Ask Proxima 9280 Projector User Manual

®
E
IV
AT
NT
TE
Desktop Projector 9280
■ PRESENTATIONS
■ WORKING SESSIONS
■ TRAINING
■ MULTIMEDIA
■ ANIMATION
■ VIDEO
TO THE OWNER
Before operating this projector, read this manual thoroughly and operate the projector properly.
This projector provides many convenient features and functions. Operating the projector properly enables you to
manage those features and maintains it in better condition for a considerable time.
Improper operation may result in not only shortening the product-life, but also malfunctions, fire hazard, or other
accidents.
If your projector seems to operate improperly, read this manual again, check operations and cable connections and try
the solutions in the “Trouble-shooting” section of the end of this booklet. If the problem still persists, contact the sales
dealer where you purchased the projector or the service center.
SAFETY PRECAUTIONS
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
● This projector produces intense light from the projection lens. Do not stare directly into the lens as possible.
Eye damage could result. Be especially careful that children do not stare directly into the beam.
● This projector should be set in the way indicated. If not, it may result in a fire hazard.
● Take appropriate space on the top, sides and rear of the projector
cabinet for allowing air circulation and cooling the projector.
Minimum distance should be taken. If the projector is to be built
into a compartment or similarly enclosed, the minimum distances
must be maintained. Do not cover the ventilation slot on the
projector. Heat build-up can reduce the service life of your
projector, and can also be dangerous.
SIDE and TOP
REAR
20cm
50cm
50cm
50cm
● Do not put any flammable object or spray can near the projector, hot air is exhausted from the ventilation
holes.
● The Remote Control Unit, supplied to this projector, emits the laser beam as the Laser Pointer function from
the Laser Light Window while pressing the LASER button (for 1 minute). Do not look into the Laser Light
Window or shine the laser beam on yourself or other people. Eye damage may result.
● If the projector is not to be used for an extended time, unplug the projector from the power outlet.
READ AND KEEP THIS OWNER'S MANUAL FOR LATER USE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION :
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE EXCEPT LAMP REPLACEMENT. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THIS SYMBOL INDICATES THAT DANGEROUS
VOLTAGE CONSTITUTING A RISK OF ELECTRIC
SHOCK IS PRESENT WITHIN THIS UNIT.
2
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT
OPERATING AND MAINTENANCE INSTRUCTIONS IN THE
OWNER'S MANUAL WITH THIS UNIT.
SAFETY INSTRUCTIONS
All the safety and operating instructions should be read before
the product is operated.
Read all of the instructions given here and retain them for later
use. Unplug this projector from AC power supply before
cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
This projector should be operated only from the type of power
source indicated on the marking label. If you are not sure of
the type of power supplied, consult your authorized dealer or
local power company.
Follow all warnings and instructions marked on the projector.
Do not overload wall outlets and extension cords as this can
result in fire or electric shock. Do not allow anything to rest on
the power cord. Do not locate this projector where the cord
may be damaged by persons walking on it.
For added protection to the projector during a lightning storm,
or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet. This will prevent damage
due to lightning and power line surges.
Do not attempt to service this projector yourself as opening or
removing covers may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified service
personnel.
Do not expose this unit to rain or use near water... for
example, in a wet basement, near a swimming pool, etc...
Do not use attachments not recommended by the
manufacturer as they may cause hazards.
Do not place this projector on an unstable cart, stand, or table.
The projector may fall, causing serious injury to a child or
adult, and serious damage to the projector. Use only with a
cart or stand recommended by the manufacturer, or sold with
the projector. Wall or shelf mounting should follow the
manufacturer's instructions, and should use a mounting kit
approved by the manufacturers.
An appliance and cart combination should
be moved with care. Quick stops,
excessive force, and uneven surfaces
may cause the appliance and cart
combination to overturn.
Slots and openings in the back and bottom of the cabinet are
provided for ventilation, to insure reliable operation of the
equipment and to protect it from overheating.
Unplug this projector from wall outlet and refer servicing to
qualified service personnel under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the projector.
c. If the projector has been exposed to rain or water.
d. If the projector does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions as improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the projector to normal operation.
e. If the projector has been dropped or the cabinet has been
damaged.
f. When the projector exhibits a distinct change in
performance-this indicates a need for service.
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer that have the same characteristics as the
original part. Unauthorized substitutions may result in fire,
electric shock, or injury to persons.
Upon completion of any service or repairs to this projector, ask
the service technician to perform routine safety checks to
determine that the projector is in safe operating condition.
The openings should never be covered with cloth or other
materials, and the bottom opening should not be blocked by
placing the projector on a bed, sofa, rug, or other similar
surface. This projector should never be placed near or over a
radiator or heat register.
This projector should not be placed in a built-in installation
such as a book case unless proper ventilation is provided.
Never push objects of any kind into this projector through
cabinet slots as they may touch dangerous voltage points or
short out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the projector.
Voor de klanten in Nederland
Bij dit product zijn batterijen
geleverd.
Wanneer deze leeg zijn,
moet u ze niet weggooien
maar inleveren als KCA.
3
COMPLIANCES
Federal Communication Commission Notice
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part
15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
AC POWER CORD REQUIREMENT
The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it.
AC Power Cord for the United States and Canada :
AC Power Cord used in the United States and Canada is listed by the Underwriters
Laboratories (UL) and certified by the Canadian Standard Association (CSA).
AC Power Cord has a grounding-type AC line plug. This is a safety feature to be sure
that the plug will fit into the power outlet. Do not try to defeat this safety feature.
Should you be unable to insert the plug into the outlet, contact your electrician.
GROUND
THE SOCKET-OUTLET SHOULD BE INSTALLED NEAR THE EQUIPMENT AND EASILY ACCESSIBLE.
4
TABLE OF CONTENTS
FEATURES AND DESIGN
PREPARATION
NAME OF EACH PART OF THE PROJECTOR
SETTING-UP THE PROJECTOR
CONNECTING THE AC POWER CORD
POSITIONING THE PROJECTOR
ADJUSTABLE FEET
MOVING THE PROJECTOR
CONNECTING THE PROJECTOR
TERMINALS OF THE PROJECTOR
CONNECTING TO THE VIDEO EQUIPMENT
CONNECTING TO THE COMPUTER
6
7
7
8
8
9
10
10
11
11
13
14
COMPUTER MODE
SELECTING COMPUTER MODE
SELECTING COMPUTER SYSTEM
COMPATIBLE COMPUTER SPECIFICATIONS
PC ADJUSTMENT
PICTURE IMAGE ADJUSTMENT
NORMAL FUNCTION
AUTO IMAGE FUNCTION
PICTURE POSITION ADJUSTMENT
PICTURE SCREEN ADJUSTMENT
VIDEO MODE
SELECTING VIDEO MODE
SELECTING VIDEO SOURCE
VIDEO SIGNAL FROM VIDEO OR S-VIDEO JACK
VIDEO SIGNAL FROM Y, Pb/Cb, Pr/Cr JACKS
SELECTING COLOR SYSTEM
PICTURE IMAGE ADJUSTMENT
BEFORE OPERATION
15
TOP CONTROLS AND INDICATORS
OPERATION OF THE REMOTE CONTROL
15
16
OPERATING RANGE
REMOTE CONTROL BATTERIES INSTALLATION
16
17
OPERATING ON-SCREEN MENU
HOW TO OPERATE THE ON-SCREEN MENU
FLOW OF ON-SCREEN MENU
MENU BAR
18
18
18
19
NORMAL FUNCTION
PICTURE SCREEN ADJUSTMENT
SETTING
SETTING MENU
SETTING LANGUAGE
APPENDIX
BASIC OPERATION
TURNING ON / OFF THE PROJECTOR
ADJUSTING THE IMAGE
ZOOM ADJUSTMENT
FOCUS ADJUSTMENT
LENS SHIFT ADJUSTMENT
KEY STONE ADJUSTMENT
NO SHOW FUNCTION
PICTURE FREEZE FUNCTION
P-TIMER FUNCTION
20
20
21
21
21
21
22
22
22
22
SOUND ADJUSTMENT
23
DIRECT OPERATION
MENU OPERATION
23
23
OPERATING WIRELESS MOUSE
MAINTENANCE
TEMPERATURE WARNING INDICATOR
AIR FILTER CARE AND CLEANING
LAMP REPLACEMENT
LAMP REPLACEMENT MONITOR TIMER
CLEANING THE PROJECTION LENS
TROUBLESHOOTING
TECHNICAL SPECIFICATIONS
24
24
24
25
26
28
29
29
30
31
32
32
32
32
32
33
34
35
35
36
36
37
38
38
39
39
39
40
40
41
42
44
TRADEMARKS
● Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple Computer,Inc.
● IBM and PS/2 are trademarks or registered trademarks of International Business Machines, Inc.
● Windows and PowerPoint are registered trademarks of Microsoft Corporation.
● Each name of corporations or products in the owner's manual is a trademark or a registered trademark of its
respective corporation.
5
FEATURES AND DESIGN
This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of
use. The projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal
display (LCD) technology.
◆
Compatibility
This projector widely accepts various video and
computer input signals including;
● Computers
IBM-compatible and Macintosh computers up to
1280 x 1024 resolution.
● 6 Color Systems
NTSC, PAL, SECAM, NTSC 4.43, PAL-M or PALN color system can be connected.
● Component Video
Component video signals, such as a DVD player
output high definition TV signals including 480i,
480p, 575i, 575p, 720p, 1035i, 1080i-50 or 1080i60, can be connected.
● S-Video
S-Video signals, such as a S-VHS VCR output
signals, can be connected.
◆
High Resolution Image
This projector provides 1024 x 768 dots resolution for
computer input and 700 horizontal TV lines. The
resolution from the computer between XGA (1024 x 768)
and SXGA (1280 x 1024) is compressed into 1024 x 768
dots. This projector cannot display image of over 1280 x
1024 dots. When the resolution of your computer is over
than 1280 x 1024, reset the computer output for lower
resolution.
◆
Multi-Scan System
This projector has Multi-Scan System to conform to
almost all computer output signals quickly. There is no
need for troublesome manual adjustment of frequency
and other settings.
◆
One-Touch Auto Imaging
Incoming computer video signals are recognized and the
best setting is automatically selected by the Auto Image
function. No complicated setup is necessary and
projection is always precise.
◆
Progressive Scan Function
This function converts interlace video signals into
progressive scan signals and provide fine picture quality.
◆
Multilanguage Menu Display
Operation menu is displayed in; English, Deutsch,
Français, Italiano, Español, or Japanese.
6
◆
Digital Zoom (Computer Mode only)
The Digital Zoom magnifies the image up to 49 times,
allowing you to focus on crucial information at a
presentation.
◆
Motor-driven Lens Shift
The projection lens can be moved up and down with the
motor-driven lens shift function. This function makes it
easy to provide the projected image where you want.
The zoom and focus can be also adjusted with motordriven operation.
◆
Keystone Correction
Positioning height of the projector may result in distorted
images being displayed in a trapezoid shape. Keystone
Correction solves this problem by digitally altering the
projection to produce undistorted images.
