 TABLE OF CONTENTS
Corporate Overview
O) Tape Controllers
A
= Disk Controllers
How to Order and Service & Warranty
5-6-7
DILOG—Distributed Logic Corporation—is the First controller corporation. Take Route 1, the DILOG
Highway, on the DEC Bus—UNIBUS and Q-Bus. Follow our signs of technical innovations and quality. Here is our
list of Firsts:
o First DEC* emulating single-board quad-size SMD disk controllers.
e First tape coupler for 2" start/stop formatted tape drives.
o First tape coupler for 2" streaming tape drives.
e First tape coupler for ¥2" cache tape drives.
e First disk controllers with Universal Formatting™ and mapping which allow connection of multiple drives that have the
same electrical interface, but have the same or different number of heads, tracks or bpi configuration.
e First to use an expanded 56-bit ECC polynomial for enhanced data error recovery.
e First disk controller designed specifically for Winchester disk drives.
o First to offer a complete family of 22-bit disk and tape controllers/couplers.
o First to offer choices of mapping one or more logical units in a physical drive on a vertical or horizontal axis.
e First full range of disk controllers that support floppy, 5%", 8” or 14” Winchester, cartridge or removable media disk drives.
AND HERE IS OUR COMPLETE RANGE:
LIST OF MANUFACTURERS
MAGNETIC TAPE HARD DISK CAPACITIES 2.5 to 300 MB
Yo" REEL-TO-REEL | 2315/5440/RK05 CMD CARTRIDGE|SMD STORAGE | WINCHESTER va" TAPE FLOPPY
STD. & STREAMER | CARTRIDGE CLASS | MODULE MODULE 5%", 8" or 14” CARTRIDGE | DISK DRIVE
AMPEX AMPEX AMPEX AMPEX AMPEX NIPPON DEI BASF
CIPHER CAELUS CONTROL BALL BASF PER LTD. | DIGI-DATA CONTROL
CONTROL DATA CENTURY DATA DATA COMPUTER CENTURY OLIVETTI ERE DATA
DATUM CONTROL DATA VERMONT CENTURY DATA РЕВТЕС (Т.А.)| KENNEDY MICROPOLIS
DIGI-DATA DEC RESEARCH DATA C.M.L PRIAM PENNY & M.P.I.
KENNEDY DIABLO CONTROL DMA SYSTEMS | QUANTUM GILES QUME
MICRODATA DRI DATA FUJITSU RODIME PEREX REMEX
PERTEC (T.A.) IOMEC MITSUBISHI IMI SEAGATE QANTEX SHUGART
S.E. LABS (EMI) | MICRODATA KENNEDY SIEMENS TANDON
TANDBERG DATA | PERTEC MEMOREX SHUGART
(IDT) WANGCO (CIPHER) MICROPOLIS S.L.l.
TDX WESTERN DYNEX MINISCRIBE TANDON
WANGCO (CIPHER) М.Р.!. TEXAS INST.
MEGATAPE N.E.C. TECSTOR
ATASI 3M
EVOTEK SYQUEST
DISCTRON VERTEX
DISCTECH ONE | MAXTOR
*DEC, RSX, RSTS, IAS, DSM, UNIBUS, MUMPS and VAX are registered trademarks of Digital Equipment Corporation.
CORPORATE OVERVIEW
RIGHT TURN
DISTRIBUTED
Armenia
INTERNATIONAL
The whole idea behind the Distributed Logic Corporation is
simple: to market state-of-the-art disk and tape drive
controllers which deliver a high level of performance at low
Cost.
Our controllers are smaller, boast lower power require-
ments and are more reliable—due to fewer components
—than any other products on the market today. They are
also easier to install and maintain. And we back up every
one of our products with quality control and delivery sys-
tems that are second to none.
Mass storage and tape drive controllers for the Digital
Equipment Corporation (DEC) line of mini- and micro-
computers are our specialty. DILOG is the acknowledged
leader in this area for the low end of the DEC product line
—by far, the largest installed base of small computers in
the world.
Collectively, the people at DILOG represent over 300 years
of electronics industry experience in the management,
marketing and technical areas. We have been involved in
all facets of the mini-/microcomputer segment of the
industry since its inception in the early 1960's. Today,
DILOG maintains a staff of experienced professionals in the
key disciplines, augmented when necessary by outside
services and consultants of the highest caliber.
Both domestically and internationally, DILOG markets its
products through direct sales offices in Garden Grove,
California and in the U.K. These are augmented by a
network of manufacturer's representatives and distributors.
