PCV-V200G / PCV-V210P

Notice

© 2004 Sony Electronics Inc. Reproduction in whole or in part without written permission is prohibited. All rights reserved. This manual and the software described herein, in whole or in part, may not be reproduced, translated, or reduced to any machine-readable form without prior written approval.

SONY ELECTRONICS INC. PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL, THE

SOFTWARE, OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DISCLAIMS

ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE

WITH REGARD TO THIS MANUAL, THE SOFTWARE, OR SUCH OTHER INFORMATION. IN NO EVENT

SHALL SONY ELECTRONICS INC. BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, OR

SPECIAL DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR OTHERWISE, ARISING OUT OF OR

IN CONNECTION WITH THIS MANUAL, THE SOFTWARE, OR OTHER INFORMATION CONTAINED

HEREIN OR THE USE THEREOF.

SONY CANNOT WARRANT THAT THE FUNCTIONS DESCRIBED IN THIS GUIDE WILL BE

UNINTERRUPTED OR ERROR-FREE. SONY ALSO ASSUMES NO RESPONSIBILITY, AND SHALL NOT

BE LIABLE FOR ANY DAMAGES TO, OR VIRUSES THAT MAY INFECT, YOUR COMPUTER

EQUIPMENT, OR OTHER PROPERTY ON ACCOUNT OF YOUR ACCESS TO, USE OF, OR BROWSING IN

ANY DESCRIBED WEB SITE, OR YOUR DOWNLOADING OF ANY MATERIALS, DATA, TEXT, IMAGES,

VIDEO, OR AUDIO FROM ANY DESCRIBED WEB SITE. WEB SITE INFORMATION IS OBTAINED FROM

VARIOUS SOURCES AND MAY BE INACCURATE. COPIES OF COPYRIGHTED INFORMATION MAY

ONLY BE MADE FOR LEGALLY PERMISSIBLE PURPOSES.

Sony Electronics Inc. reserves the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein is governed by the terms of a separate user license agreement.

This product contains software owned by Sony and licensed by third parties. Use of such software is subject to the terms and conditions of license agreements enclosed with this product. Some of the software may not be transported or used outside the United States. Software specifications are subject to change without notice and may not necessarily be identical to current retail versions.

Certain product(s) included with this computer may include features such as copy protection and content management technology. USE OF THE SOFTWARE PRODUCT(S) REQUIRES AGREEMENT TO

APPLICABLE END USER AGREEMENTS AND FULL COMPLIANCE WITH APPLICABLE PRODUCT

ACTIVATION PROCEDURES. Product activation procedures and privacy policies will be detailed during initial launch of the software product(s), or upon certain reinstallations of the software product(s), or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).

Updates and additions to software may require an additional charge. Subscriptions to online service providers may require a fee and credit card information. Financial services may require prior arrangements with participating financial institutions.

Important information for Canadian customers: Your new VAIO computer includes certain software versions or upgrades, and Internet services or offers that are available to U.S. customers only.

Sony, VAIO, the VAIO logo, Click to DVD, DVgate Plus, PictureGear, Giga Pocket, Handycam, VAIO Media,

MagicGate, Memory Stick, the Memory Stick logo, SonicStage, ImageStation, ATRAC3, and i.LINK are trademarks or registered trademarks of Sony.

Intel and Pentium are trademarks or registered trademarks of the Intel Corporation. Microsoft, Windows, and the

Windows logo are trademarks or registered trademarks of the Microsoft Corporation. PS/2 is a registered trademark of the IBM Corporation.

All other trademarks are trademarks or registered trademarks of their respective owners.

2

.

As an ENERGY STAR® Partner, Sony Corporation has determined that this product meets the ENERGY STAR® guidelines for energy efficiency.

The International

E

NERGY

S

TAR® Office Equipment Program is an international program that promotes energy saving through the use of computers and other office equipment. The program backs the development and dissemination of products with functions that effectively reduce energy consumption. It is an open system in which business proprietors can participate voluntarily. The targeted products are office equipment such as computers, displays, printers, facsimiles and copiers. Their standards and logos are uniform among participating nations.

E

NERGY

S

TAR is a U.S. registered trademark of the Environmental Protection Agency.

Owner’s Record

The model and serial numbers are located on the back of your Sony VAIO® computer. Record the model and serial numbers in the space provided here, and keep in a secure location. Refer to the model and serial numbers when you call the Sony Service Center.

Model Number:

Serial Number:

3

Safety Information and Caution

Your computer’s installed optical drives may vary, depending on the system configuration you have purchased. See the online specifications sheet for details on your installed optical drives.

Keyboard Properties (PCVA-KB6)

Carrier frequency

Output power

27.095 - 27.145MHz

Less than 46 nW

Mouse Properties (PCVA-MS2)

Carrier frequency

Output power

27.045 MHz

Less than 100 nW

To prevent fire or shock hazard, do not expose your desktop to rain or moisture.

To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.

Never install modem or telephone wiring during a lightning storm.

Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.

Never touch uninsulated telephone wire or terminals unless the telephone line has been disconnected at the network interface.

Use caution when installing or modifying telephone lines.

Avoid using the modem during an electrical storm.

Do not use the modem or a telephone to report a gas leak in the vicinity of the leak.

The socket outlet shall be installed near the equipment and shall be easily accessible.

To change the backup battery, please contact your nearest Sony Service

Center.

