DUAL BAND
GSM TELEPHONE
SGH-A800
OWNER’S MANUAL
ELECTRONICS
Printed in Korea
Code No.: GH68-03117A
English. 01/2003. Rev.2.0
Contents
Important Safety Precautions . . . . . . . . . . . . . . . . . . . . .
7
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9
Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Phone Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10
10
13
15
16
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Inserting/Removing the SIM Card . . . . . . . . . . . . . . . . . . . . .
Installing/Removing/Charging the Battery . . . . . . . . . . . . . . .
Switching the Phone On/Off . . . . . . . . . . . . . . . . . . . . . . . . .
17
18
22
Call Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rejecting a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessing Options During a Call . . . . . . . . . . . . . . . . . . . . . . .
Using the Ear-Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . .
23
26
26
27
27
28
34
Selecting Functions and Options . . . . . . . . . . . . . . . . . . . 35
The information in this manual is believed to be correct at
the time of printing; Samsung reserves the right, however,
to change or modify any of the specifications
without notice. Some of the contents in this manual may
differ from your phone, depending on the software
installed, your SIM card or your service provider.
Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the Text Input Mode . . . . . . . . . . . . . . . . . . . . . . . .
Using the T9 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the ABC Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Symbolic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Number Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .
37
38
39
41
44
44
3
Contents (continued)
Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Creating a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . . . .
Searching for and Dialling a Number in the Phonebook . . . . . .
Using the Phonebook Options . . . . . . . . . . . . . . . . . . . . . . . .
Speed-Dialling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voice-Dialling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dialling a Number Stored in Your SIM Card . . . . . . . . . . . . . .
Editing Group Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using Other Phonebook Features . . . . . . . . . . . . . . . . . . . . . .
45
48
49
51
52
53
54
55
Incoming Calls (Menu 4-1) . . . . . . . . . . . . . . . . . . . . . . . . . . .
Messages (Menu 4-2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voice Guide Volume (Menu 4-3) . . . . . . . . . . . . . . . . . . . . . . .
Connection Tone (Menu 4-4) . . . . . . . . . . . . . . . . . . . . . . . . .
Key Tone (Menu 4-5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Minute Minder (Menu 4-6) . . . . . . . . . . . . . . . . . . . . . . . . . .
Quiet Mode (Menu 4-7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Greeting Message (Menu 5-1) . . . . . . . . . . . . . . . . . . . . . . . .
Display (Menu 5-2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Light (Menu 5-3) . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Language (Menu 5-4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Security (Menu 5-5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Quick Menu (Menu 5-6) . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auto Redial (Menu 5-7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Active Folder (Menu 5-8) . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Side Key (Menu 5-9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reset Settings (Menu 5-0) . . . . . . . . . . . . . . . . . . . . . . . . . . .
List of Menu Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
59
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Inbox (Menu 1-1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outbox (Menu 1-2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
New Message (Menu 1-3) . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voice Mail (Menu 1-4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chatting (Menu 1-5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preset Messages (Menu 1-6) . . . . . . . . . . . . . . . . . . . . . . . . .
Settings (Menu 1-7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Delete All (Menu 1-8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Broadcast (Menu 1-9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
63
65
66
68
69
70
70
71
72
Call Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Missed Calls (Menu 2-1) . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Received Calls (Menu 2-2) . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dialled Calls (Menu 2-3) . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Call Times (Menu 2-4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Call Costs (Menu 2-5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
74
74
75
75
76
Voice Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Voice Dial (Menu 3-1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voice Command (Menu 3-2) . . . . . . . . . . . . . . . . . . . . . . . . . .
Voice Memo (Menu 3-3) . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
81
82
83
83
83
84
84
Phone Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
85
85
87
87
88
90
91
91
92
92
Organiser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
New Memo (Menu 6-1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Calendar (Menu 6-2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To-Do List (Menu 6-3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock (Menu 6-4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alarm (Menu 6-5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Calculator (Menu 6-6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conversion (Menu 6-7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Timer (Menu 6-8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stopwatch (Menu 6-9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
93
95
97
98
100
102
103
105
106
77
79
80
5
Important Safety
Precautions
Contents (continued)
Network Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Call Diverting (Menu 7-1) . . . . . . . . . . . . . . . . . . . . . . . . . . .
Call Barring (Menu 7-2) . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Call Waiting (Menu 7-3) . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Network Selection (Menu 7-4) . . . . . . . . . . . . . . . . . . . . . . . .
Caller ID (Menu 7-5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Active Line (Menu 7-6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Closed User Group (CUG) (Menu 7-7) . . . . . . . . . . . . . . . . . . .
107
109
111
112
113
114
114
Fun Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
WWW Browser (Menu 8-1) . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Games (Menu 8-2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Media Box (Menu 8-3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Additional Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Read these guidelines before using your wireless
phone. Failure to comply with them may be
dangerous or illegal. For more detailed safety
information, see “Health and Safety Information” on
page 135.
Road Safety at All Times
Do not use a hand-held phone while driving; park the
vehicle first.
Switching Off When Refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
ALS (Alternate Line Service) . . . . . . . . . . . . . . . . . . . . . . . . . 128
Solving Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Reference Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Access Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Health and Safety Information . . . . . . . . . . . . . . . . . . . . . . . 135
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Quick Reference Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Switching Off in Aircraft
Wireless phones can cause interference. Using them
in aircraft is both illegal and dangerous.
Switching Off in Hospitals
Switch off your phone near medical equipment.
Follow any regulations or rules in force.
Interference
All wireless phones may be subject to interference,
which may affect their performance.
Special Regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger (in a hospital for example).
6
7
Important Safety Precautions
Unpacking
Radio Frequency Exposure
The design of this phone complies with European
Union (EU) requirements relating to radio frequency
(RF) exposure. To maintain compliance with these
requirements, use only Samsung-supplied or
approved accessories. Use of non-approved
accessories may violate the requirements.
Sensible Use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Accessories and Batteries
Use only Samsung-approved accessories and
batteries.
Your package contains the following items.
Phone
Travel Adapter
Battery
Wearable
Ear-Microphone
Owner’s Manual
Hand Strap
Qualified Service
Only qualified service personnel may install or repair
your phone.
In addition, you can obtain the following accessories
for your phone from your local Samsung dealer:
• Battery charger *
• Simple Hands-free kit
• Cigarette lighter adapter • Data kit
Note: A rubber dust cover is fitted over the connector
on the bottom of the phone, to protect it during
shipment. When unpacking the phone, remove
the dust cover and dispose of it, along with any
other unwanted packaging.
* Depending on the country, this accessory may be supplied in the
package.
8
9
Your Phone
Your Phone
Closed Vi e w
Phone Layout
Antenna
The following illustrations show the main elements
of your phone.
Ear-microphone
jack
External display
Open Vi e w
Earpiece
Key
Display
WAP Browser
key
Navigation
keys
Volume key
Soft key (left)
Dial/menu
confirmation
key
Alphanumeric
keys
Interface
connector
(on the bottom)
Service light
Folder
Cancel/
correction key
Soft key (right)
Power on/off /
menu exit key
Special
function keys
Microphone
Description
Perform the functions indicated by the text
above them (on the bottom line of the
(soft keys)
display).
In the menu facility, scroll through the
menu options and phonebook memory.
In idle mode, allow you to access your
favourite menu options directly. For further
details, see the Navigation option in the
Quick menu on page 90.
In idle mode, launches the WAP Browser
directly.
Deletes characters from the display.
When held down, quickly accesses the
New Memo feature.
10
11
Your Phone
Key
Description
Your Phone
(continued)
Makes or answers a call.
In idle mode, recalls the last number dialled.
In the menu facility, selects a menu
function or stores information that you have
entered (such as a name) in the phone or
SIM memory.
Display
Display Layout
The display comprises three areas.
Icons
Ends a call.
When held down, switches the phone on
and off.
In the menu facility, cancels your input and
returns to the previous menu level.
Text and
graphic area
~
When held down in idle mode, accesses
your voice mail.
Enters numbers, letters and some special
characters.
Used for various purposes in different
functions.
When held down while entering a number,
the
key enters a pause.
key
When held down in idle mode, the
enters/exits the quiet mode.
(on the side of the phone)
During a call, adjust the earpiece volume.
In idle mode with the phone open, adjust the
key volume.
When held down in idle mode with the phone
closed, turn on the external display backlight.
When held down while receiving an
incoming call with the phone closed, reject
the call or silence the ring tone; see page 92.
12
Soft keys
Area
Description
First line
Displays various icons (see page 14).
Middle lines
Display messages, instructions and
any information that you enter
(number to be dialled, for example).
Last line
Shows the functions currently
assigned to the two soft keys.
13
Your Phone
Icons
Your Phone
External Display
Shows the received signal strength. The
greater the number of bars, the stronger
the signal.
Your phone has an external display on the cover. It
indicates that you have an incoming call or message,
and notifies you at the specified time when you set
an alarm.
Appears when a call is in progress.
When you hold down one of the volume keys or the
button on the ear-microphone connected to the phone
in idle mode with the phone closed, the external
display backlight illuminates.
Appears when the Call Diverting feature
is activated.
Appears when a new text message has
been received.
Appears when a new voice mail message
has been received.
Appears when you set the alarm.
Appears when you set the Alert type
menu option, so that the phone vibrates
when you receive a call; for further details,
see page 82.
Backlight
The display and keypad are illuminated by a backlight.
When you press any key, the backlight illuminates. It
turns off if no key is pressed within a given period of
time, depending on the Backlight menu option. The
backlight remains on at all times when the phone is
connected to an optional car kit.
To specify the length of time for which the backlight
is active, set the Backlight menu option; see
page 87 for further details.
Appears when the quiet mode is active.
Shows the level of your battery. The more
bars you see, the more power you have
left.
14
15
Your Phone
Getting Started
Service Light
Inserting/Removing the SIM Card
The service light is below the external display on the
folder. It flashes when services are available on the
phone.
When you subscribe to a cellular network, you are
provided with a SIM card loaded with your
subscription details, such as your PIN, any optional
services available and so on.
To change the colour of the light or turn it off, set the
Service light menu option; see page 87 for further
details.
Service light
• Keep all miniature SIM cards out of the reach of
small children.
• The SIM card and its contacts can easily be
damaged by scratches or bending, so be careful
when handling, inserting or removing the card.
• When installing the SIM card, always make sure
that the phone is switched off before you remove
the battery.
Inserting the SIM Card
1. If necessary, remove the battery by referring to
page 19.
2. Insert and slide the SIM card under the two tabs,
ensuring that the notched corner is top left and
the gold contacts of the card face into the phone.
16
17
Getting Started
Getting Started
Removing the SIM Card
Installing the Battery
To remove the SIM card, slide the card out of the
holder, as shown.
1. Insert the teeth on the bottom of the battery into
the corresponding slots on the phone.
2. Push the battery against the back of the phone
until it clicks into place.
Make sure that the battery is properly installed
before switching the phone on.
Installing/Removing/Charging the
Battery
Removing the Battery
Your phone is powered by a rechargeable Li-ion
battery. Use only approved batteries and chargers.
Ask your local Samsung dealer for further details.
1. If necessary, switch off the phone by pressing and
holding down the
key until the power-off
animation is displayed.
Note: You must fully charge the battery before using
your phone for the first time. A discharged
standard battery is fully recharged in
approximately 120 minutes.
2. To remove the battery, push the catch above the
battery on the back of the phone and hold it in this
position. Lift the battery away from the phone.
18
19
Getting Started
Getting Started
Charging the Battery Using the Travel Adapter
Charging the Battery Using the Battery Charger
Note: The phone can be used while the battery is
being charged, but this will cause the phone
to charge more slowly.
1. Plug the travel adapter connector into the bottom of
the battery charger.
1. Plug the travel adapter connector into the bottom
of the phone. Check that the arrow on the
connector is facing towards the front of the phone.
2. Insert the teeth on the bottom of the battery into
the slot on the battery charger and push the battery
against the battery charger until it clicks into place.
3. Plug the travel adapter into a standard AC wall
outlet.
2. Connect the adapter to a standard AC wall outlet.
A progress bar appears on the main and external
displays. While charging, the battery icon in the
top right-hand corner of the main display repeatedly fills to show that the battery is charging.
3. When charging is finished, disconnect the adapter
from the power outlet and from the phone by
pressing the grey tabs on both sides of the
connector and pulling the connector out.
20
The LED indicates the status of the battery being
charged.
Red: the battery is charging.
Green: the battery is fully charged.
Orange: the battery is not seated correctly in the
charger or the adapter is not plugged in correctly.
Check the battery and adapter.
4. Ensure that the travel adapter has been disconnected either from the charger or the wall outlet
before removing the battery. To remove the battery,
push and hold the catch above the battery and lift
the battery away.
Low Battery Indicator
When the battery is weak and only a few minutes of
talk time remain, the battery sensor informs you in the
following ways: an empty battery icon flashes (
),
you will hear a warning tone and a message will be
repeated at regular intervals on the display. When the
battery becomes too weak for the phone to operate, it
switches off automatically.
21
Getting Started
Call Functions
Switching the Phone On/Off
1. Open the phone.
2. Hold down the
switches on.
Using the Number Keypad
key until the phone
3. If the phone asks for a PIN, key in the PIN and
press the left soft key ( ). For further details,
see page 133.
The phone searches for your network and when it
finds it, the current date and time appear on the
main and external displays. Now, you can make or
receive a call.
Note: The display language is determined by the
SIM card inserted. To change the language,
use the Language menu option; for further
details, refer to page 87.
4. When you wish to switch the phone off, hold
down the
key until the power-off animation
is displayed.
22
Making a Call
When the idle screen is displayed, key in the area
code and phone number, and press the
key.
Note: If you have set the Auto redial option to On (see
page 91), the number is redialled automatically
up to ten times if the person you called does not
answer or the line is busy.
