Digital audio mixing - stepping into ENG and EFP
E
ffective audio quality is now more important than ever for Electronic News Gathering (ENG) and Electronic Field Production (EFP) applications
because, even with high-quality video, lackluster audio performance will result in a mediocre production.
Introducing the DMX-P01 Digital Portable Mixer, Sony’s answer to these high-quality audio requirements. Not only does the DMX-P01 offer
outstanding audio quality, it is also one of the most user-friendly mixers in the ENG and EFP markets.
With full 24-bit processing and a sampling rate of either 48kHz or 96kHz, the DMX-P01 provides sound quality comparable to high-end production
mixers. Its front panel is human engineered to allow fast, easy, and accurate setting adjustments - essential when working in the field. It also
includes other useful features, such as panel-lock and parameter-lock functions, selectable meter scales, camera-audio return-level check,
memory function, digital cascade capability, and digital outputs.
All of this functionality and versatility is packaged into one sleek, compact, and lightweight body that can be used effortlessly in field productions.
Make the DMX-P01 your first step into the world of portable digital-audio mixing in the field.
◗◗◗Digital Benefits of the DMX-P01
Excellent Sound Quality/Full Digital
Processing
In order to provide outstanding sound quality for ENG and
EFP applications, the DMX-P01 offers full digital-audio
processing. Its 24-bit A/D and D/A converters provide a
high level of linearity for analog inputs and outputs.
Internally, the unit utilizes 32-bit digital processing for
maximum throughput. In addition, the DMX-P01 has a
sampling rate that is selectable from either 48kHz or
96kHz.
High-Quality Digital Limiters/Compressors
By using digital limiters and compressors, the DMX-P01
can provide extremely high-quality sound in one small
package. Limiters are available at the input, and both
limiters and compressors are available at the output for
maximum flexibility.
Full Parameter Controls From The Front
Panel
The DMX-P01 puts all of its controls at your fingertips,
with a cleanly organized and logical layout on the unit’s
front panel. The DMX-P01 processes audio digitally, so
parameters that are used less frequently are stored
internally and accessed only when needed. Using the
front-panel controls and easy-to-read LCD allows full
control of every parameter without the need to remove
the unit from its audio-organizer case. The LCD panel is
also equipped with a backlight, so the unit can be used
in low-light conditions too.
Panel-Lock and Parameter-Lock Features
One major concern for audio engineers in the field is the
accidental bumping of controls, which can inadvertently
change the sound settings. The DMX-P01 safeguards
against this with its panel-lock feature, which can be set
to secure all of the control settings, or selected individual
control settings. With the lock engaged, physical contact
with the controls will not alter their settings. In addition,
a Parameter-Lock feature also avoids inadvertent
parameter changes.
Flexible Meter Scales
Because the DMX-P01 is a digital mixer, the meter
calibrations can be easily changed from one type to
another without the need to replace the entire meter.
LEFT PANEL
Six easy-to-change meter scale sheets are supplied:
VU, PPM1 (BBC-type), PPM2 (DIN-type), PPM3 (NORDICtype), PPM4 (IEC-type1), and dBFS. Simply insert the
desired scale sheet and select the appropriate meter type
from the setup menu. The DMX-P01 will display the
audio level according to the scale selected.
Camera-Audio Return-Level Check
The DMX-P01 enables users to visually verify that the
mixer’s audio level matches the level recorded to the
camcorder tape. This is done using the camera return-level
mode, available in the setup menu. Simply send a
reference tone signal to the camcorder and the level
difference between the mixer output and camcorder
return signal will be displayed. Then adjust the marker to
the central position, and the level adjustment is complete.
Memory Function
The DMX-P01 processes audio digitally, so users can
effortlessly store and recall parameters from the setup
menu. There are two memory functions: “Power-On
Memory Recall,” and “Scene Memory Recall.”
Power-On Memory Recall - When the DMX-P01 is powered
on, the system is capable of recalling parameters in three
different ways: with the default factory settings, with the
same settings as the last time the unit was used, or with
the parameters of one specific scene memory.
Scene Memory Recall - This feature allows users to recall
up to ten different user-defined parameter settings or the
factory default settings.
In situations where a single unit is required to serve
multiple users or multiple shooting scenarios, these
features can prove invaluable.
Digital Cascade
For applications requiring additional inputs, DMX-P01
mixers can be cascaded using a digital connection
between mixers. The benefit of cascading mixers digitally
is that sound quality is not degraded, as it would be when
cascading analog mixers.