Caution—The use of optical instruments with this product will increase eye hazard. As the laser beam used in this product is harmful to the eyes, do not attempt to disassemble the drive cabinet. Refer servicing to qualified personnel only.

Danger—Visible and invisible laser radiation when open. Avoid direct exposure to beam.

For DVD-RW/DVD-ROM/CD-RW: Danger—Visible and invisible laser radiation when open. Avoid direct exposure to beam.

Caution—For ADSL and V.90 modem models; to reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord.

4

Pour prévenir tout risque d’incendie ou d’électrocution, garder cet appareil à l’abri de la pluie et de l’humidité.

Pour prévenir tout risque d’électrocution, ne pas ouvrir le châssis de cet appareil et ne confier son entretien qu’à une personne qualifiée.

Ne jamais effectuer l’installation de fil modem ou téléphone durant un orage électrique.

Ne jamais effectuer l’installation d’une prise téléphonique dans un endroit mouillé à moins que la prise soit conçue à cet effet.

Ne jamais toucher un fil téléphonique à découvert ou un terminal à moins que la ligne téléphonique n’ait été débranché de l’interface réseau.

Soyez très prudent lorsque vous installez ou modifiez les lignes téléphoniques.

Évitez d’utiliser le modem durant un orage électrique.

N'utilisez pas le modem ni le téléphone pour prévenir d'une fuite de gaz vous êtes près de la fuite.

L’appareil doit être le plus près possible d’une prise murale pour en faciliter l’accès.

Pour changer la pile de rechange, veuillez contacter votre centre de service

Sony le plus près.

Avertissement: L'utilisation d'instruments optiques avec ce produit augmente les risques pour les yeux. Puisque le faisceau laser utilisé dans ce produit est dommageable pour les yeux, ne tentez pas de désassembler le boîtier.

Adressez-vous à un agent de service qualifié.

Danger: Radiation laser visible et invisible si ouvert. Évitez l’exposition directe au faisceau.

Pour les DVD-RW/DVD-ROM/CD-RW: Danger—Radiation laser visible si ouvert. Évitez l'exposition directe au faisceau.

Attention: Pour ADSL et V.90 modele modem; afin de réduire les risques d'incendie, n'utilisez qu'un cordon de communication N0. 26 AWG ou plus gros.

5

Regulatory Information

If you have questions about this product, write to Sony Customer Information Service Center at 12451 Gateway

Blvd., Ft. Myers, FL 33913, USA, or visit Sony Customer Service on the Sony Online Support Web site at http://www.sony.com/pcsupport.

Declaration of Conformity

Trade Name:

Model No.:

Responsible Party:

Address:

SONY

PCV-V200G / PCV-V210P

Sony Electronics Inc.

680 Kinderkamack Rd. Oradell, NJ 07649, USA

Telephone: 201-930-6972

This phone number is for FCC-related matters only.

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

This device complies with RSS-210 of the IC Standards.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation of the device.

Cet appareil est conforme avec la norme RSS-210 d’IC.

L'utilisation de ce dispositif est autorisée seulement aux conditions suivantes:

(1) Il ne doit pas produire de brouillage, et

(2) l'utilisateur doit être prêt à accepter tout brouillage radioélectrique reçu, même si celui-ci est susceptible de compromettre le fonctionnement du dispositif.

Model No.: PCVA-IMB5A (For models equipped with Giga Pocket features)

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

Model No.: PCVA-KB6 and PCVA-MS2

These devices comply with Part15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation of the device.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

6

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

Only peripherals (computer input/output devices, terminals, printers, etc.) that comply with FCC Class B limits may be attached to this computer product. Operation with noncompliant peripherals is likely to result in interference to radio and television reception.

All cables used to connect peripherals must be shielded and grounded. Operation with cables, connected to peripherals, that are not shielded and grounded, may result in interference to radio and television reception.

FCC Part 68

This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the rear of this equipment is a label that contains, among other information, a product identifier in the format

US:AAAEQ##TXXXX. If requested, this number must be provided to the telephone company.

This modem uses the USOC RJ-11 telephone jack.

A telephone plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. The REN is used to determine the quantity of devices which may be connected to the telephone line.

Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total RENs, contact the telephone company. For products approved after July 23, 2001, the REN for this product is part of the product identifier that has the format

US:AAAEQ##TXXXX. The digits represented by ## are the REN without a decimal point (e.g. 03 is a REN of 0.3).

For earlier products, the REN is separately shown on the label

If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advance notice is not practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.

The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the operations of the equipment. If this happens, the telephone company will provide advance notice in order for you to make the necessary modifications in order to maintain uninterrupted service.

If trouble is experienced with this equipment, for repair or warranty information, please contact the Sony Customer

Information Service Center at 1-888-4-SONY-PC (1-888-476-6972), or write to the Sony Customer Information

Center, 12451 Gateway Blvd., Fort Myers, FL 33913, USA, or find Sony Customer Service on the Web at http://www.sony.com/pcsupport. If this equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment from the network until the problem is resolved. Repair of this equipment should be made only by a Sony Service Center or Sony authorized agent. For the Sony Service Center nearest you, call 1-888-4-SONY-PC (1-888-476-6972), or visit the Sony Online Support Web site at http://www.sony.com/pcsupport.

Connection to Party Line Service is subject to state tariffs. Contact the state public utility commission, public service commission, or corporation commission for information.

If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer.

Please use a surge arrestor against electrical surges.

