GENERAL CATALOGUE 2009
UPS from 350VA to 800kVA
THE SCIENCE OF CONTINUITY
AROS
AROS, a history of research
and continuity.
Continuous operation is the key
word for AROS. It is its field of
activity, a sophisticated technology
upon which the efficiency of every
electrical system depends. AROS
has over 70 years of experience in
this highly specialized sector and is
currently a leading brand name in the
field.
But continuity is also AROS
“trademark” as acknowledged by
design and installation engineers:
the will to strive constantly to
achieve the highest production
standards and to anticipate market
demands. Thinking in this way
brought AROS to set up the
Research and Development team of
about forty persons to better
respond to the market
requirements. The result is that
today whoever thinks about
emergency power supplies thinks
AROS.
AROS was set up in 1935 and
after just a few years established
itself as the leading Italian
manufacturer of voltage
regulators, transformers and
power supplies. In the fifties
AROS was the first company
manufacturer in Italy of ballasts
for fluorescent neon lamps and
became the Italian leader in the
field of components for lighting.
In the eighties it designed,
developed and produced
switching power supplies for
IBM computers. AROS thus
acquired know-how in PWM
(Pulse-Width- Modulation)
technology that enabled it to
enter the UPS sector. This is
now the most important field of
activity for AROS, which has
maintained its leadership in
voltage regulators and
components.
Steps to success
1935 Manufacture of radio loudspeakers
1940 Production of transformers for radios and electrical power supplies
1945 Entry on the market of the first power supplies (ballasts)
for fluorescent neon lamps
1950-1959 Manufacture of magnetic reactors for fluorescent and discharge lamps
1960-1969 First suppliers of components for IBM
Manufacture of ferro-resonant regulators
1970-1979 Production of electronic components for regulators
1980-1989 Manufacture of uninterruptible power supplies (UPS),
switching power supplies and electronic reactors
1990-1999 Expansion of the range of UPS for various applications (IT, industrial)
2000-2008 Growth and consolidation in the Worldwide UPS market
2009 Expansion of its production with the STS (automatic Static Transfer Switch)
Entering the Research and Development department is like entering the heart of AROS.
Here users’ real problems are "filtered" by means of the latest technologies and
transformed into successful products.
Research
Highly trained personnel and state of the art
technologies lie behind every project.
Entering the Research and
Development department means
entering the heart of AROS. Here
users’ real problems are “filtered”
by means of the latest technologies
and transformed into successful
products. Environmental simulators,
sophisticated analysis tools, CAD
systems: super specialized devices
for super specialized design
engineers to predict tomorrow’s
needs today, needs arising from
developments in electronics and
market trends. AROS dedicates its
greatest resources to this team and
has recently boosted the power
area. This both consolidates the
strength of its core business of
Uninterruptible Power Supplies
(UPS), components and voltage
regulators, while mapping out its
future course.
To understand the work carried
out by the research team, just
think of the technological
“nodes” that are hidden behind
the apparent functional linearity
of a UPS system. To provide a
high level of efficiency, withstand
strong line interference, interact
with surrounding systems that
may not be homogeneous,
comply with complex
international safety standards,
minimize the level of interference
emitted towards the mains and
towards the environment and
finally, offer a degree of reliability
that is increasingly demanded by
new electronic systems.
AROS products are intended for sophisticated devices
- delicate electronic systems needing protection - and sophisticated
devices are required to design, develop and produce them.
New technology
Intelligent devices.
Intelligent men.
AROS products are intended for
sophisticated devices - delicate
electronic systems needing
protection - and sophisticated
devices are required to design,
develop and produce them. AROS
Research Centre is at the cutting
edge when it comes to the
synthesis and analysis of cooling
systems through the use of software
for thermal analysis based on
computational fluid dynamics and
infrared cameras. This is just one
example of how AROS engineers
and technicians use state of the art
computer-aided technologies to
make AROS solutions increasingly
competitive, not only in terms of
performance and respect for the
environment, but also as regards
reducing operational costs.
AROS uses thermal analysis to
study how the cooling properties
inside a device change by
modifying parameters such as
the size and footprint of heat
dissipators, the type and
position of the fans, deflectors
and ventilation grids, and by
eliminating the critical areas
(caused by the recirculation or
stagnation of air at high
temperatures within the UPS).
All this to achieve uniform
ventilation, significantly
increasing the safety and
performance of the system while
retaining its compact size.
Quality not only as an objective but also as an indispensable condition for
every product: this is AROS.
Quality
Millions of users believe in AROS
because AROS believes in excellence.
Quality not only as an objective but
also as an indispensable condition
for every product: this is the creed
that AROS abides by and which is
centred around the certification of
its quality system. AROS is certified
UNI EN ISO 9001:2000 for the
design and development,
manufacture, sales and after-sales
service of its products. This
certification guarantees stringent
and constant control of its
corporate processes. The result is
not just higher product quality and
reliability but also a philosophy
focused on understanding
customers’ present and future
requirements, complying with their
requests and aiming to exceed their
expectations.
With so much trade taking place
across borders, conformity
assessment has become an
important component of the
world economy.
Before they are put on the
market, all AROS products are
subjected to testing for
conformance with specifications
complying with ISO 9001:2000
standards.
For AROS, a product is not technologically complete unless it
“incorporates” a level of support that resolves users’ problems.
Service
The service rendered to customers
every day makes AROS a partner.
For AROS, a product is not
technologically complete unless it
“incorporates” a level of support
that resolves users’ problems. High
resolution capacity, low intervention
times: this formula has been one of
the keys to its success on the
domestic and worldwide markets.
A formula that finds concrete
application in services such as
PowerNetGuard, the remote
support service that remotely
manages and controls the UPS 24
hours a day. Choosing AROS
means being able to connect online with the Control centre, being
informed in real time on the status
of the UPS and obtaining immediate
action in emergencies. AROS
combines this advanced service for
its users with training activities for
technical and commercial
operators, on its own premises or
at the customer’s site.
With a highly trained team,
UPService provides a reliable
and technical support and aftersales service.
The purpose of our ATI personnel is to give advice on the relevant
standards affecting AROS UPS, installations, batteries and applications.
Technical information
AROS Technical Information (ATI)
AROS offers the on-line pre-sales
support to distributors, installers,
consultants and end customers
providing information on:
• Standard products - giving
detailed technical specifications
and helping its customer to
choose the right configuration
using the Aros software package;
• Applications - providing
assistance in choosing the right
products;
• Customer solutions - supplying
non standard products designed
to match the customer
specifications;
• Batteries - guiding the users to
choose the right battery type and
configuration;
• Installations - furnishing detailed
drawings and solving any doubt
about the installation;
• Standards - offering consultancy
on standards applicable to its
product range;
• Training - organizing sales training
and products presentations to
distributors or end customers.
ATI information is provided in
form of technical specifications,
installation manuals and
software packages for UPS
sizing.
Index
Uninterruptible
Power Supplies (UPS)
Power problems
Technical standards
Types of Uninterruptible Power Supply (UPS)
Evaluation parameters
Power quality and mains disturbance
UPS range summary
UPS options
UPS range summary: RACK version
Options for UPS RACK version
Rapido
Alfa / Alfa Plus
Pc Planet
Syncro
Spring
Spring Rack
Sentinel 6
Sentinel 6 Rack
Sentinel XR
Sentinel XR Plus
Flexus
Sentry Multistandard
Sentry HPS
Sentry MPS – Three Phase Output
Sentry MPS-HP
Sentry MPS – Single Phase Output
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
Frequency converter
Sentry MPS FC 400 Hz
p. 84
Multi-Switch
IRMS (Intelligent Redundant Multi-Switch)
p. 86
Static Transfert Switch (STS)
Sentry STS
p. 88
Accessories
Software and accessories for total reliability
in controls and communication
By-pass accessories
p. 92
p. 100
CSS Configurations
Standby Power Systems
p. 102
Stabilisers
Voltronic 4 single-phase
Voltronic 4 three-phase
ELC Line Conditioners
RQ
Tristab-T
Tristab-Y
p.
p.
p.
p.
p.
p.
p.
CSS
Stabilisers
14
15
16
18
19
20
22
24
25
26
28
30
32
34
36
38
40
42
48
52
60
66
72
78
82
104
106
108
110
112
114
116
13
Power problems
BLACKOUT,
VOLTAGE DISTURBANCES
Blackout, voltage disturbances 45%
Why an Uninterruptible Power Supply?
Data centres, servers, LAN nodes and telecommunication systems
must always be protected against possible problems in the power
supply. Sudden blackouts and variations in the mains supply may lead
to system malfunctions and severe data losses. But even other
electrical equipment can cause damage or inconvenience if there is a
breakdown in the mains. Just think of the check-out systems in a
supermarket, lighting systems and industrial production units, not to
mention safety systems, pumping systems and automatic devices in
general.
Other 55%
Power problems are caused
by various sources such as
distribution network faults,
system switching, weather
and environmental
conditions, heavy equipment
or simply just faulty
maintenance.
The simplest and most effective way of coping with these
disturbances is to install a UPS unit (UPS stands for Uninterruptible
Power Supply). Acting as an interface between the mains and the
loads, the UPS guarantees the continuity and the quality of the
electrical power supplied to the loads, whatever the condition of the
mains may be. In fact these systems stabilise the voltage perfectly,
eliminating all disturbances.
They even supply voltage when the mains fails, by means of a series
of batteries which give a back up time that is generally sufficient to
guarantee the safety of persons and of the system.
In order to decide which type of appliance is able to guarantee the
best level of protection, you must know the types of mains problems
that can disturb your systems.
TYPE OF MAINS DISTURBANCES
Peaks
Overvoltage
+15%
Nominal
voltage
-15%
Undervoltage 85%
Undervoltage
Peaks 8%
Blackout 6%
0V
Blackout
Overvoltage 1%
14
CEI, CENELEC and IEC are
the recognized
standardization bodies
respectively at national,
European and international
level. Such standardization
guarantees the compliance
with CE Directives.
Technical Standards
Safety
EN 62040-1-1 is the reference standards regulating the basic safety
requirements for UPS used in operator access areas.
EN 62040-1-2 is the reference standards regulating general and
safety requirements for UPS used in restricted access locations.
Electromagnetic Compatibility
This is the capacity of equipment to work without being disturbed
(immunity) and without disturbing (emission) other equipment due to
electromagnetic disturbances on electric wires and irradiated.
EN 50091-2 and IEC 62040-2 are the reference standards which also
defines the testing procedures.
Performances
The reference document is the Performance Requirements
EN 62040-3. It is a guide for a better understanding between
manufacturer and user since it defines which performance must be
declared as well as the relevant testing methods.
All AROS UPS’s have been designed and built in accordance with all
the above standards and therefore bear the
mark.
15
Types of Uninterruptible Power Supply
(UPS)
On-Line Uninterruptible
Power Supply (VFI)
On this type of UPS, also known as
a double conversion UPS, the
inverter draws its power continuously
from the rectifier (converter). The
current is completely regenerated by
its transformation from AC to DC and
back to AC, guaranteeing a constant
level of quality, regardless of
disturbance on the mains power
source.
By carrying out continuous double
conversion, an On-Line UPS
significantly attenuates electrical
noise, which might otherwise
damage a computer. When the AC
input supply is not within the voltage
and frequency tolerances, the battery
is used to power the inverter. The
inverter continually supplies the
critical load with a true sinewave
current.
If a converter/inverter failure occurs,
the continuity of the load power can
be improved by activating the bypass
source using a transfer switch.
Static switch
Bypass
A.C. input
Inverter
Rectifier
A.C. output
A.C. input
Battery
normal mode
battery mode
by pass mode
16
Types of Uninterruptible Power Supply
(UPS)
Line Interactive
Uninterruptible
Power Supply (VI)
On this type of UPS the inverter is
connected in parallel to the AC input
and also charges the battery (interactive
operation in reversible mode).
When the AC input supply is not within
strict amplitude and frequency
tolerances, the load is powered by the
inverter through the battery.
The normal inverter output waveform is
a stepwave or squarewave.
This technique is rarely used for high
power ratings as frequency regulation is
not possible. Active Standby (or Line
Interactive) technology is a recent
development made possible by the
advent of microprocessors. The UPS is
fully controlled by a microprocessor
which monitors the quality of the mains
power supply and reacts to any
variations. In the event of a power
problem, the UPS transfers the load to
the batteries to supply stabilised power.
It is increasingly frequent to add a
voltage compensation circuit, called a
“booster”, that is enabled in the event of
prolonged voltage drops.
Passive Standby
Uninterruptible
Power Supply
(Off-line) (VFD)
This type of UPS, also called Off-line
UPS, is connected in parallel to the
normal AC source. The current is filtered
in order to attenuate the most frequent
forms of disturbance. In the event of a
power problem the UPS transfers the
load to the batteries to supply stabilised
power: the inverter only switches on
when the mains fails or fluctuates
outside the input voltage tolerances of
the EMI filter or if it is fitted with
Automatic Voltage Stabiliser (AVS).
Static switch
Bypass
A.C. input
Automatic Voltage Regulator
A.C. output
AVR
A.C. input
Inverter
Battery
normal mode
battery mode
by pass mode
Static switch
Bypass
A.C. input
A.C. output
Inverter
Battery charger
A.C. input
Battery
normal mode
battery mode
17
Evaluation parameters
Apparent power (in VA or kVA)
It is defined as:
PAPP =VX I
for single-phase load
Crest Factor
A linear load absorbs a sinewave
current that shows an effective value
(IEFF usually measured and declared)
and a peak value (IPK). The Crest
Factor value is defined as:
PAPP = V x I x √3
for three-phase loads
where V is the load voltage supply
and I is the current absorbed by the
load in normal load conditions.
This information is normally shown on
documents and/or load nameplates
though it may be shown as an
oversized value.
Active power (in W or kW)
It is defined as:
kW = kVA x cosϕ
(where cosϕ means power factor PF).
The cosϕ value of loads is very
seldom indicated, therefore a correct
UPS sizing requires measurements
of kVA absorbed by loads.
Experience, anyway, shows that
typical loads of computer feature a
PF between 0,65 and 0,8.
Considerations on the
misleading concept of
“computer power”
In the definition of the UPS rated
power, the parameter values, defined
as “computer power”, “switching
power”, “actual power”, power a
particular temperature value, etc. are
sometimes indicated.
Such arbitrary parameter values have
no relation with apparent power and
active power; they can be neither
quantified nor defined and therefore
must not be used for the correct
sizing of the UPS.
CF =
IPK
IEFF
The nominal value for a linear load is
CF = 1,41. Most loads applied to
UPS’s are non- linear load: they
absorb distorted current with a CF
value greater than 1,41 and require
therefore higher peak currents thus
resulting in an increased distortion of
the output voltage than equivalent
linear loads. Directive EN62040-3,
indicates a typical non-linear load as
CF=3, used for UPS testing, which
may be used in the absence of other
data.
Overload
Overloads are temporary requests
from electrical equipment which
exceed regular operation absorption.
They are caused by current peaks
which may occur when one or more
users are switched on. In case the
overload exceeds the admissible
limits the UPS guarantees the energy
supply via the automatic bypass line.
For “On line” UPS’s the transfer is
effected without any break in power
(transfer time = 0 ms). The “bypass”
is a safety device with independent
protection and auxiliary supply able
to supply the load independently
from the UPS also when the UPS is
switched off or broken.
The harmonics level of AROS UPS's
complies with the present directive.
Howerver, in order to further reduce the
presence of these harmonics variuos
solutions are available such as the
installation of Active Filetrs (Power
Factor Controlled) or different Rectifier
designs.
Runtime
The batteries supplied with the UPS’s
are valve regulated batteries (VRLA)
known as sealed batteries with no
electrolyte top-up, very low gas
emission, suitable for installations in
offices and public places with no need
for special precautions. Batteries are
normally supplied with the UPS and
can either be installed in the same
cabinet or in additional ones. AROS
guarantees the power supply runtimes
specifying the apparent load power and
the power factor.
Remarks about the misleading
concept of “typycal autonomy”
In defing the runtime it is often used the
concept “typical autonomy (or runtime)”
which has nothing to do with the real
runtime based on the 100% load value
expressed in W or kW (active power).
The runtime that AROS shows on all its
documentation have been calculaterd
at 100% of the load.
Input current harmonics
The UPS battery charger rectifier
absorbs a distorted current containing
harmonics that are multiples to the
reference 50Hz frequency. These
harmonics may cause voltage distortion
which may affect the normal operation
of non privileged user’s.
18
Power quality and mains disturbance
Electronic equipment functions
properly as long as the utility is
available and with high quality.
Unfortunately not always this is
possible because most of the power
quality events are caused by factors
beyond the control of the Distribution
Company. These factors may occur
either externally (in the network
distribution system) or internally (in
the facility when the system is
located). External causes may be for
example storm, lightning, high wind,
tree limb contact, construction
activities etc, while the internal
causes may be switching of the
machine, capacitor banks, fault or
maintenance activities.
Depending on the events the power
quality disturbances may vary in
type, duration and intensity.
Typical power supply disturbances
that cause major bad effects on your
load are listen below.
Power outage
Power interruption for a time of more
than 3s is called an outage or
commonly “blackout”. This is
normally caused by atmospheric
accidents to the high voltage
distribution network or a failure in the
power supply equipment.
Blackout
Consequences:
- Computer applications
Complete system shutdown with
loss of data, possible hardware
damage and long periods of
employee inactivity.
- Industrial applications
Huge impact in the production
activity with consequent
production loss and/or unexpected
safety consequence.
Undervoltage
It is a voltage reduction in amplitude
for a time between 10 ms to 1 s.
expressed as a percentage from 10
and 100% of the rated voltage. This
is caused for example by short
circuits in the resident distribution
systems or the large inrush current of
the transformers.
Sag and Swell
Any short term voltage decrease
(sags) or increase (swell) for a time
from half cycle to 3 seconds. It is
normally caused by the equipment
shutdown, circuit breaker operations,
high peak current absorbed by the
equipments, or short-circuit.
Undervoltage
Consequences:
- Computer applications
Overheating of the electronic
components with consequent
operational breakdown.
- Industrial applications
Instability of asynchronous motors
and loss of synchronization of
synchronous motors, opening of
contactors (voltage drop > 30%),
power-off discharge lamps (voltage
drop > 50% for 20-40 ms) with
subsequent return of power after
several minutes and consequent
operational breakdown.
Overvoltages
Overvoltage is an increase in voltage
for a time of more than 10 ms.
Overvoltages may be caused by the
disconnection of major loads
(interruption in manufacturing
processes of industrial companies,
reduction in the speed of electric
motors, arc furnaces, rolling mills,
etc.) or natural events such as
lightning.
Consequences:
The major effects may be the loss of
data or the lights flicker, very
unpleasant for the people exposed to
these effects.
Transients
Transients are rapid, very high
overvoltages of up to 20 kV. They
are caused mainly by lightning (which
is random in its location, duration
and amplitude) but also by faults on
the high-voltage network, the
switching of inductive loads or the
powering of highly capacitive loads.
Consequences:
Transients destroy inadequately
protected equipment (melting of
wires, perforation of isolation in
motors, badly-timed release of
protection devices, etc.).
Consequences:
Faults in all electric/electronic
equipment (100%<overvoltage<150%);
e.g. damage to boards, power
supplies, computers/servers, faults in
lighting systems, etc.
