CLO SYSTEMS 2011 CATALOG
Full Line of Motorized & Manual Mounts
2010 - 2011
Brochure_1.7.11indd 1
1/7/11 2:33 PM
SA52
MOTORIZED SWING MOUNT
ABOUT THE PRODUCT
ABOUT THE PRODUCT
Our 1.0” thin motorized tilt mount is perfect for today’s slim
LCD and LED TVs, providing enhanced viewing as it reduces
glare and reflections. TA55 tilts your TV down at the touch
of a button and returns to an aesthetically pleasing upright
flush position when not in use. With the included learnable
IR receiver, you can program any universal remote control
to adjust the tilt position. TA55 is the Industry’s thinnest
motorized tilt mount that offers user-friendly design, and a
simple installation process. With the optional ControlWand
(Wi-Fi adapter) a hand held device (iPhone, iPod) can be used
to control the mount via auto, manual, and gyro modes. In the
gyro mode, the motion of the mount is synchronized with the
motion of the hand held device without having to push a button.
Our medium motorized swing mount is a unique
mounting technology alternative to today’s manual
articulating mount. SA52 can fine-tune the viewing
angle of a TV at the touch of a button, from the
comfort of your favorite chair, by varying the swivel
angle up to 90°. This allows the TV to be viewed from
different viewing locations such as the kitchen, or
an adjacent game room. At a 2” profile, the SA52 is
perfect for today’s slim LCD and LED TVs. With the
optional ControlWand (Wi-Fi adapter), a hand held
device (iPhone, iPod) can be used to control the
mount via auto, manual, and gyro modes. In the gyro
mode, the motion of the mount is synchronized with
the motion of the hand held device without having to
push a button.
SPECIFICATIONS
•
•
•
•
•
•
•
•
•
•
•
Fits Most: 37”- 55” Flat panel TVs
Weight Capacity: Up to 100 lbs
Variable Tilt: 0°/-10°
Profile: 1”
Presets: 2
RS-232 Port for automation control.
USB port for ControlWand (Wi-Fi adapter sold
separately) to use hand held devices like iPhone or
iPod to control the mount.
Power Supply:100V – 240V auto ranging
Color: Black
Warranty: 1 year
Certifications: UL, CUL, CE
SPECIFICATIONS
•
•
•
•
•
•
•
Optional: ControlWand Wi-Fi Adapter
•
•
•
•
BENEFITS
• With the optional Wi-Fi adapter, a hand held device
(iPhone, iPod) can be used to control the mount via
auto, manual, and gyro modes.
• Slippage gear mechanism that stops the tilting motion
if there is a resistance for safety.
• Automatically tilts the TV down, when the TV is turned
on-reducing or eliminating glare and reflections.
• Automatically tilts the TV flush against the wall, when the TV
is turned off.
• Optical cable included for auto mode feature.
• Silent and smooth operation.
• Learnable IR receiver and remote control included.
• Mounting hardware.
• Super low profile - discretely hidden behind the TV.
• $10,000 Component Assurance Guarantee.
TA55 & SA52 MOTORIZED MOUNTS
TA55
MOTORIZED TILT MOUNT
Fits Most: 40”- 52” Flat panel TVs
Weight Capacity: Up to 80 lbs
Swivel Angle: 90° left or right
Profile: 2”
Presets: 2
RS-232 Port for automation control.
USB port for ControlWand (Wi-Fi adapter sold
separately) to use hand held devices like iPhone or
iPod to control the mount.
Power Supply: 100V – 240V auto ranging
Color: Black
Warranty: 1 year
Certifications: UL, CE, TUV
Optional: ControlWand Wi-Fi Adapter
BENEFITS
30.31 [849]
10
MAX: 26.57 [675] / MIN: 7.87 [200]
19.29
[490]
15.75 13.94
[400] [354]
12.80
[325]
11.02 [280]
1.97
[50]
0.79
[20]
1.06 [27]
• With the optional Wi-Fi adapter, a hand held device
(iPhone, iPod) can be used to control the mount via
auto, manual, and gyro modes.
