On Variational Methods for Motion Compensated Inpainting
Technical Report
François Lauze, Mads Nielsen
DIKU, Institute of Computer Science, University of Copenhagen
Universitetsparken 1, 2100 Kbh Ø
Denmark
{francois,madsn}@diku.dk
Abstract
We develop in this paper a generic Bayesian framework for the joint estimation of motion and
recovery of missing data in a damaged video sequence. Using standard maximum a posteriori to
variational formulation rationale, we derive generic minimum energy formulations for the estimation
of a reconstructed sequence as well as motion recovery. We instantiate these energy formulations
and from their Euler-Lagrange Equations, we propose a full multiresolution algorithms in order to
compute good local minimizers for our energies and discuss their numerical implementations, focusing
on the missing data recovery part, i.e. inpainting. Experimental results for synthetic as well as real
sequences are presented.
Keywords. Image Sequences Restoration, Bayesian Inference, Optical Flow, Image Inpainting,
Variational Methods.
1
Introduction
Since the birth of the cinema, more than a century ago, and the apparition of video in the 50’s, a huge
amount of Motion Picture material has been recorded on different types of media, including celluloid
reels, magnetic tapes, hard disks, DVDs, flash disks...
Unfortunately, this type of material is subject to artifacts, already at image acquisition, or, for instance,
degradations of the storage medium, especially for reels and tapes, caused by bad manipulation, incorrect
storage conditions, or simply the “patina of time”. These degradations can be of extremely many different
types. For films, some of the problems encountered include, but are far from limited to, image flicker,
noise, dust, real dust or a deterioration caused by the use of incorrect chemicals when developing a
negative, for instance, missing regions and vertical line scratches, usually due to mechanical failures in the
cameras or projectors, degradation of the chemicals, color fading, and even the degradation/destruction
of the support, as it is the case for triacetate films, where excessive storage temperature and humidity
causes the formation of acetic acid (vinegar), and this process is auto-catalytic: once started, it cannot
be stopped. Nitrate cellulose based films are highly flammable. Many movie theaters were burnt down
because of that, and their storage is critical because of explosion risks. Video also is not exempt of
problems. The Telecine, a device used to convert a film to video, can introduce artifacts such as distortions
or Moiré patterns. Repeated playbacks may damage the tape, introducing for instance noise, the lost of
synchronization information produces a disturbing jittering effect. The digital medium has also its own
problems, such as the block artifact due to lossy compression methods, and during network transmission,
some blocks can be lost.
Among these degradations, blotches – i.e, following Kokaram ([33] “regions of high contrast that appear
at random position in the frame (...)”. In these regions, the original data is usually entirely lost and this
paper focuses on recovering the missing data. Digital Inpainting is the name that is commonly given to
the process of filling-in regions of missing data in an image, and although the term was first coined for
spatial images in [9], Image Sequence or Video Inpainting is now widely used. A main difference resides
1
1 INTRODUCTION
2
in the fact that information missing in one frame is supposed to exist in adjacent frames, this is used to
restrict the search space, via interframe motion estimation.
With the increasing computational power of modern computers, more and more sophisticated algorithms are developed for inpainting of still frames as well as video sequences. They are often divided into
stochastic and deterministic methods, although the two approaches often share many modeling aspects.
Spatial Image Inpainting techniques were pioneered by Masnou and Morel [38], location where data
is missing is treated as an object occluding the background and a Elastica based variational model for
the completion of broken level lines is proposed. Bertalmio et al. [9] proposed a Partial Differential
Equations (PDE) based method for filling-in regions by a sort of smoothness transport. They proposed
then a variational technique for recovery of level lines and intensity in [7]. Chan and Shen proposed in
[17] approaches based on Total Variation as well as Elastica minimization. Using a different, discrete
approach, inspired by work on texture generation [22, 21], Criminisi et al. proposed a simple and elegant
patch based method in [19].
Apart from the deterministic/non deterministic division, there exists another level of modeling, One
might speak of a low level analysis approach for a direct study of the image geometry in the spatial case,
or a “simple” 2D+time model, while an high level analysis approach will attempt to model/infer key
descriptions of the underlying 3D scene and/or its dynamics using for instance tracking, hypotheses of
(quasi)-repetitive motion , and use them for sequence reconstruction.
In the latter category, Irani and Peleg in [29] proposed a method that can among others remove foreground objects from a scene. From a multilayer parametric motion representation, foreground occluded
objects can be detected and removed thanks to the motion and intensity information available for the
other layers.
Extending the spatial exemplar based inpainting work of Criminisi et al. in, Patwardhan et al. have
proposed techniques for video inpainting, in the case of static background [44] and extended to relatively
simple camera motion [45].
In the other hand, a series of more “low level” methods have been able to produced high quality
results. Kokaram, in a series of works [35, 33, 34] explored probabilistic “2D+1” based approaches for
joint detection and reconstruction of missing data. Grossauer in [28] used optical flow in order to detect
serious violations which might then be interpreted as blotches, and then performs a simple transport
from neighbor frames. In a similar way, D’Amore et al. [20]) also developed methods for detection and
removal of blotches based on variational motion estimation. In a different way, Wexler et al. [51] proposed
a patch based method for filling in holes, with constrains enforcing spatial en temporal coherence. In
a recent work, Wang and Mirmehdi [49] used spatiotemporal random walks in order to determine best
replacement pixels, taking into account surrounding values.
The work we present here can be seen as a deterministic “lower level” approach to the blotch restoration
problem, where we are given a damaged image sequence, as well as the location of the damages, assumed
to have been obtained by specific means. Some recent automatic approaches provide good results, see for
instance Buades et al. [15] or the one of Wang and Mirmehdi [48]. In the other hand, precise detection
of large blotches can be difficult, and semi-automatic procedures are very often applied.
Starting from a general Bayesian Inference approach, and using standard approaches in motion recovery, we derive a generic variational formulation for joint estimation of motion and recovery of missing
data, we then instantiate this generic class into several energy functionals, we propose to solve them via
their Euler-Lagrange Equation in a fully multiscale framework.
Some of these ideas appeared also in the monograph of Aubert and Kornprobst [6], as a contribution
from the first author of this paper. We have also used variations over this framework for Video Deinterlacing in [31], temporal super-resolution [32] and spatial super-resolution [30]. Ideas presented here where
exposed by the authors in a conference paper [36], and turned to be similar to the ones of Cocquerez et
al. [18], but were developed independently. The connection between these two works was pointed out to
the authors by R. Deriche during a stay of the first author at INRIA Sophia-Antipolis in 2003.
This paper is organized as follows. After having introduced some notations in the first section, a
probabilistic model is discussed in section 2, modeling both the purely spatial behavior for a still frame
extracted from a video sequence, as well the temporal correlation which is expected between the frames,
correlation coming from the apparent motion. More precisely, what the model describes is the joint
probability of an image sequence and a vector field describing apparent motion, knowing that they
2 BAYESIAN FRAMEWORK FOR INPAINTING AND MOTION RECOVERY
3
should agree with a given degraded image sequence. Using Bayesian inference, an expression for a
posterior probability distribution is worked out. Then following Mumford in [41], a generic family of
variational formulations is deduced for the problems of simultaneous motion recovery and inpainting,
as well as simultaneous motion recovery, inpainting and denoising. Minimizations for these variational
formulations provide our variational motion compensated inpainting algorithms.
2
Bayesian Framework for Inpainting and Motion Recovery
In this section we introduce a generic probabilistic framework for the missing data problem, via Bayesian
inference. We first provide a general rationale for writting a posterior probability and via maximum a
posteriori estimation, we derive a generic energy minimization for the inpainting problem.
2.1
A Posterior for missing data
We use discrete settings in order to easily give a sense to the different probability computations used.
Given the degraded sequence u0 , we assume the existence of a degradation process P which results
in u0 , this can be the loss of every odd / even lines in an alternating way, as it is the case in video
interlacing, a spatial or spatiotemporal downsampling or as a less structured collection of missing blocks
of pixels, described by their location Ω with the sequence’s spatial domain D. Our goal is to reconstruct
a sequence u on D and to compute a motion field ~v for that sequence. We introduce therefore the
conditional probability p(u, ~v |u0 , P). Using The Bayes rule of retrodiction, we can write this conditional
probability as a product of a likelihood and a prior divided by an evidence
p(u, ~v |u0 , P) =
p(u0 |u, ~v , P) p(u, ~v |P)
.
p(u0 |P)
(1)
The evidence corresponding to the known data plays the role of a normalizing constant and will be
disregarded in the sequel. We assume that u0 is a degraded version of u, with for instance noise added
in the acquisition process or because of aging, and missing data coming from film abrasion due to a
mechanical failure or a bad manipulation. Therefore the observed degraded image sequence u0 is assumed
to depend only on u and not on the apparent motion ~v – i.e., occlusion and desocclusion are not considered
as degradations, they “belong” to the original sequence. The likelihood term p(u0 |u, ~v , P) is therefore
just p(u0 |u, P). Because of the nature of the causes for missing data, we can assume the independence
of (u, ~v ) and P and the prior is simply
p(u, ~v |P) = p(u, ~v ) = p(u|~v ) p(~v ).
We will now decompose this prior. For that, let’s imagine the following common situation. Using a DVD
player, a person is watching a video on a TV set. He/she pushes the “pause” button of the DVD player’s
remote control. There could be motion blur due to large motion and finite aperture times at image
acquisition, but our spectator expects to see a meaningful still image displayed on the TV screen. When
the “play” button is pushed again, the animation resumes, and this person expects to see an animation
which is coherent with the content of the still, at least for a sufficiently small amount of time, this
coherence corresponding of course to the apparent motion. This leads us to assume that p(u|~v ) has the
form p(us , ut |~v ) where us and ut denote local spatial (still frame) and temporal (animation) distributions
for u, and we factor it as
p(us , ut |~v ) = p(ut |us , ~v ) p(us |~v ).
(2)
As we see, the first term of this factorization is a direct translation of this expected temporal coherence.
