PIN & SLEEVE DEVICES
PIN & SLEEVE DEVICES
line of industrial plugs and sockets are
manufactured by ABL Sursum, a company well known in
Europe for its quality electrical products. This major
manufacturer combines the elements of good design,
high quality, safety, ease of installation and competitive
cost. The pin and sleeve devices are manufactured to EN
60309 Part 1 and 2: IEC 60309. Their rugged construction
in polyamide 6 material provides good anti-tracking
properties and high resistance to aggressive industrial
use.
In accordance with the Standard's requirements, these
devices are color coded to provide positive voltage and
frequency matching and external key-ways ensure correct
alignment of contact pins. The position of the ground pin
relative to the socket's key-way are designated as a clock
hour position.
The ground terminal also has a larger diameter than the
contacts, making it impossible to install it in an IEC 60309
device with a different voltage rating.
Features include:
• High impact and abrasion resistance
• Resistant to oil, petrol, most acids and alkalines
• Operating Temperature range
-13°F to 176°F (-25°C to 80°C)
• Excellent anti-tracking
• Grooved body improves hand grip
• Insulated cable clamp device
• Maximum wiring space
• Terminals clearly marked
• All screws are accessible from one side
FEATURE
20-30A
plugs, connectors,
and angled inlets
The shrouded housing made of high impact nylon material
protects the contacts from physical abuse and safeguards
against touching live parts when partially engaged.
Assembly is simple and quick with the help of the multiramp locking system. Parts are delivered in a half unlocked
stage to make initial assembly straightforward.
All terminals are clearly marked in both IEC 60309 and
North American Standards.
1. Match triangle icons for both housings in open position.
2. Twist counter-clockwise until locked as per above figure.
Voltage Configuration Chart
3P
+N
/5W
3P
/4W
120/250V AC
Pin and Sleeve devices are color coded to provide
positive voltage and frequency matching and external keyways ensure correct alignment of contact pins. The
position of the ground pin relative to the socket's key-way
are designated as a clock hour position.
2P/
3W
10
208Y/120V
11 12 1
9
250V AC
8
The ground terminal also has a larger diameter than the
contacts, making it impossible to install in an IEC 60309
device with a different voltage rating.
2
3
7
6
5
COLOR CODING AND
GROUND PIN POSITIONS
4
120V AC
380V AC
440V AC
L2
480V AC
L1
L3
L2
277V AC
250V AC
480V AC
L1
600V AC
400V AC
480Y/277V
PE
6h
600Y/347V
346Y/200V AC
415Y/240V AC
N
PE
N
L3
9h
Front view of receptacle/connector to contact barrier
Altech Corp.® • 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
Altech Corp.® • 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
Altech Corp.® • 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
TECHNICAL DATA
Electrical
Insulation Voltage, Max. (Volts)
16/20 Amp. (A) = 690V (Plugs, Connectors, Receptacles) / 500V (inlets)
30/32 Amp. (A) = 690V (Plugs, Connectors, Receptacles) / 500V (inlets)
60/63 Amp. (A) = 750V
125/100 Amp. (A) = 750V
Dielectric Withstanding Voltage
16/20 Amp. (A) = 3,000V (Plugs, Connectors, Receptacles) / 2,500V (inlets)
30/32 Amp. (A) = 3,000V (Plugs, Connectors, Receptacles) / 2,500V (inlets)
60/63 Amp. (A) = 2,500 V
100/125 Amp. (A) = 2,500V
Current Interrupting
Certified for current interrupting at full rated current
Endurance, Connect and
disconnect cycles at full rated
current and voltage
IEC: 16 Amp.
32 Amp.
UL: 20 Amp.
30 Amp.
(A)
(A)
(A)
(A)
=
=
=
=
5000
1000
5000
1000
at
at
at
at
a
a
a
a
power
power
power
power
factor
factor
factor
factor
of
of
of
of
0.6
0.6
0.75-0.80
0.75-0.80
63/60 Amp. (A) = 1,000 @ a p.f. of 0.6
100/125 Amp. (A) = 1,000 @ a p.f. of 0.7
Environmental
Temperature Range, Operating
-25°C to + 80°C (-13°F to + 176°F)
Temperature Resistance
Up to 1 hour +100°C (167°F)
Moisture Resistance
Splashproof IP 44; Watertight IP 67; Per IEC 60309-1, Clause 18
Flammability
per IEC 60309-1 / Clause 27
Flame Class Rating UL 94 or CSA C22.2 No. 0.17: V-2
Material
20 - 30 Amp
60 - 100 Amp
Housing
Polyamide 6
Polyamide 6
Cover
Polyamide 6
Polyamide 6
Cover Rivet
Splashproof IP44: Polyamide 6
Brass
(Front and Back)
Watertight IP67: Brass
Cover Spring
Spring Steel
Stainless Steel (A2)
Contact Carrier
Polyamide 6
Polyamide 6
Contacts
Brass or Nickel-plated Brass
Brass
Terminal Screws
Steel, Brass or Nickel Plated Brass
Steel, Nickel Plated, Bichromated
Cord Clamp / Bushing
Polypropylene and Thermoplastic Elastomer
Concentric Laminated Rubber
Gland Nut
Polyamide 6
Polyamide 6
Assembly Screws
Steel
Steel, Nickel Plated, Chromated
Internal Strain Relief
NA
Polyamide 6
Retaining Ring
NA
Steel, Electro Zinc Plated
Recommended Wire Size*
UL/CSA
IEC
Amp Rating
20
30
Wire Size / UL (min.)
