Computer Music Products Guide 2009 Vol.2
MUSIC PRODUCTION SYSTEMS
MUSIC SOFTWARE
AUDIO AND MIDI INTERFACES
Computer Music Products Guide
2009
MIDI KEYBOARD CONTROLLERS
FIELD RECORDERS
Vol.2
MIXERS
MICRO MONITORS
SYSTEM SOLUTIONS
Made for Musicians By Musicians
Cakewalk & EDIROL® Computer Music Products
These products are created by musicians
who listen, understand, and respond to
the needs of our customers, who include
award-winning producers, engineers,
composers, and musicians.
Our mission is to inspire your creativity
through the combination of superior
sound quality, industr y-leading technology,
and unmatched ease of use.
There are Cakewalk and EDIROL products
that are right for you at ever y stage of
your musical career and ability.
Read on to learn more...
MUSIC PRODUCTION SYSTEMS
04
MUSIC SOFTWARE
08
AUDIO AND MIDI INTERFACES
12
MIDI KEYBOARD CONTROLLERS
16
FIELD RECORDERS
18
MIXERS
20
MICRO MONITORS
21
SYSTEM SOLUTIONS
22
MUSIC PRODUCTION SYSTEMS
WDM
for Microsoft®Windows Vista®/
Windows®XP
AUDIO
19 in/24 out
AUDIO
24- bit /192 kHz
Windows®
Windows®
MIDI
1 in/1 out
The Ultimate Solution for Music Production
Introducing the next generation V-STUDIO, the SONAR
V-STUDIO 700 provides the ultimate solution for creative
music production through a complete offering of finelytuned and tightly-integrated hardware and software.
Roland® Fantom VS
Hardware Synthesizer
VS-700R V-STUDIO I/O
It’s your music. Take Control.
VS-700C V-STUDIO Console
SONAR 8 Producer
+
Rapture
The ultimate solution for music production
Cakewalk and Roland selected only the very best components in designing
SONAR V-STUDIO 700. At the heart of the system is SONAR 8 Producer, the
leading DAW in the market today. SONAR 8 Producer gives you everything you
need for recording, composing, editing, mixing, and mastering. Cakewalk’s flagship
instruments, Dimension Pro (included in SONAR 8 Producer) and Rapture, are also
part of the software package.
The software is intelligently matched with state-of-the-art hardware that meets
Roland’s high standards of quality and reliability. It includes the VS-700C V-STUDIO
Console multifunction control surface and VS-700R V-STUDIO 18/24 I/O audio
interface which has an integrated Roland Fantom VS hardware synthesizer based
on the world-renowned Fantom synthesizer.
Taken as a whole, SONAR V-STUDIO 700 offers the “tactile feel” of working
in a traditional studio, but in a way that takes advantage of everything modern
technology has to offer. The system represents the best that software and hardware
have to offer with amazing control, integration, and sound quality.
04
visit us online at http://www.sonarvstudio.com/
VS-700R V-STUDIO I/O
VS-700C V-STUDIO Console
High-speed USB 2.0 audio interface that provides all the recording and routing
The VS-700C Console offers broader ranging control and deeper editing and
capabilities needed to handle any music production task. It also includes an
mixing functionality for SONAR than any control surface on the market today.
onboard hardware synthesizer.
• Extensive control of editing and mixing in SONAR
• 20/26 (18/24 simultaneous) audio interface
• 2x13 LCD Display
• Superior 24-bit/192kHz A/D converters for high-definition audio recording with
flawless sound quality
• 9 Motorized Touch Sensitive Faders
• Features the same digitally controlled mic preamps found in the Roland
V-Mixer M-400
• EQ/Send/ACT Section
• Integrated Roland Fantom VS Hardware Synthesizer stocked with over
1,400 sounds
• 99 Lighted Buttons
• One ARX expansion board slot for adding additional Roland
SuperNATURAL® sounds
• Per-channel LED Meters
• 20 Rotary Encoders/Switches
• Full Transport Control
• Jog/Shuttle/Cursor
• Seven Segment Time Display
• Audio Monitor Controls
VS-700R Front / Rear View
• Dual Headphone Output
• T-Bar, Surround Joystick
• DV-7 / V-LINK Compatible
VS-700C
Roland Fantom VS Hardware Synthesizer
The world-renowned Fantom VS Hardware Synthesizer is included inside the VS700R and loads inside of SONAR as a hardware VSTi. And the VS-700R comes
with an ARX expansion slot so you can add any ARX board, supplying a dedicated
DSP-powered sound engine for Drums, Electric Pianos, or Brass.
• Integrated Roland Fantom VS hardware synthesizer
• Stocked with over 1,400 patches from world renowned Fantom Synth
• Hardware synth offers low latency and low-CPU performance
• VSTi plug-in, synth editor, and routing within SONAR for seamless integration
of Fantom VS into your creative workflow
• Expandable via SuperNATURAL
expansion board (ARX) slot found in VS700R V-STUDIO I/O
SONAR 8 Producer
SONAR 8 Producer digital audio workstation is critically-acclaimed for its music
creation features and industry leading 64-bit audio engine.
• Complete solution—from creation to delivery
• Edit and manipulate sounds inside of
SONAR with the Fantom VS and ARX Editor
• Best audio quality in industry—64-bit end-to-end processing
• Inspiring tools for creative production
• Double synth capability with additional
VS-700R V-STUDIO I/O (available separately)
• Fast and accurate audio & MIDI editing
■FANTOM VS EDITOR
• 49 effects/15 instruments including Dimension Pro and the full version of Rapture
Additional Sounds with ARX Series
The ARX series Expansion Board is powered by Roland’s proprietary
SuperNATURAL sound technology for organic, emotional expression.
Optimized effects and custom graphic interfaces are exclusive to the ARX
series. The ARX Series allows you to create and perform unique instrument
parts with the highest quality sounds and organic control.
ARX-01 DRUMS
ARX-02 ELECTRIC PIANO
ARX-03 BRASS
■SONAR 8 Producer
■Rapture
SONAR 8 can be updated to SONAR 8.5.
Visit www.cakewalk.com for details.
Visit www.sonarvstudio.com for more information.
05
MUSIC PRODUCTION SYSTEMS
for Microsoft®Windows Vista®/
Windows®XP
WDM
Windows®
Windows®
AUDIO
8 in/6 out
AUDIO
24- bit /96 kHz
MIDI
1 in/1 out
Portable Music Production Studio for Windows and Mac
SONAR V-STUDIO 100 is the
portable music production studio
that lets you create, record,
produce, and perform music with
or without a computer. For Mac
and Windows.
SONAR VS
(Win)
VS Production Pack
(Mac/Win)
SONAR V-STUDIO 100 Hardware
06
It’s your music. Take Control.