19
UPS range summary
RAPIDO
ALFA/ALFA PLUS
PC PLANET
SYNCRO
SPRING
SENTINEL 6
350-550VA
400-600-800VA
400-600-800
1100-1600VA
400-600-800VA
800-1000-1500
2000VA
500-800
1100-1500
2200-3000VA
700-1000-1500
2000-3000VA
Line Interactive
Line Interactive
Line Interactive
Line Interactive
Line Interactive
On line
Double conversion
Input Voltage
230V single-phase
230V single-phase
230V single-phase
230V single-phase
230V single-phase
230V single-phase
Output Voltage
230V single-phase
230V single-phase
230V single-phase
230V single-phase
230V single-phase
230V single-phase
Inveter Output transformer
–
–
–
–
–
–
Automatic bypass
–
–
–
–
–
●
Maintenace Internal bypass
–
–
–
–
–
–
Battery test
–
–
●
●
●
●
Deep Battery Discharge
protection
–
●
●
●
●
●
ECO mode operation
–
–
–
–
–
–
SMART ACTIVE operation
–
–
–
–
–
–
STAND BY - OFF
(Emergency ligthing - EN 50171)
–
–
–
–
–
–
Frequency Converter
–
–
–
–
–
●(2)
Multimodule Configuration
–
–
–
–
–
–
Input Harmonic Filter
–
–
–
–
–
–
Backfeed protection
●
●
●
●
●
●
downloading from internet
downloading from internet
● (no mod. 400)
●
●
●
RS 232 port
–
–
● (no mod. 400)
●
●
●
USB port
●
● (only Plus version)
–
–
●
–
Dry Contact
–
–
●(1)
●(1)
●(1)
❍(1)
pag. 26
pag. 28
pag. 30
pag. 32
pag. 34
pag. 38
Power Rating
Topology
Base Monitoring Software
(Watch&Save 3000)
● Standard
❍ Optional
(1)
(2)
(3)
(4)
Available only when the RS 232 port is not used for other functions
Available on option and facturing set
Only 6,5-8-10kVA
Only 3Ph input
20
SENTINEL XR
SENTINEL XR PLUS
FLEXUS
SENTRY MULTISTANDARD
SENTRY HPS
SENTRY HPS
3/3
3/1
3/3
3300-4000
5000-6000-6500(4)
8000-10000VA
5-6-6,5-8-10kVA
10-12-15-20kVA (1Ph)
10-12-15-20
30-40kVA (3Ph)
100-120kVA (3Ph)
60-80kVA
8-10-15-20-30-40
60-80-100kVA
On line
Double conversion
On line
Double conversion
On line
Double conversion
On line
Double conversion
230V single-phase
400V three-phase(3)
230V single-phase
400V three-phase(3)
230V single-phase (5)
400V three-phase (6)
230V single-phase
230V single-phase
–
SENTRY MPS
SENTRY MPS-HP
10-15-20-30-40
60-80kVA
30-40-60-80 (1Ph)
100-120-160-200
250-300-400-500
600-800kVA (3Ph)
100-120-160-200-250kVA
On line
Double conversion
On line
Double conversion
On line
Double conversion
On line
Double conversion
400V three-phase
400V three-phase
400V three-phase
400V three-phase
400V three-phase
230V single-phase (5)
400V three-phase (6)
400V three-phase
230V single-phase
400V three-phase
230V single-phase(7)
400V three-phase(8)
400V three-phase
–
on option
–
●
●
●
●
●
●
●
●
●
●
●
●
–
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
only from 30 to 100kVA
–
●
●
●
●
●
●
–
–
●
●
●
●
●
●
–
–
●
●
●
●
●
●
●
●
●
●
–
–
❍
❍
❍
❍
❍
❍
–
–
not required
Active Filter
❍
❍
–
not required
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
❍
●
–
–
–
–
–
●(1)
●
●
●
●
●
●
●
pag. 42
pag. 48
pag. 52
pag. 60
pag. 66
pag. 66
pag. 72
pag. 78
● Standard
❍ Optional
(5) From 10 to 20kVA
(6) From 10 to 40kVA
(7) Only 30-40-60-80kVA
(8) From 100kVA above
21
UPS options
RAPIDO
ALFA/ALFA PLUS
PC PLANET
(except PC-Planet 400)
SYNCRO
SPRING
SOFTWARE PACKAGES
Watch&Save 3000 (Professional Version)
▲
▲
▲
PowerNetGuard
▲
▲
▲
▲
▲
▲
COMMUNICATION OPTIONS
NetMan 101 Plus - Box (TCP/IP, SNMP, HTTP)
▲
NetMan 102 Plus - Slot (TCP/IP, SNMP, HTTP)
▲
MultiCom 301 - Box (MODBUS/JBUS)
▲
▲
▲
MultiCom 302 - Slot (MODBUS/JBUS)
▲
MultiCom 351 - Box (serial duplexer)
▲
▲
MultiCom 352 - Slot (serial duplexer)
▲
MultiCom 362 (RS232 + USB)
▲
MultiCom 372 (additional RS232 port and EPO)
▲
MultiCom 382 (Dry contact extension + EPO)
▲
MultiCom 401 (PROFIBUS)
▲
▲
▲
Multi I/O
▲
▲
▲
USB converter
▲
▲
AS/400 Interface
▲
▲
▲
▲
▲
OTHER OPTIONS
External Battery temperature sensor
Display Remote Monitor panel
Maintenance Bypass cabinet
IRMS
Input isolation transformer
Graphic Remote Panel
▲
▲
▲
▲
▲
on request
on request
on request
on request
on request
▲
▲
▲
▲ Option available
22
SENTINEL 6
SENTINEL XR
SENTINEL XR PLUS
FLEXUS
SENTRY
MULTISTANDARD
SENTRY HPS
SENTRY MPS
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
on request
▲
▲
▲
▲
▲
SENTRY MPS-HP
▲
▲
▲
▲
▲
up to 4kVA
▲
▲
▲
▲
▲
▲
▲
▲
on request
on request
on request
▲
on request
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲ Option available
23
UPS range summary: rack version
SPRING RACK
SENTINEL 6 RACK
SENTINEL XR RACK
500-800-1100-1500-2200-3000VA
700-1000-1500-2200-3000VA
3300-4000-5000-6000-6500(4)
8000-10000VA
Line Interactive
On line
Double conversion
On line
Double conversion
Input Voltage
230V single-phase
230V single-phase
230V single-phase
400V three-phase(3)
Output Voltage
230V single-phase
230V single-phase
230V single-phase
Inveter Output transformer
–
–
–
Automatic bypass
–
●
●
Maintenace Internal bypass
–
–
–
Battery test
●
●
●
Deep Battery Discharge protection
●
●
●
ECO mode operation
–
–
●
SMART ACTIVE operation
–
–
●
STAND BY – OFF (Emergency ligthing – EN 50171)
–
–
●
Frequency Converter
–
●
●
only 2200 and 3000VA
●(2)
●
Backfeed protection
●
●
●
Base Monitoring Software (Watch&Save 3000)
●
●
●
RS 232 port
●
●
●
USB port
●
–
●
●(1)
●(1)
●(1)
pag. 36
pag. 40
Power Rating
Topology
Battery expansion capability
Dry Contact
● Standard
❍ Optional
(1)
(2)
(3)
(4)
pag. 42
Available only when the RS 232 port is not used for other functions
Function on request and set by the factory
Only 6,5-8-10kVA
Only 3Ph input
24
Options for UPS rack version
SPRING RACK
SENTINEL 6 RACK
SENTINEL XR RACK
Watch&Save 3000
▲
▲
▲
PowerNetGuard
▲
▲
▲
Netman 101 Plus - Box (TCP/IP, SNMP, HTTP)
▲
▲
▲
Netman 102 Plus - Slot (TCP/IP, SNMP, HTTP)
▲
▲
▲
MultiCom 301 - Box (MODBUS/JBUS)
▲
▲
▲
MultiCom 302 - Slot (MODBUS/JBUS)
▲
▲
▲
MultiCom 351 - Box (serial duplexer)
▲
▲
▲
MultiCom 352 - Slot (serial duplexer)
▲
▲
▲
MultiCom 362 (RS232 + USB)
▲
▲
MultiCom 372 (additional RS232 port and EPO)
▲
▲
MultiCom 382 (Dry contact extension + EPO)
▲
▲
MultiCom 401 (PROFIBUS)
▲
▲
▲
Multi I/O (Site Monitoring and Alarm configuration)
▲
▲
▲
▲
▲
▲
▲
SOFTWARE PACKAGES
COMMUNICATION OPTIONS
USB converter
AS400 Interface
▲
▲
Modem GSM
OTHER OPTIONS
Graphic Remote Panel
▲
▲
▲
External bypass cabinet rack 16A
▲
▲
up to 4kVA
IRMS
▲
▲
▲
▲ Option available
25
Rapido
The RAPIDO range is the ideal solution
for small office and home systems
(SOHO) requiring over voltage and
mains failure protection. The
compactness, versatility (a push-button
switch with LED-based mimic panel
and user-replaceable batteries) and
functionality of the RAPIDO allow it to
easily fit into any small office and home
environment.
When the mains fails, connected loads
are powered with a pseudo sine wave
supply from the inverter. For additional
security users can download a version
of the Watch&Save 3000 UPS
monitoring and control software.
LOAD CONFIGURATOR
Load type
Power (VA)*
Personal computer
250
LCD Monitor
70
15” Monitor
150
Scanner, printer
200
Modem, TV, DVD reader,
PlayStation, Hi-Fi,
Phone, Fax
50
Laser printer**
200
CHARACTERISTICS
• Maximum compactness
• 3 sockets with mains fail protection
• 1 socket with filtering for powering
loads such as laser printers
• Integrated protection for telephone
line/modem
• Cold start capability: the UPS can
power up without a mains supply
present
• User replaceable batteries
• USB interface
• Can be placed on a desktop, floor or
be wall-mounted
• Input supply and telephone cable
included
• Short-circuit protection
• Auto restart (on mains return, after
batteries have discharged)
• GS/TÜV marks
• Available with French (2P+T), UK or
Schuko sockets
ADVANCED COMMUNICATION
• Watch&Save 3000 monitoring and
shut-down software for Windows
2008, Vista, 2003, XP, Linux, Mac
OS X and Sun Solaris
• Plug and Play function
APPLICATIONS
• Personal computers
2-YEAR WARRANTY
AVAILABLE SOCKETS
FRENCH
SOCKET
ITALIAN/
SCHUKO
SOCKET
BRITISH
SOCKET
*Average estimated value.
**Use the Rapido filtered power output.
26
Rapido
Technical data
Models
Rapido 350
Rapido 550
Power
350VA/225W
550VA/335W
Input
Rapido 350
Rapido 550
Rated voltage
230 Vac
Voltage range
188-262 Vac
Frequency
50/60 Hz
Output
Rapido 350
Voltage on mains operation
Rapido 550
230 Vac
Frequency on battery operation
50 or 60 Hz
Waveform on battery operation
Pseudo sinewave
Batteries
Rapido 350
Type
Rapido 550
Maintenance-free lead-acid VRLA, AGM
Recharge time
6-8 h
System
Rapido 350
Weight (kg)
3
Dimensions (wdh) (mm)
Rapido 550
3.1
120x320x88
Tel. protection
RJ11/J45 connectors
Communication
On USB interface
Safety compliance
EN 62040-1-1 and Directive 2006/95/EC; EN 62040-3
EMC conformance
EN 62040-2 and Directives 2004/108EC
Marks
CE; GS/TÜV
Operating temperature
O °C / +40 °C
Colour
Graphite grey
Altitude and relative humidity
6000 meters max. elevation, <95% non condensing
Accessories provided
1 input supply cable, telephone cable
Details
Sockets with UPS protection
(no break in power if mains fails)
USB communication port
Filtered socket: overvoltage protection only
Phone/modem protection
Mains input
27
Alfa/Alfa Plus
The Alfa series is available in 400 to
1600VA models and has been
designed to protect PCs and critical
peripherals in home and small office
environments.
Alfa is easy to install and provides
powerful, economic protection for:
IT equipment including PCs, Media
Centers, PoE, Voip and other such
peripherals, TVs, Home Cinemas,
Satellite and Digital Terrestrial receivers,
DVD readers and writers, Modems and
xDSL routers, Small household
appliances.
ADVANCED COMMUNICATION
APPLICATIONS
• Maximum power protection with
Watch&Save 3000 monitoring and
shutdown software available for free
download from our website
www.aros.it.
• It is suitable for installation on PC's
running Windows 2008, Vista, 2003,
XP; Linux, Mac OSX and the Sun
Solaris operating system.
• IT equipment including PCs Media
Centers, PoE, Voip and other such
peripherals
• TVs, Home Cinemas, Satellite and
Digital Terrestrial receivers, DVD
readers and writers
• Modems and xDSL routers
• Small household appliances
2-YEAR WARRANTY
CHARACTERISTICS
• Compact dimensions and ergonomic
design: Alfa can be placed on a desk
top or other convenient location, with
easy to access connections and
informative front panel.
• Front panel LCD display ( Plus
version only) providing status, load
and battery information and LEDs
(standard version).
• Silent running: Alfa can be used to
protect other sensitive electronic
devices including Home Cinemas,
CD Writers, DVD players, Satellite
and Digital Terrestrial receivers.
28
Alfa/Alfa Plus
Models
Power
Input
Technical data
Alfa 400
Alfa 600
Alfa 800
AlfaP 400 AlfaP 600 AlfaP 800 AlfaP1100 AlfaP1600
400VA/240W 600VA/360W 800VA/480W 400VA/240W 600VA/360W 800VA/480W 1100VA/660W 1600VA/960W
Alfa 400
Alfa 600
Alfa 800
AlfaP 400 AlfaP 600 AlfaP 800 AlfaP1100 AlfaP1600
Rated voltage
220-240 Vac
Voltage range
230 Vac (+20/-25%)
Frequency
50/60 Hz auto sensing
Output
Alfa 400
Alfa 600
Alfa 800
AlfaP 400 AlfaP 600 AlfaP 800 AlfaP1100 AlfaP1600
Voltage on mains operation
230 Vac (+/-15%)
Frequency on battery operation
50 or 60 Hz (+/-1%)
Voltage on battery operation
Batteries
230 Vac (+/-10%)
Alfa 400
Alfa 600
Alfa 800
Type
AlfaP 400 AlfaP 600 AlfaP 800 AlfaP1100 AlfaP1600
Maintenance-free lead-acid VRLA, AGM
Recharge time
System
6-8 h
Alfa 400
Weight (kg)
Alfa 600
Alfa 800
AlfaP 400 AlfaP 600 AlfaP 800 AlfaP1100 AlfaP1600
3
3.2
Dimensions (wdh) (mm)
3.4
6.6
90x232x192
Tel. protection
7
97x315x275
RJ11/J45 connectors
Communication
n.a.
Output sockets
4 IEC
USB
4 IEC or 3 Shuko/Italian or 3 french
Safety compliance
EN 62040-1-1 and Directive 2006/95/EC, EN 62040-3
EMC conformance
EN 62040-2 and Directives 2004/108 EC
Operating temperature
6 IEC or 4 Shuko/Italian or 4 french
O °C / +40 °C
Colour
Dark grey (RAL 7016)
Altitude and relative humidity
6000 meters max. elevation, <95% non condensing
Accessories provided
2 output supply cables (IEC version), 1 USB cable (Plus version), user guide
Details
Phone/modem
protection
Sockets with UPS protection
(no break in power if mains
fails)
USB
communication
port
Filtered sockets:
overvoltage
protection only
Mains input
Alfa
400-600-800
Alfa Plus
400-600-800
Alfa Plus
1100-1600
29
PC Planet
The PC PLANET series includes the
400-600-800VA models and uses
digital technology. The load is powered
from the mains through an AVR to
stabilise brownout, sag and surge
voltages, and EMI filters to suppress
spikes and transients. When the mains
fails, the load is powered by the inverter
with a pseudo sinewave to provide
sufficient runtime for computer system
shutdown using the Watch&Save 3000
software supplied as standard.
CHARACTERISTICS
ADVANCED COMMUNICATION
• Mains power supply stabilisation and
filtering (technology with AVR and
filters for atmospheric disturbance
suppression)
• Cold start capability: the UPS can
power up without a mains supply
present
• High reliability with built-in battery test
feature
• Supplied with 2 output cables
• Advanced, multi-platform
communication for all operating
systems and network environments:
Watch&Save 3000 monitoring and
shut-down software included, for
Windows 2008, Vista, 2003, XP;
Mac OS X, Linux and the Sun Solaris
operating system
• Standard USB interface
APPLICATIONS
• Personal computers
• Small computers network
2-YEAR WARRANTY
30
PC Planet
Technical data
Models
Power
Input
PC Planet 400
PC Planet 600
PC Planet 800
400VA/240W
600VA/360W
800VA/480W
PC Planet 400
PC Planet 600
PC Planet 800
Rated voltage
220-240 Vac
Voltage range
230 Vac (+20/-26%)
Frequency
50/60 Hz auto sensing
Output
PC Planet 400
PC Planet 600
Voltage on mains operation
230 Vac (-8%, +10%)
Voltage on battery operation
230 Vac (± 5%)
Frequency on battery operation
50 or 60 Hz (± 0.5%)
Waveform on battery operation
Pseudo sinewave
Batteries
PC Planet 400
Type
PC Planet 600
PC Planet 800
PC Planet 800
VRLA AGM Maintenance-free lead-acid
Recharge time
6-8 h
System
PC Planet 400
Weight (kg)
PC Planet 600
PC Planet 800
5.8
Dimensions (wdh) (mm)
6.2
110x325x152
Communication
USB
Safety compliance
EN 62040-1-1 and Directive 2006/95/EC, EN 62040-3
EMC conformance
EN 62040-2 and Directives 2004/108 EC
Operating temperature
O °C / +40 °C
Colour
Dark grey (RAL 7016)
Altitude and relative humidity
6000 meters max. elevation, <95% non condensing
Accessories provided
2 output supply cables, communication software, user guide
Details
USB
Mains input
Output sockets
31
Syncro
The SYNCRO series includes the 8002000VA models and uses digital
technology. The load is powered from
the mains through an AVR to stabilise
brownout, sag and surge voltages, and
EMI filters to suppress spikes and
transients.
When the mains fails, the load is
powered by the inverter with a pseudo
sinewave to provide sufficient runtime
for computer system shutdown using
the Watch&Save 3000 software
supplied as standard. The UPS also
incorporates a filtered socket for PC
network and telephone line cable
protection.
CHARACTERISTICS
ADVANCED COMMUNICATION
• Mains power supply stabilisation and
filtering (technology with AVR and
filters for atmospheric disturbance
suppression)
• Cold start capability: the UPS can
power up without a mains supply
present
• Auto restart at power-up
• Integrated protection for PC networks
and telephone line/modem
connections RJ11/45
• High reliability with built-in automatic
battery test feature
• Advanced, multi-platform
communication for all operating
systems and network environments:
Watch&Save 3000 monitoring and
shut-down software included for
Windows 2008, Vista, 2003, XP;
Mac OS X, Linux, Novell and most
popular Unix operating systems.
• The UPS is supplied with a
communications cable for Plug and
Play PC connection
APPLICATIONS
• Personal computers
• Small computers network
2-YEAR WARRANTY
For advanced communication and top
flight performance, SYNCRO is the
ideal solution for small network users
requiring total control of their power
system.
32
Syncro
Technical data
Models
Power
Input
Syncro 800
Syncro 1000
800VA/480W
1000VA/600W
Syncro 800
Syncro 1000
Syncro 1500
Syncro 2000
1500VA/900W
2000VA/1200W
Syncro 1500
Syncro 2000
Rated voltage
220-230-240 Vac
Voltage range
230 Vac (±25%)
Frequency
50/60 Hz auto sensing
Output
Syncro 800
Syncro 1000
Syncro 1500
Voltage on mains operation
230 Vac (-8%, +10%)
Voltage on battery operation
230 Vac (± 5%)
Frequency on battery operation
Syncro 2000
50 or 60 Hz (± 0.5%)
Transfer time
2 ms
Waveform on battery operation
Pseudo sinewave
Batteries
Syncro 800
Type
Syncro 1000
Syncro 1500
Syncro 2000
Maintenance-free lead-acid VRLA, AGM
Recharge time
4-6 h
System
Syncro 800
Weight (kg)
Syncro 1000
Syncro 1500
14.5
15
14
Dimensions (wdh) (mm)
140x375x180
Protection
Battery low - overcurrent - short-circuit
Tel/Modem protection
Syncro 2000
20
140x410x214
RJ11/RJ45 connectors
Communication
RS232 port
Safety compliance
EN 62040-1-1 and Directive 2006/95/EC, EN 62040-3
EMC conformance
EN 62040-2 and Directive 2004/108 EEC
Surge capability
IEC 801-5
Noise
< 40 dBA at 1 m
Colour
Dark grey (RAL 7016)
Operating temperature
0 °C / +40 °C
Storage temperature
-15 °C / +45 °C
Relative humidity
< 95% non condensing
Details
Serial interface
port
Telephone line/
modem protection
Output sockets
Mains input
Syncro 800-1000-1500
Syncro 2000
33
Spring
The SPRING series includes models
from 500VA to 3000VA and uses
sinewave digital technology.
The SPRING range, with its advanced
communications and connectivity
options, is the ideal solution for the
most demanding of customers looking
for superior protection and versatility.
SPRING is the best protection for
network devices, rack mounted
servers, conventional rack-mounted or
tower servers, network storage
systems.
VERY HIGH PROTECTION
An Automatic Voltage Regulation
provides stabilisation from brownouts,
sag and surge voltages. EMI filters then
provide further protection from spikes
and transients.
When the mains power supply fails, the
load is powered by the inverter and
receives a true SINEWAVE supply for
maximum power continuity and
reliability.
The UPS also incorporates a protection
for PC and network, telephone
line/modem connections (RJ45-RJ11).
HIGH AVAILABILITY
ADVANCED COMMUNICATION
Powershare output socket provides the
load-shedding of the least critical load
to maximise the back up time of the
most critical servers.
Hot Swappable battery from the front of
the UPS allows easy and no-risks
maintenance of the UPS.
Additional Battery Box and extended
charging current are available in
2200RT and 3000RT for very long
back up time applications.
Predictive battery testing to spot
potential battery deterioration and
failure. Deep discharge protection to
reduce overall battery aging.
• Advanced, multi-platform
communication for all operating
systems and network environments:
Watch&Save 3000 monitoring and
shut-down software included for
Windows 2008, Vista, 2003, XP;
Mac OS X, Linux, Novell and most
popular Unix operating systems.
• USB or RS232 serial port (selectable)
• Slot-in SNMP network adapter card
• LCD Display
VERSATILITY
Spring (2200RT and 3000RT) can be
placed directly onto the floor or
mounted in 19’’ rack mount cabinets.
The front panel digital display can be
easily pulled out and rotated to suit the
installation format.
Tower and Rack versions includes
Emergency Power Off switch, which
allows to shutdown the output power in
case of emergency situations.
Cold start function enables Spring to
start up when power network is not
available.
APPLICATIONS
• Personal computers
• Small computers network
• Local Area Networks (LAN)
• Workstations
• Servers
• EPOS (Electronic Point Of Sales)
system
2-YEAR WARRANTY
OPTIONS
Battery box
(only 2200RT/3000RT)
34
Spring
Models
Power
Input
Technical data
S 500T
S 800T
S 1100T
500VA/350W
800VA/540W
1100VA/740W
S 1500T
S 500T
S 800T
S 1100T
S 2000T
S 1500T
S 2000T
Rated voltage
230 Vac (selectable 200, 208, 220, 240V)
Voltage range
160 V - 294 V
Frequency
S 2200RT
S 3000RT
S 2200RT
S 3000RT
S 2200RT
S 3000RT
± 5%
S 500T
S 800T
S 1100T
Rated voltage
S 1500T
S 2000T
230 Vac (selectable 200, 208, 220, 240V)
Frequency
50 or 60 Hz auto sensing
Waveform
True sinewave
Batteries
S 3000RT
50/60 Hz auto sensing
Frequency range
Output
S 2200RT
1500VA/1050W 2000VA/1350W 2200VA/1540W 3000VA/2100W
S 500T
S 800T
S 1100T
Type
S 1500T
S 2000T
VRLA AGM Maintenance-free lead-acid
Recharge time
4-6 h
System
S 500T
S 800T
S 1100T
S 1500T
S 2000T
S 2200RT
S 3000RT
Weight (kg)
7,2
10,6
11
18
18,4
31
32,8
1 (10A)
1 (10A)
1 (10A)
1 (10A)
4 (10A)
4 (10A)
4 (10A)
4 (10A)
Dimensions (wdh) (mm)
110x383x235
IEC mains input plug
1 (10A)
IEC output sockets
4 (10A)
Protection
160x425x235
88x582x438
1 (16A)
1 (16A)
8 (10A) - 1 (16A)
Overload - short-circuit - overvoltage - undervoltage - temperature - low battery
Communication
USB / RS232 / slot for interface communication
Safety compliance
IEC / EN62040-1-1 and Directive 2006/95/EC
EMC conformance
IEC / EN62040-2 and Directive EEC 2004/108
Performance
IEC / EN62040-3
Operating temperature
0 °C / + 40 °C
Storage temperature
-15 °C - 45 °C
Relative humidity
< 95% non condensing
Noise
< 50 dBA
Colour
Dark grey (RAL 7016)
Details
USB port
Serial
interface
port RS232
Telephone/
it network
protection
Mains
input IEC
S 500T-800T-1100T
Slot for SNMP
network
adapter card
Output
sockets
IEC
Powershare
socket
S 1500T-2000T
35
Spring Rack
The SPRING series includes models
from 500VA to 3000VA and uses
sinewave digital technology.The
SPRING range, with its advanced
communications and connectivity
options, is the ideal solution for the
most demanding of customers looking
for superior protection and versatility.
