Avaya 4600 Series Telephone User Manual

4600 Series IP Telephone
LAN Administrator’s Guide
555-233-507
Issue 1.7
July 2002
Copyright 2002, Avaya Inc.
All Rights Reserved, Printed in U.S.A.
Notice
Every effort was made to ensure that the information in this book
was complete and accurate at the time of printing. However,
information is subject to change.
Avaya Web Page
The world wide web home page for Avaya is:
http://www.avaya.com
Preventing Toll Fraud
Toll fraud is the unauthorized use of your telecommunications system by an unauthorized party (for example, a person who is not a
corporate employee, agent, subcontractor, or working on your
company’s behalf). Be aware that there is a risk of toll fraud associated with your system and that, if toll fraud occurs, it can result
in substantial additional charges for your telecommunications services.
Avaya Fraud Intervention
If you suspect that you are being victimized by toll fraud and you
need technical support or assistance and are in within the United
States, call the Technical Service Center Toll Fraud Intervention
Hotline at 1.800.643.2353. If you need technical support or assistance and are outside of the United States, contact the equipment
vendor from whom you purchased your equipment service maintenance contract. If you need to report toll fraud issues regarding a
public telephone, contact the in-country telephone service provider.
Providing Telecommunications Security
Telecommunications security of voice, data, and/or video communications is the prevention of any type of intrusion to, that is,
either unauthorized or malicious access to or use of, your company’s telecommunications equipment by some party.
Your company’s “telecommunications equipment” includes both
this Avaya product and any other voice/data/video equipment that
could be accessed via this Avaya product (that is, “networked
equipment”).
An “outside party” is anyone who is not a corporate employee,
agent, subcontractor, or working on your company’s behalf.
Whereas, a “malicious party” is anyone, including someone who
may be otherwise authorized, who accesses your telecommunications equipment with either malicious or mischievous intent.
Such intrusions may be either to/through synchronous (time-multiplexed and/or circuit-based) or asynchronous (character-, message-, or packet-based) equipment or interfaces for reasons of:
• Utilization (of capabilities special to the accessed equipment)
• Theft (such as, of intellectual property, financial assets, or
toll-facility access)
• Eavesdropping (privacy invasions to humans)
• Mischief (troubling, but apparently innocuous, tampering)
• Harm (such as harmful tampering, data loss or alteration,
regardless of motive or intent)
Be aware that there may be a risk of unauthorized intrusions associated with your system and/or its networked equipment. Also
realize that, if such an intrusion should occur, it could result in a
variety of losses to your company, including but not limited to,
human/data privacy, intellectual property, material assets, financial resources, labor costs, and/or legal costs.
Federal Communications Commission Statement
Part 68: Network Registration Number. This equipment is registered with the FCC in accordance with Part 68 of the FCC Rules.
It is identified by FCC registration number AV1USA-43058-MFE.
Part 68: Answer-Supervision Signaling. Allowing this equipment to be operated in a manner that does not provide proper
answer-supervision signaling is in violation of Part 68 Rules. This
equipment returns answer-supervision signals to the public
switched network when:
• Answered by the called station
• Answered by the attendant
• Routed to a recorded announcement that can be administered by the CPE user
This equipment returns answer-supervision signals on all DID
calls forwarded back to the public switched telephone network.
Permissible exceptions are:
• A call is unanswered
• A busy tone is received
• A reorder tone is received
Industry Canada (IC) Interference Information
NOTICE: This equipment meets the applicable Industry Canada
Terminal Equipment Technical Specifications. This is confirmed
by the registration number. The abbreviation, IC, before the
registration number signifies that registration was performed
based on a Declaration of Conformity indicating that Industry
Canada technical specifications were met. It does not imply that
Industry Canada approved the equipment.
Le Présent Appareil Nomérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques
de la class A préscrites dans le reglement sur le brouillage
radioélectrique édicté par le Industrie Canada.
Trademarks
DEFINITY is a registered trademark of Avaya, Inc.
MultiVantage is a trademark of Avaya, Inc.
Ordering Information
Call:
Avaya Publications Center
U.S. and Canada Voice 1 800 457 1235
Outside U.S. and Canada Voice +1 410 568 3680
U.S. and Canada Fax 1 800 457 1764
Outside U.S. and Canada Fax +1 410 891 0207
Write:
GlobalWare Solutions
200 Ward Hill Avenue
Haverhill, MA 01835 USA
Attention: Avaya Account Manager
Email:
totalware@gwsmail.com
For additional documents, refer to the section in About This Guide
titled Related Documents. An online copy of this and other related
Avaya product documentation can be found at: http://
www.avaya.com/support.
Obtaining Products
To learn more about Avaya products and to order products,
access the Avaya web site at http://www.avaya.com. Or call
the following numbers: customers 1 800 451 2100, account
executives 1 888 778 1880 (voice) or 1 888 778 1881 (fax).
European Union Declaration of Conformity
The “CE” mark affixed to the equipment means that it conforms to the referenced European Union (EU) Directives
listed below:
EMC Directive
89/336/EEC
Low-Voltage Directive 73/23/EEC
For more information on standards compliance, contact your
local distributor.
4600 Series IP Telephone LAN Administrator’s Guide
Table of Contents
1
Introduction
About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Document Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
■ Change History
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
■ Terms Used in This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
■ Conventions Used in This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Online Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
2
Overview of Voice over IP (VoIP)
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Overview of Voice over IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
■ Data and Voice Network Similarities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
■ Delay and Jitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
■ Tandem Coding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
■ Voice Coding Standards
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
■ H.323 Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
■ DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
■ TFTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
■ NAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
■ QoS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Network Assessment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Suggestions for Installation and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
■ Reliability and Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
■ IP Address Lists and Station Number Portability . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
■ Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
4600 Series IP Telephones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Dual Connection Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
■ Single Connection Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
■ Registration and Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
■
TOC v
4600 Series IP Telephone LAN Administrator’s Guide
■
■
■
Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
WAN Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
DHCP and TFTP Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Initialization Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
■ Step 1: Telephone to Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
■ Step 2: DHCP Server to Telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
■ Step 3: Telephone and TFTP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
®
TM
■ Step 4: Telephone and the DEFINITY /MultiVantage
Call Server . . . . . . . . . . . . 2-9
3
Requirements
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Hardware Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Software Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
4
Server Administration
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Administering 4600 Series IP Telephones on
DEFINITY®/MultiVantageTM Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
®
■ DEFINITY
Release 8.4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
®
■ DEFINITY
Releases 9, 9.5, 10, and MultiVantageTM Release 11 . . . . . . . . . . . . . . 4-4
DHCP and TFTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Software Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Required Network Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Choosing a DHCP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
■ DHCP Software Alternatives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
■ DHCP Generic Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
■ Windows NT 4.0 DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
■ Windows 2000 DHCP Server
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
■
TFTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
■ TFTP Generic Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
■ Avaya TFTP (Suite Pro) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
4600 Series IP Telephone Scripts and Application Files . . . . . . . . . . . . . . . . . . . . . 4-18
■ Contents of the Upgrade Script . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
QoS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
■ IEEE 802.1D and 802.1Q
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
■ DIFFSERV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21
■ UDP Port Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
■ QoS with 4620 and 4630 IP Telephones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
■ RSVP and RTCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-23
Administering Options for the 4600 Series IP Telephones . . . . . . . . . . . . . . . . . . . . 4-24
vi
TOC
Table of Contents
■
■
■
■
■
■
■
5
DNS Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24
Customizing the Site-Specific Option Number (SSON) . . . . . . . . . . . . . . . . . . . . . 4-25
Entering Options via the Telephone Dialpad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25
Customizing the 4630 IP Telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
4630 Backup/Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30
Call Log Archive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
Customizing the 4620 IP Telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
Troubleshooting Guidelines
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Error Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
The View Administrative Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
Appendix A: Avaya - 46xx IP Telephone MIB
Appendix B: Creating Websites for the 4630 IP Telephone
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1
General Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1
Browser Features and Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-2
■ Document Skeleton . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-2
■ Content-Based Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-3
■ Logical Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-4
■ Physical Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-4
■ Physical Spacing and Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-5
■ Lists and Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-5
■ Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-7
■ Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-7
■ Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-8
■ Forms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-8
■ Character Entities
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-9
■ Colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-9
■ Fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-9
■ Cookies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-10
Design Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-10
■ Fixed-Width Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-10
■ Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-11
■ Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-11
■ Fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-11
■ Maintaining Context . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-12
■ User Interaction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-12
TOC vii
4600 Series IP Telephone LAN Administrator’s Guide
Appendix C: Creating Websites for the 4620 IP Telephone
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1
General Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1
WML Document Skeleton . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-2
Text Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-4
Text Formatting Tags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-4
Anchor Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-5
Image Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-5
Event Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-7
Task Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-10
Input Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-11
Variable Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-14
Character Entities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-15
Colors and Fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-16
Summary Of WML Tags And Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-16
viii
TOC
Introduction
1
1
m
argoP
r
About This Guide
1
This guide provides a description of Voice over IP, describes how to administer the DHCP and
TFTP servers and covers how to troubleshoot operational problems with the 4600 Series IP
Telephones and the servers.
The 4600 Series IP Telephone product line is a supplement to Avaya’s IP Solutions platform.
Unless otherwise indicated, references in this document to "the DEFINITY® server" also
refer to the MultiVantageTM media servers.
Intended Audience
1
This document is intended for personnel administering the DHCP and TFTP servers to support the
4600 Series IP Telephones and those administering the Local Area Network (LAN) itself.
CAUTION:
Many of the products mentioned in this document are not supported by Avaya. Care should
be taken to ensure there is adequate technical support available for the TFTP and DHCP
servers. If the TFTP or DHCP servers are not functioning correctly, the 4600 Series IP
Telephones may not operate correctly.
About This Guide
1-1
4600 Series IP Telephone LAN Administrator’s Guide
Document Organization
1
The guide contains the following sections:
Chapter 1, Introduction
Provides an overview of the 4600 Series IP Telephone
Administrator’s document.
Chapter 2, Overview of Voice
over IP (VoIP)
Describes VoIP and factors influencing its performance that
must be considered when implementing this feature.
Chapter 3, Requirements
Describes the hardware and software requirements for Avaya’s
VoIP offering.
Chapter 4, Server
Administration
Describes the administration of DHCP and TFTP for the 4600
Series IP Telephones.
Chapter 5, Troubleshooting
Guidelines
Describes messages that may occur during the operation of the
4600 Series IP Telephones.
Appendix A, Avaya - 46xx IP
Telephone MIB
Provides the MIB specification for the 46xx IP Telephones
(4606, 4612, 4624, and 4630).
Appendix B, Creating
Websites for the 4630 IP
Telephone
Provides information on creating and customizing websites for
viewing on the 4630 IP Telephone. Also describes the current
capabilities and limitations of the 4630’s web browser.
Appendix C, Creating
Websites for the 4620 IP
Telephone
Provides information on creating and customizing websites for
viewing on the 4620 IP Telephone. Also describes the current
capabilities and limitations of the 4620’s web browser.
Change History
Issue 1.0
This document was issued for the first time in November 2000.
Issue 1.1
This version of the document, revised and issued in April 2001,
supports through DEFINITY® Release 9.
Issue 1.5
This version of the document was revised in June, 2001 to
support DEFINITY® Release 9.5.
Issue 1.6
This version of the document was revised to support DEFINITY®
Release 10 and the 4630 IP Telephone.
Issue 1.7
This is the current version of this document, revised to support
MultiVantageTM Release 11 and the 4602 and 4620 IP
Telephones.
Document Organization
1-2
1
Introduction
Terms Used in This Guide
802.1p
802.1Q
1
802.1Q defines a layer 2 frame structure that supports VLAN
identification and a QoS mechanism usually referred to as
802.1p, but the content of 802.1p is now incorporated in 802.1D.
ARP
Address Resolution Protocol, used to verify that the IP address
provided by the DHCP server is not in use by another IP
Telephone.
CELP
Code-excited linear-predictive; voice compression requiring only
16 kbps of bandwidth.
CLAN
Control LAN, type of TN799 circuit pack.
DHCP
Dynamic Host Configuration Protocol, an IETF protocol used to
automate IP Address allocation and management.
DiffServ
Differentiated Services, an IP-based QoS mechanism.
DNS
Domain Name System, an IETF standard for ASCII strings to
represent IP addresses.
IETF
Internet Engineering Task Force, the organization that produces
standards for communications on the internet.
LAN
Local Area Network.
LDAP
Lightweight Directory Access Protocol, an IETF standard for
database organization and query exchange.
MAC
Media Access Control, ID of an endpoint.
NAPT
Network Address Port Translation.
NAT
Network Address Translation.
PSTN
Public Switched Telephone Network, the network used for
traditional telephony.
QoS
Quality of Service, used to refer to a number of mechanisms
intended to improve audio quality over packet-based networks.
RRQ
Read Request packet, a message sent from the 4600 Series IP
Telephone to the TFTP server, requesting to download the
upgrade script and the application file.
RSVP
Resource ReSerVation Protocol, used by hosts to request
resource reservations throughout a network.
RTCP
RTP Control Protocol, monitors quality of the RTP services and
can provide real-time information to users of an RTP service.
RTP
Real-time Transport Protocol, provides end-to-end services for
real-time data (such as voice over IP).
TCP/IP
Transmission Control Protocol/Internet Protocol, a network-layer
protocol used on LANs and internets.
Document Organization
1-3
4600 Series IP Telephone LAN Administrator’s Guide
TFTP
Trivial File Transfer Protocol, used to provide downloading of
upgrade scripts and application files to the IP Telephones.
UDP
User Datagram Protocol, a connectionless transport-layer
protocol.
VLAN
Virtual LAN.
Conventions Used in This Guide
1
This guide uses the following textual, symbolic, and typographic conventions to help you interpret
information.
Symbolic Conventions
1
This symbol precedes additional information about a topic. This information is not
required to run your system.
CAUTION:
This symbol is used to emphasize possible harm to software, possible loss of data, or
possible service interruptions.
Typographic Conventions
1
This guide uses the following typographic conventions:
command
Words printed in this type are commands that you enter into your
system.
device
Words printed in this type indicate parameters associated with a
command for which you must substitute the appropriate value. For
example, when entering the mount command, device must be
replaced with the name of the drive that contains the installation disk.
Administrative
Words printed in bold type are menu or screen titles and labels, or items
on menus and screens that you select to perform a task.
italics
Italic type indicates a document that contains additional information
about a topic.
<Enter>
Words enclosed in angle brackets represent a single key that should be
pressed. These include <Ctrl>, <Enter>, <Esc>, <Insert>, and
<Delete>.
Document Organization
1-4
Introduction
Online Documentation
1
The online documentation for the 4600 Series IP Telephones is located at the following URL:
http://www.avaya.com/support
Related Documents
■
1
DEFINITY® Documentation Release 8.4
This CD contains documentation that describes, among other things, how to administer a
DEFINITY switch with Release 8.4 software.
This document is provided with the DEFINITY Release 8.4 product.
■
DEFINITY® Documentation Release 9
This CD contains documentation that describes, among other things, how to administer a
DEFINITY switch with Release 9 software.
This document is provided with the DEFINITY Release 9 product.
■
DEFINITY® Documentation Release 10
This CD contains documentation that describes, among other things, how to administer a
DEFINITY switch with Release 10 software.
This document is provided with the DEFINITY Release 10 product.
■
Avaya MultiVantageTM Software Documentation Release 11
This document describes how to administer a switch with Avaya MultiVantageTM software.
This document is provided with the MultiVantageTM Release 11 product.
The following documents are available on the web site listed above under Online
Documentation.
■
4600 Series IP Telephones Safety Instructions (for 4602/4606/4612/4620/4624/4630 IP
Telephones), Issue 1, July 2002 (555-233-779)
This document contains important user safety instructions for the 4600 Series IP Telephones.
■
30A Switched Hub Set Up Quick Reference, Issue 2, July 2002 (Comcode 700234750;
Document Number 555-236-700)
This document contains important safety and installation information for the 30A Switched
Hub.
■
4600 Series IP Telephone Installation Guide (555-233-128)
This document describes how to install 4600 Series IP Telephones. It also provides
troubleshooting guidelines for the 4600 Series IP Telephones.
■
4602 IP Telephone User Guide (555-233-780)
This document provides detailed information about using the 4602 IP Telephone.
Online Documentation
1-5
4600 Series IP Telephone LAN Administrator’s Guide
■
4606 IP Telephone User Guide (555-233-765) (Int’l 555-233-769)
This document provides detailed information about using the 4606 IP Telephone.
■
4612 IP Telephone User Guide (555-233-766) (Int’l 555-233-770)
This document provides detailed information about using the 4612 IP Telephone.
■
4620 IP Telephone User Guide (555-233-781)
This document provides detailed information about using the 4620 IP Telephone.
■
4624 IP Telephone User Guide (555-233-768) (Int’l 555-233-771)
This document provides detailed information about using the 4624 IP Telephone.
■
4630 IP Telephone User Guide (555-233-764)
This document provides detailed information about using the 4630 IP Telephone.
The following documents provide standards relevant to IP Telephony.
IETF Documents
1
The following documents are available for free from the IETF web site: http://www.ietf.org/
rfc.html.
Requirements for Internet Hosts - Communication Layers, October 1989, by R. Braden (STD
3: RFC 1122)
Requirements for Internet Hosts - Application and Support, October 1989, by R. Braden (STD
3: RFC 1123)
Internet Protocol (IP), September 1981, by Information Sciences Institute (STD 5: RFC 791),
as amended by Internet Standard Subnetting Procedure, August 1985, by J. Mogul and J.
Postel (STD 5: RFC 950)
Broadcasting Internet Datagrams, October 1984, by J. Mogul (STD 5: RFC 919)
Broadcasting Internet Datagrams in the Presence of Subnets, October 1984, by J. Mogul
(STD 5: RFC 922)
User Datagram Protocol (UDP), August 28, 1980, by J. Postel (STD 6: RFC 768)
Transmission Control Protocol (TCP), September 1981, by Information Sciences Institute
(STD 7: RFC 793)
Domain Names - Concepts and Facilities (DNS), November, 1987, by P. Mockapetris (STD 13:
RFC 1034)
Domain Names - Implementation and Specification (DNS), November 1987, by P. Mockapetris
(STD 13: RFC 1035)
The TFTP Protocol (Revision 2), (TFTP), July 1992, by K. Sollins, (STD 33: RFC 1350:) as
updated by TFTP Option Extension, May 1998, by G. Malkin and A. Harkin (RFC 2347)
An Ethernet Address Resolution Protocol (ARP), November 1982, by David C. Plummer (STD
37: RFC 826)
Dynamic Host Configuration Protocol (DHCP), March 1997, by R. Droms (RFC 2131)
Related Documents
1-6
Introduction
DHCP Options and BOOTP Vendor Extensions, March 1997, by S. Alexander and R. Droms
(RFC 2132)
RTP: A Transport Protocol for Real-Time Applications (RTP/RTCP), January 1996, by H.
Schulzrinne, S. Casner, R. Frederick, V. Jacobson (RFC 1889)
Definition of the Differentiated Services Field (DS Field) in the IPv4 and IPv6 Headers,
(DIFFSRV), December 1998, by K. Nichols, S. Blake, F. Baker and D. Black (RFC 2474)
Introduction to version 2 of the Internet-standard Network Management Framework
(SNMPv2), April 1993, by J. Case, K. McCloghrie, M. Rose, and S. Waldbusser (RFC 1441)
Management Information Base for Network Management of TCP/IP Internets: MIB-II, March
1991, edited by K. McCloghrie and M. Rose (RFC 1213)
SNMPv2 Management Information Base for the Internet Protocol using SMIv2, November
1996, edited by K. McCloghrie (RFC 2011)
Structure of Management Information Version 2 (SMIv2), April 1999, edited by K. McCloghrie,
D. Perkins, and J. Schoenwaelder (RFC 2578)
Resource ReSerVation Protocol VI, September 1997, by R. Braden, L. Zhang, S. Berson, S.
Herzog, and S. Jamin (RFC 2205)
ITU Documents
1
The following documents are available for a fee from the ITU web site: http://www.itu.int.
Recommendation G.711, Pulse Code Modulation (PCM) of Voice Frequencies, November
1988.
Recommendation G.729, Coding of speech at 8 kbit/s using Conjugate-Structure AlgebraicCode-Excited Linear-Prediction (CS-ACELP), March 1996.
Annex A to Recommendation G.729: Reduced complexity 8 kbit/s CS-ACELP speech codec,
November 1996.
Annex B to Recommendation G.729: A silence compression scheme for G.729 optimized for
terminals conforming to Recommendation V.70, November 1996.
Recommendation H.225.0, Call signalling protocols and media stream packetization for
packet-based multimedia communications systems, February 1998.
Recommendation H.245, Control protocol for multimedia communication, February 1998.
Recommendation H.323, Packet-based multimedia communications systems, February 1998.
Related Documents
1-7
4600 Series IP Telephone LAN Administrator’s Guide
ISO/IEC, ANSI/IEEE Documents
1
The following documents are available for a fee from the ISO/IEC standards web site: http:/
/www.iec.ch.
International Standard ISO/IEC 8802-2:1998 ANSI/IEEE Std 802.2, 1998 Edition, Information
technology - Telecommunications and information exchange between systems - Local and
metropolitan area networks- Specific requirements- Part 2: Logical Link Control.
ISO/IEC 15802-3: 1998 ANSI/IEEE Std 802.1D, 1998 Edition, Information technologyTelecommunications and information exchange between systems- Local and metropolitan area
networks- Common specifications- Part 3: Media Access Control (MAC) Bridges.
IEEE Std 802.1Q-1998, IEEE Standards for Local and Metropolitan Area Networks: Virtual
Bridged Local Area Networks.
Customer Support
1
For support for your 4600 Series IP Telephones, call the Avaya support number provided to you by
your Avaya representative or Avaya reseller.
Information about Avaya products can be obtained at the following URL:
http://www.avaya.com/support
Customer Support
1-8
Overview of Voice over IP (VoIP)
2
2
nP
I
Introduction
2
This chapter describes the differences between data and voice networks, and the factors that
influence the performance of VoIP. The installation and administration of 4600 Series IP
Telephones on DEFINITY® servers, and the installation and configuration of DHCP and TFTP are
addressed.
Overview of Voice over IP
2
The 4600 Series IP Telephones allow enterprises to use Voice over IP (that is, packet-switched
networks) instead of telephony over the Public Switched Telephone Network (PSTN). However,
the use of data networks for transmitting voice packets poses the problem that data networks were
not designed for the specific qualities required by voice traffic.
Data and Voice Network Similarities
2
Data and voice networks share similar functions due to the nature of networking.
■
Signaling is used to establish a connection between two endpoints.
In a voice network, signaling is used to identify who the calling party is trying to call and where
the called party is on the network. Traditional telephony uses terminals with fixed addresses
and establishes a fixed connection for the communication session between two such
terminals, allocating fixed bandwidth resources for the duration of the call.
IP communications constitute a connectionless network, having neither fixed addresses nor
fixed connections.
■
Addressing. Each terminal on a network must be identified by a unique address.
In a voice network the unique address is a permanent attribute, based on international and
national numbering plans, as well as those based on local telephone company practices and
internal customer-specific codes.
In IP communications, dial plans track extension numbers assigned to terminals. No fixed
connection path is needed.
Introduction
2-1
4600 Series IP Telephone LAN Administrator’s Guide
■
Routing is related to addressing and allows connections to be established between
endpoints.
Though these functions are common to data and voice networks, the implementations differ.
Delay and Jitter
2
Data traffic is generally short and comes in bursts. Data networks like the Internet were designed
to manage these bursts of traffic from many sources on a first-come, first-served basis. Data
packets are sent to multiple destinations, often without any attempt to keep them in a particular
order.
Voice networks are designed for continuous transmission during a call. The traffic is not bursty,
and the conversation uses a specific amount of bandwidth between the two ends for the duration
of the call.
Several features of data networks are unsuitable for voice telephony:
■
Data networks are designed to deliver data at the destination, but not necessarily within a
certain time. This produces delay (latency). In data networks, delay tends to be variable. For
voice messages, variable delay results in jitter, an audible chopiness in conversations.
■
Variable routing also can result in loss of timing synchronization, so that packets are not
received at the destination in the proper order.
■
Data networks have a strong emphasis on error correction, resulting in repeated
transmissions.
While data network concepts include prioritization of traffic types to give some forms of traffic
greater reliability (for example, for interactive transactions), data requirements tend to be not as
strict as most voice requirements.
Release 1.1 of the 4600 Series IP Telephones includes a dynamic jitter buffer. This feature
automatically smooths jitter to improve audio quality.
