Operating Instructions
High Definition Plasma Display
Model No.
TH-103PF12U
The illustration shown is an image.
Before connecting, operating or adjusting this product, please read these instructions completely.
Please keep this manual for future reference.
English
TQBC2518
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: To reduce the risk of electric shock, do not remove cover or back.
No user-serviceable parts inside. Refer servicing to qualified service personnel.
The lightning flash with
arrow-head within a triangle
is intended to tell the user
that parts inside the product
are a risk of electric shock
to persons.
The exclamation point within
a triangle is intended to
tell the user that important
operating and servicing
instructions are in the papers
with the appliance.
WARNING : To prevent damage which may result in fire or shock hazard, do not expose this apparatus to rain
or moisture.
Do not place containers with water (flower vase, cups, cosmetics, etc.) above the set.
(including on shelves above, etc.)
WARNING : 1) To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to
qualified service personnel.
2) Do not remove the grounding pin on the power plug. This apparatus is equipped with a three pin
grounding-type power plug. This plug will only fit a grounding-type power outlet. This is a safety feature.
If you are unable to insert the plug into the outlet, contact an electrician.
Do not defeat the purpose of the grounding plug.
2
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11) Only use attachments / accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart / apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged
in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15) To prevent electric shock, ensure the grounding pin on the AC cord power plug is securely connected.
3
Dear Panasonic Customer
Welcome to the Panasonic family of customers. We hope that you will have many years of enjoyment
from your new Plasma Display.
To obtain maximum benefit from your set, please read these Instructions before making any adjustments,
and retain them for future reference.
Retain your purchase receipt as well, and record the model number and serial number of your set in the
space provided on the rear cover of these instructions.
Visit our Panasonic Web Site
http://panasonic.net
Table of Contents
Important Safety Instructions.................................. 3
FCC STATEMENT ...................................................... 5
Safety Precautions ................................................... 6
Maintenance .............................................................. 7
Accessories .............................................................. 8
Accessories Supplied .............................................. 8
Remote Control Batteries ........................................ 8
Connections .............................................................. 9
AUDIO OUT Terminals connection .......................... 9
PC Input Terminals connection .............................. 10
SERIAL Terminals connection ................................11
HDMI connection .................................................... 12
COMPONENT / RGB connection .......................... 12
Power ON / OFF ..................................................... 13
Selecting the input signal ...................................... 15
Basic Controls ........................................................ 16
ASPECT Controls ................................................... 18
MULTI PIP ................................................................ 19
Digital Zoom ............................................................ 22
On-Screen Menu Displays ..................................... 23
Adjusting POS. /SIZE ............................................. 25
PICTURE Adjustments ........................................... 28
ADVANCED SETTINGS ........................................ 29
Picture Profiles ....................................................... 30
Saving profiles ....................................................... 31
Loading profiles ..................................................... 32
Editing profiles ....................................................... 32
Locking profiles ..................................................... 33
SOUND Adjustment ................................................ 35
SDI SOUND OUTPUT ........................................... 35
PRESENT TIME SETUP / SET UP TIMER .............. 36
PRESENT TIME SETUP ....................................... 36
SET UP TIMER ..................................................... 36
SCREENSAVER (For preventing image retention) .. 37
Setup of SCREENSAVER Time ............................ 38
Reduces screen image retention ...............................39
EXTENDED LIFE SETTINGS ............................... 39
4
Reduces power consumption ............................... 42
Customizing the Input labels................................. 43
Selecting the On-Screen Menu Language............ 43
DISPLAY ORIENTATION ......................................... 44
SET UP for MULTI DISPLAY ................................... 45
How to setup MULTI DISPLAY .............................. 45
ID Remote Control Function .................................. 46
MULTI PIP SETUP ................................................... 47
SET UP for PORTRAIT ........................................... 48
How to setup PORTRAIT ...................................... 48
SET UP for Input Signals ....................................... 50
COMPONENT / RGB IN SELECT ......................... 50
YUV / RGB IN SELECT ......................................... 50
SIGNAL menu ....................................................... 51
3D Y/C FILTER ...................................................... 51
COLOR SYSTEM / Panasonic AUTO ................... 52
3:2 PULLDOWN .................................................... 52
XGA MODE ........................................................... 52
REFRESH RATE ................................................... 53
NOISE REDUCTION ............................................. 53
SYNC .................................................................... 54
SDI THROUGH ..................................................... 54
Input signal display ................................................ 54
Options Adjustments ............................................. 55
Weekly Command Timer ....................................... 58
Shipping condition ................................................. 59
Troubleshooting ..................................................... 60
List of Aspect Modes ............................................. 61
Applicable input signals ........................................ 62
Command list of Weekly Command Timer ........... 64
Specifications ......................................................... 65
Panasonic Professional Flat Panel Display
Limited Warranty .................................................... 66
LIMITED WARRANTY STATEMENT ....................... 67
Customer Service ................................................... 68
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced technician for help.
This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions:(1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC CAUTION:
To assure continued compliance, follow the attached installation instructions and use only shielded interface
cables when connecting to computer or peripheral devices. Any changes or modifications not expressly
approved by Panasonic Corp. of North America could void the user's authority to operate this device.
FCC Declaration of Conformity
Model No. TH-103PF12U
Responsible Party:
Contact Source:
Panasonic Corporation of North America
One Panasonic Way 1F-10, Secaucus, NJ 07094
Panasonic Professional Display Company
Panasonic Plasma Concierge 1-800-973-4390
CANADIAN NOTICE:
This Class B digital apparatus complies with Canadian ICES-003.
Note:
Do not allow a still picture to be displayed for an extended period, as this can cause a permanent image retention to
remain on the Plasma Display.
Examples of still pictures include logos, video games, computer images, teletext and images displayed in 4:3 mode.
Trademark Credits
• VGA is a trademark of International Business Machines Corporation.
• Macintosh is a registered trademark of Apple Inc. USA.
• SVGA, XGA, SXGA and UXGA are registered trademarks of the Video Electronics Standard Association.
Even if no special notation has been made of company or product trademarks, these trademarks have been fully
respected.
• HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
5
Safety Precautions
CAUTION
This Plasma Display is for use only with the following optional accessories. Use with any other type of optional
accessories may cause instability which could result in the possibility of injury.
(All of the following accessories are manufactured by Panasonic Corporation.)
• Pedestal .................................................................. TY-ST103PF9
• Wall-hanging bracket (vertical) ................................ TY-WK103PV9
• Ceiling-haging bracket ............................................ TY-CE103PS10
• BNC Component Video Terminal Board .................. TY-42TM6A
• BNC Composite Video Terminal Board ................... TY-42TM6B
• BNC Dual Video Terminal Board ............................. TY-FB9BD
• RCA Component Video Terminal Board .................. TY-42TM6Z
• RCA Composite Video Terminal Board ................... TY-42TM6V
• RGB Active Through Terminal Board ...................... TY-42TM6G
• PC Input Terminal Board ......................................... TY-42TM6P
• Composite / Component Video Terminal Board ................ TY-42TM6Y
• BNC SDI Terminal Board ........................................ TY-FB7SD
• HD-SDI Terminal Board .......................................... TY-FB9HD
• HD-SDI Terminal Board with audio ......................... TY-FB10HD
• Dual Link HD-SDI Terminal Board........................... TY-FB11DHD
• HDMI Terminal Board .............................................. TY-FB8HM
• Dual HDMI Terminal Board ..................................... TY-FB10HMD
• DVI-D Terminal Board ............................................. TY-FB11DD
• Ir Through Terminal Board ...................................... TY-FB9RT
• Wireless Presentation Board .................................. TY-FB10WPU
• AV Terminal Box ...................................................... TY-TB10AV
• LAN Control Board .................................................. TY-FB12LC
Always be sure to ask a qualified technician to carry out set-up.
Small parts can present choking hazard if accidentally swallowed. Keep small parts away from young children. Discard
unneeded small parts and other objects, including packaging materials and plastic bags/sheets to prevent them from being
played with by young children, creating the potential risk of suffocation.
When using the Plasma Display
Do not bring your hands, face or objects close to the
ventilation holes of the Plasma Display.
• Top of the Plasma Display is usually very hot due to the
high temperature of exhaust air being released through the
ventilation holes. Burns or personal injuries can happen if any
body parts are brought too close. Placing any object near the
top of the display could also result in heat damages to the object
as well as to the Display if its ventilation holes are blocked.
Be sure to disconnect all cables before moving the Plasma Display.
• Moving the Display with its cables attached might damage
the cables which, in turn, can cause fire or electric shock.
Disconnect the power plug from the wall outlet as a
safety precaution before carrying out any cleaning.
• Electric shocks can result if this is not done.
6
Clean the power cable regularly to prevent it from
becoming dusty.
• Built-up dust on the power cord plug can increase humidity
which might damage the insulation and cause fire. Unplug
the cord from the wall outlet and clean it with a dry cloth.
This Plasma Display radiates infrared rays, therefore it
may affect other infrared communication equipment.
Install your infrared sensor in a place away from direct
or reflected light from your Plasma Display.
Note:
Do not allow a still picture to be displayed for an extended
period, as this can cause a permanent image retention to
remain on the Plasma Display.
Examples of still pictures include logos, video games, computer
images, teletext and images displayed in 4:3 mode.
Safety Precautions
WARNING
Setup
Do not place the Plasma Display on sloped or unstable
surfaces.
• The Plasma Display may fall off or tip over.
Do not place any objects on top of the Plasma Display.
• If water spills onto the Plasma Display or foreign objects get
inside it, a short-circuit may occur which could result in fire or
electric shock. If any foreign objects get inside the Plasma
Display, please consult an Authorized Service Center.
Do not cover the ventilation holes.
• Doing so may cause the Plasma Display to overheat,
which can cause fire or damage to the Plasma Display.
Transport only in upright position!
• Transporting the unit with its display panel facing upright or
downward may cause damage to the internal circuitry.
If using the pedestal (optional accessory), leave a space
of 12.0” (30 cm) or more at the top, left and right, and
8.0” (20 cm) or more at the rear, and also keep the space
between the bottom of the display and the floor surface.
If using some other setting-up method, follow the manual
of it. (If there is no specific indication of installation
dimension in the installation manual, leave a space of
12.0” (30 cm) or more at the top, bottom, left and right,
and 8.0” (20 cm) or more at the rear.)
An apparatus with CLASS I construction shall be
connected to a mains socket outlet with a protective
earthing connection.
AC Power Supply Cord
The Plasma Display is designed to operate on 200240 V AC, 50/60 Hz.
• Contact an electrician for the 200 V power supply
engineering.
Ensure that the mains plug is easily accessible.
Do not use any power supply cord other than that
provided with this unit.
• Doing so may cause fire or electric shocks.
Securely insert the power cord plug as far as it will go.
• If the plug is not fully inserted, heat may be generated
which could cause fire. If the plug is damaged or the
wall socket plate is loose, they should not be used.
Do not handle the power cord plug with wet hands.
• Doing so may cause electric shocks.
Do not do anything that might damage the power cable.
When disconnecting the power cable, hold the plug,
not the cable.
• Do not make any modifications, place heavy objects on,
place near hot objects, heat, bend, twist or forcefully
pull the power cable. Doing so may cause damage to
the power cable which can cause fire or electric shock.
If damage to the cable is suspected, have it repaired at
an Authorized Service Center.
If the Plasma Display will not be used for a long period
of time, unplug the power cord from the wall outlet.
If problems occur during use
If a problem occurs (such as no picture or no sound),
or if smoke or an abnormal odor is detected from the
Plasma Display, unplug the power cord immediately.
• Continuous use of the Display under these conditions
might cause fire or permanent damage to the unit.
Have the Display evaluated at an Authorized Service
Center. Services to the Display by any unauthorized
personnel are strongly discouraged due to its high
voltage dangerous nature.
If water or foreign objects get inside the Plasma Display,
if the Plasma Display is dropped, or if the cabinet
becomes damaged, disconnect the power cord plug
immediately.
• A short may occur, which could cause fire. Contact an
Authorized Service Center for any repairs that need to
be made.
Maintenance
The front of the display panel has been specially treated. Wipe the panel surface gently using only a cleaning
cloth or a soft, lint-free cloth.
• If the surface is particularly dirty, wipe with a soft, lint-free cloth which has been soaked in pure water or water in which
neutral detergent has been diluted 100 times, and then wipe it evenly with a dry cloth of the same type until the surface
is dry.
• Do not scratch or hit the surface of the panel with fingernails or other hard objects, otherwise the surface may become
damaged. Furthermore, avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise
the quality of the surface may be adversely affected.
If the cabinet becomes dirty, wipe it with a soft, dry cloth.
• If the cabinet is particularly dirty, soak the cloth in water to which a small amount of neutral detergent has been added
and then wring the cloth dry. Use this cloth to wipe the cabinet, and then wipe it dry with a dry cloth.
• Do not allow any detergent to come into direct contact with the surface of the Plasma Display. If water droplets get
inside the unit, operating problems may result.
• Avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the cabinet
surface may be adversely affected or the coating may peel off. Furthermore, do not leave it for long periods in contact
with articles made from rubber or PVC.
7
Accessories
Accessories Supplied
Check that you have the Accessories and items shown
Operating
Instruction book
Remote Control Transmitter
EUR7636070R
AC cord
Allen wrench
Batteries for the
Remote Control
Transmitter
(AA Size × 2)
Eyebolt cap × 3
Fixing bands × 2
Blind sheet × 1
Remote Control Batteries
Requires two AA batteries.
1. Pull and hold the hook, then
open the battery cover.
2. I n s e r t b a t t e r i e s - n o t e c o r r e c t
polarity ( + and -).
3. Replace the cover.
+
-
+
-
“AA” size
Helpful Hint:
For frequent remote control users, replace old batteries with Alkaline batteries for longer life.
Precaution on battery use
Incorrect installation can cause battery leakage and corrosion that will damage the remote control transmitter.
Disposal of batteries should be in an environment-friendly manner.
Observe the following precautions:
1. Batteries should always be replaced as a pair. Always use new batteries when replacing the old set.
2. Do not combine a used battery with a new one.
3. Do not mix battery types (example: “Zinc Carbon” with “Alkaline”).
4. Do not attempt to charge, short-circuit, disassemble, heat or burn used batteries.
5. Battery replacement is necessary when the remote control acts sporadically or stops operating the Plasma Display.
6. Do not burn or breakup batteries.
Batteries must not be exposed to excessive heat such as sunshine, fire or the like.
8
Connections
AUDIO OUT Terminals connection
R
L
AUDIO OUT
Stereophonic sound code
audio equipment
AC cord connection (see page 13)
line-in
– AC cord fixing
Unplug the AC cord
Close
Push until
the hook clicks.
1 Plug the AC cord into
Open
the display unit.
Plug the AC cord until
it clicks.
2 Fix the AC cord with
the clamper.
Note:
Make sure that the
AC cord is locked on both
the left and right sides.
– Cable fixing bands
2. Pull off.
1. Keep the
knob pressed.
Unplug the
AC cord
pressing the
two knobs.
Note:
When disconnecting the AC
cord, be absolutely sure to
disconnect the AC cord plug
at the socket outlet first.
Secure any excess cables with bands as required.
Note:
Two fixing bands are supplied with this unit. In case of securing cables at four positions, please purchase it separately.
Pass the attached cable To secure cables connected to Terminals, wrap the cable fixing band around them then
fixing band through the pass the pointed end through the locking block, as shown in the figure.
clip as shown in the While ensuring there is sufficient slack in cables to minimize stress (especially
in the power cord), firmly bind all cables with the supplied fixing band.
figure.
To loosen:
Push the catch
To tighten:
Pull
2
1
Pull
R AUDIO
L
PR/CR/R
PB/CB/B
Y/G
R
AUDIO
L
COMPONENT/RGB IN
SLOT1
Optional Terminal
Board Insert Slot
(covered)
SLOT2
Dual HDMI Terminals
(equivalent of Dual
HDMI Terminal Board
(TY-FB10HMD))
(see page 12)
SLOT3
COMPONENT/RGB IN and
Audio IN Terminals (equivalent
of BNC Component Video
Terminal Board (TY-42TM6A))
(see page 12)
PC
IN
From EXTERNAL
monitor terminal
on Computer
(see page 10)
SERIAL
From SERIAL
Terminal on
Computer
(see page 11)
AUDIO OUT
From input
on audio
amplifier
(see page 9)
Note: At factory shipment, Terminal boards are installed in SLOT 2 and SLOT 3.
9
Connections
PC Input Terminals connection
(Female)
COMPUTER
AUDIO
PC IN
Conversion adapter
(if necessary)
Mini D-sub 15p
RGB
PC cable
(Male)
Audio
Stereo plug
Connect a cable which matches
the audio output terminal on the computer.
Notes:
• With regard to the typical PC input signals that are described in the applicable input signals list (see page 62), adjustment
values such as for the standard picture positions and sizes have already been stored in this unit. You can add up to eight
PC input signal types that are not included in the list.
• Computer signals which can be input are those with a horizontal scanning frequency of 15 to 110 kHz and vertical scanning
frequency of 48 to 120 Hz. (However, the image will not be displayed properly if the signals exceed 1,200 lines.)
• The display resolution is a maximum of 1,440 × 1,080 dots when the aspect mode is set to “4:3”, and 1,920 × 1,080
dots when the aspect mode is set to “FULL”. If the display resolution exceeds these maximums, it may not be possible
to show fine detail with sufficient clarity.
• The PC input terminals are DDC2B-compatible. If the computer being connected is not DDC2B-compatible, you will need
to make setting changes to the computer at the time of connection.
• Some PC models cannot be connected to the set.
• There is no need to use an adapter for computers with DOS/V compatible Mini D-sub 15P terminal.
• The computer shown in the illustration is for example purposes only.
• Additional equipment and cables shown are not supplied with this set.
• Do not set the horizontal and vertical scanning frequencies for PC signals which are above or below the specified
frequency range.
• Component Input is possible with the pin 1, 2, 3 of the Mini D-sub 15P Connector.
• Change the “COMPONENT/RGB-IN SELECT” setting in the “SET UP” menu to “COMPONENT”
(when COMPONENT signal connection) or “RGB” (when RGB signal connection). (see page 50)
Signal Names for Mini D-sub 15P Connector
Pin No.
5
4
10 9
3
2
8
1
7
1
6
15 14 13 12 11
Pin Layout for PC Input
Terminal
10
2
3
4
5
Signal Name
R (PR/CR)
G (Y)
B (PB/CB)
NC (not connected)
GND (Ground)
Pin No.
6
7
8
9
10
Signal Name
GND (Ground)
GND (Ground)
GND (Ground)
+5 V DC
GND (Ground)
Pin No.