◆
Power Management
Power Management function is provided to reduce power
consumption while the projector is not in use.
This Power Management function operates to turn the
Projection Lamp off when the projector detects signal
interruption and any button is not pressed over 5
minutes. The Projection Lamp is automatically turned on
again when the projector detects the signal or any
operation button is pressed.
This projector is shipped with this function ON.
◆
Digital Visual Interface
This projector is equipped with the DVI 24-pin terminal
for connecting DVI output of the computer.
◆
Laser Pointer Function
The Remote Control Unit supplied with this projector
includes the Laser Pointer function. This function helps
you to make a smart presentation on a projected screen.
◆
Wireless Mouse
The Remote Control Unit supplied with this projector has
Wireless Mouse function for the connected computer.
This function enables you to operate both projector and
computer with this Remote Control Unit only.
PREPARATION
NAME OF EACH PART OF THE PROJECTOR
FRONT OF THE CABINET
TOP CONTROLS
AND INDICATORS
PROJECTION LENS
LENS COVER
SPEAKERS
INFRARED
REMOTE RECEIVERS
BACK OF THE CABINET
EXHAUST VENT
HOT AIR EXHAUSTED !
Air blown from the exhaust vent is hot.
When using or installing the projector, the
following precautions should be taken.
● Do not put a flammable object near this vent.
● Keep the rear grills at least 3’(1m) away from
any object, especially heat-sensitive object.
● Do not touch this area, especially screws
and metallic parts. This area will become
hot while the projector is used.
This projector detects the internal
temperature and automatically controls the
operating power of the Cooling Fans.
POWER CORD CONNECTOR
TERMINALS
AND CONNECTORS
MAIN ON / OFF SWITCH
BOTTOM OF THE CABINET
AIR INTAKE VENTS
(Side and Bottom)
This projector is equipped with cooling
fans for protection from overheating.
Pay attention to the following to ensure
proper ventilation and avoid a possible
risk of fire and malfunction.
● Do not cover the vent slots.
● Keep bottom clear of any objects.
Obstructions may block cooling air.
ADJUSTABLE FEET
AND
FEET LOCK LATCHES
LAMP COVER
7
PREPARATION
SETTING-UP THE PROJECTOR
CONNECTING THE AC POWER CORD
This projector uses nominal input voltages of 100-120 V
or 200-240 V AC. The projector automatically selects the
correct input voltage. It is designed to work with singlephase power systems having a grounded neutral
conductor. To reduce the risk of electrical shock, do not
plug into any other type of power system.
Consult your authorized dealer or service station if you
are not sure of the type of power supply being in use.
Connect the projector with the peripheral equipment
before turning the projector on. (Refer to pages 11 ~ 14
for connection.)
CAUTION
Connect the AC Power Cord (supplied)
to the projector.
The AC outlet must be near this
equipment and must be easily
accessible.
For safety, unplug the AC Power Cord when the appliance is not used.
When this projector is connected to the outlet with the
AC Power Cord, the appliance is in Stand-by Mode
and consumes a little electric power.
NOTE ON THE POWER CORD
The AC Power Cord must meet the requirement of the country where you use the projector.
Confirm the AC plug type with the chart below. The proper AC power cord must be used.
If the supplied AC Power Cord does not match the AC outlet, contact your sales dealer.
Projector side
AC Outlet side
For the U.S.A. and Canada
For Continental Europe
Ground
To the POWER CORD
CONNECTOR on the
projector.
8
To the AC Outlet.
(120 V AC)
To the AC Outlet.
(200 - 240 V AC)
PREPARATION
POSITIONING THE PROJECTOR
● This projector is designed to project on a flat
projection surface.
● The projector can be focused from 4.6’ (1.4m) ~ 47.3’
(14.4m).
● Refer to the figure below to adjust the screen size.
ROOM LIGHT
The brightness in the room has a great
influence on the picture quality. It is
recommended to limit ambient lighting in
order to provide the best image.
47.3’ (14.4m)
35.4’ (10.8m)
23.6’ (7.2m)
200”
100”
40”
400”
300”
11.8’ (3.6m)
4.6’ (1.4m)
Max. Zoom
308”
231”
Min. Zoom
154”
77”
31”
Screen
Size
Max. Zoom
40”
100”
150”
200”
250”
300”
400”
Min. Zoom
31”
77”
115”
154”
192”
231”
308”
4.6’ (1.4m)
11.8’ (3.6m)
17.7’ (5.4m)
23.6’ (7.2m)
29.5’ (9.0m)
35.4’ (10.8m)
47.3’ (14.4m)
Distance
LENS SHIFT ADJUSTMENT
The projection lens can be moved up and down with the motor-driven lens shift function. This function makes it
easy to provide the projected image where you want. The U/D ratio can be adjusted 10 : 0 ~ 1 : 3 (refer to the
figure below.). Refer to P 21 for operation.
Highest (10 : 0)
Lowest (1 : 3)
10 : 0
1
3
9
PREPARATION
ADJUSTABLE FEET
Picture tilt and projection angle can be adjusted by
rotating the ADJUSTABLE FEET. Projection angle can
be adjusted to 9.0 degrees.
1
Lift the front of the projector and pull the FEET LOCK
LATCHES on both sides of the projector.
2
Release the FEET LOCK LATCHES to lock the
ADJUSTABLE FEET and rotate the ADJUSTABLE FEET
to fine tune the position and the tilt.
3
To shorten the ADJUSTABLE FEET, lift the front of the
projector and pull and undo the FEET LOCK LATCHES.
The position and the keystone distortion of the image can
be adjusted using the Menu Operation. (Refer to P 22,
31 and 35.)
FEET LOCK
LATCHES
ADJUSTABLE FEET
MOVING THE PROJECTOR
Use the Carry Handle when moving the Projector.
When moving the projector, replace the lens cover and
retract the feet to prevent damage to the lens and
cabinet.
When this projector is not in use for an extended period,
put it into the case (dust cover) supplied with this
projector.
CAUTION IN CARRYING OR TRANSPORTING THE PROJECTOR
● Do not drop or bump the projector, otherwise damages or malfunctions may result.
● When carrying the projector, use a suitable carrying case.
● Do not transport the projector by using a courier or transport service in an unsuitable transport case. This
may cause damage to the projector. To transport the projector through a courier or transport service,
consult your dealer for best way.
10
CONNECTING THE PROJECTOR
TERMINALS OF THE PROJECTOR
This projector has INPUT TERMINALS and OUTPUT TERMINALS on its side for connecting computers and
video equipment. Refer to the figure on pages 11 to 14 and connect properly.
PC IN-1
analog
INPUT TERMINALS
digital
PC control 1
audio 1
AV IN
R–audio–L
(stereo)
PC IN-2
R
G
B
H
V
PC control 2
monitor OUT
R
G
B
H
V
reset
audio 2
S-video
(mono)
Y/video– Cb/Pb– Cr/Pr
(stereo)
R/C jack
R–audio–L
video
OUTPUT TERMINALS
INPUT TERMINALS
COMPUTER INPUT-1
TERMINALS (DIGITAL/ANALOG)
Connect the computer output
to one of these terminals.
(Refer to P14.)
CONTROL PORT (1/2) CONNECTORS
AUDIO INPUT JACKS
S-VIDEO INPUT JACK
When controlling the computer
with the Remote Control of
this projector, connect the
mouse port of your personal
computer to these terminals.
(Refer to P14.)
Connect the audio output
from the video equipment
to these jacks.
(Refer to P13.)
Connect the S-VIDEO
output from the video
equipment to this jack.
(Refer to P13.)
PC IN-1
analog
digital
PC control 1
audio 1
(stereo)
PC IN-2
R
G
B
H
V
PC control 2
audio 2
AV IN
R–audio–L
S-video
(mono)
Y/video– Cb/Pb– Cr/Pr
(stereo)
monitor OUT
COMPUTER INPUT-2
TERMINALS (BNC x 5)
Connect the computer output to
these terminals. (Refer to P14.)
COMPUTER AUDIO INPUT (1/2) JACKS
Connect the audio output (stereo)
from the computer to these jacks.
(Refer to P14.)
VIDEO INPUT JACKS
(Y/VIDEO, Pb/Cb, Pr/Cr)
Connect the composite video output from the
video equipment to the VIDEO/Y jack or
connect the component video outputs to the
Y/VIDEO, Pb/Cb and Pr/Cr jacks.
(Refer to P13.)
11
CONNECTING THE PROJECTOR
OUTPUT TERMINALS
RESET BUTTON
R/C JACK
This projector uses a micro processor to control the
unit. Occasionally, the micro processor may
malfunction and need to be reset. This can be done
by pressing the RESET button with a pen, which will
shut down and restart the unit. Do not use the
RESET function excessively.
monitor OUT
R
G
COMPUTER MONITOR OUTPUT
JACKS (BNC x 5)
These jacks output the signal from
the COMPUTER INPUT terminals
(except the digital input signal).
Connect an external monitor to
these jacks. (Refer to P14.)
12
B
H
V
reset
When using the Wired / Wireless
Remote Control Unit as the Wired
Remote Control, Connect the Wired
Remote Control Unit to this jack with
the Remote Control Cable (supplied).
(Refer to page 21.)
R/C jack
AUDIO OUTPUT JACKS
Connect an external audio
amplifier to these jacks.
(Refer to P13, 14.)
R–audio–L
video
VIDEO MONITOR OUTPUT JACK
This terminal outputs the composite video
signal or the signal from the S-VIDEO
INPUT JACK. Connect an external
monitor to this jack. (Refer to P13.)
CONNECTING THE PROJECTOR
CONNECTING TO THE VIDEO EQUIPMENT
Cables used for connection (✽ = Cables are not supplied with this projector.)
• Video Cable (RCA x 1✽ or RCA x 3)
• S-VIDEO Cable
• Audio Cable (RCA x 2 - Mini Plug (stereo))
• Audio Cable (RCA x 2) ✽
NOTE :
When connecting the cable, the power cords of
both the projector and the external equipment
should be disconnected from AC outlet. Turn the
projector and peripheral equipment on before the
computer is switched on.
Component video output equipment.
Video Source (example)
Video Cassette Recorder
Composite
Video Output
Use any of VIDEO jack Y-Pb/CbPr/Cr jacks or S-VIDEO jack.
• When both VIDEO jack and SVIDEO jack are connected, the SVIDEO jack has priority over the
VIDEO jack.
• When both Y-Pb/Cb-Pr/Cr jacks
and S-VIDEO jack are connected,
the Y-Pb/Cb-Pr/Cr jacks has
priority over the S-VIDEO jack.
Video Disc Player
Component Video Output
S-VIDEO Output
Audio Output
Y Pb/Cb Pr/Cr
Video Cable
(RCA x 1) ✽
R
Video Cable
(RCA x 3)
S-VIDEO
Cable
L
Audio Cable
(Stereo) ✽
S-VIDEO
VIDEO
digital
PC control 1
audio 1
(stereo)
PC IN-2
R
G
AV AUDIO IN
Y-Pb/Cb-Pr/Cr
PC IN-1
analog
Terminals
of the Projector
(such as DVD player or
high-definition TV source.)