Tandem Coding
2
Tandem coding (also called transcoding) refers to the conversion of a voice signal from analog to
digital and back again. When calls are routed over multiple IP facilities, they may be subject to
multiple transcodings. The multiple conversions between analog and digital coding result in a
deterioration in the voice quality. Tandem coding should be avoided wherever possible in any
compressed voice system (for example, minimizing analog trunking on the PBX).
Overview of Voice over IP
2-2
Overview of Voice over IP (VoIP)
Voice Coding Standards
2
There are a number of voice coding standards. The Avaya 4600 Series IP Telephones offer the
options described below.
G.711, which describes the 64 kbps PCM voice coding technique. G.711-encoded voice is
already in the correct format for digital voice delivery in the public phone network or through
PBXs.
G.729A and G.729B, which describe adaptive code-excited linear-predictive (CELP)
compression that enables voice to be coded into 8 kbps streams.
Release 1.6 of the 4600 Series IP Telephones provides support for G.711 silence suppression and
custom packet loss concealment, which can improve audio quality significantly.
H.323 Standard
2
Internal signaling provides connection control and call progress (status) information. The H.323
standard is used for internal signaling for IP packet voice networks. H.323 defines more than
simply voice. It defines a complete multimedia network (voice, video, data), with everything from
devices to protocols. The H.245 standard links all the entities within H.323 by negotiating facilities
among participants and H.323 network elements.
The H.323 standard makes G.711 PCM compression the default form of compression. All other
compression formats are optional.
DHCP
2
Dynamic Host Configuration Protocol (DHCP) allows a server to assign IP addresses and other
parameters to devices such as the 4600 Series IP Telephones on an as-needed basis. This
eliminates the need to configure each end station with a static IP address. The DHCP application
also passes information to the 4600 Series IP Telephone, identifying the IP Addresses of the PBX
and the TFTP server and the path to the upgrade script and the application file on the TFTP server.
For further information, refer to DHCP and TFTP Servers on page 2-7 and DHCP on page 4-6.
TFTP
2
During the installation and, if necessary, during the reset of the 4600 Series IP Telephones, the
upgrade script and potentially, the application file, are downloaded from the Trivial File Transfer
Protocol (TFTP) server to each IP Telephone, simplifying the software upgrade process. For
further information, refer to DHCP and TFTP Servers on page 2-7 and TFTP on page 4-17.
Overview of Voice over IP
2-3
4600 Series IP Telephone LAN Administrator’s Guide
NAT
2
A Network Address Translator is an application that can be administered between your network
and the Internet. The NAT translates network layer IP addresses so your local intranet IP
addresses can duplicate global, Internet addresses. A detailed discussion of NAT is beyond the
scope of this document, but it should be noted that use of NAT can lead to problems affecting the
consistency of addressing throughout your network. In Release 1.6 and earlier Releases of the
4600 Series IP Telephones, NAT is not recommended for networks handling IP-based telephony
traffic. As of Release 1.7, all 4600 Series IP Telephones support NAT interworking; hence, there
are no problems with NAT and Release 1.7 of the 4600 Series IP Telephones. Note, however, that
support for NAT does not imply support for Network Address Port Translation (NAPT). Specifically,
the 4600 Series IP Telephones do not support communication to the PBX through any NAPT
device.
QoS
2
Quality of Service (QoS) is a term covering several initiatives to maximize the quality of the voice
heard at both ends of a call that originates, terminates, or both, on an IP-based telephone. These
initiatives include various prioritization schemes to offer voice packets a larger or prioritized share
of network resources. These schemes include standards such as IEEE’s 802.1D and 802.1Q, the
Internet Engineering Task Force’s (IETF’s) “Differentiated Services”, RTP Control Protocol (RTCP)
and Resource ReSerVation Protocol (RSVP), and port-based priority schemes such as UDP port
selection. Documentation for your LAN equipment will elaborate on the extent your network can
support any or all of these initiatives. See Chapter 4, Server Administration for some implications
of QoS for the 4600 Series IP Telephones.
As of Release 1.7, both the 4620 and 4630 IP Telephones provide information to the end user
about network audio quality that may be of use to the LAN Administrator. For specific information,
see QoS with 4620 and 4630 IP Telephones on page 4-22.
SNMP
2
Simple Network Management Protocol (SNMP) is a family of standards-based protocols and
procedures to allow vendor-independent management of data networks. Using a simple set of
protocol commands, an SNMP-compliant device will store information in standard format in one or
more Management Information Bases (MIBs). In general, devices will support the standardsspecific MIB termed MIB-II. In addition, devices may define one or more "custom MIBs" that
contain information about the specifics of the device.
Release 1.1 of the 4600 Series IP Telephones is fully compatible with SNMPv2c (a later version of
SNMP) and with Structure of Management Information Version 2 (SMIv2), although the telephones
will respond correctly to queries from entities that comply with earlier versions of SNMP, such as
SNMPv1. "Fully compatible" means that the telephones will respond to queries directed either at
the MIB-II or the Custom MIB. The 4600 Series IP Telephone Custom MIB is read-only (values
therein cannot be changed externally via network management tools). Similarly, although the 4600
Series IP Telephone’s MIB-II has read/write permissions in accordance with the standard, to
improve security any writes to MIB-II are saved but otherwise ignored.
SNMP
2-4
Overview of Voice over IP (VoIP)
More information about SNMP and MIBs can be found in the IETF references listed in Chapter 1,
Related Documents. Appendix A of this LAN Administration Guide lists the Custom MIB, which is
also available for download in *.txt format on the Avaya support website.
Network Assessment
2
The current technology allows optimum network configurations to deliver VoIP with perceived
voice quality close to that of the Public Switched Telephone Network (PSTN). Not every network is
able to take advantage of packet voice transmissions. Some data networks have insufficient
residual capacity for even compressed voice traffic. In addition, the usual approach to developing
data networks by integrating products from many vendors makes it necessary to test the
components for compatibility with Voice over IP traffic.
It is assumed that your organization has performed a network assessment (with or without the
assistance of Avaya) before attempting to install Voice over IP, in order to have a high degree of
confidence that the existing data network has the capacity to carry voice packet traffic and is
compatible with the required technology.
A network assessment would include a determination of the following:
■
A network audit to review existing equipment and evaluate its capabilities, including its ability
to meet planned voice and data needs.
■
A determination of network objectives, including the dominant traffic type, choice of
technologies, and setting voice quality objectives.
The assessment should leave you confident that the implemented network will have the capacity
for the foreseen data and voice traffic, and can support H.323, DHCP, TFTP, and jitter buffers in
H.323 applications.
It is important to distinguish between compliance with the minimal VoIP standards and support for
QoS which is needed to run VoIP on your configuration.
Suggestions for Installation and Configuration
2
Reliability and Performance
2
There is a cost/performance trade-off associated with Voice over IP. Greater reliability and
improved performance can be obtained through server redundancy and components with higher
bandwidth capabilities.
The reliability and performance of the traditional PBX systems have been very high. Although
much of the LAN is outside of the control of the PBX, there are several points to consider which
enhance the reliability and performance of the IP Telephone network.
Network Assessment
2-5
4600 Series IP Telephone LAN Administrator’s Guide
All 4600 Series IP Telephones support the tools "ping" and "traceroute." These are standard LAN/
WAN tools for identifying whether two points on a network can communicate with each other, and
what path a sample communication takes as it traverses the network from one point to the other.
All 4600 Series IP Telephones will respond appropriately to a ping or a traceroute message sent
from the DEFINITY® or MultiVantageTM switch or any other source on your network, although these
telephones will not, in general, initiate a ping or traceroute. With Release 1.6 of the 4600 Series IP
Telephones comes support of "remote ping" and "remote traceroute." The switch can instruct such
a 4600 Series IP Telephone to initiate a ping, or a traceroute, to a specified IP address. The
telephone will carry out that instruction and send a message to the switch informing it of the
results. See your DEFINITY® or MultiVantageTM Administration documentation for more details.
IP Address Lists and Station Number Portability
2
With Release 1.5 of the 4600 Series Telephones comes the capability to specify lists of IP
addresses (either dotted decimal or DNS format) for key elements of the network, rather than
merely one address for each. Specifically, you can specify up to 127 total characters in each list of
the following: router/gateways, TFTP servers, and the call server. When the 4600 telephone is
powered up or is rebooted, it attempts to establish communication with these various network
elements in turn, starting with the first address on the respective list. If the communication is
denied, or times out, the telephone proceeds to the next address on the appropriate list and tries
that one. The telephone does not report failure unless all the addresses on a given list have failed.
Obviously, this capability can significantly improve the reliability of IP telephony by maximizing the
likelihood the telephone can communicate with backup equipment if the primary equipment is
down or inaccessible (say, perhaps due to a limited network outage).
However, this capability also has the advantage of making station number portability easier.
Assume a situation where the company has multiple locations (for example, London and New
York), all sharing a corporate IP network. Users want to take their telephones from their offices in
London and bring them to New York. When users power up their telephones in the new location,
the local DHCP server will generally route them to the local switch, which denies service because
it knows nothing about these new users. However, with proper administration of the local DHCP
server, the telephone knows to try a second call server IP address, this one in London. The user
can then be automatically registered with the London switch.
Chapter 4 contains details on administration of DCHP servers for lists of alternate call servers,
router/gateways, and TFTP servers. For specific information, see DNS Addressing in Chapter 4.
Security
2
In VoIP, physical wire is replaced with an IP connection. The connection is more mobile.
Unauthorized relocation of the IP telephone allows unauthorized users to send and receive calls
as the valid owner. For further details on toll fraud, refer to the DEFINITY® or MultiVantageTM
documents in Chapter 1, Related Documents.
Suggestions for Installation and Configuration
2-6
Overview of Voice over IP (VoIP)
4600 Series IP Telephones
2
Dual Connection Architecture
2
Releases 1.0 and 1.1 of the 4600 Series IP Telephones use dual connection architecture to
communicate with the DEFINITY® or MultiVantageTM switch. In the dual connection architecture,
two station extensions must be administered for each telephone.
Single Connection Architecture
2
Release 1.5 and subsequent releases of the 4600 Series IP Telephones use single connection
architecture to communicate with the DEFINITY® or MultiVantageTM switch. In the single
connection architecture, only one station extension must be administered for each telephone.
Registration and Authentication
2
The DEFINITY® or MultiVantageTM switch supports the registering and authentication of 4600
Series IP Telephones using the extension and password. For further information, see Related
Documents on page 1-5.
Software
2
As shipped from the factory, the 4600 Series IP Telephones may not contain sufficient software for
registration and operation. When the phone is first plugged in, a software download from a TFTP
server is initiated. This gives the phone its proper functionality.
For downloads of software upgrades, the PBX provides the capability for a remote restart of the
4600 Series IP Telephone. As a consequence of restarting, the phone automatically restarts
reboot procedures. If new software is available, a download will result.
WAN Considerations
2
QoS is harder on a WAN than a LAN. A LAN assumes no bandwidth concerns. A WAN assumes a
finite amount of bandwidth. Therefore, QoS considerations are more significant when the IP
telephony environment includes a WAN. In addition, there are administrative and hardware
compatibility issues unique to WANs.
DHCP and TFTP Servers
2
The DHCP server provides the following information to the 4600 Series IP Telephone:
■
■
IP address of the 4600 Series IP Telephone
IP Address and port number of the TN799 board on the DEFINITY® or MultiVantageTM Call
server. On the call server, the standard port number is 1719.
4600 Series IP Telephones
2-7
4600 Series IP Telephone LAN Administrator’s Guide
■
IP Address of the TFTP server
■
The subnet mask
■
IP Address of the router
You should administer the LAN so that every IP Telephone can access a DHCP server with the
above information.
The IP Telephone will not function without an IP address. The failure of a DHCP server at boot
time will leave all the affected voice terminals unusable. (Although it is possible for the user to
manually assign an IP address to an IP Telephone, when the DHCP server finally returns, the
telephone will never look for a DHCP server unless the static IP data is unassigned manually. In
addition, manual entry of IP data is an error-prone process.) It is therefore strongly
recommended that a DHCP server be available when the IP Telephone reboots.
A minimum of two DHCP servers is recommended for reliability.
The TFTP server provides the 4600 Series IP Telephone with a script file and, if appropriate, new
or updated application software (see Step 3, Telephone and TFTP Server under Initialization
Process below). In addition, you can edit the script file to customize telephone parameters for your
specific environment (see Administering Options for the 4600 Series IP Telephones in Chapter 4,
Server Administration).
Initialization Process
2
The following is a high-level description of the information exchanged when the telephone is
initializing and registering. This description, which assumes all equipment is properly administered
ahead of time, may be helpful in explaining how the 4600 Series IP Telephones relate to the
routers and servers in your network.
Step 1: Telephone to Network
2
The telephone is appropriately installed and powered, and after a short initialization process, the
telephone identifies the LAN speed and sends a message out into the network, identifying itself
and requesting further information. A router in the network receives this message, and relays it to
the appropriate DHCP server.
Step 2: DHCP Server to Telephone
2
The DHCP server provides information to the telephone, as described in DHCP and TFTP Servers
on page 2-7. Among other data passed to the telephone is the IP address of the TFTP server,
which is crucial for the next step.
Initialization Process
2-8
Overview of Voice over IP (VoIP)
Step 3: Telephone and TFTP Server
2
The telephone queries the TFTP server, which transmits a script file to the telephone. This script
file, at a minimum, tells the telephone which application file the telephone should be using (the
application file is the software that has the telephony functionality, and can be easily updated for
future enhancements).
The telephone uses the script file to determine if it has the proper application file. A newly-installed
telephone will have no application file, and hence does not have the proper one. A previouslyinstalled telephone may or may not have the proper application file. In any event, if the telephone
determines it does not have the application file the script file says the telephone should have, the
telephone requests a download of the proper application file from the TFTP server. The TFTP
server then downloads the file and conducts some checks to ensure the file was downloaded
properly. If the telephone determines it already has the proper file, it proceeds to the next step
without downloading the application file again.
Step 4: Telephone and the DEFINITY®/MultiVantageTM
Call Server
2
In this step, the telephone and the PBX exchange a series of messages which cause the display
on the telephone to prompt the user. For a new installation, the user must enter the telephone’s
extension and the call server password. For a restart of an existing installation, this information is
already stored on the telephone, but the user must confirm the information. In either case, manual
intervention is required. The telephone and the switch exchange more messaging, with the
expected result that the telephone is appropriately registered on the switch.
More details about the installation process are available in the 4600 Series IP Telephone
Installation Manual and in Chapter 3 of this document.
Initialization Process
2-9
4600 Series IP Telephone LAN Administrator’s Guide
Initialization Process
2-10
Requirements
3
3
m
argoP
r
Introduction
3
The 4600 Series IP Telephones use Internet Protocol (IP) technology with Ethernet line interfaces.
The IP telephones supplement the existing DEFINITY®/MultiVantageTM IP Solutions platform. This
feature provides the user with the capability to natively administer and maintain the new 4600
Series IP Telephones.
The 4600 Series IP Telephones provide support for DHCP and TFTP over IPv4/UDP which
enhance the administration and servicing of the phones. These phones use DHCP to obtain
dynamic IP addresses and TFTP to download new versions of software for the phones.
The 4600 Series IP Telephones provide the ability to have one connection on the desktop for both
the telephone set and the PC using the telephone’s built-in hub.
Hardware Requirements
3
Before plugging in the 4600 Series IP Telephone, verify that all of the following requirements have
been met. Failure to do so will prevent the telephone from working and may have a negative
impact on your network.
The following hardware is required for 4600 Series IP Telephones to work properly.
■
The DEFINITY® switch must be installed and administered correctly, with Release 8.4 or later.
— DEFINITY® Release 8.4 supports the 4612 and 4624 IP Telephones.
— DEFINITY® Release 9 and later support the 4606, 4612, and 4624 IP Telephones.
— DEFINITY® Release 10 and later support the 4630 IP Telephone.
— MultiVantageTM Release 11 supports the 4602 and 4620 IP Telephones.
Introduction
3-1
4600 Series IP Telephone LAN Administrator’s Guide
For Release 1.1 of any of the 4600 Series IP Telephones, the DEFINITY® switch must
have Release 9 software installed. For Release 1.5 of any of the 4600 Series
Telephones, the DEFINITY® switch must have Release 9.5 software. For Release 1.6 of
the 4600 Series IP Telephones, and for support of the 4630 IP Telephone, the
DEFINITY® switch must have Release 10 software. For Release 1.7 of the 4600 Series
IP Telephones, and for support of the 4602 and 4620 IP Telephones, the MultiVantageTM
switch must have Release 11 software.
■
The following two circuit packs must be resident on the PBX server used to support the IP
telephones:
— TN2302 AP Media Processor circuit pack converts the audio levels for the IP telephone to
audio levels for DCP phones when IP phones are used in a call with non-IP telephones.
— TN799 Control-LAN (CLAN) circuit pack for the signaling capability (either the B or C
vintage) on the csi, si, and r platforms.
■
A Category 5 LAN. If the telephones are to be powered from the LAN, the LAN must comply
with the IEEE 802.3af standard for LAN powering.
■
Electrical power provided to each phone by one of the following two sources.
— A Telephone Power Module (DC power jack) (must be ordered separately).
— IEEE 802.3af, if the LAN supports this powering scheme (although the 4630 cannot be
powered this way).
■
Verify that the 4600 Series IP Telephone package includes the following components:
— 1 telephone set.
— 1 AB1C handset.
— 1 H4DU 9-foot long (when extended) 4-conductor coiled handset cord, plugged into the
telephone and the handset.
— 1 Category 5 modular line cord for the connection between the IP Telephone and the
Ethernet wall plug.
— Non-system-specific safety and installation documentation.
— Power brick
— Stylus (4630 IP Telephones only)
■
You may need a Category 5 modular line cord for the connection from the 4600 Series IP
Telephone to the PC.
Refer to the 4600 Series IP Telephone Installation Guide.
The IP telephones work the same on all DEFINITY®/MultiVantageTM platforms.
Hardware Requirements
3-2
Requirements
Software Requirements
3
The following software is required for 4600 Series IP Telephones to work properly.
■
■
DEFINITY®/MultiVantageTM Release 8.4 or later software, as appropriate. The H.323 and IP
station customer options must be turned on.
The DHCP server and application should be installed and properly administered, as described
in DHCP on page 4-6.
WARNING:
A DHCP server is not mandatory, but static addressing is necessary when a DHCP
server is unavailable.
Due to the difficulties associated with static addressing, it is very strongly recommended
that a DHCP server be installed and that static addressing be avoided.
■
The TFTP server and application must be installed and properly administered, as described in
TFTP on page 4-17.
■
For 4630 IP Telephone environments, if users are to have access to LDAP directories or
corporate Websites, the appropriate servers must be in place, and the 4630 telephones must
be appropriately administered in accordance with Chapter 4, Server Administration.
Ensure that all required parameters are configured correctly. For DEFINITY/MultiVantage, see
your administration documentation. For the DHCP and TFTP servers, see Chapter 4, Server
Administration.
Figure 3-1 on the following page illustrates a sample configuration using the 4600 Series IP
Telephones.
Software Requirements
3-3
4600 Series IP Telephone LAN Administrator’s Guide
Figure 3-1. Sample Configuration Using 4600 Series IP Telephones
Software Requirements
3-4
Server Administration
4
4
n
P
I
Introduction
4
When a 4600 Series IP Telephone is plugged in and powered, it automatically negotiates with its
associated LAN to determine the Ethernet speed. From that point on, the actions taken by the
phone depend in large part on the action taken in the network before the phone is installed, and on
the actions taken, if any, by the installer. This chapter discusses in detail the parameters and other
data the telephone needs to operate and the alternatives for delivering that information to the
telephone, where appropriate. Recommendations and specifications on which alternative(s) to
choose for which parameter(s) are also provided.
The parameters under which the phone needs to operate are summarized as follows:
■
Telephone Administration on the Call Server
■
IP address management for the telephone
■
Tagging Control and VLAN administration for the telephone, if appropriate
■
Quality of Service (QOS) administration for the telephone, if appropriate
■
Site-specific Option Number (SSON) setting of DHCP servers, if appropriate
■
Interface administration for the telephone, if appropriate
■
Application-specific administration for the telephone, if appropriate (for example, Directory- or
Web-specific information required for these optional 4630 applications)
The delivery mechanisms are:
■
Maintaining the information on the Call Server (for example, the DEFINITY®/MultiVantageTM
switch)
■
Manually entering the information via the telephone dialpad
■
Administering the DHCP Server
■
Editing the script files on the TFTP Server
These parameters can be administered in a variety of ways, as indicated in Table 4-1, below. Note
that not all parameters can be administered on all delivery mechanisms.
Introduction
4-1
4600 Series IP Telephone LAN Administrator’s Guide
Table 4-1. Administration Alternatives and Options for 4600 Series IP Telephones
Parameter(s)
Administrative Mechanisms
For More Information See:
Telephone
Administration
Call Server
Administering 4600 Series IP
Telephones on DEFINITY®/
MultiVantage™ Servers on page 4-4
and Related Documents on page
1-5.
IP Addresses
DHCP (strongly recommended)
DHCP and TFTP on page 4-4,
especially DHCP on page 4-6.
TFTP Script files
DHCP and TFTP on page 4-4 and
Administering Options for the 4600
Series IP Telephones on page 4-24.
Manual administration at the phone
See "Static Addressing Installation"
in Chapter 3 of the 4600 IP
Telephone Installation Guide.
DHCP
DHCP and TFTP on page 4-4, and
Administering Options for the 4600
Series IP Telephones on page 4-24.
TFTP Script files (strongly
recommended)
DHCP and TFTP on page 4-4 and
Administering Options for the 4600
Series IP Telephones on page 4-24.
Manual administration at the phone
See "Static Addressing Installation"
in Chapter 3 of the 4600 IP
Telephone Installation Guide.
DHCP
DHCP and TFTP on page 4-4, and
Administering Options for the 4600
Series IP Telephones on page 4-24.
TFTP Script files (strongly
recommended)
DHCP and TFTP on page 4-4, and
Administering Options for the 4600
Series IP Telephones on page 4-24.
Manual administration at the phone
See "QOS Option Setting" in Chapter
3 of the 4600 IP Telephone
Installation Guide.
DHCP
DHCP and TFTP on page 4-4, and
Administering Options for the 4600
Series IP Telephones on page 4-24.
Tagging and
VLAN
Quality of
Service
Interface
Introduction
4-2
Server Administration
Parameter(s)
SSON
Applicationspecific
parameters
Administrative Mechanisms
For More Information See:
TFTP Script files (strongly
recommended)
DHCP and TFTP on page 4-4, and
Administering Options for the 4600
Series IP Telephones on page 4-24.
Manual administration at the phone
See "Secondary Ethernet (Hub)
Interface Enable/Disable" in Chapter
3 of the 4600 IP Telephone
Installation Guide.
DHCP
Customizing the Site-Specific Option
Number (SSON) on page 4-25;
DHCP and TFTP on page 4-4,
especially DHCP on page 4-6.
TFTP Script files (strongly
recommended)
Customizing the Site-Specific Option
Number (SSON) on page 4-25;
DHCP and TFTP on page 4-4,
especially TFTP on page 4-17.
Manual administration at the phone
See "Site-Specific Option Number
Setting" in Chapter 3 of the 4600 IP
Telephone Installation Guide.
DHCP
DHCP and TFTP on page 4-4,
especially DHCP on page 4-6. Also,
Customizing the 4630 IP Telephone
on page 4-26 and Customizing the
4620 IP Telephone on page 4-32.
TFTP Script files (strongly
recommended)
DHCP and TFTP on page 4-4,
especially TFTP on page 4-17. Also,
Customizing the 4630 IP Telephone
on page 4-26 and Customizing the
4620 IP Telephone on page 4-32.
General information about administering DHCP servers is covered in DHCP and TFTP on page
4-4, especially DHCP on page 4-6. General information about administering TFTP servers is
covered in DHCP and TFTP on page 4-4, especially TFTP on page 4-17. Once you are familiar
with that material, you will be able to administer options on the telephone in accordance with
Administering Options for the 4600 Series IP Telephones on page 4-24.
Introduction
4-3
4600 Series IP Telephone LAN Administrator’s Guide
Administering 4600 Series IP Telephones on
DEFINITY®/MultiVantage™ Servers
4
DEFINITY® Release 8.4
4
DEFINITY® Release 8.4 supports the 4612 and 4624 IP Telephones. The 4612 and 4624 IP
Telephones are aliased as 6424 telephones, administered as IP Softphones. The administrative
forms for the 6424 IP Softphone are used for the two IP Telephones. See Related Documents on
page 1-5. Follow these guidelines:
■
Alias the IP Telephone as a 6424D+ DCP set, with the IP Softphone field set to “y.”