11
12
13
14
15
Signal Name
NC (not connected)
SDA
HD/SYNC
VD
SCL
Connections
SERIAL Terminals connection
The SERIAL terminal is used when the Plasma Display is controlled by a computer.
(Male)
COMPUTER
1
2
6
3
7
4
8
5
9
SERIAL
RS-232C Straight cable
Pin layout for SERIAL Terminal
(Female)
D-sub 9p
Notes:
• Use the RS-232C straight cable to connect the computer
to the Plasma Display.
• The computer shown is for example purposes only.
• Additional equipment and cables shown are not supplied
with this set.
The SERIAL terminal conforms to the RS-232C interface
specification, so that the Plasma Display can be controlled
by a computer which is connected to this terminal.
The computer will require software which allows the
sending and receiving of control data which satisfies the
conditions given below. Use a computer application such as
programming language software. Refer to the documentation
for the computer application for details.
Signal names for D-sub 9P connector
Details
Pin No.
2
3
5
4 • 6
7
8
1 • 9
RXD
TXD
GND
Non use
(Shorted in this set)
NC
These signal names are those of computer specifications.
Communication parameters
Signal level
Synchronization method
Baud rate
Parity
Character length
Stop bit
Flow control
RS-232C compliant
Asynchronous
9600 bps
None
8 bits
1 bit
-
Basic format for control data
The transmission of control data from the computer starts with
a STX signal, followed by the command, the parameters, and
lastly an ETX signal in that order. If there are no parameters,
then the parameter signal does not need to be sent.
STX
C1 C2 C3
Start
(02h)
:
P1 P2 P3 P4 P5
ETX
Colon
Parameter(s)
(1 - 5 bytes)
3-character
command (3 bytes)
End
(03h)
Notes:
• If multiple commands are transmitted, be sure to wait for
the response for the first command to come from this unit
before sending the next command.
• If an incorrect command is sent by mistake, this unit will
send an “ER401” command back to the computer.
• SL1A, SL1B, SL2A and SL2B of Command IMS are available
only when a dual input terminal board is attached.
Command
Command
PON
POF
AVL
AMT
Parameter
None
None
**
0
1
None
SL1
SL2
SL3
PC1
SL1A
SL1B
SL2A
SL2B
None
ZOOM
FULL
JUST
NORM
SELF
SJST
SNOM
SFUL
ZOM2
Control details
Power ON
Power OFF
Volume 00 - 63
Audio MUTE OFF
Audio MUTE ON
IMS
Input select (toggle)
Slot1 input
Slot2 input
Slot3 input
PC input
Slot1 input (INPUT1A)
Slot1 input (INPUT1B)
Slot2 input (INPUT2A)
Slot2 input (INPUT2B)
DAM
Screen mode select (toggle)
ZOOM (For Video/SD/PC signal)
FULL
JUST (For Video/SD signal)
4:3 (For Video/SD/PC signal)
Panasonic Auto (For Video signal)
JUST (For HD signal)
4:3 (For HD signal)
H-FILL (For HD signal)
ZOOM (For HD signal)
With the power off, this display responds to PON command only.
11
Connections
HDMI connection
This unit has terminal boards equivalent to Dual HDMI Terminal Board (TY-FB10HMD) and BNC Component Video Terminal
Board (TY-42TM6A) as standard equipment.
[Pin assignments and signal names]
Pin No.
1
2
3
4
5
6
7
8
9
10
Signal
T.M.D.S Data2+
T.M.D.S Data2
Shield
T.M.D.S Data2T.M.D.S Data1+
T.M.D.S Data1
Shield
T.M.D.S Data1T.M.D.S Data0+
T.M.D.S Data0
Shield
T.M.D.S Data0T.M.D.S Clock+
Pin No.
11
Signal
T.M.D.S Clock
Shield
12
T.M.D.S Clock-
13
CEC
R AUDIO
L
PR/CR/R PB/CB/B
Y/G
COMPONENT/RGB IN
Reserved
(N.C. on device)
14
15
16
SLOT1
SLOT2
SLOT3
SCL
SDA
DDC/CEC
Ground
+5V Power
Hot Plug Detect
17
18
19
HDMI cables
3 1
19
HDMI
AV OUT
HDMI
AV OUT
DVD player
DVD player
4 2
18
Note:
Additional equipment and HDMI cables shown
are not supplied with this set.
COMPONENT / RGB connection
COMPONENT VIDEO OUT
PR
Example of input signal source
DVD
Y, PB, PR,
OUT
RCA-BNC
adapter
plug
PB
Y
Digital TV-SET-TOP-BOX
(DTV-STB)
L
AUDIO
OUT R
R AUDIO
L
PR/CR/R PB/CB/B
Y/G
COMPONENT/RGB IN
SLOT3
Computer
RGB Camcorder
or
Notes:
• Change the “COMPONENT/RGB-IN SELECT” setting in the “SET UP” menu to “COMPONENT”
(when COMPONENT signal connection) or “RGB” (when RGB signal connection). (see page 50)
• Additional equipment, cables and adapter plugs shown are not supplied with this set.
• SYNC ON G signal is needed. (see page 54)
12
PC
Power ON / OFF
Connecting the AC cord plug to the Plasma Display.
Fix the AC cord plug securely to the Plasma Display
with the clamper. (see page 9)
Connecting the plug to the Wall Outlet.
Note:
When disconnecting the AC cord, be absolutely sure to
disconnect the AC cord plug at the socket outlet first.
Right side surface
Press the Power switch on the Plasma Display to turn the
set on: Power-On.
Main Power
On / Off Switch
Power Indicator: Green
Remote Control
Sensor
Press the
Power Indicator
button on the remote control to turn the Plasma Display off.
Power Indicator: Red (standby)
Press the
button on the remote control to turn the Plasma Display on.
Power Indicator: Green
Turn the power to the Plasma Display off by pressing the
when the Plasma Display is on or in standby mode.
switch on the unit,
Note:
During operation of the power management function, the power indicator turns
orange in the power off state.
13
Power ON / OFF
When first switching on the unit
Following screen will be displayed when the unit is turned on for the first time.
Select the items with the remote control. Unit buttons are invalid.
OSD LANGUAGE
English (UK)
OSD LANGUAGE
Deutsch
1
Select the language.
Français
Italiano
Español
2
Set.
ENGLISH (US)
Русский
PRESENT TIME SETUP
SELECT
1
Select “DAY” or “PRESENT TIME OF DAY”.
2
Setup “DAY” or “PRESENT TIME OF DAY”.
SET
PRESENT TIME SETUP
1
Select “SET”.
2
Set.
PRESENT TIME OF DAY MON 99:99
SET
MON
DAY
99:99
PRESENT TIME OF DAY
PRESENT TIME SETUP
PRESENT TIME OF DAY MON 99:99
SET
TUE
DAY
10:00
PRESENT TIME OF DAY
DISPLAY ORIENTATION
1
For vertical installation, select “PORTRAIT”.
2
Set.
DISPLAY ORIENTATION
LANDSCAPE
PORTRAIT
Notes:
• Once the items are set, the screens won't be displayed when switching on the unit next time.
• After the setting, the items can be changed in the following menus.
OSD LANGUAGE (see page 43)
PRESENT TIME SETUP (see page 36)
DISPLAY ORIENTATION (see page 44)
From the second time on, the below screen is displayed for a while (setting condition is an example).
PC
FULL
NANODRIFT
14
Selecting the input signal
Select the input signals to be connected by installing the optional Terminal Boards.
Press to select the input signal to be played back from the
equipment which has been connected to the Plasma Display.
Input signals will change as follows:
INPUT1
INPUT2A
INPUT2B
INPUT3
PC
SLOT2 is for dual input so that you can select INPUT2A or
INPUT2B for INPUT2.
INPUT2A : HDMI signal terminal in SLOT2
INPUT2B : HDMI signal terminal in SLOT2
Press the INPUT “1”, “2”, “3” or “PC”
input mode selection button to select
the INPUT mode.
to switch the input mode
Press
between INPUT2A and INPUT2B.
ENTER/
+/
VOL
-/
MENU
INPUT
Notes:
• Selecting is also possible by pressing the INPUT button on the unit.
• Input terminal will not be selected if the terminal board is not installed into the SLOT.
• Select to match the signals from the source connected to the component/RGB input terminals.
(see page 50)
• In 2 screen display, the same input mode cannot be selected for the main picture and sub
picture.
• Image retention (image lag) may occur on the plasma display panel when a still picture is kept
on the panel for an extended period. The function that darkens the screen slightly is activated
to prevent image retention (see page 60), but this function is not the perfect solution to image
retention.
15
Basic Controls
Main Unit
Right side
surface
ENTER/
+
/
VOL
-
Remote control sensor
Power Indicator
The Power Indicator will light.
• Power-OFF ...... Indicator not illuminated
(The unit will still consume
some power as long as the
power cord is still inserted
into the wall outlet.)
• Standby ........... Red
Orange (When “Slot power” is
set to “On”. See page 57)
Orange (Depending on the
type of the function board
installed, when the power is
supplied to the slot)
• Power-ON ........ Green
• DPMS (POWER MANAGEMENT)
................... Orange (With PC input signal.
See page 42)
16
/
Enter / Aspect button
(see page 18, 23)
Volume Adjustment
Volume Up “+” Down “–”
When the menu screen is displayed:
“+” : press to move the cursor up
“–” : press to move the cursor down
(see page 23)
MENU
INPUT
MENU Screen ON / OFF
Each time the MENU button is pressed, the menu
screen will switch. (see page 23)
Normal Viewing
SOUND
POS. /SIZE
INPUT button
(INPUT signal selection)
(see page 15)
Main Power On / Off Switch
SETUP
Basic Controls
Remote Control Transmitter
R button (see page 23)
Press the R button to return to previous menu screen.
Standby (ON / OFF) button
The Plasma Display must first be plugged into the wall
outlet and turned on at the power switch (see page 13).
Press ON to turn the Plasma Display On, from Standby
mode. Press OFF to turn the Plasma Display Off to
Standby mode.
Status button
Press the “Status” button to display
the current system status.
1 Input label
2 Aspect mode (see page 18)
NANODRIFT SAVER operating
(see page 40)
3 Off timer
The off timer indicator is displayed only
when the off timer has been set.
4 Clock display (see page 57)
4:3
1
2
90
3
PC
NANODRIFT
N button
(see page 27, 28, 29, 35)
4
POSITION buttons
OFF TIMER
SET UP button (see page 23)
ACTION button
Press to make selections.
SOUND button (see page 35)
POS. /SIZE button
(see page 25)
DIRECT INPUT buttons
Press the INPUT “1”, “2”, “3” or “PC”
input mode selection button to select
the INPUT mode. (see page 15)
This button is used to switch directly
to INPUT mode.
PICTURE button
(see page 28)
INPUT button
Press to select INPUT1, INPUT2,
INPUT3 and PC input SLOTS
sequentially. (see page 15)
When a dual input terminal board
is attached, A or B is displayed
depending on the selected input
signal. (Ex. INPUT1A, INPUT1B)
Channel Adjustment
This button cannot be used for this model.
Volume Adjustment
Press the Volume Up “+” or Down
“–” button to increase or decrease
the sound volume level.
Sound mute On / Off
Press this button to mute the sound.
Press again to reactivate sound.
Sound is also reactivated when power is
turned off or volume level is changed.
OFF TIMER button
The Plasma Display can be preset
to switch to stand-by after a fixed
period. The setting changes to 30
minutes, 60 minutes, 90 minutes and
0 minutes (off timer cancelled) each
time the button is pressed.
Numeric buttons
(see page 46)
ASPECT button
Press to adjust the aspect.
(see page 18)
SURROUND button
The surround setting switches on
and off each time the SURROUND
button is pressed.
The benefits of surround sound
are enormous. You can be
completely enveloped in sound;
just as if you were at a concert
hall or cinema.
10:00
30
60
90
0
When three minutes remain, “OFF
TIMER 3” will flash.
The off timer is cancelled if a power
interruption occurs.
ON
OFF
Remote ID lock (see page 46)
Digital Zoom (see page 22)
SURROUND
ON
MULTI Window buttons
(see page 19)
17
ASPECT Controls
The Plasma Display will allow you to enjoy viewing the picture at its maximum size, including wide screen cinema format
picture.
Note:
Be aware that if you put the display in a public place for commercial purposes or a public showing and
then use the aspect mode select function to shrink or expand the picture, you may be violating the
copyright under copyright law. It is prohibited to show or alter the copyrighted materials of other people
for commercial purposes without the prior permission of the copyright holder.
Press repeatedly to move through the aspect options:
For details about the aspect mode, please see “List of Aspect Modes” (page 61).
For VIDEO (S VIDEO) signal input:
4:3
ZOOM
Panasonic AUTO
JUST
FULL
Note:
When selecting an input slot that attaches BNC Dual Video Terminal
Board (TY-FB9BD), Panasonic AUTO cannot be selected.
[from the unit]
Right side surface
ENTER/
+
/
VOL
-
The aspect mode changes each time the ENTER button is pressed.
/
For PC signal input:
4:3
ZOOM
FULL
For SD signal input (525 (480) / 60i • 60p, 625 (575) / 50i • 50p):
4:3
ZOOM
FULL
JUST
For HD signal input [1125 (1080) / 60i • 50i • 60p • 50p • 24p • 25p • 30p • 24sF, 1250 (1080) / 50i, 750 (720) / 60p • 50p]:
4:3
H-FILL
ZOOM
FULL
JUST
[During MULTI PIP Operations]
4:3
FULL
• Picture and Picture, Picture in Picture :
• Others
: Aspect switching is not possible.
Notes:
• Panasonic AUTO can be selected only during Video signal input.
• The aspect mode is memorized separately for each input terminal.
• Do not allow the picture to be displayed in 4:3 mode for an extended period, as this can cause a permanent image
retention to remain on the Plasma Display Panel.
Panasonic AUTO
The display will automatically become enlarged (depending on the picture source), allowing you to view the picture at its maximum size.
4
16
Panasonic AUTO
3
For letter box image
9
Image is expanded
4
3
Changes in accordance with
the Panasonic AUTO mode
setting (see page 52).
For a 4:3 image
Notes:
• Panasonic AUTO mode is designed to automatically adjust the
aspect ratio to handle a mix of 16:9 and 4:3 program material.
Certain 4:3 program material, such as stock market data screens,
may occasionally cause the image size to change unexpectedly.
When viewing such programs, it is recommended that the ASPECT
be set to 4:3.
• If adjusting the PICTURE V-POS/V-SIZE in Panasonic AUTO with
FULL mode, the adjustment is not memorized. When exiting the
mode, the screen will return to a former adjustment.
All Aspect mode
Set “All Aspect” to “On” in Options menu to enable the extended aspect mode (page 57). When All Aspect mode, the aspect
mode of pictures is switched as follows. For details about the aspect mode, please see “List of Aspect Modes” (page 61).
For VIDEO (S VIDEO) signal input:
4:3
Zoom1
Zoom2
Zoom3
Panasonic Auto
16:9
14:9
Just
Notes:
• When selecting an input slot that attaches BNC Dual Video Terminal Board (TY-FB9BD), Panasonic Auto cannot be selected.
• In All Aspect mode, “Panasonic AUTO” is displayed as “Panasonic Auto”.
18
ASPECT Controls
For PC signal input:
4:3
Zoom
16:9
For SD signal input (525 (480) / 60i • 60p, 625 (575) / 50i • 50p):
4:3
Zoom1
Zoom2
Zoom3
16:9
14:9
Just
For HD signal input [1125 (1080) / 60i • 50i • 60p • 50p • 24p • 25p • 30p • 24sF, 1250 (1080) / 50i, 750 (720) / 60p • 50p]:
4:3 Full
Zoom1
Zoom2
Zoom3
16:9
14:9
Just1
Just2
4:3 (1)
4:3 (2)
MULTI PIP
You can display two pictures, such as a video image and computer image, in a two-screen display. (Use the remote control
for this operation. It cannot be performed with the buttons on the main unit.)
MULTI PIP SETUP
Set the functions and mode for two-screen display in “MULTI PIP SETUP” in the SET UP menu.
(see page 47)
Selecting the Display Mode
Each time this button is pressed, the screen changes.
Note:
The screen changes in the same way when “DISPLAY MODE” in “MULTI PIP SETUP” is changed. (see page 47)
During PIP:
During Advanced PIP:
One screen
Two screens (P AND P)
PC
INPUT1
Sub screen
input mode
Main screen
Two screens (P IN P)
INPUT1
PC
Advanced PIP
One screen
Main screen
input mode
–
1
Sub screen Main screen
2
3
Sub screen
4
Two screens (P OUT P)
INPUT1
PC
8
Note:
and
7
6
5
button operations are not available during
advanced PIP.
19
MULTI PIP
During Blend PIP (Composite Screen Function) :
A composite picture is displayed with the sub screen positioned over the main screen. For example, text data such as a
computer image can be displayed as a caption over a movie or still image.
One screen
FULL
P IN P
Transparent Function and Insertion Function
Two functions are available for blend PIP: the transparent function and the insertion function. Set these functions with
“TRANSPARENCY” or “INSERT” in “MULTI PIP SETUP”. (see page 47)
Transparent Function
Data such as text are displayed transparently on the
background image.
Insertion Function
The sub screen image is divided into transparent and nontransparent areas, and only the non-transparent areas are
inserted and displayed on the background image.
Note:
Be aware that if you put the display in a public place for commercial purposes or a public showing and then use the blend
PIP function to make a composite screen display, you may be violating the copyright under copyright law. It is prohibited
to show or alter the copyrighted materials of other people for commercial purposes without the prior permission of the
copyright holder.
Swapping Screens
Each time this button is pressed, the main screen and sub screen are swapped.
Two screens
(P AND P)
Main screen
20
Sub screen
Two screens
(P OUT P)
Two screens
(P IN P)
MULTI PIP
Selecting the Target Screen for Operations
Each time this button is pressed, the target screen for operations changes.
Operations on
the main screen
Operations on
the sub screen
INPUT1
PC
INPUT1
PC
Main screen
Sub screen
Main screen input mode
Sub screen input mode
Notes:
• When operations are performed for the sub screen, the sub screen audio is played.
• If no operations are performed, the operation target returns to the main screen after about 5 seconds*.
You can also return to main screen operations by operating the remote control buttons (except for
).
* It takes more than 5 seconds if a slot mounted with a Dual HDMI Terminal Board (TY-FB10HMD) is selected.
Selecting the Sub Screen Position (During P IN P Display)
Each time this button is pressed, the sub screen position changes.
Note:
Some sub screen positions may hide the display of the menu screen.
