Table of Contents
Colour and Correction Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Dance Floors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Fog Machine and Fluids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Gobos and Projection Equipment . . . . . . . . . . . . . . . . . . . . . . . .12
Luminaire and Lighting Accessories . . . . . . . . . . . . . . . . . . . . . . .17
Scenic Shop Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Staging Products for Theatre, Film & Video . . . . . . . . . . . . . . . . .33
*Clearance items will be discontinued after current inventory has been exhausted.
Contact Rosco for more information.
www.rosco.com
2
Colour and Correction Filters
PROTECTIVE FILTERS
Supergel
Supergel is the most widely used
colour filter in the world today. It
is comprised of a range of more
than 75 colours and 15 diffusions.
Selected primarily because of the
excellence and range of colour, it
is unique in its manufacturing and
durability as well.
For a detailed list consult the swatchbook or
Rosco website.
Supergel Sheets 61cm x 50cm
Supergel Rolls 61cm x 7.62m
Thermashield
When used in conjunction with Roscolux or Cinegel colour
filters, Thermashield prevents the colour filters from absorbing
IR energy as heat, thus allowing the filters to last much longer.
For maximum efficiency, a minimum 2.5cm air space must be
maintained between Thermashield and the colour filter.
Thermashield 30cm x 30cm
No. 199510
Thermashield 50cm x 61cm
No. 199511
Super Heat Shield™
E-Colour+
A comprehensive range of
European colour and correction
filters based on the Cinemoid™
system.
For a detailed list of colours,
diffusers and reflection materials
consult the E-Colour+ swatch book
or the Rosco website.
E-Colour+ Half Sheets 61cm x 53cm
E-Colour+ Full Sheets 1.22m x 53cm
E-Colour+ Rolls 1.22m x 7.62m
Super Heat Shield is a heat resistant plastic that acts as a barrier,
blocking the heat of a fixture. For maximum efficiency, a
minimum 2.5cm air space must be maintained between Super
Heat Shield and the colour filter.
Super Heat Shield 61cm x 50cm sheet
No. 1991
Super Heat Shield 61cm x 7.62m roll
No. 19911
Super Heat Shield 61cmx 15.24m roll
No. 19912
Super Heat Shield 1.22m x 7.62m roll
No. 19913
UV Filter™
Cinegel
®
The Academy Award winning
range of colour and correction
filters, Cinegel includes diffusers,
reflectors and the Storaro
Selection and CalColor filters.
For a detailed list of products, consult the Cinegel swatchbook or the
Rosco website.
Cinegel Sheets 61cm x 50cm
Cinegel Rolls (Most rolls are 1.22m x 7.62m.)
Roscolux
Roscolux is the most widely used
colour filter range for theatre,
film, television, live entertainment
and architectural applications.
Rosco UV Filter effectively extends the life of your colour
filter by absorbing the damaging ultraviolet energy that can
prematurely fade dyes.
UV Filter 50cm x 61cm sheet
No. 31141
UV Filter 61cm x 15.24m roll
No. 3114
UV Filter 1.22m x 7.62m roll
No. 311413
Storage Drawers
CLEARANCE*
Heavy gauge two-inch deep corrugated drawer and sleeve that
accepts 51cm x 61cm sheets of Rosco colour filters.
Shipped completely assembled. Packed six to a case.
Storage Drawers (set of 6)
No. 88860110
For a detailed list of the colours
and diffusers of the range consult the
Roscolux swatchbook or Rosco
website.
Roscolux Half Sheets 61cm x 53cm
Roscolux Full Sheets 1.22m x 53cmm
Rolls
1.22m x 7.62m
www.rosco.com
3
Colour and Correction Filters
OPTI-FLECS
Filters for LED Enhancement, Correction and
Softening
Opti-FLECS offers an array of options to target problematic
aspects of LED lighting. Available in 21 standard diffusions and
colours, these semi-rigid filters offer a durable, reusable filter
solution that can be inserted into a multitude of LED fixtures
used onstage, in broadcast studios and architectural installations.
No.
9101
9106
9116
9121
9201
9206
9211
9216
9301
9306
9311
9316
9321
9326
9331
9406
9411
9416
9421
9501
9506
Colour
Smoothing Frost
Powder Frost
Double Hamburg Frost
Silk
Soft Pink Tint
Soft Rouge
Soft Amber
ND Frost
Barely Minus Green
1/4 Minus Green
1/2 Minus Green
Rouge
Blushed
Barely Bronze
Warm Bronzer
Bastard Amber
1/4CTO
1/2CTO
Golden Bronzer
.3ND
.6ND
Size
30cm x 30cm sheets (11.8” x 11.8”)
60cm x 60cm sheets (23.6” x 23.6”)
Suffix
1030
1060
Options for customizing the colour and size of OPTI-FLECS
filters to fit the requirements of your job are available.
OPTI-FLECS Swatchbook
Contains one 7.5cm x 12cm (3”x5”) piece of every OPTI-FLECS
filter.
No. 950 SBOPT 0305
Lens/Reflector Cleaner
The professional’s choice for over 50 years. Specially designed
for cleaning lenses, mirrors, reflectors, glass and dichroic filters,
and other fine quality optics.
Lens Cleaner 60ml drip bottle
No. 72021
Lens Cleaner 236ml spray bottle
No. 72023
Lens Cleaner 473ml drip bottle
No. 72025
Lens Tissue
Premium, lightweight, disposable, micro-fiber tissue for cleaning
lenses, filters and optics.
Lens Tissue 10.16cm x 15.24cm booklet
No. 74461
Permacolor Dichroic Glass Filters
Rosco Permacolor dichroic glass filters are the perfect choice for
designers requiring long-lasting, high-quality filters. Permacolor
withstands the heat of high temperature lighting fixtures like
MR16, metal halide, and high wattage tungsten lamps and are
ideal for use in permanent installations.
Rosco’s range of standard colours includes the bright saturated
colours prone to premature fading in gel as well as a selection of
pale tints and accent colours selected by leading architectural
designers around the world.
Colour
Bastard Amber
Amber Blush
Bright Straw
Goldenrod
Yellow
Amber
Victorian Gold
Medium Orange
Orange
Flame Red
Primary Red
Light Pink
Pale Pink
Medium Pink
Hot Pink
Deep Magenta
Vivid Magenta
Lavender
Mauve
Purple Fusion
Lavender Accent
No.
31002
31018
31012
31013
35200
35401
33114
35600
35900
36100
36500
31033
31337
34758
34630
34763
34640
34965
31050
31048
31054
Colour
Lilac
Lavender 57
Indigo
Booster Blue
Mediterranean Blue
Sea Blue
Cyan
Light Green Blue
Sky Blue
Light Blue Green
Primary Blue
Medium Red Blue
Deep Purple
Peacock Blue
Turquoise
Gaslight Green
Industrial Green
Light Yellow Green
Fern Green
Primary Green
No.
31055
31057
31059
31062
31065
35700
35590
31076
35400
35100
31080
34600
34200
31073
34853
33388
31086
34959
35156
34954
Colour
White Diffusion
IR/UV Block
UV Blocker
CTO
3
⁄4 CTO
1
⁄2 CTO
1
⁄4 CTO
1
⁄8 CTO
ND .6
ND .3
No.
33026
38000
34000
43407
43411
43408
43409
43410
43403
43402
Colour
ND .15
1
⁄2 Minus Green
1
⁄4 Minus Green
1
⁄8 Minus Green
CTB
3
⁄4 CTB
1
⁄2 CTB
1
⁄4 CTB
Double Coated
UV Pass
No.
43415
43313
43314
43318
43202
43203
43204
43208
33660
Size
2" x 2" (50.8 mm) square
1.95" (49.5 mm) round
5.25" (133 mm) round
6.3" (160 mm) round
8.25" (209 mm) round
Custom sizes available, call for pricing.
Permacolor Frames
(Safety Grid Included)
Permacolor Frame 158mm x 158mm
(for standard 133mm size)
No. 0059525
Permacolor Frame 190mm x 190mm
(for standard 160mm size)
No. 0059075
Permacolor Frame 254mm x 254mm
(for standard 209mm size)
No. 97100
www.rosco.com
4
Colour and Correction Filters
Filter Kits
A range of gel kits, sized at 30.48cm x 30.48cm (12”x12”), that have been configured to control the output of lighting fixtures used in filmmaking,
photography and video productions.
Photo Lighting Kit
Color Correction Kit
The essential lighting filters to balance and compose light for
photography, including: CTO’s, CTB’s, Neutral Densities and a
variety of effects colours.
Specialized filters to balance common light sources in a shot,
including a complete set of CTO’s, CTB’s, Plusgreens &
Minusgreens.
Photo Lighting Kit
No. 110 11012 0001
Color Correction Kit
No. 110 11812 0001
Beauty Kit
Diffusion Kit
A selection of subtle, cosmetic colour filters that have been hand-picked
by fashion experts to beautify, soften and enhance skin tones.
A collection of materials that affect the shape, texture and
quality of light and shadow in a composition.
Beauty Kit
No. 110 11212 0001
Diffusion Kit
No. 110 12012 0001
Digital After Dark® Kit
Color Effects Kit
A selection of lighting filters designed for night shoots and for adding
vibrant colour into nighttime imagery and light painting compositions.
An assortment of popular vibrant and contrasting colour filters
for creating a wide variety of common lighting effects.
Digital After Dark® Kit
No. 110 11412 0001
Color Effects Kit
No. 110 12412 0001
CalColor™ Kit
Cinegel Sampler Kit
Rosco's Academy Award® winning system of calibrated lighting filters
produce pure primary and secondary colours to enhance your
composition.
A selection of Rosco's Academy Award-winning Cinegel line,
including a range of colour correction filters for balancing
common light sources and diffusions for softening shadows, or
altering the direction and spread of the beam.
CalColor™ Kit
No. 110 11612 0001
Cinegel Sampler Kit
No. 110 12212 0001
www.rosco.com
5
Colour and Correction Filters
Flash Packs
A range of gel kits for photographers shooting with speedlights
to enhance their lighting setups.
Each Flash Pack contains at least 55 pieces of filter, sized at
3.81cm x 13.97cm (1.5" x 5.5") - perfect for covering any
speedlight strobe.
The Strobist™ Collection
The essential filters, chosen by Strobist.com founder David
Hobby, that every photographer needs to balance & compose
the light in their shot.
The Strobist™ Collection
No. 110 11005 0001
RoscoSleeves™
For simple and economical control of fluorescent lighting,
RoscoSleeves can be supplied in any Rosco filter colour—(or
combination of colours) Roscolux, Cinegel, E-Colour+ and
GamColor. Not recommended for use with High Output or Very
High Output lamps. T5 and T8 Sleeves come standard with UV
filter in addition to the colour selected.
T5 x 61cm (24")
T8 x 61cm (24")
T12 x 61cm (24")
T5 x 91.44cm (36")
T8 x 91.44cm (36")
T12 x 91.44cm (36")
T5 x 121.92cm (48")
T8 x 121.92cm (48")
T12 x 121.92cm (48")
T5 x 152.40cm (60")
T8 x 152.40cm (60")
T8 x 2.44m (96")
T12 x 2.44m (96")
No. 110 08401 2405
No. 110 08401 2408
No. 110 08401 2412
No. 110 08401 3605
No. 110 08401 3608
No. 110 08401 3612
No. 110 08401 4805
No. 110 08401 4808
No. 110 08401 4812
No. 110 08401 6005
No. 110 08401 6008
No. 110 08401 9608
No. 110 08401 9612
ChromaSleeves
Beauty Flash Pack
A selection of cosmetic filters that have been hand-selected by
fashion photographers to enhance and beautify skin tones.
Beauty Flash Pack
No. 110 11205 0001
ChromaSleeves are body-coloured, extruded polycarbonate
sleeves with an added UV absorber to prevent premature colour
fading. Available in seven standard stocked colours. Not
recommended for use with High Output or Very High Output
lamps.
Royal Blue
Green
Ruby Red
Purple
No. 110 08410
No. 110 08411
No. 110 08412
No. 110 08413
Pink
Yellow
Amber
No. 110 08414
No. 110 08415
No. 110 08417
Add suffix to product code for each size
T5 x 48"
4805
T8 x 48"
4808
Quick Color Sleeves
Digital After Dark® Flash Pack
A collection of coloured lighting filters to create dramatic
night-time photos, selected by Kevin Adams, founder of the
"Digital After Dark®" blog.
Digital After Dark® Flash Pack
No. 110 11405 0001
CalColor™ Flash Pack
Two pieces of every CalColor - Rosco’s patented system of
primary & secondary colour filters – for photographers to
precisely control the colour of their light.
CalColor™ Flash Pack
No. 110 11605 0001
This gel-only product is a flat welded
tube of Rosco colour filter, made in any
colour from any line of Rosco gel. T5
and T8 sleeves come standard with UV filter. Quick Color
Sleeves can be supplied from any colour in the Roscolux,
Cinegel or E-Colour+ ranges. Folded flat for easy shipping and
storage, the sleeve puffs open like an envelope to slide over
standard fluorescent tube. Not recommended for use with High
Output or Very High Output lamps.
T5 x 61cm (24")
T8 x 61cm (24")
T12 x 61cm (24")
T5 x 91.44cm (36")
T8 x 91.44cm (36")
T12 x 91.44cm (36")
T5 x 121.92cm (48")
T8 x 121.92cm (48")
T12 x 121.92cm (48")
T5 x 152.40cm (60")
T8 x 152.40cm (60")
T12 x 152.40cm (60")
No. 110 08430 2405
No. 110 08430 2408
No. 110 08430 2412
No. 110 08430 3605
No. 110 08430 3608
No. 110 08430 3612
No. 110 08430 4805
No. 110 08430 4808
No. 110 08430 4812
No. 110 08430 6005
No. 110 08430 6008
No. 110 08430 6012
Please specify Rosco gel colour when ordering.
www.rosco.com
6
Dance Floors
Floor Catalogue
Rosco’s floor products are
organized in a multi-page
catalogue. Available as a download at www.rosco.com
Adagio™
Adagio’s durable surface can handle tap and other hard shoe
dance styles, yet it is supple enough for ballet and modern
dance styles. Since Adagio is dimensionally stable, it is suitable
for permanent or semi-permanent installation. 3.80kgs.per
linear metre/117.9kgs. per roll. Floor thickness is.1.5mm, width
is 1.6m and it is sold by the linear metre or full rolls 31m long.
