215
Speaker Size12-inch
15-inch
12-inch
2x12-inch
2x15-inch
Power Output
300 watts
300 watts
500 watts
500 watts
Weight
Frequency Response
LIVE! 612
300 watts
50.11 lbs
55 Hz – 19kHz , +/- 5dB
52.47 lbs
52 Hz – 19 kHz, +/- 5dB
57.46 lbs
56 Hz – 19 kHz, +/- 5dB
75.81 lbs
89.97 lbs
50 Hz – 23 kHz ± 5 dB
48 Hz – 23 kHz ± 5 dB
LIVE! SERIES
PA CABINETS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
dB Active Subwoofers
Perfect for any sound reinforcement
system where more low end is desired.
•Built-in amplifier delivers 1000 watts of
program power
•Variable stereo crossover with balanced high pass
outputs for satellite speakers
•Heavy-duty, rear mounted casters
•E xtra large grab handles and 35mm pole
mount receptacle
•3/4-inch internally braced, plywood construction
•Covered in tough carpet with steel corners
LIVE! 1212 PA Cabinet
LIVE! 1215 PA Cabinet
dB1500a Active Subwoofer
•2-way bi-amped active loudspeaker system
•2-way bi-amped active loudspeaker system
•5 00 watts RMS total power
(LF 400 watts + HF 100 watts)
•5 00 watts RMS total power
(LF 400 watts + HF 100 watts)
•Heavy-duty, 15-inch low
frequency transducer
•Two custom designed, heavy-duty, 12-inch low
frequency drivers with 3-inch voice coil
•Two custom designed, heavy-duty, 15-inch low
frequency drivers with 3-inch voice coil
•4 4 mm titanium compression driver with
1-inch exit
•4 4 mm titanium compression driver with
1-inch exit
dB1800a Active Subwoofer
•Heavy-duty, 18-inch low
frequency transducer
7
8
RESOUND HD
PA CABINETS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
RESOUND HD Passive PA Cabinets
The revamped Resound HD line features increased power handling and great versatility from a
variety of professional-grade enclosure options.
•2-way passive PA speaker cabinet
•Dual port-tuned enclosure
•1-inch throat horn
•Dual 1/4-inch and Speakon® connections
•1-1/2-inch titanium compression driver
•All-plywood cabinet construction
RS10 HD PA Enclosure
RS12 HD PA Enclosure
RS15 HD PA Enclosure
•Handles 300 watts @ 8 ohms
•Handles 500 watts @ 8 ohms
•Handles 600 watts @ 8 ohms
•10-inch low frequency driver
•12-inch low frequency driver
•15-inch low frequency driver
RS10M HD Wedge Monitor
RS12M HD Wedge Monitor
RS15M HD Wedge Monitor
•Handles 300 watts @ 8 ohms
•Handles 500 watts @ 8 ohms
•Handles 600 watts @ 8 ohms
•10-inch low frequency driver
•12-inch low frequency driver
•15-inch low frequency driver
RESOUND HD
PA CABINETS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
RS215 HD PA Enclosure
•Handles 1200 watts @ 4 ohms
•15-inch low frequency driver
Willie Adler
JD DeServio
of Lamb of God
of Black Label Society
SPECIFICATIONS
RESOUND HD
Speaker Size
15-inch 15-inch12-inch10-inch10-inch12-inch 15-inch
Power Handling
Impedance
Weight
RS215 HD
RS15 HD
RS12 HD
RS10 HD
RS10M HD
RS12M HD
RS15M HD
1200 watts
600 watts
500 watts
300 watts
300 watts
500 watts
600 watts
4 Ω
8 Ω
8 Ω
8 Ω
8 Ω
8 Ω
8 Ω
75 lbs
49.60 lbs
39.70 lbs
29.50 lbs
28.65 lbs
49.60 lbs
42 lbs
9
Jordan Rudess of
with his XP510i
EXPEDITION SERIES
PORTABLE PA
SAMSON PROFESSIONAL AUDIO SOLUTIONS
EXPEDITION SERIES
Thanks to their clever design and all-in-one feature set, Expedition Portable PAs provide ideal
solutions for any PA application where great sound and portability are a must.
EXPEDITION 510i Portable PA
•Integrated iPod® dock
•Packs up into a single portable unit that weighs just over 50 pounds
•Dual 2-way speaker enclosures with custom designed, heavy-duty
10-inch woofers
•1-inch high frequency driver
•Lightweight, Class D amplifier produces 500 watts of stereo power
(250 watts per side)
•Built-in 10-channel stereo mixer with studio quality 24-bit DSP effects
•Four mic/line inputs, three stereo inputs and phantom power
•Integrated 1-3/8-inch speaker stand mounts
XP510i & XP308i Pack and Go!
Speakers slide together
into a single case.
Removable mixer stores
inside the speaker.
Complete, lightweight system
transports with ease.
EXPEDITION 308i Portable PA
•Integrated iPod® dock
•Dual 2-way speaker enclosures, powered mixer with built-in 300 watt
(2 x 150) Class D amplifier
•Packs up into a single portable unit that weighs just over 40 pounds
•8 -channel mixer with four mic/line inputs, three
stereo inputs and phantom power
•Custom 8-inch woofers in 2-way vented enclosures with 1-inch
high frequency driver
•Integrated 1-3/8-inch speaker stand mounts
11
12
EXPEDITION SERIES
PORTABLE PA
SAMSON PROFESSIONAL AUDIO SOLUTIONS
EXPEDITION 40iw Portable PA
High-quality components, professional features and convenient
portability make the XP40i a consummate single system solution for
a wide range of public address applications.
•Lightweight, Class D amplifier produces 40 watts of high quality power
•Custom designed, heavy-duty 6-inch low frequency drivers
•XLR and 1/4-inch mic/line level inputs
•1/8-inch stereo aux input
•1/4-inch link in/out jack for stereo setup
•Built-in iPod® dock with level control
•Includes rechargeable battery
Built-in VHF wireless microphone system
EXPEDITION 40i Portable PA
Perfect for tour groups, classrooms, conference/meeting rooms,
health clubs, outdoor events and even small auditoriums.
•Lightweight, Class D amplifier produces 40 watts of high quality power
•Custom designed, heavy-duty 6-inch low frequency drivers
•XLR and 1/4-inch mic/line level inputs
•1/8-inch stereo aux input
•1/4-inch link in/out jack for stereo setup
•Built-in iPod® dock with level control
•Includes rechargeable battery
EXPEDITION 25i Portable PA
This versatile loudspeaker/push-to-talk microphone system provides power
and performance in a highly portable package.
•Compact, lightweight design with carry handle and strap
•5-inch full-range loudspeaker with 25 watts of power
•Push-to-talk microphone included
•Built-in iPod® dock with level control
•Integrated microphone stand mount
•Rechargeable battery included
KARAOKE
PRESENTATIONS
EDUCATION
PARTIES
Mixers
XML • TXM • L Series • MDR • S Series
POWERED MIXERS
XML / TXM SERIES
SAMSON PROFESSIONAL AUDIO SOLUTIONS
XML SERIES
XML Powered Mixers incorporate solid professional sound reinforcement with a lightweight,
Class D amplifier design to set apart three all-new systems from the rest of the pack.
•Lightweight, Class D amplifier design
•Studio-quality 24-bit DSP stereo effects with
100 selectable presets
•7-band graphic EQ for both the main and
monitor outputs
•1/4-inch and Speakon® speaker outputs
•Low-noise mic pre-amps, phantom power,
3-band EQ, DSP on each channel
•Solid construction with two convenient carry
handles for easy transport
XML910
XML610
XML410
•12-channel, 900 watt stereo powered mixer
•12-channel, 600 watt stereo powered mixer
•6-channel, 400 watt stereo powered mixer
•Variable compression on mono channels
•Variable compression on mono channels
•Channel feedback detection
•Channel feedback detection
12-Channel Stereo Powered Mixer
12-Channel Stereo Powered Mixer
6-Channel Stereo Powered Mixer
TXM SERIES
TXM Tabletop Powered Mixers are ergonomically correct and attractively appointed tabletop
enclosures designed to provide powerful, all-in-one portable solutions for live sound applications.
