Starting out new with USB can be quite daunting. With the USB 2.0 specification at 650 pages one could easily be
put off just by the sheer size of the standard. This is only the beginning of a long list of associated standards for
USB. There are USB Class Standards such as the HID Class Specification which details the common operation of
devices (keyboards, mice etc) falling under the HID (Human Interface Devices) Class - only another 97 pages. If
you are designing a USB Host, then you have three Host Controller Interface Standards to choose from. None of
these are detailed in the USB 2.0 Spec.
The good news is you don’t even need to bother reading the entire USB standard. Some chapters were churned
out by marketing, others aimed at the lower link layer normally taken care off by your USB controller IC and a
couple aimed at host and hub developers. Lets take a little journey through the various chapters of the USB 2.0
specification and briefly introduce the key points.
Chapter
Name
1
Introduction
Includes the motivation and scope for USB. The most important piece
of information in this chapter is to make reference to the Universal
Serial Bus Device Class Specifications. No need reading this chapter.
2
2
Terms and
Abbreviations
This chapter is self-explanatory and a necessary evil to any standard.
8
3
Background
Specifies the goals of USB which are Plug’n’Play and simplicity to the
end user (not developer). Introduces Low, Full and High Speed ranges
with a feature list straight from marketing. No need reading this chapter
either.
4
4
Architectural
Overview
10
5
USB Data Flow
Model
6
Mechanical
7
Electrical
This is where you can start reading. This chapter provides a basic
overview of a USB system including topology, data rates, data flow
types, basic electrical specs etc.
This chapter starts to talk about how data flows on a Universal Serial
Bus. It introduces terms such as endpoints and pipes then spends
most of the chapter on each of the data flow types (Control, Interrupt,
Isochronous and Bulk). While it’s important to know each transfer type
and its properties it is a little heavy on for a first reader.
This chapter details the USB’s two standard connectors. The important
information here is that a type A connector is oriented facing
downstream and a type B connector upstream. Therefore it should be
impossible to plug a cable into two upstream ports. All detachable
cables must be full/high speed, while any low speed cable must be
hardwired to the appliance. Other than a quick look at the connectors,
you can skip this chapter unless you intend to manufacture USB
connectors and/or cables. PCB designers can find standard footprints
in this chapter.
This chapter looks at low level electrical signalling including line
impedance, rise/fall times, driver/receiver specifications and bit level
encoding, bit stuffing etc. The more important parts of this chapter are
the device speed identification by using a resistor to bias either data
line and bus powered devices vs self powered devices. Unless you are
designing USB transceivers at a silicon level you can flip through this
chapter. Good USB device datasheets will detail what value bus
termination resistors you will need for bus impedance matching.
8
Protocol Layer
9
USB Device
Frame Work
USB in a Nutshell
Description
Pages
Now we start to get into the protocol layers. This chapter describes the
USB packets at a byte level including the sync, pid, address, endpoint,
CRC fields. Once this has been grasped it moves on to the next
protocol layer, USB packets. Most developers still don’t see these
lower protocol layers as their USB device IC’s take care of this.
However an understanding of the status reporting and handshaking is
worthwhile.
This is the most frequently used chapter in the entire specification and
the only one I ever bothered printing and binding. This details the bus
enumeration and request codes (set address, get descriptor etc) which
make up the most common protocol layer USB programmers and
designers will ever see. This chapter is a must read in detail.
Page 2
60
33
75
45
36
www.beyondlogic.org
10
USB Host
Hardware and
Software
11
Hub Specification
This chapter covers issues relating to the host. This includes frame and
microframe generation, host controller requirements, software
mechanisms and the universal serial bus driver model. Unless you are
designing Hosts, you can skip this chapter.
Details the workings of USB hubs including hub configuration, split
transactions, standard descriptors for hub class etc. Unless you are
designing Hubs, you can skip this chapter.
23
143
So now we can begin to read the parts of the standard relevant to our needs. If you develop drivers (Software)
for USB peripherals then you may only need to read chapters,
• 4 - Architectural Overview
• 5 - USB Data Flow Model
• 9 - USB Device Frame Work, and
• 10 - USB Host Hardware and Software.
Peripheral hardware (Electronics) designers on the other hand may only need to read chapters,
• 4 - Architectural Overview
• 5 - USB Data Flow Model
• 6 - Mechanical, and
• 7 - Electrical.
USB in a NutShell for Peripheral Designers
Now lets face it, (1) most of us are here to develop USB peripherals and (2) it's common to read a standard
and still have no idea how to implement a device. So in the next 7 chapters we focus on the relevant parts
needed to develop a USB device. This allows you to grab a grasp of USB and its issues allowing you to further
research the issues specific to your application.
The USB 1.1 standard was complex enough before High Speed was thrown into USB 2.0. In order to help
understand the fundamental principals behind USB, we omit many areas specific to High Speed USB 2.0
devices. Once a grasp of USB 1.1 is obtained, these additional 2.0 details should be easy to pick up.
Introducing the Universal Serial Bus
USB version 1.1 supported two speeds, a full speed mode of 12Mbits/s and a low speed mode of 1.5Mbits/s.
The 1.5Mbits/s mode is slower and less susceptible to EMI, thus reducing the cost of ferrite beads and quality
components. For example, crystals can be replaced by cheaper resonators. USB 2.0 which is still yet to see
day light on mainstream desktop computers has upped the stakes to 480Mbits/s. The 480Mbits/s is known as
High Speed mode and was a tack on to compete with the Firewire Serial Bus.
USB Speeds
• High Speed - 480Mbits/s
• Full Speed - 12Mbits/s
• Low Speed - 1.5Mbits/s
The Universal Serial Bus is host controlled. There can only be one host per bus. The specification in itself,
does not support any form of multimaster arrangement. However the On-The-Go specification which is a tack
on standard to USB 2.0 has introduced a Host Negotiation Protocol which allows two devices negotiate for the
role of host. This is aimed at and limited to single point to point connections such as a mobile phone and
personal organiser and not multiple hub, multiple device desktop configurations. The USB host is responsible
for undertaking all transactions and scheduling bandwidth. Data can be sent by various transaction methods
using a token-based protocol.
In my view the bus topology of USB is somewhat limiting. One of the original intentions of USB was to reduce
the amount of cabling at the back of your PC. Apple people will say the idea came from the Apple Desktop Bus,
where both the keyboard, mouse and some other peripherals could be connected together (daisy chained)
using the one cable.
However USB uses a tiered star topology, simular to that of 10BaseT Ethernet. This imposes the use of a hub
somewhere, which adds to greater expense, more boxes on your desktop and more cables. However it is not
as bad as it may seem. Many devices have USB hubs integrated into them. For example, your keyboard may
contain a hub which is connected to your computer. Your mouse and other devices such as your digital camera
USB in a Nutshell
Page 3
www.beyondlogic.org
can be plugged easily into the back of your keyboard. Monitors are just another peripheral on a long list which
commonly have in-built hubs.
This tiered star topology, rather than simply daisy chaining devices together has some benefits. Firstly power to
each device can be monitored and even switched off if an overcurrent condition occurs without disrupting other
USB devices. Both high, full and low speed devices can be supported, with the hub filtering out high speed and
full speed transactions so lower speed devices do not receive them.
Up to 127 devices can be connected to any one USB bus at any one given time. Need more devices? - Simply
add another port/host. While earlier USB hosts had two ports, most manufacturers have seen this as limiting
and are starting to introduce 4 and 5 port host cards with an internal port for hard disks etc. The early hosts had
one USB controller and thus both ports shared the same available USB bandwidth. As bandwidth requirements
grew, we are starting to see multi-port cards with two or more controllers allowing individual channels.
The USB host controllers have their own specifications. With USB 1.1, there were two Host Controller Interface
Specifications, UHCI (Universal Host Controller Interface) developed by Intel which puts more of the burden on
software (Microsoft) and allowing for cheaper hardware and the OHCI (Open Host Controller Interface)
developed by Compaq, Microsoft and National Semiconductor which places more of the burden on
hardware(Intel) and makes for simpler software. Typical hardware / software engineer relationship. . .
With the introduction of USB 2.0 a new Host Controller Interface Specification was needed to describe the
register level details specific to USB 2.0. The EHCI (Enhanced Host Controller Interface) was born. Significant
Contributors include Intel, Compaq, NEC, Lucent and Microsoft so it would hopefully seem they have pooled
together to provide us one interface standard and thus only one new driver to implement in our operating
systems. Its about time.
USB as its name would suggest is a serial bus. It uses 4 shielded wires of which two are power (+5v & GND).
The remaining two are twisted pair differential data signals. It uses a NRZI (Non Return to Zero Invert)
encoding scheme to send data with a sync field to synchronise the host and receiver clocks.