Correcting the Number
To clear...
Then...
The last digit
displayed
Press the
Any other digit
in the number
Press the or key until the
cursor ( ❘ ) is immediately to
the right of the digit to be
cleared and press the
key.
You can also insert a missing
digit simply by pressing the
appropriate key.
The whole display
Hold down the
key for
more than one second.
key.
23
Call Functions
Call Functions
Making an International Call
2. Press the
1. Press and hold down the
key for the
international prefix. The + character appears.
2. Key in the country code, area code and phone
number and press the
key.
key.
The call log is listed with the following icons:
for dialled calls
for received calls
for missed calls
3. Use the
and
keys to scroll through the list
until the required number is highlighted.
Making a Call from the Phonebook
4. To dial the number, press the
You can store the names and phone numbers called
regularly in the SIM card and phone memories,
which are jointly called the phonebook. You then do
not need to remember all your numbers; simply
select the required name to recall the associated
number. For further details on the Phonebook feature,
refer to page 45.
To view each call record, refer to “Call Records” on
page 74.
Redialling the Last Number
To redial the last number, press the
key twice.
Using the Call Log
key.
Viewing Missed Calls
If you have a subscription that includes the Caller Line
Identification (CLI) feature and you are unable to
answer a call for any reason, you can find out who was
calling you and then call the person back, if necessary.
The number of missed calls is displayed on the idle
screen immediately after a call was missed.
To view the missed call immediately, proceed as
follows.
The phone chronologically stores up to 30 calls
dialled, received or missed. The last call is saved in
first position. If the same number occurs more than
once, only the latest occurrence is saved.
1. If the phone is closed, open it.
To recall any of these numbers, proceed as follows.
3. To call the number displayed, press the
1. If you have typed any characters on the display,
press the
key to return to the idle mode.
To use the missed call options, refer to “Missed Calls”
on page 74.
24
2. Press the
soft key.
Information corresponding to the most recently
missed call is displayed.
key.
25
Call Functions
Call Functions
Speed-Dialling from the Phonebook
2. End the call by closing the phone or pressing
the
key.
Once you have stored numbers in the phonebook, you
can dial a number simply by pressing one or two
keys. For further details, see page 51.
Note: You can answer a call while using the
phonebook or menu features. The current
operation is cancelled.
Voice Dialling
Rejecting a Call
If you have set the Active folder option to Voice
dial (see page 91), your phone also allows you to say
a name when you open the phone. It then automatically dials the number stored with that name. For
further details on the Voice Dialling feature, refer to
page 77.
Ending a Call
When you have finished your call, briefly press
the
key or close the phone.
Answering a Call
To reject an incoming call, press the
key.
If the phone is closed and the Side key option is set
to Reject, you can hold down one of the volume keys
on the left side of the phone; see page 92.
Adjusting the Volume
During a call, if you wish to adjust the earpiece volume,
use the volume keys on the left side of the phone.
Press the
key to increase and the
decrease the volume.
key to
When somebody calls you, the phone rings and the
phone icon in the middle of the screen flashes.
If the caller can be identified, the caller’s phone
number or name, if stored in your phonebook, is
displayed. If the incoming call is a restricted number,
the display shows Anonymous; if it is unknown, it
shows Unknown.
1. To answer a call, open the phone. If it is already
open, press the
key.
26
In idle mode with the phone open, you can adjust the
key volume using the
and
keys.
27
Call Functions
Call Functions
If you hold down one of these keys while receiving an
incoming call, the call is rejected or the ring tone is
silenced, depending on the setting of the Side key
menu option; for further details, see page 92.
Accessing Options During a Call
To place a call on hold, simply press the Hold soft
key. You can reactivate the call whenever you want,
by pressing the Retrieve soft key.
To make a call while you have a call in progress,
proceed as follows.
1. Key in the phone number that you wish to dial or
look it up in the phonebook.
Your phone provides a number of control functions that
you can use during a call.
2. Press the
key to dial the second call.
The first call is automatically put on hold.
Switching the Microphone Off (Mute)
Or alternatively, proceed as follows.
You can temporarily switch your phone’s microphone
off, so that the other party cannot hear you.
1. Put the current call on hold by pressing the Hold
soft key.
Example: You wish to say something to another person
in the room but do not want the calling party
to hear you.
2. Make the second call in the normal way.
To switch the microphone off temporarily, press
the
key during a call.
The Mute icon ( ) appears on the bottom line of the
display and your correspondent can no longer hear you.
To switch the microphone back on, press the
again. The Mute icon disappears.
key
Putting a Call on Hold
To swap between the two calls, simply press the
or key.
The current call is placed on hold and the call on
hold is reactivated so that you can continue
conversing with the other party.
To end the call on hold, press the
select the End held call option.
soft key and
When you have finished, end each call normally by
pressing the
key.
You can place the current call on hold whenever you
want. You can make another call while you have a call
in progress if this service is supported by the network.
Of these two calls, one is active and the other is on
hold and you can swap between the calls.
28
29
Call Functions
Call Functions
Using the Scratchpad
Your phone has a convenient feature for entering a
phone number during a call as if it were a note pad.
While using this feature, the key tones are automatically muted to avoid disturbing your conversation.
2. To switch between the two calls, press the
To end a held call, press the
the End held call option.
or
key.
soft key and select
To use the Scratchpad feature, proceed as follows.
3. To end the current call, press the
key.
Any held calls will automatically be reconnected to
you.
1. Press the
option.
Searching for a Number in the Phonebook
soft key and select the Scratchpad
2. Enter the number using the number keypad.
When you end the call, the number remains on the
display.
3. Press the Save soft key to save the number in your
phonebook; for further details, refer to page 45.
Answering a Second Call
You can search for a number in the phonebook during a
call.
1. Press the
soft key.
2. If necessary, press the
or
key to highlight
the Phonebook option. Press the
soft key.
3. Select the Find name option and press the
key.
soft
The phonebook entries are listed.
You can answer an incoming call while you have a
call in progress, if this service is supported by the
network and you have activated the Call waiting
option (see page 111). You will be notified of an
incoming call by a call waiting tone.
4. Enter the first few letters of the name that you want
to find.
To answer a call while you have a call in progress,
proceed as follows.
The phonebook entries are listed, starting with the
first entry matching your input. This entry is also
highlighted.
1. Press the
key to answer the incoming call.
The first call is automatically put on hold.
Note: You can also scroll through the phonebook
from the beginning, by pressing the
and
keys.
5. To view the highlighted entry, press the
soft key.
For a more detailed description of the Phonebook
feature, refer to page 45.
30
31
Call Functions
Call Functions
Using the SMS Service
You can read a newly received message or write a
new message during a call.
1. Press the
soft key.
2. Press the
or
option. Press the
key to highlight the SMS
soft key.
3. To read a received message, select the Inbox
option, followed by the message that you wish to
read.
To write a new message, select the N e w
message option.
For detailed information on the SMS feature, refer
to page 63.
Making a Multiparty Call
A multiparty call is a network service that allows
up to six people to take part simultaneously in a
multiparty or conference call. For more information,
contact your service provider.
Setting up the Multiparty Call
1. Call the first participant in the normal way.
2. Call the second participant in the normal way.
The first call is automatically put on hold.
3. To join the first participant to the multiparty call,
press the Join soft key.
32
4. To add a new person to the multiparty call, call the
person in the normal way. Then press the Join soft
key.
You can add incoming callers by answering the call
and pressing the Join soft key. Repeat as needed.
Having a Private Conversation With One
P a rticipant
1. Press the
participant.
or
key to highlight the required
2. Press the
soft key and select the Split option.
Now you can talk privately with that person. The
other participants can continue to converse with
each other.
3. To return to the multiparty call, press the Join soft
key.
All the multiparty call participants can now hear
each other.
Removing One Participant
1. Press the
participant.
or
key to highlight the required
2. Press the
option.
soft key and select the Remove
The call is ended with that participant, but you can
continue to talk with the other participants.
3. End the multiparty call by closing the phone or
pressing the
key.
33
Call Functions
Using the Ear-Microphone
Selecting Functions
and Options
With the ear-microphone supplied with your phone,
you can make or answer a call without holding the
phone. When you connect the ear-microphone to the
jack at the top of the phone, the button on the earmicrophone will operate as listed below.
Your phone offers a set of functions that allow you to
customise your phone. These functions are arranged
in menus and sub-menus, accessed via the two soft
keys marked
and . Each menu and sub-menu
allows you to view and alter the settings of a
particular function.
To...
Then press the button...
Redial the last call
Twice in idle mode.
The roles of the soft keys vary according to the current
context; the labels or icons on the bottom line of the
display just above the keys indicate their current roles.
Answer a call
When you receive the call.
End a call
When you have finished the
call.
Note: You can use the voice dialling or voice
command features by pressing the button, if
the Active folder menu option is set to Voice
dial or Voice command. For further details,
refer to page 91.
Example:
Service Provider
Sun 16 Jan 9:50
Press the left soft key
to access the menu
functions.
34
Press the right soft key
to access the
Phonebook feature.
35
Selecting Functions and Options
Entering Text
To view the various functions/options available and
select the one required, proceed as follows.
1. Press the appropriate soft key.
When storing a name in the phonebook, creating
your personal greeting or scheduling events in your
calendar, you will need to enter text.
2. To...
You are provided with the following text input
modes.
Press the...
Select the:
• Function displayed
or
• Option highlighted
Left soft key (
View the next function
or highlight the next
option in a list
key.
Move back to the
previous function
or option in a list
key.
).
• T9 Mode
This mode allows you to enter words with only one
keystroke per letter. Each key on the keypad has
more than one letter – when you press the
key once, J, K or L may be displayed. The T9 mode
automatically compares your keystrokes with an
internal linguistic dictionary to determine the
correct word, thus requiring far fewer keystrokes
than the traditional ABC mode.
) or
• ABC Mode
This mode allows you to enter letters by pressing
the key labelled with the required letter once,
twice, three or four times until the letter is
displayed.
In some functions, you may be asked for a PIN. Enter
the required code and press the
soft key.
• Symbolic mode
This mode allows you to enter special characters.
Move back up one
level in the structure
Right soft key (
the
key.
• Number mode
This mode allows you to enter numbers.
is a registered trademark of Tegic Communications, Inc. and is
licensed under U.S. Patent 5,818,437/ 5,953,541/ 6,011,554.
36
37
Entering Text
Entering Text
Changing the Text Input Mode
Using the T9 Mode
When you are in a field that allows characters to be
entered, you will see the text input mode indicator at
the bottom of the display.
To type a word, proceed as follows.
Name
20
Example: To enter Hello in the T9 mode, press
,
,
,
.
and
Eng
Text input mode indicator:
T9 mode
To change to another text input mode, proceed as
follows.
1. Press the right soft key, indicating the current text
input mode.
2. Scroll to the required mode, by pressing the
or
key.
The Language select option allows you to change
the text input language.
Note: If you want to exit the menu without changing
the mode, press the
soft key or
key.
3. Press the
soft key to select the highlighted text
input mode.
Quickly Changing the Text Input Mode
To toggle between the...
Then hold down the...
Number and T9 modes
key.
Symbolic and T9 modes
key.
ABC and T9 modes
38
1. Start entering the word by pressing keys
to
. Press each key only once for each letter.
Right soft key.
The word you are typing appears in the display. It
may change with each key that you press.
2. Enter the whole word before editing or deleting
any keystrokes.
3. If the word is correct, start entering the next
word. Otherwise, press the
key
repeatedly to display alternate word choices for
the keys that you have pressed.
Example: Both “of” and “me” have the sequence
and
. The phone displays the
most commonly used choice first.
4. Complete each word with a space by pressing
the
key.
If Spell appears above the left soft key while you
are entering text, the word does not exist in the T9
dictionary. To type words not found in the T9 mode,
change the text input mode to the ABC mode or
proceed as follows.
1. Press the Spell soft key, or press the right soft
key and select the Add word option.
39
Entering Text
Entering Text
2. Enter the required word using the ABC mode (see
page 41) and press the
soft key.
The word is saved in the T9 dictionary and
inserted in the input field.
3. Continue entering any other words in the T9 mode.
Smart Punctuation
To enter periods, hyphens or apostrophes, press
the
key. The T9 mode applies rules of grammar
to insert the correct punctuation.
Example: The
key is used twice to display two
punctuation marks.
l
e
t
‘
s
e
a
t
.
Changing the Case
To change the case of the next letter(s) that you type,
press the
key. There are three case states:
• Lower Case (no indicator)
• Initial Capital ( )
• Capital Lock ( )
Scrolling
To move the cursor to the left or right within the text,
press the or key.
40
Clearing Letters and Words
To...
Then...
Clear the letter to
the left of the cursor
Press the
Clear all letters
on the display
Hold down the
key and
select the Erase all option.
Cancel your input
and return to the
previous menu level
Hold down the
key and
select the Go back option.
key.
Using the ABC Mode
When typing in the ABC mode, press the key labelled
with the required letter:
- Once for the first letter
- Twice for the second letter
- And so on
Example: To display the letter “C”, quickly press
the
key three times. To display the
letter “K”, press the
key twice. This
method is called Multi-tap typing.
Note: The cursor moves to the right when you press
a different key. When entering the same letter
twice or a different letter on the same key, just
wait a few seconds for the cursor to move
right automatically, and then enter the next
letter.
41
Entering Text
Entering Text
Refer to the table below for more information about
the characters available. The characters vary,
depending on text input language.
You can select the language by setting one of the
following options:
• Language select; see page 38
• Input mode (5-4-3); see page 87
Characters in the Order Displayed
Key
1
2
3
4
5
6
7
8
9
0
.
A
D
G
J
M
P
T
W
0
, B
E
H
K
N
Q
U
X
?