7

The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device, including FAX machines, to send any message unless such message clearly contains, in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business, other entity, or individual sending the message, and the telephone number of the sending machine or such business, other entity, or individual. (The telephone number provided may not be a 900 number or any other number for which charges exceed local or long distance transmission charges.)

In order to program this information into your facsimile machine, see your fax software documentation.

Telephone Consumer Guidelines (Canada)

Please refer to your telephone directory under ‘Privacy Issues’ and/or ‘Terms of Service.’ For more detailed information, please contact:

CRTC

Terrasses de la Chaudiére

Tour centrale 1 promenade du Portage

5 étage Hull PQ K1A 0N2.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Model No.: PCVA-IMB5A (For models equipped with Giga Pocket features)

Supplementary Television Broadcasting Receiving Apparatus - Appareils supplémentaires de réception de télévision, Canada.

Industry Canada Notice

This equipment meets the applicable Industry Canada technical specifications.

The Ringer Equivalence Number (REN) is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices does not exceed 5.

Le presént matériel est conforme aux spécifications techniques applicables d’Industrie Canada.

L’indice d’équivalence de la sonnerie (IES) sert à indiquer le nombre maximal de terminaux qui peuvent être raccordés à une interface téléphonique. La terminaison d’une interface peut consister en une combinaison quelconque de dispositifs, à la seule condition que la somme d’indices d’équivalence de la sonnerie de tous les dispositifs n’excède pas 5.

Macrovision license

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only, unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Licence Macrovision

Ce produit intègre une technologie de protection de la loi sur le droits de propriéte intellectuelle couverts par la législation américaine. L’utilisation de cette technologie doit être autorisée par Macrovision. Elle est uniquement destinée à un usage privé et à d’autres fins de visualisation limitée, sauf autorisation contraire de la part de

Macrovision. Tout désossage ou désassemblage est formellement interdit.

8

Disposal of Lithium Battery

You can return your unwanted lithium batteries to your nearest Sony Service Center or Factory Service Center.

In some areas the disposal of lithium batteries in household or business trash may be prohibited.

For the Sony Service Center nearest you, call 1-888-476-6972 in the United States or 1-800-961-7669 in Canada.

Do not handle damaged or leaking lithium batteries. In some areas, the disposal of lithium batteries in household or business trash may be prohibited.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

The battery pack used in this device may present a fire or chemical burn hazard if mistreated. Do not disassemble, heat above 212

°F (100°C), or

incinerate. Dispose of used battery promptly. Keep away from children.

To change the lithium battery, please contact your nearest Sony Service

Center.

Ne pas manipuler les batteries au lithium qui fuient ou sont endommagées.

Une batterie non conforme présente un danger d'explosion. La remplacer seulement par une batterie identique ou de type équivalent recommandé par le fabricant. Évacuer les batteries usées selon les directives du fabricant.

La manutention incorrecte du module de batterie de cet appareil présente un risque d'incendie ou de brûlures chimiques. Ne pas démonter, incinérer ou exposer à une température de plus de 100°C. Évacuer promptement la batterie usée. Garder hors de portée des enfants.

Pour changer la batterie au lithium, veuillez contacter votre centre de service

Sony le plus près.

9

10

Contents

Getting Started ..........................................13

Unpacking your Computer ........................................14

Locating Controls and Ports ....................17

About the Front Panel ...............................................18

About the Side Panels ...............................................20

About the Back Panel................................................23

About the Keyboard ..................................................24

About the Mouse .......................................................28

About the Remote Control ........................................30

Connecting the Power Cord ......................................36

Connecting the Wireless Keyboard...........................38

Connecting the Wireless Mouse................................40

Connecting the Modem Cable...................................42

Turning on Your Computer.......................................43

Registering Your Computer ......................................43

Turning Off Your Computer .....................................44

11

VAIO Computer Quick Start

Installing Memory..................................................... 46

Support Options........................................55

Immediate Help and Support .................................... 55

Resources for Additional Help and Support ............. 56

12

Congratulations on your purchase of the Sony VAIO® computer! Your new, high-performance, multimedia computer combines state-of-the-art computer functionality with the latest audio, video and information technology features.

13

VAIO Computer Quick Start

Unpacking your Computer

Your computer may not be supplied with all of the accessories shown, depending on the system configuration you purchased. For details on the accessories supplied with your computer, see the online Specifications sheet.

Your VAIO® computer is not supplied with System or Application Recovery CDs. Use the VAIO Recovery Wizard utility program to recover your computer's operating system and preinstalled software.

Computer and supplied accessories

System unit

Wireless keyboard

AA batteries (4)

Wireless mouse

Modem cable

Power cord

Power cord clamp

14

Giga Pocket® Personal Video Recorder accessories

(For models equipped with Giga Pocket features)

TV Coaxial cable (1)

Unpacking your Computer

Remote control (1)

AA batteries (2)

Manuals

VAIO® Computer Quick Start — Provides basic information on setting up and registering your computer. The Quick Start also provides resources for technical support, safety guidelines, and owner’s information.

Online Documentation

VAIO® Computer User Guide — Contains information on the hardware and preinstalled software programs included with your system.

To access the online User Guide:

1

Click Start in the Windows taskbar, then click Help and Support.

2

From the VAIO Help and Support Center menu, click VAIO User

Guide.

Specifications — This online specifications sheet describes the hardware and software configuration of your VAIO computer. Go to the Sony Online

Support Web site at http://www.sony.com/pcsupport to view the online

Specifications sheet.