B
H
V
PC control 2
audio 2
AV IN
R–audio–L
S-video
(mono)
Y/video– Cb/Pb– Cr/Pr
(stereo)
monitor OUT
R
G
B
H
V
reset
R/C jack
R–audio–L
video
MONITOR OUT
AUDIO OUT
Audio Cable
(Stereo)
Audio Input
Monitor Input
External Audio Equipment
Audio Amplifier
Video Cable ✽
External Monitor
Audio Speaker (stereo)
13
CONNECTING THE PROJECTOR
CONNECTING TO THE COMPUTER
Cables used for connection (✽ = Cables are not supplied with this projector.)
• VGA CABLE (HDB 15 pin)
• CONTROL CABLE FOR PS/2 PORT, SERIAL PORT, or ADB PORT
• MAC ADAPTER
• DVI CABLE (24 pin) ✽
• BNC CABLE (BNC x 5) ✽
• AUDIO CABLE (RCA X 2 - Mini Plug (stereo))
• AUDIO CABLE (Mini Plug (stereo)) ✽
NOTE :
When connecting the cable, the power cords of
both the projector and the external equipment
should be disconnected from AC outlet. Turn the
projector and peripheral equipment on before the
computer is switched on.
IBM-compatible computers or Macintosh computers (VGA / SVGA / XGA / SXGA)
Desktop type
Monitor Output
Laptop type
Monitor Output Serial port
Monitor Output
MAC Adapter
Set the slide
switches following the chart
below.
ADB port
Audio Output
Control Cable Control Cable Control Cable
for Serial Port for PS/2 Port for ADB Port
Terminal
Terminal
Audio Cable
(stereo) ✽
Terminal
VGA Cable
BNC Cable ✽
Use either VGA
Cable or DVI Cable
corresponding with
your computer.
COMPUTER IN 2
PS/2 port
COMPUTER IN 1
COMPUTER IN 1
PC IN-1
analog
Use one of these Control
Cables corresponding
with the terminal of your
computer.
DVI Cable ✽
digital
PC control 1
CONTROL PORT 1 or 2
audio 1
(stereo)
PC IN-2
R
Use any of COMPUTER
INPUT jacks.
• When both ANALOG jack
and DIGITAL jack are
connected, the DIGITAL
jack has priority over the
ANALOG jack.
G
B
H
V
PC control 2
audio 2
AV IN
R–audio–L
COMPUTER
AUDIO IN 1 or 2
S-video
(mono)
Y/video– Cb/Pb– Cr/Pr
(stereo)
monitor OUT
R
G
B
H
V
reset
MONITOR OUT
R/C jack
R–audio–L
video
AUDIO OUT
Terminals of the Projector
BNC Cable ✽
Monitor Input
External Monitor
Audio Cable
(stereo)
Audio Input
External Audio Equipment
Audio Amplifier
14
Audio Speaker
(stereo)
BEFORE OPERATION
TOP CONTROLS AND INDICATORS
INDICATORS
LAMP REPLACE INDICATOR
WARNING TEMP. INDICATOR
READY INDICATOR
LAMP INDICATOR
This indicator turns to
yellow when the life of the
projection lamp draws to an
end. (P40)
This indicator flashes red
when internal projector
temperature is too high.
(P39)
This indicator lights green
when the projector is ready
to be turned on. And it
flashes green in Power
Management mode. (P36)
This indicator is dim when
the projector is turned on.
And bright when the
projector is in stand-by
mode.
lamp warning
replace temp.
ready
lamp
status
TOP CONTROL
FOCUS BUTTONS
MENU BUTTON
POWER ON–OFF BUTTON
MODE BUTTON
Used to adjust focus. (P21)
Used to open or close the
MENU operation. (P18, 19)
Used to turn the projector
on or off. (P20)
Used to select input source
either Computer or Video.
(P24, 32)
VOLUME BUTTONS
ZOOM BUTTONS
Used to adjust zoom. (P21)
Used to adjust volume.
(P23)
power
mode
menu
zoom
lens shift
focus
volume
select
auto image
normal
LENS SHIFT BUTTONS
Used to adjust lens shift.
(P21)
AUTO IMAGE BUTTON
POINT BUTTONS
SELECT BUTTON
NORMAL BUTTON
Used to operate AUTO
IMAGE function. (P29)
Used to select an item or
adjust the value in the MENU.
It is also used to pan the image
in DIGITAL ZOOM mode.
(P31)
Used to execute the item
selected. It is also used to
Used to reset to normal
picture adjustment preset
by factory. (P29, 35)
expand the image in DIGITAL
ZOOM mode. (P31)
15
BEFORE OPERATION
OPERATION OF THE REMOTE CONTROL
Left Side
POWER ON-OFF BUTTON
ON
Used to turn the projector on
or off. (P20)
power
zoom
focus volume
lock
F
ALL OF
MENU BUTTON
mute
Used to select MENU
operation. (P18, 19)
d.zoom computer
menu
video
SELECT BUTTON
ALL-OFF SWITCH
When using the Remote Control
Unit, turn this switch to “ON.” And
turn it to “ALL OFF” when it is not
used.
laser
lens shift
keystone
blank
Used to operate the laser
pointer function. The laser
beam is emitted while pressing
this button within 1 minute.
When using the laser pointer
for more than 1 minute, release
the button and press it again.
VIDEO BUTTON
Used to select VIDEO
source. (P32)
POINT BUTTON
Used to execute the item
selected or to expand the
image in DIGITAL ZOOM
mode. (P31)
It is also used as a PC
mouse in Wireless Mouse
Operation. (P38)
LASER BUTTON
COMPUTER BUTTON
Used to select COMPUTER
input source. (P24)
freeze
auto image
normal
p-timer
P-TIMER BUTTON
Used to move the pointer on
the MENU, to adjust the item,
or to pan the image in DIGITAL
ZOOM mode. (P31)
It is also used as a PC mouse
in Wireless Mouse Operation.
(P38)
✽ When pressing the center of this
button, it works as the SELECT
button.
RIGHT CLICK BUTTON
Used to compress the image
in DIGITAL ZOOM mode.
(P31)
It is also used as a PC mouse
in Wireless Mouse Operation.
(P38)
Used to operate P-TIMER
function. (P22)
LASER POINTER FUNCTION
This remote control emits a laser beam as the Laser Pointer from the Laser Light Window. When the LASER button is
pressed, the laser light goes on. And when the button is pressed more than 1 minute or the button is released, light goes off.
Laser light is emitted with the RED light which tells the laser beam being emitted.
The laser emitted is a class II laser; therefore, do not look into the Laser Light Window or shine the laser beam on yourself or
other people. The three marks bellow are the caution labels for the laser beam.
CAUTION : Use of controls or adjustments or performance of procedures other than those specified herein may result
hazardous radiation exposure.
These caution labels are put on the remote control.
Laser Light Window
16
BEFORE OPERATION
power
ZOOM BUTTON
Used to adjust zoom.
(P21)
zoom
focus volume
VOLUME BUTTON
Used to adjust volume.
(P23)
lock
FOCUS BUTTON
Operating Range
mute
d.zoom computer
Used to adjust focus.
(P21)
menu
video
D.ZOOM BUTTON
Point the remote control toward the
projector (Receiver Window)
whenever pressing the buttons.
Maximum operating range for the
remote control is about 16.4’ (5m)
and 60° in front and rear of the
projector.
Used to select DIGITAL
ZOOM mode and resize
the image. (P31)
60°
MUTE BUTTON
Used to mute sound.(P23)
LENS SHIFT BUTTON
16.4’
(5 m)
Used to select LENS
SHIFT function. (P21)
laser
lens shift
NO SHOW BUTTON
Used to turn the picture
into black image. (P22)
AUTO IMAGE BUTTON
keystone
blank
freeze
auto image
normal
p-timer
Use to operate AUTO
IMAGE function. (P29)
FREEZE BUTTON
Used to freeze the picture.
(P22)
NORMAL BUTTON
Used to reset to normal
picture adjustments preset
by the factory. (P29, 35)
16.4’
(5 m)
KEYSTONE BUTTON
Used to correct the
keystone distortion.
(P21, 29, 35)
WIRED REMOTE JACK
When using as the Wired
Remote Control, connect the
Remote Control Cable to this
jack. (The battery installation
is required when using as the
Wired Remote Control.
60°
Remote Control Batteries Installation
1
Remove the battery
compartment lid.
Press the lid downward and slide it.
2
Slide the batteries into
the compartment.
3
Replace the compartment
lid.
Two AA size batteries
For correct polarity (+
and –), be sure the
battery terminals are in
contact with the pins in
the compartment.
To insure safe operation, please observe the following precautions :
● Use (2) AA, UM3 or R06 type alkaline batteries.
● Replace two batteries at the same time.
● Do not use a new battery with a used battery.
● Avoid contact with water or liquid.
● Do not expose the Remote Control Unit to moisture, or heat.
● Do not drop the remote control unit.
● If batteries have leaked on the remote control, carefully wipe the case clean and load new batteries.
17
BEFORE OPERATION
OPERATING ON-SCREEN MENU
HOW TO OPERATE ON-SCREEN MENU
You can control and adjust this projector through the
ON-SCREEN MENU. Refer to the following pages to
operate each adjustment in the ON-SCREEN MENU.
WIRELESS REMOTE CONTROL
POINT BUTTON
Used to move the
Pointer UP/ DOWN/
RIGHT/ LEFT.
1 MOVING THE POINTER
Move the pointer (see the NOTE below) by pressing POINT
button(s) on the TOP CONTROL or the REMOTE CONTROL.
2 SELECT THE ITEM
Select the item by pressing SELECT button.
SELECT BUTTON
Used to select the item.
TOP CONTROL
menu
NOTE : Pointer is the icon on the ON-SCREEN Menu to
select the item. See the figures on the section
"FLOW OF ON-SCREEN MENU" below.
mode
l
SELECT BUTTON
Used to select the item.
select
auto image
normal
POINT BUTTONS
Used to move the
Pointer UP/ DOWN/
RIGHT/ LEFT.
FLOW OF ON-SCREEN MENU
Display ON-SCREEN MENU
1
MENU BAR
Press MENU button to display the ON-SCREEN MENU
(MENU BAR). The red frame is the POINTER.
Select the Item
2
Move the POINTER (red frame) to the ITEM ICON that
you want to select by pressing POINT RIGHT / LEFT
buttons.
3
Select the ITEM by pressing SELECT button. The
dialog box of the ITEM appears.
POINTER
(red frame)
SELECT
BUTTON
ITEM ICON
POINTER
(red frame)
Control and adjust through ON-SCREEN MENU
4
5
Move the POINTER downward by pressing POINT
DOWN button. (The shape of the POINTER becomes
an arrow.)
Move the POINTER to the ITEM that you want to adjust
and adjust the ITEM by pressing SELECT button.
Refer to the following pages for details of respective
adjustments.
MENU
POINT
DOWN
BUTTON
POINTER
18
BEFORE OPERATION
MENU BAR
MENU BAR IN COMPUTER MODE
AUTO IMAGE MENU
PC ADJUST MENU
Used to adjust Fine
sync, Total dots,
and Picture Position
automatically.