USB supports plug’n’plug with dynamically loadable and unloadable drivers. The user simply plugs the device
into the bus. The host will detect this addition, interrogate the newly inserted device and load the appropriate
driver all in the time it takes the hourglass to blink on your screen provided a driver is installed for your device.
The end user needs not worry about terminations, terms such as IRQs and port addresses, or rebooting the
computer. Once the user is finished, they can simply lug the cable out, the host will detect its absence and
automatically unload the driver.
The loading of the appropriate driver is done using a PID/VID (Product ID/Vendor ID) combination. The VID is
supplied by the USB Implementor's forum at a cost and this is seen as another sticking point for USB. The
latest info on fees can be found on the USB Implementor’s Website
Other standards organisations provide an extra VID for non-commercial activities such as teaching, research or
fiddling (The Hobbyist). The USB Implementors forum has yet to provide this service. In these cases you may
wish to use one assigned to your development system's manufacturer. For example most chip manufacturers
will have a VID/PID combination you can use for your chips which is known not to exist as a commercial
device. Other chip manufacturers can even sell you a PID to use with their VID for your commercial device.
Another more notable feature of USB, is its transfer modes. USB supports Control, Interrupt, Bulk and
Isochronous transfers. While we will look at the other transfer modes later, Isochronous allows a device to
reserve a defined about of bandwidth with guaranteed latency. This is ideal in Audio or Video applications
where congestion may cause loss of data or frames to drop. Each transfer mode provides the designer tradeoffs in areas such as error detection and recovery, guaranteed latency and bandwidth.
Connectors
All devices have an upstream connection to the host and all hosts have a downstream connection to the
device. Upstream and downstream connectors are not mechanically interchangeable, thus eliminating illegal
loopback connections at hubs such as a downstream port connected to a downstream port. There are
commonly two types of connectors, called type A and type B which are shown below.
USB in a Nutshell
Page 4
www.beyondlogic.org
Receptacle Type A
Receptical Type B
2 1
1 2 3 4
3 4
Figure 1 : USB Connectors
Type A plugs always face upstream. Type A sockets will typically find themselves on hosts and hubs. For
example type A sockets are common on computer main boards and hubs. Type B plugs are always connected
downstream and consequently type B sockets are found on devices.
It is interesting to find type A to type A cables wired straight through and an array of USB gender changers in
some computer stores. This is in contradiction of the USB specification. The only type A plug to type A plug
devices are bridges which are used to connect two computers together. Other prohibited cables are USB
extensions which has a plug on one end (either type A or type B) and a socket on the other. These cables
violate the cable length requirements of USB.
USB 2.0 included errata which introduces mini-USB B connectors. The details on these connectors can be
found in Mini-B Connector Engineering Change Notice. The reasoning behind the mini connectors came from
the range of miniature electronic devices such as mobile phones and organisers. The current type B connector
is too large to be easily integrated into these devices.
Just recently released has been the On-The-Go specification which adds peer-to-peer functionality to USB.
This introduces USB hosts into mobile phone and electronic organisers, and thus has included a specification
for mini-A plugs, mini-A receptacles, and mini-AB receptacles. I guess we should be inundated with mini USB
cables soon and a range of mini to standard converter cables.
Pin Number
Cable Colour
Function
1
2
3
4
Red
White
Green
Black
VBUS (5 volts)
DD+
Ground
Table 1 : USB Pin Functions
Standard internal wire colours are used in USB cables, making it easier to identify wires from manufacturer to
manufacturer. The standard specifies various electrical parameters for the cables. It is interesting to read the
detail the original USB 1.0 spec included. You would understand it specifying electrical attributes, but
paragraph 6.3.1.2 suggested the recommended colour for overmolds on USB cables should be frost white how boring! USB 1.1 and USB 2.0 was relaxed to recommend Black, Grey or Natural.
PCB designers will want to reference chapter 6 for standard foot prints and pinouts.
Electrical
Unless you are designing the silicon for a USB device/transceiver or USB host/hub, there is not all that much
you need to know about the electrical specifications in chapter 7. We briefly address the essential points here.
As we have discussed, USB uses a differential transmission pair for data. This is encoded using NRZI and is
bit stuffed to ensure adequate transitions in the data stream. On low and full speed devices, a differential ‘1’ is
transmitted by pulling D+ over 2.8V with a 15K ohm resistor pulled to ground and D- under 0.3V with a 1.5K
ohm resistor pulled to 3.6V. A differential ‘0’ on the other hand is a D- greater than 2.8V and a D+ less than
0.3V with the same appropriate pull down/up resistors.
The receiver defines a differential ‘1’ as D+ 200mV greater than D- and a differential ‘0’ as D+ 200mV less than
D-. The polarity of the signal is inverted depending on the speed of the bus. Therefore the terms ‘J’ and ‘K’
states are used in signifying the logic levels. In low speed a ‘J’ state is a differential 0. In high speed a ‘J’ state
is a differential 1.
USB transceivers will have both differential and single ended outputs. Certain bus states are indicated by
single ended signals on D+, D- or both. For example a single ended zero or SE0 can be used to signify a
USB in a Nutshell
Page 5
www.beyondlogic.org
device reset if held for more than 10mS. A SE0 is generated by holding both D- and D+ low (< 0.3V). Single
ended and differential outputs are important to note if you are using a transceiver and FPGA as your USB
device. You cannot get away with sampling just the differential output.
The low speed/full speed bus has a characteristic impedance of 90 ohms +/- 15%. It is therefore important to
observe the datasheet when selecting impedance matching series resistors for D+ and D-. Any good datasheet
should specify these values and tolerances.
High Speed (480Mbits/s) mode uses a 17.78mA constant current for signalling to reduce noise.
Speed Identification
A USB device must indicate its speed by pulling either the D+ or D- line high to 3.3 volts. A full speed device,
pictured below will use a pull up resistor attached to D+ to specify itself as a full speed device. These pull up
resistors at the device end will also be used by the host or hub to detect the presence of a device connected to
its port. Without a pull up resistor, USB assumes there is nothing connected to the bus. Some devices have
this resistor built into its silicon, which can be turned on and off under firmware control, others require an
external resistor.
TM
For example Philips Semiconductor has a SoftConnect technology. When first connected to the bus, this
allows the microcontroller to initialise the USB function device before it enables the pull up speed identification
resistor, indicating a device is attached to the bus. If the pull up resistor was connected to Vbus, then this would
indicate a device has been connected to the bus as soon as the plug is inserted. The host may then attempt to
reset the device and ask for a descriptor when the microprocessor hasn’t even started to initialise the usb
function device.
TM
Other vendors such as Cypress Semiconductor also use a programmable resistor for Re-Numeration
purposes in their EzUSB devices where the one device can be enumerated for one function such as In field
programming then be disconnected from the bus under firmware control, and enumerate as another different
device, all without the user lifting an eyelid. Many of the EzUSB devices do not have any Flash or OTP ROM to
store code. They are bootstraped at connection
3.3V
1.5K +/- 5%
Full Speed Device
HOST or HUB
HOST or HUB
DEVICE
15K +/- 5%
15K +/- 5%
15K +/- 5%
DEVICE
D-
D-
D-
D-
D+
D+
D+
D+
Low Speed Device
Figure 2 : Full Speed Device with pull up resistor connected to Dconnected to D+
15K +/- 5%
1.5K +/- 5%
3.3V
Figure 3 : Low Speed Device with pull up resistor
You will notice we have not included speed identification for High Speed mode. High speed devices will start by
connecting as a full speed device (1.5k to 3.3V). Once it has been attached, it will do a high speed chirp during
reset and establish a high speed connection if the hub supports it. If the device operates in high speed mode,
then the pull up resistor is removed to balance the line.
A USB 2.0 compliant device is not required to support high-speed mode. This allows cheaper devices to be
produced if the speed isn’t critical. This is also the case for a low speed USB 1.1 devices which is not required
to support full speed.
However a high speed device must not support low speed mode. It should only support full speed mode
needed to connect first, then high speed mode if successfully negotiated later. An USB 2.0 compliant
downstream facing device (Hub or Host) must support all three modes, high speed, full speed and low speed.
USB in a Nutshell
Page 6
www.beyondlogic.org
Power (VBUS)
One of the benefits of USB is bus-powered devices - devices which obtain its power from the bus and requires
no external plug packs or additional cables. However many leap at this option without first considering all the
necessary criteria.
A USB device specifies its power consumption expressed in 2mA units in the configuration descriptor which we
will examine in detail later. A device cannot increase its power consumption, greater than what it specifies
during enumeration, even if it looses external power. There are three classes of USB functions,
• Low-power bus powered functions
• High-power bus powered functions
• Self-powered functions
Low power bus powered functions draw all its power from the VBUS and cannot draw any more than one unit
load. The USB specification defines a unit load as 100mA. Low power bus powered functions must also be
designed to work down to a VBUS voltage of 4.40V and up to a maximum voltage of 5.25V measured at the
upsteam plug of the device. For many 3.3V devices, LDO regulators are mandatory.