SPRING is the best protection for
network devices, rack mounted
servers, conventional rack-mounted or
tower servers, network storage
systems.
VERY HIGH PROTECTION
An Automatic Voltage Regulation
provides stabilisation from brownouts,
sag and surge voltages. EMI filters then
provide further protection from spikes
and transients.
When the mains power supply fails, the
load is powered by the inverter and
receives a true SINEWAVE supply for
maximum power continuity and
reliability.
The UPS also incorporates a protection
for PC and network, telephone
line/modem connections (RJ45-RJ11).
HIGH AVAILABILITY
ADVANCED COMMUNICATION
Powershare output socket provides the
load-shedding of the least critical load
to maximise the back up time of the
most critical servers.
Hot Swappable battery from the front of
the UPS allows easy and no-risks
maintenance of the UPS.
Additional Battery Box and extended
charging current are available in tower
2200 and 3000 for very long back up
time applications.
Predictive battery testing to spot
potential battery deterioration and
failure.
Deep discharge protection to reduce
overall battery aging.
• Advanced, multi-platform
communication for all operating
systems and network environments:
Watch&Save 3000 monitoring and
shut-down software included for
Windows 2008, Vista, 2003, XP;
Mac OS X, Linux, Novell and most
popular Unix operating systems.
• USB or RS232 serial port (selectable)
• Slot-in SNMP network adapter card
• LCD Display
VERSATILITY
Spring RT (tower 1500, 2200 and
3000) can be placed directly onto the
floor or mounted in 19’’ tower mount
cabinets.
The front panel digital display can be
easily pulled out and rotated to suit the
installation format.
Tower and rack versions includes
Emergency Power Off switch, which
allows to shutdown the output power in
case of emergency situations.
Cold start function enables Spring to
start up when power network is not
available.
APPLICATIONS
• Personal computers
• Small computers network
• Local Area Networks (LAN)
• Workstations
• Servers
• EPOS (Electronic Point Of Sales)
system
2-YEAR WARRANTY
OPTIONS
Battery box
(only 2200RT/3000RT)
36
Spring Rack
Models
Power
Input
Technical data
S 500R
S 800R
S 1100R
500VA/350W
800VA/540W
1100VA/740W
S 1500RT
S 500R
S 800R
S 2200RT
1500VA/1050W 2200VA/1540W
S 1100R
S 1500RT
Rated voltage
230 Vac (selectable 200, 208, 220, 240V)
Voltage range
160 V - 294 V
Frequency
S 3000RT
3000VA/2100W
S 2200RT
S 3000RT
S 2200RT
S 3000RT
S 2200RT
S 3000RT
50/60 Hz auto sensing
Frequency range
± 5%
Output
S 500R
S 800R
Rated voltage
S 1100R
S 1500RT
230 Vac (selectable 200, 208, 220, 240V)
Frequency
50 or 60 Hz auto sensing
Waveform
True sinewave
Batteries
S 500R
S 800R
S 1100R
Type
S 1500RT
VRLA AGM Maintenance-free lead-acid
Recharge time
4-6 h
System
S 500R
S 800R
S 1100R
S 1500RT
S 2200RT
S 3000RT
Weight (kg)
12
13,5
15,6
28,7
31
32,8
Dimensions (wdh) (mm)
19” x 460 x 1U
19” x 460 x 1U
19” x 460 x 1U
19” x 582 x 2U
19” x 582 x 2U
19” x 582 x 2U
IEC mains input plug
1 (10A)
1 (10A)
1 (10A)
1 (10A)
1 (16A)
1 (16A)
IEC output sockets
4 (10A)
4 (10A)
4 (10A)
8 (10A)
Protection
8 (10A) - 1 (16A)
Overload - short-circuit - overvoltage - undervoltage - temperature - low battery
Communication
USB / RS232 / slot for interface communication
Safety compliance
IEC / EN62040-1-1 and Directive 2006/95/EC
EMC conformance
IEC / EN62040-2 and Directive EEC 2004/108
Performance
IEC / EN62040-3
Operating temperature
0 °C / + 40 °C
Storage temperature
-15 °C - 45 °C
Relative humidity
< 95% non condensing
Noise
< 50 dBA
Colour
Dark grey (RAL 7016)
Details
Output
sockets IEC
S 500R-800R-1100R
S 1500R
Output
sockets IEC
Powershare
socket
Mains input IEC
Powershare
socket
USB
Serial
port
interface
port RS232
EPO
Thermal
fuses
Output
sockets IEC
Telephone/it network
protection
S 2200R-3000R
Battery expansion
connector
Output sockets
IEC 16A
37
Sentinel 6
The SENTINEL 6 series includes the 7001000-1500-2000-3000VA models and
uses double conversion technology (VFI).
The load is powered continuously by the
inverter with an EMI filtered, stabilised and
regulated sinewave supply. The input and
output EMI filters considerably increase
the immunity of the load to mains
disturbances and surges, even on
bypass.
The UPS can power the load for long
periods (using battery extension packs) or
provide sufficient runtime to allow shutdown of the protected systems using the
Watch&Save 3000 software, supplied as
standard.
For outstanding power protection and
communication SENTINEL 6 is the best
solution for sensitive and “mission-critical”
applications.
SENTINEL 6 POWER models are
supplied with a larger internal
charger and with their matching
external battery extension packs
can achieve long back up times.
OPTIONS
Extended runtime solutions
(except 700VA)
Isolation transformer box (wdh) mm
• S6-700/1000/1000power/1500
158x434x231
• S6-2000/2000power
3000/3000power
158x460x340
CHARACTERISTICS
ADVANCED COMMUNICATION
• Reliable, filtered, stabilised and regulated
sinewave output (double conversion
technology VFI in conformance with IEC
62040-3 specifications) with filters for
atmospheric disturbance suppression
• High level immunity to surges (up to
150%)
• Auto restart on mains return
(programmable)
• Start-up without mains (cold start)
• Power factor correction with sinusoidal
input to ensure a low impact on the
mains supply (UPS input power factor,
close to 1)
• Wide input voltage window (110-300Vac)
to reduce battery usage
• Integrated protection for PC networks
and telephone line/modem connections
RJ45-RJ11
• Option to extend the back up time to
several hours
• Software-programmable operating
parameters
• Timer for scheduled shut-down and
power up (software programmable)
• Highly reliable batteries with automatic
and manual test feature
• Highly reliable system with full
microprocessor control
• Breaker based input protection
• Advanced, multi-platform
communication for all operating
systems and network environments:
Watch&Save 3000 monitoring and
shut-down software included, for
Windows 2008, Vista, 2003, XP,
Mac OS X, Linux, Novell and most
popular Unix operating systems.
• Free UPS tools
configuration software
• RS232 serial port
• Slot-in SNMP network
adapter card.
APPLICATIONS
• Small computers network
• Local Area Networks (LAN)
• Workstations
• Servers
• EPOS (Electronic Point of Sales)
system
2-YEAR WARRANTY
38
Sentinel 6
Technical data
Models
S6-700
S6-1000
Power
700VA/490W
Input
S6-700
S6-1000
POWER
1000VA/700W
S6-1000
S6-1500
S6-2000
1500VA/1050W
S6-1000
POWER
S6-3000
2000VA/1400W
S6-1500
Rated voltage
S6-2000
POWER
S6-2000
S6-3000
POWER
3000VA/2100W
S6-2000
POWER
S6-3000
S6-3000
POWER
S6-2000
POWER
S6-3000
S6-3000
POWER
S6-2000
POWER
S6-3000
S6-3000
POWER
220 - 230 - 240 Vac
Minimum voltage range
110V up to 60% of load / 120V from 60% to 70% of load
140V from 70 to 80% of load / 160V from 80% to 100% of load
Rated frequency
50/60 Hz ± 5Hz
Power factor
> 0.97
Input current
Sinewave
By pass
S6-700
S6-1000
S6-1000
POWER
S6-1500
Voltage range
S6-2000
180 - 264 Vac
Frequency range
Selected frequency ±5Hz
Batteries
S6-700
S6-1000
S6-1000
POWER
Type
S6-1500
S6-2000
Maintenance-free lead-acid VRLA, AGM
Recharge time
2-4 h
Output
S6-700
S6-1000
Rated voltage
-
2-4 h
4h
-
4h
-
S6-1000
POWER
S6-1500
S6-2000
S6-2000
POWER
S6-3000
S6-3000
POWER
S6-2000
POWER
S6-3000
S6-3000
POWER
14
35
15
Selectable 220, 230 or 240 Vac ±1.5%, Sinewave
Voltage distortion
< 2%
Frequency
50 or 60 Hz auto sensing
Crest factor
3:1
Overload
110% 30’; 130% 30”; 150% 10”
System
S6-700
Weight (kg)
12
Dimensions (wdh) (mm)
S6-1000
S6-1000
POWER
14
8
158x400x231
S6-1500
S6-2000
19
34
158x500x231
Operating temperature
192x460x340
O °C / +40 °C
Relative humidity
< 95% non condensing
Protection
Overload - short-circuit - overvoltage - undervoltage - temperature - low battery
Communication
RS232 + communication interface slot
Compliance
EN 62040-1 EMC EN 62040-2 Directive 2006/95/EC - 2004/108 EC; EN 62040-3
3KA 8/20 μs
Surge capability
Colour
Dark grey (RAL 7016)
Noise
<40 dBA
Details
Serial interface
External battery pack socket
Slot for SNMP network adapter card
Serial interface
External battery
pack socket
Slot for SNMP
network adapter card
Output sockets
Input socket
Telephone/IT
network protection
S6 700
S6 1000-1000 power
S6 1500
Output sockets
Input socket
Telephone/IT network protection
Output sockets
S6 2000-2000 power
S6 3000-3000 power
39
Sentinel 6 Rack
For outstanding power protection and
communication SENTINEL 6 RACK is
the best solution for sensitive
and “mission-critical” applications.
The SENTINEL 6 RACK series
comprises the 700-1000-1500-22003000VA models and uses double
conversion technology (VFI). The load is
powered continuously by the inverter
with an EMI filtered, stabilised and
regulated sinewave supply.
The input and output EMI filters
considerably increase the immunity of the
load to mains disturbances and surges,
even on bypass. The UPS can power the
load for long periods (using battery
extension packs) or provide sufficient
runtime to allow shut-down of the
protected computer systems using the
Watch&Save 3000 software, supplied as
standard.
SENTINEL 6 RACK POWER
models are supplied with a larger
internal charger and with their
matching external battery
extension packs can achieve long
back up times.
CHARACTERISTICS
ADVANCED COMMUNICATION
• Reliable, stabilised, filtered voltage
double on-line conversion technology
(VFI according to EN62040-3
specifications) with filters for the
suppression of atmospheric
disturbances
• High overload capability (up to 150%)
• Auto restart when mains power returns
(programmable)
• Power factor correction with sinusoidal
input to ensure a low impact on the
mains supply (UPS input power factor,
close to 1)
• Wide input voltage range (110-300Vac)
to reduce battery usage
• Integrated protection for PC networks
and telephone line/modem
connections RJ45-RJ11
• Option to extend the back up time to
several hours
• Programming of operating functions via
software
• Timer for scheduled shut-down
(software programmable)
• High level reliability of the batteries
(automatic and manual test)
• High level reliability of the UPS (full
microprocessor control)
• Breaker based input protection
• Advanced, multi-platform communication
for all operating systems and network
environments: Watch&Save 3000
monitoring and shut-down software
included, for Windows 2008, XP, Vista
and 2003; Mac OS X, Linux, Novell and
most popular Unix operating systems.
• The UPS is supplied with a
communication cable for Plug and Play
PC connection
• UPS tools configuration software
• Emergency Power Off (EPO) contact
• RS232 serial port
• Slot-in SNMP network adapter card.
APPLICATIONS
• Local Area Networks (LAN)
• Data Centers
• Servers
• Industrial PLCs
• Cash registers
• Emergency devices (lights/alarms)
• Telecommunication devices
2-YEAR WARRANTY
OPTIONS
Extended runtime solutions
(except 700VA)
External manual bypass (wdh) mm/kg
• Rack version
438x360x2U / 6,8
• Box version
300x115x180 / 3,3
40
Sentinel 6 Rack
Technical data
Models
S6R 700
Power
700VA/490W
Input
S6R 700
S6R 1000
S6R 1000
POWER
1000VA/700W
S6R 1000
S6R 1500
S6R 2200
1500VA/1050W
S6R 1000
POWER
Rated voltage
S6R 1500
S6R 2200
POWER
S6R 3000
2200VA/1540W
S6R 2200
S6R 2200
POWER
S6R 3000
POWER
3000VA/2100W
S6R 3000
S6R 3000
POWER
220 - 230 - 240 Vac
Minimum voltage range
110V up to 60% of load/120V from 60% to 70% of load
Rated frequency
50/60 Hz ± 5Hz
Rated current (A)
2.5
3.5
5.2
6.8
Power factor
10
13.8
14.4
16
S6R 2200
S6R 2200
POWER
S6R 3000
S6R 3000
POWER
S6R 2200
POWER
S6R 3000
S6R 3000
POWER
S6R 3000
S6R 3000
POWER
S6R 3000
S6R 3000
POWER
> 0.97
By pass
S6R 700
S6R 1000
S6R 1000
POWER
S6R 1500
Voltage tolerance
Static ± 1.5%
Frequency tolerance
± 0,5%
Batteries
S6R 700
S6R 1000
S6R 1000
POWER
Type/Recharge time
S6R 1500
S6R 2200
Maintenance-free lead-acid VRLA, AGM / 4 h
Output
S6R 700
S6R 1000
Rated voltage
S6R 1000
POWER
S6R 1500
S6R 2200
S6R 2200
POWER
220 or 230 or 240 Vac selectable ± 1,5%, Sinewave
Voltage distortion
< 2%
Frequency
50 or 60 Hz selectable, ± 0,5 %
Crest factor (Ipeak/Irms)
3 : 1 (up to 100% of load)
Overload
110% 30’; 130% 30”; 150% 10”
System
S6R 700
Weight (kg)
13
Dimensions (wdh) (mm)
S6R 1000
S6R 1000
POWER
16
9
19"x390x2U
Communication
S6R 1500
S6R 2200
S6R 2200
POWER
21
30
13
31
14
19”x480x2U
19"x560x3U
19"x480x2U
19"x560x3U
19"x480x2U
RS232 + communication interface slot
Operating temperature
O °C / +40 °C, ideal for battery +15 °C / +25 °C
Relative humidity
< 95% non condensing
Protection
Overload - short-circuit - overvoltage - undervoltage - temperature - low battery
Compliance
EN 62040-1 EMC EN 62040-2 Directive 2006/95/EC - 2004/108 EC; EN 62040-3
3KA 8/20 μs
Capability
Colour
Dark grey (RAL 5004)
Noise
<40 dBA at 1 m
Details
S6R 700-1000-1000 power-1500
Battery extension
pack socket
IEC output socket
Serial interface
port
Input thermal
protection
IEC mains
input socket
Battery extension
pack socket
IEC output socket
Serial interface
port
Input thermal
protection
IEC mains
input socket
S6R 2200-2200 power-3000-3000 power
41
Sentinel XR
SENTINEL XR is the best solution for
protecting medium sized networking
applications which require the highest
possible levels of reliability. The UPS is
designed to support a wide applications
from IT to security. SENTINEL XR is
unique in that the UPS can be placed
directly onto the floor or mounted in 19”
rack mount cabinets. The range is
available in 3300-4000-5000-60008000-10000VA models. The UPS is
primarily an on-line double-conversion
(VFI) technology system with further
selectable operating modes that can
configure the UPS to protect
applications including emergency
lighting, security and medical systems.
Each UPS features advanced
communications and diagnostics
including a digital front panel display that
can turned to suit the installation format,
RS232 and USB interfaces, and an
internal adaptor slot for SNMP and other
interface card options.
Watch&Save 3000 software is supplied
as standard.
SIMPLIFIED INSTALLATION
SELECTABLE OPERATING MODES
• The UPS can be installed as a floor
standing tower or 19” rack mount
UPS. The front panel digital display
can be pulled out (using the keys
provided) and rotated to suite the
installation format
• Low noise level (<40dBA) thanks to
the digitally PWM controlled ventilation
system which is load and temperature
dependent, and the use of an inverter
with a high switching frequency
(>20kHZ, above the audible range)
• Optional bolt-on maintenance bypass
(SENTINEL XR 5-6-8-10 kVA models)
to allow service without disruption to
the loads
• Performance guaranteed in
temperatures up to 40°C
• Two IEC output plugs with thermal
protection (SENTINEL XR 5-6-8-10
kVA)
• PowerShare output socket (2x10A
IEC) functionality on SENTINEL XR 56-8-10 kVA models
• On line Mode (VFI)
• Economy Mode: selects Line
Interactive VI technology to power noncritical loads from mains and achieve
up to 98% operating efficiency
• Smart Active Mode: the UPS selects
automatically whether to operate in
On-line VFI technology - full system
protection or Line Interactive VI mode
depending on the stability of the mains
supply
• Emergency Mode: the UPS can be set
to work only when the mains fails suitable for emergency lighting
• Frequency converter Mode: 50 or 60Hz
Display LCD custom
42
GUARANTEED OUTPUT QUALITY
OTHER CHARACTERISTICS
ADVANCED COMMUNICATION
• Even with typical distorting IT loads
with crest factors of 3:1
• Increased short circuit current on the
bypass
• Increased overload capacity: 150% on
inverter even when mains supply has
failed
• Reliable, filtered, stabilised and
regulated sinewave output (double
conversion technology VFI in
conformity with IEC 62040-3
specifications) with filters for
atmospheric disturbance suppression
• Rephasing of load as the UPS has an
input power factor close to 1, with a
sinusoidal input current
• Output voltage selection: 220-230240Vac
• Auto restart when mains power returns
programmed using the UPS Tools
software supplied
• Bypass on: when the UPS is switched
off, it automatically goes into bypass
mode to charge the batteries
• Automatic power down due to
minimum load
• End of battery discharge pre-alarm
• Delayed start up
• Completely digitally controlled
• Automatic bypass with no break in
power supply
• Use of IMS (Insulated Metallic
Substrates) modules
• Status, measurements, and alarms
available on the standard backlit
display
• UPS can be updated digitally (flash
upgradeable)
• Input protected by resettable thermally
activated switch
• Back-feed protection: to avoid current
being fed back into the mains should a
fault occur
• Manual switch over to bypass
• Advanced, multi-platform
communication for all operating
systems and network environments:
Watch&Save 3000 monitoring and
shut-down software included, for
Windows 2008, Vista, 2003, XP; Mac
OS X, Linux, Novell and most
popular Unix operating systems.