Notes:
• Do not use the two-screen display for a long time. It will cause a permanent image retention to remain on the screen.
• If “INPUT lock” in Options menu is set to other than “Off”, MULTI PIP function isn’t available.
• Sound output is from the picture which is selected in AUDIO OUT (PIP) (see page 35).
• In two-screen display, the same input mode cannot be selected for the main picture and sub picture.
• The main picture and sub picture are processed by different circuits, resulting in a slight difference in the clarity of the
pictures. There may also be a difference in the picture quality of the sub picture depending on the type of signals displayed
on the main picture and depending on the two-screen display mode.
• Due to the small dimensions of the sub pictures, these sub pictures cannot be shown in detail.
• Computer screen picture is displayed in a simplified format, and it may not be possible to discern details on them satisfactorily.
• Following combinations of two analog signals cannot be displayed simultaneously;
Component - Component, Component - PC (RGB), PC (RGB) - Component, PC (RGB) - PC (RGB)
• 2k1k signals that are received with the Dual Link HD-SDI Terminal Board (TY-FB11DHD) cannot be displayed in two-screen
display.
21
Digital Zoom
This displays an enlargement of the designated part of the displayed image.
1
Display the operation guide.
Press to access Digital Zoom.
The operation guide will be displayed.
EXIT
1
During Digital Zoom, only the following buttons can be operated.
[Remote control]
POSITION / ACTION
button
[Unit]
Right side surface
ENTER/
+
VOL button
-
VOL button
/
MENU
MUTE button
INPUT
SURROUND button
OFF TIMER button
2
/
VOL
Select the area of the image to be enlarged.
Press on the enlargement location to select.
The cursor will move.
EXIT
2
3
Select the magnification required for the enlarged display.
Each time this is pressed, the magnification factor changes.
This is shown in the image being displayed.
s1
4
s2
Return to normal display (quit Digital Zoom).
Press to exit from the Digital Zoom.
Notes:
• When power goes OFF (including “Off Timer” operation), Digital Zoom terminates.
• The Digital Zoom function cannot be selected while in the following operation state:
“Multi-viewer” (P AND P, P OUT P, P IN P) operation. (see page 19)
When MULTI DISPLAY SETUP is ON (see page 45).
When PORTRAIT SETUP is ON (see page 48).
When SCREENSAVER (except for NEGATIVE IMAGE) is running. (see page 37)
• While Digital Zoom is in operation, “Adjusting POS. /SIZE” cannot be used.
22
s3
s4
On-Screen Menu Displays
Remote Control
1 Display the menu screen.
Unit
MENU
Press to select.
(Example: PICTURE menu)
2 Select the item.
Select.
Press several times.
Each time the MENU button is pressed, the
menu screen will switch.
Normal Viewing
SET UP
SOUND
POS. /SIZE
ENTER/
Press.
NORMALIZE NORMAL
PICTURE MENU
BRIGHTNESS
COLOR
TINT
SHARPNESS
COLOR TEMP
COLOR MANAGEMENT
ADVANCED SETTINGS
STANDARD
25
0
0
0
5
NORMAL
OFF
+
/
VOL
-
(Example:
PICTURE menu)
Select.
/
MEMORY SAVE
MEMORY LOAD
MEMORY EDIT
Set.
3 Set.
ENTER/
+
/
VOL
-
4 Exit the menu.
Press.
Set.
/
MENU
Press several times.
Press.
Press
to return to the previous menu.
23
On-Screen Menu Displays
Overview
Note: Menu that cannot be adjusted is grayout. Adjustable menu changes depending on signal, input and menu setting.
POS. /SIZE
[ VIDEO ]
SIGNAL
SET UP
NORMALIZE NORMAL
AUTO SETUP
H-POS
H-SIZE
V-POS
V-SIZE
DOT CLOCK
CLOCK PHASE
1:1 PIXEL MODE
1/2
SIGNAL
SCREENSAVER
EXTENDED LIFE SETTINGS
COMPONENT/RGB-IN SELECT
RGB
PC
INPUT LABEL
POWER SAVE
OFF
STANDBY SAVE
OFF
POWER MANAGEMENT
OFF
AUTO POWER OFF
OFF
OSD LANGUAGE
ENGLISH (US)
0
0
0
0
0
0
OFF
(see page 25-27)
3D Y/C FILTER (NTSC)
COLOR SYSTEM
3 : 2 PULLDOWN
Panasonic AUTO (4 : 3)
REFRESH RATE
NOISE REDUCTION
ON
AUTO
OFF
4:3
100 Hz
OFF
(see page 51-54)
SCREENSAVER
PRESENT TIME OF DAY 99:99
START
SCROLLING BAR ONLY
FUNCTION
OFF
MODE
(see page 37, 38)
EXTENDED LIFE SETTINGS
EXPRESS SETTINGS
CUSTOM SETTINGS
RESET
SET UP
2/2
MULTI DISPLAY SETUP
MULTI PIP SETUP
PORTRAIT SETUP
SET UP TIMER
PRESENT TIME SETUP
DISPLAY ORIENTATION LANDSCAPE
(see page 36-54)
MULTI DISPLAY SETUP
HORIZONTAL SCALE
VERTICAL SCALE
SEAM HIDES VIDEO
LOCATION
AI-SYNCHRONIZATION
OFF
×2
×2
OFF
A1
OFF
(see page 45, 46)
MULTI PIP SETUP
1/2
SOUND
NORMALIZE NORMAL
PICTURE MENU
BRIGHTNESS
COLOR
TINT
SHARPNESS
COLOR TEMP
COLOR MANAGEMENT
ADVANCED SETTINGS
(see page 39-41)
MULTI DISPLAY SETUP
STANDARD
25
0
0
0
5
NORMAL
OFF
MULTI PIP
DISPLAY MODE
TRANSPARENCY
TRANSPARENCY LEVEL
INSERT
INSERT LEVEL
NORMALIZE NORMAL
BASS
MID
TREBLE
BALANCE
SURROUND
AUDIO OUT (PIP)
SDI SOUND OUTPUT
MEMORY SAVE
MEMORY LOAD
MEMORY EDIT
LEFT CHANNEL
RIGHT CHANNEL
SOUND OUT
LEVEL METER
(see page 28, 29)
0
0
0
0
OFF
MAIN
BLEND PIP
—
OFF
0%
OFF
1
(see page 47)
2/2
CHANNEL 1
CHANNEL 1
OFF
OFF
(see page 35)
PORTRAIT SETUP
PORTRAIT SETUP
SEAM HIDES VIDEO
VIEWING AREA
LOCATION
AI-SYNCHRONIZATION
OFF
OFF
16:9
1
OFF
(see page 48, 49)
SET UP TIMER
PRESENT TIME OF DAY 99:99
ADVANCED SETTINGS
POWER ON FUNCTION
POWER ON TIME
POWER OFF FUNCTION
POWER OFF TIME
NORMALIZE NORMAL
BLACK EXTENSION
INPUT LEVEL
GAMMA
AGC
W/B HIGH R
W/B HIGH G
W/B HIGH B
W/B LOW R
W/B LOW G
W/B LOW B
0
0
2.2
OFF
0
0
0
0
0
0
(see page 28, 29)
24
OFF
0:00
OFF
0:00
(see page 36)
PRESENT TIME SETUP
PRESENT TIME OF DAY MON 99:99
SET
MON
DAY
99:99
PRESENT TIME OF DAY
(see page 36)
Adjusting POS. /SIZE
1
2
3
Press to display the POS. /SIZE menu.
Press to select the menu to adjust.
During “VIDEO (S VIDEO)”, “Digital”,
“SDI” and “HDMI” input signal.
POS. /SIZE
NORMALIZE NORMAL
AUTO SETUP
H-POS
H-SIZE
V-POS
V-SIZE
1:1 PIXEL MODE
Press to adjust the menu.
0
0
0
0
OFF
During “COMPONENT”, “RGB”
and “PC” input signal.
POS. /SIZE
4
NORMALIZE NORMAL
AUTO SETUP
Press to exit from adjust mode.
H-POS
H-SIZE
V-POS
V-SIZE
DOT CLOCK
CLOCK PHASE
1:1 PIXEL MODE
0
0
0
0
0
0
Notes:
• Unadjustable items are grayed out.
OFF
Adjustable items differ depending on the input signal and the display mode.
• Adjustment details are memorized separately for different input signal formats.
(Adjustments for component signals are memorized for 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 1125 (1080) / 60i ·
50i · 60p · 50p · 24p · 25p · 30p · 24sF, 1250 (1080) / 50i, 750 (720) / 60p · 50p each, and RGB/PC/Digital signals are
memorized for each frequency.)
• If a “Cue” or “Rew” signal from a VCR or DVD player is received, the picture position will shift up or down. This picture
position movement cannot be controlled by the POS. /SIZE function.
• If adjusting the PICTURE V-POS / V-SIZE in Panasonic AUTO with FULL mode, the adjustment is not memorized. When
exiting the mode, the screen will return to a former adjustment.
AUTO
SETUP
H-POS/V-POS, H-SIZE/V-SIZE, DOT CLOCK and CLOCK PHASE are automatically adjusted when the
RGB or PC signal is received.
This setting is enabled under the following conditions:
• This setting only support single screen display. Two screen display or multiple display are not supported.
• When “COMPONENT/RGB-IN SELECT” or “YUV/RGB-IN SELECT” in the “SET UP” menu (see page 52)
is set to “RGB”, this setting is enabled.
• When the signal is not PC format, this setting is enabled only if “OVER SCAN” (see page 26) is “OFF” or
“1:1 PIXEL MODE” (see page 27) is “ON”, and H-SIZE/V-SIZE is not automatically adjusted.
This setting will be invalid and will not work under the following conditions:
• Aspect is set to “JUST”
• “Display size” in the Options menu (see page 56) is set to “On”
Using Remote Control
Note:
To operate this function, please purchase remote controller sold separately.
Object model : N2QAYB000432
When
on the remote control is pressed, “AUTO SETUP” will be executed.
When AUTO SETUP does not work, “INVALID” is displayed.
Auto mode
When the “Auto Setup“ is set to “Auto” in the Options menu (see page 57), automatic position adjustment starts:
• When the display power is turned ON.
• When the input signal is switched.
25
Adjusting POS. /SIZE
Notes:
• If the dot clock frequency is 162 MHz or higher, DOT CLOCK and CLOCK PHASE cannot be made.
• When digital RGB signal input, DOT CLOCK and CLOCK PHASE cannot be made.
• AUTO SETUP may not work when a cropped or dark image is input. In such case, switch to a bright image
with borders and other objects are clearly shown, and then try auto setup again.
• Depending on the signal, out of alignment may occur after AUTO SETUP. Carry out fine tuning for the
position/size as required.
• If AUTO SETUP cannot set properly for vertical frequency 60Hz XGA signal (1024×768@60Hz,
1280×768@60Hz, and 1366×768@60Hz), pre-selecting the individual signal in “XGA MODE” (see page
52) may results in correct AUTO SETUP.
• AUTO SETUP does not work well when a signal such as additional information is superimposed out of
valid image period or intervals between synchronizing and image signals are short, or for image signal with
tri-level synchronizing signal added.
• If AUTO SETUP cannot adjust correctly, select “NORMALIZE” once and press ACTION ( ) then adjust
POS. /SIZE manually.
H-POS
Adjust the horizontal position.
V-POS
Adjust the vertical position.
H-SIZE
Adjust the horizontal size.
V-SIZE
Adjust the vertical size.
DOT
CLOCK
(During “COMPONENT”, “RGB” and “PC” input signal)
Periodic striped pattern interference (noise) may occur when a striped pattern is displayed. If this happens,
adjust so that any such noise is minimized.
CLOCK
PHASE
(During “COMPONENT”, “RGB” and “PC” input signal)
Eliminate the flickering and distortion.
OVER
SCAN
Turn image over scan ON/OFF.
Configurable signals are as follows:
525i, 525p, 625i, 625p, 750/60p, 750/50p (Component Video, RGB, DVI, SDI, HDMI)
ON
OFF
Notes:
• When “OFF” is set, “H-SIZE” and “V-SIZE” cannot be adjusted.
• When the “Display size” is set to “On” in the Options menu, this setting will be invalid. (see page 56)
26
Adjusting POS. /SIZE
1:1 PIXEL MODE Adjusts the display size when 1125i, 1125p or 1250i signal is input.
Notes:
• Select ON when you would like to replay 1920 × 1080 input signal.
• Applicable input signal;
1125 (1080) / 50i · 60i · 24sF · 24p · 25p · 30p · 50p · 60p, 1250 (1080) / 50i
• Select OFF when flickering is shown around the image.
• H-SIZE and V-SIZE cannot be adjusted when ON is selected.
OFF
ON
1:1 PIXEL MODE When the input signal is a 2k1k signal (2048×1080 / 24p, 2048×1080 / 24sF), the display size is
(2k1k)
adjusted as follows.
(For 2k1k signals)
OFF
ON (LEFT)
ON (CENTER)
ON (RIGHT)
Note:
2k1k signals can only be received when the Dual Link HD-SDI Terminal Board (TY-FB11DHD) is installed.
Helpful Hint (
/
NORMALIZE
Normalization)
While the POS. /SIZE display is active, if either the N button on the remote control is pressed at any time or the ACTION
( ) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.
27
PICTURE Adjustments
1
Press to display the PICTURE menu.
2
Select to adjust each item.
Press to select the menu to adjust.
Select the desired level by looking at the picture behind the menu.
Note:
Menu that cannot be adjusted is grayout. Adjustable menu changes depending on signal, input
and menu setting.
Press the left or right
STANDARD
MONITOR
NORMALIZE NORMAL
PICTURE MENU
BRIGHTNESS
COLOR
TINT
SHARPNESS
COLOR TEMP
COLOR MANAGEMENT
ADVANCED SETTINGS
STANDARD
25
0
0
0
5
NORMAL
OFF
button to switch between modes.
DYNAMIC
CINEMA
STANDARD
For viewing in standard (evening lighting) environments.
This menu selects the normal levels of BRIGHTNESS
and PICTURE.
DYNAMIC
For viewing in brighter environments.
This menu selects higher than normal levels of
BRIGHTNESS and PICTURE.
CINEMA
Ideal for movies.
Press to enter Advanced
Settings.
ADVANCED SETTINGS
Enables fine picture adjustment at a professional
level (see next page).
ADVANCED SETTINGS
NORMALIZE NORMAL
0
0
BLACK EXTENSION
INPUT LEVEL
GAMMA
AGC
W/B HIGH R
W/B HIGH G
W/B HIGH B
W/B LOW R
W/B LOW G
W/B LOW B
2.2
OFF
0
0
0
0
0
0
MONITOR
For use when creating broadcast or movie content. With
this picture, even if the overall average picture level (APL)
changes, the brightness of areas with the same signal
level does not change.
Notes:
● When “MONITOR” is selected in PICTURE MENU, the
following menu items cannot be set.
PICTURE menu: PICTURE
EXTENDED LIFE SETTINGS: PEAK LIMIT (see page 40)
SET UP menu: POWER SAVE (see page 42)
MULTI DISPLAY SETUP menu: AI-SYNCHRONIZATION (see page 46)
PORTRAIT SETUP menu: AI-SYNCHRONIZATION (see page 49)
● If you would like to change the picture and color of the
selected PICTURE menu to something else, adjust using
the items in the PICTURE menu. (see next page)
Press the left or right
NORMAL
button to switch between modes.
COOL
WARM
COLOR MANAGEMENT ON
Enables vivid color adjustment automatically.
Helpful Hint (
/
NORMALIZE
Normalization)
While the “PICTURE” menu is displayed, if either the N button on the remote control is pressed at any time or the ACTION
( ) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.
28
PICTURE Adjustments
Item
BRIGHTNESS
COLOR
TINT
SHARPNESS
Effect
Adjustments
Less
More
Darker
Brighter
Less
More
Reddish
Greenish
Less
More
Adjusts the proper picture contrast.
Adjusts for easier viewing of dark pictures
such as night scenes and black hair.
Adjusts color saturation.
Adjusts for natural flesh tones.
Adjusts picture sharpness.
Notes:
• “COLOR” and “TINT” settings cannot be
adjusted for “RGB/PC” input signal.
• You can change the level of each function
(PICTURE, BRIGHTNESS, COLOR, TINT,
SHARPNESS) for each PICTURE MENU.
• The setting details for STANDARD, DYNAMIC
and CINEMA respectively are memorized
separately for each input terminal.
• The “TINT” setting can be adjusted for NTSC signal
only during “VIDEO (S VIDEO)” input signal.
• In PICTURE, there is not a noticeable change
even when contrast is increased with a bright
picture or reduced with a dark picture.
ADVANCED SETTINGS
Item
BLACK
EXTENSION
INPUT
LEVEL
GAMMA
AGC
W/B HIGH R
W/B HIGH G
W/B HIGH B
W/B LOW R
W/B LOW G
W/B LOW B
Effect
Details
Less
More
Less
More
Down
Up
OFF
ON
Less
More
Less
More
Less
More
Less
More
Less
More
Less
More
Adjusts the dark shades of the image in gradation.
Adjustment of parts which are extremely bright and hard to see.
S+ CURVE*1
S CURVE
2.0
2.2
2.5
2.6*2
*1 When “PICTURE MENU” is set to “DYNAMIC”, GAMMA “S+ CURVE” can be
selected. When 2k1k signals are received with the Dual Link HD-SDI Terminal
Board (TY-FB11DHD), “S+ CURVE” cannot be selected.
*2 When 2k1k signals are received with the Dual Link HD-SDI Terminal Board (TYFB11DHD), GAMMA “2.6” can also be selected.
Increases the brightness of dark signal automatically.
Adjusts the white balance for light red areas.
Adjusts the white balance for light green areas.
Adjusts the white balance for light blue areas.
Adjusts the white balance for dark red areas.
Adjusts the white balance for dark green areas.
Adjusts the white balance for dark blue areas.
Notes:
• Carry out “W/B” adjustment as follows.
1. Adjust the white balance of the bright sections using the “W/B HIGH R” , “W/B HIGH G” and “W/B HIGH B” settings.
2. Adjust the white balance of the dark sections using the “W/B LOW R” , “W/B LOW G” and “W/B LOW B” settings.
3. Repeat steps 1 and 2 to adjust.
Steps 1 and 2 affect each other’s settings, so repeat each step in turn to make the adjustment.
• The adjustment values are memorized separately for each input terminal.
• The adjustment range values should be used as an adjustment reference.
Helpful Hint (
/
NORMALIZE
Normalization)
On the remote control unit, while the “ADVANCED SETTINGS” menu is displayed, if either the N button is pressed at any time
or the ACTION ( ) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.
