PCV-E302DS/308DS SERVICE MANUAL US Model

PCV-E302DS/308DS SERVICE MANUAL US Model

PCV-E302DS/308DS (US)

PCV-E302DS/308DS

SERVICE MANUAL

US Model

9-974-498-11

Sony Corporation

Information Technologies of America

English

98J205-1

Printed in USA

© 1998.10

Published by Engineering & Manufacturing Division

Specifications

Model Number

Processor

Hard Disk Drive

DVD-ROM Drive

DVD-ROM Laser

Memory Modules

PCV-E302DS PCV-E308DS

350 MHz Pentium II 450 MHz Pentium II

10.2 GB 13.6 GB

Reads DVD data 2X-5X variable transfer rate. Reads CD data from 10X to 24X variable transfer rate*

Semiconductor Laser GaA1As, 650nm (

±

15 nm) wave length;

0.6mw (typ.) output power

PCV-E302-64 MB SDRAM expandable to 256 MB, 8MB Video RAM

PCV-E308-128MB SDRAM expandable to 256 MB,8MB Video RAM

512 KB Pipeline Burst SRAM L2 Cache

MPEG

Graphics

“Sony Tuned” MPEG Digital Video supports full-screen and DVD playback

3D AGP graphics acceleration (64-bit Matrox G200)

Sound Capabilities Dynamic High Fidelity 3D PCI Audio Sound (Aureal)

Diskette Drive 3.5” 1.44 MB MFDD

Modem

Expansion

Capabilities

56 Kbps modem/14.4 Kbps FAX modem with V.90 Technology

One PCI slot

* Data on a CD-ROM disc is read at a variable transfer rate, ranging from

10X at the innermost track to 24X at the outermost track (the data transfer standard 1X rate is 150 kbytes/s). The average data transfer rate is 17X

(2550 kbytes/s).

Connection

Capabilities

Keyboard (USB style)

Mouse (PS/2 style)

Two USB ports

Three IEEE 1394 Ports (1 - 4 Pin, 2 - 6 Pin)

Serial port

Parallel (printer) Port

MIDI/game Port

Headphone Out

Line In

Microphone In

Monitor Connector

Video Out

S Video Out

Modem line (RJ-11)

Phone line (RJ-11)

S Link (Control-A1) Port

Supplied Sony 104-key keyboard,Sony two-button mouse

Accessories RJ-11 Phone Cable, Power Cord

PERSONAL COMPUTER VAIO

9-974-498-11

Information in this document is subject to change without notice.

Sony and VAIO are trademarks of Sony. Intel logo and Intel Inside logo are registered trademarks of Intel Corporation. i486 and Pentium are trademarks of Intel Corporation. Microsoft, MS-

DOS, Windows and the Windows 95 logo are trademarks of Microsoft Corporation.

All other trademarks are trademarks or registered trademarks of their respective owners.

Other trademarks and trade names may be used in this document to refer to the entities claiming the marks and names or their products. Sony

Corporation disclaims any proprietary interest in trademarks and trade names other than its own.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Service and Inspection Precautions

1. Obey precautionary markings and instructions

Labels and stamps on the cabinet, chassis, and components identify areas requiring special precautions. Be sure to observe these precautions, as well as all precautions listed in the operating manual and other associated documents.

2. Use designated parts only

The sets components possess important safety characteristics, such as noncombustibility and the ability to tolerate large voltages. Be sure that replacement parts posses the same safety characteristics as the originals. Also remember

▲ diagrams and parts lists, denotes components that have particularly important safety functions; be extra sure to use only the designated components.

3. Always follow the original design when mounting parts and routing wires.

The original layout includes various safety features, such as inclusion of insulating materials (tubes and tape) and the mounting of parts above the printer board. In addition, internal

-2wiring has been routed and clamped so as to keep it away from hot or high-voltage parts. When mounting parts or routing wires, therefore, be sure to duplicate the original layout

4. Inspect after completing service

After servicing, inspect to make sure that all screws, components, and wiring have been returned to their original condition. Also check the area around the repair location to ensure that repair work has caused no damage and confirm safety.

5. When replacing chip components…

Never reuse components. Also remember that the negative side of tantalum capacitors is easily damaged by heat.

6. When handling flexible point boards…

•The temperature of the soldering-iron temp

shoud be about 270

°

C.

• Do not apply the tip more than three times to

the same pattern.

• Handle patterns with care; never apply force.

Caution: Remember that hard disk drives are easily damaged by vibration. Always handle with care.

TABLE OF CONTENTS

Section Title Page

Chapter 1. Operation

1-1

1-2

VAIO MicroTower Read Me First .................................... 1-1

(to 1-12)

VAIO MicroTower User Guide ...................................... 1-13

(to 1-62)

Chapter 2.

PCV-E302/E308 Motherboard Description .................. 2-1

(to 2-4)

Chapter 3.