C
F
I
L
O
R
V
Y
! ‘ @ : 1
2
3
4
5
6
S 7
8
Z 9
Scrolling
To move the cursor to the left or right within the text,
press the or key.
Clearing Letters and Words
To...
Then...
Clear the letter to
the left of the cursor
Press the
Clear all letters
on the display
Hold down the
key and
select the Erase all option.
Cancel your input
and return to the
previous menu level
Hold down the
key and
select the Go back option.
key.
(Capital Lock mode in English)
Changing the Case
To change the case of the next letter(s) that you type,
press the
key. There are three case states:
• Lower Case (no indicator)
• Initial Capital ( )
• Capital Lock ( )
Inserting a Space
To insert a space between each word, press the
key.
42
43
Entering Text
Phonebook
Using the Symbolic Mode
The phonebook offers the following features.
The Symbolic mode enables you to insert symbols in
a text message.
Phonebook: allows you to create, find or manage
phonebook entries, set up the speed-dialling feature
and record voice dial entries.
To...
Then press the...
Display more symbols
Enter a given symbol
,
,
or
key.
Corresponding key.
Return to the previous
text input mode
key.
Using the Number Mode
The Number mode enables you to enter numbers.
Press the keys corresponding to the required digits
before manually switching back to the appropriate
text input mode.
Management: allows you to create or remove your
own number, set up caller groups and check the
memory status.
Services: allows you to use the service directory or
information numbers, depending on your SIM card.
These features can be accessed by pressing the
soft
key, then scrolling with the
,
, and keys.
Creating a Phonebook Entry
You can store phone numbers and the corresponding
names in the memory of your SIM card. In addition, you
can store up to 2000 names in the phone memory and
each name can be associated with up to five numbers.
There are two ways to store a number:
• Using the Save soft key in idle mode
• Using the Add entry option in the Phonebook menu
Storing a Number in Idle Mode
As soon as you start to enter a number, Save appears
above the left soft key to allow you to store the number
in the phonebook.
1. Key in the number to be stored.
44
45
Phonebook
Phonebook
Notes:
• If you make a mistake while entering a number,
correct it using the
key. For further details,
refer to page 23.
• To insert a dialling pause for special phone
services, such as banking by phone, hold down
the
key. “P” is displayed to indicate the pause.
2. When you are sure that the number is correct, press
the Save soft key.
3. Select the memory in which the number is to be
stored (Phone or SIM) and press the
soft key.
Note: If you change phones, any numbers stored in
your SIM card memory will automatically be
available with the new phone, whereas any
numbers stored in the phone memory must be
stored again.
4. Enter the associated name.
The maximum length of a name depends on your SIM
card. For information on how to enter characters, see
page 37.
5. When you are satisfied, press the
soft key.
6. If you
Then...
selected...
SIM
46
• Enter the location number.
• Press the
soft key.
The number is saved and the new
entry is displayed.
• Press the
key or the
soft
key to return to the idle screen.
If you
Then...
selected...
Phone
• Select one of the categories (described
below) by pressing the or key,
followed by the
soft key.
• Add any other numbers required in the
other categories by pressing the
soft key and selecting the Edit
number option. You can also select
the Change name option if you wish
to change the associated name.
• Press the
key or the
soft
key to return to the idle screen.
Mobile/Home/Office/F a x/Other: allows you to
group numbers by type.
E-mail: allows you to store an e-mail address (the
phone memory can contain a maximum of 200 e-mail
addresses).
URL: allows you to store a URL address (the phone
memory can contain a maximum of 100 URL addresses).
G roup: allows you to assign an entry to a caller
group. To remove a number from a group, select the
No Group option. For more information on how to
change caller group properties, see page 54.
Graphic: allows you to select an image to inform you
of an incoming call from that person.
Alert: allows you to select the colour of the service
light and the melody used to inform you of an
incoming call from that person.
47
Phonebook
Phonebook
Storing a Number Using the Phonebook Menu
1. In idle mode, press the
Phonebook menu.
soft key to access the
2. Scroll to the Add entry option by pressing the
or
key and press the
soft key.
3. Continue the procedure from Step 1 on page 45 to
store the number.
Searching for and Dialling a Number in the
Phonebook
1. When the idle screen is displayed, press the
soft key to access the Phonebook menu.
2. Select the required search method (Find name or
Find number) by pressing the
or
key, if
necessary.
3. Enter the start of the name or number that you wish
to find.
The phonebook entries are listed, starting with the
first entry matching your input. This entry is also
highlighted.
4. If necessary, press the
the required entry.
or
key to scroll to
5. Once you have found the required entry, press the
soft key.
48
6. To...
P ress the...
Dial the displayed
number
Use the phonebook
options
key.
soft key.
For further details, see
page 49.
Using the Phonebook Options
To access the options, proceed as follows.
1. From the phonebook entry, press the
soft key.
The first available option is highlighted.
2. Scroll to the required option by pressing the
or
key.
3. Press the
soft key.
The following options are available.
Edit (SIM card memory)
This option allows you to edit the selected number
and name.
Edit number (phone memory)
This option allows you to edit the selected number.
You can also add a new number if none has been
stored for the selected category.
49
Phonebook
Phonebook
Speed-Dialling
Change name (phone memory)
This option allows you to change the name of the
selected entry.
To clear the old name, press the
key. For more
information on how to enter characters, see page 37.
Send SMS
This option allows you to send an SMS message to
the selected number. For more information on how to
send a message, see page 66.
Copy
This option allows you to copy the selected entry
from the phone memory to the SIM memory, and vice
versa.
Delete entry
This option allows you to delete the selected entry
from the phonebook. To confirm the deletion, press
the
soft key. Otherwise, press the
soft key.
Once you have stored numbers in the phone memory,
you can set up to eight speed-dial entries and then
dial them easily whenever you want, simply by
pressing the associated number key.
Setting Up Speed-Dial Entries
1. When the idle screen is displayed, press the
soft key to access the Phonebook menu.
2. Scroll to Speed list by pressing the
key and press the
soft key.
or
3. Press the
or
key to scroll to the required
entry and press the
soft key.
4. Enter the required number and press the
key,then enter a name and press the
soft key.
Or, press the
soft key to recall a number from the
phonebook. The entry is automatically saved.
Removing a Speed-Dial Allocation
Select the speed-dial entry that you wish to remove
from the list and press the
soft key. Delete each
character of the number and name with the
key,
then save the empty entry by pressing the
key.
Using the Speed-Dial Feature
When the idle screen is displayed, hold down the
number key (
to
) assigned to the speeddial entry.
50
51
Phonebook
Phonebook
Using the Voice-Dial Options
Note: Key
is reserved for your Voice Mail
server number.
Replay: plays back the voice dial tag of the entry.
Delete: deletes the entry. When a confirming
message appears, press the
soft key.
Voice-dialling
Once you have stored numbers in the phone memory,
you can record up to 20 voice-dial entries.For further
details about using the voice dialling feature, refer to
page 77.
Setting Up Voice-Dial Entries
Using theVoice-Dial Feature
If you have set the Active folder option to Voice
dial (see page 91), open the phone and say the name
into the microphone. The phone then automatically
dials the number stored with that name.
1. When the idle screen is displayed, press the
soft key to access the Phonebook menu.
Or, use the Act option in the Voice dial menu option.
2. Scroll to Voice list by pressing the
key and press the
soft key.
Dialling a Number Stored in Your SIM Card
or
3. Press the
or
key to scroll to the required
entry and press the
soft key.
4. Record a name by speaking into the microphone.
5. Say the name again at a prompt to confirm it.
When the voice tag is correctly accepted, the
phone saves it.
6. Enter the required number and press the
key,then enter a name and press the
soft key.
Or, press the
soft key to recall a number from the
phonebook. The entry is automatically saved.
Once you have stored phone numbers in your SIM
card, you can dial them easily whenever required.
To dial a number stored in your SIM card, proceed as
follows.
1. Enter the number of the SIM card location in which
the number you wish to dial is stored.
2. Press the
key.
The display shows the name and number stored in
that location.
3. Press the Dial soft key or the
52
key.
53
Phonebook
Phonebook
Editing Group Settings
6. Change the setting as required and press the
soft key.
You can change the settings of the five predefined
caller groups.
7. Repeat Steps 5 and 6 to change any other options.
8. When you have finished, press the
the
key to exit.
1. When the idle screen is displayed, press the
soft key.
soft key or
2. Scroll to the Management menu, by pressing
the key.
Using Other Phonebook Features
3. Scroll to G roup setting by pressing the
key and press the
soft key.
Storing Your Own Number
or
4. Select the required caller group by pressing the
or
key and press the
soft key.
You can store your own phone number(s) with a
name. The number of phone numbers that you can
store may vary depending on the SIM card.
5. Scroll to the required setting option by pressing
the
or
key, and press the
soft key. The
following options are available.
1. When the idle screen is displayed, press the
soft key.
Melody: allows you to select the ring melody used
when you receive a call from any member of that
group.
Colour: allows you to select the colour of the
service light used when you receive a call from any
member of that group.
Graphic: allows you to select the image used
when you receive a call from any member of that
group.
Change name: allows you to change the name of
the group; for further details on how to enter
characters, see page 37.
54
2. Scroll to the Management menu, by pressing
the key.
3. When Own number is highlighted, press the
soft key.
4. Select an entry and press the
5. Enter your number and press the
to the Name field.
6. Enter the name and press the
7. Press the
soft key or the
soft key.
key to move
soft key.
key to exit.
To remove the Own number, delete the number and
name in above step 5 and 6, then press the
soft
key.
55
Phonebook
Phonebook
Checking the Memory Status
You can check how many entries are stored in the
phonebook (card and phone memories) and how
many free locations remain.
Dialling the Service Directory or Information
Numbers
Note: This feature may not be available, depending
on your SIM card.
1. When the idle screen is displayed, press the
soft key.
1. When the idle screen is displayed, press the
soft key.
2. Scroll to the Management menu, by pressing
the key.
2. Scroll to the Services menu, by pressing the
or key.
3. Scroll to Memory status by pressing the
or
key and press the
soft key.
3. Select the required option, by pressing the
or
key and press the
soft key.
The display shows the number of phone and SIM
entries used, followed by the total capacity of
each memory.
4. Press the
soft key or the
key to exit.
Service directory: enables you to view the
numbers in the Service Directory and make calls
to them.
Information: enables you to see the information
numbers in a tree structure and make a call.
4. If necessary, scroll to the required number by
pressing the
or
key and press the
key
to dial the number.
56
57
Using the Menus
Using the Menus
The phone offers a range of functions that allow you
to tailor the phone to your needs. These functions
are arranged in menus and sub-menus.
The menus and sub-menus can be accessed by
pressing the left soft key in idle mode, then scrolling
with the navigation keys.
1. In idle mode, press the
menu facility.
soft key to access the
2. Scroll through the main menus using the
key.
or
3. Find the sub-menu that you wish to use by
scrolling with the
or
key. Press the
soft key to access the sub-menu.
List of Menu Functions
The various menus let you check or change your phone
settings. The following illustration shows the menu
structure.
The numbers assigned to each menu option may not
match the menu number on the phone. It depends on
the services supported by your SIM card.
Note: You can only see menu 0, if your SIM card
supports the SIM Application Toolkit. This is a
network feature. Please contact your service
provider for more information.
Main Menu
Level 1
1. Messages
1. Inbox
2. Outbox
3. New message
4. Voice mail
5. Chatting
6. Preset messages
7. Settings
If the menu that you have selected contains
further sub-menus, repeat this step.
4. Scroll with the
of your choice.
5. Press the
or
key to find the setting
soft key to save the setting.
8. Delete all
9. Broadcast
Note: You can return to the previous menu level by
pressing the
soft key or the
key.
You can also access the menus and sub-menus by
entering the corresponding menu number.
Example: To access the Missed calls menu option,
press ,
,
in idle mode.
58
2. Call records
1. Missed calls
2. Received calls
3. Dialled calls
4. Call times
Level 2
1. Service centre
2. Validity period
3. Default recipient
4. Message type
5. Common
6. Profiles
1. Receive
2. Channel
3. Language
4. Read
1. Last call time
2. Total sent
3. Total received
4. Reset timers
59
Using the Menus
Using the Menus
Main Menu
Level 1
Level 2
Main Menu
Level 1
Level 2
2. Call records
(continued)
5. Call costs 1
1. Last call cost
2. Total cost
3. Max cost
4. Reset counters
5. Set max cost
6. Price/Unit
5. Phone settings
(continued)
6. Quick menu
1. Voice command
2. Navigation
3. Voice functions
1. Voice dial
2. Voice command
3. Voice memo
4. Sound settings
1. Incoming calls
2. Messages
1. Record
2. Act
3. Delete one
4. Play all
5. Delete all
1. Record
2. Act
3. Play all
4. Delete all
1. Record
2. Replay
3. Delete one
4. Delete all
1. Melody
2. Ring volume
3. Alert type
1. Tone
2. Alert type
3. Repetition
3. Voice guide volume
4. Connection tone
5. Key tone
6. Minute minder
7. Quiet mode
5. Phone settings
1. Greeting message
2. Display
3. Service light
4. Language
5. Security
60
7. Auto redial
8. Active folder
9. Side key
0. Reset settings
6. Organiser
1. New memo
2. Calendar
3. To-do list
4. Clock
5. Alarm
6. Calculator
7. Conversion
1. PIN check
2. Change PIN
3. SIM lock
4. FDN mode 1
5. Change PIN2
1. Currency
2. Length
3. Weight
4. Volume
5. Area
6. Temperature
8. Timer
9. Stopwatch
7. Network services
1. Call diverting
2. Call barring
1. Power On/Off Image
2. Main display
3. External display
4. Main contrast
5. External contrast
6. Backlight
1. Sound settings
2. Phone settings
3. All settings
3. Call waiting
1. Divert always
2. Busy
3. No reply
4. Unreachable
5. Unavailable 1
6. Cancel all
1. All outgoing
2. International
3. International
except to home
4. All incoming
5. Incoming while
abroad
6. Cancel all
7. Change barring
password
1. Voice calls
2. Fax calls
3. Data calls
4. Cancel all
4. Network selection
1 Shown only if supported by your SIM card.
61
Using the Menus
Messages
Main Menu
Level 1
7. Network services
(continued)
5. Caller ID
6. Active line1
7. Closed user group
8. Fun box
1. WWW browser 3
2. Games
3. Media box
Level 2
1. Index list 2
2. Outside access 2
3. Default group 2
4. Deactivate 2
1. Home
2. Bookmark
3. Go to URL
4. Clear cache
5. Browser setting
1. Fortress
2. Space War
3. X-Flighter
1. Image
2. Melody
3. Delete all
This menu allows you to create, send, read and save
text messages with the Short Message Service (SMS).