29
Picture Profiles
Up to 8 combinations of picture adjustment values (in the PICTURE menu and ADVANCED SETTINGS) can be stored in
the display memory as profiles and applied as needed, for a convenient way to enjoy your preferred picture settings.
NORMALIZE NORMAL
PICTURE MENU
BRIGHTNESS
COLOR
TINT
SHARPNESS
COLOR TEMP
COLOR MANAGEMENT
ADVANCED SETTINGS
CINEMA
18
0
0
0
3
NORMAL
OFF
Save profiles (page 31)
MEMORY SAVE
MEMORY LOAD
MEMORY EDIT
NORMALIZE NORMAL
PICTURE MENU
BRIGHTNESS
COLOR
TINT
SHARPNESS
COLOR TEMP
COLOR MANAGEMENT
ADVANCED SETTINGS
Load profiles (page 32)
Edit profiles (page 32)
Options
1/3
Weekly Command Timer
Memory lock
Onscreen display
Initial INPUT
Initial VOL level
Maximum VOL level
INPUT lock
Button lock
Remocon User level
Save profiles
Lock profiles (page 33, 34)
Save the picture adjustment
values in the MEMORY1
profile
On
Off
Off
0
Off
0
Off
Off
Off
Edit the profile
Delete or rename
the profile
MY PICTURE
MEMORY2
MEMORY3
MEMORY4
MEMORY1
MEMORY2
MEMORY3
MEMORY4
Locked profile
MEMORY8
MEMORY8
Load the profile
Original picture
Custom picture
NORMALIZE NORMAL
PICTURE MENU
BRIGHTNESS
COLOR
TINT
SHARPNESS
COLOR TEMP
COLOR MANAGEMENT
ADVANCED SETTINGS
30
CINEMA
25
0
0
0
5
NORMAL
OFF
Apply the MEMORY1
profile
NORMALIZE NORMAL
STANDARD
0
0
0
0
0
NORMAL
OFF
PICTURE MENU
BRIGHTNESS
COLOR
TINT
SHARPNESS
COLOR TEMP
COLOR MANAGEMENT
ADVANCED SETTINGS
CINEMA
25
0
0
0
5
NORMAL
OFF
Picture Profiles
Saving profiles
Follow these steps to save picture adjustment values as profiles.
Note:
When the settings are locked in “EXTENDED LIFE SETTINGS”, profiles cannot be saved.
1
Specify the picture quality in the PICTURE menu and
ADVANCED SETTINGS. (see page 28, 29)
2
In the PICTURE menu, select “MEMORY SAVE”.
MEMORY SAVE
1 select
MEMORY LOAD
MEMORY EDIT
3
5
2 access
A
N
a
n
0
!
_
Select a profile name for saving the picture adjustment
values.
1 select
MEMORY SAVE
1. [
2. [
3. [
4. [
]
]
]
]
C
P
c
p
2
#
|
D
Q
d
q
3
$
~
E
R
e
r
4
%
<
F
S
f
s
5
&
>
MEMORY1█
G H I
T U V
g h i
t u v
6 7 8
’
+
(
)
[
J
W
j
w
9
–
]
K
X
k
x
L M ALL DELETE
Y Z
DELETE
l m
y z
SPACE
/ = ? @ \
ˆ
{
}
,
.
;
:
CANCEL
2 set
2 set
MEMORY1
MEMORY2
MEMORY3
MEMORY4
Example: Specifying “MY PICTURE”
1 Select “ALL DELETE”.
MEMORY1█
All text is deleted.
To delete individual characters, select “DELETE”.
2 Select “M”.
M█
Repeat this process to enter the next character.
3 Select “Y”.
Select “OK”.
1 select
MEMORY SAVE
MY█
4
SAVE THE ADJUSTED VALUE IN MEMORY1
OK
B
O
b
o
1
”
`
OK
Profiles are labeled with these icons to indicate their
locked status. (see page 33)
[ ], [ ]:Settings can be saved in this profile.
[ ], [ ]:Settings cannot be saved in this profile.
4
Enter a name for the profile.
[Entering profile names]
Profile names can be up to 16 characters.
To enter text, select characters in the on-screen
keyboard.
Edit the default profile name in the text box as
desired.
MEMORY NAME INPUT
1 select
CANCEL
Select “SPACE”.
MY
2 set
6
█
When you finished entering the profile name, select
“OK”.
To cancel saving the profile, select “CANCEL”.
1 select
MEMORY NAME INPUT
A
N
a
n
0
!
_
B
O
b
o
1
”
`
C
P
c
p
2
#
|
D
Q
d
q
3
$
~
E
R
e
r
4
%
<
OK
MY PICTURE█
F G H I
S T U V
f g h i
s t u v
5 6 7 8
& ’
+
> (
)
[
J
W
j
w
9
–
]
K
X
k
x
L M ALL DELETE
Y Z
DELETE
l m
y z
SPACE
/ = ? @ \
ˆ
{
}
,
.
;
:
CANCEL
2 set
31
Picture Profiles
Loading profiles
Load profiles and apply the picture adjustment values to the display as follows.
Notes:
• Loaded profiles are stored in memory according to the selected input interface (SLOT1, 2, 3 or PC IN). (see page 15)
• When the settings are locked in “EXTENDED LIFE SETTINGS”, profiles cannot be loaded.
1
In the PICTURE menu, select “MEMORY LOAD”.
1 select
MEMORY SAVE
MEMORY LOAD
MEMORY EDIT
2
Select the profile to load.
1 select
MEMORY LOAD
1. [ ]
2. [ ]
3. [ ]
2 access
MEMORY1
MEMORY2
MEMORY3
2 set
Profiles are labeled with these icons to indicate their
locked status. (see page 33)
Editing profiles
Delete or rename profiles as follows.
<Deleting profiles>
Note:
Locked profiles cannot be deleted.
<Renaming profiles>
Note:
Locked profiles cannot be renamed.
1
1
In the PICTURE menu, select “MEMORY EDIT”.
1 select
MEMORY SAVE
MEMORY LOAD
MEMORY EDIT
2
2
Select “MEMORY DELETE”.
Select “MEMORY NAME CHANGE”.
3
MEMORY1
MEMORY2
MEMORY3
ALL DELETE
MEMORY NAME CHANGE
1. [ ]
2. [ ]
3. [ ]
2 set
4
MEMORY1
MEMORY2
MEMORY3
4
Enter a name for the profile.
Entering profile names
page 31
A
N
a
n
0
!
_
1 select
MEMORY DELETE
DELETE THE MEMORY1 DATA.
OK
CANCEL
1 select
2 set
1 select
MEMORY NAME INPUT
Select “OK”.
2 set
Select the profile to rename.
1 select
MEMORY DELETE
1 select
MEMORY DELETE
MEMORY NAME CHANGE
2 set
Select the profile to delete.
To delete all profiles, select “ALL DELETE”.
2 access
MEMORY EDIT
1 select
MEMORY DELETE
MEMORY NAME CHANGE
1. [ ]
2. [ ]
3. [ ]
MEMORY LOAD
MEMORY EDIT
2 access
MEMORY EDIT
3
In the PICTURE menu, select “MEMORY EDIT”.
1 select
MEMORY SAVE
B
O
b
o
1
”
`
C
P
c
p
2
#
|
D
Q
d
q
3
$
~
E
R
e
r
4
%
<
OK
F
S
f
s
5
&
>
█EMORY1
M
G H
T U
g h
t u
6 7
’
(
)
I
V
i
v
8
+
[
J
W
j
w
9
–
]
K
X
k
x
L M ALL DELETE
Y Z
DELETE
l m
y z
SPACE
/ = ? @ \
ˆ
{
}
,
.
;
:
CANCEL
2 set
2 set
5
When you finished entering the profile name, select “OK”.
To cancel renaming the profile, select “CANCEL”.
CANCEL
OK
1 select
2 set
32
Picture Profiles
Locking profiles
You can lock saved profiles to restrict operations when the profiles are loaded. You can also set passwords.
Notes:
• When the lock is set in “EXTENDED LIFE SETTINGS”, profile cannot be locked.
• If profile is locked, the menu operations of “EXTENDED LIFE SETTINGS” are restricted. (see page 40)
<Locking and unlocking profiles>
Display the menu screen. (see page 55)
1
2
4
Select “Ok”.
Input password
Select “Memory lock”.
Options
1/3
1 select
Ok
Weekly Command Timer
Memory lock
Onscreen display
Initial INPUT
Initial VOL level
Maximum VOL level
INPUT lock
Button lock
Remocon User level
3
1 select
Cancel
2 access
2 set
On
Off
Off
0
Off
5
0
Off
Select the profile and specify the desired lock setting.
1 select
Memory lock
2 adjust
MEMORY1
MEMORY2
MEMORY3
MEMORY4
Off
Off
Enter a 4-digit password.
The default password is “0123”.
Lock1
Off
Off
Off
Off
isf Mode
Change password
6
Exit the menu.
Once a profile is locked, the following operations are restricted when the profile is loaded.
Setting
Editing the Profile Editing Picture Adjustment Values via the Menu Saving Picture Adjustment Values
(MEMORY EDIT) (PICTURE menu, ADVANCED SETTINGS)
(MEMORY SAVE)
Off (unlocked) Allowed
Allowed
Allowed
Lock1
Prohibited
Prohibited (picture adjustment values Allowed
are shown)
Lock2
Prohibited
Prohibited (picture adjustment values Prohibited
are hidden)
Loading locked profiles…
In the PICTURE menu, profiles are labeled with these icons to indicate their locked status.
NORMALIZE NORMAL
PICTURE MENU
STANDARD
25
Picture adjustment values in the PICTURE menu cannot be changed, except for the “PICTURE MENU”. Once you edit
the “PICTURE MENU” setting, you can edit “PICTURE”, “BRIGHTNESS”, and other picture adjustment values.
Lock1
Picture adjustment values are shown.
NORMALIZE NORMAL
PICTURE MENU
BRIGHTNESS
COLOR
TINT
SHARPNESS
COLOR TEMP
COLOR MANAGEMENT
ADVANCED SETTINGS
Lock2
Picture adjustment values are hidden.
NORMALIZE NORMAL
STANDARD
25
0
0
0
5
NORMAL
OFF
Can be
specified.
Cannot be
specified.
PICTURE MENU
BRIGHTNESS
COLOR
TINT
SHARPNESS
COLOR TEMP
COLOR MANAGEMENT
ADVANCED SETTINGS
STANDARD
Can be
specified.
Cannot be
specified.
33
Picture Profiles
<Changing passwords>
1
2
Follow steps 1–4 in the previous procedure,
<Locking and unlocking profiles>.
3
Enter a new 4-digit password.
4
Select “Ok”.
Select “Change password”.
1 select
Memory lock
MEMORY1
MEMORY2
MEMORY3
MEMORY4
Lock1
2 access
Off
Off
Off
Ok
Off
isf Mode
Change password
5
Exit the menu.
Note:
Make a note of the new password to remember it.
<isf Mode Setting>
Switches to “PICTURE MENU” mode display.
1
2
Follow steps 1–4 in the previous procedure,
<Locking and unlocking profiles>.
Select “isf Mode”.
1 select
2 adjust
Memory lock
MEMORY1
MEMORY2
MEMORY3
MEMORY4
Lock1
Off
Off
Off
Off
isf Mode
Change password
3
4
Specify “On” or “Off”.
Exit the menu.
Specifying “On” for isf Mode changes the “PICTURE MENU” mode display as follows.
“PICTURE MENU” mode display
NORMALIZE NORMAL
PICTURE MENU
BRIGHTNESS
34
1 select
Input new password
STANDARD
25
0
isf Mode: Off
STANDARD
DYNAMIC
CINEMA
MONITOR
isf Mode: On
STANDARD
isf Mode DAY
isf Mode NIGHT
MONITOR
Cancel
2 set
SOUND Adjustment
1
1/2
SOUND
Press to display the SOUND menu.
NORMALIZE NORMAL
2
BASS
MID
TREBLE
BALANCE
SURROUND
AUDIO OUT (PIP)
Select to adjust each item.
Press to select the menu to adjust.
Select the desired level by listening to the sound.
3
0
0
0
0
OFF
MAIN
Press to exit from adjust mode.
Item
BASS
MID
TREBLE
BALANCE
SURROUND
Details
Adjusts low pitch sounds.
Adjusts normal sounds.
Adjusts pitch sound.
Adjusts left and right volumes.
Select ON or OFF.
MAIN: Selects main picture sound.
SUB: Selects PIP frame sound.
INPUT1
PC
A
AUDIO OUT (PIP)
B
INPUT1
PC
A
B
Musical note ♪ is displayed on right side of the audio output screen label.
Helpful Hint (
/
NORMALIZE
Normalization)
While the “SOUND” menu is displayed, if either the N button on the remote control is pressed at any time or the ACTION
( ) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.
SDI SOUND OUTPUT
This menu is displayed when HD-SDI Terminal Board with audio (TY-FB10HD) or Dual Link HD-SDI Terminal Board (TYFB11DHD) is installed to the unit.
SDI SOUND OUTPUT
LEFT CHANNEL
RIGHT CHANNEL
SOUND OUT
LEVEL METER
2/2
CHANNEL 1
CHANNEL 1
OFF
OFF
Notes:
• This menu is available only when selecting a
slot that HD-SDI Terminal Board with audio
(TY-FB10HD) or Dual Link HD-SDI Terminal
Board (TY-FB11DHD)is installed.
• This menu is unavailable when 2-picture
display mode is active.
Item
Details
CHANNEL 1 to CHANNEL 16
LEFT CHANNEL Selects left audio channel.
CHANNEL 1 to CHANNEL 16
RIGHT CHANNEL Selects right audio channel.
SOUND OUT
LEVEL METER
OFF
ON
ON: Enables audio output.
OFF: Disables audio output.
1-8CH
9-16CH
OFF
Sets audio channels to show in the audio level meter.
8 channels are displayed in the audio level meter; 4 channels
each on both right and left sides of the display.
OFF: Hides the audio level meter.
1-8CH: Displays the audio level meter (1-8ch)
9-16CH: Displays the audio level meter (9-16ch)
35
PRESENT TIME SETUP / SET UP TIMER
The timer can switch the Plasma Display ON or OFF.
Before attempting Timer Set, confirm the PRESENT TIME OF DAY and adjust if necessary. Then set POWER ON TIME /
POWER OFF TIME.
1
2
Press to display the SET UP menu.
Press to select SET UP TIMER or PRESENT TIME SETUP.
Press to display the SET UP TIMER screen or PRESENT
TIME SETUP screen.
SET UP
2/2
MULTI DISPLAY SETUP
MULTI PIP SETUP
PORTRAIT SETUP
SET UP TIMER
PRESENT TIME SETUP
DISPLAY ORIENTATION LANDSCAPE
PRESENT TIME SETUP
1
Press to select DAY or PRESENT TIME OF DAY.
2
Press to select SET.
PRESENT TIME SETUP
PRESENT TIME OF DAY MON 99:99
Press to set up DAY or PRESENT TIME OF DAY.
SET
button: Forward
MON
DAY
button: Back
99:99
PRESENT TIME OF DAY
Notes:
• Pressing “ ” or “ ” button once changes PRESENT TIME OF DAY 1 minute.
• Pressing “ ” or “ ” button continuously changes PRESENT TIME OF DAY by 15 minutes.
Press to store PRESENT TIME SETUP.
Notes:
• SET cannot be selected unless PRESENT TIME OF DAY is set.
• Unless setting the present time other than “99:99”, DAY setting is invalid.
• The settings of “DAY” and “PRESENT TIME OF DAY” are reset when leaving the display turned
off for about 7 days for the following reasons:
Pressing
switch of the unit to turn off the display.
Disconnecting the AC cord.
Interruption of power supply.
SET UP TIMER
1
Press to select POWER ON TIME / POWER OFF TIME.
button: Forward
button: Back
2
SET UP TIMER
Press to set up POWER ON TIME / POWER OFF TIME.
PRESENT TIME OF DAY 99:99
POWER ON FUNCTION
POWER ON TIME
POWER OFF FUNCTION
POWER OFF TIME
Notes:
• Pressing “ ” or “ ” button once changes POWER ON TIME
/ POWER OFF TIME 1 minute.
• Pressing “ ” or “ ” button continuously changes POWER ON TIME / POWER OFF
TIME by 15 minutes.
Press to select POWER ON FUNCTION / POWER OFF FUNCTION.
Press to select ON.
Note:
Timer function will not work unless “PRESENT TIME OF DAY” is set.
36
OFF
0:00
OFF
0:00
SCREENSAVER (For preventing image retention)
Do not display a still picture, especially in 4:3 mode, for any length of time.
If the display must remain on, a SCREENSAVER should be used.
1
SET UP
Press to select the SCREENSAVER.
2
Press to select the SCREENSAVER screen.
3
1/2
Press to display the SET UP menu.
FUNCTION selection
Press to select the FUNCTION.
Press to select the desired function.
NEGATIVE IMAGE
WHITE SCREEN
SCROLLING BAR ONLY
OVERLAY SCROLLING BAR
SIGNAL
SCREENSAVER
EXTENDED LIFE SETTINGS
COMPONENT/RGB-IN SELECT
RGB
PC
INPUT LABEL
POWER SAVE
OFF
STANDBY SAVE
OFF
POWER MANAGEMENT
OFF
AUTO POWER OFF
OFF
OSD LANGUAGE
ENGLISH (US)
SCREENSAVER
PRESENT TIME OF DAY 99:99
START
SCROLLING BAR ONLY
FUNCTION
OFF
MODE
NEGATIVE IMAGE
: A negative image will be displayed on the screen.
SCROLLING BAR ONLY : A white bar will scroll from left to right. The image won't be displayed.
OVERLAY SCROLLING BAR : The brightness of the image will be decreased and a white bar
will scroll on it.
WHITE SCREEN
: The whole screen will be white.
Note: OVERLAY SCROLLING BAR is not effective during two screen display.
4
5
MODE selection
Press to select the
MODE.
Press to select each
mode items.
Off
INTERVAL
: Operates when SHOW DURATION and SAVER
DURATION are set up and those times arrive.
TIME OF DAY
: Operates when START TIME and FINISH TIME
are set up and those times arrive.
STANDBY AFTER SCR SAVER: Operates while SCREENSAVER DURATION,
and display enters standby mode.
ON
: Operates when START is selected and the
ACTION ( ) button is pressed.
START setting
When the MODE is set to ON, press to select START.
Press to start SCREENSAVER.
The menu screen will disappear and the SCREENSAVER will be activated. To stop the
SCREENSAVER under ON, press the R button or any buttons on the main unit.