For sake of simplicity, we assume the independence of us and ~v . This is not necessarily true, as motion
edges and image edges have a tendency to be correlated, a fact exploited by several motion recovery
algorithms, starting with the work of Nagel and Enkelmann (see for instance [42, 3, 2]). On the other
hand, many optical flow algorithms do not use this potential dependency and provide very accurate
motion estimations, in fact often better as approaches that take explicitly into account spatial edges have
4
3 VARIATIONAL FORMULATION
a tendency to produce over-segmented flows (see [39] for instance). Putting all these elements together,
we finally obtain the following posterior distribution
p(u, ~v |u0 , P) ∝ p(u0 |u, P) p(us ) p(ut |us , ~v ) p(~v )
| {z } | {z } | {z } |{z}
P1
P2
P3
(3)
P4
where P1 is the likelihood of u, P2 is the spatial prior for the sequence, P4 is the motion prior, and P3
is a coupling term that acts both as a temporal prior for the sequence and a likelihood for the motion –
as is the gray level constancy assumption along apparent motion trajectories seen from either image or
motion point of view.
3
Variational Formulation
Among others, a standard way to compute a pair (ū, ~v̄ ) from (3) is to seek for the maximum a posteriori
(MAP) of this expression. The kind of probability functions which are normally used are Gibbsian, i.e.
of the form (1/Z)e−E where E is expressed as a sum over cliques, ([26]) and stochastic algorithms can
be used, as for instance Markov Random Field techniques.
From this point we will assume that the degradation process is given as a known missing data locus
Ω ⊂ D, the spatiotemporal domain of the sequence, and the reconstruction will be though as blotch
removal, although much of what is presented below will still formally be valid for deinterlacing or superresolution. Before discussing this, we introduce some notations and concepts that will be used in the
sequel.
3.1
Notations
The approach for sequence modeling taken in this work follows ideas of ordinary differential equations
and dynamical systems. The spatial domain of a sequence will will be taken to be the unit square
Ds := (0, 1)2 ∈ R2 . The spatial coordinates will be denoted x = (x, y), the temporal coordinate by t and
spatiotemporal coordinate r = (x, t). Given A ⊂ B the complement of A in B will be denoted by B\A
or just Ac (when B is clear from the context). Dt = [0, T ], Dt− = [0, T ), Dt+ = (0, 1]. D = Ds × Dt ,
D− := Ds × Dt− , D+ := Ds × Dt+ . A sequence will be a map u : D → Rn , with typically n = 1 for gray
value sequences and n = 3 for color ones. As used above, Ω will denote the subset of D of missing data
of a sequence. We assume that D is made of “planar particles” x(t) that move smoothly in D, at least
locally, out of some codimension 2 regions, with velocities dx/dt = ~v (x(t)) = ~v (x, t) the instantaneous
spatial velocity vector field. To each spatial velocity field ~v = (v1 , v2 )t , we associate a spatiotemporal
~ = (v t , 1)t .
velocity field V
In this setting we consider instantaneous vector fields ~v : D → R2 . They will not a priori be a
displacement, but a velocity, i.e. the spatial part of the time-derivative of a particle trajectory.
Given a smooth vector field X : D → R3 smooth enough, The directional or Lie derivative of a function
f in the direction X at r is simply
LX f (r) = X(r) · ∇3 f(r)
(∇3 denotes the spatio-temporal gradient)1 . Standard results on ordinary differential equations show that
X has a local flow cX , i.e. a local solution of the differential equation ċX = X ◦ cX and that for h small
enough the map θrX , h 7→ cX (r, h) is a local diffeomorphism from an open subset of D into D (see [25]
for a detailed exposure). Then on has
f (θrX (h)) − f (r)
.
h→0
h
LX f (r) = lim
(4)
It makes clear that if h > 0,
Lh+
X f (r) :=
1 when
f (θrX (h)) − f (r)
h
(5)
f is vector-valued, ∇3 f can be taken to be (Jf )t , the transpose of the Jacobian matrix of f and ∇f · X := Jf X
5
3 VARIATIONAL FORMULATION
is a forward differences approximation of LX , and it we will use when developing discretizations for
numerical solvers, as well as we will use its backward difference approximation
Lh−
X f (r) :=
f (r) − f (θtX (−h))
.
h
(6)
+
We will often forget the h superscript and only write L−
X and LX . Given a “particle” x at time t, under
~
V
~ is as above the spatio-temporal
the velocity field ~v , its position at time t + h is given by θ(x,t)
(h), where V
extension of ~v , and this position has the form (y, t + h) and thus induces a spatial displacement field
v(x, h, t) = y − x,
(7)
obtained by integrating the values of ~v in the interval [t, t+h]. We will denote its spatiotemporal extension
by V.
For a spatial velocity field ~v , we will denote, abusively, by L~v what should be LV~ , and similarly for
h−
Lh+
v and Lv . Denoting by ∇ the spatial gradient operator, one has
L~v f = V · ∇3 f = ~v · ∇f + ft .
We will use spatial and spatio-temporal divergence operators, respectively denoted ∇· and ∇3 ·, although, we will generally drop the subscript in the last notation, as the dimension of the vectorial
argument of ∇· should remove ambiguity. For a map f : D → Rk , J(f ) will denote the Jacobian of f
with respect to its spatial variables and for a map g : D → R, H(g) will denote its Hessian with respect
to spatial variables.
To end this section, we will denote by χA the characteristic function of a set A:
(
1 if x ∈ A
χA (x) =
.
0 if x 6∈ A
3.2
From MAP to Minimization
The MAP problem is first transformed into a discrete energy minimization problem
E(u, ~v )
=
− log(p(u, ~v |u0 , Ω)) = λ1 E1 (u) + λ2 E2 (us )
+λ3 E3 (us , ut , ~v ) + λ4 E4 (~v )
(8)
with λi Ei = − log(Pi ) (λi > 0), and our goal is thus to find a minimizer (ū, ~v̄ ) of E(u, ~v ), E being a
function of the image pixel locations and flow locations through u and ~v . When image and motion field
spaces are provided Euclidean structures, and E is reasonably smooth, a necessary (but not sufficient)
condition for (ū, ~v̄ ) to be a minimizer is to be a zero of the energy gradients with respect to u and v,
gradients that represent the corresponding differentials for the corresponding Euclidean structures, and
denoted by ∇u E and ∇v E in the sequel:
(
∇u E(ū, ~v̄ ) = 0
(9)
∇~v E(ū, ~v̄ ) = 0.
Note however that expression (8) makes sense only when we can take the log of each of the Pi distributions.
An important situation where this is clearly not the case when the likelihood term has the form of a Dirac
distribution:
(
1 if Ru = u0 on D\Ω
P (u0 |u) = δ(Ru − u0 ) =
(10)
0 otherwise
where R is an operator such as a spatial or spatiotemporal blur, or simply the identity. In that situation,
we simply seek for a (ū, ~v̄ ) satisfying

(ū, ~v̄ )
= Argmin λ2 E2 (us ) + λ3 E3 (us , ut , ~v ) + λ4 E4 (~v )
(u,~
v)
(11)
Ru = u
on D\Ω.
0
6
3 VARIATIONAL FORMULATION
In that case, a minimizer (ū, ~v̄ ) should satisfy the following conditions


∇u E(ū, ~v̄ ) = 0 on Ω
Rū = u0
on D\Ω


∇~v E(ū, ~v̄ ) = 0
(12)
At this point, the formulation we have obtained is discrete in nature. Using the Bayesian to variational
formulation proposed by Mumford in [41], limiting expressions for the probability distributions/energy
involved give rise to a continuous energy formulation, treated at least at a formal level, and deterministic
algorithms can be used to carry out the minimization problem. The continuous expressions will also be
denoted Ei . The “game” is therefore to choose meaningful expressions for each of the Ei , which are also
computationally reasonable. Variational 2-dimensional formulations of inpainting can provide the spatial
term E2 and variational optical flow algorithms can be “plugged-in” for terms E3 and E4 , and really
many of them have been proposed in the two last decades. We will extend upon these choices.
In the following paragraphs we argue on the instantiations of the different terms E1 (u; u0 ), E2 (u),
E3 (u, v) and E4 (v), they should present a good trade-off between accuracy of modeling and simplicity in
order to result in computationally tractable algorithms.
3.3
Image data term
The data term provides a measure of deviation between an observed sequence and a candidate reconstruction. As mentioned above, this term is relevant in the inpainting-denoising case, and has generally
the form
Z
E1 (u; u0 ) =
L(Ru, u0 ) dx dt
Ωc
For an additive noise, L(x, y) = φ(x − y), for a multiplicative one, L(x, y) = φ(y/x). Noise can be very
complicated to apprehend, and generally a simple model is assumed, such as additive Gaussian white
noise with a fixed variance or a more general Laplace noise, and φ(x − y) = |x − y|p for a p ≥ 1. In this
work we have restricted ourselves to the Gaussian white noise case: φ(x − y) = (x − y)2 and assume that
R = I, the identity transform – we ignore blurring, or merely we assume blurring is part of the sequence
to be restored.
3.4
Spatial regularization terms
Such a term would generally have the form
E2 (u) =
Z
D
L(∇u, ∇2 u, . . . ) dx dt
where we recall that ∇ denotes the spatial gradient. Derivatives of order > 1 are rarely used in practice
(although see [37]). Tikhonov regularization corresponds to the case L(w) = φ(|w|2 ) with φ(x)
√ = x,
but is to be avoided in general, as it blurs edges. One of the most popular choice is φ(x) = x which
corresponds to the Total Variation of
√ Rudin, Oscher and Fatemi [46]. Because of its non-differentaibility
at 0, is is often replaced by φ(x) = x + ǫ2 where ǫ > 0 is small. Other φ, some non convex, have been
reported to behave very well [6].
3.5
Motion likelihood – Temporal regularization
As our little story illustrated it, some form of coherence on the sequence content must be present. It
is expressed as the requirement that some derived quantity from the sequence is conserved across time,
quantities that depend on scene illumination, the image formation process, etc. . . In the temporal
discrete setting, this conservation can be written, using forward differences along a motion field as
L+
V F (u)(r) = 0,
∀r
(13)
7
3 VARIATIONAL FORMULATION
and in the continuous temporal setting, using the Lie-derivative
L~v (F (u)) = ~v · ∇F (u) +
∂F (u)
= 0.
