TX-Guide
Concept
The TX embedded module integrates all the core components of a common PC and is mounted
onto an application specific carrier board. TX modules have a standardized form factor of 67,6mm x
26mm, have specified pinouts and provide the functional requirements for an embedded
application. These functions include, but are not limited to, graphics, network and multiple USB
ports. A single ruggedized SO-DIMM connector provides the carrier board interface to carry all the
I/O signals to and from the TX module. This SO-DIMM connector is a well known and proven high
speed signal interface connector that is commonly used for memory cards in notebooks.
Carrier board designers can utilize as little or as many of the I/O interfaces as deemed necessary.
The carrier board can therefore provide all the interface connectors required to attach the system
to the application specific peripherals. This versatility allows the designer to create a dense and
optimized package, which results in a more reliable product while simplifying system integration.
Most importantly, TX applications are scalable, which means once a product has been developed,
the product range can be diversified by using TX modules with a different performance class.
Simply unplug one module and replace it with another, no redesign is necessary.
2/51
2015-02-02
TX-Guide
TX-Guide
Disclaimer
The information contained within this Specification, including but not limited to any product
specification, is subject to change without notice.
Ka-Ro electronics provides no warranty with regard to this Specification or any other information
contained herein and hereby expressly disclaims any implied warranties of merchantability or
fitness for any particular purpose with regard to any of the foregoing.
Intended Audience
This TX-Standard electromechanical description is intended for technically qualified personnel. It is
not intended for general audiences.
Copyright Notice
Copyright © 2010, Ka-Ro electronics GmbH. All rights reserved. All text, pictures and graphics are
protected by copyrights. No copying is permitted without written permission.
We have made every attempt to ensure that the information in this document is accurate yet the
information contained within is supplied “as-is”.
Trademarks
ARM ® is a registered trademark of ARM Limited.
All other brand and product names, trademarks, and copyrights are the property of their respective
owners.
TX-Guide
2015-02-02
3/51
TX-Guide
Acronyms and Abbreviations
Abbreviation
100-Base-T
ARM
JTAG
GPIO
LCD
LED
NC
PCB
RAM
RoHS
UART
USB
4/51
Explanation
Ethernet type that uses 100 Mega bits per second speed on RJ45 connectors and
twisted pair wiring
Advanced RISC Machines Limited CPU architecture
Joint Test Action Group. This abbreviation is commonly used to refer to a test
interface found on many modern integrated circuits. The JTAG test interface is a
boundary scan register with serial interface and is described by an IEEE standard
General Purpose Input/Output
Liquid Crystal Display
Light Emitting Diode.
An electronic component used as a visual indicator (light).
Not connected
Printed Circuit Board
Random Access Memory
Restriction on Hazardous Substances: The Directive on the Restriction of the Use
of Certain Hazardous Substances in Electrical and Electronic Equipment
2002/95/EC.
Universal Asynchronous Receiver/Transmitter
Universal Serial Bus
2015-02-02
TX-Guide
TX-Guide
Table of contents
1 Feature Overview...........................................................................................................................7
2 Connector Pin Assignments and Signal Descriptions..........................................................................8
2.1 Power Supply.......................................................................................................................9
2.2 Reset & Bootmode.............................................................................................................10
2.3 RTC & Power-Button...........................................................................................................11
2.4 Ethernet Signals.................................................................................................................12
2.4.1 Ethernet Physical Layer Layout Guidelines.................................................................12
2.4.2 Power and Ground Planes........................................................................................13
2.4.3 4 Layer Stackup......................................................................................................13
2.4.4 2 Layer Stackup......................................................................................................13
2.4.5 Component Placement.............................................................................................14
2.4.6 Design Techniques for EMI Suppression....................................................................14
2.4.7 Controlled Impedance for Differential Signals............................................................16
2.4.8 Magnetics Module....................................................................................................17
2.5 USB...................................................................................................................................18
2.5.1 USB Physical Layer Layout Guidelines.......................................................................18
2.5.2 Controlled Impedance for USB Traces.......................................................................18
2.5.3 Isolation of DP/DM Traces........................................................................................19
2.5.4 Isolated shielding on the USB connector...................................................................20
2.5.5 Optional VBUS protection.........................................................................................21
2.5.6 USB recommendations.............................................................................................22
2.6 I2C....................................................................................................................................23
2.6.1 Example I2C Voltage Level Translator (TX27 and TX51 only)......................................24
2.6.1 I2C recommendations..............................................................................................25
2.7 PWM / 1-WIRE...................................................................................................................26
2.8 CSPI – Configurable Serial Peripheral Interface....................................................................27
2.9 SDIO Interfaces.................................................................................................................28
2.9.1 SD-Card example diagram using level shifters...........................................................29
2.9.2 SD-Card example diagram only for 3.3V modules......................................................29
2.10 UARTs..............................................................................................................................30
2.10.1 UART Example diagram..........................................................................................30
2.11 Keypad Interface..............................................................................................................31
2.12 Digital Audio Ports............................................................................................................32
2.13 CMOS Sensor Interface.....................................................................................................33
2.14 Extended and 2nd CMOS Sensor Interface (TX51, TX53 and TX6 only)................................33
2.15 LCD Interface...................................................................................................................34
2.16 LVDS/SATA option (TX53, TX6 only)..................................................................................35
2.16.1 LVDS pin mapping.................................................................................................35
2.16.2 LVDS recommendations.........................................................................................35
2.16.3 SATA pin mapping.................................................................................................35
2.16.4 SATA recommendations..........................................................................................35
2.17 CAN Interface..................................................................................................................36
2.18 2nd Ethernet RMII (TX28 only).........................................................................................37
2.19 TV out (TX51, TX53 only).................................................................................................38
2.19.1 TV Encoder Recommendations...............................................................................38
2.20 PCI express (TX6 only).....................................................................................................39
2.20.1 PCI Express interface recommendations..................................................................39
TX-Guide
2015-02-02
5/51
TX-Guide
2.20.1.1 PCI Express general routing guidelines.........................................................39
2.20.1.2 PCI Express coupling lane............................................................................39
2.20.2 PCIe recommendations..........................................................................................39
2.21 GPIO and module specific signals......................................................................................40
3 Optional Debugging Connector......................................................................................................41
3.1 Debug Connector Signal Assignment...................................................................................41
3.2 Debug connector location...................................................................................................42
4 Mechanical...................................................................................................................................43
4.1 TX module outline..............................................................................................................43
4.2 SO-DIMM connector...........................................................................................................44
4.3 DIMM Connector PCB Layout example.................................................................................45
4.4 TX Fastener Kit..................................................................................................................46
4.5 TX Heatsink Kit (17 K/W)....................................................................................................47
4.6 TX Heatsink Kit (7 K/W)......................................................................................................48
4.7 Heat conductive gel foil......................................................................................................49
5 Document Revision history............................................................................................................50
6/51
2015-02-02
TX-Guide
TX-Guide
1 Feature Overview
TX modules offers the newest I/O technologies on a minimum size form factor. This includes serial
high speed buses such as:
• Ethernet
• USB
• SD - Secure Digital Card
• SPI - Serial Peripheral Interface
Multimedia interfaces
• CMOS Sensor Interface
• LCD True Color Display Interface (24bpp)
Other Standard Interfaces
• UART - Universal Asynchronous Receiver/Transmitters
• I2C - Inter-Integrated Circuit
• PWM - Pulse-Width Modulator
• 1-WIRE Interface
Plus additional control and power management signals. The versatile power supply outputs can
also be used for the baseboard and defines the IO voltage used for the module. 1.8V and 3.3V IO
voltage modules can be used on universal baseboards like the Starterkit V without the need for any
change on the baseboard or jumper setting.