Black 1.6m x linear metre
No. 87862215
Grey 1.6m x linear metre
No. 87863515
Dance Floor
Rosco Dance Floor is lightweight (2.85kgs per linear metre) and
is reversible with black on one side and your choice of white or
grey on the other. Floor thickness is 1.3 mm, width is 1.6 m and
it is sold by the linear metre or full rolls 40m long.
Adagio™ Tour
Black/Grey 1.6m x linear metre
No. 300 08720 6302
Adagio Tour lays flat quickly and provides the same versatile
surface as Adagio. Adagio Tour weighs only 2.70kgs per linear
metre so, as its name implies, it is excellent for touring dance
companies. Floor thickness is 1mm, width is 1.6m and is sold by
the linear metre or full rolls 31m long.
Black/White 1.6m x linear metre
No. 300 08723 6302
Black 1.6m x linear metre
No. 87862314
Blue/Green Chroma Floor 1.6m x linear metre
No. 300 09720 6302
Grey 1.6m x linear metre
No. 87862414
Black/Grey 2m x linear metre
No. 300 08720 7902
Black/White 2m x linear metre
No. 300 08723 7902
Arabesque™
Arabesque is, on a cost-per-square-metre basis, Rosco’s most
affordable floor. With a thickness of 2mm, Arabesque offers
durability that is ideal for hard-soled styles of dance such as tap,
hard shoe Irish and Flamenco. Arabesque is available in a
marble finish that not only helps hide scuff marks, but also adds
a note of elegance to your studio. The floor is 2m wide and can
be specified by the linear metre or full 20m roll.
Marble Black 2m x 20m metre
No. 300 08222 7900
Marble Grey 2m x 20m metre
No. 300 08235 7900
www.rosco.com
7
Dance Floors
Studio Floor
Roscotiles
An ultra matte, black vinyl floor for ballet, theatre, or any
application where a light-absorbing surface is needed. Studio
Floor is not appropriate for heavy traffic or other types of dance.
Studio Floor is .08" thick and rolls measure 1.83m wide by
18.29m long, weighing 113.4kgs per roll. Sold by full roll only.
This rugged floor product is 91.4cm by 91.4cm squares, making
it easy to pick up and put down. Designed for video production
facilities, each 3mm thick, 5.4kgs tile is designed to lie flat for
temporary, as well as permanent installations. Available in
White, Black and TV Grey.
Special Order Only.
White
No. 8726
Black
No. 8725
TV Grey
No. 8727
Studio Floor Black Matte 1.83m x 18.29m
No. 300 78035 720
Performance Floor
A durable, all-purpose floor, best for permanent or
semi-permanent installations in studios, multi-purpose rooms,
stages and showrooms—anywhere traffic is heaviest. Available in
black, white, light and dark grey. Performance Floor is 2.5mm
thick and rolls measure 1.83m wide by 18.29m, and weigh
127kgs per roll. Sold by full roll only.
Special Order Only.
Black 1.83m x 18.29m
No. 8781035
Light Grey 1.83m x 18.29m
No. 8781031
Also available in White and Dark Grey.
Rosco SubFloor
Rosco SubFloor was designed to provide the perfect
combination of resilience and stability to absorb the energy
from a dancer's impact when contact is made with the floor.
The SubFloor’s simplistic design does not need any adhesives or
special hardware, which means that almost anyone can easily
install it into their space. This design also enables Rosco’s
SubFloor to be un-installed, stored, shipped and re-installed
with ease when needed. The system consists of 1.07m x 1.07m
panels with closed-cell foam pads that connect to each other
using Rosco’s unique Wave-Lock™ design. Perimeter pieces,
Ramps and Customizing Panels lock the entire floor together.
Contact Rosco for futher information.
Roscoleum Floor
A hardwearing floor that provides an ideal surface for the
heaviest traffic areas. It stands up to tap, Flamenco and Irish
dance but will easily accommodate soft shoe styles as well.
2.5mm thick, 2m wide and approximately 32m long. Weight
192.8kgs per roll. Sold by full roll only.
Special Order Only.
Black 2m x 32m
No. 87812219
Grey 2m x 32m
No. 87813519
Show Floor
Unique WaveLock™ design assures easy installation and
safe, secure flooring.
Super glossy floor for special events, commercials and fashion
promotions. It is not recommended for heavy traffic or for permanent installation. Available in high gloss black, white and red.
Show Floor is 2.03mm thick, and each roll measures 1.83m
wide by 18.29m long, weighing 124.74kgs. Sold by full roll only.
Special Order Only.
www.rosco.com
8
Dance Floors
Floor Cleaners
Rosco offers different floor cleaning
products, designed to meet every
need. Cleaners available in 1 litre
and 3.79 litres.
Rosco All Purpose Floor Cleaner
Designed for the routine, regular cleaning of all Rosco vinyl
floors.
1 litre
No. 300 09116 0034
3.79 litres
No. 300 09116 0128
Rosco Heavy Duty Floor Cleaner
For stripping and deep cleaning of Rosco floors.
1 litre
No. 300 09112 0034
3.79 litres
No. 300 09112 0128
Granulated Floor Cleanser
Granulated, dissolvable chemical for cleaning all Rosco flooring
surfaces.
0.91kg tub
No. 871010
Floor Adhesives
For permanent installations. Consult a professional flooring
contractor before installation.
Premium Adhesive No. 755
For most porous surfaces, including concrete which is above grade.
3.79 litres (weighs 5.44kgs)
No. 300 08755 0128
11.37 litres (weighs 14.06kgs)
No. 300 08755 0448
Coverage is approximately 18.5sq metres per 3.79 litres.
Floor Welding Threads
Welding threads are available to aid in permanent seam sealing
by professional contractors. Rosco has welding threads available
for Adagio, Roscoleum, Arabesque, Performance Floor, and
Studio Floor.
Floor Type
Adagio
Roscoleum
Performance Floor
Arabesque
Studio Floor
Roll Length
50m
50.29m
152.40m
125m
152.40m
PortaBarre™
A truly portable ballet dance barre, Rosco’s aluminum
PortaBarre uses an internal double button interlocking system,
making assembly and disassembly a matter of a few minutes,
without requiring tools or locking keys. Sold complete with a
custom designed carrying case.
2.74m barre with carrying case
No. 09095 0108
1.37m barre with carrying case
No. 300 09095 0054
1.22m extension for 2.7m barre
No. 09095 0048
Floortapes
For installing floors in temporary and semi-permanent situations.
Black Vinyl tape 48mm x 33m
No. 501410
White Vinyl tape 48mm x 33m
No. 501510
Grey Vinyl tape 48mm x 33m
No. 501610
Clear Vinyl tape 48mm x 33m
No. 501310
Roscofloor Double Stick tape 48mm x 25m
No. 500410
Rosco Floor Bag
Designed specifically for dancers and dance companies who
tour, the Rosco Floor Bag is made of durable water-resistant
PVC fabric. A hook and loop fastener along the entire length of
the bag keeps it securely shut while in transit, and also allows it
to open flat for loading and unloading.
Rosco Floor Bag
No. 300 08725 6301
www.rosco.com
9
Fog Machines and Fluids
Vapour Series Fog & Haze Machines
Designed with features to meet the needs of anyone needing reliable atmospheric effects, the Vapour Series has been engineered from the ground
up to meet the diverse needs of a wide range of applications including theatre, feature film & television, theme parks and photographic studios. All
of the Vapour fog and haze machines have been designed to be affordable and easy-to-use & maintain thanks to features like DMX on-board,
intuitive remotes and an air-input valve for simple cleaning.
No matter how you use fog or haze – Rosco’s got a machine for you.
Mini-V
The most affordable and compact fog machine in the range, the
Mini-V delivers a continuous stream of professional-quality fog.
The Mini-V's small design and
energy-efficient, durable heat
exchanger make it a perfect
choice for mobile users or
applications that lack the space
for a larger fog generator.
Mini-V Fog Machine - 120v
No. 200 81110 0120
Mini-V Fog Machine - 240v
No. 200 81110 0240
Vapour
The workhorse of Rosco's new family of fog machines, the
Vapour comes packed with all the features that a professional
effects technician could want - including solid reliability and
ease of maintenance. Featuring
continuous fog output, a simple,
one-step cleaning process,
digital DMX and common core
components that are designed to
be replaced quickly – the
Vapour can be relied upon to
get the job done.
Vapour Fog Machine - 120v
No. 200 82220 0120
Vapour Fog Machine - 240v
No. 200 82220 0240
Vapour Plus
Designed specifically to fill large venues and outdoor spaces
quickly and efficiently, the Vapour Plus produces enormous
bursts of fog. This machine produces stadium-sized fog effects,
yet is small enough to mount inside box truss and power from a
single mains circuit. Features include a simple, one-step
cleaning process, digital DMX,
common core components that
are designed to be quickly and
easily replaced, and the ability to
be mounted vertically to create
cryogenic-style effects.
Vapour Plus Fog Machine - 120v
No. 200 83330 0120
Vapour Plus Fog Machine - 240v
No. 200 83330 0240
V-Hazer
Quiet and reliable, the V-Hazer creates beautiful haze that
spreads throughout a venue consistently and smoothly. The V-Hazer
features a blower that turns off when not in-use to ensure the
quietest operation possible, as well as continuous output, a simple,
one-step cleaning process and digital DMX. Adjust output on the
fly with remote, or gain
independentlycontrolled fan speed and
haze volume through
DMX-control.
V-Hazer - 120v
No. 200 84440 0120
V-Hazer - 240v
No. 200 84440 0240
Model 1700™
CLEARANCE*
The Rosco Model 1700 fog
machine is a high quality machine–
durable, dependable, and with a lower
cost. The machine delivers fog output
more than previous fog machines, but
draws less power—1190W.
Model 1700 120v with remote
No. 200 21700 0120
Model 1700 240v with remote
No. 200 21700 0240
1700/1900 DMX Remote
No. 200 51700 RDMX
15.24m remote extension–1700/1900
No. 200 51587 0050
30.48m remote extension–1700/1900
No. 200 51588 0100
Model 1700 Carrying Case
No. 200 41700 0000
Model 1900™
CLEARANCE*
Rosco’s Model 1900 fog machine is a
very high output professional fog
machine, designed primarily for industrial
applications. Its most unique feature is
the extremely high output, almost twice as
much as the Model 1700.
Model 1900 120v with remote
No. 200 21900 0120
Model 1900 240v with remote
No. 200 21900 0240
RDMX 1700/1900 DMX Remote
No. 200 51700 RDMX
15.24m remote extension–1700/1900
No. 200 51587 0050
30.48m remote extension–1700/1900
No. 200 51588 0100
www.rosco.com
10
Fog Machines and Fluids
Coldflow™
Converts liquid carbon dioxide
to dry ice to chill an aluminum
chamber. The output of a fog
machine passes through the
aluminum chamber and is
chilled so that it lays close to
the ground. For best effect use
Rosco Stage & Studio Fluid.
Coldflow – 120v
No. 200 61700 0120
Coldflow – 240v
No. 821 561700 0240
Stage and Studio Fog Fluid
A water-based fluid which creates dense fog that will dissipate
more quickly than standard fluid. Also recommended for use
with the Rosco Coldflow to produce low-lying fog.
Stage and Studio Fog Fluid 1 Litre
No. 200 08302 0010
Stage and Studio Fog Fluid 4 Litre Bottle
No. 200 08302 0040
Rosco Clear Fog Fluid
Produces dense fog with a long hang time without the
traditional Rosco scent.
Clear Fog Fluid 1 Litre
No. 200 08305 0010
Clear Fog Fluid 4 Litre Bottle
No. 200 08305 0040
Rosco Light Fog Fluid
A water-based fluid that produces a more translucent fog,
which disperses quickly into a beam-catching haze effect while
maintaining a long hang time.
Light Fog Fluid 1 Litre
No. 200 08304 0010
Light Fog Fluid 4 Litre Bottle
No. 200 08304 0040
V-Hazer Fluid
Rosco Fog Fluid
Rosco Fog Fluid, for over 30 years is the most widely used fog
fluid in theatre, live entertainment and theme parks. When
vaporized, this water-based formulation produces a dense,
realistic fog with a long hang time.
Fog Fluid 1 Litre
No. 200 08301 0010
Fog Fluid 4 Litre Bottle
No. 200 08301 0040
Designed for use exclusively with Rosco's V-Hazer, this fluid
creates a smooth haze inside performance venues, photographic
studios and production soundstages. Due to its water-based
composition, V-Hazer Fluid won't leave behind an oily residue
on performers, set pieces or equipment. When used with the
Rosco V-Hazer, this fluid will create a steady, reliable haze that
will hang in the air for hours to enhance lighting effects.
V-Hazer Fluid, 4 Litre Bottle
No. 200 08800 0135
FX Fluid
FX Fluid 1 Litre
No. 200 08306 0010
FX Fluid 4 Litre Bottle
No. 200 0830 0040
Rosco Bubble Fluid
Rosco has been honored by the Academy of Motion Picture Arts and
Sciences four times. One of the Oscars (in this case a
Scientific and Technical Award) was for “the development
of a safe, non-toxic fluid for use in motion pictures.”