VAIO Software Provides specific information about the preinstalled software on your computer.

To access this online software information:

1

Click Start in the Windows® taskbar.

2

Click Welcome to VAIO life.

15

VAIO Computer Quick Start

Hard Disk Drive Recovery

Your computer is equipped with the VAIO Recovery Wizard, a utility program that recovers your computer’s operating system and preinstalled software.

For more information about hard disk recovery

1

Click Start in the Windows® taskbar, then click Help and Support.

2

From the VAIO Help and Support Center menu, click VAIO Recovery

Options.

Other

A software library containing the Microsoft® software and Sony® end-user license agreements.

16

This section is intended to familiarize you with the controls, ports, and jacks that are available on your computer. Your computer may not be equipped with all of the hardware features described, and the location of the controls, ports, and jacks, may vary from the illustrations shown in this section. To view the specific hardware configuration for your system, see the online specifications sheet.

17

VAIO Computer Quick Start

About the Front Panel

The front panel of your VAIO® computer is equipped with indicator lights and built-in speakers.

Front panel

1

2

3

Stereo speakers (built-in)

The stereo speakers provide sound for software, audio, and video media.

Infrared receiver

Enables communication with the remote control that is supplied with models equipped with Giga Pocket ® features, to turn on TV, change TV channels, and raise or lower volume.

Optical disc and hard disk drive access indicator

Light is amber while reading and writing data.

18

4

5

6

About the Front Panel

Memory Stick® media access indicator

Light is amber when the Memory Stick media slot is in use.

Power button

Press the power button in from the right side, to turn the computer on and off.

Power indicator

Light is green while the power is on and amber when the computer is in

Stand by mode.

Press the power button correctly to avoid damage to the computer.

Your VAIO® computer has an attached LCD monitor. Handle the monitor carefully when adjusting the viewing angle.

1

Grasp both sides of the monitor firmly.

2

Tilt the monitor backwards, to the desired viewing angle.

For more information about handling the LCD monitor, see the online VAIO®

Computer User guide.

1

Click Start in the Windows taskbar, then click Help and Support.

2

From the VAIO Help and Support Center menu, click VAIO User

Guide.

19

VAIO Computer Quick Start

The side panels of your computer provide the connections for supplied and optional accessories. The icons on the side panel help you locate and identify the appropriate jack or port.

Right panel

3

4

1

2

Optical drive eject button

Ejects a disc from the optical drive.

Optical drive

See the online specifications sheet for optical drive information.

Memory Stick® media slot

Reads and writes data from and to a Memory Stick media.

PC Card slot

A PC card (PCMCIA card) can be inserted into this slot to increase your computer’s functional capabilities.

20

About the Side Panels

Left panel

1

2

3

4

5

Composite audio L In jack

*

Connection for an audio cable (optional).

Composite audio R In jack

*

Connection for an audio cable (optional).

Composite video In jack

*

Connection for a video cable (optional).

S-video In jack

*

Connection for an S-video cable (optional).

VHF/UHF port

*

Connection for a TV coaxial cable (supplied).

Headphones jack

Connection for external speakers (optional) or headphones (optional).

Line In jack

Connection for an audio device.

21

VAIO Computer Quick Start

6

7

8

9

10

Microphone jack

Connection for an external microphone (optional).

Connect button

Enables the system unit to communicate with the wireless keyboard and wireless optical mouse.

Modem line jack

Connection for a modem cable (supplied) to the telephone wall jack.

i.LINK® 4-pin, S400 port

Connection for compatible i.LINK devices (IEEE 1394).

Ethernet port

Connection for a 10BASE-T/100BASE-TX Ethernet cable. (The port marked with [Network] is for LAN connections only.).

11 Universal Serial Bus (USB 2.0) ports (2)

Connections for compatible high/full/low-speed USB devices.

* Available only on models equipped with Giga Pocket® Personal Video Recorder features.

† An optional “1-to-2” jack adapter (splitter) is required to connect both a telephone and modem line to your computer.

✍ i.LINK is a trademark of Sony used only to designate that a product contains an programs, operating system and compatible i.LINK devices. All products with an i.LINK connection may not communicate with each other.

Refer to the documentation supplied with your compatible i.LINK device for information on operating conditions and proper connection. Before connecting compatible i.LINK devices to your system, such as an optical or hard disk drive, confirm their operating system compatibility and required operating conditions.

22

About the Back Panel

About the Back Panel

The back panel of your computer contains the AC power and USB ports.

Back panel

1

2

AC Input port

Connection for the AC power cord (supplied).

Universal Serial Bus (USB 2.0) ports (2)

Connections for compatible high/full/low-speed USB devices.

23

VAIO Computer Quick Start

About the Keyboard

Your VAIO® computer is supplied with a wireless keyboard that has a standard key arrangement and additional keys that perform specific functions. Before attempting to use the wireless keyboard with your computer, see the section,

“Connecting the Wireless Keyboard” on page 38.

Wireless keyboard (top)

Standby S keys

(-) Volume

(+/-) Brightness

Mute

(+) Volume

Function

KEY

Stand by

S keys

Brightness

Windows Applications Directional arrows

Numeric keypad

DESCRIPTION

Press to place the computer into Stand by mode. Press again to resume normal operation

*

.

Press to activate specific applications.

Press to increase (+) or decrease (-) the brightness of the

LCD screen.