TX-Guide
2015-02-02
7/51
TX-Guide
2 Connector Pin Assignments and Signal Descriptions
Signal names beginning with a “#” symbol indicates that the active, or asserted state, occurs when
the signal is at a low voltage level. When “#” is not present, the signal is asserted when at a high
voltage level. Differential pairs are indicated by trailing 'P' and 'N' for the positive or negative
signal.
The following terminology is used to describe columns for the tables located below.
Term
I
Input
O
Output
I/O
VDDIO
Bi-directional Input/Output Pin
I/O type depends on the VDDIO voltage of the module
3V3
I/O type: CMOS 3.3V
5V
I/O type: CMOS 3.3V to 5V
power
8/51
Describtion
Power supply pin
USB
Universal Serial Bus differential pair signals
In compliance with the Universal Serial Bus Specification 2.0
ETN
Ethernet Media Dependent Interface differential pair signals.
In compliance with IEEE 802.3ab 100Base-T Ethernet Specification.
NC
Not Connected
PU
Pull-up resistor
2015-02-02
TX-Guide
TX-Guide
2.1 Power Supply
Pin
Signal
Description
1-4
VDDIN Module power supply input (observe DIMM socket contact current rating)
1.8V or 3.3V I/O power supply output
This output can be used for the module side supply of level shifters
or for peripherals which are operated at the VDDIO voltage level.
Module
Remark
TX27
5-7
VDDIO
VDDIO=1.8V
TX51
TX28S
type
I/O
power
I
power
O
power
O
max. 900mA
max. 200mA
max. 20mA
TX25, TX28
VDDIO=3.3V
TX48, TX53
TX6
max. 200mA
max. 900mA
Max. 300mA
+3.3V Power supply output
Module
9-12
Remark
TX27
VDD33
max. 1A
TX51
TX25, TX28, TX48, TX53, TX6
VDDIO and VDD33 are connected on the
module. Refer to ratings above.
18,26,32,39,50,58,71,82,
88,94,102,111,116,129, GND
142,147,160,171,200
TX modules operates on a single 3.3V to 5.5V supply and provide regulated power supply outputs to the
baseboard.
VDDIO
VDDIN
TX
Module
1.8V/
3.3V
Logic
Level
Shifter
3.3V
Logic
VDD33
The use of level shifters on the baseboard to interface to 3.3V logic allows for universal module
selection, because the voltage is automatically translated between VDDIO (1.8V or 3.3V) and VDD33
(3.3V) levels. Level shifters can be omitted on 3.3V only modules like the TX25, but in that case it's not
possible to use 1.8V modules anymore.
TX-Guide
2015-02-02
9/51
TX-Guide
2.2 Reset & Bootmode
Pin
8
15
16
17
Signal
Description
type I/O
System Boot Mode Select - The operational system boot mode of the module upon
system reset is determined by the settings of this pin.
BOOTMODE=H: Boot from NAND / L: Boot from UART/USB
Leave open or connect to VDDIO if not used.
VDDIO
BOOTMODE
I
Module Remark
PU
Depending on BOOTMODE external pull-up/-down resistors are selected
TX28
on LCD interface signals LD0..LD5 and LCD_RS (pin 146). Refer to the
TX28 datasheet for resistor values and level needed at startup!
Reset Out – Reset carrier board peripherals
#RESET_OUT may be used to reset peripherals on the carrier board. Depending on
#RESET_OUT
VDDIO O
the module type this signal might be asserted automatically by a system reset, but
can be controller by a GPIO function during runtime on all modules.
Power On Reset - active low input signal.
Typically a push button reset, pull low to force a reset.
A supervisor circuit is used on the TX module to monitor the power supply. This
device assert a processor system reset (POR_B) if the power supply falls outside the
programmed threshold or a manual reset (#POR) is asserted externally.
5V
#POR
I
Connect to VIN or leave open if not used.
PU
Module Remark
The i.MX28 power-on reset is generated internally.
TX28
If low the module power supply is disconnected.
TX28S Not connected
Master Reset - external active low Schmitt trigger input signal. When this signal goes
active, all modules (except the reset module, SDRAMC module, and the clock control
#RESET_IN module) are reset. The behaviour might depend on the processor, please refer to the VDDIO I
processor reference manual for details. #RESET_IN is directly connected to the
processors RESET_B pin. Pull or connect to VDDIO if not used.
#POR
Supervisor
Circuit
Processor
#RESET_IN
#RESET_OUT
10/51
2015-02-02
TX-Guide
TX-Guide
2.3 RTC & Power-Button
Pin
Signal
13
VBACKUP
Description
type I/O
DS1339 RTC backup power supply. Supply voltage must be held between 1.3V and
3.7V for proper RTC operation. This pin can be connected to a primary cell such as a
lithium button cell. Additionally, this pin can be connected to a rechargeable cell or a
super cap when used with the trickle charge feature.
Refer to DS1339 datasheet for details.
Module
Remark
power
I
Connected to BAT_VDD
TX25
DRYICE backup power supply input, max. 1.55V
The i.MX25 internal RTC is not supported
TX6 without i.MX6 RTC backup power supply. Supply voltage must be held between
DS1339
2.9V and 3.3V for proper RTC operation.
PMIC dependent Function. Leave unconnected if not used.
Module
Remark
TX25
14
PMIC_PWR_ON
No PMIC onboard - Not connected
PSWITCH - Used for chip power on or recovery. PSWITCH is at MID
TX28
level by default. Refer to i.MX28 reference manual for details.
This is an active high push button input which can be used to signal
TX27, TX51 PWR_ON and PWR_OFF events to the CPU by controlling the PMIC
EXT_WAKEUP. Refer to LP3972 datasheet, page 49 for details.
Connected to LTC3589 WAKE. To power down, drive this pin LOW.
TX48, TX53
Refer to LTC3589 datasheet, page 29 for details.
Connected to PMIC ON.
TX6
Refer to PMIC datasheet for details.
PWR_ON
TX-Guide
PMIC
LP3972
EXT_WAKEUP
2015-02-02
I
Processor
11/51
TX-Guide
2.4 Ethernet Signals
Pin
Signal
19 ETN_TXN
21 ETN_TXP
Description
100Base-TX or 10Base-T differential transmit output to magnetics.
type
I/O
ETN
O
Active low LINK ON indication: Active indicates that the link is on.
20 #ETN_LINKLED
22 ETN_3V3
Module
Remark
3V3
Output is driven active when the operating speed is 100Mbps. This LED
TX28, TX48,
will go inactive when the operating speed is 10Mbps or during line
TX53, TX6
isolation.
+3.3V analogue power supply output to magnetics. This power supply can be turned
off on the module to reduce the power consumption in the case Ethernet is not
power
needed.
O
O
23 ETN_RXN
25 ETN_RXP
100Base-TX or 10Base-T differential receive input from magnetics.
ETN
I
24 #ETN_ACTLED
Active low ACTIVITY indication: Active indicates that there is Carrier sense (CRS) from
the active PMD.