®
Building on Rosco’s 30+ years of success manufacturing the
world’s highest quality fog fluids, Rosco has developed a new
formulation of bubble fluid. Engineered as a universal fluid to
work in any bubble machine, Rosco’s water-based Bubble Fluid
creates higher volumes of extra colorful bubbles that fly higher
and farther than existing
fluids currently available—with next to no residue left behind,
which makes it safer to use on performance and dance spaces
or in areas with expensive technology.
Bubble Fluid – 3.785L
200 09500 0128
www.rosco.com
11
Gobos and Projection Equipment
Gobo Catalogue
Image Glass™
Deeply textured glass gobos that bend or
refract light. Recommended for use in moving
lights with lamps up to 1200 watts and in
ellipsoidal fixtures up to 600 watts. Requires the
use of the Universal Iris Slot Holder.
Rosco’s Gobo Catalogue lists the entire
range of standard gobos available, as
well as several pages of useful technical
information. It is available from any
Rosco office or reseller or may be
downloaded from the Rosco website.
You can also choose gobos from the
Rosco website (www.rosco.com) or
from the free MyGobo app for
iPhones, iPads, and iPod Touch.
Available in Standard B and most Moving Light sizes.
Also available in X size for Rosco X24 projector.
Flower
Lined
Plume
Lt. Plume
Pebble
Honeycomb
Waves
Irregular
Strands
Banded Lines
Lazy Swirls
Basket Weave
Pin Feathers
Winter Frost
Standard Designs
Rosco offers approximately 2,000 standard
designs in its gobo collection. Each design
is available for virtually any known
fixture used in theatrical or display
lighting. Rosco re-sellers can usually
deliver standard gobos either off the
shelf or within a day or two.
Standard Steel and Glass gobo designs
available in all sizes.
No. 33621
No. 443600
No. 443601
No. 443602
No. 443603
No. 443604
No. 443605
No. 443606
No. 443607
No. 443608
No. 443609
No. 443610
No. 443611
No. 443613
Random Blisters
Coalescing
Bubbles
Raised Mosaic
Hammered
Wood Grain
Ripples
Ice
Dune
Sparkelite
Reflections
Rain Glass
Foam Bubbles
No. 443614
No. 443615
No. 443616
No. 443617
No. 443618
No. 443619
No. 443620
No. 443621
No. 443622
No. 443623
No. 443624
No. 443625
No. 77730
ColorWaves™
Each ColorWave glass gobo is coated in one of
five dichroic colours. There are four different
styles—Waves, Ripple, Strands, Mosaic—and
thus 20 different choices in the range.
Recommended for use in moving lights with
lamps up to 1200 watts and in ellipsoidal
fixtures up to 600 watts. Requires the use of the
Universal Iris Slot Holder.
Colorizers™
Multi-coloured glass gobos that can be used
alone or in combination with a steel gobo.
Recommended for fixtures up to 1,000 watts.
Requires the use of either a Glass Gobo Holder or
the Universal Iris Slot Holder.
*No. 55004
Available in Standard B and most Moving Light sizes.
Also available in X size for Rosco X24 projector.
Stippled Series
Blue and Lavender
Amber and Red
Red, Blue and Lavender
Green, Blue and Lavender
Green and Yellow
No. 445004
No. 445005
No. 445006
No. 445007
No. 445008
Featherlight Series
Blue, Lavender and Yellow
Blue and Green
Red, Lavender and Yellow
Blue and Lavender
Green and Yellow
No. 446201
No. 446202
No. 446203
No. 446204
No. 446205
Free Flow Series
Cool: Blues, Reds and Lavenders
Warm: Red, Ambers, Blue and Lavenders
Midnight: Blues, Lavenders and Greens
No. 446101
No. 446102
No. 446103
*No. 43104
Available in Standard B and most Moving Light sizes.
Also available in X size for Rosco X24 projector.
Waves - Red
Waves - Amber
Waves - Magenta
Waves - Cyan
Waves - Indigo
No. 4433001
No. 4433002
No. 4433003
No. 4433004
No. 4433005
Mosaic - Red
Mosaic - Amber
Mosaic - Magenta
Mosaic - Cyan
Mosaic - Indigo
No. 4433301
No. 4433302
No. 4433303
No. 4433304
No. 4433305
Ripple - Red
Ripple - Amber
Ripple - Magenta
Ripple - Cyan
Ripple - Indigo
No. 4433101
No. 4433102
No. 4433103
No. 4433104
No. 4433105
Sparkelite - Red
No. 4433401
Sparkelite - Amber No. 4433402
Sparkelite - Magenta No. 4433403
Sparkelite - Cyan No. 4433404
Sparkelite - Indigo No. 4433405
Strands - Red
Strands - Amber
Strands - Magenta
Strands - Cyan
Strands - Indigo
No. 4433201
No. 4433202
No. 4433203
No. 4433204
No. 4433205
www.rosco.com
12
Gobos and Projection Equipment
Prismatics™
iPro™ Slide Library
Recommended for use in moving lights with lamps
up to 1200 watts and in ellipsoidal fixtures, lamps
up to 600 watts. Requires the use of the Universal
Iris Slot Holder.
Available in Standard B and most Moving Light sizes.
No. 43801
Custom iPro™ Slide
Prismatics are not available for use in Rosco’s X24.
Kaleidoscope
Cool Lavender
Spring Greens
Sunset
Blue Water
No. 443801
No. 443802
No. 443803
No. 443804
No. 443805
Fiery Sun
Warm Contrast
Patriotic
Crystalline
No. 443806
No. 443807
No. 443808
No. 443809
Virtually any design you can create on your computer can be
made into a Custom iPro Slide in just one day. Using Adobe
Photoshop or similar software, prepare your design and send it to
Rosco at [email protected] Within 24 hours, your
finished assembled iPro slide will be on its way back to you.
Custom iPro Slide
No. 265 27000 0860
Universal Iris Slot Holder
Allows a glass gobo to be placed in the
iris slot of fixture in front of the gate.
Double sided to allow the use of two
gobos, glass and/or steel, in the iris slot at
the same time. Fits the ETC Source Four,
Altman Shakespeare and other modern
spotlights. For use with 86mm standard
“B” size glass gobos only.
Cool Ink™ Plastic Gobos
Cool Ink gobos are a great solution for
temporary projections in many LED
luminaires. Check with the fixture
manufacturer, or Rosco, to ensure that your
LED luminaire will accept plastic gobos. The
Cool Ink gobo’s rigid plastic ring secures the Cool
Ink gobo for easier handling and installation*. Rosco provides fast
turnaround from receiving your artwork to shipping the product,
usually one business day for Cool Ink Gobos.
Universal Iris Slot Holder
No. 15786
*As with all gobos, handle via the bezel to avoid fingerprints on the image area.
Steel & Glass Gobo Holders
Custom Plastic Gobo, Custom Size
No. 265 27000 0999
Cool Ink Standard Gobo Design
No. 265 27000 0000
Cool Ink Custom Plastic Gobo, “B” Size
No. 265 27000 CI86
Cool Ink Custom Plastic Gobo, “E” Size
No. 265 27000 0375
Kreios Cool Ink Custom Plastic Gobo
No. 265 2700KR375
With the breadth and depth of gobos available, it
is important to choose the gobo holder that is
appropriate for your luminaire (most luminaires
must use a specific size gobo). Some gobos are
thicker than others and require a special holder to
accommodate it. When selecting a gobo holder,
care must be taken to ensure that both the overall
dimensions of the holder and the size of the gobo
it will accept, are compatible with the lantern used.
This is just a small selection of luminaires. For those that are not
listed please contact one of our Customer Service Team.
Manufacturer/Lantern
Designed specifically for the iPro, Rosco
offers images in a wide range of categories
that are certain to suit your needs for most
theatrical productions and live entertainment
events.
Steel
Glass
ETC
Source4 (A size)
Source4 (B size)
Source4 Iris Slot (B size)
Source4 Junior (M size)
No. 77GH61
No. 77GH59
—
No. 77GH63
No. 77GH62
No. 77GH56
No. 77GH77
No. 77GH64
SELECON
Astral/Acclaim (M size)
No. 77GH60
—
STRAND CENTURY
Brio (A size)
Cantata (A size)
Cantata (B size)
SL Coolbeam (B size)
T Spot (A size)
T Spot (B size)
—
No. 77GH74
No. 77GH73
—
No. 77GH74
No. 77GH73
No. 77GH04
No. 77GH05
—
No. 77GH76
—
—
Note: unless otherwise specified, all Rosco ‘A’ & ‘B’ size glass
gobos are made with 70mm glass, bezelled to its overall
diameter.
Cool Ink™ HD Gobos
Cool Ink HD gobos are recommended when
a longer lifespan and greater projected
resolution are desired from your plastic gobo.
Protective coated glass layers and a metal
bezel sandwich the plastic for greater durability
and to allow the image area to be cleaned with a
soft dry cloth (unlike straight plastic). A true opaque black
background in the Cool Ink HD gobo creates the higher
definition image. Rosco provides fast turnaround from receiving
your artwork to shipping the product, usually just two business
days for Cool Ink HD Gobos.
Cool Ink HD Custom Plastic Gobo, Custom Size
No. 265 2700HD999
Cool Ink HD Custom Plastic Gobo, “B” Size
No. 265 27000HD86
Cool Ink HD Standard Gobo Design
No. 265 2700HD000
Kreios Cool Ink Custom Plastic Gobo, specfically for Kreios
units, 37.5mm
No. 255 2HDKR375
www.rosco.com
13
Gobos and Projection Equipment
Belts vs. Gears:
The Vortex 360 and the Double Gobo Rotator, shown on the next page, use precision machined metal gears as the drive mechanism. From the
motor shaft to the gobo wheel, each point of contact in the drive assembly is gear to gear. The advantages are as obvious now as they were nearly
twenty years ago when these products were first designed—rock solid reliable movement and a durable, low maintenance mechanism.
The Revo, Revo PRO and Simple Spin rotators, introduced in 2011, were designed with belt drive systems. The significant benefit of the belt drive
in Rosco's new rotators series is that it is virtually silent, and fully 25% quieter than other rotators. An inherent difference with belt drive is a more
consistent smooth rotation as the belt is constantly in contact.
RevoPRO™ Gobo Rotator
SimpleSpin™ Dual Gobo Rotator
A dual programmable rotator which
includes complete DMX controlled
indexing features plus a stand-alone
programmable mode that requires no
DMX. Internal 100-240v mains power,
so no PSU is required. Like all Rosco Revo
rotators, it is built with a high temperature
silicon belt drive, stepper motors, a unique
threaded collar for easy installation of glass
or steel gobos, friction lock for secure
placement and dimmer control
capability.
One stepper motor, two gobos, Rosco’s
SimpleSpin rotator is a variable speed
device capable of rotating two gobos in
opposing direction. A “set and forget”
on-board speed control and direction
switch is included, as is an internal
universal power supply at 100-240v,
50/60hz. The device can also be
controlled by connecting it to a dimmer. Like all Rosco Revo rotators, it is
built with a high temperature silicon
belt drive, a unique threaded collar for
easy installation of glass or steel gobos
and a friction lock for secure
placement.
RevoPRO™ Gobo Rotator
No. 205 64250 0000
SimpleSpin™ Dual Gobo Rotator
No. 205 63100 0000
REVO™ Dual Indexing Rotator
Two independent variable speed stepper
motors with 8 or 16-bit indexing on both
wheels provide maximum design flexibility.
Like all Rosco Revo rotators, it is built with
a high temperature silicon belt drive,
stepper motors, a unique threaded collar
for easy installation of glass or steel gobos,
friction lock for secure placement and
dimmer control capability.
REVO™ Dual Indexing Rotator
No. 205 64200 0000
CLEARANCE*
Revo Rotator Accessories
PSU-50
24v x 50 watt power supply
No. 205 71402 0050
PSU-200
24v x 200 watt power supply
No. 205 71402 0200
4 Pin Extension Cable - 7.62m
No. 205 70002 0025
4 Pin Extension Cable - 15.24m
No. 205 70002 0050
www.rosco.com
14
Gobos and Projection Equipment
Vortex Gobo Rotator
CLEARANCE*
Infinity Gobo Animation Unit
The sleek unit houses two carefully
crafted drives. A single silent motor
drives both assemblies. Even at full
speed, the Vortex 360 Dual Rotator
is so quiet it can be used anywhere
in a theatre or venue. The Vortex 360 does not require any
additional power supply. The transformer/plug that comes with
it can be plugged directly into a wall outlet.
The Infinity Gobo Animation Unit, which
can be attached to virtually any spotlight,
is used with a steel or glass gobo in the
gate to provide unusual kinetic effects.
The Infinity is equipped with onboard
control of the Infinity Disk speed and
direction, as well as an on/off switch.
Supplied with an adaptor plate and one
Infinity Disk of your choice.
Vortex 360 Dual Rotator
No. 205 83000 0000
Infinity
No. 205 82500 0000
Double Gobo Rotator
CLEARANCE*
Rosco’s Double Gobo Rotator allows
you to achieve kinetic and often
spectacular lighting effects by rotating
two gobos in the same or opposite
directions, at the same or varying
speeds. This unit requires a DMX/DC
Controller, Variable Speed Controller or
MFX Control Adaptor.
Double Gobo Rotator
DC Vari-Speed, 0-9 RPM
No. 78RTR203/V
Infinity Disks
Infinity disks are etched stainless steel disks powder coated to
prevent reflection. Eleven designs are available. The disks are
42cm (16.5”) in diameter.