•500 watts stereo, 1000 watts bridged mono
•Dual 9-band graphic EQ
•Mono sub output with variable low-pass filter
•1/4-inch phone and Speakon® outputs
TXM20 Powered Mixer
TXM16 Powered Mixer
•12 high-quality microphone preamps
•8 high-quality microphone preamps
•Four aux sends (one pre, one pre/post, two effects)
•Three aux sends (two pre, one effects)
•Dual internal 24-bit effects processor with
100 preset programs
•Internal 24-bit effects processor with 100
preset programs
15
16
L SERIES
MIXERS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
L SERIES 4-Bus Mixing Consoles
Ideal for any live sound application, the L-Series Mixers
offer professional performance and comprehensive
features perfect for almost any live sound application.
L3200/L2400 4-Bus Mixing Consoles
•Four stereo line inputs
•2 × 12-segment LED level meter for Main L/R, PFL/AFL, Group 1-4
•Large, illuminated mute switches
•100mm faders provide studio console feel
•3-band EQ with sweepable mids
•Dual DSP with 100 digital multi-effects
•USB I/O (send from Aux or Main, return to Main or last stereo channels)
•Six aux sends and two stereo aux returns
•Talkback mic input
L2000/L1200 4-Bus Mixing Consoles
•Two stereo line channels with mic preamps and 4-band EQ
•XLR and 1/4-inch stereo main outputs
•Two large, 12-segment LED meters for main mix and PFL/Solo
•Large, illuminated mute switches and 60mm faders
•9-band stereo graphic EQ on master output
•24-bit DSP with 100 preset effects
•Three aux sends and EFX send
•Assignable USB digital I/O for computer recording and playback
L3200
L2400
•32 input channels
•24 input channels
•24 mono and four stereo XLR mic inputs
•16 mono and four stereo XLR mic inputs
L SERIES
MIXERS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
L2000
L1200
•20 input channels
•12 input channels
•16 mono mic/line channels with mic
preamps and 3-band swept mid EQ
•Eight mono mic/line channels with mic
preamps and 3-band swept mid EQ
17
18
MDR SERIES
MIXERS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
MDR SERIES Passive Mixers
Ideal for live or studio needs, the MDR Series Mixers are versatile stereo
systems that produce excellent fidelity and include 256 digital effects.
MDR1688 16-Channel Mixer
MDR1248 12-Channel Mixer
•16 input channels
•12 input channels
•Eight mic/line and four stereo line inputs
•Four mic/line and four stereo line inputs
•24-bit digital effects processor with 256 presets
•24-bit digital effects processor with 256 presets
•3-band EQ with sweepable mids on mic/line inputs
•3-band EQ with sweepable mids on mic/line inputs
•4-band EQ on stereo channels
•4-band EQ on stereo channels
•60mm faders
•60mm faders
•Standard 19-inch rackmount kit included
•Standard 19-inch rackmount kit included
MDR1064 10-Channel Mixer
MDR624 6-Channel Mixer
•Six high-quality microphone preamps with
channel inserts
•Two high-quality microphone preamps
•Full-featured compact mixer for live or studio use
•Two stereo channels
•Two stereo channels
•3 band EQ on all channels
•3 band EQ on all channels
•Dual aux sends
•Dual aux sends
•8-segment stereo LED bar VU meter
PERFORMANCES
WORSHIP
•8-segment stereo LED bar VU meter
•Full-featured compact mixer for live or studio use
S SERIES
MIXERS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
S•ZONE Multi-Zone Stereo Mixers
Front panel monitoring allows you to assign and listen to any of the four
zones with the built-in speaker or headphones.
•4-channel, 4-zone stereo mixer
•Two stereo CD/line inputs
•Two mic/stereo line inputs with ducking
•Euroblock output connectors
•Front panel micro-speaker and
headphone jack for zone monitoring
•Remote volume control
SM10 Line Mixer
Ideal for the stage, studio and an infinite variety of installation applications,
the SM10 Line Mixer is a versatile and reliable addition to your audio setup.
•Ten channels (ten 1/4-inch stereo line inputs, two
include XLR mic inputs)
•Balance control for each channel
•Switchable +4 dBu or -10 dBV line input level
•Balanced main stereo XLR and 1/4-inch line
outputs
•Two auxiliary sends
•Front-panel headphone and monitor outputs with
level controls
•Flexible, 6-segment LED meter/headphone
source control
•Versatile signal routing
•Center detents for all controls for use in low light
situations
•Low noise, discrete microphone pre-amplifiers with
48-volt phantom power
•Single 19-inch rackmount metal chassis with
internal power supply
REAR VIEW
BARS/CLUBS
RESTAURANTS
19
Amplifiers
Servo Series • SX Series
SERVO SERIES
AMPLIFIERS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
SERVO SERIES Power Amplifiers
Servo Series are stereo power amplifiers optimized for use in both professional and project
recording studios, as well as live performance applications.
SERVO 120a Power Amplifiers
•6 0 watts stereo at 4 ohms
•120 watts bridged mono at 8 ohms
•Bi-polar design and toroidal transformer
power supply
•Single-space 19-inch rackmount servo controlled
power amplifier
•Individual left and right level controls
•1/4-inch balanced phone jack and RCA inputs
•Headphone jack with speaker output mute
•10-segment, 3-color LED meters
SERVO 120a
SERVO 600 / 300 / 200 Power Amplifiers
•Bridge Mode: 200 watts @ 8 ohms
•4-stage power protection circuitry
•1/4-inch and RCA input connectors
•Independent input level controls for each channel
•5-way binding post and 1/4-inch outputs
•Dual rackspace design
•Forced air cooling via two temperature-sensitive
variable speed fans
•10-segment, 3-color LED meters
•Unique, stable bi-polar design
SERVO 600 Power Amplifier
SERVO 300 Power Amplifier
SERVO 200 Power Amplifier
•2 x 225 watts @ 8 ohms, 2 x 300 watts @ 4 ohms
•2 x 100 watts @ 8 ohms, 2 x 150 watts @ 4 ohms
•2 x 66 watts @ 8 ohms, 2 x 100 watts @ 4 ohms
21
22
SX SERIES
AMPLIFIERS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
SX SERIES Power Amplifiers
Cool and efficient amplifiers that provide clean power to effectively drive your mid-sized PA,
monitor fills or fixed installation.
•Dual variable-speed fan cooling
•XLR and TRS input connections
•Signal, peak and protection
circuitry indicators
•Dual rackspace design
•5-way binding post and Speakon® outputs
•Toroidal transformer power supply for high
current and low profile
SX3200 Power Amplifier
•Class H, rail-switching amplifier
•750 watts per side @ 8 ohms
•1100 watts per side @ 4 ohms
•2200 watts bridged mono @ 8 ohms
SX2800 Power Amplifier
SX2400 Power Amplifier
SX1800 Power Amplifier
•Class H, rail-switching amplifier
•Class H, rail-switching amplifier
•Class AB power amplifier
•700 watts per side @ 8 ohms
•550 watts per side @ 8 ohms
•400 watts per side @ 8 ohms
•900 watts per side @ 4 ohms
•750 watts per side @ 4 ohms
•600 watts per side @ 4 ohms
•1800 watts bridged mono @ 8 ohms
•1500 watts bridged mono @ 8 ohms
•1200 watts bridged mono @ 8 ohms
SX1200 Power Amplifier
•Class AB power amplifier
•300 watts per side @ 8 ohms
•450 watts per side @ 4 ohms
•900 watts bridged mono @ 8 ohms
Processors
S Mini • S Class • C Class • Powerbrite
SIGNAL PROCESSORS
S•MINI
SAMSON PROFESSIONAL AUDIO SOLUTIONS
S•MINI Mini Processors
S Class Mini Processors provide great versatility and problem-solving
capabilities for both live and studio environments.