• The UPS is supplied with a
communications cable for ‘Plug and
Play’ PC connection
• USB port
• RS232 serial port
• Interface card slot
HIGHLY RELIABLE BATTERY
PERFORMANCE
• Automatic and manual battery tests
• Unique Low Ripple Current Discharge
(LRCD) to help prolong battery life
• Hot-swap user replaceable batteries
• Unlimited extendable back-up time
using modular design Battery
Extension Packs
• Increased ride through (without
batteries) on mains breaks up to 40ms
and for fluctuations ranging from 84 to
276Vac
OPTIONS
Extended runtime solutions
with/without battery charger
External maintenance bypass
(except 3300VA and 4000VA)
Interface cards
Telescopic rails for rack cabinet
APPLICATIONS
• Local Area Networks (LAN)
• Data Centers
• Servers
• Industrial PLCs
• Cash registers
• Electromedical devices
• Emergency devices (lights/alarms)
2-YEAR WARRANTY
LE FORTING
B
A
T
I
U
S
GH
NCY LI
EMERGEPLICATIONS
AP
43
Sentinel XR
Technical data
Single-phase input
Single-phase output
Models
SXRM-3300
SXRM-4000
SXRM-5000
SXRM-6000
SXRM-8000 SXRM-10000
Power
3300VA/2300W
4000VA/2400W 5000VA/3500W
6000VA/4200W
8000VA/6400W 10000VA/8000W
Input
SXRM-3300
SXRM-4000
SXRM-6000
SXRM-8000 SXRM-10000
Rated voltage
SXRM-5000
220 - 230 - 240 Vac
Minimum voltage
164 Vac @ load 100% 84 Vac @ load 50%
Rated frequency
50/60 Hz ± 5 Hz
Power factor
> 0.98
Current distortion
≤ 7%
By pass
SXRM-3300
Voltage range
Frequency range
Batteries
SXRM-4000
SXRM-6000
SXRM-3300
SXRM-4000
SXRM-5000
SXRM-6000
SXRM-3300
SXRM-4000
SXRM-5000
SXRM-6000
SXRM-8000 SXRM-10000
220 - 230 - 240 Vac selectable
Static variation
1,5 %
≤ 5% in 20 ms
Dynamic variation
Waveform
Sinewave
Voltage distortion with linear load
< 3%
Voltage distortion with non-linear load
< 6%
Frequency
50/60 Hz selectable
Crest factor
3:1
SXRM-3300
SXRM-4000
SXRM-5000
SXRM-6000
100% < Load < 110%
1’
110% < Load < 125%
4”
Load > 150%
SXRM-8000 SXRM-10000
4-6h
Rated voltage
Overload capacity
SXRM-8000 SXRM-10000
Selected frequency ±5 % (user configurable)
Recharge time
Output
SXRM-5000
180 - 264 Vac (selectable in Economy Mode and SMART ACTIVE Mode)
SXRM-8000 SXRM-10000
0.5”
44
Sentinel XR
Single-phase input
Single-phase output
System
SXRM-3300
SXRM-4000
SXRM-5000
SXRM-6000
Weight (kg)
38
40
62
64
SXRM-8000 SXRM-10000
80
85
Dimensions (wdh) (mm) tower
175x520x455
175x660x455
2x175x660x455
Dimensions (wdh) (mm) rack
483x520x175(4U)
483x660x175(4U)
2x483x660x175(4U)
Efficiency
up to 98%
Operating temperature
O °C / +40 °C
Relative humidity
< 95% non condensing
Protection
Overload - short-circuit - overvoltage - undervoltage - temperature - low battery
Compliance
EN 62040-1 EMC EN 62040-2 Directives 2006/95/EC-2004/108 EEC EN 62040-3
Communication
USB / RS232 + communication interface slot
Colour
Dark grey (RAL 7016)
Noise
Accessories provided
<40 dBA at 1 m
<45 dBA at 1 m
2x10A cables; 1xIEC-16A plug;
software; serial cable; plastic keys
to release display; handles kit
2 cable guides; terminal board connection; software; serial cable;
plastic keys to release display; handles kit
Details
USB port
Serial port
Interface card slot
SNMP or additional
RS232 ports
Input thermal
protection re-set
Input hardwired
gland
Output hardwired
glands
Battery
extension pack
connector
SXRM 3300-4000
Input
cable access
Output
cable access
SXRM 5000-6000
SXRM 8000-10000
45
Sentinel XR
Technical data
Three-phase input
Single-phase output
Models
SXRT-6500
SXRT-8000
SXRT-10000
Power
6000VA/5200W
8000VA/6400W
10000VA/8000W
Input
SXRT-6500
SXRT-8000
SXRT-10000
Rated voltage
400 Vac tree-phase + N
Minimum voltage
164 Vac @ load 100% - 84 Vac @ load 50%
Rated frequency
50/60 Hz ± 5 Hz
Power factor
By pass
Voltage range
> 0.95
SXRT-6500
Frequency range
Batteries
SXRT-6500
SXRT-8000
SXRT-6500
SXRT-8000
220 - 230 - 240 Vac selectable
Static variation
1,5 %
Waveform
Sinewave
Voltage distortion with linear load
< 3%
Voltage distortion with non-linear load
< 6%
Frequency
50/60 Hz selectable
Crest factor
3:1
110% ≤ Load < 150%
Load > 150%
SXRT-10000
≤ 5% in 20 ms
Dynamic variation
Overload capacity
SXRT-10000
4-6h
Rated voltage
100% < Load < 110%
SXRT-10000
Selected frequency ±5 % (user configurable)
Recharge time
Output
SXRT-8000
180 - 264 Vac (selectable in Economy Mode and SMART ACTIVE Mode)
SXRT-6500
SXRT-8000
SXRT-10000
1’
4”
0.5”
46
Sentinel XR
Three-phase input
Single-phase output
System
SXRT-6500
SXRT-8000
SXRT-10000
Weight (kg)
64
80
85
Dimensions (wdh) (mm) tower
2x175x660x455
Dimensions (wdh) (mm) rack
2x483x660x175(4U)
Efficiency
up to 98%
Operating temperature
O °C / +40 °C
Relative humidity
< 95% non condensing
Protection
Overload - short-circuit - overvoltage - undervoltage - temperature - low battery
Compliance
EN 62040-1 EMC EN 62040-2 Directive 2006/95/EC- 2004/108 EC EN2040-3
Communication
USB / RS232 + communication interface slot
Colour
Dark grey (RAL 7016)
Noise
<45 dBA at 1 m
Accessories provided
2 cable guides; terminal board connection; software; serial cable;
plastic keys to release display; handles kit
Details
Battery connection
Interface card slot SNMP
or additional RS232 ports
Serial port
USB port
Input cable access
Output cable access
SXR 6500-8000-10000
47
Sentinel XR Plus
Sentinel XR Plus is the ideal solution for
powering vital mission critical, sensitive
loads such as electro-medical security
applications in order to guarantee
maximum reliability and availability.
The series includes 5kVA-6kVA
single/single phase and 6.5kVA-8kVA10kVA single/single phase and
three/single phase models and uses
double conversion on-line technology
(VFI). The load is powered constantly by
the inverter which supplies filtered,
stabilised and regulated sinewave voltage.
Moreover, the input and output filters
increase the immunity of the load against
mains power disturbances and lightning
strikes.
Sentinel XR Plus is without doubt one of
the best UPS systems on the market
today thanks to the technology used,
the features (selectable Economy Mode
and Smart Active Mode) and the
diagnostics offered (custom LCD display,
RS232 and USB interfaces complete
with Watch&Save 3000 software, EPO
contact and slots for optional interface
boards).
HIGH RELIABILITY
• Full microprocessor control.
• No break static and maintenance bypass.
• Features guaranteed up to 40 °C
(the components are designed to
operate at high temperatures and thus
are subject to less stress at ordinary
temperatures).
SELECTABLE OPERATING MODES
The operating mode can be
programmed using the software or
selected manually on the digital front
panel display.
• On line Mode (VFI).
• Economy Mode: increases efficiency
(up to 98%), and uses Line Interactive
(VI) technology to power low priority
loads from the mains supply.
• Smart Active Mode: the UPS automatically
decides which operating mode to use
(VI or VFI) depending on the quality of
the mains supply.
• Emergency Mode: the UPS can be
set to operate only when mains power
fails (emergency only mode).
• Frequency converter Mode
(50 or 60 Hz).
HIGH QUALITY OUTPUT VOLTAGE
• Even with distorting loads (IT loads
with crest factor of up to 3:1).
• High short circuit current on bypass.
• High overload capacity: 150% on
inverter, even when mains power fails.
• Filtered, stabilised and reliable voltage
(double conversion on-line technology,
VFI compliant with EN62040-3
specifications, with filters to suppress
atmospheric interference).
• Rephasing of the load: UPS input
power factor close to 1 with sinusoidal
current absorption.
48
SIMPLIFIED INSTALLATION
OTHER FEATURES
ADVANCED COMMUNICATION
• The UPS can be connected to both
single phase and three phase mains
supplies.
• Output terminal board + 2 IEC plugs
to power local equipment
(computers, modems, etc.).
• Easy to move thanks to built-in
wheels.
• Advanced diagnostics: status,
measurements and alarms available
on the custom LCD display.
• Very low noise level (<40dBA): for
installation in any environment thanks
to the PWM digitally controlled
ventilation that is load dependent, and
the use of an inverter with high
switching frequency (>20kHz, value
above the audible range).
• Autorestart when mains power
returns, can be programmed using
software or the digital front panel
display.
• Emergency mode: the UPS can be
programmed to work only when
mains power fails (suitable for
emergency lighting).
• Standard back feed protection: to
avoid current being fed back into the
mains system.
• Digital updating of the UPS
(flash upgradable).
• Compatible with the AROS
TeleNetGuard remote assistance
system.
• Advanced, multiplatform
communication for all operating
systems and network environments:
Watch&Save 3000 monitoring and
shutdown software included, for
Windows 2008, Vista, 2003, XP,
Mac OS X, Sun Solaris, Linux,
Novell and other Unix operating
systems.
• RS232 serial port.
• Plug and Play connection.
• Slots for communication interface
boards.
HIGH BATTERY RELIABILITY
• Automatic and manual battery tests.
• Low Ripple Current Discharge
system “LRCD” to prolong
battery life.
• Unlimited extendable runtime thanks
to dedicated modular design Battery
Boxes.
• Increased ride-through for mains
failures up to 40ms (high hold up
time) and for fluctuations in the input
voltage ranging from 84V to 276V).
LOW IMPACT ON MAINS POWER
• Sinusoidal input current on single
phase/single phase series.
APPLICATIONS
• Local Area Networks (LAN)
• Data Centers
• Servers
• Industrial PLCs
• Cash registers
• Electromedical devices
• Emergency devices (lights/alarms)
• Telecomunication devices
49
Sentinel XR Plus
Technical data
Models
XRMP 5000
XRMP 6000
XRTP 6500
XRTP 8000
XRTP 10000
Power
5000VA/4000W
6000VA/4800W
6500VA/5200W
8000VA/6400W
10000VA/8000W
Input
XRMP 5000
XRMP 6000
XRTP 6500
XRTP 8000
XRTP 10000
Rated voltage
220-230-240 Vac single-phase
Minimum voltage without battery intervention
220-230-240 Vac single-phase or 380-400-415 Vac three-phase with neutral
170 Vac @ load 100% / 140 Vac @ load 50%
Rated frequency
By pass
50/60 Hz ± 5Hz
XRMP 5000
Voltage range
XRMP 6000
Frequency range
Batteries
XRTP 8000
XRMP 5000
XRMP 6000
XRTP 6500
XRTP 8000
XRTP 10000
XRTP 8000
XRTP 10000
6-8h
XRMP 5000
Rated voltage
XRMP 6000
XRTP 6500
220 - 230 - 240 Vac selectable
Static variation
± 1,5 %
≤ 5% in 20 ms
Dynamic variation
Waveform
Sinewave
Voltage distortion with linear load
< 3%
Voltage distortion with non-linear load
< 6%
Frequency
50/60 Hz selectable or auto sensing
Crest factor
≥3:1
Overload capacity
100% < Load < 125%
125% ≤ Load < 150%
Load ≥ 150%
XRTP 10000
Selected frequency ±5Hz
Recharge time
Output
XRTP 6500
180 - 264 Vac (selectable in Economy Mode and SMART Mode)
XRMP 5000
XRMP 6000
SXRP 6500
SXRP 8000
SXRP 10000
1’
4”
0.5”
50
Sentinel XR Plus
System
XRMP 5000
XRMP 6000
XRTP 6500
XRTP 8000
XRTP 10000
Weight (kg)
89
90
91
94
95
Dimensions (wdh) (mm)
282x785x615
Efficiency Smart Mode
up to 98%
Operating temperature
O °C ÷ +40 °C
Humidity
< 95% non condensing
Protection
Overload - short-circuit - overvoltage - undervoltage - temperature - low battery
Compliance
EN 62040-1 EMC EN 62040-2 Directives 2006/95/EC - 2004/108 EC EN 62040-3
Communication
RS232 + USB + remote contacts + communication interface slot
Colour
Dark grey (RAL 7016)
Noise
<45 dBA at 1 m
Details
ON/OFF switch
Communication
interface slot
Emergency
power off (EPO)
Serial interface
port
IEC sockets
Input switch
(SWIN)
Battery fuse
holders (SWBT)
USB port
Maintenance
bypass (SWMB)
Output switch
(SWOUT)
51
Flexus
Flexus is ideal for the protection of critical
information and telecommunications
networks which cannot run the risk of
being powered from a power quality
electrical supply.
The Flexus series is available in 10-1215-20 kVA three-phase or single-phase
input and single-phase output models,
and 10-12-15-20-30-40-100-120 kVA
three-phase input and output models,
with double conversion on-line
technology according to the VFI-SS-111
classification, as defined by the IEC EN
62040-3 standard.
Flexus has been designed and
manufactured using state-of-the-art
technologies in order to deliver maximum
protection for critical users, a zero
impact on the mains power supply and a
high operating efficiency.
The high level of flexibility at the design
stage means that there is full
compatibility both with three-phase
power and with single-phase sources,
thus eliminating any critical factors in the
connection between UPS and system.
ZERO IMPACT SOURCE
BATTERY CARE SYSTEM
The superior technology of a Flexus UPS
allows it be used where the site mains
power supply is limited in capacity, or
has an on-site generator and/or loads
that generate current harmonic problems.
Flexus is designed to have a zero-impact
on its upstream power supply (mains or
generator):
• Input current distortion < 3%
• Input power factor 0.99
• Power walk-in function to guarantee a
progressive rectifier start-up
• Delayed switch-on function, to
sequentially restart the UPS when
installed as part of a parallel system.
Battery management is one of the
fundamentals of UPS management in
order to ensure the system can perform
in emergencies. The Flexus Battery Care
System consists of a number of
functions that together guarantee
optimum battery performance.
Flexus also act as a filter and phase-shift
protection device in respect to its
upstream supply, providing protection
from any harmonic components or
reactive power generated by
downstream loads.
Battery recharge: Flexus is suitable for
use with sealed Valve Regulated (VRLA),
AGM, GEL and open-vented lead acid
batteries, in addition to Nickel-Cadmium.
Depending on the battery type used, the
recharging functions can include:
• One-level recharge, typical for the most
commonly used VRLA AGM batteries
• Two voltage level recharge according
the IU characteristic
• Charge blocking system to reduce
consumption of the electrolyte and
further extend the life of VRLA
batteries.
Display
52
Compensation of the recharge voltage
according to temperature in order to
avoid excessive battery charging currents
and potential overheating problems.
Battery Test in order to detect battery
performance deterioration or failure.
Protection against deep discharges:
during extended low load discharges,
the end-of-discharge voltage is
increased as recommended by battery
manufacturers, to prevent damage to the
battery set.
Ripple Current: recharge current ripple
(residual AC component) is one of the
most common causes of poor battery
performance and reduced operating life.
Flexus, with its high-frequency batterycharger, produces negligible current
ripple levels and therefore helps to
extend operating life.
Wide voltage range: the rectifier can
operate from a wide input range (up to
40% at half load), reducing battery
usage and helping to extend their
operational life.
LOW MANAGEMENT COST
The high performance components and
technology used by Flexus means that
the UPS achieves exceptional
performance and efficiency levels, from a
very small footprint and overall compact
dimensions:
• the lowest footprint in this category,
only 0.26 sq. m. for 20kVA Flexus,
batteries included
• the type of input stage guarantees a
power factor close to 1 and a low
current distortion without the addition
of filters, which can be expensive and
bulky
• output power factor of 0.9 providing
up to 15% more active power than a
traditional UPS and more load
expansion.
Thanks to the high efficiency
up to 96,5% Flexus saves money
during the operation
HIGH EFFICIENCY
High operating efficiency up to 96,5% in
on-line operation providing a 50% saving
in energy usage per annum compared to
traditional UPS products (92%). This
exceptional performance can lead to a
full initial investment recovery within three
years.
Flexus 40kVA
Efficiency
(certified by TÜV)
53
FLEXIBILITY
Flexus Output Power
Leading Cosϕ (capacitive loads)
cosϕ 0,9
cosϕ 1
100% kW
Lagging Cosϕ (inductive loads)
cosϕ 0,9
1,00
Active Power
Flexus is suitable for use in a broad
spectrum of applications, thanks to a
variety of configurations, accessories
and options providing flexibility and a
choice of performance levels:
• suitable for powering capacitive loads,
such as blade servers, without any
reduction in active power
(0.9 in lead to 0.9 lag)
• multiple operating modes: On Line,
Eco, Smart Active and Stand By Off
• Frequency converter mode
• configurable Power Share connections
to ensure backup for the most critical
loads or programmed to operate only
when mains power fails
• Cold Start facility that starts the UPS
even when it is not connected to the mains
• FT/FM H version: in cabinet 440x850
x 1320 WDH, it provides optimum
solutions when medium or long term
runtime is required
• optional temperature sensor for
external battery cabinets, to assist the
recharge voltage compensation
• additional battery chargers to optimise
recharge times
• optional dual input to mains power supply
• isolation transformer options to vary
neutral connectivity in the event of
separate power sources or for
galvanic isolation between input
and output
• battery cabinets of various sizes and
capacities to ensure prolonged runtime.
0,75
100% kVA
0,50
UPS @ Cosϕ 0,9
Es. 20kVA - 18kW !!!
0,25
-1
-0,8
-0,6
-0,4
-0,2
0
0,2
0,4
0,6
0,8
1
Reactive Power
network adapter and volt-free contacts.
• REPO (Remote Emergency Power Off)
• Input for synchronization from an
external source
• Graphic mimic panel display for remote
connection
• Input for connection of the auxiliary
contact of an external manual bypass
LE FORTING
B
A
T
I
U
S
GH
NCY LIIONS
E
G
R
E
M
E
AT
APPLIC
ADVANCED COMMUNICATION
Flexus is equipped with a graphic display
that provides information, measures,
states and alarms regarding the UPS in
5 different languages.
• Advanced multiplatform
communication, for all operating
systems and network environments:
Watch&Save 3000 monitoring and
shutdown software included with for
Windwows 2008, Vista, 2003, XP;
Mac OS X, Linux, Novell and most
popular Unix operating systems
• Compatible with PowerNetGuard for
the remote assistance service
RS232 or USB serial port
• 3 slots for the installation of optional
communication accessories such as
54
EXPANDABILITY
Flexus can work in parallel up to 6 units
to increase the power availability and the
reliability. The single module or the
parallel system can be expanded at any
time to suit additional power
requirements without influencing the
initial investment. Thanks to the
peculiarity of the “Hot System
Expansion” feature, the new UPS can be
connected in parallel while the other
units are on-line and supplying regular
power to the load. When the UPS is
connected it will be updated
automatically from the other UPS on line.
To increase the flexibility of the Flexus
system, on each unit a second input is
available for a synchronization with the
external source other than the bypass
mains. The parallel configuration may be
with single or common battery.
Example of parallel
card assembly
55
Flexus
Technical data
Three-phase or single-phase input
Single-phase output
Models
Power (kVA)
Input
FM 10
FM 12
FM 15
FM 20
10
12
15
20
FM 12
FM 15
FM 20
FM 10
Rated voltage
380- 400-415 Vac three-phase with Neutral / 220-230-240Vac single-phase
Rated frequency
50/60 Hz
Frequency tolerance
40 ÷ 72 Hz
Power factor at full load
0.99
Current distortion
By pass
THDI ≤ 3%
FM 10
FM 12
Rated voltage
FM 15
Number of phases
1
Voltage tolerance
180 ÷ 264V (selectable)
Rated frequency
50 or 60 Hz (selectable)
Frequency tolerance
Output
FM 20
220-230-240 Vac
±5 (selectable)
FM 10
FM 12
FM 15
Rated power (kVA)
10
12
15
20
Active power with load PF from 0,8 cap. to 0,8 ind.
8
9.6
12
16
Output power factor
0.8
Number of phases
1
Rated voltage
220-230-240 Vac (selectable)
Static variation
± 1%
Dynamic variation
± 3%
Crest factor (Ipeak/Irms)
3:1
Voltage distortion
≤ 1% with linear load / ≤ 3% with non-linear load
Frequency
50/60 Hz
Frequency stability on battery mode
0.01%
Overload at Pf 0.8
Batteries
Type
Recharge time
FM 20
110% for 10 minutes, 133% for 1 minute, 150% for 5 seconds
FM 10
FM 12
FM 15
FM 20
VRLA AGM/GEL
6h
56
Flexus
Three-phase or single-phase input
Single-phase output
System
Weight with internal batteries (kg)
FM 10
FM 12
FM 15
FM 20
180
182
190
195
Dimensions (wdh) (mm)
320x840x930 (440x850x1320 Version FM-H)
Communication
3 communication interface slots/RS232/USB
Operating temperature
O°C - 40°C
Relative humidity
90% non condensing
Colour
Dark grey (RAL 7016)
Noise
< 52 dBA at 1 m
Protection rating
IP20
Efficiency Smart Mode
≥ 98% in Economy mode
Compliance
European Directives: L V 2006/95/EC Low voltage directive
EMC 2004/108/EC Electromagnetic compatibility directive
Standards: Safety IEC EN 62040-1; EMC IEC EN 62040-2 C2
Classification according to IEC 62040-3 (Voltage Frequency Independent) VFI - SS - 111
Details
FM-H 10-12-15-20
REPO - AS400
USB - RS232
Connectors
Comunication
interface slot
FM 10-12-15-20
Powershare
sockets
Communication
interface slot
Battery fuses
Parallel board
Remote
contacts
connectors
USB port
Serial
interface port
Input switch
(swin)
Bypass fuse
holder (SWBYP)
Output switch
(swout)
Maintenance
bypass (SWMB)
57
Flexus
Technical data
Three-phase input
Three-phase output
Models
Power (kVA)
Input
FT 10
FT 12
FT 15
FT 20
FT-H 30
FT-H 40
FT100
FT120
10
12
15
20
30
40
100
120
FT 10
FT 12
FT 15
FT 20
FT-H 30
FT-H 40
FT100
FT120
FT100
FT120
Rated voltage
380- 400-415 Vac three-phase +N
Rated frequency
50/60 Hz
Frequency tolerance
40 ÷ 72 Hz
Power factor at full load
0.99
Current distortion
By pass
THDI ≤ 3%
FT 10
FT 12
FT 15
Rated voltage
FT 20
FT-H 30
Number of phases
3+N
Voltage tolerance
180 ÷ 264V (selectable)
Rated frequency
50 or 60 Hz (selectable)
Frequency tolerance
Output
FT-H 40
380-400-415 Vac three-phase +N
±5 (selectable)
FT 10
FT 12
FT 15
FT 20
FT-H 30
FT-H 40
FT100
FT120
Rated power (kVA)
10
12
15
20
30
40
100
120
Active power with load PF from 0,9 cap. to 0,9 ind.