(Refer to P29)
Used to adjust the
parameters to
match with the input
signal format.
(Refer to P26, 27)
MODE MENU
Used to select
the Computer
input mode.
(Refer to P24)
Press MENU BUTTON while in Computer mode.
SETTING MENU
Used to set the Display
Menu and reset Lamp
Replacement Monitor
Timer.
(Refer to P36, 37)
Used to select
the language
used in the
Menu.
(Refer to P37)
SOUND MENU
SYSTEM MENU
IMAGE MENU
POSITION MENU
SCREEN MENU
Used to select a
computer
system.
(Refer to P24)
Used to adjust the
computer image.
[Fine sync / Total dots /
White Balance / Contrast
/ Brightness / Sharpness]
(Refer to P28)
Used to adjust
the position of
the image.
(Refer to P30)
Used to adjust the
size of the image or
to correct the
Keystone distortion.
(Refer to P31)
MENU BAR IN VIDEO MODE
LANGUAGE MENU
Used to adjust
or mute the
Volume.
(Refer to P23)
Press MENU BUTTON while in Video mode.
IMAGE MENU
MODE MENU
Used to select
the Video input.
(Refer to P32)
Used to adjust the picture image.
[Color / Tint / White Balance /
Contrast / Brightness/ Sharpness
/ Noise Reduction / Progressive]
(Refer to P34)
Same function as the
Computer Mode.
SYSTEM MENU
VIDEO SOURCE MENU
SCREEN MENU
Used to select a
color system of the
selected video
source.
(Refer to P33)
Used to select a
video source among
[Video, S-Video, and Y,
Pb/Cb, Pr/Cr].
(Refer to P32)
Used to set the size
of the image either
Regular or Wide,
or to correct the
Keystone distortion.
(Refer to P35)
19
BASIC OPERATION
TURNING ON / OFF THE PROJECTOR
TURNING ON THE PROJECTOR
1
Complete the peripheral connections (with Computer, VCR, etc.)
before turning on the projector. (Refer to "CONNECTING TO
THE PROJECTOR" on Pages 11~14 for connecting that
equipment.)
2
Connect the projector's AC Power Cord into a wall outlet and
turn the MAIN ON / OFF SWITCH to ON. The LAMP indicator
lights RED, and the READY indicator lights GREEN.
3
Press the POWER ON-OFF button on the Remote Control Unit
or on the Top Control to ON. The LAMP indicator dims, and the
Cooling Fans start to operate. The Preparation Display appears
on the screen and the count-down starts. The signal from the
source appears after 30 seconds.
30
The Preparation Display disappears after 30 seconds.
TURNING OFF THE PROJECTOR
1
Press the power ON-OFF button on the Remote Control Unit or
on the Top Control, and the message "Power off?" appears on
the screen.
2
Press the power ON-OFF button again to turn off the projector.
The LAMP indicator lights bright and the READY indicator turns
off. The Cooling Fans operate for 2 minutes after the projector is
turned off. (For first 1 minute of this "Cooling Down" period, this
appliance cannot be turned on.)
3
When the projector has cooled down, the READY indicator turns
to green again and you can turn the projector on. After cooling
down completely, turn the MAIN ON / OFF SWITCH to OFF and
disconnect the AC power cord.
Power off?
The message disappears after 4 seconds.
TO MAINTAIN THE LIFE OF THE LAMP, ONCE YOU
TURN THE PROJECTOR ON, WAIT AT LEAST 5
MINUTES BEFORE TURNING IT OFF.
When the Power Management function is ON, the Projector detects the signal interruption and turns the Projection Lamp off
automatically. Refer to “Power Management” on page 33.
When the TEMPERATURE WARNING indicator flashes red, the projector is automatically turned off. Wait at least 5 minutes
before turning the projector on again.
When the TEMPERATURE WARNING indicator continues to flash, follow procedures below:
1. Turn the MAIN ON / OFF SWITCH to OFF and disconnect the AC power cord from the AC outlet.
2. Check the air filters for dust accumulation.
3. Clean the Air Filter. (See "AIR FILTER CARE AND CLEANING" section on page 39.)
4. Turn the Projector on again.
If the TEMPERATURE WARNING indicator should still continue to flash, contact the sales dealer where you purchased this
projector or service center.
NOTE: The Cooling Fan may work for cooling while the projector is turned off. When the Cooling Fan is
working, TEMPERATURE WARNING INDICATOR flashes red.
20
BASIC OPERATION
ADJUSTING THE IMAGE
ZOOM ADJUSTMENT
1
Press the ZOOM ▲/▼ button(s) on the Top Control or on the
Remote Control Unit. The message “Zoom” is displayed.
2
Press the ZOOM ▲ button or the POINT UP button to make the
image larger, and press the ZOOM ▼ button or the POINT
DOWN button to make the image smaller.
Zoom
The message disappears after 4 seconds.
FOCUS ADJUSTMENT
1
Press the FOCUS ▲/▼ button(s) on the Top Control or on the
Remote Control Unit. The message “Focus” is displayed.
2
Adjust the focus of the image by pressing the FOCUS ▲/▼
button(s) or the POINT UP/DOWN button(s) .
Focus
The message disappears after 4 seconds.
LENS SHIFT ADJUSTMENT
1
Press the LENS SHIFT ▲/▼ button(s) on the Top Control or the
LENS SHIFT button on the Remote Control Unit. The message
“Lens shift” is displayed.
2
Press the LENS SHIFT ▲ button or the POINT UP button to
move the image up, and press the LENS SHIFT ▼ button or the
POINT DOWN button to move the image down.
Refer to P9 for operating range.
Lens shift
The message disappears after 4 seconds.
21
BASIC OPERATION
KEYSTONE ADJUSTMENT
If the picture has keystone distortion, correct image with KEYSTONE adjustment.
1
Press the KEYSTONE ▲/▼ button on the Remote Control Unit
or select the Keystone on the SCREEN menu. (Refer to page
31, 35.) The message “Keystone” is displayed.
2
Correct the Keystone distortion by pressing the KEYSTONE
▲/▼ button or the POINT UP/DOWN button(s). Press the
KEYSTONE ▲ button or the POINT UP button to reduce the
upper part or the image, and press the KEYSTONE ▼ button or
the POINT DOWN button to reduce the lower part.
Reduce the upper width with the KEY STONE ▲
button or the POINT UP button.
Keystone
The message disappears after 4 seconds.
Reduce the lower width with the KEY STONE ▼
button or the POINT DOWN button.
NO SHOW FUNCTION
Press the NO SHOW button on the Remote Control Unit to
black out the image. This function is cancelled when the NO
SHOW button is pressed again or any other function button is
pressed.
No show
The message disappears after 4 seconds.
PICTURE FREEZE FUNCTION
Press the FREEZE button on the Remote Control Unit to freeze the picture on-screen. This function is
cancelled when the FREEZE button is pressed again or any other function button is pressed.
P-TIMER FUNCTION
Press the P-TIMER button on the Remote Control unit. The
timer display “00 : 00” appears on the screen and the timer
starts to count the time (00 : 00 ~ 59 : 59).
To stop the P-TIMER, press the P-TIMER button. And then,
press the P-TIMER button again to cancel the P-TIMER
function.
22
BASIC OPERATION
SOUND ADJUSTMENT
DIRECT OPERATION
Indicates the roughly level
of the volume.
Sound Volume Adjustment
Press the VOLUME (+/–) button(s) on the Top Control or on the
Remote Control Unit to adjust the volume. The Volume dialog box
appears on the screen for a few seconds.
(+) button to increase the volume, and (–) button decreasing.
Sound Mute Setting
Press the MUTE button on the Remote Control Unit to cut off the
sound. To restore the sound to its previous level, press the MUTE
button again or press Volume (+/–) button(s).
Press the MUTE button to set
the Mute function On or Off.
The display disappears after 4 seconds.
MENU OPERATION
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select
SOUND and press the SELECT button. Another dialog box
SOUND ADJUST Menu will appear.
2
Press the POINT DOWN button and a red-arrow icon will
appear. Move the arrow to the item that you want to select by
pressing the POINT UP/DOWN buttons.
Indicate the roughly
level of the item.
Volume
Move the arrow to ▲ or ▼ of "Volume" by pressing the POINT UP/
DOWN buttons. To increase the volume, point the arrow to ▲ and
then press the SELECT button. To decrease the volume point the
arrow to ▼ and then press the SELECT button.
Mute
Move the arrow to
the item and then
press the SELECT
button.
Move the arrow to ▲
or ▼ and press the
SELECT button.
Close the Sound Menu.
To cut off the audio sound, point the arrow to "Mute" and then press
the SELECT button. The Mute display is changed On from Off and
the sound is cut off. To restore the sound to its previous volume level,
set the Mute to Off.
23
COMPUTER MODE
SELECTING COMPUTER MODE
DIRECT OPERATION
Select COMPUTER mode by pressing the MODE button on the
Top Control or the COMPUTER button on the Remote Control
Unit.
MODE button
COMPUTER button
COMPUTER 1
COMPUTER 1
COMPUTER 2
COMPUTER 2
VIDEO
MENU OPERATION
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select
Computer and press the SELECT button. Another dialog box
COMPUTER MODE Menu will appear.
2
Press the POINT DOWN button and a red-arrow icon will
appear. Move the arrow to the mode either Computer 1 or
Computer 2, and then press the SELECT button.
CURRENT MODE DISPLAY
When selecting the Computer Mode, the Current Mode display
appears to show the information of the computer being selected.
Providing the information of the computer detected
by the projector.
SELECTING COMPUTER SYSTEM
AUTOMATIC MULTI-SCAN SYSTEM
This projector automatically tunes to most different types of
computers based on VGA, SVGA, XGA or SXGA (refer to
“COMPATIBLE COMPUTER SPECIFICATION” on page 25).
When selecting Computer, this projector automatically tunes to
the incoming signal and projects the proper image without any
special settings. (Setting of the Computer System may be
required when connecting some computers.)
SYSTEM BOX
Display the SYSTEM being selected.
Note : The projector may display one of the following messages.
Go to PC adj. The projector cannot discriminate or detect the input
signal from the computer. Adjust and set the
computer system manually. (Refer to page 26.)
No signal
There is no signal input from the computer. Make
sure the connection of the computer and the
projector is set correctly.
(Refer to TROUBLESHOOTING on page 42.)
The system being selected.
SELECT COMPUTER SYSTEM MANUALLY
To set the Computer system manually, select the mode on the
ON-SCREEN MENU.
24
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select
SYSTEM and press the SELECT button. Another dialog box
COMPUTER SYSTEM Menu will appear.
2
Press the POINT DOWN button and a red-arrow icon will
appear. Move the arrow to the system that you want to set, and
then press SELECT button.
The systems on this dialog
box can be selected.
When this mark is
displayed as black, more
computer system modes
will be available. Move
the arrow to this mark and
then press the SELECT
button, and the other
modes will be displayed.
Close the
SYSTEM Menu.