■
Administer a Media Complex Ext for the audio channel.
DEFINITY® Releases 9, 9.5, 10, and MultiVantageTM
Release 11
4
DEFINITY® Releases 9 and 9.5 provide support for the 4606, 4612, and 4624 IP Telephones.
DEFINITY® Release 10 adds support for the 4630 IP Telephone. MultiVantageTM Release 11 adds
support for the 4602 and 4620 IP Telephones. Administration of a 4612 and 4624 IP telephone is
identical to a 6424 IP softphone. See Related Documents on page 1-5. Follow these guidelines:
■
On the Customer Options form, verify that the IP Stations field is set to “y.” If it is not, contact
your Avaya sales representative.
■
The IP Softphone field does not have to be set to “y.”
DHCP and TFTP
4
Dynamic Host Configuration Protocol (DHCP) provides a means by which configuration
parameters can be automatically assigned to clients on a TCP/IP network. This minimizes the
maintenance of a network of 4600 Series IP telephones by removing the need to assign and
maintain IP addresses and other parameters for each IP telephone on the network individually.
Administering 4600 Series IP Telephones on DEFINITY®/MultiVantage™ Servers
4-4
Server Administration
Software Checklist
4
Please make sure that you have purchased and/or own licenses to install and use the DHCP
server and TFTP server software.
It is possible to install both the DHCP server and the TFTP server on the same
machine.
WARNING:
The circuitry in the 4600 Series IP Telephones reserves IP addresses of the form
192.168.2.x for internal communications. The telephone(s) will not properly use addresses
you specify if they are of that form.
Required Network Information
4
DHCP is the control point where an enterprise controls its IP Telephones. Before administering
DHCP and TFTP, complete the information in Table 4-2 below to ensure that you have the
necessary information regarding your network. There may be more than one Gateway, TFTP
server, subnet mask and CLAN in your configuration. You will need a copy of this table for each
DHCP server.
Release 1.5 of the 4600 Series Telephones supports the ability to specify a list of IP addresses for
a gateway/router, TFTP server, and DEFINITY® CLAN board(s), as explained in Chapter 2, IP
Address Lists and Station Number Portability Each list may contain up to 127 total ASCII
characters, with IP addresses separated by commas with no intervening spaces.
When specifying IP addresses for the TFTP server or call server, you can use either dotted
decimal format ("xxx.xxx.xxx.xxx") or DNS names to identify the address(es). If you use DNS, note
that the system value DOMAIN will be appended to the IP addresses you specify. If DOMAIN is
null, the DNS names must be fully qualified, in accordance with IETF RFCs 1034 and 1035. For
more specific information about DNS, see DHCP Generic Setup (page 4-7) and DNS Addressing
(page 4-24).
Table 4-2. Required Network Information Before Installation - Per DHCP Server
1. Gateway (router) IP address(es)
2. TFTP server IP address(es)
3. Subnet mask
4. DEFINITY CLAN IP address(es)
Software Checklist
4-5
4600 Series IP Telephone LAN Administrator’s Guide
Table 4-2. Required Network Information Before Installation - Per DHCP Server
5. DEFINITY CLAN port
Although this may be a value between 0 and
65535, the default value is 1719 and should
not be changed unless this conflicts with an
existing port assignment.
6. TFTP server file path
7. Telephone IP address range
From:
To:
8. DNS Server address(es)
If applicable
The TFTP server file path is the “root” directory used for all transfers by the server. This is the
default directory which all files will be uploaded to or downloaded from. In configurations where the
upgrade script and application files are in the default directory, item 6 should not be used.
DHCP
4
This section provides information on possible DHCP servers and generic information on
administering a DHCP server.
Choosing a DHCP Configuration
4
A discussion on how to best set up your network to work with the 4600 Series IP Telephones is
beyond the scope of this document. See Network Assessment on page 2-5. This document
concentrates on the simplest case of the single LAN segment. Information provided here can be
extrapolated for more complex LAN configurations.
WARNING:
Before you start, it is important that you understand your current network configuration. An
improper installation can cause network failures or reduce the reliability and performance of
your network.
DHCP Software Alternatives
4
Two DHCP software alternatives are common to Windows operating systems:
■
Windows NT 4.0 DHCP Server
■
Windows 2000 DHCP Server
DHCP
4-6
Server Administration
Any other DHCP application may work.
It is the customer’s responsibility to install and configure the DHCP server correctly. This document
is limited to describing a generic administration that will work with the 4600 Series IP Telephones.
DHCP Generic Setup
4
Set up of a DHCP server involves the following phases:
1. Install the DHCP server software according to vendor instructions
2. Configure the DHCP server with the following information
■
IP addresses available for the 4600 Series IP Telephones
■
Lease duration (Infinite is recommended.)
■
The following DHCP options:
— Gateway (router) IP address(es) (Table 4-2, item 1). If more than one address is listed,
the total list may contain up to 127 total ASCII characters, with IP addresses
separated by commas with no intervening spaces.
— Subnet mask (Table 4-2, item 3).
— Option 6 (DNS server(s) address list). If more than one address is listed, the total list
may contain up to 127 total ASCII characters, with IP addresses separated by
commas with no intervening spaces. At least one address in Option 6 must be a valid,
non-zero, dotted decimal address - otherwise, DNS will fail.
— Option 15 (DNS Domain Name). This string should contain the domain name to be
used when DNS names in system parameters are resolved into IP addresses. This
domain name is appended to the DNS name before the 4600 IP Telephone attempts
to resolve the DNS address. Option 15 is necessary if you wish to use a DNS name for
the TFTP server; otherwise, you may specify a DOMAIN as part of TFTP
customization, as indicated in DNS Addressing on page 4-24.
— Option 66 (TFTP Server Name). Note: Microsoft DHCP servers support only dotteddecimal format for TFTP addresses, not symbolic names. Option 66 need not be used
if the TFTP server is identified in the Site Specific Option string (Option 176).
However, to simplify configuration, we recommend that you use Option 66. If you use
both Option 66 and Option 176 to identify TFTP servers, the value(s) in Option 176 will
override the value(s) in Option 66.
— A 4600 Series IP Telephone-specific DHCP option specifying information, such as
TFTP server and DEFINITY® CLAN IP addresses. Use the site-specific option
(SSON) at #176. The value for this option should be set to either of the following
strings:
MCIPADD=xxx.xxx.xxx.xxx,MCPORT=yyyy,TFTPSRVR=zzz.zzz.zzz.zzz,TFTPDIR=<
path>
OR
DHCP
4-7
4600 Series IP Telephone LAN Administrator’s Guide
MCIPADD={list of DNS names},MCPORT=yyyy,TFTPSRVR={list of DNS
names},TFTPDIR=<path>
In configurations where the upgrade script and application files are in the
default directory, the TFTPDIR=<path> should not be used.
You do not have to use Option 176. For example, if the DNS server is
specified in Option 6, and the Domain Name is specified in Option 15, you
can use the configured names "AvayaTFTPServer" and "AvayaCallServer"
for TFTPSRVR and MCIPADD, respectively.
The Call Server Name, TFTP Server Name, and SMTP Server Name must
each be no more than 32 characters in length.
Where xxx.xxx.xxx.xxx is one or more IP addresses for DEFINITY®/MultiVantageTM
CLAN IP boards, yyyy is the DEFINITY/MultiVantage CLAN port (1719),
zzz.zzz.zzz.zzz is one or more IP addresses for TFTP servers, and <path> is the
location of the location of the upgrade script and application files on the TFTP server
as entered in Table 4-2, items 4, 5, 2, and 7, respectively. Each list may contain up to
127 total ASCII characters, with IP addresses separated by commas with no
intervening spaces, and with quotes on either end (see the example in the NOTES
below). If you use DNS, note that the system value DOMAIN will be appended to the
IP addresses you specify. If DOMAIN is null, the DNS names must be fully qualified.
See Administering Options for the 4600 Series IP Telephones on page 4-24.
■
Examples of good DNS administration include the following:
- Option 6: "aaa.aaa.aaa.aaa"
- Option 15: "dnsexample.yourco.com"
- Option 66: "tftpserver.yourco.com,zzz.zzz.zzz.zzz"
- Option 176: "MCIPADD=xxxx.xxx.xxx.xxx"
DHCP
4-8
■
Depending on the DHCP application you choose, you should be aware of
the fact that the application most likely will not immediately recycle expired
DHCP leases. An expired lease may remain reserved for the original client
for a day or more (for example, Windows NT DHCP reserves expired
leases for about one day). The intent of this reservation period is to protect
a client’s lease in case the client and the DHCP server are in two different
time zones, the computers’ clocks are not in synch, or the client is not on
the network when the lease expires.
■
The implication of this fact may be seen in the following example: Assume
2 IP addresses (hence 2 possible DHCP leases) and 3 IP telephones, two
of which are using the 2 available IP addresses. When the lease expires
for the first two telephones, the third will not be able to get a lease (even if
the other two telephones have been removed from the network), until the
reservation period expires.
Server Administration
The 4600 Series IP Telephone sets the indicated system values to the values of the indicated
fields of the DHCPACK message as indicated in Table 4-3.
Table 4-3. DHCPACK Setting of System Values
System Value
Set to
IPADD
The yiaddr field.
NETMASK
Option #1 (if received).
GIPADD
The first four octets of option #3 (if received).
TFTPSRVR
The first four octets of the siaddr field.
The remainder of this section describes some common DHCP servers.
Windows NT 4.0 DHCP Server
4
This section contains details on how to verify and configure the DHCP server included in the
Windows NT 4.0 server operating system.
Use Verifying the Installation of the DHCP Server below to verify whether the DHCP server is
installed. If it is not, install the DHCP server. If it is installed, go to the section Initial Configuration
on page 4-9 and the following section.
Verifying the Installation of the DHCP Server
4
Use the following procedure to verify whether the DHCP server is installed.
1. Select Start->Settings->Control Panel.
2. Double-click the Network icon.
3. Verify that Microsoft DHCP Server is listed as one of the Network Services on the Services
Tab.
4. If it is, go to the section Initial Configuration below. If it is not, then install the DHCP server.
Initial Configuration
4
The Windows NT 4.0 DHCP server configuration involves setting up a scope for the IP telephone.
A DHCP scope is essentially a grouping of IP devices (in this case IP telephones) running the
DHCP client service in a subnet. The scope is used to define parameters for each subnet. Each
scope has the following properties:
■
A unique subnet mask used to determine the subnet related to a given IP address.
■
A scope name assigned by the administrator when the scope is created.
■
Lease duration values to be assigned to DHCP clients with dynamic addresses.
DHCP
4-9
4600 Series IP Telephone LAN Administrator’s Guide
In addition, the DHCP server can assign configuration parameters to a client, and these can be
specified for each individual DHCP scope.
Setting up of the Windows NT 4.0 DHCP server, requires the following steps.
1. Creating a DHCP scope for the IP Telephones.
2. Editing custom options.
3. Adding the DHCP options.
4. Activating the new scope.
Creating a DHCP Scope for the IP Telephones
4
Use the following procedure to create a DHCP scope for the IP Telephones.
1. Select Start->Programs->Admin Tools->DHCP Manager.
2. Expand Local Machine in the DHCP Servers window by double clicking on it until the + sign
changes to a - sign.
3. Select Scope->Create.
4. Define the range of IP addresses used by the IP telephones listed in Line 7 of Table 4-2.
The Start Address should be the first IP address to be used for the IP telephones.
The End Address should be the last IP address to be used for the IP telephones.
Subnet Mask should be set to the value as recorded in Table 4-2.
Perform the following steps to exclude any IP addresses that you do not want to be assigned
to IP telephones within the range specified by the Start and End Addresses.
a. Enter the first IP address in the range that you would like to exclude in the Start Address
field under Exclusion Range.
b.
Enter the last IP address in the range that you would like to exclude in the End Address
field under Exclusion Range.
c.
Click the Add button.
d. Repeat steps a. through c. for each IP Address range that you would like to exclude.
Example
Suppose the range of IP addresses available for your IP telephone network are:
■
135.254.76.7 to 135.254.76.80
■
135.254.76.90 to 135.254.76.200
■
135.254.76.225 to 135.254.76.230
Your start address and end address should then be 135.254.76.7 and 135.254.76.230
respectively.
DHCP
4-10
Server Administration
You should exclude the ranges 135.254.76.81 to 135.254.76.89 and 135.254.76.201 to
135.254.76.224.
We recommend that you provision the 4600 Series IP Telephones with
sequential IP addresses.
5. Under Lease Duration, select the Limited To option and set the lease duration to the
maximum.
6. Enter a sensible name for the Name field, such as “DEFINITY IP Telephones.”
7. Click OK.
A dialog box prompts you: Activate the new scope now?
8. Click No.
You will activate the scope when all options have been set.
Editing Custom Options
4
Use the following procedure to edit custom options:
1. Select DHCP Options->Defaults in the menu.
2. Click the New button.
3. Enter “46XXOPTION” for your custom in the Add Option Type dialog.
4. Select Data Type of String and enter 176 in the Identifier field.
5. Click the OK button.
The DHCP Options menu is displayed.
6. Select the Option Name for 176 and set the value string.
7. Click the OK button.
8. Select 003 Router from the drop-down list for the Option Name field.
9. Click Edit Array.
10. Enter the Gateway IP address recorded in Line 1 of Table 4-2 for the New IP Address field.
11. Select Add and then OK.
Adding the DHCP Option
4
Use the following procedure to add the DHCP option:
1. Highlight the scope you just created.
2. Select Scope under DHCP OPTIONS.
3. Select the 176 option that you created from Unused Option List.
DHCP
4-11
4600 Series IP Telephone LAN Administrator’s Guide
4. Click the Add button.
5. Select option 003 from the Unused Options List.
6. Click the Add button.
7. Click the OK button.
8. Chose the Global parameter under DHCP Comments.
9. Select the 176 option that you created from Unused Option List.
10. Click the Add button.
11. Click the OK button.
Activating the Leases
4
Use the following procedure to activate the leases:
1. Click Activate under the Scope Menu.
The light-bulb icon for the scope is lit up.
Verifying Your Configuration
4
This section describes how to verify that the 46XXOPTIONs are correctly configured for the
Windows NT 4.0 DHCP server.
Verify the Default Option, 176 46XXOPTION
4
Use the following procedure to verify the default option:
1. Select Start->Programs->Admin Tools->DHCP Manager.
2. Expand “Local Machine” in the DHCP Servers window by double clicking on it until the + sign
changes to a - sign.
3. In the DHCP Servers frame, click the scope for the IP Telephone.
4. Select Defaults from the DHCP_Options menu.
5. In the Option Name pull-down list, select 176 46XXOPTION.
6. Verify that the Value String box contains the correct string from DHCP Software Alternatives
on page 4-6.
If not, update the string and click the OK button twice.
Verify the Scope Option, 176 46XXOPTION
Use the following procedure to verify the scope option:
1. Select Scope under DHCP OPTIONS.
2. In the Active Options: scroll list, click on 176 46XXOPTION.
3. Click the Value button.
DHCP
4-12
4
Server Administration
4. Verify that the Value String box contains the correct string from DHCP Generic Setup on page
4-7.
If not, update the string and click the OK button.
Verify the Global Option, 176 46XXOPTION
4
1. Select Global under DHCP OPTIONS.
2. In the Active Options: scroll list, click 176 46XXOPTION.
3. Click the Value button.
4. Verify that the Value String box contains the correct value from DHCP Generic Setup on page
4-7.
If not, update the string and click the OK button.
Windows 2000 DHCP Server
4
This section describes the configuration of the DHCP server in Windows 2000.
Verifying the Installation of the DHCP Server
4
Use the following procedure to verify whether the DHCP server is installed:
1. Select Start->Program->Administrative Tools->Computer Management.
2. Under Services and Applications in the Computer Management tree, you should find DHCP.
3. If DHCP is not installed, install the DHCP server; otherwise please skip directly to Creating
and Configuring a DHCP Scope for instructions on server configuration.
Creating and Configuring a DHCP Scope
4
Use the following procedure to create and configure a DHCP scope:
1. Select Start->Programs->Administrative Tools->DHCP.
2. In the console tree, click the DHCP server to which you wish to add the DHCP scope for the IP
telephones. Typically this will simply be the name of your DHCP server machine.
3. Select Action->New Scope from the menu.
Windows displays the New Scope Wizard to guide you through rest of the setup.
4. Click the Next button.
The Scope Name dialog box is displayed.
5. Enter a name for the scope in the Name field, such as “DEFINITY IP Telephones,” and a brief
comment in the Description field.
6. Click the Next button when finished.
The IP Address Range dialog box is displayed.
DHCP
4-13
4600 Series IP Telephone LAN Administrator’s Guide
7. Define the range of IP addresses used by the IP telephones listed in item 7 in Table 4-2· The
Start IP Address should be the first IP address available to the IP telephones. The End IP
Address should be the last IP address available to the IP telephones.
8. You may define the subnet mask in one of two ways:
■
The number of bits of an IP address to use for the network/subnet IDs.
■
The subnet mask IP address.
Enter only one of these values. Click the Next button when finished.
The Add Exclusions dialog box is displayed.
9. Exclude any IP addresses in the range specified in the previous step that you do not wish to be
assigned to an IP telephone.
a. Enter the first IP address in the range that you would like to exclude in the Start Address
field under Exclusion Range.
b.
Enter the last IP address in the range that you would like to exclude in the End Address
field under Exclusion Range.
c.
Click the Add button.
d. Repeat steps a. through c. for each IP Address range that you would like to exclude.
You may add additional exclusion ranges later by right clicking on the Address Pool
under the newly created scope and select the New Exclusion Range option.
Example:
Suppose the ranges of IP addresses available for your IP telephone network are:
■
135.254.76.7 to 135.254.76.80
■
135.254.76.90 to 135.254.76.200
■
135.254.76.225 to 135.254.76.230
Your Start IP Address and End IP Address entered on the IP Address Range dialog box
should then be 135.254.76.7 and 135.254.76.230 respectively.
On the Add Exclusions dialog box, you should exclude the following ranges:
■
135.254.76.81 to 135.254.76.89
■
135.254.76.201 to 135.254.76.224
Click the Next button when all the exclusions have been entered.
The Lease Duration dialog box is displayed.
10. Enter 30 days in the lease duration for all telephones that will receive their IP addresses from
the server. This is the duration after which a device’s IP address expires and needs to be
renewed by the device.
11. Click the Next button.
The Configure DHCP Options dialog box is displayed.
DHCP
4-14
Server Administration
12. Click the No, I will activate this scope later radio button.
The Router (Default Gateway) dialog box is displayed.
13. For each router or default gateway, enter the IP address and click the Add button.
When you are done, click the Next button.
The Completing the New Scope Wizard dialog box is displayed.
14. Click the Finish button.
You new scope is added under your server in the DHCP tree. It is not yet active and will not
assign IP Addresses.
15. Highlight the newly created scope and select Action->Properties from the menu.
16. Under Lease duration for DHCP clients, select Unlimited and then click the OK button.
WARNING:
IP Address leases are kept active for varying periods of time. To avoid having calls
terminated suddenly, make the lease duration unlimited.
Adding DHCP Options
4
Use the following procedure to add DHCP options to the scope you created in the previous
procedure:
1. On the DHCP window, right-click the "Scope Options" folder under the scope you created in
the last procedure.
A drop-down menu is displayed.
2. Click the Configure Options... option.
The Scope Options dialog box is displayed.
3. In the General tab page, under the Available Options, check the 066 ’Boot Server Host Name’
Options checkbox.
The String Value dialog box is displayed.
4. Enter the TFTP Server address(es) in the string value. Use the same TFTPSRVR value format
as discussed in the TFTP Generic Setup section. For example, if you had a TFTP server at IP
address zzz.zzz.zzz.zzz and a second TFTP server at address tftpserver.yourco.com, in the
string value enter:
"zzz.zzz.zzz.zzz,tftpserver.yourco.com"
5. Also under the Available Options, check the 176 Site-Specific Options checkbox.
6. Click the Add button and then the Edit Array button.
The IP Address Array Editor dialog box is displayed.
7. Enter the IP Address(es) for the TFTP Server(s) supporting the IP Telephones.
8. Click the OK button.
The Predefined Options and Values dialog box is displayed.
DHCP
4-15
4600 Series IP Telephone LAN Administrator’s Guide
9. Click the OK button.
The Predefined Options and Values dialog box is closed, leaving the DHCP dialog box
enabled.
10. Expand the newly created scope to reveal its Scope Options.
11. Click Scope Options and select Action->Configure Options from the menu.
12. In the General tab page, under the Available Options, check the 176 Site-Specific Options
checkbox.
13. In the Data Entry box, enter the DHCP IP telephone option string as described in DHCP
Generic Setup on page 4-7.
You can enter the text string directly on the right side of the Data Entry box under the
ASCII label.
14. From the list in Available Options, check option 003 Router.
15. Enter the gateway (router) IP address as recorded in the IP Address field of Table 4-2.
16. Click the Add button.
17. Click the OK button.
Activating the New Scope
4
Use the following procedure to activate the new scope.
1. In the DHCP console tree, click the IP Telephone Scope created.
2. From the Action menu, select Activate.
The small red down arrow over the scope icon disappears, indicating that the scope has been
activated.
DHCP
4-16
Server Administration
TFTP
4
This section describes how to set up a TFTP server for downloading software updates to the 4600
Series IP Telephones.
WARNING:
The files defined by the TFTP server configuration have to be accessible from all IP
Telephones. Ensure that the filenames match the names in the upgrade script, including
case, since UNIX systems are case sensitive.
You can use any TFTP application you want. However, we strongly recommend
using the TFTP application available for free download at www.avaya.com/support.
The site also contains instructions for installing and configuring the Avaya TFTP
server.
TFTP Generic Setup
4
The following phases are involved in setting up a TFTP server.
■
Install the TFTP server software. The section below describes how to install and configure
Avaya’s TFTP application.
■
Configure the file path parameter to the directory where the files are to be stored. This is the
file path in line 6 of Table 4-2. For increased security, it is also recommended that you disable
the ability to upload to the server. Note that this option may be not available to all TFTP
servers.
■
In addition, you may wish to enable the transfer size option (tsize) if your TFTP server supports
it. This will allow the IP telephone to display the progress of the transfer by displaying the total
number of data blocks.
■
Download the upgrade script file and application file from the Avaya website (www.avaya.com/
support) to the directory as specified by the file path.
Avaya TFTP (Suite Pro)
4
Configuration
4
Use the following procedure to configure the Avaya TFTP server:
1. Run the TFTP Suite Pro server by selecting
Start->Programs->Avaya TFTP Server >TFTPServer32.
The TFTP server is started.
WARNING:
You must re-start Avaya TFTP manually every time you reboot your TFTP server
machine.
TFTP
4-17
4600 Series IP Telephone LAN Administrator’s Guide
2. Select System->Setup.
3. Enter the following values:
On the Outbound tab page: 1.
The Outbound path should be the TFTP file path as recorded in Table 4-2, Required Network
Information Before Installation - Per DHCP Server.
The Enable Path options should be checked.
Under the Options tab page: turn on the No Incoming option.
Under the Client Limits tab page: Set the Maximum Simultaneous Clients to infinite by
dragging the slide bar all the way to the right.
4. Place the 46xxupgrade.scr file in the file path directory. (The filename 46xxupgrade.scr is an
example, not the filename you will use. See Contents of the Upgrade Script on page 4-19.)
4600 Series IP Telephone Scripts and
Application Files
4
The files necessary to operate the 4600 Series IP Telephones are available on the following Avaya
web site:
www.avaya.com/support
Three files are needed:
■
A boot file, contained in the telephone when it is shipped from the factory. This file contains the
software that allows the telephone to connect to the LAN and attempt to acquire necessary
files and connectivity.
■
An upgrade script file, which at a minimum tells the telephone which application file it should
be using. The upgrade script file can also be used to point to a file you create to specific nondefault settings for key telephone parameters.
■
An application file, which contains all the telephony functionality of the telephone.
All three files are available from the Avaya website. In general, you do not need to download the
boot file, unless Avaya produces an enhancement to the file. The upgrade script and application
files always must be downloaded to the TFTP server.