• Adjust TV viewing position to an adjacent room, at
the touch of a button.
• Swings out for easy access to cables and wire
management.
• Compact profile to accommodate today’s slim LCD
and LED TVs.
• Learnable IR receiver and remote control included.
• Mounting hardware included.
• Easy to use and simple to install.
• Quiet and smooth operation.
• $10,000 Component Assurance Guarantee.
MAX: 28.35 [720] / MIN: 3.94 [100]
13.82
[351]
7.28
[185]
9.69
[246]
11.61
[295]
17.13
[435]
1.65
[42]
37.60 [955]
1.06 [27]
Vesa Compatible: 200mm x 100mm, 200mm x 200mm, 400mm x 400mm, 600mm x 200mm, 600mm x 400mm
Vesa Compatible: 100mm x 100mm x 200mm x 100mm, 200mm x 200mm, 400mm x 400mm
WallWizard
Toll Free: 877.425.6797
[email protected]
www.wallwizardproducts.com
Brochure_1.7.11indd 2-3
1/7/11 2:33 PM
TP150B
ABOUT THE PRODUCT
ABOUT THE PRODUCT
Our medium motorized tilt mount offers the best of both
worlds in one application. TC105B automatically tilt
to a preset viewing angle when the TV is turned on, or
included remote control may be used to tilt the TV. Perfect
for TVs placed above a fireplace, as it returns flush
against the wall when turned off, preventing heat damage
and making it aesthetically pleasing much like a picture
frame on the wall. The TC105B offers a user-friendly
design and are simple to install, allowing you to achieve
the perfect viewing experience every time.
Our large motorized tilt mount offers the best of both
worlds in one application. TP150B automatically tilt
to a preset viewing angle when the TV is turned on,
or included remote control may be used to tilt the TV.
Perfect for TVs placed above a fireplace, as it returns
flush against the wall when turned off, preventing heat
damage and making it aesthetically pleasing much like
a picture frame on the wall. The TP150B offers a userfriendly design and are simple to install, allowing you to
achieve the perfect viewing experience every time.
SPECIFICATIONS
SPECIFICATIONS
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Fits Most: 40”- 52” Flat Panel TVs
Weight Capacity: Up to 105 lbs
Variable Tilt: +3°/-13°
Profile: 3.3”
Presets: 2
Auto Mode: through optical cable feature
Power Supply: 100V – 240V auto ranging
Color: Black
Warranty: 1 year
Certifications: UL, CE, TUV
TC105B & TP150B MOTORIZED MOUNTS
TC105B
MOTORIZED TILT MOUNT
MOTORIZED TILT MOUNT
Fits Most: 40”- 60” Flat Panel TVs
Weight Capacity: Up to 150 lbs
Variable Tilt: 0°/-13°
Profile: 3.3”
Presets: 2
Auto Mode: through optical cable feature
Power Supply: 100V – 240V auto ranging
Color: Black
Warranty: 1 year
Certifications: UL, CE, TUV
BENEFITS
BENEFITS
• Automatically tilts the TV down, when the TV is turned
on-reducing or eliminating glare and reflections.
• Automatically tilts the TV flush against the wall, when
turned off.
• Perfect for TVs placed above a fireplace.
• Optical cable included for auto mode feature.
• IR receiver and remote control included.
• Mounting hardware.
• Quiet and smooth operation.
• $10,000 Component Assurance Guarantee.
13
MAX: 31.89 [810] / MIN: 4.16 [106]
• Automatically tilts the TV down, when the TV is turned
on-reducing or eliminating glare and reflections.
• Automatically tilts the TV flush against the wall,
when the TV is turned off.
• Perfect for TVs placed above a fireplace.
• Optical cable included for auto mode feature.
• IR receiver and remote control included.
• Mounting hardware.
• Quiet and smooth operation.