With your computer:
Away from your computer:
Audio Interface + DAW Controller
SD Recorder + Digital Mixer
Take control of your music production using the SONAR V-STUDIO 100 as a high-quality
Record directly to SONAR V-STUDIO 100’s SD-card wherever or whenever inspiration
audio and MIDI interface and DAW controller. Connect to a Mac or Windows and use
strikes–without the need to boot up your computer. Take the SONAR V-STUDIO 100
your favorite software such as SONAR, Logic, Live, Cubase, or the included SONAR VS
to your live gigs and use its digital mixer, reverb, compression, and EQ to mix vocals
digital audio workstation (Windows Only).
and other instruments.
visit us online at http://www.sonarvstudio.com/
High Quality USB 2.0 Audio Interface
• 8 in + mix / 6 out, 24-bit/96kHz quality
• 2 mic pre-amps w./phantom power, Hi-Z guitar input; MIDI I/O
• ASIO, WDM, Core Audio support
• Compatible with DAWs such as SONAR, Logic, Live, and Cubase
VS Production Pack
A phenomenal collection of effects and
virtual instruments (Mac/Win)
Take your music to the next level with the VS Production Pack
■VX-64 Vocal Strip
Universal DAW Controller
• Use with any DAW through Mackie Control
• 100 mm motorized, touch-sensitive fader
• 5 rotary encoders, 11 buttons, and transport control
• Advanced control of SONAR through Active Controller Technology
■Studio Instruments
Personal Digital Mixer
■Boost 11
• Ideal for mixing small bands, solo musicians, DJs, home studios
■Native Instruments Guitar Rig LE
• 8 inputs / 2 outputs, plus headphones
• 4 types of reverb and 6 channels of EQ and compression
Mobile SD Recorder
■Channel Tools
• Record away from your computer
• 2 channel wave recording and playback
• Built-in metronome
■Rapture LE
• Capture rehearsals and live performances
or play along to backing tracks
• Easily transfer audio to and from any
computer via USB
■Dimension LE
SONAR V-STUDIO 100 Hardware
SONAR VS
Powerful Digital Audio Workstation based on
the award winning SONAR Producer (Win)
Everything you need to get started recording, editing, and mixing music
and audio (Win)
■Track View
■Console View
Front Panel
Rear Panel
Visit www.sonarvstudio.com for more information.
07
MUSIC SOFTWARE
for Microsoft®Windows 7TM
Windows Vista®/ Windows®XP
The Leading Choice in Professional
Recording Software for the PC
■Dynamic Console View
■Track View
The Leading Choice in Digital Audio Workstations
SONAR 8.5 gives you what you need for recording, composing, editing, mixing,
■Matrix View
and mastering. Get innovations that matter, from exclusive features to ignite
creativity and perfect your tracks, to groundbreaking technologies that always
keep you in control, all backed by the industry’s leading 64-bit audio quality. And
SONAR 8.5 delivers the go-to production tools you want with the best collection
of virtual instruments, mixing, and mastering effects found in any DAW.
With unlimited tracks, amazing creative tools, incredible virtual instruments,
the freedom to work with any audio interface or control surface, and the most
complete delivery capability for collaboration with users of other DAWs, awardwinning SONAR is your best choice in a digital audio workstation.
■Step Sequencer 2.0
■VX-64 Vocal Strip
New in SONAR 8.5 Producer
■PX-64 Percussion Strip
• Session Drummer 3 with radio ready kits & patterns from top sound designers &
drummers • PX-64 Percussion Strip: 7-stage multi-effect for superior Drum Sounds
• VX-64 Vocal Strip: multi-effect for sculpting incredible vocal tracks • AudioSnap
2.0: optimized audio time & feel manipulation—now easier than ever
• Matrix: non-linear arrangement, remixing, & live performance of audio & MIDI
• Per-track Arpeggiator: real-time note & automation arpeggiation • Step Sequencer
2.0: easy creation of MIDI patterns, riffs, and lines • Ready for Windows 7: support
for 32- and 64-bit versions of Microsoft’s latest OS • And Much More…
■TL-64 Tube Leveler
■TS-64 Transient Shaper
SONAR 8.5 Producer Exclusives
SONAR 8.5 Producer includes everything in SONAR 8.5 Studio plus exclusive
tools, effects, and instruments
TM
■Dimension Pro
• LP-64 Linear Phase EQ for mastering • LP-64 Linear Phase Multiband
Compressor for mastering • VX-64 Vocal Strip • PX-64 Percussion Strip
• TL-64 Tube LevelerTM • TS-64 Transient Shaper • VC-64 Vintage ChannelTM
with sidechaining capabilities • Matrix view • Session Drummer 3 • Native
Instruments Guitar Rig 3 LE • Perfect SpaceTM Convolution Reverb • Lexicon ®
PantheonTM Reverb • Sonitus Surround Compressor • Dimension ProTM 1.2
instrument with Classic Keys Expansion Pack • TruePianos Amber VSTi
• BeatscapeTM looping instrument • Hollywood Edge Sound FX library for
Dimension Pro • ZETA+TM 1.5 waveshaping synthesizer • Surround mixing in
over 30 formats • SurroundBridgeTM technology to use stereo FX in surround
• POW-r dithering
08
■Beatscape
■Native Instruments Guitar Rig 3 LE
TM
■True Pianos Amber
■Channel Tools
visit us online at http://www.cakewalk.com/
for Microsoft®Windows Vista®/
Windows®XP
The easiest way to turn your PC into a
full-fledged music production studio.
■Console View
SONAR Home Studio 7
■Track View
SONAR Home Studio 7 is the easiest way to turn your PC into a full-fledged
music production studio. From start to finish, SONAR Home Studio will help you
capture your creativity and share it with the world. With SONAR Home Studio
you can record live instruments, vocals, or any audio source. You can easily edit
audio, MIDI, and music notation. The updated Loop Explorer gives you the tools
to build backing tracks faster than ever. Add real instrument sounds using the
included virtual instruments suite. Bring your mix together with studio-quality
audio effects and professional mixing tools. When you are finished, share your
music on the web or burn it to CD for fans, friends, and family. SONAR Home
Studio is the complete solution for creating and sharing professional quality
music—now easier than ever.
■Drop Zone
■Square I
SONAR Home Studio 7 is perfect for
• Bands who want to produce their own album
• Singer-songwriters who want high-quality versions of their songs
• MCs who need beats and an easy tool for recording
• Aspiring producers and engineers getting started with recording
• Educators who need to create accompaniment and lead sheets
• Video editors and podcasters who are looking to create their own soundtracks
• Anyone who dreams of having their own multitrack recording studio
XL Exclusives
SONAR Home Studio 7 XL
■Studio Devil VGA+
■Boost 11TM
■Studio Instruments
■DimensionTM LE
SONAR Home Studio 7 XL adds more value by giving you additional tools to
take your productions to the next level.