The Avaya-provided default script file is sufficient to allow the telephone to use default settings, or
settings changed via DHCP or local programming on the telephone dialpad. However, to use TFTP
to customize values of the telephone parameters, you must create an ASCII file that resides in the
same directory as the upgrade script file mentioned above. This file must be called
46xxsettings.scr or 46xxxsettings.txt (see NOTE below). This file must consist of SET
commands, one per line, in this format:
SET parameter_name value
4600 Series IP Telephone Scripts and Application Files
4-18
Server Administration
where parameter_name and value are as defined in Tables 4-4, 4-5, and 4-6. Invalid values
cause the specified value to be ignored for the associated parameter_name; the default value is
retained..
Most Windows systems interpret the file extension *.scr as a screen saver. The 4600
IP Telephones originally used *.scr to indicate a script file, but starting with Release
1.7, the file name can also have the extension *.txt.
If you choose to create a custom parameter file, you can edit the last line of the
Avaya-provided default script file to be GET 46xxxsettings.txt.
All values should be text strings, even if the data itself is numeric, a dotted-decimal IP
address, etc.
You are encouraged not to alter the Avaya-provided upgrade script file. If Avaya
changes the file in the future, to accommodate new features or functionality, any
changes you might have made would be lost. You are strongly encouraged to use the
46xxsettings.scr file to manage your customization.
The GET command causes the telephone to use TFTP to attempt to download the
file specified in the GET command. This file is assumed to be at the same directory
as the current upgrade script file. If the file specified in the GET command is
successfully obtained, its contents are interpreted as an additional script file - that is
how your options are set. If the file cannot be obtained, interpretation of the rest of
the current script file is terminated (which is why we indicate the GET should be at
the end of the script file). You can change the name of the file in the GET command;
just ensure the target file is identically named and is located appropriately.
Table 4-4 lists the parameters, descriptions, and acceptable values for all 4600 Series IP
Telephones. Table 4-5 lists the parameters, descriptions, and acceptable values specific to
applications on the 4630 IP Telephone. Table 4-6 lists the parameters, descriptions and acceptable
values specific to applications on the 4620 IP Telephone.
Contents of the Upgrade Script
4
The following is a sample upgrade script file:
The filenames 4624_000301.BIN, 4606_000301.BIN, and 4630_00301.BIN used in
this sample are examples only. The names do not match those that are used in
production.
IF $BOOTNAME SEQ 46XXCOMMON.V03 GOTO GETAPP
SET APPNAME REPLBOOT_V3.APP
GOTO END
4600 Series IP Telephone Scripts and Application Files
4-19
4600 Series IP Telephone LAN Administrator’s Guide
#GETAPP
IF $MODEL4
IF $MODEL4
IF $MODEL4
IF $MODEL4
SEQ
SEQ
SEQ
SEQ
4630D01A
4624D01A
4612D01A
4606D01A
GOTO
GOTO
GOTO
GOTO
SCREENSETS
BIGSETS
BIGSETS
SMALLSETS
#SCREENSETS
SET APPNAME 4630_000301.BIN
GOTO END
#BIGSETS
SET APPNAME 4624_000301.BIN
GOTO END
#SMALLSETS
SET APPNAME 4606_000301.BIN
#END
GET 46XXSETTINGS.SCR
QoS
4
The 4600 Series IP Telephones support both IEEE 802.1D/Q and DiffServ, and may in the future
support other, possibly proprietary, procedures for implementing Quality of Service. In addition,
other network-based QoS initiatives such as UDP port selection do not require support by the
telephones, but nonetheless can contribute to improved QoS for the entire network.
IEEE 802.1D and 802.1Q
4
IEEE’s 802.1Q standard defines a tag that can be added to voice and data packets. Most of the
information associated with this tag deals with Virtual LAN (VLAN) management, but 3 bits are
reserved for identifying packet priority. These 3 bits allow any one of 8 priorities to be assigned to a
specific packet. As defined in the standard, the 8 priorities are, from highest to lowest:
■
7: Network management traffic
■
6: Voice traffic with less than 10ms latency
■
5: Voice traffic with less than 100ms latency
■
4: “Controlled-load” traffic (mission-critical data applications)
■
3: Traffic meriting “extra-effort” by the network for prompt delivery (for example, executives’
e-mail)
■
2: Reserved for future use
■
0: Traffic meriting the network’s “best-effort” for prompt delivery (the default priority)
QoS
4-20
Server Administration
■
1: Background traffic such as bulk data transfers and backups
Priority 0 is a higher priority than Priority 1.
To support IEEE 802.1D/Q, the 4600 Series IP Telephones can be administered either from the
network, via appropriate administration of the DHCP or TFTP servers, or at the telephone itself, via
dialpad input. Specific implementation details for local administration are in the Installation Manual,
and for remote administration are in this chapter, in 4600 Series IP Telephone Scripts and
Application Files on page 4-18. In summary, three IEEE 802.1D/Q QoS parameters in the
telephones can be administered. These parameters are:
■
L2Q: setting the 802.1Q framing parameter ON or OFF
■
L2QAUD: setting the 802.1Q audio priority value (between 0 and 7, default is 6)
■
L2QSIG: setting the 802.1Q signaling priority value (between 0 and 7, default is 6)
The 4600 Series IP Telephones can simultaneously support receipt of packets using, or not using,
802.1Q parameters.
WARNING:
If you turn VLAN framing on (L2Q=1) using the TFTP-based upgrade script
(46xxupgrade.scr), and you set your VLAN ID (L2QVLAN) to something other than
your default VLAN ID, the IP address you are using for the telephone will probably be
wrong for the new VLAN. See Administering Options for the 4600 Series IP
Telephones for more information.
DIFFSERV
4
As defined in IETF RFCs 2474 and 2475, “services” are basically ways of treating different subsets
of a network’s traffic in different ways at the Internet Protocol (IP) layer, Layer 3. For example,
some packets might be routed in such a way as to expedite delivery (minimize delay), while others
are routed to minimize loss, minimize cost, etc. The differentiation between these services (that is,
Differentiated Services) is provided by a redefinition of an octet in the Layer 3 headers for IP
versions 4 and 6, also termed IPv4 and IPv6, respectively. This octet is called a Type of Service
(TOS) octet in IPv4 and a Traffic Class octet in IPv6, but in both cases the octet is interpreted
differently than it was originally defined. With Differentiated Services, bits 0 through 5 of the octet
identify a Differentiated Services Code Point (DSCP) that identifies a procedure to be used to
handle that packet on a per-hop basis. Bits 6 and 7 of the octet are currently unused, and are
ignored by DSCP-compliant routers.
With DiffServ, the default DSCP is all zeroes, and represents “no special handling”. RFC 2474 also
defines eight “Class Selector Codepoints”, which are the eight DSCP encodings that can be
represented by xxx000 where “x” represents one bit. These Code Selector Codepoints are
considered prioritized, with the larger numerical values having a higher relative order. DSCPcompliant routers should treat larger-valued DSCPs in such a way as to give the associated
packets a “probability of timely forwarding” greater than a packet with a lower-valued DSCP. In
addition to the eight Class Selector Codepoints, a network may define its own DSCPs by defining
QoS
4-21
4600 Series IP Telephone LAN Administrator’s Guide
encodings that do not terminate in 000. The specific treatment intended by these custom DSCPs
will not necessarily be carried out by routers outside the customer’s own network.
To support DiffServ, the 4600 Series IP Telephones are administered at the switch in accordance
with the documentation for the switch.
UDP Port Selection
4
Some data networks include equipment that can perform UDP port selection. This is a mechanism
by which packets with port numbers in a given range are given priority over packets with port
numbers outside that range.
To support UDP port selection, the 4600 Series IP Telephones can be administered either from the
network, via appropriate administration of the DHCP or TFTP servers, or at the telephone itself, via
dialpad input. Specific implementation details for local administration are in the 4600 Series IP
Telephone Installation Guide, and, for remote administration, in 4600 Series IP Telephone Scripts
and Application Files on page 4-18. In summary, the system value MCPORT represents the port
on the TN2302AP board. This port number can be used to administer routers, etc. that support
UDP port selection, to maximize the priority given to the voice packets being exchanged between
the PBX and the telephone.
The default value for MCPORT is 1719. The switch must be administered to use a port within the
proper range for the specific LAN, and the IP Telephone(s) will copy that port. A related parameter
is PORTAUD, which is the RTP port used by the switch. In accordance with standards RFC 1889
and 1890, the IP Telephone uses a default value for PORTAUD of 5004. MCPORT and PORTAUD
are both administrable (see Administering Options for the 4600 Series IP Telephones on page
4-24).
QoS with 4620 and 4630 IP Telephones
4
As of Release 1.7, both the 4620 and 4630 telephones offer the end user an opportunity to monitor
network audio performance while on a call. The user guides for each phone go into specific details
on how the user gets to the appropriate screen; this document tells you what the end user can see,
and what it means. Specifically, the following parameters are displayed in real-time to users on the
appropriate screens, while on a call:
Parameter
Possible Values
Audio Connection Present?
Yes (if a receive RTP stream has been established)
No (if a receive RTP stream has not been established)
Received Audio Coding
G.711 or G.729
Silence Suppression
Yes (if the telephone knows the far-end has silence
suppression Enabled)
No (if the telephone knows the far-end has silence
suppression Disabled, or the telephone does not know
either way)
QoS
4-22
Server Administration
Parameter
Possible Values
Packet Loss
"No data" or a decimal percentage. Late and out-ofsequence packets are counted as lost, if they are
discarded. Packets are not counted as lost until a
subsequent packet is received and the loss confirmed by
the RTP sequence number.
Packetization Delay
"No data" or an integer number of milliseconds. The
number reflects the amount of delay in received audio
packets, and includes any look-ahead delay associated
with the codec.
One-way Network Delay
"No data" or an integer number of milliseconds. The
number is one-half the value RTCP computes for the
round-trip delay.
Network Jitter
Compensation Delay
An integer number of milliseconds reporting the average
delay introduced by the telephone’s jitter buffer.
In addition, based on the current values for the above parameters, the Network Audio Quality
Screen presents the user with a qualitative assessment of the overall audio quality currently being
experienced. This assessment is based on separate evaluations of the Packet Loss and the total
Network Delay (the sum of Packetization Delay, One-way Network Delay, and Network Jitter
Compensation Delay), and consideration of the codec in use.
The implication of this information for LAN administration depends, of course, on the values
reported by the user and the specific nature of your LAN (topology, loading, QoS administration,
etc.) The major use for this information is to give the user an idea of how network conditions are
affecting the audio quality of the current call. It is assumed you have more detailed tools available
for troubleshooting the LAN.
RSVP and RTCP
4
Resource ReSerVation Protocol (RSVP) is an IETF-standard protocol used by hosts to request
resource reservations throughout a network. RSVP-compliant hosts send messages through a
network to receivers, which respond with messages requesting a type of service and an amount of
resources (e.g., bandwidth) to carry out that service. The host is responsible for admitting
(approving) or rejecting (denying) the request. In a QoS context, RSVP is used to try to reserve
bandwidth in the network for voice calls, on a call-by-call basis. If insufficient bandwidth is available
for the target voice quality, a request to use network bandwidth for a voice call will be rejected.
RTP Control Protocol (RTCP), as its name implies, is a protocol that provides control functions for
Real-time Transport Protocol (RTP). RTP provides end-to-end network services for real-time data
(such as Voice over IP), but does not provide a reservation function, nor does it guarantee any
level of QoS. RTCP supplements RTP by monitoring the quality of the RTP services and can
provide real-time information to users of an RTP service. In a QoS context, RTCP is valuable for
identifying information such as packet loss, 1-way delay (how long a packet has to go from source
QoS
4-23
4600 Series IP Telephone LAN Administrator’s Guide
A to destination B), jitter, etc. RTCP itself does not improve QoS, but it provides information to you
to help identify where problem areas might be.
You cannot change the telephone’s RSVP or RTCP parameters directly on the telephone or via
TFTP or DHCP administration. The only way to change these parameters is by appropriate
administration of the switch. See your DEFINITY®/MultiVantageTM administration material for more
detail.
Administering Options for the 4600 Series IP
Telephones
4
As indicated in the Introduction of this chapter, there are many parameters that can be
administered for the 4600 Series IP Telephones. This section explains how to change parameters
via the DHCP or TFTP servers. In all cases, you will be setting a system parameter in the
telephone to a desired value. Table 4-4 lists the parameter names, their default values, the valid
ranges for those values, and a description of each one. For DHCP, the parameters below are set
as desired to desired values in the DHCP Option as discussed in DHCP Generic Setup earlier in
this chapter. For TFTP, the parameters below are set as desired to desired values in the TFTP
Script File as discussed in Contents of the Upgrade Script also earlier in this chapter.
TFTP Scripts are the recommended way to administer options on the 4600 Series IP Telephones.
Some DHCP applications have limits on the amount of user-specified information; such limits
could be exceeded by the administration required, for example, a 4630 with all applications
administered.
DNS Addressing
4
As of Release 1.5, the 4600 IP Telephones support DNS addresses as well as dotted decimal
addresses. The telephone attempts to resolve a non-ASCII-encoded dotted decimal IP address by
checking the contents of DHCP Option 6, as indicated in DHCP Generic Setup, page 4-7. At least
one address in Option 6 must be a valid non-zero dotted decimal address - otherwise, DNS will
fail. The text string in the system parameter DOMAIN (Option 15, see Table 4-4) is appended to
the address(es) in Option 6 before the telephone attempts to resolve the DNS address. If Option 6
contains a list of DNS addresses, they are queried in the order given, if no response is received
from previous addresses on the list. Alternatively to administering DNS via DHCP, you may specify
the DNS server and/or Domain name in the TFTP script file (in which case, you should SET the
values for DNSSRVR and DOMAIN first; then you may use those names later in the script).
If Options 6 and 15 are appropriately administered with DNS servers and Domain
names, respectively, MCIPADD and TFTPSRVR settings need not be specified in the
Site Specific Option string.
Administering Options for the 4600 Series IP Telephones
4-24
Server Administration
Customizing the Site-Specific Option Number
(SSON)
4
As discussed in DHCP Generic Setup on page 4-7, the SSON, defined to be 176 for the 4600
Series IP Telephones, can be set to a string. For each system parameter listed in Table 4-4 that
you want to include, append the following to the SSON string:
a comma followed by name=value
where name is a parameter name and value is its associated value. Invalid values will cause the
data to be ignored for that name. Customizing the SSON will affect all telephones associated with
that DHCP server.
Entering Options via the Telephone Dialpad
4
Chapter 3 of the 4600 Series IP Telephone Installation Guide details how to use the local
administrative options.
To customize any or all of the QoS parameters locally, follow the “QoS Option Setting” procedure in
Chapter 3 of the 4600 Series IP Telephone Installation Guide.
To enable or disable the secondary Ethernet hub locally, follow the “Secondary Ethernet (Hub)
Interface Enable/Disable” procedure in Chapter 3 of the 4600 Series IP Telephone Installation
Guide.
To view the 4600 IP Telephone system parameters, refer to Chapter 5, The View Administrative
Option, page 5-8.
Table 4-4. 4600 Series IP Telephone Customizable System Parameters
Parameter Name
Default Value
Description and Value Range
DNSSRVR
" " (Null)
Text string containing the IP address of one or more
DNS servers (at least one of which must be a valid,
non-zero, dotted decimal address.
DOMAIN
" " (Null)
Text string containing the domain name to be used
when DNS names in system values are resolved into
IP addresses.
IRSTAT
1
Text string containing status of Infrared interface (0=
off/disabled, 1= on/enabled).
L2Q
0
802.1Q framing (1= on or 0= off).
L2QAUD
6
Layer 2 audio priority value (0 to 7).
L2QSIG
6
Layer 2 audio priority value (0 to 7).
Administering Options for the 4600 Series IP Telephones
4-25
4600 Series IP Telephone LAN Administrator’s Guide
Table 4-4. 4600 Series IP Telephone Customizable System Parameters —Continued
Parameter Name
Default Value
Description and Value Range
L2QVLAN
0
802.1Q VLAN IDentifier (0 to 4095).
MCPORT
1719
Call server transport-layer port number (0-65535).
PHY2STAT
1
Secondary Ethernet interface status (0=off/disabled,
1=on/enabled). This parameter was called
"HUBSTAT" in telephones supporting Releases 1.0
through 1.5; 4600 Series IP Telephones supporting
Release 1.6 will respond to changes to "HUBSTAT"
by changing "PHY2STAT".
Table 4-4 applies to all 4600 Series IP Telephones. The 4630 and 4620 IP
Telephones have additional, optional administration. See Customizing the 4630 IP
Telephone and Customizing the 4620 IP Telephone, below, for more information.
Customizing the 4630 IP Telephone
4
The 4630 IP Telephone has some unique and powerful capabilities that take advantage of its large
display and access to LAN facilities. If your organization has an LDAP-compliant directory on your
LAN, or if your organization has a corporate website suitable for displaying on the 4630’s 1/4-VGA
display, you will need to provide the telephone with key information about the servers that provide
those facilities. Specifically, to administer the 4630 telephone for the LDAP Directory application,
you must provide the information called for in Table 4-5, below. To administer the 4630 telephone
for the Web Access application, you must provide the information called for in Table 4-5 on page
4-27. This information must be provided in a customized script file, in accordance with 4600 Series
IP Telephone Scripts and Application Files on page 4-18.
CAUTION:
For the 4630 to work properly, you must have a 46xxsettings.scr file in the same directory as
the 4630 application file. If you do not edit the 46xxsettings.scr file, the 4630 will use default
settings only. The 46xxsettings.scr file is part of the *zip file on the software download
website, and is also available as a standalone download. If you already have such a file
because you downloaded it for a previous release of the 4630, installing the *zip file will
overwrite the original file.
In Table 4-5, parameters shown with a Mandatory status must be accurate and non-null for the
application to work (however, the Avaya Help website will always be available). Parameters with an
Optional status may be changed to suit your environment; if they are not changed, the defaults will
be used.
Administering Options for the 4600 Series IP Telephones
4-26
Server Administration
Table 4-5. 4630 IP Telephone Customizable System Parameters by Application
Parameter Name
Default Value
Status
Description and Value
Range
Phone Application Parameters:
PHNEMERGNUM
" " (Null)
Optional
Text string of a phone
number to be dialed in case
of an emergency (e.g., 911)
Directory Application Parameters:
DIRSRVR
" " (Null)
Mandatory
Text string of dotted decimal
IP address, or DNS name,
of the server containing the
LDAP directory.
DIRTOPDN
" " (Null)
Mandatory
"Directory Topmost
Distinguished Name"; text
string of the root entry of the
LDAP directory.
DIRFULLNAME
cn
Optional
Text string for the customerspecific label for the
database field.
DIRTELNUM
telephoneNumber
Optional
Text string for the customerspecific label for the
database field containing
telephone numbers. The
default is the standard
LDAP value.
DIRSRCHTIME
0
Optional
Text string for an integer
number of seconds; the
maximum duration the
LDAP directory should
spend searching before
reporting completion or
failure of the search. The
default is LDAP-standard for
"unlimited duration."
Administering Options for the 4600 Series IP Telephones
4-27
4600 Series IP Telephone LAN Administrator’s Guide
Parameter Name
Default Value
Status
Description and Value
Range
DIRUSERID
" " (Null)
Optional
Text string for "Directory
User ID," which should be
modified if the LDAP server
requires a User ID and
password for access to the
Directory.
DIRSRVRPWD
" " (Null)
Optional
Text string for "Directory
Server Password," which
should be modified if the
LDAP server requires a
User ID and password for
access to the Directory.
DIRCODING
Latin 1
Optional
Text string identifying the
character set used by the
LDAP directory. Besides the
default value, "ASCII" is the
other valid value.
DIRLDAPPORT
389
Optional
Directory LDAP Port; the
port used to exchange
LDAP messages with the
server.
Optional
Text string identifying
whether the 4630 phones
are allowed to have the
Stock Ticker Application. "1"
is the default in the 4630; "0"
disables the Stock Ticker
Application.
Optional
Text string identifying the
character set used by the
Voice Mail Server
Application. Besides the
default value, other
supported values include
"Latin 1" and "Unicode".
Note that "Unicode" includes
support only for the Latin
characters of Unicode.
Stock Ticker Application Parameters:
STKSTAT
1
Voice Mail Application Parameters:
VMLCODING
ASCII
Administering Options for the 4600 Series IP Telephones
4-28
Server Administration
Parameter Name
VMLHOME
Default Value
" " (Null)
Status
Description and Value
Range
Mandatory
Text string containing the
URL of the home page for
the Voice Mail Application.
Web Access Application Parameters:
WEBHOME
" " (Null)
Mandatory
Text string containing the
URL of the home page for
the Web Access application.
WEBPROXY
" " (Null)
Optional
Text string containing the IP
address, in dotted decimal
or DNS format, of an HTTP
proxy server. This
parameter is optional if the
web pages to be accessed
by the user are all on your
organization’s intranet.
WEBEXCEPT
" " (Null)
Optional
Text string containing a list
of one or more HTTP proxy
server exception domains,
separated by commas, up to
a total of 127 ASCII
characters. This parameter
is optional if the web pages
to be accessed by the user
are all on your
organization’s intranet. If
WEBPROXY is null, the
value of this parameter is
ignored.
WEBPORT
80
Optional
Text string containing the
TCP port number for the
HTTP proxy server. The
default is the TCP default for
HTTP. This parameter is
optional if the web pages to
be accessed by the user are
all on your organization’s
intranet. If WEBPROXY is
null, the value of this
parameter is ignored.
Administering Options for the 4600 Series IP Telephones
4-29
4600 Series IP Telephone LAN Administrator’s Guide
Parameter Name
WEBCODING
Default Value
ASCII
Status
Description and Value
Range
Optional
Text string containing the
coding to be used for
characters entered in forms
on web pages. Besides the
default, other supported
values include "Latin 1" and
"Unicode". Note that
"Unicode" includes support
only for the Latin characters
of Unicode.
Backup/Restore Parameters:
FTPSRVR
" " (Null)
Mandatory
(but can be
userspecified
Text string containing a 4octet for the FTP server to
be used for storage and
retrieval of 4630 user
information (see 4630
Backup/Restore, page 4-
FTPDIR
" " (Null)
Optional
(and can be
userspecified)
Path name for the directory
on FTPSRVR used for
storage and retrieval of
4630 user information.
For assistance in developing local websites tailored to the 4630 IP Telephone’s
display, see Appendix B: Creating Websites for the 4630 IP Telephone.
4630 Backup/Restore
4
Backup/Restore automatically saves a phone’s speed dial button labels and options/parameter
settings. When the Automatic Backup option on a 4630 IP Telephone is set to "Yes" and the
FTPSRVR is specified, the FTPSTOR command attempts to save all Speed Dial contents and all
system options and (non-password) parameters to the FTP server (specified by FTPSRVR in the
directory path specified by FTPDIR). Data is saved in an ASCII text file called "4630data.txt". The
System Administrator may optionally specify FTPSRVR and/or FPTDIR via network
administration, however, these values may also be specified by the phone’s user, as covered in
"Chapter 8" of the 4630 IP Telephone User’s Guide. Automatic backup occurs whenever the user
executes a Save command on a Speed Dial or Options/Parameter screen.
Administering Options for the 4600 Series IP Telephones
4-30
Server Administration
In addition to Speed Dial labels and associated phone numbers, the following options and nonpassword parameters are saved during a backup:
Setting/Parameter Name
Type
Idle Timeout
Option
Keyboard Layout
Option
Click Feedback
Option
Edit Dialing
Option
Personalized Ring
Option
Redial
Option
Go to Phone on Answer
Option
Go to Phone on Originate
Option
Call Timer
Option
Alphabetize Entries?
Option
Call Log Active?
Option
Call Log Automatic
Archive
Option
Directory User ID
Parameter
Automatic Backup
Option
FTP Server IP Address
Parameter
FTP Directory Path
Parameter
FTP User ID
Parameter
Stock Ticker Active?
Option
STK.mm
Parameter
Stock Index DJIA
Option
Stock Index S&P 500
Option
Stock Index Nasdaq
Option
Administering Options for the 4600 Series IP Telephones
4-31
4600 Series IP Telephone LAN Administrator’s Guide
Setting/Parameter Name
Type
Stock Change
Option
Stock Volume
Option
If the Automatic Backup option is set to "No," speed dial data, options and parameter settings are
not saved unless the user forces a one-time backup via the appropriate option (as covered in
"Chapter 8" of the 4630 IP Telephone User’s Guide). Restoring backed-up data is done via a
separate user option, also covered in "Chapter 8" of the 4630 IP Telephone User’s Guide.
For specific error messages relating to Backup/Restore, see Table 5-4 on page 5-13.
Call Log Archive
4
Automatic archiving of the Call Log occurs when:
■
The Call Log Automatic Archive option setting is "Yes" and
■
The Call Log is more than 50% filled with unarchived entries, or a new (unarchived) log entry
occurs within two hours of the last archive (whichever occurs first).