High power bus powered functions will draw all its power from the bus and cannot draw more than one unit
load until it has been configured, after which it can then drain 5 unit loads (500mA Max) provided it asked for
this in its descriptor. High power bus functions must be able to be detected and enumerated at a minimum
4.40V. When operating at a full unit load, a minimum VBUS of 4.75 V is specified with a maximum of 5.25V.
Once again, these measurements are taken at the upstream plug.
Self power functions may draw up to 1 unit load from the bus and derive the rest of it’s power from an external
source. Should this external source fail, it must have provisions in place to draw no more than 1 unit load from
the bus. Self powered functions are easier to design to specification as there is not so much of an issue with
power consumption. The 1 unit bus powered load allows the detection and enumeration of devices without
mains/secondary power applied.
No USB device, whether bus powered or self powered can drive the VBUS on its upstream facing port. If VBUS is
lost, the device has a lengthy 10 seconds to remove power from the D+/D- pull-up resistors used for speed
identification.
Other VBUS considerations are the Inrush current which must be limited. This is outlined in the USB
specification paragraph 7.2.4.1 and is commonly overlooked. Inrush current is contributed to the amount of
capacitance on your device between VBUS and ground. The spec therefore specifies that the maximum
decoupling capacitance you can have on your device is 10uF. When you disconnect the device after current is
flowing through the inductive USB cable, a large flyback voltage can occur on the open end of the cable. To
prevent this, a 1uF minimum VBUS decoupling capacitance is specified.
For the typical bus powered device, it can not drain any more than 500mA which is not unreasonable. So what
is the complication you ask? Prehaps Suspend Mode?
Suspend Current
Suspend mode is mandatory on all devices. During suspend, additional constrains come into force. The
maximum suspend current is proportional to the unit load. For a 1 unit load device (default) the maximum
suspend current is 500uA. This includes current from the pull up resistors on the bus. At the hub, both D- and
D+ have pull down resistors of 15K ohms. For the purposes of power consumption, the pull down resistor at the
device is in series with the 1.5K ohms pull up, making a total load of 16.5K ohms on a VTERM of typically 3.3v.
Therefore this resistor sinks 200uA before we even start.
Another consideration for many devices is the 3.3V regulator. Many of the USB devices run on 3.3V. The
PDIUSBD11 is one such example. Linear regulators are typically quite inefficient with average quiescent
currents in the order of 600uA, therefore more efficient and thus expensive regulators are called for. In the
majority of cases, you must also slow down or stop clocks on microcontrollers to fall within the 500uA limit.
Many developers ask in the USB Implementor's Forum, what are the complications of exceeding this limit? It is
understood, that most hosts and hubs don’t have the ability to detect such an overload of this magnitude and
thus if you drain maybe 5mA or even 10mA you should still be fine, bearing in mind that at the end of the day,
your device violates the USB specification. However in normal operation, if you try to exceed the 100mA or
your designated permissible load, then expect the hub or host to detect this and disconnect your device, in the
interest of the integrity of the bus.
USB in a Nutshell
Page 7
www.beyondlogic.org
Of course these design issues can be avoided if you choose to design a self powered device. Suspend
currents may not be a great concern for desktop computers but with the introduction of the On-The-Go
Specification we will start seeing USB hosts built into mobile phones and mobile organisers. The power
consumption pulled from these devices will adversely effect the operating life of the battery.
Entering Suspend Mode
A USB device will enter suspend when there is no activity on the bus for greater than 3.0ms. It then has a
further 7ms to shutdown the device and draw no more than the designated suspend current and thus must be
only drawing the rated suspend current from the bus 10mS after bus activity stopped. In order to maintain
connected to a suspended hub or host, the device must still provide power to its pull up speed selection
resistors during suspend.
USB has a start of frame packet or keep alive sent periodically on the bus. This prevents an idle bus from
entering suspend mode in the absence of data.
• A high speed bus will have micro-frames sent every 125.0 µs ±62.5 ns.
• A full speed bus will have a frame sent down each 1.000 ms ±500 ns.
• A low speed bus will have a keep alive which is a EOP (End of Packet) every 1ms only in the absence
of any low speed data.
The term "Global Suspend" is used when the entire USB bus enters suspend mode collectively. However
selected devices can be suspended by sending a command to the hub that the device is connected too. This is
referred to as a "Selective Suspend."
The device will resume operation when it receives any non idle signalling. If a device has remote wakeup
enabled then it may signal to the host to resume from suspend.
Data Signalling Rate
Another area which is often overlooked is the tolerance of the USB clocks. This is specified in the USB
specification, section 7.1.11.
• High speed data is clocked at 480.00Mb/s with a data signalling tolerance of ± 500ppm.
• Full speed data is clocked at 12.000Mb/s with a data signalling tolerance of ±0.25% or 2,500ppm.
• Low speed data is clocked at 1.50Mb/s with a data signalling tolerance of ±1.5% or 15,000ppm.
This allows resonators to be used for low cost low speed devices, but rules them out for full or high speed
devices.
USB in a Nutshell
Page 8
www.beyondlogic.org
USB Protocols
Unlike RS-232 or similar serial interfaces where the format of data being sent is not defined, USB is made up of
several layers of protocols. While this sounds complicated, don’t give up now. Once you understand what is
going on, you really only have to worry about the higher level layers. In fact most USB controller I.C.s will take
care of the lower layer, thus making it almost invisible to the end designer.
Each USB transaction consists of a
• Token Packet (Header defining what it expects to follow), an
• Optional Data Packet, (Containing the payload) and a
• Status Packet (Used to acknowledge transactions and to provide a means of error correction)
As we have already discussed, USB is a host centric bus. The host initiates all transactions. The first packet,
also called a token is generated by the host to describe what is to follow and whether the data transaction will
be a read or write and what the device’s address and designated endpoint is. The next packet is generally a
data packet carrying the payload and is followed by an handshaking packet, reporting if the data or token was
received successfully, or if the endpoint is stalled or not available to accept data.
Common USB Packet Fields
Data on the USBus is transmitted LSBit first. USB packets consist of the following fields,
Sync
All packets must start with a sync field. The sync field is 8 bits long, which is used to synchronise the
clock of the receiver with the transmitter. The last two bits indicate where the PID fields starts.
PID
PID stands for Packet ID. This field is used to identify the type of packet that is being sent. The
following table shows the possible values.
Group
PID Value
Packet Identifier
Token
0001
1001
0101
1101
OUT Token
IN Token
SOF Token
SETUP Token
Data
0011
1011
0111
1111
DATA0
DATA1
DATA2
MDATA
Handshake
0010
1010
1110
0110
ACK Handshake
NAK Handshake
STALL Handshake
NYET (No Response Yet)
Special
1100
1100
1000
0100
PREamble
ERR
Split
Ping
There is 4 bits to the PID, however to insure it is received correctly, the 4 bits are complemented
and repeated, making an 8 bit PID in total. The resulting format is shown below.
PID0
PID1
PID2
PID3
nPID0
nPID1
nPID2
nPID3
ADDR
The address field specifies which device the packet is designated for. Being 7 bits in length allows for
127 devices to be supported. Address 0 is not valid, as any device which is not yet assigned an
address must respond to packets sent to address zero.
USB in a Nutshell
Page 9
www.beyondlogic.org
ENDP
The endpoint field is made up of 4 bits, allowing 16 possible endpoints. Low speed devices, however
can only have 2 endpoint additional addresses on top of the default pipe. (4 Endpoints Max)
CRC
Cyclic Redundancy Checks are performed on the data within the packet payload. All token packets
have a 5 bit CRC while data packets have a 16 bit CRC.
EOP
End of packet. Signalled by a Single Ended Zero (SE0) for approximately 2 bit times followed by a J for
1 bit time.
USB Packet Types
USB has four different packet types. Token packets indicate the type of transaction to follow, data packets
contain the payload, handshake packets are used for acknowledging data or reporting errors and start of frame
packets indicate the start of a new frame.
Token Packets
There are three types of token packets,
In – Informs the USB device that the host wishes to read information.
Out - Informs the USB device that the host wishes to send information.
Setup – Used to begin control transfers.
Token Packets must conform to the following format,
Sync
ADDR
ENDP
CRC5
EOP
Data Packets
There are two types of data packets each capable of transmitting 0 to 1023 bytes of data.
Data0
Data1
Data packets have the following format
Sync
PID
PID
Data
CRC16
EOP
Handshake Packets
There are three type of handshake packets which consist simply of the PID
ACK – Acknowledgment that the packet has been successfully received.
NAK – Reports that the device cannot send nor received data temporary. Also used during
interrupt transaction to inform the host there is no data to send.
STALL – The device finds its in a state that it requires intervention from the host.