• Boost 11 Peak Limiter—Get maximum volume and punch from your final mix
• Dimension LE—Access over 400 amazing sounds
• Garritan Pocket Orchestra—Expand Dimension LE with leading orchestral
sounds from Garritan
• Step Sequencer—Easily create beats, synths parts, and more
• Studio Instruments—Your built-in backing band: Drums, Bass Guitar, Electric
Piano, and Strings
• Studio Devil VGA+—Plug in your guitar or bass and get inspiring tones
09
MUSIC SOFTWARE
for Microsoft®Windows Vista®/
Windows®XP
AMAZING SOUNDS. ENDLESS POSSIBILITIES.
Amazing Sounds. Endless Possibilities.
Dimension Pro is the critically-acclaimed synthesizer that combines real instruments with
advanced synthesis, giving you endless sound possibilities. The immense DVD sound
library that ships with Dimension Pro makes it the ideal go-to instrument for musicians,
while its deep editing and sound generation capabilities have a natural appeal to sound
designers.
for Microsoft®Windows Vista®/
Windows®XP
SYNTHESIS IGNITED
Synthesis Ignited.
Combining power, elegance, control, and unbeatable sounds, Rapture is one of the most
exciting synthesizers to hit the market in years. Capable of producing rich, hypnotic, and
rhythmic basses, leads, and pads, Rapture is perfect for performing and designing the
modern synthesized sounds igniting today’s pop, dance, and electronic music.
for Microsoft®Windows Vista®/
Windows®XP/2000
WAVESHAPING SYNTHESIZER
Legendary Waveshaping Synthesizer
Award-winning analog-style synthesizer with incredible sound shaping capabilities. The
exclusive bandlimited Waveshaping technology makes ZETA+ one the best and most
respected synths in the industry. ZETA+ is among the most expressive and inspiring
virtual instruments available today, capable of producing the most authentic vintage
analog sounds and incredible, cutting edge modern sounds.
for Microsoft®Windows Vista®/
Windows®XP
An Entire Band at Your Fingertips
An Entire Band at Your Fingertips
The world's first easy-to-use and affordable software instrument collection for Mac and
PC. Cakewalk Studio Instruments includes a high quality Drum Kit, Bass Guitar, Electric
Piano, and String Section that can be played stand alone or inside your favorite musicmaking software.
10
visit us online at http://www.cakewalk.com/
for Microsoft®Windows Vista®/
Windows®XP
V ER S ION 4
THE RECORDING SOFTWARE DESIGNED FOR GUITARISTS
Designed for guitarists and singer-songwriters
With Guitar Tracks Pro you get much more than just recording software. You get an
amazing virtual guitar amp for inspired, arena ready tones—without disturbing the
neighbors. You also get an entire backing band of virtual instruments—always ready
to accompany you. Plus: precise editing tools to comp the perfect solo or vocal track,
a mixing console, effects arsenal, even burn CDs or upload your music directly to the
web—all for less than a few hours in the recording studio. Get it all in Guitar Tracks Pro.
Looking for a complete solution?
Check out Guitar Tracks Pro USB featuring the Cakewalk UA-1G audio interface
for Microsoft®Windows Vista®/
Windows®XP
Create your own music fast
Make your creative dreams a reality and achieve polished, professional
recordings from your home computer with Music Creator 5—no previous
recording experience required. Music Creator 5 guides you through initial set-up,
making it easy for you to plug in your instrument or microphone and immediately
start recording. Get professional sounding results using Music Creator’s
powerful tools, instruments, and effects. Creating music on your PC has never
been this easy, fun, or affordable.
for Microsoft®Windows Vista®/
Windows®XP
Essential Tools for Your Music:
Record & Edit, MP3s, LPs, CDs, DVDs, & more
With Audio Creator's virtual toolbox, you are just a click away from recording and
editing audio; burning and ripping CDs; cleaning and converting albums to CD or
MP3; encoding, tagging, and organizing your sound library; backing up your files
to data CD, DVD, or Blu-Ray; and even publishing music to the Internet.
Produce Your Own Beats
Kinetic doesn't just sound good, it makes musical creativity accessible to anyone.
Just choose a hip hop or electronic style, then build your track with hundreds
of professional sounds, patterns, and loops. Tap out your own rhythm with your
computer keyboard and the GRID. Edit patterns and sounds with Kinetic’s part editor.
Bring in your own samples. Mix it down. Kinetic gives you everything you need.
11
AUDIO INTERFACE MIDI INTERFACES
for Microsoft®Windows Vista®/
Windows®XP
USB Audio Capture
UA-1G
for Mac OS
WDM
Windows®
Windows®
AUDIO
1 in/1 out
(STEREO)
USB
AUDIO
24- bit /96 kHz
Stylish, sleek, and easy-to-use, the portable UA-1G
allows musicians and hobbyists to record and
playback high quality audio on their computers.
The UA-1G is a compact USB Audio Interface that
offers excellent-quality sound via multiple connection
options and a simple, user-friendly design.