Call Log Archive automatically saves applicable Call Log entries. When the Call Log Automatic
Archive option on a 4630 IP Telephone is set to "Yes" and the FTPSRVR is specified, the FTP
APPE command attempts to save all call log contents to the FTP server (specified by FTPSRVR in
the directory path specified by FTPDIR). Data is saved in a file called "4630calllog.txt". The
System Administrator may optionally specify FTPSRVR and/or FPTDIR via network
administration, however, these values may also be specified by the phone’s user, as covered in
"Chapter 8" of the 4630 IP Telephone User’s Guide. Automatic backup occurs whenever the user
executes a Save command on a Speed Dial or Options/Parameter screen.
For specific error messages relating to Archiving, see Table 5-4 on page 5-13.
Customizing the 4620 IP Telephone
4
In Table 4-6, parameters shown with a Mandatory status must be accurate and non-null for the
application to work. Parameters with an Optional status may be changed to suit your environment;
if they are not changed, the defaults will be used.
Administering Options for the 4600 Series IP Telephones
4-32
Server Administration
Table 4-6. 4620 IP Telephone Customizable System Parameters
Parameter Name
Default Value
Status
Description and Value
Range
Web Access Application Parameters:
WMLHOME
" " (Null)
Mandatory
Text string containing the
URL of the home page for
the Web Access application.
WMLPROXY
" " (Null)
Optional
Text string containing the IP
address, in dotted decimal
or DNS format, of an HTTP
proxy server. This
parameter is optional if the
web pages to be accessed
by the user are all on your
organization’s intranet.
WMLEXCEPT
" " (Null)
Optional
Text string containing a list
of one or more HTTP proxy
server exception domains,
separated by commas, up to
a total of 127 ASCII
characters. This parameter
is optional if the web pages
to be accessed by the user
are all on your
organization’s intranet. If
WMLPROXY is null, the
value of this parameter is
ignored.
WMLPORT
80
Optional
Text string containing the
TCP port number for the
HTTP proxy server. The
default is the TCP default for
HTTP. This parameter is
optional if the web pages to
be accessed by the user are
all on your organization’s
intranet. If WMLPROXY is
null, the value of this
parameter is ignored.
Administering Options for the 4600 Series IP Telephones
4-33
4600 Series IP Telephone LAN Administrator’s Guide
Parameter Name
WMLCODING
Default Value
ASCII
Status
Optional
Description and Value
Range
Text string containing the
coding to be used for
characters entered in forms
on web pages. Besides the
default, other supported
values include "Latin 1" and
"Unicode". Note that
"Unicode" includes support
only for the Latin characters
of Unicode.
For assistance in developing local websites tailored to the 4620 IP Telephone’s
display, see Appendix C: Creating Websites for the 4620 IP Telephone.
Administering Options for the 4600 Series IP Telephones
4-34
Troubleshooting Guidelines
5
5
P
Introduction
5
This chapter describes problems that may occur during operation of the 4600 Series IP
Telephones and possible ways of resolving these problems.
Error Conditions
5
Table 5-1 below identifies some of the possible operational problems that might be encountered
after successful installation of a 4600 Series IP Telephone. Problems that might be encountered
during installation, and how to conduct a Self-Test of the telephone, are discussed in the
Troubleshooting chapter of the 4600 Series IP Telephone Installation Guide. The 4630 IP
Telephone User’s Guide and 4620 IP Telephone User’s Guide also contain guidance for users
having problems with specific 4630 and 4620 applications, respectively.
Most of the problems reported by users of a 4600 Series IP Telephone are likely not to be
problems with the telephone itself. More likely, the problems will be centered on the LAN,
where Quality of Service, server administration, and other issues can impact end-user
perception of IP Telephone performance.
Table 5-1. Some Error Conditions in Operation of 4600 Series IP Telephones
Condition
The telephone continually reboots, or reboots
continuously about every 15 minutes.
Cause/Resolution
CAUSE: This is a firmware fault; the
MAC address in memory is corrupted.
RESOLUTION: The telephone must be
returned to Avaya for repair.
The message light on the telephone turns on and off
intermittently, but the telephone never registers.
CAUSE: This is a hardware fault.
RESOLUTION: The telephone must be
returned to Avaya for repair.
Introduction
5-1
4600 Series IP Telephone LAN Administrator’s Guide
Table 5-1. Some Error Conditions in Operation of 4600 Series IP Telephones —Continued
Condition
Cause/Resolution
The telephone stops
working in the middle of
a call,
AND No lights are lit on
the phone and the
display is not lit.
CAUSE: Loss of power
The telephone stops
working in the middle of
a call,
AND Power to the
telephone is fine (and
the telephone may have
gone through the
restarting sequence).
CAUSE: DHCP Lease expired or DHCP
server not available when telephone
attempts to renegotiate DHCP lease.
RESOLUTION: Check the connections
between the telephone, the power
supply, and the power jack.
RESOLUTION: Short-term, restart the
telephone.
Long-term, administer the DHCP
application to allow longer leases
(“Infinite” or “Unlimited” is
recommended).
The telephone had been
working, but does not
work now,
Error Conditions
5-2
AND no lights are lit on
the phone and the
display is not lit.
CAUSE: Loss of power.
power to the telephone
is fine, but there is no
dialtone. (Display might
show “System Busy”).
CAUSE: Loss of communication with the
PBX switch
RESOLUTION: Check the connections
between the telephone, the power
supply, and the power jack.
RESOLUTION: Check LAN continuity
from the PBX to the telephone (using
ping or trace-route), and from the
telephone to the PBX (by invoking a
feature button). Verify the LAN
administration has not changed for the
TN799 or TN 2302AP boards, or the
LAN equipment (routers, servers, etc.)
between the switch and the telephone.
Verify no one has locally changed the
telephone settings (by using the VIEW
and ADDR codes, as described in the
4600 Series IP Telephone Installation
Guide). Verify the volume on the
telephone is set high enough. Finally,
conduct a self-test.
Troubleshooting Guidelines
Table 5-1. Some Error Conditions in Operation of 4600 Series IP Telephones —Continued
Condition
The telephone had been
working, but does not
work now, (continued)
The telephone works,
but the audio quality is
poor, specifically:
Cause/Resolution
AND the telephone was
recently moved.
CAUSE: Loss of communication with the
PBX.
RESOLUTION: As above, but pay
particular attention to the possibility that
the telephone is being routed to a
different DHCP server, or even a
different PBX switch. If so, the new
server or switch may need to be
administered to support the telephone.
the network was
recently changed
(servers upgraded or
replaced, your
DEFINITY/MultiVantage
switches, etc.).
CAUSE: Loss of communication with the
PBX.
the user hears echo
when speaking on a
handset.
CAUSE: Echo from digital-to-analog
conversion on your DEFINITY/
MultiVantage trunk.
RESOLUTION: As above.
RESOLUTION: Verify which trunk is
causing the echo, and swap the trunk’s
Trunk Termination parameter on the
PBX.
the user hears echo on
a headset, but not on a
handset.
CAUSE: Improper headset adapter.
the user is on
speakerphone and
hears no echo, but the
far end hears echo.
CAUSE: Room acoustics
RESOLUTION: Replace adapter with
Avaya’s M12LU or 3412-HIC adapters.
The M12LU is recommended, since it
supports Automatic Gain Control.
RESOLUTION: Ensure there are six
inches or so of blank space to the right of
the telephone. If that is insufficient, use
the handset.
Error Conditions
5-3
4600 Series IP Telephone LAN Administrator’s Guide
Table 5-1. Some Error Conditions in Operation of 4600 Series IP Telephones —Continued
Condition
Cause/Resolution
the user experiences
sudden silences (gaps
in speech), static,
clipped or garbled
speech, etc.
CAUSE: Jitter, delay, dropped packets,
etc.
RESOLUTION: One or more Quality of
Service (QoS) features should be
implemented in the network (See
Chapter 3 of the 4600 Series IP
Telephone Installation Guide).
CAUSE: Improper (non-Category 5)
wiring.
RESOLUTION: Replace non-Category 5
wiring with Category 5 wiring.
The 4612 or 4624 IP Telephone works properly
except the phone does not ring.
CAUSE: The Ringer Off (RngOF)
softkey feature has been activated.
RESOLUTION: Use the softkey Menu
option to access the RngOF feature. A
downward-pointing triangle means the
Ringer is off. Ensure the triangle points
up. Also, check the Volume setting on
the telephone. Finally, do a Self-test on
the telephone.
The telephone works properly except for the
speaker.
CAUSE: The Speaker was turned off on
the PBX.
RESOLUTION: Administer the PBX to
allow that station’s speaker to operate. If
that does not work, do a Self-test on the
telephone.
The telephone works properly, except incoming
DTMF tones are not received.
CAUSE: The TN2302AP board does not
pass in-band DTMF tones.
RESOLUTION: None; the board is
operating as designed.
Error Conditions
5-4
Troubleshooting Guidelines
Table 5-1. Some Error Conditions in Operation of 4600 Series IP Telephones —Continued
Condition
The telephone works properly, except sidetone
DTMF is not heard.
Cause/Resolution
CAUSE: PBX suppresses sidetone
DTMF.
RESOLUTION: On PBX administration,
on the Change-System-Parameters
screen, enable On-Hook Dialing. If the
user has Hands-Free Answer (HFA) and
answers the call on the telephone’s
speakerphone, then switches to the
handset, pressing the dialpad buttons
does not send DTMF tones. This is a
known bug, and the only current
resolution is to disable HFA.
Hands-Free Answer (HFA) is administered but the
telephone did not automatically answer a call.
CAUSE: HFA only works if the
telephone is idle. If a second call comes
into the telephone while the first call is in
progress (including ringing before the
first call is answered), the second call is
ignored.
RESOLUTION: None.
The TFTP application terminates and asks for
registration.
CAUSE: Non-Avaya shareware or
freeware TFTP applications often cease
operating to request registration.
RESOLUTION:
Short-term: Restart the application.
Long-term: Register the product or
replace it with an application that does
not behave this way (for example,
Avaya’s TFTP application).
Error Conditions
5-5
4600 Series IP Telephone LAN Administrator’s Guide
Table 5-1. Some Error Conditions in Operation of 4600 Series IP Telephones —Continued
Condition
Cause/Resolution
The TFTP script file is
ignored or not used by
the telephone
CAUSE: The telephone expects lines of
the script file to terminate with a
<Carriage Return><Line Feed>. Some
UNIX applications only terminate lines
with <Line Feed>. Editing the script file
with a UNIX-based editor can strip
<Carriage Return>s from the file,
causing the entire file to be treated as a
comment, and thus be ignored.
RESOLUTION: Edit the script file with a
Windows-based editor, or another editor
that does not strip out the <Carriage
Return>.
AND the TFTP server is
a LINUX or UNIX
system.
CAUSE: UNIX and LINUX systems use
case-sensitive addressing and file
labels.
RESOLUTION: Verify the file names
and path in the script file are accurately
specified.
Power to the telephone is interrupted while the
telephone is saving the application file and the TFTP
application hangs.
CAUSE: The TFTP server hangs if
power is interrupted while a telephone is
saving the application file.
RESOLUTION: Restart the TFTP
server.
The DHCP server indicates the 4600 Telephone
reports itself as a Token Ring device, and refuses to
provide the telephone an address.
CAUSE: Early versions of the 4600
Series Telephones erroneously report
being a Token Ring device. With most
DHCP servers, this does not matter.
Some LINUX servers, however, will
refuse to issue addresses to Ethernet
devices reporting to be Token Ring
devices.
RESOLUTION: Administer the DHCP
server to delete all MAC and IP
addresses associated with Lucent
Technologies or Avaya, or allow the
associated DHCP leases to expire.
Error Conditions
5-6
Troubleshooting Guidelines
Table 5-1. Some Error Conditions in Operation of 4600 Series IP Telephones —Continued
Condition
Cause/Resolution
The user indicates a 4620-specific or 4630-specific
application is not accessible.
CAUSE: The 46xxsettings script file is
not pointed to accurately, or is not
properly administered to allow the
application.
RESOLUTION: Assuming the user is
meant to have that application, verify the
46xxsettings script file is properly
specified for your system, including case
(if your TFTP server is UNIX or LINUX)
and extension. Then, verify all the
relevant parameters (as indicated in
Table 4-5 and Table 4-6, as appropriate)
are accurately specified in the
46xxsettings file.
There are three areas where installers can troubleshoot problems before seeking assistance from
the system or LAN administrator:
1. Check the wiring (power and Ethernet) for the following:
■
Whether all components are plugged in correctly.
■
Check LAN connectivity in both directions to all servers (DHCP, TFTP, Call Server)
■
If the telephone is supposed to be powered from the LAN, ensure the LAN is properly
administered and is compliant with IEEE 802.3af.
2. If you are using static addressing, do the following:
■
Use the View command to find the names of the files being used and verify that these
filenames match those on the TFTP server. Check on the Avaya website to verify whether
the correct files are being used.
■
Use the ADDR option to verify IP addresses.
■
Use the QOS option to verify QoS parameters.
Refer to Chapter 3 of the 4600 Series IP Telephone Installation Guide.
3. If the 4600 Series IP Telephone is not communicating with the system (DHCP, TFTP, or Call
Server), make a note of the last message that was displayed and consult the system
administrator.
Error Conditions
5-7
4600 Series IP Telephone LAN Administrator’s Guide
The View Administrative Option
5
If you are using static addressing and encounter problems, use the following procedure to verify
the current values of system parameters and file versions.
Also use the ADDR option to view IP addresses (see “Static Addressing Installation” in
Chapter 3 of 4600 Series IP Telephone Installation Guide). These may have been
entered incorrectly. Verify whether you were provided with correct IP addresses.
1. While the phone is on-hook and idle, press the following sequence of keys on the faceplate of
the telephone:
Mute 8 4 3 9 # (Mute V I E W #)
Press the Mute key momentarily. Do not press this key while pressing other keys.
The 4630 IP Telephone does not have a dedicated Hold button; for all other 4600
Series IP Telephones, pressing the Hold button instead of the Mute button will also
work.
The following text is displayed left-justified at the top of the display:
View settings
*=next
#=exit
2. Press the * button at any time during viewing to display the next name and system value pair
from the list below, returning to the first pair after the last pair has been displayed.
Press the # button at any time during viewing to terminate the procedure and restore the user
interface to its previous state.
The View Administrative Option
5-8
Troubleshooting Guidelines
The names and values are displayed in the following order:
Table 5-2. Parameter Values
Name
System Value
Format
Model
46ccDccc
up to 8 ASCII graphics characters
Market
domestic
export
Only one value is displayed
Phone SN
cccccccccccc
cccccccc
Phone Serial Number, up to 18 ASCII graphic
characters
PWB SN
cccccccccccc
cccccccc
Printed Wiring Board (circuit board) Serial Number,
up to 18 ASCII graphic characters
PWB comcode
ccccccccc
9 ASCII numbered characters
MAC address
00:60:1D:hh:hh:hh
Each octet of the MAC address is displayed as a
pair of hexadecimal numbers.
filename1.exe
up to 16 ASCII graphic characters.
filename2.exe
Out of the box, there will be only one
filename.exe. After installation, there should be
two filenames. If there is only one, installation has
failed. Verify the problem, and then re-install the
telephone.
Error Messages
5
The 4600 Series IP Telephones issue messages in English only. The IP Telephones also display
messages from the switch, which outside the United States may issue messages in the local
language.
Table 5-3. Possible Error Messages During Installation or Operation of 4600 Series IP
Telephones
Error Message
Cause/Resolution
During Installation
Checksum error
CAUSE: Downloaded application file was not downloaded or
saved correctly.
RESOLUTION: The telephone automatically resets and attempts
to re-initialize.
Error Messages
5-9
4600 Series IP Telephone LAN Administrator’s Guide
Table 5-3. Possible Error Messages During Installation or Operation of 4600 Series IP
Telephones—Continued
Error Message
DHCP: CONFLICT
* to program
Cause/Resolution
CAUSE: At least one of the IP address offered by the DHCP
server conflicts with another address.
RESOLUTION: Review DHCP server administration to identify
duplicate IP address(es)
File too large
Cannot save file
CAUSE: The telephone does not have sufficient room to store the
downloaded file.
RESOLUTION: Verify the proper filename is administered in the
TFTP script file, and that the proper application file is located in
the appropriate location on the TFTP server.
Gateway Error
CAUSE: DEFINITY Release 8.4 does not have an H.323 station
extension for this telephone.
RESOLUTION: On the station administration screen, ensure the
DCP set being aliased for this IP telephone has an H.323 station
extension administered, in accordance with switch administration
instructions.
Hardware failure
CAUSE: Hardware failure prevented downloading of application
file,
RESOLUTION: Replace telephone.
IP Address in use by
another
CAUSE: The telephone has detected an IP address conflict.
No Ethernet
CAUSE: When first plugged in, the IP Telephone is unable to
communicate with the Ethernet.
RESOLUTION: Verify administration to identify duplicate IP
address(es).
RESOLUTION: Verify the connection to the Ethernet jack, verify
the jack is Category 5, verify power is applied on the LAN to that
jack, etc.
No file server address
CAUSE: The TFTP server IP address in the IP telephone’s
memory is all zeroes.
RESOLUTION: Depending on the specific requirements of your
network, this may not be an error. If appropriate, either administer
the DHCP server with the proper address of the TFTP server, or
administer the telephone locally using the ADDR option as
detailed in the 4600 Series IP Telephone Installation Guide.
Error Messages
5-10
Troubleshooting Guidelines
Table 5-3. Possible Error Messages During Installation or Operation of 4600 Series IP
Telephones—Continued
Error Message
System busy
Cause/Resolution
CAUSE: Most likely, the number of IP endpoints on the
DEFINITY/MultiVantage is already at maximum, Less likely,
network resource is unavailable.
RESOLUTION: The telephone was attempting to access a
network resource (DHCP server, TFTP server, or the DEFINITY/
MultiVantage) and was not successful. The resource being called
upon should be checked for its availability. If it appears
operational and properly linked to the network, verify addressing is
accurate and a communication path exists in both directions
between the telephone and the resource.
System Error
CAUSE: DEFINITY/MultiVantage has an unspecified problem.
RESOLUTION: Consult your DEFINITY or MultiVantage
Administration and Troubleshooting documentation.
During Registration
Extension error
CAUSE: An invalid DEFINITY/MultiVantage Registration
extension has been entered.
RESOLUTION: Re-enter the extension if mis-entered initially. If
appropriate, verify proper extension with respect to switch
administration.
Extension in use
CAUSE: The specified extension is already in use, according to
the PBX switch.
RESOLUTION: Wait a few minutes, and try again. This will work
for the case when the extension is correctly administered, but
service was interrupted and DEFINITY is not yet aware of that
fact. Otherwise, verify proper extension with respect to switch
administration.
Failed to set phone IP
address
CAUSE: The 4600 Series Telephone was originally installed on
one switch with Static Addressing, and has subsequently been
installed on another switch with an active DHCP server assigning
dynamic IP addresses.
RESOLUTION: Reset the telephone.
Incompatible
CAUSE: This release of DEFINITY does not support the current
version of the IP Telephone.
RESOLUTION: Upgrade to the current version of MultiVantage
software.
Error Messages
5-11
4600 Series IP Telephone LAN Administrator’s Guide
Table 5-3. Possible Error Messages During Installation or Operation of 4600 Series IP
Telephones—Continued
Error Message
Cause/Resolution
Message light blinks on and
off, and the telephone did
not complete registration.
CAUSE: The telephone has a hardware fault.
Password Error
CAUSE: An invalid PBX Registration password has been entered.
RESOLUTION: Replace the telephone.
RESOLUTION: Re-enter the password if mis-entered initially. If
appropriate, verify proper password with respect to switch
administration.
Resource Error
CAUSE: DEFINITY rejects the registration request.
RESOLUTION: Verify your DEFINITY or MultiVantage
Administration to ensure the telephone’s proper IP address,
extension, and password are being used.
Timeout Error
CAUSE: Protocol timeout error.
RESOLUTION: Retry. If failure continues, check network
congestion, addresses, etc. to identify cause of timeout.
Undefined Error
CAUSE: An error has occurred without an identifiable cause.
RESOLUTION: Conduct Self-test, restart the telephone, and if no
other cause becomes evident, replace the telephone.
Wrong Set Type
CAUSE: The PBX does not recognize the set type.
RESOLUTION: Ensure the PBX is properly administered to
expect the appropriate telephones for the IP address and
extension.
Error Messages
5-12
Troubleshooting Guidelines
Table 5-4. Possible Error Messages During 4630 Backup/Restore
Error Message
Cause/Resolution
Current options and Speed
Dial entries have not yet
been backed up.
CAUSE: An attempt to save the current options and speed dial
entries on the FTP server has not yet been made or is in progress.
The FTP Server Name is not
known. Please check the
FTP Server IP Address
CAUSE: Invalid or missing Server name.
RESOLUTION: Wait for a message stating that backup was
successful.
RESOLUTION: Verify the FTPSRVR address is the File Server to
which backup data should be saved. Verify that the FTPDIR value
is the correct directory path for that File Server.
The FTP Server has not yet
responded, so backup has
not yet succeeded.
CAUSE: The FTP Server has not responded to the attempt to
backup/restore.
The FTP Server has denied
access. Please check FTP
Setup parameters.
CAUSE: The FTP Server has reported that it did not store data.
The FTP Server was unable
to store the backup file.
CAUSE: The FTP Server has reported that it could not store the
data.
RESOLUTION: Try again, verify the FTP server address, verify
the FTP server is online, and/or verify the network connectivity.
RESOLUTION: Verify the FTP server setup parameters, as
indicated on the FTP Setup Parameters screen (see "FTP Setup"
Chapter 8 of the 4630 IP Telephone User’s Guide.
RESOLUTION: Verify administration and available capacity/
filespace on the FTP Server.
Error Messages
5-13
4600 Series IP Telephone LAN Administrator’s Guide
Error Messages
5-14
Appendix A: Avaya - 46xx IP Telephone MIB
Avaya - 46xx IP Telephone MIB
A
5
Avaya-46xxIPTelephone-MIB
DEFINITIONS ::= BEGIN
IMPORTS
enterprises, OBJECT-TYPE, MODULE-IDENTITY, Integer32, IpAddress
FROM SNMPv2-SMI
DisplayString
FROM RFC1213-MIB ;
endpointMIB MODULE-IDENTITY
LAST-UPDATED
"200206182000Z"
ORGANIZATION
"avaya"
CONTACT-INFO
"Robert Mitchell
email : robmitchell@avaya.com
(732) 817-6330"
DESCRIPTION
"MIB Module for 46xx IP Telephones through Release 1.61"
::= { ipEndpointMIBs 1 }
avaya
OBJECT IDENTIFIER ::= { enterprises 6889 }
avayaProducts OBJECT IDENTIFIER ::= { avaya 1 }
avayaMibs
OBJECT IDENTIFIER ::= { avaya 2 }
ipEndpointProducts
OBJECT IDENTIFIER ::= { avayaProducts 69 }
Avaya - 46xx IP Telephone MIB
A-1
4600 Series IP Telephone LAN Administrator’s Guide
ipEndpointMIBs OBJECT IDENTIFIER ::= { avayaMibs 69 }
endptID
OBJECT IDENTIFIER ::= { endpointMIB 1 }
endptMARKET
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "ID designation. This variable returns a string
specifying 'domestic' or 'export'."
::= { endptID 1 }
endptMODEL
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Model identifier. This variable returns a string
of up to 8 ASCII characters."
::= { endptID 2 }
endptMCIPADD
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "List of call server addresses. This variable
returns a sequence of IP addresses, in dotted-decimal or
DNS format and separated by commas, of call server IP
addresses available for use."
::= { endptID 3 }
Avaya - 46xx IP Telephone MIB
A-2
Avaya - 46xx IP Telephone MIB
endptMCIPINUSE
OBJECT-TYPE
SYNTAX
IpAddress
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Call server address. This variable returns a
4-octet string specifying the IP address of the call
server currently in use. "
::= { endptID 4 }
endptMCPORT
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Transport layer port number. This variable
returns an integer specifying the port number in use
by the current call server."
::= { endptID 5 }
endptPHONESN
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Housing serial number. This variable returns
a string of up to 18 ASCII characters, specifying the
serial number on the outside of the endpoint's housing."
::= { endptID 6 }
Avaya - 46xx IP Telephone MIB
A-3
4600 Series IP Telephone LAN Administrator’s Guide
endptPWBCC
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "PWB comcode. This variable returns a string of up to 9
numerical characters, specifying the comcode of the printed wiring
board of the endpoint."
