Blue Seal G596 Instruction manual
Stainless Steel Counter
Refrigerators
Instruction manual
Model
G596-A/G597-A/G622-A/U636-A
Installation
Safety Tips
•
Position on a flat, stable surface.
•
A service agent/qualified technician should carry out installation and any
repairs if required. Do not remove any components or service panels on
this product.
•
Consult Local and National Standards to comply with the following:
Note: If the unit has not been stored or moved in an upright
position, let it stand upright for approximately 12 hours
before operation. If in doubt allow to stand.
1.
Remove the appliance from the packaging. Make sure that all protective
plastic film and coatings are thoroughly removed from all surfaces.
2.
Maintain a distance of 20cm (7 inches) between the unit and walls or
other objects for ventilation. Increase this distance if the obstacle is a
heat source.
• Health and Safety at Work Legislation
• BS EN Codes of Practice
• Fire Precautions
• IEE Wiring Regulations
Note: Before using the appliance for the first time, clean the
shelves and interior with soapy water.
• Building Regulations
•
DO NOT use jet/pressure washers to clean the appliance.
•
DO NOT use the appliance outside.
•
DO NOT use this appliance to store medical supplies.
•
DO NOT use electrical appliances inside the appliance
(e.g. heaters, ice-cream makers etc.).
•
DO NOT stand or support yourself on the base, drawers or doors.
•
DO NOT allow oil or fat to come into contact with the plastic
components or door seal. Clean immediately if contact occurs.
•
Bottles that contain a high percentage of alcohol must be sealed and
placed vertically in the refrigerator.
•
Always carry, store and handle the appliance in a vertical position and
move by holding the base of the appliance.
3.
•
Always switch off and disconnect the power supply to the unit before
cleaning.
•
Keep all packaging away from children. Dispose of the packaging in
accordance with the regulations of local authorities.
•
If the power cord is damaged, it must be replaced by a POLAR agent or
a recommended qualified technician in order to avoid a hazard.
Set the brakes on the castors to keep the appliance in position
OR
Level the appliance by adjusting the screw feet.
Fitting the Shelves & Floor Guards
1.
Place one set of shelf guides on either side of the cabinet at the desired
height.
2.
Slide the shelf into place.
3.
Repeat for the remaining shelves.
4.
Place the floor guards on the floor of the cabinet, ensuring the flat side
is clear of the floor.
Note: This is vital for ensuring correct drainage of condensation.
Operation
Product Description
Storing Food
G596-A - POLAR 282 litre 2 Door Counter Refrigerator
To get the best results from your POLAR appliance, follow these instructions:
G597-A - POLAR 417 litre 3 Door Counter Refrigerator
•
Only store foodstuffs in the appliance when it has reached the correct
operating temperature.
•
Do not place uncovered hot food or liquid inside the appliance.
•
Wrap or cover food where possible.
G622-A - POLAR 368 litre 3 Door Counter Refrigerator
U636-A - POLAR 240 litre 2 Door Counter Refrigerator
Introduction
Please take a few moments to carefully read through this manual. Correct
maintenance and operation of this machine will provide the best possible
performance from your POLAR product.
Pack Contents
•
Do not obstruct the fans inside the appliance.
•
Avoid opening the doors for prolonged periods of time.
Turn On
1.
Close the doors/drawers of the appliance.
2.
Ensure the power switch is set to [O] and turn on at the socket.
3.
Switch on the Power [I]. The current temperature within the appliance
is displayed.
The following is included:
•
POLAR Refrigerator
•
Instruction manual
•
Shelf guides (2 per door)
•
•
Shelves (1 per door)
Floor guards G622-A x 4,
U636-A x 3 only)
Control Panel
DEFROST LED COMPRESSOR LED
POLAR prides itself on quality and service, ensuring that at the time of
packaging the contents are supplied fully functional and free of damage.
UP button
DOWN button
Should you find any damage as a result of transit, please contact your POLAR
dealer immediately.
SET button
FANS ENABLED LED (G596-A/G597-A only)
.
1
DEFROST button
Telephone Helpline: 1300225960
To See the Setpoint
Push and immediately relese the SET key: the display will show the Setpoint value
Changing the Setpoint
1) Push the SET key for more than 2 seconds to change the Setpoint value
2) The value of the set point will be displayed and the COMPRESSOR LED starts blinking
3) To change the Set value push the UP and DOWN buttons within 10 seconds
4) To store the new Setpoint push the SET key or wait 10 seconds
Manual Defrost
The appliance will automatically run a defrost cycle every six hours.
Note: The cycle starts from the time the appliance is initially powered up.
To manually defrost the appliance:
1.
Press and hold the DEFROST button for more then 2 seconds.
2.
The defrost cycle will start immediately and the Defrost LED illuminates. .
Note: Starting a manual defrost also resets the automatic defrost timer.
3.
The next automatic defrost will start six hours after the manual defrost has finished.
Cleaning, Care & Maintenance
•
Switch off and disconnect from the power supply before cleaning.
•
Clean the interior of the appliance as often as possible.
•
Do not use abrasive cleaning agents. These can leave harmful residues.
•
Clean the door seal with water only.