∂t
(14)
The continuous equation is generally derived as an approximation of the discrete one. In this work we
used a view point a bit different: integrating along fixed time ranges the continuous equation will provide
the discrete one.
The conservation equations (13)–(14) do not generally hold perfectly, due to a series of factors: among
others, occlusions / disocclusion. Noise can also be a source of error, although presmoothing can be built
into F . F can be vectorial in order to express that several elementary quantities are expected to be
conserved, and will always be assumed to be a linear differential (or integro-differential) operator.
In order to cope with conservation equation failure, the conservation properties are enforced in a least
square or generalized least square sense via terms
Z
L (L~v F (u(r))) dr.
E3 (u, ~v ) =
D
For an x seen as ”a collection P
of features” (x1 , . . . P
, xk ) where the xi ’s can themselves be vectors, we will
always assume that L(x) = φ( i |xi |2 ) or L(x) = i φi (|xi |2 ) where |xi | is the standard Euclidean norm
of xi .
The most commonly used operator F is simply the identity: the intensities should match along the
motion trajectories. Although clearly limited in validity [47], it works well in many cases. Higher order
differential operators have been used, such as the spatial gradient, spatial Laplacian, spatial Hessian
etc. These can be potentially attractive to enforce specific properties for motion recovery. The spatial
gradient will prefer local translational motion. The Laplacian, being rotationally invariant would not
penalze rotational motion... However one must keep in mind that a differential operator of degree n will
give rise to terms of degree up to and including 2n in the Gâteaux derivative of E3 wrt u. For that
reason, we have limited our investigations to the identity and spatial gradients.
3.6
Motion regularization
A large amount of work has been devoted to regularizer terms for optical flow algorithms to accommodate
the different situations encountered in practice, ranging from natural image sequences, medical image
sequences, fluid dynamics data... Having Film/Video restoration as our goal, we focus here on natural
image sequences. They are generally composed of moving rigid/semi-rigid objects projected on the camera
plane, resulting mostly in locally translational motion.
Thus a regularizing term should enforce this behavior, in order to recover essentially smooth small
varying regions with in general 1D discontinuities between these regions. We will limit ourselves to terms
that depend on the spatial or spatiotemporal Jacobian of the motion field. More details will be provided
in the next paragraph.
3.7
Proposed variational formulations
From the discussion above, we propose several actual variational formulations for the joint motion recovery
/ image sequence inpainting. For each formulation, we consider the inpainting/denoising problem and
the pure inpainting formulation. For inpainting denoising we place ourselves in the additive Gaussian
noise situation discussed in Subsection 3.3:
Z
1
(u − u0 )2 dr.
(15)
E1 (u; u0 ) =
2 Ωc
The spatial regularization term used in this study is a regularization of the Total Variation term:
Z
E2 (u) =
φ(|∇u|2 ) dr
D
(16)
8
4 RESOLUTION METHODOLOGIES
√
where φ(x2 ) = x2 + ǫ2 for a certain ǫ > 0. From now, φ will always denotes this function. This type of
regularization in the spatial case is known to generate starcaising effects artifacts [43]. Experiments in
Section 6 on Inpainting/Denoising shows some tendency to it, when the weight of spatial regularization
is relatively important. In pure inpainting, however, this term merely acts as brightness regularization
and the above mentioned artifacts are much less stronger, on invisible.
We present candidates for remaining two terms in the following two tables. Table 1 deals with the
motion likelihood/temporal regularization part while Table 2 deals with motion regularization terms. All
these terms are “borrowed” from well-known variational optical flow formulations, λ3 and λ4 being some
weights > 0. In the sequel, we will refer to one of these terms as Eik where Eik is the k-term (k-row) of
the Ei array (i = 3, 4) presented below.
1
2
3
E3 (u, v) φ (L~v u)2 dr D−
R
2
2
+ γ|L~v ∇u| 2dr
R D− φ (L~v u)
2
φ (L~v u) + γφ |L~v ∇u| dr
D−
R
Table 1: Terms coupling intensity and motion.
1
2
3
R
E4 (v)
2
φ
|∇~
v
|
+ φ |∇~v2|2 dr
1
D−
R
2
2
R D− φ |∇~v1 |2 + |∇~v2 | 2 dr
φ |∇3~v1 | + |∇3~v2 | dr
D−
Table 2: Terms for motion field regularization
Terms E31 and E41 are regularizations of the 1-norm terms proposed by Aubert et al. ([4, 5]). Terms E32
and E33 , in their time discrete version where L+
V is used instead of Lv , have been respectively proposed by
Brox et al. [11] (that also proposed regularizer E43 ) and Bruhn and Weickert [12] and proved to provide
highly accurate flow. The time-continuous version E32 was used in the authors’ conference paper [36]. E42
was proposed by Weickert and Schnörr in [50].
All the combinations were implemented, although we present only some of them in our experiments,
for obvious space reasons.
We have not yet discussed the fact that image sequences can be vector-valued. For a sequence u =
(u1 , . . . , un ) : D → Rn , n > 1, the same energy terms are used, where we then set
|∇u|2 =
4
n
X
i=1
|∇ui |2 ,
2
(L~v u) =
n
X
2
(L~v ui ) , . . .
(17)
i=1
Resolution Methodologies
Minimizing the energies presented in the previous section is done via solving their corresponding flow
and image Euler-Lagrange equations. Motion estimation requires normally a multiresolution / multiscale
approach in order to be able to handle large displacements. We adopt a multiresolution approach here
and we propose to interleave the images inpainting steps with the flow recovery ones at each resolution
level. In this section we describe in more details this resolution approach and we introduce tools for
computing the image Euler-Lagrange equations associated with our formulations. We then process to the
computation of the different energy gradients, at least for the image related terms. Indeed, the steps for
solving motion recovery are well studied and we follow the references we have mentioned in the previous
section, we won’t provide the details of their derivations.
4 RESOLUTION METHODOLOGIES
4.1
9
Multiresolution framework
Motion computation depends critically on the range of the different discrete filters supports used for
the estimation of the differential/finite differences quantities in the optical flow equation, and/or the
smoothness of the input image data. For that reason multiscale or multiresolution techniques are needed
in order to avoid meaningless local minima. On the other hand, a good approximation of the motion
field at a given resolution should allow a precise recosntruction of image information at that resolution
by motion compensated diffusion. Therefore we present here a methodology that aims at producing
algorithms converging to a reasonable minimizer by solving iteratively for the image and the flow, in a
complete spatial multiresolution setting. We implicitly build pyramids for the image sequence and the
flow. In the sequel we assume that we have N + 1 resolution levels, level N being the coarsest, level 0
being the finest, original one. We do not require a 1/2 spatial scaling factor between consecutive levels.
We are seemingly in presence of an hen and egg problem, since in order to compute a flow with our
methods we need image values, that are a priori unknown inside the degradation locus, and we need a
flow in order to inpaint inside the degradation locus. This will be handled by using a degenerated form of
the inpainting algorithm at coarsest resolution, that allows us to recreate a starting image sequence uN .
At coarsest resolution, the interframe motion is assumed to be very small, and we inpaint the sequence
by computing a minimizer of the corresponding energy formulation where we have assumed ~v = 0 – no
motion is present. The non-linearity of the image equation provides a form for motion adaptivity.
Once we have a coarsest resolution inpainted sequence, we can start our multiresolution process. What
we do is to modify the motion field recovery algorithm by running the inpainter after the interpolation
of the lower resolution flow, and before updating the flow at that resolution level. Figure 1 illustrates a
typical iteration. At a given pyramid level k + 1, let us assume that we have an inpainted sequence uk+1 .
It is then used, together with an interpolated version of ~v k , to compute a motion field at that resolution,
to produce ~v k+1 . Then at resolution level k, we first interpolate the flow, using for instance a bilinear or
bicubic interpolation, to produce an intermediary flow field ~vik . This flow is used in order to reconstruct
the sequence uk at level k.
Figure 1: Multiresolution inpainting. From a sequence uk+1 at resolution level k + 1, 1) the optical flow
is computed, 2) it is interpolated at resolution level k and 3) used to inpaint the sequence at level k. This
process is then iterated at lower pyramid levels.
A general algorithm (not tied up to our particular formulation) is given in table 3. As it can be seen
from this sketchy algorithm, the difference between a generic multiresolution optical flow algorithm and
our inpainter are simply the interleaved inpainting steps.
10
4 RESOLUTION METHODOLOGIES
1. Compute uN by spatial TV and motion adaptive diffusions.
2. For k = N − 1 downto 1
(a) Compute ~v k+1 from uk+1
(b) Compute intermediary flow ~vik by interpolation of ~v k+1
(c) Inpaint uk using ~vik
3. Compute ~v 0 from u0
4. Output (u0 , ~v 0 ).
Table 3: Generic Motion Recovery and Inpainting Algorithm,
4.2
Derivation of Euler-Lagrange equations
In this subsection we compute the different energy derivatives with respect to image variables for the terms
proposed in Subsection 3.7. The velocity related derivatives will be provided without calculation as they
have been derived by authors mentioned in Subsection 3.7, at the exception of the new flow smoothing
term. We first provide the general methodology to compute these derivatives and some elementary results
used in the sequel. We restrict ourselve to scalar valued images and will indicate extension to the vector
valued cases.
4.2.1
Computing functionals differentials
In order to obtain the Euler-Lagrange equations, we use the technique of directional derivatives for
computing differentials dEu of u 7→ E(u):
ξ 7→ dEu ξ = ℓ′ (0),
ℓ(τ ) = E(u + τ ξ)
(18)
and use of adjunction/
integration by part will allow to transform dEu ξ, which generally appears as an
R
inner product D L1 (u)L2 (ξ) dx of a term L1 involving derivatives of u and a term L2 linear in ξ and
some of its derivatives on the domain D, into an equivalent expression
Z
Z
dEu ξ =
Fu ξ dx +
ξGu (ν) ds
∂D
D
where ∂D is the boundary of D, ν its exterior normal field, and under proper conditions on acceptable
deformations ξ or on u on the boundary D making this boundary integral vanish, Fu is the gradient of
E at u for this inner product. We will perform computations on each energy part and keep track of
resulting boundary integrals.