24

About the Keyboard

KEY DESCRIPTION

Mute

Volume Control

Function

Numeric keypad

Press to turn off speaker sound. Press again to restore sound.

Press to increase (+) or decrease (-) the speakers’ volume.

The 12 function keys are used to perform certain tasks.

The task associated with each function key varies between software programs.

Use the numeric keypad to type numbers or to perform basic math calculations. Press the Num Lock key to enable the numeric keypad function. Press the Num

Lock key again to disable the numeric keypad.

Directional arrows

Applications

The Up, Down, Left, and Right arrow keys move the pointer on the computer screen.

Press to display a shortcut menu in certain software programs. Pressing this key is equivalent to clicking the right mouse button.

Windows

The Microsoft® Windows® key, displays the Start menu. Pressing this key is equivalent to clicking Start on the taskbar.

* Use the Stand by button to resume from Stand by mode. Pressing other keys or using the mouse may not enable your computer to resume normal operation.

25

VAIO Computer Quick Start

Wireless keyboard (bottom)

1

2

3

Battery compartment

Compartment for the supplied AA batteries.

Keyboard feet

Extend to adjust the keyboard height.

CONNECT button

Press to enable the wireless keyboard to communicate with the system unit.

26

About the Keyboard

To set up the wireless keyboard

Insert two AA batteries (supplied) into the wireless keyboard as shown. You can check your keyboard’s battery power level by clicking (wireless keyboard icon), located in the Windows® taskbar notification area.

Inserting batteries into the wireless keyboard

If your wireless keyboard does not operate properly, the batteries may need to be replaced. When your wireless keyboard is not being used for extended periods of time, remove the batteries to avoid possible damage from battery leakage.

27

VAIO Computer Quick Start

About the Mouse

Your VAIO® computer is supplied with a wireless optical mouse. Before attempting to use the wireless optical mouse with your computer, see the section,

“Connecting the Wireless Mouse” on page 40.

Wireless mouse (top)

1

2

3

Left mouse button

Press to perform specific mouse functions.

Wheel button

Rotate the wheel to scroll up or down on the LCD screen.

Right mouse button

Press to perform specific mouse functions.

28

About the Mouse

Wireless mouse (bottom)

1

2

Power switch

Slide power switch to turn the mouse on or off.

CONNECT button

Press to enable communication between your VAIO® computer and the wireless mouse.

To set up the wireless mouse

Insert two AA batteries (supplied) into the wireless mouse as shown. You can check your mouse’s battery power level by clicking (wireless mouse icon), located in the Windows® taskbar notification area.

Inserting batteries into the wireless mouse

If your wireless mouse does not operate properly, the batteries may need to be replaced. When your wireless mouse is not being used for extended periods of time, remove the batteries to avoid possible damage from battery leakage.

29

VAIO Computer Quick Start

About the Remote Control

The remote control is supplied with VAIO® computers that are equipped with

Giga Pocket® Personal Video Recorder features

*

. The remote control can start and stop video recording and playback, select channels, and set viewing preferences. This section describes the basic functions of your Giga Pocket remote control

Remote control

MUTE

STANDBY

AUDIO

TV/VIDEO

DISPLAY

JUMP

REC REC STOP

ENTER

SIZE

FUNCTION

REW

STOP

FF PREV NEXT

PLAY PAUSE

TV

VIDEO

MUSIC HOME NETWORK

MENU

ENTER

BACK

APPLICATION

START

VOLUME

TOOLS

APPLICATION

CLOSE

CHANNEL

RM-GP5U

* See the online specifications sheet for information about your computer’s hardware configuration.

30

About the Remote Control

1

2

3

4

5

6

MUTE button

Press to turn off the sound. Press again to restore the sound.

Channel number buttons (0-9)

Press to select specific channels.

(Press the ENT button to activate channel selection.)

JUMP button

Press to go to the previous channel. Press again to return to the current channel.

ENTER button

Press to activate channel selection. See Channel number buttons.

REC STOP button

Press to stop recording.

(Note: The REC STOP function is only available for the Giga Pocket®

Personal Video Recorder software program.)

REC button

Press to begin recording.

(Note: The REC function is only available for the Giga Pocket software program.)

TV button

Press to change from the on-screen image to the TV/Recording deck.

VIDEO button

Press to change to the external video equipment, such as your VCR.

(Note: You cannot change the input source while recording.)

DVD button

Press to change to an external DVD device, such as a DVD player.

MUSIC button

Press to launch the SonicStage™ software program.

HOME NETWORK button

Press to launch the VAIO Media™ software program.

Direction and ENTER buttons

Press a direction arrow to navigate. Press ENTER to select.

31

VAIO Computer Quick Start

8

9

7

10

11

12

BACK button

Press to return to the previous screen.

(Note: This function is not available for the Giga Pocket software program.)

APPLICATION START button

Press to launch the Giga Pocket software program.

VOLUME button

Press to raise or lower the volume.

STANDBY button

Press to place the system into Stand by mode.

(Note: You cannot place the computer into Stand by mode when certain

Giga Pocket software program functions are running.)

AUDIO button

Press to view available sound mode options on the monitor/display.

TV/VIDEO button

Press to change the on-screen image from the TV/Recording deck to external video equipment, such as your VCR.

(Note: You cannot change the input source while recording.)

DISPLAY button

During DVD playback in full screen mode, press to show the settings window. When using the Giga Pocket software program, press to display the TV/Recording deck and playback deck screens. Press again to hide these views.