12 AWG
10 AWG
Wire Size / CSA (min.)
14 AWG
12 AWG
60
100
4 AWG
2 AWG
4 AWG
2 AWG
Amp Rating
16
32
Flexible Wire per IEC
Plugs, Connectors, Receptacles, Inlets
1mm2 - 2.5mm2
2.5mm2 - 6mm2
Solid Wire per IEC
Receptacles, Inlets
1mm2 - 4mm2
2.5mm2 - 10mm2
63
125
min. 10mm2
min. 35mm2
min. 10mm2
min. 35mm2
Housing Screws [lb.in.]
9.74
9.74
Strain Relief [lb.in.]
35.4
44.3
Recommended Screw Torque for Terminal Set Screws
Amp Rating
16A/20A
32A/30A
Receptacles, Inlets
Receptacles, Inlets
Terminal Screws [lb.in.]
8.85
9.74
16A/20A
32A/30A
Plugs, Connectors
Plugs, Connectors
8.85
9.74
63/60A
125/100A
17.7
88.5
* Please refer to National Electric Code, to determine wire size for different Amp Ratings.
Altech Corp.® • 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
Altech Corporation
35 Royal Road
Flemington, NJ 08822-6000
Phone (908) 806-9400
Fax (908) 806-9490
www.altechcorp.com
Altech Corp.® 252-052010-3M
PLUG
20-30A IP44
CONNECTOR
SPLASHPROOF
E141950, E141951
Ground Pin
Poles
Amps
4h
6h
7h
5h
3h
9h
6h
7h
12h
5h
9h
6h
7h
5h
4h
6h
7h
5h
2P/3W
2P/3W
2P/3W
2P/3W
3P/4W
3P/4W
3P/4W
3P/4W
3P/4W
3P/4W
4P/5W
4P/5W
4P/5W
4P/5W
2P/3W
2P/3W
2P/3W
2P/3W
20A
20A
20A
20A
20A
20A
20A
20A
20A
20A
20A
20A
20A
20A
30A
30A
30A
30A
120V AC
250V AC
480V AC
277V AC
380/440V AC
250V AC
400V AC
480V AC
120/250V AC
600V AC
120/208V AC
400V AC
277/480V AC
347/600V AC
120V AC
250V AC
480V AC
277V AC
Voltage
Yellow
Blue
Red
Grey
Red
Blue
Red
Red
Orange
Black
Blue
Red
Red
Black
Yellow
Blue
Red
Grey
S31S10A
S31S20A
S31S50A
S31S70A
S41S00A
S41S20A
S41S30A
S41S50A
S41S60A
S41S70A
S51S20A
S51S30A
S51S50A
S51S70A
S32S10A
S32S20A
S32S50A
S32S70A
K31S10A
K31S20A
K31S50A
K31S70A
K41S00A
K41S20A
K41S30A
K41S50A
K41S60A
K41S70A
K51S20A
K51S30A
K51S50A
K51S70A
K32S10A
K32S20A
K32S50A
K32S70A
3h
9h
6h
7h
12h
5h
9h
6h
7h
5h
3P/4W
3P/4W
3P/4W
3P/4W
3P/4W
3P/4W
4P/5W
4P/5W
4P/5W
4P/5W
30A
30A
30A
30A
30A
30A
30A
30A
30A
30A
380/440V AC
250V AC
400V AC
480V AC
120/250V AC
600V AC
120/208V AC
400V AC
277/480V AC
347/600V AC
Red
Blue
Red
Red
Orange
Black
Blue
Red
Red
Black
S42S00A
S42S20A
S42S30A
S42S50A
S42S60A
S42S70A
S52S20A
S52S30A
S52S50A
S52S70A
K42S00A
K42S20A
K42S30A
K42S50A
K42S60A
K42S70A
K52S20A
K52S30A
K52S50A
K52S70A