COMPUTER MODE
COMPATIBLE COMPUTER SPECIFICATIONS
Basically this projector can accept the signal from all computers with the V, H-Frequency mentioned below and
less than 180 MHz of Dot Clock.
ON-SCREEN
DISPLAY
VGA 1
VGA 2
VGA 3
VGA 4
VGA 5
VGA 6
VGA 7
MAC LC13
MAC 13
RGB
RGB
SVGA 1
SVGA 2
SVGA 3
SVGA 4
SVGA 5
SVGA 6
SVGA 7
SVGA 8
SVGA 9
SVGA 10
SVGA 11
MAC 16
XGA 1
XGA 2
XGA 3
XGA 4
XGA 5
XGA 6
XGA 7
XGA 8
XGA 9
XGA 10
RESOLUTION
640 x 480
720 x 400
640 x 400
640 x 480
640 x 480
640 x 480
640 x 480
640 x 480
640 x 480
––––––––
(Interlace)
––––––––
(Interlace)
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
832 x 624
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
(Interlace)
1024 x 768
H-Freq.
(kHz)
V-Freq.
(Hz)
ON-SCREEN
DISPLAY
31.47
31.47
31.47
37.86
37.86
37.50
43.269
34.97
35.00
15.734
15.625
35.156
37.88
46.875
53.674
48.08
37.90
34.50
38.00
38.60
32.70
38.00
49.72
48.36
68.677
60.023
56.47
60.31
48.50
44.00
63.48
36.00
62.04
59.88
70.09
70.09
74.38
72.81
75.00
85.00
66.60
66.67
30
25
56.25
60.32
75.00
85.06
72.19
61.03
55.38
60.51
60.31
51.09
60.51
74.55
60.00
84.997
75.03
70.07
74.92
60.02
54.58
79.35
43.59
77.07
XGA 11
XGA 12
XGA 13
XGA 14
XGA15
MAC 19
MAC 21
SXGA 1
SXGA 2
SXGA 3
SXGA 4
SXGA 5
SXGA 6
SXGA 7
SXGA 8
SXGA 9
SXGA 10
SXGA 11
SXGA 12
SXGA 13
SXGA 14
SXGA 15
SXGA 16
SXGA 17
SXGA 18
SXGA 19
SXGA 20
MAC
MAC
HDTV720p
HDTV1035i
HDTV1080i
RESOLUTION
1024 x 768
1024 x 768
(Interlace)
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1152 x 870
1152 x 864
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 960
1152 x 900
1152 x 900
1280 x 1024
(Interlace)
1280 x 1024
(Interlace)
1280 x 1024
1280 x 1024
1152 x 900
1280 x 1024
(Interlace)
1280 x 1024
1280 x 1024
1280 x 960
1280 x 1024
––––––––
––––––––
(Interlace)
––––––––
(Interlace)
H-Freq.
(kHz)
V-Freq.
(Hz)
61.00
35.522
46.90
47.00
58.03
60.24
68.68
64.20
62.50
63.90
63.34
63.74
71.69
81.13
63.98
79.976
60.00
61.20
71.40
50.00
50.00
63.37
76.97
61.85
46.43
63.79
91.146
75.00
80.00
45.00
33.75
33.75
75.70
43.48
58.20
58.30
72.0
75.08
75.06
70.40
58.60
60.00
59.98
60.01
67.19
76.107
60.02
75.025
60.00
65.20
75.60
43.00
47.00
60.01
72.00
66.00
43.35
60.18
85.024
75.08
75.08
60.00
30.00
30.00
When the input signal is from the COMPUTER INPUT-1 (DIGITAL) terminal, refer to the chart below.
ON-SCREEN
DISPLAY
RESOLUTION
H-Freq.
(kHz)
V-Freq.
(Hz)
ON-SCREEN
DISPLAY
RESOLUTION
H-Freq.
(kHz)
V-Freq.
(Hz)
D-VGA
D-SVGA
D-XGA
640 x 480
800 x 600
1024 x 768
31.469
37.879
48.363
59.940
60.317
60.004
D-SXGA 1
D-SXGA 2
D-SXGA 3
1280 x 1024
1280 x 1024
1280 x 1024
63.981
60.276
31.65
60.020
58.069
29.8
NOTE : Specifications are subject to change without notice.
25
COMPUTER MODE
PC ADJUSTMENT
This Projector can automatically tune to the display signals from most personal computers currently distributed.
However, some computers employ special signal formats which are different from the standard ones and may
not be tuned by the Multi-Scan system of this projector. If this happens, the projector cannot reproduce a proper
image and the image may be recognized as a flickering picture, a non-synchronized picture, a non-centered
picture or a skewed picture.
This projector has a PC ADJUSTMENT function to enable you to precisely adjust several parameters to match
with those special signal formats. This projector has 8 independent memory areas to memorize those
parameters manually adjusted. This enables you to recall the setting for a specific computer whenever you use
it.
Note : This PC ADJUSTMENT function cannot be operated when the input signal is from the COMPUTER INPUT-1
(DIGITAL) terminal or “RGB” is selected on the SYSTEM MENU (P24 and 25).
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT RIGHT/LEFT button to select PC
ADJUST and press the SELECT button. Another dialog box
“Where to reserve” Menu will appear.
2
In this dialog box, you can store the parameter into the area from
“Mode 1” to “Mode 8.” When memorizing the new computer
parameter, select the Mode with the message “Free” by pressing
the POINT UP/DOWN button and the SELECT button. To
change the parameters of the Mode previously set, select the
Mode with “Stored.”
3
When the Mode is selected, Parameter adjustment dialog box
appears. Move the arrow to the item that you want to change by
pressing the POINT UP/DOWN button, and adjust each item by
pressing the SELECT button to match with your computer.
4
Move the arrow to “Stored” and press the SELECT button. The
parameter is memorized in the selected Mode.
5
To activate the Mode manually adjusted in this PC
ADJUSTMENT Menu, select the Mode at the SYSTEM SELECT
Menu. (Refer to page 24.)
This Mode has
parameters being
stored.
The Vacant Mode.
Manual set Computer
Mode (1 to 8).
Close the PC
ADJUSTMENT Menu.
Move the arrow to ▲ or
▼ and press SELECT
button.
26
COMPUTER MODE
Total lines
The number of the total vertical lines. Adjust the number to match
the image of your personal computer.
Total dots
The number of the total dots in one horizontal period. Adjust the
number to match the image of your computer.
Horizontal / Vertical
Adjustment of the horizontal or vertical picture position. When the
image is not centered on the screen, adjust each of those items.
Clamp
Adjustment of the clamp level. When the image has a dark bar(s),
try this adjustment.
Fine sync
Adjust the picture as necessary to eliminate flicker from the display.
Press the SELECT button at this
column to adjust “Clamp,” “Fine
sync,” “Display area,” “Horiz.
scale” or “Vert. scale” .
Display area
Adjustment of the area displayed with this projector. Select the
resolution at the Display area dialog box, or adjust the number at the
column of “H” or “V” to match the resolution of the image.
Horizontal Scale / Vertical Scale
Adjustment of the horizontal height or vertical width of the image.
NOTE : The Display area, the Horiz. scale and the Vert. scale
cannot be adjusted when “HDTV1035i” or “HDTV1080i” is
selected on the SYSTEM MENU (P24 and 25).
Each of the keys operates as follow.
Reset
Mode free
Stored
Quit
Recalls the parameter data that was previously
adjusted.
Clears the parameter data previously set.
Stores the parameters in the memory.
Point the arrow at the Display area and press
the SELECT button. The Display area dialog
box appears.
Closes the PC ADJUST Menu.
27
COMPUTER MODE
PICTURE IMAGE ADJUSTMENTS
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select IMAGE
and press the SELECT button. Another dialog box PICTURE
IMAGE ADJUSTMENT Menu will appear.
2
Press the POINT DOWN button and a red-arrow icon will
appear. Move the arrow to the function that you want to select
and then press SELECT button.
Standard
Normal picture level preset on this projector. This picture level can
be set by pressing the NORMAL button.
Move the arrow to the level
and press the SELECT
button.
The level being selected.
Real
Picture level adjusted for the picture with fine tone.
Custom
Picture level adjusted manually in the custom setting dialog box.
When selecting “▼,” the custom setting dialog box will appear. Move
the arrow to the item that you want to change by pressing the POINT
UP/DOWN button, and adjust each value by pressing the SELECT
button to match with the image.
Press the SELECT button
at “▼” to adjust the picture
level manually.
Fine sync
Adjust the picture as necessary to eliminate flicker from the display.
(From 0 to 127.)
Total dots
The number of the total dots in one horizontal period. Adjust the
number to match your PC image.
White balance (Red / Green / Blue)
Move the arrow to the color that you want to adjust. Point to ▼ to
lighten the color and select ▲ to deepen the color. (From 0 to 63.)
Contrast
Point to ▼ to decrease contrast, and select ▲ to increase contrast.
(From 0 to 63.)
Brightness
Point to ▼ to adjust the image darker, and select ▲ to adjust
brighter. (From 0 to 63.)
Move the arrow to
▲ or ▼ and press
SELECT button.
Sharpness
Point to ▼ to soften the image, and select ▲ to sharpen the image.
(From 0 to 15.)
Each of the keys operates as follow.
Reset
Recalls the data previously adjusted.
Stored
Stores the adjusted data in the memory.
Quit
28
Closes the PICTURE IMAGE ADJUSTMENT Menu.
Close the PICTURE IMAGE
ADJUSTMENT Menu.
NOTE : The Fine sync and the Total dots cannot
be operated when the input signal is from
the COMPUTER INPUT-1 (DIGITAL)
terminal or “RGB” is selected on the
SYSTEM MENU (P24 and 25).
The Fine sync and the Total dots cannot
be fully adjusted when “HDTV1035i” or
“HDTV1080i” is selected on the SYSTEM
MENU (P24 and 25).
COMPUTER MODE
NORMAL FUNCTION
The normal picture level is preset on this projector at the
factory and can be restored anytime you press the NORMAL
button (located on the Top Control or on the Remote Control
Unit). The “Standard” display will be displayed on the screen
for a few seconds.
Standard
AUTO IMAGE ADJUSTMENT
The Auto Image function is provided to automatically adjust Fine sync., Total dots, and Picture Position for most
computers.
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select AUTO
IMAGE and press the SELECT button.
Another dialog box AUTO IMAGE Menu will appear.
2
Move the arrow to an item that you want to adjust by pressing
the POINT UP/DOWN button. Change the setting On or Off by
pressing the SELECT button.
Fine sync
Adjust the picture as necessary to eliminate flicker from the display.
This item can be adjusted manually. (Refer to page 28.)
Total dots
The number of the total dots in one horizontal period. This item can
be adjusted manually. (Refer to page 28.)
Position
Adjustment of the position of the image. This item can be adjusted
manually. (Refer to page 30.)
3
Starts the adjustment
on the item set to "On".
Move the arrow to
the item and then
press the SELECT
button.
Terminates the AUTO IMAGE
ADJUSTMENT Menu.
Move the arrow to “Go!” and press the SELECT button to start
the Auto Image function.