Infinity Disks
30011 Tangential Breakup
30012 Radial Breakup
30013 Spiral Breakup
30014 Linear Breakup
30015 Triangle Breakup
30016 Cloud Breakup
30017 Elliptical Breakup
30018 Dot Breakup
30019 Flicker Breakup
30020 Coarse Radial Breakup
30021 Coarse Tangential
Breakup
Double Gobo Rotator Accessories
DMX/DC Controller
CLEARANCE*
No. 78DCON/DMX
The Rosco DMX/DC Controller provides power and speed
control for the Double Gobo Rotator. It is intended for remote
control via a DMX512 signal. The output circuitry of Rosco’s
DMX/DC Controller is identical to that of its four channel
Variable Speed Controller. Speed, range, bi-directional drive,
load compensation and output protection are all maintained.
Variable Speed Controller
CLEARANCE*
No. 78DCON
This four channel Variable Speed Controller is designed to
provide power, direction and speed control for variable speed
rotator units on four independent channels. Output connections
are made via four conductor cables terminating in two 4-pin
XLR connectors.
30011
TANGENTIAL BREAKUP
30012
RADIAL BREAKUP
30013
SPIRAL BREAKUP
30014
LINEAR BREAKUP
30015
TRIANGLE BREAKUP
30016
CLOUD BREAKUP
Mounting Kit for DC/DMX Controller and
a Variable Speed Controller
CLEARANCE*
No. 205 70003 0KIT
DC Splitter Cable
CLEARANCE*
No. 205 70001 0000
30017
ELLIPTICAL BREAKUP
30018
DOT BREAKUP
30020
COARSE RADIAL
BREAKUP
30021
COARSE TANGENTIAL
BREAKUP
30019
FLICKER WHEEL
www.rosco.com
15
Gobos and Projection Equipment
iPro™ Image Projector
X24 X-Effects Projector
This has become the projector of choice
for shows or installations requiring a fire or
water effect. It provides stunning rippling
light effects previously unavailable to
designers. The projector is available with
on-board DMX with dowser for theatrical
applications and in an analog version for
retail, museum or architectural applications.
The iPro fits as an accessory into the
iris slot of a typical ETC Source Four,
Altman Shakespeare, Strand SL or
Selecon Pacific light fixture. Fitted
with an iPro Slide, the iPro™ delivers
bright, visible full-colour images that
will last between 15 and 50 hours.
X24 DMX X-Effects - Black (lens sold separately)
No. 205 37015 0120
X24 DMX X-Effects - White (lens sold separately)
No. 205 37025 0120
iPro Image Projector
No. 265 25100 0240
iPro™ Slide Film
19 Degree Lens for X-Effects
No. 206 37119 0000
30 Degree Lens for X-Effects
No. 206 37130 0000
50 Degree Lens for X-Effects
No. 206 37150 0000
70 Degree Lens for X-Effects
No. 206 37170 0000
X24 Replacement Lamp – emARC SMR202/D1
No. 206 37101 0000
For use with the Rosco iPro, iPro Slide
Film has been formulated from the
ground up to produce the highest
quality iPro Slide possible.
iPro Slide Film—1 sheet pack (LTR Size)
No. 265 27995 A401
iPro Slide Film—10 sheet pack (LTR Size)
No. 265 27995 A410
iPro Slide Film—25 sheet pack (LTR Size)
No. 265 27995 A425
iPro Printing Pack
Contains 10 sheets of iPro Slide Film and
10 One-Time iPro Slide Mounts
No. 265 27985 A410
iPro™ One-Time Slide Mount
Contains the slide mount and protective film necessary to make
an effective iPro Slide. Using your own transparency film and
your own printer to create the image, you can then assemble a
finished iPro Slide. Transparency film not included.
iPro Slide Mount
No. 265 27999 0860
Power Supply Units
Rosco’s power supplies are compatible with
nearly all colour scrollers, gobo rotators and
other accessory devices in common use. The
PSU-200 has four outputs and four returns. It
can be pipe mounted with a C-Clamp or other
hanging device. PSU-51 has a DMX
passthrough.
PSU-200
No. 205 71402 0200
PSU-50
No. 205 71402 0050
Hybrid Two-Fer
PSU-200
This accessory allows you to
connect the iPro and your light
fixture into the same dimmer. The
two-fer is configured with a male
stage-pin connector for the dimmer
and both a female stage pin connector for the light and a female
parallel blade connector for the iPro.
Hybrid Two-Fer
No. 265 25500 0000
www.rosco.com
16
Luminaire and Lighting Accessories
I-Cue Intelligent Mirror
A spotlight attachment to re-position a
beam of light. This allows a single
spotlight in a fixed position to be used
for multiple specials in dozens of locations. Onboard DMX is
included. A Power Supply Unit is necessary to get 24v DC to
the I-Cue.
I-Cue
No. 205 81000 0120
DMX Iris
Having complete control over the
beam spread of your leko just got
easier. The Rosco DMX Iris is
quiet, dependable, affordable,
and a perfect complement to the
I-Cue Moving Mirror. This 24 leaf
motorized iris unit can be used
with your ETC Source Four,
Selecon Pacific or most other
modern lekos. Unlike other iris
units that have only 18 or fewer
leaves in the aperture, the Rosco
DMX Iris creates an even edged, perfectly round aperture all the
way down to its smallest diameter. Using 1 channel of DMX512,
the DMX Iris’s movement is smooth even along very slow cross
fades. A microprocessor controlled stepper motor connects to
the mechanical arm of the iris unit, replacing the unreliable
noisy chain drive system found in other products. A manual
knob lets you use the DMX Iris without DMX control just by
dialing in the aperture size you want, just as you would a
conventional iris unit. The Rosco DMX Iris requires a non-dim
circuit and is auto-sensing from 100-240 volts for use anywhere
in the world. No costly external PSU is needed.
DMX Iris
No. 205 74500 0000
Miro Cubes™
Miro Cubes™ LED fixtures deliver powerful light output from a
self-contained, 50 watt, 10cm (4”) cube. An optional ARC
configuration is available on the WNC and 4C units, which offers a
hard-wired pigtail and recessed Rj45 DMX ports for permanent
installs.
Miro Cube WNC
This 10cm (4") luminaire provides 3100
lumens of bright, tunable white light.
Output can be adjusted from 2800K to
6500K, for film/TV, theatrical or
architectural applications.
Miro Cube WNC - Black
No. 515 90050 1020
Miro Cube WNC - White
No. 515 90050 2020
Miro Cube WNC ARC - Black
No. 515 90050 1029
Miro Cube WNC ARC - White
No. 515 90050 2029
Miro Cube 4C
Using RGBW Quad Chip technology,
this colour mixing wash light offers a
true white, plus a palette of saturated
mid-tone and pale tint colours which
can be dialed in at the touch of a
button.
Miro Cube 4C - Black
No. 515 90050 1014
Miro Cube 4C - White
No. 515 90050 2014
Miro Cube 4C ARC - Black
No. 515 90050 1019
Miro Cube 4C ARC - White
No. 515 90050 2019
Miro Cube UV
The smallest, most affordable high
powered UV light available to lighting
professionals. The LED emitters have a
20,000 hour life assuring a virtually
maintenance-free installation. The
luminaire outperforms conventional
long throw fixtures in virtually every
category and offers full range dimming
for the first time in a UV source.
Miro Cube UV - Black
No. 515 90050 1075
www.rosco.com
17
Lighting
and and
Projection
Equipment
Luminaire
Lighting
Accessories
Miro Accessories
Braq Cubes™
Braq Cube™ LED fixtures deliver powerful light output from a
self-contained, 100 watt, 12.7cm (5”) cube. Braq Cubes are
easily capable of 15 metre throws, making them perfect for full
stage colour washes, as key lighting inside broadcast studios, or
as a downlight in retail stores, museums or other architectural
installations.
Top Hat
No. 515 91031 0003
Egg Crate Louvre
No. 515 91031 0003
1/2 Top Hat
No. 515 91031 0002
Barn Doors (set of 4) - Black
No. 515 91030 0000
Barn Doors (set of 4) - White
No. 515 91030 0005
Double-Yoke
No. 515 91021 0000
Spread Lenses for Symmetrical and Asymmetrical Beam Shaping
Standard Lens - Set of 3 (20, 40, 60)
No. 515 91010 0001
Standard Lens - 20 Degrees
No. 515 91010 0020
Standard Lens - 40 Degrees
No. 515 91010 0040
Standard Lens - 60 Degrees
No. 515 91010 0060
Assymetric Lens - Set of 3 (60x10, 30x50, 75x45)
No. 515 91010 0002
Assymetric Lens - 30x50 Degrees
No. 515 91010 3005
Assymetric Lens - 60x10 Degrees
No. 515 91010 6010
Assymetric Lens - 75x45 Degrees
No. 515 91010 7540
UV Lens - Set of 3 (20, 40, 60)
No. 515 91011 0001
UV Lens - 20 Degrees
No. 515 91011 0020
UV Lens - 40 Degrees
No. 515 91011 0040
UV Lens - 60 Degrees
No. 515 91011 0060
Lens Cover Thumb Screw - Set of 4
No. 515 91012 0004
Standard UV Pass Filter
No. 515 93660 1000
Clear Lens Cover - Rigid
No. 515 91012 0005
Braq Cube WNC
Utilising a tri-colour mix of warm, neutral and cool LEDs, this luminaire provides 7100 lumens of bright,
tunable white light. Its output can be
adjusted from 2800K to 6500K to
create any colour temperature desired
for broadcast, theatrical or
architectural applications.
Braq Cube WNC w/Power Cord - Black
No. 515 90100 1020
Braq Cube WNC w/Power Cord - White
No. 515 90100 2020
Braq Cube WNC No Power Cord - Black
No. 515 90100 1120
Braq Cube WNC No Power Cord - White
No. 515 90100 2120
Braq Cube 4C
Using RGBW Quad Chip technology,
this high-output, colour-mixing LED
fixture offers a stunning palette of saturated mid-tone and pale tint
colours, as well as a gorgeous white
light – all of which can be dialed in at
the touch of a button.
Braq Cube 4C w/Power Cord - Black
No. 515 90100 1014
Braq Cube 4C w/Power Cord - White
No. 515 90100 2014
Braq Cube 4C No Power Cord - Black
No. 515 90100 1114
Braq Cube 4C No Power Cord - White
No. 515 90100 2114
Miro/Braq Powercon Cord with Edison Plug
No. 515 91015 0005
Powercon Cord with Edison
No. 515 91015 0001
www.rosco.com
18
Luminaire and Lighting Accessories
Miro/Braq Accessories
Braq Accessories
Power Cord with In-Line Switch
No. 515 91017 0005
Accesory Holder
No. 515 91032 0000
Top Hat
No. 515 91032 0001
Egg Crate Louvre
No. 515 91032 0002
Barn Doors
No. 515 91032 0003
Double-Yoke Black
No. 515 91023 0000
Double-Yoke White
No. 515 91023 0001
Spread Lenses for Symmetrical Beam Shaping
Standard Lens - Set of 3 (20, 40, 60)
No. 515 91010 0003
Standard Lens - 20 Degrees
No. 515 91010 0120
Standard Lens - 40 Degrees
No. 515 91010 0140
Standard Lens - 60 Degrees
No. 515 91010 0160
5/8” Receiver for Light Stands
No. 515 91026 0001
C-Clamp (1.5” - 2” OD Pipe)
No. 515 91025 0001
Miro/Braq Preset Remote
An easy-to-use, handheld remote that provides easy control of Miro or
Braq Cube LED fixtures. Four control modes offer 36 colour choices
on the 4C, as well as 10 colour temperature presets and smooth,
flicker-free dimming for both the 4C & WNC.
Miro/Braq Preset Remote
No. 515 91015 0000
www.rosco.com
19
Lighting
and and
Projection
Equipment
Luminaire
Lighting
Accessories
Miro/Braq Track Mounting
Track Adaptor Yoke Assembly
Miro Cube Track Adapter Yokes allow the
compact and lightweight Miro Cube to be
powered from many common lighting track
systems. These Adaptor/Yoke Assemblies replace the mounting yoke provided on the
Miro Cube and allow it to be
easily positioned any where along the
length of track. In addition to the standard yoke assemblies offered,
custom adaptor yokes can be made for most line voltage or mains
powered track system around the world. Please inquire with your
local Rosco representative or Distributor.
Note that Miro Cubes cannot be used on low voltage track systems.
Miro/Braq Track Mounting – continued
Two Circuit DMX Data Track
Track lighting is a standard item in the lighting
design tool box. It is ideal for architectural,
themed environment, low ceiling height, retail
and museum applications where discrete, reconfigurable, low profile fixtures and a clean
look are required. The Black Tank's DMX Data
Track takes track lighting to the next level by
combining power and full speed DMX512 control in a single track, and track adapters allow
you to integrate and control any Miro/Braq Cube™ fixture.
DMX Data Track provides an incredible solution for architectural installations and for reconfigurable performance spaces. The DMX data
allows dynamic control of lighting, colour temperature (white light) or
colour mixing as desired.
Track Adaptor Yoke – Halo Fixtures
No. 515 91101 0000
Track Adaptor Yoke – Juno Fixtures
No. 515 91102 0000
Track Adaptor Yoke – LSI Fixtures
No. 515 91103 0000
Track Adaptor Yoke – Custom
No. 515 91199 0000
The specification grade surface mounted track system contains 7 conductors and includes 2 uniquely selectable power circuits. A 22 gauge
nickel plated copper data bus provides full speed DMX512 control of
lighting fixtures and provides control signal at any point along the
track. The track consists of an extruded aluminum profile which can
be easily cut to length onsite. The track also has pre-punched holes at
200mm (8") spacing for mounting.