Voice mails and messages containing pictures or
melodies are also available.
Note: This feature is only available if your service
provider’s network supports it. Contact your
service provider for more information.
The inbox and outbox share a given amount of memory
in your phone or SIM card. When the message memory
is full, the
icon blinks and an error message is
displayed. In this case, you cannot receive any new
messages. You should delete one or more old
messages to make room for the new message using
the Delete option within the inbox or outbox or the
Delete all option; for further details, see page 71.
Inbox (Menu 1-1)
Your phone receives incoming messages and saves
them in an inbox. SMS messages are usually saved in
the SIM memory, and messages containing images or
melodies are saved in the phone memory.
1 Shown only if supported by your SIM card.
2 Shown only if the Closed User Group feature is active.
3 May not be shown or supported by your network service provider.
62
When you receive a new text message, the
icon
is displayed and you hear an alert, depending on the
message sound setting; for further details, see
page 82.
To read the message immediately, press the left soft
key. Otherwise, press the right soft key to exit.
63
Messages
When the Inbox menu option is selected, the list of
messages received is displayed with the:
• Sender’s phone number (or name if stored in the
phonebook)
• Message status ( for a read message or
for
an unread message)
To view a message, scroll to it and press the
soft
key. The screen shows the:
• Date and time at which the message was received
• Memory in which the message was stored ( for
your SIM card or for the phone memory)
• Message contents
To scroll through the message contents, press the
or
key.
To scroll through messages that include images or
melodies, press the
,
, or key. When you
focus on an object that includes a melody, the melody
is played.
You can choose the following options, by pressing
the
soft key.
Delete: allows you to delete the message.
Send: allows you to send the message to another
person.
Edit: allows you to edit the message.
Transfer: allows you to transfer the message from
your SIM card to the phone memory.
Messages
Cut number: extracts a number from the message, so
that you can call the number or save it in the
phonebook.
Extract media: saves media items, such as sounds or
images, from the message into your phone’s media box.
You can use these items when writing a message; for
further details, see page 66.
Message reply: allows you to reply by sending a text
message.
Chatting: allows you to have a conversation with
another person using text messages; for further details,
refer to page 69.
Outbox (Menu 1-2)
The outbox stores any messages that you have already
sent or just saved without sending.
When the Outbox menu option is selected, the list of
messages you have sent or saved is displayed with the:
• Recipient’s phone number (or name if stored in the
phonebook)
• Message status ( for a sent message or
for an
unsent message)
To view a message, scroll to it and press the
soft
key. The screen shows the:
• Message status (Sent or To Send)
• Memory in which the message was stored ( for
your SIM card or for the phone memory)
• Message text
Call back: allows you to call the sender back.
64
65
Messages
To scroll through the message, press the
or
key. You can choose the following options, by
pressing the
soft key.
Delete: allows you to delete the message.
Send: allows you to send the message to another
person.
Edit: allows you to edit the message.
Transfer: allows you to transfer the message from
your SIM card to the phone memory.
Cut number: allows you to extract a number from
the message, so that you can call the number or save
it in the phonebook.
New Message (Menu 1-3)
Via this menu, you can write messages, containing
text, images and melodies.
1. Create a message.
Note: For further information on how to enter
characters, refer to page 37.
2. When you have completed your message, press
the
soft key.
Messages
3. Scroll to the required option by pressing the
or
key. The following options are available.
Text: allows you to format the text. You can change
the size and alignment of the text, and use bold,
italic, underscored or strikethrough characters.
These text attributes can all be combined as
required.
Add media: allows you to add pictures, animations
and/or melodies to the message. Select the
required category: Add picture, Add animation or
Add melody. You can then choose a preset object
or an object that you have received from another
source and stored in the media box (see page 127).
P reset messages: allows you to add a preset
message to your text. Select one of the ten
messages predefined via the P reset messages
menu option (see page 70).
Send: allows you to send the message.
Send by set: allows you to send the message by
using a profile predefined via the Settings menu
option (see page 70).
Save Message: allows you to save the message
so that it can be sent later. You can read the
message in your outbox.
4. When you have finished entering your message,
select Send or Send by set to send the message.
If you just want to save the message, select Save
Message, followed by the memory location.
You do not need to continue with the following
steps.
66
67
Messages
5. If you selected...
Messages
Then...
Send
Enter a destination number.
Send by set
• Select a profile.
• Enter a destination number.
Notes:
• To recall a number from your phonebook, press
the
soft key.
• The Add soft key allows you to add up to five
numbers.
• To go back to the previous screen, press
.
6. Press the
soft key.
The message is sent.
Note: If the phone fails to send the message, “Error”
is displayed. Press the Retry soft key to retry
the transmission or the
soft key to forward
the message to another destination.
Voice Mail (Menu 1-4)
Listening to Your Voice Mail
When you receive a voice mail, your phone displays
the voice mail indicator and you hear an alert,
depending on the message sound setting; for further
information, see page 82.
There are three ways to access your voice mail box.
1. When you receive a voice mail, press the left soft
key and follow the instructions provided.
2. In idle mode, hold the
your voice mail box.
key down to access
3. Call your voice mail server number and follow the
instructions provided.
Chatting (Menu 1-5)
Using this menu option, you can have a conversation
with another person using text messages.
To start a chat session, proceed as follows.
Storing the Voice Mail Server Number
Before using the voice mail service, you must store the
voice mail server number obtained from your service
provider.
To save the voice mail server number, select the Voice
mail menu option, enter the voice mail server number
and a name (if required), then press the left soft key to
save it.
68
1. Enter the ID with which you wish to identify
yourself for the chat, and press the
key.
2. Enter the other party’s phone number and press
the
soft key. Or, press the soft key.
3. Write your chat message as you would a normal
text message, and press the
soft key to send
the message.
69
Messages
Messages
4. When you receive a reply from the other party, the
reply message (indicated by the sender’s ID) is shown
below your original message (indicated by your ID).
Validity period: allows you to set the length of time for
which your text messages will be stored at the message
centre while attempts are made to deliver them.
5. Write your reply and send it by pressing the
soft key.
Default recipient: allows you to set the default
recipient’s phone number.
6. Repeat this procedure for each chat message.
Preset Messages (Menu 1-6)
Message type: allows you to set the message type (Text,
Fax, Voice, ERMES, X400 and E-Mail). Depending on the
network, the message will be converted into the selected
format.
Common: two options are available.
Using this menu, you can preset up to ten messages
that you use most frequently. When you access this
menu, the preset message list is displayed.
Reply path: allows the recipient of your SMS message to
send you a reply via your message centre, if the service
is provided by the network.
1. Scroll to the required message or an empty entry by
pressing the
or
key.
Delivery report: allows you to activate or deactivate the
report function. When this function is activated, the
network informs you whether your message has been
delivered or not.
2. Press the
soft key and enter a new message or
edit the old message.
3. Press the Save soft key to save the message.
Settings (Menu 1-7)
Profiles: a message profile is a group of settings
required to send a message. You can use these settings
if you select the Send by set option when sending a
message.
Each of the message profiles has its own submenus:
Service centre, Validity period, Default recipient,
Message type and Profile name.
Via this menu, you can set up default SMS information.
The following options are available.
Delete All (Menu 1-8)
Service centre: allows you to store or change the
number of your SMS centre required when sending
messages. You must obtain this number from your
service provider.
You can delete all messages stored in the SIM card and
phone memories via this menu.
70
Put a check mark in front of the required memory (SIM
or Phone) by pressing the Select soft key and press the
soft key to delete all messages in that memory.
71
Messages
Messages
Broadcast (Menu 1-9)
This network service allows you to receive text
messages on various topics, such as the weather or
traffic. Messages are displayed immediately as they
are received, provided that:
• The phone is in idle mode
• The Receive option is set to On
• The message channel is currently active in the
channel list
Read: lets you view the first message. If the
message is long, press the
key on the left side of
the phone one or more times.
To view another message, scroll through the
messages using the
or
key. You can also
press the Next soft key at the end of the message to
move to the next message.
The last five messages are also stored for later
retrieval. Please contact your service provider for
more information.
The following options are available.
Receive: allows you to turn the reception of
broadcast messages on or off.
Channel: lists all available channels. The channels
currently selected are indicated by a check mark
beside the name. When you select one of them, you
can edit, enable, disable or delete the channel.
The Add option allows you to add a new channel to
the channel list. Enter the appropriate channel ID
obtained from your service provider and a title for the
channel.
Language: allows you to select your preferred
language to be used when displaying cell broadcast
messages.
72
73
Call Records
Call Records
Dialled Calls (Menu 2-3)
Via this menu, you can view:
• Missed calls
• Received calls
• Dialled calls
The number and name (if available) are displayed
together with the date and time at which the call
was made. You can also view call times and costs.
Missed Calls (Menu 2-1)
This option lets you view the last 30 unanswered
calls if the caller line identification is available.
By pressing the
soft key, you can also:
• Delete the current call record from the list
• Delete all call records in the list
• Paste the number into the phonebook
Received Calls (Menu 2-2)
This option lets you view the last 30 received calls if
the caller line identification is available.
By pressing the
soft key, you can also:
• Delete the current call record from the list
• Delete all call records in the list
• Paste the number into the phonebook
74
This option lets you view the last 30 dialled numbers.
By pressing the
soft key, you can also:
• Delete the current call record from the list
• Delete all call records in the list
• Paste the number in the phonebook
Call Times (Menu 2-4)
This options lets you view the timers for calls made
and received.
Note: If your SIM card supports the ALS feature you
must select the appropriate line first.
The following timers are available.
Last call time: length of the last call.
Total sent: total length of all calls made since the
timer was last reset.
Total received: total length of all calls received
since the timer was last reset.
You can use the Reset timers option to reset the
call timers.
Note: The actual time invoiced for calls by your
service provider may vary, depending on
network features, rounding-off for billing
purposes, and so forth.
75
Call Records
Voice Functions
Call Costs (Menu 2-5)
This feature lets you view the cost of calls.
Notes:
• This feature is not intended for billing purposes.
• AOC (Advice Of Charge) information may be
displayed in idle mode, depending on your SIM card
or service provider.
The following options are available.
Last call cost: cost of the last call made.
Note: If your SIM card supports the ALS feature, you
can see the cost of the last call on each line.
Total cost: total cost of all calls made since the cost
counter was last reset. If the total cost exceeds the
maximum cost set via the Set max cost option, you can
no longer make any calls until you reset the counter.
Max cost: maximum cost set via the Set max cost
option (see below).
Reset counters: option used to reset the cost counter;
you must first enter your PIN2 (see page 133) and then
press the
soft key.
Set max cost: option used to enter the maximum cost
that you authorise for your calls; you must first enter your
PIN2 (see page 133) and then press the
soft key.
In the Voice Functions menu, you can use voice
features, such as:
• Voice dial
• Voice command
• Voice memo
Voice Dial (Menu 3-1)
The voice dialling feature allows you to make phone
calls by saying a voice tag that has been added to a
name and phone number in the phonebook. Any
spoken word, such as a name, can be a voice tag.
When recording a voice dial tag, note that:
• Voice tags are not language-dependent. They are
dependent on the speaker’s voice.
• Voice tags are sensitive to background noise.
Where possible, record voice tags or make calls in a
quiet environment.
• When recording a voice tag or making a call, hold
the phone in the normal position close to your ear.
• The maximum length for a voice tag recording is
about 1.5 seconds, but very short names are not
recorded.
• You can record up to 20 voice-dial entries.
Price/Unit: option used to set the cost of one unit; this
price per unit is applied when calculating the cost of
your calls; you must first enter your PIN2 (see page 133)
and then press the
soft key.
76
77
Voice Functions
In the Voice Dial menu option, the following options
are available.
Record: allows you to record name tags and allocate
them to numbers for voice dialling.
1. Say the name you want to use for voice dialling
after you hear a voice prompt. For best results, use
names with at least two syllables, or use both a
first and last name. The phone stores the name as
the first sample, and then prompts you to say the
name again.
2. Respond to the prompt by repeating the name.
The phone saves the name as the second sample
and then requests the phone number and name.
3. After entering a number and name, press the
soft key.
Act: activates voice dialling.
You hear a voice guide and “Say Name” appears on
the display.
Say the voice tag clearly.
The phone automatically dials the number of the
recognised voice tag.
If no match is found for the voice tag or the tag is not
recognised, the phone may ask you to try again.
Delete one: allows you to delete an individual voice
tag. The corresponding phone number remains in the
phonebook but the voice tag is deleted.
Voice Functions
Delete all: deletes all voice tags. The corresponding
phone numbers remain in the phonebook but the voice
tags are all deleted. Press the
soft key when the
message “Delete All?” is displayed. Otherwise, press
the
soft key to exit the function without deleting
the voice tags.