S•MIX Mini Mixer
S•AMP Headphone Amplifier
S•MONITOR Self Monitor
•5-channel mini mixer
•4-channel headphone amplifier
•XLR balanced mic input with volume control
•Stereo 1/4-inch input
•XLR mic and 1/4-inch stereo mix inputs
with volume control
•AC adapter included
•RCA and 1/4-inch stereo inputs with volume control
•Four 1/4-inch stereo headphone outputs
with individual volume controls
•RCA and 1/4-inch stereo outputs
•AC adapter included
•XLR thru mic output to send to main mixer
•1/4-inch stereo mix thru for daisy chaining
additional units
•Two headphone outputs
•AC adapter included
S•DIRECT
S•DIRECT PLUS
S•DIRECT Direct Box
•Switchable input level handles instrument
and speaker levels
•4 8V phantom power or 9V operation with auto
battery shut off
•1/4-inch link output
•Switchable ground lift
S•CONVERT Bump Box
•+ 4 to -10 audio level converters
S•PHANTOM
48-Volt Phantom Power Supply
S•DIRECT PLUS Stereo Direct Box
•Stereo direct box
•RCA -10 and XLR +4 inputs with level control
•2-channel 48V phantom power supply
•1/4-inch linked inputs/outputs
•RCA -10 outputs and XLR +4 outputs
•Two balanced XLR mic inputs
•AC adapter included
•Two balanced XLR and 1/4-inch mic outputs
•4 8 volt phantom power or 9 volt operation with
auto battery shut off
•AC adapter included
•Switch-able ground lift
•Gold plated XLR balanced outputs
•Solid extruded aluminum chassis with large
rubber feet
25
26
S•CLASS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
SIGNAL PROCESSORS
S•COM PLUS 4-Channel Compressor/Limiter
S•COM 4 4-Channel Compressor/Limiter
This stereo compressor/limiter adds features like De-essing for
added control.
A compact, versatile compresser/gate that provides four channels of
high-quality dynamic processing.
•Compressor section includes variable threshold, ratio, attack and release
•4-channel compressor/limiter with Enhancer
•Expander/Gate section includes variable threshold level, switchable release
•Linkable in two stereo pairs
•SKD (Smart Knee Detector) dynamically adjusts the compression curve
•Expander/Gate with variable trigger control and switchable Fast/Slow release
•AEG (Auto Envelope Generator) dynamically adjusts attack and release
•5 -segment LED meters for Input/Output levels and gain reduction
on each channel
•EFR (Enhanced Frequency Recovery) restores high frequencies lost with
heavy compression
•Advanced circuit design utilizing Low Noise operation
•Built-in de-esser circuitry reduces sibilance
•Amplifiers and high quality VCA’s
•Input/Output, gain reduction, de-esser level, gate open/close
and limit metering
•Servo balanced inputs and outputs on XLR and 1/4-inch connectors
•Key inputs and outputs for externally processing control voltage
•SKD (Smart Knee Detector) circuit automatically switches from soft to hard knee
based on the level of Input signal applied
•Individual channel bypass and stereo link modes
•Individual threshold and ratio controls on each channel
•Balanced inputs and outputs
S•CURVE 231 2 X 31-Band EQ
S•Curve 215 2 x 15 Band EQ
A comprehensive, dual 31-band EQ for the most
demanding live or studio applications.
A professional signal processor that gives you precise tonal
control over two channels of audio.
•Dual 31-band graphic equalizer
•2/3 octave, 15-band stereo graphic equalizer
•Constant Q circuitry
•Constant Q circuitry
•LED faders
•Balanced XLR and TRS inputs and outputs
•Low Cut/Sub frequency crossover with subwoofer output
•Low-cut filter
•Balanced XLR and TRS inputs and outputs
•LED faders and LED bar VU meters
•Boost/Cut, and Cut only modes
•Bypass switch
•Switchable 6 or 12dB Filters
•Variable high cut filter
S•CLASS
SIGNAL PROCESSORS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
S•3-WAY Stereo/Mono Crossover
S•PATCH PLUS 48-Point Patch Bay
The S•3-Way is a 1-space, dual channel crossover that’s an ideal
solution for live sound venues and commercial installations.
Fully balanced and extremely durable, our 48-point patch bay
makes all your connections easy.
•Full-featured, stereo 3-way, mono 4-way electronic crossover
•Fully balanced, extremely durable 48-point patch bay
•Phase switches invert the phase of individual outputs
•Normal, Half-Normal and through mode operation
•Adjustable low frequency delay for time aligning speaker stacks
•3-way front panel mode switches
•Mode indicator LEDs provide quick visual display of operating mode
•1/4-inch TRS connectors
•4-segment LED input meter allows easy gain adjustment
•19-inch rack mount chassis
•Precision Linkwitz-Riley, 24 dB/octave filters
•Output mute switches for all individual outputs
•Constant Directivity EQ smoothes the response of CD horns
above 3.5kHz
•Peak limiter with independent threshold control and peak LED
S•PHONE 4-Channel Headphone Amplifier
A versatile 4-channel headphone amplifier, loaded with
advanced features for monitor and cue mixing.
•4-channel, 4-zone stereo mixer
•2 mic/stereo line inputs with ducking
•2 stereo CD/line inputs
•On-board speaker and headphone monitoring
•Euroblock output connectors
•Remote volume control
LIVE VENUES
27
28
C•CLASS
SIGNAL PROCESSORS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
C•CLASS Desktop Processors
Delivering high-end tools to desktop recordists in a friendly, innovative
package, C-Class are designed to compliment each other, and they also
work great individually.
C•QUE 8 Headphone Amplifier
C•CONTROL Control Room Matrix
•4 -channel headphone amplifier
•Control room matrix
•Auxiliary input with volume control
•Control room output with level control
•Eight total outputs
•Assignable to three separate outputs
•EQ shape circuit on each channel
•Talkback microphone with push-to-talk and
slate-to-tape
•Independent volume control on each channel
•Headphone amplifier with volume control
Scott Ian
of Anthrax
SIGNAL PROCESSORS
POWERBRITE
SAMSON PROFESSIONAL AUDIO SOLUTIONS
POWERBRITE Power Distributors
Providing clean, reliable power and rackmount lighting, PowerBrite Power Distributers are
exceptionally useful in any rack.
PB15 PRO Power Distributer
PB15 Power Distributer
PS15 Power Strip
•19-inch rackmount power conditioner with LED
lighting and dual digital voltage multi-meters
•19-inch rackmount power conditioner with
LED lighting
•19-inch rackmount power conditioner
•Lifetime guaranteed high intensity LED lamps with
dimmer control
•Lifetime guaranteed high intensity LED lamps with
dimmer control
•Dual digital multi-meters display input voltage and
load amperes of both the switched and
unswitched outlets
•8 rear-panel AC outlets, plus an additional frontpanel convenience outlet
•8 rear-panel AC outlets, plus an additional frontpanel convenience outlet.
•3 -point: surge protection, peak voltage spike
clamping and RFI/EMI filtering
•3 -point: surge protection, peak voltage spike
clamping and RFI/EMI filtering
•Rear rack lighting with included LED
gooseneck lamp
•8 rear-panel AC outlets, plus an additional frontpanel convenience outlet
•Dedicated switch with status light for powering the
rear-panel switched outlets
•3 -point: surge protection, peak voltage spike
clamping and RFI/EMI filtering
•Front-panel resettable 15 amp circuit breaker
protects all connected gear
•Rear rack lighting with included LED
gooseneck lamp
Sold Internationally Only with same specifications
PB10 PRO Power Distributer
PB10 Power Distributer
PS10 Power Strip
29
Recording
Studio Monitors • Microphones • USB Mics
STUDIO MONITORS
RECORDING
SAMSON PROFESSIONAL AUDIO SOLUTIONS
STUDIO GT Active Studio Monitors with USB Audio Interface
STUDIODOCK Active USB Monitors
Studio GT combines exceptional monitoring performance with a USB audio interface,
providing a complete desktop solution for recording audio to your computer.