Module
Remark
TX28, TX48, Output is driven active whenever the device detects a valid link, and
TX53, TX6 blinks indicating activity.
3V3
O
Abbildung 2.1: Ethernet Sample Diagram
2.4.1 Ethernet Physical Layer Layout Guidelines
TX modules are designed for 10 or 100 Mbps Ethernet systems. They are based on IEEE 10BASE-T and
100BASE-TX standards. The IEEE 802.3-2005 standard for 100BASE-TX defines networking over two
pairs of Category 5 unshielded twisted pair cable or Type 1 shielded twisted pair cable. The following
recommendations for the printed circuit board layout are not the only way to layout TX modules. Every
board designer will have a preference. Complexity, board space, number and types of devices will dictate
routing and placement strategies.
12/51
2015-02-02
TX-Guide
TX-Guide
2.4.2 Power and Ground Planes
The sections below describe typical 2 and 4 layer board stackups. The goal of the 4 layer designs is to
keep the signal routing on outer layers, isolated by the power and ground planes. These power and
ground planes also serve the purpose of reference planes for the signal traces. The signal traces should
run over continuous reference planes when possible. When 2 layer board designs are required, it
remains necessary that the signal traces run over continuous reference planes when possible.
2.4.3 4 Layer Stackup
•
•
•
•
•
•
•
TOP (Layer 1) – Signal with ground plane except where noted.
Layer 2 – Continuous ground plane. No signals should be routed on this layer.
Layer 3 – Power planes with ground planes except where noted. Signals may be routed on this
layer if needed.
Bottom (Layer 4) – Signal with ground plane except where noted.
Decouple ground floods and ground layer as practical. When signal traces are re-referenced to
power island planes, decoupling capacitors (10nF ceramic) are required between the ground
plane and power plane.
Signal traces routed on bottom layer over power islands that are on Layer 3 layer should have
decoupling capacitors (10nF ceramic) near the trace to enable short (direct) return current paths.
When signal traces are re-referenced to power island planes, decoupling capacitors (10nF
ceramic) are required between the ground plane and power plane as shown below.
2.4.4 2 Layer Stackup
•
•
•
TOP (Layer 1) – Signal with ground plane except where noted.
Bottom (Layer 1) – Ground plane and power islands. A limited number of slow speed signals may
be routed on the bottom layer.
Signal traces should be surrounded by ground or ground trace along at least one edge. If ground
trace is used, it should be connected to ground plane on this layer and decoupled to ground
plane on top layer.
Decouple ground planes as practical , as shown below. This will allow short (direct) return current
paths when signal traces are re-referenced to different power island planes.
TX-Guide
2015-02-02
13/51
TX-Guide
2.4.5 Component Placement
Component placement can affect signal quality, emissions, and component operating temperature.
Careful component placement can decrease potential EMI problems and simplify the task of routing
traces.
•
•
If the magnetic is a discrete component, then the distance between the magnetic and the RJ-45
needs to have the highest consideration and be kept to under 25mm (approx. 1 inch) of
separation.
The distance between the SO-DIMM socket and the magnetics needs to be 20mm or greater.
Among PHY vendors, the 25mm (approx. 1 inch) rule is considered good design practice for EMI
considerations. The intention is to isolate the PHY from the magnetics.
2.4.6 Design Techniques for EMI Suppression
The following techniques may improve EMI margin.
•
14/51
Common mode capacitors may be added to the TX+/- and RX+/- signals for high frequency
attenuation , as shown below. One end of each capacitor should be connected to the system
2015-02-02
TX-Guide
TX-Guide
ground plane, and placed within 10mm (approx. 400mils) of the magnetics. Typical capacitance
values should be between 10pF and 22pF. Values higher than 22pF may negatively impact the TX
and RX signalling.
•
Common mode chokes may be added to the TX and RX differential pairs as shown below. The
common mode chokes should be placed within 10mm (approx. 400mils) of the integrated RJ45
module, and on the magnetics side of the common mode EMI suppression capacitors. Typical
common mode impedance of the common mode choke selected should be 2kΩ@100MHz or
higher.
•
In general, no ground plane should extend under the TX and RX differential pairs, under the
magnetics, or under the RJ45 jack. In the case where common mode capacitors used for EMI
suppression, a ground plane may be located under the TX and RX signals, however the plane
must not exceed beyond the capacitors. When designing 4 layer boards, the ground plane should
exist on layer 4, assuming the differential pair is routed on layer 1. On 2 layer boards, the ground
plane can be located on layer 2, the adjacent layer to the TX and RX signal pairs. Under no
circumstances should a ground plane exist under the magnetics, the RJ45 connector or in
between the magnetics and RJ45 connector.
TX-Guide
2015-02-02
15/51
TX-Guide
2.4.7 Controlled Impedance for Differential Signals
The 802.3-2005 specifications requires the TX and RX lines to run in differential mode. The TXP and TXN
are a differential pair and need to be designed to a 100 ohm differential impedance. The RXP and RXN
traces are also a differential pars and need to be designed to a 100 ohm differential impedance target.
The board designer must maintain 100 ohm differential impedance in the layout for all differential pairs.
For differential dielectric thickness, copper weight or board stack-up, trace width and spacings will need
to be calculated.
Differential pair nets must maintain symmetry. TXP and TXN must be equal length and symmetric with
regards of shape, length, and via count. RXP and RXN must also be equal length and symmetric.
Isolation of TX/RX traces. The TX/RX traces must be isolated from nearby circuitry and signals. Maintain
a distance of parts to lines that are greater than or equal to 5 times the distance of the spacing between
the traces. Do not route differential pairs under parts. Do not cross TX/RX lines with other PCB traces
unless the traces are on the opposite side of the ground plane from TX/RX.
16/51
2015-02-02
TX-Guide
TX-Guide
2.4.8 Magnetics Module
The magnetics module has a critical effect on overall IEEE and emissions conformance. The device
should meet the performance required for a design with reasonable margin to allow manufacturing
variation. Occasionally, components that meet basic specifications may cause the system to fail IEEE
testing, because of interactions with other components or the Printed Circuit Board itself. Carefully
qualifying new magnetics modules can go a long way toward preventing this type of problem.
Suggested magnetics have not been tested in order to verify proper operation. This category of
magnetic has been evaluated by the contents of the vendor supplied data sheet and legacy performance
only. However, the designer can assume with some degree of confidence, that with proper PCB design
techniques, the magnetics presented as suggested magnetics will perform to high standards.
Qualified magnetics have been tested by the PHY vendor in order to verify proper operation. The
designer can assume with a high degree of confidence, that with proper PCB design techniques, the
qualified magnetics perform to the highest standards.