Voice Command
(Menu 3-2)
This menu gives you quick access to menus you use
frequently, by saying your own voice commands.
The following options are available.
Record: The most frequently used menu functions are
programmable with your own voice commands. The
menus are preset to Off by default, indicating that
they are not recorded. When voice commands are
recorded successfully, the menus are changed to O n
on the display.
Act: allows you to access the menus using the
recorded voice commands.
Play all: plays back all voice commands you have
recorded.
Delete all: deletes all voice commands you have
recorded. Press the
soft key to confirm the
deletion. Otherwise, press the
soft key to exit the
function without deleting the commands.
Play all: plays back all recorded voice tags.
78
79
Voice Functions
Voice Memo (Menu 3-3)
You can use the Voice Memo feature to:
• Record voice memos
• Play the recorded voice memos
• Delete one or all voice memos
The following options are available.
Record: allows you to record a memo. The display
shows the recording time counter. After recording,
press the End soft key. You are prompted to enter a
title. Enter a title of up to 24 characters.
Note: If the memory is full, you must delete obsolete
memos before recording a new one.
Replay: allows you to play back a recorded memo.
Delete one: allows you to delete a specific memo.
Delete all: allows you to delete all memos. Press
the
soft key to confirm the deletion. Otherwise,
press the
soft key to exit the function without
deleting the memos.
80
Sound Settings
You can use the Sound Settings feature to customise
various settings, such as the:
• Ring tone, volume and type for incoming calls or
messages
• Volume for the voice prompt
• Sounds made when your call is connected or when
you press a key
• Mode to which your phone switches when you
hold down the
key
Incoming Calls (Menu 4-1)
This option allows you to set up the ringer for
incoming calls.
Note: If your SIM card supports the ALS feature, you
must select the line you wish to change first.
The following options are available.
Melody: lets you choose between many different
melodies. Each time you select a melody from the list,
it plays the melody.
Ring volume: allows you to adjust the ring volume.
Use the
and
keys or the volume keys on the
left side of the phone. The more bars you see, the
greater the volume.
81
Sound Settings
Alert type: lets you specify how you are informed of
any incoming calls.
Light only: only the service light on the folder comes
on.
Melody: the phone rings using the melody selected
via the Melody option (see page 81).
Vibration: the phone vibrates but does not ring.
Vibration then melody: the phone first vibrates and
then starts ringing.
Messages (Menu 4-2)
This option allows you to set up the ringer for
incoming messages.
The following options are available.
Tone: lets you choose between many different tones.
Each time you select a tone from the list, the tone is
played.
Alert type: lets you specify how you are informed of
any incoming messages.
Silent: only the text notification appears; the phone
neither rings nor vibrates.
Tone: the phone rings using the tone selected via the
Tone option (see above).
Vibration: the phone vibrates but does not ring.
Vibration then tone: the phone first vibrates and then
starts ringing.
Repetition: allows you specify how often the phone
informs you of a new message. You can choose
between Once, Periodic and Continuous.
82
Sound Settings
Voice Guide Volume (Menu 4-3)
You can adjust the volume of the voice prompt when
using the voice functions.
Use the
and
keys or the volume keys on the left
side of the phone. The more bars you see, the greater
the volume.
Connection Tone (Menu 4-4)
This menu option allows you to specify whether the
phone should beep when the phone connects to the
network. The following options are available.
Off: the phone does not beep.
On: the phone beeps when your call is accepted.
Key Tone(Menu 4-5)
This menu option allows you to select the tone that the
keypad generates when you press a key. The following
options are available.
Off: the keys do not make any sound.
Tone: each key, when pressed, makes a different sound.
Beep: each key, when pressed, makes the same sound.
To adjust the key tone volume, press the volume keys on
the left side of the phone in idle mode with the phone
open.
83
Sound Settings
Phone Settings
Minute Minder (Menu 4-6)
This menu option allows you to specify whether the
phone must beep every minute during an outgoing
call to keep you informed of the length of your call.
The following options are available.
Off: the phone does not beep.
On: the phone beeps every minute.
Many different features of your phone can be customised
to suit your preferences via the Phone Settings menu.
Greeting Message (Menu 5-1)
This menu option allows you to set a greeting message
to be displayed briefly when the phone is switched on.
When you select this option, the current message is
displayed.
To...
Then...
When you hold the
key down in idle mode, the
phone switches to the quiet mode. You can specify
whether the phone vibrates or mutes all sounds in
the quiet mode.
Clear the existing
message
• Hold down the
key.
• Select the Erase all option.
Enter a new
message
Press the appropriate
alphanumeric keys.
The following options are available.
Change the text
input mode
• Press the right soft key.
• Select the required mode.
Vibration: the phone vibrates rather than rings in
quiet mode.
Save your input
Press the
soft key.
Mute: the phone mutes all sound settings in quiet
mode.
Cancel your input
and return to the
previous menu
Press the
key.
Quiet Mode (Menu 4-7)
Display (Menu 5-2)
You can change the settings for the main and external
displays to suit your preference and needs.
84
85
Phone Settings
Phone Settings
Power On/Off Image
Backlight
This option allows you to select the image to be
displayed when you switch the phone on or off.
You can specify whether or not the phone uses the
backlight. A marginal increase in standby/talk time
can be achieved by turning the backlight off.
Main Display
This option allows you to select the idle screen for
the main display.
Normal: displays the normal idle screen with the
navigation key functions.
Image: displays the selected wallpaper image.
External Display
This option allows you to select the type of clock to
be displayed on the external display in idle mode.
The following options are available.
Off: the backlight is not used.
Short: the backlight comes on when you press a key
or receive a call and switches off 10 seconds after
the last key is pressed.
Long: the backlight comes on when you press a key
or receive a call and switches off 20 seconds after
the last key is pressed.
Service Light (Menu 5-3)
Digital clock: displays a digital clock.
Analogue clock: displays an analogue clock.
This menu option allows you to select whether the
service light on the folder is used or not.
Main Contrast
To turn the light on, select one of the seven colours.
If you do not wish to use the service light, select Off.
This option allows you to adjust the contrast of the
main display to make it lighter or darker. Use the
and
keys or the volume keys on the left side of
the phone.
External Contrast
Language (Menu 5-4)
You can select a different language for the display,
text input modes and voice functions.
This option allows you to adjust the contrast of the
external display to make it lighter or darker. Use
the
and
keys or the volume keys on the left
side of the phone.
86
87
Phone Settings
Phone Settings
Security (Menu 5-5)
The security settings enable you to restrict the use of
your phone to:
• The people of your choice
• The types of calls of your choice
Various codes and passwords are used to protect the
features of your phone. They are described in the
following sections (also see page 133-134).
PIN Check
When the PIN Check feature is enabled, you must
enter your PIN each time you switch the phone on.
Consequently, any person who does not have your
PIN cannot use your phone without your approval.
Note: Before disabling the PIN Check feature, you
must enter your PIN.
The following options are available.
Enable: you must enter the PIN each time the phone
is switched on.
Disable: the phone connects directly to the network
when you switch it on.
To change your PIN, refer to the Change PIN menu
option on page 89.
Change PIN
This feature allows you to change your current PIN
to a new one, provided that the PIN Check feature is
enabled. You must enter the current PIN before you
can specify a new one.
Once you have entered a new PIN, you are asked to
confirm it by entering it again.
SIM Lock
To enable the SIM Lock feature, you must enter a
new four- to eight-digit SIM lock code, and confirm it
by entering it again. When the SIM Lock feature is
enabled, you must enter the SIM lock code to use
another SIM card in your phone.
To unlock the SIM, enter the SIM lock code.
FDN Mode
The FDN (Fixed Dial Number) mode, if supported by
your SIM card, allows you to restrict your outgoing
calls to a limited set of phone numbers.
The following options are available.
Enable: you can only call phone numbers stored in
the phonebook. You must enter your PIN2.
Disable: you can phone any number.
Note: Not all SIM cards have a PIN2. If your SIM
card does not, this menu option is not
displayed.
To change your PIN2, refer to the Change PIN2
menu option on page 90.
88
89
Phone Settings
Phone Settings
Change PIN2
The Change PIN2 feature allows you to change your
current PIN2 to a new one. You must enter the current
PIN2 before you can specify a new one.
Once you have entered a new PIN2, you are asked to
confirm it by entering it again.
Auto Redial (Menu 5-7)
With the Auto Redial function, the phone makes up
to ten attempts to redial a phone number after an
unsuccessful call.
Note: The interval between two call attempts varies.
Note: Not all SIM cards have a PIN2. If your SIM card
does not, this menu option is not displayed.
The following options are available.
Quick Menu (Menu 5-6)
On: the number is redialled automatically.
This menu allows you to create a quick way of
accessing specific menus using the voice command
feature or the navigation keys.
Voice command: to use the voice command feature,
refer to page 79.
Navigation: the four navigation keys can be used as
shortcut keys to the menu functions you use most
frequently. In idle mode, they allow you to access
specific menu options directly.
To assign a shortcut to a key, proceed as follows.
1. Select the shortcut key that you wish to change
by pressing the navigation keys, following by
the
soft key.
2. Select the menu option to be assigned to the key
by pressing the
or
key, and press the
soft key.
90
Off: the number is not redialled.
Active Folder (Menu 5-8)
With the Active Folder feature, the voice dial or voice
command mode can be activated automatically each
time you open the phone.
The following options are available.
Off: this feature is turned off. The voice dialling and
voice command modes must be activated manually
via the corresponding menu; for further information,
refer to page 77 and 79 respectively.
Voice dial: the voice dial mode is activated when
you open the phone.
Voice command: the voice command mode is
activated when you open the phone.
Note: When you use the ear-microphone, you can
use the Voice Dial or Voice Command features
by pressing the button on the ear-microphone.
91
Phone Settings
Organiser
Side Key (Menu 5-9)
This menu option allows you to set the function of
the volume keys on the left side of the phone when
you receive an incoming call.
The following options are available.
Reject: the incoming call is rejected when you hold
down the volume keys.
Silence: the ring tone is silenced but the call is not
rejected when you hold down the volume keys.
The Organiser feature enables you to:
• View the calendar and/or write a memo or to do
list
• Set the current date and time, and find out what
time it is in various cities around the world
• Set the alarm so that the phone rings at a specific
time
• Use your phone as a calculator, unit convertor,
timer or stopwatch
New Memo (Menu 6-1)
Reset Settings (Menu 5-0)
This menu option allows you to reset your phone to
its default configuration. You can reset the sound
settings, phone settings or all settings together.
When you are asked to confirm your choice, press
the
soft key. To exit the function without
resetting the settings, press the
soft key.
This menu option allows you to create a new memo.
Note: You can also access this menu by holding
down the
key in idle mode.
1. Write your memo of up to 100 characters and
press the
soft key.
For further information on how to enter text, see
page 37.
2. Select the category of the memo to be saved and
press the
soft key.
Scheduler: general schedule events, such as
appointments or meetings.
To-do list: tasks you need to do. They are saved
in the to do list.
Call: calls you need to make.
Anniversary: anniversaries to be remembered,
such as wedding anniversaries, birthdays or other
special days.
92
93
Organiser
Organiser
3. Select the required day on the calendar by pressing
the navigation keys. Press the
soft key.
4. If applicable, depending on the category selected,
enter the required time and press the
soft key.
If you have selected the 12-hour time format (see
page 100), select A M or P M by pressing the
or
key and then press the
soft key.
5. To set an alarm for the memo, press the Ye s soft
key.
Otherwise, press the N o soft key. The memo is
saved. Go to Step 8.
6. Enter the time for the alarm and press the
key.
soft
If you have selected the 12-hour time format (see
page 100), select A M or P M by pressing the
or
key and then press the
soft key.
7. Select the required tone for the alarm and press
the
soft key.
The memo is saved.
8. Press the
key to exit.
Calendar (Menu 6-2)
The calendar helps you to keep track of schedules,
calls that you need to make, tasks that you need to
do and anniversaries. You can set the phone to ring
when the set date for a schedule is reached.
Consulting the Calendar
To...
Then...
Move to another day
Press the
Move to another week Press the
and
keys.
and
Move to the previous Hold down the
or next month
key.
Move to the previous Hold down the
or next year
keys.
or
or
key.
The following options are available when you press
the Options soft key on the Calendar display.
Add memo: allows you to add a new memo on the
selected day.
Go to date: allows you to enter a particular date and
then schedule an event on that date.
View all: shows the events that you have
scheduled.
Delete day: deletes the scheduled event on the
selected day.
Delete all: deletes all the events that you have
scheduled.
94
95
Organiser
Organiser
Creating a New Memo
1. Select the required date in the calendar, referring
to page 95.
2. Write your memo of up to 100 characters and
press the
soft key.
For further information on how to enter
characters, see page 37.
3. When you press the
soft key, you can select a
memo type. Four types are available.
Scheduler: general schedule events, such as
appointments or meetings
To-do list: tasks you need to do
Call: calls you need to make
Anniversary: anniversaries to be remembered,
such as wedding anniversaries, birthdays or other
special days
4. Follow the procedure from Step 4 on page 94
onwards to save the memo.
A date that has a memo associated with it is
highlighted in a box. If you select a date for which
events have already been scheduled, the number of
memos of each type is shown in the bottom right
corner of the calendar:
for general schedule
events,
for tasks,
for calls and
for
anniversaries.
Press the
The following options are available when you press
the Options soft key.
Add: allows you to add a new memo. For further
information on how to add a memo, see page 93.
Delete: allows you to delete the current memo.
Edit: allows you to edit the current memo.
Move: allows you to move the current memo to a
different date.
Copy: allows you to copy the current memo to a
different date.
To-Do List (Menu 6-3)
This menu allows you to view a list of tasks.