With on-board iPod dock and USB interface,
StudioDock lets you record, mix, sync and
take your music with you.
•4.25-inch magnetically shielded, inverted cone
copolymer woofer
•Includes Cakewalk® Sonar LE music
production software
•1-inch silk dome high frequency driver
•16-bit 44.1kHz/48kHz
•2 x 20 watts of internal stereo power
•Stereo RCA and 1/8-inch aux inputs
•4i Model: 4.25-inch copolymer woofers, 40 watts
(2 x 20) of internal power
•Two combination mic and instrument/line inputs
•2-position switch for no-latency direct stereo
and mono monitoring
•25mm silk dome high frequency drivers
•Two 1/8-inch stereo headphone outputs with
level controls
•3i Model: 3.25-inch copolymer woofers, 30 watts
(2 x 15) of internal power
•Built-in iPod® dock to sync, charge and play music
•USB input to stream digital audio from your computer
•Bass reflex vented cabinet design
•Front panel 3.5mm stereo aux input jack, headphone
output jack and volume control
•Rear panel RCA inputs
MEDIAONE Active Studio Monitors
RESOLV Active Studio Monitors
RESOLV 120a Active Subwoofer
Ideal near-field monitor systems for studios,
video post-production suites or anywhere
else great sound is desired.
With precise engineering, Resolv studio
monitors render an accurate mix that instills
total confidence in your final production.
A powerful 120 watt low frequency amplifier
drives a heavy-duty 10-inch transducer,
reproducing tones between 40–180 Hz.
•5-inch, 4-inch, or 3-inch copolymer woofer
•8 -inch, 6.5-inch or 5-inch, woven carbon fiber low
frequency drivers
•120 watt low frequency amplifier
•2-way active studio reference monitors with ported
tuned enclosure
•40–180 Hz.
•Precision-tuned, rear-vented enclosure
•25mm silk dome high frequency driver
•Front panel level control, headphones and stereo
input jack
•1.25-inch silk dome high frequency drivers
•Convenient RCA inputs
•Low diffraction waveguide
•AV shielded for multimedia applications
•Active crossover with multi-pole design
•4 -position high frequency lift control
•XLR and 1/4-inch balanced inputs
•RCA unbalanced inputs
•Heavy-duty 10-inch transducer
•Active crossover
•Phase switch
•Auto sleep mode
•Mute switch jack
31
32
USB MICROPHONES
RECORDING
SAMSON PROFESSIONAL AUDIO SOLUTIONS
METEOR MIC USB Studio Mic
Q2U Recording Pak
Perfect for recording music in your home
studio, Meteor Mic is ideal for Skype, iChat
and voice recognition
A convenient combination for live sound
and digital audio application.
•L arge (25mm) diaphragm condenser for rich
audio recording
•Q2U USB/XLR dynamic handheld microphone
•CD quality, 16-bit, 44.1/48kHz resolution
•Patent pending folding-back leg design
•High-quality A/D converter with 16-bit,
48kHz sampling rate
•Stereo 1/8-inch headphone jack for no
latency monitoring
•3.5mm stereo headphone jack output with
volume control
•Headphone volume control with microphone
mute switch
•HP20 studio headphones with closed design and
40mm full-range drivers
•Includes USB cable and carry pouch
•Includes Cakewalk Music Creator
recording software
G-TRACK
•Cardioid pickup pattern
USB Condenser Mic with Audio Interface
GO MIC Portable USB Condenser Mic
The world’s first USB condenser mic with a
built-in audio interface.
The ideal portable recording microphone
that clips to your laptop.
•L arge, 19mm diaphragm studio condenser
USB microphone
•Perfect for recording music, podcasting and
field recording
•Works seamlessly with GargeBand, Logic Express
and Logic Pro
•Records electric guitars and vocals at once
•Records stereo instruments, including keyboards
and drum machines
•On-board control of input and output levels
•Ideal for voice recognition software, iChat, VoIP
and web casting
•Transducer Type: condenser, pressure gradient
with USB digital output
USB MICROPHONES
RECORDING
SAMSON PROFESSIONAL AUDIO SOLUTIONS
Q1U Dynamic USB Mic
C01U USB Condenser Mic
C03U Multi-Pattern USB Condenser Mic
Delivers great audio quality and
convenience with high-quality components,
a handheld design and USB interface.
This classic USB mic bridges the gap
between mid-level USB mics and pro-line
products that require additional gear.
Delivers pristine audio quality with enhanced
capabilities, most notably multiple
pickup patterns.
•16-bit resolution, 44.1-48kHz sampling
•16-bit resolution, 44.1-48kHz sampling
•16-bit resolution, 44.1-48kHz sampling
•High SPL neodymium element
•Cardioid pickup pattern
•Supercardioid pickup pattern
•Large, 19mm diaphragm
•Switchable cardioid, omni and figure-8
pickup patterns
•Includes Cakewalk Music Creator
recording software
•Includes Cakewalk Sonar LE recording software
•Switchable high-pass filter and –10dB pad
•High SPL neodymium element
•Large, 19mm diaphragm
•Includes Cakewalk Sonar LE recording software
UB1
C01U Recording / Podcasting Pak
C03U Recording / Podcasting Pak
Omnidirectional USB Boundary Mic
Includes everything needed to record
digital audio on your computer.
This portable package provides everything
needed to digitalize your audio recordings
and podcasts.
As a surface mount condenser with USB,
the UB1 is ideal for conference rooms,
podiums and alters.
•Bundled with Cakewalk’s Sonar LE digital
audio workstation software
•Bundled with Cakewalk’s Sonar LE digital audio
workstation software
•Plug and play operation on Mac or PC
•C01U features a 19mm internal shockmounted diaphragm
•C03U features two 19mm internal shockmounted diaphragms
•Miniature, low profile design
•Cardioid pick up pattern
•Supercardioid, Omni and Figure-8 pickup patterns
•Includes mic clip, MD5 desktop mic stand,
SP01 shockmount and USB cable
•Includes mic clip, MD5 desktop mic stand, SP01
shockmount and USB cable
•Comes in durable, lightweight aluminum case
•Comes in a durable, lightweight aluminum case
•16-bit, 44.1–48 kHz sample rates
•Omnidirectional pickup pattern
•10-foot USB cable included
•Includes Cakewalk® Sonar LE
33
34
XLR MICROPHONES
SAMSON PROFESSIONAL AUDIO SOLUTIONS
LIVE / RECORDING
C01 Large Diaphragm Condenser Mic
Ideal for recording vocals, acoustic
instruments and for use as an overhead
drum mic.
•Large, 19mm diaphragm
•Cardioid pickup pattern
•Gold plated XLR connector
•LED indicates 48V of phantom power
•Smooth, flat frequency response
•Swivel stand mount included
CL2 Pencil Condenser Microphone
Ideal for recording and live applications,
CL2s are true capacitor condenser
mics that come as a matched pair.
•High-pass filter and 10dB pad
•Includes interchangeable cardioid and
omni elements
•3 micron, gold-sputtered diaphragms
•Maximum SPL of 141dB (cardioid) and
138dB (omni)
Mike Inez
of Alice in Chains
Herman Li
of Dragonforce
•Includes mic clip, pop filter, windscreen
and shockmount
•Comes in durable, lightweight aluminum case
LIVE / RECORDING
XLR MICROPHONES
SAMSON PROFESSIONAL AUDIO SOLUTIONS
C02 Pencil Condenser Mic
C03 Multi-Pattern Condenser Mic
C05 Handheld Condenser Mic
A beautifully crafted pencil-style condenser
mic. Sold as a stereo pair.
Its multiple pickup patterns allow you to
record your best vocal, acoustic instrument,
and overhead drum or piano performances.
Great for obtaining studio quality vocals for
live performance.