We will present integration by part formulas for the spatial gradient operator ∇ as well as LV . They
all result from the standard integration by part / Stokes formula [23].
Proposition 4.1 Let D ⊂ R2 ×[0, T ] the domain of a spatiotemporal sequence, ∇ be the spatial gradient,
∇· the spatial divergence on D and νs the spatial component of the exterior unit normal to the boundary
∂D of D. Let u : D → R and ~v : D → R2 be a C 1 -vector field on D. Then
Z
Z
Z
∇u · ~v dx = −
u ∇·~v dx +
u ~v · νs ds.
D
where s is the area measure on ∂D.
D
∂D
11
4 RESOLUTION METHODOLOGIES
Proposition 4.2 Let D ⊂ R2 × [0, T ] the domain of a spatiotemporal sequence, ϕ, ψ : D → Rk , k ≥ 1,
~ its “spatiotemporal” extension, as introduced in Section 3.1. Then
~v : D → R2 be a C 1 -vector field and V
one has
Z
Z
Z
(Lv ϕ) · ψ dr = −
ϕ ∇3 · (ψ ⊗ V ) dr +
(ϕ · ψ) (V · ν) ds
D
D
∂D
Z
Z
~ · ν ds
= −
ϕ · [L~v ψ + ψ ∇ · ~v ] dr +
(ϕ · ψ) V
∂D
D
where ν is the exterior unit normal to the oriented boundary ∂D of D and s is the measure on ∂D and
⊤
and the
− · − is used to denote inner products both on Rk and R2 and ψ ⊗ V = ψ1 V ⊤ , . . . , ψk V ⊤
divergence is applied componentwise, i.e., ∇·3 (ψ ⊗ V ) = (∇·3 (ψi V ))i=1...k .
The actual velocity field may present discontinuities, as well as functions ϕ and ψ. The simple formula
above must then be replaced by a more complex one, as some terms must be considered as measures [6],
but we will not consider it in this work, the problem becoming theoretically very difficult. A practical
way to handle it will be provided by the nonlinearity of the terms considered.
In the following gradient computations, we will for legibility reasons, omit the different λi weights from
the energy components.
4.2.2
Data term
If one wants to use the inpainting/denoising formulation, term E1 (u; u0 ) defined in formula (15) must be
differentiated with respect to u and using (18), one finds immediately that
Z
dE1u ξ =
(19)
(u − u0i ) ξ dr, ∇u E1 = χΩc (u − u0 ).
Ωc
When u0 = (u0i )i=1...k and u = (ui )i=1...k have values in Rk , equations above are simply replaced by
∇ui E1 = χΩc (ui − u01 ),
4.2.3
i = 1, . . . , k.
Spatial regularity term
The derivation of the gradient of the spatial regulariry term E2 given in formula (16) is rather classical.
We recall it however as we are interested in the boundary terms that come with it. A straightforward
computation using directional derivatives and Prop. 4.1 leads to
Z
dE2u ξ = −
ξ∇· (A∇u) dr
(20a)
Z D
+
ξA (∇u · νs ) ds
(20b)
∂D
where we have set
A := A(u) := φ′ (|∇u|2 ).
(21)
In the pure inpainting case, D = Ω, and we restrict to deformations ξ that have compact support in Ω,
which means that the boundary term (20b) vanishes here and the gradient is given by
∇E2u = −χΩ ∇· (A∇u) .
(22)
When u is vector-valued, by using squared-gradient magnitude as defined in formula (17), one obtains
the k terms
∇ui E2 = −χΩ ∇· (A∇ui ) , i = 1, . . . , k
which are coupled via their common diffusivity A.
12
4 RESOLUTION METHODOLOGIES
4.2.4
Temporal prior / motion likelihood term
Terms E3i couple intensity and motion. We need to compute their gradients with respect to intensity and
with respect to motion, and the novel part is really the intensity gradient. For that reason we present
computations for E31 and E32 as well as the result for E33 . Here too, integration domains depend on the
type of problem we are interested in, it will be D = Ω for pure inpainting, and D = D for inpainting
denoising. Gradients with respect to motion fields are provided without any computation and we won’t
detail their adaptation in the multiresolution setting, which is standard and properly explained in the
references on optical flow that we provide.
The term E31 . We start with term E31 as defined in Table 1: a straightforward calculation using
formula (18) and Prop 4.2 gives
Z
1
dE3u
ξ = −
[L~v (B1 L~v u) + B1 (L~v u) ∇· ~v ] ξ dr
(23a)
D
Z
~ · ν ds
+
ξB1 L~v u V
(23b)
∂D
where we have set
B1 := B1 (u, ~v ) := φ′ (|L~v u|2 ).
(24)
Here too, in the pure inpainting case, ξ has compact support on Ω and the boundary integral (23b)
vanishes, the sought gradient is
∇u E31
= −χΩ L~v [B1 L~v u]
−χΩ B1 (L~v u) ∇· ~v .
(25)
When u is vector valued, B1 couples the different channels via formula (17) and one obtains k terms:
∇ui E31 = −χΩ (L~v [B1 L~v ui ] + B1 (L~v ui ) ∇· ~v ) ,
i = 1, . . . , k.
The term ∇~v E31 has been computed by many authors, see for instance [50], and, for the general vectorvalued setting, is given, with our notations, by the vectorial expression:
∇~v E31
= B1
k
X
i=1
(L~v ui ) ∇ui
and is associated with vanishing Neumann Boundary conditions.
The term E32 . The additional gradient magnitude term in energy E32 induces higher order terms in
the differential. Once the directional derivative is computed, in order to transform it as a sum of integrals on the domain and a boundary intergral, we need to apply Prop. 4.2 and Prop. 4.1. A careful but
nevertheless straightforward computation provides
Z
2
dE3u ξ = −
ξ [L~v (B2 L~v u) + B2 (L~v u) ∇· ~v ] dr
(26a)
D
Z
+γ
ξ∇· [L~v (B2 L~v ∇u) + B2 (L~v ∇u) ∇· ~v ] dr
(26b)
D
Z
−γ
ξ [L~v (B2 L~v ∇u) + B2 (L~v ∇u) ∇· ~v ] · νs ds
(26c)
Z ∂D
~ · ν) ds
+
B2 [ξL~v u + γ∇ξ · L~v ∇u] (V
(26d)
∂D
where we have set
B2 := B2 (u, ~v ) := φ′ |L~v u|2 + γ|L~v ∇u|2 .
(27)
13
4 RESOLUTION METHODOLOGIES
Once again, for the pure inpainting case, boundary integrals 26c and 26d vanish and the corresponding
gradient is
∇u E32
=
−χΩ [L~v (B2 L~v u) − γ∇· (L~v (B2 L~v ∇u))]
−χΩ [B2 (L~v u) ∇·~v − γ∇· (B2 (L~v ∇u) ∇·~v )] .
(28)
In the vector valued case, each component is given by the formula above, replacing u by ui , the components
coupling provides from B2 .
The gradient with respect to the motion field ~v of this term is, in the general vector valued case, given
by
k
X
∇v E32 = B2
[(L~v ui ) ∇ui + H(ui )L~v (∇ui )] .
i=1
The term E33 . Similar computations can be performed for the term E33 and similar complex boundary
integral terms appear in the computations. We set
B3 := B3 (u, ~v ) := φ′ (|L~v ∇u|2 )
(29)
and together with B1 that was defined in formula (24), we get
Z
3
dE3u
ξ = −
ξ [L~v (B1 L~v u) + B1 (Lv u) ∇· v] dr
D
Z
+γ
ξ∇· [L~v (B3 L~v ∇u) + B3 (L~v ∇u) ∇· ~v ] dr
ZD
−γ
ξ [L~v (B3 L~v ∇u) + B3 (L~v ∇u) ∇· v] · νs ds
Z ∂D
~ · ν) ds
+
[ξB1 L~v u + γB3 ∇ξ · L~v ∇u] (V
(30a)
(30b)
(30c)
(30d)
∂D
In the pure inpainting case, boundary integrals vanish because of conditions on ξ and the sought gradient
is
3
∇E3u
4.2.5
=
−χΩ [L~v (B1 L~v u) − γ∇· (L~v (B3 L~v ∇u))]
−χΩ [B1 (L~v u) ∇· ~v − γ∇· (B3 (L~v ∇u) ∇· ~v )] .
(31)
Boundary terms for minimization with respect to image
So far we have not discussed boundary conditions for the inpainting/denoising problem where the integration domain is D and we cannot assume that a deformation direction vanishes along ∂D. The resulting
boundary integrals are rather complex. We consider the case arising from combining spatial regularity
term E2 and temporal regularity term E31 . The resulting boundary integral comes from (20b) and (23b):
Z
h
i
~ · ν) ds
ξ λ1 ∇u · νs + λ3 B1 L~v u(V
∂D
and the natural boundary condition is thus to impose that
~ · ν) = 0.
λ1 ∇u · νs + λ3 B1 L~v u(V
On domain D exterior normals are respectively ν = ±(1, 0, 0)T , ±(0, 1, 0)T and ±(0, 0, 1)T corresponding
to “vertical”, “horizontal” and “temporal” faces of the domain. With these vectors, the conditions become
ux = −λ3 v1 B1
uy v 2 + ut
,
λ2 + λ3 v 1 B 1
resp. uy = −λ3 vy B1
ux v 1 + ut
,
λ2 + λ3 v 2 B 1
resp. ut = −(ux v1 + uy v2 )
if one uses the expansion L~v u = ux v1 +uy v2 +ut . However, such an expansion is problematic numerically.
Indeed, it is well known in the optical flow literature that such an expansion requires sufficient smoothness
14
4 RESOLUTION METHODOLOGIES
on u and/or small motion, and when these requirements are not fulfilled, one has to use approximations
such as the one given in formulas (5) and (6) in the previous section.