Handshake Packets have the following format,
Sync
PID
EOP
Start of Frame Packets
The SOF packet consisting of an 11-bit frame number is sent by the host every 1mS ± 500nS.
Sync
USB in a Nutshell
PID
Frame Number
Page 10
CRC5
EOP
www.beyondlogic.org
USB Functions
When we think of a USB device, we think of a USB peripheral, but a USB device could mean a USB
transceiver device used at the host or peripheral, a USB Hub or Host Controller IC device, or a USB peripheral
device. The standard therefore makes references to USB functions which can be seen as USB devices which
provide a capability or function such as a Printer, Zip Drive, Scanner, Modem or other peripheral.
So by now we should know the sort of things which make up a USB packet. No? You're forgotten how many
bits make up a PID field already? Well don't be too alarmed. Fortunately most USB functions handle the low
level USB protocols up to the transaction layer (which we will cover next chapter) in silicon. The reason why we
cover this information is most USB function controllers will report errors such as PID Encoding Error. Without
briefly covering this, one could ask what is a PID Encoding Error? If you suggested that the last four bits of the
PID didn't match the inverse of the first four bits then you would be right.
Bus
Host
USB Device
EP0 In
[Addr][Endpoint][Direction]
EP0 Out
Addr = 2
My Function
EP1 In
EP1 Out
USB Device
EP0 In
EP0 Out
EP1 In
Addr = 3
My Function
EP1 Out
EP.. In
EP.. Out
Most functions will have a series of buffers, typically 8 bytes long. Each buffer will belong to an endpoint - EP0
IN, EP0 OUT etc. Say for example, the host sends a device descriptor request. The function hardware will read
the setup packet and determine from the address field whether the packet is for itself, and if so will copy the
payload of the following data packet to the appropriate endpoint buffer dictated by the value in the endpoint
field of the setup token. It will then send a handshake packet to acknowledge the reception of the byte and
generate an internal interrupt within the semiconductor/micro-controller for the appropriate endpoint signifying it
has received a packet. This is typically all done in hardware.
The software now gets an interrupt, and should read the contents of the endpoint buffer and parse the device
descriptor request.
Endpoints
Endpoints can be described as sources or sinks of data. As the bus is host centric, endpoints occur at the end
of the communications channel at the USB function. At the software layer, your device driver may send a
packet to your devices EP1 for example. As the data is flowing out from the host, it will end up in the EP1 OUT
buffer. Your firmware will then at its leisure read this data. If it wants to return data, the function cannot simply
write to the bus as the bus is controlled by the host. Therefore it writes data to EP1 IN which sits in the buffer
until such time when the host sends a IN packet to that endpoint requesting the data. Endpoints can also be
seen as the interface between the hardware of the function device and the firmware running on the function
device.
All devices must support endpoint zero. This is the endpoint which receives all of the devices control and status
requests during enumeration and throughout the duration while the device is operational on the bus.
USB in a Nutshell
Page 11
www.beyondlogic.org
Pipes
While the device sends and receives data on a series of endpoints, the client software transfers data through
pipes. A pipe is a logical connection between the host and endpoint(s). Pipes will also have a set of parameters
associated with them such as how much bandwidth is allocated to it, what transfer type (Control, Bulk, Iso or
Interrupt) it uses, a direction of data flow and maximum packet/buffer sizes. For example the default pipe is a
bi-directional pipe made up of endpoint zero in and endpoint zero out with a control transfer type.
USB defines two types of pipes
•
Stream Pipes have no defined USB format, that is you can send any type of data down a stream pipe
and can retrieve the data out the other end. Data flows sequentially and has a pre-defined direction,
either in or out. Stream pipes will support bulk, isochronous and interrupt transfer types. Stream pipes
can either be controlled by the host or device.
•
Message Pipes have a defined USB format. They are host controlled, which are initiated by a request
sent from the host. Data is then transferred in the desired direction, dictated by the request. Therefore
message pipes allow data to flow in both directions but will only support control transfers.
Endpoint Types
The Universal Serial Bus specification defines four transfer/endpoint types,
•
•
•
•
Control Transfers
Interrupt Transfers
Isochronous Transfers
Bulk Transfers
USB in a Nutshell
Page 12
www.beyondlogic.org
Control Transfers
Control transfers are typically used for command and status operations. They are essential to set up a USB
device with all enumeration functions being performed using control transfers. They are typically bursty,
random packets which are initiated by the host and use best effort delivery. The packet length of control
transfers in low speed devices must be 8 bytes, high speed devices allow a packet size of 8, 16, 32 or 64 bytes
and full speed devices must have a packet size of 64 bytes.
A control transfer can have up to three stages.
•
The Setup Stage is where the request is sent. This consists of three packets. The setup token is sent
first which contains the address and endpoint number. The data packet is sent next and always has a
PID type of data0 and includes a setup packet which details the type of request. We detail the setup
packet later. The last packet is a handshake used for acknowledging successful receipt or to indicate
an error. If the function successfully receives the setup data (CRC and PID etc OK) it responds with
ACK, otherwise it ignores the data and doesn’t send a handshake packet. Functions cannot issue a
STALL or NAK packet in response to a setup packet.
SETUP
DATA 0
ACK
Data Error
Key
Host
Function
Setup Token Error
Token Packet
•
Data Packet
Handshake Packet
The optional Data Stage consists of one or multiple IN or OUT transfers. The setup request indicates
the amount of data to be transmitted in this stage. If it exceeds the maximum packet size, data will be
sent in multiple transfers each being the maximum packet length except for the last packet.
The data stage has two different scenarios depending upon the direction of data transfer.
•
IN: When the host is ready to receive control data it issues an IN Token. If the function receives the
IN token with an error e.g. the PID doesn't match the inverted PID bits, then it ignores the packet. If
the token was received correctly, the device can either reply with a DATA packet containing the
control data to be sent, a stall packet indicating the endpoint has had a error or a NAK packet
indicating to the host that the endpoint is working, but temporary has no data to send.
IN
DATA x
ACK
Data Error
STALL
NAK
In Token Error
Key
OUT
DATA x
Host
Function
ACK
NAK
STALL
Data Error
Token Packet
•
Data Packet
Handshake Packet
OUT: When the host needs to send the device a control data packet, it issues an OUT token
followed by a data packet containing the control data as the payload. If any part of the OUT token
or data packet is corrupt then the function ignores the packet. If the function's endpoint buffer was
empty and it has clocked the data into the endpoint buffer it issues an ACK informing the host it
USB in a Nutshell
Page 13
www.beyondlogic.org
has successfully received the data. If the endpoint buffer is not empty due to processing of the
previous packet, then the function returns a NAK. However if the endpoint has had a error and its
halt bit has been set, it returns a STALL.
•
Status Stage reports the status of the overall request and this once again varies due to direction of
transfer. Status reporting is always performed by the function.
•
IN: If the host sent IN token(s) during the data stage to receive data, then the host must
acknowledge the successful recept of this data. This is done by the host sending an OUT token
followed by a zero length data packet. The function can now report its status in the handshaking
stage. An ACK indicates the function has completed the command is now ready to accept another
command. If an error occurred during the processing of this command, then the function will issue
a STALL. However if the function is still processing, it returns a NAK indicating to the host to repeat
the status stage later.
IN
Normal
Completion
DATA0
Zero Length
Error
STALL
Still
Processing
•
ACK
NAK
OUT: If the host sent OUT token(s) during the data stage to transmit data, the function will
acknowledge the successful recept of data by sending a zero length packet in response to an IN
token. However if an error occurred, it should issue a STALL or if it is still busy processing data, it
should issue a NAK asking the host to retry the status phase later.
OUT
DATA0
Zero Length
Normal
Completion
Error
Still
Processing
USB in a Nutshell
Page 14
ACK
STALL
NAK
www.beyondlogic.org
Control Transfers : The bigger picture
Now how does all this fit together? Let's say for example, the Host wants to request a device descriptor
during enumeration. The packets which are sent are as follows.
The host will send the Setup token telling the function that the following packet is a Setup packet. The
Address field will hold the address of the device the host is requesting the descriptor from. The endpoint
number should be zero, specifying the default pipe. The host will then send a DATA0 packet. This will have
an 8 byte payload which is the Device Descriptor Request as outlined in Chapter 9 of the USB
Specification. The USB function then acknowledges the setup packet has been read correctly with no
errors. If the packet was received corrupt, the device just ignores this packet. The host will then resend the
packet after a short delay.
1. Setup Token
Sync
PID
2. Data0 Packet
Sync
PID
3. Ack Handshake
Sync
PID
ADDR
ENDP
Data0
CRC5
EOP
Address & Endpoint Number
CRC16
EOP
Device Descriptor Request
EOP
Device Ack. Setup Packet
The above three packets represent the first USB transaction. The USB device will now decode the 8 bytes
received, and determine it was a device descriptor request. The device will then attempt to send the Device
Descriptor, which will be the next USB transaction.