Highlights include
Perfect for
• Stereo input and output at 24-bit/96kHz audio quality
• Use with a laptop in mobile or portable environments
• High-end A/D and D/A converters for accurate recording and playback
• Large Input Level knob for easy control while recording
• Connecting multiple audio sources in your home studio, rehearsal space, or
tour bus to your computer
• 1/4" jack with Hi-Z option for recording electric guitar or bass
• Recording electric guitar or bass
• Electret condenser mic input
• Recording cassette tapes or vinyl to a computer
• RCA and optical S/PDIF I/O
• Connecting your computer to your home entertainment system
• Headphone output
• USB powered—no AC adapter required
• Low-latency ASIO 2.0 (Windows); WDM (Windows) and Core Audio (Mac OS X) support
Top
• SONAR LE for music recording, editing, and publishing on PC
■SONAR LE
Sides
UA-1G •Dimensions 160(W) x 58(D) x 28(H) mm / 6-5/16(W) x 2-5/16(D) x 1-1/8(H) inches
•Weight 165 g / 6 oz •www.cakewalk.com/products/audiomidi.asp
12
visit us online at http://www.cakewalk.com/
for Microsoft®Windows Vista®/
Windows®XP
USB MIDI Interface
UM-1G
USB
FPT
for Mac OS
MIDI
1 in/1 out
A Compact, Cable-style 1-In/1-Out USB MIDI Interface
Highlights include: • 1-In/1-Out MIDI port (male), with LED indicators for MIDI
I/O signal monitoring •MIDI Check switch for quick troubleshooting of MIDI
connections • MIDI cables are engraved with "Connect to MIDI In" and "Connect
to MIDI Out" labels for no confusion when connecting devices • Perfect for
hobbyists who want to connect a MIDI keyboard to a computer, or musicians
who need MIDI connectivity to control or record music with a computer • Ideal for
small studios or academic settings where only one MIDI device will be connected
in close proximity to the computer • In live performance settings, use the UM-1G
to control a synth, drum machine, MIDI light set-up
UM-1G •Dimensions 80(W) x 41.2(D) x 20(H) mm / 3-3/16(W) x 1-5/8(D) x 13/16(H) inches
•Weight 100 g / 4 oz •www.cakewalk.com/products/audiomidi.asp
for Microsoft®Windows Vista®/
Windows®XP
USB MIDI Interface
UM-2G
USB
FPT
for Mac OS
MIDI
2 in/2 out
2-In/2-Out USB MIDI Interface Designed
For Easy Connection
Highlights include: • Features 2-In/2-Out MIDI ports (female), 32 channels of
MIDI to control hardware and software • Provides ability to connect multiple MIDI
keyboards, sound modules, control surfaces, and other devices to a computer
•Ideal for musicians, producers or recording engineers with more than one MIDI
device in a small studio or portable MIDI configuration
UM-2G •Dimensions 122.9(W) x 48(D) x 28(H) mm / 4-7/8(W) x 1-15/16(D) x 1-15/16(H) inches
•Weight 125 g / 5 oz •www.cakewalk.com/products/audiomidi.asp
for Microsoft®Windows Vista®/
Windows®XP
USB MIDI Interface
UM-3G
USB
FPT
for Mac OS
MIDI
3 in/3 out
Portable, Affordable And Expandable, 3-In/3-Out
Highlights include: • 3-In/3-Out MIDI Ports (female) •Controls up to 48 channels
of MIDI equipment • Expandable design allows you to daisy-chain up to three
UM-3G interfaces providing nine total MIDI inputs and outputs without the need
for additional USB Ports • Advanced Driver mode uses FPT (Fast Processing
Technology) to ensure low-latency, even with three UM-3G interfaces daisychained together •Up to 3 units can be rack mounted via Roland RAF-70 kit,
available separately • Ideal MIDI interface for the mid- to larger-sized studio •Out
or Thru selectable switches built-in; select between MIDI Out and MIDI Thru
Rear
for each output port •Great for live settings using multiple MIDI applications,
including traditional instruments, synths, sequencers and live sound, lighting,
and special effects
UM-3G •Dimensions 138(W) x 67(D) x 42(H) mm / 5-7/16(W) x 2-11/16(D) x 1-11/16(H) inches
•Weight 210 g / 8 oz •www.cakewalk.com/products/audiomidi.asp
13
AUDIO INTERFACES
10×10 24-bit/192kHz Hi-SPEED USB Audio Capture
UA-101
for Microsoft®Windows Vista®/
Windows®XP
WDM
Core Audio
Windows®
Mac OS X
FPT
for Mac OS
Windows®
AUDIO
10 in/10 out
AUDIO
24- bit /192 kHz
MIDI
1 in/1 out
This flagship USB audio interface packs
exceptional performance in a compact body.
Supports up to 24-bit/192kHz audio quality. 10-In/10-Out.
High-quality digital mixing with a high-speed 40-bit DSP.
Professional specs in a 1U half-rack unit, including high-speed USB 2.0 and
Comes with a built-in digital mixer and patch
24-bit/192kHz audio quality. It offers the best performance in its class with
bay. Since all mixing processes are performed
simultaneous recording/playback on 10 channels at 24-bit/96kHz.
via DSP, your PC's CPU power is not drained.
■Control Panel
High-speed and stable MIDI transmission with USB 2.0.
USB 2.0 data transfer rate is approximately 40 times faster than with the
• Mic preamps with phantom power on two channels with XLR/TRS combo
previous USB 1.1. Operation is stable and smooth, even when simultaneously
jacks. • In addition to digital (optical) in and out, and eight analog outs, the unit
recording or playing back high-
comes with a monitor output (all are TRS standard). • 1-In/1-Out MIDI interface.
• Built-in analog limiter for preventing digital clipping.
quality, multi-track audio.
■Comparison chart of data transfer speed
Rear Panel
Diverse range of utilities is available to enhance its ease of use.
Each of the analog inputs 3 to 8 (TRS standard) give you a choice of two input
levels. You can also use the MONO switch to monitor mono recordings on both
left and right outputs. Backward compatible with USB 1.1*.
* Simultaneous recording and playback on two channels at 24-bit/48kHz.
UA-101 • Dimensions 218(W) x 159(D) x 45(H) mm / 8-5/8(W) x 6-5/16(D) x 1-13/16(H) inches
• Weight 1.2kg / 2 lbs 9 oz • www.cakewalk.com/Products/audiomidi.asp
FireWire Audio Capture
FA-101
AUDIO
24- bit /192 kHz
10-In/10-Out FireWire audio interface ideally suited for
desktop applications.
• Simultaneous recording/playback on up to 10 channels at 24-bit/96kHz.
• Simultaneous I/O on up to six channels at 24-bit/192kHz. •A wide range of
Rear Panel
inputs and outputs, including XLR/TRS combo jacks with mic preamps as
well as Hi-Z and optical jacks. • Supports Mac OS X's standard CoreAudio and
CoreMIDI drivers. • FireWire bus-powered unit is ideal for mobile use. •1-In/1-Out
MIDI interface.
FA-101 • Dimensions 218(W) x 137(D) x 46.5(H) mm / 8-5/8(W) x 5-7/16(D) x 1-7/8(H) inches
• Weight 950 g / 2 lbs 2 oz • www.EDIROL.net/products/en/FA-101
14
visit us online at http://www.cakewalk.com/ http://www.EDIROL.net/
24-bit/96kHz USB Audio Capture
UA-25EX
AUDIO
1 in/1 out
AUDIO
24- bit /96 kHz
(STEREO)
This USB audio interface, a new-generation standard, is
ideal for studio and live performances.
•Simultaneous I/O on 2 channels at 24-bit/96kHz. •Two analog inputs (XLR/
TRS combo jack) with mic preamp and phantom power. • Wide range of inputs
and outputs — Hi-Z jacks for directly connecting electric guitar or bass, digital
I/O, and MIDI I/O. •Low-noise/wide-range power supply keeps your recordings
pristine even when using USB bus power. • Built-in analog compressor/limiter.
Rear Panel
•Ground lift switch for canceling ground loop noise. • Lightweight, sturdy, and
compact aluminum enclosure.