Vendor
Part Number
Package
Temp
Status
Pulse
H1102
16-pin SOIC
0°..+70°C
Qualified
Halo
TG110-RP55N5
16-pin SOIC
0°..+70°C
Qualified
Halo
HFJ11-RP26E-L12RL
Integrated RJ45
0°..+70°C
Qualified
Delta
RJSE1R5310A
Integrated RJ45
0°..+70°C
Qualified
Pulse
J0011D01B
Integrated RJ45
0°..+70°C
Suggested
Bothhand
TS6121C
16-pin SOIC
0°..+70°C
Suggested
Bothhand
LU1S041X-43
Integrated RJ45
0°..+70°C
Suggested
Pulse
HX1102
16-pin SOIC
-40°..+85°C
Qualified
Halo
TG110-RPE5N5
16-pin SOIC
-40°..+85°C
Qualified
Halo
HFJ11-RPE26E-L12RL
Integrated RJ45
-40°..+85°C
Qualified
TDK
TLA-6T717W
Integrated RJ45
-40°..+85°C
Qualified
Delta
LFE8505T
16-pin SOIC
-40°..+85°C
Qualified
Midcom
000-7090-37R
16-pin SOIC
-40°..+85°C
Suggested
Midcom
MIC66211-5171T-LF3
Integrated RJ45
-40°..+85°C
Suggested
Elec & Eltek
Midcom /
Würth-Elektronik
Bel Stewart
820-M0323R
MIC24013-5101T-LF3
749 901 121 11
SI-60005-F
16-pin SOIC
-40°..+85°C
Suggested
Integrated RJ45
0°..+70°C
Integrated RJ45
N/A
TX-Guide
2015-02-02
Used on Starterkit 5
17/51
TX-Guide
2.5 USB
Pin
27
34
28
36
Signal
USBH_VBUSEN
USBOTG_VBUSEN
#USBH_OC
#USBOTG_OC
30 USBH_VBUS
38 USBOTG_VBUS
31
29
37
35
USBH_DP
USBH_DM
USBOTG_DP
USBOTG_DM
33 USBOTG_ID
Module
TX25/TX28/TX48/TX53/TX6
Description
type
I/O
3V3
O
3V3
I
5V
I
USB Host port differential data signal
USB
I/O
USB OTG port differential data signal
USB
I/O
5V
I
This pin is used to enable the external VBUS power supply.
Active low over-current indicator input connected to a GPIO.
This signal can be used as an input only.
VBUS pin of the USB cable. This pin is used for the VBUS comparator inputs.
Module
Remark
TX25
USBH_VBUS / USBOTG_VBUS unused / Not connected
TX28
USBH_VBUS unused / Not connected
ID pin of the USB cable. For an A-Device ID is grounded. For a B-Device ID is
floated.
Remark
USBOTG_VBUSEN, USBOTG_OC are also used for the 2nd CAN interface. In that case the
VBUSEN/OC functionality may be omitted or other GPIO's may be used instead.
2.5.1 USB Physical Layer Layout Guidelines
The TX modules includes the physical layer interface (PHY) for systems using Hi-Speed USB. Proper
design techniques must be used in printed circuit board (PCB) layout to maintain the signal integrity
required for 480 Mbps operation.
2.5.2 Controlled Impedance for USB Traces
the USB 2.0 specification requires that the USB DP/DM traces maintain a nominal 90 Ohms +/- 15%
differential impedance (see USB specification Rev. 2.0, paragraph 7.1.1.3 for more details). In the
example design the traces are 7 mil (175um) wide with line spacing of 7 mils. These numbers are
derived for 5 mil (125um) distance from ground reference plane. A continuous ground plane is required
directly beneath the DP/DM traces and extending at least 5 times the spacing width to either side of
DP/DM lines.
Maintain symmetry between DP/DM lines in regards to shape and length.
Single sided impedance is not as critical as differential impedance. A range of 42 to 78 Ohms is
acceptable (equivalently, common mode impedance must be between 21 Ohms and 39 Ohms).
18/51
2015-02-02
TX-Guide
TX-Guide
The figures show DP/DM traces with approximately equal trace length and symmetry. It is important to
maintain a conductor width and spacing that provides differential and common mode impedance
compliant with the USB specification. Use 45 degree turns to minimize impedance discontinuities.
2.5.3 Isolation of DP/DM Traces
The DP/DM lines must be isolated from nearby circuits and signals. Maintain a distance of components
to lines that is greater or equal to 5 times the distance of the spacing between the traces. Do not route
differential pairs under components. Do not cross DP/DM lines with other PCB traces unless the traces
are on the opposite side of the ground plane from DP/DM. Route DP/DM over solid ground plane with no
ground plane splits under the traces.
TX-Guide
2015-02-02
19/51
TX-Guide
2.5.4 Isolated shielding on the USB connector
The figure shows the Mini-AB connector housing is isolated but AC coupled to the device ground.
Industry convention is to ground only the host side of the cable shield. This is done to provide cable
shielding while preventing possible ground currents from flowing in the USB cable if there happens to be
a potential difference between the host and device grounds. If DC grounding is required replace C12
with a zero Ohms resistor.
In OTG applications the shield may be DC grounded at both ends of the cable.
20/51
2015-02-02
TX-Guide
TX-Guide
2.5.5 Optional VBUS protection
TX-Guide
2015-02-02
21/51
TX-Guide
2.5.6 USB recommendations1
In summary use the following recommendations for the USB.
1
•
Route DP and DM signals on the top or bottom layer of the board
•
The trace width and spacing of the DP and DM signals should be such that the differential
impedance is 90 Ω.
•
Route traces over continuous planes (power and ground).
•
They should not pass over any power/GND plane slots or anti-etch.
•
When placing connectors, make sure the ground plane clearouts around each pin have
ground continuity between all pins.
•
Maintain the parallelism (skew matched) between DP and DM; these traces should be the same
overall length.
•
Do not route DP and DM traces under oscillators or parallel to clock traces and/or data buses.
•
Minimize the lengths of high speed signals that run parallel to the DP and DM pair.
•
Keep DP and DM traces as short as possible.
•
Route DP and DM signals with a minimum amount of corners. Use 45-degree turns instead of 90degree turns.
•
Avoid layer changes (vias) on Dm and Dp signals. Do not create stubs or branches.
Freescale Hardware Development Guide for i.MX 6Quad, 6Dual, 6DualLite, 6Solo Families of Applications Processors,
Chap. 2.11
22/51
2015-02-02
TX-Guide
TX-Guide
2.6 I2C
Pin
Signal
Description
type
I/O
40
I2C_DATA
I2C Data
VDDIO
I/O
41
I2C_CLK
I2C Clock
VDDIO
O
Module
Devices connected to this I2C bus
TX25, TX27, TX28S,
TX51, TX53, TX6
TX28
TX48
No devices are connected to this I2C bus.
No pullup's are used on the module.
Name
Type
Speed [kbps]
Address
DS1339
RTC
400
1101000 r/w
PCA9554
IO
400
0100000 r/w
DS1339
RTC
400
1101000 r/w
LTC3589
PMIC
400
0110100 r/w
The I2C is a two-wire, bidirectional serial bus that provides a simple, efficient method of data exchange,
minimizing the interconnection between devices. This bus is suitable for applications requiring occasional
communications over a short distance between many devices. The flexible I2C allows additional devices
to be connected to the bus for expansion and system development.
TX-Guide
2015-02-02
23/51
TX-Guide
2.6.1 Example I2C Voltage Level Translator (TX27 and TX51 only)
The Texas Instruments PCA9306 allows bidirectional voltage translations between 1.2 V and 5 V, without
the use of a direction pin.
Be aware of the PCA9306 min. supply voltage: VREF2 > VREF1 + 0.6V.
Because of this limitation a Texas Instruments TXS0102 should be used instead if the
design is intended to be used with 1.8V and 3.3V TX modules.
As with the standard I2C system, pullup resistors are required to provide the logic high levels on the
translator's bus. The PCA9306 has a standard open-collector configuration of the I2C bus. The size of
these pullup resistors depends on the system, but each side of the repeater must have a pullup resistor.