A stronger requirement can be imposed, that both L~v u and ∇u · νs vanish simultaneously. If it holds,
then the boundary integral vanishes, but imposing such a requirement may lead to an overdetermined
system: for instance, on the “vertical” face, using the above Lie derivative expansion, it becomes
(
ux = 0
uy v 2 + ut = 0
and while the first equation expresses the absence of variation across the boundary, the second is problematic as uy , ut and v2 are generally estimated from ~v and u from already known values of the image.
We will nevertheless assume that L~v u = ∇u · νs = 0 as, the use of standard schemes for computing
gradient and the schemes that come from (5) and (6) for computing L~v u provide a simple and efficient
numerical treatment of these boundary conditions. These can also be extended to the terms E3 2 and
E33 by requiring also that L~v ∇u = 0 on ∂D. In fact, without such an assumption, one cannot get
rid of boundary terms appearing in the computations of differentials for E3 2 and E33 , where not only
a deformation ξ appears, but also its spatial gradient ∇ξ. What makes the difference with the pure
inpainting formulation is that it appears extremely difficult to control what happens at scene boundary.
If one could assume null camera motion and moving objects remaining in the image domain, boundary
difficulties would vanish, but this is in general a much too severe restriction.
What usually counterbalances the inconsistancies of our choice of boundary conditions is the reaction
to the data term: we are forced to stay reasonably close to the observed data u0 , along the boundary too.
With these assumptions, the three gradient terms ∇u E31 , ∇u E32 , and ∇u E33 are easily computed in the
inpainting-denoising formulation and are given by
∇u E31
∇u E32
3
∇E3u
=
=
−L~v [B1 L~v u]
−B1 (L~v u) Div ~v ,
− [L~v (B2 L~v u) − γ∇· (L~v (B2 L~v ∇u))]
− [B2 (L~v u) ∇·~v − γ∇· (B2 (L~v ∇u) ∇·~v )] ,
=
− [L~v (B1 L~v u) − γ∇· (L~v (B3 L~v ∇u))]
− [B1 (L~v u) ∇· ~v − γ∇· (B3 (L~v ∇u) ∇· ~v )] .
Two important remarks regarding the structure of these terms (also valid for their pure inpainting counterpart):
• First, one observes that these three gradient terms ∇u E31 , ∇u E32 , and ∇u E33 are each decomposed in
two parts, a part containing a double differentiation along the flow field via L~v (), which corresponds
to diffusion along a flow line, and a term where ∇· ~v appears, which corrects for the non parallelism
of the motion field ~v . These terms are non linear transport along trajectories of the velocity field
and are controled by the flow divergence. This means that not only the punctual value of ~v must
be taken into account but also its variations. This is a consequence of Prop. 4.2 and is to be put
in parallel with duality ideas of Florack et al. in [24], but see also [52, 8, 39].
• The second remark concerns the assumptions made on conserved quantities in order to build the
different terms E3i . The corresponding image gradients make clear that these conservations should
be enforced for the image minimizers of these energies, with intensity diffusion for intensity conservation and spatial gradient diffusion for spatial gradient conservation.
4.2.6
Flow regularity terms
As mentioned already, their regularizers E4i , i = 1, 2, 3, are borrowed from existing motion recovery algorithms, and their gradient calculations, with its multiresolution adaptation, have been presented in the
15
5 DISCRETIZATION
papers already mentioned. We just briefly recall the results.
The term E41 . The two gradient components are independent, and if one sets
C11 := C11 (~v ) := φ′ |∇v1 |2 , C12 := C12 (~v ) := φ′ |∇v2 |2 ,
one gets
∇~v E41 = −
∇· C11 ∇v1 .
∇· C12 ∇v2
The term E42 . The two gradient components are coupled via the common diffusivity
C2 (~v ) = φ′ |∇v1 |2 + |∇v2 |2
and
∇~v E42 = −
∇· (C2 ∇v1 )
.
∇· (C2 ∇v2 )
The term E43 . This term is a simple spatio-temporal extension of the previous one, the new diffusivity is
C3 (~v ) = φ′ |∇3 v1 |2 + |∇3 v2 |2
and
∇~v E43
∇· (C3 ∇3 v1 )
=−
∇· (C3 ∇3 v2 )
where the divergences are spatio-temporal here since we use the spatio-temporal gradients of the vi .
We note that these gradients formulations are naturally associated to Neumann boundary conditions
on the components of ~v , the main derivation mechanism being used is given by Prop. 4.1.
5
Discretization
For optical flow recovery parts, we use discretizations that have been proposed in the papers where we
“borrowed” this terms. The discretization of spatial (and spatio-temporal) divergence terms are quite
standard in the literature, see for instance [16, 6] and won’t be discussed in this paper.
We will thus exclusively concentrate on the part of the inpainting equations that come from diffusion
along flow lines i.e., terms of the type E3i . Because, in the numerics we need to use time discretized
sequences, displacement fields must be used instead of velocity fields, we modify in a natural way our
formulations to handle them, with classical warping techniques. These displacement fields do usually
provide subpixel accuracy, making necessary the use of some form of spatial interpolation, which in turn
make cumbersome the direct development of completely discrete schemes. In order to avoid that, we use
an intermediary formulation where only the time part is discretized.
We will first study the semi-discrete schemes, then discuss the discretization of spatial terms of the
form ∇· (a∇u) that appear both in the spatial regularizer term and the tow higher order ∇u E3i , i = 2, 3.
the spatial discretization. In the inpainting denoising settings, we need to discretize the gradient of the
term E1 as given by (19), this almost trivial, once one has taken care of multiresolution discretization
for χΩ . We thus discuss briefly points related to the multiresolution setting. We end by discussing the
approaches we have used to implement the final numerical solutions of the algebraic equations obtained
from discretization.
In the sequel we will assume that we have a spatio-temporal grid with spatial grid spacing hs (we
assume the spatial grid to be squared, for simplicity) and temporal grid spacing ht . Given a function
f : R2 × R → Rk , its temporal discretization will give rise to a family
(fk )k∈Z ,
fk = f (−, −, kht ) : R2 → Rk .
We will not consider explicitly the full discretization, as the general need to estimate several quantities
at non-grid point locations would make it very cumbersome.
16
5 DISCRETIZATION
5.1
A time-discrete scheme.
In order to discretize the terms ∇~v E3i , we start with a temporal-only discretization of them, and this for
two main reasons. First, displacement fields have generally subpixel accuracy, necessitating some spatial
interpolation. Second: temporal discrete sequence modeling is at the heart of multiresolution / warping
handling of motion recovery and most of these warping based motion recovery methods all use at some
point the Lie Derivative semi-discrete approximation in formula (5).
We will indicate some of the differences that naturally appear in the gradient terms with respect to
flow in this setting.
In order to develop schemes, we start from the continuous energy terms that we discretize in time and
derive analogues of Prop 4.2, using the Lie derivative forward difference expression defined in formula
(5). To get rid of the boundary conditions difficulties that arise from boundary integral in Prop 4.2, they
would be much worse in the semi-discrete case, we extend artificially the spatial domain to the whole
of R2 and the temporal range to the whole of R, while we will assume that both the sequence and the
velocity field have compact support.
Let φ, ψ : R2 × R → Rk be sequence, (φk )k∈Z and (ψk )k∈Z their temporal discretizations. Denote by
vk : R2 → R2 the displacement field v(−, kht , ht ) where v(x, t, h) was defined in formula (7). Following
(5) and (6), we set, with some abuse of notation, and dropping the subscript t from the temporal spacing
ht ,
φk (x) − φk−1 (x − vk (x))
φk+1 (x + vk (x)) − φk (x)
,
Lh−
, k ∈ Z.
Lh+
v φ k :=
v φ k :=
h
h
For k ∈ Z, set Hk = I + vk , where I is the identity map of R2 . For h small enough, this is a local
diffeomorphism if the velocity field v is smooth. Because of the compact support assumption, v is
bounded in norm, implying that for h small enough, Hk is a diffeomorphism.
Proposition 5.1 Assume that the Hk ’s are global diffeomorphisms. Define (Kk )k by Kk+1 = Hk−1 , and
set wk = I − Kk . If |JKk | is the Jacobian determinant of Kk , |JKk | = 1 − ∇· wk + |Jwk | and the
following holds:
XZ
XZ
∇· wk − |Jwk |
h−
dx.
Lh+
φ
ψ
◦
K
(x)ψ
(x)
dx
=
−
L
ψ
φ
−
k−1
k
k
k
v
w
k
k
h
R2
R2
k∈Z
k∈Z
The proof is straightforward via the change of variables theorem and renaming of summation and integration variables. The backward displacement field wk is given by
Z h
~v (x(kh − τ ), kh − τ ) dτ.
wk (x) = −
0
and passing to the limit h → 0, kh → t0 in the above proposition, one easily gets Prop. 4.2 (it is easy to
check that in the limit ∇· wk /h → −∇· ~v and |Jwk |/h → 0) with the same problems in term of modeling:
~v is generally not smooth: it should present some discontinuities, due to occlusion/disocclusion. Here
too, theoretical and practical difficulties appear, and we do not consider this case, a practical solution is
partially provided by the use of non quadratic data and regularizing terms in the variational formulations,
and some smoothness can anyway be justified by the smoothing effect of the discretization.
Note that the result stated in Prop. 5.1 is essentially an adjunction result for the Hilbert space of
functions families with inner product
XZ
φk ψk dx
(φ|ψ) =
k∈Z
R2
with the associated notion of gradient that we use in the sequel.
We will use the displacement fields and warp notations from Prop. 5.1 and as we had introduced in
Subsection 4.2.4, the spatio-temporal coefficient functions Bi , i = 1, 2, 3, we introduce their counterparts
sequences Bi± , i = 1, 2, 3, respectively defined by:
2 2 +
−
′
h−
= φ′ Lh+
u
B1k
,
B
=
φ
L
u
,
v
w
1k
k
k
17
5 DISCRETIZATION
+
= φ′
B2k
2 h− 2 2
−
+ γ Lh+
= φ′ Lh−
B2k
v ∇u k ,
w u k + γ Lw ∇u k ,
2 2 −
+
B3k
= φ′ Lh−
B3k
= φ′ Lh+
w ∇u k .
v ∇u k ,
Lh+
v u
We will also set
2
k
and
∇· wk − |Jwk |
.
h
Fk =
(32)
We look at the simplest term E31 and detail the derivation of its semi-discrete gradient. To be in the
assumptions of the above proposition, we extend the spatial domain to the whole of R2 and assume that
the both the image sequence and velocity fields have compact support. Let u = (uk )k the family of image
frames. Using forward difference approximation of Lie derivative, the semi-discretization of E31 is
Z
2 1X
1
φ Lh+
Ē3 (u, v) =
v u k dx.