UA-25EX • Dimensions 164(W) x 133(D) x 46(H) mm / 6-1/2(W) x 5-1/4(D) x 1-13/16(H) inches
• Weight 565 g / 1 lb. 4 oz • www.cakewalk.com/Products/audiomidi.asp
24-bit/96 kHz USB Audio Capture
UA-4FX
AUDIO
1 in/1 out
(STEREO)
AUDIO
24- bit /96 kHz
Perfect for mobile recording.
• High-resolution, 24-bit/96kHz audio quality. • Comes with three effects
channels and 12 types of effects. • Features a tube-amp simulator that
reproduces the warmth of analog amps. • Wide range of connectors, including
XLR jack. •Supports USB bus power.
Rear Panel
DIGITAL IN
UA-4FX • Dimensions 171(W) x 126.8(D) x 43.6(H) mm / 6-3/4(W) x 5 (D) x 1-3/4(H) inches
• Weight 335 g / 12 oz • www.cakewalk.com/Products/audiomidi.asp
MIDI (IN,OUT)
DIGITAL OUT
LINE OUT
LINE IN
FireWire Audio Capture
FA-66
AUDIO
24- bit /192 kHz
Ultra-compact FireWire interface designed for mobile
musicians.
•High-quality performance, with simultaneous I/O on six channels at
24-bit/96kHz. •Simultaneous recording and playback on four channels at
Rear Panel
24-bit/192kHz. •Features a wide range of inputs and outputs, including two
XLR/TRS combo jacks with phantom power. • Built-in analog limiter. • Supports
FireWire bus power (6-pin <-> 6-pin connections) for music making in a variety
of environments.
FA-66 • Dimensions 164(W) x 148(D) x 44(H) mm / 6-1/2(W) x 5-7/8(D) x 1-3/4(H) inches
• Weight 650 g / 1 lbs 7 oz • www.EDIROL.net/products/en/FA-66
15
MIDI KEYBOARD CONTROLLERS MIDI SOUND MODULE
for Mac OS
MIDI Keyboard Controller
PCR-800/500/300
USB
FPT
MIDI
1 in/1 out
PCR-800
PCR-800
61 keys
PCR-500
49 keys
PCR-300
32 keys
With excellent playing feel and easy-to-use controls, these full-featured MIDI keyboard controllers are
ideally suited for the stage and the studio.
The PCR-series reflects EDIROL’s no-compromise
approach to music-instrument design.
Dynamic mapping helps you connect seamlessly with
the editing software(included).
Choose from 61, 49, or 32 key models, all of which support USB bus power.
The software recognizes the PCR
and automatically assigns the main
parameters in its active window. Fully
Features fully-assignable controllers for 50 different functions.
customize your setups quickly and
easily with the included editor software.
■PCR Editor
PCR-series controllers ensure smooth workflow. You can assign a variety of MIDI
parameters to all 50 of the physical controllers, including sliders and knobs. Use
these to control your DAW software, software synths, and MIDI instruments.
•Choose from four types (12 variations) of velocity curves. •All connection jacks are
located on the side panel for convenience and space efficiency. • USB bus-powered.
•Use without a PC via optional AC adaptor. • Features a 1-In/1-Out MIDI interface.
Express yourself without restriction, from delicate to full impact.
Comes with 18 velocity-sensitive pads to capture subtle nuances — ideal for
recording drum tracks. Sliders have a long 45mm throw, and our newly developed
•MIDI merge function merges incoming MIDI signals to the MIDI Out.
Side Panel
assignable crossfaders are a powerful addition to performances as well.
PEDAL PORTS (Hold,Expression)
High-performance velocity-sensitive keyboard with aftertouch.
Get expressive and creative with aftertouch, glissando, and real-time tone
controls that are usually reserved for high-end synthesizers.
MIDI (IN,OUT)
PCR-800 •Dimensions 1001.9(W) x 250.8(D) x 91.4(H) mm / 39-1/2(W) x 9-7/8(D) x 3-5/8(H) inches
•Weight 4.5 kg / 9 lbs 15 oz •www.EDIROL.net/products/en/PCR-800
PCR-500 •Dimensions 838.9(W) x 250.8(D) x 91.4(H) mm / 33-1/16(W) x 9-7/8(D) x 3-5/8(H) inches
•Weight 3.8 kg / 8 lbs 7 oz •www.EDIROL.net/products/en/PCR-500
PCR-300 •Dimensions 605.9(W) x 250.8(D) x 91.4(H) mm / 23-7/8(W) x 9-7/8(D) x 3-5/8(H) inches
•Weight 2.9 kg / 6 lbs 7 oz •www.EDIROL.net/products/en/PCR-300
16
visit us online at http://www.EDIROL.net/
for Mac OS
MIDI Keyboard Controller
PC-50
49 keys
MIDI
1 out
This simple model has a small footprint yet provides
excellent playability.
•Features a high-performance keyboard directly inherited from our synthesizer
products. • Choose from four types (12 variations) of velocity curves. • All
connection jacks are located on the side panel for convenience and space
efficiency. •Features a value encoder that lets you change MIDI channels and
Side Panel
programs instantly. • 3-way power supply: USB bus power, optional AC adaptor,
PEDAL PORTS (Hold,Expression)
MIDI OUT
or batteries (4 AA batteries, not included)
PC-50 •Dimensions 883(W) x 184(D) x 84(H) mm / 34-13/16(W) x 7-1/4(D) x 3-5/16(H) inches
•Weight 2.7 kg / 6 lbs •www.EDIROL.net/products/en/PC-50
for Mac OS
MIDI Keyboard Controller
PCR-M1
25 keys
USB
FPT
MIDI
1 in/1 out
Packed into a 28mm (1-1/8 inches) thick body, this MIDI
keyboard controller can be used for production as well
as for live performances.
•25 "S.L.I.M." standard-size keys. •Features touch sensitivity and press-back
bender functions to enhance your creative expression. • 27 fully assignable
physical controllers. • Easy parameter configuration with the included PCR
editor. • 1-In/1-Out MIDI interface onboard. • 3-way power supply: USB bus
power, optional AC Adaptor, or batteries (4 AAA batteries, not included)
Rear Panel
PEDAL PORTS (Hold,Expression)
Taking compactness and playability to new heights.
MIDI (IN,OUT)
Short-stroke
Low-profile
Impact
Mechanism
PCR-M1 28 mm /
1-1/8 inches
With "S.L.I.M." standard-size keys, this keyboard is
approximately half the thickness of previous Roland
keyboards, and still delivers the excellent playability that
the PCR series is known for.
