Specifications
NEW
XGA PROJECTOR
Color
Brilliant
ColorTM Enhancer
sRGB
3D Y/C
Digital Comb
Password Direct
Power Off
Lock
Center
Lens
Long-life Low Standby
Lamp
Power
PinP
Low Fan
Noise
User Logo
Projection
Remote
Mouse
Control
Side
Loading
Lamp
LAN
(RJ-45)
: Picture Perfomance
1
2 3 4 5 6
7
8
2
3
4
5
6
7
8
9
10
11
12
10 11 12
9
13
13 14 15
14
15
XD3500U
Display Technology
0.7” 1-Chip DMD, DDP3020
Resolution
1024×768 (Total 786,432 pixels)
Brightness
5000lm
Contrast
2500 : 1 (on / off)
Picture Size
40"~ 300"
Projection Lens
f=24.5-33.1mm, F=2.0-2.4
Offset Axis
10 : 0
DVI
HDMI
: Presentation
Closed
Caption
1.7 ~ 2.4
Source Lamp
264W (Shut-off Time 4000hr) with Low Mode
330W (Shut-off Time 2000hr) with Standard Mode
Computer Compatibility
640×480 (Expanded) ~ 1600×1200 (Compressed)
True: 1024×768, Sync on Green available
Video Compatibility
NTSC / NTSC4.43 / PAL (including PAL-M, N) / SECAM / PAL-60,
Component Video: 480i/p (525i/p), 576i/p (625i/p), 720p (750p 50/60Hz),
1080i (1125i 50/60Hz), 1080p (1125p 50/60Hz)
PC Input Terminals
mini D-sub 15pin×1, 5 BNC×1, DVI-D (with HDCP)×1
Audio: stereo mini jack(ø3.5mm)×3
Video Input
Terminals
Video: HDMI(ver.1.2)×1, RCA×1 or BNC×1, S-Video(4pin)×1 or S-Video Y/C(BNC)
Audio: RCA (L, R)×2
Output Terminals
RGB: mini D-sub 15pin×1, DC Out: 5V 1.5A (MAX)
Audio: stereo mini jack (ø3.5mm)×1
Communication
Terminals
LAN (RJ-45)×1, RS-232C:D-sub 9pin×1, USB×1 (Mouse control),
Wired remote in: stereo mini jack (ø3.5mm) ×1, Wired remote out: stereo mini jack (ø3.5mm)×1
Audio Speaker
10W mono
: User Friendly
HDMI terminal
DVI-D (HDCP) terminal (DVI-D 24-pin)
Computer / Component Video IN-1 terminal
Audio IN-1 terminal (Mini jack)
Audio DVI-D terminal (Mini jack)
Video IN / Audio IN terminal
DC OUT [5V 1.5A (Max)]
LAN(RJ-45) terminal
Computer / Component Video IN-2 terminals
Monitor OUT terminal (Mini D-SUB 15-pin)
Audio OUT terminal (Mini jack)
Audio IN-2 terminal (Mini jack)
USB (Computer) terminal
Remote IN / OUT
Serial terminal (D-SUB 9-pin)
MULTIMEDIA DATA/VIDEO PROJECTORS
Throw Ratio
Motorized
Page
10W
up/down Speaker Lens Shift
Input and Output Terminals
1
Model
Fan Noise
26dBA (Low Mode)
Dimensions (W×H×D)
17.7”×7.4”×14.7” (excluding terminal cover)
Weight
22.7lbs (excluding detachable terminal cover)
Power Supply
AC100 - 240V, 50/60Hz
Optional Accessories
Lamp: VLT-XD3200LP
Lens: OL-XD2000SZ, OL-XD2000LZ, OL-XD2000TZ, OL-XD2000FR
Warranty
3-Years Parts/Labor, 3-Years Express Replacement Assistance,
1-Year or 500 hours lamp warranty (whichever comes first)
Large-screen projectors that provide an experience you’ll never forget!