SIZE button

Press to view the current software program in full-screen size. Press again to return the view to its original size.

FUNCTION button

When the Giga Pocket software program is selected, using the MENU button, press the Function button to switch from the TV/recording deck to the playback deck.

When using the SonicStage software program, press to change from the music drive (hard disk drive) to the CD.

32

About the Remote Control

13

14

15

16

17

REW and FF buttons

Press to rewind or fast-forward.

PREV and NEXT buttons

Press to move back to the previous screen or forward to the next screen.

STOP button

Press to stop playback.

PLAY button

Press to begin playback.

PAUSE button

Press to pause playback.

MENU button

Press to view a shortcut menu of available software programs. Press again to hide this menu.

(Note: For the Giga Pocket software program, the Select Video

Capsules window displays. Press the button again to hide this window.)

TOOLS button

The function of this button may vary between DVD media. See the DVD player software program instructions for details.

APPLICATION CLOSE button

Press to close the Giga Pocket software program.

CHANNEL button

Press to change channels automatically (no number input required).

(Note: This function is only available for the Giga Pocket software program.)

For more details about the function buttons on your remote control, see the Giga

Pocket software program Help.

33

VAIO Computer Quick Start

To set up the remote control

Insert two AA batteries (supplied) into the remote control, as shown.

Inserting batteries into the remote control

If your remote control does not operate properly, the batteries may need to be replaced. When your remote control is not being used for extended periods of time, remove the batteries to avoid possible damage from battery leakage.

34

You can set up your system quickly and easily with the instructions provided in this section. For details on your system’s hardware configuration, see the online specifications sheet.

35

VAIO Computer Quick Start

The computer’s power cord must be plugged into an AC power source, such as an AC wall outlet, surge protector, or Uninterruptible Power Supply (UPS), before you can establish communication with your wireless keyboard and wireless mouse.

Your computer has the ability to be turned on its base and the power cord may become unplugged. You may lose data if your system loses power while software programs are running. Use the supplied power cord clamp to avoid accidentally unplugging your computer.

1

Remove the adhesive backing from the power cord clamp.

2

Press the clamp firmly against the back panel near the AC input port.

Attaching the power cord clamp

3

Plug the power cord into the AC input port on the back panel of the computer.

Install your computer in an area where you can easily reach the power outlet in the event of an emergency.

36

Connecting the Power Cord

4

Use a coin to open the clamp, and then insert the power cord.

Inserting the power cord into the clamp

5

Plug the power cord into a grounded AC wall outlet, surge protector, or UPS.

Connecting the power cord

AC wall outlet

37

VAIO Computer Quick Start

Connecting the Wireless Keyboard

Your VAIO® computer is supplied with a wireless keyboard. Before attempting to use the wireless keyboard, you must enable communication between the computer and the keyboard.

When attempting to connect the wireless keyboard, confirm that the AA batteries

(supplied) are properly inserted into the keyboard before your computer is turned on.

.

To connect the wireless keyboard

1

Turn on your computer.

2

Press the CONNECT button on the left panel of the computer.

3

Turn the wireless keyboard over.

4

Press the CONNECT button to activate communication between the wireless keyboard and the computer

Connecting the keyboard

Press to connect

38

Connecting the Wireless Keyboard

Additional information about the wireless keyboard

The wireless keyboard requires unobstructed communication with the system unit for proper operation.

❑ Do not exceed a maximum distance of 2 feet between your VAIO® computer and your wireless keyboard.

Confirm that the supplied AA batteries are properly installed.

Press the CONNECT buttons located on the left panel of the computer and on the bottom of the keyboard, to establish communication between the equipment.

Avoid using radio control toys or equipment, CB radios, and other wireless devices in the area near your wireless keyboard. These devices may create interference, causing your keyboard to stop working properly.

❑ Do not place metal furniture near your computer or wireless keyboard, as this may create interference, causing your keyboard to stop working properly.

39

VAIO Computer Quick Start

Connecting the Wireless Mouse

Your VAIO® computer is supplied with a wireless mouse. Before attempting to use the wireless mouse, you must enable communication between the computer and the mouse.

When attempting to connect the wireless mouse, confirm that the AA batteries

(supplied) are properly inserted into the mouse before your computer is turned on.

To connect the wireless optical mouse

1

Turn on your computer.

2

Press the CONNECT button on the left panel of the computer.

3

Turn the wireless mouse over.

4

Slide the power button to the ON position and press the CONNECT button.

Connecting the mouse

Switch to the

ON position

Press to connect

5

Place the optical mouse on an appropriate surface to enable tracking.

40

Connecting the Wireless Mouse

Additional information about the wireless optical mouse

The wireless optical mouse requires an ideal surface texture in order to provide precision pointing and tracking.

Use surfaces such as plain paper, card stock, or fabric that have minimal repetitive patterns.

❑ Avoid surfaces such as mirrors, smooth glass, or magazines that have halftone printing.

The wireless optical mouse requires unobstructed communication with the system unit for proper operation.

Do not exceed a maximum distance of 2 feet between your VAIO® computer and your wireless mouse.

Confirm that the supplied AA batteries are properly installed.

Press the CONNECT buttons located on the left panel of the computer and on the bottom of the mouse, to establish the communication between the equipment.

Verify the infrared receiver on the computer’s front panel is free of obstructions that may prevent proper operation.