Conventional MIDI
Keyboards 84-91 mm
PCR-M1 •Dimensions 450(W) x 220(D) x 28(H) mm / 17-3/4(W) x 8-11/16(D) x 1-1/8(H) inches •Weight 1.4 kg / 3 lbs 2 oz(excluding AC Adaptor) •www.EDIROL.net/products/en/PCR-M1
for Mac OS
SD-20
USB
FPT
660
Sounds
23 DRUM
Sets
64 Voice
32 Part
MIDI
1 in
High-quality tones in a compact and stylish enclosure.
•64-voice, 32-part MIDI synthesizer module. • 660 tones and 23 drum sets.
•Supports USB bus power for use on the go. •Features line and digital outputs.
Rear Panel
OUTPUT
MIDI IN
INPUT
SD-20 •Dimensions 203(W) x 159(D) x 35(H) mm / 8(W) x 6-5/16(D) x 1-7/16(H) inches
•Weight 400g / 15 oz •www.EDIROL.net/products/en/SD-20
OPTICAL OUT
17
FIELD RECORDERS
for Mac OS
24bit 96kHz WAVE/MP3 RECORDER
R-09HR
High-quality recordings on the go …
the R-09HR is a portable recorder that
fulfills the promise of easier live recording.
Built-In Stereo Mic
IARC
Equipped with high-performance
stereo microphones.
Analog circuitry provides
premium sound quality.
Limiter & AGC
Linear PCM
24bit
96kHz
Can handle widely dynamic input.
Supports high-resolution recording.
Remote Controller
PC LINK
Includes wireless remote controller.
Save and edit data easily via
PC connectivity.
USB2.0
Famous for high-quality audio and ease of use.
•Proprietary analog circuitry "IARC" converts the
Pro-quality recording performance, including 24-bit/96kHz linear PCM, is packed
•Supports recordings in MP3 format. •Features
into this lightweight, palm-sized package. High-quality audio meets ease of use.
an organic EL display for responsive displaying.
original sound into high-quality digital signals.
Along with the peak indicator, this allows you
■High-contrast OLED Display
Built-in stereo microphones capture the ambience and
nuance of surrounding environments.
to adjust levels accurately. •Frequently used
The built-in stereo microphones are suspended
monitor" lets you check what you've recorded.
Mic unit
Mics positioned
to provide
widespread stereo
imaging.
in a “floated” housing. The microphones are
isolated from the unit's circuit board and covered
120°
functions are operable via hardware controls.
Handy wireless remote also provided. •"Preview
•Supports USB 2.0. Quickly transfer data to PC
using drag-and-drop.
■Preview Speaker
with rubber damping material to eliminate
unwanted vibrations that can become a source
■Built-in stereo mic
of noise. Mic positions and angles have been
Rubber damper provides
improved protection
from vibration
optimized to achieve a more expansive stereo
field. These positions have been meticulously
Rear Panel
Right Side Panel
3. LINE IN jack
■ “Floating” microphone construction.
4. Battery compartment
4
Analog limiter and AGC (Auto Gain Control) prevent recording errors.
Achieve optimal recording levels with the built-in analog limiter (prevents digital
clipping) and AGC/Auto Gain Control (evens out the volume of the entire recording).
5. Preview Monitor
6. HOLD switch
1
5
2
3
6
7
8
9
10
11
12
13
24-bit/96kHz audio … better than CD quality.
Supports up to 24-bit/96kHz
linear PCM recording (WAVE).
Capture subtle details in the
original sound and record with
Memory Size
1GB
2GB
4GB
27
55
110
15
30
60
120
240
WAVE(24bit/48kHz)
27
54
110
220
440
WAVE(24bit/44.1kHz)
29
59
120
240
480
pristine, realistic quality. Your
20
40
80
160
320
WAVE(16bit/88.2kHz)
22
44
88
176
352
recordings are stored on an SD/
WAVE(16bit/48kHz)
44
88
180
360
720
SDHC memory card so there is
MP3 320kbps
196
392
797
1,540
3,080
MP3 128kbps
490
980
1,993
3,990
7,980
40
81
9. LOW CUT switch
10. MIC GAIN switch
11. (+) and (-) VOLUME
buttons
166
332
14. Optical receiving port
for the remote control
8GB
220
WAVE(24bit/88.2kHz)
WAVE(16bit/44.1kHz)
8. PLUG-IN POWER switch
13. AC ADAPTOR jack
Slot
Top
WAVE(16bit/96kHz)
no mechanical noise.
18
WAVE(24bit/96kHz)
512MB
13
7. LIMITER/AGC (Auto
Gain Control) Switch
12. POWER switch
■Recording time(unit: minutes)
Data Format
1. (+) and (-) INPUT
LEVEL buttons
2. MIC INPUT jack
Mic-chassis
designed and tested to achieve the most
impressive and realistic sound field.
Left Side Panel
15. Remote indicator
16. HEADPHONE jack
17. USB terminal
14 15
16
17
18
18. SD/SDHC
memory card slot
664
*Times for recording are ideal values. Absolute time may vary due to card specifications, etc.
*The total recording time will decrease depending on the number of files recorded.
*Use memory cards that have been formatted for the R-09HR.
R-09HR •Dimensions 62.0(W) x 112.9(D) x 27(H) mm / 2-1/2(W) x 4-1/2(D) x 1-1/6(H) inches
•Weight 174g / 7 oz(including batteries and memory card)
•www.EDIROL.net/products/en/R-09HR
visit us online at http://www.EDIROL.net/
for Mac OS
4 Channel Portable Recorder
R-44
Capture high-quality, multi-channel field recordings with ease.
•Four XLR/TRS combo jacks with phantom power and high-quality mic preamps.
Ideal for a variety of applications, including live recordings. •24-bit/192kHz audio
quality when recording on two channels. •Uses an SD memory card (supports
SDHC cards). •Features high-sensitivity stereo microphones and monitor
speakers. •Limiters and low-cut filters provided for all channels. Also features an
extensive range of DSP effects. •Never miss a recording opportunity with the prerecording function. •Connect two units for eight-channel recording. •Excellent cost
performance.
This model is equipped with a hard drive for
longer recording times.
Side Panel
This pro model supports SMPTE timecode
and AES/EBU digital I/O.
4 Channel Portable Recorder and Wave Editor
R-4 Pro
Basic model with 40GB hard drive.
4 Channel Portable Recorder and Wave Editor
R-4
R-44 •Dimensions •157(W) x 183(D) x 61(H) mm / 6-3/16(W) x 7-1/4(D) x 2-7/16(H) inches
•Weight 1.3kg / 2 lbs 14 oz(including batteries)•www.EDIROL.net/products/en/R-44/
Extensive options to expand your recording possibilities.
Cover/Stand Set for R-09HR
Carrying Pouch
Silicone Rubber Case for R-09HR
OP-R09HR-C
OP-R09HR-P
OP-R09HR-S
For R-09HR
For R-09HR
For R-09HR
Optional custom
This silicon case fits snugly
This custom pouch is
cover and tripod for
onto the unit and protects from
cushion-lined to absorb impact.