The device is designed to work with standard-mode and fast-mode I2C devices, in addition to SMBus
devices. Standard-mode I2C devices only specify 3 mA in a generic I2C system where standard-mode
devices and multiple masters are possible. Under certain conditions, high termination currents can be
used.
24/51
2015-02-02
TX-Guide
TX-Guide
2.6.1 I2C recommendations2
Recommendation
Verify the target I2C interface clock rates.
Verify that the target I2C address range is supported
and does no conflict with other peripherals. If there is
an unavoidable address conflict, move the offending
device to another I2C port.
Do not place more than one set of pullup resistors on
the I2C lines
2
Explanation
The bus can only operate as fast as the slowest
peripheral on the bus. If faster operation is required,
move the slow devices to another I2C port. A slow
peripheral may unpredictably take over the bus or might
malfunction in some other way.
If it is undesirable to move a conflicting device to
another I2C port, review the peripheral operation to see
if it supports remapping the address.
This can result in excessive loading. Good design
practice is to place one pair of pullups only.
Freescale Hardware Development Guide for i.MX 6Quad, 6Dual, 6DualLite, 6Solo Families of Applications Processors,
Table 1-4
TX-Guide
2015-02-02
25/51
TX-Guide
2.7 PWM / 1-WIRE
Pin
Signal
Description
type
I/O
VDDIO
O
VDDIO
I/O
Pulse-Width Modulator (PWM) Output
42
PWM
Module
TX51
Remark
Be aware of the voltage level on this pin: 3.1V instead of 1.8V
1-Wire
43
OWIRE
Module
Remark
TX28/TX48/TX6 No 1-Wire controller – a GPIO is used instead
1-Wire is a registered trademark of Dallas Semiconductor for a device communications bus systems
designed by Dallas Semiconductor that provides low-speed data, signalling and power over a single
signal, albeit using two wires, one for ground, one for power and data. 1-Wire is similar in concept to
I2C, but with lower data rates and longer range. It is typically used to communicate with small
inexpensive devices.
26/51
2015-02-02
TX-Guide
TX-Guide
2.8 CSPI – Configurable Serial Peripheral Interface
Pin
Signal
44
CSPI_SS0
45
CSPI_SS1
46
CSPI_MOSI
47
CSPI_MISO
48
CSPI_SCLK
49
CSPI_RDY
Description
type
Slave Select bidirectional, selectable polarity signal, output in master mode, and VDDIO
input in slave mode.
VDDIO
Master Out Slave In bidirectional signal, which is TxD output signal from the
data shift register in master mode. In Slave mode it is RxD input to the data
VDDIO
shift register.
Master In Slave Out bidirectional signal, which is RxD input signal to the data
shift register in master mode. In Slave mode it is TxD output from the data shift VDDIO
register.
CSPI Clock bidirectional signal, which is CSPI clock output in master mode. In
VDDIO
slave mode it is an input CSPI clock signal.
Serial Data Ready signal - This input signal is used for hardware control only in
master mode. It indicates that external SPI slave is ready to receive data. It will
VDDIO
edge or level trigger a CSPI burst if used. If the hardware control enabled, CSPI
will transfer data only when external SPI slave is ready
I/O
I/O
I/O
I/O
I/O
I/O
I/O
The i.MX processors contains Configurable Serial Peripheral Interface (CSPI) modules that allow rapid
data communication with fewer software interrupts than conventional serial communications. Each CSPI
is equipped with two data FIFOs and is a master/slave configurable serial peripheral interface module,
allowing processor to interface with both external SPI master and slave devices.
TX-Guide
2015-02-02
27/51
TX-Guide
2.9 SDIO Interfaces
Pin
51,
95
52,
96
53,
97
54,
98
55,
99
56,
100
57,
101
Signal
SD1_CD
SD2_CD
SD1_D[0]
SD2_D[0]
SD1_D[1]
SD2_D[1]
SD1_D[2]
SD2_D[2]
SD1_D[3]
SD2_D[3]
SD1_CMD
SD2_CMD
SD1_CLK
SD2_CLK
Module
TX25, TX28, TX48
TX28
Description
type
I/O
SD Card Detect – connected to a GPIO
VDDIO
I
SD Data bidirectional signals
VDDIO
I/O
SD Command bidirectional signal
VDDIO
I/O
SD Output Clock.
VDDIO
O
Remark
Only one SD-Card available on standard pinout, SD Interface 2 is not used / not connected
Pin 101 is used as ENET_CLK
The TX pinout provides two dedicated SDIO interfaces. SDIO stands for Secure Digital Input Output
which can also be used for SD-Memory-Cards.
28/51
2015-02-02
TX-Guide
TX-Guide
2.9.1 SD-Card example diagram using level shifters
No external pullups are needed here. Each port of the TXS0108E has an internal pull-up resistor. These
have a value of 40 kΩ when the output is driving low and a value of 4 k Ω when the output is driving
high. Unfortunately the card detect feature commonly used for Micro-SD cards on DAT3/CD cannot be
used. A dedicated card detect switch is required.
2.9.2 SD-Card example diagram only for 3.3V modules
Either the use of the processor internal pullups or the use of pullups on the baseboard is possible.
TX-Guide
2015-02-02
29/51
TX-Guide
2.10 UARTs
Pin
59,
63,
67
60,
64,
68
61,
65,
69
62,
66,
70
Signal
UART1_TXD
UART2_TXD
UART3_TXD
UART1_RXD
UART2_RXD
UART3_RXD
UART1_RTS
UART2_RTS
UART3_RTS
UART1_CTS
UART2_CTS
UART3_CTS
2.10.1
30/51
Description
type
I/O
Transmit Data output signal
VDDIO
O
Receive Data input signal
VDDIO
I
Request to Send input signal
VDDIO
I
Clear to Send output signal
VDDIO
O
UART Example diagram
2015-02-02
TX-Guide
TX-Guide
2.11 Keypad Interface
Pin
Signal
Description
72
KP_COL[0]
73
KP_COL[1]
VDDIO
74
KP_COL[2]
VDDIO
75
KP_COL[3]
VDDIO
76
KP_COL[4]
VDDIO
77
KP_ROW[0] Keypad Row selection signals.
VDDIO
78
KP_ROW[1]
VDDIO
79
KP_ROW[2]
VDDIO
80
KP_ROW[3]
VDDIO
81
KP_ROW[4]
VDDIO
Keypad Column selection signals.
Module
TX28
TX25, TX48, TX53, TX6
type
I/O
VDDIO
Remark
A PCA9554 8-bit I2C-bus I/O port is used for KP_COL[0-3] and KP_ROW[0-3]
KP_COL[4], KP_ROW[4] is not part of the keypad interface, used for CAN instead.
KP_COL[4], KP_ROW[4] can also be used for the 1st CAN interface.
The Keypad Port (KPP) is designed to interface with the keypad matrix with 2-point contact or 3-point
contact keys. The KPP is designed to simplify the software task of scanning a keypad matrix. With
appropriate software support, the KPP is capable of detecting, debouncing, and decoding one or multiple
keys pressed simultaneously on the keypad.
