Food Processor Stainless Steel Cutter Mixer - 17.5 Main Features

Food Processor Stainless Steel Cutter Mixer - 17.5 Main Features
ITEM #
MODEL #
NAME #
Food Processor
Stainless Steel Cutter Mixer - 17.5
LT - Variable Speed, smooth blades
SIS #
AIA #
Main Features
• Variable speed from 300 to 3000.
• Cutter-mixer allows fast liquidising, mixing and mincing.
• 304 AISI stainless steel bowl with leak resistant spout and
watertight seal and handles.
• Large central rotating shaft that allows liquids to be mixed
without overflowing.
• Angled blades and conical base of the bowl ensure
consistent mixing.
• Spout allows products to be added in mid-cycle.
• Transparent polycarbonate cover incorporates a magnetic
contact safety system.
• Supplied with smooth blade rotor.
• IP65 touch button control panel.
• 1 of Smooth blade rotor for 17,5 lt cutter
• 1 of Stainless steel bowl 17,5 lt
PNC 653119
PNC 653272
Optional Accessories
Food Processor
Stainless Steel Cutter Mixer - 17.5 LT Variable Speed, smooth blades
603310 (KE180F)
Stainless Steel Cutter Mixer 17.5 LT - Variable Speed,
smooth blades 380-440V/3/50-60
•
•
•
•
•
•
Mobile support for cutters
Smooth blade rotor for 17,5 lt cutter
Serrated blade rotor for 17,5 lt cutter
Stainless steel bowl 17,5 lt
Equipped scraper
Serrated blade rotor for meat for 17,5 lt
cutter
Short Form Specification
Item No.
Unit to be Electrolux KE180 Cutter Mixer. Electrical characteristics to be ___380-440V
single phase operation with variable speed rotor from 300-3000 rpm. The KE180 is a simple
and robust cutter that allows all types of liquidising, mixing and mincing, performed in a
matter of seconds without warming up or altering the product.
APPROVAL:
Electrolux Professional
www.electrolux.com/foodservice
[email protected]
PNC 653017 ❑
PNC 653119 ❑
PNC 653120 ❑
PNC 653272 ❑
PNC 653279 ❑
PNC 653539 ❑
Food Processor
Stainless Steel Cutter Mixer - 17.5 LT - Variable Speed, smooth
blades
Included Accessories
Food Processor
Stainless Steel Cutter Mixer - 17.5
LT - Variable Speed, smooth blades
Front
Electric
Supply voltage:
603310(KE180-03)
Connected load:
Total Watts:
380/440 V/3 ph/50/60 Hz
3 kW
3 kW
Key Information
Top
External dimensions, Height
603 mm
External dimensions, Width
416 mm
External dimensions, Depth
680 mm
External dimensions, Weight
68 kg
Shipping weight:
75 kg
Fine mixtures capacity:
8 kg
Meat mincing capacity:
8 kg
Condiments chopping capacity:
5 kg
Mayonnaise preparation capacity: 8 kg
Pastry preparation capacity:
6 kg
Prepares:
- Mincing meats (tartare, sausage meat, patés, stuffing,
mousses, etc.)
- Chopping condiments (parsley, garlic. onions, shallots, spices,
etc.)
- Preparation of mayonnaise, mashes, flavoured butters, purées,
compotes, etc.)
- Liquidising frozen foodstuffs, fish soups with shellfish, etc.
- Preparation of all types of pastry.
- Pastrywork (almond paste, sugared almonds, half and half, etc.)
EI = Electrical connection
Side
Food Processor
Stainless Steel Cutter Mixer - 17.5 LT - Variable Speed, smooth blades
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
2010.04.06