• $10,000 Component Assurance Guarantee.
2
11.26
[286]
19.28
[490]
8.86
[225]
10.87 [276]
4.33 [110]
33.07 [840]
0.94 [24]
2.00 [51]
2.60
[66]
3.30
[84]
Vesa Compatible: 100mm x 100mm, 200mm x 100mm, 200mm x 200mm, 400mm x 400mm, 600mm x 200mm, 600mm x 400mm, 800mm x 400mm
2
11.26
[286]
19.28
[490]
23.62
[600]
12.20 9.05
[310] [230]
3.50 [89]
13
MAX: 31.89 [810] / MIN: 4.16 [106]
23.62
[600]
12.20 9.05
[310] [230]
8.86
[225]
3.50 [89]
10.87 [276]
4.33 [110]
33.07 [840]
0.94 [24]
2.00 [51]
2.60
[66]
3.30
[84]
Vesa Compatible: 100mm x 100mm, 200mm x 100mm, 200mm x 200mm, 400mm x 400mm, 600mm x 200mm, 600mm x 400mm, 800mm x 400mm
WallWizard
Toll Free: 877.425.6797
[email protected]
www.wallwizardproducts.com
Brochure_1.7.11indd 4-5
1/7/11 2:33 PM
ZA52
MOTORIZED SWIVEL STAND
ABOUT THE PRODUCT
ABOUT THE PRODUCT
Our articulating motorized mount is the most advanced
motorized mounting solution for flat panel TVs. Capable of
swiveling up to 28° left or right and tilting up 7° or down
20° to fine - tune your viewing experience at the touch of
a button. The included universal remote control offers four
programmable memory locations to recall your favorite
viewing positions. X700CB’s sturdy design supports
installation of the largest flat panel displays making them
secure and flexible. With our full motion motorized mount,
you will always have the best seat in the house.
Our ZA52 motorized swivel table stand is a unique
alternative to placing a flat panel TV on a table.
Whether you need to rotate the TV to eliminate glare
or just want to be able to see the TV from another
seating position in the room, you can do all this at
the touch of a button. Its sturdy design offers 60°
of swivel motion left or right, eliminating flat-panel
viewing problems such as glare and reflections,
including inaccurate color and loss of picture detail.
ZA52 has a built-in learnable IR receiver to learn the
signals from your own remote control to adjust your
TV, so you can fine-tune your viewing experience
every time.
SPECIFICATIONS
•
•
•
•
•
•
•
•
•
•
•
Fits Most: 40”- 63” Flat panel TVs
Weight Capacity: Up to 180 lbs
Swivel: Up to 28° left or right
Tilt Angle: +7°/-20° up or down
Profile: 4.6”
Control interface: IR or RS-232
Presets: 4
Power Supply: 100V – 240V auto ranging
Color: Black
Warranty: 1 year
Certifications: UL, CUL, CE & TUV
SPECIFICATIONS
10.43” (265mm)
31.00” (787 mm)
21.50” - 28.27” (546 - 718mm)
•
•
•
•
•
4.53”
(115mm) •
•
•
6.375”
(162 mm)
BENEFITS
17.75”
450 mm)
• Advanced full motion motorized mounting technology to
maximize your viewing pleasure
• Four programmable presets to recall those favorite
locations
• Mounting hardware included
• IR receiver and universal remote control included
• Quiet and smooth operation
• Easy to use and simple to install
• $10,000 Component Assurance Guarantee
22.64”
(575 mm)
22.75”
(578 mm)
18.75”
(476 mm)
Fits Most: 32”- 52” Flat panel TVs
Weight Capacity: Up to 100 lbs
Variable Swivel Angle: 60° left or right
Presets: 1
Power Supply: 100V – 240V auto ranging
11.61” (295mm)
Color:
Black
for Electrical Outlets
Warranty: 1 yearOpenings
1.5” x 4.25” (38 X 108 mm)
8.47”
Certifications:
UL,
CE
(215 mm)
Routing location for
A/V wires and cables
BENEFITS
10” (254 mm)
8.875” (225 mm)
• Flexible 60° swivel range in either direction, left
or right.