This adjustment can be executed by pressing AUTO IMAGE
button on the Top Control or on the Remote Control Unit.
Stored
Stores the On/Off setting of each item.
Go!
Starts the Auto Image Adjustment.
Quit
Closes the AUTO IMAGE ADJUSTMENT Menu.
NOTE : This menu cannot be operated when the input signal is from the COMPUTER INPUT-1 (DIGITAL) terminal or
“RGB,” “HDTV720p,” “HDTV1035i” or “HDTV1080i” is selected on the SYSTEM MENU (P24 and 25).
The Fine sync., Total dots, and Picture Position of some computers may not be fully adjusted with the Auto Image
Function. In that case, manual adjustment is required to make fine image. (Refer to page 28 to adjust "Fine sync."
or "Total dots" and page 30 to adjust Picture Position.)
29
COMPUTER MODE
PICTURE POSITION ADJUSTMENT
The position of the image can be adjusted vertically and horizontally through PICTURE POSITION
ADJUSTMENT.
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select
POSITION and press the SELECT button. The PICTURE
POSITION dialog box will appear.
2
Select the arrow to the direction (described as , ,
or )
that you want to adjust by pressing the POINT UP/DOWN/
LEFT/RIGHT buttons, and then press the SELECT button.
Each of the keys operates as follow.
Reset
Recalls the setting data previously set.
Stored
Stores the setting data in the memory.
Quit
30
Closes the PICTURE POSITION Menu.
Select the arrow to the
direction (described as
,
,
or
),and
then press the SELECT
button.
COMPUTER MODE
PICTURE SCREEN ADJUSTMENT
This projector has a picture screen resize function, which enables you to display the desirable image size.
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select
SCREEN
and press the SELECT button. Another dialog
box PICTURE SCREEN Menu will appear.
2
Press the POINT DOWN button and a red-arrow icon will
appear. Move the arrow to the function that you want to select
and then press SELECT button.
True
To make the image into its original size, select True in the dialog box.
When the original image size is larger than the screen size (1024 x
768), the image can be panned by pressing the POINT
UP/DOWN/LEFT/RIGHT buttons.
Keystone
When the image is distorted vertically, select Keystone in the dialog
box. The ON-SCREEN menu and SCREEN ADJUST menu
disappears and the message “Keystone” is displayed. Correct the
Keystone distortion by pressing the KEYSTONE ▲/▼ button or the
POINT UP/DOWN button(s). Refer to KEYSTONE ADJUSTMENT
on page 20.
Digital Zoom
To adjust the image size or pan the image, select Digital zoom in the
dialog box. The ON-SCREEN menu and SCREEN ADJUST menu
disappears, and the magnifying glass icon and the message “D.
Zoom” is displayed.
This projector also enters Digital Zoom mode by pressing the
D.ZOOM ▲/▼ button on the Remote Control Unit.
Move the arrow to the
function and press the
SELECT button.
NOTE
● The True and the Digital Zoom cannot be
operated when “RGB,” “HDTV1035i” or
“HDTV1080i” is selected on the SYSTEM MENU
(P24 and 25).
● This projector cannot display any resolution
higher than 1280 X 1024. If your computer’s
screen resolution is higher than 1280 X 1024,
reset the resolution to the lower before
connecting the projector.
● The image data in other than XGA (1024 x 768)
is modified to fit the screen size in the initial
mode.
● The normal "Panning Operation" may not
function properly if the computer system
prepared with the "PC Adjust" is used.
Refer to the following for operation.
Expand function
To expand the image size, press the D.ZOOM ▲ button or the
SELECT button. The image is magnified by degrees.
Compress function
To compress the image size, press the D.ZOOM ▼ button or the
RIGHT CLICK button. The size of image is reduced by degrees.
Panning function
To pan the image, press the POINT UP/DOWN/LEFT/RIGHT
buttons. Panning function can work only when the image is larger
than the screen size.
To cancel Digital Zoom mode, press any button except D.ZOOM
▲/▼, SELECT, RIGHT CLICK, or POINT button. To adjust the image
to 1024 x 768, press NORMAL button.
31
VIDEO MODE
SELECTING VIDEO MODE
DIRECT OPERATION
Select VIDEO mode by pressing the MODE button on the Top
Control or the VIDEO button on the Remote Control Unit.
MODE button
VIDEO
COMPUTER 1
COMPUTER 2
MENU OPERATION
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select Video
and press the SELECT button.
SELECTING VIDEO SOURCE
This projector automatically detects the signal from the VIDEO
INPUT JACK(s) or the S-VIDEO INPUT JACK. When those
jacks are connected at the same time, select the type of Video
source in VIDEO SOURCE Menu.
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select VIDEO
SOURCE and press the SELECT button. Another dialog box
VIDEO SOURCE Menu will appear.
2
Press the POINT DOWN button and a red-arrow icon will
appear. Move the arrow to the source that you want to select,
and then press the SELECT button.
Auto
The projector automatically detects the incoming Video source, and
adjusts itself to optimize its performance.
• When both VIDEO jack and S-VIDEO jack are connected, the SVIDEO jack has priority over the VIDEO jack.
• When both Y-Pb/Cb-Pr/Cr jacks and S-VIDEO jack are connected,
the Y-Pb/Cb-Pr/Cr jacks have priority over the S-VIDEO jack.
Video / S-Video / Y, Pb/Cb, Pr/Cr
When the VIDEO INPUT JACK(s) and the S-VIDEO INPUT JACK
are connected at the same time, or if the projector cannot chose the
proper video source, it is necessary to select a specific video source
among Video, S-Video and Y, Pb/Cb, Pr/Cr.
32
This box indicates the
Video source being
selected.
VIDEO MODE
SELECTING COLOR SYSTEM
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select
SYSTEM and press the SELECT button. Another dialog box
VIDEO SYSTEM Menu will appear.
2
Press the POINT DOWN button and a red-arrow icon will
appear. Move the arrow to "Auto", and then press the SELECT
button.
VIDEO SIGNAL FROM VIDEO JACK OR S-VIDEO JACK
Auto
The projector automatically detects the incoming Video system, and
adjusts itself to optimize its performance.
When the Video System is PAL-M or PAL-N, select the system
manually.
PAL / SECAM / NTSC / NTSC4.43 / PAL-M / PAL-N
If the projector cannot reproduce the proper video image, it is
necessary to select a specific broadcast signal format among PAL,
SECAM, NTSC, NTSC 4.43, PAL-M, and PAL-N.
This box indicates the
system being selected.
Move the arrow to
the Mode and press
the SELECT button.
VIDEO SIGNAL FROM Y, Pb/Cb, Pr/Cr JACKS
Auto
The projector automatically detects the incoming Video signal, and
adjusts itself to optimize its performance.
This box indicates the
system being selected.
COMPONENT VIDEO SIGNAL FORMAT
If the projector cannot reproduce the proper video image, it is
necessary to select a specific component video signal format among
480i, 575i, 480p, 575p, 720p, 1035i and 1080i.
Move the arrow to
the Mode and press
the SELECT button.
33
VIDEO MODE
PICTURE IMAGE ADJUSTMENT
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select IMAGE
and press the SELECT button. Another dialog box PICTURE
IMAGE ADJUSTMENT Menu will appear.
2
Press the POINT DOWN button and a red-arrow icon will
appear. Move the arrow to the function that you want to select
and then press SELECT button.
Standard
Normal picture level preset on this projector. This picture level can
be set by pressing the NORMAL button.
Move the arrow to the item
and press the SELECT
button.
The level being selected.
Cinema
Picture level adjusted for the picture with fine tone.
Custom
Picture level adjusted manually in the custom setting dialog box.
When selecting “▼,” the custom setting dialog box will appear. Move
the arrow to the item that you want to change by pressing the POINT
UP/DOWN button, and adjust each value or change the setting On or
Off by pressing the SELECT button to match with the image.
Press the SELECT button
at “▼” to adjust the picture
level manually.
Color
Point to ▼ button to lighten the image, and select ▲ to deepen the
image. (From 0 to 63.)
Tint
Point to ▼ button to increase purple, and select ▲ to increase green.
(From 0 to 63.)
White balance (Red / Green / Blue)
Move the arrow to the color that you want to adjust. Point to ▼ to
lighten the color and select ▲ to deepen the color. (From 0 to 63.)
Move the arrow to ▲
or ▼ and press
SELECT button.
Contrast
Point to ▼ button to decrease contrast, and select ▲ to increase
contrast. (From 0 to 63.)
Brightness
Point to ▼ button to darken the image, and select ▲ to brighten the
image. (From 0 to 63.)
Sharpness
Point to ▼ button to soften the image, and select ▲ to sharpen the
image. (From 0 to 31.)
Noise reduction
Set “On” to reduce the noise (rough parts) of the image.
Progressive
Set “On” to provide progressive scan mode.
Each of the keys operates as follow.
Reset
Recalls the data previously adjusted.
Stored
Stores the data in the memory.
Quit
34
Closes the PICTURE IMAGE ADJUSTMENT Menu.
Closes the PICTURE
IMAGE ADJUSTMENT
Menu.
Press the SELECT button to set the function
“On” or “Off.”
NOTE : The Noise Reduction cannot be operated
when the video signal is from the Y,
Pb/Cb, Pr/Cr jacks.
The Progressive cannot be operated when
“480p,” “575p,” “720p,” “1035i,” “1080i-50”
or “1080i-60” is selected on the SYSTEM
MENU (P33).
VIDEO MODE
NORMAL FUNCTION
The normal picture level is preset on this projector at the
factory and can be restored anytime you press the NORMAL
button (located on the Top Control or on the Remote Control
Unit). The "Standard" display will be displayed on the screen
for a few seconds.
Standard
PICTURE SCREEN ADJUSTMENT
This projector has a picture screen resize function, which enables you to display the desirable image size.
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select
SCREEN and press the SELECT button. Another dialog box
PICTURE SCREEN ADJUSTMENT DISPLAY will appear.
2
Press the POINT DOWN button and a red-arrow icon will
appear. Move the arrow to the screen size that you want to set,
and then press the SELECT button.
Regular
Normal Video Image size with 4 x 3 aspect ratio.
Wide
Resizes the image for wide screen size with 16 x 9 aspect ratio.
Keystone
When the image is distorted vertically, select Keystone in the dialog
box. Correct the Keystone distortion by pressing KEYSTONE ▲/▼
button or POINT UP/DOWN button(s). Refer to KEYSTONE
ADJUSTMENT on page 20.
Move the pointer to the function and
press the SELECT button.
NOTE : The Regular and the Wide cannot be
operated when “720p,” “1035i,” “1080i-50”
or “1080i-60” is selected on the SYSTEM
MENU (P33).
35
SETTING
SETTING MENU
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press the POINT LEFT/RIGHT buttons to select
SETTING and press the SELECT button. Another dialog box
SETTING Menu will appear.
2
Press the POINT DOWN button and a red-arrow icon will
appear. Move the arrow to the item that you want to set, and
then press the SELECT button to set it "On" or "Off" or press the
POINT LEFT/RIGHT button to adjust the value.