9
10.8
13.5
18
27
36
90
108
Output power factor
0.9
Number of phases
3+N
Rated voltage
380-400-415 Vac (selectable)
Static variation
± 1%
Dynamic variation
± 3%
Crest factor (Ipeak/Irms)
3:1
Voltage distortion
≤ 1% with linear load / ≤ 3% with non-linear load
Frequency
50/60 Hz
Frequency stability on battery mode
0.01%
Overload at Pf 0.8
Batteries
Type
Recharge time
115% unlimited, 125% for 10 minutes, 150% for 1 minute, 168% for 5 seconds
FT 10
FT 12
FT 15
FT 20
FT-H 30
FT-H 40
FT100
FT120
VRLA AGM/GEL
6h
58
Flexus
Three-phase input
Three-phase output
System
FT 10
Weight with internal batteries (kg)
FT 12
FT 15
FT 20
FT-H 30
FT-H 40
FT100
FT120
182
190
195
335
350
460*
480*
180
Dimensions (wdh) (mm)
320x840x930 (440x850x1320 FT-H version)
Communication
440x850x1320
750x855x1900
3 communication interface slots/RS232/USB
Operating temperature
O°C - 40°C
Relative humidity
90% non condensing
Colour
Dark grey (RAL 7016)
Noise
< 52 dBA at 1 m
< 48 dBA at 1 m
Protection rating
< 65 dBA at 1 m
IP20
Efficiency Smart Mode
up to 99%
Compliance
European Directives: L V 2006/95/EC Low voltage directive
EMC 2004/108/EC Electromagnetic compatibility directive
Standards: Safety IEC EN 62040-1; EMC IEC EN 62040-2 C2
Classification according to IEC 62040-3 (Voltage Frequency Independent) VFI - SS - 111
*weight without batteries
Details
FT 100-120
FT-H 10-12-15-20-30-40
REPO - AS400
USB - RS232
Connectors
Communication
interface slot
Parallel
connectors
Connectors
REPO-AS400
USB-RS232
Comunication
interface slot
Battery fuses
Input switch
(swin)
Bypass fuse
holder (SWBYP)
Output switch
(swout)
Maintenance
bypass (SWMB)
Maintenance bypass
(SWMB)
Bypass switch
(SWBYP)
Multicom 382 Slot
Output switch
(SWOUT)
Input switch
(SWIN)
Powershare
sockets
For the FT details please refer to the FM range, p.57
59
Sentry Multistandard
SENTRY MULTISTANDARD provides
maximum protection for critical data
processing networks and security
applications, thanks to its advanced
design, selectable operating modes and
communications capabilities. Operating
modes include: On-line, Economy,
Smart-Active, Standby/Off and Voltage
Stabilisation. Standard communications
features include a front panel LCD with
128 potential messages, RS232
interfaces, EPO input, communications
interface slot and Watch&Save 3000
management software.
The SENTRY MULTISTANDARD series
includes 60-80 kVA three-phase models,
and uses on-line double conversion
technology (VFI). The load is powered
continuously by the inverter with a
filtered, stabilised and regulated sinewave
supply. The input and output filters
considerably increase the immunity of the
load to mains disturbances and surges,
even on bypass.
LOW POWER CONSUMPTION
• On-line Mode: up to 92% efficiency
can be achieved due to the use of
IGBT technology, increasing to 98% in
one of the other operating modes
• Economy Mode: uses Line Interactive
(VI) technology to power less critical
loads from the mains supply for certain
periods
• Smart Active Mode: if the mains supply
is out of range, the UPS will power the
load from the inverter as an On-line
UPS. When the mains supply returns
to within range again, the UPS will
monitor this for a certain period before
selecting Line Interactive operation.
60
Fig. 1 – Block diagram UPS in parallel up to 8 units
MAXIMUM RELIABILITY
AND AVAILABILITY
MAINTENANCE SIMPLICITY = LOW
MTTR
• Connect up to 8 units in parallel or
N+1 redundancy, of even different
power ratings.
Open the door and remove the
protective panel (standards requirement)
and the power components - mounted
on a sliding tray - can be pulled out to
provide easy access to all the electrical
and electronic components for
maintenance and repair work. This
particular feature means that the MTTR
(Mean Time To Repair) is much lower
than traditional UPS designs with less
easily reached assemblies, which has
longer times due to the compact size of
the products and difficult access to the
parts.
HIGH LEVEL BATTERY RELIABILITY
• Automatic battery test
• Recharge compensated for
temperature
• Automatic or manual rapid charge
(boost) – duration progammable
A large amount of maintenance
information is available from the front
mimic panel and LCD. In addition
system operating parameters are
software configurable via a local PC to
allow new functions to be added or
adjustments made to operating
specifications.
61
SENSITIVE SUPPLY COMPATIBLE
For power supply sources that are
particularly sensitive to harmonics
(generator sets or transformers of low
power with respect to that of the UPS) it
is often a good idea to take action to
limit the harmonics injected back into the
supply by the UPS.
SENTRY MULTISTANDARD series is also
available with built-in active filter using
high frequency Isolated Gate Bipolar
(IGBT) Technology with Digital Signal
Processor (DSP) control. The Active
Filter helps to reduce harmonics
generated by the UPS into the supply
which could disrupt the operation of
downstream generators and
transformers whose rating is closely
matched to that of UPS.
• advanced technology
The active filter reduces harmonic
distortion of the phase and neutral
currents. The Digital Signal Processor
(DSP) and the “current mode” instantly
control and monitor the input current to
maintain a perfect sinewave with less
than 4% harmonic distortion
• excellent capabilities
Input distortion: (THDi) 4%
Input power factor: >0.99
• maximum efficiency
Thanks to the active filter Sentry
Multistandard systems have low input
distortion even at low loads and their
overall efficiency is not affected by
generator frequency variations or line
impedance
OTHER CHARACTERISTICS
• reduction of neutral current
The active filter reduces the input
neutrals current by up to 3.5 times
their nominal rating to help avoid
oversizing input protections and
conductors
• maximum reliability
Sentry Multistandard systems are
extremely reliable. Overall UPS
performance is unaffected should the
harmonic filter fail
Sentry Multistandard can also be
supplied without the Active Filter
for installations less sensitive to
current harmonics.
• Suitable for powering capacitive loads
such as blade servers, without any
reduction of the active power, from 0.8
leading to 0.8 lagging
• High level diagnostics: event log with
128 messages, states, measurements
and alarms - available from the built-in
LCD in several languages
• Reduced noise levels: high frequency
inverter bridge
• Back feed protection standard: to
avoid energy feeding back into the
mains supply (in compliance with CEI
11-20; DK5600)
• Power factor correction (input power
factor, close to 1)
• By pass may be deactivated to allow
operation as a frequency converter (at
50 or 60 Hz)
• Emergency operation: the UPS can be
set to operate only when the mains
fails (for emergency lighting)
UPS input current
with optional Active Filter
Sentry Multistandard with Active Filter
(internal view)
62
Multistandard Output Power
Leading Cosϕ (capacitive loads)
cosϕ 0,8
cosϕ 0,9
cosϕ 1
100% kW
cosϕ 0,9
Lagging Cosϕ (inductive loads)
Operating status, alarms, applied load,
battery charging.
cosϕ 0,8
Active Power
1,00
0,75
0,50
100% kVA
Controls and settings menu.
0,25
-1
-0,8
-0,6
-0,4
-0,2
0
0,2
0,4
0,6
0,8
1
Reactive Power
ADVANCED COMMUNICATION
APPLICATIONS
• Compatible with TeleNetGuard for
remote maintenance
• Advanced, multi-platform
communication for all operating
systems and network environments:
Watch&Save 3000 monitoring and
shut-down software included, for
Windows 2008, Vista, 2003, XP; Mac
OS X, Linux, Novell and most
popular Unix operating systems
• The UPS is supplied with a
communications cable for ‘Plug and
Play’ PC connection
• Double RS232 serial ports
• Network adapter slot for SNMP agent
• Emergency Power Off (EPO) shutdown
input contact
• Remote control mimic panel
• Local Area Networks (LAN)
• Data Centers
• Servers
• Industrial PLCs
• Cash registers
• Electromedical devices
• Emergency devices (lights/alarms)
• Telecommunication devices
• e-Business (Servers, Farms,
ISP/ASP/POP)
Language selection menu.
Battery voltages, internal operating
temperatures.
OPTIONS
Input isolation transformer
Active filter
LED remote status panel
LCD based remote control panel
Graphic Display remote control panel
Empty battery cabinet
for prolonged runtime
Additional battery charger
Dual input mains
63
Sentry Multistandard
Technical data
Three-phase input
Three-phase output
Models
ST60
Power (kVA)
60
Input
ST80
80
ST60
ST80
Rated voltage
400 Vac three-phase + N
Voltage range
± 20%
Frequency range
45 ÷ 65 Hz
Power factor
> 0.99
Current harmonic distortion
By pass
THDi 4%
ST60
ST80
Rated voltage
400 Vac
Number of phases
3+N
Permitted voltage range
± 15% (selectable from ± 5% to ± 25%)
Rated frequency
50/60 Hz
Permitted frequency range
Batteries
± 2% (selectable from ± 1% to ± 5%)
ST60
Type
ST80
Lead, open vase acid and VRLA, AGM / GEL; NiCd
Recharge time
4-8 h
Output
ST60
Rated power (kVA)
60
80
Active power
with load PF from 0,8 cap. to 0,8 ind. (kW)
48
64
Number of phases
ST80
3+N
Rated voltage
380 - 400 - 415 Vac selectable
Voltage regulation range
346 ÷ 422 Vac
Crest factor (Ipeak/Irms)
3:1
Distortion with linear load
2%
Static stability
± 1%
Dynamic stability
± 5% in 10 ms
Frequency
50 / 60 Hz selectable
Overload
125% 150% of the rated current for 10’/1’
System
ST60
Weight (kg)
180
ST80
192
Dimensions (wdh) (mm)
500x740x1400
Remote signaling
Volt free contacts
Remote controls
EPO and bypass
Communication
Double RS232/C + remote contacts + communication interface slot
Operating temperature
O °C / +40 °C
Relative humidity
<95% non condensing
Colour
Noise
Protection degree
Efficiency Smart Mode
Compliance
Dark grey (RAL 7016)
<56 dBA at 1 m
<60 dBA at 1 m
IP20
> 98,5%
EN 62040-1 EMC EN 62040-2 EN 62040-3
64
Sentry HPS
SENTRY HPS HM/HT provides
maximum protection for vital ‘missioncritical’ networks, security applications
(electro-medical) and industrial
applications thanks to its outstanding
mechanical and electrical design.
The load is powered continuously by
the inverter with a filtered, stabilised
and regulated sinewave supply. The
input and output EMI filters
considerably increase the immunity of
the load to mains disturbances and
surges.
The SENTRY HPS HM/HT series uses
on-line double conversion technology
(VFI) with an isolation transformer on the
inverter output.
SENTRY HPS HM/HT is supplied with
Watch&Save 3000 software as
standard and can be remotely
monitored using the PowerNetGuard
system from anywhere in the world.
Additional battery extension packs
allow the standard battery runtime to be
extended up to several hours.
MINIMUM IMPACT ON SUPPLIES EASY SOURSE
Input current distortion <4% for the
Sentry HPS with filter with sinusoidal
absorption to remove the risk of
resonance with other input supply
users or phase shift capacitor sets. The
absorbed current distortion is
independent of input supply
parameters such as impedance.
This enables Sentry HPS to deliver
maximum performance levels
regardless of the installation
environment. With these input features
Sentry HPS can achieve significant
savings in terms of sizing and power
supply sources - isolation transformers
and generators over less sophisticated
power systems.
MAXIMUM BATTERY CARE
SIMPLE TO INSTALL
• Capability to install the UPS into any
distribution system (neutral not
required on rectifier input)
• Capability to separate the
rectifier/bypass power networks and
to power these from two separate
sources, without Galvanic isolation
(necessary on UPS without an output
transformer)
HIGH RELIABILITY
• Extremely high short-circuit current to
ensure compatibility with the most
difficult transformer applications
(lighting, drives and industrial
processes) and an isolation
transformer on the inverter output
• Full microprocessor control with
no-break static and manual bypasses
• IGBT technology
• Battery deep discharge protection
• Temperature compensating charger
• Built-in automatic and manual battery
test feature
66
OTHER CHARACTERISTICS
ADVANCED COMMUNICATION
NO-BREAK POWER ARCHITECTURES
• 0.8 power factor makes Sentry HPS
suitable for powering ICT and industrial
loads
• High level diagnostics: event log with
128 messages, states, measurements
and alarms - available from the built-in
LCD in several languages
• BACK FEED protection: to avoid
energy feeding back into the mains
supply should a fault occur
• Compatible with TeleNetGuard for
remote maintenance
• Advanced, multi-platform
communication for all operating
systems and network environments:
Watch&Save 3000 monitoring and
shut-down software included, with
SNMP agent, for Windows 2008,
Vista, 2003, XP; Mac OS X, Linux,
Novell and most popular Unix
operating systems
• The UPS is supplied with a cable for
direct connection to the PC
(Plug and Play)
• RS232 double serial port
• Installation slot for an Emergency
Power Off (EPO) interface to allow
the UPS to be switched off remotely
in an emergency.
• Generator interface: enables
desynchronisation of the UPS output
from a generator supply which may
be subject to phase and frequency
variations. The interface also enables
more economic use of the
battery charger.
The Sentry HPS range features a wide
range of modules and configurations
that can be manufactured into one
complete system to solve your power
problems. Each system is therefore
unique and we ask that you consult our
engineers for your specific application.
OPTIONS
• Isolation transformers
• Various lead acid battery types
including 5 year, 10 year and 20 year
design life, VRLA, NiCad options and
runtimes up to several hours
• Communications software
• Solutions for low input current
distortion
• Closed loop parallel kit option (to be
ordered with the unit)
MAXIMUM RELIABILITY
AND AVAILABILITY
• Connect up to 8 units in parallel or
N+1 redundancy, even of different
power ratings.
The UPS continue to work in parallel
even if one of the interconnecting
communication cables is
disconnected (CLOSED LOOP).
APPLICATIONS
• Servers
• Local Area Network (LAN)
• Data centers
• Telecommunications
• Industrial equipment
• Electro-medical equipment
LOW CONSUMPTION LEVELS
• Sentry HPS can achieve efficiencies
>98% thanks to a selectable
Economy Mode which can be used in
stable electrical environments to
provide power supply continuity
should the mains fail.
67
Sentry HPS
Fig 1- Bock diagram UPS in parallel up to 8 units
EXPANDABILITY
The units can be connected in parallel
up to 8 units to increase power
availability or redundancy.
The single module or the system can
be expanded any time to suit power
requirements without influencing the
initial investment.
Thanks to the peculiarity of the “Hot
System Expansion” feature, the
additional unit can be connected in
parallel while the other units are on-line
and supplying regular power to the
load. The new UPS is on-line and will
be set up automatically.
80 kVA
68
Sentry HPS
Technical data
Three-phase input
Single-phase output
Models
HM8
HM10
HM15
HM20
HM30
HM40
HM60
HM80
Power (kVA)
8
10
15
20
30
40
60
80
HM8
HM10
HM15
HM20
HM30
HM40
HM60
HM80
HM100
HM60
HM80
HM100
HM80
HM100
HM80
HM100
Input
Rated voltage
Voltage range
Frequency range
Power factor
Current harmonic distortion
Soft start
By pass
HM8
HM10
HM15
Inverter output
HM20
HM8
HM10
HM15
HM40
HM20
HM30
HM40
HM60
Maintenance-free lead-acid VRLA AGM / GEL; NiCd
0,2xC10
<1%
HM8
HM10
HM15
HM20
8
6.4
10
8
15
12
20
16
HM20
System
HM8
HM10
HM15
From 190
to 460
From 200
to 470
From 220
From 230
to 490
to 500
555x720x1200
Dimensions (wdh) (mm)
HM30
HM40
HM60
30
40
60
24
32
48
1
230 Vac single-phase
220 ÷ 244 Vac phase/neutral (from control panel)
3:1
± 1%
± 5%
50/60 Hz configurable
110% 125% 150% of the rated current for 5h/10’/1’
± 0,05% on mains failure
± 2% (selectable from ± 1% to ± 5%) with mains supply present
Weight (kg)
Remote signaling
Remote controls
Communication
Operating temperature
Relative humidity
Colour
Noise
Protection degree
Efficiency Smart Mode
Compliance
Internal batteries
HM30
230 Vac single-phase
± 15% (selectable from ± 10% to ± 25% from front panel)
50/60 Hz
± 2% (selectable from ± 1% to ± 5% from front panel)
BackFeed protection; split bypass line
Type
Maximum recharge current (A)
AC ripple voltage
Rated power (kVA)
Active power (kW)
Number of phases
Rated voltage (V)
Regulation of the output voltage
Crest factor (Ipeak/Irms)
Static stability
Dynamic stability
Frequency
Overload
Frequency stability
100
400 Vac three-phase
± 20%
45 ÷ 65 Hz
> 0.92 with harmonic filter
< 5% with harmonic filter
0-100% in 10”
Rated voltage
Permitted voltage range
Rated frequency
Permitted frequency range
Standard features
Batteries
HM100
80
64
HM30
HM40
HM60
HM80
290
340
440
520
800x740x1400
100
80
HM100
650
1070x
740x1400
Volt free contacts
EPO and Bypass
RS232 + remote contacts
O °C / +40 °C
< 95% non condensing
Light grey (RAL 7035)
54 dBA at 1 m
Yes
60 dBA at 1 m
65 dBA at 1 m
IP20
up to 98%
Safety: EN 62040-1-1 (Directive 2006/95/EC); EMC: 6200-2 (Directive 2004/108/EC)
Yes
Yes
Yes
No
No
No
No
No
70
Sentry HPS
Three-phase input
Three-phase output
Models
HT10
HT15
HT20
HT30
HT40
HT60
Power (kVA)
10
15
20
30
40
60
HT10
HT15
HT20
HT30
HT40
HT60
HT40
HT60
Input
Rated voltage
Voltage range
Frequency range
Power factor
Current harmonic distortion
Soft start
By pass
HT10
HT15
Inverter output
HT10
HT20
HT30
HT80
HT15
HT20
HT30
HT40
HT60
HT80
HT60
HT80
Maintenance-free lead-acid VRLA AGM/GEL; NiCd
0,2xC10
<1%
HT10
HT15
HT20
10
8
15
12
20
16
System
HT10
Weight (kg)
From 210
to 480
HT30
HT40
30
40
60
24
32
48
3+N
400 Vac
348 ÷ 424 Vac phase/neutral (from control panel)
3:1
± 1%
± 5%
50/60 Hz configurable
110% 125% 150% of the rated current for 5h/10’/1’
± 0,05% on mains failure;
± 2% (selectable from ± 1% to ± 5%) with mains supply present
HT15
From 220
to 490
Dimensions (wdh) (mm)
Remote signaling
Remote controls
Communication
Operating temperature
Relative humidity
Colour
Noise
Protection degree
Efficiency
Compliance
Internal batteries
HT80
400 Vac three-phase
± 15% (selectable from ± 10% to ± 25% from front panel)
50/60 Hz
± 2% (selectable from ± 1% to ± 5% from front panel)
BackFeed protection; split bypass line
Type
Maximum recharge current (A)
AC ripple voltage
Rated power (kVA)
Active power (kW)
Number of phases
Rated voltage
Regulation of the output voltage
Crest factor (Ipeak/Irms)
Static stability
Dynamic stability
Frequency
Overload
Frequency stability
80
400 Vac three-phase
± 20%
45 ÷ 65 Hz
> 0.9 with harmonic filter
< 5% with harmonic filter
0-100% in 10”
Rated voltage
Permitted voltage range
Rated frequency
Permitted frequency range
Standard features
Batteries
HT80
HT20
HT30
From 230
to 500
555x720x1200
From 282
to 552
HT40
330
80
64
HT60
HT80
450
555
800x740x1400
Volt free contacts
EPO and Bypass
RS232 + remote contacts
O °C / +40 °C
< 95% non condensing
Light grey (RAL 7035)
54 dBA at 1 m
Yes
60 dBA at 1 m
62 dBA at 1 m
IP20
up to 98%
Safety: EN 62040-1-1 (Directive 2006/95/EC); EMC: 6200-2 (Directive 2004/108/EC)
Yes
Yes
Yes
No
No
No
71
Sentry MPS
Three-phase output
QUALITY POWER SUPPLY
SENTRY MPS is an on-line double
conversion UPS (VFI SS 111 in
accordance with IEC EN 62040-3) with
a transformer isolated inverter. With a
compact footprint and high power quality
output, SENTRY MPS is designed to
protect “mission critical” applications
including data processing,
telecommunications, industrial
processes, security and electro-medical
systems.
BATTERY CARE SYSTEM: MAXIMUM
LIFETIME POTENTIAL
MINIMUM INPACT ON SUPPLIES EASY SOURCE
Traditionally, when a mains supply is
present the UPS charges its batteries.
Battery power is used for the inverter
should the input supply fail. Efficient
battery management and care is
therefore essential to the overall
performance of the UPS in an
emergency. The SENTRY MPS Battery
Care System consists of a range
of features designed to provide
optimum performance and enhanced
operating life:
• Dual level charging regime to
optimise recharge currents and lower
recharge times;
• Temperature compensation and deep
discharge protection to reduce overall
battery aging;
• Charge blocking system to reduce
electrolyte consumption and lengthen
the life of VRLA batteries;
• Predictive battery testing to spot
potential battery deterioration and
failure.
SENTRY MPS is also compatible with
different battery technologies: openvase lead acid and AGM and Gel
VRLA, NiCd.
SENTRY MPS technology removes the
problems of over sizing downstream
power sources, whilst improving load
power factors and current harmonics.
The UPS features the latest input current
absorption techniques including
progressive rectifier start-up and the
option to reduce battery charging
currents. These features make SENTRY
MPS one of the most generator
compatible and environmentally friendly
UPS available.
72
FLEXIBILITY
EASY INSTALLATION
SENTRY MPS has a small footprint
(only 0,64 sqm for 200kVA and 1,63
sqm for 400kVA). Front access to
internal assemblies and top panel
ventilation make space allocation within
confined data processing or plant
rooms easy. SENTRY MPS can be
placed against a wall as there is no
requirement for rear or side panel
access for maintenance or ventilation.
MPS Output Power
Leading Cosϕ (capacitive loads)
cosϕ 0,9
cosϕ 1
100% kW
cosϕ 0,8
Lagging Cosϕ (inductive loads)
cosϕ 0,9
cosϕ 0,8
cosϕ 0,7
1,00
cosϕ 0,6
Active Power
SENTRY MPS is suitable for a wide
range of applications including IT and the
most demanding industrial environments
suitable for power capacitive loads such
as blade servers, without any reduction
of the active power, from 0,8 lagging to
0,9 leading. With a broad of accessories
and options, complex configurations and
system architectures can be achieved to
guarantee maximum power availability
and the option to add new UPS without
interruption to existing users. Using the
AROS UPS Group Synchroniser (USG)
and Parallel Systems Joiner (PSJ)
sophisticated inter group parallel and
redundant systems can be achieved to
provide the highest possible levels of
resilience and availability.