14.17”
(360 mm)
•
Modern
design to accommodate today’s slim LCD
Wall Plate
and
LED TVs
9” (229 mm)
8.25” (210 mm)
2”
• Built-in learnable IR receiver
6” (152mm)
• Mounting hardware and remote control included
16.00” (406 mm)
21.50” (546 mm)
• Easy to use and simple to install
23.63” (600 mm)
26.57” (675 mm)
• Quiet and smooth operation
Base Plate & Wall Plate (looking through
X-arm from TV
side)
• $10,000
Component
Assurance Guarantee
Base Plate
2.79
[71]
25.78
[655]
.25” (6 mm)
4.53”
(115mm)
10.43” (265mm)
31.00” (787 mm)
21.50” - 28.27” (546 - 718mm)
4.13
[105]
18.38
[467]
5.51 20.23
[140] [514]
8.47”
(215 mm)
8.875” (225 mm)
1.57
[40]
Routing location for
A/V wires and cables
6.06
[154]
2.79
[71]
10” (254 mm)
Base Plate
18.75”
(476 mm)
1.37
[35]
1.02
[26]
22.32
[567]
22.64”
(575 mm)
MAX: 29.17 [741]
MIN: 23.78 [604]
17.24
[438]
Openings for Electrical Outlets
1.5” x 4.25” (38 X 108 mm)
17.75”
450 mm)
2.04
[52]
2.36
[60]
11.61” (295mm)
6.375”
(162 mm)
22.75”
(578 mm)
X700CB MOTORIZED MOUNT & ZA52 MOTORIZED STAND
X700CB
MOTORIZED ARTICULATING MOUNT
12.48
[317]
14.17”
(360 mm)
Wall Plate
.25” (6 mm)
8.25” (210 mm)
2”
9” (229 mm)
6” (152mm)
16.00” (406 mm)
21.50” (546 mm)
23.63” (600 mm)
26.57” (675 mm)
Base Plate & Wall Plate (looking through X-arm from TV side)
WallWizard
Toll Free: 877.425.6797
[email protected]
www.wallwizardproducts.com
Brochure_1.7.11indd 6-7
1/7/11 2:34 PM
TM37
MANUAL TILT MOUNT
ABOUT THE PRODUCT
ABOUT THE PRODUCT
Our FM55 flush/tilt combo mount offers two mounting
solutions in one application: a TV can be mounted either
flush 1” from the wall or at a 6° tilt to achieve the perfect
viewing angle while reducing glare and reflections.
The quick latch feature secures the TV to the mount,
yet allows easy cable and wire management, making
installation a breeze. Compact and low profile design,
makes the mount virtually invisible, complementing
today’s slim TVs.
Our TM37 is a compact tilt mount that offers a simple
solution for mounting a flat panel TV to a single stud. Tilt
Balance feature coupled with our unique Stabilization
Technology allows effortless viewing adjustment and
eliminates the need to loosen or tighten knobs to lock
the TV in place. Slim 1.5” profile complements today’s
slender flat panel TVs yet allows easy cable and wire
management, making installation simple.
SPECIFICATIONS
•
•
•
•
•
•
•
•
•
•
•
•
•
FM55 & TM37 MANUAL TILT MOUNTS
FM55
MANUAL FLUSH/TILT COMBO MOUNT
SPECIFICATIONS
Fits Most: 26”- 55” Flat panel TVs
Weight Capacity: up to 130 lbs
Fixed Tilt: 0° or - 6°
Profile: 1”
Color: Black
Warranty: Limited Lifetime
Certifications: UL, CUL, CE
Fits Most: 19”- 37” Flat panel TVs
Weight Capacity: Up to 50 lbs
Tilt: 0°/ -15°
Profile: 1.5”
Color: Black
Warranty: Limited Lifetime
BENEFITS
• Built-in leveler for easy and simple installation.