To create a new memo of the To-do list type, refer to
page 93. When you are asked to specify the memo
type, select To-do list.
Once you have defined a task, it is listed with a
status mark (
for Done or
for Not Done)
within the To-do list menu.
To scroll to a specific task, press the
or
key,
and press the
soft key. The task is displayed with
the deadline, alarm setting, job details and status
mark.
soft key to view the memos.
If you have created more than one memo on the
same day, you can scroll to the required event by
pressing the or key.
96
97
Organiser
The following options are available when you press
the Options soft key.
Add: allows you to add a new task. For details about
adding To do list-type memos, see page 93.
Mark: allows you to change the status mark.
Edit: allows you to edit the contents of the current task.
Move: allows you to move the current task to a
different date.
Copy: allows you to copy the current task to a different
date.
Delete: allows you to delete the current task.
Delete all: allows you to delete all tasks from the list.
Organiser
World time: allows you to check the current time in
21 major cities around the world. Scroll through the
cities using the or key.
The screen shows the:
• City name
• Current date and time
• Time difference between the selected city and
your city if you have set the local time (see below
for further details) or GMT (by default)
To select your time zone, proceed as follows.
1. Select the city corresponding to your time zone by
pressing the or key one or more times.
The local date and time are displayed.
2. Press the Set soft key.
Clock (Menu 6-4)
This option allows you to change the current time and
date displayed. You can also check the current time for
Greenwich Mean Time (GMT) and 21 major cities
around the world.
The following options are available.
Set time: allows you to enter the current time. You can
choose the time format via the Set format menu
option.
Note: Before setting the time, you must specify your
time zone, via the World time menu option.
Set date: allows you to enter the day, month and year.
You can change the date format via the Set format
menu option.
98
3. To...
Select...
Update the current
date/time with this
new setting
Set local.
Indicate that the
time zone is currently
using the daylight
saving time
Set DST. The
icon is shown next to
the time difference.
Indicate that the time
zone is no longer
using the daylight
saving time
Remove DST (only
available when the
icon is shown
next to the time
difference).
99
Organiser
Organiser
Set format: allows you to change the time and date
formats.
Time format: 12 hours
24 hours
Date format: DD/MM/YYYY (day/month/year)
YYYY/MM/DD (year/month/day)
Alarm (Menu 6-5)
This option allows you to set the alarm to ring at a
specific time. You can set up to two alarms.
To set an alarm, proceed as follows.
1. Select Alarm1 or Alarm2 by pressing the
or
key and press the
soft key.
The
icon means that no alarm is currently set.
The
icon means that an alarm has already
been set.
2. Press the
soft key.
3. Select the required option and change the setting.
Alarm tone: select the required melody.
Remove alarm: deactivates the alarm.
4. Repeat Steps 2 and 3 to change each setting.
5. Press the
key to exit.
Once an alarm has been set, you can see the Alarm
icon ( ) on the top line of the display. To stop the
alarm when it rings, open the phone or press any key.
To set the alarm to ring even if your phone is switched
off, proceed as follows.
1. Scroll to Auto power in the Alarm list, and press
the
soft key.
2. If necessary, press the
or
key to select O n.
To turn the Auto Power feature off, select Off.
3. Press the
soft key to save the setting.
Once you have activated the auto power alarm, a
check mark appears to the left of Auto power. If the
phone is switched off at the specified alarm time, it
automatically switches on and rings the alarm. It then
automatically switches off again.
Alarm day: check the required day(s) of the week
by pressing the Select soft key. If you want to set
a daily alarm, select Everyday. If you want to set
a temporary alarm, select Once alarm. To
remove the check mark, press the Select soft key
again.
Alarm time: enter the required time.
100
101
Organiser
Organiser
Calculator (Menu 6-6)
Conversion (Menu 6-7)
You can use the phone as a 15-digit calculator. The
calculator performs basic arithmetic functions, such as
addition, subtraction, multiplication, division and
percentages.
This menu option allows you to convert from one
type of unit to another.
To perform a calculation, proceed as follows.
1. Select the type of conversion to be performed
from Currency, Length, Weight, Volume, A re a
and Temperature, and press the
soft key.
1. Enter the first figure using the number keys.
Note: To erase any mistakes or clear the display,
press the
key.
To convert a value, proceed as follows.
2. Enter the value to be converted and press the
key to move to the F ro m field.
2. Press the
key to enter a decimal point ( . ) or
the
key to enter the appropriate arithmetic
symbol: + (add), - (subtract), * (multiply), / (divide),
% (remainder), ( or ).
3. Select the original unit by pressing the or key
and press the
key to move to the To field.
Refer to the table on the following page for the
units available.
3. Enter the second figure.
4. Select the required unit by pressing the
key.
4. Repeat Steps 2 and 3, if necessary.
5. Press the Equal soft key to get the result.
The result appears in the Answer box.
102
or
5. Press the
soft key or the
key to view the
result.
The result appears in the Answer box.
103
Organiser
Organiser
Timer (Menu 6-8)
Units Available
Using the Timer feature, you can set the phone to
sound an alarm after a certain time.
Type
Units
Currency
EUR
FRF
ATS
PTE
LUF
DEM
ESP
BEF
GRD
Length
mm
km
yard
cm
in
mile
m
ft
Weight
g
grain
kg
oz
ton
pound
Volume
cm3
in3
gal
m3
ft3
l
yd3
2
2
1. Press the Set soft key.
2. Enter the length of time you wish to count down in
hours and minutes and press the
soft key.
3. Press the Start soft key to start counting down.
Area
cm
in2
acre
m
ft2
Temperature
°C
°F
104
ITL
NLG
FIM
IEP
a
yd2
Even if you exit the Timer screen, the timer will
continue running. After the specified time has expired,
the phone informs you by playing a melody and
displaying a text notification. To stop the timer melody
when it rings, open the phone or press any key.
To stop the timer before the end, press the Stop soft
key on the Timer screen.
Note: The timer uses power from the battery;
consequently, the phone’s operating time will
be reduced.
105
Organiser
Stopwatch (Menu 6-9)
The stopwatch can be used to measure times for
various sports.
Example: Running or swimming races.
Up to four stopwatches can be used.
The precision of the stopwatch is one hundredth of a
second. The maximum measurement time is 10 hours.
1. To start the stopwatches, press the
soft key.
2. When you wish to stop the first stopwatch, press
the
soft key. Repeat this step for the other
stopwatches.
3. Press the Reset soft key to reset the watches.
4. Press the
106
or
key to exit.
Network Services
These menu functions are network services.
Please contact your service provider to check their
availability and subscribe to them, if you so wish.
Call Diverting (Menu 7-1)
Note: The call divert options may be different
depending on your SIM card and those not
supported by your network operator may not
be shown.
This network service enables incoming calls to be
rerouted to the number that you specify.
Example: You may wish to divert your business calls
to a colleague while you are on holiday.
Call diverting can be set up in the following ways.
Divert always: all calls are diverted.
Busy: calls are diverted if you are already making
another call.
No reply: calls are diverted if you do not answer the
phone.
Unreachable: calls are diverted if you are not in an
area covered by your service provider.
Unavailable: calls are diverted if you are not
available, for example, when you are busy, do not
answer or cannot be reached.
Cancel all: all call diverting options are cancelled.
107
Network Services
You can specify individual call diverting options for
each of the following call types:
• Voice calls only
• Fax calls only (not available when line 2 is in use)
• Data calls only (not available when line 2 is in use)
Example: You can:
• Systematically divert fax calls to your
office fax machine
• Divert voice calls to your colleague if you
are already using the phone
Setting Call Diverting Options
1. Select the type of call diverting required by
pressing the
or
key and then press the
soft key.
Network Services
5. When you are satisfied, press the
key.
The phone sends your settings to the network and
the network’s acknowledgement is displayed.
Deactivating Specific Call Diverting Options
1. Select the call diverting option to be deactivated.
2. Select the type of calls to which this option
applies.
3. Press the Remove soft key.
The phone sends your settings to the network and
the network’s acknowledgement is displayed.
You can also deactivate all call diverting settings by
selecting the Cancel all option.
2. Select the type of calls to be diverted by pressing
the
or
key and then press the
soft key.
3. Press the Activate soft key to confirm your settings.
Call Barring (Menu 7-2)
4. Enter the number to which the calls are to be
diverted.
The call barring network service allows you to
restrict your calls.
To enter an international code, hold down
the
key until the + sign is displayed. You can
also select a number in the phonebook or the voice
server number, by pressing the
soft key,
followed by Phonebook or Voice server.
Call barring can be set up in the following ways.
All outgoing: calls cannot be made.
International: international calls cannot be made.
International except to home: when abroad, calls
can be made only to numbers within the current
country and to your home country, that is the country
where your home network provider is located.
108
109
Network Services
All incoming: calls cannot be received.
Incoming while abroad: calls cannot be received
when you are using your phone outside your home
service area.
Network Services
4. Enter your call barring password supplied by your
service provider.
The phone sends your settings to the network and
the network’s acknowledgement is displayed.
Cancel all: all call barring settings are deactivated;
calls can be made and received normally.
You can also deactivate all call barring settings by
selecting the Cancel all option.
You can specify individual call barring options for each
of the following call types:
• Voice calls only
• Fax calls only (not available when line 2 is in use)
• Data calls only (not available when line 2 is in use)
Change barring password: you can set and change
the call barring password obtained from your service
provider using this option. You must enter the current
password before you can specify a new one. Once you
have entered a new password, you are asked to
confirm it by entering it again.
Setting Call Barring Options
1. Select the type of call barring required by pressing
the
or
key and then press the
soft key.
2. Select the type of calls to be barred by pressing
the
or
key and then press the
soft key.
3. Press the Activate soft key to confirm your settings.
4. Enter your call barring password supplied by your
service provider.
The phone sends your settings to the network and
the network’s acknowledgement is displayed.
Deactivating Specific Call Barring Options
1. Select the call barring option to be deactivated.
2. Select the type of calls to which this option applies.
3. Press the Remove soft key.
110
Call Waiting (Menu 7-3)
This network service enables you to be informed when
someone is trying to reach you during another call.
You can specify individual call waiting options for
each of the following call types:
• Voice calls only
• Fax calls only (not available when line 2 is in use)
• Data calls only (not available when line 2 is in use)
Activating the Call Waiting Feature
1. Select the type of calls to which the call waiting
option is to be applied by pressing the
or
key and then press the
soft key.
2. Press the Activate soft key to confirm your settings.
The phone sends your settings to the network and
the network’s acknowledgement is displayed.
111
Network Services
Network Services
Deactivating Specific Call Waiting Options
1. Select the type of call to which the option applies.
2. Press the Deactivate soft key.
The phone sends your settings to the network and
the network’s acknowledgement is displayed.
You can also deactivate all call waiting settings by
selecting the Cancel all option.
Network Selection (Menu 7-4)
The Network Selection feature enables you to control
whether the network used when roaming (outside
your home area) is selected automatically or manually.
Note: You can select a network other than your home
network only if it has a valid roaming
agreement with your home network.
To indicate whether the network is to be selected
automatically or manually when roaming, proceed as
follows.
2. Press the
or
key until the preferred
network is highlighted and press the
soft key.
You are connected to that network when roaming.
Caller ID (Menu 7-5)
You can prevent your phone number from being
displayed on the phone of the person being called.
Note: Some networks do not allow the user to
change this setting.
The following options are available.
Default: the default setting provided by the network
is used.
Hide number: your number is not displayed on the
other person’s phone.
Send number: your number is sent each time you
make a call.
1. Press the
or
key until the appropriate
option is highlighted and press the
soft key.
If you select Automatic, you are connected to the
first available network when roaming.
If you select Manual, the phone scans for the
available networks. Go to Step 2.
112
113
Network Services
Network Services
Active Line (Menu 7-6)
Activating a Closed User Group
Some SIM cards may be used with two subscriber
numbers. This function is available only if your SIM
card supports it.
When you select the Closed user group menu
option, you are asked if you want to activate the CUG
function. Press the
soft key to confirm.
This menu option allows you to select the line to be
used to make calls. However, calls can be answered
on both lines, regardless of the selected line. When
you select a line, the line number appears as an
indicator after the operator/service provider’s name.
If you select the Manual option, you can choose a
line whenever you use the auto-redialling, call
barring, call diverting or call waiting functions.
Closed User Group (CUG) (Menu 7-7)
This network service allows incoming and outgoing
calls to be restricted to a selected user group. You
may be a member of up to 10 user groups.
For details on how to create, activate and use a
closed user group, contact your service provider.
Example: A company lends SIM cards to its employees
and wants to restrict outgoing calls to
members of the same team.
114
You can now access the following options.
Index list: lets you list, add or delete CUG index
numbers. The list of current CUG indexes appears.
Add a new CUG index (as advised by your service
provider) or delete a selected group.
To...
Scroll through the
existing CUG indexes
Press the...
or
key.
Add a new CUG index
Option soft key, select
Add and enter the index.
Delete a CUG index
or
key to select
the index you want to
delete, press the Option
soft key and select
Delete.
Outside access: enables you to allow or prohibit
calls to numbers other than those nominated for the
Closed User Group. This feature depends on the
nature of your CUG subscription. Please check with
your service provider.
115
Network Services
Fun Box
Default group: you may set a default CUG with your
service provider. If you have done so, you can enable
the Default group option on your phone. When
making a call, you will be given the option of using
your default CUG, instead of selecting one from the
list.
The Fun box menu contains several fun options:
• WWW Browser
• Games
• Media box
WWW Browser
(Menu 8-1)
Deactivate: deactivates the CUG function.
Your phone comes equipped with a WAP (Wireless
Application Protocol) Browser, making it possible for
you to access the Wireless Web.