Avoid using radio control toys or equipment, CB radios, and other wireless devices in the area near your wireless mouse. These devices may create interference, causing your mouse to stop working properly.

Do not place metal furniture near your computer or wireless mouse, as this may create interference, causing your mouse to stop working properly.

41

VAIO Computer Quick Start

Connecting the Modem Cable

Your computer is equipped with a single modem line jack to connect the supplied modem cable to your telephone wall jack. To use your wall jack for your telephone and modem lines, purchase a “1-to-2” jack adapter device (splitter).

To connect the modem cable

1

Unplug your telephone cable from the wall jack and insert the telephone cable into one of the RJ-11 jacks on a splitter device (optional).

2

Insert one end of the modem cable (supplied) into the other RJ-11 jack on the splitter device.

3

Insert the plug end of the splitter device into the wall jack.

4

Plug the modem cable into the modem line jack on the computer.

Connecting the modem cable

“1-to-2” jack adapter

(optional splitter)

42

Your computer has a protective sticker covering the Ethernet port located on the rear panel. Connect only 10BASE-T and 100BASE-TX cables to the

Ethernet port. Using other cables or a telephone cable may result in an electric current overload that can cause a malfunction, excessive heat, or fire in the port. For help on connecting to a network, see your network administrator.

Turning on Your Computer

Press the power button in from the right side, to turn the computer on and off.

When you start your computer, it may detect new hardware and prompt you to restart your computer. Respond to this prompt immediately.

Turning on your computer

Press the power button in this direction

Press the power button correctly to avoid damage to the computer.

Registering Your Computer

Take advantage of Sony’s commitment to quality customer support and receive these benefits by registering your computer:

Sony Customer Support — Communicate with a Support Representative to troubleshoot problems you may be having with your computer.

Limited warranty — Protect your investment. See the Limited Warranty

Card for more details.

You are prompted to register your computer the first time you turn it on. Follow the on-screen instructions to complete the registration process. If you are not able to register your computer during the first session, you are provided with additional registration opportunities later.

43

VAIO Computer Quick Start

Turning Off Your Computer

Follow these steps when you are ready to turn off your computer for an extended period of time.

To avoid loss of data, do not use the Power button to turn off the computer.

To turn off your computer

1

Click Start in the Windows taskbar, then select Turn Off Computer.

The Turn Off Computer dialog box appears.

2

Select the Turn Off option.

Respond to any prompts about saving your documents.

3

Wait for your computer to turn off automatically—the power indicator light turns off.

4

Turn off any peripheral devices connected to your computer.

If you plan to stop using your computer for a short period of time, use Stand by mode.

About the power button

If your system stops responding, press and hold the Power button for more than six seconds to force your system to shut down. You may need to repeat this procedure if your system does not shut down on the first attempt.

44

In the future, you may want to increase or upgrade the memory in your

VAIO® computer. This section provides information about installing memory.

45

VAIO Computer Quick Start

Installing Memory

The amount of preinstalled memory can vary, depending on the system configuration purchased. See the online Specifications sheet for details about the type and amount of memory installed in your computer.

Observe the proper safety precautions when you add or remove the memory in your computer. See “Before upgrading your computer” in the online VAIO®

Computer User Guide.

Removing the back cover

1

Shut down your computer and turn off all peripheral devices, such as your printer.

2

Unplug your computer and disconnect any peripheral devices.

3

Remove the screws, located on the sides of the system unit, as shown below.

Removing the back cover

Back cover

Cover release latches

4

Press the release latches on the front of the cover and pull the cover forward to remove.

46

Installing Memory

Removing the memory cover

1

Gently place the system unit on a stable surface with the LCD screen facing down.

surface. The work surface must be free of any dirt or debris that may damage the screen.

2

Lift the lower edge of the memory cover and disengage the memory cover tabs from the notches on the chassis.

Removing the memory cover

Memory cover

Memory cover tabs

Lift memory cover edge

3

Remove the memory cover to access the memory module slots.

47

VAIO Computer Quick Start

Removing a memory module

1

Locate the memory module(s) you wish to remove.

2

Push down on the latches, located on both sides of the module slot, to gently eject the module from the slot.

Removing a memory module

Memory module slot

Side

Latch

3

Grasp the memory module by the sides and remove from the system unit.

Store the module in a static-free bag.

48

Installing Memory

Installing a memory module

1

Remove the memory module from its anti-static package, handling it by the edges.

2

Locate the center notch on the bottom edge of the memory module and align it to the center notch in the open module slot.

Installing a memory module

Memory module

Module slot

(open)

Center notch

Side latch

3

Firmly insert the bottom edge of the module into the slot by pressing down evenly against the module’s upper corners.

The side latches snap into position, holding the memory module in place.

To avoid damaging a memory module or the memory module slot, move the side latches slightly outward to relieve pressure. The module is properly inserted when the side latches click into place.

49

VAIO Computer Quick Start

Replacing the memory cover

1

Align the memory cover tabs to the notches on the chassis.

2

Gently press down on the memory cover until the cover snaps into place.

Replacing the memory cover

Memory cover tabs

50

Installing Memory

Replacing the back cover

Gently slide the back cover in, until the cover release latches lock the cover into place.

Replacing the back cover

Back cover

Cover release latches

51

VAIO Computer Quick Start

52

This section describes how to troubleshoot common problems. For information on other troubleshooting topics, see the online VAIO®

Computer User Guide.

My computer does not start.