1. In Token
Sync
PID
ADDR
2. Data1 Packet
Sync
PID
3. Ack Handshake
Sync
PID
EOP
1. In Token
Sync
PID
ADDR
2. Data0 Packet
Sync
PID
3. Ack Handshake
Sync
PID
EOP
1. In Token
Sync
PID
ADDR
2. Data1/0 Packet
Sync
PID
3. Ack Handshake
Sync
PID
ENDP
Data1
CRC5
EOP
Address & Endpoint Number
CRC16
EOP
First 8 bytes of Device Descriptor
Host Acknowledges Packet
ENDP
Data0
CRC5
EOP
Address & Endpoint Number
CRC16
EOP
Second 8 bytes of Device Desc
Host Acknowledges Packet
ENDP
Data0/1
CRC5
EOP
Address & Endpoint Number
CRC16
EOP
Last 8 bytes of Device Descriptor
EOP
Host Acknowledges Packet
In this case, we assume that the maximum payload size is 8 bytes. The host sends the IN token, telling the
device it can now send data for this endpoint. As the maximum packet size is 8 bytes, we must split up the
12 byte device descriptor into chunks to send. Each chunk must be 8 bytes except for the last transaction.
The host acknowledges every data packet we send it.
Once the device descriptor is sent, a status transaction follows. If the transactions were successful, the
host will send a zero length packet indicating the overall transaction was successful. The function then
replies to this zero length packet indicating its status.
1. Out Token
Sync
PID
2. Data1 Packet
Sync
PID
3. Ack Handshake
Sync
PID
USB in a Nutshell
ADDR
ENDP
Data1
EOP
Page 15
CRC5
EOP
Address & Endpoint Number
CRC16
EOP
Zero Length Packet
Function Ack. Entire Transactions
www.beyondlogic.org
Interrupt Transfers
Any one who has had experience of interrupt requests on microcontrollers will know that interrupts are
device generated. However under USB if a device requires the attention of the host, it must wait until the
host polls it before it can report that it needs urgent attention!
Interrupt Transfers
• Guaranteed Latency
• Stream Pipe - Unidirectional
• Error detection and next period retry.
Interrupt transfers are typically non-periodic, small device "initiated" communication requiring bounded
latency. An Interrupt request is queued by the device until the host polls the USB device asking for data.
•
•
•
The maximum data payload size for low-speed devices is 8 bytes.
Maximum data payload size for full-speed devices is 64 bytes.
Maximum data payload size for high-speed devices is 1024 bytes.
IN
DATA x
ACK
Success
Data Error
STALL
NAK
Halt
No Interrupt Pending
Key
Host
Function
In Token Error
OUT
DATA x
ACK
Success
NAK
Failure
STALL
Halt
Error
Token Packet
Data Packet
Handshake Packet
The above diagram shows the format of an Interrupt IN and Interrupt OUT transaction.
•
IN: The host will periodically poll the interrupt endpoint. This rate of polling is specified in the endpoint
descriptor which is covered later. Each poll will involve the host sending an IN Token. If the IN token is
corrupt, the function ignores the packet and continues monitoring the bus for new tokens.
If an interrupt has been queued by the device, the function will send a data packet containing data relevant
to the interrupt when it receives the IN Token. Upon successful recept at the host, the host will return an
ACK. However if the data is corrupted, the host will return no status. If on the other hand a interrupt
condition was not present when the host polled the interrupt endpoint with an IN token, then the function
signals this state by sending a NAK. If an error has occurred on this endpoint, a STALL is sent in reply to
the IN token instead.
•
OUT: When the host wants to send the device interrupt data, it issues an OUT token followed by a data
packet containing the interrupt data. If any part of the OUT token or data packet is corrupt then the function
ignores the packet. If the function's endpoint buffer was empty and it has clocked the data into the endpoint
buffer it issues an ACK informing the host it has successfully received the data. If the endpoint buffer is not
empty due to processing of a previous packet, then the function returns an NAK. However if an error
occurred with the endpoint consequently and its halt bit has been set, it returns a STALL.
USB in a Nutshell
Page 16
www.beyondlogic.org
Isochronous Transfers
Isochronous transfers occur continuously and periodically. They typically contain time sensitive information,
such as an audio or video stream. If there were a delay or retry of data in an audio stream, then you would
expect some erratic audio containing glitches. The beat may no longer be in sync. However if a packet or frame
was dropped every now and again, it is less likely to be noticed by the listener.
Isochronous Transfers provide
• Guaranteed access to USB bandwidth.
• Bounded latency.
• Stream Pipe - Unidirectional
• Error detection via CRC, but no retry or guarantee of delivery.
• Full & high speed modes only.
• No data toggling.
The maximum size data payload is specified in the endpoint descriptor of an Isochronous Endpoint. This can
be up to a maximum of 1023 bytes for a full speed device and 1024 bytes for a high speed device. As the
maximum data payload size is going to effect the bandwidth requirements of the bus, it is wise to specify a
conservative payload size. If you are using a large payload, it may also be to your advantage to specify a
series of alternative interfaces with varying isochronous payload sizes. If during enumeration, the host cannot
enable your preferred isochronous endpoint due to bandwidth restrictions, it has something to fall back on
rather than just failing completely. Data being sent on an isochronous endpoint can be less than the prenegotiated size and may vary in length from transaction to transaction.
IN
DATA x
OUT
DATA x
Key
Token Packet
Host
Function
Data Packet
The above diagram shows the format of an Isochronous IN and OUT transaction. Isochronous transactions do
not have a handshaking stage and cannot report errors or STALL/HALT conditions.
USB in a Nutshell
Page 17
www.beyondlogic.org
Bulk Transfers
Bulk transfers can be used for large bursty data. Such examples could include a print-job sent to a printer or an
image generated from a scanner. Bulk transfers provide error correction in the form of a CRC16 field on the
data payload and error detection/re-transmission mechanisms ensuring data is transmitted and received
without error.
Bulk transfers will use spare un-allocated bandwidth on the bus after all other transactions have been
allocated. If the bus is busy with isochronous and/or interrupt then bulk data may slowly trickle over the bus. As
a result Bulk transfers should only be used for time insensitive communication as there is no guarantee of
latency.
Bulk Transfers
• Used to transfer large bursty data.
• Error detection via CRC, with guarantee of delivery.
• No guarantee of bandwidth or minimum latency.
• Stream Pipe - Unidirectional
• Full & high speed modes only.
Bulk transfers are only supported by full and high speed devices. For full speed endpoints, the maximum bulk
packet size is either 8, 16, 32 or 64 bytes long. For high speed endpoints, the maximum packet size can be up
to 512 bytes long. If the data payload falls short of the maximum packet size, it doesn't need to be padded with
zeros. A bulk transfer is considered complete when it has transferred the exact amount of data requested,
transferred a packet less than the maximum endpoint size of transferred a zero-length packet.
IN
DATA x
ACK
STALL
NAK
OUT
DATA x
ACK
NAK
STALL
Token Phase
Data Phase
Handshake Phase
The above diagram shows the format of a bulk IN and OUT transaction.
•
IN: When the host is ready to receive bulk data it issues an IN Token. If the function receives the
IN token with an error, it ignores the packet. If the token was received correctly, the function can
either reply with a DATA packet containing the bulk data to be sent, or a stall packet indicating the
endpoint has had a error or a NAK packet indicating to the host that the endpoint is working, but
temporary has no data to send.
•
OUT: When the host wants to send the function a bulk data packet, it issues an OUT token
followed by a data packet containing the bulk data. If any part of the OUT token or data packet is
corrupt then the function ignores the packet. If the function's endpoint buffer was empty and it has
clocked the data into the endpoint buffer it issues an ACK informing the host it has successfully
received the data. If the endpoint buffer is not empty due to processing a previous packet, then the
function returns an NAK. However if the endpoint has had an error and it's halt bit has been set, it
returns a STALL.
USB in a Nutshell
Page 18
www.beyondlogic.org
Bandwidth Management
The host is responsible in managing the bandwidth of the bus. This is done at enumeration when configuring
Isochronous and Interrupt Endpoints and throughout the operation of the bus. The specification places limits on
the bus, allowing no more than 90% of any frame to be allocated for periodic transfers (Interrupt and
Isochronous) on a full speed bus. On high speed buses this limitation gets reduced to no more than 80% of a
microframe can be allocated for periodic transfers.
So you can quite quickly see that if you have a highly saturated bus with periodic transfers, the remaining 10%
is left for control transfers and once those have been allocated, bulk transfers will get its slice of what is left.