~ Image Quality and Functionality Unlike Any Other ~
* Compliance with ISO21118-2005
* All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.
* DLPTM (Digital Light Processing) and BrilliantColorTM are trademarks of Texas Instruments.
Screen Size and Projection Distance / Optional Lenses
Refer to the following table to determine the screen size.
Front projection
W
W1
W1
W
Diagonal size
W1
H1
H2
W1
L
L
H2
H1
H3
H3
XD3500U
H
H
XD3500U
L
Screen size (XGA 4:3)
Front projection, ceiling mounted
L
Width
Height
Movable V position
Movable H position
from Default position
from Default position
Down Up Down Up Left Right Left Right
(H1) (H2) (H1) (H2) (W1) (W1) (W1) (W1)
Max. Zoom
Min. Zoom
cm
inch
inch
m
61
0
0
54
1.4
74
1.9
12 0
2
30 0
6
3 0
3
36
91
0
0
82
2.1
112
2.8
18 0
3
46 0
9
5 0
5
12 0 12
48
122
0
0
110
2.8
150
3.8
24 0
4
61 0 11
6 0
6
16 0 16
203
60
152
0
0
138
3.5
189
4.8
30 0
6
76 0 14
8 0
8
20 0 20
305
90
229
0
0
208
5.3
284
7.2
45 0
8
114 0 21 12 0 12
30 0 30
160
406
120
305
0
0
279
7.1
380
9.7
60 0 11 152 0 28 16 0 16
41 0 41
200
508
150
381
0
0
349
8.9
-
-
75 0 14 191 0 36 20 0 20
51 0 51
10.6
-
-
90 0 17 229 0 43 24 0 24
61 0 61
cm
inch
40
102
32
81
24
60
152
48
122
80
203
64
163
100
254
80
150
381
120
200
508
250
635
762
Distance from screen (L)
inch
inch
inch
300
Default height
projected
image (H)
240
cm
610
180
cm
457
0
0
419
m
inch
cm
inch
cm
8 0
8
Optional Lenses
Screen size (XGA 4:3)
A wide variety of optional lenses is available to suit any operating or user requirement.
Diagonal Size
OL-XD2000SZ
Short-throw Zoom Lens
OL-XD2000LZ
Long-throw Zoom Lens
Converter Lens
(mounted on the standard lens)
Converter Lens
(mounted on the standard lens)
OL-XD2000TZ
Tele-throw Zoom Lens
OL-XD2000FR
Rear Projection Short-thow Fixed Lens
inch
40
60
80
100
150
200
250
300
cm
102
152
203
254
381
508
635
762
Width
inch
32
48
64
80
120
160
200
240
cm
81
122
163
203
305
406
508
610
Height
inch
24
36
48
60
90
120
150
180
cm
61
91
122
152
229
305
381
457
Default
OL-XD2000SZ
OL-XD2000LZ
OL-XD2000TZ
height
projected Distance from screen (L) Distance from screen (L) Distance from screen (L)
image (H) Max. Zoom Min. Zoom Max. Zoom Min. Zoom Max. Zoom Min. Zoom
inch
0
0
0
0
0
0
0
0
cm
0
0
0
0
0
0
0
0
inch
41
63
86
108
164
219
275
331
m
1.0
1.6
2.2
2.7
4.2
5.6
7.0
8.4
inch
57
88
118
148
224
300
-
m
1.5
2.2
3.0
3.8
5.7
7.6
-
inch m inch m inch m inch m
148 3.8
88 2.2
105 2.7 135 3.4 136 3.5 224 5.7
142 3.6 182 4.6 183 4.7 301 7.6
180 4.6 228 5.8 230 5.8 377 9.6
273 6.9 345 8.8 348 8.8 568 14.4
366 9.3 462 11.7 465 11.8 759 19.3
459 11.7 579 14.7 583 14.8 951 24.1
553 14.0 696 17.7 701 17.8 1,142 29.0
Default
height
projected
image (H3)
inch
12
18
24
30
45
-
cm
30
46
61
76
114
-
OL-XD2000FR
Distance from
screen (L)
inch
25
38
51
64
97
-
m
0.6
1.0
1.3
1.6
2.5
-
The above figures are approximate and may be slightly different from the actual measurements.