•Switchable supercardioid, omni and figure-8
pickup patterns
•19mm shock-mounted capsule
•Highly-focused cardioid condenser pickup pattern
•Gold-plated XLR connectors
•Carry case and 2 shockmount mic clips included
•Dual 19mm capsule design
•Switchable high-pass filter and 10db pad
•Gold plated XLR connector
•Cardioid pickup pattern
•Gold-plated XLR connector
•Die-cast zinc casing
•Carry pouch, mic cable and mic clip included
•Carry case and swivel stand mount included
CL5 Handheld Condenser Mic
CL7 Studio Condenser Mic
CL8 Multi-Pattern Studio Condenser
A studio condenser in a handheld package,
making it an ideal selection for critical
miking of vocals and instruments.
Its true capacitor condenser mic element
design effectively reproduces vocals,
acoustic instruments and overhead cymbals.
Its capacitor-based elements faithfully
reproduce a variety of sound sources with
amazing clarity and detail.
•Pressure gradient, true condenser
•Cardioid pickup pattern
•Extended linear frequency response
•Large, gold sputtered diaphragm
•Switchable supercardioid, omni and figure-8
pickup patterns
•Super-cardioid pickup pattern
•Switchable high-pass filter and 10dB pad
•Large, gold sputtered diaphragm
•Three micron, gold-sputtered diaphragm
•36-52V phanton power operation
•Switchable high-pass filter and 10dB pad
•High SPL capability of 141 dB
•Internal shockmount
•36-52V phantom power operation
•Dual stage windscreen
•Swivel stand mount and carry case included
•Internal shockmount
•48-volt phantom power operation
•Comes in durable aluminum flight case
•Swivel stand mount and carry case included
35
36
XLR MICROPHONES
LIVE / RECORDING
SAMSON PROFESSIONAL AUDIO SOLUTIONS
Q4 Dynamic Handheld Mic
Q6 Dynamic Handheld Mic
Q7 Supercardioid Dynamic Mic
Ideal for live vocals, presentations and
instrument miking.
The Q6 gives you more gain and higher
output. Included is an XLR mic cable, mic
clip and carry pouch.
Engineered to the finest detail to provide
the ultimate in sound reproduction and
professionalism.
•High output, low impedance design
•Perfect for vocal and instrument micing
•Outstanding vocal mic for stage and studio
•Neodymium dynamic mic element
•High gain, low impedance design
•High output, low impedance design
•Cardioid pickup pattern
•Neodymium dynamic mic element
•Ultra sensitive neodymium dynamic mic element
•Multi-axis shock mounted element
•Supercardioid pickup pattern
•Supercardioid pickup pattern
•XLR mic cable, carry pouch and clip included
•Multi-axis shock mounted element
•E xtended range frequency response for
optimum reproduction
•XLR cable, carry pouch and mic clip included
•Multi-axis shockmounted element
•Carry case and mic clip included
R10S Vocal/Recording Microphone
R21 Vocal/Recording Microphone
R21S Vocal/Recording Microphone
An outstanding microphone, ideal for
karaoke and computer recording.
The R21 features a tight cardioid pickup
pattern for maximum gain before feedback.
Its rugged design gives you the performance
and dependability you need.
•Cardioid pickup pattern
•High output dynamic element
•Cardioid pickup pattern
•Feedback-reduction design
•On/off switch
•On/Off switch
•Unidirectional cardioid polar pattern for
maximum gain before feedback
•80Hz - 12kHz frequency response
•Withstands high sound pressure levels
•Gold-plated XLR connectors
•1/8-inch jack with 1/4-inch adapter
•Dual stage windscreen
•Mic clip with euro adapter
•Includes desktop stand and XLR to
1/4-inch mic cable
•Excellent for live performance and recording
•18-foot XLR cable
•Rugged road-proof design with gold plated
XLR connector
•Hardshell foam padded case
•Dual stage windscreen
LIVE / RECORDING
Q8 Cardioid Dynamic Mic
QL5 Lavalier Microphone
Our premier handheld, dynamic microphone
more than excels in both live performance
and recording applications.
The cardioid pickup pattern of the CL5’s
charged condenser element captures
speech and vocals with great detail.
•The ideal dynamic microphone for professional
live applications
•Great for presentation and video applications
•High gain output, low impedance design
•Enhanced cardioid pickup pattern
•Neodymium dynamic mic element
•Supercardioid pickup pattern
•Sturdy tie clip securely attaches microphone
out of sight
•Multi-axis shock-mounted element
•Carry pouch and PM5 XLR adapter included
XLR MICROPHONES
SAMSON PROFESSIONAL AUDIO SOLUTIONS
•Fixed, charged condenser element
•Carry case and mic clip included
R21S3 Vocal/Recording Mic (3-PACK)
R31S Vocal/Recording Microphone
Three times the performance and
dependability you need night after night.
Ensure crystal-clear presentations and
vocal recordings with this dynamic mic.
•R21S 3-pack
•Feedback-reduction design
•Cardioid pickup pattern
•On/Off switch
•On/Off switch
•80Hz - 12kHz frequency response
•Dual stage windscreen
•500 ohm impedance
•Gold-plated XLR connectors
•-53dBV/pa sensitivity
•Mic clip with Euro adapter
•1/4-inch stereo connector
•18-foot XLR cable inlcuded
•Includes mic stand clip and XLR to
1/4-inch mic cable
•Hardshell foam padded case
Brett Scallions
37
38
DRUM MICROPHONES
LIVE / RECORDING
SAMSON PROFESSIONAL AUDIO SOLUTIONS
5KIT 5-Piece Drum Mic Set
7KIT 7-Piece Drum Mic Set
8KIT 8-Piece Drum Mic Set
A set of dynamic drum mics that provide the
essentials for accurately miking drums.
A complete set of dynamic drum mics with
a pair of C02 pencil condenser mics for
overhead or close miking cymbals.
The ultimate set of drum mics, including two
C01 condenser mics and a C02H mini pencil
condenser for miking all your cymbals.
•5-piece drum mic kit
•7-piece drum mic kit
•8-piece drum mic kit
•Gold-plated XLR connectors
•Gold-plated XLR connectors
•Gold-plated XLR connectors
•Road case included
•Road case included
•Road case included
Shawn Drover
of Megadeth
Chris Adler
of Lamb of God
Charlie Benante
of Anthrax
HEADWORN MICROPHONES
HEADWORN
SAMSON PROFESSIONAL AUDIO SOLUTIONS
SE10 & SE50
Includes these 4 adapters:
SWITCHCRAFT TA3F
Works with Samson’s AirLine Synth, Concert Series and AKG® Wireless Systems
SE10 & SE50 Headworn Condenser Microphones
3.5 MM
These low profile, miniature condenser mics provide outstanding audio
reproduction for presentation, fitness and other vocal applications.
•Omnidirectional pickup pattern
•Moisture resistant coating
•Four cable adapters for compatibility with
most popular wireless transmitters
•Includes three windscreens, clothing
cable clip and carry case
Works with Sennheiser® Wireless Systems
HIROSE 4 PIN
Also available in black
Works with
Audio-Technica®
Wireless Systems
Carry Case Included with the SE10 or SE50
SWITCHCRAFT TA3F
Available in BEIGE or BLACK
Available in BEIGE or BLACK
SE10 Headworn Condenser Mic
SE50 Headworn Condenser Mic
•Micro-miniature condenser with 3mm capsule
•Micro-miniature condenser with 2.5mm capsule
Works with Shure ®
Wireless Systems
39
40
CONTRACTOR MICROPHONES
SAMSON PROFESSIONAL AUDIO SOLUTIONS
LIVE / RECORDING
CM10B Unidirectional Boundary Mic
Perfect for a conference table, or
mounting on the wall.
•Half cardioid–condenser
•All electronics on-board
•Internal high-pass filter
•Mini XLR connector
•Includes 30-foot cable with mini to
standard XLR connector
•9–52V phantom power operation
ALSO AVAILABLE IN WHITE
CM11B Omni-directional Boundary Mic
Mic any surface with this high quality
boundary mic.