Note: When the display is turned off, the SCREENSAVER will be deactivated.
37
SCREENSAVER (For preventing image retention)
Setup of SCREENSAVER Time
After selecting TIME OF DAY, INTERVAL or STANDBY AFTER SCR SAVER, the relevant Time Setup will become available
for selection and the Operating Time may be set. (Time cannot be set when “MODE” is “ON” or “OFF”.)
Press to select START TIME / FINISH TIME (when TIME OF
DAY is selected).
Press to select SHOW DURATION / SAVER DURATION
(when INTERVAL is selected).
Press to select SCREENSAVER DURATION (when
STANDBY AFTER SCR SAVER is selected).
Press to setup.
button: Forward
button: Back
Notes:
• Pressing “ ” or “ ” button once changes the Time 1 minute.
[However, switching occurs every 15 minutes when Periodic Time is selected.]
• Pressing “ ” or “ ” button continuously changes the Time by 15 minutes.
• “SCREENSAVER DURATION” of the “STANDBY AFTER SCR SAVER” can
be set from 0:00 to 23:59. When this is set to “0:00”, “STANDBY AFTER
SCR SAVER” will not be activated.
Note: Timer function will not work unless “PRESENT TIME OF DAY” is set.
38
SCREENSAVER
PRESENT TIME OF DAY 15:00
START
SCROLLING BAR ONLY
FUNCTION
TIME OF DAY
MODE
6:15
START TIME
12:30
FINISH TIME
SCREENSAVER
PRESENT TIME OF DAY 15:00
START
SCROLLING BAR ONLY
FUNCTION
INTERVAL
MODE
12:00
SHOW DURATION
3:00
SAVER DURATION
SCREENSAVER
PRESENT TIME OF DAY 15:00
START
SCROLLING BAR ONLY
FUNCTION
STANDBY AFTER SCR SAVER
MODE
6:15
SCREENSAVER DURATION
Reduces screen image retention
EXTENDED LIFE SETTINGS
The following settings are setup to reduce image retention:
SET UP
1/2
SIGNAL
SCREENSAVER
EXTENDED LIFE SETTINGS
COMPONENT/RGB-IN SELECT
RGB
PC
INPUT LABEL
POWER SAVE
OFF
STANDBY SAVE
OFF
POWER MANAGEMENT
OFF
AUTO POWER OFF
OFF
OSD LANGUAGE
ENGLISH (US)
EXTENDED LIFE SETTINGS
Set to the recommended value
Set individually
Reset to the factory settings
EXPRESS SETTINGS
CUSTOM SETTINGS
RESET
EXTENDED LIFE SETTINGS
RECOMMENDED SETTINGS
PICTURE MENU
SIDE BAR ADJUST
NANODRIFT SAVER
PEAK LIMIT
LOCK SETTINGS
APPLY TO CURRENT INPUT
APPLY TO ALL INPUTS
DYNAMIC
30
BRIGHT
HIGH MID
OFF
UNLOCK
Image Retention Reduction Menu
Image Retention Reduction Menu
“EXTENDED LIFE SETTINGS” enables you to set the following 5 menus (Image Retention Reduction Menu) as
recommended values or set them individually.
PICTURE MENU
“PICTURE MENU” and “PICTURE” are same as “PICTURE” menu items (see page 28). The settings of this menu will be
reflected to the “PICTURE” menu.
SIDE BAR ADJUST
Do not display a picture in 4:3 mode for an extended period,
as this can cause an image retention to remain on the side
bars on either side of the display field.
To reduce the risk of such an image retention, illuminate the
side bars.
side bars
4:3 mode
retention
This function may be applicable to the non-picture area.
OFF:
DARK:
MID:
BRIGHT:
Non picture area
Darken both ends.
Make it dark gray.
Make it gray.
Make it light gray.
P OUT P
P AND P
Notes:
• To reduce the occurrence of image retention, set the SIDE BAR ADJUST to BRIGHT.
• The side bar may flash (alternate black/white) depending on the picture being shown on the screen. Using Cinema mode
will reduce such flashing.
39
Reduces screen image retention
NANODRIFT SAVER
Moves the display position of the screen slightly to reduce image retention on the display panel.
OFF:
NANODRIFT SAVER does not operate.
MIN–MAX: NANODRIFT SAVER operates. The display position of the screen moves at set time intervals. You can set
the screen movement range. Some of the screen may appear to be missing as a result of this operation.
If you change the value, a mask is displayed in the range where the picture is missing as a result of position
movement.
If this is set to other than “OFF”, “NANODRIFT” is displayed below the aspect
mode display.
PC
FULL
NANODRIFT
Note:
This function does not work in the following cases.
When “MULTI DISPLAY SETUP” is set to “ON”
When “PORTRAIT SETUP” is set to “ON”
When in digital zoom mode
PEAK LIMIT
ON: Suppresses image contrast (peak brightness).
Note: When a still picture is viewed for an extended time, the screen may become slightly darker. (see page 60)
EXTENDED LIFE SETTINGS when profile is locked
If profile is locked with “Memory lock” of the Options menu, the operations of this settings menu are restricted
as shown below. “Locking profiles”
page 33
EXPRESS SETTINGS: Cannot be set.
CUSTOM SETTINGS: “PICTURE MENU”, “PICTURE” and “LOCK SETTINGS” cannot be set.
RESET:
“PICTURE MENU” and “PICTURE” are not reset.
EXPRESS SETTINGS
Set the “Image Retention Reduction” menu to the recommended settings.
All menus will be locked.
PICTURE MENU: STANDARD
PICTURE: 10
SIDE BAR ADJUST: BRIGHT
NANODRIFT SAVER: HIGH MID
PEAK LIMIT: ON
1 Select “EXPRESS SETTINGS”.
EXTENDED LIFE SETTINGS
EXPRESS SETTINGS
CUSTOM SETTINGS
RESET
2 Select the input to apply the settings.
EXTENDED LIFE SETTINGS
APPLY TO CURRENT INPUT
APPLY TO ALL INPUTS
40
1 select
2 access
3 Select “YES”.
EXTENDED LIFE SETTINGS
APPLY TO CURRENT INPUT
YES
1 select
2 set
1 select
NO
2 set
Reduces screen image retention
CUSTOM SETTINGS
Set the individual “Image Retention Reduction” menu.
1 Select “CUSTOM SETTINGS”.
EXTENDED LIFE SETTINGS
EXPRESS SETTINGS
CUSTOM SETTINGS
RESET
1 select
2 access
set each menu to the recommended setting:
2 To
Select “RECOMMENDED SETTINGS”.
EXTENDED LIFE SETTINGS
1 select
RECOMMENDED SETTINGS
PICTURE MENU
SIDE BAR ADJUST
NANODRIFT SAVER
PEAK LIMIT
LOCK SETTINGS
APPLY TO CURRENT INPUT
APPLY TO ALL INPUTS
3
DYNAMIC
30
BRIGHT
HIGH MID
OFF
UNLOCK
2 set
RECOMMENDED SETTINGS
PICTURE MENU
SIDE BAR ADJUST
NANODRIFT SAVER
PEAK LIMIT
LOCK SETTINGS
APPLY TO CURRENT INPUT
APPLY TO ALL INPUTS
DYNAMIC
30
BRIGHT
HIGH MID
OFF
UNLOCK
RECOMMENDED SETTINGS
PICTURE MENU
SIDE BAR ADJUST
NANODRIFT SAVER
PEAK LIMIT
LOCK SETTINGS
APPLY TO CURRENT INPUT
APPLY TO ALL INPUTS
DYNAMIC
30
BRIGHT
HIGH MID
OFF
LOCK
DYNAMIC
30
0
0
0
5
NORMAL
OFF
PICTURE MENU
BRIGHTNESS
COLOR
TINT
SHARPNESS
COLOR TEMP
COLOR MANAGEMENT
ADVANCED SETTINGS
EXTENDED LIFE SETTINGS
1 select
2 adjust
lock each menu setting:
4 To
Set the “LOCK SETTINGS” to “LOCK”.
EXTENDED LIFE SETTINGS
NORMALIZE NORMAL
MEMORY SAVE
MEMORY LOAD
MEMORY EDIT
Each menu will be set as same as
the “EXPRESS SETTINGS”.
Set each menu.
EXTENDED LIFE SETTINGS
When a menu is locked, it is grayed out and cannot be set.
“PICTURE MENU” and “PICTURE” will no longer
be able to set in the “PICTURE” menu, and they are
labeled with icon to indicate their locked status. Also,
“NORMALIZE”, “MEMORY SAVE” and “MEMORY
LOAD” are not available.
5 Select the input to apply the settings.
EXTENDED LIFE SETTINGS
PICTURE MENU
SIDE BAR ADJUST
NANODRIFT SAVER
PEAK LIMIT
LOCK SETTINGS
APPLY TO CURRENT INPUT
APPLY TO ALL INPUTS
DYNAMIC
30
BRIGHT
HIGH MID
OFF
LOCK
6 Select “YES”.
1 select
1 select
RECOMMENDED SETTINGS
EXTENDED LIFE SETTINGS
2 set
1 select
APPLY TO CURRENT INPUT
2 adjust
YES
NO
2 set
RESET
Reset the “Image Retention Reduction” menu to the factory settings. Each menu will be unlocked.
1 Select “RESET”.
EXTENDED LIFE SETTINGS
EXPRESS SETTINGS
CUSTOM SETTINGS
RESET
2 Select the input to reset the settings.
EXTENDED LIFE SETTINGS
RESET CURRENT INPUT
RESET ALL INPUTS
1 select
3 Select “YES”.
EXTENDED LIFE SETTINGS
1 select
RESET CURRENT INPUT
2 access
YES
NO
2 set
1 select
2 set
41
Reduces power consumption
• POWER SAVE:
• STANDBY SAVE:
• POWER MANAGEMENT:
• AUTO POWER OFF:
1
When this function is turned ON, luminous level of the Plasma Display is suppressed, so
power consumption is reduced.
When this function is turned ON, power consumption of the microcomputer is reduced during
power supply standby (see page 13, 16, 17), so standby power of the set is reduced.
When this function is set to ON, it operates under the following conditions to turn the power
on or off automatically.
When no pictures (HD/VD sync signals) are detected for 30 or so seconds during PC signal
input:
→ Power is turned off (standby); the power indicator lights up orange.
When pictures (HD/VD sync signals) are subsequently detected:
→ Power is turned on; the power indicator lights up green.
Notes:
• This function operates only during PC signal input.
• This function is invalid during input from PC Input Terminal Board (TY-42TM6P).
• This function is effective when “SYNC” is set to “AUTO”, “COMPONENT / RGB-IN SELECT”
is set to “RGB” and during normal viewing (one picture screen).
Equipment power supply is turned OFF when there is no signal.
When this is set to “ON”, the power supply of the unit goes Off 10 minutes after the input
signals stop.
Note:
This function is effective during normal viewing (one picture screen) for input signals except
PC IN terminal.
Press to select
“POWER SAVE”
“STANDBY SAVE”
“POWER MANAGEMENT”
“AUTO POWER OFF”.
2
Press to select “ON” or “OFF”.
On
Off
3
Press to exit from SET UP.
42
SET UP
1/2
SIGNAL
SCREENSAVER
EXTENDED LIFE SETTINGS
COMPONENT/RGB-IN SELECT
RGB
INPUT LABEL
PC
POWER SAVE
OFF
STANDBY SAVE
OFF
POWER MANAGEMENT
OFF
AUTO POWER OFF
OFF
OSD LANGUAGE
ENGLISH (US)
Customizing the Input labels
This function can change the label of the Input signal to be displayed.
Select the input signal which you would like to change its label before customizing the Input labels. (see page 15, 17)
Press to select INPUT LABEL.
SET UP
Press to change the INPUT LABEL.
Note:
While selecting a Input signal through Optional Terminal Board connected to Slot 1,
Slot 2 and Slot 3, the Input label will depend on each Optional Terminal Board.
1/2
SIGNAL
SCREENSAVER
EXTENDED LIFE SETTINGS
COMPONENT/RGB-IN SELECT
RGB
PC
INPUT LABEL
POWER SAVE
OFF
STANDBY SAVE
OFF
POWER MANAGEMENT
OFF
AUTO POWER OFF
OFF
OSD LANGUAGE
ENGLISH (US)
INPUT LABELS for SLOT 1, 2, 3 and PC IN:
[SLOT1] INPUT1 / DVD1 / DVD2 / DVD3 / Blu-ray1 / Blu-ray2 / Blu-ray3 / CATV / VCR / STB
[SLOT2] INPUT2 / DVD1 / DVD2 / DVD3 / Blu-ray1 / Blu-ray2 / Blu-ray3 / CATV / VCR / STB
[SLOT3] INPUT3/ DVD1 / DVD2 / DVD3 / Blu-ray1 / Blu-ray2 / Blu-ray3 / CATV / VCR / STB
[PC IN] PC / DVD1 / DVD2 / DVD3 / Blu-ray1 / Blu-ray2 / Blu-ray3 / CATV / VCR / STB
When BNC Dual Video Terminal Board (TY-FB9BD) is used, an “A” or “B” is added at the end of each input label, depending
on the input selected (see below).
Addition sign
Selected Input
“A”
Composite
“B”
S VIDEO
Selecting the On-Screen Menu Language
1
2
Press to display the SET UP menu.
Press to select OSD LANGUAGE.
Press to select your preferred language.
Selectable languages
SET UP
English(UK)
Deutsch
Français
Italiano
Español
ENGLISH(US)
.......(Chinese)
.......(Japanese)
Русский .......(Russian)
1/2
SIGNAL
SCREENSAVER
EXTENDED LIFE SETTINGS
COMPONENT/RGB-IN SELECT
RGB
PC
INPUT LABEL
OFF
POWER SAVE
OFF
STANDBY SAVE
POWER MANAGEMENT
OFF
AUTO POWER OFF
OFF
OSD LANGUAGE
ENGLISH (US)
43
DISPLAY ORIENTATION
Sets the fan control and the display style of on-screen menu for vertical installation.
1
2
3
Press to display the SET UP menu.
Press to select DISPLAY ORIENTATION.
Press to select “LANDSCAPE” or “PORTRAIT”.
PORTRAIT
Fan control for vertical installation. On-screen menu will be rotated
90 degrees counterclockwise to be suitable for the setting.
Notes:
• If the display is installed vertically, the power switch should be located at the bottom.
• Fan control will be switched when turning on the unit next time.
2/2
MULTI DISPLAY SETUP
MULTI PIP SETUP
PORTRAIT SETUP
SET UP TIMER
PRESENT TIME SETUP
DISPLAY ORIENTATION LANDSCAPE
Press to exit from adjust mode
LANDSCAPE
Fan control for horizontal installation.
44
SET UP
SET UP for MULTI DISPLAY
By lining up Plasma Displays in groups, for example, as illustrated below, an enlarged picture may be displayed across all screens.
For this mode of operation, each plasma display has to be set up with a Display number to determine its location.
(Example)
group of 4 (2 × 2) group of 9 (3 × 3)
group of 16 (4 × 4)
group of 25 (5 × 5)
How to setup MULTI DISPLAY
1
SET UP
Press to display the SET UP menu.
Press to select the MULTI DISPLAY SETUP.
2
2/2
MULTI DISPLAY SETUP
MULTI PIP SETUP
PORTRAIT SETUP
SET UP TIMER
PRESENT TIME SETUP
DISPLAY ORIENTATION LANDSCAPE
Press to display the “MULTI DISPLAY SETUP” menu.
MULTI DISPLAY SETUP
Press to select the MULTI DISPLAY SETUP.
3
Press to select “ON” or “OFF”.
Item
MULTI DISPLAY SETUP
OFF
×2
×2
OFF
A1
OFF
MULTI DISPLAY SETUP
HORIZONTAL SCALE
VERTICAL SCALE
SEAM HIDES VIDEO
LOCATION
AI-SYNCHRONIZATION
Details
Select “ON” or “OFF”.
Note: If you set MULTI DISPLAY SETUP to ON, PORTRAIT SETUP will be unavailable.
HORIZONTAL SCALE
Select “× 1”, “× 2”, “× 3”, “× 4”, “× 5”.
VERTICAL SCALE
Select “× 1”, “× 2”, “× 3”, “× 4”, “× 5”.
Select “ON” or “OFF”.
To hide joints between displays.
To show joints between displays.
Suitable for moving image display.
Suitable for still image display.
ON
OFF
SEAM HIDES VIDEO
Select the required arrangement number. (A1-E5 : Refer to the following)
Display Number locations for each arrangement.
(Examples)
( 2 × 1) ( 2 × 3 )
(4×2)
(4×4)
LOCATION
(5×5)
A1
A2
A3
A4
A5
B1
B2
B3
B4
B5
C1
C2
C3
C4
C5
D1
D2
D3
D4
D5
E1
E2
E3
E4
E5
45
SET UP for MULTI DISPLAY
Item
Details
Select “OFF” or “ON”.
The brightness depends on each
display’s setting.
Equalize the brightness of all the
displays.
OFF
ON
AI-SYNCRONIZATION
Note:
If you set AI-SYNCRONIZATION to ON, the following menus will be unavailable and these
settings will be fixed to the initial values.
PICTURE menu: COLOR, TINT, INPUT LEVEL (ADVANCED SETTINGS)
4
Press to exit from adjust mode.
ID Remote Control Function
You can set the remote control ID when you want to use this remote control on one of several different displays.
1
2
3
4
Switch
to
on the right side.
Press the
button on the remote control.
Press one of
-
,
for the tens digit setting.
Press one of
-
,
for the units digit setting.
Notes:
• The numbers in 2, 3 and 4 should be set up quickly.
• Adjustable ID number range is 0 - 99.
• If a number button is pressed more than two times, the first two numbers become the ID number
for the remote control.
ID remote control button operation
The operation is the same as normal remote control except for the
button.
ID Cancellation
Press
button on remote control. (This has the same effect as pressing the
,
,
buttons at the same time.)
Notes:
• Set the Remote ID “On” to operate the ID remote control.
If remote ID is set to “On”, you can use the remote control without identical ID number during option menu display.
(see page 56)
• The ID remote control cannot be used when ID select is set to anything other than 0, and the remote control ID is not
the same as the ID select number (see page 56).
46
MULTI PIP SETUP
Set the two-screen display function that is activated when
1
is pressed.
SET UP
Press to display the SET UP menu.
MULTI DISPLAY SETUP
MULTI PIP SETUP
PORTRAIT SETUP
SET UP TIMER
Press to select the MULTI PIP SETUP.
2
2/2
Press to display the “MULTI PIP SETUP” menu.
MULTI PIP SETUP
Press to select the menu to adjust.
Press to adjust the menu.