TX-Guide
2015-02-02
31/51
TX-Guide
2.12 Digital Audio Ports
Pin
83
89
84
90
85
91
86
92
87
93
Signal
SSI1_INT
SSI2_INT
SSI1_RXD
SSI2_RXD
SSI1_TXD
SSI2_TXD
SSI1_CLK
SSI2_CLK
SSI1_FS
SSI2_FS
Module
Description
type
I/O
Interrupt
Receive serial data
Transmit serial data
Serial clock
Frame Sync
Remark
TX28S, TX48
Only one SSI port available, SSI2 pins are not connected
TX28, TX28S
On this module the SSI is a half-duplex serial port
The SSI is a full-duplex, serial port that allows the chip to communicate with a variety of serial devices.
These serial devices can be standard CODer-DECoder (CODECs), Digital Signal Processors (DSPs),
microprocessors, peripherals, and popular industry audio CODECs that implement the inter-IC sound bus
standard (I2S) standard.
SSI is typically used to transfer samples in a periodic manner. The SSI consists of independent
transmitter and receiver sections with independent clock generation and frame synchronization.
Audio Codec example:
32/51
2015-02-02
TX-Guide
TX-Guide
2.13 CMOS Sensor Interface
Pin
Signal
103-110
CSI1_D
Description
Sensor port data (8 bit)
type
I/O
VDDIO
I
112
CSI1_HSYNC Sensor port horizontal sync
VDDIO
I
113
CSI1_VSYNC
VDDIO
I
114
CSI1_PIXCLK Sensor port data latch clock
VDDIO
I
VDDIO
O
115
CSI1_MCLK
Module
TX28
Sensor port vertical sync
Sensor port master clock
Remark
The TX28 has no camera interface. Refer to TX28 datasheet for alternate usage.
The CMOS Sensor Interface (CSI) enables the chip to connect directly to external CMOS image sensors.
CMOS image sensors are separated into two classes, dumb and smart. Dumb sensors are those that
support only traditional sensor timing (Vertical SYNC and Horizontal SYNC) and output only Bayer and
statistics data, while smart sensors support CCIR656 video decoder formats and perform additional
processing of the image (for example, image compression, image pre-filtering, and various data output
formats).
The standard CSI can support to connect one 8-bit sensor.
2.14 Extended and 2nd CMOS Sensor Interface (TX51, TX53 and TX6 only)
Pin
Signal
Description
type
I/O
161-164
CSI1_D[8-11] Sensor port data (4 bit)
VDDIO
I
152-159
CSI2_D[12-19] 2nd Sensor port data
151
VDDIO
I
nd
VDDIO
I
nd
VDDIO
I
VDDIO
I
VDDIO
O
CSI2_HSYNC 2 Sensor port horizontal sync
150
CSI2_VSYNC
149
CSI2_PIXCLK 2nd Sensor port data latch clock
148
CSI2_MCLK
Module
TX25, TX27, TX28, TX48
2 Sensor port vertical sync
nd
2 Sensor port master clock
Remark
Not available – other module specific functions are used on these pins.
TX51 and TX53 provide a second camera interface and four additional data bits for the first camera
interface. The complete interface is available on the module specific section of the TX-Standard pinout.
TX-Guide
2015-02-02
33/51
TX-Guide
2.15 LCD Interface
Pin
117-128,
130-141
143
Signal
Description
type
I/O
LCD_D[0-23] LCD Data
HSYNC
144
VSYNC
145
OE_ACD
146
LSCLK
Line Pulse or HSync
Frame Sync or VSync—This signal also serves as the
clock signal output for gate; driver (dedicated signal SPS
for Sharp panel HR-TFT)
Alternate Crystal Direction/Output Enable
Shift Clock
The LCD Controller of the i.MX processors provides display data for external greyscale or color LCD
panels. The LCD Controller is capable of supporting black-and-white, greyscale, passive-matrix color
(passive color or CSTN), and active-matrix color (active color or TFT) LCD panels.
The TX LCD Interface defines a generic 24 bit Panel Interface LCD_D[23..0].
The TFT color channel assignments are shown in the table below:
LCD_D
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
TX28
TX51
TX53
TX6
LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
TX48
LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD LD
4
3
2
1
0 16 18 21 10 9
8
7
6
5 19 22 15 14 13 12 11 17 20 23
TX25
TX27
LD LD LD LD LD LD GP GP LD LD LD LD LD LD GP GP LD LD LD LD LD LD GP GP
17 16 15 14 13 12 IO IO 11 10 9
8
7
6 IO IO 5
4
3
2
1
0 IO IO
24bpp
R7 R6 R5 R4 R3 R2 R1 R0 G7 G6 G5 G4 G3 G2 G1 G0 B7 B6 B5 B4 B3 B2 B1 B0
18bpp
R5 R4 R3 R2 R1 R0
G5 G4 G3 G2 G1 G0
B5 B4 B3 B2 B1 B0
16bpp
R4 R3 R2 R1 R0
G5 G4 G3 G2 G1 G0
B4 B3 B2 B1 B0
R3 R2 R1 R0
G3 G2 G1 G0
B3 B2 B1 B0
3
12bpp
With this assignment the two module types – 18bpp like the TX25 and TX27 and 24bpp like the TX51 –
can be used on the same carrier board without any change. On 18bpp modules the unused bits are
always connected to General Purpose IOs to be able to drive these to a defined level.
Module
TX48
3
Remark3
The blue and red color assignments to the LCD data pins are reversed when operating in RGB888
(24bpp) mode compared to RGB565 (16bpp) mode. Using the LCD Controller with this connection scheme
limits the use of RGB565 mode. Any data generated for the RGB565 mode requires the red and blue color data
values be swapped in order to display the correct color.
AM335x ARM Cortex-A8 Microprocessors (MPUs) Silicon Errata
34/51
2015-02-02
TX-Guide
TX-Guide
2.16 LVDS/SATA option (TX53, TX6 only)
As an ordering option the TX53 and TX6 are available with a dual LVDS and SATA interface instead of
the parallel LCD interface.
In that case the LCD interface signals LD0..LD19 are used to bring out the processors LVDS interfaces.
In addition to this the SATA interface is available on pins LD20..LD23.
2.16.1
LVDS pin mapping
LVDS interface 0
LCD_D
19
18
17
16
15
14
13
12
11
9
Pin
137
136
135
134
133
132
131
130
128
126
Signal TX0_N TX1_N TX0_P TX1_P TX2_N CLK_N TX2_P CLK_P TX3_N TX3_P
LVDS interface 1
LCD_D
10
8
7
6
5
4
3
2
1
0
Pin
127
125
124
123
122
121
120
119
118
117
Signal CLK_P CLK_N TX0_P TX3_P TX0_N TX3_N TX1_P TX2_P TX1_N TX2_N
2.16.2
LVDS recommendations4
Use the following recommendations for the LVDS.
• Follow standard high-speed differential routing rules for signal integrity.
• Each differential pair should be length matched to ± 5 mils.
• LVDS differential pairs should have a differential impedance of 100 Ω.
2.16.3
SATA pin mapping
LCD_D
23
22
21
20
Pin
141
140
139
138
Signal SATA_TXP SATA_RXP SATA_TXM SATA_RXM
2.16.4
SATA recommendations5
Use the following recommendations for the SATA.
• SATA differential pairs should have a differential impedance of 100 Ω.
• Each differential pair should be length matched to ± 5 mils.
• Follow standard high-speed differential routing rules for signal integrity.