• Tilt Balance feature allows smooth and effortless viewing
angle adjustment.
• Stabilization technology eliminates the need for knobs.
• Compact design with up to 15° of tilt down angle.
• Mounting hardware included.
• Low profile - discretely hidden behind the TV.
• $10,000 Component Assurance Guarantee.
BENEFITS
•
•
•
•
•
Built-in leveler for easy and simple installation.
Combo flush & tilt solutions.
Compact and low profile.
Mounting hardware included.
Quick release security latches allows for easy cable
management.
• $10,000 Component Assurance Guarantee.
9.00 [229]
8.25 [210]
24.23 [615]
6
MAX: 22.50 [571] / MIN: 3.94 [100]
2.68 [68]
15
0.87
[22]
2.75
[70]
10.25 [260]
17.10
[434]
3.94 [100]
2.88 [73]
1.96
[50]
16.25
[417]
3.94 7.87 9.00
[100] [200] [229]
6.93
[176]
1.96
[50]
1.73 [44]
1.18 [30]
VESA Compatibility: 100mm x 100mm, 200mm x 100mm,200mm x 200mm, 400mm x 200mm, 400mm x 400mm
VESA Compatibility: 75mm x 75mm, 100mm x 100mm,200mm x 100mm, 200mm x 200mm
WallWizard
Toll Free: 877.425.6797
[email protected]
www.wallwizardproducts.com
Brochure_1.7.11indd 8-9
1/7/11 2:34 PM
MC150B
ABOUT THE PRODUCT
ABOUT THE PRODUCT
Our TM60 medium tilt mount is the latest mounting
technology for flat panel TVs. Tilt Balance feature coupled
with our unique Stabilization Technology allows for
effortless viewing adjustments and eliminates the need
to loosen or tighten knobs to lock the TV in place. Open
wall plate allows for easy cable and wire management.
Lateral shift allows desired TV centering position. TM60
has a slim 1.75” profile and user-friendly design which is
perfect for today’s slim TVs.
Our MC150B large tilt mount offers our signature Tilt
Balance feature which allows effortless viewing angle
adjustment with smooth finger touch movement. Unique
Stabilization Technology eliminates the need to loosen
or tighten knobs when tilting a TV. Lateral shift allows
desired TV centering position. Slim 2.0” profile and open
wall plate accommodates cable and wire input/outputs,
for simple installation.
SPECIFICATIONS
•
•
•
•
•
•
•
•
•
•
•
•
•
TM60 & MC150B MANUAL TILT MOUNTS
TM60
MANUAL TILT MOUNT
MANUAL TILT MOUNT
SPECIFICATIONS
Fits Most: 37”- 60” Flat panel TVs
Weight Capacity: Up to 120 lbs
Tilt: 0°/-15°
Profile: 1.75”
Color: Black
Warranty: Limited Lifetime
Certifications: UL, CUL, CE
Fits Most: 37”- 60” Flat panel TVs
Weight Capacity: Up to 150 lbs
Tilt: +3°/-20°
Profile: 2.0”
Color: Black
Warranty: Limited Lifetime
• Certifications: UL, CUL, CE
BENEFITS
• Tilt Balance feature allows smooth and effortless viewing
angle adjustment.
• Stabilization Technology locks in place after tilt angle
adjustment, no knobs needed.
• Lateral shift allows desired TV centering position.
• Open wall plate allows flexibility for cable management.
• Compact design with up to 20° of tilt down angle.
• Mounting hardware included.
• Low profile - discretely hidden behind the TV.
• Easy to use and simple to install.
• $10,000 Component Assurance Guarantee.
BENEFITS
• Built-in leveler for easy and simple installation.
• Tilt Balance feature allows smooth and effortless
viewing angle adjustment.
• Stabilization Technology self locks into place,
eliminating the need for knobs.
• Lateral shift allows desired TV centering positioning.