2
R2
k∈Z
In order to compute its gradient with respect to u, we use the directional derivative approach, and for
1
ξ = ℓ′ (0) where ℓ(τ ) = Ē31 (u + τ ξ, v) to obtain
ξ = (ξk )k , we compute dĒu3
XZ
+
1
h+
dĒ3u
ξ=
B1k
Lh+
v u k Lv ξ k dx.
k∈Z
R2
Applying the above proposition, one gets
i
h
XZ
+
+
h+
1
dx
B1k−1
Lh+
ξk Lh−
dĒ3u ξ = −
v u k−1 ◦ Kk
w B 1 Lv u k − Fk
k∈Z
R2
from which the k-component of the sought gradient can be written as
+
+
h+
∇u Ē12 k = −Lh−
B1k−1
Lh+
w B 1 Lv u k + Fk
v u k−1 ◦ Kk
−1
But, by a straightforward calculation, since Kk = Hk−1
, one gets that
Lh+
v u
k−1
◦ Kk = Lh−
w u
k
,
+
−
Bik−1
◦ Kk = Bik
.
−
For a given x ∈ R2 , set x+
k = Hk (x) = x + vk (x), xk = Kk (x) = x − wk (x). Then we can write
∇u Ē31
(x)
k
=
+
+
+
+
−
−
B1k
uk−1 (x−
k ) − (B1k + B1k )uk (x) + B1k uk+1 (xk )
h2
−
)
u
(x)
−
u
(x
k−1 k
− k
Fk .
B1k
h
−
(33a)
(33b)
The spatial grid of the problem is usually imposed, and a spatial interpolation technique is necessary
±
to compute the u(x±
k ) and the Bi . In this work, we have used bilinear and bicubic interpolations. A
natural question, when implementing schemes based on the above partial discretization is what to do
when x±
k falls out of the numerical domain. The easiest solution is then use the value at x instead, this
h−
means that we impose (Lh+
v u)k = 0 (resp. (Lw u)k = 0) which are the numerical translations of the
boundary conditions we discussed in Paragraph 4.2.5. The same type of operations are applied for the
semi-discrete version of energy E32
Z
h+
2
2 1X
dx.
u
L
∇u
+
γ
φ Lh+
Ē32 (u, v) =
v
v
k
k
2
R2
k∈Z
18
5 DISCRETIZATION
This lead to the following gradient
∇u Ē32
k
=
+
+
−
−
−
+
+
+
B2k
uk−1 (x−
k ) − (B2k + B2k )uk (x) + B2k uk+1 (xk )
h2
−
− uk (x) − uk−1 (xk )
Fk
B2k
h
−
−
+
+
+ B2k ∇uk−1 (x−
k ) − (B2k + B2k )∇uk (x) + B2k ∇uk+1 (xk )
γ∇·
h2
−
− ∇uk (x) − ∇uk−1 (xk )
Fk
γ∇· B2k
h
−
while, for energy
Ē33 (u, v)
1X
=
2
k∈Z
the gradient is given by
∇u Ē33
k
=
+
+
−
Z
R2
(34a)
(34b)
(34c)
(34d)
h 2 i
2 Lh+
dx
φ Lh+
v u k
v u k + γφ
−
−
+
+
+
B1k
uk−1 (x−
k ) − (B1k + B1k )uk (x) + B1k uk+1 (xk )
2
h
−
u
(x)
−
u
(x
)
k−1 k
− k
B1k
Fk
h
−
−
+
+
+ B3k ∇uk−1 (x−
k ) − (B3k + B3k )∇uk (x) + B3k ∇uk+1 (xk )
γ∇·
h2
−
− ∇uk (x) − ∇uk−1 (xk )
Fk .
γ∇· B3k
h
−
(35a)
(35b)
(35c)
(35d)
In the three cases care must be taken when dealing with the transport-like terms that appear in the
different expressions above. While schemes resulting from (33) are relatively easy to implement, modulo
of course transport-like term, care is to be taken for schemes (34) and (35) due to the presence of spatial
divergence. When properly dealt with, a numerical scheme is then available.
Before continuing, important points regarding the above energies and schemes must be addressed.
• The use of the forward difference approximations in the energies have also an effect on their gradients
with respect to the displacement field variable. An elementary computation for the case of Ē31 gives
∇v Ē31 k = B1 k + Lh+
v u k ∇uk+1 ◦ Hk
where the warping Hk appears naturally and corresponds precisely to the type of computations
performed in multiresolution motion recovery. Remark that only Hk is used there and that there
is no assumption on its inversibility.
• Being coherent with Lie derivatives approximations above, our motion recovery algorithm will
normally return only the forward displacement field v = (vk )k of the sequence, and thus we have
only directly access to the forward warp Hk . How to compute the backward displacement field w?
Inversion of the Hk is generally not an option: even in the case where Hk was a true diffeomorphism,
this would extremely complex. Moreover occlusion and disocclusion phenomena make it impossible.
However, a simple solution consists in computing this backward flow from the image sequence
itself. This should provide a reasonable solution for at least a good reason: Given an image
u : R2 × [0, T ] → R, let us denote by û the “time-reversed” sequence obtained as
û(x, t) := u(x, T − t).
Assume that u is smooth. Then, taking the flow related part of our energy, i.e. Eij = λ3 E3i + λ4 E4j ,
an elementary computation shows that if v minimizes Eij , so is −v for the image sequence û. We
could replace the optical flow estimation by a symmetrized version, in the spirit of the work of
Alvarez et al. in [1], but this would deeply modify the formulations above.
6 EXPERIMENTAL EVALUATION
19
• All the above gradients have some transport-like terms, e.g the term (33b) in the expression of
∇u Ē31 . Such a term may be difficult to handle numerically. One can ask whether it is necessary. In
an informal way, we do expect that the diffusion term (33a) alone will smooth variations of u along
the flow lines, and thus decrease the energy, i.e. that even when forgetting the transport term, the
resulting expression would still be a descent direction for the energy, so should be consider for both
explicit gradient descent resolution as well as some relaxation schemes. This however no so simple,
as (33a) involves not only forward Lie derivatives but also backward ones while only forward ones
are present in the semi-discrete energy. In the other hand, our flow regularizers generally favor
displacement fields with small divergence, thus generally reducing the influence of the transport
part.
5.2
Multiresolution details
As mentioned in Section 4.1, we solve the equations in a multiresolution framework. A few points should
be mentioned. When building the multiresolution pyramid, image coarsening is necessary, and is in fact
already handled by the motion estimation solver. What is not handled is the coarsening of the inpainting
mask, i.e the numeric characteristic function of the missing data locus Ω. Coarsening of the image is
usually performed by smoothing ans subsampling or any kind of method that has a proper low pass
property. Coarsening of χΩ may be problematic when the same method is used. It blurs the boundary of
Ω, and while this blurring may seem coherent, as it may indicate that a given pixel at coarse resolution
contains some known partial information, we have constated that it often slows convergence down. We
have used instead the somehow rough but simple nearest neighbor approach that guaranties that the
mask remains binary valued and not become “too large” when coarsening.
In the other hand, one also need to interpolate the inpainting result from a given level to the next
finer level, while interpolation of the motion is performed already by the flow recovery algorithm. In
this work, image interpolation has been performed using a simple bilinear interpolation for inpainting
denoising, while for pure inpainting, values obtained by bilinear interpolation and not in the missing data
locus have been replaced by original image values downsampled at that resolution.
5.3
Solving the equations
Inpainting equations involving terms E32 and E33 are 4th-orders partial differential equations, with diffusion
of gradients. This type of higher order diffusion may not obey the minimum-maximum principle, see for
instance [27]. We rely therefore on a gradient descent scheme in these cases. For each resolution level we
do the following. Having chosen an evolution step dτ , we create the family un = (unk )k , n ≥ 0 and write
a standard Eulerian step
un+1
(x) − unk (x)
k
= − ∇un Ē(x) k
dτ
¯
¯
where Ē is either of the form λ1 E1 +λ2 E2 +λ3 E3i in the inpainting-denoising case, with (x, k) running over
the full spatio-temporal grid in that case, while in the pure inpainting case Ē has the form λ2 E¯2 + λ3 E3i
and (x, k) runs only on the missing data locus, i.e the discretized and downsampled copy of Ω.
In the implementation, we choose once for all the evolution step dτ as well as the number N of evolution
steps we perform. As in most explicit schemes, dτ must be chosen small enough, and this has a drastic
impact on the running-time, particularly in the case of inpainting denoising.
In the case where we use E31 , we may consider, in a fixed point approach, linearizing the resulting
equations and solvers such as Gauss-Seidel could be used. In order to be able to compare the different
methods, we have however in that work only used the explicit Gradient Descent approach.
6
Experimental Evaluation
We present results for several of the algorithms we have discussed, on synthetic and real sequences. We
follow the nomenclature of energy terms presented in Section 3, Tables 1 and 2. To accommodate the
variety of intensity ranges in the different sequences, intensities have been linearly normalized to range
20
6 EXPERIMENTAL EVALUATION
[0, 1]. This imply that numerical partial derivatives are bounded in absolute value, by bounds
√ of the same
order of magnitude, which in turns influences the practical range of ε values in φ(x2 ) = x2 + ε2 , we
have taken ε = 10−3 . In all gradient descents, we have used an algorithmic time step dt = 10−3 . This in
turns influences the choices of the different weights λi for the corresponding energies.
Although flow regularization term E41 has been used, we only report results for term E42 in the experiments we present here, as it has been argued [11, 12] that temporal regularity prior generally improves
motion estimation.