Lens shifting is not available for the OL-XD2000FR (horizontal and vertical are set at 1:1)
The lens movable range shows distances from the factory default position.
MITSUBISHI DIGITAL ELECTRONICS
AMERICA, INC.
MITSUBISHI ELECTRIC SALES
CANADA, INC.
Presentation Products Division
Phone: 888.307.0349
www.mitsubishi-presentations.com
Display & Imaging Solutions Division
Phone: 905.475.7728
www.mitsubishielectric.ca
LITXD3500U
New publication, effective February 2010.
Specifications subject to change without notice.
Industry-leading DLP Brightness of 5000lm
Large-screen reproduction of high-quality images. Breathtaking and powerful.
But image quality is not the only improvement to our large-screen projectors.
Mitsubishi Electric’s new projectors are designed for easy installation and maintenance,
superior operability and a comfortable viewing experience.
Welcome to the future of high-lumen projectors.
XD3500U
5000
lm
XGA
Stunning Beautiful Colors & High-quality Design
Operation simplified with Mitsubishi Electric’s user-friendly design
Low Maintenance & High Durability
User Friendly
New Color Wheel System
New Lamp Drive System
Dust can easily accumulate on the color wheel sensors on previous models. Now, the sensor
is mounted in the rotary shaft motor casing, which is almost fully enclosed, making it much
less likely for dust to collect on the sensor.
Arc Discharge
Initially, the gap between
the electrodes is small and
the arc density is high,
resulting in high brightness.
Electrode
Photo Sensor
Timing
Mark
Optical Signal
New color wheel illustration
Dust accumulates on
the sensor and thick part of
the timing mark—blocking
the path of the light when
using the light signal
method. This interferes with
the color distinction process,
causing poor color
alignment and breaking.
Fixed
Halleffect IC
Less than 1mm
Magnet Magnetic Signal
100%
The base spins together with the color wheel.
The wind pressure created by the centrifugal
force keeps dust from entering through the gap
(less than 1mm or 1/25in). The magnet is
embedded in the base, so there is no protruding
part for dust to accumulate on. Even if dust
does accumulate, since a magnetic signal
method is used, the signal passes through the
dust without any problem of color distinction.
Filter free
DLPTM projectors are designed with a semi-sealed light path, therefore an intake filter is not
needed, eliminating filter changing and lowering maintenance costs.
Long 4000hr Lamp Life
2,000hr lamp
Original Lamp
1st replacement
Reduced
Lamp
Replacements
4,000hr lamp
Original Lamp
2,000 hours
0%
4,000 hours
(*1): When lamp is used in “Low” mode. Maximum life in “Standard” mode is 2000hr.
(*2): Lamp life refers to the average time required for brightness to be reduced by half,
and not the time specified in the warranty. Use time may vary widely according to
the environment and conditions, and whether or not cleaning and other maintenance
procedures are followed.
Conventional Lamp
Drive System
New Lamp Drive System
Total Lamp Usage in Hour
Adoption of a new lamp drive system prevents
electrode wear, giving the lamp a longer
service life and enabling it to retain projection
brightness over a longer period of time.
Up until now, the electrodes in the lamp deteriorated more quickly when using
the projector for long periods of time, resulting in a loss of brightness. These projectors
incorporate an optical design that optimizes lamp operation to realize a lamp drive
that makes it possible to stabilize the shape of the electrode during long-term use.
As a result, the maximum lamp service life is obtained for every projection mode and
loss in projection brightness is extended over a longer period of time.