Miro WNC ARC w/Data Track Adapter - White
No. 515 91110 0004
Miro WNC ARC w/Data Track Adapter - Black
No. 515 91110 0005
100mm (4") White
No. 515911110401
100mm (4") Black
No. 515911110402
Miro 4C ARC w/Data Track Adapter - White
No. 515 91110 0006
Miro 4C ARC w/Data Track Adapter - Black
No. 515 91110 0007
200mm (8") White
No. 515911110801
200mm (8") Black
No. 515911110802
Braq 254mm (10”) Double Yoke Assy. - Black
No. 515 91023 0000
Braq 254mm (10”) Double Yoke Assy. - White
No. 515 91023 0001
300mm (12") White
No. 515911111201
300mm (12") Black
No. 515911111202
200mm (8”) Double Yoke Assembly
No. 515 91021 0000
300mm (12”) Double Yoke Assembly
No. 515 91022 0000
www.rosco.com
20
Lighting and
Equipment
Luminaire
andProjection
Lighting Accessories
Miro/Braq Track Accessories
Track Adaptor Yoke with Power and DMX
White
No. 515 91110 0001
Black
No. 515 91110 0002
Live End Feed
Ground Inside
White No. 515 91112 0001
Black
No. 515 91112 0002
Ground Outside
No. 515 91113 0001
No. 515 91113 0002
Miro/Braq Track Accessories – continued
50mm (2") Mounting Clip for 9.5mm (3/8") Diameter Stem
White
No. 515 91122 0001
Black
No. 515 91122 0002
Pendant Clip
50mm (2")
White No. 515 91120 0001
Black
No. 515 91120 0002
White
Black
Straight Coupler – Track Joiner
White
No. 515 91115 0001
Black
No. 515 91115 0002
L-Coupler
White
No. 515 91117 0001
Black
No. 515 91117 0002
2 Circuit Flex-Coupler
White
No. 515 91119 0001
Black
No. 515 91119 0002
100mm (4")
No. 515 91121 0001
No. 515 91121 0002
9.5mm (3/8") Pendant Stem 609mm (24") Long
White
No. 515 91123 0001
Black
No. 515 91123 0002
127mm (5") Canopy – Support Only
White
No. 515 91126 0001
Black
No. 515 91126 0002
Canopy Feed Cover
White
No. 515 91125 0001
Black
No. 515 91125 0002
Straight Coupler – Electrical Feed
White
No. 515 91116 0001
Black
No. 515 91116 0002
Dead End Cap
White
No. 515 91114 0001
Black
No. 515 91114 0002
www.rosco.com
21
Luminaire and Lighting Accessories
Silk™210 LED Fixture
Silk™ 210 Accessories
Silk™ 210 Egg Crate Louver 45°
No. DM-SIL-210LV45
Silk™ 210 Egg Crate Louver 60°
No. DM-SIL-210LV60
Silk™ 210 Barn Doors
No. BD-SIL-210
Silk™ 210 SoftBox
No. DM-SIL-210SB
Silk™ 210 Soft Carrying Case
No. CAS-SIL-210S
Silk™ 210 Rain Cover
No. CAS-SIL-210RC
Designed to meet the requirements of the most discerning filmmaker,
the Silk 210 LED Fixture has been specifically developed for film and
video applications that demand high-quality light output with
extreme colour accuracy.
Utilising proprietary, state-of-the-art, tungsten & daylight balanced
LEDs, Silk 210 produces a high volume of broad-spectrum white
light. With TLCI, CRI and R9 metrics in the high 90’s, the fixture is
capable of producing a high volume of light output at colour
temperatures ranging from 2800K – 6500K.
The Silk 210 features a non-glare diffuser to provide a uniform,
single-source light, which creates enticingly soft, diffused light that
gently embraces its subjects. The fixture has on-board dimming and
colour temperature controls for filmmakers to control the fixture
on-location, as well as DMX options for integration into broadcast
studios. It ships with a 100 – 240 AC power supply, enabling it for
worldwide use, and V-Lock, Anton/Bauer and 4-Pin battery options
are available to enable maximum portability.
The Rosco Silk 210 LED fixture is available as an individual unit or as
a single-unit kit that includes a lightweight, soft-cover case, and an
egg crate louvre.
Silk™ 210 LED Fixture
No. LHSIL210UK
No. LHSIL210EU
Silk™ AC PSU
No. TR-COM-120WOC
US IEC AC Power Cable
No. SCHI-C13US
UK IEC AC Power Cable
No. SCHI-C13UK
EU IEC AC Power Cable
No. SCHI-C13EU
Silk™ AC PSU Cradle
No. TR-SIL-120WC
Silk™ Anton/Bauer Battery Cheese Plate
No. BB-SIL-ABCP
Silk™ V-Lock Battery Cheese Plate
No. BB-SIL-VLOCP
Silk™ 210 LED Kit
No. KITSIL210UK
No. KITSIL210EU
Silk™ 210 single-unit kit
www.rosco.com
22
Luminaire and Lighting Accessories
LitePad Vector™
LitePad Vector produces a soft, flattering light output that filmmakers,
lighting directors and photographers can use in their projects when
they’re on-location and in small studios. LitePad Vector provides the
same edge-lit LED lighting that LitePad is known for – but with
improved brightness, colour rendering and a streamlined footprint.
Measuring in at 200mm x 200mm, LitePad Vector is available in two
models – Vector CCT (variable colour temperature) and Vector
Daylight (fixed at 6000K). Thanks to its on-board dimming & colour
temperature controls, and its compatibility with standard Anton/
Bauer or V-Mount battery packs, the LitePad Vector is the optimal
choice for illuminating any project that needs a compact, mobile
light fixture.
LitePad Vector™Kits
LitePad™ Vector is designed to travel anywhere a soft, flattering
light output is needed. Two LitePad Vector Kits are available in
order to maximize LitePad Vector’s compact, lightweight mobility:
a Two-Head Backpack Kit and a Three-Head Location Lighting Kit.
Whether it’s on top of a mountain, deep inside an ice cave or an
office building across town during rush hour, some locations are
more remote than others – but they all need proper lighting. Both
kits enable shooters to quickly and professionally set up their
lighting at any location.
See the LitePad Vector Kits Web Page for a full listing of what’s
inside each kit.
LitePad Vector CCT
No. 292 00808 0120
LitePad Vector Daylight
No. 292 00808 0056
LitePad Vector™Accessories
LitePad Vector Honeycomb Egg Crate
No. 292 00808 0200
LitePad Vector OPTI-FLECS LED Enhancement Filter Kit
No. 292 00080 8200
LitePad Vector Backpack Kit
2-Head LitePad Vector CCT Backpack Kit
No. 292 02080 8120
2-Head LitePad Vector Daylight Backpack Kit
No. 292 00808 0056
LitePad Vector Rain Cover
No. 292 00080 8300
LitePad Anton/Bauer Cheeseplate Assembly
No. 291 10305 0101
LitePad V-Mount Cheeseplate Assembly
No. 291 10305 0102
LitePad Light Stand
No. 2906 6104 9089
LitePad Carabiner Bottle Holder
No. 292 00080 8500
C-Clamp (1.5”-2” OD Pipe)
No. 515 91025 0001
Replacement 5/8” (16mm) Light Stand Receiver
No. 515 91026 0001
LitePad Vector Location Lighting Kit
3-Head LitePad Vector CCT Location Lighting Kit
No. 292 03080 8120
3-Head LitePad Vector Daylight Location Lighting Kit
No. 292 03080 8056
www.rosco.com
23
Luminaire and Lighting Accessories
LitePad Axiom
The LitePad Axiom range is a series of LED light sources
designed specifically for filmmakers, videographers and
photographers. The housing not only protects the light source, it
also provides a universal mounting system. This allows the
LitePad Axiom units to be affixed with brackets for C-Stands
or other conventional methods. Each product is available with
either tungsten-level or daylight-level output and with or
without a transformer.
LitePad Axiom Daylight
LitePad Axiom 76mm x 152mm Daylight (3” x 6”)
No. 290 70306 0240
LitePad Axiom 76mm x 305mm Daylight (3” x 12”)
No. 290 70312 0240
LitePad Axiom 152mm x 152mm Daylight (6” x 6”)
No. 290 70606 0240
LitePad Axiom 152mm x 305mm Daylight (6” x 12”)
No. 290 70612 0240
LitePad Axiom 305mm x 305mm Daylight (12” x 12”)
No. 290 71212 0240
LitePad Axiom 610mm x 610mm Daylight (24” x 24”)
No. 290 72424 0240
LitePad Axiom Tungsten
CLEARANCE*
LitePad Axiom 76mm x 152mm Tungsten (3” x 6”)
No. 290 80306 0240
LitePad Axiom 76mm x 305mm Tungsten (3” x 12”)
No. 290 80312 0240
LitePad Axiom 152mm x 152mm Tungsten (6” x 6”)
No. 290 80606 0240
LitePad Axiom 152mm x 305mm Tungsten (6” x 12”)
No. 290 80612 0240
LitePad Axiom 305mm x 305mm Tungsten (12” x 12”)
No. 290 81212 0240
LitePad Axiom 610mm x 610mm Tungsten (24” x 24”)
No. 290 82424 0240
LitePad™ HO+
LitePad HO+ is a slim profile, edge-lit LED light source. At
only 8mm thick, LitePad HO+ produces a soft quality of light
that is easy on the eyes and runs at cool temperatures. Available
in eight standard sizes, in either tungsten-level or daylight-level
outputs and with or without transformers.
LitePad HO+ Daylight
LitePad 76mm x 152mm HO+ Daylight (3” x 6’)
No. 290 40306 0240
LitePad 76mm x 305mm HO+ Daylight (3” x 12”)
No. 290 40312 0240
LitePad 152mm x 152mm HO+ Daylight (6” x 6”)
No. 290 40606 0240
LitePad 152mm x 305mm HO+ Daylight (6” x 12”)
No. 290 40612 0240
LitePad 305mm 305mm HO+ Daylight (12” x 12”)
No. 290 41212 0240
LitePad 610mm x 610mm HO+ Daylight (24” x 24”)
No. 290 42424 0240
LitePad 76mm Circle HO+ Daylight (3”)
No. 290 40003 0240
LitePad 305mm Circle HO+ Daylight (12”)
No. 290 40012 0240
LitePad HO+ Tungsten
CLEARANCE*
LitePad 76mm x 152mm HO+ Tungsten (3” x 6’)
No. 290 50306 0240
LitePad 76mm x 305mm HO+ Tungsten (3” x 12”)
No. 290 50312 0240
LitePad 152mm x 152mmmm HO+Tungsten (6” x 6”)
No. 290 50606 0240
LitePad 152mm x 305mm HO+ Tungsten (6” x 12”)
No. 290 50612 0240
LitePad 305mm x 305mm HO+ Tungsten (12” x 12”)
No. 290 51212 0240
LitePad 610mm x 610mm HO+ Tungsten (24” x 24”)
No. 290 52424 0240
LitePad 76mm Circle HO+ Tungsten (3”)
No. 290 50003 0240
LitePad 305mm Circle HO+ Tungsten (12”)
No. 290 50012 0240
LitePad HO+ is available in Tungsten and Daylight.
www.rosco.com
24
Luminaire and Lighting Accessories
LitePad™ DL
LitePad DL is a slim profile (8mm) light source that delivers soft,
even illumination in a sustainable, energy-efficient LED package,
consuming about 40% less energy than LitePad HO+. LitePad
DL was designed with event planners, theatrical lighting and
architectural designers in mind, offering a more economical
lighting solution for these professionals. Available in six standard
sizes in daylight-level outputs and with or without transformers.
LitePad DL Daylight
CLEARANCE*
LitePad 76mm x 76mm DL (3” x 3”)
No. 290 10303 0240
LitePad 76mm x 152mm DL (3” x 6”)
No. 290 10306 0240
LitePad 76mm x 305mm DL (3” x 12”)
No. 290 10312 0240
LitePad 152mm x 152mm DL (6” x 6”)
No. 290 10606 0240
LitePad 152mm x 610mm DL (6” x 12”)
No. 290 10612 0240
LitePad 610mm x 610mm DL (12” x 12”)
No. 290 11212 0240
Custom LitePad™
Custom LitePad HO90
Rosco LitePad HO90 is a flat panel LED light source providing
even, indirect lighting and is available in three colour
temperatures: 2800K, 4000K, and 5300K. At only 8mm thick,
LitePad HO90 is perfectly suited to virtually any backlighting
installation or to projects where only a cool, low profile light
source can be used. LitePad’s patented system is comprised of
indirect LED sources machined into a cast acrylic panel. Light
amplifying channels etched into the rear surface of the plastic
sheet smoothly and evenly distribute light across the entire
surface of the LitePad. This durable and reliable construction can
be fabricated in virtually any size or shape and is easily installed.
A variety of options are available to customise light output, power
management, and dimming control. Rosco project consultants
are available to assist in specifying the optimal configuration of
panels and accessories for your project.
Custom LitePad™ - continued
Custom LitePad CCT
Rosco LitePad CCT is a tunable white, flat panel LED light source,
providing even, indirect lighting. At only 8mm thick, LitePad CCT
is perfectly suited to virtually any backlighting installation or to
projects where only a cool, low profile light source can be used.
LitePad’s patented system is comprised of indirect LED sources
machined into a cast acrylic panel. Light amplifying channels
etched into the rear surface of the plastic sheet smoothly and
evenly distribute light across the entire surface of the LitePad.
This durable and reliable construction can be fabricated in
virtually any size or shape and is easily installed.
LitePad CCT Tunable White offers all the same features of
Rosco’s standard LitePad product but includes a variable colour
temperature light output. Two separate channels of LEDs allow
you to dial in the precise quality of white light, from 3000K to
6500K. Dimming and control accessories sold separately.
Custom LitePad RGB
Rosco LitePad RGB is a colour changing, flat panel LED light
source providing even, indirect lighting. At only 10mm thick,
LitePad RGB is perfectly suited to virtually any backlighting
installation or to projects where only a cool, low profile light
source can be used. LitePad’s patented system is comprised of
indirect LED sources machined into a cast acrylic panel. Light
amplifying channels etched into the rear surface of the plastic
sheet smoothly and evenly distribute light across the entire
surface of the LitePad. This durable and reliable construction can
be fabricated in virtually any size or shape and is easily installed.