0,75
100% kVA
0,50
0,25
-1
-0,8
-0,6
-0,4
-0,2
0
0,2
0,4
0,6
0,8
1
1,2
Reactive Power
FREQUENCY CONVERTER OPERATION
ADVANCED COMMUNICATION
The standard UPS with 400V operating
voltage can be configured on site as 50
to 60Hz frequency converter and viceversa, with or without connection to the
battery. On request units 400V-50Hz
input and 440V-60Hz output are also
available.
For the frequency converter range
400Hz output see page 84.
• Compatible with TeleNetGuard for
remote maintenance
• Advanced, multi-platform
communication for all operating
systems and network environments:
Watch&Save 3000 monitoring and
shut-down software included, for
Windows 2008, Vista, 2003, XP; Mac
OS X, Linux, Novell and most
popular Unix operating systems
• The UPS is supplied with a cable for
direct connection to the PC (Plug
and Play)
• RS232 double serial port
• Installation slot for an Emergency
Power Off (EPO) interface to allow
the UPS to be switched off remotely in
an emergency.
• Remote mimic panel (LED or LCD)
• Generator interface: enables
desynchronisation of the UPS output
from a generator supply which may be
subject to phase and frequency
variations. The interface also enables more
economic use of the battery charger.
APPLICATIONS
• Servers
• Local Area Network (LAN)
• Data centers
• Telecommunications
• Industrial equipment
• Electro-medical equipment
OPTIONS
Input Isolation transformer
UPS Group Syncroniser (UGS)
Parallel System Joiner (PSJ)
Interface for generator
LED remote status panel
LCD based remote control panel
Graphic Display Remote panel
Empty battery cabinets
for prolonged runtime
73
Fig 1- Bock diagram UPS in parallel up to 8 units
EXPANDABILITY
The units can be connected in parallel
up to 8 units to increase power
availability or redundancy.
The single module or the system can
be expanded any time to suit power
requirements without influencing the
initial investment.
Thanks to the peculiarity of the “Hot
System Expansion” feature, the
additional unit can be connected in
parallel while the other units are on-line
and supplying regular power to the
load. The new UPS is on-line and will
be set up automatically.
200kVA
74
DUAL BUS SYSTEM
The Dual Bus System powers the
priority loads from two independent
sources.
This configuration increases the
redundancy and availability level of a
multi-module configuration. Each bus
may consist of a single module or up to
8 modules in parallel, kept in synchro
by the UGS (UPS Group Synchroniser).
expansion or maintenance thanks to
the PSJ (Parallel System Joiner) option.
This provides a lot of flexibility in your
installation in case of maintenance or
when it is necessary to change the
redundancy level of both systems.
Fig. 2 - Dual bus System
DYNAMIC DUAL BUS SYSTEM
Two independent systems set in Dual
Bus Configuration can be merged
together at any time for system
Fig. 3 - Dynamic Dual Bus System
75
Sentry MPS
Technical data
Three-phase input
Three-phase output
Models
Power (kVA)
Input
MPS 100
MPS 120
100
120
MPS 100
MPS 120
MPS 160
MPS 160
Nominal voltage
380 - 400 - 415 Vac three-phase
Voltage tolerance
400 V ± 20%
Frequency
MPS 200
0 ÷ 100% in 30’’ configurable
Permitted frequency tolerance
± 2% (selectable from ± 1% to ± 5% from the front panel)
Standard features
Back Feed protection; separable bypass line
MPS 100
Type
MPS 120
MPS 160
MPS 200
Lead, open vase acid and VRLA, AGM / GEL; NiCd
AC ripple current
Zero
Temperature compensation
Output
200
45 ÷ 65 Hz
Soft start
Battery
MPS 200
160
-0,5 Vx °C
MPS 100
MPS 120
MPS 160
MPS 200
Rated power (kVA)
100
120
160
200
Active power with load PF from 0,9 cap. to 0,8 ind. (kW)
80
96
128
160
Number of phases
3+N
Nominal voltage
380 - 400 - 415Vac three-phase + N
Static stability
± 1%
Dynamic stability
± 5% in 10 msec.
Voltage distortion with linear load
≤1%
Voltage distortion with non linear load
≤3%
Frequency
50 or 60 Hz configurable
Waveform
Sinusoidal
Crest factor (Ipeak/Ipms)
3:1
Overload
System
110% for 60’; 125% for 10’; 150% for 1’
MPS 100
MPS 120
MPS 160
Remote signalling
Voltage-free contacts (configurable)
Remote commands
EPO and bypass
Communication
Double RS232 + remote contacts + 2 communication interface slots
Efficiency Smart Mode
Up to 98%
Dimensions (wdh) (mm)
Weight (kg)
Noise level
Operating temperature
Relative humidity
Protection degree
Colour
Compliance
MPS 200
800x800x1900
640
650
770
810
63 ÷ 68 dBA a 1 m
0 °C / +40 °C
<95% non condensing
IP20
Light grey (RAL 7035)
European Directives: L V 2006/95/EC Low voltage directive
EMC 2004/108/EC Electromagnetic compatibility directive
Standards: Safety IEC EN 62040-1; EMC IEC EN 62040-2 C2
Classification according to IEC 62040-3 (Voltage Frequency Independent) VFI - SS - 111
76
Sentry MPS
Technical data
Three-phase input
Three-phase output
Models
Power (kVA)
Input
MPS 300
MPS 400
MPS 500
MPS 600
MPS 800
300
400
500
600
800
MPS 300
MPS 400
MPS 500
MPS 600
MPS 800
Nominal voltage
380 - 400 - 415 Vac three-phase
Voltage tolerance
400 V ± 20%
Frequency
Power factor
45 ÷ 65 Hz
>0.95 in the Sinus version
>0.93 in the Sinus version
Current harmonic distortion
<3% in the Sinus version
Soft start
0 ÷ 100% in 30’’ configurable
Permitted frequency tolerance
± 2% (selectable from ± 1% to ± 5% from the front panel)
Standard features
Battery
Back Feed protection; separable bypass line
MPS 300
Type
MPS 400
MPS 500
AC ripple current
MPS 800
<1%
Temperature compensation
Output
MPS 600
Lead, open vase acid and VRLA, AGM / GEL; NiCd
-0,5 Vx °C
MPS 300
MPS 400
MPS 500
MPS 600
MPS 800
Rated power (kVA)
300
400
500
600
800
Active power with load PF from 0,9 cap. to 0,8 ind. (kW)
240
320
400
480
640
Number of phases
3+N
Nominal voltage
380 - 400 - 415 Vac three-phase + N
Static stability
± 1%
Dynamic stability
± 5% in 10 msec.
Voltage distortion with linear load
≤1%
Voltage distortion with non linear load
≤3%
Frequency
50 or 60 Hz configurable
Waveform
Sinusoidal
Crest factor (Ipeak/Ipms)
3:1
Overload
System
110% for 60’; 125% for 10’; 150% for 1’
MPS 300
MPS 400
Remote signalling
Remote commands
Communication
Weight (kg)
Noise level
Operating temperature
Relative humidity
Protection degree
Colour
Compliance
MPS 600
MPS 800
EPO and bypass
Double RS232 + remote contacts + 2 communication interface slots
Efficiency Smart Mode
Dimensions (wdh) (mm)
MPS 500
Voltage-free contacts (configurable)
Up to 98%
1630x850x1900 1630x1000x1900
2200
2600
<70 dBA at 1 m
3200x980x1900
3600
440x1000x1900
4000
<77 dBA at 1 m
5300
<80 dBA at 1 m
0 °C / +40 °C
<95% non condensing
IP20
Light grey (RAL 7035)
European Directives: L V 2006/95/EC Low voltage directive
EMC 2004/108/EC Electromagnetic compatibility directive
Standards: Safety IEC EN 62040-1; EMC IEC EN 62040-2 C2
Classification according to IEC 62040-3 (Voltage Frequency Independent) VFI - SS - 111
77
Sentry MPS-HP
ABSOLUTE PROTECTION
ZERO IMPACT SOURCE
BATTERY CARE SYSTEM
Thanks to the double conversion on-line
technology achieved entirely with IGBT
and DSP (Digital Signal Processor)
control, the Sentry MPS-HP series
guarantees maximum protection as well
as high quality power for any type of IT
and industrial load. It is especially suited
for mission critical applications and is
classed VFI SS 111 (Voltage and
Frequency Independent) in compliance
with IEC EN 62040-3 standards.
This series, available in 100 to 250kVA
models, has been designed using a new
configuration that includes an IGBT
rectifier with sinusoidal input current in
place of the traditional thyristor rectifier.
Sentry MPS-HP is a further evolution of
the Sentry MPS series with the added
advantages offered by an IGBT-based
rectifier assembly. This feature further
reduces the impact of the UPS on the
local supply and simplifies installation
where there is limited power capacity in
the form of available electrical supply
rating or generator size. Sentry MPSHP is classed as a “Zero Impact
Source” and provides:
• low input current distortion – less than
2,5%
• high input power factor 0.99
• power walk-in function that ensures
progressive rectifier start up
• delayed start up phased with the
return of mains power supply, when
several UPS are connected in the
system.
Sentry MPS-HP also performs the role
of a high performance filter, protecting
its upstream power supply sources
from any harmonics and reactive power
generated by the loads powered.
Sentry MPS-HP uses the Battery Care
System, also available on the traditional
Sentry MPS models, which optimises
battery performance in order to extend
the battery life for as long as possible.
78
FLEXIBILITY
Sentry MPS-HP models feature an
output transformer with galvanic isolation
(between the load and the battery
supply) to provide greater versatility and
installation options. The UPS can be
supplied from two separated power
sources (mains power and a second
emergency standby source) which can
help increase the resilience of parallel
system configurations.
MAIN CHARACTERISTICS
• Efficiency up to 98%;
• Compact footprint: only 0.85 m2 for
the 250kVA UPS model;
• Reduced weight;
• Double electronic and galvanic
protection of the load from the battery.
Details of the connection
The entire Sentry MPS-HP range is
suitable for a wide range of
applications thanks to the flexibility of
the configurations, accessories and
options and choice of performance
levels: compatible with capacitive
loads, such as blade servers, without
any reduction in active power, ranging
from 0.9 lead to 0.8 lag and up to 0.8
capacitive power with a low derating
equal to 15% of the active power (kW).
Efficient and reliable power supply for
mission critical applications is
guaranteed by operating in redundancy
and power parallel mode with up to 8
units (N+1), and by the Dual Bus
System and Dynamic Dual Bus system
configurations.
OPTIONS
Isolation transformer
Synchroniser device (UGS)
Parallel Systems Joiner device (PSJ)
Interface for generator set
Closed Loop kit (to be ordered with
the UPS)
Empty battery cabinets or cabinets
for extended runtime
APPLICATIONS
• Servers
• Local Area Network (LAN)
• Data centers
• Telecommunications
• Industrial equipment
• Electro-medical equipment
79
Sentry MPS-HP
Technical data
Three-phase input
Three-phase output
Models
Power (kVA)
Input
MPS-HP 100
MPS-HP 120
MPS-HP 160
MPS-HP 200
MPS-HP 250
100
120
160
200
250
MPS-HP 100
MPS-HP 120
MPS-HP 160
MPS-HP 200
MPS-HP 250
Nominal voltage
380 - 400 - 415 Vac three-phase
Range acceptable without battery intervention
300 ÷ 480 Vac
Frequency
45 ÷ 65 Hz
Power factor
>0.99
Current harmonic distortion
<2.5% THDi
Soft start
0 ÷ 100% in 30’’ (selectable)
Permitted frequency tolerance
± 2% (selectable from ± 1% to ± 5% from the front panel)
Standard features
Battery
Back Feed protection; separable bypass line
MPS-HP 100
MPS-HP 120
Type
AC ripple current
MPS-HP 200
MPS-HP 250
Zero
Temperature compensation
Output
MPS-HP 160
Free lead-acid, and VRLA AGM / GEL; NiCd
-0,5 Vx °C
MPS-HP 100
MPS-HP 120
MPS-HP 160
MPS-HP 200
MPS-HP 250
Rated power (kVA)
100
120
160
200
250
Active power with load PF from 0,9 cap. to 0,8 ind. (kW)
80
96
128
160
200
Number of phases
3+N
Nominal voltage
380 - 400 - 415 Vac three-phase + N
Static stability
± 1%
Dynamic stability
± 5% in 10 msec.
Voltage distortion with linear load
≤1%
Voltage distortion with non linear load
≤3%
Frequency stability on battery
0.05%
Frequency
50 or 60 Hz (selectable)
Overload
110% for 60’; 125% for 10’; 150% for 1’
System
MPS-HP 100
MPS-HP 120
MPS-HP 160
MPS-HP 200
Remote signalling
Voltage-free contacts (configurable)
Remote commands
EPO and bypass (configurable)
Communication
Double RS232 + remote contacts + 2 slots for communication interface
Efficiency Smart Mode
Up to 98%
Dimensions (wdh) (mm)
Weight (kg)
Noise level
Operating temperature
800x850x1900
656
1000x850x1900
700
800
<95% non condensing
IP20 (others on request)
Classification according to IEC 62040-3
1000
0 °C ÷ +40 °C
Protection degree
Compliance
910
63 ÷ 68 dBA at 1 m
Relative humidity
Colour
MPS-HP 250
Light grey (RAL 7035)
Safety: EN 62040-1-1 (directive 2006/95/EC);
EMC: EN 62040-2 (directive 2004/108/EC)
(Voltage Frequency Independent) VFI - SS - 111
80
81
Sentry MPS
Single-phase output
PROTECTION FOR INDUSTRIAL
APPLICATION
MINIMUM IMPACT ON SUPPLIES - EASY
SOURCE
MPS 1Ph is an on-line double conversion
UPS (VFI SS 111 in accordance with IEC
EN 62040-3) with transformers isolated
inverter and rectifier. MPS 1Ph has a
compact foot print and high quality output
to provide the ultimate power protection for
industrial applications:
industrial processes, petrochemical, power
plant, energy etc.
MPS 1Ph technology removes the
problems of over sizing upstream power
sources, whilst improving load power
factors and current harmonics. The UPS
features the latest input current absorption
techniques including progressive rectifier
start-up and the option to reduce battery
charging currents. These features make
MPS 1Ph one of the most generator
compatible and environmentally friendly
UPS available.
INDUSTRIAL ENVIRONMENT
MPS 1Ph is suitable for severe installation
environments such as petrochemical
manufacturing sites, where the operating
conditions (levels of vibration, mechanical
stress, ambient temperatures and dust
ingress) require a more robust and
industrialized UPS design to those installed
within, for example, data centres.
HIGH Icc
A high short-circuit current (Icc = 3 In)
making the UPS suitable for loads with high
current peaks; during switch-on or a load
step-change.
220V DC VOLTAGE
An input transformer and isolated inverter to
protect the 220Vdc bus bar (from 108 to
114 blocks), the recognised industrial
standard.
REDUNDANT VENTILATION
100% redundant ventilation with 50% fan
loading at nominal load and each fan
monitored for breakdown or failure.
FLEXIBILITY
With a broad range of accessories and
options, complex configurations
and system architectures can be achieved
to guarantee maximum power
availability and the option to add new UPS
without interruption to existing
users. Using the Aros UPS Group
Synchroniser (USG) and Parallel
Systems Joiner (PSJ) sophisticated inter
group parallel and redundant
systems can be achieved to provide the
highest possible levels of
resilience and availability.
BATTERY CARE SYSTEM: MAXIMUM
LIFETIME POTENTIAL
ADVANCED COMMUNICATION
Traditionally, when a mains supply is
present the UPS charges its batteries.
Battery power is used for the inverter
should the input supply fail. Efficient
battery management and care is therefore
essential to the overall performance of the
UPS in an emergency. The MPS 1Ph
Battery Care System consists of a range
of features designed to provide optimum
performance and enhanced operating life:
• Dual level charging regime to optimise
recharge currents and lower recharge
times
• Temperature compensation and deep
discharge protection to reduce overall
battery aging
• Charge blocking system to reduce
electrolyte consumption and lengthen
the life of VRLA batteries
• Predictive battery testing to spot
potential battery deterioration and failure
MPS 1Ph is also compatible with different
battery technologies: open-vase lead acid
and AGM and Gel VRLA, NiCd.
• Compatible with TeleNetGuard for
remote maintenance
• Advanced, multi-platform
communication for all operating
systems and network environments:
Watch&Save 3000 monitoring and
shut-down software included, for
Windows 2008, Vista, 2003, XP; Mac
OS X, Linux, Novell and most
popular Unix operating systems
• The UPS is supplied with a cable for
direct connection to the PC (Plug
and Play)
• RS232 double serial port
• Installation slot for an Emergency
Power Off (EPO) interface to allow
the UPS to be switched off remotely in
an emergency.
• Remote mimic panel (LED or LCD)
• Generator interface: enables
desynchronisation of the UPS output
from a generator supply which may be
subject to phase and frequency
variations. The interface also enables more
economic use of the battery charger.
82
Sentry MPS
Technical data
Three-phase input
Single-phase output
Models
Power (kVA)
Input
MPM 30
MPM 40
30
40
MPM 30
MPM 40
MPM 60
380 - 400 - 415 Vac three-phase
Voltage tolerance
400 V ± 20%
Frequency
MPM 80
45 ÷ 65 Hz
Power factor
≥0.93
Current harmonic distortion
<5% C
Soft start
0 ÷ 100% in 120’’ configurable
Permitted frequency tolerance
± 2% (selectable from ± 1% to ± 5% from the front panel)
Standard features
Back Feed protection; separable bypass line
MPM 30
MPM 40
Number of cells
MPM 60
MPM 80
MPM 80
108 ÷ 114
Max Vdc
274 V
Temperature compensation
Output
80
MPM 60
Nominal voltage
Battery
MPM 80
60
-0,5 Vx °C
MPM 30
MPM 40
MPM 60
Rated power (kVA)
30
40
60
80
Active power (kW)
24
32
48
64
Nominal voltage
230Vac single-phase
Static stability
± 1%
Dynamic stability
± 5%
Voltage distortion with linear load
<1%
Voltage distortion with non linear load
<3%
Frequency
50 or 60 Hz configurable
Crest factor (Ipeak/Ipms)
3:1
Overload
110% for 60’; 125% for 10’; 150% for 1’
Short circuit current
System
3 I nom.
MPM 30
MPM 40
MPM 60
Remote signalling
Voltage-free contacts
Remote commands
EPO and bypass
Communication
Double RS232 + remote contacts + 2 communication interface slots
Efficiency
Up to 94%
Dimensions (wdh) (mm)
Weight (kg)
800x800x1900
850
1600x800x1900
900
1400
Noise level
63 ÷ 68 dBA a 1 m
Ventilation
Redundant fans
Operating temperature
0 °C / +40 °C
Relative humidity
Protection degree
Colour
Compliance
Classification as per IEC 62040-3
MPM 80
1500
<95% non condensing
IP20
Light grey (RAL 7035)
Safety: EN 62040-1-1 (Directive 2006/95/EC);
EMC: EN 62040-2 (Directive 2004/108/EC)
(Voltage Frequency Independent) VFI - SS - 111
83
Sentry MPS FC 400 Hz
Frequency Converter
Sentry MPS FC series is a frequency
converter based on the Sentry MPS UPS
that can accept 50/60Hz and deliver a
400Hz output.
The device has a double conversion design
(VFI SS 111 compliant with IEC EN 62040-3)
with a transformer-isolated Inverter.
The output voltage is 208 Vac and
configurable at 200Vac on site with a 115
Vac version available on request.
The basic design is a solid state generator
with IGBT- based Inverter controlled using
PWM techniques.
It is ideal for applications such as avionic
repair workshops, hangars, aircraft ground
power in civil airports and military bases.
EASY TO INSTALL
Sentry MPS FC is compact with a foot
print of only 0.64m2. Front access to
internal assemblies and top panel
ventilation make space allocation within
confined data processing or plant room
easy. Sentry MPS FC can be placed
against a wall as there is no requirement
for rear or side panel access for
maintenance or ventilation.
APPLICATIONS
•
•
•
•
•
Aircraft ground power
Airports
Navy
Military equipment
Testing laboratories
The Easy Source input, the Battery Care
System as well as the flexibility and
communication features are the same as
those offered on the traditional Sentry
MPS series.
OPTIONS
•
•
•
•
•
•
Input Isolation transformer
2 programmable relay cards
Protection degrees higher than IP20
LED remote status panel
LCD based remote Control panel
Remote Graphics Panel
MINIMUM IMPACT
ON POWER SUPPLY – EASY SOURCES
Sentry MPS FC technology removes
problems of over sizing upstream power
sources, whilst improving load power
factors and current harmonics.
The UPS features the latest input current
absorption techniques including progressive
rectifier start-up and the option to reduce
battery charging currents. These features
make Sentry MPS FC one of the most
generator-compatible and environmentally
friendly frequency converters on the market.