The WAP Browser allows you to:
• Access up-to-the-minute information via your phone
• View specially designed text versions of popular
Internet sites
Browsing the Wireless Web using your phone is
unlike using your computer, in that site providers
have:
• Selected only the critical aspects of their site for
wireless phone users
• Removed most graphics
Each time you start the WAP Browser, the phone
connects to the Wireless Web and the service
indicator icon ( ) appears on the display to inform
you that you are:
• Connected to the Wireless Web
• Will be billed accordingly (rates vary according to
your service option)
116
117
Fun Box
The WAP Browser ends the network connection after
a certain period of inactivity and automatically
reconnects as necessary. For this reason, you may
find that you are billed for several network
connections within a single session. This is normal
and is designed to minimise your bill.
Fun Box
To store a URL address, proceed as follows.
1. Select an empty location and press the Add soft key.
2. Enter the address and press the
soft key.
For further information on how to enter text, see
page 37.
Home
3. If necessary, change the title and press the
key to save your input.
When you select this menu option, the phone
connects to the network and loads the homepage of
the Wireless Web service provider.
Once you have stored the addresses, three sub-menus
are available when you press the
soft key.
Once connected, the homepage is displayed. The
content depends on the service provider.
Remove: allows you to delete the selected bookmark.
Note: To launch the browser from the idle mode,
press the key.
The content of the WAP Browser startup homepage
depends on your Wireless Web service provider. To
scroll through the screen, use the
and
keys.
To exit the browser, press the
key at any time.
The phone returns to the idle mode.
soft
Go to URL: allows you to access the site directly.
Edit: allows you to edit the address and title of the
bookmark.
Go to URL
This menu option allows you to manually enter the URL
address of the Web site that you wish to access.
Enter the URL address and press the
soft key.
Clear Cache
Bookmark
This menu option allows you to store the URL
addresses of up to 30 of your favourite Web sites.
You can access this menu directly by holding down
the
key while using the WAP Browser.
118
This menu option allows you to clear the information
stored in the cache (the phone’s temporary memory
used to store the most recently accessed Web pages).
119
Fun Box
Fun Box
Browser Setting
Navigating the WAP Browser
This menu option allows you to:
• Set up the proxy servers
• Choose one of the proxy servers to be used when
accessing the Wireless Web
To...
Then...
Scroll through and
select browser items
Press the
or
key
until the required item is
highlighted, and then press
the
soft key.
Select a numbered
item
Press the corresponding
numeric key.
Return to the
previous page
Press the
Return to the startup
homepage
Select the Home browser
option; for more information
on this option, refer to
page 118.
P roxy setting: allows you to set up seven proxy
servers for the WAP Browser. For each proxy, the
following options are available.
Name: name of the HTTP proxy server.
WDP address: WDP address required to connect to the
Wireless Web.
Security: data transmission mode. Select Secure to
protect your data against unauthorised access;
otherwise, select Non-secure.
Home URL: address of your startup homepage.
When the default homepage is displayed, you can
delete it using the
key and enter your own choice.
To enter any special characters (/ for example), use the
symbolic mode (see page 44).
Dial number: PPP server phone number.
Login: PPP server login ID.
Password: PPP server password.
Network type: network type. Select V32 Transparent,
V32 Non-transparent, V110 Transparent or V110
Non-transparent.
Note: The WAP Browser settings may vary, depending
on the service provider. Contact your service
provider for further information.
Current pro x y: allows you to activate one of the
proxies set up.
120
soft key.
Entering Text, Numbers or Symbols
When you are prompted to enter text, the current text
input mode appears above the right soft key:
abc/Abc/ABC, NUM or SYM 1 ~ 4. To change the mode,
press the right soft key until the required mode is
displayed.
abc/Abc/ABC: allows you to enter lower-case and
upper-case letters. You can change cases by pressing
the
key.
SYM1 ~ 4: allows you to enter various symbols and
punctuation marks. To view more symbols, press the
More soft key.
NUM: allows you to enter numbers.
121
Fun Box
Fun Box
Using the WAP Browser Menu
Using the WAP Browser Options
There are various menu options available when surfing
the Wireless Web.
To access the WAP Browser menu, proceed as follows.
Several options are available when you are surfing
the Wireless Web. To access these options, press the
key once connected to the Wireless Web.
1. Press the
key.
A list of options appears.
Go to URL: allows you to manually enter the URL
address of the site that you wish to access.
2. Highlight the required option using the
key.
3. Press the
or
soft key to select the option.
4. If necessary, select the secondary option by pressing
the
or
key, followed by the
soft key.
Note: The WAP Browser menus may vary, depending
on your version of the browser.
Bookmark: allows you to use the Bookmark menu
option. For details, refer to page 118.
Message Services: allows you to read or write an
SMS message.
Phonebook: allows you to use the phonebook
option.
Media Box: allows you to download an image or
melody into the media box.
The following options are available.
B a c k: returns to the previous page.
Home: takes you back at any time to the homepage of
the Wireless Web service provider.
Exit: exits the WAP browser.
Mark Site: adds the current page to your bookmark list.
Bookmarks: allows you to load a bookmarked Web
page directly.
Inbox: stores received push messages or WAP data.
Reload: reloads the current page.
About: shows the version of the WAP Browser.
122
123
Fun Box
Fun Box
Games (Menu 8-2)
Using this menu option, you can also enjoy playing
three games.
Scroll to the required game by pressing the
key and press the
soft key.
or
To select an option, press the corresponding number
key. The following options are available.
New Game: allows you to start a new game.
High Score: shows you the High Score table.
Not all games have this option.
Key Info.: shows you which keys do what within the
game.
Continue: allows you to continue a previously saved
game. The menu is only available when a game has
already been saved.
While you are playing
a game, to...
Press the...
Adjust the game volume
Volume keys.
Pause/resume the game
key.
Exit the game
Fortress
The goal of the game is to defend the earth against
UFOs. You can check for the appearance of UFOs in
the radar at the bottom of the screen. Each level is
completed if you manage to defend the city without
running out of time or energy. You can monitor your
energy and remaining time to the left and right of the
radar.
When the start screen appears, press any key to
start the game. You will see a map of the earth. The
‘V’ mark mean you have already defended that city.
Key Commands
2: move up
8: move down
4: move left
6: move right
5: shoot
key.
At the end of the game, if your score is ranked fifth or
higher, you may enter a name of up to 10 characters.
124
125
Fun Box
Fun Box
Space War
Media Box (Menu 8-3)
Space War is an arcade board game. It requires
patience and discretion. The aim is to remove about
80% of the background while avoiding the mushroom
bombs in order to progress to the next stage.
You can view the images and melodies available in
your phone.
When the start screen appears, press any key to
start the game.
Key Commands
2: move up
4: move left
6: move right
8: move down
5: stop
X-Flighter
The goal of the game is to fly a fighter plane to its
destination. There are three stages, each stage is
harder than the previous and the weapons get more
powerful with each stage.
The following options are available.
Image: allows you to view the images received from
other sources, such as the Internet or other phones.
Press the
soft key to rename the Image or delete
it.
Melody: allows you to listen to the melodies
received from other sources, such as the Internet or
other phones. Press the
soft key to rename the
Melody or delete it.
Delete all: deletes all images and melodies in the
media box.
When the start screen appears, press any key.
Press
or
to select a player and press
to start a game.
Key Commands
1: move up
4: move left
5: move right
7: move down
6: launch a missile
9: drop a bomb
126
127
Additional Services
Additional Services
ALS (Alternate Line Service)
Note: Please contact your service provider to check
the availability of this feature and how to
subscribe to ALS.
The ALS feature enables two lines to be associated
with one SIM card. Consequently, you can make and
receive calls on either line. If you subscribe to this
network service, a few additional menu options
enable you to set up this feature.
Selecting a Line
Setting Call Diverting Options
You can set up call diverting via the Call diverting
menu option. This service reroutes incoming calls on
the line of your choice to a specified number. For
further details, see page 107.
Viewing Call Information
You can view call times and last call cost information
for each line. For further details, see pages 75 and 76.
You can select a line for each call via the Active
line menu option. For further details, refer to
page 114.
Editing the Line Name
You can edit the name of each line via the O w n
number menu option.
When you edit the name of a line, this name
replaces “Line 1” or “Line 2”, as applicable. For
further details, refer to page 55.
Setting the Ring Type
To distinguish between incoming calls on the two
lines, you can select a different ring tone for each line
via the Incoming calls menu option. See page 81
for further details.
128
129
Solving Problems
Solving Problems
“No service” is displayed
Before contacting the after-sales service, perform the
following simple checks. They may save you the time
and expense of an unnecessary service call.
When you switch your phone on, the following
messages appear
No SIM Card
• Check that the SIM card is correctly installed.
Enter PIN
• You are using your phone for the first time. You
must enter the Personal Identification Number
supplied with the SIM card.
• The option requiring that the PIN be entered each
time the phone is switched on was enabled. You
must enter your PIN and then disable this option if
so required.
Enter PUK
• The PIN was entered wrongly three times in
succession and the phone is now blocked. Enter
the PUK supplied by your network operator.
130
• The network connection was lost. You may be in a
weak reception area (in a tunnel or surrounded by
buildings). Move and try again.
• You are trying to access an option for which you
have not taken out a subscription with your
service provider. Contact the service provider for
further details.
You have entered a number but it was not dialled
• Have you pressed the
key?
• Are you accessing the right cellular network?
• You may have set an outgoing call barring option.
Your correspondent cannot reach you
• Is your phone switched on (the
key pressed
for more than one second)?
• Are you accessing the right cellular network?
• You may have set an incoming call barring option.
Your correspondent cannot hear you speaking
• Have you switched off the microphone (Mute
appears)?
• Are you holding the phone close enough to your
mouth? The microphone is located on the bottom
right of the phone.
131
Solving Problems
Reference Information
The phone starts beeping and “Battery Low”
flashes on the display
• The battery is insufficiently charged. Replace the
battery and recharge it.
The audio quality of the call is poor
• Check the signal strength indicator on the display
(
); the number of bars indicates the signal
strength from strong (
) to weak ( ).
• Try moving the phone slightly or moving closer to
a window if you are in a building.
No number is dialled when you recall a
phonebook entry
• Check that the numbers have been stored
correctly, by using the Phonebook Search feature.
• Re-store them, if necessary.
If the above guidelines do not help you to solve
the problem, take a note of:
• The model and serial numbers of your phone
• Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung
after-sales service.
Access Codes
There are several access codes that are used by your
phone and its SIM card. These codes help you protect
the phone against unauthorised use.
The access codes (except for the PUK and PUK2 codes)
can be changed using the Security menu option. See
page 88 for further details.
PIN
The PIN (Personal Identification Number) protects your
SIM card against unauthorised use. It is usually
supplied with the SIM card. When the PIN Check
feature is enabled (see page 88), you must enter the
PIN each time you switch on the phone.
If you key in an incorrect PIN three times in succession,
key in the PUK and press the
soft key to unlock the
phone. Key in a new PIN and press the
soft key.
Key in the new PIN again and press the
soft key.
PIN2
The PIN2, supplied with some SIM cards, is required to
access some functions, such as charging unit counters.
These functions are only available if supported by your
SIM card.
If you key in an incorrect PIN2 three times in succession,
key in the PUK2 and press the
soft key to unlock the
phone. Key in a new PIN2 and press the
soft key.
Key in the new PIN2 again and press the
soft key.
132
133
Reference Information
PUK
The PUK (Personal Unblocking Key) is required to
change a blocked PIN. The PUK may be supplied with
the SIM card. If not, contact your local service
provider.
If you key in an incorrect PUK ten times in succession,
the SIM card cannot be used anymore. Contact your
service provider for a new card.
You cannot change the PUK. If you lose the code,
contact your service provider.
PUK2
The PUK2, supplied with some SIM cards, is required
to change a blocked PIN2.
If you key in an incorrect PUK2 ten times in succession,
you cannot use the functions requiring the PIN2.
Contact your service provider for a new card.
You cannot change the PUK2. If you lose the code,
contact your service provider.
Reference Information
Health and Safety Information
Exposure to Radio-Frequency Energy
(SAR Information)
This phone meets European Union (EU) requirements
concerning exposure to radio waves.
Your mobile phone is a radio transmitter and receiver.
It is designed and manufactured, so as not to exceed
the limits for exposure to radio-frequency (RF) energy,
as recommended by the EU Council. These limits are
part of comprehensive guidelines and establish
permitted levels of RF energy for the general
population. The guidelines were developed by
independent scientific organisations through the
periodic and thorough evaluation of scientific
studies. The limits include a substantial safety
margin designed to ensure the safety of all persons,
regardless of age and health.
The exposure standard for mobile phones employs a
unit of measurement known as SAR (Specific
Absorption Rate). The SAR limit recommended by the
EU Council is 2.0W/kg.*
Call Barring Password
The 4-digit call barring password is required when
you use the Call Barring function. You obtain the
password from your service provider when you
subscribe to this function.
* The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/kg) averaged
over ten grams of body tissue. The limit incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations in measurements. The SAR
values may vary depending on national reporting requirements and the network band.
134
135
Reference Information
Reference Information
Precautions When Using Batteries
SAR tests are conducted using standard operating
positions with the phone transmitting at its highest
certified power level in all tested frequency bands.
Although the SAR is determined at the highest
certified power level, the actual SAR level of the
phone while operating can be well below the
maximum value. This is because the phone is
designed to operate at multiple power levels so as to
use only the power required to reach the network. In
general, the closer you are to a base station, the
lower the power output of the phone.
Before a new model phone is available for sale to
the public, compliance with the European R&TTE
Directive must be shown. This directive includes as
one of its essential requirements the protection of
the health and safety of the user and any other
person.
Your phone is powered by a rechargeable Li-ion
standard battery.