USB Descriptors
All USB devices have a hierarchy of descriptors which describe to the host information such as what the device
is, who makes it, what version of USB it supports, how many ways it can be configured, the number of
endpoints and their types etc
The more common USB descriptors are
• Device Descriptors
• Configuration Descriptors
• Interface Descriptors
• Endpoint Descriptors
• String Descriptors
USB devices can only have one device descriptor. The device descriptor includes information such as what
USB revision the device complies to, the Product and Vendor IDs used to load the appropriate drivers and the
number of possible configurations the device can have. The number of configurations indicate how many
configuration descriptors branches are to follow.
The configuration descriptor specifies values such as the amount of power this particular configuration uses, if
the device is self or bus powered and the number of interfaces it has. When a device is enumerated, the host
reads the device descriptors and can make a decision of which configuration to enable. It can only enable one
configuration at a time.
For example, It is possible to have a high power bus powered configuration and a self powered configuration. If
the device is plugged into a host with a mains power supply, the device driver may choose to enable the high
power bus powered configuration enabling the device to be powered without a connection to the mains, yet if it
is connected to a laptop or personal organiser it could enable the 2nd configuration (self powered) requiring the
user to plug your device into the power point.
The configuration settings are not limited to power differences. Each configuration could be powered in the
same way and draw the same current, yet have different interface or endpoint combinations. However it should
be noted that changing the configuration requires all activity on each endpoint to stop. While USB offers this
flexibility, very few devices have more than 1 configuration.
DeviceDescriptor
bNumConfigurations
Configuration
Descriptor
Configuration
Descriptor
bNumInterfaces
Interface
Descriptor
Interface
Descriptor
USB in a Nutshell
Endpoint
Descriptor
Interface
Descriptor
bNumEndpoints
bNumEndpoints
Endpoint
Descriptor
bNumInterfaces
Endpoint
Descriptor
Endpoint
Descriptor
Interface
Descriptor
bNumEndpoints
bNumEndpoints
Endpoint
Descriptor
Page 19
Endpoint
Descriptor
Endpoint
Descriptor
Endpoint
Descriptor
www.beyondlogic.org
The interface descriptor could be seen as a header or grouping of the endpoints into a functional group
performing a single feature of the device. For example you could have a multi-function fax/scanner/printer
device. Interface descriptor one could describe the endpoints of the fax function, Interface descriptor two the
scanner function and Interface descriptor three the printer function. Unlike the configuration descriptor, there is
no limitation as to having only one interface enabled at a time. A device could have 1 or many interface
descriptors enabled at once.
Interface descriptors have a bInterfaceNumber field specifying the Interface number and a bAlternateSetting
which allows an interface to change settings on the fly. For example we could have a device with two
interfaces, interface one and interface two. Interface one has bInterfaceNumber set to zero indicating it is the
first interface descriptor and a bAlternativeSetting of zero.
Interface two would have a bInterfaceNumber set to one indicating it is the second interface and a
bAlternativeSetting of zero (default). We could then throw in another descriptor, also with a
bInterfaceNumber set to one indicating it is the second interface, but this time setting the bAlternativeSetting
to one, indicating this interface descriptor can be an alternative setting to that of the other interface descriptor
two.
When this configuration is enabled, the first two interface descriptors with bAlternativeSettings equal to zero
is used. However during operation the host can send a SetInterface request directed to that of Interface one
with an alternative setting of one to enable the other interface descriptor.
This gives an advantage over having two configurations, in that we can be transmitting data over interface zero
while we change the endpoint settings associated with interface one without effecting interface zero.
Each endpoint descriptor is used to specify the type of transfer, direction, polling interval and maximum packet
size for each endpoint. Endpoint zero, the default control endpoint is always assumed to be a control endpoint
and as such never has a descriptor.
Composition of USB Descriptors
All descriptors are made up of a common format. The first byte specifies the length of the descriptor, while the
second byte indicates the descriptor type. If the length of a descriptor is smaller than what the specification
defines, then the host shall ignore it. However if the size is greater than expected the host will ignore the extra
bytes and start looking for the next descriptor at the end of actual length returned.
Offset
Field
Size
Value
0
bLength
1
Number
Size of the Descriptor in Bytes
1
bDescriptorType
1
Constant
Description Type
2
bcdUSB
2
BCD
USB in a Nutshell
Description
USB Start of parameters for descriptor
Page 20
www.beyondlogic.org
Device Descriptors
The device descriptor of a USB device represents the entire device. As a result a USB device can only have
one device descriptor. It specifies some basic, yet important information about the device such as the
supported USB version, maximum packet size, vendor and product IDs and the number of possible
configurations the device can have. The format of the device descriptor is shown below.
Offset
Field
Size
Value
Description
0
bLength
1
Number
Size of the Descriptor in Bytes (18 bytes)
1
bDescriptorType
1
Constant
Device Descriptor (0x01)
2
bcdUSB
2
BCD
USB Specification Number which device complies too.
4
bDeviceClass
1
Class
Class Code
If equal to Zero, each interface specifies it’s own class
code
if equal to 0xFF, the class code is vendor specified.
Otherwise field is valid Class Code.
5
bDeviceSubClass
1
SubClass
Subclass Code (Assigned by USB Org)
6
bDeviceProtocol
1
Protocol
Protocol Code (Assigned by USB Org)
7
bMaxPacketSize
1
Number
Maximum Packet Size for Zero Endpoint. Valid Sizes are
8, 16, 32, 64
8
idVendor
2
ID
Vendor ID (Assigned by USB Org)
10
idProduct
2
ID
Product ID (Assigned by Manufacturer)
12
bcdDevice
2
BCD
Device Release Number
14
iManufacturer
1
Index
Index of Manufacturer String Descriptor
15
iProduct
1
Index
Index of Product String Descriptor
16
iSerialNumber
1
Index
Index of Serial Number String Descriptor
17
bNumConfigurations
1
Integer
Number of Possible Configurations
•
The bcdUSB field reports the highest version of USB the device supports. The value is in binary
coded decimal with a format of 0xJJMN where JJ is the major version number, M is the minor
version number and N is the sub minor version number. e.g. USB 2.0 is reported as 0x0200, USB
1.1 as 0x0110 and USB 1.0 as 0x0100.
•
The bDeviceClass, bDeviceSubClass and bDeviceProtocol are used by the operating system to
find a class driver for your device. Typically only the bDeviceClass is set at the device level. Most
class specifications choose to identify itself at the interface level and as a result set the
bDeviceClass as 0x00. This allows for the one device to support multiple classes.
•
The bMaxPacketSize field reports the maximum packet size for endpoint zero. All devices must
support endpoint zero.
•
The idVendor and idProduct are used by the operating system to find a driver for your device.
The Vendor ID is assigned by the USB-IF.
•
The bcdDevice has the same format than the bcdUSB and is used to provide a device version
number. This value is assigned by the developer.
•
Three string descriptors exist to provide details of the manufacturer, product and serial number.
There is no requirement to have string descriptors. If no string descriptor is present, a index of zero
should be used.
•
bNumConfigurations defines the number of configurations the device supports at its current
speed.
USB in a Nutshell
Page 21
www.beyondlogic.org
Configuration Descriptors
A USB device can have several different configurations although the majority of devices are simple and only
have one. The configuration descriptor specifies how the device is powered, what the maximum power
consumption is, the number of interfaces it has. Therefore it is possible to have two configurations, one for
when the device is bus powered and another when it is mains powered. As this is a "header" to the Interface
descriptors, its also feasible to have one configuration using a different transfer mode to that of another
configuration.
Once all the configurations have been examined by the host, the host will send a SetConfiguration command
with a non zero value which matches the bConfigurationValue of one of the configurations. This is used to
select the desired configuration.
Offset
Field
Size
Value
Description
0
bLength
1
Number
Size of Descriptor in Bytes
1
bDescriptorType
1
Constant
Configuration Descriptor (0x02)
2
wTotalLenght
2
Number
Total Length of Data Returned
4
bNumInterfaces
1
Number
Number of Interfaces
5
bConfigurationValue
1
Number
Value to use as an argument to select this configuration
6
iConfiguration
1
Index
Index of String Descriptor Describing this configuration
7
bmAttributes
1
Bitmap
D7 Bus Powered
D6 Self Powered
D5 Remote Wakeup
D4..0 Reserved (0)
8
bMaxPower
1
mA
Maximum Power Consumption
When the configuration descriptor is read, it returns the entire configuration hierarchy which includes all related
interface and endpoint descriptors. The wTotalLength field reflects the number of bytes in the hierarchy.
Configuration Descriptor
Interface Zero Descriptor, bAlternateSetting = 0
Endpoint Descriptor One
Endpoint Descriptor Two
Interface One Descriptor, bAlternateSetting = 0
Endpoint Descriptor One
(Interrupt Pipes)
Endpoint Descriptor Two
Interface One Descriptor, bAlternateSetting = 1
Endpoint Descriptor One
(Bulk Pipes)
Endpoint Descriptor Two
•
bNumInterfaces specifies the number of interfaces present for this configuration.