• Open wall plate provides flexibility for cable and wire
management.
• Mounting hardware included.
• Quick release security latches holds bottom of TV away
from the wall allowing easy cable management.
• $10,000 Component Assurance Guarantee.
MAX: 26.50 [673] / MIN: 7.88 [200]
15
5.31
[135]
15.75
[400]
MAX: 32.00 [813] / MIN3.94 [100]
3
20
10.55
[268]
18.70
[475]
19.88
[505]
APPROXIMATE CENTER LINE OF THE TV
5.98 3.54
[152] [90]
16.61
[422]
3.15
[80]
11.30
[287]
5.98 3.54
[152] [90]
9.33
[237]
3.15
[80]
1.61 [41]
1.06
[27]
8.70
[221]
0.57
[15]
5.90
[150]
1.18
[30]
33.66
[855]
0.89 [23]
6.25 [159]
1.18 [30]
5.91 [150]
28.50 [724]
VESA Compatibility: 200mm x 200mm, 400mm x 400mm, 600mm x 200mm, 600mm x 400mm
1.02
[26]
0.75
[19]
1.61
[41]
1.50
[38]
2.00
[51]
1.73
[44]
VESA Compatibility: 100mm x 100mm, 200mm x 100mm, 200mm x 200mm, 400mm x 400mm, 600mm x 200mm, 600mm x 400mm, 800mm x 400mm
WallWizard
Toll Free: 877.425.6797
[email protected]
www.wallwizardproducts.com
Brochure_1.7.11indd 10-11
1/7/11 2:34 PM
XM60
MANUAL ARTICULATING MOUNT
ABOUT THE PRODUCT
ABOUT THE PRODUCT
Our signature XM37 offers a unique feature unlike any
other mount. XM37 is the thinnest articulating mount in
its category at 2.0” and is capable of swinging a TV out
up to 90°, like a door, with very little effort. Having the
ability to tilt, swivel and adjust the pitch means you can
enjoy viewing your TV from anywhere in the room. With
finger tip smooth movement, adjusting the TV angle is a
breeze. Our state of the art articulating mount is the latest
mounting technology available.
Our signature XM60 will take the intimidation out
of adjusting the angle of a large flat panel TV. Its
unique design allows you to tilt, adjust the pitch and
swing your TV out up to 90°, like a door, with very
little effort. Best of all, our articulating mount is only
2.75” thin, perfect for today’s slim TVs. XM60 is
user friendly, simple to install and designed for easy
access to cable and wire management behind the TV.
Our state of the art articulating mount is the latest
mounting technology available.
SPECIFICATIONS
•
•
•
•
•
•
•
•
•
XM37 & XM60 MANUAL ARTICULATING MOUNTS
XM37
MANUAL ARTICULATING MOUNT
SPECIFICATIONS
Fits Most: 26”- 37” Flat panel TVs
Weight Capacity: Up to 50 lbs
Swivel: 90° either left or right
Tilt: +3°/-15°
Extends: Up to 18”
Profile: 2.0”
Color: Black
Warranty: Limited Lifetime
Certifications: UL, CUL, CE
•
•
•
•
•
•
•
•
Fits Most: 40”- 60” Flat panel TVs
Weight Capacity: Up to 120 lbs – double stud
Swivel angle: 90° either left or right
Tilt: +3°/-15°
Extends: Up to 28”
Profile: 2.75”
Color: Black
Warranty: Limited Lifetime
• Certifications: UL, CUL, CE
BENEFITS
• Swings out like a door with one hand, eliminating the
need to pull the TV out before swiveling.
• Thinnest articulating mount in its category at a 2.0”
profile complements today’s slim LCD and LED TVs.
• Mounting hardware included.
• Smooth and effortless operation.
• Low profile modern design.
• $10,000 Component Assurance Guarantee.
BENEFITS
• Swings out like a door, eliminating the need to pull
the TV out before swiveling.