Side Access Lamp & Center Lens Designs
The XD3500U has a lamp temperature controlling system
that enables a lamp life of up to 4000hours.*1 Long-life
lamps make dramatic reductions in overall cost of
ownership by reducing the frequency of lamp replacement.
Lamp Replacement Frequency* 2
Electrode Abrasion
Previous color wheel illustration
The distance between the electrodes
increases as they wear causing a decrease
in arc density, which also results in a loss of
brightness.
The lamp can be accessed from the side of
the projector, simplifying the replacement process,
as the projector does not need to be turned around
when sitting on a shelf or turned
over when suspended from
the ceiling. The center-set lens
design makes set-up easy since
the projector lens can be
evenly aligned with the center
of the screen.
Quick Lens Change
The top cover has a removable panel around the lens.
This advanced feature enables the lens to be
changed without removing the entire top cover.
Ultra - quiet 26dBA Operation
The fan noise from a projector can be annoying during
a presentation or videoconference. But with the adoption of
a hermetically sealed color wheel and improved air duct path,
that’s a thing of the past. The
XD3500U has a significantly
low fan noise of only 26dBA
Fan noise
Fan noise
(lamp in Low mode).
Air flow
Fan
As a result, audiences can
Air flow
enjoy presentations and
Air flow
conferences with the
distraction of projector
noise.
Brilliant Color ™ and Mitsubishi Electric Engineering Yield Superior Color Performance
Brilliant Color™, one of the latest innovations from
Texas Instruments, produces amazingly rich and vibrant
colors. We developed a 5-segment color wheel (R, G,
B, W and Y), and combined it with Brilliant Color™ and
selective lamp-powered modulation techniques. The
XD3500U intelligently reproduces colors that improve
the intensity and vibrancy across the entire screen.
w/o-BrilliantColorTM
Yellow reproducibility improves
High Power
Normal Power
Low Power
R
B
W
G
Y
G
Y
Lamp Power (Basic concept)
Auto Mode (for color reproduction)
Light intensity increases for the RGB segment on
the color wheel, ensuring ample brightness while
screening brilliant colors.
High Power
4-segment (RGBW) color wheel
A user-created image (logo,
picture, etc.) can be loaded into
the projector and used as the
start-up image or the stand-by
screen.
Light intensity increases for the white and yellow
segments of the color wheel, giving greater
emphasis to bright colors in more vivid tones.
Normal Power
The air duct flow design has been improved so that fan noise doesn’t interfere with
the intake-air flow. Additionally, the fan noise is blocked from direct exit, realizing
a significant reduction in operation noise.
User Logo Projection
BrilliantColorTM
Lamp Power Modulation
Presentation Mode (for high brightness)
5-segment (RGBWY) color wheel
Low Power
R
B
W
Lamp Power (Basic concept)
Precise Gradation Reproduction
Super - bright 5000lm
The XD3500U delivers super-bright 5000lm images.
It’s the ideal brightness for giving presentations in
large meeting rooms and conference halls.
Well-established DDP3020 DLP™ data processor
High-speed LVDS (low-voltage differential signal)
10-bit I/P conversion circuit eliminate jaggies
Lavish functions to fully savor the job
Motor-driven Lens Shift* & High Contrast of 2500:1
* Function adjusts image in four directions (up/down/left/right) without
touching the projector.
Splash screen
LAN Control
Stand-by Power Consumption Under 1W
We are always striving to protect the global environment
and save energy, which has resulted in stand-by power
consumption in low mode being reduced to under 1W.
Connect a computer with ProjectorView™ installed to a LAN for wired
operation and monitoring of several different projectors.
3000lm
5000lm
Closed Caption (CC) Capable
A closed caption decoder comes installed as standard equipment. Closed Caption enabled signals are processed into subtitles
that are projected onto the screen. This feature addresses the needs of language students and hearing-impaired viewers.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