•
Always wipe dry after cleaning.
•
Do not allow water used in cleaning to run through the drain hole into the evaporation pan.
•
Take care when cleaning the rear of the appliance. Sharp edges can cut.
•
A POLAR agent or qualified technician must carry out repairs, if required.
Cleaning the Condenser
Periodically cleaning the condenser can extend the life of the appliance.
POLAR recommend that a POLAR agent or qualified technician clean the condenser.
2
Troubleshooting
If your POLAR appliance develops a fault, please check the following table before making a call to the Helpline or your POLAR retailer.
Fault
The appliance is not working
The appliance turns on, but
the temperature is too high/
low
The appliance is leaking
water
Probable Cause
Action
The unit is not switched on
Check the unit is plugged in correctly and switched on
Plug and lead are damaged
Call POLAR agent or qualified Technician
Fuse in the plug has blown
Replace the fuse
Power supply
Check power supply
Internal wiring fault
Call POLAR agent or qualified Technician
Too much ice on the evaporator
Defrost the appliance
Condenser blocked with dust
Clean condenser with the hose attachement of a vacuum
Doors are not shut properly
Check doors are shut and seals are not damaged
Appliance is located near a heat source or air
flow to the condenser is being interrupted
Move the refrigerator to a more suitable location
Ambient temperature is too high
Increase ventilation or move appliance to a cooler position
Unsuitable foodstuffs are being stored in the
appliance
Remove any excessive hot foodstuffs or blockages to the fan
Appliance is overloaded
Reduce the amount of food stored in the appliance
The appliance is not properly levelled
Adjust the screw feet to level the appliance (if applicable)
The discharge outlet is blocked
Clear the discharge outlet
Movement of water to the drain is obstructed Clear the floor of the appliance (if applicable)
The water container is damaged
The appliance is unusually
loud
Call POLAR agent or qualified Technician
The drip tray is full
Empty the drip tray (if applicable)
Loose nut/screw
Check and tighten all nuts and screws
The appliance has not been installed in a
level or stable position
Check installation position and change if necessary
Technical Specifications
Model
Voltage
Power
Current
Temperature
Range
Capacity
(litres)
Refrigerant
Dimensions
H x W x D (mm)
Weight
(Kg)
G596-A
220-240V 50Hz
350W
1.95A
-2°C to 10°C
282
R134a 230g
850 x 1360 x 700
98
G597-A
220-240V 50Hz
350W
1.95A
-2°C to 10°C
417
R134a 230g
850 x 1790 x 700
134
U636-A
220-240V 50Hz
230W
1.5A
-2°C to 10°C
240
R134a 165g
880 x 900 x 700
72
G622-A
220-240V 50Hz
230W
1.6A
2°C to 10°C
368
R134a 260g
850 x 1365 x 700
110
Electrical Wiring
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
•
Live wire (coloured brown) to terminal marked L
•
Neutral wire (coloured blue) to terminal marked N
•
Earth wire (coloured green/yellow) to terminal marked E
All POLAR appliances must be earthed, using a dedicated earthing circuit.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency disconnection being required they must be readily accessible.
3
Telephone Helpline: 1300225960
Disposal
EU regulations require refrigeration product to be disposed of by specialist companies who remove or recycle all gasses, metal and plastic
components.
Consult your local waste collection authority regarding disposal of your appliance. Local authorities are not obliged to dispose of
commercial refrigeration equipment but may be able to offer advice on how to dispose of the equipment locally.
Alternatively call the POLAR helpline for details of national disposal companies within the EU.
Compliance
The WEEE logo on this product or its documentation indicates that the product must not be disposed of as household waste. To help
prevent possible harm to human health and/or the environment, the product must be disposed of in an approved and environmentally
safe recycling process. For further information on how to dispose of this product correctly, contact the product supplier, or the local
authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory standards and specifications set by
international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or
otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to change specifications without notice.
4
DECLARATION OF CONFORMITY
Equipment Type
Refrigerator / Freezer
Model
G596-A G597-A G622-A U636-A
Legislation
C-Tick
AS/NZ 3820 Essential Safety Requirements for Low Voltage Electrical
Equipment
Standards
EN 55014-1:2006, EN 55014-2:1997+A1
EN 61000-3-2:2006,
EN 61000-3-3:1995+A1+A2,
EN 61000-3-11:2000,
EN 55015:2006, EN 61547:1995+A1
AS/NZS 60335.2.89:2002+A1:2003+A2:2005+A3:2007 with: AS/NZS
60335.1:2002+A1:2004+A2:2007+A3:2007
Producer Name
POLAR
Producer Address
15 Badgally Road,
Campbelltown,
NSW 2560
I, the undersigned, hereby declare that the equipment specified above conforms to the above Legislation and Standard(s).
Date
24/03/11
Signature
Full Name
Richard Cromwell
Position
Marketing Director
•
Notes
•
•
Note
•
Remarques
•
Notas
Noteringar
•
Merknader
•
Opmerkingen
•
•
Anmerkungen
Bemærkninger
•
•
Notas
Huomautukset
•
•
G596-A_G597-A_G622-A_G636-A__A4_v2