• Swivels out for easy cable management.
• Thinnest articulating mount at a 2.75” profile
complements today’s slim LCD and LED TVs.
• Mounting hardware included.
• Low profile, modern design.
• Smooth and effortless operation.
• $10,000 Component Assurance Guarantee.
8.86 [225]
8.00 [203]
3.94 [100]
2.95 [75]
8.86
[225]
8.0
[203]
8.00 3.94 2.95
[203] [100] [75]
3.01
[76]
MAX: 29.75 [756] / MIN: 7.88 [200]
20.63 19.69
[524] [500]
16.22
[412]
13.98
[355]
9.69
[246]
2.80
[71]
16.00 [406]
22.52 [572]
3.82 [97]
1.85 [47]
MAX 18.65 (474) / MIN17.0 (432)
VESA Compatibility: 75mm x 75mm, 100mm x 100mm, 200mm x 100mm, 200mm x 200mm
VESA Compatibility: 200mm x 200mm, 400mm x 400mm, 600mm x 200mm, 600mm x 400mm
WallWizard
Toll Free: 877.425.6797
[email protected]
www.wallwizardproducts.com
Brochure_1.7.11indd 12-13
1/7/11 2:35 PM
DM65 MANUAL COMBO MOUNT & COMPANY INFO
DM65
MANUAL FLUSH/TILT COMBO MOUNT
ABOUT THE PRODUCT
DM65 offers a different approach to mounting
solutions with its clean, modern, and minimalist
cross-bar design that is simple to install and use. A
locking handle can be attached on the right or left
side depending on the user preference; and once it is
locked, the TV cannot be detached even when the TV
is tilted up for extra safety and security. Even after
it is mounted, the TV can be easily moved laterally
to center the TV within the room. DM65 offers two
mounting solutions in one application: a TV can be
mounted either flush 1” from the wall or at a 9° tilt
to achieve the perfect viewing angle while reducing
glare and reflections. Compact and low profile design,
makes the mount virtually invisible, complementing
today’s slim TVs.
SPECIFICATIONS
•
•
•
•
•
•
•
Based in Los Angeles-California, CLO Systems, LLC has grown to become the leader in
providing superior manual and motorized mounts for flat panel TVs. Our mission is to
provide affordable mounts that effortlessly improve the viewing experience of the TV. We
also take pride in protecting our technology through a strong intellectual property portfolio
so that we can offer our customers and partners truly unique products.
Fits Most: 42”- 65” Flat panel TVs
Weight Capacity: Up to 150 lbs
Fixed Tilt: 0° or 9°
Profile: 1”
Color: Black
Warranty: Limited Lifetime
Certifications: UL, CUL, CE
40.83 [1037]
36.93 [938]
•
•
•
•
•
•
•
Modern clean design.
Detachable leveler for easy and simple installation.
Combo flush & tilt solutions.
Compact and low profile.
Mounting hardware included.
Side locking handle for easy access.
Extra safety - as the mount stays locked even when
TV is tilted up.
• Lateral shift to center the TV.
• $10,000 Component Assurance Guarantee.
9
MAX: 36 [914] / MIN: 100 [3.94]
BENEFITS
3.34
[100]
1.06 [27]
2.99
[76]
8.06
[205]
MAX: 15.75 [400]
MIN: 3.94 [100]
0.28
[7]
0.12
[3]
0.20
[5]
0.12
[3]
VESA Compatibility: 100mm x 100mm, 200mm x 200mm, 400mm x 400mm, 600mm x 400mm, 800mm x 400mm
WallWizard
Toll Free: 877.425.6797
[email protected]
www.wallwizardproducts.com
Brochure_1.7.11indd 14-15
1/7/11 2:35 PM
WallWizard is the brand behind CLO Systems, LLC
For more info, visit: www.wallwizardproducts.com
Toll Free: 877.425.6797
Fax: 626.939.3378
Brochure_1.7.11indd 16
1/7/11 2:35 PM
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
