Wiring Devices – Straight Blade Plugs / Connectors Features

Wiring Devices – Straight Blade Plugs / Connectors Features

Prices as of April 27, 2016. Check Web site for most current prices.

Wiring Devices – Straight Blade Plugs /

Connectors

BRY5266NP

9530NP

BRY5269NC

9530NC

Features

• Internal Triple-Gripper ® cord clamp with unique “radius teeth” design automatically centers and secures the cord

• Tough impact- and chemical-resistant nylon housing

• Double-wall construction

• Combination Phillips/slotted captive terminal screws

• Transparent terminal cover with clear window and teardrop wiring pockets to ease insertion of stranded wire and to make solid connections

• Captive, quick-thread assembly screws backed out, ready for assembly

• Copper wire only

• Insulated design shields exposed metal parts on hand-held side

• Integral thermoplastic elastomer dust seal surrounds cord to help prevent moisture and contaminants from entering the wiring chamber

• Ratings stamped on straight blade devices visible while in use

(15 and 20A)

• Face and body feature contrasting key for correct and easy assembly every time

• Universal cord grip design accepts

0.300” to 0.655” (7.6 to 16.6 mm) cord without inserts or adapters

(15 and 20A); 0.425” to 1.320”

(10.80 to 33.5 mm)

Agency Approvals

• UL File E2258 (Receptacle), E1381,

E3382 (Plug, Connector)

• CSA Certified 16215

15 Amp Straight Devices

Poles NEMA # Voltage Configuration Plug Part No.

Style Price

2-Pole

3-Wire

5-15

6-15

125V

G

W

5-15R

G

250V

6-15R

G

W

5-15P

G

BRY5266NP

BRY5666NP

6-15P

$7.00

$11.00

20 Amp Straight Devices

Poles NEMA # Voltage Configuration Plug Part No.

Style Price

2-Pole

3-Wire

5-20

6-20

125V

G

W

5-20R

G

250V

6-20R

G

W

5-20P

G

BRY5366NP

6-20P

BRY5466NP

$9.25

$14.50

30 Amp Straight Devices

Poles NEMA # Voltage Configuration Plug Part No.

Style Price

2-Pole

3-Wire

5-30

6-30

125V

G

W

5-30R

G

250V

6-30R

G

W

5-30P

G

6-30P

9530NP

9630NP

$73.00

$69.00

Book 3 (14.3)

eWD-182

Wiring Solutions

Connector

Part No.

BRY5269NC

BRY5669NC

Connector

Part No.

BRY5369NC

BRY5469NC

Connector

Part No.

9530NC

9630NC

Style Price

Style

$12.00

$19.00

Style Price

$15.50

$22.50

Price

$81.00

$78.00

1 - 8 0 0 - 633 - 0405

Prices as of April 27, 2016. Check Web site for most current prices.