R-09HR.
scratches and dust.
Microphone Stand Adaptor
Microphone Stand
OP-R09M
ST-100MB
For R-09HR
For R-09HR
Stereo Microphone
CS-15
For R-09HR
Carrying Case
CB-R09S
For R-09HR
Wind Shield
OP-R09HR-W
For R-09HR
* OP-R09HR-C required to attach
OP-R09HR-W to R-09HR.
In-Ear Headphones
* For hands-free operation, the optional OP-R09HR-C
(OP-R09C) and OP-R09M are ideal accessories. The OPR09HR-C allows the recorder to be mounted on a standard
mic stand, while the OP-R09M adds angle adjustability.
RH-ED1
* Mic stand sold separately.
Stereo microphone with support for
Custom carrying case for the
Microphone stand gives you ample latitude in your settings.
This microphone stand adaptor allows you to
plug-in power — ideal for external
R-09HR, with space for cables and
Special carrying pouch included.
attach the R-09HR to a generic mic stand.
use with the R-09HR.
spare batteries.
Carrying Bag for R-44
CB-R44
For R-44
Semi Hard Case for R-4
SHC-R4
For R-4 Pro/4
Stereo Microphone
CS-50
For R-44/4 Pro/4
Stereo Headphones
RH-300
For R-09HR
In-Ear Headphones
RH-iE3
For R-09HR
For R-09HR
For R-44/4 Pro/4
For R-44/4 Pro/4
Ideal for field recording with the R-44, 4, and 4 Pro.
19
MIXERS MICRO MONITORS
24-bit / 96kHz 16 Channel Digital Mixer
M-16DX
AUDIO
24- bit /96 kHz
This 3-in-1 unit is a mixer, audio interface,
and physical controller
a powerful tool for
PC-based music production.
A digital audio mixer you can use like an analog mixer.
■Incorporates the separate-module concept to expand your
configuration choices.
Controller
M-16DX is packed with state-of-the-art digital technology, including 24-bit/96kHz
high-quality digital processing, plus dedicated controls for level, EQ, pan, and
AUX on each channel. For intuitive control, the user interface offers the ease and
Rear Panel
familiarity of an analog mixer.
I/O Module
•Incorporates the separate-module concept, with all cables connected to the I/O
module. •Provides 16-channel input, with dedicated 3-band EQ for each channel.
•Four high-quality mic preamps with phantom power. •Hi-Z and digital inputs
(optical and coax) also included. •Features 12 built-in effects for a broad range of
Front Panel
applications. •Room Acoustic Auto Control function automatically compensates
for the frequency characteristics in your home studio or other environments.
•Large backlit LCD. •With a USB 2.0 jack, the M-16DX also functions as an audio
interface when connected to a PC.
Rear Panel
M-16DX Mix Controller • Dimensions 311(W) x 215.9(D) x 45.9(H) mm / 12- 1/4(W) x 8-1/2(D) x 1-13/16(H) inches • Weight 1.2kg / 2lbs 11 oz • www.EDIROL.net/products/en/M-16DX
M-16DX I/O Module • Dimensions 280(W) x 219(D) x 44(H) mm / 11-1/16(W) x 8-5/8(D) x1-3/4(H) inches • Weight 1.6kg / 3 lbs 9 oz • www.EDIROL.net/products/en/M-16DX
24bit / 96kHz 10 Channel Digital Mixer
10 Channel Mixer
M-10DX
M-10MX
10-channel digital mixer
with a compact body and
high-quality features.
10-channel analog
mixer that’s compact
and portable.
•Packed with features inherited
•10-channel (five-stereo) analog
from M-16DX, including
mixing. •Compact body is ideal
24-bit/96kHz digital processing.
for use on the go. •A variety
•Excellent cost performance with
of connectors, including RCA,
standard, and stereo mini. •Two-
high-quality specs. •Two-way
Rear Panel
power supply: AC adaptor or
batteries (eight AA batteries)
M-10DX • Dimensions 98.6(W) x 262.2(D) x 60.9(H) mm / 7- 7/8(W) x 10-3/8(D) x 2-7/16(H)
inches • Weight 1.3kg / 2lbs 14 oz • www.EDIROL.net/products/en/M-10DX
20
Rear Panel
way power supply: AC adaptor or
batteries (four AA batteries)
M-10MX • Dimensions 181.2(W) x 107.5(D) x 54(H) mm / 7-3/16(W) x 4-1/4(D) x 2-1/8(H)
inches • Weight 393g / 14 oz • www.EDIROL.net/products/en/M-10MX
visit us online at http://www.cakewalk.com/ http://www.EDIROL.net/
Digital Stereo Micro Monitors With Bass Enhancer
MA-15DBK
Choose your colors.
The new blue model is an
eye-catching favorite.
Digital Stereo Micro Monitor
MA-15D
Professional desktop monitor supports
24-bit/192kHz digital inputs.
•Wooden cabinet provides excellent acoustic characteristics. •Features bassenhancer technology to deliver clear, ultra-low bass tones. •High-quality, shielded
design with magnetically shielded power transformer and canceling magnet.
•Two-way bass reflex enclosure with power to spare — a total output of 30W
(15W+15W). •Features a 10cm woofer with PP cone for rich bass tones. •5cm
dome tweeters reproduce natural highs with no excessive coloration. •Digital input
supports up to 24-bit/192kHz audio quality. •Bass and treble controls, as well as
independent level knobs.
Control Panel
Rear Panel
MA-15DBK/MA-15D • Dimensions <L> 159(W) x 215(D) x 250(H) mm / 6-5/16 (W) x 8-1/2(D)
x 9-7/8(H) inches <R> 159(W) x 222(D) x 250(H) mm / 6-5/16 (W)
x 8-3/4(D) x 9-7/8(H) inches • Weight <R> 5kg / 11 lbs 1 oz <L> 2.5kg / 5
lbs 9 oz • www.cakewalk.com/Products/monitors.as p
Stereo Micro Monitors With Bass Enhancer
MA-7ABK
Choose your colors.
The new blue model is an
eye-catching favorite.
Stereo Micro Monitor
MA-7A
Dynamic sound reproduction in a space-saving design.
•Wooden cabinet is stylish and provides excellent acoustic characteristics.
•Larger than life — the bass enhancer technology delivers ultra-low, clear
bass tones. •High-quality, shielded design with magnetically shielded
power transformer and canceling magnet. •Full-range bass reflex monitors
provide a total output of 14W (7W+7W). •Curved cones for balanced sound
reproduction. •Front input jacks are convenient for connecting digital-audio
players. •Dedicated bass and treble EQ knobs.