•Surface mount omnidirectional boundary mic
•Condenser element
•Half omni pickup pattern
•Internal hi-pass filter
•Mini XLR connector
•Includes 30-foot cable with mini to standard
XLR connectors
•9–52V phantom power operation
ALSO AVAILABLE IN WHITE
CONTRACTOR MICROPHONES
LIVE / RECORDING
SAMSON PROFESSIONAL AUDIO SOLUTIONS
CM15P Gooseneck Podium Mic
CM20P Gooseneck Podium Mic
CM12C Hanging Choir Mic
An ideal mic solution for providing speeches
and presentations with optimal sound quality.
High quality gooseneck podium mic
for any application.
Extra long cable and steel direction guide
for easy positioning
•Cardioid–fixed charge condenser
•Cardioid–fixed charge condenser
•Miniature condenser choir microphone
•Flexible gooseneck, 15-inch overall length
•Flexible gooseneck, 20-inch overall length
•Mini XLR connector
•Internal selectable high-pass filter
•Internal selectable high-pass filter
•Flexible steel positioning bracket
•Standard XLR connector
•Standard XLR connector
•9–52V phantom power operation
•9–52V phantom power operation
•Includes 30-foot cable with mini to standard
XLR connector
•Includes flange mount and windscreen
•Includes flange mount and windscreen
•Multistage windscreen
•9–52V phantom power operation
▼
Included with CM15P & CM20P
Windscreen
Table Top Mount
▼
Optional Accessories for CM15P & CM20P
SMS1: Thru Table XLR
XFM1: Surface Mount Extension Wire XLR
41
Headphones
SR850 • PH60 • CH Series • RH Series
HEADPHONES
MONITORING
SAMSON PROFESSIONAL AUDIO SOLUTIONS
SR850 Studio Reference
C01/SR850 Bundle
PH60 Headphones
• Professional studio reference headphones
C01 CONDENSOR MICROPHONE
• Headphone Type: Semi-Open
• Semi-open design for enhanced ambient listening
environment
•Cardioid pickup pattern
• Driver Size: 34mm
• Fit Style: Supra-aural
• 5 0mm drivers for exceptional reproduction and
wide dynamic range
•Large, 19mm diaphragm
•Gold plated XLR connector
• Frequency Response: 20Hz-22kHz
•LED indicates 48-volt phantom power
• Impedance: 32 ohms
• Frequency Response: 10Hz - 30kHz
• 32ohm impedance
SR850 STUDIO REFERENCE HEADPHONES
• Self-adjusting headband
•Professional studio reference headphones
• 1/8-inch to 1/4-inch gold plated adapter included
•Semi-open design for enhanced ambient listening
•50mm drivers
• Plug Type: 1/8-inch to 1/4-inch adapter
• Cable Type: Straight
• Cord Length: Approximately 3 meters
• Weight: 0.36 pounds
CH700 Reference Headphones
CH70 Reference Headphones
RH600 Headphones
•Headphone Type: Closed
•Headphone Type: Closed
• Headphone Type: Open
•Driver Size: 40mm
•Driver Size: 40mm
• Driver Size: 40mm
•Fit Style: Circumaural
•Fit Style: Circumaural
• Fit Style: Circumaural
•Frequency Response: 20Hz-22kHz
•Frequency Response: 20Hz-22kHz
• Frequency Response: 20Hz-22kHz
•Impedance: 64 ohms
•Impedance: 32 ohms
• Impedance: 32 ohms
•Plug Type: 1/8-inch to 1/4-inch adapter
•Plug Type: 1/8-inch to 1/4-inch adapter
• Plug Type: 1/8-inch to 1/4-inch adapter
•Cable Type: Straight
•Cable Type: Straight
• Cable Type: Straight
•Cord Length: Approximately 3 meters
•Cord Length: Approximately 3 meters
• Cord Length: Approximately 3 meters
•Weight: 1.1 pounds
•Weight: 0.8 pounds
• Weight: 1.05 pounds
ALSO AVAILABLE: RH300 & RH100
43
Accessories
Mic Accessories • Stands • Racks • Cables
MIC ACCESSORIES
ACCESSORIES
SAMSON PROFESSIONAL AUDIO SOLUTIONS
WS03
MK5
MK10
WS1
WS5E
DMC100
MC1
MK5 Boom Mic Kit
WS1 Windscreen (5 PACK)
MC1 Mic Clips (3 PACK)
•A complete mic stand set-up in one box
•Reduces occurances of P-popping
•Heavy-duty mic clips
•Heavy-duty adjustable Boom Mic Stand
•Fits most popular handheld microphones
•Brass threads
WS03 Condenser Windscreen
DMC100 Drum Mic Clips (3 PACK)
•Oversized foam windscreen
•Allows for easy clip-on rim mounting of most
drum microphones
•18-foot XLR mic cable, mic clip and
windscreen included
MK10 Lightweight Boom Stand
•Collapsible tripod boom stand
•Sturdy steel construction
•Perfect for large diaphram condensers like the
C01, C03, CL7 and CL8
•Sleek black finish
WS5E Headset Windscreen
•Ultra-light for easy transport
•Windscreens for QE/QV headset microphones
•Adjustable height and swivel
•Includes mic clip
BT4
MB1
PS01
SP01
BL3
MD5
SP01 Shock Mount
MD5 Desktop Mic Stand
BT4 Telescoping Boom Stand
•For studio condenser mics
•5-inch desktop microphone stand
•Tripod, collapsible boom mic stand
•Suspension shock mount for C01, C03, CL7 and
CL8 microphones
•Designed to hold any standard mic for desktop
•Die cast and steel construction
•Weighted metal base for total stability
•Sleek black finish
•Can be used with SP01 shockmount
PS01 Pop Filter
MB1 Mini Mic Boom Stand
BL3 Ultra Light Boom Stand
•Nylon mesh screen reduces P-popping
•Heavy-duty adjustable boom mic stand
•Tripod, collapsible boom mic stand
•Flexible metal goose neck
•Perfect for miking kick drums and speaker cabinets
•Die cast and steel construction
•Light, durable steel construction
with nylon components
•Mic clip included
•Black finish
45
46
STANDS & RACKS
ACCESSORIES
SAMSON PROFESSIONAL AUDIO SOLUTIONS
MS200
MS100
SB100 Studio Mic Boom Stand
SRK Equipment Racks
MS100 Studio Monitor Stands (PAIR)
•Professional-grade studio boom mic stand
•Heavy-duty equipment racks in several sizes.Works
for both US and EU rack screws.
•Isolated studio monitor stands
•Heavy-duty steel construction
•Adjustable to over 12 feet in height
•19-inch equipment racks
•Counter-weighted telescopic boom with
over 6 feet of horizontal extension
•8, 12, 16, and 21 rackspace versions
•Locking casters for easy positioning
•Heavy-duty steel construction with fully
enclosed sides
•Tripod base folds up for easy transport or storage
•3-inch (75mm) locking casters
•Single-space blank panel included
•US and European rack screws included
•Telescoping column for height adjustment
(30-50 inches)
•Adjustable vise-style speaker bracket fits most
studio monitors
•Heavy base with carpet spikes
MS200 Studio Monitor Stands (PAIR)
•Professional-grade isolated studio monitor stands
•Telescoping column for with locking pin
•Heavy base with carpet spikes
TS20 Speaker Stand
TS50P Speaker Stand (PAIR)
TS100 Heavy Duty Speaker Stand
•Telescoping mounting pole for sub/satellite
PA systems
•Compact telescoping tripod stand
•Heavy-duty telescoping tripod stand
•110lb (50kg) handling capacity
•110lb (50kg) handling capacity
•Heavy gauge aluminum construction with standard
1-3/8-inch diameter
•Steel construction
•Aluminum construction
•Fits standard 1-3/8-inch pole receptacles
•Adjustable up to 6 feet in height
•Smaller footprint for tighter spaces
•Fits standard 1-3/8-inch pole receptacles
•Black finish
•Black finish
•Secure locking-pin height adjustment
•Height adjustable to 56-inches
CABLES
ACCESSORIES
SAMSON PROFESSIONAL AUDIO SOLUTIONS
Tourtek Cables are premium audio cables designed for musicians and sound engineers who
require superior sound quality and demand flawless reliability. All Tourtek Cables feature
genuine Neutrik® connectors and are backed by a lifetime warranty.