A variety of options are available to customise light output, power
management, and dimming control. Rosco project consultants
are available to assist in specifying the optimal configuration of
panels and accessories for your project.
LitePad RGB Variable Colour offers all the same features of
Rosco’s standard LitePad product but uses high quality colour
mixing RGB chips. Three channels of control are used to dial in
the precise colour desired. Dimming and control accessories sold
separately.
LitePad HO90 offers all the same features of Rosco’s standard
LitePad product but offers a superior colour rendering for projects
where colour fidelity is critical.
www.rosco.com
25
Luminaire and Lighting Accessories
LitePad™ Loop
CLEARANCE*
Rosco LitePad Loop is an LED ring
light designed to fit practically any
style camera, including film, video
and DSLR’s. Because the Loop is
powered by Rosco’s LitePad LED
technology, this ring light has a soft,
flattering, shadowless light output
that is perfect for close-ups, portraits,
interviews, product shots or macro
photography. Available as an
individual unit that comes with everything needed to attach the Loop to your camera or in a Pro Kit
that contains additional mounting and power accessories that
allow for cord-free mobility.
LitePad™ Kits
Rosco offers four different kits
for filmmakers, digital shooters
and still photographers. Each of
the four is available with a full
complement of Axiom LitePads
and the required accessories for
focusing, mounting, and colouring. Kits can be specified with
either daylight-level output
LitePads or tungsten-level output.
A fifth kit, the HO+ Everywhere Kit,
is equipped with both tungsten and
daylight level HO+ LitePads.
Digital Shooter
LitePad Kit
See the Rosco web site for details on what is in each kit.
LitePad Pro Gaffer’s Kit AX: Daylight
No. 290 240AXGKIT
LitePad Digital Shooters Kit AX: Daylight
No. 290 2400DSKIT
LitePad Quick Kit AX: Daylight
No. 290 240AXBKIT
LitePad Still Photo Kit AX: Daylight
No. 290 2400SPKIT
LitePad Loop
LitePad Loop
291088750BOX
LitePad Loop Pro Kit
291088750KIT
LitePad Loop Accessories
LitePad Loop Thumb Screw Replacements - 4 Pack
No. 291200021032
LitePad Loop Anton Bauer Bracket w/Cheeseplate
291103050101
LitePad Loop Colour Pack
291200000008
LitePad Loop 101mm (4") Rods
291200030204
LitePad Loop 203mm (8") Rods
291200030208
LitePad Loop AA Battery Kit
291636510812
LitePad Loop 101mm (4") L-Bracket Kit
291600010014
LitePad Loop Light Stand Plate
291600040002
LitePad Loop Light Masks
291200001008
LitePad Loop Pull String Storage Pouch
291660000909
LitePad Pro Gaffer’s Kit AX: Tungsten
CLEARANCE*
No. 290 241AXGKIT
LitePad Digital Shooters Kit AX: Tungsten
CLEARANCE*
No. 290 2410DSKIT
LitePad Quick Kit AX: Tungsten
CLEARANCE*
290 241AXBKIT
LitePad Still Photo Kit AX: Tungsten
CLEARANCE*
290 2410SPKIT
LitePad HO+ Everywhere Lighting Kit
No. 290 2400ELKIT
LitePad™ Accessories
LitePad 3 amp Transformer
No. 290 63503 0240
LitePad 5 amp Transformer
No. 290 63505 0240
Car Adapter
No. 290 63600 0000
Y Splitter
No. 290 63700 0000
3m Extension Cable
No. 290 63750 0000
4-Way Spider
No. 290 63730 0000
AA Battery Holder
No. 290 63651 0812
4-Pin Adapter Cable
No. 290 63770 0012
Anton/Bauer Adapter
No. 290 63790 0012
Right Angle 10' Extension Cable
No. 290 63751 0000
Car Adapter
Anton/Bauer Adapter
www.rosco.com
26
Luminaire and Lighting Accessories
LitePad™ Accessories – continued
LitePad 76mm Mounting Bracket (3”)
No. 290 63900 0003
LitePad 152mm Mounting Bracket (6”)
No. 290 63900 0006
LitePad 305mm Mounting Bracket (12”)
No. 290 63900 0012
LitePad 610mm Mounting Bracket (24”)
No. 290 63900 0024
1/4 – 20 Baby (5/8) Pin
No. 290 63910 1420
LitePad Axiom 1/4 – 20 Bracket
No. 290 63901 1420
LitePad Axiom Baby Pin Bracket
No. 290 63901 0058
LitePad Axiom 5/8 Receiver Bracket
No. 290 63901 0158
LitePad Axiom Wall Plate Bracket
No. 290 63901 0304
LitePad Axiom Battery Holder (for AA Battery)
No. 290 63901 8080
76mm x 152mm Eggcrate (3” x 6”)
No. 290 65000 0306
76mm x 305mm Eggcrate (3” x 12”)
No. 290 65000 0312
152mm x 152mm Eggcrate (6” x 6”)
No. 290 65000 0606
152mm x 305mm Eggcrate (6” x 12”)
No. 290 65000 0612
305mm x 305mm Eggcrate (12” x 12”)
No. 290 65000 1212
610mm x 610mm Eggcrate (24” x 24”)
No. 290 65000 2424
152mm x 152mm
Eggcrate
Single Fader Dimmer
No. 290 64000 0012
2 CH/DMX Dimmer
No. 290 64100 0012
LitePad Light Stand
No. 290 66104 9089
LitePad Snake Arm
No. 290 66114 2002
LitePad Swivel Arm
No. 290 66158 1420
LightPad Cold Shoe Attachment
No. 290 66100 1420
EZ-TIE
No. 29066TIE0241
Swivel Arm
LitePad™ Accessories – continued
76mm Circle Medium Spot Lens (3”)
No. 290 67001 0003
76mm x 152mm Medium Spot Lens (3” x 6”)
No. 290 67001 0306
76mm x 305mm Medium Spot Lens (3” x 12”)
No. 290 67001 0312
152mm x 152mm Medium Spot Lens (6” x 6”)
No. 290 67001 0606
152mm x 305mm Medium Spot Lens (6” x 12”)
No. 290 67001 0612
305mm x 305mm Medium Spot Lens (12” x 12”)
No. 290 67001 1212
610mm x 610mm Medium Spot Lens (24” x 24”)
No. 290 67001 2424
305mm Circle Medium Spot Lens (12”)
No. 290 67001 0012
76mm Circle Full Spot Lens (3”)
No. 290 67002 0003
76mmx 152mm Full Spot Lens (3” x 6”)
No. 290 67002 0306
76mm x 305mm Full Spot Lens (3” x 12”)
No. 290 67002 0312
152mm x 152mm Full Spot Lens (6” x 6”)
No. 290 67002 0606
152mm x 305mm Full Spot Lens (6” x 12”)
No. 290 67002 0612
305mm x 305mm Full Spot Lens (12” x 12”)
No. 290 67002 1212
610mm x 610mm Full Spot Lens (24” x 24”)
No. 290 67002 2424
305mm Circle Full Spot Lens (12”)
No. 290 67002 0012
Digital Shooter LitePad Case
No. 290 63860 0000
Still Photo LitePad Case
No. 290 63870 0000
Gaffer’s AX LitePad Case
No. 290 63851 0000
Quick AX LitePad Case
No. 290 63855 0000
610mm x 610mm LitePad Case (24" x 24")
No. 290 63880 0000
76mm x 152mmAxiom Housing (3” x 6”)
No. 290 69999 0306
76mm x 305mm Axiom Housing (3” x 12”)
No. 290 69999 0312
152mm x 152mm Axiom Housing (6” x 6”)
No. 290 69999 0606
152mm x 305mm Axiom Housing (6” x 12”)
No. 290 69999 0612
305mm v 305mm Axiom Housing (12” x 12”)
No. 290 69999 1212
610mm x 610mm Axiom Housing (24” x 24”)
No. 290 69999 2424
www.rosco.com
27
Scenic Shop Products
Off Broadway™
Paint Sample Kits
A vinyl acrylic paint which may be used on
a wide variety of scenic materials
including hard scenery, foam scenery,
drops and ground cloths.
Off Broadway Paint Kit
No. 5300
23-piece kit contains 29.57ml samples of each Off Broadway
colour plus Clear Flat and Clear Gloss.
Available in: 3.79L
White, White White and Black also available in 18.95L
Supersaturated Paint Kit
No. 6030
28-piece kit contains 29.57ml samples (neutral base not
included).
White
White White
Black
Yellow Ochre
Burnt Umber
Raw Sienna
Burnt Sienna
Raw Umber
Earth Umber
Ultramarine Blue
Fire Red
Deep Red
Orange
Emerald Green
Chrome Oxide Green
Lemon Yellow
Golden Yellow
Purple
Magenta
Pthalo Green
Sky Blue
Pthalo Blue
Imperial Green
Navy
Brilliant Red
Van Dyke Brown
Paynes Grey
No. 5350
No. 5351
No. 5352
No. 5353
No. 5354
No. 5355
No. 5356
No. 5357
No. 5358
No. 5359
No. 5360
No. 5361
No. 5363
No. 5364
No. 5365
No. 5366
No. 5367
No. 5368
No. 5369
No. 5371
No. 5372
No. 5373
No. 5374
No. 5375
No. 5376
No. 5380
No. 5382
Fluorescent Paint Kit
No. 5700
9-piece kit contains 29.57ml samples.
VividFX Sample Kit
No. 6200
13-piece kit contains 29.57ml samples.
Metallic Colours
Available in: 0.473L, 0.946L, and 3.79L
Bright Gold
No. 5383
Gold
No. 5384
Silver
No. 5385
Copper
No. 5386
Antique Gold
No. 5387
Product numbers refer to colour only.
Add 14 for 0.473L, 15 for 0.946L ,17 for 3.79L and 19 for
18.95L.
Approximate Paint Weights:
0.473L = 1 kilogram
0.946L = 1.5 kilograms
3.79L = 5 kilograms
18.95L = 27 kilograms
www.rosco.com
28
Scenic Shop Products
Supersaturated Roscopaint™
Brilliant dye-like colours formulated to be
diluted with substantial quantities of water
while retaining binder strength. Flexible vinyl
acrylic binder. Adheres to most scenic
surfaces, including muslin, plastics
and metal.
Available in: 1L and 5L
Red
Green Shade Blue
Ultramarine Blue
Chrome Green
Emerald Green
Pthalo Green
Imperial Green
Magenta
Brilliant Red
Spectrum Red
Purple
Iron Red
Chrome Yellow
Yellow Ochre
Raw Sienna
Moly Orange
Burnt Umber
Raw Umber
Burnt Sienna
Lemon Yellow
Turquoise Blue
Prussian Blue
Navy Blue
Paynes Grey
Leather Lake
Grass Green
Cerulean Blue
Hunter Green
Van Dyke Brown
No. 5965
No. 5968
No. 5969
No. 5971
No. 5972
No. 5973
No. 5974
No. 5975
No. 5976
No. 5977
No. 5979
No. 5980
No. 5981
No. 5982
No. 5983
No. 5984
No. 5985
No. 5986
No. 5987
No. 5988
No. 5989
No. 5990
No. 5991
No. 5992
No. 5993
No. 5994
No. 5996
No. 5997
No. 5998
Product numbers refer to colour only.
Add 1 for 1L and 5 for 5L.
Supersaturated Concentrated Bases™
Neutral Base
White
Velour Black
Gloss Medium
No. 6001 - 1L and 5L
No. 6002 - 1L, 5L and 10L
No. 6003 - 1L, 5L and 10L
No. 6004 - 1L and 5L
Product numbers refer to colour only.
Add 1 for 1L, 5 for 5L and 10 for 10L.
Acrylic Glazes
Designed to be diluted with water and applied as an overcoat to
a painted surface. They can also be mixed with the paints for
additional binder strength.
Available in: 3.79L
Clear Gloss
Clear Flat
No. 55801
No. 55811
ColorCoat™
Fast drying water borne acrylic enamel. Good choice for decks
and floors due to its high abrasion resistance.
Available in: 0.946L and 3.79L
Clear
Clear Satin
Black
Flat Black
Aluminum
No. 5620
No. 5621
No. 5634
No. 5635
No. 5636
Product numbers refer to colour only.
Add 15 for 0.946L and 17 for 3.79L.
Tough Prime™
Rosco offers a unique
water-based primer with
adhesion properties that
allow it to bond to the
hard-to-prime scenic
materials found in every
scene shop. Tough Prime covers just about any surface,
including PVC pipe, aluminum, foams and concrete floors, as
well as wood and foam core.
Available in: 1L and 5L
Tough Prime White
Tough Prime Black
No. 604005
No. 6055
Product numbers refer to colour only.
Add 17 for 3.79L and 19 for 18.95L.
www.rosco.com
29
Scenic Shop Products
Rosco Fitch Brushes
Fluorescent Paint
Vivid vinyl acrylic colours are brilliant in normal light and glow
brightly when bathed in ultraviolet light. White fluoresces a light
blue under black light. Invisible blue appears milky white under
normal light but glows blue in ultraviolet.
Available in: 0.473L, 0.946L and 3.79L
White
Red
Orange
Yellow
Green
Blue
Invisible Blue
Pink
Gold
No. 5779
No. 5780
No. 5781
No. 5782
No. 5783
No. 5784
No. 5785
No. 5786
No. 5787
Product numbers refer to colour only.
Add 14 for 0.473L, 15 for 0.946L and 17 for 3.79L.
Rosco’s professional quality scenic
fitches, often called lining brushes,
are available individually and in two
handy kits. All brushes feature
seamless ferrules and natural bristles.