•
bConfigurationValue is used by the SetConfiguration request to select this configuration.
•
iConfiguration is a index to a string descriptor describing the configuration in human readable
form.
•
bmAttributes specify power parameters for the configuration. If a device is self powered, it sets
D6. Bit D7 was used in USB 1.0 to indicate a bus powered device, but this is now done by
bMaxPower. If a device uses any power from the bus, whether it be as a bus powered device or as
USB in a Nutshell
Page 22
www.beyondlogic.org
a self powered device, it must report its power consumption in bMaxPower. Devices can also
support remote wakeup which allows the device to wake up the host when the host is in suspend.
•
bMaxPower defines the maximum power the device will drain from the bus. This is in 2mA units,
thus a maximum of approximately 500mA can be specified. The specification allows a high
powered bus powered device to drain no more than 500mA from Vbus. If a device loses external
power, then it must not drain more than indicated in bMaxPower. It should fail any operation it
cannot perform without external power.
Interface Descriptors
The interface descriptor could be seen as a header or grouping of the endpoints into a functional group
performing a single feature of the device. The interface descriptor conforms to the following format,
Offset
Field
Size
Value
Description
0
bLength
1
Number
Size of Descriptor in Bytes
1
bDescriptorType
1
Constant
Interface Descriptor (0x04)
2
bInterfaceNumber
1
Number
Number of Interface
3
bAlternateSetting
1
Number
Value used to select alternative setting
4
bNumEndpoints
1
Number
Number of Endpoints used for this interface
5
bInterfaceClass
1
Class
6
bInterfaceSubClass
1
SubClass
7
bInterfaceProtocol
1
Protocol
8
iInterface
1
Index
Class Code (Assigned by USB Org)
Subclass Code (Assigned by USB Org)
Protocol Code
Index of String Descriptor Describing this interface
•
bInterfaceNumber indicates the index of the interface descriptor. This should be zero based, and
incremented once for each new interface descriptor.
•
bAlternativeSetting can be used to specify alternative interfaces. These alternative interfaces can
be selected with the Set Interface request.
•
bNumEndpoints indicates the number of endpoints used by the interface. This value should
exclude endpoint zero and is used to indicate the number of endpoint descriptors to follow.
•
bInterfaceClass, bInterfaceSubClass and bInterfaceProtocol can be used to specify supported
classes (e.g. HID, communications, mass storage etc.) This allows many devices to use class
drivers preventing the need to write specific drivers for your device.
•
iInterface allows for a string description of the interface.
USB in a Nutshell
Page 23
www.beyondlogic.org
Endpoint Descriptors
Endpoint descriptors are used to describe endpoints other than endpoint zero. Endpoint zero is always
assumed to be a control endpoint and is configured before any descriptors are even requested. The host will
use the information returned from these descriptors to determine the bandwidth requirements of the bus.
Offset
Field
Size
Value
Description
0
bLength
1
Number
Size of Descriptor in Bytes (7 bytes)
1
bDescriptionType
1
Constant
Endpoint Descriptor (0x05)
2
bEndpointAddress
1
Endpoint
Endpoint Address, Encoded as follows
0..3b
4..6b
7b
3
bmAttributes
1
Bitmap
Endpoint Number
Reserved. Set to Zero
Direction (Ignored for Control Endpoints)
0 = Out Endpoint, 1 = In Endpoint
Bits 0..1 Transfer Type
00 = Control
01 = Isochronous
10 = Bulk
11 = Interrupt
Bits 2..7 are reserved. If Isochronous endpoint,
Bits 3..2 = Synchronisation Type (Iso Mode)
00 = No Synchonisation
01 = Asynchronous
10 = Adaptive
11 = Synchronous
Bits 5..4 = Usage Type (Iso Mode)
00 = Data Endpoint
01 = Feedback Endpoint
10 = Explicit Feedback Data Endpoint
11 = Reserved
4
wMaxPacketSize
2
Number
Maximum Packet Size this endpoint is capable of sending
or receiving
6
bInterval
1
Number
Interval for polling endpoint data transfers. Value in frame
counts. Ignored for Bulk & Control Endpoints. Iso must
equal 1 and field may range from 1 to 255 for interrupt
endpoints.
•
bEndpointAddress indicates what endpoint this descriptor is describing.
•
bmAttributes specifies the transfer type. This can either be Control, Interrupt, Isochronous or Bulk
Transfers. If an Isochronous endpoint is specified, additional attributes can be selected such as the
Synchronisation and usage types.
•
wMaxPacketSize indicates the maximum payload size for this endpoint.
•
bInterval is used to specify the polling interval of certain transfers. The units are expressed in
frames, thus this equates to either 1ms for low/full speed devices and 125us for high speed
devices.
USB in a Nutshell
Page 24
www.beyondlogic.org
String Descriptors
String descriptors provide human readable information and are optional. If they are not used, any string index
fields of descriptors must be set to zero indicating there is no string descriptor available.
The strings are encoded in the Unicode format and products can be made to support multiple languages. String
Index 0 should return a list of supported languages. A list of USB Language IDs can be found in Universal
Serial Bus Language Identifiers (LANGIDs) version 1.0
Offset
Field
Size
Value
Description
0
bLength
1
Number
Size of Descriptor in Bytes
1
bDescriptorType
1
Constant
String Descriptor (0x03)
2
wLANGID[0]
2
Number
Supported Language Code Zero
(e.g. 0x0409 English - United States)
3
wLANGID[1]
2
Number
Supported Language Code One
(e.g. 0x0c09 English - Australian)
4
wLANGID[2]
2
Number
Supported Language Code x
(e.g. 0x0407 German - Standard)
The above String Descriptor shows the format of String Descriptor Zero. The host should read this descriptor to
determine what languages are available. If a language is supported, it can then be referenced by sending the
language ID in the wIndex field of a Get Descriptor(String) request.
All subsequent strings take on the format below,
Offset
Field
Size
Value
0
bLength
1
Number
Size of Descriptor in Bytes
1
bDescriptorType
1
Constant
String Descriptor (0x03)
2
bString
n
Unicode
Unicode Encoded String
USB in a Nutshell
Description
Page 25
www.beyondlogic.org
The Setup Packet
Every USB device must respond to setup packets on the default pipe. The setup packets are used for detection
and configuration of the device and carry out common functions such as setting the USB device’s address,
requesting a device descriptor or checking the status of a endpoint.
A USB compliant Host expects all requests to be processed within a maximum period of 5 seconds. It also
specifies stricter timing for specific requests :
•
•
•
Standard Device requests without a data stage must be completed in 50ms.
Standard Device requests with a data stage must start to return data 500ms after the request.
• Each data packet must be sent within 500ms of the successful transmission of the
previous packet.
• The status stage must complete within 50ms after the transmission of the last data packet.
The SetAddress command (which contains a data phase) must process the command and return
status within 50ms. The device then has 2ms to change address before the next request is sent.
These timeout periods are quite acceptable for even the slowest of devices, but can be a restriction during
debugging. 50mS doesn't provide for many debugging characters to be sent at 9600bps on an asynchronous
serial port or for a In Circuit Debugger/Emulator to single step or to break execution to examine the internal
Registers. As a result, USB requires some different debugging methods to that of other microcontroller
projects.
Each request starts with a 8 byte long Setup Packet which has the following format,
Offset
Field
Size
Value
Description
0
bmRequestType
1
Bit-Map
1
bRequest
1
Value
D7 Data Phase Transfer Direction
0 = Host to Device
1 = Device to Host
D6..5 Type
0 = Standard
1 = Class
2 = Vendor
3 = Reserved
D4..0 Recipient
0 = Device
1 = Interface
2 = Endpoint
3 = Other
4..31 = Reserved
Request
2
wValue
2
Value
Value
4
wIndex
2
Index or
Offset
Index
6
wLenght
2
Count
Number of bytes to transfer if there
is a data phase
The bmRequestType field will determine the direction of the request, type of request and designated recipient.
The bRequest field determines the request being made. The bmRequestType is normally parsed and
execution is branched to a number of handlers such as a Standard Device request handler, a Standard
Interface request handler, a Standard Endpoint request handler, a Class Device request handler etc. How you
parse the setup packet is entirely up to your preference. Others may choose to parse the bRequest first and
then determine the type and recipient based on each request.
Standard requests are common to all USB devices and are detailed in the next coming pages. Class requests
are common to classes of drivers. For example, all device conforming to the HID class will have a common set
USB in a Nutshell
Page 26
www.beyondlogic.org
of class specific requests. These will differ to a device conforming to the communications class and differ again
to that of a device conforming to the mass storage class.
And last of all is the vendor defined requests. These are requests which you as the USB device designer can
assign. These are normally different from device to device, but this is all up to your implementation and
imagination.
A common request can be directed to different recipients and based on the recipient perform different
functions. A GetStatus Standard request for example, can be directed at the device, interface or endpoint.