We present a series of stills in this section, the reader should also look at the companion sequences, they
are available at the location http://image.diku.dk/francois/seqinp. Some previous versions were
available at the the companion web site http://www-sop.inria.fr/books/imath for the monograph of
Aubert and Kornprobst [6].
The first one is the well known Yosemite sequence, created by Lynn Quam, very often used for optical
flow evaluation. The sequence is artificial and the ground truth is known for the flow. It was degraded by
removing large polygonal patches, three of them overlapping consecutively in time, on 6 of the 15 frames.
Figure 2 shows frames 2, 3, and 4 of the original sequence, corresponding degraded frames, and the
noisy degraded ones where Gaussian noise of standard deviation 5% of the intensity range was added.
(a) original frame 3
(b) original frame 4
(c) original frame 5
(d) degraded frame 3
(e) degraded frame 4
(d) degraded frame 5
Figure 2: Yosemite sequence. Original and degraded frames. The degradation in frame 3 is very large
and one can notice that the 3 holes overlap around the frame centers.
We first run a simplified experiment where only the pure inpainting equation derived from terms E2
and E31 is solved and then the inpainting/denoising using the same spatial and trajectory smoothness
21
6 EXPERIMENTAL EVALUATION
terms. We use the ground truth forward flow ~vf . We deal with the absence of ground truth for the
backward optical flow ~vb by computing it from the optical flow PDE derived from terms E31 and E42 ,
having reversed time in the sequence and using as starting guess t 7→ −~vf (T − t) where T is the forward
flow sequence last time/frame.
Figure 3 present the results of these two experiments on the three degraded frames show in Fig.
2. For pure Inpainting, parameters where λ2 = 0.1 (spatial regularization weight), λ3 = 1 (flow lines
regularization weight). For inpainting / denoising, the data weight λ1 has been set to 20, while λ2 = λ3 =
1. Results of pure inpainting presented in (a), (b) and (c) are generally very good, one may however notice
a lack on sharpness in the center of frames (a) and (b). Unsurprisingly, inpainted/denoised results present
characteristics of Total Variation regularized images, some low scale details have been lost. Boulanger
et al. [10] as well as Buades et al. [14] have shown that image sequence denoising is best achieved with
patch based / non local means methods. Nevertheless, they cannot cope as is with large missing data.
It may be worth investigating developing an hybrid method in that case.
(a) pure inpainting frame 3
(b) pure inpainting frame 4
(c) pure inpainting frame 4
(d) inpainted/denoised frame 3
(e) inpainted/denoised frame 4
(f) inpainted/denoised frame 5
Figure 3: Pure Inpainting and Inpainting/Denoising based on ground truth motion. While pure inpainted
sequence is of excellent quality, the inpainted/denoised shows the usual patterns of Total-Variation like
regularization with loss of fine scale details.
In the second set of experiments, we abandon the ground truth and run full recovery algorithms on
the Yosemite sequence. In the first one, we run the pure inpainting algorithm corresponding to energy
λ2 E2 + λ3 E31 + λ4 E42 with λ2 = 0.1, λ3 = 1 and λ4 = 0.2, four pyramid levels where the number of pixels
is roughly divided by 2 from one level to the next coarser one. Then Energy λ2 E2 +λ3 E31 +λ4 E42 has been
used, withe the gradient weight γ = 0.1, and these parameters, as well as pyramid sizes, have been used
in all the remaining experiments presented in this work, except for the Manon sequence. Results are shown
in Figure 4. Spotting visually differences between the two sequences is difficult, although computing the
differences, as illustrated on the last row of Figure 4 shows some, covering about 7% of the intensity
range, while a plot of histograms of gradient magnitudes for the two results seems to indicate that this
difference is in fact hardly significative. These histograms are shown in figure 5.
The second example is taken from the companion CD ROM of Kokaram’s book [33]. We start with the
Mobile and Calendar sequence, that have been extensively used for MPEG coding, deinterlacing and so
on. It is a real one with 25 frames and with complex motion patterns. It is then artificially degraded to
simulate blotches. (approximately 6% of the image is degraded with blocthes of multiple size, they may
22
6 EXPERIMENTAL EVALUATION
(a)
(b)
(c)
(d)
(e)
(f)
(g)
(h)
(i)
Figure 4: Full Image and Motion recovery in the case of pure Inpainting. The first row from minimization
of low-order energy E2 + E31 + E42 , the second from higher order energy E2 + E32 + E42 and the last row
shows the differences.
450
450
Gradient magnitude for first Inpainting method
Gradient magnitude for second method
400
400
350
350
300
300
250
250
200
200
150
150
100
100
50
50
0
0.2
0.25
0.3
0.35
0.4
0.45
0.5
0.55
0.6
0.65
0
0.2
0.25
0.3
0.35
0.4
0.45
0.5
0.55
0.6
0.65
Figure 5: Comparisons of gradient magnitudes in inpainted regions. (a) when using energy term E31 , (b)
when using energy term E32 . They are almost identical.
7 CONCLUSION
23
overlap in time. Here too the energy E2 + E33 + E42 was used, with the same parameters as above. Figure
6 presents four frames of the degraded sequence, the inpainting results using energy (E2 , E33 , E42 ), and a
solver where the optical flow is computed with this energy while for the inpainting we use the lower order
equation (equivalently setting the gradient parameter γ to 0 in E33 ). Differences are non significative.
This too substantiates the idea that the lower order inpainting equation is a good descent direction.
The third sequence, Manon is a real color sequence acquired by the first author with a mobile device,
featuring the author’s daughter. The original sequence was encoded with the 3G format, a simplified
MPEG format for third generation mobile devices. It has been artificially degraded with red blotches and
inpainted with the vectorial form of the energy (E2 , E32 , E42 ) with λ2 = 0.1, λ3 = 1, γ = 0.1 and λ4 = 0.02
a value 5 times smaller than in the other experiments, because a too large values caused problems in the
recovery of hair motion among others. By its encoding and its nature, a face with non rigid motion, it
presents some challenges. Three original frames, 7, 8 and 9, the corresponding degraded sequences as
well as the inpainted ones are presented on Figure 7. The result is visually very good. Nevertheless, some
serious problems were encountered at other locations of the sequence and Figure 8 presents some of the
encountered problems at the 5th frame of the sequence, where a portion of the hair and of an eye are
wrongly interpolated.
The fourth and last sequence, called Frankenstein, also taken from Kokaram’s book, is a real degraded one, with 64 frames, for which no ground truth is known. In our experimentations we used only
a subsequence of 21 frames, with frame 8 presenting, among others, a relatively large blotch on Frankenstein’s hair. In figure 9 we show this frame, the detected blotch and its reconstruction. In figure 10 we
show a close-up of the damaged hair of the character with the detected blotch and the reconstruction.
Blotches were detected using the so called Rank Order Detector (ROD), as described in [33], modified
for the optical flow algorithm. Fine texture details were very plausibly recreated.
7
Conclusion
In this paper we have introduced a generic variational formulation for joint recovery of motion and
intensity in degraded image sequences, dealing both with noise and missing data. This generic formulation
has been instantiated in several energy formulations, mostly based on known motion recovery approached.
They give rise to system of partial differential equations, for motion and intensity. We have focused on
the intensity ones and developed schemes to handle them numerically. We have validated our approach
on a series of experiments. While they provide often excellent results, they are generally computationally
demanding, especially due to higher order equations to solve for Inpainting. Is such complex equation
necessary? We discussed that a simpler equation might still provide a good descent direction when
minimizing a higher order energy, and we presented an experiment that substantiate this idea: there is a
difference, but the result obtained with lower order equation is visually good. The possibility of using a
lower order equation opens the door for much more efficient solvers: multigrid solvers where developed for
optical flow by [40] as well as [13] and we are currently working on developing fast multigrid schemes for
lower order inpainting equations. The general multiresolution optimization framework that we have used,
decouples, at each pyramid level, the computation of the flows and the images. We are also investigating
more coupled methods, also within the multigrid framework.
References
[1] L. Alvarez, R. Deriche, T. Papadopoulo, and J. Sanchez. Symmetrical dense optical flow estimation
with occlusion detection. In A. Heyden, G. Sparr, M. Nielsen, and P. Johansen, editors, Proceedings
of the 7th European Conference on Computer Vision, pages 721–735, Copenhagen, Denmark, May
2002. Springer–Verlag.
[2] L. Alvarez, R. Deriche, J. Weickert, and J. Sànchez. Dense disparity map estimation respecting
image discontinuities: A PDE and scale-space based approach. Journal of Visual Communication
and Image Representation, Special Issue on Partial Differential Equations in Image Processing,
Computer Vision and Computer Graphics, 13(1–2):3–21, 2002.
REFERENCES
24
Figure 6: On the first column, frames 10, 11, 12 and 13 of the degraded Mobile and Calendar sequence.
The second column shows the results of minimization of energy E2 + E33 + E42 while the last column shows
the results when the corresponding inpainting equation is replaced by the low order one.
REFERENCES
25
Figure 7: On the first column, frames 7,8 and 9 of the original Manon sequence. The second column shows
the corresponding degraded frames and the last column the results of the color inpainting using Energy
(E2 , E32 , E42 ).
Figure 8: Original, degraded and inpainted frame 5 of the Manon sequence. Problems can be observed in
the reconstruction of the left eye as well as part of the hair above it.
REFERENCES
26
Figure 9: The Frankenstein sequence. From left to right: Frame 8, ROD detected defects and inpainting. by minimizing energy E2 + E32 + E42
Figure 10: The Frankenstein sequence: Close-up of the hair blotch, its detection and its inpainting
.
[3] L. Alvarez, J. Weickert, and J. Sànchez. Reliable estimation of dense optical flow fields with large
displacements. The International Journal of Computer Vision, 39(1):41–56, August 2000.
[4] G. Aubert, R. Deriche, and P. Kornprobst. Computing optical flow via variational techniques. SIAM
Journal of Applied Mathematics, 60(1):156–182, 1999.
[5] G. Aubert and P. Kornprobst. A mathematical study of the relaxed optical flow problem in the
space BV. SIAM Journal on Mathematical Analysis, 30(6):1282–1308, 1999.