⁄4 " Fitch
⁄2 " Fitch
3
⁄4 " Fitch
1" Fitch
11⁄4 " Fitch
11⁄2 " Fitch
2" Fitch
3" Fitch
1
1
No. 661010
No. 661110
No. 661210
No. 661310
No. 661410
No. 661510
No. 661610
No. 661810
7 Brush Set
No. 661710
Includes fitches whose ferrule widths are:
1
⁄4", 1⁄2", 3⁄4", 1", 11⁄4", 11⁄2 and 2"
8 Brush Set
No. 669190
Includes all the brushes in the 7 Brush Kit plus a 3" Fitch Foliage
Vivid FX™
The exceptional pigments in Vivid FX glow most brilliantly
between 365-380 nanometers. This creates stunning black light
effects and the colours intermix cleanly to provide a wide array
of intermediate fluorescent hues.
Available in: 0.473L, 0.946L and 3.79L
Bright White
Lemon Yellow
Orange Sunset
Orange
Scarlet Red
Hot Pink
Magenta
Violet
Deep Blue
Brilliant Blue
Aquamarine
Electric Green
Deep Green
No. 526 250
No. 526 251
No. 526 252
No. 526 253
No. 526 254
No. 526 255
No. 526 256
No. 526 257
No. 526 258
No. 526 259
No. 526 260
No. 526 261
No. 526 262
Product numbers refer to colour only.
Add 14 for 0.473L, 15 for 0.946L and 17 for 3.79L.
Roscoglo™
A phosphorescent water-based paint designed for use in total
darkness for stage direction and visual orientation.
29.57ml
0.473L
No. 5665
No. 56614
www.rosco.com
30
Scenic Shop Products
Premiere Clear
Water-borne urethane coating
suitable for sealing and protecting
painted finishes, floors, and
high-traffic surfaces.
Available in: 0.95L and 3.79L
Premiere Clear Flat
No. 150 068300
Premiere Clear Satin No. 150 068200
Premiere Clear Gloss No. 150 068100
Add 032 for 0.95L and 128 for 3.79L.
CrystalGel™
Rosco CrystalGel is a non-toxic,
water-based material which provides a
clear, plastic-like coating on virtually any
surface used in modern stagecraft.
CrystalGel 3.79L
CrystalGel 18.95L
No. 150 07400 0128
No. 150 07400 0640
Foamcoat™
Water-based, flame retardant,
protective coating for all rigid foams.
Foamcoat dries to a super hard durable
coating that resists chipping
and cracking.
Foamcoat 3.79L
Foamcoat 13.26L
No. 607 10017
No. 607 10021
Flexcoat™
Flexible, non-toxic, water-based coating
for polyurethane and polystyrene foam.
It contains no plasticizers, so it will not
become brittle with age or exterior
exposure.
Flexcoat 3.79L
Flexcoat 18.95L
No. 607 12017
No. 607 12019
Should be used on fabrics like cotton, linen, wool, burlap and
most other materials made of natural fibers. Premixed for use
straight out of the bottle, NF is perfect for treating backdrops,
velours, muslin cycloramas and decorative fabric panels.
Flamex NF 3.79L
No. 150 079NF 0128
Flamex NF 18.95L
No. 150 079NF 0640
Rosco Flamex SF/Synthetic Fiber
Flame Retardant
Effectively treats many synthetic fibers, such as polyesters,
nylons, acrylics and rayons, as well as most cotton/synthetic
blends. Premixed for use straight out of the bottle.
Flamex SF 3.79L
No. 150 079SF 0128
Flamex SF 18.95L
No. 150 079SF 0640
Rosco Flamex DF/Delicate Fabrics
Flame Retardant
Use for synthetic weaves, rayon or silk. Premixed for use straight
out of the bottle, DF maintains the gentleness and soft hand of
fragile fabrics and draperies.
Flamex DF 3.79L
No.150 079DF 0128
Flamex DF 18.95L
No. 150 079DF 0640
Rosco Flamex PC/Paper and
Cardboard Flame Retardant
Effectively treats papers and un-waxed cardboard materials.
Premixed for use straight out of the bottle, PC is perfect for
props and set pieces made from flammable paper products.
Flamex PC 3.79L
No. 150 079PC 0128
Flamex PC 18.95L
No. 150 079PC 0640
Rosco Flamex WD/Raw Wood
Penetrating Flame Retardant
WD is intended for untreated wood, plywood, cellulose board,
acoustical board and corrugated paper.
FlexBond™
Clear, flexible scenic glue which bonds
many porous and non-porous scenic
materials. Rosco FlexBond dries to a
clear, hard, yet pliable coating that does
not suffer from the “tackiness” common
in many other flexible glues.
FlexBond 3.79L
FlexBond 18.95L
Rosco Flamex NF/Natural Fiber
Flame Retardant
No. 607 50017
No. 607 50019
Flamex WD 3.79L
No. 150 079WD 0128
Flamex WD 18.95L
No. 150 079WD 0640
Rosco Flamex PA/Latex Paint
Additive Flame Retardant
PA can be added to most latex or water based paints in order to
create a flame retardant paint film. PA is useful for treating
scenic materials that cannot easily be treated by other methods
and for supplying the additional protection of a fire
retardant paint coating.
Flamex PA 0.24L jar
No. 150 079PA 0008
Flamex PA Case of 12 jars No. 150 079PA 1208
Flamex PA 18.95L
No. 150 079PA 0640
www.rosco.com
31
Scenic Shop Products
TV Paint™
DigiComp™ Materials
Specifically formulated for the sensitive contrast requirements of
standard television systems, this versatile acrylic paint can be
applied to nearly any surface and comes ready to use right out of
the bucket.
TV White – A neutral grey that meets the specifications for 60%
reflectance (maximum brightness intended for transmission).
3.79L
No. 573517
TV Black – A rich, matte black that meets the specifications for
3% reflectance (minimum brightness intended for transmission).
3.79L
No. 574017
DigiComp is Rosco’s trade name for paint and cable precisely
crafted to allow seamless compositing for film, video and digital
use. In the modern compositing or matting process
DigiComp Paint
®
DigiComp Blue
3.79L
No. 5705 0128
18.95L
No. 5705 0640
DigiComp Green
3.79L
No. 5707 0128
18.95L
No. 5707 0640
DigiComp Cable
Keying Paints
Video Paint Ultimatte™
Designed with the Ultimatte® technical staff to meet the
requirements of their keying effects systems.
Ultimatte® Blue 3.79L
Ultimatte® Green 3.79L
Ultimatte® Super Blue 3.79L
No. 57201
No. 57211
No. 57221
Chroma Key™
Specifically formulated to provide high luminance values and
colour saturation for keying effects. The acrylic colours provide
high build, one-coat coverage for use on nearly any surface.
Available in: 3.79L and 18.95L
Chroma Key Blue 3.79L
Chroma Key Blue 18.95L
No. 57101
No. 57105
Chroma Key Green 3.79L
Chroma Key Green 18.95L
No. 57111
No. 57115
CLEARANCE*
2.4 mm (3⁄32") DigiComp cable
1.6 mm (1⁄16") 7x7, coated diameter 2.4 mm (3⁄32")
217 kg (480 lb.) rating, 152 m (500') spool
DigiComp Green Cable
No. 850 57075 0938
DigiComp Blue Cable
No. 850 57055 0938
4.8 mm (3⁄16") DigiComp cable
3.2 mm (1⁄8") 7x19, coated diameter 4.8 mm (3⁄16")
917 kg (2000 lb.) rating, 152 m (500') spool
DigiComp Green Cable
No. 850 57075 1875
DigiComp Blue Cable
No. 850 57055 1875
6.4 mm (1⁄4" ) DigiComp cable
4.8 mm (3⁄16") 7x19, coated diameter 6.4 mm (1⁄4")
4200 lb. (1905 kg) rating, 500' (152 m) spool
DigiComp Green Cable
No. 850 57075 2500
DigiComp Blue Cable
No. 850 57055 2500
www.rosco.com
32
Staging Products for Theatre, Film & Video
Roscopak™
Cinefoil
Cinefoil is a matte black aluminum
material used for masking light leaks
and/or eliminating unwanted
reflections. It can be quickly molded
to form barndoors, flags and other
configurations.
Cinefoil in a box:
Cinefoil 61cm x 7.62m
Cinefoil 30.48cm x 15.24m
Cinefoil 1.22m x 7.62m
No. 360112
No. 360113
No. 360114
Cinefoil in a bag:
Cinefoil 61cm x 7.62m
Cinefoil 30.48cm x 15.24m
No. 101 P1001 2425
No. 101 P1001 1250
Cinefoil is also available in shorter lengths for still
photographers, videographers and students. Called Photofoil it
offers the same light control properties at an economical price.
Matte Black Photofoil, 30.48cm x 3.05m
No. 1010 1001 1210
Matte Black Photofoil, 61cm x 3.05m
No. 1010 1001 2410
Butterflies and Overheads
A number of Cinegel materials are available to fit the standard
butterfly and overhead frames used in motion picture and television production. All materials are supplied edge-finished with
binding and grommets on 61cm (24") centres and sewn hems,
except for No. 3014 Hilite and No. 3029 Silent Frost. The latter
two have an ultrasonic welded seam every 1.22m (48").
Details and more information at:
http://www.roscotex.com
Roscopak material is light in weight, yet strong and durable. The
material can be taped or tacked to virtually any wall, ceiling or
panel to turn that area into an efficient reflector. Roscopak
measures 1.2m x 1.4m (4' x 41⁄2' ), and is packaged in a handy
pocket size pouch.
Roscopak S/G (silver/gold)
No. 35850910
Reflection Media
Used for surfacing reflector boards or wherever reflected light is
required. The product designation generally indicates the
quality of the reflection. Rolls are 122cm x 7.6m (48" x 25').
Roscoflex M (mirror)
No. 3801
Roscoflex H (hard)
No. 3802
Roscoflex S (soft)
No. 3803
Roscoflex SS (supersoft)
No. 3804
Roscoflex G (gold tinted)
No. 3805
Spun Silver
No. 3830
RoscoScrim
(perforated silver/black)
No. 3809
Featherflex S/G
(silver/gold)
No. 3812
Thin Mirror - S (60" x 20')
No. 3813
Thin Mirror - G (60" x 20')
No. 3814
Cinebounce – White/Black
No. 3840
Polarizing Filters
A neutral grey linear polarizing film used in front of lights to
reduce the glare caused by smooth surfaces such as glass, water,
paper and certain metallic objects. Should be placed at a slight
distance from hot lights.
Sheet: 43cm x 51cm
Roll: 43cm x 3.05m
Roll: 43cm x 15.24m
No. 730011
No. 730012
No. 730013
Acrylic Panels
Acrylic sheets for daylight correction or light intensity reduction.
Available in: 1.22m x 2.44m and 1.52m x 2.44m sheets.
Minimum quantity of 5.
Roscolex 85
Roscolex 1⁄2 CTO
Roscolex N.3
Roscolex N.6
Roscolex N.9
No. 3761
No. 3751
No. 3762
No. 3763
No. 3764
TruColor IR Filter
Rosco’s new TruColor IR camera filter restores proper color saturation in situations where the use of heavy neutral density filter
washes out color balance in a composition.
TruColor IR Filter 10.16cm x 10.16cm (4” x 4”)
No. 120 48010 0404
TruColor IR Filter 10.16cm x 14.35cm (4” x 5.65”)
No. 120 48010 4565
TruColor IR Filter 14.35cm x 14.35cm (5.65” x 5.65”)
No. 120 48010 5656
RoscoVIEW™
RoscoView is a unique two-part window control system for film
and television professionals. It consists of wide width polarizing
filter installed on windows and a matching camera polarizing
filter. Rotating the camera filter results in 100% control of
exterior brightness as seen through the window.
P.O.A.
See the demo video at:
http://www.rosco.com/FTVP/roscoview_videos.cfm
RoscoShades™
The RoscoShade system allows television professionals to
quickly and conveniently balance outdoor and studio light when
there is a window in the TV or video picture. Custom filter
shades are made to precisely fit the studio windows, so there is
no light or glare. You can choose the filtration you need and
have it in place in just a few minutes by electronically or
manually lowering or retracting the appropriate material.
Details and a demo video at:
http://www.rosco.com/FTVP/roscoshades.cfm
TruColor IR Filter 15.24cm x 15.24cm (6.6” x 6.6”)
No. 120 48010 6666
www.rosco.com
33
Staging Products for Theatre, Film & Video
Custom Screen
Rosco will fabricate a custom screen to your precise
specifications for size, shape, and finishing details. Standard
pricing includes grommets on 305mm (12") centers, vertical
seams, finished edges and a pipe pocket and skirt. Irregular
shapes can be made but may require additional set-up charges.
Delivery in as little as two weeks. All Rosco screens are
flame-retardant and washable.
2.8m Screen
Chautauqua Theatre Company (July 2007), "The Just" by Albert Camus
Directed by Ethan McSweeny, Lighting Design by Scott Zielinski
Rosco’s projection screens can be used for front or rear
projection, digital or analog imaging, close up or long throw
installations.
Double width continuous rolls of two 55" sections welded
together. Minimum order is two linear yards.
Grey
Twin White
Black
Light Transparent
No. 2105
No. 2106
No. 2107
No. 2108
Colours and recommended uses:
Front White:
Bright white surface for front projection use.
Twin White:
Suitable for front or rear projection, or as a
cyclorama.
Grey:
Recommended for rear projection.
Black:
Recommended for rear projection and high
ambient light situations.
Light Translucent: Virtually clear, suitable for daytime, exterior
rear projections or in exceptionally bright
ambient light conditions.
Spanfix
This versatile fastener is constructed of 5⁄32” (4mm) elastic cord
with a sturdy molded hook . Overall length is 12”.
Spanfix
No. 2100A
1.4m Seamless Screen
1.4m wide. Minimum order is one linear metre.