When directed to a device it returns flags indicating the status of remote wakeup and if the device is self
powered. However if the same request is directed at the interface it always returns zero, or should it be
directed at an endpoint will return the halt flag for the endpoint.
The wValue and wIndex fields allow parameters to be passed with the request. wLength is used the specify
the number of bytes to be transferred should there be a data phase.
Standard Requests
Section 9.4 of the USB specification details the "Standard Device" requests required to be implemented for
every USB device. The standard provides a single table grouping items by request. Considering most firmware
will parse the setup packet by recipient we will opt to break up the requests based by recipient for easier
examination and implementation.
Standard Device Requests
There are currently eight Standard Device requests, all of which are detailed in the table below.
bmRequestType
bRequest
wValue
wIndex
wLenght
Data
1000 0000b
GET_STATUS
(0x00)
Zero
Zero
Two
Device Status
0000 0000b
CLEAR_FEATURE
(0x01)
Feature
Selector
Zero
Zero
None
0000 0000b
SET_FEATURE
(0x03)
Feature
Selector
Zero
Zero
None
0000 0000b
SET_ADDRESS
(0x05)
Device
Address
Zero
Zero
None
1000 0000b
GET_DESCRIPTOR
(0x06)
Descriptor
Type & Index
Zero or
Language ID
Descriptor
Length
Descriptor
0000 0000b
SET_DESCRIPTOR
(0x07)
Descriptor
Type & Index
Zero or
Language ID
Descriptor
Length
Descriptor
1000 0000b
GET_CONFIGURATION
(0x08)
Zero
Zero
1
Configuration
Value
0000 0000b
SET_CONFIGURATION
(0x09)
Configuration
Value
Zero
Zero
None
D14
D13
D12
D11
D10
D9
D8
D7
Reserved
•
D6
D5
D4
D3
D2
D1
D0
Self
Powered
D15
The Get Status request directed at the device will return two bytes during the data stage with the
following format,
Remote
Wakeup
•
If D0 is set, then this indicates the device is self powered. If clear, the device is bus powered. If D1 is
set, the device has remote wakeup enabled and can wake the host up during suspend. The remote
wakeup bit can be by the SetFeature and ClearFeature requests with a feature selector of
DEVICE_REMOTE_WAKEUP (0x01)
USB in a Nutshell
Page 27
www.beyondlogic.org
•
Clear Feature and Set Feature requests can be used to set boolean features. When the designated
recipient is the device, the only two feature selectors available are DEVICE_REMOTE_WAKEUP and
TEST_MODE. Test mode allows the device to exhibit various conditions. These are further
documented in the USB Specification Revision 2.0.
•
Set Address is used during enumeration to assign a unique address to the USB device. The address
is specified in wValue and can only be a maximum of 127. This request is unique in that the device
does not set its address until after the completion of the status stage. (See Control Transfers.) All other
requests must complete before the status stage.
•
Set Descriptor/Get Descriptor is used to return the specified descriptor in wValue. A request for the
configuration descriptor will return the device descriptor and all interface and endpoint descriptors in
the one request.
• Endpoint Descriptors cannot be accessed directly by a GetDescriptor/SetDescriptor Request.
• Interface Descriptors cannot be accessed directly by a GetDescriptor/SetDescriptor Request.
• String Descriptors include a Language ID in wIndex to allow for multiple language support.
•
Get Configuration/Set Configuration is used to request or set the current device configuration. In the
case of a Get Configuration request, a byte will be returned during the data stage indicating the
devices status. A zero value means the device is not configured and a non-zero value indicates the
device is configured. Set Configuration is used to enable a device. It should contain the value of
bConfigurationValue of the desired configuration descriptor in the lower byte of wValue to select which
configuration to enable.
Standard Interface Requests
The specification current defines five Standard Interface requests which are detailed in the table below.
Interestingly enough, only two requests do anything intelligible.
bmRequestType
bRequest
wValue
wIndex
wLenght
Data
1000 0001b
GET_STATUS
(0x00)
Zero
Interface
Two
Interface
Status
0000 0001b
CLEAR_FEATURE
(0x01)
Feature
Selector
Interface
Zero
None
0000 0001b
SET_FEATURE
(0x03)
Feature
Selector
Interface
Zero
None
1000 0001b
GET_INTERFACE
(0x0A)
Zero
Interface
One
Alternate
Interface
0000 0001b
SET_INTERFACE
(0x11)
Alternative
Setting
Interface
Zero
None
•
D15
wIndex is normally used to specify the referring interface for requests directed at the interface. Its
format is shown below.
D14
D13
D12 D11
Reserved
D10
D9
D8
D7
D6
D5
D4
D3
D2
Interface Number
D1
D0
•
Get Status is used to return the status of the interface. Such a request to the interface should
return two bytes of 0x00, 0x00. (Both bytes are reserved for future use)
•
Clear Feature and Set Feature requests can be used to set boolean features. When the
designated recipient is the interface, the current USB Specification Revision 2 specifies no
interface features.
Get Interface and Set Interface set the Alternative Interface setting which is described in more
detail under the Interface Descriptor.
•
USB in a Nutshell
Page 28
www.beyondlogic.org
Standard Endpoint Requests
Standard Endpoint requests come in the four varieties listed below.
BmRequestType
bRequest
wValue
Windex
wLenght
Data
1000 0010b
GET_STATUS
(0x00)
Zero
Endpoint
Two
Endpoint
Status
0000 0010b
CLEAR_FEATURE
(0x01)
Feature
Selector
Endpoint
Zero
None
0000 0010b
SET_FEATURE
(0x03)
Feature
Selector
Endpoint
Zero
None
1000 0010b
SYNCH_FRAME
(0x12)
Zero
Endpoint
Two
FrameNumber
•
D15
•
D15
The wIndex field is normally used to specify the referring endpoint and direction for requests directed
to an endpoint. Its format is shown below.
D14
D13
D12 D11
Reserved
D10
D9
D8
D7
Dir
D6
D5
D4
Reserved
D3
D2
D1
D0
Endpoint Number
Get Status returns two bytes indicating the status (Halted/Stalled) of a endpoint. The format of the two
bytes returned is illustrated below.
D14
D13
D12
D11
D10
D9
D8
D7
Reserved
D6
D5
D4
D3
D2
D1
D0
Halt
•
Clear Feature and Set Feature are used to set Endpoint Features. The standard currently defines one
endpoint feature selector, ENDPOINT_HALT (0x00) which allows the host to stall and clear an
endpoint. Only endpoints other than the default endpoint is recommended to have this functionality.
•
A Synch Frame request is used to report an endpoint synchronisation frame.
USB in a Nutshell
Page 29
www.beyondlogic.org
Enumeration
Enumeration is the process of determining what device has just been connected to the bus and what
parameters it requires such as power consumption, number and type of endpoint(s), class of product etc. The
host will then assign the device an address and enable a configuration allowing the device to transfer data on
the bus. A fairly generic enumeration process is detailed in section 9.1.2 of the USB specification. However
when writing USB firmware for the first time, it is handy to know exactly how the host responds during
enumeration, rather than the general enumeration process detailed in the specification.
A common Windows enumeration involves the following steps,
1. The host or hub detects the connection of a new device via the device's pull up resistors on the
data pair. The host waits for at least 100ms allowing for the plug to be inserted fully and for power
to stabilise on the device.
2. Host issues a reset placing the device is the default state. The device may now respond to the
default address zero.
3. The MS Windows host asks for the first 64 bytes of the Device Descriptor.
4. After receiving the first 8 bytes of the Device Descriptor, it immediately issues another bus reset.
5. The host now issues a Set Address command, placing the device in the addressed state.
6. The host asks for the entire 18 bytes of the Device Descriptor.
7. It then asks for 9 bytes of the Configuration Descriptor to determine the overall size.
8. The host asks for 255 bytes of the Configuration Descriptor.
9. Host asks for any String Descriptors if they were specified.
At the end of Step 9, Windows will ask for a driver for your device. It is then common to see it request all the
descriptors again before it issues a Set Configuration request.
The above enumeration process is common to Windows 2000, Windows XP and Windows 98 SE.
Step 4 often confuses people writing firmware for the first time. The Host asks for the first 64 bytes of the
device descriptor, so when the host resets your device after it receives the first 8 bytes, it is only natural to think
there is something wrong with your device descriptor or how your firmware handles the request. However as
many will tell you, if you keep persisting by implementing the Set Address Command it will pay off by asking for
a full 18 bytes of device descriptor next.
Normally when something is wrong with a descriptor or how it is being sent, the host will attempt to read it three
times with long pauses in between requests. After the third attempt, the host gives up reporting an error with
your device.
Copyright 2002, Craig Peacock ([email protected])
rd
Third Release 23 November 2002
USB in a Nutshell
Page 30
www.beyondlogic.org
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