[6] G. Aubert and P. Kornprobst. Mathematical Problems in Image Processing: Partial Differential
Equations and the Calculus of Variations, Second edition, volume 147 of Applied Mathematical Sciences. Springer, 2006.
[7] C. Ballester, M. Bertalmio, V. Caselles, G. Sapiro, and J. Verdera. Filling-in by joint interpolation
of vector fields and gray levels. IEEE Transactions on Image Processing, 10(8):1200–1211, 2001.
[8] D. Béréziat, I. Herlin, and L. Younes. A generalized optical flow constraint and its physical interpretation. In Proceedings of the International Conference on Computer Vision and Pattern Recognition,
volume 2, pages 487–492, Hilton Head Island, South Carolina, June 2000. IEEE Computer Society.
[9] M. Bertalmio, G. Sapiro, V. Caselles, and C. Ballester. Image inpainting. In Kurt Akeley, editor,
Proceedings of the SIGGRAPH, pages 417–424. ACM Press, ACM SIGGRAPH, Addison Wesley
Longman, 2000.
[10] J. Boulanger, C. Kervrann, and P. Bouthemy. Space-Time Adaptation for Patch-Based Image
Sequence Restoration. IEEE Transactions on Pattern Analysis and Machine Intelligence, 29(6):1096–
1102, 2007.
REFERENCES
27
[11] T. Brox, A. Bruhn, N. Papenberg, and J. Weickert. High accuracy optical flow estimation based on a
theory for warping. In T. Pajdla and J. Matas, editors, Proceedings of the 8th European Conference
on Computer Vision, volume 4, pages 25–36, Prague, Czech Republic, 2004. Springer–Verlag.
[12] A. Bruhn and J. Weickert. Towards Ultimate Motion Estimation: Combining Highest Accuracy Optical Flow with Real-Time Performance. In International Conference on Computer Vision, volume 1,
pages 749–755, Beijing, China, 2005. IEEE Computer Society Press.
[13] A. Bruhn, J. Weickert, T. Kolhberger, and C. Schnörr. A Multigrid Platform for Real-Time Motion
Computation With Discontinuity-Preserving Variational Methods. The International Journal of
Computer Vision, 70(3):257–277, 2006.
[14] A. Buades, B. Coll, and J. M. Morel. Nonlocal Image and Movie Denosing. The International
Journal of Computer Vision, 76(2):123–139, 2008.
[15] A. Buades, J. Delon, Y. Gousseau, and S. Masnou. Adaptive blotch detection for film restoration. In
Proceedings of International Conference on Image Processing, pages 3317–3320, Hong-Kong, China,
September 2010. IEEE, IEEE.
[16] T. Chan and J. Shen. Mathematical models for local nontexture inpainting. SIAM journal of appl.
Math, 62(3):1019–1043, 2002.
[17] T.F. Chan and J. Shen. Non-texture inpainting by curvature-driven diffusions (cdd). J. Visual
Comm. Image Rep., 12(4):436–449, 2001.
[18] J.P. Cocquerez, L. Chanas, and J. Blanc-Talon. Simultaneous inpainting and motion estimation of
highly degraded video-sequences. In Scandinavian Conference on Image Analysis, pages 523–530.
Springer-Verlag, 2003. LNCS, 2749.
[19] A. Criminisi, P. Pérez, and K. Toyama. Region filling and object removal by exemplar-based inpainting. IEEE Trans. Image Processing, 13(9):1200–1212, 2004.
[20] L. d’Amore, L. Marcellino, and A. Murli. Image Sequence Inpainting: Towards Numerical Software
for Detection and Removal of Local Missing Data with Motion Estimation. Journal of Computational
and Applied Mathematics, 198(2):396–413, January 2007.
[21] Alexei A. Efros and William T. Freeman. Image quilting for texture synthesis and transfer. Proceedings of SIGGRAPH 2001, pages 341–346, August 2001.
[22] Alexei A. Efros and Thomas K. Leung. Texture synthesis by non-parametric sampling. In IEEE
International Conference on Computer Vision, pages 1033–1038, Corfu, Greece, September 1999.
[23] L.C. Evans. Partial Differential Equations, volume 19 of Graduate Studies in Mathematics. Proceedings of the American Mathematical Society, 1998.
[24] L. Florack, W. Niessen, and M. Nielsen. The intrinsic structure of optic flow incorporating measurement duality. The International Journal of Computer Vision, 27(3):263–286, 1998.
[25] S. Gallot, D. Hulin, and J. Lafontaine. Riemannian Geometry. Springer-Verlag, 1990.
[26] S. Geman and D. Geman. Stochastic relaxation, Gibbs distributions, and the Bayesian restoration
of images. IEEE Transactions on Pattern Analysis and Machine Intelligence, 6(6):721–741, 1984.
[27] G. Gilboa, Y. Y. Zeevi, and N. Sochen. Image Sharpening by Flows Based on Triple Well Potential.
Journal of Mathematical Imaging and Vision, 20(1–2):121–131, January–March 2004.
[28] H. Grossauer. Inpainting of Movies Using Optical Flow. In O. Scherzer, editor, Mathematical Methods
in Registration for Applications in Industry and Medicine, pages 151–164. Springer, 2006.
[29] M. Irani and S. Peleg. Motion analysis for image enhancement: resolution, occlusion, and transparency. Journal on Visual Communications and Image Representation, 4(4):324–335, 1993.
REFERENCES
28
[30] S. H. Keller, F. Lauze, and M. Nielsen. Motion Compensated Video Super Resolution. In F. Sgallari,
A. Murli, and N. Paragios, editors, Proceedings of the First International Conference on Scale Space
and Variational Methods in Computer Vision, volume 4485 of LNCS, pages 801–812, Berlin, 2007.
Springer.
[31] S. H. Keller, F. Lauze, and M. Nielsen. Deinterlacing Using Variational Methods. IEEE Transactions
on Image Processing, 17(11):2015–2028, 2008.
[32] S. .H. Keller, F. Lauze, and M. Nielsen. Temporal Super Resolution. In M. Mrak, M. Kunt, and
M. Grgic, editors, High-quality Visual Experience: creation, processing and interactivity of highresolution and high-dimensional video signals (to appear), Signal and Communication Technologies.
Springer, 2010.
[33] A. Kokaram. Motion Picture Restoration: Digital Algorithms for Artefact Suppression in Degraded
Motion Picture Film and Video. Springer, 1998.
[34] A. Kokaram. On Missing Data Treatment for Degraded Video and Film Archives: A Survey and a
New Bayesian Approach. IEEE Transactions on Image Processing, 13(3):397–415, March 2004.
[35] A. Kokaram, R. Morris, W. Fitzgerald, and P. Rayner. Interpolation of Missing Data in Image
Sequences. IEEE Transactions on Image Processing, 4(11):1509–1519, 1995.
[36] F. Lauze and M. Nielsen. A variational algorithm for motion compensated inpainting. In S. Barman
A. Hoppe and T. Ellis, editors, British Machine Vision Conference, volume 2, pages 777–787. BMVA,
2004.
[37] M. Lysaker, A. Lundervold, and X-C. Tai. Noise removal using fourth-order partial differential equations with applications to medical magnetic resonnance images in space and time. IEEE Transactions
on Image Processing, 12(12):1579–1590, 2003.
[38] S. Masnou and J.M. Morel. Level lines based disocclusion. International Conference on Image
Processing, III:259–263, 1998.
[39] E. Mémin. Estimation du flot optique: contributions et panorama des différentes approches.
IRISA+IFSIC, July 2003. Document d’habilitation à diriger des recherches.
[40] E. Mémin and P. Pérez. Hierarchical estimation and segmentation of dense motion fields. The
International Journal of Computer Vision, 46(2):129–155, 2002.
[41] D. Mumford. Bayesian rationale for the variational formulation. In Geometry-Driven Diffusion In
Computer Vision, pages 135–146. Kluwer Academic Publishers, 1994. Computational Imaging And
Vision.
[42] H.H. Nagel and W. Enkelmann. An investigation of smoothness constraint for the estimation of displacement vector fields from image sequences. IEEE Transactions on Pattern Analysis and Machine
Intelligence, 8:565–593, 1986.
[43] M. Nikolova. Weakly Constrained Minimization: Application to the Estimation of Images and
Signals Involving Constant Regions. Journal of Mathematical Imaging and Vision, 21(2):155–175,
2004.
[44] K. A. Patwardhan, G. Sapiro, and M. Bertalmio. Video Inpainting of Occluding and 0ccluded
0bjects. In International Conference on Image Processing, volume II(2), pages 69–72, 2005.
[45] K. A. Patwardhan, G. Sapiro, and M. Bertalmio. Video Inpainting Under Constrained Camera
Motion. IEEE Transactions on Image Processing, 16(2):545–553, Feb 2007.
[46] L. Rudin, S. Osher, and E. Fatemi. Nonlinear total variation based noise removal algorithms. Physica
D, 60:259–268, 1992.
REFERENCES
29
[47] A. Verri and T. Poggio. Motion field and optical flow: qualitative properties. IEEE Transactions on
Pattern Analysis and Machine Intelligence, 11(5):490–498, 1989.
[48] X. Wang and M. Mirmehdi. Hmm based archive film defect detection with spatial and temporal
constraints. In Proceedings of BMVC. BMVA, 2009.
[49] X. Wang and M. Mirmehdi. Archive film restoration based on spatiotemporal random walks. In
Proceedings of the 11th European Conference on Computer Vision, volume 6315 of LNCS, pages
478–491, Heraklion, Greece, September 2010. Springer.
[50] J. Weickert and C. Schnörr. A Theoretical Framework for Convex Regularizers in PDE-Based
Computation of Image Motion. The International Journal of Computer Vision, 45(3):245–264,
December 2001.
[51] Y. Wexler, E. Shechtman, and M. Irani. Space-Time Completion of Videos. IEEE Transactions on
Pattern Analysis and Machine Intelligence, 29(3):463–467, 2007.
[52] R.P. Wildes, M.J. Amabile, A.M. Lanzillotto, and T.S. Leu. Physically based fluid flow recovery
from image sequences. In International Conference on Computer Vision and Pattern Recognition,
pages 969–975, 1997.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