Control Panel
Rear Panel
MA-7ABK/MA-7A • Dimensions <L> 145(W) x 194.2(D) x 215(H) mm / 5-3/4 (W) x 7-7/16(D) x
8-1/2(H) inches <R> 145(W) x 187.6(D) x 215(H) mm / 5-3/4 (W) x
7-11/16(D) x 8-1/2(H) inches • Weight <R> 3.3 kg / 7 lbs 5 oz <L> 1.8kg / 4
lbs • www.cakewalk.com/Products/monitors.asp
USB Speaker
MA-1EX
USB
MA-1EX • Dimensions <L> 88(W) x 57.5(D) x
130(H) mm / 3-1/2 (W) x 2-5/16(D) x
5-1/8(H) inches <R> 88(W) x 53.5(D) x
130(H) mm / 3-1/2 (W) x 2-1/8(D) x
5-1/8(H) inches
• Weight <Total Weight> 0.5 kg / 1 lbs 2oz
• www.EDIROL.net/products/en/MA-1EX
Carry it wherever you go; it’s the perfect companion
for your laptop. These compact USB speakers deliver
excellent sound quality.
•Enjoy pristine, digitally processed playback via USB without the internal noise
from your PC. •Equipped with specially designed 6cm full-range speakers. •Bassenhancer technology produces ultra-low bass tones that defy the speakers' size.
•Front panel is equipped with digital out and headphone jacks, as well as a volume
control. •Operates on standard OS drivers. •Supports USB bus power.
21
SYSTEM SOLUTIONS
SONAR V-STUDIO 700 Integrates Your Productions
Live Recording
REAC
Post Production
®
Video Control
Roland’s unique REAC
technology allows 40
channels of simultaneous
live recording. Use
SONAR V-STUDIO 700 to
mix, edit, master, and
deliver these projects
Audio for video projects
including surround mixing,
foley, ADR, and scoring
DIGITAL VIDEO
WORKSTATION
DV-7DL Series
REAL TIME VIDEO
PRESENTER
PR-80/50
Performance
V-LINK
Music production for visual
performances
(VJ, presentations, etc.)
VISUAL SAMPLER
VISUAL SYNTHESIZER
P-10
SONAR REAC Recording System
CG-8
Live Recording
REAC (Roland Ethernet Audio Communication) is Roland’s original
technology for low latency, highquality digital audio transfer. REAC
technology provides many system advantages.
LIVE MIXING CONSOLE
Digital Snake Series
M-400
32-in/8-out I/O unit uses REAC to handle
high-fidelity digital transmission.
Use REAC to configure a live
recording system based on
40CH I/O MODULAR RACK
S-4000S
SONAR and M-400. M-400 is
equipped with a REAC port for
connecting to your PC. Send
Digitally transmits 16-channel (STAGE
-> FOH) + 8-channel (FOH -> STAGE)
digitally processed audio directly to
STAGE UNIT
SONAR and record up to 40 tracks.
REAC Driver must be installed on
PC for multi-track recording.
S-1608
Digitally transmits 8-channel (FOH ->
STAGE) + 16-channel (STAGE -> FOH)
FOH UNIT
S-0816
22
visit us online at http://www.rolandsystemgroup.net/
Post Production
Video Control
DIGITAL VIDEO WORKSTATION
DV-7 DL Series
Video Presenter Series
With one touch of a button you can
put SONAR V-STUDIO 700 into video
control mode. Use the jog wheel and
Delivers state-of-the-art video
presentations in any setting.
T-Bar to control your video through
Realtime Video Presenter
V-LINK integration with the EDIROL®
DV-7 video editor. Switch back and
PR-80/50
forth between audio and video mode
without skipping a beat.
Performance
DIGITAL VIDEO WORKSTATION
Visual Sampler
CG-8
P-10
This visual synthesizer allows you
This video sampler lets you play
to generate dynamic 3D video from
back video and photos seamlessly.
graphic material and still images,
Use V-LINK to instantaneously play
and lets you "play" them as you
video and photos that link up with
would musical instruments. Use
music.
V-LINK to integrate sound and video
in your performances.
8 Channel Video Mixer
Synthesizer
V-8
V-Synth GT
®
High-performance video mixer
Roland's flagship synthesizer has
with eight inputs (seven SD video
received rave reviews and awards
inputs and a PC (RGB) input), three
around the world. Use the V-Synth
outputs, and newly developed video
GT’s V-LINK port to connect
effects onboard. With V-LINK,
with SONAR V-STUDIO 700 and
the auto faders on VS-700C fully
compatible video equipment, and
synchronize with V-8 video switching.
take your live performances to
another level.
23
Premium Disk
Included
Cakewalk
Production Plus Pack
WDM
for Microsoft®Windows Vista®/
Windows®XP
Windows®XP
Cakewalk and EDIROL® products bundled with Cakewalk Production Plus Pack
UA-25EX
UA-101
PC-50
PCR-M1
MIDI Keyboard Controller
MIDI Keyboard Controller
M-16DX
UA-4FX
PCR-300
MIDI Keyboard Controller
SD-20
24bit / 96kHz 16 Channel Digital Mixer
PCR-500
MIDI Keyboard Controller
PCR-800
MIDI Keyboard Controller
visit us online at http://www.cakewalk.com/products/LE
Cakewalk Production Plus Pack provides an essential lineup of software tools, including SONAR 6 LE (digital-audio workstation),
Project5 LE (featuring pattern-based sequencing), and Dimension LE (sample-playback synthesis).
This pack is included with select Cakewalk and EDIROL products so you can begin making music immediately.
®
TM
SONAR 6 LE is an easy-to-use DAW program that inherits a range of SONAR
6 functions, including seamless audio/MIDI operability, support for up to
24-bit/192kHz audio, and 32-bit floating point processing. Experience the
premium music-production environment only available on SONAR.
Plug-ins
Create custom tones! Comes standard with seven plug-in instruments
(including Dimension LE) and 20 plug-in effects.
®
■DropZone
■Pentagon I
Project5 LE is a multifaceted music production software that includes four
software synthesizers and a pattern-based sequencer. Its intuitive user interface
not only provides an environment for professional music production, but also
makes a powerful tool for real-time performances.
■nPULSE
■PSYN II
This powerful plug-in synth can be incorporated into SONAR LE or Project5 LE. It
comes with an extensive library packed with over 400 tones (150MB+) including
electric piano, guitar, bass, percussion, and other essential instruments.
■VELOCITY
■Audio Efffect Plugins
All specifications and appearances are subject to change without notice.
All trademarks are the property of their respective companies.
Printed in Japan Aug. 2009 RAM-4476 GR-UPR-SS AABD1
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