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby times
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging times depend on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsungapproved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than
a week, since overcharging may shorten its life.
136
137
Reference Information
Reference Information
Road Safety
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter conditions,
as you will reduce the capacity and life-time of
the battery. Always try to keep the battery at
room temperature. A phone with a hot or cold
battery may temporarily not work, even when the
battery is fully charged. Li-ion batteries are
particularly affected by temperatures below 0 °C
(32 °F).
• Do not short-circuit the battery. Accidental short
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between
the + and – terminals of the battery (metal strips
on the back of the battery), for example when
you carry a spare battery in a pocket or bag.
Short-circuiting the terminals may damage the
battery or the object causing the short-circuit.
• Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user
must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of
a car, practice good common sense and remember
the following tips.
1. Get to know your wireless phone and its features,
such as speed-dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an extra layer of convenience and
safety to your wireless phone with one of the
many hands-free accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
138
139
Reference Information
5. Do not take notes or look up phone numbers while
driving. Jotting down a to do list or flipping through
your phonebook takes your attention away from
your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
is stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make the
people with whom you are talking aware that you
are driving and suspend conversations that have
the potential to divert your attention from the road.
8. Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic
accident or medical emergencies. Remember, it is a
free call on your wireless phone!
Reference Information
Operating Environment
Remember to follow any special regulations in force
in any area and always switch off your phone
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it is
recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
Electronic Devices
9. Use your wireless phone to help others in
emergencies. If you see a car accident, crime in
progress or other serious emergency where lives
are in danger, call the emergency number, as you
would want others to do for you.
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
10. Call roadside assistance or a special nonemergency wireless assistance number when
necessary. If you see a broken-down vehicle posing
no serious hazard, a broken traffic signal, a minor
traffic accident where no one appears injured, or a
vehicle you know to be stolen, call roadside
assistance or any other special non-emergency
wireless number.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker. These
recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
140
141
Reference Information
Persons with pacemakers:
• Should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimise potential interference
If you have any reason to suspect that interference is
taking place, switch off your phone immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch off your phone in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Reference Information
Posted Facilities
Switch off your phone in any facility where posted
notices require you to do so.
Potentially Explosive Atmospheres
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch off the phone while at a
refuelling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
142
143
Reference Information
Reference Information
Emergency Calls
Other Important Safety Information
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user-programmed functions, which cannot
guarantee connection in all conditions. Therefore, you
should never rely solely on any wireless phone for
essential communications (medical emergencies, for
example).
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty installation
or service may be dangerous and may invalidate
any warranty applicable to the device.
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
To make an emergency call, proceed as follows.
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 112 or any other official
emergency number). Emergency numbers vary by
location.
3. Press the
key.
If certain features are in use (call barring, for example),
you may first need to deactivate those features before
you can make an emergency call. Consult this
document and your local cellular service provider.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating properly.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch off your phone before boarding an aircraft.
The use of wireless phones in aircraft may be
dangerous to the operation of the aircraft, and is
illegal.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
144
145
Reference Information
Reference Information
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode
electronic circuits.
• Do not touch the phone with wet hands while it is
charging. Doing so may give you an electric shock
or damage the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it
with a soft cloth slightly dampened in a mild
soap-and-water solution.
• Do not paint the phone. Paint can clog the
device’s moving parts and prevent proper
operation.
• Use only the supplied or an approved replacement
antenna. Unauthorised antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone’s electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
146
147
Glossary
To help you understand the main technical terms and
abbreviations used in this booklet and take full
advantage of the features of your mobile phone, here
are a few definitions.
Active Folder
Ability to voice dial or submit a voice command
immediately on opening the phone.
ALS (Alternate Line Service)
Capability of associating two lines with one SIM
card. With this service, you can make and receive
calls on either line, as required.
Call Barring
Ability to restrict outgoing and incoming calls.
Call Diverting
Ability to reroute calls to another number.
Call Holding
Ability to put one call on standby while answering or
making another call; you can then switch between
the two calls, as required.
Call Waiting
Ability to inform users that they have an incoming call
when engaged on another call.
148
Glossary
CLI (Caller Line Identification) Services
Services allowing subscribers to view or block the
telephone numbers of callers.
GSM (Global System for Mobile Communication)
International standard for cellular communication,
guaranteeing compatibility between the various
network operators. GSM covers most European
countries and many other parts of the world.
Multiparty Calling
Ability to establish a conference call involving up to
five additional parties.
PIN (Personal Identification Number)
Security code that protects the phone/SIM against
unauthorised use. The PIN is supplied by the service
provider with the SIM card. It may be a four to eightdigit number and can be changed, as required.
PUK (PIN Unblocking Key)
Security code used to unlock the phone when an
incorrect PIN has been entered three times in
succession. The eight-digit number is supplied by
the service provider with the SIM card.
Roaming
Use of your phone when you are outside your home
area (when travelling for example).
149
Glossary
Index
SIM (Subscriber Identification Module)
Card containing a chip with all the information
required to operate the phone (network and memory
information, as well as the subscriber’s personal
data). The SIM card fits into a small slot on the back
of the phone and is protected by the battery.
SMS (Short Message Service)
Network service sending and receiving messages to
and from another subscriber without having to speak
to the correspondent. The message created or
received can be displayed, received, edited or sent.
Soft Keys
Two keys marked
and
on the phone, the
purpose of which:
• Varies according to the function that you are
currently using
• Is indicated on the bottom line of the display just
above the corresponding key
Voice Mail
Computerised answering service that automatically
answers your calls when you are not available, plays
a greeting (optionally in your own voice) and records
a message.
150
A
C (continued)
ABC mode • 37; 41
Access codes • 133
Accessories • 9
Active folder • 91
Active line • 114
Alarm • 100
Alert type • 81; 82
ALS • 128
Answering
calls • 26
second call • 30
Auto
power • 91
redial • 91
Calls (continued)
missed • 25; 74
multiparty • 32
received • 74
records • 74
redialling • 24
automatically • 91
rejecting • 27
ring tone • 81
searching for a number in
the phonebook • 48
times • 75
via the phonebook • 48
voice functions • 77
waiting • 30; 111
Card
dialling numbers • 53
inserting • 17
lock • 89
removing • 18
Care • 146
Changing
PIN • 89
PIN2 • 90
text input modes • 38
Characters
entering • 37
Charging batteries • 20; 21
Chatting • 69
Clock • 98
Closed User Group • 114
Conference calls
• See Multiparty calls
Connecting to voice mail • 69
Connection tone • 83
Contrast • 86
Conversion • 103
Copying phonebook
numbers • 50
Correcting numbers • 23
Cost of calls • 76
CUG • 114
B
Backlight • 15; 87
Barring
calls • 109
password • 111; 134
Battery
charger • 21
charging • 20; 21
installing • 18
low battery indicator • 21
precautions • 137
removing • 19
Broadcast • 72
Browser • 117
C
Calculator • 102
Calendar • 95
Caller
groups • 54
ID • 113
Calls
alert types • 81
answering • 26
a second call • 30
barring • 109
costs • 76
dialled • 75
diverting • 107
emergency • 144
ending • 26
holding • 28
international • 24
log • 24
making • 23
D
Date setting • 98
Dialled calls • 75
Dialling • 23
phonebook numbers • 48
SIM card numbers • 53
voice • 77
151
Index
Index
D (continued)
K
M (continued)
P
Display
contrast • 86
external • 15; 86
icons • 14
main • 13; 86
power on/off image • 85
settings • 85
Diverting calls • 107
Key tones
selecting • 83
volume • 27
Keys
location • 10
purpose • 11
shortcuts • 90
Minute minder • 84
Missed calls • 25; 74
Multiparty calls
making • 32
private conversation • 33
removing a participant • 33
Mute
microphone • 28
E
FDN mode • 89
Fixed Dial Number mode • 89
Fun box • 117
Functions
selecting • 35
Language • 87
Last number redialling • 24
LCD
contrast • 86
external • 15; 86
icons • 14
main • 13; 86
power on/off image • 85
settings • 85
Length of calls • 75; 84
Letters
entering • 37
Locking
SIM card • 89
Low battery indicator • 21
G
M
Games • 124
Fortress • 125
Space War • 126
X-Flighter• 126
Greeting message • 85
Group settings • 54
Maintenance • 146
Media box • 127
Medical devices • 142
Melodies • 81
Memory status • 56
Memos
text • 93; 96
voice • 80
Menu
list • 59
scrolling • 58
Messages • 63
alert types • 82
broadcast • 72
chatting • 69
deleting • 71
greeting • 85
inbox • 63
outbox • 65
preset • 70
reading • 63
ring tone • 82
settings • 70
voice mail • 68
writing • 65; 66
Microphone mute • 28
Phonebook • 45
changing names • 49
copying numbers • 50
creating entries • 45
deleting numbers • 50
dialling • 48
editing numbers • 49
erasing numbers • 50
making calls • 48
memory status • 56
options • 49
own numbers • 55
recorded names • 78
searching • 48
sending SMS • 50
speed-dialling • 51
storing numbers/
names • 45
voice recording • 77
PIN • 133
changing • 89
checking • 88
PIN2 • 133
changing • 90
Preset messages • 70
Problem solving • 130
PUK • 134
PUK2 • 134
Ear-microphone • 34
Earpiece volume • 27
Emergency calls • 144
Ending calls • 26
Entering text • 37
Explosive atmospheres • 143
External display • 15
F
H
Health • 135
Hearing aids • 142
Holding calls • 28
I
Icons • 14
Identifying a caller • 113
external display • 86
main display • 86
power on/off • 85
Inbox • 63
Information numbers • 57
Input mode
changing • 38
setting • 87
International calls • 24
Internet • 117
152
L
N
Names
changing • 49
entering • 37
searching/dialling • 48
storing • 45
voice dial • 77
Network selection • 112
Network services • 107
Numbers
correcting • 23
FDN • 89
information • 57
mode • 37; 44
own • 55
redialling • 24
searching/dialling • 48
speed-dial • 51
storing • 45
voice dial • 77
voice server • 68
O
Options
phonebook • 49
selecting • 35
Organiser • 93
Outbox • 65
Own number • 55
P
Pacemakers • 141
Password
barring • 111; 134
Personal Identification Number
• See PIN
Phone
layout • 10
settings • 85
switching on/off • 22
(continued)
Q
Quick menu • 90
Quiet mode • 84
R
Radio-frequencies • 135
Reading messages • 63
Received calls • 74
Recording
voice commands • 79
voice dial names • 78
voice memos • 80
Redialling
automatically • 91
last number • 24
Rejecting calls • 27
Reset settings • 92
Road safety • 139
Ring tone
incoming calls • 81
messages • 82
153
154
key.
Press the
• Each of the two soft keys ( and )
performs the function indicated by the
text above it (bottom line in the display).
End a Call
➀ Open the phone.
➁ Say the name.
(Voice Dial)
➀ Key in the number.
➁ Press the
key.
(Direct Call)
Make a Call
Provided that the name is
recorded and the Active
folder menu option is set
to Voice dial:
soft key to
➃ Press the
confirm.
Waiting
call • 30; 111
WAP Browser • 117
World time • 99
Writing messages • 65; 66
WWW Browser • 117
➂ Scroll with the
or
key through the
list of options until the
required option is
selected.
W
Press and hold down
the
key.
Voice
command • 79
dial • 52;77
functions • 77
language • 87
mail
connecting to • 69
server number • 68
memo • 80
server number • 68
volume • 83
Volume
earpiece • 27
keys • 27
voice guide • 83
Switch On/Off
V
➁ Scroll with the or
key through the main
menus until you reach the
required menu.
User groups • 114
Quick Reference Card
U
soft key in
T9 mode • 37; 39
Text
entering • 37
input modes • 37
language • 87
Time
setting • 98
world • 99
Timer • 105
To-do list • 97
Tone
connection • 83
incoming call • 81
keypad • 83
message • 82
Travel adapter • 20
➀ Press the
idle mode.
T
Safety
batteries • 137
electronic devices • 141
explosive atmospheres • 143
information • 135; 145
medical devices • 142
operating environment • 141
precautions • 7
road • 139
Scratchpad • 30
Searching/dialling
phonebook numbers • 48
Second call • 30
Security settings • 88
Selecting functions/options • 35
Service directory • 57
Service light • 16; 87
Settings
alarm • 100
date • 98
display • 85
network • 107
phone • 85
reset • 92
security • 88
SMS • 70
sound • 81
text language • 87
time • 98
Shortcuts • 90
Side key • 92
SIM card
dialling numbers • 53
inserting • 17
lock • 89
removing • 18
SMS
See Messages
Solving problems • 130
Sound settings • 81
Speed-dialling • 51
Stopwatch • 106
Switching on/off
auto power • 101
microphone • 28
phone • 22
Symbolic mode • 37; 44
Access
the Menu
Functions
S
SGH-A800 GSM Telephone
Index
155
Answer a
Call
Open the phone
or
Press the volume keys on
the left side of the phone.
key.
Adjust the
Volume
Press the
Press the
Redial the
Last Number
key twice.
Speed-Dial
In idle mode hold down
the appropriate key
(
to
).
Press the
key.
Dial a Number Enter the SIM location,
in Your SIM
press
followed
Card
by
.
Listen to Your
Voice Mail
Store
Numbers
in the
Phonebook
➀ Key in the number.
➁ Press the Save soft key.
➂ Select the memory type.
soft key.
➃ Enter the name.
➄ Press the
➅ Select the category.
➆ Press the Save soft key.
Search for a ➀ Press the
soft key
in idle mode.
Number
in the
➁ Select Find name or
Phonebook
Find number.
➂ Enter a name or number.
➃ Press the
soft key.
➄ Press the or key,
if necessary.
➅ Press the
key to
dial.
156
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