4
5
Freescale Hardware Development Guide for i.MX 6Quad, 6Dual, 6DualLite, 6Solo Families of Applications Processors,
Chap. 2.10
Freescale Hardware Development Guide for i.MX 6Quad, 6Dual, 6DualLite, 6Solo Families of Applications Processors,
Chap. 2.9
TX-Guide
2015-02-02
35/51
TX-Guide
2.17 CAN Interface
Pin
Signal
76
CAN1-TX
81
type
I/O
This is the transmit signal to the CAN bus transceiver.
VDDIO
O
CAN1-RX
This is the receive signal from the CAN bus transceiver.
VDDIO
I
34
CAN2-TX
This is the transmit signal to the CAN bus transceiver.
VDDIO
O
36
CAN2-RX
This is the receive signal from the CAN bus transceiver.
VDDIO
I
Module
TX27, TX51
Description
Remark
Not available – default functions are used on these pins.
Some TX modules provides a FlexCAN communication controller that implements the CAN protocol
according to the CAN 2.0B protocol specification. The CAN protocol was designed primarily (but not
solely) to meet requirements suitable for a serial data bus in vehicle applications, including: real-time
processing, reliable operation in the EMI environment of a vehicle, cost-effectiveness, and sufficient
bandwidth. A CAN Transceiver is needed on the baseboard to connect the system to the CAN bus. The
Texas Instruments SN65HVD23x operates with a single 3.3V supply and can be connected directly to the
3.3V TX modules:
36/51
2015-02-02
TX-Guide
TX-Guide
2.18 2nd Ethernet RMII (TX28 only)
Pin
Signal
15
RESET_B
Description
152
Ethernet PHY reset. This signal is also connected to the TX28 onboard Ethernet PHY.
Ethernet PHY clock. This signal is also connected to the TX28 onboard PHY. This clock signal is
ENET_CLK
split at the driver side on the TX28. The trace length on the baseboard should be about 35mm.
ENET1_RXD0 Bit 0 of the 2 data bits that are sent by the transceiver on the receive path.
153
ENET1_RXD1 Bit 1 of the 2 data bits that are sent by the transceiver on the receive path.
154
ENET1_TXD0 Bit 0 of the MAC transmit data to the transceiver
155
ENET1_TXD1 Bit 1 of the MAC transmit data to the transceiver
156
ENET1_TX_EN Indicates that valid transmission data is present on TXD[1:0]
157
ENET1_RX_EN Receive Data Valid
101
197
ENET_INT
Ethernet PHY interrupt. This signal is wired or with the TX28 onboard Ethernet PHY interrupt.
198
ENET_MDC
ENET_MDC
199
ENET_MDIO
ENET_MDIO
TX-Guide
2015-02-02
37/51
TX-Guide
2.19 TV out (TX51, TX53 only)
Pin
Signal
168
TVDAC_IOB
169
TVDAC_IOG
170
TVDAC_IOR
Description
Triple Video Digital-to-Analog Converter (TVDAC); supports
HD720p/1080p, PAL/NTSC or VGA output for direct connection to
TV or LCD projector
type
I/O
analog
O
analog
O
analog
O
Rset = 1.05 kΩ ±1%, resistor on TVDAC_VREF pin to GND
A 75-Ω termination is already done on the module:
2.19.1
TV Encoder Recommendations6
Use the following recommendations for the TV encoder.
•
6
For the TV/VGA interface, the IOR, IOG, and IOB signals must have 75-Ω imepedance.
Freescale i.MX53 System Development User’s Guide, MX53UG, Chap. 2.7
38/51
2015-02-02
TX-Guide
TX-Guide
2.20 PCI express (TX6 only)
Pin
166, 168
167, 169
170, 172
Signal
CLK1_N,
CLK1_P
PCIE_RXM,
PCIE_RXP
PCIE_TXM,
PCIE_TXP
Description
type
I/O
Alternate reference clock for PCIe
LVDS
I/O
PCI Express receive differential pair
LVDS
I
PCI Express transmit differential pair
LVDS
O
The TX6 provides a ×1 PCIe lane. The PCIe module supports PCI Express Gen 2.0 interfaces at 5 Gb/s.
It is also backwards compatible to Gen 1.1 interfaces at 2.5 Gb/s.
2.20.1
PCI Express interface recommendations7
2.20.1.1
PCI Express general routing guidelines
Use the following recommendations for PCI Express general routing:
•
•
•
•
•
•
•
The trace width and spacing of the lanes ×1 signals should be such that the differential
impedance is 85 Ω ± 10%.
Route traces over continuous planes (power and ground). Avoid split planes, plane slots, or
anti-etch.
Maintain the parallelism (skew matched) between differential signals; these traces should be the
same overall length.
Keep signals with traces as short as possible.
Route signals with a minimum amount of corners. Use 45-degree turns instead of 90-degree
turns.
Do not create stubs or branches.
Maintain symmetry of differential pair routing.
2.20.1.2
PCI Express coupling lane
All signals are directly connected on the TX6 module. Refer to the Freescale Hardware Development
Guide for a guideline to couple the signals. Consult the PCISig documentation for detailed information.
2.20.2
PCIe recommendations8
Recommendation
Termination is required on the differential clock lines.
Connect two 49.9 Ω resistors, one between REFCLKand GND, the other between REFCLK+ and GND.
Alternately, Connect a 100 Ω resistor between REFCLKand REFCLK+.
7
8
Explanation
These termination resistors should be placed as close as
possible to the receiver device inputs in case the chip
LVDS clock outputs are used as the REFCLK source for
the PCIe endpoint device.
Freescale Hardware Development Guide for i.MX 6Quad, 6Dual, 6DualLite, 6Solo Families of Applications Processors,
chap. 2-7
Freescale Hardware Development Guide for i.MX 6Quad, 6Dual, 6DualLite, 6Solo Families of Applications Processors,
Table 1-10
TX-Guide
2015-02-02
39/51
TX-Guide
2.21 GPIO and module specific signals
Pin
Signal
148-159
161-170,
172-182,
184-199
GPIO[0-11]
40/51
Description
General Purpose Input/Output
type
I/O
VDDIO
I/O
Module specific interfaces – refer to datasheet for details
2015-02-02
TX-Guide
TX-Guide
3 Optional Debugging Connector
3.1 Debug Connector Signal Assignment
Pin
Signal
1
MFG_NC1
3
MFG_NC0
5
BOOT[1]
7
BOOT[0]
9
GND
11
#TRST
VDDIO
13
TMS
VDDIO
15
TDO
VDDIO
17
TDI
VDDIO
19
GND
21
TCK
23
GND
25, 27, 29
NC
2, 4, 6 … 28, 30
GND
TX-Guide
Description
type
Do not connect on the carrier board.
These pins are reserved for manufacturing
purposes.
Module specific boot mode, refer to the processor VDDIO
datasheet. Boot from flash is selected, if these pins
VDDIO
are not connected. (N/A on TX28)
I/O
I
I
VDDIO
2015-02-02
41/51
TX-Guide
3.2 Debug connector location
Mates with Samtec FSI - 3mm Height, One Piece Interface, part no. FSI-115-03-G-D-AD
The SO-DIMM connector socket height has to be 5.2mm if the debug connector is used.