Grey
Twin White
Black
Light Translucent
No. 2100
No. 2101
No. 2103
No. 2104
2.2m Seamless Screen
Minimum order is one linear metre.
Light Translucent
No. 2113
2.4m Seamless Screen
Minimum order is one linear metre.
Grey
Twin White
Front White
No. 2110
No. 2111
No. 2114
www.rosco.com
34
Staging Products for Theatre, Film & Video
Sure Clamp™
The Sure Clamp has a grip range of
3.18cm to 5cm to and is used to hang
lighting fixtures or scenery directly to
pipes. An extra-secure substitute for the
standard C-Clamp, it closes automatically
when weight is hung on it and is further
secured by a hand knob which requires
no tools for adjustment.
Sure Clamp
No. 850 78020 0000
Flicker Candles™
A theatrical alternative to flame candles, these
units look and act just like the real thing . . .
right down to the dripped wax. Most importantly, they are powered electrically, so they
don’t present potential hazards of using live
flames. A simple 9-volt AC Adaptor allows
you to raise or lower the dimming level on
the Flicker Candles.
Classic Range
This range of flicker candles consists of standard candle units with
the natural flickering flame and can be operated from either
batteries or power supply units.
Flicker Candles™ – continued
Professional Range
This range of Flicker Candles simulates the natural flicker and
have
a small bulb attached to the unit to give the realistic glow of a
flickering candle.
Church Candle - basic unit (40mm diameter translucent
tube)
No. 25429000
Church Candle with 45cm long white stem and flying leads
225mA
No. 25429001
Candle basic unit (20mm diameter tube)
No. 25429004
Candle with 20cm long white stem and flying leads 150mA
No. 25429005
Candle with 20cm long white stem, on/off switch & battery
connector
No. 25429006
Wee-Willie-Winkie saucer with on/off switch & battery
connector
No. 25429003
Three arm candelabra with on/off switch and battery
connector
No. 25429007
Candle - Basic unit (20mm diameter tube)
No. 25428901
Candle with 20cm long white stem and flying leads 90mA
No. 25428902
Hand held candle with 20cm long white stem, on/off switch and
battery connector
No. 25428903
Converted storm/hurricane lantern with on/off switch and battery
connector
No. 25428913
Converted storm/hurricane lantern with flying leads 90mA
No. 25428914
Classic single candlestick with flying leads 90mA
No. 25429002
Power Supplies
Some candles may be operated from either batteries or mains
DC PSU but must be loaded according to the recommendations
Mains power supply for 1 Classic Candle 90mA to 100mA
No. 25429010
Mains power supply for 3 Classic Candles or 1 Professional
200mA to 300mA
No. 25429020
Mains power supply for 25 Clasic or 10 Professional Candles
1A to 3A
No. 25429030
Classic three arm candelabra with on/off switch and battery
connector
No. 25428904
Candle in a bottle with on/off switch and battery connector
No. 25428905
www.rosco.com
35
Staging Products for Theatre, Film & Video
GaffTac™ 48mm (2”) Gaffer Tape
Manufactured using a premium quality polyethylene coated cloth
laminate with a natural rubber-based adhesive. This unique
adhesive offers high tack with excellent adhesion yet still removes
cleaning without leaving behind any sticky residue. It’s also easily
tearable, which means no need for cutting tools. The fine mesh
weave of the cloth laminate base is resistant to edge fraying and
offers a smooth, matte surface with minimal sheen – perfect for
remaining “invisible” on set, in the grid or in frame.
GaffTac™ 12mm (1⁄2”) Spike Tape
Manufactured using a premium quality polyethylene coated cloth
laminate with a natural rubber-based adhesive. This unique
adhesive offers high tack with excellent adhesion yet still removes
cleanly without leaving behind any sticky residue. It’s also easily
tearable, which means no need for cutting tools. The fine mesh
weave of the cloth laminate base is resistant to edge fraying and
offers a smooth, matte surface with minimal sheen.
Rolls measure 12mm x 25m (1/2" x 27 yds.)
Rolls measure 48mm x 50m (2" x 55 yds.)
Black
Black (Case of 24)
No. 851 12221 4850
No. 851 12221 0BOX
White
White (Case of 24)
No. 851 12222 4850
No. 851 12222 0BOX
Grey
Grey (Case of 24)
No. 851 12223 4850
No. 851 12223 0BOX
GaffTac™ 24mm (1”) Marking Tape
Made on a traditional cottom cloth and vinyl coated fabric base and
uses a synthetic rubber blend adhesive. This combination provides
high tack with excellent adhesion yet still removes cleanly without
leaving behind a sticky residue. It’s also easily tearable, which means
no need for cutting tools. The textured weave of cotton fabric helps
insure a non-reflective, matter surface, making it perfect for taping
down various set and lighting components, as well as maintaining
clean, legible written text.
Rolls measure 24mm x 25m (1" x 27 yds.)
Black
Black (Case of 24)
No. 851 12221 2425
No. 851 12221 1BOX
White
White (Case of 24)
No. 851 12222 2425
No. 851 12222 1BOX
Red
Red (Case of 96)
No. 851 15210 1225
No. 851 15210 0BOX
Yellow
Yellow (Case of 96)
No. 851 15220 1225
No. 851 15220 0BOX
Blue
Blue (Case of 96)
No. 851 15230 1225
No. 851 15230 0BOX
Fluorescent Green
Fluorescent Green (Case of 96)
No. 851 15240 1225
No. 851 15240 0BOX
White
White (Case of 96)
No. 851 15250 1225
No. 851 15250 0BOX
GaffTac™ 48mm (2”) Keying Tape
Made on a traditional cottom cloth and vinyl coated fabric base and
uses a synthetic rubber blend adhesive. This combination provides
high tack with excellent adhesion yet still removes cleanly without
leaving behind a sticky residue. It’s also easily tearable, which means
no need for cutting tools. The textured weave of cotton fabric helps
insure limited reflections or glare that might spoil the keying shot.
Rolls measure 48mm x 50m (2" x 55 yds.)
12mm x 25m (1/2” x 27 yds.)
Flourescent Green 2” (48mm)
Flourescent Green 2” (48mm)
(Case of 24)
Flourescent Green 1/2” (12mm)
Flourescent Green 1/2” (12mm)
(Case of 24)
No. 851 12224 4850
No. 851 12224 0BOX
No. 851 15240 1225
No. 851 15240 0BOX
Glow Tape
Glow-in-the-dark tape ideal for marking low light areas. It glows to a
yellow-green colour that can remain illuminated for hours. 24mm
wide.
5m roll (16.35 ft.)
10m roll (32.7 ft.)
30m roll (98.4 ft.)
No. 500005
No. 500010
No. 500015
www.rosco.com
36
Staging Products for Theatre, Film & Video
Slit Drape
Glamé™
This Rosco version of slash
curtain consists of
overlapping 0.31cm strips of
durable, flame retardant
vinyl, 91.44cm wide (36").
Solid Black
Solid Silver
Solid Gold
Black/Silver
Black/Gold
Black/Diffraction
White/Diffraction
Silver/Diffraction
Iridescent
Silver/Iridescent/Gold
Silver/Gold/Diffraction
2.4m
4.9m
7.3m
2.4m
4.9m
7.3m
2.4m
4.9m
7.3m
2.4m
4.9m
7.3m
2.4m
4.9m
7.3m
2.4m
4.9m
7.3m
2.4m
4.9m
7.3m
2.4m
4.9m
7.3m
2.4m
4.9m
7.3m
2.4m
4.9m
7.3m
2.4m
4.9m
7.3m
Glamé is woven from a
durable, lightweight,
self-extinguishing plastic film.
Roll: 1.22m x 9.15m
Bolt: 1.22m x 100m bolts
No. 261013
No. 262015
No. 262117
No. 260913
No. 261615
No. 261517
No. 262513
No. 262615
No. 262717
No. 260813
No. 261715
No. 261817
No. 260213
No. 260515
No. 261317
No. 260013
No. 260315
No. 261117
No. 260613
No. 260715
No. 261217
No. 260113
No. 260415
No. 261417
No. 263013
No. 263015
No. 263017
No. 263413
No. 263415
No. 263417
No. 263413
No. 263415
No. 263617
Showcloth™
A weave of thread and self extinguishing plastic strips produces
an elegant, shimmering fabric with a soft hand and beautiful
drape. Showcloth has a selvedge edge for easy sewing.
No. 2006
No. 2009
No. 2012
No. 2013
No. 2014
No. 2032
No. 2033
No. 2034
No. 2035
No. 2041
No. 2045
No. 2052
No. 2053
No. 2054
Add 16 to product number for 9.15m roll.
Add 19 to product number for 100m bolt.
Shimmer Scrim™
Shimmer Scrim is a combination of thread and plastic film
woven into a theatrical fabric. This self-extinguishing fabric may
be used for traditional scrim effects or as a shimmering, airy
drape. It has a selvedge edge for easy sewing.
Roll: 1.22m x 9.15m
Bolt: 1.22m x 100m
White/Iridescent/Gold
White/Clear/Iridescent
White/Iridescent/White
Black/Clear/Silver
Black/Clear/Iridescent
Black/Clear/Black
Black/Gold/Clear
No. 2051
No. 2056
No. 2055
No. 2057
No. 2005
No. 2059
No. 2061
Add 16 to product number for 9.15m roll.
Add 19 to product number for 100m bolt.
Glitter CLEARANCE*
RoscoGlitter, in 1⁄64" hexagonal chips, is uniquely suited for
production applications. The chips are brilliant under stage
lights and can be sprinkled on or mixed directly into Clear Gloss
or Flat Acrylic for easy application.
Available in 114g and 0.45kgs.
Roll: 1.22m x 9.15m
Bolt: 1.22m x 100m
White/Gold
Black/Gold
White/Silver
White/Iridescent
Black/Silver
Black/Black
Black/Iridescent
Silver
Gold
Silver/Black
Gold/Black
Gold/Silver
Silver/Diffraction
Gold/Diffraction
Clear/Diffraction
Iridescent/Diffraction
Razzle Dazzle
Black
Black/Iridescent
Silver/Iridescent
Gold/Iridescent
No. 202 41210 11
No. 202 41210 21
No. 202 41210 31
No. 202 41210 41
No. 202 41210 51
No. 202 41210 61
No. 202 41210 71
Add 6 to product number for 9.15m roll.
Add 9 to product number for 100m bolt.
Silver
Gold
Red
Sky Blue
Royal Blue
Green
Fuchsia
No. 402890
No. 402891
No. 402893
No. 402894
No. 402895
No. 402897
No. 402898
Add 11 to product number for 114g.
Add 12 to product number for 0.45kgs.
www.rosco.com
37
Staging Products for Theatre, Film & Video
Breakaways
Plastic breakaways shatter
realistically and are specially
packaged to assure that they are
delivered intact. Bottles are shipped
with labels unattached for easy
customization. Minimum order: 6
breakaways. (Bottles must be the
same colour.)
Pint Curvy Glass
Brown Beer Bottle
Budweiser Bottle
Budweiser Bottle - Green
Milk Bottle
Straight Pint Glass
Decanter
Whiskey Glass
Whiskey Cut Glass
Cola Bottle
Teachers Whiskey Bottle
Whiskey Bottle - Clear
Water Glass
Highball Glass
Wine Paris Goblet
Champagne Flute
Undressed Champagne Bottle
Green Gin Bottle
Green Wine Bottle
Metalix™
No. 80001
No. 80009
No. 80010
No. 80011
No. 80012
No. 80013
No. 80015
No. 80016
No. 80017
No. 80021
No. 80031
No. 80051
No. 80061
No. 80062
No. 80071
No. 80081
No. 80091
No. 800101G
No. 80051G
Mirrors
A variety of reflective surfaces in a metalized plastic format.
Flexible Silver (1.22m x 9.15m)
Thin Silver (1.52m x 9.15m)
Thin Gold (1.40m x 9.15m)
Rigid Gold (1.35m x 9.15m)
Rigid Silver (1.35m x 9.15m)
No. 390602
No. 392502
No. 392702
No. 393002
No. 393102
Shrink Mirror™
Rosco’s Silver Shrink Mirror is a
lightweight substitute for heavy glass
mirror. This metalized plastic laminate
is designed to be mounted to a frame
and heat shrunk for superior
reflectance. 1.37m x 9.15m
Silver Shrink Mirror
Smooths™
No. 3909
CLEARANCE*
This durable metalized plastic material is available in a variety of
colours and surfaces.
Metalix 1.22m x 9.15m roll
Silver Pebble
Soft Silver
Gold Pebble
Diffractions™
No. 390202
No. 397102
No. 397202
CLEARANCE*
Five laser etched plastic films for prismatic effects. All the
diffractions are adhesive backed.
Diffractions 61cm x 4.6m rolls
Exotic Circles
1
⁄4 " Mosaic
Horizontal Stripes
Sparklene™
No. 295622
No. 296022
No. 296222
CLEARANCE*
Eleven glitter laminate plastic film colours. Sparklene is pressure
sensitive for easy mounting.
Roll: 61cm x 4.6m
Bolt: 61cm x 100m
Blue
Red
Green
Fuchsia
Gold
Fluorescent Pink
Blue/Green Iridescent
Orange
Bronze
Rolls
No. 399122
Not available
Not available
No. 399422
No. 399522
Not available
Not available
Not available
Not available
Bolts
No. 399122001
No. 399222001
No. 399322001
No. 399422001
Not available
No. 396122001
No. 396422001
No. 396522001
No. 396722001
CLEARANCE*
The smooth colours are pressure-sensitive for easy mounting.
61cm x 9.2m (24" x 30' rolls).
Bright Orange
Gun Metal Grey
Silver
Pink Fizz
Light Gold
Smooth Iridescent
No. 397422
No. 397522
No. 398122
No. 398322
No. 398522
No. 398622
www.rosco.com
38
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