3
MULTI PIP
DISPLAY MODE
TRANSPARENCY
TRANSPARENCY LEVEL
INSERT
INSERT LEVEL
BLEND PIP
—
OFF
0%
OFF
1
MULTI PIP
DISPLAY MODE
Set the two-screen function.
The display mode can be changed separately for each function that was set in “MULTI PIP SETUP”.
P IN P
— (One screen)
P AND P
P OUT P
For “PIP”:
PIP
ADVANCED PIP
BLEND PIP
— (One screen)
1 to 8
For “ADVANCED PIP”:
— (One screen)
FULL
P IN P
For “BLEND PIP”:
Note: The display mode changes in the same way when
is pressed.
Transparent Display of the Sub Screen (During BLEND PIP)
1
2
Select “ON” in “TRANSPARENCY”.
Set the transparency level for the sub screen in “TRANSPARENCY LEVEL”. (0 to 100 %)
Setting example Transparent image (sub screen)
0 %: No transparency
100 %: Fully transparent
Note: “INSERT” cannot be set when “TRANSPARENCY” is “ON”.
Sub Screen Insertion (During BLEND PIP)
1
2
Select “ON” in “INSERT”.
Set the “INSERT LEVEL”. (1 to 10 %)
Set the brightness level threshold for discriminating between the transparent areas and non-transparent areas on the sub screen.
Setting example Image to insert (sub screen)
INSERT LEVEL
10 %
Only the areas on the overlay
image that are brighter than
the “INSERT LEVEL” are
displayed on the background
image.
Background image
(main screen)
Two-picture insertion
1%
Note: “TRANSPARENCY” cannot be set when “INSERT” is “ON”.
47
SET UP for PORTRAIT
Divide an input image into 3 parts, and display one of them to a plasma display which is set vertically. The image will be enlarged 3
times and rotated 90-degree.
(Example)
Note:
When using the PORTRAIT function with displays set vertically, “DISPLAY ORIENTATION” in SET UP menu has to be
set to “PORTRAIT” (see page 44).
How to setup PORTRAIT
1
Press to display the SET UP menu.
2
Press to select the PORTRAIT SETUP.
Press to display the “PORTRAIT SETUP” menu.
Press to select the PORTRAIT SETUP.
3
Press to select “ON” or “OFF”.
Note:
If you set PORTRAIT SETUP to ON, MULTI
DISPLAY SETUP will be unavailable.
Press to select SEAM HIDES VIDEO.
4
Press to select “OFF” , “ON”.
To hide joints between displays.
To show joints between displays.
Suitable for moving image display.
Suitable for still image display.
ON
OFF
48
SET UP
2/2
MULTI DISPLAY SETUP
MULTI PIP SETUP
PORTRAIT SETUP
SET UP TIMER
PRESENT TIME SETUP
DISPLAY ORIENTATION LANDSCAPE
PORTRAIT SETUP
PORTRAIT SETUP
SEAM HIDES VIDEO
VIEWING AREA
LOCATION
AI-SYNCHRONIZATION
OFF
OFF
16:9
1
OFF
PORTRAIT SETUP
PORTRAIT SETUP
SEAM HIDES VIDEO
VIEWING AREA
LOCATION
AI-SYNCHRONIZATION
OFF
OFF
16:9
1
OFF
SET UP for PORTRAIT
5
VIEWING AREA / LOCATION
VIEWING AREA: Set a mode of image division for PORTRAIT function.
LOCATION: Set a location of image to be displayed for PORTRAIT function.
Press to select VIEWING AREA or LOCATION.
PORTRAIT SETUP
Press to select each function.
PORTRAIT SETUP
SEAM HIDES VIDEO
VIEWING AREA
LOCATION
AI-SYNCHRONIZATION
Notes:
• For HD signal videos, the “VIEWING AREA” is set at “16:9”,
and cannot be changed.
HD signal: 1125 (1080) / 60i • 50i • 60p • 50p • 24p • 25p • 30p
• 24sF, 750 (720) / 60p • 50p, 1250 (1080) / 50i
• When “VIEWING AREA”is “16:9”, the aspect mode is set to “FULL”.
LOCATION setting
When PORTRAIT SETUP “ON”:
Display the image of the selected LOCATION.
OFF
OFF
16:9
1
OFF
When PORTRAIT SETUP is “OFF”:
Represent an area of the selected LOCATION at a normal
brightness and darken the rest of it.
VIEWING AREA and LOCATION
The mode of image division and the LOCATION by setting of VIEWING AREA is as follows.
VIEWING AREA: 16:9
Suitable to display FULL images. NORMAL
(4:3) images extend transversely.
Both right and left sides of the image are
cut by 48 dots.
LOCATION 1
LOCATION 2
Undisplayed area (48 dots)
LOCATION 3
VIEWING AREA: 4:3
LOCATION 1
6
LOCATION 2
LOCATION 3
4:3 images are displayed without changing
aspect ratio.
Although the images of each LOCATION
overlap, you can adjust POS. / SIZE to
display the image normally. (see page 25)
AI-SYNCHRONIZATION
Adjust to equalize the brightness of the 3 displays when using PORTRAIT setting.
Press to select AI-SYNCHRONIZATION.
Press to select “OFF” , “ON”.
The brightness depends on Equalize the brightness of
each display’s setting.
all the displays.
OFF
7
ON
PORTRAIT SETUP
PORTRAIT SETUP
SEAM HIDES VIDEO
VIEWING AREA
LOCATION
AI-SYNCHRONIZATION
OFF
OFF
16:9
1
OFF
Note:
If you set AI-SYNCHRONIZATION to ON, the
following menus will be unavailable and these
settings will be fixed to the initial values.
PICTURE menu: COLOR,TINT, INPUTLEVEL
(ADVANCED SETTINGS)
Press to exit from adjust mode.
49
SET UP for Input Signals
COMPONENT / RGB IN SELECT
Select to match the signals from the source connected to the COMPONENT / RGB input terminals.
Y, PB, PR signals
“COMPONENT”
RGB signals
“RGB”
1
2
SET UP
Press to select the “COMPONENT / RGB-IN SELECT”.
Press to select the desired mode.
RGB
COMPONENT
3
1/2
Press to display the SET UP menu.
SIGNAL
SCREENSAVER
EXTENDED LIFE SETTINGS
COMPONENT/RGB-IN SELECT
RGB
PC
INPUT LABEL
POWER SAVE
OFF
STANDBY SAVE
OFF
POWER MANAGEMENT
OFF
AUTO POWER OFF
OFF
OSD LANGUAGE
ENGLISH (US)
Press to exit from adjust mode.
Notes:
• Selection may not be possible, depending on which optional board is installed.
• Make setting of the selected input terminal (SLOT1, SLOT2, SLOT3 or PC IN).
YUV / RGB IN SELECT
Select to match the signals from the source connected to the DVI input terminals.
YUV signals
“YUV”
RGB signals
“RGB”
1
2
SET UP
Press to select the “YUV / RGB-IN SELECT”.
Press to select the desired mode.
YUV
RGB
3
Press to exit from adjust mode.
Notes:
• Selection may not be possible, depending on which optional board is installed.
• Make setting of the selected input terminal (SLOT1 or SLOT2).
50
1/2
Press to display the SET UP menu.
SIGNAL
SCREENSAVER
EXTENDED LIFE SETTINGS
YUV/RGB-IN SELECT
INPUT LABEL
POWER SAVE
STANDBY SAVE
POWER MANAGEMENT
AUTO POWER OFF
OSD LANGUAGE
RGB
PC
OFF
OFF
OFF
OFF
ENGLISH (US)
SET UP for Input Signals
SIGNAL menu
Note:
“SIGNAL” setup menu displays a different setting condition for each input signal.
1
2
SET UP
SIGNAL
SCREENSAVER
EXTENDED LIFE SETTINGS
COMPONENT/RGB-IN SELECT
RGB
PC
INPUT LABEL
POWER SAVE
OFF
STANDBY SAVE
OFF
POWER MANAGEMENT
OFF
AUTO POWER OFF
OFF
OSD LANGUAGE
ENGLISH (US)
Press to select the “SIGNAL”.
Press to display the SIGNAL menu.
3
Press to select the menu to adjust.
Press to adjust the menu.
Press ACTION ( ) button
For VIDEO (S VIDEO)
3D Y/C FILTER (NTSC)
COLOR SYSTEM
3 : 2 PULLDOWN
Panasonic AUTO (4 : 3)
REFRESH RATE
NOISE REDUCTION
Press to exit from adjust mode.
For RGB
[ VIDEO ]
SIGNAL
4
1/2
Press to display the SET UP menu.
SYNC
3 : 2 PULLDOWN
XGA MODE
REFRESH RATE
NOISE REDUCTION
ON
AUTO
OFF
4:3
100 Hz
OFF
3 : 2 PULLDOWN
XGA MODE
REFRESH RATE
NOISE REDUCTION
AUTO
OFF
AUTO
100 Hz
OFF
H-FREQ. 63.98 kHz
V-FREQ. 60.02 Hz
SIGNAL FORMAT 1280×1024/60
For COMPONENT
SIGNAL
[ RGB ]
SIGNAL
For Digital
[ COMPONENT ]
OFF
AUTO
100 Hz
OFF
H-FREQ. 63.98 kHz
V-FREQ. 60.02 Hz
SIGNAL FORMAT 1280×1024/60
[ Digital ]
SIGNAL
3 : 2 PULLDOWN
REFRESH RATE
NOISE REDUCTION
H-FREQ.
V-FREQ.
DOT CLOCK FREQ.
SIGNAL FORMAT
OFF
100 Hz
OFF
63.98 kHz
60.02 Hz
108.0 MHz
1280×1024/60
3D Y/C FILTER – For NTSC AV images
Select “SIGNAL” from the “SET UP” menu during VIDEO (S VIDEO) input signal mode.
(“SIGNAL [VIDEO]” menu is displayed.)
Press to select the “3D Y/C FILTER (NTSC)”.
3D Y/C FILTER (NTSC)
ON
Press to set ON / OFF.
Note:
When ON, this setting only affects NTSC input signals.
51
SET UP for Input Signals
COLOR SYSTEM / Panasonic AUTO
Select SIGNAL from the “SET UP” menu during VIDEO (S VIDEO) input signal mode.
(“SIGNAL [VIDEO]” menu is displayed.)
Press to select the “COLOR SYSTEM” or
“Panasonic AUTO (4:3)”.
Press to select each function.
If the image becomes unstable:
With the system set on Auto, under conditions of low level or noisy
input signals the image may in rare cases become unstable. Should
this occur, set the system to match the format of the input signal.
SIGNAL
3D Y/C FILTER (NTSC)
COLOR SYSTEM
3 : 2 PULLDOWN
Panasonic AUTO (4 : 3)
[ VIDEO ]
ON
AUTO
OFF
4:3
Mode
Function
COLOR SYSTEM Set the color system to match the input signal. When selecting “AUTO”, the color system is automatically
selected from NTSC/PAL/SECAM, however, M.NTSC signal is not displayed properly depending on
the attached terminal board. To display M.NTSC signal, select “M.NTSC” in COLOR SYSTEM.
To display PAL60 signal, select “PAL” when BNC Dual Video Terminal Board (TY-FB9BD) is
used. For other Video Terminal Boards, select “M.NTSC”.
PAL
NTSC
AUTO
SECAM
M.NTSC
Panasonic AUTO Set to “4:3” to view 4:3 images in an unchanged format when Panasonic AUTO is selected.
(4 : 3 )
If you would like to view 4:3 images in Just format, set to “JUST”.
Note:
Panasonic AUTO does not function when BNC Dual Video Terminal Board (TY-FB9BD) is used.
3:2 PULLDOWN
3:2 PULLDOWN: When ON, the display attempts to reproduce a more natural interpretation of sources such as movie
pictures, which are recorded at 24 frames per second.
If the picture is not stable, turn the setting to OFF.
Note:
When ON, this setting only affects the following signal input:
• NTSC / PAL signal input during “VIDEO (S VIDEO)” input signal.
• 525i(480i), 625i(575i), 1125(1080)/60i signal input during “COMPONENT” input signal.
Press to select “3:2 PULLDOWN”.
3 : 2 PULLDOWN
OFF
Press to set ON/OFF.
XGA MODE
This menu is displayed when the input signal is analog (Component/PC).
This unit supports three types of XGA signals with 60Hz vertical frequency having different aspect ratios and sampling
rates (1,024 × 768 @ 60Hz, 1,280 × 768 @ 60Hz and 1,366 × 768 @ 60Hz).
Press to select “XGA MODE”.
XGA MODE
AUTO
Press to select “AUTO”, “1024×768”, “1280×768”, “1366×768”.
AUTO: Automatically selected from 1024×768/1280×768/1366×768.
Switch the setting to suit the input signal for better display depends on the angle of view
or display resolution condition.
Note:
After making this setting, be sure to make each adjustment (such as “AUTO SETUP”) on the “POS. /SIZE” menu as
necessary. (see page 25)
52
SET UP for Input Signals
REFRESH RATE
This function sets the refresh rate of the display.
This menu is displayed when the input signal is 50 Hz system (50i, 50p, 25p, 24p, 24sF) of vertical scan rate.
100 Hz: Reduce screen flicker.
50 Hz: Enhance the resolution of moving images.
Note:
It is recommended to set to 100 Hz normally.
q
REFRESH RATE
Press to select REFRESH RATE.
100 Hz
Press to adjust.
NOISE REDUCTION
Sets the following three NR (Noise Reduction) functions together.
VIDEO NR, MOSQUITO NR, BLOCK NR
Press to select “NOISE REDUCTION”.
(
)
NOISE REDUCTION
OFF
(
)
NOISE REDUCTION
ADVANCED
Press to select “OFF”, “MIN”, “MID”, “MAX”,
“ADVANCED”.
Advanced NR
Sets the three NR functions separately.
1
Press to select “ADVANCED”.
▼
ADVANCED NR
Press to enter ADVANCED NR.
2
Press to select VIDEO NR,
MOSQUITO NR or BLOCK NR.
Press to select “OFF”, “MIN”, “MID”,
“MAX”.
VIDEO NR
MOSQUITO NR
BLOCK NR
ADVANCED NR
VIDEO NR
MOSQUITO NR
BLOCK NR
[ VIDEO ]
OFF
OFF
OFF
[ COMPONENT ]
OFF
OFF
OFF
ADVANCED NR
VIDEO NR
MOSQUITO NR
BLOCK NR
ADVANCED NR
VIDEO NR
MOSQUITO NR
BLOCK NR
[ RGB ]
OFF
OFF
OFF
[ Digital ]
OFF
OFF
OFF
VIDEO NR:
Automatically reduces unwanted picture noise.
MOSQUITO NR: Reduces mosquito noise around subtitles on MPEG videos.
BLOCK NR:
Reduces block noise when playing MPEG videos.
Note:
NOISE REDUCTION cannot be adjusted while a PC signal is being applied.
53
SET UP for Input Signals
SYNC
Select SIGNAL from the “SET UP” menu during RGB input signal.
Press to select the “SYNC”.
Press to adjust.
[ RGB ]
SIGNAL
SYNC
3 : 2 PULLDOWN
XGA MODE
AUTO
OFF
AUTO
Setting RGB sync signal
Confirm that the input is set to RGB INPUT (this setting is valid only for RGB INPUT signal).
AUTO:
ON G:
VBS:
The H and V sync or synchronized signal are automatically selected.
If both input, it is selected the H and V sync.
Uses a synchronized signal on the Video G signal, which is input from
the G connector.
Uses a synchronized signal of Composite Sync input, which is input
from the HD connector.
SYNC
AUTO
SYNC
ON G
SYNC
VBS
SDI THROUGH
Set the active through function of the Dual Link HD-SDI Terminal Board (TY-FB11DHD).
Note:
Settings can only be performed for this menu when a slot mounted with a Dual Link HD-SDI Terminal Board (TY-FB11DHD)
is selected.
Press to select the “SDI THROUGH”.
Press to select “ON” or “OFF”.
ON: Enables active through.
OFF: Disables active through.
[ Digital ]
SIGNAL
3 : 2 PULLDOWN
SDI THROUGH
REFRESH RATE
NOISE REDUCTION
OFF
OFF
100 Hz
OFF
Input signal display
Displays the frequency and the type of the current input signal.
This display is valid only for COMPONENT/RGB/PC and Digital input signal.
Display range:
Horizontal 15 - 110 kHz
Vertical
48 - 120 Hz
The dot clock frequency is displayed during digital signal input.
54
H-FREQ. 63.98 kHz
V-FREQ. 60.02 Hz
SIGNAL FORMAT 1280×1024/60
H-FREQ.
V-FREQ.
DOT CLOCK FREQ.
SIGNAL FORMAT
63.98 kHz
60.02 Hz
108.0 MHz
1280×1024/60
Options Adjustments
1
Options
1/3
Press to display the SET UP menu.
Weekly Command Timer
Memory lock
Press to select “OSD LANGUAGE”.
2
Onscreen display
Initial INPUT
Initial VOL level
Maximum VOL level
INPUT lock
Button lock
Remocon User level
Press for more than 3 seconds.
Press to select “Options”.
3
Options
Shipping
Press to display the Options menu.
Press to select your preferred menu.
4
Press to adjust the menu.
5
Off
0
Off
0
Off
Off
Off
Options
2/3
Off-timer function
Enable
Initial Power Mode
ID select
Remote ID
Serial ID
Display size
Studio W/B
Studio Gain
Normal
0
Off
Off
Off
Off
Off
3/3
Options
Slot power
Power On Screen Delay
Clock Display
All Aspect
Auto Setup
Rotate
Serial Slot Select
Press to exit from Options menu.
Item
On
Off
Off
Off
Off
Off
Manual
Off
Slot2
Adjustments
Weekly Command Timer Sets Weekly Command Timer. (see page 58)
Memory lock
Locks or unlocks saved profiles. Also for setting passwords. (see page 33)
On: Displays all the following on screen.
• Power on display
• Input signal switch display
Onscreen display
• No signal display
• Mute and the remaining time of off-timer after was pressed.
Off: Hides all the items above from view.
PC
INPUT1
INPUT2
INPUT3
Off
Adjusts the input signal when the unit is turned on.
Notes:
• Only the adjusted signal is displayed. (see page 15)
Initial INPUT
• Signal can be displayed when the Terminal board is installed.
• This menu is available only when “INPUT lock” is “Off”.
• When a dual input terminal board is attached, A or B is displayed depending on the selected input signal.
(Ex. INPUT1A, INPUT1B)
Press
Initial VOL level
On
Off
Off: Sets normal volume.
On: Sets your preferred volume.