Currently, tens of thousands of DILOG peripheral con-
trollers are installed and operating in customer sites
throughout the U.S., the U.K., Europe and Southeast Asia.
Before we began selling our products in 1978, we
spent a considerable amount of time with one
goal in mind: to be able to go from specifica-
tion to marketplace with any new controller
in 120 to 180 days, versus the industry aver-
age of 8 to 12 months. Our automated concept
for product development has enabled us to do just
that. We can always react quickly to the rapid technological
changes which are a cornerstone of the small computer
industry.
PRODUCTS
We currently offer 28 magnetic tape and disk controller
products for the DEC PDP-11 minicomputer and LSI-11
microcomputer. Connection of each controller to the
magnetic tape or disk drive which it controls is made
through common flat cables. Along with the small size of
DILOG's products, this means our customers can easily
install and service our boards.
At the heart of every DILOG product is a proprietary
design. In tandem with our unique automated computer
based peripheral controller development systems, we are
able to produce the highest quality peripheral controllers—
products which are not only more cost effective, but which
can be brought to the marketplace faster than any other
competitive products.
The intelligence—or ‘“‘personality’’—of each of our con-
trollers is determined by firmware programming of the
DILOG proprietary microprocessor-based design, represent-
ing approximately 60% of the circuitry involved with each
device. There is an 80% overall physical and electrical
commonality between most products offered by the
company.
All of DILOG's intelligent controllers have an on-board
automatic self-test feature as well. Each controller contains
built-in microdiagnostics with which it can test itself upon
initiation by the host computer. A green light on the edge of
each controller's printed circuit card remains lit as long as
the self-test procedure is successful. Should the controller
fail a test on itself, the light is extinguished. The customer
then simply unplugs the controller and replaces it.
Other DILOG controller features include automatic media
flaw compensation, automatic power down protection and
memory addressing capability to 256 Kbytes, or with 22-bit
addressing 4 megabytes. Our controllers consume up to
60% less power than multiple board type embedded con-
trollers and no specially wired connectors, power supplies
or bus converters are required.
We're currently looking into new applications of
our existing technology to other areas of data
processing. In the. near future, we hope to be
BRIGHT E.
FUTURE ) Making important announcements regarding
AHEAD / new product categories which DILOG is just
beginning to explore.
In every sense, we're a company on the move.
Wherever the industry is headed next, DILOG intends to
map out new directions in powerful, simple-to-use computer
components for all the years to come.
TAPE CONTROLLERS
DISTRIBUTED
Alen
INTERNATIONAL
MODEL DQ130
DEC LSI-11 Compatible
o Interfaces to LSI-11 through -11/23 PLUS microcomputers.
e Emulates DEC TM-11 controller.
e Handles up to eight 9-track, 800/1600 bpi industry standard
formatted tape drives at speeds from 12.5 to 125 ips—eight
stop/starts or four 2" streamers.
Completely contained on one quad-wide module.
RT-11, RSX-11, RSTS and TSX-Plus* software compatibility.
FIFO buffer for DMA latency.
Memory addressing capability to 256 Kbytes.
Software or switch selectable density control.
*TSX-Plus is a trademark of s&h computer systems, inc.
MODEL DQ132
DEC LSI-11 Compatible
o Interfaces LSI-11 through LSI-11/23 PLUS microcomputers.
o Emulates DEC TS-11 or TSVO5.
e 600 Kbytes/sec data transfer rate, for both GCR and CacheTape
compatibilities.
e Controls up to four %” streamer tape drives or four 7”
formatted start/stop tape drives, with switch selectable interrupt
vectors for the second, third and fourth drives.
RT-11, RSX-11, RSTS and TSX-Plus software compatibility.
22-bit addressing for access to four megabytes.
Contained on one quad module.
Extended 1 Kbyte data buffer.
DMA burst size of 8 bytes with dynamic auto throttle control.
AU
MODEL DU130
DEC PDP-11 Compatible
Interfaces to DEC PDP-11 UNIBUS computers.
Emulates DEC TM-11 controller.
RT-11, RSX-11, RSTS, IAS, MUMPS and TSX-Plus software
compatibility.
Handles up to eight 9-track, 800/1600 bpi industry standard
formatted tape drives at speeds from 12.5 to 125 ips—eight
stop/start or four 2” streamers.
FIFO buffer for DMA latency.
Software or switch selectable density control.
Completely contained on one quad-wide board.
Memory addressing compatibility to 256 Kbytes.