Frame Harness Connector List ................................... 3-1

(to 3-6)

Chapter 4.

Frame Harness Assembly ........................................... 4-1

(to 4-8)

Chapter 5.

Frame Harness Diagram .............................................. 5-1

(to 5-2)

Chapter 6.

Exploded View and Parts List ..................................... 6-1

-3-

®

VAIO MicroTower

User Guide

i

®

Notice to Users

©

1998 Sony Electronics Inc. Reproduction in whole or in part without written permission is prohibited. All rights reserved. This manual and the software described herein, in whole or in part, may not be reproduced, translated, or reduced to any machine-readable form without prior written approval.

SONY ELECTRONICS INC. PROVIDES

NO WARRANTY WITH REGARD TO

THIS MANUAL, THE SOFTWARE, OR

OTHER INFORMATION CONTAINED

HEREIN AND HEREBY EXPRESSLY

DISCLAIMS ANY IMPLIED

WARRANTIES OF MERCHANTABILITY

OR FITNESS FOR ANY PARTICULAR

PURPOSE WITH REGARD TO THIS

MANUAL, THE SOFTWARE, OR SUCH

OTHER INFORMATION. IN NO EVENT

SHALL SONY ELECTRONICS INC. BE

LIABLE FOR ANY INCIDENTAL,

CONSEQUENTIAL, OR SPECIAL

DAMAGES, WHETHER BASED ON

TORT, CONTRACT, OR OTHERWISE,

ARISING OUT OF OR IN CONNECTION

WITH THIS MANUAL, THE SOFTWARE,

OR OTHER INFORMATION

CONTAINED HEREIN OR THE USE

THEREOF.

Sony Electronics Inc. reserves the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein may also be governed by the terms of a separate user license agreement.

Sony, VAIO, VAIO Smart, i.LINK, S-Link, and the VAIO logo are trademarks of Sony.

Windows and the Windows logo are registered trademarks of Microsoft

Corporation. Intel and Pentium are trademarks of Intel Corporation. K56flex is a trademark of Lucent Technologies Inc. and Rockwell International. All other trademarks are trademarks of their respective owners.

Safety Information

Owner’s Record

The model number and serial number are located on the back of your Sony computer.

Record the model and serial numbers in the space provided here. Refer to the model and serial number when you call your

Sony Service Center.

Model Number:________________________

Serial Number:________________________

WARNING

WARNING

To prevent fire or shock hazard, do not expose your Sony computer to rain or moisture.

Never install modem or telephone wiring during a lightning storm.

Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations

Never touch uninsulated telephone wire or terminals unless the telephone line has been disconnected at the network interface.

Use caution when installing or modifying telephone lines.

Avoid using the modem during an electrical storm.

Do not use the modem or a telephone to report a gas leak in the vicinity of the leak.

!

The use of optical instruments with this product will increase eye hazard.

Sony VAIO User’s Guide

Regulatory Information

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the

FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

Only peripherals (computer input/output devices, terminals, printers, etc.) that comply with FCC Class B limits may be attached to this computer product.

Operation with non-compliant peripherals is likely to result in interference to radio and television reception.

All cables used to connect peripherals must be shielded and grounded. Operation with cables, connected to peripherals, that are not shielded and grounded, may result in interference to radio and television reception.

FCC Part 68

This equipment complies with Part 68 of the FCC rules. The ringer equivalence number (REN) and the FCC registration number are printed on the modem board. If requested, this information must be supplied to the telephone company.

The REN is used to determine the quantity of devices which may be connected to the phone line. Excessive REN's on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the

REN's should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total REN's, contact the telephone company to determine the maximum REN for the calling area.

This modem uses the USOC RJ-11 telephone jack.

If this equipment causes harm to the telephone network, the telephone company will, when practical, notify you in advance that temporary discontinuance of service may be required. If advance notice isn't practical, the telephone company will notify you as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.

The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the operations of the equipment. If this happens, the telephone company will notify you in advance, in order for you to make the necessary modifications in order to maintain uninterrupted service.

If trouble is experienced with this modem, for repair or warranty information, please contact 1-888-4SONY-PC, or write to the

Sony Customer Information Center, One

Sony Drive, Park Ridge, NJ 07656.

This equipment cannot be used on telephone-company-provided coin service.

Connection to Party Line Service is subject to state tariffs.

Repair of the modem should be made only by a Sony Service Center or Sony authorized agent. For the Sony Service

Center nearest you, call

1-888-4SONY-PC (1-888-476-6972).

Telephone Consumer

Protection Act of 1991

The Telephone Consumer Protection Act of

1991 makes it unlawful for any person to use a computer or other electronic device to send any message via a telephone facsimile machine unless such message clearly contains, in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business, other entity, or individual sending the message, and the telephone number of the sending machine or such business, other entity, or individual.

In order to program this information into your facsimile, see your fax software documentation.

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.