Notes:
• When “Maximum VOL level” is “On”, the volume can only be adjusted between 0 and your maximum range.
• You can hear the changed volume regardless of your volume setting before opening the options menu if
you adjust the volume when “Initial VOL level” is “On” and cursor is on the menu.
Press
Maximum VOL level
button to adjust the volume when the unit is turned on.
button to adjust the maximum volume.
On
Off
Off: Sets auto maximum volume.
On: Sets your preferred maximum volume.
Notes:
• If the “Maximum VOL level” is set lower than the “Initial VOL level”, the “Initial VOL level” automatically
becomes the same as the “Maximum VOL level”.
• The volume display can go up to 63 regardless of the settings.
• You can hear the changed volume regardless of your volume setting before opening the options menu if
you adjust the volume when “Maximum VOL level” is “On” and cursor is on the menu.
55
Options Adjustments
Item
Adjustments
INPUT lock
PC
INPUT1
INPUT2
INPUT3
Off
Locks the input switch operation.
Notes:
• Only the adjusted signal is displayed (see page 15).
• Signal can be displayed when the Terminal board is installed.
• Input switch can be used when this is set to “Off”.
• In two screen display mode, if anything other than “Off” is set, the value will be fixed as the value input in
the single screen display mode.
• When a dual input terminal board is attached, A or B is displayed depending on the selected input signal.
(Ex. INPUT1A, INPUT1B)
Button lock
Off
MENU&ENTER
On
Off: All the buttons at the right side of the main unit can be used.
MENU&ENTER:
ENTER/ buttons on right side of main unit.
MENU and
Locks
On: Locks all the button on right side of main unit.
Sets Button lock with the unit buttons in the following procedure.
INPUT four times→Press
- / four times→Press
ENTER/
+ / four times→Press
Off: Press
INPUT
/
ENTER/
ENTER/
+
MENU&ENTER: Press
four times→Press
four times→Press
four times→Press
- / four times→Press
ENTER/ four times→Press
ENTER/
+ / four times→Press
On: Press
Remocon User level
User1
User2
User3
Off
Off: You can use all of the buttons on the remote control.
User1: You can only use
,
,
,
, ,
,
,
buttons on the remote control.
,
, buttons on the remote control.
User2: You can only use
User3: Locks all the buttons on remote control.
Off-timer function
Enable: Enables the “Off-timer function”.
Disable: Disables the “Off-timer function”.
Note: When “Disable” is set, the Off-timer is cancelled.
Initial Power Mode
Standby
On
Normal
Sets the power mode of the unit for when the power recovers from failure or after plugging off and in again.
Normal: Power returns in as the same state as before the power interruption.
Standby: Power returns in standby mode. (Power Indicator : red/orange)
On:
Power returns in power On. (Power Indicator : green)
Note: When using multiple displays, “Standby” is preferred to be set in order to reduce a power load.
ID select
Remote ID
Serial ID
Sets panel ID number when panel is used in “Remote ID” or “Serial ID”.
Set value range: 0 - 100
(Standard value: 0)
The setting of this menu is valid only when using ID remote control.
Off: Disables ID remote control functions. You can use normal remote control operations.
On: Enable ID remote control functions.
Note: To use the ID remote control function, it is necessary to set each ID number of remote control and
display unit. About the setting method, please refer to “ID Remote Control Function” (see page 46)
and “ID select” (above-mentioned).
Sets the panel ID Control.
Off: Disables external control by the ID.
On: Enables the external control by the ID.
Adjusts the image display size on screen.
Off: Sets the normal image display size on screen.
On: Sets the image display size approximately 95 % of the normal image display.
Off
On
Display size
56
Notes:
• This setting is valid only when the input signals are as follows;
NTSC, PAL, SECAM, M.NTSC, PAL60, PAL-M, PAL-N (BNC Dual Video Terminal Board (TY-FB9BD))
525i, 525p, 625i, 625p, 750/60p, 750/50p, 1125/60i, 1125/50i, 1125/24sF, 1125/25p, 1125/24p, 1125/30p,
1125/60p, 1125/50p, 1250/50i (Component Video, RGB, DVI, SDI, HDMI)
• This setting is invalid when two screen display, digital zoom, Multi display or Portrait display is selected.
• When “Display size” is set to “On”, “H-POS” and “V-POS” in “POS. /SIZE” can be adjusted.
• Refer to each board’s operating instruction for DVI, SDI, HDMI’s corresponding signals.
Options Adjustments
Item
Adjustments
Studio W/B
Off: Nullify all the settings adjusted.
On: Sets the color temperature for TV studio.
Note: Valid only when the “WARM” is set as “COLOR TEMP” in PICTURE menu.
Studio Gain
Sharpens the contrast for a better view when a part of the image is too light to see.
Off: Disables “Studio Gain”.
On: Enables “Studio Gain”.
Note: This setting is valid only when the input signals are as follows:
Component Video, RGB (analog), SDI, HDMI
Slot Power
Off
Off:
Auto:
On:
Note:
Power On Screen
Delay
Clock Display
Auto
On
Power is not transmitted to the slot power.
Power is transmitted to the slot power only when main power is on.
Power is transmitted to the slot power when main power is on or in the standby state.
In some cases, power is transmitted to the slot power when main power is on or in the standby state
regardless of the slot power setting.
Off
1
2
3....
30
You can set the power-on delay time of the displays to reduce the power load, when you press
to turn
on the multiple displays that are set together, for example, on MULTI DISPLAY system.
Set each display’s setting individually.
Off:
The display will be turned on at the same time as
is pressed.
1 to 30 (sec.): Set the power-on delay time (second).
After pressing
, the display will be powered on with time delay depending on this setting.
Notes:
• During this function is working, the power indicator is blinking green.
• This function also works when the power recovers from failure or after plugging off and in again the power cord.
After you unplug and plug the power cord in while the unit is in standby mode and also the power is being
supplied to a terminal board, the unit will start supplying the power to the board with time delay according
to the setting.
The power indicator lights up red first and it turns orange when the power starts being supplied to the board.
Off: Not display the clock.
On: Display the clock.
The clock is displayed at the lower left of the screen when button is pressed.
Note: When “PRESENT TIME SETUP” is not set, the clock is not displayed even
if “Clock Display” is “On” (see page 36)
10:00
All Aspect
Sets All Aspect mode (advanced aspect setting) or default aspect mode.
With each press of
button, the aspect changes in the selected mode.
Off: Default aspect mode
On: All Aspect mode
Aspect mode of each setting is as follows:
(Example: HD signal)
Off
4:3→H-FILL→ZOOM→FULL→JUST
On
4:3 (1)→4:3 (2)→4:3 Full→Zoom1→Zoom2→Zoom3→16:9→14:9→Just1→Just2
Auto Setup
Sets the operational mode of the automatic position adjustment in the POS./SIZE menu.
Manual: Automatic position adjustment starts when
is pressed on the remote control or automatic position
adjustment is executed from the POS./SIZE menu.
Auto:
Other than remote control or menu operation, automatic position adjustment starts:
When the display power is turned ON.
When the input signal is switched.
Rotate
Serial Slot
Select
Off:
On:
Does not rotate the image.
Rotates the image 180 degrees.
Slot1
Slot2
Slot3
Selects the slot which communicates serial.
Note: The setting of an external command can be set only from the fixed serial terminal. (see page 11)
Normalization
When both main unit buttons and remote control are disabled due to the “Button lock”, “Remocon User level” or “Remote
ID” adjustments, set all the values “Off” so that all the buttons are enabled again.
- / button on main unit together with
Press the
button on the remote control and hold for more than 5 seconds. The
“Shipping” menu is displayed and the lock is released when it disappears.
57
Options Adjustments
Weekly Command Timer
You can set 7-day timer programming by setting time and command.
Note:
Before setting Weekly Command Timer, set PRESENT TIME SETUP. (see page 36)
Press to select Function.
1
Options
Press to select “On”.
On
Onscreen display
Note:
• When Function is set to On, SET UP TIMER
(see page 36) is unavailable and INTERVAL
/ TIME OF DAY in MODE of SCREENSAVER
(see page 37) cannot be selected.
Press ACTION ( ) button
Weekly Command Timer
Press to select a day.
2
1/3
Weekly Command Timer
Memory lock
Function
On
Monday
Tuesday
Program1
Program3
Wednesday
Thursday
Friday
Saturday
Sunday
Program Edit
Press to select a program number.
Note:
• You can set the program from 1 to 7.
--- indicates unset.
--Program3
--Program6
Program4
Program number
y
Thursday
Friday
Saturday
Sunday
Program Edit
Press to select Program Edit.
3
Program4
Program
8:00
01
10:30
02
--:-03
--:-04
--:-05
12:00
06
9:12
07
--:-08
Press to change the program numbers (1-7).
Press to select a command number.
Press to show the previous / next command
pages (1-8) of the selected program.
1
PON
IMS:SL1
------DAM:ZOOM
AVL:10
---
Press to show the command setting screen.
1/8
Weekly Command Timer
Program
01
02
03
04
05
06
07
08
1
8:00
10:30
PON
IMS:SL1
--:--
---
--:--
---
--:--
---
12:00
9:12
--:--
DAM:ZOOM
AVL:10
---
Command (--- indicates unset)
Set time of timer (--:-- indicates unset)
Command numbers
58
1/8
Weekly Command Timer
Press to select Program.
5
--Program6
Program Edit screen
Press to show the Program Edit screen.
4
Program3
8/8
Weekly Command Timer
Program
57
58
59
60
61
62
63
64
1
20:00
AVL:00
20:30
22:00
DAM:NORM
POF
--:--
---
--:--
---
--:--
---
--:--
---
--:--
---
Options Adjustments
Press to select Command No.
6
Press to select a command number.
Command setting screen
Weekly Command Timer
Program
1
Command No
10:30
Time
Command
Press to select Time / Command.
7
02
IMS:SL1
Weekly Command Timer
1
Program
Press to set each item.
02
Command No
Time: Set the time to execute a command program.
10:30
Time
Pressing “ ” or “ ” button once changes “Time” 1
IMS:SL1
Command
minute.
Pressing “ ” or “ ” button continuously changes “Time” by 15 minutes.
Command: Select a command to execute at the set time. This unit has 64 commands to set.
(see page 64)
Notes:
• Command is performed in order of execution time, regardless of the command number.
• If a command execution time overlaps with that of other commands, these commands are
performed in number order.
• Pressing , Time becomes --:-- and Command becomes ---.
Note:
Press
to return to the previous screen.
Shipping condition
This function allows you to reset the unit to the factory setting.
1
2
Press to display the SET UP menu.
Press to select “OSD LANGUAGE”.
Press for more than 3 seconds.
3
Press to select “Shipping”.
Press to display the Shipping menu.
4
SET UP
1/2
SIGNAL
SCREENSAVER
EXTENDED LIFE SETTINGS
COMPONENT/RGB-IN SELECT
RGB
PC
INPUT LABEL
OFF
POWER SAVE
OFF
STANDBY SAVE
POWER MANAGEMENT
OFF
AUTO POWER OFF
OFF
OSD LANGUAGE
ENGLISH (US)
Options
Shipping
Press to select “YES”.
Shipping
YES
NO
Press to confirm.
[from the unit]
1 Press the MENU button till the SET UP menu is displayed.
2 Press the Volume Up “+” or Down “–” button to select “OSD LANGUAGE”.
3 Press and hold the ENTER button till the Shipping menu is displayed.
4 Press the Volume Up “+” or Down “–” button to select “YES”.
5 Press the ENTER button and wait for 10 sec.
59
Troubleshooting
Before you call for service, determine the symptoms and make a few simple checks as shown below.
Symptoms
Checks
Sound
Interference
Noisy Sound
Electrical Appliances
Cars / Motorcycles
Fluorescent light
Normal Picture
No Sound
Volume
(Check whether the mute function has been activated on the remote control.)
No Picture
No Sound
Not plugged into AC outlet
Not switched on
PICTURE and BRIGHTNESS/Volume setting
(Check by pressing the power switch or stand-by button on the remote control.)
No Picture
Normal Sound
If a signal with a non-applicable color system format, or frequency is input, only the input
terminal indication is displayed.
No Color
Normal Sound
Color controls set at minimum level. (see page 28, 29)
COLOR SYSTEM (see page 52)
No remote control operations can be performed.
A cracking sound is sometimes heard from the unit.
The top or bottom of the picture on the screen is cut
off when I use the zoom function.
Areas at the top and bottom of the screen where
the image is missing appear when I use the zoom
function.
Check whether the batteries have discharged completely and, if they have not, whether they
were inserted properly.
Check whether the remote control sensor is exposed to an outdoor light or a strong fluorescent
light.
Check whether the remote control designed specifically for use with the unit is being used.
(The unit cannot be operated by any other remote control.)
If there is nothing wrong with the picture or sound, this is the sound of the cabinet undergoing
very slight contractions in response to changes in the room temperature. There are no adverse
effects on the performance or other aspects.
Adjust the position of the picture on the screen.
When using a video software program (such as a cinema size program) with a screen wider
than one in the 16:9 mode, blank areas separate from the images are formed at the top and
bottom of the screen.
I can hear sounds coming from inside the unit.
When the power is turned on, a sound of the display panel being driven may be heard: This is
normal and not indicative of malfunctioning.
This Plasma Display uses special image processing. Hence a slight time lag may occur between image and audio, depending on the type of input
signal. However, this is not a malfunction.
Plasma Display panel
Symptoms
Check
The screen darkens slightly when bright pictures with
minimal movements are shown.
The screen will darken slightly when photos, still images of a computer or other pictures with
minimal movements are shown for an extended period. This is done to reduce image retention
on the screen and the shortening of the screen’s service life: It is normal and not indicative of
malfunctioning.
The unit digitally processes the various signals in order to reproduce esthetically pleasing
images. As such, it sometimes takes a few moments for the picture to appear when the power
has been turned on, when the input has been switched or when the images for the main picture
and sub picture on the two screens are swapped.
Due to the characteristics of the system used to drive the panel, the edges may appear to flicker
in the fast-moving parts of the images: This is normal and not indicative of malfunctioning.
It takes a while for the picture to appear.
The edges of the images flicker.
The brightness on both sides of images in 4:3 mode
changes.
Some parts of the screen do not light up.
Image retention appears
Whirring sounds can be heard from the display unit.
60
When viewing the side panels at the “BRIGHT” or “MID” setting, the brightness on both sides
may change depending on the kind of program shown: This is normal and not indicative of
malfunctioning.
The plasma display panel is manufactured using an extremely high level of precision technology,
however, sometimes some parts of the screen may be missing picture elements or have luminous
spots. This is not a malfunction.
Do not allow a still picture to be displayed for an extended period, as this can cause a permanent
image retention to remain on the Plasma Display.
Examples of still pictures include logos, video games, computer images, teletext and images
displayed in 4:3 mode.
Note:
The permanent image retention on the Plasma Display resulting from fixed image use is not
an operating defect and as such is not covered by the Warranty.
This product is not designed to display fixed images for extended periods of time.
The display unit is fitted with a cooling fan to dissipate heat generated during normal use. The
whirring sound is caused by rotation of the fan and is not a malfunction.
List of Aspect Modes
Aspect mode
All Aspect: Factory setting
On
All Aspect: Off
16:9
14:9
FULL
JUST
JUST
Pictures with a 4:3 aspect ratio are enlarged horizontally
so that the picture distortion is minimized. The left and right
edges of the pictures are cut off. The display of the areas
around the left and right edges of the screen is slightly
elongated.
4:3
4:3 (1)
4:3
H-FILL
Zoom
ZOOM
Zoom1
Zoom2
Zoom3
The display of the pictures fills the screen.
In the case of SD signals, pictures with a 4:3 aspect ratio are
enlarged horizontally, and displayed. This mode is suited to
displaying anamorphic pictures with a 16:9 aspect ratio.
Pictures with a 4:3 aspect ratio are enlarged horizontally
so that the picture distortion is minimized. The display of
the areas around the left and right edges of the screen is
slightly elongated.
4:3
4:3 Full
Description
–
Just1
4:3 (2)
Enlarged screen
Letterbox pictures with a 14:9 aspect ratio are enlarged
vertically and horizontally so that their display fills the
screen vertically and is slightly smaller than the screen
horizontally. The top and bottom edges of the pictures are
cut off. Side panels are displayed at the left and right edges
of the screen.
Just
Just2
Pictures with a 4:3 aspect ratio are displayed with their
original aspect ratio. Side panels are displayed at the left
and right edges of the screen.
Pictures with a 4:3 aspect ratio are displayed with their
original aspect ratio. The left and right edges of the pictures
are masked by side panels.
Pictures with a 4:3 aspect ratio are enlarged horizontally so
that their display fills the screen. The left and right edges of
the pictures are cut off.
Letterbox pictures with a 16:9 aspect ratio are enlarged
vertically and horizontally so that their display fills the screen.
The top and bottom edges of the pictures are cut off.
ZOOM
Letterbox pictures with a 16:9 aspect ratio are enlarged
vertically and horizontally so that their display fills the screen.
The top and bottom edges as well as the left and right edges
of the pictures are cut off.
–
Letterbox pictures with a 2.35:1 aspect ratio are enlarged
vertically and horizontally so that their display fills the screen
vertically and is slightly larger than the screen horizontally.
The top and bottom edges as well as the left and right edges
of the pictures are cut off.