Verify that the computer is plugged into a power source and that it is turned on. Check that the power indicator is lit on the front panel of the computer.

Confirm that a disk is not in the floppy disk drive bootable floppy disk).

*

(unless you are using a

Confirm that a CD is not in an optical drive (unless you are using a bootable

CD).

Confirm that the power cord and all cables are connected firmly.

If you plugged the computer into a power strip or Uninterruptible Power

Supply (UPS), make sure the power strip or UPS is turned on and working.

Verify that the monitor is plugged into a power source and turned on.

If your system has a built-in monitor, confirm that it is plugged into an appropriate power source and that the system is turned on.

Verify that the brightness or contrast control dials are adjusted correctly. (See the manual supplied with your display for details.)

Confirm that the computer is not in Stand by mode by pressing the Stand by key, located at the top of keyboard.

* Certain VAIO computers are not equipped with a floppy disk drive. You can purchase this equipment separately.

53

VAIO Computer Quick Start

What can I do if my computer or software stop responding?

You can try to locate and close the software program that has stopped responding.

1

Press the Ctrl+Alt+Delete keys. The Windows Task Manager window appears.

2

From the Applications tab, locate the software program that has the status message, “Not responding.”

3

Select the software program that has a Not Responding status and click End

Task. Windows attempts to close the program.

If your computer does not respond or the software program does not close, try the following steps:

1

Save and close any open files, if possible.

2

Press the Alt+F4 keys. The Turn Off Computer window appears.

If the Turn Off Computer window does not appear, press Ctrl+Alt+Delete.

3

Click Restart.

If your computer still does not respond and you cannot restart, shut down your computer by pressing and holding the power button for more than six seconds.

If the software program continues to stop responding or causes your computer to stop responding, contact the software publisher or designated technical support provider.

Pressing and holding the power button for more than six seconds may result in the loss of data from files that are currently open.

54

Sony provides several options to help solve common problems or to locate technical support for your VAIO® computer. This section describes available resources and offers suggestions on how to access this information for maximum results.

You can locate helpful information immediately by consulting your hard copy guides and supplements, or by accessing the online Computer User Guide and the individual software Help files.

Your computer is supplied with these support options:

VAIO® Computer Quick Start — The Quick Start contains information on how to set up your computer quickly and easily. You can find instructions on how to plan an ergonomic work space, connect power cords, cables and peripheral devices, and register your computer with Sony®.

VAIO® Computer User Guide — The online User Guide provides information about configuring, maintaining, and upgrading your computer.

This support resource offers a variety of available topics, enabling you to quickly view specific information using context-sensitive search features. To access the online guide:

1

Click Start in the Windows® taskbar, then click Help and Support.

2

From the VAIO Help And Support Center menu, click VAIO User

Guide.

Specifications — The online specifications sheet describes the hardware and software configuration of your VAIO computer. To view this online information go to http://www.sony.com/pcsupport.

55

VAIO Computer Quick Start

Preinstalled software Help files — Each preinstalled software program provides online Help within the software, that describes the software’s features. In these Help files, you can find tutorials that teach you to use the software and locate troubleshooting support, should problems occur. To access software Help files:

1

Click Start in the Windows taskbar and point to All Programs. A submenu appears, listing all preinstalled software programs.

2

Click the desired software program

*

. The software’s main window appears.

3

From the menu bar, click Help. The Help file appears.

VAIO Software Provides specific information on preinstalled Sony® software.

To access this online software information

1

Click Start in the Windows taskbar.

2

Click Welcome to VAIO life.

Resources for Additional Help and Support

If the information provided with your VAIO® computer does not offer an immediate solution, or you would like to get direct support, try these additional help and support resources.

Sony Online Support Web site

Online help and support are available 24 hours a day, seven days a week, when you visit the Sony Online Support Web site. You can access the Web site at http://www.sony.com/pcsupport.

The Sony Online Support Web site provides:

Information about your specific model computer, such as

❑ hardware and software specifications.

upgrade and maintenance procedures.

safety and legal information.

quick solutions to common problems.

* You can locate the online Help for Sony software programs by pointing to the individual software program’s icon and selecting Help from the submenu.

56

Resources for Additional Help and Support

An automated tutorial library that contains interactive, easy-to-understand lessons on using your computer’s hardware and software features.

Links that enable you to: find the nearest Sony service center locations.

arrange for repairs or check repair status.

review warranty information.

e-mail your question or comments to the Sony Customer Information

Services Center.

❑ check pricing and availability for products, accessories and parts, as well as purchase online.

access the Sony Solutions Knowledge Base, a database that contains answers to many frequently asked questions.

Sony Customer Information Services Center

If other support options do not resolve your issue, you can contact a Sony

Support representative directly.

Before making a call to the Sony Customer Information Services Center, have this basic information readily available.

1

VAIO® computer system type.

2

Model number.

3

Serial number

*

.

Example:

4

Operating system.

5

Hardware feature or software program that has a problem. (See the online

VAIO® User Guide for the appropriate software contact information.)

6

Brief description of the issue.

For VAIO® computers purchased in the U.S. and Canada, contact a Sony

Support representative at 1-888-476-6972.

* The serial number is located on the back panel of your computer. The serial number is on a white barcode label.

57

Printed on 100% recycled paper using

VOC (Volatile Organic Compound) free vegetable oil based ink.

Printed in Japan © 2004 Sony Electronics Inc.

4-681-453-01

Was this manual useful for you? yes no
Thank you for your participation!