42/51
2015-02-02
TX-Guide
TX-Guide
4 Mechanical
4.1 TX module outline
Module
L
A
B
TX25
1.4mm
1.3mm
TX27
1.8mm
1.0mm
1.8mm
1.1mm
1.8mm
1.1mm
1.8mm
1.1mm
1.8mm
1.3mm
2.0mm
1.1mm
TX28
TX48
W
26mm
67.6mm
TX51
TX53
TX6
TX-Guide
31mm
2015-02-02
43/51
TX-Guide
4.2 SO-DIMM connector
For detailed information on socket dimensions and recommended PCB layout refer to the manufacturer
datasheets. Be sure to use DDR SO-DIMM type sockets with 2,5V keying.
Part number
1565691-1
AS0A426-E4SN-7F
SODIMM200S52T25
AS0A426-E2SN-7F
1473005-1
AS0A426-B6SN-7F
1717468-3
AS0A426-B8SN-7F
SODIMM200S92T25
AS0A426-EASN-7F
Socket
height
Overall
mounting
height
Underside
space
4,0mm
4,5mm
0,5mm
5,2mm
5,7mm
1,7mm
6,5mm
7,0mm
3,0mm
8,0mm
8,5mm
4,5mm
9,2mm
9,7mm
5,7mm
Supplier
Tyco Electronics
Foxconn
admatec
Foxconn
Tyco Electronics
Foxconn
Tyco Electronics
Foxconn
admatec
Foxconn
Tabelle 1: SO-DIMM part numbers and suppliers
Typical DDR SO-DIMM Socket specifications
•
•
•
•
•
•
•
44/51
Durability : 25 Cycles
Voltage Rating: 25V
Current Rating: 0.5A (Tyco Electronics 1473005-1)
Contact Resistance: 50mΩ max.
Dielectric Withstanding Voltage: 250V AC/1 min.
Insulation Resistance: 100MΩ
Operating Temperature: -40℃ to +85℃
2015-02-02
TX-Guide
TX-Guide
4.3 DIMM Connector PCB Layout example
The position of the TX module mounting holes depend on the used DIMM socket. The following example
applies to a Tyco socket 1473005-1.
TX-Guide
2015-02-02
45/51
TX-Guide
4.4 TX Fastener Kit
A fastener kit provides secure mounting of modules plugged into the SO-DIMM socket. An additional
thread locker is recommended to hold the screws in during vibration.
Ka-Ro Part number
TX00-ZV02
(Fastener Kit / 10 sets)
Description
Self Retaining Screw Spacer for M2,0
Length 3,0 mm,
Outside Diameter 4,00 mm
www.ettinger.de part. no. 07.51.403
Nut M2,0
Screw M2,0 x 8mm
46/51
2015-02-02
Quantity
20
20
20
TX-Guide
TX-Guide
4.5 TX Heatsink Kit (17 K/W)
The TX Heatsink Kit provides also a secure mounting of a module.
Ka-Ro p/n
Item
Heatsink
TX00-ZV06
Spacer
Thermal gap filler
Screw
TX-Guide
Description
Fischer Elektronik GmbH,
customised SK 473, 27mm x 68mm x 6mm
Self Retaining Screw Spacer
for M2,0, Length 3,0 mm,
Outside Diameter 4,00 mm
www.ettinger.de p/n 07.51.403
Screw Spacer for M2,0
Length 2,0 mm,
Outside Diameter 4,00 mm
www.ettinger.de p/n 05.81.020
Fischer Elektronik GmbH,
heat conductive gel foil GEL 10
Screw M2,0 x 10mm
2015-02-02
Quantity
1
2
2
20mm x 20mm
2
47/51
TX-Guide
4.5.1 Standard extruded heatsink – SK 473 – length 68mm
4.5.2 Heat conductive gel foil – GEL 10
Fischer Elektronik GEL 10 datasheet:
version
standard
material
GEL foil
material thickness
1 mm
tolerance
0.2
thermal conductivity
1.5 W/m·K
volume resistivity>1·106 MΩ/m
Rth
1.02 °C in2/W
hardness range
< 49 Shore 00
temperature range
-60 °C ... +200 °C
extensibility
100 %
dielectric constant
5.8 [50 Hz]
5.6 [1 KHz]
5.5 [1 MHz]
dielectric loss factor
0.048 [50 Hz]
0.015 [1 KHz]
0.003 [1 MHz]
dielectric strength
14 kV/mm (AC)
tightness
2.6 g/cm3
class of flammibility
UL 94 V-0
type of delivery
on both sides covered with protective foil material
48/51
2015-02-02
TX-Guide
TX-Guide
4.6 TX Heatsink Kit (7 K/W)
The TX Heatsink Kit provides also a secure mounting of the module.
Ka-Ro
p/n
Item
Description
Fischer Elektronik GmbH,
customised SK 560, 27mm x 68mm x 14mm
Self Retaining Screw Spacer
for M2,0, Length 3,0 mm,
Spacer
Outside Diameter 4,00 mm
TX00-ZV07
www.ettinger.de
p/n 07.51.403
Fischer Elektronik GmbH,
Thermal gap filler
heat conductive gel foil GEL 27 S 25
Screw
Screw M2,0 x 12mm
Heatsink
TX-Guide
2015-02-02
Quantity
1
4
57mm x 15mm
2
49/51
TX-Guide
4.6.1 Standard extruded heatsink – SK 560 – length 68mm
4.6.2 Heat conductive gel foil – GEL 27 S 25
Fischer Elektronik GEL 27 S 25 datasheet:
material thickness
2.5 mm
thermal conductivity
2.7 W/m·K
volume resistivity2·107 MΩ/m
Rth
0.94 °C in2/W
hardness range
45 Shore 00
temperature range
-60 °C ... +200 °C
extensibility
45 %
dielectric strength
15 kV/mm
tightness
3 g/cm3
class of flammibility
UL 94 V-0
type of delivery
on both sides covered with protective foil material
50/51
2015-02-02
TX-Guide
TX-Guide
5 Document Revision history
Revision
Changes
2009-05-28
Initial release
2009-07-21
ETN_RXN, ETN_RXP wrong pin mapping corrected.
2010-01-27
New Layout / TX37 removed and TX51 added instead / Fastener Kit part number.
2010-03-12
Page 8, TX25 reduced output current was missing in the history, Page 32 “refer to bootmode table below“
removed.
2010-08-20
Page 25, SD-Card schematics shows a standard SD-Card pinout. “MICRO” removed.
Page 30, Typo in 24bpp row.
CAN interface section and TX51 and TX53 specific extended and 2nd CMOS Sensor Interface added.
Remarks for TX28 and TX53 included and several other remarks updated.
2010-09-21
TX28 remarks updated.
2011-01-20
TX28 2nd Ethernet Interface signalling and TX53 LVDS option added.
2011-12-05
2.18 ENET_INT and ETN_3V3 pin number corrected / TX53 SATA option added / TX28 BOOTMODE remark
2012-12-20
TX48, TX6 added / TX Heatsink Kit added / Several remarks and recommendations added
2013-03-22
TX Heatsink updated and (7 K/W) TX Heatsink Kit added.
2013-09-16
AC97 removed from the SSI description, SSI module remarks added.
2015-02-02
TX6 VOUT ratings changed, added TX6 VBACKUP supply range for version without DS1339 RTC
TX-Guide
2015-02-02
51/51
Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Ka-Ro electronics:
TX00-ZV02 TX00-ZV07 TX00-ZV06
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