61
Applicable Input Signals
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
Signal name
Horizontal frequency
(kHz)
Vertical frequency
(Hz)
525 (480) / 60i
525 (480) / 60p
625 (575) / 50i
625 (575) / 50p
625 (576) / 50p
750 (720) / 60p
750 (720) / 50p
1,125 (1,080) / 60p
1,125 (1,080) / 60i
1,125 (1,080) / 50p
1,125 (1,080) / 50i
1,125 (1,080) / 24sF
1,125 (1,080) / 30p
1,125 (1,080) / 25p
1,125 (1,080) / 24p
1,250 (1,080) / 50i
2,048 × 1,080 / 24sF ∗7
2,048 × 1,080 / 24p ∗7
640 × 400 @70 Hz
640 × 480 @60 Hz
640 × 480 @72 Hz
640 × 480 @75 Hz
640 × 480 @85 Hz
800 × 600 @56 Hz
800 × 600 @60 Hz
800 × 600 @72 Hz
800 × 600 @75 Hz
800 × 600 @85 Hz
852 × 480 @60 Hz
1,024 × 768 @50 Hz
1,024 × 768 @60 Hz
1,024 × 768 @70 Hz
1,024 × 768 @75 Hz
1,024 × 768 @85 Hz
1,066 × 600 @60 Hz
1,152 × 864 @60 Hz
1,152 × 864 @75 Hz
1,280 × 768 @60 Hz
1,280 × 960 @60 Hz
1,280 × 960 @85 Hz
1,280 × 1,024 @60 Hz
1,280 × 1,024 @75 Hz
1,280 × 1,024 @85 Hz
1,366 × 768 @50 Hz
1,366 × 768 @60 Hz
1,400 × 1,050 @60 Hz
1,600 × 1,200 @60 Hz
1,600 × 1,200 @65 Hz
1,920 × 1,080 @60 Hz
1,920 × 1,200 @60 Hz
Macintosh13” (640 × 480)
Macintosh16” (832 × 624)
Macintosh21” (1,152 × 870)
15.73
31.47
15.63
31.25
31.25
45.00
37.50
67.50
33.75
56.26
28.13
27.00
33.75
28.13
27.00
31.25
27.00
27.00
31.46
31.47
37.86
37.50
43.27
35.16
37.88
48.08
46.88
53.67
31.47
39.55
48.36
56.48
60.02
68.68
37.64
53.70
67.50
47.70
60.00
85.94
63.98
79.98
91.15
39.55
48.36
65.22
75.00
81.25
67.50
74.04
35.00
49.72
68.68
59.94
59.94
50.00
50.00
50.00
60.00
50.00
60.00
60.00
50.00
50.00
48.00
30.00
25.00
24.00
50.00
48.00
24.00
70.07
59.94
72.81
75.00
85.01
56.25
60.32
72.19
75.00
85.06
59.94
50.00
60.00
70.07
75.03
85.00
59.94
60.00
75.00
60.00
60.00
85.00
60.02
75.03
85.02
50.00
60.00
60.00
60.00
65.00
60.00
59.95
66.67
74.54
75.06
*Mark: Applicable input signal
COMPONENT / RGB IN
DVI-D IN ∗8
/ PC IN
(Dot
clock (MHz))
(Dot clock (MHz))
* (13.5)
* (27.0) ∗5
* (27.0)
* (13.5)
* (27.0)
* (27.0)
* (74.25)
* (74.25)
* (74.25)
* (74.25)
* (148.5)
* (148.5) ∗1
* (74.25)
* (74.25) ∗1
* (148.5)
* (148.5) ∗1
* (74.25)
* (74.25) ∗1
* (74.25) ∗2
* (74.25)
* (74.25) ∗1
* (74.25)
* (74.25) ∗1
* (74.25)
* (74.25) ∗1
* (74.25) ∗3
*
*
*
*
*
*
*
*
*
*
*
(25.17)
(25.18)
(31.5)
(31.5)
(36.0)
(36.0)
(40.0)
(50.0)
(49.5)
(56.25)
(33.54)
*
*
*
*
*
(65.0)
(75.0)
(78.75)
(94.5)
(53.0)
*
*
*
*
*
*
*
(108.0)
(80.14)
(108.0)
(148.5)
(108.0)
(135.0)
(157.5)
∗6
* (40.0)
∗6
* (34.24)
* (51.89)
* (65.0)
* (53.0)
* (81.62)
* (108.0)
*
*
*
*
* (86.71)
* (162.0)
* (175.5)
* (148.5)
* (25.18)
∗4
(69.92)
(87.44)
(122.61)
(162.0)
* (148.5)
* (154.0)
* (30.24)
* (57.28)
* (100.0)
∗1: Based on SMPTE 274M standard.
∗2: Based on SMPTE RP211 standard.
∗3: Based on SMPTE 295M standard.
∗4: The input signal is recognized as 1,125 (1,080) / 60p.
∗5: When selected the RGB format and 525p signal input to the Mini D-sub 15P terminal, it is recognized as VGA 60Hz signal.
∗6: When inputted VGA 60Hz format signal from the other than Mini D-sub 15P terminal, it is recognized as 525p signal.
∗7: Based on SMPTE 292M and 372M standards. These signals can be received when the Dual Link HD-SDI Terminal Board
(TY-FB11DHD) is installed.
∗8: These signals can be received when the DVI-D Terminal Board (TY-FB11DD) is installed.
Note: Signals without above specification may not be displayed properly.
62
Applicable Input Signals
VIDEO input (HDMI)
Vertical
Horizontal
Dot clock
frequency (Hz) frequency (kHz)
(MHz)
1 VGA60
59.94
31.47
25.18
2 525/60p
59.94
31.47
27.00
3 625/50p
50.00
31.25
27.00
4 750/60p
60.00
45.00
74.25
5 750/50p
50.00
37.50
74.25
6 1125/60i
60.00
33.75
74.25
7 1125/50i
50.00
28.13
74.25
8 1125/60p∗
60.00
67.50
148.50
9 1125/50p∗
50.00
56.26
148.50
10 1125/24p∗
24.00
27.00
74.25
∗Not compatible with HDMI Terminal Board (TY-FB8HM).
Audio signal Linear PCM : 48/44.1/32 kHz
Signal format
Number of Total number
active pixels
of pixels
640
800
720
858
720
864
1280
1650
1280
1980
1920
2200
1920
2640
1920
2200
1920
2640
1920
2750
Number of
active lines
480
480
576
720
720
1080
1080
1080
1080
1080
Total number
of lines
525
525
625
750
750
1125
1125
1125
1125
1125
63
Command list of Weekly Command Timer
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
Command
AAC:MENCLR∗1
AAC:MENDYN∗1
AAC:MENSTD∗1
AAC:SURMON
AAC:SUROFF
AMT:0
AMT:1
ASO:M
ASO:S
AVL:00
AVL:10
AVL:20
AVL:30
AVL:40
AVL:50
AVL:60
DAM:FULL
DAM:JUST
DAM:NORM
DAM:SELF
DAM:ZOOM
DWA:OFF
DWA:OVL1
DWA:OVL2
DWA:OVL3
DWA:OVL4
DWA:OVL5
DWA:OVL6
DWA:OVLOF
DWA:OVLON
DWA:PIN0
DWA:PIN1
DWA:PIN2
DWA:PIN3
DWA:PIP
DWA:POP
DWA:SWP
DWA:TWN
IMS:PC1
IMS:SL1
IMS:SL1A
IMS:SL1B
IMS:SL2
IMS:SL2A
IMS:SL2B
IMS:SL3
ISS:PC1
ISS:SL1
ISS:SL1A
ISS:SL1B
ISS:SL2
ISS:SL2A
ISS:SL2B
ISS:SL3
OSP:SCR0
OSP:SCR1
POF
PON
SSC:FNC0
SSC:FNC1
SSC:MOD0
SSC:MOD3
VMT:0∗2
VMT:1∗2
Control details
Audio Menu (Clear)
Audio Menu (Dynamic)
Audio Menu (Standard)
Surround (ON)
Surround (OFF)
Audio Mute (OFF)
Audio Mute (ON)
Audio out when PIP mode (Main Picture)
Audio out when PIP mode (Sub Picture)
Audio Volume (00)
Audio Volume (10)
Audio Volume (20)
Audio Volume (30)
Audio Volume (40)
Audio Volume (50)
Audio Volume (60)
Aspect (FULL)
Aspect (JUST)
Aspect (4:3)
Aspect (Panasonic Auto)
Aspect (ZOOM)
Dual Picture mode (OFF)
Advanced PIP mode (1) (see page 19)
Advanced PIP mode (2) (see page 19)
Advanced PIP mode (3) (see page 19)
Advanced PIP mode (4) (see page 19)
Advanced PIP mode (5) (see page 19)
Advanced PIP mode (6) (see page 19)
Advanced PIP mode (OFF) (normal two screen display mode)
Advanced PIP mode (ON)
The location of the sub picture (lower right)
The location of the sub picture (lower left)
The location of the sub picture (upper left)
The location of the sub picture (upper right)
Dual Picture mode (Picture in Picture)
Dual Picture mode (Picture out Picture)
Swap main picture and sub picture when PIP mode
Dual Picture mode (Picture and Picture)
Input select (PC1) (Main Picture when PIP mode)
Input select (SLOT1) (Main Picture when PIP mode)
Input select (SLOT1A) (Main Picture when PIP mode)
Input select (SLOT1B) (Main Picture when PIP mode)
Input select (SLOT2) (Main Picture when PIP mode)
Input select (SLOT2A) (Main Picture when PIP mode)
Input select (SLOT2B) (Main Picture when PIP mode)
Input select (SLOT3) (Main Picture when PIP mode)
Sub Picture Input Select (PC1)
Sub Picture Input Select (SLOT1)
Sub Picture Input Select (SLOT1A)
Sub Picture Input Select (SLOT1B)
Sub Picture Input Select (SLOT2)
Sub Picture Input Select (SLOT2A)
Sub Picture Input Select (SLOT2B)
Sub Picture Input Select (SLOT3)
Screen Saver SCROLLING BAR ONLY (OFF)
Screen Saver SCROLLING BAR ONLY (ON)
Power OFF
Power ON
Screen Saver function (SCROLLING BAR ONLY)
Screen Saver function (NEGATIVE IMAGE)
Screen Saver (Mode (OFF))
Screen Saver (Mode (ON))
Picture Mute (OFF)
Picture Mute (ON)
∗1 These commands are unavailable on this model.
∗2 Picture Mute cannot be unlocked by powering off/on with the remote control. Turn off and on again with the button
on the unit or enter the command VMT:0 to unlock Picture Mute.
64
Specifications
Power Source
Power Consumption
Power on
Stand-by condition
Power off condition
Plasma Display panel
Screen size
(No.of pixels)
Operating condition
Temperature
Humidity
Applicable signals
Scanning format
PC signals
Connection terminals
HDMI A-B
COMPONENT/RGB IN
PC IN
SERIAL
AUDIO OUT
Accessories Supplied
Remote Control Transmitter
Batteries
Fixing band
Dimensions (W × H × D)
Mass (weight)
TH-103PF12U
200-240 V AC, 50/60 Hz
1,400 W
Save OFF 1.2 W, Save ON 0.7 W
0.4 W
Drive method : AC type 103-inch, 16:9 aspect ratio
89.3” (2,269 mm) (W) × 50.2” (1,276 mm) (H) × 102.4” (2,603 mm) (diagonal)
2,073,600 (1,920 (W) × 1,080 (H))
[5,760 × 1,080 dots]
32 °F - 104 °F (0 °C - 40 °C)
20 % - 80 %
525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 750 (720) / 60p · 50p, 1125 (1080) / 60i · 60p · 50i · 50p
· 24p · 25p · 30p · 24sF, 1250 (1080) / 50i
VGA, SVGA, XGA, SXGA
UXGA ···· (compressed)
Horizontal scanning frequency 15 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
TYPE A Connector × 2
with sync 1.0 Vp-p (75 Ω)
0.7 Vp-p (75 Ω)
0.5 Vrms
Y or G with sync 1.0 Vp-p (75 Ω)
Y or G without sync 0.7 Vp-p (75 Ω)
B/PB/CB : 0.7 Vp-p (75 Ω)
R/PR/CR : 0.7 Vp-p (75 Ω)
HD/VD: 1.0 - 5.0 Vp-p (high impedance)
0.5 Vrms
AUDIO IN (M3 JACK)
EXTERNAL CONTROL TERMINAL (D-SUB 9PIN)
RS-232C COMPATIBLE
RCA PIN JACK × 2 (L / R)
OUTPUT LEVEL : VARIABLE (-∞ ― 0 dB)
[INPUT 1 kHz / 0 dB, 10 kΩ Load]
Y/G (BNC)
PB/B (BNC), PR/R (BNC)
AUDIO IN (RCA PIN JACK × 2)
(HIGH-DENSITY MINI D-SUB 15PIN)
EUR7636070R
AA Size × 2
TMME203 × 2
95.0” (2,412 mm) × 55.9” (1,419 mm) × 5.1” (129 mm)
(5.6” (141 mm) when including protruding portion of slots)
apporox. 443.2 lbs
Note:
Design and specifications are subject to change without notice. Mass and dimensions shown are approximate.
65
(for the U.S.A and Puerto Rico)
Panasonic Professional Display Company
Unit of Panasonic Corporation of
North America
One Panasonic Way 1F-10
Secaucus, NJ 07094
Panasonic Professional Flat Panel Display
Limited Warranty
Panasonic Professional Display Company. (referred to
as “the Warrantor”) will repair this product and all
included accessories with new or refurbished parts,
free of charge in the USA or Puerto Rico, of the
original purchase in the event of a defect in materials or
workmanship as follows:
Models or Parts
Part
Warranty
Professional Flat
Panel Display
3 Years
Labor
Warranty
3 Years
On-site or carry-in service in the USA and Puerto Rico
may be obtained during the warranty period by contacting
Panasonic Professional Display Company Service toll free
at 1-800-973-4390.
This warranty is extended only to the original purchaser
and is non transferable. A purchase receipt or other
proof of date of original purchase will be required before
warranty service is rendered.
This warranty only covers failures due to defects in
materials or workmanship, which occur during normal
use. The warranty does not cover damage which occur
in shipment, or failures which are caused by products
not supplied by the warrantor, or failures which result
from improper installation, set-up adjustments, improper
antenna, inadequate signal pickup, maladjustment of
consumer controls, improper operation, power line surge,
improper voltage supply, lighting damage, or service by
anyone other than an authorized repair facility, or
damage that is attributable to acts of God.
LIMITS AND EXCLUSIONS
There are no express warranties except as listed above.
THE WARRANTOR SHALL NOT BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES
(INCLUDING, WITHOUT LIMITION, DAMAGE
TO DISCS) RESULTING FROM THE USE OF THIS
PRODUCT, OR ARISING OUT OF ANY BREACH OF
THE WARRANTY. ALL EXPRESS AND IMPLIED
WARRANTIES, INCLUDING THE WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR
PARTICULAR PURPOSE, ARE LIMITED TO THE
APPLICABLE WARRANTY PERIOD SET FORTH
ABOVE.
Some states do not allow the exclusion or limitation
of incidental or consequential damages, or limitations
on how long an implied warranty lasts, so the above
exclusions or limitations may nor apply to you. This
warranty gives you specific legal rights and you may
other rights, which vary from state to state.
If you have a problem with this product that is not
handled to your satisfaction, then write the Consumer
Affairs Department at the Company address indicated
above.
In the USA and Puerto Rico
FOR SERVICE
CALL TOLL FREE
1-800-973-4390
66
(for Canada)
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
LIMITED WARRANTY STATEMENT
Panasonic Canada Inc. (also known as PCI) warrants this product to be free of
defects in material and workmanship under normal use during the applicable
warranty coverage period described below. PCI agrees to repair, or at its option,
exchange, any part that becomes defective. However, the product must be
purchased and serviced in Canada. The product or part that shows evidence of
defect must be delivered prepaid or carried in to an authorized Panasonic Broadcast
Service Center. This warranty does not cover shipping costs.
The warranty coverage period is one year for both parts and labour beginning with
the date of original end user purchase, subject to the exceptions as stated below.
Repaired or replacement parts supplied during the warranty coverage period carry
the unexpired portion of the original warranty coverage period. Proof of product
purchase is a condition of warranty service. The owner must produce the product
purchase receipt or other satisfactory evidence of date of original purchase.
This warranty does not apply to external appearance items, such as handles, knobs,
safety windows, etc. This warranty does not apply to any part, or parts, of the
product, installed, altered, repaired or misused in any way that, in the opinion of PCI,
affects the reliability of or detracts from the performance of the product.
For products requiring routine preventive maintenance, that maintenance must be
performed in order to maintain warranty coverage.
Serial numbers that have been altered, defaced or removed void this warranty. This
warranty does not cover replacements or repairs necessitated by loss or damage
resulting from any cause beyond the control of PCI.
Marking or retained images (sometimes called “burn-in”) resulting from the display of
fixed images on video display products are not defects and are not covered under
this warranty.
THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. IN NO EVENT WILL PANASONIC CANADA INC. BE LIABLE FOR
ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES.
In certain instances, some jurisdictions do not allow the exclusion or limitation of
incidental or consequential damages, or the exclusion of implied warranties, so the
above limitations and exclusions may not be applicable.
WARRANTY COVERAGE PERIOD EXCEPTIONS
Item
Video Tape
P2/SD Cards
Video Heads
D5 Video heads
Parts
30 days—Replacement only
(content not covered)
(Content not covered)
1 year or 2,000 hrs. (prorated)
Whichever comes first
1 year or 1,000 hrs.
Whichever comes first
90 days
2 years
Maintenance Items
Colour Camera CCD
Imaging Block
BT-H Series LCD Monitors 2 years
3 years or 17,000 hrs.
* DLP™ Projectors
Whichever comes first
3 years or 2,500 hrs.
* LCD Projectors above
Whichever comes first
2,500 ANSI Lumens
3 years or 1,500 hrs.
* LCD Projectors below
Whichever comes first
2,500 ANSI Lumens
50% of the rated lamp life or 1 year.
Projector Lamps
Whichever comes first
103 inch Plasma displays 3 year (burn-in not covered)
1 year plus balance (if any) of
Hard Drive Disk Unit
the original Manufacturer’s
Limited Warranty.
(Content not covered)
Labour
N/A
N/A
1 year or 2,000 hrs.
Whichever comes first
1 year or 1,000 hrs.
Whichever comes first
90 days
1 year
1 year
3 years or 17,000 hrs.
Whichever comes first
3 years or 2,500 hrs.
Whichever comes first.
3 years or 1,500 hrs.
Whichever comes first
50% of the rated lamp life or 1 year.
Whichever comes first.
3 year
1 year
• Dust, smoke, rental/staging environment and twenty-four/seven operation,
dramatically decreases the interval between performances of routine preventive
maintenance required to maintain this warranty coverage.
Warranty Service
If the product needs to be shipped for service, carefully pack (preferably in the
original carton) and enclose a letter, detailing the complaint. Send prepaid and
adequately insured to the local authorized Panasonic Service Centre in your
area or to Panasonic Technical Support and Product Services Department, 5770
Ambler Drive, Mississauga, Ontario, L4W 2T3. Shipping to the latter location
requires a return authorization before shipment. No liability is assumed for loss
or damage to the product while in transit.
67
68
Customer’s Record
The model number and serial number of this product can be found on its back cover. You should note this serial number
in the space provided below and retain this book, plus your purchase receipt, as a permanent record of your purchase
to aid in identification in the event of theft or loss, and for Warranty Service purposes.
Model Number
Serial Number
© Panasonic Corporation 2009
Panasonic Professional Display Company
Unit of Panasonic Corporation of North America
Executive Office :
One Panasonic Way 1F-10, Secaucus, NJ 07094
Panasonic Canada Inc.
5770 Ambler Drive
Mississauga, Ontario
L4W 2T3
Printed in Japan
M1009S0
Download PDF

advertising