::= { endptID 7 }
endptPWBSN
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "PWB serial number. This variable returns a
string of up to 18 ASCII characters, specifying the
serial number on the endpoint's printed wiring board."
::= { endptID 8 }
endptETHERADD OBJECT-TYPE
SYNTAX
OCTET STRING
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "MAC address. This variable returns a 6-octet string
specifying the endpoint's MAC address."
::= { endptID 9 }
Avaya - 46xx IP Telephone MIB
A-4
Avaya - 46xx IP Telephone MIB
endptESPEED
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Ethernet interface speed. This variable returns
a string specifying the endpoint's Ethernet interface
speed in Mbps: '100', '10', or '0'."
::= { endptID 10 }
endptIPADD
OBJECT-TYPE
SYNTAX
IpAddress
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "IP address. This variable returns a 4-octet
string specifying the endpoint's current IP address."
::= { endptID 11 }
endptDHCPLEASETIME
SYNTAX
OBJECT-TYPE
Integer32
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Duration of IPADD lease. This variable returns
an unsigned integer specifying the length of time of the
IPADD lease."
::= { endptID 12 }
Avaya - 46xx IP Telephone MIB
A-5
4600 Series IP Telephone LAN Administrator’s Guide
endptDHCPLEASERENEW
SYNTAX
OBJECT-TYPE
Integer32
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Renewal time of IPADD lease. This variable
returns an unsigned integer specifying the length
of time at which to renew the IPADD lease."
::= { endptID 13 }
endptDHCPLEASEREBIND
SYNTAX
OBJECT-TYPE
Integer32
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Rebind time of IPADD lease. This variable returns
an unsigned integer specifying the length of time at
which to rebind the IPADD lease."
::= { endptID 14 }
endptGIPADD
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "List of router addresses. This variable returns
a sequence of IP addresses, in dotted-decimal format
and separated by commas, of routers available for use."
::= { endptID 15 }
Avaya - 46xx IP Telephone MIB
A-6
Avaya - 46xx IP Telephone MIB
endptGIPINUSE
OBJECT-TYPE
SYNTAX
IpAddress
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Router address. This variable returns a 4-octet
string specifying the IP address of the router currently
in use."
::= { endptID 16 }
endptNETMASK
OBJECT-TYPE
SYNTAX
IpAddress
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Subnet mask. This variable returns a 4-octet
string specifying the subnet mask currently in use."
::= { endptID 17 }
endptTFTPDIR
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "TFTP server path name. This variable returns
a string of 0-127 ASCII characters, specifying
the path name currently prepended to file names used in
TFTP read operations."
::= { endptID 18 }
Avaya - 46xx IP Telephone MIB
A-7
4600 Series IP Telephone LAN Administrator’s Guide
endptTFTPSRVR OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "List of TFTP server addresses. This variable
returns a sequence of IP addresses, in dotted-decimal or
DNS format and separated by commas, of TFTP servers
available for use."
::= { endptID 19 }
endptTFTPINUSE
SYNTAX
OBJECT-TYPE
IpAddress
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "TFTP server address. This variable returns a
4-octet string specifying the IP address of the TFTP
server currently in use."
::= { endptID 20 }
endptBOOTNAME
SYNTAX
OBJECT-TYPE
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Boot code file ID. This variable returns
a string specifying the boot code file
used to initiate telephone operation."
::= { endptID 21 }
Avaya - 46xx IP Telephone MIB
A-8
Avaya - 46xx IP Telephone MIB
endptAPPNAME
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Application file ID. This variable returns
a string specifying the system-specific application file
that should be used for telephone operation."
::= { endptID 22 }
endptSSON
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Site-specific option number (SSON). This variable
returns an integer between 128 and 254 inclusive,
specifying the SSON in use. The default is 176."
::= { endptID 23 }
endptBBURST
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
obsolete
DESCRIPTION "Blackburst flag. This variable returns 0
if Blackburst is currently OFF, else 1."
::= { endptID 24 }
Avaya - 46xx IP Telephone MIB
A-9
4600 Series IP Telephone LAN Administrator’s Guide
endptHUBSTAT
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
obsolete
DESCRIPTION "Hub flag. This variable has been superseded by
endptPHY2STAT."
::= { endptID 25 }
endptDSCPAUD
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "DSCP for audio. This variable specifies the
Differentiated Services Code Point for audio currently
in use (between 0 and 63 inclusive)."
::= { endptID 26 }
endptDSCPSIG
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION " DSCP for signaling. This variable specifies the
Differentiated Services Code Point for signaling
currently in use (between 0 and 63 inclusive)."
::= { endptID 27 }
Avaya - 46xx IP Telephone MIB
A-10
Avaya - 46xx IP Telephone MIB
endptL2Q
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "802.1Q flag. This variable returns 0 if the Layer
2 802.1Q framing parameter is currently OFF, else 1."
::= { endptID 28 }
endptL2QAUD
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Audio priority. This variable returns an integer
between 0 and 7 inclusive specifying the current Layer 2
802.1Q audio priority value."
::= { endptID 29 }
endptL2QSIG
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Signaling priority. This variable returns an
INTEGER between 0 and 7 inclusive specifying the current
Layer 2 802.1Q signaling priority value."
::= { endptID 30 }
Avaya - 46xx IP Telephone MIB
A-11
4600 Series IP Telephone LAN Administrator’s Guide
endptL2QVLAN
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "VLAN Identifier. This variable returns an integer
between 0 and 4095 inclusive specifying the current
Layer 2 802.1Q VLAN Identifier value."
::= { endptID 31 }
endpt46XXUPGR OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Upgrade script ID. This variable returns
a string of up to 16 ASCII characters specifying the
name of the upgrade script retrieved by TFTP after the
most recent power-up or reset."
::= { endptID 32 }
endptDNSSRVR OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "List of DNS server addresses. This variable
returns a sequence of IP addresses, in dotted-decimal
format and separated by commas, of DNS servers
available for use."
::= { endptID 33 }
Avaya - 46xx IP Telephone MIB
A-12
Avaya - 46xx IP Telephone MIB
endptDNSINUSE OBJECT-TYPE
SYNTAX
IpAddress
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "DNS server address. This variable returns a
4-octet string specifying the IP address of the DNS
server currently in use."
::= { endptID 34 }
endptDOMAIN
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "List of DNS domain labels. This variable
returns a sequence of labels, separated by periods, for
use as the highest-level domain in resolving DNS names
in system values."
::= { endptID 35 }
endptRTCPMON OBJECT-TYPE
SYNTAX
IpAddress
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "RTCP Monitor address. This variable returns a
4-octet string specifying the IP address of the RTCP
monitor currently in use."
::= { endptID 36 }
Avaya - 46xx IP Telephone MIB
A-13
4600 Series IP Telephone LAN Administrator’s Guide
endptPHY2STAT
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Hub flag. This variable returns 0 if the
endpoint's secondary Ethernet interface is currently NOT
enabled, else 1."
::= { endptID 37 }
endptIRSTAT
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "IR Interface flag. This variable returns 0 if the
endpoint's IR interface is currently NOT enabled, else 1."
::= { endptID 38 }
endptSMTPSRVR
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "SMTP server IP addresses. This variable returns a
comma-separated list of SMTP server IP addresses available
for use, in dotted-decimal format."
::= { endptID 39 }
Avaya - 46xx IP Telephone MIB
A-14
Avaya - 46xx IP Telephone MIB
endptDSPVERSION OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "DSP Version. This variable returns a string of
up to 10 characters, that identifies the version of the
DSP firmware in the endpoint."
::= { endptID 40 }
endptLOGSRVR OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Event Log server address. This variable
returns at most one IP address, in dotted-decimal
or DNS format, of the server to be used for event logging. This
function is intended for Avaya use, in debugging if necessary."
::= { endptID 41 }
endptLOGSTAT
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Event Log flag. This variable returns 0 if the
endpoint's event logging capability is currently NOT
enabled, else 1. This function is intended for Avaya use,
in debugging if necessary."
::= { endptID 42 }
Avaya - 46xx IP Telephone MIB
A-15
4600 Series IP Telephone LAN Administrator’s Guide
endptAGCHAND OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Handset AGC status. This variable returns 1 if the
endpoint's handset Automatic Gain Control capability is currently
enabled, else 0."
::= { endptID 43 }
endptAGCHEAD OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Headset AGC status. This variable returns 1 if the
endpoint's headset Automatic Gain Control capability is currently
enabled, else 0."
::= { endptID 44 }
endptPHONECC OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Phone comcode. This variable returns a string of up to 9
numerical characters, specifying the comcode of the endpoint itself."
::= { endptID 45 }
endptNVM
OBJECT IDENTIFIER ::= { endpointMIB 2 }
Avaya - 46xx IP Telephone MIB
A-16
Avaya - 46xx IP Telephone MIB
endptNVMCIPADD OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "IP address of call server stored in Non-Volatile
Memory (NVM). This variable returns a 4-octet string or DNS string.
Default is AvayaCallServer."
::= { endptNVM 1 }
endptNVMCPORT OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "NVM Transport layer port number. This variable
returns an integer specifying the call server port number
stored in NVM."
::= { endptNVM 2 }
endptNVIPADD
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "NVM IP address. This variable returns a 4-octet
string specifying the endpoint's IP address stored in
NVM."
::= { endptNVM 3 }
Avaya - 46xx IP Telephone MIB
A-17
4600 Series IP Telephone LAN Administrator’s Guide
endptNVGIPADD OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "NVM Router address. This variable returns a 4octet string specifying the IP address of the router as
stored in NVM."
::= { endptNVM 4 }
endptNVNETMASK OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "NVM Subnet mask. This variable returns a 4-octet
string specifying the subnet mask as stored in NVM."
::= { endptNVM 5 }
endptNVTFTPSRVR OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "NVM TFTP server address. This variable returns
a 4-octet string specifying the IP address of the file
server as stored in NVM. The default is AvayaTFTPserver."
::= { endptNVM 6 }
Avaya - 46xx IP Telephone MIB
A-18
Avaya - 46xx IP Telephone MIB
endptNVSSON
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "NVM Site-specific option number. This variable
returns an integer between 128 and 254 inclusive,
specifying the SSON stored in NVM. The default is 176."
::= { endptNVM 7 }
endptNVBBURST OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
obsolete
DESCRIPTION "NVM Blackburst flag. This variable returns 0
if the Blackburst parameter in NVM is OFF, else 1."
::= { endptNVM 8 }
endptNVHUBSTAT OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
obsolete
DESCRIPTION "NVM Hub flag. This variable has been superseded by
endptNVPHY2STAT."
::= { endptNVM 9 }
Avaya - 46xx IP Telephone MIB
A-19
4600 Series IP Telephone LAN Administrator’s Guide
endptNVDSCPAUD OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "NVM DSCP for audio. This variable specifies the
Differentiated Services Code Point for audio stored
in NVM (integer between 0 and 63 inclusive)."
::= { endptNVM 10 }
endptNVDSCPSIG OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION " NVM DSCP for signaling. This variable specifies
the Differentiated Services Code Point for signaling
stored in NVM (integer between 0 and 63 inclusive)."
::= { endptNVM 11 }
endptNVL2Q
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "NVM 802.1Q flag. This variable returns 0 if the
Layer 2 802.1Q framing parameter in NVM is OFF, else 1."
::= { endptNVM 12 }
Avaya - 46xx IP Telephone MIB
A-20
Avaya - 46xx IP Telephone MIB
endptNVL2QAUD OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "NVM Audio priority. This variable returns an
integer between 0 and 7 inclusive specifying the Layer 2
802.1Q audio priority value stored in NVM."
::= { endptNVM 13 }
endptNVL2QSIG OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "NVM Signaling priority. This variable returns an
integer between 0 and 7 inclusive specifying the Layer 2
802.1Q signaling priority value stored in NVM."
::= { endptNVM 14 }
endptNVL2QVLAN OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "NVM VLAN Identifier. This variable returns an
integer between 0 and 4095 inclusive specifying the Layer
2 802.1Q VLAN Identifier value stored in NVM."
::= { endptNVM 15 }
Avaya - 46xx IP Telephone MIB
A-21
4600 Series IP Telephone LAN Administrator’s Guide
endptNVPHY2STAT OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "NVM Hub flag. This variable returns 0 if the
endpoint's secondary Ethernet interface parameter in
NVM is NOT enabled, else 1."
::= { endptNVM 16 }
endptNVLOGSTAT
SYNTAX
OBJECT-TYPE
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Event Log flag. This variable returns 0 if the
endpoint's event logging capability in NVM is currently
NOT enabled, else 1."
::= { endptNVM 17 }
endptNVAGCHAND OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Handset AGC status. This variable returns 1 if the
endpoint's handset Automatic Gain Control capability in NVM is
currently enabled, else 0."
::= { endptNVM 18}
Avaya - 46xx IP Telephone MIB
A-22
Avaya - 46xx IP Telephone MIB
endptNVAGCHEAD OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Headset AGC status. This variable returns 1 if the
endpoint's headset Automatic Gain Control capability in NVM is
currently enabled, else 0."
::= { endptNVM 19}
endptMaintenance
OBJECT IDENTIFIER ::= { endpointMIB 3 }
endptUPGRADESCRIPT
SYNTAX
OBJECT-TYPE
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Script loading status flag. This variable
returns '0' if the upgrade script (endpt46XXUPGR)
was successfully obtained and interpreted since the
last power-up or reset. This variable returns '1' if
the upgrade script was successfully obtained and but
NOT successfully interpreted since the last power-up
or reset. This variable returns '2' if the upgrade
script was NOT successfully obtained since the last
power-up or reset."
::= { endptMaintenance 1 }
Avaya - 46xx IP Telephone MIB
A-23
4600 Series IP Telephone LAN Administrator’s Guide
endptAPPINUSE
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Application file name. This variable returns
the name of the application file in the endpoint."
::= { endptMaintenance 2 }
endptAPPSTAT
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Application download flag. This variable
returns '0' if the most recent attempt to download
and store an application file was successful. This
variable returns '1' if the most recent attempt to
download an application file was successful but the
file was not successfully stored in NVM. This variable
returns '2' if the most recent attempt to download an
application file was NOT successful."
::= { endptMaintenance 3 }
endptDEFINITY OBJECT IDENTIFIER ::= { endpointMIB 4 }
Avaya - 46xx IP Telephone MIB
A-24
Avaya - 46xx IP Telephone MIB
endptPORTAUD
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Transport-layer audio port. This variable returns
the endpoint's transport layer port number for audio,
currently in use."
::= { endptDEFINITY 1 }
endptPORTSIG
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Transport-layer signaling port. This variable
returns the endpoint's transport layer port number for
signaling, currently in use."
::= { endptDEFINITY 2 }
endptFEIPADD
OBJECT-TYPE
SYNTAX
OCTET STRING
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Audio endpoint address. This variable returns
a 4-octet string specifying the address of the far-end
audio endpoint currently in use."
::= { endptDEFINITY 3 }
Avaya - 46xx IP Telephone MIB
A-25
4600 Series IP Telephone LAN Administrator’s Guide
endptFEPORT
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Audio endpoint port number. This variable returns
the far-end endpoint's transport layer port number for
audio, currently in use."
::= { endptDEFINITY 4 }
endptCODECR
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Receive codec. This variable returns the
designation of the Receive codec currently in use."
::= { endptDEFINITY 5 }
endptCODECT
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Transmit codec. This variable returns the
designation of the Transmit codec currently in use."
::= { endptDEFINITY 6 }
Avaya - 46xx IP Telephone MIB
A-26
Avaya - 46xx IP Telephone MIB
endptJCPC
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Jitter compensation packet count. This variable
returns the Jitter compensation packet count currently
in use (between 0 and 20, inclusive)."
::= { endptDEFINITY 7 }
endptTMSEC
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Transmit buffer fill level. This variable returns the
transmit buffer minimum fill level, in msec, currently in use."
::= { endptDEFINITY 8 }
endptNVPHONEXT
SYNTAX
OBJECT-TYPE
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Endpoint's phone extension. This variable
returns a text string identifying the endpoint's extension,
in free text format. The default value is NULL. "
::= { endptDEFINITY 9 }
Avaya - 46xx IP Telephone MIB
A-27
4600 Series IP Telephone LAN Administrator’s Guide
endptL2QBBE
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "802.1Q BBE priority value. This variable returns
an integer between 0 and 7 inclusive specifying the
far-end endpoint's Layer 2 Better than Best Effort audio priority
value."
::= { endptDEFINITY 10 }
endptDSCPBBE
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "DSCP BBE priority value. This variable returns
an integer between 0 and 7 inclusive specifying the
far-end endpoint's DiffServ Better than Best Effort audio priority
value."
::= { endptDEFINITY 11 }
endptRTCPCONT OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "RTCP Control flag. This variable returns
0 if the RTCP control status is off/disabled, else 1."
::= { endptDEFINITY 12 }
Avaya - 46xx IP Telephone MIB
A-28
Avaya - 46xx IP Telephone MIB
endptRTCPFLOW OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "RTCP Flowrate. This variable returns
an integer between 0 and 65335 inclusive specifying the
RTCP flowrate in milliseconds."
::= { endptDEFINITY 13 }
endptRSVPCONT OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "RSVP Control flag. This variable returns
0 if the RSVP control status is off/disabled, else 1."
::= { endptDEFINITY 14 }
endptRSVPRFRSH OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "RSVP Refresh rate. This variable returns
an integer between 0 and 65335 inclusive specifying the
RSVP refresh rate in milliseconds."
::= { endptDEFINITY 15 }
Avaya - 46xx IP Telephone MIB
A-29
4600 Series IP Telephone LAN Administrator’s Guide
endptRSVPRTRY OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "RSVP Failed Retry flag. This variable returns
0 if the RSVP Failed Retry Reservation control status is
off/disabled, else 1."
::= { endptDEFINITY 16 }
endptRSVPPROF OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "RSVP profile flag. This variable returns
0 if the RSVP profile is guaranteed, else 1 for controlled
load."
::= { endptDEFINITY 17 }
endptAdvApps
OBJECT IDENTIFIER ::= { endpointMIB 5 }
endptCIBURL
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
obsolete
DESCRIPTION "Documentation URL. This variable returns
a URL of the directory in which the web-based Customer
Information Booklet web pages are located."
::= { endptAdvApps 1 }
Avaya - 46xx IP Telephone MIB
A-30
Avaya - 46xx IP Telephone MIB
endptDIRSRVR
OBJECT-TYPE
SYNTAX
OCTET STRING
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "LDAP Server address. This variable returns
a 4-octet string specifying the IP address of the
LDAP server to be used for the phone's Directory
application."
::= { endptAdvApps 2 }
endptDIRTOPDN
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Directory Top Name. This variable returns
a string specifying the Topmost Distinguished Name in the
LDAP Directory to be used for the 4630's Directory
application."
::= { endptAdvApps 3 }
endptDIRFULLNAME OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Directory FullName Label. This variable returns
a string specifying the LDAP Directory's Full Name Field
Label, to be used for the 4630's Directory application."
::= { endptAdvApps 4 }
Avaya - 46xx IP Telephone MIB
A-31
4600 Series IP Telephone LAN Administrator’s Guide
endptDIRTELNUM OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Directory Phone Number Label. This variable returns
a string specifying the LDAP Directory's Telephone Number Field
Label, to be used for the 4630's Directory application."
::= { endptAdvApps 5 }
endptDIRSRCHTIME OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Directory Search Duration. This variable returns
an integer specifying the maximum number of seconds the LDAP
Directory should be searched before reporting completion or
failure of the search."
::= { endptAdvApps 6 }
endptDIRSRVRPWD OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Directory Access Password. This variable returns
a string specifying the password used for accessing the LDAP
Directory. The null strong is returned if no password has
been specified."
::= { endptAdvApps 7 }
Avaya - 46xx IP Telephone MIB
A-32
Avaya - 46xx IP Telephone MIB
endptDIRUSERID OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Directory Access User ID. This variable returns
a string specifying the User identity used for accessing the LDAP
Directory. The null strong is returned if no user ID has
been specified."
::= { endptAdvApps 8 }
endptDIRCODING OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Directory Coding Scheme. This variable returns
a string specifying the character coding scheme (e.g. ASCII
or Latin-1) to be used for LDAP Directory queries."
::= { endptAdvApps 9 }
endptDIRSTAT
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Directory Connection Status. This variable returns
an integer specifying the result code for the most recent
Bind Request sent by the 4630 to the LDAP server."
::= { endptAdvApps 10 }
Avaya - 46xx IP Telephone MIB
A-33
4600 Series IP Telephone LAN Administrator’s Guide
endptFTPSRVR
OBJECT-TYPE
SYNTAX
OCTET STRING
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "FTP Server address. This variable returns
a 4-octet string specifying the IP address of the
FTP server to be used for the 4630's file storage and
retrieval."
::= { endptAdvApps 11 }
endptFTPDIR
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "FTP Server directory. This variable returns
a path name of the directory on the FTP server
to be used for the 4630's file storage and retrieval."
::= { endptAdvApps 12 }
endptPHNEMERGNUM OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Emergency number. This variable returns
a string specifying the emergency number to be outpulsed
when the user presses the optional Emergency button in
the 4630 Speed Dial application."
::= { endptAdvApps 13 }
Avaya - 46xx IP Telephone MIB
A-34
Avaya - 46xx IP Telephone MIB
endptPHNNUMOFCA OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Number of Call Appearances. This variable returns
the number of Call Appearances downloaded from the DEFINITY
during registration to the 4630 and 4620."
::= { endptAdvApps 14 }
endptPHNNUMOFFB OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Number of Feature Buttons. This variable returns
the number of administered Feature Buttons downloaded from
the DEFINITY during registration to the 4630 and 4620."
::= { endptAdvApps 15 }
endptWEBCODING OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Web Coding Scheme. This variable returns
a string specifying the character coding scheme (e.g. ASCII
or Latin-1) to be used for characters entered on forms on
web pages. Used by the 4630 Web application."
::= { endptAdvApps 16 }
Avaya - 46xx IP Telephone MIB
A-35
4600 Series IP Telephone LAN Administrator’s Guide
endptWEBEXCEPT OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Web Proxy Server Exception List. This variable returns
a string specifying a list of one or more HTTP proxy server
Exception domains, separated by commas with no intervening
spaces, up to 127 total characters. Used by the 4630 Web
application."
::= { endptAdvApps 17 }
endptWEBHOME
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Web application URL. This variable returns
a URL of the Home page for the 4630's Web application."
::= { endptAdvApps 18 }
endptWEBPORT
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Web application TCP port. This variable returns
an integer specifying the TCP port most recently used for
the HTTP proxy server. Used by the 4630 Web application."
::= { endptAdvApps 19 }
Avaya - 46xx IP Telephone MIB
A-36
Avaya - 46xx IP Telephone MIB
endptWEBPROXY OBJECT-TYPE
SYNTAX
OCTET STRING
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Web Proxy Server. This variable returns
an IP addresses, in dotted-decimal or DNS format, of an
HTTP proxy server. Used by the 4630 Web application."
::= { endptAdvApps 20 }
endptDIRLDAPPORT OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "LDAP Directory Port. This variable returns
the port number for LDAP messages, and has a default value
of 389."
::= { endptAdvApps 21 }
endptVMLCODING OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Voice Mail Coding Scheme. This variable returns
a string specifying the character coding scheme (e.g. ASCII
or Latin-1) to be used for characters entered on forms on
the 4630 Voice Mail application."
::= { endptAdvApps 22 }
Avaya - 46xx IP Telephone MIB
A-37
4600 Series IP Telephone LAN Administrator’s Guide
endptVMLHOME
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Voice Mail application URL. This variable returns
a URL of the Home page for the 4630 Voice Mail application."
::= { endptAdvApps 23 }
endptCLACTIVE
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Call Log activation flag. This variable returns
0 if the call log status is off/disabled, else 1."
::= { endptAdvApps 24 }
endptWMLCODING OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "4620 Web Coding Scheme. This variable returns
a string specifying the character coding scheme (e.g. ASCII
or Latin-1) to be used for characters entered on forms on
web pages. Used by the 4620 Web application."
::= { endptAdvApps 25 }
Avaya - 46xx IP Telephone MIB
A-38
Avaya - 46xx IP Telephone MIB
endptWMLEXCEPT OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "4620 Web Proxy Server Exception List. This variable returns
a string specifying a list of one or more HTTP proxy server
Exception domains, separated by commas with no intervening
spaces, up to 127 total characters. Used by the 4620 Web
application."