MICROPHONE CABLES
INSTRUMENT CABLES
SPEAKER CABLES
Tourtek Microphone Cables feature two
25-gauge multi-strand inner conductors
wrapped in a braided copper shield with
96% coverage, protected by a 7mm PVC
outer jacket.
Tourtek Instrument Cable’s inner stranded
copper conductor is covered by a PVC
insulator, which is wrapped in a second
carbon insulator, then wrapped in a braided
copper shield with 96% coverage, and
protected by a 6mm PVC outer jacket.
For serious power delivery, Tourtek Speaker
Cables use genuine Neutrik® Speakon® and
1/4-inch connectors, heavy-duty 14-gauge
copper wire and solid build construction.
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TOURTEK
TM3. . . .
TM6. . . .
TM10. . .
TM15. . .
TM20. . .
TM25. . .
TM30. . .
TM50. . .
TM100. .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
3-foot
6-foot
10-foot
15-foot
20-foot
25-foot
30-foot
50-foot
100-foot
MC18 XLR Microphone Cable (3-PACK)
•18-foot low noise microphone cable
•Heavy duty XLR connectors
•3 cables per pack
TI1 . . .
TI2 . . .
TI3 . . .
TI5 . . .
TI6 . . .
TI10. . .
TI15. . .
TI20 . .
TI25 . .
TI50 . .
TIL3. . .
TIL10. .
TIL20. .
TIL25. .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
1-foot
2-foot
3-foot
5-foot
6-foot
10-foot
15-foot
20-foot
25-foot
50-foot
3-foot right angle
10-foot right angle
20-foot right angle
25-foot right angle
TSQ3: 3-foot with ¼-inch connectors
TSQ10: 10-foot with ¼-inch connectors
TSQ30: 30-foot with ¼-inch connectors
TSS30: 30-foot with Speakon® connectors
47
Wireless Systems
AirLine Micro • AirLine Synth • AirLine 77 • Concert • Stage
AIRLINE MICRO
WIRELESS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
AIRLINE MICRO Wireless Earset System
When mobility is vital, Samson’s AirLine Micro offers the most discreet,
comfortable and convenient wireless earset solution available.
•Micro-size wireless UHF system
•Includes a convenient system carry case
•Tone squelch and auto mute for clear operation
•Includes AC adapter and charging cables
AH2 Transmitter
AR2 Receiver
AR2 Dock
•E arset transmitter and omnidirectional microphone
with no beltpack
•Low-profile wireless receiver (2.36” x 1.67” x .51”)
•Provides secure base for AR2 receiver during
operation and/or recharging
•Lithium ion rechargeable battery
(5-6 hours of operation)
•USB DC input for recharging
•Lithium ion rechargeable battery
(7-8 hours of operation)
•USB DC input for power and recharging
•USB DC input for power and recharging
(cables included)
•3.5mm balanced mic/line level output
•3.5mm balanced audio output
•Single button operation for power, mute and volume
•Water resistant
AIRLINE MICRO Wireless Camera System
When pro-level audio is a must for video applications, AirLine Micro
Wireless Camera System offers the most discreet and convenient camera
solution available.
•Wireless system with micro transmitter, receiver
and double dock
•Includes 3.5mm and XLR camera connectors, AC
adapter and charging cables
•Includes a convenient system carry case and
standard hot shoe mount
AL2 Transmitter
AR2 Receiver
AR2DT Double Dock
•Lightweight beltpack transmitter with LM10
omnidirectional lavalier microphone
•Low-profile wireless receiver (2.36” x 1.67” x .51”)
•Provides secure base for AL2 transmitter
during recharging
•Lithium ion rechargeable battery
(7-8 hours of operation)
•Single button operation for power, mute and volume
•Lithium ion rechargeable battery
(7-8 hours of operation)
•USB DC input for power and recharging
•3.5mm balanced mic/line level output
•Provides secure base for AR2 receiver during
operation and/or recharging
•USB DC input for power and recharging
(cables included)
•3.5mm unbalanced audio output
49
50
AIRLINE SYNTH
WIRELESS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
AirLine Synth Wireless Systems
AirLine Synth is the solution answer for all your wireless needs, with its roadworthy durability, crystal clear
reception and comprehensive features available in handheld, beltpack and guitar-specific designs.
AR300M (sold seperately)
AR300 Wireless Receiver
AR4300 Airline Synth Rackmounted System
•AirLine Synth wireless receiver
The AR4300 is designed to hold up to four AR300M receivers in a
single rackspace.
•Frequency-agile synthesized receiver with over
300 channels
•Automatic channel scan to select the clearest
frequency
•All-metal chassis
•Infrared transmitter channel set
•50mm x 20mm backlit LCD display
•Headphone cue system for monitoring individual or
all channels
•Metal half-rack chassis
•Mixed XLR and 1/4-inch balanced outputs
•Built-in antenna distribution
•Individual channel XLR and 1/4-inch
balanced outputs
•Mic/line level switches on each output
•Outside voltage selectable power supply
•Dual front-mounted removable TNC antennas
•Squelch control
•XLR and 1/4-inch balanced outputs
•Mic/line level switch
•Up to 11 systems for simultaneous operation
AX300 Wireless Handheld Transmitter
AL300 Wireless Beltpack Transmitter
AG300 Wireless Guitar Transmitter
•AR300 AirLine Synth wireless receiver
•AR300 AirLine Synth wireless receiver
•AR300 AirLine Synth wireless receiver
•Micro transmitter plugs into any XLR dynamic mic
•Micro-size beltpack transmitter
•Plug-in micro guitar transmitter, no beltpack
•IR transmitter channel set
•Mini XLR connector
•IR transmitter channel set
•LCD display
•IR transmitter channel set
•LCD display
•Mute switch
•LCD display
•Mute switch
•15dB pad
•Mute switch
•15dB pad
•Gain control
•15dB pad
•Gain control
•Low battery indicator
•Gain control
•Low battery indicator
•Samson Q7 mic included
•Low battery indicator
•1/4-inch gold jack convertible for Fender ® or
Gibson® style guitars
•Available with LM10 lavalier or SE10 micro
headset systems
AIRLINE 77
WIRELESS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
AirLine 77 Wireless Systems
With AirLine 77, you get complete wireless freedom that’s good to go anywhere the sound takes you. Its
great sound is packaged for handheld, guitar, aerobic, vocal, or wind instrument applictions.