Blue back
When this function is “On,” this projector will produce a blue image
instead of the video noise on the screen when the input source is
unplugged or turned off.
Display
This function decides whether to display the On-Screen Displays.
On1 ··· shows all the On-Screen Displays.
On2 ··· shows the On-Screen Displays except the Preparation
Display (Our Logo).
Off ···· sets the On-Screen Displays disappeared except;
● ON SCREEN MENU
● “Power off?” message
● P-TIMER
Set the Pointer to the item
and press the SELECT
button.
Power management
This function turns the Projection Lamp off when the projector
detects signal interruption and the projector is not used for a certain
period in order to reduce power consumption and maintain the Lamplife. (This projector is shipped with this function ON.)
Power Management function operates to turn the Projection Lamp off
when the input signal is interrupted and the projector is not operated
over 5 minutes. This function operates as follows;
1. When the signal is interrupted, “No signal” and the counting
down (5 minutes) display appears.
2. When the Projection Lamp turned off, the READY indicator
turns off. The Cooling Fans operate for 90 seconds after the
Projection Lamp is turned off. (During this "Cooling Down"
period, the Lamp cannot be turned on.)
3. When the Lamp has cooled down, the READY indicator flashes
and the Lamp can be turned on again (Power Management
mode).
In this Power Management mode, the Projection Lamp is
automatically turned on when the input signal connected or the
projector is operated with any button on the Top Control or the
Remote Control.
On start
When this function is “On,” the projector is automatically turned on
just by switching the MAIN ON / OFF SWITCH on.
Note ; Be sure to turn the projector off properly (refer to the section
“TURNING OFF THE PROJECTOR” on page 20.). If the
projector is turned off in the wrong steps, the On Start
function does not operate properly.
36
Time left until Lamp off.
SETTING
Ceiling function
Ceiling
When this function is “On,” the top / bottom and the left / right
reversed picture is provided to project the image from a ceiling
mounted projector.
Rear
When this function is “On,” the left / right reversed picture is provided
to project the image to a rear projection screen.
Rear function
Split wipe
Turn this function “On” in the SETTING menu. The picture will
change into next one by sliding black image side ways like drawing
the black curtains when the input source is turned into another one.
Remote control
This projector has two different remote transmit codes; the factoryset normal code (Mode 1) and the secondary code (Mode 2). This
switching function prevents the remote control operation mixture
(jam) when operating several projectors or video equipment together.
When operating the projector in “Mode 2,” both projector and
Remote Control must be switched to “Mode 2.”
To change the code of the projector;
Set the Remote control in the SETTING menu to “Mode 2.”
To change the code of the Remote Control;
Press both the MENU and the NORMAL buttons on the Remote
Control together for over 10 seconds.
After changing the code, make sure the Remote Control operates
properly.
To return to the normal code (Mode 1), operate both projector and
Remote Control in the ways above again.
NOTE : When the ALL-OFF switch on the Remote Control Unit is
turned to “ALL-OFF,” the remote transmit code automatically
returns to the normal code (Mode 1).
Lamp age
The Lamp age function is designed to reset the lamp replacement
monitor timer. When replacing the lamp, reset the lamp replacement
monitor timer by using this function. (Refer to page 40.)
SELECTING LANGUAGE
The language used in the ON-SCREEN MENU is selectable
from among English, German, French, Italian, Spanish and
Japanese.
1
Press the MENU button and the ON-SCREEN MENU will
appear. Press POINT LEFT/RIGHT buttons to select
LANGUAGE and press the SELECT button. Another dialog box
LANGUAGE Menu will appear.
2
Press the POINT DOWN button and a red-arrow icon will
appear. Move the arrow to the language that you want to set,
and then press the SELECT button.
Move the Pointer to the
language that you want
to set, and then press
the SELECT button.
37
APPENDIX
OPERATING WIRELESS MOUSE
The Wireless Remote Control Unit is not only able to operate the projector but also usable as a wireless mouse
for most Personal Computers. The POINT buttons and the two CLICK buttons are used for the wireless mouse
operation.
The wireless mouse is available only when PC mouse pointer is displayed on the screen. When the menu or
the indicator of the projector is displayed on the screen instead of the PC mouse pointer, the wireless mouse
cannot be used.
INSTALLATION
To use the Wireless Remote Control Unit as the Wireless Mouse for a Personal Computer, installation of the
mouse driver (not supplied) is required. Make sure that the mouse driver is properly installed in your computer.
And make sure that the mouse port of the computer connected to Control Port is activated.
1
Connect the mouse port of your computer to the Control Port of
the projector with the Control Cable. (Refer to page 11 to 14 for
connection.)
2
Turn the projector on first, and then turn on your computer.
When the computer is switched on first, the Wireless Mouse may
not work properly.
Note : When the computer has no
mouse port, connect the Serial
Port of the computer to Control
Port of the projector with the
Control Cable for Serial Port.
OPERATING WIRELESS MOUSE
When controlling the pointer of the computer, operate the Wireless Mouse with POINT button, SELECT button,
and RIGHT CLICK button on the Wireless Remote Control Unit.
POINT button
POINT button (Move the pointer)
Used to move the pointer. The pointer is moved corresponding with
the direction you are pressing.
SELECT (LEFT CLICK) button
This button has the same function as the left button in a PC mouse.
RIGHT CLICK button
This button has the same function as the right button in a PC mouse.
Pressing this button does not affect any operation when in Menu
mode.
38
SELECT button
(left button of the
mouse)
RIGHT CLICK button
(right button of the mouse)
APPENDIX
MAINTENANCE
TEMPERATURE WARNING INDICATOR
The TEMPERATURE WARNING Indicator flashes red when the internal temperature of the projector exceeds
the normal temperature. The Indicator stops flashing when the temperature of the projector returns to normal.
When the TEMPERATURE WARNING Indicator continues to flash, check the items listed below.
1
2
3
The Ventilation slots of the projector may be blocked. In such an event, reposition the appliance so that the ventilation
slots are not obstructed.
Air filters may be clogged with dust particles. Clean the air filters by following the section AIR FILTER CARE AND
CLEANING below.
If the TEMPERATURE WARNING Indicator remains on after performing the above checks, the Cooling Fans or the
Internal Circuits may be malfunctioning. Contact service a personnel from an authorized dealer or service station.
AIR FILTER CARE AND CLEANING
The Removable Air Filter prevents dust from accumulating on the surface of the Projection Lens and the
Projection Mirror. Should the Air Filter become clogged with dust particles, it will reduce the Cooling Fans'
effectiveness and may result in internal heat build up and adversely affect the life of the projector.
Clean the Air Filter following the steps below:
1
Turn the power off, and disconnect the AC power cord from the
AC outlet.
2
Turn the projector upside down and remove the Air Filter Cover
by pressing four latches sideways and pulling up. Remove three
Air Filters by pulling up the latches.
3
Clean the Air Filters with brush or wash out the dust and
particles. Be sure to dry them out.
4
Replace the Air Filters and Air Filter Cover properly. Make sure
that they are fully set.
CAUTION
Do not operate the projector with the Air Filter removed.
Dust may accumulate on the LCD Panel and the Mirror
degrading picture quality.
Do not put small parts into the Air Intake Vents. It may
result in malfunction of the projector.
Press the latches
sideways and pull up.
RECOMMENDATION
We recommend avoiding dusty/smoky environments when
operating the projector. Usage in these environments may
cause poor image quality.
When using under dusty or smoky conditions, dust may accumulate
on the liquid crystal panel, lens, or optical elements inside it. This
condition may degrade the quality of the projected image.
When the above symptoms are noticed, contact your authorized
dealer or service station for proper cleaning.
Remove three Air
Filters by pulling up
the latches.
39
APPENDIX
LAMP REPLACEMENT
When the life of the Lamp of this projector draws to an end, the LAMP REPLACEMENT indicator lights yellow.
When the image becomes dark or the color of the image becomes unnatural, replacement of the Lamp is
required.
CAUTION
● For continued safety, replace with a lamp assembly of the same type.
● Allow the projector to cool for at least 45 minutes before you open the lamp cover. The inside of the projector
can become very hot.
● Do not drop the lamp assembly or touch the glass bulb! The glass can shatter and may cause injury.
Follow these steps to replace the lamp assembly.
1
Turn off the projector and disconnect the AC plug. Allow the
projector to cool for at least 45 minutes.
2
Remove the screw with a screwdriver and remove the Lamp
Cover.
3
Remove the two screws with a screwdriver and pull out the
Lamp Assembly by grasping the handle.
4
Replace the Lamp Assembly with a new one and tighten the two
screws. Make sure that the Lamp Assembly is set properly.
Replace the Lamp Cover and tighten the screw.
5
Connect the AC Power Cord to the projector and turn the
projector on.
6
Reset the Lamp Replacement Monitor Timer (refer to the section
“Lamp Replacement Monitor Timer” below).
LAMP COVER
LAMP
ASSEMBLY
NOTE : Do not reset the LAMP REPLACEMENT MONITOR
TIMER when the lamp is not replaced.
HANDLE
ORDER REPLACEMENT LAMP
Replacement Lamp can be ordered through your dealer. When ordering the Lamp, give the following
information to the dealer.
● Model No. of your projector : Desktop Projector 9280
● Replacement Lamp Type No. : POA-LMP28
(Proxima Lamp No. : LAMP-025)
(Service Parts No. 610 285 4824)
LAMP REPLACEMENT MONITOR TIMER
Be sure to reset the Lamp Replacement Monitor Timer when the Lamp Assembly is replaced. When the Lamp
Replacement Monitor Timer is reset, the LAMP REPLACEMENT indicator stops lighting.
1
Turn the projector on, and press the MENU button and the ON-SCREEN MENU will appear. Press the POINT
LEFT/RIGHT buttons to select SETTING and press the SELECT button (refer to the page 36, 37). Another dialog box
SETTING MENU will appear.
2
Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to “Lamp age,” and then press the
SELECT button. The message "Lamp replace monitor Reset?" is displayed.
3
Select [Yes] to reset the Timer.
Do not reset the Lamp Replacement Monitor Timer, except after the lamp is replaced.
40
APPENDIX
CLEANING THE PROJECTION LENS
Follow these steps to clean the projection lens:
1
Apply a non-abrasive camera lens cleaner to a soft, dry cleaning cloth. Avoid using an excessive amount of cleaner.
Abrasive cleaners, solvents or other harsh chemicals might scratch the lens.
2
3
Lightly wipe the cleaning cloth over the lens.
When the projector is not in use, replace the lens cover.
41
APPENDIX
TROUBLESHOOTING
Before calling your dealer or service center for assistance, check the matters below once again.
1. Make sure you have connected the projector to your equipment as described in the section "CONNECTING
THE PROJECTOR" on pages 11 ~ 14.
2. Check cable connection. Verify that all computer, video and power cords are properly connected.
3. Verify that all power is switched on.
4. If the projector still does not produce an image, re-start the computer.
5. If the image sill does not appear, unplug the projector from the computer and check the computer monitor's
display. The problem may be with your graphics controller rather than with the projector. (When you
reconnect the projector, remember to turn the computer and monitor off before you power up the projector.