::= { endptAdvApps 26 }
endptWMLHOME
OBJECT-TYPE
SYNTAX
DisplayString
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "4620 Web application URL. This variable returns
a URL of the Home page for the 4620's Web application."
::= { endptAdvApps 27 }
endptWMLPORT
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "4620 Web application TCP port. This variable returns
an integer specifying the TCP port most recently used for
the HTTP proxy server. Used by the 4620 Web application."
::= { endptAdvApps 28 }
Avaya - 46xx IP Telephone MIB
A-39
4600 Series IP Telephone LAN Administrator’s Guide
endptWMLPROXY OBJECT-TYPE
SYNTAX
OCTET STRING
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "4620 Web Proxy Server. This variable returns
an IP addresses, in dotted-decimal or DNS format, of an
HTTP proxy server. Used by the 4620 Web application."
::= { endptAdvApps 29 }
endptCTISTAT
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "CTI flag. This variable returns
0 if the CTI application is set to off, else 1."
::= { endptAdvApps 30 }
endptCTIUDPPORT OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "CTI application UDP port. This variable returns
an integer specifying the UDP port most recently used for
the UDP listener to receive broadcast messages."
::= { endptAdvApps 31 }
Avaya - 46xx IP Telephone MIB
A-40
Avaya - 46xx IP Telephone MIB
endptSTKSTAT
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "Stock Ticker flag. This variable returns
0 if the 4630 Stock Ticker application is set to off, else 1."
::= { endptAdvApps 32 }
endptAdjuncts OBJECT IDENTIFIER ::= { endpointMIB 6 }
endptFKEU
OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "FKEU flag. This variable returns
0 if the Feature Key Expansion Unit is off, disabled,
or not present, else 1."
::= { endptAdjuncts 1}
endptFKEUHEALTH OBJECT-TYPE
SYNTAX
INTEGER
MAX-ACCESS read-only
STATUS
current
DESCRIPTION "FKEU flag. This variable returns
1 if the most recent self-test of the Feature Key Expansion
Unit or the 4620 failed, else 0."
::= { endptAdjuncts 2}
END
Avaya - 46xx IP Telephone MIB
A-41
4600 Series IP Telephone LAN Administrator’s Guide
Avaya - 46xx IP Telephone MIB
A-42
Appendix B: Creating Websites for the 4630 IP
Telephone
Introduction
B
5
This Appendix describes the capabilities and limitations of the web browser in the 4630 IP
Telephone and provides suggestions for designing websites for viewing on the 4630. It is intended
for 4630 IP Telephone Web Browser [web page] designers, and assumes readers are familiar with
HTML, Style Sheets, and ECMAScript.
This Appendix serves three primary functions. It:
■
Presents the technologies that have been implemented in the 4630 IP Telephone Web Access
application, including any limitations or non-standard implementations,
■
Provides a suggested model for developing effective web pages to be viewed in the browser,
and
■
Provides sample HTML, Style Sheets, and ECMAScript that demonstrate the suggested
model.
This Appendix is not intended to provide technical details on setting up a web server, nor does it
provide information on web server technologies. Finally, this document is not intended to provide
an introduction to web browser protocols or technologies.
A link to sites where HTML templates are available for customizing can be found on
the Avaya website.
General Background
5
The 4630 IP Telephone display is a quarter VGA (320 pixels wide by 240 pixels high, 256 colors
supported) display.
The data types and other features supported in the browser include:
■
HTML 4.0
■
Cascading Style Sheets (CSS), Levels 1 and 2
■
Document Object Model (DOM) Level 1
■
Images: GIF and JPEG
■
ECMAScript (JavaScript) 1.4
■
HTTP 1.1
Introduction
B-1
4600 Series IP Telephone LAN Administrator’s Guide
■
Secure Sockets Layer (SSL) 3.0
■
Cookies
Browser Features and Behavior
5
This section presents the technologies that have been implemented in the 4630 IP Telephone Web
Access application, along with any limitations or non-standard implementations. Since style sheets
have become the preferred mechanism for controlling web page appearance and have made
obsolete most attribute specifications with tags, the majority of attributes for tags were not tried.
The attributes that were tested were those of real interest to specific tags. The browser is HTML
4.0 compliant, with a few minor differences as noted below.
In the sub-sections that follow, comments specific to the 4630 IP Telephone and its
browser are shown in italics.
Document Skeleton
5
Certain tags define the basic framework of an HTML document. While most browsers are normally
good at dealing with missing tags, when style sheets are applied it is essential that the tag
structures be followed. Even ignoring style sheets, it is considered good style to follow the HTML
rules. The following tags make up the basic skeleton of an HTML document:
■
<html> indicates the start of an HTML document.
■
<head> indicates the start of an HTML document’s header. Title, meta definitions, ECMAScript
function definition, document level style sheet definition, and external style sheet inclusion are
all done in the header section.
■
<title> sets the title of the document. Normally this is shown in the frame of the browser
window. On the phone, the title is shown in the Top Line Information Display Area.
■
<body> indicates the start of the body of an HTML document. The rest of the document will be
embedded between the start and end <body> tags.
■
<meta> is used to add additional information about an HTML page. This is typically used by
web walking tools, is of little use in browsers, and has no effect on the phone.
Browser Features and Behavior
B-2
Creating Websites for the 4630 IP Telephone
Content-Based Style
5
Content-based tags deal with identifying words, phrases or chunks of text, or images as having a
specific meaning or context. The intent of content-based tags is not to show physically marked
text. However, it is not wrong for a browser to show content-based text in a distinct style, such as
font style.
Each content-based tag is shown with a brief description, and any physical effects imposed by the
browser.
■
<abbr> indicates an abbreviation. Using this tag has no effect.
■
<address> indicates an address. Using this tag has no effect.
■
<acronym> indicates an acronym. The enclosed text is shown in an italic font.
■
<cite> indicates a bibliographic citation or reference. The enclosed text is shown in an italic
font.
■
<code> indicates source code of a program. The enclosed text is shown in a monospaced
font.
■
<del> indicates deleted text. It is intended to show editorial markup. The enclosed text is
shown with a line through it.
■
<dfn> indicates a definition for a term. This is normally used with the first appearance of a term
in a document. The enclosed text is shown in an italic font.
■
<em> indicates emphasis on a string of text. This is the contextual equivalent of using the <i>
(italic) tag. The enclosed text is shown in an italic font.
■
<ins> indicates inserted text. It is intended to show editorial markup. The enclosed text is
shown underlined.
■
<kbd> indicates keyboard input. This is similar to the <code> tag, but with a different
contextual intent. The enclosed text is shown in a monospaced font.
■
<samp> indicates literal text. The enclosed text is shown in a monospaced font.
■
<strong> indicates emphasis on some text, but in a stronger contextual sense than the <em>
tag. This is the contextual equivalent of using the <b> (bold) tag. The enclosed text is shown in
a bold font.
■
<var> indicates source code variables. This is similar to the <code> tag, but with a different
contextual intent. The enclosed text is shown in an italic font.
Browser Features and Behavior
B-3
4600 Series IP Telephone LAN Administrator’s Guide
Logical Style
5
Tags that control logical style provide a similar functionality to those that control content-based
style, but they have no implicit visual characteristics or contextual meaning. Instead, they only
provide a means of invoking a style sheet. These tags, like all others, may have an ID and class
attribute set. Using style sheet rules for these class names and IDs allows the designer to provide
decoration, font, and color styles to each section. Thus, these tags may be considered to be
designer-defined content-based tags:
■
<div> indicates a division. A newline is inserted between the previous text and the text
following the <div> tag. No physical changes are noticeable, except those implemented in style
sheets.
■
<span> indicates a spanned section of text is placed immediately after the text preceding the
tag with a newline. No physical changes are noticeable, except those implemented in style
sheets.
Physical Style
5
Physical tags are effectively the opposite of content-based tags. The text in a physical tag may
have no meaning whatsoever, outside of what the designer intended. These tags show text in a
distinct style. Physical tags typically affect font style.
Each physical style tag is shown below with a brief description, and any physical effects imposed
by the browser.
■
<b> indicates that the text should appear in a bold font weight.
■
<big> indicates that the text should appear one point size larger than the current text.
■
<i> indicates that the text should appear in an italic font.
■
<small> indicates that the text should appear one point size smaller than the current text.
■
<sub> indicates that the text should appear as a subscript to the current text. The text is shown
one point size smaller.
■
<sup> indicates that the text should appear as a superscript to the current text. The text is
shown one point size smaller.
■
<tt> indicates that the text should appear as teletype text. The text is shown in a monospaced
typeface font.
Browser Features and Behavior
B-4
Creating Websites for the 4630 IP Telephone
Physical Spacing and Layout
5
Physical spacing and layout tags define the basic structure of a document. Headings, paragraphs,
tables and lists all provide some basic physical and logical layout to a page.
Each spacing and layout tag is shown with a brief description, and any unusual behavior is
described.
■
<p> indicates the start of a new paragraph. A blank line is inserted between previous text and
text following the <p> tag.
■
<br> indicates that a breakpoint should be inserted. A newline is inserted between previous
text and text following the <br> tag.
■
<pre> indicates that the following text should have no formatting rules applied to it. This
implies that no wrapping will be applied to this text, which may result in a horizontal scrollbar
being added to view the text.
■
<hr> indicates that a newline and a horizontal rule (line) should be inserted between the
previous text and text following the <hr> tag.
■
<blockquote> indicates that the following text is a quote, and should be offset in some way.
The embedded text is shown with newlines before and after the text, and spacing to the left
and right. Within that "block" of text, normal wrapping rules are applied.
■
<q> indicates that the following text is a short quote, and should be shown in double-quotes
(according to documentation). This text appears as normal text, with no physical identifying
indications.
■
<h1> - <h6> indicate heading sections. Each level is one point smaller than the previous level,
with <h1> being the largest.
The section titled Maintaining Context contains design guidelines for maintaining user context.
Lists and Tables
5
For presentation of data in a logical format, lists and tables are two of the more important sets of
tags. Since space is at a premium in the browser, tables should be used with discretion. While they
provide sets of text, which are easy for the eye to process, they can quickly become cumbersome
if misused in this browser. Both width and height are limited, so the data provided in the table cells
should be short pieces of text. Beyond that, the page designer should come up with a different
model for presenting the data, possibly using lists and divisions.
Lists
5
■
<ol> starts an ordered list. This provides a list with some type of numbering: upper-case
letters, lower-case letters, digits, upper-case roman numerals, lower-case roman numerals.
Setting the type attribute is ignored in the browser.
■
<ul> starts an unordered list. This provides a list with bullets to the left of each item.
■
<li> adds an item to an ordered or unordered list.
■
<dl> starts a definition list. This is a list with two fields per list item. The first is a term and the
second is the term's definition.
Browser Features and Behavior
B-5
4600 Series IP Telephone LAN Administrator’s Guide
■
<dt> adds a new definition term to a definition list.
■
<dd> adds a new term definition to a definition list.
Tables
5
The new HTML 4.0 table tags, <thead>, <tbody> and <tfoot> are all implemented. These tags are
intended primarily to allow printed pages to have headers and footers appear on each page, when
the table is longer than a single page. Since the 4630 IP Telephone Web Browser does not provide
the ability to print, it is recommended that these tags not be used.
■
<table> starts a table layout.
■
<caption> adds a caption to a table. The align attribute allows a caption to be placed above or
below the table. This attribute has no effect in the phone.
■
<tr> adds a new table row to a table.
■
<th> adds a header for some column(s) of a table.
■
<td> adds a piece of data for some row(s) and column(s) of a table.
■
<thead> defines a set of table header rows. The intent of this tag is to provide a set of header
rows for each printed page. While viewing the page in a browser, the header has no more
effect than the <th> tag. What it does provide for the designer is a more logical breakout of the
data. It is easy to recognize the header area of the table since it is set between the <thead>
start and end tags.
■
<tbody> defines the main body of a table, when used in conjunction with the <thead> and
<tfoot> tags.
■
<tfoot> defines a footer for a table. This tag may contain multiple rows. Like the <thead> tag,
the intent of this tag is to provide a set of footer rows for each printed page. Viewing the page
in a browser has no additional effect. And like the <thead> tag, this tag provides a logical
breakout of the data for the designer.
■
<colgroup> defines a column group. It may be used as a single definition of identical columns
or as a container for dissimilar columns. The span attribute defines what columns are parts of
each group.
■
<col> controls the appearance of one or more columns within a column group.
Browser Features and Behavior
B-6
Creating Websites for the 4630 IP Telephone
Images
5
The 4630 IP Telephone Web Browser handles both GIF and JPEG image formats. No other image
formats, included animated GIFs, are supported. Note that images take up a large amount of
memory (compared to text) and updating the display can be an issue; therefore, it is recommended
that images be kept to a minimum.
The image tags that may be used on the browser are as follows:
■
<img> displays an image.
■
<map> display a client-side image. Client-side images have shaped regions called areas.
These areas are tied to URLs or ECMAScript functions. When an area in a region is clicked,
the ECMAScript function is executed.
■
<area> defines an area in a <map> image. Each area uses the href attribute to define a URL
to jump to, or some ECMAScript to execute, when the mouse is clicked on that area.
See the Design Guidelines section for information on displaying images.
Links
5
Hyperlinks are the heart of the web browser’s power. The link is what allows the user to click on
some text or an image to jump to another web site, another page within this site, or another area in
this page. Although URLs allow various protocols to be used, only http and https should be used
for the 4630 IP Telephone Web Browser.
■
<a> specifies the full or relative URL for a hyperlink. When using the target attribute, the
_blank name should never be used. With the exception of frames, the 4630 IP Telephone Web
Browser is not intended to be a multi-window browser. Thus, if a page attempts to reference a
new, non-frame window, the browser will become confused and a reboot will be necessary.
■
<base> defines the default target to be used in all <a> tags. This is done by setting the target
attribute of the <base> tag. If the target attribute has been set in the <a> tag, the <base> tag
value is ignored.
The use of the target attribute with the Web Access Application is strongly discouraged because
the application supports a single window for browsing. The use of the target attribute may cause
the browser software to create a new window that is outside of the Web Access Application's
control.
Browser Features and Behavior
B-7
4600 Series IP Telephone LAN Administrator’s Guide
Frames
5
Frames allow multiple windows to be created on the browser's base window. The browser is
effectively split up into multiple areas. Each frame may be given a name or ID. Using the target
attribute of the <a> tag, a web page may be displayed in another frame.
Although frames behave as defined, the small size of the screen makes them impractical to use.
Just like tables, frames take up too much room on the display. One could, though, take advantage
of frames by having a small "table of contents" frame with images for links. In general, however,
use of frames is strongly discouraged.
■
<frameset> defines an area for a set of frames.
■
<frame> defines a single frame in a frameset.
■
<iframe> defines an in-line frame. More detail
■
<noframes> provides a fallback for browsers that don't handle frames. If the designer intends
to use frames and make these pages available to phone, this tag should certainly be
employed.
See the Design Guidelines section for information on displaying frames.
Forms
5
HTML forms provide the user the ability to enter data into a web browser. This data can then be
passed on the web server for processing. It is difficult to predict what web designers might have in
mind for the 4630 IP Telephone Web Browser. However, all forms-related tags have been verified,
and the results are presented here.
■
<form> defines the basic input form, and defines the action to be performed when the submit
button is selected, via the action attribute.
■
<input> defines most user input. The type attribute defines the type of input to be used. The
<button> tag was created to replace type values of button, reset and submit, in a cleaner, more
flexible way. Other type values available are checkbox, hidden, image, password, radio, and
text. The type value file is useless in the context of this browser, since the intent of this control
is to allow the user to select a file on their local disk.
■
<button> defines a button that the user may select. This behaves much like the <input
type=button> tag, except that the physical appearance is three-dimensional and any text,
image, or combination, may be displayed in the button.
■
<fieldset> encapsulates a section of a form's contents to create a group of related form
controls. The phone's browser puts a simple box around the fieldset.
■
<label> associates a relationship between a form control and one or more text labels. Labels
may be tied to form controls by the for attribute in the label and the id attribute in the form
control. They may also be tied by embedding the form control inside the <label> tag (for
example, <label>Name: <input type=text id=name></label>).
■
·<legend> gives a label to a <fieldset> tag. This label appears at the top of the fieldset section
of the form, with a line separating the legend from the rest of the fieldset.
■
<optgroup> provides nested, cascading menus to the user. This doesn't seem to work.
Browser Features and Behavior
B-8
Creating Websites for the 4630 IP Telephone
■
<option> defines the values available in a <select> scrolling list or drop-down menu.
■
<select> defines scrolling lists and drop-down menus.
■
<textarea> provides free-form user input and display. This provides a scrolled text area for the
user to read or type text.
Character Entities
5
As with any syntactic language, HTML has certain characters that have special meaning. The two
most obvious of these characters are the < and > symbols, which surround all tags. These
characters cannot be typed in directly if the designer's intent is to display these characters. Thus,
all characters that can be displayed in a web browser have numeric values assigned to them. In
addition, many of these characters have names also assigned. The numeric values are entered
into the source web page as &#nnn; where nnn is some 3 digit value. For example, the < symbol is
entered as '&#060;'. Name values are entered into the source web page as &name; where name is
the name associated with this character. Again, using the < symbol, this would be entered as '&lt;'.
The set of characters defined by the World Wide Web Consortium are fully supported in the
browser in conformance with the standard.
Colors
5
The browser supports 256 colors. Colors may be specified by name, RGB percentages or RGB
raw numbers. The HTML and CSS specifications suggest 16 named colors. The 4630 IP
Telephone browser recognizes these color names, which are: aqua, black, blue, fuchsia, gray,
green, lime, maroon, navy, olive, purple, red, silver, teal, white, and yellow. Beyond these 16 wellknown names, it is recommended that RGB percentages or raw numbers be used for specifying
colors.
Fonts
5
Font specifications are one of the most important styles that may be applied to a web browser.
Because of the size of the screen on the 4630 IP Telephone, the browser has only a single font
available for use. Font weights, such as normal and bold, are supported, although finer values,
such as lighter and bolder are not. Normal and Italic font styles are also supported. Font sizes are
also supported, specified by either percentages or raw numbers can be used. However,
percentages below 50% all appear as the same size.
Although some problems were found with font specifications, given the size and resolution of the
screen, fonts behave reasonably well. The only major problem found is the inability to specify font
families.
See the Design Guidelines section for information on displaying images.
Browser Features and Behavior
B-9
4600 Series IP Telephone LAN Administrator’s Guide
Cookies
5
Cookies can be a useful feature in maintaining the state of a user when interacting with a web site.
HTTP provides no state information, such as when or how often a user has visited a site. Cookies
allow web sites to track this information by storing a simple set of values on the browser for the
current session. Normally, browsers also provide the ability to save cookies to disk, so this
information may be retained between sessions. However, the 4630 IP Telephone browser has no
such ability to save any data between sessions. Cookies do behave well within the realm of the
current session, and may be employed if desired. The 4630 IP Telephone has a maximum of
8Kilobytes of data available for cookie storage.
Design Guidelines
5
This section presents guidelines for developing a good model that effectively presents web pages
to be viewed on the 4630 IP Telephone Browser. The biggest challenge in designing pages for this
browser is the limited amount of space available for viewing the pages. The 4630 IP Telephone
screen is a ¼ VGA display. Part of that screen is lost to the browser by the main controls of the
4630 IP Telephone. Thus, page layout must be done effectively and efficiently so as to avoid
causing more space to be lost through additional screen controls such as scrollbars. Font sizing
will make or break the usability of a page. A balance must be found between fitting as much text as
is possible, and allowing users to read the text without straining their eyes.
Fixed-Width Objects
5
One of the primary functions of a web browser is to present text, wrapped at the right (or left when
dealing with internationalization) border of the browser window. The browser always attempts to
avoid adding a horizontal scrollbar. However, if fixed-width objects, such as tables and preformatted (<pre> tags) text are used, the browser makes wrapping a secondary priority to
presenting the data exactly as the HTML dictated.
Web browsers do not resize themselves larger when scrollbars are added. Thus, if there are more
lines of text than can fit in the height of the browser window, a vertical scrollbar is added. This now
takes up some of the width of the browser, and less text is displayed on a single line. If text is wider
than the width of the browser, a horizontal scrollbar is added. This now takes up some of the height
of the browser, and fewer lines of text are displayed.
Given the small size of the browser, it is highly desirable to avoid causing scrollbars to appear.
Unless the amount of text shown in a page is kept to a bare minimum, it is unlikely that a vertical
scrollbar will be avoided. However, avoiding fixed-width objects, or ensuring that the size of fixedwidth is kept small, will gain some viewable space on the browser.
In general, if scrolling is a requirement, vertical scrolling is better perceived by users than
horizontal scrolling.
Design Guidelines
B-10
Creating Websites for the 4630 IP Telephone
Images
5
The use of images in a web page is always a concern. For example, a page with many images can
cause downloading to be slow. While this is still a concern in the phone, the size of an image has a
much greater effect. Memory in the browser, and in the phone in general, is limited. Each image
will use a sizable amount of memory, and the browser may become overwhelmed. An image
should only be used if it is essential to a page.
Images also fall into the realm of fixed-width objects. All images should be checked to verify that
they don't cause a horizontal scrollbar to be added. An image may be scaled down by the browser,
by setting the width and height attributes of the <img> tag. The designer may instead choose to
scale the images when setting up the web site. This avoids forcing the browser to deal with the
sizing (using the width and height attributes scales the image after it is downloaded by the
browser) and speeds up downloading of the images. Finally, reducing the size of the image
reduces the amount of memory used.
Animated GIF images are a bad idea since they use up quite a bit of memory. Additionally,
because of the persistence of the LCD screen, animated images tend to smear in the browser and
lose their effectiveness. Hence, animated GIFs are considered "not supported" with this phone.
Frames
5
While frames provide a useful method of browsing a series of pages (via a contents frame and a
document text frame), they also use up real estate, just like scrollbars. Even if the frame
decorations were all turned off, the frame containing the majority of the document text now suffers
the problems discussed above; the width of the frame is smaller, and the chances of adding a
horizontal scrollbar have increased. Additionally, a single line of text will have fewer characters
viewable, and the page becomes even more difficult to read and comprehend. Using simple
navigation buttons at the top and bottom of the page, or even at the top and bottom of each section
should make up for the missing contents frame.
The interaction between frames and scrollbars is another important area of concern. While most
browsers manage scrolling within each frame independently, the 4630 Web Access Application
only scrolls the entire (single) window. This moves the user's view of the frames as a whole, but it
does not scroll any of the data in individual frames. There will likely be data in frames that can
never be seen.
The combined problems of minimal screen real estate and the scrolling issues really makes
frames something simply to avoid.
Fonts
5
Font size is a major concern in the browser. Without designer intervention, the browser displays
text as if it were running on a PC in a normal width and height display. This means that the fonts
shown would appear huge relative to the screen size. As a result, only seven lines of text will be
viewed in the browser when no font sizing is applied. Additionally, only about 25 characters would
be viewed per line. This would generally be unusable from a practical point of view.
Design Guidelines
B-11
4600 Series IP Telephone LAN Administrator’s Guide
To make the browser usable, some form of font sizing should be performed to allow a reasonable
amount of text to be viewed on one screen. Ideally, font sizing should be done in a single external
style sheet, and all pages should reference this style sheet. Setting font sizes in document-level
style sheets, or even worse, in in-line style sheets or <font> tags, makes it very difficult for the
designer to update font changes, and runs the risk of failing to make the change everywhere. By
using a single external style sheet, consistency in the pages is managed.
Defining fonts may be done in a static external style sheet or by dynamically generating a style
sheet using some form of server-side application, such as a CGI script or a Java servlet. Using
dynamic generation of a style sheet allows the server to decide, per user, what font size to use.
This in turn allows the user to notify the server to change the font size. All HTML pages would have
an external style sheet reference, which is another server-side executable. This executable would
dynamically generate font information based on the cookie, form component or configuration
value, relative to the IP address of the phone.
Using a static external style sheet makes page development and testing much easier, since how it
appears to the designer would be how it appears to the reader. Allowing the user to choose a font
size forces more work on the designer to verify that all fixed size items appear acceptably
Maintaining Context
5
Given the small working area, it is easy for the user to become lost. Headings will often not be in
view, and the user, if distracted by other work, can lose their sense of context. Style sheets may be
used to help maintain this sense of context through color. The <div> and <span> tags are intended
to provide page designer-defined content-based style. By defining classes of <div> tags with
various colors and border styles, the designer may provide additional information. It is important to
bear in mind that a significant number of people suffer from some form of color blindness. Thus, it
may be necessary to design pages both with and without using color styles.