Digital Output
The DMX-P01 is equipped with a digital output, which
can be used to send audio to digital peripheral equipment
such as DAT recorders. AES/EBU and S/PDIF coaxial
interfaces are available.
RIGHT PANEL
◗◗◗Features
Inputs
• 4 microphone/line inputs with XLR type balanced connectors
• +48 V power for each microphone input
• Digital cascade input with phono connector
• Microphone/line gain-level control
• Level control knobs with stereo-link facility
• Selectable sampling rate (48 kHz or 96 kHz) for A/D
converters
Outputs
• 2 balanced outputs on XLR-type balanced connectors
• Digital AES/EBU output (stereo) on XLR-type balanced
connector
• Coaxial output connector for mix-bus output
(for cascade) or S/PDIF digital output (selectable)
• Stereo tape output on unbalanced 3.5 mm TRS jack
• Switchable output mode: stereo or monaural
• Selectable output-level control for L/R master outputs
and camera send
• Selectable sampling rate (48 kHz or 96 kHz) for D/A
converters
Panning
• Variable pan controls
Low Cut Filters
• Adjustable (50 to 200 Hz) cut-off frequencies for 2
user settings (A/B)
• Quick parameter-recall switch with OFF/A/B positions
Limiters/Compressors
• Digital limiters on both inputs and outputs
• Digital compressors on outputs
• Precise parameter control on threshold and ratio value,
attack and release time
• Link function (ON/OFF switchable)
• LED indicators for output limiter/compressor operation
Link/M-S operation
• Links input levels, LCFs, and PAN controls for channels
1/2 and 3/4
• Links output levels and limiter/compressor settings for
master left/right outputs
• Decodes M-S microphone inputs, and links the input
levels of channels 1/2 and 3/4
• Phase reverse on channels 2 and 4 (M-S decode)
LCD Panel
• Various level-meter displays: VU, PPM1 (BBC-type),
PPM2 (DIN-type), PPM3 (NORDIC-type), PPM4
(IEC-type1), dBFS
• Displays setup menus and allows various parameter
settings
• Three quick-recall memory settings for immediate
mixer setup
• Ten user-scene memory settings (each including level
meter, LCF, limiter/compressor, and link status)
• Six scale sheets supplied for different level-meter
calibrations
• Back light
• Heated LCD for low-temperature conditions
Monitoring
• 2 outputs: 1/4-inch phone jack and 3.5-mm mini jack
• Six monitoring modes: left output, right output, stereo
output, left/right-mixed monaural, M/S decode and
camera return
• Level-control knob
Camera-Audio Send/Return-Level Control
• Stereo return from a camcorder via 12-pin Tajimi
balanced connector
• Precise level control on LED with auto-evaluation
function for return level
• Monitoring capability with headphones
Oscillator/Talkback (selectable)
• Oscillator: 1-kHz pilot-tone signal into all outputs
• Talkback: slate into all outputs
• Momentary and alternative modes for both oscillator
and talkback
Power
• External DC 10 to 15 V input with 4-pin XLR connector
• External DC 12 V input with jack connector
• DC 12 V output on 4-pin Hirose connector
• 8 internal AA-size (LR6) alkaline batteries for approx.