CR77 True Diversity Wireless Receiver
AX1 Handheld System
AG1/AF1 Guitar System
•True diversity UHF wireless system with PLL
frequency control
•CR77 True Diversity Wireless Receiver
•Multi-segment audio level and RF level LED meters
•Plugs into any standard dynamic mic to make
it wireless
•Squelch and volume control
•Squelch control eliminates carrier signal noise and
RF interference
•Tuned molded antennas for
accurate reception
•XLR and unbalanced 1/4-inch outputs
with mic/line level output switch
•Power switch, power/battery LED and input
level control
•Includes Q7 dynamic microphone
•Multi-segment audio level and RF level LED meters
•Squelch and volume control
•XLR and unbalanced 1/4-inch outputs with mic/
line level output switch
•AF1/AG1 micro transmitter plugs directly into guitar
or bass
•Transmitter features power switch, power/battery
LED and 15 dB pad
•XLR and unbalanced 1/4-inch outputs with mic/
line level output switch
AH1/QE Aerobics Headset System
AH1/QV10E Vocal Headset System
AH1/HM40 Wind Instrument
•CR77 True Diversity Wireless Receiver
•CR77 True Diversity Wireless Receiver
•CR77 True Diversity Wireless Receiver
•Great RF reception for interference-free
performance
•Phase-Locked Loop (PLL) circuitry for flawless
reception
•Multi-segment audio level and RF level LED meters
•Half-rack VHF receiver design
•Locking Mini-XLR connector for all systems
•Dual conversion design and on-board noise
reduction
•Balanced XLR and 1/4-inch outputs juacks
•XLR and unbalanced 1/4-inch outputs with mic/
line level output switch
•XLR and 1/4-inch outputs
•Front panel power switch, RF level meter and
squelch control
•AH1 headset transmitter features power/battery
LED, power switch and mute switch
•Easy to read battery and signal level meters
•Mute switch, gain control
•HM40 condenser horn microphone employs
cardioid pickup pattern for outstanding sound
•Squelch and volume control
•Horn bell clamp included for easy attachment of
entire AH1/HM40 assembly to horn
51
52
CONCERT 77
WIRELESS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
CONCERT 77 Wireless Systems
Stemming from the CR77 receiver and CT7 transmitter, our Concert 77 series offers high-performance UHF
wireless solutions ideal for any application where the freedom of mobility essential to your performance.
CR77 True Diversity Wireless Receiver
CT7 Beltpack Transmitter
HT7 Handheld System
•True diversity UHF wireless system with PLL
frequency control
•P3 locking Mini-XLR input
•CR77 True Diversity Wireless Receiver
•3-segment battery indicator
•HT7 Handheld Mic Transmitter
•Balanced XLR and 1/4-inch outputs
•Separate power and on/off switches
•Q7 dynamic mic capsule
•Front panel power switch, RF level meter and
squelch control
•Adjustable AF level (audio gain)
•Supercardiod pickup pattern
•12 hours of battery life on 9V
•Extended range frequency response
•Mute switch, gain control
•AC adapter included
•9-volt battery operation, LED battery level meters
•Tuned molded antennas
LM10 Presentation System
SE10 Earset System
QV10E Headset System
•CR77 True Diversity Wireless Receiver
•CR77 True Diversity Wireless Receiver
•CR77 True Diversity Wireless Receiver
•CT7 Beltpack Trasmitter
•CT7 Beltpack Trasmitter
•CT7 Beltpack Trasmitter
•LM10 Lavalier Mic
•SE10 Headworn Mic
•QV10E condenser mic
•Omnidirectional pickup pattern
•Omnidirectional pickup pattern
•Unidirectional cardioid pickup pattern
•Intergrated clip-on design
•Unique retaining ear band
•Low profile headset with flexible gooseneck
•AC adapter and 1/4-inch cable included
•Water-resistant coating and drip ring
•Waterproof design
•AC adapter and 1/4-inch cable included
CONCERT 77
WIRELESS
53
SAMSON PROFESSIONAL AUDIO SOLUTIONS
UM1 77 Wireless Video
CR277 Dual Channel Handheld System
UM1 77
Designed for twice the versatility, our Concert 277 offers an additional channel and a
second professional microphone, increasing your vocal applications by two-fold.
Micro Diversity Wireless System for Video
•Ideal for videography, corporate video and
broadcast applications
•Dual channel true diversity UHF wireless system
with PLL frequency control
•Independent level controls
•Multi-segment RF level and peak audio indicators
for each channel
•Two HT7 handheld transmitters
•Available with Samson Concert77 Handheld,
Lavalier or Headset Transmitters
•AC adapter and 1/4-inch cable included
•UM1 System operates on the 800 MHz UHF band
•Squelch control for each channel
•Tuned molded antennas
•Diversity wireless circuitry for fail-safe operation
•Two independent 1/4-inch outputs or one 1/4-inch
mix output
•Dual-function (Battery Level/RF Level) LED meter
•Variable Squelch control and Power switch
•Balanced and unbalanced outputs
•Supplied XLR to mini-XLR cable
•Headphone output with level control
•Carry case included
•9-volt battery operation
HM40 Wind Instrument
GC1 Guitar System
UM1 Systems Include:
•CR77 True Diversity Wireless Receiver
•CR77 True Diversity Wireless Receiver
•CT7 Beltpack Trasmitter
•CT7 Beltpack Trasmitter
•CT7 Beltpack Transmitter
(Shown with the QL5 Lavalier)
•HM40 mini-condenser mic
•Heavy-duty guitar/instrument cable
•Cardioid pickup pattern
•AC adapter, 1/4-inch and 1/4-inch to Mini-XLR
cables included
•Integrated clip-on design
•Flexible gooseneck
•HT7 Handheld Transmitter
(Shown with the Q7 mic element)
•UM1 Micro Diversity Receiver
54
STAGE 5 / STAGE 55
WIRELESS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
STAGE 5 Wireless Systems
With Stage 5 Wireless Systems, you get incredible reception and crystal clear sound in a VHF system priced
to bring the freedom of wireless to everyone.
SR5 Stage 5 Receiver
ST5 Transmitter
STAGE 5H Handheld System
•High performance VHF wireless receiver
•3.5mm input
•SR5 Stage 5 Receiver
•LED display for audio and RF meters
•Battery level meter
•HT5 Handheld Mic Transmitter
•Volume and squelch control
•Audio on/off switches
•H5 dynamic mic capsule
•Dual-antenna, true diversity design
•AC adapter and 1/4-inch cable included
•Noise reduction circuitry
•Balanced XLR ouput and1/4-inch
unbalanced output
STAGE 55 Wireless Systems
The true diversity design of our Stage 55 Wireless Systems brings more incredible reception and more
crystal clear sound to all of your wireless applications.
SR55 Stage 55 Receiver
STAGE 55 Handheld System
STAGE 55 Guitar System
•High performance VHF wireless receiver
•SR55 Stage 55 Receiver
•SR55 Stage 55 Receiver
•LED display for audio and RF meters
•HT5 Handheld Mic Transmitter
•ST5 Beltpack Trasmitter
•Volume and squelch control
•Q7 dynamic mic capsule
•GC5 heavy-duty guitar/instrument cable included
•Dual-antenna, true diversity design
•Supercardiod pickup pattern
•Noise reduction circuitry
•Extended range frequency response
•Balanced XLR output and1/4-inch
unbalanced output
•AC adapter included
STAGE 55
WIRELESS
SAMSON PROFESSIONAL AUDIO SOLUTIONS
AIRLINE Guitar Systems
STAGE 5T Three In One (Guitar/Presentation/Headset) VHF Wireless System
AP1 Pedal Receiver
•SR5 Stage 5 Receiver
•Power switch and level control
•ST5 Beltpack Transmitter
•Power On/Low Battery LED indicators as well as
TX/Peak LEDs
•Comes with headset/lavalier mics and
guitar/instrument cable
•Dual swivel mounting antennas for optimum
positioning
•AC adapter included
•1/4-inch unbalanced output jack
•DC input
•Squelch control
•AF1/AG1 Transmitters feature standard 1/4-inch
plug, Power/Battery LED, Power switch, 15dB pad
switch and operate on single AAA battery
AF1
•AirLine Fender Guitar System
STAGE 55 Earset System
STAGE 55 Lavalier System
•SR55 Stage 55 Receiver
•SR55 Stage 55 Receiver
•ST5 Beltpack Trasmitter
•ST5 Beltpack Trasmitter
AG1
•SE10 Headworn Mic included
•LM5 Lavalier Mic
•AirLine Gibson Guitar System
•Omnidirectional pickup pattern
•Omnidirectional pickup pattern
•Unique retaining ear band
•Intergrated clip-on design
•Water-resistant coating and drip ring
•AC adapter and 1/4-inch cable included
55
Samson Technologies | 45 Gilpin Ave | Hauppauge, NY 11788
P: 631 784 2200 | samsontech.com
All specifications subject to change without notice.
©2011 SAMSON CATALOG 1/11
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