Y
MODEL DU132
DEC PDP-11/VAX Compatible
e Interfaces PDP-11 and VAX UNIBUS computers.
e Controls up to four 2" streamer tape drives or four 2"
formatted start/stop tape drives, with switch selectable interrupt
vectors for the second, third and fourth drives.
VMS, RT-11, RSTS and RSX software compatibility.
600 Kbytes/sec data transfer rate, with both GCR and
CacheTape compatibilities.
Contained on one quad module.
Extended 1 Kbyte data buffer.
Switch selectable DMA burst sizes of 4 to 8 bytes with dynamic
auto throttle control.
Full TU-80 diagnostic compatibility.
Emulates DEC TS-11 or TU-80.
MODEL DQ215/SMD INTERFACE
DEC LSI-11 Compatible
e Interfaces LSI-11 through 11/23 PLUS microcomputers.
e Emulates DEC RKO06 or RK07 (switch selectable).
Connects up to two SMD |/O disk drives, including 8- and
14-inch Winchester, SMD pack and CMD cartridge type drives.
RT-11, RSX-11, RSTS and TSX-Plus software compatibility.
Universal Formatting. ™
22-bit addressing for access to four megabytes.
56-bit error correction code (ECC).
Full sector data buffer.
On-board bootstrap loader.
MODEL DU218/SMD INTERFACE
DEC PDP-11 Compatible
e Interfaces to DEC PDP-11 UNIBUS computers.
o Emulates DEC RMO2/RMOS.
e Media compatible wth DEC RM02/RM03/RMO05 drives when
using CDC 9762/9766 or equivalent disk drives.
Connects to four Winchester drives that contain an industry
standard SMD interface.
RSTS, RSX-11, IAS and DSM software compatibility.
Completely contained on one hex-wide module.
FIFO data buffer of 1,536 bytes (3 sectors).
32-bit ECC for data error detection and correction in addition to
a 16-bit CRC for header error detection (RMO2/RMO5 media
compatible).
e Offset commands for electrical head adjustment,
e Number of data transfers per DMA request switch selectable
with dynamic auto throttle control,
_
в
a
MODEL DU215/SMD INTERFACE
DEC PDP-11/VAX Compatible
e Interfaces PDP-11 and VAX UNIBUS computers.
* Emulates DEC RK06 or RK07 (switch selectable).
Connects up to two SMD 1/0 disk drives, including 8- and
14-inch Winchester, SMD pack and CMD cartridge type drives.
RT-11, RSX-11, RSTS and VMS software compatibility.
Universal Formatting."M
Memory addressing to 256 Kbytes.
56-bit error correction code (ECC).
Full sector data buffer.
MODEL DQ228/SMD INTERFACE
DEC LSI-11 Compatible
e Interfaces LSI-11 through 11/23 PLUS microcomputers.
Emulates DEC RMO2/RMOS.
Connects up to two disk drives which contain an industry
standard SMD interface.
RSTS and RSX-11 software compatibility.
22-bit addressing accesses four megabytes.
56-bit error correction code (ECC).
Universal Formatting.™
Full sector data buffer.
Completely contained on one quad-wide module.
On-board bootstrap loader.
MODEL DQ614/WINCHESTER ST506
DEC LSI-11 Compatible
Interfaces LSI-11 through 11/23 PLUS microcomputers.
Emulates DEC RLO1/RLO2.
Connects up to two ST506 or equivalent disk drives.
RT-11, RSX-11, RSTS and TSX-Plus software compatibility.
Universal Formatting.™
22-bit addressing for access to four megabytes.
Enhanced error correction code (ECC) with a 32-bit checkword.
Completely contained on dual-wide module.
Full sector data buffer.
On-board bootstrap loader.
MODEL DQ409/FLOPPY
DEC LSI-11 Compatible
e Interfaces LSI-11 through 11/23 microcomputers.
e Emulates DEC RXO2.
Controls one or two single or dual density flexible diskette drives
with Shugart 800 or 850 compatibility.
RT-11 and RSX-11 software compatibility.
Media compatible with DEC RX01/RX02.
IBM 3740 format compatible.
On-board formatting capability.
Completely contained on one dual-wide module.
y
NN
DISTRIBUTED
IRs
INTERNATIONAL
MODEL DQ615/WINCHESTER ST506
DEC LSI-11 Compatible |
e Interfaces LSI-11 through 11/23 PLUS microcomputers.
e Emulates DEC RKO6/RKO7.
Connects up to two high capacity, 54" Winchester drives
which have ST506 interfaces.
RT-11, RSX-11, RSTS and TSX-Plus software compatibility.