5 hours of continuous operation
◗◗◗System Example
Headphones
Boom Mic
DMX-P01
2-Ch Portable
Receiver
Bodypack
Transmitters
Portable DAT Recorder
Camcorder
◗◗◗Specifications
Inputs
Analog inputs
Cascade input (digital)
Outputs
Master outputs (analog)
Digital outputs
Cascade output
(or S/PDIF output)
Tape outputs (analog)
Camera send/return
A/D converter
D/A converter
Sampling frequency
Signal processing
Low cut filter
Input/output limiter
Output compressor
Frequency response
Total Harmonic Distortion
Equivalent input noise
Crosstalk
Level meter calibration
Monitoring
Operating Voltage
Internal
External
Battery life
at 25 ºC
Power supply
(to wireless microphone)
Operating temperature
Storage temperature
Dimensions (W x H x D)
Weight
4 ch, XLR-3-31 (x 4), electrically balanced, microphone
power; +48 V (on/off)
Mic level; -70 to -30 dBu (max. 0 dBu), 2.2 kΩ or more
Line level; -30 to +10 dBu (max. +24 dBu), 10 kΩ or more
Phase reverse on channels 2 and 4
2 busses (L/R), S/PDIF (IEC 60958 coaxial), phono, 75 Ω
A
LCF OFF
B
+48V
Line/Mic
2 ch (L/R), -60/-10/+4 dBu (max. +24 dBu), XLR-3-32 (x 2),
balanced, 600 Ω load or more
2 ch (L/R), AES/EBU, XLR-3-32 (x 1), electrically balanced,
110 Ω load or more
2 ch (L/R), S/PDIF (IEC 60958 coaxial), phono, unbalanced,
75 Ω load
2 ch (L/R), -10 dBu (max. +10 dBu), 3.5 mm dia. TRS jack,
unbalanced, 10 kΩ load or more
2 ch (L/R), 12-pin Tajimi, balanced,
Send level; -60/-10/+4 dBu (max. +24 dBu), 600 Ω load or more
Return level; 0 dBu (max. +20 dBu), 10 kΩ or more
24 bits
24 bits
48 kHz or 96 kHz
32 bits
50 to 200 Hz (in 10 Hz steps), 12 dB/octave
Threshold; 0 to +20 dB
Threshold; -20 to +10 dB, ratio; 2:1 to 10:1, attack time;
0.5 to 100.0 ms, release time; 0.1 to 2.0 s
20 Hz to 40 kHz +0.5/-3.0 dB (at 96 kHz sampling frequency)
20 Hz to 20 kHz +0.5/1.0 dB (at 48 kHz sampling frequency)
Less than 0.05%
-126 dBu (IHF-A)
Less than -90 dB (1kHz)
VU, BBC-type DIN-type, NORDIC-type, IEC-type1,
dBSF (selectable)
1/4-inch TRS jack (x 1) and 3.5-mm dia. TRS jack (x 1)
with level control
DC 12 V (eight AA-size alkaline batteries)
DC 12 V via DC jack or DC 10 to 15 V via an XLR 4-pin
connector
5 hours or more with Sony AA-size alkaline batteries
DSP
CHANNEL INPUT
VOL
LIMITER
LCF
CH1
A/D
ATT
50 to
200Hz
Trim
+10 to -30dBu
-30 to -70dBu
Line/Mic
PAN
CHANNEL
VOL
50 to
200Hz
Trim
+10 to -30dBu
-30 to -70dBu
+48V
A
LCF OFF
B
+48V
Line/Mic
BUS
IN
24bit
96kHz/48kHz
OUTPUT R
CAMERA
LIM
PAN
S/PDIF or
BUS OUT
COAXIAL
DO
M-S
PAN
PHONES
HEADPHONE
AMP
LIM
A/D
Trim
+10 to -30dBu
-30 to -70dBu
ATT
+4/-20/-60dBu
LCF
ATT
OUTPUT L
INPUT
LIMITER
50 to
200Hz
A
LCF OFF
B
CH4
SLATE
MIC
CHANNEL
VOL
LCF
Trim
+10 to -30dBu
-30 to -70dBu
ATT
LIM
INPUT LEVEL
METER
A/D
ATT
D/A
INPUT
LIMITER
OUTPUT
COMP/
LIMITER
Line/Mic
CH3
TAPE OUT
-10dBu
OUTPUT
VOL
LIM
A/D
ATT
AES/EBU
LIM
LCF
CH2
DO
PAN
M-S
A
LCF OFF
B
+48V
LEVEL
METER
LIM
50 to
200Hz
CHANNEL
VOL
INPUT
LIMITER
D/A
PHONES
HEADPHONE
SELECT
DC IN XLR
AGC
OSC
1kHz
DC IN BP-90
DI
POWER
SUPPLY
8 x AA size
batteries
DC 12 V via 4-pin Hirose connector
+23 to +104 ºF (-5 to +40 ºC)
-22 to +158 ºF (-30 to +70 ºC)
10 1/2 x 2 3/4 x 8 1/8 inches (266 x 68 x 206 mm)
Approx. 4 Ib 13 oz (2.2 kg)
®
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
www.sony.com/proaudio
MK10015V1IW02SEP
A-1101
◗◗◗Block Diagram
96kHz
48kHz
LCD HEATER
SYSTEM
CLOCK
SAMPLING RATE SELECT
© 2002 Sony Electronics Inc. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measurements are approximate.
Sony is a trademark of Sony .
Printed in USA (11/02)
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