Power the equipment back on in order of : Projector and computer.)
6. If the problem still exists, check the following chart.
Problem:
No power.
Try these Solutions
● Plug the projector into the AC outlet.
● Be sure READY Indicator light is On.
● Wait 1 minute after the projector is turned OFF before turning the projector back on.
NOTE : After pressing the power ON-OFF switch to OFF, make sure the projector works
as follows:
1. The LAMP indicator will light and the READY indicator will turn off.
2. After 1 minute, the READY indicator will light green again and the projector may
be turned on by pressing the power ON-OFF button.
● Check the TEMPERATURE WARNING indicator. If the indicator flashes red, the
projector cannot be turned on.
(See "TURNING ON/OFF THE PROJECTOR" section on page 20.)
● Check the Projection Lamp. (Refer to page 40.)
Image is out of
focus.
● Adjust the focus
● Make sure the projection screen is at least 4.6’ (1.4m) from the projector.
● Check the projection lens to see if it needs cleaning.
NOTE : Moving the projector from a cool temperature location to a warm temperature
location may result in moisture condensation on the lens. In such an event, leave
the projector OFF and wait until condensation disappears.
Picture is Left/Right
reversed.
● Check Ceiling / Rear feature. (See “SETTING” section on page 36.)
Picture is
Top/Bottom
reversed.
● Check Ceiling feature. (See “SETTING” section on page 36.)
Some displays are
not seen during the
Operation.
● Check Display feature. (See “SETTING” section on page 36.)
No image.
● Check the connection between the computer or video equipment and the projector.
● When turning the projector on, it takes about 30 seconds to display the image.
● Check the system that you select is corresponding with the computer or the video
equipment.
● Make sure the temperature is not out of the Operating Temperature (5°C ~ 35°C).
No sound.
42
● Check audio cable connection from audio input source.
● Adjust the audio source.
● Press VOLUME (+) button.
● Press MUTE button.
APPENDIX
Problem:
Try these Solution
Remote Control Unit
does not work.
● Check the batteries.
● Check the ALL-OFF switch on the Remote Control Unit is set to “ON.”.
● Make sure nothing is between the Remote Receiver and the Remote Control Unit.
● Make sure you are not too far from the projector when using the Remote Control Unit.
Maximum operating range is 16.4’ (5m).
● Make sure the code of the Remote Control is set to conform to the projector.
(See “SETTING” section on page 36, 37.)
Wireless Mouse
function does not
work.
● Check the cable connection between the projector and the computer.
● Check the mouse setting on your computer.
● Turn the projector on before you turn on the computer.
WARNING :
High voltages are used to operate this projector. Do not attempt to open the cabinet.
If the problem still persists after following all operating instructions, contact the sales dealer where you
purchased the projector or the service center. Give the model number and explain the difficulty. We will advise
you how to obtain service.
This symbol on the nameplate means the product is Listed by Underwriters
Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety standards
against risk of fire, casualty and electrical hazards.
43
APPENDIX
TECHNICAL SPECIFICATIONS
Projector Type
Dimensions (W x H x D)
Net Weight
LCD Panel System
Panel Resolution
Number of Pixels
Color System
High Definition TV Signal
Scanning Frequency
Projection Image size (Diagonal)
Horizontal Resolution
Projection Lens
Throw Distance
Projection Lamp
AV Input Jacks
AV Audio Input Jacks
Computer Input Jacks
Computer Audio Input Jacks
Control Port Jacks
Monitor Output Jacks
Audio Output Jacks
Internal Audio Amp
Built-in Speakers
Feet Adjustment
Voltage and
Power Consumption
Operating Temperature
Storage Temperature
Remote Control Transmitter
Accessories
Desktop Projector 9280
12.44" x 6.57" x 18.9" (316mm x 167mm x 480mm)
20.3 lbs (9.2 kg)
1.3" TFT Active Matrix type, 3 panels
1024 x 768 dots
2,359,296 (1024 x 768 x 3 panels)
PAL, SECAM, NTSC, NTSC4.43, PAL-M and PAL-N
480i, 480p, 575i, 575p, 720p, 1035i, 1080i-50 and 1080i-60
H-sync. 15 ~ 100 KHz, V-sync. 50 ~ 100 Hz
Adjustable from 31” to 400”
700 TV lines
F 1.8 ~ 2.1 lens with f 48.4 mm ~ 62.5 mm with motor zoom, focus and shift
4.6’ ~ 47.2’ (1.4 m ~ 14.4 m)
250 W
RCA Type x 3 (Video/Y, Pb/Cb, Pr/Cr) and Mini DIN 4 pin x 1 (S-Video)
RCA Type x 2
(VGA) HDB 15 Terminal x 1, DVI 24 pin x 1, and BNC jack x 5
Mini Jack (stereo) x 2
Mini DIN 8 pin x 2
BNC jack x 5 (Computer) and RCA Type x 1(Video)
RCA Type x 2
2.0 W RMS (stereo)
2 speakers, 1.57" x 2.76" (40mm x 70mm)
0˚ to 9.0˚
AC 100 ~ 120 V (4.4 A Max. Ampere), 50 / 60 Hz (The U.S.A and Canada)
AC 200 ~ 240 V (2.2 A Max. Ampere), 50 / 60 Hz (Continental Europe and The U.K.)
41 ˚F ~ 95 ˚F (5 ˚C ~ 35 ˚C)
14 ˚F ~ 140 ˚F (-10 ˚C ~ 60 ˚C)
Power Source
Operating Range
Dimensions
Net Weight
Laser Pointer
:
:
:
:
:
Owner’s Manual
AC Power Cord
Wired/Wireless Remote Control Transmitter and Batteries
VGA Cable
MAC Adapter
Control Cable for PS/2 port
Control Cable for Serial port
Control Cable for ADB port
Video Cable (RCA x 3)
S-VIDEO Cable
Audio Cable (RCA x 2 - Mini plug (stereo))
Remote Control Cable
Dust Cover
Lens Cover
● The specifications are subject to change without notice.
44
AA, UM3 or R06 Type x 2
16.4’ (5m) / ±30˚
2.2” x 1.3” x 7.6” (55mm x 34mm x 192mm)
0.36 lbs (165 g) (including batteries)
Class II Laser (Max. Output : 1mW / Wave length : 650±20nm)
APPENDIX
CONFIGURATIONS OF THE TERMINALS
COMPUTER INPUT-1 TERMINAL (ANALOG)
Terminal : HDB15-PIN
Connect the display output terminal of the computer to this terminal with the VGA Cable (supplied). When connecting the
Macintosh computer, the MAC Adapter (supplied) is required.
Pin Configuration
4
5
10
15
14
2
3
9
8
13
1
7
12
6
11
1
2
3
4
5
6
7
8
Red Input
Green Input
Blue Input
Sense 2
Ground (Horiz.sync.)
Ground (Red)
Ground (Green)
Ground (Blue)
9
10
11
12
13
14
15
No Connect
Ground (Vert.sync.)
Sense 0
Sense 1
Horiz. sync.
Vert. sync.
Reserved
COMPUTER INPUT-1 TERMINAL (DIGITAL)
Terminal : DVI 24-pin
Connect the display output terminal of the computer to this terminal with the DVI cable (not supplied).
Pin Configuration
1
2
3
4
5
6
7
8
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
T.M.D.S. Data2–
T.M.D.S. Data2+
T.M.D.S. Data2 Shield
No Connect
No Connect
DDC Clock
DDC Data
No Connect
9
10
11
12
13
14
15
16
T.M.D.S. Data1–
T.M.D.S. Data1+
T.M.D.S. Data1 Shield
No Connect
No Connect
+5V Power
Ground (for +5V)
Hot Plug Detect
17
18
19
20
21
22
23
24
T.M.D.S. Data0–
T.M.D.S. Data0+
T.M.D.S. Data0 Shield
No Connect
No Connect
T.M.D.S. Clock Shield
T.M.D.S. Clock+
T.M.D.S. Clock–
CONTROL PORT CONNECTOR
Terminal : Mini DIN 8-PIN
Connect control port (PS/2, Serial or ADB port) on your computer to this terminal with the Control Cable (supplied).
Pin Configuration
8
5
1
2
3
4
5
6
7
8
7 6
4 3
2 1
PS/2
----CLK
DATA
GND
--------GND
-----
Serial
RXD
--------GND
RTS
TXD
GND
GND
ADB
----ADB
----GND
------------GND
MAC ADAPTER
Set the switches as shown in the table below depending on the RESOLUTION MODE that you want to use
before you turn-on the projector and computer.
1
ON
ON
DIP
1 2 3 4 5 6
OFF
2
3
4
5
6
13” MODE (640 x 480)
ON
ON OFF OFF OFF OFF
16” MODE (832 x 624)
OFF ON OFF ON OFF OFF
19” MODE (1024 x 768)
OFF ON
ON OFF OFF OFF
21” MODE (1152 x 870)
ON
ON
ON
ON OFF OFF
45
46
47
Warranty
Proxima Corporation warrants that the Proxima® Multimedia Projector product manufactured by Proxima is free from defects in materials and workmanship under normal use during the Warranty Period. The Warranty Period commences on the day
of purchase by the end-user. The Warranty Period is two years. The projector lamp
is not covered by this Warranty.
Each Proxima product is manufactured from new parts, or new and some used
parts. In some cases, the product may have been delivered to another end-user
and then returned. In all cases, the product has undergone testing and quality
inspection, and Proxima's full warranty terms apply.
The end-user's sales receipt or invoice showing the date of purchase of the product
and the name of the Reseller is proof of the date of purchase. The Warranty
extends only to the original purchaser and is not transferable.
During the Warranty Period, Proxima will, at no additional charge, repair or replace
defective parts or at the option of Proxima, replace the entire unit.
This Limited Warranty does not extend to any Proxima product that has been damaged or been rendered defective (a) as a result of accident, misuse, or other abuse;
(b) by the use of parts not manufactured or sold by Proxima; or (c) by modification
of the product; or (d) as a result servicing by non-authorized personnel.
Limitation of Warranties
The foregoing warranty is expressly in lieu of any other express or implied warranties, including, without limitation, warranties of merchantability or fitness for a
particular purpose. To the extent not prohibited by law, all statutory warranties are
hereby waived and excluded from this warranty. Proxima expressly disclaims all
warranties not stated in this Limited Warranty.
For Americas:
Proxima Corporation
9440 Carroll Park Drive
San Diego, CA 92121
Ph:
(858) 457-5500
(800) 447-7692 (U. S. and Canada.)
Fax. (858) 457-9647
www.proxima.com <http://www.proxima.com>
Part No. 710-00861
10 / 2000
610 xxx xxxx (1AA6P1Pxxxx-- MM6F)
For Europe, Asia, Africa, Australia:
ASK Proxima ASA
K. G. Meldahlsvei 9
Postboks 1403
N-1602 Fredrikstad
tel.
+47-69 34 01 55
fax.
+47-69 34 06 32
Technical Support & Service
Horsterweg 24
6191 RX Beek
The Netherlands
tel.
+31-43 358 5210
fax.
+31-43 358 5202
Printed in Japan