84
Sentry MPS FC
Technical data
Three-phase input
Single-phase output
Models
Power (kVA)
Input
MFC400-30
MFC400-60
MFC400-80
MFC400-100
MFC400-120
30
60
80
100
120
MFC400-30
MFC400-60
MFC400-80
MFC400-100
MFC400-120
Nominal voltage
380 - 400 - 415 Vac three-phase
Voltage tolerance
400 V ± 20%
Frequency
45 ÷ 65 Hz
Power factor
≥0.93 (in the Plus version)
Current harmonic distortion (THDi)
<5% (in the Plus version)
Soft start
Output
0 ÷ 100% in 120’’ configurable
MFC400-30
MFC400-60
MFC400-80
MFC400-100
MFC400-120
Rated power (kVA)
30
60
80
100
120
Active power (kW)
24
48
64
80
96
Nominal voltage
208Vac 3Ph + N (settable 200 V)
Static stability
± 1%
Dynamic stability
± 5%
Voltage distortion with linear load
<3%
Voltage distortion with non linear load
<4%
Frequency
400 Hz
Crest factor (Ipeak/Ipms)
3:1
Overload
System
110% for 60’; 125% for 10’; 150% for 1’
MFC400-30
MFC400-60
MFC400-80
Remote signalling
Voltage-free contacts
Remote commands
EPO and ON/OFF
Communication
Weight (kg)
Noise level
Operating temperature
Relative humidity
Protection degree
Colour
Compliance
Classification as per IEC 62040-3
MFC400-120
Double RS232 + remote contacts + 2 communication interface slots
Efficiency
Dimensions (wdh) (mm)
MFC400-100
Up to 92%
550x740x1200
330
800x800x1900
480
500
530
560
61 to 63 dBA at 1 m
0 °C to 40 °C (50°C @ 75% load)
<95% non condensing
IP20
Light grey (RAL 7035)
Safety: EN 62040-1-1 (Directive 2006/95/EC);
EMC: EN 62040-2 (Directive 2004/108/EC)
(Voltage Frequency Independent) VFI - SS - 111
85
IRMS (Intelligent Redundant Multi-Switch)
Multi-Switch is a rackmount source
transfer switch that can supply up to
eight loads from two AC power sources. Should one source fails, the other
automatically powers the load. The
sources can be two separate AC sources including mains power and UPS,
or a combination of the two.
PROTECTION AGAINST LOAD FAULTS
If a fault occurs with one of the loads
(for example due to a shortcircuit
or overload), IRMS will disconnect the
load to prevent disruption to the others.
IRMS protects sensitive installations
from both power and hardware faults.
CHARACTERISTICS
PRINCIPLE OF OPERATION
The IRMS provides electrical distribution and remote management for up to
eight network users, powered from two
direct mains supplies or UPS or a combination of both.
The Multi-SWITCH can connect each
user (up to eight, each with a
maximum power demand not greater
than 4A), to either of the two
power sources (1 and 2). Load
demand is shown on the LCD.
See “principle of operation” diagram.
PROTECTION AGAINST POWER
SUPPLY FAILURES
If one of the two power source fails or
falls outside specification, IRMS will
transfer the connected loads to the
second power source
(switching is instantaneous even if the
two sources are not in phase).
• Full protection against mains failures
and load faults
• Flexible power sources: IRMS can
be powered from 2 different
sources (2 mains supplies, 2 UPS
or a combination of both. Note than
the UPS can be of a different size)
• Designed for installation in a 19”
rack-mount cabinet
• LCD to provide
measurements/alarms/states information
• Management software included
• Remote monitoring serial interface
• No signal connection is required
between Multi-SWITCH and the
power sources or supplied hardware
• Configuration software provided as
standard
• Slot-in SNMP network adapter card
86
IRMS Multi-Switch
Technical data
2 inputs
8 outputs
Models
Multi-Switch (2 inputs – 8 outputs)
Power
8x4A output sockets
Input
Multi-Switch (2 inputs – 8 outputs)
Input voltage
180 - 276 Vac
Rated frequency
50/60 Hz
Maximum load for each input (A)
16
Input sockets
2 IEC 320 (16A)
Output
Multi-Switch (2 inputs – 8 outputs)
Output voltage
Selection of one of the two input sources
Maximum load for each output (A)
4
Output sockets
8 IEC 320 10A
Environmental
Multi-Switch (2 inputs – 8 outputs)
Weight (kg)
10
Dimensions (wdh) (mm)
19”x360x2U
Operating temperature
O °C / +40 °C
Relative humidity
< 95% non condensing
Protection
Overcurrent - overvoltage - undervoltage - back-feed protection
Safety compliance
EN 62040-1 EMC EN 62040-2 Directives 2006/95/EC - 2004/108/EC EN 62040-3
Maximum altitude
3000 m
Maximum altitude (storage conditions)
Communication
6000 m; 45 °C
RS232
Enclosure protection rating
IP 20
Colour
Dark grey (RAL 5004)
Noise
<35 dBA at 1 m
Details
FRONT
Output sockets
Ethernet (option)
Serial RS232
BACK
Input thermal
protection reset
Input sockets
87
Static Transfer Switch (STS)
Sentry STS
Sentry STS is a static transfer switch
commonly used within power continuity
applications to improve resilience. The
system can be used in conjuction with
UPS or as separate standalone
devices.
OPERATING PRINCIPLE
Sentry STS adds a source of
redundancy to a critical installation and
automatically transfers the connected
load between two separate AC power
sources. The transfer can be automatic
when an input power supply fails
outside set tolerances or be manually
forced using the front panel keypad or
remotely via a communications
network.
PROTECTION AGAINST
POWER FAILURES
In the event that one of the two power
sources does not return to the
accepted tolerance values, the Sentry
STS will transfer the other loads over to
the second power source (this
happens instantly if the two sources
are in phase).
PROTECTION AGAINST
ENVIRONMENTAL DISTURBANCES
OVERLOADS AND LOAD FAULTS
In the event of an overload or fault
condition, the internal protection
system within the STS device can be
configured to disconnect power at
defined levels. In the extreme situation
of a downstream short circuit, Sentry
STS can disconnect the load to
prevent disruption.
CHARACTERISTICS
• Full protection of critical industrial
and IT applications against power
failures and faults on the load.
• Full microprocessor control which
guarantees:
- fast and safe transfer between
the power sources;
- monitoring of all parameters on
the LCD display;
- constant control of the SCRs;
- remote advanced diagnostics
(RS232 and TCP/IP).
• Redundant power circuits:
- power is supplied to the internal
logic by two separate and
independent power circuits that are
hot swappable so as to ensure no
break in the supply to the loads;
- in the event that the power supplied
by both sources fails, full system
operation is guaranteed by the Power
Supply Backup function that provides
backup power to the circuits from an
external, independent standby power
source.
88
LED
FUNCTION
L1
S1 Priority source
L2
S2 Priority source
L3
S1 Present
L4
S2 Present
L5
Static Switch SS1 closed
L6
Static Switch SS2 closed
L7
Alarm indicator
L8
Output selection ON/OFF
5 function keys and LCD operations
• High protection:
- in the event of an output short
circuit, Sentry STS will block the
transfer between the two power
sources eliminating the risk of
propagating the short circuit and its
effects on the other loads;
- a back-feed control circuit will
trigger automatic protection devices
to avoid energy feeding back to one
of the inputs of the Sentry STS;
- Sentry STS has double redundant
ventilation called “fan redundancy
plus”. Thanks to this function, in the
remote possibility that two fans both
fail at the same time, the others
would still be able to dissipate the
heat generated by a nominal load at
a temperature of up to 40°C.
The fans can be hot swapped so as
to ensure no break in system
operation during the repair.
• Easy front access:
- power cable connections are easily
accessed with entry from below;
- board slots are positioned in a
dedicated area to allow rapid
diagnosis/replacement;
- all parts subject to controls,
maintenance and/or replacement.
3P + N
Source 1
Input
3P + N
Source 2
Input
Input
MCCB 1
Input
MCCB 2
S2
S1
Maintenance
Switch 2
Maintenance
Switch 1
S4-2
SS2
SS1
S4-1
Output
Switch 1
S3
3P + N
Output
89
Sentry STS in REDUNDANT Mode
UPS
The reliable secondary source [AS] will
power the load only and exclusively
when the primary source (PS) fails, so
as to guarantee maximum redundancy
and quality of the power supply to the
loads.
UPS
[PS]
[AS]
USER 1
UPS
Sentry STS in CROSS FEEDING Mode
The two sources power a number of
critical loads using the Sentry STS
configured in such a way as to make
one of the two power sources the
priority source (PS). In cases of power
faults or failure on one of the two
sources, the other one will be able to
supply power to all the loads
connected to the system.
UPS
[PS]
[AS]
USER 1
[PS]
[AS]
USER 2
UPS
Sentry STS in BACK UP Mode
Sentry STS powers a number of loads
using the priority source (PS). The
secondary source (AS) is formed by
independent and separate sources
which can supply standby power
should the priority source (PS) fail
suddenly.
Independent
separate lines
[PS]
[AS]
USER 1
[PS]
[AS]
USER 2
System B
Bypass 1
Mains
UPS2A
Mains
UPS1B
Battery
UPS1A
Bypass 2
Mains
UPS2B
Battery
Mains
Battery
System A
Battery
The solution offered by AROS
guarantees maximum reliability and
ensures no break power supply in all
operating conditions thanks to the UGS
option that keeps the two systems A
and B perfectly synchronised.
The flexibility of the UGS system is able
to guarantee that the power sources
remain synchronised even when one of
the two systems is not AROS UPS
model but made by another
manufacturer or when the input
sources are not UPS’s.
UGS
Sinchroniser
Static
Transfer
SWITCH
Load 1
Load 3
Static
Transfer
SWITCH
Load 2
Load 4
90
Sentry STS
Models (1)
Nominal current (A)
Input
Technical data
STS 100-X
STS 150-X
STS 200-X
STS 250-X
STS 300-X
STS 400-X
100
150
200
250
300
400
STS 100-X
STS 150-X
STS 200-X
STS 250-X
STS 300-X
STS 400-X
Nominal voltage - sources S1/S2
380 - 400 - 415 Vac 3-phases with neutral
Input voltage tolerance
180÷264 Vac (selectable)
Switched input phases
3+N (4-pole) - 3 (3-pole)
Nominal frequency
50/60 Hz
Input frequency tolerance
+/-10% (selectable)
Distribution compatibility
IT, TT, TNS, TNC
Opereting features
STS 100-X
STS 150-X
Transfer typology
STS 200-X
STS 250-X
STS 300-X
STS 400-X
“Break Before Make” (no sources overlapping)
Available transfer modes
Automatic / Manual / Remote
Transfer time for source failure
< 4 msec (S1/S2 synchronised)
10 msec (S1/S2 not synchronised)
System
STS 100-X
STS 150-X
STS 200-X
STS 250-X
STS 300-X
STS 400-X
Weight (kg)
155
175
205
210
220
240
Dimensions (wdh) (mm)
685x530x1500
Efficiency at full load (%)
685x580x1770
> 99
Noise level at 1 m from front
(from 0 to full load) - (dBA)
Storage temperature range
Ambient temperature
Relative humidity
52
55
-10°C to +50°C
0°C ÷ +40°C
90% non-condensing
Max. Installation height
1000 m at rated power (-1% power for every 100 m above 1000 m) - Max 4000 m
Standard compatibility
EN 62310-1 (safety) EN 62310-2 (electromagnetic compatibility)
Colour Light grey
RAL 7035
Index of protection
IP 20
(1) X= 3 in cases of 3-pole switching (3 phases) ; X=4 in cases of 4-pole switching (3 phases + Neutral)
91
Software and accessories for total reliability
in controls and communication
Watch&Save 3000 - Communication software
Watch&Save 3000 provides efficient, user-friendly UPS management using
bar chart displays to show major operational information such as the input
voltage, UPS load % and batteries charge %. The software also provides
detailed information on fault conditions and UPS operating characteristics.
Watch&Save 3000 has been developed with a client/server architecture that
makes it flexible and easy to use, and provides multi-lingual and on-line support.
CHARACTERISTICS
• Sequential and priority-based shutdown: Watch&Save 3000 provides
unattended shut-down of single and networked PCs, saving any active
work and the most widely used applications Windows. Users can define
their own shutdown procedures and establish the order in which critical
computers (such as servers) are to be powered down.
Watch&Save 3000 provides detailed graphical
displays.
• Multi-platform compatibility: Watch&Save 3000 uses the TCP/IP
communications protocol to achieve standardised management and
monitoring across the widest possible range of platforms. This makes it
possible to monitor computers with different operating systems from a
single console, for example monitoring a UNIX server from a PC with
Windows and also connecting to UPS located in different geographical
areas using dedicated networks (intranets) or the Internet.
• Event scheduling: Watch&Save 3000 users can program their own
shutdown procedures, detailing power-off and power-up scenarios to
increase system safety and, equally important, power economy.
A standard screen displays information on the
load, batteries status, alarms etc.
• Messages management: Watch&Save 3000 keeps users constantly
informed about the status of their local and network UPS. A list can be
defined of users who should receive e-mail messages, faxes and SMS
when faults or sudden blackouts occur.
• Integrated SNMP agent: Watch&Save 3000 features an integrated SNMP
agent for management of the UPS. This agent is able to send all the UPS
information and generate traps using the RFC 1628 MIB standard. This
makes it possible to manage the UPS in compatible SNMP management
stations such as HP Open View, Novell Managewise and IBM NetView.
• Wap server integrated: Watch&Save 3000 allows the user to monitor a UPS
through WAP mobile phone.
• Security, easy to use and connect, communication is password protected
to ensure UPS system security. Using the new discovery/browsing function,
all the AROS UPS connected to a protected computer or LAN can be
displayed in a list format. In the absence of a LAN connection, support is
provided for modem-based communication.
92
Software and accessories for total reliability
in controls and communication
Watch&Save 3000 - Communication software
GRAPHIC MONITORING OF UPS AND ENVIRONMENTAL SENSORS
STATUS
Watch&Save 3000 is a simple but powerful AROS UPS management tool.
There are various graphic versions for all the operating systems.
DETAILED UPS PARAMETER DISPLAY AND ENVIRONMENTAL
SENSORS
Watch&Save 3000 provides all the information required for first level diagnostics.
EVENTS LOG AND GRAPHICAL DISPLAY
All information can be displayed in block format.
All changes in UPS operating status are logged and displayed in a graphical
format from which the user can monitor trends in the mains electrical
parameters monitored.
PROGRAMMING OF UPS PARAMETERS
The user can select several options remotely: turn the UPS on or off, restart
after a power loss and instigate a battery test.
GRAPHIC MONITORING OF UPS STATUS VERSION FOR MAC OS X
AROS Watch&Save 3000 software is the only UPS control and shut-down
software running under Macintosh with a client-server cross platform
architecture.
It allows integration in TCP/IP networks with Windows, Novell, IBM OS/2 and
the most widely used UNIX operating systems. Watch&Save 3000 supports
the NetMan Plus series of network agents and provides multi-language support.
BLOCK AND FUNCTIONAL DIAGRAMS
Watch&Save 3000 also displays the UPS in block format providing the user
with information regarding operating status.
NOTIFICATION OF ALARMS VIA E-MAIL, SMS, FAX AND VOICE
Watch&Save 3000 can be configured to forward alarm messages
automatically via e-mail, SMS, fax and voice.
Operating systems supported
• Windows 98, Me, NT 4.0, 2000, 2003, XP, Vista 2008 Server on processors X86,X86_64 e IA64
• Linux on processors X86, X86_64 e IA64
• Novell Netware 3.x, 4.x, 5.x, 6
• Mac OS X
• The most widely used UNIX operating systems such as: IBM AIX, HP, SUN Solaris INTEL and SPARC, SCO Unixware and
Open Server, Silicon Graphics IRIX, Compaq Tru64 UNIX and DEC UNIX, Open BSD UNIX and FreeBSD UNIX, NCR UNIX
• HP OPEN VMS
All the trademarks indicated are the property of their respective owners.
93
Software and accessories for total reliability
in controls and communication
PowerNetGuard - Supervision software
PowerNetGuard software centralises UPS management using network
interface (SNMP) communications. It is ideal for Data Centre managers and
medium to large sized networks. PowerNetGuard uses the RFC1628
standard Management Information Base (MIB) and ensures standardised UPS
management wherever they are located.
CHARACTERISTICS
• Centralised control of remote UPS via Ethernet with SNMP protocol
• Multiple-level display of geographical areas, building plans, maps, etc.
• Multi-user access with various levels of security
• Compatible with NetMan Plus and RFC1628 standard network interface
(SNMP)
• Graphs of physical input and output values stored and backed up to file
• Alarm notification via e-mail and SMS
• Wap Server
• Operating systems supported: Windows (98, ME, NT, 2000, 2003, XP and
Vista), Linux, MacOSX, Solaris 8, 9 and 10 and Silicon Graphics IR
Centralized control of remote UPS
1.
1.
2.
1.
1. NETMAN PLUS CONNECTION
2. THIRD PART SNMP AGENT
94
Software and accessories for total reliability
in controls and communication
NetMan 101/102 Plus - Network agent
The NetMan Plus network agent allows UPS management across a LAN
using any of the main network communication protocols - TCP/IP, HTTP and
network interface (SNMP).
NetMan Plus enabled UPS integrate easily into medium and large sized
networks and provide reliable communications between the UPS and
management systems employed.
NetMan 101 Plus
CHARACTERISTICS
• Configured via TELNET or a serial terminal
• Compatible with Watch&Save 3000 and PowerNETGuard control software
• Supports the network interface (SNMP) standard communication protocol
with proprietary RFC 1628 and MIB
• Integrated Web server for browser-based display
• SNMP with RFC 3433 to manage the environmental sensors
• Teleguard modem compatible
• Firmware upgradeable through the serial port
• E-mail sent through SMTP server.
NetMan 101 Plus
ENVIRONMENTAL SENSORS
The NetMan Plus environmental sensors monitor and record environmental
conditions as well as activities in protected areas and at the premises where
the UPS is installed. Environmental sensors monitor and record environmental
conditions and activities within a designated building area. The sensors provide extensive management and control, triggering cooling fans and locks in
response to changes in temperature and humidity. Remote monitoring and
control can be provided via internet, SNMP and AROS Watch&Save 3000 software.
NetMan Plus can support up to 6 separate sensors. The environmental sensors are easy to install and do not need a separate external power supply.
Environmental sensors
The following sensors are available:
- Sensor for temperature: -55 +125 °C
- Sensor for temperature: -55 +125 °C and humidity: 0- 100%
- Sensor for temperature: -55 +125 °C and digital I/O: 0-12Vdc.
In 1A max out 48Vdc
APPLICATION DIAGRAM
Air conditioner
Temperature
sensor
Temperature
sensor
Smoke
detector
95
Software and accessories for total reliability
in controls and communication
MultiCom 301/302 - Protocol converter
The MultiCom 301/302 protocol converter may be used to monitor the UPS
using the MODBUS/JBUS protocol on RS485 or RS232 serial lines. It can
also manage a second, independent RS232 serial line that can be used to
connect other devices such as the Netman Plus 101 or a PC that uses the
Watch&Save 3000 software.
CHARACTERISTICS
•
•
•
•
•
MultiCom 301
Port configuration for MODBUS/JBUS as RS232 or RS485
Management of two independent serial lines
Suitable for Building Management System (BMS) integration
LED communication flow indicators
Firmware upgradeable through the serial port
MultiCom 302
MultiCom 351/352 - Serial link duplexer
The MultiCom 351/352 is a serial duplexer that allows two devices to be
connected to a single serial port on a UPS.
It can be used where numerous serial connections and multiple UPS polling
are required, and is ideal for LAN networks with a firewall.
CHARACTERISTICS
MultiCom 351
• Cascading configuration giving a maximum of 4 serial communication ports
• LED communication flow indicators
• Firmware upgradeable through the serial port
MultiCom 352
MultiCom 362 - Serial / USB port
MultiCom 362 provides a UPS with an additional RS232 serial interface or
USB port. The USB port allows the UPS to communicate with Apple
Macintosh computers as well as Windows and Linux operating systems.
CHARACTERISTICS
• Compatible with USB 1 or 2
• Compatible with Watch&Save 3000
MultiCom 362
96
Software and accessories for total reliability
in controls and communication
MultiCom 372 - Serial / ESD port
MultiCom 372 provides a UPS with an additional RS232 serial interface port.
The card has Emergency Power Off (EPO) and Remote Shut Down (RSD)
inputs with terminal connections.
CHARACTERISTICS
• EPO and UPS shutdown interface
• 12Vdc 80mA contact option
MultiCom 372
MultiCom 382 - Contacts / ESD board
MultiCom 382 provides a set of relay contacts to provide UPS alarm and status indication. The contacts are connected through terminal connections.
Signal contacts include Emergency Power Off (EPO), Remote Shut Down
(RSD), On Battery, On Bypass, Alarm and Low battery. The contacts are
change over or normally open.
CHARACTERISTICS
MultiCom 382
• Max. 3A current at 250Vac
• Signal contact customisation
Multi I/O - Protocol converter
Multi I/O has configurable input and output signal contacts to allow UPS
integration with control systems. It can be used to connect two devices to a
single UPS serial communication port. It can also communicate using the
MODBUS/JBUS protocol on RS485 lines.
CHARACTERISTICS
Multi I/O, slot version
• 8 analog/digital inputs
• 8 relay outputs to monitor UPS and mains status
• It can control two independent RS232/RS485 serial lines to monitor the
UPS and its operating states using the MODBUS/JBUS protocol
• Firmware upgradeable through the serial port
Multi I/O, box version
USB Converter - USB serial converter
The RS232-USB converter allows UPS without a USB port to connect to
Macintosh, Windows and Linux PCs with this type of port.
CHARACTERISTICS
• Compatible with USB 1or 2
• Compatible with Watch&Save 3000
USB Converter
97
Software and accessories for total reliability
in controls and communication
Multifunction I/O - Serial link / contacts duplexer
Multifunction I/O is a Sentinel 6 range accessory with which you can associate the battery operation, by-pass, alarm and battery depleted status reports
with dry contacts (maximum current 8A/250V). The accessory also has an
input which is used to set up the configurable remote on, remote off and
remote on/off functions through the UPSTools software (vers. 1.3.3 or higher).
The functions are provided for UPS with firmware version SWM020-01-16 or higher.
CHARACTERISTICS
Multifunction I/O
• Max. current 8A at 250Vac
• Possibility of configuring the signal-to-contact associations
• Pass-through serial link for PC connection
MultiCom 401 - PROFIBUS
The MultiCom 401 is an accessory with which you can connect a UPS to a
Profibus DP network. With this device management and monitoring of the
UPS can be integrated in a control system based on one of the field buses
most widely used in industry for communication between control/automation
systems and distributed I/O.
CHARACTERISTICS
•
•
•
•
•
PROFIBUS DP-V1 Protocol
Configurable address from 0 to 99
Profidrive V2 PP05
Configurable baud rate from 9.6 kBit/s to 12 MBit/s
Led reporting the communication flow
MultiCom 401
KIT for AS400 and i-Series - Communication Kit
The IBM AS/400 has a single-level memory management feature that makes it
compulsory for the system to be shutdown in a controlled and orderly manner.