Universal Formatting.™
22-bit addressing for access to four megabytes.
Enhanced error correction code (ECC) with a 32-bit checkword.
Completely contained on one dual-wide module.
Full sector data buffer.
On-board bootstrap loader.
Y.
MODEL DQ214/SMD INTERFACE
DEC LSI-11 Compatible
Interfaces LSI-11 through 11/23 PLUS microcomputers.
Emulates DEC RLO1/RLO2.
Connects up to two SMD compatible disk drives.
RT-11, RSX-11, RSTS and TSX-Plus software compatibility.
Universal Formatting."M
22-bit addressing for access to four megabytes.
56-bit error correction code (ECC).
Completely contained on one quad-wide module.
Full sector data buffering.
On-board bootstrap loader.
MODEL DQ202A/SMD INTERFACE
DEC LSI-11 Compatible
wi?
o Interfaces LSI-11 through 11/23 microcomputers.
e Emulates DEC RPO2/RP03.
* Connects up to two SMD I/O disk drives including 8- and 14-inch
Winchester, SMD pack and CMD cartridge type drives.
e RT-11, RSX-11, RSTS and TSX-Plus software compatibility.
e Universal Formatting.TM
e Completely contained on one quad-wide module.
e Automatic media flaw compensation with bad-sector flagging
and transparent, automatic track-skipping features.
e Full sector data buffer.
e On-board bootstrap loader.
| —
HOW TO ORDER
To place an order, simply supply DILOG
with the following information:
(1) Your purchase order number.
(2) “Bill to” and “Ship to" addresses.
(3) Your DEC computer type (e.g.,
PDP-11/34, etc.).
(4) Operating system and version used
MODEL DU202A/SMD INTERFACE
DEC PDP-11 Compatible
Interfaces PDP-11 computers.
Emulates DEC RP02/RP03.
Connects up to two SMD 1/0 disk drives.
RT-11, RSX-11, RSTS and TSX-Plus software compatibility.
Universal Formatting.™
Up to 88% utilization of drive unformatted storage capacity.
Completely contained on one quad-wide module. |
Full sector data buffer.
Automatic media flaw compensation with bad-sector flagging
and transparent, automatic track-skipping features.
SERVICE & WARRANTY
Twelve-month warranty with return to
factory.
Ninety-day warranty replacement
service.
Controller board loaner service
program—fixed fee—includes shipment
Ca EA
Do not affix Postage Stamps if posted in
Gt Britain, Channel Islands, N Ireland
or the Isle of Man
B.R. LICENCE NO. AHE 555
Postage
will be
paid by
licensee
(e.g., RSX-11M, Ver. 4.0; VMS, Ver. 3.1,
etc.)
(5) Manufacturer (see page 2) and drive
model number (e.g., Cipher F880-1).
(6) Emulation desired (TS-11, ВРО2, ВКОб,
etc.).
(7) Diagnostics media (800 cr 1600 bpi
tape, RX01 or 02 floppy, etc.).
(8) Quantity desired and ship date.
(9) Cables (from controllers to the drive[s]).
of loaner board via overnight express
service.
Product update service to reflect
upgrades by DEC of DEC operating
system software.
Telephone technical assistance.
On-site service availability as required.
Out-of-warranty repair—return to
factory—fixed fee.
ei on
Do not affix Postage Stamps if posted in
- Gt Britain, Channel Islands, N Ireland
B.R. LICENCE NO. AHE 555
or the Isle of Man
Postage
will be
paid by
licensee
IBUTED
IC CORP
NTE
STR
LOG
С
12 Temple Square,
AYLESBURY,
NTE
TI
С
STRI
LOGI
МАЙ
12 Temple Square,
AYLESBURY,
D
INT
Buckinghamshire,
HP20 1BR,
Buckinghamshire,
HP20 1BR,
ACTION REQUEST
Name:
Title:
Company:
Address:
Telephone (>)
My Application:
CPU _
Disk
Tape
Operating System
Present Controller
Please provide the following services:
0 Send specific data sheets on:
[J Provide price quote quantity:
[] Have salesman call.
J Add to mailing list.
ACTION REQUEST
Name:
-— Title:
E ans mat So aia
Company:
Address:
Telephone ( )
My Application:
CPU
Disk
Tape
Operating System
Present Controller
Please provide the following services:
[J Send specific data sheets on:
[J Provide price quote quantity:
[J Have salesman call.
J Add to mailing list.
BE ia. Mi. a a ot ias. > iaa à =
a a aa
Ï
e a
a UE aT
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