User Interaction
5
As discussed above, HTML forms work reasonably well in the browser. However, due to the
limitations of the phone as an input device, keyboard input can be difficult. A complete keyboard is
made available based on the context of mouse selection. When a text input control is on-screen,
the user simply needs to click on the input control. The keyboard appears, with the browser thrown
into a small scrolling area. The input control is roughly centered in the scrolling area. The user may
then press the software keys and the text is shown in the input control. Simply pressing the done
button dismisses the keyboard, and the input control shows the newly typed text. While this
interaction technically works fine, from a user perspective, it can be difficult to type a large amount
of text. Thus, unless user input is absolutely necessary, it should be avoided. When necessary,
user input should be kept to a minimum.
Design Guidelines
B-12
Appendix C: Creating Websites for the 4620 IP
Telephone
Introduction
C
5
This Appendix describes the capabilities and limitations of the web browser in the 4620 IP
Telephone and provides suggestions for designing websites for viewing on the 4620. It is intended
for 4620 IP Telephone Web Browser (web page) designers, and assumes readers are somewhat
familiar with WML.
This Appendix serves the following functions:
■
Presents the portions of WML that have been implemented in the 4620 IP Telephone Web
Access application, including any limitations or non-standard implementations
■
Provides considerations for developing effective web pages to be viewed in the browser
This Appendix is not intended to provide technical details on setting up a web server, nor does it
provide information on web server technologies. Finally, this document is not intended to provide
an introduction to web browser protocols or technologies.
General Background
5
The 4620 Telephone has a 168 pixel-by-132 pixel four-gray scale LCD display. The area of the
display available for presenting a WML web page to the user is 168 pixels across by 96 pixels in
height, arranged in 6 rows each 16 pixels in height. In addition, the top row will display the web
page title (if any) and the bottom row presents up to four softkey labels at one time, each a
maximum of 6 characters, that are used for <do> tags.
The data types and other features supported in this browser include:
■
WML 1.2
■
HTTP 1.1
A chart at the end of this Appendix summarizes the more detailed information that follows.
Unsupported WML 1.2 tags will not be rendered and will not cause the browser to fail.
Unknown tags and misspelled tags will cause an error message.
Introduction
C-1
4600 Series IP Telephone LAN Administrator’s Guide
WML Document Skeleton
5
Certain tags define the basic framework of a WML document. The tags listed below make up the
basic skeleton of a WML document, and are supported by the 4620 unless otherwise indicated.
■
Common tag attributes: xml:lang, class, and id
The attributes xml:lang, class and id are universal attributes associated with every WML element.
The web browser will support these tags as follows:
Attribute
Comments
xml:lang
NOT SUPPORTED
class
NOT SUPPORTED
id
SUPPORTED
■
<wml> tag - The <wml> tag defines a deck of cards and encloses all information the deck and
is a required WML element. This tag must contain at least one <card> tag.
■
<head> tag - The <head> tag is an optional WML tag containing information relating to the
deck as a whole, including meta-data and access control elements. This tag is not supported.
■
<meta/> tag - The optional <meta> tag is contained between multiple <head> tags. This tag
gives values for the parameters that describe the content of the deck. This tag is not
supported.
■
<card> tag - A single WML file can contain multiple cards. This leads to the analogy - a "deck"
of "cards" within a single WML file. A "card" is essentially the specification of one specific WML
page. This is a mandatory tag.
The card element attributes supported by the web browser are as follows (unsupported attributes
are indicated as such in the Comments column):
Attribute
Value(s)
Description
Comments
newcontext
true
Re-initializes the browser
context
false
Default is "false”
Clears out the current WML
browser context. This entails
emptying the navigation
stack history and clearing
out all variables. NOT
SUPPORTED
WML Document Skeleton
C-2
Creating Websites for the 4620 IP Telephone
Attribute
Value(s)
Description
Comments
ordered
true
Specifies the order of card
content. When ordered is
set to "true" the browser will
display the content in a fixed
order. When ordered is set
to "false" the users will
decide the order as they
navigate between content.
Default is "true"
Optional; sets a Boolean
value that provides
information on how the
content of the current card is
arranged. Used by the
browser to organize the
display presentation and
layout. If set to true, content
is organized in a linear
sequence of elements (for
example, a series of ordered
or non-optional input
elements). If set to false,
content is in no natural order
(for example, a series of
unordered or optional input
elements). The default is
true. NOT SUPPORTED.
false
title
cdata
The title of the card
Can be used for title
displays. SUPPORTED
onenterbackward
url
Occurs when the user
navigates into a card using a
“prev” task
SUPPORTED
onenterforward
url
Occurs when the user
navigates into a card using a
“go” task
SUPPORTED
ontimer
url
Occurs when a “timer”
expires
SUPPORTED
■
<template> tag - The <template> tag defines a template for all the cards in a deck. The "code"
in the <template> tag is added to each card in the deck. Only one <template> tag for each
deck may be specified. This tag can only contain <do> and <onevent> tags.
The template tag attributes supported by the 4620 web browser are as follows:
Attribute
Value(s)
Description
Comments
onenterbackward
url
Occurs when the user
navigates into a card using a
“prev” task
SUPPORTED
onenterforward
url
Occurs when the user
navigates into a card using a
“go” task
SUPPORTED
ontimer
url
Occurs when the “timer”
expires
SUPPORTED
WML Document Skeleton
C-3
4600 Series IP Telephone LAN Administrator’s Guide
The implication for rendering WML pages is that the local environment will always
override a global template for <do> types with the same name and type. If there is a
onevent in the template and a local onevent of the same type, the local onevent takes
precedence over the global one.
■
<access> - The <access> tag limits access within the deck to certain cards. This tag is not
supported.
Text Elements
5
■
<br> tag - The <br> tag tells the browser to add a line break to the text at the point the element
is written.
■
<p> tag - The <p> tag specifies a paragraph of text with alignment and line wrapping
properties. All text data must be contained inside this tag. Only <do> tags, wml and card
elements can exist outside of the <p> tag. When rendered, this tag will cause subsequent
text to begin on the next line.
Attribute
Value
Description
Comments
align
left
right
center
Aligns the paragraph.
Default is “left”
SUPPORTED
mode
wrap
nonwrap
Sets whether a paragraph
should wrap lines or not
Since horizontal scrolling is
not supported, all text lines
are wrapped. WML pages
with mode=nowrap are
ignored, and the text will
wrap. NOT SUPPORTED.
The following tags are not supported but the content inside the tags will be rendered as normal
text:
■
<table> tag - The <table> tag specifies a table. This tag is not supported.
■
<td> tag - The <td> tag defines individual cell contents in each row of a defined table. This tag
is not supported.
■
<tr> tag - The <tr> tag defines each row of a defined table. This tag is not supported.
Text Elements
C-4
Creating Websites for the 4620 IP Telephone
Text Formatting Tags
5
The following tags are not supported but the content inside the tags will be rendered as normal
text:
■
<b> tag - The <b> tag specifies bold text. This tag is not supported.
■
<big> tag - The <big> tag specifies large font text. This tag is not supported.
■
<em> tag - The <em> tag specifies emphasized text. This tag is not supported.
■
<i> tag - The <i> tag specifies italicized text. This tag is not supported.
■
<small> tag - The <small> tag specifies text using a small font size. This tag is not supported.
■
<strong> tag - The <strong> tag specifies strongly emphasized text. This tag is not supported.
■
<u> tag - The <u> tag specifies underlined text. For the 4620 Web Access application, only
links appear underlined. This tag is not supported.
Anchor Elements
■
5
<a> tag - <a> elements define <go> tasks that require a URL link specification. All <a> tags
will be rendered as underlined. All <a> nested tags (br, img) are supported. One anchors may
be rendered is rendered per line. The user can select the link by pressing the left Feature
Buttons associated with that display line.
Attribute
Value
Description
Comments
href
url
REQUIRED. Defines where
to go when the user selects
the link
SUPPORTED
title
cdata
Defines a text identifying the
link
SUPPORTED
accesskey
■
NOT SUPPORTED
<anchor> tag - <anchor> elements define <go> tasks that require a URL link specification. All
anchors are rendered as underlined. All <anchor> nested tags (br, go, img, prev, and refresh)
are supported. A maximum of 6 anchors may be rendered on the screen at one time. The user
selects a link by using the Left Feature button associated with that display line.
Attribute
Value
Description
Comments
title
cdata
Defines a text identifying the
link
SUPPORTED
Text Formatting Tags
C-5
4600 Series IP Telephone LAN Administrator’s Guide
Image Elements
■
5
<img> tag - The <img> tag is used to place an image in the text flow. The monochrome wbmp
(wireless bitmap) format is used to code images for a wireless display, but the 4620 browser
instead renders the alternative text supplied with the image, as specified by the alt attribute.
Attribute
Value
Description
Comments
align
top
middle
bottom
Aligns the image
NOT SUPPORTED
alt
cdata
REQUIRED. Sets an
alternate text to be
displayed if the image is not
displayed. If this is not
supplied, either default text
is displayed (if available) or
the following message is
displayed: "Image not
displayed".
SUPPORTED
height
px (pixel)
%
Sets the height of the image
NOT SUPPORTED
hspace
px
%
Sets white space to the left
and right of the image
NOT SUPPORTED
localsrc
cdata
Sets an alternate
representation for the image
NOT SUPPORTED
src
url
REQUIRED if image is to be
displayed; not used if text is
displayed instead
NOT SUPPORTED
vspace
px
%
Sets white space above and
below the image
NOT SUPPORTED
width
px
%
Sets the width of the image
NOT SUPPORTED
Image Elements
C-6
Creating Websites for the 4620 IP Telephone
Event Elements
■
5
<do> tag - The <do> tag is a card-level user interface. It serves as a general mechanism for
the user to activate a task, typically performed by the user clicking on a word or phrase in the
display. A task is performed in response to an event. There are four tasks in WML: go, noop,
prev, and refresh.
The mandatory type attribute provides information about the intent of the element, helping to
improve processing. If the 4620 web browser does not recognize the specified type, (e.g., testing,
experimental, and vendor specific types), the specified type is treated as unknown. The browser
only renders WML 1.2 tags. Any other tags will cause an error and the user will receive an error
statement "not a valid wml page".
Attribute
Value
Description
Comments
type
accept
prev
help
reset
options
delete
unknown
x-*
vnd.*
REQUIRED. Defines the
type of the “do” element
SUPPORTED
label
cdata
Creates a label for the “do”
element
Optional; creates a string
label for the element. The
4620 browser imposes a six
character limit.
SUPPORTED
name
mmtoken
Defines a name for the “do”
element
SUPPORTED
optional
true
false
If set to true, the browser
ignores this element. If set
to false, the browser does
not ignore this element.
Default is “false”
Optional.
SUPPORTED
Type
Description
Comments
accept
Acknowledgement of
acceptance
SUPPORTED
delete
Delete item
SUPPORTED
help
Request for help
SUPPORTED
options
Options or additional
operations
SUPPORTED
Event Elements
C-7
4600 Series IP Telephone LAN Administrator’s Guide
Type
Description
Comments
prev
Backward navigation
SUPPORTED
reset
Clearing or reset
SUPPORTED
X-*n or x-*n
Experimental
SUPPORTED, but treated as
‘unknown’
<do> tags are rendered as softkey labels on the bottom line of the 4620 display. <do> tags are
specified per WML page and therefore are page context-sensitive. The eight "do" types are labeled
either specifically in a WML page or by a browser-dependent label.
If no labels are given, then the "do" types will have the following default labels:
Type
Default Label if no label
specified
accept
SELECT
delete
DELETE
help
HELP
options
OPTIONS
prev
BACK
reset
RELOAD
X-*n or x-*n
UNKNOWN
Vnd* Any mix of upper or
lower cases
AVAYA (Available for future
use, but currently
UNKNOWN)
If no <do> tags have been specified, no softkeys will be displayed:
If one <do> tag is specified the following softkeys will be displayed:
1st DO
If multiple <do> tags are specified, display them as follows:
1st DO
2nd DO
3rd DO
MORE
1st DO
2nd DO
3rd DO
MORE
4th DO
5th DO
Etc.
MORE
Page 1 Softkeys:
Page 2 Softkeys:
Event Elements
C-8
Creating Websites for the 4620 IP Telephone
If more than one page of softkey labels are specified, pressing the MORE softkey
automatically presents the user with the next page of labels. If the last page is displayed
and the user presses the MORE softkey, the first page of labels is then displayed. As
implied by the above, the softkey buttons are labeled in sequential order of the <do> tags.
■
<onevent> tag - The onevent tag serves as a container for code that you wish to be executed
automatically when one of the four intrinsic events occurs. The onevent element is said to bind
(associate) the tasks (code) to the event for the element. The intrinsic event must be specified
using the mandatory type attribute.
For example, when a user presses the BACK softkey, instead of being routed to the previous
screen, the user will be directed to another specified page because this tag carries out a onevent
backward event.
The intrinsic events are:
Event
Permitted Tags
Description
onenterbackward
card or template
Occurs when a <prev>
navigates back onto a
card. SUPPORTED.
onenterforward
card or template
Occurs when a <go>
navigates into a card.
SUPPORTED
onpick
option
Occurs when an item is
selected/unselected by a
user. SUPPORTED
ontimer
card or template
Occurs when the time
expires. SUPPORTED
The template element creates code that is inserted into all cards in a single deck. The nested tags
are as follows, go, noop, prev, and refresh.
There are no visual implications for supporting the <onevent> tag.
Attribute
Value
Description
Comments
type
onenterbackward
onenterforward
onpick
ontimer
REQUIRED. Specifies
the type of the
“onevent” element
SUPPORTED
Event Elements
C-9
4600 Series IP Telephone LAN Administrator’s Guide
■
<postfield> tag - The postfield tag is used to set a name/value pair that can be transmitted to
an origin server (source of the request) during a URL request. The name is set by the name
attribute and must be a valid WML variable name. The value is set by the value attribute. There
are no visual rendering implications with this tag.
Attribute
Value
Description
Comments
name
cdata
REQUIRED. The name of
the field
SUPPORTED
value
cdata
REQUIRED. The value of
the field
SUPPORTED
Task Elements
■
5
<go> tag - The go element can contain one or more postfield elements. If the destination of a
go element is a card within the same deck, all of the postfield elements will be ignored. The go
element can also contain one or more setvar elements. Unlike postfield elements, there are no
destination limitations on passing information contained in the setvar elements. The <go>
nested tags (postfield and setvar) are supported.
Attribute
Value
Description
Comments
href
url
REQUIRED
SUPPORTED
acceptcharset
Charset_list
A comma- or space-separated
list of character encoding the
server must be able to
process. The default value is
"unknown".
SUPPORTED
method
post
get
Sets how to send the data to
the server. Default method is
get. When method="get", the
data is sent as a request
with?data appended to the
URL. The disadvantage of get
is that it can be used only for a
limited amount of data; if you
send sensitive information it
will be displayed on the screen
and saved in the web server's
logs.With method="post", the
data is sent as a request with
the data sent in the body of
the request. This method has
no limit, and sensitive
information is not visible.
SUPPORTED
Task Elements
C-10
Creating Websites for the 4620 IP Telephone
Attribute
Value
Description
Comments
sendreferer
true
false
If set to true, the browser
sends the URL of the current
deck with the request, which
allow servers to perform
simple access control on
decks, based on which decks
are linking to them. Default is
"false"
SUPPORTED
■
<noop> tag - The noop tag dictates that no operation should be done. This tag can be used on
the card level to prevent an event, specified on the deck level by the template element, from
occurring. It can only be contained in either a do or onevent element.
An example of noop is to use a <do> tag to add a "Back" link to the card. When users click on the
"Back" link, generally they should be taken back to the previous card. However, the <noop> tag
prevents this operation; when the user clicks on the "Back" link nothing happens.
■
<prev> tag - The prev tag specifies navigation to the previous URL in the history.
■
<refresh> tag - The refresh tag specifies a refresh task whereby the whatever card is being
displayed will be refreshed. This task specifies the need for an update of the user agent
context as specified by the contained <setvar> elements.This tag can only be nested inside an
anchor, do, or onevent element. Xml:lang is not an associated attribute. User-visible side
effects of the update can occur during the processing of the <refresh>.
Input Elements
■
5
<input> tag supported - The input tag specifies a point where the user is prompted to enter
text.
Attribute
Value
Description
Comments
name
nmtoken
REQUIRED. The name of the
variable that is set with the
result of the user's input
SUPPORTED
emptyok
true
false
Sets whether the user can
leave the input field blank or
not. Default is "false”
SUPPORTED
Input Elements
C-11
4600 Series IP Telephone LAN Administrator’s Guide
Attribute
Value
format
A
a
N
X
x
M
m
*f
nf
Description
Comments
Sets the data format for the
input field. Default is “M”
SUPPORTED
A = uppercase alphabetic or
punctuation characters
a = lowercase alphabetic or
punctuation characters
N = numeric characters
X = uppercase characters
x = lowercase characters
M = all characters
m = all characters
*f = Any number of characters.
Replace the f with one of the
letters above to specify what
characters the user may enter.
nf = Replace the n with a
number from 1 to 9 to specify
the number of characters the
user may enter. Replace the f
with one of the letters above to
specify what characters the
user can enter. The user
cannot exit the input box
unless the correct number or
type of characters is entered.
The user does not receive an
error message if incorrect data
is entered
maxlength
number
Sets the maximum number of
characters the user can enter
in the field
SUPPORTED
size
number_of_char
Sets the width of the input field NOT SUPPORTED
tabindex
number
Sets the tabbing position for
the input field
NOT SUPPORTED
title
cdata
Sets a title for the input field
SUPPORTED
type
text
password
Indicates the type of the input SUPPORTED
field. The default value is "text”
value
cdata
Sets the default value of the
SUPPORTED
variable in the "name" attribute
The six display lines of the 4620 associated with feature buttons are all available for input
elements. The top line of the display cannot be used for input.
The input tag causes an automatic line break before and after input text.
Input Elements
C-12
Creating Websites for the 4620 IP Telephone
Only 1 input tag can exist per display line.
When a user views a page with the input tag specified, the first thing that shows up in the top line
is the card title, if specified. When the user scrolls to the first line containing input, the top line
shows the input box title if specified, otherwise the card title is shown. The top line displays the
card title for all non-input text.
When the input box is selected, a vertical line (the "cursor") appears at the left side of the input
box.
The attribute type password should only be used when it is important to not display the user' s
password on the screen. Asterisks will be displayed instead. It is also important that the password
not be cached.
The phrase [enter text here] appears for all input tags.
Only the correct size, type, and number of characters are accepted in to the input box. For
example, if alpha text is specified and the user types in a symbol or numeric text, the user input is
not accepted. The screen repaints and the user has to re-enter their input. If the wrong kind of text
is typed, the user receives an error tone. If the "n" (number) value is specified and the user types in
the incorrect number of characters, their input will not be accepted.
■
<fieldset> tag - The fieldset tag is used to group logically related elements in a card. This tag
is not supported.
■
<optgroup> tag - Sets of <optgroup> brackets can be put around <options> in a <select> list.
The results in breaking a list into sublists.
Attribute
Value
Description
Comments
title
cdata
Sets a title for the
optgroup element
SUPPORTED
■
<option> tag - A set of option tags is needed to specify each individual item in a list. This tag
must be used with the select tag.
Attribute
Value
Description
Comments
onpick
url
Sets what is going to
happen when an user
selects an item
SUPPORTED
title
cdata
Sets a title for the
option
SUPPORTED
value
cdata
Sets the value to be
used when setting the
"name" variable in the
select element
SUPPORTED
Input Elements
C-13
4600 Series IP Telephone LAN Administrator’s Guide
■
<select> tag - The select tag allows for the definition of a list, embedded in a card, to allow the
user to choose inputs from a list rather than having to type something in. The select tag must
be used with the option tag.
Attribute
Value
Description
Comments
name
nmtoken
Names the variable
that is set with the
index result of the
selection
SUPPORTED
ivalue
cdata
Sets the pre-selected
option element. If
none is specified the
first item in a list is
automatically
selected.
SUPPORTED
multiple
true
false
Sets whether multiple
items can be selected.
Default is "false".
False is used for a
single selection.
SUPPORTED
tabindex
number
Sets the tabbing
position for the select
element
NOT SUPPORTED
title
cdata
Sets a title for the list
SUPPORTED
value
cdata
Sets the default value
of the variable in the
"name" attribute
SUPPORTED
A single select is rendered with a small square containing a dot. A multiple select is rendered as
multiple squares - blank if there is nothing in them, else a lower case “x”.
Variable Elements
■
5
<setvar> tag - There are no visual rendering implications with this tag.
Attribute
Value
Description
Comments
name
cdata
REQUIRED. Sets the
name of the variable
SUPPORTED
value
cdata
REQUIRED. Sets the
value of the variable
SUPPORTED
Variable Elements
C-14
Creating Websites for the 4620 IP Telephone
■
<timer> tag - The timer tag sets a timer that starts counting. This tag must be used with
<onevent type="ontimer"> to be useful.
Attribute
Value
Description
Comments
value
cdata
REQUIRED. Sets the
default value of the
variable defined in the
"name" attribute
SUPPORTED
name
nmtoken
REQUIRED. Names
the variable that is set
with the value of the
timer
SUPPORTED
Character Entities
5
As with any syntactic language, WML has certain characters that have special meaning. The two
most obvious of these characters are the < and > symbols, which surround all tags. These
characters cannot be typed in directly if the designer's intent is to display these characters. Thus,
all characters that can be displayed in a web browser have numeric values assigned to them. The
numeric values are entered into the source web page as &#nnn; where nnn is a three-digit value.
For example, the < symbol is entered as '&#060;'.
In addition, many of these characters also have names assigned. Name values are entered into
the source web page as &name; where name is the WML name associated with this character. For
example, the < symbol would be entered as '&lt;'. The set of characters defined by the World Wide
Web Consortium are fully supported in the 4620 browser in conformance with the standard.
For convenience, a few of these key symbols are specified below.
Description
Symbol
Numeric Entity
Name Entity
double quotation
“
&#34;
&quot;
ampersand
&
&#38;
&amp;
apostrophe
‘
&#39;
&apos;
less than
<
&#60;
Character Entities
C-15
4600 Series IP Telephone LAN Administrator’s Guide
Colors and Fonts
5
The browser supports a 4-grayscale display. Because of the size of the screen on the 4620 IP
Telephone, the browser has only a single font available for use, which is based on Latin-1. Only a
normal font weight is supported. Bold, italic and different font sizes are not supported. The font
used by the 4620 defines characters to have at most six pixels in width.
Summary Of WML Tags And Attributes
Tag
Attribute
Supported?
accesskey
href
title
Yes
No
Yes
Yes
<a>
<access>
No
<anchor>
title
Yes
Yes
<b>
No
<big>
No
<br>
Yes
<card>
newcontext
onenterbackward
onenterforward
ontimer
ordered
title
Yes
No
Yes
Yes
Yes
No
Yes
label
name
optional
type
Yes
Yes
Yes
Yes
Yes, except x-*
<do>
<em>
No
<fieldset>
No
<go>
accept-charset
href
method
sendreferer
Colors and Fonts
C-16
5
Yes
Yes
Yes
Yes
Yes
Creating Websites for the 4620 IP Telephone
Tag
Attribute
Supported?
<head>
No
<i>
No
<img>
align
alt
height
hspace
localsrc
src
vspace
width
Yes
No
Yes
No
No
No
No
No
No
emptyok
format
maxlength
name
size
tabindex
title
type
value
Yes
Yes
Yes
Yes
Yes
No
No
Yes
Yes
Yes
<input>
<meta>
No
<noop>
Yes
<onevent>
Yes
<optgroup>
title
Yes
Yes
onpick
title
value
No
Yes
Yes
Yes
align
mode
Yes
Yes
No
name
value
Yes
Yes
Yes
<option>
<p>
<postfield>
<prev>
Yes
<refresh>
Yes
Summary Of WML Tags And Attributes
C-17
4600 Series IP Telephone LAN Administrator’s Guide
Tag
Attribute
Supported?
ivalue
multiple
name
tabindex
title
value
Yes
Yes
Yes
Yes
No
Yes
Yes
name
value
Yes
Yes
Yes
<select>
<setvar>
<small>
No
<strong>
No
<table>
No
<td>
No
<template>
onenterbackward
onenterforward
ontimer
Yes
Yes
Yes
Yes
name
value
Yes
Yes
Yes
<timer>
<tr>
No
<u>
No
<wml>
Yes
{Universal Attributes}
xml:lang
class
id
Summary Of WML Tags And Attributes
C-18
No
No
Yes