Without UPS protection an AS/400 is not protected from mains failures.
A momentary loss of power can cause hardware damage, data corruption and
a lengthy reboot period. The AROS AS/400 interface kit allows a UPS to be
connected to the AS/400 to initiate an orderly system shutdown on mains failure.
CHARACTERISTICS
• Compatible with all AS/400 systems
• Supports all the AROS UPS ranges
98
Software and accessories for total reliability
in controls and communication
Graphic Remote Panel
Graphic Remote Panel is a remote monitoring device that can provide a
detailed UPS status overview in real time. It is compatible with all Aros UPS
with RS232 and can display values for UPS specific input and output
supplies, and battery set measurements. Graphic Remote Panel has a highdefinition graphical display and can report in 7 languages: English, Italian,
German, French, Spanish, Russian and Chinese. It has 3 independent serial
ports, one of which allows for UPS monitoring via the MODBUS/JBUS
protocol (on either an RS485 or RS232 serial line). The others can be used
with devices such as the Netman 101 Plus or a PC running Watch&Save
3000 software.
Graphic Remote Panel
CHARACTERISTICS
•
•
•
•
•
Graphical high definition LCD panel
Three independent serial connections
Compatible with most BMS management programs
Communications flow LED status indicator
Serial port upgradeable firmware
99
Bypass Accessories
External Manual Bypass 16A – Manual Bypass
The manual bypass is a maintenance bypass to allow a UPS to be powered
down and removed for service without disruption to the connected load(s).
The manual bypass has both manual and automatic transfer functions. If the
UPS is accidentally disconnected or fails any load(s) connected to it are automatically transferred to the mains supply. The manual bypass is available in
wall mounted or 19” rack mount formats.
CHARACTERISTICS
•
•
•
•
•
External Manual Bypass 16A
wall mount version
Wall or rack mount versions
Back-feed protection
Manual and automatic transfer functions
Mains power present LED indicator
IEC, UK, Schuko and hard wired connected options
MBB10A - MBB16A - MBB32A – Maintenance Bypass
This is available in 10, 16 and 32 Amp models, and allows a UPS unit up to
6kVA to be safely powered down for maintenance/removal, without any disruption in the power supplied to the load. Both versions are supplied with a
wall mount metal bracket.
MAINS
LOAD
OUT UPS
MBB100A – Maintenance Bypass
Available only in one version which allows manual bypass operations on
any 10 to 20kVA single phase UPS and 10 to 40kVA three phase UPS.
The device comes with three circuit breakers as shown in the attached diagram, so as to ensure complete isolation of the UPS during maintenance
or removal operations, whilst guaranteeing continuous power supply to the
loads. The device has a microswitch for connection to the appropriate UPS
input, which signals closure of the manual bypass, in order to prevent
energy being supplied simultaneously from the manual bypass and the
inverter.
MAINS
SWIN
TO UPS INPUT
or UPS BYPASS INPUT
AUX
SWMB
AUX
LOAD
SWOUT
REMOTE MAINTENANCE
BYPASS
(NORMAL CLOSE CONTACT)
FROM UPS
BYPASS
100
101
CSS Configurations
Standby Power Systems
AROS uninterruptible power supplies
are also designed and built for use in
applications such as central supply
systems for emergency lighting,
security alarms and electro-medical
equipment.
The CEI 64-8 V2, EN 50171 standards
and other guidelines set down the
characteristics and performance levels
required from such systems. The main
ones are summarized below:
• Up to 3 h back-up times
• Battery recharge time of under 12 h
• Galvanically isolated input/output
• High-level diagnostics – preferably
from a front mimic panel
• Remote interface – normally volt-free
contacts
• High short circuit current capability.
The applications require a continuous
power system configured as follows:
• A standard UPS with high capacity
battery charger
• An isolation transformer (option)
• A remote interface to communicate
with other peripherals.
Diagrams of the various system solutions
1. Always powered
2. Powered from the mains
3. Emergency only
4. Always powered/Emergency only
102
EXAMPLE OF CSS CONFIGURATIONS
Model
Powers loads
of power up to
Back-up times of up to 3 hours
SENTINEL 6
1600 W
SENTINEL XR
2000 W
SENTRY MULTISTANDARD
Model
30.000 W
Powers loads
of power up to
Back-up times of up to 1 hours
SENTINEL 6
SENTINEL XR
SENTRY MULTISTANDARD
CHARACTERISTICS
• Full microprocessor control:
for greater reliability and compactness
in size
• Use of Isolated Gate Bipolar
Transistors (IGBT) technology – used
in UPS for over 10 years to optimise
performance (such as overloads) and
reduce physical sizes
• Advanced communication interface –
the units come with a volt-free
contact interface and RS232/485
serial interface for communication
with a local PC or computer network
• PowerNetGuard remote support
service compatible for remote
diagnostics and control
• Front panel LCD to display operating
status, alarms, measurements and
logs
• Option to expand the power and/or
reliability through the parallel
connection of units – 8kVA models
and higher
ADVANCED COMMUNICATION
• Advanced, multi-platform
communication for all operating
systems and network environments:
Watch&save 3000 monitoring and
shut-down software included, for
Windws 2008, Vista, 2003, XP; Mac
OS X, Linux, Novell and most popular
Unix operating systems.
2100 W
3500 W
64.000 W
A FULL RANGE OF CSS UNITS,
FROM 700VA TO 200KVA.
The CSS range units are
comprised of the following blocks:
Rectifier: converts the
alternating voltage input from
the mains power supply or from an
alternative source (generator) into direct
current voltage.
Inverter: converts the direct
current voltage supplied by the
rectifier into alternating voltage. In this
way the voltage is reconstructed,
filtered and stabilised with regard to the
input voltage.
Soft Start inverter has been
implemented in order to limit the value
of current required. In “always
powered/emergency only” two outputs
can be used: one always powered
(such as for powering computer loads)
and one that is only powered when
there is no power from the mains (such
as for powering emergency lights that
by law must switch on within a
maximum time of 0.5 seconds from a
mains failure).
Batteries: used to feed the
inverter output for the legally
required time of 3 hours (if there is no
generator). The batteries used are
generally valve-regulated, lead-acid
type, and do not require maintenance
or a special installation room as they
have very low gas emissions.
Compliance with Legislation
The CSS configurations complies with
the relevant European regulations (and
national guidelines still in force in some
countries) governing such applications.
OPTIONS
• Communication interfaces:
see options table for individual
models
• Isolation transformers
• Second outlet emergency only
By-pass: this allows switching
between the inverter and the
mains power supply. In “always
powered” operating mode the CSS
load is always powered from the
inverter and is only switched onto the
mains via the by-pass circuit in the
event of a failure. In “powered from the
mains” mode, the load is powered and
only switched onto the inverter when
there is no power from the mains. In
“emergency only” mode the load is only
powered from the inverter in the event
of a mains power failure. To deal with
the current surges required by the
powered loads at switching-on time, a
103
Stabilisers
WHY USE STABILISERS?
ELECTRONIC STABILISERS
ELECTRONIC LINE CONDITIONERS
Proper operation of most electric and
electronic equipment depends to a
large extent on the power supply
voltage that must be kept as steady
and as near to the nominal value as
possible. In many installations, the
mains power supply tends to fluctuate
for a number of reasons. So devices
that overcome and correct this problem
are often used and the ideal solution is
a stabiliser. AROS produces a full range
of electromechanical and electronic
stabilisers as well as electronic line
conditioners.
The operating principle of an electronic
stabiliser is based on the regulation of
the voltage through self-transformer
sockets selected and connected to the
output via static switches.
Regulation is determined by a specific
electronic control circuit.
Advantages of using an electronic
stabiliser are:
• No harmonic distortion
• Insensitive to the type of load or
power factor
• Low weight/power ratio
• High reliability
• High voltage regulation speed.
An electronic line conditioner combines
an electronic stabiliser, an isolating
transformer and high attenuation
EMI/RFI filters in a single unit.
It provides maximum protection for
installations susceptible to voltage
fluctuations, high frequency line noise
and power surges. Advantages of the
line conditioners are:
• Isolation between the line
and the load
• No harmonic distortion
• Insensitive to the type of load
or power factor
• High voltage regulation speed
• Protection against power surges
• Protection against line noise.
ELECTROMECHANICAL STABILISERS
This type of stabiliser controls the
voltage output by adding or removing
(by moving a brush converter) voltage
so as to restore output to the nominal
value. Advantages of using an
electromechanical stabiliser are:
• High quality voltage
• Insensitive to the type of load or
power factor
• Low weight/power ratio
• High stabilizing accuracy
• High reliability
• Wide range of power ratings for
single-phase or three-phase voltages.
105
Voltronic 4 single-phase
The VOLTRONIC 4 single-phase
electronic voltage stabiliser is able to
adjust the output voltage within ±3% of
the rated voltage.
The main features of the VOLTRONIC 4
electronic voltage stabilisers are:
• Microprocessor full control
• Compact size
• High regulation speed
• High efficiency
• Insensitivity to load variations and
power factor.
A LED panel provides information on:
• Mains input voltage exceeding
regulation limits
• Mains frequency exceeding limit
• Load level
• Overload
• Alarm for input overvoltage and/or
overheating (the visual alarm is
accompanied by an acoustic alarm).
106
Voltronic 4 single-phase
Technical data
V4-500
V4-1000
Nominal output voltage
V4-2000
V4-4000
V4-5000
V4-10000
220-230-240 Vac single-phase
Input voltage range
-18% +14% depending on the selected output voltage
Frequency
48 -62 Hz
Power (kVA)
0,5
1
2
4
5
10
Maximum output current at 230V (A)
2,4
4,5
9
18
22
44
Efficiency
98%
Accuracy
±3%
Regulation speed (ms/V)
2
Accepted load variation
0 to 100%
Load power factor
Any
Overload
1,5 IN x 5 sec
Harmonic distortion
<0,5%
Cooling
Natural
Forced ventilation
Operating ambient temperature
0°C ÷ 40°C
Protection degree
IP 20
Display indications
Mains OK, load level, overload, alarms
Acoustic alarm
Active for overload, over-voltage, over-temperature
Input protection
Fuse
Automatic switch
Output protection
Fuse
Fuse
Input connection
Cable with Schuko plug
Internal terminal board
Output connection
Schuko socket
Internal terminal board
V4-500
Dimensions (wdh) mm
Weight (kg)
V4-1000
V4-2000
180x215x194
9
V4-4000
V4-5000
230x350x275
10
21
25
V4-10000
340x540x310
27
51
107
Voltronic 4 three-phase
The VOLTRONIC 4 three-phase
electronic voltage stabiliser is able to
adjust the output voltage within ±3% of
the rated voltage.
Voltage stabilisation is performed
independently on each phase.
The main features of the VOLTRONIC 4
three-phase electronic voltage
stabilisers are:
• Microprocessor full control
• Compact size
• High regulation speed
• High efficiency
• Insensitivity to load variations and
power factor.
A LED panel provides information on:
• Mains input voltage exceeding
regulation limits
• Mains frequency exceeding limit
• Load level
• Overload
• Alarm for input overvoltage and/or
overheating (the visual alarm is
accompanied by an acoustic alarm).
108
Voltronic 4 three-phase
Technical data
V4 3F-6000
V4 3F-10000
Nominal output voltage
V4 3F-12000
V4 3F-15000
380/400/415 Vac + N selectable
Input voltage range
-18% +14% depending on the selected output voltage
Frequency
48 - 62 Hz
Power (kVA)
6
10
12
15
Maximum output current at 230V (A)
9
15
18
22
Efficiency
98%
Accuracy
±3%
Regulation
Independent on each phase
Regulation speed (ms/V)
2
Overload
1,5 IN x 5 sec
Accepted load variation
0 to 100%
Load power factor
Any
Harmonic distortion
<0,5%
Cooling
Natural
Forced ventilation
Operating ambient temperature
0°C ÷ 40°C
Protection degree
IP 20
Display indications
Mains OK, load level, overload, alarms
Acoustic alarm
Active for overload, over temperature, irrecoverable failure
Input protection
Automatic switch
Output protection
Fuse on each phase
Input connection
Internal terminal board
Output connection
Internal terminal board
V4 3F-6000
V4 3F-10000
Dimensions (wdh) (mm)
Weight (kg)
V4 3F-12000
V4 3F-15000
340x540x310
44
48
52
60
109
ELC Line Conditioners
The electronic line conditioners of the
ELC range have been specially
designed to protect electronic control
equipment such as PC’s, PLC’s,
internet devices, laboratory
instrumentation, data transmission and
audio-video apparatus, against
anomalies or interference in the power
supply circuit. In particular, ELC protect
against line noise and power surges
ensuring effective voltage regulation.
The electronic line conditioners
guarantee and effective protection as
they combine an electronic stabilizer,
EMI/RFI filters and an isolating
transformer in a single unit.
The equipment is controlled by a
microprocessor logic that also sounds
alarms in the event of overloads,
overvoltage or overheating.
110
ELC Line Conditioners
Technical data
ELC 1500
Nominal input voltage
ELC 3000
Nominal output voltage
220/230/240 Vac selectable, single-phase
Input voltage range
-18% +14% depending on the selected output voltage
Input frequency
Power (kVA)
Max. output current at 230V (A)
ELC 5000
220/230/240 Vac single-phase
48 - 62 Hz
1,5
7
3
5
14
22
Efficiency
95%
Accuracy
±3%
Regulation speed (ms/Volt)
2
Overload
1,5 IN x 5 sec
Accepted load variation
0 to 100%
Load power factor
Any
Harmonic distortion
<0,5%
Input peak voltage protection
Up to 4KV - 130 Joule
Common mode rejection ratio
70 dB
Primary and secondary insulation voltage
2500V input/output
Cooling
Natural
Operating ambient temperature
Forced ventilation
0°C ÷ 40°C
Protection degree
IP 20
Display indications
Line OK, load level, overload, alarms
Acoustic alarm
Active for overload, overvoltage, overtemperature
Input protection
Automatic switch
Output protection
Fuses
Input connection
Internal terminal board
Output connection
Internal terminal board
ELC 1500
Dimensions (wdh) (mm)
Weight (kg)
ELC 3000
230x350x275
26
ELC 5000
340x540x310
44
56
111
RQ
The RQ stabilizers belong to the
electromechanical series with electronic
control. They provide a perfect
constant single-phase output voltage
completely independent from any
variation of the input voltage within the
accepted voltage range.
The stabilisation of the output voltage
is not affected neither by eventual
harmonic distortion present in the
mains nor by the value and load power
factor; the output power distortion is
very low (<0,2%) and the total
efficiency is very high. The installation
of the RQ stabilizers is very flexible:
their special shape makes it easy to
install them near the equipment to
power or inside it. They can be
mounted on the wall or in a cabinet.
112
RQ
Power (kVA)
Input voltage range
Maximum output current (A)
Regulation speed (ms/Volt)
Efficiency
Power (kVA)
Input voltage range
Technical data
RQ 1000
RQ 2500
RQ 5000
RQ 7000
1
2,5 / 2
5/4
7 / 5,5
±25%
±15/20%
±15/20%
±15/20%
4
11
22
31
18
16
16
16
94%
96%
97%
98%
RQ K10
RQ K15
RQ K25
RQ K35
10 / 7
15 / 10
25 / 20
35 / 25
±15/20%
±15/20%
±15/20%
±15/20%
Maximum output current (A)
44
65
109
152
Regulation speed (ms/Volt)
16
16
18
18
96%
98%
98%
98%
Efficiency
Common characteristics
Nominal input/output voltage
230 Vac
Accuracy
±1%
Nominal frequency
50/60 Hz
Load variation
0 to 100%
Load power factor
Any
Harmonic distortion
<0,2%
Cooling
Natural
Operating ambient temperature
-5°C ÷ 40°C
Protection degree
Dimensions (wdh) (mm)
Weight (kg)
Dimensions (wdh) (mm)
Weight (kg)
IP 21
RQ 1000
RQ 2500
RQ 5000
RQ 7000
275x425x260
275x425x260
275x425x260
300x565x280
23
23
28
41
RQ K10
RQ K15
RQ K25
RQ K35
300x565x280
300x565x280
405x670x1150
405x670x1150
47
55
140
150
113
Tristab-T
TRISTAB-T series includes several
voltage stabilizers of electromechanical
type with electronic control. They
provide a perfect three-phase output
voltage completely independent
from any variation of the input voltage
within the accepted voltage range. The
stabilisation of the output voltage is not
affected neither by eventual harmonic
distortion present in the mains nor by
the value and the load power factor;
the distortion of the output voltage is
very low (<0,2%); the total efficiency is
very high. The voltage regulation is
provided on the average value of threephases and then these stabilizers are
suitable for maximum 50% unbalanced
load. There is the possibility of
choosing between two input voltage
ranges according to the nominal power
required (see table).
The operator panel includes a digital
voltmeter which inform on the status of
the line downstream on the voltage of
each phase and the linked voltages.
All models (up to 60kVA) are provided
with wheels for an easier positioning
and handling.
114
Tristab-T
Power (kVA) with input ±15%
Power (kVA) with input ±20%
Input voltage range
Technical data
T5
T10
T15
T20
T30
T50
T60
5
10
15
20
30
50
60
4
7
10
15
20
36
45
±15/20%
±15/20%
±15/20%
±15/20%
±15/20%
±15/20%
±15/20%
Maximum output current (A)
7
14
21
28
43
71
87
Regulation speed (ms/Volt)
18/13
18/13
18/13
18/13
18/13
18/13
18/13
Efficiency
95%
96%
97%
98%
98%
98%
98%
T75
T105
T135
T175
T230
T300
75
105
135
175
230
300
Power (kVA) with input ±15%
Power (kVA) with input ±20%
Input voltage range
60
75
105
135
175
230
±15/20%
±15/20%
±15/20%
±15/20
±15/20%
±15/20%
Maximum output current (A)
108
152
195
253
332
433
Regulation speed (ms/Volt)
18/13
18/13
18/13
18/13
20/18
20/18
Efficiency
98%
98%
98%
98%
98%
98%
T30
T50
Common characteristics
Nominal input/output voltage
400 Vac
Accuracy
±1%
Nominal frequency
50/60 Hz
Load variation
0 to 100%
Load power factor
Any
Harmonic distortion
<0,2%
Cooling
Forced ventilation
Operating ambient temperature
-5°C ÷ 40°C
Protection degree
IP 21
T5
Dimensions (wdh) (mm)
Weight (kg)
Dimensions (wdh) (mm)
Weight (kg)
T10
T15
T20
360x520x1000
82
85
T75
T105
605x850x1450
380
405x670x1150
110
145
170
190
T135
T175
T230
T300
605x850x1650
460
510
T60
605x850x1450
320
1210x850x1650
850
930
760
115
Tristab-Y
TRISTAB-Y series includes several
voltage stabilizers of electromechanical
type with electronic control from 5 to
300kVA. They provide a perfect threephase output voltage completely
independent from any input voltage
variation within the accepted voltage
range.
The stabilisation of the output voltage
is not affected neither by eventual
harmonic distortion
present in the mains nor by the value
and load power factor; the output
voltage distortion is very low (<0,2%);
the total efficiency is very high. In the
"Y" version the stabilising effect is
obtained independently on each phase.
This solution is therefore particularly
useful with unbalanced three-phase
loads or single-phase loads.
For proper operation, the presence of
the neutral wire is necessary. There is
the possibility of choosing between two
input voltage ranges according to the
nominal power required (see table).
The operator panel includes a digital
voltmeter which provides information on
the voltage of each phase and the
linked voltages. All models (up to
60kVA) are provided with wheels for an
easier positioning and handling.
116
Tristab-Y
Technical data
Y5
Y10
Y15
Y20
Y30
Y50
Power (kVA) with input ±15%
5
10
15
20
30
50
60
Power (kVA) with input ±20%
4
7
10
15
20
36
45
±15/20%
±15/20%
±15/20%
±15/20%
±15/20%
±15/20%
±15/20%
Input voltage range
Y60
Maximum output current (A)
7
14
21
28
43
71
87
Regulation speed (ms/Volt)
16/12
16/12
16/12
16/12
16/12
16/12
18/14
Efficiency
95%
96%
97%
98%
98%
98%
98%
Y75
Y105
Y135
Y175
Y230
Y300
Power (kVA) with input ±15%
75
105
135
175
230
300
Power (kVA) with input ±20%
60
75
105
135
175
230
Input voltage range
±15/20%
±15/20%
±15/20%
±15/20%
±15/20%
±15/20%
Maximum output current (A)
108
152
195
253
332
433
Regulation speed (ms/Volt)
18/14
18/14
18/14
18/14
18/14
18/14
Efficiency
98%
98%
98%
98%
98%
98%
Common characteristics
Nominal input/output voltage
400 Vac
Accuracy
±1%
Nominal frequency
50/60 Hz
Load variation
0 to 100%
Load power factor
Any
Harmonic distortion
<0,2%
Cooling
Forced ventilation
Operating ambient temperature
-5°C ÷ 40°C
Protection degree
IP 21
Y5
Dimensions (wdh) (mm)
Weight (kg)
Dimensions (wdh) (mm)
Weight (kg)
Y10
Y15
Y20
360x520x1000
90
90
Y75
Y105
605x850x1445
430
Y50
155
180
200
Y135
Y175
Y230
Y300
580
Y60
605x850x1450
110
605x850x1650
490
Y30
405x670x1150
380
1210x850x1650
950
1030
860
117
Graphic Design and Production:
Winning Associati - Bernareggio, Milano ITALY
Photos:
Studio Immagine 2000 - Bernareggio, Milano ITALY
Printed by:
Grafiche Stella - S. Pietro di Legnago (VR) ITALY
Specifications subject to change without prior notice.
AROS
PARTNER
CATGENX0Y09CAGB
www.winningassociati.it
RPS S.p.A.
Via Somalia, 20
20032 Cormano (MI) - ITALY
Ph. +39 02 66327.1
Fax: +39 02 66327.231
E-mail: export@aros.it
www.aros.it
